cfMesh v1.1
User Guide
Document version: 1.1
Principal developer and document author:
Dr. Franjo Juretić, M. Eng., Assist. Prof.
Managing Director and Founding Partner
Creative Fields, Ltd.
Zagreb, May 2015
1
Contents
1. Introduction ................................................................................................................................................................2
2. Available meshing workflows .....................................................................................................................................2
2.1. Cartesian....................................................................................................................................................3
2.2. 2D Cartesian ..............................................................................................................................................4
2.3. Tetrahedral.................................................................................................................................................5
2.4. Polyhedral ..................................................................................................................................................6
3. Input geometry ...........................................................................................................................................................7
4. Required dictionaries and available settings .............................................................................................................9
4.1. Dictionaries ................................................................................................................................................9
4.2. Mandatory settings in meshDict ................................................................................................................9
4.3. Refinement settings in meshDict ...............................................................................................................9
4.4. Keeping/removing of cells in user-defined regions ................................................................................. 14
4.5. Boundary layers ...................................................................................................................................... 16
4.6. Anisotropic meshing ............................................................................................................................... 18
4.7. Workflow controls ................................................................................................................................... 19
4.8. Renaming patches .................................................................................................................................. 20
4.9. Enforcing geometry constraints .............................................................................................................. 22
5. Utilities .................................................................................................................................................................... 23
Appendix A: Installation instructions ............................................................................................................................... 24
2
1. Introduction
cfMesh is a cross-platform library for automatic mesh generation that is built on top of OpenFOAM®
1
. It is
licensed under GPL, and compatible with all recent versions of OpenFOAM® and foam-extend.
cfMesh supports various 3D and 2D workflows, built by using components from the main library, which are
extensible and can be combined into various meshing workflows. The core library utilises the concept of mesh
modifiers, which allows for efficient parallelisation using both shared memory parallelisation (SMP) and
distributed memory parallelisation using MPI. In addition, special care has been taken on memory usage,
which is kept low by implementing data containers (lists, graphs, etc.) that do not require many dynamic
memory allocation operations during the meshing process.
2. Available meshing workflows
Meshing workflows implemented in cfMesh require input geometry in a form of surface triangulation, shown in
Figure 1, and the user-specified settings, which will be explained in detail in subsequent sections. All
workflows are parallelised for shared memory machines and use all available computer cores while running.
The number of utilised cores can be controlled by the OMP_NUM_THREADS environment variable, which
can be set to the desired number of cores.
Figure 1 – Surface mesh
Currently available meshing workflows start the meshing process by creating a so-called mesh template from
the input geometry and the user-specified settings. The template is later on adjusted to match the input
geometry. The process of fitting the template to the input geometry is designed to be tolerant to poor quality
input data, which does not need to be watertight. The available workflows differ by the type of cells generated
in the template.
1
None of the OpenFOAM® related offering by Creative Fields, Ltd., including cfMesh, is approved or endorsed by OpenCFD, Ltd. (ESI
Group), producer of the OpenFOAM® software. OpenFOAM® and OpenCFD® are registered trade marks of ESI Group.
3
2.1. Cartesian
Cartesian workflow generates 3D meshes consisting of predominantly hexahedral cells with polyhedra in the
transition regions between the cells of different size. It is started by typing cartesianMesh in a shell window.
By default, it generates one boundary layer, which can be further refined on user request. In addition, this
workflow can be run using MPI parallelisation, which is intended for generation of large meshes, which do not
fit into the memory of a single available computer. An example of the mesh generated by cartesianMesh is
shown in Figure 2 and Figure 3.
Figure 2 – Volume mesh generated by cartesianMesh
Figure 3 – Detail of the mesh generated by cartesianMesh
4
2.2. 2D Cartesian
It generates 2D meshes and is started by typing cartesian2DMesh in the console. By default it generates one
boundary layer which can be further refined. The geometry is given in a form of a ribbon in the x-y plane and
extruded in the z direction, shown in Figure 4. An example of final mesh is given in Figure 5.
