Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
1
SOFTWARE TESTING LABORATORY
Subject Code: 15ISL67 I.AMarks:20
Hours/Week: 03 ExamHours: 3
Total Hours: 40 Exam Marks: 80
Number of Lecture Hours/Week: 01I + 02P
1. Design and develop a program in a language of your choice to solve the
triangle problem defined as follows: Accept three integers which are
supposed to be the three sides of a triangle and determine if the three values
represent an equilateral triangle, isosceles triangle, scalene triangle, or they
do not form a triangle at all. Assume that the upper limit for the size of any
side is 10. Derive test cases for your program based on boundaryvalue
analysis, execute the test cases and discuss the results.
2. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of boundary
value testing, derive different test cases, execute these test cases and discuss
the test results.
3. Design, develop, code and run the program in any suitable language to
implement the NextDate function. Analyze it from the perspective of
boundary value testing, derive different test cases, execute these test cases
and discuss the test results.
4. Design and develop a program in a language of your choice to solve the
triangle problem defined as follows: Accept three integers which are
supposed to be the three sides of a triangle and determine if the three values
represent an equilateral triangle, isosceles triangle, scalene triangle, or they
do not form a triangle at all. Assume that the upper limit for the size of any
side is 10. Derive test cases for your program based on equivalence class
partitioning, execute the test cases and discuss the results.
5. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of
equivalence class testing, derive different test cases, execute these test cases
and discuss the test results.
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
2
6. Design, develop, code and run the program in any suitable language to
implement the NextDate function. Analyze it from the perspective of
equivalence class value testing, derive different test cases, execute these test
cases and discuss the test results.
7. Design and develop a program in a language of your choice to solve the
Triangle problem defined as follows: Accept three integers which are
supposed to be the three sides of a triangle and determine if the three values
represent an equilateral triangle, isosceles triangle, scalene triangle, or they
do not form a triangle at all. Derive test cases for your program based on
decision-table approach, execute the test cases and discuss the results.
8. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of decision
table-based testing, derive different test cases, execute these test cases and
discuss the test results.
9. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of dataflow
testing, derive different test cases, execute these test cases and discuss the
test results.
10. Design, develop, code and run the program in any suitable language to
implement the binary search algorithm. Determine the basis paths and using
them derive different test cases, execute these test cases and discuss the test
results.
11. Design, develop, code and run the program in any suitable language to
implement the quicksort algorithm. Determine the basis paths and using
them derive different test cases, execute these test cases and discuss the test
results. discuss the test results.
12. Design, develop, code and run the program in any suitable language to
implement an absolute letter grading procedure, making suitable
assumptions. Determine the basis paths and using them derive different test
cases, execute these test cases and discuss the test results.
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
3
1. Design and develop a program in a language of your choice to solve the
triangle problem defined as follows: Accept three integers which are
supposed to be the three sides of a triangle and determine if the three values
represent an equilateral triangle, isosceles triangle, scalene triangle, or they
do not form a triangle at all. Assume that the upper limit for the size of any
side is 10. Derive test cases for your program based on boundary-value
analysis, execute the test cases and discuss the results.
ALGORITHM:
Step 1: Input a, b & c i.e three integer values which represent three sides of
the triangle.
Step 2: if (a < (b + c)) and (b < (a + c)) and (c < (a + b) then
do step 3
else print not a triangle. do step 6.
Step 3: if (a=b) and (b=c) then
Print triangle formed is equilateral. do step 6.
Step 4: if (a ≠ b) and (a ≠ c) and (b ≠ c) then
Print triangle formed is scalene. do step 6.
Step 5: Print triangle formed is Isosceles.
Step 6: stop
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
4
PROGRAM CODE:
#include<stdio.h>
#include<ctype.h>
#include<conio.h>
#include<process.h>
int main()
{ int a, b, c;
clrscr();
printf("Enter three sides of the triangle");
scanf("%d%d%d", &a, &b, &c);
if((a > 10) || (b > 10) || (c > 10))
{ printf("Out of range");
getch();
exit(0);
}
if((a<b+c)&&(b<a+c)&&(c<a+b))
{ if((a==b)&&(b==c))
{ printf("Equilateral triangle");
}
else if((a!=b)&&(a!=c)&&(b!=c))
{ printf("Scalene triangle");
}
else
printf("Isosceles triangle");
}
else
{ printf("triangle cannot be formed");
}
getch();
return 0;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
5
Test Report:
Case
Id
Description
Input Data
Expected
Output
Actual
Output
Comments
a
b
c
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
6
2. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of boundary
value testing, derive different test cases, execute these test cases and discuss
the test results.
