VoIP Product Guide SN411X Vo IP
User Manual: SN411X
Open the PDF directly: View PDF
.
Page Count: 28
Description Pg
Series
Product Line
Micro-Analog Telephone Adapter
Micro-Analog Fax Adapter
Residential Smart Digital BRI Telephone Adapter
Multi-Port Analog VoIP Gateway
Analog VoIP SoHo Router
ISDN BRI VoIP SoHo Router
Multi-Port Analog VoIP IAD
Multi-Port Analog IAD with Integrated WAN Access
Multi-Port ISDN VoIP IAD
Multi-Port ISDN VoIP IAD with Integrated WAN Access
Multi-Port T1/E1 VoIP IAD
High Density Analog IAD
High Density Analog Gateway
M-ATA
M-AFA
S-DTA
SN411X
SL402X
SN455X
SN452X
SN483X
SN463X
SN465X
SN4960
SN4900
SN4400
8
8
9
11
10
12
14
16
15
19
18
19
22
Model
Description
VoIP Call Capacity
Ethernet Ports
Voice Interfaces
WAN Data
Interfaces
Call Control
CODECs/Fax
Quality of Service
IP Connectivity
Features/VPN
SBC
High Precision Clk
SIP Trunking
VLAN tagging and
queuing, TOS and
Diffserv labeling
NAT, NAPT, DHCP
client/ server,
DynDNS client, DNS
SRV, VLAN, SNMP,
SNTP, PPPoE,
STUN, SYSLOG
TOS and DiffServ labeling; Active QoS with traffic scheduling and classification. Weighted fair queuing
and shaping of traffic classes with configurable tolerance; DownStreamQoS™
with dynamic restriction of inbound TCP traffic.
NAT/NAPT; DHCP server/client; DNS Relay; DynDNS client; SIP DNS SRV; VLAN .p/Q; SNMP, SNTP, WWW GUI,
RIPv1/v2, PPPoE
VLAN tagging and
queuing, TOS and
Diffserv labeling
DHCP client, DynDNS
client, DNS SRV,
VLAN, SNMP, SNTP,
WWW,PPPoE,
STUN, Syslog
SN483X
Integrated WAN
Access
VoIP Router
up to 8
2
up to 8
V.35, X.21, T1/E1,
ADSL, G.SHDSL
SN463X
Multi-Port ISDN
VoIP IAD
4 / 8
2
3 / 5
-
G.711, G.729, G.726,
G.723.1, T.38 &
G.711 Fax bypass
G.711, G.729, G.726,
G.723.1 T.38 &
G.711 Fax bypass
SIP, H.323, and MGCP
G.711, G.723.1, G.729, G.729, G.729a, G.729b,G.729ab, G,727, G.726, T.38 with G3 Fax Relay; G.711 Fax Bypass
M-ATA, M-AFA
Micro-Analog
Telephone Adapter
& Micro-Analog
Fax Adapter
2
1
1
-
SIP
Large Enterprises
Medium Enterprises
Carrier
High Precision Clocks
SIP Trunking Group
VLAN tagging and
queuing, TOS and
Diffserv labeling
SL402X
Analog VoIP
SOHO Router
4
2
1
-
SIP or MGCP
S-DTA
Smart Digital (BRI)
Telephone Adapter
2
1
1
-
SIP & H.323
IP Router, NAT/NAPT,
DHCP client,
DynDNS client, VLAN,
SNTP, PPPoE
G.711, G.729ab,
G.726, G.723.1,T.38
SN411X
Multi-Port
Analog Gateway
up to 8
2
up to 8
-
SN455X
ISDN BRI VoIP
SOHO Router
2 / 4
5 / 1
2
-
SN452X
Multi-Port Analog
VoIP Router
up to 8
2
up to 8
-
8
8
9
RReessiiddeennttiiaall VVooIIPP
Micro-Analog Telephone Adapter •
Micro-Analog Fax Adapter •
Smart Digital BRI Telephone Adapter •
11
10
12
BBrraanncchh OOffffiiccee VVooIIPP//SSooHHoo
Multi-Port Analog VoIP Gateway •
Analog VoIP SoHo Router •
ISDN BRI VoIP SoHo Router •
EEnntteerrpprriissee VVooIIPP
Multi-Port Analog VoIP IAD •
Multi-Port Analog IAD with Integrated WAN Access •
Multi-Port ISDN VoIP IAD •
Multi-Port ISDN VoIP IAD with Integrated WAN Access •
Description Pg
Enterprise Session Border
Router supporting up to
64 channels of transcoding
Enterprise Session Border
Router supporting up to
32 SIP-to-SIP calls
Series
SN5400
SN5200
21
20
Leased Line Extender over IP
2290 24
14
16
15
17
19
22
CCaarrrriieerr VVooIIPP
High Density Analog IAD •
High Density Analog Gateway •
20
21
EEnntteerrpprriissee SSeessssiioonn BBoorrddeerr RRoouutteerrss
ESBR Supporting 32 SIP-to-SIP Calls •
ESBR Supporting 64 Channels of Transcoding •
NAT/NAPT; DHCP server/client; DNS Relay; DynDNS client; SIP DNS SRV; VLAN .p/Q; SNMP, SNTP, WWW GUI, RIPv1/v2, PPPoE
Static Firewall ACLs; Filtering Ping DoS Detection; IPsec with DES/3DES/AES including Internet Key Exchange (IKE); VPN-Passthrough for PPTP/GRE
TOS and DiffServ labeling; Active QoS with traffic scheduling and classification. Weighted fair queuing and shaping of traffic classes with configurable
tolerance; DownStreamQoS™with dynamic restriction of inbound TCP traffic.
