SolarWinds

Port Requirements

Version 2016

For SolarWinds Products

This PDF is no longer being maintained at this location. View Port

requirements for all SolarWinds products for the latest information.

© 2016 SolarWinds Worldwide, LLC. All rights reserved.

This document may not be reproduced by any means nor modified, decompiled, disassembled, published

or distributed, in whole or in part, or translated to any electronic medium or other means without the prior

written consent of SolarWinds. All right, title, and interest in and to the software and documentation are

and shall remain the exclusive property of SolarWinds and its respective licensors.

SOLARWINDS DISCLAIMS ALL WARRANTIES, CONDITIONS OR OTHER TERMS, EXPRESS OR IMPLIED,

STATUTORY OR OTHERWISE, ON SOFTWARE AND DOCUMENTATION FURNISHED HEREUNDER INCLUDING

WITHOUT LIMITATION THE WARRANTIES OF DESIGN, MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, AND NONINFRINGEMENT. IN NO EVENT SHALL SOLARWINDS, ITS SUPPLIERS, NOR ITS LICENSORS

BE LIABLE FOR ANY DAMAGES, WHETHER ARISING IN TORT, CONTRACT OR ANY OTHER LEGAL THEORY EVEN

IF SOLARWINDS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

The SolarWinds and other SolarWinds marks, identified on the SolarWinds website, as updated from

SolarWinds from time to time and incorporated herein, are registered with the U.S. Patent and Trademark

Office and may be registered or pending registration in other countries. All other SolarWinds trademarks

may be common law marks or registered or pending registration in the United States or in other countries.

All other trademarks or registered trademarks contained and/or mentioned herein are used for

identification purposes only and may be trademarks or registered trademarks of their respective

companies.

2

Table of Contents

Port Requirements for SolarWinds Products 5

DameWare 5

Database Performance Analyzer (DPA) 7

Database Performance Analyzer on Orion (DPAO) 8

ipMonitor 8

Firewall Security Manager (FSM) 11

KiWi Syslog Server 11

LANsurveyor 11

Log & Event Manager (LEM) 12

Network Topology Mapper (NTM) 14

Orion Additional Poller 14

Orion Enterprise Console (EOC) 14

Orion Firewall Security Manage Module (Orion FSMM) 15

IP Address Manager (IPAM) 15

NetFlow Traffic Analyzer (NTA) 15

Orion Network Atlas 16

Network Configuration Manager (NCM) 16

Network Performance Monitor (NPM) 16

NetPath™ Ports 18

Additional Polling Engines 18

Additional Web Server 19

High Availability 19

Agents 19

Patch Manager (PaM) 20

Server & Application Monitor (SAM) 21

Server, Website, and Agent Ports 21

3

SAM Component Monitor Ports 21

SAMTemplates 26

SAMWMI Requirements 26

Additional Polling Engines 28

Additional Web Server 28

Web Performance Monitor (formerly SEUM) 28

Toolset 28

Desktop Toolset 28

Web Toolset 29

Storage Manager (STM) 29

Storage Resource Monitor (SRM) 30

User Device Tracker (UDT) 31

Virtualization Manager (VMAN) 31

VoIP & Network QualityManager (VNQM) 33

Web Help Desk (WHD) 34

4

Port Requirements for SolarWinds Products

Last Update: 12/7/2016

The following reference provides a comprehensive list of port requirements for SolarWinds products. The

ports will vary from product to product and on a per use basis. In some cases ports are configurable. Refer

to your product Administrator Guide for more information.

DameWare

PORT

NUMBER DESCRIPTION USED WITH COMPONENT

OR PRODUCT

CHANGE THE

DEFAULT PORT

IN...

MODIFY THE PORT

SETTINGS ON...

443 DameWare Internet Proxy HTTPS -

Used to connect computers through

an Internet Session or download an

MRC or Internet Session agent

DameWare Internet

Proxy

The

Configuration

Wizard

N/A

6129 DMRC protocol - DameWare agents

listen on this port for incoming

remote desktop connections

DameWare Mini

Remote Control

DameWare

Mini Remote

Control

application

Mobile Client

in Global

Settings

6130 DameWare Mobile Client protocol -

the Gateway service listens on this

port for incoming mobile

connections

DameWare Mobile

Gateway

Administration

Console or the

Configuration

Wizard

Mobile Client

on the gateway

login screen

6132 Internet Session data stream

between MRC and the DameWare

Internet Proxy

DameWare Central

Server, DameWare

Internet Proxy

The

Configuration

Wizard

N/A

6133 Communication requests for

DameWare Central Server

components

DameWare Central

Server, DameWare

Internet Proxy,

DameWare Mobile

Gateway

The

Configuration

Wizard

DRS, MRC, and

Administration

consoles on

the login

screen

Optional ports for specific DameWare features:

UDP 137 Name Services port for File & Printer

Sharing, User and Computer

Authentication

DameWare Remote

Support

DameWare Mini

Remote Support

Windows

systems

settings

N/A

5

PORT

NUMBER DESCRIPTION USED WITH COMPONENT

OR PRODUCT

CHANGE THE

DEFAULT PORT

IN...

MODIFY THE PORT

SETTINGS ON...

DameWare Central

Server

138 Datagram Services port for File &

Printer Sharing

DameWare Remote

Support

DameWare Mini

Remote Support

Windows

systems

settings

N/A

139 Session Services port for File &

Printer Sharing, User and Computer

Authentication

DameWare Remote

Support

DameWare Mini

Remote Support

DameWare Central

Server

Windows

systems

settings

N/A

TCP and

UDP 445

Direct Hosting, NetBIOS for File &

Printer Sharing, User and Computer

Authentication

DameWare Remote

Support

DameWare Mini

Remote Support

DameWare Central

Server

Windows

systems

settings

N/A

5900 VNC default port DameWare Mini

Remote Support

DameWare Central

Server

MRC

connection

settings and in

VNC

configuration

server

MRC

connection

settings and in

VNC

configuration

server

88 Kerberos V5 port DameWare Central

Server

N/A N/A

3389 RDP port DameWare Mini

Remote Support

DameWare Central

Server

MRC

connection

settings and in

Windows

registry

MRC

connection

settings and in

Windows

registry

Dynamic NTLM port DameWare Central

Server

N/A N/A

6

PORT

NUMBER DESCRIPTION USED WITH COMPONENT

OR PRODUCT

CHANGE THE

DEFAULT PORT

IN...

