SERIES
1000
LAWN
TRACTORS
LTX 1040
LTX 1042
LTX 1045
LTX 1046
LTX 1046VT
LTX 1050
LTX 1050VT
SLTX 1050
SLTX 1054
42", 46" TWIN-BLADE
DECKS AND 50", 54"
TRIPLE-BLADE DECKS
WEIGHT 468 LBS.
TO 567 LBS.
HEAVY-DUTY 9-GAUGE
STEEL FRAME RAILS
ACCURATE, EASY-TO-
READ GAS GAUGE
PADDED FOOT RESTS
FENDER FLARES
WITH GLOVE BOX
SMARTJET™ DECK WASH
FULL LINE OF
ATTACHMENTS
AND ACCESSORIES
AVAILABLE
3- AND 5-YEAR LIMITED
WARRANTY†
FEATURES
TOUGHER BUILT TRACTORSSTRONGER
ENGINES
CLEANER CUT
SMOOTHER RIDE
Powerful Cub Cadet
professional-grade
engines by Kohler®
and Briggs & Stratton®
provide exceptional
cutting performance,
even in tall, thick grass.
The cutting system features a deep
deck that provides optimal grass lift and
mulching capability. The overlapping
blades ensure that no grass is left uncut,
and a wide discharge chute spreads grass
clippings evenly — providing a manicured
lawn without clumping or uncut grass.
A comfortable, ergonomic design features high-
back seats, extensive leg room, available arm rests,
rubber-cushioned foot pads and soft-touch controls —
delivering an easy and enjoyable mowing experience.
They’re built to last with fully welded steel
frames that are the thickest in the industry,
not to mention cast-iron front axles.
And each is backed by a
5-year warranty.
PREMIUM
OUTDOOR
EQUIPMENT
HOME OWNER
The most maneuverable
lawn tractor in its class
gets the job done faster
with a 12" turning radius.
It easily mows around
obstacles, reducing the
need for trimming and
backing up.
cubcadet.com
†See specifi cations for warranty information.
TIGHTER TURNING RADIUS
THAN ANY COMPETITOR
The Series 1000 Lawn Tractor is the most innovative and maneuverable lawn tractor in its category.
It features a best-in-class 12" turning radius, professional-grade engines, and welded steel frames that are
the thickest in the industry — giving you the dependability you deserve. Combine that with a premium
cutting system that leaves no grass uncut, and you’ve got a lawn tractor that can’t be beat, not to mention it
keeps the investment you call home looking beautiful.
PROOF THAT CUB CADET TRACTORS ARE BUILT BETTER
.
YOU CAN’T GET ANY BETTER.
™
03636_1000SS_REV1.indd 103636_1000SS_REV1.indd 1 12/10/08 8:47:24 AM12/10/08 8:47:24 AM
SERIES 1000 LAWN TRACTORS
ENGINE LTX 1040 LTX 1042 LTX 1045
Engine type 19 HP* Cub Cadet professional-grade
Kohler® Courage® single-cylinder
19 HP* Cub Cadet professional-grade
Kohler® Courage® single-cylinder
20 HP* Cub Cadet professional-grade
Kohler® Courage® single-cylinder
Cylinders/material 1/cast-iron sleeve
Lubrication Fully pressurized automotive-style oil pump w/spin-on oil fi lter
DRIVE SYSTEM
Drive system Automatic CVT w/cruise control Automatic w/heavy-duty hydrostatic pump Automatic w/heavy-duty hydrostatic pump
Engine to transmission Twin CVT drive belt Heavy-duty Kevlar® belt Heavy-duty Kevlar® belt
Cruise control Standard
Transmission housing Die-cast aluminum
STEERING
Steering Manual sector & pinion
Front axle Heavy-duty cast-iron w/dual grease fi ttings — 5-year limited warranty
Spindles 3/4" w/grease fi ttings
Ball joints 2 automotive-style
Rear axle diameter 3/4" diameter with dual steel drive hubs
Turning radius 12"
CHASSIS
Chassis type Robotically welded frame assembly
Frame Heavy-duty 9-gauge steel frame rails — 5-year limited warranty
Hood & grill Corrosion- and dent-resistant high-impact ABS
Fender & bumper Steel fender w/grab handles Steel fender w/grab handles
and glove box
Steel fender w/grab handles
and glove box
ELECTRICAL SYSTEM
Alternator 15 amp. regulated
Battery 12V/heavy-duty 190 cold crank amp.
