Technics SL 1200 MK 5 GT Service Manual

User Manual: Technics-SL-1200-MK-5-GT-Service-Manual

Open the PDF directly: View PDF .
Page Count: 3

TURNTABLE SECTION

Type: Quartz direct drive

Manual turntable

Drive method: Direct drive

Motor: Brushless DC motor

Turntable platter: Aluminum diecast

Diameter 33.2cm

Mass 1.7kg

Turntable speeds: 33-1/3 r/min, 45 r/min

Variable range pitch: ±8%

Starting torque: 1.5kg-cm

Build-up characteristics: 0.7s, from standstill to 33-1/3 r/min

Braking system: Electronic brake

Wow and flutter: 0.01% WRMS*

0.025% WRMS (JIS C5521)

±0.035% peak(IEC 98A Weighted)

Rumble: -56dB (IEC 98A Unweighted)

-78dB (IEC 98A Weighted)

©2005 Matsushita Electric Industrial Co., Ltd. All

rights reserved. Unauthorized copying and

distribution is a violation of law.

SL-1200MK5GT

Colour

Silver Type: SL-1200MK5

*This rating refers to turntable assembly alone, excluding effects o

f

record, cartridge or tonearm, but including platter. Measured by

obtaining signal from built-in frequency generatorof motor assembly.

TONEARM SECTION

Type: Universal

Effective length: 230mm

A

rm height adjustment range: 0-6 mm

Overhang: 15mm

Effective mass: 12g (without cartridge)

Offset angle: 22°

Friction: Less than 7 mg (lateral, vertical)

Tracking error angle: Within 2°32’ [at the outer groove

of 30cm record]

Within 0°32’ [at the inner groove o

f

30cm record]

Stylus pressure adjustment range: 0-4g

Turntable System

Please use this manual together with the service manual for Model No.SL-1200MK5E, Order

No.AD0303064C0.

Specifications

ORDER NO. AD0504018AE

A

pplicable cartridge weight range: 3.5-13g

11-20.5g (including headshell)

(with auxiliary weight); 9.5-13g

17-20.5g (including headshell)

(with shell weight); 3.5-6.5g

11-14g (including headshell)

Headshell weight: 7.5g

1 Note 2

Note:

·

All parts are supplied by SPC .

·

Important safety notice:

·

Components identified by mark have special

characteristics important for safety.

GENERAL

Power supply: AC110V, 60Hz

Power consumption: 14W

Dimensions (W×H×D): 45.3×17.2×35.5cm

Mass: 12kg

Note:

Specifications are subject to change without notice.

Mass and dimensions are approximate.

2 Replacement Parts List 2

·

Furthermore, special parts which have purposes of

fireretardant (resistors), high-quality sound (capacitors),

low-noise (resistors), etc. are used.

·

When replacing any of components, be sure to use only

manufacture’s specified parts shown in the parts list.

CONTENTS

Page Page

1 Note

·

This simplified service manual is provided to indicate the main differences between the original model no. SL-

1200MK5(E,EB,GN,PP) and the subsequent model no. SL-1200MK5(GT).

