VectorLine constructor and variables

.....................VectorLine (constructor)!3

..................................................active!4

..........................................capLength!4

................................................collider!4

..................................................color!! 4

.........................................continuous!5

..............................continuousTexture!5

..................................................depth!5

.............................................drawEnd!5

............................................drawStart!5

...................................drawTransform!6

...............................................endCap!6

..................................................joins! ! 6

..................................................layer!! 6

............................................lineWidth!6

...............................................material!7

.................................................matrix!7

...................................maxDrawIndex!7

...............................maxWeldDistance!7

..................................................mesh!! 7

....................................minDrawIndex!7

..................................................name!8

..................................physicsMaterial!8

................................................points2!8

...............................................points3!8

......................................smoothColor!8

......................................smoothWidth!8

....................................sortingLayerID!9

.......................................sortingOrder!9

.......................................textureOﬀset!9

.......................................textureScale!9

.................................................trigger!9

............................useViewportCoords!9

......................................vectorLayer!10

..................................vectorLayer3D!10

.....................................vectorObject!10

VectorPoints

...............VectorPoints (constructor)!11

VectorLine functions

.....................................AddNormals!12

....................................AddTangents!12

.................................................Draw!12

............................................Draw3D!12

.....................................Draw3DAuto!13

...........................................GetColor!13

........................................GetLength!13

...........................................GetPoint!13

.......................................GetPoint01!14

.......................................GetPoint3D!14

...................................GetPoint3D01!14

........................GetSegmentNumber!15

..........................................GetWidth!15

.......................................MakeCircle!15

........................................MakeCube!16

.......................................MakeCurve!17

......................................MakeEllipse!18

.........................................MakeRect!19

......................................MakeSpline!19

..........................................MakeText!20

................................MakeWireframe!20

............................ResetTextureScale!20

...............................................Resize!21

...........................................Selected!22

...........................................SetColor!23

.........................................SetColors!23

....................................SetDistances!23

...........................................SetWidth!23

.........................................SetWidths!24

........................StopDrawing3DAuto!24

........................................ZeroPoints!24

INDEX!

VectorLine static functions and variables

........................BytesToVector2Array!25

........................BytesToVector3Array!25

.............................................Destroy!25

.......................................GetCamera!26

..........................................MakeLine!26

...............................RemoveEndCap!26

.......................................SetCamera!27

...................................SetCamera3D!27

................SetCameraRenderTexture!28

..........................................SetDepth!28

.......................................SetEndCap!29

.............................................SetLine!30

.........................................SetLine3D!30

...........................SetLineParameters!31

..............................................SetRay!31

.........................................SetRay3D!32

........................SetVectorCamDepth!32

..................................useMeshLines!32

................................useMeshPoints!32

..............................................Version!32

VectorManager functions and variables

..........................GetBrightnessValue!33

.....................................ObjectSetup!33

................SetBrightnessParameters!34

.......................................useDraw3D!34

A note about parameter conventions

All parameters where only the type is listed must

be supplied. All parameters where a default value

is listed are optional, and will use the default value

if they are omitted.

INDEX!

VectorLine (name : String,

points : Vector2[] or Vector3[],

material : Material,

lineWidth : float,

lineType : LineType = LineType.Discrete,

joins : Joins = Joins.None) : VectorLine

Constructs a VectorLine object with the supplied parameters. The parameters after lineWidth are optional

and have the default values indicated, though if you supply joins, you must also supply lineType.

name is a string that’s used to name the mesh created for the vector line. It’s also used in the name of the

GameObject that this constructor generates, where the complete name is “Vector ” plus the supplied name.

The name is also used to identify bounds meshes made with VectorManager.ObjectSetup.

points is a Vector2 or Vector3 array, where each entry is a point in the line using screen-space coordinates (in

the case of a Vector2 array), or world units (in the case of a Vector3 array).

The line is drawn using the material supplied by material. If diﬀerent line depths are used, the material should

use a shader that writes to the depth buﬀer for this to work reliably. The shader should use vertex colors in

order for line segment colors to work. Note: if null is passed for the material, a default material is used. This

material uses a basic shader which works with vertex colors and line depths, but has no texture.

The lineWidth is the width in pixels. This is a ﬂoat, so values like 1.5 are acceptable.

lineType is either LineType.Discrete or LineType.Continuous. For discrete lines, each line segment is made

from two entries in the Vector2 array. For continuous lines, the line starts at entry 0, and each segment is

continuously connected to the next point until the end is reached.

joins is one of Joins.None, Joins.Fill, or Joins.Weld. Joins.None is the default and draws line segments as

standard rectangles, primarily used with thin lines. Joins.Fill will ﬁll in the gaps seen where lines join at an

angle, primarily used with thick lines with no texture. This only works if using LineType.Continuous.

Joins.Weld is similar, except vertices of sequential line segments are welded, which makes it more

appropriate for textured lines. This works with LineType.Discrete, but only for sequential line segments.

The default color for the line is Color.white. This can be overridden; see below.

VectorLine (name : String,

points : Vector2[] or Vector3[],

color : Color,

material : Material,

lineWidth : float,

lineType : LineType = LineType.Discrete,

joins : Joins = Joins.None) : VectorLine

As above, but the supplied color creates a Color array of the appropriate length for the lineType (half the

length of the points array for Discrete, the length minus one for Continuous), ﬁlled with color. The line will be

drawn with this color as long as the shader used in the material for the line works with vertex colors.

VECTORLINE CONSTRUCTOR AND VARIABLES"3

VectorLine (name : String,

points : Vector2[] or Vector3[],

colors : Color[],

material : Material,

lineWidth : float,

lineType : LineType = LineType.Discrete,

joins : Joins = Joins.None) : VectorLine

As above, but the supplied colors is a Color array where each entry describes a color for a line segment in

the points array. This Color array must be half the length of the points array for LineType.Discrete (since

each line segment is created from two points), and the length minus one for LineType.Continuous. In other

words, one entry in the Color array for each line segment.

active

var active : boolean;

Sets a VectorLine active or inactive. Inactive VectorLines have their renderer disabled, and if an inactive

VectorLine is used with functions like Draw, the function will return immediately and do nothing.

capLength

var capLength : float = 0;

Sets the line’s capLength to the supplied ﬂoat. This is the number of pixels added to either end of the line (0

by default). Typically used for ﬁlling in gaps seen in thick lines when they are joined at right angles, such as

when drawing selection boxes or other rectangles.

collider

var collider : boolean = false;

If true, the line will generate a matching 2D collider when it’s drawn. The collider is updated if the line is

changed and re-drawn. If the line has been drawn with a collider, setting this to false will disable the collider.

