Surface Weather Observation XML
(SW-OB-XML)
-Client User Guide-
February 8, 2019
Version 8.2
Data
Management
Framework
Cadre de
Gestion des
Données
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 2 of 111
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 3 of 111
Table of Contents
1. DOCUMENT INFORMATION ................................................................................................................................. 5
1.1 HISTORY .................................................................................................................................................................... 5
1.2 FILENAME & LOCATION ........................................................................................................................................... 11
1.3 REFERENCED DOCUMENTS ....................................................................................................................................... 11
2. INTRODUCTION ...................................................................................................................................................... 12
2.1 OVERVIEW ............................................................................................................................................................... 12
2.2 PURPOSE AND SCOPE ............................................................................................................................................... 13
2.3 INTENDED AUDIENCE ............................................................................................................................................... 14
3. DATA STANDARDIZATION .................................................................................................................................. 15
3.1 STANDARDIZATION OF INCOMING DATA BY THE DMS ............................................................................................. 15
3.2 STANDARDIZATION FOR THE SWOB ........................................................................................................................ 15
3.2.1 Element Short Labels: .................................................................................................................................... 15
3.2.2 Units: ............................................................................................................................................................. 16
3.2.3 Codes: ............................................................................................................................................................ 17
4. SW-OB-XML FORMAT AND STRUCTURE ........................................................................................................ 19
4.1 OVERVIEW ............................................................................................................................................................... 19
4.2 STRUCTURAL ORGANIZATION OF SWOB ................................................................................................................. 20
4.3 SAMPLE SWOB ....................................................................................................................................................... 23
4.4 TAXONOMY AND URI .............................................................................................................................................. 27
4.5 QUALITY ASSESSMENT FLAG ................................................................................................................................... 30
4.6 DATA FLAG .............................................................................................................................................................. 33
4.7 MULTIPLICITY .......................................................................................................................................................... 34
5. DATASETS ................................................................................................................................................................ 35
5.1 OVERVIEW ............................................................................................................................................................... 35
5.2 DATA ELEMENT TERMINOLOGY ............................................................................................................................... 35
5.2.1 Wind ............................................................................................................................................................... 35
5.2.2 Cloud Amount/Cover ..................................................................................................................................... 36
5.2.3 Precipitation and Rainfall ............................................................................................................................. 37
5.2.4 Station elevation ............................................................................................................................................ 37
5.3 LEGACY MSC & PARTNER MANNED (WINIDE/MIDS) ........................................................................................... 38
5.4 DND HWOS ............................................................................................................................................................ 40
5.5 MSC & PARTNER AWOS (RA MESSAGES) .............................................................................................................. 41
5.6 DND AWOS ............................................................................................................................................................ 43
5.7 NAV CANADA HWOS .............................................................................................................................................. 45
5.8 NAV CANADA AWOS .............................................................................................................................................. 47
5.9 MSC & PARTNER SURFACE WEATHER NETWORK (CAMPBELL SCI. CA MESSAGES) ................................................. 49
5.10 PANAM – MINUTELY MSC & PARTNER SURFACE WEATHER NETWORK - COMPACT ........................................ 53
5.11 OPP MOORED BUOY ........................................................................................................................................... 55
5.12 BC MINISTRY OF TRANSPORTATION & INFRASTRUCTURE (BC-TRAN) ............................................................. 56
5.13 BC WILDFIRE MANAGEMENT BRANCH (BC-FLNR-WMB) ............................................................................... 58
5.14 BC MINISTRY OF ENVIRONMENT AND CLIMATE CHANGE STRATEGY-AIR QUALITY (BC-ENV-AQMET) ......... 58
5.15 BC MINISTRY OF ENVIRONMENT AND CLIMATE CHANGE STRATEGY-SNOW WEATHER (BC-ENV-SNOWWX) . 60
6. APPENDICES ............................................................................................................................................................ 62
6.1 GLOSSARY ............................................................................................................................................................... 62
6.2 SHORT LABEL ABBREVIATIONS ............................................................................................................................... 65
6.3 UNITS OF MEASURE ................................................................................................................................................. 74
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 4 of 111
6.4 UNIT CONVERSIONS ................................................................................................................................................. 77
6.5 STANDARD CODE TABLES ........................................................................................................................................ 79
6.5.1 buoy_type ....................................................................................................................................................... 79
6.5.2 ceiling_type .................................................................................................................................................... 81
6.5.3 data_flags ...................................................................................................................................................... 81
6.5.4 obscuring_phenomena ................................................................................................................................... 82
6.5.5 operating_agency .......................................................................................................................................... 84
6.5.6 precipitation_measurement_method .............................................................................................................. 85
6.5.7 present_weather ............................................................................................................................................. 86
6.5.8 rapid_pressure_change ............................................................................................................................... 103
6.5.9 report_type ................................................................................................................................................... 104
6.5.10 sky_condition .......................................................................................................................................... 106
6.5.11 station_type ............................................................................................................................................. 108
6.5.12 tendency_characteristic .......................................................................................................................... 109
6.5.13 total_cloud_amount ................................................................................................................................ 109
6.5.14 wind_gust_squall_indicator .................................................................................................................... 111
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 5 of 111
1. Document Information
1
1.1 History
Author
Date
Ver.
Remarks
Thinesh Sornalingam
June 7, 2012
1.0d
Initial draft
AbdulAziz Raouf
June 8, 2012
1.1d
Added in Section 4 Datasets
Thinesh Sornalingam
June 11, 2012
1.2d
Added units of measures and conversions
Dale Boudreau
June 13, 2012
1.3d
1st overall edit of whole document
Dale Boudreau
June 19, 2012
1.4d
2nd overall edit of whole document
Dale Boudreau
June 20, 2012
1.5d
Changed max_vis to vis for RA XML sample and
mapping table
Dale Boudreau
June 21, 2012
1.6d
Minor tweaks to data set mapping tables. Dropped
vis_code and horizontal_visibility code table
Dale Boudreau
June 25, 2012
1.7d
NC-AWOS: cld_cvr_# becomes sum_cld_cvr_#,
added ‘sum’ to Appendix 6.2
Dale Boudreau
June 26, 2012
1.8d
Updated RA XML example (Sect. 4.3)
Dale Boudreau
June 28, 2012
1.9d
Changed references to External XML and E-ML to
“SW-OB-XML” or “SWOB”. Added details (table)
on incoming code source meanings in section 3.2.3.
Abdulaziz Raouf
June 29,2012
1.9d
Updated NCHWOS dataset table to include full list
of elements present section 5.5
Dale Boudreau
July 9, 2012
2.0d
Changed rpt_typ to stn_typ for NC-AWOS (code
table 002196).
Dale Boudreau
July 10, 2012
2.1d
Added clg_hgt to WinIDE and RA mapping tables.
Dale Boudreau
July 24, 2012
2.2d
Edited XML structure example. New RA sample.
Section 4.2 part D added info in “MSNG”.
Changed avg_vis_mt50-60 to just vis for NC-
AWOS.
Dale Boudreau
July 27, 2012
2.3d
Removed ceiling height (clg_hgt) from RA dataset
Dale Boudreau
July 30, 2012
2.4d
For NC-HWOS dataset, added prsnt_wx_# and
changed cld_amt_code to cld_amt_code_#. Also
did global search from std_code_source and
replaced with std_code_src.
Tahreem Ali
July 30, 2012
2.5d
Removed indexed temperatures for CA
(air_temp_#, min_air_temp_pst1hr_#,
max_air_temp_pst1hr_#) and duplicate row for
pcpn_amt_pst1hr
Abdulaziz Raouf
July 30, 2012
2.6d
Changed label name and description for NCAWOS
element wnd_dir_10m_mt50-60_max_spd to
wnd_dir_10m_pst1hr_max_spd
Dale Boudreau
August 9, 2012
2.7d
Added std code 88 to report_type code table (from
1
For more details on additions and changes to the actual SWOB-ML product, please refer to the Release Notes cited in
Section 1.3
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 6 of 111
incoming of 126 from BUFR58 descriptor 001196).
Added icao_stn_id to WinIDE and RA.
Dale Boudreau
August 29, 2012
2.8d
Added word “snow” to descriptions of codes 83, 84
for present_weather code table.
Dale Boudreau
August 31, 2012
3.0
Final Version
Dale Boudreau
October 25, 2012
3.2
Updated description for codes 46, 47 in table
total_cloud_amount
Dale Boudreau
December 21, 2012
4.0
Multiple changes made for the DMS 2.3.12.1
release deployed on Data Depot January 15, 2013.
Changes are as follows (see Release Notes for more
detail):
WinIDE
tot_cld_amt – changed units from 1/10 to %
tot_cld_opcty – changed units from 1/10 to %
CA Added the following elements:
avg_cum_pcpn_gag_wt_fltrd_55-60
snow_dpth_#
logr_panl_temp
max_batry_volt_pst1hr
min_batry_volt_pst1hr
hdr_fwd_pwr
hdr_refltd_pwr
hdr_suply_volt
hdr_oscil_drft
Dale Boudreau
February 14, 2013
5.0
Multiple changes made for the DMS 2.4.0 release
deployed on Data Depot early March, 2013.
Changes are as follows (see Release Notes for more
detail):
RA
Element cld_amt_code_# wasn’t being reported
for clear sky because of a change to the
decoded code value from ‘CLR BLO 100’ to
‘CLR BLO’. The code substitution XML was
updated to accommodate this code change and
resolve this issue.
Added the following elements:
max_air_temp_pst6hrs
min_air_temp_pst6hrs
max_air_temp_pst24hrs
min_air_temp_pst24hrs
CA Added the following elements:
pcpn_amt_pst3hrs
pcpn_amt_pst6hrs
pcpn_amt_pst24hrs
max_air_temp_pst6hrs
min_air_temp_pst6hrs
max_air_temp_pst24hrs
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 7 of 111
min_air_temp_pst24hrs
‘air_temp_#’ added User Guide table 5.7 as
well as an explanation of how it may appear
‘snw_dpth_#’ added User Guide table 5.7 as
well as an explanation of how it may appear
NC-AWOS
Added element cld_amt_code_#
Fixed label name for the following elements by
appending an ‘s’ at the end (i.e. hr to hrs):
pcpn_amt_pst3hr
pcpn_amt_pst6hr
pcpn_amt_pst24hr
max_air_temp_pst6hr
min_air_temp_pst6hr
max_air_temp_pst24hr
min_air_temp_pst24hr
Changed ‘wmo_id’ to ‘wmo_synop_id’, and
changed ‘max_10m_wnd_gst_ spd_mt50-60’
to ‘max_wnd_gst_spd_10m_mt50-60
NC-HWOS
Added elements:
cor
pcpn_amt_pst6hrs
WinIDE
Changed ‘wmo_id’ to ‘wmo_synop_id’
Dale Boudreau
February 28, 2013
5.1
Modified code descriptions for
obscuring_phenomena (table 6.5.2) codes 28 and 34
to deal with specific meanings for NC-HWOS.
Dale Boudreau
March 18, 2013
5.2
DMS Release 2.4.1: Added the new element
max_vis_pst1hr to CA dataset. More modifications
to code descriptions for obscuring_phenomena
(table 6.5.2) codes 5, 15, 29, and 46 to deal with
specific meanings for NC-HWOS.
Dale Boudreau
May 7, 2013
5.3
DMS Release 2.4.2: Added cld_amt_code_# to the
NC-AWOS table (Sect. 5.6)
Dale Boudreau
July 15, 2013
6.0
DMS Release 2.4.2: Added NC-AWOS to
“station_type” code table (6.5.8) as code 12, and
added codes 17, 18. Removed “product_status”
code table from the appendix as it was not
referenced by any SWOB elements in any of the
networks. New codes (86-98) added to bottom of
“report_type” code table (6.5.6). Updated code
descriptions in tables 6.5.7, 6.5.8, and 6.5.10.
element additions/modifications to the various
networks:
WinIDE
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 8 of 111
Added the following element:
clg_hgt
NC-HWOS
Added 3 additional identification elements:
clim_id
msc_id
rtp_typ
Learned that the following elements have an
incorrect label since they should be for a 24
hour period. Therefore changed the labels of
the following elements to reflect that this is a
24 hour peak wind speed, not a 1-hour peak as
the SWOB label originally indicated:
Changed
max_pk_wnd_spd_10m_pst1hr to
max_pk_wnd_spd_10m_pst24hrs
wnd_dir_10m_pst1hr_pk_spd to
wnd_dir_10m_pst24hrs_pk_spd
NC-AWOS
Added the following identification element:
rtp_typ
CA
Removed duplicated element rows from Table 5.7.
Added the following element:
avg_wnd_spd_pcpn_gag_mt58-60
Dale Boudreau
August 13, 2014
6.1
CA
Added additional elements:
avg_globl_solr_radn_pst1hr
tot_globl_solr_radn_pst1hr
avg_wnd_spd_pcpn_gag_mt50-60
data_avail (future release)
Removed the following element:
stn_id (last 4 digits of wmo_synop_id)
avg_wnd_spd_pcpn_gag_mt58-60
NC-AWOS
Added element stn_elev
Removed the following elements (always missing):
pcpn_amt_pst3hrs
pcpn_amt_pst24hrs
GENERAL
Removed duplicate element rows from
Table 5.7
Added code table for
wind_gust_squall_indicator
Changed descriptions for codes 13, 10 in
station_type code table
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 9 of 111
Tahreem Ali /
Dale Boudreau
March 24, 2014
7.0
Added the following new datasets:
PanAM – MSC & Partner (CA messages)
PanAM – MSC & Partner (Compact
messages)
PanAM – MSC & Partner (ATMOS
messages)
Updated the following code tables:
station_type
report_type
present_weather
Added the following code table:
buoy_type
Reflected data changes:
removed T-12 from SWOBs
removed pcpn_amt_pst3hrs and
pcpn_amt_pst24hrs from NC-AWOS
SWOBs (not observed)
Changed precision of Pressure elements to
1 decimal place
Changed precision of snow depth
elements to 0 decimal places
Changed precision of all temperature
elements to 1 decimal place
Changed precision of relative humidity to
0 decimal places
Changed precision of all
precipitation/rainfall elements to 1 decimal
place
Many editorial changes:
Many minor editorial changes
Added text to sections 2.1, 2.3, 4.4, 5.1,
5.2.1,
Added new sections: 5.2.3, 5.2.4,
Modified Qa flag descriptions in section
4.5
Added new data set descriptions and
element tables (sections 5.9 – 5.22
Added additional glossary items
Added additional short label descriptions
Added additional units and conversions
Dale Boudreau
September 15, 2015
7.1
Added new units to section 6.3
Tahreem Ali
August 11, 2016
7.1
Added the following new datasets:
DND AWOS
DND HWOS
Updated short labels for the following datasets:
CA
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 10 of 111
Removed PanAm datasets except for CA-Compact
Updated taxonomy sections to account for new
datasets (DND)
Updated Qa section to remove the qa summary = 20
rule
Updated CA table to account for new labels
(pstXmts)
Added section on multiple sensors (Multiplicities)
Tahreem Ali
July 27, 2018
8.0
Updated all section with Generic SWOB
taxonomies, output, rules
Updated Sample SWOB section with new example
Added generic swob labels to remaining datasets
(NavCan, RA, WinIDE, CA Minutely)
Tahreem Ali
November 6, 2018
8.1
Update document to include new dataset: OPP
Marine Buoy
Added section on data_flag
Updated code tables: total_cloud_amount,
report_type, buoy_type
Updated units: 0.01in
Updated WinIDE dataset (Section 5.3) with new
elements: max_pk_wnd_spd_10m_pst24hrs,
wnd_dir_10m_pst24hrs_pk_spd,
max_pk_wnd_tm_pst24hrs, snw_dpth,
pcpn_amt_pst6hrs, pcpn_amt_pst24hrs,
avg_wnd_dir_10m_pst10mts,
avg_wnd_spd_10m_pst10mts
Tahreem Ali
February 8, 2019
8.2
Added BC datasets:
BC Forestry
BC Tran
BC SnowWx
BC AQMet
Added code table:
precipitation_measurement_method
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 11 of 111
1.2 Filename & Location
Approved (public) Version:
http://dd.weatheroffice.gc.ca/observations/doc/SWOB-ML_Product_User_Guide_v8.2_e.pdf
Current Draft (internal version):
http://ecollab.ncr.int.ec.gc.ca/org/1275692/wem/MS_lib/DMS_SW-OB-
ML_Product_User_Guide_v8.2_Public_e_Final.doc
1.3 Referenced Documents
Document
Author
Version
DMF External Met-ML Specification
http://ecollab.ncr.int.ec.gc.ca/org/1275692/wem/MS_lib/DMFExterna
lMet-MLspecification.doc
Dale Boudreau,
Thinesh Sornalingam,
Abdulaziz Raouf
1.1
Taxonomy Documentation
Ioanne Carlo Bugash
0.4.1d
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 12 of 111
2. Introduction
2.1 Overview
The creation of a product for surface weather observations has been undertaken by the Data
Management Initiative (DMI) project to provide the Metrological Service of Canada (MSC) and
external clients with a concise, user-friendly, easy to read product containing typical hourly surface
weather data from MSC and partner atmospheric monitoring networks.
These products will be generated by applications within the Data Management System (DMS). The
DMS is collection of a real-time data acquisition, decoding, standardization, quality assessment (Qa)
and product generation components for observation, forecast, and warning data. It is to become
MSC's primary disseminator of meteorological data to internal and external clients.
There are multiple phases or processing stages within DMS that incoming raw data passes through.
Each phase has an associated XML output. In the raw phase, the incoming messages are in their
original form (e.g. ASCII, BUFR, etc.). Then they are converted into a “parsed” product (typically an
XML). In the parsed phase, the data has not yet been standardized or fully "decoded". The parsed
phase prepares the data to be decoded. The parsed phase is optional in the sense that not all data must
pass through it. In some cases, the data proceeds straight to the decode phase from the raw phase. In
the decode phase, the data is standardized (i.e. mapped to a standard classification, element definition,
and name). The data emerges as a decoded XML product following the completion of its passage
through the decode phase. The decoded XML is a standards-based format, which is then put through
any number of enhanced, quality assessment and/or product generation (PG) phases to add further
value and meet client requirements. The Surface Weather Observation XML product (SW-OB-XML)
is the result of the PG phase. The SW-OB-XML is in a basic XML format patterned after the DMS
internal Met-ML format. The SW-OB-XML will be referred to by the condensed acronym ‘SWOB’
hereafter in this document. The diagram at the end of section 2.1 captures this flow for selected
networks.
As opposed to the more comprehensive DMS decoded Met-ML products, the SWOB is a simplified
XML product that focuses on core elemental data without the clutter and complexity of auxiliary
content such as non-critical metadata, and detailed Qa results. To the extent possible, this information
has been captured in a short element label and an optional qualifier to indicate a summary of any Qa.
Although the SWOB XML is intended for machine-to machine data transmission, the format and
clarity of this self-descriptive format is easily human-readable without any specific training or
knowledge of markup languages. However, for clients needing to interact with and display data over
long intervals or comparing observations from multiple stations geospatially, the use tools such as
XML parsers, graphical displays and GIS is advisable.
There are many different streams of the SWOB product, each containing data from the following
networks (a short reference name is to the right of the arrow):
1. Legacy MSC & Partner Manned aviation weather stations using the WinIDE or MIDS interface WinIDE
2. DND HWOS DND HWOS
3. Legacy MSC & Partner AWOS aviation weather stations RA
4. DND AWOS DND AWOS
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 13 of 111
5. Nav Canada HWOS aviation weather stations NC-HWOS
6. Nav Canada AWOS aviation weather stations NC-AWOS
7. MSC & Partner public surface weather stations using Campbell Scientific data loggers CA
7.1. Minutely data sets supporting the PanAm Games:
- MSC Compact stations COMPACT-minutely
8. OPP Moored buoy weather stations OPP
9. BC Ministry of Transportation weather stations BC-TRAN
10. British Columbia Wildfire Management Branch (i.e. BC Forestry) weather stations BC-FLNR-WMB
11. BC Ministry of Envrionment Air Quality Meteorological weather stations BC-ENV-AQMet
12. BC Ministry of Envrionment Snow weather stations BC-ENV-SnowWx
Each dataset product can be uniquely identified via its URI (will be discussed in more detail in Section
4.4).
During the production of a SWOB, the following tasks are carried out:
Incoming DMS element packages are assigned an abbreviated label
Unit conversion from incoming units to standard units, and if necessary, rounded to a given
precision to trim insignificant digits resulting from some unit conversions.
If the incoming element is a numeric code or a text value from a list of controlled vocabulary
(so in effect a code), then code substitution is performed to map to a DMS standard code.
An optional quality assessment (Qa) summary flag (using incoming ‘native’ and DMS quality
assessments whenever available) may be attached to applicable elements.
2.2 Purpose and Scope
One of the main purposes of the SW-OB-XML is to offer a replacement for much of the content
traditionally found in the legacy SA (surface analysis) product still being used within MSC, although
officially it was to have been retired years ago. Although the SWOB will not capture all of the SA’s
content, it will include the most sought-after hourly surface weather observation elements and any
elements pertaining to longer time frames. Some of the more subtle and obscure elements contained in
the SA will be excluded from the initial offering of the SWOB. Clients requiring specific aviation,
synoptic, or marine data may be better served acquiring the METAR or SYNOP products.
Meanwhile, additional elements not present in SA will also be available in the SWOB.
As mentioned above, there are many streams of the SWOB product, each pertaining to a specific
network. Each product will be accessible via its own URI within the DMS, or possibly a file system
containing the XML files referenced using a filename (e.g. CMC’s DataDepot).
The observation elements included in the majority of SWOBs are from these basic observation groups,
although some data sets have other groups such as radiation, wave, etc:
present weather
sky condition
visibility
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 14 of 111
pressure
wind
temperature
humidity
precipitation
The format of this product is XML. It will be generated operationally by MSC's Data Management
System (DMS) at CMC in Montreal. It will be produced in real-time from the incoming raw data of
each dataset. It will be encoded in a standards based XML, which conforms to global meteorological
observation conventions (discussed in detail in Section 4).
In addition to the elemental data from the groups indicated above, the SWOB may also contain
optional quality assessment (Qa) information in the form of a summary quality flag attached to each
element, whenever available. This flag's value is computed by considering any incoming Qa
performed on the element at the source (so-called “Native QC”), any Qa conducted in-house by the
DMS, or a combination of the two. The absence of a Qa summary flag on an element in the SWOB
indicates the quality is unknown.
The SWOB is a very condensed and convenient product of hourly observational data, as opposed to
the fuller and more comprehensive decoded XMLs being generated by DMS for the listed datasets.
Those clients requiring full element definitions, full quality assessments, etc., should gain access to the
DMS decoded, or decoded_enchanced, products of each dataset.
2.3 Intended Audience
Any clients interested in hourly surface weather data will find the SWOB product attractive due to its
content, simplicity and compactness. Most clients currently using the legacy SA format should also
find this product a suitable replacement given it has the majority of the elements in a clear format and
may have additional content which could never be encoded using the SA format. Clients who would
like quick and easy access to MSC data from the DMS, will also generally benefit from the SW-OB-
XML product, especially given that data viewing and access tools are under development in the DMS.
This version of the User Guide is intended for internal users within Environment Canada, as some
data sets described herein are not available on the publicly accessible CMC DD (DataDepot) site, but
rather only on the DDi (internal). The non-public SWOBs are either third party data sets that have as
part of their data sharing agreements restrictions on data usage or distribution, or are Beta data sets
that have not completed user acceptance testing.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 15 of 111
3. Data Standardization
3.1 Standardization of incoming data by the DMS
The DMS decodes and processes data from many networks. The same element may have a variety of
different names across the input data sets. For example, air temperature may be called dry-bulb
temperature, temperature, temp, ambient temperature, etc. The DMS standardizes elements names so
they may be more easily inter-compared, quality assessed, and extracted. Furthermore, the elements
may have optional qualifiers assigned to them to covey important metadata. Below is an example of
how a particular wind speed from MSC networks is elementalized by the DMS and stored in XML
format:
- <element group="wind" name="wind_speed" orig-name="011012" uom="m/s" value="0.0">
<qualifier group="element" name="statistical_significance" uom="unitless" value="average" />
<qualifier group="element" name="time_displacement" uom="min" value="-2" />
<qualifier group="element" name="time_duration" uom="min" value="2" />
<qualifier group="element" name="vertical_displacement" uom="m" value="10" />
</element>
The above “standard element package” would be applied consistently across the networks and look as
the example above for cases where the incoming element is an average wind speed over the last 2
minutes of the hour and a height of 10 metres.
To avoid conversion and rounding errors, all incoming codes and units are left as-is. Such operations
are typically reserved for product generators, datamarts or display tools, just as the data leaves the
DMS for client use.
3.2 Standardization for the SWOB
The SWOB product generator needs to ingest data from many networks to make one product where
the element names, units and code tables are consistent. To make the SWOB as concise as possible
and remove any remaining element description variations in the DMS decoded output, a “short label”
was devised to encapsulate all the critical element-defining metadata into one phrase. Furthermore, all
the various unit and code variations for identical elements across the networks were handled by
converting to DMS “standard units” and “standard codes”.
