Release Notes

BootROM Application

SoundPoint® IP and SoundStation® IP

Version 4.3.1

7 September 2011

Part Number 3804-11069-431

Trademark Information

names and marks associated with Polycom's products are trademarks and/or service marks of

Polycom, Inc. and are registered and/or common law marks in the United States and various

other countries. All other trademarks are property of their respective owners. No portion hereof

may be reproduced or transmitted in any form or by any means, for any purpose other than the

recipient's personal use, without the express written permission of Polycom.

Release Notes - BootROM 4.3.1

Table of Contents

1 General .............................................................................................................7

1.1 Software Revision ....................................................................................7

1.2 Important Notes .......................................................................................7

1.3 Document Revision .................................................................................8

1.4 Hardware Support ....................................................................................8

1.5 Image Signatures .....................................................................................8

1.6 Distribution Files .....................................................................................9

1.7 BootROM Upgrade/Downgrade Path ....................................................10

2 Changes by Release .......................................................................................11

2.1 Version 4.3.1 ..........................................................................................11

2.1.1 Added or Changed ..............................................................................11

2.1.2 Removed Features ..............................................................................11

2.1.3 Corrections ..........................................................................................11

2.2 Version 4.3.0 ..........................................................................................12

2.2.1 Added or Changed Features ...............................................................12

2.2.2 Removed Features .............................................................................12

2.2.3 Corrections .........................................................................................12

2.3 Version 4.2.2 ..........................................................................................13

2.3.1 Added or Changed Features ...............................................................13

2.3.2 Removed Features .............................................................................13

2.3.3 Corrections .........................................................................................13

2.4 Version 4.2.1 ..........................................................................................14

2.4.1 Added or Changed Features ...............................................................14

2.4.2 Removed Features .............................................................................14

2.4.3 Corrections .........................................................................................14

2.5 Version 4.2.0 B ......................................................................................15

2.5.1 Added or Changed Features ...............................................................15

2.5.2 Removed Features .............................................................................15

2.5.3 Corrections .........................................................................................15

2.6 Version 4.2.0 ..........................................................................................15

2.6.1 Added or Changed Features ...............................................................15

2.6.2 Removed Features .............................................................................15

2.6.3 Corrections .........................................................................................15

2.7 Version 4.1.3 ..........................................................................................16

2.7.1 Added or Changed Features ...............................................................16

2.7.2 Removed Features .............................................................................16

2.7.3 Corrections .........................................................................................16

2.8 Version 4.1.2 B ......................................................................................17

2.8.1 Added or Changed Features ...............................................................17

2.8.2 Removed Features .............................................................................17

2.8.3 Corrections .........................................................................................17

2.9 Version 4.1.2 ..........................................................................................17

2.9.1 Added or Changed Features ...............................................................17

2.9.2 Removed Features .............................................................................17

Release Notes - BootROM 4.3.1

2.9.3 Corrections .........................................................................................17

2.10 Version 4.1.1 ..........................................................................................18

2.10.1 Added or Changed Features .............................................................18

2.10.2 Removed Features ............................................................................18

2.10.3 Corrections .......................................................................................18

2.11 Version 4.1.0 ..........................................................................................18

2.11.1 Added or Changed Features .............................................................18

2.11.2 Removed Features ............................................................................19

2.11.3 Corrections .......................................................................................19

2.12 Version 4.0.1 (Limited Release) ............................................................19

2.12.1 Added or Changed Features .............................................................19

2.12.2 Removed Features ............................................................................19

2.12.3 Corrections .......................................................................................19

2.13 Version 4.0.0 ..........................................................................................19

2.13.1 Added or Changed Features .............................................................19

2.13.2 Removed Features ............................................................................20

2.13.3 Corrections .......................................................................................20

2.14 Version 3.2.3RevB .................................................................................20

2.14.1 Added or Changed Features .............................................................20

2.14.2 Removed Features ............................................................................21

2.14.3 Corrections .......................................................................................21

2.15 Version 3.2.3 ..........................................................................................21

2.15.1 Added or Changed Features .............................................................21

2.15.2 Removed Features ............................................................................21

2.15.3 Corrections .......................................................................................21

2.16 Version 3.2.2RevB .................................................................................21

2.16.1 Added or Changed Features .............................................................21

2.16.2 Removed Features ............................................................................21

2.16.3 Corrections .......................................................................................21

2.17 Version 3.2.2 ..........................................................................................21