Works with lines made with Vector3 points as well as lines made with Vector2 points. Since 2D colliders are

on the X/Y plane only, the camera should be facing along the Z axis, with no rotation, in order for the collider

to correctly match the line.

color

var color : Color; (read only)

Returns the color that was used to make the VectorLine. If a color array was used, it returns the ﬁrst entry in

that array. Use the VectorLine.SetColor function to change the color, or the VectorLine.SetColors function to

change the color array.

VECTORLINE CONSTRUCTOR AND VARIABLES"4

continuous

var continuous : boolean; (read only)

True if the VectorLine was made with LineType.Continuous, false if it was made with LineType.Discrete.

continuousTexture

var continuousTexture : boolean = false;

If this is set to true, then any texture used for the line will be stretched evenly along the entire length of the

line, regardless of how many points make up the line or how far apart the points are spaced. If set to false,

then the texture is repeated once for every line segment (which is the default).

depth

var depth : int = 0;

Sets the line’s depth to the supplied integer value. It will be clamped between 0 and 100. This is used to

specify the order in which lines are drawn, primarily used to determine which lines are drawn on top in the

case when they overlap. Lines with higher values are drawn on top of lines with lower values, as long as the

lines are drawn with materials that use shaders with ZWrite On, so they write to the zbuﬀer. VectorLine.Draw

must be called after setting the lineDepth value for the eﬀect to be visible on-screen.

drawEnd

var drawEnd : int;

Speciﬁes the index in the VectorLine’s points array at which line drawing should end. Any later points will be

erased when VectorLine.Draw is called. (Erased on-screen, not from the points array.) When used with a

discrete line, drawEnd should be an odd number. If it’s even, it will be incremented to the next highest

integer. It’s clamped between 0 and pointsArray.Length-1. This can be used with drawStart to specify a range

of points to draw in a line without having to manually erase points in the array.

drawStart

var drawStart : int;

Speciﬁes the index in the VectorLine’s points array at which line drawing should start. Any earlier points will

be erased when VectorLine.Draw is called. (Erased on-screen, not from the points array.) When used with a

discrete line, drawStart should be an even number. If it’s odd, it will be incremented to the next highest

integer. It’s clamped between 0 and pointsArray.Length-1.

VECTORLINE CONSTRUCTOR AND VARIABLES"5

drawTransform

var drawTransform : Transform;

When drawn, the line is modiﬁed by the supplied transform. For example, if the transform is located at

Vector3(5.0, 2.0, 0.0), then the line is oﬀset by 5 units on the X axis and 2 units on the Y axis. A transform

that’s rotated will cause the line to be rotated by the same amount, and a transform that’s scaled will cause

the line to be scaled by the same amount, though it will always be drawn with the correct thickness. If the

transform is modiﬁed, the line will need to be re-drawn in order to reﬂect the changes.

endCap

var endCap : String;

Speciﬁes an end cap for the VectorLine, using a name as deﬁned in SetEndCap. The name is case-sensitive,

and SetEndCap must have been called before an end cap can be added. If null or “” is used for the string,

then the end cap is removed from the VectorLine.

joins

var joins : Joins;

Returns the Joins type that was used when the line was created, and can be used to change the Joins type

at any time. Does nothing if Joins.Fill is used with a discrete line. Also does nothing if the line is VectorPoints

and either Joins.Fill or Joins.Weld are used.

layer

var layer : int = 31;

Sets the line object’s layer to the supplied integer value. Layers are used with camera culling masks. Lines by

default use layer 31, unless drawn with DrawLine3D, in which case they use layer 0 by default.

lineWidth

var lineWidth : float;

The width of the line, in pixels. This can be used to change the width of a VectorLine object after it’s been

declared. If a VectorLine has multiple widths, then setting lineWidth will set all widths in the array to the

supplied value, and reading lineWidth will return the value of the ﬁrst entry in the array. VectorLine.Draw must

be called after setting the lineWidth value for the eﬀect to be visible on-screen.

VECTORLINE CONSTRUCTOR AND VARIABLES"6

material

var material : Material;

Returns the material that was used when the VectorLine was set up, and can be used to assign a diﬀerent

material at any time after the line has been created.

matrix

var matrix : Matrix4x4;

The line will be modiﬁed by the supplied Matrix4x4 when it’s drawn. This is similar to using drawTransform,

except no other object is required since the matrix is supplied directly.

maxDrawIndex

var maxDrawIndex : int;

When drawn, the line drawing routine will stop with this index in the Vector2 or Vector3 array. By default, this

is the array’s length-1. Used for updating part of the line instead of the whole thing, which can be used for

optimization. If the line has been drawn previously, the segments after minDrawIndex are untouched, rather

than being erased. Also aﬀects updating of line segment colors with VectorLine.SetColors.

maxWeldDistance

var maxWeldDistance : float;

The number of pixels that a weld can extend, from where a given line segment joins with the next line

segment. If this distance is exceeded, the weld is cancelled. By default, maxWeldDistance is twice the pixel

width of the line when it was created.

mesh

var mesh : Mesh;

The mesh used for the actual GameObject that contains the VectorLine. Use this rather than

VectorLine.VectorObject.GetComponent(MeshFilter).mesh.

minDrawIndex

var minDrawIndex : int;

When drawn, the line drawing routine will start with this index in the Vector2 or Vector3 array. This is 0 by

default. Used for updating part of the line instead of the whole thing, which can be used for optimization. If

the line has been drawn previously, the segments before minDrawIndex are untouched, rather than being

erased. Also aﬀects updating of line segment colors with VectorLine.SetColors.

VECTORLINE CONSTRUCTOR AND VARIABLES"7

name

var name : string;

Returns the name of the line that was supplied when the VectorLine was constructed. If the name is changed

using VectorLine.name after the line has been constructed, then the VectorLine.vectorObject and mesh

names will also change appropriately.

physicsMaterial

var physicsMaterial : PhysicsMaterial2D;

If a collider is used for the line, it will have the supplied PhysicsMaterial2D. Requires Unity 4.3 or later.

points2

var points2 : Vector2[];

This is a reference to the array of Vector2 points that was used when the line was set up. The entries in the

array can be changed at any time, and then VectorLine.Draw used to draw the line with the updated points. If

points2 is resized, an error will be generated when the line is drawn. If it’s necessary to resize this array, use

the VectorLine.Resize function. If the line was made with Vector3 points, then points2 is null.

points3

var points3 : Vector3[];

Similar to points2, except it’s a reference to the array of Vector3 points that was used when the line was set

up. If the line was made with Vector2 points, then points3 is null.

smoothColor

var smoothColor : boolean = false;

Should line segment colors in this VectorLine be smoothly interpolated between segments? By default this is

false, so each segment has its own discrete color. Line segment colors are set with VectorLine.SetColor and

VectorLine.SetColors.

smoothWidth

var smoothWidth : boolean = false;

Should line segment widths in this VectorLine be smoothly interpolated between segments? By default this is

false, so each segment has its own discrete width. Line segment widths are set with VectorLine.SetWidth and

VectorLine.SetWidths.