3.2.1 Element Short Labels:
Critical element-defining metadata such as data type, element name, statistical significance, time
period displacement, time period duration, height/depth, index, etc., have been used to devise a “short
label” for each DMS element package. For example, the element package shown in Section 3.1 would
have the short label of “avg_wnd_spd_10m_pst2mts”. For the element name portion of the short label,
the name as it appears in the original DMS decoded element has been abbreviated using the
abbreviation glossary in Appendix 6.2. The length of these labels has been kept to a minimum and
special characters and spaces have been avoided so that the labels may also be used as column names
in database tables and meet the most stringent of requirements.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 16 of 111
3.2.2 Units:
All element packages have a standard element assigned by the DMS based on the data class (e.g.
velocity, temperature, azimuth, pressure, etc.), although some variations exist for certain elements
within a class. For example, most pressure-related elements will have a DMS standard unit of hPa, but
in the case of altimeter, the standard unit is inHg since it is used by a specific client community and in
practically all cases measured and used in that unit. Examples of typical standard units for some
classes are:
precipitation amount = mm
wind speed = km/h
pressure = hPa
visibility = km
height = m
temperature = °C
The conversion to DMS standard units is only done at the last possible moment, typically when data
leaves the DMS via product generators, like the one that creates the SWOB, or during the population
of custom datamarts and display tools where client requirements need to be satisfied. The DMS
standard units will meet the majority of client needs, but inevitably some clients will have different
preferences and will need to do some conversions. To assist in this, Appendix 6.4 has a list of unit
conversions so clients can see what was used to convert incoming units to DMS standard units for a
given element, or to apply client-side conversions. The data set tables in Section 5 show the incoming
uom (unit of measure) and the standard units they were converted to. As well, the rounding precision
is given where the value represents the number of digits after the decimal (e.g. 2 would represent
0.01). A value of 0 represents integer values. The intent is to remove insignificant digits as a result of
a unit conversion. To avoid giving the appearance of extra precision that was not intended, the
following rules were applied:
In the element mappings the following convention is used to represent precision:
0 = whole number
1 = one decimal digit = 0.1
2 = two decimal digits = 0.01
3 = three decimal digit = 0.001
…
Mathematical rounding precision only applies to numerical values and for elements a precision is
indicated in the Precision column (see Section 5). For instance if the decoded value = 5.67 and the
Rounding Precision is 1, then the SWOB value = 5.7. If on the other hand the decoded value has a
lower precision than what is specified for that element in the mappings, then preserve the decoded
value as-is. For example, if a decoded value or unit conversion = 5, Precision = 1 (i.e. 0.1), then
SWOB value = 5.
The following page has some examples of rounding to a specified precision:
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 17 of 111
Decoded Value
Rounding Precision
External Element Value
12.3
0 (to the nearest whole number)
12
23.3
2 (two decimal digits)
23.3 (decoded value precision is less than
requested precision, so preserve decoded
value as-is)
45.12346666666
6 (six decimal digits)
45.123467
23.549
1 (one decimal digit)
23.5 (given the requested precision is 1
decimal digit, one needs to look at the digit
immediately following it for rounding (4). As
a general rule: if precision = x, then always
look at x * 10-1 to carry out rounding)
17.6
0
18
3.2.3 Codes:
As with units, the incoming code values are preserved as-is after DMS decoding, with the code table
source and type (i.e. name) cited. Prior to the creation of the SWOB, incoming code tables are left in
their original form. The source of these tables can be any of the following:
Incoming
code-src
Description
Documentation Source
Sample code-source and
code-type
wmo_bufr
A WMO code table for data encoded
in BUFR format
WMO Pub. No. 306 =- Manual on Codes Part B –
Binary Codes:
http://www.wmo.int/pages/prog/www/WMOCodes/WM
O306_vI2/VolumeI.2.html
wmo_bufr 020003
local_bufr
A local Canadian code table for
MSC data encoded in BUFR format.
Defined by CMC
CMC:
ftp://depot.cmc.ec.gc.ca/ftp/cmoi/bufr/english/tabloc_b
ufr_e
local_bufr 020197
wmo_tac
A WMO code table for data encoded
in Traditional Alphanumeric Code
forms (TAC) such as SYNOP
WMO Pub. No. 306 =- Manual on Codes Part A –
Alphanumeric Codes
http://www.wmo.int/pages/prog/www/WMOCodes/WM
O306_vI1/VolumeI.1.html
wmo_tac 000500
local_tac
A local code table defind by the
DMS for incoming data encoded in
Traditional Alphanumeric Code
forms (TAC)
DMS code tables and encode/decode specification
documents
local_tac 008197
Various
sources
A local code table defind by the
DMS for incoming data encoded in
ASCII formats. The code source
may be the name of the network,
product, message, etc.
DMS code tables and encode/decode specification
documents
ra present_weather
rwin essPrecipSituation
metar visibility
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 18 of 111
However, a “standard” code table is also associated with each of these incoming code tables for a
given element. The master list of code tables that the DMS maintains has cross referenced similar
code tables for a given entity to a DMS standard table, which is in effect a superset of all the similar
code tables for that entity. This allows for products or clients to use one standard code value for an
element to map to their preferred codes, expressions or interpretation rather than having to map too
many different tables for a given element across multiple networks. For example, present weather is
reported by many networks, but most use different code tables or even text strings (note, in the DMS
text strings that are controlled vocabulary are also treated as if they were codes).
Example 1. Present weather arriving to the DMS in different code tables for each network is mapped
to a code value in a single DMS standard code table. Below are some examples:
Network
Observation
Incoming
code-src
Incoming
code-type
Incoming
value
SWOB code-
src
SWOB code-
type
Std code
value
WinIDE
Manned Observation: Light
rain (not freezing,
continuous)
local_bufr
020210
11
std_code_src
present_weather
65
NC-
HWOS
Manned Observation: Light
rain (not freezing,
continuous)
wmo_bufr
020019
-RA
std_code_src
present_weather
65
RA
Automated Station
Observation: Light rain
ra
present_weather
R-
std_code_src
present_weather
364
RWIN
Automated Station
Observation: Light rain
rwin
WMO4680
61
std_code_src
present_weather
364
Example 2. Cloud type and obscuring phenomena arriving to the DMS in a different code tables for
each network is mapped to a code value in a single DMS standard code table. Below are some
examples:
Network
Observation
Incoming
code-src
Incoming
code-type
Incoming
value
SWOB code-src
SWOB code-type
Std
code
value
WinIDE
Altocumulus
local_bufr
020197
0
std_code_src
obscuring_phenomena
0
NC-HWOS
Altocumulus
wmo_bufr
020012
3
std_code_src
obscuring_phenomena
0
ASCII
SYNOP
FM-12
Altocumulus
wmo_tac
000500
3
std_code_src
obscuring_phenomena
0
To see the meaning of the standard code table vales for coded SWOB elements, please refer to
Appendix 6.5. With this information clients can map the SWOB standard code values to their
preferred expression or code using a single mapping table, rather than one for each network.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 19 of 111
4. SW-OB-XML Format and Structure
4.1 Overview
As with all DMS decoded XML products, the SWOB conforms to global standards such as OGC's
Observation and Measurement schema and GML. Being compliant with such standards enhances the
interoperability of the format and also offers a common look and feel among similar products.
The two standards employed in the SWOB are the following:
Open Geospatial Consortium's Observations and Measurements Encoding Standard
(O&M) defines an abstract model and an XML schema encoding for observations and it
provides support for common sampling strategies. O&M also provides a general framework
for systems that deal in technical measurements in science and engineering. This is one of the
OGC Sensor Web Enablement (SWE) suite of standards.
Additional information of O&M can be obtained from here:
http://www.opengeospatial.org/standards/om
Open Geospatial Consortium's Geography Markup Language Encoding Standard
(GML) The Geography Markup Language (GML) is an XML grammar for expressing
geographical features. GML serves as a modeling language for geographic systems as well as
an open interchange format for geographic transactions on the Internet. As with most XML
based grammars, there are two parts to the grammar – the schema that describes the document
and the instance document that contains the actual data.
A GML document is described using a GML Schema. This allows users and developers to
describe generic geographic data sets that contain points, lines and polygons.
Additional information of GML can be obtained from here:
http://www.opengeospatial.org/standards/gml
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 20 of 111
4.2 Structural Organization of SWOB
<om:ObservationCollection>
<om:member>
<om:Observation>
<om:metadata>
<set>
<general>
<author/>
<dataset/>
<phase/>
<id/>
<parent />
</general>
<identification-elements>
<element name=" " uom="" value=""/>*
<element name=" " uom="code" code-src="" code-type="" value=""/>*
</identification-elements>
</set>
</om:metadata>
<om:samplingTime>
</gml:TimeInstant>
</om:samplingTime>
<om:resultTime>
</gml:TimeInstant>
</om:resultTime>
<om:procedure>
<om:observedProperty>
<om:featureOfInterest>
</gml:FeatureCollection>
</om:featureOfInterest>
<om:result>
<elements>
<orig-header/>
<orig-msg/>
<element name=" " uom="" value=""/>*
<element name=" " uom="" value="">
<qualifier name="qa_summary" uom="unitless" value=""/>
</element>*
<element name=" " uom="code" code-src="" code-type="" value=""/>*
<element name=" " uom="code" code-src="" code-type="" value=""/>
<qualifier name="qa_summary" uom="unitless" value=""/>
</element>*
</elements>
</om:result>
</om:Observation>
</om:member>
</om:ObservationCollection>
*Note: zero to many lines in this format can be present
A
B
C
D
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 21 of 111
Section A:
This section provides metadata around the DMS component that produces this XML.
<author> is the component's name
<dataset> contains the full taxonomy of this dataset (discussed below in detail)
<phase> the DMS phase at which point this XML was generated
<id> is the full URI (uniform resource indicator) of this instance of the XML
<parent> is the full URI of the input file that led to the generation of this XML instance. In
the case of a product generator, which produces the SWOB, the input is either the decoded
or decoded_enchanced XML.
Section B:
This section of the SWOB contains metadata elements about the observation. For instance, one
could find the time of observation, the reporting station identifier (e.g. MSC ID, ICAO ID,
WMO Synoptic ID, etc), the station's latitude, longitude and elevation, correction level of the
observation, etc. The elements in this section are of the form <element name=" " uom=""
value=""/>, where
name is an abbreviated label (less than 30 characters) assigned to each element
definition
uom is the unit of measure
value is the value of the element.
In the case when uom="code", then two additional attributes will be included, these are:
code-src is the authoritative source of which this code table originates
code-type is the type or name of a given code table available for a given source
The resulting element would look like this:
<element name="" uom="code" code-src="" code-type="" value=""/>. Such elements contain
coded values.
There can be any number of identification elements for a given observation, depending on the
dataset.
Section C:
This section contains additional metadata about the observation.
<om:samplingTime> is the full date time of this observation encoded within a GML
element
<om:resultTime> is the full date-time when the DMS product generator produced this
instance of the SWOB encoded within a GML element
<om:featureOfInterest> is the latitude and longitude of the station that reported this
observation encoded within a GML element.
Section D:
This section of the SWOB is the body of the observation, where one would expect to find the
observational elements. Fundamentally an element is a single unit of observation. For
instance, air temperature, relative humidity, wind speed, wind direction, visibility, etc. are all
examples of a singular observed phenomenon, which is encoded as an element in the SWOB.
Elements in this section are of the form:
<element name=" " uom="" value=""/> where
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 22 of 111
name is an abbreviated label (less than 30 characters) assigned to each element
definition
uom is the unit of measure
value is the value of the element
In the case when uom="code", then two additional attributes will be included, these are:
code-src is the authoritative source of which this code table originates
code-type is the type or name of a given code table available for a given source
The resulting element would look like this:
<element name="" uom="code" code-src="" code-type="" value=""/>. Such elements contain
coded integer or values or a text value from a list of controlled vocabulary (so in effect a code).
The incoming element that is encoded here, comes in with a native code source and type (an
example for a present weather code source and type may be: wmo_bufr, 020003, respectively).
During the production of the SWOB, a “standard code value” is substituted for the incoming
codes. The exact code substitutions used for each dataset of the SWOB product will be
discussed in Section 5 of this document.
For elements which are reported in the raw observation that have an empty or illegal value, the
value/code will be designated as MSNG to denote “missing”.
Finally, if Qa information is available for the element, then a qualifier will be tagged onto the
element to provide an over-all summary of the quality assessments. In this case, the element
will look like this:
<element name=" " uom="" value="">
<qualifier name="qa_summary" uom="unitless" value=""/>
</element>
or
<element name=" " uom="code" code-src="" code-type="" value=""/>
<qualifier name="qa_summary" uom="unitless" value=""/>
</element>
See Section 4.5 for details on the creation of the Qa qualifier and the meaning of the code value
(i.e. Qa flags).
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 23 of 111
4.3 Sample SWOB
Here is a full sample output of a SWOB instance for the RA (MSC AWOS) dataset:
<?xml version="1.0" encoding="UTF-8" standalone="no" ?>
<om:ObservationCollection xmlns:om="http://www.opengis.net/om/1.0"
xmlns="http://dms.ec.gc.ca/schema/point-observation/2.0"
xmlns:gml="http://www.opengis.net/gml" xmlns:xlink="http://www.w3.org/1999/xlink"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">
<om:member>
<om:Observation>
<om:metadata>
<set>
<general>
<author name="MSC-DMS-PG-SWOB" version="1.0" />
<dataset name="msc/observation/atmospheric/surface_weather/ra-1.1-ascii"
/>
<phase name="product_generic_swob-xml-2.0" />
<id xlink:href="/data/msc/observation/atmospheric/surface_weather/ra-1.1-
ascii/product_generic_swob-xml-2.0/201207181400/7018573/yoy/orig/data_60" />
<parent xlink:href="/data/msc/observation/atmospheric/surface_weather/ra-
1.1-ascii/decoded_enhanced-xml-2.0/201207181400/7018573/yoy/orig/data_60" />
</general>
<identification-elements>
<element name="tc_id" uom="unitless" value="YOY" />
<element name="stn_nam" uom="unitless" value="VAL CARTIER" />
<element name="msc_id" uom="unitless" value="7018573" />
<element name="clim_id" uom="unitless" value="7018573" />
<element name="wmo_synop_id" uom="unitless" value="71716" />
<element code-src="std_code_src" code-type="report_type" name="rpt_typ"
uom="code" value="0" />
<element name="date_tm" uom="datetime" value="2012-07-18T14:00:00.000Z" />
<element code-src="std_code_src" code-type="station_type" name="stn_typ"
uom="code" value="4" />
<element name="lat" uom="°" value="46.9" />
<element name="long" uom="°" value="71.5" />
<element name="stn_elev" uom="m" value="167.6" />
</identification-elements>
</set>
</om:metadata>
<om:samplingTime>
<gml:TimeInstant>
<gml:timePosition>2012-07-18T14:00:00.000Z</gml:timePosition>
</gml:TimeInstant>
<om:samplingTime>
<om:resultTime>
<gml:TimeInstant>
<gml:timePosition>2012-07-18T14:01:04.657Z</gml:timePosition>
</gml:TimeInstant>
</om:resultTime>
<om:procedure xlink:href="/data/msc/metadata/station/surface_weather/metadata_instance-2.0-
xml/product-jicc_xml-2.0/201207181143/yoy" />
<om:observedProperty gml:remoteSchema="/schema/point-observation/2.0.xsd" />
<om:featureOfInterest>
<gml:FeatureCollection>
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 24 of 111
<gml:location>
<gml:Point>
<gml:pos>46.9 71.5</gml:pos>
</gml:Point>
</gml:location>
</gml:FeatureCollection>
<om:featureOfInterest>
<om:result>
<elements>
<element code-src="std_code_src" code-type="total_cloud_amount"
name="cld_amt_code_1" uom="code" value="2">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="cld_bas_hgt_1" uom="m" value="1500">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element code-src="std_code_src" code-type="total_cloud_amount"
name="cld_amt_code_2" uom="code" value="2">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="cld_bas_hgt_2" uom="m" value="1800">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="vis" uom="km" value="14.484">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element code-src="std_code_src" code-type="present_weather" name="prsnt_wx"
uom="code" value="409">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="altmetr_setng" uom="inHg" value="29.77">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="air_temp" uom="°C" value="21.2">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="dwpt_temp" uom="°C" value="11.3">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="avg_wnd_dir_10m_pst2mts" uom="°" value="281">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="avg_wnd_spd_10m_pst2mts" uom="km/h" value="13">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="max_wnd_gst_spd_10m_pst10mts" uom="km/h" value="31.5">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="sum_cld_cvr_1" uom="%" value="0">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="sum_cld_cvr_2" uom="%" value="0">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="min_vis_pst10mts" uom="km" value="14.484">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="max_vis_pst10mts" uom="km" value="14.484">
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 25 of 111
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="stn_pres" uom="hPa" value="988.3">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="min_air_temp_pst1hr" uom="°C" value="20.5">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="max_air_temp_pst1hr" uom="°C" value="21.9">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="avg_wnd_dir_10m_pst10mts uom="°" value="270">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="avg_wnd_spd_10m_pst10mts" uom="km/h" value="16.7">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="wnd_dir_10m_pst1hr_pk_spd" uom="°" value="270">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="max_pk_wnd_spd_10m_pst1hr" uom="km/h" value="31.5">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="pcpn_gag_wt_fltrd" uom="kg/m²" value="410.5">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="pcpn_amt_pst1hr" uom="mm" value="0.0">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="rel_hum" uom="%" value="53" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element code-src="std_code_src" code-type="tendency_characteristic"
name="pres_tend_char_pst3hrs" uom="code" value="1" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="pres_tend_amt_pst1hr" uom="hPa" value="0.2" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="pres_tend_amt_pst3hrs" uom="hPa" value="1.5" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="pcpn_amt_pst3hrs" uom="mm" value="0.5" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="pcpn_amt_pst6hrs" uom="mm" value="0.5" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="pcpn_amt_pst24hrs" uom="mm" value="8.5" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 26 of 111
<element name="max_air_temp_pst24hrs" " uom="°C"value="31.4/>
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="max_air_temp_pst6hrs" " uom="°C" value="31.1"/>
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="min_air_temp_pst6hrs" " uom="°C"value="21.2"/>
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="min_air_temp_pst24hrs"" uom="°C" value="17.6" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
<element name="mslp" uom="hPa" value="1008.2" />
<qualifier code-src ="std_code_src" code-type="data_flags" name="data_flag"
uom="code" value="1" />
</element>
</elements>
</om:result>
</om:Observation>
</om:member>
</om:ObservationCollection>
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 27 of 111
4.4 Taxonomy and URI
Each dataset is classified using taxonomy. Each instance of a SWOB is uniquely identified via its
URI. One can access each dataset's SWOB instances using the assigned URI in the DMS notification
web application (permissions dependent).
Taxonomies are of the form:
/organization/category/type/network/dataset-version-format/phase-format-version/(<parameters>*)
Please refer to the Taxonomy Documentation referenced in Section 1.3 for more information about the
taxonomy structure and meaning of the various tokens.
The chart below indicates the taxonomy for each dataset:
Incoming Dataset
SWOB Taxonomy
Legacy MSC & Partner Manned
aviation weather stations using the
WinIDE or MIDS interface (BUFR
messages under header ‘ISAx41’)
/msc/observation/atmospheric/surface_weather/winide_fm12-1.0-
xml/product_generic_swob-xml-2.0
Legacy MSC & Partner AWOS
aviation weather stations (‘RA’ ASCII
messages)
/msc/observation/atmospheric/surface_weather/ra-1.1-
ascii/product_generic_swob-xml-2.0
DND AWOS (BUFR messages under
header ‘ISAx64’)
/dnd/observation/atmospheric/surface_weather/awos-1.0-
binary/product_generic_swob-xml-2.0
Nav Canada AWOS aviation weather
stations (BUFR messages under
header ‘ISAx61’)
/nav_canada/observation/atmospheric/surface_weather/awos-2.1-
binary/product_generic_swob-xml-2.0
DND HWOS (BUFR messages under
header ‘ISAx67’)
/dnd/observation/atmospheric/surface_weather/hwos-1.1-
binary/product_generic_swob-xml-2.0
Nav Canada HWOS aviation weather
stations (BUFR messages under
header ‘ISAx62’)
/nav_canada/observation/atmospheric/surface_weather/hwos-1.1-
binary/product_generic_swob-xml-2.0
MSC & Partner public surface
weather network stations using
Campbell Scientific data loggers
(‘CA’ ASCII messages)
/msc/observation/atmospheric/surface_weather/ca-1.1-
ascii/product_generic_swob-xml-2.0
MSC weather stations using Campbell
Scientific data loggers transmitting
minutely in support of the 2015 PanAm
Games (‘COMPACT-minutely’ CA
/msc/observation/atmospheric/surface_weather/ca-1.2-
ascii/product_generic_swob-xml-2.0
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 28 of 111
ASCII messages sent to the DMS)
OPP Moored Buoy weather network
stations (‘OPP’)
/msc/observation/atmospheric/marine/moored_buoy-1.2-
ascii/product_generic_swob-xml-2.0
BC Ministry of Transportation (‘BC-
TRAN’)
/partners/observation/atmospheric/surface_weather/bc_tran-1.0-
csv/product_generic_swob-xml-2.0
British Columbia Ministry of Forests,
Lands and Natural Resources; Wildfire
Management Branch (‘BC-FLNR-
WMB’)
/partners/observation/atmospheric/surface_weather/bc_forestry-
1.1-ascii/product_generic_swob-xml-2.0
BC Ministry of Envrionment Air Quality
Meteorological weather network stations
(‘BC-ENV-AQMet’)
/partners/observation/atmospheric/surface_weather/bc_env_aqmet
-1.0-csv/product_generic_swob-xml-2.0
BC Ministry of Envrionment Snow
weather network stations (‘BC-ENV-
SnowWx’)
/partners/observation/atmospheric/surface_weather/bc_env_snow
wx-1.0-ascii/product_generic_swob-xml-2.0
To each of the taxonomies listed above, the following parameters may be appended:
/<datetime>/<MSC Id>/<secondary station identifier>/<revision level>/<content frequency>
<datetime> is the full date-time string when the observation was reported by the station in the
format YYYYMMDDHHMM
<MSC Id> is the official MSC station identifier (for MSC stations this is the climate identifier
used by the National Climate Archive to guarantee uniqueness). For Partner networks, the
MSC identifier may be a copy of the secondary identifier unless a Climate identifier can be
assigned.
<secondary station identifier> is an additional station identifier attached to the URI. It varies
depending on the dataset and is typically the identifier most commonly used by a particular
network’s operators. For example:
o NC-AWOS, DND-AWOS: ICAO station identifier
o NC-HWOS, DND-HWOS: ICAO station identifier
o CA: TC identifier
o RA: TC identifier
o WinIDE: TC identifier
<revision level> is the correction/revision level of the observation. If the observation is the
original message “orig” will be used. If there are corrections or revisions, an indicator will be
used (e.g. CCA, CCB, CCC, etc.).
<content frequency> is used for networks that issue multiple observations for a given time with
different data content. The frequency of a particular observation is also indicated (in minutes).
The value of this parameter is in the format content_frequency, where the content types are
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 29 of 111
data, diag (diagnostic data) and supp (supplementary program data), and the message
frequency is in minutes (e.g. data_60 would be an observation containing hourly data intended
for official products; supp_1 would be an observation from a supplementary program such as
solar radiation transmitted every minute).
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 30 of 111
The chart below indicates the URI for selected dataset examples:
Dataset
URI
Example
MSC & Partner Manned
(WinIDE/MIDS -
ISAx41 BUFR)
/msc/observation/atmospheric/surface_
weather/winide_fm12-1.0-
xml/product_generic_swob-xml-
2.0/<date time>/<msc identifier>/<tc
identifier>/<revision level>/<content
frequency>
data/msc/observation/atmospheric/surf
ace_weather/winide_fm12-1.0-
xml/product_generic_swob-xml-
2.0/201808081600/7060400/cybg/orig/
data_60
MSC & Partner AWOS
(RA messages)
msc/observation/atmospheric/surface_w
eather/ra-1.1-
ascii/product_generic_swob-xml-
2.0/<date time>/<msc identifier>/<tc
identifier>/<revision level>/<content
frequency>
/msc/observation/atmospheric/surface_
weather/ra-1.1-
ascii/product_generic_swob-xml-
2.0/201808080000/8101794/ycx/orig/d
ata_60
Nav Canada HWOS
(ISAx62 BUFR)
/nav_canada/observation/atmospheric/su
rface_weather/hwos-1.1-
binary/product_generic_swob-xml-
2.0/<date time>/<msc identifier>/<tc
identifier>/<revision level>/<content
frequency>
/nav_canada/observation/atmospheric/s
urface_weather/hwos-1.1-
binary/product_generic_swob-xml-
2.0/201808081600/7047911/cyzv/orig/
data_60
Nav Canada AWOS
(ISAx61 BUFR)
/nav_canada/observation/atmospheric/su
rface_weather/awos-2.1-
binary/product_generic_swob-xml-
2.0/<date time>/<msc identifier>/<tc
identifier>/<revision level>/<content
frequency>
/data/nav_canada/observation/atmosph
eric/surface_weather/awos-2.1-
binary/product_generic_swob-xml-
2.0/201808081600/2402360/cwgz/orig
/data_60
MSC & Partner surface
weather network
(Campbell Sci. CA
messages
/msc/observation/atmospheric/surface_
weather/ca-1.1-
ascii/product_generic_swob-xml-
2.0/<date time>/<msc identifier>/<tc
identifier>/<revision level>/<content
frequency>
/msc/observation/atmospheric/surface_
weather/ca-1.1-
ascii/product_generic_swob-xml-
2.0/201808071600/3012192/pea/orig/d
ata_60
4.5 Quality Assessment Flag
The SWOB will contain a quality assessment (Qa) summary flag as a qualifier attached to an element
whenever possible. In the SWOB it will appear as such:
<element name=" " uom="" value="">
<qualifier name="qa_summary" uom="unitless" value=""/>
</element>
or
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 31 of 111
<element name=" " uom="code" code-src="" code-type="" value=""/>
<qualifier name="qa_summary" uom="unitless" value=""/>
</element>
The possibility of this flag being attached to an element is dependent on the following scenarios:
1. There will be no qa_summary flag if there are no incoming “Native QC” flags on the element
and there was no in-house DMS quality assessment done on the element.
