Qualcomm Technologies, Inc.
Qualcomm® Snapdragon™ LLVM ARM
Compiler for Android
User Guide
80-VB419-90 M
September 1, 2017
Qualcomm Snapdragon is a product of Qualcomm Technologies, Inc. Other Qualcomm products referenced herein are products of Qualcomm
Technologies, Inc. or its subsidiaries.
Qualcomm and Snapdragon are trademarks of Qualcomm Incorporated, registered in the United States and other countries. Krait is a
trademark of Qualcomm Incorporated. Other product and brand names may be trademarks or registered trademarks of their respective
owners.
This technical data may be subject to U.S. and international export, re-export, or transfer (“export”) laws. Diversion contrary to U.S. and
international law is strictly prohibited.
This document contains material provided to Qualcomm Technologies, Inc. under licenses reproduced in Appendix B that are provided to you
for attribution purposes only. Your license to this document is from Qualcomm Technologies, Inc.
Qualcomm Technologies, Inc.
5775 Morehouse Drive
San Diego, CA 92121
U.S.A.
© 2013-2017 Qualcomm Technologies, Inc. All rights reserved.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 2
Contents
1 Introduction........................................................................................... 8
1.1 Conventions..................................................................................................................8
1.2 Technical assistance......................................................................................................9
2 Functional Overview .......................................................................... 10
2.1 Features.......................................................................................................................10
2.2 Languages...................................................................................................................10
2.3 GCC compatibility...................................................................................................... 11
2.4 Processor versions ...................................................................................................... 11
2.5 LLVM versions........................................................................................................... 11
2.6 C language and compiler references........................................................................... 11
3 Getting Started.................................................................................... 12
3.1 Create source file........................................................................................................12
3.2 Compile program........................................................................................................12
3.3 Execute program.........................................................................................................13
4 Using the Compilers........................................................................... 14
4.1 Starting the compilers.................................................................................................14
4.2 Input and output files..................................................................................................15
4.3 Compiler options........................................................................................................16
4.3.1 Display..............................................................................................................21
4.3.2 Compilation.......................................................................................................21
4.3.3 C dialect ............................................................................................................22
4.3.4 C++ dialect........................................................................................................23
4.3.5 Warning and error messages .............................................................................24
4.3.6 Debugging.........................................................................................................32
4.3.7 Diagnostic format..............................................................................................34
4.3.8 Individual warning groups................................................................................36
4.3.9 Compiler crash diagnostics...............................................................................38
4.3.10 Linker..............................................................................................................38
4.3.11 Preprocessor....................................................................................................39
4.3.12 Assembling .....................................................................................................43
4.3.13 Linking............................................................................................................43
4.3.14 Directory search..............................................................................................45
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 3
Qualcomm Snapdragon LLVM ARM Compiler for Android Contents
4.3.15 Processor version ............................................................................................45
4.3.16 Code generation .............................................................................................48
4.3.17 Vectorization ...................................................................................................59
4.3.18 Parallelization .................................................................................................60
4.3.19 Optimization ...................................................................................................60
4.3.20 Specific optimizations.....................................................................................62
4.3.21 Math optimization...........................................................................................63
4.3.22 Link-time optimization ...................................................................................64
4.3.23 Profile-guided optimization............................................................................65
4.3.24 Optimization reports .......................................................................................66
4.3.25 Compiler security............................................................................................66
4.3.26 LLVM 4.0-specific compiler flags..................................................................68
4.4 Warning and error messages.......................................................................................70
4.4.1 Controlling how diagnostics are displayed.......................................................70
4.4.2 Diagnostic mappings.........................................................................................70
4.4.3 Diagnostic categories........................................................................................71
4.4.4 Controlling diagnostics with compiler options.................................................71
4.4.5 Controlling diagnostics with pragmas ..............................................................72
4.4.6 Controlling diagnostics in system headers........................................................73
4.4.7 Enabling all warnings .......................................................................................73
4.5 Using GCC cross compile environments ...................................................................74
4.6 Using LLVM with GNU Assembler...........................................................................75
4.7 Built-in functions........................................................................................................76
4.8 Compilation phases ....................................................................................................76
5 Code Optimization.............................................................................. 78
5.1 Optimizing for performance.......................................................................................78
5.2 Optimizing for code size ............................................................................................78
5.3 Automatic vectorization .............................................................................................79
5.4 Automatic parallelization ...........................................................................................79
5.4.1 Auto-parallelization using SYMPHONY library..............................................80
5.5 Merging functions ......................................................................................................82
5.6 Link-time optimization...............................................................................................83
5.7 Profile-guided optimization........................................................................................ 84
5.7.1 Instrumentation-based PGO..............................................................................84
5.7.2 Instrumentation-based profile gen with Android apps......................................86
5.7.3 Sampling-based PGO........................................................................................87
5.7.4 Sampling-based PGO on Snapdragon MDP.....................................................88
5.7.5 Profile resiliency...............................................................................................89
5.7.6 PGO tips............................................................................................................89
5.8 Loop optimization pragmas........................................................................................90
5.8.1 Pragma syntax...................................................................................................90
5.8.2 Compile options................................................................................................91
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 4
Qualcomm Snapdragon LLVM ARM Compiler for Android Contents
5.8.3 Vectorization pragmas.......................................................................................92
5.8.4 Reporting...........................................................................................................93
5.8.5 Examples...........................................................................................................94
5.9 Optimization reports...................................................................................................96
5.9.1 Example output.................................................................................................96
5.9.2 Optimization report message details.................................................................97
6 Compiler Security Tools .................................................................. 104
6.1 Sanitizer support.......................................................................................................104
6.2 Sanitizer special case lists ........................................................................................104
6.3 Sanitizer usage on Android ......................................................................................106
6.4 Sanitizer usage on Linux ..........................................................................................107
6.5 Address Sanitizer......................................................................................................108
6.5.1 Usage...............................................................................................................108
6.5.2 Symbolizing the reports.................................................................................. 109
6.5.3 Additional checks............................................................................................ 110
6.5.4 Issue suppression ............................................................................................ 110
6.5.5 Suppressing memory leaks ............................................................................. 112
6.5.6 Limitations...................................................................................................... 112
6.5.7 Options............................................................................................................ 112
6.5.8 Notes ............................................................................................................... 113
6.6 Data Flow Sanitizer.................................................................................................. 114
6.6.1 Usage............................................................................................................... 114
6.6.2 ABI list............................................................................................................ 114
6.6.3 Example .......................................................................................................... 116
6.7 Leak Sanitizer........................................................................................................... 117
6.7.1 Usage............................................................................................................... 117
6.8 Memory Sanitizer..................................................................................................... 118
6.8.1 Usage............................................................................................................... 118
6.8.2 Report symbolization...................................................................................... 119
6.8.3 Origin tracking................................................................................................120
6.8.4 Use-after-destruction detection.......................................................................121
6.8.5 Handling external code ...................................................................................121
6.8.6 Limitations......................................................................................................121
6.9 Thread Sanitizer........................................................................................................122
6.9.1 Usage...............................................................................................................122
6.9.2 Limitations......................................................................................................124
6.10 Undefined Behavior Sanitizer ................................................................................124
6.10.1 Usage.............................................................................................................125
6.10.2 Available checks ........................................................................................... 126
6.10.3 Stack traces and report symbolization ..........................................................127
6.10.4 Issue suppression ..........................................................................................127
6.10.5 Notes ............................................................................................................. 128
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 5
Qualcomm Snapdragon LLVM ARM Compiler for Android Contents
6.11 LLVM Symbolizer..................................................................................................128
6.11.1 Usage.............................................................................................................129
6.11.2 Options..........................................................................................................130
6.12 Control flow integrity.............................................................................................130
6.12.1 Configuration................................................................................................131
6.12.2 Usage.............................................................................................................131
6.12.3 Options..........................................................................................................132
6.12.4 Handler functions..........................................................................................132
6.12.5 Notes ............................................................................................................. 133
6.13 Static program analysis...........................................................................................133
6.13.1 Static analyzer...............................................................................................133
6.13.2 Postprocessor ................................................................................................139
6.13.3 Scan-build .....................................................................................................140
7 Porting Code from GCC................................................................... 141
7.1 Command options.....................................................................................................141
7.2 Errors and warnings..................................................................................................141
7.3 Function declarations................................................................................................141
7.4 Casting to incompatible types ..................................................................................142
7.5 aligned attribute........................................................................................................143
7.6 Reserved registers.....................................................................................................143
7.7 Inline versus extern inline ........................................................................................144
8 Coding Practices .............................................................................. 145
8.1 Use int types for loop counters.................................................................................145
8.2 Mark function arguments as restrict (if possible).....................................................145
8.3 Do not pass or return structs by value ......................................................................146
8.4 Avoid using inline assembly.....................................................................................147
9 Language Compatibility................................................................... 148
9.1 C compatibility.........................................................................................................148
9.1.1 Differences between various standard modes.................................................148
9.1.2 GCC extensions not implemented yet.............................................................149
9.1.3 Intentionally unsupported GCC extensions ....................................................150
9.1.4 Lvalue casts.....................................................................................................150
9.1.5 Jumps to within __block variable scope.........................................................150
9.1.6 Non-initialization of __block variables ..........................................................151
9.1.7 Inline assembly ...............................................................................................151
9.2 C++ compatibility.....................................................................................................152
9.2.1 Deleted special member functions..................................................................152
9.2.2 Variable-length arrays.....................................................................................152
9.2.3 Unqualified lookup in templates.....................................................................153
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 6
Qualcomm Snapdragon LLVM ARM Compiler for Android Contents
9.2.4 Unqualified lookup into dependent bases of class templates..........................156
9.2.5 Incomplete types in templates.........................................................................157
9.2.6 Templates with no valid instantiations............................................................158
9.2.7 Default initialization of const variable of a class type....................................159
9.2.8 Parameter name lookup...................................................................................159
A References........................................................................................ 160
A.1 Related documents...................................................................................................160
B Acknowledgements ......................................................................... 161
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 7
Qualcomm Snapdragon LLVM ARM Compiler for Android Tables
Tables
Table 4-1 Compiler input files .............................................................................15
Table 4-2 Compiler output files ...........................................................................16
Table 4-3 LLVM 4.0 release – new warnings ......................................................31
Table 4-4 LLVM 4.0 release – new compiler flags.............................................. 68
Table 5-1 Options to use for optimizing code performance................................. 78
Table 5-2 Options to use for optimizing code size...............................................78
Table 5-3 SYMPHONY library versions for supported development platforms.81
Table 5-4 Supported loop pragmas ......................................................................90
Table 5-5 Loop pragma options that enable auto-vectorization...........................91
Table 5-6 Loop pragma option combinations ......................................................91
Table 5-7 Loop optimization reporting ................................................................93
Table 6-1 Sanitizer support ................................................................................104
Table 6-2 Options supported in ASan................................................................ 113
Table 6-3 UBSan checks and option values.......................................................126
Table 6-4 Options supported in the Symbolizer.................................................130
Table 6-5 CFI options supported in the static compiler .....................................132
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 8
1Introduction
This document is a reference for C/C++ programmers. It describes C and C++ compilers
for the ARM processor architecture. The compilers are based on the LLVM compiler
framework, and are collectively referred to as the LLVM compilers.
NOTE The LLVM compilers are commonly referred to as Clang.
NOTE We strongly recommend trying to use the various LLVM code optimizations
to improve the performance of your program. Using only the default
optimization settings is likely to result in suboptimal performance.
1.1 Conventions
Courier font is used for computer text:
int main()
{
printf(“Hello world\n”);
return(0);
}
The following notation is used to define the syntax of functions and commands:
■Square brackets enclose optional items (e.g., help [command]).
■Bold is used to indicate literal symbols (e.g., the brackets in array[index]).
■The vertical bar character | is used to indicate a choice of items.
■Parentheses are used to enclose a choice of items (e.g., (on|off)).
■An ellipsis, ..., follows items that can appear more than once.
■Italics are used for terms that represent categories of symbols.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 9
Qualcomm Snapdragon LLVM ARM Compiler for Android Introduction
Examples:
#define name(parameter1[, parameter2...]) definition
logging (on|off)
Where:
■#define is a preprocessor directive, and logging is an interactive compiler
command.
■name represents the name of a defined symbol.
■parameter1 and parameter2 are macro parameters. The second parameter is
optional because it is enclosed in square brackets. The ellipsis indicates that the
macro accepts more than parameters.
■on and off are bold to show that they are literal symbols. The vertical bar
between them shows that they are alternative parameters of the logging
command.
1.2 Technical assistance
For assistance or clarification on information in this document, submit a case to
Qualcomm Technologies, Inc. (QTI) at https://createpoint.qti.qualcomm.com/.
If you do not have access to the CDMATech Support website, register for access or send
email to support.cdmatech@qti.qualcomm.com.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 10
2Functional Overview
The C and C++ compilers are based on the LLVM compiler framework and are
collectively referred to as the LLVM compilers.
2.1 Features
The LLVM compilers offer the following features:
■ISO C conformance
Supports the International Standards Organization (ISO) C language standard
■Compatibility
Supports LLVM extensions and most GCC extensions to simplify porting
■System library
Supports standard libraries as provided in the Android NDK
■Processor-specific libraries
Provides library routines that are optimized for the Qualcomm ARM architecture
■Intrinsics
Provides a mechanism for emitting LLVM assembly instructions in C source code
2.2 Languages
The LLVM compilers support C, C++, and many dialects of those languages:
■C language: K&R C, ANSI C89, ISO C90, ISO C94 (C89+AMD1),
ISO C99 (+TC1, TC2, TC3)
■C++ language: C++98, C++11
In addition to these base languages and their dialects, the LLVM compilers support a
broad variety of language extensions. These extensions are provided for compatibility
with the GCC, Microsoft, and other popular compilers, as well as to improve functionality
through the addition of extensions unique to the LLVM compilers.
All language extensions are explicitly recognized as such by the LLVM compilers, and
marked with extension diagnostics which can be mapped to warnings, errors, or simply
ignored.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 11
Qualcomm Snapdragon LLVM ARM Compiler for Android Functional Overview
2.3 GCC compatibility
The LLVM compiler driver and language features are intentionally designed to be as
compatible with the GNU GCC compiler as reasonably possible, easing migration from
GCC to LLVM. In most cases, code just works.
2.4 Processor versions
The LLVM compilers can generate code for all versions of the ARM processor
architecture that are supported by the standard LLVM compiler.
ARMv8 supports two instruction set architectures (ISA):
■AArch64 – the new 64-bit ISA, which supports a larger virtual and physical
address space. All general purpose registers (and many of the system registers) are
64 bits. All instructions are encoded in 32 bits.
■AArch32 – a 32-bit ISA which incorporates the ARMv7 ISA for both ARM and
Thumb modes, and also includes many aspects of AArch64 (including support for
cryptography and enhanced floating point).
For more information, see the ARMv8-A Reference Manual.
2.5 LLVM versions
The LLVM compilers are based on LLVM 4.0+, as defined at llvm.org.
2.6 C language and compiler references
This document does not describe the following:
■C or C++ languages
■Detailed descriptions of the code optimizations performed by LLVM
For suggested references, see Section A.1.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 12
3Getting Started
This chapter shows how to build and execute a simple C program using the LLVM
compiler.
The program is built in the Linux environment, and executed directly on ARMv7 or
ARMv8 hardware running Linux.
NOTE The Android NDK is assumed to be already installed on your computer. This
includes the tools required for assembling and linking a compiled program.
NOTE The commands shown in this chapter are for illustration only. For detailed
information on building programs, see Chapter 4.
3.1 Create source file
Create the following C source file:
#include <stdio.h>
int main()
{
printf(“Hello world\n”);
return(0);
}
Save the file as hello.c.
3.2 Compile program
Compile the program with the following command:
clang hello.c -o hello
This translates the C source file hello.c into the executable file hello.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 13
Qualcomm Snapdragon LLVM ARM Compiler for Android Getting Started
3.3 Execute program
To execute the program, use the following command:
hello
The program outputs its message to the terminal:
Hello world
You have now compiled and executed a C program using the LLVM compiler. For more
information on using the compiler see the following chapter.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 14
4Using the Compilers
The LLVM compilers translate C and C++ programs into LLVM processor code.
C and C++ programs are stored in source files, which are text files created with a text
editor. LLVM processor code is stored in object files, which are executable binary files.
4.1 Starting the compilers
To start the C compiler from the command line, enter:
clang [options...] input_files...
To start the C++ compiler from the command line, enter:
clang++ [options...] input_files...
The compilers accept one or more input files on the command line. Input files can be
C/C++ source files or object files. For example:
clang hello.c mylib.c
Command switches are used to control various compiler options (Section 4.3). A switch
consists of a dash character (-) followed by a switch name and optional parameter.
Switches are case-sensitive and must be separated by at least one space. For example:
clang hello.c -o hello
To list the available command options, use the --help option:
clang --help
clang++ --help
This option causes the compiler to display the command line syntax, followed by a list of
the available command options.
NOTE clang is the name of the front-end driver for the LLVM compiler framework.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 15
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.2 Input and output files
The LLVM compilers preprocess and compile one or more source files into object files.
The compilers then invoke the linker to combine the object files into an executable file.
Table 4-1 lists the input file types and the tool that processes files of each type. The
compilers use the file name extension to determine how to process the file.
All file name extensions are case-sensitive literal strings. Input files with unrecognized
extensions are treated as object files. For more information on LLVM IR files, see
llvm.org.
Table 4-1 Compiler input files
Extension Description Tool
.c C source file C compiler
.i C preprocessed file
.h C header file
.cc
.cp
.cxx
.cpp
.CPP
.c++
.C
C++ source file C++ compiler
.ii C++ preprocessed file
.h
.hh
.H
C++ header file
.bc
.ll
LLVM intermediate representation (IR) file C/C++ compiler
.s
.S
Assembly source file Assembler
other Binary object file Linker
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 16
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
Table 4-2 lists the output file types and the tools used to generate each file type. Compiler
options (Section 4.3) are used to specify the output file type.
4.3 Compiler options
The LLVM compilers can be controlled by command-line options (Section 4.1). Many of
the GCC options are supported, along with options that are LLVM-specific.
Many of the -f, -m, and -W options can be written in two ways: -f<option> to enable a
binary option, or -fno-<option> to disable the option.
-mllvm is not a stand-alone option, but rather a standard prefix that appears in many
LLVM-specific option names.
Following is a quick reference of the options.
Display (see Section 4.3.1)
-help
-v
Compilation (see Section 4.3.2)
-###
-c -cc1 -ccc-print-phases
-E -S -pipe
-o file
-Wp,arg[,arg...]
-Wa,arg[,arg...]
-Wl,arg[,arg...]
-x language
-Xclang arg
-no-canonical-prefixes
Table 4-2 Compiler output files
File type Default
file name Input files
Executable file a.out The specified source files are compiled and
linked to a single executable file.
Object file file.o Each specified source file is compiled to a
separate object file (where file is the source
file name).
Assembly source file file.s Each specified source file is compiled to a
separate assembly source file (where file is
the source file name).
Preprocessed C/C++ source
file
stdout The preprocessor output is written to the
standard output.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 17
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
C dialect (See Section 4.3.3)
-ansi -fno-asm -fblocks -fgnu-runtime -fgnu89-inline
-fsigned-bitfields -fsigned-char -funsigned-char
-no-integrated-cpp -std=(c89|gnu89|c94|c99|gnu99)
-traditional -Wpointer-sign
C++ dialect (see Section 4.3.4)
-cxx-isystem dir
-ffor-scope -fno-for-scope -fno-gnu-keywords
-ftemplate-depth-n -fvisibility-inlines-hidden
-fuse-cxa-atexit -nobuiltininc -nostdinc++
-Wc++0x-compat -Wno-deprecated
-Wnon-virtual-dtor -Woverloaded-virtual
-Wreorder
Warning and error messages (see Section 4.3.5)
-ferror-limit=n-ftemplate-backtrace-limit=n
-ferror-warn filename -fsyntax-only -pedantic
-pedantic-errors -Q-unused-arguments
-w -Wfoo -Wno-foo -Wall -Warray-bounds
-Wcast-align -Wchar-subscripts
-Wcomment -Wconversion
-Wdeclaration-after-statement -Wno-deprecated-declarations
-Wempty-body -Wendif-labels -Werror
-Werror=foo -Wno-error=foo
-Werror-implicit-function-declaration
-Weverything -Wextra -Wfloat-equal
-Wformat -Wformat=2 -Wno-format-extra-args
-Wformat-nonliteral -Wformat-security -Wignored-qualifiers
-Wimplicit -Wimplicit-function-declaration -Wimplicit-int
-Wno-invalid-offsetof -Wlong-long -Wmain
-Wmissing-braces -Wmissing-declarations
-Wmissing-noreturn -Wmissing-prototypes -Wno-multichar
-Wnonnull -Wpacked -Wpadded -Wparentheses -Wpedantic
-Wpointer-arith -Wreturn-type -Wshadow -Wsign-compare
-Wswitch -Wswitch-enum -Wsystem-headers
-Wtrigraphs -Wundef -Wuninitialized -Wunknown-pragmas
-Wunreachable-code -Wunused -Wunused-function -Wunused-label
-Wunused-parameter -Wunused-value -Wunused-variable
-Wno-vectorizer-no-neon -Wwrite-strings
Debugging (see Section 4.3.6)
-dumpmachine -dumpversion
-feliminate-unused-debug-symbols
-ftime-report
-g[level]-gline-tables-only
-print-diagnostic-categories
-print-file-name=library -print-libgcc-file-name
-print-multi-directory -print-multi-lib
-print-multi-os-directory -print-prog-name=program
-print-search-dirs
-save-temps -time
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 18
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
Diagnostic format (see Section 4.3.7)
-fcaret-diagnostics -fno-caret-diagnostics
-fdiagnostics-format=(clang|msvc|vi)
-fdiagnostics-show-option -fno-diagnostics-show-option
-fdiagnostics-show-category=(none|id|name)
-fdiagnostics-print-source-range-info
-fno-diagnostics-print-source-range-info
-fdiagnostics-parseable-fixits
-fdiagnostics-show-note-include-stack
-fdiagnostics-show-template-tree
-fmessage-length=n
Individual warning groups (see Section 4.3.8)
-Wextra-tokens -Wambiguous-member-template
-Wbind-to-temporary-copy
Compiler crash diagnostics (see Section 4.3.9)
-fno-crash-diagnostics
Linker (see Section 4.3.10)
-fuse-ld=(gold|bfd|qcld)
Preprocessor (see Section 4.3.11)
-A pred=ans -A -pred=ans -ansi -C -CC -d(DMNU)
-D name -D name=definition -fexec-charset=charset
-finput-charset=charset -fpch-deps -fpreprocessed
-fstrict-overflow -ftabstop=width -fwide-exec-charset=charset
-fworking-directory --help -H -I dir -I- -include file
-isystem prefix -isystem-prefix prefix
-ino-system-prefix prefix
-M -MD -MF file -MG -MM -MMD -MP -MQ target -MT target
-nostdinc -nostdinc++ -o file -P -remap --target-help
-U name -v -version --version -w -Wall -Wcomment
-Wcomments -Wendif-labels -Werror -Wimport
-Wsystem-headers -Wtrigraphs -Wundef -Wunused-macros
-Xpreprocessor option
Assembling (see Section 4.3.12)
-Xassembler option
-fintegrated-as -fno-integrated-as
Linking (see Section 4.3.13)
object_file_name -c -dynamic -E
-l library -moslib=library
-nodefaultlibs -nostartfiles -nostdlib
-pie -s -S -shared -shared-libgcc
-static -static-libgcc
-symbolic -u symbol -Xlinker option
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 19
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
Directory search (see Section 4.3.14)
-Bprefix
-F dir -I dir
--gcc-toolchain=prefix
-I-
-Ldir
--sysroot=prefix
Processor version (see Section 4.3.15)
-target triple
-march=version
-mcpu=version
-mfpu=version
-mfloat-abi=(soft|softfp|hard)
Code generation (see Section 4.3.16)
-fasynchronous-unwind-tables
-fchar-array-precise-tbaa -fno-char-array-precise-tbaa
-femit-all-data -femit-all-decls
-ffp-contract=(fast|on|off)
-fno-exceptions
-fmerge-functions
-fpic -fPIC -fpie -fPIE
-fsanitize=address -fno-sanitize=address
-fsanitize=memory -fno-sanitize=memory
-fsanitize=event[,event...] -fno-sanitize=event[,event...]
-fsanitize-blacklist=file -fno-sanitize-blacklist
-fsanitize-messages -fno-sanitize-messages
-fsanitize-opt-size -fno-sanitize-opt-size
-fsanitize-source-loc -fno-sanitize-source-loc
-fsanitize-use-embedded-rt
-fsanitize-memory-track-origins[=level]
-fshort-enums -fno-short-enums
-fshort-wchar -fshort-wchar
-ftrap-function=value -ftrapv -ftrapv-handler
-funwind-tables -fverbose-asm
-fvisibility=[default|internal|hidden|protected]
-fwrapv
-mhwdiv=(arm|thumb|arm,thumb|none)
-mllvm -aarch64-disable-abs-reloc
-mllvm -aggressive-jt
-mllvm -arm-expand-memcpy-runtime
-mllvm -arm-memset-size-threshold
-mllvm -arm-memset-size-threshold-zeroval
-mllvm -arm-opt-memcpy
-mllvm -disable-thumb-scale-addressing
-mllvm -emit-cp-at-end
-mllvm -enable-android-compat
-mllvm -enable-arm-addressing-opt
-mllvm -enable-arm-peephole
-mllvm -enable-arm-zext-opt
-mllvm -enable-print-fp-zero-alias
-mllvm -enable-round-robin-RA
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 20
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-mllvm -enable-select-to-intrinsics
-mllvm -favor-r0-7
-mllvm -force-div-attr
-mllvm -prefetch-locality-policy=(L1|L2|L3|stream)
-mrestrict-it -mno-restrict-it
Vectorization (see Section 4.3.17)
-fvectorize-loops -ftree-vectorize
-fvectorize-loops-debug
-fprefetch-loop-arrays[=stride]-fno-prefetch-loop-arrays
Parallelization (see Section 4.3.18)
-fparallel
-fparallel-symphony
Optimization (see Section 4.3.19)
-O -O0 -O1 -O2 -O3 -O4 -Os -Oz
-Ofast -Osize
Specific optimizations (see Section 4.3.20)
-falign-functions[=n] -falign-jumps[=n]
-falign-labels[=n] -falign-loops[=n]
-falign-inner-loops -fno-align-inner-loops
-falign-os -fno-align-os
-fdata-sections -ffunction-sections
-finline -finline-functions
-floop-pragma -fnomerge-all-constants
-fomit-frame-pointer -foptimize-sibling-calls
-fstack-protector -fstack-protector-all
-fstack-protector-strong -fstrict-aliasing
-funit-at-a-time -funroll-all-loops
-funroll-loops -fno-zero-initialized-in-bss
--param ssp-buffer-size=size
Math optimization (see Section 4.3.21)
-fassociative-math -ffast-math -ffinite-math-only
-fmath-errno -fno-math-errno -freciprocal-math
-fno-signed-zeros -fno-trapping-math
-funsafe-math-optimizations
Link-time optimization (see Section 4.3.22)
-flto
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 21
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
Profile-guided optimization (see Section 4.3.23)
-fprofile-instr-generate[=filename]
-fprofile-instr-use=filename
-fprofile-sample-use=filename
--fprofile-instr-sync-interval=interval
-mllvm --append-profile-files
-mllvm --enable-instrument-profile-file-sync
Optimization reports (see Section 4.3.24)
-fopt-reporter=(vectorizer|parallelizer|all)
-polly-max-pointer-aliasing-checks
-Rpass=loop-opt
-Rpass-missed=loop-opt
Compiler security (see Section 4.3.25)
--analyze -analyzer-checker=checker -analyzer-checker-help
-analyzer-disable-checker=checker --analyzer-output html
--analyzer-Werror --compile-and-analyze dir
-ffcfi -fno-fcfi
4.3.1 Display
-help
Displays compiler command and option summary.
-v
Displays compiler release version.
4.3.2 Compilation
-###
Prints commands used to perform the compilation.
-c
Compiles the source file, but does not link it.
-cc1
Bypasses the compiler driver and go directly to LLVM.
-ccc-print-phases
Prints the compilation stages as they occur.
-E
Preprocesses the source file only; does not compile it.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 22
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-S
Compiles the source file, but does not assemble it.
-pipe
Communicates between compiler stages using pipes not temporary files.
-o file
Specify the name of the compiler output file.
-Wp,arg[,arg...]
Passes the specified arguments to the preprocessor.
-Wa,arg[,arg...]
