Vibram®
Shoe Repair Catalog
QB Soling • 1-800-VIBRAM7 • www.vibram.us
Fire & Police Lifestyle
Field & Stream Industrial
TABLE OF CONTENTS
Working from the bottom up.
2
Description
COMPOSITIONGUMLITE
Since 1965, Quabaug Corporation has been the
exclusive manufacturer of VIBRAM®soles in the
United States under license from VIBRAM S.p.A.
Italy. Both companies have long been recognized
by the footwear industry as leaders in the field
of rubber soling material. The cooperative rela-
tionship has produced outstanding technology,
material and design concepts for unit soles and
heels as well as for sheet soling products.
About VIBRAM®S.p.A.
In 1935, Vitale Bramani led an expedition into the Italian Alps. The
climbers used heavy, hobnailed boots for the approach, but then
switched to thin soled rock climbing boots for the assault. These
climbing boots proved fatal when the expedition was hit by thick fog
and a blizzard. Six climbers died from frostbite and exposure.
It was this tragic experience that drove Bramani to create an
all-purpose climbing sole: lightweight, long-wearing and flexible.
MORFLEX®
The Legend of VIBRAM®Soles
100 Montagna Full Sole 4• • • •
108 Voyageur Unit Sole 4•
109 Logger Unit Sole 4••
127 Athletic Unit Sole Y/L 4•
132 Montagna Block Unit Sole 5• • •
134AR Tech Lug Unit Sole Y/L 5•• •
148 Kletterlift Unit Sole 5••
232 Mini-Lug Unit Sole 5•
251 Jasmine Flexible Unit Sole 5•
268 Men’s Dress Full Sole 5•
269 Westerner Full Sole 6••
427W Oil Resisting Cord Full Sole 6••
430 Oil Resisting Full Sole 6••
700 Tygum Full Sole 6•
1030 Izalco Full Sole 6•
1033 Winkler Trekking Sole 6•
1136 Roccia Block Unit Sole 6••
1276 Sierra Unit Sole 7• ••
1289AR Big Horn Unit Sole 7• •
1375 Bifida Cup Sole 7• •
7124 Vibram Jumbo Ripple Full Sole 7• ••
T610P Duralogical Unit Sole 7•
1705 Men’s Stowe Lug Unit Sole 8•
1712 Women’s Stowe Lug Unit Sole 8•
1716 Oxford Unit Sole 8•
1718 Oil Resisting Robinson Unit Sole 8••
1743W Bologna Unit Sole 9•
1752 Stockbridge Unit Sole 9•
1756 Batavia Unit Sole 9••
1757 Middlebury Unit Sole 9•
1758 Stalker Unit Sole 9• • •
2021 Oil Resisting Unit Sole 10 • •
2060 Sport Unit Sole 10 •
2062 Olympic Unit Sole 10 •
2070 Scooter Unit Sole 11 •
2210 Harvard Unit Sole 11 •
2224 Cambridge Unit Sole 11 •
2345 Line Lite Unit Sole 11 •
Page No.
TPV/PU
Style No. Military
Fire & Police Lifestyle
Description Field & Stream Industrial
Page No.
www.vibram.us 3
TABLE OF CONTENTS
1-800-VIBRAM7
VIBRAM HALF SOLES
CUSHION
VIBRAM HEELS AND TOPLIFTS
VIBRAM SHEETS
VIBRAM
He developed rubber compounds with excellent traction and high abrasion
resistance. He designed a new lug sole and called it Vibram, after his own
name.
Vibram®soles have gone on to conquer Mt. Everest and to become a
legend throughout the world. Yet, the search for better soling products has
never stopped. Vibram soles are now found not only on boots, but on a
whole range of fine casual, service and dress footwear. The legend lives on. Working from the bottom up.