2.17.1 Added or Changed Features .............................................................21

2.17.2 Removed Features ............................................................................22

2.17.3 Corrections .......................................................................................22

2.18 Version 3.2.1 ..........................................................................................22

2.18.1 Added or Changed Features .............................................................22

2.18.2 Removed Features ............................................................................22

2.18.3 Corrections .......................................................................................22

2.19 Version 3.2.0 (Beta Only) ......................................................................22

2.19.1 Added or Changed Features .............................................................22

2.19.2 Removed Features ............................................................................22

2.19.3 Corrections .......................................................................................23

2.20 Version 3.1.3 RevD ...............................................................................23

2.20.1 Added or Changed Features .............................................................23

2.20.2 Removed Features ............................................................................23

2.20.3 Corrections .......................................................................................23

2.21 Version 3.1.3 RevC ................................................................................23

Release Notes - BootROM 4.3.1

2.21.1 Added or Changed Features .............................................................23

2.21.2 Removed Features ............................................................................23

2.21.3 Corrections .......................................................................................23

2.22 Version 3.1.3 RevB ................................................................................23

2.22.1 Added or Changed Features .............................................................23

2.22.2 Removed Features ............................................................................23

2.22.3 Corrections .......................................................................................24

2.23 Version 3.1.3 ..........................................................................................24

2.23.1 Added or Changed Features .............................................................24

2.23.2 Removed Features ............................................................................24

2.23.3 Corrections .......................................................................................24

2.24 Version 3.1.2 ..........................................................................................24

2.24.1 Added or Changed Features .............................................................24

2.24.2 Removed Features - None. ...............................................................24

2.24.3 Corrections - None. ..........................................................................24

2.25 Version 3.1.1 ..........................................................................................24

2.25.1 Added or Changed Features .............................................................24

2.25.2 Removed Features - None. ...............................................................25

2.25.3 Corrections .......................................................................................25

2.26 Version 3.1.0 ..........................................................................................25

2.26.1 Added or Changed Features .............................................................25

2.26.2 Removed Features - None. ...............................................................25

2.26.3 Corrections .......................................................................................25

2.27 Version 3.0.1 ..........................................................................................25

2.27.1 Added or Changed Features .............................................................25

2.27.2 Removed Features - None. ...............................................................25

2.27.3 Corrections .......................................................................................25

2.28 Version 3.0.0 ..........................................................................................25

2.28.1 Added or Changed Features .............................................................25

2.28.2 Removed Features ............................................................................26

2.28.3 Corrections .......................................................................................26

2.29 Version 2.6.2 ..........................................................................................26

2.29.1 Added or Changed Features - None. ................................................26

2.29.2 Removed Features - None. ...............................................................26

2.29.3 Corrections .......................................................................................26

2.30 Version 2.6.1 ..........................................................................................26

2.30.1 Added or Changed Features - None. ................................................26

2.30.2 Removed Features - None. ...............................................................26

2.30.3 Corrections .......................................................................................26

2.31 Version 2.6.0 ..........................................................................................26

2.31.1 Added or Changed Features .............................................................26

2.31.2 Removed Features - None. ...............................................................27

2.31.3 Corrections .......................................................................................27

2.32 Version 2.5.1 ..........................................................................................27

2.32.1 Added or Changed Features - None. ................................................27

2.32.2 Removed Features - None. ...............................................................27

Release Notes - BootROM 4.3.1

2.32.3 Corrections - None. ..........................................................................27

2.33 Version 2.5.0 ..........................................................................................27

2.33.1 Added or Changed Features .............................................................27

2.33.2 Removed Features - None. ...............................................................27

2.33.3 Corrections .......................................................................................27

3 Notes ..............................................................................................................27

3.1 Outstanding Issues .................................................................................27

Release Notes - BootROM 4.3.1

1 General

1.1 Software Revision

These release notes cover Polycom‟s SoundPoint/SoundStation IP - BootROM

version 4.3.1.

1.2 Important Notes

 The BootROM for the VVX 1500 is not included in this release. For SIP

3.2.2 and future releases, the BootROM (for the VVX product) will be

distributed as part of the SIP software image as there is a tight

dependency between them. Products other than the VVX 1500 will

continue to be supported with a separate BootROM image. Refer to

technical bulletin TB 53522 for upgrade instructions.

 BootROM 4.3.0 does not include support for the SoundPoint IP 430.

BootROM 4.2.0 does not include support for the following phone models:

SoundPoint IP 300, 301, 500, 501, 600, 601 and SoundStation IP 4000.

These are termed „Legacy‟ phone models. If you have these phones

installed in your network the following options can be used if you wish to

upgrade the BootROM to 4.2.0

 Continue to host an older version of the „split‟ BootROM for these

phones e.g. you could place bootrom file 2345-11300-001-

bootrom1.ld from the BootROM Release 4.1.3 on your provisioning

server while updating/replacing the files for other phone models.

