ANS UL40

User Manual

Conventions used in this guide

In this user guide, we use the following

symbols to indicate useful and important

information:

NOTE

Notes, usage tips, or additional information

Warning Situations that could cause

injury to yourself or others

Caution Situations that could cause

damage to your device or

other equipment

Specifications ............................................................................... 2

Basics ............................................................................................ 3

In Box ..................................................................................... 3

Phone Overview .................................................................... 3

Battery .................................................................................... 3

Turning Phone On or Off ...................................................... 4

Phone Options ...................................................................... 5

Touchscreen Gestures ......................................................... 5

Using the Onscreen Keyboard ............................................ 6

Editing Text ........................................................................... 7

Getting Started ............................................................................. 8

Google Account .................................................................... 8

Getting to Know the Home Screen ..................................... 9

Customizing the Home Screen ............................................ 9

Essential Display Icons ...................................................... 10

Notifications Panel .............................................................. 11

Opening & Switching Between Applications ................... 11

Sleep Mode .......................................................................... 12

Adjusting Volume ............................................................... 13

Searching Your Phone and the Web ................................. 13

Connecting Your Phone to a Computer ............................ 14

Phone Calls ................................................................................. 15

Making Calls ........................................................................ 15

Answering or Rejecting Calls ............................................ 16

Using In-Call Options .......................................................... 17

Using Call Log ..................................................................... 17

Listening to Your Voicemail .............................................. 18

Using Voice Dialer .............................................................. 18

Contacts ...................................................................................... 19

About contacts .................................................................... 19

Opening Your contacts ...................................................... 19

Getting Started .................................................................... 19

Editing/Deleting Contacts .................................................. 21

Communicating ................................................................... 22

Account Setting .................................................................. 22

Messaging ................................................................................... 23

About Messaging ................................................................ 23

Sending Messages ............................................................. 23

Reading Messages ............................................................. 24

Receiving Emergency Alerts Messages ........................... 25

Changing Messaging Settings .......................................... 26

Google ........................................................................................ 27

Gmail ................................................................................... 27

Maps .................................................................................... 28

Calendar .............................................................................. 29

Play Music ........................................................................... 32

Google Play Store .............................................................. 32

Web ............................................................................................. 34

Chrome ................................................................................ 34

YouTube .............................................................................. 37

Wi-Fi ..................................................................................... 39

Downloads .......................................................................... 39

Bluetooth .................................................................................... 40

Using Bluetooth ................................................................. 40

Disconnecting or Un-pairing from a Bluetooth Device .. 40

Connecting to a Bluetooth Headset ................................. 41

Sending and Receiving Information Using Bluetooth .... 41

Entertainment ............................................................................ 43

Camera/Camcorder ............................................................ 43

Sound Recorder ................................................................. 44

Tools ........................................................................................... 45

Clock ................................................................................... 45

Calculator ............................................................................ 46

Settings ...................................................................................... 47

Settings on Your Phone .................................................... 47

Firmware Upgrade ............................................................. 50

Safety and use ........................................................................... 51

Please read before proceeding ........................................ 51

Limitation of damages ....................................................... 51

Important health information and safety precautions .... 52

Regulatory agency identifications ................................... 57

HEARING AID COMPATIBILITY HAC FOR WIRELESS

TELECOMMUNICATIONS DEVICES .................................. 58

Specifications

1. Display

• 4.0” TFT (800x400) Display

• Capacitive Touch Screen

2. Camera

• Front camera: VGA

• Rear camera: 2.0MP with Flash

3. Dimensions and Weight

• Dimensions: 122x63x11mm

• Weight: 120g.

4. Memory

• Internal memory: 8GB ROM / 1GB RAM

• External memory: Supports up to 32GB

5. Operating System

• Android 7.1 Nougat

6. Connectivity

• Wi-Fi (802.11 b/g/n), Bluetooth 4.0

7. Sensors

• Accelerometer, Proximity sensor,

Geomagnetic sensor

8. Power Management (Performance)

Battery Type

Capacity

Standby Time

Talk Time

Lithium-Ion

(Li-ion)

1700mAh

Up to 120 Hours

Up to 5 Hours

Basics

In Box

The UL40 comes with the following items included in the box:

1. Handset

2. Micro USB cable

3. Battery cover

4. Battery (non-removable)

5. USB power adapter

6. Quick Start Guide

Phone Overview

Battery

Note that browsing the web frequently, extended data

usage, being in a poor signal area, or subjecting the device

to extreme temperatures will cause the battery to discharge

quicker than normal. To increase battery life, limit your data

usage, or turn off GPS and Bluetooth when not required.

Charging your battery

Before you turn on your device and start using it, it is

recommended that you charge the battery.

1. Plug the USB cable into the USB power adapter.

2. Plug the power adapter into a standard outlet.

3. Locate the USB port located on the underneath of your

device.

4. Plug the other end of the USB cable into the phone’s

micro USB port.

5. The USB icon on the cable should always face up

when connecting the cable to your device as shown.

NOTE

• It is more efficient to charge the battery with your

device powered off.

• Battery operating time gradually decreases over time.

MicroSD Card

Use the microSD card to store your photos, videos, music

and certain apps from Google PlayTM Store. You can also

move and copy files to your computer from your device.

NOTE When you insert or remove the microSD card, you should

remove the battery cover.

1. Insert the microSD card

1. Locate the microSD card slot and remove the cover.

Insert the microSD card into the slot with its gold

contacts facing right above battery until it clicks

into place.

2. Removing the microSD card

1. Remove the microSD card cover.

2. Press the microSD card to eject it from the slot, then

slide it out the rest of the way.

3. Removing the microSD card while the

phone is on

If you need to remove the microSD card while the

phone is on, unmount the microSD card first to

prevent corrupting or damaging the files in the

microSD card.

1. From the Home screen, tap Apps >Settings.

2. Tap Storage >Unmount SD card >OK.

3. Remove the microSD card by following the steps in

“Removing the microSD card”.

Turning Phone On or Off

1. Turning your phone on

1. Press and hold Power/Lock.

NOTE The first time you use your phone you’ll need to set it up. See

the Getting Started chapter for details.

2. Turning your phone off

1. If the display is off, press Power/Lock to turn it

back on.

2. Press and hold Power/Lock for a few seconds.

3. When Phone options menu appears, tap Power off

>OK.

Phone Options

1. Silent mode

1. Press and hold Power/Lock to display Phone Options.

2. Tap Silent mode.

• When you select Silent mode, is displayed in the

Status bar. Ringtones, alerts, and all audible sounds

except media and alarms are silenced.

NOTE To turn silent mode off, press and hold Power/Lock and

then tap .

2. Airplane mode

1. Press and hold Power/Lock to display Phone Options.

2. Tap Airplane mode.

• When you set Airplane mode, is displayed in

the Status bar. Wi-Fi, Bluetooth, and mobile

network functions are all disabled.

NOTE To turn airplane mode off, press and hold Power/Lock and

then tap Airplane mode again.

Touchscreen Gestures

Tap

To select onscreen items such as

application and settings icons or press

onscreen buttons, simply touch them with

your finger.

Tap and hold

To open available options for the item,

simply touch and hold your finger on the

screen over the item.

Swipe or slide

Quickly drag your finger vertically or

horizontally across the screen.

Drag

Tap and hold your finger before you start

to drag. While dragging, do not release

your finger until the item reaches your

desired location.

Flick

Flicking the screen is similar to swiping,

but you only need to swipe your finger

in lighter and quicker strokes. This finger

gesture is always in a vertical direction,

such as flicking through the contacts or

the message lists.

Rotate

For most screens, you can automatically

change the screen orientation from portrait

to landscape by turning the phone

sideways. When entering text, you can

turn the phone sideways to bring up a

bigger on-screen keyboard.

Using the Onscreen Keyboard

You can enter text using the onscreen keyboard. Some

applications open the keyboard automatically. In others,

tap anywhere in a text field to open the keyboard.

1. Tap each letter on the on-screen keypad.

2. Tap and hold a letter for additional key options (not all

keys have additional options). Additional key options

include numbers and letters with accent marks. If

options are available, you will see a box with all the

options shown. Slide your finger to select the character

you want.

3. Continue until you have finished the word.

You can

also

use the following icons:

• Tap 3 while you type. When you release the key,

the lowercase letters reappear.

• Turn caps lock on. Double-tap or touch & hold.

• Tap 3, so it changes to . Touch shift key again

to return to lowercase.

• Tap

you can to delete words, tap

you can change to

the number and sign keyboard.

• To hide the Android keyboard, press

Back .

• When you write a new message, you can tap 2 to skip

from the receiver frame to text frame.

NOTE When you type the notification panel will have a “select input

method” you can set the input methods.

Adding, Editing or Deleting Words in the User Dictionary

Sometimes you may need to add a word to the predictive

text dictionary, for example, a name or a specialized

technical word. If you want to add a word to your User

dictionary while entering text, double tap the word to

highlight it, then tap and hold the word and select Add **

to dictionary.

Adding a word manually

1. From the Home screen, tap Apps >Settings.

2. Tap Language & input >Personal dictionary.

3. Press Add.

4. Type the word >tap OK.

Editing or deleting a word

1. From the Home screen, tap Apps >Settings.

2. Tap Language & input >Personal dictionary.

• To edit words from the dictionary, tap the word you

want to edit >Edit > Edit the word > Tap OK.

• To delete words from the dictionary, tap the word you

want to delete >Delete.

Editing Text

You can select, copy or cut the text you’ve entered,

then paste it in another text field within the user interface.

NOTE Some applications may offer different text editing methods.

1. Selecting text

1. Tap the text field.

2. Move the cursor to the beginning or end of the desired

text by tapping in the location you want the cursor.

3. Tap and hold the text field.

4. Tap Select word in the pop-up menu.

• Or tap Select all to select all the text in the text field.

5. Drag your finger to move the text cursor to a letter

within the text that you want to select. The selected

text is highlighted in orange.

2. Cutting and copying the text

1. Double-click to select the text to cut or copy it.

2. Tap and hold the selected text.

3. Tap Cut or Copy in the menu that opens.

• If you tap Cut, the selected text is removed

from the text field. In this case, the text is saved to

the clipboard, so that you can paste it into another

text field.

3. Pasting the text

1. Cut or copy the text to paste.

2. Tap the text field where you want to paste the text and

move the cursor to your desired location.

• You can paste text that you copied from one

application into the text field in any other application.

3. Tap and hold then select Paste in the pop up menu.

• The text is inserted after the cursor. The text also

remains in the clipboard, so you can paste that

same text into another location.

Getting Started

Google Account

You must sign in to a Google account to use Gmail,

Google Calendar, and other Google applications; to

download applications from Google Play Store; to back up

your settings to Google servers; and to take advantage of

other Google services on your phone.

1. Registering a Google account

Gmail, Google Play Store, and other applications require

a valid Google account for use. You will be prompted to

1. Tap Existing>Sign in to register your Google account.

• If you don’t have a Google account, tap New instead.

See the next section for more details.

2. Enter your Google account Email and Password > Tap

2. Creating a new Google account

1. Tap New > Enter First name, Last name and Email >

Tap Next.

2. Enter a password in to the Type a password, Confirm

password fields, then tap Next.

• Password tip: Your password must be a minimum

of 8 characters in length.

3. Select Security question and enter the Answer,

which will be needed if you forget your password and

then enter a Secondary Email >Create.

4. Read through Google Terms of Service > Tap I agree,

Next.

5. Enter the letters shown on the screen > Tap Next >

Tap Finish.

3. Adding a Google account

1. From the Home screen, tap Apps >Settings.

2. Tap Accounts >Add account.

3. Tap Google > Tap Existing.

4. Tap Sign in to register your Google account.

5. Enter your Google account Email and Password > Tap

• The UL40 supports multiple Google accounts.

• If you have the same contact across multiple Google

accounts, you can merge duplicates into a single

item in the contact list.