®
1012 Silvato Neoprene Cushion Unit Sole 11 • •
4014 Cristy Unit Sole 11 • •
7673T Toe Guards - Protective Toe Caps 12 • • • •
348 Marzia 2 Women’s Unbuffed Half Sole 12 •
365 Chicago Men’s Smooth Dress Half Sole 12 •
368 Men’s Dress Fine Line Half Sole 12 •
435 Oil Resisting Half Sole 12 • •
705 Tygum Half Sole 13 •
1253 Lug Half Sole 13 •
2336 Women’s Tapered Unbuffed Half Sole 13 •
2337 Richard Unbuffed Half Sole 13 •
2347 Pavia Unbuffed Half Sole 13 •
7673 Pro Tania Protective Half Sole 13 •
100 Montagna Heel 14 • • • •
359P Core Lug Heel 14 •
430 Oil Resisting Washer Heel 14 • •
438 Cowboy Washer Heel 14 • •
458 Men’s Washer Heel 14 •
468 Men’s Core Heel 15 •
700 Oil Resisting Heel 15 •
700C Tygum Elongated Oil Resisting Cowboy Heel 15 • •
1101 Manhattan Softee Died Out Toplift 15 •
2217H Morflex®Newton Died Out Heel 15 •
3359 Lug Heel Toplift 15 •
5330/31 Classic Soft Toplift 15 •
650 Silvano Sheet 16 •
674 Mini-Rib Sheet 16 •
1101 Manhattan Toplift Sheet 16 •
2225 Woodstock Morflex®Sheet 16 •
7166Q Toplift Sheet 16 •
7279 Women’s Dupla Toplifting Sheet 17 •
7510 Grip Rock Climbing Soling Sheet 17 •
7673 Pro Tania Protective Soling Sheet 17 •
8102 Morflex®Pyramid Sheet 17 •
8102 Morflex®Suede Sheet 17 •
8529 Gumlite Sport Utility Sheet 17 •
Repair Tag 18
Key Chain 18
Vibram Bags 18
Toe
Grds.
Style No. Military
COMPOSITION
DATE
04-07
Vibram composition soles are designed for appli-
cation in the work, military, trekking/hiking and
outdoor footwear categories. The compounds
provide high abrasion and long wearing charac-
teristics. Some compounds are oil resisting.
VIBRAM®Composition
STYLES:
04-07
VIBRAM®Montagna®Full Sole
The VIBRAM lug sole.
Sizes: 8, 9, 10, 11, 12, 13, 14 (Black)
10, 11, 12 (Honey)
Dimensions: 22 iron
Color: Black, Honey
VIBRAM®Logger Sole
Rugged outdoor lug sole that
incorporates a logger heel.
Sizes: 8, 10, 12,
Dimensions: 24 iron forepart
84 iron heel
Color: Black
Working from the bottom up.
4
Style No: 100
Style No: 109
#134AR #148 #232 #251 #268
#269
VIBRAM®Voyageur®Unit Sole
Outdoor casual lug sole.
Sizes: 8, 10, 12, 14
Dimensions: 15 iron forepart
21 iron heel
Color: Black
Style No: 108
VIBRAM®Athletic Sole
Long-wearing sport and walking sole
for footwear with an athletic flair.
Sizes: 8, 10, 12, 14
Dimensions: 71⁄2iron forepart
91⁄2iron heel
Color: Black
Style No: 127
#427W #430 #700 #1030
#1033 #1136 #1276 #1289AR #1375
#100 #108 #109 #127 #132
#7124
VIBRAM®Kletterlift Unit Sole
Classic lug sole. Requires heel wedge.
Sizes: 8, 10, 12, 14
Dimensions: 15 iron
Color: Black
Style No: 132
Style No: 148
www.vibram.us 5
COMPOSITION
1-800-VIBRAM7
Fire & Police Lifestyle
Field & Stream Industrial
VIBRAM®Montagna®
Block Unit Sole
The sole that conquered Mt. Everest
remains the quality soling choice for
rugged outdoor wear.
Sizes: 8, 9, 10, 11, 12, 14
Dimensions: 19 iron forepart
51 iron heel
Color: Black
VIBRAM®Men’s Dress Full Sole
Sizes: 10, 12 & 14
Dimensions: 12 iron
Color: Neutral
Style No: 268
VIBRAM®Jasmine®Unit Sole
Ideal for casual footwear.
Sizes: 8, 10, 12
Dimensions: 14 iron forepart
36 iron heel
Color: Caramel
Style No: 251
VIBRAM®Composition
Mini-Lug Unit Sole
Designed for rugged and
leisure outdoor casuals.
Sizes: 8, 10, 12, 14 (Black)
10, 12 (Nicotine)
Dimensions: 14 iron forepart
38 iron heel
Color: Black, Nicotine
Style No: 232
Style No:134AR
VIBRAM®Technical Lug Sole
Award winning sole and a benchmark of
quality for performance sport boots.
Sizes: 8, 10, 12, 14
Dimensions: 24 iron forepart
54 iron heel
Color: Black
PRODUCT APPLICATION LEGEND
Military
COMPOSITION
Working from the bottom up.
6
VIBRAM®Winkler
Unit Sole
High abrasion trekking sole.
