RD-M781 (GS/SGS)

RD-M781-D (GS/SGS)

SHIMANO DEORE XT Rear Derailleur

Silver / Black Version

Silver / Black Version

Mar.-2012-3320

©Shimano Inc.D

A: Same parts.

B: Parts are usable, but differ in materirals, appearance, finish, size, etc.

Absence of mark indicates non-interchangeability.

DESCRIPTION

SHIMANO

CODE NO.

ITEM

NO.

1

2

3

4

5

6

7

8

9

10

11

Y5Y098010

Y50Y17000

Y5XP98030

Y5W798030

Y5W798020

Y5UC14000

Y5W722000

Y5Y098020

Y5Y098030

Y5XF98060

Y5XC09100

Y5Y010000

Y53M24400

Bracket Axle Unit (for normal type)

B-Axle2 (for Direct Mount type)

B-Tension Adjusting Screw (M4 x 18) & Plate

Cable Fixing Bolt (M5 x 8) & Plate

Stroke Adjusting Screws & Plate

P-Seal Ring

P-Tension Spring

Outer Plate Assembly (GS-Type)

Outer Plate Assembly (SGS-Type)

Guide & Tension Pulley Set

Inner Plate (GS-Type)

Inner Plate (SGS-Type)

Pulley Bolt (M5 x 13.95)

5Y00000000-6110-003

INTERCHANGEABILITY

RD-M670

RD-M981

B

A

B

B

A

A

A

A

A

A

B

B

A

A

8

10

SGS Type

3

4

5

1

2

6

7

11

8

9

11

10

M4 x 16.5mm

M4 x 18.7mm
