SERVICE MANUAL
AMPLIFIER
E Model
SPECIFICATIONS
TA-SV7AV
Ver 1.0 2001.06
9-873-154-01 Sony Corporation
2001F0500-1 Home Audio Company
C 2001.6 Shinagawa Tec Service Manual Production Group
TA-SV7AV is the Amplifier section
in MHC-SV7AV.
Amplifier section
The following measured at AC 120, 220, 230 – 240 V,
50/60 Hz
Front Speaker:
DIN power output (rated) 95 + 95 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
120 + 120 watts
(6 ohms at 1 kHz, 10%
THD)
Center Speaker:
DIN power output (rated) 30 watts
(8 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
40 watts
(8 ohms at 1 kHz, 10%
THD)
Rear Speaker:
DIN power output (rated) 30 + 30 watts
(8 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
40 + 40 watts
(8 ohms at 1 kHz, 10%
THD)
Inputs
VIDEO (AUDIO) IN: voltage 250 mV,
(phono jacks) impedance 47 kilohms
MD IN: voltage 450 mV,
(phono jacks) impedance 47 kilohms
OPTICAL IN:
(Square optical connector jacks, rear panel)
wavelength 700 nm
MIC 1/2: sensitivity 1 mV,
(phone jack) impedance 10 kilohms
Outputs
MD OUT: voltage 250 mV
(phono jacks) impedance 1 kilohms
VIDEO OUT: max. output level
(phono jack) 1 Vp-p, unbalanced,Sync
negative, load impedance
75 ohms
S-VIDEO OUT: Y: 1 Vp-p, unbalanced,
(4-pin/mini-DIN jack) Sync negative,
C: 0.286Vp-p,
load impedance 75 ohms
PHONES: accepts headphones of
(stereo mini jack) 8 ohms or more
FRONT SPEAKER: accepts impedance of 6 to
16 ohms
REAR SPEAKER: accepts impedance of 8 to
16 ohms
CENTER SPEAKER: accepts impedance of 8 to
16 ohms
SUB WOOFER OUT: Voltage 1 V,
impedance 1 kilohms
General
Power requirements
Thailand model: 220 V AC, 50/60 Hz
Other models: 120 V, 220 V or
230 – 240 V AC,
50/60 Hz
Adjustable with voltage
selector
Power consumption 300 watts
Dimensions (w/h/d)
Approx. 280 x 128 x 350 mm
Mass Approx. 7.7 kg
Design and specifications are subject to change
without notice.
2
TA-SV7AV
TABLE OF CONTENTS
1. SERVICING NOTES ............................................... 3
2. GENERAL ................................................................... 4
3. DISASSEMBLY
3-1. Disassembly Flow ........................................................... 5
3-2. Cover ............................................................................... 6
3-3. Front Panel Section ......................................................... 6
3-4. Back Panel (2CH/VCD) Section .................................... 7
3-5. FRONT AMP Board ....................................................... 7
4. TEST MODE.............................................................. 8
5. DIAGRAMS
5-1. Note for Printed Wiring Boards
and Schematic Diagrams ................................................ 10
5-2. Printed Wiring Boards – FRONT AMP Section –........ 11
5-3. Schematic Diagram – FRONT AMP Section (1/2) –.... 12
5-4. Schematic Diagram – FRONT AMP Section (2/2) –.... 13
5-5. IC Pin Function Description ........................................... 14
5-6. Printed Wiring Board
– SURROUND AMP Section –...................................... 14
5-7. Schematic Diagram
– SURROUND AMP Section –...................................... 15
5-8. Printed Wiring Boards – CONTROL Section –............ 16
5-9. Schematic Diagram – CONTROL Section –................. 17
5-10. Printed Wiring Boards – POWER Section –................. 18
5-11. Schematic Diagram – POWER Section –..................... 19
6. EXPLODED VIEWS
6-1. Cover Section .................................................................. 20
6-2. Front Panel Section ......................................................... 20
6-3. Chassis Section ............................................................... 21
7. ELECTRICAL PARTS LIST ............................... 22
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED
LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
3
TA-SV7AV
SECTION 1
SERVICING NOTES
This set is a component of the MHC-SV7AV.
The MHC-SV7AV system configuration is as shown below, and
therefore it does not operate normally unless all four components
are connected.
In performing the repair, connect all components with the system
cables.
Note: The precaution to the users is described on the label stuck
on the back panel (Video CD player) and in the troubleshooting
section in the Operation Manual.
System Configuration:
POWER SUPPLY
AC IN
TA
MASTER & GRAPHIC
µ
con
ST
MCE
TC
µ
con
TC
DISPLAY
HTC & VMP
µ
con
MODEL IDENTIFICATION
– Back Panel –
PART No.
Model PART No.
Singapore model 4-233-558-2[]
Saudi Arabia model 4-233-558-3[]
Thailand model 4-233-558-4[]
FRONT AMP BOARD SERVICE POSITION
In checking the FRONT AMP board, prepare jig
(extension cable J-2501-019-A: 1.25 mm Pitch, 25 core, Length
300 mm)
(Fig A)
Turn over the FRONT AMP board with Heat Sink,
SURROUND AMP board and RELAY board connected.
Remove the back panel
(2CH/VCD) section.
Remove the fan motor
connector lead wire.
FRONT AMP board
(CN104)
Connect jig (extension
cable J-2501-019-A
to the FRONT AMP board (CN104)
and PANEL board (CN700).
PANEL board (CN700)
(Fig A)
4
TA-SV7AV SECTION 2
GENERAL This section is extracted from
instruction manual.
A
P
o
O
p
B C
43 5 62 7
980qaqsqdqfqgqhqj
1
Main unit
A/V amplifier
CINEMA STUDIO A–C 3 (9,
28)
DIGITAL 7 (36, 40)
ECHO LEVEL 8 (33)
ENTER/O/o/P/p 2 (11, 13,
15, 17, 21, 25, 26, 30–33, 35)
EQ qs (31)
EQ ON/OFF qd (10, 32)
FILE SELECT qa (27, 28, 32)
FUNCTION 6 (10, 14–17, 24,
25, 34, 36)
MIC 1/2 jacks q; (33)
MIC LEVEL 9 (33)
MULTI CHANNEL DECODING
indicator 4 (29)
PHONES jack qj
PICTURE EFFECT qg (21)
SET UP qf (11, 13, 30, 32, 33)
SUR qh (30)
VOLUME 5
@/1 (power) 1 (9, 10, 22, 40)
Parts Identification
The items are arranged in alphabetical order.
Refer to the pages indicated in parentheses ( ) for details.
x
Mm>.
nNnN
O
V
v
Bb
X
1234 5
wh
wj
wl
ed
ea
6
7
9
8
q;
qa
qdqs
qfqg
qj
qh
qk
ql
wa
w;
ws
wf
wd
wg
wk
es
eg
ej
ek
el
e;
ef
eh
ra
rd
rg
r;
rs
rf
Remote Control
CHECK qd (17)
CLEAR qs (17, 19)
CLOCK/TIMER SELECT 3
(26, 35)
CLOCK/TIMER SET 2 (13, 25,
34)
DBFB ej (27)
DIGITAL r; (36, 40)
DISPLAY rd (13, 18, 33, 40)
D.SKIP 9 (14, 16, 20, 21)
ENTER wf (11, 13, 15, 17, 21,
22, 25, 26, 30–33, 35)
EQ wh (31)
EQ ON/OFF wa (32)
FILE SELECT +/– wd (27, 28,
32)
FUNCTION el (10, 14–17, 24,
25, 34, 36)
GROOVE ek (27)
KARAOKE PON qk (33)
KEY CONTROL / ql (33)
MD rs (36)
Numeric buttons 8 (15, 16, 19,
20, 21)
ON SCREEN wk (18)
PICTURE EFFECT wl (21)
PRESET –/+, PREV/NEXT ea
(14, 15, 20, 22)
REPEAT q; (15, 16)
RETURN O eg (15)
PLAY MODE qa (14, 16, 17, 25)
SELECT CD N es (14–17, 19,
21)
SET UP w; (11, 13, 30, 32, 33)
SLEEP 1 (34)
SPECIAL MENU e; (19, 20, 21)
SPECTRUM ANALYZER rf
(33)
SUR wj (30)
TAPE A nN ef (23)
TAPE B nN qf (23, 24)
TUNER/BAND ed (22)
TUNING –/+ qh (22)
TV CH +/– 7 (10)
TV VOL +/– 6 (10)
TV @/1 4 (10)
TV/VIDEO rg (10)
VIDEO ra (36)
VOL +/– ws
BUTTON DESCRIPTIONS
@/1 (power) 5
X (pause) qj
x (stop) qg
./> (go back/go forward)
ea
m/M (rewind/fast forward)
qh
O/o/P/p wg
>10 eh
5
TA-SV7AV
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
3-2. COVER
(Page 6)
3-3. FRONT PANEL SECTION
(Page 6) 3-4. BACK PANEL (2CH/VCD) SECTION
(Page 7)
3-5. FRONT AMP BOARD
(Page 7)
SET
Note 1: The process described in can be performed in any order.
Note 2: Without completing the process described in , the next process can not be performed.
6
TA-SV7AV
3-3. FRONT PANEL SECTION
Note: Follow the disassembly procedure in the numerical order given.
3-2. COVER
2
two screws
(case 3 TP2)
2
two screws
(case 3 TP2
)
1
three screws
(BVTT3
×
6)
4
Remove the cover
in the direction of arrow
A
.
A
3
3
4
three screws
(BVTP3
×
8)
2
screw
(BVTP3
×
8)
6
front panel section
5
two
claws
5
two claws
5
claw
3
lug
1
wire (flat type) (25 core) (CN104)
3
lug
3
lug
2
screw
(BVTP3
×
8)
2
screw
(BVTP3
×
8
)
7
TA-SV7AV
3-4. BACK PANEL (2CH/VCD) SECTION
3-5. FRONT AMP BOARD
5
three screws
(BVTP3
×
8)
5
four screws
(BVTP3
×
8)
5
four screws
(BVTP3
×
8
)
4
RELAY board
3
two connectors
(CN106, 113)
6
connector
(CN105)
7
three connectors
(CN901, 902, 903)
1
screw
(BVTP3
×
8)
8
back panel (2CH/VCD)
section
6
1
screw
(BVTP3
×
8)
2
lug
2
screw
(BVTP3
×
8)
5
screw
(BVTP3
×
8)
4
two screws
(BVTT3
×
8)
3
bracket (PWB)
6
lug
8
Remove the FRONT AMP boar
d
in the direction of the arrow.