Sizes: 8 1/2, 10, 11 1/2, 13
Dimensions: 17 iron forepart
27 iron heel
Color: Black
Style No: 1033
VIBRAM®Tygum®Composition
Full Sole
Features a traditional Chevron pattern.
Use with style #700 heel.
Sizes: 10, 12, 14
Dimensions: 14 iron
Color: Neutral, Black
Style No:
700
VIBRAM®Oil Resisting
Cord Full Sole
Extra wide pattern. Includes cord for
extended wear.
Sizes: 91⁄2,11
1⁄2,14
Dimensions: 16 iron
Color: Black
Style No: 427W
VIBRAM®Oil Resisting
Full Sole
Features a refined lug medallion ideal
for work and industrial footwear.
Use with style 430 heel.
Sizes: 8, 10, 12, 14
Dimensions: 14 iron
Color: Black
Style No: 430
VIBRAM®Westerner®
Full Sole
Mini rib pattern.
Sizes: 10, 12, 14
Dimensions: 12 iron forepart
Color: Black
Style No: 269
VIBRAM®Izalco Sole
Is designed for use on work
and casual footwear
Sizes: 401, 423, 445
Dimensions: 5.5 mm
Color: Black
Style No: 1030
www.vibram.us 7
1-800-VIBRAM7
Fire & Police Lifestyle
Field & Stream Industrial
VIBRAM®Bifida Cup Sole
Provides excellent traction on wet/dry
surfaces and various terrain. It was
created for use in hiking and outdoor
footwear applications.
Sizes: 37, 38, 39, 40, 41, 42, 43, 44, 45,
46, 471⁄2,48
1⁄2
Color: Black
Style No: 1375
COMPOSITION / TPV/PU
VIBRAM®Big Horn Unit Sole
Is ideal for use on a variety of hunting
and outdoor footwear.
Sizes: 8, 10, 12
Dimensions: 24 iron forepart
54 iron heel
Color: Black
Style No:1289AR
VIBRAM®Sierra Unit Sole
For use on casual outdoor, casual
and military footwear.
Sizes: 8, 10, 12, 14
Dimensions: 18 iron
Color: Black, Mojave, Tan
Style No: 1276
VIBRAM®Jumbo Ripple Full Sole
Provides comfort abrasion and long
wearing characteristics.
Sizes: 8, 9, 10, 11, 12, 13, 14
Dimensions: 27 iron
Color: Black, Mojave, Tan
Style No: 7124
PRODUCT APPLICATION LEGEND
VIBRAM®Duralogical
Unit Sole
Ideal for work boots, the T610P has
excellent abrasion and slip resisting prop-
erties. It also has excellent resistance to
solvents. It is long wearing, durable and
lightweight.
Note: Needs a urethene adhesive. Outsole &
midsole combined
Sizes: 8, 9, 10, 11, 12, 13, 14
Dimensions: 23 iron forepart
48 iron heel
Color: Black, Brown
Style No:
T610P
VIBRAM®TPV/PU
NEW
Military
VIBRAM®Roccia Block
Unit Sole
Excellent alternative sole replacement for
outdoor or casual footwear.
Sizes: 81⁄2, 10, 111⁄2,13
Dimensions: 15 iron forepart
45 iron heel
Color: Black
Style No: 1136
VIBRAM®Gumlite®Unit Soles have the wear
characteristics of rubber, yet are half the
weight. Maintains its slip resisting characteristics
in cold temperatures and on wet surfaces.
VIBRAM®Gumlite
#1705 #1712 #1716 #1718 #1743W
STYLES:
08-09
#1752 #1756 #1757 #1758
VIBRAM®Gumlite®Oxford
Unit Sole
Sizes: 8, 10, 12, 14
Dimensions: 12 iron forepart
36 iron heel
Color: Black, Brown
Working from the bottom up.
8
Style No: 1716
GUMLITE
VIBRAM®Stowe Men’s
Gumlite®Lug Unit Sole
Classic mini lug designed for men’s
casual and outdoor footwear.
Sizes: 8, 10, 12, 14
Dimensions: 16 iron forepart
38 iron heel
Color: Black, Brown
Style No: 1705
Style No: 1712
VIBRAM®Stowe Women’s
Gumlite®Lug Unit Sole
With classic mini lug design, ideal for
women's outdoor or casual footwear.
Sizes: 8, 10
Dimensions: 14 iron forepart
32 iron heel
Color: Black
VIBRAM®Oil Resisting
Gumlite®Robinson Sole
Designed for work and service
footwear.