VECTORLINE CONSTRUCTOR AND VARIABLES"8

sortingLayerID

var sortingLayerID : int = 0;

The line will be drawn with the speciﬁed sorting layer, if it exists. This can be used to control the drawing

order between the line and other objects with a diﬀerent sorting layer. Requires Unity 4.3 or later.

sortingOrder

var sortingOrder : int = 0;

The line will be drawn with the speciﬁed sorting order. This can be used to control the drawing order between

the line and other objects within the same sorting order. Requires Unity 4.3 or later.

textureOﬀset

var textureOffset : float = 0.0;

Used in combination with textureScale. If the value of textureScale is not 0.0, then the texture will be

horizontally oﬀset (relative to the line) proportionally by the amount speciﬁed in textureOﬀset.

textureScale

var textureScale : float = 0.0;

Used for making uniform-scaled textures, such as dotted or dashed lines. If not 0.0, then the width of the

texture supplied by the line’s material is scaled by the speciﬁed amount compared to its height, and the

texture is repeated this way for the length of the line. For example, a value of 1.0 means a square texture

would be as wide as it is high.

trigger

var trigger : boolean = false;

If VectorLine.collider has been set, then VectorLine.trigger controls whether the collider is set as a trigger or

not.

useViewpointCoords

var useViewportCoords : boolean = false;

If true, the line (or points) is drawn with viewport coordinates, where Vector2(0.0, 0.0) is the lower-left corner

of the screen, and Vector2(1.0, 1.0) is the upper-right corner, regardless of resolution. Works with Vector2

coordinates only.

VECTORLINE CONSTRUCTOR AND VARIABLES"9

vectorLayer

static var vectorLayer : int = 31;

Sets the default layer that VectorLines will be drawn in, and which the vector camera will see. Should be set

before using VectorLine.SetCamera for it to have any eﬀect. Note that this is a static variable and applies to

all lines. Therefore it should be used like “VectorLine.vectorLayer = 20;”.

vectorLayer3D

static var vectorLayer3D : int = 0

Sets the default layer that lines drawn with DrawLine3D will be drawn in. Note that this is a static variable and

applies to all lines. Therefore it should be used like “VectorLine.vectorLayer3D = 1;”.

vectorObject

var vectorObject : GameObject;

This is a reference to the actual GameObject that’s used to hold the line mesh. It’s possible to move lines

around by using vectorObject.transform, but care should be used when doing this, since it’s possible to

break the way Vectrosity works if the transform is rotated or scaled inappropriately. In most cases it it’s more

appropriate to pass in a diﬀerent transform using drawTransform instead of directly manipulating the

vectorObject.

VECTORLINE CONSTRUCTOR AND VARIABLES"10

VectorPoints (name : String,

points : Vector2[] or Vector3[],

material : Material,

width : float) : VectorPoints

Constructs a VectorPoints object for a Vector2 array with the supplied parameters. name is a string that’s

used to name the mesh created for the vector points. It’s also used in the name of the GameObject that this

constructor generates, where the complete name is “Vector ” plus the supplied name.

points is a Vector2 or Vector3 array, where each entry is a point using screen-space coordinates (for Vector2

arrays) or world-space coordinates (for Vector3 arrays).

The points are drawn using the material supplied by material. If diﬀerent depths are used, the material

should use a shader that writes to the depth buﬀer for this to work reliably. The shader should use vertex

colors for point colors to work. If null is passed for the material, a default material is used. This material uses

a basic shader which works with vertex colors and line depths, but has no texture.

The width is the width in pixels. This is a ﬂoat, so values like 1.5 are acceptable.

Most functions that accept a VectorLine object will also work with VectorPoints, such as Draw, Draw3D,

MakeCurve, etc. Most of the variables for VectorLine (depth, minDrawIndex, etc.) work with VectorPoints,

except for capLength, joins, maxWeldDistance, and smoothWidth.

VectorPoints (name : String,

points : Vector2[],

color : Color,

material : Material,

width : float) : VectorPoints

As above, but the supplied color creates a Color array of the appropriate length, ﬁlled with color. The points

will be drawn with this color as long as the shader used in the material for the line works with vertex colors.

VectorPoints (name : String,

points : Vector2[],

color : Color[],

material : Material,

width : float) : VectorPoints

As above, but the supplied color is a Color array where each entry describes a color for the corresponding

point in the points array. All points will therefore be drawn with the respective color, as long as the shader

used in the material for the line works with vertex colors.

VECTORPOINTS"11

AddNormals

function AddNormals () : void

Creates mesh normals for a VectorLine. This should be called when a material that has a shader which

requires normals is used for the VectorLine.

AddTangents

function AddTangents () : void

Creates mesh tangents for a VectorLine. This should be called when a material that has a shader which

requires tangents is used for the VectorLine. AddNormals is called automatically whenever AddTangents is

called, since tangents require normals.

Draw

function Draw () : void

Draws the VectorLine or VectorPoints object on the screen. If VectorLine.SetCamera has not been called, it’s

called the ﬁrst time Draw is used, using the default parameters. Lines with either Vector2 or Vector3 arrays

can be used.

Draw3D

function Draw3D () : void

Draws the VectorLine object on the screen in 3D space (in contrast to Draw, which draws all lines in 2D with a

separate camera overlaid on top of the standard camera). The array of points used to create the VectorLine

object must be of type Vector3[]. If VectorLine.SetCamera3D has not been called, it’s called the ﬁrst time

DrawLine is used, using the default parameters. Since the lines exist in the scene and are not drawn in a

separate overlay as they are with Draw, they must be updated when the camera used in SetCamera changes

position or else they will no longer have the correct appearance.

Draw3D doesn’t use the vector camera object as created by SetCamera. Lines drawn with Draw3D are put

on layer 0 by default. This default layer can be changed by setting VectorLine.vectorLayer3D.

VectorLine functions are used with a VectorLine object. For example, “myLine.Draw()” or

“rectLine.MakeRect (someRect)”.

VECTORLINE FUNCTIONS"12

Draw3DAuto

function Draw3DAuto (time : float = Mathf.Infinity) : void

Draws the VectorLine object as DrawLine3D does, but automatically updates the line every frame. Therefore,

lines drawn with Draw3DAuto don’t need to be updated manually and will always appear correct regardless

of camera movement and so on.

The optional time is the number of seconds for which the line will be drawn, after which it’s destroyed. The

default is that the line is never destroyed.

GetColor

function GetColor (index : int) : Color

Returns the color of the line segment speciﬁed by the index.

