Customer Engagement
EngageOne Vault
Version 7.5
Vault Installation
1 - The Vault suite of products
Overview 4
Vault service 4
Vault clients 4
Release content 5
About Vault installations 5
About server configurations 5
License keycodes 6
2 - Installing Vault and clients
Overview 8
Hardware requirements 8
Software requirements 12
Microsoft Windows installation 13
UNIX installation 21
3 - Configuring and running
Vault
Overview 32
Before you configure 32
Security 33
Configuration steps 36
Storing documents 36
Provide index information 40
Provide font and image resources 45
Start Vault processes 47
Configuring Encryption at Rest 49
Customizing the Vault environment 49
Working with Unicode data 49
Table of Contents
1 - The Vault suite of
products
The components that make up Vault support storage, display, management
and processing of composed documents in electronic environments.
In this section
Overview 4
Vault service 4
Vault clients 4
Release content 5
About Vault installations 5
About server configurations 5
License keycodes 6
Overview
Vault Server is the document repository and forms the hub of the Vault environment. This server
component can compress, store and manage documents that have been composed in a wide range
of output formats including those specifically produced by the Generate environment.
Mobile Vault is a Windows based component that allows documents to be read from a local copy
of the document Vault.
Vault service
Vault Service family of products provide a comprehensive range of access and display mechanisms
for documents stored in Vault. They are primarily aimed at users within the corporate environment;
typically customer service or other front-line personnel.
Vault Service Client provides an intuitive, high performance Windows based interface to the
documents stored within Vault. It is an executable that can be easily rolled-out to desktops as
required. This can be supplemented with Vault Service Reprint Admin which administrators can use
for compressed stream viewing and document export capabilities.
Rendering Engine allows users to build a customized interface to Vault and optionally allow you
to integrate the document display function into an existing web server environment. This is based
on a set of API functions that communicate with Vault server and return rendered documents as
required.
Vault clients
The rollout of Vault client applications such as Vault Service Client, and Vault Service Reprint Admin
involves installing the required modules from the distribution media onto the appropriate workstations.
4EngageOne Vault 7.5 Vault Installation
The Vault suite of products
Release content
Software for each supported platform is provided as a set of computer files. Within the files, there
are Vault guides in PDF. The products supplied to you will depend on the Vault licenses you hold.
Additionally, you will only be able to install products for which you have a valid license keycode. If
you believe that you have not received the correct material or keycodes please contact your Vault
supplier.
About Vault installations
This manual explains how to install Vault Server, and Vault clients. It is intended for system
administrators and professional services personnel who are responsible for installing Vault.
These instructions assume that you are familiar with the Microsoft Windows and UNIX operating
systems.
About server configurations
There are several server components in the Vault environment of which you may have one or many
installed. Some servers have non-Vault software pre-requisites. The hardware supporting the server
configuration should reflect your needs for performance and security but all machines need to be
able to communicate freely using TCP/IP sockets. All installations will include:
• Vault Server which compresses, stores and manages the datastreams containing the documents
required for archiving and display via one of the Vault Service Clients. Your installation may have
one or many Vaults.
• In a Windows environment it is recommended that Windows Server Edition is used for Vault in
order to achieve the security provisions and remote management features that are integral to
these platforms. Ensure that you apply the most up to date service packs and security fixes.
5EngageOne Vault 7.5 Vault Installation
The Vault suite of products
Integrating with Generate
Many of the components that form Generate are optional and can reside on a range of platforms or
servers which are not necessarily connected. As a result, file based methods of exchanging key
information between the components are used particularly when Vault components are part of the
environment.
License keycodes
The functions and features that are available with all Vault software are controlled by an XML license
file. Your XML license file information will be supplied to you (separately from other release material)
typically as an email attachment.
6EngageOne Vault 7.5 Vault Installation
The Vault suite of products
2 - Installing Vault and
clients
This chapter provides information on installing and configuring your Vault
environment. Vault modules in this release are supplied for use with
Microsoft Windows and UNIX (Linux, AIX and Solaris) platforms.
In this section
Overview 8
Hardware requirements 8
Software requirements 12
Microsoft Windows installation 13
UNIX installation 21
Overview
In a Microsoft Windows environment it is recommended that Microsoft Windows Server Edition
(64-bit) is used for Vault in order to achieve the security provisions and remote management features
that are integral to these platforms. Ensure that you apply the most up to date service packs and
security fixes.
Refer to Software requirements for supported operating systems.
Hardware requirements
The hardware and network configuration that supports the Vault environment is at the discretion of
the individual installation.
The performance of servers that make up the environment is often a critical issue and you must
ensure that the configuration is optimized to meet the expectations of your user community. Disk
and memory requirements will depend on the size and complexity of your Vault applications and
on what other software products are running. As with most software, the more resources you have
available the more quickly and efficiently applications will run.
Note: If a virtual environment is used, it is the responsibility of the customer to ensure that
the virtual environment, in its entirety, is up to the demands of Vault software. Due to the
variable nature of virtual environments, performance problems or concerns that result from
using a virtual environment are the responsibility of the virtual environment administrators to
manage such that sufficient host resources are allocated in order to ensure adequate
business-level performance.
More detailed recommendations are available on the following website:
www.doc1supportnet.com
Testing
Correctly planning the hardware is a critical step in a successful Vault installation. This can be
complicated by a number of factors:
• The wide variety of configurations in which Vault can be deployed.
• The wide variety of data types Vault can process and their varied characteristics.
• The difficultly in simulating the volume and load of a production environment.
8EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
To help refine your design it is highly recommended you set up a test environment to help model
the characteristics of the production deployment.
For best results:
• Ensure you load samples of each of the data formats you intend to load in production.
• Load a good volume of data.
• Load data from different cycles, runs, and dates.
You need to determine:
• The approximate size of the all the data you intend to load in production.
• The number and type of Vault processes needed to handle the volume and load of production.
• The correct configuration settings for profiles, databases, and etc.
• The appropriate number of processors and memory for each server.
• Approximate network utilization between servers.
Processor architecture
Vault consists of a number of different components including a Microsoft Windows client and several
server processes.
The Microsoft Windows client can run on practically any recent x86 processor including:
• Intel Core i3
• Intel Core i5
• Intel Core i7
• AMD A-Series
• AMD Phenom
• AMD Althon
• AMD Sempron
Vault server processes include:
• e2serverd (Vault Server)
• e2loaderd (Vault Loader)
• e2renderd (Vault Rendering Engine)
• e2routerd (Vault Router)
• indexerd (Vault Indexer as a Service)
These processes can run on the following architectures:
• x86 running Microsoft Windows or Linux
• SPARC running Solaris
• Power running AIX
Examples of these include:
9EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
• Nehalem based Intel Xeons
• Sandy Bridge based Intel Xeons
• AMD Opterons
• SPARC T3
• SPARC64 VII+
• UltraSPARC T2
• POWER7
Memory and processor cores
The memory and process cores needed on a Vault machine will depend on the number and type
of Vault processes deployed there.
For an approximate estimate use the following values:
• e2loaderd: 1-2 cores, 1-2 GB
• e2serverd: 2-4 cores, 1-2 GB
• e2renderd: 4-8 cores, 2 GB
• e2routerd: 2-4 cores, 1 GB
• indexerd: 2-4 cores, 3-4 GB
A theoretical single machine deployment using one e2loaderd, e2serverd, and e2renderd should
have 7-14 cores and 4-8 GB of memory.
A situation where there is more load typically involves adding more e2renderd instances often
grouped together using e2routerd. You may have something such as the following:
Machine 4Machines 2 and 3Machine 1
e2routerd
2-4 cores
1 GB
2 x e2renderd
8-16 cores
4 GB
e2loaderd
e2serverd
3-6 cores
2-4 GB
In general it is preferable to favor fewer, faster cores to more, slower cores.
Storage
Choosing a good storage layout is an important part to configuring Vault because:
• Vault installations usually store vast quantities of data.
10EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
• The storage system has a significant effect on the performance of Vault deployment.
While not a SQL server, choosing a storage system for Vault has many similar considerations.
The size of data normally requires a large number of drives which increases the potential rate of
drive failures. You will need to choose some method of data protection such as using RAID 5 or
RAID 10 drive arrays.
Vault server has a number of specific directories with performance consequences. Keeping these
on isolated volumes is one way to increase the total number of I/O operations the server can handle
at once.