Sizes: 9, 11, 13
Dimensions: 21 iron forepart
57 iron heel
Color: Black
Style No: 1718
DATE
08-09
VIBRAM®Bologna Men’s
Gumlite®Unit Sole
Sizes: 8, 10, 12, 13 (Black)
10, 12 (Brown)
Dimensions: 15 iron forepart
49 iron heel
Color: Black, Brown
Style No:1743W
VIBRAM® Middlebury
Gumlite®Sole
Designed with large lugs for comfort
and durability. Ideal for casual
footwear.
Sizes: 8, 10, 12, 14
Dimensions: 22 iron forepart
53 iron heel
Color: Black
Style No: 1757
www.vibram.us 9
GUMLITE
1-800-VIBRAM7
Fire & Police Lifestyle Military
Field & Stream Industrial
VIBRAM®Stalker
Gumlite®Unit Sole
It is designed for
stability, comfort and durability.
It is ideal for use on work, outdoor
and hunting footwear.
Sizes: 9, 11, 13, 15
Dimensions: 21 iron forepart
44 iron heel
Color: Black
Style No:
1756
Style No: 1758
Style No:
1752
VIBRAM®Stockbridge
Gumlite®Sole
Ideal replacement sole for dress
and casual footwear.
Sizes: 8, 10, 12, 14 (Black)
10, 12 (Brown)
Dimensions: 19 iron forepart
45 iron heel
Color: Black, Brown
VIBRAM®Gumlite®
Batavia Sole
Is designed for use on casual
and orthopedic footwear.
Sizes: 8, 10, 12, 14
Dimensions: 27 iron forepart
52 iron heel
Color: Black
PRODUCT APPLICATION LEGEND
NEW
VIBRAM®Sport Unit Sole
Classic casual walking sole.
Sizes: 8, 10, 12, 14 (Black, Brown)
8, 10, 12 (Sahara)
Dimensions: 27 iron forepart
52 iron heel
Color: Black, Brown, Sahara
MORFLEX®
DATE
10-11
VIBRAM®Morflex®soles are made with an
advanced micro-cellular soling compound. Morflex
is one-third the weight of composition rubber.
It is extremely resilient with great “bounce”
combining foot support with comfort.
#2021 #2060 #2062 #2070 #2210
STYLES:
10-11
VIBRAM®Scooter Unit Sole
Casual sport sole requiring wedge.
Sizes: 8, 10, 12, 13 (Black, Sahara)
10, 12, 13 (Brown)
Dimensions: 12 iron
Color: Black, Brown, Sahara
VIBRAM®Oil Resisting
Unit Sole
Lightweight work sole.
Sizes: 8, 10, 12, 14
Dimensions: 33 iron forepart
57 iron heel
Color: Black, Brown, Sand
VIBRAM®Olympic Unit Sole
Ideal for rugged look comfort casuals.
Sizes: 8, 10, 12, 14
Dimensions: 22 iron forepart
43 iron heel
Color: Black, Brown
Working from the bottom up.
10
Style No: 2060
Style No: 2021
Style No: 2062
Style No: 2070
#2224 #2345 #1012 #4014
VIBRAM®Morflex®Unit Soles
www.vibram.us 11
MORFLEX®/ CUSHION
VIBRAM®Cristy
Cushion Unit Sole
Suitable for work, military and
service footwear.
Sizes: 8, 10, 12, 14
Dimensions: 21 iron forepart
45 iron heel
Color: Black, Natural
VIBRAM®Silvato®Neoprene®
Cushion Unit Sole
Oil resisting outsole for application
on work and service footwear.
Sizes: 8, 10, 12, 14
Dimensions: 21 iron forepart
51 iron heel
Color: Black
Style No: 4014
Style No: 1012
1-800-VIBRAM7
Fire & Police Lifestyle
Field & Stream Industrial
PRODUCT APPLICATION LEGEND
VIBRAM®Cambridge Unit Sole
Lightweight casual sole designed to provide
comfort, traction, and low impact on
moderate terrain.
Sizes: 8, 10, 12, 14 (Black)
10, 12 (Brown)
Dimensions: 16 iron forepart
40 iron heel
Color: Black, Brown
Style No: 2224
Style No: 2345
VIBRAM®Line-Lite Unit Sole
Lightweight sole for dress and casual
applications.
Sizes: 8, 10, 12, 14 (Black)
10, 12 (Brown)
Dimensions: 14 iron forepart
40 iron heel
Color: Black, Brown
VIBRAM®Cushion Unit Soles
VIBRAM®Harvard Unit Sole
Fine lines make this sole ideal for
dress footwear.
