XP5s

USER GUIDE

GENERAL INFORMATION

Sonim and the Sonim logo are trademarks of Sonim

Technologies, Inc. Other company and product names

may be trademarks or registered trade-marks of the

respective owners with whom they are associated.

DISPOSAL OF OLD ELECTRICAL AND

ELECTRONIC EQUIPMENT

The symbol of the crossed-out wheeled

bin indicates that within the countries in

the European Union, this product, and any

enhancements marked with this symbol,

cannot be disposed as unsorted waste but

must be taken to separate collection at their

end- of-life.

DISPOSAL OF BATTERY

Please check local regulations for disposal of

batteries. The battery should never be placed

in municipal waste. Use a battery disposal

facility if available.

GUIDELINE FOR HEADPHONE AND

EARPHONE

To prevent possible hearing damage, please

do not listen at high volume levels for long

periods.

Please register your phone at http://sonimxperience.

com/registration_portal/portal/registration.php to

receive product information and updates.

Sonim devices are covered by a 3-Year

comprehensive warranty. The battery is

covered by a 1-Year limited warranty.

Congratulations on the purchase of a Sonim XP5s

(

XP5800)

mobile phone! This phone is LTE enabled

phone and has an intuitive feature-rich user interface,

which allows you to make the best use of offered

functions.

PHONE MODELS COVERED

This user guide covers Sonim XP5s phone with the

model number

XP5800

. The model name can be seen

on backside of the phone.

SONIM SUPPORT INFORMATION

For additional product and support information, visit

www.sonimtech.com.

OPTIONS COMMONLY USED ACROSS

MENU ITEMS

The following are common actions used across

various menu items:

Conrms an action. Use the

Center

selection key to perform this function.

BACK

Use this key to display the previous

screen.

Moves the current working application to

the recent applications list/background

and displays menu screen.

RECENT

Displays the thumbnails of the

applications that you have worked on

recently. To remove any application from

this list, Select Remove from list from

option.

TABLE OF CONTENTS

GENERAL INFORMATION 2

Disposal of Old Electrical and Electronic Equipment ....... 2

Disposal of Battery ............................................................ 2

Guideline for Headphone and Earphone .......................... 2

Phone Models Covered ..................................................... 2

Sonim Support Information .............................................. 2

Options Commonly Used Across Menu Items ................. 2

SAFETY GUIDELINES 5

Avoid High Temperatures .................................................. 6

Personal Medical Devices ................................................. 6

Child Safety ........................................................................ 6

Emergency Calls ................................................................ 6

BATTERY USAGE 6

Inserting the Battery .......................................................... 6

Charging the Battery ......................................................... 7

Your SIM Card ................................................................... 7

Inserting the SIM Cards ..................................................... 8

Inserting Memory Card ...................................................... 8

Warning .............................................................................. 8

Verifying and Optimizing Battery Usage ........................... 8

Tips to Extend the Battery Life .......................................... 9

GETTING STARTED 9

What is in the Box? ............................................................ 9

Phone Specications ......................................................... 9

USING YOUR SONIM XP5S 11

Switching On the Phone .................................................. 12

Setting Up Your Phone .................................................... 12

Managing Home Screen .................................................. 12

Notication Bar Icons ...................................................... 13

Phone Operations Without SIM Card ............................. 13

Capturing a Screenshot................................................... 13

Text Entry Options ........................................................... 14

To Enter a Word ............................................................... 14

To Insert a Number .......................................................... 14

HOME SCREEN MENU OPTIONS 15

My Notications ............................................................... 15

Wallpaper ......................................................................... 15

Search .............................................................................. 15

Home Screen Shortcuts .................................................. 15

System Settings ............................................................... 15

Manage Apps................................................................... 15

QUICK SETTINGS 16

Wi-Fi ................................................................................. 16

Bluetooth .......................................................................... 16

Torch ................................................................................ 16

Airplane Mode .................................................................. 16

Proles ............................................................................. 16

MISSED EVENTS 16

MANAGING WIRELESS & NETWORK

SETTINGS 17

Wi-Fi ................................................................................. 17

Bluetooth .......................................................................... 17

Data Usage ...................................................................... 18

Mobile Networks .............................................................. 18

More ................................................................................. 18

MANAGING DEVICE SETTINGS 20

Display ............................................................................. 20

Sound ............................................................................... 20

Apps ................................................................................. 21

USB Power Saving .......................................................... 22

Storage ............................................................................. 22

Battery .............................................................................. 22

Memory ............................................................................ 22

Gesture ............................................................................ 22

MANAGING PERSONAL SETTINGS 23

Home Screen Shortcuts .................................................. 23

Emergency Info ................................................................ 23

Location ........................................................................... 23

Security ............................................................................ 23

Programmable Key .......................................................... 24

Language & Input ............................................................ 24

Factory Reset ................................................................... 24

MANAGING SYSTEM SETTINGS 25

Date & Time ..................................................................... 25

Accessibility ..................................................................... 25

About Phone .................................................................... 25

MANAGING CONTACTS 26

TABLE OF CONTENTS

Adding New Contact First Time ...................................... 26

Adding a New Contact ................................................... 26

Viewing Contact Details .................................................. 26

Sending a Message from Contacts ................................ 26

Dialing a Number from Contacts..................................... 26

Editing the Contact Details .............................................. 26

Menu Options .................................................................. 26

Managing Contact Settings ............................................. 28

MANAGING CALL SETTINGS 29

Making a Call ................................................................... 29

Dialing a Number via Contact ......................................... 29

Adding a Contact from Home Screen ............................ 29

Viewing Call History ......................................................... 29

Deleting Call History ........................................................ 29

Speed Dial Settings ......................................................... 29

Call Settings ..................................................................... 29

SENDING MESSAGES 31

Sending SMS/MMS Message ........................................ 31

Managing Message Settings ........................................... 31

Deleting Messages .......................................................... 32

AT&T EPTT SERVICES 33

SONIM SCOUT 34

Setup ................................................................................ 34

Utilities .............................................................................. 34

Support ............................................................................ 34

APPLICATIONS 35

Music ................................................................................ 35

FM Radio.......................................................................... 35

File Explorer ..................................................................... 36

Backup and Restore ....................................................... 36

Downloads ....................................................................... 36

Tools................................................................................. 37

Clock ................................................................................ 37

Calculator ......................................................................... 37

Sound Recorder .............................................................. 37

OTHER APPLICATIONS 38

Camera............................................................................. 38

Calendar .......................................................................... 38

Browser ............................................................................ 38

REGULATORY INFORMATION - USA MARKET

RF Exposure Information (SAR) ...................................... 39

Federal Communication Commission Interference

Statement......................................................................... 39

FCC Caution .................................................................... 39

HAC Rating ...................................................................... 40

ISED RF Exposure Statement (IC) ................................... 40

HAZARDOUS LOCATION USAGE WARNING 41

INDEX 42

SAFETY GUIDELINES

Please read and understand the following

safety guidelines before you use the

phone. These guidelines provide details to

enable you to operate your phone safely

and conform to any legal requirements

regarding the use of cellular phones.

Do not to use the phone at a refueling

point. Observe restrictions when using

radio equipment at fuel depots, chemical

plants or where blasting operations are in

progress.

Electrical interference may obstruct the

use of your phone. Observe restrictions in

hospitals and near medical equipment.

Switch off your cellular phone when in

an aircraft. Wireless phones can cause

interference or danger to an aircraft. In an

aircraft, the phone can be used in ight

mode.

Do not expose the device to high

temperatures (in excess of 55°C).

Adhere to road safety laws. Do not hold/

use a phone while you are driving; nd a

safe place to stop rst. Use hands-free

microphone while you are driving.

Avoid using the phone in close proximity

to personal medical devices, such as

pacemakers and hearing aids.

Use only Sonim XP5800 approved

charging equipment to charge your phone

and avoid damage to your phone.

The symbol of the crossed-out wheeled

bin indicates that this product, and any

enhancements marked with this symbol,

cannot be disposed as unsorted waste but

must be taken to separate collection at

their end-of-life.

Ensure that only qualied personnel install

or repair your phone.

The Sonim XP5800 is water-proof and can

be submerged to 2 meters for 30 minutes.

Ensure that the audio connector and the

SIM slot are properly closed. This will

prevent the deposit of water droplets

on the connectors, when the phone is

immersed in water.

Water droplets may condense under the

display cover if the phone is immersed in

water with signicant drop in temperature.

This does not indicate water leakage.

The droplets will disappear at room

temperature.

The Sonim XP5800 is dust-resistant,

rugged and shock-resistant. However, it is

not dust-proof or unbreakable if subjected

to overwhelming impact. For best results

and long product life, one should protect

the Sonim XP5800 from salt water, dust

and strong impacts.

SAFETY GUIDELINES / BATTERY USAGE

AVOID HIGH TEMPERATURES

Leaving the device in hot or cold places, such as in a

closed car in summer or winter conditions, reduces the

capacity and lifetime of the battery. For the best results,

try to use the device between -20°C and +55°C (-4°F

and 131°F). A device with a hot or cold battery may

not work temporarily, even when the battery is fully

charged. Battery performance is particularly limited in

temperatures well below freezing.

PERSONAL MEDICAL DEVICES

Mobile phones may affect the operation of cardiac

pacemakers and other implanted equipment. Please

avoid placing the mobile phone over the pacemaker, for

example in your breast pocket. When using the mobile

phone, place it at the ear opposite the pacemaker. If a

minimum distance of 15 cm (6 inches) is kept between

the mobile phone and the pacemaker, the risk of

interference is limited. If you suspect that interference

is taking place, immediately turn off your mobile phone.

Contact your cardiologist for more information. For

other medical devices, consult your physician and the

manufacturer of the device. Comply with instructions to

switch off the device or deactivate the RF transmitter

when required, especially when posted in hospitals

and airplanes. Equipment used in these places may be

sensitive to radio waves emitted from the device and

adversely affect their operation. Also, observe restrictions

at gas stations or other areas with ammable atmosphere

or when close to electro-explosive devices.

CHILD SAFETY

Do not allow children to play with your mobile phone or

its accessories. Keep it out of their reach. They could hurt

themselves or others, or could accidentally damage the

mobile phone or accessories. Your mobile phone and

its accessories may contain small parts, which could be

detached and create a choking hazard.

