SD
owner’s manual
www.simmonsdrums.net
Electronic Drum Kit
www.SimmonsDrums.net
SD
2
SD
OWNER’S MANUAL
safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near the heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety, if the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Unplug this apparatus during lightning
storms or when unused for a long periods of time.
13) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
CAUTION: Apparatus shall not be exposed to dripping or splashing
and no objects filled with liquids, such as vases, shall be placed on
the apparatus.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL WITHIN AN EQUILATERAL TRIANGLE IS INTENDED
TO ALERT THE USER TO THE PRESENCE OF UNINSULATED DANGEROUS VOLTAGE WITHIN THE PRODUCT’S
ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK
TO PERSONS.
APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED
WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO
THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE PRODUCT.
3
www.simmonsdrums.net
Table of Contents
Safety Instructions 2
Table of Contents 3
Features 4
Assembling Your Kit 5, 6
Connections
Connecting the Pads 7
Connecting the Power Supply 8
Connecting External Audio Devices 8
Connecting USB MIDI 8
Connecting Headphones 8
Panel Controls
Top Panel 9
LED Display 9
Rear and Back Panels 10
Getting Started
Switching the Power On 11
Basic Operation and Navigation 11
Listening to the Demo Song 11
Selecting a Kit 12
Playing a Song 12
Muting the Drum Part 12
Advanced Operations
Kit Mode 13
Utility Mode 14
Factory Reset 16
Drum Kit Presets
Preset Drum Kit List 17
Song Style List 17
Drum Sound List 18
MIDI Implementation Chart 19
Specifications 20
Warranty 20
4
SD
OWNER’S MANUAL
features
Polyphony
Voices - 32
Sounds
Drum Voices - 170
Keyboard Voice - 19
Drum Kits - 10 Preset / 1 User
Songs - 10 Preset / 1 User
Effects
Reverb - Hall1, Hall2, Room1, Room2,
Room3, Stage1, Stage2, Plate, Delay,
Echo.
Chorus - Chorus1, Chorus2, Chorus3,
Chorus4, ChorusFB, Short Delay,
Short Delay FB, Flanger2, Flanger3,
Celeste1, Celeste2, Celeste3.
Trigger Inputs
1 x Kick, Single Zone
1 x Snare, Single Zone
3 x Toms, Single Zone
1 x Hi-Hat, Single Zone
1 x Ride, Single Zone
1 x Crash, Single Zone
Hardware
Drum Rack and Mounts
Kick pedal / Trigger Module
Hi-Hat pedal
8” Single Zone Snare Mesh Drum
8” Single Zone Tom Mesh Drum
10” Single Zone Hi-Hat Cymbal Pad
10” Single Zone Crash Cymbal Pad
10” Single Zone Ride Cymbal Pad
External Connections
1
/
8
” Headphone Output
2 - ¼” Master Outputs
1
/
8
” Stereo Aux Input
USB Connection for MIDI via computer
Sequencer
Preset Songs - 10
User Songs - 1
Tempo - 20-240 BPM
Click/Metronome - Click Voice,
Time Signature, Tempo, Interval, Volume
SD350 Sound Module General Features
Power: 9v, 600ma
Dimensions: 37”(H) x 27”(W) x 10”(L)
Weight: 37 lbs / 16.78 kg
5
www.simmonsdrums.net
Assembling your kit
Inside this package - SD350 pads and hardware
Before assembly, please make sure that all the items listed below are present.
Drum Pads
Drum Rack
Kick Pedal Hi-Hat Pedal
Hi-Hat Arm (Long)
2 - Cymbal Arms (Short)
Drum Module
Multi-pin Cable Harness
AC Adaptor
Cymbals Accessories
(SD350MESHDRUM8S) (SD350MESHDRUM8S)
Single Zone 8” Snare Mesh Drum
Single Zone 10”
Hi-Hat Pad
Single Zone 8” Tom Mesh Drums
Single Zone 10”
Crash Cymbal Pad
Single Zone 10”
Ride Cymbal Pad
Foot ControllerBass Drum Pedal
and Trigger
(S300HHC)
(SD350)
(S300KPD1)
(S500CYM10S)
(S300RK)
SD300 Drum Rack
(S500CYM10S) (S500CYM10S)
Snare Pad L–Rod 3 - Tom Drum
Straight Rods
Drum Key
10 - Velcro
Cable Straps
1 Pair Drumsticks
6
SD
OWNER’S MANUAL
connections
CAUTION!