7
PC board holder
1
three connector
(CN913, 914, 915)
7
PC board holder
8
TA-SV7AV
[GC Test Mode]
Enter the GC Test Mode
Procedure 1:
1. Press the I/1button to turn the power on.
2. While pressing the both [STEREO/MONO] *1 and [CINEMA
STUDIO C] buttons, press the [CLOCK/TIMER] *1 button.
3. LEDs and fluorescent indicator tube are all turned on of all
units.
Procedure 2:
1. Press the I/1button to turn the power on.
2. While pressing the both [PLAY MODE] *2 and x*2 buttons,
press the Z (DISC 1) *2 button.
3. LEDs and fluorescent indicator tube are all turned on of all
units.
Version Display Mode
Procedure:
1. Enter the GC test mode.
2. Each time the [TUNER MEMORY] *1 or [DISC 1] *2 button is
pressed, microcomputer or mechanism deck version is dis-
played of each unit.
3. Press the [TUNING +] *1 or [DISC 3] *2 button to detail is
displayed the version.
Key Check Mode
Procedure:
1. Enter the GC test mode.
2. Press the [TUNING --] *1 or [DISC 2] *2 button to set the key
check mode.
3. In the key check mode, the fluorescent indicator tube displays
“K 0 J 0 V 0”. Each time a button is pressed, “K” value in-
creases. However, once a button is pressed, it is no longer taken
into account.
“J” value increases like 1, 2, 3 ... if turn the [FILE SELECT]
knob clockwise, or it decreases like 0, 9, 8 ... if turn the JOG
dial counterclockwise.
“V” value increases like 1, 2, 3 ... if turn the [VOLUME] knob
clockwise, or it decreases like 0, 9, 8 ... if turn the JOG dial
counterclockwise.
Releasing the GC Test Mode
To release from this mode, press three buttons in the same manner
as entering this mode or disconnect the power cord.
SECTION 4
TEST MODE
Note: Use following buttons in the test mode.
no mark : Button of amplifier unit (TA-SV7AV)
*1 : Button of tuner unit (ST-SV7)
*2 : Button of CD unit (MCE-SV7)
[MC Test Mode]
Enter the MC Test Mode
1. Press the I/1button to turn the power on.
2. While pressing the both [STEREO/MONO] *1 and [CINEMA
STUDIO C] buttons, press the [CINEMA STUDIO A] button.
3. “GROOVE” indication blinks on the fluorescent indicator tube
in the midst of MC test mode.
4. This mode has two modes (mode 1/mode 2).
5. To change the modes, press three buttons in the same manner
as entering this mode (step 2). Each time the step 2 operation
is repeated, it changes modes alternately.
6. To distinguish the mode, turn the [VOLUME] knob clockwise
or counterclockwise. Then display is shown as follows.
Mode 1: only “MIN” or “MAX”
Mode 2: “MIN”, “1 to 30” or “MAX”
AMP Test Mode
In the AMP test mode, it operates as follows.
•[VOLUME] knob is turned, it changes display as follows.
Counterclockwise : VOLUME MIN
Clockwise : VOLUME MAX
•[FILE SELECT] knob is turned, it changes speaker output mode
as follows.
Display of each mode:
Details of each mode:
Mode 1 : L-CH: front L-CH
R-CH: front R-CH
Mode 2 : L-CH: rear L-CH
R-CH: rear R-CH
Mode 3 : L-CH: front L-CH, rear L-CH, center
R-CH: front R-CH, rear R-CH, sub woofer
(no LFE, “EQ” indication does not light up on the fluorescent
indicator tube of tuner unit)
Mode 4 : L-CH: front L-CH, rear L-CH, center
R-CH: front R-CH, rear R-CH, sub woofer
(LFE on, “EQ” indication lights up on the fluorescent indica-
tor tube of tuner unit)
Mode 5 : L-CH: center
R-CH: sub woofer
Releasing the MC Test Mode
To release from this mode, press the I/1button or disconnect the
power cord.
Mode No. Display
1 L: L R: R
2 L: SL R: SR
3 L: LSLC R: RSRW
4 L: LSLC R: RSRW
5 L: C R: W
9
TA-SV7AV
MEMO
10
TA-SV7AV SECTION 5
DIAGRAMS
5-1. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
B
These are omitted.
CE
Q
Note on Printed Wiring Boards:
•X: parts extracted from the component side.
•Y: parts extracted from the conductor side.
•f: internal component.
•: Pattern from the side which enables seeing.
• Indication of transistor.
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and 1/4 W or less unless otherwise
specified.
•f: internal component.
•2: nonflammable resistor.
•5: fusible resistor.
•C: panel designation.
•A: B+ Line.
•B: B– Line.
• Voltages are dc with respect to ground under no-signal
conditions.
no mark : Power on
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Signal path.
F: AUDIO
N: MIC
• Abbreviation
EA : Saudi Arabia model
SP : Singapore model
TH : Thailand model
Note: The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
• Circuit Boards Location
AC OUTPUT board
SURROUND AMP board
SUB TRANS board
AC INPUT board
RELAY boar
d
FRONT AMP board
PANEL board
TA-SV7AV
1111
5-2. PRINTED WIRING BOARDS – FRONT AMP Section – • See page 10 for Circuit Boards Location.
TM101
TM102
NO109
CN113
JW142
CN103
IC801
CN108
D911
D951
JW49
JW12
C951
C952
C927
C953
R952
IC924
LP902
CN105
CN104
JW150
JW71
C861
C955C912
C911
C956
JW3
R951
JW139
R953
JW143
JW138
R954
EPT901
JW141
D881
R835
R831
R815
JW179
JW108
Q871
Q881
R883
R885
R974
R887
R839
R837
R838
JW39
RY881
JW26
R896
R814
C837
D831
C854
JW163
JW30
R894
JW148
C987
C916
C917
R889
D998
D993
D991
D992
D990
C991
C1100
D923
JW28
Q894
JW187
JW196
R907
C857
JW40
C1103
JW197
R911
R903
Q893
Q897R897C893
R906
R898
Q895
JW2
Q892
R895
JW123
JW95
R804
R807
JW78
Q891
Q896
Q851
JW115
JW113
D994 D995
D997
D996
D924
C994
C925
CN107
JW41
JW116
JW182
JW16
JW15
R908
D980
C1101
R881
C863
JW183
JW38
JW101
CN106
R904
JW177
Q821
C891
R826
R876
JW198
R825
C993
R875
C992
JW20
JW44
R821
C821
JW186
JW17
R910
C871
JW120
R827
R877
R878
D871
R879
R880
C872
JW74
JW18
JW126
JW165
C919
C920
JW180
JW160
JW159
R917
JW155
JW157
R918
JW50
JW161
R914
JW154
R913
R916
JW84
R923
JW158
R919
R920
JW173
JW156
JW195
R921
JW6
JW164
JW190
JW134
JW127
JW105
JW169
JW85
JW104
JW103
R857
JW107
JW100
JW61
R963
R964
JW59
R805
R968
JW48
R851
C852
R852
C962
JW184
Q902
C853
R801
C802
R802
C801
D801
R803
C803
JW42
JW52
C941
C806
C851
C963
R966
C892
R965
D963
JW82
JW87
JW86
JW89
JW90
JW91
JW92
JW93
JW94
JW96
Q883
R973
R809
R972
Q962
R971
R970
R969
Q963
EPT902
JW56
JW176
R925
JW174
JW175
JW172
JW153
JW27
NO101
JW136
JW162
JW135
JW13
JW73
R871
C1036
JW192
R855
JW68
JW140
Q961
JW72
JW102
C807
JW60
D802
JW133
JW117
JW106
R854
Q903
JW99
R967
JW81
JW66
JW51
JW114
C918
C804
JW131
R924
R926
R830
Q822
D821
JW130
R927
JW128
R856
D851
D973
JW55
C856
D975
R892
Q801
R808
R859
R806
JW65
C811
JW63
JW57
C812
R905
D970
D972
D971
JW185
JW191
D974