MODIFY THE PORT

SETTINGS ON...

16993 Accessing Intel AMT secure(SSL) DameWare Mini

Remote Support

MRC

connection

settings and in

Intel AMT

server

MRC

connection

settings and in

Intel AMT

server

16992 Accessing Intel AMT DameWare Mini

Remote Support

MRC

connection

settings and in

Intel AMT

server

MRC

connection

settings and in

Intel AMT

server

UDP and

TCP 389

For LDAP to handle normal queries

from client computers to the domain

controllers

DameWare Central

Server

N/A N/A

TCP and

UDP 53

For DNS from client to domain

controller and domain controller to

domain controller

DameWare Central

Server

N/A N/A

TCP 636 Computer Authentication over SLL DameWare Central

Server

N/A N/A

Database Performance Analyzer (DPA)

PORT TYPE DESCRIPTION CHANGE THE DEFAULT PORT IN ...

8123 HTTP Default HTTP port for web server Can be changed according to changes in

DPA server.xml

8124 HTTPS Default HTTPS port for web server Can be changed according to changes in

DPA server.xml

8127 TCP Internal Tomcat shutdown port 

80 HTTP Default HTTPport for web server (Amazon

AMI installs only)



443 HTTPS Default HTTPS port for web server (Amazon

AMI installs only)



7

Database Performance Analyzer on Orion (DPAO)

PORT TYPE DESCRIPTION CHANGE THE DEFAULT PORT IN ...

80 TCP Default HTTP port for IIS web server Can be changed in IIS settings

443 TCP Default HTTPS port for IIS web server Can be changed in IIS settings

17776 TCP Incoming HTTP port used for JSwis

subscriptions

N/A

17777 TCP Internal port for communication with SWIS N/A

17778 TCP Internal port for communication with SWIS

(encrypted)

N/A

8124 TCP Default HTTPS port for establish integration

with DPA

Can be changed according to changes in DPA

server.xml

ipMonitor

ipMonitor uses the following local Ports:

nHTTP Port (default is 8080 and TCP 443 for SSL or administrator assigned).

The following table provides the various ports that are utilized depending on which monitor is enabled.

MONITOR TYPE PORT PARENT

PROTOCOL

ACTIVE DIRECTORY Active Directory 389 TCP

BANDWIDTH

USAGE

Bandwidth 161 UDP

BATTERY Battery 161 UDP

CPU USAGE Processor Usage 161 UDP

DIRECTORY

MONITOR

Directory Usage n/a SMB or NFS

DNS-QA Quality Assurance Domain Name Service 53 TCP

DNS-TCP Domain Name Service - Transmission Control Protocol 53 TCP

DNS-UDP Domain Name Service - User Datagram Protocol. 53 UDP

DRIVE SPACE Drive Space Availability 161 UDP

EVENT LOG NT Event Log Monitor n/a n/a

8

MONITOR TYPE PORT PARENT

PROTOCOL

EXCHANGE SERVER Microsoft® Exchange Server n/a n/a

EXTERNAL

PROCESS

Executable File n/a n/a

FAN MONITOR Fan Status 161 UDP

FILE PROPERTY Any File Type n/a SMB or NFS

FILE WATCHING Any File Type n/a SMB or NFS

FINGER Finger Information Server 79 TCP

FTP File Transfer Protocol 21 TCP

FTP-QA Quality Assurance File Transfer Protocol 21 TCP

GOPHER Menu driven front end to resource services such as

anonymous FTP

70 TCP

HTML/ASP HyperText Transfer Protocol 80 TCP

HTTP HyperText Transfer Protocol 80 TCP

HTTP-QA Quality Assurance HyperText Transfer Protocol 80 TCP

HTTPS Hypertext Transfer Protocol Secure 443 TCP

HUMIDITY Humidity Levels 161 UDP

IMAP4 Internet Message Access Protocol 143 TCP

IMAP4-QA Quality Assurance Internet Message Access Protocol 143 TCP

IPMONITOR ipMonitor 80,443 TCP

IRC Internet Relay Chat 6667 TCP

KERBEROS 5 Kerberos 5 88 UDP

LDAP Lightweight Directory Access Protocol 389 UDP

LINK-QA Quality Assurance Link 80 TCP

LOTUS NOTES Lotus NotesTM Transport 1352 TCP

MAPI-QA Microsoft Messaging Application Program Interface n/a n/a

MEMORY USAGE Physical Memory (RAM) 161 UDP

9

MONITOR TYPE PORT PARENT

PROTOCOL

NETWORK SPEED Speed or Bandwidth Monitor 19 TCP

NNTP Network News Transfer Protocol 119 TCP

NTP Network Time Protocol 123 UDP

PING Packet InterNet Groper n/a ICMP

POP3 Post Office Protocol 110 TCP

POP3-QA Quality Assurance Post Office Protocol 110 TCP

RADIUS Remote Authentication Dial-In User Service protocol 1812 UDP

RWHOIS Recursive WhoIs Information Server 4343 TCP

SERVICE Windows NT Service Monitor n/a NT Specific

SMTP Simple Mail Transfer Protocol 25 TCP

SNMP Simple Network Management Protocol 161 TCP

SNMP-QA Quality Assurance Simple Network Management Protocol 161 UDP

SNMP TRAP-QA Simple Network Management Protocol Traps 162 UDP

SNPP Simple Network Pager Protocol 444 TCP

SQL: ADO Structured Query Language: ActiveX Data Objects n/a NT Specific

SQL: ADO-QA Structured Query Language: ActiveX Data Objects n/a NT Specific

SQL SERVER Structured Query Language Server n/a NT Specific

TELNET Remote Terminal Protocol 23 TCP

TEMPERATURE Temperature Levels 161 UDP

WHOIS WhoIs Information Server 43 TCP

ipMonitor Traps

Any agent you configure to send Traps to ipMonitor must use this same IP Address and Port combination.

If the Windows SNMP Trap Service is enabled on the ipMonitor host computer, it is very likely to conflict

with ipMonitor's SNMP Trap Listener. Both are bound by default to port 162.

