Total Access 1500
System Release 3.1
Release Notes
Module Description Firmware Issue
1180008L1 TA 1500 SCU V10
1180008L2 TA 1500 SCU COT w/MLT V10
1180008L3 TA 1500 SCU RT w/MLT V10
1180008L22 TA 1500 SCU COT w/VF Test Access V10
1180008L23 TA 1500 SCU RT, w/VF Test Access V10
1180009L1 TA 1500 Dual LIU T10
1180109L1 TA 1500 Quad LIU T10
1180109L2 TA 1500 Quad LIU, L2 (Mode II) T10
CONFIDENTIAL
61180001L1#S-40A 1
December 2005
61180008L1-40A 2 COMPANY CONFIDENTIAL
December 2005
Trademarks
Any brand names and product names included in this manual are trademarks, registered
trademarks, or trade names of their respective holders.
To the Holder of the Document
The contents of this document are current as of the date of publication. ADTRAN®
reserves the right to change the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages
or for commercial losses even if ADTRAN has been advised thereof as a result of issue
of this publication.
Training ADTRAN offers training courses on our products. These courses include overviews on
product features and functions while covering applications of ADTRAN’s product lines.
ADTRAN provides a variety of training options, including customized training and
course taught at our facilities or at customer sites. For more information about training,
please contact us.
Training Phone: 800-615-1176, ext. 7500
Training Fax: 256-963-6700
Training Email: training@adtran.com
Technical Support
Technical Support is available to all customers who need assistance with an ADTRAN
product, technology, or solution. ADTRAN’s website is also easily accessible at
www.adtran.com and provides immediate access to information, solutions, services,
training, and resources at any hour. Customers can register at the website to receive
updates and customized information and service. Technical Support contact information
is provided below:
Pre-Sales Applications/Post-Sales Technical Assistance:
Phone: 800-726-8663
Standard hours: Monday - Friday, 7 a.m. - 7 p.m. CST
Emergency hours: 7 days/week, 24 hours/day
61180008L1-40A 3 COMPANY CONFIDENTIAL
December 2005
Revision History
The history of this document is as follows:
Revision Release Date Initiator/Title Description
A December 2005 Wayne Cranford
Product Manager This is the initial issue of this
document
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
(256) 963-8000
©2005 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.
61180008L1-40A 4 COMPANY CONFIDENTIAL
December 2005
Contents
1. Overview.......................................................................................................................................5
2. Software Changes by Module ....................................................................................................6
2.1 System Control Unit (1180008L1, L2, L3, L22, and L23)..........................................................6
2.2 Dual Line Interface Unit (1180009L1) ........................................................................................8
2.3 Quad Line Interface Unit (1180109L1 and L2) ........................................................................10
Figures
Figure 1. TID and Shelf/Slot information.......................................................................................11
Figure 2. Ethernet Link Status .......................................................................................................11
Figure 3. Reset TA 1500 Commons ..............................................................................................12
Figure 4. 19-Inch Chassis Access Module Menu with L2 #S Dual LIU.......................................12
Figure 5. TL1 Logging Privilege ....................................................................................................13
Figure 6. 19-Inch Chassis Access Module Menu with L2 #S Dual LIU ......................................13
Tables
Table 1. Automatic Time Slot Assignment and Wiring Interconnect
for Quad C & R-POTS ....................................................................................................15
Table 2. Automatic Time Slot Assignment and Wiring Interconnect
for Dual 4-wire Access Modules ....................................................................................18
Table 3. Automatic Time Slot Assignment and Wiring Interconnect
for Dual 2-wire Access Modules ....................................................................................21
Table 4. Automatic Time Slot Assignment and Wiring Interconnect
for Single 4-wire Access Modules .................................................................................23
Table 5. Automatic Time Slot Assignment and Wiring Interconnect
for Single 2-wire and 1 DS0 ISDN Access Modules.....................................................25
Table 6. Automatic Time Slot Assignment and Wiring Interconnect
for 2B+D ISDN..................................................................................................................26
Table 7. Automatic Time Slot Assignment and Wiring Interconnect
for 2B, or 1B+D ISDN.......................................................................................................27
61180008L1-40A 5 COMPANY CONFIDENTIAL
December 2005
1. OVERVIEW
This document provides information relating to changes made to Total Access 1500
System components for System Release 3.1.
System Release 3.1 consists of software changes to the System Control Units (SCUs),
Dual Line Interface (Dual LIU), and Quad Line Interface Units (Q-LIUs). The software
can be uploaded in the field by using the local craftport on the SCU, or using TFTP. This
software was developed to be used by all existing hardware, and from any previous
software.
The SCU software is intended to be uploaded to all Total Access 1500 SCUs. The
software for the Quad LIU is intended to be uploaded to both versions of Quad LIU.
Software enhancements of modules are detailed in Software Changes by Module,
beginning on page 1-3.
While not released to production, some customer had previously upgraded the SCU to
V08, Dual LIU to T07, and/or the Quad LIU to T09. We recommend upgrading all of
these systems to this System Release. Items addressed specifically from the interim
software are noted in the following applicable sections.
61180008L1-40A 6 COMPANY CONFIDENTIAL
December 2005
2. Software Changes By Modules
The following sections provide detailed information regarding feature enhancements, and
fixes for each of the above listed components:
2.1 System Control Units (Software V10, checksum 8B50)
1180008L1
1180008L2
1180008L3
1180008L22
1180008L23
General
Incorporated a change such that when an 1180008L22 or 1180008L23, is deployed with a L2
Q-LIU (1180109L2), the SCU only provides Primary/Secondary Power Alarms when deployed
in the 19-inch chassis (1180019L1).
Add support for Y-Modem uploads over the RS-485.
Previously the TA 1500 only supported remote upgrade using TFTP. This added feature
allows download from either a Host TA 1500 SCU, or another ADTRAN units (TA 3000, OP-
6100). Download time estimates for Y-Modem can be between 19 to 25 minutes, based on the
activity of the RS-485 bus.
This change may require increasing the timeout of the TFTP server, as there will be additional
delay between receipt of the 1st block of data while the erase function is performed.
Added support for the Total Access 1500 19-inch Chassis when deployed with List 2 Quad
LIU (1180109L2). See Figure 4.
Previous SCU/LIU software would operate properly in the 19-inch Chassis but would display
all 24 Access Modules slots. Requires List 2 Quad LIU with software T09Q or later to work
properly.
Incorporated a change to insure Host SCU will update a new client shelf with the time and date
stamp.
Menus
Modified menu header to display the TID field in Top line on the left-hand corner of the
screen. The “Slot” field was moved to the 2nd line in the left-hand corner, replacing “Active
Alarms:” nomenclature. Alarm notification remains on the 2nd line in the center of the screen.
See Figure 1. This change will allow remote user to have the TID always present on the
screen, whether locally or remotely logged in.
Incorporated change to the SCU Management Configuration Menu whether the Ethernet Link
is either "Up" or "Down". See Figure 2.
Incorporated a change to the TFTP Application Menu to add, “Reset the TA1500 Commons”
as a menu option. See Figure 3.
Incorporated a change to the Restore Factory Default menu to challenge with a “Setting this
item will affect service” notice and require the user to select either “Yes” or ”No”.