JW7
JW10
JW11
JW147
JW9
C964
R853
C862
C865
JW29
JW69
JW152
JW80
JW58
JW19
JW181
JW31
C914
C926
R858
JW8
JW53
JW193
JW67
JW111
R891
JW88
JW146
JW881
JW62
JW149
JW122
JW35
R915
R912
JW170
JW97
JW64
D981
C915
JW151
JW36
JW1
JW54
C864
JW75
C1037
JW83
JW119
JW145
JW132
C924
JW79
D925
JW194
JW21
JW76
JW32
JW70
C1102
JW22
JW178
JW166
JW43
C954
JW45
JW37
R991
JW47
JW46
JW189
D926 R992
JW34
JW167
C990
JW188
JW98
Q904
JW125
C961
JW168
NO102
JW199
IC310
IC923
CN110
CN111 CN112
JW602
JW603
JW601
R836
C809
C833
R833
L832
C836
C831
C835
L833
R834
C832
C834
L831
R862
C859
C808
L811
L861
R861
C858
R832
R811
FRONT AMP BOARD
EE
31
31
15
–+
–+
–+
L
L
R
CENTER SPEAKER
IMPEDANCE
USE 8 – 16Ω
REAR SPEAKER
IMPEDANCE
USE 8 – 16Ω
–+
–+
R
FRONT SPEAKER
IMPEDANCE
USE 6 – 16Ω
SYSTEM CONTROL 1
FROM ST-SV7
A
SUB TRANS
BOARD
CN903
E
71
13
EE
E
M
M1
(FAN)
E
AC OUTPUT
BOARD
CN915
F
AC OUTPUT
BOARD
CN914
E
EE
E
E
E
E
E
EEE
E
E
(CHASSIS)
13 1 14
H
SURROUND AMP
BOARD
CN1002
J
SURROUND AMP
BOARD
CN1003
1-680-749-
D
PANEL BOARD
CN700
G
AC OUTPUT
BOARD
CN113
16
(CHASSIS)
SYSTEM CONTROL 2
FROM ST-SV7
RELAY BOARD
1-680-755-
2
1
21
A
B
C
D
E
F
G
H
I
J
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
11
(21)
11
(21)
(CHASSIS)
CLP1001
D801 H-7
D802 G-7
D821 I-10
D831 D-3
D851 H-7
D871 I-11
D881 D-3
D911 B-10
D923 H-3
D924 G-2
D925 G-2
D926 G-2
D951 B-12
D963 I-6
D970 H-3
D971 I-3
D972 I-4
D973 H-4
D974 H-3
D975 H-3
D980 J-2
D981 F-3
D990 H-2
D991 H-2
D992 H-2
D993 H-2
D994 H-3
D995 H-3
D996 H-3
D997 H-3
IC310 H-10
IC801 H-5
IC923 F-3
IC924 F-2
Q801 H-7
Q821 I-10
Q822 I-10
Q851 G-7
Q871 I-11
Q881 D-3
Ref. No. Location
Ref. No. Location
• Semiconductor Location
Ref. No. Location Ref. No. Location
Q883 D-3
Q891 H-9
Q892 H-9
Q893 H-10
Q894 G-9
Q895 G-9
Q896 H-9
Q897 G-9
Q902 J-3
Q903 J-3
Q904 J-4
Q961 H-7
Q962 H-4
Q963 G-4
(Page 18)
(Page 18)
(Page 14) (Page 14)
(Page
16)
(Page 18)
(Page 18)
TA-SV7AV
1212
TP205
TP203
TP201
TP199
TP202
TP204
TP200
TP198
TP197
TP196
TP195
TP194
TP193
TP192
TP191
TP190
TP189
TP188
TP187
TP186
TP185
TP184
TP183
TP182
TP181
TP180
TP179
TP178
TP176
TP177
TP175
TP174
TP173
TP172
TP171
TP170
TP169
TP168
TP165
TP164
TP163
TP162
TP158
TP157
TP156
TP155
TP154
TP153
TP152
TP151
TP150
TP149
TP148
TP147
TP146
TP145
TP144
TP143
TP142
TP159
TP160
TP161
TP141
C1100
C1102
C1101
C927
R919
R920
R918
R917
R912
R911
R913
R915
R921
R914
R916
R923
IC923 D994D995
D997 D996
D923
C992
D990D991
D993 D992
C993
D924
IC924
C994
C990
C991
C925
C926
D980
D981
C1103
D972
D971
D970
D973
D974
D975
CN107
NO109
CN106
CN105
TP166
TP167
R905
R904
R903
R907
R906
D821
Q822
C872 R880 R878
R825
R875
R826
R876
C871
R877
C924
TP251
TP250
C917
C916
C920
C918
C919
R992
R991
R908 C914
D925
D926
TP256 R910
TP255
TP252
TP253
R927
R926
R925
R924
TP254
C915
CN113
D998
R830
C821
R879 D871 R827
Q821
Q871
C941
Q904
CN112
CN111
CN110
IC310
Q903
Q902
CLP1001
CN104
R821
R871
M1
0.1
0.1
0.1
100
10V
330
330
330
330
100
100
47k
47k
330
100
100
1k
NJM78L12A-T3 11ES2-NTA2
B
11ES2-NTA2
B
11ES2-NTA2
B
11ES2-NTA2
B
11ES2
0.1
11ES2-NTA2
B
11ES2-NTA2
B
11ES2-NTA2
B
11ES2-NTA2
B
470
16V
11ES2
NJM78L05A-T3
220
10V
0.1
330
25V
10
50V
100
16V
11ES2-NTA2
B
11ES2-NTA2
B
0.1
11ES2-NTA2B
11ES2-NTA2B
11ES2-NTA2B
11ES2-NTA2B
11ES2-NTA2B
11ES2-NTA2B
20P
5P
14P
3P
2.2k
100k
10k
2.2k
1k
1SS133T-72
BN1F4M
0.47
50V 1M 4.7k
56
56
1k
1k
4.7
100V
22k
0.001
100p
100p
0.1
0.1
10
50V
1k
1k
2.2k 1
50V
1SS133T
-72
1SS133T
-72
100
47k
10k
47k
47k
100p
5P
4.7
100V
100k 1SS133T-72 22k
2SC2878
2SC2878
0.1
2SC2001
5P
14P
19P
PT8300-S
2SB1116
2SC2785
25P
680
2W
680
2W
(FAN)
1
2
3
4
6
7
8
9
10
11
VOL-A
VOL-A
VOL-B
KEY0
KEY0
PWR-KEY
PWR-KEY
CLK
LAT
VOL-B
LAT
CLK
JOG1-B
JOG1-A
JOG2-B
JOG2-A
JOG2-B
JOG2-A
JOG1-B
JOG1-A
MIC-SIG
MIC-SIG
AC1
AC2
RE
RE
AC1
AC2
Z1
Z2
Z3
Z4
Z5
Z6
Z7
Z2
Z3
Z10
Z10
Y6
Y7
Y8
X1
X2
X3
X4
X5
X6
X7
X1
X2
X3
X4
X5
X6
X7
X8
X8
X9
X10
X10
X11
X12
X13D-I
D-I
D-O
D-O
T1
T2
T3
T4
Z3
Z2
KEY0 TA
POWER KEY
FRONT-GND
CENTER-GND
MIC-SIG
MIC-GND
S-GND
DBFB FEEDBACK
EXP-CLK
EXP-LAT
EXP-OUT DATA
EXP-IN DATA
LED-BLUE
VOL3-A
VOL3-B
HP-SW
HP-L
HP-R
D GND
HP-GND
POWER KEY
KEY0
LED-POWER
LED-SUR
LED-EQ
LED-DCS_A
LED-DCS_B
LED-DCS_C
JOG1-A
JOG1-B
JOG2-A
JOG2-B
STBY RELAY
RELAY-UNREG
DGND
SUB-AC
SUB-AC
FAN+
FAN-
VF
VF
VOLA
VOLB
D-GND
AC LOW
AC LOW
AC HIGH
AC HIGH
VP
CT
EVER+5V
M(A)-GND
CT
AGND for BLUE LED
SR-IN
SL-IN
CENTER-IN
FR-IN
FL-IN
JOG2-B(FIELD SELECT)
JOG2-A(FIELD SELECT)
JOG1-B(FUNCTION)
JOG1-A(FUNCTION)
REG GND
D+5.7V
CHASSIS
MIC
EVER+5V
MIC GND
+12V
(1/2)
SYSTEM CONTROL 1
Q902,903
FAN MOTOR
DRIVE
NC
REGULATOR
O
G
I
O
G
I
+12V REGULATOR
SYSTEM
CONTROLLER
MUTING
CONTROL
MUTING
Q821,871
+5.6V REGULATOR
KEY0 TA
POWER KEY
FRONT-GND
CENTER-OUT
CENTER-GND
MIC-SIG
MIC-GND
FR-OUT
FL-OUT
SR-OUT
SL-OUT
S-GND
DBFB FEEDBACK
EXP-CLK
EXP-LAT
EXP-OUT DATA
EXP-IN DATA
KEY0 TA
POWER KEY
FRONT-GND
CENTER-GND
MIC-SIG
MIC-GND
S-GND
DBFB FEEDBACK
EXP-CLK
EXP-LAT
EXP-OUT DATA
EXP-IN DATA
CHASSIS CHASSIS
SR-IN
SL-IN
CENTER-IN
FR-IN
FL-IN
SYSTEM CONTROL 2
NC
(CHASSIS)
FROM ST-SV7
FROM ST-SV7
5-3. SCHEMATIC DIAGRAM – FRONT AMP Section (1/2) –
(Page 19)
(Page 17)
(Page 13)
TA-SV7AV
1313
TP107
TP106
TP105
TP104
TP103
TP102
TP101
TP108
TP109
TP110
TP111
TP112
TP113
TP114
TP115
TP116
TP117
TP118
TP119
TP120
TP121
TP122
TP123
TP140
TP139
TP138
TP137
TP136
TP135
TP134
TP133
TP132
TP131
TP130
TP129
TP128
NO101
C987 EPT901
EPT902
TP127
TP126
TP125
TP124
R814R815
RY881
D802
R892R891
C891
C837
D831
R894
C892
R895
R896
Q895
Q896
R898
Q897
Q894
R897
C893
R968
R963R964
C962 C961
R806
R807
D801
R808
R804
C807
C806
R809
C857
C856
R859
R858
R857
D851
R854
R856
R802C802
C852 R852 C812
C853
C803
R851
C811
R801
NO102
JW881
C801
R803
C804
C854
R853
C851
Q961
R966
C963
R965
D963
R967
R973 R974
Q963
R971
R972
R969
C964
R970
R889
R953 R951
R954 R952 C809 0.1
C808 0.1
C858
0.1
C859
0.1
R811 10 1/2W
L811
L861
R861 10 1/2W
R812
10
1/2W
R862
10
1/2W
C951 C953
C954C952
D911
D951
C911
C912
C955
C956
TM101
D881
C862C861
R887
R883
R885
Q881
R838
R837
R839
JW26
JW27
C863
C865
C864
TM102
CN103
CN108
IC801
R881
R805
R855
Q962
Q883
Q891Q892
Q893
Q851
Q801
R833 10 1/2W
R831 10 1/2W
R835 10 1/2W
7P
0.1
47k47k
1SS133T
-72
68k56k
100
10V
4.7
50V
1SS133T-72
10k
2.2
50V
10k
33k
2SC2785
2SC2785
4.7k
2SC2785
2SC2785
22k
100
10V
1
100100
100
100V
100
100V
1k
15k
1SS133T-72
100k
56k
0.068
0.068
10
1/2W
