PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Shaft Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
ABS USA
PS-851 A 1 1.375 3/4 BCFJF 11107939
PS-446 C 1 2.500 1-3/4 BCFJF 11116013
PS-267 C 1 2.750 2 BCFJF 11116014
PS-1679 C 1 3.125 2-1/4 BCFJF 11116015
PS-2116 C 3 3.875 3 BCFJF 11116016
A-C COMPRESSOR CORPORATION
PS-9708 WB 1 4.375 3-3/4 T/VCFKF 316SS 16-630-048-09-1
A-C PUMP
PS-150 B — — 1/2 BMF-F
PS-4470 A 1 1.250 5/8 BMFJF Model C1 Close Coupled Pumps 52-104-969-803
Types: CR, DDH, DG, DGH, HH, 52-104-969-813
HHS, R, RH, RHS, RS, WH 52-104-969-823
PS-642 B — — 5/8 BMF-F 52-105-071-801
PS-447V-P66 B 8 — 5/8 VCFJF A/I 52-114-660-803
PS-118 C 1 1.187 5/8 BCFJF
PS-359 C 1 1.250 5/8 BCFJF
PS-7689 C 1 1.250 5/8 QCFKF I 52-126-378-801
PS-735 D 3 1.250 5/8 BCDJF 52-104-945-805
PS-647 B — — 3/4 BMF-F
PS-358 C 1 1.375 3/4 BCFJF
PS-750 D 1 1.375 3/4 BCDJF
PS-703 D 1 1.500 7/8 BCDJF
PS-360 A 1 1.625 1 BCFJF 52-104-969-806
52-104-969-816
PS-357 C 1 1.625 1 BCFKF 52-113-094-802
PS-460 D 1 1.625 1 BCFKF
PS-754 E 1 1.625 1 BCFJF
PS-937 E — — 1 BCF-F 52-110-870-809
PS-557 E 3 1.625 1 B/VCFJF S 52-104-870-809
PS-754V E 3 1.625 1 VCFJF S 52-116-831-801
52-116-831-804
PS-276 T 1 1.625 1 BCFJF 52-105-275-808
PS-277 T 1 1.625 1 BCFKF 52-105-275-858
T9-1000 WT — — 1 TCF-F 316SS 52-108-896-803
PS-355 C 1 1.750 1-1/8 BCFKF 52-104-946-803
PS-348 C — — 1-1/8 BCF-F
PS-605 D 1 1.750 1-1/8 BCFKF 52-104-945-803
PS-204 E 1 1.750 1-1/8 BCFJF SJH, Size 3 x 2-1/2, 2-1/2 x 2 08-216-526-001
PS-867 E 3 1.750 1-1/8 BCFKF 52-104-870-806
PS-185 C 1 1.875 1-1/4 BCFJF 52-113-592-801
PS-2122 C 1 1.875 1-1/4 BCFJF 52-114-901-807
PS-756 C 1 1.875 1-1/4 BCFKF
PS-598 C 3 1.875 1-1/4 BCFKF
PS-466 C 1 2.000 1-1/4 BCFJF
PS-2230 C 3 2.000 1-1/4 BCFJF Series 2000 52-119-056-801
PS-1018 C 3 2.000 1-1/4 BCFKF Series 2000 52-118-510-801
PS-3045 C 3 2.000 1-1/4 BCFZF I Series 2000
PS-1018-EPR-P66 C 3 2.000 1-1/4 QCFKF I 52-126-211-801
PS-2200 C 3 2.000 1-1/4 VCFKF I 52-114-659-808
PS-1015 E — — 1-1/4 BCF-F 52-110-870-807
PS-361 E 1 1.875 1-1/4 BCFJF Model C16 with 215T & 52-104-609-817
Smaller Frame Motors 52-105-609-813
F2L-1, F2L-3, F2L-5 and F2L-6 52-114-605-805
PS-137 E 1 1.875 1-1/4 BCFKF 52-106-609-813
52-106-609-817
PS-108 E 1 1.875 1-1/4 NCPKP 52-105-383-807
PS-546 E 3 1.875 1-1/4 BCFJF 52-104-870-807
52-114-890-807
PS-2211 T 3 1.875 1-1/4 BCFJF 52-105-275-801
PS-177 C 1 2.000 1-3/8 BCFJF MAXEAL®-V 52-115-605-801
Sizes 6x4x12, 8x5x12, 8x6x12
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
A-C PUMP (continued)
PS-2134 C 1 2.000 1-3/8 BCFJF 52-121-998-801
PS-210 C 1 2.000 1-3/8 BCFKF Custom V 52-114-713-801
PS-1667 C 1 2.000 1-3/8 BCFKF Series 8000 52-117-036-801
PS-3213 C 3 2.000 1-3/8 VCFKF I 52-114-659-801
PS-4087 E — — 1-3/8 VCF-F 316SS/C 52-118-671-802
52-118-671-803
PS-354 E 1 2.000 1-3/8 BCFJF SS-CH, SS-DH, SS-HH, SS-L 52-111-322-801
PS-677 E 1 2.000 1-3/8 BCFKF 52-105-382-801
PS-677V E 3 2.000 1-3/8 VCFKF 52-118-679-801
T9-1375 WT — — 1-3/8 TCF-F 316SS 52-118-672-802
PS-758 C 1 2.125 1-1/2 BCFJF 52-112-870-801
PS-553 C 3 2.125 1-1/2 BCFKF 52-118-591-001
PS-382 D 1 2.125 1-1/2 BCFJF 52-104-945-801
52-104-945-806
PS-371 D 1 2.125 1-1/2 BCFKF 52-101-848-082
52-104-946-801
PS-314 E 3 2.000 1-1/2 BCFJF Type-SH 4 x 3 08-301-766-066-04
PS-316 E 3 2.000 1-1/2 BCFKF 4 x 2-1/2 SKH 08-301-766-020-36
PS-4473 EB 3 2.000 1-1/2 BCFJF 52-161-211-801
PS-4088 EB 3 2.000 1-1/2 QCFJF I 52-161-209-801
PS-238 C 1 2.375 1-5/8 BCFJF 52-110-870-811
52-114-043-805
PS-239 C 1 2.375 1-5/8 BCFKF 52-118-511-002
52-118-512-002
PS-2202 C 3 2.625 1-5/8 BCFJF Series 2000 52-119-056-802
PS-1019 C 3 2.625 1-5/8 BCFKF Series 2000 52-118-510-802
PS-3078 C 3 2.625 1-5/8 BCFKF 316SS
PS-2201 C 3 2.625 1-5/8 QCFKF I 52-126-211-802
PS-4288 C 3 2.625 1-5/8 QCFZF 52-126-874-802
PS-609 E 1 2.312 1-5/8 BCDJF Type-KSH 08-303-611-07-001
08-306-539-015-03
52-115-315-801
PS-281 R 3 2.375 1-5/8 BCDKF
PS-446 C 1 2.500 1-3/4 BCFJF MAXEAL®-V Series 5000 52-115-605-802
PS-2135 C 1 2.500 1-3/4 BCFJF 52-121-998-802
PS-1674 C 1 2.500 1-3/4 BCFKF Series 8000 52-117-036-802
PS-1674-EPR-P66 C 1 2.500 1-3/4 QCFKF I 52-126-489-802
PS-436V-P66 C 3 2.500 1-3/4 VCFKF I 52-114-659-802
PS-2109 E — — 1-3/4 BCF-F 52-110-870-802
PS-317 E 1 2.487 1-3/4 BCFJF 5 x 5 KSG 08-303-611-07-004
PS-205 E 1 2.500 1-3/4 BCFJF MAXEAL VII® C16, C17S, F2-2 08-212-616-001
F2-5, F2-8, F2L-2 and F2L-4
PS-366 E 1 2.500 1-3/4 BCFKF 52-110-871-802
PS-535 E 3 2.500 1-3/4 BCFJF 52-114-901-802
52-122-588-806
52-104-870-802
PS-262 E 3 2.500 1-3/4 BCFKF 52-114-890-802
PS-1197 K 1 2.500 1-3/4 BCFKF
PS-1608 C 1 2.625 1-7/8 BCFKF 52-114-713-805
PS-2114 C 3 2.625 1-7/8 BCFJF 52-122-693-805
52-127-471-805
PS-2069 E 1 2.625 1-7/8 BCFJF 3 x 2 MM-2
PS-2070 E 1 2.625 1-7/8 BCFKF 3 x 2 MM-2 08-301-766-02-065
PS-2071 E 3 2.625 1-7/8 BCFJF 52-122-588-814
PS-7884 EB 3 2.500 1-7/8 BCFKF 52-121-754-802
PS-318 K 1 2.625 1-7/8 BCFJF Models NSW, NSWV 52-110-280-03-801
PS-1693 K 1 2.625 1-7/8 BCFKF 52-110-280-801
PS-7352 K 1 2.625 1-7/8 BCFKF 52-110-280-807
PS-1105 V 25 2.640 1-7/8 BMFJF Model F7N-2,4 x 4 x 11
PS-2133 C 1 2.750 2 BCFJF 52-119-056-803
52-121-998-803
NOTE:
C. COMpLeTe WITH COLLAr
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
A-C PUMP (continued)
PS-267 C 1 2.750 2 BCFJF 52-122-693-807A
PS-1017 C 1 2.750 2 BCFKF Series 8000 52-117-036-803
PS-3674 C 1 2.750 2 QCFKF I 52-126-489-803
PS-3580 C 1 2.750 2 QCFZF I 52-126-872-803
PS-1017-TC-SEAT C 3 2.750 2 BCFZF 52-161-177-803
PS-1020 C 3 3.000 2 BCFKF Series 2000 52-118-510-803
PS-1020-EPR-P66 C 3 3.000 2 QCFKF I Series 2000 52-126-211-803
PS-319 E 1 2.687 2 BCFJF MAXEAL® VII Series 2000 52-115-315-803
08-212-617-001
PS-478 E 1 2.687 2 BCFKF MAXEAL® VII and KS
PS-530 E 3 2.750 2 BCFJF 52-104-870-803
52-116-823-810
PS-477 E 3 2.750 2 BCFKF 52-123-692-801
PS-477V E 3 2.750 2 VCFKF 52-115-946-803
PS-477V-TC-SEAT E 3 2.750 2 VCFZF 52-115-720-807
PS-1040 K 3 2.750 2 BCFKF 52-237-862-801
PS-7196V K 3 2.750 2 VCFJF S 52-237-862-802
PS-1687 D 1 3.000 2-1/8 BCFKF 52-104-945-802
FA-3502 E — — 2-1/8 BCF-F 316SS 52-129-173-802
PS-327 E 3 3.000 2-1/8 BCFJF 52-129-172-801
PS-1678 C 3 3.125 2-1/4 BCFJF 52-122-693-804
PS-323 E 1 3.125 2-1/4 BCDJF CUSTOM Vll, KS, C17, 8 x 8 SH 08-216-036-001
PS-351 E 1 3.125 2-1/4 BCDKF 08-630-132-009
PS-849 E 3 3.125 2-1/4 BCDKF 52-104-870-804
PS-1688 E 3 3.125 2-1/4 BCFJF 52-121-998-808
52-122-588-808
PS-351V E 3 3.125 2-1/4 VCDKF 52-114-660-804
PS-279 E 3 3.375 2-1/2 BCFJF Model F2-6
PS-349 E 3 3.375 2-1/2 BCFKF 52-104-870-805
PS-349V E 3 3.375 2-1/2 VCFKF 52-115-946-804
PS-836 C 3 3.500 2-3/4 BCFJF 52-122-693-806
PS-483 C 3 3.500 2-3/4 BCFKF 52-114-713-804
PS-838 E 3 3.500 2-3/4 V/BCFJF 08-210-902-045
52-114-890-810
52-115-315-805
PS-321 E 3 3.500 2-3/4 V/BCFKF CUSTOM Vll 08-216-035-001
52-104-870-808
PS-321V E 3 3.500 2-3/4 VCFKF 52-114-660-805
PS-7936 E 3 3.500 2-3/4 VCFZF 316SS 62-121-756-805
PS-322 K 3 3.500 2-3/4 BCFKF NSWG, NSWV, Series 300 52-109-719-802
PS-324 E 3 3.875 3 BCDJF 12 x 12 SD 08-210-902-04-037
PS-2141 K 3 3.875 3 BCFKF 52-237-805-801
PS-6228 K 3 3.875 3 VCFJF 52-237-805-803
PS-7244 K 3 4.125 3-1/4 BCFKF 52-237-806-801
PS-4113 T 3 4.375 3-1/2 BCFKF 52-115-082-801
PS-8028 X 3 4.750 3-7/8 VCFKF 316SS/I 08-217-897-801
PS-2140 K 3 6.000 5 BCFKF 52-115-055-801
52-238-383-801
NOTE:
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
VGK-2000 52-051-447 1-1/4 BCFKF
VGK-2001 52-051-404 1-1/4 BCFKF
VGK-2002 52-051-406 1-1/4 BCFKF
VGK-2003 52-051-405 1-5/8 BCFKF
VGK-2004 52-051-448 1-5/8 BCFKF
VGK-2005 52-051-453 1-5/8 BCFKF
Value Guard Seal Material
Part No. Mfg. Part No. Size Code
A-C PUMP - Replacement Seal Kits for Series AC 2000
Kits include mechanical seal, shaft sleeve, spacer, gland,
key, washer, impeller nut and stud, sleeve and casing o-rings.
A-C Pump is not affiliated with U.S.Seal Mfg. Products supplied are manufactured
or purchased by U.S.Seal Mfg. from sources other than the company listed.
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
ACE ENGINEERING
PS-633 C 1 1.250 5/8 BCFKF 1743-2CS
PS-112 C 1 1.375 3/4 BCFKF 2043-3CS
ACE PUMP CORPORATION
PS-100 A 1 1.187 5/8 BMFJF ACH-25, 33, 50, 75, 100, ACL-75
ACO & BCH-25, 33, 50, 75
PS-953 A 1 1.187 5/8 BCFJF 30210F
PS-447V B 8 — 5/8 VCFJF A 80040F, ECL-7SG
PS-4114 B 8 1.109 5/8 Special Z-ECL-7V
PS-3102 B 11 — 5/8 BCFJF A BAC-7B
PS-202V B 11 — 5/8 VCFJF A C600-10QC, 1000-21SP BAC-7VC
PS-3103 B 11 — 5/8 VCFJF Has Seat Adaptor BAC-7V2
PS-3106 B 11 1.237 5/8 VLFLF Has Seat Adaptor BAC-7SC
PS-800 C 1 1.156 5/8 BMFJF H
PS-1016 C 1 1.187 5/8 N/BCFJF B
PS-1091 C 1 1.187 5/8 VCFJF 30240F
PS-102 D 1 1.250 5/8 BCDKF
PS-3107 G 3 1.375 5/8 VCFJF BAC-7-650
PS-3005 G 3 1.250 5/8 VLFLF 316SS BAC-7SC-205V
PS-851 A 1 1.375 3/4 BCFJF ACH-150, 200, 300, 500 30220 F
ACXH-150, BCH-100, 200, 300
PS-3104 B 3 1.375 3/4 VLFLF 316SS BAC-7SC-660V
PS-752 D 1 1.375 3/4 BCDKF
PS-3105 G 25 1.375 3/4 VLFLF Light Spring Load BAC-7SC-650
PS-3214 K 3 1.375 3/4 VCFJF BAC7-650-WS
PS-892V K 3 1.500 7/8 VCFJF BAC-7-750V
PS-3112 C 1 1.625 25MM VCFJF TYPE21-984
PS-360 A 1 1.625 1 BCFJF BCH-300, 500, 750, 1000
Models 100S, 133S, 150S, 175S
PS-360V-CMS A 1 1.625 1 VCFJF 42120F, GE-7-V
PS-235V-CMS C 1 1.625 1 VCFJF 21-098-16
PS-185V-CMS C 1 1.875 1-1/4 VCFJF TYPE21-1.250
PS-185V-SC-SC C 1 1.875 1-1/4 VLFLF 30266F
ACURA SPA SYSTEMS, INC.
PS-1000 B 1 1.250 5/8 BMFJF Aquaheat, Aquaheat Plus, Magnaflow, 1090-A
Magnaflow 56, Maverick, Supercharger,
Supercharger II
ADAMATION, INC. - (Dishwashers)
PS-3159 B 8 — 5/8 BCFJF A 55-6301, 305-6154
305-6164
PS-758 C 1 2.125 1-1/2 BCFJF 55-6301-364-6193
ADVANCED PROCESS TECHNOLOGY
PS-3226 C 3 1.000 1/2 VCFKF 95601
PS-112V C 3 1.375 3/4 VCFKF 90551
PS-756V C 3 1.875 1-1/4 VCFKF 90119
ADVANTAGE ENGINEERING, INC.
PS-552 C 3 1.250 5/8 BCFJF
PS-552-EPR-P66 C 3 1.250 5/8 QCFJF I 6491000
PS-633V-P66 C 3 1.250 5/8 VCFKF I 6490000, 6495301
PS-598-EPR C 3 1.875 1-1/4 QCFKF 6495612
PS-553 C 3 2.125 1-1/2 BCFKF 6480000
PS-4361 D 1 2.375 1-5/8 BLFZF 6480005
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
AERMOTOR PUMPS
PS-100 A 1 1.187 5/8 BMFJF
PS-200 A 1 1.250 5/8 BMFJF SJ-45
PS-274 E 1 1.250 5/8 BCDJF
PS-487 E 1 1.250 5/8 BCDKF
PS-201 A 1 1.375 3/4 BMFJF SJ-47
PS-275 C 1 1.375 3/4 BCFJF
AIR-O-LATOR CORP.
PS-618 C 3 1.875 1-1/4 BCFJF 37SM-125CC
PS-598-SC-SC C 3 1.875 1-1/4 BLFLF 37SM-125SC
PS-816 C 3 2.125 1-1/2 BCFJF 37SM-150CC
PS-3101 C 3 2.125 1-1/2 BLFLF 37SM-150SC
PS-2217 C 3 2.125 1-1/2 BZFZF 37SM-150TC
PS-550 C 3 2.500 1-3/4 BCFJF 37SM-175CC
PS-436-SC-SC C 3 2.500 1-3/4 BLFLF 37SM-175SC
PS-436-TC-TC C 3 2.500 1-3/4 BZFZF 37SM-175TC
PS-532 C 3 2.750 2 BCFJF 37SM-200CC
ALCO
PS-832 D 3 2.750 2 BCDKF Models 244D and 539 2250033-2, 5250013-3
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
ALFA LAVAL® CENTRIFUGAL PUMP - Replacement Seals for Food, Dairy & Beverage Processing
Tri-Flo® (Tri-Clover®) CL Series
VGFS-2000 Single 1-1/4 QCFLF 9612-7118-01
VGFS-2001 Single 1-1/4 BCFLF 9612-7118-02
VGFS-2002 Single 1-1/4 VCFLF 9612-7118-03
VGFS-2003 Single 1-1/4 QLFLF 9612-7119-01
VGFS-2004 Single 1-1/4 BLFLF 9612-7119-02
VGFS-2005 Single 1-1/4 VLFLF 9612-7119-03
LKH 5-60
VGFS-2010 Single 32MM QLFLF 9612-1296-05
VGFS-2011 Single 32MM BLFLF 9612-1296-06
VGFS-2012 Single 32MM VLFLF 9612-1296-07
VGFS-2013 Single 32MM QCFLF 9612-1296-09
VGFS-2014 Single 32MM BCFLF 9612-1296-10
VGFS-2015 Single 32MM VCFLF 9612-1296-11
VGFS-2016 Double 32MM QCFLF 9612-1296-13
VGFS-2017 Double 32MM BCFLF 9612-1296-14
VGFS-2018 Double 32MM VCFLF 9612-1296-15
VGFS-2019 Double 32MM QLFLF 9612-1296-17
VGFS-2020 Double 32MM BLFLF 9612-1296-18
VGFS-2021 Double 32MM VLFLF 9612-1296-19
LKH 70 & 80
VGFS-2030 Single 42MM QLFCF 9612-5151-01
VGFS-2031 Single 42MM BLFCF 9612-5151-02
VGFS-2032 Single 42MM VLFCF 9612-5151-03
VGFS-2033 Single 42MM QLFLF 9612-5151-05
VGFS-2034 Single 42MM BLFLF 9612-5151-06
VGFS-2035 Single 42MM VLFLF 9612-5151-07
LKH 110 & 120 Multi-Stage - Non-Flushed
VGFS-2040 Single 42MM QLFCF 9612-3622-01
VGFS-2041 Single 42MM BLFCF 9612-3622-02
VGFS-2042 Single 42MM VLFCF 9612-3622-03
VGFS-2043 Single 42MM QLFLF 9612-3622-04
VGFS-2044 Single 42MM BLFLF 9612-3622-05
VGFS-2045 Single 42MM VLFLF 9612-3622-06
VGFS-2013
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
ALFA LAVAL® (G&H) PD PUMP - Replacement Seals for Food, Dairy & Beverage Processing
TSE/SRU 1 (322 & 332) - Hyclean Non-Flushed
VGFS-3000 Single 20MM QCFFF 9630053608
VGFS-3001 Single 20MM QLFLF 9630053609
VGFS-3002 Single 20MM VCFLF 9630057357
VGFS-3003 Single 20MM VCFFF 9630060999
VGFS-3004 Single 20MM VLFLF 9630065312
VGFS-3005 Single 20MM BCFFF 9630070142
VGFS-3006 Single 20MM BLFLF 9630090685
VGFS-3007 Single 20MM QCFLF 9630090686
VGFS-3008 Single 20MM BCFLF 9630090687
TSE/SRU 2 (422 & 432) - Hyclean Non-Flushed
VGFS-3010 Single 30MM BCFFF 9630046729
VGFS-3011 Single 30MM VCFFF 9630046730
VGFS-3012 Single 30MM QCFFF 9630046731
VGFS-3013 Single 30MM BCFLF 9630046745
VGFS-3014 Single 30MM VCFLF 9630046746
VGFS-3015 Single 30MM QCFLF 9630046747
VGFS-3016 Single 30MM BLFLF 9630046758
VGFS-3017 Single 30MM VLFLF 9630046759
VGFS-3018 Single 30MM QLFLF 9630046760
TSE/SRU 3 (522 & 532) - Hyclean Non-Flushed
VGFS-3020 Single 35MM BCFFF 9630046733
VGFS-3021 Single 35MM VCFFF 9630046734
VGFS-3022 Single 35MM QCFFF 9630046735
VGFS-3023 Single 35MM BCFLF 9630046749
VGFS-3024 Single 35MM VCFLF 9630046750
VGFS-3025 Single 35MM QCFLF 9630046751
VGFS-3026 Single 35MM BLFLF 9630046761
VGFS-3027 Single 35MM VLFLF 9630046762
VGFS-3028 Single 35MM QLFLF 9630046763
TSE/SRU 4 (622 & 632) - Hyclean Non-Flushed
VGFS-3030 Single 45MM BCFFF 9630046737
VGFS-3031 Single 45MM VCFFF 9630046740
VGFS-3032 Single 45MM QCFFF 9630046741
VGFS-3033 Single 45MM BCFLF 9630046752
VGFS-3034 Single 45MM VCFLF 9630046753
VGFS-3035 Single 45MM QCFLF 9630046754
VGFS-3036 Single 45MM BLFLF 9630046765
VGFS-3037 Single 45MM VLFLF 9630046766
VGFS-3038 Single 45MM QLFLF 9630046767
TSE/SRU 5 (722 & 732) - Hyclean Non-Flushed
VGFS-3040 Single 55MM BCFFF 9630046738
VGFS-3041 Single 55MM VCFFF 9630046743
VGFS-3042 Single 55MM QCFFF 9630046744
VGFS-3043 Single 55MM BCFLF 9630046755
VGFS-3044 Single 55MM VCFLF 9630046756
VGFS-3045 Single 55MM QCFLF 9630046757
VGFS-3046 Single 55MM BLFLF 9630046769
VGFS-3047 Single 55MM VLFLF 9630046770
VGFS-3048 Single 55MM QLFLF 9630046771
TSE/SRU 6 (822 & 832) - Hyclean Non-Flushed
VGFS-3050 Single 67MM VCFFF 9630030780
VGFS-3051 Single 67MM QCFFF 9630041719
VGFS-3052 Single 67MM QLFLF 9630041720
VGFS-3053 Single 67MM QCFLF 9630041729
VGFS-3054 Single 67MM VLFLF 9630049360
VGFS-3055 Single 67MM BCFFF 9630053215
VGFS-3056 Single 67MM VCFLF 9630057267
VGFS-3057 Single 67MM BLFLF 9630060539
VGFS-3058 Single 67MM BCFLF 9630090689
VGFS-3048
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
ALLIED PUMP CORP.
PS-507 A 1 1.250 5/8 BMFKF
ALLIS CHALMERS (See A-C PUMP)
AMERICAN DISH SERVICE
PS-162 A 1 1.000 1/2 BMFJF
AMERICAN MACHINE AND TOOL CO. (AMT) (SUBSIDIARY OF GORMAN-RUPP)
PS-200 A 1 1.250 5/8 BMFJF MS-626V
PS-200V-CMS A 1 1.250 5/8 VCFJF 1640-161-91
PS-882 B — — 5/8 BCF-F 1646-001-00
PS-642 B — — 5/8 BMF-F
PS-3124 B 1 1.087 5/8 BCFJF 1642-250-00
PS-933V C — — 5/8 VCF-F 1646-005-0
PS-201 A 1 1.375 3/4 BMFJF MS-756-B
PS-9711
W Special
2 1.375 3/4 TCFJF 316SS 1643-541-00
PS-348V C — — 1-1/8 VCF-F 1645-000-00
PS-356 C 1 1.750 1-1/8 BCFJF 287-15A/B
AMERICAN-MARSH PUMPS
PS-633V C 3 1.250 5/8 VCFKF 890031
PS-112V C 3 1.375 3/4 VCFKF 890004
PS-687V C 3 1.500 7/8 VCFKF 890036
PS-185 C 1 1.875 1-1/4 BCFJF 10-1400-02
PS-756 C 1 1.875 1-1/4 BCFKF 890003
PS-2208 C 1 1.875 1-1/4 BZFZF 10-1400-02S4
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 800-011-869
PS-756V C 3 1.875 1-1/4 VCFKF 890044
PS-3724 E 3 1.875 1-1/4 QCFKF S
PS-7702 EB 3 1.875 1-3/8 BCFJF 10-0516-05, 800-0047-851
PS-758 C 1 2.125 1-1/2 BCFJF 10-1401-01
PS-4374 EB 3 2.125 1-5/8 BCFJF 800-0048-851
999-0007-331
PS-446 C 1 2.500 1-3/4 BCFJF 10-1402-00
PS-7884V EB 3 2.500 1-7/8 VCFKF 10-0518-034
800-0049-853, FJ2002FS
PS-267 C 1 2.750 2 BCFJF 10-1403-09
PS-267V C 3 2.750 2 VCFJF 890023
AMERICAN PRODUCTS
PS-150 B — — 1/2 BMF-F
PS-1000 B 1 1.250 5/8 BMFJF Americana II®, Bronze-Bronze®, 397012
Eagle® Maxim, Power-Glass®, Ultra-Flo® 397020
PS-201 A 1 1.375 3/4 BMFJF Americana®, Bronze-Noryl® 395005
AMPCO PUMPS CO.
PS-359V-CMS C 1 1.250 5/8 VCFJF GS625002
PS-633V-CMS C 1 1.250 5/8 VCFKF GS625003
PS-357 C 1 1.625 1 BCFKF GS5009976
PS-356V-CMS C 1 1.750 1-1/8 VCFJF GS1125008
PS-7908 C 1 1.875 1-1/4 BCFJF 316SS/I GS8103410, GS5097400
PS-756 C 1 1.875 1-1/4 BCFKF GS5009974
PS-2122V-CMS C 1 1.875 1-1/4 VCFJF GS8105960
PS-1109-EPR C 3 1.875 1-1/4 QCFKF GS8106850
PS-3543 C 1 2.375 1-5/8 VCFZF 316SS/I GS5098409
AMPRO-DIACLEAR
PS-163 B 1 1.000 1/2 BMFJF Dia Cast, Lexan®-200 Series AP-504D
PS-1000 B 1 1.250 5/8 BMFJF Dura-Flo®, Noryl® Turbo, XL 600 AP-304D
ANTHONY & SYLVAN
PS-100 A 1 1.187 5/8 BMFJF 04547
PS-1000 B 1 1.250 5/8 BMFJF 04380
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
H. SprING HOLDer NOT INCLUDeD
A.O. SMITH CORP.
PS-162 A 1 1.000 1/2 BMFJF 55831, 64135
PS-506 A 1 1.000 1/2 BMFKF 9708-1, 9708-4
PS-752 D 1 1.375 3/4 BCDKF
APOLLO DENTAL PRODUCTS, INC.
PS-218 A — — 5/8 BCF-F MMS71110
PS-4323 C 3 1.187 3/4 BCFJF H MMS71102 / MMS71107
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
APV® CENTRIFUGAL PUMP - Replacement Seals for Food, Dairy & Beverage Processingcessing
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
AQUA-CHEM
PS-358 C 1 1.375 3/4 BCFJF 925-7520
PS-235 C 1 1.625 1 BCFJF 925-7526
PS-251 E 3 1.625 1 BCFKF 925-7509
PS-618 C 3 1.875 1-1/4 BCFJF 925-7563
PS-177 C 1 2.000 1-3/8 BCFJF 925-7523
PS-2114 C 3 2.625 1-7/8 BCFJF 925-7562
W 20/20, 25/75, 30/25, 30/50, 40/20, 50/25 - Non-Flushed
VGFS-1000 Single 25MM QCFLF 179644
VGFS-1001 Single 25MM QLFLF 179645
VGFS-1002 Single 25MM VCFLF 179647
VGFS-1003 Single 25MM VLFLF 179648
VGFS-1004 Single 25MM BCFLF 771661
VGFS-1005 Single 25MM BLFLF 771662
W 20/20, 25/75, 30/25, 30/50, 40/20, 50/25 - Flushed
VGFS-1006 Double 25MM QCFLF 179656
VGFS-1007 Double 25MM QC/LFLF 179657
VGFS-1008 Double 25MM VCFLF 179659
VGFS-1009 Double 25MM VC/LFLF 771660
VGFS-1010 Double 25MM BCFLF 771679
VGFS-1011 Double 25MM BC/LFLF 771680
W 30/100, 50/50, 50/100, 60/300, 70/30, 80/50, 100/130 - Non-Flushed
VGFS-1020 Single 35MM QCFLF 179650
VGFS-1021 Single 35MM QLFLF 179651
VGFS-1022 Single 35MM VCFLF 771653
VGFS-1023 Single 35MM VLFLF 771654
VGFS-1024 Single 35MM BCFLF 771670
VGFS-1025 Single 35MM BLFLF 771671
W 30/100, 50/50, 50/100, 60/300, 70/30, 80/50, 100/130 - Flushed
VGFS-1026 Double 35MM QCFLF 179662
VGFS-1027 Double 35MM QC/LFLF 179663
VGFS-1028 Double 35MM VCFLF 179665
VGFS-1029 Double 35MM VC/LFLF 179666
W+ 10/8, 22/20, 30/80, 35/35, 35/55, 50/8, 55/35 - Non-Flushed
VGFS-1030 Single 25MM QC-L- 772461
VGFS-1031 Single 25MM VC-L- 772462
VGFS-1032 Single 25MM QL-L- 772463
VGFS-1033 Single 25MM VL-L- 772464
W+ 25/210, 30/120, 30/180, 55/60, 60/110, 65/350, 70/40, 80/80, 110/130 - Non-Flushed
VGFS-1040 Single 35MM QC-L- 772466
VGFS-1041 Single 35MM VC-L- 772467
VGFS-1042 Single 35MM QL-L- 772468
VGFS-1043 Single 35MM VL-L- 772469
VGFS-1000
VGFS-1006
With Common Seat
VGFS-1042
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
b. TApereD SprING
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
ARBEE CORP.
PS-235 C 1 1.625 1 BCFJF
PS-351 E 1 3.125 2-1/4 BCDKF
ARDE BARINCO, INC.
PS-3065 K 1 1.625 1 VCFRF A315-18V
PS-3765 K 1 3.000 2-1/8 VCFRF A63-18V
ARMSTRONG PUMPS, INC.
PS-8066 X Special 1 .864 1/4 QCFLF Gemini / 10 180200-277, 880200-277
PS-401A C 1 .938 1/2 BCFJF N 816549-091
PS-3844 C 1 .938 1/2 BCFJF 816706-001, 816706-002
816706-021, 916706-021
PS-392 C 1 .938 1/2 B/QMFJF 816032-000
PS-3843 C 1 .938 1/2 VCFJF 116706-021, 116706-023
816706-003, 816706-004
816706-023, 916706-023
PS-359V-CMS C 1 1.250 5/8 VCFJF 810134-000, 910134-000
PS-358V C 3 1.375 3/4 VCFJF 816707-001, 816707-002
PS-752 D 1 1.375 3/4 BCDKF
PS-750V-CMS-P66 D 1 1.375 3/4 VCDJF I 116707-003, 116707-004
PS-750V D 3 1.375 3/4 VCDJF 816707-003
PS-8006 XB2 27 2.375 1-1/8 VCFJF 316SS 975002-003
PS-3029 C 1 1.750 1-1/4 BCFJF B 975000-958
PS-979 C 1 1.765 1-1/4 BCFKF B
PS-185-EPR-P66 C 1 1.875 1-1/4 QCFJF I 975000-991
PS-618-EPR-P66 C 3 1.875 1-1/4 QCFJF I 810150-125
PS-2203 C 3 1.875 1-1/4 QCFKF I
PS-976 D 1 1.765 1-1/4 BCFJF 825458-001
PS-977 D 1 1.765 1-1/4 BCFKF
PS-3023 D 1 1.875 1-1/4 QCFLF I 975000-981, 975000-982
9975000-981
PS-517 D 3 1.875 1-1/4 BCFKF 810150-137
PS-517-TC-SEAT D 3 1.875 1-1/4 BCFZF 810150-133
PS-383V D 3 1.875 1-1/4 VCFKF 810150-127
PS-3030 C 1 2.375 1-5/8 QCFJF I 975000-993
PS-7017 C 3 2.375 1-5/8 QCFKF I 975000-961
PS-514 D 1 2.375 1-5/8 BCDJF
PS-461 D 1 2.375 1-5/8 BCDKF
PS-3025 D 1 2.375 1-5/8 QCFLF I 975000-983, 975000-984
9975000-983
PS-8040 XB2 27 2.843 1-5/8 VCFJF 316SS 975000-956, 975002-033
PS-205 E 1 2.500 1-3/4 BCFJF 425920-001
PS-338-EPR C 3 3.000 2-1/8 QCFJF S 975000-997,9975000-997
PS-543V C 3 3.000 2-1/8 VCFKF D101166-108
PS-3035 D 1 3.000 2-1/8 QCFLF I 975000-985, 975000-987
9975000-987
PS-8035 XB2 27 3.375 2-1/8 VCFJF 316SS 975000-957, 975002-073
PS-853 C 3 3.375 2-1/2 BCFKF Model 4600 12x10x12.5 D101166-010
VGM-2966 VGMH 5 25 12 VC/LFLF 30.3
VGM-2967 VGMH 5 26 12 VC/LFLF 30.3
VGM-2968 VGMH 5 28 12 VC/LFLF 30.3
VGM-2969 VGMH 5 26 14 VC/LFLF 38.3
VGM-2970 VGMH 5 28 14 VC/LFLF 38.3
VGM-2971 VGMH 5 30 14 VC/LFLF 38.3
Mating Mating Seal
Value Guard Ring Ring Size Material Oper.
Part No. Head Thick OD MM Code Hgt.
AQUASCAPE PUMP - (Used in Decorative Ponds and Waterfalls)
Type VGMH
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Material
Part No. Head Size Code Notes Mfg. Part No.
NOTE:
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
ARMSTRONG PUMPS, INC. - Series 4300
VG-975002304 VGXB2 1-1/8 XCFLF 316SS 975002-304
VG-975002334 VGXB2 1-5/8 XCFLF 316SS 975002-334
VG-975002374 VGXB2 2-1/8 XCFLF 316SS 975002-374
VG-975002394 VGXB2 2-5/8 XCFLF 316SS 975002-394
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
ARNESON PRODUCTS, INC.
PS-200 A 1 1.250 5/8 BMFJF Pool Sweep A-8
ASTRAL POOL
PS-200 A 1 1.250 5/8 BMFJF Astramax Series 1800
PS-1000 B 1 1.250 5/8 BMFJF Sena Series 1600
ATLANTIC FLUIDICS (Div. of TUTHILL CORP.)
PS-1000 B 1 1.250 5/8 BMFJF
PS-601 B 1 1.375 3/4 BMFJF
PS-356 C 1 1.750 1-1/8 BCFJF
PS-185 C 1 1.875 1-1/4 BCFJF
PS-177 C 1 2.000 1-3/8 BCFJF
AURORA PUMP (Div. of PENTAIR)
PS-7520 C 1 1.250 15MM BCFKF I 712-6444-749
PS-3140 C 1 1.250 15MM VCFJF 712-6444-764
PS-129 D 1 1.250 15MM BCDJF #4 Series Pump 712-0703-754
PS-1675 D 1 1.250 15MM BCFKF 14AS114ABF 712-0703-752
PS-3192 D 1 1.250 15MM VCFKF I 712-0753-745
PS-100 A 1 1.187 5/8 BMFJF 712-7042-750
PS-2204 A 1 1.250 5/8 VCFZF 712-2042-767
PS-290 C 1 1.250 5/8 BCFJF N BJ, BJH, BJV, BJF w/ Motors thru 712-1003-753
3/4 HP 1750 RPM, thru 1-1/2 HP
3500 RPM
PS-633 C 1 1.250 5/8 BCFKF 712-1003-749
PS-358 C 1 1.375 3/4 BCFJF BJ, BJH, BJV, BJF w/ Motors 1HP
1750 RPM Up, 2 HP 3500 RPM Up.
Types: GAFA, GAHA, GAPB, GAVA,
Models: GA-4, 5, 6, 7 and 9.
PS-4330 C 1 1.375 3/4 BCFKF I 712-1004-749
PS-4531 C 1 1.375 3/4 QCFZF H/I 712-1004-769
PS-3162 C 1 1.375 3/4 QZFLF 712-1004-497
PS-7843 C 1 1.375 3/4 VCFJF I 712-1004-764
PS-2229V-P66 C 1 1.375 3/4 VCFKF I 712-1004-745
PS-3156 C 1 1.375 3/4 VLFLF 712-1004-576
PS-752 D 1 1.375 3/4 BCDKF 712-0705-755
PS-135 D 1 1.500 20MM BCDJF # 5 Series Turbine Pump 712-0707-752
712-0707-754
PS-614 D 1 1.500 20MM BCDKF I 712-0707-755
PS-3135 D 1 1.500 20MM BCFKF I 712-0707-749
PS-3728 D 1 1.625 25MM VCFJF 712-6452-764
Type VGXB2
Features
• External Seal Design
• Pressure Balanced
• Handles Temperatures to +450°F
• Set screw driven for positive drive
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
AURORA PUMP (Div. of PENTAIR) (continued)
PS-3167 D 1 1.625 25MM VCFZF I 712-6452-727
PS-380 D 1 1.625 1 BCFJF 712-0709-754
PS-3900 D 1 1.625 1 BCDKF H/I 712-6452-755
PS-460-P66 D 1 1.625 1 BCFKF I 712-0709-755
PS-356 C 1 1.750 1-1/8 BCFJF BC, BCH, BCV, BCF and GBH w/ 712-0907-753
Frames 56 thru 256U. Type: GBHA &
GBVA w/Mtr. Frs. 143T, 145T, 182T &
184T. Type: GBPA w/Power Frame 1.
Type OJ Power Series, 2 x 2 1/2 x 9-10-12
PS-355-P66 C 1 1.750 1-1/8 BCFKF I 712-0907-749
PS-7325 C 1 1.750 1-1/8 QCFZF I 712-0907-769
PS-356V-CMS C 1 1.750 1-1/8 VCFJF 712-0907-764
PS-355V-CMS C 1 1.750 1-1/8 VCFKF 712-0907-745
PS-801 C 3 1.750 1-1/8 B/VCFJF 712-2732-753
PS-2226 C 3 1.750 1-1/8 QCFZF I 712-0937-769
PS-384 E 1 1.750 1-1/8 BCFKF 712-0454-749
PS-867 E 3 1.750 1-1/8 BCFKF 712-0354-756
PS-3163 E 5 1.750 1-1/8 BCFZF 316SS/I 712-1431-737
PS-3109 E 5 1.750 1-1/8 QCDZF I 712-1431-769
PS-136 D 1 1.875 30MM BCDJF # 6 Series Turbine Pump 712-0713-754
PS-1179-P66 D 1 1.875 30MM BCDKF I 712-0713-755
PS-1179V-P66 D 1 1.875 30MM VCDKF I 712-0713-774
PS-3938 D 1 1.875 30MM VCFZF I 712-0713-727
PS-306 E 1 1.875 1-3/16 BCDJF GGU, KCM, KCMF, KGG, KU, KUF 712-0305-754
PS-185 C 1 1.875 1-1/4 BCFJF 712-0908-753
PS-137 E 1 1.875 1-1/4 BCFKF GMC & GAC 712-0306-755
PS-758 C 1 2.125 1-1/2 BCFJF BC, BCH, BCV & GBH W/Motor Frame 712-1010-753
284U & Up. GBHA & GBVA w/ Motor.
F. 213T & Up. Type OJ Power Series #2.
PS-2232 C 1 2.125 1-1/2 BCFKF I 712-0910-749
PS-3166 C 1 2.125 1-1/2 BZFLF 316SS
PS-2209 C 1 2.125 1-1/2 BZFZF 712-0910-678
PS-4171 C 1 2.125 1-1/2 QCFKF I
PS-3224 C 1 2.125 1-1/2 QCFZF 712-0910-769
PS-3165 C 1 2.125 1-1/2 VCFJF I 712-0910-764
PS-3141 C 1 2.125 1-1/2 VCFKF I Shorter Free Spring Length 712-0910-745
PS-7747 C 1 2.125 1-1/2 VCFZF I 712-0910-767
PS-3174 C 3 2.125 1-1/2 BCFKF Shorter Spring than PS-553 712-0940-749
PS-3160 C 3 2.125 1-1/2 QCFZF I 712-0940-769
PS-758V C 3 2.125 1-1/2 VCFJF
PS-382 D 1 2.125 1-1/2 BCFJF 712-0718-754
PS-305 E 1 2.125 1-1/2 BCFJF
PS-7933 E 1 2.125 1-1/2 QCFZF I 712-0409-769
PS-395 E 3 2.125 1-1/2 BCFJF 712-0459-753
PS-258 E 3 2.125 1-1/2 BCFKF 712-0359-753
PS-7562 E 3 2.125 1-1/2 QCFZF I 712-0359-769
PS-305V E 3 2.125 1-1/2 VCFJF 712-0359-764
PS-4368 E 5 2.125 1-1/2 QCFZF I 712-1432-769
PS-664 E 3 2.375 1-9/16 BCDJF 712-0310-754
PS-238 C 1 2.375 1-5/8 BCFJF 712-0911-753
PS-446 C 1 2.500 1-3/4 BCFJF Type OJ Power Series # 4 712-1012-753
PS-448-P66 C 1 2.500 1-3/4 BCFKF I 712-1012-749
PS-446V-CMS C 1 2.500 1-3/4 VCFJF 712-1012-764
PS-4153 C 1 2.500 1-3/4 VCFJF 316SS 2158210SC-01
PS-448V-TC-P66 C 1 2.500 1-3/4 VCFZF I 712-0912-767
NOTE:
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
I. AbrASION reSISTANT CArbON (p66)
AURORA PUMP (Div. of PENTAIR) (continued)
PS-7820 C 1 2.500 1-3/4 VLFLF 712-1012-576
PS-436-P66 C 3 2.500 1-3/4 BCFKF I 712-1042-749
PS-7035 C 3 2.500 1-3/4 QCFZF I 712-1042-769
PS-3177 E 1 2.500 1-3/4 BCFKF I 712-0412-749
PS-7736 E 1 2.500 1-3/4 QCFZF I 712-0412-769
712-0462-769
PS-366V-CMS-P66 E 1 2.500 1-3/4 VCFKF I 712-0412-745
PS-535 E 3 2.500 1-3/4 BCFJF 712-0462-753
PS-4429 E 5 2.500 1-3/4 BCFZF I 712-1433-747
PS-4372 E 5 2.500 1-3/4 QCFZF I 712-1433-769
PS-267 C 1 2.750 2 BCFJF Type OJ Power Series # 4 712-1014-753
PS-842-P66 C 1 2.750 2 BCFKF I 712-1014-749
PS-2219 C 1 2.750 2 BZFZF 712-1014-678
PS-267V-CMS C 1 2.750 2 VCFJF 712-1014-764
PS-842V-P66-CMS C 1 2.750 2 VCFKF I 712-1014-745
PS-332 C 3 2.750 2 BCFKF 712-1044-749
PS-479V E 3 2.750 2 VCFJF
PS-3708 E 5 2.750 2 BCFZF I 712-1434-747
PS-3108 E 5 2.750 2 QCFZF I 712-1434-769
PS-1678 C 3 3.125 2-1/4 BCFJF
PS-3075 E 3 3.281 2-1/4 BZFZF 712-6409-678
PS-7766 K 3 3.125 2-1/4 BCFJF 712-6478-753
PS-7060 K 3 3.281 2-1/4 BCFKF I 712-6410-749
PS-3210 V 3 .562/.750 2-1/4 BCFKF I 712-6411-749
PS-268-CMS C 1 3.250 2-3/8 BCFJF 712-1017-753
PS-492-CMS-P66 C 1 3.250 2-3/8 BCFKF I 712-0917-749
712-1017-749
712-2717-749
PS-268 C 3 3.250 2-3/8 BCFJF Type OJ Power Series # 5 712-1047-753
PS-492 C 3 3.250 2-3/8 BCFKF 712-1047-749
PS-492-P66 C 3 3.250 2-3/8 BCFKF I 712-1017-749
PS-3127 C 3 3.250 2-3/8 VCFJF I 712-1047-764
PS-278 E 3 3.250 2-3/8 BCFJF 712-0467-753
PS-350 E 3 3.250 2-3/8 BCFKF 712-0462-756
712-0467-756
PS-278V E 3 3.250 2-3/8 VCFJF 712-0467-764
PS-4006 E 5 3.250 2-3/8 BCFZF I 712-1435-747
PS-3187 E 5 3.250 2-3/8 QCFZF I 712-1435-769
PS-269 C 3 3.375 2-1/2 BCFJF SPHER-Flo Series 4A-4B 712-1048-753
712-1012-739
PS-3924 E 3 3.250 2-1/2 BCPKF 712-6390-756
PS-279 E 3 3.375 2-1/2 BCFJF 712-0468-753
PS-349 E 3 3.375 2-1/2 BCFKF 712-0468-756
PS-2205 E 3 3.375 2-1/2 BCFKF I 712-0468-755
PS-2205-EPR E 3 3.375 2-1/2 QCFKF I
PS-3164 E 5 3.375 2-1/2 BCFZF I 712-1436-747
PS-1695 K 3 3.375 2-1/2 BCFKF 712-2743-749
PS-270 C 3 3.750 2-7/8 BCFJF Type OJ Power Series # 6
PS-841-P66 E 3 3.750 2-7/8 BCFKF I 712-0471-755
PS-2116 C 3 3.875 3 BCFJF 712-7010-739
PS-3836 U 3 3.875 3 BCFJF 712-7038-753
PS-3553 T 3 4.781 3-5/8 BCFKF I 712-6415-749
PS-8054 V 3 4.781 3-5/8 BCFKF I 712-6416-749
PS-272 C 3 4.625 3-3/4 BCFJF SPHER-Flo Series 5A, 5B, 5C, 5D
PS-4414 V 3 6.781 5 BCFKF 712-6421-749
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Bore Seal Material
Part No. Size Size Code Mfg. Part No.
AURORA PUMP - REPLACEMENT SEAL KITS
VGK-1124 Small 1-1/8 BCFKF 476-0250-644
VGK-1126 Small 1-1/8 VCFKF
VGK-1127 Small 1-1/8 BCFJF
VGK-1128 Small 1-1/8 VCFJF
VGK-1125 Large 1-1/2 BCFKF 476-0253-644
VGK-1129 Large 1-1/2 VCFKF
VGK-1130 Large 1-1/2 BCFJF
VGK-1131 Large 1-1/2 VCFJF
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
AUTOMATIC ICE & BEVERAGE - (Ice Machines)
PS-6312 Q Special 1.625 1 BMPAP 9121026-91
BAKER-HYDRO (Div. of WATERCO)
PS-200 A 1 1.250 5/8 BMFJF 35B1178
PS-3985 B 1 1.375 3/4 BCFJF 316SS 634016
BAKER MFG. CO.
PS-1050 C — — 1/2 BCF-F E93B
FA-10033 C — — 1/2 VCF-F E93V
PS-3172 C 3 1.000 1/2 BCFKF E18AM
PS-933V C — — 5/8 VCF-F F93V
PS-732 C 3 1.250 5/8 BCFKF F18AM, F18AMP
PS-3133 C 3 1.250 5/8 NCFKF F18CMS
PS-359V C 3 1.250 5/8 VCFJF F18FMV
PS-633V C 3 1.250 5/8 VCFKF F18BMVP
PS-3132 D 3 1.250 5/8 NCFLF F18MNN
PS-208 C — — 7/8 BCF-F H93B
PS-617 C 3 1.500 7/8 BCFKF H18AM, H18AMP
PS-309V C 3 1.500 7/8 VCFJF H18FMV
PS-687V C 3 1.500 7/8 VCFKF H18BMV, H18BMVF
H18BMVP
PS-4318 D 3 1.500 7/8 NCFLF H18MNN
PS-3116 D 3 1.500 7/8 VCFLF 316SS H18MNV
BALDOR RELIANCE (Member of the ABB GROUP)
PS-356 C 1 1.750 1-1/8 BCFJF 64262-12L
PS-185 C 1 1.875 1-1/4 BCFJF Motor Frame 140 64262-12A
PS-2208 C 1 1.875 1-1/4 BZFZF Motor Frame 140 64262-20A
PS-185V-CMS C 1 1.875 1-1/4 VCFJF Motor Frame 140 64262-13A
PS-185V-TC-TC C 1 1.875 1-1/4 VZFZF Motor Frame 140 64262-20AA
PS-618-TC-TC C 3 1.875 1-1/4 BZFZF Motor Frame 140 64262-15E
PS-618V-TC-SEAT C 3 1.875 1-1/4 VCFZF 64262-23A
PS-381 D 1 1.875 1-1/4 BCFJF Motor Frame 140 64262-8A
PS-381-SC-SC D 1 1.875 1-1/4 BLFLF 64262-39A
PS-6229 K 3 1.875 1-1/4 BCFJF 316SS 64262-41D
• Kits include gaskets, pins, o-rings, sleeve,
and mechanical seal.
• Aurora Pump is not affiliated with U.S.Seal Mfg.
• Products supplied are manufactured or
purchased by U.S.Seal Mfg. from sources
other than the company listed.