This step can be achieved by unzipping the BootROM 4.2.0

distribution file into the same directory as an earlier BootROM had

been placed and replacing the files for the current phone models.

 If an applicable „split‟ image for the Legacy phone models is not

found the phone will still boot, but the boot time will be increased

due to the time taken for the phone to search the bootrom.ld file for

an applicable image.

 This BootROM version is not compatible with the MGCP application and

must not be used on phones running MGCP.

 When the BootROM is changed on the phone the Flash File System is re-

formatted. To ensure that user settings such as contacts are preserved

across the upgrade, a provisioning server must be used for the phone to

store back-up copies of the local settings and contact directory

information.

 The Zero Touch provisioning (ZTP) feature introduced in the current

release 4.3.1 is “UNSUPPORTED” unless the phones are running both

BootROM/Updater version 4.3.1 and UC Software version 3.3.2

Release Notes - BootROM 4.3.1

1.3 Document Revision

These release notes may be updated during the life of this release as any issues

are reported. This document was last updated September 14, 2011.

1.4 Hardware Support

This release is compatible with the following Polycom products:

 SoundPoint IP 320

 SoundPoint IP 321

 SoundPoint IP 330

 SoundPoint IP 331

 SoundPoint IP 335

 SoundPoint IP 450

 SoundPoint IP 550

 SoundPoint IP 560

 SoundPoint IP 650

 SoundPoint IP 670

 SoundStation IP 5000

 SoundStation IP 6000

 SoundStation IP 7000

 VVX 1500 (BootROM is distributed as part of the SIP 3.2.2 and later

releases)

1.5 Image Signatures

Cryptographic signatures are added to all downloaded image files as a security

feature. BootROMs 3.0.0 and later require that an image has a valid signature to

prevent malicious code from being used. Since no prior BootROMs have this

signature it is not possible to downgrade the BootROM below 3.0.0. Similarly it

will not be possible to run older applications. Care should be taken when

deciding to upgrade to later BootROMs.

Release Notes - BootROM 4.3.1

1.6 Distribution Files

The following files constitute the 4.3.1.0440 distribution of the

SoundPoint IP/SoundStation IP/VVX BootROM software. For centrally

provisioned systems, copy these files to the boot server in order to upgrade the

BootROM software on the phone.

Files

Description

bootrom.ld

Concatenated BootROM application executable.

2345-12200-002.bootrom.ld

2345-12200-005.bootrom.ld

BootROM executables for SoundPoint IP 320

2345-12360-001.bootrom.ld

BootROM executables for SoundPoint IP 321

2345-12200-001.bootrom.ld

2345-12200-004.bootrom.ld

BootROM executables for SoundPoint IP 330

2345-12365-001.bootrom.ld

BootROM executables for SoundPoint IP 331

2345-12375-001.bootrom.ld

BootROM executables for SoundPoint IP 335

2345-12450-001.bootrom.ld

BootROM executable for SoundPoint IP 450

2345-12500-001.bootrom.ld

BootROM executable for SoundPoint IP 550

2345-12560-001.bootrom.ld

BootROM executable for SoundPoint IP 560

2345-12600-001.bootrom.ld

BootROM executable for SoundPoint IP 650

2345-12670-001.bootrom.ld

BootROM executable for SoundPoint IP 670

3111-30900-001.bootrom.ld

BootROM executable for SoundStation IP 5000

3111-15600-001.bootrom.ld

BootROM executable for SoundStation IP 6000

3111-40000-001.bootrom.ld

BootROM executable for SoundStation IP 7000

Release Notes - BootROM 4.3.1

1.7 BootROM Upgrade/Downgrade Path

Due to some enhancements that have been added to the BootROM software, it

is not always possible to go to certain versions even if the hardware is

compatible. The following table lists the upgrade/downgrade paths that are not

supported:

From

Upgrade

Downgrade

1.x

2.x, 3.x, 4.x

2.0.x, 2.1.x

2.5.x, 2.6.x, 3.x, 4.x

1.x

2.2.x

3.x, 4.x

1.x, 2.0.x, 2.1.x

2.3.x, 2.4.x

3.x, 4.x

1.x, 2.0.x, 2.1.x, 2.2.x

2.5.x

3.x, 4.x

1.x, 2.0.x, 2.1.x, 2.2.x

2.6.x

1.x, 2.0.x, 2.1.x, 2.2.x

3.0.x

1.x, 2.x

3.1.0, 3.1.1

1.x, 2.x

3.1.2, 3.1.3, 3.2.x

1.x, 2.x – All platforms

All versions below 3.1.2 -

SSIP 4000 only

4.x

1.x, 2.x – All platforms

All versions below 3.1.2 -

SSIP 4000 only

Release Notes - BootROM 4.3.1

2 Changes by Release

2.1 Version 4.3.1

2.1.1 Added or Changed

 67633: Added support for Zero Touch Provisioning (ZTP) feature.