2 Replacement Parts List

Ref. No. Replacement Parts Part Name & Description Pcs Remarks

SL-1200MK5E SL-1200MK5GT

4 XTN26+6J XTN26+6JFJ SCREW 3

14 XTN3+6J XTN3+6JFJ SCREW 4

15 XWE3F6 XWE3F6FJ WASHER 2

17 XYN3+C6S XYN3+C6FJ SCREW 2

18 RGN2485-K RGN2833-K NAME PLATE 1

20 RMZ0584-1 --- BARRIER -

22 RMR1111B-K RMR1111B-K1 OPERATION BASE 1

35 XTV3+8G XTV3+8GFJ SCREW 1

36 XUC3FY XUC3FJ WASHER 2

49 SFUP122-03 SFUP122-03A PLATE, LOCK OPERATION 1

51 SFX0172-01-1 SFX0172-011 PIN, GUIDE 1

52 SFXJ172-01 SFXJ172-01A PIN, LOCK CANCELER 1

53 SFXJ172-05 SFXJ172-05A PIN 1

55 XSN2+10 XSN2+10FJ SCREW 2

59 XWE3D8 XWE3D8FJ WASHER 1

60 XYN3+C15S XYN3+C15FJ SCREW 1

63 SFMZQ20-09A SFMZQ20-09A1 SHAFT ASS’Y 1

65 SFUP122N11E SFUP122T11E AC CORD ASS’Y 1

68 SFXG122-01 SFXG122-01A SCREW 4

69 SFXG122-02 SFXG122-02A SCREW 11

70 SFXG172-01 SFXG172-01A SCREW 3

71 SFXGQ20-021 SFXGQ20-02A SCREW 3

73 SNSB10 SNSB10-1 SCREW 3

74 SNSB9-2 SNSB9-3 SCREW 6

75 XTB3+10JFZ XTB3+10JFJK SCREW 4

2

SL-1200MK5GT

Ref. No. Replacement Parts Part Name & Description Pcs Remarks

SL-1200MK5E SL-1200MK5GT

76 XTB3+8J XTB3+8JFJ SCREW 13

77 XTN3+8JFZ XTN3+8JFJK SCREW 5

78 XTV23+10G XTV23+10GFJ SCREW 1

79 XTW3+15T XTW3+15TFJ SCREW 10

80 XTW3+8T XTW3+8TFJ SCREW 4

81 RYQ0418-S RYQ0418-S1 ARM ASS’Y (S) 1

83 SFEL026-01E1 SFEL026-01E2 GROUND WIRE 1

86 SFPAB18201K1 SFPAB18201K4 TONE ARM FIXING PLATE 1

87 SFPJL18202K SFPJL18202A1 OIL DAMPER 1

91 XTW26+6S XTW26+6SFJ SCREW 1

93 SFPRT18201K SFPRT18201K1 ARM LIFT 1

94 SFPZB12201K SFPZB12201K2 PLATE 2

97 SFXG829-1 SFXG829-2 SCREW 1

99 XTN3+8J XTN3+8JFJ SCREW 1

100 XTW3+6T XTW3+6TFJ SCREW 3

102 XUC5FY-V XUC5FJ WASHER 1

104 SFPWG17201K SFPWG17201K1 BALANCE WEIGHT 1

107 XTB3+6JF XTB3+6JFJK SCREW 2

108 XTW3+12TFZ XTW3+12TFJK SCREW 2

110 XYE3+CJ25 XYE3+CJ25FJ SCREW 1

111 XYN3+C10S XYN3+C10FJ SCREW 2

117 SFTE172-01Z1 SFTE172-01Z3 TURN TABLE ASS’Y 1

118 SFUM172-055 SFUM172-054 PANEL COVER 1

119 SFPCC31001K SFPCC31001K1 HEAD SHELL K 1

131 RQLA0263 SFUP015-13 CAUTION LABEL 1

132 SFNZ10EC01 --- CAUTION LABEL -

133 RQLA0385 --- CAUTION LABEL -

134 SFNZ023S01 --- CAUTION LABEL -

137 RQLS0134-1 RQLS0347 CAUTION LABEL 1

A1 RQT7016-E

RQT7017-B

RQT8089-K O/I BOOK 1 Chinese

A11 RGS0005Z RGS0005Z-1 DISC SLIP SHEET ASS’Y 1

A14 --- RQCS0526 CHINESE LABEL 1

CN101 EMCS0360L K1KA04BA0055 PLUG 1

CN102 EMCS0460L K1KA05BA0055 PLUG 1

CN103 EMCS0760L K1KA08BA0055 PLUG 1

D1 D2SBA20 B0EBKM000025 DIODE 1

D203,204 LN21CAL LNG201CFA LED 2

D205,206 LN21CAL LNG201CFA LED 2

F1 XBA2C025TB0 K5D251BL0001 FUSE 1

IC302 TC4011BP C0JAAC000108 IC 1

P1 RPG6584 RPG7571 PACKING CASE 1

PCB6 SFDH122-10E1 SFDH122-10E3 PCB ASS’Y, OUTPUT 1

S401 SFDSD2MSL-C SFDSD2MSL-4 SW 1

T1 SFDZ122S01E SFDZ122S01E1 POWER TRANSFORMER 1
