PORTABLE QUAD-BAND
MOBILE PHONE
User Manual
Please read this manual before operating your
phone, and keep it for future reference.
T499_UG_UVKE3_PS_051611_F9
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective
suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there
to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international
treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable),
patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of
authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile,
disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the
Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with
SAMSUNG and its suppliers.
Samsung Telecommunications America (STA), LLC
©2011 Samsung Telecommunications America, LLC is a registered trademark of Samsung Electronics America, Inc.
and its related entities.
GH68-34226A
Printed in USA
Do you have questions about your Samsung Mobile Phone?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsung.com/us/support
Headquarters:
1301 E. Lookout Drive
Richardson, TX 75082
Toll Free Tel:
Customer Care Center:
1000 Klein Rd.
Plano, TX 75074
1.888.987.HELP (4357)
Internet Address:
http://www.samsung.com
Nuance®, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance
Communications, Inc., or its affiliates in the United States and/or other countries.
ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other
countries.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B
Design”) are registered trademarks and are wholly owned by the Bluetooth SIG.
microSD™ and the microSD logo are Trademarks of the SD Card Association.
Openwave® is a registered Trademark of Openwave, Inc.
Google, the Google logo, Android, the Android logo, Android Market, Gmail, Google Mail, Google Maps, Google Talk,
Picasa, and YouTube are trademarks of Google Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
Swype and the Swype logos are trademarks of Swype, Inc. © 2010 Swype, Inc. All rights reserved.
Open Source Software
Some software components of this product incorporate source code covered under GNU General Public License
(GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses.
To obtain the source code covered under the open source licenses, please visit:
http://opensource.samsung.com
.
Dynamic Noise Suppression from Audience
Your phone is equipped with an advanced voice processing chip that delivers clear mobile calls by suppressing
background noise, intermittent sounds (like a siren or nearby conversation), and echoes, allowing you to hear and
be heard nearly anywhere.
How Does It Work?
Based on the intelligence of the human hearing system, the technology:
•
Captures, evaluates and distinguishes all the sound signals surrounding your phone, and the person you're speaking with.
•
Then isolates the primary voice in conversation and filters out the background noise - so the person you're calling hears only
your voice, without disturbing background noise.
•
Dynamically equalizes and adjusts voice volume to optimize your calling experience, so you can hear clearly and don't need to
speak louder to overcome surrounding noise.
The noise suppression technology is built-in and already enabled in your new mobile phone. So it's ready to provide
unsurpassed voice clarity with every call.
Disclaimer of Warranties; Exclusion of Liability,
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE
PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE
MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN,
CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE
PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN
THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY
DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE
BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS
OF ANTICIPATED PROFITS OR BENEFITS.
1
Table of Contents
Section 1: Getting Started ................4
Understanding this User Manual . . . . . . . . . . . 4
Battery Cover . . . . . . . . . . . . . . . . . . . . . . . . . 5
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Extending Your Battery Life . . . . . . . . . . . . . . . 9
Power Control . . . . . . . . . . . . . . . . . . . . . . . . 10
Switching the Phone On or Off . . . . . . . . . . . 11
Locking and Unlocking the Phone . . . . . . . . . 11
Creating a New Google Account . . . . . . . . . . 12
Signing into Your Google Account . . . . . . . . . 12
Retrieving your Google Account Password . . 13
Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Task Manager . . . . . . . . . . . . . . . . . . . . . . . 14
Section 2: Understanding Your Phone
15
Features of Your Phone . . . . . . . . . . . . . . . . 15
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Back View of Your Phone . . . . . . . . . . . . . . . 17
Phone Display . . . . . . . . . . . . . . . . . . . . . . . 17
Status Bar . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Function Keys . . . . . . . . . . . . . . . . . . . . . . . . 21
Home Screen . . . . . . . . . . . . . . . . . . . . . . . . 23
Screen Navigation . . . . . . . . . . . . . . . . . . . . 25
Menu Navigation . . . . . . . . . . . . . . . . . . . . . 26
Applications . . . . . . . . . . . . . . . . . . . . . . . . . 27
Customizing the Screens . . . . . . . . . . . . . . . 32
Section 3: Memory Card .................37
Using the SD Card . . . . . . . . . . . . . . . . . . . . 37
SD card Overview . . . . . . . . . . . . . . . . . . . . . 37
Section 4: Call Functions and
Contacts List ................................ 40
Displaying Your Phone Number . . . . . . . . . . . 40
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . 40
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . 40
Answering a Call . . . . . . . . . . . . . . . . . . . . . . 41
Dialing Options . . . . . . . . . . . . . . . . . . . . . . . 41
International Calls . . . . . . . . . . . . . . . . . . . . . 42
Pause Dialing . . . . . . . . . . . . . . . . . . . . . . . . 42
Wait Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . 43
Wi-Fi Calling . . . . . . . . . . . . . . . . . . . . . . . . . 44
In Call Options . . . . . . . . . . . . . . . . . . . . . . . . 46
Call Log Tab . . . . . . . . . . . . . . . . . . . . . . . . . 50
Section 5: Entering Text ................. 53
Text Input Methods . . . . . . . . . . . . . . . . . . . . 53
Selecting the Text Input Method . . . . . . . . . . 53
Using the Swype Keyboard . . . . . . . . . . . . . . 54
Using the Samsung Keypad . . . . . . . . . . . . . . 57
Configuring Samsung Keypad Settings . . . . . 59
Section 6: Contacts ........................ 62
Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Contacts List . . . . . . . . . . . . . . . . . . . . . . . . . 62
Finding a Contact . . . . . . . . . . . . . . . . . . . . . 64
Contact List Options . . . . . . . . . . . . . . . . . . . 66
Contact Menu Options . . . . . . . . . . . . . . . . . . 67
Contact Entry Options . . . . . . . . . . . . . . . . . . 67
Joining Contact Information . . . . . . . . . . . . . . 68
Sending a Namecard . . . . . . . . . . . . . . . . . . . 69
Copying Contact Information . . . . . . . . . . . . . 70
Synchronizing Contacts . . . . . . . . . . . . . . . . . 71
2
Display Options . . . . . . . . . . . . . . . . . . . . . . .71
Get Friends . . . . . . . . . . . . . . . . . . . . . . . . . .72
My Profile . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Additional Contact Options . . . . . . . . . . . . . . .73
Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
The History Tab . . . . . . . . . . . . . . . . . . . . . . .75
The Updates Tab . . . . . . . . . . . . . . . . . . . . . .76
Section 7: Messages .......................77
Types of Messages . . . . . . . . . . . . . . . . . . . .77
Creating and Sending Messages . . . . . . . . . .77
Message Options . . . . . . . . . . . . . . . . . . . . . .78
Viewing Newly Received Messages . . . . . . . .79
Deleting Messages . . . . . . . . . . . . . . . . . . . . .80
Message Search . . . . . . . . . . . . . . . . . . . . . .80
Messaging Settings . . . . . . . . . . . . . . . . . . . .80
Text Templates . . . . . . . . . . . . . . . . . . . . . . .81
Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Microsoft Exchange Email (Outlook) . . . . . . . .84
Using Google Mail . . . . . . . . . . . . . . . . . . . . .87
Google Talk . . . . . . . . . . . . . . . . . . . . . . . . . .88
Section 8: Multimedia .....................89
Using the Camera . . . . . . . . . . . . . . . . . . . . .89
Camera and Camcorder Options . . . . . . . . . . .90
Using the Camcorder . . . . . . . . . . . . . . . . . . .95
Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
The Gallery . . . . . . . . . . . . . . . . . . . . . . . . . .97
Music Player . . . . . . . . . . . . . . . . . . . . . . . . .97
Using Playlists . . . . . . . . . . . . . . . . . . . . . . . .98
Creating a Playlist . . . . . . . . . . . . . . . . . . . . .98
Transferring Music Files . . . . . . . . . . . . . . . . .99
Removing Music Files . . . . . . . . . . . . . . . . . .99
YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Section 9: Applications and
Development ...............................101
Applications . . . . . . . . . . . . . . . . . . . . . . . . .101
Accounts and sync . . . . . . . . . . . . . . . . . . . .101
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . .101
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Google Mail . . . . . . . . . . . . . . . . . . . . . . . . .103
Google Search . . . . . . . . . . . . . . . . . . . . . . .103
Latitude . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Downloading a New Google Application . . . .106
Launching an Installed Google Application . .107
Android Development . . . . . . . . . . . . . . . . . .107
Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . .108
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
My Account . . . . . . . . . . . . . . . . . . . . . . . . .109
My Device . . . . . . . . . . . . . . . . . . . . . . . . . .110
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . .110
News and Weather . . . . . . . . . . . . . . . . . . . .112
Places . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Swype tips . . . . . . . . . . . . . . . . . . . . . . . . . .113
Talk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Task Manager . . . . . . . . . . . . . . . . . . . . . . .113
ThinkFree Office . . . . . . . . . . . . . . . . . . . . . .113
Voice Recorder . . . . . . . . . . . . . . . . . . . . . . .114
3
Voice Search . . . . . . . . . . . . . . . . . . . . . . . 114
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Wi-Fi Calling . . . . . . . . . . . . . . . . . . . . . . . . 115
YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Section 10: Connections ...............116
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Enable Downloading for Web Applications . 124
PC Connections . . . . . . . . . . . . . . . . . . . . . 124
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Mobile AP . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Section 11: Time Management .....128
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Section 12: Changing Your
Settings .......................................131
Wireless and networks . . . . . . . . . . . . . . . . 131
Call Settings . . . . . . . . . . . . . . . . . . . . . . . . 136
Sound Settings . . . . . . . . . . . . . . . . . . . . . . 138
Display Settings . . . . . . . . . . . . . . . . . . . . . 140
Location and Security . . . . . . . . . . . . . . . . . 140
Screen Unlock Pattern Settings . . . . . . . . . 141
Applications . . . . . . . . . . . . . . . . . . . . . . . . 143
Android Development . . . . . . . . . . . . . . . . . 145
Accounts and Synchronization . . . . . . . . . . 146
Privacy Settings . . . . . . . . . . . . . . . . . . . . . 147
SD Card & Phone Storage . . . . . . . . . . . . . . 148
Search Settings . . . . . . . . . . . . . . . . . . . . . 148
Language & Keyboard Settings . . . . . . . . . . 148
Voice Input and Out Settings . . . . . . . . . . . . 151
Accessibility Settings . . . . . . . . . . . . . . . . . 152
Date and Time . . . . . . . . . . . . . . . . . . . . . . 152
About Phone . . . . . . . . . . . . . . . . . . . . . . . . 153
Software Update . . . . . . . . . . . . . . . . . . . . . 153
Section 13: Health and Safety
Information ................................ 154
Exposure to Radio Frequency (RF) Signals . . 154
Specific Absorption Rate (SAR) Certification
Information . . . . . . . . . . . . . . . . . . . . . . . 158
Smart Practices While Driving . . . . . . . . . . . 159
Battery Use and Safety . . . . . . . . . . . . . . . . 160
Samsung Mobile Products and Recycling . . 161
UL Certified Travel Charger . . . . . . . . . . . . . 162
Display / Touch-Screen . . . . . . . . . . . . . . . . 163
GPS & AGPS . . . . . . . . . . . . . . . . . . . . . . . . 163
Emergency Calls . . . . . . . . . . . . . . . . . . . . . 164
Care and Maintenance . . . . . . . . . . . . . . . . 164
Responsible Listening . . . . . . . . . . . . . . . . . 165
Operating Environment . . . . . . . . . . . . . . . . 167
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices . . . . . . . 168
Restricting Children's Access to Your
Mobile Device . . . . . . . . . . . . . . . . . . . . . 170
FCC Notice and Cautions . . . . . . . . . . . . . . . 170
Other Important Safety Information . . . . . . . 170
Section 14: Warranty Information 172
Standard Limited Warranty . . . . . . . . . . . . . 172
End User License Agreement for Software . . 176
Index .............................................. 181
4
Section 1: Getting Started
This section explains how to get started with your
phone by installing and charging the battery, installing
the SIM card and optional memory card, and setting
up your voice mail.
Before using your phone for the first time, you’ll need
to install and charge the battery and install the SIM
card. The SIM card is loaded with your subscription
details, such as your PIN, available optional services,
and many other features. If desired, you can also
install an SD card to store media for use with your
phone.
Understanding this User Manual
The sections of this manual generally follow the
features of your phone. A robust index for features
begins on page 181.
Also included is important safety information that you
should know before using your phone. This
information is available near the back of the guide,
beginning on page 154.
This manual provides navigation instructions
according to the default display settings. If you select
other settings, navigation may be different.
Unless otherwise specified, all instructions in this
manual assume you are starting from the Home
screen and using the available keys.
Note:
Instructions in this manual are based on default settings,
and may vary from your phone, depending on the
software version on your phone, and any changes to the
phone’s Settings.
Unless stated otherwise, instructions in this User Manual
start with the phone unlocked, at the Home screen.
All screen images in this manual are simulated. Actual
displays may vary, depending on the software version of
your phone and any changes to the phone’s Settings.
Special Text
Throughout this manual, you’ll find text that is set
apart from the rest. These are intended to point out
important information, share quick methods for
activating features, to define terms, and more. The
definitions for these methods are as follows:
•
Notes
: Presents alternative options for the current feature,
menu, or sub-menu.
•
Tips
: Provides quick or innovative methods, or useful
shortcuts.
•
Important
: Points out important information about the
current feature that could affect performance.
•
Warning
: Brings to your attention important information to
prevent loss of data or functionality, or even prevent
damage to your phone.
Getting Started 5
Text Conventions
This manual provides condensed information about
how to use your phone. To make this possible, the
following text conventions are used to represent
often-used steps:
Example:
From the Home screen, press (
Menu
)
➔
Settings
➔
Wireless and networks
➔
Bluetooth
settings
.
Battery Cover
The battery and SIM card are installed under the
battery cover.
Important!:
Before removing or replacing the battery cover,
make sure the phone is switched off. To turn the
phone off, hold down the key until the
power-off image displays, then tap
Power off
.
To remove the battery cover:
1. Hold the device firmly and locate the cover
release latch.
2. Place your fingernail in the opening and firmly
“pop” the cover off the device (similar to a
soda can).
To replace the battery cover:
䊳
Position the battery cover over the battery
compartment and press down until you hear a
click.
➔
Arrows are used to represent the
sequence of selecting successive
options in longer, or repetitive,
procedures.
Release Latch
6
SIM Card Overview
Important!:
Before removing or replacing the battery cover,
make sure the phone is switched off. To turn the
phone off, hold down the key until the
power-off image displays, then tap
Power off
.
The SIM card is loaded with your subscription details
such as your telephone number, PIN, available
optional services, and many other features.
Important!:
The SIM card and its information can be easily
damaged by scratching or bending, so be careful
when handling, inserting, or removing the card.
Keep all SIM cards out of reach of small children.
Installing and Removing the SIM card
To install the SIM card:
1. Confirm the battery is not currently installed
within the battery compartment. The battery
blocks the proper installation of the SIM card
into the slot.
2. Carefully slide the SIM card into the SIM card
socket until the card is secured into place.
Make sure that the card’s gold contacts face
down and that the upper-left angled corner of
the card is positioned as shown.
To remove the SIM card:
1. If installed, remove the battery from its
compartment (1 and 2). The battery will block
the proper removal of the SIM card from the
slot.
2. Carefully slide the SIM card out of the SIM card
socket.
Install the SIM Card
Remove the SIM Card
Getting Started 7
Note:
If the card is not inserted correctly, the phone will not
detect it and no service will be available. If this happens,
turn off the phone, remove the card, and reinstall the
card in the correct orientation.
Installing the microSD Memory Card
Your phone supports an optional (external)
microSD™ or microSDHC™ memory card for
storage of media such as music, pictures, video and
other files. The SD card is designed for use with this
mobile phone and other devices.
Note:
microSD memory cards include capacities of up to 2GB.
The microSDHC™ memory card types can range from
4GB to up to 32GB.
Note:
This device supports up to a 32GB microSDHC memory
card.
1. Remove the microSD card slot cover.
2. Orient the card as shown in the illustration.
3. Firmly press the card into the slot and make
sure that it catches with the push-click
insertion. For more information on how to use
the SD card see “Using the SD Card” on
page 37.
Important!:
Be sure to align the gold contact pins on the card
with the phone’s contacts.
Removing the microSD Memory Card
1. Remove the battery cover.
2. Firmly press the card into the slot and release
it. The card should pop partially out of the slot.
3. Remove the card from the slot.
Battery
Before its initial use, install the battery and charge it
fully.
Important!:
Before removing or replacing the battery cover,
make sure the phone is switched off. To turn the
phone off, hold down the key until the
power-off image displays, then tap
Power off
.
Note:
The phone requires approximately 4 hours to achieve a
full charge.
8
Installing the Battery
1. Slide the battery into the compartment (1) so
that the tabs on the end align with the slots at
the bottom of the phone, making sure the
connectors align.
2. Gently press down to secure the battery (2).
Removing the Battery
1. Place your finger into the battery groove (1).
2. Grip the battery at the top end (2) and lift it up
and out of the battery compartment (3).
Charging the Battery
Your phone is powered by a rechargeable Li-ion
battery. A wall charger, which is used for charging the
battery, is included with your phone. Use only
approved batteries and chargers. Ask your local
Samsung dealer for further details.
Before using your phone for the first time, you must
fully charge the battery. A discharged battery
recharges fully in approximately 4 hours.
Verify that the battery is installed prior to connecting
the wall charger. If both the wall charger is connected
and the battery is not installed, the handset will power
cycle continuously and prevent proper operation.
Failure to unplug the wall charger before you remove
the battery, can cause the phone to become
damaged.
Important!:
Although the battery comes partially charged, it is
recommended you fully charge the battery before
using it for the first time.
1. Slide open the Charger/Accessory jack cover.
2. Insert the USB cable into the device’s
Charger/Accessory jack.
Installing Battery
Removing Battery
Getting Started 9
3. Plug the charger into a standard AC power
outlet. The device turns on with the screen
locked and indicates both its charge state and
percent of charge.
Note:
This illustration displays both the
correct
and incorrect
orientation for connecting the charger. If the charger is
incorrectly connected, damage to the accessory port will
occur therefore voiding the phone’s warranty.
4. When charging is finished, first unplug the
charger’s power plug from the AC wall outlet,
then disconnect the charger’s connector from
the phone.
Important!:
If your handset has a touch screen display, please
note that a touch screen responds best to a light
touch from the pad of your finger or a non-metallic
stylus. Using excessive force or a metallic object
when pressing on the touch screen may damage
the tempered glass surface and void the warranty.
For more information, refer to “Standard Limited
Warranty” on page 172.
Low Battery Indicator
When the battery level is low and only a few minutes
of talk time remain, a warning tone sounds and the
“Low battery” message repeats at regular intervals
on the display. In this condition, your phone
conserves its remaining battery power, by dimming
the backlight.
When the battery level becomes too low, the phone
automatically turns off.
Extending Your Battery Life
Active applications, light levels, Bluetooth usage, and
GPS functionality all act to drain your battery. The
following is a list of helpful tips that can help
conserve your battery power:
•
Use the Power Control shortcut bar.
•
Reduce your backlight on time.
•
Turn Bluetooth off when not in use.
•
Turn Wi-Fi off when not in use.
•
Deactivate the GPS when not needed. Most applications
using this function will periodically query the GPS
satellites for your current location; each query drains your
battery.
Correct
Incorrect
10
•
Do not wait until your battery is completely depleted
before charging your device. Repeating this process of a
complete discharge and recharge can over time reduce
the storage capacity of any battery.
•
Turn off Automatic application sync.
•
Use the Power Control Widget to deactivate hardware
functions such as Wi-Fi, Bluetooth, GPS, Synchronization,
or LCD brightness setting.
•
Check the Battery use screen to review what features or
functions have been consuming your battery resources.
•
Check the Running Services and close any unnecessary
applications.
•
Use the Task Manager feature to end/shutdown
background applications that are still running. These
minimized applications can, over time, cause your device
to “slow down”.
Power Control
Active applications, Wi-Fi, Bluetooth, GPS,
Synchronization, Location consent, or the LCD
Brightness functionality all act to drain your battery.
The Power Control shortcut bar was designed to
quickly activate (turn on), or deactivate (turn off) those
functions or applications that use the most battery
power.
1. From the
Home
screen,
touch and
hold an
empty area
until the
Add to
Home
screen
menu
displays.
2. Tap
Widgets
➔
Power control
. The Power
Control shortcut is added to the current screen.
3. Tap any of the icons on the Power Control
shortcut bar to activate/deactivate the feature.
Note:
A green bar displayed beneath the icon means the
application is active (turned on). The green bar is removed
from beneath the icon when the feature is deactivated
(turned off).
Getting Started 11
Switching the Phone On or Off
If you do not have a SIM card installed the first time
you turn on the device, you are presented with a No
SIM icon ( ) displays.
At this point you can make an emergency call with
the phone but normal cell phone service is not
available.
1. Press and hold until the phone
switches on.
The phone searches for your network and after
finding it, you can make or receive calls.
Note:
The display language is preset to English at the factory.
To change the language, use the Language menu. For
more information, refer to “Language & Keyboard
Settings” on page 148.
2. Press and hold until the Phone
options screen appears.
3. Tap
Power Off
().
Locking and Unlocking the Phone
By default, the phone screen locks when the
backlight turns off.
To unlock your phone from this lock screen:
䊳
Touch and drag the screen lock icon to
the right.
Note:
You can choose to configure lock settings to prevent
unauthorized use of your phone. For more information,
refer to “Setting up SIM Card Lock” on page 142.
Screen Lock
12
Creating a New Google Account
You should create a Google™ Account when you first
use your device in order to fully utilize the
functionality. This account provides access to several
device features such as Gmail, Google Maps, Google
Search, and the Android Market applications. Before
you are able to access Google applications, you must
enter your account information.
These applications sync between your device and
your online Google account.
To create a new Google Account from your phone:
1. From the Home screen, tap (
Market
).
2. Read the introduction and tap
Next
➔
Create
to
begin.
3. Follow the on-screen instructions to create a
Google Account.
– or –
If this is not the first time you are starting the
phone, tap ➔ (
Gmail
).
Note:
If you already have a Google account, you only need to
sign in.
To create a new Google Account from the Web:
1. From a computer, launch a Web browser and
navigate to
www.google.com
.
2. On the main page, click
Sign-in
➔
Create an
account now
.
3. Follow the on-screen prompts to create your
free account.
4. Look for an email from Google in the email box
you provided, and respond to the email to
confirm and activate your new account.
Signing into Your Google Account
1. Launch an application that requires a Google
account (such as Android Market or Gmail).
2. Click
Next
➔
Sign in
.
3. Tap the
Username
and
Password
fields and
enter your information.
4. Tap
Sign in
. Your device communicates with the
Google servers to confirm your information.
5. If prompted, create a new Gmail username by
entering a prefix for your
@gmail.com
email
address.
Getting Started 13
Retrieving your Google Account
Password
A Google account password is required for Google
applications. If you misplace or forget your Google
Account password, follow these instructions to
retrieve it:
1. From your computer, use an Internet browser
and navigate to
http://google.com/accounts.
2. Click on the
Can’t access your account?
link.
3. From the
Please select your issue
section,
select
I forgot my password
.
4. Enter your full Gmail address and click
Submit
.
Follow the password recovery procedure.
Voice Mail
Setting Up Your Voice Mail
Your device automatically transfers all unanswered
calls to voicemail, even if your device is in use or
turned off. As soon as your battery is charged and the
SIM card inserted, activate your voicemail account.
Important!:
Always use a password to protect against
unauthorized access.
For new users, follow the instructions below to set up
voice mail:
Note:
Voicemail setup may be different depending on your
network.
1. From the Home screen, tap and then
touch and hold the key until the phone
dials voice mail.
You may be prompted to enter a password.
2. Follow the tutorial to create a password, a
greeting, and a display name.
Accessing Your Voice Mail
You can access your Voice Mail by either pressing
and holding on the keypad, or by using the
phone’s Application icon, then touching the Voice
Mail application.
To access Voice Mail using the menu:
1. From the Home screen, tap and then
touch and hold until the phone dials
voice mail.
Note:
Touching and holding will launch Visual voicemail
if it is already active on your phone.
2. When connected, follow the voice prompts
from the voice mail center.
Accessing Your Voice Mail From Another Phone
1. Dial your wireless phone number.
2. When you hear your voicemail greeting, press
the asterisk key on the phone you are using.
3. Enter your passcode.
1
1
1
1
14
Task Manager
Your phone can run applications simultaneously, with
some applications running in the background.
Sometimes your device might seem to slow down
over time, and the biggest reason for this are
background applications. These are applications that
were not properly closed or shutdown and are still
active but minimized. The Task Manager not only lets
you see which of these applications are still active in
the background but also easily lets you choose which
applications are left running and which are closed.
Note:
The larger the number of applications running on your
phone, the larger the energy drain on your battery.
Task Manger Overview
䊳
From the Home screen, tap (
Applications
)
➔
Task Manager
().
– or –
Press and hold then tap
Task manager
.
This screen contains the following tabs:
• Active applications
display those currently active
applications running on your phone.
• Package
displays any installed packages or
applications from the Market that are taking up
memory space. Tap
Uninstall
to remove them from
your phone.
• RAM
, which displays the amount of current RAM
(Random Access Memory) currently being used and
allow you to
Clear memory
.
• Summary
displays a visual graph indicating the
available and used space within the Random Access
Memory (RAM), Storage, and External SD card.
•Help
provides additional battery saving techniques.
Shutting Down an Currently Active Application
1. From the Home screen, tap ➔
Task
Manager
().
2. From the
Active applications
tab, tap
End
to
close selected applications or tap
End all
to
close all background running applications.
Understanding Your Phone 15
Section 2: Understanding Your Phone
This section outlines key features of your phone. It
also describes the phone’s keys, screen and the
icons that display when the phone is in use.
Features of Your Phone
Your phone is lightweight, easy-to-use and offers
many significant features. The following list outlines
a few of the features included in your phone.
•
Touch screen with virtual (on-screen) QWERTY keyboard
•
Android 2.2, Froyo
•
Wi-Fi
®
Capability
•
USB Tethering-capable
•
Bluetooth enabled
•
Full integration with Google applications (Gmail, YouTube,
Google Maps)
•
Multiple Messaging Options: Email, Picture Messaging,
Google Talk, Google Search, Video Messaging, Text
Messaging, Predictive Text
•
Supports synchronizing with a corporate email account
•
3.0 Megapixel camera and video with multi shot and
digital zoom
•
MP3 player with Multitasking features
•
Assisted GPS (TeleNav GPS Navigation)
•
Webkit-based browser
•
Downloadable applications from Android Market
•
Up to 32GB expandable memory slot
•
Mobile Hotspot Capability
•
YouTube
Front View
The following illustrations show the main elements of
your phone:
The following list correlates to the illustrations.
1.
USB Power/Accessory connector
allows you to
connect a power cable or optional accessories
such as a USB/data cable.
78
9
11
12
14
65
4
2
1
13
10
3
16
2.
Strap holder
is used to connect a carrying strap
to the phone.
3.
Proximity Sensor
detects how close an object is
to the surface of the screen. This is typically
used to detect when your face is pressed up
against the screen, such as during a phone call.
–
While talking on the phone, the sensor detects talk
activity and locks the keypad to prevent accidental key
presses.
4.
Volume key
allows you to adjust the ringer
volume in standby mode (with the phone open)
or adjust the voice volume during a call. When
receiving an incoming call:
•
Pressing the volume key down mutes the ring tone.
•
Pressing and holding the volume key rejects the call.
5.
Menu key
displays a list of options available for
the current screen. From the Home screen it
displays Add, Wallpaper, Search, Notifications,
Edit, and Settings options.
6.
Home
key displays the Home screen when
pressed.
7.
Back key
redisplays the previous screen or
clears entries.
8.
Microphone
is used during phone calls and
allows other callers to hear you clearly when
you are speaking to them. It is also used to
make voice note recordings.
9.
Quick search
is used to search the device for
applications, contact information, or searches
the internet for information.
10.
microSD Card Slot
allows you to use a microSD
card to expand the memory of your phone.
11.
Display
shows all the information needed to
operate your phone, such as the connection
status, received signal strength, phone battery
level, and time.
12.
Power/End key
ends a call or switches the
phone off and on. Press and hold for two
seconds to turn off Silent mode, Flight mode, or
to turn the phone on or off.
13.
Receiver
allows you to hear the other caller and
the different ring tones or sounds offered by
your phone.
14.
Headset jack
allows you to connect a hands-
free headset so you can listen to music.
Understanding Your Phone 17
Back View of Your Phone
The following illustration shows the external
elements of your phone:
1.
External speaker
allows you to hear ringers,
music, and other sounds offered by your
phone.
2.
Camera lens
is used to take photos.
Phone Display
Your phone’s display provides information about the
phone’s status, and is the interface to the features of
your phone. The display indicates your connection
status, signal strength, battery status and time. Icons
display at the top of the phone when an incoming call
or message is received and also alerts you at a
specified time when an alarm was set. The screen
also displays notifications, and Application (or
shortcut) bar with four icons: Phone, Contacts,
Messaging, and Applications.
Display settings
In this menu, you can change various settings for the
for the wallpaper, cube, brightness or backlight.
䊳
From the Home screen, tap
(
Applications
) ➔
(
Settings
) ➔
Display
.
For more information, refer to “Display
Settings” on page 140.
Status Bar
The Status Bar shows information about the
connection status, signal strength, phone battery
level, and time, and displays notifications about
incoming messages and calls and other actions.
This list identifies the icons you see on your phone’s
display screen:
1 2
Google
Home
Primary
Notification
Shortcuts
Status Bar
area
Status
area
Shortcuts
Battery status
Connection Status
Time
Signal strength
search
Screen
18
Indicator Icons
This list identifies the symbols you’ll see on your
phone’s display and Indicator area:
Displays your current signal strength. The
greater the number of bars, the stronger
the signal.
Indicates that the Flight Mode is active.
You cannot send or receive any calls or
access online information.
Indicates there is no signal available.
Displays when there is no SIM card in the
phone.
Displays when there is a system error or
alert.
Displays when there is a power saver
alert has been triggered. This alert occurs
when the power saver feature has been
activated and the phone has less than a
30% battery charge level. For more
information, refer to “My Account” on
page 109.
Displays when a call is in progress.
Displays when a call is on hold.
Displays when you have missed an
incoming call.
Displays when the speakerphone is on.
Displays when Call forwarding is set to
Always forward. For more information,
refer to “Configuring Call Forwarding” on
page 138.
Displays your current battery charge
level. Icon shown is fully charged.
Displays your current battery charge level
is very low.
Shows your current battery only has
three percent power remaining and will
immediately shutdown. Represented as a
blinking icon.
Displays when connected to the EDGE
network.
Displays when your phone is
communicating with the EDGE network.
Displays when connected to the 3G
network.
Displays when your phone is
communicating with the 3G network.
Displays when the phone is connected to
a computer using a supported USB cable
connection.
Displays when there is a new text
message.
Understanding Your Phone 19
Displays when an outgoing text message
has failed to be delivered.
Displays when there is a new voicemail
message.
Displays when there is a new visual
voicemail message.
Displays in the notifications window
when there is a new Email message.
Displays when an alarm is set.
For more information, refer to “Setting an
Alarm” on page 129.
Displays when the Sound profile is set to
Silent mode and Vibrate is set to Always
or Only in silent mode.
Displays when data synchronization and
application sync is active and
synchronization is in progress
for Gmail, Calendar, and Contacts.
Displays when the Sound profile is set to
Silent mode and Vibrate is set to Never or
Only when not in silent mode.
Displays when Bluetooth technology is
active and enabled.
Displays when the Bluetooth technology
is active and communicating with an
external device.
Displays when Wi-Fi is connected, active,
and communicating with a Wireless
Access Point (WAP).
Displays when Wi-Fi is active and there
are open networks available.
Displays when the Mobile AP Hotspot
feature is active and communicating. For
more information, refer to “Mobile AP”
on page 126.
Displays when the USB Tethering feature
is active and communicating. For more
information, refer to “Tethering” on
page 133.
Displays when your phone’s GPS is on
and communicating.
Displays when the Wi-Fi calling feature is
active and in use.
Displays when the external SD card
(internal microSD) has been
disconnected (unmounted) from the
phone and is now ready for either
removal or formatting.
Displays when the External SD card is
being prepared for mounting to the
device. This is required for
communication with the External SD
card.
Displays when the microSD card has
been improperly removed.
20
For more details on configuring your phone’s settings,
see “Changing Your Settings” on page 131.
Notification Bar
The Notification area indicates new message events
(data sync status, new messages, calendar events,
call status, etc). You can expand this area to provide
more detailed information about the current on-
screen notification icons.
1. Tap the Status bar to reveal the Notifications
tab, and then drag the tab to the bottom of the
screen to open the Notifications panel (1).
2. Tap a notification entry to open the associated
application (2).
Note:
The Notifications panel can also be opened on the Home
screen by pressing and then tapping
Notifications
.
Clearing Notifications
To clear all notifications from the Notification panel:
1. Tap the status bar to reveal the Notifications
tab, and then drag the tab to the bottom of the
screen to open the Notifications panel
2. Tap
Clear
. The notifications are cleared from the
panel.
Accessing Additional Panel Functions
In addition to notifications, this panel also provides
quick and ready access to five device functions.
These can be quickly activated or deactivated.
The following functions can either be activated (blue)
or deactivated (white):
Wi-Fi
,
Bluetooth
,
GPS
,
Silent
, or
Auto rotation
.
Understanding Your Phone 21
Function Keys
Your phone comes equipped with four main function
keys that can be used on any screen:
Menu
,
Home
,
Back
, and
Search
.
Menu Key
The
Menu
key ( ) activates an available menu
function for the current screen or application. When
on the Home screen, the following menu options are
available:
•
Add
( ) adds one of the following functions to a
selected screen: Widgets, Shortcuts, Folders, and
Wallpapers.
•
Wallpaper
( ) lets you to customize the current
screen’s wallpaper image by choosing from either
Gallery, Live wallpapers, or Wallpaper gallery).
–
You can obtain images from either your Pictures folder,
from any of the available images within the device’s
Wallpaper gallery, or from the animated Live Wallpapers.
•
Search
( ) displays the Google Search box that you
can use to search for a key term both on the phone and
online.
•
Notifications
( ) allows you to expand popup
notifications area to provide more detailed information
about the current on-screen notification icons.
•
Edit
( ) allows you to add or remove extended
screens from your device. You can have up to eight
extended screens.
•
Settings
( ) provides quick access to the device’s
settings menu.
–
The Settings menu can also be accessed by pressing
and then tapping
➔
Settings
.
Home Key
The
Home
key ( ) takes you back to your Home
screen (#3 of the 7 total available screens).
䊳
Press and hold to launch the Recent Apps/Task
Manager screen. For more information, refer to
“Accessing Recently-Used Applications” on
page 27.
Back Key
The
Back
key ( ) returns you to the previously
active screen. If the on-screen keyboard is currently
open, this key closes the keyboard.
Search Key
The
Search
key ( ) displays the Google Search
box that can be used to search for either a key term
both on the phone and online. In some instances, this
key opens a search box specific only to the current
application.
Voice Search (speech to text)
Search
Options
Search
Field
22
1. Press to launch the Google Search box.
– or –
Press and tap ➔ .
2. Tap to launch the
Voice Search
function.
Using Google Search
Use the Google Search box to manually search for a
term on both your device and on the Web.
1. Press to launch the Google Search box.
2. Tap to select a search area:
•All
searches your device, the Web, and the Android
Market for your search term.
•Web
searches for your term only on the Web using
the Google search engine.
• Apps
searches for your term only within the Android
Market.
•Contacts
searches for your term only within your
current Contacts entries.
3. Enter a search term and tap a match from the
list of suggestions, phone search results, or
previously chosen search matches. Once
touched, the item opens in the appropriate
application.
– or –
Touching
Voice Search
( ) lets you speak
into your device's microphone to enter a search
term.
Using Additional Voice Search Functions
For more information, refer to:
http://www.google.com/mobile/voice-actions/
.
From an open Voice Search dialog, speak the
following words to access additional features:
•
voice actions
(such as: [your query]) allows you to search
the web by speaking the search parameters.
•
listen to [artist/song/album]
allows you to begin
listening to the selected song on Slacker radio.
•
send text to [recipient] [message]
allows you to open
the Messaging screen.
•
navigate to [address/city/business name]
allows you
to receive directions via Google maps™. Use either an
Address name, Business name, business type, or other
navigation information to get the desired directions.
•
call [name]
allows you to open the phone dial and
automatically
•
send email to [recipient] [subject]
allows you to open
your email account and compose a new email message.
•
map of [location]
allows you to view a map of an area via
Google maps. Use either an Address name, Business
name, zip code, or other navigation information.
•
go to [website]
allows you to navigate to any component
of your device.
•
note to self [message]
allows you to search for a note
save to your Memo Pad.
Understanding Your Phone 23
Home Screen
The Home screen is the starting point for using the
applications on your phone. There are seven
available panels, each populated with default
shortcuts or applications. You can customize each of
these panels.
•
Notification area
displays those icons associated with
end-user notifications such as: email messages, calls
(missed, call in progress), new voicemail, upcoming
event, USB connection, emails, and Text/MMS messages.
–
These notifications appear at the top-left of the screen
(within the Status bar area) and display important user
information.
–
This information can be accessed by either swiping down
from the Status bar (page 20) or by accessing the
Notifications panel [
>
Notifications
()].
•
Status area
displays those icons associated with the
status of the device such as communication, coverage,
Bluetooth, 3G and Wi-Fi communication, battery levels,
GPS, etc.
•
Home Screen
is a customizable screen that provides
information about notifications and device status, and
allows access to application Widgets.
•
Extended Home Screens
extend beyond the current
visible screen width to provide more space for adding
icons, widgets, and other customization features.
–
There are seven available extended screens (panels) each
of which may be populated with its own shortcuts or
widgets. These screens share the use of the three
Primary Shortcuts.
–
The current screen is indicated at the top by a larger
circle. Up to seven (7) total screens are available.
Note:
Both the status bar and primary shortcuts are visible
across all screens.
•
Google search
is an on-screen Internet search engine
powered by Google™. Touch to access the Voice Search
feature where you can verbally enter a search term and
initiate an online search.