The POP3 User Experience monitor delivers an email to the SMTP server on port 25 for the recipient

address you specify. The monitor then logs in to the POP3 Mail Server on port 110 and retrieves the LIST of

queued mail.

10

Firewall Security Manager (FSM)

PORT TYPE COMPONENT COMMENT

17778   For the NCMrepository import method. FSM connects on

this port to the Orion information service on the primary

polling engine.

18184 TCP  For network connectivity between the Check Point

management server and the FSM server.

18210 TCP FW1_Ica_pull (the Check

Point internal CA pull

service)



18190 TCP CPMI service 

18191 TCP Check Point Daemon

(CPD)



21, 22 Telnet/SSH  For direct connection to firewalls to gather configs

3050 TCP Firebird Database

Manager

OFSMM, FSM server and FSM Client communication with

Firebird DB

4568 TCP License Manager

Listener



45680 TCP License Manager

Service



48080 HTTP FSM Web Server 

17784 HTTPS Orion FSM Web Service 

KiWi Syslog Server

The following lists required ports needed for KiWi Syslog Server.

nTFTP Server uses Port 69

nSyslog uses UDP port 514

LANsurveyor

To ensure that LANsurveyor scans thoroughly, turn on file and print sharing services and configure your

workstation firewall to allow connections to UDP 137, UDP 138, UDP 445, and TCP 139, and TCP 445 ports.

11

Log & Event Manager (LEM)

The following table provides a list of all of the ports needed for communication with SolarWinds LEM.

In the table, "inbound" assumes that the LEM VM is behind the firewall, and that you are

configuring firewall rules to allow network traffic through the firewall to the LEM VM.

PORT PROTOCOL SERVICE DIRECTION DESCRIPTION

22, 32022 TCP SSH Bidirectional SSH traffic to the SolarWinds LEM VM. (Port 22 is

not used prior to version 6.3.x.)

25 TCP SMTP Outbound SMTP traffic from the SolarWinds LEM VM to

your email server for automated email

notifications.

80, 8080 TCP HTTP Bidirectional Non-secure HTTP traffic from the SolarWinds

LEM Console to the SolarWinds LEM VM. (LEM

closes this port when activation completes, but

you can re-open it with the CMC togglehttp

command.)

139, 445 TCP NetBIOS,

SMB

Bidirectional Standard Windows file sharing ports (NetBIOS

Session Service, Microsoft SMB) that LEM uses to

export debug files, syslog messages, and backup

files.

The LEM Remote Agent Installer also uses these

ports to install agents on Microsoft Windows

hosts across your network.

161, 162 TCP SNMP Bidirectional SNMP trap traffic received from devices, and

used by Orion to monitor LEM. (Monitoring LEM

on port 161 is not used prior to version 6.3.x.)

389, 636 TCP LDAP Outbound LDAP ports that the LEM Directory Service

Connector tool uses to communicate with a

designated Active Directory domain controller.

The LEM Directory Service Connector tool uses

port 636 for SSL communications to a designated

Active Directory domain controller.

443, 8443 TCP HTTPS Bidirectional HTTPS traffic from the SolarWinds LEM Console

to the LEM VM.

LEM uses these secure HTTP ports after LEM is

activated.

12

PORT PROTOCOL SERVICE DIRECTION DESCRIPTION

(445) TCP SMB Bidirectional See entry for port 139.

514 TCP or

UDP

Syslog Inbound Syslog traffic from devices sending syslog event

messages to the SolarWinds LEM VM.

(636) TCP LDAP  See entry for port 389.

2100 UDP NetFlow Inbound NetFlow traffic from devices sending NetFlow to

the SolarWinds LEM VM.

6343 UDP sFlow Inbound sFlow traffic from devices sending sFlow to the

SolarWinds LEM VM.

(8080) TCP HTTP Bidirectional See entry for port 80.

(8443) TCP HTTPS Bidirectional See entry for port 443.

8983 TCP nDepth Inbound nDepth traffic sent from nDepth to the LEM VM

containing raw (original) log data.

9001 TCP LEMReports Bidirectional LEM Reports traffic used to gather LEM Reports

data on the LEM VM.

(32022) TCP SSH Bidirectional See entry for port 22.

37890-

37892

TCP LEMAgents Inbound LEM Agent traffic sent from SolarWinds LEM

Agents to the SolarWinds LEM VM. (These ports

correspond to the destination ports on the LEM

VM.)

37893-

37896

TCP LEMAgents Outbound LEM Agent return traffic sent from the

SolarWinds LEM VM to the SolarWinds LEM

Agents. (These ports correspond to the

destination ports on the LEM agents.)



LEMno longer uses the port listed in the following table.

PORT PROTOCOL SERVICE DIRECTION DESCRIPTION

5433 TCP LEMReports Inbound Port 5433 is no longer used.

Previously, this port carried

traffic from SolarWinds LEM

Reports to the SolarWinds LEM

VM. This was used by versions

prior to LEM 5.6, for which

support ended December 2015.

13

In LEM 6.2 and later, LEM will need access to the following URLs to use the automatic connector update

function and the Threat Feeds function:

nhttp://downloads.solarwinds.com/solarwinds/Release/LEM/

nhttps://rules.emergingthreats.net/fwrules/

Network Topology Mapper (NTM)

The following list provides the various ports that are used by Network Topology Mapper:

nSNMP uses the default UDP port 161.

nVMware objects are accessed over port 443.

nWMI communications use a random port between 1024 and 65535, per Microsoft Windows

specifications. You must create firewall exceptions to allow TCP/UDP traffic on ports 1024 - 65535 or

the monitored objects that use WMI will not be mapped.

nAccess to the SWIS API requires port 17778 HTTPS.

Orion Additional Poller

TheAdditional Polling Engine will talk to the Primary Polling engine (and vice versa) on TCP port 17777 and

TCP port 5671. It will also talk to the MS SQL DB server on port 1433.

nAdditional Polling Engines have the same port requirements as primary polling engines.

nPorts 4369, 25672, and 5672 are opened by default on the main server for RabbitMQ

messaging. These ports can be blocked by the firewall.

nPort 5672 (TCP) is required for RabbitMQ messaging between Orion servers for NPM 12.0 only

(Orion Platform version 2016.1).