ALGORITHM
STEP 1: Define lockPrice=45.0, stockPrice=30.0, barrelPrice=25.0
STEP2: Input locks
STEP3: while(locks!=-1) „input device uses -1 to indicate end of data
goto STEP 12
STEP4:input (stocks, barrels)
STEP5: compute lockSales, stockSales, barrelSales and sales
STEP6: output(“Total sales:” sales)
STEP7: if (sales > 1800.0) goto STEP 8 else goto STEP 9
STEP8: commission=0.10*1000.0; commission=commission+0.15 * 800.0;
commission = commission + 0.20 * (sales-1800.0)
STEP9: if (sales > 1000.0) goto STEP 10 else goto STEP 11
STEP10: commission=0.10* 1000.0; commission=commission + 0.15 *
(sales-1000.0)
STEP11: Output(“Commission is $”, commission)
STEP12: exit
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
7
PROGRAM CODE:
#include<stdio.h>
#include<conio.h>
int main()
{ int locks, stocks, barrels, t_sales, flag = 0;
float commission;
clrscr();
printf("Enter the total number of locks");
scanf("%d",&locks);
if ((locks <= 0) || (locks > 70))
{ flag = 1;
}
printf("Enter the total number of stocks");
scanf("%d",&stocks);
if ((stocks <= 0) || (stocks > 80))
{ flag = 1;
}
printf("Enter the total number of barrelss");
scanf("%d",&barrels);
if ((barrels <= 0) || (barrels > 90))
{ flag = 1;
}
if (flag == 1)
{ printf("invalid input");
getch();
exit(0);
}
t_sales = (locks * 45) + (stocks * 30) + (barrels * 25);
if (t_sales <= 1000)
{ commission = 0.10 * t_sales;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
8
else if (t_sales < 1800)
{ commission = 0.10 * 1000;
commission = commission + (0.15 * (t_sales - 1000));
}
else
{ commission = 0.10 * 1000;
commission = commission + (0.15 * 800);
commission = commission + (0.20 * (t_sales - 1800));
}
printf("The total sales is %d \n The commission is %f",t_sales,
commission);
getch();
return;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
9
Test Report:
Case
Id
Description
Input Data
Expected
Output
Actual
Output
Comments
a
b
c
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
10
3. Design, develop, code and run the program in any suitable language to
implement the NextDate function. Analyze it from the perspective of
boundary value testing, derive different test cases, execute these test cases
and discuss the test results.
ALGORITHM
STEP 1: Input date in format DD.MM.YYYY
STEP2: if MM is 01, 03, 05,07,08,10 do STEP3 else STEP6
STEP3:if DD < 31 then do STEP4 else if DD=31 do STEP5 else
output(Invalid Date);
STEP4: tomorrowday=DD+1 goto STEP18
STEP5: tomorrowday=1; tomorrowmonth=month + 1 goto STEP18
STEP6: if MM is 04, 06, 09, 11 do STEP7
STEP7: if DD<30 then do STEP4 else if DD=30 do STEP5 else
output(Invalid Date);
STEP8: if MM is 12
STEP9: if DD<31 then STEP4 else STEP10
STEP10: tomorrowday=1, tommorowmonth=1,
tommorowyear=YYYY+1; goto STEP18
STEP11: if MM is 2
STEP12: if DD<28 do STEP4 else do STEP13
STEP13: if DD=28 & YYYY is a leap do STEP14 else STEP15
STEP14: tommorowday=29 goto STEP18
STEP15: tommorowday=1, tomorrowmonth=3, goto STEP18;
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
11
STEP16: if DD=29 then do STEP15 else STEP17
STEP17: output(“Cannot have feb”, DD); STEP19
STEP18: output(tomorrowday, tomorrowmonth, tomorrowyear);
STEP19: exit
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
12
PROGRAM CODE:
#include<stdio.h>
#include<conio.h>
main( )
{ int
month[12]={31,28,31,30,31,30,31,31,30,31,30,31};
int d,m,y,nd,nm,ny,ndays;
clrscr( );
printf("enter the date,month,year");
scanf("%d%d%d",&d,&m,&y);
ndays=month[m-1];
if(y<=1812 && y>2012)
{ printf("Invalid Input Year");
exit(0);
}
if(d<=0 || d>ndays)
{ printf("Invalid Input Day");
exit(0);
}
if(m<1 && m>12)
{ printf("Invalid Input Month");
exit(0);
}
if(m==2)
{ if(y%100==0)
{ if(y%400==0)
ndays=29;
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
13
}
else if(y%4==0)
ndays=29;
}
nd=d+1;
nm=m;
ny=y;
if(nd>ndays)
{ nd=1;
nm++;
}
if(nm>12)
{ nm=1;
ny++;
}
printf("\n Given date is %d:%d:%d",d,m,y);
printf("\n Next day‟s date is %d:%d:%d",nd,nm,ny);
getch( );
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
14
Test Report:
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
15
4. Design and develop a program in a language of your choice to solve the
triangle problem defined as follows: Accept three integers which are
supposed to be the three sides of a triangle and determine if the three values
represent an equilateral triangle, isosceles triangle, scalene triangle, or they
do not form a triangle at all. Assume that the upper limit for the size of any
side is 10. Derive test cases for your program based on equivalence class
partitioning, execute the test cases and discuss the results.