2. There will be no qa_summary flag if the incoming “Native QC” attached to the element has no
flags raised and there is no in-house DMS quality assessment done on the element
3. A qa_summary flag will be generated and attached to the element, if it arrived from the source
with one or more Native QC flags indicating a problem and/or if a quality assessment was
carried out by DMS on the element.
In scenario 2, an algorithm will be used to arrive at a single qa_summary value considering the
availability of both the native and DMS quality assessments on the element.
Below is the algorithm used to generate the value for the qa_summary qualifier:
Prior to executing the algorithm, all incoming Native QC values are converted to DMS standard Qa
flag values (so that they can be easily compared to the DMS Qa flag value) using the following
scheme:
-10 = Suppressed
-1 = Missing
0 = Error
10 = Doubtful
15 = Suspect/Warning
20 = Inconsistent
100 = Acceptable/Passed
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 32 of 111
Qa Flag Definitions:
Suppressed – the data provider has indicated that the data value is not to be used or published due to
instrumentation or environmental issues which have compromised the data.
Missing – the “value” of an element is null, blank/space, “MSNG” (from the decoder), a code representing
missing, or could not be derived.
Error – The value is physically impossible, beyond the capability of the sensor to detect, or identified as
incorrect.
Doubtful – The value is physically possible but is statistically improbable: at or exceeding expected extreme
values.
Suspect/Warning – the data provider has indicated that the data may be unreliable or is outside of nominal
limits.
Inconsistent – The value is inconsistent when it departs significantly from an expected physical relationship
with an independently measured, associated variable. It is not possible to determine if either the value or the
associated variable is in error.
Acceptable/Passed – The value passed all applicable quality assessment test(s) or has been verified as
acceptable.
The final qa_summary flag values are generated as follows:
The final qa_summary flag in the SWOB is the lowest value between the converted Native QC
flag (if exists) and the real-time DMS Qa flag:
e.g.
if Native QC flag variable = 0 and DMS Qa flag=10, then SWOB qa_summary = 0
if Native QC flag variable = -10 and DMS Qa flag=0, then SWOB qa_summary = -10
if Native QC flag variable = 10 and DMS Qa flag=100, then SWOB qa_summary = 10
if Native QC flag variable = 100 and DMS Qa flag=100, then SWOB qa_summary = 100
if Native QC flag variable = 100 and DMS Qa flag = 0, then SWOB qa_summary = 0
if Native QC flag variable = -10 and DMS Qa flag = 0, then SWOB qa_summary = -10
if Native QC flag variable = 15 and DMS Qa flag = 10, then SWOB qa_summary = 10
if Native QC flag variable = 100 and DMS Qa was not performed, then no qa_summary in SWOB
if no incoming Native QC flags and DMS Qa was not performed, then no qa_summary in SWOB
If an element does not have a qa_summary qualifier, it means that there was no direct quality
assessment performed on it within the DMS, and that if Native QC was present, no flags were
raised. Note however, that although derived elements may not have a Qa flag, it is likely that
some or all of the input elements had Native QC and/or DMS Qa and these flags were
considered when determining whether or not to derive the element.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 33 of 111
4.6 Data Flag
A new feature of the SWOB is a qualifier that may be present on some elements, if applicable.
Currently most observed elements have a qa_summary qualifier on them to indicate the quality
status via a code table. A new “data_flag” qualifier will operate the same way by providing
additional metadata on some elements to convey the following information, if it applies:
Code Value
Text Value
Description
1
derived
Value has been reformulated or mathematically derived with complete
inputs
2
estimate
Reported value received as an estimate
3
adjusted
Reported value the result of an adjustment (e.g. precipitation under
catch, wind speed extrapolated to 10m, etc.)
4
incomplete
Value has been reformulated or mathematically derived with incomplete
inputs - element derivation contains at least one missing value
5
trace
Trace. Value is zero
6
multiple
More than one occurrence
7
interpolated
Value has been derived with incomplete inputs - Missing inputs
interpolated within completeness constraints
For hourly datasets and the associated SWOBs, the most common data_flag used will be code 1
(derived) and in some cases code 5 (trace). The majority of the other flags are rarely assigned or are
typically only applicable for post-processing by other downstream product generators (e.g. derived
Dailies).
Like the qa_sunmary, the data_flag qualifier is a child of the parent element and is optional. Below
is an example of how it will appear in the SWOB for a derived element:
<element name="mslp" value="1020.8" uom="hPa"/>
<qualifier code-src="std_code_src" code-type="data_flags" name="data_flag" uom="code" value="1"/>
</element>
To associate the code to the proper code table (see Appendix), the code source (code-src =
std_code_src) and code type (code-type = data_flags) are identified. For hourly data, if a data_flag
qualifier is specified for an element, there will almost always be a single value. In the rare event
there are two data flags on an element they will appear as a comma-separated list for the value. For
example, below is a case where a derived (1) element has a trace (5) value:
<element name="tot_precip_pst24hrs" value="0" uom="mm"/>
<qualifier code-src="std_code_src" code-type="data_flags" name="data_flag" uom="code"
value="1,5"/>
</element>
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 34 of 111
4.7 Multiplicity
Some elements within the DMS are repeated due to more than one instance of occurrence or more than
one observation being made. For these elements, the element name is followed by “_#”. For example,
air temperature in the CA dataset can be observed up to three times if three sensors are available. In
this case, three air temperature measurements are sent to the DMS which are used to achieve an
“official” air temperature. A SWOB output would show the official as well as the three sensor values.
For example:
<element name="air_temp" uom="°C" value="21.2">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="air_temp_1" uom="°C" value="21.2">
<element name="air_temp_2" uom="°C" value="21.1">
<element name="air_temp_3" uom="°C" value="21.1">
Some other elements that can have more than one sensor include:
Wind – 2 sensors
Snow – 3 sensors
Precipitation gauge weight – up to 3 sensors
Furthermore, cloud elements in the NC AWOS/NC HWOS dataset can have multiple instances being
reported, one for each cloud layer. A SWOB output for this would look like the following:
<element code-src="std_code_src" code-type="total_cloud_amount"
name="cld_amt_code_1" uom="code" value="1">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="cld_bas_hgt_1" uom="m" value="900.0">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element code-src="std_code_src" code-type="total_cloud_amount"
name="cld_amt_code_2" uom="code" value="2">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
<element name="cld_bas_hgt_2" uom="m" value="1140.0">
<qualifier name="qa_summary" uom="unitless" value="100" />
</element>
Elements with more than one instance of occurence include:
Cloud elements (height, type, cover, amount) – up to 6 instances
Present weather – up to 8 instances
Recent weather – up to 3 instances
In the following sections, datasets that can contain multiplicities will have an additional column of
“Maximum Multiplicity” identifying the maximum number of times that element can be repeated.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 35 of 111
5. Datasets
5.1 Overview
This section will outline where the incoming data comes from, how it is mapped to short labels, the
description of the elements, and which elements have gone through unit conversion. The sections are
broken down by dataset:
1. Legacy MSC & Partner Manned aviation weather stations using the WinIDE or MIDS
interface
2. DND HWOS aviation weather stations
3. Legacy MSC & Partner AWOS aviation weather stations
4. DND AWOS aviation weather stations
5. Nav Canada HWOS aviation weather stations
6. Nav Canada AWOS aviation weather stations
7. MSC & Partner public surface weather network stations using Campbell Scientific data loggers
which transmit official hourly observations
MSC & Partner networks that supported the 2015 PanAm Games:
8. Minutely MSC & Partner surface weather network – COMPACT
9. OPP marine weather stations
10. BC Tran weather stations
11. BC Forestry weather stations
12. BC Environment AQ Met weather stations
13. BC Environment Snow Wx weather stations
The tables in the sub-sections below provide a superset of the weather elements that could potentially
be in a given SWOB. They describe the meaning of the short label and identify the incoming units
and codes. As well, the standard units and code tables required for the SWOB are indicated, along
with the precision values are rounded to in the event of a unit conversion. The value in the Precision
column represents the number of digits after the decimal (e.g. 2 would represent 0.01). A value of 0
represents integer values. Descriptions of the unit of measure’s (uom) expression and meaning can be
found in Appendix 6.3, while Appendix 6.4 provides unit conversions. Descriptions of the meaning of
codes in the standard code tables can be found in Appendix 6.5.
5.2 Data Element Terminology
5.2.1 Wind
The various types of wind measurements can cause confusion given the large number of variations. In
particular, the use of the terms ‘wind gust speed’, ‘maximum wind speed’, and ‘peak wind speed’
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 36 of 111
need to be defined as these terms are sometimes used interchangeably yet the data are processed quite
differently.
Maximum Wind Speed (e.g. max_wnd_spd_10m_pst10mts): This is the highest instantaneous
wind speed no matter what the value (e.g. could be 0) over the interval indicated (e.g. could be
over the past hour, or minutes 50 to 60 as in this example);
Maximum Wind Gust Speed (or just wind gust; e.g. max_wnd_gst_spd_10m_pst10mts): This
element is derived from the 10 minute maximum wind speed element described above. The
rules follow the ManObs definition and it is only reportable if the max wind speed over the last
10 minutes of the hour is ≥15 knots AND the max speed exceeds the 2-minute mean wind
speed by ≥5 knots (note the 10-minute mean is used for climate stations such as the CA data
set).
Peak Wind Speed (e.g. max_pk_wnd_spd_10m_pst1hr): This element is derived from the
maximum wind speed over the past hour. The rules follow the ManObs definition and it is
only reportable if the max wind speed over the past hour is ≥17 knots. Depending on the
network, the time of the peak and the wind direction at the time of the peak may also be
reported. The peak direction element would be wnd_dir_10m_pst1hr_pk_spd.
Given how critical the height of the anemometer is to the measurement and use of wind speed data, the
height of the instrument is typically included in the SWOB short label (e.g.
avg_wnd_spd_10m_pst10mts). For the operational MSC surface weather networks, as well as partner
data (e.g. Nav Canada, DND), the standardized anemometer heights are generally 10 m as per WMO
and ICAO guidelines. However, in the case of the MSC “Compact” stations supporting the 2015
PanAm Games Mesonet, the height of the anemometer can vary from station-to-station. The nominal
height of the anemometer for a Compact station situated on the ground is approximately 2.5 m above
the pedestal base, however, some stations are located on rooftops or other structures, so the wind speed
height can vary significantly. To keep the SWOB short label consistent for wind elements across all
the networks the label was not modified on a station-to-station basis to account for anemometer
heights that depart from the standard. Clients needing information specific to the Compact stations
will need to access the station information metadata maintained by the Data Management System.
5.2.2 Cloud Amount/Cover
Sky condition, in terms of cloud amount and cloud cover, is complicated by the fact it’s handled
differently across the networks that observe it. Human observations are capable of reporting a total
cloud amount because the human can assess the whole celestial dome, whereas the instrumentation
currently deployed at automatic stations cannot. As for cloud amount/cover reported for individual
cloud layers, the observation from a manual station is non-cumulative and pertains to each layer, while
the measurement from an automatic station is a summation so each layer incorporates the amount of
the layer below. Finally, there are variations in the way cloud amount (also known as cloud cover) is
reported across the networks. Some networks send codes that represent the sky condition as strings
such as SCT (scattered), BKN (broken), OVC (overcast), etc. Other networks observe in eighths
(octas) or tenths. For this reason is may be difficult to translate the standard code from all networks to
a single scheme without compromises being made.
Sky Coverage
Legacy MSC AWOS
MSC Manned
(WinIDE/MIDS)
NC-AWOS
NC-HWOS
METAR Product
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 37 of 111
String based on
cloud layer opacity
or
coverage/amount
Sky Coverage derived from
summation cloud cover
(amount) as estimated by a
ceilometer
Sky Coverage
derived from
observing cloud
layer opacity in
tenths
Sky Coverage derived
from summation cloud
amount as estimated
by a ceilometer.
Sky Coverage
derived from
cloud layer
amounts in
Octas
Sky Coverage derived from the
various observing systems
based on observing Cloud
layer amounts in Octas (NC-
AWOS, NC-HWOS) or mapped
from tenths (WinIDE)
CLR/SKC (clear-
no cloud or
obscuring
phenomena)
0% (results in the code of
‘CLR BLO 100’ meaning
clear below 10,000 ft)
0/10th (CLR)
0/8th (SKC)
0/8th (SKC)
0/8th (SKC)
FEW
n/a
1/10 – 3/10th
1/8 – 2/8th
1/8 – 2/8th
1/8 – 2/8th
SCT (scattered)
49%
4/10 – 5/10th
3/8 – 4/8th
3/8 – 4/8th
3/8 – 4/8th
BKN (broken)
50 – 89%
6/10 – 9/10th
5/8 – 7/8th
5/8 – 7/8th
5/8 – 7/8th
OVC (overcast)
90%
10/10th
8/8th
8/8th
8/8th
-X (partially
obscured by
surface-based
layer)
< 90% (80% in multi-
parameter)
Note: will not come out on
any METAR because you
can see through it
1/10th – <10/10th
surface-based
layer
n/a
n/a
n/a
X (totally obscured
by surface based
layer)
90%, otherwise 100%
10/10th surface-
based layer
n/a
n/a
n/a
5.2.3 Precipitation and Rainfall
Within the DMS there is a clear distinction between “precipitation”, which implies a measurement of
all forms of liquid and frozen precipitation, and “rainfall”, which is just the liquid state. The
designation of a measurement as either precipitation or rainfall is determined by the instrument is use.
For MSC data, official precipitation elements will come from an all-weather sensor capable of
operating year round. Examples of such instrumentation are weighing-type gauges (e.g. GEONOR
and PLUVIO), Piezo electric strike plates, and Doppler sensors. For rainfall and rate of rainfall
measurements, the most commonly used sensor is a tipping bucket rain gauge (TBRG) like the TB3
used by the MSC. For MSC data, an exception to the precipitation rule is granted when a station only
has a TBRG. In such cases the rainfall measurement may be used in derived precipitation elements as
long as certain criteria are met (e.g. dew point temperature is > +1°C, or the air temp is > 4.5°C).
For third party, where we have less detail on instrumentation, it may not be possible to distinguish
between precipitation and rainfall or validate that what they call “precipitation” is indeed from an all-
weather instrument. Also for the case of the Nav Canada and some stations in other third party
datasets (e.g. GRCA, TRCA) we know that a heated TBRG may be employed to report precipitation,
which can compromise the accuracy of measuring both liquid and frozen precipitation.
5.2.4 Station elevation
Station elevation is a critical parameter used for the computation of mean sea level pressure (MSLP).
For networks that have the barometer relatively close to the ground, an initial station pressure
correction may not be done for the difference in height between the level of the barometer and the
ground surface (where the elevation is normally referenced) before the final reduction to sea level for
the computation of MSLP. The automated Public Surface Weather network (i.e. Campbell stations
issuing CA messages) and legacy AWOS sites (RA messages) are examples of such networks. For
these networks the station elevation is actually referenced from the height of the barometer to
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 38 of 111
compensate for not doing a pressure correction down to ground surface. At these stations the
barometer is approximately 1.5 m to 2.5 m above the ground surface.
Station elevation is a critical parameter used for the computation of mean sea level pressure (MSLP).
For networks that have the barometer relatively close to the ground, an initial station pressure
correction may not be done for the difference in height between the level of the barometer and the
ground surface (where the elevation is normally referenced) before the final reduction to sea level for
the computation of MSLP. The automated Public Surface Weather network (i.e. Campbell stations
issuing CA messages) and legacy AWOS sites (RA messages) are examples of such networks. For
these networks the station elevation is actually referenced from the height of the barometer to
compensate for not doing a pressure correction down to ground surface. At these stations the
barometer is approximately 1.5 m to 2.5 m above the ground surface.
5.3 Legacy MSC & Partner Manned (WinIDE/MIDS)
The WinIDE and MIDS legacy applications are interfaces that DND and Nav Canada weather
observers use to enter their weather observations. The observing program is in support of aviation and
most stations are located at airports. Observers are expected to input observed conditions in
accordance with the Manual of Surface Observations (MANOBS). The output is a BUFR (Binary
Universal Form of Representation) message, which is not human readable. These stations are in the
process of being converted to NC-HWOS stations. All the incoming elements, units and values that
come from within the actual BUFR are mapped to their desired elements, units, values and qualifiers
by the DMS and stored in XML format. These elements are then mapped to the short labels shown in
the table below.
Label Name
Description
Standard
Units
Standard
Code Source
Standard Code
Type
Precision
Maximum
Multiplicity
(_#)
tc_id
TC identifier
unitless
long
longitude
°
6
lat
latitude
°
6
stn_elev
station height
m
3
stn_typ
station type
code
std_code_src
station_type
rpt_typ
report type
code
std_code_src
report_type
clim_id
climate identifier
unitless
date_tm
date and time
datetime
wmo_synop_id
WMO synoptic identifier
unitless
icao_stn_id
ICAO station identifier
unitless
stn_nam
station name
unitless
msc_id
MSC identifier
unitless
cor
correction
unitless
tot_cld_opcty
total cloud opacity
%
0
tot_cld_amt
total cloud amount
%
0
cld_bas_hgt_#
cloud height for individual
layers indexed by layer
m
0
8
cld_amt_code_#
Previously:
cld_cvr_#
cloud cover/amount (non-
cumulative) indexed by
layer
code
std_code_src
total_cloud_amo
unt
Previously:
8
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 39 of 111
sky_condition
cld_typ_#
cloud type obscuring
phenomena indexed by
layer
code
std_code_src
obscuring_phen
omena
8
cld_opcty_#
cloud opacity indexed by
layer
%
0
8
clg_typ
ceiling type
code
std_code_src
ceiling_type
clg_hgt
ceiling height
m
0
vis
horizontal visibility
km
3
prsnt_wx_#
present weather indexed
code
std_code_src
present_weather
8
stn_pres
station pressure
hPa
1
mslp
mean sea level pressure
hPa
1
air_temp
air temperature
°C
1
dwpt_temp
dew point temperature
°C
1
avg_wnd_dir_10m_mt
58-60
Previously:
avg_wnd_dir_10m_ps
t2mts
past 2-min vectoral
average 10m wind
direction
°
0
avg_wnd_spd_10m_p
st2mts
Previously:
avg_wnd_spd_10m_
mt58-60
past 2-min average 10m
wind speed
km/h
1
wnd_gst_char_10m_p
st10mts
Previously:
wnd_gst_char_10m_
mt50-60
past 10-min wind gust
character
code
std_code_src
wind_gust_squal
l_indicator
max_wnd_gst_spd_1
0m_pst10mts
Previously:
max_wnd_gst_spd_1
0m_mt50-60
past 10-min maximum
10m wind gust speed
km/h
1
altmetr_setng
altimeter setting
inHg
2
pres_tend_char_pst3
hrs
past 3-hour trend
pressure tendency
characteristic
code
std_code_src
tendency_chara
cteristic
pres_tend_amt_pst3h
rs
past 3-hour differential
pressure change amt
hPa
1
rel_hum
relative humidity
%
0
rmk
remark
unitless
pcpn_amt_pst6hrs
past 6-hour precipitation
amount
mm
1
pcpn_amt_pst24hrs
past 24-hour precipitation
amount
mm
1
snw_dpth
snow depth
cm
0
avg_wnd_spd_10m_p
st10mts
past 10-min average 10m
wind speed
km/h
1
snwfl_amt_pst24hrs
past 24h snowfall amount
cm
0
avg_wnd_dir_10m_ps
t10mts
past 10-min vectoral
average 10m wind
direction
°
0
max_pk_wnd_spd_10
m_pst24hrs
past 24-hour peak wind
speed
km/h
1
wnd_dir_10m_pst24hr
s_pk_spd
past 24-hour peak wind
direction
°
0
max_pk_wnd_tm_pst
24hrs
past 24-hour peak wind
time
datetime
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 40 of 111
5.4 DND HWOS
DND HWOS is the name given to the DND staffed observations that are sent to MSC using a BUFR
(Binary Universal Form of Representation) message. The BUFR message contains multiple fields that
are not observed or reported by DND, and thus are either not included in the SWOB output or will
always have a value of MSNG. The observers are expected to observe and input weather conditions in
accordance with the Manual of Surface Observations (MANOBS). Observations are scheduled to be
reported on an hourly basis at the top of the hour, along with ‘Special’ reports when warranted.
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#)
wmo_synop_id
WMO Identifier
unitless
data_pvdr
data provider
unitless
data_attrib_not
data attribution notice
unitless
stn_nam
station name
unitless
date_tm
official report date and time
datetime
lat
latitude
°
6
long
longitude
°
6
stn_elev
station elevation
m
3
icao_stn_id
ICAO station identifier
unitless
clim_id
climate identifier
unitless
msc_id
MSC identifier
unitless
rpt_typ
report type
code
std_code_sr
c
report_type
stn_typ
station type
code
std_code_sr
c
station_type
cor
correction level
unitless
stn_pres
station pressure
hPa
1
mslp
Mean sea level pressure
hPa
1
pres_tend_amt_p
st3hrs
past 3-hour differential
pressure tendency amount
hPa
1
pres_tend_char_p
st3hrs
past 3-hour trend of
pressure tendency
characteristic
code
std_code_sr
c
tendency_char
acteristic
altmetr_setng
altimeter settings
inHg
2
air_temp
air temperature
°C
1
dwpt_temp
dew point temperature
°C
1
rel_hum
relative humidity
%
0
vis
prevailing horizontal
visibility
km
3
vert_vis
vertical visibility (in meters)
m
3
prsnt_wx_#
present weather
code
std_code_sr
c
present_weath
er
5
recnt_wx_#
recent weather
code
std_code_sr
c
present_weath
er
3
cld_amt_code_#
non-cumulative cloud
amount coded (oktas)
indexed by layer
code
std_code_sr
c
total_cloud_a
mount
5
cld_bas_hgt_#
cloud base height
m
0
5
cld_typ_#
cloud type
code
std_code_sr
c
obscuring_phe
nomena
5
avg_wnd_dir_10
m_pst2mts
past 2-minute average 10m
wind direction
°
0
avg_wnd_spd_10
m_pst2mts
past 2-minute average 10m
wind speed
km/h
1
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 41 of 111
max_wnd_gst_sp
d_10m_pst10mts
past 10-minute max 10 m
wind gust speed
km/h
1
rmk
remark
unitless
Typically observed elements that are not reported by this dataset:
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#)
max_air_temp_pst
1hr
past 1-hour maximum air
temperature
°C
1
min_air_temp_pst1
hr
past 1-hour minimum air
temperature
°C
1
max_air_temp_pst
6hrs
past 6-hour maximum air
temperature
°C
1
min_air_temp_pst6
hrs
past 6-hour minimum air
temperature
°C
1
max_air_temp_pst
24hrs
past 24-hour maximum air
temperature
°C
1
min_air_temp_pst2
4hrs
past 24-hour minimum air
temperature
°C
1
max_vis
maximum horizontal
visibility
km
3
min_vis
minimum horizontal
visibility
km
3
tot_cld_amt
total cloud amount
%
0
avg_wnd_dir_10m
_pst10mts
past 10-minute average
10m wind direction
°
0
avg_wnd_spd_10m
_pst10mts
past 10-minute average
10m wind speed
km/h
1
wnd_dir_10m_pst2
4hrs_pk_spd
wind direction associated
with the past 24-hour peak
wind speed at 10 m
°
0
max_pk_wnd_spd_
10m_pst24hrs
past 24-hour maximum
peak 2-minute mean 10m
wind speed
km/h
1
rnfl_snc_last_syno
_hr
rainfall since last synoptic
hour (TBRG)
mm
1
pcpn_amt_pst6hrs
past 6-hour accumulated
precipitation gauge
amount
mm
1
pcpn_amt_pst24hr
s
past 24-hour accumulated
precipitation gauge
amount
mm
1
snw_dpth
snow depth
cm
0
5.5 MSC & Partner AWOS (RA messages)
RA is the bulletin header for MSC AWOS aviation weather observation reports. AWOS stations are
connected via modem and voice-grade circuits to a regional host computer. These AWOS stations
respond to a poll from the host and transmit their data. In response to a poll, AWOS transmits its most
recent observation. These outputs are the assessment of weather conditions at a particular place and
particular time. They are transmitted hourly, or whenever there is significant weather change, in
which case a “Special” report (SP) is issued.
Sample Incoming Message:
RACN00 CWAO 040100
ZVV SA 031100 AUTO 41SCT/9.+/P-/M/-24.2/-28.2/29307G18/004//2/9+ 9+/9897/-
249-241/29007G030340365/Z/1245-0/
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 42 of 111
*
CL03/VC04/PB07/TC08/WC09/RE18/
*
3*83018701/4*8301/7*8301/9*9301/18*7101/
E83-03 E87-03/E83-04/E83-07/E93-09/E71-18/=
All the incoming elements, units and values that come from within the actual RA are mapped to their
desired elements, units, values and qualifiers by the DMS and stored in XML format. These elements
are then mapped to the short labels shown in the table below.
