Name SIM900_ATC_V1.00 SIM900 ATC V1.00
SIM900_ATC_V1_00
User Manual: SIM900_ATC_V1.00
Open the PDF directly: View PDF .
Page Count: 198 [warning: Documents this large are best viewed by clicking the View PDF Link!]
- Version History
- 1 Introduction
- 2 AT Commands According to V.25TER
- 2.1 Overview of AT Commands According to V.25TER
- 2.2 Detailed Description of AT Commands According to V.25TER
- 2.2.1 A/ Re-issues The Last Command Given
- 2.2.2 ATA ANSWER AN INCOMING CALL
- 2.2.3 ATD Mobile Originated Call To Dial A Number
- 2.2.4 ATDL Redial Last Telephone Number Used
- 2.2.5 ATE Set Command Echo Mode
- 2.2.6 ATH Hang up a call
- 2.2.7 ATI Display Product Identification Information
- 2.2.8 ATL Monitor speaker loudness
- 2.2.9 ATM Monitor Speaker Mode
- 2.2.10 +++ Switch From Data Mode Or PPP Online Mode To Command Mode
- 2.2.11 ATO Switch From Command Mode To Data Mode
- 2.2.12 ATP Select Pulse Dialing
- 2.2.13 ATQ Set Result Code Presentation Mode
- 2.2.14 ATS0 Set Number Of Rings Before Automatically Answering The Call
- 2.2.15 ATS3 Set Command Line Termination Character
- 2.2.16 ATS4 Set Response Formatting Character
- 2.2.17 ATS5 Set Command Line Editing Character
- 2.2.18 ATS6 Set Pause Before Blind Dialing
- 2.2.19 ATS7 Set Number Of Seconds To Wait For Connection Completion
- ATS7 Set Number Of Seconds To Wait For Connection Completion
- 2.2.20 ATS8 Set Number Of Second To Wait For Comma Dial Modifier Encountered In Dial String Of D Command
- 2.2.21 ATS10 Set Disconnect Delay After Indicating The Absence Of Data Carrier
- 2.2.22 ATT Select Tone Dialing
- 2.2.23 ATV TA Response Format
- 2.2.24 ATX Set CONNECT Result Code Format And Monitor Call Progress
- 2.2.25 ATZ Reset default configuration
- 2.2.26 AT&C Set DCD Function Mode
- 2.2.27 AT&D Set DTR Function Mode
- 2.2.28 AT&F Factory defined configuration
- 2.2.29 AT&V Display Current Configuration
- 2.2.30 AT&W Store Active profile
- 2.2.31 AT+GCAP Request Complete TA Capabilities List
- 2.2.32 AT+GMI Request Manufacture Identification
- 2.2.33 AT+GMM Request TA Model Identification
- 2.2.34 AT+GMR Request TA Revision Identification Of Software Release
- 2.2.35 AT+GOI Request Global Object Identification
- 2.2.36 AT+GSN Request TA Serial Number Identification (IMEI)
- 2.2.37 AT+ICF Set TE-TA Control Character Framing
- 2.2.38 AT+IFC TE-TA local flow control
- 2.2.39 AT+IPR Set TE-TA Fixed Local Rate
- 2.2.40 AT+HVOIC Disconnect Voice Call Only
- 3 AT Commands According to GSM07.07
- 3.1 Overview of AT Command According to GSM07.07
- 3.2 Detailed Descriptions of AT Command According to GSM07.07
- 3.2.1 AT+CACM Accumulated Call Meter (ACM) Reset Or Query
- 3.2.2 AT+CAMM Accumulated Call Meter Maximum (ACM max) Set Or Query
- 3.2.3 AT+CAOC Advice Of Charge
- 3.2.4 AT+CBST Select Bearer Service Type
- 3.2.5 AT+CCFC Call Forwarding Number And Conditions
- 3.2.6 AT+CCWA Call Waiting Control
- 3.2.7AT+CEER Extended Error Report
- 3.2.8 AT+CGMI Request Manufacturer Identification
- 3.2.9 AT+CGMM Request Model Identification
- 3.2.10 AT+CGMR Request TA Revision Identification Of Software Release
- 3.2.11 AT+CGSN Request Product Serial Number Identification (Identical With +GSN)
- 3.2.12 AT+CSCS Select TE Character Set
- 3.2.13 AT+CSTA Select Type Of Address
- 3.2.14 AT+CHLD Call Hold And Multiparty
- 3.2.15 AT+CIMI Request International Mobile Subscriber Identity
- 3.2.16 AT+CLCC List Current Calls Of ME
- 3.2.17 AT+CLCK Facility Lock
- 3.2.18 AT+CLIP Calling Line Identification Presentation
- 3.2.19 AT+CLIR Calling Line Identification Restriction
- 3.2.20 AT+CMEE Report Mobile Equipment Error
- 3.2.21 AT+COLP Connected Line Identification Presentation
- 3.2.22 AT+COPS Operator Selection
- 3.2.23 AT+CPAS Phone Activity Status
- 3.2.24 AT+CPBF Find Phonebook Entries
- 3.2.25 AT+CPBR Read Current Phonebook Entries
- 3.2.26 AT+CPBS Select Phonebook Memory Storage
- 3.2.27 AT+CPBW Write Phonebook Entry
- 3.2.28 AT+CPIN Enter PIN
- 3.2.29 AT+CPWD Change Password
- 3.2.30 AT+CR Service Reporting Control
- 3.2.31 AT+CRC Set Cellular Result Codes For Incoming Call Indication
- 3.2.32 AT+CREG Network Registration
- 3.2.33 AT+CRLP Select Radio Link Protocol Parameter
- 3.2.34 AT+CRSM Restricted SIM Access
- 3.2.35 AT+CSQ Signal Quality Report
- 3.2.36 AT+FCLASS FAX: Select, Read Or Test Service Class
- 3.2.38 AT+FMI FAX: Report Manufactured ID
- 3.2.39 AT+FMM FAX: Rreport Model ID
- 3.2.40 AT+FMR FAX: Report Revision ID
- 3.2.41 AT+VTD Tone Duration
- 3.2.42 AT+VTS DTMF And Tone Generation
- 3.2.43 AT+CMUX Multiplexer Control
- 3.2.44 AT+CNUM Subscriber Number
- 3.2.45 AT+CPOL Preferred Operator List
- 3.2.46 AT+COPN Read Operator Names
- 3.2.47 AT+CFUN Set Phone Functionality.
- 3.2.48 AT+CCLK Clock
- 3.2.49 AT+CSIM Generic SIM Access
- 3.2.50 AT+CALM Alert Sound Mode
- 3.2.51 AT+CRSL Ringer Sound Level
- 3.2.52 AT+CLVL Loud Speaker Volume Level
- 3.2.53 AT+CMUT Mute Control
- 3.2.54 AT+CPUC Price Per Unit And Currency Table
- 3.2.55 AT+CCWE Call Meter Maximum Event
- 3.2.56 AT+CBC Battery Charge
- 3.2.57 AT+CUSD Unstructured Supplementary Service Data
- 3.2.58 AT+CSSN Supplementary Services Notification
- 4 AT Commands According to GSM07.05
- 4.1 Overview of AT Commands According to GSM07.05
- 4.2 Detailed Descriptions of AT Commands According to GSM07.05
- 4.2.1 AT+CMGD Delete SMS Message
- 4.2.2 AT+CMGF Select SMS Message Format
- 4.2.3 AT+CMGL List SMS Messages From Preferred Store
- 4.2.4 AT+CMGR Read SMS Message
- 4.2.5 AT+CMGS Send SMS Message
- 4.2.6 AT+CMGW Write SMS Message To Memory
- 4.2.7 AT+CMSS Send SMS Message From Storage
- 4.2.8 AT+CNMI New SMS Message Indications
- 4.2.9 AT+CPMS Preferred SMS Message Storage
- 4.2.10 AT+CRES Restore SMS Settings
- 4.2.11 AT+CSAS Save SMS Settings
- 4.2.12 AT+CSCA SMS Service Center Address
- 4.2.13 AT+CSCB Select Cell Broadcast SMS Messages
- 4.2.14 AT+CSDH Show SMS Text Mode Parameters
- 4.2.15 AT+CSMP Set SMS Text Mode Parameters
- 4.2.16 AT+CSMS Select Message Service
- 5 AT Commands for SIM Application Toolkit
- 6 AT Commands Special for SIMCOM
- 6.1 Overview
- 6.2 Detailed Descriptions of Commands
- 6.2.1 AT+SIDET Change The Side Tone Gain Level
- 6.2.2 AT+CPOWD Power Off
- 6.2.3 AT+SPIC Times Remain To Input SIM PIN/PUK
- 6.2.4 AT+CMIC Change The Microphone Gain Level
- 6.2.5 AT+CALA Set Alarm Time
- 6.2.6 AT+CADC Read ADC
- 6.2.7 AT+CSNS Single Numbering Scheme
- 6.2.8 AT+CDSCB Reset Cell Broadcast
- 6.2.9 AT+CMOD Configure Alternating Mode Calls
- 6.2.10 AT+CFGRI Indicate RI When Using URC
- 6.2.11 AT+CLTS Get Local Timestamp
- 6.2.12 AT+CEXTHS External Headset Jack Control
- 6.2.13 AT+CEXTBUT Headset Button Status Reporting
- 6.2.14 AT+CSMINS SIM Inserted Status Reporting
- 6.2.15 AT+CLDTMF Local DTMF Tone Generation
- 6.2.16 AT+CDRIND CS Voice/Data/Fax Call Termination Indication
- 6.2.17 AT+CSPN Get Service Provider Name From SIM
- 6.2.18 AT+CCVM Get And Set The Voice Mail Number On The SIM
- 6.2.19 AT+CBAND Get And Set Mobile Operation Band
- 6.2.20 AT+CHF Configure Hands Free Operation
- 6.2.21 AT+CHFA Swap The Audio Channels
- 6.2.22 AT+CSCLK Configure Slow Clock
- 6.2.23 AT+CENG Switch On Or Off Engineering Mode
- 6.2.24 AT+SCLASS0 Store Class 0 SMS To SIM When Received Class 0 SMS
- 6.2.25 AT+CCID Show ICCID
- 6.2.26 AT+CMTE Set Critical Temperature Operating Mode Or Query Temperature
- 6.2.27 AT+CSDT Switch On Or Off Detecting SIM Card
- 6.2.28 AT+CMGDA Delete All SMS
- 6.2.29 AT+SIMTONE Generate Specifically Tone
- AT+SIMTONE Generate Specifically Tone
- 6.2.30 AT+CCPD Connected Line Identification Presentation Without Alpha String
- 6.2.31 AT+CGID Get SIM Card Group Identifier
- 6.2.32 AT+MORING Show State of Mobile Originated Call
- 6.2.33 AT+CMGHEX Enable To Send Non-ASCII Character SMS
- 6.2.34 AT+AUTEST Audio Channel Loopback Test
- 6.2.35 AT+CCODE Configure SMS Code Mode
- 6.2.36 AT+CIURC Enable Or Disable Initial URC Presentation
- 6.2.37 AT+CPSPWD Change PS Super Password
- 6.2.38 AT+EXUNSOL Enable /Disable Proprietary Unsolicited Indications
- 6.2.39 AT+CGMSCLASS Change GPRS Multislot Class
- 6.2.40 AT+CDEVICE View Current Flash Device Type
- 6.2.41 AT+CCALR Call Ready Query
- 6.2.42 AT+GSV Display Product Identification Information
- 7 AT Commands for GPRS Support
- 7.1 Overview of AT Commands for GPRS Support
- 7.2 Detailed Descriptions of AT Commands for GPRS Support
- 7.2.1 AT+CGATT Attach /Detach From GPRS Service
- 7.2.2 AT+CGDCONT Define PDP Context
- 7.2.3 AT+CGQMIN Quality Of Service Profile (Minimum Acceptable)
- 7.2.4 AT+CGQREQ Quality Of Service Profile (Requested)
- 7.2.5 AT+CGACT PDP Context Activate Or Deactivate
- 7.2.6 AT+CGDATA Enter Data State
- 7.2.7 AT+CGPADDR Show PDP Address
- 7.2.8 AT+CGCLASS GPRS Mobile Station Class
- 7.2.9 AT+CGEREP Control Unsolicited GPRS Event Reporting
- 7.2.10 AT+CGREG Network Registration Status
- 7.2.11 AT+CGSMS Select Service For MO SMS Messages
- 8 AT Commands for TCPIP Application Toolkit
- 8.1 Overview
- 8.2 Detailed Descriptions of Commands
- 8.2.1 AT+CIPMUX Start Up Multi-IP Connection
- 8.2.2 AT+CIPSTART Start Up TCP Or UDP Connection
- 8.2.3 AT+CIPSEND Send Data Through TCP Or UDP Connection
- 8.2.4 AT+CIPQSEND Select Data Transmitting Mode
- 8.2.5 AT+CIPACK Query Previous Connection Data Transmitting State
- 8.2.6 AT+CIPCLOSE Close TCP Or UDP Connection
- 8.2.7 AT+CIPSHUT Deactivate GPRS PDP Context
- 8.2.8 AT+CLPORT Set Local Port
- 8.2.9 AT+CSTT START Task And Set APN、USER NAME、PASSWORD
- 8.2.10 AT+CIICR Bring Up Wireless Connection With GPRS Or CSD
- 8.2.11 AT+CIFSR Get Local IP Address
- 8.2.12 AT+CIPSTATUS Query Current Connection Status
- 8.2.13 AT+CDNSCFG Configure Domain Name Server
- 8.2.14 AT+CDNSGIP Query The IP Address Of Given Domain Name
- 8.2.15 AT+CIPHEAD Add An IP Head When Receiving Data
- 8.2.16 AT+CIPATS Set Auto Sending Timer
- 8.2.17 AT+CIPSPRT Set Prompt Of ‘>’ When Sending Data
- 8.2.18 AT+CIPSERVER Configure As Server
- 8.2.19 AT+CIPCSGP Set CSD Or GPRS For Connection Mode
- 8.2.20 AT+CIPSRIP Set Whether Display IP Address And Port Of Sender When Receive Data
- 8.2.21 AT+CIPMODE Select TCPIP Application Mode
- 8.2.22 AT+CIPCCFG Configure Transparent Transfer mode
- 8.2.23 AT+CIPSHOWTP Display transfer protocol in IP head when receiving data
- 9 Supported unsolicited result codes
- 10 AT Commands Sample
![](asset-1.png)
AT Commands Set
SIM900_ATC_V1.00
![](asset-2.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 2 15.01.2010
Document Title: SIM900 AT Commands Set
Version: 1.00
Date: 2010-1-15
Status: Release
Document Control ID: SIM900_ATC_V1.00
General Notes
SIMCOM offers this information as a service to its customers, to support application and
engineering efforts that use the products designed by SIMCOM. The information provided is
based upon requirements specifically provided to SIMCOM by the customers. SIMCOM has not
undertaken any independent search for additional relevant information, including any information
that may be in the customer’s possession. Furthermore, system validation of this product designed
by SIMCOM within a larger electronic system remains the responsibility of the customer or the
customer’s system integrator. All specifications supplied herein are subject to change.
Copyright
This document contains proprietary technical information which is the property of Shanghai
SIMCom Wireless Solutions Ltd, copying of this document and giving it to others and the using or
communication of the contents thereof, are forbidden without express authority. Offenders are
liable to the payment of damages. All rights reserved in the event of grant of a patent or the
registration of a utility model or design. All specification supplied herein are subject to change
without notice at any time.
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2010
![](asset-3.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 3 15.01.2010
Version History
Version Chapter What is new
V1.00 New version Created on the basis of SIM900 AT Test Result
![](asset-4.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 4 15.01.2010
Contents
Version History .................................................................................................................................3
1 Introduction..................................................................................................................................10
1.1 Scope of the document..........................................................................................................10
1.2 Related documents ................................................................................................................10
1.3 Conventions and abbreviations .............................................................................................11
1.4 AT Command syntax .............................................................................................................11
1.4.1 Basic syntax ................................................................................................................... 11
1.4.2 S Parameter syntax.........................................................................................................12
1.4.3 Extended Syntax.............................................................................................................12
1.4.4 Combining AT commands on the same Command line.................................................12
1.4.5 Entering successive AT commands on separate lines.....................................................12
1.5 Supported character sets........................................................................................................12
1.6 Flow control ..........................................................................................................................13
1.6.1 Software flow control (XON/XOFF flow control).........................................................13
1.6.2 Hardware flow control (RTS/CTS flow control)............................................................14
2 ...................................................................................15 AT Commands According to V.25TER
2.1 Overview of AT Commands According to V.25TER ............................................................15
2.2 Detailed Description of AT Commands According to V.25TER...........................................16
2.2.1 A/ Re-issues The Last Command Given ........................................................................16
2.2.2 ATA ANSWER AN INCOMING CALL .......................................................................16
2.2.3 ATD Mobile Originated Call To Dial A Number............................................................17
2.2.4 ATDL Redial Last Telephone Number Used..................................................................23
2.2.5 ATE Set Command Echo Mode .....................................................................................24
2.2.6 ATH Hang up a call........................................................................................................24
2.2.7 ATI Display Product Identification Information ............................................................25
2.2.8 ATL Monitor speaker loudness.......................................................................................25
2.2.9 ATM Monitor Speaker Mode .........................................................................................26
2.2.10 +++ Switch From Data Mode Or PPP Online Mode To Command Mode...................26
2.2.11 ATO Switch From Command Mode To Data Mode.....................................................26
2.2.12 ATP Select Pulse Dialing..............................................................................................27
2.2.13 ATQ Set Result Code Presentation Mode.....................................................................27
2.2.14 ATS0 Set Number Of Rings Before Automatically Answering The Call.....................28
2.2.15 ATS3 Set Command Line Termination Character........................................................28
2.2.16 ATS4 Set Response Formatting Character ...................................................................28
2.2.17 ATS5 Set Command Line Editing Character................................................................29
2.2.18 ATS6 Set Pause Before Blind Dialing..........................................................................29
2.2.19 ATS7 Set Number Of Seconds To Wait For Connection Completion ..........................30
ATS7 Set Number Of Seconds To Wait For Connection Completion.....................................30
2.2.20 ATS8 Set Number Of Second To Wait For Comma Dial Modifier Encountered In Dial
String Of D Command ............................................................................................................30
2.2.21 ATS10 Set Disconnect Delay After Indicating The Absence Of Data Carrier .............31
2.2.22 ATT Select Tone Dialing ..............................................................................................31
![](asset-5.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 5 15.01.2010
2.2.23 ATV TA Response Format ..........................................................................................31
2.2.24 ATX Set CONNECT Result Code Format And Monitor Call Progress .......................32
2.2.25 ATZ Reset default configuration ..................................................................................33
2.2.26 AT&C Set DCD Function Mode ..................................................................................34
2.2.27 AT&D Set DTR Function Mode...................................................................................34
2.2.28 AT&F Factory defined configuration ...........................................................................35
2.2.29 AT&V Display Current Configuration .........................................................................37
2.2.30 AT&W Store Active profile..........................................................................................37
2.2.31 AT+GCAP Request Complete TA Capabilities List .....................................................38
2.2.32 AT+GMI Request Manufacture Identification .............................................................38
2.2.33 AT+GMM Request TA Model Identification ...............................................................38
2.2.34 AT+GMR Request TA Revision Identification Of Software Release...........................39
2.2.35 AT+GOI Request Global Object Identification............................................................39
2.2.36 AT+GSN Request TA Serial Number Identification (IMEI) ........................................40
2.2.37 AT+ICF Set TE-TA Control Character Framing ..........................................................40
2.2.38 AT+IFC TE-TA local flow control...............................................................................41
2.2.39 AT+IPR Set TE-TA Fixed Local Rate ..........................................................................42
2.2.40 AT+HVOIC Disconnect Voice Call Only.....................................................................44
3 AT Commands According to GSM07.07......................................................................................45
3.1 Overview of AT Command According to GSM07.07 ...........................................................45
3.2 Detailed Descriptions of AT Command According to GSM07.07 ........................................46
3.2.1 AT+CACM Accumulated Call Meter (ACM) Reset Or Query ......................................46
3.2.2 AT+CAMM Accumulated Call Meter Maximum (ACM max) Set Or Query................47
3.2.3 AT+CAOC Advice Of Charge........................................................................................48
3.2.4 AT+CBST Select Bearer Service Type...........................................................................49
3.2.5 AT+CCFC Call Forwarding Number And Conditions ...................................................50
3.2.6 AT+CCWA Call Waiting Control ...................................................................................51
3.2.7AT+CEER Extended Error Report ..................................................................................53
3.2.8 AT+CGMI Request Manufacturer Identification ...........................................................55
3.2.9 AT+CGMM Request Model Identification ....................................................................55
3.2.10 AT+CGMR Request TA Revision Identification Of Software Release........................56
3.2.11 AT+CGSN Request Product Serial Number Identification (Identical With +GSN).....56
3.2.12 AT+CSCS Select TE Character Set..............................................................................56
3.2.13 AT+CSTA Select Type Of Address...............................................................................57
3.2.14 AT+CHLD Call Hold And Multiparty..........................................................................58
3.2.15 AT+CIMI Request International Mobile Subscriber Identity.......................................59
3.2.16 AT+CLCC List Current Calls Of ME...........................................................................59
3.2.17 AT+CLCK Facility Lock..............................................................................................60
3.2.18 AT+CLIP Calling Line Identification Presentation ......................................................62
3.2.19 AT+CLIR Calling Line Identification Restriction........................................................63
3.2.20 AT+CMEE Report Mobile Equipment Error................................................................64
3.2.21 AT+COLP Connected Line Identification Presentation ...............................................65
3.2.22 AT+COPS Operator Selection......................................................................................66
3.2.23 AT+CPAS Phone Activity Status..................................................................................68
![](asset-6.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 6 15.01.2010
3.2.24 AT+CPBF Find Phonebook Entries..............................................................................69
3.2.25 AT+CPBR Read Current Phonebook Entries ...............................................................70
3.2.26 AT+CPBS Select Phonebook Memory Storage............................................................71
3.2.27 AT+CPBW Write Phonebook Entry.............................................................................72
3.2.28 AT+CPIN Enter PIN.....................................................................................................74
3.2.29 AT+CPWD Change Password......................................................................................75
3.2.30 AT+CR Service Reporting Control ..............................................................................75
3.2.31 AT+CRC Set Cellular Result Codes For Incoming Call Indication .............................76
3.2.32 AT+CREG Network Registration.................................................................................77
3.2.33 AT+CRLP Select Radio Link Protocol Parameter........................................................79
3.2.34 AT+CRSM Restricted SIM Access ..............................................................................80
3.2.35 AT+CSQ Signal Quality Report ...................................................................................81
3.2.36 AT+FCLASS FAX: Select, Read Or Test Service Class..............................................81
3.2.38 AT+FMI FAX: Report Manufactured ID......................................................................82
3.2.39 AT+FMM FAX: Rreport Model ID..............................................................................82
3.2.40 AT+FMR FAX: Report Revision ID ............................................................................83
3.2.41 AT+VTD Tone Duration...............................................................................................83
3.2.42 AT+VTS DTMF And Tone Generation ........................................................................84
3.2.43 AT+CMUX Multiplexer Control..................................................................................85
3.2.44 AT+CNUM Subscriber Number...................................................................................87
3.2.45 AT+CPOL Preferred Operator List...............................................................................88
3.2.46 AT+COPN Read Operator Names................................................................................88
3.2.47 AT+CFUN Set Phone Functionality. ............................................................................89
3.2.48 AT+CCLK Clock..........................................................................................................90
3.2.49 AT+CSIM Generic SIM Access ...................................................................................90
3.2.50 AT+CALM Alert Sound Mode.....................................................................................91
3.2.51 AT+CRSL Ringer Sound Level....................................................................................92
3.2.52 AT+CLVL Loud Speaker Volume Level ......................................................................92
3.2.53 AT+CMUT Mute Control.............................................................................................93
3.2.54 AT+CPUC Price Per Unit And Currency Table............................................................94
3.2.55 AT+CCWE Call Meter Maximum Event .....................................................................94
3.2.56 AT+CBC Battery Charge..............................................................................................95
3.2.57 AT+CUSD Unstructured Supplementary Service Data................................................96
3.2.58 AT+CSSN Supplementary Services Notification.........................................................97
4 AT Commands According to GSM07.05......................................................................................99
4.1 Overview of AT Commands According to GSM07.05..........................................................99
4.2 Detailed Descriptions of AT Commands According to GSM07.05.......................................99
4.2.1 AT+CMGD Delete SMS Message..................................................................................99
4.2.2 AT+CMGF Select SMS Message Format ....................................................................100
4.2.3 AT+CMGL List SMS Messages From Preferred Store ................................................101
4.2.4 AT+CMGR Read SMS Message..................................................................................104
4.2.5 AT+CMGS Send SMS Message...................................................................................107
4.2.6 AT+CMGW Write SMS Message To Memory ............................................................108
4.2.7 AT+CMSS Send SMS Message From Storage.............................................................109
![](asset-7.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 7 15.01.2010
4.2.8 AT+CNMI New SMS Message Indications ................................................................. 110
4.2.9 AT+CPMS Preferred SMS Message Storage ............................................................... 113
4.2.10 AT+CRES Restore SMS Settings............................................................................... 114
4.2.11 AT+CSAS Save SMS Settings ................................................................................... 115
4.2.12 AT+CSCA SMS Service Center Address ...................................................................115
4.2.13 AT+CSCB Select Cell Broadcast SMS Messages...................................................... 116
4.2.14 AT+CSDH Show SMS Text Mode Parameters .......................................................... 117
4.2.15 AT+CSMP Set SMS Text Mode Parameters ..............................................................118
4.2.16 AT+CSMS Select Message Service............................................................................119
5 AT Commands for SIM Application Toolkit ..............................................................................121
5.1 STK AT command...............................................................................................................121
6 AT Commands Special for SIMCOM ........................................................................................123
6.1 Overview.............................................................................................................................123
6.2 Detailed Descriptions of Commands...................................................................................124
6.2.1 AT+SIDET Change The Side Tone Gain Level............................................................124
6.2.2 AT+CPOWD Power Off...............................................................................................124
6.2.3 AT+SPIC Times Remain To Input SIM PIN/PUK .......................................................125
6.2.4 AT+CMIC Change The Microphone Gain Level ........................................................125
6.2.5 AT+CALA Set Alarm Time..........................................................................................126
6.2.6 AT+CADC Read ADC .................................................................................................127
6.2.7 AT+CSNS Single Numbering Scheme.........................................................................128
6.2.8 AT+CDSCB Reset Cell Broadcast ...............................................................................128
6.2.9 AT+CMOD Configure Alternating Mode Calls ...........................................................128
6.2.10 AT+CFGRI Indicate RI When Using URC ................................................................129
6.2.11 AT+CLTS Get Local Timestamp ................................................................................129
6.2.12 AT+CEXTHS External Headset Jack Control............................................................130
6.2.13 AT+CEXTBUT Headset Button Status Reporting .....................................................131
6.2.14 AT+CSMINS SIM Inserted Status Reporting ............................................................132
6.2.15 AT+CLDTMF Local DTMF Tone Generation ...........................................................133
6.2.16 AT+CDRIND CS Voice/Data/Fax Call Termination Indication.................................133
6.2.17 AT+CSPN Get Service Provider Name From SIM ....................................................134
6.2.18 AT+CCVM Get And Set The Voice Mail Number On The SIM................................135
6.2.19 AT+CBAND Get And Set Mobile Operation Band....................................................135
6.2.20 AT+CHF Configure Hands Free Operation................................................................136
6.2.21 AT+CHFA Swap The Audio Channels .......................................................................137
6.2.22 AT+CSCLK Configure Slow Clock ...........................................................................138
6.2.23 AT+CENG Switch On Or Off Engineering Mode......................................................138
6.2.24 AT+SCLASS0 Store Class 0 SMS To SIM When Received Class 0 SMS ................140
6.2.25 AT+CCID Show ICCID .............................................................................................141
6.2.26 AT+CMTE Set Critical Temperature Operating Mode Or Query Temperature ........141
6.2.27 AT+CSDT Switch On Or Off Detecting SIM Card ...................................................141
6.2.28 AT+CMGDA Delete All SMS...................................................................................142
6.2.29 AT+SIMTONE Generate Specifically Tone..............................................................143
AT+SIMTONE Generate Specifically Tone.........................................................................143
![](asset-8.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 8 15.01.2010
6.2.30 AT+CCPD Connected Line Identification Presentation Without Alpha String.........143
6.2.31 AT+CGID Get SIM Card Group Identifier................................................................144
6.2.32 AT+MORING Show State of Mobile Originated Call ..............................................144
6.2.33 AT+CMGHEX Enable To Send Non-ASCII Character SMS....................................145
6.2.34 AT+AUTEST Audio Channel Loopback Test...........................................................146
6.2.35 AT+CCODE Configure SMS Code Mode.................................................................146
6.2.36 AT+CIURC Enable Or Disable Initial URC Presentation .........................................146
6.2.37 AT+CPSPWD Change PS Super Password ...............................................................147
6.2.38 AT+EXUNSOL Enable /Disable Proprietary Unsolicited Indications .......................148
6.2.39 AT+CGMSCLASS Change GPRS Multislot Class ...................................................150
6.2.40 AT+CDEVICE View Current Flash Device Type .....................................................151
6.2.41 AT+CCALR Call Ready Query .................................................................................151
6.2.42 AT+GSV Display Product Identification Information................................................151
7 AT Commands for GPRS Support.............................................................................................153
7.1 Overview of AT Commands for GPRS Support..................................................................153
7.2 Detailed Descriptions of AT Commands for GPRS Support...............................................153
7.2.1 AT+CGATT Attach /Detach From GPRS Service........................................................153
7.2.2 AT+CGDCONT Define PDP Context ..........................................................................154
7.2.3 AT+CGQMIN Quality Of Service Profile (Minimum Acceptable) .............................156
7.2.4 AT+CGQREQ Quality Of Service Profile (Requested) ...............................................158
7.2.5 AT+CGACT PDP Context Activate Or Deactivate ......................................................159
7.2.6 AT+CGDATA Enter Data State ....................................................................................160
7.2.7 AT+CGPADDR Show PDP Address ............................................................................160
7.2.8 AT+CGCLASS GPRS Mobile Station Class................................................................161
7.2.9 AT+CGEREP Control Unsolicited GPRS Event Reporting .........................................162
7.2.10 AT+CGREG Network Registration Status .................................................................163
7.2.11 AT+CGSMS Select Service For MO SMS Messages ................................................164
8 AT Commands for TCPIP Application Toolkit...........................................................................166
8.1 Overview.............................................................................................................................166
8.2 Detailed Descriptions of Commands...................................................................................166
8.2.1 AT+CIPMUX Start Up Multi-IP Connection...............................................................166
8.2.2 AT+CIPSTART Start Up TCP Or UDP Connection.....................................................167
8.2.3 AT+CIPSEND Send Data Through TCP Or UDP Connection.....................................169
8.2.4 AT+CIPQSEND Select Data Transmitting Mode ........................................................171
8.2.5 AT+CIPACK Query Previous Connection Data Transmitting State.............................171
8.2.6 AT+CIPCLOSE Close TCP Or UDP Connection .......................................................172
8.2.7 AT+CIPSHUT Deactivate GPRS PDP Context ...........................................................172
8.2.8 AT+CLPORT Set Local Port........................................................................................173
8.2.9 AT+CSTT START Task And Set APN、USER NAME、PASSWORD ....................174
8.2.10 AT+CIICR Bring Up Wireless Connection With GPRS Or CSD...............................174
8.2.11 AT+CIFSR Get Local IP Address...............................................................................175
8.2.12 AT+CIPSTATUS Query Current Connection Status ..................................................175
8.2.13 AT+CDNSCFG Configure Domain Name Server......................................................176
8.2.14 AT+CDNSGIP Query The IP Address Of Given Domain Name ...............................177
![](asset-9.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 9 15.01.2010
8.2.15 AT+CIPHEAD Add An IP Head When Receiving Data ............................................178
8.2.16 AT+CIPATS Set Auto Sending Timer ........................................................................178
8.2.17 AT+CIPSPRT Set Prompt Of ‘>’ When Sending Data...............................................179
8.2.18 AT+CIPSERVER Configure As Server......................................................................180
8.2.19 AT+CIPCSGP Set CSD Or GPRS For Connection Mode..........................................180
8.2.20 AT+CIPSRIP Set Whether Display IP Address And Port Of Sender When Receive
Data .......................................................................................................................................181
8.2.21 AT+CIPMODE Select TCPIP Application Mode.......................................................182
8.2.22 AT+CIPCCFG Configure Transparent Transfer mode ...............................................183
8.2.23 AT+CIPSHOWTP Display transfer protocol in IP head when receiving data.........183
9 Supported unsolicited result codes.............................................................................................185
9.1 Summary of CME ERROR Codes......................................................................................185
9.2 Summary of CMS ERROR Codes ......................................................................................186
10 AT Commands Sample.............................................................................................................188
10.1 Profile Commands.............................................................................................................188
10.2 SIM Commands ................................................................................................................189
10.3 General Commands...........................................................................................................190
10.4 Call Control Commands....................................................................................................190
10.5 SIM Toolkit Commands....................................................................................................193
10.6 Audio Commands..............................................................................................................193
10.7 SMS Commands ...............................................................................................................193
10.8 GPRS Commands .............................................................................................................194
![](asset-b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 11 15.01.2010
1.3 Conventions and abbreviations
In this document, the GSM engines are referred to as following term:
1) ME (Mobile Equipment);
2) MS (Mobile Station);
3) TA (Terminal Adapter);
4) DCE (Data Communication Equipment) or facsimile DCE (FAX modem, FAX board);
In application, controlling device controls the GSM engine by sending AT Command via its serial
interface. The controlling device at the other end of the serial line is referred to as following term:
1) TE (Terminal Equipment);
2) DTE (Data Terminal Equipment) or plainly “the application” which is running on an
embedded system;
1.4 AT Command syntax
The "AT" or "at" prefix must be set at the beginning of each Command line. To terminate a
Command line enter <CR>.