Sizes: 8, 10, 12, 14 (Black)
10, 12 (Brown)
Dimensions: 14 iron
Color: Black, Brown
Style No: 2210
Military
VIBRAM®Chicago Buffed
Dress Smooth Half Sole
Sizes: 12
Dimensions: 101⁄2iron
Color: Neutral
Sizes: 12
Dimensions: 12 iron
Color: Neutral
VIBRAM®Marzia Women’s
Unbuffed Half Sole
Sizes: 40/42 (large)
Dimensions: 4 iron
Color: Neutral
VIBRAM®Men’s Dress Fine
Line Half Sole
Sizes: 10, 12
Dimensions: 101⁄2iron
Color: Neutral
Sizes: 10, 12, 14
Dimensions: 12 iron
Color: Neutral
Style No:
365
Style No: 348
Style No: 368
DATE
12-13
Vibram half soles have slip resisting character-
istics. They provide comfort and footwear
protection.
VIBRAM®Toe Guards
#7673T #348 #365 #368
#705
STYLES:
12-13
Working from the bottom up.
12
#2336
#435
#2337
#7673
#2347
VIBRAM®Oil Resisting Half Sole
Use with 430 heel.
Sizes: 12, 14
Dimensions: 14 iron
Color: Neutral
Style No:
435
TOE GUARDS / HALF SOLES
VIBRAM®Half Soles
#1253
VIBRAM®Toe Guards
Protective Toe Caps
Sizes: Medium, Large, Extra Large
Color: Black, Neutral
Style No: 7673T
VIBRAM®Half Soles
VIBRAM®HALF SOLES
1-800-VIBRAM7
Fire & Police Lifestyle Military
Field & Stream Industrial
VIBRAM® Women’s Tapered
Unbuffed Half Sole
Sizes: 2, 3
Dimensions: 3 iron center with
tapered edges
Color: Neutral
VIBRAM®Lug Half Sole
Classic mini lug forepart tap ideal for
leather to rubber conversions or the
repair of men’s and women’s mini lugs.
Use with #3359 Lug Heel Lift.
Sizes: 43/44, 47/48
Dimensions: 10 iron
Color: Black
VIBRAM®Pavia Unbuffed
Half Sole
For casual and rugged footwear.
Size: 3
Dimensions: 9 iron
Color: Neutral
VIBRAM®Pro Tania
Protective Half Sole
Long-wearing and durable.
Sizes: 47/50 Men’s
40/42 Women’s
Dimensions: 31⁄2iron
Colors: Black, Neutral
VIBRAM®Tygum®Oil Resisting
Composition Half Sole
Use with 700 heel.
Sizes: 12, 14
Dimensions: 14 iron
Color: Black, Neutral
VIBRAM®Men’s Richard
Unbuffed Half Sole
Sizes: 47/50 (large)
Dimensions: 4 iron
Color: Neutral
Style No: 7673
Style No: 705
Style No: 2336
Style No: 2337
Style No: 2347
Style No: 1253
PRODUCT APPLICATION LEGEND
www.vibram.us 13
VIBRAM®HEELS & TOPLIFTS
DATE
14-15
Vibram offers a selection of heels and toplifts for
most applications. These are offered in com-
pounds that provide comfort and cushion.
VIBRAM®Heels and Toplifts
#100 #359P #430 #438 #458
STYLES:
14-15
VIBRAM®1/2" Lug Heel Lift
Ideal for casual and rugged footwear
Sizes: 26, 32, 36
Dimensions: 4⁄8"
Color: Black
Working from the bottom up.
14
Style No: 359P
#468 #700 #700C #1101 #2217H
#3359 #5330
VIBRAM®Oil Resisting
Washer Heel
Use with 430 full sole and 435
half sole.
Sizes: 10, 12, 14
Dimensions: 6⁄8"
Color: Black
Style No: 430
VIBRAM®Montagna®
Lug Heel
Use with 100 full sole.
Sizes: 9, 10, 11, 12, 13, 14, 15, 16 (Black)
11, 12, 13, 14, 15 (Honey)
Dimensions: 7⁄8"
Color: Black, Honey
Style No: 100
#5331
VIBRAM®Cowboy
(Washer) Heel
Features a classic western design.