Orion Enterprise Console (EOC)

PORT TYPE DESCRIPTION

80 TCP Access to the Web Console

17777 TCP Information Service protocol

14

Orion Firewall Security Manage Module (Orion FSMM)

The default port number for theFirewall Security Manager database is 3050. If the Firewall Security

Manager database port has not been changed, use the default. To be certain that 3050 is the correct port

for your installation, see your SysAdmin or the person who installedthe Firewall Security Manager

database.

Option: On the Firewall Security Manager database host, ata command prompt, typenetstat -band

pressEnter. The result contains a list of port numbers, services, and executables. Find the

executablefbserver.exeand confirm it is associated with port 3050.

IP Address Manager (IPAM)

nSNMP port uses the NPM default of UDP port 161.

nRPC Ports dynamically assigned above 1024. To configure RPC dynamic port allocations see:

http://support.microsoft.com/kb/154596

Port 53 (TCP) for zone transfers (DNS record polling).

NetFlow Traffic Analyzer (NTA)

The following table provides a list of all of the ports needed for communication with SolarWinds NTA.

PORT TYPE DESCRIPTION

53 TCP/

UDP

The TCP and UDP port used for DNS queries.

80 TCP Default port used by the web console and any other additional web servers.

If you specify any port other than 80, you must include that port in the URL used to

access the web console. For example, if you specify an IP address of 192.168.0.3 and

port 8080, the URL used to access the web console ishttp://192.168.0.3:8080.

137 UDP Port for outbound traffic if NetBIOS name resolution is turned on.

When NTA is trying to resolve the NetBIOS names of servers in their conversations, you

may find a large amount of outbound UDP 137 traffic from the NTA Collector to a

number of external addresses. You can confirm the traffic by using the Flow Navigator

to match the outbound connections to existing conversations.

This is normal behavior when NetBIOS is enabled. An easy way to demonstrate

the behavior is to disable NetBIOS in NTA and watch all outbound connections

terminate.

161 TCP The NTA collector uses this port for polling CBQoS-enabled devices for traffic-shaping

policies and results using SNMP.

15

PORT TYPE DESCRIPTION

1433 TCP The port used for communication between the NTA Flow Storage and the NPM SQL

server.

2055 UDP Default port for receiving flows on any NTA collector. It has to be open for receiving

flows on additional polling engines.

17777 TCP This port needs to be opened both to send and receive traffic between NPM and any

other Orion modules.

17778 HTTPS

and

TCP

Open to access the SolarWinds Information Service API and agent communication

17791 TCP Open for agent communication on any SolarWinds Orion server running Windows

Server 2008 R2 SP1

Device

Specific

 Cisco NetFlow Configuration: The port used for NetFlow traffic is specified in the

configuration of your Flow-enabled Cisco appliance

If you store your flows data in a remote NTA Flow Storage database, you need to open ports 1433

(TCP) and 17777 (TCP) on the NTA Flow Storage server, too.

Orion Network Atlas

Orion Network Atlas requires the following port:

nOrion Information Service Protocol uses port 17777/tcp

Network Configuration Manager (NCM)

The following lists the ports that may be needed depending on how NCM is designated to download and

upload configurations.

nFTP control (setup/teardown) on port 21, FTP data on port 20.

n161 – default port for Polling Devices, Statistics Collection via SNMP

n25 default port for e-mail sending via SMTP

n22 - default port for Config transfer via SSH/ SCP server

n23 – default port for Config transfer via Telnet

n69 – port TFTP server listens on

n8888 – default web server port

n17777 – Information service port

Network Performance Monitor (NPM)

The following tables provide the ports that are used by NPM depending on which services are enabled.

16

Ports 4369, 25672, and 5672 are opened by default on the main server for RabbitMQ messaging.

These ports can be blocked by the firewall.



PORT TYPE DESCRIPTION

25 TCP SMTP port for non-encrypted messages

80 TCP Default additional web server port. If you specify any port other than 80, you must

include that port in the URL used to access the web console. For example, if you specify

an IP address of 192.168.0.3 and port 8080, the URL used to access the web console is

http://192.168.0.3:8080 . Open the port to enable communication from your computers

to the Orion Web Console.

The port might also be used for Cisco UCS monitoring.

161 UDP NPM statistics collection

162 UDP NPM Trap Server listens for incoming messages

443 TCP Default port for https binding.

Also used for bi-directional ESX/ESXi server polling, or for Cisco UCS monitoring.

465 TCP The port used for SSL-enabled email alert actions.

514 UDP NPM Syslog Service listens for incoming messages

587 TCP The port used for TLS-enabled email alert actions.

1433 TCP The port used for communication between the SolarWinds server and the SQL Server.

Open the port from your Orion Web Console to the SQL Server.

1434 UDP The port used for communication with the SQL Server Browser Service to determine how

to communicate with certain non-standard SQL Server installations. For more

information, see this Microsoft Technet article.

1801 TCP MSMQ WCF binding (for more information see this KB:

http://support.microsoft.com/kb/183293).

5671 TCP For encrypted RabbitMQ messaging (AMQP/TLS) into the main polling engine from all

Orion servers.

17777 TCP Orion module traffic. Open the port to enable communication from your poller to the

Orion Web Console, and from the Orion Web Console to your poller.

The port used for communication between the Orion Web Console and the poller.

17778 HTTPS Required for access to the SWIS APIand agent communication

17779 HTTP SolarWinds Toolset Integration over HTTP

17

PORT TYPE DESCRIPTION

17780 HTTPS SolarWinds Toolset Integration over HTTPS

17791 TCP Open for agent communication on any SolarWinds Orion server running Windows Server

2008 R2 SP1

NetPath™ Ports

Open the following ports on your firewall for network connectivity used by NetPath™:

PORT PROTOCOL SOURCE DESTINATION DESCRIPTION

17778 TCP NetPath™

probe

Polling engine Used to send information

back to your Orion server.

11

(ICMPTime

Exceeded)

ICMP Networking

devices along

your path

NetPath™ probe Used by the NetPath™ probe

to discover network paths.