Passes the specified arguments to the assembler.
-Wl,arg[,arg...]
Passes the specified arguments to the linker.
-x language
Specifies the language of the subsequent source files specified on the command
line.
-Xclang arg
Passes the specified argument to the compiler.
-no-canonical-prefixes
When processing a pathname:
❒Does not expand any symbolic links.
❒Does not resolve any references to /./ or /../.
❒Does not make relative prefixes absolute.
4.3.3 C dialect
-ansi
For C, supports ISO C90.
For C++, removes conflicting GNU extensions.
-fno-asm
Does not recognize asm, inline, or typeof as keywords.
-fblocks
Enables the Apple blocks extension.
-fgnu-runtime
Generates output compatible with the standard GNU Objective-C runtime.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 23
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-fgnu89-inline
Uses the gnu89 inline semantics.
-fsigned-bitfields
Defines bitfields as signed.
-fsigned-char
Defines char type as signed.
-funsigned-char
Defines char type as unsigned.
-no-integrated-cpp
Compiles using separate preprocessing and compilation stages.
-std=(c89|gnu89|c94|c99|gnu99|c11)
LLVM language mode. The default setting is gnu99.
-traditional
Supports pre-standard C language.
-Wpointer-sign
Flag pointers when assigned or passed values with a differing sign.
4.3.4 C++ dialect
-cxx-isystem dir
Adds a specified directory to C++ SYSTEM include search path.
-ffor-scope
-fno-for-scope
Control whether the scope of a variable declared in a for statement is limited to
the statement or to the scope enclosing the statement.
-fno-gnu-keywords
Disables recognizing typeof as a keyword.
-ftemplate-depth-n
Specifies the maximum instantiation depth of a template class.
-fvisibility-inlines-hidden
Specifies the default visibility for inline C++ member functions.
-fuse-cxa-atexit
Registers destructors with function __cxa_atexit (instead of atexit). This
option applies only to objects that have static storage duration.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 24
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-nobuiltininc
Disables built-in #include directories.
-nostdinc++
Disables standard #include directories for the C++ standard library.
-Wc++0x-compat
Generates warnings for C++ constructs with different semantics in ISO C++ 1998
and ISO C++ 200x.
-Wno-deprecated
Does not generate warnings when deprecated features are used.
-Wnon-virtual-dtor
Generates a warning when a polymorphic class is declared with a non-virtual
destructor.
-Woverloaded-virtual
Generates a warning when a function hides virtual functions from a base class.
-Wreorder
Generates a warning when member initializers do not appear in the code in the
required execution order.
4.3.5 Warning and error messages
c++98-c++11-c++14-compat-pedantic
Hexadecimal floating literals are incompatible with C++ standards before C++1z.
cast-calling-convention
Cast between incompatible calling conventions %0 and %1; calls through this
pointer might abort at runtime.
comma
Possible misuse of comma operator here.
constant-conversion
Implicit conversion from %2 to %3 changes the value from %0 to %1.
expansion-to-defined
Macro expansion producing defined has undefined behavior.
-ferror-limit=n
Stops emitting diagnostics after n errors have been produced. The default setting
is 20. The error limit can be disabled with the option -ferror-limit=0.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 25
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
float-overflow-conversion
Implicit conversion of out of range value from %0 to %1 changes the value from
%2 to %3.
float-zero-conversion
Implicit conversion from %0 to %1 changes the non-zero value from %2 to %3.
-ftemplate-backtrace-limit=n
Only emits up to n template instantiation notes within the template instantiation
backtrace for a single warning or error. The default setting is 10. The limit can be
disabled with the option -ftemplate-backtrace-limit=0.
-ferror-warn filename
Converts the specified set of compiler warnings into errors.
The specified text file contains a list of warning names, with each warning name
separated by whitespace in the file.
Warning names are based on the switch names of the corresponding compiler
warning-message options. For example, to convert the warnings generated by the
option -Wunused-variable, use the warning name unused-variable.
This option can be specified multiple times.
NOTE This option (and its associated file) can be integrated into a build system,
and used to iteratively resolve the warning messages generated by a
project.
-fsyntax-only
Checks for syntax errors only.
incompatible-sysroot
Uses sysroot for %0 but targets %1.
nonportable-include-path
Non-portable path to file %0. The specified path differs in case from the file name
on the disk.
nonportable-system-include-path
Non-portable path to file %0. The specified path differs in case from the file name
on the disk.
null-dereference
Binding dereferenced null pointer to reference has undefined behavior.
openmp-target
Declaration is not declared in any declare target region.
-pedantic
-Wpedantic
Generate all warnings required by the ISO C and ISO C++ standards.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 26
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
pedantic-core-features
OpenCL extension %0 is a core feature or a supported optional core feature –
ignoring.
-pedantic-errors
Equivalent to -pedantic, but generate errors instead of warnings.
-Qunused-arguments
Does not generate warnings for unused driver arguments.
shadow-field-in-constructor-modified
Modifying constructor parameter %0 that shadows a field of %1.
shadow-field-in-constructor
Constructor parameter %0 shadows the field %1 of %2.
undefined-func-template
Instantiation of function %q0 required here, but no definition is available.
undefined-var-template
Instantiation of variable %q0 is required here, but no definition is available.
unguarded-availability
Using * case here; platform %0 is not accounted for.
unknown-argument
Unknown argument is ignored in clang-cl: %0.
unsupported-cb
Ignoring -mcompact-branches= option because the %0 architecture does not
support it.
varargs
Passing an object that undergoes a default argument promotion to va_start has
undefined behavior.
-w
Suppresses all warnings.
-Wfoo
Enables the diagnostic foo.
-Wno-foo
Disables the diagnostic foo.
-Wall
Enables all -W options.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 27
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-Warray-bounds
Generates a warning if array subscripts are out of bounds.
-Wcast-align
Generates a warning if a pointer cast increases the required alignment of the
target.
-Wchar-subscripts
Generates a warning if array subscript is type char.
-Wcomment
Generates a warning if a comment symbol appears inside a comment.
-Wconversion
Generates a warning if an implicit conversion may alter a value.
-Wdeclaration-after-statement
Generates a warning when a declaration appears in a block after a statement.
-Wno-deprecated-declarations
Does not generate warnings for functions, variables, or types assigned the
attribute deprecated.
-Wempty-body
Generates a warning if an if, else, or do while statement contains an empty
body.
-Wendif-labels
Generates a warning if an #else or #endif directive is followed by text.
-Werror
Converts all warnings into errors.
-Werror=foo
Converts the diagnostic foo into an error.
-Wno-error=foo
Keeps the diagnostic foo as a warning, even if -Werror is used.
-Werror-implicit-function-declaration
Generates a warning or error if a function is used before being declared.
-Weverything
Enables all warnings.
-Wextra
Enables selected warning options, and generate warnings for selected events.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 28
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-Wfloat-equal
Generates a warning if two floating point values are compared for equality.
-Wformat
In calls to printf, scanf and other functions with format strings, ensures that the
arguments are compatible with the specified format string.
-Wformat=2
This option is equivalent to specifying the following options: -Wformat
-Wformat-nonliteral -Wformat-security -Wformat-y2k.
-Wno-format-extra-args
Does not generate a warning for passing extra arguments to printf or scanf.
-Wformat-nonliteral
Generates a warning if the format string is not a string literal, except if the format
arguments are passed through va_list.
-Wformat-security
Generates a warning for format function calls that might cause security risks.
-Wignored-qualifiers
Generates a warning if a return type has a qualifier (for example, const).
-Wimplicit
Equivalent to -Wimplicit-int and -Wimplicit-function-declaration.
-Wimplicit-function-declaration
Generates a warning if a function is used before it is declared.
-Wimplicit-int
Generates a warning if a declaration does not specify a type.
-Wno-invalid-offsetof
Does not generate a warning if a non-POD type is passed to the offsetof macro.
-Wlong-long
Generates a warning if typelong long is used.
-Wmain
Generates a warning if the main() function has any suspicious properties.
-Wmissing-braces
Generates a warning if an aggregate or union initializer is not properly bracketed.
-Wmissing-declarations
Generates a warning if a global function is defined without being first declared.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 29
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-Wmissing-noreturn
Generates a warning if a function does not include a return statement.
-Wmissing-prototypes
Generates a warning if a global function is defined without a prototype.
-Wno-multichar
Does not generate a warning if a multicharacter constant is used.
-Wnonnull
Generates a warning if a null pointer is passed to an argument that is specified to
require a non-null value (with the nonnull attribute).
-Wpacked
Generates a warning if the memory layout of a structure is not affected after the
structure is specified with the packed attribute.
-Wpadded
Generates a warning if the memory layout of a structure includes padding.
-Wparentheses
Generates a warning if the parentheses are omitted in certain cases.
-Wpedantic
See -pedantic.
-Wpointer-arith
Generates a warning if any code depends on the size of void or a function type.
-Wreturn-type
Generates a warning if a function returns a type that defaults to int, or a value is
incompatible with the defined return type.
-Wshadow
Generates a warning if a local variable shadows another local variable, global
variable, or parameter; or if a built-in function gets shadowed.
-Wsign-compare
Generates a warning in a signed/unsigned compare if the result may be inaccurate
due to the signed operand being converted to unsigned.
-Wswitch
-Wswitch-enum
Generates a warning if a switch statement uses an enumeration type for the
index, and does not specify a case for every possible enumeration value, or
specifies a case with a value outside the enum range.
-Wsystem-headers
Generates a warning for constructs declared in system header files.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 30
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-Wtrigraphs
Generates a warning if a trigraph forms an escaped newline in a comment.
-Wundef
Generates a warning if an undefined non-macro identifier appears in an #if
directive.
-Wuninitialized
Generates a warning if referencing an uninitialized automatic variable.
-Wunknown-pragmas
Generates a warning if a #pragma directive is not recognized by the compiler.
-Wunreachable-code
Generates a warning if code will never be executed.
-Wunused
Specifies all of the -Wunused options.
-Wunused-function
Generates a warning if a static function is declared without being defined or used.
NOTE No warning is generated for functions declared or defined in header files.
-Wunused-label
Generates a warning if a label is declared without being used.
-Wunused-parameter
Generates a warning if a function argument is not used in its function.
-Wunused-value
Generates a warning if the value of a statement is not subsequently used.
-Wunused-variable
Generates a warning if a local or non-constant static variable is not used in its
function.
-Wno-vectorizer-no-neon
Does not generate the warning, “Vectorization flags ignored because
armv7/armv8 and neon not set”.
Vectorization requires the target to be ARMv7 or ARMv8, and the NEON feature
to be enabled. If the vectorization options are used without these required options,
a warning is normally generated and the vectorization options are ignored.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 31
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-Wwrite-strings
For C, assigns string constants the type const char[length] to ensure that a
warning is generated if the string address gets copied to a non-const char *
pointer.
For C++, generates a warning a string constant is being converted to char *.
Warning – Argument unused during compilation: -mfpu=%0
Clang generates a warning when setting -mfpu in addition to specifying AArch64. To
avoid this warning, do not specify the -mfpu option when specifying AArch64.
4.3.5.1 LLVM 4.0 release
Table 4-3 LLVM 4.0 release – new warnings
Category Description
-Wunused-command-line-argument -fdiagnostics-show-hotness argument requires
profile-guided optimization information.
-Wslash-u-filename /UA treated as the /U option.
-Wunable-to-open-stats-file Unable to open statistics output file A: B.
-Wprivate-module Top-level module A in a private module map; expected a
submodule of B.
-Wempty-decomposition ISO C++1z does not allow a decomposition group to be
empty.
-Wc++1z-extensions Use of multiple declarators in a single using declaration
is a C++1z extension.
-Wc++98-c++11-c++14-compat Initialization statements are incompatible with C++
standards before C++1z.
-Wignored-pragma-intrinsic A is not a recognized built-in intrinsic; consider including
<intrin.h> to access non-built-in intrinsics.
-Wignored-pragmas Expected enable, disable, begin, or end – ignoring.
-Wmax-unsigned-zero Call to function without interrupt attribute could clobber
VFP registers of the interruptee.
-Wextra Call to function without interrupt attribute could clobber
VFP registers of the interruptee.
-Wunused-lambda-capture Variable explicitly captured by a lambda is not used in
the body of the lambda.
-Wshadow-uncaptured-local Declaration shadows a local variable.
-Wdynamic-exception-spec ISO C++1z does not allow dynamic exception
specifications.
-Wc++1z-compat Mangled name of A will change in C++17 due to non-
throwing exception specification in function signature.
-Wreturn-type Control may reach end of non-void coroutine.
-Wmain Boolean literal returned from main.
-Wincompatible-exception-spec Exception specifications of return type differ.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 32
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.6 Debugging
-dumpmachine
Displays the target machine name.
-dumpversion
Displays the compiler version.
-feliminate-unused-debug-symbols
Generates debug information only for the symbols that are used. (Debug
information is generated in STABS format.)
-time
-ftime-report
Displays the elapsed time for each stage of the compilation.
-Winconsistent-missing-
destructor-override
A overrides a destructor but is not marked as override.
-Walloca-with-align-alignof Second argument to __builtin_alloca_with_align is
supposed to be in bits.
-Wsigned-enum-bitfield Enums in the Microsoft ABI are signed integers by
default. Consider giving the enum A an unsigned
underlying type to make this code portable.
-Wunguarded-availability A is only available on B C or newer.
-Winvalid-partial-specialization Class/variable template partial specialization is not more
specialized than the primary template.
-Wstrict-prototypes Function declaration is not a prototype.
-Wblock-capture-autoreleasing Block captures an auto-releasing out-parameter, which
might result in use-after-free bugs.
-Waddress-of-packed-member Taking address of packed member A of class or
structure B may result in an unaligned pointer value.
-Wambiguous-delete Multiple suitable A functions for B; no operator delete
function will be invoked if initialization throws an
exception.
-Wincompatible-function-pointer-
types
Incompatible function pointer types used.
-Wformat Using A format specifier annotation outside of
os_log()/os_trace().
-Wspir-compat Sampler initializer has invalid A bits.
-Wnullability-completeness-on-
arrays
Array parameter is missing a nullability type specifier
(_Nonnull, _Nullable, or _Null_unspecified).
-Wgcc-compat __final is a GNU extension. Consider using C++11
final.
Table 4-3 LLVM 4.0 release – new warnings (cont.)
Category Description
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 33
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-g[level]
Generates complete source-level debug information.
-gline-tables-only
Generates source-level debug information with line number tables only.
-print-diagnostic-categories
Displays mapping of diagnostic category names to category identifiers.
-print-file-name=library
Displays the full library path of the specified file.
-print-libgcc-file-name
Displays the library path for file libgcc.a.
-print-multi-directory
Displays the directory names of the multi libraries specified by other compiler
options in the current compilation.
-print-multi-lib
Displays the directory names of the multi libraries paired with the compiler
options that specified the libraries in the current compilation.
-print-multi-os-directory
Displays the relative path that gets appended to the multilib search paths.
-print-prog-name=program
Displays the absolute path of the specified program.
-print-search-dirs
Displays the search paths used to locate libraries and programs during
compilation.
-save-temps
Saves the normally-temporary intermediate files generated during compilation.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 34
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.7 Diagnostic format
The LLVM compilers aim to produce beautiful diagnostics by default, especially for new
users just beginning to use LLVM. However, different users have different preferences,
and sometimes LLVM is driven by another program that needs the diagnostic output to be
simple and consistent rather than user-friendly. For these cases, LLVM provides a wide
range of options to control the output format of the diagnostics that it generates.
-fcaret-diagnostics
-fno-caret-diagnostics
Print source line and ranges from source code in diagnostic.
This option controls whether LLVM prints the source line, source ranges, and
caret when emitting a diagnostic. The default setting is enabled. When enabled,
LLVM will print something like:
test.c:28:8: warning: extra tokens at end of #endif directive
[-Wextra-tokens]
#endif bad
^
//
-fdiagnostics-format=(clang|msvc|vi)
Changes diagnostic output format to better match IDEs and command line tools.
This option controls the output format of the filename, line number, and column
printed in diagnostic messages. The default setting is clang. The effect of the
setting on the output format is shown below.
clang
t.c:3:11: warning: conversion specifies type 'char *' but the
argument has type 'int'
msvc
t.c(3,11) : warning: conversion specifies type 'char *' but the
argument has type 'int'
vi
t.c +3:11: warning: conversion specifies type 'char *' but the
argument has type 'int'
-fdiagnostics-show-option
-fno-diagnostics-show-option
Enable [-Woption] information in diagnostic line.
This option controls whether LLVM prints the associated warning group option
name (Section 4.4.3) when outputting a warning diagnostic. The default setting is
disabled. For example, given the following diagnostic output:
test.c:28:8: warning: extra tokens at end of #endif directive
[-Wextra-tokens]
#endif bad
^
//
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 35
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
In this case, specifying -fno-diagnostics-show-option prevents LLVM from
printing the [-Wextra-tokens] information in the diagnostic output. This
information indicates the option needed to enable or disable the diagnostic, either
from the command line or by using the pragma GCC diagnostic (Section 4.4.5).
-fdiagnostics-show-category=(none|id|name)
Enables printing category information in diagnostic line.
This option controls whether LLVM prints the category associated with a
diagnostic when emitting it. The default setting is none. The effect of the setting
on the output format is shown below.
❒none
t.c:3:11: warning: conversion specifies type 'char *' but
the argument has type 'int' [-Wformat]
❒id
t.c:3:11: warning: conversion specifies type 'char *' but
the argument has type 'int' [-Wformat,1]
❒name
t.c:3:11: warning: conversion specifies type 'char *' but
the argument has type 'int' [-Wformat,Format String]
Each diagnostic can have an associated category. If it has one, it is listed in the
diagnostic category field of the diagnostic line (in the []'s).
This option can be used to group diagnostics by category, so it should be a high-
level category: the goal is to have dozens of categories, not hundreds or thousands
of them.
-fdiagnostics-print-source-range-info
-fno-diagnostics-print-source-range-info
Print machine-parseable information about source ranges.
This option controls whether LLVM prints information about source ranges in a
machine-parseable format after the file/line/column number information. The
default setting is disabled. The information is a simple sequence of brace-
enclosed ranges, where each range lists the start and end line/column locations.
For example, given the following output:
exprs.c:47:15:{47:8-47:14}{47:17-47:24}: error: invalid
operands to binary expression ('int *' and '_Complex float')
P = (P-42) + Gamma*4;
~~~~~~ ^ ~~~~~~~
In this case, the {}'s are generated by -fdiagnostics-print-source-range-
info.
The printed column numbers count bytes from the beginning of the line; take care
if your source contains multi-byte characters.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 36
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-fdiagnostics-parseable-fixits
Prints Fix-Its in a machine-parseable format.
This option makes LLVM print available Fix-Its in a machine-parseable format at
the end of diagnostics. The following example illustrates the format:
fix-it:"t.cpp":{7:25-7:29}:"Gamma"
In this case, the range printed is half-open, so the characters from column 25 up to
(but not including) column 29 on line 7 of file t.cpp should be replaced with the
string Gamma. Either the range or replacement string can be empty (representing
strict insertions and strict erasures, respectively). Both the file name and insertion
string escape backslash (as \\), tabs (as \t), newlines (as \n), double quotes (as
\"), and non-printable characters (as octal \xxx).
The printed column numbers count bytes from the beginning of the line; take care
if your source contains multi-byte characters.
-fdiagnostics-show-template-tree
For large templated types, this option causes LLVM to display the templates as an
indented text tree, with one argument per line, and any differences marked inline.
❒default
t.cc:4:5: note: candidate function not viable: no known
conversion from 'vector<map<[...], map<float, [...]>>>' to
'vector<map<[...], map<double, [...]>>>' for 1st argument;
❒-fdiagnostics-show-template-tree
t.cc:4:5: note: candidate function not viable: no known
conversion for 1st argument;
vector<
map<
[...],
map<
[float != float],
[...]>>>
-fmessage-length=n
Formats error messages to fit on lines with the specified number of characters.
4.3.8 Individual warning groups
-Wextra-tokens
Warns about excess tokens at the end of a preprocessor directive.
This option enables warnings about extra tokens at the end of preprocessor
directives. The default setting is enabled. For example:
test.c:28:8: warning: extra tokens at end of #endif directive
[-Wextra-tokens]
#endif bad
^
These extra tokens are not strictly conforming, and are usually best handled by
commenting them out.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 37
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-Wambiguous-member-template
Warns about unqualified uses of a member template whose name resolves to
another template at the location of the use.
This option (which is enabled by default) generates a warning in the following
code:
template<typename T> struct set{};
template<typename T> struct trait { typedef const T& type; };
struct Value {
template<typename T> void set(typename trait<T>::type
value){}
};
void foo() {
Value v;
v.set<double>(3.2);
}
C++ requires this to be an error, but because it is difficult to work around, LLVM
downgrades it to a warning as an extension.
-Wbind-to-temporary-copy
Warns about an unusable copy constructor when binding a reference to a
temporary.
This option enables warnings about binding a reference to a temporary when the
temporary does not have a usable copy constructor.
The default setting is enabled. For example:
struct NonCopyable {
NonCopyable();
private:
NonCopyable(const NonCopyable&);
};
void foo(const NonCopyable&);
void bar() {
foo(NonCopyable()); // Disallowed in C++98; allowed in
C++11.
}
struct NonCopyable2 {
NonCopyable2();
NonCopyable2(const NonCopyable2&);
};
void foo(const NonCopyable2&);
void bar() {
foo(NonCopyable2()); // Disallowed in C++98; allowed in
C++11.
}
NOTE If NonCopyable2::NonCopyable2() has a default argument whose
instantiation produces a compile error, that error will still be a hard error
in C++98 mode, even if this warning is disabled.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 38
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.9 Compiler crash diagnostics
The LLVM compilers may crash once in a while. Generally, this only occurs when using
the latest versions of LLVM.
LLVM goes to great lengths to assist you in filing a bug report. Specifically, after a crash,
it generates preprocessed source files and associated run scripts. Attach these files to a bug
report to ease reproducibility of the failure. The following compiler option is used to
control the crash diagnostics.
-fno-crash-diagnostics
Disables auto-generation of preprocessed source files during a LLVM crash.
This option can be helpful for speeding up the process of generating a delta
reduced test case.
4.3.10 Linker
-fuse-ld=(gold|bfd|qcld)
Specifies an alternative linker to use in place of the default system linker.
Several mechanisms are provided for specifying the system linker that is used in
the Snapdragon LLVM ARM toolchain:
❒-fuse-ld
This option causes the toolchain to use the specified linker (see below for
details).
❒--gcc-toolchain
If -fuse-ld is not used, this option causes the toolchain to use whatever
linker is found in the GCC toolchain option path.
❒--sysroot
If neither -fuse-ld nor --gcc-toolchain are used, this option causes the
toolchain to use whatever linker is found in the specified sysroot.
If none of the above options are used, the toolchain uses the host linker by default.
Note that this will result in errors during linking.
The -fuse-ld option can be used to specify the gold, bfd, or qcld linker as the
system linker.
gold and bfd are typically included in the GNU GCC sysroots (version 4.7 and
later). gold provides the plugin interface that is necessary to support link-time
optimization (Section 5.6), while bfd does not.
qcld specifies the Snapdragon LLVM ARM linker. For more information, see the
Qualcomm Snapdragon LLVM ARM Linker User Guide (80-VB419-102).
NOTE When using link-time optimization, the default system linker changes to
qcld. In this case, either qcld or gold must be used as the system linker
(otherwise, the optimization will fail).
NOTE For more information on sysroots see Section 4.5.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 39
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.11 Preprocessor
-A pred=ans
Asserts the predicate pred and answer ans.
-A -pred=ans
Cancels the specified assertion.
-ansi
Uses C89 standard.
-C
Retains comments during preprocessing.
-CC
Retains comments during preprocessing, including during macro expansion.
-d(DMNU)
D Prints macro definitions in -E mode in addition to normal output.
M Prints macro definitions in -E mode instead of normal output.
N Prints macro names in -E mode in addition to normal output.
U Prints referenced macro definitions in -E mode in addition to normal
output.
Also, prints #undefs for macros that are undefined when referenced.
Both are printed at the point they are referenced.
-D name
-D name=definition
Defines the specified macro symbol.
-fexec-charset=charset
Specifies the character set used to encode strings and character constants. The
default character set is UTF-8.
-finput-charset=charset
Specifies the character set used to encode the input files. The default setting is
UTF-8.
-fpch-deps
Causes the dependency-output options to additionally list the files from a
precompiled header’s dependencies.
-fpreprocessed
Notifies the preprocessor that the input file has already been preprocessed.
-fstrict-overflow
Enforces strict language semantics for pointer arithmetic and signed overflow.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 40
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-ftabstop=width
Specifies the tab stop distance.
-fwide-exec-charset=charset
Specifies the character set used to encode wide strings and character constants.
The default character set is UTF-32 or UTF-16, depending on the size of
wchar_t.
-fworking-directory
Generates line markers in the preprocessor output. The compiler uses this to
determine what the current working directory was during preprocessing.
--help
Displays the preprocessor release version.
-H
Displays the header includes and nesting depth.
-I dir
Adds the specified directory to the list of search directories for header files.
-I-
This option is deprecated.
-include file
Includes the contents of the specified source file.
-isystem prefix
Treats an included file as a system header if it is found on the specified path
(Section 4.4.6).
-isystem-prefix prefix
Treats an included file as a system header if it is found on the specified subpath of
a defined include path (Section 4.4.6).
-ino-system-prefix prefix
Does not treat an included file as a system header if it is found on the specified
subpath of a defined include path (Section 4.4.6).
-M
Outputs a make rule describing the dependencies of the main source file.
-MD
Equivalent to -M -MF file, except -E is not implied.
-MF file
Writes dependencies to the specified file.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 41
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-MG
Adds missing headers to the dependency list.
-MM
Equivalent to -M, except this opetion does not mention header files found in the
system header directories.
-MMD
Equivalent to -MD, except this option only mention user header files, not system
header files.
-MP
Creates artificial target for each dependency.
-MQ target
Specify a target to quote for dependency.
-MT target
Specify target for dependency.
-nostdinc
Omits searching for header files in the standard system directories.
-nostdinc++
Omits searching for header files in the C++-specific standard directories.
-o file
Specifies the name of the preprocessor output file.
-P
Disables linemarker output when using -E.
-remap
Generates code for file systems that only support short file names.
--target-help
Displays all command options and exit immediately.
-traditional-cpp
Emulates pre-standard C preprocessors.
-trigraphs
Preprocesses trigraphs.
-U name
Cancels any previous definition of the specified macro symbol.
-v
Equivalent to -help.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 42
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-version
Displays the preprocessor version during preprocessing.
--version
Displays the preprocessor version and exit immediately.
-w
Suppresses all preprocessor warnings.
-Wall
Enables all warnings.
-Wcomment
-Wcomments
Generate a warning if a comment symbol appears inside a comment.
-Wendif-labels
Generates a warning if an #else or #endif directive is followed by text.
-Werror
Converts all warnings into errors.
-Wimport
Generates a warning when #import is used the first time.
-Wsystem-headers
Generates a warning for constructs declared in system header files.
-Wtrigraphs
Generates a warning if a trigraph forms an escaped newline in a comment.
-Wundef
Generates a warning if an undefined non-macro identifier appears in an #if
directive.
-Wunused-macros
Generates a warning if a macro is defined without being used.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 43
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.12 Assembling
-fintegrated-as
-fno-integrated-as
Use the LLVM integrated assembler when compiling C and C++ source files.
-fno-integrated-as explicitly disables the use of the integrated assembler.
By default, the integrated assembler is enabled.
If a program can potentially generate hardware divide instructions (SDIV, UDIV),
we strongly recommend using the integrated assembler. Older GNU assemblers
may not understand these instructions.
When directly assembling a.s source file, LLVM still invokes the external
assembler because it cannot correctly translate all GNU assembly language
constructions. As a result, not all GNU assembler options (which are passed with
the -Wa option) will work with the integrated assembler.
The integrated assembler can process its own assembly-generated code, along
with most hand-written assembly that conforms to the GNU assembly syntax.
-Xassembler arg
Passes the specified argument to the assembler.
4.3.13 Linking
Starting with the LLVM 3.7 release, use Clang as the driver for linking.
object_file_name
Linker input file.
-c
Does not perform linking. This option is used with spec strings.
-dynamic
Links with a shared library (instead of a static library).
-E
Does not perform linking. This option is used with spec strings.
-l library
Searches the specified library file while linking.
-moslib=library
Searches the RTOS-specific library named liblibrary.a. The search paths for
the library and include files must be explicitly specified.
-nodefaultlibs
Does not use the standard system libraries when linking.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 44
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-nostartfiles
Does not use the standard system startup files when linking.