To prevent electric shock and damage to the device, make sure the power is switched
OFF on the sound module and all related devices before making any connection.
*See Appendix for Pad, Triggers, Name and MIDI chart.
To Crash
To Hi-Hat
Control
To Kick
Cymbal Pads
Drum Pads
Sound
Module
To Snare
From Sound
Module to 7 Pads
Connecting the
To Tom 1 To Tom 2
To Hi-Hat
To Tom 3
To Ride
7
www.simmonsdrums.net
Assembling your kit
Step 1 - Drum Rack
The Drum rack will be fully assembled in the box.
Remove the drum rack from the box and tighten the connecting
clamps until the kit is stable.
Step 2 - Attach Cymbal Arms
Insert each cymbal arm into the rack clamp. Insert (Long) hi-hat arm
on the left-side rack arm’s cymbal clamp.
Step 3 - Attach Cymbal Pads
Remove wing nuts from cymbal tilters. Place cymbal pads on tilter
assembly. Re-attach and tighten wing nuts.
Step 5 - Position Pedals & Attach Drums
Place the hi-hat pedal on the floor and to the left, as illustrated
below. Place the bass pedal on the floor in the center of the rack
as illustrated.
Loosen the wing screws on the drum mount clamps on the center
crossbar and the right side rack arm. Insert the straight rods into
clamps and place the drums on the rods. Place the tom pads into the
mounts and tighten the wing screws.
Place the L arm into the drum mount clamp on the left side rack arm
(next to the Hi Hat). Slide the snare pad onto the L arm and tighten
the wing screw.
Step 4 - Attach Drum Module
Loosen wing screw on the module mount located on the crossbar. Place
drum module into drum clamp. Tighten wing screw to secure module.
Step 6 - Connect Module to the Pads
Using the provided cables, connect the ¼” jacks to the corresponding
drum pads, cymbal pads and kick pad. (Cables are marked
accordingly). The pin connection will attach to the serial port of the
sound module. Assembly complete.C
NOTE: The voice of the hi-hat pad is controlled by the hi-hat pedal. Similar to
a real drum kit, the hi-hat pad functions as an ‘open hi-hat’ when the pedal
is released. When the pedal is pressed down, it functions as a ‘closed hi-hat’.
Use cable strips to retain cable to rack.
8
SD
OWNER’S MANUAL
connections
Connecting the Power Supply
Connect the AC power adapter to a wall socket as shown in
this illustration.
Connecting External Audio Devices
The audio output from an external source can be connected to the
AUX INPUT jack on the rear panel and mixed with the sound of the
drum module. This is ideal if you want to play along with songs or
follow an audio drum tutorial.
The volume of the external signal is controlled on that device.
Connecting USB MIDI
Your drum module is USB class-compliant. This means you can
plug it into a USB class compliant host (such as most modern MAC
and PC computers as well as many tablet devices), and it should
be recognized immediately. There are no drivers to install; simply
plug n’ play.
If you connect the drum module to a computer, you can trigger
software programs or record your performance into a MIDI
sequencing application. Check the operation and setup instructions
for the software you intend to use for more details.
USB cable not included.
Connecting Headphones
Your headphones can be connected to the SD350. The headphone
jack is located on the front left side of module. Use the MASTER
VOLUME knob to adjust the headphone volume.
AUX INPUT
AUDIO
DEVICE
— OUTPUT —
R L/MONO
AUX INPUT
AUDIO
DEVICE
— OUTPUT —
R L/MONO
AUX INPUT
AUDIO
DEVICE
— OUTPUT —
R L/MONO
9
www.simmonsdrums.net
panel controls
Top Panel
LED Display
The LED indicates the SONG, PAD or KIT status. When SONG is
selected, the song number appears in the display. When PAD is
selected, the pad name such as Snare, Crash, and Tom, etc. will
appear. Press the KIT button and the drum kit number will be
displayed on the LED.
1 [VOLUME] Knob
2 [SONG] Button
Access to song mode.
3 [START] Button
Plays the selected song.
4 [MUTE] Button
Mutes the drum part of selected song.
5 [TEMPO/TAP] Button
Adjusts the tempo of songs and click.
6 [CLICK] Button
Turns the Click/Metronome
function ON/OFF.
7 [UTILITY] Button
Access to utility functions.
8 [ - /+ ] Buttons
Adjusts the current parameter on the screen.
