Application Report
Draft v0.3 – Oct 2017
1
Memory Map of Vision SDK
Shiju Sivasankaran ADAS Software, Processor BU
ABSTRACT
TDA2x and TDA3x series of automotive processor are designed to be used in automotive safety
systems. TI Vision SDK is a multi-processor multi-channel software development platform, which
enables the easy integration of new vision applications using different heterogeneous CPUs of TI
ADAS SoCs. VISION SDK allows different usecases for different platforms and hence a generic
memory map might not be sufficient for all users. This document gives insight on different
sections of the memory map that a user can change for their usecases. The document discusses
about the Vision SDK (VSDK) memory map implementation on TDA2xx, TDA2Ex, TDA2Px and
TDA3xx
Contents
1. Introduction .................................................................................................................................... 3
2. Memory Sections of VISION SDK Memory Map ................................................................................... 3
3. VSDK Memory Map Table ................................................................................................................. 4
4. Software and Hardware Constraints to Consider For Deciding Memory Map ......................................... 5
4.1 Hardware Constraints ................................................................................................................ 5
4.2 Software Constraints ................................................................................................................. 5
5. Memory Allocation ........................................................................................................................... 5
5.1 External Buffer Memory Allocation ............................................................................................. 6
5.2 Internal Buffer Memory Allocation .............................................................................................. 7
5.3 Static Memory Sections Allocation .............................................................................................. 8
6. Memory Map of the Application ........................................................................................................ 8
6.1 Adding a new Section to Memory map ........................................................................................ 9
6.2 Changing size of a Section in the Memory map ............................................................................. 9
6.3 How To - Add a new Memory map ............................................................................................ 10
6.4 How To – Modify Linux/Bios VSDK Memory Map ........................................................................ 10
6.4.1 Cache and MMU configurations ................................................................................................ 11
6.4.2 Modify default Memory maps of VSDK ...................................................................................... 13
6.5 How To – Modify 512MB Bios Memory map to 1GB Bios Memory map ......................................... 20
6.6 How To - Modify 1GB Linux Memory map to 512MB Linux Memory map ....................................... 25
6.6.1 Sample patch for TDA2xx VSDK files modification ....................................................................... 25
6.6.2 Sample patch for TDA2xx Linux Kernel modification .................................................................... 32
7. Revision History ............................................................................................................................. 37
Draft v0.2
2 Memory Map of Vision SDK
Figures
No table of figures entries found.
Tables
No table of figures entries found.
Draft v0.2
Memory Map of Vision SDK 3
1. Introduction
It is expected that the user has gone through the below documentations to understand the hardware and software
architecture/partitioning.
TDAxx SoC architecture (TRM)
Vision SDK (Links & chain) Framework UserGuides
o VisionSDK_SW_Architecture_Details.pdf
o VisionSDK_SW_Architecture_Overview.pdf
VSDK Developer guides
o VisionSDK_DevelopmentGuide.pdf
o VisionSDK_Linux_DevelopmentGuide.pdf
2. Memory Sections of VISION SDK Memory Map
VISION SDK has multiple memory map configurations supported based on the usage scenarios and available total
memory on various platforms. The total system memory is divided into various sub-sections/processors. The broad
classification of the sections is listed below:
Shared regions: SRs are different memory partitions that are shared across processors
SR0: Shared Region 0. This shared region is used to allocate memory for data structures needed for inter
processor communication. This shared region is not cached on any of the processor cores.
SR1_FRAME_BUFFER_MEM: This memory region is used for allocating data buffers for capturing video data,
scaling, Alg processing & displaying video frames. Accessible & cached from all cores.
SR2_MEM: Used only with VSDK Linux reserving memory for CMEM allocations (contiguous memory for Linux)
SYSTEM_IPC_SHM_MEM: Non-Cached Memory section for keeping IPC link data structures
Log Mem:
REMOTE_LOG_MEM: Non-Cached Memory section reserved and accessible from all processor cores to dump
the debug/profile print messages. Each processor core uses VPS_printf() to dump the status/debug messages
on this memory region. Remote Debug Client running on master cores (IPU1-0 for Bios and A15 in case of
Linux) reads this memory region and prints the content on the (UART) console.
LINK_STATS_MEM: Non Cached Memory section reserved and accessible from all processor cores to dump
the Link statistics
TRACE_BUF: Remote proc logs, non-Cached, used only with VSDK Linux
DDR Code/data:
CODE_MEM: Partition for code section of each core’s executable binary
DATA_MEM: Partition for data section of each core’s executable binary
Internal memory:
OCMC_RAM: Internal Memory section accessible from all processor cores
L2_SRAM: DSP L2 Internal Memory section, only accessible from DSP core
Linux mem:
Memory partitions given to Linux kernel memory manager
Others:
HDVPSS_DESC_MEM: Memory section used by BSP/STW. It is used by these drivers for its internal descriptor
data structures.
Draft v0.2
4 Memory Map of Vision SDK
3. VSDK Memory Map Table
Refer the .xs file under /vision_sdk/<apps>/build/<SoC>/ for the complete memory map configuration,
For example, /vision_sdk/apps/build/tda2xx/mem_segment_definition_bios.xs defines the memory map for TDA2xx
BIOS only with 512MB DDR.
Also refer the generated map files under
/vision_sdk/binaries/<apps>/<tdaxx_evm_bios_all>/vision_sdk/bin/<tdaxx-evm>/
For example, vision_sdk_ipu1_0_release.xem4.map,
Memory sections are arranged as below
Name Origin Length Used Unused Attr
---------------------- -------- --------- -------- -------- ----
L2_ROM 00000000 00004000 000005ec 00003a14 RWIX
L2_RAM 20000000 00010000 00000000 00010000 RWIX
OCMC_RAM1 40300000 00080000 00080000 00000000 RWIX
OCMC_RAM2 40400000 00100000 00000000 00100000 RWIX
OCMC_RAM3 40500000 00100000 00000000 00100000 RWIX
DSP1_L2_SRAM 40800000 00048000 00000000 00048000 RWIX
DSP2_L2_SRAM 41000000 00048000 00000000 00048000 RWIX
NDK_MEM 85800000 00200000 00000000 00200000 RWIX
SR1_FRAME_BUFFER_MEM 85a00000 0fa00000 0fa00000 00000000 RWIX
DSP1_CODE_MEM 99000000 00200000 00000000 00200000 RWIX
DSP1_DATA_MEM 99200000 01800000 00000000 01800000 RWIX
IPU1_1_CODE_MEM 9d000000 00200000 00000000 00200000 RWIX
IPU1_1_DATA_MEM 9d200000 00200000 00000000 00200000 RWIX
IPU1_1_BSS_MEM 9d400000 00200000 00000000 00200000 RWIX
IPU1_0_CODE_MEM 9d600000 00600000 004fa45d 00105ba3 RWIX
IPU1_0_DATA_MEM 9dc00000 00400000 00000000 00400000 RWIX
IPU1_0_BSS_MEM 9e000000 00d00000 00bf5cdc 0010a324 RWIX
DSP2_CODE_MEM 9f000000 00200000 00000000 00200000 RWIX
DSP2_DATA_MEM 9f200000 00a00000 00000000 00a00000 RWIX
SR0 a0100000 00100000 00100000 00000000 RWIX
REMOTE_LOG_MEM a0200000 00040000 00027890 00018770 RWIX
LINK_STATS_MEM a0240000 00080000 00020d9c 0005f264 RWIX
SYSTEM_IPC_SHM_MEM a02c0000 00040000 00035a60 0000a5a0 RWIX
HDVPSS_DESC_MEM a0300000 00100000 000b07c0 0004f840 RWIX
TRACE_BUF a0400000 00060000 00008000 00058000 RWIX
EXC_DATA a0460000 00010000 00000000 00010000 RWIX
PM_DATA a0470000 00080000 00000000 00080000 RWIX
EVE1_VECS_MEM a2000000 00080000 00000000 00080000 RWIX
EVE1_CODE_MEM a2080000 00200000 00000000 00200000 RWIX
EVE1_DATA_MEM a2280000 00d80000 00000000 00d80000 RWIX
EVE2_VECS_MEM a3000000 00080000 00000000 00080000 RWIX
EVE2_CODE_MEM a3080000 00200000 00000000 00200000 RWIX
EVE2_DATA_MEM a3280000 00d80000 00000000 00d80000 RWIX
EVE3_VECS_MEM a4000000 00080000 00000000 00080000 RWIX
EVE3_CODE_MEM a4080000 00200000 00000000 00200000 RWIX
EVE3_DATA_MEM a4280000 00d80000 00000000 00d80000 RWIX
EVE4_VECS_MEM a5000000 00080000 00000000 00080000 RWIX
EVE4_CODE_MEM a5080000 00200000 00000000 00200000 RWIX
EVE4_DATA_MEM a5280000 00d80000 00000000 00d80000 RWIX
Draft v0.2
Memory Map of Vision SDK 5
Refer /vision_sdk/links_fw/include/link_api/systemLink_common_if.h for the available Memory Heaps,
Here is a brief list; detailed description is in systemLink_common_if.h file
SYSTEM_HEAPID_DDR_NON_CACHED_SR0: Heap ID of heap in DDR, This is non-cached memory
SYSTEM_HEAPID_DDR_CACHED_SR1: Heap ID of heap in DDR, This is cached memory
SYSTEM_HEAPID_OCMC_SR2: Heap ID of heap in OCMC
SYSTEM_HEAPID_RESERVED1: Heap ID of heap in DDR, This is cached memory
SYSTEM_HEAPID_RESERVED2: Heap ID of heap in L2 Memory, Internal memory
4. Software and Hardware Constraints to Consider For Deciding Memory Map
4.1 Hardware Constraints
AMMU in IPU1/2 handles large memory segments of size 512MB/32MB only and there can be 4 such
segments.
For EVE we have only 32 TLB entries to map the memory, one TLB can map a max of 16MB
4.2 Software Constraints
For VSDK Linux, the first 64MB from 0x8000 0000 is reserved for Linux Kernel
Frame Buffer Shared Region (SR1) is mapped on A15 Linux. But if user wants Linux side app/links to allocate
memory/buffers from any other heap, then user need to mmap the physical address in the application code
to map those memory/buffers on A15.
Important things to pay attention to, while porting the map file are:
DDR, OCMC & DSP/EVE SRAM sizes
Core specific code/data/vecs sizes
Size of the shared frame buffer pools
DDR is divided into 2 sections: cached and non-cached.
The cached part is used mainly for frame buffer (SR1) and core specific code/data sections.
The non-cached part is used mainly for Vision SDK log buffers, IPC shared data structure (SR0), HDVPSS
descriptors etc.
5. Memory Allocation
This section describes the different methods by which memory is allocated in the Vision SDK framework. The
Vision SDK framework also supports static memory allocation.