Getting to Know the

Home Screen

1. The Home screen is displayed when the device is in

idle mode. You can add your favorite apps, shortcuts,

folders and widgets to the Home screen so they’re only

a tap away.

2. Press Home to return to the center home screen.

1. Previewing the Home screens

1. From any Home screen, tap and hold an application.

2. When you choose a desired Home screen, the

application shifts to the selected Home screen.

Customizing the Home Screen

The Home screens and display wallpaper are customizable.

1. Home screen customization options

Open the Home screen you want to customize.

2. Moving an item on the Home screen

1. From the Home screen, tap and hold the item you want

to move until it vibrates. Don’t lift your finger.

2. Drag the item to a new location on the Home screen.

3. Lift your finger at the location where you want the item.

To add a shortcut for any application to a Home screen,

tap Apps, tap and hold the item, then drag it onto a

Home screen.

3. Removing an item from Home screen

1. From the Home screen, tap and hold an item until it

vibrates. Don’t lift your finger. The × Remove icon will

appear at the top of the display.

2. Drag the item to × Remove.

3. When the item turns blue, lift your finger.

4. Changing the Wallpaper of Home screen

1. From the Home screen, tap and hold any empty area

on a Home screen long time.

2. Tap WALLPAPERS:

From the list of menus, choose a photo from your

camera gallery or memory card storage.

3. Tap Set wallpaper.

10"

Essential Display Icons

1. Status icons

You can tell a lot about your phone when you

understand the icons in the Status bar.

Here’s what each one means:

Signal strength

Synchronized with the

web

No signal

Vibrate only mode

3G network

connected

Speakerphone is on

Wi-Fi signal

strength

Silent mode-no audio

or vibration

Airplane mode

Microphone is muted

Data

synchronizing

It indicates that battery

is remaining

(Empty to full charge

states)

Bluetooth is on

Connected to a

computer via USB

cable

Storage is

insufficient

2. Notification icons

Notification icons in the Status bar alert you to items that

may require your attention such as new messages,

calendar event reminders, missed call notifications, etc.

Here’s what each one means:

Call in progress

Downloading data

Missed call

Uploading data

(animated)

Call Diverted

General Warning

Icon

More (not

displayed)

notifications

No microSD card

installed

New

Google Talk

instant message

MicroSD card is

being prepared

New voicemail

Upcoming event

New message

Alarm is set

New Gmail

Wi-Fi is on and

wireless networks

are available

Connected to or

disconnected

from VPN

Song is playing

New Email

11"

Notifications Panel

When you receive a new notification, an icon will be

displayed in your status bar at the top of your screen.

1. Viewing and responding to Notifications

1. Tap and hold Status bar, and then slide your finger

downward to open the Notifications panel.

2. If you have multiple notifications, you may need to

scroll to see them all.

3. Tap a notification to respond to it.

2. Closing the Notifications panel

Drag the bottom bar of the panel up.

Or just press Back.

Opening & Switching Between

Applications

1. Opening and closing the Applications List

1. From the Home screen, tap Apps.

2. To close, press Home or Back.

2. Switching to a recently used application

1. From any screen, tap Recent apps. Scroll to see

all recently used application.

2. Tap an icon to open the application or press Back

to return to your previous screen.

12"

Sleep Mode

Sleep mode saves battery power by turning off your display.

You will still receive messages and calls when the display is

turned off.

1. Switching to Sleep mode

1. Press Power/Lock to switch your phone to Sleep

mode.

2. Your phone automatically turns off the display after a

period of inactivity. To customize the screen timeout

settings, from the Home screen, tap Apps >

Settings >Display >Sleep.

2. Waking up from Sleep mode

1.Your phone automatically wakes up when you have an

incoming call.

2. To wake it up manually, press Power/Lock. You’ll

need to unlock the screen as described below.

3. Unlocking the screen

On the lock screen, tap the unlock icon and slide

your finger in the direction of the arrows to unlock the

screen. The screen unlocks automatically when you

answer an incoming call.

NOTE If you have set up a screen unlock pattern, pin, or

password, you will be asked to draw the pattern on the

screen or enter the PIN or password to access the phone

software.

4. Activating Secure Screen Lock

1. From the Home screen, tap Apps >Settings.

2. Tap security >screen lock.

• If you have already configured the screen lock, tap

screen lock to change how to lock or unlock your

screen.

3. Tap Pattern, PIN, Password, or Face Unlock. Then

enter a custom pattern, PIN or password as prompted.

• If you select ‘None’, screen unlock security is

cancelled

13"

Adjusting Volume

Ringtone and Media volume are independent of each other

and adjusted separately.

1. Adjusting the ringer volume

From the Home screen, press Volume up or Volume

down on the right side of the phone to adjust the ringer

volume to your desired level.

• While in the lowest ringer volume level, press

Volume up or Volume down once to set your

phone to Vibrate mode. To set your phone to Silent

mode, you can press Volume down once again.

• While in the Silent mode or Vibrate mode, press

Volume up once to switch to ringtone mode.

2. Adjusting the media volume

While playing music, watching a video or using

preloaded or downloaded games or applications, press

Volume up or Volume down on the right side of the

phone to adjust the media volume.

3. Adjusting the earpiece volume for

phone calls

During a phone call, press Volume up or Volume

down.

4. Adjusting the volume via Settings menu

1. From the Home screen, tap Apps >Settings.

2. Tap Sound > Volumes.

3. Drag the volume sliders left or right to adjust your

phone’s Ringtone, Media, and Alarm. Your phone

plays a sample tone at the selected volume level

while you drag the slider.

4. When you’re done, tap Back or Home.

Searching Your Phone

and the Web

The search key is a powerful part of the UL40’s software

and enables you to quickly locate files, contacts, and

applications. You can also search the web using your

favorite web search service.

1. Tap Apps > Google.

2. Begin entering text, or tap a previously used search

term.

• As you enter the text, matching items on your phone

and suggestions from Google web search will appear

on the screen.

3. Tap a suggestion to go directly to that result.

14"

Connecting Your Phone

to a Computer

1. Copying files to and from

the microSD card

You can copy your music, photos, and other files to

the microSD card of your phone.

NOTE This option is available only when a microSD card is

inserted into the slot of your phone. While your phone is

connected to a computer, USB Mass storage mode

prevents you from using applications that access the

memory card.

1. Connect your phone to your computer using the supplied

USB cable.

2. Open the Notifications panel >tap USB options.

3. On your computer, the connected phone is recognized as

a removable hard drive.

4. Navigate to the removable drive and open it.

5. Do one of the following:

• Copy the files from the computer to the microSD card’s

root folder.

• Copy the files from the phone’s microSD card to a folder

in your computer.

6. After copying the files, un-mount the removable drive

(that is, your phone) as required by your computer’s

operating system to safely remove your phone.

7. After you have un-mounted the removable drive, you can

disconnect the phone from the computer.

15"

Phone Calls

Making Calls

The simplest way to make a call is to dial the number

directly. You can also call numbers listed in your call log or

Contacts list.

1. Making a call from the dialer screen

1. From the Home screen, tap Phone.

Or tap Apps >Phone.

2. Tap the number you want to dial.

• If you make a mistake, tap to erase a single

character. Tap and hold to erase the entire string.

3. Tap Dial.

• The Calling screen is shown and appears in the

Status bar while the call is active.

• To change the volume during a call, press Volume up /

Volume down.

4. To end the call, tap End Call.

2. Entering a Pause/Wait

Pause and wait options can help you dial additional

numbers such as a voicemail password, or phone

banking system menus.

1. From the Home screen, tap Phone.

2. Tap the number you wish to dial > tap Option

>Add 2-sec pause or Add wait.

• Add 2-sec pause: Your phone will wait for 2 seconds

then continue to dial the remaining

numbers automatically.

• Add wait: Your phone will wait with the message,

‘Send the following tone?’ until Send is

tapped, then continue dialing the

remaining numbers.

3. Making an international call

1. From the Home screen, tap Phone.

2. Tap and hold 0 until the international prefix ‘+’ appears.

3. Tap the country code, area code, and phone number.

4. Tap Dial.

4. Calling a number from the Call log

Your phone logs all incoming and outgoing calls.

1. From the Home screen, tap Phone > Call log.

2. Tap Dial at the right of any entry to dial.

• Calls are listed with the most recent at the top.

• Calls to the same phone number are grouped together.

• Scroll up or down to view additional entries in the log.

• If you want to edit a number before calling, tap

and hold the desired number, and then tap Menu

>Edit number before call.

5. Making a call from the Contact list

1. From the Home screen, tap Phone > . Or tap

Apps >People.

2. Scroll through the contact list.

• To find a specific contact, you can search by tapping

Search. Enter the name of the contact you’re

searching for. As you type, contacts with matching

names appear below the search box. Or you can use

the tab on the right hand side of the screen to scroll

through the alphabetical contacts.

3. Tap the contact you want to call.

4. Tap the phone or mobile number.

16"

6. Making an emergency call

Your phone supports international emergency numbers

such as 911. Emergency calling is supported anywhere

the phone has a network signal.

1. Making an emergency call

1. From the Home screen, tap Phone.

2. Tap the emergency number for your location.

This is usually 911, *911 or #911.

3. Tap Dial.

4. To end the emergency call, tap End Call.

2. Making an emergency call

while the phone is locked

1. When your phone is no service status, Emergency

call button is displayed on the lock screen.

Tap Emergency call.

2. Tap the emergency number for your location. This is

usually 911, *911 or #911.

3. Tap Dial.

4. To end the emergency call, tap End Call.

Answering or Rejecting Calls

When you receive a phone call, the screen displays the

caller’s name, phone number, and caller ID icon (if stored

in Contacts). When you receive a phone call from a

phone number not stored in your Contacts, only the

default caller ID icon and phone number are shown.

All incoming calls are recorded in the Call log.

If you miss a call, you receive a reminder notification.

1. Answering or rejecting an incoming call

1. Drag the icon in the direction of the arrows

to answer the call.

• If you were already in a call, the first call is placed on

hold during answering the new call.

• To silence the ringer before answering the call, press

either of the volume keys.

NOTE The caller you reject is sent directly to your voicemail box to

leave a message.

2. Checking missed calls

• If you miss a call, is displayed in the Status bar.

• If you open the Notifications panel, you will see the

number of missed calls. Tap the notification to be

taken to the call log and view detailed information.

17"

Using In-Call Options

When a call is in progress, the following options are

available:

NOTE To avoid damaging your hearing, do not hold the phone up to

your ear when the speakerphone is on.

Using Call Log

The phone stores the numbers of all incoming and

outgoing calls in the Call log. The Call log displays the

details of the call including time, date, and duration.

1. Opening the Call log

1. From the Home screen, tap Phone >Call log.

• Calls are listed with the most recent at the top.

Calls of the same phone number are grouped

together. Scroll to view earlier entries in the log.

NOTE You can tap and hold the desired number in the call log

list to select options such as Call, View contact, Edit

number before call, Send a message, Add to contacts,

Call details, Copy number, Block number.

Dial Pad

Tap Dial Pad to enter additional numbers

during your call.

Mute

You can unmute the microphone by tapping

Mute icon again.

Audio

You can turn the speakerphone off by tapping

the Speaker icon again.

The speaker is turned off automatically when

your current call ends.

Bluetooth

When a Bluetooth device is paired and

connected to your phone, you can conduct all

calls using Bluetooth for hands-free

conversation. When using Bluetooth headset

during a call, the current call screen has a blue

border and the Ongoing Call icon turns blue in

the Status bar.

Tap Bluetooth icon to toggle in-call audio to

and from the Bluetooth accessory.

18"

2. Calling a number from the Call log

1. From the Home screen, tap Phone > Call log.

1. If you want to call a number directly, tap at the right

of the entry. Or select a contact > tap Dial

• If you want to edit a number before calling, tap

and hold the desired entry, and then tap

Option >Edit number before call.

3. Adding a phone number from your

Call log to your Contacts list

1. From the Home screen, tap Phone > Call log.

2. Tap the desired entry >Add to contacts.

3. In the list of contacts that opens, tap Create new

contact or add to an existing contact.