G.711, G.723.1, G.729, G.729, G.729a, G.729b, G.729ab, G,727, G.726
T.38 with G3 Fax Relay; G.711 Fax Bypass
Generic transcoding between
G.7XX codecs
Same as SN4900
SN4900
IP Density
Analog IAD
up to 32
2
up to 32
V.35, X.21, T1/E1,
ADSL, G.SHDSL
SN5400
High Density
Enterprise Sesson
Border Router
up to 64
2
N/A
Ethernet,T1/E1, G.SHDSL
or ADSL
SN5200
High Density
Enterprise Sesson
Border Router
up to 32
5
N/A
Ethernet
SN4400
High Density
Analog Gateway
up to 32
2
up to 32
Ethernet
SN465X
Multi-Port ISDN VoIP IAD
with Integrated WAN Access
4 / 8
2
3 / 5
V.35, X.21, T1/E1,
ADSL, G.SHDSL
SN4960
Multiport T1/E1
VoIP IAD
up to 120
2
4
V.35, X.21, T1/E1,
ADSL, G.SHDSL
SIP & H.323
Model
Description
VoIP Call Capacity
Ethernet Ports
Voice Interfaces
WAN Data
Interfaces
Call Control
CODECs/Fax
Quality of Service
IP Connectivity
Features/VPN
SBC
High Precision Clk
SIP Trunking
Product Line
High Precision Clocks
SIP Trunking Group
Session Border Controller (SBC)
Number of
Telephony
Ports
Max Number of
Simultaneous Calls
Telephony
interfaces
Gateway
or
Router
1 or 4 15 to 120
software upgradeable T1/E1/PRI Router
From 1 to 32 ports for analog
FXS or FXO IP connectivity
The most comprehensive
BRI VoIP solutions on
the planet
High-capacity
trunk solutions
Codec
Transcoding
1
2
3 / 5
3 / 5
2
2 / 4
4 / 8
4 / 8
BRI So
BRI So
BRI So
BRI So
Gateway
Gateway
Router
Router
up to 32 SIP-to-SIP calls
up to 64 SIP-to-SIP calls with transcoding
N/A
T1/E1/PRI
Session Border Router
Session Border Router
1
2 to 8
1 or 2
2 to 8
2 to 8
up to 32
up to 32
2
8
4
8
8
up to 32
up to 32
FXS
FXS and FXO
FXS
FXS and FXO
FXS and FXO
FXS and FXO
FXS
Gateway
Gateway
Router
Router
Router
Router
Router
Ethernet
Ports Series Pg
WAN
Egress
Series
Description
2 SN4960 1810/100/1000 Ethernet Multi-Port T1/E1 VoIP IAD
1
5
2
2
S-DTA
SN455X
SN463X
SN465X
9
12
15
17
10/100 Ethernet
10/100 Ethernet
10/100 Ethernet
Ethernet, Sync. Serial, T1/E1,
G.SHDSL or ADSL
Residential Smart Digital Telephone Adapter
ISDN BRI VoIP SoHo Router/PSTN Gateway
Multi-Port ISDN VoIP IAD
Multi-Port ISDN VoIP IAD with Integrated WAN Access
5
2
SN5200
SN5400
20
21
Ethernet
Ethernet, T1/E1, G.SHDSL
or ADSL
Enterprise Session Border Router
High Density Enterprise Session Border Router
1
1
2
2
2
2
2
M-ATA/M-AFA
SN411X
SL402X
SN452X
SN483X
SN4900
SN4400
8
11
10
14
16
19
22
10/100 Ethernet
10/100 Ethernet
10/100 Ethernet
10/100 Ethernet
Ethernet, Sync. Serial, T1/E1,
G.SHDSL or ADSL
Ethernet, Sync. Serial, T1/E1,
G.SHDSL or ADSL
Ethernet
Micro-Analog Telephone Adapter
& Micro-Analog Fax Adapter
Multi-Port Analog VoIP Gateway
Analog VoIP SoHo Router
Multi-Port Analog VoIP IAD
Multi-Port Analog IAD with Integrated WAN Access
High Density Analog IAD
High Density Analog Gateway
Business Location
Transcoding to save bandwidth
Provider
IP Network
Provider
IP Network
Provider
IP Network
IP handsets
IP handsets
Legacy handsets
Fax Machine
Legacy Handset
DSL, T1/E1, fiber,
Ethernet WAN access
Optional VPN
IPsec encryption
DSL, T1/E1, fiber,
Ethernet WAN access
Optional VPN
IPsec encryption
DSL, T1/E1, fiber,
Ethernet WAN access
Optional VPN
IPsec encryption
Local breakout/number portability
BRI/PRI/FXO
PBX
or
PABX
IP
PBX
Legacy Trunks
LAN
E1/T1/PRI Trunking: SN4960
BRI Trunking: SN4960, SN4630
FXS/FXO Trunking: SN4830, SN4520
Recommended Products
Enterprise Session Border Router: SN5400, SN5200
Recommended Products
SN4520 Analog VoIP Router with up to 8 FXS/FXO ports
SN4630 Multiport BRI So Gateway Router (up to
8 channels)
SN4650 Multiport ISDN VoIP IAD with ADSL2+ Interface
SN4400 IpChannelBank™Multi-Port FXS Analog VoIP
Gateway Router with up to 32 ports
Recommended Products
SmartNode
SmartNode
Enterprise Session Border Router
SmartNode
See page 18
See page 20
See page 14
Local Dial-In Off-Site Call Center
Provider
IP Network
PSTN
PRI/BRI/FXO
DSL, T1/E1, fiber,
Ethernet WAN access
Optional VPN
IPsec encryption
Call Center
IP Network
Ethernet
TI/E1/PRI FXS
Local PSTN Breakout Local PSTN Breakout
FXS
FXS
Fax Machine
PBX PBX
Corporate LAN
BRI PSTN Breakout: SN4554, SN4630
PRI PSTN Breakout: SN4960
FXO PSTN Breakout: SN4110, SN4900
Recommended Products
Local Dial-in
SN4960 For T1/E1/PRI VoIP
SN4900 For analog dial-in—FXO
Off-site Call Center
SN4960 For T1/E1/PRI call center connection
SN4900 For analog call center connection—FXS
Recommended Products
SmartNode
SmartNode SmartNode
SmartNode SmartNode
SmartNode
PRI, PBX SN4960
FXS PABX SN4520, SN4830
BRI PBX SN4630, SN4650
Recommended Products
See page 19
See page 18
See page 16
See page 15
See page 14
See page 12
NETWORK ACCESS—VoIP TELEPHONY
RESIDENTIAL ATAs
8
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
VoIP
Product Guide
Micro-Analog Telephone Adapter & Fax Adapter
SmartLink™M-ATA
Quickly and easily converts any phone or fax machine to VoIP for residential and telecom-
muter applications.
The SmartLink Micro Analog Telephone Adapter provides
connectivity for analog phones and faxes to a home, home
office or corporate LAN. Connecting to any analog phone,
fax or PBX, the SmartLink product is a cost effective solu-
tion for small offices and telecommuters to access Internet-
based telephone services and corporate intranet systems
across established LAN and Internet connections like DSL
and cable modems.
The M-ATA provides one Ethernet (RJ-45) port and one
FXS (RJ-11) analog phone port for quick and easy inter-
connection to the local LAN. LEDs show at-a-glance the
status of the system, LAN, WAN, and phone ports.
A full suite of IP features (DHCP) are available to maxi-
mize universal connectivity. VLAN tagging and prioritiza-
tion enables voice traffic to be handled before data traf-
fic, ensuring higher quality voice calls. Support for PPPoE
tunneling simplifies extending corporate intranet services
to telecommuters.
The user friendly web interface offers two levels of config-
uration: level one covers basic subscriber-specific parame-
ters, level two offers advanced settings for the transport
network. Configuration and firmware can be downloaded
from a centralized TFTP or HTTP server.
The M-ATA is SIP standard compliant. Analog phones
attached to the SmartLink can use advanced calling fea-
tures such as call forwarding, caller ID, 3-way calling, call
holding, call retrieval, and call transfer.
VoIP-enable your existing
fax machines
Integrated support for T.38 brings fax machines into the
low-cost world of VoIP. The M-ATA supports G3 analog fax
machines and converts fax signaling into T.38 or G.711
pass through fax for delivery over an Intranet or the
Internet. Just configure the M-ATA, plug in the fax
machine’s phone line, add a LAN connection, and the M-
ATA is ready to go!
