TEAC CORPORATION, FEB. 2011

* A USB cable supplied with respective iPod/iPhone is required. ** AirPlane mode only.

Design and specifications are subject to change without notice.

DS-7 (Sold Separately)

1st + 2nd

generation

3rd

generation

4th

generation

4th

generation

(color)

5th

generation

(video)

classic

Capacity

Type

30/60/

80GB 4/6GB 1/2/4GB 512MB

1/2/4GB

10/15/20/

30/40GB

5/10/

20GB

20/40GB

U2

Yes Yes Yes

Connection

Charging

iPod Model

USB USB USB USB USB USB** USB** USB**

80/120/

160GB

Yes

touch

2nd/3rd

generation

touch

1st

generation

8/16/

32/64GB

Yes

iPhone

1st

generation

mini nano 1st

generation

nano 2nd

generation

(aluminium)

nano

4th/5th

generation

shuffle

all

generation

4/8/

16GB

Yes

iPhone

3G/3GS

8/16/

32GB

Yes

iPhone

4

16/32GB

Yes Yes

20/30/40

60GB/U2

YesYesYes

2/4/8GB 8/16GB

Yes

nano

6th

generation

USBUSBUSBUSBUSB

8/16GB

Yes

touch

4th

generation

8/32/

64GB

Yes

8/16/

32GB

nano 3rd

generation

(video)

4/8GB

Yes

CD-P650

CD Player with USB and iPod Digital Interface

Rev. 0 FEB04-10

Rev. 1 FEB23-10

Rev. 2 JUL14-10

Rev. 3 FEB25-11

Frequency Response: 20-20kHz (±2dB)

THD: less than 0.005% (1kHz)

S/N Ratio: more than 100dB

Analogue Output: 2.0Vms (RCA)

Frequency Response: 20-20kHz (Playback)

S/N Ratio: more than 85dB (Playback/Recording)

USB Power Supply: 5V DC, 0.5A

Analog Audio Out: x 1 (RCA, Gold-plated)

Digital Audio Out: x 1 (TOS-link Optical)

Headphone: x 1 (1/4")

USB Port: x 1

Operation: 120V AC, 60Hz (US), 230V AC, 50Hz (EUR)

Dimension (W x H x D): 17-1/8" x 3-3/8" x 11-1/4"

Weight: 8 lbs. 13 oz. 4.0kg

CD Player section

General Specifications

Function: CD, USB/iPod

Supports CD, CD-R/RW and MP3 Disc

USB Port for iPod Digital Interface and USB Memory Rec/Play

Lossless Digital Audio Connection from iPod via USB Cable*

iPod/iPhone Charging while Playback

MP3 Recording from CD to USB Memory Device

MP3 Playback from USB Memory Device

Compatible with Most MP3 Players and USB Flash Memory

BurrBrown 1791ADBR, 24-bit/192kHz Sampling,

Advanced Segment, Audio Stereo Digital-to-Analogue Converter

Refined Audio Circuits

Repeat (One, All, A-B), Shuffle, 32-track Program Play

Multi-function Fluorescent Display

1/4" Headphone Jack with Level Control

Remote Control Included

Optional iPod Cradle (DS-7)

Available in Black

General section

USB section

Main Features

435 x 85 x 285 mm

20-15kHz (Recording)