EMERGENCY CALLS

Mobile phones operate using radio signals, which cannot

guarantee connection under all conditions. Therefore

you should never rely solely upon any mobile phone for

essential communications (e.g. medical emergencies).

Emergency calls may not be possible in all areas, on all

cellular networks, or when certain network services and/

or mobile phone features are in use. Check with your

local service provider.

WARNING

It is not allowed to connect any external

devices to all ports/interface (USB, XPand and

SecureAudio Connector) in Hazardous area.

BATTERY USAGE

Sonim XP5s phone comes with a

removable battery. For any battery

related queries, contact Sonim customer

support.

• Use only a Sonim XP5800 certied battery that is

designed for this phone model.

• The use of other batteries may void the warranty

terms of your phone and cause damage.

• It is recommended to protect the battery from

extreme temperature environments and moisture.

• Please keep the battery out of the reach of children.

INSERTING THE BATTERY

1. UNSCREW COVER

To open the battery

cover, rotate both

the battery cover

screws in a counter

clockwise direction

(as shown in the

gure). Sometimes,

the battery cover may

be tight and some

extra effort is required

to open it. You can

use the screwdriver

provided to open the

screws.

2. LIFT THE COVER

Lift the back cover to

reveal the battery slot.

BATTERY USAGE

3. INSERT BATTERY

Insert the battery

and ush into the

battery slot such that

the three metallic

contacts at the top of

the battery are aligned

with the metallic

contacts within the

battery compartment.

4. CLOSE COVER

Close the battery

cover. Rotate the

battery cover screws

in clockwise direction.

You can use the

screwdriver provided

to tighten the screws.

Ensure not to over-

tighten the screws.

CHARGING THE BATTERY

The battery delivered with your mobile phone is not fully

charged. We recommend that you charge your mobile

for 5 hours before you use your mobile phone for the rst

time.

Only the power supplies with outputs meet the

SELV requirements can be used for charging.

The maximum allowable input voltage for the

phone is 9v.

There is a risk of explosion while charging if the

battery has been replaced by an incorrect type.

If the battery is completely out of charge, it can

take several minutes for the charging icon to

appear when the charger is connected.

1. INSERT CHARGER

Insert the charger plug into a power outlet.

2. CONNECT TO THE PHONE

The charging port is located in the lower side

of the phone, below the back cover. Insert the

charger connector to the charging port.

3. CHARGING ANIMATION/ICON

• If the battery is being charged when the

phone is switched off, a battery charging

animation with current battery level is

displayed.

• If the battery is being charged while the

phone is switched on, the battery icon

on the status bar shows the animation

indicating that the battery is being

charged.

• Once the battery is fully charged, charging

animation is displayed and a pop-up is

displayed “Battery is full Please unplug

the charger”.

YOUR SIM CARD

Purchase a SIM card from a mobile operator. The SIM

card associates your network services (for example,

phone number, data services, and so on) with your

phone.

REMOVING THE BACK COVER

1. UNSCREW COVER

To open the battery

cover, rotate both the

battery cover screws

in counter clockwise

direction (as shown in

the gure).

BATTERY USAGE

2. LIFT THE COVER

Lift the back cover to

reveal the battery slot.

3. USE SONIM

SCREWDRIVER

You can use the

Sonim provided

screwdriver tool to

open the screws.

INSERTING THE SIM CARDS

1. UNSCREW COVER

Use the included

screwdriver to

unscrew the two

battery cover screws

on the back of the

phone.

2. LIFT THE COVER

Remove the battery

cover and the battery.

3. INSERT SIM CARD

Open either SIM card

tray, insert SIM card

and lock SIM card tray

into place.

INSERTING MEMORY CARD

1. SLIDE THE SILVER CLIP

Slide (push forward)

and lift the silver clip

over the designated

slot located beside

the SIM card slot. (as

shown in the gure).

2. PLACE THE

MEMORY CARD

Place the memory

card in the designated

slot and close the

silver clip. (as shown

in the gure).

3. USE SONIM

SCREWDRIVER

You can use the

Sonim provided

screwdriver tool to

open the screws.

WARNING

ONLY THE BATTERY CAN BE REPLACED in

NON-HAZARDOUS LOCATION.

VERIFYING AND OPTIMIZING BATTERY

USAGE

You can check the battery usage status and also close

some applications to save battery power. In the all

application screen, select Settings ( ) > Device >

Battery ( ).

The current battery level (charging or not charging) is

displayed on the top of the screen. The discharge graph

on the top of the screen shows the battery level over time

since you last charged the device, and how long you

have been running on battery power.

BATTERY USAGE / GETTING STARTED

The list at the bottom of the screen shows the breakdown

of battery usage for individual apps and services. Select

any listed items to view more details. The details screen

for some apps includes buttons that allow you to adjust

settings affecting power usage, or stop the application

completely.

If you stop some apps or services, your device

may not work correctly.

TIPS TO EXTEND THE BATTERY LIFE

Follow these tips to extend your phone’s battery life.

• If you are not using Wi-Fi, Bluetooth, or GPS, use

the Settings to turn them off. The GPS setting is

located in Settings > Personal > Location.

• Set screen brightness to Low and set a shorter

Sleep timeout (15 seconds). The display settings are

located in Settings > Device > Display.

• If you are travelling and do not have access to

mobile data or Wi-Fi network, switch to Airplane

mode. Select Airplane mode from Quick Settings.

GETTING STARTED

WHAT IS IN THE BOX?

The list of items in the Sonim XP5s phone box are:

• Sonim XP5s

• Battery

• Wall Charger

• USB-C Cable

• Screwdriver

• Quick Start Guide

PHONE SPECIFICATIONS

FEATURE DESCRIPTION

Chipset Qualcomm MSM8920

Band GSM: 850/900/1800/1900MHz

UMTS: I/II/IV/V/VIII

LTE: B1/B2/B3/B4/B5/B7/B8/B12/

B13/B14/B25/B26/B28/B30/B38/

B41/B66

Antenna MIMO antenna for LTE

Wi-Fi Support 802.11 a/b/g/n/ac/e/k/r/h

Support max 10 connections

hotspot

Memory 16GB eMMC 5.1/ 2GB LPDDR3

CONNECTIVITY

Bluetooth BT4.x with BLE

Languages

Supported English and Spanish

Capacity(mAh) 3180mAh, removable Li-ion

Battery Life Standby: up to 675 hours

Talk time: up to 21 hours

Music playback: up to 11 hours

Video playback: up to 8 hours

Web browsing: up to 18 hours

PHYSICAL CHARACTERISTICS

Ambient

temperature -20ºC to +55ºC

Size 141mm x 63.9 mm x 23mm

GETTING STARTED

FEATURE DESCRIPTION

Weight approx. 260 gms

Dedicated keys PTT Key/Power Key/Volume key

(Up and Down)/Speaker key/

Emergency key

Ports Water-proof USB2.0 type-C, High

Speed, OTG

DISPLAY

Size 2.64”

Resolution 320x432 Transmissive

Outdoor

Visibility Yes

Capacity 262K colors

Brightness 400

AUDIO

Microphone 3 Mics with noise cancellation

Speaker Front Dual Loud Speaker, Support

HD voice and wideband

MULTIMEDIA

Audio Formats AMR-NB, AMR-WB, AAC, AAC+,

AAC+V2, MP3,V-SELP, AMR

12.65, AMR 6.6,

Video Formats 3GP,MP4, WMV, AVI, MOV,

MPEG-2, MPEG-4,H.263, H.264,

H-265

Image Formats JPEG

Graphic

Formats JPEG, PNG, and BMP

FM Radio Yes

Camera 5MP FF Rear camera, No front

camera

LED Torch Light Yes, also used for camera ash

USING YOUR SONIM XP5s

1. Sonim XPand Connector

2. Microphones

3. USB-C

4. Volume Up / Down

5. PTT Button

6. App Tray

7. Options

8. Clear

9. Answer / Accept

10. Voicemail (Press and Hold)

11. Lock / Unlock Keypad (Press and Hold)

12. Select / Center key

13. Navigation

14. End / Reject / Power On & Off (Press and Hold)

15. Speakerphone

20 1921 29

16. Back

17. Display

18. Battery Level Indicator

19. Notication Bar

20. Receiver

21. LED Notication

22. Sonim SecureAudio Connector

23. Emergency Button

24. Charging Pins

25. Battery Under Door

26. SIM Card Slots Under Battery

27. Memory Card Slot Under Battery

28. Battery Door

29. Rear Flash

30. Rear Facing Camera

USING YOUR SONIM XP5s

SWITCHING ON THE PHONE

Press and hold ON/OFF Red button for 2 seconds.

When the phone is switched on, it tries to register with

the network. After successful registration, the name of the

service provider is displayed.

Ensure that a valid SIM card is inserted in your

phone.

SETTING UP YOUR PHONE

For instructions on using your phone’s buttons, charger,

battery, and other hardware features, check the printed

Quick Start Guide provided along with your phone.

When you power ON the phone for the rst time, a

Welcome screen is displayed.

To set up your phone, select Start and follow the

instructions as shown on the screen.

Press OK on welcome guide to a use the phone.

MANAGING HOME SCREEN

After you complete the phone setup, the home screen

is displayed. The home screen is the beginning point to

access all the device’s features.

1. Alert

Notications

2. Service

Indicator

and Signal

Strength bar

3. Battery

charge

indicator

4. Home

screen

KEY DESCRIPTION

The navigation keys are located below the display screen.

KEYS DESCRIPTION

Back:

Opens the previous screens in the working

sequence till the home screen is displayed.

Once the home screen is displayed, it

remains there even when you press the

back key.

Menu:

• Always positioned in the center of

the keypad. Select to view all the

applications and device settings.

• Long press (for 2 seconds) to enable

torch light.

• Double press in unlock condition to

launch Recent screen.

Options:

Displays the options for the currently active

screen.

Clear:

Clears the entered text and deletes the

selected le.

Speaker:

You can place the call on speaker and the

icon is enabled only when call is on the

speaker.

For better result in a nosiy environment,

hold the device 10-15 cm away from your

mouth while speaking on a speaker mode.

The Notications on the top of the display screen

provides details about various notications such as

missed calls, new messages and missed alarms.

The System Icons on the top right side of the screen

display the current device status such as wireless and

network connection strength and battery level.

