Simba JDBC Driver with SQL
Connector for Google BigQuery
Installation and Configuration Guide
Simba Technologies Inc.
Version 1.1.7
August 15, 2018
Copyright © 2018 Simba Technologies Inc. All Rights Reserved.
Information in this document is subject to change without notice. Companies, names
and data used in examples herein are fictitious unless otherwise noted. No part of this
publication, or the software it describes, may be reproduced, transmitted, transcribed,
stored in a retrieval system, decompiled, disassembled, reverse-engineered, or
translated into any language in any form by any means for any purpose without the
express written permission of Simba Technologies Inc.
Trademarks
Simba, the Simba logo, SimbaEngine, and Simba Technologies are registered
trademarks of Simba Technologies Inc. in Canada, United States and/or other
countries. All other trademarks and/or servicemarks are the property of their respective
owners.
Contact Us
Simba Technologies Inc.
938 West 8th Avenue
Vancouver, BC Canada
V5Z 1E5
Tel: +1 (604) 633-0008
Fax: +1 (604) 633-0004
www.simba.com
www.simba.com 2
Installation and Configuration Guide
About This Guide
Purpose
The Simba JDBC Driver with SQL Connector for Google BigQuery Installation and
Configuration Guide explains how to install and configure the Simba JDBC Driver with
SQL Connector for Google BigQuery on all supported platforms. The guide also
provides details related to features of the driver.
Audience
The guide is intended for end users of the Simba JDBC Driver for Google BigQuery.
Knowledge Prerequisites
To use the Simba JDBC Driver for Google BigQuery, the following knowledge is
helpful:
lFamiliarity with the platform on which you are using the Simba JDBC Driver for
Google BigQuery
lAbility to use the data store to which the Simba JDBC Driver for Google
BigQuery is connecting
lAn understanding of the role of JDBCtechnologies in connecting to a data store
lExperience creating and configuring JDBCconnections
lExposure to SQL
Document Conventions
Italics are used when referring to book and document titles.
Bold is used in procedures for graphical user interface elements that a user clicks and
text that a user types.
Monospace font indicates commands, source code or contents of text files.
Note:
A text box with a pencil icon indicates a short note appended to a paragraph.
www.simba.com 3
Installation and Configuration Guide
Important:
A text box with an exclamation mark indicates an important comment related to the
preceding paragraph.
www.simba.com 4
Installation and Configuration Guide
Table of Contents
About the Simba JDBC Driver for Google BigQuery 7
System Requirements 8
Simba JDBC Driver for Google BigQuery Files 9
Installing and Using the Simba JDBC Driver for Google BigQuery 10
Referencing the JDBCDriver Libraries 10
Registering the Driver Class 11
Building the Connection URL 12
Configuring Authentication 13
Using a Google User Account 13
Using a Google Service Account 14
Using Pre-Generated Access and Refresh Tokens 15
Using Application Default Credentials 15
Configuring Logging 17
Features 19
SQL Connector 19
Data Types 19
Nested and Repeated Records 20
Arrays 21
Security and Authentication 21
Catalog and Schema Support 22
Large Result Set Support 22
Write-Back 23
Positional Parameters 24
Driver Configuration Options 25
AllowLargeResults 25
DefaultDataset 26
KMSKeyName 26
LargeResultDataset 27
LargeResultTable 27
LogLevel 27
LogPath 28
MaxResults 29
www.simba.com 5
Installation and Configuration Guide
OAuthAccessToken 29
OAuthClientId 29
OAuthClientSecret 30
OAuthPvtKeyPath 30
OAuthRefreshToken 30
OAuthServiceAcctEmail 31
OAuthType 31
ProjectId 31
ProxyHost 32
ProxyPassword 32
ProxyPort 32
ProxyUsername 33
QueryDialect 33
RequestGoogleDriveScope 33
StringColumnLength 34
Timeout 34
TimestampFallback 34
useQueryCache 35
Third-Party Trademarks 36
Third-Party Licenses 37
www.simba.com 6
Installation and Configuration Guide
About the Simba JDBC Driver for Google BigQuery
The Simba JDBC Driver for Google BigQuery enables Business Intelligence (BI),
analytics, and reporting on data that is stored in BigQuery. The driver complies with the
JDBC 4.1 and 4.2 data standards.
JDBC is one of the most established and widely supported APIs for connecting to and
working with databases. At the heart of the technology is the JDBC driver, which
connects an application to the database. For more information about JDBC, see Data
Access Standards on the Simba Technologies
website:https://www.simba.com/resources/data-access-standards-glossary.
This guide is suitable for users who want to access data residing within BigQuery from
their desktop environment. Application developers might also find the information
helpful. Refer to your application for details on connecting via JDBC.
www.simba.com 7
Installation and Configuration Guide About the Simba JDBC Driver for Google
BigQuery
System Requirements
Each machine where you use the Simba JDBC Driver for Google BigQuery must have
Java Runtime Environment (JRE) 7.0 or 8.0 installed. If you are using the driver with
JDBC API version 4.2, then you must use JRE 8.0.
www.simba.com 8
Installation and Configuration Guide System Requirements
Simba JDBC Driver for Google BigQuery Files
The Simba JDBC Driver for Google BigQuery is delivered in the following two ZIP
archives, where [Version] is the version number of the driver:
lBigQueryJDBC41_[Version].zip
lBigQueryJDBC42_[Version].zip
The archive contains the driver supporting the JDBC API version indicated in the
archive name, as well as release notes and third-party license information.
www.simba.com 9
Installation and Configuration Guide Simba JDBC Driver for Google BigQuery
Files
Installing and Using the Simba JDBC Driver for Google
BigQuery
To install the Simba JDBC Driver for Google BigQuery on your machine, extract the
files from the appropriate ZIParchive to the directory of your choice.