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#)
tc_id
TC identifier
unitless
rpt_typ
report type
code
std_code_sr
c
report_type
date_tm
actual observation date-
time
datetime
wmo_synop_id
WMO synop identifier
unitless
stn_nam
station name
unitless
icao_stn_id
ICAO station identifier
unitless
clim_id
climate identifier
unitless
msc_id
MSC identifier
unitless
stn_typ
station type
code
std_code_sr
c
station_type
lat
latitude
°
6
long
longitude
°
6
stn_elev
station elevation
m
3
clg_typ_#
ceiling type indexed by
layer
code
std_code_sr
c
ceiling_type
1
cld_amt_code_#
cumulative cloud amount
coded indexed by layer
code
std_code_sr
c
total_cloud_a
mount
6
cld_bas_hgt_#
cloud height indexed by
layer
m
0
6
sum_cld_cvr_#
summation cloud cover
indexed by layer
%
0
6
min_vis_pst10mts
Previously:
min_vis_mt50-60
past 10-min minimum
horizontal visibility
km
3
max_vis_pst10mts
Previously:
max_vis_mt50-60
past 10-min maximum
horizontal visibility
km
3
vis
horizontal visibility
km
3
prsnt_wx
present weather
code
std_code_sr
c
present_weath
er
air_temp
air temperature
°C
1
dwpt_temp
dew point temperature
°C
1
min_air_temp_pst
1hr
past 1-hour min air
temperature
°C
1
max_air_temp_pst
1hr
past 1-hour max air
temperature
°C
1
max_air_temp_pst
6hrs
past 6 hours maximum air
temperature
°C
1
min_air_temp_pst
6hrs
past 6 hours minimum air
temperature
°C
1
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 43 of 111
max_air_temp_pst
24hrs
past 24 hours maximum
air temperature
°C
1
min_air_temp_pst
24hrs
past 24 hours minimum air
temperature
°C
1
avg_wnd_dir_10m
_pst2mts
Previously:
avg_wnd_dir_10m
_mt58-60
past 2-min vectoral
average 10m wind
direction
°
0
avg_wnd_spd_10
m_ pst2mts
Previously:
avg_wnd_spd_10
m_mt58-60
past 2-min average 10m
wind speed
km/h
1
max_wnd_gst_spd
_10m_pst10mts
Previously:
max_wnd_gst_spd
_10m_mt50-60
past 10-min max 10m
wind gust speed
km/h
1
avg_wnd_dir_10m
_pst10mts
Previously:
avg_wnd_dir_10m
_mt50-60
past 10-min vectoral
average 10m wind
direction
°
0
avg_wnd_spd_10
m_pst10mts
Previously:
avg_wnd_spd_10
m_mt50-60
past 10-min average 10m
wind speed
km/h
1
wnd_dir_10m_pst1
hr_pk_spd
past 1-hour peak 10m
wind speed direction
°
0
max_pk_wnd_spd
_10m_pst1hr
past 1-hour peak 10m
wind speed
km/h
1
pcpn_gag_wt_fltrd
gauge weight filtered
kg/m²
1
pcpn_amt_pst1hr
past 1-hour precipitation
amount
mm
1
altmetr_setng
altimeter setting
inHg
2
stn_pres
station pressure
hPa
1
mslp
mean sea level pressure
hPa
1
pres_tend_char_p
st3hrs
past 3-hour trend pressure
tendency characteristic
code
std_code_sr
c
tendency_char
acteristic
pres_tend_amt_ps
t3hrs
past 3-hour differential
pressure tendency amount
hPa
1
pres_tend_amt_ps
t1hr
past 1-hour differential
pressure tendency amount
hPa
1
rel_hum
derived relative humidity
%
0
pcpn_amt_pst3hrs
derived past 3-hour
accumulated precipitation
amount
mm
1
pcpn_amt_pst6hrs
derived past 6-hour
accumulated precipitation
amount
mm
1
pcpn_amt_pst24hr
s
derived past 24-hour
accumulated precipitation
amount
mm
1
pcpn_snc_last_sy
no_hr
precipitation since last
synoptic hour
mm
1
5.6 DND AWOS
The DND AWOS is a new generation Automatic Weather Observing System maintained and managed
by the Department of National Defence (DND). These AWOS stations are a direct replacement of
legacy MSC AWOS stations throughout the country, and are deployed in support of DND operations.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 44 of 111
Raw observations are collected by DND for processing before sending to MSC using a BUFR (Binary
Universal Form of Representation) message. The BUFR message contains multiple fields that are not
observed or reported by DND, and thus are either not included in the SWOB output or will always
have a value of MSNG. The observations are scheduled to be taken hourly at top of the hour, and
whenever there is significant weather change, in which case a ‘Special’ report is issued.
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#)
clim_id
climate identifier
unitless
msc_id
msc identifier
unitless
wmo_synop_id
WMO synoptic identifier
unitless
data_pvdr
data provider
unitless
data_attrib_not
data attribution notice
unitless
stn_nam
station name
unitless
stn_typ
station type
code
std_code_sr
c
station_type
rpt_typ
report type
code
std_code_sr
c
report_type
date_tm
date
datetime
lat
latitude
°
6
long
longitude
°
6
stn_elev
station elevation
m
3
icao_stn_id
icao station identifier
unitless
stn_pres
station pressure
hPa
1
mslp
mean sea level pressure
hPa
1
pres_tend_amt_pst
3hrs
past 3-hour differential
tendency amount
hPa
1
pres_tend_char_ps
t3hrs
past 3-hour trend pressure
tendency characteristic
code
std_code_sr
c
tendency_char
acteristic
altmetr_setng
altimeter setting
inHg
2
air_temp
air temperature
°C
1
dwpt_temp
dew point temperature
°C
1
rel_hum
relative humidity
%
0
max_air_temp_pst
24hrs
past 24-hour maximum air
temperature
°C
1
min_air_temp_pst2
4hrs
past 24-hour minimum air
temperature
°C
1
avg_vis_pst10mts
past 10-min average
horizontal visibility
km
3
max_vis_pst10mts
past 10-min maximum
horizontal visibility
km
3
min_vis_pst10mts
past 10-min minimum
2.83m horizontal visibility
km
3
cld_bas_hgt_#
cloud height
m
0
6
cld_amt_code_#
Cumulative cloud amount
coded (oktas) indexed by
layer
code
std_code_sr
c
total_cloud_a
mount
6
cld_lyr_amt_rptg_
mtd
cloud layer amount
reporting method
code
std_code_sr
c
cloud_amount
_reporting_me
thod
vert_vis
vertical visibility
m
3
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 45 of 111
prsnt_wx_#
present weather indexed
code
std_code_sr
c
present_weath
er
8
avg_wnd_dir_10m
_pst10mts
past 10-min average 10m
wind direction
°
0
avg_wnd_spd_10m
_pst10mts
past 10-min average 10m
wind speed
km/h
1
avg_wnd_dir_10m
_pst2mts
past 2-min average 10m
wind direction
°
0
avg_wnd_spd_10m
_pst2mts
past 2-min average 10m
wind speed
km/h
1
max_wnd_gst_spd
_10m_pst10mts
past 10-min maximum
10m wind gust speed
km/h
1
max_pk_wnd_spd_
10m_pst1hr
past 1-hour instantaneous
10m peak wind speed
km/h
1
wnd_dir_10m_pst1
hr_pk_spd
past 1-hour instantaneous
10m peak wind direction
°
0
wnd_dir_10m_pst1
hr_max_spd
past 1-hour maximum 10m
wind speed direction
°
0
max_wnd_spd_10
m_pst1hr
past 1-hour maximum 10m
wind speed
km/h
1
Typically observed elements that are not reported by this dataset:
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#)
pcpn_amt_pst1hr
past 1-hour accumulated
precipitation gauge
amount
mm
1
pcpn_amt_pst6hrs
past 6-hour accumulated
precipitation gauge
amount
mm
2
vpr_pres
vapour pressure
hPa
1
wetblb_temp
wet bulb temperature
°C
1
max_air_temp_pst1
hr
past 1-hour maximum air
temperature
°C
1
min_air_temp_pst1h
r
past 1-hour minimum air
temperature
°C
1
max_air_temp_pst6
hrs
past 6-hour maximum air
temperature
°C
1
min_air_temp_pst6h
rs
past 6-hour minimum air
temperature
°C
1
5.7 Nav Canada HWOS
NC-HWOS is the common name given to observation data transmitted by NAV CANADA’s (NC)
new software interface for manned observations. NC-HWOS is a direct replacement of
WinIDE/MIDS. The observing program is in support of aviation and most stations are located at
airports. Observers are expected to input weather conditions in accordance with the Manual of
Surface Observations (MANOBS). The output is a BUFR (Binary Universal Form of Representation)
message, which is not human readable. All the incoming elements, units and values that come from
within the actual BUFR are mapped to their desired elements, units, values and qualifiers by the DMS
and stored in XML format. These elements are then mapped to the short labels shown below.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 46 of 111
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#)
wmo_synop_id
WMO Identifier
unitless
data_pvdr
data provider
unitless
data_attrib_not
data attribution notice
unitless
stn_nam
station name
unitless
date_tm
official report date and
time
datetime
lat
latitude
°
6
long
longitude
°
6
stn_elev
station elevation
m
3
icao_stn_id
ICAO station identifier
unitless
clim_id
climate identifier
unitless
msc_id
MSC identifier
unitless
rpt_typ
report type
code
std_code_sr
c
report_type
stn_typ
station type
code
std_code_sr
c
station_type
cor
correction level
unitless
stn_pres
station pressure
hPa
1
mslp
Mean sea level pressure
hPa
1
pres_tend_amt_ps
t3hrs
past 3-hour differential
pressure tendency amount
hPa
1
pres_tend_char_p
st3hrs
past 3-hour trend of
pressure tendency
characteristic
code
std_code_sr
c
tendency_char
acteristic
altmetr_setng
altimeter settings
inHg
2
air_temp
2 m air temperature
°C
1
dwpt_temp
2 m dew point
Temperature
°C
1
rel_hum
2 m relative humidity
%
0
max_air_temp_pst
1hr
past 1-hour max 2 m Air
Temperature
°C
1
min_air_temp_pst
1hr
past 1-hour min 2 m air
temperature
°C
1
max_air_temp_pst
6hrs
past 6-hour max 2 m Air
Temperature
°C
1
min_air_temp_pst
6hrs
past 6-hour min 2 m air
temperature
°C
1
max_air_temp_pst
24hrs
past 24-hour max 2 m air
temperature
°C
1
min_air_temp_pst
24hrs
past 24-hour min 2 m air
temperature
°C
1
vis
prevailing horizontal
visibility
km
3
max_vis
maximum horizontal
visibility
km
3
min_vis
minimum horizontal
visibility
km
3
vert_vis
vertical visibility (in
meters)
m
3
prsnt_wx_#
present weather
code
std_code_sr
c
present_weath
er
5
recnt_wx_#
recent weather
code
std_code_sr
c
present_weath
er
3
tot_cld_amt
total cloud amount
%
0
cld_amt_code_#
non-cumulative cloud
amount coded (oktas)
indexed by layer
code
std_code_sr
c
total_cloud_a
mount
5
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 47 of 111
cld_bas_hgt_#
cloud base height
m
0
5
cld_typ_#
cloud type
code
std_code_sr
c
obscuring_phe
nomena
5
avg_wnd_dir_10m
_pst10mts
Previously:
avg_wnd_dir_10m
_mt50-60
10-minute average 10m
wind direction
°
0
avg_wnd_spd_10
m_pst10mts
Previously:
avg_wnd_spd_10
m_mt50-60
10-minute average 10m
wind speed
km/h
1
avg_wnd_dir_10m
_pst2mts
Previously:
avg_wnd_dir_10m
_mt58-60
2-minute average 10m
wind direction
°
0
avg_wnd_spd_10
m_pst2mts
Previously:
avg_wnd_spd_10
m_mt58-60
2-minute average 10m
wind speed
km/h
1
max_wnd_gst_spd
_10m_pst10mts
Previously::
max_wnd_gst_spd
_10m_mt50-60
10-minute max 10 m wind
gust speed
km/h
1
wnd_dir_10m_pst2
4hrs_pk_spd
wind direction associated
with the past 24-hour peak
wind speed at 10 m
°
0
max_pk_wnd_spd
_10m_pst24hrs
past 24-hour maximum
peak 2-minute mean 10m
wind speed
km/h
1
rnfl_snc_last_syno
_hr
rainfall since last synoptic
hour (TBRG)
mm
1
pcpn_amt_pst6hrs
past 6-hour accumulated
1.5 m precipitation gauge
amount
mm
1
pcpn_amt_pst24hr
s
past 24-hour accumulated
1.5 m precipitation gauge
amount
mm
1
snw_dpth
snow depth
cm
0
rmk
remark
unitless
5.8 Nav Canada AWOS
NC-AWOS is the common name given to observation data gathered by NAV CANADA’s (NC) new
automated weather observation system (AWOS). The observing program is in support of aviation and
most stations are located at airports. NC-AWOS is a new generation system intended to replace the
MSC’s legacy AWOS. It is encoded in a defined BUFR template created by NC and EC. Although a
replacement of the legacy AWOS, NC-AWOS is not a direct data replacement. There are data content
gains, losses and differences in comparison to the MSC legacy AWOS system. The output is a BUFR
(Binary Universal Form of Representation) message, which is not human readable. All the incoming
elements, units and values that come from within the actual BUFR are mapped to their desired
elements, units, values and qualifiers by the DMS and stored in XML format. These elements are then
mapped to the short labels shown in the table below.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 48 of 111
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#)
clim_id
climate identifier
unitless
msc_id
msc identifier
unitless
wmo_synop_id
WMO synoptic identifier
unitless
data_pvdr
data provider
unitless
data_attrib_not
data attribution notice
unitless
stn_nam
station name
unitless
stn_typ
station type
code
std_code_sr
c
station_type
rpt_typ
report type
code
std_code_sr
c
report_type
date_tm
date
datetime
lat
latitude
°
6
long
longitude
°
6
stn_elev
station elevation
m
3
icao_stn_id
icao station identifier
unitless
stn_pres
station pressure
hPa
1
mslp
mean sea level pressure
hPa
1
pres_tend_amt_ps
t3hrs
past 3-hour differential
tendency amount
hPa
1
pres_tend_char_p
st3hrs
past 3-hour trend pressure
tendency characteristic
code
std_code_sr
c
tendency_char
acteristic
altmetr_setng
altimeter setting
inHg
2
air_temp
2m air temperature
°C
1
dwpt_temp
2m dew point temperature
°C
1
rel_hum
2m relative humidity
%
0
max_air_temp_pst
1hr
past 1-hour maximum 2m
air temperature
°C
1
min_air_temp_pst
1hr
past 1-hour minimum 2m
air temperature
°C
1
max_air_temp_pst
6hrs
past 6-hour maximum 2m
air temperature
°C
1
min_air_temp_pst
6hrs
past 6-hour minimum 2m
air temperature
°C
1
max_air_temp_pst
24hrs
past 24-hour maximum 2m
air temperature
°C
1
min_air_temp_pst
24hrs
past 24-hour minimum 2m
air temperature
°C
1
avg_vis_pst10mts
Previously:
vis
10-min average horizontal
visibility
km
3
max_vis_pst10mts
Previously:
max_vis_mt50-60
10-min maximum
horizontal visibility
km
3
min_vis_pst10mts
Previously:
min_vis_mt50-60
10-min minimum
horizontal visibility
km
3
cld_bas_hgt_#
cloud height
m
0
6
cld_amt_code_#
Cumulative cloud amount
coded (oktas) indexed by
layer
code
std_code_sr
c
total_cloud_a
mount
6
vert_vis
vertical visibility
m
3
prsnt_wx_#
present weather indexed
code
std_code_sr
c
present_weath
er
8
avg_wnd_dir_10m
10-min average 10m wind
°
0
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 49 of 111
_pst10mts
Previously:
avg_wnd_dir_10m
_mt50-60
direction
avg_wnd_spd_10
m_pst10mts
Previously:
avg_wnd_spd_10
m_mt50-60
10-min average 10m wind
speed
km/h
1
avg_wnd_dir_10m
_pst2mts
Previously:
avg_wnd_dir_10m
_mt58-60
2-min average 10m wind
direction
°
0
avg_wnd_spd_10
m_pst2mts
Previously
avg_wnd_spd_10
m_mt58-60
2-min average 10m wind
speed
km/h
1
max_wnd_gst_spd
_10m_pst10mts
Previously:
max_wnd_gst_spd
_10m_mt50-60
10-min maximum 10m
wind gust speed
km/h
1
max_pk_wnd_spd
_10m_pst1hr
past 1-hour instantaneous
10m peak wind speed
km/h
1
wnd_dir_10m_pst1
hr_pk_spd
past 1-hour instantaneous
10m peak wind direction
°
0
wnd_dir_10m_pst1
hr_max_spd
past 1-hour maximum 10m
wind speed direction
°
0
max_wnd_spd_10
m_pst1hr
past 1-hour maximum 10m
wind speed
km/h
1
pcpn_amt_pst1hr
past 1-hour accumulated
1.5 m precipitation gauge
amount
mm
1
pcpn_amt_pst6hrs
past 6-hour accumulated
1.5 m precipitation gauge
amount
mm
2
5.9 MSC & Partner surface weather network (Campbell Sci. CA messages)
The primary focus of the Public Surface Weather network is to support weather forecasting and
climate monitoring. Observations are reported hourly, typically from data logger output tables 11 or
160. Campbell Scientific data loggers are the data acquisition system used in this network to obtain
data from sensors, as well as process, store, and transmit the data. The data loggers encode the
observations and transmit via the Datalogger Retrieval System on a one-observation to one-file basis.
The file is transmitted to the Canadian Meteorological Centre (CMC) under the bulletin header CA.
CMC then makes the file available to the rest of EC. The raw files are paired with a configuration file
from JICC, which has information on element position, name and unit, to decode the CVS file format.
Sample of CA bulletin:
Table 160
CACN00 CWAO 121300
XQA
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 50 of 111
160,2010,132,1300,1583,100,152,-
15.84,85.4,3.774,3.77,142.4,2.584,5.639,1203,128.9,5.375,0,4.15,4.13,135.9,5.661,4.801,4.946,-
16.38,86.6,4.524,4.465,134,9.26,-15.83,-17.14,-12.95,12.32,1079,213.1,0,0.076,0.112,0.112, 0.158,-
10.14,-10.09,162,15
The resulting decoded elements are mapped to their desired element names, units, values and
qualifiers by the DMS and stored in XML format. These elements are then mapped to the short labels
shown below.
Label Name
Description
Standard
Units
Standa
rd
Code
Source
Standa
rd
Code
Type
Precision
Maximum
Multiplicit
y (_#_
wmo_synop_id
wmo identifier
unitless
stn_nam
station name
unitless
tc_id
TC identifier
unitless
clim_id
climate identifier
unitless
msc_id
MSC identifier
unitless
stn_elev
station elevation
m
3
lat
latitude
°
6
long
longitude
°
6
date_tm
date and time
datetime
data_pvdr
data provider
unitless
data_avail
data availability
%
0
logr_panl_temp
datalogger panel
temperature
°C
1
max_batry_volt_p
st1hr
past 1-hour maximum
battery voltage
V
2
min_batry_volt_ps
t1hr
past 1-hour minimum
battery voltage
V
2
hdr_fwd_pwr
HDR (High Data Rate)
transmitter forward
power
W
2
hdr_refltd_pwr
HDR (High Data Rate)
transmitter reflected
power
W
2
hdr_suply_volt
HDR (High Data Rate)
transmitter supply
voltage
V
2
hdr_oscil_drft
HDR (High Data Rate)
transmitter oscillator drift
Hz
2
avg_uvb_indx_pst
1hr
5-minute average UVB
index in past 1-hour
unitless
rel_hum
relative humidity
%
0
max_rel_hum_pst
1hr
past 1-hour maximum
relative humidity
%
0
min_rel_hum_pst
1hr
past 1-hour minimum
relative humidity
%
0
avg_rel_hum_pst
1hr
past 1-hour average
relative humidity
%
0
rnfl_amt_pst1hr
past 1-hour rainfall
amount (TBRG)
mm
1
avg_cum_pcpn_g
ag_wt_fltrd_pst5m
ts
Previously: avg_
avg_cum_pcpn_g
5-minute cumulative
precipitation gauge
weight (filtered)
kg/m²
1
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 51 of 111
ag_wt_fltrd_55-60
avg_cum_pcpn_g
ag_wt_fltrd_pst5m
ts_#
5-minute cumulative
precipitation gauge
weight (filtered) min55-
60 (indexed)
kg/m²
1
3
pcpn_amt_pst1hr
past 1-hour precipitation
amount
mm
1
pcpn_amt_pst1hr
_#
past 1-hour precipitation
amount (indexed)
mm
1
2
pcpn_amt_pst3
hrs
past 3-hour precipitation
amount
mm
1
pcpn_amt_pst24
hrs
past 24-hour
precipitation amount
mm
1
pcpn_snc_last_sy
no_hr
precipitation since last
synoptic hour
mm
1
air_temp
1-min average air
temperature
°C
1
air_temp_#
1-min average air
temperature (indexed).
°C
1
3
avg_air_temp_pst
1hr
past 1-hour average air
temperature
°C
1
avg_air_temp_pst
1hr_#
past 1-hour average air
temperature (indexed)
°C
1
3
max_air_temp_ps
t1hr
past 1-hour maximum
air temperature
°C
1
max_air_temp_ps
t1hr_#
past 1-hour maximum
air temperature
(indexed)
°C
1
3
min_air_temp_pst
1hr
past 1-hour minimum air
temperature
°C
1
min_air_temp_pst
1hr_#
past 1-hour minimum air
temperature (indexed)
°C
1
3
max_air_temp_ps
t6hrs
past 6-hour maximum
(1-minute average)
hourly air temperature
°C
1
min_air_temp_pst
6hrs
past 6-hour minimum (1-
minute average) hourly
air temperature
°C
1
max_air_temp_ps
t24hrs
past 24-hour maximum
(1-minute average)
hourly air temperature
°C
1
min_air_temp_pst
24hrs
past 24-hour minimum
(1-minute average)
hourly air temperature
°C
1
dwpt_temp
dew point temperature
(top of the hour)
°C
1
wetblb_temp
wet bulb temperature
(top of hour)
°C
1
avg_wetblb_temp
_pst24hrs
past 24-hour average (1-
minute average) wetbulb
temperature
°C
1
avg_wnd_spd_pc
pn_gag_pst10mts
Previously:
avg_wnd_spd_pc
pn_gag_mt50-60
10-minute average wind
speed at the height of
the precipitation gauge
(approx. 2 m in most
cases)
km/h
1
avg_wnd_spd_10
m_pst10mts
Previously:
avg_wnd_spd_10
m_mt50-60
10-minute average 10 m
wind speed
km/h
1
avg_wnd_spd_10
m_pst10mts_#
10-minute average 10 m
wind speed (indexed)
km/h
1
2
avg_wnd_dir_10m
_pst10mts
Previously:
avg_wnd_dir_10m
_mt50-60
10-minute vector
average 10 m wind
direction
°
0
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 52 of 111
avg_wnd_dir_10m
_pst10mts_#
10-minute vector
average 10 m wind
direction (indexed)
°
0
2
avg_wnd_spd_10
m_pst2mts
Previously:
avg_wnd_spd_10
m_mt58-60
2-minute average 10 m
wind speed
km/h
1
avg_wnd_spd_10
m_pst2mts _#
2-minute average 10 m
wind speed (indexed)
km/h
1
2
avg_wnd_dir_10m
_pst2mts
Previously:
avg_wnd_dir_10m
_mt58-60
2-minute vector average
10 m wind direction
°
0
avg_wnd_dir_10m
_pst2mts_#
2-minute vector average
10 m wind direction
(indexed)
°
0
2
avg_wnd_spd_10
m_pst1hr
past 1-hour average 10
m wind speed
km/h
1
avg_wnd_spd_10
m_pst1hr_#
past 1-hour average 10
m wind speed (indexed)
km/h
1
2
avg_wnd_dir_10m
_pst1hr
past 1-hour vector
average 10 m wind
direction
°
0
avg_wnd_dir_10m
_pst1hr_#
past 1-hour vector
average 10 m wind
direction (indexed)
°
0
2
max_wnd_spd_10
m_pst10mts
Previously:
max_wnd_spd_10
m_mt50-60
10-minute max 10 m
wind speed
km/h
1
max_wnd_spd_10
m_pst10mts_#
10-minute max 10 m
wind speed (indexed)
km/h
1
2
wnd_dir_10m_pst
10mts_max_spd
Previously:
wnd_dir_10m_mt
50-60_max_spd
Instantaneous 10 m
wind direction for max
10-minute wind speed
°
0
wnd_dir_10m_pst
10mts_max_spd_
#
Instantaneous 10 m
wind direction for max
10-minute wind speed
(indexed)
°
0
2
max_wnd_spd_10
m_pst1hr
1-hour max 10 m wind
speed
km/h
1
max_wnd_spd_10
m_pst1hr_#
1-hour max 10 m wind
speed (indexed)
km/h
1
2
wnd_dir_10m_pst
1hr_max_spd
Instantaneous 10 m
wind direction for max
hourly wind speed
°
0
wnd_dir_10m_pst
1hr_max_spd_#
Instantaneous 10 m
wind direction for max
hourly wind speed
(indexed)
°
0
2
max_wnd_spd_ps
t1hr_tm
Time of max hourly 10 m
wind speed
hhmm
1
max_wnd_spd_ps
t1hr_tm_#
Time of max hourly 10 m
wind speed (indexed)
hhmm
1
2
max_wnd_gst_sp
d_10m_pst10mts
Previously:
max_wnd_gst_sp
d_10m_mt50-60
10-min max 10m wind
gust speed
km/h
1
wnd_dir_10m_pst
1hr_pk_spd
past 1-hour peak instant
wind direction at 10m
°
0
max_pk_wnd_spd
_10m_pst1hr
past 1-hour peak
instantaneous wind
speed at 10 m
km/h
1
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 53 of 111
max_pk_wnd_tm_
pst1hr
past 1-hour peak
instantaneous wind
speed time
datetime
pk_wnd_rmk
derived peak wind
remark
unitless
stn_pres
station pressure (top of
hour)
hPa
1
mslp
mean sea level pressure
(top of the hour)
hPa
1
pres_tend_amt_p
st3hrs
past 3-hour differential
pressure tendency
amount
hPa
1
pres_tend_char_p
st3hrs
past 3-hour differential
pressure tendency
characteristic
code
std_cod
e_src
tendenc
y_chara
cteristic
avg_snw_dpth_ps
t5mts
Previously:
snw_dpth
5-min average snow
depth
cm
0
avg_snw_dpth_ps
t5mts_#
Previously:
snw_dpth_#
5-min average snow
depth (indexed). Only
present if an official
value from the three
input snow depths could
not be determined.
cm
0
3
avg_snw_dpth_ps
t1hr
past 1-hour average
snow depth
cm
0
max_vis_pst1hr
past 1-hour maximum
horizontal visibility
km
3
avg_globl_solr_ra
dn_pst1hr
past 1-hour average
global solar radition
(RF1)
W/m2
1
tot_globl_solr_rad
n_pst1hr
past 1-hour total global
solar radition (RF1)
kJ/m2
1
5.10 PanAm – Minutely MSC & Partner surface weather network - COMPACT
A temporary MSC mesonet installed to support the 2015 PanAm Games. Atmospheric weather data
are collected and output on a minutely basis. The stations are self-contained on a single portable
platform that allows for the stations to be easily moved and deployed when and where needed. Most
stations are deployed at ground level at or near venues, but some are on structures or rooftops (see
wind note in section 5.2.1). Campbell Scientific data loggers are the data acquisition system used in
this network to obtain data from sensors, as well as process, store, and transmit the data. The data
loggers encode the observations and transmit via the Datalogger Retrieval System on a one-
observation to one-file basis. The raw files are paired with a configuration file from JICC (using
Table 63), which has information on element position, names and units, to decode the CVS file format.