USING YOUR SONIM XP5s

NOTIFICATION BAR ICONS

The icons displayed at the top of the screen provides

information about the status of the device. The details

such as battery charge status and data service are

displayed when the phone is in standby mode. Other

indicators such as Bluetooth connectivity status, airplane

mode, alarm and call forward (only if Always forward

is enabled) and Wi-Fi connectivity are displayed, if the

feature is activated.

ICONS DESCRIPTION

Notication icon

Battery level indicator

Battery charging in progress

No signal

Signal strength

No SIM card

4G LTE network connected

Wi-Fi connected

Bluetooth activated

Call in progress

Speaker icon

FM Radio

Missed call

New SMS or MMS

Alarm activated

Silent mode activated

Vibration mode activated

ICONS DESCRIPTION

Headset connected

Missed Events notitifcation

Flight mode activated

Error/information notication - attention

required

Screenshot captured

Music is played

Device storage space is running out

Warranty Registration icon

PTT Available status icon

PTT Ofine status icon

PTT Do Not Disturb icon

PHONE OPERATIONS WITHOUT SIM CARD

You can perform the following operations without

inserting a SIM card in your phone.

• Make an emergency call.

• View and modify all settings except few data usage

and mobile network related settings.

• Activate and share les through Bluetooth.

• Access the Internet using Wi-Fi conectivity.

• Access your phonebook, File explorer multimedia

les, all tools and applications.

• View and modify your prole settings.

CAPTURING A SCREENSHOT

You can take the screenshot of the current screen and it

is stored in your phone’s gallery. To take a screenshot:

1. Ensure that the image to be captured is displayed on

the current screen.

2. Press the Power and Volume down button

simultaneously. The screenshot is captured and

stored in the gallery. A screen Capture ( )

USING YOUR SONIM XP5s

icon is also displayed on the notication bar.

TO CHANGE THE MESSAGE LANGUAGE

While entering the text message or saving the contacts,

you can change the message language by press and

hold the * key.

You can change the Language from English to Español

and vice versa.

TEXT ENTRY OPTIONS

When you enter the text message, you can change the

text entry options by pressing the # key. The current text

entry options are displayed in the top bar.

The various text entry options are:

• For English:

• ABC: Enter all the text in upper case.

• Abc: Enter the rst letter of the sentence in upper

case.

• abc: Enter all the text in lower case.

• 123: Enter the numbers.

• For Espanol:

• ESABC: Enter all the test in upper case

(capitalized).

• ESabc: Enter all the text in lower case.

• ESAbc: Enter the rst letter of the sentence in

upper case.

• 123: Enter the numbers.

TO ENTER A WORD

1. Start by pressing the numeric keys from 2 through 9

only once for the required letter.

• Ex 1: To enter the word Good, press 4-6-6-3. The

word displays on the screen as you type.

• Ex 2: To enter the word Hello, press 4-3-5-5-6.

The word displays on the screen as you type.

2. If the word does not display correctly, press right

navigation key to scroll through alternative word

choices. Press either the center navigation key or

0 key to accept the word.

TO INSERT A NUMBER

1. Press the key labeled with the number you want and

use the navigation key to scroll to that number as

above.

2. To insert a symbol, press and hold the numeric

key 1 and use the navigation key to scroll and

select a symbol.

DIFFERENT METHODS TO ENTER TEXT

When English is selected as input language:

• T9ABC: Enter the text based on the T9 dictionary.

All the letters are in upper case (capitalized).

• T9Abc: Enter the text based on the T9 dictionary.

Only the rst letter of the sentence is in upper case

(capitalized).

• T9abc: Enter the text based on the T9 dictionary. All

the letters are in lower case.

When Espanol is selected as input language:

• T9ESABC: Enter the text based on the T9

dictionary. All the letters is in upper case

(capitalized).

• T9ESAbc: Enter the text based on the T9 dictionary.

Only the rst letter of the sentence is in upper case

(capitalized).

• T9ESabc: Enter the text based on the T9 dictionary.

All the letters are in lower case.

CONTENT HOME SCREEN MENU OPTIONS

HOME SCREEN MENU OPTIONS

In order to see the details about any notications, on the

home screen, select Options key.

The following options are displayed:

• My Notications

• Wallpaper

• Search

• Home screen shortcuts

• System settings

• Manage apps

MY NOTIFICATIONS

The left-hand top on your device is where your

applications and message services can drop you a note

that there is something new to look at, e.g. missed calls,

new messages and downloads.

WALLPAPER

You can set an image or a photo stored in your phone as

your home screen wallpaper.

To change the wallpaper, select from one of the following

Wallpaper collections.

From Home screen, press Options key > Wallpaper.

Select Wallpapers from the popup.

• Gallery: includes photos and screenshots taken

using the phone’s camera.

• Wallpapers: includes images that are pre-loaded

with the phone.

You can search for people, places, music, movies, history

and many more. Enter the key word in the search bar and

the list is displayed.

HOME SCREEN SHORTCUTS

The navigation Up, Center and Down keys are

displayed.

For more information, refer to “home screen shortcuts”

on page 23.

SYSTEM SETTINGS

System settings refers to the following settings:

• “Managing wireless & network settings” on page

• “Managing device Settings” on page 20

• “Managing personal settings” on page 23

• “Managing system Settings” on page 25

MANAGE APPS

You can manage application and force stop them.

For more information, refer to “APPs” on page 21.

CONTENT QUICK SETTINGS/MISSED EVENTS

QUICK SETTINGS

In order to see the quick settings, on the home screen,

select Left Navigation key.

The following settings are displayed:

• Wi-Fi

• Bluetooth

• Torch

• Airplane mode

• Proles

These settings can be enabled or disabled.

WI-FI

You can enable or disable Wi-Fi settings. For more

information, refer to “wi-” on page 17.

BLUETOOTH

You can toggle between ON and OFF. For more

information, refer to “BLUETOOTH” on page 17.

TORCH

You can set the Torch ON and OFF.

AIRPLANE MODE

Toggle the button to enable or disable the airplane mode.

For more information, refer to “ACTIVATING AIRPLANE

MODE” on page 18.

PROFILES

You can select the prole from the list:

• Standard

• Outdoor

• Silence

• Meeting

For more information, refer to “sound” on page 20.

MISSED EVENTS

To view the missed events, on the home screen, select

Right navigation key.

Missed events are the missed calls or any events which

were saved earlier on the device are listed as missed

events.

The missed events can be;

• Missed calls: When you miss a call to receive, you

get a event notication.

• Calendar events: When you have saved an event

like birthday, travel etc, and you missed that event

on that particular day, a message is displayed in

missed events.

• New messages: The unread messages are

displayed in missed events.

• Alarm: A missed alarm is displayed in missed

events.

• New Voicemail: A new voice mail is displayed in

missed events.

MANAGING WIRELESS & NETWORK SETTINGS

MANAGING WIRELESS & NETWORK

SETTINGS

WI-FI

Wi-Fi is a wireless network technology that can provide

Internet access at distance up to 100 feet, depending on

the Wi-Fi router and surroundings.

You can access Internet when you connect your XP5s

to a Wi-Fi network. To connect your phone to a Wi-Fi

network;

1. From Home screen, select Menu ( ) > Settings

( ).

2. Set the Wi-Fi to ON position located under

Wireless & networks settings.

3. Select Wi-Fi.

A list of Wi-Fi access points present within your

phone’s accessible range are displayed.

4. Select your preferred network. Enter the WEP/

WPS/WPA key (if it is a secured network) and

select Connect. To verify the password before

connecting, enable Show password.

It is always recommended to make your

Wi-Fi network connection secure and also to

connect your phone to a secure network.

ADD NETWORK

1. In Wi-Fi settings screen, select Options key > Add

network.

2. Enter the following details:

• Network SSID: The wireless network ID.

• Security: Set the security type to None, WEP,

WPA/WPA2 PSK, 802.1x EAP.

3. Enable Advanced options to set the Proxy details

and IP settings.

4. Select Save to save the network settings.

CONNECT TO A NETWORK

1. Press center key on any of the listed network.

2. Enter the password on the prompted window and

get connected to the network.

EDIT A NETWORK

1. Press and hold the connected network.

2. Select Modify network. You can change the

network password. The other network setting

details such as Advanced options, Proxy, IP

settings can be updated.

3. Select Save to save the changes.

FORGET A NETWORK

1. Press and hold the connected network.

2. Select Forget network.

The selected network gets disconnected and

displayed in the Wi-Fi list.

If you have to get connected to the same network,

enter password.

ADVANCED WI-FI

On the Wi-Fi screen, select Option key > Advanced. The

following options are displayed:

• Auto connect attwi: Check this option to auto

connect to the AT&T’s Wi-Fi network.

• Install certicates: You can browse a certicate for

installation.

• Passpoint on: You can enable the option.The

device prefers Passpoint network over all open

networks including attwi and att-wi SSIDs. If one

open network and attwi network are available, the

device gives preference to attwi network.

• Wi-Fi Direct: Select Option key > Searching to

search for the peer devices and also select Rename

device to rename the device.

• WPS Push Button: Press the WPS Push Button in

your router, when prompted.

• WPS Pin Entry: Enter the given PIN number on your

Wi-Fi router.

BLUETOOTH

Bluetooth is a short-range wireless communication

technology used to communicate between the devices

over a distance of about 8 meters.

You can perform the following tasks using Bluetooth

paired devices.

• Transfer media les and contacts between

connected mobile devices using Bluetooth.

• Use Bluetooth connected headphones for playing

media le.

• Bluetooth headset can be used during call.

MANAGING WIRELESS & NETWORK SETTINGS

PAIRING A BLUETOOTH DEVICE

To activate Bluetooth and pair your XP5s phone with

other Bluetooth devices:

1. From Home screen, select Menu ( ) > Settings

( ).

2. Enable Bluetooth ( ), located under Wireless &

Networks settings.

A list of accessible Bluetooth devices are displayed.

Ensure that Bluetooth is activated on the other device

too.

3. Select your preferred device.

4. To pair with the selected Bluetooth device, select

Pair in your device. Compare the pairing codes

between your device and the other device.

The device is displayed in the Paired devices list.

EDITING PAIRED BLUETOOTH DEVICE SETTINGS

1. Select Option key on preferred paired Bluetooth

device.