0.068
0.068
10
1/2W
100k
15k
1/4W
1SS133T-72
56k
1k
56k220p
220p 56k 0.01
100p
100p
1k
0.01
1k
6P
4.7
50V
270
47
10V
47
10V
270
4.7
50V
2SC1841
33k
100
10V
15k
1SS133T-72
10k
2.2k 10k
2SC1841
2.2k
22k
22k
47
50V
100k
10k
100k 100k
100k 100k
3300
63V
3300
50V
3300
50V
3300
63V
D5SBA20
D5SBA20
0.1
100V
0.1
100V
0.1
0.1
4P
1SS133T-72
0.010.01
100k
47k
10k
2SA1175
47k
47k
47k
0.01
0.01
0.01
6P
13P
4P
STK402-120S
220
2W
0.22/0.22
5W
0.22/0.22
5W
2SA988
2SC2785
2SC27852SC2785
2SA1175
2SC2785
2SC2785
1
2
3
4
6
7
8
9
10
11
Z1
Z2
Z3
Z4
Z5
Z6
Z7
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y1
Y2
Y3
Y4 Y5
Y8
Y9
Y10
Y11
Y9
Y10
Y11
X9
X12
T1
T2
T4
Y5
X13
T3
X11
OVERLOAD DETECT
+VL
GND
-VL
REAR L-OUT
REAR GND
REAR R-OUT
CENTER GND
CENTER OUT
SURROUND RY
DC DET
PROTECT
REAR L-IN
REAR GND
REAR R-IN
CENTER GND
CENTER IN
AC1
AC1
AC1-GND
VF
VF
VP
AC4(HIGH)
AC4(HIGH)
AC3(LOW)
AC3(LOW)
AC2
AC2
AC2-GND
L-GND
R-GND
L-CH
R-CH
REAR L-CH
REAR R-CH
CENTER
RR-GND
RL-GND
C-GND
(CHASSIS)
(CHASSIS)
(CHASSIS)
(CHASSIS)
(CHASSIS)
(2/2)
POWER AMP
AMP ON
SWITCH
Q894-897
PROTECTOR
PROTECT
DETECT
Q891,892
DC DETECT
DETECT
OVER LOAD
DETECT
OVER LOAD
Q962,963
AMP ON/OFF
CONTROL
Q881,883
RELAY DRIVE
(CHASSIS)
L
R
IMPEDANCE
USE 6-16Ω
FRONT SPEAKER
L
R
IMPEDANCE
REAR SPEAKER
USE 8-16Ω
IMPEDANCE
USE 8-16Ω
CENTER SPEAKER
(CHASSIS)
L832
L831
L833
R836
10
1/2W
R834
10
1/2W
C833
0.1
C834
0.1
R832
10
1/2W
C831
0.1
C832
0.1
C836
0.1
C835
0.1
5-4. SCHEMATIC DIAGRAM – FRONT AMP Section (2/2) –
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
(Page 12)
(Page 15)
(Page 15)
(Page 19)
(Page 19)
(Page 19)
TA-SV7AV
1414
5-6. PRINTED WIRING BOARD – SURROUND AMP Section – • See page 10 for Circuit Boards Location.5-5. IC PIN FUNCTION DESCRIPTION
JW1003
C1087
C1053
JW1002
IC1001
C1052
C1003
C1084
C1054
C1004
JW1015
JW1014
JW1013
JW1012
JW1011
JW1005
C1034
JW1007
R1055
RY1062
R1032
R1031
R1092
C1033
JW1008
R1033
Q1081
D1081
C1086
JW1006
R1088
R1087
R1086
CN1002
D1062
R1062
R1005
R1085
RY1061
JW1001
C1051
R1081
CN1003
R1047
Q1093
R1059
JW1018
R1004
R1051
THP092
R1052
R1003
JW1004
R1008
JW1017
R1089
Q1063
R1063
R1001
Q1061
JW1009
R1009
R1006
R1007
R1056
R1061
JW1019
R1093
JW1010
R1095
R1090
JW1016
R1057
R1058
R1054
R1060
D1002
C1083
R1094
R1082
Q1092
C1056 C1057
C1006
C1007
D1051
D1001
Q1051
Q1001
JW1021
R1010
D1061
R1083
C1001
JW1020
C1081
R1084
R1065
R1053
R1002
C1082
R1069
C1002
C1038
C1039
CLP1000
SURROUND AMP BOARD
1-680-750-
13 1 41
EE
E
E
E
E
E
H
FRONT AMP
BOARD
CN103 J
FRONT AMP
BOARD
CN108
A
B
C
D
1 2 3 4 5
11
(21)
(CHASSIS)
• Semiconductor
Location
Ref. No. Location
D1001 B-3
D1002 C-5
D1051 B-3
D1061 B-4
D1062 C-2
D1081 D-2
IC1001 B-1
Q1001 B-3
Q1051 B-3
Q1061 C-5
Q1063 D-5
Q1081 D-1
Q1092 A-4
Q1093 A-4
• FRONT AMP BOARD IC310 PT8300-S (SYSTEM CONTROLLER)
Pin No. Pin Name I/O Description
1 VSS — Ground terminal
2RESET_B I Reset signal input terminal Not used
3CLK I Serial data transfer clock signal input from the tuner unit (ST-SV7)
4LATCH I Serial data latch pulse input from the tuner unit (ST-SV7)
5LED C O LED drive signal output of the CINEMA STUDIO C indicator (D706) “L”: LED on
6LED B O LED drive signal output of the CINEMA STUDIO B indicator (D705) “L”: LED on
7LED A O LED drive signal output of the CINEMA STUDIO A indicator (D704) “L”: LED on
8LED EQ O LED drive signal output of the EQ indicator (D703) “L”: LED on
9LED SUR O LED drive signal output of the SUR indicator (D702) “L”: LED on
10 LED BLU O LED drive signal output of the MULTI CHANNEL DECODING indicator (D781)
“L”: LED on
11 HP SW I Headphone detection signal input terminal “H”: headphone on
12 PROTECT I Over load detection signal input for speaker output “L”: over load
13 LATCHO O Serial data latch pulse output terminal Not used (open)
14 CLKO O Serial data transfer clock signal output terminal Not used (open)
15 — — Not used (open)
16 — — Not used (fixed at “L”)
17 — — Not used (open)
18 MUTING O Muting on/off control signal output terminal “L”: muting
19 LED PW O LED drive signal output of the I/1 indicator (D701) “L”: LED on
20 SUR RY O Relay drive signal output for the surround speaker (rear and center) protection “H”: on
21 F RY O Relay drive signal output for the front speaker protection “H”: on
22 STK PW O Power amplifier on/off selection signal output terminal “L”: standby, “H”: on
23 — — Not used (open)
24 STBY RY O Standby relay drive signal output terminal “L”: standby, “H”: power on
25 DATA OUT O Serial data output to the tuner unit (ST-SV7)
26 DATA IN I Serial data input from the tuner unit (ST-SV7)
27 PULLUP — Not used (open)
28 VCC — Power supply terminal (+5V)
(Page 11) (Page 11)
TA-SV7AV
1515
5-7. SCHEMATIC DIAGRAM – SURROUND AMP Section –
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
(Page 13)
(Page 13)
D1061
RY1061
R1009
R1059
C1056
C1057
C1033 C1034
R1047
R1031
R1032
R1004
R1084
R1054
C1003
R1002C1002
R1052C1052
C1083
R1082C1082
R1051
R1081
R1001
CN1003
R1006
R1007
D1001
D1051 R1058
R1057
R1056
R1086
R1087
D1081
R1088
C1087
C1086
R1089
D1062
RY1062
Q1063
R1063
Q1061
R1010
R1060
R1090 D1002
CN1002
R1092
R1095
Q1093
R1093R1094
R1005
R1055
R1085
R1008
R1065
R1062
R1061
C1001
C1004
C1054
C1051
C1081
C1084
C1053
R1083
R1069
IC1001
Q1092
Q1001
Q1051
Q1081
C1038C1039
CLP1000
R1003
R1053
C1006
C1007
THP092
R1033
1SS133T
10
1/2W
10
1/2W
0.068
0.068
100
50V
100
50V
10k
100
100
56k
56k
56k
100p
56k220p
56k220p
100p
56k220p
1k
1k
1k
4P
1k
15k
1SS133T
1SS133T 100k
15k
1k
1k
15k
1SS133T
100k
0.068
0.068
10
1/2W
1SS133T
BA1F4M
10k
2SA1175-HFE
47k
56k
68k
1SS133T
13P
100k
22k
2SC2785
100k68k
0.22
2W
0.22 2W
0.22 2W
100k
22k
220
2W
220
2W
10
50V
47
10V
47
10V
10
50V
10
50V
47
10V
100p
1.3k
STK443-050
2SC2785
2SC2785
2SC2785
2SC2785
0.010.01
0.068
0.068
1
A1
A2
A3
A1
A2
A3
*
*
REAR L-OUT
REAR R-OUT
CENTER OUT
SURROUND RY
PROTECT
DC DET
REAR L-IN
REAR GND
REAR R-IN
CENTER GND
CENTER IN
GND
OVERLOAD DETTECT
-VL
+VL
REAR GND
CENTER GND
Q1092,1093
THERMAL DETECT
OVER
DETECT
LOAD
OVER
DETECT
LOAD
Q1061,1063
RELAY DRIVE
OVER
DETECT
LOAD
POWER AMP
(CHASSIS)
*
R1003,1053
680
1k
(EA,SP)
(TH)
TA-SV7AV
1616
D701 B-11
D702 C-10
D703 C-8
D704 B-8
D705 B-7
D706 B-6
D710 B-3
D781 A-6
IC701 B-3
IC702 C-3
Q701 C-6
Q702 C-6
Q710 C-3
5-8. PRINTED WIRING BOARDS – CONTROL Section –• See page 10 for Circuit Boards Location.