The minutely observed values are then used to derive additional minutely, hourly and daily elements.
These are then mapped to the short labels below.
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
wmo_synop_id
wmo identifier
unitless
stn_nam
station name
unitless
tc_id
TC identifier
unitless
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 54 of 111
clim_id
climate identifier
unitless
msc_id
MSC identifier
unitless
stn_elev
station elevation
m
3
lat
latitude
°
6
long
longitude
°
6
date_tm
date and time
datetime
data_avail_pst1hr
data availability
%
0
data_avail_pst1mt
data availability
%
0
min_batry_volt_pst1mt
past 1-minute minimum battery
voltage
V
2
min_batry_volt_pst1hr
past 1-hour minimum battery
voltage
V
2
max_batry_volt_pst1mt
past 1-minute maximum battery
voltage
V
2
max_batry_volt_pst1hr
past 1-hour maximum battery
voltage
V
2
logr_panl_temp
datalogger panel temperature
°C
1
air_temp
Previously:
avg_air_temp_pst1mt
1-min average air temperature
°C
1
rel_hum
Previously:
avg_rel_hum_pst1mt
1-minute average relative
humidity
%
0
max_rel_hum_pst1mt
1-minute maximum relative
humidity
%
0
min_rel_hum_pst1mt
1-minute minimum relative
humidity
%
0
dwpt_temp
Previously:
avg_dwpt_temp_pst1mt
1-minute average dew point
temperature
°C
1
wetblb_temp
Previously:
avg_wetblb_temp_pst1mt
1-minute average wet bulb
temperature
°C
1
stn_pres
Previously:
avg_stn_pres_pst1mt
1-minute average station
pressure
hPa
1
avg_wnd_spd_10m_pst1mt
1-minute average wind speed
km/h
1
avg_wnd_dir_10m_pst1mt
1-minute vector average wind
direction
°
0
max_wnd_spd_10m_pst1m
t
1-minute maximum wind speed
km/h
1
wnd_dir_10m_pst1mt_max
_spd
1-minute vector average wind
direction
°
0
max_wnd_spd_10m_pst10
mts
10-minute maximum wind speed
km/h
1
wnd_dir_10m_pst10mts_m
ax_spd
1-minute vector average wind
direction
°
0
max_wnd_spd_10m_pst1hr
1-hour maximum wind speed
km/h
1
wnd_dir_10m_pst1hr_max_
spd
1-hr vector average wind
direction
°
0
max_wnd_spd_10m_pst1hr
_tm
1-hour maximum wind speed
hhmm
1
avg_wnd_spd_10m_pst1hr
past 1-hour average wind speed
km/h
1
avg_wnd_dir_10m_pst1hr
past 1-hour vector average wind
direction
°
0
avg_wnd_spd_10m_pst10
mts
past 10-minute average wind
speed
km/h
1
avg_wnd_dir_10m_pst10mt
s
past 10-minute vector average
wind direction
°
0
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 55 of 111
avg_wnd_spd_10m_pst2mt
s
past 2-minute average wind
speed
km/h
1
avg_wnd_dir_10m_pst2mts
past 2-minute vector average
wind direction
°
0
mslp
Previously:
avg_mslp_pst1mt
past 1-minute average mean
sea level pressure
hPa
1
avg_dwpt_temp_pst1hr
1-hour average dew point
temperature
°C
1
max_rel_hum_pst1hr
1-hour maximum relative
humidity
%
0
min_rel_hum_pst1hr
1-hour minimum relative
humidity
%
0
avg_air_temp_pst1hr
past 1-hour average air
temperature
°C
1
max_air_temp_pst1hr
past 1-hour maximum air
temperature
°C
1
min_air_temp_pst1hr
past 1-hour minimum air
temperature
°C
1
avg_rel_hum_pst1hr
past 1-hour average relative
humidity
%
0
rnfl_amt_pst1hr
past 1-hour rainfall amount
(TBRG)
mm
1
pcpn_amt_pst1hr
past 1-hour precipitation amount
mm
1
pcpn_amt_pst1mt
past 1-minute precipitation
amount
mm
1
pcpn_amt_pst10mts
past 10-minute precipitation
amount
mm
1
pcpn_typ_pst1mt
past 1-minute precipitation
amount
code
std_code_sr
c
present_weat
her
1
pcpn_amt_snc_top_of_hr
precipitation amount since top of
the hour
mm
1
max_wnd_gst_spd_10m_p
st10mts
10-min max wind gust speed
km/h
1
wnd_dir_10m_pst1hr_pk_s
pd
past 1-hour peak instantaneous
wind direction
°
0
max_pk_wnd_spd_10m_ps
t1hr
past 1-hour peak instantaneous
wind speed
km/h
1
5.11 OPP Moored Buoy
The Ocean Protection Plan is the largest Government of Canada (GoC) undertaking to improve marine
safety and responsible shipping, protect Canada's marine environment, and offer new possibilities for
Indigenous and coastal communities. Towards this effort Environment and Climate Change Canada is
mandated to deploy new moored buoys along the Pacific and Atlantic coasts. These buoys will report
hourly weather, wave and housekeeping (diagnostic) data in CSV (comma separated value) format
over the Iridium satellite network. The data will be processed in real-time, quality assessed and
products such as WMO synoptic and SWOB will be generated and disseminated to their respective
end-points. Additionally, MSC forecasters will use the OPP data in NinJo (forecaster workstation) to
produce accurate and localized coastal marine forecasts towards fulfilling GoC OPP objectives.
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#_
wmo_synop_id
wmo identifier
unitless
stn_nam
station name
unitless
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 56 of 111
msc_id
MSC identifier
unitless
stn_elev
station elevation
m
3
lat
latitude
°
6
long
longitude
°
6
date_tm
date and time
datetime
buoy_typ
type of buoy
code
std_code_sr
c
buoy_type
rpt_typ
report type
code
std_code_sr
c
report_type
crnt_buoy_lat
current buoy latitude
°
6
crnt_buoy_long
current buoy longitude
°
6
avg_crnt_volt_pst10mts
10-minute average current
voltage
V
1
1
avg_solr_panl_crnt_pst10m
ts
10-minute average solar panel
current
A
2
1
avg_batry_volt_pst10mts
10-minute average battery
voltage
V
1
1
avg_air_temp_pst10mts
10-min average air temperature
°C
1
1
avg_stn_pres_pst10mts
10-minute average station
pressure
hPa
1
2
avg_sea_sfc_temp_pst10m
ts
10-minute sea surface
temperature
°C
1
1
avg_wnd_spd_pst10mts
10-minute average wind speed
km/h
1
2
avg_wnd_dir_pst10mts
10-minute vector average wind
direction
°
0
2
max_avg_wnd_spd_pst10
mts
10-minute maximum average
wind speed
km/h
1
2
wnd_snsr_vert_disp
vertical displacement of the wind
sensors
m
1
2
pk_wave_pd_pst20mts
20-minute peak wave period
s
1
1
pk_wave_hgt_pst20mts
20-minute peak wave height
m
1
1
sig_wave_pd_pst20mts
20-minute significant wave
period
s
1
1
sig_wave_hgt_pst20mts
20-minute significant wave
height
m
1
1
avg_wave_pd_pst20mts
20-minute average wave period
s
1
1
avg_wave_hgt_pst20mts
20-minute average wave height
m
1
1
avg_max_wave_pd_pst20
mts
20-minute maximum average
wave period
s
1
1
avg_max_wave_hgt_pst20
mts
20-minute maximum average
wave height
m
1
1
avg_mslp_pst10mts
10-minute average mean sea
level pressure
hPa
1
1
pres_tend_amt_pst3hrs
3-hour pressurent tendency
amount
hPa
1
1
pres_tend_char_pst3hrs
3-hour pressure tendency
characteristic
code
std_code_sr
c
tendency_char
acteristic
5.12 BC Ministry of Transportation & Infrastructure (BC-TRAN)
British Columbia Ministry of Transportation and Infrastructure (BC-TRAN) operates a network of
automatic weather stations along its highways throughout the province. This network resets
accumulations and measurement intervals for statistics at 0600 and 1800 Pacific Standard Time daily.
Environment Canada retrieves the data from BC-TRAN server in CSV format and ingests into the
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 57 of 111
DMS. The resulting decoded elements are mapped to the corresponding DMS elements, units, values
and qualifiers and stored in XML format. These elements are then mapped to the short labels shown
below.
Label Name
Description
Standard
Units
Standard
Code Source
Standard Code
Type
Precision
lat
Latitude
°
6
long
Longitude
°
6
stn_elev
Station elevation
m
msc_id
MSC identifier
unitless
stn_id
Station identifier
unitless
stn_nam
Station name
unitless
stn_shrt_nam
Station short name
unitless
date_tm
Date and time
datetime
data_pvdr
Data provider
unitless
data_attrib_not
Data attribution notice
unitless
stn_pres
Station pressure
hPa
max_wnd_spd_10
m_pst1hr
Past 1-hr maximum 10 m
wind speed
km/h
1
avg_wnd_spd_10
m_pst10mts
Past 10-min average 10 m
wind speed
km/h
1
avg_wnd_dir_10m
_pst10mts
Past 10-min vector
average 10 m wind
direction
°
0
air_temp
Air temperature
°C
max_air_temp_sn
c_last_reset
Maximum air temperature
since last reset
°C
min_air_temp_snc
_last_reset
Minimum air temperature
since last reset
°C
dwpt_temp
Dew point temperature
°C
pcpn_amt_pst1hr
Precipitation amount past
1-hr
mm
1
pcpn_snc_last_res
et
Precipitation amount since
last reset
mm
1
pcpn_dctn
Precipitation detected
unitless
pcpn_msrmnt_mtd
Precipitation measurement
method
code
std_code_src
precipitation_meas
urement_method
pcpn_amt_pst3hrs
Precipitation amount past
3 hrs
mm
1
pcpn_amt_pst6hrs
Precipitation amount past
6 hrs
mm
1
pcpn_amt_pst12hr
s
Precipitation amount past
12 hrs
mm
1
pcpn_amt_pst24hr
s
Precipitation amount past
24 hrs
mm
1
rel_hum
Relative humidity
%
snw_dpth
Adjacent snow depth
cm
0
snwfl_snc_last_re
set
Snowfall amount since last
reset
cm
0
snwfl_amt_pst1hr
Snowfall amount past 1-hr
cm
0
mslp
Mean sea level pressure
hPa
1
last_reset_date_t
m
Last reset date time
datetime
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 58 of 111
5.13 BC Wildfire Management Branch (BC-FLNR-WMB)
British Columbia Ministry of Forests, Lands and Natural Resources - Wildfire Management Branch,
commonly known as BC forestry, operates approximately 260 hourly automated weather stations to
support fire weather forecasting and the Canadian Forest Fire Danger Rating System. BC forestry
encodes the data from all stations into single ASCII file and it is retrieved by EC. The resulting
decoded elements are mapped to the corresponding DMS elements, units, values and qualifiers and
stored in XML format. These elements are then mapped to the short labels shown below.
Label Name
Description
Standard
Units
Standard
Code Source
Standard Code
Type
Precision
msc_id
MSC identifier
unitless
stn_id
Station identifier
unitless
stn_nam
Station name
unitless
lat
Latitude
°
6
long
Longitude
°
6
stn_elev
Station elevation
m
3
date_tm
Date and time
datetime
data_pvdr
Data provider
unitless
data_attrib_not
Data attribution notice
unitless
rnfl_amt_pst1hr
Rainfall amount past 1-
hour
mm
1
rnfl_amt_pst6hrs
Rainfall amount past 6
hours
mm
1
rnfl_amt_pst3hrs
Rainfall amount past 3
hours
mm
1
rnfl_amt_pst24hrs
Rainfall amount past 24
hours
mm
1
air_temp
Air temperature
°C
1
rel_hum
Relative humidity
%
0
avg_wnd_dir_10m
_pst10mts
Past 10-min vector
average 10 m wind
direction
°
0
avg_wnd_spd_10
m_pst10mts
Past 10-min average 10 m
wind speed
km/h
1
pcpn_amt_pst1hr
Precipitation amount past
1-hour
mm
1
snw_dpth
Snow depth
cm
0
pcpn_msrmnt_mtd
Precipitation measurement
method
code
std_code_src
precipitation_meas
urement_method
5.14 BC Ministry of Environment and Climate Change Strategy-Air Quality (BC-
ENV-AQMet)
British Columbia Ministry of Environment and Climate Change Strategy (BC ENV) operates a network of
weather stations for the purpose of air quality monitoring. BC ENV operates approximately 50
meteorological monitoring stations that transmit data via cellular or telephone telemetry to a central
database every hour. Hourly data is retrieved from BC ENV in a CSV format and ingested into the DMS.
The resulting decoded elements are mapped to the corresponding DMS elements, units, values and
qualifiers and stored in XML format. There elements are then mapped to the short labels shown below.
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 59 of 111
Label Name
Description
Standard
Units
Standard Code
Source
Standard Code
Type
Precision
stn_nam
station name
unitless
msc_id
msc identifier
unitless
lat
latitude
°
6
long
longitude
°
6
stn_elev
station elevation
m
3
data_pvdr
data provider
unitless
data_attrib_not
data attribution notice
unitless
date_tm
date
datetime
stn_id
station id
unitless
pcpn_msrmnt_mtd
precipitation measurement
method
code
avg_rel_hum_pst1hr
past 1-hour relative humidity
%
0
avg_stn_pres_pst1hr
past 1-hour station pressure
kPa
1
avg_vpr_pres_pst1hr
past 1-hour vapour pressure
kPa
wnd_gst_spd_pst1hr_tm
past 1-hour wind gust speed
km/h
avg_cum_pcpn_gag_wt_pst
1mt
Past 1-minute cumulative
precipitation gauge weight
mm
1
avg_1mt_wnd_dir_10m_pst
1hr_max_avg_1mt_wnd_sp
d
Past 1-hour average 10m wind
direction of maximum 1-minute
mean wind speed
°
max_1mt_avg_wnd_spd_1
0m_pst1hr
past 1-hour maximum 10m 1-
minute mean wind speed
km/h
1
std_dev_wnd_spd_sclr_10
m_pst1hr
past 1-hour standard deviation
10m scalar wind speed
km/h
1
avg_wnd_spd_sclr_10m_ps
t1hr
past 1-hour average 10m scalar
wind speed
km/h
avg_wnd_dir_std_dev_10m
_pst1hr
past 1-hour standard deviation
10m wind direction based on 4
15 minute sub-intervals
°
avg_unit_vtr_wnd_dir_10m
_pst1hr
past 1-hour average 10m unit
vector wind direction
°
max_wnd_gst_spd_10m_ps
t1hr
past 1-hour maximum 10m wind
gust speed
km/h
1
std_dev_wnd_dir_10m_pst
1hr
past 1-hour standard deviation
10m wind direction
°
0
avg_wnd_dir_10m_pst1hr
past 1-hour average 10m wind
direction
°
0
max_wnd_spd_10m_pst1hr
past 1-hour maximum 10m wind
speed
km/h
1
avg_wnd_spd_10m_pst1hr
past 1-hour average 10m wind
speed
km/h
1
snw_snsr_sgnl_qlty
snow sensor signal quality
unitless
weighng_gag_stat
weighing gauge status
unitless
data_avail_pst1hr
past 1-hour data availability
%
dwpt_temp
dew point temperature
°C
1
avg_air_temp_pst1hr
past 1-hour average air
temperature
°C
1
avg_globl_solr_radn_pst1hr
past 1-hour global solar
radiation
W/m2
1
snw_dpth
snow depth
cm
0
pcpn_amt_pst1hr
past 1-hour precipitation amount
mm
1
pcpn_amt_pst3hrs
past 3-hour precipitation amount
mm
1
pcpn_amt_pst6hrs
past 6-hour precipitation amount
mm
1
pcpn_amt_pst12hrs
past 12-hour precipitation
amount
mm
1
pcpn_amt_pst24hrs
past 24-hour precipitation
amount
mm
1
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 60 of 111
5.15 BC Ministry of Environment and Climate Change Strategy-Snow Weather
(BC-ENV-SnowWx)
British Columbia Ministry of Environment and Climate Change Strategy (BC ENV) operates a network of
automatic weather stations that report snow, precipitation, and temperature values. This network utilizes
GOES for transmitting observations from the station to a central processor. GOES transmissions are routed
through the GTS where they are retrieved by ECCC hourly and ingested into the DMS. The resulting
decoded elements are mapped to the corresponding DMS elements, units, values and qualifiers and stored
in XML format. There elements are then mapped to the short labels shown below.
Label Name
Description
Standard
Units
Standard
Code
Source
Standard
Code Type
Precision
Maximum
Multiplicity
(_#_
stn_nam
station name
unitless
msc_id
msc identifier
unitless
lat
latitude
°
6
long
longitude
°
6
stn_elev
station elevation
m
3
data_pvdr
data provider
unitless
data_attrib_not
data attribution notice
unitless
date_tm
date
datetime
nesdis_id
NESDIS Identifier
unitless
air_temp_#
current air temperature
°C
1
2
air_temp_1hr_ago_#
air temperature 1 hour ago
°C
1
2
air_temp_2hrs_ago_#
air temperature 2 hours ago
°C
1
2
snw_dpth_wtr_equiv
snow depth water equivalence
cm
1
snw_dpth_wtr_equiv_1hr_a
go
snow depth water equivalence 1
hour ago
cm
1
snw_dpth_wtr_equiv_2hrs_
ago
snow depth water equivalence 2
hours ago
cm
1
snw_dpth
snow depth
mm
0
snw_dpth_1hr_ago
snow depth 1 hour ago
mm
0
snw_dpth_2hrs_ago
snow depth 2 hours ago
mm
0
cum_pcpn_amt
cumulative rainfall amount
mm
1
cum_pcpn_amt_1hr_ago
cumulative rainfall amount 1
hour ago
mm
1
cum_pcpn_amt_2hrs_ago
cumulative rainfall amount 2
hours ago
mm
1
batry_volt
battery voltage
V
batry_volt_1hr_ago
battery voltage 1 hour ago
V
2
batry_volt_2hrs_ago
battery voltage 2 hours ago
V
2
solr_volt
solar voltage
V
2
solr_volt_1hr_ago
solar voltage 1 hour ago
V
2
solr_volt_2hrs_ago
solar voltage 2 hours ago
V
2
trans_batry_volt
transmitter voltage
V
trans_batry_volt_1hr_ago
transmitter voltage 1 hour ago
V
2
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 61 of 111
trans_batry_volt_2hrs_ago
transmitter voltage 2 hours ago
V
2
wtr_lvl_1hr_ago
water level
m
1
wtr_lvl_2hrs_ago
water level 2 hours ago
m
snw_dpth_qlty
snow depth quality
unitless
snw_dpth_qlty_1hr_ago
snow depth quality 1 hour ago
unitless
snw_dpth_qlty_2hrs_ago
snow depth quality 2 hours ago
unitless
wtr_temp
water temperature
C
1
wtr_temp_1hr_ago
water temperature 1 hour ago
C
1
wtr_temp_2hrs_ago
water temperature 2 hours ago
C
1
pcpn_amt_pst1hr
past 1-hour precipitation amount
mm
1
pcpn_amt_pst3hrs
past 3-hour precipitation amount
mm
1
pcpn_amt_pst6hrs
past 6-hour precipitation amount
mm
1
pcpn_amt_pst12hrs
past 12-hour precipitation
amount
mm
1
pcpn_amt_pst24hrs
past 24-hour precipitation
amount
mm
1
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 62 of 111
6. Appendices
6.1 Glossary
Term
Abbreviation For:
Definition
ASCII
American Standard Code for Information
Interexchange
a code for representing data as numbers, with each
character assigned a number from 0 to 127
ATMOS
Automated Transportable Meteorological
Observing System
automatic surface weather stations (using Campbell
data loggers) operated by EC’s Science and
Technology Branch
AWOS
Automated Weather Observing Station
weather stations that use automated sensors to
report weather observations
BDQ
Base de Données Qualifiées
decoding and Qa/Qc software used in Quebec
Region
BUFR
Binary Universal Format for Representation
a binary WMO code form used to transmit numerical
or quantitative data
CA
Campbell
an ASCII CVS file containing data recoded by a
Campbell Scientific data logger
CMC
Canadian Meteorological Centre
provides forecast guidance to national and regional
prediction centres
COMPACT
automatic compact surface weather stations (using
Campbell data loggers) operated by the MSC.
Temporarily deployed in support of the 2015 PanAm
Games
CSV
Comma, Space, Value
a file format where data values are delimited by a
comma or space
DMF
Data Management Framework
new framework data management policies,
procedures, processes and standards that are being
implement to manage MSC’s environmental
monitoring data
DMI
Data Management Initiative
an initiative used to lead the development,
implementation and enhancement of a data
management framework and systems that provides
clients with an authoritative source of MSC and
related external data of known quality
DMS
Data Management System
a real-time data acquisition, standardization, quality
assessment and product generation software of
observation, forecast, and warning data
DND
Department of National Defense
Department of National Defense
EC
Environment Canada
the department of the Government of Canada
responsible for coordinating environmental policies
and programs, providing weather forecasts and
detailed meteorological information as well as
preserving and enhancing the natural environment
and renewable resources
GML
Geography Markup Language
the XML grammar defined by the Open Geospatial
Consortium (OGC) to express geographical features;
serves as a modeling language for geographic
systems as well as an open interchange format for
geographic transactions on the Internet.
HWOS
Human Weather Observation Stations
weather stations that require an observer to report
weather conditions
ICAO
International Civil Aviation Organization
a specialized agency of the United Nations that
codifies the principles and techniques of international
air navigation and fosters the planning and
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 63 of 111
development of international air transport to ensure
safe and orderly growth
ISAx41
telecommunications circuit header used to transmit
BUFR data collected from manned stations
ISAx61
telecommunications circuit header used to transmit
BUFR data collected from Nav Canada automated
stations
ISAx62
telecommunications circuit header used to transmit
BUFR data collected from Nav Canada manned
stations
LWIS
Limited Weather Information System
a more basic automated weather system (AWOS),
capable of measuring only wind, altimeter
setting, temperature and dew point temperature
JICC
Java Interactive CodeCon
a software interface for entering and maintaining
automatic station configuration data and used to
decode their raw messages
MANOBS
Manual for Surface Weather Observation
a manual that prescribes the standard procedures of
the Meteorological Service of Canada for observing,
recording and reporting weather conditions
METAR
Meteorological Aviation Report
an ASCII format for routine surface weather
observation for aviation purposes, reported on-the-
hour;
MIDS
a legacy interface for entering weather observations
at aviation stations
MSC
Meteorological Services of Canada
a Branch of Environment Canada, which provides
public meteorological information, weather
forecasts and warnings of severe weather and also
monitors and conducts research
on climate, atmospheric science, air quality, water
quantities, ice and other environmental issues
MSLP
Mean Sea Level Pressure
station pressure reduced to the level of mean sea
level
NativeQC
Native Quality Control
Incoming information and flags indicating data quality
or quality control performed at source
NC
Nav Canada (National Aviation Canada)
private corporation that provides aviation data and
weather briefings
O&M
Observations and Measurements international
standard
defines standard models and XML schema for
encoding observations and meteorological data from
a sensor, both archived and real-time. O&M is one of
the core standards in the OGC Sensor Web
Enablement (SWE) suite.