Typically you would separate the directories into the following groups: index, data, and support. The
index directory is used in searching for and linking to documents. It typically experiences very heavy
random read and write disk I/O. The data directories consist of docdata and pagedata or storage,
depending on the configuration. You normally have heavy sequential writes and very heavy random
reads to this data. It is sometimes reasonable to further separate this area into even smaller volumes
(either by docdata/pagedata or by storage/year). The remainder of the directories serve various
purposes that are normally not as critical to performance.
Avoid
• Using storage that might not have a reliable connection to the server.
• Virus scanners, in particular real time virus scanners.
• Using a 32-bit operating system. A 64-bit operating system will generally have a higher threshold
for kernel memory.
Network
Vault processes and clients communicate over TCP/IP. Often large transfers of data occur between
machines:
• Transferring raw jobs to Vault server.
• Large Postscript headers.
• Documents with a large number of pages.
Aim for high bandwidth between servers (1 gigabit or even 10 gigabit capable servers connected
via switches).
Use the test environment to model how much your deployment actually needs.
Avoid performance sapping issues such as:
• Bad cables (for example, crossed pairs)
• Duplex mismatches
11EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
Backup and recovery
Vault installations contain vast amounts of critical data. Ensure that there are plans in place to handle
backup and recovery of the database.
The indexes that are at the root of the data must be backed up correctly. To ensure the proper
consistency of the index backup, the process should make use of the indexbackup.adm flag file
to create a consistent index copy to server\backup and then back up that copy.
Note: Avoid storing the indexes on remote storage (redirection, NAS, iSCSI, etc.). The
indexes are particularly sensitive to storage failures.
Backup programs must not lock Vault files or open them in exclusive mode. Doing so can prevent
Vault processes from accessing your data properly.
Software requirements
Microsoft Windows support
Vault Service Clients (Vault Reprint Admin, and Mobile Vault) are supported on the following operating
systems:
• Microsoft Windows 7 Service Pack 1
• Microsoft Windows 8
Vault and Render servers are supported on the following:
• Microsoft Windows Server 2008 R2 Service Pack 1
• Microsoft Windows Server 2008 Service Pack 2
• Microsoft Windows Server 2012 and Windows Server 2012 R2
• Microsoft Windows Server and Datacenter 2016 versions that support 32 bit applications.
Note: that the Windows 2016 Nano Server does not support 32 bit applications.
The following is supported:
• 32-bit x86
• 64-bit x64 (runs as a 32-bit process)
12EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
It is highly recommended that you use a 64-bit operating system to host Vault. Vault servers can
put considerable stress on the kernel resources of 32-bit versions of Microsoft Windows. This can
be exacerbated by using antivirus software, the use of bad drivers or even large amounts of memory
(which requires more kernel space for page tables).
Note: Vault is not supported on Itanium Processor Architecture.
UNIX support
Vault server and the Rendering Engine are supported on Linux, Solaris on SPARC, and AIX platforms.
The requirements for each are as follows:
Linux
Linux distribution (32-bit or 64-bit x86) with kernel version greater than or equal to 2.6.18, and glibc
version greater than or equal to 2.3. This includes Red Hat Linux and Suse Linux.
Note: Running on a 64-bit Linux version will require the installation of 32-bit compatibility
libraries.
AIX
IBM AIX 6.1, and 7.1 with C++ runtime libraries (xlC.rte and xlC.aix50.rte filesets). The component
xlC.aix61.rte must be at level 9.0.0.5 or higher. The AIX XL C/C++ runtime must be version 9.0.0.5
or higher. The xlC supplemental runtime for aix50 (xlC.sup.aix50.rte) at level 9.0.0.1 or higher.
To determine the current level of the installed xlC components, run the following AIX command:
lslpp -l | grep xlC
Solaris on SPARC
Sun Solaris 10 (for 64-bit SPARC).
Microsoft Windows installation
There are three installation scripts, including the required script for installing the Vault server
components and two optional scripts for installing Vault Windows service clients.
Note: Installing under microsoft windows requires administrator access rights.
These scripts run under Powershell 2.0 and later versions. Note that for Windows 7, Windows 8,
Windows Server 2008 Windows Server 2012 and Windows Server 2016, Powershell is bundled
with Windows.
13EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
Vault Windows installation material is contained in InstallSet.zip file. The actual filename will
reflect the product name (Vault), the version number (7.2.0.22 for example), the word InstallSet,
and a ZIP filetype. Extract the contents of this ZIP file to your chosen install directory, for example
c:\vault-temp, at this point the following files will be available:
•install-admin.bat - the Windows admin service client
•install-desktop.bat - the Windows desktop service client
•install-vault.bat - Vault system servers components
Installing Vault server (required)
There are four files required for Vault system installation:
•install-libs.psm1 - the powershell common module/functions of the installation
•install-vault.ps1 - the powershell main script for the installation
•install-vault.bat - the main install batch command file
•install-vault-config.txt - the install configuration
Configuring Vault installation
The parameters used to configure Vault installation are specified in install-vault-config.txt.
Refer to the information below for details of this configuration file:
###################################################
#parameters for licence
#
# description of parameters:
#
# [licence_path] : is for the licence info root directory,
# should include the public key file and licence file;
#
# [licence_file] : is for the licence file name
#
# [Environment] : is for the evironment ID, should match the value inside
licence file
#
# If you don't know the Environment ID from a license file, you can use
the
# scripts of (print-lic.bat) to display the license information:
# for example: print-lic.bat <full-path-license-file>
#
licence_path=c:\\licence
licence_file=VaultKeys.xml
Environment=1
14EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
###################################################
#parameters for source files
#
# description of parameters:
#
# [source_path] is for the root path/dir which is including
# Vault system files/resources/sub-directories which are used to
install,
# the default value is the current working directory if not setup
or empty,
#
#source_path=C:\\test\\9.9M9p0012-InstallSet-Vault
###################################################
#parameters for installation
#
# description of parameters:
#
# [program_group] : is for the group entry name in Windows START menu,
default is "Vault"
#
# [install_path] : is for the target/destination directory to install
Vault system
# if not defining install_path, or it is empty
# then use the path of "C:\\Program Files (x86)\\PBBI CCM\\Vault"
#
# [install_servers] : is for settings of servers components, can be
below values
# "server" : is for server components (e2serverd, e2laoderd,
indexerd);
# "render" : is for e2renderd (Rendering engine) components;
# "router" : is e2routerd components;
#
# [install_clients] : is for windows client components, can be below
values
# "admin" : is for Vault Windows Admin service client
# "desktop" : is for Vault Windows Desktop service Client
#
program_group=Vault
#install_path=c:\\test\\install
install_servers=server, render, router
install_clients=admin, desktop
###################################################
#parameters for IP addresses and ports
15EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
#
# description of parameters:
#
# [ip_server] : is for the ip address of e2serverd
# [ip_loader] : is for the ip address of e2loaderd
# [ip_render] : is for the ip address of e2renderd
# [ip_router] : is for the ip address of e2routerd
#
# [port_server] : is for the port number of e2serverd
# [port_loader] : is for the port number of e2loaderd
# [port_render] : is for the port number of e2renderd
# [port_router] : is for the port number of e2routerd
#
ip_server=127.0.0.1
ip_loader=127.0.0.1
ip_render=127.0.0.1
ip_router=127.0.0.1
port_server=6001
port_loader=6002
port_render=6003
port_router=6004
###################################################
#install server/render/router as a service
#
# description of parameters:
#
# [install_service] : set up if install servers(e2serverd, e2loaderd,
indexerd,
# e2renderd, e2routerd) as Windows service;
# true : install the servers as a windows service; otherwise, not
install them
# as services
# the default value for [install_service] is true if don't setup or
empty
#
# [stop_running_service] : set up if stop running service of servers
(e2serverd,
# e2loaderd, indexerd, e2renderd, e2routerd)
# true : stop running services if applicable; otherwise not stop
the running
# service, the users need manually stop it;
# the default value for [stop_running_service] is false (not stop
the running
# service) if don't setup or empty;
#
# [delete_existing_service] : set up if delete the existing services
for
# (e2serverd, e2loaderd, indexerd, e2renderd, e2routerd)
# true : delete the existing services; otherwise not delete the
16EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
existing
# services, the users need manually delete them;
# the default for [delete_existing_service] is false (not delete
the existing
# services) if don't setup or empty;
#
install_service=true
stop_running_service=true
delete_existing_service=true
###################################################
#parameters for Windows service clients
#
# description of parameters:
#
# [primaryHost_admin] : is for the host name / ip address of admin
service client
# [serviceIP_admin] : is for the ip address of server which the client
will connect to
# [servicePort_admin] : is for the port number of server which the client
will connect to
#
# [primaryHost_desktop] : is for the host name / ip address of desktop
service client
# [serviceIP_desktop] : is for the ip address of server which the
client will connect to
# [servicePort_desktop] : is for the port number of server which the
client will connect to
#
primaryHost_admin=localhost
serviceIP_admin=localhost
servicePort_admin=6001
primaryHost_desktop=localhost
serviceIP_desktop=localhost
servicePort_desktop=6001
Installing Vault
Follow the steps below to install Vault:
1. Open a command prompt using the Run as administrator option.
2. Go to your install directory into which Vault system files were extracted, (for example,
c:\vault-temp).