Typical applications
FEATURES & BENEFITS
Ultra-miniature—Smallest full-function analog telephone
adapter available today!
Supports over 20 voice calling features—Call waiting, call
conference, caller ID, hotline, distinctive ring and more!
DHCP, PPPoE—Provides maximum connectivity across
firewalls and transport networks.
SIP Signaling—Deploy into any multimedia, interactive,
or softswitch network with the leading call and session
signaling protocols.
Toll Quality CODECs & T.38 fax—Uses G.723 or G.729
for low-bandwidth applications or standard G.711 or
G.726 CODECs for toll-quality voice.
Centralized management—HTTP/SNMP manageable
from any location.
ORDERING INFORMATION
M-ATA-1/E: Micro Analog Telephone Adapter; 1 x FXS RJ11; 1 x
10/100Base-TX
M-AFA-1/E: Micro Analog FAX Adapter; 1 x FXS RJ11; 1 x
10/100Base-TX,T.38 and G.711 only
SPECIFICATIONS
Voice Connectivity: 2-wire
Loopstart, RJ-11/12 • Short haul loop
1.1 km @3REN • Caller-ID Type-1/2
FSK and ITU V.23/Bell 202 generation
Connectivity: 1 10/100Base-TX
Full Duplex/Autosensing Ethernet RJ-45
Voice Processing (signalling
dependent): SIP • Voice CODECS
(G.711 A-Law/µ-Law (64 kbps); G.726
(ADPCM 40, 32, 24,16 kbps); G.723.1
(5.3 or 6.3 kbps); and G.729ab (8 kbps))
• G.168 echo cancellation • 2 parallel
voice connections • DTMF detection and
generation • Carrier tone detection and
generation • Silence suppression and
comfort noise • Configurable dejitter
buffer • DTMF in-band & out-of-band •
Configurable transmit packet length •
RTP/RTCP (RFC 1889) • STUN
Fax and Modem Support:
G.711 transparent fax • T.38 fax relay
(9.6 k, 14.4 k)
Voice Services/Features:
Anonymous CallerID block • Call blocking
• Call forward - on busy • Call forward
- selective • Call forward - unconditional
• Call hold/retrieve • Call return • Call
transfer - blind • Call transfer - with
consultation • Call waiting/retrieval •
Caller-ID • Conference drop •
Conferencing (3-way calling) •
Distinctive ring • Do not disturb •
Hotline calling • Incoming CallerID on/off
• IP URL dialing • Message waiting
indication • Self-caller ID block • Speed
dial • Voicemail message retrieval •
Warmline calling
IP Services: DHCP client • PPPoE •
Programmable static routes • ICMP redi-
rect (RFC 792); Packet fragmentation •
VLAN support 802.1p/q
Management: Browser configuration
interface • Multilevel security access •
TFTP & HTTP configuration & firmware
loading • SNMP v2 agent (MIB II and pri-
vate MIB) • Syslog support
Operating Environment:
Op. temp.: 0–40°C (32–104°F)
Op. humidity: 5–80% (non-condensing)
System: Power: 100-240 VAC
(50/60 Hz)
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 50950 • CE compliance • FCC
Part 15 Class B
Physical:
Dimensions: 3.6L x 2.1W x 0.78H in.
(9.0L x 5.3W x 1.9H cm)
Weight:0.2 lbs (0.09 kg)
Patton’s Micro-Analog Telephone Adapter provides seamless access to Internet telephony and data services. The M-ATA connects
to any broadband access provider via a cable or xDSL modem.
Corporate IP-PBX
Fax
Phone
Internet
M-ATA
M-ATA
Cable Modem
xDSL Modem
Corporate
Intranet
Connect via network,
xDSL Modem, or Cable Modem
FXS
FXS
Voice Internet
Service Provider
Smaller
than a pencil,
these adapters
can easily fit in
your shirt pocket!
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
9
NETWORK ACCESS—VoIP TELEPHONY
RESIDENTIAL ATAs
CATALOG
Network Access
Smart-DTA Residential Digital Telephone Adapter
Model S-DTA
The S-DTA brings all advantages of VoIP to ISDN users. It connects multiple terminals to its
BRI So bus, and converts 2 concurrent voice or fax calls to SIP or H.323 —at an incredibly
low price.
The Smart-DTA enables integration of ISDN network users
into a local VoIP phone service, or extends an ISDN line
of a PBX to a remote site over IP. It offers a simple end-
user configuration interface and connects both to a
PBX in point-to-point mode and an So bus in point-multi-
point mode.
Unlike most other products on the market, Patton’s intelli-
gent call routing technology does not only offer simple ISDN
to VoIP, but also advanced features like number plan adap-
tations, mappings between ISDN and SIP/H.323, manipu-
lation of call properties through regular expressions, routing
calls based on time-of-day or bearer capability criteria and
much more.
Providing power to the ISDN line, the S-DTA eliminates the
need for an external power supply to provide power to the
terminals. Gateway functions use standard CODECs such as
G.723, G.729, and T.38 fax as well as industry standard
SIP, H.323 and MGCP/IUA signaling protocols to ensure
seamless connection and compatibility for all voice services.
Quality of service (QoS) features complete the offering with
advanced voice prioritization and traffic management includ-
ing VLAN and 802.1p/Q tagging.
SPECIFICATIONS
WAN Connectivity: 10/100Base-
T Ethernet WAN • Auto-MDI-X • DHCP
Client • PPPoE Client (multi-session) •
SNTP • IP Multi-Netting
IP Quality of Service: IEEE
802.1p,TOS, DiffServ Labeling • IEEE
802.1Q,VLAN Tag insertion/deletion
(4,096 VLANs)
Management: Web-based GUI •
Fully documented CLI • Telnet and HTTP
access • TFTP configuration up- and
download • TFTP firmware upgrade •
SNMPv1 agent, MIB II and enterprise
MIB • Built-in diagnostic tools • Auto-
Provisioning—Configuration and
Firmware
Fax and Modem Support: T.38
fax over IP • Fax relay and bypass •
Modem bypass
ISDN Specification: 1 port Euro-
ISDN BRI/So RJ-45, NT • DSS-1, Q.921,
Q.931 • Point-point & point-multipoint
Voice Signaling: SIPv2 •
H.323v4 • MGCP/IUA • SIP call trans-
fer, redirect • Overlap or en-bloc dialing
• DTMF in-band & out-of-band •
Configurable call progress tones
Call Routing & Services:
Regular expression number matching •
Regular expression number manipulation
• Least Cost Routing • Number blocking
• Short-Dialing • Digit collection •
Distribution-Groups & Hunt-Groups • 2nd
call offering
Voice Processing: G.723.1
(5.3/6.3 kbps) • G.729, G.729a,
G.729ab (8 kbps) • G.726 ADPCM (16
,24, 32, 40 kbps) • G.168 echo cancella-
tion (25ms) • Transparent ISDN data •
Silence suppression and comfort noise •
Adaptive and configurable dejitter buffer
• Configurable packet length
Power & Packaging:
Dimensions: 4.2W x 1.5H x 5.0D in.