ALGORITHM:
Step 1: Input a, b & c i.e three integer values which represent three sides of
the triangle.
Step 2: if (a < (b + c)) and (b < (a + c)) and (c < (a + b) then
do step 3
else print not a triangle. do step 6.
Step 3: if (a=b) and (b=c) then
Print triangle formed is equilateral. do step 6.
Step 4: if (a ≠ b) and (a ≠ c) and (b ≠ c) then
Print triangle formed is scalene. do step 6.
Step 5: Print triangle formed is Isosceles.
Step 6: stop
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
16
PROGRAM CODE
#include<stdio.h>
#include<ctype.h>
#include<conio.h>
#include<process.h>
int main()
{ int a, b, c;
clrscr();
printf("Enter three sides of the triangle");
scanf("%d%d%d", &a, &b, &c);
if((a > 10) || (b > 10) || (c > 10))
{ printf("Out of range");
getch();
exit(0);
}
if((a<b+c)&&(b<a+c)&&(c<a+b))
{ if((a==b)&&(b==c))
{
printf("Equilateral triangle");
}
else if((a!=b)&&(a!=c)&&(b!=c))
{
printf("Scalene triangle");
}
else
printf("Isosceles triangle");
}
else
{
printf("triangle cannot be formed");
}
getch();
return 0;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
17
Test Report:
Case
Id
Description
Input Data
Expected
Output
Actual
Output
Comments
a
b
c
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
18
5. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of
equivalence class testing, derive different test cases, execute these test cases
and discuss the test results.
ALGORITHM
STEP 1: Define lockPrice=45.0, stockPrice=30.0, barrelPrice=25.0
STEP2: Input locks
STEP3: while(locks!=-1) „input device uses -1 to indicate end of data goto
STEP 12
STEP4:input (stocks, barrels)
STEP5: compute lockSales, stockSales, barrelSales and sales
STEP6: output(“Total sales:” sales)
STEP7: if (sales > 1800.0) goto STEP 8 else goto STEP 9
STEP8: commission=0.10*1000.0; commission=commission+0.15 * 800.0;
commission = commission + 0.20 * (sales-1800.0)
STEP9: if (sales > 1000.0) goto STEP 10 else goto STEP 11
STEP10: commission=0.10* 1000.0; commission=commission + 0.15 *
(sales-1000.0)
STEP11: Output(“Commission is $”, commission)
STEP12: exit
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
19
PROGRAM CODE:
#include<stdio.h>
#include<conio.h>
int main()
{ int locks, stocks, barrels, t_sales, flag = 0;
float commission;
clrscr();
printf("Enter the total number of locks");
scanf("%d",&locks);
if ((locks <= 0) || (locks > 70))
{ flag = 1;
}
printf("Enter the total number of stocks");
scanf("%d",&stocks);
if ((stocks <= 0) || (stocks > 80))
{ flag = 1;
}
printf("Enter the total number of barrelss");
scanf("%d",&barrels);
if ((barrels <= 0) || (barrels > 90))
{ flag = 1;
}
if (flag == 1)
{ printf("invalid input");
getch();
exit(0);
}
t_sales = (locks * 45) + (stocks * 30) + (barrels * 25);
if (t_sales <= 1000)
{
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
20
commission = 0.10 * t_sales;
}
else if (t_sales < 1800)
{ commission = 0.10 * 1000;
commission = commission + (0.15 * (t_sales - 1000));
}
else
{ commission = 0.10 * 1000;
commission = commission + (0.15 * 800);
commission = commission + (0.20 * (t_sales - 1800));
}
printf("The total sales is %d \n The commission is %f",t_sales,
commission);
getch();
return;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
21
Test Report:
Case
Id
Description
Input Data
Expected
Output
Actual
Output
Comments
a
b
c
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
22
6. Design, develop, code and run the program in any suitable language to
implement the NextDate function. Analyze it from the perspective of
equivalence class value testing, derive different test cases, execute these test
cases and discuss the test results.