9 [KIT] Button
Access to kit mode.
10 [VOICE] Button
Selects voice.
11 [RECORD/PLAY] Button
Access to record mode.
12 [POWER] Button
Press and release to power ON or OFF.
13 Headphone Output
SONG mode
PAD mode
KIT mode
1
4
2
7
910 11 12
3
5
6
8
13
10
SD
OWNER’S MANUAL
panel controls
Rear Panel
Back Panel
1 Serial Connection Jack
Control cable connects the pads and the
pedals to the module.
1 AC Adapter Input
Connection for the 9V DC power adapter.
2 USB Port
Used for connecting the SD350 module to a computer.
3 AUX Input
Stereo 1
/
8
” jack to connect external audio devices
to module.
4 Output
¼” stereo audio outputs to connect to external
audio sources.
1
1 2 3 4
11
www.simmonsdrums.net
getting started
Switching the Power On
1. Connect the AC Adapter to the drum module.
2. Press the power switch on the front panel to turn on the module.
Note: There is an automatic power off function that turns off the
module when the kit is not being used for a certain period of time.
The default setting is Always ON. You can change this setting by
holding down the [KIT] button for two seconds. This will disable the
auto power off function. Press and hold the [KIT] button again to
switch it back on.
Basic Operation and Navigation
Selecting Modes
There are 3 main modes for the module: KIT, SONG and UTILITY.
To enter these modes press the corresponding buttons on the top
panel of the module.
Adjusting Values
1. Select the parameter to be adjusted.
2. Adjust the value using [ - ] / [+] buttons.
Listening to the Demo Song
The demo song helps to show you the capabilities and sounds of the
SD350 module. There is one demo in the module. The demo song
is a medley that has several patterns combined to show the different
genres of music that the module can play.
1. Press the [SONG] button to enter Song Mode. Use the
[ - ] / [ + ] buttons to select song d-1.
2. Press the [START] button to start or stop the demo.
3. After stopping the demo, press any of the Mode buttons
(KIT, SONG or UTILITY) to exit the Demo Mode.
12
SD
OWNER’S MANUAL
getting started
Selecting a Kit
Entering KIT Mode
1. Press the [KIT] button. The LCD displays the current Kit number.
2. Press the [–] / [+] buttons to select a preset or user kit.
Selecting a Song
1. Press the [SONG] button. The LCD displays the current Song
Number.
2. Press the [–] / [+] buttons to select the song you want to play.
Playing a Song
1. Press [START] to play a song.
2. Press the [START] button again to stop playback of the song.
NOTE: You can temporarily change the tempo of a song while playback
is in progress by using the [TEMPO/TAP] and [–] / [+] buttons. The
song returns to its default tempo when a different song is selected.
Muting the Drum Part
1. While a Song is playing press the [MUTE] button. This will
mute the drum sound. The screen will show the mute status “On”
or “Off”.
2. To unmute the Drums press the [MUTE] button again.
13
www.simmonsdrums.net
advanced operations
Kit Mode
Editing a Kit
The drum kits of the module can be modified from the factory presets.
However to save them you will have to save them to User memory
locations. See the steps below on how to change the parameters
for each pad input.
1. Press the [KIT] button.
2. Press the [Voice] button to see the current voice -
the default is the Snare pad.
3. Strike a drum pad to view the Voice currently assigned.
4. Press the [ - ] / [+] buttons to change the assigned voice.
5. Press the [REC/PLAY] button to save the assignment to a
User Kit.
Recording a Song
Recording
Press and hold the [REC/PLAY] button for 2 seconds. Recording will
start after you hear one bar of metronome hits.
Press [REC/PLAY] button again to stop recording. After you have
stopped recording, press the [REC/PLAY] button to play back your
recording. Press the [REC/PLAY] button again to stop playback.
14
SD
OWNER’S MANUAL
advanced operations
Click/Metronome
Click Settings
The Click is the metronome. The click can be played during a song
in song mode or on its own.
Press [CLICK] button to start and stop the metronome.
1. To edit the Click settings press and hold the [CLICK]
button for 2 seconds.
2. The first parameter is the time signature.
3. Press the [ - ] / [ + ] buttons to select the time signature
that you want.
4. To adjust the tempo of the click press the [TEMPO/TAP] button
and use the [ - ] / [ + ] buttons to adjust.