(10.6W x 3.9H x 12.7D cm) • Weight:
< 15.9 oz (450 g) • Power Consumption
< 4W
Environment: Temp.: 32–104°F
(0–40°C) • Humidity: up to 90%, non
condensing
Compliance: FCC Part 15 Class B
(US EMC) • CE per RTTE 99/5/EC (EMC
and LVD) • Safety—EN60950 • TBR-3
(ISDN BRI/So)
FEATURES & BENEFITS
Instant ISDN to VoIP Connectivity—Provides one inter-
nally powered So bus for up to 8 terminals.
Simultaneously converts 2 voice and fax calls to VoIP.
Transparent Telephony Features—Preserves ISDN fea-
tures like caller ID and name (CLIP/CLIR), call transfer,
hold, waiting, charging information (AOC) and much
more.
Outstanding Interoperability—Interoperable for voice
and fax calls with a wide variety of ISDN terminals, PBXs,
as well as SIP and H.323 soft switches and application
servers.
Full SIP and T.38 support—Complete range of industry
standard signaling protocols supported: SIPv2, H.323v4,
MGCP/IUA, ISDN, BRI, T.38, fax and modem bypass,
DTMF relay
Integrated Management and Provisioning—Web GUI for
easy end-user setup, fully automated provisioning system
and SNMP management for mass deployment
-
Network Integration
ORDERING INFORMATION
S-DTA/EUI: ISDN VoIP adapter, 1x BRI/So, 2 voice/fax calls, 1x 10/100 Ethernet, external UI power (100–240 VAC)
Patton’s Smart Digital Telephony Adapter provides seamless access to Internet telephony services for ISDN terminals. The S-DTA
connects to any LAN or broadband access provider via modem.
S-Bus
• • •
Up to 8 ISDN phones
Home LAN
PC
Internet
ISDN Home User
S-DTA
I’m John, one of Patton’s VoIP Products
Group Managers. If you have tech-
nical questions or comments con-
cerning VoIP Products, please call
me at +1 (301) 975-1000,
x182. You can also send e-mail
to jwu@patton.com.
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP GATEWAYS
10
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
VoIP
Product Guide
Analog VoIP SoHo Router
SmartLink™4020 Series
The SmartLink 4020 VoIP SoHo Router connects your LAN, standard analog phones, and fax
to any IP network. This full-featured IP router includes VPN/Security and Quality of Service
for converged low-cost sales-office/telecommuter voice data communications.
The SmartLink VoIP SoHo Router provides transparent connec-
tivity for analog phones and faxes to the world of Internet
voice. Connecting to any analog phone, fax or PBX, the
SmartLink product is an effective and flexible solution for small
offices and telecommuters to access Internet-based telephone
services and corporate intranet systems across established LAN
and Internet connections like xDSL and cable modems.
The SmartLink Model 4021 provides two RJ-45 Ethernet ports
and one FXS (RJ-11) analog phone port. The SmartLink Model
4022 provides two RJ-45 Ethernet ports and two FXS (RJ-11)
analog phone ports. Front panel LEDs quickly show at-a-glance
the status of the system, LAN, WAN, and phone ports.
A full suite of IP features (DHCP, NAT/PAT, NTP and VPN) are
available to LAN devices attached downstream. VLAN tagging
and prioritization enables voice traffic to be handled before
data traffic. Support for PPPoE and IPSEC tunneling simplifies
extending corporate intranet services to remote teleworkers.
The web interface offers two levels of configuration access for
the network operator and end user. The friendly web interface
and product labeling (Phone, LAN, WAN etc.) to help ensure
a trouble-free installation for the end user. Configuration and
firmware can be downloaded from a TFTP server.
The SmartLink is SIP standard compliant, so it can be used
with most SIP-based telephony services. Analog phones
attached to the SmartLink can use such advanced voice call-
ing features as call forwarding, caller ID, 3-way calling, call
holding, call retrieval and call transfer.
FEATURES & BENEFITS
Up to 2 FXS ports connect to a standard phone or PBX.
Quality of Service ensures voice traffic gets priority with-
out shutting down your Ethernet LAN.
Firewall, NAT, DHCP, PPPoE—Connect to any broadband
access provider, serve the whole network, and secure
your data. User configurable IP services ensure every
host is connected to the LAN.
SIP Signaling—Deploy into any multimedia, interactive,
or softswitch network with the leading call and session
signaling protocols.
Toll Quality CODECs & T.38 fax—Uses standard G.711 or
G.726 CODECs for toll-quality voice, or G.723 or G.729
for low-bandwidth applications.
ORDERING INFORMATION
SN4021/EUI/S: 1 Port FXS VoIP Gateway Router, 100–240 VAC
external power supply (PS), SIP
SN4021/EUI/M: 1 Port FXS VoIP Gateway Router, 100–240 VAC
external PS, MGCP
SN4022/EUI/S: 2 Port FXS VoIP Gateway Router, 100–240 VAC
external PS, SIP
SN4022/EUI/M: 2 Port FXS VoIP Gateway Router, 100–240 VAC
external PS, MGCP
SPECIFICATIONS
Voice Connectivity: 2-wire loop-
start, RJ-11/12 • short haul loop 1.1 km
@3REN • Caller-ID Type-1/2 FSK & ITU
V.23/Bell 202 generation
Voice Processing (signaling
dependent): SIP • MGCP (Packet
Cable NCS 1.0 & IETF MGCP 1.0) • Voice
CODECs (G.711 A-Law/µ-Law (64 kbps);
G.726 (ADPCM 40, 32, 24, 16 kbps);
G.723.1 (5.3 or 6.3 kbps); G.729ab (8
kbps)) • G.168 echo cancellation • 4
parallel voice connections • DTMF
detection & generation • carrier tone
detection & generation • silence sup-
pression & comfort noise • configurable
dejitter buffer • DTFM in-band & out-of-
band • configurable transmit packet
length • RTP/RTCP (RFC 1889)
Voice Services/Features: Call
forwarding • Call transfer • Call hold •
Call waiting • 3-way calling
IP Services: IPv4 router; RIPv1, v2
(RFC 1058 & 2453) • IP filtering •
NAPT • NTP • DHCP client & server •
PPPoE • IPSEC VPN • programmable
static routes • ICMP redirect (RFC 792);
Packet fragmentation • DiffServe/ToS set
or queue per header bits • VLAN support
802.1p/q • AES/DES/3DES encryption
Fax and Modem Support:
G.711 transparent fax & T.38 fax relay
(9.6 k, 14.4 k)
Connectivity: 2 10/100 Full
Duplex/Autosensing Ethernet RJ-45
Management: Browser configura-
tion interface • TFTP configuration &
firmware loading • SNMP v2 agent (MIB
II & private MIB)
Environment: Temp.: 32–104°F
(0–40°C) • Humidity: 5–80% (non con-
densing)
System: Power: 100–240 VAC
(50/60 Hz)
Compliance: EMC compliance:
EN55022 & EN55024 • Safety compli-
ance: EN 50950 • CE compliance • FCC
Part 15 Class B
Local PSTN + Packet Voice
Using Patton’s SmartLink VoIP SoHo routers with FXS supports
seamless access to Internet telephony and data.