•
Widgets
are self-contained on-screen applications (not
shortcuts). These can be placed onto any of the available
screens (Home or extended).
Google search bar/Widget
Home
Primary
Notification
Shortcuts
Status Bar
area
Status
area
Shortcuts
Screen
24
•
Shortcuts
are icons that launch available device
applications such as Camera, YouTube, Voicemail,
Contacts, Phone, Email, Market, etc. These function the
same as shortcuts on your computer.
–
Although some may already be found on the Extended
Home screens, the majority can also be found within the
Applications screens.
–
The Application screens can be accessed by tapping
(
Applications
) from the Primary shortcuts area.
–
Shortcuts can be removed from a screen and added back
any number of times.
•
Primary Shortcuts
: are four shortcuts present throughout
all of the available screens and can be used to both
navigate within the device or launch any of the following
functions:
–
Phone
( ) launches the phone-related screen
functions (Dialer, Call log, Favorites, and Contacts).
–
Contacts
( ) launches the Contacts-related screens
(Contacts, Groups, History, and Updates).
–
Messaging
( ) launches the Messaging menu
(create new messages or open an existing message
string).
–
Applications/Home
toggles functionality between the
Home and Application screens.
•
Tap (
Applications
) to access the Application
screens loaded with every available local application.
•
While in the Applications screens, tap
(
Home
)
to easily return to the Home screen.
As you transition from screen to screen, the screen
counter (located at the top) displays the current panel
number in a circle.
Counter displays
the currently
active screen
Widget
Understanding Your Phone 25
Screen Navigation
Using the touch screen display and the keys, you can
navigate the features of your phone and enter
characters. The following conventions are used in
this manual to describe the navigation action in the
procedures.
Navigating Through the Screens
The following terms describe the most common
hardware and on-screen actions.
•
Press and hold
:
Pressing relates to use of the hardware
keys and buttons to select or activate an item. For
example: press the Navigation key to scroll through a
menu. Some buttons and keys require you to press and
hold them to activate a feature, for example, you press
the Lock key to lock and unlock the phone.
•
Tap
: Use a brief touch to select items on the display or to
enter text on the virtual QWERTY keyboard. For example:
touch an Application icon to open the application. A light
touch works best.
•
Touch and hold
: Touch and hold an icon or key to open
the available options, or to access a pop-up menu. For
example: press and hold from the Home screen to access
a menu of customization options.
•
Flick
: Move your finger in lighter, quicker strokes than
swiping. This finger gesture is always used in a vertical
motion, such as when flicking through contacts or a
message list.
Press and hold Tap Touch and hold
Flick
Swipe or
Rotate
slide and
Drag
26
•
Swipe or slide
: Quickly drag your finger vertically or
horizontally across the screen. This allows you to move
the area of focus or to scroll through a list. For example:
slide your finger left or right on the Home screen to scroll
among the seven panels.
•
Drag
: Press and hold your finger with some pressure
before you start to move it. Do not release your finger until
you have reached the target position.
•
Rotate
: Automatically change the screen orientation from
portrait to landscape by turning the device sideways. For
example: rotate to landscape orientation when entering
text, to provide a larger keyboard, or when viewing web
content to minimize scrolling.
•
Pinch
: “Pinch” the screen using your thumb and
forefinger to zoom out when viewing a picture or a Web
page. (Move fingers inward to zoom out.)
•
Spread
: “Spread” the screen using your thumb and
forefinger to zoom in when viewing a picture or a Web
page. (Move fingers outward to zoom in.)
Note:
These screens can be re-arranged in any desired order.
For more information, refer to “Customizing the Screens”
on page 32.
Menu Navigation
You can tailor the phone’s range of functions to fit
your needs using both menus and applications.
Menus, sub-menus, and features are accessed by
scrolling through the available on-screen menus. Your
phone defaults with seven home screens.
Navigating Through the Application Menus
There are four default Application Menus available. As
you add more applications from the Android
Marketplace, more screens are created to house
these new apps.
1. Press and then tap (
Applications
).
The first Application Menu displays.
•
To close the Applications screen, tap or press
.
2. Sweep the screen to access the other menus.
3. Tap any of the on-screen icons to launch the
associated application.
Pinch (Zoom Out)
Spread (Zoom In)
Understanding Your Phone 27
Using Sub-Menus
Sub-menus are available from within most screen
and applications.
1. Press . A sub-menu displays at the
bottom of the phone screen.
2. Tap an option.
Using Context Menus
Context menus (also called pop-up menus) contain
options that apply to a specific item on the screen.
They function similarly to menu options that appear
when you right click your mouse on your desktop
computer.
䊳
Touch and hold an item on-screen to open its
context menu.
Accessing Recently-Used Applications
1. Press and hold the to open the recently-
used applications window.
Note:
This recent applications screen also provides access to
the
Task manager
.
2. A pop-up displays the six most recently used
applications.
3. Tap an icon to open the recent application.
Applications
The Application menu provides quick access to the
most frequently used applications. Applications
display on each of the three panels on the
Applications screens.
The following table contains a description of each
application available via both the Primary shortcuts
area and via the Applications screens. If the
Sub-Menu items
Context
Menu
28
application is already described in another section of
this user manual, then a cross reference to that
particular section is provided. For information on
navigating through the Applications icons, see
“Navigating Through the Application Menus” on
page 26.
Accounts and sync
Allows you to add applications and
determine which type of account
information you want to synchronize with
your Contact list. For more information, refer
to “Accounts and Synchronization” on
page 146.
Calculator
Launches the on-screen calculator
application. The calculator provides the
basic arithmetic functions; addition,
subtraction, multiplication, and division. You
can also use this as a scientific calculator.
For more information, refer to “Calculator”
on page 101.
Calendar
Launches a calendar application that syncs
to your Facebook™, Google™, or Microsoft
Exchange work calendars.
For more information, refer to “Calendar”
on page 128.
Camera
Launches the built-in 3.0 megapixel camera
application from where you can take a
picture with the rear facing camera.
Note:
An SD card must be inserted before the
camera will take and store photos.
For more information, refer to “Using the
Camera” on page 89.
Clock
Allows you to set an alarm, configure and
view the World clock, use a stopwatch, or
set a timer. The applications display in a
tabular format and quickly accessed with
the touch of a finger.
For more information refer to Alarms &
Clocks on page 129.
Contacts
The default storage location for saving
phone numbers to your Contacts List is your
phone’s built-in memory.
For more information, refer to “Contacts
List” on page 62.
Understanding Your Phone 29
Email
Provides access to both your Outlook
(Exchange Server-based) work email and
Internet email accounts (such as Gmail and
Yahoo! Mail). For more information, refer to
“Email” on page 82.
Files
Lets you view supported image files and text
files on your microSD card. Organize and
store data, images, and more in your own
personal file folders. Files are stored to the
memory card in separate (user defined)
folders.
For more information, refer to “Files” on
page 96.
Gallery
Displays a Gallery of camera images and
video stored in the microSD card. For more
information, refer to “The Gallery” on
page 97.
Gmail
Provides access to your Gmail account.
Google Mail (Gmail) is a web-based email
service. Gmail is configured when you first
set up your phone. For more information,
refer to “Using Google Mail” on page 87.
Google Search
Provides an on-screen Internet search
engine powered by Google™. For more
information, refer to “Using Google Search”
on page 22.
Latitude
Lets you see your friends’ locations and
share yours with them. The application also
lets you see your friends’ locations on a
map or in a list. It also lets you send instant
messages and emails, make phone calls,
and get directions to your friends’ locations.
For more information, refer to “Latitude” on
page 103.
Maps
Launches a Web-based dynamic map that
helps you find local businesses, locate
friends, view maps and get driving
directions. For more information, refer to
“Maps” on page 104.
Market
Allows you to find and download free and
for-purchase applications on Android
Market. For more information, refer to
“Downloading a New Google Application”
on page 106.
Memo
Creates new text memos. For more
information, refer to “Memo” on page 108.
30
Messaging
Provides access to text and multimedia
messaging (SMS and MMS). For more
information, refer to “Creating and Sending
Messages” on page 77.
Music
Launches the built-in Music Player that
allows you to play music files that you have
stored on your microSD card. You can also
create playlists. For more information, refer
to “Music Player” on page 97.
My Account
Provides you with account specific
information such as: current status, Activity,
Set Alerts, Bill Summary, Plan Services, and
FAQ’s Info. For more information, refer to
“My Account” on page 109.
My Device
Allows you to configure device settings,
view Personalize your CallerTunes,
Ringtones, or Wallpapers, View Quick Tools,
Support, and battery storage information.
For more information, refer to “My Device”
on page 110.
Navigation
Launches a Web-based navigation
application.
Caution!:
Traffic data is not real-time and
directions may be wrong, dangerous,
prohibited, or involve ferries.
For more information, refer to “Navigation”
on page 110.
News & Weather
Launches a Web-based news and weather
feed based on your current location. For
more information, refer to “News and
Weather” on page 112.
Places
Displays company logos on a layer of Google
Maps. When viewing an area you can
quickly locate a business or person, find out
more information about the business, see
coupons, public responses, and more. For
more information, refer to “Places” on
page 112.
Settings
Accesses the device’s built-in Settings
menu. For more information, refer to
“Changing Your Settings” on page 131.
Understanding Your Phone 31
Swype Tips
Provides an on-screen video tutorial that
teaches you how to use Swype text input
method. For more information, refer to
“Swype Text Entry Tips” on page 55.
Talk
Launches a Web-based Google Talk
application that lets you chat with family
and friends over the Internet for free. For
more information, refer to “Google Talk” on
page 88.
Task Manager
Use Task Manager to see which applications
are running on your phone, and to end
running applications to extend battery life.
For more information, refer to “Task
Manager” on page 113.
ThinkFree Office
ThinkFree Office Mobile for Android is a
Microsoft Office compatible office suite. This
application provides a central place for
managing your documents online or offline.
For more information, refer to “ThinkFree
Office” on page 113.
Voice Recorder
Allows you to record an audio file up to one
minute long and then immediately send it as
a message. For more information, refer to
“Voice Recorder” on page 114.
Voice Search
Launches your phone’s built-in voice
recognition software and initiates a Google
search based on the recognized text. For
more information, refer to “Voice Search”
on page 114.
Web
Open the browser to start surfing the web.
The browser is fully optimized and comes
with advanced functionality to enhance the
Internet browsing feature on your phone.
For more information, refer to “Web” on
page 116.
Wi-Fi Calling
Provides the ability to use your available Wi-
Fi data connection to make outbound calls
that do not count against your phone
minutes. Similar to VOIP (Voice Over IP). For
more information, refer to “Wi-Fi Calling”
on page 44.
YouTube
Launches the YouTube webpage via the
browser. For more information, refer to
“YouTube” on page 99.
32
Customizing the Screens
You can customize the Home screens (panels) to
display the Widgets, Shortcuts, Folders, or
Wallpapers. For example, one screen could contain
the Music Player shortcut and other forms of media,
while another screen might contain communication
apps such as Gmail and IM.
You can customize your Home screen by doing the
following:
•
Adding, Deleting, and Rearranging screens
•
Adding and Removing Shortcuts
•
Adding and Removing Widgets
•
Creating Folders
•
Changing the Background (Wallpapers)
Adding and Deleting Screens
Your phone comes with seven screens. You can delete
these screens and then add them back later.
Note:
These screens can be deleted and re-arranged.
Important!:
Your phone can only contain at most seven screens
and at least one screen.
To delete a screen:
1. Press
➔ and
then tap
(
Edit
).
2. Touch and
hold, then
drag the
undesired
screen down
to the
Remove
tab ( ).
3. Press to return to the main Home screen.
To add a screen:
1. Press ➔ and then tap
(
Edit
).
2. Tap the
Add
icon ( ). The newly added
screen appears as the last page.
3. Press to return to the main Home screen.
Rearranging the Screens
1. Press ➔ and then tap
Edit
( ).
2. Touch and hold a screen and then drag it into
its new location. Upper-left is screen position
#1 and bottom-right is screen position #7.
Understanding Your Phone 33
Adding and Removing Primary Shortcuts
The device comes with four Primary shortcuts:
Phone, Contacts, Messaging, and Applications/Home.
As long as the menu is displayed in a
Customizable
grid
, you can replace the Phone, Contacts, and
Messaging shortcuts with other applications so you
access the shortcuts that are most frequently used.
1. Press and then tap
(
Applications
).
2. Press and then tap
View type
➔
Customizable grid
.
3. Press and then tap
Edit
. A box outline
then appears around the application icons.
4. Scroll through the list and locate the desired
application.
5. Touch and hold the on-screen icon, then drag it
over one of the four primary shortcuts to
replace it.
•
The new primary shortcut displays at the bottom of
the screen. The previous primary shortcuts switches
places with your selected icon.
6. Press and then tap
Save
.
7. Tap to return to the Home screen.
Managing Shortcuts
Note:
To move a shortcut from one screen to another, you must
carefully touch and hold the shortcut and slowly drag it to
the edge of the screen. As the shortcut turns light blue,
you can begin to move it to the adjacent screen.
If this does not work, delete it from its current screen.
Activate the new screen and then add the selected
shortcut.
To add a shortcut from the Applications screen:
1. Press to
go to the
Home screen.
2. Select a
location
(screen) for
your new
shortcut by
scrolling
across your
available
screens until
you reach the
desired one.
3. Tap
Applications
( ) to reveal all your
current available applications. By default,
applications are displayed as an Alphabetical
grid.
34
4. Scroll across the screens and locate your
desired application.
5. Touch and hold the on-screen icon. The new
shortcut then appears to hover over the current
screen.
6. While still holding the on-screen icon, position
it on the current screen. Once complete,
release the screen to lock the shortcut into its
new position.
To add a shortcut via the Add to Home screen:
1. Press to
go to the
Home screen.
2. Touch and
hold an empty
area of the
screen.
3. From the
Add
to Home
screen
window tap
Shortcuts
.
4. Tap a selection from the available list.
To delete a shortcut:
1. Press to go to the Home screen.
2. Touch and hold the desired shortcut. This
unlocks it from its location on the current
screen.
3. Drag the shortcut over the
Remove
tab ( )
and release it.
Adding and Removing Widgets
Widgets are self-contained applications that can be
placed on any screen. Unlike shortcuts, widgets
appear as applications.
To add a Widget:
1. Press to go to the Home screen.
2. Touch and hold an empty area of the screen.
3. From the
Add to Home screen
window tap
Widgets
.
4. Tap an available Widget to place it on your
current screen.
To remove a Widget:
1. Touch and hold a Widget until it unlocks from
the current screen.
2. Drag the widget over the
Remove
tab ( )
and release it.
•
As you place the Widget into the Trash, both items
turn red.
Understanding Your Phone 35
•
This action doesn’t delete the Widget, it just removes
it from the current screen.
To place a widget onto a different screen:
1. Touch and hold the widget until it becomes
transparent.
2. Drag it to the edge of your screen.
3. Slowly drag it past the edge of the screen until
it turns light blue.
4. Drag the widget to its desired position on the
new screen.
5. Repeat these steps to continue moving it to
other screens.
Creating and Managing a Folder
Folders hold items that you want to organize and
store together on the workspace.
To create a new on-screen folder:
1. Press to go to the Home screen.
2. Touch and hold an empty area of the screen.
3. From the
Add to Home screen
window tap
Folders
.
4. Tap an available folder type and place it on the
current screen.
Renaming a folder
1. Tap the desired folder you want to rename.
2. With the folder open, touch and hold the Folder
title bar (top of the Folder window) until the
Rename folder
pop-up displays.
3. Tap the folder name field, enter a new title for
this folder and tap
OK
.
Deleting a folder
1. Touch and hold a desired folder. This unlocks it
from its location on the current screen.
2. Drag the folder over the
Remove
tab ( )
and release it.
Managing Wallpapers
Wallpapers consist of either Gallery images (user
taken), Live wallpapers (animated backgrounds), or
Wallpaper gallery (default phone wallpapers).
Note:
Selecting animated Live wallpapers will require
additional battery power.
To change the current wallpaper:
1. Press to go to the Home screen.
2. Touch and hold an empty area of the screen.
3. From the
Add to Home screen
window tap
Wallpapers
.
36
4. Select a Wallpaper:
•
Tap
Gallery
to select from a user image stored in the
camera image gallery, crop the image, and tap
Save
.
•
Tap
Live wallpapers
to select from a list of animated
backgrounds, once done tap
Set wallpaper
.
•
Tap
Wallpaper gallery,
scroll through the images, tap
a wallpaper image, then tap
Set wallpaper
.
Memory Card 37
Section 3: Memory Card
Your device lets you use a microSD™ (SD) or
microSDHC™ card (also referred to as a memory
card) to expand available memory space. This secure
digital card enables you to exchange images, music,
and data between SD-compatible devices. This
section addresses the features and options of your
device’s SD functionality. The device has a USB SD
card mode.
•
microSD card storage: up to 2GB in size
•
SDHC card storage: up to 32GB in size
Using the SD Card
There are several methods for using the SD card:
1. Connecting to your PC to store files (such as
music, videos, or other types of files and
media).
2. To activate the camera, video, music player,
and other dependant media or applications.
Important!:
The Camera, Audio Postcard, Music Player, and
Video functionality is all dependant on a mounted
SD card. Your device can support SDHC cards up to
32GB capacity.
SD card Overview
After mounting an SD card in the device you can use
your computer to access and manage the SD card.
Important!:
If access to the external SD card is not available,
download and install the USB drivers.
microSD Icon Indicators
The following icons show your microSD card
connection status at a glance:
Important!: DO NOT
remove a microSD card while the device is
accessing or transferring files. Doing so will result
in loss or damage of data. Make sure your battery
is fully charged before using the microSD card.
Your data may become damaged or lost if the
battery runs out while you are using the microSD
card.
• the card has been unmounted
(released from use) from the device.
• the card is being prepared for use
and for mounting.
• the card has been improperly
removed.
38
Mounting the SD Card
To store photos, music, videos, and other
applications. You must mount (install) the SD card
prior to use. Mounting the SD card establishes a USB
connection with your computer.
Important!:
You must enable USB storage to mount the SD card.
1. Press ➔ and then tap
(
Settings
) ➔ SD card and phone storage.
2. Tap
Mount
SD card
.
Connecting to the SD card
1. Insert the SD card into the external, SD card
slot (For more information, refer to “Installing
the microSD Memory Card” on page 7.)
2. Connect the USB cable to the phone and
connect the cable to the computer. The “
USB
Mass Storage
” screen is displayed.
3. Tap
Turn on USB storage
➔ OK. Both the phone
and computer display icons to show that the
device is mounted. As soon as the connection
is established a drive letter is assigned to the
phone’s storage device.
4. Tap
Turn Off USB storage
to close the USB
connection between the phone and your
computer.
Unmounting the SD card
Unmounting the SD card prevents corruption and
damage to the SD card while removing it from the
slot.
1. Press ➔ and then tap
(
Settings
) ➔ SD card and phone storage.
2. Tap
Unmount
SD card
➔ OK.
3. When the “
SD card will be unmounted
”
message displays and the
Mount SD card
now
appears in the menu list, you can remove the
SD card. For more information, refer to
“Installing the microSD Memory Card” on
page 7.
SD card Memory Status
To view the memory allocation for your external SD
card:
䊳
Press ➔ and then tap
(
Settings
) ➔ SD card and phone storage. The
available memory displays under the Total
space and Available space headings.
Erasing Files from the SD card
You can erase files from the SD card using the phone.
1. Ensure the SD card is mounted.
2. Press ➔ and then tap
(
Settings
) ➔ SD card and phone storage ➔
Unmount SD card
➔
OK
.
Memory Card 39
3. Tap
Format SD card
➔
Format SD card
➔
Erase
everything
to format the SD card. The SD card
formats and erases all the data stored on it.
Factory Data Reset
From this menu you can reset your phone and sound
settings to the factory default settings.
1. Press ➔ and then tap
(
Settings
) ➔
Privacy
.
2. Tap
Factory data reset
. This action erases all
data from your phone except current system
software and bundled applications, or SD card
files such as music or photos.
3. Tap
Reset phone
➔
Erase everything
.
40
Section 4: Call Functions and Contacts List
This section describes features and functionality
associated with making or answering calls, and the
Contacts list, which is used to store contact
information.
Displaying Your Phone Number
䊳
Press ➔ and then tap
(
Settings
) ➔
About phone
➔
Status
. Your phone
number displays in the
My phone number
field.
Note:
The phone’s
Settings
menu can also be activated by
pressing and then tapping ➔ (
Settings
).
Making a Call
You can store phone numbers that are regularly used
to the SIM card or to the phone’s memory. These
entries are referred to as the Contacts list.
1. Press and then tap .
2. Enter the phone number to dial then press
.
䊳
If you make a mistake while dialing, touch
to clear the last digit. Touch and hold
to clear the entire sequence.
Note:
When you activate the Auto redial option in the Call
settings menu, the phone automatically redials up to 10
times when the person does not answer the call or is
already on the phone, provided your call is not sent to
voice mail.
Ending a Call
䊳
Briefly tap key to end the call.
Note:
To redial a recent number, tap , tap a number from
the Call log list, and tap
Call
.
If you exit the current call screen and return to the
Home screen, You are visually notified that you are
still on an active call by the active call icon ( )
located in the Status bar.
Resuming a Live Call
1. Tap the Status bar to reveal the Notifications
tab, and then drag the tab to the bottom of the
screen to open the Notifications panel.
2. Tap any of the available phone functions to
regain access to the phone screen.
Call Functions and Contacts List 41
Answering a Call
When somebody calls you, the phone rings and
displays the incoming call image.
The caller's phone number, picture, or name if stored
in Contacts List, displays.
䊳
At the incoming call screen:
•
Touch and slide
to the right to answer
the call.
•
Touch and slide
to the left to reject the
call.
Pressing the Volume down button mutes the ringer.
If the incoming call is from a number stored in your
Contacts, the entry’s name is displayed. You may also
see the caller’s phone number, if available.
Dialing Options
When you enter
numbers on the
Keypad, you will
see three on-screen
options.
From the keypad
screen, use one of
the following
options:
•
Call
() to
call the entered
number.
•
Delete
( ) to delete digits from the current number.
•
Voicemail
( ) to access the phone’s voicemail
system.
To view additional dialing options, tap :
•
Add to Contacts
to add the current number to either a
new or existing Contacts entry.
•
Speed dial setting
to access the Speed Dialing menu
where you can assign a speed dial location to a current
Contacts entry.
•
Add 3 sec pause
to insert a three-second pause to enter
a 3-second delay within a number string (the phone
continues dialing after 4 seconds without any additional
keys being pressed).
•
Add wait
to insert a hard pause within the number string
(the phone waits for your input). A wait requires that any
consecutive numbers be manually sent by tapping
Send
.
Phone functions
42
International Calls
1. From the Home screen, tap , then touch
and hold . The + symbol displays.
2. Use the on-screen keypad to enter the country
code, area code, and phone number.
•
If you make a mistake, tap
once to delete a
single digit.
•
Touch and hold to delete all digits.
3. Tap .
Pause Dialing
You can dial or save phone numbers with pauses for
use with automated systems, such as voicemail or
financial phone numbers.
•
3 Second Pause
automatically sends the next set of
numbers after a three-second pause. This is indicated in
the number string as a colon (
;
).
•
Wait
sends the next set of numbers only after tapping
. This is indicated in the number string as a
semicolon (
;
).
1. From the Home screen, tap and use the
on-screen keypad to enter the phone number.
2. Press and then tap
Add 3 sec pause
. This
feature adds an automatic three-second pause.
3. Use the keypad to enter the additional numbers
that will be dialed automatically after the
second pause.
Tip:
You can create pauses longer than two seconds by entering
multiple 2-sec pauses.
4. Tap .
Wait Dialing
Inserting a Wait into your dialing sequence means that
the phone waits until it hears a dial tone before
proceeding with the next sequence of numbers.
1. From the Home screen, tap and use the
on-screen keypad to enter the phone number.
2. Press and then tap
Add wait
. This feature
causes the phone to require your acceptance
before sending the next set of entered digits.
3. Tap .
4. Once prompted, tap to dial the
remaining digits.
Redialing the Last Number
The phone stores the numbers of the calls you’ve
dialed, received, or missed if the caller is identified.
To recall any of these numbers:
1. From the Home screen, tap .
2. Tap the
Call log
tab to display the list of recent
calls.
3. Tap the name/number and tap from the
on-screen available options.
0
Send
Send
Call Functions and Contacts List 43
Speed Dialing
Once you have stored phone numbers from your
Contacts List, you can set up to 8 speed dial entries
and then dial them easily whenever you want, simply
by touching the associated numeric key.
Setting Up Speed Dial Entries
Important!:
Speed dial location #1 is reserved for Voicemail. No
other number can be assigned to this slot.
1. From the Home screen, tap .
2. Press
and then tap
Speed dial setting
. The
Speed dial
screen displays a virtual keypad
with the numbers 1 through 9.
3. Tap an unassigned number. The
Contacts
screen displays.
4. Tap a contact and select a number to assign to
the speed dial location. The selected contact
number/image is displayed in the speed dial
number box.
Changing a Speed Dial Entry
1. From the Home screen, tap .
2. Press
and then tap
Speed dial setting
.
Important!:
The number 1 is reserved for Voicemail and
another number cannot be assigned to this slot.
3. Press
and then tap
Change order
.
4. In a single motion, touch and drag an entry
over another location on the virtual keypad.
5. Tap
Save
to store the new assignment.
6. Press to return to the previous screen.
Removing a Speed Dial Entry
1. From the Home screen, tap .
2. Press
and then tap
Speed dial setting
.
3. Touch and hold an on-screen speed dial
location and select
Remove
from the context
menu.
– or –
Press
and then tap
Remove
. Tap an entry
and select
Remove
.
4. Press to return to the previous screen.
Call log options
44
Making a Call Using Speed Dial
You can assign a short cut number to a phone number
in the Contacts List for speed dialing.
1. From the Home screen, tap .
2. Touch and hold a speed dial location (numbers
2-9, or 1 if you are dialing voice mail) until the
number begins to dial.
3. If you are not certain of the speed dial location,
tap ➔
➔
Speed dial setting
and
touch a speed dial number to view the assigned
phone number.
Wi-Fi Calling
Wi-Fi Calling is a free feature for T-Mobile customers
with a Wi-Fi capable phone. Wi-Fi Calling is an
excellent solution for coverage issues in and around
the home or wherever cellular coverage is limited.
Minutes used while connected to the Wi-Fi network
count against available rate plan minutes.
The benefits of Wi-Fi Calling include the following:
•
Wi-Fi Calling provides a coverage option to improve upon
your current in-home coverage experience
•
Wi-Fi Calling works anywhere there is an open Wi-Fi
signal available
Important!:
Wi-Fi must first be active and communicating prior
to launching Wi-Fi Calling.
Note:
Wi-Fi call quality will depend on the condition of the user’s
current Wi-Fi network. A Wi-Fi call may be dropped if the
user travels outside of their Wi-Fi coverage area.
Activating Wi-Fi:
1. Press ➔ and then tap ➔
Wireless and networks
➔
Wi-Fi settings.
2. Tap
Wi-Fi
to turn it on. A checkmark displays to
indicate activation.
3. Tap an available WAP (Wireless Access Point)
from within the
Wi-Fi networks
area of the
page. Follow the on-screen instructions to
complete connection.
Note:
To avoid international data roaming fees when using Wi-Fi
calling when outside the United States, the Data Roaming
feature on your device must be turned off. For more
information, refer to “Data Roaming” on page 135.
Note:
With certain rate plans, minutes used while connected to
the Wi-Fi network count against available rate plan
minutes.
Call Functions and Contacts List 45
Launching Wi-Fi Calling
Note:
Verify you are currently connected to a Wireless Access
Point.
1. Ensure that the
Wi-Fi connected
icon displays
on the status bar. The network names and
security settings (Open network or Secured
with WEP) of detected Wi-Fi networks display
in the Wi-Fi networks section.
Note:
When you select an open network you are automatically
connected.
Important!:
W-Fi calling using plan minutes.
2. From the Home screen, tap ➔
(
Wi-Fi Calling
).
3. If prompted, tap
Register
to communicate with
the network and register your phone for this
service.
4. If not already activated, tap the slider to
activate Wi-Fi Calling. The slider shows
On
.
Your device connects to the T-Mobile Network.
Wi-Fi Connected
Displays when Wi-Fi is connected, active,
and communicating with a Wireless
Access Point (WAP).
Wi-Fi Communication Issue
Displays when Wi-Fi is active and there
are open networks available.
When
Action
Then
Displays on the
screen status
bar.
You are connected to the
T-Mobile network and can
make Wi-Fi calls.
Does not display
on the screen
status bar.
You are charged normal
calling rate minutes. For
more information, refer to
“Activating Wi-Fi” on
page 167.
Wi-Fi Calling
activation
slider
46
5. If prompted, tap
Confirm
to register the service
on the network (for first time users).
6. Use the phone Dialer, call log, or contacts list to
make a call. For more information, refer to
“Making a Call” on page 40.
7. Confirm you established a Wi-Fi calling
connection to the T-Mobile network by making
sure appears at the top of the screen.
8. Go to the dialer and make a call.
In Call Options
Your phone provides a number of features that are
available for use during a call.
Adjusting the Call Volume
During a call, use the Volume keys on the left side of
the phone, to adjust the earpiece volume.
䊳
Press the
Up
volume key to increase the volume
level and the
Down
volume key to decrease the
level.
– or –
From the screen during a call, press the
Up
Volume key.
From the Home screen, you can also adjust the ring
volume using these keys.
Place a call
on hold
Adds a
new call
Activates
speakerphone
Ends the
call
Dials the
number
Mute or Unmutes
Activates
the
Bluetooth
the current call headset
Call Functions and Contacts List 47
Placing a Call on Hold
You can place the current call on hold whenever you
want. If your network supports this service, you can
also make another call while a call is in progress.
To place a call on hold:
1. Tap
Hold
to place the current call on hold.
2. Tap
Unhold
to activate the call that is on hold.
To make a new call while a call is in progress:
1. Enter the new phone number that you wish to
dial or look it up in Call history.
2. Tap
Add call
to dial the second call.
3. Dial the new phone number and tap .
To switch between the two calls:
䊳
Tap
Swap
. The In call number turns gray and
displays On hold. The active call displays a
green background behind the number.
Turning the Speakerphone on and off
While on a call, you can use your Speakerphone by
following these steps:
1. Tap (
Speaker off
) to turn the
speakerphone on.
2. Tap (
Speaker on
) to turn the
speakerphone off.
Tip:
When the speaker is turned
On
, the color of the speaker is
green. When the speaker is turned
Off
, the color of the
speaker is gray.
Muting a Call
1. Tap (
Mute off
) so the other caller
cannot hear you speaking.
2. Tap (
Mute on
) to turn mute off and
resume your conversation.
Switching to Bluetooth Headset
1. While on a call, switch to the Bluetooth
headset instead of speaker by tapping
Headset
.
2. At the prompt, tap
Yes
to enable Bluetooth if it
is not already activated.
More In-call Options
During a call you can save the current caller’s
information to the Contacts list, or create a Memo.
Viewing the Contacts List
During a call you can look up a number in the
Contacts list.
1. Press and then tap (
Contacts
).
2. Browse the Contacts list for the information
you need.
3. Press and tap to return to the
active call.
Speaker
Speaker
Mute
Mute
48
Creating a Memo During a Call
During a call it may be necessary to record
information (a Note).
1. Press and then tap (
Applications
)
➔
(
Memo
).
2. Tap
Create memo
.
3. Use the keyboard to enter the note then tap
Save
.
4. Press and tap to return to the
active call.
Automatic screen lock
If you configured your phone with the Automatic
screen lock option, during a call your screen locks to
prevent accidental screen presses. To temporarily
unlock the screen press the lock key (on the right side
of the phone).
Multi-Party calls
Making a Multi-Party Call
A multi-party call is a network service that allows up
to six people to participate in a multi-party or
conference call.
For further details about subscribing to this service,
contact T-Mobile customer service.
Setting up a Multi-Party Call
1. From the Home screen, tap .
2. Dial the number for the first participant and tap
.
3. Tap
Add call
, enter the second phone number
and tap . The first caller is placed on
hold.
4. Wait for the second caller to answer the
incoming call and tap
Merge calls
. The two calls
are now joined into a multi-party call and
display in the order in which they were called.
Important!:
A maximum of two callers can be joined to a single
multi-party line at a time. Additional callers will
participate in a new Multiparty session and held in
conjunction with the previous multiparty call. You
can swap or place each multi-party call on hold.
Call Functions and Contacts List 49
Having a Private Conversation With One Participant
When you have two
participants in a
multi-party session,
it might be
necessary to place
one of those
participants on hold
so that a private
conversation can be
held with a single
caller. While you are
in a multi-party call:
1. Tap
Manage
(located on
the center of the screen).
2. Tap (
Split
) adjacent to the participants
you would like to split from the current call.
The list displays the callers in the order they
were dialed.
3. Tap the number for the participant in which you
want to speak privately.
You can now talk privately to that person while
the other participants can continue to converse
with each other. If there is only one other
participant, that person is placed on hold.
4. To return to the multi-party call, tap Merge
calls. All of the multi-party call participants
can now hear each other.
Dropping One Participant
1. Tap
Manage
(located on the center of the
screen).
2. Tap to the right of the number to drop.
The participant is disconnected and you can
continue the call with the other participant.
3. Tap to end the current call.
Call Waiting
You can answer an incoming call while you have a
call in progress, if this service is supported by the
network and you have previously set the Call waiting
option to Activate.
You are notified of an incoming call by a call waiting
tone. For more information, refer to “Configuring
Additional Call Settings” on page 138.
Manage
End caller Split caller
50
To answer a new call while you have a call in progress:
1. In a single motion, touch and slide it to
the right to answer the new incoming call.
Note:
The new caller appears at the top of the list. The previous
caller is placed on hold and appears at the bottom of the
list.
2. Select
Hold XXX
if you wish to place the
previous caller on Hold. You can also choose to
end your previous call and start a new one
(
End XXX
).
3. Tap Swap to switch between the two calls. This
places the new caller on hold and activates the
previous call. The active call displays with a
green background.
4. Tap
Swap
again to switch back.
Call Log Tab
The Call log tab is a list of the phone numbers (or
Contacts entries) for calls you placed, accepted, or
missed. The Call log tab makes redialing a number
fast and easy. It is continually updated as your device
automatically adds new numbers to the beginning of
the list and removes the oldest entries from the
bottom of the list.
The Notification area of the Home screen (upper-left)
displays phone notifications, status, or alerts such as:
Accessing the Call Log Tab
1. From the Home screen, tap
➔
Call log
tab.
2. Tap an entry to view available options.
Note:
The Call log tab only records calls that occur while the
phone is turned on. If a call is received while it is turned
off, it will not be included in your calling history.
Each entry contains the phone number (if it is
available) and Contacts entry name (if the number is
in your Contacts).
Displays when a call is in progress.
Displays when a call was missed.
Indicates all outgoing calls made from
your device.
Indicates any received calls that were
answered.
Indicates a missed call.
Call Functions and Contacts List 51
Accessing the Call Log from The Notifications
Area
1. Locate from the Notifications area of the
Status bar.
2. Tap the Status bar to reveal the Notifications
tab, and then drag the tab to the bottom of the
screen to open the Notifications panel (1).
3. Tap the Missed call entry to open the Call log
screen (2).
Tip:
Press and tap
Notifications
to open the panel.
This list provides easy access to redial an entry, or
you can also choose to access two types of history
entry lists depending on how they are touched.
Call Log - Caller Overview
•
Tap a contact entry name or number to reveal the
call
options
screen:
•Call
allows you to redial the entry by name or
number.
• Send message
allows you to create a new text
message to the selected entry.
• Send email
allows you to create a new email that is
then addressed to the entry’s available email
address.
Call Log screen
Call options (tap)
Entry-specific
context menu
(touch and hold)
52
•Time
provides the time and date of the call and its
duration.
• Add to Contacts
to save the number if it is not already
in your Contacts.
•
Touch and hold an entry to display the entry-specific
context menu:
• Call [Number]
to redial the current phone number.
• Send message
allows you to create a new text
message to the selected entry.
• Edit number before call
to make alterations to the
current phone number prior to redial.
• Add to Contacts
to save the number if it is not already
in your Contacts.
•View contact
to view the information for the currently
stored Contacts entry.
• Send contact information
to send the Log entry
information via text message.
• Delete
to delete the entry from the Log list.
Altering Numbers from the Call Log
If you need to make a call from the Call log screen
and you need to alter the number prior to dialing, you
can add the appropriate prefix by prepending the
number.
1. Tap
➔
Call log
tab.
2. Touch and hold an entry to access the entry-
specific context menu.
3. Tap
Edit number before call
.
4. Edit the number using the on-screen dialpad or
delete digits by pressing to erase the
numbers.
5. Tap once the number has been
changed.
Erasing the Call Log
You can delete either an individual call log entry or all
current entries from the Call log list.
To clear a single entry from the list:
1. Tap
➔
Call log
tab.
2. Touch and hold an entry and select
Delete
.
To clear all entries from the list:
1. Tap
➔
Call log
tab.
2. Press
➔
Delete.
3. Tap
Select all
➔
Delete
➔
OK
.
Viewing Missed Calls from Lock Screen
When you are unable to answer a call for any reason
and your screen is locked, the number of missed calls
are displayed on the Lock screen immediately after a
call is missed.
To view a missed call immediately:
1. Press to reactive the screen.
2. Touch and drag to the right.
3. Tap the Status bar to reveal the Notifications
tab, and then drag the tab to the bottom of the
screen to open the Notifications panel where
you can view your missed calls.
The Call log tab is then displayed.
Entering Text 53
Section 5: Entering Text
This section describes how to select the desired text
input method
when entering characters into your phone. This
section also describes the predictive text entry
system that reduces the amount of key strokes
associated with entering text.
Your phone comes equipped with an orientation
detector that can tell if the phone is being held in an
upright (Portrait) or sideways (Landscape)
orientation. This is useful when entering text.
Your phone also provides several on-screen keypad
text entry options to make the task of text entry that
much easier.
Text Input Methods
There are two text input methods available:
•
Samsung keypad
: an on-screen QWERTY keypad
that can be used in both portrait and landscape
orientation.
•
Swype
(default): a new way to enter text on touch
screens. Instead of tapping each key, use your
finger to trace over each letter of a word.