Commands are usually followed by a response that includes.”<CR><LF><response><CR><LF>”
Throughout this document, only the responses are presented, <CR><LF> are omitted
intentionally.
The AT Command set implemented by SIM900 is a combination of GSM07.05, GSM07.07 and
ITU-T recommendation V.25ter and the AT commands developed by SIMCOM.
Note: A HEX string such as “00 49 49 49 49 FF FF FF FF” will be sent out through serial
port at the baud rate of 115200 immediately after SIM900 is powered on. The string shall be
ignored since it is used for synchronization with PC tool. Only enter AT Command through
serial port after SIM900 is powered on and Unsolicited Result Code “RDY” is received from
serial port. If auto-bauding is enabled, the Unsolicited Result Codes “RDY” and so on are
not indicated when you start up the ME, and the “AT” prefix, not “at” prefix must be set at
the beginning of each command line.
All these AT commands can be split into three categories syntactically: “basic”, “S parameter”,
and “extended”. These are as follows:
1.4.1 Basic syntax
These AT commands have the format of “AT<x><n>”, or “AT&<x><n>”, where “<x>”is the
Command, and “<n>”is/are the argument(s) for that Command. An example of this is “ATE<n>”,
which tells the DCE whether received characters should be echoed back to the DTE according to
the value of “<n>”. “<n>” is optional and a default will be used if missing.
![](asset-c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 12 15.01.2010
1.4.2 S Parameter syntax
These AT commands have the format of “ATS<n>=<m>”, where “<n>” is the index of the S
register to set, and “<m>”is the value to assign to it. “<m>” is optional; if it is missing, then a
default value is assigned.
1.4.3 Extended Syntax
These commands can operate in several modes, as in the following table:
Table 1: Types of AT commands and responses
Test Command AT+ <x>=? The mobile equipment returns the list of parameters
and value ranges set with the corresponding Write
Command or by internal processes.
Read Command AT+ <x>? This command returns the currently set value of the
parameter or parameters.
Write Command AT+<x>=<…> This command sets the user-definable parameter
values.
Execution Command AT+<x> The execution command reads non-variable
parameters affected by internal processes in the GSM
engine
1.4.4 Combining AT commands on the same Command line
You can enter several AT commands on the same line. In this case, you do not need to type the
“AT” or “at” prefix before every command. Instead, you only need type “AT” or “at” the
beginning of the command line. Please note to use a semicolon as the command delimiter after an
extended command, for example: ATE1&W&F+ICF?;+CFUN?;&W.
The Command line buffer can accept a maximum of 556 characters. If the characters entered
exceeded this number then none of the Command will executed and TA will return “ERROR”.
1.4.5 Entering successive AT commands on separate lines
When you need to enter a series of AT commands on separate lines, please Note that you need to
wait the final response (for example OK, CME error, CMS error) of last AT Command you entered
before you enter the next AT Command.
1.5 Supported character sets
The SIM900 AT Command interface defaults to the IRA character set. The SIM900 supports the
following character sets:
• GSM format
![](asset-d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 13 15.01.2010
• UCS2
• HEX
• IRA
• PCCP
• PCDN
• 8859-1
The character set can be set and interrogated using the “AT+CSCS” Command (GSM 07.07).
The character set is defined in GSM specification 07.05.
The character set affects transmission and reception of SMS and SMS Cell Broadcast messages,
the entry and display of phone book entries text field and SIM Application Toolkit alpha strings.
1.6 Flow control
Flow control is very important for correct communication between the GSM engine and DTE. For
in the case such as a data or fax call, the sending device is transferring data faster than the
receiving side is ready to accept. When the receiving buffer reaches its capacity, the receiving
device should be capable to cause the sending device to pause until it catches up.
There are basically two approaches to achieve data flow control: software flow control and
hardware flow control. SIM900 support both two kinds of flow control.
In Multiplex mode, it is recommended to use the hardware flow control.
1.6.1 Software flow control (XON/XOFF flow control)
Software flow control sends different characters to stop (XOFF, decimal 19) and resume (XON,
decimal 17) data flow. It is quite useful in some applications that only use three wires on the serial
interface.
The default flow control approach of SIM900 is hardware flow control (RTS/CTS flow control), to
enable software flow control in the DTE interface and within GSM engine, type the following AT
Command:
AT+IFC=1, 1
This setting is stored volatile, for use after restart, AT+IFC=1, 1 should be stored to the user
profile with AT&W.
NOTE:
The AT commands listed in the table of AT&W chapter should be stored to user profile with
AT&W for use after restart. Most other AT commands in V.25, 07.05, 07.07, GPRS will store
parameters automatically and can be used after module restart.
Ensure that any communications software package (e.g. Hyper terminal) uses software flow
control.
![](asset-e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 14 15.01.2010
NOTE:
Software Flow control should not be used for data calls where binary data will be transmitted or
received (e.g. TCP/IP) as the DTE interface may interpret binary data as flow control characters.
1.6.2 Hardware flow control (RTS/CTS flow control)
Hardware flow control achieves the data flow control by controlling the RTS/CTS line. When the
data transfer should be suspended, the CTS line is set inactive until the transfer from the receiving
buffer has completed. When the receiving buffer is ok to receive more data, CTS goes active once
again.
To achieve hardware flow control, ensure that the RTS/CTS lines are present on your application
platform.
![](asset-f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 15 15.01.2010
2 AT Commands According to V.25TER
These AT Commands are designed according to the ITU-T (International Telecommunication
Union, Telecommunication sector) V.25ter document.
2.1 Overview of AT Commands According to V.25TER
Command Description
A/ RE-ISSUES LAST AT COMMAND GIVEN
ATA ANSWER AN INCOMING CALL
ATD MOBILE ORIGINATED CALL TO DIAL A NUMBER
ATD><N> ORIGINATE CALL TO PHONE NUMBER IN CURRENT MEMORY
ATD><STR> ORIGINATE CALL TO PHONE NUMBER IN MEMORY WHICH
CORRESPONDS TO FIELD <STR>
ATD L REDIAL LAST TELEPHONE NUMBER USED
ATE SET COMMAND ECHO MODE
ATH DISCONNECT EXISTING CONNECTION
ATI DISPLAY PRODUCT IDENTIFICATION INFORMATION
ATL SET MONITOR SPEAKER LOUDNESS
ATM SET MONITOR SPEAKER MODE
+++ SWITCH FROM DATA MODE OR PPP ONLINE MODE TO
COMMAND MODE
ATO SWITCH FROM COMMAND MODE TO DATA MODE
ATP SELECT PULSE DIALLING
ATQ SET RESULT CODE PRESENTATION MODE
ATS 0 SET NUMBER OF RINGS BEFORE AUTOMATICALLY
ANSWERING THE CALL
ATS 3 SET COMMAND LINE TERMINATION CHARACTER
ATS 4 SET RESPONSE FORMATTING CHARACTER
ATS 5 SET COMMAND LINE EDITING CHARACTER
ATS 7 SET NUMBER OF SECONDS TO WAIT FOR CONNECTION
COMPLETION
ATS 8 SET NUMBER OF SECONDS TO WAIT WHEN COMMA DIAL
MODIFIER ENCOUNTERED IN DIAL STRING OF D COMMAND
ATS10 SET DISCONNECT DELAY AFTER INDICATING THE ABSENCE OF
DATA CARRIER
ATT SELECT TONE DIALING
![](asset-10.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 16 15.01.2010
ATV TA RESPONSE FORMAT
ATX SET CONNECT RESULT CODE FORMAT AND MONITOR CALL
PROGRESS
ATZ SET ALL CURRENT PARAMETERS TO USER DEFINED PROFILE
AT& C SET DCD FUNCTION MODE
AT& D SET DTR FUNCTION MODE
AT& F SET ALL CURRENT PARAMETERS TO MANUFACTURER
DEFAULTS
AT& V DISPLAY CURRENT CONFIGURATION
AT& W STORE CURRENT PARAMETER TO USER DEFINED PROFILE
AT+ GC AP REQUEST COMPLETE TA CAPABILITIES LIST
AT+ GM I REQUEST MANUFACTURER IDENTIFICATION
AT+GMM REQUEST TA MODEL IDENTIFICATION
AT+ GM R REQUEST TA REVISION INDENTIFICATION OF SOFTWARE
RELEASE
AT+GOI REQUEST GLOBAL OBJECT IDENTIFICATION
AT+ GS N REQUEST TA SERIAL NUMBER IDENTIFICATION
AT+ IC F SET TE-TA CONTROL CHARACTER FRAMING
AT+ IF C SET TE-TA LOCAL DATA FLOW CONTROL
AT+ IP R SET TE-TA FIXED LOCAL RATE
AT+HVOIC DISCONNECT VOICE CALL ONLY
2.2 Detailed Description of AT Commands According to V.25TER
2.2.1 A/ Re-issues The Last Command Given
A/ Re-issues The Last Command Given
Response
Re-issues the previous Command
Execution
Command
A/
Parameter
Reference
V.25ter
Note
2.2.2 ATA ANSWER AN INCOMING CALL
ATA ANSWER AN INCOMING CALL
![](asset-11.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 17 15.01.2010
Response
TA sends off-hook to the remote station.
Note1: Any additional commands on the same Command line are ignored.
Note2: This Command may be aborted generally by receiving a character
during execution. The aborting is not possible during some states of
connection establishment such as handshaking.
Response in case of data call, if successfully connected
CONNECT<text> TA switches to data mode.
Note: <text> output only if ATX<value> parameter setting with the
<value> >0
When TA returns to Command mode after call release
OK
Response in case of voice call, if successfully connected
OK
Response if no connection
NO CARRIER
Execution
Command
ATA
Parameter
Reference
V.25ter
Note
See also ATX
2.2.3 ATD Mobile Originated Call To Dial A Number
ATD Mobile Originated Call To Dial A Number
Execution
Command
ATD<n>[<mgsm
][;]
Response
This Command can be used to set up outgoing voice, data or fax calls. It
also serves to control supplementary services.
Note: This Command may be aborted generally by receiving an ATH
Command or a character during execution. The aborting is not possible
during some states of connection establishment such as handshaking.
If no dial tone and (parameter setting ATX2 or ATX4)
NO DIALTONE
If busy and (parameter setting ATX3 or ATX4)
BUSY
If a connection cannot be established
NO CARRIER
If the remote station does not answer
![](asset-12.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 18 15.01.2010
NO ANSWER
If connection successful and non-voice call.
CONNECT<text> TA switches to data mode.
Note: <text> output only if ATX<value> parameter setting with the
<value> >0
When TA returns to Command mode after call release
OK
If connection successful and voice call
OK
Parameter
<n> string of dialing digits and optionally V.25ter modifiers
dialing digits:
0-9, * , #, +, A, B, C
Following V.25ter modifiers are ignored:
,(comma), T, P, !, W, @
Emergency call:
<n> Standardized emergency number 112(no SIM needed)
<mgsm> string of GSM modifiers:
I Actives CLIR (Disables presentation of own number
to called party)
i Deactivates CLIR (Enable presentation of own
number to called party)
G Activates Closed User Group invocation for this call
only
g Deactivates Closed User Group invocation for this call
only
<;> only required to set up voice call , return to Command state
Reference
V.25ter
Note
z Parameter “I” and “i” only if no *# code is within the dial string
z <n> is default for last number that can be dialed by ATDL
z *# codes sent with ATD are treated as voice calls. Therefore, the
Command must be terminated with a semicolon “;”
z See ATX Command for setting result code and call monitoring
parameters.
Responses returned after dialing with ATD
z For voice call two different responses mode can be determined. TA
returns “OK” immediately either after dialing was completed or after
![](asset-13.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 19 15.01.2010
the call is established. The setting is controlled by AT+COLP. Factory
default is AT+COLP=0, this cause the TA returns “OK” immediately
after dialing was completed, otherwise TA will returns “OK”,
“BUSY”, “NO DIAL TONE”, “NO CARRIER”.
Using ATD during an active voice call:
z When a user originates a second voice call while there is already an
active voice call, the first call will be automatically put on hold.
z The current states of all calls can be easily checked at any time by
using the AT+CLCC Command
2.2.5 ATD> <n> ORIGINATE CALL TO PHONE NUMBER IN CURRENT MEMORY
ATD><n> ORIGINATE CALL TO PHONE NUMBER IN CURRENT MEMORY
![](asset-14.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 20 15.01.2010
Response
This Command can be used to dial a phone number from current phonebook
memory.
Note: This Command may be aborted generally by receiving an ATH
Command or a character during execution. The aborting is not possible
during some states of connection establishment such as handshaking.
If error is related to ME functionality
+CME ERROR: <err>
If no dial tone and (parameter setting ATX2 or ATX4)
NO DIALTONE
If busy and (parameter setting ATX3 or ATX4)
BUSY
If a connection cannot be established
NO CARRIER
If the remote station does not answer
NO ANSWER
If connection successful and non-voice call.
CONNECT<text> TA switches to data mode.
Note: <text> output only if ATX<value> parameter setting with the
<value> >0
When TA returns to Command mode after call release
OK
If successfully connected and voice call
OK
Execution
Command
ATD><n>[<clir>
][ <cug>][;]
Parameter
<n> Integer type memory location should be in the range of
locations available in the memory used
<mgsm> string of GSM modifiers:
<clir>
I Override the CLIR supplementary service subscription
default value for this call
Invocation (restrict CLI presentation)
i Override the CLIR supplementary service subscription
default value for this call
![](asset-15.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 21 15.01.2010
Suppression (allow CLI presentation)
<cug>
G Control the CUG supplementary service information for
this call
CUG Not supported
g Control the CUG supplementary service information
for this call
CUG Not supported
<;> Only required to set up voice call , return to Command state
Reference
V.25ter
Note
z Parameter “I” and “i” only if no *# code is within the dial string
z *# codes sent with ATD are treated as voice calls. Therefore, the
Command must be terminated with a semicolon “;”
z See ATX Command for setting result code and call monitoring
parameters.
2.2.6 ATD> <str> ORIGINATE CALL TO PHONE NUMBER IN MEMORY WHICH
CORRESPONDS TO FIELD <STR>
ATD><str> ORIGINATE CALL TO PHONE NUMBER IN MEMORY WHICH
CORRESPONDS TO FIELD <STR>
![](asset-16.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 22 15.01.2010
Execution
Command
ATD><str>[<clir
>][<cug>][;]
Response
This Command make the TA attempts to set up an outgoing call to stored
number.
All available memories are searched for the entry <str>.
Note: This Command may be aborted generally by receiving an ATH
Command or a character during execution. The aborting is not possible
during some states of connection establishment such as handshaking.
If error is related to ME functionality
+CME ERROR: <err>
If no dial tone and (parameter setting ATX2 or ATX4)
NO DIALTONE
If busy and (parameter setting ATX3 or ATX4)
BUSY
If a connection cannot be established
NO CARRIER
If the remote station does not answer
NO ANSWER
If connection successful and non-voice call.
CONNECT<text> TA switches to data mode.
Note: <text> output only if ATX<value> parameter setting with the
<value> >0
When TA returns to Command mode after call release
OK
If successfully connected and voice call
OK
![](asset-17.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 23 15.01.2010
Parameters
<str> string type(string should be included in quotation marks)
value (“x“), which should equal to an alphanumeric field in
at least one phone book entry in the searched memories. str
formatted as current TE character set specified by +CSCS.
<mgsm> string of GSM modifiers:
I Actives CLIR (Disables presentation of own number
to called party)
i Deactivates CLIR (Enable presentation of own
number to called party)
G Activates Closed User Group invocation for this call
only
g Deactivates Closed User Group invocation for this call
only
<;> only required to set up voice call , return to Command state
Reference
V.25ter
Note
z Parameter “I” and “i” only if no *# code is within the dial string
z *# codes sent with ATD are treated as voice calls. Therefore, the
Command must be terminated with a semicolon “;”
z See ATX Command for setting result code and call monitoring
parameters.
2.2.4 ATDL Redial Last Telephone Number Used
ATDL Redial Last Telephone Number Used
Execution
Command
ATDL
Response
This Command redials the last voice and data call number used.
Note: This Command may be aborted generally by receiving an ATH
Command or a character during execution. The aborting is not possible
during some states of connection establishment such as handshaking.
If error is related to ME functionality
+CME ERROR: <err>
If no dial tone and (parameter setting ATX2 or ATX4)
NO DIALTONE
If busy and (parameter setting ATX3 or ATX4)
BUSY
If a connection cannot be established
NO CARRIER
![](asset-18.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 24 15.01.2010
If the remote station does not answer
NO ANSWER
If connection successful and non-voice call.
CONNECT<text> TA switches to data mode.
Note: <text> output only if ATX<value> parameter setting with the
<value> >0
When TA returns to Command mode after call release
OK
If successfully connected and voice call
OK
Reference
V.25ter
Note
z See ATX Command for setting result code and call monitoring
parameters.
z Return the numbers and symbols which ATD supports if there is no
last dialing context.
2.2.5 ATE Set Command Echo Mode
ATE Set Command Echo Mode
Response
This setting determines whether or not the TA echoes characters received
from TE during Command state.
OK
Execution
Command
ATE<value>
Parameter
<value> 0 Echo mode off
1 Echo mode on
Reference
V.25ter
Note
2.2.6 ATH Hang up a call
ATH Hang up a call
Execution
Command
ATH[n]
Response
Disconnect existing call by local TE from Command line and terminate call
OK
Note: OK is issued after circuit 109(DCD) is turned off, if it was previously
on.
![](asset-19.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 25 15.01.2010
Parameter
<n> 0 Disconnect ALL calls on THE channel the command is
Requested. All active or waiting calls, CS data calls, GPRS
call of the channel will be disconnected
1 Disconnect all calls on ALL connected channels. All active
or waiting calls, CSD calls, GPRS call will be
disconnected.(clean up of all calls of the ME).
2 Disconnect all connected CS data call only on the channel
the command is requested (speech calls (active or waiting)
or GPRS calls are not disconnected).
3 Disconnect all connected GPRS calls only on the channel
the command is requested (speech calls (active or waiting)
or CS data calls are not disconnected
4 Disconnect all CS calls (either speech or data) but does not
disconnect waiting call (either speech or data) on the
channel the command is requested.
5 Disconnect waiting call (either speech or data) but does not
disconnect other active calls (either CS speech, CS data or
GPRS) on the channel the command is requested.
(rejection of incoming call)
Reference
V.25ter
Note
2.2.7 ATI Display Product Identification Information
ATI Display Product Identification Information
Execution
Command
ATI
Response
TA issues product information text
Example:
SIM900 R11.0
OK
Reference
V.25ter
Note
2.2.8 ATL Monitor speaker loudness
ATL Monitor speaker loudness
Execution
Command
Response
OK
![](asset-1a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 26 15.01.2010
ATL<value> Parameter
<value> 0..9 volume
Reference
V.25ter
Note
z No effect in GSM
2.2.9 ATM Monitor Speaker Mode
ATM Monitor Speaker Mode
Response
OK
Execution
Command
ATM<value> Parameter
<value> 0..9 mode
Reference
V.25ter
Note
z No effect in GSM
2.2.10 +++ Switch From Data Mode Or PPP Online Mode To Command Mode
+++ Switch From Data Mode Or PPP Online Mode To Command Mode
Response
The +++ character sequence causes the TA to cancel the data flow over the
AT interface and switch to Command mode. This allows you to enter AT
Command while maintaining the data connection to the remote server.
OK
To prevent the +++ escape sequence from being misinterpreted as data, it
should comply to following sequence:
1. No characters entered for T1 time (1 second)
2. “+++” characters entered with no characters in between (0.5 second)
3. No characters entered for T1 timer (0.5 second)
4. Switch to Command mode, otherwise go to step 1.
Execution
Command
+++
Parameter
Reference
V.25ter
Note
z To return from Command mode back to data mode: Enter ATO.
2.2.11 ATO Switch From Command Mode To Data Mode
ATO Switch From Command Mode To Data Mode
![](asset-1b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 27 15.01.2010
Response
TA resumes the connection and switches back from Command mode to data
mode.
CONNECT
If connection is not successfully resumed
NO CARRIER
else
TA returns to data mode from Command mode CONNECT <text> Note:
<text> only if parameter setting ATX>0
Execution
Command
ATO[n]
Parameter
<n> 0 switch from Command mode to data mode
Reference
V.25ter
Note
2.2.12 ATP Select Pulse Dialing
ATP Select Pulse Dialing
Response
OK
Execution
Command
ATP Parameter
Reference
V.25ter
Note
z No effect in GSM
2.2.13 ATQ Set Result Code Presentation Mode
ATQ Set Result Code Presentation Mode
Response
This parameter setting determines whether or not the TA transmits any result
code to the TE. Information text transmitted in response is not affected by
this setting.
If <n>=0:
OK
If <n>=1:
(none)
Execution
Command
ATQ<n>
Parameter
<n> 0 TA transmits result code
1 Result codes are suppressed and not transmitted
Reference
V.25ter
Note
![](asset-1c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 28 15.01.2010
2.2.14 ATS0 Set Number Of Rings Before Automatically Answering The Call
ATS0 Set Number Of Rings Before Automatically Answering The Call
Read Command
ATS0?
Response
<n>
OK
Response
This parameter setting determines the number of rings before auto-answer.
OK
ERROR
Write Command
ATS0=<n>
Parameter
<n> 0 Automatic answering is disable
1-255 Number of rings the modem will wait for before
answering the phone if a ring is detected
Reference
V.25ter
Note
z If <n> is set too high, the calling party may hang up before the call can
be answered automatically.
2.2.15 ATS3 Set Command Line Termination Character
ATS3 Set Command Line Termination Character
Read Command
ATS3?
Response
<n>
OK
Response
This parameter setting determines the character recognized by TA to
terminate an incoming Command line. The TA also returns this character in
output.
OK
ERROR
Write Command
ATS3=<n>
Parameter
<n> 13 Command line termination character
Reference
V.25ter
Note
z Default 13 = CR. It only supports default value.
2.2.16 ATS4 Set Response Formatting Character
ATS4 Set Response Formatting Character
Read Command
ATS4?
Response
<n>
![](asset-1d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 29 15.01.2010
OK
Response
This parameter setting determines the character generated by the TA for
result code and information text.
OK
ERROR
Write Command
ATS4=<n>
Parameter
<n> 10 response formatting character
Reference
V.25ter
Note
z Default 10 = LF. It only supports default value.
2.2.17 ATS5 Set Command Line Editing Character
ATS5 Set Command Line Editing Character
Read Command
ATS5?
Response
<n>
OK
Response
This parameter setting determines the character recognized by TA as a
request to delete from the Command line the immediately preceding
character.
OK
ERROR
Write Command
ATS5=<n>
Parameter
<n> 0-8-127 response formatting character
Reference
V.25ter
Note
z Default 8 = Backspace.
2.2.18 ATS6 Set Pause Before Blind Dialing
ATS6 Set Pause Before Blind Dialing
Read Command
ATS6?
Response
ERROR
Write Command
ATS6=<n>
Response
OK
ERROR
![](asset-1e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 30 15.01.2010
Parameter
<n> 0..999 Time
Reference
V.25ter
Note
No effect in GSM
2.2.19 ATS7 Set Number Of Seconds To Wait For Connection Completion
ATS7 Set Number Of Seconds To Wait For Connection Completion
Read Command
ATS7?
Response
<n>
OK
Response
This parameter setting determines the amount of time to wait for the
connection completion in case of answering or originating a call.
OK
ERROR
Write Command
ATS7=<n>
Parameter
<n> 1-60-255 number of seconds to wait for connection completion
Reference
V.25ter
Note
z If called party has specified a high value for ATS0=<n>, call setup
may fail.
z The correlation between ATS7 and ATS0 is important
Example: Call may fail if ATS7=30 and ATS0=20.
z ATS7 is only applicable to data call. -
2.2.20 ATS8 Set Number Of Second To Wait For Comma Dial Modifier Encountered In Dial
String Of D Command
ATS8 Set Number Of Second To Wait For Comma Dial Modifier Encountered In Dial
String Of D Command
Read Command
ATS8?
Response
<n>
OK
Response
OK
ERROR
Write Command
ATS8=<n>
Parameter
<n> 0-225 The value of this register determines how long the modem
should pause when it sees a comma in the dialling string
Reference Note
![](asset-1f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 31 15.01.2010
V.25ter z No effect in GSM
2.2.21 ATS10 Set Disconnect Delay After Indicating The Absence Of Data Carrier
ATS10 Set Disconnect Delay After Indicating The Absence Of Data Carrier
Read Command
ATS10?
Response
<n>
OK
Response
This parameter setting determines the amount of time that the TA will
remain connected in absence of data carrier. If the data carrier is once more
detected before disconnecting, the TA remains connected.
OK
ERROR
Write Command
ATS10=<n>
Parameter
<n> 1-15-254 number of tenths seconds of del
Reference
V.25ter
Note
2.2.22 ATT Select Tone Dialing
ATT Select Tone Dialing
Response
OK
Execution
Command
ATT Parameter
Reference
V.25ter
Note
z No effect in GSM
2.2.23 ATV TA Response Format
ATV TA Response Format
Execution
Command
ATV<value>
Response
This parameter setting determines the contents of the header and trailer
transmitted with result codes and information responses.
When <value>=0
0
When <value>=1
OK
![](asset-20.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 32 15.01.2010
Parameter
<value> 0 Information response: <text><CR><LF>
Short result code format: <numeric code><CR>
1 Information response: <CR><LF><text><CR><LF>
Long result code format: <CR><LF><verbose
code><CR><LF>
The result codes, their numeric equivalents and brief descriptions of the use
of each are listed in the following table.
Reference
V.25ter
Note
ATV1 ATV0 Description
OK 0 Acknowledges execution of a Command
CONNECT 1 A connection has been established; the DCE is moving
from Command state to online data state
RING 2 The DCE has detected an incoming call signal from
network
NO CARRIER 3 The connection has been terminated or the attempt to
establish a connection failed
ERROR 4 Command not recognized, Command line maximum
length exceeded, parameter value invalid, or other
problem with processing the Command line
NO DIALTONE 6 No dial tone detected
BUSY 7 Engaged (busy) signal detected
NO ANSWER 8 "@" (Wait for Quiet Answer) dial modifier was used,
but remote ringing followed by five seconds of silence
was not detected before expiration of the connection
timer (S7)
PROCEEDING 9 An AT command is being processed
CONNECT
<text>
Manufacturer-
specific
Same as CONNECT, but includes
manufacturer-specific text that may specify DTE speed,
line speed, error control, data compression, or other
status
2.2.24 ATX Set CONNECT Result Code Format And Monitor Call Progress
ATX Set CONNECT Result Code Format And Monitor Call Progress
![](asset-21.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 33 15.01.2010
Response
This parameter setting determines whether or not the TA detected the
presence of dial tone and busy signal and whether or not TA transmits
particular result codes
OK
ERROR
Execution
Command
ATX<value>
Parameter
<value> 0 CONNECT result code only returned, dial tone and
busy detection are both disabled
1 CONNECT<text> result code only returned, dial tone
and busy detection are both disabled
2 CONNECT<text> result code returned, dial tone
detection is enabled, busy detection is disabled
3 CONNECT<text> result code returned, dial tone
detection is disabled, busy detection is enabled
4 CONNECT<text> result code returned, dial tone and
busy detection are both enabled
Reference
V.25ter
Note
2.2.25 ATZ Reset default configuration
ATZ Reset default configuration
Response
TA sets all current parameters to the user defined profile.
OK
ERROR
Execution
Command
ATZ[<value>]
Parameter
<value> 0 (Default value) Restore profile 0
1 Restore profile 1
Reference
V.25ter
Note
Parameter impacted by Z command:
Command Parameter name Default value
ATE <echo> 0x01
ATQ <result> 0x00
ATV <format> 0x01
ATX <result> 0x04
AT&C <behavior> 0x01
![](asset-22.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 34 15.01.2010
AT&D <behavior> 0x02
AT+IFC <TA_by_TE> 0x00
AT+IFC <TE_by_TA> 0x01
AT+FCLASS <class> 0x00
ATS0 <num> 0x00
ATS3 <char> 0x00
ATS4 <char> 0x0D
ATS5 <char> 0x0A
ATS7 <time> 0x08
ATS8 <time> 0x32
ATS10 <time> 0x0E
2.2.26 AT&C Set DCD Function Mode
AT&C Set DCD Function Mode
Response
This parameter determines how the state of circuit 109 (DCD) relates to the
detection of received line signal from the distant end.
OK
ERROR
Execution
Command
AT&C[<value>]
Parameter
<value> 0 DCD line is always ON
1 DCD line is ON only in the presence of data carrier
Reference
V.25ter
Note
2.2.27 AT&D Set DTR Function Mode
AT&D Set DTR Function Mode
Execution
Command
AT&D[<value>]
Response
This parameter determines how the TA responds when circuit 108/2 (DTR)
is changed from the ON to the OFF condition during data mode.
OK
ERROR
![](asset-23.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 35 15.01.2010
Parameter
<value> 0 TA ignores status on DTR
1 ON->OFF on DTR: Change to Command mode with
remaining the connected call
2 ON->OFF on DTR: Disconnect call, change to
Command mode. During state DTR = OFF is
auto-answer off.
Reference
V.25ter
Note
2.2.28 AT&F Factory defined configuration
AT&F Factory defined configuration
Response
TA sets all current parameters to the manufacturer defined profile.
OK
Execution
Command
AT&F[<value>]
Parameter
<value> 0 set all TA parameters to manufacturer defaults.
Reference
V.25ter
Note
Parameter impacted by &F command:
Command Parameter name Default value
ATE <echo> 0x01
ATQ <result> 0x00
ATV <format> 0x01
ATX <result> 0x04
AT+IFC <TA_by_TE> 0x00
AT+IFC <TE_by_TA> 0x02
ATS0 <num> 0x00
ATS3 <char> 0x0D
ATS4 <char> 0x0A
ATS5 <char> 0x08
ATS7 <time> 0x64
ATS8 <time> 0x02
ATS10 <time> 0x0E
AT+CRLP <ver> 0x00
AT+CRLP <T4> 0x07
AT+CRLP <iws> 0x61
AT+CRLP <mws> 0x61
AT+CRLP <T1> 0x48
![](asset-24.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 36 15.01.2010
AT+CRLP <N2> 0x06
AT+CPBS <storage> 0x53 0x4D 0x00
AT +CSMP <fo> 0x11
AT +CSMP <vp> 0x00
AT +CSMP <vp> 0x18
AT +CSMP <vp> 0x00
AT +CSMP <vp> 0x00
AT +CSMP <fo> 0x11
AT +CSMP <vp> 0x00
AT +CSMP <vp> 0x18
AT +CSMP <vp> 0x00
AT +CSMP <vp> 0x00
AT +CSMP <fo> 0x11
AT +CSMP <vp> 0x00
AT +CSMP <vp> 0x18
AT +CSMP <vp> 0x00
AT +CSMP <vp> 0x00
AT +CSMP <vp> 0x00..0x00
AT +CSMP <pid> 0x00
AT +CSMP <dcs> 0x00
AT +CR <mode> 0x00
AT +CSTA <type> 0x81
AT +CBST <speed> 0x05 0x02 0x00
AT+CBST <name> 0x01 0x00
AT +CBST <ce> 0x01
AT +CRC <mode> 0x00
AT +CMOD <mode> 0x00
AT +CMEE <n> 0x00
AT +CREG <n> 0x00
AT +CGREG <n> 0x00
AT +CSMS <service> 0x00
AT +CMGF <mode> 0x00
AT +CSDH <show> 0x00
AT +CSCS <chset> 0x00
AT +CLIR <n> 0x00
AT +CLIP <n> 0x00
AT +COLP <n> 0x00
![](asset-25.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 37 15.01.2010
2.2.29 AT&V Display Current Configuration
AT&V Display Current Configuration
Response
TA returns the current parameter setting.
<current configurations text>
OK
ERROR
Execution
Command
AT&V[<n>]
Parameter
<n> 0 Responses in numeric format
Reference
V.25ter
Note
2.2.30 AT&W Store Active profile
AT&W Store Active profile
Response
TA stores the current parameter setting in the user defined profile.
OK
ERROR
Execution
Command
AT&W[<n>]
Parameter
<n> 0 (Default value) Store the current configuration in profile 0
1 Store the current configuration in profile 1
Reference
V.25ter
Note
z The user defined profile is stored in non volatile memory.
Parameter stored by &W
Command Parameter name Displayedby &V
ATE <echo> Y
ATQ <result> Y
ATV <format> Y
ATX <result> Y
AT&C <behavior> Y
AT&D <behavior> Y
AT+IFC <TA_by_TE> Y
AT+IFC <TE_by_TA> Y
AT+FCLASS <class> Y
ATS0 <num> Y
ATS3 <char> Y
![](asset-26.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 38 15.01.2010
ATS4 <char> Y
ATS5 <char> Y
ATS7 <time> Y
ATS8 <time> Y
ATS10 <time> Y
2.2.31 AT+GCAP Request Complete TA Capabilities List
AT+GCAP Request Complete TA Capabilities List
Response
TA reports a list of additional capabilities.
