The String Instructions Chapter Six

The String Instructions

Beta Draft - Do not distribute

Page

935

The String Instructions

Chapter Six

6.1

Chapter Overview

A string is a collection of objects stored in contiguous memory locations. Strings are usually arrays of

bytes, w

ords, or (on 80386 and later processors) double w

ords.

The 80x86 microprocessor f

amily supports

eral instructions speciﬁ

cally designed to cope with strings.

This chapter e

xplores some of the uses of

these string instructions.

The 80x86 CPUs can process three types of strings: byte strings

, w

ord strings

, and double w

ord strings

The

y can mo

e strings

, compare strings

, search for a speciﬁ

c v

alue within a string

, initialize a string to a

ﬁ

ed v

alue

, and do other primiti

e operations on strings.

The 80x86’

s string instructions are also useful for

manipulating arrays, tables, and records.

ou can easily assign or compare such data structures using the

string instructions. Using string instructions may speed up your array manipulation code considerably

6.2

The 80x86 String Instructions

All members of the 80x86 f

amily support ﬁ

e dif

ferent string instructions: MO

, CMPS

, SCAS

LODS

, and ST

. (

= B,

, or D for byte, w

ord, or double w

ord, respecti

ely

This te

xt will generally

drop the x suf

ﬁ

x when talking about these string instructions in a general sense.)

The

y are the string primi

since you can b

uild most other string operations from these ﬁ

e instructions. Ho

w you use these ﬁ

instructions is the topic of the ne

xt se

eral sections.

For MOVS:

movsb();

movsw();

movsd();

For CMPS:

cmpsb(); // Note: repz is a synonym for repe

cmpsw();

cmpsd();

cmpsb(); // Note: repnz is a synonym for repne.

cmpsw();

cmpsd();

For SCAS:

scasb(); // Note: repz is a synonym for repe

scasw();

scasd();

scasb(); // Note: repnz is a synonym for repne.

scasw();

scasd();

For STOS:

stosb();

stosw();

stosd();

1. The 80x86 processor support two additional string instructions, INS and OUTS which input strings of data from an input

port or output strings of data to an output port. We will not consider these instructions since they are privileged instructions

and you cannot execute them in a standard 32-bit OS application.

Chapter Six

Volume Six

Page

936

Beta Draft - Do not distribute

For LODS:

lodsb();

lodsw();

lodsd();

6.2.1

How the String Instructions Operate

The string instructions operate on blocks (contiguous linear arrays) of memory

. F

or e

xample, the MO

instruction mo

es a sequence of bytes from one memory location to another

The CMPS instruction com

pares tw

o blocks of memory

The SCAS instruction scans a block of memory for a particular v

alue.

These

string instructions often require three operands, a destination block address, a source block address, and

(optionally) an element count. F

or e

xample, when using the MO

VS instruction to cop

y a string, you need a

source address, a destination address, and a count (the number of string elements to mo

e).

Unlik

e other instructions which operate on memory

, the string instructions don’

t ha

e an

y e

xplicit oper

ands.

The operands for the string instructions include

•

the ESI (source index) register,

• the EDI (destination index) register,

• the ECX (count) register,

• the AL/AX/EAX register, and

• the direction ﬂag in the FLAGS register.

For example, one variant of the MOVS (move string) instruction copies a string from the source address

speciﬁed by ESI to the destination address speciﬁed by EDI, of length ECX. Likewise, the CMPS instruction

compares the string pointed at by ESI, of length ECX, to the string pointed at by EDI.

Not all instructions have source and destination operands (only MOVS and CMPS support them). For

example, the SCAS instruction (scan a string) compares the value in the accumulator (AL, AX, or EAX) to

values in memory.

6.2.2

The REP/REPE/REPZ and REPNZ/REPNE Preﬁxes

The string instructions, by themselv

es, do not operate on strings of data.

The MO

VS instruction, for

xample, will mo

e a single byte, w

ord, or double w

ord.

When e

ecuted by itself, the MO

VS instruction

ignores the v

alue in the ECX re

gister

The repeat preﬁ

xes tell the 80x86 to do a multi-byte string operation.

