Introduction
- Installation and Versioning
Vectors
- Thrust Namespace
- Iterators and Static Dispatching
Algorithms
Fancy Iterators
Additional Resources

CUDA Toolkit 4.0

PG-05688-040_v01 | January 2011

Document Change History

Version Date Authors Description of Change

01 2011/1/13 NOJW Initial import from wiki.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | ii

Introduction

Thrust is a C++ template library for CUDA based on the Standard Template Library

(STL). Thrust allows you to implement high performance parallel applications with

minimal programming eﬀort through a high-level interface that is fully interoperable with

CUDA C.

Thrust provides a rich collection of data parallel primitives such as scan, sort, and reduce,

which can be composed together to implement complex algorithms with concise, readable

source code. By describing your computation in terms of these high-level abstractions you

provide Thrust with the freedom to select the most eﬃcient implementation automatically.

As a result, Thrust can be utilized in rapid prototyping of CUDA applications, where

programmer productivity matters most, as well as in production, where robustness and

absolute performance are crucial.

This document describes how to develop CUDA applications with Thrust. The tutorial is

intended to be accessible, even if you have limited C++ or CUDA experience.

Installation and Versioning

Installing the CUDA Toolkit will copy Thrust header ﬁles to the standard CUDA include

directory for your system. Since Thrust is a template library of header ﬁles, no further

installation is necessary to start using Thrust.

In addition, new versions of Thrust continue to be available online through the Google

Code Thrust project page. The version of Thrust included in this version of the CUDA

Toolkit corresponds to version 1.4.0 from the Thrust project page.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 3

Vectors

Thrust provides two vector containers, host_vector and device_vector. As the names

suggest, host_vector is stored in host memory while device_vector lives in GPU device

memory. Thrust’s vector containers are just like std::vector in the C++ STL. Like

std::vector,host_vector and device_vector are generic containers (able to store any

data type) that can be resized dynamically. The following source code illustrates the use of

Thrust’s vector containers.

#include < t hru st / h os t_ v ec to r . h >

#include < thrust / devi ce _ve ct or .h >

#include <iostream >

int main(void)

{

// H has storage for 4 i nt eg er s

t hr u st : : h os t_ v ec t or < int > H (4) ;

// init ia lize i ndi vi du al e le me nt s

H [0] = 14 ;

H [1] = 20 ;

H [2] = 38 ;

H [3] = 46 ;

// H. s iz e () re tur ns the siz e of vec tor H

std :: cout << "H has size " < < H. s iz e () << std :: e ndl ;

// print contents of H

for (int i = 0; i < H . size () ; i ++)

std :: cout << "H [ " << i << "] = " << H[ i] << std :: e ndl ;

// resize H

H . res iz e ( 2) ;

std :: cout << "H now has size " < < H. s iz e () << std :: e ndl ;

// Copy ho st _ve ct or H to d evi ce _ ve cto r D

t hr u st : : d e vi c e_ v ec to r < int > D = H;

// elements of D can be modifie d

D [0] = 99 ;

D [1] = 88 ;

// print contents of D

for (int i = 0; i < D . size () ; i ++)

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 4

std :: cout << "D [ " << i << "] = " << D[ i] << std :: e ndl ;

// H and D are aut oma ti c al ly d eleted when the f unction returns

return 0;

}

As this example shows, the =operator can be used to copy a host_vector to a

device_vector (or vice-versa). The =operator can also be used to copy host_vector to

host_vector or device_vector to device_vector. Also note that individual elements of

adevice_vector can be accessed using the standard bracket notation. However, because

each of these accesses requires a call to cudaMemcpy, they should be used sparingly. We’ll

look at some more eﬃcient techniques later.

It’s often useful to initialize all the elements of a vector to a speciﬁc value, or to copy only

a certain set of values from one vector to another. Thrust provides a few ways to do these

kinds of operations.