Memory in Vision SDK framework is allocated for the following purposes
Purpose
Region in memory used for
allocation
Type of allocation
(Dynamic, Static)
External Buffer memory for storing
video, algorithms results and/or HW
engine results
SR1_FRAME_BUFFER_MEM
Dynamic (heap based)
and/or Static
Internal Buffer memory for storing
algorithms results and/or HW engine
results
OCMC_RAM
Dynamic (heap based)
and/or Static
Notify Shared region – ONLY used
SR0
Dynamic (heap based)
Draft v0.2
6 Memory Map of Vision SDK
during Notify setup (IPC_Start()), not
used later
Temporary scratch memory in internal
memory for algorithms results
DMEM in EVE
L2SRAM in DSP
Dynamic (non-heap,
linear allocation)
Shared memory for remote core print
logs
REMOTE_LOG_MEM
Static
Shared memory for link statistics
LINK_STATS_MEM
Static
Shared memory for inter processor
communication
SYSTEM_IPC_SHM_MEM
Static
VPDMA descriptor memory for VIP, VPE
HW engines
HDVPSS_DESC_MEM
Static
CPU specific memory for BIOS objects
like semaphores, tasks, interrupts,
clocks
CPU specific data section
Static
The subsequent sections provide more details on each type of memory allocation
In the below description,
<soc> = tda2xx, tda2ex, tda3xx, tda2x-entry & TDA2Px
<ddr_size> = 128MB, 256MB, 512MB, 1024MB
<os_type> = Bios, Linux
5.1 External Buffer Memory Allocation
Location where memory map is specified
The memory region used for external buffer memory allocation is specified via the below file
o File: /vision_sdk/<apps>/build/<soc>/mem_segment_definition_<os_type>.xs
o Variable SR1_FRAME_BUFFER_SIZE
The heap from which memory is allocated is defined in file
o FILE: /vision_sdk/links_fw/src/rtos/utils_common/src/utils_mem_ipu1_0.c
#pragma DATA_SECTION(gUtils_memHeapDDR, ".bss:heapMemDDR")
o This heap is placed in “SR1_FRAME_BUFFER” section via the IPU1-0 cfg file
FILE: /vision_sdk/links_fw/src/rtos/bios_app_common/<soc>/ipu1_0/Ipu1_0.cfg
Program.sectMap[".bss:heapMemDDR"] = "SR1_FRAME_BUFFER_MEM";
The heap is defined only on IPU1-0 CPU; all other CPUs sends message to IPU1-0 to allocate memory. This is
done internally inside the Utils_memAlloc APIs.
API to allocate and free memory
Below APIs are used to allocate and free memory
o FILE: /vision_sdk/links_fw/src/rtos/utils_common/include/utils_mem.h
o API:
Utils_memAlloc() with heapId as SYSTEM_HEAPID_DDR_CACHED_SR1
Utils_memFree() with heapId as SYSTEM_HEAPID_DDR_CACHED_SR1
Draft v0.2
Memory Map of Vision SDK 7
Utils_memGetHeapStats() with heapId as SYSTEM_HEAPID_DDR_CACHED_SR1
Other APIs from this file are not recommended to be used by users and are used internally by the framework
Using static memory allocation
When a system wants to use static memory allocation and avoid the heap, it should set the size of this heap
segment as 0 by modifying the #define in utils_mem_cfg.h file
Define static memory objects (arrays, data structures) in IPU1-0 use-case file. Make sure the objects are
placed in data section “.bss:heapMemDDR" via #pragma
The links which support static memory allocation allow passing of memory region pointers from use-case file
via System_LinkMemAllocInfo data structure
When creating a link from a use-case, user should now pass memory pointer allocated statically from use-case
file. This prevents the link for allocating memory internally. Thus dynamic memory allocation is avoided
o See capture link “captureLink.h” for example
o See use-case “/vision_sdk/apps/src/rtos/usecases/vip_single_cam_view” for sample usage of passing
user memory pointer to a link
o NOTE: In the use-case the memory allocation is still done using Utils_memAlloc APIs. In a fully static
memory system, this API won’t be used by the user.
The links assert if the memory segment size passed to it is smaller than what is needed. In this case, it also
reports the size required by the link.
When creating user specific AlgPlugins same mechanism should be used, i.e algorithm plugin should take
memory pointer passed from use-case file rather than allocating memory internally. See “Capture” link for
example
5.2 Internal Buffer Memory Allocation
Location where memory is specified
The memory region used for buffer memory allocation is specified via the below file
o File: /vision_sdk/<apps>/build/<soc>/mem_segment_definition_<os_type>.xs
o Variable OCMC1_SIZE
The heap from which memory is allocated is defined in file
o FILE: /vision_sdk/links_fw/src/rtos /utils_common/src/utils_mem_ipu1_0.c
#pragma DATA_SECTION(gUtils_memHeapOCMC, ".bss:heapMemOCMC")
o FILE: /vision_sdk/links_fw/src/rtos /utils_common/include/utils_mem_cfg.h
#define UTILS_MEM_HEAP_OCMC_SIZE
o This heap is placed in “OCMC” section via the IPU1-0 cfg file
FILE: /vision_sdk/links_fw/src/rtos/bios_app_common/<soc>/ipu1_0/Ipu1_0.cfg
Program.sectMap[".bss:heapMemOCMC"] = "OCMC_RAM";
The heap is defined only on IPU1-0 CPU; all other CPUs send a command to IPU1-0 to allocate memory. This is
done internally inside the Utils_memAlloc APIs.
Draft v0.2
8 Memory Map of Vision SDK
API to allocate and free memory
Below APIs are used to allocate and free memory
o FILE: /vision_sdk/links_fw/src/rtos/utils_common/include/utils_mem.h
o API:
Utils_memAlloc() with heapId as SYSTEM_HEAPID_OCMC_SR2
Utils_memFree() with heapId as SYSTEM_HEAPID_OCMC_SR2
Utils_memGetHeapStats() with heapId as SYSTEM_HEAPID_OCMC_SR2
Other APIs from this file are not recommended to be used by users and are used internally by the framework
5.3 Static Memory Sections Allocation
The memory region used for these sections are specified via the below file
o File: /vision_sdk/<apps>/build/<soc>/mem_segment_definition_<os_type>.xs
o Variable “REMOTE_LOG_SIZE” for Remote Log memory
o Variable “SYSTEM_IPC_SHM_SIZE” for inter-processor communication
o Variable “LINK_STATS_SIZE” for Link Statistics
o Variable “HDVPSS_DESC_SIZE” for VPDMA descriptors
6. Memory Map of the Application
Memory map of the entire usecase is governed by following artifacts.
1. DDR_MEM variable in /vision_sdk/apps/configs/tdaxxx_evm_<OS>_all/cfg.mk
List of VSDK files need to be reviewed & modified
1. /vision_sdk/apps/build/tdaxxx/mem_segment_definition_<OS>.xs
2. /vision_sdk/links_fw/rtos/src/utils_common/include/utils_mem_cfg.h
3. /vision_sdk/links_fw/src/rtos/bios_app_common/tdaxx/ipu1_0/ Ammu1.cfg or Ammu1_linux.cfg (if you
modify the IPU1 memory map)
4. /vision_sdk/links_fw/src/rtos/ bios_app_common/tdaxx/ipu2/ Ammu2.cfg or Ammu2_linux.cfg (if you
modify the IPU2 memory map)
5. /vision_sdk/links_fw/src/rtos/links_ipu/system/system_bsp_init.c (vpsInitPrms.virtBaseAddr &
vpsInitPrms.physBaseAddr translation)
6. /vision_sdk/links_fw/include/link_api/system_vring_config.h (only for Linux/HLOS build)
7. /vision_sdk/links_fw/src/hlos/osa/include/osa_mem_map.h (Generated file, only for Linux/HLOS build)
8. /vision_sdk/links_fw/src/rtos /links_common/system/system_rsc_table_ipu.h (only for Linux/HLOS build,
if resource table modification required)
9. /vision_sdk/links_fw/src/rtos /links_common/system/system_rsc_table_dsp.h (only for Linux/HLOS build,
if resource table modification required)
10. /vision_sdk/links_fw/src/rtos/bios_app_common/tdaxxx/<ipu2 or ipu1>/gen_system_mem_map.xs (only
for Linux/HLOS build, This file auto generates a .h file using XDC varaiables defined in
mem_segment_definition_<OS>.xs
Draft v0.2
Memory Map of Vision SDK 9
List of Linux Kernel files need to be modified
11. /ti_components/os_tools/kernel/omap/arch/arm/boot/dts/dra7-evm-infoadas.dts (For TDA2x)
12. /ti_components/os_tools/kernel/omap/arch/arm/boot/dts/dra72-evm-infoadas.dts (For TDA2Ex)
13. /ti_components/os_tools/kernel/omap/arch/arm/boot/dts/dra76-evm-infoadas.dts (For TDA2Px)
#1 – DDR_MEM is an environment variable that tells build system which .xs is to be picked up for the final
executable.
#2 – The .xs file overrides default implementation for the platform defined by xdc.runtime. This file can be
modified to increase/decrease size of a section or add/remove sections from the memory map. For Linux/HLOS,
Linux enables L2MMU for each core, so all the addresses mentioned in the .xs file are slave virtual addresses.
#3 – The .dts file is used to reserve memory from Linux, this is a platform specific file. This ensures Linux and bios
side don’t overwrite into each other. Typically the bios side needs some memory sections and rest all can be given
to Linux. Essentially this creates a few holes in Linux memory that is later mapped to user space at the application
startup time.
6.1 Adding a new Section to Memory map
While adding a new section in the memory map of ipu/dsp/eve/A15, following things needs to be taken care of:
1. Add a new section in appropriate .xs file by defining NEW_SECTION_SIZE, NEW_SECTION_ADDR &
NEW_SECTION_MEM (just follow the convention used in .xs file)
2. Its advised to remove or reduce some unwanted sections to free-up the memory required for the new section
3. Make sure the total memory should not exceeds the total available physical memory
4. Make sure the new section doesn’t overlap with any other sections.
5. If you add any new memory section and, the data/code corresponding to that can be placed into the section
by adding Program.sectMap in the appropriate
/vision_sdk/links_fw/src/rtos/bios_app_common/tdaxxx/<cpu>/<cpu>.cfg file.
6. In case of Linux, it should lie within the hole of memory declared in .dts file in kernel using /memreserve
7. If needed, /memreserve can be used to increase the size of the hole accommodate new section’s memory
requirement.
8. If this newly added section has to be mapped into L2MMU of ipu/dsp by Linux and hence it needs to be added
in the resource table i.e. in system_rsc_table_ipu.h or system_rsc_table_dsp.h accordingly.
9. If this section is going to be accessed from Linux user space or kernel space, this mapping needs to be taken
care by the application or through OSA_mem module in vision_sdk
10. If you are changing base addresses and sizes for IPU’s, DSP’s carve-out sections (code/data) and if you plan to
change CMA address in linux kernel (.dts) please ensure you also make this changes to
/vision_sdk/links_fw/include/link_api/system_vring_config.h.
11. Refer section “6.4: How To – Modify Linux/Bios VSDK Memory Map” for more details
6.2 Changing size of a Section in the Memory map
While changing the size of the section in the memory map from ipu/dsp/eve/A15, following things needs to be
taken care of:
1. Do changes in respective .xs file for the section sizes
2. Its advised to reduce some unwanted sections to free-up the memory required for new size (increase)
Draft v0.2
10 Memory Map of Vision SDK
3. Make sure the total memory should not exceeds the total available physical memory
4. Make sure the new section doesn’t overlap with any other sections.
5. In case of Linux, it should lie within the hole of memory declared in .dts file in kernel using /memreserve
6. If needed, /memreserve can be used to increase the size of the hole accommodate new section’s memory
requirement.
7. As you are modifying existing section, no need to change resource table mappings, the updated value will be
picked up in resource table in the build process.