Internet
Model 4022
Headquarters
PC PC
LAN
LAN/WAN QoS & Router
As a premise router, the SmartLink offers voice and com-
plete Internet access. With dual 10/100 Ethernet ports, the
SmartLink connects hosts to your LAN with VLAN tagging,
DHCP server/client, and Firewall/ACL services. Use PPPoE
and IPSEC VPN with DES, 3DES, and AES encryption and
bring your voice and data to the WAN through a single and
secure network connection.
Model 4022
QoS
NAT/NAPT
VLAN
DHCP IPsec/DES
LAN WAN
PPPoE
DHCP
11
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP GATEWAYS
visit us online
www.patton.com FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
Product Guide
VoIP
1-8 Extensions (FXS)
SmartNode 4118
SOHO/Remote Office
Carrier Softswitch PSTN Gateway
Corporate Headquarters
PBX
Central Office Headquarters
Internet
SN4520
SN4630
SN4960
10/100
Ethernet
LAN
For local/remote calling, PBX
access, or toll bypass the SN4118
VoIP Media Router provides
transparent analog access to all
connections all the time.
1-4 Extensions (FXO)
Remote/Branch Office
FEATURES & BENEFITS
Up to 8 FXS and/or FXO ports—Compact, reliable stand-
alone VoIP gateway with different port options. Supports
simultaneous voice or fax calls on all ports.
Advanced Local Call Switching—Virtual interfaces and rout-
ing tables provide industry leading flexibility in call han-
dling programming. Local call switching, soft fallback to
alternative routes. Simultaneously connects to multiple SIP
services/IP PBXs.
Complete SIP and T.38 support—Supports the complete
range of industry standard VoIP: SIP, H.323, T.38 fax,
fax and modem handling, DTMF relay. Codecs G.729,
G.723, etc.
Easy Management & Provisioning—Web-based manage-
ment, SNMP, command line interface. Automated mass
provisioning for efficient large-scale deployments.
Outstanding Interoperability—Proven integration for
voice and T.38 fax with Asterisk™, PingTel™and other
leading IP PBX systems and soft switch vendors.
Multi-Port FXS/FXO VoIP Gateway Series
SmartNode™4110 Series
The SmartNode 4110 VoIP gateway integrates up to eight legacy PSTN, PBX or standard
phone lines with next-generation IP based telephony systems. Part of the proven SmartNode
family, this product is designed to provide superior technology at an optimized cost.
The SmartNode 4110 VoIP Media Gateway supports up to
eight transparent phone calls while leveraging VoIP for
lower-cost carrier and corporate access. Connecting to any
analog phone, fax, or PBX, the SN4110 is an effective and
flexible solution for toll-bypass, remote/branch office voice
connectivity, and enhanced carrier services.
The SN4110 series is the perfect choice for phone-to-IP con-
nectivity supporting up to 8 FXS ports or a combination of 4
FXS and 2 or 4 FXO ports. With its FXS analog ports, the
SN4110 connects to any legacy telephone or PBX and pro-
vides dial-tone, ringing, and caller-ID. When equipped with
FXO ports, the local PSTN can be accessed enabling local
calling and enhanced toll-bypass applications while using a
single connected telephone. Flexible call integration allows
per-port telephone numbers, programmable call progress
tones, and distinctive ringing. With Telephony-over-IP (ToIP)
call switching, calls can automatically select the least-cost-
route while providing flexible numbering plans and end-to-
end feature transparency. PPPoE, DHCP, and VLAN offers uni-
versal IP connectivity and optional IPSEC VPN with
AES/3DES guarantees secure voice over the public network.
Patton’s SmartNode 4110 delivers the legacy phone inter-
faces, service transparency, and flexible PSTN integration
required for true converged packet voice.
ORDERING INFORMATION
SN4112/JS/EUI: 2 Port FXS VoIP Media Gateway, 100–240 VAC
external power supply (PS)
SN4114/JS/EUI: 4 Port FXS VoIP Media Gateway, 100–240 VAC
external PS
SN4116/JS/EUI: 6 Port FXS VoIP Media Gateway, 100–240 VAC
external PS
SN4118/JS/EUI: 8 Port FXS VoIP Media Gateway, 100–240 VAC
external PS
SN4114/2JS2JO/UI: 2 FXS & 2 FXO Port VoIP Media Gateway,
100–240 VAC internal PS
SN4118/4JS4JO/EUI: 4 FXS & 4 FXO Port VoIP Media Gateway,
100–240 VAC external PS
Options & Accessories
SNSW-VPN1: License Key for IPSec VPN support (DES, 3DES, AES)
SPECIFICATIONS
Capacity: Up to 8 simultaneous VoIP
or T.38 fax calls (depending on the model)
Voice Signaling: H.323v4, SIPv2
(B2BUA capable, multi-instance, simulta-
neous support of multiple registrars and
direct IP dialing) • SIP call transfer, redi-
rect • DTMF in-band & out-of-band • All
tones programmable (dial, ringing, busy)
Voice Processing:CODEC G.711
a-law/mu-law, G.723, G.729ab, • G.726,
G.727.T.38 fax relay (9.6 k, 14.4 k) •
G.711 transparent fax and bypass
Call Switching and Services:
Virtual interfaces • Regular expression
based call routing and number manipulation
• Number blocking • Short-dialing • Digit
collection, distribution and hunt groups •
Transparent line extension • Fallback
Routing: Soft fallback to alternative route(s)
FXS Connectivity: 2-wire Loopstart
on RJ-11/12 •short haul loop 1.1km
@3REN • EuroPOTS (ETSI EG201188) •
programmable AC impedance, feeding, ring
and on-hook voltage • Caller-ID FSK and
ITU V.23/Bell 202 generation
FXO Connectivity: 2-wire Loopstart
on RJ-11/12 • Programmable impedance,
ring detection, tone detection, disconnect
supervision • Caller ID detection
IP services: One 10/100 Ethernet
port • DHCP Client • access control lists
• Traffic policing • IEEE 802.1p, TOS,
DiffServ labeling • IEEE 802.1Q,VLAN tag
insertion/deletion (simultaneous support of
multiple VLANs) • IPSEC,IKE,
AES/DES/3DES Encryption (optional)
Management:Web/HTTP, CLI with
local console and remote Telnet access •
TFTP configuration & firmware loading •
SNMP MIB II and product MIB • Secure
Mass provisioning for both firmware and
unit/subscriber configuration • Built-in
diagnostic tools (trace, debug, call generator)