Important:
If you received a license file through email, then you must copy the file into the
same directory as the driver JAR file before you can use the Simba JDBC Driver
for Google BigQuery.
To access a BigQuery data store using the Simba JDBC Driver for Google BigQuery,
you need to configure the following:
lThe list of driver library files (see Referencing the JDBCDriver Libraries on page
10)
lThe Driver or DataSource class (see Registering the Driver Class on page
11)
lThe connection URL for the driver (see Building the Connection URL on page 12
)
Referencing the JDBCDriver Libraries
Before you use the Simba JDBC Driver for Google BigQuery, the JDBCapplication or
Java code that you are using to connect to your data must be able to access the driver
JARfiles. In the application or code, specify all the JAR files that you extracted from
the ZIP archive.
Using the Driver in a JDBC Application
Most JDBCapplications provide a set of configuration options for adding a list of driver
library files. Use the provided options to include all the JAR files from the ZIP archive
as part of the driver configuration in the application. For more information, see the
documentation for your JDBC application.
Using the Driver in Java Code
You must include all the driver library files in the class path. This is the path that the
Java Runtime Environment searches for classes and other resource files. For more
information, see "Setting the Class Path" in the appropriate Java SE Documentation.
www.simba.com 10
Installation and Configuration Guide Installing and Using the Simba JDBC Driver
for Google BigQuery
For Java SE7:
lFor Windows:
http://docs.oracle.com/javase/7/docs/technotes/tools/windows/classpath.html
lFor Linux and Solaris:
http://docs.oracle.com/javase/7/docs/technotes/tools/solaris/classpath.html
For Java SE 8:
lFor Windows:
http://docs.oracle.com/javase/8/docs/technotes/tools/windows/classpath.html
lFor Linux and Solaris:
http://docs.oracle.com/javase/8/docs/technotes/tools/solaris/classpath.html
Registering the Driver Class
Before connecting to your data, you must register the appropriate class for your
application.
The following is a list of the classes used to connect the Simba JDBC Driver for
Google BigQuery to BigQuery data stores. The Driver classes extend
java.sql.Driver, and the DataSource classes extend
javax.sql.DataSource and javax.sql.ConnectionPoolDataSource.
To support JDBC 4.1, classes with the following fully-qualified class names (FQCNs)
are available:
lcom.simba.googlebigquery.jdbc41.Driver
lcom.simba.googlebigquery.jdbc41.DataSource
To support JDBC 4.2, classes with the following FQCNs are available:
lcom.simba.googlebigquery.jdbc42.Driver
lcom.simba.googlebigquery.jdbc42.DataSource
The following sample code shows how to use the DriverManager to establish a
connection for JDBC 4.0:
private static Connection connectViaDM() throws Exception
{
Connection connection = null;
connection = DriverManager.getConnection(CONNECTION_URL);
return connection;
}
www.simba.com 11
Installation and Configuration Guide Installing and Using the Simba JDBC Driver
for Google BigQuery
The following sample code shows how to use the DataSource class to establish a
connection:
private static Connection connectViaDS() throws Exception
{
Connection connection = null;
DataSource ds = new
com.simba.googlebigquery.jdbc41.DataSource();
ds.setURL(CONNECTION_URL);
connection = ds.getConnection();
return connection;
}
Building the Connection URL
Use the connection URL to supply connection information to the data store that you are
accessing. The following is the format of the connection URL for the Simba JDBC
Driver for Google BigQuery:
jdbc:bigquery://[Host]:[Port];ProjectId=[Project];OAuthType=
[AuthValue];[Property1]=[Value1];[Property2]=[Value2];...
The variables are defined as follows:
l[Host] is the DNS or IP address of the server.
l[Port] is the number of the TCP port to connect to. Specifying the port number is
optional if you are connecting to port 443.
l[Project] is the name of your BigQuery project.
l[AuthValue] is a number that specifies the type of authentication used by the
driver. For more information, see OAuthType on page 31 and Configuring
Authentication on page 13.
l[Property1..N] and [Value1..N] are additional connection properties supported by
the driver. For a list of the properties available in the driver, see Driver
Configuration Options on page 25.
Important:
lProperties are case-sensitive.
lDo not duplicate properties in the connection URL.
www.simba.com 12
Installation and Configuration Guide Installing and Using the Simba JDBC Driver
for Google BigQuery
Configuring Authentication
The Simba JDBC Driver for Google BigQuery uses the OAuth 2.0 protocol for
authentication and authorization. It authenticates your connection through Google
OAuth APIs. You can configure the driver to provide your credentials and authenticate
the connection to the database using one of the following methods:
lUsing a Google User Account on page 13
lUsing a Google Service Account on page 14
lUsing Pre-Generated Access and Refresh Tokens on page 15
lUsing Application Default Credentials on page 15
Using a Google User Account
You can configure the driver to authenticate the connection with a Google user
account.
You must provide your Google user account credentials to connect to the server. For
more information about authenticating through OAuth 2.0 with a Google user account,
see "Using OAuth 2.0 to Access Google APIs" in the Google Identity Platform
documentation: https://developers.google.com/identity/protocols/OAuth2.
To configure user account authentication:
1. Connect to the server using a connection URL written in the following format:
jdbc:bigquery://[Host]:[Port];ProjectId=[Project];
OAuthType=1;
The variables are defined as follows:
l[Host] is the DNS or IP address of the server.
l[Port] is the number of the TCP port to connect to. Specifying the port
number is optional if you are connecting to port 443.
l[Project] is the name of your BigQuery project.