8. If you are changing base addresses and sizes for IPU’s, DSP’s carve-out sections (code/data) and if you plan to
change CMA address in linux kernel (.dts) please ensure you also make this changes to
/vision_sdk/links_fw/include/link_api/system_vring_config.h.
9. Refer section “6.4: How To – Modify Linux/Bios VSDK Memory Map” for more details
6.3 How To - Add a new Memory map
In general, if you are planning to have your own memory map for the application, you can follow these steps
1. Evaluate memory requirements of the sections e.g. (Is 256 MB SR1 sufficient or you need more or less?)
2. Add appropriate .xs file under $INSTALL_DIR/vision_sdk/apps/build/tdaxxx/, for example
mem_segment_definition_bios.xs
2. Modify DDR_MEM_XXXX, for example DDR_MEM_512M variable in
/vision_sdk/apps/configs/tdaxxx_evm_<OS>_all/cfg.mk
3. Modify appropriate platform ISI build files to pick the correct memory map (.xs) file, for example, refer below
files for TDA2x,
a. /vision_sdk/build/rtos/tda2xx/config_arp32.bld
b. /vision_sdk/build/rtos/tda2xx/config_c66.bld
c. /vision_sdk/build/rtos/tda2xx/config_m4.bld
d. /vision_sdk/build/rtos/tda2xx/config_a15.bld
4. Now follow the section “6.4: How To – Modify Linux/Bios VSDK Memory Map” for more details and how to
modify all necessary VSDK and Linux kernel files
6.4 How To – Modify Linux/Bios VSDK Memory Map
The memory map of complete VISION SDK is controlled in
/vision_sdk/build/rtos/tdaxxx/config_<ISI>.bld
The mem_segment_definition (for example - mem_segment_definition_linux.xs) file is included in this build
configuration file, size of each sections are reconfigured in .xs file. For example, DSP code size and DSP data size
section can be changed by modifying the following entries.
DSP1_CODE_SIZE = 3*MB;
DSP1_DATA_SIZE = 13*MB;
The base addresses of each section are incremented based on the base address of previous section and the size of
the previous section. For example, if sections are created in the numerical order, base address of Section 2 is
calculated as below:
Draft v0.2
Memory Map of Vision SDK 11
<Start Addr of Sect 2> = <Start Addr of Sec 1> + <Size of Sect 1>
VSDK need one cached and one non-cached memory segments in the memory map (.xs) file.
Cached segment: You can place any memory sections in this segment except the ones listed under Non-cached
segments
Non-cached segments: Below sections must be placed under non-cached segments
SR0_ADDR
REMOTE_LOG_ADDR
LINK_STATS_ADDR
SYSTEM_IPC_SHM_ADDR
HDVPSS_DESC_ADDR
OPENVX_SHM_ADDR
Below Sections are used only for A15 Linux memory map
TRACE_BUF_BASE
EXC_DATA_BASE
PM_DATA_BASE
To modify the memory map, user needs to consider the following:
Refer to the hardware limitations and software limitations in section 4:
o We assume a one-to-one mapping of AMMU virtual address to physical address.
The other sections like “Remote Debug”, “HDVPSS Shared Memory” etc. are read directly from the build
configuration file
Changes in the Linux memory size in build configuration file has to be reflected in the boot arguments of
the Linux kernel using “mem=<SIZE>M” entry.
Consider the overall buffer requirement for the specific usecase before modifying the Frame Buffer or
Meta data buffer or BitsBuffer section sizes.
The current default memory maps of VSDK (as per 3.0 releases) as below
TDA2xx Bios – 512 MB
TDA2xx Linux – 1024 MB
TDA2Ex Bios – 512 MB
TDA2Ex Linux – 1024 MB
TDA3xx Bios – 512 MB
TDA3xx Bios – 128 MB
TDA2Px Bios – 512 MB
TDA2Px Linux – 1024 MB
6.4.1 Cache and MMU configurations
List of VSDK files sets the Cache and MMU configurations
<1> DSP
DSP L1 & L2 Cache configuration is in
/vision_sdk/links_fw/src/rtos/bios_app_common/tdaxxx/cfg/DSP_common.cfg,
Below the default cache size setting for L1P, L1D and L2 as 32K
var Cache = xdc.useModule('ti.sysbios.family.c66.Cache');
Cache.initSize.l1pSize = Cache.L1Size_32K;
Cache.initSize.l1dSize = Cache.L1Size_32K;
Cache.initSize.l2Size = Cache.L2Size_32K;
Draft v0.2
12 Memory Map of Vision SDK
Cache ON/OFF setting of DSP also in
/vision_sdk/links_fw/src/rtos/bios_app_common/tdaxxx/cfg/DSP_common.cfg
/* Set cache sections */
/* configure MARs, by default cache is enabled for the entire memory region */
for (var i = 0; i < Program.cpu.memoryMap.length; i++)
{
memSegment = Program.cpu.memoryMap[i];
Cache.setMarMeta(memSegment.base, memSegment.len, Cache.Mar_ENABLE);
}
/* set non-cached sections */
for (var i = 0; i < Program.cpu.memoryMap.length; i++)
{
memSegment = Program.cpu.memoryMap[i];
if ((memSegment.name == "SR0") ||
(memSegment.name == "REMOTE_LOG_MEM") ||
(memSegment.name == "LINK_STATS_MEM") ||
(memSegment.name == "SYSTEM_IPC_SHM_MEM") ||
(memSegment.name == "OPENVX_SHM_MEM"))
{
Cache.setMarMeta(memSegment.base, memSegment.len, Cache.Mar_DISABLE);
}
}
If you plan to add any new non-cached DSP section, then add the same section in above code snippet in
DSP_common.cfg.
<2> IPU
Refer below files which set the AMMU of IPU to configure MMU and Cache settings
/vision_sdk/links_fw/src/rtos/bios_app_common/tdaXxx/ipu1_0/Ammu1_bios.cfg or Ammu1_linux.cfg
/vision_sdk/links_fw/src/rtos/bios_app_common /tdaXxx/ipu2/Ammu2_bios.cfg or Ammu2_linux.cfg
Map program code/data & other cached memory into ammu (cacheable) by AMMU.largePages[1]
Map SR_0 & other non-cached data memory into ammu (non-cacheable) by AMMU.largePages[2]
Note: Only for TDA3x, IPU1 AMMU setting is done in SBL.
Refer /vision_sdk/links_fw/src/rtos/bios_app_common/tda3xx/ipu1_0/Ammu1_bios.cfg,
AMMU.configureAmmu = false;
If configureAmmu is set to false, then AMMU setting is done in SBL.
<3> EVE
Refer /vision_sdk/links_fw/src/rtos/bios_app_common/tda2xx/eve_common/tlb_config_eve_common.c for
EVE memory mapping by programming the TLB registers, each TLB can map a max of 16MB contiguous region
and 16MB aligned.
No changes required in this file as it has been taken care automatically.
<4> A15 (Bios)
If A15 running Bios, then /vision_sdk/links_fw/src/rtos/bios_app_common/tda2xx/a15_0/ a15_0.cfg does the
MMU & cache configurations,
Mmu.setSecondLevelDescMeta();
Draft v0.2
Memory Map of Vision SDK 13
6.4.2 Modify default Memory maps of VSDK
Please revisit & modify the list of below files (as required)
List of VSDK files
<1>
/vision_sdk/apps/build/tdaxxx/mem_segment_definition_<OS>.xs.
A single file that configures the entire memory map of all cores in the SoC, and the major file to be modified if
you want to make changes in VSDK memory map. This file defines all the memory sections for IPU, DSP, EVE,
A15 and other heaps such as SR1, SR0 etc. Below a sample section,
DSP1_START_ADDR = 0x99000000;
DSP1_CODE_SIZE = 2*MB;
DSP1_DATA_SIZE = 24*MB;
………………………………………………………….
………………………………………………………….
DSP1_CODE_ADDR = DSP1_START_ADDR;
DSP1_DATA_ADDR = DSP1_CODE_ADDR + DSP1_CODE_SIZE;
………………………………………………………….
………………………………………………………….
function getMemSegmentDefinition_external(core)
{
memory[index++] = ["DSP1_CODE_MEM", {
comment : "DSP1_CODE_MEM",
name : "DSP1_CODE_MEM",
base : DSP1_CODE_ADDR,
len : DSP1_CODE_SIZE
}];
………………………………………………………….
………………………………………………………….
}
If you add any new memory section and, the data/code corresponding to that can be placed into the section
by adding Program.sectMap[] in the appropriate
/vision_sdk/links_fw/src/rtos/bios_app_common/tdaxxx/<cpu>/<cpu>.cfg file.
For example, /vision_sdk/links_fw/src/rtos/bios_app_common/tda2xx/dsp1/Dsp1.cfg is the file for DSP1 of
TDA2x, and below code place “bss:extMemNonCache:ipcShm” into the memory section
“SYSTEM_IPC_SHM_MEM”
Program.sectMap[".bss:extMemNonCache:ipcShm"] = "SYSTEM_IPC_SHM_MEM";
Program.sectMap[".bss:extMemNonCache:linkStats"] = "LINK_STATS_MEM";
Same apply for all cores like IPU1-0, IPU1-1, IPU2, A15, DSP1-2 and EVE1-4 of TDA2x, TDA2Px, TDA2Ex and
TDA3x.
The .xs file to look at depends on SoC, A15 OS and DDR memory config selected; here is a list of default
memory map of VSDK 3.1.0.0
Draft v0.2
14 Memory Map of Vision SDK
Modify “start address”, “size” or even add/remove a memory section to change the memory map as per your
requirement.
<2>
/vision_sdk/links_fw/src/rtos/utils_common/include/utils_mem_cfg.h
This file defines the size of major internal memory heaps, and these sizes need to be in sync with above .xs
file. The memory allocation utility/API refers this file for the heap size. Any modification of these heap size to
be updated in both utils_mem_cfg.h & mem_segment_definition_<OS>.xs file.
#define UTILS_MEM_HEAP_L2_SIZE (224*1024) – DSP internal memory (SRAM)
#define UTILS_MEM_HEAP_L2_SIZE (24*1024) - EVE internal memory (SRAM)
#define UTILS_MEM_HEAP_OCMC_SIZE (512*1024) – Shared OCMC internal memory
#define UTILS_MEM_HEAP_DDR_CACHED_SIZE (256*1024*1024) – Shared cached DDR heap memory.
<3>
/vision_sdk/links_fw/src/rtos/links_ipu/system/system_bsp_init.c (vpsInitPrms.virtBaseAddr &
vpsInitPrms.physBaseAddr translation)
/* This one to one mapping is required for the 1GB builds */
vpsInitPrms.virtBaseAddr = 0x80000000U;
vpsInitPrms.physBaseAddr = 0x80000000U;
/* if Virtual address != Physical address then enable translation */
vpsInitPrms.isAddrTransReq = FALSE;
/* This one to one mapping is required for the 512MB builds */
vpsInitPrms.virtBaseAddr = 0xA0000000U;
vpsInitPrms.physBaseAddr = 0x80000000U;
/* if Virtual address != Physical address then enable translation */
vpsInitPrms.isAddrTransReq = TRUE;
<4>
/vision_sdk/links_fw/src/rtos/bios_app_common/tda2xx/ipu1_0/Ammu1_bios.cfg or Ammu1_linux.cfg (if
you modify the IPU1 memory map)
/vision_sdk/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/Ammu2_bios.cfg or Ammu2_linux.cfg (if you
modify the IPU2 memory map)
This file set IPU subsystem (core 0 and core 1) AMMU and Cache configurations. IPU can access only the
memory sections mapped via AMMU. A sinle AMMU sets the memory map of both cores (core 0 & core 1) of
an IPU subsystem.