5. You can also adjust the tempo by using the “TAP” function. Press
and hold the [TEMPO/TAP] button. The LED screen will flash
the current tempo. Strike Tom1 2-4 times consecutively to set the
desired “TAP” tempo.
Utility Mode
The Utility mode is for the main functions of the module such as
trigger setup for the pads, effects, MIDI setup and saving global
settings.
Trigger Settings
You can set the parameters of each drum and cymbal pad in the
Trigger menu. While editing the settings, you can select each trigger
by hitting the corresponding trigger pad.
1. Press the [UTIL] button.
2. Strike the drum pad you want to edit to view the setting
currently assigned.
3. To recover factory settings perform the factory reset.
(See page 16)
4. Press the [ - ] / [ + ] buttons to change the parameter setting.
5. To get to the next parameter press the [UTIL] button. See page 15
for a list of parameters and their descriptions.
6. After completing your settings Press the [REC/PLAY] button to
save them.
15
www.simmonsdrums.net
advanced operations
Parameter definitions
Retrig-C (Retrigger cancel)
Retrigger Cancel prevents retriggering from occurring. Although
setting this to a high value prevents retriggering, it then becomes
easy for sounds to be omitted when the drums is played fast (roll
etc.). Set this to the lowest value possible while still ensuring that
there is no retriggering.
Threshold
This setting allows a trigger signal to be received only when the
pad is struck harder than a specified force. This can be used to
prevent a pad from sounding in response to peripheral vibrations
from another pad.
Curve (Trigger curve)
This setting allows you to control the relation between the velocity
(striking force) and changes in volume (the dynamic curve.) Adjust
this curve until the response feels as natural as possible.
X- Talk (Pad Crosstalk)
When two pads are mounted on the same stand, the vibration
produced by hitting one pad may trigger the sound from another
pad unintentionally, this is called crosstalk. You can avoid this
problem by adjusting Crosstalk Cancel on the pad that is sounding
inadvertently. If the value is set too high, then when two pads are
played simultaneously, the one that is struck less forcefully will not
sound. Setting the value too low may result in crosstalk.
MIDI Settings
Pad MIDI Note assignments
The MIDI output notes from the SD350 are preset in the module. The
following list has the MIDI notes that are sent from the module when
the drum pads and pedals are played.
For more details on MIDI functionality please see the MIDI
Implementation Chart in the Appendix section of the manual.
MIDI Note Pad
36 Kick
38 Snare – Center
48 Tom 1
45 Tom 2
43 Tom 3
46 Hi Hat – Open
42 Hi Hat – Closed
44 Hi Hat – Pedal
49 Crash
51 Ride
16
SD
OWNER’S MANUAL
Factory Reset
There may be occasions where you want the module to return to
the factory settings. This function will return the module back to
factory setup.
To Reset the Module to Factory Setup
1. Power off the module
2. Press and hold the [ - ] / [+ ] buttons while simultaneously pressing
and holding the power button.
advanced operations
17
www.simmonsdrums.net
drum kit PRESETs
Kit # Kit Name
Kit 1 Maple
Kit 2 Funk 1
Kit 3 Studio
Kit 4 Hip Hop
Kit 5 Metal
Kit 6 Simmons
Kit 7 Jazz
Kit 8 Latin Percussion
Kit 9 LA Funk Rock