+GCAP: <name>s
OK
Execution
Command
AT+GCAP
Parameters
<name> +CGSM GSM function is supported
+FCLASS FAX function is supported
Reference
V.25ter
Note
The command can be executed only when the SIM card is present.
2.2.32 AT+GMI Request Manufacture Identification
AT+GMI Request Manufacture Identification
Response
OK
Test Command
AT+GMI=?
Parameter
TA reports one or more lines of information text which permit the user to
identify the manufacturer.
SIMCOM_Ltd
OK
Execution
Command
AT+GMI
Parameter
Reference
V.25ter
Note
2.2.33 AT+GMM Request TA Model Identification
AT+GMM Request TA Model Identification
Test Command
AT+GMM=?
Response
OK
![](asset-27.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 39 15.01.2010
Parameter
TA reports one or more lines of information text which permit the user to
identify the specific model of device.
SIMCOM_SIM900
OK
Execution
Command
AT+GMM
Parameter
Reference
V.25ter
Note
2.2.34 AT+GMR Request TA Revision Identification Of Software Release
AT+GMR Request TA Revision Identification Of Software Release
Response
OK
Test Command
AT+GMR=?
Parameter
TA reports one or more lines of information text which permit the user to
identify the revision of software release.
Revision: <revision>
OK
Execution
Command
AT+GMR
Parameter
<revision> revision of software release
Reference
V.25ter
Note
2.2.35 AT+GOI Request Global Object Identification
AT+GOI Request Global Object Identification
Response
OK
Test Command
AT+GOI=?
Parameter
Execution
Command
AT+GOI
Response
TA reports one or more lines of information text which permit the user to
identify the device, based on the ISO system for registering unique object
identifiers.
<Object Id>
SIM900
OK
![](asset-28.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 40 15.01.2010
Parameter
<Object Id> identifier of device type
see X.208, 209 for the format of <Object Id>
Reference
V.25ter
Note
2.2.36 AT+GSN Request TA Serial Number Identification (IMEI)
AT+GSN Request TA Serial Number Identification(IMEI)
Response
OK
Test Command
AT+GSN=?
Parameter
Response
TA reports the IMEI (international mobile equipment identifier) number in
information text which permit the user to identify the individual ME device.
<sn>
OK
Execution
Command
AT+GSN
Parameter
<sn> IMEI of the telephone(International Mobile station
Equipment Identity)
Reference
V.25ter
Note
z The serial number (IMEI) is varied by individual ME device.
2.2.37 AT+ICF Set TE-TA Control Character Framing
AT+ICF Set TE-TA Control Character Framing
Response
+ICF: (list of supported <format>s), (list of supported <parity>s)
OK
Test Command
AT+ICF=?
Parameter
See Write Command.
Response
+ICF: <format>,<parity>
OK
Read Command
AT+ICF?
Parameter
See Write Command.
![](asset-29.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 41 15.01.2010
Response
This parameter setting determines the serial interface character framing
format and parity received by TA from TE.
OK
Write Command
AT+ICF=[<form
at>,[<parity>]]
Parameters
<format> 1 8 data 0 parity 2 stop
2 8 data 1 parity 1 stop
3 8 data 0 parity 1 stop
4 7 data 0 parity 2 stop
5 7 data 1 parity 1 stop
6 7 data 0 parity 1 stop
<parity> 0 odd
1 even
3 space (0)
Reference
V.25ter
Note
z The Command is applied for Command state;
z In <format> parameter, “0 parity” means no parity;
z The <parity> field is ignored if the < format > field specifies no
parity and string “+ICF: <format>,255” will be response to AT+ICF?
Command.
2.2.38 AT+IFC TE-TA local flow control
AT+IFC TE-TA local flow control
Response
+IFC: (list of supported <dce_by_dte>s), (list of supported
<dte_by_dce>s)
OK
Test Command
AT+IFC=?
Parameter
See Write Command.
Response
+IFC: <dce_by_dte>,<dte_by_dce>
OK
Read Command
AT+IFC?
Parameter
See Write Command.
Write Command
AT+IFC=[<dce_
by_dte>[,<dte_b
y_dce>]]
Response
This parameter setting determines the data flow control on the serial
interface for data mode.
OK
![](asset-2a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 42 15.01.2010
Parameters
<dce_by_dte> specifies the method will be used by TE at receive of data
from TA
0 No flow control (default)
1 Software flow control
2 Hardware flow control
<dte_by_dce> specifies the method will be used by TA at receive of data
from TE
0 No flow control
1 Software flow control
2 Hardware flow control (default)
Reference
V.25ter
Note
2.2.39 AT+IPR Set TE-TA Fixed Local Rate
AT+IPR Set TE-TA Fixed Local Rate
Response
+IPR: (),(list of supported <rate>s)
OK
Test Command
AT+IPR=?
Parameter
See Write Command.
Response
+IPR: <rate>
OK
Read Command
AT+IPR?
Parameter
See Write Command.
Write Command
AT+IPR=<rate>
Response
This parameter setting determines the data rate of the TA on the serial
interface. The rate of Command takes effect following the issuance of any
result code associated with the current Command line.
OK
![](asset-2b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 43 15.01.2010
Parameter
<rate> Baud rate per second
0 (Auto-bauding)
1200
2400
4800
9600
19200
38400
57600
115200
Reference
V.25ter
Note
z Factory setting is AT+IPR=0(auto-bauding).
2.2.39.1 Auto-bauding
Synchronization between DTE and DCE ensure that DTE and DCE are correctly synchronized and
the baud rate used by the DTE is detected by the DCE (= ME). To allow the baud rate to be
synchronized, simply issue an "AT" string. This is necessary when you start up the module while
auto-bauding is enabled. It is recommended to wait 3 to 5 seconds before sending the first AT
character. Otherwise undefined characters might be returned.
If you want to use auto-bauding and auto-answer at the same time, you can easily enable the
DTE-DCE synchronization, when you activate auto-bauding first and then configure the
auto-answer mode.
Restrictions on auto-bauding operation
z The serial interface has to be operated at 8 data bits, no parity and 1 stop bit (factory
setting).
z Only the strings “AT” or “At” (not “aT” or “at”) can be detected when auto-bauding is
enabled.
z AT+IPR=0 setting to auto-bauding will take effect after module resets. If user wants to
change DTE baud rate during module is running, i.e from 115200 to 9600, DTR shall be
used to urge auto-bauding progress. DTR shall be pulled up to invalid state at least 2
seconds by DTE and then pulled down to valid state. The step will urge auto-bauding
progress and DCE will synchronize its baud rate after it receives data from the serial port.
z Unsolicited Result Codes that may be issued before the ME detects the new baud rate (by
receiving the first AT Command string) will be sent at the previously detected baud rate.
z The Unsolicited Result Codes “RDY” and so on are not indicated when you start up the
ME while auto-bauding is enabled.
z It is not recommended to switch to auto-bauding from a baud rate that cannot be detected
by the auto-bauding mechanism (e.g. 300 baud). Responses to +IPR=0 and any commands
on the same line might be corrupted.
Auto-bauding and baud rate after restart
The most recently detected baud rate can not be stored when module is powered down.
![](asset-2c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 44 15.01.2010
2.2.40 AT+HVOIC Disconnect Voice Call Only
AT+HVOIC Disconnect Voice Call Only
Response
Disconnect existing voice call by local TE from Command line and
terminate call with existing PPP or CSD connection on.
OK
Execution
Command
AT+HVOIC
Parameter
Reference
V.25ter
Note
![](asset-2d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 45 15.01.2010
3 AT Commands According to GSM07.07
3.1 Overview of AT Command According to GSM07.07
Command Description
AT+ CA CM ACCUMULATED CALL METER(ACM) RESET OR QUERY
AT+CAMM ACCUMULATED CALL METER MAXIMUM(ACM MAX) SET OR
QUERY
AT+CAOC ADVICE OF CHARGE
AT+CBST SELECT BEARER SERVICE TYPE
AT+CCFC CALL FORWARDING NUMBER AND CONDITIONS CONTROL
AT+CCWA CALL WAITING CONTROL
AT+CEER EXTENDED ERROR REPORT
AT+ CG MI REQUEST MANUFACTURER IDENTIFICATION
AT+CGMM REQUEST MODEL IDENTIFICATION
AT+ CG MR REQUEST TA REVISION IDENTIFICATION OF SOFTWARE
RELEASE
AT+CGSN REQUEST PRODUCT SERIAL NUMBER IDENTIFICATION
(IDENTICAL WITH +GSN)
AT+CSCS SELECT TE CHARACTER SET
AT+ CS TA SELECT TYPE OF ADDRESS
AT+CHLD CALL HOLD AND MULTIPARTY
AT+CIMI REQUEST INTERNATIONAL MOBILE SUBSCRIBER IDENTITY
AT+CLCC LIST CURRENT CALLS OF ME
AT+ CL CK FACILITY LOCK
AT+ CL IP CALLING LINE IDENTIFICATION PRESENTATION
AT+ CL IR CALLING LINE IDENTIFICATION RESTRICTION
AT+CMEE REPORT MOBILE EQUIPMENT ERROR
AT+ CO LP CONNECTED LINE IDENTIFICATION PRESENTATION
AT+COPS OPERATOR SELECTION
AT+ CPA S PHONE ACTIVITY STATUS
AT+CPBF FIND PHONEBOOK ENTRIES
AT+CPBR READ CURRENT PHONEBOOK ENTRIES
AT+CPBS SELECT PHONEBOOK MEMORY STORAGE
AT+ CP BW WRITE PHONEBOOK ENTRY
AT+ CP IN ENTER PIN
AT+ CP WD CHANGE PASSWORD
AT+CR SERVICE REPORTING CONTROL
AT+CRC SET CELLULAR RESULT CODES FOR INCOMING CALL
INDICATION
![](asset-2e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 46 15.01.2010
AT+CREG NETWORK REGISTRATION
AT+CRLP SELECT RADIO LINK PROTOCOL PARAMETER
AT+CRSM RESTRICTED SIM ACCESS
AT+ CS Q SIGNAL QUALITY REPORT
AT+ FC LAS S FAX: SELECT, READ OR TEST SERVICE CLASS
AT+ FM I FAX: REPORT MANUFACTURED ID
AT+FMM FAX: REPORT MODEL ID
AT+ FM R FAX: REPORT REVISION ID
AT+ VT D TONE DURATION
AT+ VT S DTMF AND TONE GENERATION
AT+CMUX MULTIPLEXER CONTROL
AT+CNUM SUBSCRIBER NUMBER
AT+ CP OL PREFERRED OPERATOR LIST
AT+COPN READ OPERATOR NAMES
AT+CFUN SET PHONE FUNCTIONALITY
AT+CCLK CLOCK
AT+ CS IM GENERIC SIM ACCESS
AT+ CA LM ALERT SOUND MODE
AT+CRSL RINGER SOUND LEVEL
AT+ CLV L LOUD SPEAKER VOLUME LEVEL
AT+ CM UT MUTE CONTROL
AT+ CP UC PRICE PER UNIT CURRENCY TABLE
AT+CCWE CALL METER MAXIMUM EVENT
AT+CBC BATTERY CHARGE
AT+CUSD UNSTRUCTURED SUPPLEMENTARY SERVICE DATA
AT+CSSN SUPPLEMENTARY SERVICES NOTIFICATION
3.2 Detailed Descriptions of AT Command According to GSM07.07
3.2.1 AT+CACM Accumulated Call Meter (ACM) Reset Or Query
AT+CACM Accumulated Call Meter(ACM) Reset Or Query
Test Command
AT+CACM=?
Response
OK
Parameter
Read Command
AT+CACM?
Response
TA returns the current value of ACM.
+CACM: <acm>
OK
If error is related to ME functionality:
![](asset-2f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 47 15.01.2010
+CME ERROR: <err>
Parameter
<acm> string type (string should be included in quotation
marks); three bytes of the current ACM value in
hexa-decimal format (e.g. "00001E" indicates
decimal value 30)
000000 – FFFFFF
Write Command
AT+CACM=[<pa
sswd>]
Parameter
<passwd> string type (string should be included in quotation
marks):
SIM PIN2
Response
TA resets the Advice of Charge related accumulated call meter (ACM)
value in SIM file EF (ACM). ACM contains the total number of home
units for both the current and preceding calls.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Reference
GSM 07.07 [13]
Note
3.2.2 AT+CAMM Accumulated Call Meter Maximum (ACM max) Set Or Query
AT+CAMM Accumulated Call Meter Maximum(ACM max) Set Or Query
Test Command
AT+CAMM=?
Response
OK
Parameter
Read Command
AT+ CAMM?
Response
TA returns the current value of ACM max.
+CAMM: <acmmax>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
see Write Command
Write Command
AT+CAMM=[<a
cmmax>[,<passw
d>]]
Response
TA sets the Advice of Charge related accumulated call meter maximum
value in SIM file EF (ACM max). ACM max contains the maximum
number of home units allowed to be consumed by the subscriber.
OK
If error is related to ME functionality:
+CME ERROR: <err>
ERROR
![](asset-30.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 48 15.01.2010
Parameters
<acmmax> string type (string should be included in quotation
marks); three bytes of the max. ACM value in
hex-decimal format (e.g. "00001E" indicates decimal
value 30)
000000
disable ACMmax feature
000001-FFFFFF
<passwd> string type (string should be included in quotation
marks)
SIM PIN2
Reference
GSM 07.07 [13]
Note
3.2.3 AT+CAOC Advice Of Charge
AT+CAOC Advice Of Charge
Test Command
AT+CAOC=?
Response
+CAOC: (list of supported <mode>s)
OK
Parameters
see Write Command
Read Command
AT+CAOC?
Response
+CAOC: <mode>
OK
Parameters
see Write Command
Write Command
AT+CAOC=<mo
de>
Response
TA sets the Advice of Charge supplementary service function mode.
If error is related to ME functionality:
+CME ERROR: <err>
ERROR
If <mode>=0, TA returns the current call meter value
+CAOC: <ccm>
OK
If <mode>=1, TA deactivates the unsolicited reporting of CCM value
OK
If <mode>=2. TA activates the unsolicited reporting of CCM value
OK
Parameters
<mode> 0 query CCM value
![](asset-31.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 49 15.01.2010
1 deactivate the unsolicited reporting of CCM
value
2 activate the unsolicited reporting of CCM value
<ccm> string type (string should be included in quotation
marks); three bytes of the current CCM value in
hex-decimal format (e.g. "00001E" indicates decimal
value 30); bytes are similarly coded as ACMmax
value in the SIM
000000-FFFFFF
Reference
GSM 07.07 [13]
Note
3.2.4 AT+CBST Select Bearer Service Type
AT+CBST Select Bearer Service Type
Test Command
AT+CBST=?
Response
+CBST: (list of supported <speed>s) ,(list of supported <name>s) ,(list
of supported <ce>s)
OK
Parameters
see Write Command
Read Command
AT+CBST?
Response
+CBST: <speed>,<name>,<ce>
OK
Parameter
see Write Command
Write Command
AT+CBST=[<spe
ed>[,<name>[,<c
e>]]]
Response
TA selects the bearer service <name> with data rate <speed>, and the
connection element <ce> to be used when data calls are originated.
OK
ERROR
Parameters
<speed> 0 Auto-bauding (automatic selection of the speed; this
setting is possible in case of 3.1kHz modern and
non-transparent service)
7 9600 bps (V.32)
71 9600 bps(V.110 or X.31 flag stuffing)
Supported if UMTS_FTR is activated
<name> 0 Data circuit asynchronous (UDI or 3.1 kHz modem)
<ce> 1 non-transparent
![](asset-32.png)
SIM900 AT Commands Set
Reference Note
GSM 07.07 [14] z GSM 02.02[1]: lists the allowed combinations of the sub parameters
z It only supports the speed of 9600bps when in non-transparent mode.
3.2.5 AT+CCFC Call Forwarding Number And Conditions
AT+CCFC Call Forwarding Number And Conditions Control
SIM900R01_ATC_V1.00 50 15.01.2010
Response
+CCFC: (list of supported <reason>s)
OK
Test Command
AT+CCFC=?
Parameters
see Write Command
Response
TA controls the call forwarding supplementary service. Registration,
erasure, activation, deactivation, and status query are supported.
Only ,<reads> and <mode> should be entered with mode (0-2,4)
If <mode>≠2 and Command successful
OK
If <mode>=2 and Command successful (only in connection with <reads> 0
–3)
For registered call forwarding numbers:
when <mode>=2 and command successful:
+CCFC: <status>,<class1> [,<
number
>,<t
ype
>[,<
subaddr
>,<
sa
t
ype
>[,<
time>]]]
[<CR><LF>+CCFC: <status>,<class2>
[,<
number
>,<t
ype
>[,<
subaddr
>,<
sa
t
ype
>[,< time>]]][…]
OK
If no call forwarding numbers are registered (and therefore all classes are
inactive):
+CCFC: <status>, <class>
OK
where <status>=0 and <class>=7
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CCFC =
<reason>,
<mode>
[, <number> [,
<type> [,<class>
[, <subaddr>
[,<satype>
[,time]]]]]]
Parameters
<reason>
0 unconditional
1 mobile busy
2 no reply
3 not reachable
![](asset-33.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 51 15.01.2010
4 all call forwarding
5 all conditional call forwarding
<mode>
0 disable
1 enable
2 query status
3 registration
4 erasure
<number> string type (Phone number of forwarding address in format
specified by <type>)
<type> Type of address
<subaddr> string type (subaddress of format specified by <satype>)
<satype> type of sub-address in integer
<class> 1 voice (telephony)
2 Data (refers to all bearer services; with <mode>=2 this may
refer only to some bearer service if TA does not support
values 16, 32, 64 and 128)
4 Fax (facsimile services)
7 all classes
<time> 1..30 When "no reply" is enabled or queried, this gives the time in
seconds to wait before call is forwarded, default value is 20.
<status>
0 - not active
1 - active
Reference Note
GSM07.07
3.2.6 AT+CCWA Call Waiting Control
AT+CCWA Call Waiting Control
Read Command Response
AT+CCWA? +CCWA: <n>
OK
Test Command Response
+CCWA: (list of supported <n>s)
AT+CCWA=?
![](asset-34.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 52 15.01.2010
OK
Write Command
AT+CCWA=[<n
>[,<mode>[,<clas
s>]]]
Response
when <mode>=2 and command successful
+CCWA:
<
s
t
a
t
us
>,<
class1
>[<
CR
><
L
F>+
CC
WA:
<status>,<class2> […]]
TA controls the Call Waiting supplementary service. Activation,
deactivation and status query are supported.
If <mode>≠2 and Command successful
OK
If <mode>=2 and Command successful
+CCWA :<status>,<class1>[<CR><LF>+CCWA:<status>,<class2>[...]]
OK
Note: <status>=0 should be returned only if service is not active for any
<class> i.e. +CCWA: 0, 7 will be returned in this case.
When mode=2, all active call waiting classes will be reported. In this mode
the Command is abortable by pressing any key.
If error is related to ME functionality:
+CME ERROR: <err>
ERROR
Parameters
<n> 0 disable presentation of an unsolicited result code
1 enable presentation of an unsolicited result code
<mode> when <mode> parameter not given, network is not
interrogated
0 disable
1 enable
2 query status
<class> is a sum of integers each representing a class of information
1 voice (telephony)
2 data (refers to all bearer services; with <mode>=2 this
may refer only to some bearer service if TA does not
support values 16, 32, 64 and 128)
4 fax (facsimile services)
7 default(1+2+4)
<status> 0 not active
1 enable
Unsolicited result code
RING
![](asset-35.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 53 15.01.2010
+CCWA: <number>,<type>,<class>[,<alpha>]
Parameters
<number> string type (string should be included in quotation marks)
phone number of calling address in format specified by
<type>
<type> type of address octet in integer format;
129 Unknown type(IDSN format number)
161 National number type(IDSN format)
145 International number type(ISDN format )
177 Network specific number(ISDN format)
<alpha> optional string type(string should be included in quotation marks)
alphanumeric representation of
<number> corresponding to the entry found in phone book
Reference Note
GSM07.07
3.2.7AT+CEER Extended Error Report
AT+CEER Extended Error Report
Test Command Response
+CEER:(0-1)
AT+CEER=?
OK
Write Command Parameters
<n> 0 the reason for last call release as text code
AT+CEER=<n>
1 the reason for last call release as number code
Execution Response
Command TA returns an extended report of the reason for the last call release.
AT+CEER +CEER: <report>
OK
Parameter
<report> If AT+CEER=0, <c>(string)
<c>(string) string representing the Cause
If AT+CEER=1, CauseSelect: <cs> Cause:<c>
<cs> number representing the CauseSelect
<c>(number) number representing the Cause
Parameters
CauseSelect <cs> Cause <c>(number) <c>(string)
![](asset-36.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 54 15.01.2010
0 (No cause) 0 (No cause)
16 (Service provider) 0 (Unknown)
1 (Not Allowed)
2 (No cause)
6 (Wrong parameter)
9 (Network access not allowed)
20 (all call instances are used)
21 (ACM over ACM Max)
22 (invalid AOC element)
23 (SIM increase not allowed)
24 (switch off)
25 (Unknown call id)
28 (barred)
65 (Local cause) 1 (state error)
2 (no call entity)
3 (wrong TI)
6 (DTMF buffer overflow)
7 (call disconnected)
17 (No cell available)
32 (Local rejection)
33 (PLMN not allowed)
34 (emergency call not possible)
35 (authentication rejected)
36 (network rejection)
37 (LA not allowed)
38 (Local timeout)
39 (server congestion)
40 (local data rejection)
48 (failed replace PDP context)
66 (MM network cause) See [24.008]
67 (CC network cause) See [24.008]
69 (RP cause) See [24.008]
71 (SIM cause) 0 (Unknown problem)
1 (Memory problem)
2 (File Id not found)
![](asset-37.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 55 15.01.2010
6 (Increase problem)
7 (Technical problem)
11 (Command not allowed)
15 (SIM card out)
0 (Unknown)
(
SM cause) See [24.008]
Reference Note
GSM 07.07 [13]
3.2.8 AT+CGMI Request Manufacturer Identification
AT+CGMI Request Manufacturer Identification
Test Command Response
AT+CGMI=? OK
Execution Response
Command TA returns manufacturer identification text.
AT+CGMI <manufacturer>
OK
Parameter
<manufacturer> the ID of manufacturer
Reference Note
GSM 07.07 [13]
3.2.9 AT+CGMM Request Model Identification
AT+CGMM Request Model Identification
Test Command Response
AT+CGMM=? OK
Execution Response
Command TA returns product model identification text.
AT+CGMM <model>
OK
Parameter
<model> product model identification text.
Reference Note
GSM 07.07 [13]
![](asset-38.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 56 15.01.2010
3.2.10 AT+CGMR Request TA Revision Identification Of Software Release
AT+CGMR Request TA Revision Identification Of Software Release
Test Command
AT+CGMR=?
Response
OK
Execution
Command
AT+CGMR
Response
TA returns product software version identification text.
Revision: <revision>
OK
Parameter
<revision> product software version identification text.
Reference
GSM 07.07 [13]
Note
3.2.11 AT+CGSN Request Product Serial Number Identification (Identical With +GSN)
AT+CGSN Request Product Serial Number Identification (Identical With +GSN)
Test Command
AT+CGSN=?
Response
OK
Execution
Command
AT+CGSN
Response
see +GSN
<sn>
OK
Parameter
<sn>International mobile equipment identity (IMEI)
Reference
GSM 07.07 [13]
Note
3.2.12 AT+CSCS Select TE Character Set
AT+CSCS Select TE Character Set
Test Command
AT+CSCS=?
Response
+CSCS: (list of supported <chset>s)
OK
Parameters
<chset> “GSM”
GSM 7 bit default alphabet (3GPP TS 23.038);.
“UCS2” 16-bit universal multiple-octet coded character
set (ISO/IEC10646); UCS2 character strings are
converted to hexadecimal numbers from 0000 to
FFFF; e.g. "004100620063" equals three 16-bit
characters with decimal values 65, 98 and 99
![](asset-39.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 57 15.01.2010
“IRA” International reference alphabet (ITU-T
T.50)
"HEX" character strings consist only of
hexadecimal numbers from 00 to FF;
"PCCP" PC character set Code
"PCDN" PC Danish/Norwegian character set
"8859-1" ISO 8859 Latin 1 character set
Read Command Response
AT+CSCS? +CSCS: <chset>
OK
Parameter
<chset> see Test Command
Write Command Response
AT+CSCS=<chse Sets which character set <chset> are used by the TE. The TA can then
t> convert character strings correctly between the TE and ME character sets.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameter
<chset> see Test Command
Reference Note
GSM 07.07 [13]
3.2.13 AT+CSTA Select Type Of Address
AT+CSTA Select Type Of Address
Test Command Response
AT+CSTA=? +CSTA: (list of supported <type>s)
OK
Read Command Response
AT+CSTA? +CSTA: <type>
OK
Parameter
< type > Current address type setting.
Write Command Response
AT+CSTA=<type OK
>
If <type> is not in the parameter range:
![](asset-3a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 58 15.01.2010
ERROR
Parameters
<type> type of address octet in integer format;
129 Unknown type(IDSN format number)
161 National number type(IDSN format)
145 International number type(ISDN format )
177 Network specific number(ISDN format)
Reference
GSM 07.07 [13]
Note
z The ATD Command overrides this setting when a number is dialed.
3.2.14 AT+CHLD Call Hold And Multiparty
AT+CHLD Call Hold And Multiparty
Test Command
AT+CHLD=?
Response
+CHLD: (list of supported <n>s)
OK
Response
TA controls the supplementary services Call Hold, Multiparty and Explicit
Call Transfer. Calls can be put on hold, recovered, released, added to
conversation, and transferred.
Note These supplementary services are only applicable to tele service 11
(Speech: Telephony).
OK
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CHLD=[<n>
]
Parameter
<n> 0 Releases all held calls or sets User Determined User
Busy
(UDUB) for a waiting call
1 Releases all active calls (if any exist) and accepts t
he
o
t
her
(held or waiting) call.
1x Releases a specific active call x
2 Place all active calls on hold (if any) and accept the
other (held or waiting) call.
2x Places all active calls on hold except call X with which
communication shall be supported.
3 Adds a held call to the conversation.
![](asset-3b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 59 15.01.2010
Reference Note
3.2.15 AT+CIMI Request International Mobile Subscriber Identity
AT+CIMI Request International Mobile Subscriber Identity
Test Command
AT+CIMI=?
Response
OK
Parameter
Execution
Command
AT+CIMI
Response
TA returns <IMSI>for identifying the individual SIM which is attached to
ME.
<IMSI>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameter
<IMSI> International Mobile Subscriber Identity (string without
double quotes)
Reference
GSM 07.07 [13]
Note
3.2.16 AT+CLCC List Current Calls Of ME
AT+CLCC List Current Calls Of ME
Test Command
AT+CLCC=?
Response
OK
Execution
Command
AT+CLCC
Response
TA returns a list of current calls of ME.
Note: If Command succeeds but no calls are available, no information
response is sent to TE.
[+CLCC: <id1>,<dir>,<stat>,<mode>,<mpty>[,<number>,<type
>[,""]][<CR><LF>+CLCC: <id2>,<dir>,<stat>,<mode>,<
mpty>[,<number>,<type>[,""]][...]]]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<idx> 1..7 Call identification number
![](asset-3c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 60 15.01.2010
This number can be used in +CHLD command
operations
<dir> 0 mobile originated (MO) call
1 mobile terminated (MT) call
<stat> state of the call:
0 active
1 held
2 dialing (MO call)
3 alerting (MO call)
4 incoming (MT call)
5 waiting (MT call)
<mode> bearer/tele service:
0 voice
1 data
2 fax
<mpty> 0 call is not one of multiparty (conference) call parties
1 call is one of multiparty (conference) call parties
<number> string type(string should be included in quotation marks)
phone number in format specified by <type>
<type> type of address
Reference
GSM 07.07
[13][14]
Note
3.2.17 AT+CLCK Facility Lock
AT+CLCK Facility Lock
Response
+CLCK: (list of supported <fac>s)
OK
Test Command
AT+CLCK=?
Parameter
see Write Command
![](asset-3d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 61 15.01.2010
Response
when <mode>=2 and command successful:
+CLCK: <status>[,<class1>[<CR><LF>+CLCK:
<status>,<class2>[…]]
+CME ERROR: <err>
This Command is used to lock, unlock or interrogate a ME or a network
facility <fac>. Password is normally needed to do such actions. When
querying the status of a network service (<mode>=2) the response line for
‘not active’ case (<status>=0) should be returned only if service is not active
for any <class>.
If <mode>≠2 and Command is successful
OK
If <mode>=2 and Command is successful
+CLCK: <status>[,<class1>[<CR><LF>
+CLCK: <status>, class2....]]
OK
Write Command
AT+CLCK =
<fac>, <mode>
[,<passwd>
[,<class>]]
Parameters
<fac>
"AO" BAOC (Barr All Outgoing Calls)
"OI" BOIC (Barr Outgoing International Calls)
"OX" BOIC-exHC (Barr Outgoing International Calls except
to Home Country)
"AI" BAIC (Barr All Incoming Calls)
"IR" BIC-Roam (Barr Incoming Calls when Roaming
outside the home country)
"AB" All Barring services
"AG" All out Going barring services
"AC" All in Coming barring services
"FD" SIM card or active application in the UICC (GSM or
USIM) fixed dialling memory feature (if PIN2
authentication has not been done during the current
session, PIN2 is required as <passwd>)
"SC" SIM (lock SIM/UICC card) (SIM/UICC asks
password
in
MT power-up and when this lock command issued)
Correspond to PIN1 code.
"PN" Network Personalization, Correspond to NCK code
"PU" network subset Personalization
Correspond to NSCK code
"PP" service Provider Personalization
![](asset-3e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 62 15.01.2010
Correspond to SPCK code
<mode> 0 unlock
1 lock
2 query status
<passwd> string type (Shall be the same as password specified for the
facility from the MT user interface or with command
Change Password +CPWD)
<class> 1 voice (telephony)
2 data refers to all bearer services; with <
mode
>=
2
t
his
may refer only to some bearer service if TA does not
support values 16, 32, 64 and 128)
4 fax(facsimile services)
7 all classes (default)
<status> 0 Not active
1 Active
Reference
GSM 07.07 [14]
Note
CME errors if SIM not inserted or PIN is not entered.
3.2.18 AT+CLIP Calling Line Identification Presentation
AT+CLIP Calling Line Identification Presentation
Response
+CLIP: <n>, <m>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Read Command
AT+CLIP?
Parameters
see Write Command
Response
+CLIP: (list of supported <n>s)
OK
Test Command
AT+CLIP=?
Parameters
see Write Command
Write Command
AT+CLIP=[<n>]
Response
TA enables or disables the presentation of the CLI at the TE. It has no effect
on the execution of the supplementary service CLIP in the network.
OK
If error is related to ME functionality:
+CME ERROR: <err>
![](asset-3f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 63 15.01.2010
Parameters
<n> 0
Disable +CLIP notification
1 Enable +CLIP notificatio
<m> 0 CLIP not provisioned
1 CLIP provisioned
2 unknown (e.g. no network, etc.)
Unsolicited result code
When the presentation of the CLI at the TE is enabled (and calling
subscriber allows), an unsolicited result code is returned after every RING
(or +CRING: <type>) at a mobile terminating call.
+CLIP: <number>,<type> [,<subaddr>,<satype>[,[“”][,<CLI
validity>]]]
Parameters
<number> string type(string should be included in quotation marks)
phone number of calling address in format specified by
<type>
<type> type of address octet in integer format;
129 Unknown type(IDSN format number)
161 National number type(IDSN format)
145 International number type(ISDN format )
177 Network specific number(ISDN format)
<subaddr> string type(subaddress of format specified by <satype>)
<satype> Integer type(type of subaddress)
<CLI validity> 0 CLI valid
1 CLI has been withheld by the originator
2 CLI is not available due to interworking problems
or limitations of originating network
Reference Note
3.2.19 AT+CLIR Calling Line Identification Restriction
AT+CLIR Calling Line Identification Restriction
Response
+CLIR: <n>, <m>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Read Command
AT+CLIR?
Parameters
see Write Command
Test Command Response
![](asset-40.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 64 15.01.2010
AT+CLIR=? +CLIR: (list of supported <n>s)
OK
Response
TA restricts or enables the presentation of the CLI to the called party when
originating a call.
The Command overrides the CLIR subscription (default is restricted or
allowed) when temporary mode is provisioned as a default adjustment for
all following outgoing calls. This adjustment can be revoked by using the
opposite Command.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CLIR=[<n>]
Parameters
<n> (parameter sets the adjustment for outgoing calls):
0 presentation indicator is used according to the
subscription of the CLIR service
1 CLIR invocation
2 CLIR suppression
<m> (parameter shows the subscriber CLIR service status in the
network):
0 CLIR not provisioned
1 CLIR provisioned in permanent mode
2 unknown (e.g. no network, etc.)
3 CLIR temporary mode presentation restricted
4 CLIR temporary mode presentation allowed
Reference Note
3.2.20 AT+CMEE Report Mobile Equipment Error
AT+CMEE Report Mobile Equipment Error
Response
+CMEE: (list of supported <n>s)
OK
Test Command
AT+CMEE=?