User

configured

TCP NetPath™

probe

Endpoint service Any ports of the monitored

services that are assigned to

the probe.

Used by the NetPath™ probe

to discover service status.

43

443

TCP Main polling

engine

BGP data providers and

announcements, such as:

nhttp://whois.arin.net/ui/

nhttps://stat.ripe.net/

Used by NetPath™ to query

BGP information about the

discovered IP addresses.

Additional Polling Engines

Additional Polling Engines used with NPM have the same port requirements as the NPM primary polling

engine. The following ports are the minimum required for an APE to ensure the most basic polling

functions.

PORT TYPE DESCRIPTION

1433 TCP (outbound) The port used for communication between the APE and the Orion

database.

5671 TCP (AMQP/TLS -

outbound)

For SSL encrypted RabbitMQ messaging from the Orion Web Console

to the APE.

17777 TCP (bidirectional) The port used for communication between the APE and the Orion Web

Console.

18

Additional Web Server

PORT TYPE DESCRIPTION

80 TCP

(inbound)

Default additional web server port. Open the port to enable communication from

your computers to the Orion Web Console.

If you specify any port other than 80, you must include that port in the URL used

to access the web console. For example, if you specify an IP address of

192.168.0.3 and port 8080, the URL used to access the web console is

http://192.168.0.3:8080 .

1433 TCP

(outbound)

The port used to send data from the Additional Web Server to the Orion

database.

1801 TCP

(outbound)

The port used for MSMQ messaging from the Additional Web Server to primary

polling engine.

5671 TCP

(AMQP/TLS -

outbound)

For SSL encrypted RabbitMQ messaging from the Additional Web Server to the

primary polling engine.

17777 TCP

(bidirectional)

The port used for communication between the Additional Web Server and the

primary polling engine.

High Availability

The following ports are used in addition to ports used by your primary products when you enable High

Availability.

PORT TYPE DESCRIPTION

4369 TCP Open on the main Orion server and its standby server for RabbitMQ clustering. This port

exchanges EPMD and Erlang distribution protocol messages for RabbbitMQ. This port is

not required when protecting additional polling engines.

5671 TCP For encrypted RabbitMQ messaging (AMQP/TLS) into the main polling engine from all Orion

servers.

25672 TCP Open on the main Orion server and its standby server for RabbitMQ clustering. This port

exchanges EPMD and Erlang distribution protocol messages for RabbbitMQ. This port is

not required when protecting additional polling engines.

Agents

The following ports are used by the SolarWinds Orion agent.

19

PORT TYPE DESCRIPTION

17791 TCP Allows agent communication on any SolarWinds Orion server running Windows Server

2008 R2 SP1.

 17790 TCP Open on the remote computer (inbound).

17778 TCP Open on the SolarWinds Orion server (inbound).

135 TCP Open on the remote computer (inbound) if you deploy the agent from the SolarWinds

server.

445 TCP Microsoft-DS SMB file sharing. This port must be open on the client computer (inbound) for

remote deployment.

Patch Manager (PaM)

The following sections describe the ports used in the Patch Managerenvironment.

PORT TYPE DESCRIPTION

135 TCP RPC Endpoint Mapper -The Patch Manager server uses this port to establish WMI

connections to remotecomputers. It also uses this port to connect to the Service

Control Manager (SCM)when it provisions the WMI providers dynamically on the

remote computer.

389 TCP Lightweight Directory Access Protocol - Patch Manager servers use this port for Active

Directory authentication.

445 TCP SMB over TCP - The Patch Manager server uses this port when it provisions the WMI

providers toa remote computer.

4092  Console-to-Server Communication - The Patch Manager console uses this port to

communicate to an independentPatch Manager application server. This is a one-way

communication channel, soit only requires inbound TCP traffic on the application

server.

Patch Manager servers in a distributed environment also use this port in the

samemanner for "downstream" communication. For example, the Patch

ManagerPrimary Application Server (PAS) uses port 4092 to communicate with

remotePatch Manager servers in secondary server roles.

8787 TCP Web Console Connections - By default, users connect to the Patch Manager web

console server on port 8787.

17777 TCP SolarWinds Information Service - The SolarWinds Information Service (SWIS) facilities

data exchange for the PatchManager web console, along with the web console

Application ProgramingInterface (API). Ensure this port is not blocked on servers

running the PatchManager web console server.

20

PORT TYPE DESCRIPTION

1024-

65536

Dynamic

Ports

DCOM or RPC - WMI technology is based on Distributed Component Object Model

(DCOM)/RPCcommunication. DCOM/RPC allocates the ports used by the server within

adynamic port range. This range is typically between 1024 and 65536. Toconfigure

these ports using Windows Firewall on your managed computers,enable the Inbound

Rules in the Windows Management Instrumentation (WMI)group

Server & Application Monitor (SAM)

Server, Website, and Agent Ports

PORT TYPE COMPONENT DESCRIPTION

5671 TCP  RabbitMQ messaging

17791 TCP Agents Open for agent communication on any SolarWinds Orion server running

Windows Server 2008 R2 SP1.

17777 TCP SAM

Server

and

Website

Must be open on both the SAM server and the website.

Additional polling engines will require access to the SQL database.

135  Agents Open Ports Requirements for Remote Deployment from the Orion Server -

Microsoft EPMAP (DCE/RPC Locator service). This port is required to be open

on the client computer (Inbound) for remote deployment.

445  Agents Open Ports Requirements for Remote Deployment from the Orion Server -

Microsoft-DS SMB file sharing. This port is required to be open on the client

computer (Inbound) for remote deployment.

SAM Component Monitor Ports

COMPONENT/

MONITOR PORT TYPE DESCRIPTION

DHCP User

Experience

Monitor

67 UDP The UDP port used for the DHCP request.

DHCP User

Experience

Monitor

68 UDP The UDP port used for the DHCP response.

Directory

Size Monitor

  See "Application Performance Monitor WMI Requirements" on

page "4".

21

COMPONENT/

MONITOR PORT TYPE DESCRIPTION

DNS Monitor

DNS User

Experience

Monitor

53 TCP/UDP The TCP and UDP port used for DNS queries.

Download

Speed

Monitor

19  The port used for the character generator service.

File Age

Monitor

File Change

Monitor

File Existence

Monitor

Files Size

Monitor

445 TCP/UDP These components monitor uses TCP/445 and UDP/445 ports.

File Count

Monitor

  See "Application Performance Monitor WMI Requirements" on

page "4".