Kit 10 Techno
Kit 11 User Kit
Style # Style Name
d–1
01
Demo Song
Bonz Beat
02 Blues Beat
03 Black Magic
04 Alt Rock
05 Funky Strut
06 Hip Hop
07 Funky D
08 Tech Step
09 Metalhead
10 Jazz Walk
Preset Drum Kit List
Song Style List
18
SD
OWNER’S MANUAL
drum kit PRESETs
Drum Sound List
KICK
BD_Maple
BD_HeavyMetal
BD_Jazz
BD_LAFunkRock
BD_Metal
BD_MetalGuitar-Kick
BD_Studio
BD_Thickick
BD_Vintage
EDRM_BD-HipHopcp1
EDRM_BD-Techno1Cp
EDRM_BD808Kick
BD_Banzai_Kick
BD_WahKick
BD_PunchKick
SNARE
SD_Aluminum_Center
SD_Aluminum_CS
SD_Aluminum_RS
SD_BellBrass_center
SD_BellBrass_CS
SD_BellBrass_RS
SD_Brass_RS
SD_Brass-center
SD_Brass-CS
SD_BrushSnare-center
SD_BrushSnare-Rim
SD_DeepBrass-Center
SD_DeepBrass-CS
SD_DeepBrass-RS
SD_Funk1_CenterA
SD_HeavyMetal
SD_LAFunkrock_CenterA
SD_LAFunkrock_CS
SD_LAFunkrock_RS
SD_Maple_CenterA
SD_Maple_RS
SD_Metal-CenterA
SD_Metal-CS
SD_Metal-RS
SD_ShallowBrass-Center
SD_ShallowBrass-CS
SD_ShallowBrass-RS
SD_ShallowWood-CenterA
SD_ShallowWood-CS
SD_ShallowWood-RS
SD_SteelSnare_Center
SD_SteelSnare_CS
SD_SteelSnare_RS
SD_SteelSnare2-Center
SD_SteelSnare2-CS
SD_SteelSnare2-RS
SD_Studio_CenterA
SD_Studio_CS
SD_Studio_RS
SD_Vintage
EDRM_SD-HipHopcp1
EDRM_SD-Techno1Cp
SD_SynthSnare
SD_LoFiSnare
SD_HipHopSnare
TOM
TOM_Brush-Hi
TOM_Brush-Lo
TOM_HeavyMetal-Hi
TOM_HeavyMetal-Low
TOM_HeavyMetal-Mid
TOM_LAFunk_Hi
TOM_LAFunk_Low
TOM_LAFunk_Mid
TOM_Maple_Hi
TOM_Maple_Low
TOM_Maple_Mid
TOM_Metal-Hi
TOM_Metal-Low
TOM_Metal-Mid
TOM_Studio_Hi
TOM_Studio_Low
TOM_Studio_Mid
TOM_Vintage-Hi
TOM_Vintage-Low
TOM_Vintage-Mid
EDRM_Simmons_Tom1Cp-Hi
EDRM_Simmons_Tom1Cp-Low
EDRM_Simmons_Tom1Cp-Mid
EDRM_Simmons_Tom1Cp
EDRM_Tom-Techno1-Hi
EDRM_Tom-Techno1-Low
EDRM_Tom-Techno1-Mid
EDRM_Simmons_Kick1Cp
EDRM_Simmons_Snare1Cp
CYMBALS
CYM_China
CYM_Crash1
CYM_Crash2
CYM_Ride-MetalPingA
CYM_Ride1-BellA
CYM_Ride1-BowA-0
CYM_Ride1-BowA
CYM_Ride2-BellA
CYM_Ride2-Bow
CYM_Ride2-CrashEdge
ECYM_808Cymbal
ECYM_Ride-Simmons1
ECYM_Simmons_Crash1cp
ECYM_Techno_CrashChinaElec
ECYM_SimmonsRide
HI HAT
CYM_HH1-Closed-0
CYM_HH1-Closed-1
CYM_HH1-Foot-0
CYM_HH1-Foot-1
CYM_HH1-Open-0
CYM_HH1-Open-1
CYM_HH2-Closed
CYM_HH2-Foot
CYM_HH2-Open
CYM_HH3-Closed
CYM_HH3-Foot
CYM_HH3-Open
ECYM_HH-Foot
ECYM_HHClosed4
ECYM_HipHopHHClsd1
ECYM_HipHopHHOpen1
ECYM_SimmonsHHOpen03
ECYM_Techno_ClsdHH2cp
ECYM_Techno_OpenHH1Cp
PERCUSSION
PERC_Agogo-Large
PERC_Agogo-Small
PERC_Bongo-Large
PERC_Bongo-Small
PERC_Cabasa
PERC_Clave
PERC_Conga-Slap
PERC_Conga
PERC_Cowbell_Open
PERC_Cowbell-
Mute2Open
PERC_Guiro
PERC_Marcas
PERC_Quica-Down
PERC_Quica-Hi_tone
PERC_Shaker
PERC_Sleighbells
PERC_Small
PERC_Surdo
PERC_Tambourine-Slap
PERC_Timbale-Hi
PERC_Timbale
PERC_Triangle-Mute
PERC_Triangle-
Mute2Open
PERC_Triangle-Open
PERC_Tumba-Open-Slap
PERC_Tumba-Slap
PERC_Tumba
PERC_Vibraslap
PERC_Whistle-Long
PERC_Whistle
PERC_Woodblock-Lo
PERC_Woodblock
EPERC_808claps
EPERC_808Conga
EPERC_808Cowbell
EPERC_BigClap
EPERC_Bleep
EPERC_FilterSnap
EPERC_Kling
EPERC_Ping
EPERC_Punch
EPERC_PsychoRainstick
PERC_BigDrum
PERC_CongaTumba
BD_ElectroKick
EPERC_DigitalChimes
EPERC_Bass-SlapPhrase3
KEYBOARD SOUNDS
AC Bass
Synth Bass 1
Synth Bass 2
Synth Bass 4
Synth Bass 3
Synth Bass 5
Slap Bass
Strut Guitar
Distorted Guitar
Wah Wah
Muted Stock
Distorted Stock
Crunch Guitar
Acoustic Piano
Ep1
Horn Section
Organ 1
Organ 2
Synth 1