SoC
A15 OS
DDR config
TDA2XX_BUILD
Bios
TDA2XX_512MB_DDR
TDA2XX_BUILD
Linux
TDA2XX_1024MB_DDR
TDA3XX_BUILD
NA
TDA3XX_128MB_DDR
TDA3XX_BUILD
NA
TDA3XX_512MB_DDR
TDA2EX_BUILD
Bios
TDA2EX_512MB_DDR
TDA2EX_BUILD
Linux
TDA2EX_1024MB_DDR
TDA2PX_BUILD
Bios
TDA2PX_512MB_DDR
TDA2PX_BUILD
Linux
TDA2PX_1024MB_DDR
Draft v0.2
Memory Map of Vision SDK 15
function init()
{
………………………………………………………….
………………………………………………………….
Map program code/data & other cached memory into ammu (cacheable) by AMMU.largePages[1]
Map SR_0 & other non-cached data memory into ammu (non-cacheable) by AMMU.largePages[2]
………………………………………………………….
………………………………………………………….
}
<5>
/vision_sdk/links_fw/src/rtos/bios_app_common/tda2xx/eve_common/tlb_config_eve_common.c (if you
modify any EVE1-4 memory map)
This file implements common MMU configuration for all EVE as per Vision SDK requirements
There are only 32 TLB entries in EVE, Each TBL entry can maps a max of 16MB, and need 16MB alignment,
No changes required in this file as it has been taken care automatically.
<6>
/vision_sdk/links_fw/include/link_api/system_vring_config.h (used only in A15 Linux Build)
Vring virtual addresses (For Start address) of IPU & DSP are used by IPC, if it is changed in .XS file, same need
to be updated in this system_vring_config.h also.
#ifdef BUILD_M4_0
#define IPU_PHYS_MEM_IPC_VRING 0x9e000000
#endif
#ifdef BUILD_DSP_1
#define DSP_PHYS_MEM_IPC_VRING 0xa1000000
#endif
#ifdef BUILD_DSP_2
#define DSP_PHYS_MEM_IPC_VRING 0xa3000000
#endif
#ifdef BUILD_M4_2
#define IPU_PHYS_MEM_IPC_VRING 0x99000000
#endif
<7>
/vision_sdk/links_fw/src/hlos/osa/include/osa_mem_map.h (Build time generated file, used only in A15
Linux Build)
This is an auto generated file from [gen_system_mem_map.xs], please check and confirm the entries in
osa_mem_map.h is matching with .XS file or the MAP file
#define SR0_ADDR 0xa0100000
#define SR0_SIZE 0x100000
#define SYSTEM_IPC_SHM_MEM_ADDR 0xa02c0000
Draft v0.2
16 Memory Map of Vision SDK
#define SYSTEM_IPC_SHM_MEM_SIZE 0x80000
#define REMOTE_LOG_MEM_ADDR 0xa0200000
#define REMOTE_LOG_MEM_SIZE 0x40000
#define SR1_FRAME_BUFFER_MEM_ADDR 0x84203000
#define SR1_FRAME_BUFFER_MEM_SIZE 0xfa00000
#define SR2_FRAME_BUFFER_MEM_ADDR 0xa9000000
#define SR2_FRAME_BUFFER_MEM_SIZE 0x4000000
#define OPENVX_OBJ_DESC_MEM_ADDR 0xa0440000
#define OPENVX_OBJ_DESC_MEM_SIZE 0x200000
<8>
If a newly added section has to be mapped into L2MMU of ipu/dsp by Linux and hence it needs to be added in
the resource table i.e. in system_rsc_table_ipu.h or system_rsc_table_dsp.h accordingly.
/vision_sdk/links_fw/src/rtos/links_common/system/system_rsc_table_ipu.h (modify if required, used only in
A15 Linux Build )
struct my_resource_table {…}
struct my_resource_table ti_ipc_remoteproc_ResourceTable = {…}
system_rsc_table_ipu.h define the resource table entries for all IPU cores. This will be incorporated into
corresponding base images, and used by the remoteproc on the host-side to allocated/reserve resources.
/vision_sdk/links_fw/src/rtos/links_common/system/system_rsc_table_dsp.h (modify if required, used only
in A15 Linux Build)
struct my_resource_table {…}
struct my_resource_table ti_ipc_remoteproc_ResourceTable = {…}
system_rsc_table_dsp.h define the resource table entries for all DSP cores. This will be incorporated into
corresponding base images, and used by the remoteproc on the host-side to allocated/reserve resources.
<9>
/vision_sdk/links_fw/src/rtos/bios_app_common/tdaxxx/<ipu2 or ipu1>/gen_system_mem_map.xs (only for
Linux/HLOS build, This file auto generates a .h file using XDC varaiables defined in
mem_segment_definition_<OS>.xs
Change this file only when you want to create a 512MB or <512MB Linux memory map
List of Linux Kernel files
<1>
/ti_components/os_tools/kernel/omap/arch/arm/boot/dts/dra7-evm-infoadas.dts (for TDA2x only)
Modify the start address of IPU1, IPU2, DSP1, DSP2 or CMEM, if any of this is changed in the memory map,
/* Update the CMA regions for Vision SDK binaries */
&ipu2_cma_pool {
Draft v0.2
Memory Map of Vision SDK 17
reg = <0x0 0x99000000 0x0 0x5000000>;
};
&dsp1_cma_pool {
reg = <0x0 0xa1000000 0x0 0x2000000>;
};
&ipu1_cma_pool {
reg = <0x0 0x9e000000 0x0 0x2000000>;
};
&dsp2_cma_pool {
reg = <0x0 0xa3000000 0x0 0x2000000>;
};
This file reserves the memory for SR1, SR0, CMEM and EVE data/code memory sections and the size.
Additional memory regions required for Vision SDK Keep this in sync with VSDK
apps/build/tda2xx/mem_segment_definition_linux.xs
&reserved_mem {
cmem_ocmc: cmem@40300000 {
compatible = "shared-dma-pool";
reg = <0x0 0x40300000 0x0 0x300000>;
sram = <&ocmcram1>;
no-map;
status = "okay";
};
cmem_pool: cmem@A9000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA9000000 0x0 0x4000000>;
no-map;
status = "okay";
};
vsdk_sr1_mem: vsdk_sr1_mem@84000000 {
compatible = "shared-dma-pool";
reg = <0x0 0x84000000 0x0 0x10000000>;
status = "okay";
};
vsdk_sr0_mem: vsdk_sr0_mem@A0000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA0000000 0x0 0x1000000>;
status = "okay";
};
vsdk_eve_mem: vsdk_eve_mem@A5000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA5000000 0x0 0x4000000>;
status = "okay";
Draft v0.2
18 Memory Map of Vision SDK
};
};
<2>
/ti_components/os_tools/kernel/omap/arch/arm/boot/dts/dra72-evm-infoadas.dts (for TDA2Ex only)
Modify the start address of IPU1, IPU2, DSP1 or CMEM, if any of this is changed in the memory map,
/* Update the CMA regions for Vision SDK binaries */
&ipu2_cma_pool {
reg = <0x0 0x99000000 0x0 0x5000000>;
};
&dsp1_cma_pool {
reg = <0x0 0xa1000000 0x0 0x2000000>;
};
&ipu1_cma_pool {
reg = <0x0 0x9e000000 0x0 0x2000000>;
};
This file reserves the memory for SR1, SR0 and CMEM sections and the size. Additional memory regions
required for Vision SDK Keep this in sync with VSDK apps/build/tda2Ex/mem_segment_definition_linux.xs
&reserved_mem {
cmem_ocmc: cmem@40300000 {
compatible = "shared-dma-pool";
reg = <0x0 0x40300000 0x0 0x300000>;
sram = <&ocmcram1>;
no-map;
status = "okay";
};
cmem_pool: cmem@A9000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA9000000 0x0 0x4000000>;
no-map;
status = "okay";
};
vsdk_sr1_mem: vsdk_sr1_mem@84000000 {
compatible = "shared-dma-pool";
reg = <0x0 0x84000000 0x0 0x10000000>;
status = "okay";
};
vsdk_sr0_mem: vsdk_sr0_mem@A0000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA0000000 0x0 0x1000000>;
status = "okay";
};
};
Draft v0.2
Memory Map of Vision SDK 19
<3>
/ti_components/os_tools/kernel/omap/arch/arm/boot/dts/dra76-evm-infoadas.dts (for TDA2Px only)
Modify the start address of IPU1, IPU2, DSP1, DSP2 or CMEM, if any of this is changed in the memory map,
/* Update the CMA regions for Vision SDK binaries */
&ipu2_cma_pool {
reg = <0x0 0x99000000 0x0 0x5000000>;
};
&dsp1_cma_pool {
reg = <0x0 0xa1000000 0x0 0x2000000>;
};
&ipu1_cma_pool {
reg = <0x0 0x9e000000 0x0 0x2000000>;
};
&dsp2_cma_pool {
reg = <0x0 0xa3000000 0x0 0x2000000>;
};
This file reserves the memory for SR1, SR0, CMEM and EVE data/code memory sections and the size.
Additional memory regions required for Vision SDK Keep this in sync with VSDK
apps/build/tda2Px/mem_segment_definition_linux.xs
&reserved_mem {
cmem_ocmc: cmem@40300000 {
compatible = "shared-dma-pool";
reg = <0x0 0x40300000 0x0 0x300000>;
sram = <&ocmcram1>;
no-map;
status = "okay";
};
cmem_pool: cmem@A9000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA9000000 0x0 0x4000000>;
no-map;
status = "okay";
};
vsdk_sr1_mem: vsdk_sr1_mem@84000000 {
compatible = "shared-dma-pool";
reg = <0x0 0x84000000 0x0 0x10000000>;
status = "okay";
};
vsdk_sr0_mem: vsdk_sr0_mem@A0000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA0000000 0x0 0x1000000>;
Draft v0.2
20 Memory Map of Vision SDK
status = "okay";
};
vsdk_eve_mem: vsdk_eve_mem@A5000000 {
compatible = "shared-dma-pool";
reg = <0x0 0xA5000000 0x0 0x4000000>;
status = "okay";
};
};
Clean and Rebuild Kernel & VSDK.
Note1: If SR1 or IPU1-2 memory needs to be increased to very high value, then Move DSP1-2 or EVE1-4 out of
0xA000 0000 address space. This will avoid the need of any IPU AMMU reconfiguration.
Note2: To build SBL, Build appropriate secondary boot loader as per your memory configuration. Refer file
/vision_sdk/build/rtos/makerules/build_sbl.mk for all valid configurations. For examples, EMIFMODE =
DUAL_EMIF_1GB_512MB (default) or DUAL_EMIF_2X512MB or SINGLE_EMIF_256MB
Note3: In case of A15 Linux, You also need to change DMM configuration in Uboot to set the DDR
configuration, i.e., the EMIF and LISA map configuration as per custom board or memory map.