Figure 4 – Input geometry for the cartesian2DMesh
Figure 5 – Mesh generated by cartesian2DMesh
5
2.3. Tetrahedral
Tetrahedral workflow generates meshes consisting of tetrahedral cells and is started by typing tetMesh in a
console. By default, it does not generate any boundary layers, and they can be added and refined on user
request. An example of a tetrahedral mesh generated by this workflow is given in Figure 6 and Figure 7.
Figure 6 – Mesh generated by tetMesh
Figure 7 – Detail of the mesh generated by tetMesh
6
2.4. Polyhedral
Polyhedral workflow is a new concept for generating meshes consisting of arbitrary polyhedral cells. The
meshing process starts by typing pMesh in a console. It is applicable to dirty geometries and is optimised to
memory usage. An example of a polyhedral mesh generated by this workflow is given in Figure 8 and Figure
9.
Figure 8 – Mesh generated by pMesh
Figure 9 - Detail of the mesh generated by pMesh
7
3. Input geometry
cfMesh requires geometries in the form of a surface triangulation. For 2D cases, the geometry is given in a
form of a ribbon of triangles with boundary edges in the x-y plane (other orientations are not supported).
The geometry consists of the following entities:
List of points – contains all points in the surface triangulation.
List of triangles – contains all triangles in the surface mesh.
Patches are entities that are transferred onto the volume mesh in the meshing process. Every triangle
in the surface is assigned to a single patch, and cannot be assigned to more than one patch. Each
patch is identified by its name and type. By default, all patch names and types are transferred on the
volume mesh, and are readily available for definition of boundary conditions for the simulation.
Facet subsets are entities, which are not transferred onto the volume mesh in the meshing process.
They are used for definition of meshing settings. Each face subset contains indices of triangles in the
surface mesh. Please note that a triangle in the surface mesh can be contained in more than one
subset.
Feature edges are treated as constraints in the meshing process. Surface points where three or more
feature edges meet are treated as corners. Feature edges can be generated by the
surfaceFeatureEdges utility.
The user must define all sharp features transferred by the cfMesh prior to the meshing process. The edges at
the border between the two patches and the feature edges are handled as sharp features in the meshing
process. Other edges in the triangulation are not constrained. Figure 10 shows a surface mesh with a patch
highlighted in green, a facet subset coloured in blue and user-selected feature edges coloured in red.
Figure 10 – Geometry with entities
8
The file formats suggested for meshing are: fms, ftr, and stl. In addition, the geometry can be imported in all
formats supported by the surfaceConvert utility, which comes with OpenFOAM®. In addition, cfMesh also
provides additional utilities for conversion of surface mesh into fms and from fms to other formats. However,
the three suggested formats support definition of patches, which are transferred onto the volume mesh by
default. Other formats can also be used for meshing but they do not support definition of patches in the input
geometry and all faces at the boundary of the resulting volume mesh end up in a single patch.
The preferred format for cfMesh is fms, designed to hold all relevant information for setting up a meshing job.
It stores patches, subsets, and feature edges in a single file. In addition, it is the only format, which can store
all geometric entities into a single file, and the users are strongly encouraged to use it. An example of the
surface mesh written in fms is depicted in Figure 11.
Figure 11 – Structure of the fms geometry file format
9
4. Required dictionaries and available settings
4.1. Dictionaries
The meshing process is steered by the settings provided in a meshDict dictionary located in the system
directory of the case. For parallel meshing using MPI, a decomposeParDict located in the system directory of
a case is required, and the number of nodes used for the parallel run must match the numberOfSubdomains
entry in decomposeParDict. Other entries in decomposeParDict are not required.
The resulting volume mesh is written in the polyMesh directory inside the constant directory. The settings
available in meshDict will be handled in the remainder of this section.
4.2. Mandatory settings in meshDict
cfMesh requires only two mandatory settings (see Figure 12) to start a meshing process:
surfaceFile points to a geometry file. The path to the geometry file is relative to the path of the case
directory.
maxCellSize represent the default cell size used for the meshing job. It is the maximum cell size
generated in the domain.
