CONTENTS

Recorders + Media + Mixers

A wide selection of recorders, players and mixers, including the popular

portable recorders range

Outboard Equipment

Effects and amplifiers to take your sound to a whole new level

Computer Zone

Computer music production gear including audio interfaces, MIDI keyboards,

microphones and software

Microphones

A huge choice of quality microphones and recording accessories from the

world’s best brands

Headphones + Speakers

A vast range of headphones and speakers for all purposes, including our own

Fortissimo MkII and Auditorium ranges

Stands + Lighting

A range of stands designed and manufactured to support a variety of purposes

whether on stage or in the studio

Cable + Connectors

A massive selection of cable and connectors covering every possible application

Leads + Looms + Snakes

The widest choice in the industry, over 800 different leads, looms and snakes for all

purposes

Cases + Racks + Service

A comprehensive range of quality pro audio cases, racks, patch panels, and

accessories

Acoustics

Sound treatment and soundproofing products to improve your sound whether

playing live or recording

4-21

22-31

32-43

44-83

84-111

112-130

132-159

160-177

178-191

192-205

2017 CAT PAGES 2-3:Layout 1 16/12/2016 16:07 Page 1

Website www.studiospares.com

Tel (UK Calls) 020 8208 9930

Tel (Non-UK Calls) +44 (0)20 8208 9930

Free Fax (Orders Only) 0800 731 3767

Returns 020 8208 9951

Accounts 020 8208 9936/34

Email sales@studiospares.com

Next Day Delivery cut off time 3pm

Methods of Ordering

Mainland GB

(Excludes Highlands and Islands)

Express per 20kg £4.99 (£5.99 inc VAT)

Next working day

Standard per 20kg £3.74 (£4.49 inc VAT)

2 - 5 working days

Letter post (<1kg + <£25) £2.08 (£2.49 inc VAT)

See page 207 for full delivery charges

Delivery Charges

Look out for Studiospares at the following events

this year:

Bett Show

January 25 - 28, ExCeL, London

PLASA Focus

May 9 - 10, Royal Armouries, Leeds

Events Schedule

PLASA members operate to a Code

of Ethics guaranteeing integrity.

964 North Circular Road, Staples Corner,

Neasden, London, NW2 7JR.

www.studiospares.com

Artwork origination by Studiospares Ltd.

Printed by Wyndeham Group.

All prices exclusive of VAT and are correct at time of going to press.

Studiospares endeavours to hold the catalogue price for the life of that

catalogue. However although many prices have fallen, others are rising

significantly. For this reason, we cannot guarantee catalogue prices. Prices

and specifications subject to change without notice. All special offers are

subject to stock availability. Full terms and conditions on p206. E&OE.

Welcometo the 2017 Studiospares Catalogue, your

single source for a massive and ever-increasing range

of the best professional audio products, including

hundreds of essential accessories and problem

solvers that other suppliers prefer to forget!

The Paper Catalogue!

You're holding it, a 200-page cornucopia of great brands and great gear! It doesn't

need power, you can skim-read it, fold down pages, look at 2 pages at the same

time, even tear pages out if you want! It's increasingly kind to the environment as

we've slimmed it down to half the size it was a few years ago. But we are all

shopping more online, so do you still want the paper catalogue? Please drop us

an email and let us know - we will publish some of your replies online. Your

feedback is very helpful as we consider what catalogues to produce in future.

Service

We continue to work tirelessly to

maintain our service at the highest

level. As I write this, the last 20

customer reviews on Trustpilot have

all been 5 stars! Our rating has

increased from 9.3 last year to a solid

9.4 today, and we thank everyone

who has taken the time to leave a

review.It's good to know that so

many of you still appreciate being

able to discuss your audio

requirements, before and after

making a purchase. Our fantastic

technical sales people, all Music Tech graduates, can advise on almost every

aspect of live sound and studio recording.

Simple and Flexible

We continue to make ordering and

dealing with Studiospares simple.

Having our whole operation and all

our stock in one location in England

certainly helps! We are also regularly

complimented for sorting things out

when they do go wrong - usually

logistical problems with the carriers.

Our mobile-friendly website will be

improved further early next year, Click and Collect is popular, Pay4Later offers

credit facilities to make your purchase more affordable, and Late Night Opening

on Thursdays is vital for many customers - as is the free on site parking, a rarity

in London.

Thank You

Still a family business after 34 years, we wouldn't be here without your support.

Thank you for trusting us with your pro-audio needs for over three decades!

Please let us know if we can improve any aspect of our operation. We look

forward to being of service again in the coming year.

Barry Lambden

Managing Director

NAMM is the National Association of

Music Merchants.

WELCOME

Monday 8.30am - 5pm

Tuesday 8.30am - 5pm

Wednesday 8.30am - 5pm

Thursday 8.30am - 8pm

Friday 8.30am - 5pm

Saturday CLOSED

Sunday CLOSED

Opening Times

Excellent

9.4

Customer Review Rating

2017 CAT PAGES 2-3:Layout 1 20/12/2016 12:07 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Portable Recorders

Portable Recorders 4

Portastudios 6

PC Card Recorders 6

CD Recorders 7

Other Recorders 7

CD Players 7

Media Players 7

USB/SD Players 8

DJ Media Players 8

CD-R 9

Memory Cards 9

Pen Drives 9

Tape 10

Cassettes 10

Media Accessories 10

Broadcast Consoles 10

Digital Mixers 10

Analogue Mixers 14

Powered Mixers 18

Zone Mixers 19

DJ Mixers 19

Other Mixers 19

Portable PA 20

PA Packages 21

Recorders + Players + Mixers

Portable Recorders

Zoom H2n

Portable Recorder

Representing a new generation of portable

recording, the H2n is Zoom’s most innovative

handheld recorder to date.

The Zoom H2n is the only portable recorder with five mic capsules

onboard. This design enables the H2n to offer four unique recording

modes: Mid-Side (MS) stereo, 90° X/Y stereo, 2-channel and 4-channel

surround sound. The H2n’s onboard 90° X/Y stereo condenser mics are

arranged with the right and left mics on the same axis. Choose between

2-channel mode, which combines the Mid-Side and X/Y mics, and 4-

channel mode, which records two separate stereo files, allowing you even

more post-production capability comes with Steinberg’s WaveLab LE 7

professional audio editing software.

H2n 361-290 £107.50

H2n Accessory Pack 361-291 £25.00

H2n + Accessory Pack 361-292 £124.17

Zoom H4n Pro

Portable Recorder

The H4n Pro is packed with features that

make it perfect for capturing audio for film.

With advanced X/Y microphones, incredibly natural-sounding preamps, and a

super-low noise floor, you can record everything from the Indy 500 to the fluttering

of a hummingbird with extraordinary realism. The onboard X/Y microphones

deliver spectacular stereo imaging, and two combo input jacks allow you to use

your favourite microphones as well. It also includes a headphone/line out jack to

easily send high-definition stereo directly to your camera. Capable of handling

up to 140 dB SPL, it can record everything from ear-splitting heavy metal

to bass-heavy EDM.

The Pro also functions as a 2-input/2-output USB audio interface for

PC or Mac. Cubase LE software included.

H4n Pro 378-640 £165.83

H4n Pro + 8GB SDHC Card 378-641 £166.66

Zoom H6

6-in, 2-out Handheld Recorder

The revolutionary H6 is the most versatile portable

recorder ever...

Four interchangeable input capsules—X/Y, MS, Shotgun, and Dual XLR/TRS

Combo—make the H6 the ultimate chameleon of the audio world, and its

advanced preamps make it the best-sounding one too. Four mic/line inputs with

XLR/TRS combo connectors, gain controls (real knobs!) and -20dB pads for

each input. Six-track simultaneous recording. Large full-colour LCD display,

angled so it's easy to read in all environments. Records directly to SD, SDHC

and SDXC cards up to 128GB. Phantom power for all main inputs:

+12/+24/+48V. Up to 24-bit/96kHz audio in BWF-compliant WAV or a variety of

MP3 formats. Multitrack to stereo internal mixdown. Whatever your application—

live recording, professional film/video work, or broadcast ENG (electronic news

gathering), etc.—the H6 can handle it with ease.

The Zoom H6 Accessory Pack includes a remote control unit, a windshield, a

mains PSU adapter and a USB cable,

H6 377-850 £274.17

H6 Accessory Pack 377-852 £37.50

H6 + Accessory Pack 377-853 £299.17

H6 XLR Microphone 377-858 £40.83

NEW

Zoom Q8

Video Audio Recorder

The perfect camera for music

and video creators everywhere.

• Marries high-definition video with

high-resolution audio

• 160 degree wide-angle lens and

digital zoom

• Groundbreaking interchangeable

mic capsule system

• Two XLR/TRS combo inputs

• Large full-color LCD touchscreen

for ease of use

• Built-in speaker and stereo

Headphone/Line Out jack

Q8 378-500 £279.17

Zoom Q4n

Handy Video Recorder

Combines Full HD 1080p video

with Zoom's high-quality audio

capture technology.

• Full HD 1080p/30 Video

• 120° X/Y Condenser Microphone

• Detachable 2.0" LCD Screen

• 130° Wide-Angle Lens

• Outboard Audio Controls

• Line-In/Stereo Mic Input Jack

• Combo Headphones/Line Output

Jack with Micro HDMI Output

• USB Port for Using Camcorder as a

Webcam

• 3-Prong Action Camera Mount

Compatible

Q4n 378-570 £220.83

NEW

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

2017 CAT PAGES 4-9:Layout 1 12/12/2016 11:57 Page 1

Portable Recorders 5

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Zoom H1

Zoom's smallest recorder ever!

Featuring renowned recording technology and studio-quality microphones, the

H1 gives you clean, clear stereo sound effortlessly.

The H1's onboard microphones are configured in an X/Y pattern, and are both

arranged on the same axis so that stereo sound is captured with remarkable

depth and clarity. It can record linear PCM (WAV) files at 24-bit/96 kHz, which

far exceeds CD quality, and also records in MP3 which maximizes recording time.

The H1 supports microSD cards with capacities of up to 32GB for hours of

recording, and unwanted background noise can be dramatically reduced using

the built-in low cut filter. The H1's stereo microphone input jack accepts stereo

line-level inputs. The H1 has a built-in reference speaker and uses USB 2.0.

Optional APH1 accessory pack (Code 361-200) also available. It includes a

windscreen, a mic clip adapter, adjustable tripod stand, a soft case, AC adapter

(USB type) and USB cable

Includes extra 2GB microSD card and one AA battery.

H1 Black 361-130 £65.83

APH1 Accessory Pack 361-200 £16.66

H1 + APH1 Accessory Pack 361-131 £78.33

Rycote Suspension for H1 208-500 £47.50

Rycote Audio Kit for H1 208-580 £82.50

Hot Shoe Mount for H1 377-940 £12.50

Zoom H5

Handy Recorder

Evolved recording in more ways

than one.

• Modular Mic and Input System

• Includes XY Microphone Module

• Four Simultaneous Inputs

• Uses SD Memory Cards

• Compatible with H6 Mic Modules

• Optional Shotgun Mic and XLR/TRS

Inputs

H5 377-950 £190.83

H5 + 8GB Card 377-951 £191.66

XYH5 Mic Capsule for H5 378-580 £62.50

PCH5 Protective Case 378-610 £20.83

Roland R-05

WAV/MP3 Recorder

The compact R-05 is easy to

use, affordable, and packed with

big-ticket features that raise the

bar in its price class.

• Stereo recording 24-bit 96kHz

• Direct to SD card. Battery life 30 Hr

Play, 16 Rec

• Onboard editing functions

• Music practice features

• Auto, record start, song split, level

adjust

• Built in stereo mic or external input

• Includes SD card and two AA

batteries

R-05 369-890 £137.50

R-05 + 4GB SD Card 369-895 £139.58

R-05 + 8GB SD Card 369-896 £141.67

Marantz PMD620 MKII

Solid State Recorder

Professional recording features

and flexible file formats.

• 2 quality condenser mics and

monitor speaker

• Solid state SD/SDHC media

• 16 & 24-bit recording, On-board

editing and playback features

• Including USB 2.0 connectivity

PMD620 MKII 271-870 £249.17

PMD620 MKII + 8GB Card 271-871 £249.99

Marantz PMD561

4-Channel Handheld Recorder

Professional recording features

and flexible file formats.

• Record professional-grade audio

directly to SD/SDHC flash media

• Selectable stereo / mono / .WAV /

MP3 recording

• 44.1, 48, and 96 kHz sample rates

• Selectable 16- and 24-bit recording

depths

• Six selectable sampling rates from

192 kbps to 32 kbps (MP3)

• S/PDIF Digital Input for connecting

to studio interfaces and more

• (2) Balanced XLR Mic inputs with

+48v phantom power

PMD561 272-340 £315.83

NEW

Zoom F8

Multi-Track Field Recorder

Designed for professional and

enthusiast recording

applications on set and in the

field.

• 8x XLR/TRS Combo Jacks with

+75 dB Gain

• Up to 192 kHz/ 24-Bit PCM

Recording

• Record Up to 10 Tracks

Simultaneously

• 2x SDXC Card Slots

• Built-In Slate Microphone

• 8x AA Batteries, AC, External DC

Adaptor

• +24V/+48V Phantom Power

F8 378-560 £750.00

NEW

Olympus LS-P1

Linear PCM Recorder

Allows you to record

professional quality audio in a

compact recorder.

• 4GB Internal Memory, for fast setup

and easy handling

• Stereo Microphones, offering a wide

stereo image for lifelike recordings

• 60Hz - 20kHz, to capture an almost

full range of music, including drums,

guitars and vocals

• Pocket Size, take this wherever you

need to go

LS-P1 359-440 £90.83

LS-P2 359-450 £124.17

NEW

Olympus LS-P2

Linear PCM Recorder

Delivers an accurate recording

across the full range of human

hearing, 20Hz - 20kHz.

• Three microphones for a wide

stereo image

• Integrated 8GB of built-in memory

• Additional 32GB available through

accessories

• Manual recording levels and limiter

• Bluetooth Connectivity

• 24-bit and 96kHz recording

NEW

Zoom IQ6

A stereo X/Y

microphone

with a

Lightning

connector

small enough

to slip into your

pocket.

Turn your favourite iOS

device into a field recorder by plugging in a Zoom iQ6. Capture

the sound of concerts, interviews, meetings and lectures with

precision and full fidelity, then share your creations with the

world. The compact and lightweight iQ6 allows you to create

high-quality recordings wherever you go. It features two high

quality unidirectional condenser microphones in an X/Y

configuration. You can even change the mic angle from 90

degrees for a tightly focused image to 120 degrees for

immersive wide-angle stereo.

iQ6 378-510 £62.50

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

More Products Online...

2017 CAT PAGES 4-9:Layout 1 12/12/2016 11:57 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Portable Recorders + PC Card Recorders + CD Recorders

Portable Recorders

Continued

Tascam DR-10SG

DSLR Audio Recorder with Shotgun Microphone

Packs problem-solving punch

into a small package.

• Features an extremely directional

supercardioid microphone and an

integrated shock-resistant mounting

foot

• Four selectable EQ modes

• On-board audio slate for

synchronization during post

production

• Dual Recording mode

DR-10SG 238-780 £132.50

NEW

PC Card Recorders

Gemini DRP-1

The DRP-1 is a 1U Rackmount Digital Recorder from Gemini offering USB flash

drive and up to 32GB SDHC compatibility for direct easy recording.

The DRP-1 from Gemini is a standalone digital rack mountable recorder that allows you to record and playback from one

convenient device. Its single rackspace design ensures discreet integration into your rack set up, making this handy recording

device ideal for DJs, musicians, bars, clubs, schools, houses of worship and anywhere else high-quality audio recording is a

must. For true recording versatility, the DRP-1 features a USB port and SD card slot, allowing you to record directly to a thumb

drive or memory card.

DRP-1 290-010 £182.50

CD Recorders

Denon DN-300CR

CDR/CDRW Recorder

A professional, full-featured CD recorder providing the highest

level of audio quality for broadcast, studio and entertainment

applications. The Denon Professional DN-300CR combines top-

flight audio performance, input/output flexibility, rack-mount

utility and robust construction. It records on standard CD-R and

CD-RW media, and CD text is programmed and read from the

front panel OLED display. Features specified by the installation

market include slot-in transport, programmable auto-track

increment, level-dependent sync recording, and more.

DN-300CR 272-260 £190.83

NEW

ALSO RECOMMENDED

Marantz PMD-901V

High definition recorder, to capture

the sights, sounds and locations.

271-970 £274.17

Tascam DR100 MKII

The MKII update brings added

professional features to the DR100.

228-640 £207.50

Tascam DR05

Records in MP3 or WAV format to

microSD or microSDHC media.

238-050 £72.92

Tascam DR40

Giving you the flexibility needed to

record anywhere.

238-160 £132.50

Roland R-26

An innovative hand-held recorder

with multi-dimensional sound

309-630 £299.17

ALSO RECOMMENDED

Marantz PMD661 MKII

The high definition audio and video

recorder at your fingertips.

271-860 £440.83

Tascam SD-20M

Designed for installations like

schools, house of worship,

and conferences.

238-800 £177.50

Stageline DPR-110

A 1U MP3 recorder with USB

interface and SD/MMC card

slot.

256-620 £149.99

Tascam SSR200

Features parallel and RS-

232C serial control balanced

& unbalanced I/O

238-260 £457.50 More products online...

ALSO RECOMMENDED

TEAC CDR-W890

A powerful unit capable of

transferring to CD from any

medium.

223-030 £245.83 More products online...

Keep up to date with all

the latest products and

current prices on the

Studiospares website!

Check out

www.studiospares.com

Trade Counter

Visit our trade counter!

You’ll get friendly advice

and immediate access to

8000+ product lines. Free

Parking also for 40 cars!

Delivery before noon...

No problem!

2017 CAT PAGES 4-9:Layout 1 12/12/2016 11:57 Page 3

NEW

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

TABLE STAND

£1

448-080

CD Recorders + Other Recorders + CD Players + Media Players 7

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Tascam CD-RW900MKII

One of the most popular CD recorders on the market!

TThe CD-RW900MKII features a new tray-loading transport which allows gapless recording when setting track marks. 24 bit

A/D & D/A converters, MP3 playback, key control, sample rate conversion, and selectable CD disc reading speed. It provides

dedicated analogue front panel input control, rear panel unbalanced (RCA) I/O, and SPDIF digital I/O (optical and coaxial).

Recently added features include Auto Cue and Auto Ready from the menu, selectable I/R remote Enable/Disable, and MP3

Action Setting (prevents accidental termination of continuous MP3 playback). Includes Pitch Control on playback (0.1 to 1.0%

in 0.1 steps), Auto or Manual track division, Sync Record Start, Power on Play, Elapsed, Remain, Total and Total remain Time

display, and CD-Text read and write.

Tascam CD-RW901MKII

Essentially the same specification as the CD-RW900Mk11 but with additional professional level analogue XLR connectors and

+4dBu output, a wired romote control, a parallel D-Sub 15 pin port plus a D-Sub 9 pin (RS232C) serial port. Intended for the

serious user.

CD-RW900MKII 238-730

238-740 £540.83

We only learn the difference between manufacturers

when things go wrong. Support for any professional

product is essential. Dealing with companies who

manufacture domestic equipment and stick rack ears

either end is problematic because a professional user

has higher expectations than the average consumer.

Tascam have served professional users with

appropriate products and service for around five

decades and are still going strong.

WHY

BUY TASCAM?

If you need more information, please contact our

technical sales team, who will be glad to help further.

Other Recorders

Tascam CD-200

Updated version of the best-selling

CD160!

The CD-200 offers a simple, cost-effective solution to

installations or PA rental where the extra features of a more

complex CD player might go unused. Yet it provides features

such as pitch control with an on/off knob, a headphone output

with level control, intro check, anti-shock memory, and a

variety of convenient playback modes which can help prevent

the user from making a mistake. The CD-200 can also play

back MP3 and WAV files from data CDs and display ID3 tags

and CD-Text. The included wireless remote control gives

access to most features and allows a track to be selected

directly via a 10-key pad.

Tascam CD-200SB

SD/USB/CD Player Rackmount

The CD-200 series with all the professional features plus

SD/SDHC and USB Memory Device playback support.

Supports numerous audio formats including CD:CD-DA,Data-

D(wav/mp3/mp2). D/SDHC/USB: wav/mp3/mp2/WMA/AAC.

CD-200 228-660 £207.50

CD-200SB 238-330 £332.50

Stageline CD156

Stereo CD Player

Stereo CD player for HiFi and PA applications.

• Double suspended, dampened player mechanism

• Title programming, repeat function (repeat 1, repeat all), random

replay, standard operating functions

• Adjustable headphone output

• Infrared remote control with direct title selection

CD156 260-310 £115.83

CD Players

Media Players

Newhank BDP-432

Blu-Ray DVD/USB Player

19” Rack Solution for Playback of Blu-rays and other

popular Media Formats from Disk or USB with RS-232

Control port.

• Disk tray loader with Sanyo Laser and MTK 8560 decoder

• Supported Disk formats: BDMV, BDAV, BD-ROM2.0, BD-R/RE,

DVD-VIDEO, DVD-R/+R, DL, CD-DA, CD+G, DTS-CD, VCD,

SVCD, CD-R/RW

• Supported Video formats: MKV, MP4, AVI, MT2S, VOB, FLV, MPG,

MOV

• Supported Music formats: MP3, WAV, AAC, M4A

• Supported Photo formats: JPG, PNG, GIF

• Outputs for L/R audio on RCA, Optical SPDIF and Coaxial

BDP-432 232-060 £199.17

ALSO RECOMMENDED

Tascam MC-CD1 MKIII

Combines CD playback and

MiniDisc recording in a 2U

rackmount unit.

228-300 £624.17

Cymatic LR16

16-Track recorder. Records

direct to stand–alone USB

hard & thumb drives.

261-030 £224.17 More products online...

Newhank MP203USB

Playback of WAV and MP3

files from CD, CDR, CDRW

and MP3 files from USB media

232-000 £345.00

Newhank DUS-1

The perfect solution for the

playback of multiple formats.

USB and SD card slot.

232-040 £265.83

Stageline CD-112

CD and MP3 player with USB

interface and SD/MMC card

slot suitable for all applications.

256-590 £199.00 More products online...

1000s of products

Available from stock!

2017 CAT PAGES 4-9:Layout 1 12/12/2016 11:57 Page 4

£326.50

CD-RW901MKII

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Media Players + USB/SD Players + DJ Media Players

Media Players

Continued

Denon DN-500BD

Blu-Ray Player

Offers a raft of professional video and audio features at a

friendly consumer price.

• Panel lock and IR remote lock functions

• Power-on Play button

• OSD (On Screen Display) hiding mode

• Repeat mode offers an uninterrupted playback loop

• Supports BD-Video, BD-R, BD-RE, DVD-Video, DVD-Audio,

DVD+R, DVD+RW

DN-500BD 271-960 £265.83

Tascam BD-01U

A rugged, professional, single-rackspace Blu-Ray player for installation and

studio use.

Building on the success of the install-standard DV-D01U, the Hi-Definition player includes control via LAN, RS-232C, and an

included wireless remote. DVD, WAV, MP3, DTS, and Dolby playback are also supported from optical and USB flash drives.

Media can be played back at up to 130% speed. A pair of balanced XLR and RCA unbalanced outputs is provided on the rear

panel, in addition to the HDMI audio/video output. The analog outputs can be attenuated up to -12dB. Both optical and coaxial

digital audio outs are also provided. Other professional features include a defeatable on-screen display, chapter repeat function,

and JPEG slideshow. TASCAM channels the years of experience gained with the DV-D01U to create the ultimate source

playback for education, house of worship, boardroom, and other high-stress installs.

BD-01U 238-770 £346.67

NEW

USB/SD Players

Denon DN500R

SD/USB Recorder

Records to SD/SDHC and USB media in MP3 and WAV (up

to 24-bit/96kHz).

• Dual Record feature

• XLR and RCA audio connections (analogue and digital)

• MP3, WAV, AIFF, AAC playback

• Front panel USB keyboard connection

• EDL marking & file edit functions

• Record Monitor (listen the recorded signal while recording)

DN500R 271-910 £307.50

DN700R 271-920 £440.83

Denon DN700R

Network SD/USB Recorder

The unit can be configured for ‘dual’ simultaneous

recording to both formats or ‘relay/cascade’ recording

where longer recording times are desirable.

• Records to SD/SDHC and USB media in MP3 and WAV

• Dual Record feature and Relay Record feature

• Web Remote for setup and control with Password Protection

• Independent switchable XLR Mic/Line inputs with +48V Phantom

Power, Timer recording/playback (30 schedules available)

DJ Media Players

Numark PT01

Touring Turntable

A classically-styled suitcase unit

that recalls the popular portable

turntables from the past.

• 3-speed (33 1/3, 45 and 78 RPM)

portable suitcase-style turntable

• Self-contained design with built-in

speakers

• 45 RPM adapter included

• USB port and EZ Vinyl/Tape

conversion software

• 1/8” Headphone jack and 1/8" aux

input

• Built in rechargeable battery

PT01 277-760 £49.17

NEW

ALSO RECOMMENDED

Denon DN-300ZB

Plays audio from USB thumb

and HDDs, SD/SDHC cards.

Balanced XLR outputs

272-050 £265.83

Denon DN-300C

A 1RU-sized player, capable

of extremely high

performance.

272-060 £149.17

Denon DN-300H

Full-featured AM/FM digital

tuner with options such as

Program Type Search.

272-210 £115.83

Denon DN-300UI

This is the perfect broadcast-

receiving device for

commercial applications

272-220 £224.17

Denon DN-300MP

This is the perfect broadcast-

receiving device for

commercial applications

272-230 £190.83

Denon DN-500CB

Perfect for retail, education,

and hotel/conference

applications.

272-240 £224.17

Denon DN-500DC

A multi-format, feature-rich

media player with unlimited

possibilities for any installation.

272-250 £332.50

Denon DN-501C

The DN-501C is the ideal

choice for installations no

matter the environment.

271-900 £390.83

NEW

More products online...

ALSO RECOMMENDED

Gemini CDX-2250

19-inch twin CD player suited

to both mobile DJ’s and

permanent installations.

289-890 £190.83

Stageline CD-292

A professional dual CD and

MP3 player, with USB 2.0

interface.

256-580 £249.17

Gemini CDM-4000

Provides easy-to-use track

search and playback features

across dual CD decks.

290-130 £240.83 More products online...

Saturday delivery...

No problem!

2017 CAT PAGES 4-9:Layout 1 12/12/2016 12:16 Page 5

DJ Media Players + CDRs + Memory Cards + Pen Drives 9

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Numark MP103USB

The MP103USB is a rack-

mountable CD/MP3 player and

designed for professional DJs

and installations.

Thousands of songs can be loaded from a computer

onto a USB flash or hard drive. The MP103USB's USB

input allows you to put your entire digital music library on

a USB flash or hard drive and perform with it at a gig. If you

are a DJ transitioning to using MP3 files, the MP103USB is ideal because it allows you to still use your entire library of CDs or MP3 CDs

while giving you more options for using digital media. A fully loaded, compact, and portable media player makes the CDJ-300 a must

have for all serious home, mobile and club Djs. It comes loaded with features working DJs need like Master Tempo, Scratching, Seamless

Loop, Pitch Control, Reverse and Brake effects and an Auto-BPM counter. The MP103USB is loaded with premium features but is still

affordable for DJs of any level. Balanced XLR outputs mean you can connect to any system in seconds with professional results.

MP103USB 277-430 £166.66

Numark CDN77 USB

Rackmounting USB Dual CD Player

The Numark CDN77 USB is a

Dual USB and MP3 CD player

designed for professional DJs.

• USB drive support

• Master Tempo, Scratching,

Seamless Loop, Pitch Control,

Reverse and Brake effects

• Auto-BPM counter

• Allows you to still use your entire

library of CDs or MP3 CDs

CDN77 USB 277-400 £274.99

CDR Professional

HHB CDR80 Silver IP

Inkjet Printable

Printable version of the HHB

CDR80 which is popular with

recordists and archivists.

• Optimised and intended for use in

single speed professional audio

recorders

• White disc surface

• Optimised for use with inkjet

printers including models from

Affex, Copytrax, Fargo and IMT

• Packed in jewel cases

CDR80IP Single 123-320 £0.89

CDR80IP 10 Pack 123-330 £7.94

CDR80IP Cakebox 50 123-270 £18.70

CDR80Bulk Cakebox 50 123-340 £18.70

HHB CDR80Bulk Cakebox

Thermal Printable

Bulk Thermal Cakebox 50 pack.

• Printable version of the CDR80

• Matt white disc surface optimised

for use with thermal printers

CDR Consumer Type

Fuji CDR Audio*

CDR Consumer Type

Delivers bit-perfect recording

and playback precision for

accurate music storage and

reproduction.

• 80 minutes

• 700MB capacity

• For use on CD recorders which

require the SCMS code in the disk

• Some older CD recorders may not

be suited for use with 80 minute

CDRs.

CDR80 x1 122-550 £0.62

CDR80 Pack of 10 122-600 £5.88

*May be replaced by an alternative quality brand.

Memory Cards

Integral SDHC Card

Class 4 + 10

High storage capacity (4GB

upwards) and fast data transfer.

• Store your digital content such as

MP3’s, high-resolution photos,

high definition videos

• Without the restrictions of

memory card size and data write-

speeds of the past

SDHC 4GB Class 4 137-370 £2.88

SDHC 4GB Class 10 137-390 £3.25

SDHC 8GB Class 4 137-440 £3.13

SDHC 8GB Class 10 137-530 £5.62

SDHC 16GB Class 4 137-460 £3.71

SDHC 16GB Class 10 137-540 £6.50

SDHC 32GB Class 4 137-490 £6.38

SDHC 32GB Class 10 137-560 £7.46

Integral MicroSDHC Class 4/Class 10

Micro SDHC

Upgrade your multimedia device

with an Integral microSDHC

memory card.

• High quality Integral memory card

for portable recorders, mobile

phones and other multimedia

devices

• Up to 32GB capacity for storing

digital data

• Class 4 specification provides more

than 4MB/sec continuous write

speed, Class 10 more than

10MB/sec

Class 4 16GB 137-570 £4.54

Class 4 32GB 137-770 £7.04

Class 10 8GB (Last Few) 137-900 £2.95

Class 10 16GB 137-910 £3.50

Class 10 32GB (Last Few) 137-920 £9.92

Pen Drives

Integral USB 2.0 High Speed

Pen Drive

Useful and portable pen drives

for use with Mac or PC...

• For use with Mac or PC

• USB 2.0 and 1.1 compatible.

• Featuring red LED

• Weight 9g

• Supplied with a USB extension

lead, neck holder and Windows

driver disc

4GB 137-180 £2.96

4GB 10-Pack 137-181 £27.08

8GB 137-190 £3.13

16GB 137-200 £4.13

32GB 137-210 £6.17

64GB 137-230 £10.33

ALSO RECOMMENDED

HHB CDR74 Gold x10

HHB's original audio optimised 1X to

8X disc. 10 Pack.

123-110 £25.40

HHB CDR80 Silver x10

Silver reflective layer increases

reflectivity. 10 Pack.

123-220 £7.44

Delivery before 10am...

No problem!

Price Changes

This catalogue was priced

in December 2016. Many

prices will have come

down, while some will have

increased. Check online for

up-to-date pricing.

2017 CAT PAGES 4-9:Layout 1 12/12/2016 11:57 Page 6

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Tape + Cassettes + Accessories + Broadcast Consoles + Digital Mixers

Tape

RMG Magnetic Tape

Formed out of the media giant

Philips in Holland who had the

plant and technology to produce

tape with quality and consistency.

• Produces two Quantegy bias

compatible tapes

• High bias, high output SM900

replaces 499 and GP9, lower bias

and output

• SM911 replaces Quantegy 456

SM900 1/4” NAB Spool 119-100 £43.75

SM900 1/2” NAB Spool 119-110 £60.42

SM900 1” NAB Spool 119-120 £104.17

SM900 2” NAB Spool 119-130 £174.17

SM911 1/4” NAB Spool 119-000 £43.75

SM911 1/2” NAB Spool 119-010 £61.25

SM911 1” NAB Spool 119-020 £108.17

SM911 2” NAB Spool 119-030 £177.08

Cassettes

TDK/Maxell Ferric 90

Cassette

A ferric cassette which has

outlasted the competition.

• Low friction rollers

• Antistatic liners

• Record inhibit tabs

• Normal ferric biasing

• Highly reliable

Ferric 90 142-240 £0.99

Media Accessories

CD Wallets Plastic 10/100 Packs

• Basic clear plastic wallet for CDs

• Open one end with flap to secure

• Sold in packs of 10 or 100

Pack of 10 127-920 £0.85

Pack of 100 127-930 £7.20

Isopropyl Alcohol 100ml

The industry's most sought after

head cleaning agent.