VGK-1125
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
S. SLOTTeD MATING rING
BALDOR RELIANCE (Member of the ABB GROUP) (continued)
PS-4134
X Special
Special 1.875 1-3/8 B/NCPGF 64147-24R
PS-758 C 1 2.125 1-1/2 BCFJF Motor Frame 140 or 180 64262-12B
PS-758-SC-SC C 1 2.125 1-1/2 BLFLF Motor Frame 140 or 180 64262-39B
PS-2209 C 1 2.125 1-1/2 BZFZF Motor Frame 140 or 180 64262-20B
PS-7409 C 1 2.125 1-1/2 VCFJF 316SS Motor Frame 140 or 180 64262-13B
PS-758V-SC-SC C 1 2.125 1-1/2 VLFLF Motor Frame 140 or 180 64262-39BB
PS-659V-TC-VS-TC C 1 2.125 1-1/2 VZFZF Motor Frame 140 or 180 64262-20BB
PS-382 D 1 2.125 1-1/2 BCFJF Motor Frame 140 or 180 64262-8B
PS-446 C 1 2.500 1-3/4 BCFJF Motor Frame 180 or 210 64262-12C
PS-6210 C 1 2.500 1-3/4 BZFZF Motor Frame 180 or 210 64262-20C
PS-446V-CMS C 1 2.500 1-3/4 VCFJF Motor Frame 180 or 210 64262-13C
PS-7820 C 1 2.500 1-3/4 VLFLF Motor Frame 180 or 210 64262-39CC
PS-446V-TC-TC C 1 2.500 1-3/4 VZFZF Motor Frame 180 or 210 64262-20CC
PS-436-SC-SC C 3 2.500 1-3/4 BLFLF Motor Frame 180 or 210 64262-39C
PS-436-TC-TC C 3 2.500 1-3/4 BZFZF Motor Frame 140 or 180 64262-15C
PS-2207 C 3 2.500 1-3/4 VCFZF Motor Frame 180 or 210 64262-23C
PS-237 D 1 2.500 1-3/4 BCDJF Motor Frame 180 or 210 64262-8C
PS-6217 D 1 2.500 1-3/4 VZFLF 316SS Motor Frame 180 or 210 64262-25CC
PS-267 C 1 2.750 2 BCFJF Motor Frame 210 or 250 64262-12D
PS-267-SC-SC-CMS C 1 2.750 2 BLFLF Motor Frame 210 or 250 64262-39D
PS-2219 C 1 2.750 2 BZFZF Motor Frame 210 or 250 64262-20D
PS-267V-CMS C 1 2.750 2 VCFJF Motor Frame 210 or 250 64262-13D
PS-6224 C 1 2.750 2 VLFLF Motor Frame 210 or 250 64262-39DD
PS-6218 C 1 2.750 2 VZFZF Motor Frame 210 or 250 64262-25DD
PS-6213 C 1 2.750 2 VZFZF 316SS Motor Frame 210 or 250 64262-20DD
PS-267V-TC-SEAT C 3 2.750 2 VCFZF Motor Frame 210 or 250 64262-23D
PS-2143 K 1 2.750 2 BCFJF
PS-7196 K 3 2.750 2 BCFJF S 64262-41E
PS-1057 C 3 3.000 2-1/8 B/VCFKF 611725-5B
PS-1679 C 1 3.125 2-1/4 BCFJF Motor Frame 250 64262-12E
PS-3182 C 1 3.125 2-1/4 BLFLF Motor Frame 250 64262-39E
PS-7064 C 1 3.125 2-1/4 BZFZF Motor Frame 250 64262-20E
PS-1678V C 3 3.125 2-1/4 VCFJF Motor Frame 250 64262-13E
PS-6233 C 3 3.125 2-1/4 VCFLF 64262-67A
PS-7766 K 3 3.125 2-1/4 BCFJF 64262-41C
PS-6205 C 1 3.500 2-3/4 BCFJF Motor Frame 320 64262-18F
PS-6220 C 1 3.500 2-3/4 BZFLF Motor Frame 320 64262-25N
PS-6908 C 1 3.500 2-3/4 BZFZF Motor Frame 320 64262-20N
PS-6207 C 3 3.500 2-3/4 VCFJF Motor Frame 320 64262-18N
PS-483V-TC-SEAT C 3 3.500 2-3/4 VCFZF 64262-23G
PS-2154V-TC-TC C 3 3.500 2-3/4 VZFZF Motor Frame 320 64262-20NN
PS-2153-SC-SC-CMS C 1 3.875 3 BLFLF Motor Frame 320 64262-39M
PS-7875 C 1 3.875 3 BZFZF Motor Frame 360 64262-20H
PS-7998 C 1 3.875 3 BZFZF Motor Frame 360 64262-20M
PS-3539 C 1 3.875 3 VZFZF Motor Frame 360 64262-20MM
PS-6214 C 1 3.875 3 VZFZF Motor Frame 320 64262-20HH
PS-2116 C 3 3.875 3 BCFJF Motor Frame 360 64262-12G
PS-2153 C 3 3.875 3 BCFJF Motor Frame 320 64262-18G
PS-6206V C 3 3.875 3 VCFJF Motor Frame 320 64262-18L
PS-3232 C 3 3.875 3 VCFZF 64262-23H
PS-6225 C 3 3.875 3 VLFLF Motor Frame 360 64262-39HH
PS-3231 C 3 3.875 3 VZFLF 64262-25H
PS-6202 D 1 3.875 3 BZFZF Motor Frame 360 64262-8H, 64262-62HH
PS-6232 D 3 3.875 3 VZFLF Motor Frame 360 64262-62AA
PS-6228 K 3 3.875 3 VCFJF 64262-41B
PS-6226 C 3 4.125 3-1/4 VLFLF Motor Frame 360 64262-39KK
PS-7172 D 3 4.125 3-1/4 BCFJF Motor Frame 360 64262-8J, 64262-63C
PS-3827 D 3 4.125 3-1/4 BZFZF Motor Frame 360 64262-8Kand 20K
PS-6201 D 3 4.125 3-1/4 VCFJF Motor Frame 360 64262-8F and 36KK
PS-6227 K 3 4.125 3-1/4 VCFJF 64262-41A
PS-6204 C 3 4.375 3-1/2 BCFJF 64262-12K
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
N. NON-STANDArD SprING HOLDer
BALDOR RELIANCE (Member of the ABB GROUP) (continued)
PS-6221 D 3 4.375 3-1/2 V/BZFZF 64262-33A
PS-3745 D 3 4.375 3-1/2 VZFZF 64262-37PP
PS-6203 D 3 4.625 3-3/4 VCFJF 64262-8M
PS-6231 D 3 6.375 5-3/8 VZFLF 64262-43F
PS-6230 D 3 6.625 5-5/8 VCFJF 64262-42D
BALDWIN-LIMA-HAMILTON (PATTERSON PUMP CO.)
PS-371 D 1 2.125 1-1/2 BCFKF 600-28-267
PS-288 D 1 2.500 1-3/4 BCDKF 600-28-284
BALTIMORE AIRCOIL CO.
PS-299 A — — 5/8 BMF-F 300329
PS-974 A — — 3/4 BCF-F 300331
BALZER, INC.
PS-618 C 3 1.875 1-1/4 BCFJF 33013
PS-598-SC-SC C 3 1.875 1-1/4 BLFLF 36755
BANJO CORP.
PS-3985 B 1 1.375 3/4 BCFJF 316SS 12713BN, 12733BN
PS-4056 B 1 1.375 3/4 QCFJF 150P3, 200P3 & 5 12713, 12733
PS-3986 B 1 1.375 3/4 VCFJF 12713V, 12733V
PS-601V B 3 1.375 3/4 VCFJF 127135
PS-3785 C 1 1.625 1 VCFJF 150/200-P1-3, 200P1-5 17035, 17135
PS-3959 K 1 1.625 1 VCFJF 17235
PS-3813 C 1 2.125 1-1/2 VCFJF B/H 300-P1-8, 300PB/PO1 18025, 18125
BARNARD-LEAS MFG.
PS-200V A 3 1.250 5/8 VCFJF 5-0-17
BARNES, JOHN S.
PS-400 C — — 1/2 BMF-F PA-4947
PS-933 C — — 5/8 BCF-F PA-2408
PS-508 D 1 1.250 5/8 BCDJF 5080
PS-358 C 1 1.375 3/4 BCFJF 3SE2042L 67562
PS-578 D — — 7/8 BCD-F PA-2421
PS-397 C — — 1 BCF-F PA-1525
PS-348 C — — 1-1/8 BCF-F PA-4386
PS-383 D 1 1.875 1-1/4 BCFKF Y-42
PS-461 D 1 2.375 1-5/8 BCDKF Y-45
PS-223 D — — 1-7/8 BCD-F PA-3684
BEACH RUSS
PS-400 C — — 1/2 BMF-F
PS-678 K — — 5/8 BCF-F
PS-564 C — — 3/4 BCF-F
PS-145 K — — 3/4 BCF-F
PS-141 R — — 1 BCF-F
PS-185 C 1 1.875 1-1/4 BCFJF
BELL & GOSSETT
PS-8066 X Special 1 .864 1/4 QCFLF 189144
PS-400A — 1 .938 1/2 B--J- 118619
PS-401 C — — 1/2 BCF-F N 118614
PS-400 C — — 1/2 BMF-F Cast Iron 3/4 thru 3 Booster Pumps PZ-3118-118680
Type: E and H1 PZ-4118
Type: E1, 1-1/4, 1-1/2HV
PS-401A C 1 .938 1/2 BCFJF N For PD-35, PD-37 Series 1522 Kit #3, 186681
PS-393 C 1 .938 1/2 BMFKF
PS-392 C 1 .938 1/2 B/QMFJF Bronze 3/4 thru 3 Boosters BPD 35, Kit #7, 189102, 189182
BPD 37-Series 1522- PD 35 & PD Kit 118681
37- Series 60AA 1522 Cast Iron 3TC29200AB-F58
PS-7712 C 1 1.125 1/2 BMFJF Kit #20
PS-4349 G 1 .938 1/2 QLFLF P86261
PS-516 A 1 1.250 5/8 BCFJF DP0304
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
b. TApereD SprING
I. AbrASION reSISTANT CArbON (p66)
BELL & GOSSETT (continued)
PS-200 A 1 1.250 5/8 BMFJF 180013
PS-118 C 1 1.187 5/8 BCFJF 186879
PS-359 C 1 1.250 5/8 BCFJF
PS-2160 C 1 1.250 5/8 BCFJF DP0302, 180014
PS-399 D — — 3/4 BCD-F PW2Z-3188
P-18008-0601
PS-437 D 1 1.275 3/4 BCDJF 1512-PD-39, BPD-39 and 60A Kit #2, 172553, 185260
186433, 186499
PS-4098 D 1 1.275 3/4 QCDJF
PS-4024 G 1 1.275 3/4 QLFLF P86262
PS-309 C 1 1.500 7/8 BCFJF DP0294
PS-397 C — — 1 BCF-F
PS-235 C 1 1.625 1 BCFJF 180011, 650PF
PS-398 D — — 1 BCF-F PW1Z-4118
PS-348 C — — 1-1/8 BCF-F PHD-118A
PS-356 C 1 1.750 1-1/8 BCFJF 180017
PS-3712 D 3 1.750 1-1/8 VCFZF I DP0476
PS-384 E 1 1.750 1-1/8 BCFKF
PS-978 C 1 1.765 1-1/4 BCFJF B All Iron-Series 1510, 1515, 1531 186860, 186862
(Small Frame) Types M1 and M2
PS-979 C 1 1.765 1-1/4 BCFKF B
PS-978-EPR-TC C 1 1.765 1-1/4 QCFZF B 186861
PS-978-EPR-SC-SC C 1 1.765 1-1/4 QLFLF B P75423
PS-4204 C 1 1.765 1-1/4 QRFLF
PS-978V C 1 1.765 1-1/4 VCFJF B 185060
PS-185-P66 C 1 1.875 1-1/4 BCFJF I P70511
PS-185V-CMS C 1 1.875 1-1/4 VCFJF P70513, 186877
PS-416 D — — 1-1/4 BCF-F
PS-976 D 1 1.765 1-1/4 BCFJF Series 1510, 1515, 1531 Universal Kit #1 185011, 186680
(Small Frame) Types M1 and M2
PS-977 D 1 1.765 1-1/4 BCFKF
PS-6261 G 1 1.875 1-1/4 QCFJF 316SS/I P75221
PS-6260 G 1 1.875 1-1/4 QCFZF 316SS/I P75223
PS-6264 G 1 1.875 1-1/4 VCFJF 316SS/I P75225
PS-172 C — — 1-3/8 BCF-F AC5228
FA-10166 C — — 1-3/8 BCF-F I P63336
PS-177 C 1 2.000 1-3/8 BCFJF 52-115-605-801 / DP 0298
PS-376-EPR-P66 D — — 1-3/8 QCD-F I P63316
PS-491 D 1 2.000 1-3/8 BCDJF 186827
PS-186 D 1 2.000 1-3/8 BCDKF VSC 4 x 4x 9-3/4, 5 x 5 x 9-3/4, P77084
5 x 5 x 12, 6 x 6 x 9-3/4
PS-7803 D 1 2.000 1-3/8 QCDZF I 186834
PS-186V D 1 2.000 1-3/8 VCDKF
PS-224 E 3 2.125 1-1/2 NCFKF
PS-238 C 1 2.375 1-5/8 BCFJF 186544
PS-3831 C 1 2.375 1-5/8 BCFJF B
PS-238-EPR C 1 2.375 1-5/8 QCFJF
PS-1019 C 3 2.625 1-5/8 BCFKF 185043
PS-4288 C 3 2.625 1-5/8 QCFZF AC3048
PS-514 D 1 2.375 1-5/8 BCDJF Series 1531, 1510 Universal Kit #8,186543
(Large Frame) M2 and C
PS-461 D 1 2.375 1-5/8 BCDKF Kit #8
PS-514-EPR-TC D 1 2.375 1-5/8 QCDZF 185225
PS-6262 G 1 2.375 1-5/8 QCFJF 316SS/I P75222
PS-6263 G 1 2.375 1-5/8 QCFZF 316SS/I P75224
PS-2108 C — — 1-3/4 BCF-F AC5229
FA-10168 C — — 1-3/4 BCF-F I P63337
PS-550 C 3 2.500 1-3/4 BCFJF 52-112-693-802
PS-446V C 3 2.500 1-3/4 VCFJF F4992S
PS-237 D 1 2.500 1-3/4 BCDJF 186826
PS-288 D 1 2.500 1-3/4 BCDKF VSC 6 x 6 x 12, 8 x 8 x 10-1/2 &13 P77033
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
I. AbrASION reSISTANT CArbON (p66)
BELL & GOSSETT (continued)
PS-7652 D 1 2.500 1-3/4 QCDZF I 186835
FA-2000 C — — 2 BCF-F AC0642, AC5230
PS-4345 C 3 3.000 2 BCFJF I P70517
PS-1020-EPR-P66 C 3 3.000 2 QCFKF I 186574
PS-3027 C 3 3.000 2 QCFZF AC3049
PS-4357 G 25 2.750 2 QCFLF VSX P5001889
PS-3019 G 25 2.750 2 QLFLF 316SS P5001028
PS-3170 G 25 2.750 2 VCFLF 316SS P5001890
PS-3020 G 3 3.000 2-1/8 QCFJF 316SS P75396
PS-1676 C 3 3.125 2-1/4 BCFKF 52-118-949-802
PS-834 D 3 3.250 2-3/8 BCDJF VSC 10 x 10 x 13, 12 x 12 x 13 186828
PS-594 D 3 3.250 2-3/8 BCDKF VSC 10 x 10 x 13, 12 x 12 x 13
PS-3804 G 25 3.375 2-1/2 QCFLF VSX P5001891
PS-4490 G 25 3.375 2-1/2 QLFLF 316SS P5001086
PS-7909 D 3 3.375 2-5/8 BCFJF I P75572, 185377
PS-3188 D 3 3.375 2-5/8 QCFZF 316SS 185378
PS-328-P66 E 3 3.375 2-5/8 BCFJF I
PS-838 E 3 3.500 2-3/4 V/BCFJF 52-122-588-813
PS-3802 G 3 3.875 3 QCFLF VSX-VSH 18 x 10 x 22A P5001893
PS-3793 G 3 4.375 3-1/2 QCFLF VSX-VSC 14 x 16 x 17 P5001895
Value Guard Seal Material
Part No. Head Size Code Notes Pump Nameplate Data Mfg. Part No.
BELL & GOSSETT - Series 80-SC
VG-P75202 VGXB2 1-1/4 XCFLF 316SS P75202
VG-975002334 VGXB2 1-5/8 XCFLF 316SS P75203
Value Guard Seal Material
Part No. Head Size Code Pump Nameplate Data Mfg. Part No.
BELL & GOSSETT - Models 80-S, 1510-S, 1531-S, VSC-S*, VSVS-S*
VG-P85070 VGRO 1-1/4 XZFCF P85070
VG-185050 VGRO 1-5/8 XZFCF 185050
VG-185051 VGRO 2 XZFCF 185051
VG-185054 VGRO 2-5/8 XLFCF 185054
VG-185052 VGRO 2-5/8 XZFCF 185052
VG-185055 VGRO 3-3/4 XLFCF 185055
VG-185053 VGRO 3-3/4 XZFCF 185053
Type VGXB2
Type VGRO
* Split Case Pumps - Require 2 Seals
Features
• External seal design
• Pressure balanced
• Handles temperatures to +450°F
• Set screw driven for positive drive
Features
• Handles temperatures to +450°F
• Set screw driven for positive drive
• Multiple springs create consistent face pressure
• Unitized rotating assembly simplifies installation
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
BEMATEK SYSTEMS, INC.
FA-10047 C — — 2 VCF-F 20178-P2347
BENNETT PUMP
PS-400 C — — 1/2 BMF-F 541-M-1003
PS-157 C — — 3/4 BCF-F 541-M-1001
BERGSTROM MFG.
PS-3225 A 1 1.000 1/2 BCFJF 573630
BERKELEY (See PENTAIR, INC. for Additional Part Numbers)
PS-516 A 1 1.250 5/8 BCFJF S-20788, S-20789, S-20994
PS-200 A 1 1.250 5/8 BMFJF New Style Mid-Jet S4 Models: HS, S-08019, S-20790
CIMPS, CIMPHS,CIXPS, CIXPRS,
C1-1/4MPS, B1-1/2APKS, D1-1/2MPKS
PS-202 B 11 — 5/8 BMFJF A BM-3081 Mid-Jet 49-53 B1MRS, S-05053, S-05645
B1MRHS, B1XRHS, B1-1/4MRS, S-16844, S-20900
B1-1/2MRS S-20996
PS-202V B 11 — 5/8 VCFJF A S-18150
PS-3960 G 1 1.250 5/8 BCFJF S-08019
PS-851 A 1 1.375 3/4 BCFJF S-20794, S-21961
PS-973 A 1 1.375 3/4 BCFKF S-22380
PS-201 A 1 1.375 3/4 BMFJF New Style: C1-1/2TPLS, C2TPMS, S-05646, S-20791
C2-1/2TPMS, B1-1/2MQKS S-20792, S-21962
C2TPMS, C2-1/2TPMS, B1XQHS
B1-1/4MQS, B1-1/2MQS
PS-921 A 1 1.375 3/4 BMFKF S-20793, S-32280
PS-201V-CMS A 1 1.375 3/4 VCFJF S-18662
PS-440 B 11 — 3/4 BMFJF A S-20997
PS-7618 B 11 1.375 3/4 BCFJF S-06405
PS-750 D 1 1.375 3/4 BCDJF Model 142MPKS, 1-1/2MQKS S-05647
PS-752 D 1 1.375 3/4 BCDKF S-20780
PS-2008 D 1 1.375 3/4 BCFJF S-20779
PS-360 A 1 1.625 1 BCFJF S-08742, S-09583
S-20795, S-20796
PS-460 D 1 1.625 1 BCFKF S-20781
PS-754 E 1 1.625 1 BCFJF S-14867
PS-236 E 1 1.625 1 BCFKF S-20764, S-20765
PS-356 C 1 1.750 1-1/8 BCFJF S-32690
PS-2227 C 1 1.750 1-1/8 BCFJF S-32689
PS-604 D 1 1.750 1-1/8 BCFJF S-16812
PS-605 D 1 1.750 1-1/8 BCFKF S-20783
PS-204 E 1 1.750 1-1/8 BCFJF BZR, BZQ S-07216
PS-384 E 1 1.750 1-1/8 BCFKF BZR, BZQ S-20767, S-20768, S-20995
PS-185 C 1 1.875 1-1/4 BCFJF S-32014
PS-2122 C 1 1.875 1-1/4 BCFJF S-32013
PS-381 D 1 1.875 1-1/4 BCFJF Model 2TPKHS, 3TQKHS, 2TQKIS, S-05649, S-20784, S-20785
3TQKHS, 22TQKHS, 2TRKHS
PS-383 D 1 1.875 1-1/4 BCFKF S-20786
PS-361 E 1 1.875 1-1/4 BCFJF All Models A Row Pump except S-05648, S-20770
6YPH, 4EPBL & 6YP
PS-137 E 1 1.875 1-1/4 BCFKF S-15368, S-20769
PS-1185 E 1 1.875 1-1/4 NCPJP S-20771
PS-883 K 1 1.875 1-1/4 BCFJF S-39485
PS-305 E 1 2.125 1-1/2 BCFJF Models 6YPH, 4EPBL, B1-1/2TQLS, S-05650 S-20774
B2TQMS, 2-1/2TQMS, B3TQMS
PS-374 E 1 2.125 1-1/2 BCFKF S-15385
PS-258 E 3 2.125 1-1/2 BCFKF S-20773, S-20775
PS-374V E 3 2.125 1-1/2 VCFKF S-15538
PS-821 D 3 2.375 1-5/8 BCDJF S-16656
PS-446 C 1 2.500 1-3/4 BCFJF S-32015
PS-2142 C 1 2.500 1-3/4 BCFJF S-32692
PS-237 D 1 2.500 1-3/4 BCDJF S-16768
PS-288 D 1 2.500 1-3/4 BCDKF
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
BERKELEY (See PENTAIR, INC. for Additional Part Numbers)
PS-205 E 1 2.500 1-3/4 BCFJF “A” Row Pump, Model B3TPMS S-07277, S-20776, S-20777
PS-366 E 1 2.500 1-3/4 BCFKF
PS-593 D 3 2.625 1-7/8 BCDKF S-20787, S-20993
PS-2069 E 1 2.625 1-7/8 BCFJF S-15213, S-20778
PS-2072 E 3 2.625 1-7/8 BCFKF S-20884
PS-479 E 1 2.750 2 BCFJF S-13481
PS-4248 C 3 3.000 2-1/8 VCFJF S S-32016
PS-537 E 1 3.000 2-1/8 BCFJF S-15894, S-15950
PS-353 E 1 3.000 2-1/8 BCFKF S-16076
PS-327 E 3 3.000 2-1/8 BCFJF S-17274
PS-835 D 3 3.375 2-1/2 BCDJF S-18337
PS-463 D 3 3.375 2-1/2 BCDKF S-30320
Value Guard Shaft
Part No. Head MM Material Code Mfg. Part No.
BJM PUMPS®
VGM-01325E VGMA 20 BCFJF / BLFLF M01325E
VGM-01325V VGMA 20 VCFJF / VLFLF M01325V
VGM-01352CV VGMA 25 VCFJF / VLFLF M01352CV
VGM-8030V * VGM562 30 VCFJF / VLFLF M01368V
VGM-01362E VGMA 32 QCFJF / QLFLF M01362E
VGM-01362V VGMA 32 VCFJF / VLFLF M01362V
VGM-01366E VGMA 35 QCFJF / QLFLF M01366E
VGM-01366V VGMA 35 VCFJF / VLFLF M01366V
VGM-1355 * VGM562 45 BLFLF / BLFLF M01355
VGM-1355V * VGM562 45 VLFLF / VLFLF M01355V
* Includes retaining plate
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
BLACKMER (Dover Corp.)
PS-303 D 1 1.500 7/8 BCDKF 333030
PS-9007 W Special 2.156 1 TCFJF 316SS 333102
PS-9338 W 27 1.812 1-1/16 TCFKF 331277
BLAKESLEE, INC. - (Dishwashers and Prep Equipment)
PS-235V C 3 1.625 1 VCFJF PUMPAKS Models 30-010 thru 30-023 32-036
PS-3401 Q 9 — 1 NMDKF A 02255
BOWSER
PS-564 C — — 3/4 BCF-F 27A09
PS-466 C 1 2.000 1-1/4 BCFJF 28A09
BRADEN WINCH
PS-201 A 1 1.375 3/4 BMFJF
BSM PUMP CORP.
PS-358 C 1 1.375 3/4 BCFJF 466-142-1
PS-182 C 20 Plate 3/4 NCPGP Models 3S, 53, 55, 103 713-9030-270
PS-235 C 1 1.625 1 BCFJF 466-137-1
PS-185 C 1 1.875 1-1/4 BCFJF 213-744-274
PS-185-P66 C 1 1.875 1-1/4 BCFJF I 713-9245-270
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 466-292-1
PS-186 D 1 2.000 1-3/8 BCDKF 466-143-1
PS-237 D 1 2.500 1-3/4 BCDJF 213-752-274
BUFFALO PUMPS
PS-290 C 1 1.250 5/8 BCFJF N Models BPL, BPM, BPO CC-10900
PS-235 C 1 1.625 1 BCFJF Models BPL, BPM, BPO CC-10901
PS-384 E 1 1.750 1-1/8 BCFKF Models 1-1/2, 2 & 3SL,1-1/2 & 2SA
w/ Solid Shafts, 2-1/2SW
PS-137 E 1 1.875 1-1/4 BCFKF 1-1/2, 2 & 3SL, SA Sleeved 231-31-330
Type VGMA
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
BUFFALO PUMPS (continued)
PS-2104 E — — 1-3/8 BCF-F 231-31-412, 231-31-1012
231-31-1573
PS-354 E 1 2.000 1-3/8 BCFJF
PS-677 E 1 2.000 1-3/8 BCFKF
PS-374 E 1 2.125 1-1/2 BCFKF 4SL, 3SA, 2RR, 284 Stage,
6SLH & 4HSM
PS-744 E 1 2.375 1-5/8 BCDKF 5SL, 4S, Large Frame 13564-6
PS-340 C 1 2.625 1-7/8 BCFJF 231-31-435
PS-340-EPR-TC-CMS C 1 2.625 1-7/8 QCFZF 231-31-1602
PS-2069 E 1 2.625 1-7/8 BCFJF 231-31-1357
PS-2070 E 1 2.625 1-7/8 BCFKF 6SL, 4RR, 6HSM, 2 STAGE D1 13564-8
Dbl. Suction, 4SL Extra Heavy
PS-2069-TC-SEAT E 1 2.625 1-7/8 BCFZF 231-31-1278
PS-7869 E 1 2.625 1-7/8 QCFZF I 231-31-1150
PS-279 E 3 3.375 2-1/2 BCFJF 231-31-1724
PS-349 E 3 3.375 2-1/2 BCFKF Model 8SL
PS-350 E 3 3.250 2-3/8 BCFKF D2 Dbl. Suction Pumps, 6S & 6SU
PS-321 E 3 3.500 2-3/4 V/BCFKF 231-31-410
BURKS PUMPS (Div. of CRANE PUMPS & SYSTEMS)
PS-1002 C 1 1.000 1/2 BCFJF 21727
PS-200 A 1 1.250 5/8 BMFJF 17038
PS-290 C 1 1.250 5/8 BCFJF N 8514, 23846
PS-290V C 1 1.250 5/8 VCFJF N 9652, 9676, 9762, 3CJSM
PS-2206 C 3 1.250 5/8 QCFKF 20764-C
PS-1156V C 3 1.250 5/8 VCFKF 20498-C
PS-201 A 1 1.375 3/4 BMFJF 17039
PS-3149 C 1 1.375 3/4 BCFJF 08991
PS-358V C 3 1.375 3/4 VCFJF 9813
PS-185 C 1 1.875 1-1/4 BCFJF 9917
PS-756-EPR C 1 1.875 1-1/4 QCFKF
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 9926
PS-598-EPR C 3 1.875 1-1/4 QCFKF 23559
PS-381 D 1 1.875 1-1/4 BCFJF 33066-1-1/2
PS-4044 C 1 2.125 1-3/8 BCFJF
PS-238 C 1 2.375 1-5/8 BCFJF 21136
PS-238V-CMS C 1 2.375 1-5/8 VCFJF 21189
PS-1068 C 1 2.500 1-3/4 BCFKF M-3842-C
BYRON JACKSON (Div. of FLOWSERVE)
PS-775 D 3 1.500 7/8 BCDJF Series 400 D-30903
PS-428 R 1 1.500 7/8 BCDJF Series 400 D-30904
PS-2033 D 3 1.625 1 BCFJF Series 513 D-30433
PS-8111 XB2 3 2.125 1-7/16 BCFKF 316SS
PS-382 D 1 2.125 1-1/2 BCFJF
CAMAC INDUSTRIES
PS-358V-CMS C 1 1.375 3/4 VCFJF Series 50
PS-883V-CMS K 1 1.875 1-1/4 VCFJF 254
CAMERON COMPRESSION SYSTEMS
PS-185 C 1 1.875 1-1/4 BCFJF 2-01S-073-003
PS-1018 C 3 2.000 1-1/4 BCFKF Z2-01S-140-001
PS-177 C 1 2.000 1-3/8 BCFJF Z109-500
PS-3213 C 3 2.000 1-3/8 VCFKF I Z024-616
PS-239 C 1 2.375 1-5/8 BCFKF 2-01S-077-001
PS-535 E 3 2.500 1-3/4 BCFJF ZJA-043-000
CARLYLE COMPRESSOR CO.
PS-6058 E Plate Plate 1-1/2 NCPGP
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
b. TApereD SprING
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
CARTER PUMPS, INC.
PS-100 A 1 1.187 5/8 BMFJF 1S-5010
PS-200 A 1 1.250 5/8 BMFJF 1S-5005A, 1S-5054
PS-290 C 1 1.250 5/8 BCFJF N 1S-5023, 1S-5035
PS-201 A 1 1.375 3/4 BMFJF 1S-5039
PS-360 A 1 1.625 1 BCFJF 2S-5050, 2S-5089
2S-5054, 2S-5112
PS-383 D 1 1.875 1-1/4 BCFKF 2S-5116, 2S-5119
3S-5239
PS-186 D 1 2.000 1-3/8 BCDKF 4S-5106, 4S-5151
PS-553 C 3 2.125 1-1/2 BCFKF 4S-5215
PS-446 C 1 2.500 1-3/4 BCFJF 4S-5052
PS-237 D 1 2.500 1-3/4 BCDJF 6S-5202
PS-288 D 1 2.500 1-3/4 BCDKF 5S-5029
CARVER PUMP CO.
PS-200 A 1 1.250 5/8 BMFJF B20-1, B1-2-1-1/4
PS-359 C 1 1.250 5/8 BCFJF BB20-1
PS-201 A 1 1.375 3/4 BMFJF K1/2, L20-11
PS-358 C 1 1.375 3/4 BCFJF Model T14C6
PS-188 E 1 1.500 7/8 BCFJF
PS-229 E 3 1.500 7/8 BCFKF 091-087-02-0212
PS-3507 E 3 1.500 7/8 VZFLF 316SS 091-087-02-02AQ
PS-360 A 1 1.625 1 BCFJF KN-3LC
PS-356 C 1 1.750 1-1/8 BCFJF A300-810
PS-627 C 1 1.750 1-1/8 BCFJF B 26C6, 2-1/2YC7, 2YC7, 3YC9
PS-185 C 1 1.875 1-1/4 BCFJF K2L-20-9
PS-525 C 3 1.875 1-1/4 BCFKF B
PS-466 C 1 2.000 1-1/4 BCFJF 090-125-01-0101
PS-466V C 1 2.000 1-1/4 VCFJF 090-125-01-0103
PS-4131 C 1 2.000 1-1/4 VCFJF 316SS 090-125-01-0114
PS-3185 C 1 2.000 1-1/4 VCFKF 090-125-01-0104
PS-3178 C 1 2.000 1-1/4 VCFLF 090-125-01-0166
PS-381 D 1 1.875 1-1/4 BCFJF KN-2H-2L-3N
PS-1183-P66 E 3 1.875 1-1/4 BCFKF I Model 10P 090-125-02-0236
PS-4049 E 3 1.875 1-1/4 VCFLF 316SS Model 10P 090-125-02-1269
PS-681 U 1 1.875 1-1/4 BCD/FJF 1, 1-1/4, 1-1/2, 2, 3, 4L,
1-1/4, 1-1/2, 2, 2-1/2, 3, 4LA,
1LB, 1-1/4, 2, 2-1/2, 3, 4H,
1-1/4, 1-1/2, 2, 2-1/2, 3, 4HA
PS-186 D 1 2.000 1-3/8 BCDKF 4GHC, 4GHB, 4B, 4BB
PS-745 E 1 2.375 1-5/8 BCDJF 090-162-02-4608
PS-822 E 3 2.375 1-5/8 BCDKF
PS-1683V E 3 2.375 1-5/8 VCFJF 090-162-02-0203
PS-262-EPR-P66 E 3 2.500 1-3/4 QCFKF I 090-175-02-0246
PS-7252 E 1 2.625 1-3/4 BCFJF 090-175-01-0110
PS-2130 E 3 2.625 1-3/4 BCFJF
PS-4290 E 3 2.625 1-3/4 QCFLF Model 20P
PS-4141 E 3 2.625 1-3/4 QCFZF I 090-175-01-0137
PS-3227 E 3 2.625 1-3/4 VCFJF 316SS 090-175-01-0114
PS-3169 E 3 2.625 1-3/4 VCFKF 316SS 090-175-01-0104
PS-3054 E 3 2.625 1-3/4 VCFLF 316SS Model 20P 090-175-01-0166
PS-4228 E 3 2.625 1-3/4 VCFZF 316SS/I 090-175-01-0105
PS-8124 XB 3 2.375 1-7/8 QCFLF 316SS/S 090-187-02-J6DW
PS-8010 XB 3 2.375 1-7/8 VCFZF 316SS/I 090-187-02-9958
PS-8059 XBT 3 2.375 1-7/8 QCFZF 316SS 090-187-02-99AZ
PS-3522 E 3 2.750 2 BCFKF 316SS/I 090-200-02-0236
PS-477 E 3 2.750 2 BCFKF
PS-3079 E 3 2.750 2 VCFKF I 090-200-02-0299
PS-3999 E 3 2.750 2 VCFZF 316SS 091-200-02-1678
PS-3134 E 3 3.000 2-1/8 QCFZF 316SS 090-212-02-02DW
PS-353V E 3 3.000 2-1/8 VCFKF 090-212-02-0204
PS-3576 E 3 3.125 2-1/4 VCFJF 316SS/I 090-225-02-02EG
PS-2098V E 3 3.250 2-3/8 VCFKF 090-237-02-0204
PS-8121 XB 3 3.000 2-3/8 QCFLF 316SS 090-237-02-J6DW
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
CATERPILLAR
PS-642 B — — 5/8 BMF-F 4S-7805
PS-647 B — — 3/4 BMF-F 1N-9177
PS-235 C 1 1.625 1 BCFJF 6N-4743, 6N-9313
C-B TOOL CO. (LANCASTER PUMP DIVISION)
PS-150 B — — 1/2 BMF-F 4761
PS-200 A 1 1.250 5/8 BMFJF 2661
PS-201 A 1 1.375 3/4 BMFJF 1661
PS-357 C 1 1.625 1 BCFKF 4400 Series
CDS - JOHN BLUE COMPANY
PS-879 K 1 1.625 1 BCFJF S3565
PS-879V-CMS K 1 1.625 1 VCFJF Model S3220, (Serial # below 9920) S3565S
VG-2656 HDV 1 2.062 1-3/8 VCFJF Model S3220, (3”, 43005) S3645V
CENCO
PS-452 B 9 — 5/8 BMFJF A P-35332
PS-441 B 9 — 3/4 BMFKF A P-35334
PS-112 C 1 1.375 3/4 BCFKF
PS-1026 D 1 1.437 3/4 BCDKF P-35219
PS-547 C 3 2.000 1-3/8 BCFKF P-29538
CENTREX
PS-299 A — — 5/8 BMF-F
PS-360 A 1 1.625 1 BCFJF 201-491,201-493
CH&E MFG. CO.
PS-516 A 1 1.250 5/8 BCFJF W105-7A
PS-200 A 1 1.250 5/8 BMFJF W105-7
PS-200V-SC-SC A 1 1.250 5/8 VLFLF W105-7C
PS-851 A 1 1.375 3/4 BCFJF W105-1
PS-201V-CMS A 1 1.375 3/4 VCFJF W105-1V
PS-1125-SC-SC C 1 1.375 3/4 BLFLF W105-1D
PS-145 K — — 3/4 BCF-F W105-8
PS-7434 C 1 1.625 1 BCFJF W105-2
PS-380 D 1 1.625 1 BCFJF W105-10
PS-185-SC-SC C 1 1.875 1-1/4 BLFLF W105-15A
PS-758 C 1 2.125 1-1/2 BCFJF W105-4
PS-758-SC-SC C 1 2.125 1-1/2 BLFLF W105-4C
PS-541 K 1 2.125 1-1/2 BCFJF W105-6A
PS-432 R 1 2.125 1-1/2 BCFKF W105-6
PS-449 K 1 2.500 1-3/4 BCFJF W105-11A
CHALLENGE MFG.
PS-642 B — — 5/8 BMF-F
PS-647 B — — 3/4 BMF-F
PS-235 C 1 1.625 1 BCFJF D-97
PS-357V C 3 1.625 1 VCFKF D-98
PS-355 C 1 1.750 1-1/8 BCFKF E-97
PS-659 C 1 2.125 1-1/2 BCFKF H-97
PS-659V C 3 2.125 1-1/2 VCFKF H-98
CHAMPION INDUSTRIES - (Dishwashers)
PS-4470 A 1 1.250 5/8 BMFJF 106467
PS-4479 B 9 1.109 5/8 QCFJF A 108426
PS-3100 Q — — 1 NMDKF Unitized 110276
PS-758 C 1 2.125 1-1/2 BCFJF 110611
PS-3100
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
H. SprING HOLDer NOT INCLUDeD
CHEMINEER, INC. (Unit of ROBBINS & MYERS)
PS-818 C 3 2.375 1-5/8 BCFJF 472-00242
PS-238V C 3 2.375 1-5/8 VCFJF 472-00082
CHEM-TROL, INC.
PS-8110 XB2 3 2.000 1-3/8 VCFJF 316SS
CHICAGO PUMP (Div. of YEOMANS CHICAGO CORP.)
PS-100 A 1 1.187 5/8 BMFJF
PS-200 A 1 1.250 5/8 BMFJF 2658090
PS-263 D 1 1.187 5/8 BCDKF 266910
PS-750 D 1 1.375 3/4 BCDJF 2655888, 2663071
PS-265 D 3 1.375 3/4 BCDKF
PS-250 D 3 1.500 7/8 BCDKF 2675339
PS-188 E 1 1.500 7/8 BCFJF 2657110, 2663072
PS-229 E 3 1.500 7/8 BCFKF 267338
PS-380 D 1 1.625 1 BCFJF
PS-252 D 3 1.625 1 BCFKF 2675341
PS-754 E 1 1.625 1 BCFJF 2655887
PS-251 E 3 1.625 1 BCFKF 2675340
PS-604 D 1 1.750 1-1/8 BCFJF 2658071
PS-605 D 1 1.750 1-1/8 BCFKF 2655131
PS-254 D 3 1.750 1-1/8 BCFKF 2675344
PS-253 E 3 1.750 1-1/8 BCFKF 2675343
PS-306 E 1 1.875 1-3/16 BCDJF 2655886
PS-255 E 3 1.875 1-3/16 BCDKF 2675345
PS-361 E 1 1.875 1-1/4 BCFJF
PS-256 E 3 1.875 1-1/4 BCFKF 2675347
PS-264 E 3 1.875 1-1/4 BCFKF 2675318
PS-354 E 1 2.000 1-3/8 BCFJF 2655089
PS-257 E 3 2.000 1-3/8 BCFKF 2675350 000
PS-258 E 3 2.125 1-1/2 BCFKF 2675351
PS-259 E 3 2.125 1-1/2 BCFKF 2675352 000
PS-868 T 1 2.125 1-1/2 BCFJF VPM-LLC4
PS-446 C 1 2.500 1-3/4 BCFJF 117185
PS-262 E 3 2.500 1-3/4 BCFKF VPM-LMC4 2675354
CLAY EQUIPMENT
PS-185 C 1 1.875 1-1/4 BCFJF 0-902718-0
PS-758 C 1 2.125 1-1/2 BCFJF 0-902719-0
CLAYTON MARK
PS-501 A 1 1.250 5/8 BMFJF 29304B
CLEARWATER INDUSTRIES, INC.
PS-163 B 1 1.000 1/2 BMFJF 516069
CLEAVER-BROOKS, INC.
PS-358 C 1 1.375 3/4 BCFJF 925-65
CLEVELAND GEAR CO.
PS-5082 C 2 1.750 1 BCFKF H Z1032N
PS-254 D 3 1.750 1-1/8 BCFKF Z1028C
PS-4363 D 3 2.187 1-1/2 BCFGF Z1028E
PS-3026 D 3 2.437 1-5/8 BCDGF Z1028F
PS-333 D 3 2.812 2 NCPGP Reducer 400 Z1028G
PS-335V D 3 3.375 2-1/2 VCPGP Z1028H
PS-3713 D 3 4.000 3 NCPGP Z1028J
CLIMAX ENGINE
PS-380 D 1 1.625 1 BCFJF
CLOW CORP. (See YEOMANS CHICAGO CORP.)
COLUMBIA
PS-142 B 1 1.000 1/2 BMFJF
CONSOLIDATED DIESEL ELECTRIC
PS-758 C 1 2.125 1-1/2 BCFJF 0338-0275
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
CONSTRUCTION MACHINE (See CRANE PUMPS & SYSTEMS)
CONTINENTAL PUMP
PS-290 C 1 1.250 5/8 BCFJF N V8-15Q
PS-359 C 1 1.250 5/8 BCFJF V8-15A, U8-15Q
PS-359-EPR-CMS C 1 1.250 5/8 QCFJF
PS-358 C 1 1.375 3/4 BCFJF U8-56QA/R
PS-358V-CMS C 1 1.375 3/4 VCFJF U8-56F
COOPER ENERGY SERVICES (See CAMERON COMPRESSION SYSTEMS)
CORCORAN CO.
PS-358V C 3 1.375 3/4 VCFJF
CORKEN, INC.
PS-598 C 3 1.875 1-1/4 BCFKF 2994-XA
PS-756V C 3 1.875 1-1/4 VCFKF 2994-XD
CORNELL PUMP
PS-3960 G 1 1.250 5/8 BCFJF A14997G-40
PS-618 C 3 1.875 1-1/4 BCFJF A17161J-40, A17161P-40
PS-546 E 3 1.875 1-1/4 BCFJF A15002C-40, A15002E-40
A17161X-40
PS-137V E 3 1.875 1-1/4 VCFKF A15002D-40
PS-3153 K 1 1.875 1-1/4 BZFLF A15007Y-40
PS-2211 T 3 1.875 1-1/4 BCFJF A15002H-40
PS-3607 T 3 1.875 1-1/4 NAFGF A15002I-40
PS-3229 R 3 1.875 1-1/4 VZFLF S A17161Z-40
PS-864 E 3 2.000 1-3/8 BCFJF A15003J-40
PS-821 D 3 2.375 1-5/8 BCDJF A15005H-40
PS-1698 D 3 2.375 1-5/8 BCFJF A17064M-40
PS-3223 D 3 2.375 1-5/8 BZFLF A17064K-40
PS-3186 D 3 2.375 1-5/8 VCFLF 316SS/S A20769J-40
PS-3772 D 3 2.375 1-5/8 VZFLF A17064X-40
PS-595 E 3 2.375 1-5/8 BCDJF A15005D-40
PS-822 E 3 2.375 1-5/8 BCDKF A1500SC-40
PS-1683 E 3 2.375 1-5/8 BCFJF A15005A-40, A17064Q-40
PS-1699 E 3 2.375 1-5/8 BCFKF A15005Y-40, A207691-40
PS-1699V E 3 2.375 1-5/8 VCFKF A15005X-40
PS-4471 E 3 2.375 1-5/8 VCFLF 316SS A17064V-40
PS-3071 R 2 2.375 1-5/8 NAFGF S A150051-40
PS-550 C 3 2.500 1-3/4 BCFJF A15006F-40, A15006M-40
PS-436-TC-VS-SC C 3 2.500 1-3/4 B/VZFLF A15006J-40
PS-532 C 3 2.750 2 BCFJF A20777G-40
PS-833 D 3 2.750 2 BCDJF A15007D-40, A17264P-40
PS-2075 D 3 2.750 2 BCFJF A15007M-40
PS-3142 D 3 2.750 2 VZFLF 316SS/S A17264Q-40
PS-530 E 3 2.750 2 BCFJF A15007B-40
PS-2143 K 1 2.750 2 BCFJF A15007J-40-225
PS-7196 K 3 2.750 2 BCFJF S A15007J-40
PS-468 D 3 3.250 2-1/2 BCDJF A15008E-40
PS-463-TC-SC D 3 3.375 2-1/2 BZFLF A17258W-40, A205226U-40
PS-3888 D 3 3.375 2-1/2 VZFLF A16421D-40, A20526R-40
PS-279 E 3 3.375 2-1/2 BCFJF A15008A-40
PS-349V-TC-SC E 3 3.375 2-1/2 VZFLF A17258V-40, A20526F-40
PS-1613 K 3 3.375 2-1/2 BCFJF A15008R-40
PS-6219 D 3 3.875 3 BZFLF A169721-40
PS-4033 D 3 3.875 3 VZFLF A169720-40, A20564P-40
PS-324 E 3 3.875 3 BCDJF A15009A-40, A20564D-40
PS-7875 C 1 3.875 3 BZFZF A22335E-40
PS-7873 K 3 3.875 3 BCFJF A15009G-40
PS-3222 D 3 4.125 3-1/4 VZFLF S A22646A-40
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
CRANE-DEMING (Div. of CRANE PUMPS & SYSTEMS)
PS-1002 C 1 1.000 1/2 BCFJF 0058125
PS-106 C 1 1.000 1/2 BCFKF 0058216
PS-1002V C 1 1.000 1/2 VCFJF 0055716
PS-200 A 1 1.250 5/8 BMFJF Fig. 4910-63, 4357, 4358
PS-501 A 1 1.250 5/8 BMFJF Fig. 4910, 11, 12, 13, 4963, 66, 67
PS-507 A 1 1.250 5/8 BMFKF
PS-200V-CMS A 1 1.250 5/8 VCFJF 0040861
PS-507V-CMS A 1 1.250 5/8 VCFKF 8009530
PS-493 C 1 1.187 5/8 BCFKF 0006841, 0006876
PS-359 C 1 1.250 5/8 BCFJF 0034427
PS-633 C 1 1.250 5/8 BCFKF 115515
PS-359V-CMS C 1 1.250 5/8 VCFJF 115835
PS-226 D 1 1.187 5/8 BCDKF 0006875, 0020444
PS-201 A 1 1.375 3/4 BMFJF Fig. 4910, 4911, 3305, 3352, 4352
PS-750 D 1 1.375 3/4 BCDJF
PS-208 C — — 7/8 BCF-F 6880
PS-309 C 1 1.500 7/8 BCFJF Fig. 4001, Dwg. 116-386 0030876
PS-687 C 1 1.500 7/8 BCFKF Fig. 4001 0030877
PS-309V C 3 1.500 7/8 VCFJF 0084876
PS-687V C 3 1.500 7/8 VCFKF 0084877
PS-790 D 1 1.437 7/8 BCDJF Fig. 4001, Dwg. 112-041
PS-892 K 1 1.500 7/8 BCFJF Fig. 4001 0030894
PS-878 K 1 1.500 7/8 BCFKF Fig. 4001 0030895
PS-428 R 1 1.500 7/8 BCDJF Fig. 4001, Dwg. 113-068
PS-2145 C 3 1.437 1 BCFJF 0065187
PS-3755 C 3 1.437 1 VCFJF 0075513
PS-235 C 1 1.625 1 BCFJF 0030878
PS-357 C 1 1.625 1 BCFKF Fig. 4011, Dwg. 115-313 0030879
PS-460 D 1 1.625 1 BCFKF Fig. 4011
PS-4882 E 3 1.437 1 BCFJF 0099273
PS-879 K 1 1.625 1 BCFJF
PS-3126 K 1 1.625 1 BCFKF 0030897
PS-141 R — — 1 BCF-F Fig. 3302-04 #2
PS-429 R 1 1.625 1 BCFJF
PS-608 E 1 1.687 1-1/8 BCFKF Fig. 4012, Size 1A
PS-384 E 1 1.750 1-1/8 BCFKF 0029177
PS-185 C 1 1.875 1-1/4 BCFJF 0030880, 0070713
PS-756 C 1 1.875 1-1/4 BCFKF 0030881
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 0088458, 0088459
PS-598-TC-SEAT C 3 1.875 1-1/4 BCFZF 8030880
PS-756V C 3 1.875 1-1/4 VCFKF 0084881
PS-381 D 1 1.875 1-1/4 BCFJF
PS-383 D 1 1.875 1-1/4 BCFKF Model 7180
PS-1015 E — — 1-1/4 BCF-F 0078876
PS-546 E 3 1.875 1-1/4 BCFJF Model AVS 0078879
PS-883 K 1 1.875 1-1/4 BCFJF 0030898
PS-890 K 1 1.875 1-1/4 BCFKF 0030899
PS-2211 T 3 1.875 1-1/4 BCFJF 0045935
PS-186 D 1 2.000 1-3/8 BCDKF 0030882
PS-209 K — — 1-3/8 BCF-F
PS-2234 E 3 2.062 1-7/16 BCFKF Models 1523, 1535 0036636
PS-758 C 1 2.125 1-1/2 BCFJF 0030884
PS-659 C 1 2.125 1-1/2 BCFKF Fig. 4021HD 0030885
PS-2209 C 1 2.125 1-1/2 BZFZF 8030885
PS-659V-CMS C 1 2.125 1-1/2 VCFKF 0084885
PS-382 D 1 2.125 1-1/2 BCFJF Fig. 4021HD
PS-3128 K 1 2.125 1-1/2 BCFJF 0030900
PS-3130 K 1 2.125 1-1/2 BCFKF 0030901
PS-431 R 1 2.125 1-1/2 BCFJF
PS-432 R 1 2.125 1-1/2 BCFKF
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
CRANE-DEMING (Div. of CRANE PUMPS & SYSTEMS) (continued)
PS-238 C 1 2.375 1-5/8 BCFJF 0030886
PS-239 C 1 2.375 1-5/8 BCFKF 0030887
PS-238V-CMS C 1 2.375 1-5/8 VCFJF 106330
PS-239V-CMS C 1 2.375 1-5/8 VCFKF 106331
PS-446 C 1 2.500 1-3/4 BCFJF Model 7360 0030888
PS-448 C 1 2.500 1-3/4 BCFKF 0030889
PS-2207 C 3 2.500 1-3/4 VCFZF 117779
PS-237 D 1 2.500 1-3/4 BCDJF
PS-2109 E — — 1-3/4 BCF-F 0078877
PS-535 E 3 2.500 1-3/4 BCFJF Model 3065 0078882
PS-4097 EB 3 2.500 1-3/4 BCFKF 124410
PS-449 K 1 2.500 1-3/4 BCFJF Fig.7182- Fig.4031
PS-213 R — — 1-3/4 BCD-F
PS-3115 T 3 2.500 1-3/4 BCFJF 0045936
PS-340 C 1 2.625 1-7/8 BCFJF 0046389
PS-1608 C 1 2.625 1-7/8 BCFKF 0046390
PS-312 C 3 2.625 1-7/8 BCFKF
PS-312V C 3 2.625 1-7/8 VCFKF 0075518
PS-543 C 1 3.000 2-1/8 BCFKF 0030891
PS-543V C 3 3.000 2-1/8 VCFKF 119412
PS-353 E 1 3.000 2-1/8 BCFKF
PS-2086 E 3 3.000 2-1/8 BCFKF
PS-2126 T 3 3.000 2-1/8 BCFJF 0043483, 0045937
PS-1679 C 1 3.125 2-1/4 BCFJF 0030892
PS-1676 C 3 3.125 2-1/4 BCFKF 0030893
PS-1676V C 3 3.125 2-1/4 VCFKF 0075520
CRANE PUMPS & SYSTEMS
PS-3000 G 1 26MM 12MM BLFLF 112566B
PS-633-EPR-CMS C 1 1.250 5/8 QCFKF 124476
PS-7547 C 1 1.250 5/8 VLFLF 005080SK
PS-732 C 3 1.250 5/8 BCFKF 21752
PS-5625 Special 1 1.250 5/8 QC-J- 23568
PS-3110 C 1 1.375 3/4 BLFLF 110395SD
PS-3916 C 3 1.375 3/4 BCFJF 110395
PS-767 C 3 1.375 3/4 B/VCFJF 63599
PS-9339 W 2 1.375 3/4 TCFJF 316SS 21741
PS-8064 X 3 1.375 3/4 BLFLF 316SS 083459-A
PS-309 C 1 1.500 7/8 BCFJF M-3824-B, 0030876
PS-3907 C 1 1.500 7/8 BCFJF 2-31006
PS-687V-CMS C 1 1.500 7/8 VCFKF 120941
PS-774 C 3 1.500 7/8 BCFJF 111131
PS-3176 C 3 1.500 7/8 BLFLF 111131SD
PS-197 K — — 7/8 BCF-F M-3046
PS-8065 X 3 1.500 7/8 BLFLF 316SS 082827-A
PS-235 C 1 1.625 1 BCFJF M-4292-B
PS-357 C 1 1.625 1 BCFKF 5MPK, 6MFP, 9MFP, 16PK, M-4292-C
CC1-1/2-1-1/2, CC1-1/2-2
PS-2145 C 3 1.437 1 BCFJF 0068157
PS-235V C 3 1.625 1 VCFJF M-4292-G, 7841-0
PS-4302 C 1 1.750 1-3/16 BCFJF 21942-P
PS-355-SC-SC C 1 1.750 1-1/8 BLFLF 070712SD
PS-604 D 1 1.750 1-1/8 BCFJF M-4274-C
PS-521 D 1 1.875 1-1/8 BCFKF
PS-756 C 1 1.875 1-1/4 BCFKF 19146, 110697
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 23109
PS-185V-TC-SEAT C 1 1.875 1-1/4 VCFZF 118359
PS-185V-TC-TC C 1 1.875 1-1/4 VZFZF 123284
PS-466 C 1 2.000 1-1/4 BCFJF M-3957-C
PS-598-TC-SEAT C 3 1.875 1-1/4 BCFZF 121918
PS-756V C 3 1.875 1-1/4 VCFKF 20500-C, 84881
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
CRANE PUMPS & SYSTEMS (continued)
PS-1015 E — — 1-1/4 BCF-F 78876
PS-546 E 3 1.875 1-1/4 BCFJF 40684
PS-7323 K 1 1.875 1-1/4 BZ/CFZ/JF 60817
PS-467 C 1 2.125 1-3/8 BCFKF M-3983-C
PS-177V C 3 2.000 1-3/8 VCFJF 7842-0
PS-758 C 1 2.125 1-1/2 BCFJF 0030884
PS-758-SC-TC-CMS C 1 2.125 1-1/2 BLFZF 0030885B
PS-2209 C 1 2.125 1-1/2 BZFZF 0030885A
PS-395 E 3 2.125 1-1/2 BCFJF 0099274
PS-238 C 1 2.375 1-5/8 BCFJF 0030886
PS-3664 C 1 2.375 1-5/8 BZFZF 131710
PS-238V-P66-TC C 1 2.375 1-5/8 VCFZF I 131793
PS-7806 C 1 2.375 1-5/8 VLFLF 125579
PS-3144 C 1 2.375 1-5/8 VZFZF 122825
PS-239V C 3 2.375 1-5/8 VCFKF 23150
PS-2212 C 1 2.500 1-3/4 BCFJF M-3842-F
PS-1068 C 1 2.500 1-3/4 BCFKF M-3842-C
PS-466-TC-TC C 1 2.500 1-3/4 BZFZF 71559
PS-4410 C 1 2.500 1-3/4 BZFZF M-3842-L
PS-7820 C 1 2.500 1-3/4 VLFLF M-3842-V
PS-550 C 3 2.500 1-3/4 BCFJF 125852
PS-436-SC-SC C 3 2.500 1-3/4 BLFLF 125852SD
PS-4035
C/X Special
1 2.500 1-3/4 BCFJF M-9262
PS-4491 DB 3 2.375 1-3/4 BCFZF
PS-859-TC-SEAT E 3 2.500 1-3/4 BCFZF 117781
PS-213 R — — 1-3/4 BCD-F M-2653
PS-340 C 1 2.625 1-7/8 BCFJF 46389
PS-3190 K 1 2.625 1-7/8 BZFZF 060818SC
PS-1028 C 1 2.750 2 BCFKF
PS-2219 C 1 2.750 2 BZFZF 71560
PS-1145 C 3 2.750 2 VCFKF 0-536026-E
PS-7892 EB 3 2.625 2 BCFKF 9054995
PS-7196 K 3 2.750 2 BCFJF S 00103045
PS-543 C 1 3.000 2-1/8 BCFKF 0030891
PS-3727 E 3 3.000 2-1/8 VLFLF 122556
PS-1679 C 1 3.125 2-1/4 BCFJF 0030892
PS-1688 E 3 3.125 2-1/4 BCFJF 0099278
PS-3651 C/X 1 3.375 2-1/2 BCFJ* *Special Wave Spring M-9439
PS-468 D 3 3.250 2-1/2 BCDJF M-4272-B
PS-6205 C 1 3.500 2-3/4 BCFJF 85980
PS-6908 C 1 3.500 2-3/4 BZFZF 85981
PS-2153-CMS C 1 3.875 3 BCFJF 085983
CREPACO
PS-397 C — — 1 BCF-F 549S6407F
PS-397V C — — 1 VCF-F 549S6408F
PS-154 C — — 1-1/4 BCF-F 549S6407
CROWN PUMPS (Div. of CRANE PUMPS & SYSTEMS)
PS-235-EPR C 1 1.625 1 QCFJF B4, B6(1-1/2”), B9(2”) BM7274
PS-185V-CMS C 1 1.875 1-1/4 VCFJF B12(3x2), B19(3x3), B21 BM7275
CULLIGAN INTERNATIONAL
PS-4489 A 1 1.375 3/4 BMFJF 325494
CUMMINS WAGNER
PS-1619 B 1 1.625 1 BCDJF 3089056
CURTIS
PS-605 D 1 1.750 1-1/8 BCFKF
PS-288 D 1 2.500 1-3/4 BCDKF RMB-414
DAKON
PS-150 B — — 1/2 BMF-F Seat is Impeller
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
DARLEY, W.S. & COMPANY
PS-6006 D 3 1.375 3/4 BCDLF Springholder not Required 1841502
PS-4246 D 3 1.875 1-1/4 BCDLF 1841203
PS-448 C 1 2.500 1-3/4 BCFKF 1842300
DAYTON (See TEEL PUMP)
DEAN PUMP (Div. of MET-PRO CORP.)