The on-screen QWERTY keypad works the same in
both portrait and landscape mode.
Selecting the Text Input Method
The Text Input Method can be assigned from within
one of two locations:
Settings Menu:
䊳
Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
➔
Select input method
.
Text Input field:
1. From a screen where you can enter text, touch
and hold the text input field to open the
context-menu.
2. Select the desired input method (
Swype
or
Samsung keypad
).
Default Text
Input Method
54
Using the Swype Keyboard
Swype™ is the default text input method that allows
you to enter a word by sliding your finger or stylus
from letter to letter, lifting your finger between words.
SWYPE uses error correcting algorithms and a
language model to predict the next word. SWYPE also
includes a touch predictive text system.
The onscreen keyboard options are different between
the Samsung keypad and Swype onscreen input
methods.
Enabling and Configuring SWYPE
If you configure another text input method (Samsung
keypad) you must re-enable SWYPE before using the
SWYPE keyboard.
Even when SWYPE is enabled you can use the on-
screen keys by either tapping (main characters) or
touching and holding (alternate characters).
1. Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
.
2. Tap
Select input method
➔
Swype
.
SWYPE Settings
To configure Swype settings:
1. Press ➔ and then tap ➔
Language and keyboard
➔
Swype
.
2. Locate the
Preferences
section to alter these
settings:
• Language
: allows you to select the current text input
language. Default language is US English.
• Word prediction
: predicts words as you are typing.
• Audio feedback
: turns on sounds generated by the
Swype application.
• Enable tip indicator
: turns on a flashing indicator for
quick help.
3. Locate the
Swype Advanced Settings
section to
alter these settings:
•Auto-spacing
: automatically inserts a space between
words. When you finish a word, just lift your finger or
stylus and start the next word.
• Auto-capitalization
: automatically capitalizes the first
letter of a sentence.
• Show complete trace
: sets the length of time the
word trace line remains on-screen as you swipe
across the screen. Move the slider between Shorter or
Longer and tap
OK
.
• Word choice window
: sets the amount of times the
word choice selection window displays on screen.
Move the slider between Never or Always and tap
OK
.
• Speed vs. accuracy
: sets how quickly Swype
responds to
on-screen input. Move the slider between Fast
Response (speed) or Error Tolerant (accuracy) and tap
OK
.
4. Locate the
Help
section to alter these settings:
• Swype help
: allows you to view the on-line user
manual for Swype.
•Tutorial
: a short tutorial that helps you to get started
using Swype.
5. Locate the
About
section to review the Swype
application information:
•Version
: lists the Swype version number.
Entering Text 55
Swype Text Entry Tips
You can access the SwypeTips application and watch
a video or tutorial on using Swype. You can also use
the following Swype text entry tips.
•
Create a squiggle (like an S shape) to create a double
letter (such as
pp
in apple).
•
Touch and hold a key to view the punctuation menu then
make a selection.
•
Move your finger or stylus over the apostrophe to enter
contractions.
•
Double-touch on the word you want to change to correct
a misspelled word, then touch the delete key to erase one
character. Touch and hold the delete key to erase an
entire word.
Selecting a Text Input Mode in Swype
1. From a screen where you can enter text, tap
the text input field to reveal the on-screen
keyboard.
2. With Swype as your text entry method, select
one of the following text mode options:
• 123 ABC
to use Swype with alphanumeric
characters from the onscreen keyboard.
•SYM
(Symbol)
to enter symbols from the
onscreen keyboard.
Note:
After typing an initial uppercase character, the key
changes to and all letters that follow are in lower
case.
Swype Keyboard Overview
• Text Input field
: a field where text, number, or other
characters can be entered.
• Additional Functions
: provides additional message
options.
• CAPS/ALT key
: When in 123ABC mode, this key
changes the capitalization of the subsequent entered
characters. When in SYM mode, this key can show
additional symbol characters.
•SWYPE tips
: Tapping this button displays the Swype
tips and tutorial screen.
• Text Input mode
: There are two available modes:
123ABC
and
SYM.
ABC
123
SYM
Text input field
CAPS/ALT
Text Input Voice actions
Delete
Current Mode
mode
SWYPE Tips
Additional
Functions
key
56
–
123ABC mode contains alphanumeric characters and a
few common punctuation marks. Text mode button
indicates
SYM
.
–
SYM mode contains only symbols and numbers. Text
mode button indicates
123ABC
.
Using 123ABC Mode in SWYPE
In
123ABC
mode, you can enter only letters and a few
common punctuation marks from the onscreen
keyboard. The text mode key shows .
1. From a screen where you can enter text, tap
the text input field to reveal the on-screen
keyboard.
Note:
An on-screen landscape keyboard is not available since in
this orientation you can use the QWERTY keyboard found
below the screen.
2. Tap to configure the keyboard for
123ABC mode (showing letters and numbers on
the onscreen keys). Once in this mode, the text
input type shows .
Note:
After typing an initial uppercase character, the key
changes to and all letters that follow are in lower
case.
3. Swipe your finger continuously over the letters
to form a word.
–
If you make a mistake, tap to erase a single
character. Touch and hold to erase an entire
word.
4. Tap to send the message.
By default, the first letter of an entry is capitalized and
the following letters are lower case. After a word is
entered and you lift your finger, the cursor
automatically adds a space after the word.
To enter text via Swype:
This example shows a user entering the word “there”.
Put your finger down on the “t”, and without lifting,
glide it to the “h”, and then to the “e”, and then over
to the “r”, and back to the “e”. When complete, lift
your finger off the screen to allow the device to
determine the closest word match.
Note:
If multiple word choices exist for your Swype entry, an on-
screen popup appears to provide additional word choices.
SYM
ABC
123
SYM
All lowercase
Displays when the next character is
entered in lowercase.
Initial Uppercase
Displays when the next character is
entered as uppercase but all subsequent
characters are lowercase.
All Uppercase
Displays when all characters will be
entered as uppercase characters.
Send
Entering Text 57
Entering Numbers and Symbols in SWYPE
By using the onscreen keyboard in portrait mode,
some symbols are not available (such as Emoticons
or Smileys). In SYM mode using Swype, you can only
enter symbols and numbers from the onscreen
keyboard. Once in SYM mode, the text mode key
shows .
1. From a screen where you can enter text, tap
the text input field to reveal the on-screen
keyboard.
2. Tap to configure the keyboard for SYM
mode. Once in this mode, the text input type
shows .
3. Tap the on-screen key for the number or
symbol you want to enter.
4. Touch and hold an on-screen key to enter the
secondary symbol (above the main one on the
same key).
5. Tap to choose from additional symbols.
For example:
•
To enter
&
: tap
123ABC
and swirl over the
a&
key.
•
To enter
@
: tap
123ABC
and swirl over the
w@
key.
Using the Samsung Keypad
This QWERTY keypad can be used to enter text in
either a Portrait or Landscape orientation. The only
difference between the two orientations are the sizes
of the keys.
From a screen where you enter text, rotate your
phone counterclockwise to a landscape orientation.
The on-screen QWERTY keypad displays.
Enabling the Samsung Keypad
This device has a built-in, QWERTY keypad (portrait
mode) or keyboard (landscape mode). Using the
QWERTY keypad/ keyboard, you can type letter,
numbers, punctuation, and other characters.
To use the Samsung keypad you must first configure
the settings to default to the Samsung keypad.
1. Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
➔
Select
input method
➔
Samsung keypad
.
– or –
From a screen where you can enter text, tap
and hold the text input field and tap
Input
method
➔
Samsung keypad
.
2. The virtual keyboard is then assigned to the
Samsung keypad configuration for all
subsequent text input.
ABC
123
SYM
ABC
123
58
Changing the Text Input Mode in Keypad
1. From a screen where you can enter text, tap
the text input field to reveal the on-screen
keyboard.
2. With Samsung keypad as your text entry
method, select one of the following text mode
options:
• ABC
to use alphabetic characters from the
on-screen keyboard. In this mode, the text mode
button displays .
•SYM
(Symbol)
to enter numbers by pressing
the numbers selecting them on the onscreen
keyboard. In this mode, the text mode button displays
.
Note:
After typing an initial uppercase character, tap to
toggle capitalization.
Using ABC Mode in Samsung Keypad
1. From a screen where you can enter text, tap
the text input field to reveal the on-screen
keyboard.
Note:
An on-screen landscape keyboard is not available since in
this orientation you can use the QWERTY keyboard found
below the screen.
2. Tap to configure the keyboard for ABC
mode. Once in this mode, the text input type
shows .
Note:
After typing an initial uppercase character, the key
changes to and all letters that follow are in lower
case.
3. Enter your text using the on-screen keyboard.
–
If you make a mistake, tap to erase a single
character. Touch and hold to erase an entire
word.
4. Tap to send the message.
By default, the first letter of a new entry is capitalized
and the following letters are lowercased. After a
character is entered, the cursor automatically
advances to the next space.
ABC
?123
?123
ABC
All lowercase
Displays when the next character is
entered in lowercase.
Initial Uppercase
Displays when the next character is
entered as uppercase but all subsequent
characters are lowercase.
ABC
?123
Send
Entering Text 59
Using Symbol Mode in Samsung Keypad
Use Symbol Mode to add numbers, symbols, or
emoticons. While in this mode, the text mode key
displays .
1. From a screen where you can enter text, tap
the text input field to reveal the on-screen
keyboard.
Important!:
To use the Samsung keypad, the phone must be
maintained in a portrait orientation. If you need to
change the orientation of the screen to Landscape,
we recommend using the QWERTY keyboard
beneath the screen.
2. Tap to configure the keyboard for
Symbol mode.Once in this mode, the text input
type shows . Tap a number, symbol, or
emoticon character.
3. Tap to return to ABC mode where the
key shows .
To enter symbols:
1. Tap to enter
?123
mode.
2. Tap the appropriate symbol key.
– or –
Tap to select from additional symbol
characters.
•
The first number on this key indicates which page (1,
2, or 3) of additional characters is active.
Configuring Samsung Keypad Settings
1. Press ➔ and then tap ➔
Language and keyboard
➔
Samsung keypad.
– or –
From within an active text entry screen, tap
from the bottom of the screen to reveal
the Samsung keypad settings screen.
2. Set any of the following options:
• Portrait keypad types
allows you to choose a
keypad configuration (Qwerty Keypad [default] or 3x4
Keypad).
• Input languages
sets the input language. Tap a
language from the available list. The keyboard is
updated to the selected language.
•XT9
enables predictive text entry mode. This must be
enabled to gain access to the advanced settings.
• XT9 advanced settings
configuration of more
advanced XT9 features. For more information, refer
to
“Using Predictive Text”
on page 60.
• Keypad sweeping
automatically moves the screen in
the direction your finger moves along the screen.
• Auto-capitalization
automatically capitalizes the first
letter of the first word in each sentence (standard
English style).
• Voice input
activates the Voice input feature. This is
an experimental feature that uses Google’s
networked speech recognition application.
• Auto full stop
automatically inserts a full stop by
tapping the space bar twice.
•Tutorial
launches a brief onscreen tutorial covering
the main concepts related to the Samsung keypad.
ABC
?123
ABC
ABC
?123
?123
1/3
60
Using Predictive Text
XT9 is a predictive text system that has next-letter
prediction and regional error correction, which
compensates for users pressing the wrong keys on
QWERTY keyboards.
Note:
XT9 is only available when ABC mode is selected. XT9
advanced settings are available only if the XT9 field has
been selected.
1. Press ➔ and then tap ➔
Language and keyboard
➔
Samsung keypad.
– or –
From within an active text entry screen, tap
at the bottom of the screen to access
the
Samsung keypad settings
screen.
2. Tap the
XT9
field. A checkmark indicates
activation.
3. Tap the
XT9
advanced settings
and configure
any of the following advanced options:
•Word completion
tells your device to attempt to
predict how to complete the word you have started. (A
green check mark indicates the feature is enabled.)
• Word completion point
sets how many letters should
be entered before a word prediction is made. Choose
from 2 letters, 3 letters, 4 letters, or 5 letters.
• Spell correction
enables the automatic correction of
typographical errors by selecting from a list of possible
words that reflect both the characters of the keys you
touched, and those of nearby characters. (A green
check mark indicates the feature is enabled.)
• Next word prediction
predicts the next word you are
like to enter. (A green check mark indicates the
feature is enabled.)
• Auto-append
automatically adds predictions to the
word you are typing. (A green check mark indicates
the feature is enabled.)
• Auto-substitution
allows the device to automatically
replace misspelled or miskeyed words. This option
reduce “typos.” (A green check mark indicates the
feature is enabled.)
• Regional correction
automatically tries to correct
errors caused when you tap keys adjacent to the
correct keys. (A green check mark indicates the
feature is enabled.
• Recapture
sets the device to redisplay the word
suggestion list after selecting the wrong word from the
list.
•XT9 my words
allows you to add new words to the
built-in XT9 dictionary.
–
Tap
Add word
.
–
Use the
Register to XT9 my words
field to enter the
new word.
–
Tap
Done
to store the new word.
Entering Text 61
• XT9 auto-substitution
allows you create a word rule
by adding words for automatic substitution during
text entry (for example youve becomes you’ve).
–
Tap the XT9 auto-substitution field. Flick up or down to
review the current list of word substitutions.
–
Press and then tap
Add
.
–
Enter the original word that will be replaced in the
Shortcut
field (for example, youve).
–
Enter the substitute word that will be used in the
Substitution
field (for example, you?fve).
–
Tap
Done
to save the substitution rule.
4. Press to return to the previous screen.
62
Section 6: Contacts
This section explains how to use and manage your
Contacts List. You can save phone numbers to your
phone’s memory.
Accounts
From the Accounts menu you decide if you want
applications to synchronize, send, and receive data at
any given time, or if you want the applications to
synchronize automatically. After determining how you
want the accounts to synchronize, indicate which
account to synchronize with your Contacts list.
1. Sign in to your Google account.
2. Press ➔ and then tap
(
Settings
) ➔
Accounts and sync
.
– or –
From the Home screen, press and then
tap
Settings
➔
Accounts and sync
.
3. From the General sync settings section, touch
one of the following options:
• Background data
: allows your phone to use data in
the background.
• Auto-sync
: automatically synchronizes your data with
the phone.
4. From the Manage accounts area, tap next
to the account you want to synchronize.
– or –
Tap
Add account
to create a new account.
5. Tap an account type to add.
6. Follow the on-screen instructions. The selected
account type synchronizes with your Contacts
list.
Contacts List
Creating a Contact
The default storage
location for saving
phone numbers to
your Contacts List is
your phone’s built-in
memory.
If existing Google
and Corporate email
accounts have been
synchronized to your
phone, these will be
made available to
your device during
the creation of new entries. These new Contacts
entries can be assigned or saved to synced accounts
such as Phone, SIM, Google, or Corporate.
Your phone automatically sorts the Contacts entries
alphabetically. You can create either a
Phone
,
SIM
,
Google
, or
Microsoft Exchange ActiveSync
contact.
Note:
Before you can save a contact to the Phone, Contact
settings must be set to
Save new contacts
to
Phone
.
Contacts 63
•
Phone
contacts are stored locally on the device.
Note:
If the phone is ever reset to its factory default
parameters, contacts stored on the phone can be lost.
•
SIM
contacts are stored within the SIM Card.
Note:
SIM contacts only store the Name and Phone number for
an entry.
•
Google
contacts are shared with your existing Google
account and can also be imported to your phone after you
have created a Google Mail account.
•
Microsoft Exchange
(also known as Work or Outlook)
contacts are those contacts that are intended to be
shared with either an Exchange Server or from within
Microsoft
®
Outlook
®
.
Note:
When storing an entry into your SIM card, note that only
the Name, and Number are saved. To save additional
information for a particular contact, such as notes, email,
dates, etc., it is important to save that Contact into your
phone’s onboard memory.
1. From the Home screen, tap (
Contacts
).
2. Tap
to create a contact.
Note:
You can also add a new contact by entering a number
from the keypad and pressing and then tap
Add to
Contacts
➔ (
Create contact
). Continue with step 3.
3. Tap a destination type (
Phone
,
SIM
,
Google
, or
Microsoft Exchange ActiveSync
) (depending on
where you want to save the new contact
information).
4. Tap the
First name
and
Last name
fields, and
enter a name for this contact using the
displayed keypad.
5. Tap the image icon and select a photo for this
contact. Selections are:
Album
, or
Take photo
.
6. Tap the label button (to the left of the
Phone
number
field) to select a category such as
Mobile
(default),
Home
,
Work
,
Work fax
,
Home
fax
,
Pager
,
Other
,
Custom
, or
Callback
.
Note:
Some destinations may provide different options or
arrangement.
7. Tap a phone number field and enter a phone
number.
•
Tap on the QWERTY keyboard to remove a
previously entered phone number.
•
Tap to enter an additional phone number
•
Tap to remove a previously entered phone
number.
64
8. Enter additional information such as:
Email
,
IM
,
Groups, Ringtone
,
Postal address
,
Organization
or
More
fields to input additional category
information.
•More
provides options such as: Notes, Nickname,
Website, Birthday or Anniversary.
•
Use your finger to slide the page up or down to see
additional fields and categories.
9. Tap
Save
to complete and store the new entry.
To save a Number from your Keypad:
1. From the Home screen, tap (
Phone
).
2. Enter a phone number using the on-screen
dialpad.
3. Tap
Add to Contacts
➔ (
Create contact
)
or select the Contact entry from the on-screen
list.
– or –
Press and then tap
Add to Contacts
➔
(
Create contact
) or select the Contact
entry from the on-screen list.
•
If you're updating an existing contact, tap the entry
from the list and proceed to step 5.
4. Tap a destination type (
Phone
,
SIM
,
Google
, or
Microsoft Exchange ActiveSync
).
5. Tap the
First name
and
Last name
fields, and
enter a name for this contact.
6. Tap the label button (to the left of the
Phone
number
field) to select a category such as
Mobile
(default),
Home
,
Work
,
Work fax
,
Home
fax
,
Pager
,
Other
,
Custom
, or
Callback
.
7. Tap
Save
to complete and store the new entry.
Note:
For further details about how to enter characters, see
“Text Input Methods” on page 53.
Finding a Contact
You can store phone numbers and their corresponding
names onto either your SIM card, your phone’s built-
in memory, or an external location (such as Google,
Exchange, or T-Mobile Backup). They are all
physically separate but are used as a single entity,
called Contacts.
Depending on the storage size of the particular SIM
card, the maximum number of phone numbers the
card can store may differ.
1. From the Home screen, tap (
Contacts
).
2. Swipe up or down until you see the contact
displayed.
– or –
Tap the
Search contacts
field and begin entering
the entry’s name. Matching entries are then
displayed. This process filters through all of
your current account Contact entries to only
show you the matching entries.
Contacts 65
– or –
In a single motion, touch and hold the letter tab
area (on the right) until on-screen letters
appear, then scroll through the list. You are
then taken to that section of the Contacts list.
Tap the contact entry.
Editing Contact Information
1. From the Home screen, tap .
2. Tap a contact name from the list.
3. Press and select
Edit
.
Note:
You can also access an entry’s context menu by touching
and holding an entry then tapping
Edit
.
4. Edit the contact information then tap
Save
.
Adding a Number to an Existing Contact
1. From the Home screen, tap .
2. Touch and
hold an
entry and
select
Edit
to reveal
the
Contact
entry’s
details
screen
(page 67).
Search
Contacts
Tabs
Tabbed
Navigation
Create
Contact Contacts
field
Context
Menu
Contact Details Screen
66
3. Touch a phone number field and enter a phone
number.
•
Tap on the QWERTY keyboard to remove a
previously entered phone number.
•
Tap to enter an additional phone number
•
Tap to remove a previously entered phone
number.
4. Enter additional information such as:
Email
,
IM
,
Ringtone
,
Postal address
,
Organization
or
More
fields to input additional category information.
•More
provides options such as: Notes, Nickname,
Website, Birthday or Anniversary.
•
Use your finger to slide the page up or down to see
additional fields and categories.
5. Tap
Save
to complete and store the new entry.
Deleting Contacts
This option allows you to delete your contacts. You
can delete all your entries from your phone’s memory,
your SIM card, FDN, or All.
Important!:
Once Contacts List entries are deleted, they cannot
be recovered.
1. From the Home screen, tap .
2. Touch and hold a contact name from the list
and select Delete ➔
OK
.
Contact List Options
1. From the Home screen, tap .
2. Press . The following options display:
• New contact
: allows you to add a new contact entry.
•Delete
: allows you to delete 1 or more of your
contacts.
• My profile
: allows you to set up a profile for yourself.
The information will be the same that you can add for
a new contact.
•Import/Export
: imports or exports contacts to or from
the SIM card or microSD card.
• Get friends
: allows you to get contacts from your
friends on Facebook, Twitter, or MySpace. You can
also get contacts from Microsoft Exchange ActiveSync
or Google accounts.
•More
:
–
Accounts
: allows you to add and manage mobile
accounts on Facebook, Twitter, or MySpace. You can also
add Corporate or Google accounts.
–
Speed dial
: allows you to set up speed-dialing.
–
Send email
: allows you to send an email using your
Google account.
–
Send message
: allows you to send a text or picture
message.
–
Display options
: where you can choose to only display
contacts that have phone numbers, sort by first or last
name, display contacts first name first or last name first,
display contacts stored to your SIM card, display contacts
stored on your phone, and/or display contacts stored to
other accounts.
–
Settings
: allows you to configure where you save new
contacts, or view your Own numbers, or Service
numbers.
Contacts 67
Contact Menu Options
1. From the
Home screen,
tap .
2. Touch and
hold an entry
to reveal the
context menu.
The following
options
display:
•Edit
: allows you to edit the currently selected
Contacts entry.
•Delete
: allows you to delete the currently selected
Contacts entry.
• Join contact
: allows you to link the current contact to
another current contact. Similar to a “see also”
feature. If you can’t remember a contact’s
information, linking entries can help you find the
person you are looking for.
• Send contact information
: allows you to send the
current entry info via text message.
• Add to favorites
: allows you to copy the current
Contacts entry to the list within the Favorites tab.
• Remove from favorites
: allows you to remove the
current Contacts entry from the Favorites tab.
• Add to group
: allows you to add the current Contacts
entry to an existing group.
• Mark as default
: allows you to assign default
numbers, email, etc.. for a selected Contact. For
more information, refer to
“Marking a Contact as
Default”
on page 69.
• Send namecard via
: allows you to send the current
Contact entry’s information to an external recipient via
either
Bluetooth
,
Email
(Exchange or Internet),
Gmail
, or
Messaging
.
Contact Entry Options
1. From the
Home screen,
tap .
2. Touch an entry
to reveal the
Contact entry’s
Overview
Screen
. This
screen
contains
Name, contact
numbers, email, and linked contact
information.
3. Press to reveal the context menu specific
to this entry.
4. Tap an available option.
Contact Overview Screen
68
Joining Contact Information
Most people now maintain multiple email accounts,
social networking logins, and other similar account
information. For example, a Facebook account login
name might differ from a corporate email account
login because they are maintained separately and for
different groups of people.
This device can synchronize with multiple accounts
(such as Facebook, Twitter, MySpace, Microsoft
Exchange ActiveSync or Google). When you
synchronize your phone with those accounts, each
account creates a separate contact entry in the
Contacts list.
If one of your contacts (Amy Smith) has a regular
email account that you maintain in Gmail, but also has
a Facebook account under her maiden and married
name, as well as a Video! chat account, when you
merge those accounts into your Contacts list you can
join all of her entries and view the information in one
record.
Joining contact information makes sending messages
easy. You can select any account email address or
information all from one screen, versus searching
multiple, individual screens to locate the desired
account information.
Next time you synchronize your phone with your
accounts, any updates contacts make to email
account names, email addresses, etc. automatically
update in your contacts list.
For more information about synchronizing accounts,
see “Get Friends” on page 72.
1. From the Home screen, tap .
2. Tap a contact name (the name you want to link
to another entry).
Note:
Typically this is the same contact with a different name or
account information.
3. Press and then tap
Join contact
.
4. Tap the second contact entry (the entry in
which to link). The second contact is now
linked with the first and the account
information is merged into one screen.
Note:
The information is still maintained in both entries, but
displays in one record for easier viewing when you link
the contacts.
Important!:
It is the second contact image that is displayed for
both by the first contact’s name that is used.
For example: If Amy (original entry) is joined with
Julie (second entry). Julie appears to disappear and
only Amy remains. Tap the Amy entry (showing the
Julie image) to view both.
5. Tap the main linked contact to view the contact
information you linked. The contacts and
information displays with an icon next to the
contact name to indicate what type of account
information is contained in the entry.
Contacts 69
Unjoining a Contact
1. From the Home screen, tap .
2. Tap a contact name (the account name from
which you want to unjoin an entry). This
reveals the details for entry.
Note:
Typically this is the same contact with a different name
or account information.
3. Tap the
Joined contacts
area.
4. Tap next to the entry you want to unjoin.
The contacts are “unjoined” or separated and
no longer display in the merged record screen.
Both contacts now go back to being separately
displayed.
Marking a Contact as Default
When you use applications such as the Voice Dialer
or other messaging type applications, the application
needs to know which information is primary (default)
in a contact entry list. For example, when you say
“Call John Smith”, if you have three phone records
for John Smith, the Voice dialer is looking for the
“default” number or entry.
The
Mark as default
option marks one entry in a
contact record to use as the default. This comes in
handy when you have multiple entries for the same
person (see Linked contacts).
1. From the Home screen, tap .
2. Tap a Contact entry.
3. Press and then tap
Mark as default
. The
Mark as default screen displays radio buttons
next to the contact name, phone number, or
other contact information.
4. Tap the radio button next to the entry
information you want to be the primary
information (such as name, phone number, or
email) and select
Save
.
Sending a Namecard
A Namecard contains contact information, and can
be sent to recipients as a Virtual Business Card (V-
card) attachment using Bluetooth, Google Mail, or as
a message.
1. From the Home screen, tap .
2. Tap a Contact entry.
3. Press and then tap
Send via
and select a
delivery method:
Bluetooth
,
Email, Gmail,
or
Messaging
.
The Namecard attaches to the selected
message type and is delivered when you send
the message.
Sending All Current Namecards
Rather than selecting once Contact entry at a time,
you can send all of your current entries at once.
1. From the Home screen, tap .
70
2. Press and then tap
Import/Export
➔
Send
namecard via
.
3. Tap
Select all
to place a check mark alongside
all currently displayed Contact entries.
4. Tap
Send
and select a delivery method:
• Bluetooth
to transmit this contact to another
bluetooth-compatible device.
•Email
to attach the contact card to a new outgoing
email (Exchange or Internet).
•Gmail
to attach the contact card to a new outgoing
Internet-based email.
• Messaging
to attach the contact card to a new
outgoing text message.
Sending a namecard using Bluetooth
You must create a Contact prior to sending a
namecard to a recipient. For more information, refer
to “Creating a Contact” on page 62.
1. From the Home screen, tap .
2. Touch and hold the entry to reveal the on-
screen context menu.
3. Tap
Send namecard via
➔
Bluetooth
.
Important!:
You must activate Bluetooth to use this feature.
4. Tap the Bluetooth device in which to send this
name card. Bluetooth forwards the namecard
to the recipient.
Copying Contact Information
Copying Contact Information to the SIM Card
The default storage location for saving phone
numbers to your Contacts list is your phone’s built-in
memory. This procedure allows you to copy numbers
saved to the phone’s memory, onto the SIM card.
Note:
These must be contacts stored on the phone. External
entries (Google, Exchange, etc...) can not be transferred in
this manner.
1. From the Home screen, tap .
2. From the Contacts List, press and then
tap
Import/Export
➔
Export to SIM card
.
3. Tap
Select all
to choose all current phone
contact entries.
– or –
Select a specific entry by touching an entry. A
check mark indicates a selection.
4. Tap
Export
. The name and phone number for
the selected contact is then copied to the SIM.
Contacts 71
Copying Contact Information to the microSD
Card
This procedure allows you to copy entry information
saved on the phone’s memory, onto the SD card.
1. Verify you have a properly mounted SD located
within the microSD card slot.
Note:
If your SD card is not properly mounted, you will not
receive an option to export contacts to the SD card.
2. From the Home screen, tap .
3. From the Contacts List, press and then
tap
Import/Export
➔
Export to SD card
.
4. Tap
Yes
to choose all current phone contact
entries.
Synchronizing Contacts
Syncing data from your managed accounts allows
you to add and manage a new or existing contact
from your online or remote accounts to your phone.
Prior to syncing, you must first have an active Google
or Microsoft Exchange account with current Contact
entries, and be signed into your account via the
phone.
With syncing, any Contacts entries (with phone
numbers, email addresses, pictures, etc.) are
updated and synced with your phone. For more
information about syncing existing managed
accounts, see “Accounts and Synchronization” on
page 146.
1. Press ➔ and then tap ➔
Accounts and sync
.
2. Locate the email account containing the
contacts you wish to synchronize.
3. Tap within the adjacent account field to
reveal the account’s synchronization settings
screen.
4. To synchronize Contacts, tap
Sync Contacts
. A
green checkmark indicates the feature is
enabled.
Note:
The process of updating your Contacts tab can take
several minutes. If after 10-20 minutes, your list has not
been updated, repeat step 2-3.
5. Your
Contacts
tab then reflects any updated
Contact information.
Note:
Syncing of contacts requires you are logged into your
Gmail and Corporate accounts via the device.
Display Options
The Display options menu allows you to allows you to
choose whether to display contacts saved from the
Phone, SIM, T-Mobile Contacts Backup, external
source, or all. You can also choose to display only
contacts that have phone numbers.
1. From the Home screen, tap .
72
2. Press and then tap
More
➔
Display
options
. Configure any of the following options:
• Only contacts with phones
allows you to display only
those contacts containing phone numbers.
•Sort by
defines how the current list of Contacts are
sorted:
First name
or
Last name
.
• Display contacts by
defines how the current list of
Contacts are listed:
First name first
(ex: Steve Smith)
or
Last name first
(Smith, Steve).
• Select contacts to display
allows you to filter
Contacts based on category entries from within the
locations such as:
Phone
,
SIM
,
Google
, and
Microsoft Exchange
.
3. Tap
Done
.
Get Friends
When you synchronize applications such as
Facebook, Twitter, MySpace, a corporate email
account, or Google, using the Get Friends option
synchronizes the data from the selected account type
with your Contacts list.
1. From the Home screen, tap .
2. Press and then tap
Get friends
➔
Add
account
➔
Add account
.
3. Determine which type of account information
you want to synchronize with your Contact list.
Selections are:
Facebook, Twitter, MySpace,
Microsoft Exchange ActiveSync
, or
Google
.
4. Tap an account type to add.
5. Follow the prompts. The selected account type
synchronizes with your Contacts list.
6. After synchronizing accounts you may want to
link contact information. For more information,
refer to “Joining Contact Information” on
page 68.
To add Facebook content to your Contacts list:
You can now add your Facebook contact information,
such as pictures, email, and phone numbers directly
to your Contacts list. All of their current contact
information is then migrated over to your phone. If a
Contacts entry already exists with a slightly different
name, separate entries are created and can later be
linked (joined) together into a single entry.
You will need to have an existing Facebook account
before you can synchronize your contacts between
your phone and this account type.
Important!:
This process not only synchronizes your contact
information but also your status, events, and more.
1. Press ➔ and then tap
(
Settings
) ➔
Accounts and sync
➔
Add account
➔
Facebook.
•
This process adds your Facebook account to the list of
managed and synchronized accounts. In this case,
your Facebook contacts are synchronized with your
phone’s Contacts list.
2. Read the on-screen information and tap
Next
.
Contacts 73
3. Enter your account’s access
Email
and
Password
information and tap
Login
.
4. Select a sync interval (from
None
to
Once a day
)
and tap
Next
.
5. Tap those settings you wish to synchronize (all
are enabled by default). A green checkmark
indicates the feature is enabled.
•
Choose from:
Select Contacts to Sync
,
Sync all
contacts
, or
Sync Calendar
.
6. Tap
Done
to save these settings and return to
Accounts and sync screen.
7. Tap to confirm your Facebook contacts
are now synchronized and appear in your
Contacts list.
My Profile
You can send this Virtual Business Card (V-card) to
other contacts as an attachment. My Profile is the
first Contact listed in the Contacts list.
Note:
As with any profile, your profile can be associated with a
group.
To create My Profile:
1. From the Home screen, tap .
2. Press and then tap
My profile
.
3. Enter information into the various fields.
4. Tap
Save
to store the new entry.
To edit My Profile:
1. With My profile displayed, press and then
tap
Edit
.
2. Modify any of the information contained in My
Profile, then tap
Save
.
Additional Contact Options
Sending an Email to a Contact
Note:
Contacts must contain and email account and address
before you can use the Send email feature.
1. From the Home screen, tap .
2. Press and then tap
More
➔
Send email
.
Contacts that contain an email address display.
3. Tap the contact to which you want to send an
email. A check mark displays next to the
selection.
Note:
The select contact must have an email as part of their
details screen.
4. Tap
Add
.
5. Select an email account type.
6. Compose the email and tap
Send
.
Export/Import
For more information, refer to “Copying Contact
Information” on page 70.
74
Contact List Settings
From this menu you can determine the default
storage location for Contacts, display your phone’s
primary number, and view service numbers listed in
your Contact list.
1. From the Home screen, tap .
2. Press and then tap
More
➔
Settings
.
3. Select one of the following options:
• Save new contacts to
: defines the default storage
location of new Contacts. Choose from:
Always ask
,
Phone
,
SIM
,
Google
, or
Microsoft Exchange
ActiveSync
.
• Own numbers
: displays the number for this device.
• Service numbers
: displays the list of Service Dialing
Numbers (SDN) assigned by your service provider.
These numbers include emergency numbers,
customer service numbers and directory inquiries.
Groups
This feature allows you to add a new or existing
contact to a call group. This group can be one of the
already present groups (Family, Friends, or Work) or a
user-created group.
Creating a New Caller Group
1. From the Home screen, tap ➔
Groups
tab.
2. Press and then tap
Create
.
3. Tap the
Group name
field and use the on-screen
keypad to enter a new group name. For more
information, refer to “Text Input Methods” on
page 53.
4. Tap
Ringtone
and select a ringtone for the
group. Selections are:
Default ringtone
,
Sound
,
or
Phone ringtone
.
5. Tap
Save
to store the newly created group
Adding an Existing Entry to a Current Caller
Group
1. From the Home screen, tap ➔
Groups
tab.
2. Tap a group entryy, then tap (
Add group
member
).
Note:
Some group members require that you add new members
externally. Ex: Google
3. From the list of contacts, tap the contact(s) you
want to add. A checkmark displays next to
contact entry.
4. Tap
Add
. The selected contacts are added to
the group.
Contacts 75
Removing an Entry From a Caller Group
1. From the Home screen, tap ➔
Groups
tab.
2. Touch a group entry.
3. Press and then tap
Remove member
.
4. Tap all of the contacts you want to remove
from this group. A checkmark displays next to
contact entry.
5. Tap
Remove
.The contacts are removed from
the group.
Editing a Caller Group
To edit a Group entry, there must be at least one
member as part of the selected group.
1. From the Home screen, tap ➔
Groups
tab.
2. Touch a group entry.
3. Press and then tap
Edit group
.
4. Make modifications to the
Group name
or
Ringtone
fields. For more information, refer to
“Creating a New Caller Group” on page 74.
5. Tap
Save
.
Sending a Message to a Group
1. From the Home screen, tap ➔
Groups
tab.
2. Tap an existing group, and press and
then tap
Send message
.
3. Select the recipients of the new message
(indicated by a green checkmark). If an entry
contains multiple phone numbers, each must
be selected individually.
4. Tap
Add
.
5. Type your message, and tap
Send
.
The History Tab
The History tab is a list of the phone numbers that
have been received, missed, and returned. For more
information, refer to “Call Log Tab” on page 50.
1. From the Home screen, tap .
2. Tap the
History
tab.
3. Press . The following options are
available:
• Delete
: allows you to delete calls or messages from
History. Select a call or message and tap
Delete
.
•View by
: allows you to select the type of displayed
calls, messages, or emails. Selections are: Call,
Message, Email, Facebook, MySpace, Twitter, or
Select all. Tap the items you want to display then
tap
Done
.
76
The Updates Tab
From the Updates tab you can view updated contact
information that were synchronized with Facebook,
Myspace, or Twitter.
1. From the Home screen, tap .
Note:
You must log in to an SNS account (Facebook, Myspace or
Twitter) before you can view the Updates.
2. Tap the
Updates
tab. The updates display.
Messages 77
Section 7: Messages
This section describes how to send or receive
different types of messages. It also explains the
features and functionality associated with
messaging.
Types of Messages
Your phone provides the following message types:
•
Text Messages
•
Multimedia (Picture, Video, and Audio) Messages
•
Audio Postcards
•
IM Messages
•
Email and Gmail Messages
•
Google Talk
Message Icons on the Status Bar
Icons are displayed on the Status Bar at the top of the
display when new messages are received. For more
information, refer to “Status Bar” on page 17.
Creating and Sending Messages
The Short Message Service (SMS) lets you send and
receive text messages to and from other mobile
phones or email addresses. To use this feature, you
may need to subscribe to your service provider’s
message service.
The Multimedia Messaging Service (MMS) lets you
send and receive multimedia messages (such as
picture, video, and audio messages) to and from
other mobile phones or email addresses. To use this
feature, you may need to subscribe to your service
provider’s multimedia message service.
Important!:
When creating a message, adding an image, a
sound file, or a video clip to a text message
changes the message from a text message to a
multimedia message.
Messaging icons are displayed at the top of the
screen and indicate when messages are received
and their type. For more information, refer to
“Indicator Icons” on page 18.
1. From the Home screen, tap
(
Messaging
)
➔
New message
.
2. Tap on the
To
field to manually enter a recipient
or select one of the following:
• Recent
: to select a recipient from a list of recently
sent messages.
•Contacts
: to select a recipient from your Contacts list
(valid entries must have a wireless phone number or
email address).
•Group
: to select a recipient from the Group list.
3. If adding a recipient from either Recent,
Contacts, or Group, tap the contact to place a
checkmark then tap
Add
. The contact displays
in the recipient field.
Note:
For the Group option, if the number of recipients is less
than 10, all members in the group are added. Delete any
unnecessary members in the list by selecting the trash
can icon and deleting unwanted entries.