For example:
jdbc:bigquery://https://www.googleapis.com/bigquery/v2:4
43;ProjectId=MyBigQueryProject;OAuthType=1;
The driver returns a connection URL, and requests an access token.
www.simba.com 13
Installation and Configuration Guide Configuring Authentication
2. In a web browser, navigate to the connection URL, and provide your Google
account name and password for authentication.
The browser returns an access token.
3. In the driver, type or paste the access token and press ENTER.
For more information about connection URL syntax, see Building the Connection URL
on page 12.
Using a Google Service Account
You can configure the driver to authenticate the connection with a Google service
account. The service account can handle the authentication process so that no user
input is required.
You must provide a Google service account email address and the full path to a private
key file for the service account. You can download the private key file from the Google
APIconsole web page. For more information about OAuth authentication using a
service account, see "Using OAuth 2.0 for Server to Server Applications"in the Google
Identity Platform
documentation:
https://developers.google.com/identity/protocols/OAuth2ServiceAccount.
To configure service account authentication:
1. Set the OAuthType property to 0.
2. Set the ProjectID property to the name of your BigQuery project.
3. Set the OAuthServiceAcctEmail property to your Google service account
email address.
4. Set the OAuthPvtKeyPath property to the full path to the key file that is used to
authenticate the service account email address. This parameter supports keys in
.pl2 or .json format.
For example, the following connection URLauthenticates the connection using a
service account:
jdbc:bigquery://https://www.googleapis.com/bigquery/v2:443;
ProjectId=MyBigQueryProject;OAuthType=0;
OAuthServiceAcctEmail=bqtest1@data-driver-
testing.iam.gserviceaccount.com;
OAuthPvtKeyPath=C:\SecureFiles\ServiceKeyFile.p12;
For more information about connection URLsyntax, see Building the Connection URL
on page 12.
www.simba.com 14
Installation and Configuration Guide Configuring Authentication
Using Pre-Generated Access and Refresh Tokens
You can configure the driver to authenticate the connection using access or refresh
tokens that have already been generated from the Google Authorization Server. When
using this method, you can authenticate your connection by providing an access token,
or by providing a refresh token along with a client ID and client secret.
For information about obtaining access and refresh tokens, see "Using OAuth 2.0 to
Access Google APIs" in the Google Identity Platform documentation:
https://developers.google.com/identity/protocols/OAuth2.
Important:
When generating the tokens to access BigQuery, you must specify the
https://www.googleapis.com/auth/bigquery scope. If you are working
with federated tables, you should also specify the
https://www.googleapis.com/auth/cloud-platform scope.
To configure authentication using an access or refresh token:
1. Set the OAuthType property to 2.
2. Set the ProjectID property to the name of your BigQuery project.
3. Do one of the following:
lSet OAuthAccessToken to your access token.
lOr, set OAuthRefreshToken to your refresh token.
4. If you are using a refresh token, set the OAuthClientId property to to your
client ID and set the OAuthClientSecret property to your client secret.
For example, the following connection URLauthenticates the connection using a
refresh token:
jdbc:bigquery://https://www.googleapis.com/bigquery/v2:443;
OAuthType=2;ProjectId=MyBigQueryProject;
OAuthAccessToken=a25c7cfd36214f94a79d;OAuthRefreshToken=1jt9
Pcyq8pr3lvu143pfl4r86;OAuthClientId=11b5516f132211e6;OAuthCl
ientSecret=bCD+E1f2Gxhi3J4klmN;
For more information about connection URL syntax, see Building the Connection URL
on page 12.
Using Application Default Credentials
You can configure the driver to authenticate the connection using credentials obtained
through Application Default Credentials on the environment, if they are available. For
www.simba.com 15
Installation and Configuration Guide Configuring Authentication
information about how to configure Application Default Credentials, see "Google
Application Default Credentials" in the Google Identity Platform documentation:
https://developers.google.com/identity/protocols/application-default-credentials.
For more information about authenticating through OAuth 2.0, see "Using OAuth 2.0 to
Access Google APIs"in the Google Identity Platform documentation:
https://developers.google.com/identity/protocols/OAuth2.
To configure authentication using Application Default Credentials:
1. Set the OAuthType property to 3.
2. Set the ProjectID property to the name of your BigQuery project.
For example:
jdbc:bigquery://https://www.googleapis.com/bigquery/v2:443;
OAuthType=3;ProjectId=MyBigQueryProject;
For more information about connection URL syntax, see Building the Connection URL
on page 12.
www.simba.com 16
Installation and Configuration Guide Configuring Authentication
Configuring Logging
To help troubleshoot issues, you can enable logging in the driver.
Important:
Only enable logging long enough to capture an issue. Logging decreases
performance and can consume a large quantity of disk space.
In the connection URL, set the LogLevel key to enable logging at the desired level of
detail. The following table lists the logging levels provided by the Simba JDBC Driver
for Google BigQuery, in order from least verbose to most verbose.
LogLevel Value Description
0Disable all logging.
1Log severe error events that lead the driver to abort.
2Log error events that might allow the driver to continue
running.
3Log events that might result in an error if action is not taken.
4Log general information that describes the progress of the
driver.
5Log detailed information that is useful for debugging the
driver.
6Log all driver activity.
To enable logging:
1. Set the LogLevel property to the desired level of information to include in log
files.