Incorporated support for NMA logging channel.
This new feature allows an active user with TL1 Logging privileges to receive TL1 commands
61180008L1-40A 7 COMPANY CONFIDENTIAL
December 2005
and responses for all active TL1 sessions, including autonomous alarms. Additionally, the
User Name and Password will sent logged for those local or remote Menu users. Privileges
are established in the Security/User Information menu. See Figure 5.
SMNP
Added SNMP Support for SCU LED status.
TL1
Modified TL1 response to RTRV-USER-SECU to return the ASCII character instead of the
hex value.
Incorporated a one-hour inactivity timer for TL1 sessions to Client shelves over the RS-485.
Previously the TCP/IP Inactivity Timer in the SCU Management Menu would timeout any TL1
session to the Host or Client shelves. However, unless the user terminated the TL1 session to
the Client, the Client would maintain that TL1 session. This TL1 Inactivity timer is not user
selectable, and is independent of whether the TL1 session is via TCP/IP or X.25 to the Host
shelf.
Fixes
Modified Y-Modem download to erase SCU or LIU flash after receiving a valid Y-Modem file
header.
Previously the SCU would erase the Application Flash code, and if a file were never sent – a
reset of the SCU would result in the SCU or LIU powering up in a Boot Mode.
Modified local and remote TFTP upload to erase the flash following receipt of the first good
block.
Previously the SCU and LIU would erase Application Flash code before the file transfer was
initiated. If a file were never sent, (wrong file name or TFTP server Location) a reset of the
SCU or LIU would result in the units to power-up in a Boot Mode.
Incorporated a change where a RS485 client will be rediscovered following a loss of the
physical connection. While not expected to be a field-related issue, this change could help in
lab or otherwise temporary installations where the user has not wire-wrapped the RS-485.
Incorporated change such that a corrupted auto logoff menu would provide an “error”,
allowing the user to select either enable or disabled.
During software upgrade in a lab environment, it was noted on one occasion that the Auto
Logoff selection in the SCU Provisioning Menu was not present.
Implemented a change where the 4W ETO was not always properly recognized in the menu.
Implemented a change where the SCU would update the LIU provisioning items following a
failover, when the LIUs are at different software revision.
Previously, the SCU would not download the provisioning information of the Online LIU to
the Offline LIU prior to performing the failover, if the LIU software were not the same.
Implemented a change to the TCP/IP Inactivity Timer. Sessions would timeout immediately
for some back-to-back connections as well as with Tollgrade’s Loopcare OSS.
Implemented a change so 1180008L22 and 1180008L23, SCU with Voice Frequency Test
Access would send the correct Signaling States to the Dual FXO/TO (1180207L4) and Dual
FXO GT (1180215L2). Previously the Test Access feature would not work properly with the
Access Modules. (Updated since V08)
61180008L1-40A 8 COMPANY CONFIDENTIAL
December 2005
2.2 Dual Line Interface Unit (Software T10, checksum BF53)
1180009L1
ALARMS
Implemented a change to disabled the External Clock OOS alarms in the SCU Alarm menu by
default.
GENERAL
Incorporated a Mode in Dual T1 where DS0 assignment for a 2B+D U-BR1TE will be
automatically mapped in tri-slot arrangement, following the same guidelines of an SLC-96 or
SLC-5.
In D4 counting (See Table 6):
Slots 1, 4, 7, 10, 13, 16, 19, 22, the LIU will automatically assign the two DS0s of the physical
slot, along with the odd DS0 from the adjacent physical slot immediately to the right. This is
dependent on adjacent slot being unoccupied, or containing a 2B+D U-BR1TE. Example: a
2B+D U-BR1TE in Slot 1 would be assigned DS0-1, DS0-2, and DS-3 from T1-A.
Slots 2, 5, 8, 11, 14, 17, 20, and 23, the LIU will automatically assign for a 2B+D U-BR1TE
the even DS0 from that physical slot, along with the two DS0s from the adjacent physical slot
immediately to the right. This is dependent on the adjacent slot being unoccupied. Example, a
U-BR1TE in Slot 5 would be assigned DS0-10, DS0-11, and DS0-12 from T1 A.
In slots 3, 6, 9, 12, 15, 18, 21 and 24, a 2B+D U-BR1TE will not be automatically assigned
DS0s.
SNMP
Added support for retrieving signal bits via SNMP
Added support for retrieving LIU status LED via SNMP
Added support for retrieving Access Module LED status via SNMP.
Added SNMP support to Enable/Disable T1 select.
Add SNMP support for “Manufactured By” and “Date of Manufacture”. This will only be available
on those access modules with this capability to be displayed.
FIXES
Removed Signaling Bits from the Status Screen of the 4W TO.
Implemented a change for the 2nd port of the Dual FXS GT to display the signaling bits in the
Status Menu.
Implemented a change to FXS and FXS GT LEDs such that exiting a test while provisioned for TO
(ETO) mode would allow the LEDs return to the proper state. Previously, when exiting a test the
Status LED would go from Amber to off, instead of Green. (Fixed in R36)
Implemented a change to the 1004Hz Test Tone on 2-wire analog access modules that disables the
analog-to-digital path when sending a 1004 Hz towards the loop. Previously the 1004Hz tone was
also received in T1 DS0 about -23 dB. This was due to reflection from the access Modules.
Implemented a change to insure the SCU could reliably read which LIU was Online, and which was
Offline. In a lab environment it was noted on several occasions LIU-A would not operate as the
Online LIU.
Implemented a change on the Dual LIU to allow for Manual Timeslot assignment by T1-B.
Implemented a change to correct a problem with the tone generation of the LIU. Previously the LIU
could corrupt the 1004Hz, Ringback and other tones generate by the LIU for use within the system.
This intermittent anomaly was not service affecting however the 1004Hz Menu Tests would not
operate properly. (Updated since T07)
61180008L1-40A 9 COMPANY CONFIDENTIAL
December 2005
KNOWN ERRATA
A range of DS0 cannot be manual mapped for the Total Access 1500 Fractional T1 Dataport
(P/N 1180405L1).
Work Around – manual map each DS0
61180008L1-40A 10 COMPANY CONFIDENTIAL
December 2005
2.3 Quad Line Interface Unit (Software T10, checksum 48D7)
1180109L1
1180109L2
ALARMS
Implemented a change to disabled the External Clock OOS alarms in the SCU Alarm menu by
default.
Implemented a change for the PHTL and ATB alarms to be assigned the appropriate T1 for the
List 2 Q-LIU (P/N 1180109L2). PHTL or ATB are specific to SLC Mode II operation.
Previously the AID in the TL1 report for these alarms used a “0” instead of a “1” or “2”,
indicating the specific T1 with this alarm condition.
GENERAL
Incorporated a Mode in Dual T1 where DS0 assignment for a 2B+D U-BR1TE will be
automatically mapped in tri-slot arrangement, following the same guidelines of an SLC-96 or
SLC-5.
In D4 counting (See Table 6):
Slots 1, 4, 7, 10, 13, 16, 19, 22, the LIU will automatically assign the two DS0s of the physical
slot, along with the odd DS0 from the adjacent physical slot immediately to the right. This is
dependent on adjacent slot being unoccupied, or containing a 2B+D U-BR1TE. Example: a
2B+D U-BR1TE in Slot 1 would be assigned DS0-1, DS0-2, and DS-3 from T1-A.