78
4. Tap the
Tap to compose
field and use the on-
screen keypad to enter a message. For more
information, refer to “Text Input Methods” on
page 53.
5. Add more recipients by touching the Recipient
field.
6. Review your message and tap
Send.
Note:
If you exit a message before you touch send the message
automatically saves as a draft.
Message Options
1. From the Home screen, tap
(
Messaging
).
2. From within an open message, press to
display additional messaging options:
•View contact
: reveals the current Contact’s overview
screen.
• Add/Remove subject
: inserts or deletes a Subject
field in your message.
• Attach
: allows you to attach the following:
–
Slideshow
: allows you to create up to a 10 page
slideshow to attach to the message.
–
Pictures
: allows you to tap an existing image from your
Pictures list to add it to your message.
–
Videos
: allows you to tap an existing video file you wish
to attach.
–
Audio
: allows you to choose an existing audio file
from the Audio list, then add it to your message by
tapping
OK
.
–
Capture picture
: allows you to temporarily exit the
message, take a photo with phone’s camera, then add it
to your message by tapping
Save
.
–
Capture video
: allows you to temporarily exit the
message, record a video clip using the phone’s video
camera, then add it to your message by touching
Save
.
–
Record audio
: allows you to temporarily exit the
message, record an audio clip using the phone’s
microphone, then add it to your message by pressing
then tapping
Add
.
–
Contacts
: allows you to tap on an existing Address
Book entry to add their contact info to your message.
–
Calendar
: allows you to tap on an existing Calendar
event
and add it to your message.
–
Memo
: allows you to tap on an existing Memo and add it
to your message.
• Add text
: allows you to add text items from
sources such as: Contacts, Calendar, Memo,
and Text templates.
• Insert smiley
: allows you to insert an emoticon
(smiley).
•More
: provides additional mesaging functions
such as: Delete messages, Discard, and Call.
Messages 79
Viewing Newly Received Messages
When you receive a message, your phone notifies
you by displaying within the Notification area
at the top left of your Home screen.
To read a message:
1. Open the Notification Bar and select the
message. For more information, refer to
“Notification Bar” on page 20.
– or –
From the Home screen, tap
then tap the
new message to view. The selected message
displays on the screen.
2. Tap to play a multimedia message.
3. In a single motion, touch and scroll up or down
the page to scroll through the message (if
additional pages were added).
Message Threads
Sent and received text and picture messages are
grouped into message threads. Threaded messages
allow you to see all the messages exchanged (similar
to a chat program) and displays a contact on the
screen.
Message threads are listed in the order in which they
were received, with the latest message displayed at
the top.
To reply to a text
message:
1. From the
Home
screen, tap
.
2. While the
message is
open, tap
the
Type to
compose
field and
then type
your reply
message.
3. Compose your reply.
Your texts are colored Blue and your caller’s
replies are Yellow.
4. Tap
Send
to review your reply.
– or –
Press and then tap one of these
messaging options:
View contact
,
Add subject
,
Attach
,
Add text
,
Insert smiley
, or
More
(Delete
messages, Discard, and Call).
Current Recipient My Text
Reply Bubble
Text Message Thread
80
To access additional Bubble options:
䊳
Touch and hold the message bubble to display
the following options:
• Delete message
: deletes the currently selected
message bubble from the thread.
• Add to Contacts
: adds the current caller to your
Contacts list.
•Copy message text
: copies the currently selected
message bubble from the thread.
•Lock/Unlock message
: locks or unlocks the currently
selected message bubble from being accidentally
deleted.
•Forward
: allows you to forward the currently selected
message bubble to an external recipient.
•Copy to SIM
: copies the currently selected message
bubble as a single text message within the SIM card.
• View message details
: displays details for the
currently selected message bubble.
Deleting Messages
Deleting a single message
1. From the Home screen, tap .
2. Touch and hold a message, then select
Delete
thread
.
3. At the prompt, tap
OK
to delete or
Cancel
to exit.
Deleting multiple messages
1. From the Home screen, tap .
2. Press and then tap
Delete threads
.
3. Tap each message thread you want to delete. A
checkmark displays beside each selected
message.
4. Tap
Delete
.
5. At the prompt, tap
OK
to delete or
Cancel
to end
the process.
Message Search
You can search through your messages by using the
Message Search feature.
1. From the Home screen, tap .
2. Press and then tap
Search
.
3. Use the on-screen keypad to enter a word or
phrase in which to search, then tap .
4. All messages that contain the entered search
string display.
Messaging Settings
To configure the settings for text messages,
multimedia messages, Voice mails, and Push
messages.
1. From the Home screen, tap .
2. Press and then tap
Settings
.
The following Messaging settings are available:
Message skin
• Message skin
: applies one of several interface skins
to the messaging appliation. Choose from: Default,
Edge,Gloss, and Sticky note.
Messages 81
Storage settings
• Delete old messages
: deletes old messages once
the message limit has been reached.
• Text message limit
: allows you to set a limit on how
many text messages are allowed in one conversation.
• Multimedia message limit
: allows you to set a limit
on how many multimedia messages are allowed in
one conversation.
Text message settings
• Delivery reports
: when this option is activated, the
network informs you whether or not your message
was delivered.
• Manage SIM card messages
: allows you to manage
the messages stored on the SIM card.
• Message center
: allows you to enter the number of
your message center where your messages reside
while the system is attempting to deliver them.
• Input mode
: allows you to set the input mode for
your text messages. Choose GSM Alphabet, Unicode,
or Automatic).
Multimedia message settings
• Delivery reports
: when this option is activated, the
network informs you whether or not your message
was delivered.
• Read reports
: when this option is activated, your
phone receives a request for a read reply along with
your message to the recipient.
•Auto-retrieve
: allows the message system to
automatically retrieve messages.
• Roaming auto-retrieve
: allows the message system
to automatically retrieve while roaming.
• Creation mode
: allows you to select the creation
mode: Free, Restricted, or Warning.
–
Restricted
: you can only create and submit messages
with content belonging to the Core MM Content Domain.
–
Warning
: the phone will warn you via pop up messages
that you are creating a multimedia message which does
not fit the Core MM Content Domain.
–
Free
: you may add any content to the message.
Notification settings
• Notifications
: allows you to see message
notifications on your status bar.
• Select ringtone
: allows you to set the ringtone for
your message notifications.
Text Templates
This screen displays your available text message
reply templates. This is a readily accessible list of
both default and user-defined text snippets that can
be used to quickly reply to incoming messages.
1. From the Home screen, tap .
2. From the Messaging list, press and then
tap
Text templates
.
3. Tap a message to immediately insert it into
your current message conversation.
To create your own text template:
1. From the Home screen, tap .
2. From the Messaging list, press and then
tap
Text templates
.
3. Tap (
Create template
).
4. Enter a new text string and tap
Save
.
82
Email
Email (or Internet Email) enables you to review and
create email using several email services. You can
also receive text message alerts when you receive an
important email. Your phone’s Email application lets
you access and manage multiple email accounts
simultaneously in one convenient location.
There are currently three main types of email
accounts on your phone: Gmail, Internet-based email
(Gmail, Yahoo, etc..), and Microsoft Exchange
(Corporate email or Outlook®).
To send and receive email messages through an ISP
(Internet Service Provider) account, or if you wish to
use your device to access your corporate email
through a VPN (Virtual Private Network), you will first
need to set up an IMAP or POP account.
•
IMAP
(Internet Message Access Protocol) - This protocol
is frequently used in large networks and commercial
settings. IMAP4 is the current standard.
•
POP3
(Post Office Protocol) - This protocol is supported by
most ISPs (Internet service providers) and common
among consumer applications. POP3 is the current
standard.
•
Microsoft Exhange ActiveSync
- This protocol is
frequently used with a large corporate email server
system and provides access to email, contact, and
calendar synchronization.
Creating an Internet Email Account
1. From the Home screen, tap (
Applications
)
➔ (
Email
). If you already have email
accounts, your accounts screen is displayed.
2. Enter your email address in the
Email
address
field. The phone will try to resolve the email
address.
3. Enter your password in the
Password
field and
tap
Next
.
•
Tap
Manual setup
to configure your connection
settings manually (POP3 or IMAP). Follow the on-
screen prompts and enter the information specific to
your email provider.
•
The unique account name is used to differentiate this
account from other email accounts accessed by your
device.
4. At the
Your accounts
screen, name the account
and enter a screen name to identify yourself on
this account. If you have already setup this
account, skip to step 6.
5. Messages for this account display on the Inbox
tab. You can also view Personal information for
this account, Receipts (if you setup the account
to return receipts), Travel information, and
more (if available).
6. Tap
Done
to store the new account.
Important!:
Only some “Plus” accounts include POP access
allowing this program to connect. If you are not able
to sign in with your correct email address and
password, you may not have a paid “Plus” account.
Launch the Web browser to access your account.
Messages 83
Opening an Internet Email
1. From the Home screen, tap ➔
(
Email
).
2. Press and then tap
Accounts
.
3. Select an email account and tap an email
message.
Refreshing Internet Email Messages
1. From the Home screen, tap ➔
(
Email
).
2. Select an email account.
3. Press and then tap
Refresh
.
Composing Internet Email
1. From the Home screen, tap ➔
(
Email
).
2. Press and then tap
Accounts
.
3. Select an email account.
4. Tap
Inbox
and press .
5. Tap
Compose
.
6. Enter the message recipient’s email address in
the
To
field.
•
If you are sending the email message to several
recipients, separate the email addresses with a
comma. You can add as many message recipients as
you want.
•
Use the
Cc
field to carbon copy additional recipients.
•
Use the
Bcc
field to blind copy additional recipients.
7. Tap the
Subject
field and enter the email
subject.
8. Tap the email text field and compose your
email message.
•
To add a picture attachment, tap
Attach
(from the
bottom of the screen) and make a selection.
9. Once complete, tap
Send
.
Configuring Internet Email Settings
1. From the Home screen, tap ➔
(
Email
).
2. Press and then tap
Accounts
.
3. Select an account.
4. From the email list screen, press and
then tap
More
➔
Account settings
.
5. Alter any of the following settings:
• Account name
: displays your uniquely created
account display name.
•Your name
: displays the name used in the From field
of your outgoing email messages.
• Email check frequency
: Tap to adjust the time
interval used by your device to check your email
account for new email messages.
• Default account
: Assign this account as the default
email account used for outgoing messages.
• Email notifications
: Activates the email notification
icon to appear within the Notifications area of the
status bar when a new Internet mail (Gmail, etc..) is
received.
84
• Select ringtone
: Plays a selected ringtone when a
new email message is received.
•Vibrate
: Activates a vibration when a new email
message is received.
• Incoming settings
: Lets you specify incoming email
settings, such as username, password, and IMAP
server.
• Outgoing settings
: Lets you specify outgoing
settings, such as username, password, and SMTP
server.
• Recent messages
: Lets you assign the number of
recent messages that are displayed on-screen.
Choose from: 25 - Total.
• Forward with files
: Lets you include attachments
when forwarding an email.
• Add signature
: Lets you attach a customized
signature to the bottom of all outgoing emails.
• Signature:
Lets you create an email signature for your
outgoing Gmail email messages.
Microsoft Exchange Email (Outlook)
Your phone also provides access to your company’s
Outlook Exchange server. If your company uses either
Microsoft Exchange Server 2003 or 2007, you can
use this email application to wirelessly synchronize
your email, Contacts, and Calendar information
directly with your company’s Exchange server.
Setting Up a Microsoft Exchange Email account
1. From the Home screen, tap ➔
(
Email
).
2. If you already have other email account setup:
•
Press and then tap
Accounts
.
•
Press and then tap
Add account
.
– or –
Enter your
Email address
and
Password
information, and then tap
Next
. Consult your
Network or IT Administrator for further details
and support.
• Email address
: your Outlook work email address.
•Password
: typically your network access password
(case-sensitive).
3. Tap
Microsoft Exchange ActiveSync
(from the
add new email account screen).
4. When prompted to provide additional detailed
information, scroll down the screen and tap
Next
.
5. Enter a
Domain
, confirm your
Username
and
Password
information and tap
Next
.
•
If your network requires SSL encryption, tap the
Accept all SSL certificates
field to place a check
mark in the box and activate this additional level.
Important!:
If your exchange server requires this feature,
leaving this field unchecked can prevent
connection.
6. If prompted with a connection error, manually
enter your
Exchange server
information within
the appropriate field.
Messages 85
• Exchange Server
: your exchange server remote
email address. Typically starts with
mail.XXX.com
.
Obtain this information from your company network
administrator. Do not accept the default entry as this
is a guess based on returned information.
7. With the new server information entered, tap
Next
.
8. Read the on-screen activation disclaimer and,
if prompted, tap
OK
.
9. Adjust the various on-screen configuration
fields and tap
Next
.
10. Identify your new account with a unique name
and provide the outgoing name text then tap
Done
.
Opening an Exchange Email
1. From the Home screen, tap ➔
(
Email
).
2. Press and then tap
Accounts
.
3. Select an exchange email account and tap an
email message.
Refreshing Exchange Email
1. From the Home screen, tap ➔
(
Email
).
2. Select an exchange email account.
3. Press and then tap
Refresh
.
Composing Exchange Email
1. From the Home screen, tap ➔
(
Email
).
2. Press and then tap
Accounts
.
3. Select an exchange email account.
4. Tap
Inbox
and press and then tap
Compose
.
5. Enter the message recipient’s email address in
the
To
field.
•
If you are sending the email message to several
recipients, separate the email addresses with a
comma. You can add as many message recipients as
you want.
•
Use the
Cc
field to carbon copy additional recipients.
•
Use the
Bcc
field to blind copy additional recipients.
6. Tap the
Subject
field and enter the email
subject.
7. Tap the email text field and compose your
email message.
•
To add a picture attachment, tap
Attach
(from the
bottom of the screen) and make a selection.
•
Tap the file you wish to attach.
8. Once complete, tap
Send
.
86
Deleting an Exchange Email Message
䊳
Touch and hold an email (from your inbox list)
and select
Delete
from the on-screen context
menu.
– or –
With the email message displayed, press
and then tap
Delete
.
Configuring Microsoft Exchange Email Settings
1. Press ➔ and then tap ➔
Accounts and sync.
2. Tap within the Microsoft Exchange
account field to reveal the account’s
synchronization settings screen.
3. Toggle either the
Sync Contacts
or
Sync
Calendar
fields to force the device to manually
resync either the exchange Contacts or
Calendar entries.
– or –
Tap
Account settings
and specify any other
email settings you wish to synchronize:
• Account name
displays the name used by the device
to track the account.
•Your name
displays the name used in the From field
within your outgoing email messages.
• Amount to synchronize
to assign the sync range for
your incoming and outgoing email messages between
your phone and your external exchange server. How
many days worth of email messages should the
phone and server synchronize. Choose from:
1 day
,
3 days
,
1 week
,
2 weeks
, or
1 month
.
• Default account
assigns this account as the default
used when sending out new email messages.
• Out of office settings
assigns this account’s out of
office settings.
• Empty server trash
: allows you to delete your email
account’s trash bin remotely.
• Sync schedule
allows you to configure your email
sync schedule.
• Email size
configures the incoming email size allowed
to pass through to your phone automatically without
user interaction. Larger emails will have to be
retrieved manually.
• Email notifications
enables the phone to display a
status bar icon when new email messages have been
received.
• Select ringtone
assigns an audible ringtone when a
new or upcoming event is pending.
•Vibrate
assigns a vibration when a new or upcoming
event is pending.
• Exchange server settings
provides access to the
Domain, password, and exchange server settings.
•Sync Contacts
synchronizes the contacts between
your phone and the remote exchange server.
• Sync Calendar
synchronizes your exchange calendar
entries between your phone and the remote exchange
server.
• Period to sync Calendar
assigns a period for your
phone to sync calendar events.
Messages 87
• Add signature
activates the email signature feature.
• Signature
allows you to create an outgoing email
signature attached to new email messages sent from
your phone.
4. Press to return to the previous page.
Using Google Mail
Google Mail (Gmail) is Google’s web-based email.
When you first setup the phone, Gmail is configured.
Depending on the synchronization settings, Gmail is
automatically synchronized with your Gmail account.
Signing into Google Mail
1. From the Home screen, tap ➔
(
Gmail
).
Note:
You must sign in to your Gmail account in order to access
features such as Google Mail and Android Market.
2. Tap
Next
to add a Google account.
3. Tap
Create
if you do not have a Google account.
– or –
Tap
Sign in
if you have a Google account.
The Inbox loads conversations and email.
Opening Gmail
1. From the Home screen, tap ➔
(
Gmail
).
2. Tap an existing email message.
Refreshing Google Mail
䊳
From within the Gmail message list, press
and then tap
Refresh
to send and receive
new emails and synchronize your email with
the Gmail account.
Composing a Gmail Message
1. From the Home screen, tap ➔
(
Gmail
).
2. From the Gmail Inbox, press and then tap
Compose
.
3. Enter the recipients Email address in the
To
field.
Tip:
Separate multiple recipient email addresses with a
comma.
4. Press and select
Add Cc/Bcc
to add a
carbon or blind copy.
5. Enter the subject of this message in the
Subject
field.
6. Tap the
Compose Mail
field and begin
composing your message.
7. Once complete tap (
Send
).
88
Viewing a Gmail Message
1. From the Gmail Inbox, touch a message to
view. The following options are available:
•Archive
: archives the selected Email.
• Delete
: deletes the Email.
•<:
displays older Emails.
•>:
displays newer Emails.
2. Press to select one of the following
additional options:
• Change labels
: changes the label on the email or
conversation.
• Mark unread
: unread messages or threads with
unread messages display in boldface text in the Inbox.
• Go to inbox
: displays the Google Mail Inbox.
•Mute
: mutes the conversation.
• Add/Remove star
: click a message's star to add or
remove the star (just like clicking flags in Outlook).
•More
:
–
Report spam
: reports the Email message as spam.
–
Select text
: allows you to select text to copy and paste.
–
Settings
: allows you to configure the General, or
Notification settings.
–
Help
: launches the browser and displays Google Mobile
Help information.
Google Talk
Google Talk™ is a free Windows and web-based
application for instant messaging offered by Google.
Conversation logs are automatically saved to a Chats
area in your Gmail account. This allows you to search
a chat log and store them in your Gmail accounts.
1. From the Home screen, tap ➔
(
Talk
).
2. Tap
Next
to add a Google account.
3. Tap
Create
if you do not have a Google account.
– or –
Tap
Sign in
if you have a Google account. The
Inbox loads conversations and email.
4. After entering your user name and password,
tap the
Down
Navigation key.
5. Tap
Sign in
.
6. Begin using Google Talk.
Note:
The Network confirms your login and processes. This
could take up to 5 minutes to complete.
Multimedia 89
Section 8: Multimedia
This section explains how to use the multimedia
features of your phone, including the Camera/
Camcorder, Music Player, and how to manage your
photos, images and sounds.
This section explains how to use the camera on your
phone. You can take photographs and shoot video by
using the built-in camera functionality. Your camera
produces photos in JPEG format.
Important!:
Do not take photos of people without their
permission.
Do not take photos in places where cameras are
not allowed.
Do not take photos in places where you may
interfere with another person’s privacy.
Using the Camera
Taking Photos
Taking pictures with your device’s built-in camera is
as simple as choosing a subject, pointing the camera,
then pressing the camera key.
Note:
When taking a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
1. From the Home screen, tap
(
Camera
).
2. Using the phone’s main display screen as a
viewfinder, adjust the image by aiming the
camera at the subject.
3. Before you take a picture, zoom in or out by
using either:
•
The
Up
and
Down
Volume keys.
You can magnify the picture up to x3 (300
percent).
4. If desired, before taking the photo, tap
(
Settings
) to access various camera options
and settings.
5. Press the on-screen Camera button until the
shutter sounds. For more information, refer to
“Camera and Camcorder Options” on
page 90.
Note:
An SD card must be present and mounted properly
before you can take any photos or shoot any videos.
90
Camera and Camcorder Options
You can change options using your keypad in capture
mode.
Camera Options
The following short cuts are available for the camera:
Note:
The options disappear after a few seconds. Touch the
screen to display the tab, then touch the tab to view these
options.
1.
Shooting mode
: allows you to set the following
options:
• Single shot
: takes a single photo and view it before
returning to the shooting mode.
• Smile shot
: the camera focuses on the face of your
subject. Once the camera detects the person’s smile,
it takes the picture.
• Continuous
: takes a succession of consecutive
photos by pressing and holding the Camera key.
• Panorama
: takes a landscape photo by taking an
initial photo and then adding additional images to
itself. The guide box lets you view the area where the
second part of the panoramic picture should fall
within.
• Add me
: combines people with existing background.
Touch the screen to pick which side of the screen to
focus on. Press the camera key. Focus on a
background and press the camera key a second time.
2.
Scene mode
: selects a camera setting for better
image capture under different lighting
environments. Choose from: None (default),
Landscape, Night, Sports, Party/Indoor,
Beach/Snow, Sunset, Dawn, Fall color,
Firework, Candlelight and Backlight.
3.
Brightness
: sets the total amount of light
allowed to fall on the subject through the lens
sensor while taking a picture.Touch and drag
the slider to the left (to decrease the value), to
the right (to increase the value). You can also
touch the Minus icon (to decrease the value) or
the Plus icon (to increase the value).
4.
Settings
: displays two types of settings, Camera
(first tab) and General settings (second tab).
Camera settings
:
•Timer
: allows you to set a time delay before the
camera takes the photo. Select the length of delay you
want and touch the Off, 2 sec, 5 sec, and 10 sec.
When you press the Camera key, the camera takes
the photo after the specified time elapses.
6
7
5
4
3
1
2
Multimedia 91
•Resolution
: sets the photo resolution to:
2048x1536, 1600x1200, 12800x960, or 320x240.
• White balance
: allows you to set this option from the
following choices: Auto, Daylight, Cloudy,
Incandescent, or Fluorescent.
• Effects
: allows you to change the color tone or apply
special effects to the photo. Options include: Normal,
Black and White, Negative, or Sepia.
• Metering
: allows you to set how the camera
measures or meters the light source: Center-
weighted, Spot, or Matrix.
• Image quality
: sets the photo quality (compression)
to: Superfine, Fine, or Normal.
• Adjust
: enhances additional camera settings such as
Contrast, Saturation, and Sharpness. Move the
corresponding slider to adjust the value.
General settings
:
• Guidelines
: displays alignment or framing guidelines
to perfectly set up each shot.
•Review
: displays the photo for review. Selections are:
Off, 2 sec, or On.
•GPS
: records GPS information onto the image file.
• Shutter sound
: allows you to select a tone to play
when the camera’s shutter opens and closes. Sound
selections are Sound 1, Sound 2, Sound 3, or Off.
•Reset
: resets the camera settings to the default
settings.
5.
Camera / Camcorder Mode
: allows you to take a
photo in various modes. Once you change the
mode, the corresponding indicator appears at
the top left of the display. Choose from Camera
or Camcorder.
6.
Camera button
: takes a photo when pressed in
Camera mode.
7.
Quick view
: displays the photo for quick
viewing.
Camcorder Options
You can change options using your keypad in capture
mode. The following short cuts are available:
1.
Recording mode
: Normal or Limit for MMS.
2.
Brightness
: sets the total amount of light
allowed to fall on the subject through the lens
sensor while recording a video. Touch and drag
the slider to the left to decrease the value, or to
the right to increase the value. Or touch the
Minus icon to decrease the value, or the Plus
icon to increase the value.
5
6
4
3
2
1
92
3.
Settings
: displays two types of settings,
Camcorder (first tab) and General settings
(second tab).
Camcorder settings
:
•Timer
: allows you to set a time delay before the
camcorder records the video. Select the length of
delay you want and touch the Off, 2 sec, 5 sec, and
10 sec. When you press the Camera key, the
camcorder records the video after the specified time
elapses.
•Resolution
: sets the video resolution to: 320x240 or
176x144.
• White balance
: allows you to set this option from the
following choices: Auto, Daylight, Cloudy,
Incandescent, or Fluorescent.
• Effects
: allows you to change the color tone or apply
special effects to the photo. Options include: Normal,
Black and White, Negative, or Sepia.
• Video quality
: allows you to set the video quality to:
Superfine, Fine, or Normal.
• Adjust
: allows you to adjust the Contrast, Saturation
and Sharpness for this video.
General settings
:
• Guidelines
: displays alignment or framing guidelines
to perfectly set up each recording.
• Audio recording
: activates audio recording feature so
you can record audio while recording the video.
•Review
: set to
On
to review the recorded video.
• Reset
: resets the camcorder settings to the default
settings.
4.
Camcorder / Camera Mode
: allows you to record
a video various modes. Once you change the
mode, the corresponding indicator appears at
the top left of the display. Choose from
Camcorder or Camera.
5.
Camcorder button
: records a video when
pressed in Camcorder mode.
6.
Quick view
: displays the video for quick
viewing.
Pictures and Videos Image Viewer Options
After you take a photo or record a video, you can
access various options.
Photo options
•Share
: allows you to share a picture using Bluetooth,
Messaging, Picasa, Gmail, Email, Kodak, or Snapfish.
•Set as
: sets the photo as a Contact icon, Home
screen Wallpaper, or Lock screen Wallpaper.
•More
:
–
Send to My Album Online
: sends this photo to My
Album Online.
–
Set Default Destination
: sets the default photo location
to: Recent log, Contacts, Online album, New Email
address, or New Phone number.
–
Delete
: deletes this photo.
Multimedia 93
Video options
•Share
: allows you to share a video using Messaging,
YouTube, Bluetooth, Email, Gmail, Kodak, and
Snapfish.
•Play
: plays the current video.
•More
:
–
Send to My Album Online
: sends this video to My
Album Online.
–
Set Default Destination
: sets the default photo
location to: Recent log, Contacts, Online album, New
Email address, or New Phone number.
–
Delete
: deletes this video.
Camera Gallery Options
The Gallery is where you can access the Gallery of
stored camera images.
1. From the Home screen, tap
(
Applications
)
➔ (
Gallery
).
2. Select a folder location (ex:
Camera
) and select
an image by tapping it once to place a green
check mark on the file.
3. Press from this main Gallery screen to
reveal gallery-specific options
Share
,
Delete
,
and
More
.
Camera Image Options
When you take a picture, the file is saved in the Photo
folder. You can view your pictures immediately or
view them anytime in the Photo folder.
1. From the Home screen, tap
(
Applications
)
➔ (
Gallery
).
2. Select a folder location and tap a file to open it
in the Image viewer. Touch and drag a picture
to the left to see the next picture or to the right
to see the previous picture.
3. Tap
Slideshow
to initiate an on-screen
slideshow displaying every image in the
current folder.
– or –
Tap
Menu
to display the following image menu
options:
•Share
: allows you to share a picture using Bluetooth,
Messaging, Picasa, Gmail, Email, Kodak, and
Snapfish.
• Delete
:
allows you to delete the current image.
94
•More
: provides you with the additional options such
as:
–
Send to My Album Online
: allows you to send the file
to your pre-configure My Album Online.
–
Set Default Destination
: allows you to assign a default
action to take after taking an image (Recent log,
Phonebook, Online album, Email address or Phone
number).
–
Details
: files details such as Title, Type, Date taken,
Album, Location, latitude, Longitude, etc..
–
Set as
: allows you to assign a picture to one of three
location: Home screen Wallpaper, Lock screen
Wallpaper, or to a Contact’s icon image.
–
Crop
: provides an on-screen box that allows you to crop
the current picture. Tap
Save
to update the image with
the new dimensions or
Discard
to ignore any changes.
–
Rotate left
: allows you to rotate the view of the current
image in a counterclockwise direction.
–
Rotate right
: allows you to rotate the view of the current
image in a clockwise direction.
Assigning an Image as a Contact Icon
1. From the Home screen, tap (
Applications
)
➔ (
Gallery
).
2. Select a folder location and tap a file to open it
in the Image viewer.
3. With the image displayed, tap
Menu
➔
More
➔
Set as
➔
Contact icon
.
4. Tap a contact to make a selection.
5. Crop the image and tap
Save
.
Assigning an Image as a Wallpaper
1. From the Home screen, tap (
Applications
)
➔ (
Gallery
).
2. Select a folder location and tap a file to open it
in the Image viewer.
3. With the image displayed, tap
Menu
➔
More
➔
Set as.
Multimedia 95
4. Select one of the two options:
• Home screen Wallpaper
assigns the current image
to the home screen background. This image is
spread across all available screens.
• Lock screen Wallpaper
assigns the selected image
to the background for the lock screen.
• Contact icon
assigns the selected image as the
displayed image for a selected Contact.
5. Touch and drag the crop box anywhere on the
picture. Touch and drag the sides of the crop
box to zoom in or out to create a cropped area.
6. Tap
Save
to assign the wallpaper image.
– or –
Tap
Cancel
to stop without updating the
wallpaper image.
Using the Camcorder
In addition to taking photos, the camera also doubles
as a camcorder that also allows you to record, view,
and send videos.
Note:
To ensure the Camcorder can record the video, use an
SDHC memory card.
Shooting Video
Tip:
When shooting video in direct sunlight or in bright
conditions, it is recommended that you provide your
subject with sufficient light by having the light source
behind you.
1. From the Home screen, tap
(
Applications
)
➔ (
Camera
) to activate the
camera mode.
2. Tap the camera icon from the upper-right of
the screen to toggle to the camcorder mode.
Note:
To return to the camera mode tap the camcorder icon
from the upper-right of the screen.
3. Using the phone’s main display screen as a
viewfinder, adjust the image by aiming the
camcorder at the subject.
4. Press the record video key ( ) to begin
shooting video.
5. Touch to pause the recording or touch
to stop the recording and save the video file to
your Photo folder.
6. Once the file is saved, tap
Play
to play your
video for review.
7. Press to return to the viewer.
Camcorder Options
Camcorder options are represented by icons across
both sides of the screen.
For more information, refer to “Camera and
Camcorder Options” on page 90.
96
Accessing Videos
When you shoot a video, the file is saved in the
Camera folder. You can view your videos immediately
or view them anytime in the Camera folder.
1. From the Home screen, tap (
Applications
)
➔ (
Gallery
).
2. Select a folder location and tap a video icon to
begin video playback.
– or –
Touch and hold the video icon from the main
Gallery to select the video (green check mark)
and display the following video menu context
options:
•Share
: allows you to share a video using Messaging,
YouTube, Bluetooth, Email, Gmail, Kodak, or Snapfish.
• Delete
:
allows you to delete chosen/selected pictures.
Touch the checkmark, to turn it green, next to any file or
folder you want to delete, then touch Delete.
•More
: provides you with the additional options such
as:
–
Send to My Album Online
: allows you to send the file
to your pre-configure My Album Online.
–
Set Default Destination
: allows you to assign a default
action to take after shooting video (Recent log,
Phonebook, Online album, New Email address or New
Phone number).
–
Details
: displays video file information.
Files
Files allows you to manage your sounds, images,
videos, bluetooth files, Android files, and other
memory card data in one convenient location. This
application allows you to launch a file if the
associated application is already on your phone (ex:
MP4).
䊳
From the Home screen, tap (
Applications
)
➔ (
Files
).
Note:
Navigation in this viewer works on a hierarchy structure
with folders, subfolders, etc.
Opening and Navigating within Files
DCIM is the default location for pictures or video taken
by the device. These files are actually stored in the
DCIM folder location.
1. From the Home screen, tap (
Applications
)
➔ (
Files
).
2. Tap a folder and scroll down or up until you
locate your selected file.
•Up tab
allows you to back up into a higher directory.
•Home tab
allows you to back up to the root directory.
•
Press and then tap
View by
to change the way
the files are displayed on-screen. Choose from:
List
,
List and details
, or
Thumbnail
.
Multimedia 97
•
Press
for these additional options:
Share
,
Create folder
,
Delete
,
View by
,
List by
, and
More
(Move, Copy, Rename, Bluetooth visibility and
Settings).
3. Once you have located your file, tap the file
name to launch the associated application.
The Gallery
The Gallery is where you view photos and play back
videos. For photos, you can also perform basic
editing tasks, view a slideshow, set photos as
wallpaper or caller image, and share as a picture
message.
Note:
If the phone displays a memory full message when
accessing the Gallery, access
Files
and remove some of
the media files from the folders, and then open the
Gallery.
Opening the Gallery
䊳
From the Home screen, tap
(
Applications
)
➔ (
Gallery
). For more
information, refer to “Camera Gallery Options”
on page 93.
Note:
If you stored your files in folders (directories) on the
storage card, Gallery displays these folders as separate
albums. The top left album contains all the pictures in the
storage card.
Music Player
Playing Music
1. From the Home screen, tap
(
Applications
)
➔ (
Music
). Music player
tips display.
2. Touch a tab to select the music category:
Artists
,
Albums
,
Songs
, or
Playlists
.
3. Scroll through the list and tap an entry to begin
playback.
4. The following Music Player controls are
available:
Pause the song.
Start the song after pausing.
Press and hold to rewind the song. Tap
to go to previous song.
Press and hold to fast-forward the
song. Tap to go
to next song.
Plays the entire song list once.
shuffles the current list of songs
randomly.
songs play in order and are not shuffled.
Plays the entire song list once.
Repeats the currently playing song.
98
Making a Song a Phone Ringtone
1. From the Home screen, tap (
Applications
)
➔ (
Music
).
2. Tap the
Songs
tab.
3. Touch and hold a song from the list to reveal
the on-screen context menu.
4. Tap
Set as phone ringtone.
Music Player Options
The Music Player Settings menu allows you to set
preferences for the music player such as whether you
want the music to play in the background, sound
effects, and how the music menu displays.
䊳
With the music player application displayed and
a song active, press and select one of the
following options:
•Library
: view your current audio library.
• Party shuffle on/off
: activates/deactivates this song
shuffle function.
• Add to playlist
: adds the selected music file to a
quick playlist.
• Settings
: allows you to activate or deactivate the 5.1
channel mode and select an available music equalizer
configuration such as: Normal, Rock, Jazz, Classic,
Dance, Pop, Live, Concert hall, Wide, Music clarity,
Bass enhancement, or Externalization.
• Set as ringtone
: sets the current song as your phone
ringtone.
•More
:
–
Delete
: permanently deletes the current song from the
SD card.
–
Stop playing music
: stops playback of the current
song.
Using Playlists
Playlists are used to assign music files into groups for
playback. These Playlists can be created using the
Music player on this device, or using a third-party
application (such as Windows Media Player) and
downloading those files to an SD card inserted into
the device.
Creating a Playlist
1. From the Home screen, tap (
Applications
)
➔ (
Music
).
2. Tap a song and begin playback.
3. Press ➔
Add to playlist
➔
New
.
4. Backspace over the default playlist title and
type a new name for this playlist, then tap
Save
.
Adding Music to a Playlist
1. From the Home screen, tap (
Applications
)
➔ (
Music
).
2. Tap the
Artists
or
Songs
tab.
3. Touch and hold a song title and select
Add to
playlist
➔
Add to playlist
➔
Current playlist
.
Replays the current list when the list
ends.
Multimedia 99
Note:
If a playlist is empty, add a song by touching a holding a
song name from the main screen to open the context
menu. Select
Add to playlist
.
Removing Music from a Playlist
1. From the Home screen, tap
(
Applications
)
➔ (
Music
).
2. Tap the
Playlists
tab.
3. Tap the playlist name in which to delete music.
4. Touch and hold a song to reveal the on-screen
context menu.
5. Tap
Remove from playlist.
Editing a Playlist
Besides adding and removing music files in a playlist,
you can also share, delete, or rename the playlist.
Only those playlist you have created can be edited.
Default playlists can not be renamed.
1. From the Home screen, tap
(
Applications
)
➔ (
Music
).
2. Tap the
Playlists
tab.
3. Touch and hold a playlist entry to reveal the
on-screen context menu.
4. Tap
Rename
.
5. Enter a new name for this playlist and tap
Save
.
Transferring Music Files
Music files can be downloaded to the phone using
one of two methods:
1. Downloaded to the phone from or Android
Market.
Music files are directly stored on your phone.
2. Downloaded to the phone via a direct USB
connection.
Music files are stored into a Music folder on
the SD card.
Removing Music Files
1. From the Home screen, tap
(
Applications
)
➔ (
Music
).
2. Tap the
Songs
tab.
3. Touch and hold a song entry to reveal the on-
screen context menu.
4. Tap
Delete
➔
OK.
The music file(s) is deleted.
YouTube
YouTube is a video sharing website on which users
can upload and share videos, and view them in
MPEG-4 format.
1. From the Home screen, tap
(
Applications
)
➔ (
YouTube
).
2. Tap
Accept
if you accept the Terms and
Conditions, or touch
Exit
.
100
3. When the screen loads you can begin searching
and viewing posted videos.
4. Press ➔
Settings
➔
High quality on mobile
if you prefer high quality output.
Applications and Development 101
Section 9: Applications and Development
This section outlines the various applications that are
available on your phone.
Applications
The Applications list provides quick access to all the
available applications on the phone.
Refer to the application table on page 27 for a
description of each Application, its function, and how
to navigate through that particular application. If the
application is already described in another section of
this user manual, then a cross reference to that
particular section is provided.
Accounts and sync
This application allows you to configure general
synchronization settings that determine whether the
background data is synchronized, and whether you
automatically synchronize data with the phone.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Accounts and sync
).
For more information, refer to “Accounts and
Synchronization” on page 146.
Calculator
Using this feature you can use the phone as a
calculator. The calculator provides the basic
arithmetic functions; addition, subtraction,
multiplication, and division. You can also use this as a
scientific calculator.
1. From the Home screen, tap
(
Applications
)
➔ (
Calculator
).
2. Enter the first number using the numeric keys.
3. Enter the operation for your calculation by
touching the
Plus, Minus, Multiplication,
or
Division
key.
4. Enter the next number.
5. To view the result, tap the
=
(equals)
key.
6. Repeat steps 1 to 4 as many times as required.
7. Press and tap
Advanced panel
to reveal
additional scientific functions.
Calendar
With the Calendar feature, you can consult the
calendar by day, week, or month, create events, and
set an alarm to act as a reminder. Google Calendar is
built into the phone and synchronizes both new and
existing entries between your phone and your online
Google account.
Important!:
You must have previously added an account
(Facebook, Microsoft Exchange ActiveSync, or
Google) prior to using the Calendar.