GetLength

function GetLength () : float

Returns the total length of all line segments that make up the VectorLine. The length refers to pixels when

used with Vector2 lines, and world units when used with Vector3 lines. If the points that make up the line

array are changed after GetLength is called, then SetDistances should be called before using GetLength

again in order to maintain accurate segment distances.

GetPoint

function GetPoint (distance : float) : Vector2

Returns a Vector2 in screen-space coordinates that corresponds to the given distance in the VectorLine. If

distance is equal to or less than 0, then the ﬁrst point in the VectorLine is returned. If the distance is equal to

or greater than the total length of the line as deﬁned by GetLength, then the last point in the VectorLine is

returned. The ﬁrst and last points are clamped by the VectorLine’s drawStart and drawEnd values. If the

points that make up the line array are changed after GetPoint is called, then SetDistances should be called

before using GetPoint again in order to maintain accurate segment distances.

function GetPoint (distance : float

out index : int) : Vector2

As above, but the out parameter index will contain the line segment index that corresponds to the distance.

VECTORLINE FUNCTIONS"13

GetPoint01

function GetPoint01 (distance : float) : Vector2

Same as GetPoint, except that distance is normalized between 0.0 and 1.0, where 0.0 is the ﬁrst point in the

VectorLine and 1.0 is the last point in the VectorLine.

function GetPoint01 (distance : float

out index : int) : Vector2

As above, but the out parameter index will contain the line segment index that corresponds to the distance.

GetPoint3D

function GetPoint3D (distance : float) : Vector3

Returns a Vector3 in world-unit coordinates that corresponds to the given distance in the VectorLine. If

distance is equal to or less than 0, then the ﬁrst point in the VectorLine is returned. If the distance is equal to

or greater than the total length of the line as deﬁned by GetLength, then the last point in the VectorLine is

returned. The ﬁrst and last points are clamped by the VectorLine’s drawStart and drawEnd values. If the

points that make up the line array are changed after GetPoint3D is called, then SetDistances should be called

before using GetPoint3D again in order to maintain accurate segment distances.

function GetPoint3D (distance : float

out index : int) : Vector2

As above, but the out parameter index will contain the line segment index that corresponds to the distance.

GetPoint3D01

function GetPoint3D01 (distance : float) : Vector3

Same as GetPoint3D, except that distance is normalized between 0.0 and 1.0, where 0.0 is the ﬁrst point in

the VectorLine and 1.0 is the last point in the VectorLine.

function GetPoint3D01 (distance : float

out index : int) : Vector2

As above, but the out parameter index will contain the line segment index that corresponds to the distance.

VECTORLINE FUNCTIONS"14

GetSegmentNumber

function GetSegmentNumber () : int

Returns the number of line segments that it would be possible to make with the given VectorLine. This is the

number of points in the Vector2 or Vector3 array minus one for continuous lines, and half the number of

points for discrete lines.

GetWidth

function GetWidth (index : int) : float

Returns the width of the line segment speciﬁed by the index.

MakeCircle

function MakeCircle (origin : Vector2 or Vector3,

up : Vector3 = Vector3.forward,

radius : float,

segments : int = all,

pointRotation : float = 0.0,

index : int = 0) : void

Creates a circle in the Vector2 or Vector3 array for the VectorLine. If using Vector2, the supplied origin is in

screen space pixels, as is the supplied radius. If using Vector3, the coordinates are world space.

The optional up vector indicates the orientation of circles when drawn using Vector3 arrays. It has no eﬀect

when using a Vector2 array. The default of Vector3.forward means that the circle is drawn in the X/Y plane.

Using Vector3.up would mean that the circle would be drawn in the X/Z plane. The up vector can be any

arbitrary vector and does not need to be normalized.

The optional segments indicates how many line segments will be used to create the circle, with a minimum

of 3. If segments is omitted, then all of the segments in the VectorLine will be used. This is normally used with

the index parameter to create multiple circles in the same VectorLine.

The optional pointRotation describes how many degrees clockwise the points will be rotated around the

origin. Negative values rotate the points counter-clockwise.

The optional index is 0 by default, though it can be anything, as long as the number of segments would ﬁt in

the Vector2 or Vector3 array. This allows creation of multiple circles in the same line, since the points used to

create the circle start at the value deﬁned by index. The length of the Vector2 or Vector3 array used for line

must be at least the number of segments speciﬁed plus one if the line was created as continuous line, or

twice the number of segments if it was created as a discrete line. Note that specifying the index also

requires that segments be speciﬁed.

VECTORLINE FUNCTIONS"15

MakeCube

function MakeCube (origin : Vector3,

xSize : float,

ySize : float,

zSize : float,

index : int = 0) : void

Creates a cube in the Vector3 array (which must have a length of at least 24) for the VectorLine, which must

use a discrete line. The origin is the world-space coordinate for the center of the cube. The xSize, ySize, and

zSize are ﬂoats indicating how many units in size the cube is for those dimensions. The optional index is 0

by default, though it can be anything, as long as the length of the array is at least 24 plus the index.

VECTORLINE FUNCTIONS"16

MakeCurve

function MakeCurve (curvePoints : Vector2[] or Vector3[],

segments : int,

index : int = 0) : void

Creates a bezier curve in the Vector2 or Vector3 array for the VectorLine. The supplied curvePoints is a

Vector2 or Vector3 array that must contain four elements, where the elements are Vector2s using screen

space pixel coordinates or Vector3s using world space coordinates, and are deﬁned as follows:

curvePoints[0] = the ﬁrst anchor point of the curve

curvePoints[1] = the ﬁrst control point of the curve

curvePoints[2] = the second anchor point of the curve

curvePoints[3] = the second control point of the curve

The supplied segments indicates how many line segments will be used to create the curve, with a minimum

of 2. The optional index is 0 by default, though it can be anything, as long as the number of segments would

ﬁt in the line array. This allows creation of multiple curves in the same line, since the points used to create the

curve start at the value deﬁned by index. The length of the array used for line must be at least the number of

segments speciﬁed plus one if the line was created as continuous line, or twice the number of segments if it

was created as a discrete line.

Example: a curve with 10 segments would require an array in line that contains 11 points, as long as line is a

continuous line. If it was a discrete line, the array would need to contain 20 points. Two curves of 10

segments each in the same line would require double the number of points, or 22 and 40 respectively. The

index for the second curve would be 11 for a continuous line or 20 for a discrete line.

function MakeCurve (anchor1 : Vector2 or Vector3,

control1 : Vector2 or Vector3,

anchor2 : Vector2 or Vector3,

control2 : Vector2 or Vector3,

segments : int,

index : int = 0) : void

The anchor and control points for the curve are deﬁned as individual Vector2s or Vector3s rather than a

Vector2[] or Vector3[] array, but otherwise this is the same as above. The Vector2s use screen space pixel

coordinates, and Vector3s use world space coordinates.

function MakeCurve (curvePoints : Vector2[] or Vector3[]) : void

As above, but since the number of segments isn’t speciﬁed, the maximum allowed by the entire Vector2 or

Vector3 array will be used.