Parameters
see Write Command
![](asset-41.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 65 15.01.2010
Response
+CMEE: <n>
OK
Read Command
AT+CMEE?
Parameters
See Write Command
Response
TA disables or enables the use of result code +CME ERROR: <err> as an
indication of an error relating to the functionality of the ME.
OK
If error is related to ME functionality:
+CME ERROR:<err>
Write Command
AT+CMEE=[<n>
]
Parameters
<n> 0 Disable +CME ERROR: <err> result code and use
ERROR instead.
1 Enable +CME ERROR: <err> result code and use
numeric <
err
>
2 Enable +CME ERROR: <err> result code and use
verbose <
err
>
values
Reference
GSM 07.07 [13]
Note
3.2.21 AT+COLP Connected Line Identification Presentation
AT+COLP Connected Line Identification Presentation
Response
+COLP: <n>,<m>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Read Command
AT+COLP?
Parameters
See Write Command
Response
+COLP: (list of supported <n>s)
OK
Test Command
AT+COLP=?
Parameters
See Write Command
![](asset-42.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 66 15.01.2010
Response
TA enables or disables the presentation of the COL (Connected Line) at the
TE for a mobile originated call. It has no effect on the execution of the
supplementary service COLR in the network.
Intermediate result code is returned from TA to TE before any +CR or
V.25ter responses.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<n> (parameter sets/shows the result code presentation status in
the TA):
0 Disable +COLP notification
1 Enable +COLP notification
<m> (parameter shows the subscriber COLP service status in the
network):
0 COLP not provisioned
1 COLP provisioned
2 unknown (e.g. no network, etc.)
Intermediate result code
When enabled (and called subscriber allows), an intermediate result code is
returned before any +CR or V.25ter responses:
+COLP: <number>,<type>[,<subaddr>,<satype> [,””]]
Write Command
AT+COLP=[<n>
]
Parameters
<number> string type(string should be included in quotation
marks) phone number of format specified by <type>
<type> type of address octet in integer format;
129 Unknown type(IDSN format number)
161 National number type(IDSN format)
145 International number type(ISDN format )
177 Network specific number(ISDN format)
<subaddr> string type(string should be included in quotation
marks) sub address of format specified by <satype>
<satype> type of sub address octet in integer format (refer GSM
04.08 [8] sub clause 10.5.4.8)
Reference Note
3.2.22 AT+COPS Operator Selection
AT+COPS Operator Selection
![](asset-43.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 67 15.01.2010
Response
TA returns a list of quadruplets, each representing an operator present in
the network. Any of the formats may be unavailable and should then be an
empty field. The list of operators shall be in order: home network,
networks referenced in SIM, and other networks.
+COPS: (list of supported<stat>, long alphanumeric <oper>, short
alphanumeric <oper>, numeric <oper>)s [,,(list of supported
<mode>s),(list of supported <format>s)]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Test Command
AT+COPS=?
Parameters
see Write Command
Response
TA returns the current mode and the currently selected operator. If no
operator is selected, <format> and <oper> are omitted.
+COPS: <mode>[,<format>, <oper>]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Read Command
AT+COPS?
Parameters
see Write Command
Write Command
AT+COPS =
<mode>
[,<format>[,<ope
r>]]
Response
TA forces an attempt to select and register the GSM network operator. If
the selected operator is not available, no other operator shall be selected
(except <mode>=4). The selected operator name format shall apply to
further read commands (+COPS?).
OK
If error is related to ME functionality:
+CME ERROR: <err>
![](asset-44.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 68 15.01.2010
Parameters
<stat> 0 unknown
1 operator available
2 operator current
3 operator forbidden
<oper> Refer to [27.007]
operator in format as per <format>
<mode> 0 automatic mode; <oper> field is ignored
1 Manual (<oper> field shall be present, and <AcT>
optionally)
4 manual/automatic (<oper> field shall be present); if
manual selection fails, automatic mode (<mode>=0)
is entered
<format> 0 long format alphanumeric <oper>;(default)
1 short format alphanumeric <oper>
2 numeric <oper>; GSM Location Area Identification
number
Reference
GSM 07.07 [14]
Note
3.2.23 AT+CPAS Phone Activity Status
AT+CPAS Phone Activity Status
Response
+CPAS: (list of supported <pas>s)
OK
Test Command
AT+CPAS=?
Parameter
see Execution Command
Execution
Command
AT+CPAS
Response
TA returns the activity status of ME.
+CPAS: <pas>
OK
If error is related to ME functionality:
+CME ERROR: <err>
![](asset-45.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 69 15.01.2010
Parameter
<pas> 0 Ready (MT allows commands from TA/TE)
2
Unknown (MT is not guaranteed to respond to
instructions)
3 Ringing (MT is ready for commands from TA/TE,
but the ringer is active)
4 Call in progress (MT is ready for commands from
TA/TE, but a call is in progress)
Reference
GSM 07.07 [13]
Note
3.2.24 AT+CPBF Find Phonebook Entries
AT+CPBF Find Phonebook Entries
Response
+CPBF: maximum length of field <nlength>,maximum length of field
<tlength>
OK
If error is related to ME functionality:
+CME ERROR: <err>
Test Command
AT+CPBF=?
Parameters
see Write Command
Write Command
AT+CPBF=[<fin
dtext>]
Response
TA returns phone book entries (from the current phone
b
ook memory
storage selected with +CPBS) which contains alphanumeric string
<findtext>.
[+CPBF:<index1>,<number>,<type>,<text>][----]
<CR><LF>[+CBPF:<index2>,<number>,<type>,<text>]
OK
![](asset-46.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 70 15.01.2010
Parameters
<index1> integer type values in the range of location numbers of phone
book memory
<index2> integer type values in the range of location numbers of phone
book memory
<number> string type(string should be included in quotation marks)
phone number of format <type>
<type> type of address octet in integer format ;
129 Unknown type(IDSN format number)
161 National number type(IDSN format)
145 International number type(ISDN format )
177 Network specific number(ISDN format)
<text> string type(string should be included in quotation marks) field of
maximum length <tlength> in current TE character set specified by +CSCS.
<nlength> integer type value indicating the maximum length of field
<number>
<tlength> integer type value indicating the maximum length of field
<text>
Reference
GSM 07.07 [13]
Note
3.2.25 AT+CPBR Read Current Phonebook Entries
AT+CPBR Read Current Phonebook Entries
Response
TA returns location range supported by the current storage as a compound
value and the maximum lengths of <number> and <text> fields.
+CPBR: (list of supported <index>s), <nlength>, <tlength>
OK
Test Command
AT+CPBR=?
Parameters
<index> location number
<nlength> max. length of phone number
<tlength> max. length of text for number
Write Command
AT+CPBR=
<index1>
[, <index2>]
Response
TA returns phone book entries in location number range <index1>...
<index2> from the current phone book memory storage selected with
+CPBS. If <index2> is left out, only location <index1> is returned.
+CPBR:<index1>,<number>,<type>,<text>[<CR><LF>+CPBR: .....+C
PBR: <index2>, <number>, <type>, <text>]
OK
![](asset-47.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 71 15.01.2010
Parameters
<index1> read as of this location number
<index2> read to this location number
<number> phone number
<type> type of number
<text> text for phone number in current TE character set specified
by +CSCS.
Reference
GSM 07.07 [13]
Note
3.2.26 AT+CPBS Select Phonebook Memory Storage
AT+CPBS Select Phonebook Memory Storage
Response
+CPBS: (list of supported <storage>s)
OK
Test Command
AT+CPBS=?
Parameters
see Write Command
Response
+CPBS: <storage>[,<used>,<total>]
OK
Read Command
AT+CPBS?
Parameters
See Write Command
Write Command
AT+CPBS=<stor
age>
Response
TA selects current phone book memory storage, which is used by other
phone book commands.
OK
![](asset-48.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 72 15.01.2010
Parameters
<storage> "DC" ME dialed calls list(+CPBW may not be applicable
for this storage)(same as LD)
"EN" SIM (or MT) emergency number (+CPBW is not
be applicable for this storage)
"FD" SIM fix dialing-phone book。If a SIM card is
present or if a UICC with an active GSM
application is present, the information in EFFDN
under DFTelecom is selected
"MC" MT missed (unanswered received) calls
lis
t
(
+
C
PBW
may not be applicable for this storage)
"ON" SIM (or MT) own numbers (MSISDNs) list
(reading of this storage may be available through
+CNUM also). When storing information in the
SIM/UICC, if a SIM card is present or if a UICC
with an active GSM application is present, the
information in EFMSISDN under DFTelecom is
selected.
"RC" MT received calls list (+CPBW may not be
applicable for this storage)
"SM" SIM/UICC phonebook. If a SIM card is present or
if a UICC with an active GSM application is present, the
EFADN under DFTelecom is selected.
"LA" Last Number All list (LND/LNM/LNR)
"BN" SIM barred dialed number
"SD" SIM service dial number
"VM" SIM voice mailbox
"LD" SIM last-dialing-phone book
<used> integer type value indicating the total number of used
Locations in selected memory
<total> integer type value indicating the total number of locations
In selected memory
Reference
GSM 07.07 [13]
Note
3.2.27 AT+CPBW Write Phonebook Entry
AT+CPBW Write Phonebook Entry
![](asset-49.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 73 15.01.2010
Response
TA returns location range supported by the current storage, the maximum
length of <number> field, supported number formats of the storage, and the
maximum length of <text> field.
+CPBW: (list of supported <index>s), <nlength>, (list of supported
<type>s), <tlength>
OK
Test Command
AT+CPBW=?
Parameters
see Write Command
Response
TA writes phone book entry in location number <index> in the current
phone book memory storage selected with +CPBS. Entry fields written are
phone number <number> (in the format <type>) and text <text> associated
with the number. If those fields are omitted, phone book entry is deleted. If
<index> is left out, but <number> is given, entry is written to the first free
location in the phone book.
OK
Write Command
AT+CPBW=
<index1>
[, <number>,
[<type>,
[<text>]]]
Parameters
<nlength> max. length of phone number
<tlength> max. length of text for number
<index> location number
<number> phone number
<type> type of number;
129 National number type(IDSN format
161 National number type(IDSN format)
145 International number type(ISDN format )
177 Network specific number(ISDN format)
<text> string type(string should be included in quotation marks):
text for phone number in current TE character set specified
by +CSCS.
Note: The following characters in <text> must be entered via the
escape sequence:
GSM char. Seq. Seq.(hex) Note
\ \5C 5C 35 43 (backslash)
“ \22 5C 32 32 (string delimiter)
BSP \08 5C 30 38 (backspace)
NULL \00 5C 30 30 (GSM null)
‘0’ (GSM null) may cause problems for application layer
software when reading string lengths.
Reference Note
![](asset-4a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 74 15.01.2010
GSM 07.07 [13]
3.2.28 AT+CPIN Enter PIN
AT+CPIN Enter PIN
Test Command
AT+CPIN=?
Response
OK
Parameter
see Write Command
Response
TA returns an alphanumeric string indicating whether some password is
required or not.
+CPIN: <code>
OK
Read Command
AT+CPIN?
Parameter
<code>
READY MT is not pending for any password
SIM PIN MT is waiting SIM PIN to be given
SIM PUK MT is waiting for SIM PUK to be given
PH_SIM PIN ME is waiting for phone to SIM card (antitheft)
PH_SIM PUK ME is waiting for SIM PUK (antitheft)
SIM PIN2 PIN2, e.g. for editing the FDN book possible only
if preceding Command was acknowledged with +CME ERROR:17
SIM PUK2 possible only if preceding Command was acknowledged
with error +CME ERROR: 18.
Response
TA stores a password which is necessary before it can be operated (SIM
PIN, SIM PUK, PH-SIM PIN, etc.).
If the PIN required is SIM PUK or SIM PUK2, the second pin is required.
This second pin, <new pin>, is used to replace the old pin in the SIM.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CPIN=<pin>
[, <new pin>]
Parameters
<pin> string type; password
<new pin> string type; If the PIN required is SIM PUK or SIMPUK2:
new password
Reference
GSM 07.07 [13]
Note
![](asset-4b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 75 15.01.2010
3.2.29 AT+CPWD Change Password
AT+CPWD Change Password
Test Command
AT+CPWD=?
Response
TA returns a list of pairs which present the available facilities and the
maximum length of their password.
+CPWD: (list of supported <fac>s, <pwdlength>s)
OK
Parameters
<fac>
otherwise see Write Command
<pwdlength> integer max. length of password
Response
TA sets a new password for the facility lock function.
OK
Write Command
AT+CPWD =
<fac>,
<oldpwd>,
<newpwd> Parameters
<fac>
"AO" BAOC (Barr All Outgoing Calls)
"OI" BOIC (Barr Outgoing International Calls)
"OX" BOIC-exHC (Barr Outgoing International Calls except
to Home Country)
"AI" BAIC (Barr All Incoming Calls)
"IR" BIC-Roam (Barr Incoming Calls when Roaming
outside the home country)
"AB" All Barring services
“P2” SIM PIN2
"SC" SIM (lock SIM/UICC card) (SIM/UICC asks
password
in
MT power-up and when this lock command issued)
Correspond to PIN1 code.
<oldpwd> string type (string should be included in quotation marks):
password specified for the facility from the user interface or
with Command. If an old password has not yet been set,
<oldpwd> is not to enter.
<newpwd> string type (string should be included in quotation marks):
new password
Reference
GSM 07.07 [13]
Note
3.2.30 AT+CR Service Reporting Control
AT+CR Service Reporting Control
![](asset-4c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 76 15.01.2010
Response
+CR: (list of supported <mode>s)
OK
Test Command
AT+CR=?
Parameter
see Write Command
Response
+CR: <mode>
OK
Read Command
AT+CR?
Parameters
see Write Command
Response
TA controls whether or not intermediate result code +CR: <serv> is
returned from the TA to the TE at a call set up.
OK
Parameter
<mode> 0 Disable
1 Enable
Write Command
AT+CR=[<mode
>]
Intermediate result code
If enabled, an intermediate result code is transmitted at the point during
connect negotiation at which the TA has determined which speed and
quality of service will be used, before any error control or data
compression reports are transmitted, and before any final result code (e.g.
CONNECT) is transmitted.
+CR:<serv>
Parameter
<serv> ASYNC asynchronous transparent
SYNC synchronous transparent
REL ASYNC asynchronous non-transparent
REL SYNC synchronous non-transparent
Reference
GSM 07.07 [13]
Note
3.2.31 AT+CRC Set Cellular Result Codes For Incoming Call Indication
AT+CRC Set Cellular Result Codes For Incoming Call Indication
Test Command
AT+CRC=?
Response
+CRC: (list of supported <mode>s)
OK
![](asset-4d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 77 15.01.2010
Parameters
see Write Command
Response
+CRC: <mode>
OK
Read Command
AT+CRC?
Parameter
see Write Command
Response
TA controls whether or not the extended format of incoming call
indication is used.
OK
Parameter
<mode> 0 Disable extended format
1 Enable extended format
Write Command
AT+CRC=[<mod
e>]
Unsolicited result code
When enabled, an incoming call is indicated to the TE with unsolicited
result code +CRING: <type> instead of the normal RING.
Parameter
<type> ASYNC asynchronous transparent
SYNC synchronous transparent
REL ASYNC asynchronous non-transparent
REL SYNC synchronous non-transparent
FAX facsimile
VOICE voice
Reference
GSM 07.07 [13]
Note
3.2.32 AT+CREG Network Registration
AT+CREG Network Registration
Response
+CREG: (list of supported <n>s)
OK
Test Command
AT+CREG=?
Parameters
see Write Command
![](asset-4e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 78 15.01.2010
Read Command
AT+CREG?
Response
TA returns the status of result code presentation and an integer <stat>
which shows whether the network has currently indicated the registration
of the ME. Location information elements <lac> and <ci> are returned
only when <n>=2 and ME is registered in the network.
+CREG: <n>,<stat>[,<lac>,<ci>]
OK
If error is related to ME functionality:
+CME ERROR: <err>
Response
TA controls the presentation of an unsolicited result code +CREG: <stat>
when <n>=1 and there is a change in the ME network registration status.
OK
Parameters
<n> 0 disable network registration unsolicited result code
1 enable network registration unsolicited result code
+CREG: <stat>
2 enable network registration unsolicited result code with
location information +CREG: <stat>[,<lac>,<ci>]
<stat> 0 not registered, MT is not currently searching a new
operator to register to
1 registered, home network
2 not registered, but MT is currently searching a new
operator to register to
3 registration denied
4 unknown
5 registered, roaming
<lac> string type(string should be included in quotation marks);
two byte location area code in hexadecimal format
< ci > string type(string should be included in quotation marks);
two byte cell ID in hexadecimal format
Write Command
AT+CREG=<n>
Unsolicited result code
If <n>=1 and there is a change in the MT network registration status
+CREG: <stat>
If <n>=2 and there is a change in the MT network registration status or a
change of the network cell:
+CREG: <stat>[,<lac>,<ci>]
Parameters
see Write Command
Reference Note
![](asset-4f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 79 15.01.2010
GSM 07.07 [13]
3.2.33 AT+CRLP Select Radio Link Protocol Parameter
AT+CRLP Select Radio Link Protocol Parameter
Response
TA returns values supported. RLP versions 0 and 1 share the same
parameter set. TA returns only one line for this set (where <verx> is not
present).
+CRLP: (list of supported <iws>s), (list of supported <mws>s), (list of
supported <T1>s), (list of supported <N2>s), (list of supported <ver1>s),
(list of supported <T4>s)
OK
Test Command
AT+CRLP=?
Parameters
see Write Command
Response
TA returns current settings for RLP version. RLP versions 0 and 1 share
the same parameter set. TA returns only one line for this set (where
<verx> is not present).
+CRLP: <iws>,<mws>,<T1>,<N2>,<ver1>,<T4>
OK
Read Command
AT+CRLP?
Parameters
see Write Command
Write Command
AT+CRLP=[<iws
>[,<mws>[,<T1>[
,<N2>[,<ver>[,<T
4>]]]]]]
Response
TA sets radio link protocol (RLP) parameters used when non-transparent
data calls are setup.
OK
![](asset-50.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 80 15.01.2010
Parameters
<iws> 0-61 Interworking window size (IWF to MS)
<mws> 0-61 Mobile window size(MS to IWF)
<T1> 44-255 acknowledgment timer T1 in 10 ms units
<N2> 1-255 retransmission attempts N2
<verx> 0 RLP version number
<T4> 7 re-sequencing period in integer format, in units of 10
ms.
Reference
GSM 07.07 [13]
Note
3.2.34 AT+CRSM Restricted SIM Access
AT+CRSM Restricted SIM Access
Test Command
AT+CRSM=?
Response
OK
Write Command
AT+CRSM=<Co
mmand>[,<fileId
>[,<P1>,<P2>,<P
3>[,<data>]]]
Response
+CRSM: <sw1>, <sw2> [,<response>]
OK / ERROR / +CME ERROR: <err>
Parameters
<Command>
176 READ BINARY
178 READ RECORD
192 GET RESPONSE
214 UPDATE BINARY
220 UPDATE RECORD
242 STATUS
all other values are reserved; refer GSM 11.11.
<fileId> integer type; this is the identifier for an elementary data file on
SIM. Mandatory for every Command except STATUS
<P1>,<P2>,<P3> integer type, range 0 - 255
parameters to be passed on by the ME to the SIM; refer GSM 11.11.
<data> information which shall be written to the SIM (hex-
decimal character format)
<sw1>, <sw2> integer type, range 0 - 255
status information from the SIM about the execution
of the actual Command. These parameters are delivered to the TE in both
cases, on successful or failed execution of the Command; refer GSM
11.11.
![](asset-51.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 81 15.01.2010
<response> response of a successful completion of the Command
previously issued (hexadecimal character format)
Reference
GSM 07.07
GSM 11.11
Note
3.2.35 AT+CSQ Signal Quality Report
AT+CSQ Signal Quality Report
Test Command
AT+CSQ=?
Response
+CSQ: (list of supported <rssi>s),(list of supported <ber>s)
OK
Response
+CSQ: <rssi>,<ber>
OK
+CME ERROR: <err>
Execution Command returns received signal strength indication <rssi>
and
channel bit error rate <ber> from the ME. Test Command returns values
supported by the TA.
Execution
Command
AT+CSQ
Parameters
<rssi>
0 -115 dBm or less
1 -111 dBm
2...30 -110... -54 dBm
31 -52 dBm or greater
99 not known or not detectable
<ber> (in percent):
0...7 as RXQUAL values in the table in GSM 05.08 [20] subclause 7.2.4
99 not known or not detectable
Reference
GSM 07.07 [13]
Note
3.2.36 AT+FCLASS FAX: Select, Read Or Test Service Class
3.2.37 AT+FCLASS Model Identification
AT+FCLASS Model Identification
Test Command
AT+FCLASS=?
Response
+FCLASS: (list of supported <class>s)
OK
![](asset-52.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 82 15.01.2010
Parameters
see Write Command
Response
+FCLASS: <class>
OK
Read Command
AT+ FCLASS?
Parameters
See Write Command.
Response
TA sets a particular mode of operation (data fax). This causes the TA to
process information in a manner suitable for that type of information
OK
Write Command
AT+FCLASS=
[<class>s]
Parameter
<n> 0 data
1 fax class 1 (TIA-578-A)
Reference
GSM 07.07 [13]
Note
3.2.38 AT+FMI FAX: Report Manufactured ID
AT+FMI FAX: Report Manufactured ID
Response
OK
Test Command
AT+ FMI =?
Parameters
see Execution Command
Response
TA reports one or more lines of information text which permit the user to
identify the manufacturer.
<manufacturer Id>
OK
Execution
Command
AT+ FMI
Parameter
<manufacturer Id> the ID of manufacturer
Reference
EIA/TIA-578-D
Note
3.2.39 AT+FMM FAX: Rreport Model ID
AT+FMM FAX: Rreport Model ID
Response
OK
Test Command
AT+ FMM =?
Parameters
see Execution Command
![](asset-53.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 83 15.01.2010
Response
TA reports one or more lines of information text which permit the user to
identify the specific model of device.
<model Id>
OK
Execution
Command
AT+ FMM
Parameter
<model Id> the ID of model
Reference
EIA/TIA-578-D
Note
3.2.40 AT+FMR FAX: Report Revision ID
AT+FMR FAX: Report Revision ID
Response
OK
Test Command
AT+ FMR =?
Parameter
see Execution Command
Response
TA reports one or more lines of information text which permit the user to
identify the version, revision level or data or other information of the
device.
Revision:<Revision Id>
OK
Execution
Command
AT+ FMR
Parameter
<Revision Id> the version, revision level or data or other information of the
device.
Reference
EIA/TIA-578-D
Note
3.2.41 AT+VTD Tone Duration
AT+VTD Tone Duration
Response
+VTD: (list of supported <n>s)
OK
Test Command
AT+VTD=?
Parameters
see Write Command
![](asset-54.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 84 15.01.2010
Response
+VTD: <n>
OK
Read Command
AT+VTD?
Parameter
see Write Command
Response
This Command refers to an integer <n> that defines the length of tones
emitted as a result of the +VTS Command. This does not affect the D
Command.
OK
Write Command
AT+VTD = <n>
Parameter
<n> 1-255 duration of the tone in 1/10 seconds
Reference
GSM 07.07 [13]
Note
3.2.42 AT+VTS DTMF And Tone Generation
AT+VTS DTMF And Tone Generation
Response
+VTS: (list of supported <dtmf>s), ,(list of supported <duration>s)
OK
Test Command
AT+VTS=?
Parameters
see Write Command
![](asset-55.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 85 15.01.2010
Write Command
Generate tone
Duration is set by
+VTD
AT+VTS=<dtmf-s
tring>
Response
This Command allows the transmission of DTMF tones and arbitrary
tones in voice mode. These tones may be used (for example) when
announcing the start of a recording period.
Note: D is used only for dialing.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Note: The Command is writing only.
Parameters
<dtmf-string> which has a max length of 20 characters, must be entered
between double quotes (“ “) and consists of combinations of the following
separated by commas. But a single character does not require quotes.
1) <dtmf> A single ASCII characters in the set 0-9, #,*, A-D. This is
interpreted as a sequence of DTMF tones whose duration is set by the
+VTD Command.
2) {<dtmf>, <duration>} This is interpreted as a DTMF tone whose
duration is determined by <duration>.
<duration> duration of the tone in 1/10 seconds range :1-255
Reference
GSM 07.07 [13]
Note
3.2.43 AT+CMUX Multiplexer Control
AT+CMUX Multiplexer Control
Response
+CMUX: list of supported (<mode>),(<subset>s),(<port_spe
ed>s),(<N1>s),(<T1>s),(<N2>s),(<T2>s),(<T3>s),(<k>s)
OK
Test Command
AT+CMUX=?
Parameters
See Write Command
Write Command
AT+CMUX=[<m
Response
+CME ERROR: <err>
![](asset-56.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 86 15.01.2010
ode>[,<subset>[,
<port_speed>[,<
N1>[,<T1>[,<N2
>[,<T2>[,<T3>[,<
k>]]]]]]]]]
Parameters
<mode> multiplexer transparency mechanism
0 Basic option
<subset> the way in which the multiplexer control channel is set up
0 UIH frames used only
<port_speed> transmission rate
1 9 600 bits/t
2 19 200 bits/t
3 38 400 bits/t
4 57 600 bits/t
5 115 200bit/s
6 230 400 bits/t
7 460 800 bits/t
Proprietary values, available if MUX NEW PORT
SPEED FTR is activated
8 921 600 bits/t
Proprietary values, available if MUX NEW PORT
SPEED FTR is activated
<N1> maximum frame size
1-32768 Default: 31 (64 if Advanced option is used)
<T1> acknowledgement timer in units of ten milliseconds
1-255 Default:10(100 ms)
<N2> maximum number of re-transmissions
0-100 Default:3
<T2> response timer for the multiplexer control channel in units of
ten milliseconds
2-255 Default:30
<T3> wake up response timers in seconds
1-255 Default:10
<k> window size, for Advanced operation with Error Recovery
options
1-7 Default:2
Read Command
AT+CMUX ?
Response:
+CMUX:[<mode>[,<subset>[,<port_speed>[,<N1>[,<T1>[,<N2>[,<T2
>[,<T3>[,<k>]]]]]]]]]
OK
ERROR
Reference
GSM 07.07 [13]
Note
z The multiplexing transmission rate is according to the current serial
baud rate. It is recommended to enable multiplexing protocol under
![](asset-57.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 87 15.01.2010
115200 bit/s baud rate
z Multiplexer control channels are listed as follows:
Channel Number Type DLCI
None Multiplexer Control 0
1 07.07 and 07.05 1
2 07.07 and 07.05 2
3 07.07 and 07.05 3
4 07.07 and 07.05 4
3.2.44 AT+CNUM Subscriber Number
AT+CNUM Subscriber Number
Test Command
AT+CNUM=?
Response
OK
Response
+CNUM: [<alpha1>],<number1>,<type1>[,<speed>,<service>]
[<CR><LF>+CNUM:[<alpha2>],<number2>,<type2>[,<speed>,<serv
ice>]
[...]]
OK
+CME ERROR: <err>
Execution
Command
AT+CNUM
Parameters
<alphax> optional alphanumeric string associated with <numberx>;
used character set should be the one selected with
Command Select TE Character Set +CSCS
<numberx> string type(string should be included in quotation marks)
phone number of format specified by <typex>
<typex> type of address octet in integer format (refer GSM04.08[8]
subclause 10.5.4.7)
<speed> as defined by the +CBST Command
<service> (service related to the phone number: )
0 asynchronous modem
1 synchronous modem
2 PAD Access (asynchronous)
3 Packet Access (synchronous)
4 Voice
5 Fax
Reference
GSM 07.07 [13]
Note
![](asset-58.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 88 15.01.2010
3.2.45 AT+CPOL Preferred Operator List
AT+CPOL Preferred Operator List
Response
+CPOL: (list of supported <index>s),(list of supported <format>s)
OK
Test Command
AT+CPOL=?
Parameters
see Write Command
Response
+CPOL: <index1>,<format>,<oper1>
[<CR><LF>+CPOL: <index2>,<format>,<oper2>
[…]]
OK
+CME ERROR: <err>
Read Command
AT+CPOL?
Parameters
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CPOL=<ind
ex>[,<format>,<o
per>] Parameters
<index> integer type: order number of operator in SIM preferred
operator list
<format> 0 long format alphanumeric <oper>
1 short format alphanumeric <oper>
2 numeric <oper>
<oper> string type(string should be included in quotation marks):
<format> indicates whether alphanumeric or numeric
format used (see +COPS Command)
Reference
GSM 07.07 [13]
Note
3.2.46 AT+COPN Read Operator Names
AT+COPN Read Operator Names
Test Command
AT+COPN=?
Response
OK
![](asset-59.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 89 15.01.2010
Response
+COPN: <numeric1>,<alpha1 >
[<CR><LF>+COPN: <numeric2>,<alpha2>
[…]]
OK
+CME ERROR: <err>
Execution
Command
AT+COPN
Parameters
<numericn> string type(string should be included in quotation marks):
operator in numeric format (see +COPS)
<alphan> string type(string should be included in quotation marks):
operator in long alphanumeric format (see +COPS)
Reference
GSM 07.07 [13]
Note
3.2.47 AT+CFUN Set Phone Functionality.
AT+CFUN Set Phone Functionality.
Response
+CFUN: (list of supported <fun>s), (list of supported <rst>s)
OK
+CME ERROR: <err>
Test Command
AT+CFUN=?
Parameters
See Write Command
Response
+CFUN: <fun>
OK
+CME ERROR: <err>
Read Command
AT+CFUN?
Parameters
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CFUN=<fun
>,[<rst>]
Parameters
<fun> 0 minimum functionality
1 full functionality (Default)
4 disable phone both transmit and receive RF circuits
<rst> 0 Do not reset the MT before setting it to <fun> power
level
1 Reset the MT before setting it to <fun> power level
![](asset-5a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 90 15.01.2010
Reference
GSM 07.07 [13]
Note
z Minimum functionality mode(AT+CFUN=0)and RF disabled
functionality mode (AT+CFUN=4) cannot be switched to each other.
z The <fun> power level will be written to flash except minimum
functionality.
z AT+CFUN=1,1 can be used to reset module purposely. Response
string “OK” will be returned after module resets if baud rate is set to
fixed baud rate.
3.2.48 AT+CCLK Clock
AT+CCLK Clock
Response
OK
Test Command
AT+CCLK=?
Parameters
Response
+CCLK: <time>
OK
+CME ERROR: <err>
Read Command
AT+CCLK?
Parameter
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CCLK=<tim
e>
Parameter
<time> string type(string should be included in quotation marks)
value; format is "yy/MM/dd,hh:mm:ss±zz", where
characters indicate year (two last digits),month, day, hour,
minutes, seconds and time zone (indicates the difference,
expressed in quarters of an hour, between the local time
and GMT; range -47...+48). E.g. 6th of May 1994,
22:10:00 GMT+2 hours equals to "94/05/06,22:10:00+08"
Reference
GSM 07.07 [13]
Note
3.2.49 AT+CSIM Generic SIM Access
AT+CSIM Generic SIM Access
Test Command
AT+CSIM=?
Response
OK
![](asset-5b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 91 15.01.2010
Parameters
Response
+CSIM: < length >,< response >
OK
+CME ERROR: <err>
Write Command
AT+CSIM=<leng
th>,<Command>
Parameters
<length> integer type: length of characters sent to the TE in
<Command> or <response> (i.e. twice the number of
octets in the raw data)
<Command> string type(string should be included in quotation marks):
hex format: GSM 11.11 SIM Command sent from
the ME to the SIM
<response> string type(string should be included in quotation marks):
hex format: GSM 11.11 response from SIM to
<Command>
Reference
GSM 07.07 [13]
Note
3.2.50 AT+CALM Alert Sound Mode
AT+CALM Alert Sound Mode
Response
+CALM: (list of supported <mode>s)
OK
+CME ERROR: <err>
Test Command
AT+CALM=?
Parameter
See Write Command
Response
+CALM: <mode>
OK
+CME ERROR: <err>
Read Command
AT+CALM?
Parameter
See Write Command
Write Command
AT+CALM=<mo
de>
Response
OK
+CME ERROR: <err>
![](asset-5c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 92 15.01.2010
Parameter
<mode> 0 normal mode
1 silent mode (all sounds from ME are prevented)
Reference
GSM 07.07 [13]
Note
3.2.51 AT+CRSL Ringer Sound Level
AT+CRSL Ringer Sound Level
Response
+CRSL: (list of supported <level>s)
OK
+CME ERROR: <err>
Test Command
AT+CRSL=?
Parameter
See Write Command
Response
+CRSL: <level>
OK
+CME ERROR: <err>
Read Command
AT+CRSL?
Parameter
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CRSL=<leve
l>
Parameter
<level> integer type value (1-100) with manufacturer specific range
(smallest value represents the lowest sound level)
Reference
GSM 07.07 [13]
Note
3.2.52 AT+CLVL Loud Speaker Volume Level
AT+CLVL Loud Speaker Volume Level
Response
+CLVL: (list of supported <level>s)
OK
+CME ERROR: <err>
Test Command
AT+CLVL=?
Parameter
see Write Command
![](asset-5d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 93 15.01.2010
Response
+CLVL: <level>
OK
+CME ERROR: <err>
Read Command
AT+CLVL?