6.5 How To – Modify 512MB Bios Memory map to 1GB Bios Memory map
Assume TDA2x build
Subject: [PATCH] 1GB Bios memory map for TDA2x
- all default cores enabled
- DSP and EVE moved to the second 512MB
---
apps/build/tda2xx/mem_segment_definition_bios.xs | 53 ++++++++++++----------
build/rtos/makerules/build_sbl.mk | 2 +-
.../rtos/bios_app_common/tda2xx/a15_0/a15_0.cfg | 2 +-
.../bios_app_common/tda2xx/ipu1_0/Ammu1_bios.cfg | 6 +--
.../bios_app_common/tda2xx/ipu2/Ammu2_bios.cfg | 6 +--
.../src/rtos/links_ipu/system/system_bsp_init.c | 4 +-
6 files changed, 38 insertions(+), 35 deletions(-)
mode change 100644 => 100755 links_fw/src/rtos/bios_app_common/tda2xx/a15_0/a15_0.cfg
mode change 100644 => 100755 links_fw/src/rtos/bios_app_common/tda2xx/ipu1_0/Ammu1_bios.cfg
mode change 100644 => 100755 links_fw/src/rtos/bios_app_common/tda2xx/ipu2/Ammu2_bios.cfg
diff --git a/apps/build/tda2xx/mem_segment_definition_bios.xs
b/apps/build/tda2xx/mem_segment_definition_bios.xs
index ebdae5d..bbf0e17 100755
--- a/apps/build/tda2xx/mem_segment_definition_bios.xs
+++ b/apps/build/tda2xx/mem_segment_definition_bios.xs
@@ -18,7 +18,7 @@ function getMemSegmentDefinition_external(core)
MB=KB*KB;
DDR3_ADDR = 0x80000000;
- DDR3_SIZE = 512*MB;
Draft v0.2
Memory Map of Vision SDK 21
+ DDR3_SIZE = 1024*MB;
/*
* In case of ECC_FFI_INCLUDE, DDR3_BASE_ADDR_1 and DDR3_BASE_SIZE_1
@@ -27,7 +27,7 @@ function getMemSegmentDefinition_external(core)
* If this DDR3_BASE_SIZE_0 is changed, update Ipu1_0.cfg
*/
DDR3_BASE_ADDR_0 = DDR3_ADDR;
- DDR3_BASE_SIZE_0 = 508*MB;
+ DDR3_BASE_SIZE_0 = 512*MB;
/* The start address of the second mem section should be 16MB aligned.
* This alignment is a must as a single 16MB mapping is used for EVE
@@ -42,7 +42,7 @@ function getMemSegmentDefinition_external(core)
* in non-cached virtual address of
* DDR3_BASE_ADDR_1 + 512*MB
*/
- DDR3_BASE_ADDR_1 = DDR3_BASE_ADDR_1+512*MB;
+ /* DDR3_BASE_ADDR_1 = DDR3_BASE_ADDR_1+512*MB; */
}
DSP1_L2_SRAM_ADDR = 0x40800000;
@@ -188,35 +188,17 @@ function getMemSegmentDefinition_external(core)
* be kept constant across all platforms and should match the increment
* to heapStats.heapSize in utils_xmc_mpu.c
*/
- EVE1_VECS_ADDR = DDR3_BASE_ADDR_0;
- EVE1_CODE_ADDR = EVE1_VECS_ADDR + EVE1_VECS_SIZE;
- EVE1_DATA_ADDR = EVE1_CODE_ADDR + EVE1_CODE_SIZE;
- EVE2_VECS_ADDR = EVE1_DATA_ADDR + EVE1_DATA_SIZE;
- EVE2_CODE_ADDR = EVE2_VECS_ADDR + EVE2_VECS_SIZE;
- EVE2_DATA_ADDR = EVE2_CODE_ADDR + EVE2_CODE_SIZE;
- EVE3_VECS_ADDR = EVE2_DATA_ADDR + EVE2_DATA_SIZE;
- EVE3_CODE_ADDR = EVE3_VECS_ADDR + EVE3_VECS_SIZE;
- EVE3_DATA_ADDR = EVE3_CODE_ADDR + EVE3_CODE_SIZE;
- EVE4_VECS_ADDR = EVE3_DATA_ADDR + EVE3_DATA_SIZE;
- EVE4_CODE_ADDR = EVE4_VECS_ADDR + EVE4_VECS_SIZE;
- EVE4_DATA_ADDR = EVE4_CODE_ADDR + EVE4_CODE_SIZE;
- NDK_DATA_ADDR = EVE4_DATA_ADDR + EVE4_DATA_SIZE;
+ NDK_DATA_ADDR = DDR3_BASE_ADDR_0 + 16*MB;
IPU1_1_CODE_ADDR = NDK_DATA_ADDR + NDK_DATA_SIZE;
IPU1_0_CODE_ADDR = IPU1_1_CODE_ADDR + IPU1_1_CODE_SIZE;
IPU2_CODE_ADDR = IPU1_0_CODE_ADDR + IPU1_0_CODE_SIZE;
- DSP1_CODE_ADDR = IPU2_CODE_ADDR + IPU2_CODE_SIZE;
- DSP2_CODE_ADDR = DSP1_CODE_ADDR + DSP1_CODE_SIZE;
- IPU1_1_DATA_ADDR = DSP2_CODE_ADDR + DSP2_CODE_SIZE;
+ IPU1_1_DATA_ADDR = IPU2_CODE_ADDR + IPU2_CODE_SIZE;
IPU1_0_DATA_ADDR = IPU1_1_DATA_ADDR + IPU1_1_DATA_SIZE;
IPU2_DATA_ADDR = IPU1_0_DATA_ADDR + IPU1_0_DATA_SIZE;
- DSP1_DATA_ADDR = IPU2_DATA_ADDR + IPU2_DATA_SIZE;
- DSP2_DATA_ADDR = DSP1_DATA_ADDR + DSP1_DATA_SIZE;
Draft v0.2
22 Memory Map of Vision SDK
- A15_0_DATA_ADDR = DSP2_DATA_ADDR + DSP2_DATA_SIZE;
+ A15_0_DATA_ADDR = IPU2_DATA_ADDR + IPU2_DATA_SIZE;
SR1_BUFF_ECC_ASIL_ADDR = A15_0_DATA_ADDR + A15_0_DATA_SIZE;
SR1_BUFF_ECC_QM_ADDR = SR1_BUFF_ECC_ASIL_ADDR + SR1_BUFF_ECC_ASIL_SIZE;
- DSP1_DATA_ADDR_2 = SR1_BUFF_ECC_QM_ADDR + SR1_BUFF_ECC_QM_SIZE;
- DSP2_DATA_ADDR_2 = DSP1_DATA_ADDR_2 + DSP1_DATA_SIZE_2;
- SR1_BUFF_NON_ECC_ASIL_ADDR = DSP2_DATA_ADDR_2 + DSP2_DATA_SIZE_2;
+ SR1_BUFF_NON_ECC_ASIL_ADDR = SR1_BUFF_ECC_QM_ADDR + SR1_BUFF_ECC_QM_SIZE;
SR1_FRAME_BUFFER_ADDR = SR1_BUFF_NON_ECC_ASIL_ADDR + SR1_BUFF_NON_ECC_ASIL_SIZE;
/* Non Cached Section */
@@ -232,6 +214,27 @@ function getMemSegmentDefinition_external(core)
HDVPSS_DESC_ADDR = SYSTEM_IPC_SHM_ADDR + SYSTEM_IPC_SHM_SIZE;
OPENVX_SHM_ADDR = HDVPSS_DESC_ADDR + HDVPSS_DESC_SIZE;
+ EVE1_VECS_ADDR = DDR3_BASE_ADDR_1 + 16*MB;
+ EVE1_CODE_ADDR = EVE1_VECS_ADDR + EVE1_VECS_SIZE;
+ EVE1_DATA_ADDR = EVE1_CODE_ADDR + EVE1_CODE_SIZE;
+ EVE2_VECS_ADDR = EVE1_DATA_ADDR + EVE1_DATA_SIZE;
+ EVE2_CODE_ADDR = EVE2_VECS_ADDR + EVE2_VECS_SIZE;
+ EVE2_DATA_ADDR = EVE2_CODE_ADDR + EVE2_CODE_SIZE;
+ EVE3_VECS_ADDR = EVE2_DATA_ADDR + EVE2_DATA_SIZE;
+ EVE3_CODE_ADDR = EVE3_VECS_ADDR + EVE3_VECS_SIZE;
+ EVE3_DATA_ADDR = EVE3_CODE_ADDR + EVE3_CODE_SIZE;
+ EVE4_VECS_ADDR = EVE3_DATA_ADDR + EVE3_DATA_SIZE;
+ EVE4_CODE_ADDR = EVE4_VECS_ADDR + EVE4_VECS_SIZE;
+ EVE4_DATA_ADDR = EVE4_CODE_ADDR + EVE4_CODE_SIZE;
+
+ DSP1_CODE_ADDR = EVE4_DATA_ADDR + EVE4_DATA_SIZE;
+ DSP2_CODE_ADDR = DSP1_CODE_ADDR + DSP1_CODE_SIZE;
+ DSP1_DATA_ADDR = DSP2_CODE_ADDR + DSP2_CODE_SIZE;
+ DSP2_DATA_ADDR = DSP1_DATA_ADDR + DSP1_DATA_SIZE;
+ DSP1_DATA_ADDR_2 = DSP2_DATA_ADDR + DSP2_DATA_SIZE;
+ DSP2_DATA_ADDR_2 = DSP1_DATA_ADDR_2 + DSP1_DATA_SIZE_2;
+
+
if ((SR1_FRAME_BUFFER_ADDR + SR1_FRAME_BUFFER_SIZE) > (DDR3_BASE_ADDR_0 +
DDR3_BASE_SIZE_0))
{
throw xdc.$$XDCException("MEMORY_MAP OVERFLOW ERROR ",
diff --git a/build/rtos/makerules/build_sbl.mk b/build/rtos/makerules/build_sbl.mk
index 7f2d52e..ea40268 100755
--- a/build/rtos/makerules/build_sbl.mk
+++ b/build/rtos/makerules/build_sbl.mk
@@ -28,7 +28,7 @@ PDK_BUILD_OPTIONS += TOOLCHAIN_PATH_EVE=$(CODEGEN_PATH_EVE)
BIOS_INSTALL_PATH=$(
PDK_BUILD_OPTIONS += EDMA3LLD_BIOS6_INSTALLDIR=$(edma_PATH) radarLink_PATH=$(radarLink_PATH)
PDK_BUILD_OPTIONS += utils_PATH=$(UTILSPATH)
-PDK_SBL_BUILD_OPTIONS = $(PDK_BUILD_OPTIONS) EMIF_MODE=SINGLE_EMIF_512MB
+PDK_SBL_BUILD_OPTIONS = $(PDK_BUILD_OPTIONS) EMIF_MODE=DUAL_EMIF_2X512MB
Draft v0.2
Memory Map of Vision SDK 23
ifneq ($(ECC_FFI_INCLUDE),yes)
PDK_SBL_BUILD_OPTIONS+= SBL_CONFIG=disable_safety
endif
diff --git a/links_fw/src/rtos/bios_app_common/tda2xx/a15_0/a15_0.cfg
b/links_fw/src/rtos/bios_app_common/tda2xx/a15_0/a15_0.cfg
old mode 100644
new mode 100755
index 25a03f9..8a96266
--- a/links_fw/src/rtos/bios_app_common/tda2xx/a15_0/a15_0.cfg
+++ b/links_fw/src/rtos/bios_app_common/tda2xx/a15_0/a15_0.cfg
@@ -162,7 +162,7 @@ attrs2.attrIndx = 0; // Non-cache, normal memory
// Set the descriptor for each entry in the address range
for (var i=0xA0000000; i < 0xC0000000; i = i + 0x00200000) {
// Each 'BLOCK' descriptor entry spans a 2MB address range
- Mmu.setSecondLevelDescMeta(i, i-0x20000000, attrs2);
+ Mmu.setSecondLevelDescMeta(i, i, attrs2);
}
// Region for NDK packet data buffers.