VECTORLINE FUNCTIONS"17

MakeEllipse

function MakeEllipse (origin : Vector2 or Vector3,

up : Vector3 = Vector3.forward,

xRadius : float,

yRadius : float,

segments : int = all,

pointRotation : float = 0.0,

index : int = 0) : void

Creates an ellipse in the Vector2 or Vector3 array for the VectorLine. For Vector2, the supplied origin is in

screen space pixels, as are the supplied radii. Vector3 uses world space coordinates. xRadius is the

horizontal radius of the ellipse, and yRadius is the vertical radius.

The optional up vector indicates the orientation of ellipses when drawn using Vector3 arrays. It has no eﬀect

when using a Vector2 array. The default of Vector3.forward means that the ellipse is drawn in the X/Y plane.

Using Vector3.up would mean that the ellipse would be drawn in the X/Z plane. The up vector can be any

arbitrary vector and does not need to be normalized.

The optional segments indicates how many line segments will be used to create the ellipse, with a minimum

of 3. If segments is omitted, then all of the segments in the VectorLine will be used. This is normally used with

the index parameter to create multiple ellipses in the same VectorLine.

The optional pointRotation describes how many degrees clockwise the points will be rotated around the

origin. Negative values rotate the points counter-clockwise.

The optional index is 0 by default, though it can be anything, as long as the number of segments would ﬁt in

the Vector2 or Vector3 array. This allows creation of multiple ellipses in the same line, since the points used

to create the ellipse start at the value deﬁned by index. The length of the Vector2 or Vector3 array used for

line must be at least the number of segments speciﬁed plus one if the line was created as continuous line,

or twice the number of segments if it was created as a discrete line. Note that specifying the index also

requires that segments be speciﬁed.

VECTORLINE FUNCTIONS"18

MakeRect

function MakeRect (rect : Rect,

index : int = 0) : void

Creates a rectangle in the Vector2 or Vector3 array for the VectorLine. The supplied rect is in screen space

pixels if using Vector2, or world space coordinates if using Vector3.

The optional index is 0 by default, though it can be anything, as long as the rect would ﬁt in the Vector2 or

Vector3 array. This allows creation of multiple rectangles in the same line, since the points used to create the

rectangle start at the value deﬁned by index. The length of the Vector2 or Vector3 array used for line must be

at least 5 if the line was created as continuous line, or 8 if it was created as a discrete line.

function MakeRect (topLeft : Vector2 or Vector3,

bottomRight : Vector2 or Vector3,

index : int = 0) : void

Creates a rectangle in the Vector2 or Vector3 array for the VectorLine. The supplied topLeft and

bottomRight describe the respective corners of the rectangle in screen space pixels if using Vector2, or

world space coordinates if using Vector3. Otherwise this is the same as MakeRectInLine using a Rect.

MakeSpline

function MakeSpline (splinePoints : Vector2[] or Vector3[],

segments : int,

index : int = 0,

loop : boolean = false) : void

Creates a Catmull-Rom spline in the Vector2 or Vector3 array for the VectorLine. The supplied splinePoints

are a Vector2 (screen space) or Vector3 (world space) array deﬁning the points that should be used to create

the spline. The resulting curve will pass directly through all points in the splinePoints array. The supplied

segments indicates how many line segments will be used to create the circle, with a minimum of 3. loop

indicates whether the ﬁrst and last points in the splinePoints array will be connected or not.

The optional index is 0 by default, though it can be anything, as long as the number of segments would ﬁt in

the Vector2 or Vector3 array. This allows creation of multiple splines in the same line, since the points used to

create the spline start at the value deﬁned by index. The length of the Vector2 or Vector3 array used for line

must be at least the number of segments speciﬁed plus one if the line was created as continuous line, or

twice the number of segments if it was created as a discrete line.

function MakeSpline (splinePoints : Vector2[] or Vector3[],

loop : boolean = false) : void

As above, but since the number of segments isn’t speciﬁed, the maximum allowed by the entire Vector2 or

Vector3 array will be used.

VECTORLINE FUNCTIONS"19

MakeText

function MakeText (text : String,

position : Vector2 or Vector3,

size : float,

characterSpacing : float = 1.0,

lineSpacing : float = 1.5,

uppercaseOnly : boolean = true) : void

Creates the string text in VectorLine line. The text is placed at position using screen-space pixel coordinates

if used with Vector2 points, or world space coordinates if used with Vector3 points. size is the number of

pixels in height if used with Vector2 points, or world units if used with Vector3 points. Text is always

monospaced. Any characters not present in the default font are ignored. “\n” can be used as a newline

character. If the points array for line is not large enough to contain the line segments that make up the text, it

will be resized appropriately. If this happens, any variables referencing the original points array will no longer

reference the new points array. If a new reference is needed, it should be assigned to line.points2 if the line

was made with Vector2 points, or line.points3 if the line was made with Vector3 points.

The optional characterSpacing is 1.0 by default, which is a relative value, where 1.0 equals size, .5 would

be half of size, etc. The optional lineSpacing is 1.5 by default, and is also a relative value in the same way. If

supplying either the character spacing or the line spacing, both values must be supplied.

The optional uppercaseOnly is true by default, which makes the text always display using uppercase

characters, even if text contains lowercase characters.

MakeWireframe

function MakeWireframe (mesh : Mesh) : void

Creates a wireframe in the VectorLine using all the triangles in mesh. The points array used to create line

must be of type Vector3, and the line must be created using LineType.Discrete. If the points array for line is

not large enough to contain the line segments that make up the wireframe, it will be resized appropriately.

ResetTextureScale

function ResetTextureScale () : void

Sets all UVs in the mesh object for the VectorLine to their initial values. Used after

VectorLine.SetTextureScale has been called, in case a return to the default state is desired.