PS-3589 E 5 1.625 1 VCFZF
DECATUR PUMP
PS-501 A 1 1.250 5/8 BMFJF 20888
PS-359 C 1 1.250 5/8 BCFJF
PS-290 C 1 1.250 5/8 BCFJF N 8514
PS-290V C 1 1.250 5/8 VCFJF N 9762
PS-750 D 1 1.375 3/4 BCDJF
PS-185 C 1 1.875 1-1/4 BCFJF 9917
PS-2203 C 3 1.875 1-1/4 QCFKF I 21271
DEFCO, INC.
PS-359V-CMS C 1 1.250 5/8 VCFJF D-520 A2518
VG-879V-SC-SC-CMS
HVD 1 1.625 1 VLFLF A-2517ED
PS-360V-CMS A 1 1.625 1 VCFJF A-720GE-A-715 A2519
DeLAVAL (See IMO INDUSTRIES, INC.)
DELAVAN PUMPS, INC.
PS-200V-CMS A 1 1.250 5/8 VCFJF 34943
PS-1061 A 1 1.250 9/16 VCFJF
DELTA T SYSTEMS, INC.
PS-3147 C 3 1.250 5/8 QCFKF I 108-00001-00
PS-2167-EPR-P66 C 1 1.437 7/8 QCFJF I 108-00006-00
PS-2224 C 3 1.437 7/8 QCFKF I 108-00002-00
DEMING (See CRANE PUMPS & SYSTEMS)
DEMPSTER INDUSTRIES, LLC
PS-162 A 1 1.000 1/2 BMFJF
PS-200 A 1 1.250 5/8 BMFJF 907-06030
PS-202 B 11 — 5/8 BMFJF A
PS-441 B 9 — 3/4 BMFKF A 907-06001
PS-440 B 11 — 3/4 BMFJF A 907-06006
PS-358 C 1 1.375 3/4 BCFJF 907-06043
PS-309 C 1 1.500 7/8 BCFJF 907-06033
PS-309V C 3 1.500 7/8 VCFJF 907-06034
PS-598 C 3 1.875 1-1/4 BCFKF 907-06035
PS-756V C 3 1.875 1-1/4 VCFKF 907-06046
DENISON HYDRAULICS (Parker Hannifin HPD)
PS-5108 C 2 1.562 3/4 VCFKF 623-10508
PS-5676 C 2 2.187 1-3/8 B/VCFJF 316SS
PS-5711 C 2 2.187 1-3/8 B/VCFKF 316SS New Design 623-00006-0
PS-5676V C 2 2.187 1-3/8 VCFJF 316SS 623-00006-5
PS-5074 C 3 2.000 1-3/8 BCFKF 623-08981, 623-11038
PS-5720 C 2 2.125 1-1/2 BCFKF 623-00012-0
PS-5002 D 2 2.500 1-11/16 BCFKF 623-12260-0
PS-5194 D 2 2.500 1-11/16 VCFKF 623-12263-0
PS-5712 C 2 3.000 1-7/8 B/VCFKF N New Design 623-00016-0
PS-5342 C 2 3.000 1-7/8 VCFJF Old Design 623-00016-0
PS-5679 C 2 3.000 1-7/8 QCFJF 623-00016-4
PS-5717 C 2 3.000 1-7/8 VCFJF 623-00016-5
PS-5011 C Plate 3.528 1-7/8 BCFGF 623-00002-0
PS-5721 C Plate Plate 1-7/8 VCFGF 623-00002-5
PS-5706 C 2 3.000 2-1/8 VCFKF 316SS 623-00015-5
PS-5005 D 2 3.000 2-3/16 BCFKF 623-12322-0
PS-5719 D 2 3.000 2-3/16 QCFKF 623-12330-0
PS-5024 D 2 3.000 2-3/16 VCFKF 623-12331-0
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
S. SLOTTeD MATING rING
DETROIT HARVESTER HOWELL
PS-298 A — — 1/2 BMF-F 3-6
PS-299 A — — 5/8 BMF-F H,SM-F,PM,1/4HP, Seat is Impeller. 4-6
PS-100 A 1 1.187 5/8 BMFJF
DEUBLIN CO.
PS-397 C — — 1 BCF-F 954-211
PS-235V C 3 1.625 1 VCFJF
DeVILBISS
PS-508 D 1 1.250 5/8 BCDJF QM-4507
PS-358 C 1 1.375 3/4 BCFJF QM-4509
PS-752 D 1 1.375 3/4 BCDKF QMW-4509
DIACLEAR
PS-142 B 1 1.000 1/2 BMFJF 36100
DISCFLO CORP.
PS-446V-SC-SEAT C 3 2.500 1-3/4 VCFLF P-170-100097
PS-7488 E 3 2.500 1-3/4 VLFLF P-170-100034
PS-338V-SC-SC C 3 3.000 2-1/8 VLFLF S P-170-100036
PS-3877 C 3 3.375 2-1/2 VLFLF P-170-100035
DIXIE PUMP
PS-200 A 1 1.250 5/8 BMFJF
PS-201 A 1 1.375 3/4 BMFJF
DOERR
PS-359 C 1 1.250 5/8 BCFJF
DOMESTIC PUMP (Div. of ITT CORP.)
PS-200 A 1 1.250 5/8 BMFJF 180013
PS-359 C 1 1.250 5/8 BCFJF 180014
PS-201 A 1 1.375 3/4 BMFJF
PS-358 C 1 1.375 3/4 BCFJF 180010
PS-360 A 1 1.625 1 BCFJF
PS-235 C 1 1.625 1 BCFJF 180011
PS-177 C 1 2.000 1-3/8 BCFJF 180015
DOUGHBOY INDUSTRIES (Div. of HOFFINGER INDUSTRIES)
PS-671 B 1 .875 3/8 BMFJF 306-1003
PS-200 A 1 1.250 5/8 BMFJF 306-1006
PS-1000 B 1 1.250 5/8 BMFJF 306-1002
PS-642 B — — 5/8 BMF-F 308-1264
PS-202 B 11 — 5/8 BMFJF A 306-1001
DOUGLAS MOTOR CORP.
PS-201 A 1 1.375 3/4 BMFJF 47406
PS-210 C 1 2.000 1-3/8 BCFKF 46154
DOWDELL CO., J.L. (DOWCO PUMP)
PS-202 B 11 — 5/8 BMFJF A D1101S-5/8
PS-440 B 11 — 3/4 BMFJF A D1101S-3/4
DRESSER INDUSTRIES (See GARDNER DENVER LEROI)
PS-200 A 1 1.250 5/8 BMFJF 125-101/113-1
PS-618 C 3 1.875 1-1/4 BCFJF
PS-1062 C 3 2.125 1-3/8 VCFKF
PS-436V C 3 2.500 1-3/4 VCFKF 125-693-2
DRESSER RAND
PS-768 C 3 1.375 3/4 BCFKF SEL 244
PS-3136 D 2 2.125 1-1/2 BCDKF W27658P1
PS-553 C 3 2.125 1-1/2 BCFKF W27658P2
PS-3931 E 2 2.312 1-5/8 BCDKF W35548P1
PS-3952 E Special 3 3.031 2 NCDKF 000-049-082
PS-611 E 3 2.812 2-1/8 BCFJF
PS-556 U 1 3.000 2-1/8 BCFKF 720025J1
PS-4172 E 3 3.875 3 VCFKF 316SS 050-825-201
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
C. COMpLeTe WITH COLLAr
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
DUFF-NORTON
PS-933 C — — 5/8 BCF-F 732015C
PS-185 C 1 1.875 1-1/4 BCFJF 464901C
DUNHAM, C.A.
PS-508 D 1 1.250 5/8 BCDJF 614
DUNHAM-BUSH (MEPCO Marshall Engineered Products Co.)
PS-1002 C 1 1.000 1/2 BCFJF S-996
PS-106 C 1 1.000 1/2 BCFKF 996 New
PS-118 C 1 1.187 5/8 BCFJF
PS-359 C 1 1.250 5/8 BCFJF S-472
PS-552-SC-SC C 1 1.250 5/8 BLFLF S-5099
PS-633V-CMS C 1 1.250 5/8 VCFKF S-2143, S-5549
PS-552-EPR C 3 1.250 5/8 QCFJF S-5011
PS-552-EPR-P66 C 3 1.250 5/8 QCFJF I S-4940
PS-3147 C 3 1.250 5/8 QCFKF I S-4981
PS-633V-TC SEAT C 3 1.250 5/8 VCFZF S-472-TC-V
PS-750 D 1 1.375 3/4 BCDJF 40088878W
PS-188 E 1 1.500 7/8 BCFJF 40090790W
PS-982 C 1 1.625 1 BCFKF 860
PS-499 C 3 1.625 1 BCFKF GA-1781-4
PS-983 C 1 1.750 1-1/8 BCFKF 861, ML-8702
PS-185 C 1 1.875 1-1/4 BCFJF S-4998
PS-756 C 1 1.875 1-1/4 BCFKF S-3179
PS-756V-CMS C 1 1.875 1-1/4 VCFKF S-5548
PS-618-EPR-P66 C 3 1.875 1-1/4 QCFJF I S-4982, S-5085
PS-239 C 1 2.375 1-5/8 BCFKF S-3291
PS-3616 C 1 2.375 1-5/8 QCFKF S-4932
DURIRON (See FLOWSERVE CORP.)
PS-866 E 3 1.750 1-1/8 BCFJF
PS-867 E 3 1.750 1-1/8 BCFKF
PS-886 T 3 1.750 1-1/8 BCFJF
PS-918 T 3 1.750 1-1/8 BCFKF
PS-3792 E 3 2.125 1-3/8 VCFJF 316SS/C Mark III Group 1K
PS-3783 E 3 2.125 1-3/8 VCFLF 316SS/C Mark III Group 1K
PS-2069 E 1 2.625 1-7/8 BCFJF
PS-7559 E 3 2.625 1-7/8 BCFJF C
PS-2072 E 3 2.625 1-7/8 BCFKF
PS-3046 E 3 2.625 1-7/8 QCFJF
316SS/H/S
PS-3049 E 3 2.625 1-7/8 QZFLF
316SS/H/S
Mark III Group 2
PS-3929 E 3 2.625 1-7/8 VCFJF 316SS/C Mark III Group 2
PS-7698V-LC E 3 2.625 1-7/8 VCFKF C/S
PS-7878 T 1 2.625 1-7/8 BCFJF
PS-743 T 1 2.625 1-7/8 BCFKF
PS-4392 E 3 3.625 2-5/8 QCFLF C
DURO
PS-452 B 9 — 5/8 BMFJF A 5486
PS-508 D 1 1.250 5/8 BCDJF 5485
PS-102 D 1 1.250 5/8 BCDKF Models DV-30, 50, 70, 100, VX-30, B-170
50, 70, 100 DJ-70, 100, S J70, 100
EAST SIDE MFG.
PS-100 A 1 1.187 5/8 BMFJF P-28322
PS-200 A 1 1.250 5/8 BMFJF
PS-1000 B 1 1.250 5/8 BMFJF Model BTH
PS-359 C 1 1.250 5/8 BCFJF
PS-201 A 1 1.375 3/4 BMFJF
PS-358 C 1 1.375 3/4 BCFJF
PS-750 D 1 1.375 3/4 BCDJF MF-1
PS-360 A 1 1.625 1 BCFJF Series C, CM and CH P-28175
EASTERN ENGINEERING (See PULSAFEEDER)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Size Material
Part No. Head MM Code
NOTE:
N. NON-STANDArD SprING HOLDer
EBARA FLUID HANDLING
VGM-2971V * VGM562 13 VLFLF / VCFJF
VGM-2982V * VGM562 14 VLFLF / VCFJF
VGM-2979V * VGM562 15 VLFLF / VCFJF
VGM-2974V * VGM562 16 VLFLF / VCFJF
VGM-2980V VGM562 20 VLFLF / VCFJF
VGM-2975V VGM562 25 VLFLF / VCFJF
VGM-8030V VGM562 30 VLFLF / VCFJF
VGM-2976V VGM562 35 VLFLF / VCFJF
VGM-2977V VGM562 40 VLFLF / VCFJF
VGM-2978V VGM562 45 VLFLF / VCFJF
VGM-2983V VGM562 50 VLFLF / VCFJF
* Supplied with cup mounted mating rings and no retaining plate
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
ECONOMY PUMP (PATTERSON PUMP CO.)
PS-100 A 1 1.187 5/8 BMFJF AMP, TEP, JFP
PS-360 A 1 1.625 1 BCFJF MMZ-85
PS-356 C 1 1.750 1-1/8 BCFJF C5
PS-1067 E 1 1.875 1-1/8 BCFKF GCZ-2012
PS-185 C 1 1.875 1-1/4 BCFJF HRS-73
PS-177 C 1 2.000 1-3/8 BCFJF SAD-1959
PS-305 E 1 2.125 1-1/2 BCFJF BDAC 05291950
PS-395 E 3 2.125 1-1/2 BCFJF
EDWARDS ENGINEERING
PS-3578V C 1 1.175 7/16 VCFJF C-316
PS-867V E 3 1.750 1-1/8 VCFKF 220000
ELECTROMOTIVE DIV.
PS-632 C 1 1.000 1/2 BCFKF N 822832
PS-602 D 1 1.562 7/8 BCDJF 5876888
ELGIN SWEEPER CO. - (Street Sweepers)
PS-5625 Special 1 1.250 5/8 QC-J-
Type VGM562 with Plate
PS-5625
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
S. SLOTTeD MATING rING
ELKINGTON DISHWASHER
PS-3440 C 1 1.750 1 BCFJF
ENPO-CORNELL PUMP CO.
PS-961 B 1 1.250 5/8 BCFJF
PS-452 B 9 — 5/8 BMFJF A
PS-201 A 1 1.375 3/4 BMFJF
PS-360 A 1 1.625 1 BCFJF
PS-466 C 1 2.000 1-1/4 BCFJF M-3957-F
PS-466V C 1 2.000 1-1/4 VCFJF M-3957-G
PS-546 E 3 1.875 1-1/4 BCFJF
PS-467 C 1 2.125 1-3/8 BCFKF M-3983-C
PS-1683 E 3 2.375 1-5/8 BCFJF
PS-2212 C 1 2.500 1-3/4 BCFJF M-3842-F
PS-1068 C 1 2.500 1-3/4 BCFKF M-3842-C
PS-449 K 1 2.500 1-3/4 BCFJF
PS-2139 C 1 2.750 2 BCFJF M 4414-F
PS-842 C 1 2.750 2 BCFKF
PS-1040 K 3 2.750 2 BCFKF
PS-1041 K 3 3.250 2-3/8 BCFKF
PS-1613 K 3 3.375 2-1/2 BCFJF
ENVIRONMENT ONE CORP.
PS-2033 D 3 1.625 1 BCFJF A-2021B110
PS-3042 G 3 1.625 1 BCFJF S NB0053PO1
ESSICK
PS-358 C 1 1.375 3/4 BCFJF 9014009
PS-175 K 1 1.375 3/4 BCFJF 9014225
1.500
PS-185 C 1 1.875 1-1/4 BCFJF 9014025
PS-177 C 1 2.000 1-3/8 BCFJF 9014027
PS-495 K 1 2.000 1-3/8 BCFJF 9014140
EUROPLAST LTD.
PS-201 A 1 1.375 3/4 BMFJF 60985AA
EVERITE
PS-150 B — — 1/2 BMF-F Seat Is Impeller 1205
PS-200 A 1 1.250 5/8 BMFJF 2544
PS-501 A 1 1.250 5/8 BMFJF
PS-359 C 1 1.250 5/8 BCFJF 2584
FAIRBANKS MORSE (See PENTAIR, INC. for Additional Part Numbers)
PS-506 A 1 1.000 1/2 BMFKF Models 49 and 59 Circulating Pumps 91325
PS-200 A 1 1.250 5/8 BMFJF Models H, HC, HV 82723, 82470-75
PS-501 A 1 1.250 5/8 BMFJF H500, 649, 650 Shallow Well and 82635-60, 82702-75
All Model 49 Ejectors to 1 HP.
Models 300, 500 and 750 VS-VD
PS-507 A 1 1.250 5/8 BMFKF For UL 25 Westco Shallow Well 82480-60
PS-359 C 1 1.250 5/8 BCFJF Submersible Motor
PS-508 D 1 1.250 5/8 BCDJF Model 49 82480-75
PS-102 D 1 1.250 5/8 BCDKF 82698
PS-201 A 1 1.375 3/4 BMFJF Models AC, AEC, AES, AS
PS-877 C 1 1.375 3/4 BCFJF Model 5553B-Build Together Pump HYDE2, 82738-60
PS-750 D 1 1.375 3/4 BCDJF 40088878
PS-188 E 1 1.500 7/8 BCFJF 1-1/4 Fig. 5553E, Mtr Frm. up to 184 HYD1Q1
PS-229 E 3 1.500 7/8 BCFKF Westco BR545
/
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
C. COMpLeTe WITH COLLAr
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
FAIRBANKS MORSE (See PENTAIR, INC. for Additional Part Numbers) (continued)
PS-235 C 1 1.625 1 BCFJF CND-1726D-1726C
LV411900X01
PS-356 C 1 1.750 1-1/8 BCFJF 1-1/2,2,3,4 Fig.5553N, Frm. 213 & Up HYD1AC
PS-204 E 1 1.750 1-1/8 BCFJF 1-1/4 Fig. 5553E, Mtr. Frm. 213 & Up HYD1Q2
PS-6812 C 1 1.875 1-3/16 BCFJF LV7140047753
PS-8074 XB 3 1.687 1-3/16 Special C HYD1BT3
PS-185 C 1 1.875 1-1/4 BCFJF HYD1AC2
PS-756 C 1 1.875 1-1/4 BCFKF HYD1BX8
PS-381 D 1 1.875 1-1/4 BCFJF Westco 2G
PS-510 D 1 2.000 1-1/4 BCFJF Models 5554, 5554A HYD1E2
PS-883 K 1 1.875 1-1/4 BCFJF HYD1AD2
PS-865 E 3 2.000 1-3/8 BCFKF HYD1Q3
PS-3198 V 3 2.140 1-3/8 BCFJF HYD1S3
PS-1104 V 25 2.140 1-3/8 BCFJF Frame 25
PS-8079 XB5 3 1.937 1-7/16 Special HYD1BT6
PS-758 C 1 2.125 1-1/2 BCFJF
PS-305 E 1 2.125 1-1/2 BCFJF ND2502-A1
PS-395 E 3 2.125 1-1/2 BCFJF 3” & 4” Fig. 5821, 2” & 3” Fig. 5822, HYD1AA1, HYD1X3
2” & 2-1/2” Fig. 5823, 3” Fig. 5874A
PS-395-EPR E 3 2.125 1-1/2 QCFJF FMB088775CO1
PS-515 E 3 2.250 1-1/2 BCFJF 2” Fig. 5812, 3”, 4” Fig. 5811 HYD1A2
PS-514 D 1 2.375 1-5/8 BCDJF ND1246-A4
PS-1683 E 3 2.375 1-5/8 BCFJF HYD1BG1
PS-446 C 1 2.500 1-3/4 BCFJF HYD1AC3, HYD1AD1
PS-550 C 3 2.500 1-3/4 BCFJF HYD1CB2
PS-6241 C 3 2.500 1-3/4 BLFLF HYD1EH2
PS-3963 C 3 2.500 1-3/4 BLFZF HYD1CM2
PS-3719 C 3 2.500 1-3/4 B/VLFZF HYD1DJ2
PS-3687 C 3 2.500 1-3/4 BZFZF HYD1CD2
PS-3718V C 3 2.500 1-3/4 VCFJF HYD1CR2
PS-449 K 1 2.500 1-3/4 BCFJF Models 5421 BP, KTPA-10031 HYD1AD1
PS-6246 K 1 2.500 1-3/4 BCFJF HYD1AD7
PS-6242 T 3 2.500 1-3/4 VCFJF 316SS HYD1EN2
PS-1070 U 3 2.375 1-3/4 BCFJF 5” Fig. 5821, 6” Fig. 5821, 4” Fig. 5822, HYD1AA3
3” Fig. 5823, 4” Fig. 5874A, 3” Fig. 5876A,
2” Fig. 5972A, 2-1/2” Fig. 5972A
PS-519 U 3 2.500 1-3/4 BCFJF Fig. 5822A, Size 4 HYD1T2
PS-2069 E 1 2.625 1-7/8 BCFJF HYD1E4
PS-2070 E 1 2.625 1-7/8 BCFKF HYD1Q4
PS-3964 T 3 2.625 1-7/8 BCFJF HYD1CW1
PS-898 U 3 2.500 1-7/8 BCFJF 8” Fig. 5821, 5” & 6” Fig. 5822, HYD1AA4
4” & 5” Fig. 5823, 5” Fig. 5874A
PS-4467 V 3 2.625 1-7/8 BCFJF HYD1S16
PS-1105 V 25 2.640 1-7/8 BMFJF Frame 28
PS-8077
X Special
3 2.500 1-7/8 VCFJF 316SS HYD1BT10-9906F
PS-7781 C 1 2.750 2 BCFJF HYD1CB1
PS-7781-SC-TC C 1 2.750 2 BLFZF HYD1CK2, HYD1CN2
PS-4015 C 3 2.750 2 BCFKF HYD1CE2
PS-332 C 3 2.750 2 BCFKF Collar supplied upon request HYD1BX1
PS-6238 C 3 2.750 2 BLFLF HYD1EH1
PS-3721 C 3 2.750 2 BLFZF HYD1CM1, HYD1DJ1
PS-3688 C 3 2.750 2 BZFZF N/S HYD1D1CD1
PS-6247V C 3 2.750 2 VCFKF HYD1CS2
PS-4178 C 3 2.750 2 VLFLF HYD151
PS-530 E 3 2.750 2 BCFJF HYD1BG2
PS-2143 K 1 2.750 2 BCFJF
PS-4478 K 1 2.750 2 BCFJF HYD1AD8
PS-338 C 3 3.000 2-1/8 BCFJF S Frame 30 Model 5500 HYD1AC4
PS-327 E 3 3.000 2-1/8 BCFJF HYD1Q5
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
I. AbrASION reSISTANT CArbON (p66)
FAIRBANKS MORSE (See PENTAIR, INC. for Additional Part Numbers) (continued)
PS-887 K 1 3.000 2-1/8 BCFJF HYD1AD3
PS-1102 V 3 3.140 2-1/8 BCFJF Frame 32 HYD1S5
PS-7782 C 1 3.125 2-1/4 BCFKF HYD1CE1
PS-1676 C 3 3.125 2-1/4 BCFKF Collar supplied upon request HYD1BX10
PS-3966 C 3 3.125 2-1/4 BLFZF HYD1CN1
PS-6248 C 3 3.125 2-1/4 VCFKF HYD1CS1
PS-7431 K 1 3.125 2-1/4 BCFJF HYD1AD9
PS-269 C 3 3.375 2-1/2 BCFJF HYD1AD4
FMB027764A01
PS-853 C 3 3.375 2-1/2 BCFKF Collar supplied upon request HYD1BX3
PS-6254 E 3 3.500 2-1/2 BCFJF HYD1CX2
PS-279 E 3 3.375 2-1/2 BCFJF Collar supplied upon request HYD1AA6, HYD1BG3
PS-1613 K 3 3.375 2-1/2 BCFJF HYD1AD10
PS-4072 T 3 3.500 2-1/2 BCFJF HYD1CW2
PS-6244 T 3 3.500 2-1/2 VCFJF HYD1EN4
PS-6243 T 3 3.500 2-1/2 VLFZF HYD1ES4, FMB1403087
PS-2147 V 3 3.500 2-1/2 BCFJF HYD1S17
PS-3994 C 3 3.500 2-3/4 BCFJF HYD1CB3
PS-6239 C 3 3.500 2-3/4 BLFLF HYD1EH3
PS-4366 C 3 3.500 2-3/4 BLFZF HYD1CM3
PS-2154-TC-SEAT C 3 3.500 2-3/4 B/VCFZF FMB060882X01
PS-3661 C 3 3.500 2-3/4 VLFZF HYD1DJ3
PS-2148 K 3 3.500 2-3/4 BCFJF HYD1AD11
PS-328 E 3 3.375 2-5/8 BCFJF HYD1AA8, HYD1Q6
PS-542 E 3 3.375 2-5/8 BCFKF
PS-329 E 3 3.750 2-7/8 BCFJF HYD1Q7
PS-2153 C 3 3.875 3 BCFJF HYD1EF3
PS-2115 C 3 3.875 3 BCFKF Collar supplied upon request HYD1BX4
PS-3600 C 3 3.875 3 BCFKF HYD1CE3
PS-2115-TC-SEAT C 3 3.875 3 BCFZF FMB060882X02
PS-6240 C 3 3.875 3 BLFLF HYD1EH4
PS-3701 C 3 3.875 3 BLFZF HYD1CM4
PS-6249-SC-TC C 3 3.875 3 BLFZF HYD1CN3
PS-6249 C 3 3.875 3 BZFZF HYD1CK3
PS-6250 C 3 3.875 3 VCFKF HYD1CS3
PS-475 E 3 3.875 3 BCDKF HYD1BE4
PS-324SS E 3 3.875 3 BCFJF HYD1BG4
PS-3969 E 3 4.000 3 BCFJF HYD1CX3
PS-7993 T 3 4.000 3 BCFJF HYD1CW3
PS-3836 U 3 3.875 3 BCFJF HYD1AA7
PS-7215 V 3 4.000 3 BCFJF 316SS HYD1S18
PS-4069 V 3 4.000 3 BCFZF FMB061419X01
PS-4127 C 3 4.125 3-1/4 BCFJF HYD1EF4
PS-6258 C 3 4.125 3-1/4 BCFKF HYD1CE4
PS-3702 C 3 4.125 3-1/4 BLFZF HYD1CN4
PS-6253 C 3 4.125 3-1/4 VCFJF HYD1CR4
PS-6252 C 3 4.125 3-1/4 VCFKF HYD1CS4
PS-330 E 3 4.125 3-1/4 BCDJF HYD1Q8
PS-6245 C 3 4.375 3-1/2 BCFKF HYD1BX6
PS-4019 E 3 4.375 3-1/2 BCFJF I HYD1BG5
PS-4881 E 3 4.375 3-1/2 BCFKF HYD1BE5
PS-3499 E 3 4.625 3-5/8 BCFJF HYD1CX4
PS-3684 T 3 4.625 3-5/8 BCFJF HYD1CW4
PS-3645 T 3 4.625 3-5/8 BLFZF
PS-6237 T 3 4.625 3-5/8 BCFZF FMB083739BO1
FMB213293X01
PS-3779 V 3 4.625 3-5/8 BCFJF HYD1S19
PS-4014 D 3 4.625 3-3/4 BLFZF HYD1DB3, HYD1DC1
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
FEDERAL PUMP
PS-501 A 1 1.250 5/8 BMFJF
PS-293 A 14 .815 5/8 BMFKF Seat is Metal to Metal Press Fit
PS-293-EPR A 14 .815 5/8 QCFKF Seat is Metal to Metal Press Fit
PS-245 C 1 1.625 1 BCFJF B/H
PS-248 C 1 1.625 1 BCFKF B/H
PS-380 D 1 1.625 1 BCFJF
PS-246 C 1 1.875 1-1/4 BCFJF B/H
PS-249 C 1 1.875 1-1/4 BCFKF B/H
PS-381 D 1 1.875 1-1/4 BCFJF
PS-547 C 3 2.000 1-3/8 BCFKF
PS-682 C 1 2.156 1-1/2 BCFJF B/H
PS-247 C 1 2.156 1-1/2 BCFKF B/H
PS-382 D 1 2.125 1-1/2 BCFJF
PS-446 C 1 2.500 1-3/4 BCFJF
PS-205 E 1 2.500 1-3/4 BCFJF
FINISH THOMPSON, INC.
PS-359-EPR-CMS C 1 1.250 5/8 QCFJF J101256
PS-3216 D 3 Special 2.000 1-3/8 VCFJF 316SS J100122
PS-3196 K 3 2.000 1-3/8 VCFJF J100124
PS-8110 XB2 3 2.000 1-3/8 VCFJF 316SS J100123
FINN CORP.
PS-185 C 1 1.875 1-1/4 BCFJF 080485
FLINT & WALLING (Div. of ZOELLER CO.)
PS-165 B 9 .906 1/2 BMFJF A 132891/92
PS-800 C 1 1.156 5/8 BMFJF H Models BPA, C, C6267,CA AC-16,131100 132377
PS-201 A 1 1.375 3/4 BMFJF 81, 82, 83, 605, 607, 609 Shallow Well, 126544, 126545
64, 65, 66, 67, 68 Deep Well
PS-687 C 1 1.500 7/8 BCFKF 121224
PS-357 C 1 1.625 1 BCFKF Series C211 129868
PS-204 E 1 1.750 1-1/8 BCFJF
PS-185 C 1 1.875 1-1/4 BCFJF Spring Supplied by Customer 136557
FLO FAB
PS-185V-SC-SC C 1 1.875 1-1/4 VLFLF
FLOWAY (Div. of WEIR SPECIALTY PUMPS)
PS-252 D 3 1.625 1 BCFKF 542949-2010
PS-264 E 3 1.875 1-1/4 BCFKF 545305-1010, 231-31-413
FLOWSERVE CORP. (See DURCO, IDP and WORTHINGTON)
PS-928 C — — 9/16 BCF-F 1 GAM 055954-00, 27337583
PS-4292 C 3 1.031 9/16 BCFKF 1 GAM
PS-3542 C 3 1.031 9/16 VCFKF 1 GAM 74744277
PS-516 A 1 1.250 5/8 BCFJF 74297284
PS-528 A 1 1.375 5/8 BMFJF 28518652
PS-637 A 3 1.250 5/8 BMFJF 60311669
PS-933 C — — 5/8 BCF-F 055955-00, 27337591
PS-3915 C 1 1.250 5/8 BCFJF H 749082-37
PS-359V-CMS C 1 1.250 5/8 VCFJF 74315409
PS-626 C 1 1.375 5/8 VCFJF PO2099-00, 28518660
PS-7635 C 3 1.062 5/8 VCFKF 2 GA 74744285
PS-951 C 3 1.375 5/8 VCFKF PO2752-00, 74262767
PS-564 C — — 3/4 BCF-F 024439-00, 27197623
PS-2236 C 3 1.375 3/4 BCFJF 60721792, 60980901
PS-3068 C 3 1.375 3/4 QLFLF SMP
PS-2235 C 3 1.375 3/4 VCFJF 60724572
PS-3074 C 3 1.375 3/4 VLFLF SMP 2000
PS-4093 E 3 1.187 3/4 QCFKF 3&4 GAM
PS-7994 E 3 1.187 3/4 VCFKF 3&4 GAM 1802AJCTYP1RO75XP171
PS-602 D 1 1.562 7/8 BCDJF 60110418
PS-936 E — — 7/8 BCF-F 024440-00, 27197631
PS-7859V E 3 1.312 7/8 VCFKF 316SS 5&6 GAM 74744301
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
C. COMpLeTe WITH COLLAr
I. AbrASION reSISTANT CArbON (p66)
FLOWSERVE CORP. (See DURCO, IDP and WORTHINGTON) (continued)
PS-845 U 3 1.562 15/16 BCFGF 27252691
PS-560V U 3 1.562 15/16 VCFKF 031446-01, 74744319
PS-252 D 3 1.625 1 BCFKF 82230962
PS-8112 XB2 3 1.625 1 BCFKF 316SS
PS-348 C — — 1-1/8 BCF-F PO2885-00, 28518934
68885854
PS-348V C — — 1-1/8 VCF-F PO2889-00, 74262874
PS-356 C 1 1.750 1-1/8 BCFJF 74908260
PS-801 C 3 1.750 1-1/8 B/VCFJF 60954526
PS-355V C 3 1.750 1-1/8 VCFKF 39633201
PS-604 D 1 1.750 1-1/8 BCFJF 60110434
PS-605 D 1 1.750 1-1/8 BCFKF CPM-10055, 60110442
FA-607 E — — 1-1/8 BCF-F 053129-00, 68885870
68885896, 74308461
FA-608V E — — 1-1/8 VCF-F 60954690
PS-607 E 1 1.687 1-1/8 BCFJF 60110327, 60110335
PS-384 E 1 1.750 1-1/8 BCFKF 60110616
PS-867 E 3 1.750 1-1/8 BCFKF 69237592
PS-4262 E 3 1.750 1-1/8 B/VCFKF 68885862
PS-204V E 3 1.750 1-1/8 VCFJF 60954682
PS-3060 E 3 1.750 1-1/8 VCFJF
316SS/C/I
78925468
PS-867V-TC-SEAT E 3 1.750 1-1/8 VCFZF 60954716
PS-1636 E 3 1.812 1-1/8 B/VCFJF 60514098
PS-1637 E 3 1.812 1-1/8 B/VCFKF 60514254
T9-1125 WT — — 1-1/8 TCF-F 316SS PO2877-00, 258188-01
60954914
PS-723 T 1 1.875 1-3/16 BCDJF 60111267
PS-618 C 3 1.875 1-1/4 BCFJF 60721800, 60980918
60980919
PS-618-EPR-P66 C 3 1.875 1-1/4 QCFJF I 74737990
PS-2203 C 3 1.875 1-1/4 QCFKF I 68867910
PS-7436 C 3 1.875 1-1/4 QCFZF I 60671328
PS-185V C 3 1.875 1-1/4 VCFJF 68867902
PS-756V C 3 1.875 1-1/4 VCFKF 74898800
PS-618V-TC-SEAT C 3 1.875 1-1/4 VCFZF 60727401
PS-7972 G 1 1.875 1-1/4 BLFLF Model 4MSX7 81955064 - Lower Seal
See PS-7971 for Upper Seal
PS-394 U 3 1.875 1-1/4 BCF/DKF 031448-00
PS-394V U 3 1.875 1-1/4 VCF/DKF 78978772
PS-172 C — — 1-3/8 BCF-F PO2886-00, 28518868
FA-10165 C — — 1-3/8 QCF-F I 74332321, 80631400
PS-172V C — — 1-3/8 VCF-F PO2890-00, 28518884
PS-4163 E — — 1-3/8 QCF-F
316SS/C/I
74712241
PS-2104V E — — 1-3/8 VCF-F 74816034
PS-4087 E — — 1-3/8 VCF-F 316SS/C PO2874-00
PS-3925 E 3 2.125 1-3/8 VCFJF 74816117
PS-7971 G 1 2.000 1-3/8 BCFJF See PS-7972 for Lower Seal 81955072 - Upper Seal
PS-3014 G 1 2.000 1-3/8 BLFZF 316SS 81981193
PS-725 T 1 2.000 1-3/8 BCFJF 60111275
PS-561SS U 1 2.000 1-3/8 BCFKF 050498-00, 026457-00
27215094
PS-8111 XB2 3 2.125 1-7/16 BCFKF 316SS 81918523
PS-2106 E — — 1-1/2 BCF-F 05484500, 27335819
68886167, 68886175
69170181
PS-2106V E — — 1-1/2 VCF-F 60506169, 60549581
74332164, 80612400
PS-258 E 3 2.125 1-1/2 BCFKF 68886100, 68886118
PS-305V E 3 2.125 1-1/2 VCFJF 68886068
PS-4034 E 3 2.312 1-1/2 BCFZF 60514148
PS-1648 E 3 2.312 1-1/2 B/VCFKF 60514130, 60514288
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NOTE:
C. COMpLeTe WITH COLLAr
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
FLOWSERVE CORP. (See DURCO, IDP and WORTHINGTON) (continued)
PS-1651 E 3 2.312 1-1/2 VCFJF H/HC 60514122
PS-1652 E 3 2.312 1-1/2 VCFKF 60514726
PS-239-EPR C 3 2.375 1-5/8 QCFKF 60727328
PS-609 E 1 2.312 1-5/8 BCDJF 60110343
PS-610 E 1 2.312 1-5/8 BCFKF 60110350
PS-2108 C — — 1-3/4 BCF-F 28518876
FA-10159 C — — 1-3/4 BRF-F 74334681, 80996900
FA-10045 C — — 1-3/4 VCF-F PO2891-00, 74262882
PS-2109 E — — 1-3/4 BCF-F PO2871-00, 28518785
PS-7950 E 3 2.312 1-3/4 QCFZF I 74840992
PS-366V E 3 2.500 1-3/4 VCFKF 74780065
PS-3016 G 1 2.500 1-3/4 BLFLF 81974883
PS-4216 G 1 2.500 1-3/4 BLFZF 81974917
PS-3884 U 1 2.500 1-3/4 VCFZF
FA-9400 WT — — 1-3/4 TCF-F 28518843, PO2883-00
FA-513V E — — 1-7/8 VCF-F 60954765
FA-4193 E — — 1-7/8 VCF-F 316SS AY38032C-HF50
PS-2072 E 3 2.625 1-7/8 BCFKF 60433083, 60434321
68885987
PS-7951 E 3 2.625 1-7/8 QCFZF 316SS/I 60433125
PS-1659 E 3 2.625 1-7/8 VCFJF 60954757
PS-1660 E 3 2.625 1-7/8 VCFKF 60954807
PS-4193 E 3 2.625 1-7/8 VCFZF 316SS
PS-3648 EB Special 2.687 1-7/8 VCFZF 60502697
PS-3017 G 1 2.625 1-7/8 BCFJF 81974875
PS-3018 G 1 2.625 1-7/8 BLFLF 316SS 81974909
PS-9709 WT 3 2.625 1-7/8 T/VCFJF 316SS .
PS-530 E 3 2.750 2 BCFJF 60110780
PS-477 E 3 2.750 2 BCFKF 60110756, 69261352
PS-477V E 3 2.750 2 VCFKF 78945368
PS-8053 XB1T 3 2.500 2 VCFZF
316SS/I/S
A Line
PS-456-EPR U 3 2.750 2 QCFKF 75329441
PS-3591 U 3 2.750 2 QCFZF I 75329490
PS-456V U 3 2.750 2 VCFKF 75329540
PS-8119 XBT 3 2.500 2 VCFJF 316SS
FA-2120 C — — 2-1/8 BCF-F PO2888-00
PS-1612 E 3 2.812 2-1/8 BCFKF 60110376
PS-4146 EB 5 2.625 2-1/8 BCFZF 100 Series S Line
FA-350V E — — 2-3/8 VCF-F 60969805
PS-278V E 3 3.250 2-3/8 VCFJF 60969797
PS-4492 E 3 3.250 2-3/8 VLFLF 10X8X13HOC
PS-3936V-TC-SEAT EB 3 3.125 2-3/8 VCFZF
PS-3073 G 1 3.125 2-3/8 BCFLF 316SS 88380754
PS-3008 G 1 3.250 2-3/8 BCFJF 81974891
PS-3022 G 1 3.250 2-3/8 BLFZF 81974941
PS-8113 XBT 3 3.250 2-3/8 VCFJF 316SS 8X10X13HOC
PS-2205-EPR E 3 3.375 2-1/2 QCFKF I 60647260
PS-279V E 3 3.375 2-1/2 VCFJF 8X6X13 HOC-3 74816125
1802AJCTYP1A250-XF1C1
PS-349V E 3 3.375 2-1/2 VCFKF 75514554
PS-4392 E 3 3.625 2-5/8 QCFLF C
PS-8102 XB 3 3.375 2-3/4 VCFZF 316SS
PS-475 E 3 3.875 3 BCDKF 60434883
PS-5252 E 3 3.875 3 BCFKF 74841065
PS-325SS U 3 4.125 3-1/4 BCFKF 69261378
PS-3157 U 3 4.125 3-1/4 BZFZF C 69981555
PS-4475 U 3 4.125 3-1/4 QCFJF 316SS/C
PS-4483 U 3 4.125 3-1/4 VCFZF 753860-78
PS-7986 U 3 4.625 3-3/4 BCDKF 60311578
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Flygt Upper Seal Seal Size Materials of Lower Seal Seal Size Materials of Buna O-Ring Kit
Model No. Part No. MM Construction Part No. MM Construction Part No.
FLYGT
2066 VGF-02020 20 Ca/TC/B VGF-03020 20 TC/TC/V VGF-2066-OKIT
2102.040 VGF-09022 22 TC/TC/B VGF-10022 22 TC/TC/V VGF-2102-OKIT
2102.041 VGF-07022 22 TC/TC/B VGF-08022 22 TC/TC/V VGF-2102-OKIT
2102.210 VGF-07022 22 TC/TC/B VGF-08022 22 TC/TC/V VGF-2102-OKIT
2125 VGF-19028 28 TC/TC/B VGF-20028 28 TC/TC/V VGF-2125-OKIT
2140 VGF-19028 28 TC/TC/B VGF-20028 28 TC/TC/V VGF-2140-OKIT
2151.010 VGF-21035 35 TC/TC/B VGF-22035 35 TC/TC/V VGF-2151-OKIT
2151.011 VGF-21035 35 TC/TC/B VGF-23035 35 TC/TC/V VGF-2151-OKIT
2151.050 VGF-21035 35 TC/TC/B VGF-23035 35 TC/TC/V VGF-2151-OKIT
2201.011LT VGF-28045 45 Ca/TC/B VGF-29045 45 TC/TC/V VGF-3152-OKIT
2250 VGF-30060 60 Ca/TC/B VGF-31060 60 TC/TC/V VGF-2250-OKIT
2400 VGF-34060 60 TC/TC/B VGF-35060 60 TC/TC/V VGF-2400-OKIT
3066 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3066-OKIT
3067.090 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3067-OKIT
3067.170 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3067-OKIT
3067.180 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3067-OKIT
3067.250 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3067-OKIT
3067.590 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3067-OKIT
3067.690 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3067-OKIT
3067.890 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3067-OKIT
3082 VGF-09022 22 TC/TC/B VGF-10022 22 TC/TC/V VGF-3082-OKIT
3085.091 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.092 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.120 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.170 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.171 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.172 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.180 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.181 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.182 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.280 VGF-04020 20 Ce/Ca/B VGF-06020 20 TC/TC/V VGF-3085-OKIT
3085.290 VGF-04020 20 Ce/Ca/B VGF-06020 20 TC/TC/V VGF-3085-OKIT
3085.890 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3085.891 VGF-04020 20 Ce/Ca/B VGF-05020 20 TC/TC/V VGF-3085-OKIT
3101 VGF-17028 28 TC/TC/B VGF-18028 28 TC/TC/V VGF-3101-OKIT
3102 VGF-14025 25 Ce/TC/B VGF-15025 25 TC/TC/V VGF-3102-OKIT
3126.090 VGF-21035 35 TC/TC/B VGF-22035 35 TC/TC/V VGF-3126-OKIT
3126.091 VGF-21035 35 TC/TC/B VGF-25035 35 TC/TC/V VGF-3126-OKIT
3126.180 VGF-21035 35 TC/TC/B VGF-22035 35 TC/TC/V VGF-3126-OKIT
3126.181 VGF-24035 35 Ca/TC/B VGF-25035 35 TC/TC/V VGF-3126-OKIT
3126.280 VGF-21035 35 TC/TC/B VGF-25035 35 TC/TC/V VGF-3126-OKIT
3126.290 VGF-21035 35 TC/TC/B VGF-25035 35 TC/TC/V VGF-3126-OKIT
3127 VGF-24035 35 Ca/TC/B VGF-25035 35 TC/TC/V VGF-3127-OKIT
3140 VGF-28045 45 Ca/TC/B VGF-29045 45 TC/TC/V VGF-3140-OKIT
3152 VGF-28045 45 Ca/TC/B VGF-29045 45 TC/TC/V VGF-3152-OKIT
3170 VGF-32060 60 Ca/TC/B VGF-33060 60 TC/TC/V VGF-3201-OKIT
3201 VGF-32060 60 Ca/TC/B VGF-33060 60 TC/TC/V VGF-3201-OKIT
3300.091 VGF-36090 90 TC/TC/B VGF-37080 80 TC/TC/V VGF-3300-OKIT
3300.181 VGF-36090 90 TC/TC/B VGF-37080 80 TC/TC/V VGF-3300-OKIT
3300.280 VGF-36090 90 TC/TC/B VGF-37080 80 TC/TC/V VGF-3300-OKIT
3300.980 VGF-36090 90 TC/TC/B VGF-37080 80 TC/TC/V VGF-3300-OKIT
3530 VGF-36090 90 TC/TC/B VGF-39120 120 TC/TC/V Call
Materials of Construction Explanation
Ca/TC/B Carbon vs Tungsten Carbide with Buna Elastomers
Ce/Ca/B Ceramic vs Carbon with Buna Elastomers
TC/TC/B Tungsten Carbide vs Tungsten Carbide
with Buna Elastomers
TC/TC/V Tungsten Carbide vs Tungsten Carbide
with Viton® Elastomers
• Please call for models not shown.
• Also available upon request
Machined metal version of seals
Viton® O-Ring kits.
VGF-14025 VGF-15025 VGF-24035
VGF-25035 VGF-28045 VGF-29045
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Flygt Value Guard Seal Size Materials of Buna O-Ring
Model No. Part No. MM Construction Part No.
FLYGT PLUG-IN™
2610 VG-20000 20 TC/TC/V // TC/Ce/V VGF-2610-OKIT
2620 VG-20000 20 TC/TC/V // TC/Ce/V VGF-2620-OKIT
2630 VG-20000 20 TC/TC/V // TC/Ce/V VGF-2630-OKIT
2640 VG-20000 20 TC/TC/V // TC/Ce/V VGF-2640-OKIT
2660 VG-20001 25 SIC/SIC/V // TC/Ce/V Call
2670 VG-20002 35 TC/TC/V // TC/TC/V VGF-2670-OKIT
3153 VG-20002 35 TC/TC/V // TC/TC/V VGF-3153-OKIT
3171 VG-20003 45 TC/TC/V // TC/TC/V VGF-3171-OKIT
3202 VG-20004 60 TC/TC/V // TC/TC/V VGF-3202-OKIT
3301 VG-20005 80 TC/TC/V // TC/TC/V VGF-3301-OKIT
4610 VG-20000 20 TC/TC/V // TC/Ce/V VGF-4610-OKIT
4620 VG-20000 20 TC/TC/V // TC/Ce/V VGF-4610-OKIT
4630 VG-20001 25 SIC/SIC/V // TC/Ce/V VGF-4630-OKIT
4640 VG-20001 25 SIC/SIC/V // TC/Ce/V VGF-4630-OKIT
4650 VG-20003 45 TC/TC/V // TC/TC/V VGF-4650-OKIT
4660 VG-20003 45 TC/TC/V // TC/TC/V VGF-4650-OKIT
4670 VG-20004 60 TC/TC/V // TC/TC/V VGF-4670-OKIT
4680 VG-20004 60 TC/TC/V // TC/TC/V VGF-4670-OKIT
5100.210 VG-20002 35 TC/TC/V // TC/TC/V VGF-5100-OKIT
5100.211 VG-20002 35 TC/TC/V // TC/TC/V VGF-5100-211-OKIT
5100.220 VG-20002 35 TC/TC/V // TC/TC/V VGF-5100-OKIT
5100.221 VG-20002 35 TC/TC/V // TC/TC/V VGF-5100-211-OKIT
5100.250 VG-20003 45 TC/TC/V // TC/TC/V VGF-5100-250-OKIT
5100.251 VG-20003 45 TC/TC/V // TC/TC/V VGF-5100-250-OKIT
5100.260 VG-20003 45 TC/TC/V // TC/TC/V VGF-5100-250-OKIT
5100.261 VG-20003 45 TC/TC/V // TC/TC/V VGF-5100-250-OKIT
5100.300 VG-20004 60 TC/TC/V // TC/TC/V VGF-5100-300-OKIT
5100.310 VG-20004 60 TC/TC/V // TC/TC/V VGF-5100-300-OKIT
5150.300 VG-20004 60 TC/TC/V // TC/TC/V VGF-5150-300-OKIT
5150.310 VG-20004 60 TC/TC/V // TC/Ce/V VGF-5150-300-OKIT
5150.350 VG-20005 80 TC/TC/V // TC/TC/V VGF-5150-350-OKIT
5150.360 VG-20005 80 TC/TC/V // TC/TC/V VGF-5150-350-OKIT
Features
• Compact design
• Double cartridge seal
• Faces are protected during installation
• Factory assembled as a unit
• Fool proof mounting
• Springs are isolated from the pump media
Please call for models not shown.
Materials of Construction Explanation
SIC/SIC/V // TC/Ce/V Silicon Carbide / Silicon Carbide / Viton® vs Tungsten Carbide / Ceramic / Viton®
TC/TC/V // TC/Ce/V Tungsten Carbide / Tungsten Carbide / Viton® vs Tungsten Carbide / Ceramic / Viton®
TC/TC/V // TC/TC/V Tungsten Carbide / Tungsten Carbide / Viton® vs Tungsten Carbide / Tungsten Carbide / Viton®
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
FOOTE BROTHERS
PS-383 D 1 1.875 1-1/4 BCFKF
PS-186 D 1 2.000 1-3/8 BCDKF
PS-371 D 1 2.125 1-1/2 BCFKF
PS-462 D 1 2.750 2 BCDKF
FRANKLIN ELECTRIC CO., INC. (LITTLE GIANT PUMP CO., MONARCH PUMPS)
PS-200 A 1 1.250 5/8 BMFJF 106196105
PS-200V-CMS A 1 1.250 5/8 VCFJF 240316
PS-1021 B 8 — 5/8 BMFJF A 292456101
PS-452 B 9 — 5/8 BMFJF A
PS-3960 G 1 1.250 5/8 BCFJF 240104
PS-877 C 1 1.375 3/4 BCFJF 106196102
PS-360 A 1 1.625 1 BCFJF 240180
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 240362
PS-360V-CMS A 1 1.625 1 VCFJF 240369
PS-2122 C 1 1.875 1-1/4 BCFJF 106196101
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 240359
FRANKLIN PUMP SYSTEMS (Div. of JACUZZI)
PS-200 A 1 1.250 5/8 BMFJF 10000206
PS-201 A 1 1.375 3/4 BMFJF 10150209, 100002060001
PS-546 E 3 1.875 1-1/4 BCFJF 10153104
PS-877 C 1 1.375 3/4 BCFJF 10120301, 10123010001
PS-235 C 1 1.625 1 BCFJF 10129906
PS-2122 C 1 1.875 1-1/4 BCFJF 106196101
PS-2142 C 1 2.500 1-3/4 BCFJF 10037000
FREDERICK PUMP & ENGINE
PS-952 A 1 1.250 5/8 BCFJF
PS-360 A 1 1.625 1 BCFJF
PS-185 C 1 1.875 1-1/4 BCFJF
PS-756V C 3 1.875 1-1/4 VCFKF 80912
PS-1042 U 1 2.500 1-3/4 BCFJF
FRICK CO.