diff --git a/links_fw/src/rtos/bios_app_common/tda2xx/ipu1_0/Ammu1_bios.cfg
b/links_fw/src/rtos/bios_app_common/tda2xx/ipu1_0/Ammu1_bios.cfg
old mode 100644
new mode 100755
index 7809abc..685a934
--- a/links_fw/src/rtos/bios_app_common/tda2xx/ipu1_0/Ammu1_bios.cfg
+++ b/links_fw/src/rtos/bios_app_common/tda2xx/ipu1_0/Ammu1_bios.cfg
@@ -204,13 +204,13 @@ function init()
entry.pageEnabled = AMMU.Enable_YES;
entry.translationEnabled = AMMU.Enable_YES;
entry.logicalAddress = 0xA0000000;
- entry.translatedAddress = 0x80000000;
+ entry.translatedAddress = 0xA0000000;
entry.size = AMMU.Large_512M;
entry.L1_cacheable = AMMU.CachePolicy_NON_CACHEABLE;
entry.L1_posted = AMMU.PostedPolicy_NON_POSTED;
entry.L2_cacheable = AMMU.CachePolicy_NON_CACHEABLE;
entry.L2_posted = AMMU.PostedPolicy_NON_POSTED;
-/*
+
var entry = AMMU.largePages[3];
entry.pageEnabled = AMMU.Enable_YES;
entry.translationEnabled = AMMU.Enable_YES;
@@ -221,6 +221,6 @@ function init()
entry.L1_posted = AMMU.PostedPolicy_NON_POSTED;
entry.L2_cacheable = AMMU.CachePolicy_NON_CACHEABLE;
entry.L2_posted = AMMU.PostedPolicy_NON_POSTED;
-*/
+
}
Draft v0.2
24 Memory Map of Vision SDK
diff --git a/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/Ammu2_bios.cfg
b/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/Ammu2_bios.cfg
old mode 100644
new mode 100755
index 21d55cc..f44a488
--- a/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/Ammu2_bios.cfg
+++ b/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/Ammu2_bios.cfg
@@ -204,13 +204,13 @@ function init()
entry.pageEnabled = AMMU.Enable_YES;
entry.translationEnabled = AMMU.Enable_YES;
entry.logicalAddress = 0xA0000000;
- entry.translatedAddress = 0x80000000;
+ entry.translatedAddress = 0xA0000000;
entry.size = AMMU.Large_512M;
entry.L1_cacheable = AMMU.CachePolicy_NON_CACHEABLE;
entry.L1_posted = AMMU.PostedPolicy_NON_POSTED;
entry.L2_cacheable = AMMU.CachePolicy_NON_CACHEABLE;
entry.L2_posted = AMMU.PostedPolicy_NON_POSTED;
-/*
+
var entry = AMMU.largePages[3];
entry.pageEnabled = AMMU.Enable_YES;
entry.translationEnabled = AMMU.Enable_YES;
@@ -221,5 +221,5 @@ function init()
entry.L1_posted = AMMU.PostedPolicy_NON_POSTED;
entry.L2_cacheable = AMMU.CachePolicy_NON_CACHEABLE;
entry.L2_posted = AMMU.PostedPolicy_NON_POSTED;
-*/
+
}
\ No newline at end of file
diff --git a/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
b/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
index f4a4b80..63bad9d 100755
--- a/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
+++ b/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
@@ -265,10 +265,10 @@ Int32 System_bspInit(void)
vpsInitPrms.virtBaseAddr = 0x80000000U;
vpsInitPrms.physBaseAddr = 0x80000000U;
#else
- vpsInitPrms.virtBaseAddr = 0xA0000000U;
+ vpsInitPrms.virtBaseAddr = 0x80000000U;
vpsInitPrms.physBaseAddr = 0x80000000U;
/* if Virtual address != Physical address then enable translation */
- vpsInitPrms.isAddrTransReq = TRUE;
+ vpsInitPrms.isAddrTransReq = FALSE;
#endif
Vps_printf(" SYSTEM: VPDMA Descriptor Memory Address translation"
" ENABLED [0x%08x -> 0x%08x]\n",
--
Draft v0.2
Memory Map of Vision SDK 25
6.6 How To - Modify 1GB Linux Memory map to 512MB Linux Memory map
Assume TDA2xx build
6.6.1 Sample patch for TDA2xx VSDK files modification
Subject: [PATCH] [vsdk.30] - TDA2x 512MB linux build
- VSDK changes to make TDA2x 512MB linux build
- All EVE cores and IPU1 are disabled
---
apps/build/tda2xx/mem_segment_definition_linux.xs | 70 ++++++++++++----------
apps/configs/tda2xx_evm_linux_all/cfg.mk | 10 ++--
build/Rules.make | 2 +-
links_fw/include/link_api/system_vring_config.h | 16 ++---
links_fw/src/hlos/osa/include/osa_mem_map.h | 15 ++---
.../tda2xx/ipu2/gen_system_mem_map.xs | 6 +-
.../links_common/system/system_rsc_table_ipu.h | 24 ++++++--
.../src/rtos/links_ipu/system/system_bsp_init.c | 4 +-
8 files changed, 85 insertions(+), 62 deletions(-)
mode change 100644 => 100755 links_fw/include/link_api/system_vring_config.h
mode change 100644 => 100755 links_fw/src/rtos/links_common/system/system_rsc_table_ipu.h
diff --git a/apps/build/tda2xx/mem_segment_definition_linux.xs
b/apps/build/tda2xx/mem_segment_definition_linux.xs
index 405d123..e66832c 100755
--- a/apps/build/tda2xx/mem_segment_definition_linux.xs
+++ b/apps/build/tda2xx/mem_segment_definition_linux.xs
@@ -12,6 +12,9 @@
* ======== Single file for the memory map configuration of all cores =========
*/
+function getMemSegmentDefinition_external(core)
+{
+
KB=1024;
MB=KB*KB;
@@ -49,12 +52,12 @@ SR2_BASE_ADDR 0xA9000000
A15-Linux 0xC0000000(End of Interleaving)
*************************/
DDR3_ADDR = 0x80000000;
-DDR3_SIZE = 1024*MB;
+DDR3_SIZE = 512*MB;
DDR3_LINUX_MEM_OFFSET = 64*MB;
/* First 512 MB - cached */
DDR3_BASE_ADDR_0 = 0x80000000;
-DDR3_BASE_SIZE_0 = 448*MB + DDR3_LINUX_MEM_OFFSET;
+DDR3_BASE_SIZE_0 = 507*MB;
/* The start address of the second mem section should be 16MB aligned.
Draft v0.2
26 Memory Map of Vision SDK
@@ -62,13 +65,22 @@ DDR3_BASE_SIZE_0 = 448*MB + DDR3_LINUX_MEM_OFFSET;
* to map SR0, REMOTE_LOG_MEM sections.
* tlb_config_eveX.c need to be modified otherwise
*/
-DDR3_BASE_ADDR_1 = 0xA0000000;
-DDR3_BASE_SIZE_1 = 512*MB;
+DDR3_BASE_ADDR_1 = DDR3_BASE_ADDR_0 + DDR3_BASE_SIZE_0;
+DDR3_BASE_SIZE_1 = DDR3_SIZE - DDR3_BASE_SIZE_0;
+
+if(core=="ipu1_1" || core=="ipu1_0" || core=="ipu2")
+{
+ /* for ipu1_0, ipu1_1, ipu2 DDR3_BASE_ADDR_1 should be
+ * in non-cached virtual address of
+ * DDR3_BASE_ADDR_1 + 512*MB
+ */
+ DDR3_BASE_ADDR_1 = DDR3_BASE_ADDR_1+512*MB;
+}
/* Address and Size definitions of different components running on different cores */
NDK_START_ADDR = DDR3_BASE_ADDR_0 + DDR3_LINUX_MEM_OFFSET;
NDK_MEM_SIZE = 2*MB
-SR1_FRAME_BUFFER_SIZE = 250*MB;
+SR1_FRAME_BUFFER_SIZE = 205*MB;
SR1_BUFF_ECC_ASIL_SIZE = 4*KB;
SR1_BUFF_ECC_QM_SIZE = 4*KB;
SR1_BUFF_NON_ECC_ASIL_SIZE = 4*KB;
@@ -83,20 +95,20 @@ if (ipummSupport == "yes") {
IPU2_DATA_SIZE = 60*MB;
}
else {
- IPU2_DATA_SIZE = 20*MB;
+ IPU2_DATA_SIZE = 16*MB;
}
-IPU1_START_ADDR = 0x9e000000;
-IPU1_0_CODE_SIZE = 8*MB;
-IPU1_0_DATA_SIZE = 21*MB;
+IPU1_START_ADDR = 0x9D000000;
+IPU1_0_CODE_SIZE = 1*KB;
+IPU1_0_DATA_SIZE = 1*KB;
-DSP1_START_ADDR = 0xA1000000;
+DSP1_START_ADDR = 0x9B000000;
DSP1_CODE_SIZE = 2*MB;
-DSP1_DATA_SIZE = 24*MB;
+DSP1_DATA_SIZE = 12*MB;
-DSP2_START_ADDR = 0xA3000000;
+DSP2_START_ADDR = 0x9C000000;
DSP2_CODE_SIZE = 2*MB;
-DSP2_DATA_SIZE = 14*MB;
Draft v0.2
Memory Map of Vision SDK 27
+DSP2_DATA_SIZE = 12*MB;
/* The start address of the second mem section should be 16MB aligned.
* This alignment is a must as a single 16MB mapping is used for EVE
@@ -118,25 +130,25 @@ PM_DATA_LEN = 512*KB;
OPENVX_SHM_SIZE = 2*MB;
/* The start address of EVE memory must be 16MB aligned. */
-EVE_START_ADDR = 0xA5000000;
+EVE_START_ADDR = 0x9D100000;
/* EVE vecs space should be align with 16MB boundary, and if possible try to fit
* the entire vecs+code+data in 16MB section. In this case a single TLB map would
* be enough to map vecs+code+data of an EVE.
* tlb_config_eveX.c need to be modified if any of these EVE memory sections or
* SR1_FRAME_BUFFER_MEM section is modified.