-nostdlib
Does not use the standard system startup files or libraries when linking.
-pie
Generates a position-independent executable as the output file.
-s
Deletes all symbol table information and relocation information from the
executable.
-S
Does not perform linking. This option is used with spec strings.
-shared
Generates a shared object as the output file. The resulting file can be subsequently
linked with other object files to create an executable.
-shared-libgcc
Links with the shared version of the library, libgcc.
-static
Does not link with the shared libraries. Only relevant when using dynamic
libraries.
-static-libgcc
Links with the static version of the library, libgcc.
-symbolic
Binds references to global symbols when building a shared object.
-u symbol
Pretends the symbol is undefined to force linking of library modules to define
symbol.
-Xlinker arg
Passes the specified argument to the linker.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 45
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.14 Directory search
-Bprefix
Specifies the top-level directory of the compiler.
-F dir
Adds the specified directory to the search path for framework includes.
--gcc-toolchain=prefix
Equivalent to -B above.
-I dir
Adds the specified directory to the include file search path.
-I-
This option is deprecated.
-Ldir
Adds the specified directory to the list of directories searched by the -l option.
--sysroot=prefix
Specifies the root directory of the system tools environment (Section 4.5).
4.3.15 Processor version
LLVM defines the options -target, -march, and -mcpu for specifying the ARM
processor version to generate code for.
If none of these options are specified, the LLVM compilers, by default, generate code for
the lowest ARMv4t instruction set architecture, in ARM mode, for the ARM7tdmi CPU.
If the ARMv7 or ARMv8 architecture is specified using the options -march or -mcpu, but
ARM mode (i.e., 32-bit-only mode) is not specified on the command line, the LLVM
compilers default to generating code in Thumb-2 mode. To disable Thumb mode, use the
options -mno-thumb or -marm.
-target triple
Specifies the ARM architecture, operating system, and ABI for code generation.
The triple argument has the following format:
arch-platform-abi
For example, to generate code for the ARMv7a which runs on Linux and
conforms to gnueabi, specify the following option:
clang -target armv7a-linux-gnueabi foo.c
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 46
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
The best way to specify the architecture version and CPU is by using the -march
and -mcpu options respectively. Even though a target triple can be used to specify
the architecture, it must match the GCC tools sysroot (Section 4.5). Thus, the
above command can be alternately expressed as follows:
clang -target arm-linux-gnueabi -mcpu=cortex-a9 foo.c
Where cortex-a9 indicates ARMv7a as the CPU.
Following are some commonly used target triples:
❒arm-linux-gnueabi
❒arm-none-linux-gnueabi (equivalent to arm-linux-gnueabi)
❒arm-linux-androideabi (for code conforming to Android EABI)
❒aarch64-linux-gnu (for ARMv8 AArch64 mode)
❒aarch64-linux-android (for code conforming to Android EABI)
❒armv8-linux-gnu (for ARMv8 AArch32 mode)
❒arm-none-eabi (for ARM bare-metal executables)
NOTE In older versions of LLVM, the -target option was named -triple.
-march=version
Specifies the ARM architecture for code generation.
This option has the following possible values:
armv5e
armv6j
armv7
armv7-a
armv7-m
armv8
armv8-a
-mcpu=version
Specifies the ARM CPU for code generation.
For a complete list of the values defined for this option, run the following
command:
llvm-as | </dev/null | llc -march=arm -mcpu=help
Following are some commonly used CPU values:
❒ARMv7:
cortex-a8
cortex-a9
cortex-a15
❒Qualcomm ARMv7:
scorpion
krait
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 47
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
❒ARMv8:
cortex-a53
cortex-a57
kryo
NOTE -mcpu automatically sets -mfpu.
-mfpu=version
Specifies the ARM architecture extensions.
For a complete list of the values defined for this option, run the following
command:
llvm-as | </dev/null | llc -march=arm -mcpu=help
Following are some commonly used option values for -mfpu:
❒neon
Enable the NEON single instruction, multiple data (SIMD) architecture
extension for the ARM Cortex-A or Qualcomm ARM v7 and ARMv8
processors.
❒vfpv4
Enable the VFPv4 architecture extensions. The VFPv4 extension enables
code generation of the fused multiply add and subtract instructions
(Section 4.3.16).
❒neon-fp-armv8
Enable NEON and ARMv8 FP extensions.
❒crypto-neon-fp-armv8
Enable Cryptography, NEON, and ARMv8 FP extensions.
Following are examples of valid -mfpu option values for ARM and AArch64:
vfp
vfpv2
vfpv3
vfpv3-fp16
vfpv3-d16
vfpv3-d16-fp16
vfpv3xd
vfpv3xd-fp16
vfpv4
vfpv4-d16
fpv4-sp-d16
fpv5-d16
fpv5-sp-d16
fp-armv8
neon
neon-fp16
neon-vfpv4
neon-fp-armv8
crypto-neon-fp-armv8
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 48
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
Using the -mcpu option automatically enables the default NEON and FP
extensions for the specified CPU target. For example:
❒-mcpu=krait
Automatically enables the NEON and VFPv4 extensions.
❒-mcpu=cortex-a9
Automatically enables the NEON and VFPv3 extensions (including the half-
precision extension).
❒-mcpu=cortexa57
Automatically enables the Cryptography, NEON, and ARMv8 FP extensions.
NOTE To disable a specific NEON or FP extension, use -mcpu along with -
mfpu. But note that using -mcpu, -march, or --target with -mfpu will
generate an error if the specified -mfpu option is invalid.
-mfloat-abi=(soft|softfp|hard)
Specifies the floating-point ABI.
NOTE ARMv8 mandates hardware floating point.
4.3.16 Code generation
-fasynchronous-unwind-tables
Generates unwind table. The table is stored in DWARF2 format.
-fchar-array-precise-tbaa
-fno-char-array-precise-tbaa
Prevents aliasing of char arrays by non-char pointers.
This option causes the compiler to assume that no pointer other than a pointer to
char can reference an element in a char array.
The default setting is disabled.
NOTE -fchar-array-precise-tbaa is enabled by default at the -Ofast
level.
In the example below, enabling -fchar-array-precise-tbaa results in the
statement d = *p being hoisted out, because p is a pointer to int.
typedef struct {
char a;
char b[100];
char c;
} S;
int *p;
S x;
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 49
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
void func1 (char d) {
for (int i = 0; i < 100; i++) {
x.b[i] += 1;
d = *p;
x.a += d;
}
}
-femit-all-data
Emits all data, even if unused.
-femit-all-decls
Emits all declarations, even if unused.
-ffp-contract=(fast|on|off)
Fused multiply add and subtract operations (VFMLA,VFMS) are more accurate
than chained multiply add and subtract operations (VMLA, VMLS) because the
chained operations perform rounding both after the multiply and before the
add/subtract. While rounding itself introduces only a small error, cumulatively it
can have a huge impact on the final result.
While fused operations are IEEE compliant, it is not IEEE compliant for the
compiler to automatically replace a multiply followed by an add/subtract (or
VMLA/VMLS) with the equivalent fused operation, since the numeric result can
differ so much. However, if a programmer explicitly specifies the use of a fused
operation, then the substitution is considered IEEE compliant.
Fused operations are explicitly specified with the -ffp-contract option. It has
the following possible values:
❒fast
Enable fused operations throughout the program.
❒on
Enable fused operations according to the FP_CONTRACT pragma (default).
❒off
Disable fused operations throughout the program.
NOTE This option must be used with the -mfpu=neon-vfpv4 option.
NOTE Enabling fused operations causes the compiler to relax IEEE compliance
for floating point computation.
-fno-exceptions
Does not generate code for propagating exceptions.
-finstrument-functions
Generates instrumentation calls in function entries and exits.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 50
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-fmerge-functions
-fno-merge-functions
Attempt to merge functions that are equivalent, or differ by only a few instructions
(Section 5.5). The default setting is disabled.
This option attempts to improve code size by merging similar functions. It uses a
number of heuristics to determine whether it is worthwhile to merge a pair of
functions. For instance, very small functions or functions with significant
differences are usually not merged.
NOTE Because this option may have a negative impact on program performance,
it is disabled by default. It becomes enabled only when it is specified
explicitly.
-fpic
Generates position-independent code (PIC) for use in a shared library.
-fPIC
Generates position-independent code for dynamic linking, avoiding any limits on
the size of the global offset table.
-fpie
-fPIE
Generates position-independent code (PIC) for linking into executables.
-fsanitize=address
-fno-sanitize=address
Generates instrumentation for the address sanitizer (Section 6.2).
-fsanitize=memory
-fno-sanitize=memory
Generates instrumentation for the memory sanitizer (Section 6.8).
-fsanitize=event[,event...]
-fno-sanitize=event[,event...]
Generates instrumentation for the undefined behavior sanitizer. One or more
events can be specified.
This option accepts the following event values:
❒alignment
Misaligned pointers or creating a misaligned reference.
❒bool
Loading boolean values that are neither true nor false.
❒bounds
Out-of-bounds array indexes (when the bounds can be statically determined).
❒enum
Loading enum values that are out-of-range for an enum type.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 51
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
❒float-cast-overflow
Floating-point conversion which would overflow the destination.
❒float-divide-by-zero
Floating-point division by zero.
❒function
Indirect function calls through a pointer of the wrong type (Linux and C++
only).
❒integer-divide-by-zero
Integer division by zero.
❒nonnull-attribute
Returning null pointer from a function declared to never return null.
❒null
Using a null pointer or creating a null reference.
❒object-size
Attempts to use bytes that the optimizer can determine are not part of the
object being accessed. (Object sizes are determined with
__builtin_object_size, so it may be possible to detect more problems at
higher optimization levels.)
❒return
In C++, reaching the end of a value-returning function without returning a
value.
❒returns-nonnull-attribute
Returning null pointer from a function declared to never return null.
❒shift
Shift operators where the amount shifted is less than zero, or greater than or
equal to the promoted bit-width of the left-hand side, or where the left-hand
side is negative. For a signed left shift, it also checks for signed overflow in C,
and for unsigned overflow in C++.
❒signed-integer-overflow
Signed integer overflow, including all the checks added by -ftrapv, and
checking for overflow in signed division (INT_MIN / -1).
❒unreachable
Program control flow reaches __builtin_unreachable.
❒unsigned-integer-overflow
Unsigned integer overflows.
❒vla-bound
Variable-length arrays whose bounds do not evaluate to a positive value.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 52
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
❒vptr
Use of an object whose vptr indicates that it is of the wrong dynamic type, or
that its lifetime has not begun or has ended. Incompatible with -fno-rtti
and -fsanitize-use-embedded-rt.
NOTE Using this option requires user-defined diagnostic handler functions. For
more information, see the undefined behavior sanitizer (Section 6.10).
-fsanitize=integer
Generates instrumentation for the undefined behavior sanitizer for the following
events (as defined above):
signed-integer-overflow
unsigned-integer-overflow
shift
integer-divide-by-zero
-fsanitize=undefined
Generates instrumentation for the undefined behavior sanitizer for the following
events (as defined above):
alignment
bool
bounds
enum
float-cast-overflow
float-divide-by-zero
function
integer-divide-by-zero
nonnull-attribute
null
object-size
return
returns-nonnull-attribute
shift
signed-integer-overflow
unreachable
vla-bound
vptr
NOTE vptr is not included when this option is used with -fsanitize-use-
embedded-rt.
-fsanitize-blacklist=file
-fno-sanitize-blacklist
Disables the generation of -fsanitize runtime checks in the specified functions
or source code files (Section 6.2).
The specified option argument is a text file, with each line in the file specifying
the name of a function or source file:
❒Function names are prefixed with fun:
❒File names are prefixed with src:
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 53
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
For example:
# Disable checks in function and source file
fun:my_func
src:my_file
Empty lines and lines starting with # are ignored.
File and function names can be specified using regular expressions, but note that #
works as it does in shell wildcarding.
-fsanitize-memory-track-origins[=level]
Tracks the origin of uninitialized memory in the memory sanitizer (Section 6.8).
This option accepts the following level values:
❒0 – Disable origin tracking.
❒1 – Track and report where uninitialized values were allocated (default).
❒2 – Track and report where uninitialized values were allocated, along with
information on intermediate stores that the uninitialized values went through.
-fsanitize-messages
-fno-sanitize-messages
Controsl the generation of diagnostic messages for undefined behavior violations
when using -fsanitize-use-embedded-rt. Enabled by default.
-fsanitize-opt-size
-fno-sanitize-opt-size
Reduces the code size of undefined behavior runtime checks when using
-fsanitize-use-embedded-rt. Using this option may decrease program
performance. Disabled by default.
-fsanitize-source-loc
-fno-sanitize-source-loc
Controls the generation of file and line number information in messages for
undefined behavior violations when using -fsanitize-use-embedded-rt.
Enabled by default, except when used with -fsanitize-opt-size, then
disabled by default.
-fsanitize-use-embedded-rt
Uses alternate undefined behavior sanitizer instrumentation and runtime
appropriate for embedded environments.
-fshort-enums
-fno-short-enums
Allocates to an enum type only as many bytes necessary for the declared range of
possible values. The default setting is disabled.
-fshort-wchar
-fno-short-wchar
Forces wchar_t to be short unsigned int. The default setting is disabled.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 54
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-ftrap-function=name
Issues a call to the specified function rather than a trap instruction.
-ftrapv
Traps on integer overflow.
-ftrapv-handler=name
Specifies the function to be called in the case of an overflow.
-funwind-tables
Similar to -fexceptions, except that it only generates any necessary static data,
without affecting the generated code in any other way.
-fverbose-asm
Adds commentary information to the generated assembly code to improve code
readability.
-fvisibility=[default|internal|hidden|protected]
Sets the default symbol visibility for all global declarations.
-fwrapv
Treats signed integer overflow as two's complement.
-mhwdiv=(arm|thumb|arm,thumb|none)
Controls the generation of hardware divide instructions in ARM or Thumb mode.
❒arm
Generate hardware divide instructions in ARM mode only.
❒thumb
Generate hardware divide instructions in Thumb mode only.
❒arm,thumb
Generate hardware divide instructions in ARM and Thumb modes.
❒none
Do not generate hardware divide instructions (default).
NOTE This option applies only to ARMv7 processors that support hardware
divide.
NOTE -mcpu=krait automatically sets -mhwdiv=arm,thumb.
-mllvm -aarch64-disable-abs-reloc
Eliminates absolute relocation by changing all global variable references to be
PC-relative.
This option is commonly used with -mllvm -emit-cp-at-end.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 55
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-mllvm -aggressive-jt
A jump table is an efficient method to optimize switch statements by replacing
them with unconditional branch instructions and simple operations to transfer
program flow to them.
This option enables switch statements with small ranges to be automatically
converted to jump tables.
The default setting is disabled.
-mllvm -arm-expand-memcpy-runtime
Sets a threshold of 8 or 16 bytes for expanding (inlining) memcpy calls.
This option enables the generation of runtime checks for copy sizes 8 or 16 bytes,
and inlining of memcpy calls that have copy sizes smaller than or equal to 8 or 16
bytes. For any other copy size the memcpy function is invoked.
Enabling this option causes an LLVM IR-level transformation. The resultant code
might be vectorized, if NEON is enabled.
This option is effective for optimization level equal or higher than -O1, Os, and
Oz. Otherwise, it is silently ignored.
-mllvm -arm-memset-size-threshold
Controls the code generation for memset library calls using NEON vector stores.
This option specifies the maximum number of bytes of data in memset call that
should be implemented with NEON vector stores. A memset call with data size
above the specified threshold will not be compiled into vector store operations.
The default setting is 128.
-mllvm -arm-memset-size-threshold-zeroval
Controls the code generation for memset library calls that write 0 value using
NEON vector stores.
This option specifies the maximum number of bytes of data in memset call that
writes 0 value that can be implemented with NEON vector stores. A memset call
that writes 0 value with data size above the specified threshold will not be
compiled into vector store operations.
The default setting is 32.
-mllvm -arm-opt-memcpy
The optimized libc for Krait targets includes two specialized memcpy functions
for copy sizes greater than 8 and 16 bytes:
memcpyGT8(void*, const void*, size_t)
memcpyGT16(void*, const void*, size_t)
When this option is set in conjunction with -mllvm -arm-expand-memcpy-
runtime, the compiler transforms the LLVM IR by replacing memcpy calls with
the runtime checks for copy size less than or equal to 8 or 16 bytes and these
specialized memcpy calls. Their implementation uses vector instructions and
requires NEON to be enabled.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 56
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
Also set the option for the copy size threshold, -mllvm -arm-expand-memcpy-
runtime.
This option has no effect if -mllvm -arm-expand-memcpy-runtime is disabled.
This option is effective for optimization level equal or higher than -O1, Os and Oz.
Otherwise it is silently ignored.
The default setting is disabled.
-mllvm -disable-thumb-scale-addressing
Controls the code generation of scaled immediate addressing in Thumb mode.
By default, scaled immediate addressing is enabled in Thumb mode, unless
-mcpu=krait is set in the command line.
To disable it, set -mllvm -disable-thumb-scale-addressing=true.
-mllvm -emit-cp-at-end
Place constant pool at the end of a function.
When this option is used in conjunction with -mllvm -aarch64-disable-abs-reloc
(which changes all global variable references to be PC-relative), the compiler
places the constant pool at the end of a function.
The default setting is disabled.
In the following example, global variable a is loaded using the default relocation
code:
movz x8, #:abs_g3:a
movk x8, #:abs_g2_nc:a
movk x8, #:abs_g1_nc:a
movk x8, #:abs_g0_nc:a
ldr w0, [x8]
Enabling this option with -mllvm -aarch64-disable-abs-reloc changes the
code to the following:
ldr x8, .LCPI0_0
ldr w0, [x8]
ret
.LCPI0_0:
.xword a // address of a
-mllvm -enable-android-compat
Controls the generation of hardware divide instructions (Section 4.5).
-mllvm -enable-arm-addressing-opt
Promotes use of optimized address modes by merging ADD operations into the
associated LOAD instruction.
The default setting is enabled.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 57
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-mllvm -enable-arm-peephole
Enables peephole optimizations to eliminate VMOV instructions, which can be an
expensive operations.
This option controls two peephole optimizations:
❒Eliminate vmovs from D to R to S
Eliminates excess VMOVs that result from copying a value from a D register
to an S register.
There is no copy instruction from D to S, so the code generator inserts a
VMOV from D to R and then another VMOV from R back to S.
This peephole optimization eliminates the VMOVs by using D registers that
alias S registers – registers D0-D15 are aliases as S0-S31. No copy is
necessary to get to an S register from these D registers.
❒Eliminate VMOVs from D to R for an ADD operation.
Eliminates excess VMOVs that result from an ADD instruction whose
operands are defined by VMOVs from a D register. The ADD is replaced with
a horizontal ADD using the VPADD instruction and a VMOV to get the result
to the R register.
The default setting is enabled.
-mllvm -enable-arm-zext-opt
Removes redundant ZERO-EXTEND operations, for example, when preceded by
a LOAD instruction that zero-extends the value to 32 bits as part of its operation.
The default setting is enabled.
-mllvm -enable-print-fp-zero-alias
When this option is used in conjunction with -no-integrate-as, the compiler
prints FP compare-with-zero instructions using the alias format fcmXY ..., #0
instead of the default LLVM format fcmXY ..., #0.0 specified in the ARMv8
documentation.
This ensures assembly code compatibility between LLVM and GNU tools while
the tools are out of sync (i.e., the 4.9 GNU assembler currently uses #0 syntax).
-mllvm -enable-round-robin-RA
Enables a round-robin register allocation heuristic which selects registers
avoiding back-to-back reuse to minimize false data dependency.
This heuristic works well for targets with limited register renaming capability, as
in Krait targets.
The default setting is disabled, unless -mcpu=krait is specified.
-mllvm -enable-select-to-intrinsics
Exposes more if-statements to be converted into LLVM IR's SELECT instruction
which in turn can more easily be mapped to ARM HW instructions.
The default setting is disabled, unless -mcpu=krait is specified.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 58
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-mllvm -favor-r0-7
Enables a heuristic in the Greedy Register Allocator that better guides the
assignment of high-order registers (R8-R15) which are currently avoided
aggressively in the allocator. The allocator exploits the fact that a Thumb-2
instruction that uses one of R8-15 registers must be encoded in 32 bits. So a
candidate assigned to these registers has a very a high cost.
With this option, the allocator avoids this register assignment based on an
additional cost, the candidate frequency in a function. The benefits are better code
size reduction, better performance/power generated from better code density, and
reduced spilling. This change impacts mostly Thumb code generation, but ARM
code generation can also be affected because it disables R8-15 register avoidance.
The default setting is disabled.
NOTE Use -falign-inner-loops with -favor-r0-7 to achieve the maximum
benefit from loop alignment.
-mllvm -force-div-attr
Controls the generation of hardware divide instructions (Section 4.5).
-mllvm -prefetch-locality-policy=(L1|L2|L3|stream)
Configures data prefetch to be temporal or non-temporal.
❒L1
Temporal or retained prefetch allocated in L1 cache.
❒L2
Temporal or retained prefetch allocated in L2 cache.
❒L3
Temporal or retained prefetch allocated in L3 cache.
❒stream
Streaming or non-temporal prefetch.
The default setting is L1.
NOTE This option is available only for AArch64, and only when
–fprefetch-loop-arrays is enabled.
-mrestrict-it
-mno-restrict-it
Controls the code generation of IT blocks.
In the ARMv8 architecture (AArch32) IT blocks are deprecated in Thumb mode.
They can only be one instruction long, and can only contain a subset of all 16-bit
instructions.
-mrestrict-it disallows the generation of IT blocks that are deprecated in
ARMv8.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 59
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-mno-restrict-it allows generation of legacy IT blocks (i.e., deprecated forms
in ARMv7).
The default option setting is determined by the target architecture (ARMv8 or
ARMv7). For ARMv8 (AArch32) Thumb mode, -mrestrict-it is enabled by
default, while for other targets it is disabled by default.
4.3.17 Vectorization
-fvectorize-loops
Performs automatic vectorization of loop code (Section 5.3).
Vectorization is subject to the following constraints:
❒On nested loops, it is performed only on the innermost loop.
❒It can be used at any code optimization level higher than -O0.
❒It works only with the ARMv7 or ARMv8 processor architecture with the
NEON extension. NEON is enabled either implicitly (by specifying a CPU
that has this extension with a -mfpu flag), or explicitly with -mfpu=neon.
NOTE -fvectorize-loops is enabled by default with -O2, -O3, -O4, and
-Ofast.
-ftree-vectorize
Alias of -fvectorize-loops, provided for GCC compatibility.
-fvectorize-loops-debug
Equivalent to -fvectorize-loops, but also generates a report indicating which
loops in the program were vectorized.
NOTE This option works best when used with the -g option to print out the
precise location of the loops that get vectorized.
NOTE LLVM does not support the GCC -ftree-vectorizer-verbose option.
-fprefetch-loop-arrays[=stride]
-fno-prefetch-loop-arrays
Controls the automatic insertion of ARM PLD instructions into loops that are
vectorized.
The stride argument specifies the distance that the PLD instruction attempts to
load. If the argument is omitted, the compiler automatically chooses a value.
The default setting is disabled.
NOTE This option must be used with the -fvectorize-loops option.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 60
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.18 Parallelization
-fparallel
Performs automatic parallelization of loop code (Section 5.4).
Parallelization is subject to the following restrictions:
❒It must be specified (on the command line) when compiling each .c or .cpp
file.
❒It must additionally be specified on the command line that directs linking.
❒It can be used only with -O2, -O3, -O4, or -Ofast.
-fparallel-symphony
Performs automatic parallelization of loop code at runtime using the
SYMPHONY library (Section 5.4.1).
Parallelization using SYMPHONY is subject to the following restrictions:
❒The -fparallel-symphony option must be specified when compiling each
.c or .cpp file.
❒The same option must also be specified when linking.
❒SYMPHONY works only with dynamically-linked executables.
NOTE This option is an alternative to -fparallel and must not be used with it.
4.3.19 Optimization
-O0
Does not optimize. This is the default optimization setting.
-O
-O1
Enables a small set of optimizations. We do not recommend this optimization
level for performance or code size.
-O2
Enables optimizations for performance, including automatic loop vectorization
(Section 4.3.17). Optimizations enabled at -O2 improve performance but may
cause a small-to-moderate increase in compiled code size.
-O3
Enables aggressive optimizations for performance. Optimizations enabled at –O3
improve performance but may cause a large increase in compiled code size.
-O4
Similar to -Ofast, but also enables advanced loop fusion and data layout
optimizations for performance. Optimizations enabled at –O4 improve
performance but may cause a large increase in compiled code size.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 61
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
NOTE The Qualcomm LLVM compilers define –O4 differently from the
standard LLVM compiler. In particular, the Qualcomm compilers do not
enable link-time optimization (Section 5.6) in –O4, while the standard
compiler does enable it in –O4,additionally mapping –O4 to –O3.
-Os
Enables optimizations for code size. Optimizations enabled at –Os reduce code
size at the cost of a small-to-moderate decrease in compiled code performance.
-Ofast
Enables all options at -O3, and increases the aggressiveness of optimizations such
as function inlining and loop unrolling. Also, -Ofast enables fast math that
allows floating point computation optimizations. User applications that require
IEEE floating point conformant code should not use -Ofast because fast math
does not preserve IEEE floating point requirements.
If -Ofast is combined with any other optimization level (-Os, -O0 to -O4) in the
command line, the last -O option prevails.
-Osize
Enables -Os level optimizations and some additional options that trade off
performance for best code size.
If -Osize is combined with any other optimization level (-Os, -Ofast, -O0 to
-O4) in the command line, the last -O option prevails.
NOTE This option has been tuned for ARMv7 targets only. It has not been tuned
for ARMv8 targets (AArch32 and AArch64) and therefore should not be
used with them.
-Oz
Enable optimizations for code size at the expense of performance. Optimizations
enabled with –Oz reduce code size at the cost of a potentially significant decrease
in compiled code performance.
4.3.19.1 Recommended options for best performance and code size
Performance:
The LLVM compilers generate the best performing code with the -Ofast option.
Examples:
❒-Ofast -mcpu=cortex-a57 (Thumb mode and -fvectorize-loops are
enabled by default)
❒-Ofast -mcpu=cortex-a57 -marm (ARM mode and
-fvectorize-loops are enabled by default)
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 62
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
Code-size:
Currently, LLVM generates the smallest code when compiled for Thumb-2 mode.
Following are the options recommended for generating compact code:
❒-Osize -mthumb (for 32-bit mode)
❒-Os (For 64-bit mode (AArch64))
4.3.20 Specific optimizations
-fdata-sections
Assigns each data item to its own section.
-ffunction-sections
Assigns each function item to its own section in the output file. The section is
named after the function assigned to it.
-finline
Specifies the inline keyword as active.
-finline-functions
Performs heuristically-selected inlining of functions.
-floop-pragma
Enables auto-parallelization and auto-vectorization when using loop pragmas.
-fnomerge-all-constants
Does not merge constants.
-fomit-frame-pointer
Does not store the stack frame pointer in a register if it is not required in a
function.
-foptimize-sibling-calls
Optimizes function sibling calls and tail-recursive calls.
-fstack-protector
Generates code which checks selected functions for buffer overflows.
-fstack-protector-all
Generates code which checks all functions for buffer overflows.
-fstack-protector-strong
Generates code which applies strong heuristic to check additional selected
functions for buffer overflows.
Additional functions checked include those with local array definitions or
references to local frame addresses.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 63
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-fstrict-aliasing
Enforces the strictest possible aliasing rules for the language being compiled.
-funit-at-a-time
Parses the entire compilation unit before beginning code generation.
-funroll-all-loops
Unrolls all loops.
-funroll-loops
Unrolls selected loops.
-fno-zero-initialized-in-bss
Assigns all variables that are initialized to zero to the BSS section.
--param ssp-buffer-size=size
Specifies the minimum size (in bytes) that a buffer must be in order to have
buffer-overflow checks generated for it by the -fstack-protector options. The
default value is 8.
4.3.21 Math optimization
-fassociative-math
Allows the operands in a sequence of floating-point operations to be re-
associated.
Because this option may reorder floating-point operations, it should be used with
caution when exact results are required (with no expectation of an error cutoff).
To use this option, both -fno-signed-zeros and -fno-trapping-math must
be enabled, while -frounding-math must not be enabled.
NOTE The optimization flag, -frounding-math, is not supported [-
Wignored-optimization-argument].
NOTE This option enables additional features of parallelization (Section 5.4).
-ffast-math
Enables the Fast-math mode in the compiler front end. This has no effect on
optimizations, but defines the preprocessor macro __FAST_MATH__ , which is the
same as the GCC -ffast-math option.