Charging system Flywheel alternator
Headlights Standard
System monitor package Digital hour meter, change oil service minder, battery voltage monitor, park brake and PTO start sequence LEDs
Safety systems Neutral start, operator presence, reverse safety switch, brake pedal lock, RevTEK™ reverse mowing technology
OPERATION
PTO clutch Manual lever control
Deck lift Manual/12-position
Brakes Automotive-style disc
Seat
Mid-back seat,
12 positions with
6" seat travel
High-back seat,
12 positions with
6" seat travel
High-back seat,
12 positions with
6" seat travel
ADDITIONAL SPECIFICATIONS
Front tires 15" x 6"
Rear tires 20" x 8"
Forward speed 0 – 5.2 mph
Reverse speed 0 – 2.3 mph
Fuel tank 3.5 gal. easy fi ll, rustproof
Engine oil 1.6 qt.
Transmission oil 19 oz. 1.9 qt. 1.9 qt.
Wheelbase 47.5"
Overall length 69"
Estimated weight w/deck 468 lbs. 498 lbs. 510 lbs.
MOWING DECK
Cutting width/blades 42" heavy-duty twin blades 42" heavy-duty twin blades 46" heavy-duty twin blades
Deck cutting height 1.5" – 4"
Mower deck construction 12-gauge steel
Mower drive system Heavy-duty Kevlar® belt
Anti-scalping 4 wheels
Mulch kit Optional
Deck spindles Die-cast aluminum spindle housings w/ball bearings and grease fi ttings for long life
Deck pulleys All steel w/heavy-duty bearings
Deck attach/removal QuickAttach™ in seconds, no tools required
Deck wash Patented SmartJet™ high-pressure deck washing system
WARRANTY†
3-year/120-hr and 5-year/500-hr limited warranty
†Cub Cadet will provide a limited warranty for a period of 5 years or 500 hours, whichever occurs fi rst, for the frame and pivoting cast-iron front axle on all new
Cub Cadet Series 1000 tractors. For complete details on 3-year and 5-year limited warranties, see your Cub Cadet Independent Dealer or operator’s manual.
3 years or 120 hours, whichever comes fi rst. Warranty does not cover normal wear on parts, batteries, and frame and front axle. Frame and front axle are covered
for 5 years or 500 hours, whichever comes fi rst. See operator’s manual for details on Cub Cadet’s Manufacturer’s Limited Warranty for Series 1000 Lawn Tractors.
03636_1000SS_REV1.indd 203636_1000SS_REV1.indd 2 12/10/08 8:47:55 AM12/10/08 8:47:55 AM
ENGINE LTX 1046 LTX 1046VT LTX 1050 LTX 1050VT
Engine type
22 HP* Cub Cadet
professional-grade
Kohler® Courage® V-Twin OHV
23 HP* Cub Cadet
professional-grade
Briggs & Stratton® V-Twin OHV
22 HP* Cub Cadet
professional-grade
Kohler® Courage® V-Twin OHV
24 HP* Cub Cadet
professional-grade
Briggs & Stratton® V-Twin OHV
Cylinders/material 2/cast-iron sleeve
Lubrication Fully pressurized automotive-style oil pump w/spin-on oil fi lter
DRIVE SYSTEM
Drive system Automatic w/heavy-duty hydrostatic pump
Engine to transmission Heavy-duty Kevlar® belt
Cruise control Standard
Transmission housing Die-cast aluminum
STEERING
Steering Manual sector & pinion
Front axle Heavy-duty cast-iron w/dual grease fi ttings — 5-year limited warranty
Spindles 3/4" w/grease fi ttings
Ball joints 2 automotive-style
Rear axle diameter 3/4" diameter with dual steel drive hubs
Turning radius 12"
CHASSIS
Chassis type Robotically welded frame assembly
Frame Heavy-duty 9-gauge steel frame rails — 5-year limited warranty
Hood & grill Corrosion- and dent-resistant high-impact ABS
Fender & bumper Steel fender w/grab handles and glove box
ELECTRICAL SYSTEM
Alternator 15 amp. regulated
Battery 12V/H.D. 235 cold crank amp. 12V/H.D. 235 cold crank amp. 12V/H.D. 190 cold crank amp. 12V/H.D. 190 cold crank amp.
Charging system Flywheel alternator
Headlights Standard
System monitor package Digital hour meter, change oil service minder, battery voltage monitor, park brake and PTO start sequence LEDs
Safety systems Neutral start, operator presence, reverse safety switch, brake pedal lock, RevTEK™ reverse mowing technology
OPERATION
PTO clutch Electronic fi ngertip engagement for smooth operation of deck or attachments
Deck lift Manual/12-position
Brakes Automotive-style disc
Seat High-back seat, 12 positions with 6" seat travel
ADDITIONAL SPECIFICATIONS
Front tires 15" x 6"
Rear tires 20" x 8"20" x 8" 20" x 10"20" x 10"
Forward speed 0 – 5.2 mph
Reverse speed 0 – 2.3 mph
Fuel tank 3.5 gal. easy fi ll, rustproof
Engine oil 1.9 qt.
Transmission oil 2.0 qt.