PS-492-CMS C 1 3.250 2-3/8 BCFKF 80BA2-47
PS-4028 K 3 Special 4.500 2-7/8 NCFGF Model MRI-90
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
FRISTAM PUMPS® - Replacement Seals for Food, Dairy & Beverage Processing
FP, FPX Size 633
VGFS-4001 Single 22MM VLFCF 1802600004
VGFS-4000 Single 22MM VWFCF 1802600002
VGFS-4002 Double 22MM
VW/JFCF
1802600000
VGFS-4003 Double 22MM VL/JFCF 1802600003
VGFS-4004 Double 22MM VLFCF 1802600295
Split - 2 Piece Mating Ring
VGFS-4005 Single 22MM VLFLF 1802600005
VGFS-4006 Single 22MM VWFLF 1802600135
VGFS-4007 Double 22MM
VL/JFL/CF
1802600006
VGFS-4008 Double 22MM
VW/JFL/CF
1802600140
FP, FPX Size 735
VGFS-4011 Single 30MM VLFCF 1802600296
VGFS-4010 Single 30MM VWFCF 1802600127
VGFS-4012 Double 30MM
VW/JFCF
1802600128
VGFS-4013 Double 30MM VL/JFCF 1802600288
VGFS-4014 Double 30MM VLFCF 1802600312
Tapered Mating Ring ID
VGFS-4015 Single 30MM VWFCF 1802600310
VGFS-4000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Material
Part No. Head Size Code Notes Mfg. Part No.
FYBROC (Div. of MET-PRO CORP.)
VG-81375 VGXB2 1-3/8 X/TCFJF 316SS 08976C010
VG-81376 VGXB2 1-3/8 X/TCFLF 316SS 08976C100
VG-82125 VGXB2 2-1/8 X/TCFJF 316SS 08975C010
VG-82126 VGXB2 2-1/8 X/TCFLF 316SS 08975C070
VG-82875 VGXB2 2-7/8 X/TCFJF 316SS 08974C010
VG-82876 VGXB2 2-7/8 X/TCFLF 316SS —
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
FRISTAM PUMPS® - Replacement Seals for Food, Dairy & Beverage Processing (continued)
FP, FPX Size 735 - Split - 2 Piece Mating Ring
VGFS-4016 Single 30MM VLFLF 1802600129
VGFS-4017 Single 30MM VWFLF 1802600143
VGFS-4018 Double 30MM
VL/JFL/CF
1802600130
VGFS-4019 Double 30MM
VW/JFL/CF
1802600142
FP, FPX Size 736
VGFS-4021 Single 35MM VLFCF 1802600337
VGFS-4020 Single 35MM VWFCF 1802600009
VGFS-4022 Double 35MM VW/JFCF 1802600131
VGFS-4023 Double 35MM VLFCF 1802600301
VGFS-4024 Double 35MM VL/JFCF 1802600328
Split - 2 Piece Mating Ring
VGFS-4025 Single 35MM VLFLF 1802600132
VGFS-4026 Single 35MM VWFLF 1802600141
VGFS-4027 Double 35MM
VL/JFL/CF
1802600139
VGFS-4028 Double 35MM
VW/JFL/CF
1802600393
FPR
VGFS-4030 Single 30MM VLFLF 1802600639
VGFS-4031 Single 30MM VWFCF 1802600651
VGFS-4032 Single 30MM VWFLF 1802600678
VGFS-4034 Double 30MM QL/JFCF 1802600845
VGFS-4033 Double 30MM VW/JFCF 1802600775
FT
VGFS-4040 Single 30MM VWFCF 1802600027
VGFS-4042 Single 30MM VWFLF 1802600340
VGFS-4041 Single 30MM VLFLF 1802600306
FZX 2000 Mixer Pump
VGFS-4052 Single 30MM VLFCF 1802600014
VGFS-4051 Single 30MM VLFLF 1802600012
VGFS-4050 Single 30MM VWFCF 1802600010
VGFS-4053 Single 30MM VWFLF 1802600016
VGFS-4022
Type VGXB2
Shown with Ceramic mating ring
Type VGXB2
Shown with Silicon Carbide mating ring
• Multi-spring , outside mounted
• Full clamp flush design mating ring
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GALION
PS-157 C — — 3/4 BCF-F
PS-397 C — — 1 BCF-F
GARDNER DENVER
PS-441 B 9 — 3/4 BMFKF A 60BN-1
PS-373 C 1 1.375 3/4 BCFKF 60AY-10
PS-360 A 1 1.625 1 BCFJF 60BT-11
PS-370 A 1 1.625 1 BCFKF 60BT-1
PS-357V C 3 1.625 1 VCFKF
PS-236 E 1 1.625 1 BCFKF 60AY-2,16 &18
PS-605 D 1 1.750 1-1/8 BCFKF 60BC-10
PS-384 E 1 1.750 1-1/8 BCFKF 60AY-11 &13
PS-3173 C 3 1.875 1-1/4 VCFKF S 60DD-591
PS-383 D 1 1.875 1-1/4 BCFKF 60BC-3
PS-6036 D 2 1.875 1-1/4 VCPFP 60DD-597
PS-186 D 1 2.000 1-3/8 BCDKF 60BC-14
PS-6048 D 3 2.000 1-3/8 VCPSP 60DD-594
PS-354 E 1 2.000 1-3/8 BCFJF
PS-7367 C Special 2.718 1-7/16 VCFGF 60DD-52
PS-6055 E 28 2.718 1-7/16 VCPGP 60DD-105
PS-6056 X
27 Special
2.718 1-7/16 VCFSF 60SS-593
PS-382 D 1 2.125 1-1/2 BCFJF
PS-371 D 1 2.125 1-1/2 BCFKF
PS-374 E 1 2.125 1-1/2 BCFKF 60AY-21
PS-239V C 3 2.375 1-5/8 VCFKF 60BC-2-5
PS-6005 C 3 2.375 1-5/8 VCFKF 60DD-86
PS-6075 D 3 2.375 1-5/8 VCPSP 60DD-592
PS-312V C 3 2.625 1-7/8 VCFKF 60DD-98
PS-593 D 3 2.625 1-7/8 BCDKF 60BC-9, 12
PS-6094 D 3 2.625 1-7/8 VCPSF 60DD-599
PS-2070 E 1 2.625 1-7/8 BCFKF 60AY-20
PS-3955 C
27 Special
3.125 2-1/4 VCFGF 60DD-53
PS-1676V C 3 3.125 2-1/4 VCFKF 60DD-104
PS-5358 D 3 3.125 2-1/4 Special 60DD-595
PS-351 E 1 3.125 2-1/4 BCDKF 60AY-15
PS-463 D 3 3.375 2-1/2 BCDKF 60BC-8
PS-6154 C 27 4.406 2-3/4 VCFGF 60DD-54
PS-6174 E 3 3.875 3 VCDGP 00519056 0030
GARDNER DENVER LEROI
PS-687V C 3 1.500 7/8 VCFKF 125-907
PS-460V D 3 1.625 1 VCFKF S 125.988
PS-598 C 3 1.875 1-1/4 BCFKF H125.775
PS-4431 D 3 1.875 1-1/4 VLFLF 125.9831
PS-210V C 3 2.000 1-3/8 VCFKF Model A204-1455 125-940
PS-467 C 1 2.125 1-3/8 BCFKF
PS-467V C 3 2.125 1-3/8 VCFKF 125-188-2
PS-371V-SC-SC D 3 2.125 1-1/2 VLFLF 125.9821
PS-1676V C 3 3.125 2-1/4 VCFKF 125.927
PS-6002 D 3 3.375 2-5/8 VCFKF 125-848
PS-6155 C 3 3.500 2-3/4 VCFKF S 125-711
GARWOOD INDUSTRIES
PS-303 D 1 1.500 7/8 BCDKF 206556
PS-227 D 1 1.750 1 BCFKF
PS-210 C 1 2.000 1-3/8 BCFKF 2016264
PS-376 D — — 1-3/8 BCD-F 2039056
GE OSMONICS
PS-4272 C 1 1.250 5/8 BCFJF 316SS 1113515
PS-552-EPR-P66 C 3 1.250 5/8 QCFJF I 1114630
PS-3148 E 3 1.250 5/8 BCFJF 1113517
PS-235V C 3 1.625 1 VCFJF
PS-791 E 3 1.625 1 BCFKF 1114326
PS-3129 E 3 1.625 1 QCFZF 1201945
PS-2047V D 3 2.000 1-3/8 VCFJF 3011311
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
G. MOUNTS IN pLASTIC
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GEARMASTER
PS-1043 C 1 1.000 1/2 BMFJF A34-3970
GECKO ALLIANCE, INC.
PS-200 A 1 1.250 5/8 BMFJF Circ-Master®, Dominator®–High Head 92500150
Dominator®–Medium Head, Flo-Master® 92500151
Pond-Flo, Tub-Master®
PS-200V-CMS A 1 1.250 5/8 VCFJF 92500152
PS-2131 A 31 — 5/8 BMFJF G Flo-Master®, Tub-Master® 91049000
PS-642 B — — 5/8 BMF-F
PS-1021 B 8 — 5/8 BMFJF A K-81159 PU10
PS-1000 B 1 1.250 5/8 BMFJF A, B, and D-Series 92509040
A, C, and D-Series, Dominator® 92500050
High and Medium head – pre 1995
PS-201 A 1 1.375 3/4 BMFJF
PS-309 C 1 1.500 7/8 BCFJF AC Series 92500000
PS-774 C 3 1.500 7/8 BCFJF
PS-361 E 1 1.875 1-1/4 BCFJF
GECO SALES
PS-1000 B 1 1.250 5/8 BMFJF
GENERAL MOTORS CORP. (GMC)
PS-642 B — — 5/8 BMF-F 5121751
PS-933 C — — 5/8 BCF-F 5186571
PS-752 D 1 1.375 3/4 BCDKF 5186113
PS-192 C 3 2.125 1-1/2 NCFGF
GENERAL PUMP
PS-200 A 1 1.250 5/8 BMFJF
PS-810 C 1 1.250 5/8 N/BCFJF B
GEORGIA PACIFIC PUMP
PS-200 A 1 1.250 5/8 BMFJF
GG INDUSTRIES
PS-200 A 1 1.250 5/8 BMFJF P-M03885
PS-642 B — — 5/8 BMF-F P-M03857, P-M07909
PS-1000 B 1 1.250 5/8 BMFJF P-Seal 4 / P-Seal 5 Mark III
GILBARCO, INC.
PS-1000 B 1 1.250 5/8 BMFJF K81159X
PS-756 C 1 1.875 1-1/4 BCFKF K74050X
PS-514 D 1 2.375 1-5/8 BCDJF
PS-461 D 1 2.375 1-5/8 BCDKF
GLT, INC. - (Dishwashers / Disposals)
PS-6313 Q 1 1.019 1/2 BCFJF
PS-1085V C 1 1.250 5/8 VCFJF B 114696
PS-6318 Q 9 1.578 1-1/8 VMFAF 117071
GORMAN-RUPP CO.
PS-150 B — — 1/2 BMF-F Seat is Impeller S8243-4
PS-788 B 1 1.000 1/2 BMFKF
PS-106 C 1 1.000 1/2 BCFKF 25271-801
PS-106V C 1 1.000 1/2 VCFKF 25271-802
PS-218 A — — 5/8 BCF-F 12873-002
PS-200 A 1 1.250 5/8 BMFJF S756, S1531
PS-507 A 1 1.250 5/8 BMFKF
PS-882 B — — 5/8 BCF-F 8243-12
PS-118 C 1 1.187 5/8 BCFJF S809
PS-3915 C 1 1.250 5/8 BCFJF H 25271-824
PS-1080 C 1 1.250 5/8 NCFKF 25270-113
PS-3121 C 1 1.250 5/8 VCFKF I 25271-821
PS-1045 C 3 1.250 5/8 VCFJF
PS-508 D 1 1.250 5/8 BCDJF S217
PS-795 S 8 1.187 5/8 NAPSP GS-625
PS-851 A 1 1.375 3/4 BCFJF S1190
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GORMAN-RUPP CO. (continued)
PS-601 B 1 1.375 3/4 BMFJF Model 83E-F13 26822-008
PS-564 C — — 3/4 BCF-F S32
PS-358 C 1 1.375 3/4 BCFJF S936, S1575
PS-112 C 1 1.375 3/4 BCFKF S1679
PS-358V-CMS C 1 1.375 3/4 VCFJF 25271-850
PS-373V C 1 1.375 3/4 VCFKF 25271-021
PS-5728 C 3 1.375 3/4 VLFLF 25284-921
PS-750 D 1 1.375 3/4 BCDJF Model 82T-A8 S383
PS-752 D 1 1.375 3/4 BCDKF Model 82T-A8
PS-792 S 8 1.500 3/4 NAPSP GS-750
PS-617 C 3 1.500 7/8 BCFKF 25271-159, 25271-855
PS-2027V D 3 1.500 7/8 VCFKF
PS-360 A 1 1.625 1 BCFJF S2147
PS-397 C — — 1 BCF-F S237
PS-235 C 1 1.625 1 BCFJF S1906, S1832
PS-357 C 1 1.625 1 BCFKF
PS-499 C 3 1.625 1 BCFKF 25271-869
PS-357V C 3 1.625 1 VCFKF 25271-870
PS-380 D 1 1.625 1 BCFJF S1415
PS-460 D 1 1.625 1 BCFKF S363, S364
PS-4253 DB 3 1.500 1 VCFKF 316SS 25276-251
PS-236 E 1 1.625 1 BCFKF
PS-557 E 3 1.625 1 B/VCFJF S 25271-032
PS-791 E 3 1.625 1 BCFKF S388
PS-793 S 8 1.750 1 NAPSP Model 13A2-B GS-1000
PS-9018 W 27 2.156 1 TCFJF 316SS S1212
PS-348 C — — 1-1/8 BCF-F 92055-1112
PS-867 E 3 1.750 1-1/8 BCFKF 25271-039
PS-867V E 3 1.750 1-1/8 VCFKF 25271-037
PS-756 C 1 1.875 1-1/4 BCFKF S1621
PS-185-EPR C 1 1.875 1-1/4 QCFJF 25271-893
PS-598 C 3 1.875 1-1/4 BCFKF 25271-889
PS-185V C 3 1.875 1-1/4 VCFJF 25271-888
PS-756V C 3 1.875 1-1/4 VCFKF 25271-836, 25271-886
PS-381 D 1 1.875 1-1/4 BCFJF S321
PS-383 D 1 1.875 1-1/4 BCFKF S37, S493
PS-517 D 3 1.875 1-1/4 BCFKF S493C
PS-981 D 3 1.875 1-1/4 BCFKF S321A
PS-383V D 3 1.875 1-1/4 VCFKF 25271-192
PS-361 E 1 1.875 1-1/4 BCFJF S335
PS-137 E 1 1.875 1-1/4 BCFKF S350
PS-546 E 3 1.875 1-1/4 BCFJF 42029, 25271-044
PS-137V E 3 1.875 1-1/4 VCFKF
PS-4396 E 3 1.875 1-1/4 VCFKF 316SS 25271-043
PS-6259 G 1 1.875 1-1/4 VCFJF 316SS 25276-633
PS-794 S 8 2.125 1-1/4 NAPSP Model 14C2B GS-1250
PS-2234 E 3 2.062 1-7/16 BCFKF 25271-051
PS-2234V E 3 2.062 1-7/16 VCFKF 25271-056
PS-758 C 1 2.125 1-1/2 BCFJF S1150
PS-553 C 3 2.125 1-1/2 BCFKF 25271-907
PS-659V C 3 2.125 1-1/2 VCFKF
PS-5727 C 3 2.125 1-1/2 VRFRF 316SS 25284-961
PS-382 D 1 2.125 1-1/2 BCFJF S1934
PS-371 D 1 2.125 1-1/2 BCFKF S283, S317, S774
PS-534 D 3 2.125 1-1/2 BCFKF
PS-371V D 3 2.125 1-1/2 VCFKF 25271-207
PS-7079 D 28 2.375 1-1/2 VZFZF 12364A
PS-374 E 1 2.125 1-1/2 BCFKF S239
PS-8002 X Special 3 2.125 1-1/2 BCFJF 25271-554
PS-544 C 3 2.375 1-5/8 BCFKF 25271-922
PS-239V C 3 2.375 1-5/8 VCFKF 25271-921
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GORMAN-RUPP CO. (continued)
PS-2058 E 1 2.375 1-5/8 BCFKF 25271-061
PS-1683 E 3 2.375 1-5/8 BCFJF 25271-064
PS-446 C 1 2.500 1-3/4 BCFJF S1822
PS-2212 C 1 2.500 1-3/4 BCFJF 25271-947
PS-446V-CMS C 1 2.500 1-3/4 VCFJF 25271-942
PS-436 C 3 2.500 1-3/4 BCFKF 25271-943
PS-267 C 1 2.750 2 BCFJF 25271-971
PS-267V-CMS C 1 2.750 2 VCFJF
PS-332 C 3 2.750 2 BCFKF S1929
PS-1145 C 3 2.750 2 VCFKF 25271-983
PS-3142 D 3 2.750 2 VZFLF 316SS/S 26835-545
PS-1688 E 3 3.125 2-1/4 BCFJF 25271-095
PS-463 D 3 3.375 2-1/2 BCDKF
PS-3888 D 3 3.375 2-1/2 VZFLF 26835-541
PS-349V-TC-SC E 3 3.375 2-1/2 VZFLF 26835-544, 26835-546
PS-6219 D 3 3.875 3 BZFLF 26835-548
PS-4033 D 3 3.875 3 VZFLF 26835-542
PS-3180 C 3 4.125 3-1/4 VCFJF 25271-994
Value Guard Seal Material
Part No. Head Size Code Pump Nameplate Data Mfg. Part No.
GORMAN-RUPP CO. - S SERIES - Submersible Pump
VG-7100 VGR 1
BC/ZFK/ZF
Model S3A1 46512-044
VG-7101 VGD 1-1/2 VZFZF Models S4A1, S4B1, S6C1 12430
PS-382 D 1-1/2 BCFJF Use for Upper Seal S1934
VG-7101 VGD 1-1/2 VZFZF Models S6B1, S8A1, S8B1 12430A
PS-382 D 1-1/2 BCFJF Use for Upper Seal S1934
VG-7102 VGD 1-3/4 VZFZF Model S8C1 46512-055
PS-2212 C 1-3/4 BCFJF Use for Upper Seal 25271-947
GORMAN-RUPP CO. - T SERIES - Self Priming Pump
VG-7080 VGD 1-1/2 VLFLF Models T3, T4, T6
VG-7079 VGD 1-1/2 VZFZF Models T3, T4, T6 12364A947
VG-7094 VGDU 1-1/2 VLFLF Models T3, T4, T6 46513-151
VG-7095 VGDU 1-1/2 VZFZF Models T3, T4, T6 46513-150
VG-7082 VGD 1-7/8 VLFLF Model T8
VG-7081 VGD 1-7/8 VZFZF Model T8
VG-7084 VGD 2-3/4 VLFLF Model T10
VG-7083 VGD 2-3/4 VZFZF Model T10
Features
• Tungsten Carbide and Silicon Carbide
faces for severe abrasive service.
• Solid drive band extends seal life during
periods of vibration and cavatation.
• Full convolution elastomer bellows for
maximum self aligning capabilities.
• Pump sleeve, o-ring and impeller shim kit
supplied for ease of installation
Also Used On:
• All Prime Models S3, S4, S6, S8, S9, S10
• Wemco Models WSP3A, 4A, 6A, 8A, 10A
Type VGDU
Type VGD
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GOULDS PUMPS
PS-1002 C 1 1.000 1/2 BCFJF Fig. 3604 742070050
PS-631 C 1 1.000 1/2 BCFJF N
PS-1002V C 1 1.000 1/2 VCFJF 742080050, 742090050
PS-4240 A 1 1.187 5/8 BCFJF 10K10, 10K121
PS-518-SC-SC A 1 1.187 5/8 BLFLF 10K63
PS-702 A 1 1.187 5/8 BMFJF Balanced Flow BF-03, Series: LS, LD,
10K1, 10K6, 704705062
G, O, M, XS05,15, 20, 30, 50, Jetomatic,
725981062, 20831100
Fig. 3642, 3742, Fig 3672
PS-4462 A 1 1.187 5/8 BMFJF 10K2
PS-701 A 1 1.187 5/8 BMFKF Balanced Flow BF-03, Figs.: 3648, 725983062
3628, 3728, 3748, 3642, 3742, 3638,
3738, 3788, and 3811
PS-702-EPR A 1 1.187 5/8 QCFJF 10K110, 725988082
PS-702V A 1 1.187 5/8 VCFJF
PS-3977 A 1 1.187 5/8 VLFLF 10K105, 10K120, 3481008
725987062
PS-200V-SC-SC A 1 1.250 5/8 VLFLF
PS-600 B 1 1.187 5/8 BMFJF Fig. 3231
PS-700 B 1 1.187 5/8 BMFJF Cellar Drainer Fig. 3631 10K7
PS-1000V B 3 1.250 5/8 VCFJF 696-0442
PS-3926 B 9 1.062 5/8 VCFKF 316SS 10K127
PS-411V B 11 — 5/8 VCFJF A 15K20
PS-1155 C 1 1.187 5/8 BCFJF
PS-493 C 1 1.187 5/8 BCFKF Fig. 3377 and 3371 Multi Stage 10K3
PS-4222 C 1 1.187 5/8 QCFLF
316SS/H
920551062
PS-3201 C 1 1.187 5/8 QCFLF
316SS/H
Light Spring Load 10K18
PS-3707 C 1 1.187 5/8 QLFLF
316SS/H
10K81
PS-1155V C 1 1.187 5/8 VCFJF
PS-4031 C 1 1.187 5/8 VCFLF 10K46, 10K55
PS-3613 C 1 1.187 5/8 VLFLF
PS-4226 C 1 1.187 5/8 VLFLF
316SS/H
PS-6267 G 1 1.187 5/8 QLFLF 10K167, A00576C1
PS-1522 A — — 3/4 BMF-F 7501000
PS-750 D 1 1.375 3/4 BCDJF 10K4
PS-3996 C 1 1.500 7/8 VCFLF 10K40
PS-703 D 1 1.500 7/8 BCDJF XS15,20,50 Aqua Lawn Jetomatic, 10K8
Fig. 3629, 3649, 3729,3749, 3639,
3739, 3678 and 3789
PS-303 D 1 1.500 7/8 BCDKF 704704087
PS-397V C — — 1 VCF-F 41355000000
PS-235 C 1 1.625 1 BCFJF 10K12, 84001-2
PS-754 E 1 1.625 1 BCFJF Fig. 3169M, 3750S, 3655, 3450, 3650, 707831100
3750 & 3755
PS-236 E 1 1.625 1 BCFKF 691272100
PS-557 E 3 1.625 1 B/VCFJF S 916661000, 916701000
PS-3976 E 3 1.625 1 VCFJF 316SS Model 3655 / 3755 S
PS-8020 XB2 3 Special 1.750 1 VCFJF 316SS
PS-710 E 1 1.750 1-1/16 BCFJF Fig. 3405, 3305S 707833106
PS-356 C 1 1.750 1-1/8 BCFJF Fig. 3643 10K21
PS-355-SC-SC C 1 1.750 1-1/8 BLFLF 10K28
PS-356-SC-TC C 1 1.750 1-1/8 BLFZF 10K22
PS-588 C 3 1.750 1-1/8 BCFKF B Fig. 3643 10K9, 764071112
PS-185 C 1 1.875 1-1/4 BCFJF Fig. 3656 9152071001
PS-4463 C 1 1.875 1-1/4 BCFJF 316SS 10K13
PS-2208 C 1 1.875 1-1/4 BZFZF 9152071002
PS-4464 C 1 1.875 1-1/4 QCFKF 316SS
PS-3131 C 1 1.875 1-1/4 QCFLF
316SS/H
10K19,764070125
PS-3062 C 1 1.875 1-1/4 QLFLF 316SS 10K126, 764071125
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 10K25, A06101A02
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
C. COMpLeTe WITH COLLAr
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GOULDS PUMPS (continued)
PS-3538 C 1 1.875 1-1/4 VCFLF 316SS 10K27, 764078125
PS-4176 C 1 1.875 1-1/4 VCFZF 316SS A06101A07
PS-4101 C 1 1.875 1-1/4 VLFLF 316SS
PS-4150 C 1 1.875 1-1/4 VLFLF
316SS/H
10K64, 10K188
PS-3215 C 25 2.261 1-1/4 VLFLF B 46075200000
PS-510 D 1 2.000 1-1/4 BCFJF 51010
PS-361 E 1 1.875 1-1/4 BCFJF 2” Fig. 3460
PS-2128 E 3 1.875 1-1/4 BCFJF 3316-3405 Group S
PS-2129 E 3 1.875 1-1/4 BCFKF
PS-177 C 1 2.000 1-3/8 BCFJF
PS-7919 C 3 2.000 1-3/8 B/VLFLF 43350000000
PS-4194 D 1 2.000 1-3/8 VLFLF A05616E000
PS-354 E 1 2.000 1-3/8 BCFJF Fig. 3345, 3320
PS-677 E 1 2.000 1-3/8 BCFKF
PS-864 E 3 2.000 1-3/8 BCFJF 3196ST
PS-865 E 3 2.000 1-3/8 BCFKF 3196ST
PS-3901 E 3 2.000 1-3/8 VCFJF
316SS/C/H
A04710A01
T9-1375 WT — — 1-3/8 TCF-F 316SS 904320001
PS-705 E 3 2.062 1-7/16 BCFJF Fig. 3405M, 3305M 707833143
FA-10167 E — — 1-1/2 BCF-F I 916710001
PS-305 E 1 2.125 1-1/2 BCFJF Fig. 3169, 3650, 3655, 3750 707831150
For Group M and K, 2-1/2” Fig. 3430
PS-374 E 1 2.125 1-1/2 BCFKF
PS-395 E 3 2.125 1-1/2 BCFJF 776A9082
PS-4476 EB 3 2.125 1-1/2 VCFJF Model 3755M
PS-8109 XB2
3 Special
2.125 1-1/2 VCFJF 316SS
PS-238-EPR-SC C 1 2.375 1-5/8 QCFLF 10K20
PS-238V-CMS C 1 2.375 1-5/8 VCFJF 10K26
PS-238V-SC-CMS C 1 2.375 1-5/8 VCFLF 10K45
PS-7806 C 1 2.375 1-5/8 VLFLF 10K65, 10K189
PS-818 C 3 2.375 1-5/8 BCFJF 45162000000
46983000000
PS-238V C 3 2.375 1-5/8 VCFJF 46984000000
PS-238V-SC-SEAT C 3 2.375 1-5/8 VCFLF A05632E000
PS-544V-SC-SC C 3 2.375 1-5/8 VLFLF 10K186
PS-7497 C 25 2.500 1-5/8 B/VCFJF A05669E000R
PS-7497V C 25 2.500 1-5/8 VCFJF A05670E000
PS-1911 C 25 2.500 1-5/8 VLFLF
PS-2108 C — — 1-3/4 BCF-F 92055 1175
PS-446 C 1 2.500 1-3/4 BCFJF 10K181-See PS-267 for Upper Seal 10K157, 9152091001
10K181-Lower Seal
PS-446-SC-SC C 1 2.500 1-3/4 BLFLF 10K31
PS-446V-CMS C 1 2.500 1-3/4 VCFJF 9152091003
PS-3718 C 3 2.500 1-3/4 BCFJF 10K82
PS-3719 C 3 2.500 1-3/4 B/VLFZF 10K83
PS-4884 C 3 2.500 1-3/4 VCFJF 316SS 47134000000
PS-4487 D 1 2.500 1-3/4 VLFLF 316SS A05620E000
PS-7867 E — — 1-3/4 BCF-F
316SS/C/I
90161001
PS-1684 E 3 2.312 1-3/4 BCFJF 3316, 3405 Group M
PS-4326 E 3 2.312 1-3/4 VCFJF
316SS/C
PS-4149 E 3 2.312 1-3/4 VCFZF C 3316 & 3405 Group M
PS-535 E 3 2.500 1-3/4 BCFJF 3196MT - 3735/36M
PS-262 E 3 2.500 1-3/4 BCFKF
PS-3726 E 3 2.500 1-3/4 B/VCFJF C/I
PS-3902 E 3 2.500 1-3/4 VCFJF
316SS/C/S
3196MT A04754A01, 090161-1006
PS-1078 E 27 3.000 1-3/4 BCFJF 3316-3405M
PS-4096 EB 3 2.500 1-3/4 VCFLF
316SS/C/S
PS-3123 T 3 2.500 1-3/4
VLFLF/VCFLF
316SS
PS-3899 T 3 2.500 1-3/4
VZFZF/VCFZF
316SS/I 3196MT
PS-3754 V 3 2.750 1-3/4 BCFJF 43424000000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
C. COMpLeTe WITH COLLAr
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GOULDS PUMPS (continued)
PS-267 C 1 2.750 2 BCFJF 10K181-Upper Seal 9152101002
10K182-Lower Seal
See PS-446 for Lower Seal
PS-2219 C 1 2.750 2 BZFZF 9152101001
PS-6218 C 1 2.750 2 VZFZF 9152101004
PS-3993 C 3 2.750 2 BCFJF 10K142
PS-3721 C 3 2.750 2 BLFZF 10K85, 764079200
PS-267V-SC-SC C 3 2.750 2 VLFLF 43434000000
PS-3066 D 1 2.750 2 VLFLF A05622E000
PS-707 E 3 2.875 2-1/16 BCDKF Fig. 3305, 3306, 3405, 3406 Group L
PS-3897 E 3 2.875 2-1/8 VCFJF
316SS/C
3196LT A05166A01
PS-1679 C 1 3.125 2-1/4 BCFJF 9152111001
PS-848 E 3 3.125 2-1/4 BCDJF
PS-849 E 3 3.125 2-1/4 BCDKF
PS-3067 E 3 3.125 2-1/4 BCFZF 316SS 3405-3316 Group L
PS-3951 E 27 3.906 2-1/4 VCFKF 3405L 10x12-14
PS-3806 E 3 3.250 2-1/2 VCFJF
316SS/C
PS-4466 E 3 3.250 2-1/2 VZFLF
316SS/C
3196 XLTX
PS-3059 E 3 3.500 2-3/4 QCFLF
316SS/C
Model 3410L
PS-4089 E 3 3.500 2-3/4 VCFLF 316SS 3410 L Pump
PS-2153-CMS C 1 3.875 3 BCFJF 9152141001
PS-4481 C 3 3.875 3 VZFZF 9152141006
PS-3050 EB 3 3.875 3-1/4 BCFJF 3410 XL
PS-8104 X 3 4.625 3-3/4 VCFJF 316SS/S 10K109
PS-8055 X 3 4.750 3-7/8 VCFJF 316SS/I Model 3409 (AC9100) 52-240-979-001
PS-8060 X 3 5.375 4-3/8 VCFKF 316SS Fig. 3415 Group M
Value Guard Seal Material
Part No. Head Size Code Pump Nameplate Data Mfg. Part No.
GPM, INC. (Eliminator)
VGM-8500 VGMHD 40MM VLFLF 30154-050
VGM-1969 VGMHD 50MM VLFLF
VGM-2362 VGMHD 60MM VLFLF
VGM-2756 VGMHD 70MM VLFLF 84-40404-050/84-60406-
040/84-BCLH4-050
VGM-3250 VGMHD 3-1/4 VLFLF
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
Type VGMHD
GRAHAM ENGINEERING CORP.
PS-1688 E 3 3.125 2-1/4 BCFJF 65100021
GRAINGER (See TEEL PUMP)
GRISWOLD PUMP CO.
PS-2122 C 1 1.875 1-1/4 BCFJF 10036903
PS-758 C 1 2.125 1-1/2 BCFJF
PS-3218 E 3 2.000 1-3/8 BCFJF C/S 22049-1-1
PS-446 C 1 2.500 1-3/4 BCFJF
PS-2142 C 1 2.500 1-3/4 BCFJF 10037002
PS-448V-CMS C 1 2.500 1-3/4 VCFKF 10037002CNV
PS-7820 C 1 2.500 1-3/4 VLFLF 10037002SSV
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GRUNDFOS CBS, INC.
PS-4027 A 1 1.250 5/8 QCFJF JP5 96768182
PS-4424 A 1 1.250 5/8 VCFJF JP5
PS-1618 C 1 1.250 5/8 BCFJF B 14032695 / 91868262
PS-974 A — — 3/4 BCF-F 91867994
PS-768 C 3 1.375 3/4 BCFKF 91868257
PS-112V C 3 1.375 3/4 VCFKF 91868215
PS-154 C — — 1-1/4 BCF-F 91868171
PS-185 C 1 1.875 1-1/4 BCFJF 91868317
PS-1109V C 3 1.875 1-1/4 VCFKF 91868217
PS-1015 E — — 1-1/4 BCF-F 91868030
PS-361-P66 E 1 1.875 1-1/4 BCFJF I 91867954
PS-1183-P66 E 3 1.875 1-1/4 BCFKF I 91867962
PS-137V-P66 E 3 1.875 1-1/4 VCFKF I 91867976
PS-3974 DB 1 1.875 1-3/8 BCFJF 91867955
FA-1850 C — — 1-1/2 BCF-F 91868172
PS-2106 E — — 1-1/2 BCF-F 91868014
PS-2108 C — — 1-3/4 BCF-F 91868173
FA-10045 C — — 1-3/4 VCF-F 91868252
PS-2142 C 1 2.500 1-3/4 BCFJF 91868269
PS-2151 C 3 2.500 1-3/4 BCFKF 91868260
PS-2151V C 3 2.500 1-3/4 VCFKF 91868219
PS-2151V-TC-SEAT
C 3 2.500 1-3/4 VCFZF 91868230
PS-2109 E — — 1-3/4 BCF-F 91868003, 91868293
PS-205 E 1 2.500 1-3/4 BCFJF 91867956
PS-205V-CMS-P66 E 1 2.500 1-3/4 VCFJF I 96702875
PS-262 E 3 2.500 1-3/4 BCFKF 91867963
PS-449 K 1 2.500 1-3/4 BCFJF 91868291
PS-674 T 1 2.500 1-3/4 BCFJF 91868024
PS-477-P66 E 3 2.750 2 BCFKF I 91868207
FA-2000 C — — 2 BCF-F 91868174
PS-3537 C 1 3.125 2-1/4 BCFJF 91868272
PS-3041 C 3 3.125 2-1/4 BCFKF 91868261
FA-10144 EB — — 3-1/4 BCF-F 91868313
Value Guard Seal Size Material
Part No. Head MM Code Pump Nameplate Data Mfg. Part No.
* Allows for easy installation where the impeller spline shaft can not be removed.
GRUNDFOS CBS, INC.
BELLOWS COMPONENT SEALS
VGMG-1300 VGM706B 12 QLFLF Models CR2, CRN2(S), CR4, CRN4(S), CR8 405096
VGMG-1301 VGM706B 12 VLFLF Models CR2, CRN2(S), CR4, CRN4(S), CR8 405347
VGMG-1302 VGM706B 12 VZFZF Models CR2, CRN2(S), CR4, CRN4(S), CR8 405347TC
VGMG-1303 VGM706B 16 QLFLF Models CR8, CR8(S), CR16, CRN16(S) 425763
VGMG-1304 VGM706B 16 VLFLF Models CR8, CR8(S), CR16, CRN16(S) 425762
VGMG-1305 VGM706B 16 VZFZF Models CR8, CR8(S), CR16, CRN16(S) 425762TC
O-RING COMPONENT SEALS
VGMG-1516* VGM706D 12 VCFLF SPK 1,2,4 & 8 3950008
VGMG-1400 VGM706E 12 VZFZF CNP-CDL
VGMG-1401 VGM706E 16 VZFZF CNP-CDL
Type VGM706D
Grundfos Type B
Type VGM706B Type VGM706E
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GUSHER PUMPS
PS-164 B 9 — 1/2 BMFKF A
PS-1002 C 1 1.000 1/2 BCFJF 84076-3
PS-957 A 1 1.187 5/8 BCFJF 84081
PS-701V A 1 1.187 5/8 VCFKF 84090
PS-359 C 1 1.250 5/8 BCFJF 84000-2, 84000-30
PS-1079 C 1 1.250 5/8 NCFJF
PS-1080 C 1 1.250 5/8 NCFKF
PS-359V-CMS C 1 1.250 5/8 VCFJF 84000-24
PS-359V-SC-CMS C 1 1.250 5/8 VCFLF 84000-38
PS-441 B 9 — 3/4 BMFKF A 84082
PS-358V-TC-TC C 1 1.375 3/4 VZFZF 84064-6
PS-309 C 1 1.500 7/8 BCFJF 84079-2
PS-3941 C 1 1.500 7/8 VLFLF 84079-9
PS-2026 D 3 1.500 7/8 B/VCFJF 84138-1
PS-370 A 1 1.625 1 BCFKF 84089
PS-235 C 1 1.625 1 BCFJF 84001-2, 84001-12
PS-235V-CMS C 1 1.625 1 VCFJF 84001-10
PS-235V-SC-SC C 1 1.625 1 VLFLF 84001-14
PS-2216V-CMS C 1 1.625 1 VZFZF 84176-2
Value Guard Seal Size Material
Part No. Head MM Code Mfg. Part No.
GRUNDFOS CBS, INC. (continued)
CARTRIDGE STYLE-Threaded Retainer
Pump Models CR, CR8, CRI, CRN1, CRN3, CRN5, CRNE1, CRNE3-23HS
VGMG-1500 VGM706C 12 QCFZF 96455082
VGMG-1501 VGM706C 12 QZFZF 96455086
VGMG-1502 VGM706C 12 VCFZF 96455083
VGMG-1503 VGM706C 12 VLFLF 96455087
VGMG-1504 VGM706C 12 VZFZF 96455085
Pump Models CR, CRI, CRN10, CRN15, CRN20
VGMG-1505 VGM706C 16 QCFZF 96511836
VGMG-1506 VGM706C 16 QZFZF 96511840
VGMG-1507 VGM706C 16 VCFZF 96511837
VGMG-1508 VGM706C 16 VLFLF 96511845
VGMG-1509 VGM706C 16 VZFZF 96511841
CARTRIDGE STYLE - Clamped Retainer
Pump Models CR, CRN32, CRN45, CRN64, CRN90
VGMG-1510 VGM706C 22 QCFZF 96416584
VGMG-1511 VGM706C 22 QZFZF 96433365
VGMG-1512 VGM706C 22 VCFZF 96525459
VGMG-1513 VGM706C 22 VLFLF 96525490
VGMG-1514 VGM706C 22 VZFZF 96436728
Grundfos Type H
Type VGM706C
Grundfos Type E
Type VGM706C
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
C. COMpLeTe WITH COLLAr
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
GUSHER PUMPS
PS-185 C 1 1.875 1-1/4 BCFJF 84217-4
PS-2122 C 1 1.875 1-1/4 BCFJF 11019CIHA 84002-31
PS-2123 C 1 1.875 1-1/4 BCFKF 84002-17
PS-3146 C 1 1.875 1-1/4 BZFLF 84002-53
PS-1081 C 1 1.875 1-1/4 NCFJF
PS-1083 C 1 1.875 1-1/4 NCFJF
PS-1082 C 1 1.875 1-1/4 NCFKF
PS-1084 C 1 1.875 1-1/4 NCFKF
PS-2215 C 1 1.875 1-1/4 QCFJF I 84002-18, 84002-3
84002-33
PS-4053 C 1 1.875 1-1/4 QLFLF 84002-57
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 84217-3
PS-2123V-CMS C 1 1.875 1-1/4 VCFKF 84002-12
PS-3175 C 1 1.875 1-1/4 VCFZF 84002-34
PS-185V-SC-SC C 1 1.875 1-1/4 VLFLF 84217-1
PS-7805 C 1 1.875 1-1/4 VLFLF 84002-22, 84002-50
PS-3119 C 1 1.875 1-1/4 VZFLF 84002-41, 84002-58
84002-59, 84006-59
PS-361 E 1 1.875 1-1/4 BCFJF 84003-14
PS-210V-CMS C 1 2.000 1-3/8 VCFKF 84105-7
PS-177V-SC-SEAT C 1 2.000 1-3/8 VCFLF 84144-10
PS-177V-SC-SC C 1 2.000 1-3/8 VLFLF 84105-18
PS-210V-TC-SC C 3 2.000 1-3/8 VZFLF 84105-5
PS-3117 K 1 2.000 1-3/8 VCFJF 84144-2
PS-758 C 1 2.125 1-1/2 BCFJF 84109-1
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 84109-3
PS-758V-SC-SC C 1 2.125 1-1/2 VLFLF 84109-2
PS-2107 C — — 1-5/8 BCF-F 84004-55
PS-238 C 1 2.375 1-5/8 BCFJF 84004-28
PS-239 C 1 2.375 1-5/8 BCFKF 84004-18
PS-4389 C 1 2.375 1-5/8 BCFLF 84004-51
PS-3145 C 1 2.375 1-5/8 BZFLF 84004-40
PS-3664 C 1 2.375 1-5/8 BZFZF 84004-30
PS-238-EPR C 1 2.375 1-5/8 QCFJF 84004-34
PS-238-EPR-SC C 1 2.375 1-5/8 QCFLF 84004-52
PS-7902 C 1 2.375 1-5/8 VCFJF 84004-46
PS-238V-CMS C 1 2.375 1-5/8 VCFJF 84004-26
PS-239V-CMS C 1 2.375 1-5/8 VCFKF 84004-7
PS-238V-SC-CMS C 1 2.375 1-5/8 VCFLF 84004-54
PS-238V-P66-TC C 1 2.375 1-5/8 VCFZF I 84004-20
PS-7806 C 1 2.375 1-5/8 VLFLF 84004-23, 84004-39
PS-238V-TC-SC-CMS
C 1 2.375 1-5/8 VZFLF 84004-42, 84004-48
84004-49, 84004-55
PS-3144 C 1 2.375 1-5/8 VZFZF 84004-35
PS-2057 E 1 2.375 1-5/8 BCFJF 84005-2, 84005-15
PS-2058V-TC-SEAT E 1 2.375 1-5/8 VCFZF 84005-28
PS-1699V E 3 2.375 1-5/8 VCFKF 84005-20
PS-3113 E 3 2.375 1-5/8 XZFLF 316SS 84005-29
PS-3111 K 1 2.375 1-5/8 VLFLF 84056-22
PS-3114 C 1 2.500 1-3/4 BZFZF C 84006-8, 84006-13
PS-3118 C 1 2.500 1-3/4 VCFJF C 84006-11
PS-4461 C 1 2.500 1-3/4 VZFLF C 84006-17, 84006-35
PS-3114V C 1 2.500 1-3/4 VZFZF C 84006-24
PS-7561 E 3 2.500 1-3/4 VCFZF C/I 84007-15
PS-7901 EB 1 2.375 1-3/4 BCFJF 84004-46
PS-9106 W 2 2.500 1-3/4 TCFJF 316SS 84010-01
PS-267 C 1 2.750 2 BCFJF 84176-1
PS-267V-CMS C 1 2.750 2 VCFJF 84176-2
PS-6224 C 1 2.750 2 VLFLF 84176-4
PS-1613 K 3 3.375 2-1/2 BCFJF 84059-5
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
G. MOUNTS IN pLASTIC
H. SprING HOLDer NOT INCLUDeD
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
HAIGHT PUMP PS-1651 E 3 2.312 1-1/2 VCFJF H/HC 60514122
PS-825 D 3 2.500 1-3/4 BCDKF AP13.518X
PS-237V D 3 2.500 1-3/4 VCDJF AP13.518Y
HALE PRODUCTS, INC.
PS-201 A 1 1.375 3/4 BMFJF 292-5040-00-3
PS-851 A 1 1.375 3/4 BCFJF 296-5040-00
PS-360 A 1 1.625 1 BCFJF 296-5010-00
296-5011-00-0
PS-235 C 1 1.625 1 BCFJF Model 20FD 106434 25D-G444,1001-02-20-00
PS-1048 C 1 1.625 1 BCFJF H 296-5050-00-0
PS-548 C 3 1.625 1 BCFJF 296-5060-06-0
PS-1049 C 3 1.625 1 BCFJF H
PS-356 C 1 1.750 1-1/8 BCFJF 296-5220-00
PS-177 C 1 2.000 1-3/8 BCFJF 296-5250-99
PS-495 K 1 2.000 1-3/8 BCFJF 296-5070-00
PS-758 C 1 2.125 1-1/2 BCFJF 296-5021-03
PS-347 C 1 2.125 1-1/2 BCFJF B/H 6D-58
PS-659 C 1 2.125 1-1/2 BCFKF 296-5021-01
PS-378 C 1 2.125 1-1/2 BCFKF B/H 296-5020-06
PS-2209 C 1 2.125 1-1/2 BZFZF 296-5021-06-0
PS-267 C 1 2.750 2 BCFJF 296-5210-00
HALL SCOTT
PS-200 A 1 1.250 5/8 BMFJF
PS-750 D 1 1.375 3/4 BCDJF
Value Guard Seal Size Material
Part No. Head MM Code Mfg. Part No.
HANJIN PUMPS - Series 2921 / 2924 / 2926
VGM-2921 VGM562 20 VLFLF / VCFJF SP-1026
VGM-2922 VGM562 25 VLFLF / VCFJF HTV-3-5.5-18
HTV-4-4.5-18
VGM-2923 VGM562 30 VLFLF / VCFJF SP-2026
HTV-4-11-48
HTV-4-15-48
VGM-2924 VGM562 35 VLFLF / VCFJF SP-3026
VGM-2925 VGM562 40 VLFLF / VCFJF SP-4026
VGM-2926 VGM562 45 VLFLF / VCFJF SP-5026
Type VGM562
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
HARTFORD COMPRESSORS, INC.
PS-9703 WB Special 2.500 2 T/NCFKF 316SS SEL 24A
PS-9710 WB Special 3.125 2-1/2 T/NCFKF 316SS SEL 22A
HAYWARD GORDON
PS-436-TC-TC C 3 2.500 1-3/4 BZFZF 54099158
PS-2114 C 3 2.625 1-7/8 BCFJF 5403016
PS-477-TC-TC E 3 2.750 2 BZFZF 54099121
HAYWARD INDUSTRIES, INC.
PS-200 A 1 1.250 5/8 BMFJF Cast Iron SPX1250XZ2C
PS-2131 A 31 — 5/8 BMFJF G Power-Flo LX, Power-Flo® Matrix SPX1500KA
Power-Flo II®, Turbo Flo®
PS-3960 G 1 1.250 5/8 BCFJF Max-Flo II® SPX1250XZ2, SPX-2700SA
PS-3890 G 1 1.381 5/8 BCFJF NorthStar, Tri-Star SPX-3200SA, SPX-4000
SPX4000SA, SPX4000SA2
PS-201 A 1 1.375 3/4 BMFJF Max-Flo®, Super Pump®, Super Pump II® SPX1600Z2, SPX1600Z2G
PS-370 A 1 1.625 1 BCFKF
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
HOBART CORP. - (Dishwashers / Disposals)
PS-631 C 1 1.000 1/2 BCFJF N R-23682
PS-663 Q 1 1.000 1/2 BMFJF C115710
PS-6313 Q 1 1.019 1/2 BCFJF
PS-3985 B 1 1.375 3/4 BCFJF 316SS C44A
PS-1085V C 1 1.250 5/8 VCFJF B A104329, 00-114696
PS-235 C 1 1.625 1 BCFJF R-79205
PS-539 C 1 1.625 1 BCFJF H R-87809
PS-754V E 3 1.625 1 VCFJF S A104330
PS-6318 Q 9 1.578 1-1/8 VMFAF 00-117071
PS-6317 Q 9 2.000 1-3/8 VMPSP 00-114144
PS-3854 Q 25 2.000 1-3/8 BMPAP C-114144
PS-4041 Q 1 3.375 2-1/4 VMPSP 00-117072
Value Guard Seal Material
Part No. Size Code Mfg. Part No.
HOFFMAN PUMPS - Replacement Seal Kits
VGK-1087 5/8 BMFJF 180013
VGK-1088 5/8 BCFJF 180014
VGK-1085 3/4 BCFJF 180010
VGK-1086 1 BCFJF 180011
VGK-1089 1-3/8 BCFJF 180015
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
HOLLAND PUMP MFG
PS-2209 C 1 2.125 1-1/2 BZFZF
PS-2060-TC-TC D 1 2.500 1-3/4 BZFZF 6TP
PS-340 C 1 2.625 1-7/8 BCFJF
PS-340-TC-TC C 1 2.625 1-7/8 BZFZF 8TP
HOMART-SEARS
PS-162 A 1 1.000 1/2 BMFJF 259-043, W6476
PS-100 A 1 1.187 5/8 BMFJF 42G2377W
PS-508 D 1 1.250 5/8 BCDJF 759-31
HOMELITE (Div. of RIVERSIDE PUMP MFG., INC.)
PS-200 A 1 1.250 5/8 BMFJF 62729
PS-711 A 3 1.187 5/8 BMFJF A-62861-2
PS-201 A 1 1.375 3/4 BMFJF A-75911
PS-601 B 1 1.375 3/4 BMFJF 43271
PS-4056 B 1 1.375 3/4 QCFJF Models AP215, AP220 43303-A
PS-601V-CMS B 1 1.375 3/4 VCFJF Models AP302, AP502 48299
PS-360 A 1 1.625 1 BCFJF A-62403
PS-1086 A 3 2.000 1 BCFJF A-62713, A-62713-1
PS-235 C 1 1.625 1 BCFJF 47046
PS-466 C 1 2.000 1-1/4 BCFJF 46150
• Kits for Hoffman Pumps include gaskets and mechanical seal.
• Hoffman Pumps is not affiliated with U.S.Seal Mfg.
• Products supplied are manufactured or purchased by
U.S.Seal Mfg. from sources other than the company listed.
VGK-1087
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
Value Guard Seal Size Material
Part No. Head MM Code Pump Model No. Mfg. Part No.