FTP Monitor

FTP User

Experience

Monitor

21  This field is the port number used for FTP sessions

HTTP Form

Login

Monitor

HTTP Monitor

TCP Port

Monitor

80  This field is the port number used for HTTP forms-based login

sessions.

HTTPS

Monitor

443  The port used by the web site.

IMAP4

Monitor

143  

IMAP4 User

Experience

Monitor

143 and

993

IMAP4 This component monitor uses these ports when used with a

Microsoft Exchange mail server.

22

COMPONENT/

MONITOR PORT TYPE DESCRIPTION

IMAP4 User

Experience

Monitor

25 SMTP This component monitor uses these ports when used with a

Microsoft Exchange mail server.

IMAP4 Port

sessions

143 IMAP4 This field is the port number used for IMAP 4 sessions.

IMAP4 Port

sessions

585 IMAP4 For Secure IMAP (IMAP4-SSL), use port 585.

IMAP4 Port

sessions

993 IMAP4 For IMAP4 over SSL (IMAPS), use port 993.

LDAP User

Experience

Monitor

389  The port used for LDAP connections.

LDAP User

Experience

Monitor

636  For LDAP over SSL, use port 636.

Linux/Unix

Script

Monitor Ports

22  This field allows you to specify the port number used for the SSH

connection.

NNTP

Monitor

119 UDP This field is the port number used for NNTP connections.

ODBC User

Experience

Monitor

1630 TCP This component monitor uses port TCP/1630.

Oracle User

Experience

Monitor

1521 TCP The Oracle SQL*Net Listener allows Oracle client connections to

the database over Oracle's SQL*Net protocol. You can configure

it during installation. To reconfigure this port, use Net

Configuration Assistant.

Oracle User

Experience

Monitor

1526 TCP The Oracle SQL*Net Listener allows Oracle client connections to

the database over Oracle's SQL*Net protocol. You can configure

it during installation. To reconfigure this port, use Net

Configuration Assistant.

Performance

Counter

Monitor

See

description

TCP This monitor uses RPC, requiring the following ports:

nTCP/135

nRPC/named pipes (NP) TCP 139

23

COMPONENT/

MONITOR PORT TYPE DESCRIPTION

nRPC/NP TCP 445

nRPC/NP UDP 137

nRPC/NP UDP 138

POP3

Monitor

POP3 User

Experience

Monitor

110

(default)

 This field is the port number used for POP3 connections.

POP3

Monitor

POP3 User

Experience

Monitor

995  For Secure POP3 (SSL-POP) use port 995.

POP3 User

Experience

Monitor

SMTP

Monitor

25 SMTP This component uses port 25 for SMTP sessions.

SMTP

Monitor

465 SSMTP For Secure SMTP (SSMTP), use port 465.

POP3

Monitor

See

Description

 This component monitor uses the following ports when used with

a Microsoft Exchange mail server.

n102 X.400 MTA

n110 POP3

n119 NNTP

n143 IMAP4

n389 LDAP

n563 POP3 over SSL

n636 LDAP over SSL

n993 IMAP4 over SSL

n995 Secure POP3 over SSL

POP3 User

Experience

Monitor

110

(default)

 This field is the port number used for POP3 sessions. The default

value is 110. For Secure POP3 (SSL-POP) use port 995. It also uses

an SMTP Port, port 25 for SMTP sessions.

24

COMPONENT/

MONITOR PORT TYPE DESCRIPTION

Process

Monitor

 SNMP This component monitor uses SNMP communication.

Process

Monitor WMI

  Uses WMI communication to test if the specified Windows

process is running and uses RPC communication to test if the

specified Windows process is running.

RADIUS User

Experience

Monitor

1812

1645

 This field is the RADIUS protocol authentication port. The default

value is 1812. Cisco devices may require port 1645. This field is

the RADIUS protocol accounting port. The default value is 1813.

Cisco devices may require port 1646.

RWHOIS Port

Monitor

4321  This template tests the ability of an RWHOIS server to accept

incoming sessions on port 4321.

SQL Server

User

Experience

Monitor

1433  This component monitor only works if Microsoft SQL Server is

using the default port 1433. If you have a Microsoft SQL Server

database that uses a non-standard port, you cannot monitor it

using the SQL Server User Experience monitor. You need to use

the ODBC User Experience monitor instead to manually define a

connection string that will allow you to talk to Microsoft SQL

Server on its custom port.

TACACS+User

Experience

Monitor

49  This field is the TACACS+ protocol connection port. The default

value is 49.

Tomcat

Server

Monitor

8080  This field allows you to specify the port number used by the web

site. The default value for this field is 8080.

VMware

Performance

Counter

Monitor

443  Port number to use for VMware API. The default is 443.

ESX

Hardware

Monitoring

5989  Ensure port 5989 is open on the firewall.

Windows

Event Log

Monitor

  This component monitor uses the following ports:

nTCP/135

nRPC/named pipes (NP) TCP 139

nRPC/NP TCP 445

25

COMPONENT/

MONITOR PORT TYPE DESCRIPTION

nRPC/NP UDP 137

nRPC/NP UDP 138

nPOP3 User Experience Monitor port 110

SAMTemplates

Template port requirements will vary depending on how you utilize them. The following provides a list of

monitor templates that use ports.

TEMPLATE PORT DESCRIPTION

Blackberry Delivery

Confirmation

template

25 Blackberry Delivery Confirmation template uses port 25 on the SMTP server

for sending the test email. If the SMTP server uses a different port, change

this value.

Finger Port Monitor 79 This template tests the ability of the Finger service to accept incoming

sessions on port 79.

Gopher Port

Monitor

70 This template tests the ability of a Gopher server to accept incoming

sessions on port 70.

IRC Port Monitor 6667 This template tests the ability of an IRC server to accept incoming sessions

on port 6667.

Java Application

Server (SNMP)

template

1161 This template is configured to send SNMP requests on port 1161.

SNPP Port Monitor 444 This template tests the ability of an SNPP server to accept incoming sessions

on port 444.