-ffinite-math-only
Enables optimizations which assume that floating-point argument and result
values are never NaNs nor +-Infs.
-fno-math-errno
Does not set errno after using single-instruction math functions.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 64
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-freciprocal-math
Enables optimizations which assume that the reciprocal of a value can be used
instead of dividing by the value.
-fno-signed-zeros
Enables optimizations which ignore the sign of floating point zero values.
-fno-trapping-math
Enables optimizations which assume that floating-point operations cannot
generate user-visible traps.
-funsafe-math-optimizations
Enables code optimizations which assume that the floating-point arguments and
results are valid, and which may violate IEEE or ANSI standards.
This option enables -fno-signed-zeros, -fno-trapping-math,
-fassociative-math, and -freciprocal-math.
4.3.22 Link-time optimization
-flto
Performs link-time optimization (Section 5.6).
This option can be used when the files in a program are compiled separately. In
this case, the option must be specified when compiling each source file, and again
when the compiler is used to link the resulting object files.
When this option is used with -c, it produces a bitcode file that is used during
link-time optimization (LTO).
All compile-time options must be passed to the linker command line so that LTO
can generate code for the specified optimization level. To ensure that the options
are passed correctly, we strongly recommend using clang/clang++ to perform
the linking.
When this option is used, the default system linker changes to the qcld linker, and
either qcld or the gold linker must be used as the system linker. The gold linker
can be specified with the -fuse option (Section 4.3.10).
NOTE The gold linker cannot be used with the Windows version of the LLVM
compilers. In this case, only the qcld linker can be used to perform LTO.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 65
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.23 Profile-guided optimization
-fprofile-instr-generate[=filename]
Specifies the name and location of the raw profile data file to be created. The
default name is default.profraw.
The default location is /data/data for Android applications.
-fprofile-instr-use=filename
Uses the specified instrumentation-generated profile data file to perform
profile-guided optimization.
-fprofile-sample-use=filename
Uses the specified sampling-generated profile data file to perform profile-guided
optimization.
--fprofile-instr-sync-interval=interval
Periodically synchronizes the collected profile data to the profile data file with the
specified time interval (in milliseconds).
On Android, if the --enable-instrument-profile-file-sync option is
enabled, this flag also means a threshold value for the number of times a function
is entered upon which the profile data sync is triggered.
-mllvm --append-profile-files
Save into the same profile file the profiling data from different runs of the same
executable or different executable runs.
-mllvm --enable-instrument-profile-file-sync
Set this option to cause the compiler to instrument functions with a call to sync
profile data to a file.
The actual sync operation occurs periodically upon entering a function and the
number of times the function is entered exceeds a threshold value, which is set via
the --fprofile-instr-sync-interval option.
On Android for example, this option must be used to avoid creating a thread for
syncing profiling data periodically.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 66
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.24 Optimization reports
-fopt-reporter=(vectorizer|parallelizer|all)
Requests the specified type of optimization report data (Section 5.9).
-polly-max-pointer-aliasing-checks
Increases the number of runtime checks that are allowed to be inserted into a loop
in order to disambiguate the pointers, thus enabling the loop to be vectorized
-Rpass=loop-opt
Outputs the line numbers of the loops that were auto-parallelized and/or
vectorized.
-Rpass-missed=loop-opt
Outputs the line number and reason why a loop was not optimized.
4.3.25 Compiler security
--analyze
Invokes the static program analyzer (Section 6.13.1) on the specified input files.
-analyzer-checker=checker
Enables the specified checker or checker category in the static program analyzer.
The checker categories are alpha, core, cplusplus, debug, and security.
Enabling a checker category enables all the checkers in that category.
For a complete list of checker names use -analyzer-checker-help.
NOTE -analyzer-checker must be prefixed with -Xclang
-analyzer-checker-help
Lists the complete set of checkers and their categories for use in
-analyzer-checker and -analyzer-checker-disable.
NOTE -analyzer-checker-help must be prefixed with -cc1
-analyzer-disable-checker=checker
Disables the specified checker or checker category in the static program analyzer.
The checker categories are alpha, core, cplusplus, debug, and security.
Disabling a checker category disables all the checkers in that category.
For a complete list of checker names use -analyzer-checker-help.
NOTE -analyzer-disable-checker must be prefixed with -Xclang
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 67
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
--analyzer-output html
Generates the static analyzer output report in HTML format.
The default report format is plist.
NOTE --analyzer-output and its argument must each be prefixed with
-Xclang.
--analyzer-Werror
Converts all static analyzer warnings into errors.
--compile-and-analyze dir
Invokes static program analyzer on an entire program.
The analysis report files are written to the specified directory.
You can replace dir with the sub-flag, --analyzer-perf. This sub-flag will
prevent the analyzer from generating HTML files and instead print a summarized
report on the stdout.
-ffcfi
Enables control-flow integrity checks (Section 6.12).
--compile-and-analyze-high
Invokes the static program analyzer on an entire program with only a small list of
high priority checkers.
The analysis report files are written to the specified directory. If you use the sub-
flag, --analyzer-perf, they are printed to the stdout.
--compile-and-analyze-medium
Invokes the static program analyzer on an entire program with a list of
high+medium priority checkers.
The analysis report files are written to the specified directory. If you use the sub-
flag, --analyzer-perf, they are printed to the stdout.
-fno-fcfi
Disables control-flow integrity checks.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 68
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.3.26 LLVM 4.0-specific compiler flags
Table 4-4 LLVM 4.0 release – new compiler flags
Flag Description
-fcoroutines-ts Enables support for the C++ Coroutines TS
-fno-coroutines-ts Disables support for the C++ Coroutines TS
-fdebug-info-for-profiling Emits extra debug information to make sample profile more
accurate
-fno-debug-info-for-profiling Does not emit extra debug information for sample profiler
-fbuiltin-module-map Loads the clang built-in intrinsics module map file
-fdiagnostics-show-hotness Enables profile hotness information in diagnostic line
-fno-sanitize-address-use-after-scope Disables use-after-scope detection in AddressSanitizer
-fsanitize-thread-memory-access Enables memory access instrumentation in ThreadSanitizer
(default)
-fno-sanitize-thread-memory-access Disables memory access instrumentation in ThreadSanitizer
-fsanitize-thread-func-entry-exit Enables function entry/exit instrumentation in ThreadSanitizer
(default)
-fno-sanitize-thread-func-entry-exit Disables function entry/exit instrumentation in ThreadSanitizer
-fsanitize-thread-atomics Enables atomic operations instrumentation in ThreadSanitizer
(default)
-fno-sanitize-thread-atomics Disables atomic operations instrumentation in ThreadSanitizer
-fno-experimental-new-pass-manager Disables an experimental new pass manager in LLVM.
-flto-jobs= Controls the back-end parallelism of
-flto=thin (default of 0 means the number of threads will be
derived from the number of CPUs detected)
-fprebuilt-module-path= Specify the prebuilt module path
-fmodules-disable-diagnostic-validation Disable validation of the diagnostic options when loading the
module
-fmodules-ts Enable support for the C++ Modules TS
-fno-diagnostics-show-hotness Disable profile hotness information in diagnostic line
-fdiagnostics-absolute-paths Print absolute paths in diagnostics
-frelaxed-template-template-args Enable C++17 relaxed template template argument matching
-fno-relaxed-template-template-args Disable C++17 relaxed template template argument matching
-faligned-allocation Enable C++17 aligned allocation functions
-fno-aligned-allocation Disable C++17 aligned allocation functions
-faligned-new faligned_allocation
-fno-aligned-new fno_aligned_allocation
-fropi Enable ARM Read-Only position independence relocation model
-fno-ropi Disable ARM Read-Only position independence relocation model
-frwpi Enable ARM Read-write position independence relocation model.
-fno-rwpi Disable ARM Read-write position independence relocation model.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 69
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
-fpreserve-as-comments Preserve comments in inline assembly
-fno-preserve-as-comments Do not preserve comments in inline assembly
-fdebug-macro Emit macro debug information
-fno-debug-macro Do not emit macro debug information
-fsave-optimization-record Generate a YAML optimization record file
-fno-save-optimization-record Do not generate a YAML optimization record file
-foptimization-record-file= Specify the file name of any generated YAML optimization record
-fstrict-return Always treat control flow paths that fall off the end of a non-void
function as unreachable
-fno-strict-return Not treat control flow paths that fall off the end of a non-void
function as unreachable
-fsplit-dwarf-inlining Place debug types in their own section (ELF Only)
-fno-split-dwarf-inlining Do not place debug types in their own sections (ELF only)
-mlong-calls Generate branches with extended addressability, usually via
indirect jumps.
-mno-long-calls Restore the default behavior of not generating long calls
-mexecute-only Disallow generation of data access to code sections (ARM only)
-mno-execute-only Allow generation of data access to code sections (ARM only)
-mpure-code mexecute_only
-mno-pure-code mno_execute_only
-mpie-copy-relocations Use copy relocations support for PIE builds
-mno-pie-copy-relocations Do not use copy relocations support for PIE builds
-mfentry Insert calls to fentry at function entry (x86 only)
-save-stats Save llvm statistics.
-precompile Only precompile the input
Table 4-4 LLVM 4.0 release – new compiler flags (cont.)
Flag Description
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 70
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.4 Warning and error messages
LLVM provides a number of ways to control which code constructs cause the compilers to
emit errors and warning messages, and how the messages are displayed on the console.
4.4.1 Controlling how diagnostics are displayed
When LLVM emits a diagnostic, it includes rich information in the output, and gives you
fine-grain control over which information is printed. LLVM has the ability to print this
information. The following options are used to control the information:
■A file/line/column indicator that shows exactly where the diagnostic occurs in
your code.
■A categorization of the diagnostic as a note, warning, error, or fatal error.
■A text string describing the problem.
■An option indicating how to control the diagnostic (for diagnostics that support it)
[-fdiagnostics-show-option].
■A high-level category for the diagnostic for clients that want to group diagnostics
by class (for diagnostics that support it) [-fdiagnostics-show-category].
■The line of source code that the issue occurs on, along with a caret and ranges
indicating the important locations [-fcaret-diagnostics].
■FixIt information, which is a concise explanation of how to fix the problem (when
LLVM is certain it knows) [-fdiagnostics-fixit-info].
■A machine-parseable representation of the ranges involved (disabled by default)
[-fdiagnostics-print-source-range-info].
For more information on these options see Section 4.3.7.
4.4.2 Diagnostic mappings
All diagnostics are mapped into one of the following classes:
■Ignored
■Note
■Warning
■Error
■Fatal
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 71
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.4.3 Diagnostic categories
Though not shown by default, diagnostics can each be associated with a high-level
category. This category is intended to make it possible to triage builds which generate a
large number of errors or warnings in a grouped way.
Categories are not shown by default, but they can be turned on with the -fdiagnostics-
show-category option (Section 4.3.7). When this option is set to name, the category is
printed textually in the diagnostic output. When set to id, a category number is printed.
NOTE The mapping of category names to category identifiers can be obtained by
invoking LLVM with the option -print-diagnostic-categories.
4.4.4 Controlling diagnostics with compiler options
LLVM can control which diagnostics are enabled through the use of options specified on
the command line.
The -W options are used to enable warning diagnostics for specific conditions in a
program. For instance, -Wmain will generate a warning if the compiler detects anything
unusual in the declaration of function main().
-Wall enables all the warnings defined by LLVM. -w disables all of them.
Warnings for a specific condition can be disabled by specifying the corresponding -Wcond
option as -Wno-cond. For instance, -Wno-main disables the warning normally enabled by
-Wmain.
-Werror=cond changes the specified warning to an error (Section 4.4.2). -Werror
specified without a condition changes all the warnings to errors. -ferror-warn changes
only the warnings that are listed in the specified text file.
-pedantic and -pedantic-errors enable diagnostics that are required by the ISO C
and ISO C++ standards.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 72
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.4.5 Controlling diagnostics with pragmas
LLVM can also control which diagnostics are enabled through the use of pragmas in the
source code. This is useful for disabling specific warnings in a section of source code.
LLVM supports GCC's pragma for compatibility with existing source code, as well as
several extensions.
The pragma may control any warning that can be used from the command line. Warnings
can be set to ignored, warning, error, or fatal. The following example instructs LLVM or
GCC to ignore the -Wall warnings:
#pragma GCC diagnostic ignored "-Wall"
In addition to all the functionality provided by GCC's pragma, LLVM also enables you to
push and pop the current warning state. This is particularly useful when writing a header
file that will be compiled by other people, because you don't know what warning flags
they build with.
In the below example -Wmultichar is ignored for only a single line of code, after which
the diagnostics return to whatever state had previously existed:
#pragma clang diagnostic push
#pragma clang diagnostic ignored "-Wmultichar"
char b = 'df'; // no warning.
#pragma clang diagnostic pop
The push and pop pragmas save and restore the full diagnostic state of the compiler,
regardless of how it was set. That means that it is possible to use push and pop around
GCC-compatible diagnostics, and LLVM will push and pop them appropriately, while
GCC will ignore the pushes and pops as unknown pragmas.
NOTE While LLVM supports the GCC pragma, LLVM and GCC do not support the
same set of warnings. Thus even when using GCC-compatible pragmas there
is no guarantee that they will have identical behavior on both compilers.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 73
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.4.6 Controlling diagnostics in system headers
Warnings are suppressed when they occur in system headers. By default, an included file
is treated as a system header if it is found in an include path specified by -isystem, but
this can be overridden in several ways.
The system_header pragma can be used to mark the current file as being a system
header. No warnings will be produced from the location of the pragma onwards within the
same file.
char a = 'xy'; // warning
#pragma clang system_header
char b = 'ab'; // no warning
The options -isystem-prefix and -ino-system-prefix can be used to override
whether subsets of an include path are treated as system headers. When the name in a
#include directive is found within a header search path and starts with a system prefix,
the header is treated as a system header. The last prefix on the command-line which
matches the specified header name takes precedence. For example:
$ clang -Ifoo -isystem bar -isystem-prefix x/
-ino-system-prefix x/y/
Here, #include "x/a.h" is treated as including a system header, even if the header is
found in foo, and #include "x/y/b.h" is treated as not including a system header, even
if the header is found in bar.
An #include directive which finds a file relative to the current directory is treated as
including a system header if the including file is treated as a system header.
4.4.7 Enabling all warnings
In addition to the traditional -W flags, all warnings can be enabled by specifying the
-Weverything option.
-Weverything works as expected with -Werror, and it also includes the warnings from
-pedantic.
NOTE When this option is used with -w (which disables all warnings), -w takes
priority.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 74
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.5 Using GCC cross compile environments
The LLVM compilers are stand-alone compilers which rely on an existing system tools
root environment – also known as sysroot – for accessing include files and libraries. The
compilers are prebuilt to work with a GCC sysroot environment: to include header files
and libraries in the build, they assume a predefined directory structure anchored by a GCC
system root directory.
For example, the GCC sysroot for the ARMv8 AArch64 toolchain has the following
structure:
/aarch64-linux-gnu/
/bin/
/debug-root/
/include/
/include/c++/4.8.2/
/backward/
/lib/
/libc/
/usr/
/include/
The top level of the GCC tools directory must have a subdirectory that matches the target
triple specified on the compiler command line (Section 4.3.15). The target triple directory
typically contains a libc directory which mimics a host compilation environment by
storing the following items:
■The library files in GCC-top/target-triple/libc/lib
■The include files in GCC-top/target-triple/libc/usr/include
Thus the sysroot location is GCC-top/target-triple/libc.
The sysroot location is specified with the compile option --sysroot.
The LLVM compilers also require the location of the GNU linker (if they are not using
qcld). This location is specified with the option -B or -gcc-toolchain, and it must point
to the top of the GCC toolchain directory.
For example, the following two LLVM commands compile a source file and generate code
for the ARMv8 AArch64 ISA:
clang -target aarch64-linux-gnu --sysroot=GCC-top/aarch64-linux-
gnu/libc -BGCC-top foo.c
clang -target aarch64-linux-gnu --sysroot=GCC-top/aarch64-linux-
gnu/libc --gcc-toolchain=GCC-top foo.c
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 75
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
With C++, it may be necessary to add a set of C++ include directories so the LLVM
compilers can correctly search for the header files. Note that this is required only with
certain GCC toolchain sysroots – in such cases the following directories should be added
to the LLVM compiler command using the -isystem option:
-isystem GCC-top/include/c++/GCC-version
-isystem GCC-top/include/c++/GCC-version/triple
-isystem GCC-top/include/c++/GCC-version/backward
Where GCC-version indicates the version number of the GCC toolchain (4.6, 4.8.1, etc.).
NOTE The target triple specified above may differ from the target triple used on the
compiler command line.
4.6 Using LLVM with GNU Assembler
Snapdragon LLVM includes support for using the GNU Assembler (GAS) as the system
assembler. The options “-mllvm -enable-android-compat” and “-mllvm
-force-div-attr” (Section 4.3.16) are used to control the generation of hardware
divide instruction so it is compatible with various versions of GAS.
By default, the LLVM compiler only emits the DIV attribute when the -mhwdiv option is
specified. Depending on the GAS version you are using, it may be necessary to change
this default behavior. Use the following guideline:
■GCC 4.6 and older releases
❒The DIV attribute is not emitted by GCC/GAS compiler/assembler.
When using LLVM with this GNU version, you must specify the option
“-mllvm -enable-android-compat”.
■GCC 4.6 / 4.7 releases
❒The DIV attribute is emitted whether or not the option -mhwdiv is specified.
It is given a different value depending on the target architecture specified:
• 0 – Allow hardware division if supported in the target architecture, or if
no information exists.
• 1 – Disallow hardware division.
• 2 – Allows hardware division as an optional extension above the base
target architecture hardware features.
When using LLVM with this GNU version, you must specify the option
“-mllvm -force-div-attr”.
■Post GCC 4.7 releases
❒The DIV attribute is emitted only when the option -mhwdiv is specified.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 76
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
4.7 Built-in functions
__builtin_neon_memcpy_1024(void*, const void*, size_t)
The header file arm_memcpy_bias.h contains the declaration of a specialized ARM 32-
bit memcpy built-in for copy size of 1024.
Using this built-in function in the source will result in generated code with a runtime
check for copy size of 1024 and the inlining of the memcpy specialized implementation for
copy size 1024 using vector instructions.
NOTE NEON must be enabled to use this built-in.
4.8 Compilation phases
The LLVM compiler consists of a driver program (named cc1) which in turn invokes a set
of tools that perform the various phases of the overall compilation process.
View phases
To view these phases during compilation, invoke the compiler using the option
-ccc-print-phases (Section 4.3.2). For example:
clang -ccc-print-phases test.c
This option prints the following information during compilation:
0: input, "test.c", c
1: preprocessor, {0}, cpp-output
2: compiler, {1}, assembler
3: assembler, {2}, object
4: linker, {3}, image
This option is useful when paired with options that control compilation. For example:
clang -c -ccc-print-phases test.c
0: input, "test.c", c
1: preprocessor, {0}, cpp-output
2: compiler, {1}, assembler
3: assembler, {2}, object
clang --analyze -ccc-print-phases test.c
0: input, "test.c", c
1: preprocessor, {0}, cpp-output
2: analyzer, {1}, plist
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 77
Qualcomm Snapdragon LLVM ARM Compiler for Android Using the Compilers
View phase commands
To view the actual tool commands performed by the driver program at each compilation
phase, invoke the compiler using the option -### (Section 4.3.2). For example:
clang -### test.c --sysroot=path_to_aarch64_android_sysroot
--gcc-toolchain=path_to_aarch64_android_tools
--target=aarch64-linux-android
This option prints the following command information:
■Preprocessor and compiler:
"clang" "-cc1" "-triple" "armv4t--linux-androideabi" "-emit-obj"
...
"-o" "/tmp/t-871e8e.o" "-x" "c" "t.c"
■Linker:
"ld" "--sysroot=..."
...
"-o" "a.out"
...
"/tmp/t-2e40e1.o"
Specify phase options
To pass a command option to the tool that performs a specific compilation phase, invoke
the compiler using the option -X (Section 4.3.2). For example:
clang -Xlinker --print-map test.c
In this example, -X is used to pass the option --print-map to the linker.
-X specifies the tool that the option will be passed to:
If the option to be passed contains one or more arguments that are separated from the
option name by spaces, then you will need to use -X multiple times in order to pass the
option. For example:
clang --analyze -Xclang -analyzer-output -Xclang html
-o dir test.c
In this example, -X is used twice to pass the option -analyzer-output html to the
compiler.
-Xclang Compiler
-Xassembler Assembler
-Xlinker Linker
-Xanalyzer Static analyzer
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 78
5Code Optimization
The LLVM compilers provide many tools and features for improving the size or speed of
the generated object code.
NOTE We strongly recommend you try using the various code optimizations to
improve the performance of your program. Using only the default
optimization settings might result in suboptimal performance.
5.1 Optimizing for performance
LLVM currently generates the fastest code when compiling for ARM mode.
For more information on -Ofast, see Section 4.3.19.
5.2 Optimizing for code size
LLVM currently generates the smallest code when compiling for Thumb-2 mode.
NOTE Thumb-2 is available only on ARMv6T2, ARMv7, and AArch32.
For ARMv7, the -Osize option is preferred over -Os because it enables additional
optimizations for code size.
For more information on -Osize, see Section 4.3.19.
Table 5-1 Options to use for optimizing code performance
Core Options
ARMv7 -Ofast -mcpu=krait
ARMv8 (AArch32) -Ofast -mcpu=cortex-a57
ARMv8 (AArch64)
Table 5-2 Options to use for optimizing code size
Core Options
ARMv7 -Ofast -mcpu=krait
ARMv8 (AArch32) -Ofast -mcpu=cortex-a57
ARMv8 (AArch64)
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 79
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.3 Automatic vectorization
LLVM includes support for automatic code vectorization. By default, the vectorizer is
enabled at code optimization level -O2 or higher. To enable it at lower optimization levels
use the -fvectorize-loops option (Section 4.3.17).
Vectorization can be used at any code optimization level higher than -O0.
To see which loops in a program get vectorized, use the following option:
-fvectorize-loops-debug
Vectorization works only with the ARMv7 or ARMv8 processor architecture with the
NEON extension. NEON is enabled either implicitly (by specifying a CPU that has this
extension with the -mcpu flag) or explicitly with -mfpu=neon.
The following is an example of a loop that can be vectorized with -fvectorize-loops:
void foo(int * restrict A, int N) {
for (int i = 0; i < N; i++)
A[i] = A[i] + 1;
}
For vectorization of floating point computation, the GCC option -ffast-math should be
specified. Because floating point vectorizations (reductions in particular) are not IEEE
compliant, the fast math option is required to ensure maximum vectorization of floating
point computations.
The vectorizer can also be enabled using the option -ftree-vectorize, which is an alias
for -fvectorize-loops.
NOTE The GCC option -ftree-vectorizer-verbose (for printing out verbose
information on a vectorized loop) is not supported. Instead, use
-fvectorize-loops-debug.
NOTE The vectorizer currently operates only on the innermost loop of a nested loop.
5.4 Automatic parallelization
The Qualcomm LLVM compilers include support for automatic code parallelization. By
default, parallelization is disabled – to enable it use the -fparallel option
(Section 4.3.18).
Parallelization can be used only with code optimization level -O2, -O3, -O4, or -Ofast.
Automatic code parallelization enables selected loops to be executed in parallel for faster
performance. During parallelization, if a loop is determined to be free of any data, control,
or memory dependencies, it is then split into multiple loops, each of which performs part
of the work from the original loop. The resulting loops are dispatched to work queues on
separate cores so they can be executed in parallel.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 80
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
Parallelization requires a runtime component which is linked into the final executable
image. The purpose of the component is to initialize a new thread at program initialization
time, and subsequently manage the work queues during parallel execution.
While automatic code parallelization can significantly improve overall performance by
distributing work across multiple cores, it accomplishes this by putting otherwise
underutilized cores to use. Because other cores get used, performance becomes a function
of the entire system, and is not fully determinable at compile time. Thus it is possible for
performance to improve, but also for the net performance to decline. Although the threads
maintain the cores in a power-saving mode when they are not working, the additional
work that is done in parallel can increase the overall power usage.
For this reason, automatic code parallelization is not enabled by default in the compiler,
and its use must be evaluated on a case-by-case basis.
5.4.1 Auto-parallelization using SYMPHONY library
The Qualcomm LLVM compilers use a library named SYMPHONY to manage loop auto-
parallelization at runtime in multi-core asynchronous runtime environments.
SYMPHONY uses work stealing and adaptive scheduling to provide more opportunities
for speeding up parallel loops when using auto-parallelization.
Using SYMPHONY
To perform auto-parallelization with SYMPHONY, use the -fparallel-symphony
option (Section 4.3.18).
-fparallel-symphony is used in place of -fparallel, and can be used with the other
auto-parallelization options (such as -fparallel-num-workloads to control loop
chunking).
We recommend using -fparallel-symphony only with the highest optimization level
(-Ofast). However, it can be used with lower optimization levels.
NOTE For full documentation on SYMPHONY (including instructions on how to
download the SYMPHONY System Manager SDK), see:
https://developer.qualcomm.com/software/symphony-system-manager-sdk.
NOTE SYMPHONY can be used only with Android applications.
SYMPHONY library
To perform auto-parallelization with SYMPHONY, the SYMPHONY dynamic library
must be available on the target Android device. If this library is not found on the device,
the program will generate an error message indicating that it is unable to load
SYMPHONY.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 81
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
The SYMPHONY library file libsymphony-1.0.0.so should be stored in the following
location:
■/system/vendor/lib64 (Android 64-bit devices)
■/system/vendor/lib (Android 32-bit devices)
To obtain the proper version of the SYMPHONY library for your Android device,
download it from:
https://developer.qualcomm.com/software/symphony-system-manager-sdk
The Android adb utility can be used to push the library file to the Android file system:
■adb push libsymphony-1.0.0.so /system/vendor/lib64/ (64-bit)
■adb push libsymphony-1.0.0.so /system/vendor/lib/ (32-bit)
Command line example
The following example shows the commands necessary to compile, link, and run a
program using auto-parallelization with the SYMPHONY library.
Compile:
$ clang --target aarch64-linux-android
--sysroot=<AArch64_Android_Sysroot>
--gcc-toolchain=<AArch64_Android_Toolchain>
-Ofast -fparallel-symphony -c /tmp/test.c
Link:
$ clang --target aarch64-linux-android
--sysroot=<AArch64_Android_Sysroot>
--gcc-toolchain=<AArch64_Android_Toolchain>
-Ofast -fparallel-symphony /tmp/test.o -o a.out
Run:
$ adb push a.out /data/data/
$ adb shell chmod 755 /data/data/a.out
$ adb shell /data/data/a.out
The executable file a.out will run without problems as long as the SYMPHONY library
is available in the specified location, and the application can be parallelized.
Table 5-3 SYMPHONY library versions for supported development platforms
Platform SYMPHONY Library File
Windows 64-bit C:\Program Files (x86)\Qualcomm\Symphony SDK\
1.0.0\aarch64-linux-android\lib
32-bit C:\Program Files (x86)\Qualcomm\Symphony SDK\
1.0.0\arm-linux-androideabi\lib
Linux 64-bit /opt/Qualcomm/Symphony/
1.0.0/aarch64-linux-android\lib
32-bit /opt/Qualcomm/Symphony/
1.0.0/arm-linux-androideabi\lib
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 82
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.5 Merging functions
LLVM includes support for function merging. By default, this optimization is disabled – to
enable it, use the -fmerge-functions option (Section 4.3.16).
Function merging attempts to improve code size by merging functions that are equivalent
or differ in only a few instructions. The optimization uses a number of heuristics to
determine whether it is worthwhile to merge a pair of functions. For instance, very small
functions or functions with significant differences are usually not merged.
The following example shows how function merging works:
int f1(int a, int b) { int f2(int a, int b) {
int x; int x;
x = a + 4; x = a + 10;
return x * b; return x * b;
} }
Function merging determines that functions f1 and f2 are similar, and replaces them with
the following functions:
int f1__merged(int a, int b, int choice) {
int x;
if (choice)
x = a + 10;
else
x = a + 4;
return x * b;
}
int f1(int a, int b) {
return f1__merged(a, b, 0);
}
int f2(int a, int b) {
return f1__merged(a, b, 1);
}
This example is for illustration purposes only. In practice, the optimizer would determine
that functions f1 and f2 are too small to be worth merging.
NOTE Because function merging may have a negative impact on program
performance, it is disabled by default, and becomes enabled only when it is
specified explicitly.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 83
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.6 Link-time optimization
Link-time optimization (LTO) comprises a set of powerful intermodular optimizations
which are performed during the linking stage of compilation.