2.1.2 Removed Features

 None

2.1.3 Corrections

 59371: "Initial log entry" is not the initial log entry.

 60287: The phone displays misleading messages when it is booting

and attempting to contact the boot/provisioning server.

 61918: The default value is restored for the flash parameter

"dhcp.enabled”

 64474: Phone application fails to set up the correct DNS and SNTP

settings from the DHCP server.

 65461: Phone will attempt a DHCP VLAN discovery even after it

receives a VLAN ID from CDP or LLDP.

 65660: SoundStation IP 6000, IP 7000: Unprotected access to flash

memory may lead to corruption of the phone.

 66361: SoundStation IP 6000, IP 7000: When the Path MTU Discovery

is disabled on the Windows 2003 server, the phone does not become

provisioned using FTP.

 67431: When the phone runs continuously during the boot up stage,

the phone will not be provisioned as a result of memory allocation

errors.

Release Notes - BootROM 4.3.1

 68476: The phone will not be able to boot if it is configured with

Option 60, ASCII String and DHCP Server Option 43.

 69195: SoundStation IP 7000: The "CLink Mode" parameter cannot be

edited in the BootROM/Updater setup menu.

 69563: SoundStation IP 6000, IP 7000: The phones‟ application

cannot be upgraded using TFTP.

 69671: Phones fail to receive the VLAN ID from the DHCP option 129

in a specific scenario and boot up with the native VLAN.

 69934: The phone displays incorrect progress notification when it is

attempting to update the software image.

2.2 Version 4.3.0

2.2.1 Added or Changed Features

 None

2.2.2 Removed Features

 56248: Removed support for the SoundPoint IP 430.

2.2.3 Corrections

 54017: VVX 1500: Erroneous log timestamps during boot-up.

 54219: SoundPoint IP 560, 670: Phones will not establish a network

link when they are connected to a switch when both the phone and

the switch have their port settings fixed at 100Mb/Full Duplex.

 55648: Socket bind for passive FTP data connection will use another

random port.

 56333: Phone will reboot automatically when the lease time expires

after disabling and then enabling the DHCP server.

 56381: SoundStation IP 6000, 7000: Phones do not accept a DHCP

offer because the packets from the DHCP server do not include the

terminating END (0xFF) option.

 56401: The „Admin‟ password length in the boot menu and advanced

menu are different.

Release Notes - BootROM 4.3.1

 56868: Published CDP power values (in TB 48152) do not match

actual measured consumption. The fix involved updating the

software and technical bulletin.

 57629: A corruption to the Flash configuration will reset, but will not

use the factory default values.

 57863: Phones do not accept a DHCP INFORM response if a packet

does not contain the END option.

 59352: The phone executes an application despite an image

signature error.

 59470: SoundPoint IP 5000: “ModelNumber” element in

“DeviceInformation” XML block is not consistent with other phones.

 59625: Automatic BootBlock upgrade fails through MAC.cfg file.

2.3 Version 4.2.2

2.3.1 Added or Changed Features

 Added support for SoundStation IP 5000 conference phone.

 54041: Format of DHCP option 60 is now a configurable parameter.

Added support for DHCP Option 125 as per RFC 3925.

 56912: Added support for parsing DHCP Vendor Specific Information

option 43 as per RFC 2132

2.3.2 Removed Features

 None.

2.3.3 Corrections

 45780: SoundPoint IP 320, 321, 325, 330, 331, 335, 430, 450, 550, 560,

650, 670: MIPS coprocessor zero register may be incorrectly set and

may change value upon boot up.

 47954: SoundStation IP 7000-HDX Integration: After a hard reboot of

an HDX, the IP 7000 continuously reboots itself.

 56017: BootROM 4.2.x contains unnecessary firmware intended for

SoundPoint IP 320, 321, 325, 330, 331, 335, 430, 450, 550, 560, 650,

670 phones.

 56303: Updating the bootBlock fails when re-installing the same

bootBlock.

 56307: BootROM 4.2.x: If “RAM Loading” is enabled,

(APP_NET_LOAD_FILE_PATH="sip.ld"), then the BootROM will

Release Notes - BootROM 4.3.1

download the sip.ld image. But then it reboots instead of running the

SIP Application software.

 56488: SoundStation IP 6000, 7000: DHCP client asks for duplicate

options of "Router"(3) and "Domain Name"(15).

 57235: SoundPoint IP450: Changes in the display palette have

created contrast problems in BootROM.