VECTORLINE FUNCTIONS"20

Resize

function Resize (linePoints : Vector2[]) : void

Resizes the Vector2 points array in this VectorLine to that supplied by linePoints. VectorLine.Draw must be

called afterwards for the new line to show up. If line segment widths have been supplied with

VectorLine.SetWidths, they must be reset, and the same applies to VectorLine.SetColors (if a color array has

been used for the line, all entries will be initially set to whatever the ﬁrst color in the color array was).

function Resize (linePoints : Vector3[]) : void

As above, but for lines using a Vector3 array.

function Resize (newSize : int) : void

Resizes the number of points for the Vector2 or Vector3 array in this VectorLine to the number supplied by

newsize. The points in the newly sized array are all set to zero, and the reference to the original Vector2 or

Vector3 array used for making this VectorLine will no longer be valid, so VectorLine.points2 or

VectorLine.points3 should be used instead. In other words, here’s a line set to 4 points ﬁrst, and resized to 2

points:

var linePoints = [Vector2(10, 10), Vector2(50, 50), Vector2(100, 100), Vector2(200, 200)];

var line = new VectorLine("Example", linePoints, null, 2.0);

line.Resize(2);

linePoints = line.points2;

linePoints[0] = Vector2(20, 20);

linePoints[1] = Vector2(150, 150);

line.Draw();

VECTORLINE FUNCTIONS"21

Selected

function Selected (position : Vector2) : boolean

Returns true if this VectorLine contains position, which is a screen-space coordinate, such as that provided

by Input.mousePosition. (Vector3 is implicitly cast to Vector2, so Input.mousePosition will work directly even

though it’s technically a Vector3.)

function Selected (position : Vector2,

out index : int) : boolean

Returns true if this VectorLine contains position. The index is an integer variable declared elsewhere, which

will contain the line segment index when passed in to the Selected function. If Selected returns false, then

index will contain -1. If using VectorPoints instead of VectorLine, then index is the point that’s currently

selected rather than the line segment.

function Selected (position : Vector2,

extraDistance : int,

out index : int) : boolean

Returns true if this VectorLine contains position. The extraDistance parameter is the number of pixels that a

line is expanded by for the purposes of determining whether it contains position, so that the position doesn’t

need to be exact in order to register as being inside the line. The extra distance is for computation only and

does not aﬀect the visual appearance of the line. As above, the index is an integer variable which will contain

the line segment index.

VECTORLINE FUNCTIONS"22

SetColor

function SetColor (color : Color) : void

Sets all the line segment colors in the VectorLine to the supplied color. The line has its color changed

immediately without having to call VectorLine.Draw.

function SetColor (color : Color, index : int) : void

Sets the line segment speciﬁed by index to the supplied color. The other line segments are unaﬀected. The

line has its color changed immediately without having to call VectorLine.Draw.

function SetColor (color : Color, startIndex : int, endIndex : int) : void

Sets the line segments speciﬁed by startIndex up to and including endIndex to the supplied color. The

other line segments outside of this range are unaﬀected. The line has its color changed immediately without

having to call VectorLine.Draw.

SetColors

function SetColors (colors : Color[]) : void

Sets all the line segment colors in the VectorLine to the supplied colors array. The line has its colors changed

immediately without having to call VectorLine.Draw. Each entry in the color array corresponds to a line

segment, so the length of the color array must be half the length of the Vector2 or Vector3 array in the

VectorLine if using a discrete line, or the length of the Vector2 or Vector3 array minus one if using a

continuous line.

SetDistances

function SetDistances () : void

Used to recompute line segment distances in the VectorLine after changing any of the Vector2 or Vector3

points that make up the line. If GetLength or any of the GetPoint functions have been used, and the line

points are changed, those functions will no longer return accurate information unless SetDistances is called

before using those functions again. It’s not necessary to call SetDistances before using GetLength or any of

the GetPoint functions for the ﬁrst time.

SetWidth

function SetWidth (width : float, index : int) : void

Sets the pixel width of the line segment specified by index to the specified width. VectorLine.Draw must be

called afterwards in order for altered line segment to show up correctly.

VECTORLINE FUNCTIONS"23

SetWidths

function SetWidths (lineWidths : float[] or int[]) : void

Sets the pixel widths of the line segments in the VectorLine to the values supplied by the lineWidths array,

which can be either a ﬂoat array or an int array. Each entry in the line widths array corresponds to a line

segment, so the length of the line widths array must be half the length of the Vector2 or Vector3 array in line

if using a discrete line, or the length of the Vector2 or Vector3 array minus one if using a continuous line.

VectorLine.Draw must be called afterwards in order for the new widths to show up. Whether each line

segment is a distinct width, or the widths are smoothly blended, is determined by VectorLine.smoothWidth.

StopDrawing3DAuto

function StopDrawing3DAuto () : void

Stops the automatic update of any line drawn with Draw3DAuto.

ZeroPoints

function ZeroPoints (index : int = 0) : void

Sets points in the Vector2 or Vector3 array in the VectorLine to Vector2.zero or Vector3.zero respectively. By

default it starts from index 0 and sets all points to zero, but an index value greater than 0 can be supplied,

which zeroes out points starting from that index (must be less than the Vector2 or Vector3 array length).

function ZeroPoints (startIndex : int = 0, endIndex : int = 0) : void

As above, except it sets points to Vector2.zero or Vector3.zero in the range from startIndex up to (but not

including) endIndex.

VECTORLINE FUNCTIONS"24

BytesToVector2Array

static function BytesToVector2Array (lineBytes : byte[]) : Vector2

Converts the bytes from TextAsset.bytes to a Vector2 array, used for making speciﬁc lines without having to

use long strings of hard-coded Vector2 array data in scripts. These TextAssets are made with the LineMaker

editor script.

BytesToVector3Array

static function BytesToVector3Array (lineBytes : byte[]) : Vector3

Converts the bytes from TextAsset.bytes to a Vector3 array, used for making speciﬁc lines without having to

use long strings of hard-coded Vector3 array data in scripts. These TextAssets are made with the LineMaker

editor script.

Destroy

static function Destroy (ref line : VectorLine) : void

Removes a VectorLine (or VectorPoints) and all associated Unity objects from the scene. If line is null, it’s

ignored and no null reference exception errors are possible.

static function Destroy (ref line : VectorLine,

gameObject : GameObject) : void

Removes a VectorLine and all associated Unity objects from the scene, and destroys gameObject at the

same time. If line or gameObject are null, they are ignored and no null reference exception errors are

possible.

static function Destroy (lines : VectorLine[]) : void

Removes all of the VectorLines in the supplied array.

static function Destroy (lines : List.<VectorLine>) : void

Removes all of the VectorLines in the supplied generic List.

VectorLine static functions are not used with a VectorLine object, but are called explicitly with VectorLine.

For example, “VectorLine.SetCamera()”.

VECTORLINE STATIC FUNCTIONS"25

GetCamera

static function GetCamera () : Camera

Returns the camera used for line drawing, as made with SetCamera.

MakeLine

static function MakeLine (name : String,

points : Vector2[] or Vector3[]) : VectorLine

Creates a VectorLine from the parameters given in VectorLine.SetLineParameters, using the supplied name

and Vector2 or Vector3 array in points. This can be used as a shortcut, instead of supplying all parameters

when constructing a VectorLine. If SetLineParameters has not been called ﬁrst, an error will be generated.

static function MakeLine (name : String,

points : Vector2[] or Vector3[],

color : Color) : VectorLine

Creates a VectorLine from the parameters given in VectorLine.SetLineParameters, using the supplied name

and Vector2 or Vector3 array in points, and overrides the default color with the supplied color.

static function MakeLine (name : String,

points : Vector2[] or Vector3[],

colors : Color[]) : VectorLine

Creates a VectorLine from the parameters given in VectorLine.SetLineParameters, using the supplied name

and Vector2 or Vector3 array in points, and overrides the default color with the supplied colors array.