3. If you wish to change the default values, open install-vault-config.txt in Notepad
and change values as required. Care should be taken when editing
install-vault-config.txt.
17EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
Here are the settings:
Environment ID, should match the value inside licence file. If you don't know the
Environment ID from a license file, use the print-lic.bat scripts to display
the license information. For example: print-lic.bat c:\vaultlic\VaultKeys.xml
[Environment]
IP address of e2serverd[ip_server]
IP address of e2loaderd[ip_loader]
IP address of e2renderd[ip_render]
IP address of e2routerd[ip_router]
Port number of e2serverd[port_server]
Port number of e2loaderd[port_loader]
Port number of e2renderd[port_render]
Port number of e2routerd[port_router]
Host name/IP address of admin service client[primaryHost_admin]
Host name/IP address of server which the client will connect to[serviceIP_admin]
Port number of server to which the client connects[servicePort_admin]
Host name/IP address of desktop service client[primaryHost_desktop]
IP address of server to which the client connects[serviceIP_desktop]
Port number of server to which the client connects[servicePort_desktop]
4. Run install-vault.bat from your install directory (for example,
c:\vault-temp\install-vault.bat).
5. In case an error condition is encountered, the appropriate error message will be displayed at
the command prompt or from a log file (install-vault-YYYYMMDD-HHMMSS.log). Follow
the information provided in the error messages to resolve the issue and retry.
6. On successful installation the following message is displayed at the command prompt: Vault
system installation complete.
18EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
7. Restart your system, Vault is ready to use.
Installing the Admin Service client (optional)
To install the Windows Admin Service client follow these steps:
1. Open a command prompt using the Run as administrator option.
2. Go to your install directory into which Vault system files were extracted, (for example,
c:\vault-temp).
3. If you wish to change the default values, open install-admin.bat in Notepad and change values
highlighted below:
set serviceIP=localhost - server's iP address the client will connect to
set primaryHost=localhost - server’s IP address the client will connect to
set servicePort=6001 - server's port number the client will connect to
set targetdir=C:\Program Files (x86)\PBBI CCM\Vault - the target install root
path
Care should be taken when editing install-admin.bat.
4. Run install-admin.bat (for example, c:\vault-temp\install-admin.bat)
5. In case an error condition is encountered, the appropriate error message will be displayed at
the command prompt or from a log file (install_vault_admin.log). Follow the information
provided in the error messages to resolve the issue and re-try.
6. On successful installation the following message is displayed at the command prompt: Vault
admin client installation complete.
7. Restart your system, the Windows Admin Service client is ready to use.
Installing Desktop Service client (optional)
1. Open a command prompt using the Run as administrator option.
2. Go to your install directory into which Vault system files were extracted, (for example,
c:\vault-temp).
3. If you wish to change the default values, open install-desktop.bat in Notepad and change
values highlighted below:
set serviceIP=localhost - server's iP address the client will connect to
set primaryHost=localhost - server’s IP address the client will connect to
set servicePort=6001 - server's port number the client will connect to
set targetdir=C:\Program Files (x86)\PBBI CCM\Vault - the target install root
path
19EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
Care should be taken when editing install-admin.bat.
4. Run install-desktop.bat (for example, c:\vault-temp\install-desktop.bat)
5. In case an error condition is encountered, the appropriate error message will be displayed at
the command prompt or from a log file (install_vault_desktop.log). Follow the information
provided in the error messages to resolve the issue and re-try.
6. On successful installation the following message is displayed at the command prompt: Vault
desktop client installation complete.
7. Restart your system, the Desktop Service client is ready to use.
Optimizing file system performance
Microsoft Windows deals with the recording of short file names for compatibility with much older
software that is turned on by default on the operating system. This functionality can be changed by
running a single DOS command on the server where Vault is installed.
Note that you will notice a performance improvement only with a large number of files (over 300,000)
in relatively few folders where a lot of the filenames start with similar names. Not having 8.3 filenames
available will prevent the use of old applications such as Word 2.0 and Excel 4.0.
Since Vault typically has filenames beginning with CCYYMMDD-HHMMSS, many files often do
have the same first 'n' characters (specifically, the year: 2006, and even the following characters
only use numbers, reducing the variability available in the first 8 characters. This causes the operating
system to perform many searches to find the next available shortened filename to use on a given
file.
To disable this functionality, run the DOS command prompt and type the following:
C:\> FSUTIL behavior set disable8dot3 1
Installing Vault in small memory environments
If Vault is being installed in a small memory Windows environment (less than 4 GB), the memory
footprint of the Indexer as a Service can be minimized by tuning the cache size in the initialization
parameters.
This is done by creating a file named indexerd.ini in the Vault "server" directory. The contents
of the file should include the following lines:
[Indexer1]
CacheSize=256
QueueSize=10000
20EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
Upgrading an existing e2 Vault installation on Microsoft Windows
To upgrade an existing e2 Vault installation on Microsoft Windows:
1. Back up the existing installation and data before doing the upgrade.
2. Stop Vault services or Vault running applications.
3. If the version of Vault that will be installed is same as the existing one, copy the executable
files.If the versions are different, remove the existing installation and then follow the above
installation sections.
Note: if you are using vault indexer as a service release 6.0, the index.dr2 file created
under release 6.0 will not be compatible with the release 6.1 or higher of the indexer as
a service.
A full reindex of your data using release 6.1 or higher will be required to make your
document index visible with release 6.1.
The recommended method is to rename your existing release 6.0 index.dr2 file and
allow vault to create a new empty index.dr2 file. the reindex operation will then populate
the newly created index.dr2 file.
UNIX installation
Linux
The following procedure uses the GNU "tar" command to install Vault software on Linux.
Note: Before installing under Linux, verify that “SELinux” support is not set to the “Enforcing”
mode. Vault may not install or run correctly if SELinux is set to this mode.
1. Log on as root.
2. Copy the Vault installation tarball to your directory. The name will usually be constructed of the
product name (Vault), the release number (7.2.0.20 for example), and the operation system
version (Linux) and ends with ".tar.gz".
3. Decompress the installation tarball:
tar -zxvf <name-of-the-install-tarball>.tar.gz
21EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
4. Run the install script:
cd <name-of-the-tarball>
./install.sh
Note: If you are installing on a 64 bit Linux system, please verify that the following
prerequisite libraries are installed on your system:
•glibc.i686
•libstdc++.so.6
If these libraries are missing, the Vault executable will fail to run.
General information
1. Vault software will be installed to /opt/PBBI CCM/Vault which is the installation root directory
and contains the following sub-directories:
•lib
•render
•router
•server
2. The Vault repository server can be configured through the INI configuration files in the repository
server's root directory:
/opt/PBBI CCM/Vault/server
Vault ADM server's download directory is:
/opt/PBBI CCM/Vault/server/download
3. Please note that on UNIX platforms, Vault ADM server only monitors the download directory
for files that have the “.done” extension (for example, MyFile.afp.DONE,MyFile.jrn.DONE,
MyFile.rpk.DONE). Files with all other extensions are ignored and will not be processed by
Vault server.
The recommended way to transfer printstream files (and their associated journals and resource
packs) is to first transfer the files to the ADM server's download directory without the “.DONE”
extension. Once the files have been transferred/copied successfully, they should then be renamed
and have the “.DONE” extension appended:
(example)
root:[~/]# for i in MyFile.afp MyFile.jrn MyFile.rpk;
> do
> cp $i /opt/PBBI CCM/Vault/server/download/$i && mv /opt/PBBI
CCM/Vault/server/download/$i /opt/PBBI
CCM/Vault/server/download/$i.DONE
> done
22EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
Post-install configuration
Licence file and Environment information has to be added or updated before Vault servers can be
run, as the installation package does not supply a Licence file.