• For cleaning rubber components

apply on a cloth

• 99% pure alcohol (If it were 100%

pure it would immediately

evaporate)

• Highly inflammable.

Isopropyl Alcohol 100ml 126-000 £2.34

Broadcast Consoles

Digital Mixers

Behringer X Air XR18

A powerful 18 input, 12 bus

portable mixer that is reliable

and robust.

The Behringer X Air XR18 Digital Mixer is built upon the

success of the Behringer X32 Digital Mixing Desk and

includes many of the high quality features that you can

expect from a Behringer product, but cased in a small

yet powerful mixer. This mixer is aimed towards a

market of live engineers and studio engineers that may

be looking to mix and record their performances. 16

MIDAS-designed preamps, for high quality microphone

preamplification that will be crystal clear and clean. 18-

in, and 18-out USB Bus, for multi-track recording with your digital mixer. The ability

to control via iPad and Android tablets make this a consumer and professional friendly mixer.

XR18 384-440 £540.83

XR16 384-750 £332.50

Behringer X Air XR12

Digital Mixer

A 12-Input Digital Mixer for

iPad/Android Tablets.

• 4 Programmable MIDAS Preamps,

8 Line Inputs, Integrated Wifi

Module and USB Stereo Recorder

• Built-In Tri-Mode Wifi router

• 100-band Real Time Analyser

• 2 aux and main LR buses with

inserts, full dynamics processing

• 31-band graphic EQ

• 40-Bit floating-point DSP

Behringer X Air XR16

Digital Mixer

A 16-Input Digital Mixer for

iPad/Android Tablets.

• 8 Programmable MIDAS Preamps,

8 Line Inputs, Integrated Wifi

Module and USB Stereo Recorder

• Built-In Tri-Mode Wifi router

• 100-band Real Time Analyser

• 4 aux and main LR buses with

inserts, full dynamics processing

• 31-band graphic EQ

• MIDI In/Out

XR12 384-740 £207.50

Behringer X Air X18

Digital iPad/Tablet Mixer

Digital Mixer for iPad/Android

Tablets.

• 18-input digital mixer for studio and

live applications

• 16 Programmable MIDAS Preamps

• Integrated Wifi Module

• Multi-Channel USB Audio Interface

X18 384-430 £395.83

Presonus Studiolive AI Series

Digital Mixers

The Presonus Studiolive AI

series combines the ease of a

surface-driven analogue

workflow with the digital power.

• Familiar interface keeps critical

controls visible and accessible

• Integrates with iPad and iPhone for

a cohesive workflow

• Compressor, limiter, expander/gate,

and fully parametric EQ on every

channel and bus

• 4 effects processors, with their own

dedicated mix bus; 31-band

graphic EQ on every aux mix plus

the mains; and 500 ms of delay on

4 subgroups

16.4.2AI 16 Channels 328-650 £1215.83

24.4.2AI 24 Channels 328-660 £1665.83

32.4.2AI 32 Channels 328-630 £1849.17

Sonifex S0

Radio Broadcast Mixer

A user friendly xed format radio

broadcast mixer with USB for

recording.

• Ideal for community and internet

radio stations

• Telephone hybrid for making and

recording on air calls

• Built-in limiter for hearing protection

• Studio speakers mute & automatic

mic live sign switching

• 4 mic, 12 stereo line, 1 TBU & 1

stereo auxiliary inputs

Sonifex S1

Radio Broadcast Mixer

Added exibility on and off air

with this easy to use, compact,

xed format radio mixer.

• Analogue & digital inputs and

outputs (remote outputs per channel)

• Main stereo output buss plus 2

Aux output busses, pre or post

fader selectable

• Programmable general purpose

I/O. Monitor muting on mic live/on-

air sign switching

• Telephone hybrid for making and

recording on air calls

S0 368-290 £1746.66

S1 368-300 £2166.00

PRICE

DOWN

2017 CAT PAGES 10-19:Layout 1 16/12/2016 09:03 Page 1

Digital Mixers 11

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Allen & Heath Qu Series

Combine exceptional ease of use with class-

leading audio performance.

With its responsive touchscreen, motor faders and acclaimed

AnalogiQ recallable preamps, the Qu Series take compact digital

mixing to a new level. Drawing on the technologies and workflow

pioneered on our GLD and iLive touring systems, Qu makes

Allen & Heath digital mixing more accessible and more

compact than ever. Qu’s AnalogiQ total recall preamps

feature zero crossing detection and an advanced

padless 1dB step gain stage, closely allied to the DSP

for optimal gain accuracy and audio transparency. Qu-16,

Qu-24 and Qu-32 feature 16, 24 and 32 motorized ALPS

faders respectively, arranged over 2 layers, allowing instant access to all

channels and masters in a compact space. Forget soundcard drivers and

software setup, Qu has an integrated multitrack USB recorder, providing 18 channels of

48kHz, 24bit recording and playback straight to / from your USB hard drive.

Qu-16 16 In / 12 Out 269-580 £1249.17

Qu-16 + Trojan Case 269-585 £1288.33

Qu-24 30 In / 24 Out 269-620 £1665.83

Qu-24 + Trojan Case 269-625 £1707.50

Qu-32 38 In / 28 Out 269-640 £2082.50

Qu-16 Case 459-080 £107.50

Qu-24 Case 459-090 £115.83

Qu-32 Case 459-360 £137.50

Allen & Heath AB168

Portable Stage Box

Provides 16 XLR inputs and 8

XLR outputs when connected to

a GLD-80 or GLD-112 mixer, or

to an AR2412 AudioRack.

• Connects over a single Cat5 cable

via a secure dSNAKE EtherCon port

• 16 Mic Preamps on XLR

• Phantom Power LED per Input

• 8 XLR Line Outs

• dSNAKE Connection with locking

Ethercon port

• Rubber bumpers

• Carry handle

• Optional rack mount kit available

AB168 269-650 £707.50

Allen & Heath QU-PAC

Gives complete freedom to

control the Mixer from an

iPad or iPhone.

269-700 £1082.50

Allen & Heath GLD-80

An analogue-style channel

processing control section

complemented by a graphical

8.4 inch touch screen.

269-510 £3165.83

Presonus Studiolive RML Series

Rackmount Digital Mixers

A revolutionary new way to mix

music in both live and studio

situations with its innovative

rack mountable design.

• 32 internal channels and 25 buses

• 52x34 FireWire 800 recording

interface

• AVB Ethernet networking

• Fat Channel signal processing on all

input channels and all buses

• 4-band parametric EQ, compressor,

gate, and limiter

RML16AI 16 Channels 338-130 £965.83

RML32AI 32 Channels 338-140 £1440.83

NEW

Presonus RM32AI

Compact 32-channel, 25-bus

rack-mount Active

Integration™ digital mixer.

338-040 £1024.17

Soundcraft Ui Series

Remote Controlled Digital Mixers

Packs a complete digital mixing

system into a compact, road-

rugged stagebox format.

• Tablet/PC/Smartphone Controlled

Digital Mixer

• Integrated Wi-Fi

• Legendary Harman Signal

Processing

• Fully recallable and remote-

controlled mic preamps

• 4-band Parametric EQ, High-Pass

Filter, Compressor, De-esser and

Noise Gate

• 2-channel USB audio playback and

recording

Ui12 12 Inputs 268-040 £207.50

Ui16 16 Inputs 268-050 £415.83

Soundcraft Si Impact

Digital Mixer

Delivers digital live sound mixing

and recording for those who

refuse to compromise on audio

quality.

• 32 Mic Inputs

• 8 XLR/1/4" Combi-jacks

• 40 DSP input channels (32 mono

inputs and 4 stereo channels/returns)

• 31 Output busses (All with full DSP

processing and GEQ)

• 4-band Fully Parametric EQ on

each channel and bus

• 4 fully customisable Fader Layers

• Built-in Stagebox Connectivity

• 5" touchscreen display

• 32x32 USB audio interface

Si Impact 268-130 £2082.50

NEW

Soundcraft SI Performer

Series

Bring unparalleled mix power and

performance to small format digital

live sound mixers. Performer 1 - 16-

Channel; Performer 2 - 24-Channel

Performer 3 - 32-Channel

Performer 1 268-010 £2774.17

Performer 2 268-020 £2999.17

Performer 3 268-030 £3124.17

Soundcraft SI Expression

Series

Soundcraft’s most powerful cost

effective digital consoles ever.

Expression 1 - 16 mic pre amps;

Expression 2 - 24 mic pre amps;

Expression 3 - 32 mic pre amps

Expression 1 267-960 £1749.17

Expression 2 267-970 £1940.83

Expression 3 267-980 £2290.83

Line 6 Stagescape M20d

Touchscreen Mixing System

StageScape™ M20d is the world's first smart mixing system for

live sound. Utilising a groundbreaking touchscreen visual mixing

environment, the M20d streamlines the way you mix to get your

sound dialed in quickly and help you stay in the creative zone.

M20d 301-490 £978.33

More Products Online...

2017 CAT PAGES 10-19:Layout 1 12/12/2016 13:12 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Digital Mixers

Continued

Behringer X32

Digital Mixing Console

Lets you focus on your event,

instead of navigating a vast sea of

knobs, buttons and menus like

some live digital mixers.

Intuitive and powerful with 40 processing channels and 25 mix buses, all equipped with dynamics and EQ, which can be configured quickly. Use any

combination of the local 32 console mic inputs or the networked digital snake inputs on stage—their audiophile quality programmable preamps always ensure

full control, purity and impeccable dynamics. The dedicated channel strip section puts 17 backlit buttons and 13 rotary controls with LED-collars right at your

fingertips for nuanced adjustment of each channel's compressor, 4-band parametric EQ and much more. I/O abounds with 32 high-end programmable mic

preamps; 6 Aux Inputs on 1/4" TRS; 16 balanced XLR Outs, plus balanced Control Room outputs on both XLR and 1/4" TRS connectors. A single CAT5 cable

from FOH to the stage can receive up to 48 channels of audio input—and deliver all bus outputs, along with 16 individual monitor feeds for Behringer’s brand

new P16 personal monitoring system.The onboard virtual FX Rack provides access to eight true-stereo, multi-effects processors (16 mono) including delay,

chorus, dynamics—and it can run 4 production quality true-stereo reverbs concurrently with 8 channels of 31-band graphic equalization.

WINNER

‘BEST MIXING

DESK (LIVE)’

MIPA 2013

Key features:

• 40-input channel, 25-bus digital mixing console • High-resolution 7" day-viewable Color TFT

• 32 MIDAS- designed, fully programmable mic preamps • Main LCR, 6 matrix buses and 16 mix buses

• 25 Fully automated motorized 100 mm faders • Virtual FX rack featuring 8 true-stereo FX slots

• 16 XLR outputs plus 6 additional line in/outputs • 40-Bit floating-point DSP

• 32 x 32 channel X-USB audio interface over USB 2.0 • 48-channel Digital Snake ready via AES50 ports

X32 382-820 £1707.50

X32 + S16 Digital Snake 382-824 £2390.83

X32 + Mixer Case 382-825 £1790.83

X32 + S16 + Case 382-828 £2474.17

X32 + 2x S16 + Case 382-829 £3099.17

X-USB Card for X32 384-060 £169.17

X-UF USB/FW Card for X32 384-061 £249.17

X-ADAT ADAT Card for X32 384-062 £249.17

X-MADI MADI Card for X32 384-063 £249.17

X-DANTE Card for X32 384-065 £412.50

Cynatic U-Track-32 Card 261-210 £290.83

WINNER

‘READER’S

CHOICE AWARD’

NAMM 2013

WINNER

‘BEST DIGITAL

MIXING CONSOLE’

WFX 2013

WINNER

‘READER’S

CHOICE AWARD’

Musikmesse 2014

BEST

SELLER

2017 CAT PAGES 10-19:Layout 1 12/12/2016 13:12 Page 3

Digital Mixers 13

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Behringer X32 Compact

Compact digital mixing console

for Studio and Live application.

Thanks to its legendary onboard X32 mix engine, the X32

Compact can be your top-notch studio recording interface

today, control a complex theater production tomorrow, or

sit securely in your side-rack while you mix your band’s club

gig from your iPad. A revolution in its own right, the

incredible X32 Compact combines the finest analogue I/O and powerful digital connectivity with

ample processing for 40 channels, 25 buses and up to 152 signal sources.

Behringer X32 Producer

Powerhouse features in a rock

solid form factor.

Processing power, ample I/O and flexible routing are

central themes in the X32 Producer. Where larger

consoles make sense in fixed installations or studios,

with the X32 Producer, studio-calibre performance now

goes wherever life takes you. Eight stereo effects

engines provide the signal processing power

equivalent to racks of outboard gear without having to haul anything besides the X32 Producer.

• 40-input channel, 25-bus digital

mixing console

• 16 MIDAS- designed, fully

programmable mic preamps

• 17 Fully automated motorized

100 mm faders

• 8 XLR outputs plus 6 additional line

in/outputs

• Main LCR, 6 matrix buses and 16 mix

buses

• 32 x 32 channel X-USB 2.0 audio

interface

• 40-input channel, 25-bus rack-

mountable digital mixing console

• 16 MIDAS- designed, fully

programmable mic preamps

• 17 Fully automated motorized

100 mm faders

• 8 XLR outputs plus 6 additional line

in/outputs

• Main LCR, 6 matrix buses and 16 mix

buses

• 32 x 32 channel X-USB 2.0 audio

interface

Behringer X32 Core

Compact 40-

input channel,

25-bus digital

mixing console for Studio and Live application.

The X32 CORE forms the nucleus of an ultra-flexible studio control room setup when paired with S16

I/O and P16 personal monitoring systems in each tracking room. The built-in 32 x 32 X-USB

recording interface, 8 stereo effects engines, zero-latency monitoring (independent from DAW) and

100% total recall deliver the tools to handle any project you dare to tackle.

• 40-input channel, 25-bus 1U digital

rack mixer

• 48-channel Digital Snake ready

• 32 x 32 channel X-USB 2.0 audio

interface

• 2 TRS outputs for local monitoring

• Main LCR, 6 matrix buses and 16 mix

buses

• Virtual FX rack featuring 8 true-

stereo FX slots

Behringer X32 Rack

The ideal choice for

handling audio now —

and as your needs grow.

The X32 RACK is a revolutionary product

genre that combines finest analogue I/O and powerful digital connectivity, with ample processing for

40 channels, 25 buses and up to 152 signal sources. It can be your top-notch studio recording

interface today, control a complex theater production tomorrow, or sit securely in your side-rack

while you're mixing your band's club gig from your iPad.

• 40-input channel, 25-bus 3U rack-

mountable digital mixer

• 16 MIDAS- designed, fully

programmable mic preamps

• 48 channel Digital Snake ready

• 40 Bit floating-point DSP

• Main LCR, 6 matrix buses and 16 mix

buses

• Virtual FX rack featuring 8 true-

stereo FX slots

Gator G-Tour X32

X32 Case

Features a thick, 12mm heavy

duty plywood construction and a

tough laminated PVC exterior.

• Unique design which provides easy

cable routing and full rear access

• Spring loaded carrying handles

• Specialised EVA foam padding

• Detachable lids/heavy duty castors

• External dimensions mm: 1008W x

925L x 280H; Weight 47kg

Studiospares Trojan X32 Wheeled

4 Drawer Case

Designed specifically for the

Behringer X32 and accessories.

• 4-Wheels, 4-lockable drawers for

accessories and a lift off lid

• Constructed from 9mm plywood

faced with a tough and attractive

Black Phenolic surface

• Corners are protected by chrome

plated steel bumpers

• Catches fully retract

Studiospares Trojan X32 Case

Mixer Case

Professional grade mixer case

specifically designed for the

Behringer X32.

• Constructed from 9mm plywood

and aluminium and built to a high

standard

• The plywood has been covered with

a layer of laminated plastic

• Lid secured using 4 butterfly

latches

X32 Compact 383-900 £1207.50

X32 Compact + S16 Snake 383-904 £1874.17

X32 Compact + Case 383-905 £1290.83

X32 Compact + S16 + Case 383-908 £1957.50

X32 Compact Case 458-960 £129.00

X32 Producer 384-040 £1145.83

X32 Core 383-910 £474.17

X32 Rack 384-050 £915.83

Trojan X32 Case 458-790 £140.00

Trojan X32 Wheeled Case 458-720 £166.66

Trojan X32 Rack + Case 459-070 £249.00

G-Tour X32 Case 471-200 £308.32

Price Match

Studiospares will BEAT any

genuine price from any UK

competitor on any item or

order. Call or email us for

more details.

PDF Catalogue

Want this catalogue on

your phone or laptop?

Download it in PDF format

from our website today!

1000s of products

Available from stock!

2017 CAT PAGES 10-19:Layout 1 12/12/2016 13:13 Page 4

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Digital + Analogue Mixers

Digital Mixers

Continued Yamaha TF Series

Mixer range with advanced live recording

features and seamless operation with

high-performance I/O racks.

TouchFlow Operation offers unprecedented comfort and

convenience. 33 motorised faders (32 channels + 1 master motorised

fader). 48 input mixing channels (40 mono + 2 stereo + 2 return). 20 Aux (8

mono + 6 stereo) + Stereo + Sub buses. 8 DCA groups with Roll-out. 32

analogue XLR/TRS combo mic/line ins + 2 analogue RCA stereo line

inputs. 16 analogue XLR outputs.

TF5 32+1 Master channel 274-830 £2564.17

TF3 24+1 Master channel 274-840 £2275.00

TF1 16+1 Master channel 274-850

459-350

459-340

459-330 £124.17

TF5 32+1

TF1 16+1

Mackie DL32R

32-Channel Wireless Digital Mixer

Completely controlled wirelessly

from Mackie's Master Fader app.

• 32-channel Touch Software-

controlled with 28 Buses

• 14 Stereo-linkable Aux Sends

• 32 x 32 USB 2.0 Audio Interface

• 32 Onyx+ Microphone Preamps

• Multitrack Recording/Playback

• Onboard Digital Effects

DL32R 262-720 £1249.17

MIDAS M32

Digital Mixing Console

The groundbreaking M32

console combines legendary

MIDAS sound quality with

advanced digital technology.

• 40 Input Channels

• 32 MIDAS Microphone

Preamplifiers and 25 Mix Buses

• 96 kHz capable open architecture

design

• 192 kHz ADC and DAC converters

M32 777-000 £3082.50

Trojan M32 Mixer Case 459-370 £165.83

Mackie Pro DX Series

Wireless Digital Mixers

Perfect for solo performers,

small bands, venues and

commercial applications.

• Control every level from the single

knob front panel interface

• Clean and professional design

• Wireless Streaming and Control via

the MixerConnect™ app on iOS

and Android™

• Powerful Built-in Processing

• 3-band EQ with low-cut per channel

• 16 great-sounding ReadyFX™

Pro DX4 4-Channel 262-870 £174.17

Pro DX8 8-Channel 262-880 £249.17

NEW

Stageline DMIX-20

Digital Mixer

The digital mixer DMIX-20

impresses with an intuitive

operating concept of the well

thought-out user surface.

• 19-channel digital audio mixer

• Touch screen, 2 DSP effect units

and USB interface

• 16 mono input channels with

assignable controls

• 8 channel inserts

• 2 stereo input channels

• +48 V phantom power

DMIX-20 258-670 £625.00

NEW

Analogue Mixers

Mix5 262-750 £50.00

Mix8 262-760 £71.67

Mackie Mix Series

Compact Mixer

5, 8 and 12-channel compact

mixers with proven high-

headroom, low-noise

performance.

• Mic/line inputs with studio-level

audio quality

• Three-band EQ with clean, precise

tone shaping

• Pan, level and overload indication

• Phantom power for condenser mics

• Multiple stereo 1/4" line inputs

• Tape in/out

• Dedicated stereo RCA inputs/

outputs for playback or recording

• Main L/R outputs

Mixer Description Code

Mix5 Inputs: 1 Mono XLR and TRS Jack

balanced/unbalanced + 2x Stereo

TRS Jack balanced/unbalanced

262-750

Mix8 Inputs: 2 Mono XLR and TRS Jack

balanced/unbalanced + 2x Stereo

TRS Jack balanced/unbalanced; One

aux send with stereo 1/4" returns

262-760

Mackie ProFX12 v2

8 Channels, 4 mic preamps. Provides

a comprehensive live sound solution.

262-800 £249.17

Mackie ProFX22 v2

22 Channels, 16 mic preamps.

Includes a ReadyFX effects engine.

262-820 £505.83

More mixers from the PROFX series available online.

ALSO RECOMMENDED

Mackie DL08

8 channel mixer with Cirrus

Logic® converters. Lightning

connector.

262-665 £433.33

Mackie DL1608

Transforms your iPad into a

16-track digital live mixer with

the added analogue Mackie

sound. Lightning version.

262-445 £578.33 More products online...

ALSO RECOMMENDED

Yamaha 01V96i

16 in/16 out Digital Mixer with

USB 2.0 audio streaming at

an impressive 96kHz.

274-570 £1378.33 More products online...

PRICE

DOWN

The Website

Keep up to date with all the

Popular new and innovative

powered mixer series...

• 2 x 800-Watt stereo, 1600-Watt

bridged mode

• Low weight and high efficiency

• Class-D technology including a new

switch-mode power supply

• 24-bit FX processors

• FBQ Feedback Detection

Mixer Description Code

PMP1680S 10-Channel, 8 high-quality mic

preamps

382-610

PMP2000 14-Channel, 9 high-quality mic

preamps

381-280

PMP2000D 14-Channel, 9 high-quality mic

preamps, Wireless option

384-910

PMP4000 16-channel, 8 built-in XENYX mic

preamps

382-620

PMP6000 20-channel, 12 built-in XENYX mic

preamps

382-630

PMP1680S 382-610 £329.17

PMP2000 381-280 £245.83

PMP2000D 384-910 £257.50

PMP4000 382-620 £366.67

PMP6000 382-630 £441.67

ALSO RECOMMENDED

Denon DN-312X

12-Channel Line Mixer with

Priority. 6 HDHQ™

Combination inputs.

272-150 £107.50

Denon DN-410XB

Bluetooth®-enabled 3RU

rackmount mixer is ideal for

event spaces and restaurants.

272-160 £249.17

Denon DN-412X

12-Channel, 2-bus audio

mixer. Portable tabletop

format for events and more.

272-170 £249.17

Denon DN-408X

8-Channel, 2-bus audio mixer.

Portable tabletop format for

events and more.

272-180 £199.17

Denon DN-306X

6-Channel mixer with Mic 1

Priority. XLR/TRS combo input

jacks with phantom power.

272-310 £115.83

NEW

More products online...

ALSO RECOMMENDED

Soundcraft GB2R 12.2

19” rack-mountable mixer designed

specifically for smaller installations.

267-800 £999.17

Roland MX-1

A mixer with step-sequenced FX,

transport, and tempo control.

319-200 £324.17

Saturday delivery...

No problem!

Delivery before noon...

No problem!

2017 CAT PAGES 10-19:Layout 1 12/12/2016 13:13 Page 9

Powered + Zone + DJ + Other Mixers 19

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Yamaha EMX312S

300 Watt Powered Mixer

12 Stereo channels include phono jacks for connection of

playback devices, to which the 3-band channel equalisers can

be applied. There are also two 7-band graphic equalisers. The

cabinets are made from a lightweight-but-rugged material, while

a switching power supply delivers all the clean power the system

needs. The mixer features a forced-air cooling system and a

feedback channel locating system. It can be rack mounted using

the optional RK512 rack-mount kit. The EMX312SC features

one knob compressor on all four mono mic/line channels and

also include 16 Yamaha SPX effects.

EMX312S 12 Channels 300W 274-010 £289.17

RK512 Rack Kit 274-030 £49.17

Yamaha EMX2

Powered Mixer

Both a mixer and a power

amplifier, so you only need

speakers and mics to have a

fully functioning sound system.

• 10 inputs - 2 outputs

• 250+250 watts @4Ω <10% distortion

• 110+110 watts @4Ω<1% distortion

• Feedback suppressor

• 3 band EQ with 15dB boost and cut

• Reverbs Plate, Hall, Room, Echo

• Phantom Power On - Off

• Speaker impedance switch 8Ω and

4Ω

• Subwoofer output

• Signal Level readout and Limiter

• High Z input for Instruments

EMX2 274-940 £275.00

NEW

Zone Mixers

Behringer Ultrazone ZMX8210

Zone Mixer

A professional 8-channel audio mixer designed specifically

for fixed installations that can distribute music

programming and announcements to up to three zones.

• 6 low noise mic/line inputs

• 2 selectable stereo inputs

• 3 assignable outputs

• 4-band master EQ

• Global mic low-cut filter

• Channel muting system

Ultrazone ZMX8210 381-750 £111.67

DN-508MX 272-190 £424.17

DN-508MXA 272-200 £607.50

DJ Mixers

Behringer DDM4000

Digital DJ Mixer

Ultimate 5-Channel Digital DJ

Mixer with Sampler, Dual BPM

Counter and MIDI...

• 32-bit digital DJ mixer with beat-

sync

• Beat-controlled loop, real-time pitch

control

• FX engines (Bitcrusher, Resonator,

Reverb, Flanger, etc

• Frequency-selective crossfading

• Digital SPDIF output for direct

recording

DDM4000 381-790 £256.50

DDM4000 Cross-Fader 383-520 £22.17

Behringer DJX750

Professional DJ Mixer

Pro 5-Channel DJ mixer with

advanced digital effects and

dual auto-BPM Counter.

• Super-smooth ULTRAGLIDE faders

• Awesome adjustable XPQ stereo

surround effect

• 3-band kill EQ (-32 dB) and precise

level meters

• Monitor function with master/cue

balance control and split option

• Auto-talkover function with

separate depth control

DJX750 381-830 £145.83

Behringer DX2000USB

Professional DJ Mixer

Professional, 7-channel, ultra-

low noise DJ mixer with state-

of-the-art phono preamps.

• Built-in USB interface for recording

and playback of any digital music

file

• Ultra-musical 3-band kill EQ (-32

dB) with EQ on/off switch on all

stereo channels

• 100-mm faders and sealed rotary

controls on all input channels

• Headphone output

DX2000USB 382-790 £220.83

Behringer DJX900USB

DJ Mixer

Professional 5-Channel DJ mixer

with innium “contact-free” VCA

crossfader, advanced digital

effects and USB/audio interface.

• 45-mm infinium “contact-free"

optical crossfader with adjustable

tension and fader curve for years of

use

• State-of-the-art 24-bit digital effects

with advanced parameter control

• Built-in USB interface for recording

and playback of any digital music

file

• Intelligent dual auto-BPM counter

DJX900USB 382-880 £183.33

Other Mixers

Denon Split Mix 6

6 Channel Mixer Splitter

6-Channel Mixer with Signal Splitter Functionality.

• Used as a 6-channel mixer or 8-output splitter

• Perfect for sending a stereo program to separate zones or

amplified speaker systems

• Create custom mixes utilizing mixed and separate audio feeds

• Balanced and unbalanced inputs and outputs

• Balance and level controls with 6-segment LED meters on mono

input channels

• Main input and output level controls with 6-segment LED meters

Split Mix 6 272-330 £107.50

NEW

Denon DN-508MX/DN-508MXA

Zone Mixer

High-performance solutions for controlling and routing up

to eight audio sources in multi-room venues.

• 6 mic/line inputs and 4 ST inputs

• 1 aux input on front and rear, and 8 zone outputs

• Remote controllability using TCP/IP, RS-232, and RS-422

• 3-band equalizer for all inputs

• 5-band equalizer for all zone outputs

• Delay and dynamics function

• DN-508MXA includes a 4-Zone Amplifier

NEW

Denon DN-306XA

6 Channel Mixer Amp

A 6-channel mixer with a built-in 120W Class-D amplifier

in one rack space.

• XLR/TRS combo input jacks with phantom power

• Two XLR line outputs

• Euroblock speaker outputs support 4 Ohm, 70V-line and 100V-line

• Master level control and 3-band equalizer

• Mic one priority control

DN-306XA 272-320 £165.83

NEW

More Products Online...

Want A Job?

Studiospares are constantly

expanding. We require

additional staff for a variety of

positions, working in a very

congenial atmosphere. Practical

experience of recording and/or

live sound engineering would be

preferable.

Send in your CV in the first

instance.

2017 CAT PAGES 10-19:Layout 1 12/12/2016 13:13 Page 10

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Portable PA

Behringer PPA Europort Series

Ultra-Compact Portable PA Systems

with Wireless Microphone Option.

The EUROPORT PPA series pack amazing sound quality into

compact, portable briefcase-style PA systems that are incredibly

fast and easy to set up. Whether you’re using them for a

corporate event, seminar or are a working musician, you’ll have

inputs for 2 microphones, your mp3 player, or up to 5 musical

instruments. They also feature effects from KLARK TEKNIK – and

Behringer’s handy FBQ Feedback Detection System for

feedback free crystal clear sound. Best of all, the PPAs are

“wireless ready” for Behringer’s high-quality ULM Digital

Microphones, so you can own the room. A high-quality

microphone, and all the cables and accessories you’ll need are included.

The PPA2000BT/PPA500BT include built-in Bluetooth connectivity allowing you to stream music from your smart-phone, tablet or other

Bluetooth-equipped device.

PPA200 5-Channel 200W 384-400 £255.00

PPA2000BT 8-Channel 2000W 384-410 £583.33

PPA500BT 6-Channel 500W 384-420 £366.67

JBL EON 615

15" Two-Way Multipurpose PA System

More than just another great JBL sound system, the new

EON615 is a true step forward in technology developed

specifically to deliver the best sound possible regardless of its

application. Completely rethinking how truly good an affordable

self-contained, portable PA system can be, JBL engineers

purposely designed and built the EON615 from the ground up

featuring JBL’s advanced waveguide technology, JBL designed

and manufactured transducers, and convenient, wireless remote

control of its onboard DSP EQ parameters via Bluetooth. This

total redesign of the EON platform leverages the latest

technologies in cabinet materials, acoustic science, transducer

design and user friendliness that delivers the extraordinary

quality of a high-end studio monitor in a fully professional, highly

flexible, easy to use, portable system for today’s working

musicians and sound providers.

EON615 x 1 445-340 £382.50

Fender Passport Event

Portable PA System

A self-contained seven channel

portable audio system that

includes everything you need.

• 375 Watts output

• Channel Controls Volume, Treble,

bass, Reverb, 20dB pad

• Hi Z Instrument/Line Switch

• Bluetooth Pair Switch

• Inputs, 4x XLR Mic/Line, 1x Jack

Instrument/Line, 2x Stereo Mic/line

• 1x Stereo Bluetooth

• Speakers 2x 8” and 2x 1.2” Horn

Loaded Tweeters

Fender Passport Venue

Portable PA System

Lets you record WAV audio les

using a USB ash drive and play

WAV and MP3 les.

• 600 watts output

• Input Channels: 10x (4x Mic/Line,

2x Line/Hi-Z, 2x Stereo plus USB

• Channel Controls: Volume, Treble,

Bass, Reverb and Phantom Power

• 20dB Pad (chans 1-4)

• Controls for Reverb: Time and

Tone, Master Volume

• USB (Record, Play/Pause,

Previous/Next Track

• Outputs: 3x Line inc Headphone,

1x Sub Output

Passport Event 211-010 £430.83

Passport Venue 211-020 £549.17

PS-512 Powered Sub 211-030 £257.50

Yamaha Stagepas 400i/600i

Portable PA System

A complete, extremely portable

sound solution.

• Can be set up quickly and easily in

a variety of configurations and

environments

• Two sleek, lightweight speakers

• Detachable powered mixer

• A pair of speaker cables

• Power output - 400W for the 400i

and 680W for the 600i

• Frequency Range 55Hz - 20kHz

• Mixer - 8 channels for the 400i

and 10 channels for the 600i

400i 274-650 £426.67

600i 274-660 £634.17

600i Trolley 274-665 £82.50

JBL EON 206P

Portable PA System

An easy to use, lightweight

package with un-compromised

sound quality.

• Powered mixer panel and dual full-

ranged speakers

• Detachable powered mixer

• Ultra light weight and compact,

weighing only (25 lbs)

• Ergonomic soft touch top grip

• 100° H x 80° V asymmetrical wave

guide

• Integrated 36 mm pole mount

socket

• Lightweight and ergonomic design

EON 206P 445-360 £382.50

JBL EON 208P

Portable PA System

All-in-one portable PA system,

complete with an 8-channel

mixer and Bluetooth audio.

• Suitcase-style design

• Great sound for performances,

meetings and events

• 8-channel detachable mixer

• 8” two-way stereo speakers

• Bluetooth connectivity

• 300 W (2x 150 W stereo)

• Professional I/O, thoughtfully

designed controls and Bluetooth

audio

EON 208P 445-460 £582.50

NEW

JBL EON ONE

Portable PA System

All-in-one portable PA system,

complete with an 8-channel

mixer and Bluetooth audio.