Sizes: 3/5, 7, 9, 11, 13 (Neutral)
7, 9, 11 (Amber)
Dimensions: 7⁄16"
Color: Neutral, Amber
Style No: 438
VIBRAM® 4/8" Men’s Washer
Comfort Cushion Half Heel
Sizes: 9/10, 10/11, 11/11, 11/12, 12/13,
13/14
Dimensions: 4⁄8"
Color: Neutral
VIBRAM®6/8" Men’s
Washer Comfort Cushion
Full Heel
Sizes: 11/12, 13/14, 12/13
Dimensions: 6⁄8"
Color: Neutral
Style No: 458
www.vibram.us 15
VIBRAM®HEELS & TOPLIFTS
VIBRAM®Newton
Morflex®Heel
Replacement heels for Morflex®
dress soles.
Sizes: 15/16
Dimensions: 18, 24 iron
Color: Black, Brown
VIBRAM®Lug Heel Lift
Use with #1253 VIBRAM®Lug Half
Sole for a rugged profile.
Sizes: 24, 28, 34, 40
Dimensions: 2⁄8"
Color: Black
VIBRAM®Men’s Manhattan
Softees Died Out Soft
Toplift
Sizes: 13/14
Dimensions: 12 iron
Color: Neutral
VIBRAM®Men’s Top of the
Line Soft Toplift
Sizes: 13/14, 15/16
Dimensions: 12 iron (5330)
15 iron (5331)
Color: Neutral
Style No: 3359
Style No: 1101
Style No: 2217H
Style No: 5330, 5331
1-800-VIBRAM7
Fire & Police Lifestyle Military
Field & Stream Industrial
VIBRAM®Tygum®Elongated
Oil Resisting Cowboy Heel
Sizes: 12, 13
Dimensions: 6⁄8"
Color: Black, Amber
Style No: 700C
VIBRAM®Oil Resisting Heel
Use with style #700 full sole and 705
half sole.
Sizes: 10, 11, 12
Dimensions: 6⁄8"
Color: Black, Neutral
Style No: 700
VIBRAM®4/8" Men’s Core
Comfort Cushion Half Heel
Sizes: 9/10, 10/11, 11/11, 11/12, 12/13,
13/14, 14/15, 15/16, 16/17
Dimensions: 4⁄8"
Color: Neutral
VIBRAM®5/8" Men’s Core Comfort Cushion
Loafer Heel
Sizes: 9/10, 10/11, 11/12, 12/13, 13/14, 14/15, 15/16, 16/17
Dimensions: 5⁄8"
Color: Neutral
VIBRAM®6/8" Men’s Core Comfort Cushion
Full Heel
Sizes: 9/10, 10/11, 11/12, 12/13, 13/14, 14/15, 15/16, 16/17
Dimensions: 6⁄8"
Color: Neutral
Style No: 468
PRODUCT APPLICATION LEGEND
SHEETS
DATE
16-17
Vibram provides sheets for most applications.
These include orthopedic, build up, work, outdoor,
toplifting and protective soling, All sheets are
molded with premium compounds for the specif-
ic application.
VIBRAM®Sheets
#650 #674 #1101 #2225 #7166Q
STYLES:
16-17
VIBRAM®Woodstock
Morflex Soling Sheet
For sandal, clogs and casual
footwear sole replacement.
Sizes: 22" x 27"
Dimensions: 18 and 21 iron
Color: Black
Sizes: 22" x 27"
Dimensions: 21 iron
Color: Brown
VIBRAM®Silvano
Outdoor/Work Sheet
Long-wearing, provides excellent
traction.
Sizes: 20" x 25"
Dimensions: 10 iron
Color: Black
Working from the bottom up.
16
Style No: 650
Style No: 2225
#7279 #7510 #7673 #8102 #8102
Style No: 7166Q
VIBRAM®Women’s Firm
Toplift Sheet
Sizes: 91⁄2" x 30"
Dimensions: 101⁄2iron
Color: Neutral, Oak
VIBRAM®Men’s Soft
Toplift Sheet
Sizes: 141⁄2" x 30"
Dimensions: 12 and 15 iron
Color: Neutral
VIBRAM®Mini-Rib
Sheet is long-wearing composition
sheet ideal for work and casual
footwear.
Sizes: 22" x 29"
Dimensions: 7 and 10 iron
Color: Black
Style No: 674
Style No: 1101
VIBRAM®Women’s
Manhattan Firm
Toplift Sheet
Sizes: 18" x 17"
Dimensions: 101⁄2iron
Color: Neutral
#8529
www.vibram.us 17
SHEETS
VIBRAM®Sport Utility Oil
Resisting Gumlite®Sheet
This versatile multi-directional sheet is
now manufactured in Oil Resisting
Gumlite®. Excellent replacement for
casual, golf or orthopedic footwear.