JW504
JW503
R713
S711
S712
S713
S718
J703
S719
S714 S705
R712
S715
D706 D701
S710
D705
CN700
NO780
C735
IC702
IC701
NO711
JW522
R710
C710
Q701
R707
R708
JW505
FB704
C712
FB707
NO750
R736
C726
C711
R728
C723
C724
R729
R731
R730
C725
C729
R732
C727
C734
R735
C730
C733
JW508
C728
C732
C751
C705
CLP702
Q710
R737
C731
R740
R738 R711
CLP701
R739
C702
C701
C703
C704
C706 Q702
JW509
NO710
R733
R715
R709
JW517
R714
R721
R716
R717
R718R719
D704
JW521
R720
JW520
JW524
JW512
JW514
JW510
JW515 JW511
R734
FB703
FB708
FB702
JW502 FB705
FB706
D702
JW518
JW507
JW506
JW705
S723
JW513
JW704
JW501
JW525
D703
JW519
C752
JW516
CLP703
RV761 RV762
NO761
D781
R724
NO781
C781
5
4
8
1
C741
C745 C746
C748
R751 R750
C743
R744
R745
R743
C747C738
C740
C744
R747
D710
R746
C739
R742
C750
C737
C749
R749
C742
1
7
814
R748
2
4
5
3
16
7
2
4
5
3
16
7
R727
C722R726
C721
C736
FB701
R741
R722
S717
7
J701 – 703
6
3
2
4
5
1
PANEL BOARD
E
21
E
FUNCTION
DIGITAL
MIC 2
J702
MIC 1
J701
(CHASSIS)
S703
ROTARY ENCODER
13
VOLUME
S702
ROTARY ENCODER
13
FILE SELECT
EQ
ENTER
SUR
v
V
b
B
EQ ON/OFF SET UP
PHONES
S701
ROTARY ENCODER
13
DFRONT AMP
BOARD
CN104
(CHASSIS)
CINEMA STUDIO
B
D705, S713
CINEMA
STUDIO
C
D706, S714
CINEMA STUDIO
A
D704, S712
D703, S711
13
13
D702, S710
I/1
D701, S705
1-680-754-
11
(21)
(CHASSIS)
MIC LEVEL ECHO LEVEL
51
51
21
MULTI CHANNEL
DECODING
A
B
C
D
E
F
1 2 3 4 5 6 7 8 9 10 11
EFFECT
2
4
3
1
67
5
•Semiconductor
Location
Ref. No. Location
(Page 11)
OSCILLATOR
1/2 VCC
AUTO
RESET
LPF1
MAIN
CONTROL
A/D
20KBIT
SRAM
LPF2
D/A
12 3 45 6 7
89
10
14 13 12 11
CLOCK
RESET
MO
MI
D1 DO0
DO1
VCC
CLOCK
REF
OP2IN
OP2OUT
LPF2IN
LPF2OUT
LPF1IN
LPF1OUT
OP1OUT
OP1IN
CC1
CC2
GND
•IC Block Diagram
– PANEL BOARD –
IC701 M65850P
TA-SV7AV
1717
C781
S723
S718S719S715S714S713S712S710 S711
S705
D706D705D704D703D702
D701
FB707
D781
S701 S702 S703
RV761
Q710
R735
C731
R736
R738
C732
R739
R740
R737
C735
C729C728
R732
R734
C734
C726
C724
FB702
R729
C751CLP701
R728 C723
FB703
C733
R731R730C725
R733
FB706
FB705
FB704
C710
C712
CLP702
J703
JW704
R708
Q702
NO780 NO781
Q701
JW705FB708
NO711
NO710
R716 R717 R718 R719
C701
C702
C703
C704 C705 C706
R707
R721R720R715R714R713R712R711R710R709
IC702(1/2)
IC702(2/2)
S717
R722
CN700
C721
R726
C722R727
FB701
J701
J702
RV762
NO761
C711
NO750
R741
C736
R747
C750
R748
C749
C744
R749
C737
C738
D710
C741
C740
C742 R743
R745
R744
C743
R746
R751R750
C746
C747
C748
C745
C752
R742
C739
C730
C727
IC701
0.01
SEL5923ASEL5923ASEL5923ASEL5923ASEL5923A
SEL5223S
-TP15
0 H
SEL5E20C
50k
2SC2785
150k
2.2
50V 100
10k
100
10V
10k
100k
1k
10
16V
2.2
50V
0.1
50V
22k
10k
47p
47p
0.22
50V
1k
0.01
10k 0.01 10
16V
1k100k1000p
100
0.001
0.001
100
BN1F4M
2P 2P
BA1A4M
3P
3P
2.2k 2.7k 3.9k 5.6k
0.01
0.01
0.01
0.01 0.01 0.01
330
15k8.2k1.5k1.2k1k820560470270
NJM4580D
NJM4580D
27k
25P
0.22
50V 1k
0.0110k
50k
5P
0.01
5P
15k
2.2
50V
120k
1
50V
22k
0.0068
0.15
47k
0.022
0.0068
MTZJ-T-72-5.1B
47
10V
47 10V
0.068 22k
22k
22k
0.001
270
22k22k
0.47
50V
0.068
0.001
47 50V
10
16V
15k
1
50V
270p
470p
M65850P
LED-POWER
LED-SUR
LED-EQ
LED-DCS_A
LED-DCS_B
LED-DCS_C
LED-BLUE
LED-POWER
LED-SUR
LED-EQ
LED-DCS_A
LED-DCS_B
LED-DCS_C
LED-BLUE
A1
A2
A3
A4
A5
A6
A8
A9
A5
A4
A3
A2
A1
A6
A8
A9
LED-BLUE
VOL3-A
VOL3-B
HP-SW
HP-L
HP-R
D GND
HP-GND
POWER KEY
KEY0
LED-POWER
LED-SUR
LED-EQ
LED-DCS_A
LED-DCS_B
LED-DCS_C
JOG1-A
JOG1-B
JOG2-A
JOG2-B
SET UPEQ ON/OFF
AGND for BULUE LED
MIC
A GND
EVER+5V
+12V
ENTER
DIGITALCBAEQSUR
CINEMA
STUDIO
CINEMA
STUDIO
C
CINEMA
STUDIO
CINEMA
STUDIO
BA
EQSUR
Q701,702
LED DRIVE
DECODING
MULTI CHANNEL
GND
GND
GND
2A
2B
1B
1A
3A
3B
FUNCTION FILE SELECT VOLUME
ROTARY ENCODERROTARY ENCODERROTARY ENCODER
PHONES
MIC LEVEL
REGULATOR
MIC AMP
(CHASSIS)
(CHASSIS)
3
2
4
1
5
6
8
7
EFFECT
MIC2
MIC1
ECHO LEVEL
OP2OUT
VCC
CLOCK
REF
OP2IN
LPF2IN
LPF2OUT
GND
CC2
CC1
OP1IN
OP1OUT
LPF1OUT
LPF1IN
DIGITAL
ECHO
5-9. SCHEMATIC DIAGRAM – CONTROL Section –• See page 16 for IC Block Diagram.
(Page 12)
TA-SV7AV
1818
5-10. PRINTED WIRING BOARDS – POWER Section –• See page 10 for Circuit Boards Location.
JW906
F913
JW901
CN913
CN915
F934
JW961
F933 F932 F931 F937
CN914
JW938
JW930
JW922
JW923
NO921
JW803
JW907
CN903
JW920
LP102
T901
POWER
TRANSFORMER
(SUB)
JW913
CN901
RY901
JW802
D901
Q901
R902
R901
JW801
JW903
JW805
C901
JW902
JW806
JW807
JW808
JW809
JW810
JW811
JW812
JW804
JW905
CN902
F935
F936
VOLTAGE SELECTOR
S901
230 – 240V T 220V T 120V
AC OUTPUT BOARDAC INPUT BOARD
3
1
1
6
4
1
F
FRONT AMP
BOARD
NO101
G
FRONT AMP
BOARD
NO102
E
FRONT AMP
BOARD
NO101
1-680-754-
1
2
3
4
(TH)
1-680-752-
T911
POWER
TRANSFORMER
(MAIN)
2
2341
1
(AC IN)
(TH)
SUB TRANS BOARD
1
E
5
A
FRONT AMP
BOARD
NO109
1-680-751- 11
(21)
11
(21)
11
(21)
(EA, SP)
(EA, SP)
(EA, SP)
(EA, SP)
(TH)
(TH)
(TH)
(TH)
(Page 11)
(Page 11)
(Page 11)
(Page 11)
TA-SV7AV
1919
JW905
JW913 JW907
RY901
D901
R902
R901
Q901
CN903
JW922
JW923
F931
F932
F933
F934
JW938
F937
CN915
CN914
CN913
T911
F936F935
JW903
JW902
JW901
C901
JW906
F913
S901
T901
CN901
NO921 CN902
1SS133T
10k
100k
2SC2785
5P
T8AL
250V
T6.3AL
T6.3AL 250V
T8AL 250V
T4AL 250V
3P
4P
6P
T2.5AL 250VT2.5AL 250V
0.01
250V
T5AL
250V
2P
STBY RELAY
RELAY-UNREG
DGND
SUB-AC
SUB-AC
POWER
TRANSFORMER
(SUB)
120/230
NEUTRAL
AC1
AC2
AC2
AC1
VF
VF
120/230
NEUTRAL
AC1-GND
AC2-GND
VP
AC3(LOW)
AC3(LOW)
AC4(HIGH)
AC4(HIGH)
(AC IN)
RELAY
DRIVE
POWER
TRANSFORMER
(MAIN)
(TH)
(TH)
(EA,SP)
(EA,SP)
(TH) (TH)
4P
2P (TH)
(EA,SP)
230-240
220
(EA,SP)
(TH)
4P
2P (TH)
(EA,SP)
220
230-240
VOLTAGE SELECTOR
230-240V
120V
220V
(EA,SP)
5-11. SCHEMATIC DIAGRAM – POWER Section –
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
(Page 13)
(Page 13)
(Page 13)
(Page 12)
TA-SV7AV
2020
6-1. COVER SECTION
SECTION 6
EXPLODED VIEWS
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Hardware (# mark) list is given in the last of
the electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
6-2. FRONT PANEL SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
#4
#1
#1
#1
#1
#1
#1
#1
#1
#1
not supplied
Front panel section
2
2
1
5
M1
7
4
3
not supplied
not supplied
not supplied
51
51
53
52
54
59
56
supplied with S702
supplied with S703
supplied with S701
zC
zA
zB
55
56
57
56
56
58
(including zA,
zB, zC)
1 1-773-210-11 WIRE (FLAT TYPE) (25 CORE)
2 3-363-099-21 SCREW (CASE 3 TP2)
3 4-232-336-11 COVER
4 4-233-558-21 PANEL (2CH/VCD), BACK (SP)
4 4-233-558-31 PANEL (2CH/VCD), BACK (EA)
4 4-233-558-41 PANEL (2CH/VCD), BACK (TH)
5 1-680-751-11 SUB TRANS BOARD
7 1-680-755-11 RELAY BOARD
M1 1-763-072-11 FAN, D. C.