The syntax for the repeat preﬁx is:

For MOVS:

rep.movsb();

rep.movsw();

rep.movsd();

For CMPS:

repe.cmpsb(); // Note: repz is a synonym for repe.

repe.cmpsw();

repe.cmpsd();

repne.cmpsb(); // Note: repnz is a synonym for repne.

repne.cmpsw();

repne.cmpsd();

For SCAS:

repe.scasb(); // Note: repz is a synonym for repe.

repe.scasw();

repe.scasd();

The String Instructions

repne.scasb(); // Note: repnz is a synonym for repne.

repne.scasw();

repne.scasd();

For STOS:

rep.stosb();

rep.stosw();

rep.stosd();

You don’t normally use the repeat preﬁxes with the LODS instruction.

When specifying the repeat preﬁx before a string instruction, the string instruction repeats ECX times2.

Without the repeat preﬁx, the instruction operates only on a single byte, word, or double word.

You can use repeat preﬁxes to process entire strings with a single instruction. You can use the string

instructions, without the repeat preﬁx, as string primitive operations to synthesize more powerful string

operations.

6.2.3 The Direction Flag

Besides the ESI, EDI, ECX, and AL/AX/EAX registers, one other register controls the 80x86’s string

instructions – the ﬂags register. Speciﬁcally, the direction ﬂag in the ﬂags register controls how the CPU pro-

cesses strings.

If the direction ﬂag is clear, the CPU increments ESI and EDI after operating upon each string element.

For example, if the direction ﬂag is clear, then executing MOVS will move the byte, word, or double word at

ESI to EDI and will increment ESI and EDI by one, two, or four. When specifying the REP preﬁx before this

instruction, the CPU increments ESI and EDI for each element in the string. At completion, the ESI and EDI

registers will be pointing at the ﬁrst item beyond the strings.

If the direction ﬂag is set, then the 80x86 decrements ESI and EDI after processing each string element.

After a repeated string operation, the ESI and EDI registers will be pointing at the ﬁrst byte or word before

the strings if the direction ﬂag was set.

The direction ﬂag may be set or cleared using the CLD (clear direction ﬂag) and STD (set direction ﬂag)

instructions. When using these instructions inside a procedure, keep in mind that they modify the machine

state. Therefore, you may need to save the direction ﬂag during the execution of that procedure. The follow-

ing example exhibits the kinds of problems you might encounter:

procedure Str2; nodisplay;

begin Str2;

std();

end Str2;

cld();

Str2();

2. Except for the cmps instruction which repeats at most the number of times speciﬁed in the cx register.

Chapter Six Volume Six

This code will not work properly. The calling code assumes that the direction ﬂag is clear after Str2

returns. However, this isn’t true. Therefore, the string operations executed after the call to Str2 will not func-

tion properly.

There are a couple of ways to handle this problem. The ﬁrst, and probably the most obvious, is always to

insert the CLD or STD instructions immediately before executing a sequence of one or more string instruc-

tions. The other alternative is to save and restore the direction ﬂag using the PUSHFD and POPFD instruc-

tions. Using these two techniques, the code above would look like this:

Always issuing CLD or STD before a string instruction:

procedure Str2; nodisplay;

begin Str2;

std();

end Str2;

cld();

Str2();

cld();

Saving and restoring the ﬂags register:

procedure Str2; nodisplay;

begin Str2;

pushfd();

std();

popfd();

end Str2;

cld();

Str2();

If you use the PUSHFD and POPFD instructions to save and restore the ﬂags register, keep in mind that

you’re saving and restoring all the ﬂags. Therefore, such subroutines cannot return any information in the

ﬂags. For example, you will not be able to return an error condition in the carry ﬂag if you use PUSHFD and

POPFD.

6.2.4 The MOVS Instruction

The MOVS instruction uses the following syntax:

movsb()

The String Instructions

movsw()

movsd()

rep.movsb()

rep.movsw()

rep.movsd()

The MOVSB (move string, bytes) instruction fetches the byte at address ESI, stores it at address EDI

and then increments or decrements the ESI and EDI registers by one. If the REP preﬁx is present, the CPU

checks ECX to see if it contains zero. If not, then it moves the byte from ESI to EDI and decrements the

ECX register. This process repeats until ECX becomes zero.