#include < t hru st / h os t_ v ec to r . h >

#include < thrust / devi ce _ve ct or .h >

#include < th ru st / cop y .h >

#include < th ru st / fil l .h >

#include < t hru st / se qu enc e . h >

#include <iostream >

int main(void)

{

// init ia lize all ten i nt eg er s of a d evi ce_ vec to r to 1

t hr u st : : d e vi c e_ v ec to r < int > D (10 , 1) ;

// set the f irst se ven el em ents of a vecto r to 9

thrus t :: fi ll ( D. be gin () , D . beg in () + 7, 9) ;

// in it ializ e a hos t_ vec to r with the f irs t five e le me nt s of D

t hr u st : : h os t_ v ec t or < int > H(D . begi n () , D. b egin () + 5) ;

// set the el em en ts of H to 0 , 1 , 2 , 3 , ...

th rus t :: s eq ue nc e ( H . be gi n () , H . end () ) ;

// copy all of H back to the b eg innin g of D

thrus t :: co py ( H. be gin () , H . end () , D . begi n () ) ;

// pr int D

for (int i = 0; i < D . size () ; i ++)

std :: cout << "D [ " << i << "] = " << D[ i] << std :: e ndl ;

return 0;

}

Here we’ve illustrated use of the fill,copy, and sequence functions. The copy function

can be used to copy a range of host or device elements to another host or device vector.

Like the corresponding STL function, thrust::fill simply sets a range of elements to a

speciﬁc value. Thrust’s sequence function can be used to a create a sequence of equally

spaced values.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 5

Thrust Namespace

You’ll notice that we use things like thrust::host_vector or thrust::copy in our

examples. The thrust:: part tells the C++ compiler that we want to look inside the

thrust namespace for a speciﬁc function or class. Namespaces are a nice way to avoid

name collisions. For instance, thrust::copy is diﬀerent from std::copy provided in the

STL. C++ namespaces allow us to distinguish between these two copy functions.

Iterators and Static Dispatching

In this section we used expressions like H.begin() and H.end() or oﬀsets like

D.begin() + 7. The result of begin() and end() is called an iterator in C++. In the

case of vector containers, which are really just arrays, iterators can be thought of as

pointers to array elements. Therefore, H.begin() is an iterator that points to the ﬁrst

element of the array stored inside the Hvector. Similarly, H.end() points to the element

one past the last element of the Hvector.

Although vector iterators are similar to pointers they carry more information with them.

Notice that we did not have to tell thrust::fill that it was operating on a

device_vector iterator. This information is captured in the type of the iterator returned

by D.begin() which is diﬀerent than the type returned by H.begin(). When a Thrust

function is called, it inspects the type of the iterator to determine whether to use a host or

a device implementation. This process is known as static dispatching since the host/device

dispatch is resolved at compile time. Note that this implies that there is no runtime

overhead to the dispatch process.

You may wonder what happens when a “raw” pointer is used as an argument to a Thrust

function. Like the STL, Thrust permits this usage and it will dispatch the host path of the

algorithm. If the pointer in question is in fact a pointer to device memory then you’ll need

to wrap it with thrust::device_ptr before calling the function. For example:

size_ t N = 10;

// raw p oi nt er to device me mory

int * raw_ptr;

cu da Mallo c (( void **) & raw_pt r , N * sizeof(int ));

// wrap raw poin te r with a d ev ice _p tr

t hr u st : : d ev ic e_ pt r < int > dev_ptr(raw_ptr);

// use d evi ce _ptr in thrust alg or ithms

th rus t :: fi ll ( dev _p tr , d ev _p tr + N , ( int ) 0) ;

To extract a raw pointer from a device_ptr the raw_pointer_cast should be applied as

follows:

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 6

size_ t N = 10;

// cr eate a d ev ice _p tr

t hr u st : : d ev ic e_ pt r < int > d ev _ pt r = t h ru s t : : d e vi c e_ m al lo c < int >( N ) ;

// extract raw p oi nt er from d evi ce _ptr

int * raw_ptr = thru st :: r aw_ poi nte r_c ast ( de v_ pt r );

Another reason to distinguish between iterators and pointers is that iterators can be used

to traverse many kinds of data structures. For example, the STL provides a linked list

container (std::list) that provides bidirectional (but not random access) iterators.