After successfully completing the installation, copy the Licence file (for example, VaultKeys.xml)
to Vault repository server's root directory (/opt/PBBI CCM/Vault/server) and update Vault
repository server's server.ini configuration file:
[Licence]
LicenceFile=<Path to keycode/licence file>
Environment=<environment from keycode/licence to select>
The LicenceFile key can be set to either an absolute path and filename:
(for example)
LicenceFile=/opt/PBBI CCM/Vault/server/VaultKeys.xml
or a path/filename relative to the repository server's root directory:
(for example)
LicenceFile=VaultKeys.xml
Starting and stopping Vault servers
Vault servers can be started or stopped using vault RC (run control) script that is installed by the
installation script:
/etc/init.d/vault
Once Vault software has been installed and configured (Licence file, profiles, etc.) Vault servers
can be controlled as follows:
(to start Vault servers)
/etc/init.d/vault start
(to stop currently running Vault servers)
/etc/init.d/vault stop
Note: this script only facilitates manual startup and shutdown of Vault servers.
If you are not using the Indexer as a Service, you can use /etc/init.d/vault_noindexer
script in place of the /etc/init.d/vault script. The vault_noindexer script will not start or
stop the Indexer as a Service.
Uninstalling Vault
1. Ensure that all Vault servers have been stopped: /etc/init.d/vault stop
23EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
2. Manually uninstall Vault software by removing:
• the installation root directory (including all binaries, libraries, configuration files, and ingested
data): rm -rf /opt/PBBI CCM/Vault
• Vault RC scripts:
rm -f /etc/init.d/vault
rm -f /etc/init.d/vault_noindexer
AIX
The following procedure uses the AIX “gunzip” and “tar” commands to install Vault software on AIX:
1. Log on as root.
2. Copy the Vault installation tarball to your directory. The name will usually be constructed of the
product name (Vault), the release number (7.2.0.20 for example), and the operation system
version (Linux) and ends with ".tar.gz".
3. Decompress the installation tarball:
/bin/gunzip -dc <name-of-the-install-tarball>.tar.gz | /bin/tar -xf -
4. Run the install script:
cd <name-of-the-tarball>
./install.sh
Note: The install script will prompt for confirmation that the dependencies (C++ runtime
libraries for AIX) have already been installed before continuing with the installation.
General information
1. Vault software will be installed to /opt/PBBI CCM/Vault which is the installation root directory
and contains the following sub-directories:
•lib
•render
•router
•server
2. The Vault repository server can be configured through the INI configuration files in the repository
server's root directory: /opt/PBBI CCM/Vault/server/download
Vault ADM server's download directory is: /opt/PBBI CCM/Vault/server/download/opt/
24EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
3. Note that on UNIX platforms, the Vault ADM server only monitors the download directory for
files that have the “.DONE” extension (for example, MyFile.afp.DONE,MyFile.jrn.DONE,
MyFile.rpk.DONE).
Files with all other extensions are ignored and will not be processed by the Vault server.
The recommended way to transfer print files (and their associated journals and resource packs)
is to first transfer the files to the ADM server's download directory without the “.DONE” extension.
Once the files have been transferred/copied successfully, they should then be renamed and
have the “.DONE” extension appended:
Example
root:[~/]# for i in MyFile.afp MyFile.jrn MyFile.rpk;
> do
> cp $i /opt/PBBI CCM/Vault/server/download/$i && mv /opt/PBBI
CCM/Vault/server/download/$i /opt/PBBI
CCM/Vault/server/download/$i.DONE
> done
Post-install configuration
Licence file and Environment information has to be added and/or updated before Vault servers can
be run, as the installation package does not supply a Licence file.
After successfully completing the installation, copy the Licence file (for example, VaultKeys.xml)
to the Vault repository server's root directory (/opt/PPBI CCM/Vault/server) and update Vault
repository server's server.ini configuration file:
[Licence]
LicenceFile=<Path to keycode/licence file>
Environment=<environment from keycode/licence to select>
The LicenceFile key can be set to either an absolute path and filename:
LicenceFile=/opt/PBBI CCM/Vault/server/VaultKeys.xml
or a path/filename relative to the repository server's root directory:
LicenceFile=VaultKeys.xml
Starting and stopping Vault servers
Vault servers can be started or stopped using the Vault RC (run control) script that is installed by
the package:
/etc/rc.d/vault
Once the Vault package has been installed and configured (Licence file, profiles, etc.) Vault servers
can be controlled as follows:
To start Vault servers:
25EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
/etc/rc.d/vault start
To stop currently running Vault servers:
/etc/rc.d/vault stop
Note:
• This script only facilitates manual startup and shutdown of Vault servers.
• If you are not using the indexer as a Service, then you can use the
/etc/rc.d/vault_noindexer script instead of the /etc/rc.d/vault script. The
vault_noindexer script will not start or stop the indexer as a service
Uninstalling Vault
1. Ensure that all Vault servers have been stopped: /etc/rc.d/vault stop
2. Manually uninstall Vault software by removing:
• The installation root directory (including all binaries, libraries, configuration files, and ingested
data): rm -rf “/opt/PBBI CCM/Vault”
• Vault RC scripts:
rm -f /etc/rc.d/vault
rm -f /etc/rc.d/vault_noindexer
Solaris on SPARC
The following procedure uses the Solaris “gunzip” and “tar” commands to install Vault software on
Solaris:
1. Log on as root.
2. Copy the Vault installation tarball to your directory. The name will usually be constructed of the
product name (Vault), the release number (7.2.0.20 for example), and the operation system
version (Linux) and ends with ".tar.gz".
3. Decompress the installation tarball:
/bin/gunzip -dc <name-of-the-install-tarball>.tar.gz | /bin/tar -xf -
4. Run the install script:
cd <name-of-the-tarball>
./install.sh
26EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
General information
1. Vault software will be installed to /opt/PBBI CCM/Vault which is the installation root directory
and contains the following sub-directories:
•lib
•render
•router
•server
2. The Vault repository server can be configured through the INI configuration files in the repository
server's root directory: /opt/PBBI CCM/Vault/server
Vault ADM server's download directory is: /opt/PBBI CCM/Vault/server/download
3. Note that on UNIX platforms, the Vault ADM server only monitors the download directory for
files that have the “.DONE” extension (for example, MyFile.afp.DONE,MyFile.jrn.DONE,
MyFile.rpk.DONE).
Files with all other extensions are ignored and will not be processed by Vault server.
The recommended way to transfer print files (and their associated journals and resource packs)
is to first transfer the files to the ADM server's download directory without the “.DONE” extension.
Once the files have been transferred/copied successfully, they should then be renamed and
have the “.DONE” extension appended:
Example
root:[~/]# for i in MyFile.afp MyFile.jrn MyFile.rpk;
> do
> cp $i "/opt/PBBI CCM/Vault/server/download/$i" && mv "/opt/PBBI
CCM/Vault/server/download/$i" "/opt/PBBI
CCM/Vault/server/download/$i.DONE"
> done
Post-install configuration
Licence file and Environment information has to be added and/or updated before Vault servers can
be run, as the installation package does not supply a Licence file.
After successfully completing the installation, copy the Licence file (for example, VaultKeys.xml)
to the Vault repository server's root directory (/opt/PBBI CCM/Vault/server) and update Vault
repository server's server.ini configuration file:
[Licence]
LicenceFile=<Path to keycode/licence file>
Environment=<environment from keycode/licence to select>
The LicenceFile key can be set to either an absolute path/filename:
LicenceFile=/opt/PBBI CCM/Vault/server/VaultKeys.xml
27EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
or a path/filename relative to the repository server's root directory:
LicenceFile=VaultKeys.xml
Starting and stopping Vault servers
Vault servers can be started or stopped using the Vault RC (run control) script that is installed by
the package:
/etc/init.d/vault
Once the Vault package has been installed and configured (Licence file, profiles, etc.) Vault servers
can be controlled as follows:
To start Vault servers:
/etc/init.d/vault start
To stop currently running Vault servers:
/etc/init.d/vault stop
Note:
• This script only facilitates manual startup and shutdown of Vault servers.
• If you are not using the Indexer as a Service, you can use the
/etc/init.d/vault_noindexer script to start and stop Vault instead of the
/etc/init.d/vault script. The vault_noindexer script will not start or stop the
Indexer as a Service.
Uninstalling Vault
1. Ensure that all Vault servers have been stopped: /etc/init.d/vault stop
2. Manually uninstall Vault software by removing:
• The installation root directory (including all binaries, libraries, configuration files, and ingested
data): rm -rf “/opt/PBBI CCM/Vault”
• Vault RC scripts:
rm -f /etc/init.d/vault
rm -f /etc/init.d/vault_noindexer
Failure recovery on UNIX
In the event that Vault experiences a failure (crash, abnormal exit due to mis-configuration, etc.) on
UNIX, the following procedure can be used to recover and restart Vault servers after a such an
occurrence:
28EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
1. Ensure that all Vault servers have been stopped either by running the Vault RC (run control)
script for your platform or by manually stopping the servers (for example, “ps -ef|grep -i
e2”,“kill -TERM <Vault server PIDs>”, etc.).