LTO expands the scope of optimizations from individual modules to the entire program (or
at least to all the modules visible at link time). This enables deeper compiler analysis (such
as better alias analysis) and more effective code transformations (such as function
inlining), which can result in improved performance and code size.
When used with -c, the -flto option produces a file containing the LLVM compiler's
intermediate representation (also known as bitcode). This file can be subsequently used in
a final link step which then performs inter-module code optimizations on the file contents.
LTO comprises the following elements:
■The link-time optimizer, a compiler feature (controlled with -flto) which
performs the inter-modular optimizations while linking the files together.
■The LTO-specific attribute lto_preserve, which when applied to a C or C++
function or variable prevents it from being discarded by the link-time optimizer.
The Snapdragon LLVM ARM linker has been verified to support LTO on ARMv7 and
ARMv8 targets, and Linux and Windows hosts. The GNU Gold linker may support LTO
for ARMv8, depending on the GCC toolchain/sysroot version used. LTO is not supported
on Windows using the Gold linker.
NOTE For more information on the Snapdragon LLVM ARM linker, see the
Qualcomm Snapdragon LLVM ARM Linker User Guide.
NOTE For more information on the Gold linker see llvm.org/docs/GoldPlugin.html.
Link-time optimizer
The link-time optimizer is invoked with the following command:
clang -flto input_files...
The optimizer inputs several LLVM bitcode files or archives. It then links the specified
files together, performs the specified inter-modular optimizations on them as a whole, and
finally generates a single assembly file containing the optimized result.
An important optimization that the optimizer performs is the aggressive removal of any
functions that it determines are not used. To provide the optimizer with a larger context for
determining if a function is used, the list of filenames may include additional non-bitcode
objects and archives. The optimizer will use the symbol information in these files to
determine if a function should be preserved.
NOTE The optimizer requires archives to be homogeneous: the members of a given
archive must be either all bitcode files or all object files.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 84
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.7 Profile-guided optimization
Profile-guided optimization (PGO) is a two-step process:
1. A program is first executed to collect profile information on it.
2. The program is then recompiled, this time using the collected profile information
to improve the code optimization that can be performed on the program.
The availability of accurate source code profile information enables the compiler to
generate better optimized code: the compiler can focus on costly high-performance
optimizations (in terms of code size or compile time) at the profile-identified hot spots,
while limiting adverse code generation trade-offs to pathways that are relatively cold.
PGO can use two different kinds of profile information:
■Instrumentation-based profiling
■Sampling-based profiling
Each method offers distinct advantages and disadvantages when performing PGO.
However, both provide the compiler with useful information for improving code
optimization.
PGO uses the same compile options that are described here:
clang.llvm.org/docs/UsersManual.html#profile-guided-optimization
5.7.1 Instrumentation-based PGO
The instrumentation-based approach to PGO relies on a special build of the user’s code,
which inserts instrumentation that generates the appropriate profile information. The
resulting information can be used for PGO during a subsequent build.
NOTE An instrumented binary has extra runtime overhead and executes more slowly
than normal, but the generated profile information still accurately reflects the
code’s uninstrumented execution.
The following procedure explains how to perform instrumentation-based PGO:
Step 1: Build instrumented application
Compile and link your application code, using the compile option –fprofile-instr-
generate. For example:
clang++ –O2 –fprofile-instr-generate source.cc –o application
NOTE –fprofile-instr-generate optionally accepts a filename argument which
specifies the name and location of the raw profile data file to be created.
Otherwise, the file will be created with the default name and location.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 85
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
Step 2: Generate profile information
Run the built application on your device to generate the profile information. For example,
to run the above application on Android, perform the following commands:
HOST$: adb push application /data/local/tmp
HOST$: adb shell
DEVICE$ cd /data/local/tmp
DEVICE$ ./application
This command sequence creates the raw profile data file “/sdcard/default.profraw”.
Step 3: Convert profile information
Profile information can be generated either by running the instrumented program once
(which results in a single set of profile information), or by running the program several
times with different input data (which results in several sets of profile information).
In either case, the collected “raw” profiles must be converted to a file format profile that is
compatible with the Snapdragon LLVM version of PGO. To do this, use the LLVM tool
llvm-profdata and its “merge” functionality. For example:
llvm-profdata merge –output=application.profile dataset-1.profraw
dataset-2.profraw
The above example inputs two raw profile files (dataset-1.profraw,
dataset-2.profraw), merges their contents, converts the merged profiles to a format
usable in PGO, and writes the merged data to the file application.profile.
NOTE The “merge” step is required even if you only have a single profile file.
NOTE A raw profile data file can be merged with an existing merged profile data
file, or with multiple profile data files that have already been merged.
Step 4: Rebuild application using PGO
Enable PGO in your application builds, using the profile data generated in the previous
step. For example:
clang++ –O3 –fprofile-instr-use=application.profile source.cc
–o application
NOTE PGO profiles can be used at any code optimization level, and with any other
compile option (Section 5.7.5).
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 86
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.7.2 Instrumentation-based profile gen with Android apps
In instrumentation-based PGO the collected profile data is normally written to a profile
data file when the application exits. However, Android applications (APKs) typically do
not have an exit mechanism. Therefore, to collect profile data while developing Android
applications, use the compile option -fprofile-instr-sync-interval (along with the
other profile- generation options).
This option directs the compiler to create a background writer thread which syncs the
collected profile data to the file at a user-specified interval (expressed in milliseconds).
The following example directs the compiler to sync collected profile data to the file
/sdcard/default.profraw, with a sync period of 1 second:
clang++ -O2 -fprofile-instr-generate=/sdcard/default.profraw
-fprofile-instr-sync-interval=1000 source.cc
NOTE At every sync event the collected profile data is appended to the raw profile
output file. This causes the file to progressively grow in size. Raw profile files
are compressed to their normal size after the usual postprocessing is
performed with the llvm-profdata tool.
Controlling profile generation
As an alternative to using -fprofile-instr-sync-interval, Snapdragon LLVM also
provides APIs which can be used to limit profile generation to specific parts of a program.
The APIs (which must be added to the program source code) explicitly control syncing of
the collected profile data to the profile data file:
■Profile start: extern "C" int llvm_start_profile();
■Profile stop: extern "C" int lvm_stop_profile();
llvm_start_profile() resets the profile data counters to zero, thus resetting the
collected profile data.
llvm_stop_profile() syncs the currently-collected profile data to the file, and then
resets the profile data counters to zero.
NOTE The APIs are intended for advanced users who need finer control over profile
generation than is offered by -fprofile-instr-sync-interval.
NOTE The APIs return a value indicating success (0) or failure (-1). The most
common source of failure is an inaccessible write location or disk full.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 87
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.7.3 Sampling-based PGO
The sampling-based approach to PGO requires two external tools to set up the profile
information:
■Profile generator: Linux perf profiler (perf.wiki.kernel.org)
■Profile converter: autofdo (github.com/google/autofdo)
The file format for sample-based profile information is described here:
clang.llvm.org/docs/UsersManual.html#sample-profile-format
Any profile generator or converter tool that can work with this file format can be used
instead of the tools listed above.
NOTE Sample-based profiling has less runtime overhead than instrumentation-based
profiling. However, its effectiveness tends to be directly proportional to the
number of samples collected. Thus, obtaining more accurate sampled profile
information requires collecting larger amounts of sampled profile data.
The following procedure explains how to use Linux perf and autofdo to perform
sampling-based PGO:
Step 1: Build the application
Build the application code with the compile option –gline-tables-only. For example:
clang++ –gline-tables-only –O2 source.cc –o application
NOTE The application must be compiled with –gline-tables-only (or –g) to
ensure that the profile information maps accurately back to the source code.
Step 2: Generate profile information
Use the profile generator perf to collect the profile information. For example:
perf record -e cycles -c 10000 ./application
This command generates a profile data file named perf.data.
NOTE On most commercial devices, installing perf requires root access.
Step 3: Convert profile information
Install the autofdo tool and convert the raw profiles into the required sample profile
format. For example:
create_llvm_prof --binary=./application --out=application.profile
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 88
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
Step 4: Rebuild application using PGO
Enable PGO in your application build, using the profile data generated in the previous
step. For example:
clang++ –O3 –gline-tables-only –fprofile-sample-use=
application.profile source.cc –o application
NOTE The application must be compiled with –gline-tables-only to ensure that
the profile information maps accurately back to the source code.
NOTE Sample-based profile information can be used even as the user code changes
over time (Section 5.7.5).
5.7.4 Sampling-based PGO on Snapdragon MDP
Snapdragon Mobile Development Platform (MDP) devices are targeted for application
developers, and contain the latest Snapdragon processors and mobile features. MDP
devices additionally include hardware and software features that specifically support
application development.
Detailed information on Snapdragon MDP is presented here:
developer.qualcomm.com/mobile-development/development-devices/mobile-develop
ment-platform-mdp
One of the MDP developer features is the collection of sample-based profiles. Normally a
device must be rooted to collect sample data. However, MDP is preconfigured for this, and
thus makes profile collection easy to perform using production applications.
NOTE The only additional step necessary is to add the location of perf to your
PATH before using it.
The following procedure explains how to perform sampling-based PGO on a Snapdragon
MDP.
Step 1: Build the application
Build the application code with the compile option –gline-tables-only:
clang++ –gline-tables-only –O2 source.cc –o application
After building the application, move the resulting binary file to the MDP.
Step 2: Generate profile information
perf is pre-installed on a Snapdragon MDP – you just need to add it to PATH:
export PATH=/data/data/com.qualcomm.qview/:$PATH
perf record -e cycles -c 10000 ./application
After running perf, move the generated profile data files back to the host.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 89
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
Step 3: Convert profile information
Install the autofdo tool on the host and convert the raw profiles into the required sample
profile format. For example:
create_llvm_prof --binary=./application --out=application.profile
Step 4: Rebuild application using PGO
Enable PGO in your application build, using the profile data generated in step 3:
clang++ –O3 –gline-tables-only –fprofile-sample-use=
application.profile source.cc –o application
5.7.5 Profile resiliency
Profile information collected for PGO is associated back to the user’s source code, and
then used to perform PGO. As the user source code changes over time, LLVM will
associate as much of the profile information with the code as it can. In cases where LLVM
cannot associate the profiles back to source code, a warning message is generated and the
unmappable profile information is ignored. The compiler then continues associating the
profiles for the remaining parts of the user code.
LLVM profiles are thus quite resilient to changes in the source code. The user can reuse
the collected application profiles over time, without needing to re-profile the application
every time. LLVM will continue using the profiles as best as it can. Over time, as the user
code evolves, the utility of these application profiles will degrade, and they will need to be
refreshed. However, these profile refreshes are usually proportional to the scale of
evolution of the application code.
5.7.6 PGO tips
■The benefits of using PGO are closely tied to the quality of the profiles collected. The
profiles should reflect the workloads and user experience that you are trying to
optimize performance for. Often, collecting profiles while running automated
“correctness” tests for an application does not adequately exercise the hot loops. In
this case, consider creating tests that specifically target what you are optimizing for.
Improved performance of the final LLVM-generated binary is usually proportional to
how relevant the input profiles are.
■Ensure that the profiles collected cover the different use cases and are collected over
multiple runs of the same input data set (especially when using sampling-based PGO).
The accuracy of sampling-based profilers tends to improve as the sample coverage
increases.
■PGO has a greater impact on application performance when compiling at higher
optimization levels, especially if PGO is combined with link-time optimization (LTO).
With LTO profile-guided inlining is more powerful because it operates across module
boundaries. With LTO profile-guided indirect call promotion is enabled. This
optimization resolves the frequent targets for indirect or virtual calls, and thus
improves the performance of applications with indirect or virtual calls.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 90
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
■Sampling-based profiling requires using the options -g or -gline-tables-only. It
helps LLVM accurately associate the generated profiles to source code.
■PGO is resilient to changes to the user's code. The profiles generated can be
reused over time even as the application code changes. LLVM adjusts and uses the
still-relevant profiles, while ignoring the profiles it deems outdated.
■When using instrumented PGO the linker option -static (which is used to build
static executables) is not supported.
■Profile data generated with -fprofile-instr-sync-interval may include a
final profile counter section which is truncated. This can result in warnings or errors
while postprocessing with llvm-profdata. In this case, the messages can be
ignored because all the preceding profile data sections were handled correctly by
llvm-profdata. The postprocessed output is thus valid and usable for PGO.
■When a program is compiled with -fprofile-instr-generate, errno may not be
initially set to zero at the instrumented executable’s startup.
■On Android targets, PGO dumps data to logcat and requires the log library to be either
statically (-llog is passed to the linker flags) or dynamically linked.
5.8 Loop optimization pragmas
The compiler supports pragmas that can be used to selectively enable and disable the
following loop transformations:
■Auto-vectorization
NOTE The compiler always verifies the correctness of any transformation, and will
not vectorize a loop unless it can prove it is safe to do so.
5.8.1 Pragma syntax
The syntax used for loop pragmas follows the conventions used by the LLVM community.
To add a pragma to a loop, specify the pragma immediately before the target loop, using
the following syntax:
#pragma clang loop pragma [...pragma]
For detailed descriptions of the supported loop pragmas listed in Table 5-4, see
Section 5.8.3 and Section 5.8.4.
Table 5-4 Supported loop pragmas
Name Description
Vectorization pragmas
vectorize(enable) Enable auto-vectorization for a loop.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 91
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.8.2 Compile options
The loop pragmas for auto-vectorization take effect whenever the auto-vectorization
transformations are enabled. These transformations can be enabled explicitly with a
compile option (e.g., -fvectorize-loops) or implicitly with an optimization level (e.g.,
auto-vectorization is enabled at -O3).
As long as the corresponding transformation is enabled, no extra compile options are
necessary to cause loop pragmas to take effect. To have a loop pragma take effect without
enabling the transformation in general, specify the option -floop-pragma. For example,
to vectorize only a specific loop, add the following pragma to the loop and compile the file
with -floop-pragma:
#pragma clang loop vectorize(enable)
The -floop-pragma option enables the compiler to vectorize loops with enable
pragmas. Currently, -floop-pragma must be used to respect the enable pragmas when
auto-vectorization is not otherwise enabled.
NOTE This restriction is expected to be lifted in the future so enable pragmas can be
supported without the need for an additional compile option.
Table 5-6 lists the command option combinations that can enable auto-vectorization.
vectorize(disable) Disable auto-vectorization for a loop.
vectorize_width(N) Enable auto-vectorization for a loop with the specified vector
factor N. The vector factor is the number of iterations that will
be executed in parallel.
NOTE The value N must be a power of 2.
Table 5-4 Supported loop pragmas (cont.)
Name Description
Vectorization pragmas
Table 5-5 Loop pragma options that enable auto-vectorization
Name Description
-fvectorize-loops Enable auto-vectorization for all eligible loops.
-floop-pragma Enable auto-vectorization for loops specified with an enable
pragma.
Table 5-6 Loop pragma option combinations
Combination Description
-fvectorize-loops -floop-pragma Enable auto-vectorization for all eligible loops.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 92
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.8.3 Vectorization pragmas
The Snapdragon LLVM compiler supports the following vectorization pragmas:
■#pragma clang loop vectorize(enable)
■#pragma clang loop vectorize(disable)
■#pragma clang loop vectorize_width(N)
NOTE These are the same vectorization pragmas that are supported by the LLVM
community compiler.
#pragma clang loop vectorize(enable)
Enable vectorization for a loop.
This pragma has two primary use cases:
1. Enable vectorization for a specific loop when auto-vectorization is not enabled in
general.
2. Override the profitability heuristic of the auto-vectorizer.
Case 1 requires the use of the compile option -floop-pragma to enable the vectorizer to
act on loops with enabling pragmas. Case 2 can be used to vectorize loops with constant
upper bounds that would not normally be vectorized.
Safety conditions are always enforced by the compiler. The loop will not be vectorized
unless the compiler can prove it is safe, regardless of the existence of the enable pragma.
NOTE Unlike the threadify(enable)pragma, this pragma does override the
profitability conditions checked by the compiler.
#pragma clang loop vectorize(disable)
Disable vectorization for a loop.
This pragma is used to disable vectorization for a specific loop. It can be used to avoid
vectorizing loops that are not profitable, or to work around bugs in the vectorizer by not
vectorizing loops that are incorrectly vectorized.
#pragma clang loop vectorize_width(N)
Set the vector factor used to vectorize a loop.
The vector factor determines how many iterations of a loop are done in parallel. The
vector width must be a power of 2. Invalid vector widths are ignored. If the vector width is
greater than the size of the vector register, the loop is unrolled until the specified vector
width is reached.
For example, if the vector width is set to 16 and the vector register holds 4 elements, the
loop is unrolled 4 times to achieve the requested vector width.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 93
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
Setting the vector width to a value greater than 1 adds an implicit vectorize(enable)
pragma to the loop. Setting the vector width to 1 is equivalent to using a
vectorize(disable) pragma.
5.8.4 Reporting
The presence of a loop pragma can have an impact on what reports are generated for a
loop. The compile option -floop-pragma has no impact on the reports generated by the
auto-vectorizer when auto-vectorization is enabled. When auto-vectorization is disabled,
-floop-pragma triggers reporting only for loops that have pragmas.
Table 5-7 shows the interaction between reporting, options, and loop pragmas. A
checkmark indicates that the option is enabled (either from the command line or implicitly
by the optimization level), while an X indicates that the option is disabled (either explicitly
on the command line or by not appearing).
Table 5-7 assumes that all report data is requested (-fopt-reporter=all). The reports
can be further filtered using the usual mechanism of passing a specific transformation to
the -fopt-reporter option.
A new report code has been added for loops that are explicitly disabled by a loop pragma.
If the loop would otherwise be vectorized but has been disabled by a loop pragma, a loop
failed report is generated with a loop pragma disable reason code.
Table 5-7 Loop optimization reporting
-fvectorize-loops -floop-pragma Report Content
X X No reporting
X✔Report on vectorization results only for
loops with enable pragmas
✔X Report vectorization results only
✔✔
Report vectorization results for all loops
X✔Report vectorization results only for loops
with enable pragmas
✔X Report vectorization results for all loops
✔✔
Report vectorization results for all loops
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 94
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.8.5 Examples
This section presents a number of examples showing how to use pragmas and command
options to perform loop vectorization. The examples are not exhaustive – they are
intended to show how to achieve specific results.
5.8.5.1 Vectorize only a specific loop
This example demonstrates how to restrict auto-vectorization to only act on a specific
loop.
Command line
clang -Os -floop-pragma
Pragma
#pragma clang loop vectorize(enable)
Example
Typically, vectorization is disabled at -Os, but the pragma and -floop-pragma option
ensure that the loop is vectorized.
void foo(int *A, int N) {
#pragma clang loop vectorize(enable)
for(int i = 0; i < N; ++i)
A[i] += 1;
}
5.8.5.2 Disable vectorization of a specific loop
This example demonstrates how to disable auto-vectorization of a specific loop.
Command line
clang -mfpu=neon -mcpu=cortex-a57 -Ofast -fvectorize-loops
Pragma
#pragma clang loop vectorize(disable)
Example
The pragma ensures that the loop is not vectorized even though the -fvectorize-loops
option is specified on the command line.
void foo(int *A, int N) {
#pragma clang loop vectorize(disable)
for(int i = 0; i < N; ++i)
A[i] += 1;
}
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 95
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.8.5.3 Vectorize a non-profitable loop
The auto-vectorizer may decide that a loop is not profitable to vectorize, and disable
vectorization of the loop. In this case, a loop pragma can be used to specifically enable
vectorization of the loop.
Command line
clang -mfpu=neon -mcpu=cortex-a57 -Ofast
-fvectorize-loops
Pragma
#pragma clang loop vectorize(enable)
Example
Enable vectorization for the inner loop. Without the option, the auto-vectorizer could
decide that the loop is not profitable to vectorize.
void foo (int *A, int n) {
for (int j = 0; j < n; j++) {
int *p = A + 4*j;
#pragma clang loop vectorize(enable)
for (int i = 0; i < 4; i++)
p[i] += 1;
}
}
5.8.5.4 Vectorize a loop with a different vector factor
The auto-vectorizer chooses a vector factor for the loop based on an internal heuristic.
This can be overridden by using a loop pragma.
Command line
clang -mfpu=neon -mcpu=cortex-a57 -Ofast -fvectorize-loops
Pragma
#pragma clang loop vectorize_width(16)
Example
Auto-vectorize the loop in function foo, and enforce a vector factor of 16. Without the
pragma, the vectorizer could choose a different vector factor.
void foo (int *A, int n) {
#pragma clang loop vectorize_width(16)
for (int i = 0; i < n; i++)
A[i] += 1;
}
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 96
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.9 Optimization reports
Optimization reports are a new compiler reporting mode which can be used to obtain
information on why a loop is not auto-vectorized or auto-parallelized.
NOTE This feature is under development, and is subject to change in future releases.
We encourage interested users to experiment with this feature and provide
feedback on its usefulness.
The optimization report is a performance tool whose main purpose is to provide feedback
to the user on why a loop could not be vectorized or parallelized. It is particularly useful
when you have a loop you want to optimize, but the compiler optimizations are not
working on the loop. Using optimization reports, you can learn why the compiler could
not optimize the loop, and possibly take action to enable the desired optimization.
Using optimization reports to analyze a loop is an iterative process. There may be multiple
reasons why a loop cannot be transformed. The compiler will only report the first problem
it finds with the loop. After fixing the initial problem, there may be additional problems
with the loop that will be reported (by recompiling the modified source code), and will
need to be fixed before the loop is finally optimized.
The optimization report extends the community's LLVM optimization report for
auto-vectorization and auto-parallelization optimizations. The standard LLVM options
for enabling community optimization reports are described here:
clang.llvm.org/docs/UsersManual.html#options-to-emit-optimization-reports
To enable loop optimization reporting output from the compiler, specify the pass name as
loop-opt. Two options are used to output the compiler remarks:
■-Rpass=loop-opt outputs the line number of the loops that were auto-
parallelized and/or vectorized, depending on what optimization is enabled by the
compile options.
■-Rpass-missed=loop-opt outputs the line number and the reason why the loop
was not optimized.
5.9.1 Example output
Here is an example of an optimization report – it shows the messages a user will see when
a loop is successfully vectorized.
$ cat t.c
void v1(int *A, int *B, int N) {
for (int i = 0; i < N; ++i)
A[i] += B[i];
}
$ clang -mfpu=neon -mcpu=cortex-a57 -Ofast -c -g -Rpass=loop-opt
t.c
t.c:2:3: remark: Vectorized loop. [-Rpass=loop-opt]
for (int i = 0; i < N; ++i)
^
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 97
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.9.2 Optimization report message details
This section describes the most common messages produced by the compiler. Each
message description includes an example of what code triggers the message, along with
potential actions a user can take to avoid the problem and vectorize the loop.
5.9.2.1 Unsupported control flow
The unsupported control flow message indicates that a loop contains control flow and
cannot be vectorized. This is the most common message a user is likely to encounter. All
outer and nested loops will be marked as invalid because of this reason (because they
contain an inner loop, which is control flow). In many cases the control flow in an inner
loop is unavoidable, but sometimes a user can rewrite the code slightly to make it
friendlier for the vectorizer.
void foo(int *A, int *B, int N, int c, int d, int e) {
for (int i = 0; i < N; ++i) {
if (A[i] < c)
B[i] += d;
else if (A[i] > c)
B[i] += e;
}
}
t.c:2:8: remark: Loop body contains unsupported control flow
[-Rpass-missed=loop-opt]
for (int i = 0; i < N; ++i) {
The control flow could be eliminated by the compiler if there was a store to B[i] in all
cases. In this example, an else clause can be added, which enables the compiler to
remove the control flow and vectorize the loop:
void foo(int *A, int *B, int N, int c, int d, int e) {
for (int i = 0; i < N; ++i) {
if (A[i] < c)
B[i] += d;
else if (A[i] > c)
B[i] += e;
else
B[i] = B[i];
}
}
t.c:2:3: remark: Vectorized loop. [-Rpass=loop-opt]
for (int i = 0; i < N; ++i) {
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 98
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.9.2.2 Non-affine loop bound
The loop optimizer requires all loop bounds to be affine, which is a linear function of the
loop induction variable. If the loop bound is not affine – meaning that the number of
iterations of the loop cannot be analyzed – then the loop is marked as invalid for
optimization.
typedef struct S {
int a;
struct S *next;
} S;
int foo(S *s) {
while (s->next != 0) {
s->a += 1;
s = s->next;
}
return 0;
}
t.c:8:5: remark: Failed to derive an affine function from the loop
bounds.
[-Rpass-missed=loop-opt]
s->a += 1;
^
The loop bound is non-affine because the compiler cannot analyze how many iterations
the loop will execute ahead of time, because it depends on the length of the list of S
structs. Contrast this case with a standard for loop (e.g., for (int i = 0; i < N;
++i){...}), where it is known that the loop will execute N times.
void foo(int *A, unsigned int N) {
for (unsigned i = 0; i < N; i+=2) {
A[i] += 1;
}
}
t.c:3:5: remark: Failed to derive an affine function from the loop
bounds.
[-Rpass-missed=loop-opt]
A[i] += 1;
^
This example shows the problem of using unsigned variables for the loop index, with a
non-unit step. On each iteration, the loop induction variable increases by two. Because the
variable is unsigned, the C language requires that the value wrap if it reaches the max
unsigned integer value. Because the variable may wrap, it is impossible for the compiler to
compute how many iterations the loop may execute.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 99
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
This problem can be fixed by using an int for the loop variable. Unlike unsigned ints, a
plain int has undefined behavior when it wraps beyond the maximum value. The compiler
can exploit this fact to assume that the value does not wrap, and compute how many times
the loop executes (N/2 in this case).
void foo(int *A, unsigned int N) {
for (int i = 0; i < N; i+=2) {
A[i] += 1;
}
}
t.c:2:3: remark: Vectorized loop. [-Rpass=loop-opt]
for (int i = 0; i < N; i+=2) {
^
5.9.2.3 Unspecified error
This message is generated in cases where a problem cannot be easily described in terms of
actionable error messages. One example of when this message is generated is from the
complex control flow surrounding a loop.
int bar();
void foo(int *A, int N) {
while(1) {
while (*A < 10) {
if (bar())
(*A++) += 1;
else
break;
}
if (*A == 100)
break;
}
}
t.c:3:3: remark: Unspecified error. [-Rpass-missed=loop-opt]
while(1) {
^
t.c:4:5: remark: Unspecified error. [-Rpass-missed=loop-opt]
while (*A < 10) {
^
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 100
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.9.2.4 Non-loop-invariant loop bound
This message is generated when the compiler cannot prove that the loop bound does not
change during execution of the loop. The user can fix the problem by hoisting the loop
bound computation out of the loop.
int bar(int);
void n3(int *A, int *B, int N) {
for (int i = 0; i < bar(N); ++i)
A[i] += B[i];
}
t.c:4:5: remark: Loop bound may change between two different loop
iterations.
[-Rpass-missed=loop-opt]
A[i] += B[i];
^
In this example, the loop bound is computed as the return value from function bar(). The
compiler cannot see the definition of bar(), so it assumes that it must be computed on each
loop iteration. The fix is to hoist the call out of the loop.
int bar(int);
void n3(int *A, int *B, int N) {
int Bound = bar(N);
for (int i = 0; i < Bound; ++i)
A[i] += B[i];
}
t.c:4:3: remark: Vectorized loop. [-Rpass=loop-opt]
for (int i = 0; i < Bound; ++i)
^
5.9.2.5 Inst_FuncCall
This message is generated when the loop body contains a function call. You can work
around the problem by inlining the function call into the loop body (if possible).
int inc(int);
void n5(int *A, int *B, int N) {
for (int i = 0; i < N; ++i)
A[i] = inc(B[i]);
}
t.c:4:12: remark: This function call cannot be handled. Try to
inline it.
[-Rpass-missed=loop-opt]
A[i] = inc(B[i]);
^
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 101
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
If the function body is known, you can either inline the definition into the loop, or add
__attribute__((always_inline)) to the function definition. Here it is assumed that
inc() is a simple function which increments its arguments.
void n5(int *A, int *B, int N) {
for (int i = 0; i < N; ++i)
A[i] = B[i] + 1;
}
t.c:3:3: remark: Vectorized loop. [-Rpass=loop-opt]
for (int i = 0; i < N; ++i)
^
5.9.2.6 Base pointer not loop invariant
This message indicates that a pointer used to access memory can potentially change during
the execution of the loop. To successfully vectorize a loop, the compiler depends on
having base values that do not move during the loop. The problem may not always be
obvious when examining the source code, because it could be caused by potential aliasing
of values in the loop.
typedef struct {
int **b;
} S;
void foo(S *A, int N) {
for (int i = 0; i < N; ++i)
A->b[i] = 0;
}
t.c:6:5: remark: The base address of this array is not invariant
inside the loop
[-Rpass-missed=loop-opt]
A->b[i] = 0;
^
In this example, the base value is loaded from the A struct at each iteration of the loop.