4. Tap Done.

4. Sending a text message from the Call log

1. From the Home screen, tap Phone > Call log.

2. Tap the contact > Send text message.

3. Enter your message and tap to Send.

5. Clearing the Call log

1. From the Home screen, tap Phone > Call log.

2. Tap Option >Call log>Tap >Clear call log

>OK.

• To remove just one entry from the Call log, tap the

entry. In the pop up options, tap Call details >click

Delete icon>OK.

Listening to Your Voicemail

Voicemail application is displayed only when phone calls

are available. When you have a new voicemail message,

appears in the Status bar.

1. Calling your voicemail from the Dial Pad

1. From the Home screen, tap Phone.

2. Tap your phone number and tap Dial.

2 Calling your voicemail from the

Notification panel

1. Open the Notifications panel and

tap ” New voicemail”.

Using Voice Dialer

You can use the Voice Search application or Voice Dialer

application to place a phone call by speaking the name of

a contact or a phone number.

1. From the Home screen, tap Phone > Search

contacts.

• If you have a Bluetooth headset that supports

“voice-recognition” or “voice-dialing,” you may be

able to open Voice Search by pressing and holding

your headset’s main button and dial by voice using

your headset. For details, see your headset

manual.

2. Say the name of the contact you want to call

• Or, follow one of the suggestions for dialing a number

or controlling your phone in other ways.

19"

Contacts

About contacts

Contacts give you quick and easy access to the people you

want to reach. Contacts from Google accounts are also

downloaded and synced with the Contact list.

You can manage your communications with your contacts

via phone, messaging, and email without the need to

jump from one app to another.

Opening Your contacts

Open contacts to add, view, and communicate with

your friends and acquaintances.

1. From the Home screen, tap Apps >contacts.

• All of your contacts are displayed alphabetically in a

scrolling list.

• You can use the tab on the right hand side of

the screen, or flick your finger up or down to

scroll quickly.

Getting Started

1. Adding a new contact

1. From the Home screen, tap Apps >contacts.

2. Tap ALL> .

3. If you have more than one account, select an account

then enter the information for the contact.

• Tap > select Take photo or Choose photo from

Gallery to add a picture.

• Enter your contact’s information.

4. Tap Done.

Saving a phone number from the Dial Pad

1. From the Home screen, tap Phone.

2. Enter the number >Tap Create new contact.

3. Enter the information for the contact>tap Done.

Storing a contact using Call log

1. From the Home screen, tap Apps > Phone.

2. Tap Call log >tap the number you want to save

>Add to contacts.

3. Tap Create new contact or select an existing contact.

4. If you have more than one account, tap the account

where you want to save the contact >enter the

information for the contact > tap Done

2. Importing / Exporting / Sharing contacts

Importing contacts from your microSD card

If you have contacts stored in vCard format on the

microSD card, you can import them into Contacts on your

phone.

1. From the Home screen, tap Apps >contacts.

2. Tap Option >Import/Export.

3. Tap Import from .vcf file.

4. If you have more than one account on your phone,

select the desired account.

5. Tap the vCard files on the microSD card. The contacts

are imported.

Exporting contacts to your microSD card

1. From the Home screen, tap Apps >contacts.

2. Tap Option >Import/Export.

3. Tap Export to .vcf file.

4. Select contacts, tap OK to confirm.

• This process creates a file containing all your selected

contacts with a .vcf extension on your microSD card.

20"

Sharing visible contacts

1. From the Home screen, tap Apps >contacts.

2. Tap Option >Import/Export.

3. Tap Share all contacts > Select Bluetooth,

Gmail.

3. Viewing details about a contact

1. From the Home screen, tap Apps >contacts.

2. Tap the contact whose details you want to view.

3. Tap the communication icon to start dialing, texting, or

emailing the contact.

4. Search for a contact

1. From the Home screen, tap Apps >contacts.

2. Tap Search.

3. Start entering the contact’s name.

As you type, contacts with matching names appear

below the search box.

4. Tap the matching contact in the list to open

21"

Editing/Deleting Contacts

1. Editing contact details

1. From the Home screen, tap Apps >contacts.

2. Tap the contact you want to edit >Tap Edit

contact.

3. Edit the contact information.

4. Tap Done.

2. Setting a contact’s default phone

number/email

Setting a contact’s default phone number

The default phone number is used when you initiate a

call or text message by tapping and holding a contact.

1. From the Home screen, tap Apps >contacts.

2. Find the desired contact > Tap and hold the phone

number to designate it as the default phone number.

3. Tap Set default.

• The default phone number is indicated with a

checkmark.

Setting a contact’s default email

The default email is used when you send an email from

the list by tapping and holding a contact.

1. From the Home screen, tap Apps >contacts.

2. Find the desired contact > Tap and hold the email

address to designate it as the default email address.

3. Tap Set default.

• The default email is indicated with a checkmark.

3. Setting a ringtone for a contact

1. From the Home screen, tap Apps >contacts.

2. Tap the desired contact> Tap Edit contact.

3. Tap Option >Set ringtone.

• Tap a ringtone from the list to play when the contact

calls. A sample of the ringtone is played.

4. Tap OK.

4. Adding a contact to your favorites

1. From the Home screen, tap Apps >contacts.

2. Tap the desired contact >Tap .

• To remove a contact from your favorites list, tap

contacts >tap the desired contact >Tap .

5. Linking contacts

1. From the Home screen, tap Apps >contacts.

2. Tap the contact you want to save. The others will

merge into this file. This is the contact you will see in

contacts after linking.

3. Tap Edit contact > Tap Option >link.

4. Tap the contact you want to join with the first contact.

The information from the second contact is added to

the first contact, and the second contact is hidden.

6. Deleting a contact

1. From the Home screen, tap Apps >contacts.

2. Tap the contact you want to delete,

tap Option >Delete.

3. Tap OK.

22"

Communicating

1. Sending text message

1. From the Home screen, tap Apps >contacts.

2. Tap and hold the contact you want to send >tap .

• The Primary Phone Number is used, or you

are prompted to choose a phone number.

2. Making calls

1. From the Home screen, tap Apps >contacts.

2. Tap and hold the contact to call >tap the number.

• The Primary Phone Number is used, or you are

prompted to choose a phone number.

3. Connecting by using Quick Contact

1. From the Home screen, tap Apps >contacts.

2. Tap the icon or photo next to your desired contact >tap

the desired communication method.

• Only the icons relevant to your contact’s data

are displayed.

• If there are too many icons to fit on the screen, drag

to the left or right to select an icon.

Account Setting

1. Working with Google accounts

1. From the Home screen, tap Apps >contacts.

2. Tap Menu >Manage accounts.

• After registering your Google account, your online

Google contacts are synchronized to your phone.

Changes made online or on the phone are

automatically synchronized and updated in both

locations. This address book will be used throughout

the user interface.

• If you register two or more accounts, you can merge

address books from the multiple accounts into one

address book.

2. Contact List Display and Settings Options

1. From the Home screen, tap Apps >contacts.

2. Tap Option >Contacts to display.

• All contacts display in the contacts list.

3. Tap Option >Settings.

• Sort list by: Select First name or Last name.

• View contact names as:

Select First name first or Last name first.

• About Contacts: Build version, Open source licenses,

23"

Messaging

About Messaging

Use Messaging to send text messages (SMS) and

multimedia messages (MMS) to other mobile phones and

email addresses.

1. From the Home screen, tap Apps > Messaging.

On the Messaging screen, your sent and received

messages are neatly grouped into conversations, by

contact names or phone number. You can:

• Scroll up or down the list of conversations by flicking

your finger on the screen.

• Tap a contact name or number to view the

conversation history.

• Tap the photo or to open additional menu options.

Sending Messages

1. Sending a Text Message

NOTE Depending on your billing plan, if you exceed the single

text message character limit, you will be billed for multiple

messages.

1. From the Home screen, tap Apps > Messaging.

2. Tap Create New message.

3. Enter the phone number in the To field. Fill in one or more

recipients. You can:

• Enter the first few letters of a contact name or phone

number. Matching contacts are displayed. Continue

typing or tap a name or phone number from the search

results.

• Tap > Select message recipients from your contact

list >Ok.

4. Tap Type message >enter your message.

• Tap Menu to see more options.

Add subject

Add subject.

Attach

Attach Media Files or a Slideshow

within the message.

Send

Send the message.

Insert smiley

Insert a smiley in the message.

Discard

Delete the message in progress.

Import Temple

Some default text

5. Tap to Send.

• Tap Back to save the message as a draft.

NOTE Your text message automatically becomes a multimedia

message on below condition:

• Add subject

• Attach an item

24"

2. Sending a multimedia message (MMS)

To compose a multimedia message, start by creating a

new text message. Then simply add an attachment.

1. From the Home screen, tap Apps > Messaging.

2. Tap Create New message.

3. Enter the phone number in the To field.

Or select recipients from the contact list.

4. Tap Type message > enter your message.

Tap to add the message template.

5. Tap Attach > choose the type of attachment.

• Pictures

Select a photo.

• Capture picture

Capture a new photo.

• Videos

Select a video.

• Capture video

Record a new video.

• Audio

Select an audio file.

• Record audio

Record a new audio file.

• Slideshow

Create a slideshow from up to 10

of your photos.

6. From the message body, tap:

• View: To view the attached item.

• Replace: To change attached files.

• Remove: To remove attached files.

7. Tap Send MMS.

• Tap Back to save it as a draft.

3. Resuming a draft message

1. From the Home screen, tap Apps > Messaging.

2. Tap the message indicated by “Draft” to resume

editing.

3. When you finish editing, tap Send.

Reading Messages

1. From the Home screen, tap Apps > Messaging.

2. Tap a message thread.

3. Tap and hold an individual message to see more

options.

Save to SIM card

To save the message to SIM card.

Call icon

To call the message sender

Add to Contacts

To save the phone number or email

address to Contacts. (Only on

messages from unkown number)

Forward

To forward a message. Enter a

recipient, edit the content of the

message as needed >tap Send.

Copy message text

To copy text from a message.

View message details

To view details about a message.

Delete message

To delete a message.

1. Deleting a message thread

1. From the Home screen, tap Apps > Messaging.

2. Tap and hold to select the message thread, tap

Delete thread.

• If you want delete all message threads, tap and hold a

message thread and select all,

tap Delete all threads.

3. Tap Delete.

2. Searching messages

1. From the Home screen, tap Apps > Messaging.

2. Tap Search to search.

3. Enter the search term >tap Search.

25"

3. Replying to a message

1. From the Home screen, tap Apps >

Messaging.

2. Tap the received message > tap Type message >

enter your message.

3. Tap Send.

Receiving Emergency Alerts

Messages

Emergency Alerts service allows you to receive automatic

alerts in times of crisis (e.g., earthquake, hurricanes, etc.).

Wireless Emergency Alerts (WEA), also known as CMAS, is

a part of a national alerting system called IPAWS

(Integrated Public Alert and Warning System) that enables

emergency management officials to rapidly disseminate the

warnings and safety information via text alerts to wireless

phones based on the phones’ geographic location, The

Federal Emergency Management Agency or FEMA is

responsible for receiving the alerting information and

forwarding the alerts to participating wireless carriers such

as Sprint. Such alerts may come from the President of the

United States; the National Weather Service, state or county

public safety officials. This system is integrated into the

same national alerting services that serve television and

radio today. For more information regarding WEA/CMAS

please go to: FEMA website.

http://www.fema.gov/emergency/ipaws/projects.shtm#6

1. Receiving Emergency Alerts Messages

1. From the Home screen, tap Apps > Messaging.

2. Tap Emergency alerts message you want to view.

Emergency alert messages are indicated with

Emergency alert icon.

• If Emergency alert arrives on your phone during a

call, is displayed in the Status bar. If Presidential

Emergency Alert, emergency alert icon will flashes. If

non-Presidential, Emergency alert icon is static icon.