If you are running the Indexer as a Service, you must manually stop it as well (for example, "ps
-ef | grep -i indexerd",kill -TERM <Vault indexerd PID>"
2. Remove any orphaned files left behind for example, core file (/opt/PBBI
CCM/Vault/server/core) or PID files (/var/opt/vault/run/*.pid), etc.
3. If the failure condition was due to a configuration error (for example, “the compressed block
size is too small to handle this data”), update Vault server’s relevant configuration to correct the
error.
4. Restart Vault servers.
Upgrading an existing e2 Vault installation on UNIX
1. Unpack the install package (tar -zxvf …)
2. Stop the existing vault system
a) su root (enter root password when prompted)
b) cd /etc/init.d
c) ./e2vault stop
3. Backup the following files in the existing Vault install path (/opt/PBBI CCM/Vault)
a) server/e2serverd
b) server/e2util
c) server/e2loaderd
d) render/e2renderd
e) router/e2routerd
f) lib
4. Backup all files in server/tools
5. As root, copy the equivalent new files from the installation directories
a) server/e2serverd
b) server/e2util
c) server/e2loaderd
d) render/e2renderd
e) router/e2routerd
f) All files from server/tools
g) All files from lib
6. Restart Vault.
a) su root (enter root password when prompted)
29EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
b) cd /etc/init.d
c) ./e2vault start
Note: This upgrade process does not install the Indexer as a Service.
30EngageOne Vault 7.5 Vault Installation
Installing Vault and clients
3 - Configuring and
running Vault
The main component of Vault is the document repository which compresses,
stores and manages documents composed in a wide range of output
datastreams including most of those produced within the Generate
environment.
In this section
Overview 32
Before you configure 32
Security 33
Configuration steps 36
Storing documents 36
Provide index information 40
Provide font and image resources 45
Start Vault processes 47
Configuring Encryption at Rest 49
Customizing the Vault environment 49
Working with Unicode data 49
Overview
Under normal circumstances the processes required by the repository are automatically invoked
when the operating system is started. Before you can start loading documents into the repository
you will need to define the properties of the incoming documents. Refer to Creating application
profiles on page 43 for further information. This section is intended to provide information on
configuring, loading and troubleshooting repository processing.
Another component which makes up Vault is the Mobile Vault which is a Microsoft Windows based
application that allows documents to be read from a local copy of an Vault database. Refer to the
"Vault User Guide" for more information.
Before you configure
The output datastream passed to Vault must be in one of the supported formats such as AFPDS,
Metacode, or Postscript. Before any datastream is usable within Vault you must provide or create
an index for the documents it contains.
The storage in vault is broken into several areas:
Page data:
• compressed and stored in .drp files
• shared across whole the server
Document data:
• includes properties such as doc.date
• includes pointers to pages in the .drp files
• is compressed and stored in .drd files
• shared across whole the server.
Index data:
• each database has its own indexes.
• made up of the customer table (.drr/.drt) and index files (.dri/.dru).
• allows controls that let you specify which documents are visible in a database.
• if using authentication, databases can be restricted to specific users or groups.index entries are
made up of:
• fields from the document, such as doc.data.
• pointers to the document records in the .drd files or customer records in the customer table.
32EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
Note: Loading resources via HIP file is not supported for Postscript.
• Datastreams produced by Generate are the preferred source as the environment provides
a simple method of creating an acceptable index known as an Interchange Journal (DIJ).
• For datastreams not created by Generate you will need to configure Vault to identify the
appropriate index information directly from the contents of the datastream.
The settings related to a particular application are stored as sections within the profiles.ini file. Each
section is known as an application profile and contains:
• the expected type of output datastream and index.
• the name template by which files related to the application are identified by the ADM.
• document handling parameters.
If required, you can move or rename the file location. In some scenarios you can configure Vault to
store documents from particular applications in different databases so that you can refine access
control.
Security
Enabling SSL for Vault servers
SSL can be enabled for Vault servers by modifying their respective configuration files. Assuming
that you already have the SSL private key (for example, e2vault-server.key) and the
corresponding SSL certificate (for example, e2vault-server.crt), enable SSL for Vault servers
as follows:
Note: The insertion of chevron markers (>>>>) denote the newly added lines for SSL.
1. Vault server: modify the server\e2serverd.ini file.
[server1]
service=*:6001
>>>> ssl=1
>>>> sslcertificate=e2vault-server.crt
>>>> sslprivatekey=e2vault-server.key
[connection1]
>>>> ssl=1
33EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
2. Loader server: modify the server\e2loaderd.ini file.
[server1]
service=*:6002
[connection1]
service=localhost:6001
>>>> ssl=1
>>>> sslcertificate=e2vault-server.crt
>>>> sslprivatekey=e2vault-server.key
3. Rendering engine: modify the render\e2renderd.ini file.
[server1]
service=*:6003
>>>> ssl=1
>>>> sslcertificate=e2vault-server.crt
>>>> sslprivatekey=e2vault-server.key
[connection1]
service=localhost:6001
>>>> ssl=1
4. Vault Router server: modify the router\e2routerd.ini file.
[router1]
# Number of rendering engines to use
count=2
[server1]
# Hostname and port that e2routerd listens on for incoming connections
service=*:7003
>>>> ssl=1
>>>> sslcertificate=/opt/e2vault-server.crt
>>>> sslprivatekey=/opt/e2vault-server.key
# First of two rendering engines to use
[connection1]
service=127.0.0.1:6003
>>>> ssl=1
# Second of two rendering engines to use
[connection2]
service=127.0.0.1:6004
>>>> ssl=1
With the above changes made, once Vault servers are restarted, SSL will be enabled and used
for all network communications between the servers and for communications to/from the server
by other systems or entities (Perl web client, Java Service web client, and etc., along with the
API sets, such as .NET API and Java API).
Using uclient.exe and loader.exe
34EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
When enabling SSL, if you wish to use the ‘uclient.exe’ and ‘loader.exe’ you need to add
2 lines to client.ini.
[installer]
>>>> ssl=1
primary=e2vault2
[connection1]
>>>> ssl=1
service=e2vault2:6001
serverlicence=1
Generating an SSL certificate for use with Vault
1. Use the openssl executable/binary located in the server\tools folder of your Vault install
for generating the SSL key and certificate for Vault.
2. Set the OPENSSL_CONF environment variable to the full path and location of the openssl.cnf
configuration file which is also located in the server\tools folder of your Vault install:
UNIX example
export OPENSSL_CONF=/opt/PBBI CCM/Vault/server/tools/openssl.cnf
Microsoft Windows example
set OPENSSL_CONF=C:\Program Files\PBBI
CCM\Vault\server\tools\openssl.cnf
3. Generate a new SSL key-certificate pair to use with Vault as follows:
a) Change directory into the folder containing the openssl executable/binary (see above).
b) Generate an RSA Private Key (example below creates a 4096-bit key):
openssl genrsa -out e2vault-server.key 4096
c) Generate a CSR (Certificate Signing Request)
openssl req -new -key e2vault-server.key -out e2vault-server.csr
d) Generate a Self-Signed SSL Certificate
openssl x509 -req -days 365 -in e2vault-server.csr -signed
e2vault-server.key -out e2vault-server.crt
You can change the validity of the generated SSL certificate as desired; the above example
makes the certificate valid for 1 year.
Once the steps above have been completed successfully, you will have the following files:
•e2vault-server.crt (Self-signed SSL certificate for Vault server)
•e2vault-server.csr (Certificate Signing Request that was used to create the
self-signed certificate above)
•e2vault-server.key (RSA Private Key that was used to self-sign the SSL certificate
above)
35EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
4. Copy the e2vault-server.crt and e2vault-server.key files into the directory containing
the e2serverd and e2loaderd executables (for example, \some\path\server\), as well as
the directory containing the e2renderd executable (for example, \some\path\render\).
Configuration steps
Carry out the following steps when configuring your installation of the document Vault:
1. Configure document storage settings, refer to Storing documents on page 36
2. Configure directory paths, refer to Configure directory paths on page 38
3. Provide index information, refer to Provide index information on page 40
4. Create application profiles, refer to Creating application profiles on page 43
5. Provide font and image resources, refer to Provide font and image resources on page 45
6. Start the necessary Vault processes, refer to Start Vault processes on page 47
Compression
It is important to note that the maximum size of an individual output datastream file that can be
stored in Vault after compression should not exceed 4GB. If the file is larger than 4GB, consider
splitting the incoming datastream into multiple files.