Slots 2, 5, 8, 11, 14, 17, 20, and 23, the LIU will automatically assign for a 2B+D U-BR1TE
the even DS0 from that physical slot, along with the two DS0s from the adjacent physical slot
immediately to the right. This is dependent on the adjacent slot being unoccupied. Example, a
U-BR1TE in Slot 5 would be assigned DS0-10, DS0-11, and DS0-12 from T1 A.
In slots 3, 6, 9, 12, 15, 18, 21 and 24, a 2B+D U-BR1TE will not be automatically assigned
DS0s.
Incorporated a “DLC” counting sequence to the Quad LIU Bank Provisioning menu when the
Quad LIU is provisioned for Quad T1 Bank Mode.
When selected, the LIU will automatically assign the DS0s such that all DS0 from a T1 will
appear on the 50-pin amphenol connectors on the rear of the chassis. T1-A will appear on P1
(T/R), T1-B will appear on P2 (T1/R1), T1-C will appear on P3 (E/SG), and T1-D will appear
on P4 (M/SB). Tables1-7 provides the T1/DS0 timeslot and amphenol connector information.
MENUS
Added support for the 19-inch chassis in List 2 Quad LIU (1180109L2).
Previously the LIU would not detect a 19-inch chassis and would display all 24 Access
Modules slots. Requires upgraded SCU software V08 or later to work properly. See Figure 5.
Fixed PHTL alignment in the Alarm Menu of the List 2 Quad LIU (P/N 1180109L2). This
selection only appears in the menu when the LIU is provisioned for SLC-96 Mode II.
61180008L1-40A 11 COMPANY CONFIDENTIAL
December 2005
SNMP
Added support for retrieving signal bits via SNMP
Added support for retrieving LIU status LED via SNMP
Added support for retrieving Access Module LED status via SNMP.
Added SNMP support to Enable/Disable T1 select.
Add SNMP support for “Manufactured By” and “Date of Manufacture”. This will only be
available on those access modules with this capability to be displayed.
FIXES
Removed Signaling Bits from the Status Screen of the 4W TO.
Implemented a change for the 2nd port of the Dual FXS GT to display the signaling bits in the
Status Menu.
Implemented a change to FXS and FXS GT LEDs such that exiting a test while provisioned for
TO (ETO) mode would allow the LEDs return to the proper state. Previously, when exiting a
test the Status LED would go from Amber to off, instead of Green. (Fixed in R36)
Implemented a change to the 1004Hz Test Tone on 2-wire analog access modules that disables
the analog-to-digital path when sending a 1004 Hz towards the loop. Previously the 1004Hz
tone was also received in T1 DS0 about -23 dB. This was due to reflection from the access
Modules.
Implemented a change to insure the SCU could reliably read which LIU was Online, and which
was Offline. In a lab environment it was noted on several occasions LIU-A would not operate
as the Online LIU.
Implemented a change to correct a problem with the tone generation of the LIU. Previously the LIU
could corrupt the 1004Hz, Ringback and other tones generate by the LIU for use within the system.
This intermittent anomaly was not service affecting however the 1004Hz Menu Tests would not operate
properly and MLT test would not function. (Updated since T09)
KNOWN ERRATA
A range of DS0 cannot be manual mapped for the Total Access 1500 Fractional T1 Dataport
(P/N 1180405L1).
Work Around – manual map each DS0
61180008L1-40A 12 COMPANY CONFIDENTIAL
December 2005
TID: HTVLALEX0101 TOTAL ACCESS SYSTEM 1500 01/01/05 20:16
Slot: SCU Major Minor
TA1500 Main Menu
1. System Controller
2. Online LIU - [LIU A]
3. Offline LIU - [.....]
4. Access Modules
5. Alarm Log
6. Logoff
Selection:
'?' - System Help Screen
Figure 1. TID and Shelf/Slot information
TID: HTVLALEX0101 TOTAL ACCESS SYSTEM 1500 01/01/05 20:17
Slot: SCU Major Minor
Management Configuration
1. IP Address
2. IP Subnet Mask
3. IP Default Gateway
4. TELNET Port Number 2000
5. TCP/IP Port Number 2001
6. TCP/IP Inactivity Timeout 30 min
7. SNMP Configuration
Ethernet Link Down
Selection:
'?' - System Help Screen
Figure 2. Ethernet Link Status
61180008L1-40A 13 COMPANY CONFIDENTIAL
December 2005
TID: HTVLALEX0101 TOTAL ACCESS SYSTEM 1500 01/01/05 20:18
Slot: SCU Major Minor
TFTP Application
1. TFTP Upload Destination SCU
2. TFTP Host IP Address
3. SCU Application Filename
4. LIU Application Filename
5. Start TFTP Upload
6. Modify Checksum 6D26
7. Compute Checksum and Store
8. Reset the TFTP Destination
9. Reset the TA1500 Commons
Selection:
'?' - System Help Screen
Figure 3. Reset TA 1500 Commons Addition
TID: HTVLALEX0101 TOTAL ACCESS SYSTEM 1500 01/01/05 20:19
Slot: SCU Major Minor
Access Modules
1. Quad R-POTS 10. ....................
2. DS0DP 11. ....................
3. .................... 12. ....................
4. .................... 13. ....................
5. .................... 14. ....................
6. .................... 15. ....................
7. .................... 16. ....................
8. .................... 17. ....................
9. .................... 18. ....................
Selection:
'?' - System Help Screen
Figure 4. 19-Inch Chassis Access Module Menu with L2 Q-LIU
61180008L1-40A 14 COMPANY CONFIDENTIAL
December 2005
TID: HTVLALEX0101 TOTAL ACCESS SYSTEM 1500 01/01/05 20:20
Slot: SCU Major Minor
User Information
1. User Name USER
2. Password ********
3. R/W Read/Write
4. Test Enabled
5. Admin Enabled
6. TL1 Logging Enabled
7. Delete this User
Selection:
'?' - System Help Screen
Figure 5. TL1 Logging Privilege
TID: HTVLALEX0101 TOTAL ACCESS SYSTEM 1500 01/01/05 20:20
Slot: Online LIU Major Minor
LIU Time Slot Assignment by Card
Card Card Card Card
Slot Name Slot Name
--------------------------------------+----------------------------------------
1. Quad R-POTS A01 --- --- --- |10.
2. DS0DP A02 N/A N/A N/A |11.
3. |12.
4. |13.
5. |14.
6. |15.
7. |16.
8. |17.
9. |18.