• 10” bass-reflex subwoofer

• Six 2” HF drivers

• Bluetooth connectivity

• Powerful 6-channel mixer

• 380 watts of power, 118 dB max

SPL

EON 208P 445-470 £690.83

NEW

More Portable PA Systems

are available, see pages

110-111.

PRICE

DOWN

Saturday delivery...

No problem!

Delivery before noon...

No problem!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:31 Page 1

Studiospares Fortissimo MkII PA Packages

Portable PA Packages

Portable PA 21

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Studiospares Gold PA Package

Amazingly cost effective solution featuring the

popular Auditorium 212B speakers and the

Yamaha P7000 power amp. Great for large

pubs, clubs and venues up to 1000 people.

2x 12” Passive Auditorium

1x Yamaha P7000

1x Behringer SX3242FX Mixer

with 24 mic inputs

2x 5m Speakon Cables

2x 5m XLR Leads

OUR PRICE

£1195+VAT

If bought separately:

£1305+VAT

SAVE

£132

(INC VAT)

Studiospares Platinum PA Package

The Studiospares Platinum PA Package is, as

the name suggests, a superb combination of

top quality equipment. This package will give

you over a killowatt of audio power that is ideal

for larger venues, auditoriums, halls and clubs.

2x Dual 15” Passive Auditorium

1x Yamaha P7000S power amp

1x Behringer X32 Digital Mixer

2x 5m Pro Speakon Cables

2x 5m Pro XLR Leads

OUR PRICE

£2749+VAT

If bought separately:

£2890+VAT

SAVE

£169

(INC VAT)

248-860

574-711

580-120

382-820

264-850

Platinum 250-140 £2749.00

248-830

588-270

588-890

381-770

264-850

Gold 250-130 £1195.00

10A PA Package 250-500 £290.83

10A + XENYX 1002FX 250-510 £349.17

10A + MG10XU 250-520 £415.83

10A + ZED-i 10FX 250-530 £457.50

12A PA Package 250-540 £324.17

12A + XENYX 1202FX 250-550 £390.83

12A + Signature 12 250-560 £574.17

12A + PROFX16 V2 250-570 £645.83

15A PA Package 250-580 £357.50

15A + QX1202USB 250-590 £437.50

15A + MG16XU 250-600 £665.83

15A + Signature 16 250-610 £774.17

Studiospares Fortissimo 10A MkII

PA Package

Excellent entry-level kit for small venues and

private functions up to 200 people, featuring

the new Fortissimo 10A MkII speakers.

2 x Fortissimo 10A MkII PA Speakers 249-330

2x Pro PA Speaker Stands + Carry Bag 648-032

Additional bundles include 2x Pro XLR Leads and ONE

of the following mixers:

Behringer XENYX

1002FX

Yamaha MG10XU Allen & Heath ZED-i

10FX

2 x Fortissimo 12A MkII PA Speakers 249-340

2x Pro PA Speaker Stands + Carry Bag 648-032

Additional bundles include 2x Pro XLR Leads and ONE

of the following mixers:

Behringer XENYX

1202FX

Soundcraft

Signature 12

Mackie PROFX16

2 x Fortissimo 15A MkII PA Speakers 249-350

2x Pro PA Speaker Stands + Carry Bag 648-032

Additional bundles include 2x Pro XLR Leads and ONE

of the following mixers:

Behringer

QX1202USB

Yamaha MG16XU Soundcraft

Signature 16

If bought separately:

£373+VAT

Our Price

£291+VAT

Save

£99

(Inc VAT)

Studiospares Fortissimo 12A MkII

PA Package

Highly specified system and ideal for slightly

larger venues, school halls, pubs or private

functions up to 350 people.

If bought separately:

£406+VAT

Our Price

£324+VAT

Save

£99

(Inc VAT)

Studiospares Fortissimo 15A MkII

PA Package

A popular, cost effective combination suitable

for venues, schools, large pubs, small theatres

and private functions up to 500 people.

If bought separately:

£440+VAT

Our Price

£358+VAT

Save

£99

(Inc VAT)

NEW NEW NEW

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:31 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Compressors + Compressor/Gates + Graphic Equalisers

Compressors 22

Compressor / Gates 22

Graphic Equalisers 22

Enhancers 23

Reverberation 23

Audio Signal Distribution 23

Multi Processors 24

Microphone Preamps 24

Other Preamps 26

Power Amps 26

Guitar + Keyboard Amps 29

Guitar Pedals 30

Other Amplifiers 30

Induction Loops 31

Crossovers 31

Outboard

Compressors

Behringer Multicom Pro XL MDX4600

4-Channel Compressor

Packs a lot of processing power into 1U of rack space.

• 4 Channels of Compression, Expansion and Gate

• Programme dependant attack and release settings

• Soft and hard knee compression

• Programme adaptive Expander

• LED ladder provides status information

MDX4600 Multicom Pro 359-970 £111.67

Art Pro VLA II

2 Channel Compressor

Two Channel tube driven compressor / levelling amplifier.

• Vactrol based optical electronic circuitry rather than the more

typical design VCA driven level detection circuit

• XLR and 1/4-inch TRS balanced inputs and outputs

• +4dBu/-10dBu mode switch

• Enhanced Link Mode optimising use as a mastering tool

• LED Backlit VU Input/Output Indicates Both Average Level And

Peak Hold

• VCA-Less Vactrol Opto-Compression Design

VLA II 325-730 £290.83

Compressor/Gates

dbx 266XS

Compressor/Gate/Expander

The DBX266XS is a compressor/limiter/gate 1U rack mountable

unit for your live sound rig or studio giving you more dynamic

control to help create a more polished output. Having

compression in your audio chain gives you the ability to smooth

out uneven levels, add sustain to guitars and fatten up your

drums. It also makes it easy to bring vocals to the front of your

mix - adding greater clarity and making them stand out from the

surrounding instruments. New gate timing algorithms ensure the

smoothest release characteristics. Great sounding dynamics

control for any type of programme material. Separate precision

LED displays for gain reduction, compression threshold and gate

threshold allow quick, accurate setup. Stereo or dual-mono

operation. Balanced inputs and outputs on 1/4" TRS and XLR

connectors. Side Chain insert. Classic dbx® "Auto" mode.

266XS 359-670 £82.50

Behringer Composer

Pro XL MDX 2600

A popular processor which

provides interactive control

over the signal dynamics.

359-200 £95.83

ALSO RECOMMENDED

More products online...

Alesis 3632

Provides two independent,

full-featured compressor/

limiters in one compact rack.

385-690 £99.99

ALSO RECOMMENDED

More products online...

Alesis SCL2

Highly flexible dynamics

processor designed for easy

operation and great tone.

326-070 £115.83

Graphic Equalisers

Mixer Description Size

EQ215 15 frequency bands spaced at 2/3rd

octaves with 35mm sliders

1U High

EQ231 31 frequency bands of ISO spaced

frequencies at 1/3 octave intervals with

35mm sliders

2U High

EQ230 31 frequency bands of ISO spaced

frequencies at 1/3 octave intervals with

55 mm sliders

3U High

EQ215 348-130 £65.83

EQ231 348-140 £93.50

EQ230 348-150 £99.17

Studiospares Trojan EQ Series

Graphic Equalisers

This range of Graphic Equalisers share common facilities

including two switches for bypassing EQ circuits and total

bypass linking input to output.

• A variable low cut filter operates between 10Hz and 250Hz

• An LED ladder indicates the onset of overloading

• Each frequency band can have 12dB boost or cut

• An output transformer avoids making ground loops when

interfacing with other equipment

• Gain control allows for differing equipment signal levels

dbx 215S/231S

Graphic Equalisers

The 2-Series from dbx represents a major step forward in the

performance of entry-level graphic equalizers. From their

amazing 10Hz to 50kHz frequency response, to the 108dB

dynamic range and internal toroidal transformers, the 2-Series

offers fantastic specifications at an affordable price point. With

2/3 octave Constant Q frequency bands, XLR and TRS inputs

and outputs and switchable boost/cut ranges of +/-6 or +/-

12dB. Sure to find a home in the studio, on tour and with

installed sound venues.

215S 2x 15-band EQ 359-680 £104.17

231S 2x 31-band EQ 359-690 £115.83

FBQ1502HD 15-Band 384-880 £70.83

FBQ3102HD 15-Band 384-890 £104.17

FBQ6200HD 15-Band 384-900 £140.83

Behringer Ultragraph Pro HD Series

Graphic Equalisers

High-Definition Stereo Graphic Equalisers with FBQ

Feedback Detection System.

• Ultra-low noise 4580 operational amplifiers for highest signal

integrity

• Dedicated mono subwoofer output with adjustable crossover

frequency

• Additional sweepable high and low-cut filters

• LED input/output metering and input gain controls

• Relay-controlled hard-bypass with an auto-bypass function

NEW

Behringer Ultracurve Pro DEQ2496

Graphic Equaliser

High quality mastering processor ideal for audiophile

mastering and PA purposes.

• 31 band graphic, 10 band parametric EQ, feedback destroyer and

3 dynamic EQs per channel

• Includes AKM 24bit/96kHz A/D and D/A converters

• 4 concurrently selectable EQ modules

• Metering for Peak/RMS, VU and SPL with dBA/dBC weighting via

RTA mic input

Ultracurve Pro 370-230 £224.17

PRICE

DOWN

1000s of products

Available from stock! More Products Online...

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:32 Page 3

Enhancers + Reverberation + Audio Signal Distribution 23

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Enhancers

Behringer Feedback Destroyer Pro

Feedback Suppressor

The fastest and the only 96kHz Feedback Suppressor on

the market!

• 96 kHz Feedback Suppressor

• Ultra-fast feedback detection algorithm

• Automatically and “intelligently” locates up to 20 feedback

frequencies per channel

• Auto mode continuously monitors the mix, resetting programmed

filters automatically

• Manual mode allows individual setting of up to 40 fully parametric

filters

• MIDI I/O

• 1/4" and XLR I/O

FBQ2496 380-250 £149.17

Behringer Micro HD400

This compact 2-channel solution

removes AC hum and noise

quickly, easily and reliably.

380-270 £18.67

ALSO RECOMMENDED

More products online...

Behringer Shark FBQ100

A high performance single

channel Feedback Destroyer.

+48V phantom power.

383-010 £74.17

Behringer Sonic Exciter

The SX3040 produces natural

brightness through harmonic

enhancement.

381-620 £74.17

Reverberation

Lexicon MX200

A popular dual Reverb/Effects

Processor from Lexicon.

359-200 £95.83

ALSO RECOMMENDED

More products online...

Audio Signal Distribution

Studiospares RED 502

Single channel Passive Bi-directional

Balanced to Unbalanced and

vice/versa.

Superbly engineered from a die cast aluminium extrusion with

metal endplates on which the connectors and switches are

mounted. Input/Outputs are a standard quarter inch Jack socket

and an RCA Phono socket. The other end has male and female

XLRs as balanced Inputs/Outputs. Inputs to outputs are fully isolated

from each other via a transformer.

An earth lift switch is provided. Response 0.05dB down at 20Hz and 20kHz. Max

input +28dBu. No power supply required. Metal XLRs throughout.

RED 502 458-210 £22.80

ART DTI

A high

quality totally

passive audio interface.

The DTI (Dual Transformer/Isolater) uses a pair of high

performance transformers to totally separate input and output

signal grounds, thereby isolating two systems and reducing

hum and ground-loop noise. The DTI's audio transformers

have an extremely flat and wide frequency response and can

handle high signal levels while maintaining an isolated

balanced output. This gives the DTI a very clean and neutral

sound with a wide variety of signal sources. The transformers

are wound for 1:1 unity gain and are designed to be used with

impedances from 600 ohms to 100 kilohms. The DTI also

features highly versatile connectivity, with XLR, 1/4" Jack, and

RCA Phono connections on all inputs and outputs.

DTI 325-310 £37.49

Art Cleanbox Pro

2 Way Stereo Converter

Two channels of unbalanced

inputs (phono or minijack) to

balanced pro line-level outputs

(XLR).

• Each section has stereo level

controls

• Conversion in reverse; balanced to

unbalanced; Lighted On/Off switch

• Includes external power supply

• Rugged extruded aluminium case

Cleanbox Pro 325-790 £45.83

Radial Relay XO

Balanced AB Wireless Signal Router

A 1-in, 2-out balanced audio

switcher designed to route the

output of a microphone to two

different audio inputs.

• Switch vocal microphone from PA

to intercom

• Allows artist to speak with

musicians and techs

• Remote control using footswitch

• Route any balanced signal to two

destinations

• Balanced XLR input and two

balanced XLR outputs

Relay XO 310-320 £165.83

NEW

Radial StudioQ

Talkback Interface

A desk-top solution that

manages to do it all in a super

compact design.

• Simple cue switch that turns on the

built-in microphone or the

‘producer’ mic XLR input

• Remote control using footswitch

• Balanced program signal path

• Each mic is equipped with an

individual trim control along with a

master mic volume

StudioQ 310-360 £283.33

NEW

dbx DriveRack PA2

Complete Loudspeaker Management System

Provides all the processing you need between your mixer

and amplifiers to optimize and protect your loudspeakers.

• All New AFS™ (Advanced Feedback Suppression)

• Mobile Control (Android®, iOS®, Mac®, Windows®)

• dbx Compression and Graphic EQ

• 8-Band Parametric EQ (adjusted when using the AutoEQ) Input

• Subharmonic Synthesis

• Crossover (supports full range, 2-way, and 3-way systems)

• 8-Band Parametric EQs (used for speaker tunings) Output

• Streamlined AutoEQ™

• Driver Alignment Delays

DriveRack PA2 379-650 £357.50

PDF Catalogue

Want this catalogue on

your phone or laptop?

Download it in PDF format

from our website today!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:32 Page 4

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Audio Signal Distribution + Multi Processors + Microphone Preamplifiers

Audio Signal Distribution

Continued

Radial HotShot DM-1

Stage Mic Toggle

Designed to address on-stage

communication problems for

artists who employ in-ear

monitoring systems.

• Redirects mic signal to

communicate with techs

• Lets band members with in-ear

monitors chat between songs

• Momentary switch requires foot

action to engage

• Passive design does not require any

power to work

NEW

Radial HotShot ABi

Balanced Footswitch Selector

Allows you to instantly select

between two sources by

depressing a latching

footswitch.

• Quickly select between two

balanced XLR sources

• Toggle or mute the source with a

latching footswitch

• Selectable input pad to better

match signal levels

• Heavy duty 14 gauge steel

construction for dependability

NEW

Radial HotShot ABo

Balanced Footswitch Selector

Delivers instant footswitch

control to divert the audio signal

to two destinations for greater

efciency on stage.

• Redirect a balanced signal to two

different destinations

• Toggle or mute the source with a

latching footswitch

• Selectable input pads to better

match signal levels

• Made from 14 gauge steel for

dependability

NEW

Hotshot DM-1 310-330 £82.50

Hotshot ABi 310-340 £82.50

Hotshot ABo 310-350 £82.50

Sonifex RB-DA6

A 6 way stereo distribution

amplifier for splitting a source

into different outputs.

368-050 £270.83

ALSO RECOMMENDED

More products online...

dbx goRack

For live sound applications

where portability is essential

without compromising quality.

379-670 £70.83

Multi Processors

Behringer Virtualizer 3D FX2000

Multi Effects Processor

Get even more mind-expanding power for your keyboard,

bass, guitar or vocals with the Virtualizer Pro 3D FX2000

Effects Processor.

• 71 breathtaking new algorithms—true RSM (Real Sound Modeling)

stereo and 3D effects

• Wave-adaptive virtual room algorithms for natural reverb and delay

• Authentic amp simulation, distortion and special effects

• Awesome modulation, dynamic, psychoacoustic and EQ

algorithms

Virtualizer 3D FX2000 383-230 £96.67

Finaliser 96K 386-650 £1249.17

tc Electronic Finaliser 96K

Rackmount Effects Unit

Delivers an unprecedented level of clarity, warmth and

punch to your mix.

• 96 kHz Internal and External Processing.

• 24bit/96kHz AD/DA converters

• Five-band, 24bit Stereo Digital Equalizer

• Dynamic EQ, Stereo Adjust, Digital Radiance Generator

• A Complete Range of Mastering Tools

NEW

Microphone Preamplifiers

Audient ASP880

8-Channel Microphone Preamplifier

Audient's renowned console mic pres, pristine converter

technology and a feature set that includes Variable

Impedance and Variable High Pass Filters.

• All new, Burr Brown AD converter technology

• Variable Input Impedance with variable High Pass Filters

• 8 Insert points between the mic preamps and AD converters

• 2 Channels of Class-A Discrete JFET D.I instrument inputs

• Digital Outputs - ADAT, AES & S/PDIF

ASP880 201-040 £610.00

Audient ASP800

8-Channel Microphone Preamplifier

Designed to transform your sessions into world class

recordings, making it the perfect addition to your audio

interface.

• 8 x World Class Audient Console Mic Pres

• 2 x Retro Channels with Dual Stage COLOUR Saturation Controls

- HMX & IRON

• 2 x Discrete JFET Instrument Inputs

• Pristine 118-dB Burr-Brown A-D Converters

• Balanced Analogue Line Outputs

• ADAT Output for Expandability

• Word Clock Input

• All-Metal Enclosure

ASP800 201-100 £499.17

Focusrite ISA One

Microphone Preamplifier

The ISA One is a classic single-

channel microphone pre-

amplifier with independent DI.

• Encased in a rugged and portable

chassis

• Vintage mic pre-amp topology

• XLR and 1⁄4” jack line input

• D.I. channel with gain control

• Phantom power and phase reverse

• 75Hz, 18dB/octave high-pass filter

ISA One 389-600 £332.50

Studiospares RED 501

A high quality, in-line preamplifier

providing improved sound for

microphones.

The maximum gain is 60dB. Maximum input level - 3dBu.

Maximum output level +26dBu. It generates 48v Phantom

Power whichcan be switched off. A Low Cut switch

switches in a high pass filter to attenuated frequencies

below 90Hz. There is a 3.5mm Headphone Socket, a +12v

DC input socket, Signal Present LED, Phantom Power LED and

Clip LED when the signal clips through overloading the input.There is also

an overall On-Off switch. Ins and outs via 3 pin XLRs. Metal XLRs throughout

RED 501 458-200 £24.99

Art Tube MP

Microphone Preamplifier

For a minimal investment, a

Tube MP can provide the single

largest improvement to the

sound of your studio.

• For mics, instruments and line

level sources

• Variable input/output gain controls

• XLR/1/4" inputs and outputs

• Phantom power

• Phase reversal switch

Tube MP 325-430 £40.83

Saturday delivery...

No problem!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:32 Page 5

Microphone Preamplifiers 25

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Studiospares RED 520

Popular

model in the

Studiospares RED preamps series!

Built in 48volt phantom powering. Mic/Line input switch

optimises the gain structure. Inputs via XLR/Jack combo

socket. Low Cut Switch filters out unwanted sub sonic

frequencies. Phase Reversal switch counters problems with

incorrectly phased mics. 8 band LED ladder indicates

incoming signal level enabling the operator to optimise system

performance. Gain range 0-50dB. Response 20Hz - 20kHz.

Signal/noise ratio better than 100dB.

RED 520 348-230 £41.20

Tritonaudio Fethead Series

High quality, in-line preamplifiers providing improved sound for microphones.

Tritonaudio Fethead

FetHead is a high quality, phantom powered in-line preamplifier providing improved sound for ribbon and dynamic

microphones. The electronics are housed in a robust metal chassis with a balanced 3-pole female XLR input and a

balanced 3-pole male XLR output, rugged enough for use at home, in the studio or on tour. When mated with a high-

end dynamic microphone like a Sennheiser MD441, or Shure SM7 FetHead really shines. Some ribbon microphones

do not tolerate phantom power, FetHead's circuit uses Phantom power but shields it from its input and the

microphone's output. As a result it offers effective protection to the microphone. Fethead uses low noise jfets

configured as a double class a amplifier. Attach FetHead on to a balanced microphone cable and plug it in a dynamic

microphone, switch on phantom power and enjoy FetHead’s natural open sound!

Tritonaudio Fethead Filter

FetHead Filter is a Fethead version with a built-in 6dB/octave high pass filter with a corner frequency of 220Hz (other

cutoff frequencies available on request). It is specially designed for microphones which exhibit an excessive proximity

effect / low frequency response, like long motor ribbon microphones. The components which make up the filter are

not directly in the signal path but are applied to the components which set the gain of FetHead Filters amplifier, thus

making it frequency dependant. This way the sonic character which makes a FetHead attractive to the ear is preserved.

FetHead Filter can be distinguished by a green dot below the TritonAudio label.

Tritonaudio Fethead Phantom

FetHead Phantom is a FetHead version which allows phantom power to reach the microphone. It was developed

after several requests from different audio engineers to build a FetHead for condenser microphones with low output.

It works well with electret microphones like the countryman or an AKG C1000. These are microphones which consume

very little power, FetHead Phantom also works great on "real" condenser microphones like a U87 or even with an

Oktava MK319 which consumes a hefty 8mA!

FetHead Phantom can be distinguished by a red dot below the TritonAudio label.

Tritonaudio Fethead Broadcast

FetHead Broadcast was developed in conjunction with Dutch Broadcasting and facility service company

CineVideoGroup. It is based on technology used in our product FetHead and is fitted with a high quality jfet preamp,

followed by a low impedance output buffer to enable output to drive cables up to 3 kilometres long. 23dB's of low

noise amplification. For both dynamic and condenser mics. Low output impedance downs interference and low

noise Class A jFet amplifier. Internal supply power filtering. Reverse polarity protection.

Fethead 314-000 £59.00

Fethead Filter 314-010 £49.17

Fethead Phantom 314-020 £62.50

Fethead Broadcast 314-030 £115.00

Art TPS II

The tube driven TPS II adds

warmth and texture to any

audio source.

325-520 £145.83

ALSO RECOMMENDED

More products online...

Art USB Dual Pre PS

Designed to work over a

range of applications from field

recording to studio tracking.

325-740 £66.66

Behringer Ultragain Pro

Lets the true colours of even

your finest microphone shine

through.

360-700 £74.17

Goldmike Mk2 340-150 £749.17

SPL GoldMike Mk2

Tube Preamplifier

Retains a hybrid solid state and tube construction to

combine the best of both worlds.

• Discrete Class A solid stage

• Tube drive in three different intensity levels

• Flair presence enhancement in two switchable settings

• Switching inserts

• Pre-output limiter stage (extremely fast diode-based operation,

perfect for A/D converter protection)

• VU metering with three different, switchable display ranges

NEW

OctaMic XTC 377-670 £1424.17

RME OctaMic XTC

8 Channel Preamplifier

The most exible and advanced interface ever built to

work with the iPad.

• Full range hi-end preamp and AD/DA-converter

• Clock Control (ICC), SyncCheck, SteadyClock, QuickGain,

AutoSet, MIDI over MADI, and remote control via USB, MADI and

MIDI

• 8-channel 192 kHz / 24-bit AD conversion

• 8 high class microphone and line/ instrument pre-amplification

inputs

NEW

Radial McBoost

Mic Signal Booster

Designed to elevate the output

of a typical dynamic microphone

for greater transient response.

• 25dB signal booster for dynamic &

ribbon mics

• Extends dynamic range and

microphone reach

• Uses standard 48V phantom for

power

• 3-position load switch and high-

pass filter

McBoost 310-300 £165.83

NEW

Delivery before 10am...

No problem!

Delivery before noon...

No problem!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:32 Page 6

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Microphone + Other Preamplifiers + Power Amplifiers

Microphone Preamplifiers

Continued

Focusrite Clarett OctoPre

Gives you eight outputs that you can use to extend the capabilities of your

Clarett Thunderbolt audio interface - or any other interface fitted with ADAT

optical inputs and outputs!

The eight mic pres feature automatic mic/line switching inputs and two front-panel instrument inputs. Designed specifically for the Clarett

range, they offer plenty of gain, yet low noise and distortion - and great sound quality. They also include a special “Air” feature that switches

in an analogue model of the classic transformer-based Focusrite ISA mic pre, switching the impedance of the preamp to that of the original

ISA and enabling a ‘transformer resonance effect’, giving microphone sources the air and clarity of an ISA transformer-based mic pre

recording. In addition, the mic pres have plenty of headroom and are ideal for recording drums and other extreme level sources.

The front panel instrument inputs feature extra headroom to handle high-output pickups, while the rear panel includes universal XLR/jack

connectors for the remaining auto-switching mic/line inputs. The inputs drive eight channels of precision 24-bit Focusrite A-D with 118dB

dynamic range and standard sample rates up to 192kHz. In addition to providing eight mic pres, the Clarett OctoPre offers D-A conversion

(from the ADAT inputs, with 119dB dynamic range) of up to eight channels, making it perfect for mixing as well as tracking.

Clarett OctoPre 392-280 £540.83

NEW

Studiospares Mono Valve

Microphone Preamplifier

The first step in re-creating the

warmth of the sounds of

yesteryear.

• Based on two low noise 6N3 twin

triode valves 100Hz Low, 2.5kHz

Mid and 10kHz High equalisers

• Gain is adjustable from zero to -55dB

• No transformers are used in the

signal path so distortion is at a very

low level

• 48volt phantom powering can be

switched on-off

• Input impedance 100k (3.4k

with phantom power switched on)

Mono Valve 348-000 £79.17

Other Preamplifiers

Denon DN-500AV

Surround Sound Preamplifier

The most affordable and

professional option to providing

high-quality, channel-separated

balanced audio outputs.

• HDMI version 1.4a (3D,ARC)

• 6-HDMI inputs and 1 output

• 2 assignable component video

inputs and 1 output

• Direct play for portable audio

devices

• USB memory device via USB

• XLR analogue input

• XLR 7.1ch Pre output

DN-500AV 271-930 £515.83

Radial J33

Active Turntable/Phono Preamp

Made to handle the rigors of

the professional recording

studio and the abusive

environment of live touring.

• Combination RIAA Phono preamp

and DI box

• Stereo RCA, ¼" TRS, 3.5mm and

XLR outputs

• Built -in low frequency rumble filter

• Choice of 48V phantom or DC

supply

J33 310-000 £170.83

Radial Decoder

Mid/Side Matrix and Mic Preamp

Allows the user to easily create

M/S recordings without having

to re-configure a recording

console.

• Quick and easy mid/side recording

without a mixer

• Three ultra-quiet built-in mic

preamps

• Pre-mixed stereo outputs

• Line level operation for use with

pre-recorded tracks

Decoder 310-370 £332.50

NEW

Art Deejay Pre II

Corrects the output of record

cartridges so that they can be

fed into any stereo or mono

sound system.

325-000 £39.99

ALSO RECOMMENDED

More products online...

Art Headamp 4

Stereo Headphone Amplifier

Adds additional headphone

outputs to equipment without

creating any additional load on

the existing headphone source.

• 1x ¼” stereo jack input

• 4x ¼” stereo jack headphone

outputs

• Output impedance of 51(omega)

• Maximum input level is +14dBV

signal-to-noise of 90dB, distortion

below 0.01 percent.

• Mains adaptor included

Headamp 4 325-010 £45.83

Power Amplifiers

Behringer Europower

Meet the needs of professional

musicians for both installed

applications or on the road...

The EP2000 and EP4000 represent everything musicians

loved about the popular EP1500/EP2500—excellent sound

quality, road-worthy toughness and reliability, low-noise

operation and incredible power. With 2,000 and 4,000-Watts

peak respectively, the EP2000 and EP4000 amplifiers are

perfect for medium-sized club gigs, mobile PA systems,

church services or public spaces. No corners were cut in the

design process. XLR and 1/4" TRS input connectors for

compatibility with any source. Independent limiters per

channel offer reliable protection against overload and

distortion.

Model into 2Ωinto 4Ωinto4Ωbridged

EP2000 2 x 650W RMS 2 x 600W RMS 1400W RMS

EP4000 2 x 1250W RMS 2 x 905W RMS 2400W RMS

EP2000 382-010 £183.33

EP4000 382-000 £241.67

Behringer A500

Power Amplifier

The top choice for recording studios and post-production

work, yet its amazing price is just the beginning.

• 2 x 300W into 4Ω, 600W into 8Ωin bridged mono operation

• Advanced convection-cooling, precise level meter and clip

indicators

• Input on balanced XLR, 1/4'' TRS and RCA connectors

• Ultra-reliable Toshiba / Fairchild power transistors

A500 380-160 £145.83

More Products Online...

Saturday delivery...

No problem!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:32 Page 7

Power Amplifiers 27

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Yamaha P Series

Power Amplifiers

Yamaha’s P series amps are stable under all conditions.

This version incorporates a new higher efficiency power supply called the EEE (Energy Efficient Engine). Increased efficiency means less heat generated

and greater reliability. Recently upgraded to be only 2U high and lighter, they will power a 2Ωload with a slight increase in output power. Provision is made

for bridging by activating a rear mounted switch. Slew rate figures are amongst the best at a maximum of +30V usec into an 8Ωload. Inputs via XLR type

connectors and 1/4” Jacks. Outputs are Speakon, 5 way binding post, and 1/4” mono Jack. Probably the most popular and reliable amplifiers on the

market over the last couple of years. As with all Yamaha products the build quality is excellent and the failure rate practically zero.

Model into 4Ωinto 8Ω

P2500S 2 x 390W 2 x 275W 264-820 £291.67

P3500S 2 x 590W 2 x 390W 264-830 £369.17

P5000S 2 x 750W 2 x 525W 264-840 £375.00

P7000S 2 x 1100W 2 x 750W 264-850 £437.50

BEST

SELLER

Behringer iNuke Series

The Behringer iNUKE power amplifiers pack massive amounts of output power

into exceptionally lightweight, rack-mountable packages.

The revolutionary high-density Class-D technology with "near-zero" thermal buildup combined with ultra-efficient switch-mode power supplies

ensures these feather-light powerhouses will drive your rig effortlessly for many years to come. Built-in Subwoofer/Satellite crossover for

perfect subwoofer operation. Ultra-efficient switch-mode power supply for noise-free audio, superior transient response and low power

consumption.

Model into 2Ωinto 4Ωinto bridge 4Ω

NU1000 2 x 500W 2 x 300W 1000W 382-970 £110.00

NU1000DSP 2 x 500W 2 x 300W 1000W 382-960 £145.83

NU3000 2 x 1600W 2 x 900W 3000W 382-950 £169.17

NU3000DSP 2 x 1600W 2 x 900W 3000W 382-940 £204.17

NU6000 - 2 x 3000W -382-930 £257.50

NU6000DSP - 2 x 3000W -382-920 £198.33

NU12000 2 x 6000W 2 x 3000W -384-330 £512.50

NU12000DSP 2 x 6000W 2 x 3000W -384-320 £583.33

NU4-6000 4 x 1600W 4 x 860W 2x 3000W 383-960 £254.58

Stageline STA-1508

8-Channel 1800W Pro Amplifier

Multi-channel PA amplifier with integrated limiter.

• Balanced inputs

• Power: Stereo 4 - 8 x 160W RMS; Stereo 8 - 8 x 100W RMS;

8 bridged – 4 x 320W RMS

• High and low-pass filter and Tamper-resistant level adjustment

• Soft start and fan cooling

STA-1508 255-770 £315.83

Stageline STA-1000D

High power capability and

high energy efficiency. 2 x

500W into 4, 2 x 280W into

8.

258-600 £290.83

ALSO RECOMMENDED

More products online...

Free Catalogue

Are you reading someone

else’s catalogue? Why not

call us and order your own

copy... It’s free!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:40 Page 8

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Power Amplifiers

Continued

Studiospares Trojan Series

Power Amplifiers

The Trojan series has quickly gained a reputation for reliability and a solid performance covering a power

range of between 200 and 900 watts. The new range Trojan Plus extends the power range to from 900

watts to 2.2 kilowatts with enough muscle to drive most speakers to a cinder. It features a plug in output

stage which can be replaced by anyone handy with a screwdriver within minutes. The overall construction

is more substantial and the circuitry more sophisticated. Both ranges share common features such as

automatic protection against short circuits, overload, and overheating.

System Status is provided by LEDs indicating signal present and power clipping. Quiet fans whose speed

varies with the output stage’s temperature keep the electronics at the right temperature. Aside from the 1U

200 watt model, all versions are 2U high. Studiospares amplifiers quote RMS power which is real power.

Other manufacturers forget to quote which standard they use so can quote any wattage that enters their

heads. Inputs are via combined XLRs and Jacks. Outputs are via Speaklocs which mate with any other

twist to lock speaker plugs and binding posts.

Combines solid

engineering principles

with the requirements

of the serious power

amplifier user.