System: CPU Motorola MPC870 @
66MHz • Memory 32MB SDRAM/8MB
Flash • Power 100–240 VAC (50/60 Hz) •
Power dissipation 4-12W, model dependent
Environment:
Temp.: 32–104°F (0–40°C)
Humidity: 5–80% (non condensing)
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 60950 • CE compliance • FCC
Part 15 Class A • TBR21 (FXS) • RoHS
Remote Office/Branch Office Voice Extension and Access diagram
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
12
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
VoIP
Product Guide
SPECIFICATIONS
Capacity: 2 simultaneous VoIP or T.38
fax calls
ISDN Connectivity: 2 ports Euro-
ISDN BRI/So RJ-45 • 1 NT port/1 TE port
• DSS-1, Q.921, Q.931 • Point-point and
point-multipoint • Lifeline Bypass Relay
TE port to NT port • Optional QSIG support
VoIP Signaling: SIPv2 (B2BUA capa-
ble, multi-instance, supports registrar and
direct IP dialing at the same time) •
H.323v4 • MGCP/IUA • SIP call transfer,
redirect • DTMF in-band & out-of-band •
All tones programmable (dial, ringing, busy)
• Overlap or en-bloc dialing• Transparent
AOC, ECT, CLIP, CLIR, etc • speech,audio &
data (Fax Gr 4, UDI 64, • RDI 64);
Voice Processing:CODEC G.711
a-law/mu-law, G.723, G.729ab, G.726,
G.727.T.38 fax relay (9.6 k, 14.4 k) •
G.711 transparent fax and bypass
LAN and IP Services: 4-port LAN
Switch • Auto-MDI-X • IPv4,RIPv2,
ICMP • Dynamic and static NAT and
NAPT • ACL Firewall • DNS, DynDNS •
DHCP Server • SNTP Client• IPSEC, IKE,
AES/DES/3DES Encryption (hardware
accelerated, on model 4562 only)
WAN Connectivity: 10/100BaseT
Ethernet WAN • Auto-MDI-X • DHCP
Client • PPPoE Client (multi-session) • IP
Multi-Netting
Quality of Service:Voice priority •
DownStreamQoS™• Traffic management,
shaping and policing • IEEE 802.1p,TOS,
DiffServ labeling • IEEE 802.1Q,VLAN tag
insertion/deletion (simultaneous support of
multiple VLANs and PPPoE sessions)
Management:Web/HTTP, CLI with
local console and remote Telnet access •
TFTP configuration & firmware loading •
SNMP MIB II and product MIB • Secure
mass provisioning for both firmware and
unit/subscriber configuration • Built-in
diagnostic tools (trace, debug, call generator)
System: CPU Motorola MPC870 @
66MHz • Memory 32MB SDRAM/8MB
Flash • Power 100–240 VAC (50/60 Hz) •
Power dissipation 4-12W, model dependent
Environment:Temp.: 0–40°C •
Humidity: 5–80% (non condensing)
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 60950 • CE compliance • FCC
Part 15 Class A • TBR3 (ISDN) • RoHS
FEATURES & BENEFITS
Full SIP and T.38 support—Complete range of industry
standard signaling protocols supported: SIPv2, H.323v4,
MGCP/IUA, DSS1, Euro-ISDN, VN4, T.38 fax, fax and
modem bypass, DTMF relay.
Toll-Quality VoIP—Advanced traffic management and
shaping, combined with Patton’s patent-pending
DownStream QoS™enforce uninterrupted toll-quality
voice over best-effort networks.
Transparent Telephony Features—Preserves ISDN fea-
tures like caller ID and name (CLIP/CLIR), call transfer,
hold, waiting, AOC and much more. Handles complex
number manipulation for most seamless integration with
existing infrastructure.
Management & Provisioning—Built-in Web based man-
agement, SNMP, Command Line Interface and Auto-
Provisioning for automated configuration distribution and
software upgrades.
Accelerated Voice over VPN*—Encrypts voice, signaling
and data traffic over IP networks with IPsec, AES, 3DES
and IKE. Complete access router with NAT, firewall,
PPPoE, DHCP and DynDNS.
ClearConnect™dial-backup option for survivable voice and
data connectivity.
Small & Branch Office ISDN VoIP Routers
SmartNode™4552 (Standard) & 4562 (Secure)
The SmartNode 4552 and 4562 are the perfectly integrated devices to take branch office
connectivity to the next level. Combining VoIP, ISDN and IP access routing, they enable the
cost savings of VoIP while preserving speech and fax quality and reliability.
The SmartNode 4552 and 4562 enable the integration of
ISDN branch offices or remote users into corporate voice and
data networks. They attach any standard ISDN telephone or
PBX to a public or corporate VoIP service, generating lots of
communication cost savings without having to sacrifice quality.
Industry-leading call switching features include hard and soft
communication fallback to the ISDN breakout port in the
event of failure, ensuring that no services are interrupted
when migrating to VoIP.
The SmartNode 4562 adds hardware accelerated encryption
power to the impressive feature list of the SmartNode
4552, making VoIP accessible to organizations that have
been missing out on the cost-saving benefits of Internet
telephony because of security concerns.
With the ClearConnect™dial-backup option, adaptive net-
work monitoring recognizes WAN uplink failures and initiates
an ISDN dial-up connection to guarantee interrupt-free voice
and data access at all times. If the VoIP link goes down or
becomes congested, the SN4552 will switch over to the
PSTN and guarantee your call each time.
Broadband network connectivity integrates with any fixed IP,
DHCP or PPPoE service. An integrated 10/100 Ethernet LAN
switch, with advanced routing features such as multiple
VLANs, NAT, Firewall/ACL or DynDNS fulfills the require-
ments of demanding network users. Quality of Service
(QoS) features complete the offering with advanced voice
prioritization and traffic management. Patton’s patent-
pending DownStreamQoS™ensures voice without interrup-
tions even over best-effort Internet connections. ORDERING INFORMATION
SN4552/2BIS/EUI: ISDN BRI VoIP SoHo Router, 2-port,
10/100Base-T WAN, 4-port 10/100Base-T switch 100–240 VAC
external power supply
SN4562/2BIS/EUI: SmartNode ISDN Voice over VPN Router, 2 port,
10/100Base-T WAN, 4-port 10/100Base-T LAN switch, 100-240
VAC external power supply. Includes VPN license key for IPSec
VPN, IKE and Voice-Over-VPN. Hardware accelerated cryptography.