Windows FTP

Server (via WMI)

21 This template monitors the Windows FTP Publishing Service and tests the

ability of the FTP server to accept incoming sessions on port 21.

SAMWMI Requirements

Microsoft Windows by default uses a random port between 1024 and 65535 for WMI communications. You

must create firewall exceptions to allow TCP/UDP traffic on ports 1024 - 65535 or the component monitors

and templates that use WMI will not work.

The following component monitors use WMI:

nPerformance Counter Monitor

nProcess Monitor – WMI (if script uses WMI access)

nWindows Event Log Monitor

nWindows PowerShell Monitor (if script uses WMI access)

26

nWindows Script Monitor

nWindows Service Monitor (if script uses WMI access)

The following templates use WMI:

nActive Directory

nBlackberry Enterprise Server

nCitrix XenApp 5.0 Core WMI Counters

nCitrix XenApp 5.0 ICA Session WMI Counters

nCitrix XenApp 5.0 Presentation Server WMI Counters

nCitrix XenApp 5.0 Services

nErrors in Application Event Log

nExchange 2007

nExchange 2007 Client Access Role Services

nExchange 2007 Client Access Role WMI Counters

nExchange 2007 Common WMI Counters

nExchange 2007 Edge Transport Role Services

nExchange 2007 Hub Transport Role Services

nExchange 2007 Hub Transport Role WMI Counters

nExchange 2007 Mailbox Role Services

nExchange 2007 Mailbox Role WMI Counters

nExchange 2007 Unified Messaging Role Services

nExchange 2007 WMI Counters

nExchange 2010 Client Access Role Services

nExchange 2010 Common Performance Counters

nExchange 2010 Edge Transport Role Services

nExchange 2010 Hub Transport Role Services

nExchange 2010 Mailbox Role Services

nExchange 2010 Unified Messaging Role Services

nExchange Server 2000 and 2003

nInternet Information Services

nOrion Server

nSharePoint Server (MOSS) 2007

nSharePoint Services (WSS) 3.0

nSQL Server 2005 Database

nSQL Server 2008 Database

nWindows Print Services

nWindows Server 2003-2008

27

Additional Polling Engines

Additional Polling Engines have the same port requirements as primary polling engines, as outlined above.

Additional Web Server

If you have installed an additional web server:

nDefault port 80.

nIf you specify any port other than 80, you must include that port in the URL used to access the web

console. For example, if you specify an IP address of 192.168.0.3 and port 8080, the URL used to

access the web console is http://192.168.0.3:8080.

Web Performance Monitor (formerly SEUM)

The following list of ports is required for the WPM Player, Recorder and the Web Interface.

PORT TYPE DESCRIPTION

80

(or

8787)

TCP Default web port.If you specify any port other than 80, you must include that port in the

URL used to access the web console. For example, if you specify an IP address of

192.168.0.3 and port 8080, the URL used to access the web console

ishttp://192.168.0.3:8080. Open the port to enable communication from your computers

to the Orion Web Console.depends on what the default port for the Orion web interface

is.

443 TCP Used when a certificate for encryption to the Orion web interface is installed (SSL/HTTPS)

1433 TCP Usedfor communication between the SolarWinds server and the SQL Server. Open the

port from your Orion Web Console to the SQL Server.

17777 TCP Usedfor OrionWPM traffic.

17781 TCP The default port the SEUM Player listens on. This port must be open between the Orion

server and theWPM player for proper communications.

17782 TCP Used for player-initiated communications mode

Toolset

Desktop Toolset

The following lists the required ports needed for the Engineer's Toolset.

COMPONENT PORT TYPE DESCRIPTION

Syslog

Server

514 UDP Allows you to listen for incoming Syslog messages on UDP port 514.

28

COMPONENT PORT TYPE DESCRIPTION

WAN

Killer

7

9

 Use port 7 to generate traffic going both ways. When data is sent to port 7

(echo), all traffic that is received by the target device will be sent back to WAN

Killer. This will generate a load in both directions.

Use port 9 (discard) to generate one-way traffic. Port 9 discards all data when

received.

Netflow

Realtime

2055  Listens on Port 2055

TFTP

Server

69 UDP 

SNMP

Polling

161  

Sending

emails

25  

Web Toolset

nUses port 443 for Secured SSH Connection.

Storage Manager (STM)

PORT TYPE DESCRIPTION

22 TCP Used on the control system for EMC Celerra Storage Devices.

80 TCP Used on the NetApp head/cluster node and any available CIFS/NFS.

161 UDP Used for polling of Fiber Channel Switches: Cisco MDS, Brocade, McData, and QLogic

Switches.

Used on the EqualLogic Group IP.

162 UDP Agents use this port to notify Storage Manager Server when information is available to be

retrieved from the agent.

If port 162 is in use by Orion NPM, then Storage Manager will use 10162 or 20162 when

SNMP traps are sent to the Storage Manager Server.

443 TCP Storage Manager uses this port to communicate with VMware Virtual Center or ESX server.

Used on the NetApp head/cluster node and any available CIFS/NFS.

1094 TCP Used by MS SQL application module.

1433 TCP Used by MS SQL application module.

29

PORT TYPE DESCRIPTION

1521 TCP Used by Oracle application module.

2463 TCP Used to set RPC sessions to the storage controller from the SMI-Sprovider for LSI and SUN

StorageTek storage devices.

3306 TCP Used by the Storage Manager Database.

4319 TCP Handles the collection from Storage Manager Agents and also acts as a local data

collector/agent. Storage Manager communicates with data collectors/agents.

5988 TCP HTTP port used by SMI-S providers.

5989 TCP HTTPS port used by SMI-S providers.

8443 TCP HTTPS port used to communicate with the Storage Profiler Module

9000 TCP Storage Manager Web Console

17778 TCP Required for access to the SWIS API

43501 TCP Java Management Extensions (JMX) if blocked can also use 43052, 43503, and 43504. Allows

web server to obtain memory from STM services (collector,

event receiver, maintenance, and poller).