The following specification is common to all models:

Input sensitivity Trojan Balanced 0.89V (-1dBV), Unbalanced 1.67V (4.5dBV)

Trojan Plus 1.4v Balanced/Un balanced

Frequency Response Trojan 5Hz - 20kHz +0dB - 1dB

Trojan Plus 20Hz - 20kHz + 0.3dB

Signal/Noise ratio (A weighted below rated power) 100dB

THD (at full bandwidth power 20Hz - 20kHz) <0.03%

Damping factor (4) >300

Load Impedance Stereo mode 4-8per chan Bridge Mono 8

Protection DC, short circuit, thermal, overload and clip limiter

Input connectors XLR and Jack

Output connectors 3x Speakons

Indicators Signal LED, Clip LED, Power LED

Cooling Variable speed low noise fan

Power requirements 110 - 120V/60Hz and 220 - 240V/50Hz

Trojan Plus Plug in

Output stage

Model into 4Ωinto 8Ωinto 8Ωbridged

Trojan 200 2 x 100W 2 x 60W 200W 348-100 £119.00

Trojan 600 2 x 300W 2 x 150W 500W 348-110 £149.83

Trojan 900 2 x 450W 2 x 230W 900W 348-120 £165.83

Trojan 900+ 2 x 450W 2 x 300W 900W 348-200 £207.50

Trojan 1500+ 2 x 750W 2 x 500W 1500W 348-210 £237.50

Trojan 2200+ 2 x 1100W 2 x 700W 2200W 348-220 £265.83

Trojan 2200+

Saturday delivery...

No problem!

Delivery before noon...

No problem!

Delivery before 10am...

No problem!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:33 Page 9

Power + Guitar + Keyboard Amplifiers 29

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Crown XLS Drivecore 2 Series

The next generation of XLS got a makeover with a sleek new look, a LCD display

that is three times larger, and more DSP with higher capabilities.

Like its predecessor, the new XLS is ultra-efficient with Crown’s patented DriveCore technology and can drive 2400W at 4 bridged with

tons of headroom guaranteeing a clean, undistorted signal straight to your speakers. The XLS DriveCore 2 assures that you will be heard

as you deliver a powerful, pure sound experience for any venue. Class D amp with Crown's ultra-efficient DriveCore technology weighs

less than 11 lb (5 kg). Higher DSP capabilities: More control; has band pass filter per channel.

Model into 2Ω Dual into 4Ω Dual into 4Ω bridged

1002 550 watts RMS 350 watts RMS 1100 watts RMS 243-100 £360.00

1502 775 watts RMS 525 watts RMS 1550 watts RMS 243-110 £450.00

2002 1050 watts RMS 650 watts RMS 2100 watts RMS 243-120 £590.00

2502 1200 watts RMS 775 watts RMS 2400 watts RMS 243-130 £680.00

Crown XLi Series

Power Amplifiers

Represents a new era in affordable, quality power

amplification.

• All four models in the series are powerful, rugged and reliable

• Suited for musicians, DJs, and entertainers as well as houses of

worship, discos, and pubs

• Electronically balanced RCA & XLR inputs; binding post and

Speakon outputs.

Model into 4Ωinto 8Ωinto 8Ω bridged

800 300W RMS 200W RMS 600W RMS

1500 450W RMS 330W RMS 900W RMS

2500 750W RMS 500W RMS 1500W RMS

3500 1350W RMS 1000W RMS 2700W RMS

800 243-240 £290.00

1500 243-230 £365.00

2500 243-220 £520.00

3500 243-210 £985.00

Art SLA-4

4-Channel Power Amplifier

A true four-channel amplifier in a single rack-space that can

be switched easily from Multi-channel, Stereo and Bridged

Mono Modes.

• 4 x 100W/Ch at 8Ω, 140W/Ch at 4Ω

• 2 x 200W/Ch at 16Ω, 280W/Ch at 8Ω(bridged)

• 2 x 100W/Ch at 8Ωand 1 x 280W at 8Ω(bridged)

• Toroidal transformer

• 1/4-inch TRS, and euroblock balanced inputs

• 10Hz to 40kHz frequency response

SLA-4 325-490 £357.50

SDA-1 326-130 £274.17

Art SDA-1

Studio Digital Amplifier

The perfect choice for critical listening in studio

environments.

• 200 watts per channel (at 4 ohms) in a compact, single rack space

chassis

• Lightweight and ultra quiet

• Flat 20Hz to 20kHz frequency response

• Balanced inputs and versatile multi-way binding post outputs

NEW

Denon DN-200AZB

Amplifier with Bluetooth Receiver

Adds Bluetooth and amplier

support to any audio systems.

• Bluetooth level control

• 4 Ohm, 70v, 100v, 20 W RMS

Amplifier

• Euroblock Speaker Output and

Euroblock Line Input

• Up to 33m (100 ft) range

• Discreet, robust build quality

DN-200AZB 272-270 £99.17

NEW

Samson Servo Series

Power Amplifiers

The Servo series has been a stalwart of studio monitoring

systems for many years offering efficient, clear and

reliable power for monitor speakers.

• 4-stage power protection circuitry

• All power ratings are RMS at 4 impedance unless otherwise

stated

• Samson Servo 120A - 1U rack mount and is rated at 60W per

channel at 4

• Samson Servo 200 - 100W per channel. 200 watts bridged mono

at 8

• Samson Servo 300 - Essentially a 200 but with 130W per channel

Servo 120A 388-040 £157.50

Servo 200 388-490 £165.83

Servo 300 388-060 £199.17

Guitar + Keyboard Amplifiers

Radial JDX 48

Guitar Amp Direct Box

Takes your amp's true sound all

the way to the PA

• 48-volt phantom-powered guitar

amp direct box with reactive load

• Supports amplifiers up to 300-watts

• Eliminates in and feedback issues

stage

• Speaker cabinet emulation for

natural tone

• Direct feed to console eliminates

need for a mic

• 15-volt DC power supply included

JDX 48 310-080 £170.83

Radial JX42

4-Input Guitar Switcher

A compact guitar and amp

switcher made to handle up to

four guitars and two amps

simultaneously.

• Selects up to 4 guitars and 2 amps

• Ultra quiet opto-resistive switching

• Transformer isolated - eliminates

hum

• Made from 15 gauge steel

• Includes class-A buffering circuit

JX42 310-280 £340.83

NEW

Radial Headload Prodigy

Combination Load Box and DI

A load box made to deliver a

load of tone!

• Load box with 100%, 50% and

silent attenuation

• Let's you drive your amp hard for

best tone

• JDX Reactor direct output for PA

and monitors

• Built-in headphone amp for

practicing

Headload Prodigy 310-290 £383.33

NEW

1000s of products

Available from stock!

2017 CAT PAGES 20-29:Layout 1 13/12/2016 15:33 Page 10

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Guitar & Keyboard Amplifiers + Guitar Pedals + Other Amplifiers

Guitar & Keyboard Amplifiers

Continued

Behringer KT108

Keyboard Amp

Ultra-compact 15-watt keyboard

amplifier with VTC-Technology.

• Extremely versatile 2-channel

keyboard amplifier

• Powerful 20-watt, 8” dual-cone

Bugera speaker for wide frequency

response

• 2 Instrument inputs with separate

volume control for each channel

• VTC Virtual Tube Circuitry for tube-

like sound & EQ

• CD input allows you to play along to

your favourite music

KT108 383-380 £65.83

Behringer Ultratone KXD12/KXD15

Keyboard Amp

600-Watt 4-Channel PA System /

Keyboard Amplifier with Original

TURBOSOUND Speaker.

• Bi-amping design delivers dedicated

power for LF and HF drivers

• Class-D amplifier technology: high

power and light weight

• 12'' Turbosound speaker; 1'' driver

• Klark Teknik FX processor with 100

presets

• Reverb, chorus, flanger, delay, pitch

shifter and multi-effects

• Revolutionary FBQ Feedback

Detection System

• Full 4-channel stereo with separate

Volume and FX Send per channel

KXD12 12” 384-630 £261.67

KXD15 15” 384-640 £333.33

Laney AH150 Audiohub

Combo/Monitor

Delivers optimum performance,

flexibility and sound quality for a

wide array of audio inputs.

• 5 channels

• 5-band graphic master EQ and

Digital Delay

• 150W RMS power

• 12” woofer plus tweeter

AH150 Audiohub 203-000 £207.50

NEW

Guitar Pedals Behringer PB1000

Pedal Board

Universal effects pedal floor

board with integrated power

supply.

• Ultra-compact and lightweight

• Transports up to 12 effects pedals

• 1.7 A power adapter included

• Ultra-rigid plastic design

• High-quality components and

rugged construction

PB1000 382-120 £96.67

Boss CH-1

This Super Chorus pedal delivers a

clean classic chorus sound.

319-250 £57.50

Boss FV-500H

Mono, high-impedance volume pedal

with a new stylish design.

319-280 £65.83

Boss FS-6

Combines latch- and momentary-

type switching into one unit.

319-290 £40.83

Boss JS-10 eBand

Compact jam station packed with pro

features and larger-than-life sound.

319-310 £274.17

Boss RC30

A twin pedal multitrack looper with

two stereo tracks and built-in effects.

309-550 £140.83

Boss RC3

Powerfully equipped yet compact.

Enjoy up to 3 hours of recording time.

309-560 £99.17

Boss RE-20

The Roland RE-201 has been reborn

as the BOSS RE-20 Twin Pedal!

319-340 £165.83

Boss RC-300

One of the most powerful Loop

Stations ever brought to the market.

309-720 £340.83

Boss VE-20

Offers some of the finest vocal-effects

technology on the market.

309-770 £170.83

Radial SB-15 Tailbone

Tailbone Combination Buffer

Delivers exceptional sonic

quality, reduces noise and adds

the convenience of 15VDC

power for your Tonebone.

• 100% discrete Class-A buffer

• Drag™ control load correction

• Drives pedals to 15 meters (50')

• Converts two 9V supplies to 15

VDC

SB-15 Tailbone 310-130 £70.83

NEW

Other Amplifiers

Denon DN-333XAB

Line Mixer Amp

A well engineered product with

clear front panel identification.

• Audio mixer with Bluetooth receiver

and 120 Watt amplifier

• Independent volume controls for mic,

line and Bluetooth inputs

• 3 XLR+1/4” combo mic inputs with

selectable +15V phantom power

• 2 RCA line level stereo inputs; front

panel 1/8” (3.5mm) Aux input

• Built-in limiter automatically prevents

erratic audio sources from clipping

• Bluetooth pairing control with LED

status indicator

• RCA line-level send-return

connections

DN-333XAB 271-940 £249.17

Denon DN-200BR

Bluetooth Receiver

The DN-200BR interfaces with

any professional audio system

for sound reinforcement, special

event or retail applications.

• A simple no nonsense product with

countless applications

• Receives Bluetooth signals wirelessly

• Routes the audio to balanced XLR or

¼-inch TRS outputs

• Easily integration with mixers and

amplification systems.

• Bluetooth Pairing mode ensures a

secure connection

DN-200BR 271-990 £74.17

Want A Job?

Studiospares are constantly

expanding. We require

additional staff for a variety of

positions, working in a very

congenial atmosphere. Practical

experience of recording and/or

live sound engineering would be

preferable.

Send in your CV in the first

instance.

1000s of products

Available from stock!

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:45 Page 1

Other Amplifiers + Induction Loops + Crossovers 31

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Denon DN-202WT

Wireless Audio Transmitter

The DN-202 WT and WR

combination is ideal for getting

stereo audio from point A to B.

• For use with DN-202WR

• Sends audio up to 30m without wires

• XLR and 1/4” audio inputs

• Able to broadcast to multiple

receivers (sold separately).

• External optimum antenna for best

transmission and reception

• Multiple DN-202WR’s may be used

with a single DN-202WT

• Rugged metal enclosure.

• Built- in eyelets for mounting screws

DN-202WT 272-010 £74.17

Denon DN-202WR

Wireless Audio Receiver

Perfect for event spaces, houses

of worship, entertainment

venues, education, retail, home

and more.

• For use with DN-202WT

• Receives up to 30m without wires

• Use multiple DN-202WR in a system

for more coverage

• XLR and 1/4” audio outputs

• External optimum antenna for best

transmission and reception

DN-202WR 272-020 £74.17

Induction Loops

Monacor LR-200

Inductive Receiver

Receives audio signals in

inductive sound reproduction

systems. Any number of

receivers can be operated within

one induction loop.

• 3.5mm mono minijack connection

• Volume control

• Low cut switch

• Belt clip

• Power supply via 9V battery

• 63 x 100 x 29mm

Monacor LA-200

Loop Amplifier Active

Constant current technology with dynamic compressor

for setting up an inductive sound reproduction systems.

• Automatic talk-over

• Metal loss correction 0-(+3)dB/oct

• Phantom power

• Supplied with 19" rack mounting brackets

LA-200 255-630 £169.00

LR-300 255-640 £33.50

Crossovers

Behringer Ultradrive Pro DCX2496

Digital loudspeaker management system with impressive audio quality and a

great feature list.

An indispensable tool for the precise set-up of multiple loudspeaker systems or arrays. Installation contractors and live-sound engineers

will find it invaluable. Signals can be split in various ways to assure precise sound by using the optimal frequency range of each

loudspeaker. 3 analogue inputs (one suitable for AES/EBU) and 6 analogue outputs, extreme dynamic range of 113dB. Precise dynamic

EQs for level-dependent equalization and extremely musical parametric EQs, selectable for all inputs and outputs, and “Zero“-attack

limiters on all output channels guarantee optimal signal and loudspeaker protection. This is not just a sleek design:

with highpower 32-bit SHARC®-DSP and ultrahigh resolution CRYSTAL®/AKM® A/D & D/A converters the Ultradrive

Pro offers outstanding audio performance.

DCX2496 370-330 £220.83

dbx 234s/234xs

2/3/4 Way Crossover

A dual channel crossover with all the features you would

expect from a professional product.

• Ultra low-noise, rugged reliability

• Linkwitz-Riley 24dB per octave filters

• Independent output gain controls for level matching

• Output phase inversion

• 40 Hz low cut filter

• Optional mono summing of the low frequency (subwoofer)

output

• High quality 1/4" TRS inputs and outputs

• 234s features Jack outputs, while the 234xs has XLR outputs

234s 379-190 £180.00

234xs 379-200 £165.83

Behringer Super-X Pro CX2310

Crossover

High-Precision Stereo 2-Way/Mono 3-Way Crossover with

Subwoofer Output.

• Linkwitz-Riley filters with 24 dB/octave

• Additional subwoofer output with independent Frequency control

• Individual output Gain controls for all bands

• Individual output Mute switches for easy band adjustment

• Switchable 25 Hz Low cut filter on each input

• Individual Phase reverse switches for instant phase correction

• Servo-balanced and gold-plated XLR connectors for all inputs and

outputs

CX2310 370-010 £59.17

Behringer Super-X Pro CX3400

Crossover

High-Precision Stereo 2-Way/3-Way/Mono 4-Way

Crossover with Limiters, Adjustable Time Delays and CD

Horn Correction.

• Individual Limiters on each output for optimal loudspeaker protection

• Adjustable time delay for phase alignment between drivers

• CD horn equalization for constant directivity horn compensation

• Flat summed amplitude response, zero phase difference

• “Low Sum” function provides mono output for subwoofer operation

• Individual output Gain controls, output Mute switches and Phase

reverse switches

CX3400 370-020 £96.67

Delivery before noon...

No problem!

Saturday delivery...

No problem!

Price Match

Studiospares will BEAT any

genuine price from any UK

competitor on any item or

order. Call or email us for

more details.

The Website

Keep up to date with all the

latest products and current

prices on the Studiospares

website! Check out

www.studiospares.com.

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:45 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Audio Interfaces/Sound Cards - USB

Audio Interfaces USB 32

Firewire 36

Hybrid 36

Thunderbolt 36

iOS 37

Network 38

Digital Converters 38

MIDI Interfaces 39

MIDI Controllers 39

DJ Controllers 40

MIDI Keyboards 40

Synthesizers 41

Samplers 42

Sound Modules 42

Computer Accessories 42

Software 43

Computer Zone

Audio Interfaces/Sound Cards - USB

Audient ID22

22-Channel USB2 Audio Interface

Transforms your DAW into a

world-class recording system by

connecting directly to your mics,

computer and monitors.

• 2-in, 6-out high performance 24-

bit/96kHz AD/DA converters

• 2 superb class-A mic

preamplifiers & 1 discrete JFET

instrument input

• High current headphone amplifier

fed by an independant DAC

• Main and alternative stereo outputs

• User defined monitoring

functionality with hardware control

• USB2 class compliant connectivity

ID22 201-000 £274.17

Audient ID14

USB Audio Interface with Free Bag

Delivers the audio performance

of a large format console in a

compact and elegant desktop

package.

• 2x Class-A Audient Mic Preamps

• 2-in / 4-out High Performance Burr

Brown AD/DA Converters

• 1 x Discrete JFET Instrument Input

• Main Speaker Output

• Independent Class-AB Phone Output

• Full Monitor Control Functionality

(software controlled)

• ADAT Input for Expandability

• Low Latency DSP Mixer

• iD ScrollControl Mode

ID14 201-090 £157.50

Audient ID4

2-In 2-Out USB Audio Interface

Delivers the audio performance

of a large format console in a

portable desktop package.

• 2-in/2-out USB Audio Interface

• 1 x Class-A Audient Console Mic

Preamplifier

• 1 x Discrete JFET Instrument Input

• High Performance Converters

• iD ScrollControl Mode

• Zero Latency Monitoring with

Monitor Mix & Pan

• Main Speaker Output

• Independent Class-AB Headphone

Amplifier with Dual Outputs

• 24bit/96khz

ID4 201-110 £99.17

NEW

8Pre 375-600 £362.50

MOTU 8Pre

USB 2.0 Audio Interface

Delivers everything you need to turn your computer into a

powerful 24-bit, 96kHz digital audio workstation.

• Eight microphone/instrument preamps

• Pristine 96kHz analogue recording and playback

• 8 channels of ADAT optical digital I/O

• Expand your system by connecting additional 8pres or other

MOTU audio interfaces.

Behringer U-Phoria HD Series

USB Audio Interfaces

Record the perfect vocal right to your computer-based DAW thanks to

the 4 astonishingly pure, world-class MIDAS-designed mic preamps,

which include +48 Volt phantom power for condenser microphones, all

going through studio-grade 24-Bit/192 kHz converters for the best

possible sound quality. Whether you’re a singer-songwriter, producer on

the go, or just need a rock-solid interface for running backing tracks at

a gig, the ultra-dependable U-PHORIA UMC HD interfaces will help you

shine in the digital domain.

UMC202HD 384-570 £44.58

UMC204HD 384-560 £59.17

UMC404HD 384-550 £74.17

Behringer U-Phoria UMC202HD

• 2x2 USB 2.0 audio interface for

recording microphones and

instruments

• Audiophile 24-Bit/192 kHz resolution

for professional audio quality

• Streams 2 inputs / 2 outputs with

ultra-low latency to your computer

• 2 state-of-the-art, MIDAS designed

Mic Preamplifiers with +48 V

phantom power

• Zero-latency direct monitoring

Behringer U-Phoria UMC204HD

• Similar to the UMC202HD but

streams 2 inputs / 4 outputs plus 1x

MIDI I/O with ultra-low latency

• Analogue Inserts for use of external

effects such as compressors, etc.

Behringer U-Phoria UMC404HD

• Similar to the UMC204HD but

streams 4 inputs / 4 outputs with 4

state-of-the-art, MIDAS designed

Mic Preamplifiers with +48 V

phantom power

Behringer UCA222

An ultra flexible audio interface that

connects your instruments, mixer,

etc. with your computer for

recording and playback.

The revolutionary energyXT2 Compact music production

software is included with a rich audio/MIDI sequencer that

loads almost instantaneously on all computer platforms. Its

massive software bundle includes Audacity audio editor,

comprehensive podcasting software and over 150 virtual

instruments and effect plug-ins. The UCA222 works with your

PC or Mac computer and no setup or drivers are required.

Its high quality components and exceptionally rugged

construction ensure long life.

UCA222 382-380 £22.42

Tascam US-20x20

USB Audio Interface

20-in/20-out USB 3.0 Interface

with Mic Pre and Digital Mixer

Modes.

• 20 channels of analog and digital I/O

• USB 3.0/2.0 connectivity

• Eight Ultra-HDDA microphone

preamps

• 56dB of gain and high headroom

• Ten channels of digital I/O are

included on ADAT and S/PDIF

connectors

• Built-in DSP mixer includes

parametric EQ and compression on

every channel

US-20x20 238-760 £362.50

MiNiSTUDIO Personal US-32 238-860 £99.17

MiNiSTUDIO Creator US-42 238-870 £132.50

NEW

Tascam MiNiSTUDIO Personal US-32

USB Audio Interface

The complete, desktop online

broadcast studio.

• XLR/combo mic/line connector

• Professional quality micropone

preamp

• Built-in phantom power

• Built-in microphone

• 4-band parametric EQ,

• Adjustable on-board compression

• Digital reverb effect

NEW

Tascam MiNiSTUDIO Creator US-42

USB Audio Interface

Delivers everything you need to

become the next internet

sensation.

• Pair of XLR/combo connectors and

dual HDDA mic preamps

• Studio-quality mic pres, coupled

with built-in phantom power

• 4-band parametric EQ,

• Adjustable on-board compression

• Digital reverb effect

• Two Hi-z 1/4" inputs ready to

accept an electric guitar or bass

NEW

PRICE

DOWN

1000s of products

Available from stock!

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:45 Page 3

Audio Interfaces/Sound Cards - USB 33

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Apogee Duet

Create professional recordings

anywhere on your iPhone, iPad or Mac.

321-080 £490.83

Behringer U-Phono UFO202

High-quality USB audio interface for

digitalising your tapes and records.

382-390 £22.42

Roland Duo Capture

Perfect for both home recording and

mobile production.

309-920 £95.83

RME Babyface Pro

24-Channel 192 kHz bus-powered

professional USB 2.0 Audio Interface.

377-660 £535.83

USB Guitar Link

Turn a PC or Mac Computer in to a

guitar amp and recording system.

602-980 £12.49

Behringer IS202

Simply connect the mixer’s outputs

to iStudio, open the app and go.

384-030 £74.17

Roland UM-ONE MKII

Boasts high-performance FPT

processing for low latency and timing.

309-930 £26.67

Focusrite iTrack Studio

For making music on the iPad, Mac

and PC. Lightning compatible.

389-910 £186.67

Focusrite iTrack Dock

Comprehensive yet easy-to-use,

studio-quality iPad recording interface.

392-030 £124.99

Focusrite iTrack Pocket

A portable, high quality stereo mic

and guitar input.

392-080 £39.17

MOTU Ultralite

Part of MOTU’s popular, award-

winning UltraLite interface series.

375-720 £515.83

M Audio M-Track Series

Transforms your computer into a digital recording studio with plug-and-play

simplicity.

M-Track Hub

The M-Track Hub is a 3-port USB monitoring interface that is perfect for

anyone who demands a high-quality audio interface monitoring hub. It is

a USB hub and has two balanced ¼-inch TRS audio outputs, controlled

by a large, solid-feeling metal rotary level knob with black-knurled rubber

ring. There are three USB inputs and a ¼-inch headphone jack with level

control for private listening. The M-Track Hub is the ideal way to unite your

VI control and audio output in one sleek, all-metal, space-saving solution.

M-Track 2x2

With the M-Track 2X2, you can create flawless 24-bit/192kHz studio-

quality recordings with an intuitive and easy-to-use audio interface.

Boasting an elegant pro-grade metal chassis with a large central volume

knob, the M-Track 2X2 features all-new transparent low-noise pre-amps

and pristine A/D converters that deliver the highest audio performance in

its class. The M-Track 2X2 enables you to record up to 2 channels at once

with its dedicated XLR+1/4" balanced combo input, and an all-new 1/4"

instrument input that has a specially designed gain and impedance stage

to provide the most accurate representation of a guitar or bass plugged

directly into the interface.

M-Track 2x2m

Essentially the same facilities as the M-Track 2x2, but with additional inputs including MIDI in/out.

M-Track 8x4

Featuring a 8x4 configuration, the M-Track 8x4 allows you to connect your

external devices quickly and easily to this all-in-one audio interface. The

M-Track 8x4 features four XLR/TRS combo inputs and two instrument

inputs, making it ideal for recording vocal and instrument pieces. 2 x

Headphone Outs have also been included with an independent level

control for monitoring purposes. This allows you to record 2 musicians

with 2 separate mixes, allowing for versatile recording possibilities. The

USB-C high-speed audio interface features zero-latency monitoring with

USB/Direct Balance control.

M-Track Hub 374-320 £45.00

M-Track 2x2 374-330 £65.83

M-Track 2x2m 374-340 £82.50

M-Track 8x4 374-350 £207.50

NEW

Akai EIE I/O Pro

Tabletop USB 2.0 Audio Interface

Perfectly tailored for your

project and portable studio

setups.

• Four-in, four-out (4x4) device

features low latency ASIO drivers

• 24-bit resolution and sample rates

of 44.1 kHz/48 kHz/88.2 kHz/96kHz

• Compatible with Mac and PC-

based systems

• XLR-¼” combo jack, dedicated

sturdy, gain-pots and

Mic/Line/Guitar switches on each

channel

• 48V phantom power available

EIE I/O Pro 265-780 £157.50 8Pre 375-600 £362.50

M Audio M-Track Eight

Audio MIDI Interface

M-Track Eight has 24-bit / 96 kHz (max.) digital audio for

recording audio higher than CD quality.

• Eight-Channel USB Audio Interface

• High-headroom mic preamps; up to 24-bit/96 kHz resolution

• 8 XLR+1/4″combo inputs with individual metering

• Auto- level switching (7, 8) and selectable phantom power

• Dual headphone outs plus dedicated control room outputs

• 8 Balanced 1/4″outputs ; USB/Analog Direct balance control

• Avid Pro Tools Express and AIR Ignite included

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:45 Page 4

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Audio Interfaces/Sound Cards - USB

Zoom U-22

USB Audio Interface

Easy to connect to a laptop or

an iPad and create great-

sounding audio anywhere.

• 2-in/2-out ultra-portable design

• Stereo USB audio interface for

PC/Mac/iPad

• XLR/TRS input with high-

performance mic preamp

• High-quality recording and playback

at resolutions up to 24-bit/96 kHz

• Approximately 5 hours of operation

with 2 AA alkaline batteries

• Includes download code for Ableton

Live 9 Lite

U-22 378-660 £65.83

U-24 378-670 £99.17

U-44 378-680 £132.50

NEW

Zoom U-24

USB Audio Interface

Provides all of the essential

tools you need for recording and

performing.

• 2-in/4-out audio interface

• Connect to your PC, Mac, or iPad

via USB and record mics,

instruments, and more

• Two mic/line inputs with high

performance mic preamps

• High-quality recording and playback

at resolutions up to 24-bit/96 kHz

• Approximately 4 hours of operation

with 2 AA alkaline batteries

NEW

Zoom U-44

USB Audio Interface

Enables you to record and

perform wherever you are.

• 4-in/4-out audio interface

• Connect to your PC, Mac, or iPad

via USB and record mics,

instruments, and more

• Two mic/line inputs with high

performance mic preamps

• High-quality recording and playback

at resolutions up to 24-bit/96 kHz

• Standalone AD/DA conversion

• Functions as a 2-channel

micpreamp with analogue and

digital outputs

NEW

Audio Interfaces/Sound Cards - USB

Continued

Behringer FCA1616

USB Audio Interface

Instantly turn your computer

into a recording and editing

workstation.

• 16 In/16 Out, 24-Bit/96 kHz

FireWire/USB Audio/MIDI Interface

• 4 state-of-the-art MIDAS mic

preamps, with phantom power,

individual Pad, Low Cut and Hi-Z

high impedance guitar input

• Support Windows XP/Vista/7, Mac

OS X

• ADA8000 ADAT connectivity

• I/Os including analogue, S/PDIF

(coaxial and optical), ADAT and

S/MUX. Built-in MIDI

FCA1616 384-010 £185.00

FCA610 384-020 £149.17

Behringer FCA610

USB Audio Interface

6 In/10 Out, 24-Bit/96 kHz

FireWire/USB Audio/MIDI

Interface.

• 2 state-of-the-art MIDAS mic

preamps, with phantom power,

individual Pad, Low Cut and Hi-Z

high impedance guitar input

• 2x Headphone outs with individual

Volume control, Mono and Source

signal select

• Support Windows XP/Vista/7, Mac

OS X

• ADA8000 ADAT connectivity

• I/Os including analogue, S/PDIF

(coaxial and optical), ADAT and

S/MUX

Roland UA-55 Quad Capture

4 in/4 out Audio Interface

Sets a new standard for portable

USB 2.0 audio interfaces...

• Two combo XLR/TRS inputs with

premium mic preamps (VS

Preamps), two TRS outputs, coaxial

I/O, headphone out, and MIDI I/O

• Graphical Control Panel software

• Phantom power, ground lift, and Hi-Z

switches

• One-click AUTO-SENS function

• Low Latency VS Streaming driver

• Low-noise, wide-range power supply

• Durable aluminum body

UA-55 309-590 £137.50

Studiospares USB A/D Interface Leads

USB 2.0 A Male to 4 Phono plugs

2m long.

• 16bit/48kHz Cable Type USB A

analogue audio interface

• Converts analogue signals to digital

data and sends it to your computer

to be recorded

• USB powered WIN98 SE,

WIN2000, WIN, ME, WIN XP

• Impedance: 90±13% Ohms

• Transmission speed: 24Mbps and

above

USB 2.0 - 4x Phono 589-980 £9.99

CLEARANCE!

M Audio Vocal Studio Pro

Vocal Studio Package

The all-in-one solution for your

computer-recording projects.

• M-Audio M-Track Interface

• M-Audio large diaphragm vocal

microphone

• M-Audio studio headphones

• Avid Pro Tools Express with iLok

USB key

• Ignite by Air (Download)

• Mic clip

• XLR microphone cable

• USB cable

• User Guides

• Safety & Warranty Manual

Vocal Studio Pro 374-370 £65.83

Vocal Studio Pro II 374-380 £115.83

NEW

M Audio Vocal Studio Pro II

Complete Recording Package

The all-in-one solution for your

computer-recording projects.

• M-Audio M-Track Interface

• M-Audio large-diaphragm

condenser microphone

• M-Audio studio headphones

• Ableton Live Lite

• Waves plugin pack

• Mic clip

• XLR microphone cable

• USB cable

• User Guides

• Safety & Warranty Manual

• Achieve Accurate Audio Recordings

NEW

Studio 192 338-080 £649.17

Presonus Studio 192

USB Audio Interface

Flexible connectivity in addition to professional monitoring

and mixing controls in a single rack-space unit

• 22x26, 24-bit, 192 kHz audio interface and studio command

center

• Input monitoring with StudioLive® Fat Channel DSP processing on

every analogue input and the first ADAT inputs

• Integrated zero-latency monitoring

• Speaker switching and talkback

SPL Crimson II

USB Audio Interface + Monitor Controller

Crimson combines an audio

interface with high-quality

preamps and a fully-featured

monitor controller.

• Max. six recording and six playback

channels

• 10 source connections, 20

monitoring channels

• 34V operational voltage for pro

levels up to +22dBu

• 24Bit/192kHz converter

• Two discrete mic preamplifiers

• Two instrument preamplifiers (Hi-Z,

+22dBu)

• Two separate headphones amps

• Connect and control two stereo

speaker sets

Crimson II 340-160 £407.50

NEW

SPL Creon

USB Audio Interface + Monitor Controller

Creon is designed to operate

with your Digital Audio

Workstation.

• 2 discrete SPL mic preamplifiers

• Instrument preamplifier (Hi-Z, +22

dBu)

• 2 Line inputs

• 2 Channel USB-Interface with

24Bit/192kHz converter

• USB Class 2.0 compliant for iOS

device recording/monitoring

• Powerful headphone amplifier

• Stereo speaker output

• Play-along and monitoring also

without DAW (stand-alone)

• Real-time analog monitoring

• One knob monitor mix

Creon 340-170 £274.17

NEW

Delivery before noon...

No problem!

Saturday delivery...

No problem!

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:45 Page 5

Audio Interfaces/Sound Cards - USB 35

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Focusrite Scarlett 2nd Generation

The second generation Scarlett range is packed full of upgrades.

Solo

Second generation 2 in / 2 out USB 2.0 audio interface with one Scarlett mic preamp and one instrument

input, 24bit/192kHz & USB bus powered. Pro Tools | First & Ableton Live Lite recording software, plug-ins

and samples included. Mac & PC compatible. Super-low latency.

2i2

The Scarlett 2i2 is a 2 in / 2 out USB recording interface featuring two Focusrite mic preamps housed in

an attractive anodized aluminium unibody chassis. Excellent 24-bit digital performance and sample rates

of up to 192kHz. Rugged metal unibody case. Low latency.

2i4

Similar to the 2i2, but with a 2 in / 4 out USB audio interface.