Although Thrust does not provide device implementations of such containers, it is

compatible with them.

#include < thrust / devi ce _ve ct or .h >

#include < th ru st / cop y .h >

#include < list >

#include < vector >

int main(void)

{

// crea te an STL list with 4 va lues

std :: li st < int > stl _list ;

stl_li st . p us h_bac k (10) ;

stl_li st . p us h_bac k (20) ;

stl_li st . p us h_bac k (30) ;

stl_li st . p us h_bac k (40) ;

// in it ializ e a dev ice _ve ct or with the li st

t hr u st : : d e vi c e_ v ec to r < int > D ( stl _l ist . b eg in () , s tl _list . end () );

// copy a de vic e_v ec tor into an STL ve ct or

std :: ve ct or < int > s tl _ ve ct o r ( D. s ize () ) ;

thrus t :: co py ( D. be gin () , D . end () , s tl _ve cto r . begi n () ) ;

return 0;

}

For Future Reference: The iterators we’ve covered so far are useful, but fairly basic. In

addition to these normal iterators, Thrust also provides a collection of fancy iterators with

names like counting_iterator and zip_iterator. While they look and feel like normal

iterators, fancy iterators are capable of more exciting things. We’ll revisit this topic later

in the tutorial.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 7

Algorithms

Thrust provides a large number of common parallel algorithms. Many of these algorithms

have direct analogs in the STL, and when an equivalent STL function exists, we choose the

name (e.g. thrust::sort and std::sort).

All algorithms in Thrust have implementations for both host and device. Speciﬁcally,

when a Thrust algorithm is invoked with a host iterator, then the host path is dispatched.

Similarly, a device implementation is called when a device iterator is used to deﬁne a range.

With the exception of thrust::copy, which can copy data between host and device, all

iterator arguments to a Thrust algorithm should live in the same place: either all on the

host or all on the device. When this requirement is violated the compiler will produce an

error message.

Transformations

Transformations are algorithms that apply an operation to each element in a set of (zero or

more) input ranges and then stores the result in a destination range. One example we have

already seen is thrust::fill, which sets all elements of a range to a speciﬁed value.

Other transformations include thrust::sequence,thrust::replace, and of course

thrust::transform. Refer to the documentation for a complete listing.

The following source code demonstrates several of the transformation algorithms. Note

that thrust::negate and thrust::modulus are known as functors in C++ terminology.

Thrust provides these and other common functors like plus and multiplies in the ﬁle

thrust/functional.h.

#include < thrust / devi ce _ve ct or .h >

#include < thrust / transf or m .h >

#include < t hru st / se qu enc e . h >

#include < th ru st / cop y .h >

#include < th ru st / fil l .h >

#include < thr us t/ replace .h >

#include < thrust / functi on al .h >

#include <iostream >

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 8

int main(void)

{

// al lo ca te three dev ice _ve ct o rs wit h 10 el em en ts

t hr u st : : d e vi c e_ v ec to r < int > X (1 0) ;

t hr u st : : d e vi c e_ v ec to r < int > Y (1 0) ;

t hr u st : : d e vi c e_ v ec to r < int > Z (1 0) ;

// in iti al ize X to 0 ,1 ,2 ,3 , .. ..

th rus t :: s eq ue nc e ( X . be gi n () , X . end () ) ;

// com pu te Y = -X

thrus t :: t ran sf orm ( X. b eg in () , X . end () , Y. b eg in () , th ru st :: negate < int >() ) ;

// fill Z with twos

thrus t :: fi ll ( Z. be gin () , Z . end () , 2) ;

// com pu te Y = X mod 2

thrus t :: t ran sfo rm ( X. beg in () , X. end () , Z. b egin () , Y. b eg in () , th rust :: m odul us < int ←-

>() ) ;

// rep la ce all the ones in Y with ten s

th ru st :: r epl ac e ( Y. b eg in () , Y. en d () , 1 , 10 ) ;

// pr int Y

thrus t :: co py ( Y. be gin () , Y . end () , std :: os tre am _it er ato r < int >( std :: cout , "\n"));

return 0;

}

While the functors in thrust/functional.h cover most of the built-in arithmetic and

comparison operations, we often want to do something diﬀerent. For example, consider the

vector operation y<-a*x+ywhere xand yare vectors and ais a scalar constant.