*/
-EVE1_VECS_SIZE = 0.5*MB;
-EVE1_CODE_SIZE = 2*MB;
-EVE1_DATA_SIZE =13.5*MB;
-EVE2_VECS_SIZE = 0.5*MB;
-EVE2_CODE_SIZE = 2*MB;
-EVE2_DATA_SIZE =13.5*MB;
-EVE3_VECS_SIZE = 0.5*MB;
-EVE3_CODE_SIZE = 2*MB;
-EVE3_DATA_SIZE =13.5*MB;
-EVE4_VECS_SIZE = 0.5*MB;
-EVE4_CODE_SIZE = 2*MB;
-EVE4_DATA_SIZE =13.5*MB;
+EVE1_VECS_SIZE =1*KB;
+EVE1_CODE_SIZE =1*KB;
+EVE1_DATA_SIZE =1*KB;
+EVE2_VECS_SIZE =1*KB;
+EVE2_CODE_SIZE =1*KB;
+EVE2_DATA_SIZE =1*KB;
+EVE3_VECS_SIZE =1*KB;
+EVE3_CODE_SIZE =1*KB;
+EVE3_DATA_SIZE =1*KB;
+EVE4_VECS_SIZE =1*KB;
+EVE4_CODE_SIZE =1*KB;
+EVE4_DATA_SIZE =1*KB;
TOTAL_MEM_SIZE = (DDR3_SIZE);
@@ -209,12 +221,10 @@ if (A15TargetOS == "Qnx") {
}
else {
/* Shared Region handled by A15 HLOS Linux*/
- SR2_BASE_ADDR = 0xA9000000;
- SR2_SIZE = 0x4000000;
+ SR2_BASE_ADDR = 0x9D200000;
+ SR2_SIZE = 0x2000000;
Draft v0.2
28 Memory Map of Vision SDK
}
-function getMemSegmentDefinition_external(core)
-{
var memory = new Array();
var index = 0;
diff --git a/apps/configs/tda2xx_evm_linux_all/cfg.mk b/apps/configs/tda2xx_evm_linux_all/cfg.mk
index 1e32d6b..bc445b9 100755
--- a/apps/configs/tda2xx_evm_linux_all/cfg.mk
+++ b/apps/configs/tda2xx_evm_linux_all/cfg.mk
@@ -23,10 +23,10 @@ PROC_IPU2_INCLUDE=yes
PROC_A15_0_INCLUDE=yes
PROC_DSP1_INCLUDE=yes
PROC_DSP2_INCLUDE=yes
-PROC_EVE1_INCLUDE=yes
-PROC_EVE2_INCLUDE=yes
-PROC_EVE3_INCLUDE=yes
-PROC_EVE4_INCLUDE=yes
+PROC_EVE1_INCLUDE=no
+PROC_EVE2_INCLUDE=no
+PROC_EVE3_INCLUDE=no
+PROC_EVE4_INCLUDE=no
VSDK_BOARD_TYPE=TDA2XX_EVM
@@ -112,7 +112,7 @@ DATA_VIS_INCLUDE=no
#
# Enable below macro to enable OPENVX into Vision SDK
#
-OPENVX_INCLUDE=yes
+OPENVX_INCLUDE=no
CIO_REDIRECT=yes
diff --git a/build/Rules.make b/build/Rules.make
index 000ddd4..e061397 100755
--- a/build/Rules.make
+++ b/build/Rules.make
@@ -55,7 +55,7 @@ MAKEAPPNAME?=apps
# tda2px_evm_bios_iss
#
#
-MAKECONFIG?=tda2xx_evm_bios_all
+MAKECONFIG?=tda2xx_evm_linux_all
# Default build environment
# Options: Windows_NT or Linux
diff --git a/links_fw/include/link_api/system_vring_config.h
b/links_fw/include/link_api/system_vring_config.h
old mode 100644
Draft v0.2
Memory Map of Vision SDK 29
new mode 100755
index 3a6b0e9..b062abb
--- a/links_fw/include/link_api/system_vring_config.h
+++ b/links_fw/include/link_api/system_vring_config.h
@@ -107,11 +107,11 @@ extern "C" {
#define IPU_MEM_VRING_BUFS0 0x60040000
#define IPU_MEM_VRING_BUFS1 0x60080000
-#define DSP_MEM_IPC_VRING 0xA0000000
-#define DSP_MEM_RPMSG_VRING0 0xA0000000
-#define DSP_MEM_RPMSG_VRING1 0xA0004000
-#define DSP_MEM_VRING_BUFS0 0xA0040000
-#define DSP_MEM_VRING_BUFS1 0xA0080000
+#define DSP_MEM_IPC_VRING 0x9FB00000
+#define DSP_MEM_RPMSG_VRING0 0x9FB00000
+#define DSP_MEM_RPMSG_VRING1 0x9FB04000
+#define DSP_MEM_VRING_BUFS0 0x9FB40000
+#define DSP_MEM_VRING_BUFS1 0x9FB80000
/*
* Vring physical addresses
@@ -129,15 +129,15 @@ extern "C" {
*/
#ifdef BUILD_M4_0
-#define IPU_PHYS_MEM_IPC_VRING 0x9e000000
+#define IPU_PHYS_MEM_IPC_VRING 0x9D000000
#endif
#ifdef BUILD_DSP_1
-#define DSP_PHYS_MEM_IPC_VRING 0xa1000000
+#define DSP_PHYS_MEM_IPC_VRING 0x9B000000
#endif
#ifdef BUILD_DSP_2
-#define DSP_PHYS_MEM_IPC_VRING 0xa3000000
+#define DSP_PHYS_MEM_IPC_VRING 0x9C000000
#endif
#ifdef BUILD_M4_2
diff --git a/links_fw/src/hlos/osa/include/osa_mem_map.h b/links_fw/src/hlos/osa/include/osa_mem_map.h
index a83dca5..9eab2b8 100644
--- a/links_fw/src/hlos/osa/include/osa_mem_map.h
+++ b/links_fw/src/hlos/osa/include/osa_mem_map.h
@@ -11,23 +11,20 @@
#define _SYSTEM_MEM_MAP_H_
-#define SR0_ADDR 0xa0100000
+#define SR0_ADDR 0x9fc00000
#define SR0_SIZE 0x100000
Draft v0.2
30 Memory Map of Vision SDK
-#define SYSTEM_IPC_SHM_MEM_ADDR 0xa02c0000
+#define SYSTEM_IPC_SHM_MEM_ADDR 0x9fdc0000
#define SYSTEM_IPC_SHM_MEM_SIZE 0x80000
-#define REMOTE_LOG_MEM_ADDR 0xa0200000
+#define REMOTE_LOG_MEM_ADDR 0x9fd00000
#define REMOTE_LOG_MEM_SIZE 0x40000
#define SR1_FRAME_BUFFER_MEM_ADDR 0x84203000
-#define SR1_FRAME_BUFFER_MEM_SIZE 0xfa00000
+#define SR1_FRAME_BUFFER_MEM_SIZE 0xcd00000
-#define SR2_FRAME_BUFFER_MEM_ADDR 0xa9000000
-#define SR2_FRAME_BUFFER_MEM_SIZE 0x4000000
-
-#define OPENVX_OBJ_DESC_MEM_ADDR 0xa0530000
-#define OPENVX_OBJ_DESC_MEM_SIZE 0x200000
+#define SR2_FRAME_BUFFER_MEM_ADDR 0x9d200000
+#define SR2_FRAME_BUFFER_MEM_SIZE 0x2000000
#endif /* _SYSTEM_MEM_MAP_H_ */
diff --git a/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/gen_system_mem_map.xs
b/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/gen_system_mem_map.xs
index 93c07eb..929d0ad 100755
--- a/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/gen_system_mem_map.xs
+++ b/links_fw/src/rtos/bios_app_common/tda2xx/ipu2/gen_system_mem_map.xs
@@ -48,13 +48,13 @@ function GenSystemMemMap()
fd.writeLine("#define _SYSTEM_MEM_MAP_H_");
fd.writeLine("");
fd.writeLine("");
- fd.writeLine("#define SR0_ADDR " + Value2HexString(SR0.base));
+ fd.writeLine("#define SR0_ADDR " + Value2HexString((SR0.base)-0x20000000));
fd.writeLine("#define SR0_SIZE " + Value2HexString(SR0.len) );
fd.writeLine("");
- fd.writeLine("#define SYSTEM_IPC_SHM_MEM_ADDR " +
Value2HexString(SYSTEM_IPC_SHM_MEM.base));
+ fd.writeLine("#define SYSTEM_IPC_SHM_MEM_ADDR " +
Value2HexString((SYSTEM_IPC_SHM_MEM.base)-0x20000000));
fd.writeLine("#define SYSTEM_IPC_SHM_MEM_SIZE " + Value2HexString(SYSTEM_IPC_SHM_MEM.len) );
fd.writeLine("");
- fd.writeLine("#define REMOTE_LOG_MEM_ADDR " + Value2HexString(REMOTE_LOG_MEM.base));
+ fd.writeLine("#define REMOTE_LOG_MEM_ADDR " + Value2HexString((REMOTE_LOG_MEM.base)-
0x20000000));
fd.writeLine("#define REMOTE_LOG_MEM_SIZE " + Value2HexString(REMOTE_LOG_MEM.len) );
fd.writeLine("");
fd.writeLine("#define SR1_FRAME_BUFFER_MEM_ADDR " + Value2HexString(SR1.base));
diff --git a/links_fw/src/rtos/links_common/system/system_rsc_table_ipu.h
b/links_fw/src/rtos/links_common/system/system_rsc_table_ipu.h
old mode 100644
Draft v0.2
Memory Map of Vision SDK 31
new mode 100755
index f97437a..4789fc5
--- a/links_fw/src/rtos/links_common/system/system_rsc_table_ipu.h
+++ b/links_fw/src/rtos/links_common/system/system_rsc_table_ipu.h
@@ -79,9 +79,9 @@ Limited License.
/* Number of entries in resource table */
#ifdef IPU1_LOAD_EVES
-#define RSC_NUM_ENTRIES 19
+#define RSC_NUM_ENTRIES 20
#else
-#define RSC_NUM_ENTRIES 18
+#define RSC_NUM_ENTRIES 19
#endif
/* IPU Memory Map */
@@ -107,10 +107,13 @@ Limited License.
#define IPU_TILER_MODE_0_1 0xA0000000
#define L3_TILER_MODE_2 0x70000000
-#define IPU_TILER_MODE_2 0xB0000000
+#define IPU_TILER_MODE_2 0xA1000000
#define L3_TILER_MODE_3 0x78000000
-#define IPU_TILER_MODE_3 0xB8000000
+#define IPU_TILER_MODE_3 0xB0000000
+
+#define L3_AMMU_NONCACHED 0x9FB00000
+#define IPU_AMMU_NONCACHED 0xBFB00000
#define IPU_MEM_TEXT 0x0
@@ -126,7 +129,7 @@ Limited License.