• Only the Presidential Emergency Alert icon is displayed

under the Time/Date on the unlock/lock screen.

• If you are on an Emergency alert message screen

in the Messaging application, the following

options are removed or disabled : Reply,

Forward, and Call.

• If you have power cycled your phone and a Presidential

Emergency Alert has not been viewed, the Presidential

Emergency Alert icon will continue to flash when the

device is powered on again.

26"

Changing Messaging Settings

1. From the Home screen, tap Apps >

Messaging.

2. Tap Option >Settings.

1. Storage settings

Delete old

messages

Check to delete older messages in a

thread when messaging memory or

thread limits are reached. Uncheck to

keep all messages. You may need to

manually delete messages if the

messaging memory limit is reached.

Text

Message

limit

Tap to set the number of messages to

save per message thread. When the limit

is reached, older text messages are

deleted if ‘Delete old messages’ is

checked.

Multimedia

message

limit

Tap to set the number of multimedia

messages to save per message thread.

When the limit is reached, older

multimedia messages are deleted if

‘Delete old messages’ is checked.

2. Multimedia message (MMS) settings

Auto-retrieve

Uncheck to download only the heading

of multimedia messages. You will need

to tap the MMS message heading and

manually download each MMS

message. You may want to use this

feature when roaming or when

connected to a slow data network.

MMS Validity

period

Set MMS Validity period to Maximum or

Two days

3. Notification settings

Sound

Select a ringtone to sound when you

receive new message notifications.

Vibrate

Set the phone to vibrate every time you

receive a new message notification,

only when silent mode, or never.

4. Receive Emergency Alerts

Show extreme

threats

Set to receive Extreme Emergency Alerts.

Show Severe

alerts

Set to receive Severe Emergency Alerts.

Show Amber

alerts

Set to receive Amber Emergency Alerts.

Turn on

notifications

Set to display emergency alert broadcasts

Alert

reminder

Set alert reminder to once, every 2

minutes, every 15 minutes or off

Speak alert

message

Set to use text-to-speech to speak

emergency alert messages

27"

Google

Gmail

1. Opening your Inbox and Reading your

Gmail

The inbox is your default Gmail view. All your received

emails are delivered to your inbox.

1. From the Home screen, tap Apps > Gmail.

2. Tap the email you want to read.

• Tap to star the email.

• If the sender is a friend in Google Talk, you can

see your friend’s online status.

• Tap Archive to archive the message.

• Tap Delete to delete the message from your inbox.

• Slid left and right to see the previous or next message

in the list.

Replying to or forwarding an email message

1. From the Home screen, tap Apps > Gmail.

2. When reading a message:

• To reply to the sender, tap .

• To reply to all message recipients, tap Option >

Reply all.

• To forward the message, tap Option > Forward.

2. Sending a new email

1. From the Home screen, tap Apps > Gmail.

2. From any message list, tap .

3. Enter a name or address in the To field.

To send the email to several recipients,

separate each email address with a comma.

4. Enter a subject in the Subject field.

5. Type the message text in the Compose Mail field.

• To attach an image file, Tap Option >Attach

file>select the picture you want to attach.

6. Tap Send.

• To save the message as a draft, tap Option >Save

draft.

3. Working with Multiple Email Messages

You can archive, delete or label groups of email

messages at the same time.

1. From the Home screen, tap Apps > Gmail.

2. From any message list, check the box next to the

email messages you want to work with.

Tap Archive to move messages out of your inbox

without deleting. Archived emails are assigned the All

Mail label.

• Tap Delete to delete selected messages.

• Tap Labels > select the labels that you want to assign

>tap OK.

4. Switching between Google accounts

If you have set up two or more Google Accounts on your

phone, you can switch between them in Gmail. Gmail

displays only one Google Account at a time. The current

account is shown at the top right of any message list.

1. From the Home screen, tap Apps > Gmail.

2. From any message list, tap Option >Accounts.

3. Tap the account that you want to view. You can also

tap the account name at the top of the screen to see

a list of your accounts.

28"

5. Labeling email messages

You can organize your emails by label. Gmail has preset

labels. Or you can create your own labels in Gmail when

viewed on a computer. (Note: Custom label colors

created on the web are not supported on your phone).

Labeling an email

1. From the Home screen, tap Apps > Gmail.

2. When reading a message, tap >Change labels.

3. Select a label > tap OK.

6. Viewing emails by label

1. From the Home screen, tap Apps > Gmail.

2. From any message list, tap >Go to labels.

3. Tap a label to view matching email messages.

7. Starring/un-starring an email message

You can star an important email to make it easy to find

again. Starred emails are assigned the Starred labels.

1. From the Home screen, tap Apps > Gmail.

2. From any message list:

• Tap to star a message.

• Tap to un-star a message.

Maps

Use Maps to find your current location and get directions.

You can search for addresses, landmarks and businesses

directly on a street map or satellite image.

NOTE You need an active mobile data or Wi-Fi connection to use

Maps. To see your location and get directions, you must turn

on location services. From the Home screen, tap Apps >

Settings >Location services. Select one or both from

Use wireless networks or Use GPS satellites. Maps may

not be available for all locations.

1. Opening and viewing Maps

Viewing your location

1. From the Home screen, tap Apps > Maps.

2. Shows your location on the map and points north for

your reference.

Using Maps

1. From the Home screen, tap Apps > Maps.

2. While viewing a map, swipe to any direction on the

screen.

2. Viewing location details

Viewing information for a location

1. From the Home screen, tap Apps > Maps.

2. While viewing a map, tap and hold a location, starred

place, or a search result on the map.

• A balloon opens over the location, with summary

information.

3. Tap the balloon to see the address or more

information.

Starring or un-starring a location

Add a Star to bookmark and easily return to a map

location.

1. While viewing detail information for a location,

• Tap to star the location.

• Tap to un-star the location.

29"

Viewing a location in Street view

Street view mode provides a street-level view of the

location. Street view may not be available for all areas

1. From the Home screen, tap Apps > Maps.

2. While viewing detailed information for a location, tap

• To view surrounding areas, swipe the screen in any

direction.

3. Searching for a location

You can search Google Maps for specific locations,

company names, or business types.

1. From the Home screen, tap Apps > Maps.

2. Tap Search.

3. Enter the search criteria. As you type, suggested

matches from your contacts, the web, and previously

searched items are displayed.

• Tap to search

• Tap a suggested search term.

4. The search results are displayed as markers with

letter labels on the map.

• Tap markers and titles to view more information.

• Tap to show the search results as a list >tap each

item to see more information.

4. Viewing map layers

Initially, Google Maps opens with a street map. You can

view additional map layers, such as satellite images

and traffic information. You can also view custom Web

created Google Maps.

1. From the Home screen, tap Apps > Maps.

2. Tap Option >Layers. A dialog opens with a list

of layers.

3. Turn layers on or off by tapping the layer name. A

check mark indicates the layer is selected.

• Tap Option > Clear Map to deselect all layers.

Layers may change the map entirely or overlay additional

information. Tap icons or interactive items to explore

different layer types.

5. Getting directions

1. From the Home screen, tap Apps > Maps.

2. Tap >Directions.

3. Use your current location as the starting point, or enter

a location in the Start point field.

4. Enter your destination in the End point field.

5. Tap or or to select your transportation

method > tap Get directions.

Calendar

The Calendar application data on your phone syncs with

the web-based Google Calendar service. It is also

compatible with Microsoft Exchange ActiveSync Calendar.

1. Opening Calendar

1. From the Home screen, tap Apps > Calendar.

Events are color coded to enable you to distinguish

between multiple calendars. Events times are shown

using your local time zone, which is provided by your

active mobile network. When traveling, you may

want to set a home time zone in Calendar.

2. Creating an event

Events created on your phone will be synced to Google

Calendar or Microsoft Exchange automatically.

1. From the Home screen, tap Apps >Calendar.

2. There are two ways to create an event:

• Tap Option >New event.

30"

• In Day, Week, or Month view, tap and hold the screen

at the date and/or time you want >New event.

3. Enter the name, time, location, description, and

optional additional details for your event.

• If you have more than one calendar, choose the

calendar to which to add the event.

• In the Guests field, enter email addresses of anyone

you want to invite. Separate multiple addresses with

commas (,). If your invitees use Google Calendar,

they’ll receive an invitation in Calendar and by email.

• If the event occurs on a regular basis, tap the

Repetition box and choose the reoccurrence

information.

• You can set multiple reminders for an event.

4. Tap Done.

3. Viewing calendar and events

Changing calendar view

When you open Calendar, Month view is shown by

default. You can also view the Calendar by Agenda, Day,

or Week.

1. From the Home screen, tap Apps > Calendar.

2. Tap Option > Settings >General settings choose the

type of view that you want

Day

Displays a chart of the events of one day, in a

table of one-hour rows, All-day and multiday

events are displayed at the top. Each event is

displayed at the corresponding time. Swipe left

or right to change dates, and swipe up or down

to view earlier or later times.

Week

Displays one week calendar. All-day and multiday

events are displayed at the top. Swipe left or right

to change weeks, and swipe up or down to view

earlier or later times.

Month

Displays a chart of the events of the month.

Events are shown as blue bars on each calendar

date. Swipe left or right to change months.

Agenda

A list of your events in chronological order.

All-day and multiday events are listed at the

start of each day. Days without events are

not shown. Flick up or down to view earlier

or later events.

Today

Displays a chart of the events of today.

Option

You can select New event, Calendars or Settings.

Viewing event details

• In Day, Week, or Agenda view, tap an event.

• In Month view, tap a day to switch to Day view >

tap an event.

4. Editing or deleting an event

1. In event details view, press the event > Edit event to

edit the event.

2. Make your changes to the event > tap Done.

• To delete the event, press the event > Delete event

> tap OK.

5. Synchronizing and displaying calendars

You can select which calendars to show or hide on your

phone’s Calendar, and which ones to synchronize.

1. From the Home screen, tap Apps >Calendar.

31"

2. Tap Option >Calendars to display.

All the calendars you’ve added or subscribed to are

displayed. (Calendars for accounts you’ve configured

not to synchronize are not included in the list.)

3. Tap the icon next to a calendar to change storage and

visibility settings.

Calendar events stored on phone and visible in

Calendar.

Calendar events stored on phone but not visible

in Calendar.

Calendar events not synchronized to phone.

4. Tap OK.

6. Changing Calendar settings

1. From the Home screen, tap Apps >Calendar.

2. Tap Option >Settings.

Calendar

view

setting

Hide declined

events

Check if you don’t want to see

events to which you’ve declined

invitations.

Use home time

zone

Displays calendars and event

times in your home time zone

when traveling.

Home time zone

If Use home time zone is

checked, you can set home time

zone.

Week

number

setting

Display week

number

Check if you want to see week

number in Calendar.

First week

of year

If Display week number is

checked, you can set first week

of year.

Reminder

settings

Set alerts &

notifications

Configure event reminders.

Select ringtone

Select which ringtone will sound

when you receive an event

reminder.

Vibrate

Configure the phone to vibrate

whenever you receive an event

reminder.

Default reminder

time

Select the default reminder time

used when creating new calendar

events.

32"

Play Music

Play music and audio files with Music application.

NOTE You need to copy music files to your microSD card to use the

Music application.

1.Viewing your music library

1. From the Home screen, tap Apps >Play Music

2. You can select library to open at the bottom of the

screen.

• You can view the lists of music in the microSD card.

• The lists are automatically organized according

information contained in the music files. To view

each list of music, you can tap the corresponding

category; Artists, Albums, Songs, Playlists or

Genres.

Google Play Store

Google Play Store provides direct access to applications

and games to download and install on your phone. To

access Google Play Store, you must first sign into your

Google account using a Wi-Fi or data connection. When

you open Google Play Store for the first time, you must read

and accept the terms of service to continue.

1. Finding applications

1.Browsing applications

You can browse and sort applications by category.