2. Select Rename this device to rename the paired

Bluetooth device.

3. To unpair the device, select the paired device.

Select Forget to unpair the deivce and Connect

to reconnect with the device.

4. Enable Media Audio to connect the Bluetooth

device for listening to media les.

DATA USAGE

Data usage refers to the amount of data utilized by your

phone during data transfers through the Internet. The

data usage charges are dependent of the wireless plan

provided by your service provider.

To monitor your data usage, adjust your data usage

settings.

1. From Home screen, select Menu ( ) > Settings

( ).

2. Select Wireless & networks > Data usage ( ).

3. Press Option key > Cellular networks to access

Standard data option.

4. Usage: You can see the details about the data

usage for a particular time frame.

• Data saver: Enable Data saver to reduce data

usage. Data Saver prevents some apps from

sending or receiving data in the background.

5. The following options are present in Cellular.

• Cellular data usage: Displays the data usage for a

particular time frame.

• Billing cycle: Billing of the used data is displayed

here.

• You can enable the Set data warning to get

the warning message when your data usage is

crossed the preset limits.

• Data warning shows the data available for a

particular time frame.

• Enable Set data limit to set the data usage limit.

6. Select Wi-Fi > Wi-Fi data usage. When Wi-Fi is

enabled, it shows the data used for a particular

time frame.

• Network restrictions: The background data is

restricted for these networks. While downloading

apps, you receive a warning message for these

restricted networks.

MOBILE NETWORKS

You can view and set your mobile service provider

settings.

1. From Home screen, select Menu ( ) > Settings

( ).

2. Select Wireless & networks > Mobile networks

( ).

3. Enable Mobile Data > Standard Data.

You can use mobile data services such as web

browsing and other services over the cellular

network.

4. Enable International Data Roaming >

International Data to have a network connectivity

when you are in a roaming network out of your

country.

5. Enable Enhanced LTE Services.

You can use advanced communication services

where ever it is available.

6. Select Cellular Network > cellular network

settings to add /edit APN settings.

ACTIVATING AIRPLANE MODE

When your phone is set in airplane mode, network

connectivity or mobile data connectivity is disabled.

But you can access your camera, media les and other

features that do not require mobile connectivity.

To activate airplane mode:

1. From Home screen, select Menu ( ) > Settings

( ).

• Select More located under Wireless & networks

settings.

2. Enable Airplane mode.

MANAGING WIRELESS & NETWORK SETTINGS

TETHERING & PORTABLE HOTSPOT

You can share your device’s mobile data connection via

USB / mobile hotspot / Bluetooth.

1. From Home screen, select Menu ( ) > Settings

( ).

2. Select Wireless & network > More > Tethering

& portable hotspot.

3. Enable USB tethering. This is enabled only when

USB is connected to the device.

4. Portable Wi-Fi hotspot: Enable Portable Wi-Fi

hotspot.

• Set up Wi-Fi hotspot: You can set up a Wi-Fi

hotspot by entering the following details:

• Network name: Enter the network name.

• Security: Select the security from the drop-down

list.

• Password: The password must have at least 8

characters.

• Maximum Connections: The maximum number

of devices which can be connected to the Wi-Fi

hotspot are ten.

• Wi-Fi Hotspot Power Mode: You can select one of

the options:

• Auto disable Mobile Hotspot after 5 minutes of

inactivity

• Auto disable Mobile Hotspot after 10 mintuets of

inactivity

• Do not disable Mobile Hotspot due to inactivity

• Connected Devices: The devices which are

connected to the Hotspot are displayed here.

5. Enable Bluetooth tethering. When you activate

Bluetooth tethering, you can share your phone’s

Internet connection with other Bluetooth paired

devices.

VPN

1. From Home screen, select Menu ( ) > Settings

( ).

2. Select Wireless & Networks > More > VPN.

3. Select Options key > Add VPN prole.

A conrmation window is displayed with the message

You need to set a lock screen PIN or password

before you can use credential storage. Select OK

to set the lock selection.

4. In Edit VPN prole screen, enter the Name, Type

(select from the drop-down list), and the server

address.

5. Enter Username and password.

6. Select Save.

NETWORK SETTINGS RESET

1. From Home screen, select Menu ( ) > Settings

( ).

2. Select Wireless & Networks > More > Network

settings reset.

3. Select RESET SETTINGS.

It reset all the network settings including Wi-Fi,

Cellular data, and Bluetooth.

MANAGING DEVICE SETTINGS

DISPLAY

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Display ( ).

2. Set one of the following options to congure your

phone’s display:

• Brightness level: Set the brightness of the phone

display. This also optimizes the battery power

consumed.

• Wallpaper: Set the wallpaper for your home screen.

You can select from one of the following wallpaper

collections:

• Gallery: includes photos and screenshots taken

using the phone’s camera.

• Wallpapers: includes images that are pre-loaded

with the phone.

• Sleep: Set the sleep time so that the screen

brightness is turned down after specied time of

phone inactivity. This setting also optimizes the

battery power.

• Font size: Set the font size of the text displayed in

the screen.

SOUND

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Sound ( ).

2. Select Prole and the following options are

displayed:

OPTION DESCRIPTION

1. Standard

Set to Standard and select

Option key > Edit.

The following options are

displayed:

Sound

• You can set Media volume,

Ring volume, Alarm

volume, Phone ringtone,

Default notication

ringtone.

• You can enable the Vibrate

when ringing.

Other Sounds

You can set Screen lock

sounds, Charging sounds, and

key press tones.

OPTION DESCRIPTION

Notication

• If Pulse LED light is

enabled, battery status

indication is not affected.

• If Flash notication alert is

enabled, when battery is

above 20% level, you can

use camera ash light for

missed events.

• If Flash call alert is enabled,

you can use Flash camera

light for incoming voice

call.

2. Outdoor

Set to Outdoor and select

Option key > Edit.

The following options are

displayed:

Sound

• You can set Media volume,

Ring volume, Alarm

volume, Phone ringtone,

Default notication

ringtone.

• You can enable the Vibrate

when ringing.

Other Sounds

You can set Screen lock

sounds, Charging sounds, and

key press tones.

Notication

• If Pulse LED light is

enabled, battery status

indication is not affected.

• If Flash notication alert is

enabled, when battery is

above 20% level, you can

use camera ash light for

missed events.

• If Flash call alert is enabled,

you can use Flash camera

light for incoming voice

call.

3. Silence

Set to Silence and select

Option key > Edit.

The following options are

displayed:

MANAGING DEVICE SETTINGS

OPTION DESCRIPTION

Sound

When set to Silence mode,

this prole blocks all sounds

and vibrations including alarms,

videos, and games. You will be

able to make phone calls.

Notication

• If Pulse LED light is

enabled, battery status

indication is not affected.

• If Flash notication alert is

enabled, when battery is

above 20% level, you can

use camera ash light for

missed events.

• If Flash call alert is enabled,

you can use Flash camera

light for incoming voice call.

4. Meeting

Set to Meeting and select

Option key > Edit.

The following options are

displayed:

Sound You can set Media volume, and

Alarm volume.

Apart from default proles, user can create

customized proles.

To create a new prole,

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Sound ( ).

2. Select Proles > Option key > Create new.

3. Enter the required prole name.

Maximum length of 24 characters is allowed for the

prole name and the name should be unique.

4. After modifying the necessary sound and

notication settings, save the new prole.

QUICK PROFILE SWITCH

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Sound > Prole ( ).

2. Select Quick Prole Switch.

You can use this option to quickly switch proles via

home screen shortcut and Speaker key.

SOUND

• Media Volume: You can increase, decrease, and

mute media volume.

• Alarm volume: You can increase, decrease or mute

the alarm volume.

• Ring volume: You can change the ringer volume to

no ringer or ringing.

• Also vibrate for calls: Enable this option to set the

device on vibration for calls.

• Phone ringtone: You can select the required

ringtone from the list.

• Default notication ringtone: Set the default

notication ringtone from the list.

OTHER SOUNDS

• Screen lock sounds: Enable or disable this option.

• Charging sounds: Enable or disable this option.

• Key press tones: Enable or disable this option.

NOTIFICATION

• Pulse LED light: If Pulse LED light is enabled, Pulse

LED light is used to display notication alert and the

battery status indication is not affected.

• Flash notication alert: If Flash notication alert is

enabled, when battery is above 20% level, you can

use camera ash light for missed events.

• Flash call alert: If Flash call alert is enabled, you

can use Flash camera light for incoming voice call.

VOICE NOISE CANCELLATION

By default, FENS is enabled and reduces the noise

cancellation.

APPS

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Apps ( ).

2. Select All apps drop-down list. You can select

any of the following options:

• All apps

• Enabled

• Disabled

3. Select the required app from the list. Open the

app and select FORCE STOP.

4. Select the app and press Options key. The

following options are displayed:

• Advanced

• Show system

• Reset app preferences

MANAGING DEVICE SETTINGS

USB POWER SAVING

1. From Home screen, select Menu ( ) > Settings

( ) > Device > USB Power Saving ( ).

2. Automatic Power ON: If enabled, the device

gets automatically power ON when the USB is

connected.

3. Automatic Power OFF:

• Automatic Power OFF: If enabled, the device

gets automatically power OFF when the USB is

connected at set time.

• Power off device at: If you enable Automatic

power off, this option will be active. You can set

the time frame for the device to be powered off.

• Automatic power OFF: If this is enabled, upon

USB disconnection, the device is power off after

the set hours.

• On USB disconnect, power off: You can set the

hours for the device to be powered off once the

USB is disconnected.

STORAGE

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Storage ( ).

2. On Internal shared storage, the following options

are displayed with memory used for each app:

• Shows the used memory

• Apps

• Images

• Videos

• Audio

• System

• Other

• Cached data

• Explore

BATTERY

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Battery ( ).

2. Set the Battery saver ON by selecting the option

given for Turn on automatically:

• Never

• at 5% battery

• at 15% battery

Battery saver turns off automatically when

your device is charging.

You can also view the battery usage data.

MEMORY

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Memory ( ).

2. Go to Memory and select the time from the drop-

down list. You can view the applications usage

based on the set time frame.

3. Select Memory used by apps to check the

memory used for each application for the set time

frame.

GESTURE

1. From Home screen, select Menu ( ) > Settings

( ) > Device > Gesture ( ).