Parameter
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CLVL=<leve
l>
Parameter
<level> 1-100 integer type value with manufacturer specific range
(smallest value represents the lowest sound level)
Reference
GSM 07.07 [13]
Note
3.2.53 AT+CMUT Mute Control
AT+CMUT Mute Control
Response
+CMUT: (list of supported <n>s)
OK
Test Command
AT+CMUT=?
Parameter
see Write Command
Response
+CMUT: <n>
OK
+CME ERROR: <err>
Read Command
AT+CMUT?
Parameter
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CMUT=<n>
Parameter
<n> 0 mute off
1 mute on
Reference
GSM 07.07 [13]
Note
Only during a call this command can be set successfully.
![](asset-5e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 94 15.01.2010
3.2.54 AT+CPUC Price Per Unit And Currency Table
AT+CPUC Price Per Unit And Currency Table
Response
OK
Test Command
AT+CPUC=?
Parameters
see Write Command
Response
+CPUC: <currency>,<ppu>
OK
+CME ERROR: <err>
Read Command
AT+CPUC?
Parameters
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CPUC=<cur
rency>,<ppu>[,<
passwd>] Parameters
<currency> string type(string should be included in quotation marks);
three-character currency code (e.g. "GBP",
"DEM");
character set as specified by Command Select TE
Character
Set +CSCS
<ppu> string type(string should be included in quotation
marks); price per unit; dot is used as a decimal separator(e.g.
"2.66")
<passwd> string type(string should be included in quotation marks);
SIM PIN2
Reference
GSM 07.07 [13]
Note
3.2.55 AT+CCWE Call Meter Maximum Event
AT+CCWE Call Meter Maximum Event
Test Command
AT+CCWE=?
Response
+CCWE: (list of supported <mode>s)
OK
+CME ERROR: <err>
![](asset-5f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 95 15.01.2010
Parameter
see Write Command
Response
+CCWE: <mode>
OK
+CME ERROR: <err>
Read Command
AT+CCWE?
Parameter
See Write Command
Response
OK
+CME ERROR: <err>
Write Command
AT+CCWE=[<m
ode>]
Parameter
<mode> 0 Disable call meter warning event
1 Enable call meter warning event
Unsolicited result codes supported:
+CCWV Shortly before the ACM (Accumulated Call Meter)
maximum
value is reached, an unsolicited result code +CCWV will
be
Approximately when 5 seconds call time remains. It is
also issued when starting a call if less than 5 s call time
remains.
Parameters
Reference
GSM 07.07 [13]
Note
z GSM 07.07 specifies 30 seconds, so SIMCOM deviates from the
specification.
3.2.56 AT+CBC Battery Charge
AT+CBC Battery Charge
Response
+CBC: (list of supported < bcs >s),(list of supported < bcl >s),(voltage)
OK
Test Command
AT+CBC=?
Parameters
see Execution Command
![](asset-60.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 96 15.01.2010
Response
+CBC: < bcs >, < bcl >,<voltage>
OK
+CME ERROR: <err>
Execution
Command
AT+CBC
Parameters
<bcs> charge status
0 ME is not charging
1 ME is charging
2 Charging has finished
<bcl> battery connection level
1...100 battery has 1-100 percent of capacity remaining
vent
<voltage> battery voltage(mV)
Reference
GSM 07.07 [13]
Note
z Support for this Command will be hardware dependant and only be
used when battery is set to vibrator
3.2.57 AT+CUSD Unstructured Supplementary Service Data
AT+ CUSD Unstructured Supplementary Service Data
Response
+CUSD: (<n>s)
OK
Test Command
AT+CUSD=?
Parameter
see Write Command
Response
+CUSD: <n>
OK
Read Command
AT+CUSD?
Parameter
see Write Command
Write Command
AT+CUSD=[<n>
[,<str>[,<dcs>]]
Response
OK
+CME ERROR: <err>
![](asset-61.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 97 15.01.2010
Parameters
<n> a numeric parameter which indicates control of the unstructured
supplementary service data
0 disable the result code presentation in the TE
1 enable the result code presentation in the TE
2 cancel session (not applicable to read Command response)
<str> string type(string should be included in quotation marks)
USSD-string
<dcs> Cell Broadcast Data Coding Scheme in integer format (default 0)
Reference
GSM 03.38 [25]
Note
3.2.58 AT+CSSN Supplementary Services Notification
AT+CSSN Supplementary Services Notification
Response
+CSSN: (list of supported <n>s), (list of supported <m>s)
OK
Test Command
AT+CSSN=?
Parameters
see Write Command
Response
+CSSN: <n>,<m>
OK
Read Command
AT+CSSN?
Parameters
see Write Command
Write Command
AT+CSSN=[<n>[
,<m>]]
Response
OK
+CME ERROR: <err>
![](asset-62.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 98 15.01.2010
Parameters
<n> a numeric parameter which indicates whether to show the
+CSSI:<code1>[,<index>] result code presentation status after a
mobile originated call setup
0 disable
1 enable
<m> a numeric parameter which indicates whether to show the
+CSSU:<code2> result code presentation status during a mobile
terminated call setup or during a call, or when a forward check
supplementary service notification is received.
0 disable
1 enable
<code1> 0 unconditional call forwarding is active
1 some of the conditional call forwarding are active
2 call has been forwarded
3 call is waiting
4 this is a CUG call (also <index> present)
5 outgoing calls are barred
6 incoming calls are barred
7 CLIR suppression rejected
<index> closed user group index
<code2> 0 this is a forwarded call
Reference
Note
![](asset-63.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 99 15.01.2010
4 AT Commands According to GSM07.05
The GSM 07.05 commands are for performing SMS and CBS related operations. SIM900 supports
both Text and PDU modes.
4.1 Overview of AT Commands According to GSM07.05
Command Description
AT+CMGD DELETE SMS MESSAGE
AT+ CM GF SELECT SMS MESSAGE FORMAT
AT+ CM GL LIST SMS MESSAGES FROM PREFERRED STORE
AT+ CM GR READ SMS MESSAGE
AT+ CM GS SEND SMS MESSAGE
AT+ CM GW WRITE SMS MESSAGE TO MEMORY
AT+CMSS SEND SMS MESSAGE FROM STORAGE
AT+ CN MI NEW SMS MESSAGE INDICATIONS
AT+CPMS PREFERRED SMS MESSAGE STORAGE
AT+CRES RESTORE SMS SETTINGS
AT+CSAS SAVE SMS SETTINGS
AT+ CS CA SMS SERVICE CENTER ADDRESS
AT+CSCB SELECT CELL BROADCAST SMS MESSAGES
AT+CSDH SHOW SMS TEXT MODE PARAMETERS
AT+CSMP SET SMS TEXT MODE PARAMETERS
AT+CSMS SELECT MESSAGE SERVICE
4.2 Detailed Descriptions of AT Commands According to GSM07.05
4.2.1 AT+CMGD Delete SMS Message
AT+CMGD Delete SMS Message
Test Command
AT+CMGD=?
Response
+CMGD:(List of supported <index>s),(list of supported <delflag>s)
OK
Write Command
AT+CMGD=<in
dex>[,<delflag>]
Response
TA deletes message from preferred message storage <mem1> location
<index>.
OK
ERROR
If error is related to ME functionality:
+CMS ERROR:<err>
![](asset-64.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 100 15.01.2010
Parameter
<index> integer type; value in the range of location numbers supported by
the associated memory
<delflag> 0 Delete the message specified in <index>
1 Delete all read messages from preferred message storage,
leaving unread messages and stored mobile originated
messages (whether sent or not) untouched
2 Delete all read messages from preferred message storage
and sent mobile originated messages, leaving unread
messages and unsent mobile originated messages
untouched
3 Delete all read messages from preferred message storage,
sent and unsent mobile originated messages leaving unread
messages untouched
4 Delete all messages from preferred message storage
including unread messages
Reference
GSM 07.05
Note
4.2.2 AT+CMGF Select SMS Message Format
AT+CMGF Select SMS Message Format
Response
+CMGF: <mode>
OK
Read Command
AT+CMGF?
Parameter
see Write Command
Test Command
AT+CMGF=?
Response
+CMGF: (list of supported <mode>s)
OK
Response
TA sets parameter to deNote which input and output format of messages to
use.
OK
Write Command
AT+CMGF=[<m
ode>]
Parameter
<mode> 0 PDU mode
1 text mode
Reference
GSM 07.05
Note
![](asset-65.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 101 15.01.2010
4.2.3 AT+CMGL List SMS Messages From Preferred Store
AT+CMGL List SMS Messages From Preferred Store
Response
+CMGL: (list of supported <stat>s)
OK
Test Command
AT+CMGL=?
Parameters
see Write Command
Parameters
1) If text mode:
<stat> "REC UNREAD" Received unread messages (default)
"REC READ" Received read messages
"STO UNSENT" Stored unsent messages
"STO SENT" Stored sent messages
"ALL" All messages
<mode> 0 normal
1 not change status of the specified SMS record
2) If PDU mode:
<stat> 0 Received unread messages (default)
1 Received read messages
2 Stored unsent messages
3 Stored sent messages
4 All messages
<mode> 0 normal
1 not change status of the specified SMS record
Write Command
AT+CMGL=<sta
t>[,<mode>]
Response
TA returns messages with status value <stat> from message storage
<mem1> to the TE. . If status of the message is 'received unread', status in
the storage changes to 'received read'.
1) If text mode (+CMGF=1) and Command successful:
for SMS-SUBMITs and/or SMS-DELIVERs:
+CMGL:
<index>,<stat>,<oa/da>,[<alpha>],[<scts>][,<tooa/toda>,<length>]<CR
><LF><data>[<CR><LF>
+CMGL:
<index>,<stat>,<da/oa>,[<alpha>],[<scts>][,<tooa/toda>,<length>]<CR
><LF><data>[...]]
for SMS-STATUS-REPORTs:
+CMGL:
<index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>[<CR><LF
>
+CMGL:
![](asset-66.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 102 15.01.2010
<index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>[...]]
for SMS-COMMANDs:
+CMGL: <index>,<stat>,<fo>,<ct>[<CR><LF>
+CMGL: <index>,<stat>,<fo>,<ct>[...]]
for CBM storage:
+CMGL:<index>,<stat>,<sn>,<mid>,<page>,<pages><CR><LF><data
>[<CR><LF>
+CMGL:
<index>,<stat>,<sn>,<mid>,<page>,<pages><CR><LF><data>[...]]
OK
2) If PDU mode (+CMGF=0) and Command successful:
+CMGL:<index>,<stat>,[<alpha>],<length><CR><LF><pdu><CR><L
F>
+CMGL: <index>,<stat>,[alpha],<length><CR><LF><pdu>[...]]
OK
3)If error is related to ME functionality:
+CMS ERROR: <err>
Parameters
<alpha> string type(string should be included in quotation marks)
alphanumeric representation of <da> or <oa>
corresponding to the entry found in MT phonebook;
implementation of this feature is manufacturer
specific; used character set should be the one selected
with Command Select TE Character Set +CSCS (see
definition of this Command in TS 07.07)
<da> GSM 03.40 TP-Destination-Address Address-Value field in
string format; BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (refer Command+CSCS in
TS 07.07); type of address given by <toda>
<data> In the case of SMS: GSM 03.40 TP-User-Data in text mode
responses; format:
- if <dcs> indicates that GSM 03.38 default alphabet is used and
<fo> indicates that GSM 03.40
TPUser-Data-Header-Indication is not set:
- if TE character set other than "HEX" (refer Command Select
TE Character Set +CSCS in TS 07.07):ME/TA
converts GSM alphabet into current TE character set
according to rules of Annex A
- if TE character set is "HEX": ME/TA converts each 7-bit
character of GSM alphabet into two IRA character
long hexadecimal number (e.g. character P (GSM 23)
![](asset-67.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 103 15.01.2010
is presented as 17 (IRA 49 and 55))
- if <dcs> indicates that 8-bit or UCS2 data coding scheme is
used, or <fo> indicates that GSM 03.40
TP-User-Data-Header-Indication is set: ME/TA
converts each 8-bit octet into two IRA character long
hexadecimal number (e.g. octet with integer value 42
is presented to TE as two characters 2A (IRA 50 and
65)) In the case of CBS: GSM 03.41 CBM Content of
Message in text mode responses; format:
- if <dcs> indicates that GSM 03.38 default alphabet is used:
- if TE character set other than "HEX" (refer Command +CSCS
in GSM 07.07): ME/TA converts GSM alphabet into
current TE character set according to rules of Annex A
- if TE character set is "HEX": ME/TA converts each 7-bit
character of GSM alphabet into two IRA character
long hexadecimal number
- if <dcs> indicates that 8-bit or UCS2 data coding scheme is
used: ME/TA converts each 8-bit octet into two IRA
character long hexadecimal number
<length> integer type value indicating in the text mode (+CMGF=1)
the length of the message body <data> (or <cdata>)
in characters; or in PDU mode (+CMGF=0), the length
of the actual TP data unit in octets (i.e. the RP layer
SMSC address octets are not counted in the length)
<index> integer type; value in the range of location numbers supported
by the associated memory
<oa> GSM 03.40 TP-Originating-Address Address-Value field in
string format; BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (refer Command +CSCS in
TS 07.07); type of address given by <tooa>
<pdu> In the case of SMS: GSM 04.11 SC address followed by
GSM 03.40 TPDU in hexadecimal format: ME/TA
converts each octet of TP data unit into two IRA
character long hexadecimal number (e.g. octet with
integer value 42 is presented to TE as two characters
2A (IRA 50 and 65)). In the case of CBS: GSM
03.41 TPDU in hexadecimal format.
<scts> GSM 03.40 TP-Service-Center-Time-Stamp in time-string
format (refer <dt>)
<toda> GSM 04.11 TP-Destination-Address Type-of-Address octet
in integer format (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129)
<tooa> GSM 04.11 TP-Originating-Address Type-of-Address octet
![](asset-68.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 104 15.01.2010
in integer format (default refer<toda>)
Reference
GSM 07.05
Note
4.2.4 AT+CMGR Read SMS Message
AT+CMGR Read SMS Message
Test Command
AT+CMGR=?
Response
OK
Parameters
<index> integer type; value in the range of location numbers supported by
the associated memory
<mode> 0 normal
1 not change status of the specified SMS record
Write Command
AT+CMGR=<in
dex>[,<mode>]
Response
TA returns SMS message with location value <index> from message storage
<mem1> to the TE. If status of the message is 'received unread', status in the
storage changes to 'received read'.
1) If text mode (+CMGF=1) and Command successful:
for SMS-DELIVER:
+CMGR:
<stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<
length>]<CR><LF><data>
for SMS-SUBMIT:
+CMGR:
<stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp>],<sca>,<tosca>,
<length>]<CR><LF><data>
for SMS-STATUS-REPORTs:
+CMGR: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
for SMS-COMMANDs:
+CMGR:
<stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<length><CR><LF><c
data>]
for CBM storage:
+CMGR: <stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data>
2) If PDU mode (+CMGF=0) and Command successful:
+CMGR: <stat>,[<alpha>],<length><CR><LF><pdu>
OK
3) If error is related to ME functionality:
+CMS ERROR: <err>
Parameters
<alpha> string type(string should be included in quotation marks)
alphanumeric representation of <da> or <oa>
![](asset-69.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 105 15.01.2010
corresponding to the entry found in MT phonebook;
implementation of this feature is manufacturer specific
<da> GSM 03.40 TP-Destination-Address Address-Value field in
string format; BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (specified by +CSCS in TS
07.07); type of address given by <toda>
<data> In the case of SMS: GSM 03.40 TP-User-Data in text mode
responses; format:
- if <dcs> indicates that GSM 03.38 default alphabet is used and
<fo> indicates that GSM 03.40
TPUser-Data-Header-Indication is not set:
- if TE character set other than "HEX" (refer Command Select
TE Character Set +CSCS in TS 07.07):ME/TA
converts GSM alphabet into current TE character set
according to rules of Annex A
- if TE character set is "HEX": ME/TA converts each 7-bit
character of GSM alphabet into two IRA character
long hexadecimal number (e.g. character P (GSM 23)
is presented as 17 (IRA 49 and 55))
- if <dcs> indicates that 8-bit or UCS2 data coding scheme is
used, or <fo> indicates that GSM 03.40
TP-User-Data-Header-Indication is set: ME/TA
converts each 8-bit octet into two IRA character long
hexadecimal number (e.g. octet with integer value 42
is presented to TE as two characters 2A (IRA 50 and
65)) In the case of CBS: GSM 03.41 CBM Content of
Message in text mode responses; format:
- if <dcs> indicates that GSM 03.38 default alphabet is used:
- if TE character set other than "HEX" (refer Command +CSCS
in GSM 07.07): ME/TA converts GSM alphabet into
current TE character set according to rules of Annex A
- if TE character set is "HEX": ME/TA converts each 7-bit
character of GSM alphabet into two IRA character
long hexadecimal number
- if <dcs> indicates that 8-bit or UCS2 data coding scheme is
used: ME/TA converts each 8-bit octet into two IRA
character long hexadecimal number
<dcs> depending on the Command or result code: GSM 03.38 SMS
Data Coding Scheme (default 0), or Cell Broadcast
Data Coding Scheme in integer format
<fo> depending on the Command or result code: first octet of GSM
03.40 SMS-DELIVER, SMS-SUBMIT (default 17),
SMS-STATUS-REPORT, or SMS-COMMAND
![](asset-6a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 106 15.01.2010
(default 2) in integer format
<length> integer type value indicating in the text mode (+CMGF=1)
the length of the message body <data> (or <cdata>)
in characters; or in PDU mode (+CMGF=0), the length
of the actual TP data unit in octets (i.e. the RP layer
SMSC address octets are not counted in the length)
<mid> GSM 03.41 CBM Message Identifier in integer format
<oa> GSM 03.40 TP-Originating-Address Address-Value field in
string format; BCD numbers (or GSM default alphabet
characters) are converted characters of the currently
selected TE character set (specified by +CSCS in TS
07.07); type of address given by <tooa>
<pdu> In the case of SMS: GSM 04.11 SC address followed by
GSM 03.40 TPDU in hexadecimal format: ME/TA
converts each octet of TP data unit into two IRA
character long hexadecimal number (e.g. octet with
integer value 42 is presented to TE as two characters
2A (IRA 50 and 65)). In the case of CBS: GSM
03.41 TPDU in hexadecimal format.
<pid> GSM 03.40 TP-Protocol-Identifier in integer format (default
0)
<sca> GSM 04.11 RP SC address Address-Value field in string
format; BCD numbers (or GSM default alphabet
characters) are are converted to characters of the
currently selected TE character set (specified by
+CSCS in TS 07.07);; type of address given by
<tosca>
<scts> GSM 03.40 TP-Service-Centre-Time-Stamp in time-string
format (refer <dt>)
<stat> 0 "REC UNREAD" Received unread messages
1 "REC READ" Received read messages
2 "STO UNSENT" Stored unsent messages
3 "STO SENT" Stored sent messages
<toda> GSM 04.11 TP-Destination-Address Type-of-Address octet
in integer format (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129)
<tooa> GSM 04.11 TP-Originating-Address Type-of-Address octet
in integer format (default refer<toda>)
<tosca> GSM 04.11 RP SC address Type-of-Address octet in integer
format (default refer <toda>)
<vp> depending on SMS-SUBMIT <fo> setting: GSM 03.40
TP-Validity-Period either in integer format (default 167) or in
time-string format (refer <dt>)
![](asset-6b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 107 15.01.2010
Reference
GSM 07.05
Note
4.2.5 AT+CMGS Send SMS Message
AT+CMGS Send SMS Message
Test Command
AT+CMGS=?
Response
OK
Parameters
<da> GSM 03.40 TP-Destination-Address Address-Value field in
string format(string should be included in quotation
marks):; BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (specified by +CSCS in TS
07.07); type of address given by <toda>
<toda> GSM 04.11 TP-Destination-Address Type-of-Address octet
in integer format (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129)
<length> integer type value (not exceed 160 bytes) indicating in the text
mode (+CMGF=1) the length of the message body
<data> (or <cdata>) in characters; or in PDU mode
(+CMGF=0), the length of the actual TP data unit in
octets (i.e. the RP layer SMSC address octets are not
counted in the length)
Write Command
1) If text mode
(+CMGF=1):
+CMGS=<da>[,<
toda>]<CR>
text is entered
<ctrl-Z/ESC>
ESC quits without
sending
2) If PDU mode
(+CMGF=0):
+CMGS=<length
><CR>
PDU is given
<ctrl-Z/ESC>
Response
TA sends message from a TE to the network (SMS-SUBMIT). Message
reference value <mr> is returned to the TE on successful message delivery.
Optionally (when +CSMS <service> value is 1 and network supports)
<scts> is returned. Values can be used to identify message upon unsolicited
delivery status report result code.
1) If text mode(+CMGF=1) and sending successful:
+CMGS: <mr>
OK
2) If PDU mode(+CMGF=0) and sending successful:
+CMGS: <mr>
OK
3)If error is related to ME functionality:
+CMS ERROR: <err>
Parameter
<mr> GSM 03.40 TP-Message-Reference in integer format
![](asset-6c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 108 15.01.2010
Reference
GSM 07.05
Note
If TE Character Set is GSM, it supports 160-byte maximum; If TE
Character Set is UCS2, it supports 70-word maximum.
4.2.6 AT+CMGW Write SMS Message To Memory
AT+CMGW Write SMS Message To Memory
Test Command
AT+CMGW=?
Response
OK
Response
TA transmits SMS message (either SMS-DELIVER or SMS-SUBMIT)
from TE to memory storage <mem2>. Memory location <index> of the
stored message is returned. By default message status will be set to 'stored
unsent', but parameter <stat> allows also other status values to be given.
If writing is successful:
+CMGW: <index>
OK
If error is related to ME functionality:
+CMS ERROR: <err>
Write Command
1) If text mode
(+CMGF=1):
AT+CMGW=[<o
a/da>[,<tooa/toda
>]]
<CR> text is
entered
<ctrl-Z/ESC>
<ESC> quits
without sending
2) If PDU mode
(+CMGF=0):
AT+CMGW=<le
ngth><CR>
PDU is given
<ctrl-Z/ESC>
Parameters
<oa> GSM 03.40 TP-Originating-Address Address-Value field in
string format(string should be included in quotation
marks); BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (specified by +CSCS in TS
07.07);type of address given by <tooa>
<da> GSM 03.40 TP-Destination-Address Address-Value field in
string format(string should be included in quotation
marks); BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (specified by +CSCS in TS
07.07); type of address given by <toda>
<tooa> GSM 04.11 TP-Originating-Address Type-of-Address octet
in integer format (default refer <toda>)
<toda> GSM 04.11 TP-Destination-Address Type-of-Address octet
in integer format (when first character of <da> is + (IRA 43)
default is 145, otherwise default is 129)
129 Unknown type(IDSN format number)
161 National number type(IDSN format)
145 International number type(ISDN format )
177 Network specific number(ISDN format)
![](asset-6d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 109 15.01.2010
<length> integer type value (not exceed 160 bytes) indicating in the
text mode (+CMGF=1) the length of the message body
<data> (or <cdata>) in characters; or in PDU mode
(+CMGF=0), the length of the actual TP data unit in
octets (i.e. the RP layer SMSC address octets are not
counted in the length)
<pdu> In the case of SMS: GSM 04.11 SC address followed by
GSM 03.40 TPDU in hexadecimal format: ME/TA
converts each octet of TP data unit into two IRA
character long hexadecimal number (e.g. octet with
integer value 42 is presented to TE as two characters
2A (IRA 50 and 65)). In the case of CBS: GSM
03.41 TPDU in hexadecimal format.
<index> Index of message in selected storage <mem2>
Execution
Command
AT+ CMGW
Response
TA transmits SMS message (either SMS-DELIVER or SMS-SUBMIT)
from TE to memory storage <mem2>. Memory location <index> of the
stored message is returned. By default message status will be set to 'stored
unsent', but parameter <stat> allows also other status values to be given.
If writing is successful:
+CMGW: <index>
OK
If error is related to ME functionality:
+CMS ERROR: <err>
Reference
GSM 07.05
Note
4.2.7 AT+CMSS Send SMS Message From Storage
AT+CMSS Send SMS Message From Storage
Test Command
AT+CMSS=?
Response
OK
![](asset-6e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 110 15.01.2010
Response
TA sends message with location value <index> from message storage
<mem2> to the network (SMS-SUBMIT). If new recipient address <da> is
given, it shall be used instead of the one stored with the message. Reference
value <mr> is returned to the TE on successful message delivery. Values can
be used to identify message upon unsolicited delivery status report result
code.
1) If text mode(+CMGF=1) and sending successful:
+CMSS: <mr> [,<scts>]
OK
2) If PDU mode(+CMGF=0) and sending successful:
+CMSS: <mr> [,<ackpdu>]
OK
3)If error is related to ME functionality:
+CMS ERROR: <err>
Write Command
AT+CMSS=<ind
ex>,<da>[,<toda
>]
Parameters
<index> integer type; value in the range of location numbers supported
by the associated memory
<da> GSM 03.40 TP-Destination-Address Address-Value field in
string format(string should be included in quotation
marks); BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (specified by +CSCS in TS
07.07);; type of address given by <toda>
<toda> GSM 04.11 TP-Destination-Address
Type-of-Address octet in integer format (when first
character of <da> is + (IRA 43) default is 145,
otherwise
default is 129)
<mr> GSM 03.40 TP-Message-Reference in integer format
Reference
GSM 07.05
Note
4.2.8 AT+CNMI New SMS Message Indications
AT+CNMI New SMS Message Indications
![](asset-6f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 111 15.01.2010
Response
+CNMI: (list of supported <mode>s),(list of supported <mt>s),(list of
supported <bm>s),(list of supported <ds>s),(list of supported <bfr>s)
OK
Test Command
AT+CNMI=?
Parameters
see Write Command
Response
+CNMI: <mode>,<mt>,<bm>,<ds>,<bfr>
OK
Read Command
AT+CNMI?
Parameters
see Write Command
Write Command
AT+CNMI=[<m
ode>[,<mt>[,<b
m>
[,<ds>[,<bfr>]]]]]
Response
TA selects the procedure for how the receiving of new messages from the
network is indicated to the TE when TE is active, e.g. DTR signal is ON. If
TE is inactive (e.g. DTR signal is OFF), message receiving should be done
as specified in GSM 03.38.
OK
If error is related to ME functionality:
ERROR
![](asset-70.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 112 15.01.2010
Parameters
<mode> 0 Buffer unsolicited result codes in the TA. If TA result
code buffer is full, indications can be buffered in some
other place or the oldest indications may be discarded
and replaced with the new received indications.
1 Discard indication and reject new received message
unsolicited result codes when TA-TE link is reserved
(e.g. in on-line data mode). Otherwise forward them
directly to the TE.
2 Buffer unsolicited result codes in the TA when TA-TE
link is reserved (e.g. in on-line data mode) and flush
them to the TE after reservation. Otherwise forward
them directly to the TE.
3 Forward unsolicited result codes directly to the TE.
TA-TE link specific inband technique used to embed
result codes and data when TA is in on-line data mode.
<mt> (the rules for storing received SMs depend on its data coding
scheme (refer GSM 03.38 [2]), preferred memory
storage (+CPMS) setting and this value):
0 No SMS-DELIVER indications are routed to the TE.
1 If SMS-DELIVER is stored into ME/TA, indication of
the memory location is routed to the TE using
unsolicited result code: +CMTI: <mem>,<index>
2 SMS-DELIVERs (except class 2) are routed directly to
the TE using unsolicited result code: +CMT:
[<alpha>],<length><CR><LF><pdu> (PDU mode
enabled) or +CMT: <oa>, [<alpha>],<scts>
[,<tooa>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<length
>]<CR><LF><data> (text mode enabled; about
parameters in italics, refer Command Show Text Mode
Parameters +CSDH). Class 2 messages result in
indication as defined in <mt>=1.
3 Class 3 SMS-DELIVERs are routed directly to TE
using unsolicited result codes defined in <mt>=2.
Messages of other classes result in indication as
defined in <mt>=1.
<bm> (the rules for storing received CBMs depend on its data
coding scheme (refer GSM 03.38 [2]), the setting of
Select CBM Types (+CSCB) and this value):
0 No CBM indications are routed to the TE.
2 New CBMs are routed directly to the TE using
unsolicited result code: +CBM:
<length><CR><LF><pdu> (PDU mode enabled) or
![](asset-71.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 113 15.01.2010
+CBM:
<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data>
(text mode enabled).
<ds> 0 No SMS-STATUS-REPORTs are routed to the TE.
1 SMS-STATUS-REPORTs are routed to the TE using
unsolicited result code: +CDS:
<length><CR><LF><pdu> (PDU mode enabled) or
+CDS: <fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
(text mode enabled)
<bfr> 0 TA buffer of unsolicited result codes defined within
this Command is flushed to the TE when <mode> 1...3
is entered (OK response shall be given before flushing
the codes).
1 TA buffer of unsolicited result codes defined within
this command is cleared when <mode> 1…3 is entered
Unsolicited result code
+CMTI: <mem>,<index> Indication that new message has been
received
+CMT: [<alpha>],<length><CR><LF><pdu> Short message is output
directly
+CBM: <length><CR><LF><pdu> Cell broadcast message is output
directly
Reference
GSM 07.05
Note
4.2.9 AT+CPMS Preferred SMS Message Storage
AT+CPMS Preferred SMS Message Storage
Response
+CPMS:
<mem1>,<used1>,<total1>,<mem2>,<used2>,<total2>,<mem3>,<used3
>,<total3>
OK
If error is related to ME functionality:
ERROR
Read Command
AT+CPMS?
Parameters
see Write Command
Test Command
AT+CPMS=?
Response
+CPMS: (list of supported <mem1>s),(list of supported <mem2>s) ,(list of
supported <mem3>s)
OK
![](asset-72.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 114 15.01.2010
Parameters
see Write Command
Response
TA selects memory storages <mem1>, <mem2> and <mem3> to be used for
reading, writing, etc.
+CPMS: <used1>,<total1>,<used2>,<total2>,<used3>,<total3>
OK
If error is related to ME functionality:
ERROR
Write Command
AT+CPMS=
<mem1>
[,<mem2>
[,<mem3>]]
Parameters
<mem1> Messages to be read and deleted from this memory
storage
"SM" SIM message storage
<mem2> Messages will be written and sent to this memory
storage
"SM" SIM message storage
<mem3> Received messages will be placed in this memory
storage if routing to PC is not set ("+CNMI")
"SM" SIM message storage
<usedx> integer type;Number of messages currently in <memx>
<totalx> integer type;Number of messages storable in <memx>
Reference
GSM 07.05
Note
4.2.10 AT+CRES Restore SMS Settings
AT+CRES Restore SMS Settings
Test Command
AT+CRES=?
Response
+CRES: (list of supported <profile>s)
OK
Response
TA restores SMS settings for +CSCA, +CSMP from non-volatile memory
to active memory.
OK
If error is related to ME functionality:
ERROR
Write Command
AT+CRES=<pro
file>
Parameter
<profile> 0 Restore SM service settings from profile 0
1 Restore SM service settings from profile 1
![](asset-73.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 115 15.01.2010
Execution
Command
AT+CRES
Response
Same as AT+CRES=0.
OK
If error is related to ME functionality:
+CMS ERROR <err>
Reference
GSM 07.05
Note
4.2.11 AT+CSAS Save SMS Settings
AT+CSAS Save SMS Settings
Test Command
AT+CSAS=?
Response
+CSAS: (list of supported <profile>s)
OK
Response
TA saves SMS settings for +CSCA, +CSMP from non-volatile memory to
active memory.
OK
If error is related to ME functionality:
ERROR
Write Command
AT+CSAS=<prof
ile>
Parameter
<profile> 0 Save SM service setting in profile 0
1 Save SM service setting in profile 1
Execution
Command
AT+CSAS
Response
Same as AT+CSAS=0
OK
If error is related to ME functionality:
ERROR
Reference
GSM 07.05
Note
4.2.12 AT+CSCA SMS Service Center Address
AT+CSCA SMS Service Center Address
Response
+CSCA: <sca>,<tosca>[,<scaAlpha>]
OK
Read Command
AT+CSCA?
Parameters
see Write Command
![](asset-74.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 116 15.01.2010
Test Command
AT+CSCA=?
Response
OK
Response
TA updates the SMSC address, through which mobile originated SMS are
transmitted. In text mode, setting is used by send and writes commands. In
PDU mode, setting is used by the same commands, but only when the
length of the SMSC address coded into <pdu> parameter equals zero.
Note: The Command writes the parameters in NON-VOLATILE memory.
OK
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CSCA =
<sca>[,<tosca>]
Parameters
<sca> GSM 04.11 RP SC address Address-Value field in
string format(string should be included in quotation
marks); BCD numbers (or GSM default alphabet
characters) are converted to characters of the currently
selected TE character set (specified by +CSCS in TS
07.07); type of address given by <tosca>
<tosca> Service center address format GSM 04.11 RP SC
address Type-of-Address octet in integer format
(default refer <toda>)
<scaAlpha> string type(string should be included in quotation
marks)
Service center address alpha data
Reference
GSM 07.05
Note
4.2.13 AT+CSCB Select Cell Broadcast SMS Messages
AT+CSCB Select Cell Broadcast SMS Messages
Response
+CSCB: <mode>,<mids>,<dcss>
OK
Read Command
AT+CSCB?