2. Set the LogPath property to the full path to the folder where you want to save
log files. To make sure that the connection URLis compatible with all
JDBCapplications, escape the backslashes (\) in your file path by typing
another backslash.
www.simba.com 17
Installation and Configuration Guide Configuring Logging
For example, the following connection URLenables logging level 3 and saves
the log files in the C:\temp folder:
jdbc:bigquery://localhost;LogLevel=3;LogPath=C:\\temp
3. To make sure that the new settings take effect, restart your JDBC application and
reconnect to the server.
The Simba JDBC Driver for Google BigQuery produces the following log files in the
location specified in the LogPath property:
lABigQuery_driver.log file that logs driver activity that is not specific to a
connection.
lABigQuery_connection_[Number].log file for each connection made to
the database, where [Number] is a number that identifies each log file. This file
logs driver activity that is specific to the connection.
If the LogPath value is invalid, then the driver sends the logged information to the
standard output stream (System.out).
To disable logging:
1. Set the LogLevel property to 0.
2. To make sure that the new setting takes effect, restart your JDBC application and
reconnect to the server.
www.simba.com 18
Installation and Configuration Guide Configuring Logging
Features
More information is provided on the following features of the Simba JDBC Driver for
Google BigQuery:
lSQL Connector on page 19
lData Types on page 19
lNested and Repeated Records on page 20
lArrays on page 21
lSecurity and Authentication on page 21
lCatalog and Schema Support on page 22
lLarge Result Set Support on page 22
lWrite-Back on page 23
lPositional Parameters on page 24
SQL Connector
The SQL Connector feature of the driver enables applications to execute standard SQL
queries or legacy BigQuery SQL queries against the database.
The driver does not support query prefixes, and instead determines which dialect to
use based on the QueryDialect connection setting. By default, QueryDialect is
set to SQL so that the driver executes queries using standard SQL syntax. For more
information, see QueryDialect on page 33.
Data Types
The Simba JDBC Driver for Google BigQuery supports many common data formats,
converting between BigQuery, SQL, and Java data types.
The following table lists the supported data type mappings.
Note:
For NUMERIC data, the driver always returns 38 for the precision and 9 for the
scale.
BigQuery Type SQL Type Java Type
BOOL SQL_BOOLEAN BOOLEAN
www.simba.com 19
Installation and Configuration Guide Features
BigQuery Type SQL Type Java Type
BYTES SQL_VARBINARY BYTE[]
DATE SQL_DATE DATE
DATETIME SQL_VARCHAR STRING
FLOAT64 SQL_DOUBLE DOUBLE
INT64 SQL_BIGINT BIGINTEGER
NUMERIC SQL_NUMERIC BIGDECIMAL
STRING SQL_VARCHAR STRING
TIME SQL_TIME TIME
TIMESTAMP SQL_TIMESTAMP TIMESTAMP
Nested and Repeated Records
The Simba JDBC Driver for Google BigQuery fully supports nested and repeated
records.
The Standard SQLsyntax represents the sub-components of record data as nested
sub-types. In the example below, city and years belong to the base record type of
address.
If the record column is specified in a query projection list, the driver returns the base
record as a text representation of the JSON record object, and no flattening occurs.
The dot operator (.) is used to select sub-components. For example, to select from
city, the column name address.city should be used.
{
"address":[
{
"city":"Vancouver",
"years":5
}
],
"name":"Google"
}
www.simba.com 20
Installation and Configuration Guide Features
In Legacy SQL, sub-components of record types are implicitly flattened and are
represented as individual attributes. In the example below, the sub-components of
city and years of the record address are represented as individual columns of
address_city and address_years.
{
"address_city":"Vancouver",
"address_years":"5",
"name":"Google"
}
Arrays
The Simba JDBC Driver for Google BigQuery fully supports array data types. The
driver returns the base array type as a text representation of the JSON array object.
For example, the SQL statement SELECT [1,2,3] returns the following JSON:
{
"v":[
{
"v":"1",
},
{
"v":"2",
},
{
"v":"3"
}
]
}
Security and Authentication
To protect data from unauthorized access, BigQuery data stores require all
connections to be authenticated using the OAuth 2.0 protocol. The Simba JDBC Driver
for Google BigQuery provides mechanisms that allow you to complete an OAuth 2.0
authentication flow using a personal Google account, a Google service account, or
Application Default Credentials. You can also specify an access token or refresh token
that you have already generated from the Google Authorization Server, and use those
credentials to connect to Google BigQuery.
www.simba.com 21
Installation and Configuration Guide Features
When you connect to BigQuery using a personal Google account, a Google service
account, or Application Default Credentials, the driver automatically initiates an OAuth
2.0 authentication flow. The driver retrieves an access token based on the credentials
specified in the connection URL, and then uses the token to authenticate the
connection to the database. When you connect using an access token or refresh token,
the driver authenticates the connection to BigQuery without going through an OAuth
2.0 authentication flow.
For detailed driver configuration instructions, see Configuring Authentication on page
13.
For more information about OAuth 2.0, see "Using OAuth 2.0 to Access Google APIs"
in the Google Identity Platform documentation:
https://developers.google.com/identity/protocols/OAuth2.
Catalog and Schema Support
The Simba JDBC Driver for Google BigQuery supports both catalogs and schemas to
make it easy for the driver to work with various JDBC applications. Projects are
mapped to catalogs, and table datasets are mapped to schemas. For more information,
see ProjectId on page 31. The driver provides access to all of the schemas/databases
that are listed under this catalog, ensuring compatibility with standard BI tools.
