FD-3500-B

FD-3500-F

SHIMANO SORA Front Derailleur

(For Double Gear)

(For Double Gear)

Mar.-2012-3415

©Shimano Inc.D

A: Same parts.

B: Parts are usable, but differ in materirals, appearance, finish, size, etc.

Absence of mark indicates non-interchangeability.

5N

G

0000000-2110-003

5N

G

0000000-2120-001

DESCRIPTION

SHIMANO

CODE NO.

ITEM

NO. INTERCHANGEABILITY

FD-2300

FD-4600

FD-3400

1

2

3

4

5

6

7

8

9

Y5NG98010

Y5NG98020

Y59L19300

Y5NG98030

Y5NG98040

Y5JD98040

Y5JD98050

Y59L19100

Y5C252200

Stroke Adjust Screws (M4 x 13) & Plate

Cable Fixing Bolt Unit

Clamp Bolt（M5 x 16.5）

Clamp Band Adapter (2 pcs.) for S-size / φ28.6 mm (1-1/8”)

Clamp Bolt (M5 x 15.2) & Radius Washer for Brazed-on Type

SM-AD11 Clamp Band Unit φ31.8 mm (1-1/4”) for Brazed-on Type

SM-AD15 Clamp Band Unit φ34.9 mm (1-3/8”) for Brazed-on Type

Clamp Bolt (M5 x 17.5) for SM-AD11 / AD15

Clamp Bolt （M5 x 15.2） for SM-AD11 / AD15

A

A

A

A

A

A

B

B

B

B

A

A

A

B

A

A

A

A

A

SM-AD11

SM-AD15

Band Type

Brazed-on Type

5

1

2

4

1

2

3

8

6

9

7

8

9
