22
Bticino entrance panels –
vandal resistant
push button panels (Linea 2000 metal)
Pack Cat. Nos. Vandal resistant push button panels
(Linea 2000 metal)
Surface mounting plug and play entrance panels
Colour video push button panels
Zamak finish video push button panels with
adjustable colour camera
Swivel camera on 2 axis
Blue LED name plate light
1 3429 91 1 push button
1 3429 92 2 push buttons
Black and white video push button panels
Zamak finish video push button panels with
adjustable black and white camera
Swivel camera on 2 axis
Blue LED name plate light
1 3429 81 1 push button
1 3429 82 2 push buttons
Audio push button panels
Zamak finish audio push button panels
Blue LED name plate light
1 3429 71 1 push button
1 3429 72 2 push buttons
3429 82
3429 92
3429 81
3429 91 3429 72
3429 71
Bticino entrance panels –
with motorised camera
electronic push button panels (Axolute)
Pack Cat. Nos. Electronic push button panels for IP system
(
Axolute)
Colour video electronic push button panel
1 3491 40 Suitable for use in IP systems
IP 54
IK 07
Fitted with :
•capacitive soft touch control backlit keypad
•motorised colour camera (swivel operation can be
controlled from the pre-set handsets)
•colour display with home page that can be fully
customised by the installer
•transponder reader for door lock release – may also
be activated using a numeric code for residents
Module to be installed with flush mounting box,
Cat. No. 3393 13, and surround plate,
Cat. Nos. 3392 13 (steel), or 3392 23 (brass)
TiAxolute Outdoor and TiContacts programming
software, residents’ address book creation, and
configuration supplied
By locally installing a permanent cable with RJ45
socket (T568B type cross connection), it is possible
to update the residents address book and the
configuration, without removing the push button
panel
Surround plate and frame
3 module
Anti-tamper assembly/disassembly safety key
supplied
1 3392 13 Steel finish
1 3392 23 Brass finish
Flush mounting box
1 3393 13 With tearing protection 3 module
Transponder keys and programme
1 3482 00 Black transponder key
1 3482 01 Red transponder key
1 3482 02 Green transponder key
1 3482 03 Blue transponder key
1 3482 04 Orange transponder key
1 3482 05 Grey transponder key
1 3482 06 Yellow transponder key
1 3484 02 Table-top transponder key programmer
3393 13 3392 13 3484 023491 40
Arteor building automation system
see p. 50
Dimensions and technical data p. 34 Dimensions and technical data p. 34
