The TC-NT2 is a convenient and comprehensive cable tester
for network professionals. Its powerful and user-friendly
features enable network installers to accurately check pin
configurations of various voice and data communication
cables. The TC-NT2 includes a master unit that transmits test
signals to its corre-sponding remote terminator to verify cable
reliability. It checks continuity and displays wiring
configuration up to 300 meters of cable installation. With the
unique feature of the audio tone generator, the TC-NT2
identifies and troubleshoots faulty cables to assure proper pin
and wiring structure.
TC-NT2
Professional Cable Tester with Tone Generator
Tests Pin Configuration of 10/100/1000Base-T, 10Base-2 (coax), RJ-
11/RJ-12/RJ-45, EIA/TIA-356A/568A/568B, and Token Ring Cables
Tests USB and IEEE 1394 cables with optional adapters
Built-in Tone Generator for tracing cable with standard Tone Probe
Tests the grounding on shielded (screened) cable
Verifies cable continuity, opens, shorts, and miswires
Tests cable up to 300 meters
Auto-Scan or Manual-Scan mode
Includes Deluxe Carrying Pouch, two RJ45-to-BNC Adapters, and
RJ45 Patch Cable
1-year warranty
FEATURES PRODUCT INFORMATION
TC-NT1: Network Cable Tester for
UTP, STP, Coaxial, and Modular
Cables
TC-NT2: Network Cable Tester with
Tone Generator for UTP, STP, Coaxial,
and Modular Cables
TC-CT68: RJ-11/RJ-45 Crimp/Cut/Strip
Tool
TC-PDT: Punch Down Tool with 110
and Krone Blade
TC-1KC5G: 1,000 feet Solid CAT5e
UTP Cable
To Order Please Call:
1-888-326-6061
ORDERING INFORMATIONORDERING INFORMATION
Power Requirement: One DC 9V battery
Tone Frequency: 600 ~ 800 Hz.
Dimensions (appr.): Master Unit: 115 x 68 x 27 mm
(4.5 x 2.7 x 1.1 inch)
Remote Terminator: 118 x 32 x 27 mm (4.6 x 1.3 x 1.1 inch)
Operating Temp: 0° C ~ 45° C (32° F ~ 113° F)
Weight (appr.): Master Unit: 113 gram (4 Oz.) (without battery)
Remote Terminator: 57 gram (2 Oz.)
SPECIFICATIONS
TC-NT2 (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: 310-891-1100
Fax: 310-891-1111
Web:
Email: sales@trendware.com
www.TRENDNET.com