RemoveEndCap

static function RemoveEndCap (name : String) : void

Removes the end cap deﬁned by name from the end cap library.

VECTORLINE STATIC FUNCTIONS"26

SetCamera

static function SetCamera (camera : Camera = Camera.main,

clearFlags : CameraClearFlags = CameraClearFlags.DepthOnly,

useOrtho : boolean = false) : Camera

Sets the camera up for line drawing. This generally has to be done once at startup, though it also needs to be

called after any screen resolution changes, and may need to be called after level changes, if any non-vector

cameras aren’t manually set to ignore layer 31.

This function is used automatically with the default parameters the ﬁrst time VectorLine.Draw,

VectorLine.DrawViewport, VectorLine.SetLine, or VectorLine.SetRay is called. Therefore it only needs to be

called manually if parameters other than the defaults are desired.

The optional non-vector camera is set to the ﬁrst camera in the scene found tagged “Main Camera” by

default. This camera is used for supplying the viewpoint for any 3D vector objects, and has its culling mask

set to ignore layer 31, so lines aren’t visible except to the vector camera. Setting VectorLine.vectorLayer to

an integer, before calling SetCamera, will cause the line-drawing layer to be that supplied rather than 31.

The optional clearFlags for the vector camera is DepthOnly by default. Passing clearFlags will change this

to the supplied value instead.

The optional useOrtho is false by default. Passing true will cause the vector camera to use orthographic

mode, which may render lines slightly more accurately, but can potentially cause anomalies in 3D lines under

certain circumstances.

SetCamera returns the vector camera that’s created. This can be used if further modiﬁcations to the vector

camera are desired.

SetCamera3D

static function SetCamera3D (camera : Camera = Camera.main) : void

Sets the camera up for drawing lines with VectorLine.Draw3D. The optional camera is set to the ﬁrst camera

in the scene found tagged “Main Camera” by default. In contrast to VectorLine.SetCamera, the culling mask

for the supplied camera is not altered, and the vector camera normally used for drawing lines is not created.

This function is called automatically when DrawLine3D is used for the ﬁrst time, so it’s normally not

necessary to call it manually, unless using a camera other than “Main Camera” is desired.

VECTORLINE STATIC FUNCTIONS"27

SetCameraRenderTexture

static function SetCameraRenderTexture (renderTexture : RenderTexture,

color : Color = Color.black,

clearFlags : CameraClearFlags = CameraClearFlags.SolidColor,

useOrtho : boolean = false) : Camera

Makes the vector camera render to the speciﬁed renderTexture instead of the main screen. The

renderTexture will have the optionally supplied color as the background color (black by default). By default,

the renderTexture will use a solid color for the background, but this can be changed with the optional

clearFlags. The camera used for the renderTexture will be orthographic if the optional useOrtho is true.

Passing in null as the renderTexture will set the vector camera back to normal. SetCameraRenderTexture

calls SetCamera and returns the vector camera.

Note: this function requires Unity Pro.

SetDepth

static function SetDepth (transform : Transform,

depth : int) : void

Sets the line depth of transform to the value supplied by depth. This can be used for special eﬀects, where

transforms (usually planes) are positioned in the space used by vector lines. The object must be drawn on

the same layer as lines for it to be visible to the vector camera. The depth for VectorLines is set with

VectorLine.depth.

VECTORLINE STATIC FUNCTIONS"28

SetEndCap

static function SetEndCap (name : String,

capType : EndCap,

material : Material = null,

offset : float = 0.0;

texture1 : Texture2D = null,

texture2 : Texture2D = null) : void

Creates a named end cap that can be used with VectorLine.endCap. There can be any number of diﬀerent

end caps that exist in the end cap library, as long as each one uses a unique name. Once an end cap is set

up, it can be used by any VectorLine in any script, so SetEndCap should only be called once for each end

cap. (The end cap library exists only at runtime, not in the project.)

The name is case-sensitive.

The capType can be EndCap.Front, EndCap.Back, EndCap.Both, EndCap.Mirror, or EndCap.None.

EndCap.Front: only one texture needs to be supplied (texture1), and it will appear at the front of the line,

as deﬁned by the ﬁrst point in the array of points that makes up the VectorLine.

EndCap.Back: only one texture needs to be supplied (texture1), and it will appear at the back of the line,

as deﬁned by the last point in the array of points that makes up the VectorLine.

EndCap.Both: two textures need to be supplied (texture1 and texture2), the ﬁrst of which will appear at

the front of the line, and the second of which will appear at the back of the line.

EndCap.Mirror: only one texture needs to be supplied (texture1), which will appear at both the front and

back of the line, and the texture’s appearance at the back will be a mirror image compared to the front.

EndCap.None: the named end cap will be removed from the end cap library.

The material should normally (but not necessarily) be the same material that will be used when creating a

particular VectorLine, so that the end cap material will match the material used for the rest of the line. Note

that lines with end caps will have two draw calls instead of one. Also, only one pair of end caps can be used

for any given VectorLine, even if LineType.Discrete is used.

The oﬀset is a percentage of the end cap’s length. By default (when the oﬀset is 0.0), end caps are added to

the ends of the line. If the oﬀset is set to -1.0, for example, the end caps will be moved inward by their own

length, so the line will be as long as it would have been without end caps.

VECTORLINE STATIC FUNCTIONS"29

SetLine

static function SetLine (color : Color,

time : float = Mathf.Infinity,

params points : Vector2[] or Vector3[]) : VectorLine

Creates a VectorLine using the supplied points, and draws it immediately using the supplied color. The

points use screen-space coordinates if made with Vector2s, or world coordinates if made with Vector3s.

“Params” means that each point is supplied individually, rather than as an array. At least two Vector2s are

required; this will create a single line segment. Each additional Vector2 will extend the line to that point by

adding another line segment from the last. SetLine returns a VectorLine object, so it can be assigned to a

variable and used in any function that takes a VectorLine.

The optional time parameter speciﬁes how long, in seconds, the line will be drawn before it’s destroyed. If

this is left out, the line will never be removed.

If VectorLine.SetCamera has not been called, it’s called the ﬁrst time SetLine is used, using the default

parameters.

SetLine3D

static function SetLine3D (color : Color,

time : float = Mathf.Infinity,

params points : Vector3[]) : VectorLine

Creates a VectorLine using the supplied points, and draws it immediately using the supplied color. The

points use world-space coordinates. “Params” means that each point is supplied individually, rather than as

an array. At least two Vector3s are required; this will create a single line segment. Each additional Vector3 will

extend the line to that point by adding another line segment from the last. SetLine3D returns a VectorLine

object, so it can be assigned to a variable and used in any function that takes a VectorLine.