Storage Resource Monitor (SRM)

PORT TYPE DESCRIPTION

25  SSL/TLS for email alert actions should be enabled

80 TCP Default web port.If you specify any port other than 80, you must include that port

in the URL used to access the web console. For example, if you specify an IP

address of 192.168.0.3 and port 8080, the URL used to access the web console

ishttp://192.168.0.3:8080. Open the port to enable communication from your

computers to the Orion Web Console.

Used on the NetApp head/cluster node and any available CIFS/NFS.

Used by EMC VNX/Clariion for file side performance.

161 UDP Used for polling storage arrays through SNMP

Used on the EqualLogic Group IP.

443 TCP Used on the NetApp head/cluster node and any available CIFS/NFS.

Used by EMC VNX/Clariion for file side performance.

1433 TCP Used for communication between the SRM and the SQL Server.

30

PORT TYPE DESCRIPTION

1434 UDP The port used for communication with the SQL Server Browser Service to

determine how to communicate with certain non-standard SQL Server

installations. For more information, see this Microsoft Technet article.

1801 TCP MSMQ WCF binding (for more information see this

KB:http://support.microsoft.com/kb/183293).

5988 TCP HTTP port used by SMI-S providers.

5989 TCP HTTPS port used by SMI-S providers.

8088 TCP HTTP Backup port used for NetApp DFM management servers for 7-mode arrays

8443 TCP HTTPS port used by Storage Profiler SWIS

8488 TCP HTTPS Used for NetApp DFM management servers for 7-mode arrays

17777 TCP Orion module traffic. Open the port to enable communication from your poller to

the Orion Web Console, and from the Orion Web Console to your poller.

The port used for communication between the Orion Web Console and the poller.

17778 HTTPS Required for access to the SWIS API

17779 HTTP/HTTPS SolarWinds Toolset Integration

User Device Tracker (UDT)

PORT TYPE DESCRIPTION

80 TCP Used to access the website

161 UDP Used for SNMP (polling) traffic

1433 TCP Used to communicate with MS SQL

17777 TCP Information Service Protocol

Virtualization Manager (VMAN)

The port requirements of SolarWinds Virtualization Manager depend on the features and components that

are in use. The features and components on which the port requirements depend are the following:

nVMware data collection

nHyper-V data collection

nAD/LDAP authentication

nSending email notifications (used in alerting and reporting)

nSending SNMP traps (used in alerting)

31

nOrion integration

nFederated collectors

The following inbound ports need to be configured for communication with the Virtualization Manager

master appliance:

PORT DESCRIPTION

80 For HTTP access to the Virtualization Manager user interface.

8983 For performing auto-upgrade after installing hotfixes on federated collectors, if federated

collectors are configured.

443 For HTTPS access to the Virtualization Manager user interface.

5480 For HTTPS access to the Management Console.

61616 For Active MQ master-collector communication.

22 For SSH access to the virtual appliance.



The following outbound ports need to be configured, depending on the individual setup and the functions

you use:

PORT DESCRIPTION

162 For sending SNMP traps.

25 For sending emails through SMTP.

389 For Active Directory authentication.

3268 For LDAP authentication.

17778 For communication with the Orion server if the integration with Orion is enabled.

123 For using the NTP service.



If you use Virtualization Manager integrated with NPM or SAM in an environment with multiple polling

engines and federated collectors, make sure that you open TCP port 17778 from the primary collector to

every polling engine that is used to poll virtualization data.

The following inbound ports need to be configured on the federated collector:

PORT DESCRIPTION

5480 For HTTPS access to the Management Console.

22 For SSH access to the federated collector.

32

The following outbound ports need to be configured on the federated collector:

PORT DESCRIPTION

61616 For Active MQ master-collector communication.

443 or 80 For performing auto-upgrade or version upgrade.

8983 For performing auto-upgrade after installing hotfixes.

Depending on the environment that is polled, the following outbound ports need to be configured on the

master or the collector for data collection:

PORT DESCRIPTION

443 For data collection from ESX hosts and vCenters.

7 For access to Hyper-V hosts that were added by using a fully qualified domain name.

135 For WMI data collection from Hyper-V hosts or VMs.

Dynamic RCP

ports

For WMI communication. The available ports can be configured on the WMI

target/policy.

VoIP & Network QualityManager (VNQM)

The following table provides a list of all of the ports needed for communication with SolarWinds VNQM.

PORT TYPE DESCRIPTION

21 TCP FTP (CDR/CMR download)

22 TCP SFTP (CDR/CMR download)

SSH for CLI (operation polling)

23 TCP TELNET for CLI (operation polling)

80 TCP HTTP port

Default port used by additional web servers. If you change this setting, you must include

the port in the URL used to access the web console.

161 UDP Default UDP port of NPM, used by SNMP.

443 TCP Used for conducting secure SSL communications.

17777 TCP Must be opened for Orion module traffic.

33

Web Help Desk (WHD)

The following table provides a list of all of the ports needed for communication with SolarWinds Web Help

Desk.

PORT TYPE DESCRIPTION

25 TCP Traffic from the SolarWinds WHD appliance to your email server for automated email

notifications

80 TCP Non secure connection to EWS

110 TCP Non Secure POP3

135 TCP Asset discrovery via WMI

143 TCP Non Secure IMAP

389 TCP Traffic from the SolarWinds WHD appliance to a designated server (usually a domain

controller) for use with the Directory Service tool (LDAP, AD)

443 TCP Secure connection to EWS

636 TCP Secure traffic from the SolarWinds WHD appliance to a designated server (usually a

domain controller) for use with the Directory Service tool (LDAP, AD)

993 TCP Secure IMAP

995 TCP Secure POP3

1433 TCP Microsoft SQL external database, Lansweeper,Miscrosoft SMS/SCCM, Solarwinds

NCM/NPM/SAM

1521 TCP Oracle JDBC forAsset discovery

3306 TCP MySQL external database, LANrev, Casper 8 and lower

4445 TCP Remote log server reader

5432 TCP External PostgreSQL database

5433 TCP Asset discovery Apple Remote 3.2

7100 TCP Asset discovery Sybase

8081 TCP Non-secure traffic from the SolarWinds Web Help Desk Console

8443 TCP Secure traffic from the SolarWinds Web Help Desk Console

17778 TCP SolarWinds Orion Integration

20293 TCP Embedded PostgreSQL

61616 TCP Web Help Desk Discovery Engine

34