Options & Accessories
PM-BRI-EXT: External S-Bus Phantom-Power Supply 40 VDC for
Phone only (not required)
SNSW-QSIG1: License Key for QSIG support
SNSW-DB1: Dial-Backup Feature License
Network Integration
VoIP
LAN
LAN
SN4552
PSTN
Internet
VoIP/
Packet Voice
Regular Telephone Calls
Internet Access
Still make incom-
ing & outgoing
PSTN calls with
one phone
Bypass the PSTN
for lowest cost
access using VoIP
Complete data
access connects
your LAN to the
WAN
* Available on SN4562 only
13
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
visit us online
www.patton.com FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
Product Guide
VoIP
SPECIFICATIONS
WAN Connectivity: 10/100Base-
T Ethernet WAN • Auto-MDI-X • DHCP
Client • PPPoE Client (multi-session) •
SNTP • IP Multi-Netting
IP Quality of Service: IEEE
802.1p,TOS, DiffServ Labeling • IEEE
802.1Q,VLAN Tag insertion/deletion 4,096
Management: • Web-based GUI •
Fully documented CLI • Telnet and HTTP
access • TFTP configuration up- and
download • TFTP firmware upgrade •
SNMPv1 agent, MIB II and enterprise MIB
• Built-in diagnostic tools • Auto-provi-
sioning—configuration and firmware
Fax and Modem Support: •
T.38 fax over IP • Fax relay and bypass
• Modem bypass
ISDN Specification: • 2 port
Euro-ISDN BRI/So RJ-45, TE • DSS-1,
Q.921, Q.931 • Point-point & point-
multipoint
Voice Signaling: • SIPv2 •
H.323v4 • MGCP/IUA • SIP call trans-
fer, redirect • Overlap or en-bloc dialing
• DTMF in-band & out-of-band •
Configurable call progress tones
Fax and Modem Support: •
T.38 fax over IP • Fax relay and bypass
• Modem bypass
Call Routing & Services:
Regular expression number matching •
Regular expression number manipulation
• Least Cost Routing • Number blocking
• Short-Dialing • Digit collection •
Distribution- & Hunt-Groups • 2nd
call offering
Voice Processing: G.711_/A-law
• G.723.1 (5.3/6.3 kbps) • G.729,
G.729a, G.729ab (8 kbps) • G.726
ADPCM (16 ,24, 32, 40 kbps) • G.168
echo cancellation (25ms) • Transparent
ISDN data • Silence suppression and com-
fort noise • Adaptive and configurable
dejitter buffer • Configurable packet length
Power & Packaging: Dimensions:
4.2W x 1.5H x 5.0D in. (10.6W x 3.9H x
12.7D cm) • Weight:< 15.9 oz (450 g)
• Power Consumption < 4W
Environment: • Temp.: 32–104°F
(0–40°C) • Humidity: up to 90% , non
condensing
Compliance: • FCC Part 15 Class B
(US EMC) • CE per RTTE 99/5/EC (EMC
and LVD) • Safety - EN60950 • TBR-3
(ISDN BRI/So)
ISDN BRI PSTN Gateway
SmartNode™4554
The SmartNode 4554 ISDN VoIP gateway enables any IP PBX to make calls to the ISDN
PSTN. The compact, reliable stand-alone design allows enterprises to easily and flexibly inte-
grate BRI lines into their VoIP system.
The SmartNode 4554 ISDN BRI PSTN Gateway converts up
to four simultaneous phone or fax calls from SIP or H.323
to BRI ISDN. It is a compact, reliable stand-alone VoIP gate-
way for IP-based voice systems which matches up to ISDN
standards in terms of performance and quality.
Compared to PC-based solutions that combine IP PBX and a
PCI BRI card, the SN4554 has several advantages: No need
to install additional drivers or software, new services can be
installed without downtime, several SN4554 can be com-
bined and serve as redundant cluster, no ventilation or hard-
disk required, scaleable without limitation by the amount of
PCI card slots available. Also, your system administrators
don’t have to learn ISDN, as industry standard protocols like
SIP or H.323 do the job of connecting the PSTN to your
voice system.
The SN4554 perfectly integrates in today’s IP PBX systems
supporting their advanced functionality, while preserving the
majority of ISDN comfort features. Patton, as a leader in
ISDN-VoIP technology, has integrated the following ISDN
specific features into the SmartNode 4554: Advice of
Charge (AOC), Explicit Call Transfer (ECT), CLIP, CLIR, 64k
transparent data calls, support for both MSN and DID lines,
overlap dialing, call waiting, call hold.
FEATURES & BENEFITS
Compact, reliable stand-alone gateway for VoIP sys-
tems—Connects an IP PBX or other VoIP systems to the
ISDN PSTN, offering 2 BRI TE ports and 4 simultaneous
voice or fax calls.
Full SIP and T.38 support—Supports the complete range
of industry standard VoIP: SIP, H.323, T.38 fax, fax and
modem bypass, DTMF relay. Codecs G.729, G.723 etc.
Transparent Telephony Features—Preserves ISDN fea-
tures like caller ID and name (CLIP/CLIR), call transfer,
hold, waiting, AOC. Supports DID and MSN lines in
all major countries as well as complex numbering
plan manipulations.
Outstanding Interoperability—Interoperable for voice
and T.38 fax with Asterisk™, PingTel™and other leading
IP PBX systems.
ORDERING INFORMATION
SN4554/2BIS/EUI: ISDN BRI VoIP Gateway, 2 BRI ports, 2 Ethernet
ports, 4 simultaneous calls, 100–240 VAC external power supply
Options & Accessories
SNSW-VPN1: License Key for IPSec VPN support (DES, 3DES, AES)
SNSW-QSIG1: License Key for QSIG support
Application diagram
SIP phones
POTS phone
M-ATA
IP PBX
Ethernet SN4554
PSTN
ISDN (4 simul-
taneous calls)
I’m Jen, one of Patton’s Sales
Associates. Call me at
+1 301.975.1000 when you
want to purchase Patton products
or if you have questions about our
products. You can also send
e-mail to sales@patton.com.
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
14
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
VoIP
Product Guide
SPECIFICATIONS
Capacity: Up to 8 simultaneous VoIP
or T.38 fax calls (depending on the
model)
Voice Signaling: H.323v4, SIPv2
(B2BUA capable, multi-instance, simulta-
neous support of multiple registrars and
direct IP dialing) • SIP call transfer, redi-
rect • DTMF in-band & out-of-band • All
tones programmable (dial, ringing, busy)
Voice Processing: CODEC G.711
a-law/mu-law, G.723, G.729ab, •
G.726, G.727. T.38 fax relay (9.6 k, 14.4
k) • G.711 transparent fax and bypass
Call Switching and
Services: Virtual interfaces •
Regular expression based call routing and
number manipulation • Number blocking
• Short-dialing • Digit collection, distri-
bution and hunt groups • Transparent line
extension • Fallback Routing: Soft fall-
back to alternative route(s)
FXS Connectivity: 2-wire Loopstart
on RJ-11/12 •short haul loop 1.1km
@3REN • EuroPOTS (ETSI EG201188) •
programmable AC impedance, feeding, ring
and on-hook voltage • Caller-ID FSK and
ITU V.23/Bell 202 generation
FXO Connectivity: 2-wire Loopstart
on RJ-11/12 • Programmable impedance,
ring detection, tone detection, disconnect
supervision • Caller ID detection
Data Services: Two 10/100
Ethernet ports • Complete IP access router
• DHCP Client & server • Packet frag-
mentation • Static firewall, NAT, NAPT
RFC 1631 access control lists • DMZ port
• IPSEC, IKE, AES/DES/3DES Encryption
(optional, hardware accelerated)
Quality of Service: Voice priority
• DownStreamQoS™• Traffic manage-
ment, shaping and policing • IEEE
802.1p,TOS, DiffServ labeling • IEEE
802.1Q,VLAN tag insertion/deletion
(simultaneous support of multiple VLANs)
Management: Web/HTTP, CLI with
local console and remote Telnet access
• TFTP configuration & firmware loading
• SNMP MIB II and product MIB •
Secure Mass provisioning for both
firmware and unit/subscriber configura-
tion • Built-in diagnostic tools (trace,
debug, call generator)
System: CPU Motorola MPC875 @
66MHz • Memory 32MB SDRAM/8MB
Flash • Power 100–240 VAC (50/60
Hz) • Power dissipation 4-12W, model
dependent
Temperature: 32–104°F
(0–40°C)
Humidity: 5–80%, non-condensing
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 60950 • CE compliance • FCC
Part 15 Class A • TBR21 (FXS) • RoHS
FEATURES & BENEFITS
Up to 8 analog ports—Compact, reliable stand-alone
VoIP gateway with different port options. Supports simul-
taneous voice or fax calls on all ports.