6i6

Second generation 6 in / 6 out USB 2.0 Audio interface with two Scarlett Mic/Instrument preamplifiers,

24bit/192kHz, two line outputs and two headphone outputs. Software and sample pack included. Mac /

PC compatible. Super Low latency.

18i8

Second generation 18 in / 8 out USB 2.0 Audio interface with four Scarlett Mic preamps, 24bit/192kHz,

eight ADAT inputs, four line inputs, two main monitor outputs and two headphone outputs. Recording

software included. Mac / PC compatible. Super Low latency.

18i20

Second generation 18 in / 20 out USB 2.0 audio interface with eight Scarlett Mic preamps, 24bit/192kHz,

eight ADAT inputs, eight line outputs, two main monitor outputs and two headphone outputs. Recording

Software Included. Mac/PC compatible. Lowest roundtrip latency in its class.

Solo Studio

The complete professional recording package for musicians. Includes Scarlett Solo USB audio interface,

CM25 large diaphragm condenser microphone, HP60 closed-back headphones, 3 metre / 10' XLR mic

cable, Stand clip for attaching the microphone to a stand and Recording software and effects.

2i2 Studio

Similar to the 2i2 Studio, but with a Scarlett 2i2 USB audio interface instead.

For more information and

accessories on these products,

please see our website.

Scarlett Solo 392-200 £70.83

Scarlett 2i2 392-210 £98.33

Scarlett 2i4 392-220 £117.50

Scarlett 6i6 392-230 £154.17

Scarlett 18i8 392-240 £215.83

Scarlett 18i20 392-250 £342.50

Scarlett Solo Studio 392-260 £132.50

Scarlett 2i2 Studio 392-270 £154.17

NEW

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:46 Page 6

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Audio Interfaces/Sound Cards - USB + Firewire + Hybrid + Thunderbolt

Audio Interfaces/Sound Cards - USB

Continued

IK iRig Pre

Mic Interface

The first studio-quality mic-

preamp for the iOS platform.

• Create music any time, anywhere

• Simple, intuitive use

• Plug microphone into your iOS

device

• Phantom power available

iRig Pre 321-530 £28.75

Shure Motiv MVi

Digital Audio Interface

Connects any microphone,

guitar, bass or keyboard to any

iOS device, Mac or PC for high-

quality audio capture.

• Intuitive touch panel allows easy,

real-time access to volume, gain

and mode selection functions

• Equipped with five built-in DSP

preset modes

• Includes (1) Micro-B to USB Cable

and (1) Micro-B to Lightning cable

• Supplies 12-48v phantom power

• Discrete JFET Class A buffered

instrument preamplifier input

Motiv MVi 443-900 £99.17

Audio Interfaces/Sound Cards - Firewire

Focusrite Saffire Pro 40

Features eight award-winning Focusrite preamps!

The Pro 40 delivers seamless integration, excellent routing flexibility and future-proof, rock-solid driver stability. The eight preamps ensure

low noise and distortion, whilst quality digital conversion and JetPLL jitter elimination technology ensure pristine audio quality as your

audio flows between the analogue and digital domains. The Pro40 offers a host of I/O options; 10 analogue outputs, ADAT I/O, stereo

SPDIF I/O and 2 virtual 'loopback' inputs for routing digital audio between software applications. Every channel features phantom power,

with the first two channels also featuring -9dB pads for additional headroom. Front panel 5-LED metering for each analogue input offers

accurate viewing of levels. 2 independent headphone outputs each have front-panel controls.

Saffire Pro 40 389-640 £315.83

Saffire Pro 40 + Rode NT1A 389-641 £432.50

MOTU 24Ao

Serving as an audio interface,

analogue-to-digital converter,

or standalone mixer. 24

channels.

375-710 £750.00

ALSO RECOMMENDED

More products online...

Audio Interfaces/Sound Cards - Hybrid

828 MK3 375-440 £565.83

MOTU 828 Mk3 Hybrid

Hybrid Firewire/USB2 Interface

Equally well-suited for studio and stage, with or without a

computer.

• Flexible connectivity to any Mac or PC via FireWire or high-speed

USB 2.0

• Ten channels of pristine 192 kHz analog recording and playback,

combined with sixteen channels of ADAT digital I/O and stereo

S/PDIF

• Connect all of your studio gear, including microphones, guitars,

synths, keyboards, drum machines and even effects processors

• Record, monitor, route and process all of these live inputs using

the professional on-board CueMix FX digital mixer

• Signal overload protection gives you an extra 12 dB of headroom

above zero with no digital clipping or harsh artefacts

• Full-screen real-time FFT display

Motu Ultralite MKIII

Updated to include both USB

and Firewire connection

options to expand the

compatibility of the interface.

375-470 £415.83

ALSO RECOMMENDED

More products online...

Audio Interfaces/Sound Cards - Thunderbolt

MOTU 828x

MOTU’s all-time best selling audio

interface, now with Thunderbolt

technology and USB 2.0.

Connect up to six devices total (with the 828x at the end of

the chain), and the Thunderbolt bus won't even break a

sweat. Thunderbolt combines plug-and-play convenience

with massive bandwidth and low latency for truly professional

audio interface performance. Two combo-style mic/guitar

inputs with preamps, 8 balanced analogue in/out, XLR main

outs, 16 channels of ADAT optical (8 channels at 96 kHz),

plus S/PDIF, word clock and MID. With recording up to 192

kHz the 8unique V-Limit™ hardware limiter offers an

additional 12 dB of headroom over digital zero with no digital

clipping or harsh artifact. After programming the on-board

mixing in the studio, unplug the 828x from the computer and

take it on the road for operation as a stand-alone mixer with

effects. All mixing and effects parameters are adjustable using

the front panel backlit LCD.

828X 375-610 £665.83

MOTU 16A

Provides industry-leading

dynamic range and large

console style mixing.

375-660 £1165.83

ALSO RECOMMENDED

MOTU 8M

Equally well-suited for studio and

stage, as an interface or

standalone mixer.

375-650 £1165.83

MOTU 112D

Popular in studios and stage. 24

channels of AES/EBU I/O and 64

channels of MADI I/O.

375-690 £1165.83

More products online...

MOTU 1248

Designed for studio recording,

installed sound, and live sound

reinforcement applications.

375-640 £1165.83

Focusrite Saffire Pro 26

Adds another highly flexible

Firewire audio interface to the

Saffire series soundcards.

392-050 £224.17

Free Catalogue

Are you reading someone

else’s catalogue? Why not

call us and order your own

copy... It’s free!

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:46 Page 7

Audio Interfaces/Sound Cards - Thunderbolt + iOS 37

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Focusrite Clarett Series

The best-sounding, fastest range of Thunderbolt interfaces.

Combining Focusrite’s passion for sound quality with the very latest in Thunderbolt technology, the Clarett range features brand new

transformer-modeled preamps, crystal clear conversion, and interface latency so negligible that you can monitor and track within your

software without any noticeable delay. The Clarett preamps model the impedance and transformer resonance of the iconic Focusrite

ISAs. This gives you the same exceptional clarity and signature sound at the touch of a button.

Clarett 2Pre

• 10 in / 4 out

• Transformer-modeled preamps

• Crystal clear conversion

• Single independent headphone output

Clarett 4Pre

• 18 in / 8 out

• 4 Independent line outputs

• 2 headphone outputs

• SPDIF i/o

Clarett 8Pre

• 18 in / 20 out

• Independent word clock output on BNC

• A wealth of connectivity in a 1U rack space

Clarett 8PreX

• 26 in / 28 out

• Extended ADAT i/o

• Dedicated phantom power, and high pass filters

on every channel

2Pre 392-140 £315.83

2Pre + 2m TB Cable White 392-145 £332.50

4Pre 392-150 £411.57

4Pre + 2m TB Cable White 392-155 £436.67

8Pre 392-160 £504.17

8Pre + 2m TB Cable White 392-165 £524.17

8PreX 392-170 £612.50

8PreX + 2m TB Cable White 392-175 £637.50

In addition, new custom potentiometers deliver superior

linear gain. Every Clarett interface boasts the same

unrivaled dynamic range and crystal clear conversion, to

capture every nuance of your sound.

8PreX

8Pre

4Pre

2Pre

Audio Interfaces/Sound Cards - iOS

Tascam IXR

Audio Interface

A very portable audio MIDI interface that can be connected

directly to an iPad with the lightning cable that usually

comes with an iOS device.

• Audio/MIDI interface for iOS, MacOS and Windows

• Support for high-resolution recording formats up to 96 kHz and 24

bits

• Two Ultra-HDDA (High Definition Discrete Architecture) mic preamps

• Balanced XLR/TRS input jacks that can provide +48V phantom

power

• Two balanced analogue TRS output jacks suitable for connection

to powered monitors

• Direct monitoring Mono/Stereo switching

NEW

IK Multimedia iRig HD 2

Professional quality digital guitar

interface for iPhone, iPad, Mac and PC.

1/8" Headphone-mic jack connection.

321-890 £81.25

ALSO RECOMMENDED

IK Multimedia iRig Acoustic

Acoustic Guitar Mobile

Microphone/Interface for iPhone and

iPad. Headphone output.

321-920 £39.58

More products online...

IK Multimedia iRig 2

Guitar & instrument interface adapter

for iPhone, iPod touch, iPad, Mac and

Android. Fits in your pocket.

321-930 £31.25

NEW

Studio 192 Mobile 338-200 £465.83

Presonus Studio 192 Mobile

USB 3.0 Audio Interface

Delivers exceptional sonic fidelity, flexible connectivity, and

professional monitoring and mixing controls in a compact

desktop design.

• 26x32, 24-bit, 192 kHz audio interface and studio command

center

• Input monitoring with StudioLive® Fat Channel DSP processing on

every analogue input and the first ADAT inputs

• Integrated zero-latency monitoring

• Speaker switching and talkback

NEW

RED 4Pre 392-190 £1698.33

Focusrite RED 4Pre

Audio Interface

Red represents the pinnacle of Focusrite’s interface range.

• 58 in/64 out Thunderbolt and Pro Tools HD compatible interface

• ‘Parallel path summing' conversion

• Dual Ethernet ports for Dante audio-over-IP networking

• Ethernet for up to 64 additional channels anywhere on your network

• Low latency

• –129 dB EIN and 63dB of gain

• Mic pres can be controlled digitally, for adjusting/recalling settings

and stereo linking via Focusrite Control software

• 24-bit/192kHz sampling capability

• 118dB(A-D)/121dB (D-A) dynamic range

NEW

IXR 238-790 £117.50

PRICE

DOWN

More Products Online...

Trade Counter

Visit our trade counter!

You’ll get friendly advice

and immediate access to

8000+ product lines. Free

Parking also for 40 cars!

Delivery before 10am...

No problem!

2017 CAT PAGES 30-39:Layout 1 16/12/2016 09:18 Page 8

Focusrite Rednet AM2

Stereo Dante headphone amplifier

and line output interface solution

with PoE.

• Cost-effective headphone/

loudspeaker stereo monitoring

solution

• Superb digital to analogue

conversion at up to 96kHz provides

transparent audio quality

• Powerful headphone amp delivers

plenty of level even with high-Z

headphones for maximum audibility

• Independent headphone/line output

level controls for maximum control

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Audio Interfaces/Sound Cards - Network + Digital Converters

Audio Interfaces/Sound Cards - Network

Focusrite Rednet Range

Audio Interfaces/Signal Distribution

Designed with multiple audio applications in mind – from Live

Sound rigs to Multi-room Recording Studios, Houses of Worship,

Audio Distribution Installations, Post Production environments and

anything in-between – fundamentally RedNet is an extremely

scalable, near zero latency audio distribution system that can be

used to expand I/O channel count, interface digital components,

and/or bridge between Pro Tools|HD or MADI and the Dante audio

network. It harnesses the power of Audinate’s tried and tested

Dante digital audio networking system to bring studio quality

sound to any modern audio application.

Email or phone us for a quote or for more information.

Focusrite Rednet 1

Connects to your network with a single Ethernet cable.

• Eight channels of line-level analogue in and out

• 24-bit A-D and D-A conversion for superb audio performance

• 119dB dynamic range at sample rates up to 192kHz

• The rear panel includes standard DB25 connectors

Focusrite Rednet 2

Same as above but with 16 analogue channels instead of 8.

Focusrite Rednet 3

Interfaces your existing digital audio systems and

components to the RedNet network.

• Up to 32 inputs and outputs and full software remote control

• Includes support for AES/EBU, S/PDIF and ADAT formats

• Allows the RedNet system to be synchronised to incoming signal

clock or a word clock source

Focusrite Rednet 4

Adds eight of the latest remote-controlled Focusrite

mic preamps / line inputs to your RedNet system.

• Eight high-quality Focusrite 'RedNet' mic preamps

• DC-coupled signal path for open and transparent sound

• Selectable line and DI inputs for input flexibility

• Dynamic range: 119dB; Mic input Level up to +16dBu

Focusrite Rednet 5

Connects your RedNet system to Pro Tools HD®.

• Each RedNet 5 can route up to 32 input and 32 output channels

between your RedNet network and Pro Tools HD system

• Connecting six RedNet 5 units to a Pro Tools HDX system allows

up to 192 inputs and outputs

• Compatible with Pro Tools HD® TDM system

RedNet 1 389-920 £1399.17

RedNet 2 389-930 £2082.50

RedNet 3 389-940 £1049.17

RedNet 4 389-950 £1607.50

RedNet 5 389-960 £874.17

RedNet 6 389-970 £1399.17

RedNet D16 392-040 £1049.17

RedNet A16R 392-770 £2332.50

RedNet AM2 392-780 £316.66

RedNet A8R 392-790 £1857.50

RedNet PCIe Card 389-980 £582.50

RedNet PCIeR Card 392-800 £699.17

Focusrite Rednet 6

Allows multiple channels to be carried along a single interface.

• Provides the link between your RedNet Ethernet-based audio

system and any MADI / AES10 setup

• Supports up to 64 channels of both coaxial and optical MADI

interfaces

• External Word Clock I/O for either RedNet or MADI

Focusrite Rednet D16

1U 16-channel AES3 I/O for Dante audio networks.

• Ethernet Redundancy

• Sample Rate Conversion on all input channels

• Input and Output on XLR as well as DB25

• XLR Input for DARS or Digital Audio

Northbrook College

Northbrook College offers a range of Foundation and

BA(Hons) Degrees revolved around Music Business,

Composition for Film and Media, Music Performance and

Music Production. With a new campus build in the pipeline,

and the diversity of projects, flexibility was a must when

deciding on methods of converting audio signals and

sending them to various rooms in the building. The College

have recently installed RedNet systems in three of their

control rooms, alongside their Pro Tools HDX systems. With

recent investments in Dante fitted live consoles, Northbrook

can now offer range of possibilities with tracking into their

control rooms from both studio and live performances.

RedNet Case Study

Focusrite Rednet A16R

16 channels of Dante-networked A-D and D-A conversion,

with network and PSU redundancy.

• 16 channels of high-quality line-level analogue I/O

• 24-bit precision Focusrite conversion up to 192kHz

• 119dB dynamic range, flat from 20Hz – 20kHz, +/-0.15dB

• Internally balanced throughout

• Analogue I/O to AES59 standard on DB25 connectors

Focusrite Rednet A8R

Stereo Dante headphone amplifier and line output interface

solution with PoE.

• Eight channels of high-quality line-level analogue I/O

• 24-bit precision Focusrite conversion up to 192kHz

• 119dB dynamic range, flat from 20Hz – 20kHz, +/-0.15dB

• Internally balanced throughout

• Dante-based remote-controlled audio-over-IP connectivity

• Dual power supplies and network connections with full power and

network redundancy, including latching connectors for maximum

reliability

Focusrite Rednet PCIe Card

For situations in which low-

latency performance is critical.

• 128 channels in and out

• Compatible with any Dante network

• Up to 192 kHz sample rate

• Under 3ms analogue-to-analogue

round-trip latency (Dependent on

ASIO/Core Audio buffer size)

Focusrite RedNet PCIeR Card

Dedicated Dante audio interface

card with network redundancy

for Windows or Mac.

• Dual Ethernet ports for full

redundancy

• 128 channels in and 128 channels

out at 96kHz and below

• 64 channels in and 64 channels out

at 176.4kHz and 192kHz

NEW

Digital Converters

M Audio Micro DAC

Portable Digital-to-Analogue Converter

with Analogue & Coaxial Digital

Outputs. Aluminum housing.

374-460 £82.50

ALSO RECOMMENDED

More products online...

M Audio Transit Pro

Super-high resolution USB to

optical/DSD converter. 32bit/384kHz

digital “engine.”

374-480 £165.83

NEW

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:46 Page 9

MIDI Interfaces + MIDI Controllers 39

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

MIDI Interfaces

IK Multimedia iRig Pro

Universal Audio-MIDI interface for

iPhone, iPad and Mac. Preamp gain

control.

321-720 £87.50

ALSO RECOMMENDED

IK Multimedia iRig Pro Duo

Truly mobile dual input audio interface

for iPhone, iPad, Android, Mac and

PC. Simultaneous dual track recording.

321-900 £157.50

More products online...

M-Audio MIDISport 2x2

One of the first to be equipped with

the high speed USB connection

suitable for use with PCs or MACs.

360-910 £33.33

NEW

Yamaha UD-BT01

Bluetooth wireless MIDI adaptor for

connecting instruments with a USB

TO HOST terminal to your iOS devices.

274-900 £35.00

NEW

Yamaha MD-BT01

Bluetooth wireless MIDI adaptor for

connecting instruments with MIDI

IN/OUT terminals to your iOS devices.

274-910 £32.50

NEW

UMC1820 384-920 £218.33

Behringer UMC1820

USB Audio MIDI Interface

Audiophile 18x20, 24-Bit/96 kHz USB Audio/MIDI Interface

with MIDAS Mic Preampliers.

• 8x20 USB2.0 Audio/MIDI Interface with ADAT I/O for recording

microphones and instruments

• Audiophile 24-Bit/96 kHz resolution for professional audio quality

• Compatible with popular recording software including Avid Pro

Tools*, Ableton Live*, Steinberg Cubase*, etc.

• Streams 18 inputs and 20 outputs of ultra-low latency audio to

your computer, supporting Mac and Windows

• 8 state-of-the-art, MIDAS designed Mic Preamplifiers with +48 V

phantom power

• Optical I/Os supporting S/PDIF, ADAT and S/MUX formats up to

96 kHz

NEW

MIDI Controllers

Behringer B-Control Fader BCF2000

MIDI Controller

An innovative, hands-on control

surface with ultra-precise

100mm motorised faders...

• The ultimate control for virtual

mixers, organ-drawbars, synths and

samplers

• Motorised faders for automated

control

• Full MIDI In/Out/Thru capability

• 8 endless rotary encoders, each

with a 15-element LED indicator

• USB compatible

BCF2000 380-030 £224.17

Behringer X-Touch

Universal Control Surface

Provides you with hands-on

control over your DAW via HUI

or Mackie control protocols.

• Comprehensive control surface for

DAW/X32 mixer

• Touch-sensitive 100mm motorised

faders

• Rotary controls with LED-collars

• Smooth jog wheel

• Colour-coded LCD scribble strips

• USB and 5-pin MIDI integration

• Ethernet interface for Real-Time

Protocol MIDI and X32

X-Touch 384-820 £500.00

X-Touch Mini 384-810 £50.83

X-Touch Compact 384-800 £337.50

Behringer X-Touch Mini

Ultra-Compact Universal USB Control Surface

Puts the power of your

production software right at

your ngertips.

• Features a 60 mm master fader

• Use one layer for virtual synths –

and the other to control lighting

• A true plug-and-play USB control

surface you can take anywhere

• 8 rotary controls with LED-collars

• 16 illuminated buttons

• Control plug-ins and DAWs via MIDI

or Mackie Control protocols

• Tough, ultra-compact design

Behringer X-Touch Compact

Universal USB/MIDI Controller

For control over DAW,

instruments, effects and lighting

systems.

• 9 touch-sensitive and fully-

automated motorised faders

• Dual-Layer Mode between DAW

and instrument control

• Preconfigured controls for instant use

• Universal Remote Control for DAWs,

Instruments, Effects and Lighting

• Mackie Control* mode

• ED-collars for on-the-fly adjustments

• 39 illuminated buttons

• USB/MIDI interface & MIDI I/O ports

Novation Launchpad Pro

MIDI Controller

The simplest and best way to

create dynamic, expressive

performances in Ableton Live, or

any music software.

• 64 RGB backlit velocity and

pressure sensitive button grid

• 32 RGB backlit round mode buttons

• One setup button

• Front LED strip

• Orange rubber base mat

• High retention USB connector

• Two MIDI sockets (3.5mm jack

sockets with MIDI din cables)

• Power supply connector

• Power switch

• Kensington Security Slot

Launchpad Pro 389-490 £182.50

Novation Launchpad Mini MkII

MIDI Controller

The all new MK2 version of

Novation's popular USB grid

controller for Ableton Live.

• 64 multicoloured backlit pads +16

function buttons

• Inc Ableton Live Lite, Novation Bass

Station virtual instrument and 1GB

of Loopmasters samples

• A smaller and portable controller for

compact setups

• Connect to a iPad to control all

sorts of iOS music apps

• Pads backlit with LEDs showing

status of loaded clips

• Buttons to trigger scenes, switch

modes and session navigation

• USB bus-powered

Launchpad Mini MkII 392-700 £69.99

Novation Launchpad MkII

Lets you launch clips, play drum racks

and control your mixer while creating

lightshows.

392-750 £120.00

ALSO RECOMMENDED

More products online...

Behringer FCB1010

Helps you get the most out of your

gear without tying up your hands or

slowing down your performance.

370-140 £111.67

PRICE

DOWN

PDF Catalogue

Want this catalogue on

your phone or laptop?

Download it in PDF format

from our website today!

Delivery before noon...

No problem!

Saturday delivery...

No problem!

Delivery before 10am...

No problem!

2017 CAT PAGES 30-39:Layout 1 13/12/2016 10:46 Page 10

WEB |www.studiospares.com EMAIL |sales@studiospares.com

DJ Controllers + MIDI Keyboards

Numark Mixtrack Pro III

DJ Controller

Mixtrack Pro is a complete DJ

system that works with the

music on your Mac or PC.

• Classic two-turntables-and-a-

mixer setup

• Large, touch-sensitive turntables

for accurate scratching and beat-

juggling

• Houses a complete audio interface

for top-quality sound

Mixtrack Pro III 277-510 £149.99

DJ Controllers

Korg Kaoss Pad KP3+

Use the touchpad to control effects

in real time. A total of 150 effects for

remixing, DJs and live applications.

273-670 £275.00

ALSO RECOMMENDED

Behringer CMD Studio 2A

The compact and ultra-portable

CMD STUDIO 2A lets you create

moods on the fly.

384-590 £73.33

Behringer CMD Touch TC64

Clip Launch Controller with 64

Buttons and Multi-Color LED

Feedback.

384-600 £49.17 More products online...

MIDI Keyboards

M Audio Oxygen 3rd Generation

Perfect for composing on the go or performing live bass lines and pads, firing

samples, or triggering audio and/or visual effects.

Featuring 25 keys with 4 octave transposition, the Oxygen 25 is a fully functional MIDI keyboard gives great action. The Oxygen 49 is a 49-

key USB MIDI controller and it also features nine assignable sliders. The Oxygen 61 is a 61-key USB MIDI controller plus dedicated transport

and track select buttons. Furthermore the Oxygen MIDI keyboards features eight MIDI assignable knobs to control any MIDI parameters you

desire in your hardware or software, pitch and mod wheels, dual MIDI outputs one from keyboard, one from computer and keyboard doubles

as elegant user interface. Includes full MIDI message support, plus 6 transport controls that can be reassigned to any MIDI parameter.

This MIDI controller is powered via USB

bus, batteries or DC adapter, and includes

a Maximum Audio Tools software bundle.

Oxygen 25 373-380 £65.83

Oxygen 49 373-390 £95.00

Oxygen 61 373-400 £115.83

IK Multimedia iRig Keys Series

USB MIDI Keyboards

The affordable USB MIDI controllers for Mac/PC

• Velocity-sensitive mini-keys (2 full octaves range plus 1 note)

• Volume/Data knob (assignable)

• Back-lit, soft-touch Octave Up/Down buttons

• USB class compliant (Mac/PC) - plug and play

• Powered from the Mac/PC USB

• iRig Keys 25 and 37 - Mini keys

• iRig Keys 37 PRO - Fully-sized keys

iRig Keys 25 - 25 Mini Keys 321-940 £47.92

iRig Keys 37 - 37 Mini Keys 321-950 £62.08

iRig Keys 37 PRO - 37 Keys 321-960 £79.17

NEW

Alesis V Series

USB MIDI Controllers

Combine velocity-sensitive keys with eight drum/trigger

pads, allowing virtual instruments to be played with

dynamic expression.

• Full size, flat-front keys (25, 49, or 61)

• Pitch Bend and Modulation Wheels

• 8 Pads with blue LED illumination

• 4 Assignable knobs and buttons

• Sustain pedal input

• Octave shift keys

V25 25-Note 395-240 £57.50

V49 49-Note 395-250 £74.99

V61 61-Note 395-260 £104.16

Akai LPK25

Laptop Performance Keyboard

A USB-MIDI controller for musicians, producers, and DJs.

• 25 velocity-sensitive mini-keyboard keys

• Arpeggiator, sustain button, octave up and down, and tap tempo

controls

• Plug-and-play USB connection for Mac and PC

• Small enough to fit in a backpack or laptop bag

• Four programmable memory banks

LPK25 265-870 £32.50

More Products Online...

Behringer Motor 49

USB MIDI Keyboards

USB/MIDI Master Controller Keyboard with Motorized

Faders and Touch-Sensitive Pads.

• 49 semi-weighted full-sized keys, 60 mm faders and backlit

velocity and pressure sensitive drum pads

• Hardware-based arpeggiator to add arpeggios to software and

hardware synths and create complex arrangements on the fly

• Spacious, backlit LCD screen

• Loaded with a variety of useful presets

• Free audio recording, editing and podcasting software with 150

instruments and effects plug-ins

• Total control over soft synth drum sounds

Motor 49 49-Note 384-840 £295.83

Alesis Q Series

USB/MIDI Keyboard Controller

Keyboard controllers that work with virtually all music

software and MIDI hardware devices.

• For use with virtually all music software and MIDI devices

• Velocity sensitive keys for expressive, musical performance

USB MIDI and traditional MIDI for use with Mac and PC

• Pitch and Modulation wheels for capturing musical expression

• Backlit Octave Up and Down buttons expand your range

• Assignable volume/data-entry slider enables you to control your

most-used parameter

• Production package included: Xpand!2 by AIR Music Tech, and

Ableton Live Lite Software

Q25 25-Note Keyboard 385-640 £40.83

Q49 49-Note Keyboard 385-540 £49.17

PRICE

DOWN

Delivery before noon...

No problem!

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:25 Page 1

MIDI Keyboards + Synthesizers 41

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

M Audio Keystation 49 II

Step into computer-based music creation and performance with the Keystation

49 keyboard controller from M-Audio.

Keystation 49 is a simple, powerful MIDI controller designed for sequencing music and playing virtual instruments on your Mac or PC. It

features 49 full-size velocity-sensitive keys and a series of controls that expand the range of playable notes, expressive capabilities, and

enhance your recording workflow. Use the octave range buttons; pitch-bend and modulation wheels; and transport and directional controls

to play, perform, and record with your music software without using a mouse or trackpad. Keystation 49 also includes a 1/4” (6.3mm) sustain

pedal input that lets you use an external control pedal, such as the SP2 (sold separately), for genuine piano sustain.

Keystation 49 II 373-140 £57.50

M Audio Keystation 61 II

USB MIDI Keyboard Controller.

61-Key Semi-Weighted

keyboard.

363-590 £90.83

ALSO RECOMMENDED

M Audio Keystation 88 II

USB MIDI Keyboard Controller.

61-Key Semi-Weighted

keyboard.

363-710 £124.17

M Audio Keystation Mini 32

Portable Keyboard Controller.

32 velocity-sensitive synth-action

keys.

374-040 £32.50 More products online...

M-Audio CTRL 49

USB MIDI Controller

49-Key USB/MIDI Smart Controller with Full-Color Screen.

• Integrated 4.3-inch high-resolution full-color screen

• Includes Virtual Instrument Player software

• Custom 49-key M-Audio semi-weighted keybed with aftertouch

• 9 faders and 8 buttons for instant and seamless DAW control

• 8 performance-ready 360-degree knobs

• 8 velocity- and pressure-sensitive drum pads with RGB illumination

• Dedicated pad bank, transport control, octave, and performance

buttons

• Roll mode, time division, pattern arpeggiator, and tap tempo

buttons

• Expression pedal and footswitch inputs; 5-Pin MIDI IN/OUT

CTRL 49 374-410 £274.17

NEW

Alesis VX49

Controller Keyboard

The VX49 fuses the creative power of software

instruments with the live playability of a keyboard

workstation.

• High resolution colored screen with dedicated interface buttons

• Screen provides 1:1, real-time feedback of plugin parameters

• Includes VIP — load, play, & control any VST plugin

• 8 performance-ready 360° knobs

• Custom 49-key Alesis semi weighted keybed with aftertouch

• 8 velocity- & pressure-sensitive drum pads with RGB illumination

• Expression pedal and footswitch inputs

VX49 395-410 £249.17

NEW

Alesis V Mini

Portable 25-Key USB-MIDI Controller

The Alesis V Mini is a powerful, intuitive, and portable

MIDI controller that lets you take full command of your

music software.

• Compact USB-powered design lets you create anywhere

• 25 expressive velocity-sensitive, synth-action mini keys

• 4 backlit velocity-sensitive drum pads; 4 backlit assignable knobs

• Dedicated octave, pitch bend, modulation, and sustain buttons

• Includes Xpand!2 virtual instrument software by AIR Music Tech

V Mini 395-420 £40.83

NEW

Synthesizers

Novation Bass Station II

An analogue mono-synth based

on the classic original Bass

Station but re-worked.

389-420 £312.49

ALSO RECOMMENDED

Novation Mininova

A compact performance synth

with the same sound engine as

its big brother: the UltraNova.

389-370 £211.67

Yamaha Reface CS

An Analogue Physical Modeling

Engine with multiple synthesis

and oscillator types.

364-400 £275.00

More products online...

Yamaha Reface DX

Perfect for creating emersive pad

sounds as well as other multi-

timbral effects.

364-410 £275.00

Yamaha Reface CP

Utilises a Vintage Keyboard

Sound Engine with six incredibly

detailed vintage keyboard types.

364-420 £275.00

Yamaha Reface YC

Utilises a AWS Organ Flute

Sound Engine with six incredibly

detailed vintage Organ types.

364-430 £275.00

Roland System 1

Plug Out Synthesizer. Controls

plug-in versions of now

legendary Roland synths.

319-130 £340.83

Roland Juno DS Series

Synthesizers

Roland’s JUNO synths are known everywhere for their

great sound, ease of use, and exceptional value.

• Lightweight, gig-ready instrument with pro sound

• Includes all the sounds from the popular JUNO-Di

• Velocity-sensitive keyboard with synth action

• Easy sound manipulation and editing with knobs and sliders

• Intuitive eight-track pattern sequencer

Juno DS61 319-370 £440.83

Juno DS88 319-380 £682.50

NEW

PRICE

DOWN

Quantity Discounts Apply

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:25 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Synthesizers + Samplers + Sound Modules + Computer Accessories

Synthesizers

Continued

M-Audio Accent 88-Key

88-Key Digital Piano with Hammer Action

Professional features, versatility, natural playing response

and rich sound to meet any requirement.

• Authentic hammer-action weighted 88-key keybed

• Professional XLR outputs for top quality audio

• 20 built-in voices, can split or layer two voices simultaneously

• Top-quality AIR Music Technology Steinway piano samples included

• Built-in DSP with adjustable EQ, Reverb, and Chorus FX

• Transpose control, built-in metronome

• Expression pedal and footswitch inputs; 5-Pin MIDI IN/OUT

Accent 88-Key 374-390 £224.99

Accent Module 374-400 £149.99

NEW

M-Audio Accent Module

Stage Piano Module with USB MIDI Hosting

When players want to convert their standalone MIDI controller into

a stage piano, free from the restrictive encumbrance of a laptop

computer, the M-Audio Accent Module is the perfect solution. This

compact unit easily connects to any USB or 5-pin MIDI controller.

With 20 built-in voices, it has the ability to split or layer two voices

simultaneously, plus it includes the superb, world-renowned AIR

Steinway Piano and AIR Structure VSTs.

NEW

Samplers

Roland SP-404 SX

Sampler

Powerful performance sampler

with 12 pads and 3 knobs.

• Sample anytime, anywhere with

built in mic and battery power

• 29 DSP effects with seamless

effects switching

• Pattern sequencer with quantize

and shuffle

• 1GB SD included, explainable to

32GB

• Import files from computer and

assign samples to pads

• Fast, fun hands-on sampler for

DJs, producers and engineers.