This is the well-known SAXPY operation provided by any BLAS library.

If we want to implement SAXPY with Thrust we have a few options. The ﬁrst is to use two

transformations (one addition and one multiplication) and a temporary vector ﬁlled with

the value a. A better choice is to use a single transformation with a user-deﬁned functor

that does exactly what we want. We illustrate both approaches in the source code below.

struct saxpy_functor

{

con st floa t a;

saxpy_functor(float _a ) : a( _a ) {}

__host __ _ _d evi ce __

flo at o perator () ( c on st flo at & x , co ns t f lo at & y ) cons t {

return a * x + y;

}

};

void sa xpy _fa st ( float A , th rus t :: d ev ic e_v ec to r < float > & X , thr ust :: de vic e_v ect or <←-

float >& Y)

{

// Y <- A * X + Y

thrus t :: t ran sfo rm ( X. beg in () , X. end () , Y. b egin () , Y. b eg in () , s axp y_f un ct or ( A) );

}

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 9

void sa xpy _sl ow ( float A , th rus t :: d ev ic e_v ec to r < float > & X , thr ust :: de vic e_v ect or <←-

float >& Y)

{

th ru st :: d ev ic e_ ve cto r < float > t em p (X . siz e () ) ;

// temp <- A

th ru st :: fill ( t em p . be gi n () , tem p .e nd () , A) ;

// temp <- A * X

thrus t :: t ran sfo rm ( X. beg in () , X. end () , temp . be gi n () , temp . be gi n () , thru st ::←-

mu lt ipl ie s < float >() ) ;

// Y <- A * X + Y

thrus t :: t ran sf orm ( t emp . b egin () , temp . end () , Y. be gi n () , Y. begi n () , t hr us t :: plus <←-

float >() ) ;

}

Both saxpy_fast and saxpy_slow are valid SAXPY implementations, however

saxpy_fast will be signiﬁcantly faster than saxpy_slow. Ignoring the cost of allocating

the temp vector and the arithmetic operations we have the following costs:

Ifast_saxpy: performs 2N reads and N writes

Islow_saxpy: performs 4N reads and 3N writes

Since SAXPY is memory bound (its performance is limited by memory bandwidth, not

ﬂoating point performance) the larger number of reads and writes makes saxpy_slow much

more expensive. In contrast, saxpy_fast will perform about as fast as SAXPY in an

optimized BLAS implementation. In memory bound algorithms like SAXPY it is generally

worthwhile to apply kernel fusion (combining multiple operations into a single kernel) to

minimize the number of memory transactions.

thrust::transform only supports transformations with one or two input arguments (e.g.

f(x)→yand f(x, y)→z). When a transformation uses more than two input arguments

it is necessary to use a diﬀerent approach. The arbitrary_transformation example

demonstrates a solution that uses thrust::zip_iterator and thrust::for_each.

Reductions

A reduction algorithm uses a binary operation to reduce an input sequence to a single

value. For example, the sum of an array of numbers is obtained by reducing the array with

a plus operation. Similarly, the maximum of an array is obtained by reducing with a

operator that takes two inputs and returns the maximum. The sum of an array is

implemented with thrust::reduce as follows:

int sum = th rus t :: r edu ce ( D. be gi n () , D. end () , ( i nt ) 0 , t h ru s t : : pl us < int >() ) ;

The ﬁrst two arguments to reduce deﬁne the range of values while the third and fourth

parameters provide the initial value and reduction operator respectively. Actually, this