The MOVSW (move string, words) instruction fetches the word at address ESI, stores it at address EDI

and then increments or decrements ESI and EDI by two. If there is a REP preﬁx, then the CPU repeats this

procedure as many times as speciﬁed in ECX.

The MOVSD instruction operates in a similar fashion on double words. Incrementing or decrementing

ESI and EDI by four for each data movement.

When you use the rep preﬁx, the MOVSB instruction moves the number of bytes you specify in the

ECX register. The following code segment copies 384 bytes from CharArray1 to CharArray2:

CharArray1: byte[ 384 ];

CharArray2: byte[ 384 ];

cld();

lea( esi, CharArray1 );

lea( edi, CharArray2 );

mov( 384, ecx );

rep.movsb();

If you substitute MOVSW for MOVSB, then the code above will move 384 words (768 bytes) rather

than 384 bytes:

WordArray1: word[ 384 ];

WordArray2: word[ 384 ];

cld();

lea( esi, WordArray1 );

lea( edi, WordArray2 );

mov( 384, ecx );

rep.movsw();

Remember, the ECX register contains the element count, not the byte count. When using the MOVSW

instruction, the CPU moves the number of words speciﬁed in the ECX register. Similarly, MOVSD moves

the number of double words you specify in the ECX register, not the number of bytes.

If you’ve set the direction ﬂag before executing a MOVSB/MOVSW/MOVSD instruction, the CPU dec-

rements the ESI and EDI registers after moving each string element. This means that the ESI and EDI regis-

ters must point at the end of their respective strings before issuing a MOVSB, MOVSW, or MOVSD

instruction. For example,

CharArray1: byte[ 384 ];

CharArray2: byte[ 384 ];

cld();

lea( esi, CharArray1[383] );

lea( edi, CharArray2[383] );

Chapter Six Volume Six

mov( 384, ecx );

rep.movsb();

Although there are times when processing a string from tail to head is useful (see the CMPS description

in the next section), generally you’ll process strings in the forward direction since it’s more straightforward

to do so. There is one class of string operations where being able to process strings in both directions is abso-

lutely mandatory: processing strings when the source and destination blocks overlap. Consider what happens

in the following code:

CharArray1: byte;

CharArray2: byte[ 384 ];

cld();

lea( esi, CharArray1 );

lea( edi, CharArray2 );

mov( 384, ecx );

rep.movsb();

This sequence of instructions treats CharArray1 and CharArray2 as a pair of 384 byte strings. However,

the last 383 bytes in the CharArray1 array overlap the ﬁrst 383 bytes in the CharArray2 array. Let’s trace the

operation of this code byte by byte.

When the CPU executes the MOVSB instruction, it copies the byte at ESI (CharArray1) to the byte

pointed at by EDI (CharArray2). Then it increments ESI and EDI, decrements ECX by one, and repeats this

process. Now the ESI register points at CharArray1+1 (which is the address of CharArray2) and the EDI

pointed at by EDI. However, this is the byte originally copied from location CharArray1. So the MOVSB

instruction copies the value originally in location CharArray1 to both locations CharArray2 and

CharArray2+1. Again, the CPU increments ESI and EDI, decrements ECX, and repeats this operation. Now

the movsb instruction copies the byte from location CharArray1+2 (CharArray2+1) to location

CharArray2+2. But once again, this is the value that originally appeared in location CharArray1. Each repe-

tition of the loop copies the next element in CharArray1[0] to the next available location in the CharArray2

array. Pictorially, it looks something like that shown in Figure 6.1.

The String Instructions

Figure 6.1 Copying Data Between Two Overlapping Arrays (forward direction)

The end result is that the MOVSB instruction replicates X throughout the string. The MOVSB instruc-

tion copies the source operand into the memory location which will become the source operand for the very

next move operation, which causes the replication.

If you really want to move one array into another when they overlap, you should move each element of

the source string to the destination string starting at the end of the two strings as shown in Figure 6.2.