Figure 12 – Mandatory settings
4.3. Refinement settings in meshDict
Quite often a uniform cell size is not satisfactory, and there are many options for local refinement sources in
cfMesh. boundaryCellSize option is used for refinement of cells at the boundary. It is a global option and the
requested cell size is applied everywhere at the boundary. An example is given in Figure 13.
boundaryCellSizeRefinementThickness specifies the distance from the boundary at which the
boundaryCellSize is still applied. minCellSize is a global option which activates automatic refinement of the
mesh template. This option performs refinement in regions where the cells are larger than the estimated
feature size. The scalar value provided with this setting, specifies the smallest cell size allowed by this
procedure, see Figure 13. This option is useful for quick simulation because it can generate meshes in
complex geometry with low user effort. However, if high mesh quality is required, it provides hints where some
mesh refinement is needed.
Figure 13 – boundaryCellSize and minCellSize
10
localRefinement allows for local refinement regions at the boundary. It is a dictionary of dictionaries and each
dictionary inside the main localRefinement dictionary is named by a patch or facet subset in the geometry that
is used for refinement, see Figure 14. The requested cell size for an entity is controlled by the cellSize
keyword and a scalar value, or by specifying additionalRefinementLevels keyword and the desired number of
refinements relative to the maximum cell size. It is possible to specify patches via regular expressions. The
thickness of the refinement zone can be specified by the refinementThickness option.
Figure 14 – localRefinement
objectRefinement is used for specifying refinement zones inside the volume. The supported objects that can
be used for refinement are: lines, spheres, boxes, truncated cones, and hollow cones (annulus). It is specified
as a dictionary of dictionaries, where each dictionary inside the objectRefinement dictionary represents the
name of the object used for refinement. refinementThickness option can be used to specify the thickness of
the refinement zone away from the object. cellSize specifies the requested cell size inside the volume.
Alternatively, additionalRefinementLevels specifies the number of additional refinement levels compared to
maxCellSize, applicable inside the volume. Available primitives and the associated settings are:
box is defined by its centre and the size in x, y, and z directions. An example is show in Figure 15.
Figure 15 - Box refinement
11
cone is intended for defining cylinders, truncated cones and cones. It is specified by two points on the
axis, and the radius at each point, see Figure 16.
Figure 16 - Cone refinement
hollowCone (annulus) is defined by two points on the axis, and two radiuses for each point. An
example is available below, Figure 17.
Figure 17 - Hollow cone refinement (annulus)
sphere is defined by its centre and the radius, Figure 18.
12
Figure 18 - Sphere refinement
line is defined by the two points, see Figure 19.
Figure 19 - Line refinement
surfaceMeshRefinement allows for using surface meshes as refinement zones in the mesh. It is specified as a
dictionary of dictionary where each refinement zone is a sub-dictionary inside the surfaceMeshRefinement
dictionary. Surface mesh used for the refinement zone is provided with the surfaceFile keyword, and the
requested cell size for an entity is controlled by the cellSize keyword and a scalar value, or by specifying
additionalRefinementLevels keyword and the desired number of refinements relative to the maximum cell
size. Currently, the setting is used to refine the mesh in the region intersected by the surface mesh. It is
possible to control the thickness of the refinement zone via refinementThickness keyword. An example of the
available settings is given in Figure 20.
13
Figure 20 – surfaceMeshRefinement
edgeMeshRefinement allows for using edge meshes as refinement zones in the mesh. It is specified as a
dictionary of dictionary where each refinement zone is a sub-dictionary inside the edgeMeshRefinement
dictionary. Edge mesh used for the refinement zone is provided with the edgeFile keyword, and the requested
cell size for an entity is controlled by the cellSize keyword and a scalar value, or by specifying
additionalRefinementLevels keyword and the desired number of refinements relative to the maximum cell
size. Currently, the setting is used to refine the mesh in the region intersected by the edge mesh. It is possible
to control the thickness of the refinement zone via refinementThickness keyword. An example of the available
settings is given in Figure 21.