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 10

kind of reduction is so common that it is the default choice when no initial value or

operator is provided. The following three lines are therefore equivalent:

int sum = th rus t :: r edu ce ( D. be gi n () , D. end () , ( i nt ) 0 , t h ru s t : : pl us < int >() ) ;

int sum = th rus t :: r edu ce ( D. be gi n () , D. end () , ( i nt ) 0) ;

int sum = th ru st :: re du ce ( D. begi n () , D. end () )

Although thrust::reduce is suﬃcient to implement a wide variety of reductions, Thrust

provides a few additional functions for convenience (like the STL). For example,

thrust::count returns the number of instances of a speciﬁc value in a given sequence:

# in cl ude < thr us t / co un t .h >

# inc lu de < thr ust / devi ce _ve ct or .h >

...

// put t hree 1 s in a de vic e_ v ec tor

t hr u st : : d e vi c e_ v ec to r < int > vec ( 5 ,0) ;

vec [1] = 1;

vec [3] = 1;

vec [4] = 1;

// count the 1 s

int re sul t = t hru st :: co un t ( ve c . be gin () , vec . end () , 1) ;

// res ul t is thr ee

Other reduction operations include thrust::count_if,thrust::min_element,

thrust::max_element,thrust::is_sorted,thrust::inner_product, and several others.

Refer to the documentation for a complete listing.

The SAXPY example in the Transformations section showed how kernel fusion can be

used to reduce the number of memory transfers used by a transformation kernel. With

thrust::transform_reduce we can also apply kernel fusion to reduction kernels. Consider

the following example which computes the norm of a vector.

#include <thrust/transform_reduce.h>

#include < thrust / functi on al .h >

#include < thrust / devi ce _ve ct or .h >

#include < t hru st / h os t_ v ec to r . h >

#include <cmath >

// square < T > c om pu te s the square of a num be r f(x ) -> x* x

templa te <t yp en am e T >

struct square

{

__host __ _ _d evi ce __

Toperat or ( ) ( cons t T& x) con st {

return x * x;

}

};

int main(void)

{

// init ia lize host ar ray

flo at x [4] = {1.0 , 2.0 , 3.0 , 4.0};

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 11

// transf er to device

th ru st :: d ev ic e_ ve cto r < float > d _x (x , x + 4 ) ;

// setup a rg ument s

square < float > unary_ op ;

th ru st :: plus < float > bi na ry _op ;

flo at init = 0;

// com pu te norm

flo at no rm = std :: sq rt ( th ru st :: t ra ns fo rm_ re du ce ( d_x . beg in () , d_ x . end () , ←-

unary_op , init , binary _o p ) );

std :: cout << norm << std :: endl ;

return 0;

}

Here we have a unary operator called square that squares each element of the input

sequence. The sum of squares is then computed using a standard plus reduction. Like the

slower version of the SAXPY transformation, we could implement norm with multiple

passes: ﬁrst a transform using square or perhaps just multiplies and then a plus

reduction over a temporary array. However this would be unnecessarily wasteful and

considerably slower. By fusing the square operation with the reduction kernel we again

have a highly optimized implementation which oﬀers the same performance as

hand-written kernels.

Prex-Sums

Parallel preﬁx-sums, or scan operations, are important building blocks in many parallel

algorithms such as stream compaction and radix sort. Consider the following source code

which illustrates an inclusive scan operation using the default plus operator:

#include < th ru st / sca n .h >

int data [6] = {1 , 0, 2 , 2 , 1, 3};

thrus t :: i n cl usi ve_ sca n (data , data + 6, data ) ; // in - pl ace scan

// data is now {1 , 1, 3 , 5 , 6 , 9}

In an inclusive scan each element of the output is the corresponding partial sum of the

input range. For example, data[2] = data[0] + data[1] + data[2]. An exclusive scan

is similar, but shifted by one place to the right:

#include < th ru st / sca n .h >

int data [6] = {1 , 0, 2 , 2 , 1, 3};

thrus t :: e x cl usi ve_ sca n (data , data + 6, data ) ; // in - pl ace scan

// data is now {0 , 1, 1 , 3 , 5 , 6}

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 12

So now data[2] = data[0] + data[1]. As these examples show, inclusive_scan and

exclusive_scan are permitted to be performed in-place. Thrust also provides the

functions transform_inclusive_scan and transform_exclusive_scan which apply a

unary function to the input sequence before performing the scan. Refer to the

documentation for a complete list of scan variants.