The loop can be vectorized if the load of the base pointer is hoisted out of the loop.
typedef struct {
int **b;
} S;
void foo(S *A, int N) {
int **b = A->b;
for (int i = 0; i < N; ++i)
b[i] = 0;
}
t.c:6:3: remark: Vectorized loop. [-Rpass=loop-opt]
for (int i = 0; i < N; ++i)
^
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 102
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
5.9.2.7 Non-affine memory access
This message indicates that a memory access in the loop is non-affine, meaning that it is
not a linear function of the loop induction variable. Often, these accesses are the result of
double indirections in the memory access, but they can also arise from non-linear
arithmetic (e.g. A[i*i], A[i%n]).
void n4(int *A, int *B, int N) {
for (int i = 0; i < N; ++i)
A[B[i]] += 1;
}
t.c:3:5: remark: The array subscript of "A" is not affine
[-Rpass-missed=loop-opt]
A[B[i]] += 1;
^
In this example, the double indirection is the problem. The memory location accessed in
the A array is read from the B array, which makes the access to A non-affine. If possible,
the programmer should try to remove the double indirection in order to vectorize the loop.
5.9.2.8 Memory alias
This message indicates that the compiler was unable to vectorize the loop because of
aliasing problems with pointers in the loop. Normally, the compiler will insert runtime
checks to disambiguate the pointers to enable vectorization. However, if there are too
many pointers the runtime checks will not be inserted because the checks themselves may
be more costly than the benefit gained from vectorizing the loop.
The fix for this error is to increase the number of allowed runtime checks by using the
option “-mllvm -polly-max-pointer-aliasing-checks”, or by adding “restrict”
to the pointer parameters that are passed to the function.
void n4(int *A, int *B, int *C, int *D, int *E, int N) {
for (int i = 0; i < N; ++i)
A[i] = B[i] + C[i] + D[i] + E[i] + 1;
}
t.c:3:5: remark: Accesses to the arrays "B", "C", "D", "E", "A" may
access the same memory.
[-Rpass-missed=loop-opt]
A[i] = B[i] + C[i] + D[i] + E[i] + 1;
^
The compiler reports an aliasing issue with the pointers in the loop. In this case, the
number of runtime checks can be increased using the option -mllvm -polly-max-
pointer-aliasing-checks=5 in order to vectorize the loop.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 103
Qualcomm Snapdragon LLVM ARM Compiler for Android Code Optimization
Alternatively, restrict can be added to the function parameters to tell the compiler that
the pointers do not alias. Adding restrict is the preferred fix in this case because it
avoids the overhead of runtime checks and leads to more efficient code.
void n4(int * restrict A, int * restrict B, int * restrict C, int *
restrict D, int * restrict E, int N) {
for (int i = 0; i < N; ++i)
A[i] = B[i] + C[i] + D[i] + E[i] + 1;
}
t.c:2:3: remark: Vectorized loop. [-Rpass=loop-opt]
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 104
6Compiler Security Tools
The LLVM compilers support several tools and features for improving the security and
reliability of program code.
6.1 Sanitizer support
Not all sanitizers are supported on all targets. Table 6-1 shows which sanitizers are
supported on which targets.
6.2 Sanitizer special case lists
The behavior of the sanitizers can be controlled for certain source-level entities (such as
functions) by providing a special file at compile-time. This file is called a special case list.
Special case lists are used to do the following things:
■Speed up time-critical functions that are already known to be correct
■Ignore functions that perform low-level operations (such as traversing thread
stacks, which bypasses the stack frame boundaries)
■Ignore functions with known problems
To create a special case list, create a text file which lists the source-level entities to be
ignored. Then pass this file to the compiler with the option -fsanitize-blacklist
(Section 4.3.16).
Example case list:
Table 6-1 Sanitizer support
Sanitizer AARCH64-Linux AARCH64-Android ARM-Linux ARM-Android
Address Sanitizer ✔✔✔✔
Data flow Sanitizer ✔XXX
Leak Sanitizer ✔XXX
Memory Sanitizer ✔XXX
Thread Sanitizer ✔XXX
Undefined Behavior
Sanitizer
✔X✔X
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 105
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
# Disable checks in function and source file
fun:my_func
src:my_file
Each line in a special case list file has the following syntax:
entity:regexp[=category]
entity specifies the type of source-level entity. It has the following possible values:
■src – Source file
■fun – Function
■global – Global variable (ASan only)
■type – Class or struct type (ASan only)
global and type are specific to the Address Sanitizer. They are used to suppress error
reports for out-of-bound accesses to the specified global symbols, or to instances of the
specified class or struct type.
regexp specifies a regular expression which specifies the entity name.
category optionally specifies a category value to associate with the entity. Category
values are specific to each sanitizer.
Empty lines and lines starting with # are ignored. The meaning of * in regular expression
for entity names is different – it is treated as in shell wildcarding.
For example:
# Lines starting with # are ignored.
# Turn off checks for the source file (use absolute path or path
relative
# to the current working directory):
src:/path/to/source/file.c
# Turn off checks for a particular function (use mangled names):
fun:MyFooBar
fun:_Z8MyFooBarv
# Extended regular expressions are supported:
fun:bad_(foo|bar)
src:bad_source[1-9].c
# Shell like usage of * is supported (* is treated as .*):
src:bad/sources/*
fun:*BadFunction*
# Specific sanitizer tools may introduce categories.
src:/special/path/*=special_sources
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 106
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.3 Sanitizer usage on Android
Generating an Android LLVM executable with sanitizer instrumentation requires the
following items:
■The Android NDK (for its linker)
■sysroot (for building the executable)
Once the executable is built, push your executable, the sanitizer runtime library, and the
LLVM Symbolizer (Section 6.11) to an Android device. The sanitizer runtime library is a
shared object which must be preloaded into the executable when launched.
The shared object can be found under the LLVM release tools installation directory:
export INSTALL_PREFIX=LLVM_release_tools_install_dir
file $INSTALL_PREFIX/lib/clang/*/lib/linux/libclang_rt.xsan-arm-
android.so
NOTE xsan specifies a sanitizer library (asan, msan, etc.).
Example
Choose one of the examples that are provided in the individual sanitizer sections (for
example, Section 6.5.1).
1. Build a C/C++ executable with the sanitizer instrumentation:
$ mkdir -p out
$ $INSTALL_PREFIX/bin/clang++ -target arm-linux-androideabi -g
-fsanitize=san_opt boom.cc -o out/boom
--sysroot=Android_ARM_sysroot
--gcc-toolchain=Android_NDK_toolchain
NOTE san_opt specifies a sanitizer option value (address, memory, etc.).
2. Push the executable, sanitizer runtime library, and symbolizer to Android device
(Jellybean or later)
$ adb push out/boom /data/data/
$ adb push $INSTALL_PREFIX/lib/clang/*/lib/linux/libclang_rt.
xsan-arm-android.so
/data/data/
$ adb push $INSTALL_PREFIX/arm-linux-androideabi/llvm-
symbolizer /data/data/
NOTE xsan specifies a sanitizer library (asan, msan, etc.).
3. Run the sanitizer-instrumented executable:
$ adb shell "san_path_SYMBOLIZER_PATH=/data/data/llvm-
symbolizer LD_PRELOAD=/data/data/libclang_rt.xsan-arm-
android.so /data/data/boom"
NOTE san_path and xsan specify a sanitizer path variable (ASAN, MSAN, etc.)
and library (asan, msan, etc.).
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 107
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
Include the symbolizer in the argument string (as shown above) only if the
sanitizer you are using requires a symbolizer to resolve the symbol names.
If the command line execution outputs the error, “CANNOT LINK EXECUTABLE:
could not load library”, try exporting the LD_LIBRARY_PATH:
adb shell "export LD_LIBRARY_PATH=/data/data/ ;
san_path_SYMBOLIZER_PATH=/data/data/llvm-symbolizer
LD_PRELOAD=/data/data/libclang_rt.xsan-arm-android.so
/data/data/boom"
6.4 Sanitizer usage on Linux
1. Build a C/C++ executable with sanitizer instrumentation:
$INSTALL_PREFIX/bin/clang++ -target arm-linux-gnueabi
--sysroot=Linux_ARM_sysroot
--gcc-toolchain=Linux_ARM_toolchain
-g
-fsanitize=san_opt boom.cc
-o boom
2. Run the ARM sanitizer-instrumented executable. You can run the executable on
an ARM Linux system:
san_path_SYMBOLIZE_PATH=$INSTALL_PREFIX/arm-linux-gnueabi/llvm-
symbolizer ./boom
NOTE san_opt and san_path specify a sanitizer option value (address,
memory, etc.) and path variable (ASAN, MSAN, etc.).
Include the symbolizer (as shown above) only if the sanitizer you are using
requires a symbolizer to resolve the symbol names.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 108
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.5 Address Sanitizer
The LLVM compiler release includes a tool named Address Sanitizer (ASan), which can
be used to detect memory errors in C and C++ code.
ASan controls checking for the following memory errors:
■Out-of-bounds accesses to heap, stack, and globals
■Use-after-free
■Use-after-return (to a certain extent)
■Double-free, invalid free
■Double-free, invalid free
■Memory leaks (experimental)
ASan is a runtime tool which requires compile-time instrumentation of the code, and a
dedicated runtime library. If ASan encounters a bug during the execution of a program, it
halts the execution and displays (on stderr) an error message and stack trace.
NOTE A program instrumented with ASan typically runs 2x slower.
6.5.1 Usage
To use ASan you must instrument your C/C++ code and generate an Android/Linux
executable.
To instrument your C/C++ code with ASan, add the following options to both the compile
and link options in LLVM:
-g -fsanitize=address
The ASan runtime library must be linked to the final executable – be sure to use clang
(not ld) for the final link step.
When linking shared libraries, the ASan runtime is not linked, so -Wl,-z,defs may
cause link errors (do not use it with ASan). To get a reasonable performance add -O1 or
higher. To get nicer stack traces in error messages, add -fno-omit-frame-pointer. To
get perfect stack traces, it might be necessary to disable inlining (only use -O1) and tail
call elimination (-fno-optimize-sibling-calls).
For example:
% cat example_UseAfterFree.cc
int main(int argc, char **argv) {
int *array = new int[100];
delete [] array;
return array[argc]; // BOOM
}
# Compile and link
% clang -O1 -g -fsanitize=address -fno-omit-frame-pointer
example_UseAfterFree.cc
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 109
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
Or:
# Compile
% clang -O1 -g -fsanitize=address -fno-omit-frame-pointer -c
example_UseAfterFree.cc
# Link
% clang -g -fsanitize=address example_UseAfterFree.o
If a bug is detected, the program will print an error message to stderr and exit with a
non-zero exit code. ASan exits on the first detected error. This is by design:
■This approach enables ASan to produce faster and smaller generated code (both
by approximately 5%).
■Fixing bugs becomes unavoidable. ASan does not produce false alarms. Once
memory is corrupted the program is in an inconsistent state, which can lead to
confusing results and potentially misleading subsequent reports.
6.5.2 Symbolizing the reports
To make ASan symbolize its output, you must set the ASAN_SYMBOLIZER_PATH
environment variable to point to the llvm-symbolizer binary (or alternatively ensure
that llvm-symbolizer is in your $PATH).
For example:
% ASAN_SYMBOLIZER_PATH=/usr/local/bin/llvm-symbolizer ./a.out
==9442== ERROR: AddressSanitizer heap-use-after-free on address
0x7f7ddab8c084 at pc 0x403c8c bp 0x7fff87fb82d0 sp 0x7fff87fb82c8
READ of size 4 at 0x7f7ddab8c084 thread T0
#0 0x403c8c in main example_UseAfterFree.cc:4
#1 0x7f7ddabcac4d in __libc_start_main ??:0
0x7f7ddab8c084 is located 4 bytes inside of 400-byte region
[0x7f7ddab8c080,0x7f7ddab8c210)
freed by thread T0 here:
#0 0x404704 in operator delete[](void*) ??:0
#1 0x403c53 in main example_UseAfterFree.cc:4
#2 0x7f7ddabcac4d in __libc_start_main ??:0
previously allocated by thread T0 here:
#0 0x404544 in operator new[](unsigned long) ??:0
#1 0x403c43 in main example_UseAfterFree.cc:2
#2 0x7f7ddabcac4d in __libc_start_main ??:0
==9442== ABORTING
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 110
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.5.3 Additional checks
ASan performs the following additional checks.
Initialization order checking
ASan can optionally detect dynamic initialization order problems, when initialization of
globals defined in one translation unit uses globals defined in another translation unit. To
enable this check at runtime, set the environment variable:
ASAN_OPTIONS=check_initialization_order=1.
Memory leak detection
For more information on memory leak detection in ASan, see Section 6.7.
6.5.4 Issue suppression
ASan generally does not produce false positives, so if you see one, look again. Most likely
it is a true positive.
Suppressing reports in external libraries
Runtime interposition allows ASan to find bugs in code that is not being recompiled. If
you run into an issue in external libraries, we recommend immediately reporting it to the
library maintainer so that it gets addressed. However, you can use the following
suppression mechanism to unblock yourself and continue on with the testing. This
suppression mechanism should only be used for suppressing issues in external code; it
does not work on code recompiled with ASan. To suppress errors in external libraries, set
the environment variable ASAN_OPTIONS to point to a suppression file. You can specify
either the full path to the file, or the path of the file relative to the location of your
executable.
For example:
ASAN_OPTIONS=suppressions=MyASan.supp
Use the following format to specify the names of the functions or libraries you want to
suppress. You can see these in the error report. Remember that the narrower the scope of
the suppression, the more bugs you will be able to catch.
interceptor_via_fun:NameOfCFunctionToSuppress
interceptor_via_fun:-[ClassName objCMethodToSuppress:]
interceptor_via_lib:NameOfTheLibraryToSuppress
__has_feature(address_sanitizer)
In some cases, you may need to execute different code depending on whether ASan is
enabled. The language extension __has_feature can be used for this purpose.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 111
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
For example:
#if defined(__has_feature)
# if __has_feature(address_sanitizer)
// code that builds only under AddressSanitizer
# endif
#endif
__has_feature is a function-like macro which accepts a single identifier argument that is
the name of a feature. It evaluates to 1 if the feature is both supported by Clang and
standardized in the current language standard. If not, it evaluates to 0.
Another use of __has_feature is to check for compiler features not related to the
language standard (such as ASan itself).
__attribute__((no_sanitize("address")))
Some code should not be instrumented by ASan. To disable the instrumentation of a
particular function, use the following function attribute:
__attribute__((no_sanitize("address")))
NOTE The no_sanitize attribute has the deprecated synonyms
no_sanitize_address and no_address_safety_analysis.
Blacklist – Runtime Suppression
ASan supports the use of sanitizer special case lists to suppress error reports in the
specified source files or functions (Section 6.2). Additionally, it defines the ASan-specific
entity types global and type for suppressing error reports on any out-of-bound accesses
to globals with certain names and types (you can only specify class or struct types).
ASan defines a sanitizer-specific category, init, which can be used in a case list to
suppress error reports about initialization-order problems occurring in certain source files
or with certain global variables.
For example:
# Suppress error reports for code in a file or in a function:
src:bad_file.cpp
# Ignore all functions with names containing MyFooBar:
fun:*MyFooBar*
# Disable out-of-bound checks for global:
global:bad_array
# Disable out-of-bound checks for global instances of a given class
...
type:Namespace::BadClassName
# ... or a given struct. Use wildcard to deal with anonymous
namespace.
type:Namespace2::*::BadStructName
# Disable initialization-order checks for globals:
global:bad_init_global=init
type:*BadInitClassSubstring*=init
src:bad/init/files/*=init
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 112
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.5.5 Suppressing memory leaks
If the Leak Sanitizer (Section 6.7) is run as part of ASan, any memory leak reports it
generates can be suppressed by a separate file passed to the compiler using the
environment variable LSAN_OPTIONS. For example:
LSAN_OPTIONS=suppressions=MyLSan.supp
The specified text file (in this case, MyLSan.supp) contains one or more lines of the
following form:
leak:pattern
Memory leaks will be suppressed if the any of the patterns specified in this file match a
function name, source file name, or library name in the symbolized stack trace of the leak
report. For details, see Section 6.7.
6.5.6 Limitations
■ASan uses more real memory than a native run. Exact overhead depends on the
allocations sizes. The smaller the allocations you make the bigger the overhead is.
■ASan uses more stack memory. We have seen up to 3x increase.
■On 64-bit platforms, ASan maps (but not reserves) 16+ terabytes of virtual
address space. This means that tools like ulimit may not work as usually expected.
■Static linking is not supported.
6.5.7 Options
When you run your instrumented executable and ASan does not detect any errors, you will
see no output. Conversely, when you see no output, it can mean either that no errors
occurred, or that your executable was not instrumented with the ASan runtime.
To verify that your executable is instrumented with ASan, use the environment variable
ASAN_OPTIONS and the flag “verbosity=1”. Doing this directs the ASan runtime to
output a startup message when your executable is launched. For example (in Bash):
$ ASAN_OPTIONS=verbosity=1 ./myExe
If no output is generated while verbose mode is enabled, this implies your executable was
not instrumented with ASan. Check that the option -fsanitize=address was passed to
clang for both for the compilation step and the linking step.
ASan offers a variety of options for controlling the runtime behavior and enabling/
disabling its functionality. For example, if you are running out of memory, set
qualantine_size=0. This causes ASan to miss any use-after-free errors but still detect
buffer-overflow errors. Similarly, if you are overflowing the stack, set redzone=0 to save
stack space. In this case, you will miss buffer-overflow errors, but can still detect
use-after-free errors.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 113
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
You can specify multiple options by separating flags with a colon. For example:
$ ASAN_OPTIONS=log_path=my-asan-report:redzone=8
6.5.8 Notes
The ASan runtime library does not yet demangle symbols, but the LLVM symbolizer can
be used to demangle symbols (Section 6.11).
The ASan runtime library cannot be statically linked on Android. The linker does not load
the libc symbols before any others, as it does on Linux systems. ASan relies on this
feature to hijack symbols before any other shared objects are loaded. Therefore, on
Android it is necessary to use the LD_PRELOAD trick.
NOTE For more information on ASan see
clang.llvm.org/docs/AddressSanitizer.html.
Table 6-2 Options supported in ASan
Option Default Description
verbosity 0 Be more verbose (mostly for testing the tool
itself).
malloc_context_size 30 Number of frames in malloc/free stack traces (0-
256).
redzone 16 Size of minimal redzone.
log_path stderr Path to log files. If specified as log_path=PATH,
every process will write error reports to PATH.PID.
sleep_before_dying 0 Sleep for the specified number of seconds before
exiting the process on failure.
quarantine_size 256Mb Size of quarantine (in bytes) for finding use-after-
free errors. Lower values save memory but
increase false negatives rate.
exitcode 1Call _exit(exitcode) on error.
abort_on_error 0 If set to 1, on error call abort() instead of
_exit(exitcode).
strict_memcmp 1If set to 1 (default), treat memcmp("foo",
"bar", 100) as a bug.
alloc_dealloc_mismatch 1 If set to 1, check for mismatches between
malloc()/new/new and free()/delete/delete.
handle_segv 1 If set to 1, ASan installs its own handler for
SIGSEGV.
allow_user_segv_handler 0If set to 1, allows the user to override SIGSEGV
handler installed by ASan.
check_initialization_order 0 If set to 1, detect existing initialization order
problems.
strip_path_prefix "" If strip_path_prefix=PREFIX, remove the
substring .*PREFIX from the reported file names.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 114
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.6 Data Flow Sanitizer
The LLVM compiler release includes a tool named Data Flow Sanitizer (DFSan), which
can be used to perform generalized data flow analysis on C and C++ code.
Unlike the other sanitizers, DFSan is not designed to detect a specific class of bugs on its
own. Instead, it provides a generic dynamic data flow analysis framework to be used by
clients to help detect application-specific issues within their own code.
6.6.1 Usage
With no program changes, applying DFSan to a program will not alter its behavior. To use
DFSan, the program uses API functions to apply tags to data to cause it to be tracked, and
to check the tag of a specific data item. DFSan manages the propagation of tags through
the program according to its data flow.
The APIs are defined in the header file sanitizer/dfsan_interface.h. For further
information about each function, please refer to the header file.
6.6.2 ABI list
DFSan uses a list of functions known as an ABI list to decide whether a call to a specific
function should use the operating system’s native ABI, or whether it should use a variant
of this ABI that also propagates labels through function parameters and return values.
The ABI list file also controls how labels are propagated in the former case. DFSan comes
with a default ABI list which is intended to eventually cover the glibc library on Linux,
but it may become necessary for users to extend the ABI list in cases where a particular
library or function cannot be instrumented (for example, because it is implemented in
assembly or another language that DFSan does not support) or a function is called from a
library or function which cannot be instrumented.
DFSan’s ABI list file uses the same format as a sanitizer special case list (Section 6.2).
The pass treats every function in the uninstrumented category in the ABI list file as
conforming to the native ABI. Unless the ABI list contains additional categories for those
functions, a call to one of those functions will produce a warning message, as the labeling
behavior of the function is unknown.
DFSan defines the sanitizer-specific categories discard, functional, and custom to
control the sanitizer behavior:
■discard – To the extent that this function writes to (user-accessible) memory, it
also updates labels in shadow memory (this condition is trivially satisfied for
functions which do not write to user-accessible memory). Its return value is
unlabelled.
■functional – Like discard, except that the label of its return value is the union of
the label of its arguments.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 115
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
■custom – Instead of calling the function, a custom wrapper __dfsw_F is called,
where F is the name of the function. This function may wrap the original function
or provide its own implementation. This category is generally used for
uninstrumentable functions which write to user-accessible memory or which have
more complex label propagation behavior. The signature of __dfsw_F is based on
that of F with each argument having a label of type dfsan_label appended to the
argument list. If F is of non-void return type a final argument of type
dfsan_label * is appended to which the custom function can store the label for
the return value.
For example:
void f(int x);
void __dfsw_f(int x, dfsan_label x_label);
void *memcpy(void *dest, const void *src, size_t n);
void *__dfsw_memcpy(void *dest, const void *src, size_t n,
dfsan_label dest_label, dfsan_label src_label,
dfsan_label n_label, dfsan_label *ret_label);
If a function defined in the translation unit being compiled belongs to the uninstrumented
category, it will be compiled so as to conform to the native ABI. Its arguments will be
assumed to be unlabeled, but it will propagate labels in shadow memory.
For example:
# main is called by the C runtime using the native ABI.
fun:main=uninstrumented
fun:main=discard
# malloc only writes to its internal data structures, not
# user-accessible memory.
fun:malloc=uninstrumented
fun:malloc=discard
# tolower is a pure function.
fun:tolower=uninstrumented
fun:tolower=functional
# memcpy needs to copy the shadow from the source to the
destination region.
# This is done in a custom function.
fun:memcpy=uninstrumented
fun:memcpy=custom
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 116
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.6.3 Example
The following program demonstrates label propagation by checking that the correct labels
are propagated.
#include <sanitizer/dfsan_interface.h>
#include <assert.h>
int main(void) {
int i = 1;
dfsan_label i_label = dfsan_create_label("i", 0);
dfsan_set_label(i_label, &i, sizeof(i));
int j = 2;
dfsan_label j_label = dfsan_create_label("j", 0);
dfsan_set_label(j_label, &j, sizeof(j));
int k = 3;
dfsan_label k_label = dfsan_create_label("k", 0);
dfsan_set_label(k_label, &k, sizeof(k));
dfsan_label ij_label = dfsan_get_label(i + j);
assert(dfsan_has_label(ij_label, i_label));
assert(dfsan_has_label(ij_label, j_label));
assert(!dfsan_has_label(ij_label, k_label));
dfsan_label ijk_label = dfsan_get_label(i + j + k);
assert(dfsan_has_label(ijk_label, i_label));
assert(dfsan_has_label(ijk_label, j_label));
assert(dfsan_has_label(ijk_label, k_label));
return 0;
}
NOTE For more information on DFSan, see
clang.llvm.org/docs/DataFlowSanitizer.html.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 117
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.7 Leak Sanitizer
The LLVM compiler release includes a tool named Leak Sanitizer (LSan), which can be
used to detect runtime memory leaks in C and C++ code.
LSan can be combined with the Address Sanitizer (Section 6.5) to enable both memory
error and leak detection, or it can be used as a stand-alone tool.
NOTE LSan adds almost no performance overhead until the very end of the process,
when an extra leak detection phase is performed.
6.7.1 Usage
To use LSan, simply build your program with the Address Sanitizer (Section 6.5).
For example:
$ cat memory-leak.c
#include <stdlib.h>
void *p;
int main() {
p = malloc(7);
p = 0; // The memory is leaked here.
return 0;
}
% clang -fsanitize=address -g memory-leak.c ; ./a.out
==23646==ERROR: LeakSanitizer: detected memory leaks
Direct leak of 7 byte(s) in 1 object(s) allocated from:
#0 0x4af01b in __interceptor_malloc /projects/compiler-
rt/lib/asan/asan_malloc_linux.cc:52:3
#1 0x4da26a in main memory-leak.c:4:7
#2 0x7f076fd9cec4 in __libc_start_main libc-start.c:287
SUMMARY: AddressSanitizer: 7 byte(s) leaked in 1 allocation(s).
To use LSan in stand-alone mode, link your program with the option -fsanitize=leak.
Be sure to use clang (not ld) for the link step, to ensure that the proper LSan runtime
library is linked into the final executable.
NOTE For more information on LSan, see clang.llvm.org/docs/LeakSanitizer.html.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 118
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.8 Memory Sanitizer
The LLVM compiler release includes a tool named Memory Sanitizer (MSan) which can
be used to detect the use of uninitialized memory in C and C++ code.
MSan is a runtime tool which requires compile-time instrumentation of the code, and a
dedicated runtime library. If MSan encounters a bug during the execution of a program, it
halts the execution and displays (on stderr) an error message and stack trace. In addition, it
may optionally display information on where the uninitialized memory was originally
allocated.
6.8.1 Usage
To instrument your C/C++ code with MSan, add the following option to both the compile
and link options in LLVM:
-fsanitize=memory
The MSan runtime library must be linked to the final executable – be sure to use clang
(not ld) for the final link step.
When linking shared libraries, the MSan runtime is not linked, so -Wl,-z,defs may
cause link errors (do not use it with MSan). For reasonable execution performance use -O1
or higher. For meaningful stack traces in error messages use -fno-omit-frame-
pointer. For perfect stack traces you may need to disable inlining (only use -O1) and tail
call elimination (-fno-optimize-sibling-calls).
For example:
% cat umr.cc
#include <stdio.h>
int main(int argc, char** argv) {
int* a = new int[10];
a[5] = 0;
if (a[argc])
printf("xx\n");
return 0;
}
% clang -fsanitize=memory -fno-omit-frame-pointer -g -O2 umr.cc
If a bug is detected, the program will print an error message to stderr and exit with a
non-zero exit code:
% ./a.out
WARNING: MemorySanitizer: use-of-uninitialized-value
#0 0x7f45944b418a in main umr.cc:6
#1 0x7f45938b676c in __libc_start_main libc-start.c:226
NOTE By default, MSan exits on the first detected error. If you find the error report
hard to understand, try enabling origin tracking (Section 6.8.3).
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 119
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
__has_feature(memory_sanitizer)
In some cases you may need to execute different code depending on whether MSan is
enabled. The language extension __has_feature can be used for this purpose.
For example:
#if defined(__has_feature)
# if __has_feature(memory_sanitizer)
// code that builds only under MemorySanitizer
# endif
#endif
__has_feature is a function-like macro which accepts a single identifier argument that is
the name of a feature. It evaluates to 1 if the feature is both supported by Clang and
standardized in the current language standard. If not, it evaluates to 0.
Another use of __has_feature is to check for compiler features not related to the
language standard (such as MSan itself).
__attribute__((no_sanitize_memory))
Some code should not be instrumented by MSan. To disable the instrumentation of a
particular function, use the following function attribute:
__attribute__((no_sanitize_memory))
To avoid false positives MSan may still instrument such functions.
Blacklist
MSan supports the use of sanitizer special case lists to suppress error reports in the
specified source files or functions (Section 6.2). All “Use of uninitialized value” warnings
are suppressed, and all values loaded from memory are considered fully initialized.