1. From the Home screen, tap Apps > Play Store.

2. Tap GAMES, BOOKS & REFERENCE, BUSINESS or

COMICS, etc. at the left of the Market screen.

• Scroll to view subcategories and tap one to explore.

3. Tap the subcategory you want.

2.Searching for applications

1. From the Home screen, tap Apps > Play

Store.

2. Tap at the top right of the screen to search apps.

3. Enter the name or type of app you’re looking for >tap

to search.

3.Viewing details about an application

1. While browsing Google Play Store, or in a list of search

results, tap an application to view more details.

Application details screens include a description, ratings,

and specific information about the application. The

Comments tab includes comments from people who have

used the application. You can download and install an

application from this screen.

33"

2. Installing applications

1.Installing an application

1. From the Home screen, tap Apps > Play Store

2. Find the application you want to purchase and view the

application details.

3. Tap Download to download and install the application.

For paid applications, the download button is labeled

with the application’s price. Tap the price to buy the

application. The subsequent screen notifies you

whether the app will require access to your personal

information or access to certain functions or settings of

your phone.

1. Tap Accept & download to begin downloading and

installing the app. If you selected a paid app, you will

be redirected to the Google Checkout screen to pay

for the app before it’s downloaded to your phone.

NOTE Be cautious when downloading apps that have access to

phone functionality or a significant amount of personal

data. You’re responsible for the results of using

downloaded apps on your phone.

2. Creating a Google Checkout account

You must have a Google Checkout account

to purchase items from Google Play Store.

You can set up a Checkout account with your

first purchase from Google Play Store.

• In a web browser, go to http://checkout.google.com to

create a Google Checkout account.

• From the phone, you will be prompted to enter your

billing and credit card information when you buy your

first application from Google Play Store.

NOTE Once you’ve purchased something from Google Play

Store, the phone remembers your password, so you

don’t need to enter it the next time. Be sure to secure

your phone with a password to prevent unauthorized

purchases.

3. Managing your downloads

1.Viewing downloaded applications

1. From the Home screen, tap Apps > Play Store

2. Tap Option > My Apps.

In the list of the free and paid applications that opens,

you can tap an application to rate it, uninstall it,

request a refund, and more.

2. Updating an application

You can update downloaded applications.

1. From the Home screen, tap Apps > Play

Store.

2. Tap Option > My Apps > tap the application to

update.

3. Tap Update >Accept & download.

4. Tap the explanation that best matches why you’re

installing > tap Open or press Back.

The application is installed. You can uninstall the

application again at any time. If you paid to buy the

application, you will not be charged again.

34"

3. Uninstalling an application

You can uninstall applications from Google Play Store.

You can also uninstall downloaded applications from the

Settings.

1. From the Home screen, tap Apps > Settings>

Apps.

2. Tap Manage apps >DOWNLOADED > tap the

application to uninstall.

3. Tap Uninstall >OK.

4. Tap the explanation that best matches why you’re

uninstalling > tap OK.

The application is uninstalled. You can install the

application again at any time. If you paid to buy the

application, you will not be charged again.

Web

Chrome

Search for information or browse web pages using the

Chrome. To access the internet, you must have an

active data or Wi-Fi connection.

1. Opening Chrome

1. From the Home screen, tap Apps >Chrome.

• When you open the Browser, the default

homepage is displayed. If you have used the

Browser recently, your most recently viewed

webpage is displayed.

• The Browser also opens when you select a web link in

other applications like email or text messaging.

2. Accessing a webpage or searching the

web

1. From the Home screen, tap Apps >Chrome.

2. Tap the URL field on top of the screen.

3. Enter the URL of a webpage or search term and tap

“Go”.

• As you type, suggestions of web pages and key

words will appear on the screen. Tap a suggestion

to go directly to that webpage or view search

results.

3. Using Browser options

1. Stopping page loading

While webpage is loading, tap Option >Stop.

Or tap on the left of the URL field.

2. The current page

Tap Option >Refresh.

35"

3. Finding the text on the current page

1. While viewing any web pages, tap Option >Find

on page.

2. Enter the search term.

• As you type, matching characters will be

highlighted. Tap ∧or ∨to scroll to the previous or

next matching term.

4. Sharing a webpage

1. While viewing any web pages, tap Option >Share

page.

2. Tap an application to send the URL. The application

opens with the URL you’ve entered.

4. Downloading files

You can download images, files, and applications from

web pages. All downloaded files are saved to the

microSD card.

1. Tap and hold an image, a link or a file you want to

download.

2. Tap the desired action (Save image, View image, or

Set as wallpaper).

1. Navigating between webpages

• Press Back to return to the previous web pages.

Or tap Option >Forward if you pressed Back

by accident.

2. Switching between Browser windows

1. From any web pages, tap Option >Bookmarks

>tap HISTORY .

2. Tap the window to view it full screen. You can also tap

to close a window.

NOTE You can have up to 8 browser windows open at one time.

5. Using bookmarks

Browser bookmarks are stored shortcuts which allow you

to quickly access webpages without having to type in its

full address.

1. Bookmarking a webpage

1. While viewing webpages, tap Option >tap Save

to bookmarks.

2. Edit the name or location if needed >tap OK.

2. Opening a bookmark

1. When viewing any webpages, tap Option

>Bookmarks.

2. Tap a bookmark to open it.

• If you prefer to open the webpages in a new

window, tap and hold the bookmark and tap

Open in new tab.

3. Editing a bookmark

1. From any webpages, tap Option >Bookmarks.

2. Tap on the right of the bookmark to edit >Edit.

3. Edit the name and/or location >tap OK.

4. Deleting a bookmark

1. From any webpages, tap Option >Bookmarks.

2. Tap on the right of the bookmark to delete

>Delete >OK.

36"

6. Browser settings

Customize your browser settings to optimize your

browsing experience.

1. From the Home screen, tap Apps >Browser.

2. Tap Option >Settings.

General

settings

Set home page

Select the home page

Form auto-fill

Fill out web forms with a single

touch

Auto-fill text

Set up text to auto-fill in web

forms

Privacy &

Security

Clear cache

Tap it you can clear locally

cached content and databases

Clear history

You can clear the browser

navigation history

Show security

warning

If you tap it, it will show warning if

there’s a problem with a site’s

security

Accept cookies

Allow sites to save and read

cookie data

Privacy &

Security

Clear all cookie

data

Delete all cookie data

Remember form

data

Remember what you enter in form

fields

Clear form data

Delete all the information the

browser remembered

Enable location

Allow sites to request access to

your location

Clear location

access

Delete location access for all

websites

Remember

passwords

Save your passwords for some

webpages that require you to sign

in.

Clear passwords

Delete all saved passwords

Accessibility

settings

Force enable

zoom

Override a website’s request to

control zoom behavior

Text Size

Text scaling, Zoom on double-tap

and Minimum font size

Inverted Screen

Rendering

Making the black becomes white

and vice versa

Advanced

settings

Set search engine

You can choose Google, Yahoo,

Bing Etc to browse the web

Open in

background

Tap to open new tabs behind the

current tab

Enable

JavaScript

Allow JavaScript to run on web

pages.

Website settings

Set for individual websites.

Reset to default

Restore default settings

Bandwidth

management

Search result

preloading

Allow browser to pre load high

confidence search results in the

background

Bandwidth

management

Load images

Display images on web pages

Labs settings

Fullscreen

Use full screen mode to hide the

status bar

Slide Tab

Transitions

Swipe from the edge to reveal the

next/previous tab in the list

37"

YouTube

YouTube is Google’s online video streaming service

for viewing, discovering, and sharing videos.

1. Opening and signing into YouTube

1. Signing into YouTube

You can discover and watch YouTube videos

without a YouTube account, but if you want to take

advantage of many YouTube features, you must

sign into your YouTube account.

1. From the Home screen, tap Apps >YouTube.

2. Tap Option > Sign in

The first time you use a YouTube feature that

requires an account, you’re prompted to sign in.

Create a new account or enter your YouTube

account. For more information about YouTube

accounts, visit YouTube on the web.

2. Finding videos

1. Browsing videos by category

1. From the Home screen, tap Apps >YouTube.

2. Tap YouTube Trending

3. Tap a category in the scrolling list.

• Tap the current time filter setting at the top of the

category screen to change the time period and

reduce the number of videos listed.

• Tap Most viewed, Top rated, Most discussed or

Top favorite.

2. Searching for videos

1. From the Home screen, tap Apps >YouTube.

2. Tap Search.

3. Enter the search criteria >tap to search.

4. Scroll through the search results and tap a video to

watch it.

3. Watching videos

1. From the Home screen, tap Apps >YouTube.

2. Tap a video to begin playback.

• Tap the video to pause or resume playback.

• Tap Info, Related videos or Comments to learn more

about the video.

• Rotate your phone to watch the video in full-screen

view. You can also double-tap the video to toggle

full-screen view on and off.

Add to

Watch later

Bookmark the video to watch it later.

Favorites

Add the video to your Favorites.

New

playlist

Add your new playlist.

Share the video via Bluetooth, Email,

Gmail

4. Uploading videos

1. To shoot and upload a new video

1. From the Home screen, tap Apps >YouTube.

2. Tap . The Camera will open in video mode.

3. Tap to start recording > tap to stop recording.

4. Enter a title for the video and more details > tap

Upload.

2. To upload an existing video

1. From the Home screen, tap Apps > YouTube.

2. Tap Option>Upload. The Gallery will open.

3. Tap the video you want to upload.

4. Enter the title for the video and more details >tap

Upload.

38"

5. Sharing videos

1. From the Home screen, tap Apps > YouTube.

2. Tap a video to play.

3. Tap Share.

4. Tap the application you want to use to share the video.

6. YouTube settings

You can change the following settings for YouTube on

your phone.

1. From the Home screen, tap Apps > YouTube.

2. Tap Option>Settings.

General

settings

High quality on

mobile

Check if you prefer to watch

videos in high resolution by

default when connected to

mobile networks. Watch videos

in standard mode to reduce

startup time and data use. This

setting has no effect if you are

connected to a Wi-Fi network,

where videos are always

shown in higher resolution.

Caption font size

Set the preferred text size when

viewing video captions.

Uploads

Specify network preferences

for uploads.

Clear search

history

Remove previous YouTube

video search results.

settings

SafeSearch

filtering

Select if you want Google

SafeSearch filtering to block

some results when you

search for videos. Settings

are: Block no search results

(Don’t filter), only explicit or

offensive videos (Moderate),

or both explicit and

offensive text and videos

(Strict)

Preloading

Preload

subscriptions

Enable preload to fetch videos

in advance while on Wi-Fi and

charging, so you can enjoy

watching them later on slow

networks

Preload watch

later

About

Help

Open the YouTube Help Center

in your phone’s Browser.

Feedback

Open a YouTube feedback form

in your phone’s Browser.

Google Mobile

Terms of

Service

Display the Google Mobile

YouTube Terms

of Service

Display the YouTube Terms of

Service.

Google Mobile

Display the Google Mobile

YouTube

Display the YouTube Privacy

Policy.

Application

version

The YouTube application

version number installed on

your phone.

39"

Wi-Fi

1. Turning Wi-Fi on and connecting to a

wireless network

1. From the Home screen, tap Apps >Settings.

2. Tap Wireless & networks >Wi-Fi.

3. Select the Wi-Fi check box to turn Wi-Fi on.

4. The network names and security settings of detected

Wi-Fi networks are displayed.

5. Tap a Wi-Fi network to connect.

• If you selected a network that is secured, enter the

security key and then tap Connect. Depending on the

network type and security settings, you may also

need to enter more information or choose a security

certificate.

2. Connecting to a Wi-Fi network

with EAP-TLS security

You may need to install a network certificate to your phone

before you can connect to a Wi-Fi network with EAP-TLS

authentication protocol.

1. Save the certificate file to the root folder of the microSD

card.

2. From the Home screen, tap Apps >Settings.

3. Tap security >Install from SD card.

4. Select the network certificate needed to connect to the

EAP-TLS network.