--------------------------------------+----------------------------------------
Select Card (1..18):
'?' - System Help Screen
Figure 6. 19-Inch Chassis Access Module Menu with L2 Q-LIU
61180008L1-40A 15 COMPANY CONFIDENTIAL
December 2005
Table 1. Automatic Time Slot Assignment and Wiring Interconnect for Quad C & R-POTS
Associated T1/DS0 Connections
Physical
Slot Module
Circuit Dual T1 Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23- Inch
Chassis 19- Inch
Chassis
Interconnect
Wiring
1 A1 A1 A1 A1 P1 - 26/1 P1 - 26/1 T/R
2 A2 A2 A3 B1 P2 - 26/1 P1 - 27/2 T/R
3 N/A A3 A5 C1 P3 - 26/1 P1 - 28/3 T/R
1
4 N/A A4 A7 D1 P4 - 26/1 P1 - 29/4 T/R
1 A5 A5 A9 A2 P1 - 27/2 P1 - 30/5 T/R
2 A6 A6 A11 B2 P2 - 27/2 P1 - 31/6 T/R
3 N/A A7 A13 C2 P3 - 27/2 P1 - 32/7 T/R
2
4 N/A A8 A15 D2 P4 - 27/2 P1 - 33/8 T/R
1 A9 A9 A17 A3 P1 - 28/3 P1 - 34/9 T/R
2 A10 A10 A19 B3 P2 - 28/3 P1 - 35/10 T/R
3 N/A A11 A21 C3 P3 - 28/3 P1 - 36/11 T/R
3
4 N/A A12 A23 D3 P4 - 28/3 P1 - 37/12 T/R
1 A13 A13 A2 A4 P1 - 29/4 P1 - 38/13 T/R
2 A14 A14 A4 B4 P2 - 29/4 P1 - 39/14 T/R
3 N/A A15 A6 C4 P3 - 29/4 P1 - 40/15 T/R
4
4 N/A A16 A8 D4 P4 - 29/4 P1 - 41/16 T/R
1 A17 A17 A10 A5 P1 - 30/5 P1 - 42/17 T/R
2 A18 A18 A12 B5 P2 - 30/5 P1 - 43/18 T/R
3 N/A A19 A14 C5 P3 - 30/5 P1 - 44/19 T/R
5
4 N/A A20 A16 D5 P4 - 30/5 P1 - 45/20 T/R
1 A21 A21 A18 A6 P1 - 31/6 P1 - 46/21 T/R
2 A22 A22 A20 B6 P2 - 31/6 P1 - 47/22 T/R
3 N/A A23 A22 C6 P3 - 31/6 P1 - 48/23 T/R
6
4 N/A A24 A24 D6 P4 - 31/6 P1 - 49/24 T/R
1 B1 B1 B1 A7 P1 - 32/7 P2 - 26/1 T/R
2 B2 B2 B3 B7 P2 - 32/7 P2 - 27/2 T/R
3 N/A B3 B5 C7 P3 - 32/7 P2 - 28/3 T/R
7
4 N/A B4 B7 D7 P4 - 32/7 P2 - 29/4 T/R
1 B5 B5 B9 A8 P1 - 33/8 P2 - 30/5 T/R
2 B6 B6 B11 B8 P2 - 33/8 P2 - 31/6 T/R
3 N/A B7 B13 C8 P3 - 33/8 P2 - 32/7 T/R
8
4 N/A B8 B15 D8 P4 - 33/8 P2 - 33/8 T/R
1 B9 B9 B17 A9 P1 - 34/9 P2 - 34/9 T/R
2 B10 B10 B19 B9 P2 - 34/9 P2 - 35/10 T/R
3 N/A B11 B21 C9 P3 - 34/9 P2 - 36/11 T/R
9
4 N/A B12 B23 D9 P4 - 34/9 P2 - 37/12 T/R
1 B13 B13 B2 A10 P1 - 35/10 P2 - 38/13 T/R
2 B14 B14 B4 B10 P2 - 35/10 P2 - 39/14 T/R
3 N/A B15 B6 C10 P3 - 35/10 P2 - 40/15 T/R
10
4 N/A B16 B8 D10 P4 - 35/10 P2 - 41/16 T/R
1 B17 B17 B10 A11 P1 - 36/11 P2 - 42/17 T/R
2 B18 B18 B12 B11 P2 - 36/11 P2 - 43/18 T/R
3 N/A B19 B14 C11 P3 - 36/11 P2 - 44/19 T/R
11
4 N/A B20 B16 D11 P4 - 36/11 P2 - 45/20 T/R
61180008L1-40A 16 COMPANY CONFIDENTIAL
December 2005
Table 1. (continued) Automatic Time Slot Assignment and Wiring Interconnect for Quad C
and R-POTS
Associated T1/DS0 Connections
Physical
Slot Module Circuit
Dual T1 Quad T1
(D4) Quad T1 (DID) Quad T1
(DLC) 23- Inch
Chassis 19- Inch
Chassis
Interconnect
Wiring
1 B21 B21 B18 A12 P1 - 37/12 P2 - 46/21 T/R
2 B22 B22 B20 B12 P2 - 37/12 P2 - 47/22 T/R
3 N/A B23 B22 C12 P3 - 37/12 P2 - 48/23 T/R
12
4 N/A B24 B24 D12 P4 - 37/12 P2 - 49/24 T/R
1 C1 C1 C1 A13 P1 - 38/13 P3 - 26/1 T/R
2 C2 C2 C3 B13 P2 - 38/13 P3 - 27/2 T/R
3 N/A C3 C5 C13 P3 - 38/13 P3 - 28/3 T/R
13
4 N/A C4 C7 D13 P4 - 38/13 P3 - 29/4 T/R
1 C5 C5 C9 A14 P1 - 39/14 P3 - 30/5 T/R
2 C6 C6 C11 B14 P2 - 39/14 P3 - 31/6 T/R
3 N/A C7 C13 C14 P3 - 39/14 P3 - 32/7 T/R
14
4 N/A C8 C15 D14 P4 - 39/14 P3 - 33/8 T/R
1 C9 C9 C17 A15 P1 - 40/15 P3 - 34/9 T/R
2 C10 C10 C19 B15 P2 - 40/15 P3 - 35/10 T/R
3 N/A C11 C21 C15 P3 - 40/15 P3 - 36/11 T/R
15
4 N/A C12 C23 D15 P4 - 40/15 P3 - 37/12 T/R
1 C13 C13 C2 A16 P1 - 41/16 P3 - 38/13 T/R
2 C14 C14 C4 B16 P2 - 41/16 P3 - 39/14 T/R
3 N/A C15 C6 C16 P3 - 41/16 P3 - 40/15 T/R
16
4 N/A C16 C8 D16 P4 - 41/16 P3 - 41/16 T/R
1 C17 C17 C10 A17 P1 - 42/17 P3 - 42/17 T/R
2 C18 C18 C12 B17 P2 - 42/17 P3 - 43/18 T/R
3 N/A C19 C14 C17 P3 - 42/17 P3 - 44/19 T/R
17
4 N/A C20 C16 D17 P4 - 42/17 P3 - 45/20 T/R
1 C21 C21 C18 A18 P1 - 43/18 P3 - 46/21 T/R
2 C22 C22 C20 B18 P2 - 43/18 P3 - 47/22 T/R
3 N/A C23 C22 C18 P3 - 43/18 P3 - 48/23 T/R
18
4 N/A C24 C24 D18 P4 - 43/18 P3 - 49/24 T/R
1 D1 D1 D1 A19 P1 - 44/19 N/A T/R
2 D2 D2 D3 B19 P2 - 44/19 N/A T/R