OGC
Open Geospatial Consortium
an international industry consortium of companies,
government agencies and universities participating in
a consensus process to develop publicly available
interface standards
OPP
Ocean Protection Plan
Government of Canada (GoC) undertaking to
improve marine safety and responsible shipping,
protects Canada's marine environment, and offer
new possibilities for Indigenous and coastal
communities
PG
Product Generator
software that generates products (e.g. SYNOP,
METAR, SWOB)
Qa
Quality Assessment
an evaluation where data are subjected to quality
check routines used to assess and characterize the
quality of data
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 64 of 111
QC
Quality Control
measures taken to correct or control bad data
RA
bulletin header for MSC’s legacy AWOS weather
observation reports
RCS
Reference Climate Station
an enhanced automatic surface weather observing
station operated by the MSC
SA
Surface Analysis
decommissioned ASCII format used for surface
weather observation
SP
Special
special aviation weather report issued off the top of
the hour when there is significant change in weather
SWE
Sensor Web Enablement
an OGC initiative that enables all types of Web
and/or Internet-accessible sensors, instruments, and
imaging devices to be accessible and, where
applicable, controllable via the Web
SW-OB-XML
Surface Weather Observation XML
an XML product containing surface weather and
climate observations from MSC, partner and 3rd party
monitoring networks. It is simplified XML product that
focuses on core weather data without the clutter and
complexity of auxiliary metadata
SWOB
Surface Weather Observation
a condensed reference to the SW-OB-XML product
SYNOP
Synoptic
weather observations reported at least four times a
day at 0000 UTC, 0600 UTC, 1200 UTC and 1800
UTC
Taxonomy
structure for classifying content (a unique dataset)
according to a predetermined information domain;
assists in organizing and describing information
TBRG
Tipping Bucket Rain Gauge
a tipping bucket rain gauge is used to measure liquid
precipitation (rainfall) or rate of rainfall
TC_ID
Transport Canada identifier
unique 3-letter ID's traditionally assigned by
Transport Canada aviation weather stations, but also
assigned by MSC to public surface weather stations
URI
Uniform Resource Identifier
the path that uniquely identifies an individual instance
of a dataset. It is made up of the taxonomy and
additional parameters unique to the dataset.
WinIDE
Windows Interactive Data Entry
a software interface that allows data to be recorded
at manned aviation weather stations and transmits
the data in BUFR format
WMO
World Meteorological Organization
specialized agency of the United Nations for
meteorology (weather and climate), operational
hydrology and related geophysical sciences
XML
Extensible Markup Language
a markup language that defines a set of rules for
encoding documents in a format that is both human-
readable and machine-readable
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 65 of 111
6.2 Short Label Abbreviations
The table below shows the full word being abbreviated for the name portion of the SWOB element
‘short label’.
Word/Phrase
abbrev
above
abv
above mean sea level
amsl
accretion
accretn
accumulated
accum
accuracy
acc
acquisition
acq
actual
actl
aerial
aerl
agency
agncy
air
air
aircraft
acft
airframe
arfrm
algorithm
algo
altimeter
altmetr
altitude
altd
amount
amt
and
and
anemometer
anemom
angle
angl
approximated
aprxd
arrangement
arrngmnt
arrival
arrivl
attribution
attrib
automatic/automated
auto
availability
avail
aviation
avtn
awos
aws
aws (automatic weather system)
aws
azimuth
azmth
barometer
baro
base
bas
based
based
battery
batry
bearing
berng
below
blw
black
blck
block
blk
bound
bnd
boundary
bndry
bright
brght
buoy
buoy
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 66 of 111
bypass
bypas
cable
cabl
calibration
cal
capability
cap
ceiling
clg
ceilometer
ceilmtr
change
chg
characteristic/character
char
checksum
cksum
chosen
chsn
class
class
clear
clr
climate
clim
cloud
cld
code/coded
code
coefficient
coeff
computer
comp
conditions/condition
condn
configuration
config
constant
const
contamination
contamntn
correction
cor
count
cnt
cover
cvr
cumulative
cum
current
crnt
data
data
datalogger
logr
date
date
date-time
datetm
day
dy
decode
decod
degree
deg
density
dnsty
departure
depart
deposit
dpst
depression
deprssn
depth
dpth
derived
der
description
desc
descriptor
dscrptr
designator
dsgntr
destination
dest
detection
dtctn
development
devlmt
deviation
dev
dewpoint
dwpt
diagnostic
diagnstc
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 67 of 111
diameter
dia
differential
diff
diffuse
dfuse
digit
digit
direct
drect
direction
dir
discrimination
discrmn
displacement
dsplcmt
distance/distant
dis
drift
drft
drifting
drftg
drogue
drog
dummy
dum
duration
dur
east
east
edge
edg
element
elemt
elevation
elev
emittance
emit
end
end
engineering
eng
enroute
enrt
equipment
eqpt
equivalent
equiv
error
err
evaporation
evap
events
evnts
evolution
evoln
extended
extnd
factor
factr
filtered
fltrd
fine
fine
fire
fire
flag/flags
flg
flight
flt
flown
flown
forward
fwd
free
free
frequency
freq
fresh
frsh
friction
fric
fuel
fuel
gauge
gag
Geonor
gnor
geopotential
geoptl
global
globl
globe
glob
GPS (global positioning system)
gps
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 68 of 111
ground
gnd
group
grp
gust
gst
hailstone
halstn
hardware
hrdwr
hazard
hzrd
header/HDR (high data rate GOES
transmitter)
hdr
height
hgt
high
hi
horizontal
hor
hour
hr
hourly
hly
hours
hrs
humidity
hum
hwos (human weather observing system)
hwos
hydrostatic
hydrosttc
icao (international civil aviation organization)
icao
ice
ice
icing
icng
identifier, identify
id
index
indx
indicator
indctr
information
info
infrared
ir
initial
initl
input
inpt
instantaneous
inst
instrument
instr
intensity
intnsty
interface
intrfc
internal
int
irradiance
irrad
isobaric
isobar
issuing
issug
julian day (day of year)
jday
last
last
latitude
lat
layer
lyr
length
len
level
lvl
lightning
ltng
liquid
lqd
local
locl
local standard time
lst
logger
logr
longitude
long
low
lo
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 69 of 111
lower
lwr
lowest
lwst
magnitude
mag
main
main
maintenance
matnanc
mandatory
mand
manned
mnd
marine
marin
marsden
marsden
maximum
max
mean (average)
avg
mean sea level
msl
mean sea level pressure
mslp
measurement
msrmnt
message
msg
method
mtd
middle
mid
minimum
min
minute
mt
mobile
mbl
model
modl
moisture
moist
motion
mtn
MSC (meteorological service of Canada)
msc
name
nam
national
natl
navigational/navigation
nav
network
ntwk
node
node
north
north
notice
not
number
nbr
obscuration
obscn
obscuring
obscg
observation
obs
occurrence
ocr
octas
octas
office
off
official
ofcl
offset
offset
opacity
opcty
operating
oprating
oscillator
oscil
other
othr
override
ovrd
pan
pan
panel
panl
panic
panic
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 70 of 111
part
prt
past
pst
peak
pk
period
pd
peripheral
periphl
phase
phas
phenomenon
phenom
plan
plan
point
pt
position
pos
power
pwr
precipitation
pcpn
precision
precisn
present
prsnt
pressure
pres
prevailing
prev
processed
procssd
product
prdct
program
prg
provider
pvdr
province
prov
proximity
prxmty
pyranometer
pyrnmtr
quadrant
quad
qualifier
qlfr
quality
qlty
radiation
radn
rainfall
rnfl
range
rng
rapid
rpd
read/reading
read
recent
recnt
reference
ref
reflected
refltd
refuel
reful
region
regn
relative
rel
relay
relay
release
rls
remark
rmk
removal
remov
report
rpt
reporting
rptg
reset
reset
revised
rev
roll
rol
run
run
runway
rwy
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 71 of 111
rvr (runway visual range)
rvr
salinity
salnty
satellite
sat
sea
sea
send
snd
sensor
snsr
serial
ser
service
serv
setting
setng
shear
shr
shift
shft
ship
shp
shortwave
shrtwv
shutdown
shtdwn
signal
sgnl
significant/significance/signature
sig
since
snc
situation
situatn
sky
sky
snow
snw
snowfall
snwfl
SOG (snow on ground)
sog
soil
soil
solar
solr
solid
sld
sonde
sonde
space
spce
special
spcl
specification
spec
speed
spd
spray
spry
spread
sprd
square
sq
stage
stg
standard
std
start
start
state
state
station
stn
statistical
statcal
status
stat
stop
stop
storm
strm
strike
strk
string (text string)
strng
subsurface
subsfc
summation
sum
sunshine
sunshn
supplementary
suppl
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 72 of 111
supply
suply
suppressed
spprssd
surface
sfc
suspect
suspct
swell
swell
synoptic
syno
system
sys
table
tbl
TC (Transport Canada)
tc
technique
technq
temperature
temp
tendency
tend
thickness
thknes
time
tm
top
top
total
tot
towards
twds
track
trk
tracking
trkng
transducer
transdcr
transient
trnsnt
transmission/transmitter
trans
trend
trnd
tropic
tropic
tropopause
tropo
turbulence
turb
type
typ
ultraviolet radiation
uv
ultraviolet A radiation
uva
ultraviolet B radiation
uvb
unfiltered
unfiltrd
unit
unit
unknown
unkn
unprocessed
unprocssd
upper
upr
used
used
UTC (universal coordinated time)
utc
valid
vld
value
val
vapour
vpr
variable/variation
var
vector
vtr
version
ver
vertical
vert
vicinity
vcnity
visibility
vis
voltage
volt
vortex
vrtx
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 73 of 111
warning
wrng
watchman
wtchmn
water
wtr
Wave
wave
weather
wx
weight
wt
wet-bulb
wetblb
wind
wnd
with
w
without
wo
wmo (world metrological organisation)
wmo
year
yr
zone
zn
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 74 of 111
6.3 Units of Measure
The table below is an inventory of all units of measure used by the DMS.
UNIT CLASS
UNIT NAME
UNIT
SYMBOL
UNIT DESCRIPTION
Angle
decadegree(s)
da°
Angle, azimuth or coordinates in tens of a degree
Angle
decidegree(s)
d°
Angle, azimuth or coordinates in tenth of a degree
Angle
decidegree(s)
0.1°
Angle, azimuth or coordinates in tenth of a degree
Angle
minute(s) of arc - (1/60) degree
'
Angle in second(s) of arc - (1/60) degree
Angle
degree(s) - equal to (pi/180)rad
°
Angle in degree(s)degree(s) - unit of angle equal
to (pi/180)rad
Angle
decadegrees
10°
Angle in tens of degrees azimuth
Angle
second(s) of arc - (1/60) minute
"
Angle in second(s) of arc - (1/60) minute
Angle
millidegrees
m°
Angle in thousandths of a degree
Area
square kilometre(s)
km²
Area in square kilometre(s)
Area
hectare(s)
ha
Area in hectare(s)
Area
square metre(s)
m²
Area in square metre(s)
Area
acre(s)
acre
Area in acre(s)
Area
square mile(s)
mi²
Area in square mile(s)
Areal_Weight
kilograms per square metre(s)
kg/m²
Areal Weight in kilograms per square metre(s)
Calibration
centimetre(s) per square hertz
cm/Hz²
unit for a calibration coefficient parameter used to
convert a weighing precipitation gauge transducer
value (from a vibrating wire of a specific length) to
precipitation weight per unit area (kg/m2), which is
equivalent to mm)
Calibration
centimetre(s) per hertz
cm/Hz
unit for a calibration coefficient parameter used to
convert a weighing precipitation gauge transducer
value (from a vibrating wire of a specific length) to
precipitation weight per unit area (kg/m²), which is
equivalent to mm)
Code
unit is a code value
code
Unit is a code value
Density
microgram(s) per cubic meter
µg/m³
Unit used to measure density
Density
milligram(s) per litre
mg/L
Unit used to measure density/concentration
Density
micrograms(s) per litre
µg/L
Unit used to measure density/concentration
Electrical/Magnetic
Siemens
S
The Siemens (symbol: S) is the SI derived unit of
electric conductance and electric admittance
Electrical/Magnetic
milliSiemens
mS
The Siemens (symbol: S) is the SI derived unit of
electric conductance and electric admittance
Electrical/Magnetic
milliSiemens per 10 cm
mS/10cm
Unit used to measure rate of electrical
conductivity over 10 cm
Electrical/Magnetic
milli-mhos per 10 cm
milli-
mhos/10cm
Rate of electrical conductivity in milli-mhos over
10 cm where mhos is a non-SI unit of conductivity
which is equivalent to 1 Siemens
Electrical/Magnetic
milliSiemens per 10 cm
mS/dm
Unit used to measure rate of electrical
conductivity over 10 cm (i.e. a decimeter)
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 75 of 111
Electrical/Magnetic
milli-mhos per 10 cm
milli-
mhos/dm
Rate of electrical conductivity in milli-mhos over
10 cm (i.e. a decimeter) where mhos is a non-SI
unit of conductivity which is equivalent to 1
Siemens
Electrical/Magnetic
milliSiemens per cm
mS/cm
Unit used to measure rate of electrical
conductivity over 1 cm
Electrical/Magnetic
volt
V
Electrical/Magnetic in volt(s) - potential difference
Electrical/Magnetic
Relative Fluorescence Unit
RFU
Unit used to measure fluorescence of particles in
a fluid
Energy_Flux
kilojoule(s) per square metre
kJ/m²
Energy Flux in kilojoule(s) per square metre
Energy_Flux
joule(s) per square metre
J/m²
Energy Flux in joule(s) per square metre
Energy_Flux
watt(s) per square metre
W/m²
Energy Flux in watt(s) per square metre
Energy_Flux
watt(s)
W
Rate of energy conversion in watt(s), equivalent to
one joule per second
Energy_Flux
microvolt-watt per square metre
µVW/m²
calibration coefficient to convert voltage into W/m2
Energy_Flux
megajoule(s) per square metre
MJ/m²
Energy Flux in megajoule(s) per square metre
Flow/Rate
cubic metre(s) per second
m³/s
Flow/Rate in cubic metre(s) per second
Flow/Rate
litre(s) per minute
L/min
Flow/Rate in litre(s) per minute
Flow/Rate
litre(s) per hour
L/h
Flow/Rate in litre(s) per hour
Flow/Rate
millilitre(s) per second
mL/s
Flow/Rate in millilitre(s) per second
Flow/Rate
millilitre(s) per hour
mL/h
Flow/Rate in millilitre(s) per hour
Flow/Rate
millimetre(s) per hour
mm/h
Flow/Rate in millimetre(s) per hour
Flow/Rate
U.S. gallon(s) per hour
USgal/h
Flow/Rate in U.S. gallon(s) per hour
Flow/Rate
Imperial gallon(s) per hour
gal/h
Flow/Rate in Imperial gallon(s) per hour
Flow/Rate
Imperial gallon(s) per minute
gal/min
Flow/Rate in Imperial gallon(s) per minute
Flow/Rate
Jackson Turbidity Unit
JTU
Unit used to measure turbidity in water
Frequency
hertz(s)
Hz
Unit of frequency defined as the number of cycles
per second of a periodic phenomenon
Intensity
unit is particular m per second
m²˙³/s
Intensity in particular m per second
Length
tenths of mile(s)
0.1mi
Length in tenths of a mile(s)
Length
tenths of millimetre(s)
0.1mm
Length in tenths of millimetre(s)
Length
nanometre(s)
nm
Length in nanometre(s)
Length
millimetre(s)
mm
Length in millimetre(s)
Length
centimetre(s)
cm
Length in centimetre(s)
Length
half metre(s)
0.5m
Length in half metre(s)
Length
metre(s)
m
Length in metre(s)
Length
hectometre(s)
hm
Length in hectometre(s)
Length
kilometre(s)
km
Length in kilometre(s)
Length
foot or feet
ft
Length in feet
Length
thirties of metres
30m
Length in thirties of metres
Length
hundreds of feet
100ft
Length in hundreds of feet
Length
inch(es)
in
Length in inch(es)
Length
hundredths of inch(es)
0.01in
Length in hundredths of inch(es)
Length
(statute) mile(s)
mi
Length in (statute) mile(s)
Length
nautical mile(s)
n.mi
Length in nautical mile(s)
Length
yard(s)
yd
Length in yard(s)
Length
geopotential metre(s)
gpm
Length in Geopotential metre(s)
Length
tenths of millimeter(s)
mm/10
Length in tenths millimetre(s)
Length
hectometre(s)
100m
Length in hundreds of metres
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 76 of 111
Length
decimeter(s)
dm
Length in tenths of metres
Mass
kilogram(s)
kg
Mass in kilogram(s)
Mass
gram(s)
g
Mass in gram(s)
Mass
ounce(s)
oz
Mass in ounce(s)
Mass
pound(s)
lb
Mass in pound(s)
Mass
milligram(s)
mg
Mass in milligram(s)
Mass
kilogram per kilogram
kg/kg
Mass in kilogram per kilogram
Percent/Fraction/Index
hundredths part(s) per thousand
0.01ppt
hundredths part(s) per thousand
Percent/Fraction/Index
part(s) per million
ppm
Percent/Fraction/Index in part(s) per million
Percent/Fraction/Index
hundredths of a percent
100%
Percent/Fraction/Index in hundredths of a percent
Percent/Fraction/Index
percent
%
Percent/Fraction/Index in percent
Percent/Fraction/Index
part(s) per billion
ppb
Percent/Fraction/Index in part(s) per billion
Percent/Fraction/Index
eighth(s)
1/8
Percent/Fraction/Index in eighth(s)
Percent/Fraction/Index
tenth(s)
1/10
Percent/Fraction/Index in tenth(s)
Percent/Fraction/Index
part(s) per thousand
ppt
parts per thousands
Pressure/Stress
pounds per square inch
psi
Pressure/Stress in pounds per square inch
Pressure/Stress
atmosphere(s)
atm
Pressure/Stress in atmosphere(s)
Pressure/Stress
hectopascal(s)
hPa
Pressure/Stress in hectopascal(s)
Pressure/Stress
centibar(s)
cbar
Pressure/Stress in centibar(s)
Pressure/Stress
decapascal(s)
daPa
Pressure/Stress in tens of pascals
Pressure/Stress
inches of mercury
inHg
Pressure/Stress in inches of mercury
Pressure/Stress
kilopascal(s)
kPa
Pressure/Stress in kilopascal(s)
Pressure/Stress
pascal(s)
Pa
Pressure/Stress in pascal(s)
Pressure/Stress
millimetres of mercury
mmHg
Pressure/Stress in millimetres of mercury
Pressure/Stress
millibar(s)
mbar
Pressure/Stress in millibar(s)
Signal_Strength
decibel(s) milliwatt
dBm
The expression dBm is used to define signal
strength in wires and cables at RF and AF
frequencies. The symbol is an abbreviation for
"decibels relative to one milliwatt" (dBmW)
Temperature
degree(s) Fahrenheit
°F
Temperature in degree(s) Fahrenheit
Temperature
low precision Kelvin
bufrK
Temperature in Kelvin decoded from MSC
CodeCon BUFR (precision of 0.1)
Temperature
Kelvin
K
Temperature in Kelvin
Temperature
decidegree(s) Celsius
d°C
Temperature in tenth of degree(s) Celsius
Temperature
centidegrees Celsius
c°C
hundredths of a degree(s) Celsius
Temperature
degree(s) Celsius
°C
Temperature in degree(s) Celsius
Time/Date
annum (year)
a
Time/Date in annum (year)
Time/Date
month(s)
mo
Time/Date in month(s)
Time/Date
day(s)
d
Time/Date in day(s)
Time/Date
date-time
datetime
Time/Date in full ISO 8601 format YYYY-MM-
DDTHH:MM:SS.000Z
Time/Date
hour(s) and minute(s)
hhmm
Time/Date in hour(s) and minute(s)
Time/Date
hour(s), minute(s) and second(s)
hhmmss
Time/Date in hour(s), minute(s) and second(s)
Time/Date
minute(s)
min
Time/Date in minute(s)
Time/Date
hour(s)
H
Time/Date in hour(s)
Time/Date
day of year
doy
Time/Date in day of year (also referred to as
Julian day)
Time/Date
second(s)
S
Time/Date in second(s)
Time/Date
millisecond(s)
ms
Time/Date in millisecond(s)
Time/Date
decisecond(s)
0.1s
Time/Date in tenths of a second
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 77 of 111
Unitless
unit is not applicable
unitless
Unit is not applicable
Velocity
knot(s)
kn
Velocity in knot(s)- nautical mile(s) per hour
Velocity
mile(s) per hour
mph
Velocity in mile(s) per hour
Velocity
kilometre(s) per hour
km/h
Velocity in kilometre(s) per hour
Velocity
foot or feet per second
ft/s
Velocity in foot or feet per second
Velocity
decimetre(s) per second
dm/s
Velocity in decimetre(s) per second
Velocity
metre(s) per second
m/s
Velocity in metre(s) per second
Velocity
centimetres per second
cm/s
Velocity in centimetres per second
Volume
quart(s)
qt
Volume in quart(s)
Volume
pint(s)
pt
Volume in pint(s)
Volume
fluid ounce(s)
fl.oz
Volume in fluid ounce(s)
Volume
U.S. gallon(s)
USgal
Volume in U.S. gallon(s)
Volume
cubic yard(s)
yd³
Volume in cubic yard(s)
Volume
millilitre(s)
mL
Volume in millilitre(s)
Volume
cubic metre(s)
m³
Volume in cubic metre(s)
Volume
litre(s)
L
Volume in litre(s)
Volume
cubic centimetre(s)
cm³
Volume in cubic centimetre(s)
Volume
Imperial gallon(s)
gal
Volume in Imperial gallon(s)
6.4 Unit Conversions
The table below is an inventory of unit conversions employed in the DMS
ORIGINAL UNIT
MULTIPLIER
OFFSET
TARGET UNIT
0.1mi
0.1609344
0
km
0.1mi
0.1
0
mi
0.1mm
0.1
0
kg/m²
0.1mm
0.1
0
mm
0.1s
0.1
0
s
0.5m
0.5
0
m
1/10
10
0
%
1/8
12.5
0
%
100ft
1
0
30m
100ft
30
0
m
10°
10
0
°
30m
30
0
m
J/m²
0.001
0
kJ/m²
K
1
-273.15
°C
MJ/m²
1000
0
kJ/m²
MJ/m²
1000000
0
J/m²
Pa
0.1
0
daPa
Pa
0.01
0
hPa
Pa
0.001
0
kPa
Pa
0.0002953
0
inHg
bufrK
1
-273.2
°C
cbar
10
0
hPa
cm
10
0
mm
cm
0.01
0
m
daPa
10
0
Pa
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 78 of 111
daPa
0.1
0
hPa
da°
10
0
°
dm
0.1
0
m
dm/s
0.36
0
km/h
ds
0.1
0
s
d°
0.1
0
°
d°C
0.1
273.15
K
d°C
0.1
0
°C
ft
0.3048
0
m
ft
0.0003048
0
km
h
60
0
min
hPa
100
0
Pa
hPa
10
0
daPa
hPa
1
0
mbar
hPa
0.1
0
kPa
hPa
0.02952998
0
inHg
hm
100
0
m
in
2.54
0
cm
in
25.4
0
mm
inHg
33.86389
0
hPa
inHg
3386.389
0
Pa
kPa
10
0
mbar
kPa
0.2952998
0
inHg
kPa
10
0
hPa
kg/m²
1
0
mm
km
1000
0
m
km
0.62137119
0
mi
km
0.539957
0
n.mi
km/h
0.539957
0
kn
km/h
0.277778
0
m/s
km/h
0.62137119
0
mph
kn
1.150779
0
mph
kn
1.852
0
km/h
kn
0.514444
0
m/s
m
0.033333
0
100ft
m
0.03333333
0
30m
m
2
0
0.5m
m
100
0
cm
m
3.2808399
0
ft
m
0.01
0
hm
m
0.001
0
km
m
0.000621371
0
mi
m
1000
0
mm
m/s
3.6
0
km/h
m/s
1.94384
0
kn
mbar
0.02952998
0
inHg
mbar
1
0
hPa
mbar
0.1
0
kPa
mbar
100
0
Pa
mbar
10
0
daPa
mi
1.609344
0
km
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 79 of 111
mi
0.868976
0
n.mi
mi
1609.344
0
m
milli-mhos/10cm
1
0
mS/10cm
milli-mhos/10cm
1
0
mS/dm
mS/cm
10
0
mS/dm
mS/dm
0.1
0
mS/cm
ms
0.000016667
0
min
s
0.016666667
0
min
min
0.016666667
0
h
mm
10
0
0.1mm
mm
1
0
kg/m²
mm
0.001
0
m
mm/10
0.1
0
mm
mph
1.609344
0
km/h
mph
0.44704
0
m/s
m°
0.001
0
°
n.mi
1.852
0
km
n.mi
1.150779
0
mi
n.mi
1852
0
m
s
10
0
0.1s
°
0.1
0
da°
°
10
0
d°
°
10
0
0.1°
°C
1
273.15
K
°C
1.8
32
°F
°C
10
0
d°C
°F
0.55556
-17.77778
°C
6.5 Standard Code Tables
The tables below provide descriptions of the standard code values for a given code type (i.e. table
name)
6.5.1 buoy_type
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
buoy_type
0
Unspecified drifting buoy
1
Standard Lagrangian drifter (Global Drifter Programme)
2
Standard FGGE-type drifting buoy (non-Lagrangian meteorological
drifting buoy)
3
Wind measuring FGGE-type drifting buoy (non-Lagrangian
meteorological drifting buoy)
4
Ice float
5
Reserved
6
Reserved
7
Reserved
8
Unspecified subsurface float
9
SOFAR
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 80 of 111
10
ALACE
11
MARVOR
12
RAFOS
13
Reserved
14
Reserved
15
Reserved
16
Unspecified moored buoy
17
6-metre Nomad
18
3-metre discus
19
10–12-metre discus
20
ODAS 30 series
21
ATLAS (e.g. TAO area)
22
TRITON
23
Reserved
24
Omnidirectional wave rider
25
Directional wave rider
26
Subsurface ARGO float
27
Reserved
28
Reserved
29
Reserved
30
Reserved
31
Reserved
32
Reserved
33
Reserved
34
Reserved
35
Reserved
36
Reserved
37
Reserved
38
Reserved
39
Reserved
40
Reserved
41
Reserved
42
Reserved
43
Reserved
44
Reserved
45
Reserved
46
Reserved
47
Reserved
48
Reserved
49
Reserved
50
Reserved
51
Reserved
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 81 of 111
52
Reserved
53
Reserved
54
Reserved
55
Reserved
56
Reserved
57
Reserved
58
Reserved
59
Reserved
60
Reserved
61
Reserved
62
Reserved
63
Missing value (// in SYNOP & coded 63 in BUFR)
64
1.7-metre WatchKeeper
65
Standard Lagrangian drifting Buoy with barometer
6.5.2 ceiling_type
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
ceiling_type
0
RESERVED
1
Measured by aircraft
2
Measured by balloon
3
Estimated
4
Delimited by precipitation
5
Indefinite
6
Measured
7
ground-base layer delimited by precipitation
8
ground-base layer not delimited by precipitation
6.5.3 data_flags
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
data_flags
0
reserved
1
Value has been reformulated or mathematically derived (ARKEON flag
D)
2
Reported value received as an estimate (ARKEON flag E)
3
Reported value the result of an adjustment (e.g. precipitation under
catch)
4
Incomplete - element derivation contains at least one missing value
(ARKEON flag I)
5
Trace. Value is zero (ARKEON flag T)
6
More than one occurrence (ARKEON flag S)
7
Missing inputs interpolated within completeness constraints (ARKEON
flag E)
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 82 of 111
6.5.4 obscuring_phenomena
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
obscuring_phenomena
0
Altocumulus
1
Altocumulus castellanus
2
Altostratus
3
Cirrocumulus
4
Cirrostratus
5
Cirrus. For the Nav Canada NC-HWOS data set this code is used
for Cirrus and Sky Clear (SKC).