6.8.2 Report symbolization
MSan uses an external symbolizer to print files and line numbers in reports. Ensure that
the llvm-symbolizer binary is in PATH, or set the environment variable
MSAN_SYMBOLIZER_PATH to point to it.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 120
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.8.3 Origin tracking
MSan can track origins of uninitialized values, similar to Valgrind’s –track-origins
option. This feature is enabled with the option -fsanitize-memory-track-origins=2
(or simply -fsanitize-memory-track-origins).
Example of origin tracking (using the code from the preceding example):
% cat umr2.cc
#include <stdio.h>
int main(int argc, char** argv) {
int* a = new int[10];
a[5] = 0;
volatile int b = a[argc];
if (b)
printf("xx\n");
return 0;
}
% clang -fsanitize=memory -fsanitize-memory-track-origins=2 -fno-
omit-frame-
pointer -g -O2 umr2.cc
% ./a.out
WARNING: MemorySanitizer: use-of-uninitialized-value
#0 0x7f7893912f0b in main umr2.cc:7
#1 0x7f789249b76c in __libc_start_main libc-start.c:226
Uninitialized value was stored to memory at
#0 0x7f78938b5c25 in __msan_chain_origin msan.cc:484
#1 0x7f7893912ecd in main umr2.cc:6
Uninitialized value was created by a heap allocation
#0 0x7f7893901cbd in operator new[](unsigned long)
msan_new_delete.cc:44
#1 0x7f7893912e06 in main umr2.cc:4
By default, MSan collects both the allocation points and all intermediate stores that the
uninitialized value went through.
Origin tracking has proved to be very useful for debugging MSan reports. It slows down
program execution by a factor of 1.5x-2x on top of the usual MSan slowdown, and
increases memory overhead.
The option -fsanitize-memory-track-origins=1 enables a slightly faster mode
when MSan collects only allocation points and not intermediate stores.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 121
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.8.4 Use-after-destruction detection
MSan supports use-after-destruction detection. After its destructor is invoked, an object is
considered no longer readable, and using the underlying memory will lead to error reports
in runtime.
To enable this feature at runtime, perform the following steps:
1. During compilation, specify the option -fsanitize-memory-use-after-dtor.
2. Before running the program, set the environment variable
MSAN_OPTIONS=poison_in_dtor=1.
NOTE This feature is experimental.
6.8.5 Handling external code
MSan requires all program code to be instrumented, including any libraries that the
program depends on (even libc). Failure to do this may result in the generation of false
reports.
Full MSan instrumentation is very difficult to achieve. To make it easier, the MSan
runtime library includes 70+ interceptors for the most common libc functions. This
makes it possible to run MSan-instrumented programs linked with an uninstrumented
version of libc.
6.8.6 Limitations
■MSan uses 2x more real memory than a native run, and 3x with origin tracking.
■MSan maps (but not reserves) 64 terabytes of virtual address space. This means
that tools like ulimit may not work as expected.
■Static linking is not supported.
■Older versions of MSan (LLVM 3.7 and older) didn’t work with non-position-
independent executables, and could fail on some Linux kernel versions with
disabled ASLR. For more information, see the LLVM documentation for older
versions.
NOTE For more information on MSan, see
clang.llvm.org/docs/MemorySanitizer.html.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 122
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.9 Thread Sanitizer
The LLVM compiler release includes a tool named Thread Sanitizer (TSan), which can be
used to detect data race conditions in C and C++ code.
TSan is a runtime tool which requires compile-time instrumentation of the code, and a
dedicated runtime library.
If TSan encounters a bug during the execution of a program, it displays (on stderr) an error
message.
TSan slows down program execution by a factor of 5x-15x, with a memory overhead of
about 5x-10x.
NOTE Currently TSan symbolizes its error output using an external addr2line
process (this will be fixed in the future).
6.9.1 Usage
To instrument your C/C++ code with TSan, add the following option to both the compile
and link options in LLVM:
-fsanitize=thread
The TSan runtime library must be linked to the final executable – be sure to use clang
(not ld) for the final link step.
For reasonable execution performance use -O1 or higher. To include file names and line
numbers in the generated error messages use -g.
For example:
% cat projects/compiler-rt/lib/tsan/lit_tests/tiny_race.c
#include <pthread.h>
int Global;
void *Thread1(void *x) {
Global = 42;
return x;
}
int main() {
pthread_t t;
pthread_create(&t, NULL, Thread1, NULL);
Global = 43;
pthread_join(t, NULL);
return Global;
}
$ clang -fsanitize=thread -g -O1 tiny_race.c
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 123
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
If a data race is detected, the program will print an error message to stderr:
% ./a.out
WARNING: ThreadSanitizer: data race (pid=19219)
Write of size 4 at 0x7fcf47b21bc0 by thread T1:
#0 Thread1 tiny_race.c:4 (exe+0x00000000a360)
Previous write of size 4 at 0x7fcf47b21bc0 by main thread:
#0 main tiny_race.c:10 (exe+0x00000000a3b4)
Thread T1 (running) created at:
#0 pthread_create tsan_interceptors.cc:705 (exe+0x00000000c790)
#1 main tiny_race.c:9 (exe+0x00000000a3a4)
__has_feature(thread_sanitizer)
In some cases you may need to execute different code depending on whether TSan is
enabled. The language extension __has_feature can be used for this purpose.
For example:
#if defined(__has_feature)
# if __has_feature(thread_sanitizer)
// code that builds only under ThreadSanitizer
# endif
#endif
__has_feature is a function-like macro which accepts a single identifier argument that is
the name of a feature. It evaluates to 1 if the feature is both supported by Clang and
standardized in the current language standard. If not, it evaluates to 0.
Another use of __has_feature is to check for compiler features not related to the
language standard (such as TSan itself).
__attribute__((no_sanitize_thread))
Some code should not be instrumented by TSan. To disable the instrumentation of a
particular function, use the following function attribute:
__attribute__((no_sanitize_thread))
To avoid false positives and provide meaningful stack traces, TSan may still instrument
such functions.
Blacklist
TSan supports the use of sanitizer special case lists to suppress data race reports in the
specified source files or functions (Section 6.2).
NOTE Unlike functions marked with no_sanitize_thread, blacklisted functions
are not instrumented at all. This can result in false positives due to missed
synchronization via atomic operations, and missed stack frames in reports.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 124
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.9.2 Limitations
■TSan uses more real memory than a native run. At the default settings the memory
overhead is 5x plus 1Mb per thread. Settings with 3x (less accurate analysis) and
9x (more accurate analysis) overhead are also available.
■TSan maps (but does not reserve) a lot of virtual address space. This means that
tools like ulimit may not work as usually expected.
■libc/libstdc++ static linking is not supported.
■Non-position-independent executables are not supported. Therefore:
❒When compiling without -fPIC, -fsanitize=thread causes the compiler to
act as though -fPIE had been specified.
❒When linking an executable, -fsanitize=thread causes the compiler to act
as though -pie had been specified.
NOTE For more information on TSan, see clang.llvm.org/docs/ThreadSanitizer.html.
6.10 Undefined Behavior Sanitizer
The LLVM compiler release includes a tool named Undefined Behavior Sanitizer (UBSan)
which can detect code whose behavior is undefined according to the C language
specification.
UBSan can catch a wide variety of errors, including the following:
■Using misaligned or null pointers
■Signed integer overflow
■Conversions to, from, or between floating-point types which result in overflow
UBSan is a runtime tool which requires compile-time instrumentation of the code. It
includes an optional runtime library which provides better error reporting.
If UBSan encounters code with undefined behavior during the execution of a program, it
displays (on stderr) an error message, and then responds according to the type of program
behavior:
■After a signed integer overflow, the program continues executing.
■After the invalid use of a null pointer, the program is halted.
■After the use of a misaligned pointer, a trap is generated.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 125
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.10.1 Usage
To instrument your C/C++ code with UBSan, add the following option to both the compile
and link options in LLVM:
-fsanitize=undefined
If you link the UBSan runtime library to the final executable, be sure to use clang++
(not ld) for the final link step, to ensure that the executable is linked with the proper
UBSan runtime libraries.
NOTE When using C code, you can link with clang instead of clang++.
For example:
% cat test.cc
int main(int argc, char **argv) {
int k = 0x7fffffff;
k += argc;
return 0;
}
% clang++ -fsanitize=undefined test.cc
% ./a.out
test.cc:3:5: runtime error: signed integer overflow: 2147483647 + 1
cannot be represented in type 'int'
You can configure UBSan to change the following behavior:
■Enable only a subset of the regular UBSan checks.
■Define how UBSan responds to each type of undefined program behavior (either
continue, halt, or trap).
For example:
% clang++ -fsanitize=signed-integer-overflow,null,alignment -fno-
sanitize-recover=null -fsanitize-trap=alignment
In this example, the program will continue executing after a signed integer overflow, exit
after the invalid use of a null pointer, and trap after the use of a misaligned pointer.
NOTE The trap option does not require UBSan runtime support.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 126
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.10.2 Available checks
The checks performed by UBSan are individually controlled by option values passed to
the -fsanitize=event option (Section 4.3.16).
Table 6-3 UBSan checks and option values
Option value Description
alignment Use of a misaligned pointer or creation of a misaligned reference.
bool Load of a boolean value that is neither TRUE nor FALSE.
bounds Out-of-bounds array indexing, in cases where the array bound can be statically
determined.
enum Load of a value of an enumerated type which is not in the range of representable
values for that enumerated type.
float-cast-overflow Conversion to, from, or between floating-point types which would overflow the
destination.
float-divide-by-zero Floating point division by zero.
function Indirect call of a function through a function pointer of the wrong type.
integer-divide-by-zero Integer division by zero.
nonnull-attribute Passing null pointer as a function parameter which is declared to never be null.
null Use of a null pointer or creation of a null reference.
object-size Attempt to use bytes which the optimizer can determine are not part of the object
being accessed.
return In C++, reaching the end of a value-returning function without returning a value.
returns-nonnull-attribute Returning null pointer from a function which is declared to never return null.
shift Shift operators where the amount shifted is greater or equal to the promoted bit-
width of the left-hand side or less than zero, or where the left-hand side is negative.
For a signed left shift, also checks for signed overflow in C, and for unsigned
overflow in C++.
shift-base Check only left-hand side of a shift operation.
shift-exponent Check only right-hand side of a shift operation.
signed-integer-overflow Signed integer overflow, including all the checks added by -ftrapv, and checking for
overflow in signed division (INT_MIN / -1).
unreachable If control flow reaches __builtin_unreachable.
unsigned-integer-overflow Unsigned integer overflows.
unreachable If control flow reaches __builtin_unreachable.
unsigned-integer-overflow Unsigned integer overflows.
vla-bound A variable-length array whose bound does not evaluate to a positive value.
vptr Use of an object whose vptr indicates that it is of the wrong dynamic type, or that
its lifetime has not begun or has ended. Incompatible with -fno-rtti. Link must
be performed by clang++, not clang, to make sure C++-specific parts of the
runtime library and C++ standard libraries are present.
undefined All of the checks listed above other than unsigned-integer-overflow.
integer Checks for undefined or suspicious integer behavior (e.g. unsigned integer
overflow).
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 127
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.10.3 Stack traces and report symbolization
To make UBSan print a symbolized stack trace for each error report, use the following
procedure:
1. Compile with -g and -fno-omit-frame-pointer to get the proper debug
information in your binary.
2. Run your program with the environment variable
UBSAN_OPTIONS=print_stacktrace=1.
3. Ensure that the llvm-symbolizer binary is in PATH.
6.10.4 Issue suppression
UBSan generally does not produce false positives, so if you see one, look again. Most
likely it is a true positive.
__attribute__((no_sanitize("undefined")))
Some code should not be instrumented by UBSan. To disable the instrumentation of a
particular function, use the following function attribute:
__attribute__((no_sanitize_("undefined")))
All values of -fsanitize=event can be used in this attribute. For example, if your
function deliberately contains possible signed integer overflow, you can use the following:
__attribute__((no_sanitize("signed-integer-overflow"))).
Blacklist
UBSan supports the use of sanitizer special case lists to suppress error reports in the
specified source files or functions (Section 6.2).
Runtime suppressions
Sometimes you can suppress UBSan error reports for specific files, functions, or libraries
without recompiling the code. You need to pass a path to suppression file in a
UBSAN_OPTIONS environment variable.
UBSAN_OPTIONS=suppressions=MyUBSan.supp
You need to specify a check (Section 6.5.3) you are suppressing, along with the bug
location. For example:
signed-integer-overflow:file-with-known-overflow.cpp
alignment:function_doing_unaligned_access
vptr:shared_object_with_vptr_failures.so
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 128
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
Several limitations apply:
■Sometimes your binary must have enough debug information or a symbol table,
so that the runtime could figure out source file or function name to match against
the suppression.
■It is only possible to suppress recoverable checks. For the example above, you can
additionally pass -fsanitize-recover=signed-integer-
overflow,alignment,vptr, although most of the UBSan checks are
recoverable by default.
■Check groups (such as undefined) cannot be used in suppressions files. Only
fine-grained checks are supported.
6.10.5 Notes
In the C language specification, undefined behavior is the result of performing certain
erroneous operations that are not flagged with an error. Note that a single instance of
undefined behavior causes all of a program’s output to be considered unpredictable and
therefore useless.
NOTE For more information on undefined behavior see,
blog.llvm.org/2011/05/what-every-c-programmer-should-know.html.
NOTE For more information on UBSan see,
clang.llvm.org/docs/UndefinedBehaviorSanitizer.html.
6.11 LLVM Symbolizer
The LLVM compiler release includes a tool named LLVM Symbolizer, which can be used
to convert program addresses into source code locations.
The Symbolizer is a command-line tool – it reads object file names and addresses from the
standard input, and writes the corresponding source code locations to the standard output.
If an object file name is directly specified as a command-line argument, the Symbolizer
treats it as the name of the input object file, and reads only addresses from the standard
input.
NOTE To perform its conversion, the Symbolizer uses the symbol tables and debug
information sections that are stored in the object files.
To start the Symbolizer from a command line, type:
llvm-symbolizer options...
Command options are used to control the symbolizer (Section 6.11.2).
NOTE The Symbolizer normally returns 0 as a program return code. Any other code
values indicate an internal program error.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 129
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
NOTE The Symbolizer is used with ASan (Section 6.5), MSan (Section 6.8), and
UBSan (Section 6.10).
6.11.1 Usage
$ cat addr.txt
a.out 0x4004f4
/tmp/b.out 0x400528
/tmp/c.so 0x710
/tmp/mach_universal_binary:i386 0x1f84
/tmp/mach_universal_binary:x86_64 0x100000f24
$ llvm-symbolizer < addr.txt
main
/tmp/a.cc:4
f(int, int)
/tmp/b.cc:11
h_inlined_into_g
/tmp/header.h:2
g_inlined_into_f
/tmp/header.h:7
f_inlined_into_main
/tmp/source.cc:3
main
/tmp/source.cc:8
_main
/tmp/source_i386.cc:8
_main
/tmp/source_x86_64.cc:8
$ cat addr2.txt
0x4004f4
0x401000
$ llvm-symbolizer -obj=a.out < addr2.txt
main
/tmp/a.cc:4
foo(int)
/tmp/a.cc:12
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 130
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.11.2 Options
Symbolizer is controlled by command-line options.
6.12 Control flow integrity
Control flow integrity (CFI) is a compiler feature which is designed to abort the program
upon detecting certain forms of undefined behavior that can potentially allow attackers to
subvert the program’s control flow.
When CFI is enabled, the program code is instrumented with fast checks for indirect calls,
and hooks for a function to report violations of forward-edge control-flow integrity.
CFI is controlled with the compile options -ffcfi and -fno-fcfi. For example:
clang -S -emit-llvm -ffcfi -o foo.ll foo.c
Table 6-4 Options supported in the Symbolizer
Option Description
-obj Path to object file to be symbolized.
-functions=(none|short|linkage) Specify how function names are printed.
none – Omit function name
short – Print short function name
linkage – Print full linkage name (Default)
-use-symbol-table Favor function names stored in the symbol table over
function names in debug information sections.
The default setting is enabled.
-demangle Print demangled function names.
The default setting is enabled.
-inlining If a source code location is in an inlined function, prints
all the inlined frames.
The default setting is enabled.
-default-arch arch_name If a binary contains object files for multiple architectures
(e.g., it is a Mach-O universal binary), symbolize the
object file for the specified architecture.
The architecture name is specified as a string value.
The default setting is an empty string.
The architecture can alternatively be specified by
passing the string “binary_name:arch_name” as
part of the input (Section 6.11.1).
NOTE If an architecture is not specified in either way,
addresses will not be symbolized.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 131
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.12.1 Configuration
CFI must be configured to handle control-flow violations; otherwise, the violations are
ignored by default.
It can also be configured to generate different types of code instrumentation. Different
types of programs may execute more efficiently with different types of instrumentation.
CFI configuration is performed with the LLVM static compiler tool.
NOTE The static compiler is different from the normal LLVM compiler – it is
invoked by the latter to translate LLVM bitcode into target native code.
To start the static compiler from a command line, type:
llc options...
Command options are used to control the static compiler (Section 6.12.3).
6.12.2 Usage
The following example shows how to use CFI.
1. Compile program files, enabling CFI and generating LLVM bitcode files:
clang -S -emit-llvm -ffcfi -o foo.ll foo.c
clang -S -emit-llvm -ffcfi -o bar.ll bar.c
2. Link bitcode files:
llvm-link -o prog.ll foo.ll bar.ll
3. Static-compile bitcode files, configuring CFI and generating relocatable object
file:
llc -cfi-enforcing -cfi-type=sub -jump-table-type=simplified
-filetype=obj -o prog.o prog.ll
4. Link relocatable object file into executable binary:
clang -o prog prog.o
5. Run CFI-instrumented executable binary:
./prog
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 132
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.12.3 Options
The LLVM static compiler is controlled by command-line options.
6.12.4 Handler functions
If a user-defined handler function is specified (with option -cfi-func-name), the
function must accept two char* parameters.
The first parameter is a C string which will contain the name of the function where the
control-flow integrity violation occurred.
The second parameter will contain the pointer that violated control-flow integrity.
The handler function must be defined as a linker symbol in order to be specified using
-cfi-func-name.
Table 6-5 CFI options supported in the static compiler
Option Description
-cfi-enforcing Enforce control-flow integrity.
By default, integrity violations invoke a handler function
specified with -cfi-func-name.
If no function is specified the violation is ignored.
-cfi-func-name=name Specify the handler function that is called when a CFI
violation occurs.
NOTE This option is superseded by -cfi-enforcing.
-cfi-type=(sub|ror|add) Specify the type of CFI checks to be performed.
sub
Subtract pointer from table base, then mask (default).
ror
Use rotate to check offset from table base.
add
Mask out high bits and add to aligned base.
-jump-table-type=
(single|arity|simplified|full)
Specify the type of jump table to use for CFI
instrumentation.
single
Create a single table for all functions (default).
arity
Group functions into tables by the number of
arguments they receive.
simplified
Create one table per simplified function type.
full
Create one table per function type.
NOTE We recommend simplified because it offers the
best balance between security and robustness.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 133
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.12.5 Notes
The current CFI implementation does not imply –fsanitize or -flto. Therefore you
must compile each source file to bitcode using -ffcfi, and then compile and link the
bitcode files into native code.
The LLVM Snapdragon compiler includes support for a particular CFI scheme known as
forward-edge control flow integrity. It is supported on ARMv7 and ARMv8 (AArch32 and
AArch64) targets. For more information on this scheme, see
www.pcc.me.uk/~peter/acad/usenix14.pdf.
For more information on CFI, see clang.llvm.org/docs/ControlFlowIntegrity.html.
For more information on the LLVM static compiler, see
llvm.org/docs/CommandGuide/llc.html.
6.13 Static program analysis
The LLVM compiler release includes the following tools for performing static analysis on
a program:
■Static analyzer
■Postprocessor
■Scan-build
The static analyzer is a source code analysis tool which finds potential bugs in C and C++
programs. It can be used to analyze individual files or entire programs.
The postprocessor creates a summary of the reports that are generated by performing static
analysis while compiling a program.
Scan-build is an additional tool for compiling and statically analyzing a program. It can be
used with a Make-based build system.
6.13.1 Static analyzer
The static analyzer is a source code analysis tool which is integrated into the LLVM
compiler. It analyzes a program for various types of potential bugs – including security
threats, memory corruption, and garbage values – and generates a diagnostic report
describing the potential bugs it detected.
The static analyzer has the following features:
■It supports more than 100 distinct checkers which are organized into the
categories alpha, core, cplusplus, debug, and security
■Checkers can be selectively enabled or disabled from the command line
■Disabling a checker category disables all the checkers in that category
■Selected parts of the program code can be excluded from checking
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 134
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.13.1.1 Analyzing programs
To use the static analyzer on an entire program, invoke the LLVM compiler on the
program using the option --compile-and-analyze (Section 4.3.25). For example:
clang --compile-and-analyze dir input_files...
--compile-and-analyze <dir> specifies the directory where the static analyzer report
will be stored. (If the directory does not exist, the compiler automatically creates it.). The
report is automatically generated in HTML format. The files are named report*.html.
input_files specifies the program source files.
We recommend statically analyzing an entire program at once (as opposed to selected
source files) for the following reasons:
■The generated analysis report files are all stored in a single location.
■The command option can be passed from the build system, which helps perform
the static analysis and compilation every time the program is built.
■Because build systems are good at tracking files that have changed, and compiling
only the minimal set of required files, the overall turnaround time for static
analysis is relatively small, making it reasonable to run the static analyzer with
every build.
NOTE When using a build system, specifying the same directory name throughout
the build will generate all the HTML report files in the specified directory.
The filenames generated for a report are based on hashing functions, so the
report files will not be overwritten.
6.13.1.2 Analyzing programs using default flags
To use the static analyzer on specific program source files, invoke the LLVM compiler on
the files using the static analyzer options (Section 4.3.25). For example:
clang --analyze -Xclang --analyzer-output -Xclang html
-o dir files
--analyze causes the compiler to generate a static analyzer report instead of a program
object file.
--analyzer-output html specifies that the report is generated in HTML format.
NOTE -Xclang must be used (twice) to pass the --analyzer-output html option
to the compiler. For details, see Section 4.3.2.
-o specifies the directory where the report files will be stored. (If the directory does not
exist, the compiler automatically creates it.). The files are named report*.html.
files specifies the program source files to be analyzed.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 135
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
Example of a diagnostic report entry:
// @file: test.cpp
int main() {
int* p = new int();
return* p;
}
warning: Potential leak of memory pointed to by ‘p’
NOTE Each potential bug flagged in a report includes the path (i.e., control and data)
required for locating the bug in the program.
NOTE Static analyzer warnings can be converted to errors with the
--analyzer-Werror option.
6.13.1.3 Managing checkers
The static analyzer supports more than 100 individual checkers which can analyze
programs for various types of potential bugs. By default, only a subset of these checkers is
enabled, to minimize both the compile time and the generation of false positives.
To enable additional checkers, invoke the static analyzer using the option -analyzer-
checker (Section 4.3.25). For example:
clang++ --compile-and-analyze <dir> -Xclang -analyzer-
checker=NewDelete test.cpp
-analyzer-checker specifies the checker to be enabled (in this case, NewDelete).
To disable individual checkers, invoke the static analyzer using the option -analyzer-
disable-checker (Section 4.3.25). For example:
clang++ --compile-and-analyze <dir> -Xclang -analyzer-disable-
checker=deadcode.deadstore test.cpp
NOTE -Xclang must be used to pass the -analyzer-output, -analyzer-
checker, and -analyzer-disable-checker options to the compiler. For
details, see Section 4.3.2.
To list all the supported checkers, use the following command:
clang -cc1 -analyzer-checker-help
To list only the default checkers, use the -v option while running the analyzer on a test
file. For example: clang++ -v --compile-and-analyze --analyzer-perf
test.cpp (Section 4.3.2).
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 136
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
Packages
The individual checkers are organized into the following categories:
■alpha
■core
■cplusplus (only for analyzing C++ programs)
■debug
■security
■unix
■optin
Each category (or package) is defined to include a number of checkers. For example, the
checker NullDereference is a core checker, while NewDelete is a cplusplus checker.
Organizing checkers into packages (and sub-packages) makes it easier to enable/disable
specific sets of checkers.
Example of using the static analyzer with all alpha checkers enabled:
clang --compile-and-analyze <dir> -Xclang -analyzer-checker=alpha
test.cpp
Lists
To enable or disable multiple individual checkers, multiple checker and package names
can be specified as a single comma-separated list. For example:
clang --compile-and-analyze <dir> -Xclang -analyzer-
checker=alpha,core test.cpp
6.13.1.4 Handling false positives
While checking a program for potential bugs, the static analyzer may report false
positives, which are sections of code that the analyzer incorrectly flags as bugs.
To minimize false positives, the static analyzer, by default, enables a set of checkers that
has been tested to identify a high percentage of actual program bugs (Section 6.13.1.3).
And if necessary, additional checkers can be individually enabled.
However, despite the overall accuracy of the checkers, several cases still exist where false
positives can be generated. For instance, if you enable the checker used to analyze dead
code, the static analyzer will flag as a false positive any code that has been conditionally
enabled for debugging purposes.
To handle such cases, the static analyzer supports several features for handling false
positives:
■Special comment
■Preprocessor symbol
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 137
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
■Function attribute
■Blacklist file
NOTE We do not recommend using comments or symbols to handle false positives
because they make the code inaccessible to the analyzer. Instead, report any
false positives so the existing checkers can be improved to eliminate them.
For more information on false positives, see clang-analyzer.llvm.org/faq.html.
BlackList file
The blacklist file consists of row-wise indications of warnings that must silenced. It
uniquely identifies each warning by filename, function name, and bug description. Place
this file in a network location that is accessible to all developer machines using the
analyzer.
During postprocessing, we identify the blacklist file through the flag --blacklist-file
<file>. The post-process script will not report the bugs marked in this file. Besides
silencing warnings across developer machines, this mechanism also allows us to silence
warnings across build variants.
A blacklist file contains row-by-row warnings in the following format:
<filename.cpp> <function identifier/Global> <full warning
description>
For example:
test.cpp foo Address of stack memory associated with local variable
buff returned to caller [core.StackAddressEscape]
Special comment
Individual lines of code can be excluded from checking by adding the following comment
to the line:
// clang_sa_ignore [checker] [user_comment_text]
checker specifies a checker, package, or list (Section 6.13.1.3) that is excluded from
being applied to the line of code. It must be enclosed in square brackets. For example:
g_ptr = new int(0); // clang_sa_ignore [deadcode.DeadStores]
g_ptr = new int(0); // clang_sa_ignore [alpha] my comment text
g_ptr = new int(0); // clang_sa_ignore [alpha,deadcode.DeadStores]
Preprocessor symbol
One or more lines of code can be conditionally excluded from all checking by using the
preprocessor symbol __clang_analyzer__, which is automatically defined by the static
analyzer. For example:
#ifndef __clang_analyzer__
// Code excluded from checking
#endif
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 138
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
When using the preprocessor symbol with the static analyzer, the code must remain
compilable, even though it does not need to be linkable or executable. For example, to
exclude the body of a function from being analyzed, use the following conditional code:
#ifdef __clang_analyzer__
void noisyFunction(); // this version is for analysis only
#else // __clang_analyzer__
static void noisyFunction() {
// function body is generating too many false positives
}
#endif // __clang_analyzer__
Function attribute
A common source of false positives is non-returning functions such as assert functions.
Although the static analyzer is aware of the standard library non-returning functions, if
(for example) a program has its own implementation of asserts, it helps to mark them with
the following function attribute:
__attribute__((__noreturn__))
Using this attribute greatly improves the static analysis diagnostics and lessens the number
of false positives. For example:
void my_abort(const char* msg) __attribute__((__noreturn__)) {
printf("%s", msg);
exit(1);
}
6.13.1.5 Whitelisting directories
Often, unwieldy build systems make it impossible to turn on the static analyzer for only
some subdirectories. For instance, assume we have the following hierarchy:
ANDROID
Open_source Qcomm_hardware_code Qcomm_software_code
Assume we want to see results for only the Qcomm_code directories and not the
Open_source directory. The build system employed here only allows cflags to be set at a
global level. In this case, we create a whitelist file containing row-wise entries of the
folders to be scanned. For example:
ANDROID/Qcomm_hardware_code
ANDROID/Qcomm_software_code
The post-process script must be notified of the whitelist file through the flag,
--whitelist-file <whitelist text file>. The script then identifies the row-wise
entries and checks them against any static analysis warnings found. If none of the entries
are a substring of the file location of a particular bug, that bug is silenced. Thus, having
only Qcomm_hardware_code and Qcomm_software_code in the whitelist file will suffice
because they would both be part of the location of the warnings we are interested in.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 139
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
6.13.1.6 Treating warnings as errors
Static analysis warnings can be treated as errors by appending the --analyzer-Werror
flag to the build flags. For example:
clang --compile-and-analyze <dir> -Xclang --analyzer-Werror test.c
6.13.1.7 Checker categorization by priority
Because checkers fall under two major priority categories (high and medium), the
following flags are available in addition to the regular --compile-and-analyze flag:
--compile-and-analyze-high
The high flag allows only a small subset of checkers to be turned on. These
checkers are security critical and have an extremely low false positive rate. Teams
adopting this tool should start with the high flag.