51 4-232-342-01 KNOB (FUNC)
52 4-232-338-01 KNOB (VOL)
53 X-4953-680-1 PANEL ASSY, FRONT
54 4-232-341-01 SHEET (VOL)
55 4-232-343-01 BUTTON (ENTER)
56 4-951-620-01 SCREW (2.6X8), +BVTP
57 4-232-344-01 INDICATOR (BLUE)
58 A-4275-755-A PANEL BOARD, COMPLETE (EA, SP)
58 A-4726-288-A PANEL BOARD, COMPLETE (TH)
59 4-232-340-01 KNOB (MIC)
• Abbreviation
EA : Saudi Arabia model
SP : Singapore model
TH : Thailand model
21
TA-SV7AV
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
6-3. CHASSIS SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 A-2007-899-A FRONT AMP BOARD, COMPLETE (EA, SP)
101 A-4726-279-A FRONT AMP BOARD, COMPLETE (TH)
102 1-680-753-11 AC OUTPUT BOARD
103 4-900-386-01 SCREW
104 1-680-752-11 AC INPUT BOARD
105 A-2007-897-A SURROUND AMP BOARD, COMPLETE (EA, SP)
105 A-4726-276-A SURROUND AMP BOARD, COMPLETE (TH)
106 3-970-608-01 SUMITITE (B3), +BV
107 4-965-822-01 FOOT
*108 3-703-244-00 BUSHING (2104), CORD (EA, SP)
108 3-703-571-11 BUSHING (S) (4516), CORD (TH)
0109 1-777-071-81 CORD, POWER (EA, SP)
0109 1-791-901-11 CORD, POWER (TH)
0T911 1-435-935-11 TRANSFORMER, POWER
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
#2
#1
#1 #2
#3
T911
107
106
106
101
102
103
103
104 105
109
108
22
TA-SV7AV SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC INPUT
AC OUTPUT
FRONT AMP
1-680-752-11 AC INPUT BOARD
***************
**************************************************************
1-680-753-11 AC OUTPUT BOARD
****************
1-533-217-41 HOLDER, FUSE
< CONNECTOR >
CN913 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN914 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN915 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< FUSE >
0F931 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
0F932 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0F933 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL/250V)
0F934 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250V)
0F935 1-533-469-11 FUSE, GLASS TUBE (DIA. 5) (T2.5AL/250V)
0F936 1-533-469-11 FUSE, GLASS TUBE (DIA. 5) (T2.5AL/250V)
0F937 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (T4AL/250V)
**************************************************************
A-2007-899-A FRONT AMP BOARD, COMPLETE (EA, SP)
A-4726-279-A FRONT AMP BOARD, COMPLETE (TH)
***************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C801 1-126-963-11 ELECT 4.7uF 20% 50V
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-947-11 ELECT 47uF 20% 10V
C806 1-136-495-11 FILM 0.068uF 5% 50V
C807 1-136-495-11 FILM 0.068uF 5% 50V
C808 1-136-165-00 FILM 0.1uF 5% 50V
C809 1-136-165-00 FILM 0.1uF 5% 50V
C811 1-162-306-11 CERAMIC 0.01uF 30% 16V
C812 1-162-306-11 CERAMIC 0.01uF 30% 16V
C821 1-107-721-11 ELECT 4.7uF 20% 100V
C831 1-136-165-00 FILM 0.1uF 5% 50V
C832 1-136-165-00 FILM 0.1uF 5% 50V
C833 1-136-165-00 FILM 0.1uF 5% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
C834 1-136-165-00 FILM 0.1uF 5% 50V
C835 1-136-165-00 FILM 0.1uF 5% 50V
C836 1-136-165-00 FILM 0.1uF 5% 50V
C837 1-126-963-11 ELECT 4.7uF 20% 50V
C851 1-126-963-11 ELECT 4.7uF 20% 50V
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-947-11 ELECT 47uF 20% 10V
C856 1-136-495-11 FILM 0.068uF 5% 50V
C857 1-136-495-11 FILM 0.068uF 5% 50V
C858 1-136-165-00 FILM 0.1uF 5% 50V
C859 1-136-165-00 FILM 0.1uF 5% 50V
C861 1-162-306-11 CERAMIC 0.01uF 30% 16V
C862 1-162-306-11 CERAMIC 0.01uF 30% 16V
C863 1-162-306-11 CERAMIC 0.01uF 30% 16V
C864 1-162-306-11 CERAMIC 0.01uF 30% 16V
C865 1-162-306-11 CERAMIC 0.01uF 30% 16V
C871 1-107-721-11 ELECT 4.7uF 20% 100V
C872 1-126-959-11 ELECT 0.47uF 20% 50V
C891 1-104-665-11 ELECT 100uF 20% 10V
C892 1-126-961-11 ELECT 2.2uF 20% 50V
C893 1-104-665-11 ELECT 100uF 20% 10V
C911 1-130-777-00 MYLAR 0.1uF 5% 100V
C912 1-130-777-00 MYLAR 0.1uF 5% 100V
C914 1-115-871-11 ELECT 1uF 20% 50V
C915 1-162-282-31 CERAMIC 100PF 10% 50V
C916 1-162-282-31 CERAMIC 100PF 10% 50V
C917 1-162-282-31 CERAMIC 100PF 10% 50V
C918 1-164-159-11 CERAMIC 0.1uF 50V
C919 1-126-964-11 ELECT 10uF 20% 50V
C920 1-164-159-11 CERAMIC 0.1uF 50V
C924 1-162-294-31 CERAMIC 0.001uF 10% 50V
C925 1-126-795-11 ELECT 10uF 20% 50V
C926 1-126-382-11 ELECT 100uF 20% 16V
C927 1-104-665-11 ELECT 100uF 20% 10V
C941 1-164-159-11 CERAMIC 0.1uF 50V
C951 1-135-516-11 ELECT 3300uF 20% 63V
C952 1-135-516-11 ELECT 3300uF 20% 63V
C953 1-135-515-11 ELECT 3300uF 20% 50V
C954 1-135-515-11 ELECT 3300uF 20% 50V
C955 1-136-165-00 FILM 0.1uF 5% 50V
C956 1-136-165-00 FILM 0.1uF 5% 50V
C961 1-128-563-11 ELECT 100uF 20% 100V
• Abbreviation
EA : Saudi Arabia model
SP : Singapore model
TH : Thailand model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
23
TA-SV7AV
C962 1-128-563-11 ELECT 100uF 20% 100V
C963 1-104-665-11 ELECT 100uF 20% 10V
C964 1-119-943-91 ELECT 47uF 20% 50V
C987 1-164-159-11 CERAMIC 0.1uF 50V
C990 1-164-159-11 CERAMIC 0.1uF 50V
C991 1-126-940-11 ELECT 330uF 20% 25V
C992 1-113-342-11 CERAMIC 0.1uF 50V
C993 1-126-935-11 ELECT 470uF 20% 16V
C994 1-126-176-11 ELECT 220uF 20% 10V
C1100 1-164-159-11 CERAMIC 0.1uF 50V
C1101 1-164-159-11 CERAMIC 0.1uF 50V
C1102 1-164-159-11 CERAMIC 0.1uF 50V
C1103 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN103 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN104 1-784-786-11 CONNECTOR, FFC 25P
CN105 1-564-506-11 PLUG, CONNECTOR 3P
CN106 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN107 1-794-498-21 SOCKET, CONNECTOR 20P
(SYSTEM CONTROL 1 FROM ST-SV7)
CN108 1-770-721-11 CONNECTOR, BOARD TO BOARD 4P
CN113 1-770-594-21 CONNECTOR, BOARD TO BOARD 5P
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D802 8-719-911-19 DIODE 1SS133T-72
D821 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D851 8-719-911-19 DIODE 1SS133T-72
D871 8-719-911-19 DIODE 1SS133T-72
D881 8-719-911-19 DIODE 1SS133T-72
D911 8-719-510-68 DIODE D5SBA204101
D923 8-719-024-99 DIODE 11ES2-NTA2B
D924 8-719-024-99 DIODE 11ES2-NTA2B
D925 8-719-911-19 DIODE 1SS133T-72
D926 8-719-911-19 DIODE 1SS133T-72
D951 8-719-510-68 DIODE D5SBA204101
D963 8-719-911-19 DIODE 1SS133T-72
D970 8-719-024-99 DIODE 11ES2-NTA2B
D971 8-719-024-99 DIODE 11ES2-NTA2B
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
D980 8-719-024-99 DIODE 11ES2-NTA2B
D981 8-719-024-99 DIODE 11ES2-NTA2B
D990 8-719-024-99 DIODE 11ES2-NTA2B
D991 8-719-024-99 DIODE 11ES2-NTA2B
D992 8-719-024-99 DIODE 11ES2-NTA2B
D993 8-719-024-99 DIODE 11ES2-NTA2B
D994 8-719-024-99 DIODE 11ES2-NTA2B
D995 8-719-024-99 DIODE 11ES2-NTA2B
D996 8-719-024-99 DIODE 11ES2-NTA2B
D997 8-719-024-99 DIODE 11ES2-NTA2B
< GROUND TERMINAL >
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
EPT902 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC310 6-800-467-01 IC PT8300-S
IC801 8-749-016-96 IC STK402-120S
IC923 8-759-595-88 IC NJM78L12A-T3
IC924 8-759-708-05 IC NJM78L05A-T3
<COIL>
L811 1-420-872-00 COIL, AIR-CORE
L831 1-420-872-00 COIL, AIR-CORE
L832 1-420-872-00 COIL, AIR-CORE
L833 1-420-872-00 COIL, AIR-CORE
L861 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q801 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q821 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q822 8-729-900-63 TRANSISTOR BN1F4M-TP