Large Result Set Support
Normally, when you execute queries using Legacy SQL, result sets that are larger than
128MB (compressed) are not supported. To enable large result sets in Legacy SQL,
the Simba JDBC Driver for Google BigQuery supports the AllowLargeResults
option in BigQuery job configurations. Large result sets are always enabled in
Standard SQL, so the AllowLargeResults option is not relevant when you execute
queries using Standard SQL.
Important:
Working with large data sets may cause you to reach the query limits defined in
Google BigQuery. For information about query limits, see the following sections in
the Google BigQuery documentation:
l"Queries" in Quota Policy:https://cloud.google.com/bigquery/quotas.
l"Limits" in Running Interactive and Batch Queries:
https://cloud.google.com/bigquery/docs/running-queries.
www.simba.com 22
Installation and Configuration Guide Features
In Legacy SQL
By default, when working in Legacy SQL, the driver stores large result sets using a
temporary hidden dataset named "_simba_jdbc" and a temporary table with a name
consisting of the prefix "temp_table_" followed by the time of table creation. These
default temporary datasets and tables are deleted after 24 hours.
If you want to store large result sets for longer than 24 hours, you can configure the
driver to create and use persistent tables and datasets. To do this, set the
LargeResultTable and LargeResultDataset properties to the names of the
table and dataset, respectively. Query results are stored in these tables until you
overwrite them by running another query with the same table and dataset specified.
Important:
When AllowLargeResults is enabled, all query results are written to and read
from the temporary tables described above, regardless of the query and its result
size. Because of this, the result cache is not available for subsequent queries, and
you are billed for every query that you make.
In Standard SQL
When you execute queries using Standard SQL, large results are always supported,
and the AllowLargeResults option is not used. All query results, regardless of
size, are stored in temporary tables that serve as a snapshot in time. Note that the
result cache is always available for subsequent queries when you use Standard SQL.
Write-Back
The Simba JDBC Driver for Google BigQuery supports Data Manipulation Language
(DML) statements such as INSERT, UPDATE, and DELETE.
For example, the following INSERTstatement is supported:
INSERT INTO MyTable (Col1, Col2) VALUES ("Key", "Value");
The driver also supports Data Definition Language (DDL) statements. Be aware that
BigQuery supports specific syntax for DDL statements, and your statements must be
written in that syntax. For more information, see "Using Data Definition Language
Statements" in Google BigQuery's Standard SQL Query Reference:
https://cloud.google.com/bigquery/docs/data-definition-language.
www.simba.com 23
Installation and Configuration Guide Features
Positional Parameters
A parameterized query contains placeholders that are used for parameters. The values
of those parameters are supplied at execution time.
Query parameters can be used as substitutes for arbitrary expressions. Parameters
cannot be used as substitutes for identifiers, column names, table names, or other
parts of the query.
The Simba JDBC Driver for Google BigQuery supports SQL positional parameters.
Parameters are specified in queries with a question mark (?).
For example, the following parameterized query is supported:
SELECT * FROM MyTable WHERE Col1=?
www.simba.com 24
Installation and Configuration Guide Features
Driver Configuration Options
Driver Configuration Options lists and describes the properties that you can use to
configure the behavior of the Simba JDBC Driver for Google BigQuery.
You can set configuration properties using the connection URL. For more information,
see Building the Connection URL on page 12.
Note:
Property names and values are case-sensitive.
AllowLargeResults
Default Value Data Type Required
0Integer No
Description
This option specifies whether the driver supports query results larger than 128MB
when working in Legacy SQL.
l1: The driver allows query results that are larger than 128MB in size.
l0: The driver returns an error when query results are larger than 128MB in size.
When working in Standard SQL (the QueryDialect property is set to SQL), this
option is always considered to be enabled. For more information about the supported
SQLdialects, see QueryDialect on page 33.
Important:
When this option is enabled for Legacy SQL, all query results are written to and
read from the temporary tables described above, regardless of the query and its
result size. Because of this, the result cache is not available to subsequent queries,
and you are billed for every query that you make.
For detailed information about how the driver stores large result sets, see Large
Result Set Support on page 22.
www.simba.com 25
Installation and Configuration Guide Driver Configuration Options
DefaultDataset
Default Value Data Type Required
None String No
Description
The name of a dataset that the driver queries by default.
Specifying a default dataset enables you to use unqualified table names in SQL
statements. The driver treats unqualified tables as part of the default dataset.
Additionally, it treats the default dataset as part of the project that is being billed. For
information about specifying the project to bill, see ProjectId on page 31.
KMSKeyName
Default Value Data Type Required
None.
The driver uses the
default encryption key
from Google.
String No
Description
The keyname of the customer-managed encryption key (CMEK) that you want the
driver to use when executing queries. When this property is not set, the driver uses the
default encryption key from Google.
For information about CMEKs and Cloud KMS encryption, see "Protecting Data with
Cloud KMSKeys" in the Google BigQuery documentation:
https://cloud.google.com/bigquery/docs/customer-managed-encryption.
Important:
lDo not set this property unless you are certain that you are specifying the
correct CMEK. If you execute an INSERT statement with an incorrect CMEK,
the driver returns an error or corrupts the table.
lWhen this property is set, the driver uses the specified CMEKfor all queries.
www.simba.com 26
Installation and Configuration Guide Driver Configuration Options
LargeResultDataset
Default Value Data Type Required
_simba_jdbc String No
Description
The dataset for storing query results when using Legacy SQLwith the
AllowLargeResults property enabled. For more information, see
AllowLargeResults on page 25 and Large Result Set Support on page 22.
LargeResultTable
Default Value Data Type Required
A value consisting of the
prefix temp_table_
followed by the time of
table creation.