Storing documents
Output datastreams and their associated files are loaded into the repository by the Automated Data
Manager feature (ADM) which polls the download directory for incoming data.
The download directory is defined in the server.ini file as follows:
[Paths]
DownloadPath=path
If the files are being generated on a machine remote from Vault you will need to use a transfer
protocol such as FTP and file sharing. You must ensure that all text translation features are disabled
when transferring data. Note: caution is needed with file transfer in that failed transfers directly to
download might lead to fragments being ingested.
36EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
Note: Datastream and HIP files should be handled as binary.
Any information, warning or error messages generated by the ADM are stored in a log file which
has the default location of:
<drpath>\server\log\process.<timestamp>.<processid>.log
For example: e2loaderd.20120130.080827.4148.log
Naming download files
Files that appear in the ADM download directory should have names that conform to one of the
entries in the [FileMap] section of profiles.ini. In this way they are mapped to an application
profile within the ini that specifies the type of data and index expected and any other custom document
or application requirements. Refer to Creating application profiles on page 43 for details.
Note: It is important that the download file names be unique enough so that they are not
confused for another.
It is important to note that for Generate created datastreams the base name used for both the
datastream itself and the associated DIJ must be the same.
The requirements are:
• The base job name is the same for the stream and journal (if using journals).
• The base job filenames must be unique so that streams and journals for multiple jobs are not
confused.
• The search fragments in the [filemap] are tested in order and the first fragment found determines
the profile.
Output datastreams will be identified providing their base name matches an application profile. Data
files must end with a recognized extension, such as:
AFPDS.afp
Metacode.mtc
PostScript.ps
HTML pages contained within an XML 'pak' construct as
produced by Generate
.xml
It is also recommended that file have the following format:
37EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
YYYYMMDD-HHMMSS-doctype
Where the first part of the file name is the date and time in a most-to-least significant order – year
month day, hour minute second. This is of particular benefit when viewing a listing of your files which
will always be shown in date order when sorted by name. 'doctype' indicates the application – use
a short name such as BILL14 as this is repeated for all documents of this type that share the same
profile – resources, format, page options, etc. Ensure that the names are as unique as possible to
prevent failed files from having problems in the work directory.
For example:
20020131-114532-bizbill.afp
Downloading remote files
A remote file can be downloaded without having to copy or move the file to the download directory.
ADM is capable of retrieving a remote file over the network, provided it is both shared and accessible
to the account ADM is using. Under Microsoft Windows, files accessed this way should be specified
using UNC syntax: \\servername\sharename\path\filename
To download a remote file, create a file with the .indirect extension and place it in the download
directory. Indirect files may stand in for print streams, journals or resource packs. Enter the full path
to a file in another location (<drpath>). Vault will treat the .indirect file as if it was the remote file
when placed in the download directory. The remote file does not get deleted after processing is
complete (only the .indirect file is deleted). You also do not have to copy or move the file to the
download directory, Vault will read it from where it is. Indirect files may stand in for print streams,
journals or resource packs.
Note: e2serverd.exe must be able to access the file given the account the service logs in
as. this also applies when you redirect a directory to another location or set access controls
on the existing Vault tree.
Configure directory paths
Vault consists of several working directories. These include the repository itself, a log directory,
diagnostic tools, various working directories, and the download directory. By default these are created
as sub-directories under the main installation directory name.
38EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
Defining the download directory
The download directory is a key part of the mechanism that loads document datastreams and
associated resources. It is continually polled by Vault Loader for new files which are then processed
and stored in the repository as appropriate.
By default the download directory will be located in <drpath>\server\download you can
reconfigure the download directory to any location that is directly accessible by the repository. You
may, for example, want to isolate it from the rest of the repository directories as a security measure.
You can then allow general access to the download directory while leaving the other directories in
a more secure environment. You may also want to redirect subdirectories to improve disk
performance. For example, you can place the index directory, download directory, pagedata directory,
and etc., on separate drive arrays to increase the number of simultaneous operations by sending
requests to different hardware sub-systems.
Under normal circumstances the other directories that make up the repository are not user
configurable. You should, however, ensure that these have a suitable level of protection against
unauthorized access.
To move the download directory:
1. Create or identify the required directory.
If you are not using the default location for the download directory you will need to create a new
directory within your file system. This is not created by the repository.
2. Open the server initialization file (server.ini) for edits.
<drpath>\server\server.ini
3. Insert or change the DownloadPath setting.
The required syntax is:
[Paths]
DownloadPath=dlpath
Where dlpath is the is the path name that will be polled for new documents. You will need to
create the [Paths] section if it does not already exists in the ini file. Refer to the "Vault Customizing
Guide" for detailed information on server.ini settings.
4. Stop and restart the e2loadered service.
39EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
Provide index information
Documents are stored in Vault in a structure that makes it easy to select and browse the required
documents. This is done by organizing documents in a similar way to the traditional paper filing
system – sorting documents together by a unique identifier into logical folders. Once a single customer
has been selected, all the documents that have been archived for that customer can be quickly and
easily browsed.
Typically the unique identifier, or primary key, would be the customer account number as this is
normally a unique, non-recycled number that clearly and positively identifies a specific customer.
Note: Important: if your primary key is not unique or is recycled, contact your Vault supplier
to resolve this issue before proceeding.
Other information, or secondary keys can be linked with the primary key, such as the customer
name, address, phone number, social security number. These keys provide the index and can be
used to search for a document, for example, the account number for 'Joe Smith' or the individual at
'123 Water Street'. Any information can be a key, whatever helps in searching for a document.
Providing the index information
If you are creating the documents to be archived using Generate then the index information is
provided in a separate file that is loaded into Vault along with the output datastream. This file is
known as a standard or XML journal (Document Interchange Journal).
You specify the type of index being used for an application as part of the profiles initialization file.
See Creating application profiles on page 43 for details.
The DIJ index process
A DIJ is an XML construct that can contain all the references with which it is possible to search for
documents within vault. The DIJ is defined as a standard Journal when creating the application
using the Designer. All the indexible references can be provided using references to fields within
the application data to be used in the production environment or by other objects such as constants
and environment settings. One entry per document is added to the DIJ when it is created by the
GEN component of Generate.
Important: Special care is required if you intend to manipulate the order of pages within the
datastream after it has been rendered by Generate. You may be using StreamWeaver or a third
party tool to merge or reorder pages within datastreams. Where this is the case you must ensure
40EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
that a new DIJ file is created that reflects the amended datastream. StreamWeaver provides
commands that allow you to read and write DIJ records and individual elements as required. If this
is not feasible, consider storing the documents in Vault before any such post processing. Another
consideration is the page signatures that generate marks pages with so that you can double check
the journal to stream page mapping in the XML journal based modes.
Note: Refer to the designer users guide for creating a DIJ object and the production guide
for specifying the file to receive the DIJ output.
Once generated, the DIJ should be passed to Vault along with the datastream to which it pertains
by placing both files in the ADM download directory. The base name of both files must match the
relevant entries in the [FileMap] section of profiles.ini for this to happen. Ensure the following
conditions are met:
• Stream and journal must share the same base name (20120101-invoice.afp,
20120101-invoice.jrn)
• There are appropriate file map entries to map the file name to the correct profile.
ADM automatically creates Vault index entries from the information held in the DIJ. By default the
index is assumed to contain four basic references (keys) which are displayed to the end user when
searching for a document.
These are:
• Customer account number (primary key)
• Customer name
• Customer address
• Document date
The following are the default indexes:
visiblerequiredto customeraccount
visibleoptionalto customername
visibleoptionalto customeraddress
visiblerequiredto documentinvlink
hiddenoptionalto documentguid
hiddenoptionalto documentiguid
41EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
Note that the various individual address elements that are configured as part of the DIJ object in
the Designer (address line 1-7 and Postal Code) are concatenated together to form the single
Customer address index element by ADM.
If required, you may amend the attributes that are made available to client systems by using the
Index and Render keywords:
•indexN= entries in profiles.ini can change how keys are created.
•indexN= entries in database.ini can alter search behavior.
•RenderN= entries in database.ini are used to specific search output columns.
Refer to the "Vault Customizing Guide" for detailed information on alternative methods of indexing.
