T
RANZ® 330 gives retailers a fast, low-cost way to
authorize and process credit card sales and
guarantee checks.
It lets retailers accept debit (ATM) cards in payment,
through an optional PIN pad. Plus, it supports other point-
of-service (POS) applications involving the transfer of value,
such as healthcare and government benefits programs.
With TRANZ 330, you can connect a slip, roll or sprocket
printer for fast, accurate sales receipts and reports. And
you can quickly add, update and create applications using
TCL,
™ the VeriFone® terminal control language designed
specifically for transaction processing.
TRANZ 330
Versatile enough to handle a variety of applications,
the TRANZ 330 transaction system lets you add
new functions when your business needs change.
TRANZ 330 is so easy to use, you can complete a
typical transaction with just a few keystrokes. It displays
large, legible numbers and letters—providing simple,
easy-to-understand prompts that guide you through each
step of a typical transaction.
TRANZ 330
4800 Great America Parkway
Santa Clara, CA 95054-1200
TEL: 408-496-0444
FAX: 408-919-1405
NET: www.verifone.com
Features
■Accepts all major credit, debit and
private-label cards, providing low-cost
credit card authorization, check
guarantee and data capture for a
variety of retail applications
■Supports electronic benefits transfer
for individual healthcare providers,
pharmacies, hospitals and government
agencies
■Simplifies the creation and updating of
application programs through TCL, a
unique POS terminal control language
■Performs fast application downloads
and file transfers
■Lets you expand by adding a slip, roll
or sprocket printer and a PIN pad
■Supports third-party devices such as
intelligent barcode wands and
handheld scanners
■Prompts you through each step of a
typical transaction with an easy-to-
read display
■Includes all the security and fraud
control features required in bank card
environments
■Is available with custom keypad
overlays specially designed for your
application needs
■CSA approved
Specifications
Hardware
Microprocessor Z80® CPU
Memory 32-Kbytes EPROM and 32 Kbytes battery-backed RAM
Display 16-character, vacuum fluorescent display
including decimal point and comma
Card Reader ABA track 1 or track 2 magnetic stripe card reader
Peripheral Ports RS-232 serial port for a slip, roll or sprocket printer
Communications Port For connecting a PIN pad or a third-party device
such as an intelligent barcode wand or hand held scanner
Communications
Modem Configurations 300/1200 baud modem that supports
both Bell 103 and Bell 212 configurations
Bell 202 leased-line configuration
CCITT V.21/V.22/V.23 configuration
Physical
Height 1.5 in (38.1 mm)
Width 5.6 in (142.2 mm)
Depth 6.0 in (152.4 mm)
Shipping Weight 2.2 lbs (1.0 kg)
Environmental
Operating Temperature 0° to 40° C (32° to 104° F)
Storage Temperature -18° to 70° C ()° to 158° F)
Operating Humidity 20% to 90%, non-condensing
Power
Voltage 120 VAC, 60 Hz
© 1998 VeriFone, Inc. All rights reserved. VeriFone, the VeriFone logo, TRANZ and OMNI are registered trademarks of VeriFone, Inc. TCL is a trademark of the company. All features and specifications are subject to change without notice. 5/98 98-286 Rev A