5. After the certificate is installed, follow the steps in the

previous section to connect to the Wi-Fi network.

3. Checking wireless network status

1. From the Home screen, tap Apps >Settings.

2. Tap Wi-Fi.

3. Tap the wireless network that the phone is currently

connected to.

A message box is then displayed showing the Wi-Fi

network name, status, speed, signal strength, and more.

4. Connecting to another Wi-Fi network

1. From the Home screen, tap Apps >Settings.

2. Tap Wi-Fi.

3. Detected Wi-Fi networks are displayed in the Wi-Fi

networks section. To manually scan for available Wi-

Fi networks, on the Wi-Fi settings screen, tap Scan.

• To set advanced settings, on the Wi-Fi settings screen,

tap Option>Advanced.

4. Tap another Wi-Fi network to connect to it.

Downloads

Images, files and other items you download in Browser,

Gmail, is stored on your phone. You can view, manage

or delete what you have downloaded.

1. Opening Downloads

1. From the Home screen, tap Apps >Downloads.

2. Tap an item you want to view it.

• Check the checkbox of the item you want to delete and

then tap Delete.

• Tap Option to select Sort by size or Sort by date.

2. Viewing a file

1. From the Home screen, tap Apps >Downloads.

2. Tap the file you want to open.

• Turn your phone left or right to view the file in upright

(portrait) or sideways (landscape) orientation.

40"

3. Working with files

1. From the Home screen, tap Apps >Downloads.

2. Tap the file you want to manage.

3. Tap Option to Share, Delete.

• Tap Share to share the selected file.

• Tap Delete to delete the selected file.

Bluetooth

Using Bluetooth

Bluetooth is a short-range wireless communications

technology that devices can use to exchange information

over a distance of about 30 feet. The most common

Bluetooth devices are headphones, hands-free car kits,

and portable devices, including laptops and cell phones.

1. Turning Bluetooth on or off

1. From the Home screen, tap Apps >Settings>

Bluetooth.

2. Check or uncheck Bluetooth to turn it on or off.

2. Changing the phone’s Bluetooth name

The phone name identifies your phone to other devices.

1. From the Home screen, tap Apps >Settings.

2. Tap Bluetooth.

3. If Bluetooth isn’t turned on, check Bluetooth to turn it

on.

4. Tap Option> Rename this device> Enter the name

for your phone in the dialog box >OK.

3. Pairing your phone with a

Bluetooth device

1. From the Home screen, tap Apps >Settings.

2. If Bluetooth isn’t turned on, check Bluetooth to turn it

on.

3. Tap Bluetooth >Search for devices. A list of nearby

Bluetooth devices is displayed.

4. Tap the ID of the other device to pair them.

4. Connecting to a Bluetooth device

Once paired, your phone will automatically connect

whenever it detects a paired Bluetooth device. You

can also manually connect Bluetooth devices as

follows:

1. From the Home screen, tap Apps >Settings.

2. If Bluetooth isn’t turned on,check Bluetooth to turn it on.

3. Tap Bluetooth >Search for devices.

4. When the phone and the device are connected, the

device is displayed as connected in the list.

Disconnecting or Un-pairing

from a Bluetooth Device

1. Disconnecting a Bluetooth device

1. From the Home screen, tap Apps >Settings.

2. Tap Bluetooth.

3. In the Bluetooth devices section, tap and hold the

device name to disconnect.

4. Tap Forget.

41"

2. Un-pairing from a Bluetooth device

You can make your phone forget its pairing connection

with another Bluetooth device.

1. From the Home screen, tap Apps >Settings.

2. Tap Bluetooth .

3. In the Bluetooth devices section, tap of the device

name to un-pair.

4. Tap Un-pair.

Connecting to a Bluetooth

Headset

1. From the Home screen, tap Apps >Settings.

2. Tap Bluetooth.

3. If Bluetooth isn’t turned on, check Bluetooth to turn it

on.

4. Tap Search for devices. Your phone will start to scan

for Bluetooth devices within range.

5. When you see the name of your headset

displayed in the Bluetooth devices section, tap

the name. Your phone then automatically tries to

pair with the Bluetooth device.

6. If automatic pairing fails, enter the passcode supplied

with your headset.

1. Reconnecting a headset

1. Put the Bluetooth device in pairing mode.

2. From the Home screen, tap Apps >Settings.

3. Tap Bluetooth.

4. If Bluetooth isn’t turned on, check Bluetooth to turn it

on.

5. Tap the device’s name in the Bluetooth devices

section.

6. If prompted to enter a passcode, try 0000 or 1234, or

consult the headset documentation to find the

passcode.

Sending and Receiving

Information Using Bluetooth

You can use Bluetooth to transfer information between

your phone and another Bluetooth-enabled device such as

a phone or laptop computer. You can send the following

types of information, depending on the device you are

sending to:

• Images and videos

• Contacts

• Audio files

To send files, your phone must have a microSD card

installed.

NOTE The first time you transfer information between your

phone and another device, you need to enter or confirm a

security passcode. Your phone and the other device are

then paired, and you will not need to exchange passcodes

to transfer information in the future.

1. On your phone, open the application that contains the

item you want to send.

2. Follow the steps for the type of the application, select

Send File or Send in the menu. Then select

Bluetooth.

3. If you are prompted to turn on Bluetooth, tap Turn on.

4. Tap the name of the receiving device.

5. On the receiving device, accept the file.

42"

1. Receiving information from another device

Your device is capable of receiving a wide variety of file

types with Bluetooth, including photos, music tracks, and

documents such as PDFs.

To receive files from another device, your phone must have

a microSD card installed.

1. From the Home screen, tap Apps >Settings.

2. Tap Bluetooth.

3. If Bluetooth isn’t turned on, check Bluetooth to turn it

on.

4. Tap the name of the Bluetooth to make the device

available.

5. On the sending device, send one or more files to your

phone.

6. If a Bluetooth authorization request is displayed on

your phone, enter the same passcode on both your

phone and the other device, or confirm the auto-

generated passcode.

7. When your phone receives a file transfer request

notification, slide down the notifications panel,

and then tap Accept.

8. When the transfer is complete, a notification is

displayed. To open the file immediately, slide down

the notifications panel, and tap the notification.

43"

Entertainment

Camera/Camcorder

You can take pictures and shoot videos with

Camera/Camcorder. Photos and videos captured with the

camera will be stored on the internal memory.

1. Opening Camera

• From the Home screen, tap Apps >Camera.

• Or, when in Camcorder mode, tap to choose

change to camera.

2. Camera settings

When in Camera mode, Camera settings are displayed

on screen. Before taking the photo, you can adjust your

camera settings or leave the controls in automatic mode.

1. From the Home screen, tap Apps >Camera.

2. Tap Option. The settings open over the screen.

Tap the setting you want to change.

General

settings

Exposure

+2, +1, 0, -1, -2

Picture size

3M Pixels, 2M Pixels, 1M Pixels,

VGA, QVGA

Picture quality

Super fine, Fine, Normal

Color effect

None, Mono, Sepia, Negative

Camera settings

Restore defaults

GPS

location

Off / On

Activate to use your phone’s

location-based services. Take

pictures wherever you are and

tag them with the location.

White

balance

Auto, Incandescent, Daylight,

Fluorescent, Cloudy.

Storage

Phone/SD

Card

To set the storage location

3. Tap screen to close the settings menus.

3. Taking a picture

1. From the Home screen, tap Apps >Camera.

2. Frame your subject on screen.

• Tap . The camera brings the image into focus.

When the image is in focus, the camera takes a

picture.

The picture you just took is briefly previewed

full-screen, and then is displayed as a

thumbnail in the lower left corner. Tap the

thumbnail to view, share, or work with your

pictures in Gallery.

4. Opening Camcorder

• When you’re in Camera mode, tap to choose

change to camcorder.

Camcorder

1. Camcorder settings

When in Camcorder mode, Camcorder settings are

displayed on screen. Before recording, you can

adjust your camcorder settings or leave them in

automatic mode.

Tap Option. The settings open over the screen.

• Tap screen to close the settings menus

Tap the setting you want to change.

44"

General

settings

Color effect

None, Mono, Sepia, Negative

Video quality

WVGA, VGA, CIF, QVGA, QCIF

Video Encoder

MPEG4, H263, H264

Audio Encoder

AMRNB, AAC

Video duration

30 seconds (MMS), 10 minutes,

30 minutes

Camera settings

Restore defaults

White

balance

Auto, Incandescent, Daylight,

Fluorescent, Cloudy.

Video

quality

High (30m), Low (30m), MMS (Low, 15s),

YouTube (High, 10m), Custom

NOTE Depending on the selected video quality, not all video quality

and video encoder options may be available.

2. Recording videos

1. From the Home screen, tap Apps >Camera>

tap >choose .

2. Frame the scene where you want to start recording.

3. Tap to start recording.

4. Tap to stop recording.

An image from your most recent video is displayed as a

thumbnail at the top right. Tap the thumbnail to view,

share, or work with your videos in Gallery.

Sound Recorder

1. Opening Sound Recorder.

1. From the Home screen, tap Apps >Sound

Recorder.

2. Tap to start recording a voice clip.

3. Tap to stop recording.

• To save the voice clip, enter voice record name > tap

Done.

• To discard the voice clip, tap Discard.

• Tap to listen to the recording.

45"

Tools

Clock

1. Opening the Clock

1. From the Home screen, tap Apps >Clock.

• The Clock application opens and displays the date,

time and other useful information.

•Tap Set alarm to set alarm.

2. Managing Alarms

1. Adding a new alarm

1. From the Home screen, tap Apps >Clock.

2. Tap Set alarm> Add alarm.

3. To change the alarm time, scroll up and down to type

the number. Then toggle AM/PM >Set.

4. Check the checkbox, ‘Turn alarm on’.

5. Edit Turn alarm on, Time, Repeat, Ringtone,

Vibrate and Label >Ok.

2. Editing an alarm

1. From the Home screen, tap Apps >Clock.

2. Tap > Tap an existing alarm.

3. Turn the alarm on or off by checking or

un-checking the checkbox, ‘Turn alarm on’. In

the alarm list, set alarms are underlined in green.

4. Edit Time, Repeat, Ringtone, Vibrate and Label

>Done. Or tap Delete to remove the alarm >OK.

3. Changing alarm settings

1. From the Home screen, tap Apps >Clock

2. Tap > tap Option >Settings.

Alarm in silent

mode

Check to play alarms even when the phone is

in silent mode.

Alarm volume

Set the volume of alarms.

Snooze

duration

Set how long Clock waits before playing an

alarm again.

Auto-silence

Alarm will silence after 10 minutes

Volume button

Set the side button behavior for alarms.

Set default

ringtone

Set ringtone default

4. Stopping an alarm

1. When the alarm sounds, tap Dismiss to stop the

alarm.

• Tap Snooze to repeat the alarm after a specified length

of time.

46"

Calculator

Using Calculator

1. From the Home screen, tap Apps >Calculator.

2. Enter numbers and arithmetic operators.

• Tap Option >Advanced panel.

• Tap and hold the Calculator’s display to open a text

editing menu. You can cut, copy, and select text for

use in Calculator or other Applications.

• Tap Clear history to delete the last number or operator

you entered. Tap and hold DELETE to delete

everything in the display.

47"

Settings

Settings on Your Phone

Control and customize phone settings on the Settings

screen.

1. From the Home screen, tap Apps >

Settings.

• Wireless & networks

Wi-Fi/ Wi-

Fi settings

Wi-Fi On / Off.

Set up and manage Wi-Fi networks. For details

about working with these settings, see “Wi-Fi”.

Bluetooth/

Bluetooth

settings

Bluetooth On / Off.

For details about working with these settings, see

“Bluetooth”.

Data

usage

This setting you can see mobile data and wi-fi data

statistics, and you can turn on or turn off the data.

VPN

settings

Set up and manage Virtual Private

Networks (VPNs).

Airplane

mode

Airplane mode On / Off.