Sizes: 23" x 28"
Dimensions: 12 and 15 iron
Color: Black
VIBRAM®Morflex®
Pyramid Sheet
Durable, oil resisting, lightweight
Morflex®sheets for outsole replacement.
Sizes: 18" x 36"
Dimensions: 12, 15, 18, 21, 24, 30 iron
Color: Black, Brown
Dimensions: 12, 15, 18, 24, iron
Color: Coffee
Dimensions: 12, 18, 24 iron
Color: Taupe, White
Dimensions: 12, 24 iron
Color: Red, Grey
VIBRAM®Pro Tania
Protective Soling Sheet
Sizes: 36" x 36", 18" x 36"
Dimensions: 31⁄2iron
Color: Black, Neutral
VIBRAM®Morflex®
Suede Sheet
Durable, oil resisting, lightweight
Morflex®sheets for
orthopedic build up.
Sizes: 18" x 36"
Dimensions: 12 and 24 iron
Color: Black, White
Dimensions: 24 iron
Color: Tan, Mojave
Style No: 8102
Style No: 7673
Style No: 8529
Style No: 8102
1-800-VIBRAM7
Fire & Police Lifestyle
Field & Stream Industrial
VIBRAM®Women’s Dupla
Toplift Sheet
Long-wearing sheet with pebble finish.
Two-ply feature provides flexibility and
cushioning.
Sizes: 18" x 17"
Dimensions: 6 mm
Color: Black, Neutral
Style No: 7279
VIBRAM®Grip Rock
Climbing Soling Sheet
Grip compound provides optimum
traction for indoor or outdoor rock
climbing shoes.
Sizes: 25" x 37"
Dimensions: 1.8, 3.5, 5.0 mm
Color: Black
Style No: 7510
PRODUCT APPLICATION LEGEND
Military
Working from the bottom up.
18
BUY SMART / CHARTS
Packaging: 5,000 tags per carton
Numbered 0001 - 5000
and Numbered
5001 - 10,000
Remarks: Blank space provided on tag
for shop name, address and
telephone number. Tag num-
bered on top and bottom.
Made in U.S.A.
Tag Size: 27⁄8" x 55⁄8"
Material: Yellow Card Stock
Ink: Black ink printed on 2 sides
Perforation: One easy tear perforation
the width of the tag
Reinforced Hole: 3⁄16"
Packaging: 50
per carton
Color: Black,
yellow label
12" x 7" x 23"
Yellow bags with
the VIBRAM®
logo on both
sides.
1,000 bags per
box.
Vibram®Repair Tag
Working from the bottom up.
®
Measurement Conversion Chart
1 1.8 .039 1⁄32
2 3.8 .079 1⁄8
3 5.6 .118
4 7.5 .157 5⁄32
5 8.9 .197 3⁄16
6 11.3 .236 1⁄4
7 13.3 .276
8 15.1 .315 5⁄16
9 17.0 .354
10 18.9 .394
11 20.8 .433 7⁄16
12 22.7 .472
13 24.6 .512 1⁄2
14 26.5 .551 9⁄16
15 28.3 .590
16 30.2 .630 5⁄8
17 32.1 .669
18 34.0 .709
19 35.9 .748 3⁄4
20 37.8 .787
21 39.7 .827
22 41.6 .866 7⁄8
23 43.4 .905
24 45.4 .945
25 47.2 .984 1"
FRACTIONS
INCHES
IRONMM Vibram®cushion soles are sized according to die marks in the rear of the heel.
This chart is a reference tool to help you quickly identify sole sizes.
MEN’S WOMEN’S
ALL STYLES-EXCEPT 2062 STYLE 1712
Approx. Approx.