3 N/A D3 D5 C19 P3 - 44/19 N/A T/R
19
4 N/A D4 D7 D19 P4 - 44/19 N/A T/R
1 D5 D5 D9 A20 P1 - 45/20 N/A T/R
2 D6 D6 D11 B20 P2 - 45/20 N/A T/R
3 N/A D7 D13 C20 P3 - 45/20 N/A T/R
20
4 N/A D8 D15 D20 P4 - 45/20 N/A T/R
1 D9 D9 D17 A21 P1 - 46/21 N/A T/R
2 D10 D10 D19 B21 P2 - 46/21 N/A T/R
3 N/A D11 D21 C21 P3 - 46/21 N/A T/R
21
4 N/A D12 D23 D21 P4 - 46/21 N/A T/R
1 D13 D13 D2 A22 P1 - 47/22 N/A T/R
2 D14 D14 D4 B22 P2 - 47/22 N/A T/R
3 N/A D15 D6 C22 P3 - 47/22 N/A T/R
22
4 N/A D16 D8 D22 P4 - 47/22 N/A T/R
61180008L1-40A 17 COMPANY CONFIDENTIAL
December 2005
Table 1. (continued) Automatic Time Slot Assignment and Wiring Interconnect for Quad C
and R-POTS
Associated T1/DS0 Connections
Physical
Slot Module
Circuit Dual T1 Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23- Inch
Chassis 19- Inch
Chassis
Interconnect
Wiring
1 D17 D17 D10 A23 P1 - 48/23 N/A T/R
2 D18 D18 D12 B23 P2 - 48/23 N/A T/R
3 N/A D19 D14 C23 P3 - 48/23 N/A T/R
23
4 N/A D20 D16 D23 P4 - 48/23 N/A T/R
1 D21 D21 D18 A24 P1 - 49/24 N/A T/R
2 D22 D22 D20 B24 P2 - 49/24 N/A T/R
3 N/A D23 D22 C24 P3 - 49/24 N/A T/R
24
4 N/A D24 D24 D24 P4 - 49/24 N/A T/R
61180008L1-40A 18 COMPANY CONFIDENTIAL
December 2005
Table 2. Automatic Time Slot Assignment and Wiring Interconnect for Dual 4-wire Access
Modules
Associated T1/DS0 Connections
Physical
Slot Module
Circuit Dual T1
(D4) Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
P1 - 26/1 P1 - 26/1 T/R
1 A1 A1 A1 A1
P2 - 26/1 P1 - 27/2 T1/R1
P3 - 26/1 P1 - 28/3 T/R
1
2 A2 A2 A3 B1
P4 - 26/1 P1 - 29/4 T1/R1
P1 - 27/2 P1 - 30/5 T/R
1 A3 A5 A9 A2
P2 - 27/2 P1 - 31/6 T1/R1
P3 - 27/2 P1 - 32/7 T/R
2
2 A4 A6 A11 B2
P4 - 27/2 P1 - 33/8 T1/R1
P1 - 28/3 P1 - 34/9 T/R
1 A5 A9 A17 A3
P2 - 28/3 P1 - 35/10 T1/R1
P3 - 28/3 P1 - 36/11 T/R
3
2 A6 A10 A19 B3
P4 - 28/3 P1 - 37/12 T1/R1
P1 - 29/4 P1 - 38/13 T/R
1 A7 A13 A2 A4
P2 - 29/4 P1 - 39/14 T1/R1
P3 - 29/4 P1 - 40/15 T/R
4
2 A8 A14 A4 B4
P4 - 29/4 P1 - 41/16 T1/R1
P1 - 30/5 P1 - 42/17 T/R
1 A9 A17 A10 A5
P2 - 30/5 P1 - 43/18 T1/R1
P3 - 30/5 P1 - 44/19 T/R
5
2 A10 A18 A12 B5
P4 - 30/5 P1 - 45/20 T1/R1
P1 - 31/6 P1 - 46/21 T/R
1 A11 A21 A18 A6
P2 - 31/6 P1 - 47/22 T1/R1
P3 - 31/6 P1 - 48/23 T/R
6
2 A12 A22 A20 B6
P4 - 31/6 P1 - 49/24 T1/R1
P1 - 32/7 P2 - 26/1 T/R
1 A13 B1 B1 A7
P2 - 32/7 P2 - 27/2 T1/R1
P3 - 32/7 P2 - 28/3 T/R
7
2 A14 B2 B3 B7
P4 - 32/7 P2 - 29/4 T1/R1
P1 - 33/8 P2 - 30/5 T/R
1 A15 B5 B9 A8
P2 - 33/8 P2 - 31/6 T1/R1
P3 - 33/8 P2 - 32/7 T/R
8
2 A16 B6 B11 B8
P4 - 33/8 P2 - 33/8 T1/R1
P1 - 34/9 P2 - 34/9 T/R
1 A17 B9 B17 A9
P2 - 34/9 P2 - 35/10 T1/R1
P3 - 34/9 P2 - 36/11 T/R
9
2 A18 B10 B19 B9
P4 - 34/9 P2 - 37/12 T1/R1
P1 - 35/10 P2 - 38/13 T/R
1 A19 B13 B2 A10
P2 - 35/10 P2 - 39/14 T1/R1
P3 - 35/10 P2 - 40/15 T/R
10
2 A20 B14 B4 B10
P4 - 35/10 P2 - 41/16 T1/R1
P1 - 36/11 P2 - 42/17 T/R
1 A21 B17 B10 A11
P2 - 36/11 P2 - 43/18 T1/R1
P3 - 36/11 P2 - 44/19 T/R
11
2 A22 B18 B12 B11
P4 - 36/11 P2 - 45/20 T1/R1
61180008L1-40A 19 COMPANY CONFIDENTIAL
December 2005
Table 2. (continued) Automatic Time Slot Assignment and Wiring Interconnect for Dual 4-
wire Access Module
Associated T1/DS0 Connections
Physical
Slot Module
Circuit Dual T1
(D4) 23-Inch
Chassis 19-Inch
Chassis Quad T1
(DLC) 23-Inch
Chassis 19Inch
Chassis
Interconnect
Wiring
P1 - 37/12 P2 - 46/21 T/R
1 A23 B21 B18 A12
P2 - 37/12 P2 - 47/22 T1/R1
12
2 A24 B22 B20 B12
P3 - 37/12 P2 - 48/23 T/R
P1 - 38/13 P3 - 26/1 T/R
1 B1 C1 C1 A13
P2 - 38/13 P3 - 27/2 T1/R1
P3 - 38/13 P3 - 28/3 T/R
13
2 B2 C2 C3 B13
P4 - 38/13 P3 - 29/4 T1/R1
P1 - 39/14 P3 - 30/5 T/R
1 B3 C5 C9 A14
P2 - 39/14 P3 - 31/6 T1/R1
P3 - 39/14 P3 - 32/7 T/R
14
2 B4 C6 C11 B14
P4 - 39/14 P3 - 33/8 T1/R1
P1 - 40/15 P3 - 34/9 T/R
1 B5 C9 C17 A15
P2 - 40/15 P3 - 35/10 T1/R1
P3 - 40/15 P3 - 36/11 T/R
15
2 B6 C10 C19 B15
P4 - 40/15 P3 - 37/12 T1/R1
P1 - 41/16 P3 - 38/13 T/R
1 B7 C13 C2 A16
P2 - 41/16 P3 - 39/14 T1/R1
P3 - 41/16 P3 - 40/15 T/R
16