ALGORITHM
STEP 1: Input date in format DD.MM.YYYY
STEP2: if MM is 01, 03, 05,07,08,10 do STEP3 else STEP6
STEP3:if DD < 31 then do STEP4 else if DD=31 do STEP5 else
output(Invalid Date);
STEP4: tomorrowday=DD+1 goto STEP18
STEP5: tomorrowday=1; tomorrowmonth=month + 1 goto STEP18
STEP6: if MM is 04, 06, 09, 11 do STEP7
STEP7: if DD<30 then do STEP4 else if DD=30 do STEP5 else
output(Invalid Date);
STEP8: if MM is 12
STEP9: if DD<31 then STEP4 else STEP10
STEP10: tomorrowday=1, tommorowmonth=1, tommorowyear=YYYY+1;
goto STEP18
STEP11: if MM is 2
STEP12: if DD<28 do STEP4 else do STEP13
STEP13: if DD=28 & YYYY is a leap do STEP14 else STEP15
STEP14: tommorowday=29 goto STEP18
STEP15: tommorowday=1, tomorrowmonth=3, goto STEP18;
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
23
STEP16: if DD=29 then do STEP15 else STEP17
STEP17: output(“Cannot have feb”, DD); STEP19
STEP18: output(tomorrowday, tomorrowmonth, tomorrowyear);
STEP19: exit
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
24
PROGRAM CODE:
#include<stdio.h>
#include<conio.h>
main( )
{ int month[12]={31,28,31,30,31,30,31,31,30,31,30,31};
int d,m,y,nd,nm,ny,ndays;
clrscr( );
printf("enter the date,month,year");
scanf("%d%d%d",&d,&m,&y);
ndays=month[m-1];
if(y<=1812 && y>2012)
{ printf("Invalid Input Year");
exit(0);
}
if(d<=0 || d>ndays)
{ printf("Invalid Input Day");
exit(0);
}
if(m<1 && m>12)
{ printf("Invalid Input Month");
exit(0);
}
if(m==2)
{ if(y%100==0)
{ if(y%400==0)
ndays=29;
}
else if(y%4==0)
ndays=29;
}
nd=d+1;
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
25
nm=m;
ny=y;
if(nd>ndays)
{ nd=1;
nm++;
}
if(nm>12)
{ nm=1;
ny++;
}
printf("\n Given date is %d:%d:%d",d,m,y);
printf("\n Next day‟s date is %d:%d:%d",nd,nm,ny);
getch( );
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
26
Test Report:
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
27
7. Design and develop a program in a language of your choice to solve the
triangle problem defined as follows: Accept three integers which are
supposed to be the three sides of a triangle and determine if the three values
represent an equilateral triangle, isosceles triangle, scalene triangle, or they
do not form a triangle at all. Derive test cases for your program based on
decision-table approach, execute the test cases and discuss the results.
ALGORITHM:
Step 1: Input a, b & c i.e three integer values which represent three sides of
the triangle.
Step 2: if (a < (b + c)) and (b < (a + c)) and (c < (a + b) then
do step 3
else
print not a triangle. do step 6.
Step 3: if (a=b) and (b=c) then
Print triangle formed is equilateral. do step 6.
Step 4: if (a ≠ b) and (a ≠ c) and (b ≠ c) then
Print triangle formed is scalene. do step 6.
Step 5: Print triangle formed is Isosceles.