Wheelbase 47.5"
Overall length 69"
Estimated weight w/deck 513 lbs. 513 lbs. 548 lbs. 548 lbs.
MOWING DECK
Cutting width/blades 46" heavy-duty twin blades 46" heavy-duty twin blades 50" heavy-duty triple blades 50" heavy-duty triple blades
Deck cutting height 1.5" – 4"
Mower deck construction 12-gauge steel
Mower drive system Heavy-duty Kevlar® belt
Anti-scalping 4 wheels
Mulch kit Optional
Deck spindles Die-cast aluminum spindle housings w/ball bearings and grease fi ttings for long life
Deck pulleys All steel w/heavy-duty bearings
Deck attach/removal QuickAttach™ in seconds, no tools required
Deck wash Patented SmartJet™ high-pressure deck washing system
WARRANTY†
3-year/120-hr and 5-year/500-hr limited warranty
*as rated by engine manufacturer †See your local Cub Cadet Independent Dealer for warranty details.
03636_1000SS_REV1.indd 303636_1000SS_REV1.indd 3 12/10/08 8:47:56 AM12/10/08 8:47:56 AM
ENGINE SLTX 1050 SLTX 1054
Engine type 25 HP* Cub Cadet professional-grade
Kohler® Courage® V-Twin OHV
26 HP* Cub Cadet professional-grade
Kohler® Courage® V-Twin OHV
Cylinders/material 2/cast-iron sleeve
Lubrication Fully pressurized automotive-style oil pump w/spin-on oil fi lter
DRIVE SYSTEM
Drive system Automatic w/heavy-duty hydrostatic pump
Engine to transmission Heavy-duty Kevlar® belt
Cruise control Standard
Transmission housing Die-cast aluminum
STEERING
Steering Manual sector & pinion
Front axle Heavy-duty cast-iron w/dual grease fi ttings — 5-year limited warranty
Spindles 3/4" w/grease fi ttings
Ball joints 2 automotive-style
Rear axle diameter 3/4" diameter with dual steel wheel drive hubs
Turning radius 12"
CHASSIS
Chassis type Robotically welded frame assembly
Frame Heavy-duty 9-gauge steel frame rails — 5-year limited warranty
Hood & grill Corrosion- and dent-resistant high-impact ABS
Fender & bumper Steel fender w/twin rear fender fl ares w/grab handles and glove box and tubular steel bumper
ELECTRICAL SYSTEM
Alternator 15 amp. regulated
Battery 12V/H.D. 235 cold crank amp.
Charging system Flywheel alternator
Headlights Standard
System monitor package Digital hour meter, change oil service minder, battery voltage monitor, park brake and PTO start sequence LEDs
Safety systems Neutral start, operator presence, reverse safety switch, brake pedal lock, RevTEK™ reverse mowing technology
OPERATION
PTO clutch Electronic fi ngertip engagement for smooth operation of deck or attachments
Deck lift Manual/6-position/spring-assisted
Brakes Automotive-style disc
Seat Deluxe high-back seat, 12-position fi ngertip adjustment mechanism with 6" of travel.
(Arm rests standard on SLTX 1054)
ADDITIONAL SPECIFICATIONS
Front tires 16" x 6.5"
Rear tires 22" x 9.5"
Forward speed 0 – 5.2 mph
Reverse speed 0 – 2.3 mph
Fuel tank 3.5 gal. easy fi ll, rustproof
Engine oil 1.9 qt.
Transmission oil 2.0 qt.
Wheelbase 47.5"
Overall length 69"
Estimated weight w/deck 548 lbs. 567 lbs.
MOWING DECK
Cutting width/blades 50” heavy-duty triple blades 54" heavy-duty triple blades
Deck cutting height 1.5" – 4"
Mower deck construction 12-gauge steel
Mower drive system Heavy-duty Kevlar® belt
Anti-scalping 4 wheels, 1 roller (front)
Mulch kit Optional
Deck spindles Die-cast aluminum spindle housings w/ball bearings and grease fi ttings for long life
Deck pulleys All steel w/heavy-duty bearings
Deck attach/removal QuickAttach™ in seconds, no tools required
Deck wash Patented SmartJet™ high-pressure deck washing system
WARRANTY†
3-year/120-hr and 5-year/500-hr limited warranty
*as rated by engine manufacturer †See your local Cub Cadet Independent Dealer for warranty details.
This brochure is for advertisement purposes only. The product depictions are not meant to be used or relied upon as a substitute for the safety and use information that is published in the respective operator’s
manual. Before operating
the machine, read, understand and follow all instructions in the manual and on the machine. Specifi cations and programs are subject to change without notice. Images may not refl ect dealer inventory and/or unit specifi cations.
773-03636 Printed in U.S.A. 12/08 © 2009 Cub Cadet