2. Enable Toggle Torch.

3. To quickly toggle torch, shake the device twice.

MANAGING PERSONAL SETTINGS

HOME SCREEN SHORTCUTS

You can set the shortcuts on the home screen.

1. From Home screen, select Menu ( ) > Settings

( ) > Personal.

2. Select Home screen shortcuts ( ).

3. Go to the Navigation up key and selct the app to

be set for the up key navigation.

4. Go to the Navigation center key and selct the

app to be set for the center key navigation.

5. Go to the Navigation down key and selct the app

to be set for the down key navigation.

EMERGENCY INFO

You can enter the emergency information to be viewed

during an emergency.

1. From Home screen, select Menu ( ) > Settings

( ) > Personal.

2. Select Emergency Info ( ).

3. Go to My information and enter the following

details:

• First name

• Last name

• Phone number

• Email address

• Address

• Blood type

• Allergies

• Medication

• Organ donor

4. If you do not want to enter any of the above

details, select Skip.

5. The Add screen is displayed and you can select

the contact from the phonebook by selecting

Select contact.

6. Select Add new. Enter First name, Last name,

and Phone number. Select Add.

This contact is added under Emergency contacts list.

LOCATION

You can enable and congure the Location settings.

1. From Home screen, select Menu ( ) > Settings

( ) > Personal.

2. Select Location ( ). Enable and modify

required security settings.

3. Set the Location Mode to one of the following

options:

• High accuracy: uses AGPS, Wi-Fi, mobile

networks, and other sensors to get the highest-

accuracy location for your device. It uses location

help to estimate your location faster and more

accurately.

• Battery saving: allows your device to estimate

your location using low battery-intensive location

sources, such as Wi-Fi and mobile networks. It

uses location help to estimate your location faster

and more accurately.

• Device only: allows your device to estimate

your location using GPS only. It uses the satellite

information to provide location information. This

mode may use more battery power and take

longer time to determine your location.

4. You can also view the apps which have requested

location recently under Recent location

requests.

SECURITY

You can activate and protect your phone from

unauthorized access by conguring the security settings.

1. From Home screen, select Menu ( ) > Settings

( ) > Personal.

2. Select Security ( ).

3. Select Device security > Screen lock and select

one of the following options to congure the

phone:

• None

• Press and hold * key

• PIN: When enabled, enter you own PIN value. When

the phone is locked, unlock it using the PIN.

When the phone is locked, you can answer an

incoming call, without unlocking the phone.

4. Encryption: By default, the phone is already

encrypted.

5. SIM card lock: Select Set up SIM card lock to

view the SIM settings.

• Lock SIM card: You can set a PIN to use the

phone.

• Change SIM PIN: You can change the SIM PIN.

MANAGING PERSONAL SETTINGS

6. Enable Make password visible option to view the

password characters.

7. Device administration:

• Device administrators: You can view or deactivate

the device administrator.

• Unknown sources: When enabled, it allows

installing the apps from unknown sources.

8. Credential storage:

• Storage type: Displays the storage type.

• Trusted credentials: You can view and verify the

system and user certicates.

• Install from SD card: You can view and install new

user certicates from SD card.

• Clear credentials: You can remove all certicates.

9. Advanced:

• Trust agents: To use this option, a screen lock

should be set.

• Apps with usage access: Select the app and

select center key to enable/disable the Permit

usage access.

PROGRAMMABLE KEY

You can asisign any application to the programmable

key.

1. From Home screen, select Menu ( ) > Settings

( ) > Personal.

2. Select Programmable key ( ).

LANGUAGE & INPUT

You can set the phone’s language to any of the

languages displayed in the language list.

1. From Home screen, select Menu ( ) > Settings

( ) > Personal.

2. Select Langauage & input ( ).

3. Go to Languages and select any language from

the list as your preferred language.

The following languages can be set as a preferred

language:

• English

• Español

All the menu items and user feedback messages will

get displayed in the set language.

4. Select Keyboard & input methods > FlexT9 Text

Input.

• Input languages: You can set the input language to

either English or Español.

• Personal Dictionary: The default keyboard input

language is set to English (US)/Spanish (US) - T9

format. This cannot be modied. You can add a

custom word to the personal dictionary.

• Preferences:

• Auto-capitalization: The rst letter of the new

sentence is automatically capitalized.

• Auto-punctuation: If this option is enabled, when

you press the space key twice at the end of the

word to insert a period.

• Language switch key: Press and hold the * key

to switch the language.

• Next Word Prediction: Predicts a next word

based on the previous word entered.

• Suggest contact names: Displays suggested

contact while typing.

5. Select Support > FlexT9 Help. It displays FlexT9

help guide.

Select Support > About. It displays the FlexT9

version details.

6. Select Speech > Text-to-speech output. You

can set and reset the Speech rate and Speech

Pitch.

FACTORY RESET

You can erase all the data from your phone’s internal

storage.

1. From Home screen, select Menu ( ) > Settings (

) > Personal.

2. Select Fatory Reset ( ).

3. You can erase all data from your phone’s internal

storage which includes;

• System and app data and settings

• Downloaded apps

• Music

• Photos

• Other user data

MANAGING SYSTEM SETTINGS

• High contrast text: If this option is enabled, you

can see the text changes into the contrast colors.

• Mono Audio: Enable Mono audio to combine the

channels when playing audio.

• Vibrate on Keypress: If this option is enabled, on

each key press, the device is vibrated.

• Sound balance: You can adjust the left and right

volume balance.

• Text-to-speech output:

• Preferred engine: The preferred engine is set.

• General: You can adjust the Speech rate and

Pitch. Reset the speech rate and speech pitch.

You can demonstrate a speech synthesis. English

is set as default language status.

ABOUT PHONE

1. From Home screen, select Menu ( ) > Settings

( ) > System.

2. Select About phone ( ).

3. Go to AT&T Software Update and Check

for Updates. If there are any updates, it starts

updating.

4. The following information is displayed:

• AT&T Software Update

• Status

• Legal Information

• Model

• Firmware version

• Firmware security patch level

• Baseband version

• Kernel version

• Build number

MANAGING SYSTEM SETTINGS

DATE & TIME

You can set and display the date and time on the phone.

You can also select the display format.

1. From Home screen, select Menu ( ) > Settings

( ) > System.

2. Select Date & time ( ).

3. Select the following options to congure phone:

• To synchronize the date and time with the network

provided time, enable Automatic date & time.

• To synchronize the time zone with the network

provided time, enable Automatic time zone.

• To set the date manually, select Set date. Scroll and

select the date, month and year. Select OK.

• To set the time manually, select Set time. Scroll and

select the hour and minute. Select OK.

• To set the time zone, select Select time zone.

Scroll and select your time zone.

• To set the clock to 24-hour format enable Use

24-hour format. By default, the phone is set to

12-hour format.

ACCESSIBILITY

You can make websites and applications more

accessible to people with disabilities when they are using

mobile phones and other devices.

1. From Home screen, select Menu ( ) > Settings

( ) > System.

2. Select Accessibility ( ).

3. Select Services.

• SCOUT by AetherPal: Enable the privacy feature

of Remote Management Service by moving the

toggle to ON.

• Talkback: When Talkback is enabled, it helps

vision-impaired users interact with their devices.

It uses spoken word, vibration and other audible

feedback to let you know what is on your screen.

4. Select System.

• Captions: When Captions is ON, you can set the

following options under Standard options:

• Language

• Text size

• Caption style

• Font size: You can set the font size from smaller to

bigger and see the preview of the same.

MANAGING CONTACTS

You can use the phonebook to maintain

phone numbers of your contacts. This

feature enables you to add, dial phone

numbers and send SMS and MMS

messages.

To access the contacts, from Home screen, select

Contacts ( ). The contacts saved in the phonebook

are displayed.

ADDING NEW CONTACT FIRST TIME

After inserting the SIM, when you switch ON the device

for the rst time and there are no contacts added in the

device or SIM.

You have only two options here:

• Add Contact: Add New contact screen is

displayed. Enter all the details and select Options

key > Save to save the contact.

• Import Contacts: Select Import Contact to import

from .vcf le or import from SIM card.

ADDING A NEW CONTACT

1. From Home screen, select Menu ( ) > Contacts

( ).

2. To add a new contact, select Menu > Contacts

> Option key > Add contact. Enter the contact

details and select Option key > Save to save the

contact.

3. You can also enter a number using dialpad and

select Add to contact ( ) and then Create

new contact ( ) to add a new contact. Select

Option key > Save to save the contact.

VIEWING CONTACT DETAILS

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Scroll to the required contact and select the

contact to view the contact details.

SENDING A MESSAGE FROM CONTACTS

You can send SMS and MMS messages to the contacts.

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Scroll to the required contact and open it.

3. Select Option key > Send message.

4. Enter the message and select Option key >

Attach photos/videos to attach the photos and

videos.

5. Select Option key > Send.

If you attach a media le or a contact to your

SMS message it is converted to an MMS

message automatically.

DIALING A NUMBER FROM CONTACTS

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Scroll to the required contact and select the

contact to view the details.

3. Select the number and press Center key to

initiate the call. OR

4. Select the required contact from the list and press

the green button on the phone to initiate the call.

EDITING THE CONTACT DETAILS

1. From Home screen, select Contacts ( ).

2. Scroll to the required contact and select the

contact to view the details.

3. Select Option key > Edit.

4. Edit the required details. Select Option key >

Save to save the details.

MENU OPTIONS

On the Contacts screen, select Options key to view the

menu options. Following are the menu options:

ME:

1. Select Me and a screen is displayed to add device

owner’s name, Phone number and an email id. Select

Option key > Save to save the contact details.

If contact details of ME are not saved, the

Menu options are not displayed.

• Select Option key and you have the following

options:

• Send message: You can select either email or the

phone number to send a message.

• Edit: You can edit the contact details.

• Share: You can share your contact details via

Messaging and Bluetooth.The contact is shared

as .vcf le.

MANAGING CONTACTS

• Copy to SIM: You can copy the contact from the

device to SIM.

• Send Contact: The contact is sent as a text

message to the selected contact.

ADD CONTACT

You can add a new contact by entering all the details.

Select Options key > Save to save the contact.

IMPORT/EXPORT

IMPORT FROM .VCF FILE

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Select Option key > Import/export.