The lines created by SetLine3D are drawn in world space, rather than on top of other objects, and are not

seen by the vector camera, which is not required for 3D lines.

If VectorLine.SetCamera3D has not been called, it’s called the ﬁrst time SetLine3D is used, using the default

parameters.

VECTORLINE STATIC FUNCTIONS"30

SetLineParameters

static function SetLineParameters (color : Color,

material : Material,

lineWidth : float,

capLength : float,

depth : int,

lineType : LineType,

joins : Joins) : void

Used to set up the default parameters for VectorLine.MakeLine. The color, material, line width, end cap

length, depth, LineType, and Joins are then used whenever constructing a line with VectorLine.MakeLine.

When this is called again, any further lines will then use the new defaults, but already-created lines will be

unaﬀected.

SetRay

static function SetRay (color : Color,

time : float = Mathf.Infinity,

origin : Vector3,

direction : Vector3) : VectorLine

Creates a VectorLine from origin to origin + direction, and draws it immediately using the supplied color.

SetRay returns a VectorLine object, so it can be assigned to a variable and used in any function that takes a

VectorLine.

The optional time parameter speciﬁes how long, in seconds, the line will be drawn before it’s destroyed. By

default, the line will never be removed.

If VectorLine.SetCamera has not been called, it’s called the ﬁrst time SetRay is used, using the default

parameters.

VECTORLINE STATIC FUNCTIONS"31

SetRay3D

static function SetRay3D (color : Color,

time : float = Mathf.Infinity,

origin : Vector3,

direction : Vector3) : VectorLine

Creates a VectorLine from origin to origin + direction, and draws it immediately using the supplied color.

The line is drawn in world space, rather than on top of other objects, and is not seen by the vector camera,

which is not required for 3D lines. SetRay3D returns a VectorLine object, so it can be assigned to a variable

and used in any function that takes a VectorLine.

The optional time parameter speciﬁes how long, in seconds, the line will be drawn before it’s destroyed. If

this is left out, the line will never be removed.

If VectorLine.SetCamera3D has not been called, it’s called the ﬁrst time SetRay is used, using the default

parameters.

SetVectorCamDepth

static function SetVectorCamDepth (depth : int) : void

Sets the depth of the vector cam used to show lines drawn with VectorLine.Draw. By default, when

VectorLine.SetCamera is called, the depth is one greater than the depth of the standard camera, so that lines

are drawn on top of the view. By setting depth to a diﬀerent value, the depth of the vector camera can be

changed, which is normally only done for special eﬀects.

useMeshLines

static var useMeshLines : boolean = false;

If true, VectorLines will be created using MeshTopology.Lines if they are 1 pixel thick. This must be called

before any VectorLines are created; otherwise a warning is printed and MeshTopology.Lines will not be used.

useMeshPoints

static var useMeshPoints : boolean = false;

If true, VectorPoints will be created using MeshTopology.Points if they are 1 pixel big. This must be called

before any VectorLines or VectorPoints are created; otherwise a warning is printed and MeshTopology.Points

will not be used.

Version

static function Version () : String

Returns a string containing version information.

VECTORLINE STATIC FUNCTIONS"32

GetBrightnessValue

static function GetBrightnessValue (position : Vector3) : float

Given the distance of position from the non-vector camera used in VectorLine.SetCamera, returns a ﬂoat

between 0 and 1, where 0 is 0% brightness and 1 is 100% brightness.

ObjectSetup

static function ObjectSetup (gameObject : GameObject,

vectorLine : VectorLine,

visibility : Visibility,

brightness : Brightness,

makeBounds : boolean = true) : void

Makes gameObject have a “shadow” 3D vector object as deﬁned by vectorLine, which behaves according

to the transform of gameObject. Depending on the values of visibility and brightness, one or more

components may be attached to gameObject when this function is called.

visibility can be Visibility.Dynamic, Visibility.Static, Visibility.Always, or Visibility.None. Visibility.Dynamic

causes the vector line to always be drawn when gameObject is visible to a camera, using the object’s

transform. Visibility.Static only draws the vector line if the camera moves and the gameObject is visible to a

camera, and is for objects that never move, since the object’s transform is only used once when the 3D

vector line is initialized. Visibility.Always causes the vector line to be drawn every frame and has no

optimizations. Visibility.None doesn’t add any visibility components, and removes any Visibility scripts if

ObjectSetup has been called on this gameObject before.

brightness can be Brightness.Fog or Brightness.Normal. Brightness.Fog adds the BrightnessControl

component, which makes the 3D vector object’s color behave according to the parameters given in

VectorManager.SetBrightnessParameters. If SetBrightnessParameters hasn’t been called, the defaults for

that function will be used. Currently only the ﬁrst color in the array is used for the entire object.

Brightness.None doesn’t add any component, so the vector line’s color won’t be altered, and removes

BrightnessControl if ObjectSetup has been called on this gameObject before.

The optional makeBounds by default creates an invisible bounds mesh for the gameObject’s mesh ﬁlter, so

that OnBecameInvisible and OnBecameInvisible will still work, which allows optimizations for

Visibility.Dynamic and Visibility.Static. If set to false, then the gameObject’s mesh is not replaced by a

bounds mesh. One bounds mesh is created for each VectorLine name, so VectorLines that share a name will

also share a bounds mesh.

VECTORMANAGER"33

SetBrightnessParameters

static function SetBrightnessParameters (minBrightnessDistance : float = 500,

maxBrightnessDistance : float = 250,

brightnessLevels : int = 32,

frequency : float = .2,

color : Color = Color.black) : void

Sets parameters for objects that use Brightness.Fog with VectorManager.ObjectSetup.

minBrightnessDistance is the distance that the object must be from the non-vector camera in order to have

the minimum amount of brightness, or in other words have 100% “fog” color. maxBrightnessDistance is the

distance that the object must be from the non-vector camera in order to have the maximum amount (100%)

of brightness. The color of this brightness is taken from entry 0 in the vector line’s segmentColors array. The

vector line will have brightnessLevels “steps” between 0% and 100% brightness. The fewer steps, the more

obvious the transitions become as the object moves closer and farther from the camera. How often the

distance of objects is checked depends on frequency, which by default is 5 times per second. The color

deﬁnes the “fog” color.

useDraw3D

var useDraw3D : bool = false

Tells the VectorManager routines to use VectorLine.Draw3D if VectorManager.useDraw3D is set to true, or

VectorLine.Draw if set to false, which is the default. See VectorLine.Draw3D for more details about 3D lines.

VECTORMANAGER"34

Vectrosity Reference Guide

Vectrosity%20Reference%20Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