1. From the Home screen, tap
(
Applications
)
➔ (
Calendar
). The
Calendar displays four tabs:
102
2. Press and select one of the following
options:
•Day
: displays the Day view.
•Week
: displays the Week view.
•Month
: displays the Month view (default view).
• Agenda
: allows you to search for events for the
selected Month, Week, or Day. Or you can look for
events for a future date.
•Today
: displays the date highlighted with a Blue box
highlighting the date.
•More
: allows you to select additional options such as:
Create, Go to, Calendars, and Settings.
–
Create
: creates a new Event.
–
Go to
: displays a specific date.
–
Calendars
: accesses the My calenders feature.
–
Settings
: displays a list of configurable settings.
For more information, refer to “Synchronizing
Contacts” on page 71.
To manually sync calendar events:
1. Press ➔ and then tap ➔
Accounts and sync
.
2. Locate the email account containing the events
you wish to synchronize.
3. Tap within the adjacent account field to
reveal the account’s synchronization settings
screen.
4. Tap
Sync Calendar
to activate the
synchronization of calendar events between
your device and the remote exchange server. A
green checkmark indicates the feature is
enabled.
Camera
Use your 3.0 megapixel camera feature to produce
photos in a JPEG format.
Note:
An SD card must be inserted before the Camera will take
and store photos.
䊳
From the Home screen, tap (
Applications
)
➔ (
Camera
).
For more information, refer to “Using the Camera” on
page 89.
Clock
Here you can set an alarm, launch a slideshow,
access the music player, or return Home. For more
information, refer to “Clock” on page 129.
䊳
From the Home screen, tap (
Applications
)
➔ (
Clock
).
Contacts
The default storage location for saving phone
numbers to your Contacts List is your phone’s built-in
memory.
For more information, refer to “Contacts List” on
page 62.
Applications and Development 103
Email
Email enables you to review and create email using
most email services. The phone alerts you when you
receive an email.
For more information, refer to “Email” on page 82.
Files
Organize and store data, images, and more in your
own personal file folders. Files are stored to the
memory card in separate (user defined) folders.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Files
).
For more information, refer to “Files” on page 96.
Gallery
The Gallery is where you view photos and play back
videos. For photos, you can also perform basic
editing tasks, view a slideshow, set photos as
wallpaper or caller image, and share as a picture
message.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Gallery
).
For more information, refer to “The Gallery” on
page 97.
Google Mail
Google Mail (Gmail) is a web-based email service.
Gmail is configured when you first set up your phone.
Depending on your synchronization settings, Gmail
can automatically synchronize with your Gmail
account on the web.
For more information, refer to “Using Google Mail”
on page 87.
Google Search
Google Search is a web-based search engine that
uses text-based queries to search for content on web
pages.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Google Search
) and
enter the search text.
– or –
Touch the microphone on the Google Search
bar and say the search information. For more
information, refer to “Search Key” on page 21.
For more information, refer to “Using Google
Search” on page 22.
Latitude
Google Latitude allows you and your friends share
locations and status messages with each other. It
also lets you send instant messages and emails,
make phone calls, and get directions to your friends’
locations.
Important!:
You must sign in to your Google account, enable
Wi-Fi, and enable the Location feature before you
can use this application. For more information,
refer to “Wi-Fi settings” on page 131.
1. From the Home screen, tap
(
Applications
)
➔ (
Latitude
).
104
2. If desired, tap
Join Latitude
to Join Latitude
where you can share your current location with
your Google friends and contacts.
3. If currently disabled, tap
Wi-Fi Disabled
to begin
the process of turning on Wi-Fi.
4. Press and tap
Join Latitude
➔
Privacy
.
From here you can configure your location
reporting. Choose from one of the following:
• Detect your location
to use your GPS to detect your
current location and update that onto your map.
• Set your location
to manually set a location for
yourself on the map. This does not have to be your
actual location.
• Hide your location
so friends can not see your
current location.
5. From within the Suggested Friends page, press
and then tap an available application
option such as:
Refresh friends
,
See map
,
Add
friends
, or
Privacy
.
6. From the main application page, press
and then tap an available application option
such as:
Search
,
Directions
,
Starred Places
,
Clear Map
,
Latitude
, or
More
(Labs, Help, Terms,
Privacy & Notices, and About).
Maps
Google Maps allow you to track your current location,
view real-time traffic issues, and view detailed
destination directions. There is also a search tool
included to help you locate places of interest or a
specific address. You can view locations on a vector
or aerial map, or you can view locations at the street
level.
Important!:
Before using Google Maps you must have an active
data (3G) or Wi-Fi connection. The Maps application
does not cover every country or city.
䊳
From the Home screen, tap (
Applications
)
➔ (
Maps
).
Enabling a Location source
Before you use Google Maps and find your location or
search for places of interest, you must enable a
location source. To enable the location source you
must enable the wireless network, or enable the GPS
satellites.
Important!:
The more location determining functions are
enabled, the more accurate the determination will
be of your position.
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Use wireless networks
to enable GPS to
determine location based on nearby cell
towers.
Applications and Development 105
3. Tap
Use GPS satellites
to enable the GPS
satellite.
Tip:
When using Google Maps you can turn on Enable GPS
satellites. Selecting GPS satellites allows you to locate
places of interest at the street-level. However, this also
requires a clear view of the sky and uses more battery
power.
Opening Maps
1. From the Home screen, tap
(
Applications
)
➔ (
Maps
).
2. Locate the top row of the applications to
access additional options:
• Search Maps
: allows you to search for a place of
interest.
• Places
: provides access to the places menu where
you can quickly locate a business or person, find out
more information about a business, see coupons,
public responses, and more (page 112). Locate and
tap one of the listed places (Restaurants, Coffee,
Bars, Hotels, Attractions, ATMs, Gas Stations, or Add
your own place.)
A list of places within this category displays.
•Layers
: allows you to switch map views:
–
Traffic
: (available only in selected areas) Real-time
traffic conditions are displayed over roads as color-
coded lines. Each color represents how fast the traffic is
moving.
–
Satellite
: Maps uses the same satellite data as Google
Earth. Satellite images are not real-time. Google Earth
acquires the best imagery available, most of which is
approximately one to three years old.
–
Terrain
: combines a topographical view of the area’s
terrain with the current map location.
–
Buzz
: allows you post public messages and photos at a
location for everyone to see.
–
Latitude
: allows you to see your friend's locations and
share your location with them.
–
Clear Map
: clears the current map selection.
–
More Layers
: allows you to add additional layers such
as My Maps, Wikipedia, Transit Lines, and Favorite
places.
•My Location
: when touched, the location displays on
the map with a blinking blue dot.
3. Press and select one of the following
options:
•Search
: allows you to search for a place of interest.
•Directions
: displays navigation directions to a
location from a starting point.
• Starred Places
: marks favorite locations on the map.
These items are automatically synchronized with
maps.
•Clear Map
: after viewing or following directions, this
option resets the map.
• Join Latitude
: lets you and your friends share
locations and status messages with each other. It
also lets you send instant messages and emails,
make phone calls, and get directions to your friends’
locations.
•More
:
–
Labs
: a testing ground for experimental features that
are not ready to use publically.
–
Help
: uses the browser to display a searchable Google
Mobile Help screen.
106
–
Terms, Privacy & Notices
: displays the Terms and
Conditions, Privacy Policy, or Legal Notices information.
Select the desired information from the pop-up menu.
–
About
: displays general information about Google maps
such as Version, Platform, Locale, Total data sent, Total
data received, Free memory, etc.
Market
Android Market provides access to downloadable
applications and games to install on your phone.
Android Market also allows you to provide feedback
and comments about an application, or flag an
application that might be incompatible with your
phone.
Accessing the Market
1. From the Home screen, tap (
Applications
)
➔ (
Market
).
2. If not already logged in with your Google
account, tap
Next
.
3. Tap
Sign in
and enter your Google account
information.
4. Tap
Accept
to agree to the Android Market
terms of service.
For more information, refer to “Downloading a New
Google Application” on page 106.
Downloading a New Google Application
To download a new application, you will need to use
your Google account to sign in to Android Market. The
Android Market home page provides several ways to
find applications. The home page features
applications and includes a list of item applications by
category, a list of games, a link to search, and a link
to My downloads.
1. From the Home screen, tap (
Applications
)
➔ (
Market
).
2. Browse through the categories, find an
application you're interested in, and tap the
name.
3. Read the application descriptions.
Important!:
If the selected application requires access to data or
control of a function on your phone, Market displays
the information the application will access.
Tap
OK
if you agree to the conditions of the
application. Once you tap
OK
on this screen you are
responsible for using this application on the phone
and the amount of data it uses. Use this feature with
caution.
4. Tap
Install
.
Note:
Use caution with applications which request access to
any personal data, functions, or significant amounts of
data usage times.
5. If prompted, follow the on-screen instructions
to pay for the application.
Applications and Development 107
6. Check the progress of the current download by
opening the Notifications panel.
7. After the item is downloaded and installed on
your phone, the content download icon
appears in the notification area of the status
bar.
8. On the Android Market screen, tap either
Downloads
or
My apps
, tap the installed
application in the list, and then tap
Open
.
Tip:
The newly downloaded application displays on the Home
screen or other selected panel.
Note:
A data plan is required to use this feature. Charges may
apply. Please contact your service provider for further
details.
Launching an Installed Google
Application
1. From the Home screen, tap
(
Applications
).
2. Tap the newly installed application. This
application is typically located on the last
Applications page.
Android Development
This device can be used for Android application
development. You can write applications in the SDK
and install them on this device, then run the
applications using the hardware, system, and
network.
Warning!:
Android Dev Phones are not intended for non-
developer end-users. Because the device can be
configured with system software not provided by or
supported by Google or any other company, end-
users operate these devices at their own risk.
Unknown sources
This feature can be used for Android application
development. The feature allows developers to install
non-Market applications.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Unknown sources
.
Unknown sources displays a check mark to
indicate it is active.
Manage applications
This feature allows you to manage and remove
installed applications. You can also view the amount
of memory or resources used as well as the
remaining memory and resources for each of the
applications on your phone and clear the data, cache,
or defaults.
䊳
Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Manage
application
.
108
Clearing application cache and data
1. Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Manage
applications
.
2. Tap an application in which to clear the cache
or data.
3. Tap
Force stop
,
Clear data
,
Clear cache
, or
Clear
defaults
.
Uninstalling third-party applications
You can uninstall any application you downloaded and
installed from Android Market.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Manage
applications
.
2. Tap the third-party application, and from the
Application info
screen, tap
Uninstall
.
Memo
This feature allows you to create a memo.
1. From the Home screen, tap (
Applications
)
➔ (
Memo
).
2. Tap
Create memo
.
– or –
Press and then tap
Create
.
3. Compose the memo and touch
Save
.
•
Before you save your new memo, you can also press
and adjust the memo’s background color.
For more information, refer to “Text Input Methods”
on page 53.
Memo options
1. While viewing the list of Memos, press
and select one of the following options:
•Create
: allows you to create a memo.
•
Maximize: remove the bent, lower-right corner of the
memo page and to maximize the information display.
•Delete
: allows you to delete one or more memos.
•Search
: allows you to search within the current set of
memos.
2. Touch and hold the memo then select
Send via
and choose the method to send this memo:
Bluetooth
,
Email
, or
Messaging
.
3. From the memo list, touch the upper-left edit
button and select a color for the memo’s
background, then tap
Save
.
Messaging
This application allows you to use the Short Message
Service (SMS) to send and receive short text
messages to and from other mobile phones.
You can also use the Multi Media Service (MMS) to
create multimedia messages to send and receive
from other mobile phones.
䊳
From the Home screen, tap (
Applications
)
➔ (
Messaging
).
For more information, refer to “Messages” on
page 77.
Applications and Development 109
Music
Music Player allows you to play music files that you
have stored on your microSD card. You can also
create playlists.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Music
).
For more information, refer to “Music Player” on
page 97.
My Account
This option provides you with account specific
information such as your current activity, billing
information, and Plan Services information. You can
also set alerts for minute or message usage,
payment reminder, or power saver.
Note:
You may be prompted to log into the Android Market to
receive the latest version of the T-Mobile My Account
application.
The differences between My Account and My Device
are these:
• My Account
: check Activity, Set Alerts, review Billing,
and review your current Plan and services.
•My Device
: Personalize settings, Quick Tools,
Support, and Storage & Battery.
Tip:
Use the Menu key to toggle between My Account and My
Device.
1. From the Home screen, tap
(
Applications
)
➔ (
My Account
).
2. Read the on-screen information and tap
OK
.
The initial screen displays four tabs: Activity, Set
Alerts, Billing, and Plans Services.
Activity
The Activity tab displays your current minute and
message activity. You can view what percentage of
minutes were used as well as the number of
messages used for a particular start date.
Set Alerts
From this screen you can activate alerts to notify you
of the following:
• Minute Usage
: tracks the number of minutes used
and remaining in your plan.
–
Minute Usage Reminder: sends an alert when the
number of minutes used reaches 75 percent of the total
available minutes in the plan.
–
Over Limit Alert: sends an alert when usage exceeds
your plan’s total available minutes.
• Message Usage
: tracks the number of messages
used and remaining in your plan. If you plan includes
unlimited messages this setting does not apply.
• Data Usage
: tracks data used and remaining in your
plan. If you plan includes unlimited data usage this
setting does not apply.
• Payment Reminder
: alerts when your bill is due.
•Power Saver
: sends an alert when the battery level
reaches 30 percent. The alert displays in the
notification window. This alert is automatically set to
On.
Billing
This provides a billing summary.
110
Plan Services
This screen displays specific information and charges
for your current plan and services. The screen also
displays additional services information and charges.
My Device
Use the My Device application to configure device
settings, view support information, personalize your
CallerTunes, Ringtones, or Wallpapers, or view battery
storage information.
1. From the Home screen, tap (
Applications
)
➔ (
My Device
).
2. Read the on-screen information and tap
OK
.
Tip:
Use the Menu key ( ) to toggle between My Account
and My Device.
The differences between My Account and My Device
are these:
• My Account
: check Activity, Set Alerts, review Billing,
and review your current Plan and services.
• My Device
: Personalize settings, Quick Tools,
Support, and Storage & Battery.
The initial screen displays four tabs: Personalize,
Quick Tools, Support, and Storage Battery.
Personalize My Device
Using this menu you can personalize CallerTunes,
Ringtone, and Wallpapers.
• Ringtones
: you can personalize your phone’s
ringtones by choosing from recordings, voices, and
more.
• Wallpapers
: you can personalize your phone’s
background by selecting wallpapers from the Shop,
Gallery, Live Wallpapers, and the Wallpaper Gallery.
Quick Tools
Quick Tools is a shortcut that allows you to adjust the
following features: Wi-Fi, Bluetooth, Data Roaming,
GPS, Brightness, Screen Timeout, and provides Phone
Information.
Support
Displays support information My Account Feedback,
T-Mobile Forums, and T-Mobile on Twitter.
Storage & Battery
From this tab you can view Memory storage
information for the phone or memory card. You can
also view the battery level percentage and other
information.
Navigation
Google Maps Navigation (Beta) is an internet-
connected turn-by-turn, GPS navigation system with
voice guidance.
Caution!:
Traffic data is not real-time and directions may be
wrong, dangerous, prohibited, or involve ferries.
Important!:
To receive better GPS signals, avoid using your
device in the following conditions:
- inside a building or between buildings
- in a tunnel or underground passage
- in poor weather
- around high-voltage or electromagnetic fields
- in a vehicle with tinted windows
Applications and Development 111
䊳
From the Home screen, tap
(
Applications
)
➔ (
Navigation
).
Enabling GPS Location
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
2. Tap
Use GPS satellites.
A green check mark
indicates the GPS location feature is enabled.
Navigation options
1. From the Home screen, tap ➔
(
Navigation
). The navigation application can be
configured from the main screen.
2. Read the on-screen disclaimer and tap
Accept
.
3. Choose from the following on-screen options:
• Driving/Walking
: configures the method of travel.
Selection of Walking would negate the need to track
traffic jams and obstructions.
–
Driving mode enables the
Settings
feature: allows you
to configure your Route options such as:
Avoid
highways
or
Avoid tolls
.
•Maps
: enables the on-screen real-time map
functionality.
• Speak Destination
: allows you to use the voice
recognition feature to search for matching locations
in your area.
• Type Destination
: allows you to manually enter a
destination address (via the on-screen keypad).
•Contacts
: allows you to receive turn-by-turn
directions to the address stored for a selected
Contacts entry.
• Starred Places
: allows you to obtain directions to
locations that have been starred within Google maps
(
maps.google.com
).
Navigation Map options
Once on the map screen, you can access the
following features:
•
Destination
: returns you to the previous Navigation
options screen.
•
Search by voice
: Speak your destination instead of
typing (English only).
•
Layers
: allows you to switch map views:
• Traffic view
: (available only in selected areas) Real-
time traffic conditions are displayed over roads as
color-coded lines. Each color represents how fast the
traffic is moving.
• Satellite
: Maps uses the same satellite data as
Google Earth. Satellite images are not real-time.
Google Earth acquires the best imagery available,
most of which is approximately one to three years
old.
• Parking
: displays parking information relative to your
current location.
• Gas Stations
: displays gas station location relative to
your current location.
• ATMs & Banks
: displays ATM and Bank locations
relative to your current location.
• Restaurants
: displays restaurant and eatery
locations relative to your current location.
•
Mute
: allows you to mute the audio readout and
directional information.
•
Exit Navigation
: terminates the application.
112
•
More
: provides additional application information such as:
Directions List, Set Destination, Help and Term, Privacy &
Notices.
•Set Destination
: returns you to the navigation options
screen where you can access a destination by either
Speaking, Typing, or selecting from a Contacts entry
or Starred Place.
Caution!:
Navigation is a beta product. Use caution.
News and Weather
1. From the Home screen, tap (
Applications
)
➔ (
News and Weather
).
2. Select from any of the available tabs:
Weather
,
Top Stories
,
U.S., Sports
, and
Entertainment
.
To access the settings:
1. Press and then tap
Settings
.
2. Tap an available option:
Weather settings
,
News
settings
,
Refresh settings
, and
Application
version
.
Places
Google Places displays company logos on a layer of
Google Maps. When viewing an area you can quickly
locate a business or person, find out more information
about the business, see coupons, public responses,
and more.
1. From the Home screen, tap (
Applications
)
➔ (
Places
).
2. Use the
Find places
field to manually enter a
desired place or choose from among the
various categories. Matches are filtered by
those closest to your current location.
3. Locate and tap one of the listed places
(Restaurants, Coffee, Bars, Hotels, Attractions,
ATMs, Gas Stations, or Add your own place.) A
list of places within this category displays.
4. Touch the Maps icon (upper-right) to launch the
related maps feature.
5. Press and then tap
Latitude
. The functions
of this application are similar to those of the
Navigation application, but work along with the
Latitude service where you can share your
location with your chosen Google friends.
Settings
This icon navigates to the sound and phone settings
for your phone. It includes such settings as: display,
security, memory, and any extra settings associated
with your phone.
䊳
From the Home screen, tap (
Applications
)
➔ (
Settings
).
– or –
Press ➔ and then tap
(
Settings
).
For more information, refer to “Changing Your
Settings” on page 131.
Applications and Development 113
Swype tips
Using the SwypeTips application you can watch a
video or start a tutorial that teaches you how to use
Swype most efficiently.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Swype Tips
).
For more information, refer to “Swype Text Entry
Tips” on page 55.
Talk
You can instant message with Google Talk. Google
Talk allows you to communicate with other people
who are also connected with Google Talk on the
phone or on the web.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Google Talk
).
For more information, refer to “Google Talk” on
page 88.
Task Manager
Sometimes your phone might seem to slow down over
time, and the biggest reason for this are background
applications. These are applications that were not
properly closed or shutdown and are still active but
minimized. The Task Manager not only lets you see
which of these applications are still active in the
background but also easily lets you choose which
applications are left running and which are closed.
Shutting Down Applications
1. From the Home screen, tap
(
Applications
)
➔ (
Task Manager
).
– or –
Press and hold then tap
Task manager
.
This screen contains the following tabs:
• Active applications
display those currently active
applications running on your phone.
•Package
displays any installed packages or
applications from the Market that are taking up
memory space. Tap
Uninstall
to remove them from
your phone.
•RAM
, displays the amount of current RAM (Random
Access Memory) currently being used and allows you
to
Clear memory
.
• Summary
displays a visual graph indicating the
available and used space within the internal
Storage
location and
External SD card.
•Help
provides additional battery saving techniques.
2. From the
Active applications
tab, tap
End
to
close selected applications or tap
End all
to
close all background running applications.
ThinkFree Office
ThinkFree Office Mobile for Android is a Microsoft
Office compatible office suite. This application
provides a central place for managing your
documents online or offline.
The application can also open Adobe PDF (Portable
Document Format) files.
114
1. From the Home screen, tap (
Applications
)
➔ (
ThinkFree Office
).
2. Read the End User License Agreement, then tap
Accept
if you agree with the terms of use.
3. On its initial launch, tap
Activate now
.Three tabs
display:
•Home
: displays the introduction to ThinkFree Office
and lists a short description of each of the tabs and
what type of information they provide.
•My Docs
: This is where you keep your documents on
this device. You can manage documents, or send
them to others, and upload the documents to
ThinkFree Online.
•Online
: This provides your
thinkfree.com
online
storage information. You can also share your
documents to others without using email
attachments.
Voice Recorder
The Voice Recorder allows you to record an audio file
up to one minute long and then immediately send it
as a message.
1. From the Home screen, tap (
Applications
)
➔ (
Voice Recorder
).
2. Tap the Record icon to record an audio file.
3. Tap Stop to stop recording. The file
automatically saves to the Voice list.
4. Press and then tap
Share
and select a
method in which to share this audio file.
Selections are:
Bluetooth
,
Email
,
Gmail
, or
Messaging
. Refer to each specific section,
depending on the method you selected to send
this voice recording.
Voice Search
The Voice Search feature is a voice-activated
application that allows you to tell the phone what to
search for and then the phone activates a Google
search based on what you said.
For more information, refer to “Using Additional Voice
Search Functions” on page 22.
1. From the Home screen, tap (
Applications
)
➔ (
Voice Search
).
2. Select
Agree
if you want Google to use location
for improved search results and other services,
or
Disagree
to decline.
3. At the
Speak now
screen speak your search
command slowly and clearly.
Google searches for the information and
displays related information in the browser.
Applications and Development 115
Web
Open the browser to start surfing the web. The
browser is fully optimized and comes with advanced
functionality to enhance the Internet browsing feature
on your phone.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Web
).
For more information, refer to “Web” on page 116.
Wi-Fi Calling
This feature allows you to make calls using a Wi-Fi
over the T-Mobile network.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Wi-Fi Calling
).
For more information, refer to “Wi-Fi Calling” on
page 44.
Note:
After you complete a connection to an active Wi-Fi
network, the Wi-Fi Calling feature will automatically be
enabled.
YouTube
YouTube is a video sharing website on which users
can upload and share videos, and view them in
MPEG-4 format.
1. From the Home screen, tap
(
Applications
)
➔ (
YouTube
).
2. When the screen loads you can begin
searching and viewing posted videos.
To configure YouTube Settings:
䊳
Press ➔
Settings
and configure the
following parameters:
• High quality on mobile
, when enabled, allows you to
start all videos in high quality mode while you are
connected to a mobile network.
• Caption front size
allows you to set the font size
used by on-screen captions. Choose from: Small,
Medium, Large, or Extra Large.
• Clear search history
allows you to clear any previous
YouTube searches from appearing within the search
box.
• SafeSearch filtering
allows you to configure block
settings for videos containing restricted content. This
option blocks these videos from appearing within
your search results. Choose from: Don’t filter,
Moderate, or Strict blocking.
•Help
provides answers to most YouTube questions.
• Feedback
allows you to provide user feedback to
YouTube.
• Google Mobile Terms of Service
• YouTube Terms of Service
• Google Mobile Privacy Policies
• YouTube Privacy Policies
• Application version
displays the software version for
the current YouTube application.
To watch a high quality video:
䊳
While playing a video, press ➔
Settings
➔
High quality on mobile
.
116
Section 10: Connections
Your phone is equipped with features that allow you to
quickly connect to the web.
Web
Your phone is equipped with a Google browser to
navigate the mobile web. This section explains how to
navigate the browser and use the basic features.
Accessing the Internet
To access the Browser:
䊳
From the Home screen, tap (
Applications
)
➔ (
Web
).
Homepage
When you access the Browser, the
web2go home page
displays the following topics:
•
Google Search
: allows you to quickly search for online
topics using the Google search engine.
•
Advertisement
: provides an on-screen advertisement
bubble providing suggested phone applications.
•
More Sites
: displays different on-screen pages containing
shortcuts to a variety of different applications (Email/IM,
Social/Chat, etc..) and categories (Sports, Weather,
En Español, My Account).
•
Downloads
: allows you to download Ringtone,
Callertunes, Games, Apps, or Gift and Deals.
•
Yahoo Mail
: displays the Sign in for Yahoo Mail. Register
by sending a text message with the word START to 92500
if you are not already registered.
•
Facebook
: displays the Facebook Log in. Sign up from
this page if you are not already registered.
•
AccuWeather
: based on your location settings,
AccuWeather displays the current weather conditions.
•
CNN
: displays current news headlines and more.
•
ESPN
: displays current sports news headlines and more.
•
E! Online
: displays current entertainment news headlines
and more.
•
Mapquest
: provides access to the online mapquest site.
•
Yelp
: provides access to Yelp which is an online urban city
guide that helps people find cool places to eat, shop,
drink, relax and play. Its the fun and easy way to find,
review and talk about what's great in your world.
•
What’s Now
: provides quick access to a variety of
different entertainment and shopping websites.
•
My Account
: provides quick access to your My Account
page.
Navigating with the Browser
1. To select an item, touch an entry.
2. To scroll through a website, sweep the screen
with your finger in an up or down motion.
3. To return to the previous page, touch .
Browser Options
䊳
From the home page, press to access the
following options:
Connections 117
• New window
: displays a new window so you can
browse multiple URLs. For more information, refer to
“Adding and Deleting Windows”
on page 117.
• Windows
: displays a list of the windows you have
open.
•Refresh
: reloads the current page.
•Forward
: forwards the browser to another web page.
• Add bookmark
: allows you to add a URL to your
bookmark list.
•More
: displays the following additional options:
–
Add shortcut to Home
: adds a shortcut to your
web2go homepage on your phone’s Home screen.
–
Add RSS feeds
: adds RSS feeds to your browser.
–
Find on page
: allows you to search in the current page.
–
Page info
: displays information about the selected
page.
–
Share page
: allows you to share the page using Gmail
or as a message.
–
Downloads
: displays the download history.
–
Settings
: allows you to change the way you view your
web pages by changing these options. See “Browser
Settings” on page 119.
Entering a URL
You can access a website quickly by entering the
URL. Websites are optimized for viewing on your
phone.
To enter a URL and go to a particular website, follow
these steps:
䊳
Tap the URL field at the top of the screen, enter
the URL and tap
Go
.
Search the Internet
To perform an internet search using keywords, follow
these steps:
1. Tap the Google search field, enter the
keyword(s) to search using the on-screen
keypad.
2. Tap (
Search
). A list of search results
displays.
•
Depending on which screen you are on, the search
icon might also appear as .
3. Tap a link to view the website.
Adding and Deleting Windows
You can have up to eight Internet windows open at
one time. To add a new window, follow these steps:
1. From your browser, press and then tap
New Window.
– or –
Press and then tap
Windows
➔
New
Window
.
2. A new browser window displays.
3. Press and then tap
Windows
to see a list
of all open windows.
Note:
This icon will display a number that corresponds to the
current number of active browser windows,
118
4. Scroll across the screen to view the currently
active windows and tap an entry to launch the
selected Internet window.
5. Tap next to the listing to delete the
window.
Using Bookmarks
While navigating a website, you can bookmark a site
to quickly and easily access it at a future time. The
URLs (website addresses) of the bookmarked sites
display in the Bookmarks page. From the Bookmarks
page you can also view your Most visited websites
and view your History.
1. From the Home webpage, tap . The
Bookmarks
page displays. Additional pages
include
Most visited
and
History
.
2. Press to display the following options:
• Bookmark last-viewed page
: Creates a new
bookmark for the last webpage that you viewed.
• List/Thumbnail view
: Select
Thumbnail view
(default) to view a thumbnail of the webpage with the
name listed, or select
List view
to view a list of the
bookmarks with Name and URL listed.
•Create folder
: Creates a new folder in which to store
new bookmarks.
• Change order
: Allows you to rearrange the Bookmark
on the screen.
3. Tap a bookmark to view the webpage, or touch
and hold a bookmark for the following options:
•Open
: Opens the webpage of the selected bookmark.
• Open in new window
: Opens the webpage in a new
window.
•Edit bookmark
: Allows you to edit the name or URL of
the bookmark. For more information, refer to
“Editing Bookmarks”
on page 118.
• Add shortcut to Home
: Adds a shortcut to the
bookmarked webpage to your phone’s Home screen.
• Share link
: Allows you to share a URL address via
Bluetooth, Facebook, Email, Gmail, or Messaging.
• Copy link URL
: Allows you to copy the URL address to
use in a message.
• Delete bookmark
: Allows you to delete a bookmark.
For more information, refer to
“Deleting
Bookmarks”
on page 119.
• Set as homepage
: Sets the bookmark to your new
homepage.
Adding Bookmarks
1. From the Home webpage, tap ➔
Add
.
2. Use the on-screen keypad to enter the name of
the bookmark and the URL.
3. Assign a folder location.
Home
is the default.
4. Tap
OK
. The new save page now appears on
the Bookmarks page.
Editing Bookmarks
1. From the Bookmarks page, touch and hold the
bookmark you want to edit.
2. Tap
Edit bookmark
.
3. Use the on-screen keypad to edit the name of
the bookmark or the URL.
Connections 119
4. Tap
OK
.
Deleting Bookmarks
1. From the Bookmarks page, touch and hold the
bookmark you want to delete.
2. Tap
Delete bookmark
.
3. At the confirmation window, tap
OK
.
Emptying the Cookies
A cookie is a small file placed on your phone by a
website during navigation. In addition to containing
some site-specific information, a cookie can also
contain some personal information (such as a
username and password) which might pose a
security risk if not properly managed. You can clear
these cookies from your phone at any time.
1. From the Home webpage, press and then
tap
More
➔
Settings
➔
Clear all cookie data
.
2. Tap
OK
to delete the cookies or touch
Cancel
to
exit.
Using Web History
The History list displays a list of the most recently
viewed websites. These entries can be used to return
to previously unmarked web pages.
1. From the Home webpage, tap ➔
History
tab.
A list of the most recently viewed websites
displays.
2. Tap an entry to display the webpage.
– or –
Press and then tap
Clear history
to delete
the current History list.
Using Most Visited
The Most visited list provides you with a list of the
most visited and bookmarked websites. These
entries are used to return to previously unmarked
web pages.
1. From the Home webpage, tap ➔
Most
visited
tab.
A list of your most frequently visited webpages
displays. The most frequently visited web
pages display at the top of the list.
2. Tap any entry to display the selected webpage.
Browser Settings
To make configure browser settings, follow these
steps:
1. From the Home screen, tap
(
Applications
)
➔ (
Web
).
2. Press and then tap
More
➔
Settings
.
3. Choose from the following on-screen options:
• Default zoom
: Adjusts the zoom feature. Set to Far,
Medium, or Close.
• Open pages in overview
: Displays an overview of
recently viewed web pages.
• Text encoding
: Adjusts the current text encoding.
120
• Block pop-up windows
: Prevents popup
advertisement or windows from appearing on-screen.
Remove the checkmark to disable this function.
•Load images
: Allows web page images to load along
with the other text components of a loaded website.
• Auto-fit pages
: Allows web pages to be resized to fit
as much of the screen as possible.
• Landscape view only
: Displays the browser in only
the horizontal position.
• Enable JavaScript
: Enables javascript for the current
Web page. Without this feature, some pages may not
display properly. Remove the checkmark to disable
this function.
• Enable plug-ins
: Allows the download of plug-ins.
• Open in background
: New pages are launched in a
separate page and displayed behind the current one.
Remove the checkmark to disable this function.
• Set home page
: Sets the current home page for the
Web browser.
• Default storage
: Sets the default storage to Memory
card.
• Clear cache
: Deletes all currently cached data. Tap
OK
to complete the process or
Cancel
to exit.
•Clear history
: Clears the browser navigation history.
Tap
OK
to complete the process or
Cancel
to exit.
• Accept cookies
: Allows sites, that require cookies, to
save and read cookies from your device.
• Clear all cookie data
: Deletes all current browser
cookie files.
• Remember form data
: Allows the device to store
data from any previously filled out forms. Remove the
checkmark to disable this function.
• Clear form data
: Deletes any stored data from
previously filled out forms. Tap
OK
to complete the
process or
Cancel
to exit.
• Enable location
: Allows websites to request access
to your location.
• Clear location access
: Clears location access for all
websites. Tap
OK
to complete the process or
Cancel
to exit.
• Remember passwords
: Stores usernames and
passwords for visited sites. Remove the checkmark to
disable this function.
• Clear passwords
: Deletes any previously stored
usernames or passwords. Tap
OK
to complete the
process or
Cancel
to exit.
• Show security warnings
: Notifies you if there is a
security issue with the current website. Remove the
checkmark to disable this function.
• Set search engine
: Allows you to choose a default
search engine for your phone. Choose from:
Google
,
Yahoo!
, or
Bing
.
• Website settings
: View advanced settings for
individual websites.
• Reset to default
: Clears all browser data and resets
all settings to default.
Connections 121
Bluetooth
About Bluetooth
Bluetooth is a short-range communications
technology that allows you to connect wirelessly to a
number of Bluetooth devices, such as headsets and
hands-free car kits, and Bluetooth-enabled
handhelds, computers, printers, and wireless
devices. The Bluetooth communication range is
usually up to approximately 30 feet.
Turning Bluetooth On and Off
To turn Bluetooth on:
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Bluetooth settings
.
2. Tap the
Bluetooth
field to activate the feature
(checkmark indicates active). When active,
displays in the Status area.
To turn Bluetooth off:
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Bluetooth settings
.
2. Tap the
Bluetooth
field to deactivate the
feature.
Bluetooth Status Indicators
The following icons show your Bluetooth connection
status at a glance:
Displays when Bluetooth is active.
Displays when Bluetooth is connected
(paired) and communicating.
Bluetooth Settings
The Bluetooth settings menu allows you to set up
many of the characteristics of your device’s Bluetooth
service, including:
•
Entering or changing the name your device uses for
Bluetooth communication and description
•
Setting your device’s visibility (or “discoverability”) for
other Bluetooth devices
•
Displaying your device’s Bluetooth address
To access the Bluetooth Settings menu:
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Bluetooth settings
.
2. Verify Bluetooth is active. Indicated by a green
check mark in the Bluetooth field.
3. Tap the
Device name
,
Visible
, and
Scan devices
fields to set the options.
122
To change your Bluetooth name:
1. Verify Bluetooth is active.
2. From the Bluetooth settings page, tap
Device
name
.
3. Enter a new name.
4. Tap
OK
to complete the rename process.
To set visibility:
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, tap
Visible
.
Making your device visible allows other devices
to pair and communicate.
Note:
Your device is visible for up to 120 seconds (2 minutes).
This value appears as a countdown within this field.
To scan for Bluetooth devices:
1. Verify Bluetooth is active.
2. From the Bluetooth settings page, tap
Scan
devices
to search for visible external Bluetooth-
compatible devices such as headsets, devices,
printers, and computers.
Pairing Bluetooth Devices
The Bluetooth pairing process allows you to establish
trusted connections between your device and another
Bluetooth device. When you pair devices, they share a
passkey, allowing for fast, secure connections while
bypassing the discovery and authentication process.
Note:
Pairing between two Bluetooth devices is a one-time
process. Once pairing is established the devices continue
to recognize their partnership and exchange information
without entering a passcode.
To pair your device with another Bluetooth device:
1. Verify Bluetooth is active.
2. From the Bluetooth settings page, tap
Visible
.
Your device must be visible to successfully pair
with an external device.
3. Tap
Scan devices
. Your device displays a list of
discovered in-range Bluetooth devices.
4. Tap a device from the list to initiate pairing.
5. Enter the passkey or PIN code, if needed, and
tap
OK
.
6. The external device must accept the connection
and enter your device’s PIN code.
Once successfully paired to an external device,
displays in the Status area.
Connections 123
Note:
Due to different specifications and features of other
Bluetooth-compatible devices, display and operations
may be different, and functions such as transfer or
exchange may not be possible with all Bluetooth-
compatible devices.
Disconnecting a Paired Bluetooth Device
Disconnecting a paired device breaks the connection
between the device and your phone, but retains the
knowledge of the pairing. At a later point when you
wish to reconnect the device, there is no need to
setup the connection information again.
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, touch the
previously paired device (from the bottom of
the page).
3. Tap
OK
to confirm disconnection.
– or –
From the Bluetooth settings page, touch and
hold the name of the previously paired device,
and select
Disconnect
.
Note:
Disconnections are manually done but often occur
automatically if the paired device goes out of range of
your phone or it is powered off.
Deleting a Paired Bluetooth Device
Deleting a device from your list removes its
“connection record” and upon reconnection would
require that you re-enter all the previous pairing
information.
1. Verify Bluetooth is active.
2. From the Bluetooth settings page, touch and
hold the name of the previously paired device
(from the bottom of the page). This opens the
connected device’s menu options.
3. Tap
Unpair
to delete the paired device.
Sending Contacts via Bluetooth
Depending on your paired devices’ settings and
capabilities, you may be able to send pictures,
Contact information, or other items using a Bluetooth
connection.
Note:
Prior to using this feature, Bluetooth must first be
enabled on both your phone and the external device, and
the recipient’s device must be visible.
Only a Contact’s information can be sent via Bluetooth.
No other file type (video, image, or audio) can be sent
using Bluetooth.
1. Verify your Bluetooth is active and your phone
is visible.
2. From the Home screen, tap (
Contacts
).
3. Touch and hold the entry from the list to
display the on-screen context menu.
124
4. Tap
Send namecard via
➔
Bluetooth
and select
a paired external Bluetooth device.
Note:
The external Bluetooth device must be visible and
communicating for the pairing to be successful.
5. A Bluetooth share notification displays in your
notifications list.