Code Size Size in Inches Code Size Size in Inches
(Toe to Heel) (Toe to Heel)
IIII 8 12" II 6 105⁄16"
II 10 123⁄4" IIII 8 11"
IIII 12 133⁄8" IIIII 9 113⁄8"
I I 13 133⁄4"
I II 14 14"
STYLE 2062
IIII 8 113⁄4"
II 10 121⁄2"
IIII 12 131⁄4"
IIIII 14 133⁄4"
Cushion Sole Die Cutting Code Chart
Vibram®Key Chain / Shoe Bag
www.vibram.us 19
1-800-VIBRAM7
INDEX
Vibram®Repair Catalog Index
100 Montagna Full Sole 4
100 Montagna Heel 14
108 Voyageur Unit Sole 4
109 Logger Unit Sole 4
127 Athletic Unit Sole Y/L 4
132 Montagna Block Unit Sole 5
134AR Tech Lug Unit Sole Y/L 5
148 Kletterlift Unit Sole 5
232 Mini-Lug Unit Sole 5
251 Jasmine Flexible Unit Sole 5
268 Men’s Dress Full Sole 5
269 Westerner Full Sole 6
348 Marzia 2 Women’s Unbuffed Half Sole 12
359P Core Lug Heel 14
365 Chicago Men’s Smooth Dress Half Sole 12
368 Men’s Dress Fine Line Half Sole 12
427W Oil Resisting Cord Full Sole 6
430 Oil Resisting Full Sole 6
430 Oil Resisting Washer Heel 14
435 Oil Resisting Half Sole 12
438 Cowboy Washer Heel 14
458 Men’s Washer Heel 14
468 Men’s Core Heel 15
650 Silvano Sheet 16
674 Mini-Rib Sheet 16
700 Tygum Full Sole 6
700 Oil Resisting Heel 15
700C Tygum Elongated Oil Resisting Cowboy Heel 15
705 Tygum Half Sole 13
1012 Silvato Neoprene Cushion Unit Sole 11
1030 Izalco Full Sole 6
1033 Winkler Trekking Sole 6
1101 Manhattan Softee Died Out Soft Toplift 15
1101 Manhattan Toplift Sheet 16
1136 Roccia Block Unit Sole 6
1253 Lug Half Sole 13
1276 Sierra Unit Sole 7
1289AR Big Horn Unit Sole 7
1375 Bifida Cup Sole 7
1705 Men’s Stowe Lug Unit Sole 8
1712 Women’s Stowe Lug Unit Sole 8
1716 Oxford Unit Sole 8
1718 Oil Resisting Gumlite Robinson Unit Sole 8
1743W Bologna Unit Sole 9
1752 Stockbridge Unit Sole 9
1756 Batavia Unit Sole 9
1757 Middlebury Unit Sole 9
1758 Stalker Gumlite Unit Sole 9
2021 Oil Resisting Unit Sole 10
2060 Sport Unit Sole 10
2062 Olympic Unit Sole 10
2070 Scooter Unit Sole 11
2210 Harvard Unit Sole 11
2217H Morflex®Newton Died Out Heel 15
2224 Cambridge Unit Sole 11
2225 Woodstock Morflex®Sheet 16
2336 Women’s Tapered Unbuffed Half Sole 13
2337 Richard Unbuffed Half Sole 13
2345 Line Lite Unit Sole 11
2347 Pavia Unbuffed Half Sole 13
3359 Lug Heel Toplift 15
4014 Cristy Unit Sole 11
5330/31 Classic Soft Toplift 15
7124 Vibram®Jumbo Ripple Full Sole 7
7166Q Toplift Sheet 16
7279 Women’s Dupla Toplifting Sheet 17
7510 Grip Rock Climbing Soling Sheet 17
7673 Pro Tania Protective Half Sole 13
7673 Pro Tania Protective Soling Sheet 17
7673T Toe Guards - Protective Toe Caps 12
8102 Morflex®Pyramid Sheet 17
8102 Morflex®Suede Sheet 17
8529 Gumlite®Sport Utility Sheet 17
T610P Duralogical Unit Sole 7
Repair Tag 18
Key Chain 18
Shoe Bag 18
Working from the bottom up.
®
Vibram®provides you with innovative products
that deliver consistent quality.
A well-designed sole can make or break the shoe. For example, our hunting/fishing lug designs are specifically
engineered for better braking, gripping, and pushing off purposes. Work/utility boot soles, designed with beveled heels
and ladder grips, allow for efficient pole and ladder climbing. And, the fine line design of our dress/casual soles
promotes slip resistance.
Vibram®has developed special compounds for different applications of footwear. For hunting/fishing footwear we
offer a hard compound that protects the foot from unpredictable and rocky terrain. For work/utility boots, we offer
oil and flame resisting compounds. For dress/casual footwear, we offer lighter weight, softer compounds that provide
the right balance of comfort and performance.
Whether your customer is an executive, firefighter or construction worker,
Vibram®provides you with the performance-proven sole to fit their lifestyle.
QB SOLING
18 School Street, North Brookfield, MA 01535-1920
Phone: 1-800-VIBRAM7 • Fax: 508-867-4600
www.vibram.us
© 2004 Quabaug Corporation, North Brookfield, Massachusetts 01535.
Manufacturers of VIBRAM®Soles under exclusive license in the United States.
VIBRAM®and the yellow octagonal label are the registered trademarks of VIBRAM S.p.A. of Italy.