Step 6: stop
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
28
PROGRAM CODE:
#include<stdio.h>
#include<ctype.h>
#include<conio.h>
#include<process.h>
int main()
{ int a, b, c;
clrscr();
printf("Enter three sides of the triangle");
scanf("%d%d%d", &a, &b, &c);
if((a<b+c)&&(b<a+c)&&(c<a+b))
{ if((a==b)&&(b==c))
{
printf("Equilateral triangle");
}
else if((a!=b)&&(a!=c)&&(b!=c))
{
printf("Scalene triangle");
}
else
printf("Isosceles triangle");
}
else {
printf("triangle cannot be formed");
}
getch();
return 0;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
29
Test Report:
Input data decision Table
RULES
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
C1: a < b + c
C2 : b < a + c
Conditions
C3 : c < a + b
C4 : a = b
C5 : a = c
C6 : b = c
a
1
: Not a triangle
a
2
: Scalene triangle
Actions
a3 : Isosceles triangle
a
4
: Equilateral triangle
a
5
: Impossible
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
30
8. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of decision
table-based testing, derive different test cases, execute these test cases and
discuss the test results.
ALGORITHM
Step 1: Input 3 integer numbers which represents number of Locks, Stocks
and Barrels sold.
Step 2: compute the total sales =(Number of Locks sold *45) + (Number of
Stocks sold *30) + (Number of Barrels sold *25)
Step 3: if a totals sale in dollars is less than or equal to $1000
then commission = 0.10* total Sales do step 6
Step 4: else if total sale is less than $1800
then commission1 = 0.10* 1000
commission = commission1 + (0.15 * (total sales – 1000))
do step 6
Step 5: else commission1 = 0.10* 1000
commission2 = commission1 + (0.15 * 800))
commission = commission2 + (0.20 * (total sales – 1800)) do
step 6
Step 6: Print commission.
Step 7: Stop.
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
31
PROGRAM CODE:
#include<stdio.h>
#include<conio.h>
int main()
{ int locks, stocks, barrels, t_sales, flag = 0;
float commission;
clrscr();
printf("Enter the total number of locks");
scanf("%d",&locks);
if ((locks <= 0) || (locks > 70))
{ flag = 1;
}
printf("Enter the total number of stocks");
scanf("%d",&stocks);
if ((stocks <= 0) || (stocks > 80))
{ flag = 1;
}
printf("Enter the total number of barrelss");
scanf("%d",&barrels);
if ((barrels <= 0) || (barrels > 90))
{ flag = 1;
}
if (flag == 1)
{ printf("invalid input");
getch();
exit(0);
}
t_sales = (locks * 45) + (stocks * 30) + (barrels * 25);
if (t_sales <= 1000)
{ commission = 0.10 * t_sales;
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
32
}
else if (t_sales < 1800)
{ commission = 0.10 * 1000;
commission = commission + (0.15 * (t_sales - 1000));
}
else
{ commission = 0.10 * 1000;
commission = commission + (0.15 * 800);
commission = commission + (0.20 * (t_sales - 1800));
}
printf("The total sales is %d \n The commission is %f",t_sales,
commission);
getch();
return;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
33
Test Report:
RULES
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
C1:
C2 :
Conditions
C3 :
C4 :
C5 :
C6 :
a1
:
a2
:
Actions
a3 :
a4
:
a5
:
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
34
9. Design, develop, code and run the program in any suitable language to
solve the commission problem. Analyze it from the perspective of dataflow
testing, derive different test cases, execute these test cases and discuss the
test results.