HONDA TRASH PUMP
VGM-2964 VGM-BV 20 BCFJF WT20X, WT30X
VGM-8502 VGM-BV 20 VLFLF WT20X, WT30X 78130-YB4-901
VGM-2965 VGM-BV 30 BCFJF WT40X
VGM-8501 VGM-BV 30 VLFLF WT40X
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
HOYT CORP. - (Washers)
PS-6301 Q 3 3.000 2-1/4 NMPAP 28-488
HYDROMATIC PUMP CO. (See PENTAIR, INC. for Additional Part Numbers)
PS-1621 Q 9 — 1/2 BMFJF A 54840001
PS-299 A — — 5/8 BMF-F 000830071
PS-200 A 1 1.250 5/8 BMFJF 00083000, 00083001
14525A010
PS-200V-CMS A 1 1.250 5/8 VCFJF 830101
PS-447 B 8 — 5/8 BCFJF A 75480001
PS-359 C 1 1.250 5/8 BCFJF 015560001
PS-6216 C 1 1.250 5/8 VZFZF 113970011
PS-851 A 1 1.375 3/4 BCFJF 170480001
PS-201V-CMS A 1 1.375 3/4 VCFJF 170480011
PS-1622 B 9 — 3/4 BMFJF A 049170001
PS-358 C 1 1.375 3/4 BCFJF 1000001
PS-703 D 1 1.500 7/8 BCDJF 11716A011
PS-235 C 1 1.625 1 BCFJF Model HPLX200 3000001
PS-235-SC-SC C 1 1.625 1 BLFLF 003000041
PS-2216 C 1 1.625 1 BZFZF 006960001
PS-235V-CMS C 1 1.625 1 VCFJF 003000011
PS-2216V-CMS C 1 1.625 1 VZFZF 003000031
PS-185 C 1 1.875 1-1/4 BCFJF 049160001
PS-185-SC-SC C 1 1.875 1-1/4 BLFLF 049160031
PS-2208 C 1 1.875 1-1/4 BZFZF 049160011
PS-185E-SC-CMS C 1 1.875 1-1/4 QCFLF 049160051
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 049160021
PS-185V-TC-SC C 1 1.875 1-1/4 VZFLF 049160061
PS-185V-TC-TC C 1 1.875 1-1/4 VZFZF 049160041
PS-758 C 1 2.125 1-1/2 BCFJF 009200011
PS-347 C 1 2.125 1-1/2 BCFJF B/H 081000005
PS-758-SC-SC C 1 2.125 1-1/2 BLFLF 009200131
PS-758-SC-TC-CMS
C 1 2.125 1-1/2 BLFZF 009200111
PS-2209 C 1 2.125 1-1/2 BZFZF 009200041
PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 009200031, 009200051
009200071
PS-659V-TC-VS-TC C 1 2.125 1-1/2 VZFZF 009200091, 009200141
PS-446 C 1 2.500 1-3/4 BCFJF 110490011
PS-6210 C 1 2.500 1-3/4 BZFZF 110490021
PS-4410 C 1 2.500 1-3/4 BZFZF 21181A015
PS-340 C 1 2.625 1-7/8 BCFJF 148590001
Type VGM-BV
d D D1 L1 L2 L3
20 40 35 9.5 12.0 5
30 52 48 10.0 9.5 8
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
HYDROMATIC PUMP CO. (See PENTAIR, INC. for Additional Part Numbers) (continued)
PS-340-TC-SC C 1 2.625 1-7/8 BZFLF 148590031
PS-340-TC-TC C 1 2.625 1-7/8 BZFZF 148590011
PS-267 C 1 2.750 2 BCFJF 019570001
PS-267-SC-SC-CMS
C 1 2.750 2 BLFLF 019570051
PS-2219 C 1 2.750 2 BZFZF 019570021
PS-267V-CMS C 1 2.750 2 VCFJF 019570011
PS-6218 C 1 2.750 2 VZFZF 019570041
PS-1087 C 1 3.125 2-1/4 BCFJF 080730001
PS-7064 C 1 3.125 2-1/4 BZFZF 080730011
PS-1679V-CMS C 1 3.125 2-1/4 VCFJF 080730031
PS-3530 E 3 3.125 2-1/4 B/VZFZF 1100148SC2
PS-1088 C 3 3.875 3 BCFJF B 037180001
PS-761 D 3 3.875 3 BCDJF 434210011
HYPRO CORPORATION (See PENTAIR, INC. for Additional Part Numbers)
PS-1050 C — — 1/2 BCF-F 10522C
PS-3001 G 3 1.000 1/2 VCFJF 24608
PS-3002 G 3 1.000 1/2 VCFJF 316SS 24766
PS-516 A 1 1.250 5/8 BCFJF 9501-3, 2120-0008
PS-200V-CMS A 1 1.250 5/8 VCFJF Models 9203, 9401C, 9300C-HM 2120-0009
PS-200V A 3 1.250 5/8 VCFJF 9501-4, 9202-C
PS-3159 B 8 — 5/8 BCFJF A 12314
PS-3667 B 9 — 5/8 BLFLF A 24054
PS-3741 B 1 1.250 5/8 VLFLF 24466
PS-359V C 3 1.250 5/8 VCFJF
PS-4442 C 3 1.250 5/8 VCFKF 2120-0003
PS-3204 G 1 1.250 5/8 BCFJF 24605
PS-3006 G 1 1.250 5/8 BCFJF 316SS 24275
PS-4220 G 1 1.250 5/8 VCFJF 24609
PS-3200 G 1 1.250 5/8 VCFJF 316SS 24276
PS-3005 G 3 1.250 5/8 VLFLF 316SS 2120-0039
PS-851 A 1 1.375 3/4 BCFJF 2120-0010
PS-201V-CMS A 1 1.375 3/4 VCFJF 9000 Series 2120-0011
PS-201V A 3 1.375 3/4 VCFJF 9501-50
PS-3009 G 1 1.500 7/8 BCFJF 316SS 24458
PS-360 A 1 1.625 1 BCFJF 24607, 2120-0054
PS-360V-CMS A 1 1.625 1 VCFJF 2120-0034
PS-397 C — — 1 BCF-F 21399
PS-4425 G 1 1.750 1-1/8 BLFLF 316SS 23906
PS-3015 G 25 2.000 1-3/8 VLFLF 316SS 2120-0043
ICEE DISTRIBUTORS, INC. - (Frozen Drink Machines)
PS-6234 C 1 1.250 5/8 BCFJF 0-ID1339
IMO INDUSTRIES, INC.
PS-2138 C Special 1.360 1/2 BCFGF PP046JCE
PS-3729
X Special
3 1.000 1/2 BCFKF PP046JRF
PS-7727
X Special
3 1.000 1/2 VCFGF PP046JRH
PS-4313 C
3 Special
1.500 5/8 VCFGF PP046JC/C
PS-752 D 1 1.375 3/4 BCDKF PP046DP
PS-687 C 1 1.500 7/8 BCFKF PP046H
PS-3824 C 28 2.438 1 BCFKF PP046JM
PS-1034V C 28 2.438 1 VCFKF PP046JCH
PS-7991 D 25 1.625 1 BCPGP PP046DF
PS-4255 DB 3 1.500 1 VCFZF PPO46KDA
PS-8091 X 3 1.625 1 VCFRF 316SS PP046JZ/CR
PS-254 D 3 1.750 1-1/8 BCFKF PP046JGF
PS-1044 C 28 2.834 1-3/16 BCFKF PP046JL
PS-1044V C 28 2.834 1-3/16 VCFKF PP046JHG
PS-4152 C 3 1.875 1-1/4 BCFGF PP046JLC/C
PS-1036 C 28 2.835 1-1/4 BCFKF PP046JH, PP046JH/C
PS-1036V C 28 2.835 1-1/4 VCFKF PP046JN
PS-4431 D 3 1.875 1-1/4 VLFLF
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
IMO INDUSTRIES, INC. (continued)
PS-8073 X 28 2.832 1-1/4 VCFKF 316SS PP046JBS/PP046JBS/CR
PS-3979 C Special 2.740 1-1/2 BCFKF PP046JAH
PS-371 D 1 2.125 1-1/2 BCFKF PP046DAA
PS-1035 C 28 3.544 1-5/8 BCFKF PP046JK
PS-1039 C 28 3.544 1-5/8 VCFKF PP046JR, PP046JRC
PS-436-SC-SEAT C 3 2.500 1-3/4 BCFLF PP046JDT/CR
PS-1038 C 28 3.544 1-3/4 BCFKF PP046JG
PS-8058 X 3 2.500 1-3/4 VCFLF 316SS PP046JWF
PS-462 D 1 2.750 2 BCDKF PP046BP
PS-1676 C 3 3.125 2-1/4 BCFKF PP046JCD
PS-3051 C 3 3.250 2-3/8 BCFLF S PP046JWH
PS-1677 C 28 5.118 2-3/8 BCFKF PP046FBY
PS-8003 X 3 3.250 2-3/8 VCFLF 316SS PP046JTT
PS-3862 X 3 4.375 3-1/2 VCFKF 316SS PP046JZM
INGERSOLL-DRESSER PUMPS AND COMPRESSORS (Also See FLOWSERVE CORP.)
PS-164 B 9 — 1/2 BMFKF A
PS-200 A 1 1.250 5/8 BMFJF CPM-6252C1
CPM-6258C1
PS-507V A 3 1.250 5/8 VCFKF CPM-625271
CPM-625871
PS-600 B 1 1.187 5/8 BMFJF Bronze Fitted KRVSA-3/4, 1-1/4, CPM-10015
Model B 1/4 to 1-1/2 HP Motors
PS-616 B 1 1.187 5/8 BMFKF Iron Fitted KRVSA-3/4, 1-1/4, CPM-10029, 60110269
Model B 1/4 to 1-1/2 HP Motors
PS-359 C 1 1.250 5/8 BCFJF 1x 4, 3/4, 1, 1-1/4, 2 x 5 HK & HOK CPM-6251C1
PS-633 C 1 1.250 5/8 BCFKF 1x 4, 3/4, 1, 1-1/4, 1-1/2, 2 x 5 HK CPM-625171
PS-760 A 3 1.375 3/4 BMFJF SMP 1000 & SMP 2000 CPM-10600A
PS-601 B 1 1.375 3/4 BMFJF CPM-10034, 60116225
PS-606 B 1 1.375 3/4 BMFKF CPM-10035, 60110301
PS-564 C — — 3/4 BCF-F 024439-00
PS-3654 C 1 1.375 3/4 BCFKF SMP2000
PS-2236 C 3 1.375 3/4 BCFJF SMP2000 1802ATY210RM075BF1C1
60721792, 60980901
PS-2235 C 3 1.375 3/4 VCFJF CPM-10606A, 60724572
PS-7994 E 3 1.187 3/4 VCFKF 1802AJCTYPIR075XP171
PS-303 D 1 1.500 7/8 BCDKF SMP2000 W-11448, W-20168
PS-602 D 1 1.562 7/8 BCDJF KRVS-1-1/2, 2, 3 1/4 to 1-1/2 HP CPM-10052
PS-603 D 1 1.562 7/8 BCDKF KRVS CPM-10053
PS-7859V E 3 1.312 7/8 VCFKF 316SS 1802AJCTYP1R088BF171
PS-560V U 3 1.562 15/16 VCFKF 7GA 1802AJCTYP1R094
03144601, 74744319
PS-801 C 3 1.750 1-1/8 B/VCFJF 3 x 5 HK, 3 x 6 HK CPM-1121C1, 60487089
PS-2226 C 3 1.750 1-1/8 QCFZF I 3 x 5 HK, 3 x 6 HK CPM-112171
PS-355V C 3 1.750 1-1/8 VCFKF 39633201, 39757141
PS-604 D 1 1.750 1-1/8 BCFJF Bronze Fitted KRVS-1 CPM-10054, CPM-10026
60110434
PS-605 D 1 1.750 1-1/8 BCFKF Iron Fitted KRVS-1 CPM-10055, 60110442
PS-521 D 1 1.875 1-1/8 BCFKF
PS-607 E 1 1.687 1-1/8 BCFJF Bronze Fitted 1, 2 RVN-1 1-1/2, 2, CPM-10043, 60110327
3 RVNL, 1-1/2, 2 RV and RVH-3RVS,
1-1/2 RVL
PS-608 E 1 1.687 1-1/8 BCFKF Iron Fitted 1, 2 RVN-1 1-1/2, 2, CPM-10044, CPM-10087
3 RVNL, 1-1/2, 2 RV and RVH-3RVS, 60110335
1-1/2 RVL
PS-867 E 3 1.750 1-1/8 BCFKF 68885865, 69237592
PS-4421 E 3 1.750 1-1/8 QCFJF 316SS
PS-204V E 3 1.750 1-1/8 VCFJF CPM-10715A, 60954682
1802AJCTYP1A112XF1C1
PS-867V E 3 1.750 1-1/8 VCFKF CPM-10715B, 68885847
PS-867V-TC-SEAT E 3 1.750 1-1/8 VCFZF 1802AJCTYP1A112XF1D1
60954716
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
INGERSOLL-DRESSER PUMPS AND COMPRESSORS (Also See FLOWSERVE CORP.) (continued)
PS-1636 E 3 1.812 1-1/8 B/VCFJF H/HC/VOC/HOC CPM-10465A, CPM-10470A
PS-1637 E 3 1.812 1-1/8 B/VCFKF H/HC/VOC/HOC CPM-10406B, CPM-10465B
CPM-10470B
PS-619 E 3 1.812 1-1/8 BCFJF Extended Carbon CPM-10217A, CPM-10220A
PS-948 E 3 1.812 1-1/8 BCFKF Extended Carbon CPM-10220B, CPM-10217B
PS-1668 E 3 1.812 1-1/8 BCFZF CPM-10465C, CPM-10470C
PS-1172V E 3 1.812 1-1/8 VCFJF 6 VOC 7 HOC CPM-10406A
PS-1639V E 3 1.812 1-1/8 VCFKF CPM-10406B
PS-3511 T 3 1.750 1-1/8 VCFJF HOC2 & VOC 2 1802AJCTYP1DBLXF1C1
PS-310 E 1 1.875 1-3/16 BCDJF CPM-118S429X5
PS-343 E 1 1.875 1-3/16 BCDKF CPM-118S429X2
PS-723 T 1 1.875 1-3/16 BCDJF Models DHV and DMV CPM-118S429X4
60111267
PS-724 T 1 1.875 1-3/16 BCDKF Models DHV and DMV CPM-118S429X3
PS-185 C 1 1.875 1-1/4 BCFJF CPM-10601A
PS-756 C 1 1.875 1-1/4 BCFKF
PS-618 C 3 1.875 1-1/4 BCFJF SMP 3000 & SMP 2000 1802ATY210RM125BF1C1
60721800, 60980918
60980919, CPM-10601A
PS-598-EPR C 3 1.875 1-1/4 QCFKF CPM-10604A
1802TY210RM028F171
PS-2203 C 3 1.875 1-1/4 QCFKF I 1802ATY210RM125028F171
68867910
PS-185V C 3 1.875 1-1/4 VCFJF CPM-10613A
1802ATY210RMXFICI
68867902
PS-756V C 3 1.875 1-1/4 VCFKF 74898800
PS-618V-TC-SEAT C 3 1.875 1-1/4 VCFZF CPM-10709, 60727401
PS-416 D — — 1-1/4 BCF-F 74898800, W-32652
PS-3973 U 2 1.875 1-1/4 BCPKF
PS-467 C 1 2.125 1-3/8 BCFKF W-28861, W-21642
PS-5003 C 2 2.125 1-3/8 NCFKF 316SS
PS-354 E 1 2.000 1-3/8 BCFJF CPM-137S429X5
PS-677 E 1 2.000 1-3/8 BCFKF CPM-137S429X2
PS-3925 E 3 2.125 1-3/8 VCFJF 1802AJCTYPEA138XF1C1
74816117
PS-3878 E 3 2.125 1-3/8 VCFJF 316SS HOC 3, Group 1
PS-725 T 1 2.000 1-3/8 BCFJF CPM-137S429X4, 60111275
PS-726 T 1 2.000 1-3/8 BCFKF CPM-137S429X3
PS-371 D 1 2.125 1-1/2 BCFKF W-27658
PS-2106 E — — 1-1/2 BCF-F 3879AJCTYP1A150BF1-1
68886183, 68886175
PS-2106V E — — 1-1/2 VCF-F CPM-10369ABC
CPM-10407ABC
3879AJCTYPA150-XFI
80612400
PS-305 E 1 2.125 1-1/2 BCFJF GTB CPM-10367A
CPM-10368A
PS-395 E 3 2.125 1-1/2 BCFJF CPM-10132
PS-258 E 3 2.125 1-1/2 BCFKF GTB CPM-10129, CPM-10367B
CPM-10368B, 6886100
PS-305V E 3 2.125 1-1/2 VCFJF GTB CPM-10369A
1802AJCTYP1A150XF1C1
68886068
PS-374V E 3 2.125 1-1/2 VCFKF GTB CPM-10369B
1802AJCTYPIRXP171
1802AJCTYP1A150XF171
PS-620 E 3 2.312 1-1/2 BCFJF Extended Carbon CPM-10218A
CPM-10221A
PS-629 E 3 2.312 1-1/2 BCFKF Extended Carbon CPM-10218B
CPM-10221B
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
INGERSOLL-DRESSER PUMPS AND COMPRESSORS (Also See FLOWSERVE CORP.) (continued)
PS-4034 E 3 2.312 1-1/2 BCFZF CPM-10466C, 60514148
PS-1647 E 3 2.312 1-1/2 B/VCFJF H/HC CPM-10466A
CPM-10471A
PS-1648 E 3 2.312 1-1/2 B/VCFKF H/HC CPM-10466B
CPM-10471B, 60514288
PS-1651 E 3 2.312 1-1/2 VCFJF H/HC CPM-10473A, 60514122
PS-620V E 3 2.312 1-1/2 VCFJF Extended Carbon CPM-10224A
PS-1652 E 3 2.312 1-1/2 VCFKF H/HC CPM-10473B, 60514726
PS-1691 E 3 2.312 1-1/2 VCFKF Extended Carbon CPM-10224B
PS-1692 E 3 2.312 1-1/2 VCFZF Extended Carbon CPM-10224C
PS-818 C 3 2.375 1-5/8 BCFJF SMP 3000 CPM-10602A, 60721818
PS-609 E 1 2.312 1-5/8 BCDJF 2,3,4 and 5RVL-3 RVH-1-1/2 ORVL CPM-10045, 60110343
PS-484 E 1 2.312 1-5/8 BCDKF X33548P1
PS-346 E 1 2.312 1-5/8 BCFJF 3 RVL CPM-10028
PS-610 E 1 2.312 1-5/8 BCFKF 2,3,4 and 5RVL-3 RVH-1-1/2 ORVL CPM-10046, 60110350
PS-7950 E 3 2.312 1-3/4 QCFZF I 74840992
PS-859-TC-SEAT E 3 2.500 1-3/4 BCFZF S-Row Series 100 CPM-10347
PS-4139 E 3 2.625 1-3/4 VCFKF 1802ATCTYP1R175XF171
PS-674 T 1 2.500 1-3/4 BCFJF 3, 4, 5 RVL and CRVL CPM-10024
PS-722 E 1 2.625 1.771 BCFJF CPM-177S429X5
PS-719 E 1 2.625 1.771 BCFKF CPM-177S429X2
PS-727 T 1 2.625 1.771 BCFJF CPM-177S429X4
PS-728 T 1 2.625 1.771 BCFKF CPM-177S429X3
PS-340-EPR-CMS C 1 2.625 1-7/8 QCFJF CPM-10656
PS-2069 E 1 2.625 1-7/8 BCFJF CPM-10370A
PS-2071 E 3 2.625 1-7/8 BCFJF CPM-10371A
PS-2072 E 3 2.625 1-7/8 BCFKF 3GT CPM-10158, CPM-10370B
CPM-10371B,
1802AJCTYP1A188B
XF1716043421,68885987
PS-1659 E 3 2.625 1-7/8 VCFJF GTB CPM-10372A
1802AJCTYPA188XF1C1
60954757
PS-1660 E 3 2.625 1-7/8 VCFKF GTB CPM-10372B
60954807, 68859601
PS-1661 E 3 2.625 1-7/8 VCFZF CPM-10716C
1802AJCTYP1A188-XF1D1
PS-949 E 3 2.687 1-7/8 BCFKF Extended Carbon CPM-10219B, CPM-10222B
PS-1664 E 3 2.687 1-7/8 B/VCFJF VOC/HOC CPM-10219A, CPM-10222A
CPM-10461A, CPM-10467B
CPM 10472B
PS-7020 E 3 2.687 1-7/8 VCFJF CPM-10225A, CPM-10408A
CPM-10467A
PS-1653 T 3 2.687 1-7/8 VCFJF HOC 6 x 4 x 13 CPM-10278
PS-530 E 3 2.750 2 BCFJF
PS-477 E 3 2.750 2 BCFKF S Line CPM-200S429X2
CPM-200S429X7
PS-342 E 3 2.750 2 NCPKP 1-1/2, 2 and 3 VM-1-1/2 and 3 VL CPM-10130
3 VLA Vertical Pumps and S Line CPM-200S429X1
PS-611 E 3 2.812 2-1/8 BCFJF All Bronze Fitted Pump CPM-10047
1-1/2, 2 MRV-5 RVH, 6 RVL, 50RVL D
PS-1612 E 3 2.812 2-1/8 BCFKF All Iron Fitted Pumps CPM-10048, 60110376
1-1/2, 2 MRV-5 RVH, 6 RVL, 50RVL D
PS-2086 E 3 3.000 2-1/8 BCFKF Series 100S CPM-10351
PS-5076 C 3Special 3.125 2-1/4 VCFKF
PS-278 E 3 3.250 2-3/8 BCFJF HOC CPM-10469A
PS-350 E 3 3.250 2-3/8 BCFKF 4GT/S/HOC CPM-10159, CPM-10469B
PS-278V E 3 3.250 2-3/8 VCFJF HOC 1802AJCTYP1A238-XF1C1
6003427, 60969797
PS-2098V E 3 3.250 2-3/8 VCFKF CPM-10718B, CPM-10251B
PS-3498 D 3 3.375 2-1/2 VAFLF N/S 39929351
PS-279 E 3 3.375 2-1/2 BCFJF CPM-10134
PS-349 E 3 3.375 2-1/2 BCFKF S Line CPM-250S429X2
CPM-250S429X7, 69261360
PS-321 E 3 3.500 2-3/4 V/BCFKF S Line Series 100 CPM-10355
PS-475 E 3 3.875 3 BCDKF 6GT
PS-325SS U 3 4.125 3-1/4 BCFKF S Line, 8 x 14SD,10 x 14SD CPM-325S429X2, 69261378
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
//
INSINGER MACHINE CO. - (Dishwashers)
PS-204 E 1 1.750 1-1/8 BCFJF B15
ITT INDUSTRIES (See A-C Pump, Bell & Gossett, Domestic Pump, Jabsco, Marlow)
ITT R & CW (ITT RESIDENTIAL & COMMERCIAL WATER PUMPS)
PS-3926 B 9 1.062 5/8 VCFKF 316SS A00202C 1
PS-544V-SC-SC C 3 2.375 1-5/8 VLFLF 76407 3625
PS-3993 C 3 2.750 2 BCFJF 76407 1200
JABSCO
PS-642 B — — 5/8 BMF-F Seat is Impeller 1/2” Motor Pump
PS-382 D 1 2.125 1-1/2 BCFJF 3200 and 3200-01, 3200-21
JACUZZI (Div. of STA-RITE INDUSTRIES)
PS-162 A 1 1.000 1/2 BMFJF 10-563
PS-631 C 1 1.000 1/2 BCFJF N Model 5AM 10-564
PS-200 A 1 1.250 5/8 BMFJF Cygnet K, KM, Vector LVLA, 10-467, 10-1436-00
J, JCM, LCM, LCU and LR Series 10-0002-06
PS-290 C 1 1.250 5/8 BCFJF N 10-1202, 10-1203, 7524000
PS-359 C 1 1.250 5/8 BCFJF 10-478, 10-506
PS-102 D 1 1.250 5/8 BCDKF 10-502
PS-201 A 1 1.375 3/4 BMFJF Model 5RP, SF, Magnum®, RC-Series 10-477, 10-486, 10-120
10-1390-04, 10-1502-09
PS-358 C 1 1.375 3/4 BCFJF 10-479
PS-877 C 1 1.375 3/4 BCFJF 8M 10-1203-01, 10-1203-19
PS-683 C 1 1.500 3/4 BCFJF 10-100
PS-750 D 1 1.375 3/4 BCDJF 10-503
PS-235 C 1 1.625 1 BCFJF 10M 10-504, 10-1299-06
PS-204 E 1 1.750 1-1/8 BCFJF 10-505
PS-185 C 1 1.875 1-1/4 BCFJF 10-0369-29, 10-1400-02
PS-2122 C 1 1.875 1-1/4 BCFJF 10-0369-03
PS-209 K — — 1-3/8 BCF-F 10-315, 10-328
PS-758 C 1 2.125 1-1/2 BCFJF 10-1348-07
PS-2142 C 1 2.500 1-3/4 BCFJF 10-0307-00
PS-205 E 1 2.500 1-3/4 BCFJF 10-330
PS-213 R — — 1-3/4 BCD-F 10-323
PS-874 D 1 3.125 2-1/4 BCDJF 10-365
JAEGER
PS-201 A 1 1.375 3/4 BMFJF
PS-360 A 1 1.625 1 BCFJF
PS-356 C 1 1.750 1-1/8 BCFJF 80237
PS-177 C 1 2.000 1-3/8 BCFJF 81031-1
PS-461 D 1 2.375 1-5/8 BCDKF 66319-1
PS-876 D 1 2.625 2 BCDKF 66435-1
JANDY (Div. of ZODIAC POOL SYSTEMS)
PS-1000 B 1 1.250 5/8 BMFJF P84-60 P55
PS-3890 G 1 1.381 5/8 BCFJF PB-460Q P84-3
PS-4280 G 1 1.381 5/8 VCFJF FHP, JEP, MHP, PHP, SHP, SWF, R00479400
WFTR
PS-4231 G 1 1.375 5/8 VCFJF PHPM, PHPF New & Old Style R0445500
1.381 3/4 Contains PS-4280 and PS-3868
PS-601 B 1 1.375 3/4 BMFJF HHP, HHPU, MHP, MHPU R0338200
JOHN BEAN TECH
PS-397 C — — 1 BCF-F 401-50-0001
FA-1850 C — — 1-1/2 BCF-F 401-50-0006
JOHNSON CONTROLS
PS-4026 D 3 2.500 1-3/4 NCFKF 029 22359 001
PS-6147 C — — 2-1/2 NCF-F 522M0007H01
PS-6151 D — — 2-5/8 NCP-P I 02913450 000
PS-4028 K
3 Special
4.500 2-7/8 NCFGF 523B0201G01
JOY MFG. (See SULLIVAN PALATEK)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
KADY INTERNATIONAL
PS-687 C 1 1.500 7/8 BCFKF 91381
PS-210 C 1 2.000 1-3/8 BCFKF 91379
PS-3541 T 3 2.000 1-3/8 VZFZF 316SS 118563
KASCO MARINE
PS-3960 G 1 1.250 5/8 BCFJF 840500
PS-3199 G 1 1.250 5/8 BLFLF 840370
KENCO
PS-162 A 1 1.000 1/2 BMFJF Type 62, 63, 64, 65
PS-163 B 1 1.000 1/2 BMFJF AE001A1
PS-165 B 9 .906 1/2 BMFJF A 59A,140A
PS-200 A 1 1.250 5/8 BMFJF Model 139A New Style
PS-452 B 9 — 5/8 BMFJF A Model 109A New Style
PS-762 A 3 1.375 3/4 BMFKF Model 114 6A001A1
KINNEY VACUUM PUMP (Div. of TUTHILL CORP.)
PS-358 C 1 1.375 3/4 BCFJF KC2.5-15, KS-13
KC-5, KC-8(491)
PS-358V C 3 1.375 3/4 VCFJF 65046
PS-197 K — — 7/8 BCF-F SK-549
PS-357 C 1 1.625 1 BCFKF KS-27-47
PS-159 D 3 1.625 1 NCPGP VSM-778-8811 65024
PS-355 C 1 1.750 1-1/8 BCFKF KC-46
PS-659 C 1 2.125 1-1/2 BCFKF KD-110, KDH-130
PS-238V-CMS C 1 2.375 1-5/8 VCFJF 065241A000
PS-366 E 1 2.500 1-3/4 BCFKF KD-220, KDH-220
PS-462 D 1 2.750 2 BCDKF
PS-658 R 1 2.750 2 BCDKF KBM-1200, MB-17
KLEIN PRODUCTS OF KANSAS, INC.
PS-547 C 3 2.000 1-3/8 BCFKF 33011197
PS-3138 C 1 2.375 1-5/8 BCFKF 33024421
PS-3179 C 1 2.375 1-5/8 BCFLF 33024421HD
KNIGHT EQUIPMENT - (Dishwashers)
PS-200-EPR A 1 1.250 5/8 QCFJF 9600745
KRAISSL CO.
PS-150 B — — 1/2 BMF-F Seat is Impeller
Value Guard Seal Material
Part No. Head Size Code Mfg. Part No.
KSB CENTRIFUGAL PUMP
VGM-3950 VGMC-1 10MM VLFLF KU 010
VGM-3951 VGMC-1 15MM VLFLF KU 015
VGM-3952 VGMC-12S 16MM VLFLF
VGM-3242 VGMC-12S 22MM VLFLF KU 022
VGM-3243 VGMC-12S 28MM VLFLF NU 026
VGM-3244 VGMC-12S 38MM VLFLF NU 038
VGM-3245 VGMC-12S 48MM VLFLF NU 048
Type VGMC-1 Type VGMC-12S
D0 D1 D2 L1 L2
10.00 19.20 20.00 25.90 6.60
15.00 24.60 25.00 28.40 6.60
16.00 27.00 26.00 22.20 12.10
22.00 37.00 36.00 25.40 12.10
28.00 43.00 47.00 35.60 14.40
38.00 56.00 58.00 41.80 13.20
48.00 66.00 69.00 50.40 9.60
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
Value Guard Seal Material
Part No. Head Size Code Mfg. Part No.
KSB SUBMERSIBLE PUMP
VGM-1410U VGMC-1 10MM VCFLF
VGM-1410L VGMC-1 VLFLF SU 010
VGM-1415U VGMC-1 15MM VCFLF
VGM-1415L VGMC-1 VLFLF SU 015
VGM-1425U VGMC-1 25MM VCFLF
VGM-1425L VGMC-1 VLFLF SU 025
VGM-1428U VGMC-1 28MM VCFLF
VGM-1428L VGMC-1 VLFLF SU 028
VGM-1430U VGMC-1 30MM VCFLF
VGM-1430L VGMC-1 VLFLF SU 030
VGM-1433U VGMC-1 33MM VCFLF
VGM-1433L VGMC-1 VLFLF SU 033
VGM-1443U VGMC-1 43MM VCFLF
VGM-1443L VGMC-1 VLFLF SU 043
VGM-1448U VGMC-1 48MM VCFLF
VGM-1448L VGMC-1 VLFLF SU 048
VGM-1475U VGMC-1 75MM VCFLF
VGM-1475L VGMC-1 VLFLF SU 075
VGM-1490U VGMC-1 90MM VCFLF
VGM-1490L VGMC-1 VLFLF SU 090
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
LABCONCO CORP. - (Dishwashers)
PS-6308 Q 9 1.250 11/16 Special A 4485800
LANCASTER PUMP CO.
PS-150 B — — 1/2 BMF-F Seat is Impeller 4761
376 Laundro Pak
PS-1002 C 1 1.000 1/2 BCFJF Converto, Supreme Jet, MTR Jet, 1061
Type M 901 thru 906, Type P, all models
PS-200 A 1 1.250 5/8 BMFJF 2661
PS-1000 B 1 1.250 5/8 BMFJF 5236
PS-151 B 1 1.375 5/8 BMFJF Types S & SD Lancaster Dutchman- 2461
1182, 1183, 1192, 1193
PS-1005A B 1 1.375 5/8 BMFKF 2561
PS-447 B 8 — 5/8 BCFJF A Model 570, 575, 1775
PS-493 C 1 1.187 5/8 BCFKF 5256
PS-201 A 1 1.375 3/4 BMFJF Types S & SD Lancaster Dutchman- 1661
1182, 1183, 1192, 1193
PS-358 C 1 1.375 3/4 BCFJF Self Priming Pump Model 673 1361
PS-703 D 1 1.500 7/8 BCDJF Turbo Pak Model 523BF- 524 BG 429 7/8
PS-360 A 1 1.625 1 BCFJF Type M-907 and M-908 7561
PS-381 D 1 1.875 1-1/4 BCFJF Type M-909 and M-910 909-61
LEAR SIEGLER (See Sherwood Brass)
Other Materials Available Upon Request
Type VGMC-1
D0 D1 D2 L1 L2
10.00 19.20 20.00 14.50 6.50
15.00 24.60 28.00 17.00 7.00
25.00 38.00 41.00 23.00 7.50
28.00 43.00 47.00 26.50 9.00
30.00 45.00 47.00 26.50 10.50
33.00 48.00 51.00 27.50 11.00
43.00 61.00 62.20 30.00 12.00
48.00 66.00 69.00 30.50 11.50
75.00 97.00 102.00 40.00 14.00
90.00 115.00 126.00 45.00 15.00
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
LEHIGH
PS-752 D 1 1.375 3/4 BCDKF D-811
PS-108 E 1 1.875 1-1/4 NCPKP D-845
LELAND FARADAY
PS-142 B 1 1.000 1/2 BMFJF
PS-163 B 1 1.000 1/2 BMFJF Model LFP-43000
PS-1000 B 1 1.250 5/8 BMFJF Models LFP-2075, 2100, 2150, 2200
PS-800 C 1 1.156 5/8 BMFJF H Models LFP-333-615, 14107-14120,
34105-34320
PS-877 C 1 1.375 3/4 BCFJF Models LFP-533-1100, 5050, 5075, 5100
LEROY SOMER NORTH AMERICA
PS-3893 C
3 Special
1.500 7/8 VCFGF 90243401
PS-3943 C
3 Special
2.125 1-1/2 VCFGF 90348301
PS-3945 C
3 Special
1.875 1-1/4 VCFGF 90311601
PS-3584 C
3 Special
2.000 1-3/8 VCFGF 90300001
PS-3939 C
3 Special
2.375 1-5/8 VCFKF 90352401
LEWIS, CHARLES S. & CO. (Div. of WEIR GROUP)
PS-381 D 1 1.875 1-1/4 BCFJF
PS-3032 D 1 1.875 1-1/4 VLFLF
PS-3555 D 1 1.875 1-1/4 QLFLF 10282
PS-205 E 1 2.500 1-3/4 BCFJF
PS-205-P66 E 1 2.500 1-3/4 BCFJF I 21353
PS-366 E 1 2.500 1-3/4 BCFKF 10283
PS-3031 E 1 2.500 1-3/4 VLFLF 316SS
PS-858-EPR-SC-SC E 3 2.500 1-3/4 QLFLF 14690
LINK BELT
PS-357 C 1 1.625 1 BCFKF WB-35
PS-355 C 1 1.750 1-1/8 BCFKF WB-40
PS-461 D 1 2.375 1-5/8 BCDKF WB-60
PS-288 D 1 2.500 1-3/4 BCDKF WB-70
LITTLE GIANT PUMP CO. (Div. of FRANKLIN ELECTRIC CO., INC.)
PS-3048 B 1 1.000 1/2 BCFJF 926029, 926030
PS-163 B 1 1.000 1/2 BMFJF 926024
PS-165 B 9 .906 1/2 BMFJF A 108112, 926031
PS-961 B 1 1.250 5/8 BCFJF 926034
PS-1000 B 1 1.250 5/8 BMFJF Pump 10 &12
PS-933 C — — 5/8 BCF-F 926052
PS-552 C 3 1.250 5/8 BCFJF 926051
PS-356V C 3 1.750 1-1/8 VCFJF 926042, 926043
LOBEE PUMP & MACHINERY CO.
PS-9009 W 2 1.500 7/8 TCFJF 316SS
LOCKWOOD PUMP
PS-301 A 1 1.375 3/4 BMFJF
PS-360 A 1 1.625 1 BCFJF CM Pump
LOGANSPORT
PS-400 C — — 1/2 BMF-F P-9509
PS-106 C 1 1.000 1/2 BCFKF P-17251
PS-109 D — — 5/8 BCD-F SF-4, SF-10 P-14883
PS-564 C — — 3/4 BCF-F SF-80, 100, 125, 150 P-9518
LOMART
PS-150 B — — 1/2 BMF-F Seat is Impeller
PS-142 B 1 1.000 1/2 BMFJF
PS-163 B 1 1.000 1/2 BMFJF 40-027, 40-029
PS-1000 B 1 1.250 5/8 BMFJF
LOUIS PUMP
PS-370 A 1 1.625 1 BCFKF
LOU-RICH MACHINE TOOL - (Ice Machines)
PS-6305 Q 2 1.625 1 BMDAF 13417
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
LUITWEILER PUMP
PS-201 A 1 1.375 3/4 BMFJF
PS-361 E 1 1.875 1-1/4 BCFJF
LYCO WAUSAU, INC.
PS-446 C 1 2.500 1-3/4 BCFJF 1100-17
MAGNETROL (See SCHAUB ENGINEERING CO.)
MAGNUM PRODUCTS, LLC.
PS-516 A 1 1.250 5/8 BCFJF 48273
PS-185-SC-SC C 1 1.875 1-1/4 BLFLF 48253
PS-758 C 1 2.125 1-1/2 BCFJF 48265
PS-541 K 1 2.125 1-1/2 BCFJF 42764
MANITOWOC CO., INC. - (Ice Machines)
PS-360 A 1 1.625 1 BCFJF 003705011
MARLOW
PS-151 B 1 1.375 5/8 BMFJF 42513-00
PS-2161 B 1 1.375 5/8 BMFJF SCT Series, Stainless Steel 46328-00
PS-411 B 11 — 5/8 BMFJF A Model H23EC-A 1-1/2 HP, 2AF Series 23736-00, 25353-00
25353-20, 26467-00
PS-411V B 11 — 5/8 VCFJF A 27678-00, 29163-00
29163Z
PS-201 A 1 1.375 3/4 BMFJF Argonaut®, Mardur® 38592-00
PS-405 A 27 1.625 1 B/VCFJF 26473-00
PS-413 C 27 1.625 1 BCFJF 20760-00, 25355-00
PS-978 C 1 1.765 1-1/4 BCFJF B L Series 45672-20
PS-979 C 1 1.765 1-1/4 BCFKF B
PS-923 C 25 2.250 1-1/4 BCFJF B 27233-20, 27452-00
PS-416 D — — 1-1/4 BCF-F 27453-00
PS-416A D 25 2.250 1-1/4 BCFJF 3B Series 27223-00, 27224-00
27225-00, 3B28EC-C2
PS-7919 C 3 2.000 1-3/8 B/VLFLF 43350-00
PS-929 C 25 2.000 1-3/8 BCFJF 25481-00
PS-404 D 25 2.000 1-3/8 BCDJF 25356-00, 25356-20
26477-00
PS-8048 XT 3 2.125 1-3/8 VCFJF 316SS 45184000000
PS-3832 C 1 2.375 1-5/8 QCFLF B/I
PS-818 C 3 2.375 1-5/8 BCFJF 46983-00
PS-544V-SC-SC C 3 2.375 1-5/8 VLFLF 43435-00
PS-7497 C 25 2.500 1-5/8 B/VCFJF 28146-00, A05669E000R
PS-514 D 1 2.375 1-5/8 BCDJF L Series 45673-20
PS-446 C 1 2.500 1-3/4 BCFJF 25357-00
PS-550 C 3 2.500 1-3/4 BCFJF Model 6 EL 47182-00
PS-3040 K 3 2.750 1-3/4 BCFJF 4DW165B
PS-267 C 1 2.750 2 BCFJF 25358-00
PS-478 E 1 2.687 2 BCFKF
PS-7963 K 3 3.000 2 BCFJF 43426000000
MASSEY FERGUSON
PS-642 B — — 5/8 BMF-F 892-563M1
PS-647 B — — 3/4 BMF-F 1019-293M1
McDONALD A-Y
PS-166 A 1 1.187 5/8 BMFJF 5MCD1
PS-501 A 1 1.250 5/8 BMFJF 3000, 4000 and 4100 Jet Well 5MCD4
PS-201 A 1 1.375 3/4 BMFJF 5MCD5
PS-521 D 1 1.875 1-1/8 BCFKF 5MCD2
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
MEGATOR CORP.
PS-359 C 1 1.250 5/8 BCFJF 5079
PS-359V-CMS C 1 1.250 5/8 VCFJF 5079V
PS-358 C 1 1.375 3/4 BCFJF 5479
PS-309 C 1 1.500 7/8 BCFJF 5679
PS-309V-CMS C 1 1.500 7/8 VCFJF 5679V
PS-356 C 1 1.750 1-1/8 BCFJF 5879
PS-356V-CMS C 1 1.750 1-1/8 VCFJF 5879V
PS-185 C 1 1.875 1-1/4 BCFJF 5779
PS-758 C 1 2.125 1-1/2 BCFJF 5979
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 5979V
MEMPHIS PUMP & MFG. CO., INC.
PS-100 A 1 1.187 5/8 BMFJF 0625-6BC
PS-118 C 1 1.187 5/8 BCFJF
PS-1091 C 1 1.187 5/8 VCFJF
PS-508 D 1 1.250 5/8 BCDJF
PS-201 A 1 1.375 3/4 BMFJF
PS-1093 C 1 1.375 3/4 VCFJF
PS-1092 C 1 1.375 3/4 VCFKF
PS-1094 C 1 1.625 1 VCFJF
MEPCO (Marshall Engineered Products Co.) See DUNHAM-BUSH
METAL MASTER
PS-150 B — — 1/2 BMF-F Seat is Impeller 12515
PS-680 A 1 1.187 5/8 BCFJF 19023
PS-702 A 1 1.187 5/8 BMFJF 15110
PS-200 A 1 1.250 5/8 BMFJF
PS-153 A 1 1.250 5/8 BMFKF
PS-151 B 1 1.375 5/8 BMFJF
MET-PRO CORP.
PS-1000V B 3 1.250 5/8 VCFJF 6960440
PS-3962
W Special
2 1.250 5/8 TCFJF 6960444
PS-397V C — — 1 VCF-F 6765570
PS-236V E 3 1.625 1 VCFKF 6764554
T9-1000 WT — — 1 TCF-F 316SS 6765575
PS-9349 WT 27 2.000 1 TCFZF 316SS
PS-3137 C 3 1.750 1-1/8 VCFLF Light Spring Load 6765938
PS-2104V E — — 1-3/8 VCF-F 6767102
PS-1056V C 3 2.500 1-3/4 VCFKF 6765941
PS-1056V-SC-SEAT C 3 2.500 1-3/4 VCFLF 6765942
PS-366V E 3 2.500 1-3/4 VCFKF 6764540, 6765965
PS-8122 XB1 3 2.500 2 XCFLF 316SS 6765945
MEYER- MOJONNIER
PS-227 D 1 1.750 1 BCFKF 750062149
MIDLAND PRODUCTS (Div. of CRANE PUMPS & SYSTEMS)
PS-201 A 1 1.375 3/4 BMFJF 6070-0
PS-360 A 1 1.625 1 BCFJF Models 5M, 7M and 18M 6007-0
PS-177 C 1 2.000 1-3/8 BCFJF Models 40M and 40W
PS-805 C 3 2.000 1-3/8 BCFJF 6368-0
PS-550 C 3 2.500 1-3/4 BCFJF 6412-0
PS-532 C 3 2.750 2 BCFJF 6428-0
MILE HIGH EQUIPMENT CO. - (Ice Machines)
PS-3120 Q Special 1.625 1 Special 9121026-91
PS-6311 Q Special 2.375 1-5/8 N/BMDAF 9121025-91
MILRECO
PS-448 C 1 2.500 1-3/4 BCFKF RMB-414
MILTON ROY
PS-1002V C 1 1.000 1/2 VCFJF 7802910
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
N. NON-STANDArD SprING HOLDer
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
MONARCH PUMPS (Div. of FRANKLIN ELECTRIC CO., INC.)
PS-200 A 1 1.250 5/8 BMFJF 240160
PS-200V-CMS A 1 1.250 5/8 VCFJF ATH, AT600 240136
PS-851 A 1 1.375 3/4 BCFJF 240260
PS-201 A 1 1.375 3/4 BMFJF 240170, MS17
PS-201V-CMS A 1 1.375 3/4 VCFJF BSGF 6&8, B2U 240344, MS44
PS-460 D 1 1.625 1 BCFKF 240060
PS-185 C 1 1.875 1-1/4 BCFJF 240070
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 8BSGF 240359
PS-186 D 1 2.000 1-3/8 BCDKF 240367
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 240362
PS-3972 K 3 2.500 1-1/2 VLFLF
2.125
PS-448 C 1 2.500 1-3/4 BCFKF 240120
PS-436V C 3 2.500 1-3/4 VCFKF 240387
PS-835 D 3 3.375 2-1/2 BCDJF 240363
PS-838 E 3 3.500 2-3/4 V/BCFJF 240290
MONTGOMERY WARD
PS-358 C 1 1.375 3/4 BCFJF 24181
MORETRENCH
PS-7766 K 3 3.125 2-1/4 BCFJF
MOYNO, INC.
PS-631 C 1 1.000 1/2 BCFJF N
PS-1002 C 1 1.000 1/2 BCFJF 3204215000
PS-4214 C 1 1.000 1/2 BCFJF 3206480000
PS-1002-EPR C 1 1.000 1/2 QCFJF 3206497000
PS-1002V C 1 1.000 1/2 VCFJF 3206037000
PS-200 A 1 1.250 5/8 BMFJF
PS-359 C 1 1.250 5/8 BCFJF 3202424000
PS-1119 C 1 1.250 5/8 BCFJF EM & EC Pumps 3202423000
PS-359-EPR-CMS C 1 1.250 5/8 QCFJF 3206379000
PS-359V-CMS C 1 1.250 5/8 VCFJF 3206501000
PS-633V-TC-SC C 3 1.250 5/8 VZFLF
PS-851 A 1 1.375 3/4 BCFJF 48-65C 3201625000
PS-358 C 1 1.375 3/4 BCFJF 3203945000
PS-5723 C 1 1.575 25MM QCFLF 316SS 4230509001
PS-360 A 1 1.625 1 BCFJF EC-67
PS-548 C 3 1.625 1 BCFJF 3201750000
PS-380 D 1 1.625 1 BCFJF
PS-262 E 3 2.500 1-3/4 BCFKF
PS-3158 G 25 63MM 45MM VLFLF 4241749045
MP PUMPS, INC.
PS-4055 A 1 1.000 5/16 BCFJF 33976
PS-114 A 1 1.000 5/16 BMDJF
PS-162 A 1 1.000 1/2 BMFJF 21609
PS-165 B 9 .906 1/2 BMFJF A
PS-113 B 1 1.093 5/8 BMFJF 13385
PS-447V B 8 — 5/8 VCFJF A Model 2430 21580
PS-358 C 1 1.375 3/4 BCFJF 15151
PS-112 C 1 1.375 3/4 BCFKF 15112
PS-128V C 3 1.375 3/4 VCFJF B 15110, 15150, 15131, 15200, 15241 26640
PS-3788 G 3 1.375 3/4 VCFJF 30061
PS-9339 W 2 1.375 3/4 TCFJF 316SS 30054
PS-703 D 1 1.500 7/8 BCDJF 9524
PS-245V-CMS C 1 1.625 1 VCFJF B/H Flomax 5 & 8 22272 - Old Style
PS-248V-CMS C 1 1.625 1 VCFKF B/H 22274
PS-380 D 1 1.625 1 BCFJF 14233
PS-4195 G 1 1.625 1 VCFJF 316SS Flomax 5 & 8 22272 - New Style
PS-604 D 1 1.750 1-1/8 BCFJF
/
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
MP PUMPS, INC. (continued)
PS-758 C 1 2.125 1-1/2 BCFJF 37203
PS-347 C 1 2.125 1-1/2 BCFJF B/H 14421, 14424
PS-347V-CMS C 1 2.125 1-1/2 VCFJF B/H Flomax 10 & 15 22361
PS-4482 C 1 2.125 1-1/2 VCFKF 22363
PS-382 D 1 2.125 1-1/2 BCFJF
PS-3992 G 1 2.125 1-1/2 VCFJF 31374
PS-7587 W 2 2.125 1-1/2 TCFJF 316SS 26565
PS-446V-CMS C 1 2.500 1-3/4 VCFJF 26685
PS-7959 D 3 2.500 1-3/4 VRFZF 26752
MTH TOOL CO., INC.
PS-3133 C 3 1.250 5/8 NCFKF 12-5013-01-478
FA-10036 C — — 7/8 VCF-F I 12-1068-01-494
PS-9317 W 2 2.000 1-3/8 TCFJF 316SS 12-1675-01-509
MURPHY DIESEL
PS-358 C 1 1.375 3/4 BCFJF MD-4090
PS-1095 C — — 1 BCF-F MD-7980B1
MUSKIN
PS-163 B 1 1.000 1/2 BMFJF 09-2001
PS-142 B 1 1.000 1/2 BMFJF 09-2013
MYERS, F.E. (See PENTAIR, INC. for Additional Part Numbers)
PS-1621 Q 9 — 1/2 BMFJF A 21607A001
PS-162 A 1 1.000 1/2 BMFJF 21607A015
PS-200 A 1 1.250 5/8 BMFJF 10840A1, A2, A3
14525A000,1425A010
16275A
PS-200V-CMS A 1 1.250 5/8 VCFJF 21181A044
PS-3845 B 8 1.299 5/8 BMFJF 25053A000
PS-359 C 1 1.250 5/8 BCFJF 22447A
PS-359V-CMS C 1 1.250 5/8 VCFJF 21181A021
PS-508 D 1 1.250 5/8 BCDJF 10840A1
PS-968 A 1 1.437 3/4 BCFJF 11416A000
PS-101 A 1 1.437 3/4 BMFJF Models H, HN, K, MHN 11416A, A2, A3
PS-902 B 9 — 3/4 BMFKF A 21579A
PS-1125 C 1 1.375 3/4 BCFJF 25370A000
PS-7514 C 1 1.437 3/4 BCFJF
PS-309 C 1 1.500 7/8 BCFJF 21576A000
PS-3907 C 1 1.500 7/8 BCFJF 21576A010
PS-3749 C 1 1.500 7/8 BCFJF 21576A011
PS-7130 C 1 1.500 7/8 BCFJF WG-20-21-15
PS-703 D 1 1.500 7/8 BCDJF Model 125 Centri-Thrift 11716A1
PS-983V C 3 1.750 1-1/8 VCFKF 21181A6
PS-204 E 1 1.750 1-1/8 BCFJF 8824A1
PS-185 C 1 1.875 1-1/4 BCFJF 22577A000
PS-185-SC-SC C 1 1.875 1-1/4 BLFLF 21181A062
PS-2208 C 1 1.875 1-1/4 BZFZF 21181A019
PS-381 D 1 1.875 1-1/4 BCFJF Model 2695 21181A016, 15218A
PS-758 C 1 2.125 1-1/2 BCFJF 22922A000, 9200011
PS-2209 C 1 2.125 1-1/2 BZFZF 21181A013
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 21181A022, 9200031
PS-659V-TC-VS-TC C 1 2.125 1-1/2 VZFZF 21181A064
PS-238 C 1 2.375 1-5/8 BCFJF 21181A032
PS-2212 C 1 2.500 1-3/4 BCFJF 22883A000
PS-446 C 1 2.500 1-3/4 BCFJF 11049-001-1
PS-237 D 1 2.500 1-3/4 BCDJF 300 FS-VG4D
PS-7138 C 1 3.125 2-1/4 BCFJF 23605A000
PS-7138-TC-TC C 1 3.125 2-1/4 BZFZF 21181A020
PS-1088 C 3 3.875 3 BCFJF B 25449A000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
NASH_ELMO (Div. of GARDNER DENVER NASH)
PS-100 A 1 1.187 5/8 BMFJF
PS-100V-CMS A 1 1.187 5/8 VCFJF PK-0389
PS-452 B 9 — 5/8 BMFJF A S1-1/4C
PS-600 B 1 1.187 5/8 BMFJF PK-0339
PS-600V-CMS B 1 1.187 5/8 VCFJF PK-0654
PS-764 A 1 1.375 3/4 BCFJF PK-0482
PS-866 E 3 1.750 1-1/8 BCFJF PK-0295, PK-0754
PS-282 U 3 1.750 1-1/8 BCFKF PK-0334
PS-177 C 1 2.000 1-3/8 BCFJF MH-50, MH-80 PK-0874
PS-177V C 3 2.000 1-3/8 VCFJF PK-2044
PS-354 E 1 2.000 1-3/8 BCFJF AL 621 PK-0475
PS-864 E 3 2.000 1-3/8 BCFJF PK-0873
PS-758 C 1 2.125 1-1/2 BCFJF PK-0791
PS-2223 C 3 2.125 1-1/2 VCFZF PK-0959
PS-382 D 1 2.125 1-1/2 BCFJF MPS-673 PK-0624
PS-817 D 3 2.125 1-1/2 BCFJF PK-0302, PK-0306
PS-305 E 1 2.125 1-1/2 BCFJF MP-40 PK-0678
PS-884 K 1 2.125 1-1/2 BCFKF MPS-40
PS-238V C 3 2.375 1-5/8 VCFJF PK-3437
PS-3125 C 3 2.500 1-3/4 BCFJF I PK-0900
PS-446V-P66 C 3 2.500 1-3/4 VCFJF I PK-1531
PS-340 C 1 2.625 1-7/8 BCFJF PK-0893
PS-338V C 3 3.000 2-1/8 VCFJF S PK-3438
PS-9122 W 2 3.000 2-1/8 TCFJF 316SS PK-2510
PS-874 D 1 3.125 2-1/4 BCDJF 1-1/2 H-6 PK-0341
PS-2089 D 3 3.125 2-1/4 BCFJF PK-0479
PS-3233 C 3 3.250 2-3/8 VCFJF 316SS PK-3439
PS-269V C 3 3.375 2-1/2 VCFJF PK-1772
PS-838 E 3 3.500 2-3/4 V/BCFJF PK-0523
PS-9314 W 2 3.500 2-3/4 TCFJF 316SS PK-3368
PS-8120 X 3 3.500 2-3/4 VCFZF 316SS PK-3181
PS-2116 C 3 3.875 3 BCFJF AD-303 PK-0937
PS-9140 W 2 3.875 3 TCFJF 316SS PK-2522
PS-9351 W 2 4.875 4 TCFJF 316SS PK-2549
NATIONAL OILWELL VARCO
PS-3143 E 3 4.375 3-1/2 VZFZF 658416102
VG-3015 EV 3 3.375 2-1/2 VZFZF 316SS Magnum™ 1 22451-1
NEPTUNE
PS-150 B — — 1/2 BMF-F Seat is Impeller
NEW BRUNSWICK SCIENTIFIC
PS-3082 C 3 .875 3/8 Q/NCFJF P0280-0072
PS-4465 C 3 1.375 3/4 VCFJF 316SS PO280-4582
PS-8036 X 5 1.383 3/4 QCFZF 316SS PO280-0120
PS-8101
X Specia
l 5 1.375 3/4 QCFZF 316SS P0280-0420
PS-8116 X 5 1.633 1 QCFZF 316SS P0280-4120
PS-8044 X 5 2.125 1-7/16 VCFZF 316SS P0280-0131
VG-3015
VG-3015
• Used in Mission™ Magnum™ 1 Mud Pumps
• Rugged design with machined 316SS retainer
and drive band
Mission™ Magnum™ is a registered trademark of
National Oilwell Varco.