Working with non-Generate created data
If you are using non-Generate created date data you will need to configure Vault to identify the
appropriate index information directly from the contents of the datastream as it is loaded. Using this
method may limit the flexibility of your application as redesigning a document may result in the
content of the output datastream no longer being compatible with the index generation criteria
specified originally. You will also need to understand the relevant datastream protocol so that you
can specify the elements to be searched.
Note: Non-journal methods may be useful for loading legacy data that was generated before
the production of journals was possible in your environments.
The supported non-indexing methods are as follows:
Journal: uses a text file that contains the index information that has been extracted from the
datastream in a prescribed format. Note that the journal model doesn't scrape data from the stream
as the genericXXX modes do and so it is not sensitive to layout or print encoding changes.
GenericAFP: uses TRN Transparent Data commands (TRN is a transparent data command) within
AFPDS files to indicate the start of a command sequence which completes with the text string
required for indexing.
GenericTLE: values within AFP Tag Logical Element (TLE) records provide the index information.
GenericMetacode: searches for binary patterns within Metacode streams to determine the start
and end of index text. Refer to the Vault Customizing Guide for further information on alternative
methods of indexing.
StreamWeaver: added <tags> and edit assistants in the Visual Engineer product to assist in making
the XML journal files.
Output from Generate
When working with output from Generate you must always supply the following resources to the
download directory as a group:
42EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
• The output datastream file (containing the actual documents)
• The DIJ file that provides the index into the documents.
• The fonts and image resources referenced within the datastream.
Font and image resources are stored in the HIP file as created by a Designer publishing task. Fonts
and image resources can be:
• manually loaded.
• loaded via resource packs (which can be dropped into download).
• via ExtractResources= (for inline AFP resources).
• resource packs should (ideally) be loaded before print streams that use them (otherwise it will
delay the loading of those streams).
They are made available to the download directory where they are matched to the appropriate
datastreams using internal identifiers stored in the associated DIJ. A HIP containing new or updated
font and image resources can be passed to the ADM polling location as soon as it becomes available,
but for consistency you may want to make it available at the same time as the application output
files to which they relate.
Creating application profiles
You may intend to store documents related to one or many applications within Vault. The settings
that govern how each application is handled within the Vault environment are defined in the profiles.ini
file, a default version of which is installed with Vault software.
profiles.ini is made up of multiple sections. There must always be a [FileMap] section plus
as many 'application profiles' sections as needed by your installation.
The [FileMap] section is used to identify which application profile is to be applied to incoming file.
For example, how the ADM will process files found in the download directory. For each application
profile you should specify one or more file name templates that identify the files belonging to that
application. In the following example all files that include the string '' in any part of their basename
will be associated with the application profile MyApp as shown below:
[FileMap]
=MyApp
[MyApp]
Format=AFP
Documents=XMLJournal
In this example the following files would be associated with the named profile MyApp profile: new.afp,
.afp,new.jrn,newapp.afp and so on. Note that templates apply to both datastreams and their
associated DIJ, standard and XML journal index files where applicable.
You may specify the application keyword (MyApp in this example) multiple times to associate
additional file name templates if necessary.
43EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
The primary function of the application profiles themselves is to identify the type of output datastream
expected (the Format keyword) and the method by which documents are to be indexed (Documents).
You can also use them to define a specific document database and resource file location for the
application and include other settings that provide formatting information not included within the
datastream itself. Refer to the Vault Customizing Guide for a full listing of profiles.ini settings.
Extended example of profiles.ini
[FileMap]
Stat=Statements
=Default
[Statements]
Documents=XMLjournal
Format=Postscript
Stream=1
LengthDelimited=0
TapeBlockFormat=1
MarginX=0
MarginY=0
Tray=group1.wmf
PageBreak=0
SkipHeaderPages=1
[Default]
Documents=GenericTLE
Format=AFP
Database=UnknownDocs
Databases and access rights
A database is a collection of documents within Vault. Documents are included in a particular database
by reference names that are associated with them when they are loaded into Vault. Documents are
added to the default database unless otherwise configured.
You can apply one or more database references to documents either at the application level using
profiles.ini or globally using server.ini. You can also specify multiple databases or * to
read a list of databases from the document record attributes.
To configure an application specific database:
Add the database keyword to an application profile section of profiles.ini . The name associated
with the keyword becomes a path name within the Vault environment so you should restrict its length
to 16 characters and avoid using special characters. Do not use the names 'Default' or 'Error' which
are reserved.
44EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
For example:
[MyApp]
Database=SpecialReports
For further information about the profiles initialization file refer to Creating application profiles on
page 43. Refer to the Vault Customizing Guide for a full listing of profiles.ini settings.
If database references are in place and you are using the Rendering Engine to create a custom
client for Vault you can code appropriate access control methods using these settings.
To control access to databases, for Vault client applications, you can set up Microsoft Windows
authentication for the databases in server.ini. For more information, refer to the Server
initialization file section in the "Vault Customizing Guide".
Provide font and image resources
If you are creating the documents using Generate the resources can be made available by passing
the HIP file to the ADM to be loaded into Vault.
Resources can be stored either in a default location or in a specific directory, known as a resource
set. Note that there is a default resource set called “default”.
For Generate created documents additional sub-directories are created for the resource set and
are not user configurable.
To change the default resource location:
Set the following keyword in server.ini
[Production]
ResourceSet=<resdir>
Where:
The meaning is different for XML journals, in this case it
is the name of the template resource set (which gets
copied into the one the xml journal process automatically
creates).
ResourceSet=
A directory in <drpath>\server\distrib\ for the
resource set. The default is Default.
<resdir>
It is important to note that this keyword should not normally be changed once you start loading
resources to Vault.
45EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
To configure an application resource set:
Set the following keyword in profiles.ini
[<Profile>]
ResourceSet=<resdir>
Where:
the application profile being amended.<Profile>
directory in <drpath>\server\distrib\ for the
resource set.
<resdir>
directory where the repository was installed<drpath>
Make Generate resources available
A typical Generate application will have all its resources bundled into its HIP file as part of the
application Publish process.
New resources can be made available to Vault at any time simply by placing the appropriate HIP
file in the ADM download directory.
Note that the resources are stored in sub-directories within this location, one per application version
as determined by a unique identifier within the HIP file.
Other methods of loading resources
For datastreams with embedded resources a range of utilities is provided to extract them for use
with Vault. Refer to the "Vault Customizing Guide" for further information on Vault utilities.
Note: Resource files can be added while vault is running, but ensure that you restart Vault
after changes are made to server.ini and profile.ini
Alternatively you may have the resources already available as independent files perhaps copied
from your printer and browser environment. In both cases, store them either within the appropriate
resource set or the default location by copying them into the appropriate Vault directory.
46EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
The Document Interchange Journal
A Document Interchange Journal (DIJ) is an index of documents contained within an output
datastream file created by Generate. Every output datastream created by Generate that is intended
to be stored in Vault. For example, documents for use with Service components must be accompanied
by a DIJ file.
A DIJ is an XML file and is configured as part of a publication design in the Designer. You will need
to specify parameters for the DIJ that allow Vault to identify the intended recipient of each document
using an account number and its version using a 'statement date'. See “Interfacing with Vault” in
the "Generate Users Guide" for details on creating and configuring a DIJ file as part of a Designer
application design.
At production time Generate writes an entry to the DIJ file for each document it processes. If you
use PCE or another post-composition process to merge output datastreams or to add/remove
documents, you will need to ensure that the associated DIJ is updated to reflect such changes.
When creating a DIJ the relevant vendor, payment and document control information will normally
be created automatically within the Generate environment.
In order to present documents correctly when they are viewed, the font and image resources with
which the application was designed must be made available in Vault. Refer to the "Vault Customizing
Guide" for information on working with fonts. Topics discussed include Font Embedding, Font
Substitution, and PDF enhancement.
Non-Generate created print streams
If you are using non-Generate created documents or where you need to supplement existing
resources manually, you will need to use an alternative method for loading resources into Vault.
There are two possible routes: to extract embedded resources from a datastream or to place resource
files manually in the appropriate vault directory.
Start Vault processes
In previous versions, all processes were started under a single service. The server, loader, render,
router, and indexing (Indexer as a Service) processes are separate services and will appear in the
services configuration as:
• Vault Server
• Vault Loader
• Rendering Engine
• Router
47EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
• Indexer as a Service
Separating the processes makes it easier to stop and start individual processes using standard
Microsoft Windows tools, for example: “net stop e2loaderd” would stop ADM but not server
or render.
On Microsoft Windows
For starting each service (or you can use the services applet in administrative tools):
•net start e2serverd
•net start e2loaderd
•net start e2renderd
•net start e2router
•net start indexerd
Starting manually
In a testing scenario the two main Vault processes can, if required, be started manually. When run
in this mode all output from a process is displayed in the command window from which it was started.