XABCDEFGH I JKL

1st move operation:

XXBCDEFGH I JKL

2nd move operation:

XXXCDEFGH I JKL

3rd move operation:

XXXXDEFGH I JKL

4th move operation:

XXXXXXXXX X XXL

nth move operation:

Chapter Six Volume Six

Figure 6.2 Using a Backwards Copy to Copy Data in Overlapping Arrays

Setting the direction ﬂag and pointing ESI and EDI at the end of the strings will allow you to (correctly)

move one string to another when the two strings overlap and the source string begins at a lower address than

the destination string. If the two strings overlap and the source string begins at a higher address than the des-

tination string, then clear the direction ﬂag and point ESI and EDI at the beginning of the two strings.

If the two strings do not overlap, then you can use either technique to move the strings around in mem-

ory. Generally, operating with the direction ﬂag clear is the easiest, so that makes the most sense in this case.

You shouldn’t use the MOVSx instruction to ﬁll an array with a single byte, word, or double word value.

Another string instruction, STOS, is much better for this purpose. However, for arrays whose elements are

larger than four bytes, you can use the MOVS instruction to initialize the entire array to the content of the

ﬁrst element.

The MOVS instruction is generally more efﬁcient when copying double words than it is copying bytes

or words. In fact, it typically takes the same amount of time to copy a byte using MOVSB as it does to copy

a double word using MOVSD3. Therefore, if you are moving a large number of bytes from one array to

another, the copy operation will be faster if you can use the MOVSD instruction rather than the MOVSB

3. This is true for MOVSW, as well.

XABCDEFGHIJKL

1st move operation:

XAB

CDEFGH IJKK

2nd move operation:

XAB

CDEFGH IJJK

3rd move operation:

XAB

CDEFGH IIJK

4th move operation:

XAA

BCDEF G HIJK

nth move operation:

The String Instructions

instruction. Of course, if the number of bytes you wish to move is an even multiple of four, this is a trivial

change; just divide the number of bytes to copy by four, load this value into ECX, and then use the MOVSB

instruction. If the number of bytes is not evenly divisible by four, then you can use the MOVSD instruction

to copy all but the last one, two, or three bytes of the array (that is, the remainder after you divide the byte

count by four). For example, if you want to efﬁciently move 4099 bytes, you can do so with the following

instruction sequence:

lea( esi, Source );

lea( edi, Destination );

mov( 1024, ecx ); // Copy 1024 dwords = 4096 bytes

rep.movsd();

movsw(); // Copy bytes 4097 and 4098.

movsb(); // Copy the last byte.

Using this technique to copy data never requires more than three MOVSx instructions since you can copy

one, two, or three bytes with no more than two MOVSB and MOVSW instructions. The scheme above is

most efﬁcient if the two arrays are aligned on double word boundaries. If not, you might want to move the

MOVSB or MOVSW instruction (or both) before the MOVSD so that the MOVSD instruction works with

dword-aligned data (see Chapter Three for an explanation of the performance beneﬁts of double word

aligned data).

If you do not know the size of the block you are copying until the program executes, you can still use

code like the following to improve the performance of a block move of bytes:

lea( esi, Source );

lea( edi, Dest );

mov( Length, ecx );

shr( 2, ecx ); // divide by four.

if( @nz ) then // Only execute MOVSD if four or more bytes.

rep.movsd(); // Copy the dwords.

endif;

mov( Length, ecx );

and( %11, ecx ); // Compute (Length mod 4).

if( @nz ) then // Only execute MOVSB if #bytes/4 <> 0.

rep.movsb(); // Copy the remaining one, two, or three bytes.

endif;

On most computer systems, the MOVSD instruction provides about the fastest way to copy bulk data

from one location to another. While there are, arguably, faster ways to copy the data on certain CPUs, ulti-

mately the memory bus performance is the limiting factor and the CPUs are generally much faster than the

memory bus. Therefore, unless you have a special system, writing fancy code to improve memory to mem-

ory transfers is probably a waste of time. Also note that Intel has improved the performance of the MOVSx

instructions on later processors so that MOVSB operates almost as efﬁciently as MOVSW and MOVSD

when copying the same number of bytes. Therefore, when working on a later x86 processor, it may be more

efﬁcient to simply use MOVSB to copy the speciﬁed number of bytes rather than go through all the com-

plexity outlined above.