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
OBERDORFER PUMPS
PS-671 B 1 .875 3/8 BMFJF IGCC Pump 32373
PS-671V-CMS B 1 .875 3/8 VCFJF
PS-1098 B 1 .875 1/2 BMFJF Model 142 32482
PS-3197 C 3 1.000 1/2 VCFJF 316SS 32772
PS-3003 G 3 1.000 1/2 BCFJF 32592
PS-642 B — — 5/8 BMF-F 4GP, 9GP, RA-TV, RB-TB A-5377, A-6019
PS-600 B 1 1.187 5/8 BMFJF 4GP, 9GP, RA-TV, RB-TB
PS-933V C — — 5/8 VCF-F 9798A
PS-4346 C 3 1.187 5/8 VCFJF 316SS 33109
PS-359 C 1 1.250 5/8 BCFJF A-5935
PS-235 C 1 1.625 1 BCFJF 32315
PS-235V-CMS C 1 1.625 1 VCFJF 32372
OHLER PUMP
PS-141 R — — 1 BCF-F
PS-235 C 1 1.625 1 BCFJF
PS-357 C 1 1.625 1 BCFKF
PS-185 C 1 1.875 1-1/4 BCFJF
PS-186 D 1 2.000 1-3/8 BCDKF
PS-209 K — — 1-3/8 BCF-F
PACER PUMPS
PS-601 B 1 1.375 3/4 BMFJF 714-11
PS-4056 B 1 1.375 3/4 QCFJF S1A150-704, S2A150-704 714-12
S2A150-975, S3A150-975
PS-601V-CMS B 1 1.375 3/4 VCFJF 714-14
PAC-FAB (PENTAIR POOL PRODUCTS, INC.)
PS-952 A 1 1.250 5/8 BCFJF AV-7 Pump 23822
PS-200 A 1 1.250 5/8 BMFJF Challenger®, Dynamite, Dynamo® 354545
Dynatron®, Pinnacle®
PS-201 A 1 1.375 3/4 BMFJF Hydropump® 354001
PACIFIC PUMPING CO. (PACO)
PS-516 A 1 1.250 5/8 BCFJF 14010242
PS-200 A 1 1.250 5/8 BMFJF SL-7101, SL-7741
K102-1, 91909744
PS-628 A 3 1.250 5/8 BMFKF K100-7, 14008630
K102-7, 91909687
91909747
PS-1618 C 1 1.250 5/8 BCFJF B 14032695
PS-2149 C 3 1.250 5/8 BCFKF B 14032688
PS-508 D 1 1.250 5/8 BCDJF SL-7100
PS-973 A 1 1.375 3/4 BCFKF K101-7, 91909722
PS-201 A 1 1.375 3/4 BMFJF K101-1, 91909719
PS-768 C 3 1.375 3/4 BCFKF 14032689
PS-112V C 3 1.375 3/4 VCFKF 14032363
PS-750 D 1 1.375 3/4 BCDJF Model 1-1/2LRV, 1-1/4JS
PS-752 D 1 1.375 3/4 BCDKF SL-7104
PS-703 D 1 1.500 7/8 BCDJF SL-7098
PS-235 C 1 1.625 1 BCFJF SL-7735
PS-380 D 1 1.625 1 BCFJF SL-7087
PS-460 D 1 1.625 1 BCFKF SL-7106
PS-754 E 1 1.625 1 BCFJF 14007521
PS-204 E 1 1.750 1-1/8 BCFJF SL-7770
PS-2122 C 1 1.875 1-1/4 BCFJF K105-1, 14032698, K107-1
91909832, 91909909
PS-185 C 1 1.875 1-1/4 BCFJF 14033710
PS-756 C 1 1.875 1-1/4 BCFKF SL-7094
PS-1109 C 3 1.875 1-1/4 BCFKF K105-7, 14032691
91909838
PS-756V C 3 1.875 1-1/4 VCFKF K107-6, 91909912
PS-1109V C 3 1.875 1-1/4 VCFKF K105-6, 14032365
91909837
PS-154 C — — 1-1/4 BCF-F 14032143
PS-361 E 1 1.875 1-1/4 BCFJF Model 2CLSU-3ALR 14007099
PS-361-P66 E 1 1.875 1-1/4 BCFJF I 14007083
PS-137 E 1 1.875 1-1/4 BCFKF SL-8102
PS-1183-P66 E 3 1.875 1-1/4 BCFKF I 14008102
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
PACIFIC PUMPING CO. (PACO) (continued)
PS-137V-P66 E 3 1.875 1-1/4 VCFKF I K600-6, 91911824
PS-3974 DB 1 1.875 1-3/8 BCFJF 14007089
PS-758 C 1 2.125 1-1/2 BCFJF
PS-371 D 1 2.125 1-1/2 BCFKF
PS-2106 E — — 1-1/2 BCF-F 14010219
PS-305 E 1 2.125 1-1/2 BCFJF SL-8223
PS-374 E 1 2.125 1-1/2 BCFKF
PS-2108 C — — 1-3/4 BCF-F 14032145, 14032355
PS-446 C 1 2.500 1-3/4 BCFJF 91909802
PS-2142 C 1 2.500 1-3/4 BCFJF K104-1, 14032700
PS-2150 C 3 2.500 1-3/4 BCFJF K106-1, 91909874
K108-1, 91909944
PS-2151 C 3 2.500 1-3/4 BCFKF K303-7, 14032693
PS-2151V C 3 2.500 1-3/4 VCFKF K106-6, 91909878
K108-6, 91909947
PS-2151V-TC-SEAT C 3 2.500 1-3/4 VCFZF 14032384
PS-205 E 1 2.500 1-3/4 BCFJF Model 3CLSU SL-7090, 14007090
PS-366 E 1 2.500 1-3/4 BCFKF SL-8398
PS-262 E 3 2.500 1-3/4 BCFKF KP3014-516 K307-71, 14008148
14008650,14009965
29-5015-47001
PS-449 K 1 2.500 1-3/4 BCFJF 14033023
FA-1875 C — — 1-7/8 BCF-F 14033944
PS-3070 DB 3 2.500 1-7/8 BCDJF
FA-513V E — — 1-7/8 VCF-F 14034032
FA-2000 C — — 2 BCF-F 14032146
PS-479 E 1 2.750 2 BCFJF K602-1, 91911836
PS-843 E 1 2.750 2 BCFKF K602-7, 91911839
PS-530 E 3 2.750 2 BCFJF K602-6, 91911838
PS-477 E 3 2.750 2 BCFKF
PS-3537 C 1 3.125 2-1/4 BCFJF 14032701
PS-3041 C 3 3.125 2-1/4 BCFKF 14032694
PS-323 E 1 3.125 2-1/4 BCDJF 14001709, 14007709
PS-351 E 1 3.125 2-1/4 BCDKF 14017123, 29-60122-47001
K308-71
PS-1688 E 3 3.125 2-1/4 BCFJF K111-1, 91910192
PS-2094V E 3 3.125 2-1/4 VCFKF K111-6, 91910195
PS-8089 XB1 3 3.125 2-1/2 QCFLF
316SS/I/S
Value Guard Seal Material
Part No. Size Code Old Paco No. New Paco No.
PACIFIC PUMPING CO. (PACO) - Replacement Seal Kits for End Suction Pumps
VGK-1006 5/8 BCFJF K100-1 91909684
VGK-1007 5/8 VCFKF K100-6 91909686
VGK-1008 5/8 BCFKF K100-7 91909687
VGK-1012 5/8 BMFJF K102-1 91909744
VGK-1013 5/8 VCFKF K102-6 91909746
VGK-1014 5/8 BCFKF K102-7 91909747
VGK-1009 3/4 BMFJF K101-1 91909719
VGK-1010 3/4 VCFKF K101-6 91909721
VGK-1011 3/4 BCFKF K101-7 91909722
VGK-1054 7/8 BCFJF K1503-1 91910735
VGK-1018 1-1/4 BCFJF K105-1 91909832
VGK-1019 1-1/4 VCFKF K105-6 91909837
VGK-1020 1-1/4 BCFKF K105-7 91909838
VGK-1024 1-1/4 BCFJF K107-1 91909909
VGK-1025 1-1/4 VCFKF K107-6 91909912
VGK-1026 1-1/4 BCFKF K107-7 91909913
VGK-1061 1-1/4 BCFJF K453-1 91911801
VGK-1062 1-1/4 VCFKF K453-6
VGK-1063 1-1/4 BCFKF K453-7
VGK-1070 1-1/4 BCFJF K600-1 91911821
VGK-1071 1-1/4 VCFKF K600-6 91911824
VGK-1072 1-1/4 BCFKF K600-7 91911825
VGK-1073 1-1/4 BCFJF K601-1 91911832
VGK-1074 1-1/4 VCFKF K601-6 91911834
VGK-1075 1-1/4 BCFKF K601-7 91911835
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Material
Part No. Size Code Old Paco No. New Paco No.
PACIFIC PUMPING CO. (PACO) - Replacement Seal Kits for End Suction Pumps (continued)
VGK-1079 1-1/4 BCFJF K607-1
VGK-1080 1-1/4 VCFKF K607-6 91911848
VGK-1081 1-1/4 BCFKF K607-7
VGK-1082 1-1/4 BCFJF K608-1
VGK-1083 1-1/4 VCFKF K608-6 91911850
VGK-1084 1-1/4 BCFKF K608-7
VGK-1058 1-1/4 BCFJF K1815-1 91910839
VGK-1059 1-1/4 VCFKF K1815-6 91910841
VGK-1060 1-1/4 BCFKF K1815-7 91910842
VGK-1055 1-3/8 BCFJF K1575-1
VGK-1056 1-3/8 VCFKF K1575-6
VGK-1057 1-3/8 BCFKF K1575-7 91910804
VGK-1015 1-3/4 BCFJF K104-1 91909802
VGK-1016 1-3/4 VCFKF K104-6 91909805
VGK-1017 1-3/4 BCFKF K104-7 91909806
VGK-1021 1-3/4 BCFJF K106-1 91909874
VGK-1022 1-3/4 VCFKF K106-6 91909878
VGK-1023 1-3/4 BCFKF K106-7 91909879
VGK-1027 1-3/4 BCFJF K108-1 91909944
VGK-1028 1-3/4 VCFKF K108-6 91909947
VGK-1029 1-3/4 BCFKF K108-7 91909948
VGK-1033 1-3/4 BCFJF K110-1 91910149
VGK-1034 1-3/4 VCFKF K110-6 91910150
VGK-1035 1-3/4 BCFKF K110-7 91910151
VGK-1042 1-3/4 BCFJF K127-1 91910609
VGK-1043 1-3/4 VCFKF K127-6 91910611
VGK-1044 1-3/4 BCFKF K127-7 91910612
VGK-1045 1-3/4 BCFJF K128-1 91910629
VGK-1046 1-3/4 VCFKF K128-6 91910631
VGK-1047 1-3/4 BCFKF K128-7 91910632
VGK-1051 1-3/4 BCFJF K141-1 91910715
VGK-1052 1-3/4 VCFKF K141-6 91910717
VGK-1053 1-3/4 BCFKF K141-7 91910718
VGK-1064 1-3/4 BCFJF K454-1 91911802
VGK-1065 1-3/4 VCFKF K454-6
VGK-1066 1-3/4 BCFKF K454-7 91911803
VGK-1076 2 BCFJF K602-1 91911836
VGK-1077 2 VCFKF K602-6 91911838
VGK-1078 2 BCFKF K602-7 91911839
VGK-1030 2-1/4 BCFJF K109-1 91910061
VGK-1031 2-1/4 VCFKF K109-6 91910065
VGK-1032 2-1/4 BCFKF K109-7 91910066
VGK-1036 2-1/4 BCFJF K111-1 91910192
VGK-1037 2-1/4 VCFKF K111-6 91910195
VGK-1038 2-1/4 BCFKF K111-7 91910196
VGK-1048 2-1/4 BCFJF K140-1 91910707
VGK-1049 2-1/4 VCFKF K140-6 91910708
VGK-1050 2-1/4 BCFKF K140-7 91910709
VGK-1067 2-1/4 BCFJF K455-1 91911806
VGK-1068 2-1/4 VCFKF K455-6
VGK-1069 2-1/4 BCFKF K455-7
VGK-1039 2-3/4 BCFJF K112-1 91910246
VGK-1040 2-3/4 VCFKF K112-6 91910252
VGK-1041 2-3/4 BCFKF K112-7 91910250
VGK-1021 VGK-1077
Kits for Paco End Suction Pumps include
gaskets, o-rings, shaft key, impeller bolt,
impeller washer, and mechanical seal.
Loctite® is included, if required for installation.
Paco is not affiliated with U.S.Seal Mfg.
Products supplied are manufactured or
purchased by U.S.Seal Mfg. from sources
other than the company listed.
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
S. SLOTTeD MATING rING
Value Guard Seal Material
Part No. Size Code Mfg. Part No.
PACIFIC PUMPING CO. (PACO) - Replacement Seal Kits for Split Case Pumps
VGK-1000 1-3/4 BCFJF K0303-1
VGK-1000B* 1-3/4 BCFJF K0303-1
VGK-1001 1-3/4 VCFKF K0303-6
VGK-1001B* 1-3/4 VCFKF K0303-6
VGK-1002 1-3/4 BCFKF K0303-7
VGK-1002B* 1-3/4 BCFKF K0303-7
VGK-1003 1-3/4 BCFJF K0308-1
VGK-1003B* 1-3/4 BCFJF K0308-1
VGK-1004 1-3/4 VCFKF K0308-6
VGK-1004B* 1-3/4 VCFKF K0308-6
VGK-1005 1-3/4 BCFKF K0308-7
VGK-1005B* 1-3/4 BCFKF K0308-7
Kits include gaskets, o-rings, slingers, and mechanical seals.
* Kits with the letter B in the part number include the items listed above PLUS the bearings and oil seal.
Paco is not affiliated with U.S.Seal Mfg.
Products supplied are manufactured or purchased by U.S.Seal Mfg. from sources other than the company listed.
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
PAUL MUELLER CO.
PS-1002 C 1 1.000 1/2 BCFJF 9841604
PS-309 C 1 1.500 7/8 BCFJF 9842885
PS-356 C 1 1.750 1-1/8 BCFJF 9840339
PS-177 C 1 2.000 1-3/8 BCFJF 6840666
PS-4438 C 3 2.125 1-1/2 QCFZF S 560173
PEABODY-BARNES MFG.
PS-165 B 9 .906 1/2 BMFJF A 29726
PS-163 B 1 1.000 1/2 BMFJF 18189
PS-200 A 1 1.250 5/8 BMFJF For Comet, Rocket Econo, 25,31,33, 11397-12839, 12703
35,48,49,50,52,102DM and 740DM
PS-359 C 1 1.250 5/8 BCFJF 18873A
PS-552 C 3 1.250 5/8 BCFJF 23701
PS-508 D 1 1.250 5/8 BCDJF 5080
PS-201 A 1 1.375 3/4 BMFJF Vertical Single and Multi Stage 152, 13110, 14017122
152DM, 202D, 202DM, 302D 302DM
and 502DM
PS-358 C 1 1.375 3/4 BCFJF 15344, 67562
PS-235 C 1 1.625 1 BCFJF 18004-30090
PS-236 E 1 1.625 1 BCFKF 8022
PS-879 K 1 1.625 1 BCFJF 64434
PS-4301 K 1 1.625 1 BLFLF/ 064434SD
BCFJF
PS-185 C 1 1.875 1-1/4 BCFJF Models 18ACG, 18, 19, 23 & 26 CCG 70713
PS-598 C 3 1.875 1-1/4 BCFKF 3TACG Int 1020 33289
PS-383 D 1 1.875 1-1/4 BCFKF 12074
PS-4282 K 1 1.875 1-1/4
BL/CFL/JF
39485SD
PS-1118 K 1 1.875 1-1/4 B/HCFJF 39485
PS-7323 K 1 1.875 1-1/4
BZ/CFZ/JF
60817
PS-228 K 3 1.875 1-1/4 BCFKF Model 3TCCG 25328A
PS-3230 C 1 2.000 1-3/8 NCFJF 52601
PS-547 C 3 2.000 1-3/8 BCFKF 39463
PS-758 C 1 2.125 1-1/2 BCFJF 24998
PS-553 C 3 2.125 1-1/2 BCFKF 31000
PS-2062 D 3 2.500 1-3/4 BCFKF 13301
PS-2237 K 1 2.625 1-7/8 BCFJF 51938
PS-3753 K 1 2.625 1-7/8
BL/CFL/JF
0608181SD
PS-332 C 3 2.750 2 BCFKF 53626
VGK-1003
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
PEERLESS
PS-162 A 1 1.000 1/2 BMFJF 2665554
PS-100 A 1 1.187 5/8 BMFJF
PS-200 A 1 1.250 5/8 BMFJF 2658090
PS-300 A 1 1.250 5/8 BMFJF Convertible & Single Stage Jet 2655294-V12271
Water King 1181377-2665624
PS-637 A 3 1.250 5/8 BMFJF 26922-69 000
PS-263 D 1 1.187 5/8 BCDKF 2675336
PS-508 D 1 1.250 5/8 BCDJF 2666910
PS-301 A 1 1.375 3/4 BMFJF Single Stage Jet: J2G, J3G 1J, 2J, 2655293, 26650131
3J, 15J, 75J,1GJ
PS-750 D 1 1.375 3/4 BCDJF 2655888, 2663071
PS-265 D 3 1.375 3/4 BCDKF
PS-303 D 1 1.500 7/8 BCDKF 2655239, 2664873
PS-250 D 3 1.500 7/8 BCDKF 2675339, 269042101
PS-188 E 1 1.500 7/8 BCFJF 2663072, 2657110
PS-229 E 3 1.500 7/8 BCFKF 2675338
PS-778 A 3 1.625 1 BCFKF 2692914
PS-380 D 1 1.625 1 BCFJF PE-200, PE-300, PE-500 Fluidyne
PS-252 D 3 1.625 1 BCFKF 2664873, 269042102
PS-252-EPR D 3 1.625 1 QCFKF 2675341 000
PS-754 E 1 1.625 1 BCFJF 2655887
PS-251 E 3 1.625 1 BCFKF 2675340, 2656324
PS-801 C 3 1.750 1-1/8 B/VCFJF 269987501000
PS-529 C 3 1.750 1-1/8 BCFKF 269794701000
PS-983V-TC-TC C 3 1.750 1-1/8 VZFZF
PS-604 D 1 1.750 1-1/8 BCFJF 2658071
PS-605 D 1 1.750 1-1/8 BCFKF TVB-58, Turbine Vane Pump 2655131
PS-254 D 3 1.750 1-1/8 BCFKF 2675344, 2655131
PS-204 E 1 1.750 1-1/8 BCFJF 2663077
PS-253 E 3 1.750 1-1/8 BCFKF Model 300-90 2675343, 2664886
2675317
PS-306 E 1 1.875 1-3/16 BCDJF 2655886
PS-255 E 3 1.875 1-3/16 BCDKF 2675345, 269042103
PS-1109-CER C 3 1.875 1-1/4 BCFJF 269986601 000
PS-1109 C 3 1.875 1-1/4 BCFKF 2687165 000
PS-1109-EPR C 3 1.875 1-1/4 QCFKF 2687626 000, 2687926 000
PS-2122V C 3 1.875 1-1/4 VCFJF 269986602 000
PS-1109V C 3 1.875 1-1/4 VCFKF 268716501
PS-361 E 1 1.875 1-1/4 BCFJF PB-3, 3 x 4 x 10
PS-256 E 3 1.875 1-1/4 BCFKF 2664893, 2675347
PS-264 E 3 1.875 1-1/4 BCFKF 2675318, 2687266
PS-547 C 3 2.000 1-3/8 BCFKF 269794702
PS-354 E 1 2.000 1-3/8 BCFJF 2655089, 2663075
PS-677 E 1 2.000 1-3/8 BCFKF 2663368, 2675349
PS-257 E 3 2.000 1-3/8 BCFKF 2675350
PS-1110 C 3 2.125 1-1/2 BCFKF F2-1044AM,1230AM, 1240AM, 3AE14 2687166 000
PS-2221 C 3 2.125 1-1/2 QCFKF 2691073
PS-1110V C 3 2.125 1-1/2 VCFKF 268716607
PS-2223-SC-SEAT C 3 2.125 1-1/2 VCFLF 505123B7
PS-382 D 1 2.125 1-1/2 BCFJF 2656981, 2675353
FA-10167 E — — 1-1/2 BCF-F I 2689751 000
PS-305 E 1 2.125 1-1/2 BCFJF 2663008, 2675108
PS-258 E 3 2.125 1-1/2 BCFKF 2675351, 2691073
PS-259 E 3 2.125 1-1/2 BCFKF 2675352
PS-550 C 3 2.500 1-3/4 BCFJF 269359803 000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
PEERLESS (continued)
PS-436 C 3 2.500 1-3/4 BCFKF AD IV-V 2693598 000
PS-436-EPR C 3 2.500 1-3/4 QCFKF 2675319 000
PS-825 D 3 2.500 1-3/4 BCDKF PE-Pumps 2675356
PS-2109 E — — 1-3/4 BCF-F 2689752 000
PS-205 E 1 2.500 1-3/4 BCFJF 2663044
PS-535 E 3 2.500 1-3/4 BCFJF MTP Frame
PS-262 E 3 2.500 1-3/4 BCFKF 2675355
PS-262-EPR-P66 E 3 2.500 1-3/4 QCFKF I 2675354 000
PS-2114 C 3 2.625 1-7/8 BCFJF 269987701 000
PS-312 C 3 2.625 1-7/8 BCFKF 269794703
PS-2072 E 3 2.625 1-7/8 BCFKF Type AD Fig. 5130 2676205
PS-332 C 3 2.750 2 BCFKF Type AD Group IV, 8AE-12 2693599 000, 504293
PS-477-EPR E 3 2.750 2 QCFKF
PS-353 E 1 3.000 2-1/8 BCFKF Model 6A-16
PS-327 E 3 3.000 2-1/8 BCFJF Model 6A-16
PS-1676 C 3 3.125 2-1/4 BCFKF 2692217 000
PS-492 C 3 3.250 2-3/8 BCFKF 2693666 000
PS-4325 C 3 3.250 2-3/8 VCFLF I Model 6AE18
PS-483 C 3 3.500 2-3/4 BCFKF 2693601 000
PS-475 E 3 3.875 3 BCDKF
Value Guard Seal Material
Part No. Size Code Mfg. Part No.
PEERLESS - Replacement Seal Kits
VGK-1123 1-1/4 BCFJF BSE-2 (Ceramic)
VGK-1090 1-1/4 BCFKF BSE-2 (Ni-Resist)
VGK-1120 1-1/4 VCFJF BSE-2 (Vit / Cer)
VGK-1092 1-1/4 VCFKF BSE-2 (Vit / Nir)
VGK-1121 1-1/2 BCFJF BSE-3 (Ceramic)
VGK-1091 1-1/2 BCFKF BSE-3 (Ni-Resist)
VGK-1122 1-1/2 VCFJF BSE-3 (Vit / Cer)
VGK-1093 1-1/2 VCFKF BSE-3 (Vit / Nir)
VGK-1133 1-1/4 BCFJF ISE-2 (Ceramic)
VGK-1132 1-1/4 BCFKF ISE-2 (Ni-Resist)
VGK-1135 1-1/4 VCFJF ISE-2 (Vit / Cer)
VGK-1134 1-1/4 VCFKF ISE-2 (Vit / Nir)
VGK-1137 1-1/2 BCFJF ISE-3 (Ceramic)
VGK-1136 1-1/2 BCFKF ISE-3 (Ni-Resist)
VGK-1138 1-1/2 VCFJF ISE-3 (Vit / Cer)
VGK-1139 1-1/2 VCFKF ISE-3 (Vit / Nir)
Kits include gaskets, sleeve, impeller bolt, impeller washer, key, and mechanical seal.
Peerless is not affiliated with U.S.Seal Mfg.
Products supplied are manufactured or purchased by U.S.Seal Mfg. from sources other than the company listed.
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
PELLERIN MILNOR CORP. - (Laundry Equipment)
PS-750 D 1 1.375 3/4 BCDJF 24S020
PENBERTHY INJECTOR
PS-162 A 1 1.000 1/2 BMFJF D-1104
PS-165 B 9 .906 1/2 BMFJF A
PS-1112 Q 9 — 1/2 BMFJF A 14036
VGK-1090
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
PENTAIR, INC. (See AURORA, BERKELEY, FAIRBANKS MORSE, HYDROMATIC,
HYPRO, MYERS, F.E., STA-RITE)
PS-359 C 1 1.250 5/8 BCFJF 01556-000-1
PS-633-TC-TC C 1 1.250 5/8 BZFZF 21181A024
PS-358 C 1 1.375 3/4 BCFJF 100001
PS-4020 G 1 1.375 3/4 BCFJF 145730001
PS-2216V-CMS C 1 1.625 1 VZFZF 00300-002-1
PS-185 C 1 1.875 1-1/4 BCFJF 22577A000
PS-185-SC-SC C 1 1.875 1-1/4 BLFLF 049160031
PS-2208 C 1 1.875 1-1/4 BZFZF 21181A019
PS-466 C 1 2.000 1-1/4 BCFJF 21181A031
PS-758-SC-TC-CMS
C 1 2.125 1-1/2 BLFZF 00920-011-1
PS-2209 C 1 2.125 1-1/2 BZFZF 00920-004-1
PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 00920-005-1 / 00920-007-1
PS-758V-SC-SC C 1 2.125 1-1/2 VLFLF 00920-010-1
PS-6224 C 1 2.750 2 VLFLF 24509585920
PS-1088-TC-TC-CMS
C 1 3.875 3 BZFZF B 25449A001
PS-1088V-TC-TC-CMS
C 1 3.875 3 VZFZF B 37180021
PS-1088V C 3 3.875 3 VCFJF B 37180051
PENTAIR POOL PRODUCTS
PS-200 A 1 1.250 5/8 BMFJF 354545S
PS-961 B 1 1.250 5/8 BCFJF 071734S, 071734-SP
PS-4352 C 3 3.875 3 BLFZF B 60 MPH & 60 MMPH 037180041
PERFECTING (Div. of DUFF-NORTON)
PS-359 C 1 1.250 5/8 BCFJF 732015
PS-356 C 1 1.750 1-1/8 BCFJF 732049
PS-177 C 1 2.000 1-3/8 BCFJF 732057
PESCO
PS-507 A 1 1.250 5/8 BMFKF
PFAUDLER, INC.
PS-3893 C 3 Special 1.500 7/8 VCFGF 3515444
PS-356 C 1 1.750 1-1/8 BCFJF 1621492
PS-758 C 1 2.125 1-1/2 BCFJF 1621350
PS-3943 C 3 Special 2.125 1-1/2 VCFGF 3512911
PS-3584 C 3 Special 2.000 1-3/8 VCFGF 3512910
PHILLIPS GASKET (See CATERPILLAR)
PIONEER (See DETROIT HARVESTER HOWELL)
PIONEER PUMP
PS-3189 D 3 3.500 2-3/4 VLFZF 316SS 730400173
PIQUA MACHINE (See ENPO-CORNELL PUMP CO.)
POWER PRODUCTS (See TECUMSEH PRODUCTS CO.)
PRECISION SCIENTIFIC
PS-1043 C 1 1.000 1/2 BMFJF 342005
PS-732 C 3 1.250 5/8 BCFKF 342003
PS-1113 C 1 1.375 3/4 BCFKF 342027
PS-499 C 3 1.625 1 BCFKF 342012
PREMIER
PS-201 A 1 1.375 3/4 BMFJF Series 120T, MKII 225/255, 300 31-812
325/355, 725/756
PS-1000 B 1 1.250 5/8 BMFJF Series 220/225 (Pre 1988), 455/456 31-813
500, 600
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
H. SprING HOLDer NOT INCLUDeD
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
PRICE PUMP CO.
PS-1002V C 1 1.000 1/2 VCFJF Model S95M
PS-516 A 1 1.250 5/8 BCFJF 0118
PS-447 B 8 — 5/8 BCFJF A Models SE100, E100B, PRYCO-50, 0538
75, 95
PS-3159 B 8 — 5/8 BCFJF A 0538
PS-447V B 8 — 5/8 VCFJF A 0539
PS-4479 B 9 1.109 5/8 QCFJF A 0383
PS-359 C 1 1.250 5/8 BCFJF 0841
PS-4272V C 1 1.250 5/8 VCFJF 316SS Model “S” Motor Pumps 0553
PS-4155 G 1 1.250 5/8 VLFLF 0541
PS-3885 K 1 1.178 5/8 VCFJF 0985
PS-9155 W 2 1.250 5/8 TLFLF 316SS Model LT-25
PS-201 A 1 1.375 3/4 BMFJF Model SP-15
PS-601 B 1 1.375 3/4 BMFJF PRYCO-100, 125, 150
PS-358 C 1 1.375 3/4 BCFJF 1112
PS-3191 C 1 1.375 3/4 VCFJF 316SS 0549
PS-1094 C 1 1.625 1 VCFJF 8304-211
PS-758 C 1 2.125 1-1/2 BCFJF Models E150, E200
PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 0122
PS-7587 W 2 2.125 1-1/2 TCFJF 316SS 0123
PS-446-EPR C 1 2.500 1-3/4 QCFJF 3724
PS-446V-CMS C 1 2.500 1-3/4 VCFJF 3516
PROCON PRODUCTS
PS-4060 G 1 1.181 7/16 BCFJF 1034-A7
PS-4061 G 1 1.181 7/16 QCFJF For Home Water Systems 1034-A4W
PS-4062 G 1 1.181 7/16 QCFJF 1034-A4
PS-4063 G 1 1.181 7/16 VCFJF 1034-A2
PROSSER PUMP (Div. of CRANE PUMPS & SYSTEMS)
PS-1002 C 1 1.000 1/2 BCFJF 558312-2, 558312-21
PS-359 C 1 1.250 5/8 BCFJF 5 HP 2-31001
PS-3915 C 1 1.250 5/8 BCFJF H
PS-3916 C 3 1.375 3/4 BCFJF
PS-3907 C 1 1.500 7/8 BCFJF 2-31006
PS-185 C 1 1.875 1-1/4 BCFJF 2-31020
PS-756 C 1 1.875 1-1/4 BCFKF 25 and 40 HP Model 9-26032-3
PULSAFEEDER (Div. of IDEX CORP.)
PS-1065 C 3 .875 3/8 BCFJF 307328
PS-1065V C 3 .875 3/8 VCFJF Y0900921-316 with
Y1000521-000
FA-10033 C — — 1/2 VCF-F Y0900121-316
PS-933V C — — 5/8 VCF-F Y0900421-316
PS-552 C 3 1.250 5/8 BCFJF Model 2-17 Type 107 307414
PUREX / HYDROTECH
PS-100 A 1 1.187 5/8 BMFJF L Series™ P28280
PS-952 A 1 1.250 5/8 BCFJF AV-7 Pump P23822
PS-501 A 1 1.250 5/8 BMFJF Aquatron® 071733
PS-3202 B 1 1.250 5/8 QCFJF
PS-3865R B 1 1.250 5/8 VCFJF Whisperflo® 071734
PS-201 A 1 1.375 3/4 BMFJF AH Series™, L Series™ 071728
PS-360 A 1 1.625 1 BCFJF C Series 071725
QUINCY COMPRESSOR
PS-6090 E 3 2.500 1-3/4 B/VCFKF 22578-1
PS-2152V C 3 3.500 2-3/4 VCFKF 22592-1
PS-6177 C 3 4.250 3-3/8 VCFKF 22593-1
RAINBOW IRRIGATION PUMPS
PS-185 C 1 1.875 1-1/4 BCFJF 14821
PS-446 C 1 2.500 1-3/4 BCFJF 13470
RAPID DAYTON (See TAIT)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
RED JACKET (VEEDER- ROOT CO.)
PS-106 C 1 1.000 1/2 BCFKF Deep and Shallow Well Type A & B 540
Multi Stage Pumps Models 25A, 33A,
50A, 75A, 100A
PS-518 A 1 1.187 5/8 BCFKF 076-183
PS-100 A 1 1.187 5/8 BMFJF SW-DW Jet Pump C76-78A, C76-98A
C176-037
PS-701 A 1 1.187 5/8 BMFKF C76-134
PS-711 A 3 1.187 5/8 BMFJF 076-182
PS-493 C 1 1.187 5/8 BCFKF For Centri-Jet “R” and Centri-Jet V 500
25R, 33R, 50R, 75R, 100, 101,150, 151
PS-102 D 1 1.250 5/8 BCDKF Deep Well & Shallow Well Type H, 530
Models 25H, 33H, 50H, 75H, 100H
PS-201 A 1 1.375 3/4 BMFJF 76-129, 76-189
PS-902 B 9 — 3/4 BMFKF A Centri Jet X Pumps 33X and 50X C76-99A, 555
“CJ”, “CJM”, and “SJ” Pumps
PS-750 D 1 1.375 3/4 BCDJF All Types HB Centrifugal Jet Pumps 560
PS-370 A 1 1.625 1 BCFKF 76-132
PS-460 D 1 1.625 1 BCFKF 545
REDA PUMP
PS-508 D 1 1.250 5/8 BCDJF 17197A
PS-188 E 1 1.500 7/8 BCFJF 13131A
PS-703 D 1 1.500 7/8 BCDJF 14011A
PS-380 D 1 1.625 1 BCFJF 13977A
PS-382 D 1 2.125 1-1/2 BCFJF 15114A
REXNORD INDUSTRIES, LLC.
PS-201 A 1 1.375 3/4 BMFJF X7718
PS-578 D — — 7/8 BCD-F X203565
PS-188 E 1 1.500 7/8 BCFJF X203224
PS-141 R — — 1 BCF-F X6185
PS-154 C — — 1-1/4 BCF-F X7387
PS-185 C 1 1.875 1-1/4 BCFJF X8023
PS-137 E 1 1.875 1-1/4 BCFKF X203691
PS-169 K — — 1-1/4 BCF-F X6186
PS-172 C — — 1-3/8 BCF-F X7389
PS-177 C 1 2.000 1-3/8 BCFJF X2U59-1
PS-209 K — — 1-3/8 BCF-F X6187
PS-223 D — — 1-7/8 BCD-F X7235
PS-593 D 3 2.625 1-7/8 BCDKF X2U59-6
PS-196 D — — 2 BCD-F X7380
RICE
PS-200 A 1 1.250 5/8 BMFJF 21-024
PS-201 A 1 1.375 3/4 BMFJF 12-023
PS-750 D 1 1.375 3/4 BCDJF 0330-9-6
ROBBINS & MYERS (See MOYNO, INC.)
ROMAR FILTER
PS-200 A 1 1.250 5/8 BMFJF 618-001
ROPER PUMP CO.
PS-1050 C — — 1/2 BCF-F G3-29, G14-263
PS-400 C — — 1/2 BMF-F G14-222-403, G14-263X
FA-10033 C — — 1/2 VCF-F G14-32
PS-933 C — — 5/8 BCF-F G14-116
PS-933V C — — 5/8 VCF-F G14-13
PS-633 C 1 1.250 5/8 BCFKF G14-225
PS-564 C — — 3/4 BCF-F G14-117
PS-768 C 3 1.375 3/4 BCFKF G14-226
PS-112V C 3 1.375 3/4 VCFKF G14-471
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
ROPER PUMP CO. (continued)
PS-752 D 1 1.375 3/4 BCDKF G14-261, G14-266
PS-208 C — — 7/8 BCF-F G14-324
PS-617 C 3 1.500 7/8 BCFKF G14-227
PS-687V C 3 1.500 7/8 VCFKF G14-477
PS-703 D 1 1.500 7/8 BCDJF
PS-935 E 1 1.500 7/8 BCFKF 316SS
PS-397 C — — 1 BCF-F G14-320
PS-397V C — — 1 VCF-F G14-51
PS-235 C 1 1.625 1 BCFJF G14-338X
PS-499 C 3 1.625 1 BCFKF Model 1AM-27 G14-338
PS-3220 C 3 1.625 1 BCFKF G4-397
PS-499-EPR C 3 1.625 1 QCFKF G14-312
PS-357V C 3 1.625 1 VCFKF
PS-7207 C 3 1.750 1 VCFKF Model P2-C1219
PS-3619 C 3 1.750 1 VCFKF G-4-398
PS-937 E — — 1 BCF-F G14-120, G14-250
PS-236 E 1 1.625 1 BCFKF G14-343
PS-891 K 1 1.625 1 BCFKF G4-94
PS-2155 C 3 1.750 1-1/16 BCFKF G4-101, G14-489
PS-127 D 1 1.750 1-1/16 BCDKF G14-288
PS-348 C — — 1-1/8 BCF-F G14-278, G4-334
PS-529 C 3 1.750 1-1/8 BCFKF G4-313
PS-355V C 3 1.750 1-1/8 VCFKF G4-15, G4-375
PS-154 C — — 1-1/4 BCF-F G14-429
PS-10040 C — — 1-1/4 VCF-F G3-10, G3-36
PS-756 C 1 1.875 1-1/4 BCFKF
PS-598 C 3 1.875 1-1/4 BCFKF
PS-416 D — — 1-1/4 BCF-F G14-121, G14-122
PS-172 C — — 1-3/8 BCF-F G14-512
PS-172V C — — 1-3/8 VCF-F G14-510
PS-467 C 1 2.125 1-3/8 BCFKF G14-579
PS-186 D 1 2.000 1-3/8 BCDKF G14-248
PS-2156 C 3 2.250 1-7/16 BCFKF G4-112
PS-2156V C 3 2.250 1-7/16 VCFKF G4-142
FA-1850 C — — 1-1/2 BCF-F G14-430
FA-10043 C — — 1-1/2 VCF-F G3-35
PS-553 C 3 2.125 1-1/2 BCFKF G4-267, G14-230
PS-7975 C 3 2.125 1-1/2 VCFKF S G4-75, G14-475
PS-939 D — — 1-1/2 BCF-F G14-123, G14-124
PS-371 D 1 2.125 1-1/2 BCFKF
PS-1145 C 3 2.750 2 VCFKF G4-46
PS-543V C 3 3.000 2-1/8 VCFKF G4-41
PS-1676V C 3 3.125 2-1/4 VCFKF
PS-942 D — — 2-1/4 BCD-F G14-125
PS-941 D 1 3.125 2-1/4 BCDKF G14-223
ROTARY COMPRESSION TECHNOLOGIES, INC.
PS-460V D 3 1.625 1 VCFKF S 125.988
PS-4431 D 3 1.875 1-1/4 VLFLF 125.983.1
PS-436V C 3 2.500 1-3/4 VCFKF 125.693.2
PS-1676V C 3 2.125 2-1/4 VCFKF 125.927
ROTH PUMP CO.
PS-1120 C 1 1.062 1/2 BCFJF Size 00-100 F8A030VF
PS-118 C 1 1.187 5/8 BCFJF Size 0 and 10 F8B015VF / 086VL
PS-188 E 1 1.500 7/8 BCFJF FZD204FC
PS-348V C — — 1-1/8 VCF-F F8E011UF
PS-7884V EB 3 2.500 1-7/8 VCFKF F7J2002FS
FA-10047 C — — 2 VCF-F F8H056UF
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
Value Guard Seal Material
Part No. Head Size Code Head Part No. Mfg. Part No.
ROTO-JET®
VG-3001 VGXAB 2-1/2 VLFZF 06604721JC 0652046-002
VG-3002 VGXAB 2-1/2 VZFZF 060754067 0652046-002
Type VGXAB
• Roto-Jet® pumps are used in high pressure wash systems.
RUTH BERRY
PS-102 D 1 1.250 5/8 BCDKF 610
PS-201 A 1 1.375 3/4 BMFJF 601, 601A
PS-750 D 1 1.375 3/4 BCDJF 620
RUTHMAN COMPANIES
PS-164 B 9 — 1/2 BMFKF A Model 55-4520 906
PS-165 B 9 .906 1/2 BMFJF A
PS-452 B 9 — 5/8 BMFJF A
PS-633 C 1 1.250 5/8 BCFKF
PS-902 B 9 — 3/4 BMFKF A
PS-360 A 1 1.625 1 BCFJF
PS-235 C 1 1.625 1 BCFJF
SCHAUB ENGINEERING CO.
PS-493 C 1 1.187 5/8 BCFKF 12-3113-001
PS-1123 C 1 1.625 1 BCFKF 12-3113-002
PS-598 C 3 1.875 1-1/4 BCFKF 12-3113-003
SCOT PUMP (Div. of ARDOX CORP.)
PS-516 A 1 1.250 5/8 BCFJF 101.000.110C
118.000.102, 118.000.110
PS-952 A 1 1.250 5/8 BCFJF 118.000.340
PS-200 A 1 1.250 5/8 BMFJF 101.000.340
PS-501 A 1 1.250 5/8 BMFJF 118.000.340D
PS-200V-CMS A 1 1.250 5/8 VCFJF
PS-359V-CMS C 1 1.250 5/8 VCFJF 101.000.103
PS-3550 C 1 1.250 5/8 VRFRF 101.000.239
PS-732-EPR C 3 1.250 5/8 QCFKF 101.000.173
PS-633V C 3 1.250 5/8 VCFKF 101.000.120, 101.000.316
PS-633V-P66 C 3 1.250 5/8 VCFKF I 101.000.225X
PS-9309 W 3 1.187 5/8 QRFRF 101.000.242
PS-201 A 1 1.375 3/4 BMFJF 101.000.102
PS-201V-CMS A 1 1.375 3/4 VCFJF 101.000.115
PS-112V C 3 1.375 3/4 VCFKF 101.003.171
PS-360 A 1 1.625 1 BCFJF 101.000.159
PS-185 C 1 1.875 1-1/4 BCFJF 101.000.104, 101.000.104A
PS-185-P66 C 1 1.875 1-1/4 BCFJF I 101.000.294
PS-756-EPR C 1 1.875 1-1/4 QCFKF 101.000.124C, 101.000.203
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 101.000.194
PS-756V-CMS C 1 1.875 1-1/4 VCFKF 101.000.124
PS-2203 C 3 1.875 1-1/4 QCFKF I 101.000.124A
PS-185V C 3 1.875 1-1/4 VCFJF
PS-756V C 3 1.875 1-1/4 VCFKF
PS-3872 E 1 1.875 1-1/4 QCFKF
PS-883V-CMS K 1 1.875 1-1/4 VCFJF 101.000.210
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
N. NON-STANDArD SprING HOLDer
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
SCOT PUMP (Div. of ARDOX CORP.) (continued)
PS-228V-CMS K 1 1.875 1-1/4 VCFKF 101.000.164
PS-758 C 1 2.125 1-1/2 BCFJF 101.000.168, 118.000.343
118.000.344
PS-758V C 3 2.125 1-1/2 VCFJF 101.000.175
PS-4212 C 3 2.125 1-1/2 VCFJF I 101.000.191
PS-659V C 3 2.125 1-1/2 VCFKF 101.000.182
PS-446 C 1 2.500 1-3/4 BCFJF 101.000.196
PS-446-P66 C 1 2.500 1-3/4 BCFJF I 118.000.388
PS-436V C 3 2.500 1-3/4 VCFKF 101.000.221
PS-836-CMS C 1 3.500 2-3/4 BCFJF 137.001.692
SCOTSMAN ICE SYSTEMS - (Ice Machines)
PS-380 D 1 1.625 1 BCFJF
PS-6305 Q 2 1.625 1 BMDAF 02-1300-01, 02-1300-01BK
PS-4133 Q Special 2.500 1-3/4 Special 02-0929-02
SCREW COMPRESSOR TECH
PS-6098 C
3 Special
2.625 1.875 VCFKP S 4470026
SEEPEX, INC.
PS-3158 G 25 63MM 45MM VLFLF GRDJ33045AS1S1
SERFILCO
PS-1002 C 1 1.000 1/2 BCFJF 55-434
PS-358 C 1 1.375 3/4 BCFJF 55-407
PS-309 C 1 1.500 7/8 BCFJF 55-488
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 55-481
SETHCO (Div. of MET-PRO CORP)
PS-1050 C — — 1/2 BCF-F 760P04-320
PS-1002V C 1 1.000 1/2 VCFJF
PS-359 C 1 1.250 5/8 BCFJF
PS-801 C 3 1.750 1-1/8 B/VCFJF 760P101-180
PS-356V C 3 1.750 1-1/8 VCFJF 760P101-181
SHERWOOD BRASS
PS-631 C 1 1.000 1/2 BCFJF N 5789
PS-1002 C 1 1.000 1/2 BCFJF 10522
PS-200 A 1 1.250 5/8 BMFJF 10159
PS-447 B 8 — 5/8 BCFJF A 12859
PS-452 B 9 — 5/8 BMFJF A 8388
PS-508 D 1 1.250 5/8 BCDJF 10523
PS-578 D — — 7/8 BCD-F 8570
PS-703 D 1 1.500 7/8 BCDJF 8578
PS-188 E 1 1.500 7/8 BCFJF 9791
SHIPPENSBURG PUMP CO., INC. (SHIPCO)
PS-356-EPR C 1 1.750 1-1/8 QCFJF SDPS-00155
PS-4037 C 3 1.750 1-1/8 VLFLF SDPS-00155SV
PS-185-EPR-P66 C 1 1.875 1-1/4 QCFJF I SDPS-00132
SID HARVEY INDUSTRIES, INC.
PS-1050 C — — 1/2 BCF-F
SIEMENS WATER TECHNOLOGIES
PS-4437 D 2 3.000 2-1/8 BCDKF WTU18080
SIHI PUMPS AMERICAS
PS-732 C 3 1.250 5/8 BCFKF 503750
PS-818 C 3 2.375 1-5/8 BCFJF 43092930
PS-544 C 3 2.375 1-5/8 BCFKF 501483
PS-239V C 3 2.375 1-5/8 VCFKF 502261
PS-312 C 3 2.625 1-7/8 BCFKF 501806
PS-1057 C 3 3.000 2-1/8 B/VCFKF 501980
PS-3606 C 3 3.000 2-1/8 VCFLF 43092920
PS-4133
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
H. SprING HOLDer NOT INCLUDeD
N. NON-STANDArD SprING HOLDer
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
SIMFLO PUMPS, INC.
PS-618 C 3 1.875 1-1/4 BCFJF 059-0220MA
PS-7702 EB 3 1.875 1-3/8 BCFJF 059-0180MA
PS-4159 EB 3 2.125 1-5/8 VCFJF 059-0200MA
PS-2114 C 3 2.625 1-7/8 BCFJF 059-0270MA
PS-532 C 3 2.750 2 BCFJF 059-0280MA
PS-1678 C 3 3.125 2-1/4 BCFJF 059-0290MA
PS-269 C 3 3.375 2-1/2 BCFJF 059-0300MA
PS-7703 EB 3 3.375 2-5/8 BCFJF 059-0201MA
SIMMONS PUMP CORP.
PS-200 A 1 1.250 5/8 BMFJF Model 6
PS-359 C 1 1.250 5/8 BCFJF
PS-235 C 1 1.625 1 BCFJF
SKIDMORE PUMP
PS-663 Q 1 1.000 1/2 BMFJF 50648
PS-100 A 1 1.187 5/8 BMFJF 142-54049
PS-536 C 3 1.187 5/8 BCFJF 53497
PS-359 C 1 1.250 5/8 BCFJF 50625-1
PS-290 C 1 1.250 5/8 BCFJF N 142-54099
PS-508 D 1 1.250 5/8 BCDJF 142-54052, P15, P15A
PS-309 C 1 1.500 7/8 BCFJF 142-54055, 50625-2
PS-356 C 1 1.750 1-1/8 BCFJF 142-54058, 50625-3
SMITH & LOVELESS, INC.
PS-1104 V 25 2.140 1-3/8 BCFJF Frame 25
VG-1105 HDV 1 2.640 1-7/8 BCFJF B-Shaft H60A119
VG-3315 HV 1 2.640 1-7/8 BCFJF B-Shaft H87A28
PS-1105 V 25 2.640 1-7/8 BMFJF Frame 28 H60A119
VG-3316 HV 1 3.187 2-1/8 BCFJF C-Shaft H87A97
PS-1102 V 3 3.140 2-1/8 BCFJF Frame 32
SOMAT CO. - (Ice Machines)
PS-3915 C 1 1.250 5/8 BCFJF H 54300
PS-309 C 1 1.500 7/8 BCFJF 54302
PS-801 C 3 1.750 1-1/8 B/VCFJF 54310
PS-529 C 3 1.750 1-1/8 BCFKF 54311
PS-544 C 3 2.375 1-5/8 BCFKF 54325
PS-332 C 3 2.750 2 BCFKF 54326
PS-6302 Q 1 3.375 2-1/4 BMPAP 54306
SPECIALTY PACKAGING - (Dishwashers / Disposals)
PS-539 C 1 1.625 1 BCFJF H 00-104330
PS-6318 Q 9 1.578 1-1/8 VMFAF 00-117071
PS-6317 Q 9 2.000 1-3/8 VMPSP 00-114144
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 00-223422
PS-4041 Q 1 3.375 2-1/4 VMPSP 00-117072
SPECK PUMPS
VG-200 AV 1 1.250 5/8 BMFJF 2920060603 60603-200
VGM-2920 VGMA 1 35MM 20MM BCFLF 2920343310
Type HV
Type HDV
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
STA-RITE INDUSTRIES (See PENTAIR, Inc. for Additional Part Numbers)
PS-4225 G 1 23MM 12MM QCFLF
PS-1615 B 1 1.000 3/8 BMFJF Model 297A U109-173
PS-162 A 1 1.000 1/2 BMFJF U109-103
PS-142 B 1 1.000 1/2 BMFJF
PS-163 B 1 1.000 1/2 BMFJF LT Series U109-68SS, U109-321SS
PS-4360 B 8 — 1/2 BLFLF U9-439A/B
PS-663 Q 1 1.000 1/2 BMFJF U109-100
PS-957 A 1 1.187 5/8 BCFJF U9-106SS
PS-100 A 1 1.187 5/8 BMFJF AJ Series, Dura-Glas Pre 1998, U9-469, U109-6, U109-6A
Dyna-Glas and Dyna-Max, U109-93SS, 17351-0102S
Max-E-Glass pre 1998, PLBC Series
Pre 1995, PLBC Series
PS-200 A 1 1.250 5/8 BMFJF Dura-Glas®, Max-E-Glas® 17304-0100, 17304-0100S
Series PE, PEA, P2R and P2RA 17038
PS-501 A 1 1.250 5/8 BMFJF 118-000-340
PS-1000 B 1 1.250 5/8 BMFJF CF / CFA Series, HP Series, U109-136SS
PS-3102 B 11 — 5/8 BCFJF A S20900
PS-118 C 1 1.187 5/8 BCFJF U9-102, U109-87, U109-118
PS-493 C 1 1.187 5/8 BCFKF U9-1
PS-1618 C 1 1.250 5/8 BCFJF B
PS-4267 G 1 1.187 5/8 BCFJF U9-6
PS-4404 G 1 1.187 5/8 BCFJF 316SS M13800
PS-1900 G 1 1.187 5/8 VLFLF 316SS U9-437
PS-4390 G 1 1.250 5/8 VLFLF 316SS 17304-0102
PS-851 A 1 1.375 3/4 BCFJF 37400-0027S
PS-201 A 1 1.375 3/4 BMFJF DJ/JS/JT Series Pre 01/01, Dura-Glas II U109-358SS, U109-372SS
Pre 1998, Dura-Jet, Dyna-Glas/ 17351-0101
Dyna-Max, Dyna-Jet, JW/JWPA Series,
Max-E-Glas II Pre 1998
PS-851-EPR A 1 1.375 3/4 QCFJF U109-122, 17351-0101A
PS-201V-CMS A 1 1.375 3/4 VCFJF
PS-1622 B 9 — 3/4 BMFJF A
PS-4048 B 9 1.312 3/4 BLFLF U9-394SS
PS-358 C 1 1.375 3/4 BCFJF U109-99
PS-877 C 1 1.375 3/4 BCFJF U109-267
PS-128 C 1 1.375 3/4 BCFJF B U9-99
PS-750 D 1 1.375 3/4 BCDJF U9-43
PS-4265 G 1 1.375 3/4 BCFJF 37400-27S
PS-3868 G 1 1.375 3/4 VCFJF Dura-Glass II and Max-E Glas II
(Series P4E, P4EA, P4R, P4RA)
Max-E-Pro (Series P6E & P6RA)
PS-687 C 1 1.500 7/8 BCFKF U9-18, 20, 22, 25, 29, 32
U109-21, U109-30
PS-774 C 3 1.500 7/8 BCFJF U109-170
PS-235 C 1 1.625 1 BCFJF 16504
PS-380 D 1 1.625 1 BCFJF Model-AS-H-3
PS-127 D 1 1.750 1-1/16 BCDKF U109-31
PS-204 E 1 1.750 1-1/8 BCFJF U109-96
PS-866 E 3 1.750 1-1/8 BCFJF U109-96SS
PS-867-EPR E 3 1.750 1-1/8 QCFKF U9-307
PS-185 C 1 1.875 1-1/4 BCFJF CC/C Series, D Series U109-200, U109-433SS
CC/C Series, D Series pre 8/00 S32014
CSPH / CCSPH Series
PS-246 C 1 1.875 1-1/4 BCFJF B/H CC/C Series, D Series U109-220
PS-804 D 3 1.875 1-1/4 BCFJF CC/C Series, D Series
PS-3883 G 1 1.875 1-1/4 BCFJF U9-433SS
PS-6265 G 1 1.875 1-1/4 VLFLF U9-451SS
PS-758 C 1 2.125 1-1/2 BCFJF 16554
PS-446 C 1 2.500 1-3/4 BCFJF CCPH / CCSPH Series S32015
PS-2142 C 1 2.500 1-3/4 BCFJF S32692
PS-535 E 3 2.500 1-3/4 BCFJF U109-251
PS-340 C 1 2.625 1-7/8 BCFJF S32694
PS-3211 C 1 2.625 1-7/8 BCFJF S32693
PS-327 E 3 3.000 2-1/8 BCFJF U109-252
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
/
STEIN SAM ASSOC.