Check to turn off all the phone’s radios

that transmit voice or data.

Mobile

network

The settings include Data enable,

Data roaming, Access Point Names.

And you can choose use only 2G

network to save battery, also you can

select a network operator.

Emergency

alerts

Select the types of emergency alerts

to display

Sound

Volume

Set the volume of ringtones that sound

when you receive a phone call or

notification, media (music, videos, and so

on), and alarms.

Phone

ringtone

Select the ringtone to sound when you

receive a phone call.

Default

notification

Select the ringtone to sound when you

receive a notification.

Vibrate when

ring

Vibrate when the ringtone ring out.

Dail pad touch

tones

Check to play tones when using dial pad.

Touch sound

Check to play sound when touching the

panel.

Screen lock

sounds

Check to play sounds when locking and

unlocking the screen.

Vibrate on

touch

When touch the panel will vibrate.

Emergency

tone

Select the Emergency tone

48"

Display

Brightness

Adjusting the brightness of the screen.

Auto-rotate

screen

Automatically switch the orientation of the

screen as you turn the phone sideways or

even upside down.

Wallpaper

You can set wallpaper.

Sleep

Adjust the delay before the screen

automatically turns off.

Font size

You can set the size of display.

Storage

Storage manager, you can see the SD card and the

phone space.

Unmount SD

card

Unmount the SD card so you can safely

remove it.

Erase SD card

Erases all data on the SD card, such as

music and photos.

Mount SD card

Add SD card.

Erase Phone

storage

Erases all data on the phone storage,

such as music and photos.

Primary

storage

Switch primary storage.

Battery

Tap Battery you can see how much the apps using the

battery and the all battery.

Apps

Manage

apps

Manage and remove installed

applications.

Location

Access

to my

location

Let apps that have asked your permission use

your location information.

GPS

satellites

Let apps use GPS on your phone to pinpoint

your location.

Wi-Fi &

mobile

network

location

Let apps use Google’s location service to

estimate your location faster. Anonymous

location data will be collected and sent to

Google.

49"

Security

Screen lock

Configure your phone to require a pattern,

PIN, or password to unlock your screen.

Owner info

Show owner info on lock screen, you can type

text to display on the lock screen.

Make

passwords

visible

Show password characters as you enter them.

Device

administrat

ors

View or deactivate device administrators.

Unknown

sources

Check to allow installation of non-Market

applications.

Trusted

credentials

Display trusted CA certificates.

Install from

SD card

Install certificates from SD card.

Clear

credentials

You can remove all credentials.

Language & input

language

Select the language to use for the text on your

phone.

Personal

dictionary

Add or delete the words suggested when entering

text.

Android

keyboard

Set Vibrate on key-press, Sound on key-press,

Popup on key-press, Touch to correct words,

Auto- capitalization, Show settings key, Voice

input, Input languages, Quick fixes, Show

suggestions or Auto- complete.

For details about working with these settings,

see “Using the onscreen keyboard”.

Voice

You can set the voice search.

Text-to-

speech

output

You can set the Text-to-speech output.

Pointer

speed

You can set the speed of point.

Back &reset

Back up my

data

Back up app data, Wi-Fi passwords, and other

settings to Google servers.

Back up

account

Backing up to debug-only private cache.

Automatic

restore

When reinstalling an app, restore backed up

settings and data.

Factory

data reset

Eraser all data on phone and reset.

Accounts

You can add an account for Corporate, Email,

Facebook, Google, and Twitter.

Date & time

Automatic

time zone

Use network-provided time zone.

Use 24-hour

format

Display the time using 24-hour format.

Choose date

Format

Select the format for displaying date.

50"

Accessibility

Talkback

When talkback is on, your device provides spoken

feedback to help blind and low-vision users. For

example, it describes what you touch, select, and

activate.

Large text

Let the word large or normal

Power button

ends call

When the icon is on, you can press power on/off

icon ends call.

Auto-rotate

screen

Let the phone auto rotate.

Speak

passwords

If you set the passwords, you can speak password

unlock the phone.

Touch &hold

delay

Set the time of touch & hold short, medium, long.

Enhance web

accessibility

If you install scripts from Google that make their

web content more accessible.

About phone

System updates

You can upgrade your system to up-to-date

version.

Status

Information about your Phone number,

signal, etc.

Legal information

Legal information about Open source

licenses and Google legal.

Model number

Check the Model number.

Android version

Check the android version.

Baseband version

Check the baseband version.

Kernel version

Check the Kernel version.

Software version

The phone’s build number.

Hardware version

You can check hardware version.

Firmware Upgrade

1. Make sure the target device is power on with a fully

charged battery.

2. Tap to go to Settings>About phone and tap System

update.

3. Upgrade according to tips.

4. During the period of update, the target device will

automatically reboot for TWO times. Please don’t

operate the device until the update is completed.

51"

Safety and Use

Please read before

proceeding

THE BATTERY IS NOT FULLY CHARGED WHEN

YOU TAKE THE PHONE OUT OF THE BOX. YOUR

WARRANTY IS INVALIDATED IF YOU ATTEMPT TO

REMOVE THE BATTERY, OR ATTEMPT TO

DISASSEMBLE THE DEVICE.

1. Privacy restrictions

Some countries require full disclosure of recorded

telephone conversations, and stipulate that you must

inform the person with whom you are speaking that the

conversation is being recorded. Always obey the relevant

laws and regulations of your country when using the

recording feature of your phone.

2. Disclaimers

ANY WEATHER, STOCK, OR OTHER INFORMATION,

DATA, OR DOCUMENTATION (“ACCESSED

INFORMATION”) ARE PROVIDED “AS IS” AND

WITHOUT ANY WARRANTY OR ANY TECHNICAL

SUPPORT. TO THE MAXIMUM EXTENT PERMITTED

BY APPLICABLE LAW, AMERICAN NETWORK

SOLUTIONS LLC AND ITS AFFILIATES expressly

disclaim any and all representations and warranties,

arising by law or otherwise, related to the Accessed

Information, including without limitation any express or

implied

representation or warranty of merchantability, fitness for a

particular purpose, non-infringement, quality, accuracy,

completeness, effectiveness, reliability, or usefulness.

Without limiting the foregoing, it is further understood that

AMERICAN NETWORK SOLUTIONS LLC and its Affiliates

are not responsible for any use of the Accessed

Information or the results arising from such use and that

you use such information at your own risk.

Limitation of damages

TO THE MAXIMUM EXTENT PERMITTED BY

APPLICABLE LAW, IN NO EVENT SHALL AMERICAN

NETWORK SOLUTIONS LLC OR ITS AFFILIATES BE

LIABLE TO YOU, ANY USER, OR THIRD PARTY FOR

ANY INDIRECT, SPECIAL, CONSEQUENTIAL,

INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND,

ARISING IN CONTRACT, TORT, OR OTHERWISE,

INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF

REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS

OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF

PROFITS, REGARDLESS OF THE FORESEEABILITY

THEREOF OR WHETHER AMERICAN NETWORK

SOLUTIONS LLC OR ITS AFFILIATES HAVE BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

AND IN NO EVENT SHALL THE TOTAL LIABILITY OF

AMERICAN NETWORK SOLUTIONS LLC OR ITS

AFFILIATES EXCEED THE AMOUNT RECEIVED FROM

YOU, REGARDLESS OF THE LEGAL THEORY UNDER

WHICH THE CAUSE OF ACTION IS BROUGHT. THE

FOREGOING DOES NOT AFFECT ANY STATUTORY

RIGHTS WHICH MAY NOT BE DISCLAIMED.

52"

Important health information

and safety precautions

When using this product, the safety precautions

below must be taken to avoid possible legal liabilities

and damages. Retain and follow all product safety

and operating instructions. Observe all warnings in

the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire and

damage to the equipment, observe the following

precautions.

1. Electrical safety

This product is intended for use when supplied with

power from the designated battery or power supply unit.

Other usage may be dangerous and will invalidate any

approval given to this product.

2. Safety precautions for proper grounding

installation

Connecting to improperly grounded equipment can

result in an electric shock to your device.

This product is equipped with a USB Cable for

connecting with desktop or notebook computer. Be sure

your computer is properly grounded (earthed) before

connecting this product to the computer. The power

supply cord of a desktop or notebook computer has an

equipment grounding conductor and a grounding plug.

The plug must be plugged into an appropriate outlet

which is properly installed and grounded in accordance

with all local codes and ordinances.

3. Safety precautions for power supply unit

1. Use the correct external power source

A product should be operated only from the type of power

source indicated on the electrical ratings label. If you are not

sure of the type of power source required, consult your

authorized service provider or local power company. For a

product that operates from battery power or other sources,

refer to the operating instructions that are included with the

product.

This product should be operated only with the following

designated power supply unit(s).

Travel charge: Input: 100-240V, 50/60Hz,

0.3A Output: 5V, 2000mA

2. Handle battery packs carefully

This product contains a Lithium-ion polymer or Lithium-ion

battery. There is a risk of fire and burns if the battery pack is

handled improperly. Do not attempt to open or service the

battery pack. Do not disassemble, crush, puncture, short

external contacts or circuits, dispose of in fire or water, or

expose a battery pack to temperatures higher than 140°F

(60°C).

Danger of explosion if battery is incorrectly replaced. To

reduce risk of fire or burns, do not disassemble, crush,

puncture, short external contacts, expose to temperature

above 140°F (60°C), or dispose of in fire or water. Replace

only with specified batteries. Recycle or dispose of used

batteries according to the local regulations or reference

guide supplied with your product.

53"

3. Take extra precautions

• Keep the battery or device dry and away from water or

any liquid as it may cause a short circuit.

• Keep metal objects away so they don’t come in

contact with the battery or its connectors as it may

lead to short circuit during operation.

• The phone should only be connected to products

that bear the USB-IF logo or have completed the

USB-IF compliance program.

• Do not use a battery that appears damaged,

deformed, or discolored, or the one that has

any rust on its casing, overheats, or emits a

foul odor.

• Always keep the battery out of the reach of babies

and small children, to avoid swallowing of the

battery. Consult the doctor immediately if the

battery is swallowed.

• Only use the battery with a charging system that has

been qualified with the system per this standard,

IEEE-Std-1725-2006. Use of an unqualified battery or

charger may present a risk of fire, explosion, leakage

or other hazard.

• Replace the battery only with another battery that has

been qualified with the system per this standard,

IEEE-Std-1725-2006. Use of an unqualified battery

may present a risk of fire, explosion, leakage or other

hazard.

• Avoid dropping the phone or battery. If the phone

or battery is dropped, especially on a hard

surface, and the user suspects damage, take it to

a service center for inspection.

• If the battery leaks:

• Do not allow the leaking fluid to come in contact

with skin or clothing. If already in contact, flush the

affected area immediately with clean water and

seek medical advice.

• Do not allow the leaking fluid to come in contact

with eyes. If already in contact, DO NOT rub; rinse

with clean water immediately and seek medical

advice.

• Take extra precautions to keep a leaking battery away

from fire as there is a danger of ignition or explosion.

4. Safety precautions for direct sunlight

Keep this product away from excessive moisture and

extreme temperatures. Do not leave the product or its

battery inside a vehicle or in places where the

temperature may exceed 140°F (60°C), such as on a

car dashboard, window sill, or behind a glass that is

exposed to direct sunlight or strong ultraviolet light for

extended periods of time. This may damage the

product, overheat the battery, or pose a risk to the

vehicle.

5. Prevention of hearing loss

Permanent hearing loss may occur if earphones or

headphones are used at high volume for prolonged

periods of time.

6. Safety in aircraft

Due to the possible interference caused by this

product to an aircraft’s navigation system and its

54"

communications network, using this device’s phone

function on board an airplane is against the law in

most countries. If you want to use this device when on

board an aircraft, remember to turn off RF on your

phone by switching to Airplane Mode.