Enable Downloading for Web
Applications
Important!:
Before you can download a web application you
must insert an SD into the phone and enable the
Unknown sources
feature (enables downloading).
For more information, refer to “Installing the
microSD Memory Card” on page 7. Also, see
“Mounting the SD Card” on page 38.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
.
2. Tap the
Unknown sources
check box.
3. Tap
OK
to allow install of non-Market
applications. Tap again to remove the
checkmark and disable the installation of non-
market applications.
Warning!:
Not all Web applications are safe to download. In
order to protect your phone and data, use Android
Market to install web applications. For more
information, refer to “Downloading a New Google
Application” on page 106.
PC Connections
You can connect your device to a PC using an optional
PC data cable using various USB connection modes.
Mass storage is the default connection method.
•
Mass storage
: allows you to use the onboard storage
capacity of the phone to store and upload files. This option
allows your computer to detect the phone as a removable
storage drive.
Connecting as a Mass Storage Device
You can connect your device to a PC as a removable
disk and access the file directory. If you insert a
memory card in the device, you can also access the
files directory from the memory card by using the
device as a memory card reader.
Note:
The file directory of the memory card displays as a
removable disk, separate from the internal memory.
1. Insert a memory card into the device to transfer
files from or to the memory card.
Note:
To use any downloaded market application that requires a
USB connection between your phone and your PC, you
should first set the USB setting to
Mass storage
.
2. Press to return to Idle mode.
3. Connect the multifunction jack on your device
to a PC using an optional PC data cable.
A pop-up window displays on the PC when
connected.
4. Open the folder to view files.
Connections 125
5. Copy files from the PC to the memory card.
Enabling USB Debugging
1. Press ➔ and then tap
(
Settings
) ➔
Applications.
2. Tap the
USB debugging
field to verify the
feature is active before connecting your USB
cable.
Wi-Fi
About Wi-Fi
Wi-Fi (short for "wireless fidelity") is a term used for
certain types of Wireless Local Area Networks
(WLAN). Wi-Fi communication requires access to an
existing and accessible Wireless Access Point (WAP).
These WAPs can either be Open (unsecured) as
within most Hot Spots, or Secured (requiring
knowledge of the Router name and password).
Note:
After you complete a connection to an active Wi-Fi
network, the Wi-Fi Calling feature will automatically be
enabled.
Activating Wi-Fi
By default, your device’s Wi-Fi feature is turned off
(deactivated). Activating Wi-Fi allows your device to
discover and connect to compatible in-range WAPs
(Wireless Access Points).
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Tap
Wi-Fi
to activate the feature. A checkmark
indicates that Wi-Fi is active. The device scans
for available in-range wireless networks and
displays them under Wi-Fi networks on the
same screen.
Connecting to a Wi-Fi Network
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
The network names and security settings
(Open network or Secured with WEP) of
detected Wi-Fi networks display in the Wi-Fi
networks section.
2. Tap the network you wish to connect to.
Note:
When you select an open network you are automatically
connected.
3. Enter a wireless password (if necessary).
Manually Add a New Network Connection
1. Tap
Add Wi-Fi network
.
2. Enter the Network SSID (the name of your
Wireless Access Point).
3. Tap the
Security
field and select a security
option. This must match the current security
setting on your target WAP.
126
4. Enter your WAP’s password if the WAP is
secure.
5. Tap
Save
to store the new information and
connect to the target WAP.
Note:
No prompt to enter the WAP key displays if this is the
second time to connect to a previously accessed or
secured wireless network. The WAP key is required when
the device is reset using factory default settings.
Deactivating Wi-Fi
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Tap the
Wi-Fi
field to deactivate the feature. The
checkmark grays.
Note:
Use of wireless data connections such as Wi-Fi and
Bluetooth can reduce battery life and use times.
Manually Scan for a Wi-Fi Network
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Press and then tap
Scan
.
Wi-Fi Status Indicators
The following icons indicate the Wi-Fi connection
status:
Displays when Wi-Fi is connected, active,
and communicating with a Wireless Access
Point (WAP).
Displays when Wi-Fi is active and there are
open networks available.
Wi-Fi Advanced Settings
The Wi-Fi settings - Advanced menu allows you to set
up many of the device’s Wi-Fi services, including:
•
Setting the Wi-Fi sleep policy
•
Viewing the device’s MAC Address
•
Configuring use of either a DHCP or Static IP
To access the Wi-Fi Advanced Settings menu:
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Press and then tap
Advanced
.
Mobile AP
This feature allows you to turn your phone into a Wi-Fi
hotspot. The feature works best when used in
conjunction with 3G data services.
Important!:
The Mobile AP service can not be active at the same
time as Wi-Fi. Please close your Wi-Fi connection
prior to launching the Mobile AP service.
To activate the Mobile AP service:
Connections 127
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Tethering and portable hotspot
.
2. Tap
Mobile AP
and place a checkmark in the
adjacent field to activate the service.
3. Tap
Mobile AP settings
➔
Configure mobile AP
and write down the Network SSID name. This
name is generally
AndroidAP
.
4. Confirm the Mobile AP service icon
appears at the top of the screen.
Note:
By default, the connection is open and not secured. It is
recommended that you access the Mobile AP settings
and create a secure connection by using a password for
communication.
Note:
Using your 3G service and Mobile AP Hotspot drains your
phone’s battery at a much faster rate than when using
any other feature combination.
The best way to keep using the phone as a hotspot is to
have it connected to a power supply.
To connect to the Hotspot:
1. Enable Wi-Fi (wireless) functionality on your
target device (laptop, media device, etc.).
2. Scan for Wi-Fi networks from the device and
select your phone hotspot from the network
list.
•
The default name for your phone’s hotspot is
AndroidAP
.
•
You can change the name by tapping
Configure
mobile AP
➔
Network SSID
and changing the
entry.
3. Select this Hotspot and follow your on-screen
instructions to complete the connection.
4. Launch your Web browser to confirm you have
an Internet connection.
To secure the Mobile AP service:
The two most common methods for securing your
connection to the Hotspot are to a security method
(WPA2 PSK) and to Hide your phone’s SSID name.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Tethering and portable hotspot
➔
Mobile AP
settings
➔
Configure mobile AP
.
2. Tap the
Security
field and select
WPA2 PSK
.
3. With security enabled, enter a new password
into the
Password
field.
Important!:
The more complex the password, the harder it will
be for intruders to break your security. It is
recommended that you not use names, birthdays,
or other personal information.
4. Tap
Save
to store the new settings.
128
Section 11: Time Management
This section describes how you can manage time
using time-related applications such as the Calendar,
Alarm Clock, Analog or Digital clock, and the World
clock.
Calendar
With the Calendar feature, you can consult the
calendar by day, week, or month, create events, and
set an alarm to act as a reminder.
1. From the Home screen, tap (
Applications
)
➔ (
Calendar
).
2. Press and select one of the following
options:
•Day
: displays the Day view.
•Week
: displays the Week view.
•Month
: displays the Month view.
• Agenda
: displays the List view. This view allows you
to search for events for the selected Month, Week, or
Day or you can look for events for a future date.
•Today
: displays only today’s events.
•More
: provides access to additional calendar
functions such as:.
–
Create
: creates a new Event.
–
Go to
: displays a specific date.
–
Calendars
: provides access to various calendar
accounts.
–
Settings
: displays a list of configurable settings.
Creating a Calendar Event
1. From the Home screen, tap (
Applications
)
➔ (
Calendar
).
2. From the Month tab, press ➔
More
➔
Create
.
– or –
Touch and hold an on-screen calendar day and
select
Create
.
Calendar Settings
Using the Calendar settings you can select the day
with which you want the calendar to begin. You also
select how you want to view the calendar, by Month,
Week, or Day or determine how to manage events,
notifications, sounds, and defaults reminders.
1. From the Home screen, tap (
Applications
)
➔ .
2. Press ➔
More
➔
Settings
.
3. Tap
Hide declined events
to activate this option.
A check mark indicates selection.
4. Tap
First day of week
and select either
Sunday
or
Monday
.
5. Tap
Set alerts and notifications
to adjust the
event notification method. Choose from:
Alert
,
Status bar notification
, and
Off
.
Time Management 129
6. Tap
Select ringtone
to assign a ringtone to a
calendar event notification.
7. Tap
Vibrate
to activate this notification option.
Selections are:
Always
,
Only in Silent mode
, or
Never
.
8. Tap
Default reminder time
to activate this event
reminder time value. Choose from:
1minute
,
5minutes
,
10 minutes
,
15 minutes
,
20 minutes
,
25 minutes
,
30 minutes
,
45 minutes
,
1 hour
,
2 hours
,
3 hours
,
12 hours
,
24 hours
,
2 days
, or
1 week
.
9. The
Build version
displays the current calendar
software version.
Clock
This feature allows you to create an alarm to ring at a
specified time, track time in other parts of the world,
use a stopwatch, or set a timer.
䊳
From the Home screen, tap
(
Applications
)
➔ (
Clock
).
Setting an Alarm
1. From the Home screen, tap
(
Applications
)
➔ (
Clock
) ➔ (
Alarm
).
2. Tap
(
Add alarm
).
3. Use the plus
or minus
symbols to
enter the
hour, and
minutes, then
tap
AM
or
PM
(toggles
depending on
which was
last selected)
and select
Set
.
4. Tap the
Repeat
field and select the number of
times you want this alarm to repeat. Selections
are:
Never
(no options selected) or choose any
of the available days. Tap each day of the week
in which you want this alarm to repeat, then
tap
OK
.
5. Tap the
Ringtone
field and select an audio
ringtone for this alarm. This can be used to
differentiate between various alarm events.
6. Tap the
Vibrate
field to activate a vibration
function to this alarm event.
Clock
Slideshow
Home
Music
130
7. Tap the
Label
field to assign a title to this alarm
event.
8. Tap
Done
to save the new alarm event.
To disable an existing alarm:
䊳
From the Alarms listing page, tap the alarm
clock icon to remove the green bar below it.
This green bar indicates the alarm event is
active.
To enable an existing alarm:
䊳
From the Alarms listing page, tap the alarm
clock icon to activate the green bar below it.
This green bar indicates the alarm event is
active.
Changing Your Settings 131
Section 12: Changing Your Settings
This section explains the sound and phone settings for
your phone. It includes such settings as: display,
security, memory, and any extra settings associated
with your phone.
Wireless and networks
Using Flight mode
Flight mode allows you to use many of your phone’s
features, such as Camera, Games, and more, when
you are in an airplane or in any other area where
making or receiving calls or data is prohibited.
Important!:
When your phone is in Airplane Mode, it cannot
send or receive any calls or access online
information or applications.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
.
2. Tap
Flight mode
. A check mark displayed next
to the feature indicates Flight mode is active.
Activating Wi-Fi
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Tap
Wi-Fi
. A check mark displayed indicates
Wi-Fi is active.
Wi-Fi settings
Once set up for Wi-Fi connectivity, your phone
automatically uses Wi-Fi, when available, for all your
mobile phone services.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Configure the settings as desired.
The available connection types displayed with a
security type displayed next to them.
Network Notification
By default, when Wi-Fi is on, you receive notifications
in the Status bar anytime your phone detects an
available Wi-Fi network. You can deactivate this
feature if you do not want to receive notifications.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Tap
Network notification
. A check mark
displayed next to the feature indicates Network
notification is active.
3. Tap
Network notification
again to remove the
check mark and deactivate this feature.
132
Manually Adding a Wi-Fi Network
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Wi-Fi
settings
.
2. Tap
Wi-Fi
to turn it on.
3. Tap
Add Wi-Fi network
.
4. Enter the SSID (Service Set Identifier) and
Security settings then tap
Save
.
Note:
An SSID is a unique key which identifies a wireless LAN.
Its purpose is to stop other wireless equipment from
accessing your LAN — whether accidentally or
intentionally. To communicate, wireless devices must be
configured with the same SSID.
Bluetooth settings
In this menu you can activate Bluetooth, view or
assign a device name, activate your phone so other
Bluetooth devices can discover it, or scan for other,
available Bluetooth devices with which to pair.
Activating Bluetooth
䊳
Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Bluetooth
settings
and tap
Bluetooth
to turn it on.
Note:
Bluetooth must be enabled prior to use.
Activating the Device Name
1. Activate Bluetooth.
2. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Bluetooth
settings
➔
Device name
. The assigned device
name displays.
3. Press to erase the current device name
and enter a new name for this device using the
keyboard.
4. Tap
OK
to confirm your setting.
Activating Visibility
䊳
Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Bluetooth
settings
➔
Visible
.
The phone is now activated for discovery for
119 seconds so you can pair with another
device. After 119 seconds the phone becomes
undiscoverable again.
Scanning for Devices
This option allows you to scan for active Bluetooth
devices so you can pair with them.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Bluetooth
settings
➔
Scan devices
. Your phone begins
scanning and lists any discovered devices in
the Bluetooth devices section.
Changing Your Settings 133
2. Tap a device name to pair with the device.
Important!:
Some Bluetooth devices are secured and require a
PIN number to confirm and pair with them.
3. Enter a PIN to pair with the device, if one is
required, and tap
OK
.
Tethering
This option allows you to share your phone’s mobile
data connection via a direct USB connection between
your phone and computer. A wireless version of this
same functionality would be the Mobile AP feature.
Note:
You can not mount your phone’s microSD card to your
computer while using the USB tethering feature. If
additional software or USB drivers are required, navigate
to: http://www.samsung.com/us/support/downloads.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Tethering and portable hotspot
.
2. Plug in the USB cable between your computer
and your phone.
3. When prompted for a USB mode, press to
exit the menu.
4. Tap
USB tethering
from the Tethering menu.
This places a green check mark next to the
entry and activates the feature. A Tethering or
Hotspot active notification briefly appears on
the screen. Look for the Tethering active icon
in the Status bar area of the screen.
To disconnect tethering:
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Tethering and portable hotspot
.
2. Tap
USB tethering
from the Tethering menu to
remove the check mark and deactivate the
feature.
3. Remove the USB cable from the phone.
Mobile AP
For more information, refer to “Mobile AP” on
page 126.
VPN settings
The VPN settings menu allows you to set up and
manage Virtual Private Networks (VPNs).
Important!:
Before you can use a VPN you must establish and
configure one.
134
Adding a VPN
Before you add a VPN you must determine which VPN
protocol to use: PPTP (Point-to-Point Tunneling
Protocol), L2TP (Layer 2 Tunneling Protocol), L2TP/
IPSec PSK (Pre-shared key based L2TP/IPSec), or
L2TP/IPSec CRT (Certificate based L2TP/IPSec).
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
VPN
settings
.
2. Tap
Add VPN
.
To establish a PPTP (Point-to-Point Tunneling Protocol):
1. Establish a VPN name (a name for this
connection).
2. Set the VPN server.
3. Enable encryption (if desired).
4. Set the DNS search domains.
To establish a L2TP (Layer 2 Tunneling Protocol):
1. Establish a VPN name (a name for this
connection).
2. Set the VPN server.
3. Enable L2TP secret.
4. Set L2TP secret.
5. Set the DNS search domains.
To establish a L2TP/IPSec PSK (Pre-shared key based
L2TP/IPSec):
1. Establish a VPN name (a name for this
connection).
2. Set the VPN server.
3. Set IPSEc pre-shared key.
4. Enable L2TP secret.
5. Set L2TP secret.
6. Set the DNS search domains.
To establish a L2TP/IPSec CRT (Certificate based L2TP/
IPSec):
1. Establish a VPN name (a name for this
connection).
2. Set the VPN server.
3. Enable L2TP secret.
4. Set L2TP secret.
5. Set user certificate.
Note:
A user certificate must be installed to use this setting.
6. Set CA certificate.
Note:
A CA certificate must be installed to use this setting.
7. Set the DNS search domains.
Changing Your Settings 135
Mobile networks
Before you use applications such as Google Maps
and find your location or search for places of interest,
you must enable the Mobile networks options.
䊳
Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
.
The following options display:
Use packet data
Allows you to activate data usage on your phone.
䊳
Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
➔
Use packet data
.
Data Roaming
Data roaming allows you to connect to your service
provider’s partner networks and access data services
when you are out of your service providers area of
coverage.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
.
2. Tap
Data roaming
to connect to data services
while roaming outside your network.
– or –
Tap
Data roaming
again to remove the green
checkmark and deactivate the feature.
Access Point Names
To use Wi-Fi you need access to a wireless access
point (hotspot).
䊳
Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
➔
Access Point Names
. A list of the
Access point names display. The active access
point displays a bright green, filled circle to the
right of the name.
Using the 2G (EDGE) Network
If you are not using applications that require the 3G
network speed (any application that accesses the
network or uses a browser), using the 2G network
saves battery life.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
.
2. Tap
Use only 2G networks
. A check mark
displays next to this option to indicate that it is
active.
Note:
Connecting to 2G networks slows the data transfer speed
and time.
136
Using the 3G Network
If you are using applications that require the 3G
network speed, follow these instructions to reactivate
your 3G network connection.
By default, your phone uses 3G communication. If
your phone is ever set to use 2G communication, you
can reset it using these steps:
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
.
2. Remove the checkmark from the
Use only 2G
networks
field. Deactivating this feature
resumes 3G communication.
Network Operators
Using this feature you can view the current network
connection. You can also scan and select a network
operator manually, or set the network selection to
Automatic.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
.
2. Tap
Network operators
. The current network
connection displays at the bottom of the list.
Important!:
You must deactivate data service prior to searching
for an available network.
3. Tap
Search now
to manually search for a
network.
4. Tap
Select automatically
to automatically select
a network connection.
Note:
Connecting to 2G networks slows the data transfer speed
and time.
Default Setup Options
Your phone default is set to Automatic (to
automatically search for an available network. You
can set this option to Manual to select a network each
time you connect.
1. Press ➔ and then tap
(
Settings
) ➔
Wireless and networks
➔
Mobile
networks
➔
Network operators
.
2. Tap
Default Setup
.
3. Tap
Manual
to locate and connect to a network
manually.
– or –
Tap
Automatic
to allow the device to
automatically select a network.
Call Settings
To access the Call settings menu:
䊳
Press ➔ and then tap
(
Settings
) ➔
Call settings
.
– or –
From the Home screen, tap ➔
Settings
➔
Call settings
.
Changing Your Settings 137
Fixed Dialing Numbers
Fixed Dial Number (FDN), allows you to restrict
outgoing calls to a limited set of phone numbers.
Enabling FDN
1. Press ➔ and then tap
(
Settings
) ➔
Call settings
➔
Fixed Dialing
Numbers
.
2. Tap
Enable FDN
.
3. At the prompt, enter your PIN2 code and tap
OK
.
Important!:
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
an incorrect PIN2 code could cause the phone to
lock. Contact customer service for assistance.
Changing the PIN2 Code
1. Press ➔ and then tap
(
Settings
) ➔
Call settings
➔
Fixed Dialing
Numbers
.
2. Tap
Change PIN2
.
3. At the prompt, enter your old PIN2 code.
4. At the prompt, enter a new PIN2 code.
5. Confirm your PIN2 code.
Important!:
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
an incorrect PIN2 code could cause the phone to
lock. Contact customer service for assistance.
Managing the FDN List
When this feature is enabled, you can make calls only
to phone numbers stored in the FDN list on the SIM
card.
1. Press ➔ and then tap
(
Settings
) ➔
Call settings
➔
Fixed Dialing
Numbers
.
2. Tap
Enable FDN
.
3. At the prompt, enter your PIN2 code and tap
OK
.FDN is enabled.
4. Tap
FDN list
then press and then tap
Add
contact
or edit the contacts that were stored.
Important!:
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
an incorrect PIN2 code could cause the phone to
lock. Contact customer service for assistance.
138
Voicemail
You can view your voicemail number from this menu.
1. Press ➔ and then tap
(
Settings
) ➔
Call settings
.
2. Tap
Voicemail service
and select
My carrier
.
3. Tap
Voicemail number
to now view your number
within the Voicemail number field.
HAC Mode
This menu is used to activate or deactivate Hearing
Aid Compatibility for this device.
1. Press ➔ and then tap
(
Settings
) ➔
Call settings
➔
HAC mode
.
2. Tap
On
to activate the feature, or
Off
to
deactivate the feature. Off is the default setting.
Configuring Call Forwarding
䊳
Press ➔ and then tap
(
Settings
) ➔
Call settings
➔
Call forwarding
.
Call forwarding
configures the following call
forwarding options:
–
Always forward
: incoming calls are re-routed to a
secondary number that you specify.
–
Forward when busy
: forwards all your calls to
voicemail when your phone is busy.
–
Forward when unanswered
: automatically forwards
to your voicemail number when the phone is not
answered, and otherwise allows you to enter a voicemail
number.
–
Forward when unreachable
: automatically forwards
to your voicemail number when the phone is not in
service, or is turned off.
Configuring Additional Call Settings
Configure additional call settings using this option.
1. Press ➔ and then tap
(
Settings
) ➔
Call settings
➔
Additional settings.
2. Tap one of the following options:
•Caller ID
: configures the way your outgoing calls are
displayed. Choose from Network default, Hide
number, or Show number.
• Call waiting
: enables call waiting functionality. When
deactivated, all incoming calls are directed to your
voicemail if you are already on an active call.
Sound Settings
From this menu you can control the sounds on the
phone as well as configure the display settings.
䊳
Press ➔ and then tap
(
Settings
) ➔
Sound
.
The following options display:
Silent mode
Silent mode is convenient when you wish to stop the
phone from making noise, in a theater for example. In
Silent Mode the speaker is muted and the phone only
vibrates to notify you of incoming calls, or other
functions that normally have a defined tone or sound
as an alert.
1. Press ➔ and then tap
(
Settings
) ➔
Sound
.
Changing Your Settings 139
2. Tap
Silent mode
.
– or –
From the Home screen, press and hold the
Lock
key until
Phone options
displays then tap
Silent mode
to activate or deactivate this mode
(the current mode displays).
Setup Phone Vibration
1. Press ➔ and then tap
(
Settings
) ➔
Sound
2. Tap
Vibrate
and select a vibration mode.
Choose from:
Always
,
Never
,
Only in Silent
mode
, or
Only when not in Silent mode
.
Note:
The Phone vibrate setting is independent of other call
sounds settings. For example, if you have Silent mode
enabled with Phone vibrate, your phone won’t play a
ringtone, but will vibrate for an incoming call.
Adjusting the Volume Settings
The Volume menu now provides access to various
volume settings within one on-screen popup menu.
1. Press ➔ and then tap
(
Settings
) ➔
Sound
➔
Volume
.
2. Touch and drag the on-screen slider to assign
the volume settings for any of the following
volume levels.
• Ringtone
,
Media
,
Alarm
,
System volume
, or
Notification
.
3. Tap
OK
to assign the volume levels.
Setup the Voice Call Ringtone
1. Press ➔ and then tap
(
Settings
) ➔
Sound
.
2. Tap
Phone ringtone
.
3. Tap a ringtone from the available list. The
ringtone briefly plays when selected.
4. Tap
OK
to assign a ringer.
Setting a Notification Ringtone
1. Press ➔ and then tap
(
Settings
) ➔
Sound
➔
Notification ringtone
.
2. Tap one of the ringtones and tap
OK
.
Audible Tone Settings
The Audible touch tones and Audible selection
options are used when you use the dialing pad or
making a screen selection. Each time you press a key
or make a selection the selected tone sounds.
1. Press ➔ and then tap
(
Settings
) ➔
Sound
.
2. Tap
Audible touch tones
or
Audible selection
. A
check mark displayed next to these features
indicates active status.
140
Screen Lock Sounds
The screen lock sounds option is used to activate/
deactivate sounds when locking and unlocking the
screen.
1. Press ➔ and then tap
(
Settings
) ➔
Sound
.
2. Tap
Screen lock sounds
. A check mark
displayed next to these features indicates
active status.
Display Settings
In this menu, you can change various settings for the
display such as the font, orientation, pop-up
notifications, puzzle lock feature, animation,
brightness, screen timeout, power saving mode, and
tv out settings.
䊳
Press ➔ and then tap
(
Settings
) ➔
Display
. The following options
display:
• Wallpapers
: assigns either the Home screen or Lock
screen wallpaper images.
•Font style
: sets the fonts used on the LCD display.
Selections are: Default font. Tap
Get fonts online
to
download additional fonts.
• Brightness
: configures the LCD Brightness levels.
Move the slider to adjust the brightness level.
• Auto-rotate screen
: when enabled, the phone
automatically switches from portrait to landscape
orientation and vice versa. When this setting is
disabled, the phone displays in portrait mode only.
•Animation
: determines whether some or all of the
window elements animate. Selections are: No
animations, Some animations, or All animations.
• Screen timeout
: adjusts the delay time before the
screen automatically turns off. Selections are: 15
seconds, 30 seconds,
1 minute, 2 minutes, 10 minutes, and 30 minutes.
• Horizontal calibration
: uses the accelerometer to
calibrate the phone when held in a horizontal position.
Horizontal Calibration
Calibrate your phone by using the built-in
accelerometer.
1. Press ➔ and then tap
(
Settings
) ➔
Display
➔
Horizontal calibration
.
2. Place the phone on a level surface and tap
Calibrate
. The phone adjusts the level of the
accelerometer. During the calibration process a
green circle appears on-screen and the center
circle adjusts to the center position.
Location and Security
The Location and Security settings allow you to
configure phone location and security settings.
Using Wireless Networks
Before you use applications such as Google Maps and
find your location or search for places of interest, you
must enable the Use wireless networks option or
enable the GPS satellites.
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
Changing Your Settings 141
2. Tap
Use wireless networks
to enable location
information using the wireless network.
Enabling the GPS Satellites
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Use GPS satellites
enable the GPS satellite.
Screen Unlock Pattern Settings
To secure data and limit phone access, set the phone
to require a screen unlock pattern each time you turn
on the device, or every time the phone wakes up
from sleep mode (when the screen automatically
turns off).
Setting an Unlock Pattern
Creating a screen unlock pattern increases security
on the phone. When you enable the User visible
pattern field, you will draw an unlock pattern on the
screen whenever you want to unlock the phone’s
buttons or touch screen. When you activate the User
tactile feedback field, you feel vibration as feedback
while drawing the pattern.
Note:
Make sure the Require Pattern field is activated.
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Set screen lock
➔
Pattern
.
3. Read the instructions then tap
Next
.
4. Review the onscreen animation procedure for
drawing a pattern and tap
Next
when you are
ready to draw a pattern.
5. Draw your pattern by touching your first
on-screen point. Then,
without removing your
finger from the screen, drag your finger over
adjacent points until the gray trace line overlaps
each point
and they are highlighted with a
green circle.
6. When you have connected at least four dots in
a vertical, horizontal or diagonal direction, lift
your finger from the screen and tap
Continue
.
7. Confirm the new pattern by redrawing it and
then tapping
Confirm
. The Unlock pattern is
set.
Changing the Screen Lock Pattern
This feature allows you to change the previously
stored unlock pattern and update it if necessary. This
process is similar to changing your password from
time to time.
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Set screen lock
➔
Change screen lock
.
3. Retrace your current pattern on the screen.
4. Tap
Pattern
and repeat steps 3 - 7 from the
previous section.
142
Using Visible a Pattern
When enabled, this feature displays the onscreen lock
grid that is used to unlock the phone.
PIN Lock and Unlock
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Set screen lock
.
3. Tap
PIN
.
4. Enter a PIN number using the numeric keypad
and touch
Continue
to confirm the password.
5. Confirm the PIN by re-entering it and tap
OK
to
confirm.
Your phone now requires you to enter this PIN
number in order to unlock the phone.
Password Lock and Unlock
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Set screen lock
.
3. Tap
Password
.
4. Enter a password using the keypad and tap
Continue
to confirm the password.
5. Confirm the password by re-entering it and tap
OK
to confirm.
Setting up SIM Card Lock
Prevent another user from using your SIM card to
make unauthorized calls or from accessing
information stored on your SIM card by protecting the
information using a PIN code.
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Set up SIM card lock
.
3. Tap
Lock SIM card
, enter your SIM PIN code,
then tap
OK
.
Note:
You must activate Lock SIM card before you can change
your SIM PIN code.
To change an existing SIM Card PIN:
1. Tap
Change SIM PIN
.
2. Enter the old SIM PIN code and tap
OK
.
3. Enter the new SIM PIN code and tap
OK
.
4. Re-type the new SIM PIN code and tap
OK
.
Password Settings
When you create a phone password you can also
configure the phone to display the password as you
type it instead of using an asterisk (*).
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Visible passwords
to activate this feature.
Changing Your Settings 143
Device Administration
Activating this feature allows Google to administrate
your phone in a way similar to IT security settings on
a corporate PC. This would be beneficial in the case
that your phone was lost or stolen. The phone could
be “deactivated” or “restricted” (through
administration) from a remote location.
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Select device administrators
to begin
configuring this setting.
3. Select an administrator device and follow the
prompts.
Credential Storage
This option allows certain applications to access
secure certificates and other credentials. Certificates
and credentials can be installed to the SD card and
password protected.
1. Press ➔ and then tap
(
Settings
) ➔
Location and security
.
2. Tap
Use secure credentials
to activate this
feature. A check mark displayed next to the
feature indicates secure credentials is active.
3. Tap
Install from SD card
to install encrypted
certificates from the memory (SD) card.
4. Tap
Set password
to set or change the
credential storage password.
5. Tap
Clear storage
to clear the storage (SD card
or phone memory) of all contents and reset the
credentials password.
Applications
This phone can be used for Android development. You
can write applications in the SDK and install them on
this device, then run the applications using the
hardware, system, and network. This feature allows
you to configure the device for development.
Warning!:
Android Dev Phones are not intended for non-
developer end-users. Because the device can be
configured with system software not provided by or
supported by Google or any other company, end-
users operate these devices at their own risk.
Unknown Sources
Before you can download a web application you must
enable the Unknown sources feature (enables
downloading). Developers can use this option to
install non-Market applications.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
.
2. Tap
Unknown sources
to active this feature.
Note:
If you are notified that you can not download a Market
application because it comes from an “Unknown
source”, enabling this option corrects this issue.
144
Managing Applications
This feature allows you to manage installed
applications. You can view and control currently
running services, or use the device for application
development.
You can also view the amount of memory or resources
used as well as the remaining memory and resources
for each of the applications on your phone and clear
the data, cache, or defaults.
䊳
Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Manage
applications
.
Clearing Application Cache and Data
Important!:
You must have downloaded applications installed to
use this feature.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Manage
applications
.
2. Tap the
Downloaded
tab and select your desired
application.
3. Tap
Force stop
,
Clear data
,
Clear cache
,
Clear
defaults
, or
Show all
.
Uninstalling Third-party Applications
Important!:
You must have downloaded applications installed to
use this feature.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Manage
applications
.
2. Tap the
Downloaded
tab and select your desired
application.
3. Tap
Uninstall
(from within the top area of the
Application info page).
4. At the prompt, tap
OK
to uninstall the
application.
5. Select a reason for uninstalling the application,
then tap
OK
.
Moving Third-party Applications to your SD Card
Your phone’s built in memory is augmented by using a
microSD card to store additional data. When the
phone’s built-in memory capacity is reached, it can be
possible to move some applications over to the
internal microSD card. Freeing up memory space on
the phone can help avoid any sluggish performance
when the phone has to work harder to manage
memory resources.
Since there is a limited amount of on-board memory,
it is recommended that you move your applications to
the internal SD card when possible.
Changing Your Settings 145
Important!:
Only certain downloaded applications are capable
of being moved from phone to card.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Manage
applications
.
2. Tap the
Downloaded
tab and select your
desired application.
3. Tap
Move to SD card
(from within the Storage
section of the Application info page).
Once the application has been moved to the microSD
card, this button now reads “Move to phone”.
Running Services
The Running services option allows you to view and
control currently running services such as Backup,
Google Talk, SNS (messaging), Swype, and more.
1. Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Running services
The screen displays all the processes that are
running.
2. Tap a process to stop the process from
running.
When you stop the process the service or
application will no longer run until you start the
process or application again.
Important!:
Stopping a process might have undesirable
consequences on the application.
Android Development
䊳
Press ➔ and then tap
(
Settings
) ➔
Applications
➔
Development
.
Important!:
These features are used for development purposes
only.
USB Debugging
This feature is used for development purposes and
for use with the Kies mini software. For more
information, refer to “PC Connections” on page 124.
Stay awake
This feature is used to set the screen to never go into
sleep mode while the phone is charging.
Allowing Mock Locations
This feature is used for development purposes only.
If you are a developer who is testing a GPS
applications using this device, you can tell the device
that the phone is at different GPS locations. In other
words, the phone is allowed to “mock” the
coordinates.
146
Accounts and Synchronization
Your phone provides the ability to synchronize data
from a variety of different sources or sites. These
accounts can range from Google, a Corporate
Microsoft Exchange Email Server, and other social
sites such as Facebook, Twitter, and MySpace.
Corporate and Google accounts provide the ability to
synchronize Calendar events and Contacts.
To enable the auto-sync feature:
1. Press ➔ and then tap
(
Settings
) ➔
Accounts and sync
.
2. Tap
Auto-sync
. A green checkmark indicates
the feature is enabled. This feature enables the
synchronization of data between your phone
and external sites or servers.
•
The three main components are Contacts Email, and
Calendar Events. Before these can be synchronized,
they must be added to the managed accounts list.
• Background data
: allows your phone to use data in
the background.
Synchronizing a Google Account
By default, there are no accounts managed by the
device. These must be manually added.
To manage an existing Google account
:
1. Press ➔ and then tap
(
Settings
) ➔
Accounts and sync
.
2. Tap
Add account
➔
Google
.
3. Tap
Next
➔
Sign in
.
Note:
If you do not already have a Google account, tap
Create
and follow the on-screen prompts to create your new
account.
4. Touch the
Username
(@gmail.com) and
Password
fields and enter your information.
5. Tap
Sign in
. Your phone then communicates
with the Google servers to confirm your
information. Your existing Gmail account then
appears within the
Manage accounts
area of the
screen.
•
Any changes or updates to your Gmail account are
then automatically updated to your device.
To configure the Google management settings:
1. Press ➔ and then tap
(
Settings
) ➔
Accounts and sync
.
2. Tap within the Google account field to
reveal the account’s synchronization settings
screen.
3. Tap the parameters you wish to synchronize
(
Sync Contacts
,
Sync Gmail
, or
Sync Calendar
). A
green checkmark indicates the feature is
enabled.
4. Press to return to the previous screen.
For more information, refer to “Synchronizing
Contacts” on page 71.
Changing Your Settings 147
Synchronizing Your Corporate Account
By default, there are no Corporate Calendar events
managed by the device. These must be manually
added.
Note:
Once a corporate email account is created, it is
automatically added as a managed account.
Use the following procedure to configure your phone
to synchronize with a corporate email account.
1. From the Home screen, tap
(
Applications
)➔
Settings
➔
Accounts and sync
.
– or –
Press ➔ and then tap
(
Settings
) ➔
Accounts and sync
.
2. Locate the email account containing the events
you wish to synchronize.
3. Tap within the adjacent account field to
reveal the account’s synchronization settings
screen.
4. Toggle the check mark adjacent to either the
Sync Contacts or Sync Calendar fields to
manually sync the account.
Privacy Settings
Location settings, backup configurations, or reset the
phone to erase all personal data.
䊳
Press ➔ and then tap
(
Settings
) ➔
Privacy
.
Mobile Backup and Restore
The phone can be configured to back up your current
settings, application data and settings.
1. Press ➔ and then tap
(
Settings
) ➔
Privacy
.
2. Tap
Back up my data
to create a backup of your
current phone settings and applications.
3. Tap
Automatic restore
to assist in the re-
installation of a previously installed application
(including preferences and data).
Factory Data Reset
From this menu you can reset your phone and sound
settings to the factory default settings.
1. Press ➔ and then tap
(
Settings
) ➔
Privacy
. (You will see a disclaimer.)
2. Touch
Factory data reset
➔
Reset
phone.
3. If necessary, enter your password and touch
Erase everything
.
The phone resets to the factory default settings
automatically and when finished displays the
Home screen.
148
SD Card & Phone Storage
From this menu you can view the memory allocation
for the memory card as well as mount or unmount the
SD card.
For more information about mounting or unmounting
the SD card, see “Using the SD Card” on page 37.
To view the memory allocation for your external SD
card:
䊳
Press ➔ and then tap
(
Settings
) ➔ SD card and phone storage.The
available memory displays under the Total
space and Available space headings.
Search Settings
You can use your phone's search preferences to
configure some aspects of Google Web search (for
example, whether it makes suggestions below the
Quick Search Box as you type), and what phone
features you want to include in searches.
1. Press ➔ and then tap
(
Settings
) ➔
Search
.
2. Tap any of the following search parameters to
then alter the settings:
• Google search
opens a screen where you can set
your Google search preferences.
–
Show web suggestions
: includes search matches
from Google’s online search engine.
–
Use My Location
: uses your My Location information
for Google search results and services.
–
Search history
: determines whether you also wish to
included personalized search history results in the list of
matches.
–
Manage search history
: helps to manage the
personalized search history associated with your current
registered Google account.
• Searchable items
: opens a screen where you can
choose the search categories included in device
searches. such as:
Web, Apps
,
Contacts
,
Memo,
Messaging, Music
,
or
Voice Search
.
• Clear shortcuts
: erases the history for recently
selected search results.
Language & Keyboard Settings
This setting allows you to configure the language in
which to display the menus. You can also set on-
screen keyboard options.
䊳
Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
.
Language Settings
To set the language that the menus display on the
phone:
1. Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
➔
Select
language
.
2. Select a language and region from the list.
Changing Your Settings 149
Select Input Method
There are two input methods available: Swype and
Samsung keypad.
1. Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
➔
Select
input method
.
2. Select an input method.
Swype Settings
For more information, refer to “SWYPE Settings” on
page 54.
1. Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
➔
Swype
.
2. Tap one of the following Swype preferences to
activate the setting:
• Language
: allows you to select the current text input
language. Default language is US English.
• Word prediction
: uses a built-in word database to
predict words while entering text in Swype.
• Audio feedback
: turns off sounds generated by the
Swype application.
• Enable tip indicator
: turns on an on-screen flashing
indicator that provides helpful user information.
Swype Advanced settings
Advanced settings provide access to Swype
operation parameters.
•Auto-spacing
: automatically inserts a space
between words. When you finish a word, just lift your
finger or stylus and start the next word.