PS-397 C — — 1 BCF-F 401-50-0001
FA-1850 C — — 1-1/2 BCF-F 401-50-0006
STERLING FLUID SYSTEMS
PS-4470 A 1 1.250 5/8 BMFJF 96667758
1181377000
PS-529 C 3 1.750 1-1/8 BCFKF 2697947010000
PS-1109V C 3 1.875 1-1/4 VCFKF 97630629
PS-354V E 3 2.000 1-3/8 VCFJF Lock Collar Supplied Separately 96885762
PS-865V-SC-SC E 3 2.000 1-3/8 VLFLF Lock Collar Supplied Separately 96853723
PS-816 C 3 2.125 1-1/2 BCFJF 504290
PS-1110 C 3 2.125 1-1/2 BCFKF 97937996
PS-258 E 3 2.125 1-1/2 BCFKF 269825601000
96706697
PS-436V C 3 2.500 1-3/4 VCFKF 96677366
PS-2109 E — — 1-3/4 BCF-F 96677802
PS-205V E 3 2.500 1-3/4 VCFJF Lock Collar Supplied Separately 96849274
PS-7488 E 3 2.500 1-3/4 VLFLF Lock Collar Supplied Separately 96853602
PS-3929 E 3 2.625 1-7/8 VCFJF
316SS/C
96662531
PS-532 C 3 2.750 2 BCFJF 269359903000
96690109
PS-1057 C 3 3.000 2-1/8 B/VCFKF 501908
PS-279V E 3 3.375 2-1/2 VCFJF Lock Collar Supplied Separately 96854658
PS-483 C 3 3.500 2-3/4 BCFKF 502365
STERLING, INC.
PS-3723 C 3 1.437 5/8 QCFJF I 081.00036.00
081.00036.01
PS-3981 C 3 1.437 5/8 QCFKF I 081.00037.00
PS-7872 C 3 1.437 5/8 VCFKF I 081.00039.00
PS-3826 C 1 1.437 7/8 QCFJF I 081.00034.00
PS-2224 C 3 1.437 7/8 QCFKF I 081.00024.00
081.00024.02
PS-3678 C 3 1.437 7/8 QCFLF I 081.00035.00
PS-4017 C 3 1.437 7/8 VCFKF I 081.00027.00
PS-758 C 1 2.125 1-1/2 BCFJF 081.00017.00
STERLING MACHINERY
PS-201 A 1 1.375 3/4 BMFJF
PS-564 C — — 3/4 BCF-F
PS-358 C 1 1.375 3/4 BCFJF 1616
PS-145 K — — 3/4 BCF-F
PS-175 K 1 1.375 3/4 BCFJF
1.500
PS-303 D 1 1.500 7/8 BCDKF J81-E
PS-1681 D 3 1.437 7/8 BCDKF
PS-185 C 1 1.875 1-1/4 BCFJF 1636
PS-177 C 1 2.000 1-3/8 BCFJF 1706
PS-178 R 1 2.000 1-3/8 BCDJF
PS-209 K — — 1-3/8 BCF-F
PS-629 E 3 2.312 1-1/2 BCFKF 133861
PS-216 K — — 1-1/2 BCF-F
PS-213 R — — 1-3/4 BCD-F
PS-217 R 1 2.500 1-3/4 BCDKF
PS-853 C 3 3.375 2-1/2 BCFKF 13498, 20125-H
STERO CORP. - (Dishwashers)
PS-3159 B 8 — 5/8 BCFJF A P571030
PS-3440 C 1 1.750 1 BCFJF P571697
STEVENS PUMP CO.
PS-200 A 1 1.250 5/8 BMFJF 16-062-03
STONE BENNETT
PS-499 C 3 1.625 1 BCFKF 30016
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
STONE CONSTRUCTION
PS-851 A 1 1.375 3/4 BCFJF 32223, 322231H
PS-360 A 1 1.625 1 BCFJF 32224, 322241H
PS-185 C 1 1.875 1-1/4 BCFJF 37692
PS-758 C 1 2.125 1-1/2 BCFJF 37691, 376911H
PS-446 C 1 2.500 1-3/4 BCFJF 377281H
SULLAIR CORP.
PS-6097 C
3 Special
2.625 1-7/8 NCFZF 316SS 250034-518
PS-6098 C
3 Special
2.625 1-7/8 VCFKP S 240048
PS-6120 K
3 Special
3.000 2-1/8 VCFZF 250038-066
PS-6121 K
3 Special
3.000 2-1/8 VCFZ/KF I 250038.068
PS-6138 C
3 Special
3.375 2-1/2 VCFKF 250038-093
PS-6997 K 3 3.375 2-1/2 NCFKF S 250038-078
PS-6141 K
3 Special
3.375 2-1/2 VCFKF 250038-080
PS-6140 K
3 Special
3.375 2-1/2 VCFZF 250038-079
PS-8108 X1T
3 Special
3.375 2-1/2 VCFKF 316SS 250041-326
PS-6173 C
3 Special
3.875 3 VCFKF 250035-751
PS-6172 C
3 Special
3.875 3 VCFKF H 250035-750
PS-6169 K
3 Special
3.875 3 NCFKF 250035-734
PS-6171 K
3 Special
3.875 3 VCFKF 250035-736
PS-6170 K
3 Special
3.875 3 VCFZF S 250035-735
PS-3961 K — — 3-3/8 VCF-F 250014-770
SULLIVAN-PALATEK, INC.
PS-1053 C 3 1.875 1-1/4 B/VCFKF 519056-08
PS-6180 C 3 2.000 1-3/8 VCFGF 519056-25
PS-210V C 3 2.000 1-3/8 VCFKF
PS-534 D 3 2.125 1-1/2 BCFKF RP-250, RP-365 A-222599
PS-1055 C — — 1-3/4 BCF-F RPV-125
PS-3789 C 3 2.500 1-3/4 VCFGF 519058-0006
PS-1056V C 3 2.500 1-3/4 VCFKF 519056-6
PS-4276 C 3 3.000 2-1/8 VCFKF 519056-13
PS-853 C 3 3.375 2-1/2 BCFKF Model 600
PS-6174 E 3 3.875 3 VCDGP 519056-15
SUPERIOR EQUIPMENT SOLUTIONS - (Dishwashers)
PS-3100 Q — — 1 NMDKF Unitized 75-7050-020
SWABY MFG. CO.
PS-359 C 1 1.250 5/8 BCFJF
PS-758 C 1 2.125 1-1/2 BCFJF
PS-446 C 1 2.500 1-3/4 BCFJF
PS-2120 C 1 3.375 2-1/2 BCFJF
SWIMQUIP
PS-201 A 1 1.375 3/4 BMFJF XL VI/XL VII Series 37407-0009
SYNCROFLO, INC.
PS-921 A 1 1.375 3/4 BMFKF 13-690-0600
PS-360 A 1 1.625 1 BCFJF 13-650-0610
PS-370 A 1 1.625 1 BCFKF 13-690-0610
PS-235 C 1 1.625 1 BCFJF 13-690-0710
PS-185 C 1 1.875 1-1/4 BCFJF 13-950-0880
PS-756 C 1 1.875 1-1/4 BCFKF 13-690-2112
PS-1109 C 3 1.875 1-1/4 BCFKF 13-690-0611
PS-361 E 1 1.875 1-1/4 BCFJF 13-650-1010
PS-137 E 1 1.875 1-1/4 BCFKF 13-690-0650
PS-3954 EB 1 1.875 1-3/8 BCFKF 13-690-2713
PS-3991 EB 3 1.875 1-3/8 BCFKF 13-690-0612
PS-238 C 1 2.375 1-5/8 BCFJF 13-950-0886
PS-1019 C 3 2.625 1-5/8 BCFKF 13-690-2515
PS-205 E 1 2.500 1-3/4 BCFJF 13-650-3011
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
TACO, INC.
PS-8100
X Special
1 .875 1/4 QCFLF 185-026
PS-163 B 1 1.000 1/2 BMFJF 106-031
PS-3561 C 1 .938 1/2 BCFJF 180-097, 180-108
PS-3563 C 1 .938 1/2 QCFLF 180-240
PS-1002 C 1 1.000 1/2 BCFJF Series 1616 121-008
PS-106 C 1 1.000 1/2 BCFKF 131-031
PS-3583 C 1 1.000 1/2 BCFKF 121-136
PS-3004 G 1 1.000 1/2 QCFLF 185-135
PS-3568 G 1 1.000 1/2 QLFLF 185-151
PS-200 A 1 1.250 5/8 BMFJF 172-009, 172-017
PS-200V A 3 1.250 5/8 VCFJF 172-006
PS-1000V B 3 1.250 5/8 VCFJF 1600-305
PS-359 C 1 1.250 5/8 BCFJF 121-009, 122-009
PS-633 C 1 1.250 5/8 BCFKF Series 131-9, 132-9 170-102RP, 1600-170RP
133-9, 138-9, 1600-9
PS-3525 C 3 1.250 5/8 QCFKF I 1600-170
PS-3586 G 1 1.250 5/8 QCFJF 1600-846C
PS-3840 C 1 1.275 3/4 BCFJF 180-162
PS-358 C 1 1.375 3/4 BCFJF 180-206
PS-752 D 1 1.375 3/4 BCDKF 142-043
PS-360 A 1 1.625 1 BCFJF 170-021, 170-095
PS-754 E 1 1.625 1 BCFJF 900-012
PS-356 C 1 1.750 1-1/8 BCFJF 950-670RP, 951-3161BRP
PS-355 C 1 1.750 1-1/8 BCFKF 950-664RP
PS-529-EPR C 3 1.750 1-1/8 QCFKF 950-664BRP
PS-355V C 3 1.750 1-1/8 VCFKF 950-667RP
PS-204 E 1 1.750 1-1/8 BCFJF 900-024
PS-384 E 1 1.750 1-1/8 BCFKF 840-128
PS-867 E 3 1.750 1-1/8 BCFKF 840-128BRP
PS-264 E 3 1.875 1-1/4 BCFKF 840-011
PS-758 C 1 2.125 1-1/2 BCFJF 950-671RP
PS-758-EPR C 3 2.125 1-1/2 QCFJF 951-3162BRP
PS-659V C 3 2.125 1-1/2 VCFKF 950-668RP
PS-305 E 1 2.125 1-1/2 BCFJF 862-029
PS-374 E 1 2.125 1-1/2 BCFKF 862-172
PS-544 C 3 2.375 1-5/8 BCFKF 950-673RP
PS-4068 C 3 2.375 1-5/8 QCFZF I 950-676RP
PS-340-EPR-CMS C 1 2.625 1-7/8 QCFJF 951-2968RP
PS-267 C 1 2.750 2 BCFJF 950-672RP
PS-842 C 1 2.750 2 BCFKF 950-666RP
PS-1145 C 3 2.750 2 VCFKF 950-669RP
PS-479 E 1 2.750 2 BCFJF Model 6012
PS-1676 C 3 3.125 2-1/4 BCFKF 950-674RP
PS-1676-EPR-P66 C 3 3.125 2-1/4 QCFKF I
PS-1676V-TC-SEAT C 3 3.125 2-1/4 VCFZF 950-677RP
PS-483 C 3 3.500 2-3/4 BCFKF 950-675RP
Value Guard Seal Material
Part No. Size Code Mfg. Part No.
TACO, INC. - Replacement Seal Kits
VGK-1094* 1/2 BCFKF 1600-055BRP
VGK-1096* 5/8 BCFKF 1600-170BRP
VGK-1095* 5/8 BCFJF 1600-170ERP
VGK-1097* 5/8 BCFJF 1600-868CRP
VGK-1098 1-1/8 BCFKF 840-128BRP
VGK-1102 1-1/8 BCFKF 950-664BRP
VGK-1105 1-1/8 VCFZF 950-667BRP
VGK-1108 1-1/8 BCFJF 950-670BRP
VGK-1116 1-1/8 BCFKF 953-1549-1BRP
* These kits do not include sleeve.
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
N. NON-STANDArD SprING HOLDer
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
Value Guard Seal Material
Part No. Size Code Mfg. Part No.
TACO, INC. - Replacement Seal Kits (continued)
VGK-1117 1-1/8 BCFJF 953-1549-3BRP
VGK-1112 1-1/8 BCFKF 951-3159BRP
VGK-1114 1-1/8 BCFJF 951-3161BRP
VGK-1099 1-1/2 BCFKF 862-171BRP
VGK-1100 1-1/2 BCFKF 862-172BRP
VGK-1119 1-1/2 BCFJF 862-172ERP
VGK-1103 1-1/2 BCFKF 950-665BRP
VGK-1106 1-1/2 VCFZF 950-668BRP
VGK-1109 1-1/2 BCFJF 950-671BRP
VGK-1113 1-1/2 NCFKF 951-3160BRP
VGK-1115 1-1/2 BCFJF 951-3162BRP
VGK-1118 1-1/2 BCFJF 953-1549-6BRP
VGK-1101 1-7/8 BCFJF 950-1369BRP
VGK-1111 1-7/8 BCFJF 951-2968BRP
VGK-1104 2 BCFKF 950-666BRP
VGK-1107 2 VCFZF 950-669BRP
VGK-1110 2 BCFJF 950-672BRP
• Kits include gaskets, o-rings, sleeve*, rubber
bonded washer, and mechanical seal.
• Taco, Inc. is not affiliated with U.S.Seal Mfg.
• Products supplied are manufactured or purchased
by U.S.Seal Mfg. from sources other than the
company listed.
TAIT
PS-162 A 1 1.000 1/2 BMFJF W-6476
PS-201 A 1 1.375 3/4 BMFJF 25062
PS-921 A 1 1.375 3/4 BMFKF 24820
PS-1125 C 1 1.375 3/4 BCFJF 16519
PS-703 D 1 1.500 7/8 BCDJF 24584
PS-360 A 1 1.625 1 BCFJF
PS-380 D 1 1.625 1 BCFJF 24963
PS-598 C 3 1.875 1-1/4 BCFKF W-16524
PS-805 C 3 2.000 1-3/8 BCFJF 16538
PS-267 C 1 2.750 2 BCFJF
TECUMSEH PRODUCTS CO.
PS-350 E 3 3.250 2-3/8 BCFKF K-509-9
TEEL PUMP
PS-392 C 1 .938 1/2 B/QMFJF 5NC03
PS-631 C 1 1.000 1/2 BCFJF N 5P380, 5P418
PS-1002 C 1 1.000 1/2 BCFJF 1P609, 1P610 1R305
PS-3542 C 3 1.031 9/16 VCFKF 5P419
PS-100 A 1 1.187 5/8 BMFJF 2P141, 2P894-2P899, 3P683-684-685 1R311, 5P403, 5P404
3P-686-687-690-692-715-716
PS-516 A 1 1.250 5/8 BCFJF 1P746-851-860-896-897-952-955-996 1R303, 5P407
1P998, 2P004-006-390, 2P091,
2P092, 3P551-3P553, 3P577
PS-200 A 1 1.250 5/8 BMFJF 1R312, 5P405, 5P406
PS-501 A 1 1.250 5/8 BMFJF 1R315, 5P409, 5P410
VGK-1100
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
TEEL PUMP (continued)
PS-200V A 3 1.250 5/8 VCFJF 1P862, 2P486 opt. for 1P746-851 1R300, 5P408
1P854-856-860-884-896-897-952-955
1P996-998-2P004-006-290 3P551-553
3P577
PS-113 B 1 1.093 5/8 BMFJF 1P795 1R302, 5P366
PS-600 B 1 1.187 5/8 BMFJF 5P367
PS-1000 B 1 1.250 5/8 BMFJF 2P356, 2P360, 2P363, 2P366 1R317, 1R318
5P368, 5P369
PS-1152 B 1 1.250 5/8 BMFKF 1R318
PS-447 B 8 — 5/8 BCFJF A 1P787-793-796-798-831-837, 1R306,1P831, 5P402
2P498-503-852, 3P736
PS-447V B 8 — 5/8 VCFJF A Optional for 1P787-793-796-798-831 1R324, 5P365
-1P837, 2P498-503
PS-800 C 1 1.156 5/8 BMFJF H 1P-849-850-879, 3P547-550- 1R307, 5P387, 5P421
571-599-648, 1P979-984, 2P019-280,
PC-18-2PC56
PS-359 C 1 1.250 5/8 BCFJF 1P898, 3P569A, 3P570A 1P557, 5P386, 1R310
PS-2160 C 1 1.250 5/8 BCFJF 3P511, 3P512, 3P579, 1P861 5P420, 1R298
PS-359V C 3 1.250 5/8 VCFJF 1P555, 1P804, 3P569, 3P570 5NC07, 5P385
PS-508 D 1 1.250 5/8 BCDJF 1R316, 5P382, 5P384
PS-851 A 1 1.375 3/4 BCFJF 1P855-868-869-895,1P913, 1P950, 5P414, 1R299
2P007-008, 2P333,3P525 3P526, 3P600
PS-201 A 1 1.375 3/4 BMFJF 5P411, 5P412, 1R313
PS-101 A 1 1.437 3/4 BMFJF 5P416, 1R319
PS-201V A 3 1.375 3/4 VCFJF 1P946; Optional for 1P855-868-869 5P413, 1R245
1P895-913-950-979-984, 2P007-008,
3P525-526-600
PS-877 C 1 1.375 3/4 BCFJF Optional for 1P700-702-799-803-947 5P389, 1R308
1P949, 2P391, 2P392, 2P393, 2P394
PS-877V C 1 1.375 3/4 VCFJF 1P700-702-799-803-947-949, 2P391 5P388, 1R309
2P392, 2P393, 2P394
PS-750 D 1 1.375 3/4 BCDJF 5P383
PS-188V E 3 1.500 7/8 VCFJF 5NC27
PS-360 A 1 1.625 1 BCFJF 5NC01, 5P417
PS-235 C 1 1.625 1 BCFJF 5P390
PS-380 D 1 1.625 1 BCFJF 5P423
PS-754 E 1 1.625 1 BCFJF 5P370
PS-356 C 1 1.750 1-1/8 BCFJF 5NC11, 2P015, 2P141,
3P582-601-604-609, 3P653-656-663,
3P664, 3P703-704-705-706, 3P707,
3P737, 3P608, 5P391
PS-355 C 1 1.750 1-1/8 BCFKF 5P392
PS-529 C 3 1.750 1-1/8 BCFKF 5P393
PS-604 D 1 1.750 1-1/8 BCFJF IR301
PS-204 E 1 1.750 1-1/8 BCFJF 5P373
PS-253 E 3 1.750 1-1/8 BCFKF 5P372
PS-204V E 3 1.750 1-1/8 VCFJF 5NC29
PS-185 C 1 1.875 1-1/4 BCFJF 2P142, 3P660, 3P661, 3P662 5P394, IR439
PS-246 C 1 1.875 1-1/4 BCFJF B/H 5P395
PS-756 C 1 1.875 1-1/4 BCFKF 5P396
PS-361 E 1 1.875 1-1/4 BCFJF 5P374
PS-177 C 1 2.000 1-3/8 BCFJF 5P397
PS-705 E 3 2.062 1-7/16 BCFJF 5P375
PS-758 C 1 2.125 1-1/2 BCFJF 5P398
PS-609 E 1 2.312 1-5/8 BCDJF 5P377
PS-484 E 1 2.312 1-5/8 BCDKF 5P376
PS-448 C 1 2.500 1-3/4 BCFKF 5P399
PS-205 E 1 2.500 1-3/4 BCFJF 5P378
PS-1659 E 3 2.625 1-7/8 VCFJF 5NC35
PS-479V E 3 2.750 2 VCFJF 5NC36
PS-322 K 3 3.500 2-3/4 BCFKF 5P401
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
N. NON-STANDArD SprING HOLDer
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
TERRA PRODUCTS
PS-601V B 3 1.375 3/4 VCFJF 127135
PS-245V C 3 1.625 1 VCFJF B/H 17035
THELCO CORP.
PS-348 C — — 1-1/8 BCF-F SU1774
PS-348V C — — 1-1/8 VCF-F SU1778
T9-1125 WT — — 1-1/8 TCF-F 316SS SU1766
PS-172 C — — 1-3/8 BCF-F SU1775
PS-172V C — — 1-3/8 VCF-F SU1789
PS-2108 C — — 1-3/4 BCF-F SU1776
FA-10045 C — — 1-3/4 VCF-F SU1780
THERMO KING
PS-159 D 3 1.625 1 NCPGP 220203, 220378
PS-1128 D 3 1.875 1-1/4 NCPKF 1210A02G01
THERMOTRON INDUSTRIES
PS-3833 C 2 1.750 1-1/8 BCFKF 555824
PS-239 C 1 2.375 1-5/8 BCFKF 1246366
THOMSEN® GROUP, LLC.
PS-9700 C 1 1.625 .970 VCFJF 9122-VL
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 9123-VL
THRUSH PUMPS
PS-163 B 1 1.000 1/2 BMFJF
PS-106 C 1 1.000 1/2 BCFKF GT, GTB, GTN Series Circulators 1/3
PS-600 B 1 1.187 5/8 BMFJF AA-190, AA-199
PS-290 C 1 1.250 5/8 BCFJF N 1-1/2TV3/4, 2TV3/4, J #s 1, 2, 3, 4
PS-633V-CMS C 1 1.250 5/8 VCFKF TX-022/024
PS-208 C — — 7/8 BCF-F 9765-0260
PS-687 C 1 1.500 7/8 BCFKF 1-1/2ATV1, 1-1/2TVI, 2TVB1-1/2,
2VTB1, 2TV1, 2TV1-1/2, 2TV2, 3TV1,
3TV1-1/2, 3TV2, N#’s 1, 2, 3, 4
PS-687V C 3 1.500 7/8 VCFKF TX-026/028
PS-348 C — — 1-1/8 BCF-F 9765-0300
PS-355 C 1 1.750 1-1/8 BCFKF 2TV3, 2-1/2TV3, 2-1/2TV5, 3TV3,
3TV5 5ATV3, 5ATV5, 5TV3, 5TV5,
Series R #s 1, 2, 3, 4
PS-154 C — — 1-1/4 BCF-F 9765-0520
PS-598-EPR C 3 1.875 1-1/4 QCFKF 7307-000-1
PS-756V C 3 1.875 1-1/4 VCFKF TX052/054
PS-172 C — — 1-3/8 BCF-F 9765-0340
PS-210 C 1 2.000 1-3/8 BCFKF 2-1/2TV7-1/2, 3TV7-1/2, 3TV1,
5ATV7-1/2, 2-1/2TV10, 4TV10
5TV15, Series V #’s 3, 4
PS-210V C 3 2.000 1-3/8 VCFKF TX-035/036
PS-2107 C — — 1-5/8 BCF-F 9765-0560
PS-239V C 3 2.375 1-5/8 VCFKF TX-056/058
TOLEDO
PS-501 A 1 1.250 5/8 BMFJF A14067
TONKAFLOW (See GE OSMONICS)
TORO CO.
PS-200V-CMS A 1 1.250 5/8 VCFJF 42088
TRANE, INC.
PS-192 C 3 2.125 1-1/2 NCFGF X10063400000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Mating Mating Seal Oper.
Value Guard Ring Ring OD Size Material Height
Part No. Head Thick L1 D1 d Code L Mfg. Part No.
• To DIN 24960 • Bi-Directional • Elastomer Bellows • Unbalanced
TRAVAINI
VGM-8251 VGMH 10.3 37 22 VCFLF 27.5 950022SAC915
950022SAC916
VGM-8253 VGMH 12.0 43 28 VCFLF 32.5 950028SAC915
950028SAC916
VGM-8255 VGMH 12.0 50 35 VCFLF 32.5 950035SAC915
950035SAC916
VGM-8258 VGMH 12.0 61 43 VCFLF 34.0 950043SAC915
950043SAC916
VGM-8261 VGMH 13.5 75 55 VCFLF 34.5 950055SAC915
950055SAC916
VGM-8263 VGMH 15.9 97 75 VCFLF 44.7 950075SAC915
VGM-8251Z
VGMC-12
7.5 37 22 VCFLF 30.0
VGM-8253Z
VGMC-12
7.5 43 28 VCFLF 35.0
VGM-8255Z
VGMC-12
7.5 50 35 VCFLF 35.0
VGM-8258Z
VGMC-12
9.0 61 43 VCFLF 36.0
VGM-8261Z
VGMC-12
11.0 75 55 VCFLF 36.5
VGM-8263Z
VGMC-12
11.3 97 75 VCFLF 48.7
Value Guard Materials of
Part No. Description Construction Mfg. Part No.
3EH - Seal Size - 1-1/2
VGFS-5000 Cup Stainless Steel 216D-80-3P
VGFS-5001 Rotary Face Carbon 3EH-141D-26
VGFS-5002 Spring Stainless Steel 3EH-141D-27
VGFS-5003 Seal O-Ring EPR S328-80-2-E
VGFS-5004 Outer Seat Gasket Non Asbestos
VGFS-5005 Inner Seat O-Ring EPR
VGFS-5006 Inner Seat Ceramic
VGFS-5007 Outer Seat Ceramic
4EH - Seal Size - 1-3/4
VGFS-5010 Rotary O-Ring EPR 10CPLO-1-73-2-U
VGFS-5011 Cup Stainless Steel 4EH-143-23P-S
VGFS-5012 Rotary Face Carbon 4EH-143A-26
VGFS-5013 Single Seal Spring Stainless Steel 4EH-143A-27A
VGFS-5014 Seal Collar Stainless Steel 4EH-148A-23-S
VGFS-5015 Double Seal Spring Stainless Steel 4EH-148A-27A
VGFS-5016 Outer Seat Gasket Non Asbestos
VGFS-5017 Inner Seat O-Ring EPR
VGFS-5018 Inner Seat Ceramic
VGFS-5019 Outer Seat Ceramic
TRI-CLOVER® - Replacement Seals for Food, Dairy & Beverage Processing cessing
Dimensions in MM
Type VGMH
Shown with LS3.
Type VGMC-12
Shown with G6.
G60 is Optional
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Kit Seal Material
Part No. Type Size Code Mfg. Part No.
Value Guard Materials of
Part No. Description Construction Mfg. Part No.
C114 / SP114 - Components
VGFS-5020 Back Plate Stainless Steel 114D-11-316
VGFS-5021 Cup Stainless Steel 114D-80-3P
VGFS-5022 Spring Stainless Steel 114D-80-4
VGFS-5023 Rotary Face Carbon 114E-80-1A
VGFS-5024 Rotary O-Ring EPR 60C-3-34A-E
VGFS-5025 Rotary O-Ring Viton® 60C-3-34A-SFY
VGFS-5026 Rotary O-Ring Buna 60C-3-34A-U
VGFS-5027 Casing Gasket Buna S114-90A-U
VGFS-5028 Set Screw Stainless Steel SC905A-SS
VGFS-5029 Drive Collar Stainless Steel SP114D-23P-316L
TRI-CLOVER® - Replacement Seals for Food, Dairy & Beverage Processing (continued)
Pump Service Kit-1 includes rotary face, rotary o-ring, casing gasket and impeller pin.
Pump Service Kit-2 includes rotary face, rotary o-ring, spring and cup.
Pump Service Kit-3 includes rotary face, rotary o-ring, spring, cup, casing gasket and set screws.
Value Guard Materials of
Part No. Description Construction Mfg. Part No.
C216 / SP216 - Components
VGFS-5040 Rotary O-Ring EPR 01-1165-19-E
VGFS-5041 Rotary O-Ring Viton® 01-1165-19-SFY
VGFS-5042 Rotary O-Ring Buna 01-1165-19-U
VGFS-5043 Back Plate Stainless Steel 216D-11-316
VGFS-5044 Cup Stainless Steel 216D-80-3P
VGFS-5045 Spring Stainless Steel 216D-80-4
VGFS-5046 Rotary Face Carbon 216D-80-1A
VGFS-5047 Casing Gasket Buna S216-90A-U
VGFS-5048 Set Screw Stainless Steel SC1105A-SS
VGFS-5049 Drive Collar Stainless Steel SP216D-23P-S
TRI-CLOVER® - Replacement Seals for Food, Dairy & Beverage Processing (continued)
VGFS-5030
Kit-1
VGFS-5036
Kit-3
VGFS-5043
Back Plate
TRI-CLOVER® - Replacement Seals for Food, Dairy & Beverage Processing (continued)
C114 / SP114 - Pump Service Kits
VGFS-5030 Kit-1 3/4 BCF-F C114-1
VGFS-5031 Kit-1 3/4 QCF-F C114-CE
VGFS-5032 Kit-1 3/4 VCF-F C114-1V
VGFS-5033 Kit-2 3/4 BCF-F C114-3
VGFS-5034 Kit-2 3/4 QCF-F C114-3E
VGFS-5035 Kit-2 3/4 VCF-F C114-3V
VGFS-5036 Kit-3 3/4 BCF-F 9613990013
VGFS-5037 Kit-3 3/4 QCF-F 9613990014
VGFS-5038 Kit-3 3/4 VCF-F 9613990015
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
Value Guard Kit Seal Material
Part No. Type Size Code Mfg. Part No.
Pump Service Kit-1 includes rotary face, rotary o-ring, casing gasket and impeller pin.
Pump Service Kit-2 includes rotary face, rotary o-ring, spring and cup.
Pump Service Kit-3 includes rotary face, rotary o-ring, spring, cup, casing gasket and set screws.
Value Guard Materials
Part No. Description of Construction Mfg. Part No.
TRI-CLOVER® - Replacement Seals for Food, Dairy & Beverage Processing
Value Guard Kit Seal Material
Part No. Type Size Code Mfg. Part No.
Pump Service Kit-1 includes rotary face, rotary o-ring, casing gasket and impeller pin.
Pump Service Kit-2 includes rotary face, rotary o-ring, spring and cup.
Pump Service Kit-3 includes rotary face, rotary o-ring, spring, cup, casing gasket and set screws.
TRUPAR
PS-507 A 1 1.250 5/8 BMFKF P-1190
PS-102 D 1 1.250 5/8 BCDKF P-11048
PS-201 A 1 1.375 3/4 BMFJF P-11201
TRW (See REDA PUMP)
TRI-CLOVER® - Replacement Seals for Food, Dairy & Beverage Processing (continued)
C216 / SP216 - Pump Service Kits
VGFS-5050 Kit-1 1-1/8 BCF-F C216-1
VGFS-5051 Kit-1 1-1/8 QCF-F C216-1E
VGFS-5052 Kit-1 1-1/8 VCF-F C216-1V
VGFS-5053 Kit-2 1-1/8 BCF-F C216-3
VGFS-5054 Kit-2 1-1/8 QCF-F C216-3E
VGFS-5055 Kit-2 1-1/8 VCF-F C216-3V
VGFS-5056 Kit-3 1-1/8 BCF-F 9613990016
VGFS-5057 Kit-3 1-1/8 QCF-F 9613990017
VGFS-5058 Kit-3 1-1/8 VCF-F 9613990018
VGFS-5053
Kit-2
C218 / C328 SP218 / SP328 - Components
V VGFS-5060 Back Plate Stainless Steel 328D-11-316
VGFS-5061 Cup Stainless Steel 328D-80-3P
VGFS-5062 Spring Stainless Steel 328D-80-4
VGFS-5063 Rotary Face Carbon 328E-80-1A
VGFS-5064 Rotary O-Ring EPR S328-80-2-E
VGFS-5065 Rotary O-Ring Viton® S328-80-2-SFY
VGFS-5066 Rotary O-Ring Buna S328-80-2-U
VGFS-5067 Casing Gasket Buna S328-90A-U
VGFS-5068 Set Screw Stainless Steel SC1105A-SS
VGFS-5069 Drive Collar Stainless Steel SP328D-23P-S
TRI-CLOVER® - Replacement Seals for Food, Dairy & Beverage Processing
C218 / C328 SP218 / SP328 - Pump Service Kits
VGFS-5070 Kit-1 1-1/2 BCF-F C328-1
VGFS-5071 Kit-1 1-1/2 QCF-F C328-1E
VGFS-5072 Kit-1 1-1/2 VCF-F C328-1V
VGFS-5073 Kit-2 1-1/2 BCF-F C328-3
VGFS-5074 Kit-2 1-1/2 QCF-F C328-3E
VGFS-5075 Kit-2 1-1/2 VCF-F C328-3V
VGFS-5076 Kit-3 1-1/2 BCF-F 9613990019
VGFS-5077 Kit-3 1-1/2 QCF-F 9613990020
VGFS-5078 Kit-3 1-1/2 VCF-F 9613990021
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
N. NON-STANDArD SprING HOLDer
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
Value Guard Seal Size Material
Part No. Head MM Code Mfg. Part No.
TSURUMI PUMP
VGMW-14HL VGM562 14 VLFLF W-14HL / 025-290-19
VGMHT-2530N VGM562 25/30 VLFLF HT-2530N
025-000-01, 025-302-15
VGMH-30 VGM562 30 VLFLF H-30 / 025-194-12
VGMHT-3035N VGM562 30/35 VLFLF HT-3035N
025-000-02, 025-303-16
VGMH-35 VGM562 35 VLFLF H-36 / 025-195-13
VGMHT-3540N VGM562 35/40 VLFLF HT-3540N
025-000-03, 025-304-17
VGMHT-4550N VGM562 45/50 VLFLF HT-4550N
025-000-04, 025-305-18
VGMH-50T VGM562 50 VLFLF H-50T / 025-268-18
VGMH-60 VGM562 60 VLFLF H-60 / 025-199-17
VGMH-70 VGM562 70 VLFLF H-70 / 025-200-12
TUTHILL CORP.
PS-3208 C 1 1.375 3/4 VCFJF 065046 A000
PS-768 C 3 1.375 3/4 BCFKF 065238 A000
PS-252 D 3 1.625 1 BCFKF 065024 A00
PS-355V C 3 1.750 1-1/8 VCFKF 065049 A000
FA-10040 C — — 1-1/4 VCF-F 065220 0000
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 065239 A000
PS-4123 D 3 2.000 1-3/8 VCFKF 005019-2-B
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 065240 A000
PS-4408 D 3 2.125 1-1/2 B/VCPKP 065018 A000
PS-238V-CMS C 1 2.375 1-5/8 VCFJF 065241 A000
PS-446V C 3 2.500 1-3/4 VCFJF 065289 A000
FA-1875 C — — 1-7/8 BCF-F 065215 0000
FA-1875V C — — 1-7/8 VCF-F 065219 0000
FA-2120 C — — 2-1/8 BCF-F 065214 0000
PS-1678V C 3 3.125 2-1/4 VCFJF 065242 A000
TUTHILL PUMP CO.
PS-633 C 1 1.250 5/8 BCFKF 2C1B9
PS-768 C 3 1.375 3/4 BCFKF 3C1B9
PS-499 C 3 1.625 1 BCFKF 5C1B9
PS-4189 E 3 2.250 1-7/16 BCPKF CC0919-1A
PS-4189V E 3 2.250 1-7/16 VCPKF CC0919-1B
U.S. ELECTRICAL MOTOR
PS-358 C 1 1.375 3/4 BCFJF PUL-2112
PS-356 C 1 1.750 1-1/8 BCFJF
PS-320 C 1 2.250 1-1/2 BCFJF Frame 213
U.S. FILTER
PS-1002V C 1 1.000 1/2 VCFJF 7802910
PS-290V C 1 1.250 5/8 VCFJF N 7802918
PS-1687 D 1 3.000 2-1/8 BCFKF U18080
Type VGM562
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
VERTIFLO PUMP CO.
PS-358 C 1 1.375 3/4 BCFJF SJ-2112-C1-00
PS-358V-CMS C 1 1.375 3/4 VCFJF SJ-2112-C1-X2
PS-112V-CMS C 1 1.375 3/4 VCFKF SJ-2112-71-X0
PS-7305 C 1 1.375 3/4 VLFLF 316SS SJ-2112-S1-X2
PS-756 C 1 1.875 1-1/4 BCFKF SJ-2120-71-00
PS-3886 C 1 1.875 1-1/4 VCFJF 316SS SJ-2120-C1-X2
PS-185V-CMS C 1 1.875 1-1/4 VCFJF SJ-2120-C1-X0
PS-758 C 1 2.125 1-1/2 BCFJF SJ-2124-C1-02
PS-659 C 1 2.125 1-1/2 BCFKF SJ-2124-71-00
PS-758V-CMS C 1 2.125 1-1/2 VCFJF SJ-2124-C1-X0
PS-7409 C 1 2.125 1-1/2 VCFJF 316SS SJ-2124-C1-X2
PS-659V-CMS C 1 2.125 1-1/2 VCFKF SJ-2124-71X-0
PS-238 C 1 2.375 1-5/8 BCFJF SJ-2126-C1-00
PS-239 C 1 2.375 1-5/8 BCFKF SJ-2126-71-00
PS-238V-CMS C 1 2.375 1-5/8 VCFJF SJ-2126-C1-X0
PS-239V-CMS C 1 2.375 1-5/8 VCFKF SJ-2126-71-X0
PS-844 C 1 3.000 2-1/8 BCFJF SJ-2134-C1-00
VIC CLEANING MACHINE
PS-162 A 1 1.000 1/2 BMFJF 22-907
PS-701 A 1 1.187 5/8 BMFKF 42-607
VICAN PUMP (Unit of IDEX CORP.)
PS-7105 C 3 2.250 1-7/16 BCFKF 335-00-180-243
PS-4455 D 3 2.062 1-7/16 VCPKF 335-00-210-055
PS-6338 E 3 2.312 1-7/16 VCPKF 335-00-210-024
VICO (BALBOA WATER GROUP)
PS-2136 A 1
1.375/1.750
3/4 BCFJF SuperFlo, UltraFlo, Ultima PPSFSeal
VIKING INSTRUMENT
PS-162 A 1 1.000 1/2 BMFJF 1-3438-3
VIKING PUMP, INC. (Div. of IDEX CORP.)
PS-164 B 9 — 1/2 BMFKF A 2-471-008-999-00
PS-6321 C 3 1.125 1/2 BCFKF 2-471-051-999-00
PS-3735 C 3 1.125 1/2 VCFKF 2-471-052-999-00
PS-7948 E Special 1.193 1/2 BCPKF 2-471-003-999-00
PS-4451 E Special 1.193 1/2 QCPKF 2-471-022-999-00
PS-7948V E Special 1.193 1/2 VCPKF 2-471-017-999-00
PS-9320
W Special
Special 1.193 1/2 TCPKF 2-471-004-999-00
PS-1625 C 3 1.250 5/8 BCFKF 2-472-014-999-00
PS-3133 C 3 1.250 5/8 NCFKF 2-472-058-999-00
PS-1626 C 3 1.250 5/8 VCFKF 2-472-015-999-00
PS-9321 W 2 1.250 5/8 TCFKF 2-472-006-999-00
PS-9322 WT Special 1.490 5/8 TCFOF 316SS 2-472-012-999-00
PS-7087 D 3 1.375 3/4 BCPKF 2-473-003-999-00
PS-7613 D 3 1.375 3/4 NCPKF 2-473-009-999-00
PS-7613V D 3 1.375 3/4 VCPKF 2-473-018-999-00
PS-3935 W 2 1.375 3/4 TCFKF 316SS 2-473-038-999-00
PS-9324 W 2 1.375 3/4 TCFKF 316SS 2-473-006-999-00
PS-9323
W Special
2 1.375 3/4 TCFKF 316SS 2-473-001-999-00
PS-9325
W Special
2 1.375 3/4 TCFOF 316SS 2-473-034-999-00
PS-460 D 1 1.625 1 BCFKF 2-475-002-999-00
PS-6328 D 3 1.625 1 BCPKF 2-475-001-999-00
PS-6329 D 3 1.625 1 NCPKF 2-475-005-999-00
PS-4137 D 3 1.625 1 VCPKF 2-475-010-999-00
PS-6331 E 3 1.625 1 BCPKF 2-475-115-999-00
PS-3803 E 3 1.625 1 VCFKF 2-475-012-999-00
PS-1631 T 3 1.625 1 NCPKF 2-475-004-999-00
PS-9313 W 2 1.625 1 TCFKF 2-475-019-999-00
PS-9334 W 2 1.625 1 TCFOF 316SS 2-475-025-999-00
PS-7967 E 3 2.000 1-1/8 BCPKF 2-476-001-999-00
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
C. COMpLeTe WITH COLLAr
H. SprING HOLDer NOT INCLUDeD
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
VIKING PUMP, INC. (Div. of IDEX CORP.) (continued)
PS-3653 E 3 2.000 1-1/8 NCPGF 2-476-006-999-00
PS-3063 E 3 2.000 1-1/8 QCPKF 2-476-046-999-00
PS-6334 E 3 2.000 1-1/8 VCPKF 2-476-012-999-00
PS-7232 W 2 2.000 1-1/8 TCFKF 316SS 2-476-003-999-00
PS-9327 W 2 2.000 1-1/8 TCFOF 316SS 2-476-005-999-00
PS-9328 W 28 2.354 1-1/8 TCFKF 316SS 2-476-123-999-00
PS-9329 W 28 2.354 1-1/8 Special 316SS 2-476-133-999-00
PS-3731 Special 3 1.625 1-1/8 BCPKP 2-476-018-999-00
PS-6337 D 3 1.875 1-1/4 BCPKF 2-477-015-999-00
PS-6339 D 3 1.875 1-1/4 BCPKF 2-477-100-999-00
PS-3934 D 3 1.875 1-1/4 NCPKF 2-477-019-999-00
PS-1632V D 3 1.875 1-1/4 VCPKF 2-477-020-999-00
PS-4091 D 3 1.875 1-1/4 VLFLF 316SS/H 2-477-596-999-00
PS-3611 WT 2 1.875 1-1/4 TCFOF 316SS 2-477-140-999-06
PS-9003 WT 2 2.343 1-1/4 TCFKF 316SS 2-477-018-999-00
PS-7105 C 3 2.250 1-7/16 BCFKF 2-477-288-999-00
PS-4067 E 3 2.125 1-7/16 VCFKF 2-477-042-999-00
PS-6340 E 3 2.171 1-7/16 BCPKF 2-477-173-999-00
PS-6342 E 3 2.171 1-7/16 VCPKF 2-477-180-999-00
PS-4189 E 3 2.250 1-7/16 BCPKF
PS-1634 E 3 2.250 1-7/16 BCPKP 2-477-008-999-00
2-477-027-999-00
PS-3848 E 3 2.312 1-7/16 BCPKF 2-477-001-999-00
PS-6344 E 3 2.312 1-7/16 NCPKF 2-477-429-999-00
PS-6338 E 3 2.312 1-7/16 VCPKF 2-477-038-999-00
PS-4140 E 3 2.375 1-7/16 VCFLF 2-477-669-999-00
PS-1633 T 3 2.187 1-7/16 NCPKF 2-477-006-999-00
PS-9227 W 2 2.312 1-7/16 TCFKF 2-477-003-999-00
PS-9307 W 2 2.312 1-7/16 TCFOF 2-477-005-999-00
PS-9330 W Special 2.484 1-7/16 TCFKF 316SS 2-477-179-999-00
PS-9304 W 27 2.687 1-7/16 TCFKF 2-477-116-999-00
PS-9331 W 28 2.687 1-7/16 Special 2-477-346-999-00
PS-6348 E 3 2.375 1-5/8 BCPKF 2-478-041-999-00
PS-6349 E 3 2.375 1-5/8 VCPKF 2-478-046-999-00
PS-9017 WT 28 2.875 1-5/8 TCFKF 316SS 2-478-040-999-00
PS-9332 WT 28 2.875 1-5/8 TCFOF 316SS 2-478-026-999-00
PS-7580 E 3 3.437 2-7/16 BCPKP 2-480-001-999-00
PS-3751 E 3 3.437 2-7/16 VCPKF 2-480-004-999-00
PS-9333 W 28 4.000 2-7/16 TCFKF 316SS 2-480-051-999-00
PS-3505 U 3 4.375 3-7/16 VCPKF 2-481-006-999-00
PS-8106 X 3 4.312 3-7/16 VCFK* 2-481-124-999-00
VILTER MFG., INC.
PS-6175 R 3 3.875 3 NCPGP A-33489-A
VULCAN-HART
PS-1618 C 1 1.250 5/8 BCFJF B
PS-508 D 1 1.250 5/8 BCDJF
PS-360 A 1 1.625 1 BCFJF 97505
PS-236 E 1 1.625 1 BCFKF 97049
PS-1167 C 1 1.750 1-1/8 BCFKF B
PS-604 D 1 1.750 1-1/8 BCFJF
WARREN PUMPS
PS-4529 E 3 5.500 4-1/2 BCFJF 316SS/C
WATER ACE PUMP CO.® (Part of Pentair Pump Group)
PS-3845 B 8 1.299 5/8 BMFJF Models RSP-7, 10, 15 25053A000
WATERCO USA
PS-3985 B 1 1.375 3/4 BCFJF 316SS Supatuf 6340162
PS-185 C 1 1.875 1-1/4 BCFJF 19B5032
PS-446 C 1 2.500 1-3/4 BCFJF 19B5033
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
• Includes Seals, O-Rings and Wave Springs for 2 shafts
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U1 006, 015, 018, 024 - Seal & O-Ring Kits
VGFS-6000 Single 1-1/4 BJ-CF 105295
VGFS-6002 Single 1-1/4 BL-CF 105297
VGFS-6004 Single 1-1/4 BL-LF
VGFS-6005 Single 1-1/4 QJ-CF
VGFS-6006 Single 1-1/4 QL-CF
VGFS-6007 Single 1-1/4 QL-LF
VGFS-6001 Single 1-1/4 VJ-CF 105296
VGFS-6003 Single 1-1/4 VL-CF 105298
VGFS-6008 Single 1-1/4 VL-LF
VGFS-6010 Double 1-1/4 BJ-CF 105299
VGFS-6012 Double 1-1/4 BL-C/LF 105301
VGFS-6014 Double 1-1/4 QJ-CF
VGFS-6015 Double 1-1/4 QL-C/LF
VGFS-6011 Double 1-1/4 VJ-CF 105300
VGFS-6013 Double 1-1/4 VL-C/LF 105302
WATEROUS CO.