3. Selcet Import from .vcf le.

4. Press Center key to select the .vcf le to be

imported.

5. Select OK.

The contact is imported to the list.

If the device has only one vcf le, it is

imported without any selection window.

IMPORT FROM SIM CARD

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Select Option key > Import/export.

3. Select Import from SIM card.

The list of contacts stored in your SIM card are

displayed.

4. Select the contact to be moved to the phone.

5. Select Option key > Done.

6. A conrmation message is displayed. Select OK

to conrm.

The contact is imported to the phone address

book.

EXPORT TO SIM CARD

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Select Option key > Import/export.

3. Select Export to SIM card.

4. Select the contact to be exported from Phone to

SIM card.

5. Select Option key > Done.

The contact is exported to the SIM card.

EXPORT TO .VCF FILE

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Select Option key > Import/export.

3. Select Export to .vcf le.

4. Press Center key to select the contact to be

exported.

5. Select Option key > Done.

A message is displayed for the location, where the

.vcf le saved.

6. Select OK to conrm.

The .vcf le is exported to the device internal

memory.

SHARE ALL CONTACTS

You can send contact information in two different ways:

1. From Home screen, select Menu ( ) > Contacts

( )

2. Select Option key > Import/export.

3. Select Share all contacts. You can use one of the

following options to share the required contact:

• Messaging: Send the contact details as a

multimedia message to any mobile phone.

• Bluetooth: Send the contact details to a

Bluetooth device paired with your phone. Select a

Bluetooth device to share the contact.

BLOCKED NUMBERS

You cannot receive either a call or a text message from

the blocked number.

SELECT

You can select the required contacts by checking the

boxes next to the contact.

MANAGING CONTACTS

SETTINGS

You can set the sort list to view the contacts and also the

rst or last name of the contact to be displayed rst.

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Select Options key > Settings. Set the following

options:

• Sort by: Sort the contact names by rst name or

last name.

• Name format: Set the contact display name to

rst name or last name.

MANAGING CONTACT SETTINGS

You can edit and modify ringtone and call receiving

settings for individual contacts.

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Scroll to the required contact and select the

contact to view the contact details.

3. Select Options key and select one of the

following:

• Set Ringtone to set a specic ringtone for that

contact.

• Check the option All calls to voicemail to forward

all incoming calls from that contact to your voice-

mail box.

DELETING A CONTACT

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Scroll to the required contact and select the

contact to view the contact details.

3. Select Options key > Delete or press Clear ( )

key. The contact is deleted after the conrmation.

MANAGING CALL SETTINGSThe selected call log is deleted.

MANAGING CALL SETTINGS

MAKING A CALL

• Press Green key ( ) or select Menu > Phone and

the Call history can be viewed.

The phone screen with last dialed number, missed

calls and received calls are displayed.

• From home screen, you can enter the number and

initiate a call.

DIALING A NUMBER VIA CONTACT

1. From Home screen, select Menu ( ) > Contacts

( ).

2. Scroll to the contact and select the contact. The

contact details are displayed.

3. Select the required phone number to call the

contact.

ADDING A CONTACT FROM HOME SCREEN

1. From Home screen, enter the required number to be

dialed.

2. Select Add to contact ( )

3. Select Create new contact ( ).

4. In the Add new contact screen, add the name

and other details for the contact.

5. Select Option key > Save.

The contact is saved.

VIEWING CALL HISTORY

1. Press Green key ( ) or from Home screen, select

Menu > Phone ( ).

2. The Recent calls screen displayed with recently

called, received, and missed calls.

DELETING CALL HISTORY

1. Press Green key ( ) or from Home screen, select

Menu > Phone ( ).

2. On the Recent calls screen, select Option key >

Delete selected call log.

Press Clear ( ) key on the keyboard to delete the

selected call log.

3. A conrmation message is displayed to delete the

selected call log. Select Delete to delete the call

log. The selected call log is deleted.

SPEED DIAL SETTINGS

With this option, the user can assign a contact to each

key present in the keypad (2 to 9).

To set the speed dial,

1. Press Green key ( ) or from Home screen, select

Menu > Phone ( ).

2. On Recent calls screen, select Option key >

Speed dial settings.

3. Assign a contact for each key present in the

keypad (2 to 9) and Key 1 is used for voicemail.

4. Long press a particular numeric key to initiate a

call to the assigned contact.

CALL SETTINGS

To view and modify call settings,

1. Press Green key ( ) or from Home screen, select

Menu > Phone ( ).

2. On Recent calls screen, select Option key > Call

settings. Different settings are:

QUICK RESPONSES

When you are not able to answer an incoming call, you

can send a quick response to the caller. To view and

edit quick responses, select Call settings > Quick

responses. Select the specic response message to

edit. Edit the message and select OK.

CALLS

I. Calling Accounts:

SIP SETTINGS

• SIP Accounts:

To add a SIP account and congure your incoming and

outgoing preferences:

1. In the Call settings screen, select Calling accounts

> SIP accounts.

2. Enable Receive incoming calls to answer

incoming Internet calls.

This might reduce your phone’s battery life.

3. Select Option key > Add account to congure a

new SIP account.

4. Enter the following details and select Option key

> Save to save the account:

• Username: Username to login to SIP account.

MANAGING CALL SETTINGS

SETTINGS DESCRIPTION

When

unreachable

Forward calls when your phone is

switched off or is out of coverage area.

V. Additional Settings:

• Caller ID: You can choose Network default, Hide

number, or Show number.

• Call waiting: When call waiting is enabled and the

phone is in conversation, the incoming number is

displayed when you receive a call. To activate call

waiting in the Call settings screen, select Additional

settings. Enable Call waiting.

CALL BLOCKING

You will not receive calls or messages from the blocked

numbers.

ACCESSIBILITY

If you enable TTY mode, hearing-impaired individuals can

send and receive phone calls as text over the phone.

1. In Call settings screen, select Accessibility > TTY

mode to view and modify TTY mode settings.

2. Set one of the following options:

• TTY Off: disables TTY mode.

• TTY Full: enables TTY mode for both incoming and

outgoing calls. Set this for both hearing and voice

assistance.

• TTY HCO: enables TTY mode only for incoming

calls. Set this for only hearing assistance.

• TTY VCO: enables TTY mode only for outgoing

calls. Set this for only voice assistance.

• Password: Password to login to SIP account.

• Server: SIP server details.

• Optional Settings: Select to view/modify or hide

optional details such as authentication username,

display name, outbound proxy address, port

number, transport type and Send keep alive

options.

• USE SIP CALLING

• Select Calling accounts > Use SIP calling.

• A dialog is open with the following options:

• For all calls: If this option is selected and when

the phone is connected to Wi-Fi network or

mobile Internet, each dialed call becomes an

Internet call.

• Only for SIP calls: If this option is selected, only

SIP call can be dialed.

• RECEIVE INCOMING CALLS

Enable Receive incoming calls to answer incoming

Internet calls.

This might reduce your phone’s battery life.

II. VOICEMAIL:

• Service: Displays the Service name. It is displayed

as My carrier.

• Setup: You can set a number for voicemail.

• Sound: Set the sound from the list.

• Vibrate: Check the box to set it to vibrate.

III. Fixed Dialing Numbers:

• Enable FDN: Fixed Dialing numbers are enabled.

• Change PIN2: Change the PIN for FDN access.

• FDN List: Manage phone number list.

IV.Call Forwarding:

You can forward your incoming calls to a number in

the contacts or a new number, provided your network

operator supports this service.

Select one of the following call forward options:

SETTINGS DESCRIPTION

Always

forward

Forward all incoming calls to a pre-

designated number.

When busy Forward calls when your phone is

busy. Forward

When

unanswered

Forward calls when you do not answer

incoming calls.

SENDING MESSAGES

SMS and MMS are convenient and

inexpensive means of communication.

You can send a text message to other

people via SMS service. MMS allows

you to send messages by including

multimedia content such as pictures,

audio les, video les, and so on.

You can use the Messaging in your phone to send an

SMS and MMS message to other mobile phones or any

other equipment that can receive SMS and MMS.

The MMS feature is available only if you

subscribe it from your network operator.

To access the message function, from Home screen,

select Messaging ( ).

SENDING SMS/MMS MESSAGE

You can send SMS and MMS messages to contacts

in your phonebook and to new numbers that are not

present in the phonebook.

1. To create a SMS message, from Home screen,

select Messaging ( ).

2. Select Option key > New message.

3. Enter the contact name or the phone number in

the To eld.

If you enter an alphabet, all the contact names

starting with that alphabet and containing that

alphabet are displayed as a list. Scroll down to

select the contact.

4. Enter the message.

When you add an attachment, the message is

automatically converted to a multimedia message.

MMS charges will apply, based on the operator.

5. You can add any multimedia attachment up to

the size of <= 1 MB. To add an attachment, select

Options key > Attach photos/videos. Browse to

a specic folder and select the multimedia le to

be attached.

6. Select Option key > Attach others. Select the

attachment type from the options in the next step.

ATTACHMENT

TYPE

DESCRIPTION

Capture picture Take a new photo using the mobile

camera and attach.

Capture video Take a new video using the

camcorder and attach.

Audio Attach an audio le from the phone

memory.

Record audio Record a new audio using the sound

recorder and attach.

vCard Attach a contact available in the

phone.

vCalendar Attach a calendar event.

Slideshow Create new slideshow or edit the

existing slides and attach.

MANAGING MESSAGE SETTINGS

You can customize the way you want to view and lter

the messages.

To view and modify the message settings,

1. To edit message settings, from Home screen, select

Messaging ( ).

2. Select Option key > Settings.

3. View and edit the following settings:

SENDING MESSAGES

SETTINGS DESCRIPTION

NOTIFICATION

Vibrate Enable vibrate alert for incoming

messages.

Pop-up Alert Enable to view received message

as a pop-up.

DISPLAY

Group

notication

message

Enable this notication message to

auto combine the notication into

one group.

STORAGE

Delete old

messages

Delete old messages automatically

when the storage limit is reached.

Text message

limit

Set the maximum number of SMS

messages to be stored.

Multimedia

message limit

Set the maximum number of MMS

messages to be stored.

Memory status Shows the memory used for SMS,

MMS and the total memory used.