7. Environment restrictions

Do not use this product in gas stations, fuel depots,

chemical plants or where blasting operations are in

progress, or in potentially explosive atmospheres such

as fuelling areas, fuel storehouses, below deck on

boats, chemical plants, fuel or chemical transfer or

storage facilities, and areas where the air contains

chemicals or particles, such as grain, dust, or metal

powders. Please be aware that sparks in such areas

could cause an explosion or fire resulting in bodily

injury or even death.

8. Explosive atmospheres

When in any area with a potentially explosive atmosphere

or where flammable materials exist, the product should

be turned off and the user should obey all signs and

instructions. Sparks in such areas could cause an

explosion or fire resulting in bodily injury or even death.

Users are advised not to use the equipment at refueling

points such as service or gas stations, and are reminded

of the need to observe restrictions on the use of radio

equipment in fuel depots, chemical plants, or where

blasting operations are in progress. Areas with a

potentially explosive atmosphere are often, but not

always, clearly marked. These include fueling areas,

below deck on boats, fuel or chemical transfer or storage

facilities, and areas where the air contains chemicals or

particles, such as grain, dust, or metal powders.

9. Road safety

Full attention must be given to driving at all times in

order to reduce the risk of an accident. Using a phone

while driving (even with a hands free kit) causes

distraction and can lead to an accident. You must

comply with local laws and regulations restricting the

use of wireless devices while driving.

10. Safety precautions for RF exposure

• Avoid using your phone near metal structures (for

example, the steel frame of a building).

• Avoid using your phone near strong electromagnetic

sources, such as microwave ovens, sound speakers,

TV and radio.

• Use only original manufacturer-approved accessories,

or accessories that do not contain any metal.

• Use of non-original manufacturer-approved

accessories may violate your local RF exposure

guidelines and should be avoided.

11. Interference with medical equipment

functions

This product may cause medical equipment to

malfunction. The use of this device is forbidden in most

hospitals and medical clinics.

If you use any other personal medical device, consult

the manufacturer of your device to determine if they

are adequately shielded from external RF energy.

Your physician may be able to assist you in obtaining

this information.

Turn your phone OFF in health care facilities when

any regulations posted in these areas instruct you to

do so. Hospitals or health care facilities may be using

equipment that could be sensitive to external RF

energy.

55"

12. Non-ionizing radiation

Your device has an internal antenna. This product

should be operated in its normal-use position to

ensure the radioactive performance and safety of the

interference. As with other mobile radio transmitting

equipment, users are advised that for satisfactory

operation of the equipment and for the safety of

personnel, it is recommended that no part of the

human body be allowed to come too close to the

antenna during operation of the equipment.

Use only the supplied integral antenna. Use of

unauthorized or modified antennas may impair call

quality and damage the phone, causing loss of

performance and SAR levels exceeding the

recommended limits as well as result in non-

compliance with local regulatory requirements in

your country.

To assure optimal phone performance and ensure

human exposure to RF energy is within the guidelines

set forth in the relevant standards, always use your

device only in its normal-use position. Contact with the

antenna area may impair call quality and cause your

device to operate at a higher power level than needed.

Avoiding contact with the antenna area when the

phone is IN USE optimizes the antenna performance

and the battery life.

13. Electrical safety

Accessories

• Use only approved accessories.

• Do not connect with incompatible products or

accessories.

• Take care not to touch or allow metal objects, such as

coins or key rings, to contact or short circuit the

battery terminals.

Connection to a car

Seek professional advice when connecting a phone

interface to the vehicle electrical system.

Faulty and damaged products

• Do not attempt to disassemble the phone or its

accessory.

• Only qualified personnel must service or repair the

phone or its accessory.

14. General precautions

You alone are responsible for how you use your phone

and any consequences of its use. You must always

switch off your phone wherever the use of a phone is

prohibited. Use of your phone is subject to safety

measures designed to protect users and their

environment.

Avoid applying excessive pressure to the device

Do not apply excessive pressure on the screen and the

device to prevent damaging them and remove the device

from your pants’ pocket before sitting down. It is also

recommended that you store the device in a protective

case and only use the device stylus or your finger when

interacting with the touch screen. Cracked display

screens due to improper handling are not covered by the

warranty.

Device getting warm after prolonged use

When using your device for prolonged periods of time,

such as when you’re talking on the phone, charging the

battery or browsing the Web, the device may become

warm. In most cases, this condition is normal and

56"

therefore should not be interpreted as a problem with the

device.

Heed service markings

Except as explained elsewhere in the Operating or

Service documentation, do not service any product

yourself. Service needed on components inside the

device should be done by an authorized service

technician or provider.

Protect your phone

• Always treat your phone and its accessories with care

and keep them in a clean and dust-free place.

• Do not expose your phone or its accessories to open

flames or lit tobacco products.

• Do not expose your phone or its accessories to liquid,

moisture or high humidity.

• Do not drop, throw or try to bend your phone or its

accessories.

• Do not use harsh chemicals, cleaning solvents, or

aerosols to clean the device or its accessories.

• Do not paint your phone or its accessories.

• Do not attempt to disassemble your phone or its

accessories, only authorized personnel must do so.

• Do not expose your phone or its accessories to

extreme temperatures, minimum -4°F (-20°C)

and maximum 122°F (50°C).

• Please check local regulations for disposal of electronic

products.

• Do not carry your phone in your back pocket as it

could break when you sit down. Damage requiring

service

Unplug the product from the electrical outlet and refer

servicing to an authorized service technician or

provider under the following conditions:

• Liquid has been spilled or an object has fallen into the

product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you

follow the operating instructions.

Avoid hot areas

The product should be placed away from heat sources

such as radiators, heat registers, stoves, or other

products (including amplifiers) that produce heat.

Avoid wet areas

Never use the product in a wet location.

Avoid using your device after a dramatic change in

temperature

When you move your device between environments

with very different temperature and/or humidity

ranges, condensation may form on or within the

device. To avoid damaging the device, allow sufficient

time for the moisture to evaporate before using the

device.

NOTICE: When taking the device from low-

temperature conditions into a warmer environment or

from high-temperature conditions into a cooler

environment, allow the device to acclimate to room

temperature before turning on power.

Avoid pushing objects into product

Never push objects of any kind into cabinet slots

or other openings in the product. Slots and

openings are provided for ventilation. These

openings must not be blocked or covered.

57"

Air bags

Do not place a phone in the area over an air bag or in

the air bag deployment area. Store the phone safely

before driving your vehicle.

Mounting accessories

Do not use the product on an unstable table, cart,

stand, tripod, or bracket. Any mounting of the product

should follow the manufacturer’s instructions, and

should use a mounting accessory recommended by

the manufacturer.

Avoid unstable mounting

Do not place the product with an unstable base.

Use product with approved equipment

This product should be used only with personal

computers and options identified as suitable for use with

your equipment.

Adjust the volume

Turn down the volume before using

headphones or other audio devices.

Cleaning

Unplug the product from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a

damp cloth for cleaning, but NEVER use water to clean

the LCD screen. Small children

Do not leave your phone and its accessories within the

reach of small children or allow them to play with it. They

could hurt themselves or others, or could accidentally

damage the phone. Your phone contains small parts with

sharp edges that may cause an injury or which could

become detached and create a choking hazard.

Repetitive motion injuries

To minimize the risk of RSI, when Texting or playing

games with your phone:

• Do not grip the phone too tightly

• Press the buttons lightly

• Make use of the special features in the handset which

minimize the number of buttons which have to be

pressed, such as message templates and predictive

text.

• Take lots of breaks to stretch and relax.

Operating machinery

Full attention must be given to operating the machinery

in order to reduce the risk of an accident.

Loud noise

This phone is capable of producing loud noises which

may damage your hearing.

Emergency calls

This phone, like any wireless phone, operates using

radio signals, which cannot guarantee connection in all

conditions. Therefore, you must never rely solely on any

wireless phone for emergency communications.

Regulatory agency

identifications

1. FCC Regulations:

This mobile phone complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2)

this device must accept any interference received,

including interference that may cause undesired operation.

This mobile phone has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses

and can radiated radio frequency energy and, if not

installed and used in accordance with the instructions, may

cause harmful interference to radio communications.

58"

However, there is no guarantee that interference will not

occur in a particular installation If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference

by one or more of the following measures：

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and

receiver.

-Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician

for help.

Changes or modifications not expressly approved by the

party responsible for compliance could void the user‘s

authority to operate the equipment.

2. RF Exposure Information (SAR)

This mobile phone meets the government’s requirements

for exposure to radio waves.

This phone is designed and manufactured not to exceed

the emission limits for exposure to radio frequency (RF)

energy set by the Federal Communications Commission of

the U.S. Government.

The exposure standard for wireless mobile phones

employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit set by the FCC

is 1.6W/kg. *Tests for SAR are conducted using standard

operating positions accepted by the FCC with the phone

transmitting at its highest certified power level in all tested

frequency bands. Although the SAR is determined at the

highest certified power level, the actual SAR level of the

phone while operating can be well below the maximum

value. This is because the phone is designed to operate

at multiple power levels so as to use only the power

required to reach the network. In general, the closer you

are to a wireless base station, the lower the power output.

The highest SAR value for the model phone as reported to

the FCC when tested for use at the ear is 1.18 W/kg and

when worn on the body, as described in this user guide, is

1.08 W/kg (Body-worn measurements differ among phone

models, depending upon available accessories and FCC

requirements.)

While there may be differences between the SAR levels of

various phones and at various positions, they all meet the

government requirement.

The FCC has granted an Equipment Authorization for this

model phone with all reported SAR levels evaluated as in

compliance with the FCC RF exposure guidelines. SAR

information on this model phone is on file with the FCC

and can be found under the Display Grant section of

www.fcc.gov/oet/ea/fccid after searching on FCC ID:

2ALZM-UL40.

For body worn operation, this phone has been tested and

meets the FCC RF exposure guidelines for use with an

accessory that contains no metal and the positions the

handset a minimum of 1.5 cm from the body. Use of

other accessories may not ensure compliance with FCC

RF exposure guidelines. If you do not use a body-worn

accessory and are not holding the phone at the ear,

position the handset a minimum of 1.5 cm from your body

when the phone is switched on.

HEARING AID COMPATIBILITY HAC FOR

WIRELESS TELECOMMUNICATIONS

DEVICES

THIS PHONE HAS A HAC RATING OF M3/T3

WHAT IS HEARING AID COMPATIBILITY?

The Federal Communications Commission has

implemented rules and a rating system designed to

enable people who wear hearing aids to more effectively

use these wireless telecommunications devices. The

59"

standard for compatibility of digital wireless phones with

hearing aids is set forth in American National Standard

Institute (ANSI) standard C63.19. There are two sets of

ANSI standards with ratings from one to four (four being

the best rating): an “M” rating for reduced interference

making it easier to hear conversations on the phone when

using the hearing aid microphone, and a “T” rating that

enables the phone to be used with hearing aids operating

in the tele-coil mode thus reducing unwanted background

noise.

HOW WILL I KNOW WHICH WIRELESS PHONES ARE

HEARING AID COMPATIBLE?

The Hearing Aid Compatibility rating is displayed on the

wireless phone box.

A phone is considered Hearing Aid Compatible for acoustic

coupling (microphone mode) if it has an “M3” or “M4” rating.

A digital wireless phone is considered Hearing Aid

Compatible for inductive coupling (tele-coil mode) if it has a

“T3” or “T4” rating.

HOW WILL I KNOW IF MY HEARING AID WILL WORK

WITH A PARTICULAR DIGITAL WIRELESS PHONE?

You’ll want to try a number of wireless phones so that you

can decide which works the best with your hearing aids.

You may also want to talk with your hearing aid

professional about the extent to which your hearing aids

are immune to interference, if they have wireless phone

shielding, and whether your hearing aid has a HAC ratio.

ANSUL40APBUG1ENG

UL40 user manaul 20170908 V1.2x ANS UL40 User Guide UL40usermanaul20170908 V1.2

Navigation menu

Versions of this User Manual:

Views

Navigation