6
Cumulonimbus
7
Cumulus
8
Cumulus fractus
9
Stratus fractus
10
Towering cumulus (aka cumulus congestus)
11
Nimbo stratus
12
Stratocumulus
13
Stratus
14
Missing
15
Cloud not visible owing to darkness, fog, duststorm, sandstorm, or
other analogous phenomena. For the Nav Canada NC-HWOS
data set this means smoke (i.e. FU, equivalent to code 65).
16
No CH clouds
17
Cirrus fibratus, sometimes uncinus, not progressively invading the
sky
18
Cirrus spissatus, in patches or entangled sheaves, which usually
do not increase and sometimes seem to be the remains of the
upper part of a Cumulonimbus; or Cirrus castellanus or floccus
19
Cirrus spissatus cumulonimbogenitus
20
Cirrus uncinus or fibratus, or both, progressively invading the sky;
they generally thicken as a whole
21
Cirrus (often in bands) and Cirrostratus, or Cirrostratus alone,
progressively invading the sky; they generally thicken as a whole,
but the continuous veil does not reach 45 degrees above the
horizon
22
Cirrus (often in bands) and Cirrostratus, or Cirrostratus alone,
progressively invading the sky; they generally thicken as a whole;
the continuous veil extends more than 45 degrees above the
horizon, without the sky being totally covered
23
Cirrostratus covering the whole sky
24
Cirrostratus not progressively invading the sky and not entirely
covering it
25
Cirrocumulus alone, or Cirrocumulus predominant among the Ch
cloud
26
CH clouds invisible owing to darkness, fog, blowing dust or sand,
or other similar phenomena, or because of a continuous layer of
lower clouds
27
No CL clouds
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 83 of 111
28
Cumulus humilis or Cumulus fractus other than of bad weather, or
both. For the Nav Canada NC-HWOS data set this means only
Cumulus fractus (i.e. equivalent to code 8)
29
Cumulus mediocris or congestus, Towering cumulus (TCU), with
or without Cumulus of species fractus or humilis or Stratocumulus,
all having their bases at the same level. For the Nav Canada NC-
HWOS data set this means only TCU (i.e. equivalent to code 10).
30
Cumulonimbus calvus, with or without Cumulus, Stratocumulus or
Stratus
31
Stratocumulus cumulogenitus
32
Stratocumulus other than Stratocumulus cumulogenitus
33
Stratus nebulosus or Stratus fractus other than of bad weather
34
Stratus fractus or Cumulus fractus of bad weather, or both
(pannus), usually below Altostratus or Nimbostratus. For the Nav
Canada NC-HWOS data set this means only Stratus fractus (i.e.
equivalent to code 9)
35
Cumulus and Stratocumulus other than Stratocumulus
cumulogenitus, with bases at different levels
36
Cumulonimbus capillatus (often with an anvil), with or without
Cumulonimbus calvus, Cumulus, Stratocumulus, Stratus or
pannus
37
CL clouds invisible owing to darkness, fog, blowing dust or sand,
or other similar phenomena
38
No CM clouds
39
Altostratus translucidus
40
Altostratus opacus or Nimbostratus
41
Altocumulus translucidus at a single level
42
Patches (often lenticular) of Altocumulus translucidus, continually
changing and occurring at one or more levels
43
Altocumulus translucidus in bands, or one or more layers of
Altocumulus translucidus or opacus, progressively invading the
sky; these Altocumulus as a whole clouds generally thicken as a
whole
44
Altocumulus cumulogenitus (or cumulonimbogenitus)
45
Altocumulus translucidus or opacus in two or more layers, or
Altocumulus opacus in a single layer, not progressively invading
the sky, or Altocumulus with Altostratus or Nimbostratus
46
Altocumulus castellanus or floccus. For the Nav Canada NC-
HWOS data set this means only Altocumulus castellanus (i.e.
equivalent to code 1).
47
Altocumulus of a chaotic sky, generally at several levels
48
CM clouds invisible owing to darkness, fog, blowing dust or sand,
or other similar phenomena, or because of continuous layer of
lower clouds
49
Reserved
50
Reserved
51
Reserved
52
Reserved
53
Reserved
54
Rain
55
Hail
56
Ice pellets
57
Drizzle
58
Ice crystals
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 84 of 111
59
Snow
60
Blowing snow
61
Fog
62
Dust, blowing dust
63
Haze
64
Sand, blowing sand
65
Smoke
66
Volcanic ash
67
CH
68
CM
69
CL
70
Reserved
71
Reserved
72
Reserved
73
Reserved
74
Reserved
75
Reserved
76
Reserved
77
Reserved
78
Reserved
79
Reserved
80
Reserved
81
Reserved
82
Reserved
83
Reserved
84
Reserved
85
Reserved
6.5.5 operating_agency
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
operating_agency
0
Australia, Bureau of Meteorology (BOM)
1
Australia, Joint Australian Facility for Ocean Observing Systems
(JAFOOS)
2
Australia, the Commonwealth Scientific and Industrial Research
Organization (CSIRO)
3
Canada, Marine Environmental Data Service (MEDS)
4
Canada, Institute of Ocean Sciences (IOS)
5
Canada, Environment Canada
6
Canada, Department of National Defence
7
Canada, Nav Canada
8
China, The State Oceanic Administration
9
China, Second Institute of Oceanography, State Oceanic
Administration
10
China, Institute of Ocean Technology
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 85 of 111
11
France, Institut de Recherche pour le Développement (IRD)
12
France, Institut Français de Recherche pour l’Exploitation de la
mer (IFREMER)
13
Germany, Bundesamt fuer Seeschiffahrt und Hydrographie (BSH)
14
Germany, Institut fuer Meereskunde, Kiel
15
India, National Institute of Oceanography (NIO)
16
India, National Institute for Ocean Technology (NIOT)
17
India, National Centre for Ocean Information Service
18
Japan, Japan Meteorological Agency (JMA)
19
Japan, Frontier Observational Research System for Global
Change
20
Japan, Japan Marine Science and Technology Centre
(JAMSTEC)
21
Republic of Korea, Seoul National University
22
Republic of Korea, Korea Ocean Research and Development
Institute (KORDI)
23
Republic of Korea, Meteorological Research Institute
24
New Caledonia, Institut de Recherche pour le Développement
(IRD)
25
New Zealand, National Institute of Water and Atmospheric
Research (NIWA)
26
Russian Federation, State Oceanographic Institute of
Roshydromet
27
Russian Federation, Federal Service for Hydrometeorology and
Environmental Monitoring
28
Spain, Instituto Español de Oceanografía
29
United Kingdom, Hydrographic Office
30
United Kingdom, Southampton Oceanography Centre (SOC)
31
USA, NOAA Atlantic Oceanographic and Meteorological
Laboratories (AOML)
32
USA, NOAA Pacific Marine Environmental Laboratories (PMEL)
33
USA, Scripps Institution of Oceanography (SIO)
34
USA, Woods Hole Oceanographic Institution (WHOI)
35
USA, University of Washington
36
USA, Naval Oceanographic Office
6.5.6 precipitation_measurement_method
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
precipitation_measurement_method
0
Manual measurement
1
Tipping bucket method
2
Weighing method
3
Optical method
4
Pressure method (impact plate - piezoelectric)
5
Float method
6
Drop counter method
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 86 of 111
7
Reserved
8
Reserved
9
Reserved
10
Reserved
11
Reserved
12
Reserved
13
Reserved
14
Other
15
Missing
16
Doppler radar
6.5.7 present_weather
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
present_weather
0
Manned Observation: Cloud development not observed or not
observable
1
Manned Observation: Clouds generally dissolving or becoming less
developed. (Characteristic change of the state of sky during the past
hour)
2
Manned Observation: State of sky on the whole unchanged.
(Characteristic change of the state of sky during the past hour)
3
Manned Observation: Clouds generally forming or developing.
(Characteristic change of the state of sky during the past hour)
4
Manned Observation: Visibility reduced by smoke, e.g. veldt or forest
fires, industrial smoke or volcanic ashes
5
Manned Observation: Haze
6
Manned Observation: Widespread dust in suspension in the air, not
raised by wind at or near the station at the time of observation
7
Manned Observation: Dust or sand raised by wind at or near the
station at the time of observation, but no well-developed dust whirl(s)
or sand whirl(s), and no duststorm or sandstorm seen; or, in the case
of sea stations and coastal stations, blowing spray at the station
8
Manned Observation: Well-developed dust whirl(s) or sand whirl(s)
seen at or near the station during the preceding hour or at the time of
observation, but no duststorm or sandstorm.
9
Manned Observation: Duststorm or sandstorm within sight at the time
of observation, or at the station during the preceding hour
10
Manned Observation: Mist
11
Manned Observation: Shallow fog or ice fog patches at the station,
whether on land or sea, not deeper than about 2 metres on land or 10
metres at sea
12
Manned Observation: Shallow fog or ice fog, more or less continuous,
at the station, whether on land or sea, not deeper than about 2 metres
on land or 10 metres at sea
13
Manned Observation: Lightning visible, no thunder heard
14
Manned Observation: Precipitation within sight, not reaching the
ground or the surface of the sea
15
Manned Observation: Precipitation within sight, reaching the ground or
the surface of the sea, but distant, i.e. estimated to be more than 5 km
from the station
16
Manned Observation: Precipitation within sight, reaching the ground or
the surface of the sea, near to, but not at the station
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 87 of 111
17
Manned Observation: Thunderstorm, but no precipitation at the time of
observation
18
Manned Observation: Squalls (at or within sight of the station during
the preceding hour or at the time of observation)
19
Manned Observation: Funnel cloud(s) [Tornado cloud or water-spout]
(at or within sight of the station during the preceding hour or at the
time of observation)
20
Manned Observation: Drizzle (not freezing) or snow grains (not falling
as shower(s))
21
Manned Observation: Rain (not freezing) (not falling as shower(s))
22
Manned Observation: Snow (not falling as shower(s))
23
Manned Observation: Rain and snow or ice pellets (not falling as
shower(s))
24
Manned Observation: Freezing drizzle or freezing rain (not falling as
shower(s))
25
Manned Observation: Shower(s) of rain
26
Manned Observation: Shower(s) of snow, or of rain and snow
27
Manned Observation: Shower(s) of hail [hail, small hail, snow pellets],
or of rain and hail [hail, small hail, snow pellets]
28
Manned Observation: Fog or ice fog
29
Manned Observation: Thunderstorm (with or without precipitation)
30
Manned Observation: Slight or moderate duststorm or sandstorm has
decreased during the preceding hour
31
Manned Observation: Slight or moderate duststorm or sandstorm - no
appreciable change during the preceding hour
32
Manned Observation: Slight or moderate duststorm or sandstorm has
begun or has increased during the preceding hour
33
Manned Observation: Severe duststorm or sandstorm has decreased
during the preceding hour
34
Manned Observation: Severe duststorm or sandstorm - no appreciable
change during the preceding hour
35
Manned Observation: Severe duststorm or sandstorm has begun or
has increased during the preceding hour
36
Manned Observation: Slight or moderate drifting snow - generally low
(below eye level)
37
Manned Observation: Heavy drifting snow - generally low (below eye
level)
38
Manned Observation: Slight or moderate blowing snow - generally
high (above eye level)
39
Manned Observation: Heavy blowing snow - generally high (above eye
level)
40
Manned Observation: Fog or ice fog at a distance at the time of
observation, but not at the station during the preceding hour, the fog or
ice fog extending to a level above that of the observer
41
Manned Observation: Fog or ice fog in patches
42
Manned Observation: Fog or ice fog, sky visible - has become thinner
during the preceding hour
43
Manned Observation: Fog or ice fog, sky invisible - has become
thinner during the preceding hour
44
Manned Observation: Fog or ice fog, sky visible - no appreciable
change during the preceding hour
45
Manned Observation: Fog or ice fog, sky invisible - no appreciable
change during the preceding hour
46
Manned Observation: Fog or ice fog, sky visible - has begun or has
become thicker during the preceding hour
47
Manned Observation: Fog or ice fog, sky invisible - has begun or has
become thicker during the preceding hour
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 88 of 111
48
Manned Observation: Fog, depositing rime, sky visible
49
Manned Observation: Fog, depositing rime, sky invisible
50
Manned Observation: Very light drizzle
51
Manned Observation: Light drizzle (not freezing, continuous)
52
Manned Observation: Moderate drizzle (not freezing, continuous)
53
Manned Observation: Heavy drizzle (not freezing, continuous)
54
Manned Observation: Light drizzle (not freezing, intermittent)
55
Manned Observation: Moderate drizzle (not freezing, intermittent)
56
Manned Observation: Heavy drizzle (not freezing, intermittent)
57
Manned Observation: Very light freezing drizzle
58
Manned Observation: Light freezing drizzle
59
Manned Observation: Moderate freezing drizzle
60
Manned Observation: Heavy freezing drizzle
61
Manned Observation: Moderate or heavy freezing drizzle
62
Manned Observation: Light drizzle and rain
63
Manned Observation: Moderate or heavy drizzle and rain
64
Manned Observation: Very light rain
65
Manned Observation: Light rain (not freezing, continuous)
66
Manned Observation: Moderate rain (not freezing, continuous)
67
Manned Observation: Heavy rain (not freezing, continuous)
68
Manned Observation: Light rain (not freezing, intermittent)
69
Manned Observation: Moderate rain (not freezing, intermittent)
70
Manned Observation: Heavy rain (not freezing, intermittent)
71
Manned Observation: Very light freezing rain
72
Manned Observation: Light freezing rain
73
Manned Observation: Moderate freezing rain
74
Manned Observation: Heavy freezing rain
75
Manned Observation: Moderate or heavy freezing rain
76
Manned Observation: Rain or drizzle and snow, slight
77
Manned Observation: Rain or drizzle and snow, moderate or heavy
78
Manned Observation: Very light snow
79
Manned Observation: Light snow (continuous)
80
Manned Observation: Moderate snow (continuous)
81
Manned Observation: Heavy snow (continuous)
82
Manned Observation: Light snow (intermittent)
83
Manned Observation: Moderate snow (intermittent)
84
Manned Observation: Heavy snow (intermittent)
85
Manned Observation: Ice crystals
86
Manned Observation: Snow grains (with or without fog)
87
Manned Observation: Very light snow grains
88
Manned Observation: Light snow grains
89
Manned Observation: Moderate snow grains
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 89 of 111
90
Manned Observation: Heavy snow grains
91
Manned Observation: Isolated star-like snow crystals (with or without
fog)
92
Manned Observation: Ice pellets
93
Manned Observation: Very light ice pellets
94
Manned Observation: Light ice pellets
95
Manned Observation: Moderate ice pellets
96
Manned Observation: Heavy ice pellets
97
Manned Observation: Very light rain showers
98
Manned Observation: Light rain showers
99
Manned Observation: Moderate rain showers
100
Manned Observation: Heavy rain showers
101
Manned Observation: Moderate or heavy rain showers
102
Manned Observation: Light showers of rain and snow mixed
103
Manned Observation: Moderate or heavy showers of rain and snow
mixed
104
Manned Observation: Very light snow showers
105
Manned Observation: Light snow showers
106
Manned Observation: Moderate snow showers
107
Manned Observation: Heavy snow showers
108
Manned Observation: Moderate or heavy snow showers
109
Manned Observation: Light showers of snow pellets or small hail, with
or without rain or rain and snow mixed
110
Manned Observation: Moderate or heavy showers of snow pellets or
small hail, with or without rain or rain and snow mixed
111
Manned Observation: Very light hail
112
Manned Observation: Light showers of hail, with or without rain or rain
and snow mixed, not associated with thunder
113
Manned Observation: Moderate hail
114
Manned Observation: Heavy hail
115
Manned Observation: Moderate or heavy showers of hail, with or
without rain or rain and snow mixed, not associated with thunder
116
Manned Observation: Light rain at time of observation - Thunderstorm
during the preceding hour but not at time of observation
117
Manned Observation: Moderate or heavy rain at time of observation -
Thunderstorm during the preceding hour but not at time of observation
118
Manned Observation: Light snow, or rain and snow mixed or hail [hail,
small hail, snow pellets] at time of observation - Thunderstorm during
the preceding hour but not at time of observation
119
Manned Observation: Moderate or heavy snow, or rain and snow
mixed or hail [hail, small hail, snow pellets] at time of observation -
Thunderstorm during the preceding hour but not at time of observation
120
Manned Observation: Thunderstorm, slight or moderate, without hail
[hail, small hail, snow pellets], but with rain and/or snow at time of
observation - Thunderstorm at time of observation
121
Manned Observation: Thunderstorm, slight or moderate, with hail [hail,
small hail, snow pellets] at time of observation - Thunderstorm at time
of observation
122
Manned Observation: Thunderstorm, heavy, without hail [hail, small
hail, snow pellets], but with rain and/or snow at time of observation -
Thunderstorm at time of observation
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 90 of 111
123
Manned Observation: Thunderstorm combined with duststorm or
sandstorm at time of observation - Thunderstorm at time of
observation
124
Manned Observation: Thunderstorm, heavy, with hail [hail, small hail,
snow pellets] at time of observation - Thunderstorm at time of
observation
125
Manned Observation: No present or recent weather
126
Manned Observation: Slight or moderate blowing dust
127
Manned Observation: Heavy blowing dust
128
Manned Observation: Slight or moderate blowing snow
129
Manned Observation: Slight or moderate blowing sand
130
Manned Observation: Heavy blowing sand
131
Manned Observation: Drifting sand
132
Manned Observation: Drifting snow
133
Manned Observation: Drifting dust
134
Manned Observation: Funnel cloud(s)
135
Manned Observation: Tornado
136
Manned Observation: Waterspout
137
Manned Observation: Tornado or waterspout
138
Manned Observation: Fog (prevailing visibility < 5/8 miles)
139
Manned Observation: Freezing fog (prevailing visibility < 5/8 miles,
temperatures < 0 °C and ≥ -30 °C)
140
Manned Observation: Shallow Fog
141
Manned Observation: Ice Fog
142
Manned Observation: Patchy fog
143
Manned Observation: Fog covering part of the aerodrome
144
Manned Observation: Smoke
145
Manned Observation: Thunderstorm
146
Manned Observation: Heavy Thunderstorm
147
Manned Observation: Well-developed dust whirl(s) or sand whirl(s),
but no duststorm or sandstorm
148
Manned Observation: Very light snow pellet showers, or small hail (i.e.
diameter of largest stone < 5mm)
149
Manned Observation: Light snow pellet showers, or small hail (i.e.
diameter of largest stone < 5mm)
150
Manned Observation: Moderate snow pellet showers, or small hail (i.e.
diameter of largest stone < 5mm)
151
Manned Observation: Heavy snow pellet showers, or small hail (i.e.