STORAGE DAYS

Delete messages

by days

Enable this option to delete the

messages as the set days are

reached.

Messages expiry

days

You can set the number of days for

message expiry.

ADVANCED SETTINGS

Text (SMS) messages settings

Message

template

Edit the quick message template.

Manage SIM

card messages

Manages the messages in the

SIM card located under Text

Messages.

Enable WAP

PUSH Service

Enable to receive service message.

Multimedia (MMS) messages settings

Group

messaging

Enable and use MMS to send a

single message when there are

multiple recipients.

Creation mode You can set the mode for creating

MMS message.Select one of the

modes: Restricted, Warning and

Free.

DELETING MESSAGES

To delete all the messages,

1. From Home screen, select Messaging ( ).

2. Select the message and press Option key >

Delete selected thread or select a message

thread and press Clear key ( )

3. A conrmation message is displayed. Select

Delete to delete the selected message.

4. To delete an individual conversation, select the

converstion to be deleted and select Delete

option and conrm the choice.

EMERGENCY ALERTS

You receive active alerts and emergency alerts from the

service provider.

AT&T EPTT SERVICES

Your Sonim phone comes with pre-loaded

PTT application.

For more information on AT&T EPTT, refer to the link:

https://www.business.att.com/solutions/Family/

mobility-services/eld-management/.

SONIM SCOUT

Sonim SCOUT is a solution that allows

the user to register with Sonim and use a

number of key enterprise features.

Sonim Cloud account required to fully utilize SCOUT

capabilities. Visit http://www.sonimcloud.com for more

information.

To access Sonim Scout,

• From Home screen, select Menu ( ) > Sonim

Scout ( ).

SETUP

Setup tab consists of the following features:

• SonimSetupWizard

• SafeGuard

UTILITIES

Utilities tab consists of the following features:

• Contact Transfer

• Sonim BLE Connect

SUPPORT

Support tab consists of the following features:

• Chat

• Remote Control

• SonimCare

• Warranty Registration

• Device Information

• Contact Sonim Support

• Call

• Email

APPLICATIONS

MUSIC

You can play music les and voice memos stored in your

phone using the music application.

From Home screen, select Menu ( ) > Applications

( ) > Music ( ) .

• Select Artists to view the music les sorted based

on the artists.

• Select Albums to view the music les sorted based

on the albums.

• Select Songs to view the complete list of songs

stored in your phone.

• Select Playlists to access the default playlists in the

music folder.

• Select Recently added playlist to view the music

les that are recently added to the music folder.

• Select My recordings playlist to access all your

voice memo les.

FM RADIO

You can listen to the radio through FM radio. A wired

Headset should be connected to enable FM radio.

1. To listen to the radio, select Menu ( ) >

Applications ( ) > FM Radio ( ) .

2. A message Connect Headset is displayed.

Connect a wired Headset with the side connector

to enable FM Radio. FM radio icon is displayed

on the Notication bar.

• Side Connector: As the Sonim XP5s device does

not support the jack, side connector is used to plug-

in the jack and listen to FM radio over the headset.

3. Select Options > Radio On to turn on the radio.

4. Select Options and the following options are

displayed:

• Auto Scan:

• On selecting Auto Scan for the rst time, the

device starts scanning all available stations and a

pop-up message is displayed; Scanning for all

stations.

• Once the scanning is completed, a conrmation

message is displayed on All Channels screen;

Scan Complete: Number of channels scanned.

• If any channel present in Preset list, select Auto

Scan and a pop-up message is displayed; Clear

the preset list? Select Yes to scan all available

channels.

• All Channels: All scanned channels are listed.

• Preset: Connect to a particular station and select

Options > Add to presets. The selected channel is

added to the preset list.

Select Preset > Options and the following options

are displayed:

• Rename: You can rename the channel/station.

• Remove from presets: Selected channel is

removed from the preset.

• Loud Speaker/Wired Headset: You can set the

radio on loud speaker. When you set the radio on

loudspeaker mode, it displays Wired Headset as an

option.

• Sleep: You can turn off the radio after a selected

time frame:

• 15 minutes

• 30 minutes

• 45 minutes

• 1 Hour

• Start Recording: You can record the audio which is

broadcasted on the radio to listen to the same later.

• Settings: The following options are displayed under

Settings:

• Regional Band: The regional band with frequency

range is displayed.

• Audio Output Mode: Select any of the following

options as a output mode: Stereo or Mono

• Alternate Frequency: Check this option enable/

disable the auto selection of alternate frequency.

• Revert to Factory Defaults: This option deletes

all the settings including Presets. Select OK to

conrm.

• Radio off: Select this option to turn off the radio.

Side Connector

APPLICATIONS

FILE EXPLORER

You can view/edit/delete/share the les stored in the

phone through File Explorer ( ).

To view the les, select Menu ( ) > Applications ( )

> File Explorer ( ).

Select any folder and press Option key to view the

following options:

• Recent: Displays the recent les captured or stored.

• Share: Share the le or folder via Messaging/

Bluetooth.

• Delete: Delete the existing folder.

• Copy to: Copy the contents of the folder.

• Move to: Move the contents of folder.

• Properties: View the properties of the folder.

• Select: Select a particular folder.

• Downloads: Displays the downloaded les.

• Exit: You can select Exit option for exiting from

File Explorer.

• Downloads: Displays the different folder under

Downloads.

• Share: Share the le or folder via Messaging/

Bluetooth.

• Delete: Delete the existing folder.

• Copy to: Copy the contents of the folder.

• Move to: Move the contents of folder.

• Rename: Rename the existing folder.

• Properties: View the properties of the folder.

• Select: Select a particular folder.

• Sort by: You can sort the folder using Sort option.

Sorting options are; By Name, By Date Modied

and By Size.

• New folder: You can create a new folder.

• Exit: You can select Exit option for exiting from

File Explorer.

• XP5800: Displays the different folder in the device

drive.

• Search: Search for the le and folder.

• Delete: Delete the existing folder.

• Copy to: Copy the contents of the folder.

• Move to: Move the contents of folder.

• Rename: Rename the existing folder.

• Properties: View the properties of the folder.

• Select: Select a particular folder.

• Sort by: You can sort the folder using Sort option.

Sorting options are; By Name, By Date Modied

and By Size.

• New folder: You can create a new folder.

• Exit: You can select Exit option for exiting from

File Explorer.

If SD card is inserted, all the les in the SD

card can be view/edit/delete/share from le

explorer.

BACKUP AND RESTORE

If you need to replace your device or erase its data,

you can restore your data for any accounts that were

previously backed up.

To back up your data,

1. From Home screen, select Menu ( ) >

Applications ( ).

2. Select Backup and Restore ( ).

3. Select Backup.

All your contacts, Calendar, SMS and MMS data will

be backed up and media content like photos, audio

and videos are moved to SD card.

A warning message is displayed Backup may

take few minutes. Please do not perform other

operations during this time.

Select OK to start the backup.

4. Select Restore.

The contacts, Calendar, SMS and MMS are restored.

Without SD card, the user cannot take

device back-up.

DOWNLOADS

Use the Downloads screen to view, open, or delete the

downloaded les.

1. From Home screen, select Menu ( ) >

Applications ( ).

2. Select Downloads ( ).

3. Select Options > Select to select the downloaded

le to be opened, viewed, or deleted.

TOOLS

CLOCK

You can view the time of major cities in different time

zones using this function.

1. From Home screen, select Menu ( ) > Tools

( ).

2. Select Clock ( ).

3. Select World clock icon ( ) located on the top

of the screen. To add a city , select Option key >

Add city. Select the check boxes next to the cities

to add them to the Clock.

• The local time in the home city is displayed in the

upper half of the screen.

• To set the home city, select the required city from

the list. It is added to the selected cities list. The

selected city is set as the home city.

ALARM

You can set an alarm for a particular time.

1. From Home screen, select Menu ( ) > Tools( ).

2. Select Clock ( ).

3. Select Alarm activation icon ( ) on the top of

the screen.

4. Select Option key > Add to add a new alarm.

5. To set a recurring alarm, select Option key > Edit.

You can choose and set the following options:

• Time: You can set the required time.

• Repeat: You can select the days in a week to

repeat the alarm for all the selected days.

• Alarm Ringtone: Select the alarm ringtone.

• Label: You can name the alarm.

• Vibrate: Enable this option to set the device on

vibrate when the alarm rings.

6. Select any of the ringtones from the Default alarm

tone sound present, and select OK.

The alarm will work even when the phone is

set in silent mode.

STOPWATCH

1. From Home screen, select Menu ( ) > Tools ().

2. Select Clock ( ) > Stop watch ( ).

3. Select START and STOP to run the stop watch.

TIMER

1. From Home screen, select Menu ( ) > Tools ().

2. Select Clock ( ) > Timer ( ).

3. The following actions can be performed:

• RESET, START, STOP, and LAP

CALCULATOR

The default calculator in this phone is designed to

perform simple mathematical calculations and the

advanced panel for scientic calculations.

1. From Home screen, select Menu ( ) > Tools

( ) > Calculator ( ) .

• To enter the numbers, select the numeric keys.

• To use mathematical operators, select the

respective operation key on the keypad.

• Select = for the nal result.

2. Select Option key > Advanced panel for

scientic calculations.

You can toggle between Basic panel and Advanced

panel.

SOUND RECORDER

You can record voice memos using the sound recorder.

To access the sound recorder,

• From Home screen, select Menu ( ) > Tools

( ) > Sound Recorder ( ) .

• To record an audio le, select Record ( ).

• To stop the recording, select Stop ( ).

• To save the voice memo, press left arrow key and

select Save.

• To exit without saving, press left arrow key and

select Discard.

• To play the recorded le instantly, press right

arrow key and select the le to be played. Press

Center key to play the voice memo.

OTHER APPLICATIONS

CAMERA

The Sonim XP5s has a rear camera with 5MP xed focus

for taking pictures. The pictures are saved in the Gallery.

1. From Home screen, select Menu ( ) > Camera

( ).

2. Select Camera mode to set the following modes:

• Normal ( ): To shoot a picture in normal mode,

press center key to capture the picture. Use Left

and Right navigation keys for Zoom in and Zoom

out.

• Video ( ): Press center key to start/stop a video

recording.You cannot pause the recording in the

middle.

3. Select Option key to view or change camera

settings such as Flash, Exposure, and File

Format etc.