14
Figure 21 - edgeMeshRefinement
4.4. Keeping/removing of cells in user-defined regions
Meshing workflows implemented in cfMesh are based on the inside-out meshing, and the meshing process
starts by generating the so-called mesh template based on the user-specified cell size. However, if the cell
size is locally larger than the geometry feature size it may result with gaps in the geometry being filled by the
mesh. On the contrary, the mesh in thin parts of the geometry can be lost if the specified cell size is larger
than the local feature size.
keepCellsIntersectingBoundary is a global option which ensures that all cells in the template which are
intersected by the boundary remain part of the template. By default, all meshing workflows keep only cells in
the template which are completely inside the geometry. keepCellsIntersectingBoundary keyword must be
followed by either 1 (active) or 0 (inactive), see Figure 22. Activation of this option can cause locally
connected mesh over a gap, and the problem can be remedied by the checkForGluedMesh option which also
must be followed by either 1 (active) or 0 (inactive).
Figure 22 – keepCellsIntersectingBoundary and checkForGluedMesh
keepCellsIntersectingPatches is an option which preserves cells in the template in the regions specified by the
user. It is a dictionary of dictionaries, and each dictionary inside the main keepCellsIntersectingPatches
dictionary is named by patch or facet subset, see Figure 23. This option is not active when the
keepCellsIntersectingBoundary option is switched on. Patches can be specified using regular expressions.
15
Figure 23 – keepCellsIntersectingPatches subdictionary
removeCellsIntersectingPatches is an option which removes cells from the template in the regions
specified by the user. It is a dictionary of dictionaries, and each dictionary inside the main
removeCellsIntersectingPatches dictionary is named by a patch or a facet subset as shown in Figure
24. The option is active when the keepCellsIntersectingBoundary option is switched on. Patches can
be specified using regular expressions.
Figure 24 – removeCellsIntersectingPatches subdictionary
16
4.5. Boundary layers
Boundary layers in cfMesh are extruded from the boundary faces of the volume mesh towards the interior,
and cannot be extruded prior to the meshing process. In addition, their thickness is controlled by the cell size
specified at the boundary and the mesher tends to produce layers of similar thickness to the cell size. Layers
in cfMesh can span over multiple patches if they share concave edges or corners with valence greater than
three. All boundary layer settings are provided inside a boundaryLayers dictionary, shown in Figure 25. The
options are:
nLayers specifies the number of layers which will be generated in the mesh. It is not mandatory. In
case it is not specified the meshing workflow generates the default number of layers, which is either
one or zero.
thicknessRatio is a ratio between the thickness of the two successive layer. It is not mandatory. The
ratio must be larger than 1. The default value is 1.
maxFirstLayerThickness ensures that the thickness of the first boundary layer never exceeds the
specified value. It is not mandatory.
patchBoundaryLayers setting is a dictionary which is used for specifying local properties of boundary layers
for individual patches. It is possible to specify nLayers, thicknessRatio and maxFirstLayerThickness for each
patch individually within a dictionary with the name equal to the patch name. By default, the number of layers
generated at a patch is governed by the global number of layers, or the maximum number of layers specified
at any of the patches which form a continuous layer together with the existing patch. allowDiscontinuity option
ensures that the number of layers required for a patch shall not spread to other patches in the same layer.
Patches can be specified using regular expressions.
Figure 25 – boundaryLayers subdictionary
cfMesh provides additional controls of boundary layer quality, intended for situations when the large number
of layers is required, and when the thickness shall vary smoothly. Activation of the feature is controlled via the
17
optimiseLayer keyword. In addition, the parameters of the quality control procedure can also be controlled via
additional parameters given inside the optimisationParameters dictionary located inside the boundaryLayers
dictionary. The parameters available inside the optimisationParameters dictionary are:
nSmoothNormals is the number of iterations in the procedure for smoothing normal vectors in the
boundary layer. It is not mandatory, and the default value is five.
maxNumIterations is the number of iterations in the smoothing procedure. The settings is not
mandatory and its default value is five.
featureSizeFactor is the ratio between the maximum allowed layer thickness and the estimated
feature size. It is used to limit layer thickness in the regions dominated by curvature. It is not
mandatory, and its valid range is between zero and one. The default value is 0.3.
reCalculateNormals calculates the surface normal vectors, and aligns boundary-layer edges to point
in the normal direction. The setting is not mandatory, and is active by default.
relThicknessTol controls the maximum difference of the layer thickness between the two neighbouring
points, divided by the distance between the points. It is not mandatory, and the valid range is between
zero and infinity. Lower values reduce layer thickness thin and enforce uniform thickness distribution.