Parameters
see Write Command
Response
+CSCB: (list of supported <mode>s)
OK
Test Command
AT+CSCB=?
Parameters
see Write Command
![](asset-75.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 117 15.01.2010
Response
TA selects which types of CBMs are to be received by the ME.
Note: The Command writes the parameters in NON-VOLATILE memory.
OK
If error is related to ME functionality:
+CMS ERROR: <err>
Write Command
AT+CSCB=
<mode>[,mids>[,
<dcss>]]
Parameters
<mode> 0 message types specified in <mids> and <dcss> are
accepted
1 message types specified in <mids> and <dcss> are not
accepted.
<mids> string type (string should be included in quotation marks); all
different possible combinations of CBM message
identifiers (refer <mid>) (default is empty string); e.g.
"0,1,5,320,922". Total 15 different <mids> values can
be supported. <mids> values cannot be written
consecutively, such as “100-200”
<dcss> string type(string should be included in quotation marks); all
different possible combinations of CBM data coding
schemes (refer <dcs>) (default is empty string); e.g.
"0,5". Total 5 different <dcss> values can be
supported. <dcss> values cannot be written
consecutively, such as “0-5”
Reference
GSM 07.05
Note
AT+CSCB=0 will reset <mids> and <dcss> and select no <mids> and no
<dcss>.
AT+CSCB=1 means all <dcss> are accepted but this command has no
effect on the list of the <mids> accepted. “0-255” means all <dcss> are
accepted.
AT+CSCB=0,<mids> will add the <mids> values in the <mids> current list
handled by module.
AT+CSCB=0,,<dcss> will add the <dcss> values in the <dcss> current list
handled by module.
If AT+CSCB=0,<mids> is received while the list of <mids> is full, OK is
returned and new value is not added.
4.2.14 AT+CSDH Show SMS Text Mode Parameters
AT+CSDH Show SMS Text Mode Parameters
![](asset-76.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 118 15.01.2010
Response
+CSDH: <show>
OK
Read Command
AT+CSDH?
Parameters
see Write Command
Response
+CSDH: (list of supported <show>s)
OK
Test Command
AT+CSDH=?
Parameter
see Write Command
Response
TA determines whether detailed header information is shown in text mode
result codes.
OK
Write Command
AT+CSDH=[<sh
ow>]
Parameter
<show> 0 do not show header values defined in commands
+CSCA and +CSMP (<sca>, <tosca>, <fo>, <vp>,
<pid> and <dcs>) nor <length>, <toda> or <tooa> in
+CMT, +CMGL, +CMGR result codes for
SMS-DELIVERs and SMS-SUBMITs in text mode
1 show the values in result codes
Reference
GSM 07.05
Note
4.2.15 AT+CSMP Set SMS Text Mode Parameters
AT+CSMP Set SMS Text Mode Parameters
Response
+CSMP: (list of supported <fo>s),(list of supported <vp>s), (list of
supported <pid>s), (list of supported <dcs>s)
OK
Test Command
AT+CSMP=?
Parameters
see Write Command
Read Command
AT+CSMP?
Response
+CSMP: <fo>,<vp>,<pid>,<dcs>
OK
![](asset-77.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 119 15.01.2010
Response
TA selects values for additional parameters needed when SM is sent to the
network or placed in a storage when text mode is selected (+CMGF=1). It is
possible to set the validity period starting from when the SM is received by
the SMSC (<vp> is in range 0... 255) or define the absolute time of the
validity period termination (<vp> is a string).
Note: The Command writes the parameters in NON-VOLATILE memory.
OK
Write Command
AT+CSMP=[<fo
>[,<vp>,<pid>,<
dcs>]]
Parameters
<fo> depending on the Command or result code: first octet
of GSM 03.40 SMS-DELIVER, SMS-SUBMIT
(default 17), SMS-STATUS-REPORT, or
SMS-COMMAND (default 2) in integer format. SMS
status report is supported under text mode if <fo> is set
to 49.
<vp> depending on SMS-SUBMIT <fo> setting: GSM 03.40
TP-Validity-Period either in integer format (default
167) or in time-string format (refer <dt>)
<pid> GSM 03.40 TP-Protocol-Identifier in integer format
(default 0).
<dcs> GSM 03.38 SMS Data Coding Scheme in Integer
format.
Reference
GSM 07.05
Note
4.2.16 AT+CSMS Select Message Service
AT+CSMS Select Message Service
Response
+CSMS: <service>,<mt>,<mo>,<bm>
OK
Read Command
AT+CSMS?
Parameters
see Write Command
Response
+CSMS: (list of supported <service>s)
OK
Test Command
AT+CSMS=?
Parameters
see Write Command
![](asset-78.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 120 15.01.2010
Response
+CSMS: <mt>,<mo>,<bm>
OK
If error is related to ME functionality:
+CMS ERROR: <err>
Write Command
AT+CSMS=
<service>
Parameters
<service> 0 GSM 03.40 and 03.41 (the syntax of SMS AT
commands is compatible with GSM 07.05 Phase 2
version 4.7.0; Phase 2+ features which do not require
new Command syntax may be supported (e.g. correct
routing of messages with new Phase 2+ data coding
schemes))
<mt> Mobile Terminated Messages:
0 Type not supported
1 Type supported
<mo> Mobile Originated Messages:
0 Type not supported
1 Type supported
<bm> Broadcast Type Messages:
0 Type not supported
1 Type supported
Reference
GSM 07.05
Note
![](asset-79.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 121 15.01.2010
5 AT Commands for SIM Application Toolkit
5.1 STK AT command
*PSSTK command is defined to support SIM toolkit by AT commands. Only part of SIM toolkit
commands that interact with user or MMI can be controlled. All other SIM toolkit mechanism
such as terminal profile, SMS or CBM data download, call control or MO SMS control by SIM,
event download and all command that does not require interaction with the user (or screen) are
internally managed by the ME.
AT*PSSTKI SIM Toolkit interface configuration
Test Command
AT*PSSTKI=?
Response
*PSSTKI: list of supported <mode >s
OK
Parameter
See Write Command.
Read Command
AT*PSSTKI?
Response
*PSSTKI: <mode>
OK
ERROR
Parameter
See Write Command.
Write Command
AT*PSSTKI
=<mode>
Response
OK
ERROR
Parameter
<mode > integer type
0 SIM toolkit notification is disabled
1 SIM toolkit notification is enabled
Reference Note
If AT*PSSTK=1 is set, *PSSTK: “SETUP MENU” string will be sent out
after power on.
![](asset-7a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 122 15.01.2010
AT*PSSTK SIM toolkit control
Test Command
AT*PSSTK=?
Response
*PSSTK: list of supported <response type>s
Parameter
See Write Command.
Read Command
AT*PSSTK?
Response
ERROR
Parameter
See Write Command.
Response
OK
ERROR
Write Command
AT*PSSTK
=<response
type>,[<parameter
1>,…,<parameter
n]
Parameter
<response type> string type that represents the type of response to be sent
to SIM
“COMMAND REJECTED”
“NOTIFICATION”
“SETUP CALL”
“DISPLAY TEXT”
“GET INKEY”
“GET INPUT”
“PLAY TONE”
“SELECT ITEM”
“SETUP MENU”
“REMOVE MENU”
“MENU SELECTION”
“ALL CALLS DISCONNECTED”
“USER ACTIVITY”
“IDLE SCREEN AVAILABLE”
“SETUP CALL TERMINATED”
“GET ITEM LIST”
“LANGUAGE NOTIFICATION”
“SETUP IDLE MODE TEXT”
<parameteri> integer or string type which number of parameters
depends of response type
Reference Note
![](asset-7b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 123 15.01.2010
6 AT Commands Special for SIMCOM
6.1 Overview
Command Description
AT+ SIDET CHANGE THE SIDE TONE GAIN LEVEL
AT+ CP OW D POWER OFF
AT+SPIC TIMES REMAIN TO INPUT SIM PIN/PUK
AT+ CM IC CHANGE THE MICROPHONE GAIN LEVEL
AT+CALA SET ALARM TIME
AT+CADC READ ADC
AT +CSNS SINGLE NUMBERING SCHEME
AT +CDSCB RESET CELL BROADCAST
AT +CMOD CONFIGRUE ALTERNATING MODE CALLS
AT +CFGRI INDICATE RI WHEN USING URC
AT+ CLT S GET LOCAL TIMESTAMP
AT+CEXTHS EXTERNAL HEADSET JACK CONTROL
AT+CEXTBUT HEADSET BUTTON STATUS REPORTING
AT+CSMINS SIM INSERTED STATUS REPORTING
AT+CLDTMF LOCAL DTMF TONE GENERATION
AT+CDRIND CS VOICE/DATA/FAX CALL TERMINATION INDICATION
AT+CSPN GET SERVICE PROVIDER NAME FROM SIM
AT+CCVM GET AND SET THE VOICE MAIL NUMBER ON THE SIM
AT+CBAND GET AND SET MOBILE OPERATION BAND
AT+ CH F CONFIGURE HANDS FREE OPERATION
AT+CHFA SWAP THE AUDIO CHANNELS
AT+ CS CLK CONFIGURE SLOW CLOCK
AT+CENG SWITCH ON OR OFF ENGINEERING MODE
AT+ SC LAS S0 STORE CLASS 0 SMS TO SIM WHEN RECEIVED CLASS 0 SMS
AT+CCID SHOW ICCID
AT+CMTE SET CRITICAL TEMPERATURE OPERATING MODE OR QUERY
TEMPERATURE
AT+ CS DT SWITCH ON OR OFF DETECTING SIM CARD
AT+CMGDA DELETE ALL SMS
AT+SIMTONE GENERATE SPECIFICALLY TONE
AT+CCPD CONNECTED LINE IDENTIFICATION PRESENTATION WITHOUT
ALPHA STRING
AT+CGID GET SIM CARD GROUP IDENTIFIER
AT+MORING SHOW STATE OF MOBILE ORIGINATED CALL
AT+CMGHEX ENABLE TO SEND NON-ASCII CHARACTER SMS
![](asset-7c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 124 15.01.2010
AT+AUTEST AUDIO CHANNEL LOOPBACK TEST
AT+CCODE CONFIGURE SMS CODE MODE
AT+CIURC ENABLE OR DISABLE INITIAL URC PRESENTATION
AT+CPSPWD CHANGE PS SUPER PASSWORD
AT+EXUNSOL ENABLE/DISABLE PROPRIETARY UNSOLICITED INDICATIONS
AT+CGMSCLASS CHANGE GPRS MULTISLOT CLASS
AT+CDEVICE VIEW CURRENT FLASH DEVICE TYPE
AT+CCALR CALL READY QUERY
AT+ GS V DISPLAY PRODUCT IDENTIFICATION INFORMATION
6.2 Detailed Descriptions of Commands
6.2.1 AT+SIDET Change The Side Tone Gain Level
AT+SIDET Change The Side Tone Gain Level
Response:
+SIDET: <gainlevel>,<gainlevel>
OK
Read Command
AT+SIDET?
Parameter
See Write Command
Response
+SIDET: (list of supported <channel>s),(list of supported < gainlevel>s)
OK
Test Command
AT+SIDET=?
Parameter
See Write Command
Response
OK
ERROR
Write Command
AT+SIDET=<
channel>,<
gainlevel > Parameter
< channel > 0 normal channel
1 aux channel
< gainlevel > int: 0 – 16
Reference Note
z <gainlevel> value is related to channel specific.
6.2.2 AT+CPOWD Power Off
AT+CPOWD Power Off
![](asset-7d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 125 15.01.2010
Response Write Command
AT+CPOWD =
<n>
Parameter
<n> 0 Power off urgently ( Will not send out NORMAL POWER
DOWN)
1 Normal power off (Will send out NORMAL POWER
DOWN)
Reference Note
6.2.3 AT+SPIC Times Remain To Input SIM PIN/PUK
AT+SPIC Times Remain To Input SIM PIN/PUK
Response
Times remain to input SIM PIN
+SPIC: <pin1>,<puk1>,<pin2>,<puk2>
OK
Execution
Command
AT+SPIC
Parameters
<pin1>Times remain to input chv1
<puk1>Times remain to input puk1
<pin2>Times remain to input chv2
<puk2>Times remain to input puk2
Reference Note
6.2.4 AT+CMIC Change The Microphone Gain Level
AT+CMIC Change The Microphone Gain Level
Response :
+ CMIC: < gainlevel(Main_Mic) >, <gainlevel(Aux_Mic)>
OK
Read Command
AT+CMIC?
Parameters
See Write Command
Response
+CMIC: (list of supported <channel >s), (list of supported < gainlevel
>s)
OK
Test Command
AT+CMIC=?
Parameters
See Write Command
![](asset-7e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 126 15.01.2010
Response :
OK
ERROR
Write Command
AT+CMIC=
<channel>,<
gainlevel>
Parameters
<channel> 0 – Main Microphone
1 – Aux Microphone
<gainlevel> int: 0 – 15
0 0dB
1 +1.5dB
2 +3.0 dB
3 +4.5 dB
4 +6.0 dB
5 +7.5 dB
6 +9.0 dB
7 +10.5 dB
8 +12.0 dB
9 +13.5 dB
10 +15.0 dB
11 +16.5 dB
12 +18.0 dB
13 +19.5 dB
14 +21.0 dB
15 +22.5 dB
Reference Note
Please refer to actual model for channel number.
6.2.5 AT+CALA Set Alarm Time
AT+CALA Set Alarm Time
Response :
+CALA: (<time>,<n1>,[<recurr>]
(<CR><LF>+CALA: <time>,<n2>,[<recurr>]
(…)))
OK
+CME ERROR: <err>
Read
Command
AT+CALA?
Parameters
See Write Command
![](asset-7f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 127 15.01.2010
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Write
Command
AT+CALA=
<time>,<n1>,[
<recurr>]
Parameters
< time > a string parameter(string should be included in quotation marks)
which indicates the time when alarm arrives. The format is
“yy/MM/dd,hh:mm:ss” where characters indicate the last two
digits of year, month, day, hour, minute, second a
<n> index of the alarm (range 1 to 5 for now).
<recurr> “0”, “1”---“7” string type value indicating day of week for the
alarm in one of the following formats:
"<1..7>[,<1..7>[…]]" – Sets a recurrent alarm for one or more days in the
week. The digits 1 to 7 corresponds to the days in the week, Monday (1), …,
Sunday (7).
Example: The string "1,2,3,4,5" may be used to set an alarm for all weekdays.
"0" – Sets a recurrent alarm for all days in the week
Reference Note
6.2.6 AT+CADC Read ADC
AT+CADC Read ADC
Response :
+CADC: <status>,<value>
OK
Read Command
AT+ CADC?
Parameters
See test Command
Response :
+CADC: (list of supported <status>s), (list of supported <value>s)
OK
Parameters
<status>
1 success
0 fail
<value> integer 0-2400
Test Command
AT+CADC=?
Note
It is not supported temporarily.
![](asset-80.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 128 15.01.2010
6.2.7 AT+CSNS Single Numbering Scheme
AT+CSNS Single Numbering Scheme
Response :
+CSNS: (list of supported <mode>s)
OK
Test Command
AT+CSNS =?
Parameter
Response :
+CSNS: <mode>
OK
Read Command
AT+CSNS?
Parameter:
Response :
OK
ERROR
Write Command
AT+CSNS=<mo
de>
Parameter
<mode>
0 voice
2 fax
4 data
Reference
Note
6.2.8 AT+CDSCB Reset Cell Broadcast
AT+CDSCB Reset Cell Broadcast
Response
OK
Execution
Command
AT+CDSCB
Parameter
Reference
Note
Please also refer to AT+CSCB.
6.2.9 AT+CMOD Configure Alternating Mode Calls
AT+CMOD Configure Alternating Mode Calls
Read Command
AT+CMOD?
Response
+CMOD: <mode>
OK
![](asset-81.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 129 15.01.2010
Parameter
Response
+CMOD: (0)
OK
Test Command
AT+CMOD =?
Parameter:
Response
OK
ERROR
Write Command
AT+CMOD=[<m
ode>]
Parameter
<mode> 0 Only single mode is supported
Reference
Note
6.2.10 AT+CFGRI Indicate RI When Using URC
AT+CFGRI Indicate RI When Using URC
Response
+CFGRI: <status>
OK
Read Command
AT+CFGRI?
Parameter
See Write Command
Response
OK
ERROR
Write Command
AT+CFGRI=[<st
atus>]
Parameter
<status>
1 on
0 off
Reference
Note
6.2.11 AT+CLTS Get Local Timestamp
AT+CLTS Get Local Timestamp
Test Command
AT+CLTS=?
Response
+CLTS: the format of <timestamp>
OK
![](asset-82.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 130 15.01.2010
Parameter
See Execution Command
Response
+CLTS: <timestamp>
OK
Execution
Command
AT+CLTS
Parameter
<timestamp> a string parameter(string should be included in quotation
marks) which indicates the local timestamp. The format of
timestamp is "yy/MM/dd,hh:mm:ss+/-zz"
yy: year
MM: month
dd: day
hh: hour
mm: minute
ss: second
zz: time zone
Reference
Note
z Support for this Command will be network dependant
6.2.12 AT+CEXTHS External Headset Jack Control
AT+ CEXTHS External Headset Jack Control
Response
+CEXTHS: (<mode>s)
OK
Test Command
AT+CEXTHS=?
Parameter
See Write Command
Response
+CEXTHS: <mode>,<headset attach>
OK
Read Command
AT+CEXTHS?
Parameters
See Write Command
Response
OK
ERROR
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CEXTHS=<
mode>
Unsolicited result code:
+CEXTHS: <mode>,<headset attach>
![](asset-83.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 131 15.01.2010
Parameters
<mode> a numeric parameter which indicates whether an
unsolicited event code (indicating whether the
headset has been attached/detached) should be sent
to the terminal.
0 not send unsolicited event code
1 send unsolicited event code
<headset attach> a numeric parameter which indicates whether a
headset has been attached or not
0 not attached
1 attached
Reference
Note
z For this command, please refer to actual model.
6.2.13 AT+CEXTBUT Headset Button Status Reporting
AT+ CEXTBUT Headset Button Status Reporting
Response
+CEXTBUT: (<mode>s)
OK
Test Command
AT+CEXTBUT=
?
Parameter
See Write Command
Response
+CEXTBUT: <mode>,<headset button press>
OK
Read Command
AT+CEXTBUT?
Parameters
See Write Command
Response
OK
ERROR
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CEXTBUT=
<mode>
Unsolicited result code
+CEXTBUT: <mode>,<headset button press>
![](asset-84.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 132 15.01.2010
Parameters
<mode> a numeric parameter which indicates whether an
unsolicited event code (indicating whether the
headset button has been pressed) should be sent to
the terminal.
0 not send unsolicited event code
1 send unsolicited event code
<headset attach> a numeric parameter which indicates whether a
headset button has been pressed or not
0 not pressed
1 pressed
Reference
Note
z For this command, please refer to actual model.
6.2.14 AT+CSMINS SIM Inserted Status Reporting
AT+ CSMINS SIM Inserted Status Reporting
Response
+CSMINS: (list of supported <n>s)
OK
Test Command
AT+CSMINS=?
Parameter
See Write Command
Response
+CSMINS: <n>,<SIM inserted>
OK
Read Command
AT+CSMINS?
Parameter
See Write Command
Write Command
AT+CSMINS=<
n>
Response
OK
ERROR
If error is related to ME functionality:
+CME ERROR: <err>
![](asset-85.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 133 15.01.2010
Parameters
<n> a numeric parameter which indicates whether to show an
unsolicited event code indicating whether the SIM has just been
inserted or removed.
0 disable
1 enable
< SIM inserted> a numeric parameter which indicates whether SIM
card has been inserted.
0 not inserted
1 inserted
Reference
Note
6.2.15 AT+CLDTMF Local DTMF Tone Generation
AT+ CLDTMF Local DTMF Tone Generation
Test Command
AT+CLDTMF=?
Response
+CLDTMF: (0-1000),(0-9,A,B,C,D,*,#)
OK
Response
OK
ERROR
Write Command
AT+CLDTMF=<
n>[,<DTMF
string>] Parameters
<n> a numeric parameter(1-1000) which indicates the
duration of all DTMF tones in < DTMF -string> in 1/10
secs
< DTMF -string> a string parameter(string should be included in
quotation marks) which has a max length of 20 chars of
form < DTMF >, separated by commas.
< DTMF > A single ASCII chars in the set 0-9,#,*,A-D.
Execution
Command
AT+CLDTMF
Response
OK
Aborts any DTMF tone currently being generated and any DTMF tone
sequence.
Reference
Note
6.2.16 AT+CDRIND CS Voice/Data/Fax Call Termination Indication
AT+ CDRIND CS Voice/Data/Fax Call Termination Indication
Test Command
AT+CDRIND=?
Response
+CDRIND: (list of supported <n>s)
OK
![](asset-86.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 134 15.01.2010
Parameter
See Write Command
Response
+CDRIND: <n>
OK
Read Command
AT+CDRIND?
Parameter
See Write Command
Response
OK
ERROR
Parameter
<n> a numeric parameter which indicates whether to enable an
unsolicited event code indicating whether a CS voice call, CS
data, fax call has been terminated.
0 disable
1 enable
Write Command
AT+CDRIND=<
n>
Unsolicited result code
When enabled, an unsolicited result code is returned after the connection
has been terminated
+CDRIND: < type >
Parameter
< type > connection type
0 CSV connection
1 CSD connection
2 PPP connection
Reference
Note
6.2.17 AT+CSPN Get Service Provider Name From SIM
AT+CSPN Get Service Provider Name From SIM
Read Command
AT+CSPN?
Response:
+CSPN: <spn>,<display mode>
OK
+CME ERROR: <err>
![](asset-87.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 135 15.01.2010
Parameters
<spn> string type(string should be included in quotation
marks); service provider name on SIM
<display mode> 0 – don’t display PLMN. Already registered on
PLMN
1 – display PLMN
Reference Note
z CME errors if SIM not inserted.
6.2.18 AT+CCVM Get And Set The Voice Mail Number On The SIM
AT+CCVM Get And Set The Voice Mail Number On The SIM
Response
If voice mail number is not set:
OK
If voice mail number is set:
+CCVM: <vm number>[,<alpha string>]
OK
Read Command
AT+CCVM?
Parameters
See Write Command
Response
+CCVM: <vm number>[,<alpha string>]
OK
Test Command
AT+CCVM=?
Parameters
See Write Command
Response
OK
ERROR
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CCVM=<vm
number>,<alpha
string>
Parameters
<vm number> String type(string should be included in quotation marks)
-The voice mail number to write to the SIM
<alpha-string> String type(string should be included in quotation marks)
-The alpha-string to write to the SIM
Reference Note
6.2.19 AT+CBAND Get And Set Mobile Operation Band
AT+CBAND Get And Set Mobile Operation Band
![](asset-88.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 136 15.01.2010
Response
+CBAND: <op_band>[,<ALL_BAND>]
OK
Read Command
AT+CBAND?
Parameter
See Write Command
Response
+CBAND: (list of supported <op_band>s)
OK
Test Command
AT+CBAND=?
Parameter
See Write Command
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Write Command
AT+CBAND=<o
p_band>
Parameter
<op_band> A string parameter which indicate the operation band.
And the following strings should be included in
quotation marks.
PGSM_MODE
DCS_MODE
PCS_MODE
EGSM_DCS_MODE
GSM850_PCS_MODE
ALL_BAND
Reference Note
z Radio settings following updates are stored in non-volatile memory.
6.2.20 AT+CHF Configure Hands Free Operation
AT+CHF Configure Hands Free Operation
Response
+CHF: <ind>,<state>
OK
Read Command
AT+CHF?
Parameters
See Write Command.
![](asset-89.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 137 15.01.2010
Test Command
AT+CHF=?
Response
+CHF: (0-1),(0-1)
OK
Response
OK
ERROR
If error is related to ME functionality:
CME ERROR: <err>
Write Command
AT+CHF=[<in
d>[,<state>]]
Parameters
<ind> 0 Unsolicited result code disabled
1 Unsolicited result code enabled
(non-volatile)
<state> 0 Hands free operation disabled
1 Hands free operation enabled
(volatile)
Reference Note
z For this command, please refer to actual model.
6.2.21 AT+CHFA Swap The Audio Channels
AT+ CHFA Swap The Audio Channels
Response
+CHFA: <n>
OK
Read Command
AT+CHFA?
Parameter
See Write Command.
Response
+CHFA: (0 = NORMAL_AUDIO, 1 = AUX_AUDIO)
OK
Test Command
AT+ CHFA=?
Parameter
See Write Command.
Response
OK
+CME ERROR: <err>
Write Command
AT+CHFA=[<n>
]
Parameter
<n> 0 – Normal audio channel(default)
1 – Aux audio channel
Reference Note
z This Command swaps the audio channels between the normal channel
![](asset-8a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 138 15.01.2010
and the aux channel.
z For this command, please refer to actual model.
6.2.22 AT+CSCLK Configure Slow Clock
AT+ CSCLK Configure Slow Clock
Response
+CSCLK: <n>
OK
Read Command
AT+CSCLK?
Parameter
See Write Command.
Response
+CSCLK: (0,1,2)
OK
Test Command
AT+CSCLK=?
Parameter
See Write Command.
Response
OK
ERROR
Write Command
AT+CSCLK
=[<n>]
Parameter
<n> 0 – disable slow clock, module will not enter sleep mode.
1– enable slow clock, it is controlled by DTR. When DTR is
high, module can enter sleep mode. When DTR changes to
low level, module can quit sleep mode.
2–The module decides by itself when it enters sleep mode.
When there is no data on serial port, module can enter
sleep mode. Otherwise, it will quit sleep mode.
Reference Note
6.2.23 AT+CENG Switch On Or Off Engineering Mode
AT+ CENG Switch On Or Off Engineering Mode
![](asset-8b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 139 15.01.2010
Response
Engineering Mode is designed to allow a field engineer to view and test the
network information received by a handset, when the handset is either in
idle mode or dedicated mode (that is: with a call active). In each mode, the
engineer is able to view network interaction for the “serving cell” (the cell
the handset is currently registered with) or for the neighbouring cells.
TA returns the current engineering mode. The network information
including serving cell and neighbouring cells are returned only when
<mode>=1 or <mode> = 2. <cell> carry with them corresponding network
interaction.
+CENG: <mode>,<Ncell>
[+CENG:
<cell>,”<arfcn>,<rxl>,<rxq>,<mcc>,<mnc>,<bsic>,<cellid>,< lac >,<
rla >,< txp >,< TA>”
<CR><LF>+CENG: <cell>,”<arfcn>,<rxl>,<bsic>,<Lac>”
…]
OK
Read Command
AT+CENG?
Parameters
See Write Command.
Response
TA returns the list of supported modes.
+CENG: (list of supported <mode>s),(list of supported <Ncell>)
OK
Test Command
AT+CENG=?
Parameters
See Write Command.
Response
TA attempt to switch on or off engineering mode.GSM network operator.
TA controls the presentation of an unsolicited result code +CENG: (network
information) when <mode>=2 and there is a change of network
information .
OK
ERROR
Write Command
AT+ CENG
=<mode>[,<Ncell
>]
Parameters
<mode> 0 switch off engineering mode
1 switch on engineering mode
2 switch on engineering mode, and activate the
unsolicited reporting of network information.
![](asset-8c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 140 15.01.2010
<Ncell> 0 un-display neighbor cell ID
1 display neighbor cell ID
<cell> 0 the serving cell
1-6 the index of the neighboring cell.
<arfcn> absolute radio frequency channel number.
<rxl> receive level.
<rxq> receive quality.
<mcc> mobile country code.
<mnc> mobile network code.
<bsic> . base station identity code
<cellid> cell id.
<lac> location area code
< rla > receive level access minimum.
<txp> transmit power maximum CCCH.
<TA> Timing Advance
Reference Note
6.2.24 AT+SCLASS0 Store Class 0 SMS To SIM When Received Class 0 SMS
AT+ SCLASS0 Store Class 0 SMS To SIM When Received Class 0 SMS
Response
+SCLASS0: <mode>
OK
Read Command
AT+SCLASS0?
Parameter
See Write Command.
Response
+SCLASS0: (0, 1)
OK
Test Command
AT+SCLASS0=?
Parameter
See Write Command.
Response
OK
ERROR
Write Command
AT+SCLASS0=[
<mode>]
Parameter
<mode>
0 – disable to store Class 0 SMS to SIM when received Class 0 SMS
1 – Enable to store Class 0 SMS to SIM when received Class 0 SMS
Reference Note
It is not supported temporarily.
![](asset-8d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 141 15.01.2010
6.2.25 AT+CCID Show ICCID
AT+CCID Show ICCID
Test Command
AT+CCID =?
Response:
OK
Response:
Ccid data [ex. 898600810906F8048812]
OK
Execution
Command
AT+ CCID
Parameter
Reference Note
6.2.26 AT+CMTE Set Critical Temperature Operating Mode Or Query Temperature
AT+CMTE Set Critical Temperature Operating Mode Or Query Temperature
Response
+CMTE: <mode><Temperature>
OK
Read Command
AT+ CMTE?
Parameters
See Write Command
Response
OK
ERROR
Write Command
AT+CMTE=
[<mode>]
Parameters
<mode>
0 disable temperature detection
1 enable temperature detection
< Temperature> range of -40 to 90
Reference Note
z When temperature is extreme high or low, product will power off.
z URCs indicating the alert level "1" or "-1" are intended to enable the
user to take appropriate precautions, such as protect the module from
exposure to extreme conditions, or save or back up data etc.
z Level "2" or "-2" URCs are followed by immediate shutdown.
6.2.27 AT+CSDT Switch On Or Off Detecting SIM Card
AT+ CSDT Switch On Or Off Detecting SIM Card
![](asset-8e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 142 15.01.2010
Response
+CSDT: <mode>
OK
Read Command
AT+ CSDT?
Parameter
Response
+CSDT: (0-1)
OK
Test Command
AT+ CSDT =?
Parameter
See Write Command.
Response
OK
ERROR
Write Command
AT+CSDT=[<mo
de>]
Parameter
<mode>
0 – switch off detecting SIM card (default)
1 – switch on detecting SIM card
Reference Note
It is not supported temporarily.
6.2.28 AT+CMGDA Delete All SMS
AT+ CMGDA Delete All SMS
Response:
+CMGDA: (listed of supported <type>s)
OK
+CMS ERROR: <err>
Test Command
AT+CMGDA=?
Parameter
see Write Command
Write Command
AT+CMGDA=<t
ype>
Response:
OK
ERROR
+CMS ERROR: <err>
![](asset-8f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 143 15.01.2010
Parameter
1) If text mode:
“DEL READ” delete all read messages
“DEL UNREAD” delete all unread messages
“DEL SENT” delete all sent SMS
“DEL UNSENT” delete all unsent SMS
“DEL INBOX” delete all received SMS
“DEL ALL” delete all SMS
2) If PDU mode :
1 delete all read messages
2 delete all unread messages
3 delete all sent SMS
4 delete all unsent SMS
5 delete all received SMS
6 delete all SMS
Reference Note
6.2.29 AT+SIMTONE Generate Specifically Tone
AT+SIMTONE Generate Specifically Tone
Response
+SIMTONE: (0,1), (20-20000), (0-5000), (0-5000), (0-500000)
OK
Test Command
AT+ SIMTONE
=?
Parameters
See Write Command.
Response
OK
ERROR
Write Command
AT+ SIMTONE
=<mode>,<
frequency >,<
periodOn >,<
periodOff >[,<
duration >]
Parameters
<mode> 0 – Stop playing tone
1 – Start playing tone
<frequency > the frequency of tone to be generated
<periodon> the period of generating tone
<periodoff> the period of stopping tone
<duration> duration of tones in milliseconds
Reference Note
6.2.30 AT+CCPD Connected Line Identification Presentation Without Alpha String
AT+CCPD Connected Line Identification Presentation Without Alpha String
![](asset-90.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 144 15.01.2010
Response
+CCPD: <mode>
OK
Read Command
AT+ CCPD?
Parameter
Response
OK
ERROR
Write Command
AT+CCPD=[<m
ode>]
Parameter
<mode>
0 – disable to present alpha string
1 – enable to present alpha string
Reference Note
6.2.31 AT+CGID Get SIM Card Group Identifier
AT+CGID Get SIM Card Group Identifier
Response
+GID: <gid1> <gid2>
OK
ERROR
Execution
Command
AT+ CGID
Parameters
<gid1> integer type of SIM card group identifier 1
<gid2> integer type of SIM card group identifier 2
Reference Note
z If the SIM supports GID files, the GID values were retuned. Otherwise
0xff is retuned.
6.2.32 AT+MORING Show State of Mobile Originated Call
AT+MORING Show State of Mobile Originated Call
Response
+MORING: (0,1)
OK
Test Command
AT+MORING=?
Parameters
See Write Command.
![](asset-91.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 145 15.01.2010
Read Command
AT+MORING?
Response
+MORING: <mode>
OK
Response
OK
ERROR
Write Command
AT+MORING
=[<mode>]
Parameters
<mode> 0 not show call state of mobile originated call
1 show call state of mobile originated call. After dialing
call numbers, the URC strings of MO RING will be sent if the other call
side is alerted and the URC strings of MO CONNECTED will be sent if the
call is established.