• Auto-capitalization
: automatically capitalizes the
first letter of a sentence.
• Show complete trace
: determines whether or not to
display the complete Swype trace path on-screen.
• Word choice window
: sets the amount of times the
word choice selection window displays on screen.
Move the slider between Never or Always and tap
OK
.
• Speed vs. accuracy
: sets how quickly Swype
responds to on-screen input. Move the slider
between Fast Response (speed) or Error Tolerant
(accuracy) and tap
OK
.
Swype Help settings
Help settings provide access to Swype help operation
parameters.
• Swype help
: displays the on-screen Swype User
Manual.
•Tutorial
: provides an on-screen tutorial that shows
you how to input text faster in Swype input mode.
About
Provides information about the current Swype
application version.
Samsung Keyboard Settings
For more information, refer to “Using the Samsung
Keypad” on page 57.
1. Press ➔ and then tap
(
Settings
) ➔
Language and keyboard
➔
Samsung keypad
.
150
2. Tap
Portrait Keypad types
and select a text input
method:
•
Qwerty Keypad
•
3x4 Keypad
3. Tap
Input languages
and select a language.
4. Tap
XT9
to use XT9 Predictive text method. For
more information, refer to “Text Input Methods”
on page 53.
5. Tap the
Keypad sweeping
field if you want to
sweep the keypad and change from
ABC
to
?123
mode. For more information, refer to “Text
Input Methods” on page 53.
6. Tap the
Auto-capitalization
field to
automatically capitalize the first letter of a
sentence.
7. Tap
Voice input
to activate the Voice input
feature. This is an experimental feature that
uses Google’s networked speech recognition
application.
8. Tap
Auto-full stop
to automatically insert a full
stop by tapping the space bar twice.
9. Tap the
Tutorial
field to view a short tutorial on
use of the Samsung keyboard.
XT9 Advanced Settings
The following XT9 Advanced settings are available
when the XT9 field is selected.
1. Tap the
XT9
field to select XT9 (predictive text)
mode, then tap
XT9 advanced settings
.
2. Tap the
Word completion
field to enable word
completion. Your phone predicts how to
complete the word typed.
3. Tap the
Word completion point
field then tap
2 letters
,
3 letters
,
4 letters
, or the
5 letters
radio
button. Word completion begins after 2 or more
(depending on your selection).
4. Tap the
Spell correction
field. This option
corrects typographical errors by selecting from
a list of possible words that reflect the
characters of the keys you touched as well as
the characters of nearby keys.
5. Tap the
Next word prediction
field to enable
word prediction.
6. Tap the
Auto-append
field to automatically add
predictions.
7. Tap the
Auto-substitution
field to automatically
replace words that you are typing. This option
assists with correcting misspelled words.
Changing Your Settings 151
8. Tap the
Regional correction
field. This option
sets the device to automatically correct
mistyped words according to normal spelling
for your region.
9. Tap the
Recapture
field. This option sets the
device to re-display the word suggestion list
when you select the wrong word from the list.
10. To add a new word to the T9 dictionary:
Tap the
XT9 my words
field, then press
and then tap
Add
. Enter the new word in the
Register to XT9 my words
field, then tap
Done
.
11. Tap
XT9 auto-substitution
to add words to
substitute (for example youve becomes
you’ve). A list of substitutions displays.
12. If you do not see the substitution you want,
press and then tap
Add
, then input the
Shortcut word and Substitution word.
13. Tap
Done
.
Voice Input and Out Settings
Configuring Voice Input Recognition
This feature allows the phone to correctly recognize
verbal input.
1. Press ➔ and then tap
(
Settings
) ➔
Voice input and output
➔
Voice
recognition settings
.
2. Configure the available options to alter the
settings associated with this feature:
• Language
: selects an input language and associated
dialect recognition (if available).
• SafeSearch
: sets the explicit image filter settings.
These settings apply to only Google voice search
results. Choose from:
Off
,
Moderate
, or
Strict
.
• Block offensive words
: allows you to block
recognition of known offensive words or language. (A
green check mark indicates the feature is active).
• Show hints
: displays hints on a search box.
3. Press to return to the previous screen.
Configuring Text-to-speech
This feature allows the phone to provide a verbal
readout of on-screen data such as messages and
incoming caller information.
1. Press ➔ and then tap
(
Settings
) ➔
Voice input and output
➔
Text-to-speech settings
.
2. Configure the available options to alter the
settings associated with this feature:
• Listen to an example
: plays a short example of what
the text-to-speech feature sounds like on your device
when activated.
• Always use my settings
: accepts an override of
application settings with personal configurations for
this text-to-speech settings screen. If enabled, your
device defaults to using the text-to-speech feature.
152
• Default engine
: sets the speech synthesis engine that
will be used for the spoken text. Choices include:
Pico
TTS
.
• Install voice data
: assists in installation of voice data
applications necessary for voice synthesis.
• Speech rate
: adjusts the rate at which on-screen text
is spoken by the device. Choose from:
Very slow
,
Slow
,
Normal
,
Fast
, and
Very fast
.
• Language
: assigns the language used for verbal
readout. Choose from American English or Spanish.
• Pico TTS
: configures the pico TTS settings for various
languages.
Accessibility Settings
This service is able to collect all the text you type,
including personal data credit card numbers except
passwords. It may also log your user interface
interactions. It comes from the applications such as
KickBack, SoundBack, and TalkBack.
1. Press ➔ and then tap
(
Settings
) ➔
Accessibility
.
2. Tap
OK
if prompted to install a screen reader
from the Android market.
Note:
Initially, it might be necessary to download accessibility
applications from the Android Market (ex: TalkBack).
3. Tap
Accessibility
to activate the feature, then
select the services for which you want data to
log.
4. Select
The power key ends calls
field to activate
this feature which ends any current calls.
Date and Time
This menu allows you to change the current time and
date displayed.
1. Press ➔ and then tap
(
Settings
) ➔
Date and time
.
2. Tap
Automatic
to allow the network set the date
and time.
Important!:
Deactivate
Automatic
to manually set the rest of the
options.
3. Tap
Set date
and use the plus or minus icons to
set the
Month
,
Day
, and
Year
then touch
Set
.
4. Tap
Select time zone
, then touch a time zone.
5. Tap
Set time
and use the plus or minus icons,
set
Hour
, and
Minute
. Touch
PM
or
AM
, then tap
Set
.
•
Optional: Tap
Use 24-hour format
. If this is not
selected the phone automatically uses a 12-hour
format.
6. Tap
Select date format
and touch the date
format type.
Changing Your Settings 153
About Phone
This menu contains legal information, system tutorial
information, and other phone information such as the
model number, firmware version, baseband version,
kernel version, and software build number.
To access phone information:
䊳
Press ➔ and then tap
(
Settings
) ➔
About phone
. The following
information displays:
•Status
: displays the battery status, the phone
number for this device, the network connection,
signal strength, mobile network type, service state,
roaming status, mobile network state, IMEI number,
IMEI SV, Wi-Fi MAC address, Bluetooth address, and
Up time.
•Battery use
: displays the applications or services (in
percentages) that are using battery power.
• Legal information
: This option displays information
about Open source licenses as well as Google legal
information. This information clearly provides
copyright and distribution legal information and facts
as well as Google Terms of Service, Terms of Service
for Android-powered Phones, and much more
pertinent information as a reference.
Read the information and terms, then press to
return to the Settings menu.
• System tutorial
: provides a quick, online tutorial that
walks you through basic phone features. Read the
on-screen information and follow the system
prompts.
• Model number
: displays the phone’s model number.
• Android version
: displays the firmware version
loaded on this handset.
• Baseband version
: displays the baseband version
loaded on this handset.
•Kernel version
: displays the kernel version loaded on
this handset.
• Build number
: displays the software, build number.
Note:
Firmware, baseband, kernal and build numbers are
usually used for updates to the handset or support. For
additional information please contact your T-Mobile
service representative.
Software Update
The Software Update feature enables you to use your
phone to connect to the network and upload any new
phone software directly to your phone. The phone
automatically updates with the latest available
software when you access this option.
䊳
Press ➔ and then tap
(
Settings
) ➔
Software update
.
The phone automatically updates the software
(if available).
154
Section 13: Health and Safety Information
This section outlines the safety precautions
associated with using your phone. The terms “mobile
device” or “cell phone” are used in this section to
refer to your phone.
Read this information before using
your mobile device
.
Exposure to Radio Frequency (RF)
Signals
The U.S. Food and Drug Administration (FDA) has
published information for consumers relating to Radio
Frequency (RF) exposure from wireless phones. The
FDA publication includes the following information:
Do cell phones pose a health hazard?
Many people are concerned that cell phone radiation
will cause cancer or other serious health hazards. The
weight of scientific evidence has not linked cell
phones with any health problems.
Cell phones emit low levels of Radio Frequency (RF)
energy. Over the past 15 years, scientists have
conducted hundreds of studies looking at the
biological effects of the radio frequency energy
emitted by cell phones. While some researchers have
reported biological changes associated with RF
energy, these studies have failed to be replicated. The
majority of studies published have failed to show an
association between exposure to radio frequency
from a cell phone and health problems.
The low levels of RF cell phones emit while in use are
in the microwave frequency range. They also emit RF
at substantially reduced time intervals when in the
stand-by mode. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to
low level RF that does not produce heating effects
causes no known adverse health effects.
The biological effects of radio frequency energy
should not be confused with the effects from other
types of electromagnetic energy.
Very high levels of electromagnetic energy, such as is
found in X-rays and gamma rays, can ionize biological
tissues. Ionization is a process where electrons are
stripped away from their normal locations in atoms
and molecules. It can permanently damage biological
tissues including DNA, the genetic material.
The energy levels associated with radio frequency
energy, including both radio waves and microwaves,
are not great enough to cause ionization of atoms and
molecules. Therefore, RF energy is a type of non-
ionizing radiation. Other types of non-ionizing
radiation include visible light, infrared radiation (heat),
and other forms of electromagnetic radiation with
relatively low frequencies.
While RF energy does not ionize particles, large
amounts can increase body temperatures and cause
tissue damage. Two areas of the body, the eyes and
the testes, are particularly vulnerable to RF heating
because there is relatively little blood flow in them to
carry away excess heat.
Health and Safety Information 155
Research Results to Date: Is there a connection
between RF and certain health problems?
The results of most studies conducted to date say no.
In addition, attempts to replicate and confirm the few
studies that have shown a connection have failed.
The scientific community at large therefore believes
that the weight of scientific evidence does not show
an association between exposure to Radio Frequency
(RF) from cell phones and adverse health outcomes.
Still the scientific community has supported
additional research to address gaps in knowledge.
Some of these studies are described below.
Interphone Study
Interphone is a large international study designed to
determine whether cell phones increase the risk of
head and neck cancer. A report published in the
International Journal of Epidemiology (June, 2010)
compared cell phone usage for more than 5,000
people with brain tumors (glioma and meningioma)
and a similar number of healthy controls.
Results of this study did NOT show that cell phones
caused brain cancer. In this study, most people had
no increased risk of brain cancer from using cell
phones. For people with the heaviest use of cell
phones (an average of more than ½ hour per day,
every day, for over 10 years) the study suggested a
slight increase in brain cancer. However, the authors
determined that biases and errors prevented any
conclusions being drawn from this data. Additional
information about Interphone can be found at
http://com.iarc.fr/en/media-centre/pr/.
Interphone is the largest cell phone study to date, but
it did not answer all questions about cell phone
safety. Additional research is being conducted around
the world, and the FDA continues to monitor
developments in this field.
International Cohort Study on Mobile Phone Users
(COSMOS)
The COSMOS study aims to conduct long-term health
monitoring of a large group of people to determine if
there are any health issues linked to long-term
exposure to radio frequency energy from cell phone
use. The COSMOS study will follow approximately
300,000 adult cell phone users in Europe for 20 to 30
years. Additional information about the COSMOS
study can be found at
http://www.ukcosmos.org/
index.html
.
Risk of Brain Cancer from Exposure to Radio
Frequency Fields in Childhood and Adolescence
(MOBI-KIDS)
MOBI-KIDS is an international study investigating the
relationship between exposure to radio frequency
energy from communication technologies including
cell phones and brain cancer in young people. This is
an international multi-center study involving 14
European and non-European countries. Additional
information about MOBI-KIDS can be found at
http://www.creal.cat/programes-recerca/en_projectes-
creal/view.php?ID=39.
156
Surveillance, Epidemiology, and End Results (SEER)
Program of the National Cancer Institute
The National Cancer Institute (NCI) actively follows
cancer statistics in the United States to detect any
change in rates of new cases for brain cancer. If cell
phones play a role in risk for brain cancer, rates
should go up, because heavy cell phone use has been
common for quite some time in the U.S. Between
1987 and 2005, the overall age-adjusted incidence of
brain cancer did not increase. Additional information
about SEER can be found at
http://seer.cancer.gov/
.
Cell Phone Industry Actions
Although the existing scientific data do not justify FDA
regulatory actions, the FDA has urged the cell phone
industry to take a number of steps, including the
following:
•
Support-needed research on possible biological
effects of RF for the type of signal emitted by cell
phones;
•
Design cell phones in a way that minimizes any RF
exposure to the user; and
•
Cooperate in providing users of cell phones with the
current information on cell phone use and human
health concerns.
The FDA also is working with voluntary standard-
setting bodies such as the Institute of Electrical and
Electronics Engineers (IEEE), the International
Commission on Non-Ionizing Radiation Protection
(ICNIRP), and others to assure that safety standards
continue to adequately protect the public.
Reducing Exposure: Hands-Free Kits and Other
Accessories
Steps to Reduce Exposure to Radio Frequency
Energy
If there is a risk from being exposed to radio
frequency energy (RF) from cell phones - and at this
point we do not know that there is - it is probably very
small. But, if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your RF exposure.
•
Reduce the amount of time spent using your cell phone;
•
Use speaker mode or a headset to place more distance
between your head and the cell phone.
Hands-Free Kits
Hands-free kits may include audio or Bluetooth®
headsets and various types of body-worn accessories
such as belt-clips and holsters. Combinations of these
can be used to reduce RF energy absorption from cell
phones.
Headsets can substantially reduce exposure because
the phone is held away from the head in the user's
hand or in approved body-worn accessories. Cell
phones marketed in the U.S. are required to meet RF
exposure compliance requirements when used
against the head and against the body.
Because there are no known risks from exposure to
RF emissions from cell phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used for convenience and comfort. They
are also required by law in many states if you want to
use your phone while driving.
Health and Safety Information 157
Cell Phone Accessories that Claim to Shield the
Head from RF Radiation
Because there are no known risks from exposure to
RF emissions from cell phones, there is no reason to
believe that accessories which claim to shield the
head from those emissions reduce risks. Some
products that claim to shield the user from RF
absorption use special phone cases, while others
involve nothing more than a metallic accessory
attached to the phone. Studies have shown that
these products generally do not work as advertised.
Unlike “hands-free” kits, these so-called “shields”
may interfere with proper operation of the phone. The
phone may be forced to boost its power to
compensate, leading to an increase in RF absorption.
Children and Cell Phones
The scientific evidence does not show a danger to
any users of cell phones from RF exposure, including
children and teenagers. The steps adults can take to
reduce RF exposure apply to children and teenagers
as well.
•
Reduce the amount of time spent on the cell phone;
•
Use speaker mode or a headset to place more distance
between the head and the cell phone.
Some groups sponsored by other national
governments have advised that children be
discouraged from using cell phones at all. For
example, The Stewart Report from the United
Kingdom made such a recommendation in December
2000. In this report, a group of independent experts
noted that no evidence exists that using a cell phone
causes brain tumors or other ill effects. Their
recommendation to limit cell phone use by children
was strictly precautionary; it was not based on
scientific evidence that any health hazard exists.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations (updated 10/1/2010):
•
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/.
•
Environmental Protection Agency (EPA):
http://www.epa.gov/radtown/wireless-tech.html.
•
Occupational Safety and Health Administration (OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/.
(Note: This web address is case sensitive.)
•
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/.
•
World Health Organization (WHO):
http://www.who.int/peh-emf/en/.
•
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de.
•
Health Protection Agency:
http://www.hpa.org.uk/Topics/Radiation/.
•
US Food and Drug Administration:
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/default.htm.
158
Specific Absorption Rate (SAR)
Certification Information
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the exposure limits for Radio Frequency (RF)
energy set by the Federal Communications
Commission (FCC) of the U.S. Government.
These FCC exposure limits are derived from the
recommendations of two expert organizations: the
National Council on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical
and Electronics Engineers (IEEE).
In both cases, the recommendations were developed
by scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg).
The FCC exposure limit incorporates a substantial
margin of safety to give additional protection to the
public and to account for any variations in
measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC.
For body-worn operation, this phone has been tested
and meets FCC RF exposure guidelines when used
with an accessory that contains no metal and that
positions the mobile device a minimum of 1.5 cm
from the body.
Use of other accessories may not ensure compliance
with FCC RF exposure guidelines.
The FCC has granted an Equipment Authorization for
this mobile phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. The maximum SAR values for this model
phone as reported to the FCC are:
•
Head: 0.91 W/Kg.
•
Body-worn: 1.12 W/Kg.
2.4GHZ WLAN
•
Head: 0.28 W/Kg.
•
Body-worn: 0.16 W/Kg.
Health and Safety Information 159
SAR information on this and other model phones can
be viewed online at
http://www.fcc.gov/oet/ea
. To find
information that pertains to a particular model phone,
this site uses the phone FCC ID number which is
usually printed somewhere on the case of the phone.
Sometimes it may be necessary to remove the
battery pack to find the number. Once you have the
FCC ID number for a particular phone, follow the
instructions on the website and it should provide
values for typical or maximum SAR for a particular
phone. Additional product specific SAR information
can also be obtained at
www.fcc.gov/cgb/sar
.
Smart Practices While Driving
On the Road - Off the Phone
The primary responsibility of every driver is the safe
operation of his or her vehicle.
Responsible drivers understand that no secondary
task should be performed while driving whether it be
eating, drinking, talking to passengers, or talking on
a mobile phone - unless the driver has assessed the
driving conditions and is confident that the secondary
task will not interfere with their primary
responsibility.
Do not engage in any activity while
driving a moving vehicle which may cause you to take
your eyes off the road or become so absorbed in the
activity that your ability to concentrate on the act of
driving becomes impaired
. Samsung is committed to
promoting responsible driving and giving drivers the
tools they need to understand and address
distractions.
Check the laws and regulations on the use of mobile
devices and their accessories in the areas where you
drive. Always obey them. The use of these devices may
be prohibited or restricted in certain areas. For
example, only hands-free use may be permitted in
certain areas.
Before answering calls, consider your circumstances.
Let the call go to voicemail when driving conditions
require. Remember, driving comes first, not the call!
If you consider a call necessary and appropriate,
follow these tips:
•
Use a hands-free device;
•
Secure your phone within easy reach;
•
Place calls when you are not moving;
•
Plan calls when your car will be stationary;
•
Do not engage in stressful or emotional conversations;
•
Let the person with whom you are speaking know that
you are driving and will suspend the call if necessary;
•
Do not take notes or look up phone numbers while
driving;
Notice regarding legal restrictions on mounting this
device in an automobile:
Laws in some states may prohibit mounting this
device on or near the windshield of an automobile. In
other states, the law may permit mounting this
device only in specific locations in the automobile. Be
sure to consult the state and local laws or ordinances
where you drive before mounting this device in an
automobile. Failure to comply with these restrictions
could result in fines, penalties, or other damages.
160
Never mount this device in a manner that will obstruct
the driver's clear view of the street and traffic.
Never use wireless data services such as text
messaging, Web browsing, or e-mail while operating a
vehicle.
Never watch videos, such as a movie or clip, or play
video games while operating a vehicle.
For more information
, go to
http://www.ctia.org
.
Battery Use and Safety
Important!: Handle and store batteries properly to avoid injury or
damage
. Most battery issues arise from improper
handling of batteries and, particularly, from the
continued use of damaged batteries.
•
Do not disassemble, crush, puncture, shred, or
otherwise attempt to change the form of your battery
.
Do not put a high degree of pressure on the battery. This
can cause leakage or an internal short-circuit, resulting in
overheating.
•
Do not let the phone or battery come in contact with
liquids.
Liquids can get into the phone's circuits, leading
to corrosion. Even when the phone appears to be dry and
appears to operate normally, the circuitry could slowly
corrode and pose a safety hazard. If the phone and/or
battery get wet, have them checked by your service
provider or contact Samsung, even if they appear to be
working properly.
•
Do not place your battery in or near a heat source
.
Excessive heating can damage the phone or the battery
and could cause the phone or the battery to explode. Do
not dry a wet or damp battery with an appliance or heat
source such as a microwave oven, hair dryer, iron, or
radiator. Avoid leaving your phone in your car in high
temperatures.
•
Do not dispose of the phone or the battery in a fire
.
The phone or the battery may explode when overheated.
•
Do not handle a damaged or leaking battery
. Do not let
leaking battery fluid come in contact with your eyes, skin
or clothing. For safe disposal options, contact your nearest
Samsung-authorized service center.
•
Avoid dropping the cell phone
. Dropping the phone or
the battery, especially on a hard surface, can potentially
cause damage to the phone and battery. If you suspect
damage to the phone or battery, take it to a service center
for inspection.
•
Never use any charger or battery that is damaged in
any way
.
•
Do not allow the battery to touch metal objects
.
Accidental short-circuiting can occur when a metallic
object (coin, key, jewelry, clip, or pen) causes a direct
connection between the + and - terminals of the battery
(metal strips on the battery), for example when you carry
a spare battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object causing
the short-circuiting.
Health and Safety Information 161
Important!: Important
: Use only Samsung-approved batteries,
and recharge your battery only with Samsung-
approved chargers which are specifically designed
for your phone.
Warning!: Warning: Use of a non-Samsung-approved battery or
charger may present a risk of fire, explosion, leakage,
or other hazard
. Samsung's warranty does not cover
damage to the phone caused by non-Samsung-
approved batteries and/or chargers.
•
Do not use incompatible cell phone batteries and
chargers
. Some websites and second-hand dealers not
associated with reputable manufacturers and carriers,
might be selling incompatible or even counterfeit
batteries and chargers. Consumers should purchase
manufacturer or carrier-recommended products and
accessories. If unsure about whether a replacement
battery or charger is compatible, contact the
manufacturer of the battery or charger.
•
Misuse or use of incompatible phones, batteries, and
charging devices could result in damage to the
equipment and a possible risk of fire, explosion, or
leakage, leading to serious injuries, damages to your
phone, or other serious hazard
.
Samsung Mobile Products and
Recycling
Samsung cares for the environment and encourages
its customers to recycle Samsung mobile devices and
genuine Samsung accessories.
Proper disposal of your mobile device and its battery
is not only important for safety, it benefits the
environment. Batteries must be recycled or disposed
of properly.
Recycling programs for your mobile device, batteries,
and accessories may not be available in your area.
We've made it easy for you to recycle your old
Samsung mobile device by working with respected
take-back companies in every state in the country.
Drop It Off
You can drop off your Samsung-branded mobile
device and batteries for recycling at one of our
numerous Samsung Recycling Direct (SM)
locations. A list of these locations may be found at:
http://pages.samsung.com/us/recyclingdirect/
usactivities_environment_samsungrecyclingdirect_locati
ons.jsp.
Samsung-branded devices and batteries will be
accepted at these locations for no fee.
Consumers may also recycle their used mobile
device or batteries at many retail or carrier-
provided locations where mobile devices and
batteries are sold. Additional information regarding
specific locations may be found at:
http://www.epa.gov/epawaste/partnerships/plugin/
cellphone/index.htm
or at
http://www.call2recycle.org/
.
162
Mail It In
The Samsung Mobile Take-Back Program will provide
Samsung customers with a free recycling mailing label.
Just go to
http://www.samsung.com/us/aboutsamsung/citizenship/
usactivities_environment_samsungrecyclingdirect.html?I
NT=STA_recyle_your_phone_page and follow the
instructions to print out a free pre-paid postage label and
then send your old mobile device or battery to the address
listed, via U.S. Mail, for recycling.
Dispose of unwanted electronics through an approved
recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect
Or call, (877) 278-0799.
Follow local regulations regarding disposal of
mobile devices and batteries
Dispose of your mobile device and batteries in
accordance with local regulations. In some areas, the
disposal of these items in household or business trash
may be prohibited. Help us protect the environment -
recycle!
Warning!:
Never dispose of batteries in a fire because they may
explode.
UL Certified Travel Charger
The Travel Charger for this phone has met applicable
UL safety requirements. Please adhere to the
following safety instructions per UL guidelines:
FAILURE TO FOLLOW THE INSTRUCTIONS
OUTLINED MAY LEAD TO SERIOUS PERSONAL
INJURY AND POSSIBLE PROPERTY DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE
THESE INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, CAREFULLY FOLLOW
THESE INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN
NORTH AMERICA, USE AN ATTACHMENT
PLUG ADAPTOR OF THE PROPER
CONFIGURATION FOR THE POWER
OUTLET.
THIS POWER UNIT IS INTENDED TO BE
CORRECTLY ORIENTED IN A VERTICAL OR
HORIZONTAL OR FLOOR MOUNT
POSITION.
Health and Safety Information 163
Display / Touch-Screen
Please note the following information when using
your mobile device:
WARNING REGARDING DISPLAY
The display on your mobile device is made of
glass or acrylic and could break if your mobile
device is dropped or if it receives significant
impact. Do not use if screen is broken or
cracked as this could cause injury to you.
WARRANTY DISCLAIMER: PROPER USE OF A
TOUCH-SCREEN MOBILE DEVICE
If your mobile device has a touch-screen
display, please note that a touch-screen
responds best to a light touch from the pad of
your finger or a non-metallic stylus. Using
excessive force or a metallic object when
pressing on the touch-screen may damage the
tempered glass surface and void the warranty.
For more information, please refer to the
“Standard Limited Warranty” on page 172.
GPS & AGPS
Certain Samsung mobile devices can use a Global
Positioning System (GPS) signal for location-based
applications. A GPS uses satellites controlled by the
U.S. Government that are subject to changes
implemented in accordance with the Department of
Defense policy and the 2008 Federal Radio
navigation Plan (FRP). Changes may affect the
performance of location-based technology on your
mobile device.
Certain Samsung mobile devices can also use an
Assisted Global Positioning System (AGPS), which
obtains information from the cellular network to
improve GPS performance. AGPS uses your wireless
service provider's network and therefore airtime,
data charges, and/or additional charges may apply in
accordance with your service plan. Contact your
wireless service provider for details.
Your Location
Location-based information includes information that
can be used to determine the approximate location of
a mobile device. Mobile devices which are connected
to a wireless network transmit location-based
information. Additionally, if you use applications that
require location-based information (e.g. driving
directions), such applications transmit location-based
information. The location-based information may be
shared with third-parties, including your wireless
service provider, applications providers, Samsung,
and other third-parties providing services.
Use of AGPS in Emergency Calls
When you make an emergency call, the cellular
network may activate AGPS technology in your
mobile device to tell the emergency responders your
approximate location.
AGPS has limitations and
might not work in your area
.
Therefore:
164
•
Always tell the emergency responder your location to the
best of your ability; and
•
Remain on the mobile device for as long as the emergency
responder instructs you.
Navigation
Maps, directions, and other navigation data may
contain inaccurate or incomplete data, and
circumstances can and do change over time. In some
areas, complete information may not be available.
Therefore,
you should always visually confirm that the
navigational instructions are consistent with what you
see before following them. All users should pay
attention to road conditions, closures, traffic, and all
other factors that may impact safe driving or walking.
Always obey posted road signs
.
Emergency Calls
This mobile device, like any wireless mobile device,
operates using radio signals, wireless and landline
networks, as well as user-programmed functions,
which cannot guarantee connection in all conditions,
areas, or circumstances. Therefore, you should never
rely solely on any wireless mobile device for essential
communications (medical emergencies, for example).
Before traveling in remote or underdeveloped areas,
plan an alternate method of contacting emergency
services personnel. Remember, to make or receive
any calls, the mobile device must be switched on and
in a service area with adequate signal strength.
Emergency calls may not be possible on all wireless
mobile device networks or when certain network
services and/or mobile device features are in use.
Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. From the Home screen, tap .
3. Enter the emergency number for your present
location (for example, 911 or other official
emergency number), then tap .
Emergency numbers vary by location.
If certain features are in use (call blocking, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult your User Manual and your local cellular
service provider. When making an emergency call,
remember to give all the necessary information as
accurately as possible. Remember that your mobile
device may be the only means of communication at
the scene of an accident; do not cut off the call until
given permission to do so.
Care and Maintenance
Your mobile device is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years:
Health and Safety Information 165
Keep your Samsung Mobile Device away from:
Liquids of any kind
Keep the mobile device dry. Precipitation, humidity,
and liquids contain minerals that will corrode
electronic circuits. If the mobile device does get
wet, do not accelerate drying with the use of an
oven, microwave, or dryer, because this may
damage the mobile device and could cause a fire or
explosion. Do not use the mobile device with a wet
hand. Doing so may cause an electric shock to you
or damage to the mobile device.
Extreme heat or cold
Avoid temperatures below 0°C / 32°F or above 45°C /
113°F.
Microwaves
Do not try to dry your mobile device in a microwave oven.
Doing so may cause a fire or explosion.
Dust and dirt
Do not expose your mobile device to dust, dirt, or sand.
Cleaning solutions
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the mobile device. Wipe it with a soft
cloth slightly dampened in a mild soap-and-water
solution.
Shock or vibration
Do not drop, knock, or shake the mobile device. Rough
handling can break internal circuit boards.
Paint
Do not paint the mobile device. Paint can clog the
device’s moving parts or ventilation openings and prevent
proper operation.
Responsible Listening
Caution!: Avoid potential hearing loss
.
Damage to hearing occurs when a person is exposed
to loud sounds over time. The risk of hearing loss
increases as sound is played louder and for longer
durations. Prolonged exposure to loud sounds
(including music) is the most common cause of
preventable hearing loss. Some scientific research
suggests that using portable audio devices, such as
portable music players and cell phones, at high
volume settings for long durations may lead to
permanent noise-induced hearing loss. This includes
the use of headphones (including headsets, earbuds,
and Bluetooth® or other wireless devices). Exposure
to very loud sound has also been associated in some
studies with tinnitus (a ringing in the ear),
hypersensitivity to sound, and distorted hearing.
Individual susceptibility to noise-induced hearing loss
and potential hearing problem varies. Additionally,
the amount of sound produced by a portable audio
device varies depending on the nature of the sound,
the device settings, and the headphones that are
used. As a result, there is no single volume setting
that is appropriate for everyone or for every
combination of sound, settings, and equipment.
You should follow some common sense
recommendations when using any portable audio
device:
•
Always turn the volume down before plugging the
earphones into an audio source.
166
•
Set the volume in a quiet environment and select the
lowest volume at which you can hear adequately.
•
Be aware that you can adapt to higher volume settings
over time, not realizing that the higher volume may be
harmful to your hearing.
•
When using headphones, turn the volume down if you
cannot hear the people speaking near you or if the person
sitting next to you can hear what you are listening to.
•
Do not turn the volume up to block out noisy surroundings.
If you choose to listen to your portable device in a noisy
environment, use noise-cancelling headphones to block
out background environmental noise. By blocking
background environment noise, noise cancelling
headphones should allow you to hear the music at lower
volumes than when using earbuds.
•
Limit the amount of time you listen. As the volume
increases, less time is required before you hearing could
be affected.
•
Avoid using headphones after exposure to extremely loud
noises, such as rock concerts, that might cause
temporary hearing loss. Temporary hearing loss might
cause unsafe volumes to sound normal.
•
Do not listen at any volume that causes you discomfort. If
you experience ringing in your ears, hear muffled speech,
or experience any temporary hearing difficulty after
listening to your portable audio device, discontinue use
and consult your doctor.
You can obtain additional information on this subject
from the following sources:
American Academy of Audiology
11730 Plaza American Drive, Suite 300
Reston, VA 20190
Voice: (800) 222-2336
Email: info@audiology.org
Internet:
http://www.audiology.org/Pages/default.aspx
National Institute on Deafness and Other
Communication Disorders
National Institutes of Health
31 Center Drive, MSC 2320
Bethesda, MD 20892-2320
Email: nidcdinfo@nih.gov
Internet:
http://www.nidcd.nih.gov/
Health and Safety Information 167
Operating Environment
Remember to follow any special regulations in force
in any area, and always switch your mobile device off
whenever it is forbidden to use it, or when it may
cause interference or danger. When connecting the
mobile device or any accessory to another device,
read its user's guide for detailed safety instructions.
Do not connect incompatible products.
Using Your Mobile Device Near Other Electronic
Devices
Most modern electronic equipment is shielded from
Radio Frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless mobile device. Consult
the manufacturer to discuss alternatives.
Implantable Medical Devices
A minimum separation of six (6) inches should be
maintained between a handheld wireless mobile
device and an implantable medical device, such as a
pacemaker or implantable cardioverter defibrillator,
to avoid potential interference with the device.
Persons who have such devices:
•
Should ALWAYS keep the mobile device more than six (6)
inches from their implantable medical device when the
mobile device is turned ON;
•
Should not carry the mobile device in a breast pocket;
•
Should use the ear opposite the implantable medical
device to minimize the potential for interference;
•
Should turn the mobile device OFF immediately if there is
any reason to suspect that interference is taking place;
•
Should read and follow the directions from the
manufacturer of your implantable medical device. If you
have any questions about using your wireless mobile
device with an implantable medical device, consult your
health care provider.
For more information see:
http://www.fcc.gov/oet/
rfsafety/rf-faqs.html#
.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to determine
if it is adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining
this information. Switch your mobile device off in
health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health
National Institute for Occupational Safety and Health
(NIOSH)
395 E Street, S.W.
Suite 9200
Patriots Plaza Building
Washington, DC 20201
Voice: 1-800-35-NIOSH (1-800-356-4674)
1-800-CDC-INFO (1-800-232-4636)
Outside the U.S. 513-533-8328
Email: cdcinfo@cdc.gov
Internet:
http://www.cdc.gov/niosh/topics/noise/
default.html
1-888-232-6348 TTY
168
care facilities may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle before using
your mobile device in a motor vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your mobile device off in any facility where
posted notices require you to do so.
Potentially Explosive Environments
Switch your mobile device off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death. Users are advised to switch the mobile device
off while at a refueling point (service station). Users
are reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants, or where
blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not
always, clearly marked. They include below deck on
boats, chemical transfer or storage facilities, vehicles
using liquefied petroleum gas (such as propane or
butane), areas where the air contains chemicals or
particles, such as grain, dust, or metal powders, and
any other area where you would normally be advised
to turn off your vehicle engine.
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices
On July 10, 2003, the U.S. Federal Communications
Commission (FCC) Report and Order in WT Docket 01-
309 modified the exception of wireless mobile
devices under the Hearing Aid Compatibility Act of
1988 (HAC Act) to require digital wireless mobile
devices be compatible with hearing aids.
The intent of the HAC Act is to ensure reasonable
access to telecommunications services for persons
with hearing disabilities. While some wireless mobile
devices are used near some hearing devices (hearing
aids and cochlear implants), users may detect a
buzzing, humming, or whining noise. Some hearing
devices are more immune than others to this
interference noise, and mobile devices also vary in
the amount of interference they generate.
The wireless telephone industry has developed a
rating system for wireless mobile devices to assist
hearing device users find mobile devices that may be
compatible with their hearing devices. Not all mobile
devices have been rated. Mobile devices that are
rated have the rating on their box or a label located on
the box.
The ratings are not guarantees. Results will vary
depending on the user's hearing device and hearing
loss. If your hearing device happens to be vulnerable
to interference, you may not be able to use a rated
mobile device successfully. Trying out the mobile
Health and Safety Information 169
device with your hearing device is the best way to
evaluate it for your personal needs.
M-Ratings
: Mobile devices rated M3 or M4 meet FCC
requirements and are likely to generate less
interference to hearing devices than mobile devices
that are not labeled. M4 is the better/higher of the
two ratings.
T-Ratings
: Mobile devices rated T3 or T4 meet FCC
requirements and are likely to generate less
interference to hearing devices than mobile devices
that are not labeled. T4 is the better/higher of the two
ratings.
Hearing devices may also be rated. Your hearing
device manufacturer or hearing health professional
may help you find this rating. Higher ratings mean
that the hearing device is relatively immune to
interference noise. The hearing aid and wireless
mobile device rating values are then added together.
A sum of 5 is considered acceptable for normal use.
A sum of 6 is considered for best use. If a hearing aid
meets the M2 level rating and the wireless mobile
device meets the M3 level rating, the sum of the two
values equal M5. This is synonymous for T ratings.
This should provide the hearing aid user with “normal
usage” while using their hearing aid with the
particular wireless mobile device.
“Normal usage” in this context is defined as a signal
quality that is acceptable for normal operation. The M
mark is intended to be synonymous with the U mark.
The T mark is intended to be synonymous with the
UT mark. The M and T marks are recommended by
the Alliance for Telecommunications Industries
Solutions (ATIS). The U and UT marks are referenced
in Section 20.19 of the FCC Rules.
The HAC rating and measurement procedure are
described in the American National Standards
Institute (ANSI) C63.19 standard.
HAC/Wi-Fi for Newer Technologies
This phone has been tested and rated for use with
hearing aids for some of the wireless technologies
that it uses. However, there may be some newer
wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is
important to try the different features of this phone
thoroughly and in different locations, using your
hearing aid or cochlear implant, to determine if you
hear any interfering noise. Consult your service
provider or the manufacturer of this phone for
information on hearing aid compatibility. If you have
questions about return or exchange policies, consult
your service provider or phone retailer.
M3 + M2 = 5 T3 + T2 =
170
Restricting Children's Access to Your
Mobile Device
Your mobile device is not a toy. Do not allow children
to play with it because they could hurt themselves
and others, damage the mobile device, or make calls
that increase your mobile device bill.
Keep the mobile device and all its parts and
accessories out of the reach of small children.
FCC Notice and Cautions
FCC Notice
The mobile device may cause TV or radio interference
if used in close proximity to receiving equipment. The
FCC can require you to stop using the mobile device if
such interference cannot be eliminated. Vehicles
using liquefied petroleum gas (such as propane or
butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard,
contact the National Fire Protection Association.