SP-404 SX 309-190 £315.83

Zoom ARQ Aero Rhythmtrak

Sampler

An all-in-one production and live

performance instrument.

• Drum machine, sequencer,

synthesizer, looper, clip launcher,

and MIDI controller in onedevice

• Includes 468 drum/instrument

sounds and 70 types of synthesizer

sounds

• 96 velocity- and pressure-sensitive

pads and 160 programmable

colourLEDs

• Grip Detection

• 3-axis accelerometer

• Use up to 5 effects simultaneously

• Onboard mixer

• Wireless Bluetooth® Ring Controller

ARQ Aero Rhythmtrak 378-650 £415.83

NEW

Alesis Sample Pad 4

Sampler

Add custom sounds to your

drum or percussion setup!

• 4 pads allow endless percussive

and sampling triggering possibilities

• Built-in library of 25 percussion and

electronic drum sounds

• 10 preset kits

• Accepts SD/SDHC cards up to

32GB, storing 89 user kits and 512

samples per card

• Dynamic blue LED lighting

• USB-MIDI output for use with virtual

instrument and recording software

Sample Pad 4 395-400 £124.99

NEW

Akai MPX8

A standalone SD sample launcher with

MPC pads. 8 velocity and pressure-

sensitive pads.

265-980 £65.83

ALSO RECOMMENDED

More products online...

Korg ESX2

Features an evolved step sequencer,

trigger pads, touch pads plus a hybrid

synth engine and Ableton Live Lite.

283-390 £311.67

Sound Modules

Roland VT-3

Easy voice transformation

with vocoder, lo-fi effects, and

synths you can sing.

319-160 £137.50

ALSO RECOMMENDED

More products online...

Roland TR-8

Rhythm Performer

Every control has a solid,

predictable feel with each drum

instrument having robust,

“playable” faders.

• Illuminated knobs and RGB-lit

buttons

• Control variations in your patterns

and any incoming external signal

• Reverse, glitch, gate, truncate,

stutter and perform rhythmic

variations

• 10 different types of Scatter and

adjust the intensity or ‘Scatter

Depth’

• Realtime pattern creation up to 32

steps

TR-8 319-150 £340.83

Roland A-01

Controller Sound Generator

Add custom sounds to your

drum or percussion setup!

• Ultra-compact controller and sound

generator

• Highly portable for mobile music

making

• High-quality construction with metal

front panel

• Dual assignable ribbon controls for

pitch bend, modulation, sound

preview, CC, and more

• MIDI over Bluetooth®

• CV/GATE outputs for legacy

analogue/modular synthesizers

A-01 319-400 £320.83

NEW

Boss RC-202

Desktop Loopstation

Perfect for club performers,

electronic musicians, and

beatboxers.

• Advanced BOSS technology in a

compact tabletop looper

• Two simultaneous stereo phrase

tracks with dedicated controls and

loop status indicators

• Four Input FX and four Track FX

• 64 phrase memories (8 memories x

8 banks)

• Expanded external control

• 17 onboard rhythm patterns

• XLR mic input with phantom power

RC-202 319-430 £262.50

NEW

Computer Accessories

Studiospares Laptop Stand Premium

Laptop Stand

Easily erected with no loose parts to misplace. Aluminium alloy

makes it light and strong. Shelf takes accessories keeping your

desktop clear. Laptop dimensions 350mm x 274mm. Shelf

dimensions 203mm x 120mm. Height adjustable from 320mm -

435mm. Colour White.

Laptop Stand Premium 449-510 £20.79

Studiospares LS100

Floorstanding Laptop Stand

Laptop is clamped to its tray

without covering ports, DVD

drive trays and expansion slots.

• Height adjustable between 610 -

1120mm

• Tray dimensions 400mm x 300mm

• Mouse tray dimensions 165mm x

200mm

• Two holders can be adjusted in

width and depth to securely anchor

any sized laptop

LS100 449-550 £29.99

PRICE

DOWN

More Products Online...

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:25 Page 3

Computer Accessories + Software 43

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Denon DN-271HE

HDMI Audio Extractor

Designed to augment the signal

routing capability of an A/V

system.

• 7.1 Channel HDMI Audio Extractor

• Separates audio signals from

digitally encoded content

• HDMI and Optical audio input

• Line level Euroblock connectors

• Supports HDMI and Optical audio

sampling rates up to 192kHz

• 4K2K ready

DN-271HE 272-070 £215.83

NEW Computer Software

Steinberg Wavelab 8.5

Computer Software

Accelerates workflows for

essential audio tasks such as

batch processing, file rendering

and working with encoders.

• Drag-and-drop automated offline-

processing feature

• Encoder Checker compares and

contrast codec quality and settings

on the fly without perceivable latency

• Render to multiple audio file formats

simultaneously and save encoding

chains as presets

• Encode straight to AAC formats,

such as HE-AAC, HE-AAC v2, HD-

AAC and 3GPP

Wavelab 8.5 365-070 £299.17

Wavelab 8.5 Academic* 365-075 £179.00

Elements 8.5 365-950 £53.33

Elements 8.5 Academic* 365-955 £40.83

*These codes and prices are only available to genuine educational

establishments on receipt of an official purchase order.

Steinberg Wavelab Elements 8.5

Computer Software

The affordable yet highly powerful WaveLab Elements production

environment is devoted to the needs of home producers and

musicians, delivering uncompromising quality when it comes to

editing and restoring audio material alongside creating state-of-

the-art podcasts. The smallest member of the current WaveLab

product range provides a convincing toolset which will most

certainly meet your requirements while seamlessly integrating into

your home studio setup.

Steinberg Cubase Pro 9

Computer Software

Used by star producers and

musicians for composing,

recording, mixing and editing

music.

• Combines outstanding audio quality,

intuitive handling and a collection of

highly advanced audio and MIDI

tools

• Ideal for Professional producers, film

composers, recording engineers

• Up to 256 different audio sources

• Unlimited audio and MIDI tracks

Cubase Pro 9 366-020 £390.00

Cubase Pro 9 Academic* 366-025 £234.17

Cubase Artist 9 366-030 £220.83

Cubase Artist 9 Academic* 366-035 £134.17

Cubase Elements 9 365-980 £66.66

Cubase Elements 9 Aca* 365-985 £45.00

*These codes and prices are only available to genuine educational

establishments on receipt of an official purchase order.

Steinberg Cubase Artist 9

Computer Software

Enhanced usability due to the brand-new take-comping system,

its commendable user interface, Windows and Mac 64-bit support

and many other refinements make Cubase Artist 8.5 the perfect

choice for talented newcomers and seasoned musicians. New

features include an outstandingly efficient new audio engine,

inspirational song- writing features, superb virtual instruments, FX

and amps, and much more.

Steinberg Cubase Elements 9

Computer Software

An entry-level Cubase package for music recording and

production. Cubase Elements 8 is your personal music studio,

incorporating professional workflows as used by countless

professional artists around the globe. Using the same technology

platform as its larger siblings in the Cubase family, Cubase

Elements 8 offers tools for intuitive song-writing, instruments to

develop your musical ideas and studio-grade effects.

Steinberg HALion 5*

Computer Software

A powerfully inspirational virtual

sampling and sound design

instrument that forms the heart

of modern sound creation and

production environments.

• State-of-the-art sampler and sound

creation system

• Up to 192 kHz, 32 stereo outputs

• Powerful multi-timbral audio engine

• Outstanding library including over

2,500 synthesized sounds

• AudioWarp and Full VST Expression

2 support

• Wide range of high-end audio effects

• Flexible user interface with multi-

monitor support

HALion 5 366-100 £191.67

HALion 5 Academic* 366-105 £124.17

*These codes and prices are only available to genuine educational

establishments on receipt of an official purchase order.

IK Multimedia iRig Blueboard

Bluetooth Pedal Controller

The first wireless MIDI

pedalboard controller for

iPhone, iPad and Mac.

• Bluetooth MIDI pedalboard

• 4 backlit assignable foot switches

• 2 1/4" inputs for assignable

expression pedals or switches

• Can send MIDI Program Changes

and MIDI Control Changes

• Direct integration with AmpliTube

• Runs on standard AAA batteries

• Small enough to fit in a laptop bag

Blueboard 321-980 £79.17

NEW

Startech 4-Port USB 3.0 Hub

USB-C to 1x USB-C and 3x USB-A

The first wireless MIDI

pedalboard controller for

iPhone, iPad and Mac.

• Expand the connectivity of your

USB-C enabled computer

• Portable and lightweight design

• Add both USB-C and USB-A ports

to your MacBook, Chromebook, or

computer that features a USB Type-

C port

• Thunderbolt 3 data port compatible

• Fast and easy installation

4-Port USB 3.0 Hub 515-150 £29.99

NEW

ALSO RECOMMENDED

Art M-Connect

For connection of any MIDI

device to your computer. USB

interface for any MIDI device.

Separate MIDI In and Out cables.

325-940 £20.83

IK Multimedia BlueTurn

Backlit silent Bluetooth page

turner for iPhone, iPad, Mac and

Android. 2 highly visible backlit

silent footswitch buttons.

321-970 £59.25

NEW

Startech 4-Way Hub

Add four external SuperSpeed

USB 3.0 ports from a single USB

connection. Also compatible with

USB 2.0 and USB 1.0 devices.

515-140 £24.99

NEW

Social Networking

You can now be kept up to date of all

things new at Studiospares via Youtube,

and Twitter. Follow us on all our social

media platforms!

Trade Counter

Visit our trade counter!

You’ll get friendly advice

and immediate access to

8000+ product lines.

More Products Online...

2017 CAT PAGES 40-49:Layout 1 13/12/2016 12:01 Page 4

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Studio Condenser Microphones

Studio Condenser Mics 44

Valve Mics 48

USB Mics 49

Ribbon Mics 49

Smartphone/Tablet Mics 50

Instrument Mics 50

Drum Mic Kits 53

Vocalist Mics - Condenser 54

Vocalist Mics - Dynamic 55

Broadcast Mics 59

Boundary Mics 60

Installation Mics 61

Stereo Mics 62

Lavalier Mics 62

Video Camera Mics 62

E.N.G. Reporting Mics 63

Highly Directional Mics 64

Headworn Mics 64

Speech Mics 65

Radiomics 66

In Ear Monitoring 72

Radiomic Accessories 72

Windshields 72

Pop Screens 73

Microphone Reflection Filters 74

Elastic Suspensions 75

Goosenecks 76

Microphone Holders 76

Microphone Hygiene 77

Smartphone Accessories 77

Phantom Power Supplies 78

Thread Adaptors 78

Mic Splitters/Combiners 79

Mic/Line Problem Solvers 79

Inline Attenuators 80

Passive DI Boxes 80

Active DI Boxes 82

Microphones Neumann TLM103

The mic for everyone who, despite budget limitations,

does not want to do without the uncompromising

Neumann sound.

Neumann microphones have long been the natural choice of the large studios and

broadcast facilities. The TLM 103 exhibits all the quality characteristics of its sister products

but with a huge price reduction. The large diaphragm capsule that characterises Neumann

products has an exceptionally high sensitivity. With just 7dB-A /1.5dB CCIR the self-noise

level of the TLM 103 is so reduced that even the smallest signals are reproduced basically

noise-free. As it is capable of handling sound pressure levels up to 138dB without

distortion, the TLM 103 provides a dynamic range of 131dB, according to DIN/IEC 651.

With TLM technology the usual output transformer is replaced by an electronic circuit,

which ensures good common mode rejection and prevents RF interference that may

influence the balanced signal. Supplied complete with a swivel microphone mount.

TLM103 Nickel 416-400 £599.17

TLM103 Black 416-410 £599.17

TLM103 Studio Set Nickel 416-460 £665.83

TLM103 Studio Set Black 416-465 £665.83

EA1 Elastic Suspension only 416-010 £140.83

Neumann TLM102 Cardioid

Condenser Microphone

A high-quality large-diaphragm

cardioid condenser microphone.

• Large-diaphragm microphone with

cardioid directional characteristic

built with transformerless

circuitry

• High maximum sound pressure

level

• Slight presence boost above 6 kHz

• Frequency range: 20 Hz - 20 kHz

with a presence boost above 6 kHz

TLM102 Black 416-430 £374.17

TLM102 Nickel 416-435 £374.17

Neumann TLM107

Condenser Microphone

The TLM107 features a newly

developed transducer that was

designed especially for this

microphone.

• Multipattern large diaphragm

microphone with 5 polar patterns

(omni, wide cardioid, cardioid,

hypercardioid, figure-eight)

• Navigation switch with LED

illuminated display for polar pattern,

PAD and low cut

• Sound characteristics: transparent,

natural reproduction of human voice,

outstanding transient response

• Balanced sound in all 5 polar

pattern settings

TLM107 Nickel 416-480 £807.50

TLM107 Black 416-485 £807.50

Studio Condenser Microphones

Neumann U87 Ai

Still the most prestigious and respected mic in any

studio.

Warm sound through large capsule giving smooth and extended bass response. Suited to any

application where quality is of paramount importance. This updated version has an elevated

capsule voltage to provide greater sensitivity and even less self noise. An industry standard for

lead vocalists. 10dB pre-attenuator. Switched bass cut at 30Hz and 200Hz.

The Studio set includes a U87 large diaphragm microphone, a EA87 shockmount and wooden

box. The Stereo set includes 2x U87 large diaphragm microphones, 2x EA87 shockmounts and

an aluminium case.

U87 Ai Nickel 416-040 £1583.33

U87 Ai Black 416-041 £1583.33

U87 Studio Set - Nickel 416-080 £1716.67

U87 Studio Set - Black 416-085 £1716.67

U87 Stereo Set - Nickel 416-090 £3466.67

U87 Stereo Set - Black 416-095 £3466.67

Audix ADX10FL

Miniature Condenser Microphone

Lightweight, low profile and will

provide natural sound with

exceptional transient response.

• Cardioid Polar Pattern

• For use with a standard flute

• Frequency Response 50Hz - 18kHz

• May be used wired or with RAD360

Wireless System

• Modular threaded capsule,

machined brass body with matte

black finish

ADX10FL 432-030 £137.50

NEW

More Products Online...

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:26 Page 5

Studio Condenser Microphones 45

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Audio Technica AT4033 Cardioid

Condenser Microphone

The AT4033 offers low-noise,

symmetrical, transformerless

circuitry.

• Precision-machined, nickel-plated

brass, acoustic element baffle

• 2-micron-thick gold diaphragm

• Floating-construction capsule

assembly

• State-of-the-art surface-mount

electronics

• Custom shock mount

Because of the 4033’s extended low

frequency response we include the

elastic suspension in our pricing.

AT4033A + Shockmount 404-840 £269.17

Stand Mount 450-180 £58.50

Windshield 700-240 £32.50

Audio Technica AT2035 Cardioid

Condenser Microphone

This side-address cardioid

studio condenser mic delivers

exceptional detail and low noise

designed for the home, project,

professional studio.

• Large diaphragm for smooth,

natural sound and low noise

• Switchable 80 Hz high-pass filter

and 10 dB attenuation pad

• Custom shock mount

• Fixed-charge back plate,

permanently polarized condenser

Audio Technica AT2020 Cardioid

Condenser Microphone

The new standard for affordable

side-address studio condensers.

• Ideal for project/home-studio

applications

• High SPL handling and wide

dynamic range

• Custom-engineered low-mass

16mm diaphragm

• Cardioid polar pattern

• Rugged construction for durability

• Includes pivoting, threaded stand

mount

• Bundle includes stand and pop filter

AT2020 447-070 £83.33

AT2020 Bundle 447-072 £88.70

AT2035 447-250 £132.50

Telefunken CU-29

Offers a warm, well-rounded low end

accented by a delicate and intimate 'air'

in the high end.

499-300 £1220.83

ALSO RECOMMENDED

More products online...

Sontronics STC-2

A large-diaphragm cardioid condenser

mic. Ideally suited for recording vocals,

spoken word and acoustic instruments.

325-271 £140.83

Studiospares S2000

The product of a long line of multi pattern condenser mics

which benefits from an extended development

programme.

A multiple pattern studio condenser microphone, the S2000 can easily handle the wide range of

sound levels found in a studio. A dual capsule design with back to back 35mm Gold capsules

operating via a VPM (Voltage Phase Matrix) which maintains a highly predictable polar pattern.

The capsules are pre aged to ensure they maintain their tight tolerances for life not just for a

few months. They are polarized by an elevated voltage which increases the output voltage

which is reflected in the system noise which has reached a new low. Excessive SPLs are

contained by switching in the -10dB attenuator. The front end design is based on a pair of

JFETs which yield the lowest noise platform currently available. They also allow a wide

overload margin allowing the S2000 to function without compromise in any situation within

the recording studio, whether for instruments or vocalists.

Includes an elastic suspension and foam windshield.

Studiospares S2000 Studio Pack

The Studio Pack contains the Studiospares S2000 with a Pop Filter, Microphone Reflection Filter and Microphone Stand.

S2000 449-950 £65.83

S2000 Studio Pack 449-955 £95.83

Studiospares S980 Cardioid

Condenser Microphone

Nothing ever beats the sound of

an Electret Capsule for

capturing percussive sounds.

• Cardioid response with little side and

rear pickup

• Small enough to be unobtrusive.

• Maximum SPL is 148dB

• Frequency response 5kHz to 10kHz

• The response is + 3dB from 50Hz to

19kHz

• Supplied complete with a bag, foam

windshield and a microphone clip

S980 449-670 £24.40

Studiospares S1200 Cardioid • Omni • Hypercardioid

3-Capsule Condenser Microphone

Based on small 19mm diameter

gold sputtered capsules.

• Supplied with 3 capsules: Cardioid,

HyperCardioid and Omni-Directional

• Frequency response Cardioid 22Hz

– 19kHz

• Frequency response Hyper Cardioid

24Hz – 18kHz

• Frequency response Omni 20Hz –

21kHz

• Two Bass Roll Off Filters @ 75Hz

and 150Hz

• Two Attenuation levels -10dB and -

15dB

• Includes a microphone clip and a

foam windshield

• With each capsule being dedicated

to a specific polar pattern, the off

axis response is held within tight

limits

S1200 449-920 £40.83

The diaphragm of a condenser or electret

microphone weighs between 5 and 50 times less

than a dynamic. Therefore the condenser can

respond much quicker to the rapid and minute

changes in air pressure of complex sound waves.

A condenser microphone will practically always

produce a more accurate sound than a dynamic.

WHY

BUY A CONDENSER MICROPHONE?

If you need more information, please contact our

technical sales team, who will be glad to help further.

Sennheiser MK8

The MK 8 offers a great solution for

advanced home recording applications

and project studios alike.

473-940 £465.83

ALSO RECOMMENDED

More products online...

Sennheiser MK4

The MK 4 is a large-diaphragm true

condenser microphone for

professional studio recordings.

455-200 £199.17

Blue Bluebird

Designed for applications ranging from

vocals and guitars to drums and

percussion.

424-550 £249.17

PRICE

DOWN

1000s of products

Available from stock!

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:26 Page 6

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Studio Condenser Microphones

Continued

Rode NT2-A

The NT2-A carries on the tradition forged by the

legendary Rode NT2.

A professional large capsule (1") studio microphone incorporating three-position pick-up patterns,

PAD and high pass filter switches conveniently located on the mic body, the NT2-A is at home on

an incredibly diverse range of sound sources. The frequency and transient response of this

transducer has been voiced to complement today's modern recording techniques, and yet still

evoke the silky smooth character of the legendary microphones of the 50's and 60's. Three 3-

position switches allow selection of cardioid, fig 8 or omni polar patterns. Flat response, 40Hz,

80Hz high-pass filters. - Pad adjustments of 0dB, -5dB or -10dB attenuation. Has a wide

dynamic range and exceptionally low self-noise. Perfect for recording vocals and acoustic

instruments. It has a rugged design and features a high-strength, heat-treated steel mesh head.

With a durable, satin nickel finish.

Its superlative audio characteristics combined with the included SM6 shock mount with integrated

pop filter, 3m (10') XLR cable and dustcover, make the NT2-A one of the most versatile condenser

mics available.

NT2A 417-010 £249.17

NT2A + RED 100 Mic Filter 417-017 £290.83

NT2A + Mic Stand (Without Boom) 417-018 £257.50

NT2A + RED 50 + Mic Stand (Without Boom) 417-019 £282.50

Rode NT5

Suitable for a variety of applications where a flat frequency

response and accuracy are of paramount importance.

The externally biased 1/2” Gold sputtered capsule delivers a smooth on axis frequency response with a

reduced proximity effect. A JFET Impedance converter with a bipolar output provides a self noise as low as

16dbSPL (A weighted) and a dynamic range of 128dB with a maximum SPL of 143dB. The microphone

body is fabricated from a heavy duty cast metal with a satin chrome finish.In comparison to transformer

output stages the NT5’s transformerless output stage drastically reduces low frequency distortion. Typical

anticipated usage will be for drum overheads, acoustic instruments and vocals.

Supplied complete with RM5 stand adaptor, WS5 windshield and carry case.

The NT5 Matched Pair Bundle includes Studiospares mic stand, stereo bar and 2x XLR leads.

NT5 Single microphone 417-180 £140.83

NT5 Matched Pair 417-110 £257.50

NT5 Matched Pair Bundle 417-115 £220.83

Rode M3 Cardioid

Condenser Microphone

Extremely versatile microphone

that is at home in the studio, on

location, or wherever a wide-

response cardioid condenser

microphone is demanded.

• Low-noise wide-response cardioid

condenser microphone

• Battery status LED

• High Pass Filter

• Included windshield and a stand

mount

• Powered via 9V battery or 48V

Phantom

• Bundle includes stand and Pro 5m

lead

M3 417-360 £74.17

M3 Bundle 417-365 £86.67

Rode M5 Matched Pair

Condenser Microphones

Carefully selected to ensure a

variation of no more than 1dB

sensitivity between the mics.

• Half inch Electret cardioid capsule

• Proprietary ceramic coating

provides a sleek matt black finish

• JFET impedance converter with

bipolar output buffer; Maximum

SPL 140dB

• Equivalent Noise Level 19dB-A

• Powering 24 or 48volts

M5 Pair 497-100 £107.50

Behringer C2 Matched Pair

Condenser Microphone

The C-2s utilize a low-mass diaphragm for ultra-wide frequency

response and ultimate sound reproduction and their

inconspicuous size makes them perfect for acoustic instruments,

overhead applications, pianos and similar. The cardioid pickup

pattern effectively eliminates feedback, plus there is switchable

low frequency roll-off and -10dB input attenuation. Ultra low-

noise transformerless FET input eliminates low-frequency

distortion, while a gold-plated 3-pin XLR connector assures the

highest signal integrity. Custom microphone stand adaptors,

windscreens, stereo-bar and transport case are all included.

C2 Pair 381-160 £44.17

Behringer C1

Condenser microphone designed to

capture sounds with incredible realism,

sensitivity and accuracy.

381-170 £36.67

ALSO RECOMMENDED

More products online...

Sennheiser MK4

The MK 4 is a large-diaphragm true

condenser microphone for

professional studio recordings.

455-200 £199.17

Behringer C3

Designed to capture sounds with

incredible realism and accuracy.

Cardioid polar pattern.

381-150 £51.67

Behringer C4

These outstanding condenser mics are

especially great for live applications.

Sold as matched pair.

381-840 £44.17

AKG P220

Offers a warm and clear sound for lead

vocals, acoustic guitar and brass

instruments.

469-460 £124.17

AKG P420

An ideal tool for stereo miking

techniques and ambient recording.

One-inch dual-diaphragm microphone.

469-470 £174.17

Quantity Discounts Apply

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:26 Page 7

Studio Condenser Microphones 47

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

Rode NT1A

Very popular in school and college recording studios, the

NT1A is a quality condenser mic that will take your

recordings to a new level.

The design brief when developing the NT1 was to produce a microphone with the same sonic

clarity as the NT2. Rode have accomplished this task with very little compromise; the same open

warm sound produced by the NT2 is present with the NT1. An internal shock mount assembly

holds the transducer which features a large 1” gold sputtered Milar diaphragm as used in the

more expensive NT2. Two layers of high grade stainless steel have been used in the Head. The

first is a strong open weave and the second is a fine weave providing excellent Pop screening.

Transformerless FET circuitry generates very low self-noise, whilst the body of the microphone is

precision machined and finished in a durable coating.

The NT1A Recording Pack now includes a studio grade pop shield and shock mount, a 20’

mic cable, dust cover and an instructional DVD with recording tips.

Rode NT1A + RED 100/RED 50

The Rode NT1A mics are famed for their flat frequency response and incredible accuracy. Combine

this with the hugely popular RED 100 and RED 50 microphone filters, and the quality of any vocal

recording will be simply exceptional. Save more than 15% when getting these great products together!

Rode NT1A Recording Pack 417-005 £140.83

Rode NT1A Matched Pair 417-250 £349.17

BEST

SELLER

NT1A + RED 100 Mic Filter 417-007 £190.83

NT1A + RED 50 + Mic Stand (Without Boom) 417-009 £174.17

NT1A + Mic Stand (Without Boom) 417-008 £149.17

AKG C1000S MKIV

Classic condenser mic found in practically every studio!

This updated version includes a PB1000 Presence Boost Adaptor which adds a presence boost

to frequencies between 5kHz and 9kHz to provide a more “brilliant” sound. This gentle boost adds

clarity and enables a vocalist to “cut through the mix”. A PPC1000 adaptor changes the polar

pattern to hypercardioid. The overall frequency response is from 30Hz-19kHz. The C1000S is

designed as a versatile instrument microphone for any recording studio. Better separation for close

miked drum kits is obtained by fitting the PPC1000 polar pattern adaptor over the capsule to make

it’s pick up hypercardioid. That configuration is particularly relevant in reducing feedback problems

with the PA where the acoustics are lively. Powering by internal 9 volt battery or phantom powered

from the mixer (9V-52V).

Supplied with W1000 External Windshield, SA43 Mic Holder and PPC 1000 hypercardioid

adaptor and PB1000 Presence Booster.

AKG C1000S MKIV Pack

The pack contains an AKG C1000S MKIV mic, a Studiospares Mic Stand, a 5m Neutrik XLR

Lead and a Studiospares Steel Mesh Popkiller.

C1000S MKIV 469-230 £73.33

C1000S MKIV + 5m XLR Lead 469-231 £77.50

C1000S MKIV Pack 469-235 £95.83

AKG C414 XLS

Condenser Microphone

Especially designed for

recording of solo vocals and

solo instruments.

• Cardioid pick up pattern

• A classic mic with a distinctive

timbre

• High sound pressure level capability

• Immune to electro-magnetic

interference

• Three switchable bass cut filters

• Three pre-attenuation pads

• Flat frequency response

• XLII version and matched pair

available online

C414 XLS 409-841 £690.83

AKG C214

Condenser Microphone

Features AKG’s legendary 1”

edge-terminated large

diaphragm sound.

• Outstanding dynamic range (up to

156 dB SPL, ultra-low noise)

• Integrated suspension to reduce

mechanical noise

• Switchable 20 dB attenuation pad

and low cut switch

• Shock mount carrying case

included

C214 439-800 £262.50

C214 Stereo Pair 439-920 £557.50

AKG C314

Dual Diaphragm Condenser Microphone

The latest sibling from one of

the industry’s most widely used

studio and stage microphone

families.

• Professional multi-pattern

condenser microphone

• Four selectable polar patterns

• Lowest self noise

• Overload detection LED

• Computer-matched diaphragms

• Integrated capsule suspension

• 20 dB attenuation pad and bass-

cut filter

C314 469-510 £499.17

C314 Stereo Set 469-515 £982.50

AKG C314 Stereo Set

With the AKG C314 Matched Stereo Pair you're well-equipped for

drum overheads, vocal ensembles, room miking and other stereo

recording applications. The C314 Stereo Set Includes metal case,

stereo mic bar, shockmounts, stand adapters and windscreens.

ALSO RECOMMENDED

More products online...

AKG C451B

An excellent tool for accurately

capturing signals rich in transients

such as drums and percussion.

419-790 £232.50

PRICE

DOWN

Delivery before noon...

No problem!

Delivery before 10am...

No problem!

Saturday delivery...

No problem!

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:26 Page 8

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Studio Condenser + Valve Microphones

Studio Condenser Microphones

Continued

Studiospares S1105

Easily the best large capsule microphone around!

The Studiospares S1105 microphone is an impressive alternative to more expensive large

diaphragm condenser microphones. The full range frequency response enables this microphone

to be faithful to many instruments. Large Diaphragm Microphones are extremely versatile and allow

them to work with many different instruments, voices and recording equipment. The high sensitivity

makes this microphone a great place to start for small home recordings, but is not well suited for

live sound. It comes complete with carry case, and an elastic suspension.

The S1105 includes two polar patterns and two frequency response options. While the cardioid

polar pattern is great for reducing room reverberation, Omni-directional does the opposite and

helps create spaciousness that is desired for some recordings, such as drum overheads.

The flat frequency response provides a well-balanced response that is ideal for most

recordings, but the high pass filter can attenuate the low frequencies to maintain that

balance when the microphone is close to the sound source.

Specification:

1” diameter dual Gold sputtered capsule, Sensitivity -41dB + 2dB

Pickup pattern Cardioid and Omni, Frequency range 20Hz - 20kHz

Maximum SPL @1kHz 125dB @ 0.5% distortion Signal/noise ratio 76dB

Equivalent Noise ≤20dB (A weighted) Powering 48V phantom power

Studiospares S1005

Retains all the features of the S1105 but without the omni directional characteristic. When quality is taken into account, no other

microphone represents such incredible value. Accessories: Elastic suspension and carrying case.

Studiospares S1105/S1005 Packs

Pack 1 Contains

•Studiospares S1105 or S1005 microphone

•Studiospares Mic Stand

• 5m XLR Lead

•Studiospares Stonewall Dual Blast Filter

Pack 2 Contains

•Studiospares S1105 or S1005 microphone

•Studiospares Mic Stand (without boom)

• 5m XLR Lead

•Studiospares RED 50 Microphone Sound Filter

S1105 449-570 £57.50

S1005 449-560 £41.66

Foam Windshield 448-590 £4.90

Spare Rubber Band 711-573 £1.95

S1105 Pack 1 449-571 £65.83

S1005 Pack 1 449-561 £48.33

S1105 Pack 2 449-572 £82.50

S1005 Pack 2 449-562 £65.83

Paypal

Worried about using your credit card

online? We now accept Paypal for online

payment! Visit www.studiospares.com

for more information.

Rode NT1 KIT

The NT1 Kit comprises of a black NT1,

a SMR Shock Mount and a Pop

Screen.

497-090 £215.83

ALSO RECOMMENDED

More products online...

Shure Beta 87C

This vocal mic has an extremely

smooth, tailored response for a warm,

natural sound.

443-640 £240.83

Shure PGA27

A large diaphragm side-address

condenser mic with a cardioid pickup

pattern.

443-460 £149.17

Shure PGA181

Ideal for capturing clear sound of

guitar amps, acoustic instruments,

vocals and percussion.

443-530 £90.83

sE 2200A II

The SE2200 series remains their best

selling microphone for the last 10 years.

Multi Pattern Condenser microphone.

422-390 £190.83

Shure KSM32

The Shure KSM32 Condenser Mic has

an extended frequency response for

incredibly natural sound.

423-240 £424.17

Valve Microphones

Rode K2 Cardioid • Omni • Figure of 8

Valve Multi Directional Microphone

The RØDE K2 is the result of

designing and building 1000's of

valve microphones.

• Large capsule with gold sputtered

diaphragm and internal shock

mounting

• Ultra low noise

• Wide dynamic range

• Class 'A' valve circuitry

• Hand-selected and graded 6922

twin-triode valve

• Dedicated power supply

K2 417-130 £515.83

1000s of products

Available from stock!

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:26 Page 9

USB + Ribbon Microphones 49

TELEPHONE |020 8208 9930 FAX |020 8450 4390 ALL PRICES EXCLUSIVE OF VAT.

USB Microphones

Studiospares UX500

The UX500 bridges the traditional studio microphone to

digital technology by providing an outstanding studio

microphone with a digital USB output.

25mm Electret condenser capsule provides a high output to reduce system noise. Bass roll off filter at

150Hz to attenuate sub sonic frequencies. Attenuation Pad -10dB increases maximum SPL.

Frequency response 20Hz – 20kHz. Sensitivity -35dB + 2dB. Noise < 22dB weighted. Maximum SPL

130dB. MAC and PC compatible. Cutting edge A-D converters. Powering via USB connection. This

product equals and beats products costing treble. Includes a Elastic Shockmount and USB lead.

The Studiospares UX500 Table Stand Pack contains our high quality UX500 USB Condenser

Microphone bundled with a table stand, a shockmount, protective pouch and USB cable.