ALGORITHM
STEP 1: Define lockPrice=45.0, stockPrice=30.0, barrelPrice=25.0
STEP2: Input locks
STEP3: while(locks!=-1) „input device uses -1 to indicate end of data goto
STEP 12
STEP4:input (stocks, barrels)
STEP5: compute lockSales, stockSales, barrelSales and sales
STEP6: output(“Total sales:” sales)
STEP7: if (sales > 1800.0) goto STEP 8 else goto STEP 9
STEP8: commission=0.10*1000.0; commission=commission+0.15 * 800.0;
commission = commission + 0.20 * (sales-1800.0)
STEP9: if (sales > 1000.0) goto STEP 10 else goto STEP 11
STEP10: commission=0.10* 1000.0; commission=commission + 0.15 *
(sales-1000.0)
STEP11: Output(“Commission is $”, commission)
STEP12: exit
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
35
PROGRAM CODE:
#include<stdio.h>
#include<conio.h>
int main()
{ int locks, stocks, barrels, t_sales, flag = 0;
float commission;
clrscr();
printf("Enter the total number of locks");
scanf("%d",&locks);
if ((locks <= 0) || (locks > 70))
{ flag = 1;
}
printf("Enter the total number of stocks");
scanf("%d",&stocks);
if ((stocks <= 0) || (stocks > 80))
{ flag = 1;
}
printf("Enter the total number of barrelss");
scanf("%d",&barrels);
if ((barrels <= 0) || (barrels > 90))
{ flag = 1;
}
if (flag == 1)
{ printf("invalid input");
getch();
exit(0);
}
t_sales = (locks * 45) + (stocks * 30) + (barrels * 25);
if (t_sales <= 1000)
{ commission = 0.10 * t_sales;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
36
else if (t_sales < 1800)
{ commission = 0.10 * 1000;
commission = commission + (0.15 * (t_sales - 1000));
}
else
{ commission = 0.10 * 1000;
commission = commission + (0.15 * 800);
commission = commission + (0.20 * (t_sales - 1800));
}
printf("The total sales is %d \n The commission is %f",t_sales,
commission);
getch();
return;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
37
Test Report:
Case
Id
Description
Input Data
Expected
Output
Actual
Output
Comments
a
b
c
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
38
10. Design, develop, code and run the program in any suitable language to
implement the binary search algorithm. Determine the basis paths and using
them derive different test cases, execute these test cases and discuss the test
results.
ALGORITHM
Step 1: Input value of „n‟. Enter „n‟ integer numbers in array int mid;
Step 2: Initialize low = 0, high = n -1
Step 3: until ( low <= high ) do
mid = (low + high) / 2
if ( a[mid] == key )
then do Step 5
else if ( a[mid] > key )
then do
high = mid - 1
else
low = mid + 1
Step 4: Print unsuccessful search do step 6.
Step 5: Print Successful search. Element found at position mid+1.
Step 6: Stop.
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
39
PROGRAM CODE:
#include<stdio.h>
#include<conio.h>
int main()
{ int a[20],n,low,high,mid,key,i,flag=0;
clrscr();
printf("Enter the value of n:\n");
scanf("%d",&n);
if(n>0)
{ printf("Enter %d elements in ASCENDING order\n",n);
for(i=0;i<n;i++)
{ scanf("%d",&a[i]);
}
printf("Enter the key element to be searched\n");
scanf("%d",&key);
low=0;
high=n-1;
while(low<=high)
{ mid=(low+high)/2;
if(a[mid]==key)
{ flag=1;
break;
}
else if(a[mid]<key)
{ low=mid+1;
}
else
{ high=mid-1;
}
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
40
if(flag==1)
printf("Successful search\n Element found at Location
%d\n",mid+1);
else printf("Key Element not found\n");
}
else printf("Wrong input");
getch();
return 0;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
41
Test Report:
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
42
11. Design, develop, code and run the program in any suitable language to
implement the quicksort algorithm. Determine the basis paths and using
them derive different test cases, execute these test cases and discuss the test
results. discuss the test results.
PROGRAM CODE:
#include <stdio.h>
void swap ( int* a, int* b )
{ int t = *a;
*a = *b;
*b = t;
}
int partition (int arr[], int l, int h)
{ int x = arr[h];
int i = (l - 1),j;
for (j = l; j <= h- 1; j++)
{ if (arr[j] <= x)
{ i++;
swap (&arr[i], &arr[j]);
}
}
swap (&arr[i + 1], &arr[h]);
return (i + 1);
}
void quickSortIterative (int arr[], int l, int h)
{ int stack[10],p;
int top = -1;
stack[ ++top ] = l;
stack[ ++top ] = h;
while ( top >= 0 )
{ h = stack[ top-- ];
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
43
l = stack[ top-- ]
p = partition( arr, l, h );
if ( p-1 > l )
{ stack[ ++top ] = l;
stack[ ++top ] = p - 1;
}
if ( p+1 < h )
{ stack[ ++top ] = p + 1;
stack[ ++top ] = h;
}
}
}
int main()
{ int arr[20],n,i;
clrscr();
printf("Enter the size of the array");
scanf("%d",&n);
printf("Enter %d elements",n);
for(i=0;i<n;i++)
scanf("%d",&arr[i]);
quickSortIterative( arr, 0, n - 1 );
printf("Elements of the array are;");
for(i=0;i<n;i++)
printf("%d",arr[i]);
getch();
return 0;
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
44
Test Report:
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
45
12. Design, develop, code and run the program in any suitable language to
implement an absolute letter grading procedure, making suitable
assumptions. Determine the basis paths and using them derive different test
cases, execute these test cases and discuss the test results.