Cautions
Any changes or modifications to your mobile device
not expressly approved in this document could void
your warranty for this equipment and void your
authority to operate this equipment. Only use
approved batteries, antennas, and chargers. The use
of any unauthorized accessories may be dangerous
and void the mobile device warranty if said
accessories cause damage or a defect to the mobile
device. Although your mobile device is quite sturdy, it
is a complex piece of equipment and can be broken.
Avoid dropping, hitting, bending, or sitting on it.
Other Important Safety Information
•
Only qualified personnel should service the mobile device
or install the mobile device in a vehicle. Faulty installation
or service may be dangerous and may invalidate any
warranty applicable to the device.
•
Ensure that any mobile devices or related equipment
installed in your vehicle are securely mounted.
•
Check regularly that all wireless mobile device equipment
in your vehicle is mounted and operating properly.
•
Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the
mobile device, its parts, or accessories.
•
For vehicles equipped with an air bag, remember that an
air bag inflates with great force. Do not place objects,
including installed or portable wireless equipment near or
in the area over the air bag or in the air bag deployment
area. If wireless equipment is improperly installed and the
air bag inflates, serious injury could result.
•
Switch your mobile device off before boarding an aircraft.
The use of wireless mobile devices in aircraft is illegal and
may be dangerous to the aircraft's operation. Check with
appropriate authorities before using any function of a
mobile device while on an aircraft.
•
Failure to observe these instructions may lead to the
suspension or denial of cell phone services to the
offender, or legal action, or both.
•
If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified service
facility. The personnel there will assist you, and if
necessary, arrange for service.
Health and Safety Information 171
•
Dispose of phones in accordance with local regulations.
In some areas, the disposal of phones in household or
business trash may be prohibited. For safe disposal
options for phones, contact your nearest Samsung
authorized service center.
172
Section 14: Warranty Information
Standard Limited Warranty
What is Covered and For How Long?
SAMSUNG TELECOMMUNICATIONS AMERICA, LLC
("SAMSUNG") warrants to the first consumer
purchaser ("Purchaser") that SAMSUNG's handsets
and accessories ("Products") are free from defects in
material and workmanship under normal use and
service for the period commencing upon the date of
purchase and continuing for the following specified
period of time after that date:
What is Not Covered?
This Limited Warranty is conditioned upon proper use of
Product by Purchaser. This Limited Warranty does not cover:
(a) defects or damage resulting from accident, misuse,
abnormal use, abnormal conditions, improper storage,
exposure to liquid, moisture, dampness, sand or dirt,
neglect, or unusual physical, electrical or electromechanical
stress; (b) scratches, dents and cosmetic damage, unless
caused by SAMSUNG; (c) defects or damage resulting from
excessive force or use of a metallic object when pressing on
a touch screen; (d) equipment that has the serial number or
the enhancement data code removed, defaced, damaged,
altered or made illegible; (e) ordinary wear and tear; (f)
defects or damage resulting from the use of Product in
conjunction or connection with accessories, products, or
ancillary/peripheral equipment not furnished or approved by
SAMSUNG; (g) defects or damage resulting from improper
testing, operation, maintenance, installation, service, or
adjustment not furnished or approved by SAMSUNG; (h)
defects or damage resulting from external causes such as
collision with an object, fire, flooding, dirt, windstorm,
lightning, earthquake, exposure to weather conditions, theft,
blown fuse, or improper use of any electrical source; (i)
defects or damage resulting from cellular signal reception or
transmission, or viruses or other software problems
introduced into the Product; or (j) Product used or purchased
outside the United States. This Limited Warranty covers
batteries only if battery capacity falls below 80% of rated
capacity or the battery leaks, and this Limited Warranty
does not cover any battery if (i) the battery has been
charged by a battery charger not specified or approved by
SAMSUNG for charging the battery; (ii) any of the seals on
the battery are broken or show evidence of tampering; or
(iii) the battery has been used in equipment other than the
SAMSUNG phone for which it is specified.
What are SAMSUNG's Obligations?
During the applicable warranty period, provided the
Product is returned in accordance with the terms of
this Limited Warranty, SAMSUNG will repair or replace
the Product, without charge to Purchaser, or at
SAMSUNG'S sole option, refund the purchase price.
SAMSUNG may, at SAMSUNG's sole option, use
rebuilt, reconditioned, or new parts or components
Phone 1 Year
Batteries 1 Year
Case/Pouch/Holster 90 Days
Other Phone Accessories 1 Year
Warranty Information 173
when repairing any Product, or may replace Product
with a rebuilt, reconditioned or new Product.
Repaired/replaced cases, pouches and holsters will
be warranted for a period of ninety (90) days. All
other repaired/replaced Products will be warranted
for a period equal to the remainder of the original
Limited Warranty on the original Product or for 90
days, whichever is longer. All replaced Products,
parts, components, boards and equipment shall
become the property of SAMSUNG. This Limited
Warranty is extended to the Purchaser and is not
transferable or assignable to any other person or
entity.
What must you do to obtain warranty service?
To obtain service under this Limited Warranty,
Purchaser must return the Product to an authorized
phone service facility in an adequate container for
shipping, accompanied by the sales receipt or
comparable proof of sale showing the original date of
purchase, the serial number of the Product and the
seller's name and address. To obtain assistance on
where to deliver the Product, please call SAMSUNG
Customer Care at 1-888-987-4357. If SAMSUNG
determines that any Product is not covered by this
Limited Warranty, Purchaser must pay all parts,
shipping, and labor charges for the repair or return of
such Product.
Purchaser should keep a separate backup copy of
any contents of the Product before delivering the
Product to SAMSUNG for warranty service, as some
or all of the contents may be deleted or reformatted
during the course of warranty service.
What Are The Limits On SAMSUNG’s liability?
THIS LIMITED WARRANTY SETS OUT THE FULL EXTENT OF
SAMSUNG'S RESPONSIBILITIES, AND THE EXCLUSIVE
REMEDY REGARDING THE PRODUCTS. ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION, IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY. IN NO EVENT SHALL SAMSUNG
BE LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE
PRICE OF THE PRODUCT OR FOR, WITHOUT LIMITATION,
COMMERCIAL LOSS OF ANY SORT; LOSS OF USE, TIME,
DATA, REPUTATION, OPPORTUNITY, GOODWILL, PROFITS
OR SAVINGS; INCONVENIENCE; INCIDENTAL, SPECIAL,
CONSEQUENTIAL OR PUNITIVE DAMAGES; OR DAMAGES
ARISING FROM THE USE OR INABILITY TO USE THE
PRODUCT. SOME STATES AND JURISDICTIONS DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, OR THE DISCLAIMER OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATIONS AND DISCLAIMERS MAY NOT APPLY TO
YOU.
SAMSUNG MAKES NO WARRANTIES OR
REPRESENTATIONS, EXPRESS OR IMPLIED, STATUTORY OR
OTHERWISE, AS TO THE QUALITY, CAPABILITIES,
OPERATIONS, PERFORMANCE OR SUITABILITY OF ANY
THIRD-PARTY SOFTWARE OR EQUIPMENT USED IN
CONJUNCTION WITH THE PRODUCT, OR THE ABILITY TO
INTEGRATE ANY SUCH SOFTWARE OR EQUIPMENT WITH
THE PRODUCT, WHETHER SUCH THIRD-PARTY SOFTWARE
OR EQUIPMENT IS INCLUDED WITH THE PRODUCT
DISTRIBUTED BY SAMSUNG OR OTHERWISE.
RESPONSIBILITY FOR THE QUALITY, CAPABILITIES,
174
OPERATIONS, PERFORMANCE AND SUITABILITY OF ANY
SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT RESTS
SOLELY WITH THE PURCHASER AND THE DIRECT VENDOR,
OWNER OR SUPPLIER OF SUCH THIRD-PARTY SOFTWARE
OR EQUIPMENT.
Nothing in the Product instructions or information shall be
construed to create an express warranty of any kind with
respect to the Products. No agent, employee, dealer,
representative or reseller is authorized to modify or extend
this Limited Warranty or to make binding representations or
claims, whether in advertising, presentations or otherwise,
on behalf of SAMSUNG regarding the Products or this
Limited Warranty.
This Limited Warranty gives you specific legal rights, and
you may also have other rights that vary from state to state.
What is the procedure for resolving disputes?
ALL DISPUTES WITH SAMSUNG ARISING IN ANY WAY
FROM THIS LIMITED WARRANTY OR THE SALE,
CONDITION OR PERFORMANCE OF THE PRODUCTS
SHALL BE RESOLVED EXCLUSIVELY THROUGH FINAL
AND BINDING ARBITRATION, AND NOT BY A COURT
OR JURY. Any such dispute shall not be combined or
consolidated with a dispute involving any other
person's or entity's Product or claim, and specifically,
without limitation of the foregoing, shall not under any
circumstances proceed as part of a class action.
The arbitration shall be conducted before a single
arbitrator, whose award may not exceed, in form or
amount, the relief allowed by the applicable law. The
arbitration shall be conducted according to the
American Arbitration Association (AAA) Commercial
Arbitration Rules applicable to consumer disputes.
This arbitration provision is entered pursuant to the
Federal Arbitration Act. The laws of the State of Texas,
without reference to its choice of laws principles,
shall govern the interpretation of the Limited Warranty
and all disputes that are subject to this arbitration
provision. The arbitrator shall decide all issues of
interpretation and application of this arbitration
provision and the Limited Warranty.
For any arbitration in which the Purchaser's total
damage claims, exclusive of attorney fees and expert
witness fees, are $5,000.00 or less ("Small Claim"),
the arbitrator may, if the Purchaser prevails, award
the Purchaser's reasonable attorney fees, expert
witness fees and costs as part of any award, but may
not grant SAMSUNG its attorney fees, expert witness
Warranty Information 175
fees or costs unless it is determined that the claim
was brought by the Purchaser in bad faith. In a Small
Claim case, the Purchaser shall be required to pay no
more than half of the total administrative, facility and
arbitrator fees, or $50.00 of such fees, whichever is
less, and SAMSUNG shall pay the remainder of such
fees. Administrative, facility and arbitrator fees for
arbitrations in which the Purchaser's total damage
claims, exclusive of attorney fees and expert witness
fees, exceed $5,000.00 ("Large Claim") shall be
determined according to AAA rules. In a Large Claim
case, the arbitrator may grant to the prevailing party,
or apportion among the parties, reasonable attorney
fees, expert witness fees and costs. Judgment may
be entered on the arbitrator's award in any court of
competent jurisdiction.
This arbitration provision also applies to claims
against SAMSUNG'S employees, representatives and
affiliates if any such claim arises from the Product's
sale, condition or performance.
Purchaser may opt out of this dispute resolution
procedure by providing notice to SAMSUNG no later
than 30 calendar days from the date of Purchaser's
original purchase of the Product. To opt out,
Purchaser must send notice by e-mail to
optout@sta.samsung.com, with the subject line:
"Arbitration Opt Out." Purchaser must include in the
opt out e-mail (a) Purchaser's name and address; (b)
the date on which the Product was purchased; (c) the
Product model name or model number; and (d) the
IMEI or MEID or Serial Number, as applicable, if
Purchaser has it (the IMEI or MEID or Serial Number
can be found (i) on the Product box; (ii) on the Product
information screen, which can be found under
"Settings;" (iii) on a label on the back of the Product
beneath the battery, if the battery is removable; and
(iv) on the outside of the Product if the battery is not
removable). Alternatively, Purchaser may opt out by
calling 1-888-987-4357 and providing the same
information. These are the only two forms of notice
that will be effective to opt out of this dispute
resolution procedure. Opting out of this dispute
resolution procedure will not affect the coverage of
the Limited Warranty in any way, and Purchaser will
continue to enjoy the benefits of the Limited
Warranty.
Severability
If any portion of this Limited Warranty is held to be
illegal or unenforceable, such partial illegality or
unenforceability shall not affect the enforceability of
the remainder of the Limited Warranty.
Samsung Telecommunications America, LLC
1301 E. Lookout Drive
Richardson, Texas 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©
2011 Samsung Telecommunications America, LLC. All
rights reserved.
No reproduction in whole or in part allowed without prior
written approval. Specifications and availability subject to
change without notice. [050611]
176
End User License Agreement for
Software
IMPORTANT. READ CAREFULLY: This End User License
Agreement ("EULA") is a legal agreement between
you (either an individual or a single entity) and
Samsung Electronics Co., Ltd. for software owned by
Samsung Electronics Co., Ltd. and its affiliated
companies and its third party suppliers and licensors
that accompanies this EULA, which includes computer
software and may include associated media, printed
materials, "online" or electronic documentation
("Software"). BY CLICKING THE "I ACCEPT" BUTTON
(OR IF YOU BYPASS OR OTHERWISE DISABLE THE "I
ACCEPT", AND STILL INSTALL, COPY, DOWNLOAD,
ACCESS OR OTHERWISE USE THE SOFTWARE), YOU
AGREE TO BE BOUND BY THE TERMS OF THIS EULA.
IF YOU DO NOT ACCEPT THE TERMS IN THIS EULA,
YOU MUST CLICK THE "DECLINE" BUTTON, AND
DISCONTINUE USE OF THE SOFTWARE.
1. GRANT OF LICENSE. Samsung grants you the
following rights provided that you comply with all
terms and conditions of this EULA: You may install,
use, access, display and run one copy of the Software
on the local hard disk(s) or other permanent storage
media of one computer and use the Software on a
single computer or a mobile device at a time, and you
may not make the Software available over a network
where it could be used by multiple computers at the
same time. You may make one copy of the Software
in machine-readable form for backup purposes only;
provided that the backup copy must include all
copyright or other proprietary notices contained on
the original.
2. RESERVATION OF RIGHTS AND OWNERSHIP.
Samsung reserves all rights not expressly granted to
you in this EULA. The Software is protected by
copyright and other intellectual property laws and
treaties. Samsung or its suppliers own the title,
copyright and other intellectual property rights in the
Software. The Software is licensed, not sold.
3. LIMITATIONS ON END USER RIGHTS. You may not
reverse engineer, decompile, disassemble, or
otherwise attempt to discover the source code or
algorithms of, the Software (except and only to the
extent that such activity is expressly permitted by
applicable law notwithstanding this limitation), or
modify, or disable any features of, the Software, or
create derivative works based on the Software. You
may not rent, lease, lend, sublicense or provide
commercial hosting services with the Software.
4. CONSENT TO USE OF DATA. You agree that
Samsung and its affiliates may collect and use
technical information gathered as part of the product
support services related to the Software provided to
you, if any, related to the Software. Samsung may use
this information solely to improve its products or to
provide customized services or technologies to you
and will not disclose this information in a form that
personally identifies you.
5. UPGRADES. This EULA applies to updates,
supplements and add-on components (if any) of the
Software that Samsung may provide to you or make
available to you after the date you obtain your initial
Warranty Information 177
copy of the Software, unless we provide other terms
along with such upgrade. To use Software identified
as an upgrade, you must first be licensed for the
Software identified by Samsung as eligible for the
upgrade. After upgrading, you may no longer use the
Software that formed the basis for your upgrade
eligibility.
6. SOFTWARE TRANSFER. You may not transfer this
EULA or the rights to the Software granted herein to
any third party unless it is in connection with the sale
of the mobile device which the Software
accompanied. In such event, the transfer must
include all of the Software (including all component
parts, the media and printed materials, any
upgrades, this EULA) and you may not retain any
copies of the Software. The transfer may not be an
indirect transfer, such as a consignment. Prior to the
transfer, the end user receiving the Software must
agree to all the EULA terms.
7. EXPORT RESTRICTIONS. You acknowledge that the
Software is subject to export restrictions of various
countries. You agree to comply with all applicable
international and national laws that apply to the
Software, including the U.S. Export Administration
Regulations, as well as end user, end use, and
destination restrictions issued by U.S. and other
governments.
8. TERMINATION. This EULA is effective until
terminated. Your rights under this License will
terminate automatically without notice from
Samsung if you fail to comply with any of the terms
and conditions of this EULA. Upon termination of this
EULA, you must cease all use of the Software and
destroy all copies, full or partial, of the Software.
9. THIRD-PARTY APPLICATIONS. Certain third-party
applications may be included with, or downloaded to
this mobile device. SAMSUNG makes no
representations whatsoever about any of these
applications. Since SAMSUNG has no control over
such applications, Purchaser acknowledges and
agrees that SAMSUNG is not responsible for the
availability of such applications and is not
responsible or liable for any content, advertising,
products, services, or other materials on or available
from such applications. Purchaser expressly
acknowledges and agrees that use of third-party
applications is at Purchaser's sole risk and that the
entire risk of unsatisfactory quality, performance,
accuracy and effort is with Purchaser. It is up to
Purchaser to take precautions to ensure that
whatever Purchaser selects to use is free of such
items as viruses, worms, Trojan horses, and other
items of a destructive nature. References on this
mobile device to any names, marks, products, or
services of any third-parties are provided solely as a
convenience to Purchaser, and do not constitute or
imply an endorsement, sponsorship, or
recommendation of, or affiliation with the third-party
or its products and services. Purchaser agrees that
SAMSUNG shall not be responsible or liable, directly
or indirectly, for any damage or loss caused or
alleged to caused by, or in connection with, use of or
reliance on any such third-party content, products, or
services available on or through any such application.
Purchaser acknowledges and agrees that your use of
178
any third-party application is governed by such third-
party application provider's Terms of Use, License
Agreement, Privacy Policy, or other such agreement
and that any information or personal data you provide,
whether knowingly or unknowingly, to such third-
party application provider, will be subject to such
third-party application provider's privacy policy, if
such a policy exists. SAMSUNG DISCLAIMS ANY
RESPONSIBILITY FOR ANY DISCLOSURE OF
INFORMATION OR ANY OTHER PRACTICES OF ANY
THIRD-PARTY APPLICATION PROVIDER.
10. Disclaimer of Warranty Regarding Third-Party
Applications. SAMSUNG DOES NOT WARRANT OR
MAKE ANY REPRESENTATIONS REGARDING THE
AVAILABILITY, USE, TIMELINESS, SECURITY, VALIDITY,
ACCURACY, OR RELIABILITY OF, OR THE RESULTS OF
THE USE OF, OR OTHERWISE RESPECTING, THE
CONTENT OF ANY THIRD-PARTY APPLICATION
WHETHER SUCH THIRD-PARTY APPLICATION IS
INCLUDED WITH THE PRODUCT DISTRIBUTED BY
SAMSUNG, IS DOWNLOADED, OR OTHERWISE
OBTAINED. USE OF ANY THIRD-PARTY APPLICATION
IS DONE AT PURCHASER'S OWN DISCRETION AND
RISK AND PURCHASER IS SOLELY RESPONSIBLE FOR
ANY DAMAGE TO YOUR MOBILE DEVICE OR LOSS OF
DATA THAT RESULTS FROM THE DOWNLOADING OR
USE OF SUCH THIRD-PARTY APPLICATIONS.
SAMSUNG EXPRESSLY DISCLAIMS ANY WARRANTY
REGARDING WHETHER PURCHASER'S PERSONAL
INFORMATION IS CAPTURED BY ANY THIRD-PARTY
APPLICATION PROVIDER OR THE USE TO WHICH SUCH
PERSONAL INFORMATION MAY BE PUT BY SUCH
THIRD-PARTY APPLICATION PROVIDER. ANY THIRD-
PARTY APPLICATIONS PROVIDED WITH THIS MOBILE
DEVICE ARE PROVIDED "AS IS" AND ON AN "AS
AVAILABLE" BASIS, WITHOUT WARRANTIES OF ANY
KIND FROM SAMSUNG, EITHER EXPRESS OR IMPLIED.
TO THE FULLEST EXTENT POSSIBLE PURSUANT TO
APPLICABLE LAW, SAMSUNG DISCLAIMS ALL
WARRANTIES EXPRESS, IMPLIED, OR STATUTORY,
INCLUDING, BUT NOT LIMITED TO, IMPLIED
WARRANTIES OF MERCHANTABILITY, SATISFACTORY
QUALITY OR WORKMANLIKE EFFORT, FITNESS FOR A
PARTICULAR PURPOSE, RELIABILITY OR AVAILABILITY,
ACCURACY, LACK OF VIRUSES, QUIET ENJOYMENT,
NON-INFRINGEMENT OF THIRD PARTY RIGHTS OR
OTHER VIOLATION OF RIGHTS. SAMSUNG DOES NOT
WARRANT AGAINST INTERFERENE WITH YOUR
ENJOYMENT OF THE THRID-PARTY APPLICATION,
THAT THE FUNCTIONS CONTAINED IN THE THIRD-
PARTY APPLICATION WILL MEET PURCHASER'S
REQUIREMENTS, THAT THE OPERATION OF THE
THIRD-PARTY APPLICATION WILL BE UNINTERRUPTED
OR ERROR-FREE, OR THAT DEFECTS IN THE THIRD-
PARTY APPLICATION WILL BE CORRECTED.
PURCHASER ASSUMES THE ENTIRE COST OF ALL
NECESSARY SERVICING, REPAIR, OR CORRECTION.
SOME JURISDICTIONS DO NOT ALLOW EXCLUSIONS
OR LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. NO ADVICE OR
INFORMATION, WHETHER ORAL OR WRITTEN,
OBTAINED BY PURCHASER FROM SAMSUNG SHALL
BE DEEMED TO ALTER THIS DISCLAIMER OF
WARRANTY REGARDING THIRD-PARTY APPLICATIONS,
OR TO CREATE ANY WARRANTY.
Warranty Information 179
11. Limitation of Liability. SAMSUNG WILL NOT BE
LIABLE FOR ANY DAMAGES OF ANY KIND ARISING
OUT OF OR RELATING TO THE USE OR THE INABILITY
TO USE ANY THIRD-PARTY APPLICATION, ITS
CONTENT OR FUNCTIONALITY, INCLUDING BUT NOT
LIMITED TO DAMAGES CAUSED BY OR RELATED TO
ERRORS, OMISSIONS, INTERRUPTIONS, DEFECTS,
DELAY IN OPERATION OR TRANSMISSION,
COMPUTER VIRUS, FAILURE TO CONNECT, NETWORK
CHARGES, AND ALL OTHER DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES EVEN IF SAMSUNG HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. SOME JURISDICTIONS DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
NOTWITHSTANDING THE FOREGOING, SAMSUNG'S
TOTAL LIABILITY TO PURCHASER FOR ALL LOSSES,
DAMAGES, CAUSES OF ACTION, INCLUDING BUT NOT
LIMITED TO THOSE BASED ON CONTRACT, TORT, OR
OTHERWISE, ARISING OUT OF PURCHASER'S USE OF
THIRD-PARTY APPLICATIONS ON THIS MOBILE
DEVICE, OR ANY OTHER PROVISION OF THIS EULA,
SHALL NOT EXCEED THE AMOUNT PURCHASER PAID
SPECIFICALLY FOR ANY SUCH THIRD-PARTY
APPLICATION THAT WAS INCLUDED WITH THIS
MOBILE DEVICE. THE FOREGOING LIMITATIONS,
EXCLUSIONS, AND DISCLAIMERS (INCLUDING
SECTIONS 9, 10, AND 11) SHALL APPLY TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
EVEN IF ANY REMEDY FAILS ITS ESSENTIAL
PURPOSE.
12. U.S. GOVERNMENT END USERS. The Software is
licensed only with "restricted rights" and as
"commercial items" consisting of "commercial
software" and "commercial software documentation"
with only those rights as are granted to all other end
users pursuant to the terms and conditions herein.
13. APPLICABLE LAW. This EULA is governed by the
laws of TEXAS, without regard to conflicts of laws
principles. This EULA shall not be governed by the UN
Convention on Contracts for the International Sale of
Goods, the application of which is expressly
excluded. If a dispute, controversy or difference is not
amicably settled, it shall be finally resolved by
arbitration in Seoul, Korea in accordance with the
Arbitration Rules of the Korean Commercial
Arbitration Board. The award of arbitration shall be
final and binding upon the parties.
14. ENTIRE AGREEMENT; SEVERABILITY. This EULA is
the entire agreement between you and Samsung
relating to the Software and supersedes all prior or
contemporaneous oral or written communications,
proposals and representations with respect to the
Software or any other subject matter covered by this
EULA. If any provision of this EULA is held to be void,
invalid, unenforceable or illegal, the other provisions
shall continue in full force and effect.
Precautions for Transfer and Disposal
If data stored on this device is deleted or reformatted
using the standard methods, the data only appears to
be removed on a superficial level, and it may be
possible for someone to retrieve and reuse the data
by means of special software.
180
To avoid unintended information leaks and other
problems of this sort, it is recommended that the
device be returned to Samsung’s Customer Care
Center for an Extended File System (EFS) Clear which
will eliminate all user memory and return all settings
to default settings. Please contact the
Samsung
Customer Care Center
for details.
Important!:
Please provide warranty information (proof of
purchase) to Samsung’s Customer Care Center in
order to provide this service at no charge. If the
warranty has expired on the device, charges may
apply.
Customer Care Center:
1000 Klein Rd.
Plano, TX 75074
Toll Free Tel: 1.888.987.HELP (4357)
Samsung Telecommunications America, LLC:
1301 East Lookout Drive
Richardson, Texas 75082
Phone: 1-800-SAMSUNG (726-7864)
Important!:
If you are using a handset other than a standard
numeric keypad, dial the numbers listed in
brackets.
Phone: 1-888-987-HELP (4357)
©2011 Samsung Telecommunications America. All
rights reserved.
No reproduction in whole or in part allowed without
prior written approval. Specifications and availability
subject to change without notice.
181
Index
Numerics
2G Network
Using 135
3G Network 136
Using 136
A
Accessing
Recently-used applications 27
Voice mail 13
Accounts and syncronization 101
Add 3 sec Pause 42
Adjusting
Call volume 46
Adobe PDF 113
Alarm
Disable Existing 130
Enable Existing 130
Setting 129
Alarm Volume
Setting 139
Answering a call 41
Application cache and data
Clearing 108
Application Menus
Navigating through 26
Applications 27
Android Market 29, 106
Browser 31, 115
Calculator 28, 101
Calendar 28
Camera 28, 102
Clock 28
Contacts 28
Email 29, 103
Files 29
Gallery 29
Google Mail 29, 103
Google Maps 104
Google Search 29
Google Talk 31
Latitude 29
Maps 29
Memo 29
memo 108
Messaging 30
messaging 108
Music 30
My Account 30
My Device 30
Navigation 30
News & Weather 30
Places 30
Settings 30
Swype Tips 31
Task Manager 31
ThinkFree Office 31
Using the Camcorder 95
Using the Camera 89
Voice Recorder 31, 114
Voice Search 31, 114
182
Wi-Fi Calling 31
YouTube 31, 115
Applications and Development 101
Auto-sync
Enabling 146
B
Back up
My Data 147
Backup and Restore 147
Battery
Charging 8
Extending Life 9
Installing 8
Low Battery Indicator 9
Removal 8
Saving Power 10
Wall Charger 8
Battery Cover
Removal 5
Replace 5
Battery Life
Extending 9
Battery Use & Safety 160
Bing
Set Search Engine 120
Bluetooth
About 121
Change Name 122
Deleting a Paired Device 123
Disable 121
Disconnecting a Paired Device 123
Enable 121
Paring Devices 122
Scan for Devices 122
Sending Contact Information 123
Sending Contacts Via 123
Set Visibility 122
Settings 121
Status indicators 121
Switching to Headset during call 47
Turning on and off 121
Browser
Adding bookmarks 118
Deleting bookmarks 119
Emptying cookies 119
Entering a URL 117
Navigation 116
Options 116
Search Engine 120
Settings 119
Bubble
Options 80
C
Calendar 128
Creating an event 128
Manually Sync Events 102
Settings 128
Calibration 140
Call Forwarding 138
Call Functions 40
Answering 41
Ending 40
Ending a Call 40
Making a Multi-Party Call 48
Pause Dialing 42
Redialing the last number 42
183
Wait dialing 42
Call Log 50
Accessing 50
Accessing from Notifications 51
Altering Numbers 52
Erasing 52
Call Settings 136
Additional 138
Call Forwarding 138
Call Volume
Adjusting 46
Call Waiting 49, 138
Caller ID
Hide Number 138
Calls
Making a 40
Multi-party 48
Muting 47
Camcorder 95
Accessing the Video Folder 96
Camcorder Options 95
Options 91
Settings 92
Shooting Video 95
Camera 89
Camera Options 90
Options 90
Taking Pictures 89
Care and Maintenance 164
Charging battery 8
Children and Cell Phones 157
Clearing
Application cache and data 108
Connections
Accessing the Internet 116
Contact
Copying to microSD Card 71
Copying to SIM Card 70
Creating a New 62
Joining 68
New From Keypad 64
Contact Entry
Options 67
Contact Image
Set as 94
Contact List
Options 66
Contact Menus
Options 67
Contacts
Adding a Number to Existing 65
Adding Your Facebook Friends 72
Additional Options 73
Default Storage Location 74
Deleting 66
Display Options 71, 72
Displaying Contacts by Name 72
Filtering 72
First Name First 72
Groups 74
Last Name First 72
Sending 69
Sending All 69
Setting Default Location 66
Settings 74
184
Contacts List 40
Context Menus 65, 67
Navigation 27
Using 27
Cookies
Emptying 119
Copying Contact 70
Corporate Email
Account Syncronization 147
Add Account 147
Creating a Playlist 98
Creating and sending
Messages 77
Customizing
Home screens 32
D
Data Roaming 135
Activate/Deactivate 135
Date and Time 152
Deleting
Multiple messages 80
Single message 80
Deleting a contact 66
Display
Icons 18
Settings 17
Status Bar 17
Display / Touch-Screen 163
Displaying your phone number 40
Do cell phones pose a health hazard? 154
Downloading
New application 106
E
EDGE Network 135
Email 82
Composing Internet Email 83
Configuring Internet Email Settings 83
Creating an Internet Email Account 82
Internet Email 82
Opening Internet Email 82, 83
Refreshing Internet Email Messages 83
Sending 73
Emergency Calls 164
Ending
A call 40
Entering Text 53
Using SWYPE 54
Erasing files from
Memory card 38
Exchange Email 84
Account Setup 84
Composing 85
Configuring Settings 86
Deleting Message 86
Opening 85
Refreshing Messages 85
Exposure to RF Signals 154
F
Factory Data Reset 147
Factory data reset 39
FCC Hearing Aid Compatibility (HAC) Regulations for
Wireless Devices 168
FCC Notice and Cautions 170
Fixed Dialing Numbers 137
185
Folder
Creating and Managing 35
Deleting 35
Renaming 35
Font
Style 140
Font Size
Caption 115
G
Gallery
Folder Options 93
Image Options 93
Opening 97
Get Friends 72
Getting Started 4
Battery 7
Battery Cover 5
Locking/Unlocking the Phone 11
microSD card 7
SIM Card 6
Switching Phone On/Off 11
Voice Mail 13
Gmail 87, 103
Composing a message 87
Opening 87
Refreshing 87
Signing In 87
Viewing 88
Google
Account Management Settings 146
Account Syncronization 146
Add Account 146
Adding a Sync Account 146
Create New Account 12
Retrieving Password 13
Set Search Engine 120
Signing into Your Account 12
Google mail
see also Gmail 87
Google Maps
Enabling a location source 104
Opening a map 105
Google Talk 31, 113
GPS & AGPS 163
Groups
Adding an Member to an Existing Group 74
Creating a new caller group 74
Editing a caller group 75
Removing an Entry 75
Settings 75
H
HAC Mode 138
Health and Safety Information 154
Hide Number 138
History tab 75
Hold
Placing a call on hold 47
Home 23
Home Key 21
Home Screen
Overview 23
Home Screen Wallpaper 140
Set as 94
Setting 92
Home screens
Customizing 32
186
Horizontal Calibration 140
I
Icons
Description 18
Indicator 18
Status 18
Images
Assigning as a Contact icon 94
Assigning as wallpaper 94
Importing and Exporting
To SIM card 73
In call
Options 46, 47
Indicator icons 18
International Call 42
International calls
Making 42
Internet 116
Search 117
Internet Email 82
J
Joining
Contact information 68
K
Kodak 93, 96
L
Lock Screen
Viewing Missed Calls 52
Lock Screen Wallpaper 140
Set as 94
Setting 92
Low battery indicator 9
M
Making
International calls 42
New call 40
Managing Applications 144
Clearing Application Cache 144
Moving Third-party Applications to Card 144
Uninstalling Third-party Applications 144
Market 106
Marking contact
As a default 69
Media Volume
Setting 139
Memo
Options 108
Memory card
Erasing files from the 38
Message
Options 78
Read 79
Reply 79
Threads 79
Message Search 80
Message threads 79
Messaging
Creating and sending 77
Creating and Sending Text Messages 77
Deleting a message 80
Google Mail 87
Icons on the Status Bar 77
Insert Smiley 78
Options 78
Settings 80
187
Signing into Google Mail 87
Skin 80
Text Templates 81
Types of Messages 77
Viewing new 79
microSD Card
Insertion 7
Removal 7
Microsoft Exchange 63, 82
Missed Call
Viewing from Lock Screen 52
Mobile AP 126
Activating 126
Connecting 127
Securing 127
Mobile Networks 135
Data Roaming 135
Mobile NetworksUse Packet Data 135
Mobile Web 116
Entering Text in the Mobile Web Browser
117
Navigating with the Mobile Web 116
Using Bookmarks 118
mounting the SD card 38
Move to SD card 145
Multi-Party Call 48
Dropping One Participant 49
Private conversation 49
Multi-party call
Setting up 48
Multi-party calls 48
Music
Making a Song a Ringtone 98
Music Player 97
Adding music 98
Creating a playlist 98
Editing a Playlist 99
Options 98
Playing Music 97
Removing music 99
Using Playlists 98
My Profile 73
N
Namecard
Send Via 69
Sending 69
Sending All 69
Navigating
Application Menus 26
Sub-Menus 27
Through Screens 25
Network connection
Adding a new 125
Network Mode
2G Network 135
3G Network 136
New applications
Downloading 106
News and Weather 112
Notification Bar 20
Using 20
Notification Volume
Setting 139
O
On/off switch 11
Operating Environment 167
188
Organizer
Calculator 101
Other Important Safety Information 170
Outlook 82
Synchronizing 147
Overview
Home Screen 23
P
Pause Dialing 42
Phone
Icons 18
Switching on/off 11
Phone number
Finding 40
Phone Options 139
Phone Ringtone 139
Set as 98
Photos
Options 92
Setting As 92
Sharing 92
Pico TTS 152
Power Control 10
Power Saver 109
Predictive Text
Using XT9 60
Primary Shortcuts 24
Adding and Deleting 33
R
Recently-used Applications
Accessing 27
Redialing the last number 42
Reducing Exposure
Hands-Free Kits and Other Accessories 156
Reset 147
Responsible Listening 165
Restore 147
Restricting Children's Access to Your Mobile device
170
Ringtone
Assinging a Song 98
Phone 139
Ringtone Volume
Setting 139
S
Samsung Keyboard
Settings 149
XT9 Advanced Settings 150
Samsung Keypad 57
ABC Mode 58
Changing the Input Type 58
Enabling 57
Entering Symbols 59
SYM Mode 59
Samsung Products and Recycling 161
SAR Certification Information 158
Save a Number
From Keypad 64
Screen
Home 23
Navigation 25
Screen Lock 141
Changing 141
Screen Rotation
Auto-Rotate 140
Screen Timeout 110, 140
189
Screens
Adding and Deleting 32
Customizing 32
Rearranging 32
SD card
Connecting to 38
mounting the 38
Unmounting 38
Search Engine 120
Select Language 148
Sending a Namecard 69
Setting an alarm 129
Setting up
Voicemail 13
Settings 131
Browser 119
Contact list 74
Display 17
Enabling the GPS Satellites 141
Enabling wireless network locations 140
Messaging 80
Shortcuts
Adding from Application Screen 33
Adding from Home Screen 34
Deleting from a Screen 34
Managing 33
Primary 24
SIM Card
Changing Exisitng PIN 142
Importing and Exporting 73
Insertion 6
Lock 142
Removal 6
SIM Card Lock
Setting Up 142
Skin 80
Smart Practices While Driving 159
Snapfish 93, 96
Song
Set as 98
Speakerphone
Turning on and off 47
Speed Dial
Changing an entry 43
Making a call 44
Removing an entry 43
Setting up entries 43
Standard Limited Warranty 172
Status Bar 17
Stay Awake 145
Sub-Menus
Navigation 27
Switching to a Bluetooth
During a call 47
SWYPE
123ABC Mode 56
Example 56
Swype
Advanced Settings 54, 149
Entering Text 56
Entering text using 54
Help 149
Settings 54, 149
Tutorial 149
Swype Keyboard
Using 54
190
System Volume
Setting 139
T
Tethering 133
Activating 133
Active Icon 133
Disconnecting 133
Text Input
Methods 53
Text Input Method
Selecting 53
Text Templates 81
Create Your Own 81
Text-to-speech
Configuration 151
Third-Party Applications 144
Uninstalling 108
Time Management
Calendar 128
Tools
Camera 89
Transferring Music Files 99
U
UL Certified Travel Charger 162
Understanding Your Phone 15
Back View 17
Display 17
Features 15
Front View 15
Home 23
Uninstalling
Third-party applications 108
Unmounting
SD card 38
Updates tab 76
USB Connection
Turn Off 38
USB Connections
As mass storage device 124
USB Settings
As mass storage device 124
Use GPS Satellites 105, 141
Use Packet Data 135
Use Wireless Networks 104, 141
Using Favorites
Adding Favorites 118
Deleting a Favorite 119
Editing Favorites 118
V
Vibrate 139
Vibration
Setup 139
Videos
Options 93
Voice Actions 22
Voice Input Recognition 151
Voice mail
Accessing 13
Accessing from another phone 13
Setting up 13
Volume Settings
Adjusting 139
VPN
Adding 134
Settings 133
191
W
Wait 42
Wait dialing 42
Wallpapers
Changing 35
Managing 35
Warranty Information 172
Web 116
History 119
Web applications
enable downloading 124
Widgets
Adding and Removing 34
Moving to a Different Screen 35
Settings 112
Wi-Fi
About 125
Activating 44, 125
Advanced settings 126
Connecting to 125
Deactivating 126
Manually scan for network 126
Status icons 126
WPA2 PSK 127
Y
Yahoo! 120
YouTube
High Qulaity 100
Settings 115

Navigation menu