Reordering

Thrust provides support for partitioning and stream compaction through the following

algorithms:

Icopy_if : copy elements that pass a predicate test

Ipartition : reorder elements according to a predicate (true values precede false

values)

Iremove and remove_if : remove elements that fail a predicate test

Iunique: remove consecutive duplicates within a sequence Refer to the documentation

for a complete list of reordering functions and examples of their usage.

Sorting

Thrust oﬀers several functions to sort data or rearrange data according to a given

criterion. The thrust::sort and thrust::stable_sort functions are direct analogs of

sort and stable_sort in the STL.

# in clu de < th ru st / sor t .h >

...

con st int N = 6;

int A[N] = {1 , 4 , 2 , 8 , 5 , 7};

thrus t :: sort (A , A + N) ;

// A is now {1 , 2, 4, 5, 7 , 8}

In addition, Thrust provides thrust::sort_by_key and thrust::stable_sort_by_key,

which sort key-value pairs stored in separate places.

# in clu de < th ru st / sor t .h >

...

con st int N = 6;

int keys [ N ] = { 1, 4, 2 , 8 , 5 , 7};

char value s [N ] = { 'a','b','c','d','e','f'};

th rus t :: s or t_ by _k ey ( keys , key s + N , val ues ) ;

// keys is now { 1 , 2, 4, 5, 7, 8}

// v alues is now { 'a','c','b','e','f','d'}

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 13

Like their STL brethren, the sorting functions also accept user-deﬁned comparison

operators:

# in clu de < th ru st / sor t .h >

# inclu de < thr us t / func ti onal .h >

...

con st int N = 6;

int A[N] = {1 , 4 , 2 , 8 , 5 , 7};

th rus t :: s ta bl e_ so rt ( A , A + N , th ru st :: g re at er < int >() ) ;

// A is now {8 , 7, 5, 4, 2 , 1}

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 14

Fancy Iterators

Fancy iterators perform a variety of valuable purposes. In this section we’ll show how

fancy iterators allow us to attack a broader class problems with the standard Thrust

algorithms. For those familiar with the Boost C++ Library, note that our fancy iterators

were inspired by (and generally derived from) those in Boost Iterator Library.

constant_iterator

Arguably the simplest of the bunch, constant_iterator is simply an iterator that returns

the same value whenever we access it. In the following example we initialize a constant

iterator with the value 10.

#include < thrust / iterator / co nst ant _it er ato r .h >

...

// cre ate i te rator s

thrust::constant_iterator <int > f ir st ( 10 ) ;

thrust::constant_iterator <int > last = firs t + 3;

fir st [0] // returns 10

fir st [1] // returns 10

fir st [1 00] // returns 10

// sum of [first , last )

thrus t :: reduc e ( first , last ); // returns 30 (i . e. 3 * 10)

Whenever an input sequence of constant values is needed, constant_iterator is a

convenient and eﬃcient solution.

counting_iterator

If a sequence of increasing values is required, then counting_iterator is the appropriate

choice. Here we initialize a counting_iterator with the value 10 and access it like an

array.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 15

#include < thrust / iterator / co unt ing _it er ato r .h >

...

// cre ate i te rator s

thrust::counting_iterator <int > f ir st ( 10 ) ;

thrust::counting_iterator <int > last = firs t + 3;

fir st [0] // returns 10

fir st [1] // returns 11

fir st [1 00] // returns 110

// sum of [first , last )

thrus t :: reduc e ( first , last ); // ret ur ns 33 ( i .e. 10 + 11 + 12)

While constant_iterator and counting_iterator act as arrays, they don’t actually

require any memory storage. Whenever we dereference one of these iterators it generates

the appropriate value on-the-ﬂy and returns it to the calling function.

transform_iterator

In the Algorithms section we spoke about kernel fusion, i.e. combining separate algorithms

like transform and reduce into a single transform_reduce operation. The

transform_iterator allows us to apply the same technique, even when we don’t have a

special transform_xxx version of the algorithm. This example shows another way to fuse

a transformation with a reduction, this time with just plain reduce applied to a

transform_iterator.