2.4 Version 4.2.1

2.4.1 Added or Changed Features

 52816: VVX 1500. Combine BootROM with SIP software for

distribution/upgrade. See Technical Bulletin TB53522 for more

information.

 54098: Add support for Automatic BootBlock upgrade

2.4.2 Removed Features

 Remove support for VVX1500. BootROM is now combined with the

SIP software image.

2.4.3 Corrections

 23978: Bootrom doesn't star out Admin password when entering the

setup screen

 47768: SoundPoint IP 450: CDP power usage advertisement is low for

peak power conditions.

 50531: SoundStation IP7000: Phone does not startup without

network connection when using the PIC cable

 52277: SoundPoint IP Phones: Bootrom fails DHCP if server config

has a blank password

 52712: SoundPoint IP 320, 321, 330, 331, 335: "Loading application"

message box overlaps the progress bar

 52943: LLDP reported power usage in logs indicates inappropriate

power consumption.

 54033: SoundPoint IP 320, 321, 330, 331, 335: "Downloading new

application" message box overlaps the progress bar

 55435: LLDP not used when enabled, as well as CDP/static

VLAN/DVD enabled for precedence test.

 55583: BootROM does not report correct User Agent in the HTTP and

DHCP requests. Introduced in BootROM 4.1.3.

Release Notes - BootROM 4.3.1

2.5 Version 4.2.0 B

2.5.1 Added or Changed Features

 52925: Add support for SoundPoint IP335 platform

2.5.2 Removed Features

 None.

2.5.3 Corrections

 None.

2.6 Version 4.2.0

2.6.1 Added or Changed Features

 32753: Add support for LLDP protocol

 45174: Upgrade zlib to version 1.2.3

 45743: Upgrade curl library to version 7.19.2

 52348: SoundStation IP 7000-HDX Integration: Support integration

with HDX 6000/7000 products.

2.6.2 Removed Features

 48772: Remove support for Legacy phone models:

SoundPoint IP 300, 301, 500, 501, 600, 601, SoundStation IP 4000

2.6.3 Corrections

 13786/29344: HTTP Digest Authentication does not work on IIS.

 27048: Application load progress bar doesn't match actual progress

 43646: It takes too long to load existing image if users mistakenly

specify valid non-existing bootserver on different network.

 45658: Platform string in transmitted CDP packets is not consistent

across all SoundPoint IP products.

 49696: After a long loss of Network connectivity during

"Downloading new application" the phone receives an IP address but

it does not reboot and it does not display any error message

 49758: SoundStation IP7000 gets into a bad state and does not

recover from temporarily unplugging network connection during an

active call.

Release Notes - BootROM 4.3.1

 51631: Phone not releasing first assigned IP address when VLAN is

set via DHCP

2.7 Version 4.1.3

2.7.1 Added or Changed Features

 48197: Add support for SoundPoint IP 321/331 products.

 49115: SoundStation IP 6000, 7000: Support new revision of Ethernet

PHYs.

2.7.2 Removed Features

 46268: Remove DHCP timeout from the settings menu. (All phones

except SoundPoint IP300 and IP500)

2.7.3 Corrections

 42233: Phone does not attempt Digest Authentication after redirect

 45708: SoundStation IP 6000, IP 7000: When DHCP is disabled, CDP

messages do not contain IP Address data.

 VOIP-45860: SoundPoint IP 450: Phone is flickering in dark gray solid

background when backlight turns to low (IP450)

 46008: VVX 1500: BootROM - About screen displays inaccurate IP

address information when configured with static network settings.

 46607: Phone fails to connect to redirected server running on

different system/IP address

 46939: Digest Authentication may fail on first file in the

CONFIG_FILES list

 46966: SoundPoint IP 320, 330, 430, 450, 550, 650, 670; SoundStation

IP 4000: HTTP Digest Authentication cnonce from phone is always

equal to "AAAAAAAAAAAAAAAA"

 47620: SoundStation IP 4000 may get stuck at the Polycom logo

screen if the reboot is triggered by IP address change

 47908: SoundStation IP 4000 will not boot up when the switch port is

set at 10FD and the LAN Port Mode in the phone UI is also set at

10FD.

 48280: When using TFTP or FTP as the provisioning Server Type,

phone does not save directory entries to flash when TFTP or FTP

server is not available.

 48799: VVX 1500: In booting up, after the "Running sip.ld" prompt the

screen goes white. Phone is still running however.

Release Notes - BootROM 4.3.1

 49274: SoundStation IP 6000, 7000; VVX 1500: CDP shutdown frame

is sent with TTL value of 180 seconds.