The above procedure does not guarantee inexistence of any negative volume cells in the boundary layer, and
by default, cfMesh performs smoothing and untangling of the layer cells until their volume becomes positive.
This procedure is activated by default, and it is possible to deactivate it using untangleLayers setting in the
boudaryLayers dictionary.
An example of settings related to boundary layer optimisation is shown in Figure 26.
Figure 26 - Boundary layer optimisation
18
4.6. Anisotropic meshing
Quite often, the physics of the solution requires anisotropic cells, in order to generate accurate solutions with
a minimum number of cells. The requirement for generating anisotropic cells is enabled via primitive objects,
used for specifying regions with anisotropic cells. The settings for anisotropic meshing are given in
anisotropicSources dictionary.
Primitive objects applicable are:
Box primitive defines the range of coordinates, and generates anisotropic cells within the whole range
of x, y, and z coordinates. The settings applicable to a box are:
o centre are the coordinates of the centre.
o lengthX is the length of the box in the x-direction.
o lengthY is the length of the box in the y-direction.
o lengthZ is the length of the box in the z-direction.
o scaleX is a scaling factor applied in the x-direction. The valid range is between zero and
infinity. Values smaller than 1 make the cells smaller in the x-direction, and value greater than
1 make the cells larger, respectively.
o scaleY is a scaling factor applied in the y-direction.
o scaleZ is a scaling factor applied in the z-direction.
Plane primitive, defined by its origin and normal, is intended for situations when the anisotropic cells
are not aligned with the main axes of the coordinate system. It generates anisotropic cells at the
positive side of the plane, within the distance specified by the user. The settings applicable to a plane
are:
o origin specifies the origin of the plane.
o normal specified the normal vector of the plane.
o scalingDistance specifies the distance from the plane in the positive direction of surface
normal. The mesher generates anisotropic cells in the in the region between the plane and
plane translated by a scaling distance.
o scalingFactor is applied in the normal direction. The valid range is between zero and infinity.
Values smaller than one make the cells smaller in the direction of the normal vector, and
value greater than one make the cells larger, respectively.
An example of anisotropicSources is given in Figure 27.
19
Figure 27 - Anisotropic sources
It is possible to use more than one anisotropic source in a single meshing job, with a restriction that their zone
of influence must not overlap. In case their zones of influence overlap, the mesher stops and reports the error.
4.7. Workflow controls
This feature enables users to save the mesh and stop the meshing process after every step in the meshing
workflow. In addition, it is possible to restart from the latest step, in case the mesh meets the expectations,
Settings are provided in a workflowControls dictionary, and the locations to save the mesh and stop the
meshing process are given after the stopAfter keyword. Possible locations in the workflow are:
1. templateGeneration – stops the meshing process after the initial template has been
generated. It is useful for checking whether the template mesh is fine enough to resolve
required geometry features.
2. surfaceTopology – stops after the surface of the mesh has been cleansed from invalid
connections of surface faces. It is useful to stop here when the settings are coarse for the
geometry under consideration.
3. surfaceProjection – instructs the mesher to stop after projection of volume mesh’s surface
on the input geometry. It is useful to stop here and check whether the mesh has been
projected to the correct locations at the input geometry.
4. patchAssignment – stops the meshing process after each boundary face is assigned a
boundary patch it belong to. It is useful to stop here and check whether feature edges are
resolved correctly.
20
5. edgeExtraction – stops the meshing process after the input geometry has been preserved in
the meshing process. It is useful for checking the quality of mesh surface, and fin locations
where modifications are need to generate the desired mesh.
6. boundaryLayerGeneration – stops the meshing process after the boundary layers have been
generated. It is useful for checking whether the topology of the layer meets the required
criteria.
7. meshOptimisation – stops after the thorough optimisation has been performed. It is useful for
checking the quality of the resulting mesh.
8. boundaryLayerRefinement - stops after the boundary layer generation process is completed.
It is useful for checking the quality of the boundary layers.
In addition, it is possible to read the mesh saved on disk and restart the workflow from the latest step by using
the restartFromLatestStep keyword in the workflowControls dictionary.