PROGRAM CODE:
#include<stdio.h>
main()
{ float kan,eng,hindi,maths,science, sst,avmar;
printf("Letter Grading\n");
printf("SSLC Marks Grading\n");
printf("Enter the marks for Kannada:");
scanf("%f",&kan);
printf("enter the marks for English:");
scanf("%f",&eng);
printf("enter the marks for Hindi:");
scanf("%f",&hindi);
printf("enter the marks for Maths");
scanf("%f",&maths);
printf("enter the marks for Science:");
scanf("%f",&science);
printf("enter the marks for Social Science:");
scanf("%f",&sst);
avmar=(kan+eng+hindi+maths+science+sst)/6.25;
printf("the average marks are=%f\n",avmar);
if((avmar<35)&&(avmar>0))
printf("fail");
else if((avmar<=40)&&(avmar>35))
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
46
printf("Grade C");
else if((avmar<=50)&&(avmar>40))
printf("Grade C+");
else if((avmar<=60)&&(avmar>50))
printf("Grade B");
else if((avmar<=70)&&(avmar>60))
printf("Grade B+");
else if((avmar<=80)&&(avmar>70))
printf("Grade A");
else if((avmar<=100)&&(avmar>80))
printf("Grade A+");
}
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
47
Test Report:
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
48
Viva Questions
1. What is the MAIN benefit of designing tests early in the life
cycle?
It helps prevent defects from being introduced into the code.
2. What is the purpose of exit criteria?
The purpose of exit Criteria is to define when a test level is
completed.
3. What determines the level of risk?
The likelihood of an adverse event and the impact of the event
determine the level of risk.
4. When is used Decision table testing?
Decision table testing is used for testing systems for which the
specification takes the form of rules or cause-effect combinations.
In a decision table the inputs are listed in a column, with the
outputs in the same column but below the inputs. The remainder
of the table explores combinations of inputs to define the outputs
produced.
5. What is beta testing?
Testing performed by potential customers at their own locations.
6. We use the output of the requirement analysis, the
requirement specification as the input for writing …
User Acceptance Test Cases
7. What are the benefits of Independent Testing?
Independent testers are unbiased and identify different defects at
the same time.
8. In a REACTIVE approach to testing when would you expect
the bulk of the test design work to be begun?
The bulk of the test design work begun after the software or
system has been produced.
9. What are the phases of a formal review
In contrast to informal reviews, formal reviews follow a formal
process. A typical formal review process consists of six main
steps: Planning, Kick-off, Preparation, Review meeting,
Rework,Follow-up.
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
49
10. What is an equivalence partition (also known as an
equivalence class)?
An input or output ranges of values such that only one value in
the range becomes a test case.
11. What is negative and positive testing?
A negative test is when you put in an invalid input and receives
errors. While a positive testing, is when you put in a valid input
and expect some action to be completed in accordance with the
specification.
12. What is the purpose of a test completion criterion?
The purpose of test completion criterion is to determine when to
stop tes
13. What is the difference between re-testing and regression
testing?
Re-testing ensures the original fault has been removed;
regression testing looks for unexpected side effects.
14. Could reviews or inspections be considered part of testing?
Yes, because both help detect faults and improve quality.
15. How much testing is enough?"
The answer depends on the risk for your industry, contract and
special requirements.
16. Which of the following is the main purpose of the integration
strategy for integration testing in the small?
The main purpose of the integration strategy is to specify which
modules to combine when and how many at once.
17. What is test coverage?
Test coverage measures in some specific way the amount of
testing performed by a set of tests (derived in some other way,
e.g. using specification-based techniques). Wherever we can
count things and can tell whether or not each of those things has
been tested by some test, then we can measure coverage.
18. What is called the process starting with the terminal
modules?