6.2.5 The CMPS Instruction

The CMPS instruction compares two strings. The CPU compares the string referenced by EDI to the

string pointed at by ESI. ECX contains the length of the two strings (when using the REPE or REPNE pre-

ﬁx). Like the MOVS instruction, HLA allows several different forms of this instruction:

cmpsb();

cmpsw();

Chapter Six Volume Six

cmpsd();

repe.cmpsb();

repe.cmpsw();

repe.cmpsd();

repne.cmpsb();

repne.cmpsw();

repne.cmpsd();

Like the MOVS instruction you specify the actual operand addresses in the ESI and EDI registers.

Without a repeat preﬁx, the CMPS instruction subtracts the value at location EDI from the value at ESI

and updates the ﬂags. Other than updating the ﬂags, the CPU doesn’t use the difference produced by this

subtraction. After comparing the two locations, CMPS increments or decrements the ESI and EDI registers

by one, two, or four (for CMPSB/CMPSW/CMPSD, respectively). CMPS increments the ESI and EDI reg-

isters if the direction ﬂag is clear and decrements them otherwise.

Of course, you will not tap the real power of the CMPS instruction using it to compare single bytes,

words, or double words in memory. This instruction shines when you use it to compare whole strings. With

CMPS, you can compare consecutive elements in a string until you ﬁnd a match or until consecutive ele-

ments do not match.

To compare two strings to see if they are equal or not equal, you must compare corresponding elements

in a string until they don’t match. Consider the following strings:

“String1”

The only way to determine that these two strings are equal is to compare each character in the ﬁrst string

to the corresponding character in the second. After all, the second string could have been “String2” which

deﬁnitely is not equal to “String1”. Of course, once you encounter a character in the destination string which

doesn’t equal the corresponding character in the source string, the comparison can stop. You needn’t com-

pare any other characters in the two strings.

The REPE preﬁx accomplishes this operation. It will compare successive elements in a string as long as

they are equal and ECX is greater than zero. We could compare the two strings above using the following

80x86 assembly language code:

cld();

mov( AdrsString1, esi );

mov( AdrsString2, edi );

mov( 7, ecx );

repe.cmpsb();

After the execution of the CMPSB instruction, you can test the ﬂags using the standard conditional jump

instructions. This lets you check for equality, inequality, less than, greater than, etc.

Character strings are usually compared using lexicographical ordering. In lexicographical ordering, the

least signiﬁcant element of a string carries the most weight. This is in direct contrast to standard integer com-

parisons where the most signiﬁcant portion of the number carries the most weight. Furthermore, the length

of a string affects the comparison only if the two strings are identical up to the length of the shorter string.

For example, “Zebra” is less than “Zebras”, because it is the shorter of the two strings, however, “Zebra” is

greater than “AAAAAAAAAAH!” even though it is shorter. Lexicographical comparisons compare corre-

sponding elements until encountering a character which doesn’t match, or until encountering the end of the

shorter string. If a pair of corresponding characters do not match, then this algorithm compares the two

strings based on that single character. If the two strings match up to the length of the shorter string, we must

compare their length. The two strings are equal if and only if their lengths are equal and each corresponding

pair of characters in the two strings is identical. Lexicographical ordering is the standard alphabetical order-

ing you’ve grown up with.

For character strings, use the CMPS instruction in the following manner:

The String Instructions

• The direction ﬂag must be cleared before comparing the strings.

•Use the CMPSB instruction to compare the strings on a byte by byte basis. Even if the strings

contain an even number of characters, you cannot use the CMPSW or CMPSD instructions.

They do not compare strings in lexicographical order.

•You must load the ECX register with the length of the smaller string.

• Use the REPE preﬁx.

•The ESI and EDI registers must point at the very ﬁrst character in the two strings you want to

compare.