2 B8 C14 C4 B16
P4 - 41/16 P3 - 41/16 T1/R1
P1 - 42/17 P3 - 42/17 T/R
1 B9 C17 C10 A17
P2 - 42/17 P3 - 43/18 T1/R1
P3 - 42/17 P3 - 44/19 T/R
17
2 B10 C18 C12 B17
P4 - 42/17 P3 - 45/20 T1/R1
P1 - 43/18 P3 - 46/21 T/R
1 B11 C21 C18 A18
P2 - 43/18 P3 - 47/22 T1/R1
P3 - 43/18 P3 - 48/23 T/R
18
2 B12 C22 C20 B18
P4 - 43/18 P3 - 49/24 T1/R1
P1 - 44/19 N/A T/R
1 B13 D1 D1 A19
P2 - 44/19 N/A T1/R1
P3 - 44/19 N/A T/R
19
2 B14 D2 D3 B19
P4 - 44/19 N/A T1/R1
P1 - 45/20 N/A T/R
1 B15 D5 D9 A20
P2 - 45/20 N/A T1/R1
P3 - 45/20 N/A T/R
20
2 B16 D6 D11 B20
P4 - 45/20 N/A T1/R1
P1 - 46/21 N/A T/R
1 B17 D9 D17 A21
P2 - 46/21 N/A T1/R1
P3 - 46/21 N/A T/R
21
2 B18 D10 D19 B21
P4 - 46/21 N/A T1/R1
P1 - 47/22 N/A T/R
1 B19 D13 D2 A22
P2 - 47/22 N/A T1/R1
P3 - 47/22 N/A T/R
22
2 B20 D14 D4 B22
P4 - 47/22 N/A T1/R1
61180008L1-40A 20 COMPANY CONFIDENTIAL
December 2005
Table 2. (continued) Automatic Time Slot Assignment and Wiring Interconnect for Dual 4-
wire Access Module
Associated T1/DS0 Connections
Physical
Slot Module
Circuit Dual T1 Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
P1 - 48/23 N/A T/R
1 B21 D17 D10 A23
P2 - 48/23 N/A T1/R1
P3 - 48/23 N/A T/R
23
2 B22 D18 D12 B23
P4 - 48/23 N/A T1/R1
P1 - 49/24 N/A T/R
1 B23 D21 D18 A24
P2 - 49/24 N/A T1/R1
P3 - 49/24 N/A T/R
24
2 B24 D22 D20 B24
P4 - 49/24 N/A T1/R1
61180008L1-40A 21 COMPANY CONFIDENTIAL
December 2005
Table 3. Automatic Time Slot Assignment and Wiring Interconnect for Dual 2-wire Access
Modules
Associated T1/DS0 Connections
Physical
Slot Module
Circuit Dual T1 Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
1 A1 A1 A1 A1 P1 - 26/1 P1 - 26/1 T/R
1 2 A2 A2 A3 B1 P3 - 26/1 P1 - 28/3 T/R
1 A5 A5 A9 A2 P1 - 27/2 P1 - 30/5 T/R
2 2 A6 A6 A11 B2 P3 - 27/2 P1 - 32/7 T/R
1 A9 A9 A17 A3 P1 - 28/3 P1 - 34/9 T/R
3 2 A10 A10 A19 B3 P3 - 28/3 P1 - 36/11 T/R
1 A13 A13 A2 A4 P1 - 29/4 P1 - 38/13 T/R
4 2 A14 A14 A4 B4 P3 - 29/4 P1 - 40/15 T/R
1 A17 A17 A10 A5 P1 - 30/5 P1 - 42/17 T/R
5 2 A18 A18 A12 B5 P3 - 30/5 P1 - 44/19 T/R
1 A21 A21 A18 A6 P1 - 31/6 P1 - 46/21 T/R
6 2 A22 A22 A20 B6 P3 - 31/6 P1 - 48/23 T/R
1 B1 B1 B1 A7 P1 - 32/7 P2 - 26/1 T/R
7 2 B2 B2 B3 B7 P3 - 32/7 P2 - 28/3 T/R
1 B5 B5 B9 A8 P1 - 33/8 P2 - 30/5 T/R
8 2 B6 B6 B11 B8 P3 - 33/8 P2 - 32/7 T/R
1 B9 B9 B17 A9 P1 - 34/9 P2 - 34/9 T/R
9 2 B10 B10 B19 B9 P3 - 34/9 P2 - 36/11 T/R
1 B13 B13 B2 A10 P1 - 35/10 P2 - 38/13 T/R
10 2 B14 B14 B4 B10 P3 - 35/10 P2 - 40/15 T/R
1 B17 B17 B10 A11 P1 - 36/11 P2 - 42/17 T/R
11 2 B18 B18 B12 B11 P3 - 36/11 P2 - 44/19 T/R
1 B21 B21 B18 A12 P1 - 37/12 P2 - 46/21 T/R
12 2 B22 B22 B20 B12 P3 - 37/12 P2 - 48/23 T/R
1 C1 C1 C1 A13 P1 - 38/13 P3 - 26/1 T/R
13 2 C2 C2 C3 B13 P3 - 38/13 P3 - 28/3 T/R
1 C5 C5 C9 A14 P1 - 39/14 P3 - 30/5 T/R
14 2 C6 C6 C11 B14 P3 - 39/14 P3 - 32/7 T/R
61180008L1-40A 22 COMPANY CONFIDENTIAL
December 2005
Table 3. (continued) Automatic Time Slot Assignment and Wiring Interconnect for Dual 2-
wire Access Modules
Associated T1/DS0 Connections
Interconnect
Wiring
Physical
Slot Module
Circuit
Dual T1 Quad T1
(D4) Interconne
ct Wiring Quad T1
(DLC) 23-Inch
Chassis 19-Inch
Chassis
1 C9 C9 C17 A15 P1 - 40/15 P3 - 34/9 T/R
15 2 C10 C10 C19 B15 P3 - 40/15 P3 - 36/11 T/R
1 C13 C13 C2 A16 P1 - 41/16 P3 - 38/13 T/R
16 2 C14 C14 C4 B16 P3 - 41/16 P3 - 40/15 T/R
1 C17 C17 C10 A17 P1 - 42/17 P3 - 42/17 T/R
17 2 C18 C18 C12 B17 P3 - 42/17 P3 - 44/19 T/R
1 C21 C21 C18 A18 P1 - 43/18 P3 - 46/21 T/R
18 2 C22 C22 C20 B18 P3 - 43/18 P3 - 48/23 T/R
1 D1 D1 D1 A19 P1 - 44/19 N/A T/R
19 2 D2 D2 D3 B19 P3 - 44/19 N/A T/R
1 D5 D5 D9 A20 P1 - 45/20 N/A T/R
20 2 D6 D6 D11 B20 P3 - 45/20 N/A T/R
1 D9 D9 D17 A21 P1 - 46/21 N/A T/R
21 2 D10 D10 D19 B21 P3 - 46/21 N/A T/R
1 D13 D13 D2 A22 P1 - 47/22 N/A T/R
22 2 D14 D14 D4 B22 P3 - 47/22 N/A T/R
1 D17 D17 D10 A23 P1 - 48/23 N/A T/R
23 2 D18 D18 D12 B23 P3 - 48/23 N/A T/R
1 D21 D21 D18 A24 P1 - 49/24 N/A T/R
24 2 D22 D22 D20 B24 P3 - 49/24 N/A T/R