 49335: SoundStation phones' model name contain "SSIP" string

2.8 Version 4.1.2 B

2.8.1 Added or Changed Features

 Add support for VVX 1500 hardware

2.8.2 Removed Features

None.

2.8.3 Corrections

None.

2.9 Version 4.1.2

2.9.1 Added or Changed Features

 29024: Add ability to disable PC Ethernet port (full support requires SIP

3.1.0 or later)

 40755: Add support for SoundPoint IP450 product

 41721: Add SoundStation IP7000 video unit integration support

 43776: Add IP560,IP670 Gigabit Ethernet 1000FD Master/Slave

clocking configuration (full support requires SIP 3.1.0 or later)

2.9.2 Removed Features

 42620: Remove SAS-VP Provisioning Option from the User Interface

2.9.3 Corrections

 37580: SoundPoint IP601: Multicast rate limiting is not enabled

 39642: SoundStation IP6000, IP7000: Phone should not reply to IP

packets of unknown protocol with ICMP messages

 40328: Phone hanging on HTTP PUT with authentication

 40400: Phone issuing DHCP Inform packet un-necessarily.

 41366: Update phone UI and documentation to properly reference

'CDP'

 42813: Phone repeating USER AGENT in HTTP request.

 42969: Malformed DHCP option can cause phone to re-boot.

Release Notes - BootROM 4.3.1

2.10 Version 4.1.1

2.10.1 Added or Changed Features

 35976: Add support for SoundPoint IP670 platform

 36859: Add support for SoundStation IP 6000 platform

 Add support for SoundStation IP 7000 platform

 34934, 39547: New 8MB flash device support on SoundPoint IP 550,

560, 650 phones

 40475: Set VLAN Filtering to 'Off' by default

2.10.2 Removed Features

None.

2.10.3 Corrections

 39998: Spelling/grammar error in reporting incompatible sip.ld load.

 40121: VLAN tag not added to frame that is an IP fragment with

between 1 and 3 octets of payload

 40309: Negative cache is not created when doing an nslookup

without using the FQDN

 41199: 802.1x packets do not get forwarded by SoundPoint IP 320,

330, 430, 550, 560, 650 phones

2.11 Version 4.1.0

2.11.1 Added or Changed Features

 35150: Add electronic hook-switch capability using Jabra DHSG

protocol on SoundPoint IP 320, 330, 430, 550, 560, 650 phones. This

feature requires SIP 3.0.0 or later software release to operate. Refer

to technical bulletin 35150 for more details.

 37256: Add Jabra Jx10 electronic hook switch support on

SoundPoint IP 320, 330, 430, 550, 560, 650 phones. Requires an

“Interface Cable” from the headset base to the phone for use. Refer

to technical bulletin 35150 for more details.

 39072: Reduce DHCPINFORM retry timeouts.

 39330: Make DHCPINFORM only apply if boot server address is Null

or 0.0.0.0.

 39695: Change minimum syslog.renderLevel to 0 from 1

Release Notes - BootROM 4.3.1

2.11.2 Removed Features

None.

2.11.3 Corrections

 27607: Image Copyright info is not up to date.

 39584: Large application software images cannot be loaded. Affects

SoundPoint IP 550, 560 and 650 phones. Does not affect SIP 3.0.0 or

earlier releases.

2.12 Version 4.0.1 (Limited Release)

2.12.1 Added or Changed Features

 35817: Native VLAN ID, Auxiliary VLAN ID and CDP Power usage are

logged.

 36483: Add support for SoundPoint IP 560 platform.

 38357: Add ability to adjust the maximum brightness of the

SoundPoint IP 550 and 650 phones.

 38654: Add support for SoundPoint IP 320 Part Number 2345-12200-

005 and SoundPoint IP 330 Part Number 2345-12200-004 for China

market.

2.12.2 Removed Features

None.

2.12.3 Corrections

 27621: FTP Password may disappear in a specific scenario.

 32535: "Running 'sip.ld' " screen on IP430 has unwanted vertical line

on the display.

 37923: Phone stuck in reboot loop if app checksum is incorrect.

2.13 Version 4.0.0

2.13.1 Added or Changed Features

 25274: Send Vendor ID information through DHCP.

 26623: Add application version to boot log.

 29030: Add automatic provisioning support for individual image files.

 33652: Add SYSLOG feature.

 34401: Add BootROM update progress bar.

Release Notes - BootROM 4.3.1

 34625: Add ability to discover provisioning server address using

DHCPINFORM.

 35316: Add phone serial (MAC address) to user-agent string of HTTP

Get.

 35361: Add ability for parameters in MAC.cfg to be overridden by

model or platform specific versions.

 35362: Add part number and substitution macros for parameter

values in MAC.cfg.