Q851 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q871 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q881 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q883 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q891 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q892 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q893 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q894 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q895 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q896 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q897 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q902 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q903 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q904 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q961 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q962 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q963 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-410-11 CARBON 270 5% 1/4W
R804 1-249-438-11 CARBON 56K 5% 1/4W
0R805 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
R806 1-249-417-11 CARBON 1K 5% 1/4W
R807 1-249-431-11 CARBON 15K 5% 1/4W
R808 1-249-441-11 CARBON 100K 5% 1/4W
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-260-076-11 CARBON 10 5% 1/2W
R812 1-260-076-11 CARBON 10 5% 1/2W
R814 1-249-437-11 CARBON 47K 5% 1/4W
R815 1-249-437-11 CARBON 47K 5% 1/4W
0R821 1-215-891-11 METAL OXIDE 680 5% 2W F
R825 1-249-402-11 CARBON 56 5% 1/4W
R826 1-249-417-11 CARBON 1K 5% 1/4W
R827 1-249-433-11 CARBON 22K 5% 1/4W
R831 1-260-076-11 CARBON 10 5% 1/2W
FRONT AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
24
TA-SV7AV
R832 1-260-076-11 CARBON 10 5% 1/2W
R833 1-260-076-11 CARBON 10 5% 1/2W
R834 1-260-076-11 CARBON 10 5% 1/2W
R835 1-260-076-11 CARBON 10 5% 1/2W
R836 1-260-076-11 CARBON 10 5% 1/2W
R837 1-249-437-11 CARBON 47K 5% 1/4W
R838 1-249-437-11 CARBON 47K 5% 1/4W
R839 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-410-11 CARBON 270 5% 1/4W
R854 1-249-438-11 CARBON 56K 5% 1/4W
0R855 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
R856 1-249-417-11 CARBON 1K 5% 1/4W
R857 1-249-431-11 CARBON 15K 5% 1/4W
R858 1-249-441-11 CARBON 100K 5% 1/4W
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-260-076-11 CARBON 10 5% 1/2W
R862 1-260-076-11 CARBON 10 5% 1/2W
0R871 1-215-891-11 METAL OXIDE 680 5% 2W F
R875 1-249-402-11 CARBON 56 5% 1/4W
R876 1-249-417-11 CARBON 1K 5% 1/4W
R877 1-249-433-11 CARBON 22K 5% 1/4W
R878 1-249-425-11 CARBON 4.7K 5% 1/4W
R879 1-249-441-11 CARBON 100K 5% 1/4W
R880 1-247-903-00 CARBON 1M 5% 1/4W
0R881 1-215-888-00 METAL OXIDE 220 5% 2W F
R883 1-249-437-11 CARBON 47K 5% 1/4W
R885 1-249-429-11 CARBON 10K 5% 1/4W
R887 1-249-441-11 CARBON 100K 5% 1/4W
R889 1-249-429-11 CARBON 10K 5% 1/4W
R891 1-249-438-11 CARBON 56K 5% 1/4W
R892 1-249-439-11 CARBON 68K 5% 1/4W
R894 1-249-429-11 CARBON 10K 5% 1/4W
R895 1-249-429-11 CARBON 10K 5% 1/4W
R896 1-249-435-11 CARBON 33K 5% 1/4W
R897 1-249-433-11 CARBON 22K 5% 1/4W
R898 1-249-425-11 CARBON 4.7K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-441-11 CARBON 100K 5% 1/4W
R905 1-249-421-11 CARBON 2.2K 5% 1/4W
R906 1-249-417-11 CARBON 1K 5% 1/4W
R907 1-249-421-11 CARBON 2.2K 5% 1/4W
R908 1-249-421-11 CARBON 2.2K 5% 1/4W
R910 1-247-807-31 CARBON 100 5% 1/4W
R911 1-247-807-31 CARBON 100 5% 1/4W
R912 1-247-807-31 CARBON 100 5% 1/4W
R913 1-249-437-11 CARBON 47K 5% 1/4W
R914 1-247-807-31 CARBON 100 5% 1/4W
R915 1-249-437-11 CARBON 47K 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-249-411-11 CARBON 330 5% 1/4W
R918 1-249-411-11 CARBON 330 5% 1/4W
R919 1-249-411-11 CARBON 330 5% 1/4W
R920 1-249-411-11 CARBON 330 5% 1/4W
R921 1-249-411-11 CARBON 330 5% 1/4W
R923 1-249-417-11 CARBON 1K 5% 1/4W
R924 1-249-437-11 CARBON 47K 5% 1/4W
R925 1-249-437-11 CARBON 47K 5% 1/4W
R926 1-249-429-11 CARBON 10K 5% 1/4W
R927 1-249-437-11 CARBON 47K 5% 1/4W
R951 1-249-441-11 CARBON 100K 5% 1/4W
R952 1-249-441-11 CARBON 100K 5% 1/4W
R953 1-249-441-11 CARBON 100K 5% 1/4W
R954 1-249-441-11 CARBON 100K 5% 1/4W
0R963 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R964 1-212-881-11 FUSIBLE 100 5% 1/4W F
R965 1-249-431-11 CARBON 15K 5% 1/4W
R966 1-249-435-11 CARBON 33K 5% 1/4W
R967 1-249-429-11 CARBON 10K 5% 1/4W
0R968 1-202-972-61 FUSIBLE 1 5% 1/4W F
R969 1-249-433-11 CARBON 22K 5% 1/4W
R970 1-249-441-11 CARBON 100K 5% 1/4W
R971 1-249-421-11 CARBON 2.2K 5% 1/4W
R972 1-249-433-11 CARBON 22K 5% 1/4W
R973 1-249-421-11 CARBON 2.2K 5% 1/4W
R974 1-249-429-11 CARBON 10K 5% 1/4W
R991 1-249-417-11 CARBON 1K 5% 1/4W
R992 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY881 1-515-920-11 RELAY
< TERMINAL >
TM101 1-694-677-12 TERMINAL BOARD (4P)
(FRONT SPEAKER IMPEDANCE USE 6-16Ω)
TM102 1-694-674-12 TERMINAL BOARD (6P)
(REAR/CENTER SPEAKER IMPEDANCE USE 8-16Ω)
**************************************************************
A-4725-755-A PANEL BOARD, COMPLETE (EA, SP)
A-4726-288-A PANEL BOARD, COMPLETE (TH)
**********************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-162-306-11 CERAMIC 0.01uF 30% 16V
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-162-306-11 CERAMIC 0.01uF 30% 16V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
C706 1-162-306-11 CERAMIC 0.01uF 30% 16V
C710 1-162-294-31 CERAMIC 0.001uF 10% 50V
C711 1-162-306-11 CERAMIC 0.01uF 30% 16V
C712 1-162-294-31 CERAMIC 0.001uF 10% 50V
C721 1-115-868-11 ELECT 0.22uF 20% 50V
C722 1-162-306-11 CERAMIC 0.01uF 30% 16V
C723 1-162-306-11 CERAMIC 0.01uF 30% 16V
C724 1-115-868-11 ELECT 0.22uF 20% 50V
C725 1-162-294-31 CERAMIC 0.001uF 10% 50V
C726 1-162-215-31 CERAMIC 47PF 5% 50V
C727 1-162-290-31 CERAMIC 470PF 10% 50V
C728 1-115-867-11 ELECT 0.1uF 20% 50V
C729 1-115-872-11 ELECT 2.2uF 20% 50V
C730 1-162-287-31 CERAMIC 270PF 10% 50V
C731 1-115-872-11 ELECT 2.2uF 20% 50V
FRONT AMP PANEL
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
25
TA-SV7AV
C732 1-126-382-11 ELECT 100uF 20% 10V
C733 1-126-791-11 ELECT 10uF 20% 16V
C734 1-162-215-31 CERAMIC 47PF 5% 50V
C735 1-126-791-11 ELECT 10uF 20% 16V
C736 1-115-872-11 ELECT 2.2uF 20% 50V
C737 1-161-494-00 CERAMIC 0.022uF 25V
C738 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C739 1-115-871-11 ELECT 1uF 20% 50V
C740 1-126-785-11 ELECT 47uF 20% 10V
C741 1-126-785-11 ELECT 47uF 20% 10V
C742 1-136-495-11 FILM 0.068uF 5% 50V
C743 1-162-294-31 CERAMIC 0.001uF 10% 50V
C744 1-136-167-00 FILM 0.15uF 5% 50V
C745 1-115-870-11 ELECT 0.47uF 20% 50V
C746 1-115-870-11 ELECT 0.47uF 20% 50V
C747 1-136-495-11 FILM 0.068uF 5% 50V
C748 1-162-294-31 CERAMIC 0.001uF 10% 50V
C749 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C750 1-115-871-11 ELECT 1uF 20% 50V
C751 1-162-306-11 CERAMIC 0.01uF 30% 16V
C752 1-126-791-11 ELECT 10uF 20% 16V
C781 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN700 1-784-747-11 CONNECTOR, FFC 25P
< DIODE >
D701 8-719-058-04 LED SEL5223S-TP15 (I/1)
D702 8-719-057-97 LED SEL5923A-TP15 (SUR)
D703 8-719-057-97 LED SEL5923A-TP15 (EQ)
D704 8-719-057-97 LED SEL5923A-TP15 (CINEMA STUDIO A)
D705 8-719-057-97 LED SEL5923A-TP15 (CINEMA STUDIO B)
D706 8-719-057-97 LED SEL5923A-TP15 (CINEMA STUDIO C)
D710 8-719-109-85 DIODE MTZJ-T-72-5.1B
D781 8-719-084-07 LED SEL5E20CTP15
(MULTI CHANNEL DECODING)
< COIL >
FB707 1-412-473-21 INDUCTOR 0uH
< IC >
IC701 8-759-450-96 IC M65850P
IC702 8-759-167-88 IC NJM4565D
< JACK >
J701 1-691-293-21 JACK (MIC 1)
J702 1-691-293-21 JACK (MIC 2)
J703 1-691-293-21 JACK (PHONES)
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR BA1A4M-TP
Q702 8-729-900-63 TRANSISTOR BN1F4M-TP
Q710 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R707 1-249-411-11 CARBON 330 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-249-410-11 CARBON 270 5% 1/4W
R710 1-249-413-11 CARBON 470 5% 1/4W
R711 1-249-414-11 CARBON 560 5% 1/4W
R712 1-249-416-11 CARBON 820 5% 1/4W
R713 1-249-417-11 CARBON 1K 5% 1/4W
R714 1-249-418-11 CARBON 1.2K 5% 1/4W
R715 1-249-419-11 CARBON 1.5K 5% 1/4W