String No
Description
The table for storing query results when using Legacy SQLwith the
AllowLargeResults property enabled. For more information, see
AllowLargeResults on page 25 and Large Result Set Support on page 22.
LogLevel
Default Value Data Type Required
0Integer No
Description
Use this property to enable or disable logging in the driver and to specify the amount of
detail included in log files.
www.simba.com 27
Installation and Configuration Guide Driver Configuration Options
Important:
Only enable logging long enough to capture an issue. Logging decreases
performance and can consume a large quantity of disk space.
Set the property to one of the following numbers:
l0: Disable all logging.
l1: Enable logging on the FATAL level, which logs very severe error events that
will lead the driver to abort.
l2:Enable logging on the ERROR level, which logs error events that might still
allow the driver to continue running.
l3:Enable logging on the WARNING level, which logs events that might result in
an error if action is not taken.
l4:Enable logging on the INFO level, which logs general information that
describes the progress of the driver.
l5:Enable logging on the DEBUG level, which logs detailed information that is
useful for debugging the driver.
l6:Enable logging on the TRACE level, which logs all driver activity.
When logging is enabled, the driver produces the following log files in the location
specified in the LogPath property:
lABigQuery_driver.log file that logs driver activity that is not specific to a
connection.
lABigQuery_connection_[Number].log file for each connection made to
the database, where [Number] is a number that distinguishes each log file from
the others. This file logs driver activity that is specific to the connection.
If the LogPath value is invalid, then the driver sends the logged information to the
standard output stream (System.out).
LogPath
Default Value Data Type Required
The current working
directory.
String No
Description
The full path to the folder where the driver saves log files when logging is enabled.
www.simba.com 28
Installation and Configuration Guide Driver Configuration Options
MaxResults
Default Value Data Type Required
0Integer No
Description
The maximum number of results that are displayed per page.
The default value of 0allows an unlimited number of results to be displayed per page.
OAuthAccessToken
Default Value Data Type Required
None String No
Description
The pre-generated access token you are using to authenticate into BigQuery. For
details, see Using Pre-Generated Access and Refresh Tokens on page 15.
OAuthClientId
Default Value Data Type Required
None String Yes, if using a refresh
token.
Description
The Client IDyou are using to authenticate into BigQuery with a pre-generated refresh
token. For details, see Using Pre-Generated Access and Refresh Tokens on page 15.
www.simba.com 29
Installation and Configuration Guide Driver Configuration Options
OAuthClientSecret
Default Value Data Type Required
None String Yes, if using a refresh
token.
Description
The client secret you are using to authenticate into BigQuery with a pre-generated
refresh token. For details, see Using Pre-Generated Access and Refresh Tokens on
page 15.
OAuthPvtKeyPath
Default Value Data Type Required
None String Yes, if
OAuthUserAuth=0.
Description
The full path to the .p12 or .json key file that is used to authenticate the service
account email address, if you are authenticating your connection using a service
account. For more information, see Using a Google Service Account on page 14.
OAuthRefreshToken
Default Value Data Type Required
None String No
Description
The pre-generated refresh token you are using to authenticate into BigQuery. For
details, see Using Pre-Generated Access and Refresh Tokens on page 15.
www.simba.com 30
Installation and Configuration Guide Driver Configuration Options
OAuthServiceAcctEmail
Default Value Data Type Required
None String Yes, if
OAuthUserAuth=0.
Description
The service account email ID that is used for authentication if you are using service
authentication. For more information, see Using a Google Service Account on page 14.
OAuthType
Default Value Data Type Required
0Integer No
Description
This option specifies how the driver obtains or provides the credentials for OAuth 2.0
authentication.
l0: The driver uses service-based OAuth authentication (see Using a Google
Service Account on page 14).
l1: The driver uses user-based OAuth authentication (see Using a Google User
Account on page 13).
l2: The driver uses pre-generated tokens for authentication (see Using Pre-
Generated Access and Refresh Tokens on page 15).
l3: The driver uses Application Default Credentials for authentication (see Using
Application Default Credentials on page 15).
ProjectId
Default Value Data Type Required
None String Yes
www.simba.com 31
Installation and Configuration Guide Driver Configuration Options
Description
The name of your BigQuery project. This project is the default project that the Simba
JDBC Driver for Google BigQuery queries against, and also the project that is billed for
queries that are run using the DSN.
ProxyHost
Default Value Data Type Required
None String No
Description
The IP address or host name of your proxy server.
ProxyPassword
Default Value Data Type Required
None String No
Description
The password, if needed, for proxy server settings.
ProxyPort
Default Value Data Type Required
None Integer No
Description
The listening port of your proxy server.
www.simba.com 32
Installation and Configuration Guide Driver Configuration Options
ProxyUsername
Default Value Data Type Required
None String No
Description
The user name, if needed, for proxy server settings.
QueryDialect
Default Value Data Type Required
SQL Enumerated No
Description
This option specifies whether the driver executes queries using standard SQLsyntax
or the legacy BigQuery SQLsyntax.
lSQL: The driver uses standard SQL.
lBIG_QUERY: The driver uses legacy SQL.
RequestGoogleDriveScope
Default Value Data Type Required
0Integer No
Description
This option specifies whether the driver requests access to Google Drive. Allowing the
driver to access Google Drive enables support for federated tables that combine
BigQuery data with data from Google Drive.
l0: The driver does not request access to Google Drive.
l1: The driver requests access to Google Drive.
www.simba.com 33
Installation and Configuration Guide Driver Configuration Options
StringColumnLength
Default Value Data Type Required
65535 Long No
Description
The maximum length for string type columns.
