MANUAL OVERRIDE:
Press the hold the “TIME” button, and press the
“OFF” button repeatedly to select from the
following options:
Continuously ON: The Digital LED will display “O”.
Continuously OFF: The Digital LED will display “F”.
Return to Timer control: The Digital LED will
display the current time.
WARNING:
When used outdoors this timer must be plugged
into a GFCI protected outlet to prevent shock
hazard. Let the switch hang downward so moisture
doesn’t accumulate in the outlet. Install cord and
unit above ground level with the receptacle in down-
ward minimum 1.5m above ground. Suitable for
damp locations. Not for water immersion or for use
were directly exposed to water. Store indoors when
not in use.
DO NOT splice, repair or modify. Unplug when not in
use. Fully insert plug. DO NOT use damaged remote
sets. Inspect periodically. Use within the electrical
rating as the specification. DO NOT plug more than
a total 1,000 watts in this unit. If watts are not
marked on appliance, multiply ampere rating (on
nameplate) by 125 to determine equivalent watts.
Add determined watts for each plugged-in appliance
or lamp (sum of watts on bulbs) to find total watts
being used. Operating temperature range -30C
(-22F) to 45C (113F).
PROGRAMMING INSTRUCTION:
Plug the timer into a power outlet. “C” will
appear on the Digital LED.
Set Current Time:
Press the “TIME” button repeatedly to set the
current hour. The dot at the bottom right of the
Digital LED will appear to indicate PM hours.
Set Off Time:
Press the “OFF” button repeatedly to set the
OFF hour. The dot at the bottom right of the
Digital LED will appear to indicate PM hours.
Press the “TIME” button to complete the
programming. Your timer is now set to turn the
plugged-in devices ON at Dusk and OFF at the
time you set, or at Dawn, whichever comes first.
REVIEW OFF TIME SETTING:
Press the “OFF” button once. The Digital LED will
display “E” first and then the OFF time.
NOTES:
The unit you are plugging into the timer must be on
for the timer to function properly.
Toll-Free Customer Support: 1.800.730.3707
Plug the timer to the power outlet,
the Digital LED will light up.
3-Wire Grounded Outlet and Plug
Rated: 125V/8A/1000WTungsten/60Hz
3-Outlet Photocell Digital Timer
TIME OFF
ON
Time It™
is trademark of The NCC, Inc.
Distributed by: The NCC, Inc., Brooklyn, NY 11220 • www.thencc.com Made in China
SAVE THESE INSTRUCTIONS!