Reference Note
6.2.33 AT+CMGHEX Enable To Send Non-ASCII Character SMS
AT+CMGHEX Enable To Send Non-ASCII Character SMS
Response
+CMGHEX: <mode>
OK
Read Command
AT+CMGHEX?
Parameter
see Write Command
Test Command
AT+CMGHEX
=?
Response
+CMGHEX: (0,1)
OK
Response
OK
ERROR
Write Command
AT+CMGHEX
=<mode>
Parameter
<mode> 0 Send SMS in ordinary way
1 Enable to send SMS varying from 0x00 to 0x7f except
0x1a and 0x1b under text mode and GSM character set
Reference
Note
z Only be available in TEXT mode and +CSCS=”GSM”.
z It is not supported temporarily.
![](asset-92.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 146 15.01.2010
6.2.34 AT+AUTEST Audio Channel Loopback Test
AT+AUTEST Audio Channel Loopback Test
Test Command
AT+AUTEST=?
Response
+AUTEST: (0-1), (0-1)
OK
Response
OK
ERROR
Write Command
AT+AUTEST=
<state>[,<type>]
Parameters
<state> 0 test is off
1 test is on
<type> 0 Normal audio channel
1 AUX audio channel
Reference Note
6.2.35 AT+CCODE Configure SMS Code Mode
AT+CCODE Configure SMS Code Mode
Test Command
AT+CCODE=?
Response
+CCODE:(0,1)
OK
Response
+CCODE:<mode>
OK
Read Command
AT+CCODE?
Parameter
see Write Command
Response
OK
ERROR
Write Command
AT+CCODE=
<mode>
Parameter
<mode> 0 code mode according with NOKIA
1 code mode according with SIEMENS
Reference
Note
z Default value is 0
z It is not supported temporarily.
6.2.36 AT+CIURC Enable Or Disable Initial URC Presentation
AT+CIURC Enable Or Disable Initial URC Presentation
![](asset-93.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 147 15.01.2010
Test Command
AT+CIURC=?
Response
+CIURC: (0,1)
OK
Response
+CIURC:<mode>
OK
Read Command
AT+CIURC?
Parameter
see Write Command
Response
OK
ERROR
Write Command
AT+CIURC=
[<mode>]
Parameter
<mode> 0 disable URC presentation.
1 enable URC presentation
Reference Note
z When module power on and initialization procedure is over .
z URC “Call Ready” will be presented if <mode> is 1.
6.2.37 AT+CPSPWD Change PS Super Password
AT+CPSPWD Change PS Super Password
Response
OK
ERROR
Write Command
AT+CPSPWD=
<oldpwd>,<newp
wd> Parameters
<oldpwd> string type(string should be included in quotation marks).
Old password and length should be 8.
<newpwd> string type(string should be included in quotation marks).
New password and length should be 8.
Reference Note
z Default value of <oldpwd> is “12345678”.
z If module is locked to a specific SIM card through +CLCK and
password lost or SIM state is PH-SIM PUK, you can use the super
password to unlock it.
z It is not supported temporarily.
![](asset-94.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 148 15.01.2010
6.2.38 AT+EXUNSOL Enable /Disable Proprietary Unsolicited Indications
AT+EXUNSOL Enable /Disable Proprietary Unsolicited Indications
Response
+EXUNSOL:(list of supported < exunsol>s)
OK
Test Command
AT+EXUNSOL
=?
Parameters
see Write Command
Write Command
AT+EXUNSOL=
<exunsol>,<mo
Response
OK
ERROR
![](asset-95.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 149 15.01.2010
de> Parameters
<exunsol> string type(string should be included in quotation marks).
values currently reserved by the present document
“SQ” Signal Quality Report
Displays signal strength and channel bit error rate (similar
To AT+CSQ) in form +CSQN: <rssi>,<ber>when values change.
“FN” forbidden network available only
When returning to a non- registered state this indicates whether
All the available PLMNs are forbidden.
“MW” SMS Message waiting
On receiving an SMS (as indicated by the +CMTI indication) the
SMS is decoded and checked to see if it contains one or more of the
message waiting indications (i.e. voicemail, email, fax etc). If so, an
unsolicited indication is shown in the form for each message type:
+CMWT: <store>,<index>,<voice>,<fax>,<email>,<other>
Where <store> is the message store containing the SM, index is the
message index and <voice>,<email>,<fax>,<other> contain the
number of waiting messages (with ‘0’ defined as clear indication,
non-zero for one or more waiting messages) or blank for not
specified in this message.
“UR” Unsolicited result code
Produces an unsolicited indication following particular call state
Transitions. Multiple notifications may occur for the same transition
+CGURC: <event>
Where <event> describes the current call state:
<event>
0 Active call terminated, at least one held call remaining
1 Attempt to make an Mobile Originated call
2 Mobile Originated Call has failed for some reason
3 Mobile Originated call is ringing
4 Mobile Terminated call is queued (Call waiting)
5 Mobile Originated Call now connected
6 Mobile Originated or Mobile Terminated call has disconnected
7 Mobile Originated or Mobile Terminated call hung up
8 Mobile Originated call to non-emergency number in emergency
mode
9 Mobile Originated call no answer
10 Mobile Originated call remote number busy
“BC” Battery Charge
Displays battery connection status and battery charge level(similar
To AT+CBC) in form +CBCN:<bcs>,<bcl> when values change.
![](asset-96.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 150 15.01.2010
“BM” Band mode
Displays band mode (similar to AT+CBAND)in form +CBAND:
<band>when value changes.
“SM” Additional SMS Information
Displays additional information about SMS events in the form of
Unsolicited messages of the following format
+TSMSINFO: <CMS error info>
where <CMS error info> is a standard CMS error in the format
defined by the AT+CMEE command i.e. either a number or a
string.
“CC” Call information
Displays the disconnected call ID and the remain call numbers after
one of the call disconnected.
+CCINFO : <Call id Disconnected>,<Remain calls>
<mode>
0 disable
1 enable
Reference
Note
Only “SQ” is supported currently.
6.2.39 AT+CGMSCLASS Change GPRS Multislot Class
AT+CGMSCLASS Change GPRS Multislot Class
Response
MULTISLOT CLASS: <class>
OK
Read Command
AT+CGMSCLA
SS?
Parameters
see write command
Test Command
AT+CGMSCLA
SS=?
Response
MULTISLOT CLASS: <4,8,9,10>
OK
Response
OK
ERROR
Write Command
AT+CGMSCLA
SS=<class>
Parameters
<class> GPRS multislot class
Reference
Note
![](asset-97.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 151 15.01.2010
6.2.40 AT+CDEVICE View Current Flash Device Type
AT+CDEVICE View Current Flash Device Type
Response
Device Name: (Current flash device type)
OK
ReadCommand
AT+CDEVICE?
Parameter
Reference
V.25ter
Note
6.2.41 AT+CCALR Call Ready Query
AT+CCALR Call Ready Query
Response
+CCALR: (list of supported <mode>s)
OK
Test Command
AT+CCALR=?
Parameter
<mode> a numeric parameter which indicates whether the
module is ready for phone call.
0 module is not ready for phone call
1 module is ready for phone call
Response
ME returns the status of result code presentation and an integer <n>
which shows whether the module is currently ready for phone call.
+CCALR: <n>
OK
Read Command
AT+CCALR?
Parameter
<mode>
See Test Command
Reference
Note
z URC “Call Ready” will be presented after power on and initialize.
6.2.42 AT+GSV Display Product Identification Information
AT+GSV Display Product Identification Information
![](asset-98.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 152 15.01.2010
Response
TA issues product information text
Example:
SIMCOM_Ltd
SIMCOM_
Revision: 1137B01V01SIM900M32_ST
OK
Execution
Command
AT+GSV
Reference
Note
![](asset-99.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 153 15.01.2010
7 AT Commands for GPRS Support
7.1 Overview of AT Commands for GPRS Support
Command Description
AT+ CG ATT ATTACH/DETACH FROM GPRS SERVICE
AT+CGDCONT DEFINE PDP CONTEXT
AT+CGQMIN QUALITY OF SERVICE PROFILE (MINIMUM ACCEPTABLE)
AT+CGQREQ QUALITY OF SERVICE PROFILE (REQUESTED)
AT+CGACT PDP CONTEXT ACTIVATE OR DEACTIVATE
AT+CGDATA ENTER DATA STATE
AT+CGPADDR SHOW PDP ADDRESS
AT+CGCLASS GPRS MOBILE STATION CLASS
AT+ CG ERE P CONTROL UNSOLICITED GPRS EVENT REPORTING
AT+ CG REG NETWORK REGISTRATION STATUS
AT+ CG SM S SELECT SERVICE FOR MO SMS MESSAGES
7.2 Detailed Descriptions of AT Commands for GPRS Support
7.2.1 AT+CGATT Attach /Detach From GPRS Service
AT+CGATT Attach /Detach From GPRS Service
Test Command
AT+CGATT=?
Response
+CGATT: (list of supported <state>s)
OK
Parameter
See Write Command
Read Command
AT+CGATT?
Response
+CGATT: <state>
OK
Parameter
See Write Command
Write Command
AT+CGATT=<st
ate>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameter
<state> indicates the state of GPRS attachment
0 – detached
1 – attached
Other values are reserved and will result in an ERROR
response to the Write Command.
![](asset-9a.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 154 15.01.2010
Reference
Note
7.2.2 AT+CGDCONT Define PDP Context
AT+CGDCONT Define PDP Context
Test Command
AT+CGDCONT
=?
Response
+CGDCONT: (range of supported <cid>s),<PDP_type>,,,(list of
supported<d_comp>s),(list of supported<h_comp>s)
[<CR><LF>+CGDCONT:
(range of supported <cid>s), <PDP_type>,,,(list ofsupported
<d_comp>s),(list of supported <h_comp>s) [...]]
OK
Parameters
See Write Command
Read Command
AT+CGDCONT
?
Response
+CGDCONT:
<cid>,<PDP_type>,<APN>,<PDP_addr>,<data_comp>,<head_comp>
[<CR><LF>+CGDCONT:
<cid>,<PDP_type>,<APN>,<PDP_addr>,<data_comp>,<head_comp>
[…]]
OK
Parameters
See Write Command
Write Command
AT+CGDCONT
=<cid>[,<PDP_ty
pe>,[APN>[,<PD
P_addr>[,<d_co
mp>[,<h_comp>]
]]]]
Response
OK
ERROR
Parameters
<cid> (PDP Context Identifier)
1 PDP Context Identifier 1
Definition stored in non-volatile memory
2 PDP Context Identifier 2
Definition stored in non-volatile memory
3 PDP Context Identifier 3
Default <cid>
Locked in non-volatile memory and is always defined, it can
not be changed by user.
<PDP_type> (Packet Data Protocol type)
IP Internet Protocol (IETF STD 5)
<APN> (Access Point Name) a string parameter(string should be
included in quotation marks) which is a logical name that is
used to select the GGSN or the external packet data
![](asset-9b.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 155 15.01.2010
network. If the value is null or omitted, then the
subscription value will be requested.
<PDP_addr> a string parameter (IP address). Format:
"<n>.<n>.<n>.<n>" where <n>=0..255
If the value is null or equals 0.0.0.0 a dynamic address
will be requested. The allocated address may be read using
the +CGPADDR command
<d_comp> a numeric parameter that controls PDP data compression
0 –PDP data compression off (default if value is omitted)
<h_comp> a numeric parameter that controls PDP data compression
0 –PDP header compression off (default if value is omitted)
.
Reference
Note
7.2.2.1For <cid> 1,2 and 3 the following parameters are stored in non volatile memory:
Parameter name Default value
<cid> 1,2 or 3
Locked 0xFF..0Xff
Defined 0x00
<precedence> 0x00
<delay> 0x00
<reliability> 0x03
<peak> 0x00
<mean> 0x00
<pdp_type> 0x01 (IP)
<APN> 0xFF..0xFF
<PDP_address> 0x00..0x00
<Guaranteed bitrate DL> 0x00
<Guaranteed bitrate UL> 0x00
<Traffic handling priority> 0x00
<Transfer delay> 0x00
<SDU error ratio> 0x00
<Residual bit error ratio> 0x00
<Maximum bitrate DL> 0x00
<Maximum bitrate UL> 0x00
<Maximum SDUsize> 0x00
<Delivery of erroneous
SDUs>
0x00
<Delivery order> 0x00
![](asset-9c.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 156 15.01.2010
<Traffic class> 0x00
7.2.3 AT+CGQMIN Quality Of Service Profile (Minimum Acceptable)
AT+CGQMIN Quality Of Service Profile (Minimum Acceptable)
Test Command
AT+CGQMIN=?
Response
+CGQMIN: <PDP_type>,(list of supported <precedence>s),(list of
supported <delay>s),(list of supported <reliability>s),<list of supported
<peak>s),(list of supported <mean>s)
[<CR><LF>+CGQMIN: <PDP_type>,(list of supported <precedence>
s),(list of supported <delay>s),(list of supported <reliability>s),<list of
supported <peak>s),(list of supported <mean>s)
[…]]
OK
Parameters
See Write Command
Read Command
AT+CGQMIN?
Response
+CGQMIN: <cid>,<precedence>,<delay>,>reliability>,<peak>,<mean>
[<CR><LF>+CGQMIN:
<cid>,<precedence>,<delay>,<reliability>,<peak>,<mean>
[…]]
OK
Parameters
See Write Command
Write Command
AT+CGQMIN=<
cid>[,<precedenc
e>[,<delay>[,<rel
iability>[,<peak>
[,<mean>]]]]]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<cid>
1..3 PDP Context Identifier
Definition stored in non-volatile memory (refer to
+CGDCONT). cid 3 is reserved and is always defined, it
cannot be changed by user.
<precedence>
0 (default) QOS precedence class subscribed value
1..3 QOS precedence class
<delay>
0 (default) QOS delay class subscribed value
1..4 QOS delay class subscribed
<reliability>
0(default) QOS reliability class subscribed value
![](asset-9d.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 157 15.01.2010
1..5 QOS reliability class.
<peak>
0 (default) QOS peak throughput class subscribed value
1..9 QOS peak throughput class
<mean>
0 (default) QOS mean throughput class subscribed value
1..18 QOS mean throughput class
31 QOS mean throughput class best effort
Reference
Note
![](asset-9e.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 158 15.01.2010
7.2.4 AT+CGQREQ Quality Of Service Profile (Requested)
AT+CGQREQ Quality Of Service Profile (Requested)
Test Command
AT+CGQREQ=?
Response
+CGQREQ: <PDP_type>,(list of supported <precedence>s),(list of
supported <delay>s),(list of supported <reliability>s),<list of supported
<peak>s),(list of supported <mean>s)
[<CR><LF>+CGQREQ: <PDP_type>,(list of supported <precedence>
s),(list of supported <delay>s),(list of supported <reliability>s),<list of
supported <peak>s),(list of supported <mean>s)
[…]]
OK
Parameters
See Write Command
Read Command
AT+CGQREQ?
Response
+CGQREQ: <cid>,<precedence>,<delay>,>reliability>,<peak>,<mean>
[<CR><LF>+CGQREQ:
<cid>,<precedence>,<delay>,<reliability>,<peak >,<mean>
[…]]
OK
Parameters
See Write Command
Write Command
AT+CGQREQ=
<cid>[,<precede
nce>[,<delay>[,<
reliability>[,<pea
k>[,<mean>]]]]]
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<cid> a numeric parameter which specifies a particular PDP context
definition (see +CGDCONT Command)
1..3 Definition stored in non-volatile memory (refer to
+CGDCONT) cid 3 is reserved and is always defined, it
cannot be changed by user.
The following parameter are defined in GSM 03.60
<precedence> a numeric parameter which specifies the precedence class
0 (default) QOS precedence class subscribed value
1..3 QOS precedence class
<delay> a numeric parameter which specifies the delay class
0 (default) QOS delay class subscribed value
1..4 QOS delay class
<reliability> a numeric parameter which specifies the reliability class
0 QOS reliability class subscribed value
![](asset-9f.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 159 15.01.2010
1..5 QOS reliability class; default value: 3
<peak> a numeric parameter which specifies the peak throughput
class
0 (default) QOS peak throughput class subscribed value
1..9 QOS peak throughput class
<mean> a numeric parameter which specifies the mean throughput
class
0 (default) QOS mean throughput class subscribed value
1..18 QOS mean throughput class
31 QOS mean throughput class best effort
Reference
Note
7.2.5 AT+CGACT PDP Context Activate Or Deactivate
AT+CGACT PDP Context Activate Or Deactivate
Test Command
AT+CGACT=?
Response
+CGACT: (list of supported <state>s)
OK
Parameter
See Write Command
Read Command
AT+CGACT?
Response
+CGACT: <cid>,<state>[<CR><LF>+CGACT:<cid><state>…]
OK
Write Command
AT+CGACT=<st
ate>,<cid>
Response
OK
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<state> indicates the state of PDP context activation
0 – deactivated
1 – activated
Other values are reserved and will result in an ERROR
response to the Write Command.
<cid> a numeric parameter which specifies a particular PDP
context definition (see +CGDCONT Command)
1..3 PDP Context Identifier, cid 3 is reserved and is always
defined, it cannot be changed by user.
Reference Note
![](asset-a0.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 160 15.01.2010
z This command is used to tests PDPs with network simulators.
Successful activation of PDP on real network is not guaranteed.
z Refer to +CGDATA clarification for more information.
7.2.6 AT+CGDATA Enter Data State
AT+CGDATA Enter Data State
Test Command
AT+CGDATA=?
Response
+CGDATA: list of supported <L2P>s
OK
Parameter
See Write Command
Write Command
AT+CGDATA[=
<L2P>,[<cid>]]
Response
CONNECT
If error is related to ME functionality:
+CME ERROR: <err>
Parameters
<L2P> a string parameter(string should be included in quotation
marks) that indicates the layer 2 protocol to be used
between the TE and MT:
PPP – Point to Point protocol for a PDP such as IP
Other values are not supported and will result in an ERROR
response to the execution Command.
<cid> a numeric parameter which specifies a particular PDP
context definition (see +CGDCONT Command)
1..3 PDP Context Identifier. cid 3 is reserved
and is always defined, it cannot be changed by user.
Reference
Note
7.2.7 AT+CGPADDR Show PDP Address
AT+CGPADDR Show PDP Address
Test Command
AT+CGPADDR=
?
Response
+CGPADDR: (list of defined <cid>s)
OK
Parameter
See Write Command
Write Command
AT+CGPADDR=
Response
+CGPADDR: <cid>,<PDP_addr>
![](asset-a1.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 161 15.01.2010
[<cid>] [<CR><LF>+CGPADDR: <cid>,<PDP_addr>[…]]
OK
ERROR
Parameters
<cid> a numeric parameter which specifies a particular PDP
context definition (see +CGDCONT Command) If no <cid>
is specified, the addresses for all defined contexts are
returned.
1..3 PDP Context Identifier, cid 3 is reserved and is always
defined, it cannot be changed by user.
<PDP_addr>
String type IP address
Format: "<n>.<n>.<n>.<n>" where <n>=0..255
Reference Note
z Write command returns address provided by the network if a
connection has been established.
7.2.8 AT+CGCLASS GPRS Mobile Station Class
AT+CGCLASS GPRS Mobile Station Class
Test Command Response
+CGCLASS: (list of supported <class>s)
AT+CGCLASS=
?
OK
Parameter
See Write Command
Read Command Response
AT+CGCLASS? +CGCLASS: <class>
OK
Parameter
See Write Command
Write Command Response
AT+CGCLASS= OK
<class> ERROR
If error is related to ME functionality:
+CME ERROR: <err>
Parameter
<class> a string parameter(string should be included in quotation
marks) which indicates the GPRS mobile class (in
![](asset-a2.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 162 15.01.2010
descending order of functionality)
B Class-B mode of operation (A/Gb mode), (not
applicable in I
u
mode)
MT would operate PS and
CS
services
bu
t not simultaneously
CC Class-C mode of operation in CS only mode
(A/Gb mode), or CS (Iu mode) (lowest
mode of operation). MT would only operate
C
S
service
s
Reference Note
z It only supports Class B and CC.
7.2.9 AT+CGEREP Control Unsolicited GPRS Event Reporting
AT+CGEREP Control Unsolicited GPRS Event Reporting
Test Command Response
+CGEREP: (list of supported <mode>s) ,(list of supported <bfr>s)
AT+CGEREP=?
OK
Parameter
See Write Command
Read Command Response
+CGEREP: <mode>,<bfr>
AT+CGEREP?
OK
Parameter
See Write Command
Write Command Response
AT+CGEREP=< OK
mode>[,<bfr>] ERROR
Parameter
<mode>
0 Buffer unsolicited result codes in the MT; if MT
result code buffer is full, the oldest ones is discarded.
1 Discard unsolicited result codes when MT TE link
is reserved (e.g. in on line data mode); otherwise
forward them directly to the TE
2 Buffer unsolicited result codes in the MT when MT
![](asset-a3.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 163 15.01.2010
TE link is reserved (e.g. in on line data mode) and flush
them to the TE when MT TE link becomes available;
otherwise forward them directly to the TE
<bfr> 0 MT buffer of unsolicited result codes defined within
this command is cleared when <mode>
1
or
2 is
entered
1 MT buffer of unsolicited result codes defined within this
command is flushed to the TE when <mode> 1 or 2
is entered
Reference Note
7.2.10 AT+CGREG Network Registration Status
AT+CGREG Network Registration Status
Test Command Response
+CGREG: (list of supported <n>s)
AT+CGREG=?
OK
Parameter
See Write Command
Read Command Response
AT+CGREG? +CGREG: <n>,<stat>[,<lac>,<ci>]
OK
+CME ERROR: <err>
Parameter
See Write Command
Write Command Response
AT+CGREG=[< OK
n>] ERROR
Parameters
<n> 0 disable network registration unsolicited result code
1 enable network registration unsolicited result code
+CGREG:<stat>
2 enable network registration and location information
unsolicited result code +CGREG: <stat>[,<lac>,<ci>]
<stat>
0 Not registered, MT is not currently searching an
operator to register to
The GPRS service is disabled, the UE is allowed to attach
![](asset-a4.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 164 15.01.2010
for GPRS if requested by t
he
user
1 Registered, home network
2 Not registered, but MT is currently trying to attach or
searching an operator to register to
The GPRS service is enabled, but an allowable PLMN is
currently not available. The UE will start a GPRS
attach as soon as an allowable PLMN is available.
3 Registration denied
The GPRS service is disabled, the UE is not allowed to
attach for GPRS if requested by the user.
4 Unknown
5 Registered, roaming
<lac> string type (string should be included in quotation marks); two
byte location area code in hexadecimal format (e.g. “00C3”
equals 195 in decimal)
<ci> string type (string should be included in quotation marks); two
bytes cell ID in hexadecimal format
Reference Note
7.2.11 AT+CGSMS Select Service For MO SMS Messages
AT+CGSMS Select Service For MO SMS Messages
Test Command Response
+CGSMS: (list of currently available <service>s)
AT+CGSMS=?
OK
Parameter
See Write Command
Read Command Response
AT+CGSMS? +CGSMS: <service>
OK
Parameter
See Write Command
Write Command Response
AT+CGSMS=[<s OK
ervice>] If error is related to ME functionality:
+CME ERROR: <err>
Parameter
<service> a numeric parameter which indicates the service or service
![](asset-a5.png)
SIM900 AT Commands Set
SIM900R01_ATC_V1.00 165 15.01.2010
preference to be used
0 Packet Domain
1 Circuit switched
2 Packet Domain preferred (use circuit switched if
GPRS not available)
3 Circuit switched preferred (use Packet Domain if
circuit switched not available)
Reference Note
z The circuit switched service route is the default method
![](asset-a6.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 166 15.01.2010
8 AT Commands for TCPIP Application Toolkit
8.1 Overview
Command Description
AT+CIPMUX START UP MULTI IP CONNECTION
AT+CIPSTART START UP TCP OR UDP CONNECTION
AT+CIPSEND SEND DATA THROUGH TCP OR UDP CONNECTION
AT+CIPQSEND SELECT DATA TRANSMITTING MODE
AT+CIPACK QUERY PREVIOUS CONNECTION DATA TRANSMITTING STATE
AT+ CI PC LO S E CLOSE TCP OR UDP CONNECTION
AT+CIPSHUT DEACTIVATE GPRS PDP CONTEXT
AT+CLPORT SET LOCAL PORT
AT+CSTT START TASK AND SET APN, USER NAME, PASSWORD
AT+CIICR BRING UP WIRELESS CONNECTION WITH GPRS OR CSD
AT+CIFSR GET LOCAL IP ADDRESS
AT+ CI PS TATU S QUERY CURRENT CONNECTION STATUS
AT+CDNSCFG CONFIGURE DOMAIN NAME SERVER
AT+CDNSGIP QUERY THE IP ADDRESS OF GIVEN DOMAIN NAME
AT+ CI PH EA D ADD AN IP HEAD WHEN RECEIVING DATA
AT+ CI PAT S SET AUTO SENDING TIMER
AT+CIPSPRT SET PROMPT OF ‘>’ WHEN SENDING DATA
AT+CIPSERVER CONFIGURE AS SERVER
AT+ CI PC SGP SET CSD OR GPRS FOR CONNECTION MODE
AT+CIPSRIP SET WHETHER DISPLAY IP ADDRESS AND PORT OF SENDER
WHEN RECEIVE DATA
AT+CIPMODE SELECT TCPIP APPLICATION MODE
AT+CIPCCFG CONFIGURE TRANSPARENT TRANSFER MODE
AT+CIPSHOWTP DISPLAY TRANSFER PROTOCOL IN IP HEAD WHEN RECEIVING
DATA
8.2 Detailed Descriptions of Commands
8.2.1 AT+CIPMUX Start Up Multi-IP Connection
AT+CIPMUX Start Up Multi-IP Connection
Test Command
AT+CIPMUX=?
Response
+CIPMUX: (0,1)
OK
Parameter
![](asset-a7.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 167 15.01.2010
See Write Command
Read Command
AT+CIPMUX?
Response
+CIPMUX: <n>
OK
Parameter
See Write Command
Write Command
AT+CIPMUX=<
n>
Response
OK
Parameters
<n> 0 Single IP connection
1 Multi IP connection
Reference
Note
z Only in IP initial state, AT+CIPMUX=1 is effective;
z Only when multi IP connection and GPRS application are both shut
down, AT+CIPMUX=0 is effective
8.2.2 AT+CIPSTART Start Up TCP Or UDP Connection
AT+CIPSTART Start Up TCP Or UDP Connection
Test Command
AT+CIPSTART=
?
Response
1) If AT+CIPMUX=0
+CIPSTART: (list of supported <mode>),IP address range,(port range)
+CIPSTART: (list of supported <mode>),(domain name),(port range)
OK
2) If AT+CIPMUX=1
+CIPSTART: (list of supported <n>),(list of supported <mode>),IP
address range,(port range)
+CIPSTART: (list of supported <n>),(list of supported <mode>),(domain
name),(port range)
OK
Parameters
See Write Command
Write Command
1)If single IP
connection
(+CIPMUX=0)
+CIPSTART=<m
ode>,<IP
address>,<port>
Or
Response
1)If single IP connection (+CIPMUX=0)
If format is right response OK, otherwise response
+CME ERROR <err>
If connection exists, response
ALREAY CONNECT
If connected successfully response
CONNECT OK
![](asset-a8.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 168 15.01.2010
+CIPSTART=<m
ode>,<domain
name>,<port>
2)If multi-IP
connection
(+CIPMUX=1)
+CIPSTART=<n>
,<mode>,<address
>,<port>
+CIPSTART=<n>
,<mode>,<domain
name>,<port>
Otherwise
STATE: <state>
CONNECT FAIL
2)If multi-IP connection
(+CIPMUX=1)
If format is right response OK, otherwise response
+CME ERROR <err>
If connection exists, response
<n>,ALREAY CONNECT
If connected successfully response
<n>,CONNECT OK
Otherwise
<n>,CONNECT FAIL
Parameters
<n> 0..7 a numeric parameter which indicates the connection
number
<mode> a string parameter(string should be included in quotation
marks) which indicates the connection type
“TCP” Establish a TCP connection
“UDP” Establish a UDP connection
<IP address> a string parameter(string should be included in quotation
marks) which indicates remote server IP address
<port> remote server port
<domain name> a string parameter(string should be included in quotation
marks) which indicates remote server domain name
<state> a string parameter(string should be included in quotation
marks) which indicates the progress of connecting
0 IP INITIAL
1 IP START
2 IP CONFIG
3 IP GPRSACT
4 IP STATUS
5 TCP CONNECTING/UDP
CONNECTING/SERVER LISTENING
6 CONNECT OK
7 TCP CLOSING/UDP CLOSING
8 TCP CLOSED/UDP CLOSED
9 PDP DEACT
In Multi-IP state:
0 IP INITIAL
1 IP START
2 IP CONFIG
![](asset-a9.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 169 15.01.2010
3 IP GPRSACT
4 IP STATUS
5 IP PROCESSING
9 PDP DEACT
Reference
Note
z This command is allowed to establish a TCP/UDP connection only
when the state is IP INITIAL or IP STATUS when it is in single state.
In multi-IP state, the state is in IP STATUS only. So it is necessary to
process “AT+CIPSHUT” before establish a TCP/UDP connection with
this command when the state is not IP INITIAL or IP STATUS.
z When in multi-IP state, before executing this command, it is necessary
to process” AT+CSTT, AT+CIICR, AT+CIFSR”
8.2.3 AT+CIPSEND Send Data Through TCP Or UDP Connection
AT+CIPSEND Send Data Through TCP Or UDP Connection
Test Command
AT+CIPSEND=?
Response
1) If single IP connection (+CIPMUX=0)
+CIPSEND: <length>
OK
2) If multi IP connection (+CIPMUX=1)
+CIPSEND: <0-7>,<length>
OK
Read Command
AT+CIPSEND?
Response
1) If single IP connection (+CIPMUX=0)
+CIPSEND:<size>
OK
2) If multi IP connection (+CIPMUX=1)
+CIPSEND:<n><size>
OK
Parameter
<n> a numeric parameter which indicates the connection number
<size> a numeric parameter which indicates the data length sent at a
time
Execution
Command
AT+CIPSEND
response”> ”, then
Response
This Command is used to send changeable length data.
If single IP connection (+CIPMUX=0)
If connection is not established or disconnection:
![](asset-aa.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 170 15.01.2010
type data for send,
tap CTRL+Z to
send, tap ESC to
cancel the
operation
+CME ERROR <err>
If sending successfully:
When +CIPQSEND=0
SEND OK
When +CIPQSEND=1
DATA ACCEPT:<length>
If sending fail:
SEND FAIL
Note
This Command can only be used in single IP connection mode
(+CIPMUX=0) and to send data on the TCP or UDP connection that has
been established already. Ctrl-Z is used as a termination symbol. ESC is
used to cancel sending data. There are at most <size> bytes that can be sent
at a time.
Write Command
1) If single IP
connection
(+CIPMUX=0)
+CIPSEND=<len
gth>
2) If multi IP
connection
(+CIPMUX=1)
+CIPSEND=<n>[
,<length>]
Response
This Command is used to send changeable length data
If single IP connection (+CIPMUX=0)
If connection is not established or disconnection:
+CME ERROR <err>
If sending successfully:
When +CIPQSEND=0
SEND OK
When +CIPQSEND=1
DATA ACCEPT:<length>
If sending fail:
SEND FAIL
If multi IP connection (+CIPMUX=1)
If connection is not established or disconnection:
+CME ERROR <err>
If sending successfully:
When +CIPQSEND=0
<n>,SEND OK
When +CIPQSEND=1
DATA ACCEPT:<n>,<length>
If sending fail:
<n>,SEND FAILParameter
<n> a numeric parameter which indicates the connection number
<length> a numeric parameter which indicates the length of sending
data, it must less than <size>
Reference
Note
z The data length which can be sent depends on network status.Set the
![](asset-ab.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 171 15.01.2010
time that send data automatically with the Command of
AT+CIPATS.
z Only send data at the status of established connection
8.2.4 AT+CIPQSEND Select Data Transmitting Mode
AT+CIPQSEND Select Data Transmitting Mode
Test Command
AT+CIPQSEND
=?
Response
+CIPQSEND: (0,1)
OK
Parameter
See Write Command
Read Command
AT+CIPQSEND
?
Response
+CIPQSEND: <n>
OK
Parameters
See Write Command
Write Command
AT+CIPQSEND
=<n>
Response
OK
Parameters
<n> 0 Normal mode – when the server receives TCP data, it will
response SEND OK
1 Quick send mode – when the data is sent to module, it will
response DATA ACCEPT, while not response SEND OK
Reference
Note
8.2.5 AT+CIPACK Query Previous Connection Data Transmitting State
AT+CIPACK Query Previous Connection Data Transmitting State
Test Command
AT+CIPACK=?
Response
OK
Execution
Command
If in single IP
connection
(+CIPMUX=0)
AT+CIPACK
Response
+CIPACK: <txlen>, <acklen>, <nacklen>
Parameters
See write command
Write Command
If in multi IP
Response
+CIPACK: <txlen>, <acklen>, <nacklen>
![](asset-ac.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 172 15.01.2010
connection
(+CIPMUX=1)
AT+CIPACK=<
n>
OK
Parameters
<n> a numeric parameter which indicates the connection number
<txlen> the data amount which has been sent
<acklen> the data amount confirmed successful by the server
<nacklen>the data amount without confirmed by the server
Reference
Note
8.2.6 AT+CIPCLOSE Close TCP Or UDP Connection
AT+CIPCLOSE Close TCP Or UDP Connection
Test Command
AT+CIPCLOSE
=?