Bottom-up integration
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
50
References:
1. Paul C. Jorgensen: Software Testing, A Craftsman’s Approach,3rd
Edition, Auerbach Publications,2008
2. Mauro Pezze, Michal Young :Software Testing and Analysis- Process,
Principles and Techniques, Wiley India,2008
3. https://www.guru99.com/software-testing-interview-questions.html
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
51
TER – VI Subject Code 15ISL67 IA Marks 20 Number of Lecture Hours/Week 01I +
02P Exam Marks 80 Total Number of Lecture Hours 40 Exam Hours 03 CREDITS – 02
Course objectives: This course will enable students to • Analyse the requirements for the
given problem statement • Design and implement various solutions for the given problem
• Employ various design strategies for problem solving. • Construct control flow graphs
for the solution that is implemented • Create appropriate document for the software
artefact Description (If any): Design, develop, and implement the specified algorithms for
the following problems using any language of your choice under LINUX /Windows
environment. Lab Experiments: 1. Design and develop a program in a language of your
choice to solve the triangle problem defined as follows: Accept three integers which are
supposed to be the three sides of a triangle and determine if the three values represent an
equilateral triangle, isosceles triangle, scalene triangle, or they do not form a triangle at
all. Assume that the upper limit for the size of any side is 10. Derive test cases for your
program based on boundary-value analysis, execute the test cases and discuss the results.
2. Design, develop, code and run the program in any suitable language to solve the
commission problem. Analyze it from the perspective of boundary value testing, derive
different test cases, execute these test cases and discuss the test results. 3. Design,
develop, code and run the program in any suitable language to implement the NextDate
function. Analyze it from the perspective of boundary value testing, derive different test
cases, execute these test cases and discuss the test results. 4. Design and develop a
program in a language of your choice to solve the triangle problem defined as follows:
Accept three integers which are supposed to be the three sides of a triangle and determine
if the three values represent an equilateral triangle, isosceles triangle, scalene triangle, or
they do not form a triangle at all. Assume that the upper limit for the size of any side is
10. Derive test cases for your program based on equivalence class partitioning, execute
the test cases and discuss the results. 5. Design, develop, code and run the program in any
suitable language to solve the commission problem. Analyze it from the perspective of
equivalence class testing, derive different test cases, execute these test cases and discuss
the test results. 6. Design, develop, code and run the program in any suitable language to
implement the NextDate function. Analyze it from the perspective of equivalence class
value testing, derive different test cases, execute these test cases and discuss the test
results. 7. Design and develop a program in a language of your choice to solve the
triangle problem defined as follows: Accept three integers which are supposed to be the
three sides of a triangle and determine if the three values represent an equilateral triangle,
isosceles triangle, scalene triangle, or they do not form a triangle at all. Derive test cases
for your program based on decision-table approach, execute the test cases and discuss the
results. 8. Design, develop, code and run the program in any suitable language to solve
the commission problem. Analyze it from the perspective of decision table-based testing,
derive different test cases, execute these test cases and discuss the test results. 9. Design,
develop, code and run the program in any suitable language to solve the commission
problem. Analyze it from the perspective of dataflow testing, derive different test cases,
execute these test cases and discuss the test results. 10. Design, develop, code and run the
program in any suitable language to implement the binary search algorithm. Determine
the basis paths and using them derive different test cases, execute these test cases and
Software Testing Laboratory-15ISL67 VI Sem.ISE
Dept.,of ISE,CIT,Gubbi
52
discuss the test results. 11. Design, develop, code and run the program in any suitable
language to implement the quicksort algorithm. Determine the basis paths and using them
derive different test cases, execute these test cases and discuss the test results. 12. Design,
develop, code and run the program in any suitable language to implement an absolute
letter grading procedure, making suitable assumptions. Determine the basis paths and
using them derive different test cases, execute these test cases and discuss the test results
Study Experiment / Project: 1. Design, develop, code and run the program in any suitable
language to solve the triangle problem. Analyze it from the perspective of dataflow
testing, derive different test cases, execute these test cases and discuss the test results. 2.
Design, develop, code and run the program in any suitable language to solve the Nextdate
problem. Analyze it from the perspective of decision table-based testing, derive different
test cases, execute these test cases and discuss the test results. Course outcomes: The
students should be able to: • List out the requirements for the given problem • Design and
implement the solution for given problem in any programming language(C,C++,JAVA) •
Derive test cases for any given problem • Apply the appropriate technique for the design
of flow graph. • Create appropriate document for the software artefact. Conduction of
Practical Examination: 1. All laboratory experiments are to be included for practical
examination. 2. Students are allowed to pick one experiment from the lot. 3. Strictly
follow the instructions as printed on the cover page of answer script for breakup of marks
4. Procedure + Conduction + Viva: 35 + 35 + 10 (80) 5. Change of experiment is allowed
only once and marks allotted to the procedure part to be made zero