PS-499 C 3 1.625 1 BCFKF
PS-460V D 3 1.625 1 VCFKF S V-2672
PS-3010 G 3 1.625 1 BCFLF V-3386
PS-3193 D 3 1.750 1-1/16 VCDLF V-3385
PS-605 D 1 1.750 1-1/8 BCFKF V-1467
PS-3013 G 25 1.750 1-1/8 VCFLF 316SS V-3505
PS-598 C 3 1.875 1-1/4 BCFKF V-2145
PS-383V D 3 1.875 1-1/4 VCFKF V-1150
PS-6266 G 3 1.875 1-1/4 BCFLF 316SS V-3218
PS-659V C 3 2.125 1-1/2 VCFKF
WATERWAY PLASTICS
PS-671 B 1 .875 3/8 BMFJF Tiny Mite 811-4000A
PS-1000 B 1 1.250 5/8 BMFJF 319-3100B
PS-3212 B 1 1.250 5/8 VCFJF Light Spring Load 811-1090
WATTS
PS-680 A 1 1.187 5/8 BCFJF
PS-1000 B 1 1.250 5/8 BMFJF
WAUKESHA® CHERRY-BURRELL®
PS-3730 C — — 1-3/8 NFF-F M549P122960
PS-544 C 3 2.375 1-5/8 BCFKF 506 4131207
PS-239V C 3 2.375 1-5/8 VCFKF PG4-45, 5164130809
PS-267V C 3 2.750 2 VCFJF
PS-1145 C 3 2.750 2 VCFKF PG4-46, 5065080809
PS-1676 C 3 3.125 2-1/4 BCFKF 5065711207
PS-1676V C 3 3.125 2-1/4 VCFKF 5065710809
VGFS-6015
U1- Double Seal & O-Ring Kit
2 Required per Pump
VGFS-6008
U1- Single Seal & O-Ring Kit
2 Required per Pump
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U1 006, 015, 018, 024 - Seal & O-Ring Kits
VGFS-6020 Single 1-1/4 B--F- 105247
VGFS-6022 Single 1-1/4 Q--F-
VGFS-6021 Single 1-1/4 V--F- 105251
VGFS-6023 Double 1-1/4 B--F- 105249
VGFS-6025 Double 1-1/4 Q--F-
VGFS-6024 Double 1-1/4 V--F- 105253
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
U1 006, 015, 018, 024 - Seal & Seat Components
Inner Seal
VGFS-6030 Stationary Face Seal Ceramic 015-306-002
VGFS-6031 Stationary Face Seal Carbon 015-306-007
VGFS-6032 Stationary Face Seal Silicon Carbide 015-306-009
VGFS-6033 Stationary Face O-Ring Buna AD0079000
VGFS-6034 Stationary Face O-Ring EPR AD0079002
VGFS-6035 Stationary Face O-Ring Silicone AD0079SC0
VGFS-6036 Stationary Face O-Ring Viton® AD0079V00
Outer Seal
VGFS-6037 Stationary Face Seal Carbon 015-206-007
VGFS-6038 Stationary Face O-Ring Buna N50228
U1 006, 015, 018, 024 - Components for Inner and Outer Seals
VGFS-6040 Shaft O-Ring EPR E70022
VGFS-6041 Shaft O-Ring Buna N70022
VGFS-6042 Shaft O-Ring Silicone S70022
VGFS-6043 Shaft O-Ring Viton® V70022
VGFS-6044 Rotary Face Seal Ceramic 015-014-002
VGFS-6045 Rotary Face Seal Silicon Carbide 015-014-009
VGFS-6046 Sleeve Stainless Steel 015-098-000
VGFS-6047 Sleeve Chrome Oxide 015-098-002
Coated Stainless
VGFS-6048 Sleeve Zirconia 015-098-004
VGFS-6049 Wave Spring Stainless Steel 015-304-000
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
VGFS-6022
• Includes Sleeves and O-Rings for 2 shafts
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U1 030, 034 - Seal & O-Ring Kits
VGFS-6100 Single 1-1/2 BJ-CF 105305
VGFS-6102 Single 1-1/2 BL-CF 105307
VGFS-6104 Single 1-1/2 BL-LF
VGFS-6105 Single 1-1/2 QJ-CF
VGFS-6106 Single 1-1/2 QL-CF
VGFS-6107 Single 1-1/2 QL-LF
VGFS-6101 Single 1-1/2 VJ-CF 105306
VGFS-6103 Single 1-1/2 VL-CF 105308
VGFS-6108 Single 1-1/2 VL-LF
VGFS-6109 Double 1-1/2 BJ-CF 105309
VGFS-6111 Double 1-1/2 BL-C/LF 105311
VGFS-6113 Double 1-1/2 QJ-CF
VGFS-6114 Double 1-1/2 QL-C/LF
VGFS-6110 Double 1-1/2 VJ-CF 105310
VGFS-6112 Double 1-1/2 VL-C/LF 105312
Sleeve & O-Ring Kits
VGFS-6120 Single 1-1/2 B--F- 105259
VGFS-6121 Single 1-1/2 Q--F-
VGFS-6122 Single 1-1/2 V--F- 105263
VGFS-6123 Double 1-1/2 B--F- 105261
VGFS-6124 Double 1-1/2 Q--F-
VGFS-6125 Double 1-1/2 V--F- 105265
• Includes Seals, O-Rings and Wave Springs for 2 shafts
• Includes Sleeves and O-Rings for 2 shafts
U1 030, 034 - Seal & Mating Ring Components
Inner Seal
VGFS-6130 Stationary Face Seal Ceramic 030-306-002
VGFS-6131 Stationary Face Seal Carbon 030-306-007
VGFS-6132 Stationary Face Seal Silicon Carbide 030-306-009
VGFS-6133 Stationary Face O-Ring Buna AD0079000
VGFS-6134 Stationary Face O-Ring EPR AD0079002
VGFS-6135 Stationary Face O-Ring Silicone AD0079SC0
VGFS-6136 Stationary Face O-Ring Viton® AD0079V00
Outer Seal
VGFS-6137 Stationary Face Seal Carbon 030-206-007
VGFS-6138 Stationary Face O-Ring Buna N50335
U1 030, 034 - Components for Inner and Outer Seals
VGFS-6140 Shaft O-Ring EPR E70028
VGFS-6141 Shaft O-Ring Buna N70028
VGFS-6142 Shaft O-Ring Silicone S70028
VGFS-6143 Shaft O-Ring Viton® V70028
VGFS-6144 Rotary Face Seal Ceramic 030-014-002
VGFS-6145 Rotary Face Seal Silicon Carbide 030-014-009
VGFS-6146 Sleeve Stainless Steel 030-098-000
VGFS-6147 Sleeve Chrome Oxide 030-098-002
Coated Stainless
VGFS-6148 Sleeve Zirconia 030-098-004
VGFS-6149 Wave Spring Stainless Steel 030-304-000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U1 040, 060, 064, 130, 134 - Seal & O-Ring Kits
VGFS-6200 Single 1-7/8 BJ-CF 105315
VGFS-6202 Single 1-7/8 BL-CF 105317
VGFS-6204 Single 1-7/8 BL-LF
VGFS-6205 Single 1-7/8 QJ-CF
VGFS-6206 Single 1-7/8 QL-CF
VGFS-6207 Single 1-7/8 QL-LF
VGFS-6201 Single 1-7/8 VJ-CF 105316
VGFS-6203 Single 1-7/8 VL-CF 105318
VGFS-6208 Single 1-7/8 VL-LF
VGFS-6209 Double 1-7/8 BJ-CF 105319
VGFS-6211 Double 1-7/8 BL-C/LF 105321
VGFS-6213 Double 1-7/8 QJ-CF
VGFS-6214 Double 1-7/8 QL-C/LF
VGFS-6210 Double 1-7/8 VJ-CF 105320
VGFS-6212 Double 1-7/8 VL-C/LF 105322
U1 040, 060, 064, 130, 134 - Sleeve & O-Ring Kits
VGFS-6220 Single 1-7/8 B- - F- 105271
VGFS-6221 Single 1-7/8 Q- - F-
VGFS-6222 Single 1-7/8 V- - F- 105275
VGFS-6223 Double 1-7/8 B- - F- 105273
VGFS-6224 Double 1-7/8 Q- - F-
VGFS-6225 Double 1-7/8 V- - F- 105277
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
• Includes Seals, O-Rings and Wave Springs for 2 shafts
• Includes Sleeves and O-Rings for 2 shafts
U1 040, 060, 064, 130, 134 - Seal & Mating Ring Components
Inner Seal
VGFS-6230 Stationary Face Seal Ceramic 030-306-002
VGFS-6231 Stationary Face Seal Carbon 030-306-007
VGFS-6232 Stationary Face Seal Silicon Carbide 030-306-009
VGFS-6233 Stationary Face O-Ring EPR E70331
VGFS-6234 Stationary Face O-Ring Buna N70331
VGFS-6235 Stationary Face O-Ring Silicone S70331
VGFS-6236 Stationary Face O-Ring Viton® V70331
Outer Seal
VGFS-6237 Stationary Face Seal Carbon 060-206-007
VGFS-6238 Stationary Face O-Ring Buna N50338
U1 040, 060, 064, 130, 134 - Components for Inner and Outer Seals
VGFS-6240 Shaft O-Ring EPR E70131
VGFS-6241 Shaft O-Ring Buna N70131
VGFS-6242 Shaft O-Ring Silicone S70131
VGFS-6243 Shaft O-Ring Viton® V70131
VGFS-6244 Rotary Face Seal Ceramic 060-014-002
VGFS-6245 Rotary Face Seal Silicon Carbide 060-014-009
VGFS-6246 Sleeve Stainless Steel 060-098-000
VGFS-6247 Sleeve Chrome Oxide 060-098-002
Coated Stainless
VGFS-6248 Sleeve Zirconia 060-098-004
VGFS-6249 Wave Spring Stainless Steel 060-304-000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U1 220, 224 - Seal & O-Ring Kits
VGFS-6300 Single 2-3/4 BJ-CF 105325
VGFS-6302 Single 2-3/4 BL-CF 105327
VGFS-6304 Single 2-3/4 BL-LF
VGFS-6305 Single 2-3/4 QJ-CF
VGFS-6306 Single 2-3/4 QL-CF
VGFS-6307 Single 2-3/4 QL-LF
VGFS-6301 Single 2-3/4 VJ-CF 105326
VGFS-6303 Single 2-3/4 VL-CF 105328
VGFS-6308 Single 2-3/4 VL-LF
VGFS-6309 Double 2-3/4 BJ-CF 105329
VGFS-6311 Double 2-3/4 BL-C/LF 105331
VGFS-6313 Double 2-3/4 QJ-CF
VGFS-6314 Double 2-3/4 QL-C/LF
VGFS-6310 Double 2-3/4 VJ-CF 105330
VGFS-6312 Double 2-3/4 VL-C/LF 105332
U1 220, 224 - Sleeve & O-Ring Kits
VGFS-6320 Single 2-3/4 B- - F- 105283
VGFS-6321 Single 2-3/4 Q- - F-
VGFS-6322 Single 2-3/4 V- - F- 105287
VGFS-6323 Double 2-3/4 B- - F- 105285
VGFS-6324 Double 2-3/4 Q- - F-
VGFS-6325 Double 2-3/4 V- - F- 105289
• Includes Seals, O-Rings and Wave Springs for 2 shafts
• Includes Sleeves and O-Rings for 2 shafts
U1 220, 224 - Seal & Mating Ring Components
Inner Seal
VGFS-6330 Stationary Face Seal Ceramic 220-306-002
VGFS-6331 Stationary Face Seal Carbon 220-306-007
VGFS-6332 Stationary Face Seal Silicon Carbide 220-306-009
VGFS-6333 Stationary Face O-Ring EPR E70338
VGFS-6334 Stationary Face O-Ring Buna N70338
VGFS-6335 Stationary Face O-Ring Silicone S70338
VGFS-6336 Stationary Face O-Ring Viton® V70338
Outer Seal
VGFS-6340 Stationary Face Seal Carbon 220-206-007
VGFS-6341 Stationary Face O-Ring Buna N50344
U1 220, 224 - Components for Inner and Outer Seals
VGFS-6350 Shaft O-Ring EPR E70144
VGFS-6351 Shaft O-Ring Buna N70144
VGFS-6352 Shaft O-Ring Silicone S70144
VGFS-6353 Shaft O-Ring Viton® V70144
VGFS-6354 Rotary Face Seal Seat Ceramic 220-014-002
VGFS-6355 Rotary Face Seal Seat Silicon Carbide 220-014-009
VGFS-6356 Sleeve Stainless Steel 220-098-000
VGFS-6357 Sleeve Chrome Oxide 220-098-002
Coated Stainless
VGFS-6358 Sleeve Zirconia 220-098-004
VGFS-6359 Wave Spring Stainless Steel 220-304-000
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Inner Seal Components
VGFS-6410 Rotary Face Carbon 36027
VGFS-6411 Rotary Face Silicon Carbide 40754
VGFS-6412 Rotary Face Ceramic 40755
VGFS-6413 Full Clamp Seat Gasket EPR 300042001
VGFS-6414 Full Clamp Seat Gasket Silicone
VGFS-6415 Rotary Face O-Ring EPR E70238
VGFS-6416 Rotary Face O-Ring Silicone S75238
VGFS-6417 Rotary Face O-Ring Viton® V70238
VGFS-6418 Shaft O-Ring EPR E70234
VGFS-6419 Shaft O-Ring Silicone S75234
VGFS-6420 Shaft O-Ring Viton® V70234
VGFS-6421 Complete Rotary QCF-F
VGFS-6422 Complete Rotary QLF-F 40572
VGFS-6423 Complete Rotary ICF-F
VGFS-6424 Complete Rotary ILF-F
VGFS-6425 Complete Rotary VCF-F
VGFS-6426 Complete Rotary VLF-F
VGFS-6427 Set Screw Stainless Steel 110038
VGFS-6428 Spring Stainless Steel 40875
Outer Seal Components
VGFS-6430 Full Clamp Seat Gasket EPR 300042002
VGFS-6431 Full Clamp Seat Gasket Silicone
VGFS-6432 Complete Rotary QCF-F 323114003
VGFS-6433 Rotary Face Carbon
VGFS-6434 Rotary Face Silicon Carbide
VGFS-6435 Spring Stainless Steel
Mating Ring Components
VGFS-6440 Full Clamp Flush Seat Ceramic 300014027
VGFS-6441 Full Clamp Flush Seat Silicon Carbide 300042031
VGFS-6442 Full Clamp Non-Flush Ceramic 300014012
VGFS-6443 Full Clamp Non-Flush Silicon Carbide 300042016
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U1 320, 323, 324
Per Shaft - Includes Double Seal for 1 Shaft
VGFS-6400 Double 3 QC/L-LF
VGFS-6401 Double 3 IC/L-LF
VGFS-6402 Double 3 VC/L-LF
Per Pump - Includes Double Seals for 2 shafts
VGFS-6403 Double 3 QC/L-LF
VGFS-6404 Double 3 IC/L-LF
VGFS-6405 Double 3 VC/L-LF
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U2 006, 015, 018
VGFS-6500 Single 1-1/4 QL-CF
VGFS-6501 Single 1-1/4 QL-LF
VGFS-6502 Single 1-1/4 VL-CF
VGFS-6503 Single 1-1/4 VL-LF
VGFS-6504 Double 1-1/4 QC/J-JF
VGFS-6505 Double 1-1/4 QC/L-LF
VGFS-6506 Double 1-1/4 QJ-CF
VGFS-6507 Double 1-1/4 QL-LF
VGFS-6508 Double 1-1/4 VC/J-JF
VGFS-6509 Double 1-1/4 VC/L-LF
VGFS-6510 Double 1-1/4 VJ-CF
VGFS-6511 Double 1-1/4 VL-LF
Inner Seal Components
VGFS-6520 Stationary Face Seal Carbon 101651
VGFS-6521 Stationary Face Seal Ceramic 101652
VGFS-6522 Stationary Face Seal Silicon Carbide 101653
VGFS-6523 Wave Spring Stainless Steel 101683
VGFS-6524 Stationary Face O-Ring EPR E70028
VGFS-6525 Stationary Face O-Ring Buna N70028
VGFS-6526 Stationary Face O-Ring Viton® V70028
Outer Seal Components
VGFS-6530 Stationary Face Seal Carbon 101679
VGFS-6531 Wave Spring Stainless Steel 101684
VGFS-6532 Stationary Face O-Ring EPR E70035
VGFS-6533 Stationary Face O-Ring Buna N70035
VGFS-6534 Stationary Face O-Ring Viton® V70035
Mating Ring Components
VGFS-6540 Rotary Face O-Ring EPR E70024
VGFS-6541 Rotary Face O-Ring Buna N70024
VGFS-6542 Rotary Face O-Ring Viton® V70024
VGFS-6543 Rotary Face Seal Seat Ceramic 101667
VGFS-6544 Rotary Face Seal Seat Silicon Carbide 101668
VGFS-6501 VGFS-6505
* Includes Seals, O-Rings and Wave Springs for One Shaft (Two Required Per Pump)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Inner Seal Components
VGFS-6620 Stationary Face Seal Carbon 101655
VGFS-6621 Stationary Face Seal Ceramic 101656
VGFS-6622 Stationary Face Seal Silicon Carbide 101657
VGFS-6623 Wave Spring Stainless Steel 101685
VGFS-6624 Stationary Face O-Ring EPR E70031
VGFS-6625 Stationary Face O-Ring Buna N70031
VGFS-6626 Stationary Face O-Ring Viton® V70031
Outer Seal Components
VGFS-6630 Stationary Face Seal Carbon 101680
VGFS-6631 Wave Spring Stainless Steel 101686
VGFS-6632 Stationary Face O-Ring EPR E70041
VGFS-6633 Stationary Face O-Ring Buna N70041
VGFS-6634 Stationary Face O-Ring Viton® V70041
Mating Ring Components
VGFS-6640 Rotary Face O-Ring EPR E70029
VGFS-6641 Rotary Face O-Ring Buna N70029
VGFS-6642 Rotary Face O-Ring Viton® V70029
VGFS-6643 Rotary Face Seal Ceramic 101670
VGFS-6644 Rotary Face Seal Silicon Carbide 101671
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U2 030, 034
VGFS-6600 Single 1-1/2 QL-CF
VGFS-6601 Single 1-1/2 QL-LF
VGFS-6602 Single 1-1/2 VL-CF
VGFS-6603 Single 1-1/2 VL-LF
VGFS-6604 Double 1-1/2 QC/J-JF
VGFS-6605 Double 1-1/2 QC/L-LF
VGFS-6606 Double 1-1/2 QJ-CF
VGFS-6607 Double 1-1/2 QL-LF
VGFS-6608 Double 1-1/2 VC/J-JF
VGFS-6609 Double 1-1/2 VC/L-LF
VGFS-6610 Double 1-1/2 VJ-CF
VGFS-6611 Double 1-1/2 VL-LF
* Includes Seals, O-Rings and Wave Springs for One Shaft (Two Required Per Pump)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Inner Seal Components
VGFS-6720 Stationary Face Seal Carbon 101659
VGFS-6721 Stationary Face Seal Ceramic 101660
VGFS-6722 Stationary Face Seal Silicon Carbide 101661
VGFS-6723 Wave Spring Stainless Steel 101687
VGFS-6724 Stationary Face O-Ring EPR E70035
VGFS-6725 Stationary Face O-Ring Buna N70035
VGFS-6726 Stationary Face O-Ring Viton® V70035
Outer Seal Components
VGFS-6730 Stationary Face Seal Carbon 101681
VGFS-6731 Wave Spring Stainless Steel 101688
VGFS-6732 Stationary Face O-Ring EPR E70043
VGFS-6733 Stationary Face O-Ring Buna N70043
VGFS-6734 Stationary Face O-Ring Viton® V70043
Mating Ring Components
VGFS-6740 Rotary Face O-Ring EPR E70133
VGFS-6741 Rotary Face O-Ring Buna N70133
VGFS-6742 Rotary Face O-Ring Viton® V70133
VGFS-6743 Rotary Face Seal Ceramic 101673
VGFS-6744 Rotary Face Seal Silicon Carbide 101674
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U2 040 ,045, 060, 064, 130, 134
VGFS-6700 Single 1-7/8 QL-CF
VGFS-6701 Single 1-7/8 QL-LF
VGFS-6702 Single 1-7/8 VL-CF
VGFS-6703 Single 1-7/8 VL-LF
VGFS-6704 Double 1-7/8 QC/J-JF
VGFS-6705 Double 1-7/8 QC/L-LF
VGFS-6706 Double 1-7/8 QJ-CF
VGFS-6707 Double 1-7/8 QL-LF
VGFS-6708 Double 1-7/8 VC/J-JF
VGFS-6709 Double 1-7/8 VC/L-LF
VGFS-6710 Double 1-7/8 VJ-CF
VGFS-6711 Double 1-7/8 VL-LF
* Includes Seals, O-Rings and Wave Springs for One Shaft (Two Required Per Pump)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Inner Seal Components
VGFS-6820 Stationary Face Seal Carbon 101663
VGFS-6821 Stationary Face Seal Ceramic 101664
VGFS-6822 Stationary Face Seal Silicon Carbide 101665
VGFS-6823 Wave Spring Stainless Steel 101689
VGFS-6824 Stationary Face O-Ring EPR E70041
VGFS-6825 Stationary Face O-Ring Buna N70041
VGFS-6826 Stationary Face O-Ring Viton® V70041
Outer Seal Components
VGFS-6830 Stationary Face Seal Carbon 101682
VGFS-6831 Wave Spring Stainless Steel 101690
VGFS-6832 Stationary Face O-Ring EPR E70046
VGFS-6833 Stationary Face O-Ring Buna N70046
VGFS-6834 Stationary Face O-Ring Viton® V70046
Mating Ring Components
VGFS-6840 Rotary Face O-Ring EPR E70145
VGFS-6841 Rotary Face O-Ring Buna N70145
VGFS-6842 Rotary Face O-Ring Viton® V70145
VGFS-6843 Rotary Face Seal Seat Ceramic 101676
VGFS-6844 Rotary Face Seal Seat Silicon Carbide 101677
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U2 180, 220, 224
VGFS-6800 Single 2-3/4 QL-CF
VGFS-6801 Single 2-3/4 QL-LF
VGFS-6802 Single 2-3/4 VL-CF
VGFS-6803 Single 2-3/4 VL-LF
VGFS-6804 Double 2-3/4 QC/J-JF
VGFS-6805 Double 2-3/4 QC/L-LF
VGFS-6806 Double 2-3/4 QJ-CF
VGFS-6807 Double 2-3/4 QL-LF
VGFS-6808 Double 2-3/4 VC/J-JF
VGFS-6809 Double 2-3/4 VC/L-LF
VGFS-6810 Double 2-3/4 VJ-CF
VGFS-6811 Double 2-3/4 VL-LF
* Includes Seals, O-Rings and Wave Springs for One Shaft (Two Required Per Pump)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Inner Seal Components
VGFS-6920 Stationary Face Seal Carbon 105412
VGFS-6921 Stationary Face Seal Ceramic 105413
VGFS-6922 Stationary Face Seal Silicon Carbide 105414
VGFS-6923 Wave Spring Stainless Steel 105419
VGFS-6924 Stationary Face O-Ring EPR E70154
VGFS-6925 Stationary Face O-Ring Buna N70154
VGFS-6926 Stationary Face O-Ring Viton® V70154
Outer Seal Components
VGFS-6930 Stationary Face Seal Carbon 105418
VGFS-6931 Wave Spring Stainless Steel 105420
VGFS-6932 Stationary Face O-Ring EPR E70160
VGFS-6933 Stationary Face O-Ring Buna N70160
VGFS-6934 Stationary Face O-Ring Viton® V70160
Mating Ring Components
VGFS-6940 Rotary Face O-Ring EPR E70149
VGFS-6941 Rotary Face O-Ring Buna N70149
VGFS-6942 Rotary Face O-Ring Viton® V70149
VGFS-6943 Rotary Face Seal Seat Ceramic 105416
VGFS-6944 Rotary Face Seal Seat Silicon Carbide 105417
Value Guard Seal Seal Material
Part No. Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
U2 210, 320, 324
VGFS-6900 Single 3 QL-CF
VGFS-6901 Single 3 QL-LF
VGFS-6902 Single 3 VL-CF
VGFS-6903 Single 3 VL-LF
VGFS-6904 Double 3 QC/J-JF
VGFS-6905 Double 3 QC/L-LF
VGFS-6906 Double 3 QJ-CF
VGFS-6907 Double 3 QL-LF
VGFS-6908 Double 3 VC/J-JF
VGFS-6909 Double 3 VC/L-LF
VGFS-6910 Double 3 VJ-CF
VGFS-6911 Double 3 VL-LF
* Includes Seals, O-Rings and Wave Springs for One Shaft (Two Required Per Pump)
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Seal Material
Part No. Type Size Code
Value Guard Materials of
Part No. Component Construction Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
200 Series Components
VGFS-7002 Oversized Cup Viton® 9-37
VGFS-7003 Rotary Face Carbon 9-225A
VGFS-7004 Rotary Face Silicon Carbide 9-225C
VGFS-7005 Rotary Face Tungsten Carbide 9-225F
VGFS-7006 Oversized Mating Ring Silicon Carbide 23-17
VGFS-7007 Oversized Cup Mating Ring V--L- 23-17V
VGFS-7008 Retainer Spring Stainless Steel 23-77
VGFS-7009 Seal Retainer Stainless Steel 23-79
VGFS-7010 Coil Spring Stainless Steel 24-65
VGFS-7011 Wave Spring Stainless Steel 24-65Z
VGFS-7012 Tabbed Washer Stainless Steel 43-87
• Kits include rotary face, O-rings,
and oversized cup mating ring.
Value Guard Seal Seal Material
Part No. Kit Type Type Size Code Mfg. Part No.
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
200 Series Seal Kits
VGFS-7000 Single 1-3/4 VC-L
VGFS-7001 Single 1-3/4 VL-Z
WAUKESHA® CHERRY-BURRELL® - PD PUMP -
Replacement Seals for Food, Dairy & Beverage Processing
Model 2045 - Seal Kits
VGFS-7020 1 Basic Single 1-1/2 VC--- 309-241
VGFS-7021 1 Complete Single 1-1/2 VC-L- 309-245
VGFS-7022 4 Basic Double 1-3/4 VC--- 309-249
VGFS-7023 4 Complete Double 1-3/4 VC-L- 309-253
Model 2065 / 2065HV / 2065LV - Seal Kits
VGFS-7030 1 Basic Single 1-1/2 VC--- 309-242
VGFS-7031 1 Complete Single 1-1/2 VC-L- 309-246
VGFS-7032 4 Basic Double 1-3/4 VC--- 309-250
VGFS-7033 4 Complete Double 1-3/4 VC-L- 306-254
Model 2075 / 2085 / 2085LV - Seal Kits
VGFS-7040 1 Basic Single 1-1/2 VC--- 309-243
VGFS-7041 1 Complete Single 1-1/2 VC-L- 309-247
VGFS-7042 4 Basic Double 1-3/4 VC--- 309-251
VGFS-7043 4 Complete Double 1-3/4 VC-L- 309-255
Model 2105 - Seal Kits
VGFS-7050 1 Basic Single 1-1/2 VC--- 309-244
VGFS-7051 1 Complete Single 1-1/2 VC-L- 309-248
VGFS-7052 4 Basic Double 1-3/4 VC--- 309-252
VGFS-7053 4 Complete Double 1-3/4 VC-L- 309-256
• Type 1 Basic Kit includes casing o-ring, impeller o-ring, rotary face and rotary o-ring.
• Type 4 Basic Kit includes casing o-ring, impeller o-ring, rotary faces, rotary o-rings and seal housing o-rings.
• Type 1 Complete Kit includes casing o-ring, impeller o-ring, L-gasket, rotary face and rotary o-ring.
• Type 4 Complete Kit includes casing o-ring, impeller o-ring, L-gaskets, rotary faces, seal housing o-rings, stationary faces and stationary o-rings.
VGFS-7021
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
WAUKESHA MOTORS
PS-642 B — — 5/8 BMF-F 102320 & 20B
PS-1522 A — — 3/4 BMF-F 810350
PS-201 A 1 1.375 3/4 BMFJF 152243-B
PS-647 B — — 3/4 BMF-F 120828
PS-752 D 1 1.375 3/4 BCDKF
PS-685 R 1 1.500 7/8 BCDKF 108025
PS-1619 B 1 1.625 1 BCDJF 117177G-J
PS-380 D 1 1.625 1 BCFJF
PS-604 D 1 1.750 1-1/8 BCFJF 157475, 157475E
157475K
PS-185 C 1 1.875 1-1/4 BCFJF 178033
WAYNE COMBUSTION SYSTEM
PS-162 A 1 1.000 1/2 BMFJF 15717 / 56106
PS-163 B 1 1.000 1/2 BMFJF 15863 / 56108
PS-400 C — — 1/2 BMF-F 15189
PS-1137 Q 1 1.000 1/2 BMFJF 15780 / 56107
PS-200 A 1 1.250 5/8 BMFJF Series SJ-CJX 15559 / 56104
PS-642 B — — 5/8 BMF-F
PS-1000 B 1 1.250 5/8 BMFJF 15996 / 56109
PS-1155 C 1 1.187 5/8 BCFJF Series J and S 15529
PS-201 A 1 1.375 3/4 BMFJF 15693 / 56105
PS-201V A 3 1.375 3/4 VCFJF 16229
WAYNE PUMPS
PS-150 B — — 1/2 BMF-F 16722
PS-974 A — — 3/4 BCF-F 16829
PS-1522 A — — 3/4 BMF-F 16725
WAYNE WATER SYSTEMS
PS-200-EPR A 1 1.250 5/8 QCFJF CJX, SJD, SW 56393
PS-201V-CMS A 1 1.375 3/4 VCFJF 2-1/2” & 3 HP 56112
PS-4106 B 1 1.375 3/4 VCFJF 316SS 16993-001/16995-001
WDM PUMPS
PS-354V E 3 2.000 1-3/8 VCFJF MSIXFCEA138
PS-436V C 3 2.500 1-3/4 VCFKF MS21XFNRAC134
WEBER INDUSTRIES, INC.
PS-3228 A 1 1.250 5/8 VCFJF 316SS 70X130-M
PS-359V-CMS C 1 1.250 5/8 VCFJF 70X120-M
PS-3677 D 3 1.250 5/8 BCDLF 70X110-M
PS-851 A 1 1.375 3/4 BCFJF 70X107-M
PS-358V-CMS C 1 1.375 3/4 VCFJF 70X121-M
PS-356V-CMS C 1 1.750 1-1/8 VCFJF 70X118-M
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 70X123-M
PS-446V-CMS C 1 2.500 1-3/4 VCFJF 70X125-M
WEBSTER ELECTRIC
PS-218 A — — 5/8 BCF-F
PS-467 C 1 2.125 1-3/8 BCFKF 151-26815
WEIL PUMP CO., INC.
PS-100 A 1 1.187 5/8 BMFJF 1-1/4” Submersible 17-30009-005, 330.009.005
PS-600 B 1 1.187 5/8 BMFJF
PS-1000 B 1 1.250 5/8 BMFJF
PS-989 C 1 1.187 5/8 N/BCFJF B
PS-851 A 1 1.375 3/4 BCFJF 17-62372-008
PS-358 C 1 1.375 3/4 BCFJF 205.016.101
PS-358V-CMS C 1 1.375 3/4 VCFJF 205.093.101
PS-750 D 1 1.375 3/4 BCDJF X1397, X2372
PS-617 C 3 1.500 7/8 BCFKF X3452
PS-380 D 1 1.625 1 BCFJF X992
PS-2033 D 3 1.625 1 BCFJF 17-62427-000
PS-754 E 1 1.625 1 BCFJF X993
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
WEIL PUMP CO., INC. (continued)
PS-356 C 1 1.750 1-1/8 BCFJF 137-000-129
PS-604 D 1 1.750 1-1/8 BCFJF X2428
PS-802 D 3 1.750 1-1/8 BCFJF Springholder by Customer 17-62428-008, 362.432.000
PS-204 E 1 1.750 1-1/8 BCFJF
PS-384 E 1 1.750 1-1/8 BCFKF X-217UKY
PS-866 E 3 1.750 1-1/8 BCFJF 17-61117-008
PS-381 D 1 1.875 1-1/4 BCFJF X2174, X-2429UKY
PS-804 D 3 1.875 1-1/4 BCFJF 17-62429-006
PS-3184 K 3 2.000 1-1/4 BCFJF 305.511.001
PS-1623 K 3 2.125 1-1/4 BCFJ/KF 17-05511-001
PS-210 C 1 2.000 1-3/8 BCFKF Model AS
PS-758 C 1 2.125 1-1/2 BCFJF 205.228.001
PS-758-SC-SC C 1 2.125 1-1/2 BLFLF 205.229.001
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 205.228.002
PS-758V-SC-SC C 1 2.125 1-1/2 VLFLF 205.229.002
PS-926 C 3 2.312 1-1/2 BCFJF
PS-514 D 1 2.375 1-5/8 BCDJF Springholder by Customer 362.432.000
PS-446-SC-SC C 1 2.500 1-3/4 BLFLF 205.311.001
PS-1142 K 3 2.500 1-3/4 BCFJ/KF 17-05514-005
PS-2069 E 1 2.625 1-7/8 BCFJF Model AYM 4x5
PS-267 C 1 2.750 2 BCFJF 205.258.001
PS-847 D 3 3.125 2-1/4 BCDKF Model AYM 5 & 6 17-62550-009
WEINMAN (Div. of CRANE PUMPS & SYSTEMS)
PS-501 A 1 1.250 5/8 BMFJF Types 4, 5, 6 & 8ACK, 4&6AEK
PS-4371 A 1 1.250 5/8 VCFJF I Q26-77-Y25
PS-3816 A 1 1.250 5/8 VCFKF I Q26-77-Y6
PS-309 C 1 1.500 7/8 BCFJF Q26-394-Y2
PS-188 E 1 1.500 7/8 BCFJF Type 2SB Q26-177-Y2
PS-245 C 1 1.625 1 BCFJF B/H Types 4AE, 6AC, 6AE, & 6AC Q26-201-Y2
PS-248 C 1 1.625 1 BCFKF B/H Types 4AE, 6AC, 6AE, & 6AC Q26-143-Y34
PS-380 D 1 1.625 1 BCFJF Q26-78-Y2
PS-4289 DB 3 1.500 1 VCFKF I Q26-409-Y6
PS-204 E 1 1.750 1-1/8 BCFJF Q26-184-Y2
PS-867 E 3 1.750 1-1/8 BCFKF Q26-102-Y34
PS-228 K 3 1.875 1-1/4 BCFKF FR#11, 3UE-B11, 4UD-B11, 4UE-B11 Q26-190-Y34
PS-185 C 1 1.875 1-1/4 BCFJF Q26-395-Y2
PS-246 C 1 1.875 1-1/4 BCFJF B/H Group A-Type 1G, 1-1/4G, 1-1/2G, Q26-166-Y2
1-1/2K, 1-1/2KH, 2G, GB, and KB.
Group B-7-1/2. HP & Less at 1750:
20 HP & less at 3500 RPM Types.
1-1/2KH,2K, 2-1/2G, 2-1/2K, 3G, 3K,
4GL, and 4G
PS-185-P66 C 1 1.875 1-1/4 BCFJF I Q26-395-Y21
PS-249 C 1 1.875 1-1/4 BCFKF B/H Q26-276-Y34
PS-756 C 1 1.875 1-1/4 BCFKF 1G2A30P12G-D Q26-395-Y34
PS-185-TC-SEAT C 1 1.875 1-1/4 BCFZF Q26-395-Y10
PS-185-SC-SC C 1 1.875 1-1/4 BLFLF Q26-395-Y39
PS-4464 C 1 1.875 1-1/4 QCFKF 316SS Q26-395-Y53
PS-4029 C 1 1.875 1-1/4 QCFZF 316SS Q26-395-Y30
PS-1082 C 1 1.875 1-1/4 NCFKF Q26-395-Y24
PS-185V-CMS-P66 C 1 1.875 1-1/4 VCFJF I Q26-395-Y25
PS-185V-TC-SEAT C 1 1.875 1-1/4 VCFZF Q26-395-Y17
PS-756V C 3 1.875 1-1/4 VCFKF Q26-395-Y47
PS-381 D 1 1.875 1-1/4 BCFJF Q26-79-Y2
PS-383 D 1 1.875 1-1/4 BCFKF Q26-5-Y34
PS-361 E 1 1.875 1-1/4 BCFJF When Seal is Mounted on Shaft: Q26-243-Y2
2L-4, 5, 6, 3L-6, 4L3, 5L3
PS-264 E 3 1.875 1-1/4 BCFKF Q26-243-Y34
PS-137V-P66 E 3 1.875 1-1/4 VCFKF I Q26-243-Y6
PS-3587 CB 3 1.875 1-3/8 BCFZF S
PS-4119 CB 3 1.875 1-3/8 VCFKF S Q26-415-Y47
PS-7702 EB 3 1.875 1-3/8 BCFJF Q26-318-Y2
PS-4145 EB 3 1.875 1-3/8 BCFZF Q26-318-Y10
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
b. TApereD SprING
H. SprING HOLDer NOT INCLUDeD
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
WEINMAN (Div. of CRANE PUMPS & SYSTEMS) (continued)
PS-3769 EB 3 1.875 1-3/8 VCFZF I Q26-318-Y17
PS-347 C 1 2.125 1-1/2 BCFJF B/H Group B-10 HP, Over at 1750; 25 HP Q26-167-Y2
Over at 3500 RPM 1-1/2KH, 2K,
2-1/2G, 2-1/2K, 3G, 3K, 4GL, 4G.
Group C TYP.- 2-1/2KH.
PS-378 C 1 2.125 1-1/2 BCFKF B/H Q26-175-Y34
PS-305 E 1 2.125 1-1/2 BCFJF When Seal is Mounted on Sleeve: Q26-264-Y2
2L-4, 2L-5, 3L-6, 4L-2, 4L-3, 5L-3
When Seal is Mounted on Shaft:
2-1/2JC, 3L-4, 3L-5, 4L-1, 5L-2, 6L-2,
6L03
PS-374 E 1 2.125 1-1/2 BCFKF Q26-265-Y34
PS-395 E 3 2.125 1-1/2 BCFJF Q26-178-Y2
PS-258 E 3 2.125 1-1/2 BCFKF Q26-178-Y34
PS-305V-P66 E 3 2.125 1-1/2 VCFJF I Q26-178-Y25
PS-374V E 3 2.125 1-1/2 VCFKF Q26-178-Y47
PS-818 C 3 2.375 1-5/8 BCFJF Q26-373-Y2
PS-544 C 3 2.375 1-5/8 BCFKF Q26-373-Y34
PS-3171 C 3 2.375 1-5/8 VCFJF I Q26-373-Y25
PS-239V C 3 2.375 1-5/8 VCFKF Q26-373-Y47
PS-2057 E 1 2.375 1-5/8 BCFJF When Seal is Mounted on Shaft: Q26-240-Y03
Type 3JC, 4L-4, 5L-1, 8L-3
PS-2058 E 1 2.375 1-5/8 BCFKF Q26-241-Y35
PS-1699 E 3 2.375 1-5/8 BCFKF Q26-240-Y35
PS-3183 E 3 2.375 1-5/8 VCFKF I Q26-240-Y6
PS-205 E 1 2.500 1-3/4 BCFJF When Seal is Mounted on Sleeve: Q26-222-Y2
Type 3L-4, 3L-5, 4L-1, 5L-2, 6L-2, 6L-3
When Seal is Mounted on Shaft: 2-1/2JC
PS-205-P66 E 1 2.500 1-3/4 BCFJF I Q26-179-Y21
PS-366 E 1 2.500 1-3/4 BCFKF Q26-223-Y34
PS-205V-CMS-P66 E 1 2.500 1-3/4 VCFJF I Q26-179-Y25
PS-535 E 3 2.500 1-3/4 BCFJF Q26-217-Y2
PS-262 E 3 2.500 1-3/4 BCFKF Q26-217-Y34
PS-3540 E 3 2.500 1-3/4 QZFZF
PS-7774 EB 3 2.375 1-3/4 BCFJF Q26-319-Y2
PS-2231 EB 3 2.375 1-3/4 BCFKF Q26-304-Y34
PS-7821 EB 3 2.375 1-3/4 BCFZF Q26-304-Y10
PS-449 K 1 2.500 1-3/4 BCFJF Frame #12-3UE, 4UD, 4UE-B12 Q26-191-Y2
Frame #13: 4UF, 5UF, 6UG-B13
PS-2170 U 3 2.500 1-3/4 BCFJF Q26-179-Y2
PS-4488 UB 3 2.375 1-3/4 BCFZF
PS-479 E 1 2.750 2 BCFJF When Seal is Mounted on Shaft: Q26-267-Y2
6L-1, 8L-2, 10L-2, 10L-3
When Seal Mounted on Sleeve:
4L-4, 5L-1, 8L-3
PS-477 E 3 2.750 2 BCFKF Q26-268-Y34
PS-7892 EB 3 2.625 2 BCFKF Q26-305-Y34
PS-4102 EB 3 2.625 2 VCFZF 5L1
PS-385A U 3 2.750 2 BCFKF 3JC and 5LI Split Case Q26-180-Y34
PS-4468 U 3 2.750 2 VCFLF Q26-180Y52
PS-4391 U 3 2.750 2 VLFLF 8L2
PS-3784 EB 3 3.000 2-1/4 BCFJF Q26-306-Y2
PS-3643 EB 3 3.000 2-1/4 B/VCFKF Q26-306-Y34
PS-7749 EB 3 3.000 2-1/4 BCFZF Q26-306-Y10
PS-278 E 3 3.250 2-3/8 BCFJF When Seal is Mounted on Shaft: Q26-181-Y2
8L-1, 12L-2. When Seal is Mounted Q26-273-Y2
on Sleeve: 6L-1, 8L-2, 10L-3
PS-350 E 3 3.250 2-3/8 BCFKF Q26-181-Y34
Q26-275-Y34
PS-350V-P66-TC E 3 3.250 2-3/8 VCFZF I Q26-181-Y17
PS-2158 K 1 3.375 2-1/2 BCFJF Q26-406-Y2
PS-279 E 3 3.375 2-1/2 BCFJF Pump Type 10L-2, Seal is Mtd. on Sleeve Q26-182-Y2
PS-349 E 3 3.375 2-1/2 BCFKF Q26-198-Y34
PS-542 E 3 3.375 2-5/8 BCFKF Q26-408-Y35
PS-7927 EB 3 3.375 2-5/8 BCFKF Q26-340-Y34
PS-4485 EB 3 3.375 2-5/8 BLFZF
PS-324SS E 3 3.875 3 BCFJF Type 8L-1, 12L-2 Seal is Mtd. on Sleeve Q26-199-Y2
PS-5252 E 3 3.875 3 BCFKF Q26-183-Y35
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
Lower Seal
• Spring is covered by an elastomer boot which
prevents seal clogging from stringy waste material.
• Durable Viton® elastomers and Tungsten Carbide
rotating face.
• Sintered Silicon Carbide mating ring is standard.
• Dimensionally equivalent to the accompanying
upper seal.
Hidrostal® Type G & X Seal Types Also Available
WEIR SPECIALTY PUMPS
PS-356 C 1 1.750 1-1/8 BCFJF 157257
PS-3234 C 1 1.750 1-1/8 VZFLF 157548
PS-758 C 1 2.125 1-1/2 BCFJF 157258
PS-3166 C 1 2.125 1-1/2 BZFLF 316SS 157646
PS-2209 C 1 2.125 1-1/2 BZFZF 52597
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 157549
PS-7409 C 1 2.125 1-1/2 VCFJF 316SS 157256
PS-3558 K 3 2.375 1-1/2 BCFJF 157319
PS-3236 K 1 2.500 1-3/4 BZFZF 157442
PS-4304 K 1 2.500 1-3/4 VZFZF 157472
PS-4353 K 3 2.500 1-3/4 BCFJF 157172
PS-267 C 1 2.750 2 BCFJF 157259
PS-267V-CMS C 1 2.750 2 VCFJF 157554
PS-4343 K 3 2.750 2 BZFZF/ 804820
BCFJF
PS-1679 C 1 3.125 2-1/4 BCFJF 52600
PS-2120 C 1 3.375 2-1/2 BCFJF 157599
PS-4109 T 3 3.375 2-1/2 VZFLF 316SS 800724
PS-3235 C 1 3.875 3 BCFJF 316SS 157260
WELLS BLOOMFIELD
PS-359 C 1 1.250 5/8 BCFJF 35902
WEMCO (Div. of WEIR SPECIALTY PUMPS)
PS-541 K 1 2.125 1-1/2 BCFJF 157174
WEMCO® - HIDROSTAL
Type M Replacement Seals
VG-7085 VG714 1-1/8 VZFLF Lower Seal 157261
PS-356 C 1 1.750 1-1/8 BCFJF Upper Seal 157257
VG-7086 VG714 1-1/2 VZFLF Lower Seal 157262
PS-758 C 1 2.125 1-1/2 BCFJF Upper Seal 157258
VG-7087 VG714 2 VZFLF Lower Seal 157263
PS-267 C 1 2.750 2 BCFJF Upper Seal 157259
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
WESTINGHOUSE
PS-663 Q 1 1.000 1/2 BMFJF 69782
WHEELER, C.H.
PS-218 A — — 5/8 BCF-F
PS-702 A 1 1.187 5/8 BMFJF Reuse Brass Seat Housing
WHITE
PS-701 A 1 1.187 5/8 BMFKF
PS-200 A 1 1.250 5/8 BMFJF
VG-7087
Lower Seal
PS-267
Upper Seal
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
Value Guard Seal Size Material
Part No. Head MM Code Mfg. Part No.
WILO-EMU®
VGM-2961 VGM763 35 VLFLF 6037442
VGM-2962 VGM763 50 VLFLF 6037443
VGM-2963 VGM763 75 VLFLF 6037444
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
WORTHINGTON (See FLOWSERVE CORP.)
PS-928 C — — 9/16 BCF-F 1 GA 055954-00, 74744277
PS-200 A 1 1.250 5/8 BMFJF Model 1-1/40CS-5, 1-1/4OM-5 043008-00
PS-507 A 1 1.250 5/8 BMFKF 1-1/2PM3
PS-528 A 1 1.375 5/8 BMFJF Delta 512 and 520 PO2098-00, 28518652
PS-200V A 3 1.250 5/8 VCFJF 055016-00
PS-933 C — — 5/8 BCF-F 2GAR, 2GA 055955-00
PS-359 C 1 1.250 5/8 BCFJF 050675-00
PS-359V-CMS C 1 1.250 5/8 VCFJF 055016-00, 74315409
PS-626 C 1 1.375 5/8 VCFJF Delta 520 PO2099-00
PS-951 C 3 1.375 5/8 VCFKF Delta 512 and 520 PO2752-00, 74262767
PS-201 A 1 1.375 3/4 BMFJF 1-1/2PE, 3 & 4
PS-564 C — — 3/4 BCF-F 3 & 4 GA Pumps 024439-00
PS-373 C 1 1.375 3/4 BCFKF Frame 1A, DN2 026493-00, 026492-00
PS-768 C 3 1.375 3/4 BCFKF SEL 244
PS-578 D — — 7/8 BCD-F 5 & 6 AUM
PS-936 E — — 7/8 BCF-F 5 & 6 GAUM 024440-00, 27197631
PS-560SS U 2 1.562 15/16 BCFKF Frame 1 026456-00, 031446-00
PS-370 A 1 1.625 1 BCFKF
PS-348 C — — 1-1/8 BCF-F PO2885-00, 28518934
PS-529 C 3 1.750 1-1/8 BCFKF Frame 1 D-812, 820, 1012, 1020 PO2885-00 w/ PO2893-00
PS-801 C 3 1.750 1-1/8 B/VCFJF Frame 1 D-812, 820, 1012, 1020 PO2885-00 w/ PO2897-00
PS-356V C 3 1.750 1-1/8 VCFJF Frame 1 D-812, 820, 1012, 1020 PO2889-00 w/ PO2897-00
PS-355V C 3 1.750 1-1/8 VCFKF Frame 1 D-812, 820, 1012, 1020 PO2889-00 w/ PO2893-00
PS-866 E 3 1.750 1-1/8 BCFJF Frame 1 D-1011, 1021 PO2869-00 w/ PO2897-00
PS-867 E 3 1.750 1-1/8 BCFKF Frame 1 D-1011, 1021 PO2869-00 w/ PO2893-00
PS-282 U 3 1.750 1-1/8 BCFKF 2-1/2 LR10 051610-00, 053129-00
PS-394 U 3 1.875 1-1/4 BCF/DKF 2, 2-1/2 GRM1, 3GRWMCI 03144800, 74295924
PS-394V U 3 1.875 1-1/4 VCF/DKF 03144801, 78945442
PS-805 C 3 2.000 1-3/8 BCFJF Frame 2 D-812, 820, 1012, 1020 PO2886-00 w/ PO2898-00
PS-547 C 3 2.000 1-3/8 BCFKF Frame 2 D-812, 820, 1012, 1020 PO2886-00 w/ PO2894-00
PS-177V C 3 2.000 1-3/8 VCFJF Frame 2 D-812, 820, 1012, 1020 PO2890-00 w/ PO2898-00
PS-210V C 3 2.000 1-3/8 VCFKF Frame 2 D-812, 820, 1012, 1020 PO2890-00 w/ PO2894-00
PS-864 E 3 2.000 1-3/8 BCFJF Frame 2 D-811, 821, 1011, 1021 PO2870-00 w/ PO2898-00
PS-865 E 3 2.000 1-3/8 BCFKF Frame 2 D-811, 821, 1011, 1021 PO2870-00 w/ PO2894-00
PS-561SS U 1 2.000 1-3/8 BCFKF Frame 2 2-1/2 LR-13 050498-00, 026457-00
272150-94
PS-2106V E — — 1-1/2 VCF-F 605061-69
PS-395 E 3 2.125 1-1/2 BCFJF 3LR-9, 4, 5 & 6LR-10, 3LR-12, 051708-00 w/ 053130-00
4LR-12, 1-1/2LLR-7, 1-1/2LLR-10,
2LLR-9
• Replacement Seals for EBS® double
cartridge seals
• Materials of Construction -
Viton® / Silicon Carbide / Silicon Carbide / 304SS
• Seal Repair Kits available upon request
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
I. AbrASION reSISTANT CArbON (p66)
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
WORTHINGTON (See FLOWSERVE CORP.) (continued)
PS-258 E 3 2.125 1-1/2 BCFKF 3LR-9, 4, 5, & 6LR-10, 3LR-12,
4LR-12, 1-1/2LLR-7, 1-1/2LLR-10,
2LLR-9
PS-458 U 3 2.375 1-5/8 BCDKF 4LR-14, 5LR-13, 4LR-11 051613-00 w/ 053132-00
PS-2108 C — — 1-3/4 BCF-F PO2887-00, 28518876
FA-10045 C — — 1-3/4 VCF-F PO2891-00
PS-550 C 3 2.500 1-3/4 BCFJF Frame 3 D-812, 820, 1012, 1020 PO2887-00 w/ PO2899-00
PS-436 C 3 2.500 1-3/4 BCFKF Frame 3 D-812, 820, 1012, 1020 PO2887-00 w/ PO2895-00
PS-7679 C 3 2.500 1-3/4 VLFLF
PS-535 E 3 2.500 1-3/4 BCFJF Frame 3 D-811, 821, 1011, 1021 PO2871-00 w/ PO2899-00
PS-262 E 3 2.500 1-3/4 BCFKF Frame 3 D-811, 821, 1011, 1021 PO2871-00 w/ PO2895-00
PS-555 U 1 2.500 1-3/4 BCF/DKF Frame 3 026458-00
PS-555SS U 1 2.500 1-3/4 BCFKF Frame 3 050499-00
PS-2070 E 1 2.625 1-7/8 BCFKF 4GRWM 031449-00
PS-1108 V 1 2.625 1-7/8 BMFJF 4FNC-10
PS-582 C 3 3.000 2 BCFKF
PS-477 E 3 2.750 2 BCFKF 2” HBL, 4GRM, 5GRWM 031450-00
PS-477V E 3 2.750 2 VCFKF 031450-01, 78945368
PS-456 U 3 2.750 2 BCFKF 5LR-15, 6LR-13, 6LR-16, 8LR-13 051614-00 w/ 053133-00
PS-385A U 3 2.750 2 BCFKF 8LR-14
PS-854 C 3 2.875 2-1/8 BCFJF Frame 4 D-1012, 1020 PO2888-00 w/ PO2900-00
PS-855 C 3 2.875 2-1/8 BCFKF Frame 4 D-1012, 1020 PO2888-00 w/ PO2896-00
PS-856 E 3 2.875 2-1/8 BCFJF Frame 4 D-1011, 1021 PO2872-00 w/ PO2900-00
PS-857 E 3 2.875 2-1/8 BCFKF Frame 4 D-1011, 1021 PO2872-00 w/ PO2896-00
PS-556 U 1 3.000 2-1/8 BCFKF Frame 4 026459-00, 050500-00
PS-475 E 3 3.875 3 BCDKF 6LR-18, 10LR-15 055426-00 w/ 055425-00
PS-330 E 3 4.125 3-1/4 BCDJF 6 UZD-1
XYLEM INC.
PS-2160 C 1 1.250 5/8 BCFJF DP0302
PS-4024 G 1 1.275 3/4 QLFLF P86262
PS-309 C 1 1.500 7/8 BCFJF DP0294
PS-3589 E 5 1.625 1 VCFZF DP0296
PS-6261 G 1 1.875 1-1/4 QCFJF 316SS/I P75221
PS-6260 G 1 1.875 1-1/4 QCFZF 316SS/I P75223
PS-6264 G 1 1.875 1-1/4 VCFJF 316SS/I P75225
PS-177 C 1 2.000 1-3/8 BCFJF DP0298
PS-376-EPR-P66 D — — 1-3/8 QCD-F I P63316
PS-6262 G 1 2.375 1-5/8 QCFJF 316SS/I P75222
PS-6263 G 1 2.375 1-5/8 QCFZF 316SS/I P75224
PS-2108-EPR-P66 C — — 1-3/4 QCF-F I AC5232
PS-3027 C 3 3.000 2 QCFZF AC3049
PS-3020 G 3 3.000 2-1/8 QCFJF 316SS P75396
PS-4490 G 25 3.375 2-1/2 QLFLF 316SS P5001086
PS-7909 D 3 3.375 2-5/8 BCFJF I P75572
YEOMANS CHICAGO CORP.
PS-185 C 1 1.875 1-1/4 BCFJF C3-2-57
PS-2208 C 1 1.875 1-1/4 BZFZF C3-2-72
PS-756V-CMS C 1 1.875 1-1/4 VCFKF C3-2-142
PS-383V D 3 1.875 1-1/4 VCFKF C3-2-12
PS-883 K 1 1.875 1-1/4 BCFJF C3-2-82
PS-3150 G 1 1.890 32MM VLFLF 316SS C3-2-374, 97821064
PS-210V C 3 2.000 1-3/8 VCFKF C3-2-51
PS-758 C 1 2.125 1-1/2 BCFJF C3-2-73
PS-2209 C 1 2.125 1-1/2 BZFZF C3-2-58
PS-816 C 3 2.125 1-1/2 BCFJF 98114183
PS-446 C 1 2.500 1-3/4 BCFJF C3-2-59
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
PUMP MANUFACTURERS’ CROSS-REFERENCE
NOTE:
A. MOUNTS ON SHAFT
S. SLOTTeD MATING rING
U.S. Seal Mfg. Mating Mating Seal Material
Part No. Head Ring Ring OD Size Code Notes Pump Nameplate Data Mfg. Part No.
YEOMANS CHICAGO CORP. (continued)
PS-2210 C 1 2.500 1-3/4 BCFZF C3-2-93
PS-436V C 3 2.500 1-3/4 VCFKF C3-2-100
PS-3151 G 1 2.500 1-3/4 VLFLF 316SS C3-2-376, 97809285
PS-449 K 1 2.500 1-3/4 BCFJF C3-2-43
PS-267 C 1 2.750 2 BCFJF C3-2-60
PS-842-TC-SEAT C 1 2.750 2 BCFZF C3-2-94
PS-1145 C 3 2.750 2 VCFKF C3-2-98
PS-2143 K 1 2.750 2 BCFJF C3-2-47
PS-7196 K 3 2.750 2 BCFJF S 04700050-000, 97806997
PS-3562 T 3 2.937 2-1/8 BCFKF C3-2-153, 97873617
PS-844 C 1 3.000 2-1/8 BCFJF C3-2-83
PS-887 K 1 3.000 2-1/8 BCFJF C3-2-44
PS-1679 C 1 3.125 2-1/4 BCFJF C3-2-61
PS-1676V C 3 3.125 2-1/4 VCFKF C3-2-99
PS-7932 R 1 3.125 2-1/4 BCDJF 98105544
PS-3077 R 1 3.125 2-1/4 BCFJF 00017293-000
PS-2158 K 1 3.375 2-1/2 BCFJF C3-2-53
PS-3152 C 1 3.875 3 VLFLF 316SS C3-2-274, 97809259
PS-3021 G 1 3.875 3 VLFLF 316SS C3-2-378, 97809287
PS-3518 K 1 3.875 3 BCFJF C3-2-45, 97809295
PS-3154 G 1 4.125 3-1/4 VLFLF 316SS C3-2-380, 97816952
PS-3155 K 3 6.000 5 BCFKF C3-2-55, 97873678
YORK (See JOHNSON CONTROLS)
ZODIAC POOL SYSTEMS, INC. (See JANDY)
ZOELLER PUMP CO.
PS-3033 Q 8 .906 1/2 BCFKF 005095
PS-7929 B 1 1.250 5/8 VLFLF 012240
PS-447 B 8 — 5/8 BCFJF A 001017
PS-397 C — — 1 BCF-F 007767
PS-356 C 1 1.750 1-1/8 BCFJF 006510
PS-4443 C 1 1.750 1-1/8 BCFLF 011125
PS-355-SC-SC C 1 1.750 1-1/8 BLFLF 011124
PS-356V-SC-SC-CMS
C 1 1.750 1-1/8 VLFLF 011126
PS-185 C 1 1.875 1-1/4 BCFJF 008165
PS-185-SC-SC C 1 1.875 1-1/4 BLFLF 011128
PS-2208 C 1 1.875 1-1/4 BZFZF 008166
PS-185V-CMS C 1 1.875 1-1/4 VCFJF 008177
PS-185V-SC-SEAT C 1 1.875 1-1/4 VCFLF 011131
PS-4101 C 1 1.875 1-1/4 VLFLF 316SS 011130
PS-758 C 1 2.125 1-1/2 BCFJF 006500
PS-758-SC-SEAT C 1 2.125 1-1/2 BCFLF 011132
PS-659-TC C 1 2.125 1-1/2 BCFZF 007024
PS-758-SC-SC C 1 2.125 1-1/2 BLFLF 007023
PS-2209 C 1 2.125 1-1/2 BZFZF 007011
PS-758V-CMS C 1 2.125 1-1/2 VCFJF 007027
PS-758V-SC-SEAT C 1 2.125 1-1/2 VCFLF 011133
PS-758V-SC-SC C 1 2.125 1-1/2 VLFLF 011134
PS-659V-TC-VS-TC C 1 2.125 1-1/2 VZFZF 007026, 008180
PS-446 C 1 2.500 1-3/4 BCFJF 008168
PS-6210 C 1 2.500 1-3/4 BZFZF 008169
PS-340 C 1 2.625 1-7/8 BCFJF 007131
PS-340-TC-SC C 1 2.625 1-7/8 BZFLF 011139
PS-340-TC-TC C 1 2.625 1-7/8 BZFZF 007440
PS-267 C 1 2.750 2 BCFJF 008171
U.S. Seal Mfg. Tel: 800-243-5489 Fax: 877-849-7325 www.ussealmfg.com