 36030: Add Ethernet Ingress Filtering for DoS suppression and VLAN

filtering.

 36228: Add support for 16 levels of gray on LCD in BootROM on

SoundPoint IP 550 and 650 platforms.

2.13.2 Removed Features

 35344: BootROM will not provision configuration files anymore.

 35350: BootROM will not support start type that triggers a bootROM

upgrade.

2.13.3 Corrections

 27145: DHCP timeout setting is not used.

 27981/11858: DHCPDECLINE not sent if duplicate IP detected by

DHCP client on SoundStation IP 4000.

 33365: Boot time is too long with unreachable boot server.

 35463: Phone booting via URL displays password in boot log file.

 36107: SoundStation IP 4000 drops max size packets with VLAN

enabled.

 36658: DHCP broadcast flag is set on SoundPoint IP 330/320, 430,

550 and 650 phones.

 36659: DHCP Request does not use same 'xid' as the DHCP Offer.

 36682: DHCP: xid and IP header ID does not change on SoundPoint

IP 320, 330, 430, 550, 650, and SoundStation IP 4000.

 36905: CDP packet always advertises LAN duplex mode as "Duplex:

Full" on SoundPoint IP 300, 301, 500, and 501.

2.14 Version 3.2.3RevB

2.14.1 Added or Changed Features

 32146: Add support for SoundPoint IP 330 product.

Release Notes - BootROM 4.3.1

 33391: Add support for SoundPoint IP 320 product.

2.14.2 Removed Features

None.

2.14.3 Corrections

None.

2.15 Version 3.2.3

2.15.1 Added or Changed Features

 16110: Add support for SoundPoint IP 550 platform.

2.15.2 Removed Features

None.

2.15.3 Corrections

 34899: Phones can lose internal configuration after loss of power.

 35063: SoundPoint IP650 should request 6W (was 5W in prior

release) for PoE usage.

 35068: Reduce PoE power level requested by SoundPoint IP601

when configured for Expansion Module use (EM_Power=1) to 11W

(was 12W).

2.16 Version 3.2.2RevB

2.16.1 Added or Changed Features

 14874: Add support for SoundPoint IP 650 platform.

2.16.2 Removed Features

None.

2.16.3 Corrections

 18766: Ethernet transmit level is low on IP 430 platform.

2.17 Version 3.2.2

2.17.1 Added or Changed Features

 17412: Add ability to set Ethernet link mode on IP430 and IP 4000

platforms.

Release Notes - BootROM 4.3.1

2.17.2 Removed Features

None.

2.17.3 Corrections

 17134: BootROM „About‟ screen on IP430 shows incorrect VLAN

initially for few seconds and then goes to the correct one.

2.18 Version 3.2.1

2.18.1 Added or Changed Features

 11678: Add template support in master config. file.

 15930: Add ability to set Ethernet link mode on IP 601.

2.18.2 Removed Features

None.

2.18.3 Corrections

 12337: LCD flickers on IP 430.

 15956: Phone fails to up/download file after an up/download fails

during data transfer.

 16021: Ftp downloads may fail because phone improperly times out

connect attempts.

 16629: Set transfer time-out for image file download to worst case

scenario.

2.19 Version 3.2.0 (Beta Only)

2.19.1 Added or Changed Features

 Add support for IP4000 PoE PIM.

 13552: Improve boot-up diagnostics.

 13813: Add the ability for file transfers to attempt to contact multiple

IP's per DNS name.

 14400: Phone can take up to 30 minutes to boot when HTTP goes

through TCP timeouts.

 14625: BootROM takes 15 minutes if DNS server IPs are not valid.

2.19.2 Removed Features

None.

Release Notes - BootROM 4.3.1

2.19.3 Corrections

 14673: @ character is not accepted as part of the FTP user name,

password, or filename.

 14844: Failed downloads of pre-existing files causes deletion of pre-

existing files.

 15614: Having different parameters in flash based on platform can

cause issues.

2.20 Version 3.1.3 RevD

2.20.1 Added or Changed Features

None.

2.20.2 Removed Features

None.

2.20.3 Corrections

 12337: LCD flickers on IP430.

2.21 Version 3.1.3 RevC

2.21.1 Added or Changed Features

 12414: Add support for IP 430 hardware platform.

2.21.2 Removed Features

None.

2.21.3 Corrections

 15986: BootROM boots from a cached copy after downloading a

wrong signature load.

2.22 Version 3.1.3 RevB

2.22.1 Added or Changed Features

 9873: Maintain Ethernet link during boot-up sequence on IP 4000.

2.22.2 Removed Features

None.

Release Notes - BootROM 4.3.1

2.22.3 Corrections

None.