CALENDAR

The Calendar helps you to set appointments, schedule

reminders and alerts and repeat them if required. You can

also view your saved tasks on a daily or weekly basis.

To access calendar;

1. From Home screen, select Menu ( ) > Calendar

( ).

2. To change the calendar view, choose Month or

Agenda from Options menu.

3. Select Options key to view the list of the following

available options:

• Today: Access current date events.

• New event: New event can be added on selecting

this option.

• Agenda: Select each agenda and to view the event

details.

• Search: You can search for a particular event.

• Delete Events: Select the event > Option key >

Done to delete the selected event. Select Select all

to delete all the events.

When you have an event, the Delete events option is

enabled.

• Settings:

• Displays the General settings of the calendar.

• Displays the Build version in About Calendar.

GALLERY

The pictures, videos, and screenshots captured from the

camera are stored in Gallery and can be viewed later.

From Home screen, select Menu ( ) > Gallery ().

You can view the photo album, screenshots, and the

individual pictures.

BROWSER

1. From Home screen, select Menu ( ) > Browser

().

2. Enter the URL to search for the required

information or any website.

3. Select Option key and you can view the list of

options such as;

• Go to URL

• Homepage

• Switch Tabs

• Refresh

• Forward

• Bookmarks

• Save to bookmarks

• History

• Copy URL

• Share page

• Find on page

• Settings

• Exit

REGULATORY INFORMATION - USA MARKET

REGULATORY INFORMATION - USA

MARKET

RF EXPOSURE INFORMATION (SAR)

This device meets the government’s requirements for

exposure to radio waves.

This device is designed and manufactured not

to exceed the emission limits for exposure to

radio frequency (RF) energy set by the Federal

Communications Commission of the U.S. Government.

The exposure standard for wireless device employs a

unit of measurement known as the Specic Absorption

Rate, or SAR. The SAR limit set by the FCC is 1.6W/

kg. *Tests for SAR are conducted using standard

operating positions accepted by the FCC with the

device transmitting at its highest certied power level

in all tested frequency bands. Although the SAR is

determined at the highest certied power level, the

actual SAR level of the device while operating can

be well below the maximum value. This is because

the device is designed to operate at multiple power

levels so as to use only the poser required to reach the

network. In general, the closer you are to a wireless

base station antenna, the lower the power output.

The highest SAR value for the model device XP5800

(Type number PG2112) as reported to the FCC:

• when tested for use at the ear is 0.98W/kg, and

• when worn on the body, as described in this user

guide, is 1.35W/kg (Body-worn measurements

differ among device models, depending upon

available accessories and FCC requirements.)

While there may be differences between the SAR levels

of various devices and at various positions, they all

meet the government requirement.

The FCC has granted an Equipment Authorization for

this model device with all reported SAR levels evaluated

as in compliance with the FCC RF exposure guidelines.

SAR information on this model device is on le with the

FCC and can be found under the Display Grant section

of www.fcc.gov/oet/ea/fccid after searching on FCC ID:

WYPPG2132.

For body worn operation, this device has been tested

and meets the FCC RF exposure guidelines for use with

an accessory that contains no metal and be positioned

a minimum of 1.5cm from the body. Use of other

accessories may not ensure compliance with FCC RF

exposure guidelines. If you do not use a body-worn

accessory and are not holding the device at the ear,

position the handset a minimum of 1.5cm from your

body when the device is switched on.

FEDERAL COMMUNICATION COMMISSION

INTERFERENCE STATEMENT

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received,

including interference that may cause undesired

operation.

This device has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses,

and can radiate radio frequency energy, and, if not

installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation If this equipment

does cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV

technician for help.

FCC CAUTION

• Any Changes or modications not expressly

approved by the party responsible for compliance

could void the user‘s authority to operate the

equipment.

• The antenna(s) used for this transmitter must not

be co-located or operating in conjunction with any

REGULATORY INFORMATION - USA MARKET

a minimum of 1.5cm from the body. Use of other

accessories may not ensure compliance with FCC RF

exposure guidelines. If you do not use a body-worn

accessory and are not holding the device at the ear,

position the handset a minimum of 1.5cm from your

body when the device is switched on.

HAC RATING

The FCC has created a rating system for cellular phones

regarding their HAC-related performance. This rating

helps consumers with hearing disabilities to nd phones

that work well with their hearing aid devices. The HAC

rating and measurement procedure are described in the

American National Standards Institute (ANSI C63.19-

2011) contains two rating standards: an “M” rating from

1 to 4 for hearing aids operating in microphone mode,

and a “T” rating from 1 to 4 for hearing aids operating in

tele coil mode. M-Rating stands for Microphone rating

and indicates the amount of reduction of RF interference

between the telephone and the hearing aid in acoustic

coupling mode (also called microphone mode). Phones

rated M3 or M4 meet FCC requirements and generate

less interference to hearing devices set in microphone

mode. T-Rating stands for tele coil rating and represents

inductive coupling with hearing aids that are operating in

telecoil mode. A tel coil is a small piece of tightly wrapped

wire, built into some hearing aids.

microphone of a hearing aid picks up all sounds, the

telecoil only picks up an electromagnetic signal from the

telephone. Thus, users of telecoil-equipped hearing aids

are able to communicate over the telephone without the

amplication of unwanted background noise. Phones

rated T3 or T4 meet FCC requirements and generate

less interference to hearing devices set in telecoil mode.

A combination of M-rating and T-rating denes the

nal HAC rating and is a deciding factor in selecting

cellular phones for people with hearing problems. A HAC

compliant phone could be rated:

• M3/T3

• M3/T4

• M4/T3

• M4/T4

These ratings assist hearing device users to nd

phones that are compatible with their hearing devices.

Ratings are shown on the phone’s box or label. The

ratings are not guaranteed for suitability. The results

vary depending on the individual’s hearing loss and the

immunity characteristics of the used hearing device, i.e.

its resistance to interference. The best way to evaluate

the suitability of the phone is to try it with the intended

hearing aid device.

The model XP5800 have been tested for hearing aid

device compatibility and complies with the Federal

Communications Commission (FCC) requirements.

These devices are rated M3/T4.

ISED RF EXPOSURE STATEMENT (IC)

This EUT is compliance with SAR for general

population/uncontrolled exposure limits in IC RSS-

102 and had been tested in accordance with the

measurement methods and procedures specied in

IEEE 1528 and IEC 62209. This equipment should be

installed and operated with minimum distance 1.5 cm

between the radiator and your body. This device and

its antenna(s) must not be co-located or operating in

conjunction with any other antenna or transmitter.

Cet appareil est conforme aux limites d’exposition DAS

incontrôlée pour la population générale de la norme

CNR-102 d’Industrie Canada et a été testé en conformité

avec les méthodes de mesure et procédures spéciées

dans IEEE 1528 et IEC 62209. Cet appareil doit être

installé et utilisé avec une distance minimale de 1.5cm

entre l’émetteur et votre corps. Cet appareil et sa ou ses

antennes ne doivent pas être co-localisés ou fonctionner

en conjonction avec tout autre antenne ou transmetteur.

HAZARDOUS LOCATION USAGE WARNING

HAZARDOUS LOCATION USAGE

WARNING

Determine by inspection that the following

information is made available to the user

by one or more of;

(a) Printed on the label for the battery

(b) Printed on the label for the host device,

or (d) Posted in a help le or Internet web

site.

Do not disassemble or open crush, bend or

deform, puncture or shred.

Do not modify or remanufacture, attempt

to insert foreign objects into the battery,

immerse or expose to water or other liquids,

expose to re, explosion or other hazard.

Only use the battery for the system for which it is

specied.

Only use the battery with a charging system that

has been qualied with the system per CTIA

Certication Requirements for Battery System

Compliance to IEEE 1725. Use of an unqualied

battery or charger may present a risk of re,

explosion, leakage, or other hazard.

Do not short circuit a battery or allow metallic

conductive objects to contact battery terminals.

Replace the battery only with another battery

that has been qualied with the system per this

standard, IEEE-Std-1725. Use of an unqualied

battery may present a risk of re, explosion,

leakage or other hazard. Only authorized service

providers shall replace battery. (If the battery is

non-user replaceable).

Do not short circuit a battery or allow metallic

conductive objects to contact battery terminals.

Promptly dispose of used batteries in

accordance with local regulations.

Battery usage by children should be supervised.

Avoid dropping the phone or battery. If the

phone or battery is dropped, especially on a

hard surface, and the user suspects damage,

take it to a service center for inspection.

Improper battery use may result in a re,

explosion or other hazard.

INDEX

Accessibility 25

Account Sync 29

Airplane Mode 18

Alarm

Timer 37

Applications

Music

FM Radio

File Explorer 12, 13, 15, 22

Apps 21

Backup 36

Battery 7

Battery Usage

Charging 7

Blocked Numbers 27

Bluetooth

Pairing 18

Browser 38

Calculator 37

Calendar 38

Capturing Screenshot 13

Child Safety 6

Contacts

Export

Import

Share 17, 26, 27, 28

Data Warning 18

Date 25

Display 20

Downloads 36

Emergency Alerts 32

Emergency Info 23

Encryption 23

EPTT Services 33

Export 27

Factory Reset 24

File Explorer 35

FlexT9 Text 24

FM Radio 35

Gesture 22

HAC 40

Hazardous Location 41

Home Screen 12

Hotspot 19

Import 27

INDEX

Keyboard 24

Keyboard Dictionaries 34

Language 24

Location 23

Memory

App usage 22

Messages 31

Missed Events 16

Mobile Network 18

My Notications 15

Noise Cancellation

FENS 21

Notication 21

Operations 13

Phone Specications 9

Power Optimization 8

Programmable Key 24

Quick Prole Switch 21

Quick Settings 16

Restore 36

Scout 34

Search 15

Security 23

Security Settings 23

Setup wizard 34

Side Connector 35

SMS/MMS Message 31

Sound 20

Sound Recorder 37

Stopwatch 37

Storage

Internal Share 22

Support 34

Temperatures 6

Tethering 19

Text Entry 14

Time 25

Toggle Torch 22

Torch 16

USB Power Saving 22

Utilities 34

VPN 19

Wallpaper 15

Wi-Fi 17

WPS 17

XP5s 11

Sonim Xp5s Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