Timeout
Default Value Data Type Required
10 Integer No
Description
The length of time, in seconds, that the driver waits for a query to retrieve the results of
an executed job.
TimestampFallback
Default Value Data Type Required
0Integer No
Description
Important:
This connection property is deprecated. Only enable this option if you need to
temporarily support connections that used driver version 1.1.0 or earlier, while
transitioning your applications to connect using driver version 1.1.1 or later.
This property specifies whether the driver sets the default timezone of the JVM to UTC.
l1: The driver sets the default timezone of the JVM to UTC. This behavior is non-
optimal, but consistent with the behavior from driver versions 1.1.0 and earlier.
www.simba.com 34
Installation and Configuration Guide Driver Configuration Options
Note:
Before enabling TimestampFallback, be aware of the following:
lThis property applies to all connections that use the Simba JDBC
Driver for Google BigQuery.
lEnabling this property causes the driver to change JVMsettings,
affecting other processes that are running on the same JVM.
lOnce you have made a connection with this property enabled, all
subsequent connections must also have this property enabled.
Otherwise, the driver returns an error.
l0: The driver does not change the timezone settings on the JVM. This is the
preferred driver behavior.
useQueryCache
Default Value Data Type Required
1Integer No
Description
This option specifies whether the driver uses cached query results.
l1: The driver uses cached query results.
l0: The driver does not use cached query results.
www.simba.com 35
Installation and Configuration Guide Driver Configuration Options
Third-Party Trademarks
Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names
may be trademarks of their respective owners.
Google BigQuery, Google, and BigQuery are trademarks or registered trademarks of
Google, Inc. or its subsidiaries in Canada, the United States and/or other countries.
All other trademarks are trademarks of their respective owners.
www.simba.com 36
Installation and Configuration Guide Third-Party Trademarks
Third-Party Licenses
The licenses for the third-party libraries that are included in this product are listed
below.
Apache License, Version 2.0
The following notice is included in compliance with the Apache License, Version 2.0
and is applicable to all software licensed under the Apache License, Version 2.0.
Apache License
Version 2.0, January 2004
http://www.apache.org/licenses/
TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION
1. Definitions.
"License" shall mean the terms and conditions for use, reproduction, and
distribution as defined by Sections 1 through 9 of this document.
"Licensor" shall mean the copyright owner or entity authorized by the copyright
owner that is granting the License.
"Legal Entity" shall mean the union of the acting entity and all other entities that
control, are controlled by, or are under common control with that entity. For the
purposes of this definition, "control" means (i) the power, direct or indirect, to
cause the direction or management of such entity, whether by contract or
otherwise, or (ii) ownership of fifty percent (50%) or more of the outstanding
shares, or (iii) beneficial ownership of such entity.
"You" (or "Your") shall mean an individual or Legal Entity exercising permissions
granted by this License.
"Source" form shall mean the preferred form for making modifications, including
but not limited to software source code, documentation source, and configuration
files.
"Object" form shall mean any form resulting from mechanical transformation or
translation of a Source form, including but not limited to compiled object code,
generated documentation, and conversions to other media types.
"Work" shall mean the work of authorship, whether in Source or Object form,
made available under the License, as indicated by a copyright notice that is
www.simba.com 37
Installation and Configuration Guide Third-Party Licenses
included in or attached to the work (an example is provided in the Appendix
below).
"Derivative Works" shall mean any work, whether in Source or Object form, that
is based on (or derived from) the Work and for which the editorial revisions,
annotations, elaborations, or other modifications represent, as a whole, an
original work of authorship. For the purposes of this License, Derivative Works
shall not include works that remain separable from, or merely link (or bind by
name) to the interfaces of, the Work and Derivative Works thereof.
"Contribution" shall mean any work of authorship, including the original version
of the Work and any modifications or additions to that Work or Derivative Works
thereof, that is intentionally submitted to Licensor for inclusion in the Work by the
copyright owner or by an individual or Legal Entity authorized to submit on behalf
of the copyright owner. For the purposes of this definition, "submitted" means any
form of electronic, verbal, or written communication sent to the Licensor or its
representatives, including but not limited to communication on electronic mailing
lists, source code control systems, and issue tracking systems that are managed
by, or on behalf of, the Licensor for the purpose of discussing and improving the
Work, but excluding communication that is conspicuously marked or otherwise
designated in writing by the copyright owner as "Not a Contribution."
"Contributor" shall mean Licensor and any individual or Legal Entity on behalf of
whom a Contribution has been received by Licensor and subsequently
incorporated within the Work.
2. Grant of Copyright License. Subject to the terms and conditions of this License,
each Contributor hereby grants to You a perpetual, worldwide, non-exclusive, no-
charge, royalty-free, irrevocable copyright license to reproduce, prepare
Derivative Works of, publicly display, publicly perform, sublicense, and distribute
the Work and such Derivative Works in Source or Object form.