After the execution of the CMPS instruction, if the two strings were equal, their lengths must be com-

pared in order to ﬁnish the comparison. The following code compares a couple of character strings:

mov( AdrsStr1, esi );

mov( AdrsStr2, edi );

mov( LengthSrc, ecx );

if( ecx > LengthDest ) then // Put the length of the shorter string in ECX.

mov( LengthDest, ecx );

endif;

repe.cmpsb();

if( @z ) then // If equal to the length of the shorter string, cmp lengths.

mov( LengthSrc, ecx );

cmp( ecx, LengthDest );

endif;

If you’re using bytes to hold the string lengths, you should adjust this code appropriately (i.e., use a MOVZX

instruction to load the lengths into ECX). Of course, HLA strings use a double word to hold the current

length value, so this isn’t an issue when using HLA strings.

You can also use the CMPS instruction to compare multi-word integer values (that is, extended preci-

sion integer values). Because of the amount of setup required for a string comparison, this isn’t practical for

integer values less than six or eight double words in length, but for large integer values, it’s an excellent way

to compare such values. Unlike character strings, we cannot compare integer strings using a lexicographical

ordering. When comparing strings, we compare the characters from the least signiﬁcant byte to the most sig-

niﬁcant byte. When comparing integers, we must compare the values from the most signiﬁcant byte (or

word/double word) down to the least signiﬁcant byte, word or double word. So, to compare two 32-byte

(256-bit) integer values, use the following code on the 80x86:

std();

lea( esi, SourceInteger[28] );

lea( edi, DestInteger[28] );

mov( 8, ecx );

rep.cmpsd();

This code compares the integers from their most signiﬁcant word down to the least signiﬁcant word. The

CMPSD instruction ﬁnishes when the two values are unequal or upon decrementing ECX to zero (implying

that the two values are equal). Once again, the ﬂags provide the result of the comparison.

The REPNE preﬁx will instruct the CMPS instruction to compare successive string elements as long as

they do not match. The 80x86 ﬂags are of little use after the execution of this instruction. Either the ECX

compared in the two strings until a match. While this form of the CMPS instruction isn’t particularly useful

for comparing strings, it is useful for locating the ﬁrst pair of matching items in a couple of byte, word, or

double word arrays. In general, though, you’ll rarely use the REPNE preﬁx with CMPS.

One last thing to keep in mind with using the CMPS instruction – the value in the ECX register deter-

mines the number of elements to process, not the number of bytes. Therefore, when using CMPSW, ECX

Chapter Six Volume Six

speciﬁes the number of words to compare. This, of course, is twice the number of bytes to compare. Like-

wise, for CMPSD, ECX contains the number of double words to process.

6.2.6 The SCAS Instruction

The CMPS instruction compares two strings against one another. You do not use it to search for a partic-

ular element within a string. For example, you could not use the CMPS instruction to quickly scan for a zero

throughout some other string. You can use the SCAS (scan string) instruction for this task.

Unlike the MOVS and CMPS instructions, the SCAS instruction only requires a destination string

(pointed at by EDI) rather than both a source and destination string. The source operand is the value in the

AL (SCASB), AX (SCASW), or EAX (SCASD) register. The SCAS instruction compares the value in the

accumulator (AL, AX, or EAX) against the value pointed at by EDI and then increments (or decrements)

EDI by one, two, or four. The CPU sets the ﬂags according to the result of the comparison. While this might

be useful on occasion, SCAS is a lot more useful when using the REPE and REPNE preﬁxes.

With the REPE preﬁx (repeat while equal), SCAS scans the string searching for an element which does

not match the value in the accumulator. When using the REPNE preﬁx (repeat while not equal), SCAS scans

the string searching for the ﬁrst string element which is equal to the value in the accumulator.

You’re probably wondering “why do these preﬁxes do exactly the opposite of what they ought to do?”

The paragraphs above haven’t quite phrased the operation of the SCAS instruction properly. When using the

REPE preﬁx with SCAS, the 80x86 scans through the string while the value in the accumulator is equal to

the string operand. This is equivalent to searching through the string for the ﬁrst element which does not

match the value in the accumulator. The SCAS instruction with REPNE scans through the string while the

accumulator is not equal to the string operand. Of course, this form searches for the ﬁrst value in the string

which matches the value in the accumulator register. The SCAS instructions take the following forms:

scasb()

scasw()

scasd()

repe.scasb()

repe.scasw()

repe.scasd()

repne.scasb()

repne.scasw()

repne.scasd()

Like the CMPS and MOVS instructions, the value in the ECX register speciﬁes the number of elements

to process, not bytes, when using a repeat preﬁx.

