SNAKChat
A CS 252 Lab Project
Introduction:
We have designed a chat application using PyQt GUI as the user interface and python socket
programming at the backend. Chat application supports creating of groups, group chats,
multimedia messaging, LDAP registration besides the basic chat functionality
Running the software:
Find the following -les in `SNAKChat/src` directory:
● server.py
● chatclient.py
Open a terminal on any machine on the same network as the chat server you are connecting
to and run:
$ bash script_client.sh SERVER_IP_ADDR PORT_NO username password
Enter the same value for port number as that of the chat server. The username and password
correspond to the the LDAP username and password respectively.
This should open up a GUI window.
Note: If you want to set up your own server:
Open up a terminal and run the following command:
$ bash script_server.sh SERVER_IP_ADDR PORT_NO
Specify IP Address of the machine on which server is hosted on inside the -le server.py and a
random port number in the command above
Logging In:
Logging in requires sending the credentials in the command itself.
The chat application matches the credentials with those hosted on
www.cs252lab.cse.iitb.ac.in. This authentication server can be changed by editing this url in
server.py.
If the credentials are correct, the main chat application window would open up, otherwise
you’ll have to try logging again.
Chatting:
On the left side, you will see a list of all users who are registered on the chat server. They
include all users who have logged in at least once onto the network. Click on any of the
buttons with the user names.
Now type away into the chat box in the bottom right and hit ‘Send’! Do not press ‘Enter’ inside
the textbox. I.e. no ‘\n’ characters.
Create a new group:
Click on ‘Create group’ at the bottom left of the window.. You’ll -nd additional -elds on the
window screen. Check all the users you want in the group. Enter a quirky group name for your
group (PLEASE DO NOT ENTER A SPACE IN THE NAME), submit and you’ll -nd another
button for your newly created group on the left, click on it and chat away!
Log out:
Find the Logout button on the top right corner of the application. Clicking on it closes the
application.
That’s more than enough to get you started on our chat app!
Cheers!