#define IPU_MEM_IPC_DATA XDC_CFG_IPC_DATA
#define IPU_NDK_MEM XDC_CFG_NDK_MEM
#define SYSTEM_COMMON_SHM_VIRT XDC_CFG_SYSTEM_COMMON_SHM_VIRT
-#define SYSTEM_COMMON_SHM XDC_CFG_SYSTEM_COMMON_SHM_VIRT
+#define SYSTEM_COMMON_SHM (XDC_CFG_SYSTEM_COMMON_SHM_VIRT-0x20000000)
#define EVE_MEM_VIRT XDC_CFG_EVE_MEM
#define EVE_MEM XDC_CFG_EVE_MEM
@@ -227,6 +230,9 @@ struct my_resource_table {
/* devmem entry */
struct fw_rsc_devmem devmem13;
+ /* devmem entry */
+ struct fw_rsc_devmem devmem14;
+
};
extern char ti_trace_SysMin_Module_State_0_outbuf__A;
Draft v0.2
32 Memory Map of Vision SDK
@@ -262,6 +268,7 @@ struct my_resource_table ti_ipc_remoteproc_ResourceTable = {
offsetof(struct my_resource_table, devmem12),
#endif
offsetof(struct my_resource_table, devmem13),
+ offsetof(struct my_resource_table, devmem14),
},
/* rpmsg vdev entry */
@@ -380,6 +387,13 @@ struct my_resource_table ti_ipc_remoteproc_ResourceTable = {
SR2_VIRT, SR2_PHYS,
SR2_SIZE, 0, 0, "SR2_MEM",
},
+
+ {
+ TYPE_DEVMEM,
+ IPU_AMMU_NONCACHED, L3_AMMU_NONCACHED,
+ 0x500000, 0, 0, "IPU_AMMU_NONCACHED",
+ },
+
};
#endif /* _RSC_TABLE_IPU_H_ */
diff --git a/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
b/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
index 97287ff..5a18372 100755
--- a/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
+++ b/links_fw/src/rtos/links_ipu/system/system_bsp_init.c
@@ -251,8 +251,10 @@ Int32 System_bspInit(void)
#ifdef A15_TARGET_OS_LINUX
/* This one to one mapping is required for the 1GB Linux builds */
- vpsInitPrms.virtBaseAddr = 0x80000000U;
+ vpsInitPrms.virtBaseAddr = 0xA0000000U;
vpsInitPrms.physBaseAddr = 0x80000000U;
+ /* if Virtual address != Physical address then enable translation */
+ vpsInitPrms.isAddrTransReq = TRUE;
#else
vpsInitPrms.virtBaseAddr = 0xA0000000U;
vpsInitPrms.physBaseAddr = 0x80000000U;
--
6.6.2 Sample patch for TDA2xx Linux Kernel modification
Subject: [PATCH] Linux kernel- TDA2x 512MB VSDK build
- Changes in DRA7x infoAdas dts for 512MB VSDK linux build
---
arch/arm/boot/dts/dra7-evm-infoadas.dts | 22 +++++++++++-----------
1 file changed, 11 insertions(+), 11 deletions(-)
diff --git a/arch/arm/boot/dts/dra7-evm-infoadas.dts b/arch/arm/boot/dts/dra7-evm-infoadas.dts
index c8fd926..98cf975 100755
Draft v0.2
Memory Map of Vision SDK 33
--- a/arch/arm/boot/dts/dra7-evm-infoadas.dts
+++ b/arch/arm/boot/dts/dra7-evm-infoadas.dts
@@ -61,19 +61,19 @@
/* Update the CMA regions for Vision SDK binaries */
&ipu2_cma_pool {
- reg = <0x0 0x99000000 0x0 0x5000000>;
+ reg = <0x0 0x99000000 0x0 0x2000000>;
};
&dsp1_cma_pool {
- reg = <0x0 0xa1000000 0x0 0x2000000>;
+ reg = <0x0 0x9B000000 0x0 0x1000000>;
};
&ipu1_cma_pool {
- reg = <0x0 0x9e000000 0x0 0x2000000>;
+ reg = <0x0 0x9D000000 0x0 0x100000>;
};
&dsp2_cma_pool {
- reg = <0x0 0xa3000000 0x0 0x2000000>;
+ reg = <0x0 0x9C000000 0x0 0x1000000>;
};
&reserved_mem {
@@ -85,28 +85,28 @@
status = "okay";
};
- cmem_pool: cmem@A9000000 {
+ cmem_pool: cmem@9D200000 {
compatible = "shared-dma-pool";
- reg = <0x0 0xA9000000 0x0 0x4000000>;
+ reg = <0x0 0x9D200000 0x0 0x2000000>;
no-map;
status = "okay";
};
vsdk_sr1_mem: vsdk_sr1_mem@84000000 {
compatible = "shared-dma-pool";
- reg = <0x0 0x84000000 0x0 0x15000000>;
+ reg = <0x0 0x84000000 0x0 0xD000000>;
status = "okay";
};
- vsdk_sr0_mem: vsdk_sr0_mem@A0000000 {
+ vsdk_sr0_mem: vsdk_sr0_mem@9FB00000 {
compatible = "shared-dma-pool";
- reg = <0x0 0xA0000000 0x0 0x1000000>;
+ reg = <0x0 0x9FB00000 0x0 0x500000>;
Draft v0.2
34 Memory Map of Vision SDK
status = "okay";
};
- vsdk_eve_mem: vsdk_eve_mem@A5000000 {
+ vsdk_eve_mem: vsdk_eve_mem@9D100000 {
compatible = "shared-dma-pool";
- reg = <0x0 0xA5000000 0x0 0x4000000>;
+ reg = <0x0 0x9D100000 0x0 0x100000>;
status = "okay";
};
};
--
6.7 Moving reserved memory entries to ‘high-mem’ in Linux builds
For Linux configurations (such as tda2xx_evm_linux_all, tda2ex_linux_infoadas etc.) 500-600MB of data is
carved-out as a ‘reserved memory’ entry to prevent the kernel from overwriting the contents within this
address space. A summary of the memory-maps for various configurations is listed below
Section
tda2xx-
linux(MB)
tda2ex-
linux(MB)
tda2ex_17x17-
linux(MB)
tda2px-
linux(MB)
tda2xx-
infoadas(MB)
tda2ex-
infoadas(MB)
tda2px-
infoadas(MB)
IPU-1
CMA
32
32
32
32
32
32
32
IPU-2
CMA
80
80
80
80
80
80
80
DSP-1
CMA
32
32
32
32
32
32
32
DSP-2
CMA
32
NA
NA
32
32
NA
32
EVEs CMA
64
NA
NA
64
64
NA
64
SR-0
16
16
16
16
16
16
16
SR-1
256
256
256
336
256
256
256
SR-2
64
64
64
64
64
64
64
Total
576
480
480
656
576
480
576
For all the configurations the ‘reserved mem’ entries lie within the address space 0x80000000 – 0xB0000000.
This region also is the ‘low-mem’ region in the kernel. The ‘low-mem’ region in the kernel is where all kernel
data-structures reside. By default the kernel is configured to work on a 1:3 split (CONFIG_VMSPLIT_3G), i.e in
a system with 4GB RAM, the low-mem, vmalloc and high-mem regions are as below:
1. 0x80000000 – 0xB0000000 – Low-mem region (768MB)
2. 0xB0000000 – 0xC0000000 – Vmalloc region (256MB)
3. 0xC0000000 – 0xFFFFFFFFF – High-mem region (3GB)
With roughly 500-600MB reserved for shared region and CMA entries, often the kernel runs out of low-mem.
To overcome the constraint, few sections can be moved. These are:
1. DSP-1
2. DSP-2
3. EVEs
4. SR-1
Draft v0.2
Memory Map of Vision SDK 35
DSP-1, DSP-2 and EVEs CMA regions can be moved to high-mem. This can be achieved by referring to section-
6.4 of this document. The address can be in the range 0xC0000000 – 0xFFFFFFFF depending on the size of the
RAM available.
While moving SR-1 from low-mem the following constraints must be considered:
1. The SR-1 region must be contained within 0xBFFFFFF: The cached shared-region can be moved from low-
mem address space to the vmalloc address space, i.e the SR-1 region can reside within 0xB0000000 –
0xBFFFFFFF. The shared-region can’t reside outside the 0xBFFFFFFF boundary, since the AMMU
configuration for IPU lists entries only upto 0xBFFFFFFF.
2. All entries constituting SR-1 must be atleast 1MB in size: SR-1 comprises of the following entities:
a. SR1_FRAME_BUFFER_SIZE – typically greater than 200 MB
b. SR1_BUFF_ECC_ASIL_SIZE – 4KB
c. SR1_BUFF_ECC_QM_SIZE – 4KB
d. SR1_BUFF_NON_ECC_ASIL_SIZE – 4KB
When moving SR-1 outside low-mem, the entries ‘SR1_BUFF_ECC_ASIL_SIZE’, ‘SR1_BUFF_ECC_QM_SIZE’
and ‘SR1_BUFF_NON_ECC_ASIL_SIZE’ must be set to atleast 1MB. This change is essential as the remote-
proc driver on the kernel performs a ‘dma_map_single’ on page-table entries less than 64KB. This
function expects an address within low-mem address space, and crashes if address is outside low-mem.
3. Performance impact for direct CPU-access : The region 0x80000000 – 0xA0000000 is mapped as cached
region in the IPU-AMMU configuration, while the region 0xA000000 – 0xC0000000 is mapped as non-
cached region. By moving SR-1 to non-cached region of IPU, use-cases which perform CPU-access from
IPU will have a performance impact. While most use-cases perform DMA access, certain links such as the
grpxSrcLink, algFrameDraw perform CPU access to update contents of buffers. These use-cases may
notice a performance drop.
It’s strongly advised not to move the below reserved-memory regions:
1. IPU-2 CMA region
2. SR-0
3. NDK base-address
An example indicating moving of SR-1 to high-mem is demonstrated below:
--- a/apps/build/tda2xx/mem_segment_definition_linux.xs
+++ b/apps/build/tda2xx/mem_segment_definition_linux.xs
@@ -62,10 +62,10 @@ DDR3_BASE_SIZE_1 = 512*MB;
/* Address and Size definitions of different components running on different cores */
NDK_START_ADDR = DDR3_BASE_ADDR_0 + DDR3_LINUX_MEM_OFFSET;
NDK_MEM_SIZE = 2*MB
SR1_FRAME_BUFFER_SIZE = 250*MB;
-SR1_BUFF_ECC_ASIL_SIZE = 4*KB;
-SR1_BUFF_ECC_QM_SIZE = 4*KB;
-SR1_BUFF_NON_ECC_ASIL_SIZE = 4*KB;
+SR1_BUFF_ECC_ASIL_SIZE = 1*MB;
+SR1_BUFF_ECC_QM_SIZE = 1*MB;
+SR1_BUFF_NON_ECC_ASIL_SIZE = 1*MB;
var ipummSupport = java.lang.System.getenv("IPUMM_INCLUDE");
Draft v0.2
36 Memory Map of Vision SDK
@@ -133,7 +133,7 @@ TOTAL_MEM_SIZE = (DDR3_SIZE);
* So both of these sections should be one after another without any gap
*/
NDK_MEM_ADDR = NDK_START_ADDR
-SR1_BUFF_ECC_ASIL_ADDR = NDK_MEM_ADDR + NDK_MEM_SIZE;
+SR1_BUFF_ECC_ASIL_ADDR = 0xb0000000;
SR1_BUFF_ECC_QM_ADDR = SR1_BUFF_ECC_ASIL_ADDR + SR1_BUFF_ECC_ASIL_SIZE;
SR1_BUFF_NON_ECC_ASIL_ADDR = SR1_BUFF_ECC_QM_ADDR + SR1_BUFF_ECC_QM_SIZE;
SR1_FRAME_BUFFER_ADDR = SR1_BUFF_NON_ECC_ASIL_ADDR + SR1_BUFF_NON_ECC_ASIL_SIZE;
--
Draft v0.2
Memory Map of Vision SDK 37
Revision History
Version #
Date
Author Name
Revision History
0.1
26/12/2016
Shiju S
First draft
0.2
28/6/2017
Shiju S
Updated for VSDK3.0
0.3
16/10/2017
Shiju S
Updated for VSDK3.1
0.4
05/04/2018
Shravan Karthik
Updated for VSDK3.3

Navigation menu