6.2.7 The STOS Instruction

The STOS instruction stores the value in the accumulator at the location speciﬁed by EDI. After storing

the value, the CPU increments or decrements EDI depending upon the state of the direction ﬂag. Although

the STOS instruction has many uses, its primary use is to initialize arrays and strings to a constant value. For

example, if you have a 256-byte array you want to clear out with zeros, use the following code:

cld();

lea( edi, DestArray );

mov( 64, ecx ); // 64 double words = 256 bytes.

xor( eax, eax ); // Zero out EAX.

rep.stosd();

This code writes 64 double words rather than 256 bytes because a single STOSD operation is faster than four

STOSB operations.

The String Instructions

The STOS instructions take four forms. They are

stosb();

stosw();

stosd();

rep.stosb();

rep.stosw();

rep.stosd();

The STOSB instruction stores the value in the AL register into the speciﬁed memory location(s), the

STOSW instruction stores the AX register into the speciﬁed memory location(s) and the STOSD instruction

stores EAX into the speciﬁed location(s).

Keep in mind that the STOS instruction is useful only for initializing a byte, word, or double word array

to a constant value. If you need to initialize an array to different values, you cannot use the STOS instruction.

See the exercises for additional details.

6.2.8 The LODS Instruction

The LODS instruction is unique among the string instructions. You will probably never use a repeat pre-

ﬁx with this instruction. The LODS instruction copies the byte, word, or double word pointed at by ESI into

the AL, AX, or EAX register, after which it increments or decrements the ESI register by one, two, or four.

Repeating this instruction via the repeat preﬁx would serve no purpose whatsoever since the accumulator

accumulator will contain the last value read from memory.

Instead, use the LODS instruction to fetch bytes (LODSB), words (LODSW), or double words

(LODSD) from memory for further processing. By using the STOS instruction, you can synthesize powerful

string operations.

Like the STOS instruction, the LODS instructions take four forms:

lodsb();

lodsw();

lodsd();

rep.lodsb();

rep.lodsw();

rep.lodsd();

As mentioned earlier, you’ll rarely, if ever, use the REP preﬁxes with these instructions4. The 80x86

increments or decrements ESI by one, two, or four depending on the direction ﬂag and whether you’re using

the LODSB, LODSW, or LODSD instruction.

6.2.9 Building Complex String Functions from LODS and STOS

The 80x86 supports only ﬁve different string instructions: MOVS, CMPS, SCAS, LODS, and STOS5.

These certainly aren’t the only string operations you’ll ever want to use. However, you can use the LODS

and STOS instructions to easily generate any particular string operation you like. For example, suppose you

wanted a string operation that converts all the upper case characters in a string to lower case. You could use

the following code:

mov( StringAddress, esi ); // Load string address into ESI.

mov( esi, edi ); // Also point EDI here.

4. They appear here simply because they are allowed. They’re not veryuseful, but they are allowed.

5. Not counting INS and OUTS which we’re ignoring here.

Chapter Six Volume Six

mov( (type str.strrec [esi].length, ecx );

repeat

lodsb(); // Get the next character in the string.

if( al in ’A’..’Z’ ) then

or( $20, al ); // Convert upper case character to lower case.

endif;

stosb(); // Store converted character back into string.

dec( ecx );

until( ecx == 0 );

Since the LODS and STOS instructions use the accumulator as an intermediary, you can use any accu-

mulator operation to quickly manipulate string elements.

6.3 Putting It All Together

In this chapter we took a quick look at the 80x86’s string instructions. We studied their implementation

and saw how to use them. These instructions are quite useful for synthesizing character set functions (see

the source code for the HLA Standard Library string module for examples). We also saw how to use these

instructions for non-character string purpose such as moving large blocks of memory (i.e., assigning one

array to another) and comparing large integer values. For more information on the use of these instructions,

please see the volume on Advanced String Handling.

AoA String Instructions

StringInstructions

StringInstructions

Navigation menu

Versions of this User Manual:

Views

Navigation