61180008L1-40A 23 COMPANY CONFIDENTIAL
December 2005
Table 4. Automatic Time Slot Assignment and Wiring Interconnect for Single 4-wire
Access Modules
Associated T1/DS0 Connections
Physical
Slot Dual T1
(D4) Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
P1 - 26/1 P1 - 26/1 T/R
1 A1 A1 A1 A1
P2 - 26/1 P1 - 27/2 T1/R1
P1 - 27/2 P1 - 30/5 T/R
2 A3 A5 A9 A2
P2 - 27/2 P1 - 31/6 T1/R1
P1 - 28/3 P1 - 34/9 T/R
3 A5 A9 A17 A3
P2 - 28/3 P1 - 35/10 T1/R1
P1 - 29/4 P1 - 38/13 T/R
4 A7 A13 A2 A4
P2 - 29/4 P1 - 39/14 T1/R1
P1 - 30/5 P1 - 42/17 T/R
5 A9 A17 A10 A5
P2 - 30/5 P1 - 43/18 T1/R1
P1 - 31/6 P1 - 46/21 T/R
6 A11 A21 A18 A6
P2 - 31/6 P1 - 47/22 T1/R1
P1 - 32/7 P2 - 26/1 T/R
7 A13 B1 B1 A7
P2 - 32/7 P2 - 27/2 T1/R1
P1 - 33/8 P2 - 30/5 T/R
8 A15 B5 B9 A8
P2 - 33/8 P2 - 31/6 T1/R1
P1 - 34/9 P2 - 34/9 T/R
9 A17 B9 B17 A9
P2 - 34/9 P2 - 35/10 T1/R1
P1 - 35/10 P2 - 38/13 T/R
10 A19 B13 B2 A10
P2 - 35/10 P2 - 39/14 T1/R1
P1 - 36/11 P2 - 42/17 T/R
11 A21 B17 B10 A11
P2 - 36/11 P2 - 43/18 T1/R1
P1 - 37/12 P2 - 46/21 T/R
12 A23 B21 B18 A12
P2 - 37/12 P2 - 47/22 T1/R1
P1 - 38/13 P3 - 26/1 T/R
13 B1 C1 C1 A13
P2 - 38/13 P3 - 27/2 T1/R1
P1 - 39/14 P3 - 30/5 T/R
14 B3 C5 C9 A14
P2 - 39/14 P3 - 31/6 T1/R1
P1 - 40/15 P3 - 34/9 T/R
15 B5 C9 C17 A15
P2 - 40/15 P3 - 35/10 T1/R1
P1 - 41/16 P3 - 38/13 T/R
16 B7 C13 C2 A16
P2 - 41/16 P3 - 39/14 T1/R1
P1 - 42/17 P3 - 42/17 T/R
17 B9 C17 C10 A17
P2 - 42/17 P3 - 43/18 T1/R1
P1 - 43/18 P3 - 46/21 T/R
18 B11 C21 C18 A18
P2 - 43/18 P3 - 47/22 T1/R1
P1 - 44/19 N/A T/R
19 B13 D1 D1 A19
P2 - 44/19 N/A T1/R1
P1 - 45/20 N/A T/R
20 B15 D5 D9 A20
P2 - 45/20 N/A T1/R1
P1 - 46/21 N/A T/R
21 B17 D9 D17 A21
P2 - 46/21 N/A T1/R1
P1 - 47/22 N/A T/R
22 B19 D13 D2 A22
P2 - 47/22 N/A T1/R1
61180008L1-40A 24 COMPANY CONFIDENTIAL
December 2005
Table 4. (continued) Automatic Time Slot Assignment and Wiring Interconnect for Single
4-wire Access Modules
Associated T1/DS0 Connections
Physical
Slot Dual T1
(D4) Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
P1 - 48/23 N/A T/R
23 B21 D17 D10 A23
P2 - 48/23 N/A T1/R1
P1 - 49/24 N/A T/R
24 B23 D21 D18 A24
P2 - 49/24 N/A T1/R1
61180008L1-40A 25 COMPANY CONFIDENTIAL
December 2005
Table 5. Automatic Time Slot Assignment and Wiring Interconnect for Single 2-wire and 1
DS0 ISDN Access Modules
Associated T1/DS0 Connections
Physical
Slot Dual T1
(D4) Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC) 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
1 A1 A1 A1 A1
P1 - 26/1 P1 - 26/1 T/R
2 A3 A5 A9 A2
P1 - 27/2 P1 - 30/5 T/R
3 A5 A9 A17 A3
P1 - 28/3 P1 - 34/9 T/R
4 A7 A13 A2 A4
P1 - 29/4 P1 - 38/13 T/R
5 A9 A17 A10 A5
P1 - 30/5 P1 - 42/17 T/R
6 A11 A21 A18 A6
P1 - 31/6 P1 - 46/21 T/R
7 A13 B1 B1 A7
P1 - 32/7 P2 - 26/1 T/R
8 A15 B5 B9 A8
P1 - 33/8 P2 - 30/5 T/R
9 A17 B9 B17 A9
P1 - 34/9 P2 - 34/9 T/R
10 A19 B13 B2 A10
P1 - 35/10 P2 - 38/13 T/R
11 A21 B17 B10 A11
P1 - 36/11 P2 - 42/17 T/R
12 A23 B21 B18 A12
P1 - 37/12 P2 - 46/21 T/R
13 B1 C1 C1 A13
P1 - 38/13 P3 - 26/1 T/R
14 B3 C5 C9 A14
P1 - 39/14 P3 - 30/5 T/R
15 B5 C9 C17 A15
P1 - 40/15 P3 - 34/9 T/R
16 B7 C13 C2 A16
P1 - 41/16 P3 - 38/13 T/R
17 B9 C17 C10 A17
P1 - 42/17 P3 - 42/17 T/R
18 B11 C21 C18 A18
P1 - 43/18 P3 - 46/21 T/R
19 B13 D1 D1 A19
P1 - 44/19 N/A T/R
20 B15 D5 D9 A20
P1 - 45/20 N/A T/R
21 B17 D9 D17 A21
P1 - 46/21 N/A T/R
22 B19 D13 D2 A22
P1 - 47/22 N/A T/R
23 B21 D17 D10 A23
P1 - 48/23 N/A T/R
24 B23 D21 D18 A24
P1 - 49/24 N/A T/R
61180008L1-40A 26 COMPANY CONFIDENTIAL
December 2005
Table 6. Automatic Time Slot Assignment and Wiring Interconnect for 2B+D ISDN
Associated T1/DS0 Connections
Physical
Slot Single T1
(D4) Dual T1
(D4) Quad T1
(D4) Quad T1
(DID) Quad T1
(DLC)Note 1 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
1 A1, A2, A3 A1, A2, A3 A1, A2, A3 A1, A3, A5 A1, B1, C1 P1 - 26/1 P1 - 26/1 T/R
2 Blank A4, A5, A6 A5, A6, A7 A9, A11, A13 A2, B2, C2 P1 - 27/2 P1 - 30/5 T/R
3 Blank Blank A9, A10, A11 A17, A19, A21 A3, B3, C3 P1 - 28/3 P1 - 34/9 T/R