An example is presented in Figure 28
Figure 28 - Workflow controls
.
4.8. Renaming patches
The settings presented in this section are used for changing of patch names and patch types during the
meshing process. The settings are provided inside a renameBoundary dictionary with the following options:
newPatchNames is a dictionary inside the renameBoundary dictionary. It contains dictionaries with
names of patches which shall be renamed. For each patch it is possible to specify the new name or
the new patch type with the settings:
o newName keyword is followed by the new name for the given patch. The setting is not
mandatory.
o type keyword is followed by the new type for the given patch. The setting is not mandatory.
defaultName is a new name for all patches except the ones specified in newPatchNames dictionary.
The setting is not mandatory.
defaultType sets the new type for all patches except the ones specified in newPatchNames directory.
The setting is not mandatory.
Patch names can be specified using regular expressions. An example is given in Figure 29.
21
Figure 29 – renameBoundary subdictionary
22
4.9. Enforcing geometry constraints
Sometimes it is not possible to capture all geometric features during the meshing process and the acceptance
criteria are not met. enforceGeometryConstraints option stops the meshing process when it is not possible to
capture all features of the input geometry. When active, it stops the meshing process and writes a subset of
points that had to be moved away from the geometry in order to yield a valid mesh. An example is given in
Figure 30.
Figure 30 – enforceGeometryConstraints
23
5. Utilities
checkSurfaceMesh
Performs basic topology and geometric checks on the inout surface mesh, and reports the kind of probems it
could cause in the meshing process.
copySurfaceParts
It copies surface facets in a specified facet subset into a new surface mesh.
extrudeEdgesInto2DSurface
This utility extrudes edges written as feature edges in the geometry into a ribbon of triangles required for 2D
mesh generation. Generated triangles are stored in a single patch.
FLMAToSurface
It converts geometry from AVL's flma format into the format readable by cfMesh. Cell selections defined in
the input file are transferred as facet subsets.
FMSToSurface
The utility converts the data in a fms file into several files which can be imported into ParaView.
FMSToVTK
Converts fms file into ParaView’s vtm file, containing all data available in an fms file.
generateBoundaryLayers
Generates boundary layer in the volume mesh based on the settings available in meshDict.
importSurfaceAsSubset
The utility matches the triangles of the surface mesh used for meshing with the other surface, and create a
facet subset in the original surface.
improveMeshQuality
Reads the mesh from disk applies the smoother in order to improve mesh quality. The number of iterations is
controllable via optional parameters.
improveSymmetryPlanes
OpenFOAM is very sensitive to the position of points in the symmetry plane. This utility calculates the
regression plane for all vertices belonging to a symmetry plane, and ensures that all vertices lie in a plane.
mergeSurfacePatches
The utility allow the user to specify the patches in the surface mesh which shall be merge together.
meshToFPMA
This utility converts the mesh into the AVL's fpma format.
24
patchesToSubsets
It converts patches in the geometry into facet subsets.
preparePar
It creates processor directories required for MPI parallelisation. The number of processor directories is
dependent on the numberOfSubdmains specified in decomposeParDict.
removeSurfaceFacets
It is a utility for removing facets from the surface mesh. The facets that shall be removed are given by a patch
name or a facet subset.
scaleMesh
Scales the mesh by a given factor.
scaleSurfaceMesh
Scale the surface mesh by a given factor. Operates on fms files.
subsetToPatch
It creates a patch in the surface mesh consisting of facets in the given facet subset.
surfaceFeatureEdges
It is used for generating feature edges in the geometry. In case the output is a fms file, generated edges are
stored as feature edges. Otherwise it generates patches bounded by the selected feature edges.
surfaceGenerateBoundingBox
It generates a box around the geometry. It does not resolve self-intersections in case the box intersects with
the rest of the geometry.
surfaceToFMS
A converter from common surface triangulation formats into fms.
Python utilities
extractFeatureEdges.py
A script to extract feature edges from geometries created in Salome.
salomeTriSurf.py
A script for extracting a fms file from the geometry created in Salome.
Appendix A: Installation instructions
The simplest way to install cfMesh is to download the installer for OpenFOAM® and cfMesh from the
company website www.c-fields.com.