#include < thrust / iterator / tr ans for m_i ter ato r .h >

// init ia lize vector

t hr u st : : d e vi c e_ v ec to r < int > vec ( 3) ;

vec [0] = 10; vec [1] = 20; vec [2] = 30;

// cre at e it er ato r ( typ e omi tt ed )

... first = t hr us t :: m ak e_t ra nsf or m_i te rat or ( vec . be gi n () , negate < int >( ) );

... las t = th ru st :: m ak e_ tr an sf or m_ ite ra to r ( vec . en d () , negate < int > () ) ;

fir st [0] // ret ur ns -10

fir st [1] // ret ur ns -20

fir st [2] // ret ur ns -30

// sum of [first , last )

thrus t :: reduc e ( first , last ); // ret ur ns -60 ( i.e. -10 + -20 + -30)

Note, we have omitted the types for iterators first and last for simplicity. One downside

of transform_iterator is that it can be cumbersome to specify the full type of the

iterator, which can be quite lengthy. For this reason, it is common practice to simply put

the call to make_transform_iterator in the arguments of the algorithm being invoked.

For example,

// sum of [first , last )

thrus t :: reduc e ( thrust :: m ake _ tr ans for m_i ter a tor ( vec . begin () , negate < int >( ) ) ,

th ru st :: m ak e_ tr an sf orm _i te ra to r ( vec . end () , negat e < int >() ) );

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 16

allows us to avoid creating a variable to store first and last.

permutation_iterator

In the previous section we showed how transform_iterator is used to fuse a

transformation with another algorithm to avoid unnecessary memory operations. The

permutation_iterator is similar: it allows us to fuse gather and scatter operations with

Thrust algorithms, or even other fancy iterators. The following example shows how to fuse

a gather operation with a reduction.

#include < thrust / it er at or / p erm uta tio n_i ter ato r .h >

...

// gat her l oc ation s

t hr u st : : d e vi c e_ v ec to r < int > map ( 4) ;

map [0] = 3;

map [1] = 1;

map [2] = 0;

map [3] = 5;

// array to ga ther from

t hr u st : : d e vi c e_ v ec to r < int > so ur ce (6) ;

sourc e [0] = 10;

sourc e [1] = 20;

sourc e [2] = 30;

sourc e [3] = 40;

sourc e [4] = 50;

sourc e [5] = 60;

// fuse gather with re ducti on :

// sum = s ource [ map [0]] + sourc e [map [1]] + ...

int sum = th rust :: r ed uc e ( th ru st :: m ake _per mu tat ion_ iter at or ( so ur ce . begi n () , map .←-

be gi n ( ) ) ,

th ru st :: m ak e_ pe rm ut at io n_i te ra to r ( s ou rce . beg in () , ma p . end←-

() ) );

Here we have used the make_permutation_iterator function to simplify the construction

of the permutation_iterators. The ﬁrst argument to make_permutation_iterator is the

source array of the gather operation and the second is the list of map indices. Note that

we pass in source.begin() for the ﬁrst argument in both cases, but vary the second

argument to deﬁne the beginning and end of the sequence.

When a permutation_iterator is used as an output sequence of a function it is equivalent

to fusing a scatter operation to the algorithm. In general permutation_iterator allows

you to operate on speciﬁc set of values in a sequence instead of the entire sequence.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 17

zip_iterator

Keep reading, we’ve saved the best iterator for last! The zip_iterator is an extremely

useful gadget: it takes multiple input sequences and yields a sequence of tuples. In this

example we “zip” together a sequence of int and a sequence of char into a sequence of

tuple<int,char> and compute the tuple with the maximum value.

