Via Brandoli Ovest, 2a/2b 41030 San Prospero (MO) Italy - Tel. +39 059 80.94.13 Fax. +39 059 80.94.10 - info@clmramps.com
www.clmramps.com
Testing & Cerication
Organizzazione con Sistema
di Gestione certicato
Company with Management
System certifiet
ISO 9001:2008
Automotive SINGLE LOADING CHUTE
TECHNICAL DETAILS
Side edges none
Maximum load capacity 500 kg
Length from 2,5 to 4,0 m
Width from 600 to 800 mm
30.25.60 300 2.500 600 21
30.25.80 300 2.500 800 26
30.30.60 300 3.000 600 26
30.30.80 300 3.000 800 31
30.35.60 300 3.500 600 31
30.35.80 300 3.500 800 37
30.40.60 300 4.000 600 36
30.40.80 300 4.000 800 44
50.25.60 500 2.500 600 22
50.25.80 500 2.500 800 27
50.30.60 500 3.000 600 28
50.30.80 500 3.000 800 34
50.35.60 500 3.500 600 32
50.35.80 500 3.500 800 39
50.40.60 500 4.000 600 38
50.40.80 500 4.000 800 46
TYPE LOAD CAPACITY LENGTH USEFUL WIDTH WEIGHT
kg mm mm kg
Via Brandoli Ovest, 2a/2b 41030 San Prospero (MO) Italy - Tel. +39 059 80.94.13 Fax. +39 059 80.94.10 - info@clmramps.com
www.clmramps.com
Testing & Cerication
Organizzazione con Sistema
di Gestione certicato
Company with Management
System certifiet
ISO 9001:2008
Automotive
TECHNICAL DETAILS
Side edges none
Maximum load capacity 1000 kg
Length from 1470 to 4000 mm
Width from 600 to 1000 mm
30.25.60 / P 300 2.500 600 28
30.25.80 / P 300 2.500 800 35
30.30.60 / P 300 3.000 600 33
30.30.80 / P 300 3.000 800 42
30.35.60 / P 300 3.500 600 40
30.35.80 / P 300 3.500 800 51
30.40.60 / P 300 4.000 600 47
30.40.80 / P 300 4.000 800 58
50.25.60 / P 500 2.500 600 29
50.25.80 / P 500 2.500 800 36
50.30.60 / P 500 3.000 600 36
50.30.80 / P 500 3.000 800 45
50.35.60 / P 500 3.500 600 42
50.35.80 / P 500 3.500 800 52
85.1470.60.P 1000 1470 600 17
85.1870.60.P 1000 1870 600 20
85.2470.60.P 1000 2470 600 27
85.2870.60.P 1000 2870 600 31
85.3270.60.P 1000 3270 600 35
85.1470.75.P 800 1470 750 20
85.1870.75.P 800 1870 750 24
85.2470.75.P 800 2470 750 33
85.2870.75.P 800 2870 750 37
85.3270.75.P 800 3270 750 41
85.1470.100.P 550 1470 1000 26
85.1870.100.P 550 1870 1000 32
85.2470.100.P 550 2470 1000 41
85.2870.100.P 550 2870 1000 47
85.3270.100.P 550 3270 1000 53
MODEL LOAD CAPACITY LENGTH USEFUL WIDTH WEIGHT
kg mm mm kg
SINGLE LOADING CHUTE
with bridge-type flat surface