2.23 Version 3.1.3

2.23.1 Added or Changed Features

 14052: Add ability to disable Expansion Module support and reduce

CDP power requirements accordingly.

 14886: Change the power reported via CDP to the minimum required

value.

2.23.2 Removed Features

None.

2.23.3 Corrections

 13793: For HTTP digest authentication, cnonce from our phone is not

random.

 14489: Phone won't upload all log files to TFTP boot server if

log_file_directory specified on MAC.cfg doesn't exist on IP 300, IP

400 and IP 500.

 15104: CDP incorrectly advertises new link duplex levels on IP 4000

2.24 Version 3.1.2

2.24.1 Added or Changed Features

 13910: Prevent SSIP 4000 from downgrading to BootROM versions

that have bug #13361.

 13911: Auto detect and correct bug #13361 on SSIP 4000.

2.24.2 Removed Features - None.

2.24.3 Corrections - None.

2.25 Version 3.1.1

2.25.1 Added or Changed Features

 13475: User agent headers for HTTP will include the MAC address of

the phone when SAS-VP is enabled.

Release Notes - BootROM 4.3.1

2.25.2 Removed Features - None.

2.25.3 Corrections

 13361: SSIP 4000 may lose the custom CA Certificate or the SAS-VP

ID after file system activity.

2.26 Version 3.1.0

2.26.1 Added or Changed Features

 8761: Added IP 601 support.

2.26.2 Removed Features - None.

2.26.3 Corrections

 11857: Phone ignores short DHCP packets on SSIP 4000 SIP.

2.27 Version 3.0.1

2.27.1 Added or Changed Features

 11633: Use flash credentials when URLs lack them.

2.27.2 Removed Features - None.

2.27.3 Corrections

 2179: FTP password is present in the boot logs.

 11409: Provisioning may not work reliably with the proftpd FTP

server on Linux.

 11417: Phone may not be able to boot from a remote subnet.

2.28 Version 3.0.0

2.28.1 Added or Changed Features

 7663, 8970, 9299: Added ability to specify addresses as URLs.

 7847: Added support for HTTP boot server transport for SPIP

301/501/600/601 and SSIP 4000.

 7895: Add support for provisioning signed images only.

 9579: Allow specific master config file to be specified in boot server

URL.

Release Notes - BootROM 4.3.1

2.28.2 Removed Features

 11973: Removed support for port mode (Active) FTP server

configurations

Use an FTP server/firewall that supports passive mode connections.

2.28.3 Corrections

 9043: Phone does not reboot after a CDP VLAN change.

2.29 Version 2.6.2

2.29.1 Added or Changed Features - None.

2.29.2 Removed Features - None.

2.29.3 Corrections

 8553: DHCP short packets are ignored in the BootROM. Not fixed for

SoundStation IP 4000 SIP.

 11278: DHCP decline not sent on duplicate IP address. Not fixed for

SoundStation IP 4000 SIP.

2.30 Version 2.6.1

2.30.1 Added or Changed Features - None.

2.30.2 Removed Features - None.

2.30.3 Corrections

 9447: Phone fails to boot if the boot server is not present and the

application is not self-provisioning.

 9537: When using TFTP, the phone does not display the “Phone

could not contact the boot server” screen.

 9581: Phone does not format the file system if the application does

not fit.

2.31 Version 2.6.0

2.31.1 Added or Changed Features

 5761: Added support for the SoundStation IP 4000 SIP.

 7175: Made TFTP file provisioning consistent with FTP.

 8232: Added DHCP VLAN Discovery.

 8760: Added support for the SoundPoint IP 301.

Release Notes - BootROM 4.3.1

2.31.2 Removed Features - None.

2.31.3 Corrections

 6782: Invalid <MAC>.cfg can hang the phone.

 8548: Phone waits 2.5 minutes for SNTP to fail.

2.32 Version 2.5.1

2.32.1 Added or Changed Features - None.

2.32.2 Removed Features - None.

2.32.3 Corrections - None.

2.33 Version 2.5.0

2.33.1 Added or Changed Features

 5116: Added support for the SoundPoint IP 300.

2.33.2 Removed Features - None.

2.33.3 Corrections

 5191: FTP provisioning fails if the FTP server root directory is not

readable.

 5623: Hitting the left arrow key before the cursor advances moves

the cursor 2 spaces.

 5668: Spaces in the admin password are ignored.

 5754: Phone did not log out of FTP server after a BootROM update.

3 Notes

3.1 Outstanding Issues

None

Release Notes BootROM 4.3.1 SOUNDPOINT IP 300 Sound Point Boot ROM 4 3 1

Navigation menu

Versions of this User Manual:

Views

Navigation