Response
OK
Execution
Command
AT+CIPCLOSE
Response
If close successfully:
CLOSE OK
If close fail:
ERROR
Write Command
1) If single IP
connection
(+CIPMUX=0)
AT+CIPCLOSE
=<id>
2) If multi IP
connection
(+CIPMUX=1)
AT+CIPCLOSE
=<n><id>
Response:
1) If single IP connection (+CIPMUX=0)
CLOSE OK
2) If multi IP connection (+CIPMUX=1)
<n>, CLOSE OK
Parameters
<id> 0 slow close (default)
1 quick close
<n> a numeric parameter which indicates the connection number
Reference
Note
z AT+CIPCLOSE only close connection at the status of TCP/UDP
CONNECTING or CONNECT OK,otherwise response ERROR, after
closing the connection, the status is IP CLOSE when in single IP mode
8.2.7 AT+CIPSHUT Deactivate GPRS PDP Context
AT+CIPSHUT Deactivate GPRS PDP Context
![](asset-ad.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 173 15.01.2010
Test Command
AT+CIPSHUT=?
Response
OK
Execution
Command
AT+CIPSHUT
Response
If close successfully:
SHUT OK
If close fail:
ERROR
Note Except at the status of IP INITIAL, you can close moving scene by
AT+CIPSHUT. After closed, the status is IP INITIAL.
Reference
Note
z If this command executed in multi-connection mode, all of the IP
connection will be shut
8.2.8 AT+CLPORT Set Local Port
AT+CLPORT Set Local Port
Test Command
AT+CLPORT=?
Response
+CLPORT: (list of supported <port>s)
OK
Parameter
See Write Command
Read Command
AT+CLPORT?
Response
TCP: <port>
UDP: <port>
OK
Parameter
See Write Command
Write Command
AT+CLPORT=<
mode>,<port>
Response
OK
ERROR
Parameters
<mode> a string parameter(string should be included in quotation
marks) which indicates the connection type
“TCP” TCP local port
“UDP” UDP local port
<port> 0-65535 a numeric parameter which indicates the local port
0 is default value, it can be dynamically allocated a port.
Reference
Note
z This command will be effective only in single connection mode
(+CIPMUX=0) and when module as a Client
![](asset-ae.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 174 15.01.2010
8.2.9 AT+CSTT START Task And Set APN、USER NAME、PASSWORD
AT+CSTT Start Task And Set APN、USER NAME、PASSWORD
Test Command
AT+CSTT=?
Response
+CSTT: "APN","USER","PWD"
OK
Read Command
AT+CSTT?
Response
+CSTT: <apn>,<user name>,<password>
OK
Parameters
See Write Command
Write Command
AT+CSTT=<apn
>,<user name>,<
password>
Response
OK
ERROR
Parameters
<apn> a string parameter(string should be included in quotation
marks) which indicates the GPRS access point name
<user name> a string parameter(string should be included in quotation
marks) which indicates the GPRS user name
<password> a string parameter(string should be included in quotation
marks) which indicates the GPRS password
Execution
Command
AT+CSTT
Response
OK
ERROR
Reference
Note
z The write command and execution command of this command is valid
only at the state of IP INITIAL. After operating this command, the
state will be changed to IP START.
8.2.10 AT+CIICR Bring Up Wireless Connection With GPRS Or CSD
AT+CIICR Bring Up Wireless Connection With GPRS Or CSD
Test Command
AT+CIICR=?
Response
OK
Execution
Command
AT+CIICR
Response
OK
ERROR
Reference
Note
z AT+CIICR only activates moving scene at the status of IP START,
![](asset-af.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 175 15.01.2010
after operating this Command, the state will be changed to IP
CONFIG.
z After module accepting the activated operation, if activate successfully,
the state will be changed to IP GPRSACT, response OK, otherwise
response ERROR.
8.2.11 AT+CIFSR Get Local IP Address
AT+CIFSR Get Local IP Address
Test Command
AT+CIFSR=?
Response
OK
Execution
Command
AT+CIFSR
Response
<IP address>
ERROR
Parameter
<IP address> a string parameter(string should be included in quotation
marks) which indicates the IP address assigned from GPRS
or CSD
Reference
Note
z Only at the status of activated the moving scene: IP GPRSACT、
TCP/UDP CONNECTING、CONNECT OK、IP CLOSE can get local
IP Address by AT+CIFSR, otherwise response ERROR.
8.2.12 AT+CIPSTATUS Query Current Connection Status
AT+CIPSTATUS Query Current Connection Status
Test Command
AT+CIPSTATUS
=?
Response
OK
Execution
Command
AT+CIPSTATUS
Response
1)If single connection mode (+CIPMUX=0)
OK
STATE: <state>
2) If multi-connection mode (+CIPMUX=1)
OK
STATE: <state>
If the module is set as server
S: 0, <bearer>, <port>, <server state>
C: <n>,<bearer>, <TCP/UDP>, <IP address>, <port>, <client state>
Parameter
<n> 0-7 a numeric parameter which indicates the connection number
![](asset-b0.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 176 15.01.2010
<bearer> 0-1 GPRS bearer, default is 0
<server state> OPENING,
LISTENING,
CLOSING
< client state > INITIAL
CONNECTING
CONNECTED
CLOSING
CLOSED
<state> a string parameter(string should be included in quotation
marks) which indicates the progress of connecting
0 IP INITIAL
1 IP START
2 IP CONFIG
3 IP GPRSACT
4 IP STATUS
5 TCP CONNECTING/UDP
CONNECTING/SERVER LISTENING
6 CONNECT OK
7 TCP CLOSING/UDP CLOSING
8 TCP CLOSED/UDP CLOSED
9 PDP DEACT
In Multi-IP state:
0 IP INITIAL
1 IP START
2 IP CONFIG
3 IP GPRSACT
4 IP STATUS
5 IP PROCESSING
9 PDP DEACT
Reference
Note
8.2.13 AT+CDNSCFG Configure Domain Name Server
AT+CDNSCFG Configure Domain Name Server
Test Command
AT+CDNSCFG=
?
Response
+CDNSCFG: (“Primary DNS”),(“Secondary DNS”)
OK
Read command Response
![](asset-b1.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 177 15.01.2010
AT+CDNSCFG? PrimaryDns: <pri_dns>
SecondaryDns: <sec_dns>
OK
Write Command
AT+CDNSCFG=
<pri_dns>,<sec_
dns>
Response
OK
ERROR
Parameters
<pri_dns> a string parameter(string should be included in quotation
marks) which indicates the IP address of the primary
domain name server
<sec_dns> a string parameter(string should be included in quotation
marks) which indicates the IP address of the secondary
domain name server
Reference
Note
8.2.14 AT+CDNSGIP Query The IP Address Of Given Domain Name
AT+CDNSGIP Query The IP Address Of Given Domain Name
Test Command
AT+CDNSGIP=
?
Response
OK
Write Command
AT+CDNSGIP=
<domain name>
Response
OK
ERROR
If successful, return:
+CDNSGIP: 1, <domain name>,<IP>
If fail, return:
+CDNSGIP:0,<dns error code>
Parameters
<domain name> a string parameter(string should be included in
quotation marks) which indicates the domain name
<IP address> a string parameter(string should be included in
quotation marks) which indicates the IP address
corresponding to the domain name
<dns error code> a numeric parameter which indicates the error
code
10 DNS GENERAL ERROR
11 DNS MAX RETRIES,
12 DNS NO SERVER ADDR,
13 DNS NO MEMORY,
14 DNS INVALID NAME,
15 DNS INVALID RESP,
There are some other error code as well.
![](asset-b2.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 178 15.01.2010
Reference
Note
8.2.15 AT+CIPHEAD Add An IP Head When Receiving Data
AT+CIPHEAD Add An IP Head When Receiving Data
Test Command
AT+CIPHEAD=
?
Response
+CIPHEAD: (list of supported <mode>s)
OK
Parameter
See Write Command
Read Command
AT+CIPHEAD?
Response
+CIPHEAD: <mode>
OK
Parameter
See Write Command
Write Command
AT+CIPHEAD=
<mode>
Response
OK
ERROR
Parameter
<mode> a numeric parameter which indicates whether adding an IP
header to received data or not
0 not add IP header
1 add IP header, the format is “+IPD,data length:”
Reference
Note
8.2.16 AT+CIPATS Set Auto Sending Timer
AT+CIPATS Set Auto Sending Timer
Test Command
AT+CIPATS=?
Response
+CIPATS: (list of supported <mode>s),(list of supported <time>)
OK
Parameter
See Write Command
Read Command
AT+CIPATS?
Response
+CIPATS: <mode>,<time>
OK
![](asset-b3.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 179 15.01.2010
Parameter
See Write Command
Write Command
AT+CIPATS=<m
ode>[,<time>]
Response
OK
ERROR
Parameters
<mode> a numeric parameter which indicates whether set timer
when sending data
0 not set timer when sending data
1 Set timer when sending data
<time> 0..100 a numeric parameter which indicates the seconds
after which the data will be sent
Reference
Note
8.2.17 AT+CIPSPRT Set Prompt Of ‘>’ When Sending Data
AT+CIPSPRT Set Prompt Of ‘>’ When Sending Data
Test Command
AT+CIPSPRT=?
Response
+CIPSPRT: (<send prompt>s)
OK
Parameter
See Write Command
Read Command
AT+CIPSPRT?
Response
+CIPSPRT: <send prompt>
OK
Parameter
See Write Command
Write Command
AT+CIPSPRT=<
send prompt>
Response
OK
ERROR
Parameter
<send prompt> a numeric parameter which indicates whether echo
prompt ‘>’ after issuing AT+CIPSEND Command
0 no prompt and show “send ok” when send successfully
1 echo ‘>’ prompt and show “send ok” when send successfully
2 no prompt and not show “send ok” when send successfully
Reference
Note
![](asset-b4.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 180 15.01.2010
8.2.18 AT+CIPSERVER Configure As Server
AT+CIPSERVER Configure As Server
Test Command
AT+CIPSERVE
R=?
Response
+CIPSERVER: (0-CLOSE SERVER, 1-OPENSERVER),(1,65535)
OK
Read Command
AT+CIPSERVE
R?
Response
+CIPSERVER: <mode>[,<port>,<channel id>,<bearer>]
OK
Parameter
See write command
Write Command
AT+CIPSERVE
R=<mode>[,<por
t>]
Response
OK
ERROR
Parameters
<mode> 0 close server
1 open server
<port> 1..65535 Listening port
<channel id> channel id
<bearer> GPRS bearer
Reference
Note
This command is allowed to establish a TCP server only when the state is IP
INITIAL or IP STATUS when it is in single state. In multi-IP state, the
state is in IP STATUS only.
8.2.19 AT+CIPCSGP Set CSD Or GPRS For Connection Mode
AT+CIPCSGP Set CSD Or GPRS For Connection Mode
Test Command
AT+CIPCSGP=?
Response
+CIPCSGP:0-CSD,DIALNUMBER,USER
NAME,PASSWORD,RATE(0-3)
+CIPCSGP: 1-GPRS,APN,USER NAME,PASSWORD
OK
Parameters
See Write Command
Read Command
AT+CIPCSGP?
Response
+CIPCSGP: <mode>, <apn>, <user name>, <password>[,<rate>]
OK
Parameter
![](asset-b5.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 181 15.01.2010
See Write Command
Write Command
AT+CIPCSGP=
<mode>,[(<apn>,
<user name >,
<password>),
(<dial
number>,<user
name>,<passwor
d>,<rate>)]
Response
OK
ERROR
Parameters
<mode> a numeric parameter which indicates the wireless connection
mode
0 set CSD as wireless connection mode
1 set GPRS as wireless connection mode
GPRS parameters:
<apn> a string parameter(string should be included in quotation
marks) which indicates the access point name
<user name> a string parameter(string should be included in quotation
marks) which indicates the user name
<password> a string parameter(string should be included in quotation
marks) which indicates the password
CSD parameters:
<dial number> a string parameter(string should be included in quotation
marks) which indicates the CSD dial numbers
<user name> a string parameter(string should be included in quotation
marks) which indicates the CSD user name
<password> a string parameter(string should be included in quotation
marks) which indicates the CSD password
<rate> a numeric parameter which indicates the CSD connection
rate
0 2400
1 4800
2 9600 (default)
3 14400
Reference
Note
8.2.20 AT+CIPSRIP Set Whether Display IP Address And Port Of Sender When Receive
Data
AT+CIPSRIP Set Whether Display IP Address And Port Of Sender When Receive Data
Test Command
AT+CIPSRIP=?
Response
+CIPSRIP: (list of supported <mode>s)
OK
Parameter
See Write Command
Read Command Response
![](asset-b6.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 182 15.01.2010
AT+CIPSRIP?
+CIPSRIP: <mode>
OK
Parameter
See Write Command
Write Command
AT+CIPSRIP=<
mode>
Response
OK
ERROR
Parameter
<mode> a numeric parameter which indicates whether show the
prompt of where the data received are from or not before
received data.
0 do not show the prompt
1 show the prompt, the format is as follows: RECV
FROM:<IP ADDRESS>:<PORT>
Note that the default mode is not to show the prompt.
Reference
Note
8.2.21 AT+CIPMODE Select TCPIP Application Mode
AT+CIPMODE Select TCPIP Application Mode
Test Command
AT+CIPMODE=
?
Response
+CIPMODE 0-NORMAL MODE,1-TRANSPARENT MODE)
OK
Read Command
AT+CIPMODE?
Response
+CIPMODE: <mode>
OK
Parameter
See Write Command
Write Command
AT+CIPMODE=
<mode>
Response
OK
ERROR
Parameter
<mode> 0 normal mode
1 transparent mode
Reference
Note
![](asset-b7.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 183 15.01.2010
8.2.22 AT+CIPCCFG Configure Transparent Transfer mode
AT+CIPCCFG Configure Transparent Transfer Mode
Test Command
AT+CIPCCFG=
?
Response
+CIPCCFG: (NmRetry:3-8),(WaitTm:2-10),(SendSz:1-1460),(esc:0,1)
OK
Read Command
AT+CIPCCFG?
Response
+CIPCCFG: <NmRetry>,<WaitTm>,<SendSz>,<esc>
OK
Parameters
See Write Command
Write Command
AT+CIPCCFG=
<NmRetry>,<Wa
itTm>,<SendSz>,
<esc>
Response
OK
ERROR
Parameters
<NmRetry> number of retries to be made for an IP packet.
<WaitTm> number of 200ms intervals to wait for serial input before
sending the packet.
<SendSz> size in bytes of data block to be received from serial port
before sending.
<esc> whether turn on the escape sequence, default is TRUE.
Reference
Note
z This command will be effective only in single connection mode
(+CIPMUX=0)
8.2.23 AT+CIPSHOWTP Display transfer protocol in IP head when receiving data
AT+CIPSHOWTP Display transfer protocol in IP head when receiving data
Test command
AT+CIPSHOWTP
=?
Response
+CIPSHOWTP: (list of supported <mode>s)
OK
Parameter
See write command
Read command
AT+CIPSHOWTP
?
Response
+CIPSHOWTP: <mode>
OK
Parameter
See write command
Write command Response
![](asset-b8.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 184 15.01.2010
AT+CIPSHOWTP
=<mode>
OK
ERROR
Parameter
<mode> a numeric parameter which indicates whether display transfer
protocol in IP header to received data or not
0 does not display transfer protocol
1 display transfer protocol, the format is “+IPD,<data
Size>,<TCP/UDP>:<data>”
Reference
Note
Only when +CIPHEAD set to 1,the setting of this command would work
![](asset-b9.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 185 15.01.2010
9 Supported unsolicited result codes
9.1 Summary of CME ERROR Codes
Final result code +CME ERROR: <err> indicates an error related to mobile equipment or network.
The operation is similar to ERROR result code. None of the following commands in the same
Command line is executed. Neither ERROR nor OK result code shall be returned.
<err> values used by common messaging commands:
Code of <err> Meaning
0 phone failure
1 no connection to phone
2 phone-adaptor link reserved
3 operation not allowed
4 operation not supported
5 PH-SIM PIN required
6 PH-FSIM PIN required
7 PH-FSIM PUK required
10 SIM not inserted
11 SIM PIN required
12 SIM PUK required
13 SIM failure
14 SIM busy
15 SIM wrong
16 incorrect password
17 SIM PIN2 required
18 SIM PUK2 required
20 memory full
21 invalid index
22 not found
23 memory failure
24 text string too long
25 invalid characters in text string
26 dial string too long
27 invalid characters in dial string
30 no network service
31 network timeout
32 network not allowed - emergency calls only
40 network personalization PIN required
![](asset-ba.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 186 15.01.2010
41 network personalization PUK required
42 network subset personalization PIN required
43 network subset personalization PUK required
44 service provider personalization PIN required
45 service provider personalization PUK required
46 corporate personalization PIN required
47 corporate personalization PUK required
100 Unknown
103 illegal MS
106 illegal ME
107 GPRS services not allowed
111 PLMN not allowed
112 location area not allowed
113 roaming not allowed in this location area
132 service option not supported
133 requested service option not subscribed
134 service option temporarily out of order
148 unspecified GPRS error
149 PDP authentication failure
150 invalid mobile class
9.2 Summary of CMS ERROR Codes
Final result code +CMS ERROR: <err> indicates an error related to message service or network.
The operation is similar to ERROR result code. None of the following commands in the same
Command line is executed. Neither ERROR nor OK result code shall be returned.
<err> values used by common messaging commands:
Code of <err> Meaning
300 ME failure
301 SMS ME reserved
302 Operation not allowed
303 Operation not supported
304 Invalid PDU mode
305 Invalid text mode
310 SIM not inserted
311 SIM pin necessary
312 PH SIM pin necessary
313 SIM failure
![](asset-bb.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 187 15.01.2010
314 SIM busy
315 SIM wrong
316 SIM PUK required
317 SIM PIN2 required
318 SIM PUK2 required
320 Memory failure
321 Invalid memory index
322 Memory full
330 SMSC address unknown
331 No network
332 Network timeout
500 Unknown
512 SIM not ready
513 Unread records on SIM
514 CB error unknown
515 PS busy
528 Invalid (non-hex) chars inPDU
529 Incorrect PDU length
530 Invalid MTI
531 Invalid (non-hex) chars in address
532 Invalid address (no digits read)
533 Incorrect PDU length (UDL)
534 Incorrect SCA length
536 Invalid First Octet (should be 2 ore 34)
537 Invalid Command type
538 SRR bit not set
539 SRR bit set
540 Invalid User Data Header IE
![](asset-bc.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 188 15.01.2010
10 AT Commands Sample
10.1 Profile Commands
Demonstration Syntax Expect Result
The AT Command
interpreter is actively
responded to input.
AT OK
Display the product
name and the product
release information.
ATI
SIM900 R11.0
Display product
identification
information: the
manufacturer, the
product name and the
product revision
information.
AT+ GS V SIMCOM_Ltd
SIMCOM_SIM900
Revision:1137B01SIM900M32_ST
OK
Display current
configuration, a list of
the current active profile
parameters.
AT& V [A complete listing of the active profile]
OK
Reporting of mobile
equipment errors. The
default CME error
reporting setting is
disabled. Switching to
verbose mode displays a
string explaining the
error in more details.
AT+ CM EE= ?
AT+ CM EE?
AT+CSCS=?
AT+CSCS=”TEST”
AT+ CM EE= 2
AT+CSCS=”TEST”
+CMEE: (0-2)
OK
+CMEE: 1
OK
+CSCS: ("GSM","HEX","IRA",
"PCCP","PCDN","UCS2","8859-1")
OK
ERROR
OK
+CME ERROR: operation not allowed
Storing the current
configuration in
nonvolatile memory.
When the board is reset,
the configuration
changes from the last
session are loaded.
ATE0&W
AT
[Reset the board]
AT
ATE1&W
AT
OK
[No echo]
OK
[No echo]
OK
[No echo]
OK
[Echo on]
![](asset-bd.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 189 15.01.2010
OK
Set the ME to minimum
functionality
AT+ I P R ?
AT+CFUN=0
AT+IPR = 115200
AT+ IP R?
AT+CFUN=0
+IPR:0
OK
OK
OK
+IPR:115200
OK
+CPIN: NOT READY
OK
ME has entered full functionality mode. AT +C FUN? +CFUN:1
OK
10.2 SIM Commands
Demonstration Syntax Expect Result
Listing available
phonebooks, and
selecting the SIM
phonebook.
AT+CPBS=?
AT+CPBS=”SM”
+CPBS:
("MC","RC","DC","LD","LA","SM","FD",
"ON","BN","SD","VM","EN")
OK
OK
Displaying the
ranges of phonebook
entries and listing
the contents of the
phonebook.
AT+CPBR=?
AT+CPBR=1,10
+CPBR: (1-250),40,14
OK
[a listing of phonebook contents]
OK
Writing an entry to
the current
phonebook.
AT+CPBW=,”13918
18xxxx”, ,”Daniel”
AT+CPBR=1,10
OK
[a listing of phonebook contents]
OK
Finding an entry in
the current
phonebook using a
AT+CPBF=”Daniel” +CPBF: 5,”13918186089”,129,”Daniel”
OK
![](asset-be.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 190 15.01.2010
text search.
Deleting an entry
from the current
phonebook specified
by its position index.
AT+CPBW=2,”10086 ”
AT+CPBR=1,10
OK
[a listing of phonebook contents]
OK
10.3 General Commands
Demonstration Syntax Expect Result
Displays the current network operator
that the handset is currently registered
with.
AT+ CO PS ? +COPS: 0,0,”CHINA
MOBILE”
OK
Display a full list of network operator
names.
AT+COPN +COPN:”20201”,
“COSMO”
[skip a bit]
+COPN:
"901012","Maritime Comm
Partner AS"
OK
Power down the phone – reducing its
functionality. This will deregister the
handset from the network.
AT+ IP R?
AT+CFUN=0
[wait for deregister]
ATD6241xxxx;
AT+CFUN=1
+IPR: 0
OK
OK
ERROR
OK
Request the IMSI AT+CIMI 460008184101641
OK
10.4 Call Control Commands
Demonstration Syntax Expect Result
Make a voice call ATD6241xxxx; OK
MS makes a voice call
Hang up a call ATH OK
Call dropped
Make a voice call using the last number
facility. The initial call is established
then cancelled. The second call is made
using the previous dial string.
ATD6241xxxx;
ATH
ATD L
OK
OK
OK
Example of a MT voice call Make MT voice call to
MS.
RING
RING
![](asset-bf.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 191 15.01.2010
ATA
ATH
OK[accept call]
OK[hang up call]
Call related supplementary service:
AT+CHLD. This Command provides
support for call waiting functionality.
AT+CHLD=<N>
<N>=0 RELEASE
ALL HELD CALLS
OR SEND USER
BUSY STATUS TO
WAITING CALL
<N>=1 RELEASE
ALL ACTIVE CALLS
AND ACCEPT
OTHER
CALL(WAITING OR
HELD) <N>=1X
RELEASE CALL X
<N>=2 PLACE ALL
ACTIVE CALLS ON
HOLD AND ACCEPT
CALL <N>=2X
PLACE ALL CALLS
ON HOLD EXCEPT
CALL X
Return value:(0,1,1x,2,2x,3)
Terminate current call and accept waiting
call.
Establish a voice call from EVB, receive
an incoming call(incoming call accepts
waiting status), terminate active call and
accept incoming call. Note call waiting
must be active for this option – use
“AT+CCWA=1,1” before running this
demonstration.
AT+CCWA=1,1
ATD6241xxxx;
<RX incoming call>
AT+CHLD=1
OK
OK
+CCWA:”62418148”,
129,1,””
OK
<waiting call active>
Set current call to busy and accept
waiting call.
Establish a voice call from EVB, receive
an incoming call(incoming call accepts
waiting status), place active call on hold
and switch to incoming call. Terminate
active call and switch back to original
call. Note call waiting must have been
previously enabled for this
demonstration to work.
ATD6241xxxx;
<RX incoming call>
AT+CHLD=2
AT+CHLD=1
+CCWA:”1391818
6089”,129,1,””
OK
<waiting call active other
call on hold>
OK
<incoming call terminated,
dialed number now active>
Switch between active and held calls.
Establish a voice call from EVB, receive
an incoming call (incoming call accepts
ATD6241xxxx;
<RX incoming call>
OK
+CCWA:”1391818
![](asset-c0.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 192 15.01.2010
waiting status), place active call on hold
and switch to incoming call. Switch
between both calls, placing each in the
hold state whilst the other is active
before terminating each one. This feature
relies on knowing each call’s ID. This is
done using the List Current
Calls(AT+CLCC) Command. A call’s ID
is required to switch between held and
active calls. Held calls that are not
automatically resumed when all other
calls are terminated. They need to be
made active using the AT+CHLD=2x
Command. Note call waiting must have
been previously enabled for this
demonstration to work.
AT+CHLD=2
AT+CHLD=21
AT+CLCC
AT+CHLD=23
AT+CHLD=13
AT+CHLD=11
6089”,129,1,””
OK
<incoming call activated,
original on hold>
OK
<original call actived,
incoming call held>
+CLCC:1,0,0,0,0,”62
418148”,129
+CLCC:3,1,1,0,0,”139
18186089”,129
OK
< Note incoming call held
flag set>
OK
<original call held, incoming
call active>
OK
<terminate incoming call>
<terminate original call>
Send busy status to incoming waiting
caller.
Establish a voice call from EVB, receive
an incoming call (incoming call accepts
waiting status), send ‘busy’ status to
waiting mobile. Note call waiting must
have been previously enabled for this
demonstration to work.
ATD6241xxxx;
<RX incoming call>
AT+CHLD=0
OK
+CCWA:”1391818
6089”,129,1,””
OK
OK
<incoming call sent busy
msg, current call retained>
Drop all calls on hold.
Establish a voice call from EVB, receive
an incoming call (incoming call accepts
waiting status), switch to incoming call
and drop all waiting calls.
Note call waiting must have been
previously enabled for this
demonstration to work.
ATD6241xxxx;
<RX incoming call>
AT+CHLD=2
AT+CHLD=0
OK
+CCWA:”1391818
6089”,129,1,””
OK
<incoming call actived,
original on hold>
OK
<incoming call on hold
terminated, current call
retained>
![](asset-c1.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 193 15.01.2010
10.5 SIM Toolkit Commands
Demonstration Syntax Expect Result
Select the 1st menu item: individual
assistance
at*psstk="MENU
SELECTION",1
*PSSTK: "SELECT
ITEM",0,0,,0,0,1,0,0,5
Go to the menu of individual assistance
at*psstk="GET ITEM
LIST",5
*PSSTK: "GET ITEM
LIST",1,1,2,5E2E52A9,0,0,0
*PSSTK: "GET ITEM
LIST",2,2,2,752862377BA174
06,0,0,0
*PSSTK: "GET ITEM
LIST",3,3,2,52067EC47BA17
406,0,0,0
*PSSTK: "GET ITEM
LIST",4,4,2,7FA453D16D886
06F,0,0,0
*PSSTK: "GET ITEM
LIST",5,5,2,65E57A0B63D09
192,0,0,0
OK
Select 1: help at*psstk="SELECT
ITEM",1,1,0,0
at*psstk="SELECT
ITEM",cmmand,Itemd
enfier,Icon,help
*PSSTK:
"NOTIFICATION",1,19,1,2,5
3D190014FE1606F2026,0,0
Go back to main menu at*PSSTK="NOTIFICA
TION",1,0 *PSSTK: "END SESSION"
10.6 Audio Commands
Demonstration Syntax Expect Result
DTMF tones AT+CLDTMF=2,”1,2,
3,4,5”
OK
10.7 SMS Commands
Demonstration Syntax Expect Result
Set SMS system into text mode, as
opposed to PDU mode.
AT+ CM GF= 1 OK
Send an SMS to myself.
AT+CSCS=”GSM”
AT+CMGS=”+861391
818xxxx”
>This is a test
<Ctrl+Z>
OK
+CMGS:34
OK
![](asset-c2.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 194 15.01.2010
Unsolicited notification of the SMS
arriving
+CMTI:”SM”,1
Read SMS message that has just arrived.
Note: the number should be the same as
that given in the +CMTI notification.
AT+ CM GR= 1 +CMGR: “REC UNREAD”,
“+8613918186089”, ,”02
/01/30,20:40:31+00”
This is a test
OK
Reading the message again changes the
status to “READ” from ”UNREAD”
AT+ CM GR= 1 +CMGR: “REC READ”,
“+8613918186089”, ,
“02/01/30,20:40:31+00”
This is a test
OK
Send another SMS to myself. AT+CMGS=”+861391
818xxxx”
>Test again<Ctrl+Z>
+CMGS:35
OK
Unsolicited notification of the SMS
arriving
+CMTI:”SM”,2
Listing all SMS messages.
Note:”ALL” must be in uppercase.
AT+CMGL=”ALL” +CMGL: 1,”REC
READ”,”+8613918186089”,
, “02/01/30,20:40:31+00”
This is a test
+CMGL: 2,”REC
UNREAD”,” ”,”+861391818
6089”,
, “02/01/30,20:45:12+00”
Test again
OK
Delete an SMS message. AT+CMGD=1 OK
List all SMS messages to show message
has been deleted.
AT+CMGL=”ALL” +CMGL: 2,”REC READ”,
“+8613918186
089”,”02/01/30,20:45:12+00
”
Test again
OK
Send SMS using Chinese characters
AT+CSMP=17,0,2,
25
AT+CSCS=”UCS2”
AT+CMGS=”0031003
OK
OK
+CMGS:36
![](asset-c3.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 195 15.01.2010
300390031003800310
038003x003x003x003
x”
>4E014E50<Ctrl+Z>
OK
10.8 GPRS Commands
Demonstration Syntax Expect Result
To establish a GPRS context. Setup modem driver
Setup dial up
connection with *99#
Run internet explorer
Should be able to surf the
web using Internet explorer.
There are two GPRS Service Codes for
the ATD Command: Value 88 and 99.
Establish a connection by service code
99.
Establish a connection by service code
99 and using CID 1
ATD*99#
ATD*99***1#
CONNECT
<data>
CONNECT
To check if the MS is connected to the
GPRS network
Detach from the GPRS network
To check if the MS is connected to the
GPRS network
AT+ CG ATT?
AT+CGATT=0
AT+ CG ATT?
+CGATT:1
OK
OK
+CGATT : 0
OK
To check the class of the MS AT+ CG CLA SS ? +CGCLASS:B
OK
Establish a context using the terminal
equipment: defines CID 1
and sets the PDP type to IP, access
point name and IP address aren’t set.
AT+CGDCONT=1,”I
P”
ATD*99#
OK
CONNECT
<data>
Cancel a context using the terminal
equipment
Pause data transfer and enter Command
mode by +++
Stop the GPRS data transfer
AT+CGDCONT=1,
“IP”
ATD*99#
+++
ATH
OK
CONNECT
<data>
OK
OK
![](asset-c4.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 196 15.01.2010
Reconnect a context using the terminal
equipment
Resume the data transfer
AT+CGDCONT=1,”I
P”
ATD*99#
+++
ATO
OK
CONNECT
<data>
OK
CONNECT
<data>
*Quality of Service (QOS) is a special parameter of a CID which consists of several parameters itself.
The QOS consists of
The precedence class
The delay class
The reliability class
The peak throughput class
The mean throughput class
And is decided in “requested QOS” and “minimum acceptable QOS”.
All parameters of the QOS are initiated by default to the “network subscribed value (=0)” but the
QOS itself is set to be undefined. To define a QOS use the AT+CGQREQ or AT+CGQMIN
Command.
Overwrite the precedence class of
QOS of CID 1 and sets the QOS of
CID 1 to be present
AT+CGQREQ=1,2 OK
Response: all QOS values of CID 1
are set to network subscribed except
precedence class which is set
to 2
AT+CGQREQ? +CGQREQ:1,0,0,0,0,0
+CGQREQ: 3,0,0,3,0,0
OK
Set the QOS of CID 1 to not present.
Once defined, the CID it can be
activated.
AT+CGQREQ=1 OK
Activate CID 2, if the CID is already
active, the mobile returns OK at once.
If no CID is defined the mobile
responses +CME ERROR: invalid index.
Note: If the mobile is NOT attached
by AT+CGATT=1 before activating, the
attach is automatically done by the
AT+CGACT Command.
AT+CGACT=1,2
AT+CGACT=1,3
OK
OK
Use the defined and activated CID
to get online. The mobile can be
connected using the parameters of
appointed CID or using default
parameter
AT+CGDATA=”PPP”,
1
CONNECT
The mobile supports Layer 2 Protocol (L2P) PPP only.
![](asset-c5.png)
SIM900 AT Commands Set
SIM900_ATC_V1.00 197 15.01.2010
Note: If the mobile is NOT attached by AT+CGATT=1 and the CID is NOT activated before
connecting, attaching and activating is automatically done by the AT+CGDATA Command.
Some providers require to use an APN to establish a GPRS connection. So if you use the
Microsoft Windows Dial-Up Network and ATD*9… to connect to GPRS you must provide the
context definition as part of the modem definition (Modem
properties/Connection/Advanced…/Extra settings.) As an alternative, you can define and activate
the context in a terminal program (e.g. Microsoft HyperTerminal) and then use the Dial-Up
Network to send only the ATD Command.
Contact us:
Shanghai SIMCom wireless solutions Ltd.