4 A4, A5, A6 A7, A8, A9 A13, A14, A15 A2, A4, A6 A4, B4, C4 P1 - 29/4 P1 - 38/13 T/R
5 Blank A10, A11, A12 A17, A18, A19 A10, A12, A14 A5, B5, C5 P1 - 30/5 P1 - 42/17 T/R
6 Blank Blank A21, A22, A23 A18, A20, A22 A6, B6, C6 P1 - 31/6 P1 - 46/21 T/R
7 A7, A8, A9 A13, A14, A15 B1, B2, B3 B1, B3, B5 A7, B7, C7 P1 - 32/7 P2 - 26/1 T/R
8 Blank A16, A17, A18 B5, B6, B7 B9, B11, B13 A8, B8, C8 P1 - 33/8 P2 - 30/5 T/R
9 Blank Blank B9, B10, B11 B17, B19, B21 A9, B9, C9 P1 - 34/9 P2 - 34/9 T/R
10 A10, A11, A12 A19, A20, A21 B13, B14, B15 B2, B4, B6 A10, B10, C10 P1 - 35/10 P2 - 38/13 T/R
11 Blank A22, A23, A24 B17, B18, B19 B10, B12, B14 A11, B11, C11 P1 - 36/11 P2 - 42/17 T/R
12 Blank Blank B21, B22, B23 B18, B20, B22 A12, B12, C12 P1 - 37/12 P2 - 46/21 T/R
13 A13, A14, A15 B1, B2, B3 C1, C2, C3 C1, C3, C5 A13, B13, C13 P1 - 38/13 P3 - 26/1 T/R
14 Blank B4, B5, B6 C5, C6, C7 C9, C11, C13 A14, B14, C14 P1 - 39/14 P3 - 30/5 T/R
15 Blank Blank C9, C10, C11 C17, C19, C21 A15, B15, C15 P1 - 40/15 P3 - 34/9 T/R
16 A16, A17, A18 B7, B8, B9 C13, C14, C15 C2, C4, C6 A16, B16, C16 P1 - 41/16 P3 - 38/13 T/R
17 Blank B10, B11, B12 C17, C18, C19 C10, C12, C14 A17, B17, C17 P1 - 42/17 P3 - 42/17 T/R
18 Blank Blank C21, C22, C23 C18, C20, C22 A18, B18, C18 P1 - 43/18 P3 - 46/21 T/R
19 A19, A20, A21 B13, B14, B15 D1, D2, D3 D1, D3, D5 A19, B19, C19 P1 - 44/19 N/A T/R
20 Blank B16, B17, B18 D5, D6, D7 D9, D11, D13 A20, B20, C20 P1 - 45/20 N/A T/R
21 Blank Blank D9, D10, D11 D17, D19, D21 A21, B21, C21 P1 - 46/21 N/A T/R
22 A22, A23, A24 B19, B20, B21 D13, D14, D15 D2, D4, D6 A22, B22, C22 P1 - 47/22 N/A T/R
23 Blank B22, B23, B24 D17, D18, D19 D10, D12, D14 A23, B23, C23 P1 - 48/23 N/A T/R
24 Blank Blank D21, D22, D23 D18, D20, D22 A24, B24, C24 P1 - 49/24 N/A T/R
Note 1: Automatic mapping of 2B+D ISDN is not recommended for Quad T1/DLC counting modes. All 3
DS0s intended for ISDN applications should be mapped to the same T1.
61180008L1-40A 27 COMPANY CONFIDENTIAL
December 2005
Table 7. Automatic Time Slot Assignment and Wiring Interconnect for 2B, or 1B+D ISDN
Associated T1/DS0 Connections
Physical
Slot Dual T1
(D4) Quad T1
(D4) Quad T1 (DID) Quad T1
(DLC) Note 1 23-Inch
Chassis 19-Inch
Chassis
Interconnect
Wiring
1 A1, A2 A1, A2 A1, A3 A1, B1 P1 - 26/1 P1 - 26/1 T/R
2 A3, A4 A5, A6 A9, A11 A2, B2 P1 - 27/2 P1 - 30/5 T/R
3 A5, A6 A9, A10 A17, A19 A3, B3 P1 - 28/3 P1 - 34/9 T/R
4 A7, A8 A13, A14 A2, A4 A4, B4 P1 - 29/4 P1 - 38/13 T/R
5 A9, A10 A17, A18 A10, A12 A5, B5 P1 - 30/5 P1 - 42/17 T/R
6 A11, A12 A21, A22 A18, A20 A6, B6 P1 - 31/6 P1 - 46/21 T/R
7 A13, A14 B1, B2 B1, B3 A7, B7 P1 - 32/7 P2 - 26/1 T/R
8 A15, A16 B5, B6 B9, B11 A8, B8 P1 - 33/8 P2 - 30/5 T/R
9 A17, A18 B9, B10 B17, B19 A9, B9 P1 - 34/9 P2 - 34/9 T/R
10 A19, A20 B13, B14 B2, B4 A10, B10 P1 - 35/10 P2 - 38/13 T/R
11 A21, A22 B17, B18 B10, B12 A11, B11 P1 - 36/11 P2 - 42/17 T/R
12 A23, A24 B21, B22 B18, B20 A12, B12 P1 - 37/12 P2 - 46/21 T/R
13 B1, B2 C1, C2 C1, C3 A13, B13 P1 - 38/13 P3 - 26/1 T/R
14 B3, B4 C5, C6 C9, C11 A14, B14 P1 - 39/14 P3 - 30/5 T/R
15 B5, B6 C9, C10 C17, C19 A15, B15 P1 - 40/15 P3 - 34/9 T/R
16 B7, B8 C13, C14 C2, C4 A16, B16 P1 - 41/16 P3 - 38/13 T/R
17 B9, B10 C17, C18 C10, C12 A17, B17 P1 - 42/17 P3 - 42/17 T/R
18 B11, B12 C21, C22 C18, C20 A18, B18 P1 - 43/18 P3 - 46/21 T/R
19 B13, B14 D1, D2 D1, D3 A19, B19 P1 - 44/19 N/A T/R
20 B15, B16 D5, D6 D9, D11 A20, B20 P1 - 45/20 N/A T/R
21 B17, B18 D9, D10 D17, D19 A21, B21 P1 - 46/21 N/A T/R
22 B19, B20 D13, D14 D2, D4 A22, B22 P1 - 47/22 N/A T/R
23 B21, B22 D17, D18 D10, D12 A23, B23 P1 - 48/23 N/A T/R
24 B23, B24 D21, D22 D18, D20 A24, B24 P1 - 49/24 N/A T/R
Note 1: Automatic mapping of 1B+D ISDN is not recommended for Quad T1/DLC counting
modes. Both DS0s intended for ISDN applications should be mapped to the same T1.
Automatic mapping of 2B ISDN will work properly

Navigation menu