It is not recommended that processes be started manually in a production environment; always use
the monitoring service, refer to the previous section for details.
Note:
•e2loaderd can be started manually with -f or -b
•-b is a batch mode that exits when there is nothing left to
do
•-f starts the full loader in the foreground
manual start commands:
•e2serverd -f
•e2loaderd -f
•e2loaderd -b
•indexerd -f
Executable name changes
The following executables used from versions 5.3 and earlier have been renamed:
48EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
New NameOld Name
e2renderd.exerender
e2serverd.exeserver -s
e2loaderd.exeserver -a
e2util.exeserver -c/-h/-i
Configuring Encryption at Rest
If you plan using the Vault Encryption at Rest feature, you should plan for the deployment, installation
and configuration of a encryption key server. See "Encryption at Rest " section in the Vault
Customizing Guide for details.
Customizing the Vault environment
Customization of the Vault environment and the way client systems interact with the repository is
controlled by a series of initialization files (INIs). A set of default INIs are created as part of Vault
installation and for most installations the majority of the settings within the INIs can be left at their
default values.
For information on customizing the Vault environment using the initialization files, refer to the "Vault
Customizing Guide".
Working with Unicode data
In order to successfully load Unicode data into Vault you will need to provide either a Unicode
enabled standard journal or an XML journal. Additionally, you will need to configure the indexes to
support Unicode data.
49EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
Unicode journals
To specify a journal in Unicode enabled standard format, add the following profile options in
profiles.ini:
[someprofile]
Documents=ujournal
JournalCodePage=<codepagename>
Where <codepagename> is the encoding used for the journal (for example, UTF-8, gb18030,
windows-1252, shift_jis78, ISO-8859-1, etc.). The format of the journal has the ability to use a wide
variety of encodings. This in turn allows you specify data in languages other than English. To specify
a journal in XML format, add the following profile option in profiles.ini:
[someprofile]
Documents=uxmljournal
Note that the encoding is specified in the header of the XML file as per the XML standard.
Unicode indexes
There are two parts to each database in Vault: A single customer table and several indexes. Some
indexes, like the account number index, are required for basic Vault operations, others are optional.
Refer to the Vault Customizing Guide for information on custom indexing, this part of the configuration
has remained unchanged. However the ability to use a Unicode enabled form of the customer table
and/or indexes is now available. The Unicode customer table permits storage of names and addresses
in any language. Unicode indexes let you search attributes containing data in any language. To use
the normal customer table and index formats, no additional settings are required.
To use the Unicode customer table and index formats, with a single sort order, add the following
database option in database.ini:
[somedatabase]
LanguageDefault=<sortorder>
To use a mix of normal and Unicode customer table and index formats or multiple sort orders, add
the following database options in database.ini:
[somedatabase]
LanguageDefault=* or <sortorder>
LanguageN= * or <sortorder
Where:
50EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
LanguageDefault can either be * indicating normal customer table, indexes are normal by default
or <sortorder> indicating a Unicode customer table, indexes will be Unicode using the specified
sort order by default.
LanguageN can either be * indicating index N is normal or <sortorder> indicating index N is
Unicode and uses the specified sort order.
Sort orders
The sort order specification supports a number of options but in most cases you can specify a
minimum of options to get appropriate behavior. The typical form of the sort order is as follows:
L<language>_R<region>_AS
Examples:
English (United States)Len_RUS_AS
Chinese (China)Lzh_RCN_AS
Chinese (Singapore)Lzh_RSG_AS
Japanese (Japan)Lja_RJP_AS
Korean (South Korea)Lko_RKR_AS
Thai (Thailand)Lth_RTH_AS
Note that "_AS" is an option that reduces the significance of whitespace and punctuation which
makes searching easier.
You can get a list of registered locales by running e2util -xl from the server directory. More
detail on the collator options can be found here:
http://userguide.icu-project.org/collation/concepts
51EngageOne Vault 7.5 Vault Installation
Configuring and running Vault
Notices
Copyright ©2018 Pitney Bowes, Inc. All rights reserved.
This publication and the software described in it is supplied under license and may only be used or
copied in accordance with the terms of such license. The information in this publication is provided
for information only, is subject to change without notice, and should not be construed as a commitment
by Pitney Bowes Inc. To the fullest extent permitted by applicable laws Pitney Bowes Inc. excludes
all warranties, representations and undertakings (express or implied) in relation to this publication
and assumes no liability or responsibility for any errors or inaccuracies that may appear in this
publication and shall not be liable for loss or damage of any kind arising from its use.
Except as permitted by such license, reproduction of any part of this publication by mechanical,
electronic, recording means or otherwise, including fax transmission, without the express permission
of Pitney Bowes Inc. is prohibited to the fullest extent permitted by applicable laws.
Nothing in this notice shall limit or exclude Pitney Bowes Inc.'s liability in respect of fraud or for death
or personal injury arising from its negligence. Statutory rights of the user, if any, are unaffected.
*TALO Hyphenators and Spellers are used. Developed by TALO B.V., Bussum, Netherlands Copyright
©1998 *TALO B.V., Bussum, NL *TALO is a registered trademark ®
Encryption algorithms licensed from Unisys Corp. under U.S. Patent No. 4,558,302 and foreign
counterparts.
Security algorithms Copyright ©1991-1992 RSA Data Security Inc.
Base 14 fonts and derivations Copyright 1981 – 1983, 1989, 1993 Heidelberger Druckmaschinen
AG. All rights reserved.
Datamatrix and PDF417 encoding, fonts and derivations Copyright ©1999, 2000 DL Technology
Ltd. All rights reserved.
Barcode fonts Copyright ©1997 Terrapin Solutions Ltd. with NRB Systems Ltd.
This product includes software developed by the Apache Software Foundation
(http://www.apache.org/).
This product contains the Regex++ library Copyright ©1998-2000 Dr. John Maddock
PostScript is a trademark of Adobe Systems Incorporated.
PCL is a trademark of Hewlett Packard Company.
Portions of this software are copyright ©2013 The FreeType Project (www.freetype.org). All rights
reserved.
This software contains Ghostscript as licensed by Artifex Software Inc. under the terms of a specific
OEM agreement. Portions Copyright ©1998/2015 Artifex Software Inc. This software is based in
part on the work of the Independent JPEG Group. Portions Copyright ©2001 URW++. Portions
Copyright ©2005 LuraTech Imaging GmbH. All Rights Reserved.
The software includes ICU - International Components for Unicode (http://site.icu-project.org/)
Copyright (c) 1995-2013 International Business Machines Corporation and others.
This software is based in part on the work of the Independent JPEG Group.
53EngageOne Vault 7.5 Vault Installation
Copyright
This software contains material from OpenSSL. Copyright (c) 1998-2013 The OpenSSL Project. All
rights reserved.
This software contains material from SSLeay. Copyright (C) 1995-1998 Eric Young
(eay@cryptsoft.com)
This software contains material from zlib (zlib.net) Copyright (C) 1995-2013 Jean-loup Gailly and
Mark Adler
This software contains material from the Apache Xerces project Licensed under the Apache License,
Version 2.0 (the "License")
This product contains, swagger-annotations, version number 1.5.9 which is licensed under the
Apache license, version number 2.0. The license can be downloaded from http://swagger.io/license/.
The source code for this software is available from http://Swagger.io.
This product contains Apache Common Pool, version number 2.4.1, which is licensed under the
Apache License, version number 2.0. The license can be downloaded from
http://www.apache.org/licenses/. The source code for this software is available from
http://commons.apache.org/proper/commons-pool.
This product contains Apache Chemistry which is licensed under the Apache License, version
number 2.0. The license can be downloaded from http://www.apache.org/licenses/ The source code
for this software is available from http://chemistry.apache.org
This product contains okhttp which is licensed under the Apache License, version number 2.0. The
license can be downloaded from http://www.apache.org/licenses/ The source code for this software
is available from http://square.github.io/okhttp/
This product contains okio which is licensed under the Apache License, version number 2.0. The
license can be downloaded from http://www.apache.org/licenses/ The source code for this software
is available from http://github.com/square/okio
Otherwise all product names are trademarks or registered trademarks of their respective holders.
Printed in the UK.
54EngageOne Vault 7.5 Vault Installation
Copyright
3001 Summer Street
Stamford CT 06926-0700
USA
www.pitneybowes.com
© 2018 Pitney Bowes Software Inc.
All rights reserved

Navigation menu