The Studiospares UX500/M1000 Recording Pack contains the UX500 USB Condenser

Microphone bundled with a our M1000 Monitor headphones and the Studiospares Microphone Stand

with boom, one of our best ever selling products.

UX500 449-960 £40.83

UX500 Table Stand Pack 449-965 £49.17

UX500/M1000 Recording Pack 449-969 £80.83

Studiospares UX100

A dynamic handheld microphone that features an XLR,

headphone and a USB I/O.

The UX100 can plug directly into any sound console or any USB input. The microphone’s on/off switch lets

you control the audio into the XLR output, allowing you to perform in live settings and record to a computer

simultaneously. This microphone also features a built in 3.5mm stereo headphone jack with a volume control

for low latency monitoring during recording. Built with a cardioid pickup pattern and a high quality A/D

converter, the UX100 has a 16-bit 44.1/48kHz sampling rate ensuring the sound reproduction in both live and

recording applications is clear, detailed and accurate. It is also compatible with any computer based digital

workstation. Supplied with USB cable, microphone holder and mini desk stand.

UX100 449-270 £24.99

UX100 + Mic Stand 449-275 £32.50

Samson UB1

USB Boundary Microphone Omni

The Samson UB1 is a miniature, low-profile surface mount

condenser microphone featuring an omni directional pick-up

pattern and USB output. Since the UB1 is a class compliant

USB device, it is plug and play compatible with Macs and PC’s.

It ships with Cakewalk’s Sonar LE, and comes with a 2m USB

cable and a durable storage case. The mic is ideal for placing

on a conference table, podium, or altar and can also be

mounted using its keyhole mounting points. Recording at 16-

bit, 44.1kHz – 48 kHz, it has a solid zinc body, Black finish and

sturdy steel grille.

UB1 388-480 £66.66

Rode NT-USB

Fully compatible with all mainstream

recording applications on both

Windows and Mac OS.

497-310 £132.50

ALSO RECOMMENDED

More products online...

Behringer C1U

An affordable and ideal choice for

vocals, piano, guitar, amp-cabinets

and more.

382-130 £44.17

Studiospares SB450USB

USB Boundary Microphone

A highly sensitive USB Boundary

Electret Microphone with a

multitude of applications.

• USB output for Mac/PC

• Highly sensitive back Electret

capsule captures sounds from all

directions

• Subsonic filter to remove

troublesome frequencies that exist

close to walls and floors

• Probably the best boundary mic

around

• Supplied with 3m of cable

SB450USB 449-690 £26.66

Ribbon Microphones

sE X1R

Ribbon Microphone

A classic sounding ribbon mic

with a gentle HF lift

• For anything acoustic like jazz,

classical, string parts, drum

overheads or folk

• Hugely powerful Neodymium

magnets raise the output level

• Aluminium ribbon element

• Frequency Response 20Hz – 16kHz

+ 1dB

• Sensitivity -55dB ref 1V/Pa + 1dB

• Directional pattern Fig of 8

• Max SPL 135dB

X1R 422-470 £124.99

Studiospares S300

Active Ribbon Microphone

Delivers a warm and natural

classic sound. The rich low end

response is balanced by the

transparent mid/high frequency

output

• Pre Aged aluminium ribbon for

stability

• Ribbon assembly user replaceable

with out having to re calibrate

• Very low noise front end FETs

coupled with an impedance

matching trans-former toboost the

output

• Max SPL150dB @ 1KHz

• Frequence response 20Hz - 18kHz

• Signal/Noise ratio 69dB @ 1 Pa

• Includes a bag, foam windscreen

and elasticated mic holder.

• Compares favourably with

products costing treble

S300 Ribbon Microphone 449-680 £63.83

Spare Ribbon Assembly 449-689 £26.00

Price Match

Studiospares will BEAT any

genuine price from any UK

competitor on any item or

order. Call or email us for

more details.

More Products Online...

2017 CAT PAGES 40-49:Layout 1 13/12/2016 11:26 Page 10

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Ribbon + Smartphone/Tablet + Instrument Microphones

Ribbon Microphones

Continued

Beyerdynamic M160

Ribbon Microphone

Beyerdynamic M160 is a classic

ribbon microphone, sporting a

dynamic double ribbon element.

• Unique double ribbon microphone

transducer

• Hypercardioid polar pattern

• Extended frequency response

• Excellent transparency and

transient response

• Compact and rugged design

• Warm and natural sound

• Noise attenuation of 25 dB at 110-

degrees

• Ideal for stereo recordings in MS

technique

M160 700-977 £325.00

Marantz MPM-3500R

Ribbon Microphone

Faithfully captures every sound

from the subtle nuances of

stringed instruments to rock

vocals and percussion

• Low-mass ribbon diaphragm

• Polar Pattern: Dipole (Figure-of-8)

• Frequency Response: 20–20kHz

±3dB

• Low-frequency attenuation switch

• Sensitivity: -34dB ±2dB

• Output Impedance: 200Ω

• Max SPL: 135dB

• S/N Ratio: 79dB

• Phantom Power: 48VDC

• Integrated pop filter and shock

mount

MPM-3500R 272-480 £165.83

NEW

Smartphone/Tablet Microphones

IK iRig Voice

iOS Android Handheld Mic

Turn your smartphone or tablet

into the ultimate portable vocal

studio and monster karaoke rig.

• Compact cardioid pattern minimizes

feedback

• Constructed of durable, lightweight

thermoplastic

• Works with dozens of karaoke,

sing-along and music making apps

• Headphone jack for real-time

monitoring

• Convenient on/off switch located on

the mic

• Operates through the 3.5mm (1/8”)

TRRS analogue mic/headphone jack

iRig Voice Blue 321-750 £32.50

iRig Voice Green 321-751 £32.50

iRig Voice Pink 321-752 £32.50

iRig Voice White 321-753 £32.50

iRig Voice Yellow 321-754 £32.50

IK iRig Mic HD

Digital Handheld iOS Microphone

Connects to an iPhone, iPad,

iMac and MacBook Pro

• 24-bit audiophile-grade A/D

converter, a 44.1/96 kHz

• Low noise/high definition pre-amp

• Sturdy metal-body construction

• Can also be mounted on a standard

mic stand with the clip

• Lighting connector and USB cable

included

• 30-pin cable available separately

iRig Mic HD 321-760 £95.83

Shure MOTIV MV88

Directly connects to any Apple iPhone,

iPod or iPad equipped with a

Lightning® connector.

443-870 £120.83

ALSO RECOMMENDED

More products online...

Shure MOTIV MVi

Delivering the convenience of a

professional sound studio on the go. 5

DSP Preset Modes.

443-900 £99.17

Shure MOTIV MV51

Specifically engineered for high-quality

digital audio capture. 5 DSP Preset

Modes.

443-880 £165.83

Shure MOTIV MV5

Engineered for quick and easy

portable use. 3 DSP Preset Modes

(Vocals, Flat, Instrument)

443-890 £90.83

Sennheiser MKE 2 Digital

The MKE 2 digital is a professional

solution for mobile recording. Includes

Apple MFi Certified Lightning connector

473-930 £332.50

Sennheiser Clip Mic Digital

The ClipMic digital delivers

professional-level recordings when on

the go.

473-920 £124.17

IK Multimedia iRig Mic Studio

Digital Condenser Microphone

Make professional studio-quality

recordings on the go.

• Professional studio microphone

with large-diaphragm capsule

• Ultra-compact size

• High-quality 1” back electret

condenser capsule

• 24-bit converter with 44.1/48Khz

sampling rate

• Low-noise, high-definition preamp

Integrated headphone output

• Multicolor LED status and level

indicator

• Onboard gain control and

headphone level control

• Includes portable tripod tabletop

stand and Lightning, Micro-USB

OTG and USB cables

iRig Mic Studio Black 321-910 £140.83

iRig Mic Studio Silver 321-915 £140.83

NEW

Studiospares iM100

Smartphone Mini Condenser Microphone

Miniature Smartphone

Microphone with Cardioid

Pickup Pattern to increase

directionality.

• 12mm Back Electret Condenser

Microphone.

• Cardioid pickup pattern rejects

unwanted sounds.

• Frequency response 20Hz - 20kHz.

• Sensitivity -45dB +/- 2dB.

• Dimensions 12mm x 70mm

(excuding plug)

• Enhances iPhone sound quality

making it a serious recording tool.

iM100 449-930 £12.42

Instrument Microphones

Beyer M201 Hypercardioid

Instrument Microphone

Classic dynamic, 'workhorse' microphone for vocal or

instrumental applications.

• Rugged construction with high output moving coil transducer

• Small dimensions for unobtrusive positioning and includes clamp

and pouch

• Frequency response of 40Hz-18kHz and hyper-cardioid polar

pattern

M201 410-121 £147.50

Shure Beta 52A

Bass Drum Microphone

Designed specifically for kick

drums and other bass

instruments.

• Built–in dynamic locking stand

adapter with integral XLR connector

• Hardened steel mesh grille that

resists wear and abuse

• Advanced pneumatic shock mount

system

• Neodymium magnet for high

signal–to–noise ratio output

Beta 52A 423-910 £144.17

Delivery before noon...

No problem!

Saturday delivery...

No problem!

2017 CAT PAGES 50-59:Layout 1 13/12/2016 12:16 Page 1

Instrument Microphones 51

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Shure SM57 LC

A well established industry standard for over 45 years!

Sturdy construction and good all round performance with the well known Shure mid-range presence

peak to increase intelligibility and clarity under difficult conditions. Favoured by female backing groups

and for miking up guitars, snare drums, kick drums and wind instruments.

The frequency response is 40Hz - 15kHz. The small physical size makes it inconspicuous for

television, stage and theatre work.

Supplied with Mic Holder with 5/8” Thread. Use STA4 thread adaptor Code 401-100 for 3/8”

stands.

Shure SM57 Packs

SM57 LC 423-031 £82.50

SM57 LC 3-Pack 423-033 £232.50

SM57 + Economy 5m XLR Lead 423-034 £83.33

SM57 + Economy 10m XLR Lead 423-035 £85.00

SM57 + Pro 5m XLR Lead 423-036 £89.17

SM57 + Pro 10m XLR Lead 423-037 £93.33

SM57 + Pro 5m XLR Lead + Short Boom Stand 423-038 £93.33

SM57 + Pro 10m XLR Lead + Short Boom Stand 423-039 £97.50

Pro XLR leads are

handmade in our London

workshop using Sommer

cable and Neutrik XLRs.

Studiospares S980

Nothing ever beats the sound of an Electret Capsule for capturing

percussive sounds.

The smaller and hence the lighter the diaphragm the better. Inspired by the legendary AKG 451 the S980

captures the sizzle of the cymbal and crack of the tom tom. Thankfully the sound is not chromium plated or

metallic. Conventional dynamic microphones sound as if you are listening through a door in comparison. The

frequency response reveals why the sound is so smooth. It is ruler flat right through the ‘difficult’ 5kHz to 10kHz

region where others exhibit ‘presence peaks’. The response is + 3dB from 50Hz to 19kHz and the maximum

SPL is 148dB. The equivalent Noise Level is 18dB-A (IEC 268-4) A weighted. The low noise platform is

attributed to the front end bi polar FETs.

Supplied complete with a bag, foam windshield and a microphone clip.

S980 449-670 £24.40

Studiospares S150

Part of the new generation of back electret microphones

for very close miking.

Part of a new generation of miniature back electret microphones designed to be secured to the

instrument, the ultimate in close miking. The frequency response is 50Hz - 18kHz so can capture the

slightest nuance. Maximum SPL is 130dB so it is able to llive comfortably in front of practically any

instrument. Gooseneck length 105mm. Phantom powered 48 volts. An excellent all rounder that is

capable of being mounted right at the source of the sound.

Sold in huge quantities, hence the highly competitive pricing.

S150 449-180 £33.25

Shure PGA57

Cardioid Instrument Microphone

Picks up great sound and

prevents any unwanted noise or

background noise.

• Compact and robust

• Ideal microphone to record both

snare drums and guitar tones.

• Tailored microphone cartridge

design

• Stand adapter for mounting to a

microphone stand

PGA98D 443-520 £99.17

PGA57 443-490 £51.67

PGA81 443-510 £108.33

PGA52 443-470 £104.17

PGA56 443-480 £62.50

PGA98H 443-525 £99.17

Shure PGA98D

Cardioid Condenser Microphone

Designed to clip safely on to

either a snare drum, tom, or

other percussion instruments

you want to record.

• Tailored microphone cartridge

design

• Flexible gooseneck design

• Molded one-piece drum mount

• Integrated preamplifier

Shure PGA81

Instrument Microphone

A professional instrument

microphone at an affordable

price.

• Prevents any unwanted noise and

background sounds

• Flat-response mic cartridge design

• Stand adapter for mounting to a

microphone stand

Shure PGA52

Drum Microphone

A professional dynamic

microphone ideal for capturing a

clear Kick Drum sound.

• Heavy-duty drum microphone

• Tailored microphone cartridge

design for low frequency clarity

• Swivel joint with quick release latch

with a design similar to bicycle

component-locking technology

Shure PGA56

Drum Microphone

A robust, dynamic microphone

design to capture the clearest of

drum sounds.

• Ideal for toms and snare

• Tailored microphone cartridge

design

• Swivel joint with quick release latch

• Updated industrial design with

black metallic finish

• Drum mount included for quick

attachment to drum rims

Shure PGA98H-TQG

Instrument Microphone

Can be used to capture audio in

various environments for

applications such as live stage,

theatre, studios, and more.

• Black metallic finish and grill

• Flexible gooseneck design

• Integrated horn clamp for quick and

easy mounting

2017 CAT PAGES 50-59:Layout 1 13/12/2016 12:16 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Instrument Microphones

Continued

AKG D112 MkII

Features a new integrated flexible mount,

while retaining all the sonic strengths that

have made its predecessor the industry-

standard.

The D112 MkII can handle more than 160 dB SPL without distortion. Its

large diaphragm has a very low resonance frequency that delivers a solid

and powerful response below 100 Hz. Its authoritative low end is

complemented by a narrow-band presence boost at 4 kHz that

punches through even dense mixes and loud stage volumes with forceful

impact. One of the many reasons artists and sound engineers love the D112

MkII is that it requires no additional EQ to sound just right as soon as you

bring up the fader. Further refining its performance, the D112 MkII features an

integrated hum-compensation coil that keeps noise to an absolute minimum.

In addition to being an exceptional bass drum mic on stage and in the

studio, the D112 MkII is an excellent choice for miking electric bass

cabinets and trombones.

D112 MkII 469-520 £99.17

D112 MkII + Stand + 10m Lead 469-522 £110.83

D112 MkII + Stand + 10m Pro Neutrik Lead 469-524 £115.00

Studiospares SD101

Studiospares most popular bass drum mic,

also great for double basses.

The low frequency response just keeps going on and on down to subsonic

frequencies. This type of response certainly livens up percussive sounds giving

a real zing to very high transients. Bass drums are really brought to life. The body is die

cast zinc not plastic so is able to provide effective screening against RF interference.

Studiospares SD107

Very sensitive bass drum microphone,

providing high outputs.

The maximum SPL level is 136dB so it can be placed inside a bass drum.

The response is tailored by the dynamics of the capsule being slightly enhanced

below 200Hz. Nothing added, nothing taken away. Pure bass drum sound. The body

is die cast zinc, not plastic which takes knocks and provides a high level of screening

from unwanted interference. A hardened steel mesh protects against knocks.

Studiospares S935

Equally at home covering woodwind or brass

sections.

Great value Instrument microphone designed to capture excellent recordings on a range

of sources. Excels at close mic applications. Very high output capability. Smooth frequency

response of between 30Hz and 15kHz. Popular guitar microphone captures every nuance. Max

SPL 136dB.

SD101 448-660 £24.40

SD107 449-600 £24.50

S935 449-580 £19.99

PRICE

DOWN

Shure KSM137

Cardioid Instrument Microphone

Equally at home in the studio or

in live applications.

• Highly consistent cardioid polar

pattern

• Ultra-thin, 2.5 micron, 24 karat

gold-layered, low mass Mylar®

diaphragm

• Class A, discrete, transformerless

preamplifier for fast transient

response

• Gold-plated internal and external

connectors

• Premium electronic components

• Stereo matched pair available

KSM137 423-390 £307.50

KSM137 Stereo Pair 423-395 £624.17

Shure KSM141

End-address condenser microphone

with mechanically switching dual polar

patterns.

423-380 £407.50

ALSO RECOMMENDED

More products online...

Audix i5 Cardioid

A dynamic instrument microphone

used for stage, studio and broadcast

applications.

422-500 £74.17

Sennheiser MD421 Cardioid

Extremely versatile, robust legendary

cardioid microphone. Copes with the

most diverse recording conditions.

452-111 £265.83

AKG P170

For recording of overheads,

percussions, acoustic guitars and other

strings.

469-450 £70.83

Audio Technica AE2300

Instrument Microphone

Able to capture sound from

guitar amps, brass and

woodwinds, drums and

percussion instruments with

equal clarity and precision.

• Cardioid polar pattern

• Excels in high-SPL applications

• Minimal off-axis coloration

• Switchable low-pass filter

• Low-profile design

• Rugged, brass metal construction

• Frequency response 60 – 20,000Hz

AE2300 481-140 £183.33

NEW

More Products Online...

2017 CAT PAGES 50-59:Layout 1 13/12/2016 12:16 Page 3

Instrument Microphones + Drum Microphone Kits 53

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Studiospares S975

The S975 gets really close to the action. For any

percussive application, this model is difficult to

beat whatever the price.

The pre-polarised electret capsule has a tiny diaphragm so is able to capture the

harmonics associated with percussion instruments. The upper frequency limit is

beyond the range of audio measuring equipment. This microphone has little response

from other local instruments due to the tight pickup pattern. It simply clips onto the

body, bell or rim etc of any instrument. The gooseneck allows precise placement of

the capsule. Living next to a snare drum or being clipped to the bell of a saxophone

makes great demands on the overload factor.

The S975 is Phantom powered 49 volts with an SPL of 130dB.

Sennheiser e604

This space saving, compact drum and

brass microphone is ideal for low visibility,

close miking techniques.

The frequency response and pick-up pattern are optimised for drum sets and

percussion instruments. The e604 also excels on brass and woodwind. An integral

stand mount screws directly onto mic stands. The included clip attaches the mic directly

to the rim of the drum. It is able to reproduce levels in excess of 160dB. The lightweight

voice coil provides extended high frequencies and rapid transient response. The

response extends from 40Hz to 18kHz. The tough reinforced glass fibre body takes the

knocks and shocks and suppresses impact noise.

Supplied complete with pouch and mic clip.

S975 449-590 £29.99

e604 452-870 £82.50

e604 3-Pack 452-873 £224.17

Sennheiser e609/e906 Supercardioid

Instrument Microphone

Specially developed for miking

guitar cabs face on and extremely

close to the signal source.

• Rugged metal body

• Advanced shock-mount design

• Super-cardioid pick-up pattern

• Hum compensating coil

• e906 is the same as the e609,

but with a 2 way switchable EQ

e609 473-590 £82.50

e906 454-460 £115.83

Sennheiser e904

Dynamic Percussion Microphone

The cardioid e904 provides great

sound without getting in the way

in even the most crowded set-

ups.

• Specifically designed for drum

applications

• Very short body

• Integrated stand mount and rim clip

e904 454-440 £107.50

Audio Technica ATM230

Hypercardioid Instrument Microphone

Ideally suited for miking toms,

snare and other percussion

instruments.

• Hypercardioid polar pattern

• Handles very high SPL at close

range

• Low-profile design

• Rugged, all-metal construction

• Frequency response 30-12,000 Hz

• Includes AT8665 drum mount and a

protective pouch

ATM230 481-150 £90.83

ATM230 3-Pack 481-153 £249.17

NEW

Drum Microphone Kits

Shure PGA Drumkit6

Extended Drum Microphone Pack

A complete package of

professional quality

microphones.

• Designed to provide excellent

sound for full drum kit performance

and recording

• 1 x PGA52 kick drum microphone

• 2 x PGA56 drum microphones

• 1 x PGA57 instrument microphone

• 2 x PGA81 instrument microphones

• 2 x Drum mounts

• 6 x XLR-XLR cables

• 1 x carrying case

PGA Drumkit6 443-550 £374.17

AKG Drum Set Session I

Extended Drum Microphone Pack

The ideal all-in-one starter kit

that delivers an impressive

combination of performance and

value.

• All microphones are from the

Perception Live series and feature a

durable metal casing, rugged spring

steel microphone grill, scratch-

resistant finish and high maximum

SPL capabilities

• 1 x P2 bass drum microphone

• 2 x P17 for overheads

• 4 x P4 for toms and snare

Drum Set Session I 469-540 £232.50

Drum Mic kits offer huge cost savings. They are

grouped by application so all models will be

appropriate to the task in hand. And best of all, you

can see which microphones have been left behind.

WHY

BUY A DRUM MICROPHONE KIT?

If you need more information, please contact our

technical sales team, who will be glad to help further.

Shure PGA Drumkit4

Essential Drum Microphone Pack

Helps you to choose a perfect,

affordable selection of

microphones for your drum-kit.

• Perfect for live usage or in the

recording studio

• 1 x PGA52 Cardioid Dynamic Kick

Drum Microphone

• 2 x PGA56 Cardioid Dynamic

Snare/Tom Microphones

• 1 x PGA57 Cardioid Instrument

Microphones

• 1 x A25D Break-resistant

Microphone Clip

• 2 x AP56DM Break-resistant Drum

Rim Mounts

• 4 x XLR-XLR cables 4.6m

• Comes in a zippered carrying case

PGA Drumkit4 443-540 £224.17

Trade Counter

Visit our trade counter!

You’ll get friendly advice

and immediate access to

8000+ product lines. Free

Parking also for 40 cars!

2017 CAT PAGES 50-59:Layout 1 13/12/2016 12:16 Page 4

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Drum Microphone Kits + Vocalist Microphones - Condenser

Drum Microphone Kits

Continued

Studiospares SD705/SD805

A carefully selected group of microphones, each the finest for their particular

application.

Two self contained kits each designed for slightly different microphone techniques. Housed in a carry case with cutouts to ensure the kit

is complete when clearing up after a session.

SD705

Contains

• 1x SD106 Bass Drum Microphone

• 2x S935 Instrument Microphones

• 2x S985 Overhead Percussion Microphones

• 3x Mic clips, 2x Overhead mic clips, 2x Overhead foam

windshields.

SD805

Contains

• 1x SD106 Bass Drum Microphone

• 4x S935 Instrument Microphones

• 2x S985 Overhead Percussion Microphones

• 5x Mic clips, 2x Overhead mic clips, 2x Overhead foam

windshields.

SD705

SD805

SD705 449-650 £65.83

SD805 449-660 £82.50

Samson DK707

Drum Microphone Set

Designed to provide excellent

sound for close-mic

performance and recording

environments.

• 7-piece drum mic kit

• One Q71 Kick Drum Microphone

with swivel-style mic adapter

• Four Q72 Instrument Microphone

with swivel-style mic adapters and

tension-mounted rim clips

• Two C02 Pencil Condenser

• Microphones with shock-mounted

swivel-style mic adapters

• Includes hardshell carry case

DK707 368-950 £190.83

NEW

Samson DK705

Drum Microphone Set

Ideal for drum set and high-

volume source records.

• 5-piece drum mic kit

• One Q71 Kick Drum Microphone

with swivel-style mic adapter

• Four Q72 Instrument Microphones

with swivel-style mic adapters and

tension-mounted rim clips

• Includes hardshell carry case

DK705 368-960 £132.50

NEW

Electro-Voice ND68

Dynamic Supercardioid Bass Drum Microphone

A robust, high-performance,

large-diaphragm dynamic

supercardioid kick drum and

low-frequency instrument

microphone.

• Excellent acoustic isolation

• Large-diaphragm dynamic capsule

• Extremely high SPL handling

capability - 144 dB SPL

• Humbucking coil guards against line

hum

• Memraflex grille resists denting

ND68 414-070 £137.50

NEW

DPA d:vote

4-mic Rock Touring Kit

Offers a wide selection of

condenser microphones and

accessories selected for typical

use in a live rock music setting.

• 4x 4099 Instrument Microphone in

Pouch

• 4x Microdot extension cable 1.8m

• 4x Clip for drum

• 4x Clip for sax and trumpet

• 2x Clip for universal use

• 1x VO4 Peli™ Case

d:vote 416-930 £1300.00

NEW

AKG Drum Set Concert 1

Drum Microphone Kit

Provides a complete collection

of mics designed to withstand

even the toughest stage

environments.

• Including five dynamic and two

condenser overhead microphones

for an array of applications

• Microphones optimally tuned

• Includes all microphone clamps and

stand adapters

• Roadworthy, rugged aluminum

carrying case

Concert 1 469-640 £624.17

NEW

Audix FP7

1x F5 dynamic, 3x F2 dynamics, 1x F6

dynamic, 2x F9 condensers, 6x D

Clips, 1x MC1 clip, 1x Aluminum

carrying case with foam inserts.

422-950 £324.17

ALSO RECOMMENDED

More products online...

Telefunken DD4

1x M82 (for kick drums), 1x M80-SHB

(for snare), 2x M81-SH (for toms), 4x

5m XLR with right angle female

connector and 1x Flight Case.

499-390 £1258.33

Vocalist Microphones - Condenser

2017 CAT PAGES 50-59:Layout 1 20/12/2016 16:30 Page 5

Female Vocalist

Microphone

An attractive, great

sounding microphone

designed to

complement the

female voice.

To capture the natural nuances of the

female voice a prepolarised electret

capsule was selected. Moisture from

the breath can cause havoc with earlier externally polarised

condenser capsules and the ruler flat response, particularly

at mid and high frequencies is essential for a natural sound.

Only 19mm diameter and 108mm long. Frequency response

20Hz – 20kHz. Cardioid pickup pattern. Maximum SPL

135dB.

Includes a stand clamp and pouch.

Female Vocalist Mic 449-940 £32.50

Mic + Gold Pop Filter 449-945 £37.50

Vocalist Microphones - Condenser + Dynamic 55

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Studiospares S955 Hypercardioid

Vocalist Condenser Mic

The Electret capsule easily

responds to the intimate

presence and every nuance of

the human voice.

• No sibilance or edgy sounds

• Great for solo vocalists or

groups/choirs

• Doubles as a high quality

instrument mic

• 19mm Gold Electret Capsule

• Effective double Pop Blast filtering

• Filter easily cleaned and refreshed

• Response 20Hz - 20kHz

• Maximum SPL 134dB

• Phantom powered

• Includes a microphone stand clip

S955 449-620 £24.99

AKG C7

Condenser Vocal Microphone

Delivers premium studio-quality

condenser sound and hassle-

free operation on any stage.

• Custom-tuned supercardioid

condenser capsule

• Open-space capsule design

• Mechano-pneumatic shock

absorber suspension

• Multi-layer pop noise protection

• Patented ultralight 24-karat gold

AKG capsule technology

• Supercardioid Polar Patterns

C7 469-680 £65.83

NEW

Rode iXY Lightning

The ultimate recording microphone for

iPhone and iPad. Record stereo audio

at 24-bit, 96kHz.

497-280 £132.50

ALSO RECOMMENDED

More products online...

Electro Voice RE410

Optimised to capture the human voice

in professional club and concert sound

as well as studio recording.

414-020 £124.17

JTS Carbon Microboom

Designed to be used on stage but not

seen. 3 alternative tiny electret capsules.

1450mm boom.

437-990 £162.50

Electro-Voice RE510

Offers the warmth of a larger capsule

design without sacrificing off-axis

performance or transient response.

414-030 £125.00

Vocalist Microphones - Dynamic

Studiospares S940

As a vocal microphone this model compares favourably

with models costing five times more.

The neodymium magnet assembly is coupled to a very lightweight diaphragm that easily

responds to transients and provides an output capable of pushing any system noise well out of

earshot. The capsule captures the nuances of male and female vocalists alike. Musically the

output is faithful and will capture stringed and brass instruments with an uncanny accuracy. The

transparency also retains the pureness of reed and woodwind instruments. The capsule in the

S940 sounds particularly sweet and has been described as a ‘smoothie’. Male vocalists will be

pleased to hear that low frequencies will be enhanced when used close up. The diaphragm is

protected from the excesses of the outside world by a stainless steel mesh and an internal foam

windshield. The body is not plastic but of die cast zinc which provides excellent screening against

hum and RF interference. The general ‘feel’ of the microphone inspires confidence. The On-Off

switch is of the ‘lite touch’ variety.

Lifetime guarantee. Manufactured in accordance with Quality standard ISO9001.

Supplied complete with a 4 metre XLR to Jack lead.

Studiospares S945

Designed with a rugged feel that inspires confidence in the

singer.

The neodymium magnet assembly is coupled to a very lightweight diaphragm that easily responds

to transients and provides an output capable of pushing any system noise well out of earshot. The

capsule captures the nuances of male and female vocalists alike. Musically the output is faithful and

will capture stringed and brass instruments with an uncanny accuracy. The transparency also retains

the pureness of reed and woodwind instruments. The capsule in the S945 sounds particularly sweet

and has been described as a ‘smoothie’. The diaphragm is protected from the excesses of the

outside world by a stainless steel mesh and an internal foam windshield. The body is not plastic but

of die cast zinc which provides excellent screening against hum and RF interference. The On-Off

switch is of the ‘lite touch’ variety.

Specifications.

Frequency response: 50Hz - 15kHz

Sensitivity: -53dB

Max SPL: 144dB

S940 448-600 £22.50

S940 - 3 Pack 448-603 £59.99

S940 + Mic Stand + Mic Clip 448-605 £33.30

S945 449-630 £15.92

S945 - 3 Pack 449-633 £41.66

S945 + 5m XLR Lead 449-635 £19.17

S945 + Mic Stand + 5m XLR Lead 449-636 £27.08

Behringer Ultravoice XM1800S Cardioid

Vocal Microphones

Dedicated vocal and instrument

mic with on/off switch which

delivers excellent quality for

your studio and live

performance

• Wide frequency response for a

brilliant and transparent sound

• On/off switch to mute during

breaks

• Stand adapter and carrying case

included

XM1800S 3-Pack 381-130 £29.58

Behringer Ultravoice XM8500 Cardioid

Vocal Dynamic Microphone

The XM8500 provides a good

healthy frequency response of

50Hz to 15kHz, and includes a

two-stage pop filter to minimize

breath and pop noises.

• Cardioid characteristic cuts

background noise and feedback

• Smooth mid-frequency presence

rise

• Includes mic stand adapter and an

impact-resistant carrying case

XM8500 381-120 £14.75

More Products Online...

2017 CAT PAGES 50-59:Layout 1 16/12/2016 09:47 Page 6

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Vocalist Microphones - Dynamic

Continued

Studiospares S1940

The S1940 looks great and quickly becomes part of the act.

Recreating the sounds of the 40s and 50s starts at the microphone. It even feels 1940s.

Manufactured from a zinc die casting which houses a large dynamic capsule heavily protected from

pop and blast by the slots which break up blasts whilst an internal red foam windshield filters out the

rest. To be really authentic there is a slight presence peak which provides greater intelligibility and

clarity. The On - Off switch is silent and will not “pop the monitors” when activated. The S1940 is

capable of withstanding the rigours of the stage and the road. Includes a sturdy microphone case.

Bundle includes round-based chrome stand and an armoured XLR lead.

S1940 449-140 £47.08

S1940 Bundle 449-145 £64.50

Studiospares S1945

Vocal / Harmonica Microphone

Captures every nuance of the

harmonica which is very rich in

harmonics.

• For reproducing the harmonica the

S1945 is almost impossible to beat

• Chrome finish captures the realism

of the 1940s era

• Very popular with harpists

• Angle adjustable

• Sold at a fraction of the price of

competitive products

S1945 449-740 £40.83

S1945 + Mic Stand + Cable 449-745 £53.33

Shure 55SH

Artists feel the synergy between

themselves and the 50s and 60s era

when performing with the 55SH.

423-190 £117.92

ALSO RECOMMENDED

More products online...

Shure 520DX

The Shure 520DX is fully controllable

from the microphone allowing greater

control during live performances.

443-760 £107.50

Retro Vocal Mic

This Retro Microphone conjures up the

nostalgia of the 50s and 60s. Response

tailored to fit that era.

401-790 £32.80

Shure Super55

This supercardioid dynamic vocal mic

combines a vintage design with a

contemporary performance upgrade.

433-190 £187.50

AKG D5

An extremely rugged vocal/speech microphone featuring a

patented laminated varimotion diaphragm.

The D 5 dynamic vocal microphone for lead and backing vocals delivers a powerful sound even on the

noisiest stage. Its supercardioid polar pattern ensures maximum gain before feedback (for more details,

visit www.feedbackisdead.com). The D 5 stands for a crisp sound that cuts through every mix. AKG

made the first microphone diaphragm ever whose thickness varies across its diameter. The new

Laminated Varimotion diaphragm deep-drawing process allows the diaphragm itself to be fine-tuned with

no extra tuning resonators, leading to a quantum leap in audio performance. The dual shock mount

eliminates any kind of mechanical noise for trouble-free live use. The audience will hear nothing but the

pristine sound of your voice!