--compile-and-analyze-medium
The medium flag is slightly more permissive than the high flag. The medium flag
contains a few more checkers that are deemed security critical but have a slightly
higher false positive rate.
6.13.1.8 Performance mode
The static analyzer can be run in Performance mode. This mode prevents the creation of
all the raw HTML files, and instead it displays a summary of the warnings in the console
output.
To enable this mode, append the --analyzer-perf flag to the --compile-and-
analyze flag in place of the <dir> option. For example:
clang --compile-and-analyze --analyzer-perf test.c
clang --compile-and-analyze-high --analyzer-perf test.c
6.13.2 Postprocessor
The postprocessor is a report generator which is implemented as a stand-alone script. This
post-process script creates a summary of the report that is generated by using the option
-compile-and-analyze (Section 6.13.1).
The postprocessor is invoked with the following command:
post-process --report-dir dir
The postprocessor reads all the files from the directory specified by the option --report-
dir, and writes in the same directory a summary report file named index.html.
The report title can be specified with the option, --html-title.
For more information on the postprocessor, enter the command, post-process --help.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 140
Qualcomm Snapdragon LLVM ARM Compiler for Android Compiler Security Tools
NOTE The post-process script is stored in the directory $INSTALL_PREFIX/bin.
NOTE In some cases the static analyzer may generate multiple report files for the
same bug. The postprocessor cleans up after multiple report files. For this
reason it should be run regularly to keep the report directory clean.
6.13.3 Scan-build
Scan-build is a stand-alone tool for compiling and statically analyzing a program. It can
be used with a Make-based build system (instead, however, we recommend using the
LLVM static analyzer whenever possible; see Section 6.13.1).
Scan-build enables a user to run the static analyzer as part of regular build process. Here
are two examples of invoking scan-build:
scan-build clang++ -c test.cpp
scan-build -v -k -o out-dir -disable-checker deadcode
-use-c++=clang++ --use-c=clang make -j8
Scan-build works well with a Make-based build system.
For more information, enter the command, scan-build --help.
NOTE The Scan-build script is stored in the directory $INSTALL_PREFIX/bin.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 141
7Porting Code from GCC
This chapter describes issues commonly encountered while porting to LLVM an
application that was previously built only with GCC.
NOTE For more information on GCC compatibility see Chapter 9.
7.1 Command options
LLVM supports many but not all of the GCC command options. Unsupported options are
either ignored or flagged with a warning or error message: most receive warning
messages.
For more information, see Section 4.3.5.
7.2 Errors and warnings
LLVM enforces strict conformance to the C99 language standard. As a result, you may
encounter new errors and warnings when compiling GCC code.
To handle these messages when porting to LLVM, consider the following steps:
1. Remove the command option -Werror if it is being used (because it converts all
warnings into errors).
2. Update the code to eliminate the remaining errors and warnings.
7.3 Function declarations
LLVM enforces the C99 rules for function declarations. In particular:
■A function declared with a non-void return type must return a value of that type.
■A function referenced before being declared is assumed to return a value of type
int. If the function is subsequently declared to return some other type, it is
flagged as an error.
■A function declaration with the inline attribute assumes the existence of a
separate definition for the function, which does not include the inline attribute.
If no such definition appears in the program, a link-time error will occur.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 142
Qualcomm Snapdragon LLVM ARM Compiler for Android Porting Code from GCC
To satisfy these restrictions when porting to LLVM, consider the following steps:
1. Use option -Wreturn-type to generate a warning whenever a function definition
does not return a value of its declared type.
2. Use -Wimplicit-function-declaration to generate a warning whenever a
function is used before being declared.
3. Update the code to eliminate the remaining errors and warnings.
For more information on inlining, see http://clang.llvm.org/compatibility.html#inline.
For a discussion of different inlining approaches, see
http://www.greenend.org.uk/rjk/tech/inline.html.
7.4 Casting to incompatible types
LLVM enforces the C99 rules for strict aliasing.
In the C language, two pointers that reference the same memory location are said to alias
one another. Because any store through an aliased pointer can potentially modify the data
referenced by one of its pointer aliases, pointer aliases can limit the compiler’s ability to
generate optimized code.
In strict aliasing, pointers to different types are prevented from being aliased with one
another. The compiler flags pointer aliases with an error message.
Strict aliasing has a few exceptions:
■Any pointer type can be cast to char* or void*.
■A char* or void* can be cast to any pointer type.
■Pointers to types that differ only by signedness (e.g., int versus unsigned int)
can be aliased.
To satisfy strict aliasing when porting to LLVM, consider the following steps:
1. Use option -Wcast-align to generate a warning whenever a pointer alias is
detected.
2. Update the code to eliminate the resulting warnings.
NOTE Dereferencing a pointer that is cast from a less strictly aligned type has
undefined behavior.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 143
Qualcomm Snapdragon LLVM ARM Compiler for Android Porting Code from GCC
7.5 aligned attribute
LLVM does not allow the aligned attribute to appear inside the __alignof__ operator.
To satisfy this restriction when porting to LLVM, create a typedef with the aligned
attribute. For example:
typedef unsigned char u8;
#ifdef __llvm__
typedef u8 __attribute((aligned)) aligned_u8;
#endif
unsigned int foo()
{
#ifndef __llvm__
return __alignof__(u8 __attribute__ ((aligned)));
#else
return __alignof__(aligned_u8);
#endif
}
7.6 Reserved registers
LLVM does not support the GCC extension to place global variables in specific registers.
To satisfy this restriction when porting to LLVM, use the equivalent LLVM intrinsics
whenever possible. For example:
#ifndef __llvm__
register unsigned long current_frame_pointer asm("r11");
#endif
…
#ifndef __llvm__
fp = current_frame_pointer;
#else
fp = (unsigned long)__builtin_frame_address(0);
#endif
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 144
Qualcomm Snapdragon LLVM ARM Compiler for Android Porting Code from GCC
7.7 Inline versus extern inline
LLVM conforms to the C99 language standard, which defines different semantics for the
inline keyword than GCC. For example, consider the following code:
inline int add(int i, int j) { return i + j; }
int main() {
int i = add(4, 5);
return i;
}
In C99 the function attribute inline specifies that a function's definition is provided only
for inlining, and that another definition (without the inline attribute) is specified
elsewhere in the program.
This implies that the above example is incomplete, because if add() is not inlined (for
example, when compiling without optimization), then main() will include an unresolved
reference to that other function definition. This will result in the following link-time error:
Undefined symbols:
"_add", referenced from: _main in cc-y1jXIr.o
By contrast, GCC's default behavior follows the GNU89 dialect, which is based on the
C89 language standard. C89 does not support the inline keyword; however, GCC
recognizes it as a language extension, and treats it as a hint to the optimizer.
There are several ways to fix this problem:
■Change add() to a static inline function. This is usually the right solution if only
one translation unit needs to use the function. Static inline functions are always
resolved within the translation unit, so it will not be necessary to add a non-inline
definition of the function elsewhere in the program.
■Remove the inline keyword from this definition of add(). The inline
keyword is not required for a function to be inlined, nor does it guarantee that it
will be. Some compilers ignore it completely. LLVM treats it as a mild suggestion
from the programmer.
■Provide an external (non-inline) definition of add() somewhere else in the
program. Note that the two definitions must be equivalent.
■Compile with the GNU89 dialect by adding -std=gnu89 to the set of LLVM
options. We do not recommend this approach.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 145
8Coding Practices
This chapter describes recommended coding practices for users of the LLVM compilers.
These practices typically result in the compiler generating more optimized code.
8.1 Use int types for loop counters
We strongly recomment using an int type for loop counters, which results in the compiler
generating more efficient code. If the code uses a non-int type, the compiler will have to
insert zero and sign-extensions to abide by C rules. For example, we do not recommend
the following code:
extern int A[30], B[30];
for (short int ctr = 0; ctr < 30; ++ctr) {
A[ctr] = B[ctr] + 55;
}
Use this code instead:
extern int A[30], B[30];
for (int ctr = 0; ctr < 30; ++ctr) {
A[ctr] = B[ctr] + 55;
}
8.2 Mark function arguments as restrict (if possible)
LLVM supports the restrict keyword for function arguments. Using restrict on a
pointer passed in as a function argument indicates to the compiler that the pointer will be
used exclusively to dereference the address it points at. This allows the compiler to enable
more aggressive optimizations on memory accesses.
NOTE When using the restrict keyword, you must ensure that the restrict
condition holds for all calls made to that function. If an argument is
erroneously marked as restrict, the compiler may generate incorrect code.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 146
Qualcomm Snapdragon LLVM ARM Compiler for Android Coding Practices
8.3 Do not pass or return structs by value
We strongly recommend that structs are passed to (and returned from) functions by
reference and not by value.
If a struct is passed to a function by value, the compiler must generate code which makes a
copy of the struct during application runtime. This can be extremely inefficient, and will
reduce the performance of the compiled code. For this reason, we recommend that structs
be passed by pointer.
For instance, the following code is inefficient:
struct S {
int z;
int y[50];
char *x;
long int w[40];
};
int bar(struct S arg1) {
…
}
int baz() {
struct S s;
…
bar(s);
}
While this code is much more efficient:
struct S {
int z;
int y[50];
char *x;
long int w[40];
};
int bar(struct *S arg1) {
/* Access z here using ‘arg1->z’ (instead of ‘arg1.z’) */
…
}
int baz() {
struct S s;
…
bar(&s);
}
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 147
Qualcomm Snapdragon LLVM ARM Compiler for Android Coding Practices
Alternatively, in C++, the efficient code can be simplified by using reference parameters:
struct S {
int z;
int y[50];
char *x;
long int w[40];
};
int bar(struct &S arg1) {
…
}
int baz() {
struct S;
… populate elements of S …
bar(S);
}
8.4 Avoid using inline assembly
Using inline assembly snippets in C files is strongly discouraged for two reasons:
■Inline assembly snippets are extremely difficult to write correctly. For instance,
omitting the input, output, or clobber parameters frequently leads to incorrect
code. The resulting failure can be extremely difficult to debug.
■Inline assembly is not portable across processor versions. If you need to emit a
specific assembly instruction, we recommend using a compiler intrinsic instead of
inline assembly.
Intrinsics are easy to insert in a C file, and are portable across processor versions. If
intrinsics are insufficient, then you should add a new function written in assembly which
contains the desired functionality. The assembly function should be called from C code.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 148
9Language Compatibility
LLVM strives to both conform to current language standards, and to implement many
widely-used extensions available in other compilers, so that most correct code will just
work when compiled with LLVM. However, LLVM is more strict than other popular
compilers, and may reject incorrect code that other compilers allow.
This chapter describes common compatibility and portability issues with LLVM to help
you understand and fix the problem in your code when LLVM emits an error message.
9.1 C compatibility
This section describes common compatibility and portability issues with LLVM C.
9.1.1 Differences between various standard modes
LLVM supports the -std option, which changes what language mode LLVM uses. The
supported modes for C are c89, gnu89, c94, c99, gnu99, c11, and various aliases for those
modes. If no -std option is specified, LLVM defaults to gnu99 mode.
The c* and gnu* modes have the following differences:
■c* modes define __STRICT_ANSI__.
■Target-specific defines not prefixed by underscores (such as “linux”) are defined
in gnu* modes.
■Trigraphs default to being off in gnu* modes; they can be enabled by the
-trigraphs option.
■The parser recognizes asm and typeof as keywords in gnu* modes; the variants
__asm__ and __typeof__ are recognized in all modes.
■Arrays that are VLAs according to the standard, but which can be constant folded
by the compiler front end, are treated as fixed size arrays. This occurs for things
such as “int X[(1, 2)];”, which is technically a VLA. c* modes are strictly
compliant and treat these as VLAs.
■The Apple blocks extension is recognized by default in gnu* modes on some
platforms. It can be enabled in any mode with the -fblocks option.
The *99 and *11 modes have the following differences:
■Warnings for use of C11 features are disabled.
■__STDC_VERSION__ is defined to 201112L rather than 199901L.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 149
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
The *89 and *99 modes have the following differences:
■The *99 modes default to implementing inline as specified in C99, while the
*89 modes implement the GNU version. This can be overridden for individual
functions with the __gnu_inline__ attribute.
■Digraphs are not recognized in c89 mode.
■The scope of names defined in a for, if, switch, while, or do statement is
different. (example: "if ((struct x {int x;}*)0) {}".)
■__STDC_VERSION__ is not defined in *89 modes.
■inline is not recognized as a keyword in c89 mode.
■restrict is not recognized as a keyword in *89 modes.
■Commas are allowed in integer constant expressions in *99 modes.
■Arrays which are not lvalues are not implicitly promoted to pointers in *89
modes.
■Some warnings are different.
c94 mode is identical to c89 mode except that digraphs are enabled in c94 mode.
9.1.2 GCC extensions not implemented yet
LLVM tries to be compatible with GCC as much as possible, but the following GCC
extensions are not yet implemented in LLVM:
■#pragma weak – This is likely to be implemented at some point in the future, at
least partially.
■Decimal floating (_Decimal32, etc.) and fixed-point types (_Fract, etc.) – No
one has expressed interest in these yet, so it is currently unclear when they will be
implemented.
■Nested functions – This is a complex feature which is infrequently used, so it is
unlikely to be implemented anytime soon.
■Global register variables – This is unlikely to be implemented soon because it
requires additional LLVM back-end support.
■Static initialization of flexible array members – This appears to be a rarely used
extension, but could be implemented pending user demand.
■__builtin_va_arg_pack and __builtin_va_arg_pack_len – This is used
rarely, but in some potentially interesting places such as the glibc headers, so it
may be implemented pending user demand. Note that because LLVM pretends to
be like GCC 4.2, and this extension was introduced in 4.3, the glibc headers will
currently not try to use this extension with LLVM.
■Forward-declaring function parameters – This has not showed up in any
real-world code yet, though, so it might never be implemented.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 150
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
9.1.3 Intentionally unsupported GCC extensions
LLVM intentionally does not implement the following GCC extensions:
■Variable-length arrays in structures – This is not implemented for several
reasons: it is tricky to implement, the extension is completely undocumented, and
the extension appears to be rarely used. Note that LLVM does support flexible
array members (arrays with a zero or unspecified size at the end of a structure).
■An equivalent to GCC's "fold" – This implies that LLVM does not accept some
constructs GCC might accept in contexts where a constant expression is required,
such as "x-x" where x is a variable.
■__builtin_apply and related attributes – This extension is extremely obscure
and difficult to implement reliably.
9.1.4 Lvalue casts
Old versions of GCC permit casting the left-hand side of an assignment to a different type.
LLVM produces an error for code like this:
lvalue.c:2:3: error: assignment to cast is illegal, lvalue casts
are not supported
(int*)addr = val;
^~~~~~~~~~ ~
To fix this problem, move the cast to the right-hand side. For example:
addr = (float *)val;
9.1.5 Jumps to within __block variable scope
LLVM disallows jumps into the scope of a __block variable. Variables marked with
__block require special runtime initialization. A jump into the scope of a __block
variable bypasses this initialization, leaving the variable's metadata in an invalid state.
Consider the following code fragment:
int fetch_object_state(struct MyObject *c) {
if (!c->active) goto error;
__block int result;
run_specially_somehow(^{ result = c->state; });
return result;
error:
fprintf(stderr, "error while fetching object state");
return -1;
}
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 151
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
GCC accepts this code, but produces code that will usually crash when the result goes out
of scope if the jump is taken. (It's possible for this bug to go undetected, because it often
will not crash if the stack is fresh – i.e., is still zeroed.) Therefore, LLVM rejects this code
with a hard error:
t.c:3:5: error: goto into protected scope
goto error;
^
t.c:5:15: note: jump bypasses setup of __block variable
__block int result;
^
The fix is to rewrite the code to not require jumping into a __block variable's scope; for
example, by limiting that scope:
{
__block int result;
run_specially_somehow(^{ result = c->state; });
return result;
}
9.1.6 Non-initialization of __block variables
In the following example code, the variable x is used before it is defined:
int f0() {
__block int x;
return ^(){ return x; }();
}
By an accident of implementation, GCC and llvm-gcc unintentionally always zero any
initialized __block variables. However, any program that depends on this behavior is
relying on unspecified compiler behavior. Programs must explicitly initialize all local
block variables before they are used, as with other local variables.
LLVM does not zero-initialize local block variables – thus any programs that rely on such
behavior will most likely break when built with LLVM.
9.1.7 Inline assembly
In general, LLVM is highly compatible with the GCC inline assembly extensions,
allowing the same set of constraints, modifiers and operands as GCC inline assembly.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 152
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
9.2 C++ compatibility
This section describes common compatibility and portability issues with LLVM C++.
The types in C++ code compiled with -std=c++11 are not interoperable with the types in
C++ code compiled with -std=c++03, or with code compiled with no “-std=”
specification. For example, the std::string from a C++03 compilation is unrelated to a
std::string from a C++11 compilation, and the two std::string types are not easily
convertible to each other.
9.2.1 Deleted special member functions
In C++11, the explicit declaration of a move constructor, or a move assignment operator
within a class, deletes the implicit declaration of the copy constructor and copy
assignment operator. This change occurred fairly late in the C++11 standardization
process, so early implementations of C++11 (including LLVM before 3.0, GCC before
4.7, and Visual Studio 2010) do not implement this rule, leading them to accept the
following ill-formed code:
struct X {
X(X&&); // deletes implicit copy constructor:
// X(const X&) = delete;
};
void f(X x);
void g(X x) {
f(x); // error: X has a deleted copy constructor
}
This affects some early C++11 code, including Boost's popular shared_ptr, up to version
1.47.0. The fix for Boost's shared_ptr is described here:
svn.boost.org/trac/boost/changeset/73202
9.2.2 Variable-length arrays
GCC and C99 allow an array’s size to be determined at run time. This extension is not
permitted in standard C++. However, LLVM supports such variable length arrays in very
limited circumstances for compatibility with GNU C and C99 programs:
■The element type of a variable length array must be a plain old data (POD) type,
which means that it cannot have any user-declared constructors or destructors, any
base classes, or any members of non-POD type. All C types are POD types.
■Variable length arrays cannot be used as the type of a non-type template
parameter.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 153
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
If your code uses variable length arrays in a manner that LLVM does not support, several
ways are available to fix your code:
■Replace the variable length array with a fixed-size array if you can determine a
reasonable upper bound at compile time; sometimes this is as simple as changing
int size = ...; to const int size = ...; (if the initializer is a
compile-time constant).
■Use std::vector or some other suitable container type.
■Allocate the array on the heap instead using new Type[] – just remember to
delete[] it.
9.2.3 Unqualified lookup in templates
Some versions of GCC accept the following invalid code:
template <typename T> T Squared(T x) {
return Multiply(x, x);
}
int Multiply(int x, int y) {
return x * y;
}
int main() {
Squared(5);
}
LLVM flags this code with the following messages:
my_file.cpp:2:10: error: call to function 'Multiply' that is
neither visible in the template definition nor found by argument-
dependent lookup
return Multiply(x, x);
^
my_file.cpp:10:3: note: in instantiation of function template
specialization 'Squared<int>' requested here
Squared(5);
^
my_file.cpp:5:5: note: 'Multiply' should be declared prior to the
call site
int Multiply(int x, int y) {
^
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 154
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
The C++ standard states that unqualified names such as “Multiply” are looked up in two
ways:
■First, the compiler performs an unqualified lookup in the scope where the name
was written. For a template, this means the lookup is done at the point where the
template is defined, not where it's instantiated. Because Multiply has not been
declared yet at this point, unqualified lookup will not find it.
■Second, if the name is called like a function, then the compiler also does
argument-dependent lookup (ADL). In ADL the compiler looks at the types of all
the arguments to the call. When it finds a class type, it looks up the name in that
class's namespace; the result is all the declarations it finds in those namespaces,
plus the declarations from unqualified lookup. However, the compiler does not do
ADL until it knows all the argument types.
In the example code above, Multiply is called with dependent arguments, so ADL is not
done until the template is instantiated. At that point, the arguments both have type int,
which does not contain any class types, and so ADL does not look in any namespaces.
Since neither form of lookup found the declaration of Multiply, the code does not
compile.
Here's another example, this time using overloaded operators, which obey very similar
rules.
#include <iostream>
template<typename T>
void Dump(const T& value) {
std::cout << value << "\n";
}
namespace ns { struct Data {};
}
std::ostream& operator<<(std::ostream& out, ns::Data data) {
return out << "Some data";
}
void Use() {
Dump(ns::Data());
}
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 155
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
Again, LLVM flags this code with the following messages:
my_file2.cpp:5:13: error: call to function 'operator<<' that is
neither visible in the template definition nor found by argument-
dependent lookup
std::cout << value << "\n";
^
my_file2.cpp:17:3: note: in instantiation of function template
specialization 'Dump<ns::Data>' requested here
Dump(ns::Data());
^
my_file2.cpp:12:15: note: 'operator<<' should be declared prior to
the call site or in namespace 'ns'
std::ostream& operator<<(std::ostream& out, ns::Data data) {
^
As before, unqualified lookup did not find any declarations with the name operator<<.
Unlike before, the argument types both contain class types:
■One of them is an instance of the class template type std::basic_ostream
■The other is the type ns::Data that is declared in the example above
Therefore, ADL will look in the namespaces std and ns for an operator<<. Because one
of the argument types was still dependent during the template definition, ADL is not done
until the template is instantiated during Use, which means that the operator<< it should
find has already been declared. Unfortunately, it was declared in the global namespace,
not in either of the namespaces that ADL will look in!
Two ways exist to fix this problem:
■Make sure the function you want to call is declared before the template that might
call it. This is the only option if none of its argument types contain classes. You
can do this either by moving the template definition, or by moving the function
definition, or by adding a forward declaration of the function before the template.
■Move the function into the same namespace as one of its arguments so that ADL
applies.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 156
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
9.2.4 Unqualified lookup into dependent bases of class
templates
Some versions of GCC accept the following invalid code:
template <typename T> struct Base {
void DoThis(T x) {}
static void DoThat(T x) {}
};
template <typename T> struct Derived : public Base<T> {
void Work(T x) {
DoThis(x); // Invalid!
DoThat(x); // Invalid!
}
};
LLVM correctly rejects this code with the following errors (when Derived is eventually
instantiated):
my_file.cpp:8:5: error: use of undeclared identifier 'DoThis'
DoThis(x);
^
this->
my_file.cpp:2:8: note: must qualify identifier to find this
declaration in dependent base class
void DoThis(T x) {}
^
my_file.cpp:9:5: error: use of undeclared identifier 'DoThat'
DoThat(x);
^
this->
my_file.cpp:3:15: note: must qualify identifier to find this
declaration in dependent base class
static void DoThat(T x) {}
As noted in Section 9.2.3, unqualified names such as DoThis and DoThat are looked up
when the template Derived is defined, not when it's instantiated. When looking up a name
used in a class, we usually look into the base classes. However, we cannot look into the
base class Base<T> because its type depends on the template argument T, so the standard
says we should ignore it.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 157
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
The fix, as LLVM indicates, is to tell the compiler that we want a class member by
prefixing the calls with this->:
void Work(T x) {
this->DoThis(x);
this->DoThat(x);
}
Alternatively, you can tell the compiler exactly where to look:
void Work(T x) {
Base<T>::DoThis(x);
Base<T>::DoThat(x);
}
This works whether the methods are static or not, but be careful: if DoThis is virtual,
calling it this way will bypass virtual dispatch!
9.2.5 Incomplete types in templates
The following code is invalid, but compilers are allowed to accept it:
class IOOptions;
template <class T> bool read(T &value) {
IOOptions opts;
return read(opts, value);
}
class IOOptions { bool ForceReads; };
bool read(const IOOptions &opts, int &x);
template bool read<>(int &);
According to the standard, types that do not depend on template parameters must be
complete when a template is defined if they affect the program's behavior. However, the
standard also says that compilers are free to not enforce this rule. Most compilers enforce
it to some extent; for example, it would be an error in GCC to write opts.ForceReads in
the code above. In LLVM, the decision to enforce the rule consistently provides a better
experience, but unfortunately, it also results in some code getting rejected that other
compilers accept.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 158
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
9.2.6 Templates with no valid instantiations
The following code contains a typo: the programmer meant init() but wrote innit()
instead.
template <class T> class Processor {
...
void init();
...
};
...
template <class T> void process() {
Processor<T> processor;
processor.innit(); // <-- should be 'init()'
...
}
Unfortunately, the compiler can't flag this mistake as soon as it detects it: inside a
template, we're not allowed to make assumptions about "dependent types" such as
Processor<T>. Suppose that later on in this file the programmer adds an explicit
specialization of Processor, like so:
template <> class Processor<char*> {
void innit();
};
Now the program will work – but only if the programmer ever instantiates process()
with T = char*! This is why it's hard, and sometimes impossible, to diagnose mistakes in
a template definition before it's instantiated.
The standard states that a template with no valid instantiations is ill-formed. LLVM tries to
do as much checking as possible at definition-time instead of instantiation-time: not only
does this produce clearer diagnostics, but it also substantially improves compile times
when using precompiled headers. The downside to this philosophy is that LLVM
sometimes fails to process files because they contain broken templates that are no longer
used. The solution is simple: because the code is unused, remove it.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 159
Qualcomm Snapdragon LLVM ARM Compiler for Android Language Compatibility
9.2.7 Default initialization of const variable of a class type
The default initialization of a const variable of a class type requires a user-defined default
constructor.
If a class or struct has no user-defined default constructor, C++ does not allow you to
default-construct a const instance of it. For example:
class Foo {
public:
// The compiler-supplied default constructor works fine, so we
// don't bother with defining one.
...
}
void Bar() {
const Foo foo; // Error!
...
}
To fix this, you can define a default constructor for the class:
class Foo {
public:
Foo() {}
...
};
void Bar() {
const Foo foo; // Now the compiler is happy.
...
}
9.2.8 Parameter name lookup
Due to a bug in its implementation, GCC allows the redeclaration of function parameter
names within a function prototype in C++ code, e.g.
void f(int a, int a);
LLVM diagnoses this error (where the parameter name has been redeclared). To fix this
problem, rename one of the parameters.
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 160
AReferences
A.1 Related documents
Title Number
Qualcomm Technologies, Inc.
Qualcomm Snapdragon LLVM ARM Linker User Guide 80-VB419-102
Applicable Hexagon Programmer’s Reference Manuals:
■Hexagon V4 Programmer's Reference Manual
■Hexagon V5x Programmer's Reference Manual
■Hexagon V60/V61 Programmer's Reference Manual
■Hexagon V62 Programmer's Reference Manual
■Qualcomm Hexagon V65 Programmer's Reference Manual
80-N2040-9
80-N2040-8
80-N2040-33
80-N2040-36
80-N2040-39
Applicable Hexagon HVX Programmer’s Reference Manuals:
■Hexagon V60 HVX Programmers Reference Manual
■Hexagon V62 HVX Programmer’s Reference Manual
■Qualcomm Hexagon V65 HVX Programmer's Reference Manual
80-N2040-30
80-N2040-37
80-N2040-41
C language reference
The C Programming Language (2nd Edition), Brian Kernighan and
Dennis Ritchie, Prentice Hall, 1988 ISBN 0-13-110370-9
The C++ Programming Language (3rd Edition), Bjarne Stroustrup,
Addison-Wesley, 1997 ISBN 0201889544
Compiler reference
Compilers: Principles, Techniques, and Tools (2nd Edition), Alfred
Aho, Monica Lam, Ravi Sethi, and Jeffrey Ullman, Prentice Hall,
2006
ISBN 0-321-48681-1
Engineering a Compiler (2nd Edition), Keith Cooper and Linda
Torczon, Morgan Kaufmann, 2011 ISBN-13: 978-0120884780
80-VB419-90 M MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 161
BAcknowledgements
We would like to thank the LLVM community for their many contributions to the LLVM
Project.
This document includes content derived from the LLVM Project documentation under the
terms of the LLVM Release License:
llvm.org/releases/3.8.0/LICENSE.TXT

Navigation menu