diameter of largest stone < 5mm)
152
Manned Observation: Very light ice pellet showers
153
Manned Observation: Light ice pellet showers
154
Manned Observation: Moderate ice pellet showers
155
Manned Observation: Heavy ice pellet showers
156
Manned Observation: Slight or moderate sandstorm
157
Manned Observation: Severe sandstorm
158
Manned Observation: Slight or moderate duststorm
159
Manned Observation: Severe duststorm
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 91 of 111
160
Manned Observation: Volcanic ash
161
Manned Observation: Blowing dust in the vicinity
162
Manned Observation: Blowing sand in the vicinity
163
Manned Observation: Blowing snow in the vicinity
164
Manned Observation: Duststorm in the vicinity
165
Manned Observation: Fog in the vicinity
166
Manned Observation: Dust/sand whirls in the vicinity
167
Manned Observation: Showers in the vicinity
168
Manned Observation: Sandstorm in the vicinity
169
Manned Observation: Volcanic ash in the vicinity
170
Manned Observation: Funnel cloud in the vicinity
171
Manned Observation: Recent blowing snow
172
Manned Observation: Recent duststorm
173
Manned Observation: Recent Funnel Cloud, Tornado, Waterspout
174
Manned Observation: Recent freezing drizzle
175
Manned Observation: Recent freezing rain
176
Manned Observation: Recent hail
177
Manned Observation: Recent snow pellets
178
Manned Observation: Recent ice pellets
179
Manned Observation: Recent sandstorm
180
Manned Observation: Recent volanic ash
181
Manned Observation: Recent drizzle
182
Manned Observation: Recent snow
183
Manned Observation: Recent rain
184
Manned Observation: Recent thunderstorm
185
RESERVED
186
RESERVED
187
RESERVED
188
RESERVED
189
RESERVED
190
RESERVED
191
RESERVED
192
RESERVED
193
RESERVED
194
RESERVED
195
RESERVED
196
RESERVED
197
RESERVED
198
RESERVED
199
RESERVED
200
RESERVED
201
RESERVED
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 92 of 111
202
RESERVED
203
RESERVED
204
RESERVED
205
RESERVED
206
RESERVED
207
RESERVED
208
RESERVED
209
RESERVED
210
RESERVED
300
Automated Station Observation: No significant weather observed
301
Automated Station Observation: Clouds generally dissolving or
becoming less developed during the past hour
302
Automated Station Observation: State of sky on the whole unchanged
during the past hour
303
Automated Station Observation: Clouds generally forming or
developing during the past hour
304
Automated Station Observation: Haze or smoke, or dust in suspension
in the air, visibility equal to or greater than 1 km
305
Automated Station Observation: Haze or smoke, or dust in suspension
in the air, visibility less than 1 km
306
RESERVED
307
RESERVED
308
RESERVED
309
RESERVED
310
Automated Station Observation: Mist
311
Automated Station Observation: Diamond dust
312
Automated Station Observation: Distant lightning
313
RESERVED
314
RESERVED
315
RESERVED
316
RESERVED
317
RESERVED
318
Automated Station Observation: Squalls
319
RESERVED
320
Automated Station Observation: Fog
321
Automated Station Observation: PRECIPITATION at the station during
the preceding hour but not at the time of observation
322
Automated Station Observation: Drizzle (not freezing) or snow grains
323
Automated Station Observation: Rain (not freezing)
324
Automated Station Observation: Snow
325
Automated Station Observation: Freezing drizzle or freezing rain
326
Automated Station Observation: Thunderstorm (with or without
precipitation)
327
Automated Station Observation: BLOWING OR DRIFTING SNOW OR
SAND
328
Automated Station Observation: Blowing or drifting snow or sand,
visibility equal to or greater than 1 km
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 93 of 111
329
Automated Station Observation: Blowing or drifting snow or sand,
visibility less than 1 km
330
Automated Station Observation: FOG
331
Automated Station Observation: Fog or ice fog in patches
332
Automated Station Observation: Fog or ice fog, has become thinner
during the past hour
333
Automated Station Observation: Fog or ice fog, no appreciable change
during the past hour
334
Automated Station Observation: Fog or ice fog, has begun or has
become thicker during the past hour
335
Automated Station Observation: Fog, depositing rime. Freezing Fog
for Nav Canada stations
336
RESERVED
337
RESERVED
338
RESERVED
339
RESERVED
340
Automated Station Observation: PRECIPITATION
341
Automated Station Observation: Light or moderate precipitation
342
Automated Station Observation: Heavy precipitation
343
Automated Station Observation: Light or moderate liquid precipitation
344
Automated Station Observation: Heavy liquid precipitation
345
Automated Station Observation: Light or moderate solid precipitation
346
Automated Station Observation: Heavy solid precipitation
347
Automated Station Observation: Light or moderate freezing
precipitation
348
Automated Station Observation: Heavy freezing precipitation
349
RESERVED
350
Automated Station Observation: DRIZZLE
351
Automated Station Observation: Very light drizzle
352
Automated Station Observation: Light drizzle (not freezing)
353
Automated Station Observation: Moderate drizzle (not freezing)
354
Automated Station Observation: Heavy drizzle (not freezing)
355
Automated Station Observation: Very light freezing drizzle
356
Automated Station Observation: Light freezing drizzle
357
Automated Station Observation: Moderate freezing drizzle
358
Automated Station Observation: Heavy freezing drizzle
359
Automated Station Observation: Light drizzle and rain
360
Automated Station Observation: Moderate or heavy drizzle and rain
361
RESERVED
362
Automated Station Observation: RAIN
363
Automated Station Observation: Very light rain
364
Automated Station Observation: Light rain (not freezing)
365
Automated Station Observation: Moderate rain (not freezing)
366
Automated Station Observation: Heavy rain (not freezing)
367
Automated Station Observation: Very light freezing rain
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 94 of 111
368
Automated Station Observation: Light freezing rain
369
Automated Station Observation: Moderate freezing rain
370
Automated Station Observation: Heavy freezing rain
371
Automated Station Observation: Light rain (or drizzle) and snow
372
Automated Station Observation: Moderate or heavy rain (or drizzle)
and snow
373
RESERVED
374
Automated Station Observation: SNOW
375
Automated Station Observation: Very light snow
376
Automated Station Observation: Light snow
377
Automated Station Observation: Moderate snow
378
Automated Station Observation: Heavy snow
379
Automated Station Observation: Light ice pellets
380
Automated Station Observation: Moderate ice pellets
381
Automated Station Observation: Heavy ice pellets
382
Automated Station Observation: Snow grains
383
Automated Station Observation: Ice crystals
384
RESERVED
385
Automated Station Observation: SHOWERS or INTERMITTENT
PRECIPITATION
386
Automated Station Observation: Light rain showers or light intermittent
rain
387
Automated Station Observation: Moderate rain showers or moderate
intermittent rain
388
Automated Station Observation: Heavy rain showers or heavy
intermittent rain
389
Automated Station Observation: Violent rain showers or violent
intermittent rain
390
Automated Station Observation: Light snow showers or light
intermittent snow
391
Automated Station Observation: Moderate snow showers or moderate
intermittent snow
392
Automated Station Observation: Heavy snow showers or heavy
intermittent snow
393
RESERVED
394
Automated Station Observation: Hail
395
Automated Station Observation: Very light hail
396
Automated Station Observation: Light hail
397
Automated Station Observation: Moderate hail
398
Automated Station Observation: Heavy hail
399
Automated Station Observation: THUNDERSTORM
400
Automated Station Observation: Thunderstorm, slight or moderate with
no precipitation
401
Automated Station Observation: Thunderstorm, slight or moderate,
with rain showers and/or snow showers
402
Automated Station Observation: Thunderstorm, slight or moderate,
with hail
403
Automated Station Observation: Thunderstorm, heavy, with no
precipitation
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 95 of 111
404
Automated Station Observation: Thunderstorm, heavy, with rain
showers and/or snow showers
405
Automated Station Observation: Thunderstorm, heavy, with hail
406
RESERVED
407
RESERVED
408
Automated Station Observation: Tornado
409
Automated Station Observation: No precipitation
410
Automated Station Observation: Very light unclassified precipitation
411
Automated Station Observation: Light unclassified precipitation
412
Automated Station Observation: Moderate unclassified precipitation
413
Automated Station Observation: Heavy unclassified precipitation
414
Automated Station Observation: Error in present weather
determination, none could be reported
415
Automated Station Observation: Light frozen precipitation
416
Automated Station Observation: Moderate frozen precipitation
417
Automated Station Observation: Heavy frozen precipitation
418
Automated Station Observation: Other
500
Not used
501
Not used
502
Not used
503
Not used
504
Manned or Automated Station Observation: Volcanic ash suspended
In the air aloft
505
Not used
506
Manned or Automated Station Observation: Thick dust haze, visibility
less than 1 km
507
Manned or Automated Station Observation: Blowing spray at the
station
508
Manned or Automated Station Observation: Drifting dust (sand)
509
Manned or Automated Station Observation: Wall of dust or sand in
distance (like haboob)
510
Manned or Automated Station Observation: Snow haze
511
Manned or Automated Station Observation: Whiteout
512
Not used
513
Manned or Automated Station Observation: Lightning, cloud to surface
514
Not used
515
Not used
516
Not used
517
Manned or Automated Station Observation: Dry thunderstorm
518
Not used
519
Manned or Automated Station Observation: Tornado cloud
(destructive) at or within sight of the station during preceding hour or at
the time of observation
520
Manned or Automated Station Observation: Deposition of volcanic ash
521
Manned or Automated Station Observation: Deposition of dust or sand
522
Manned or Automated Station Observation: Deposition of dew
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 96 of 111
523
Manned or Automated Station Observation: Deposition of wet snow
524
Manned or Automated Station Observation: Deposition of soft rime
525
Manned or Automated Station Observation: Deposition of hard rime
526
Manned or Automated Station Observation: Deposition of hoarfrost
527
Manned or Automated Station Observation: Deposition of glaze
528
Manned or Automated Station Observation: Deposition of ice crust (ice
slick)
529
Not used
530
Manned or Automated Station Observation: Duststorm or sandstorm
with temperature below 0 degrees C
531
Not used
532
Not used
533
Not used
534
Not used
535
Not used
536
Not used
537
Not used
538
Not used
539
Manned or Automated Station Observation: Blowing snow, impossible
to determine whether snow is falling or not
540
Not used
541
Manned or Automated Station Observation: Fog on sea
542
Manned or Automated Station Observation: Fog in valleys
543
Manned or Automated Station Observation: Arctic or Antarctic sea
smoke
544
Manned or Automated Station Observation: Steam fog (sea, lake or
river)
545
Manned or Automated Station Observation: Steam fog (land)
546
Manned or Automated Station Observation: Fog over ice or snow
cover
547
Manned or Automated Station Observation: Dense fog, visibility 60-90
m
548
Manned or Automated Station Observation: Dense fog, visibility 30-60
m
549
Manned or Automated Station Observation: Dense fog, visibility less
than 30 m
550
Manned or Automated Station Observation: Drizzle, rate of fall less
than 0.10 mm/h
551
Manned or Automated Station Observation: Drizzle, rate of fall 0.10-
0.19 mm/h
552
Manned or Automated Station Observation: Drizzle, rate of fall 0.20-
0.39 mm/h
553
Manned or Automated Station Observation: Drizzle, rate of fall 0.40-
0.79 mm/h
554
Manned or Automated Station Observation: Drizzle, rate of fall 0.80-
1.59 mm/h
555
Manned or Automated Station Observation: Drizzle, rate of fall 1.60-
3.19 mm/h
556
Manned or Automated Station Observation: Drizzle, rate of fall 3.20-
6.39 mm/h
557
Manned or Automated Station Observation: Drizzle, rate of fall 6.4
mm/h or more
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 97 of 111
558
Not used
559
Manned or Automated Station Observation: Drizzle and snow
560
Manned or Automated Station Observation: Rain, rate of fall less than
1.0 mm/h
561
Manned or Automated Station Observation: Rain, rate of fall 1.- 1.9
mm/h
562
Manned or Automated Station Observation: Rain, rate of fall 2.- 3.9
mm/h
563
Manned or Automated Station Observation: Rain, rate of fall 4.- 7.9
mm/h
564
Manned or Automated Station Observation: Rain, rate of fall 8.-15.9
mm/h
565
Manned or Automated Station Observation: Rain, rate of fall 16.0-31.9
mm/h
566
Manned or Automated Station Observation: Rain, rate of fall 32.0-63.9
mm/h
567
Manned or Automated Station Observation: Rain, rate of fall 64.0
mm/h or more
568
Not used
569
Not used
570
Manned or Automated Station Observation: Snow, rate of fall less than
1.0 cm/h
571
Manned or Automated Station Observation: Snow, rate of fall 1.0-1.9
cm/h
572
Manned or Automated Station Observation: Snow, rate of fall 2.0-3.9
cm/h
573
Manned or Automated Station Observation: Snow, rate of fall 4.0-7.9
cm/h
574
Manned or Automated Station Observation: Snow, rate of fall 8.0-15.9
cm/h
575
Manned or Automated Station Observation: Snow, rate of fall 16.0-
31.9 cm/h
576
Manned or Automated Station Observation: Snow, rate of fall 32.0-
63.9 cm/h
577
Manned or Automated Station Observation: Snow, rate of fall 64.0
cm/h or more
578
Manned or Automated Station Observation: Snow or Ice crystal
precipitation from a clear sky
579
Manned or Automated Station Observation: Wet snow, freezing on
contact
580
Manned or Automated Station Observation: Precipitation of rain
581
Manned or Automated Station Observation: Precipitation of rain,
freezing
582
Manned or Automated Station Observation: Precipitation of rain and
snow mixed.
583
Manned or Automated Station Observation: Precipitation of snow
584
Manned or Automated Station Observation: Precipitation of snow
pellets or small hall
585
Manned or Automated Station Observation: Precipitation of snow
pellets or small hail, with rain
586
Manned or Automated Station Observation: Precipitation of snow
pellets or small hail, with rain and snow mixed
587
Manned or Automated Station Observation: Precipitation of snow
pellets or small hail, with snow
588
Manned or Automated Station Observation: Precipitation of hail
589
Manned or Automated Station Observation: Precipitation of hail, with
rain
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 98 of 111
590
Manned or Automated Station Observation: Precipitation of hall, with
rain and snow mixed
591
Manned or Automated Station Observation: Precipitation of hail, with
snow
592
Manned or Automated Station Observation: Shower(s) or
thunderstorm over sea
593
Manned or Automated Station Observation: Shower(s) or
thunderstorm over mountains
594
Not used
595
Not used
596
Not used
597
Not used
598
Not used
599
Not used
600
Reserved
601
Reserved
602
Reserved
603
Reserved
604
Reserved
605
Reserved
606
Reserved
607
Reserved
608
Reserved
609
Reserved
610
Reserved
611
Reserved
612
Reserved
613
Reserved
614
Reserved
615
Reserved
616
Reserved
617
Reserved
618
Reserved
619
Reserved
620
Reserved
621
Reserved
622
Reserved
623
Reserved
624
Reserved
625
Reserved
626
Reserved
627
Reserved
628
Reserved
629
Reserved
630
Reserved
631
Reserved
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 99 of 111
632
Reserved
633
Reserved
634
Reserved
635
Reserved
636
Reserved
637
Reserved
638
Reserved
639
Reserved
640
Reserved
641
Reserved
642
Reserved
643
Reserved
644
Reserved
645
Reserved
646
Reserved
647
Reserved
648
Reserved
649
Reserved
650
Reserved
651
Reserved
652
Reserved
653
Reserved
654
Reserved
655
Reserved
656
Reserved
657
Reserved
658
Reserved
659
Reserved
660
Reserved
661
Reserved
662
Reserved
663
Reserved
664
Reserved
665
Reserved
666
Reserved
667
Reserved
668
Reserved
669
Reserved
670
Reserved
671
Reserved
672
Reserved
673
Reserved
674
Reserved
675
Reserved
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 100 of 111
676
Reserved
677
Reserved
678
Reserved
679
Reserved
680
Reserved
681
Reserved
682
Reserved
683
Reserved
684
Reserved
685
Reserved
686
Reserved
687
Reserved
688
Reserved
689
Reserved
690
Reserved
691
Reserved
692
Reserved
693
Reserved
694
Reserved
695
Reserved
696
Reserved
697
Reserved
698
Reserved
699
Reserved
700
Reserved
701
Reserved
702
Reserved
703
Reserved
704
Reserved
705
Reserved
706
Reserved
707
Reserved
708
Reserved
709
Reserved
710
Reserved
711
Reserved
712
Reserved
713
Reserved
714
Reserved
715
Reserved
716
Reserved
717
Reserved
718
Reserved
719
Reserved
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 101 of 111
720
Reserved
721
Reserved
722
Reserved
723
Reserved
724
Reserved
725
Reserved
726
Reserved
727
Reserved
728
Reserved
729
Reserved
730
Reserved
731
Reserved
732
Reserved
733
Reserved
734
Reserved
735
Reserved
736
Reserved
737
Reserved
738
Reserved
739
Reserved
740
Reserved
741
Reserved
742
Reserved
743
Reserved
744
Reserved
745
Reserved
746
Reserved
747
Reserved
748
Reserved
749
Reserved
750
Reserved
751
Reserved
752
Reserved
753
Reserved
754
Reserved
755
Reserved
756
Reserved
757
Reserved
758
Reserved
759
Reserved
760
Reserved
761
Reserved
762
Reserved
763
Reserved
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 102 of 111
764
Reserved
765
Reserved
766
Reserved
767
Reserved
768
Reserved
769
Reserved
770
Reserved
771
Reserved
772
Reserved
773
Reserved
774
Reserved
775
Reserved
776
Reserved
777
Reserved
778
Reserved
779
Reserved
780
Reserved
781
Reserved
782
Reserved
783
Reserved
784
Reserved
785
Reserved
786
Reserved
787
Reserved
788
Reserved
789
Reserved
790
Reserved
791
Reserved
792
Reserved
793
Reserved
794
Reserved
795
Reserved
796
Reserved
797
Reserved
798
Reserved
799
Reserved
800
Reserved
801
Reserved
802
Reserved
803
Reserved
804
Reserved
805
Reserved
806
Reserved
807
Reserved
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 103 of 111
808
Manned or Automated Station Observation: No significant
phenomenon to report, present and past weather omitted
809
Manned or Automated Station Observation: No observation, data not
available, present and past weather omitted
810
Manned or Automated Station Observation: Present and past weather
missing, but expected
811
Missing value
812
Automated Station Observation: Rain, hail detected
813
Automated Station Observation: Snow, rain detected
814
Automated Station Observation: Snow, hail detected
815
Automated Station Observation: Snow, rain, hail detected
816
Automated Station Observation: Unclassified precipitation detected
817
Automated Station Observation: Rain, unclassified precipitation
detected
818
Automated Station Observation: Hail, unclassified precipitation
detected
819
Automated Station Observation: Rain, hail, unclassified precipitation
detected
820
Automated Station Observation: Snow, unclassified precipitation
detected
821
Automated Station Observation: Snow, rain, unclassified precipitation
detected
822
Automated Station Observation: Snow, hail, unclassified precipitation
detected
823
Automated Station Observation: Snow, hail, rain, unclassified
precipitation detected
824
Automated Station Observation: Light snow grains
825
Automated Station Observation: Moderate snow grains
826
Automated Station Observation: Heavy snow grains
827
Automated Station Observation: Snow pellets
828
Automated Station Observation: Thunderstorm in vicinity
829
Automated Station Observation: Sand
830
Automated Station Observation: Dust
831
Automated Station Observation: Haze
832
Automated Station Observation: Smoke
833
Automated Station Observation: Volcanic ash
834
Automated Station Observation: Blowing snow
835
Automated Station Observation: Blowing sand
836
Automated Station Observation: Light unclassified freezing
precipitation
837
Automated Station Observation: Moderate unclassified freezing
precipitation
838
Automated Station Observation: Heavy unclassified freezing
precipitation
839
Automated Station Observation: No precipitation detected
6.5.8 rapid_pressure_change
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
rapid_pressure_change
0
not occurring
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 104 of 111
1
Pressure rising rapidly
2
Pressure falling rapidly
3
missing
6.5.9 report_type
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
report_type
0
hourly regular report (SA)
1
hourly special report (SP)
2
hourly regular special report (RS)
3
SA and SM reports
4
SA and CS reports
5
SA, CS and SM reports
6
SA and SX reports
7
SP and SX reports
8
CS and SX reports
9
SA, SX and SM reports
10
SA, SX, SM and CS reports
11
reserved
12
reserved
13
reserved
14
reserved
15
missing
16
reserved
17
SM (Synoptic) Reports, e.g. FM-12 LAND SYNOP (6 hr)
18
SA + SM
19
CS Reports
20
SA + CS
21
SM + CS
22
SA + SM + CS
23
SX (Soil) Reports
24
SA + SX (Soil)
25
SM + SX (Soil)
26
SA + SM + SX(Soil)
27
CS + SX (Soil)
28
SA + CS + SX(Soil)
29
SM + CS + SX (Soil)
30
SA + SM + CS + SX (Soil)
31
SX (UV) Reports
32
SA + SX(UV)
33
SM + SX (UV)
34
SA + SM + SX(UV)
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 105 of 111
35
CS + SX (UV)
36
SA + CS + SX (UV)
37
SM + CS + SX (UV)
38
SA + SM + CS + SX(UV)
39
SX(Soil + UV)
40
SA + SX(Soil + UV)
41
SM + SX(Soil + UV)
42
SA + SM + SX(Soil + UV)
43
CS + SX (Soil + UV)
44
SA + CS + SX (Soil + UV)
45
SM + CS + SX (Soil + UV)
46
SA + SM + CS + SX (Soil + UV)
47
SX (Unofficial) Reports
48
SA + SX (Unoff)
49
SM + SX(Unoff)
50
SA + SM + SX(Unoff)
51
CS + SX(Unoff)
52
SA + CS + SX (Unoff)
53
SM + CS + SX(Unoff)
54
SA + SM + CS + SX(Unoff)
55
SX(Soil + Unoff)
56
SA + SX( Soil + Unoff)
57
SM + SX(Soil + Unoff)
58
SA + SM + SX(Soil + Unoff)
59
CS + SX(Soil + Unoff)
60
SA + CS + SX(Soil + Unoff)
61
SM + CS + SX(Soil + Unoff)
62
SA + SM + CS + SX(Soil + Unoff)
63
SX(UV + Unoff)
64
SA + SX(UV + Unoff)
65
SM + SX(UV + Unoff)
66
SA + SM + SX(UV + Unoff)
67
CS + SX(UV + Unoff)
68
SA + CS + SX (UV + Unoff)
69
SM + CS + SX(UV + Unoff)
70
SA + SM + CS + SX (UV + Unoff)
71
SX(Soil + UV + Unoff)
72
SA + SX ( Soil + UV + Unoff)
73
SM + SX (Soil + UV + Unoff)
74
SA + SM + SX(Soil + UV + Unoff)
75
CS + SX (Soil + UV + Unoff)
76
SA + CS + SX( Soil + UV + Unoff)
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 106 of 111
77
SM + CS + SX(Soil + UV + Unoff)
78
SA + SM + CS + SX(Soil + UV + Unoff)
79
Reserved
80
FM-13 SHIP SYNOP
81
DRIBU, DRIFTER, Ship
82
Great Lakes obs
83
FM-18 BUOY SYNOP
84
FM-14 MOBIL SYNOP
85
Quebec Co-op Partner data. Hourly report with optional multi-hour
data (e.g. 6, 12, 24 hour intervals).
86
Correction to a previously issued product (COR)
87
Amendment to a previously issued product (AMD)
88
Correction to a previously issued amended product (COR AMD)
89
Cancellation of a previously issued product (CNL)
90
No product available (NIL)
91
Corrected special report (SPECI COR)
92
Reserved
93
Reserved
94
Reserved
95
Reserved
96
Reserved
97
Reserved
98
Reserved
99
Minutely message other than SPECI and METAR
100
Any message type other than 1) a regular hourly message, 2) SPECI
or 3) minutely messages other than SPECI and METAR
101
Report for storm (wind) conditions encountered at sea
102
Regular report (taken at 06:00 and 18:00 PST)
103
Hourly regular report from an LWIS station
104
Supplementary Aviation Weather Report
105
Moored buoy report - Cell GPRS meteorological data
106
Moored buoy report - Cell GPRS housekeeping data
107
Moored buoy report - Cell Wave Data
108
Moored buoy report - Iridium Combined MET/WAVE/Housekeeping
Data
109
Moored buoy report - Iridium meteorological data
110
Moored buoy report - Iridium housekeeping data
111
Moored buoy report - Iridium Wave Data
6.5.10 sky_condition
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
sky_condition
0
Clear (CLR) - The sky condition when no cloud or obscuring
phenomena are present
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 107 of 111
1
Thin scattered (-SCT)
2
Scattered (SCT) - a layer aloft with a summation opacity of 4/10 to
5/10 (amount of 3/8 - 4/8 in METAR), inclusive
3
Thin broken (-BKN)
4
Broken (BKN) - a layer aloft with a summation opacity of 6/10 - 9/10
(amount of 5/8 - 7/8 in METAR), inclusive
5
Thin overcast (-OVC)
6
Overcast (OVC) - a layer aloft with a summation amount of 10/10
(amount of 8/8 in METAR)
7
Obscured (X) - a surface-based layer with summation opacity of
10/10
8
Partially obscured (-X) - a surface-based layer with summation
opacity of at least 1/10 but less than 10/10
9
Thin few (-FEW)
10
Few (FEW) - a layer aloft with a summation opacity of 1/10 to 3/10
(amount of 1/8 - 2/8 in METAR)
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 108 of 111
6.5.11 station_type
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
station_type
0
AUTO 1 (MARS I)
1
AUTO 2 (MARS II)
2
AUTO 3 (MAPS I)
3
AUTO 4 (MAPS II)
4
AUTO 5 - MSC Automatic Weather Observing System (AWOS)
5
AUTO 6 (Hurricane)
6
AUTO 7 - Campbell Scientific data logger automatic weather station
(Partner, non-MSC)
7
AUTO 8 - Campbell Scientific data logger automatic weather station
(MSC owned & operated)
8
AUTO 9
9
Generic AUTO station
10
Limited Weather Information System (LWIS)—MSC or NavCan
11
Nav Canada Human Weather Observing System (NC-HWOS)
12
Nav Canada Automatic Weather Observing System (NC-AWOS)
13
SAWR (Supplementary Aviation Weather Report—Manned); MSC or
NavCan
14
IHR (WinIDE - Manned hourly observations)
15
MIDS (WinIDE-type interface for Manned hourly observations)
16
Generic manual/manned station
17
Generic hybrid: both Manned and Automatic
18
Missing Value
19
A station that reports temperature and precipitation
20
A station that reports temperature only
21
A station that reports precipitation only
22
A station that reports precipitation twice in a day: once in the morning
and once in the evening
23
A station that reports precipitation once a day in the evening
24
A station that reports temperature and precipitation once a day in the
morning
25
A station that reports temperature and precipitation once a day in the
evening
26
A station that reports temperature and precipitation twice a day in the
morning and evening
27
A station that reports temperature once a day in the morning, and
reports precipitation twice a day in the morning and evening
28
A station that reports temperature once a day in the evening, and
reports precipitation twice a day in the morning and evening
29
A station that reports precipitation once a day in the morning
30
Quebec stations which observe precipitation 1-5 times a day
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 109 of 111
6.5.12 tendency_characteristic
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
tendency_characteristic
0
Increasing, then decreasing; atmospheric pressure the same or higher
than three hours ago
1
Increasing, then steady; or increasing, then increasing more slowly
2
Increasing (steadily or unsteadily)
3
Decreasing or steady, then increasing; or increasing, then increasing
more rapidly
4
Steady; atmospheric pressure the same as three hours ago
5
Decreasing, then increasing; atmospheric pressure the same or lower
than three hours ago
6
Decreasing, then steady; or decreasing, then decreasing more slowly
7
Decreasing (steadily or unsteadily)
8
Steady or increasing, then decreasing; or decreasing, then decreasing
more rapidly
9
Reserved
10
Reserved
11
Reserved
12
Reserved
13
Reserved
14
Reserved
15
Missing value
6.5.13 total_cloud_amount
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
total_cloud_amount
0
Sky clear (cloud amount of 0 octas or 0/10) - Manned or Auto station
1
FEW - cloud amount of 1 to 2 octas (1/10 to 3/10)
2
Scattered (SCT) - cloud amount of 3 to 4 octas (cloud coverage of ≤49%
for MSC AWOS observations)
3
Broken (BKN) - cloud amount of 5 to 7 octas (cloud coverage of 50% to
89% for MSC AWOS observations)
4
Overcast (OVC) - cloud amount of 8 octas (cloud coverage of ≥90% for
MSC AWOS observations)
5
Reserved
6
Scattered/broken (Many forecasts use scattered/broken or
broken/overcast
7
Broken/overcast followed by cloud type(s))
8
Isolated (Used on aviation charts to describe the cloud type Cb)
9
Isolated embedded (Used on aviation charts to describe the cloud type
Cb)
10
Occasional (Used on aviation charts to describe the cloud type Cb)
11
Occasional embedded (Used on aviation charts to describe the cloud
type Cb)
12
Frequent (Used on aviation charts to describe the cloud type Cb)
13
Dense (Used on aviation charts to describe cloud that would cause
sudden changes in visibility (less than 1 000 m))
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 110 of 111
14
Layers
15
Obscured (OBSC)
16
Embedded (EMBD)
17
Frequent embedded
18
reserved
19
reserved
20
reserved
21
reserved
22
reserved
23
reserved
24
reserved
25
reserved
26
reserved
27
reserved
28
reserved
29
reserved
30
reserved
31
missing
32
1 okta or less, but not zero (1/10 or less, but not zero)
33
2 oktas (2/10 - 3/10)
34
3 oktas (4/10)
35
4 oktas (5/10)
36
5 oktas (6/10)
37
6 oktas (7/10 - 8/10)
38
7 oktas or more, but not 8 oktas (9/10 or more, but not 10/10)
39
8 oktas (10/10)
40
Sky obscured by fog and/or other meteorological phenomena
41
Cloud cover is indiscernible for reasons other than for or other
meteorological phenomena, or observation is not made
42
Sky Clear reported from manned station.
43
Nil Significant Cloud (clear below 1500 meters)
44
Obscured Significance
45
Sky Clear reported from auto station.
46
Sky obscured by a surface-based layer of coverage ≥90%
47
Sky partially obscured by a surface-based layer with coverage of <90%
48
No clouds detected below 10000 ft
49
Sky partially obscured by fog and/or other meteorological phenomena
50
No cloud detected
51
No clouds detected below 25,000 ft (NC-AWOS)
52
Ceiling and Visibility OK
53
No significant weather
54
Thin few
DMF Team SW-OB-XML User Guide
February 8, 2019 SW-OB-XML User Guide Page 111 of 111
55
Thin scattered
56
Thin broken
57
Thin overcast
6.5.14 wind_gust_squall_indicator
CodeSource
CodeType
CodeValue
CodeDescEng
std_code_src
wind_gust_squall_indicator
0
Gust from an autostation
1
Gust
2
Squall