R716 1-249-421-11 CARBON 2.2K 5% 1/4W
R717 1-249-422-11 CARBON 2.7K 5% 1/4W
R718 1-249-424-11 CARBON 3.9K 5% 1/4W
R719 1-249-426-11 CARBON 5.6K 5% 1/4W
R720 1-249-428-11 CARBON 8.2K 5% 1/4W
R721 1-249-431-11 CARBON 15K 5% 1/4W
R722 1-249-434-11 CARBON 27K 5% 1/4W
R726 1-249-417-11 CARBON 1K 5% 1/4W
R727 1-249-429-11 CARBON 10K 5% 1/4W
R728 1-249-429-11 CARBON 10K 5% 1/4W
R729 1-249-417-11 CARBON 1K 5% 1/4W
R730 1-249-441-11 CARBON 100K 5% 1/4W
R731 1-249-417-11 CARBON 1K 5% 1/4W
R732 1-249-433-11 CARBON 22K 5% 1/4W
R733 1-247-807-31 CARBON 100 5% 1/4W
R734 1-249-429-11 CARBON 10K 5% 1/4W
R735 1-247-883-00 CARBON 150K 5% 1/4W
R736 1-247-807-31 CARBON 100 5% 1/4W
R737 1-249-417-11 CARBON 1K 5% 1/4W
R738 1-249-429-11 CARBON 10K 5% 1/4W
R739 1-249-429-11 CARBON 10K 5% 1/4W
R740 1-249-441-11 CARBON 100K 5% 1/4W
R741 1-249-431-11 CARBON 15K 5% 1/4W
R742 1-249-431-11 CARBON 15K 5% 1/4W
R743 1-249-433-11 CARBON 22K 5% 1/4W
R744 1-249-433-11 CARBON 22K 5% 1/4W
R745 1-249-433-11 CARBON 22K 5% 1/4W
R746 1-249-410-11 CARBON 270 5% 1/4W
R747 1-247-881-00 CARBON 120K 5% 1/4W
R748 1-249-433-11 CARBON 22K 5% 1/4W
R749 1-249-437-11 CARBON 47K 5% 1/4W
R750 1-249-433-11 CARBON 22K 5% 1/4W
R751 1-249-433-11 CARBON 22K 5% 1/4W
< VARIABLE RESISTOR >
RV761 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
RV762 1-225-739-11 RES, VAR CARBON 50K (ECHO LEVEL)
< SWITCH >
S701 1-473-534-11 ENCODER, ROTARY (FUNCTION)
S702 1-473-534-11 ENCODER, ROTARY (FILE SELECT)
S703 1-473-392-11 ENCODER, ROTARY (VOLUME)
S705 1-771-410-21 SWITCH, TACTILE (I/1)
S710 1-771-410-21 SWITCH, TACTILE (SUR)
S711 1-771-410-21 SWITCH, TACTILE (EQ)
S712 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO A)
S713 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO B)
S714 1-771-410-21 SWITCH, TACTILE (CINEMA STUDIO C)
S715 1-771-410-21 SWITCH, TACTILE (DIGITAL)
PANEL
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
26
TA-SV7AV
S717 1-771-410-21 SWITCH, TACTILE (PICTURE EFFECT)
S718 1-771-410-21 SWITCH, TACTILE (SET UP)
S719 1-771-410-21 SWITCH, TACTILE (EQ ON/OFF)
S723 1-771-879-11 SWITCH, TACTILE (ENTER)
**************************************************************
1-680-755-11 RELAY BOARD
************
< CONNECTOR >
CN110 1-793-351-41 SOCKET, CONNECTOR 19P
(SYSTEM CONTROL 2 FROM ST-SV7)
*CN111 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
CN112 1-770-593-41 CONNECTOR, BOARD TO BOARD 5P
**************************************************************
1-680-751-11 SUB TRANS BOARD
****************
1-533-217-41 HOLDER, FUSE (SP, EA)
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN902 1-568-106-11 PIN, CONNECTOR 4P (EA, SP)
*CN902 1-564-321-21 PIN, CONNECTOR 2P (TH)
CN903 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D901 8-719-911-19 DIODE 1SS133T-72
< FUSE >
0F913 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) (T5AL/250V)
(EA, SP)
< RESISTOR >
R901 1-249-441-11 CARBON 100K 5% 1/4W
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(EA, SP)
< TRANSFORMER >
0T901 1-435-825-11 TRANSFORMER, POWER
**************************************************************
A-2007-897-A SURROUND AMP BOARD, COMPLETE (EA, SP)
A-4726-276-A SURROUND AMP BOARD, COMPLETE (TH)
*******************************
< CAPACITOR >
C1001 1-126-964-11 ELECT 10uF 20% 50V
C1002 1-162-286-31 CERAMIC 220PF 10% 50V
C1003 1-162-282-31 CERAMIC 100PF 10% 50V
C1004 1-126-947-11 ELECT 47uF 20% 10V
C1006 1-136-495-11 FILM 0.068uF 5% 50V
C1007 1-136-495-11 FILM 0.068uF 5% 50V
C1033 1-126-968-11 ELECT 100uF 20% 50V
C1034 1-126-968-11 ELECT 100uF 20% 50V
C1038 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1039 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1051 1-126-964-11 ELECT 10uF 20% 50V
C1052 1-162-286-31 CERAMIC 220PF 10% 50V
C1053 1-162-282-31 CERAMIC 100PF 10% 50V
C1054 1-126-947-11 ELECT 47uF 20% 10V
C1056 1-136-495-11 FILM 0.068uF 5% 50V
C1057 1-136-495-11 FILM 0.068uF 5% 50V
C1081 1-126-964-11 ELECT 10uF 20% 50V
C1082 1-162-286-31 CERAMIC 220PF 10% 50V
C1083 1-162-282-31 CERAMIC 100PF 10% 50V
C1084 1-126-947-11 ELECT 47uF 20% 10V
C1086 1-136-495-11 FILM 0.068uF 5% 50V
C1087 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN1002 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
CN1003 1-770-725-11 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
D1051 8-719-911-19 DIODE 1SS133T-72
D1061 8-719-911-19 DIODE 1SS133T-72
D1062 8-719-911-19 DIODE 1SS133T-72
D1081 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-017-19 IC STK443-050
< TRANSISTOR >
Q1001 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1051 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1061 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q1063 8-729-900-36 TRANSISTOR BA1F4M-TP
Q1081 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1092 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1093 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R1001 1-249-417-11 CARBON 1K 5% 1/4W
R1002 1-249-438-11 CARBON 56K 5% 1/4W
R1003 1-249-415-11 CARBON 680 5% 1/4W
(EA, SP)
R1003 1-249-417-11 CARBON 1K 5% 1/4W
(TH)
R1004 1-249-438-11 CARBON 56K 5% 1/4W
0R1005 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
R1006 1-249-417-11 CARBON 1K 5% 1/4W
R1007 1-249-431-11 CARBON 15K 5% 1/4W
R1008 1-249-441-11 CARBON 100K 5% 1/4W
PANEL RELAY SUB TRANS SURROUND AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
27
TA-SV7AV
R1009 1-260-076-11 CARBON 10 5% 1/2W
R1010 1-249-437-11 CARBON 47K 5% 1/4W
0R1031 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R1032 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R1033 1-202-972-61 FUSIBLE 1 5% 1/4W F
R1047 1-249-429-11 CARBON 10K 5% 1/4W
R1051 1-249-417-11 CARBON 1K 5% 1/4W
R1052 1-249-438-11 CARBON 56K 5% 1/4W
R1053 1-249-415-11 CARBON 680 5% 1/4W
(EA, SP)
R1053 1-249-417-11 CARBON 1K 5% 1/4W
(TH)
R1054 1-249-438-11 CARBON 56K 5% 1/4W
0R1055 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
R1056 1-249-417-11 CARBON 1K 5% 1/4W
R1057 1-249-431-11 CARBON 15K 5% 1/4W
R1058 1-249-441-11 CARBON 100K 5% 1/4W
R1059 1-260-076-11 CARBON 10 5% 1/2W
R1060 1-249-438-11 CARBON 56K 5% 1/4W
0R1061 1-215-888-00 METAL OXIDE 220 5% 2W F
0R1062 1-215-888-00 METAL OXIDE 220 5% 2W F
R1063 1-249-429-11 CARBON 10K 5% 1/4W
R1065 1-249-433-11 CARBON 22K 5% 1/4W
R1081 1-249-417-11 CARBON 1K 5% 1/4W
R1082 1-249-438-11 CARBON 56K 5% 1/4W
R1083 1-247-834-11 CARBON 1.3K 5% 1/4W
R1084 1-249-438-11 CARBON 56K 5% 1/4W
0R1085 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
R1086 1-249-417-11 CARBON 1K 5% 1/4W
R1087 1-249-431-11 CARBON 15K 5% 1/4W
R1088 1-249-441-11 CARBON 100K 5% 1/4W
R1089 1-260-076-11 CARBON 10 5% 1/2W
R1090 1-249-439-11 CARBON 68K 5% 1/4W
R1092 1-249-441-11 CARBON 100K 5% 1/4W
R1093 1-249-441-11 CARBON 100K 5% 1/4W
R1094 1-249-439-11 CARBON 68K 5% 1/4W
R1095 1-249-433-11 CARBON 22K 5% 1/4W
< RELAY >
RY1061 1-515-920-11 RELAY (24V)
RY1062 1-515-920-11 RELAY (24V)
< THERMISTOR (POSITIVE) >
THP092 1-807-796-11 THERMISTOR
**************************************************************
MISCELLANEOUS
**************
1 1-773-210-11 WIRE (FLAT TYPE) (25 CORE)
0109 1-777-071-81 CORD, POWER (EA. SP)
0109 1-791-901-11 CORD, POWER (TH)
M1 1-763-072-11 FAN, D. C.
0T911 1-435-935-11 TRANSFORMER, POWER
************************************************************
SURROUND AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-685-871-01 SCERW +BVTT 3X6 (S)
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
01-569-088-21 ADAPTOR, CONVERSION (EA, SP)
TA-SV7AV
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2001.06 New

Navigation menu