3. Grant of Patent License. Subject to the terms and conditions of this License, each
Contributor hereby grants to You a perpetual, worldwide, non-exclusive, no-
charge, royalty-free, irrevocable (except as stated in this section) patent license
to make, have made, use, offer to sell, sell, import, and otherwise transfer the
Work, where such license applies only to those patent claims licensable by such
Contributor that are necessarily infringed by their Contribution(s) alone or by
combination of their Contribution(s) with the Work to which such Contribution(s)
was submitted. If You institute patent litigation against any entity (including a
cross-claim or counterclaim in a lawsuit) alleging that the Work or a Contribution
incorporated within the Work constitutes direct or contributory patent
infringement, then any patent licenses granted to You under this License for that
Work shall terminate as of the date such litigation is filed.
www.simba.com 38
Installation and Configuration Guide Third-Party Licenses
4. Redistribution. You may reproduce and distribute copies of the Work or
Derivative Works thereof in any medium, with or without modifications, and in
Source or Object form, provided that You meet the following conditions:
(a) You must give any other recipients of the Work or Derivative Works a
copy of this License; and
(b) You must cause any modified files to carry prominent notices stating that
You changed the files; and
(c) You must retain, in the Source form of any Derivative Works that You
distribute, all copyright, patent, trademark, and attribution notices from the
Source form of the Work, excluding those notices that do not pertain to
any part of the Derivative Works; and
(d) If the Work includes a "NOTICE" text file as part of its distribution, then
any Derivative Works that You distribute must include a readable copy of
the attribution notices contained within such NOTICE file, excluding those
notices that do not pertain to any part of the Derivative Works, in at least
one of the following places: within a NOTICE text file distributed as part of
the Derivative Works; within the Source form or documentation, if
provided along with the Derivative Works; or, within a display generated
by the Derivative Works, if and wherever such third-party notices normally
appear. The contents of the NOTICE file are for informational purposes
only and do not modify the License. You may add Your own attribution
notices within Derivative Works that You distribute, alongside or as an
addendum to the NOTICE text from the Work, provided that such
additional attribution notices cannot be construed as modifying the
License.
You may add Your own copyright statement to Your modifications and may
provide additional or different license terms and conditions for use, reproduction,
or distribution of Your modifications, or for any such Derivative Works as a whole,
provided Your use, reproduction, and distribution of the Work otherwise complies
with the conditions stated in this License.
5. Submission of Contributions. Unless You explicitly state otherwise, any
Contribution intentionally submitted for inclusion in the Work by You to the
Licensor shall be under the terms and conditions of this License, without any
additional terms or conditions. Notwithstanding the above, nothing herein shall
supersede or modify the terms of any separate license agreement you may have
executed with Licensor regarding such Contributions.
6. Trademarks. This License does not grant permission to use the trade names,
trademarks, service marks, or product names of the Licensor, except as required
www.simba.com 39
Installation and Configuration Guide Third-Party Licenses
for reasonable and customary use in describing the origin of the Work and
reproducing the content of the NOTICE file.
7. Disclaimer of Warranty. Unless required by applicable law or agreed to in writing,
Licensor provides the Work (and each Contributor provides its Contributions) on
an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND,
either express or implied, including, without limitation, any warranties or
conditions of TITLE, NON-INFRINGEMENT, MERCHANTABILITY, or FITNESS
FOR A PARTICULAR PURPOSE. You are solely responsible for determining
the appropriateness of using or redistributing the Work and assume any risks
associated with Your exercise of permissions under this License.
8. Limitation of Liability. In no event and under no legal theory, whether in tort
(including negligence), contract, or otherwise, unless required by applicable law
(such as deliberate and grossly negligent acts) or agreed to in writing, shall any
Contributor be liable to You for damages, including any direct, indirect, special,
incidental, or consequential damages of any character arising as a result of this
License or out of the use or inability to use the Work (including but not limited to
damages for loss of goodwill, work stoppage, computer failure or malfunction, or
any and all other commercial damages or losses), even if such Contributor has
been advised of the possibility of such damages.
9. Accepting Warranty or Additional Liability. While redistributing the Work or
Derivative Works thereof, You may choose to offer, and charge a fee for,
acceptance of support, warranty, indemnity, or other liability obligations and/or
rights consistent with this License. However, in accepting such obligations, You
may act only on Your own behalf and on Your sole responsibility, not on behalf of
any other Contributor, and only if You agree to indemnify, defend, and hold each
Contributor harmless for any liability incurred by, or claims asserted against, such
Contributor by reason of your accepting any such warranty or additional liability.
END OF TERMS AND CONDITIONS
APPENDIX: How to apply the Apache License to your work.
To apply the Apache License to your work, attach the following boilerplate notice,
with the fields enclosed by brackets "[]" replaced with your own identifying
information. (Don't include the brackets!) The text should be enclosed in the
appropriate comment syntax for the file format. We also recommend that a file or
class name and description of purpose be included on the same "printed page" as
the copyright notice for easier identification within third-party archives.
Copyright [yyyy] [name of copyright owner]
Licensed under the Apache License, Version 2.0 (the "License"); you may not
use this file except in compliance with the License. You may obtain a copy of
the License at
http://www.apache.org/licenses/LICENSE-2.0
www.simba.com 40
Installation and Configuration Guide Third-Party Licenses
Unless required by applicable law or agreed to in writing, software distributed
under the License is distributed on an "AS IS" BASIS, WITHOUT
WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
This product includes software that is licensed under the Apache License, Version 2.0
(listed below):
Google APIClient
Copyright © 2010-2016 Google, Inc.
Google BigQuery APIv2 Client Library for Java
Copyright © 2010 Google, Inc.
Google GSON
Copyright © 2008-2011 Google, Inc.
Google Guava
Copyright © 2006-2015 Google, Inc.
Google HTTPClient
Copyright © 2010-2016 Google, Inc.
Google OAuth Client
Copyright © 2010-2016 Google, Inc.
Jackson
Copyright © 2009-2011 FasterXML, LLC
Licensed under the Apache License, Version 2.0 (the "License"); you may not use this
file except in compliance with the License. You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software distributed under
the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR
CONDITIONS OF ANY KIND, either express or implied. See the License for the
specific language governing permissions and limitations under the License.
www.simba.com 41
Installation and Configuration Guide Third-Party Licenses

Navigation menu