#include < thrust / itera to r / zi p_ ite ra tor .h >

...

// init ia lize v ec tors

t hr u st : : d e vi c e_ v ec to r < int > A (3) ;

th rus t :: d ev ic e_v ec to r < char > B (3) ;

A [0] = 10; A [1] = 20; A [2] = 30;

B [0] = 'x'; B [1] = 'y'; B [ 2] = 'z';

// cre at e it er ato r ( typ e omi tt ed )

fir st = t hr us t :: m ak e_ zi p_i tera tor ( th rust :: mak e_ tup le ( A. begin () , B . begi n () ) );

las t = thr ust :: ma ke _z ip _it er at or ( t hru st :: m ake _t up le ( A . end () , B. end () )) ;

fir st [0] // ret urns tu ple (10 , 'x')

fir st [1] // ret urns tu ple (20 , 'y')

fir st [2] // ret urns tu ple (30 , 'z')

// max im um of [first , last )

t hr u st : : m ax imu m < tu pl e < int ,char > > binar y_ op ;

t hr u st : : tuple < int ,char > init = first [0];

thrus t :: reduc e ( first , last , init , b in ary_op ); // return s tuple (30 , 'z')

What makes zip_iterator so useful is that most algorithms accept either one, or

occasionally two, input sequences. The zip_iterator allows us to combine many

independent sequences into a single sequence of tuples, which can be processed by a broad

set of algorithms.

Refer to the arbitrary_transformation example to see how to implement a ternary

transformation with zip_iterator and for_each. A simple extension of this example

would allow you to compute transformations with multiple output sequences as well.

In addition to convenience, zip_iterator allows us to implement programs more

eﬃciently. For example, storing 3d points as an array of float3 in CUDA is generally a

bad idea, since array accesses are not properly coalesced. With zip_iterator we can store

the three coordinates in three separate arrays, which does permit coalesced memory access.

In this case, we use zip_iterator to create a virtual array of 3d vectors which we can feed

in to Thrust algorithms. Refer to the dot_products_with_zip example for additional

details.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 18

Additional Resources

This guide only scratches the surface of what you can do with Thrust. The following

resources can help you learn to do more with Thrust or provide assistance when problems

arise.

IComprehensive Documentation of Thrust’s API

IA list of Frequently Asked Questions

IMegaNewtons: A blog for Thrust developers

ICollection of example programs

We strongly encourage users to subscribe to the thrust-users mailing list. The mailing list

is a great place to seek out help from the Thrust developers and other Thrust users.

CUDA Toolkit 4.0 Thrust Quick Start Guide PG-05688-040_v01 | 19

www.nvidia.com

Notice

ALL NVIDIA DESIGN SPECIFICATIONS, REFERENCE BOARDS, FILES, DRAWINGS, DIAGNOSTICS, LISTS, AND OTHER

DOCUMENTS (TOGETHER AND SEPARATELY, “MATERIALS”) ARE BEING PROVIDED “AS IS.” NVIDIA MAKES NO

WARRANTIES, EXPRESSED, IMPLIED, STATUTORY, OR OTHERWISE WITH RESPECT TO THE MATERIALS, AND

EXPRESSLY DISCLAIMS ALL IMPLIED WARRANTIES OF NONINFRINGEMENT, MERCHANTABILITY, AND FITNESS FOR

A PARTICULAR PURPOSE.

Information furnished is believed to be accurate and reliable. However, NVIDIA Corporation assumes no

responsibility for the consequences of use of such information or for any infringement of patents or other

rights of third parties that may result from its use. No license is granted by implication of otherwise under

any patent rights of NVIDIA Corporation. Specifications mentioned in this publication are subject to change

without notice. This publication supersedes and replaces all other information previously supplied. NVIDIA

Corporation products are not authorized as critical components in life support devices or systems without

express written approval of NVIDIA Corporation.

Trademarks

NVIDIA and the NVIDIA logo are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S.

and other countries. Other company and product names may be trademarks of the respective companies with

which they are associated.

Thrust Quick Start Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