D5 439-730 £62.50

Heil PR-30

Professional Dynamic Vocal Microphone

Includes a hum bucking coil in

addition to the shock-mounted

large diaphragm to virtually run

noise-free.

• 1.5” diaphragm for easy extended

bass.

• Three screens, 2x wire mesh and 1x

foam virtually eliminates popping

and sibilance

• Response 40Hz - 18kHz

• Max SPL 146dB

• Output level -51dB

• With an adjustable cast metal mic

holder in a foam-fitted box

PR-30 318-030 £216.63

Heil PR-35

Professional Dynamic Vocal Microphone

Excellent articulation & a natural

upper mid-range along with a

wide smooth at response.

• Matte black/Chrome rubberised

finish looks and feels good.

• Cardioid polar pattern

• Low-cut roll off switch, stops low

end feed back loops.

• Large 1.5” shock-mounted hum-

bucking coil reduces handling and

electronic interference;

• Max SPL 140dB

• Three interchangeable colored trim

rings (black, silver, and purple) and

a mic clip along with a black

acoustical wind screen

• Flat response from 40 Hz to 18 kHz

PR-35 Black 318-040 £224.17

PR-35 Chrome 318-045 £324.17

Audix OM6

Vocal Microphone

Concert level, professional vocal

mic with very wide and highly

accurate frequency response.

• Broad frequency response

• Full-bodied and articulate sound

reproduction

• Ability to handle high SPLs in

excess of 144 dB without distortion

• Hypercardioid polar pattern

• rising response between 2kHz -

10kHz

• Bass response from 60 Hz - 1 kHz

OM6 432-020 £165.83

NEW

TC Helicon MP-76

Vocal Microphone

A microphone engineered for

the sonic realities of modern

vocal performance.

• Excellent pop and breath noise

rejection

• Super-Cardioid pick-up Pattern

• Superior background noise rejection

and resistance to feedback

• Suspended dual shock mount

• Mic Control™ button for control of

TC-Helicon vocal effects

• Rugged and ergonomic design

MP-76 386-640 £124.17

NEW Lewitt MTP550

Vocal Microphone

Shaped specically for

demanding vocal applications

and provides consistently rich

and powerful output in any live

setting.

• High gain before feedback

• Detailed, rich and modern sound

• Improved internal shock-mount

• The capsule is fully rubber-mounted

• Equipped with an on/off switch

• Rugged and ergonomic design

• Built-in spherical wind and pop-filter

MTP550 456-360 £94.16

NEW

2017 CAT PAGES 50-59:Layout 1 13/12/2016 12:16 Page 7

Vocalist Microphones - Dynamic 57

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Shure SM58 LC Cardioid

Easily the world’s most popular and most

copied stage microphone.

The SM58 is guaranteed to enhance any artist’s

performance through the punchy and dynamic sound.

The capsule is elastically suspended to minimise

shock and handling noise. The pick up pattern is

cardioid which helps reduce unwanted feedback

enabling the performer to increase the level of the PA.

The frequency response is tailored to the vocal

spectrum with a range 50Hz to 15kHz. The Wire Mesh

pop shield minimises breath and popping noises and

can be removed for cleaning or replacement.

• Cardioid (unidirectional) dynamic

• Rugged and reliable

• Pneumatic shock-mount system

• Uniform cardioid pickup pattern

• Frequency response: 50 to 15,000 Hz

• Built-in spherical wind and pop filter

• Supplied with break-resistant stand

adaptor and storage bag

• Bundle option with either a Pro or

Economy XLR Lead

Shure SM58 - 50th Anniversary

Celebrate the 50th anniversary of this legendary workhorse with a unique commemorative

limited edition featuring an elegant silver handle. This edition marks the first time in 50 years

that Shure has released a colour variation of the SM58 to the public. Otherwise, the SM58-

50A is the mic you know and trust: it’s the industry-standard cardioid dynamic microphone

tailored to deliver warm and clear vocal reproduction under extreme conditions.

The pack consists of the Shure SM58-50A with a silver finish, a Commemorative

certificate, bumper sticker & photo, a historical user guide, a mic clip and a Zipper bag.

First introduced in 1966, the

SM58 remains one of the

best selling microphones in

the world today.

SM58 LC 423-011 £77.50

SM58 LC 3-Pack 423-013 £225.00

SM58 LC + 5m XLR Lead 423-014 £79.17

SM58 LC + 10m XLR Lead 423-015 £81.67

SM58 LC + Pro 5m XLR Lead 423-016 £85.00

SM58 LC + Pro 10m XLR Lead 423-017 £88.33

SM58 LC + 5m XLR Lead + Mic Stand 423-020 £81.67

SM58 LC + 10m XLR Lead + Mic Stand 423-021 £85.83

SM58 LC + Pro 5m XLR Lead + Mic Stand 423-018 £82.50

SM58 LC + Pro 10m XLR Lead + Mic Stand 423-019 £86.67

SM58 On/Off Switched version 423-100 £90.83

SM58 - 50th Anniversary Limited Edition 423-029 £82.50

Protective Grille 404-741 £9.16

SM58 LC Windshield 423-090 £6.65

2017 CAT PAGES 50-59:Layout 1 13/12/2016 12:17 Page 8

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Vocalist Microphones - Dynamic

Continued

Studiospares S965

Gives good account of itself whatever the situation.

The frequency response is tailored to slightly enhance mid and upper frequencies. The pickup pattern is

hypercardioid so problems of acoustic feedback when venturing near speakers are drastically reduced.

A dual pop blast filter reduces the incidence of pop blast from over enthusiastic performers. Both filters

can be easily refreshed by simply unscrewing the protective grille. The capsule is soft mounted to reduce

any handling noise from nervous performers. Although this model is sold as a vocalist microphone it

doubles equally well as an instrument microphone finding frequent applications such as being close to

the bell of a saxophone, miking acoustic guitars or in front of a speaker cabinet.

Specification. Frequency response 50Hz - 15kHz. Maximum SPL 144dB.

S965 449-640 £18.75

S965 - 3 Pack 449-643 £49.99

S965 - 10 Pack 449-641 £149.00

S965 + Stand 449-645 £25.70

S965 + Stand + 5m XLR Lead 449-646 £29.50

Shure SM7B

A smooth and warm sounding microphone that

is ideal for close-talk applications such as radio

presenting and voiceovers for TV.

The SM7B dynamic microphone has a smooth, flat, wide range frequency

response appropriate for music and speech in all professional audio applications.

It features excellent shielding against electromagnetic hum generated by computer

monitors, neon lights, and other electrical devices. The SM7B has been updated

from earlier models with an improved bracket design that offers greater stability. Its

highly effective pop filter eliminates need for any add-on protection against

explosive breath sounds, even for close-up vocals or narration. In addition to it's

standard windscreen, it also includes the A7WS windscreen for close-talk

applications and a locking yoke mount that is designed to reduce plosive sounds

and gives a warmer tone for close-talk vocals. The SM7B has a rugged

construction and excellent cartridge protection for outstanding reliability.

SM7B 423-880 £324.17

Shure KSM8 Dualdyne

The world's first dual-diaphragm dynamic handheld

microphone for revolutionary vocal reproduction and

accurate sound-reinforcement and control.

Designed for live sound performances where vocal clarity and sound quality are absolutely critical, the

KSM8 not only meets the most discerning quality and reliability standards, it also has the versatility to

adapt to changing environments without impacting performance. The patented Dualdyne cartridge of

the KSM8, which features two ultra-thin diaphragms—one active and one passive—and a

groundbreaking inverted airflow system.

The KSM8 will revolutionize dynamic microphones in the live sound industry by providing sound

engineers with a dynamic microphone that has virtually no proximity effect, a mastery of off-axis

rejection and an output accuracy that requires none of the presence peaks or roll-offs that are typical

of other dynamic microphones.

KSM8 Black 483-110 £379.17

KSM8 Nickel 483-115 £379.17

NEW

Shure SV100

Vocal Dynamic Microphone

The Shure SV100 can be used

for karaoke, sound

reinforcement and multimedia

applications.

• Wide frequency response

• Unidirectional pickup pattern

• High output

• Clear and vibrant sound

• Suitable for instrument pickup

SV100 423-840 £25.00

SV100 + Pouch + Mic Holder 423-841 £29.17

SV200 423-845 £27.08

SV200 + Pouch + Mic Holder 423-846 £31.25

Shure SV200

Dynamic Microphone with Pouch and Mic Holder

Perfect for uses like karaoke,

presentations, and hobbyist

musicians.

• Entry level dynamic cardioid

microphone

• On/off switch

• Black handle, Silver grille

• XLR to XLR on a 4.5 m lead

• The unidirectional (cardioid) pickup

pattern of the SV200 helps reduce

feedback

Shure PGA48

Handheld Vocal Microphone

The PGA48 is Ideal for picking

up clear audio and dismissing

any unwanted noise.

• Cartridge design specifically for

clarity in the standard frequency

range of speech

• Cardioid polar pattern

• 15 ft (4.57 m) XLR-Jack or XLR-

XLR cable

• On/Off switch for discrete control of

microphone operation

• Stand adapter for mounting to a

microphone stand

• Zipper pouch included

PGA48 with XLR-Jack Lead 443-450 £37.50

PGA48 with XLR-XLR Lead 443-455 £37.50

Shure PGA58

Handheld Vocal Microphone

The PGA58 is the ideal mic for

live performances be it backing

or lead vocals.

• Tailored microphone cartridge

design for natural clarity in the

frequency range of vocal

performance

• Cardioid polar pattern

• 15 ft (4.57 m) XLR-Jack or XLR-

XLR cable

• On/Off switch for discrete control of

microphone operation

• Stand adapter for mounting to a

microphone stand

• Zipper pouch included

• The PGA58BTS includes the

PGA58, an XLR cable and a Tripod

Boom Stand

PGA58 with XLR-Jack Lead 443-500 £51.67

PGA58 with XLR-XLR Lead 443-505 £51.67

PGA58BTS 443-920 £60.00

2017 CAT PAGES 50-59:Layout 1 16/12/2016 09:47 Page 9

Vocalist Microphones - Dynamic + Broadcast Microphones 59

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Shure Beta 58A

Vocal Microphone

Features a neodymium magnet

assembly which produces a 3dB

higher output level.

• The length of the magnetic field is

also increased to ensure the coil

stays within the field even when

driven hard by high SPLs

• This increase in sensitivity can be

useful where the microphone is

distant from the sound source

• Includes a revised shock mount

• Supplied with Mic Holder with 5/8”

Thread

Beta 58A 423-160 £132.50

STA4 Thread Adaptor 401-100 £1.63

Shure Beta 57A

Cardioid Vocal Microphone

Updated for optimal warmth and

presence.

• The grille has been restyled and

hardened, allowing engineers

to place the microphone closer to

the sound source

• Shock mount further reduces

handling noise

• Finds frequent use amongst female

vocalists, particularly in backing

groups

• Supplied with Mic Holder with 5/8”

Thread

Beta 57A 423-170 £112.50

STA4 Thread Adaptor 401-100 £1.63

Sennheiser e835 Evolution

A dynamic vocalist microphone with a gentle presence

boost that will cut through the mix or the PA.

The capsule features a cardioid pick up pattern with a uniform on and off axis response. This design

yields excellent rejection to ambient noise and feedback. The design is optimised for the proximity

effect when used close to the mouth, which produces a warmer and more dynamic sound.

Frequency response 40Hz - 16kHz. The body is of metal construction and has a well balanced feel

for stage use. The sophisticated shockmount system effectively decouples handling and cable

noises. Extremely rugged and able to withstand the rigours of stage and road use. Supplied

complete with pouch and mic clip. The e835S is the Switched version.

e835 452-840 £59.08

e835 3-Pack 452-843 £157.50

e835S 455-130 £59.08

Sennheiser e945 Supercardioid

Supercardioid Vocal Microphone

A fully professional super-

cardioid vocal microphone

which cuts through the mix and

offers a smooth, natural sound.

• Rugged metal body

• Advanced shock-mount design

• Consistent on-/off-axis response

• Hum compensating coil

• Includes a pouch and a mic clamp

e945 453-820 £132.50

Sennheiser e845 Evolution

Cardioid Vocal Microphone

A high quality, powerful

performance vocal microphone!

• High quality, performance vocal mic

• Extended high frequency response

• Super cardioid pick-up pattern

• Freq response 40Hz - 16kHz

• Full metal construction and shielding

• Effective internal shockmount system

• Supplied with pouch and mic clip

e845 452-850 £72.42

Telefunken M82

A robust dynamic cardioid microphone

that features a large 35mm diaphragm

with superb low frequency capabilities.

499-340 £373.33

ALSO RECOMMENDED

More products online...

AKG D5C

For lead and backing vocals delivering a

powerful sound even on the noisiest

stage.

469-490 £74.17

Telefunken M81

A clear and detailed top end, articulate

mid-range, and minimal proximity effect.

Cardioid pickup pattern.

499-330 £233.33

Telefunken M80

Delivers condenser-like performance in

a dynamic design. Wider frequency

response and higher SPL capabilities.

499-320 £233.33

Shure SM48-LC

Dynamic Vocal Microphone

A rugged cardioid dynamic

microphone for reliable use in

spoken word and vocal

performance applications.

• Cardioid pickup pattern rejects off-

axis sound and provides superior

gain before feedback

• Frequency response tailored for

vocals, with brightened mid-range

and bass rolloff

• Shock-mounted cartridge for

exceptional ruggedness and

reduced handling noise

• Built-in "pop" filter that reduces

breath sounds and wind noise

• Supplied stand adapter and

carrying/storage bag

SM48-LC 443-000 £57.50

SM48-LC with Switch 443-010 £60.00

Live M10

Vocalist Microphone

A “no compromise product”

bringing quality sound to all

vocalists and musicians.

• Designed to not accentuate sibilant

voices

• Ideal for stage performers

• Frequency Response 50Hz - 15kHz

• Metal body provides good screening

against electrical interference

M10 Switched 449-750 £8.30

M10 3-Pack + Case/Clips 449-753 £24.17

M10 + Stand + 5m XLR Lead 449-755 £17.92

Broadcast Microphones

Shure VP82

Shotgun Microphone

Compact, lightweight and

exhibits natural off-axis sound

rejection.

• Integrated preamplifier design (not

modular)

• Wide aperture for near-field sound

sources

• Provides natural off-axis rejection

• Zipper pouch and foam windscreen

(included)

• Compatible with VP89S premium

accessories

• Rugged, roadworthy construction

VP82 443-950 £269.58

Want A Job?

Studiospares are constantly

expanding. We require

additional staff for a variety of

positions, working in a very

congenial atmosphere. Practical

experience of recording and/or

live sound engineering would be

preferable.

Send in your CV in the first

instance.

2017 CAT PAGES 50-59:Layout 1 13/12/2016 12:17 Page 10

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Broadcast + Boundary Microphones

Broadcast Microphones

Continued

Studiospares SB200 Hypercardioid

Broadcasters Microphone

A large dynamic capsule

microphone equally at home in

the broadcast studio or

voiceover booth.

• Capsule exploits the air suspension

technique for effective shock and

vibration resistance

• Hum bucking coil rejects magnetic

field interference

• Bass Roll Off switch starts to roll off

at 350Hz

• The Presence switch boosts

frequencies between 2-4kHz

• Supplied complete with an elastic

suspension

SB200 449-130 £73.33

SB200 + Desk Boom Arm 449-135 £99.17

SB200 Broadcast Pack 449-136 £107.50

Studiospares SB200 Broadcast Pack

This package includes the SB200 together with a Multipoise Desk

Boom Arm designed to hold larger microphones without drooping,

and a RED 200 pop shield.

Rode Stereo VideoMic X

The Stereo VideoMic X is the ultimate

broadcast- grade stereo microphone for

on-camera use.

497-460 £457.50

ALSO RECOMMENDED

More products online...

Rode Reporter

Designed to allow the user freedom of

use, without the technique related

issues.

417-980 £115.83

Rode NTG3B

Uses an RF signal to bias the capsule to

stop the effects of moisture causing

problems.

417-555 £490.83

Rode NTG4

The NTG4 builds on the platform

created by RØDE's award- winning

NTG1 shotgun microphone.

497-470 £215.83

Rode NTG4+

Features an condenser capsule with

low noise and the convenience of on-

board equalisation/level control.

497-480 £249.17

Electro-Voice RE20

The Electro-Voice RE20 is a favourite

for broadcast show hosts and voice

over studios. Also used inside bass

drums, on acoustic guitars, and more.

414-071 £365.83

ALSO RECOMMENDED

More products online...

Shure VP64A

The VP64A is a high-output

omnidirectional handheld dynamic

microphone designed for professional

audio and video production.

443-930 £119.58

Boundary Microphones

Studiospares SB450USB

Boundary Microphone

A highly sensitive USB Boundary

Electret Microphone with a

multitude of applications.

• USB output OK for Mac and PC

computers

• Highly sensitive back Electret

capsule captures sounds from all

directions

• Subsonic filter to remove

troublesome frequencies that exist

close to walls and floors

• Supplied with 3m of cable

SB450USB 449-690 £26.66

Studiospares SB400

Prevents comb filtering by keeping phase

interference above the audible range.

Some applications for directional boundary mics are picking up actors' voices onstage

in drama or musicals, picking up the footwork of dance troupes, picking up speech at

conference tables and boardrooms and recording small musical ensembles or soloists.

A smooth wide response is guaranteed by using a back electret capsule powered by

phantom powering or any voltage between 9 and 52 volts. The underside of the die

cast alloy body has a rubber pad to avoid stage borne interference. Output is via a mini

3 pin XLR. Supplied complete with a connecting lead for conventional 3 pin XLR inputs.

The response is substantially flat from 50Hz - 20kHz. Max SPL 130dB. Designed to

withstand the rigours of the road and represents incredible value for money.

SB400 449-520 £22.92

MXL AC-404

USB Web Conferencing Mic

Uses built-in custom circuitry to

produce smooth, quiet, and

professional sounding

conferences, no matter where

you are.

• 180-degree coverage for great

sound over a wide range

• Frequency response 40Hz - 16kHz

AC-404 315-120 £65.83

Samson UB1

USB Boundary Microphone

Miniature, low-prole surface

mount condenser microphone.

• Ideal for portable computer recording

• Low-profile surface mount

condenser

• Omni directional pick-up pattern

• Ships with Cakewalk Sonar LE

• Includes USB cable and storage

case

UB1 388-480 £66.66

Shure Beta 91

Cardioid Boundary Microphone

Designed specifically for kick

drum or bass use, the Beta 91

should add attack and punch to

recordings.

• The diaphragm’s moving coil is

designed to stay within the

magnetic flux of the Neodymium

magnet assembly

• The microphone’s low profile helps

to eliminate the need for a stand or

mounting hardware

• Integrated XLR preamplifier

Beta 91 423-070 £182.50

ALSO RECOMMENDED

More products online...

Boundary/Ceiling Panel Mic

Suitable for use where discreet audio

surveillance is required. Phantom

powered (9-52Vdc). Omnidirectional

pick-up pattern.

476-650 £37.50

Price Changes

This catalogue was priced

in December 2016. Many

prices will have come

down, while some will have

increased. Check online for

up-to-date pricing.

2017 CAT PAGES 60-69:Layout 1 13/12/2016 12:35 Page 1

Boundary + Installation Microphones 61

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Crown PCC-160

Surface Mount Microphone

Popular for attaching to walls,

under grand pianos and in

conference rooms.

• Directional polar pattern

• Reduced unwanted room noise

• Max SPL 120dB

• Surface-mounting creates a “half-

supercardioid” polar pattern and

increases directivity by 3 dB

• Frequency response (typical): 50 Hz

to 18,000 Hz at 30 degrees

PCC-160 243-190 £255.00

Installation Microphones

AKG 99 Series

High class microphones for any application at a remarkable price point, making

this the most popular new series of microphones of the last 5 years.

AKG CGN 99 C/S

The cardioid polar pattern is the most popular because its uses are almost limitless. The 125 pickup angle is especially suited for

inexperienced or very "vivacious" talkers who often fail to talk directly into the microphone. The choice of two different lengths and the

flexible joint ensure optimum alignment of the gooseneck to any talker position. Hypercardioid version and other lengths available. See

pricelist for more options.

AKG CHM 99

The CHM 99 Condenser Hanging Microphone provides both ease of use and a high level of

functionality. There is hardly any more affordable and simpler solution for recording choirs at

worship centers. Suspended from the ceiling or a beam, the hanging microphone is aligned and

then fixed in the correct position. Now use the spring steel clamp to adjust the correct angle,

and off you go! Using two CHM 99 hanging microphones in an XY configuration (coincident pair)

is a good way to make stereo recordings, particularly of choirs. However, sound source

locations are defined only by intensity differences. Adjusting the angle between the microphones

determines the width and depth of the stereo image.

AKG CBL 99

The CBL 99 is a high-quality boundary microphone designed to deliver superior results for a

multitude of recording applications. The boundary layer technique is well-known for recording

and offers non-directional pickup that is frequencyindependent. The CBL 99 is small, lightweight

and easy to place . no stand is needed. Since the transducer sits in a metal plate only 5 mm (0.2

in) thick, the plate doesn’t interfere with or colour the sound. Frequency response is very uniform

within its hemisphere and it captures the “room sound’’ of an instrument very accurately. It can

be permanently attached to the floor or wall of a studio using the screw holes in the plate or

attached temporarily using the supplied adhesive compound. Its 3-pin output connector also has

a switchable bass-cut filter to minimize surface-born noise.

More AKG 99 Series options available online.

CGN99 C/S Cardioid Gooseneck 30cm 469-010 £90.83

CGN99 C/L Cardioid Gooseneck 50cm 469-020 £90.83

CGN99 H/C Hypercardioid G/Neck 30cm 469-030 £90.83

CGN99 H/L Hypercardioid G/Neck 50cm 469-040 £90.83

CHM99 Black Hanging Choir Mic 469-050 £90.83

CHM99 White Hanging Choir Mic 469-051 £90.83

CBL99 Black Boundary Microphone 469-060 £90.83

Audio Technica Pro45

Hanging Condenser Microphone

The Pro45’s high-SPL handling is

perfect for suspension over

choirs

and orchestras.

• Offers versatile sound-

reinforcement solutions for speech,

theater, orchestra and choir sound

reinforcement and recording

• Robust construction and

unobtrusive appearance

Audio Technica Pro49Q

Gooseneck Microphone

Same capsule as Pro 45 but

goose-neck mounted and

includes self contained

electronics.

• Quick-mount double-gooseneck

cardioid condenser microphone

• Designed to plug into any standard

XLRF-type surface or cable

connector

• Flat, smooth frequency response

and self-contained electronics

• Quiet, fixed-placement, long-life

gooseneck

• Wide-range condenser element

with low-mass diaphragm for

superior performance

PRO45 447-120 £81.67

PRO45W White 447-125 £111.00

PRO49Q 447-130 £83.29

Studiospares HM10

The HM10 provides an

unobtrusive and clear

sounding way to capture

audio for choral, orchestral

and religious applications.

A back Electret capsule designed to be hung by

its cable. It includes a UniGuard design that makes

it practically immune to RF interference. The

pickup pattern is cardioid with excellent rear

sound rejection. The response is 30Hz - 20kHz

with a maximum SPL of 139dB. The

signal/noise ratio is 70dB ref 1kHz

@ 1Pa so even the quietest

sound will cut through

any system noise.

HM10 449-500 £37.50

Samson CM12C

Hanging Choir Microphone

A miniature cardioid hanging

microphone designed to hang

directly over a choir or

orchestra.

• Steel hanger positions the correct

angle

• Hardwired 30-foot cable with mini

XLR

• Mini to standard XLR connector

included

• 9-52V Phantom Power Operation

• Condenser capsule

• Response 50Hz - 18kHz

• Max SPL 136dB

Samson CM15P/CM20P

Mini Gooseneck Podium Microphone

High-quality gooseneck

microphone for any podium

application.

• The condenser element and

cardioid pickup pattern provide

optimum sound quality for speech

• 380mm gooseneck with flexible

top and bottom

• Internal Selectable Hi-pass filter

• Standard XLR connector

• Flange-mount included

• 9-52V Phantom Power Operation

CM12C 388-860 £58.32

CM12CW White 388-861 £58.32

CM15P 15” 388-870 £58.32

CM20P 20” 388-880 £58.32

XFM1 Cable Flange Mount 388-900 £16.66

2017 CAT PAGES 60-69:Layout 1 13/12/2016 12:36 Page 2

WEB |www.studiospares.com EMAIL |sales@studiospares.com

Stereo + Lavalier + Video Camera Microphones

Stereo Microphones

Rode NT4

Cardioid Single Point Stereo Microphone

Solves the problem of stereo

recording by eliminating the

need to purchase matched

pairs.

• Stereo X/Y condenser microphone

• Dual externally biased 1/2" capsules

with gold sputtered diaphragm

• Capsules closely matched with full

frequency response

• Dual power operation

• Custom stereo cables included

• Twin head windshield (WS4) included

NT4 417-100 £365.83

NTRM3 Stand Mount 417-420 £12.50

WS4 Windshield 417-470 £12.50

Lavalier Microphones

Rode Lavalier

Omni Lavalier Microphone

A discreet lavalier or lapel style

mic that provides simple and

intuitive audio in any application.

• Low self noise and user friendly

omni polar pattern

• Minimal appearance so ideal

solution for film, TV, theatres,

houses of worship

• Includes mini-furry and cable

management clips

• All supplied in anti-trauma water-

resistant case

Lavalier 417-770 £140.83

Audio Technica ATR3350

Lavalier Microphone

This high quality Audio Technica

omnidirectional ATR3350 lavalier

is engineered for intelligible,

accurate voice reproduction.

• Terminates with 3.5mm Mini Jack

plug

• Back Electret quality capsule

• Ideal for aerobics/dance/sports

instructors

• Includes Tie clip, battery, foam

windscreen, and 1/4 inch (6.35 mm)

adaptor

ATR3350 447-050 £20.42

Audio Technica PRO70

Lavalier Microphone

The PRO70 is designed to make

music and speech clearly and

comfortably audible, yet never

draw attention to itself.

• Operates on battery or phantom

power

• 1.8 m cable permanently attached

• Low frequency roll off

80Hz@8dB/octave

• Cardioid. Response 100-14,000 Hz

• Natural and articulate sound

• Output via XLR

Pro70 447-720 £90.83

Shure MOTIV MVL

Lavalier Microphone

A reliable and discreet lapel

microphone designed for close-

mic speech recording

applications.

• 1/8" (3.5 mm) TRRS connector

plugs

• Sleek, miniature housing for

discreet appearance onscreen

• Best-in-class in signal-to-noise

ratio, headroom and maximum SPL

• Proven Shure RF/GSM interference

protection

• Quality design and construction

• Includes windscreen, tie clip and

carrying pouch

MOTIV MVL 483-090 £45.83

Condenser Tie Clip Mic

A highly sensitive microphone with a

wide frequency response ideal for

music and speech recordings.

476-710 £16.66

ALSO RECOMMENDED

More products online...

Lavalier Condenser Mic

Lavalier Omni tie-clip microphones for

use with VHF and UHF beltpack

transmitters. Colour Beige.

476-720 £12.42

Shure SM911-CN

Designed for use in TV broadcasting,

sound reinforcement, certain radio and

motion picture applications.

443-570 £120.83

Shure SM93

An omnidirectional miniature lavalier

condenser microphone designed for

use in speech applications.

443-580 £162.50

IK Multimedia iRig Mic

Lavalier Microphone

The chainable mobile lavalier

with built-in monitoring

capability for all mobile devices.

• Professional mobile lavalier mic

• High-quality omnidirectional

condenser capsule

• Includes foam pop shield and

durable mounting clip

• 1/8" TRRS jack connects to iPhone,

iPad, iPod touch, Android

• Combo 1/8" TRRS port

• Compatible with any audio app that

accepts audio from headset input

• Comes with a suite of powerful

recording apps

• 150cm/66” cable

iRig Lavalier Mic 321-870 £37.49

iRig Lavalier Mic 2-Pack 321-872 £62.49

NEW Video Camera Microphones

Sennheiser MKE 440

Stereo Camera Microphone

Compact stereo shotgun

microphone for cameras with a

lighting shoe mount and

external microphone input.

• Dual mini shotgun mics create

frontal focus

• Suppression of ambience and

background noise

• Built-in elastic suspension and wind

protection

• 3-level sensitivity adjustment and

low-cut

• Compact, all-metal construction

• Standard size camera shoe mount

MKE 440 473-130 £245.83

NEW

Sennheiser AVX Combo Set

Camera RF Kit

The perfect digital wireless

microphone for lm projects.

• Includes a handheld microphone,

the plug on receiver, a bodypack

transmitter with lavalier microphone

and all accesories

• Very fast setup

• Plugs directly into XLR audio input

• Ultra compact receiver

• Switches on/off by P48 Phantom

power

• Optimized dynamic range

AVX Combo Set 473-990 £607.50

NEW

Rode Videomic

Mini Shotgun Video Camera Microphone

The Rode VideoMic is a professional grade condenser shotgun

microphone. Based on the latest ‘Film industry’ technology, the

VideoMic is designed specifically for use with high quality Digital

Video Cameras. The microphone exhibits low noise and an

unusually wide bandwidth for its size. It is ultra lightweight, yet

rugged due to its ABS construction. The VideoMic is powered

by a standard 9 V battery and offers a Low Battery LED status

indicator and a switchable high pass filter to reduce unwanted

low frequency rumble. Battery life in excess of 100 hours. The

VideoMic attaches to any Camcorder that has the standard hot-

shoe fitting and utilizes a stereo Mini Jack for audio output. The

integrated Rycote® Lyre shock mounting system isolates the

VideoMic capsule and electronics from its all-metal shoe mount,

providing isolation from external physical factors that may cause

unwanted rumble and vibrations in the microphone.

Rode Dead Cat

Fits over the existing foam

windshield. The DeadCat is designed

for outdoor use where strong winds

would generate excessive low

frequencies, too much for the high

pass filter to remove.

VideoMic 417-150 £82.50

VideoMic Tripod 417-530 £20.83

Dead Cat 417-160 £27.50

2017 CAT PAGES 60-69:Layout 1 13/12/2016 12:36 Page 3

Video Camera + E.N.G. Reporting Microphones 63

ALL PRICES EXCLUSIVE OF VAT.

TELEPHONE |020 8208 9930 FAX |020 8450 4390

Rode Filmmaker Kit

Camera Microphone Kit

Provides everything you need to

start shooting video wirelessly.

• Including a receiver, transmitter and

broadcast-grade lavalier mic

• Series II, 2.4GHz digital transmission

• 128-bit encryption

• Up to 100 metres range

• OLED display (on receiver)

• One button pairing

• Three level gain control

• AA battery or USB powered

• Includes Rode's broadcast Lavalier

microphone

Filmmaker Kit 497-500 £274.17

Rode VMPR Videomic Pro-R

Shotgun Microphone

Designed for use with

camcorders, DSLR cameras and

portable recorders as a source

of primary and reference audio.

• Rycote® Lyre® shock mounting

onboard

• All new capsule with lower noise

and higher sensitivity

• Broadcast recording quality

condenser microphone

• Compact form factor and Ultra

lightweight (85g/3oz)

• 9V battery powered

VideoMic Pro-R 497-510 £140.83

Rode Newsshooter Kit

Camera Microphone Kit

Digital Wireless System for

News Gathering and Reporting.

• Series II, 2.4GHz digital

transmission

• 128-bit encryption

• Up to 100 metres range*

• OLED display (on receiver)

• One touch pairing

• Five level gain control

• AA battery, NP-F battery or USB

powered

• Locking XLR input and headphone

output on transmitter

Newsshooter Kit 497-580 £374.17

NEW

Shure VP83 LensHopper

Camera Mount Shotgun Microphone

Provides detailed, high-

denition audio with DSLR

cameras and camcorders.

• Camera-Mount Condenser

Microphone

• Integrated Rycote Lyre System

• Three-Position Gain Adjustment

• Switchable Low-Cut Filter

• 130 Hours of Battery Life

• Attached 3.5mm Audio Cable

• Standard-Size Shoe Mount

• Lightweight All-Metal Construction

• Includes Foam Windscreen

VP83 LensHopper 443-960 £162.50

VP83F 443-970 £282.50

Shure VP83F

Camera Mount Flash Recorder Microphone

The VP83F shares the same features as the VP83, but has a built-

in microSDHC slot, to which it can record audio in up to 24-

bit/48kHz quality while simultaneously sending audio to your

camera.

Audio Technica AT875R

Line + Gradient Condenser Microphone

Designed for video production

and broadcast (ENG/EFP) audio

acquisition.