KITS
Maple
Funk 1
Studio
Hip Hop
Metal
Simmons
Jazz
Latin Percussion
LA Funk Rock
Techno
User Kit
19
www.simmonsdrums.net
Function Transmitted Recognized Remarks
Basic
Channel
Default
Changed
10CH
X
1-16
1-16 each
Memorized
Mode Default
Messages
Altered
Mode 3
X
**************
Mode 3
X
X
Note Number True Voice 0–127
**************
0–127
0–127
Velocity Note ON
Note OFF
O (99H, V=1–127)
O (89H, V=0)
O (9nH, V=1–127)
O (8nH, V=0) or 8nH
Aftertouch X X
Pitch Blend X O
Control Change 0, 32
1
5
6
7
10
11
64
65
66
67
80, 81
91, 93
100, 101
121
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O (*1)
O
Bank Select
Modulation
Portamento Time
Data Entry
Volume
Pan
Expression
Sustain
Portamento
Sostenuto
Soft Pedal
DSP TYPE
DSP DEPTH
RPN LSB, MSB
Reset all Controllers
Program Change
True member
O 0-10 O 0-127
0-127
System Exclusive X X
System
Common
:Song Position
:Song Select
:Tune
X
X
X
X
X
X
System
Real Time
:Clock
:Commands
X
X
X
X
Aux
Messages
:Local ON/OFF
:All Notes OFF
:Active Sense
:Reset
X
X
X
X
X
O
X
O
All Notes OFF is sent as
All Sound OFF (CC# 120)
O: YES X: NO
*1: Registered parameter number: #0: Pitch sensitivity, #1: Fine tuning, #2: Coarse tuning Model 1: OMNI ON, POLY
Mode 2: OMNI ON, MONO
Mode 3: OMNI OFF, POLY
Mode 4: OMNI OFF, MONO
midi implementation chart
20
SD
OWNER’S MANUAL
Pads 4 mesh drums and 3 rubber cymbals with touch response and two pedals for bass drum and hi-hat
Sounds 170 drum voices
Drum Kits 10 Preset kits, 1 User kit
Songs 10 Preset songs, 1 User song
Overall Controls Tempo, Main Volume
Metronome Voice, Click or Light
Connections 9V adapter, head phones, USB to host (MIDI IN/OUT), aux input, stereo out, serial pin connector
Dimensions 37” (H) x 27” (W) x 10” (L)
Weight 37 lbs
Power Supply 9V adapter
Accessories Drum sticks, drum key, velcro cable straps, user manual
SPECIFICATIONS
warranty
FCC Statements
1. Caution: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
2. Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a different circuit.
•Consult an experienced radio/TV technician for help.
Two (2) Year Limited Warranty
Subject to the limitations set forth below, Simmons hereby represents and warrants
that the components of this product shall be free from defects in workmanship and
materials, including implied warranties of merchantability or fitness for a particular
purpose, subject to normal use and service, for two (2) years to the original owner
from the date of purchase.
Retailer and manufacturer shall not be liable for damages based upon inconve-
nience, loss of use of product, loss of time, interrupted operation or commercial
loss or any other incidental or consequential damages including but not limited to
lost profits, downtime, goodwill, damage to or replacement of equipment and property,
and any costs of recovering, reprogramming, or reproducing any program or data stored
in equipment that is used with Simmons products. This guarantee gives you specific le-
gal rights. You may have other legal rights which vary from state to state. Some states do
not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.
Simmons
P.O. Box 5111
Thousand Oaks, CA 91359-5111
All trademarks and registered trademarks mentioned herein are recognized as the
property of their respective holders.
Made in China
1704-17201141

Navigation menu