Toll-Quality VoIP—Advanced traffic management and
shaping, combined with Patton’s patent-pending
DownStream QoS™enforce uninterrupted toll-quality
voice over best-effort networks.
Advanced Local Call Switching—Virtual interfaces and
routing tables provide industry leading flexibility in call
handling programming. Local call switching, soft fallback
to alternative routes. Simultaneously connects to multiple
SIP services/IP PBXs.
Complete SIP and T.38 support—Supports the complete
range of industry standard VoIP: SIP, H.323, T.38 fax,
fax and modem handling, DTMF relay. Codecs G.729,
G.723, and so on.
Easy Management & Provisioning—Web-based manage-
ment, SNMP, command line interface. Automated mass
provisioning for efficient large-scale deployments.
Outstanding Interoperability—Proven integration for
voice and T.38 fax with Asterisk™, PingTel™and other
leading IP PBX systems and soft switch vendors.
Multi-Port FXS/FXO VoIP Gateway Router
SmartNode™4520 Series
The SmartNode 4520 VoIP Gateway Router combines IP routing, VPN/Security, and Quality
of Service for up to 8 transparent voice, fax, and data over any IP or PSTN network. Leverage
low-cost packet-voice and IP services for complete branch office voice and data connectivity.
Connect with confidence using the SmartNode 4520 Series
Router. Integrating a complete enterprise router with local PSTN
and remote packet-voice, the SN4520 supports eight simulta-
neous calls for a new standard in toll-bypass, remote/branch
office connectivity, and enhanced carrier services.
Perfect for the remote office, branch office, or PBX/switch
extension, the SmartNode 4520 integrates all your voice,
fax, and LAN traffic for seamless and secure networking.
With its FXS analog ports the SN4520 connects to any
legacy telephone or PBX and provides dial-tone, ringing,
and caller-ID. When equipped with FXO ports, the local
PSTN can be accessed enabling local calling and enhanced
toll-bypass service.
With dual 10/100 Ethernet ports, the SN4520 provides
guaranteed Quality of Service while passing LAN traffic at
wire-speed. Voice traffic is prioritized while LAN/IP traffic
shaping permits efficient access to the Internet and corpo-
rate networks. As a complete enterprise router, the
SN4520 supports DHCP, NAT, Firewall/ACL, and PPPoE
clients. While optional IPSEC VPN and VLAN features tun-
nel data and AES/3DES ensures secure voice over the
public network.
ORDERING INFORMATION
SN4522/JS/EUI: 2 port FXS VoIP Gateway Router, 100–240 VAC
external power supply (PS)
SN4522/JO: 2 port FXO Gateway Router
SN4524/JS/EUI: 4 port FXS VoIP Gateway Router
SN4522/JO: 4 port FXO Gateway Router
SN4526/4JS2JO: 4 port FXS 2 port FXO Gateway Router
SN4526/JS/EUI: 6 port FXS VoIP Gateway Router
SN4528/JS/EUI: 8 port FXS VoIP Gateway Router
SN4524/2JS2JO/EUI: 2 port FXS, 2 Port FXO Gateway Router
SN4528/4JS4JO/EUI: 4 port FXS, 4 Port FXO Gateway Router
Options & Accessories
SNSW-VPN1: License Key for IPSec VPN support (DES, 3DES,AES)
Remote Office/Branch Office Voice Extension and Access
10/100
LAN
LAN/DSL/Cable
Access
1-8 Extensions (FXS)
Local Calling
End-to-End Packet Voice
Local Breakout
1-4 Local Telco
Extensions
QoS
NAT/NAPT
Firewall/ACL
IPSEC/AES
VLAN
DHCP
LAN WAN
Internet
PPPoE
DHCP
15
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
visit us online
www.patton.com FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
Product Guide
VoIP
Multi-Port ISDN VoIP IAD
SmartNode™4630 Series BRI So Gateway Router
The award-winning SmartNode 4630, with up to 5 BRI ports and 8 simultaneous voice
channels, is the best way to connect ISDN networks to the world of voice over IP. It enables
small offices/remote offices to lower communication costs and provides business-class
Internet telephony for demanding ISDN users.
The SmartNode 4630 series are the multi-port ISDN BRI
models of the proven market-leading SmartNode VoIP prod-
uct family. The available 3 and 5 BRI/So port configurations
fit the requirements of small and medium enterprises looking
for a cost-efficient way to network PBX systems on multiple
sites or connect to a public Internet telephony service.
The extra BRI port solves many VoIP network integration prob-
lems encountered in real-world installations. The port can syn-
chronize the gateway and provide error-free ISDN data and fax
transmissions, and it can be used as a fallback or local-break-
out port for optimized call-routing and risk-free operation. With
the life-line relay, the port even enables integration of an ISDN
emergency terminal powered from the public ISDN.
Like every SmartNode, the 4630 Series models are state-of-
the-art VoIP gateways that also provide complete access
routing and IP security features. Use the SmartNode as CPE
or access router on broadband access, and you can benefit
from industry leading Quality of Service (QoS) features
ensuring a voice quality unmatched by any IP-phone or gate-
way on the market.
With the ClearConnect™dial-backup option, adaptive net-
work monitoring recognizes WAN uplink failures and initiates
an ISDN dial-up connection to guarantee interrupt-free voice
and data access at all times. If the VoIP link goes down or
becomes congested, the SN4630 will switch over to the
PSTN and guarantee your call each time.
The SmartNode 4630 is the solution for service providers
and network integrators looking for a VoIP product that
matches up to ISDN standards in terms of features and qual-
ity. SmartNode products provide seamless network integra-
tion, continuous trouble-free operation and cost effective
deployment to protect your investments for the future.
SPECIFICATIONS
Voice Signaling: SIPv2 • H.323v4
• MGCP/IUA • SIP call transfer, redirect
• Overlap or en-bloc dialing • DTMF in-
band, out-of-band • Configurable tones)
Call Routing & Services:
Regular expression number matching •
Regular expression number manipulation
• Least Cost Routing • Number blocking
• Short-Dialing • Digit collection •
Distribution- and Hunt- Groups
ISDN: 3/5 BRI So ports, RJ-45 •
NT/TE configurable per port • Built-in
line power on each port (total 4W) •
DSS1, Q.921, Q.931. NTT-64 • Point-
point and point-multipoint • Lifeline
Bypass Relay • Optional QSIG support*
Voice Processing: G.711m/A-law
• G.723.1 (6.4Kbps) • G.729, 729a,
729ab (8Kbps) • G.726 (16 ,24, 32, 40
Kbps) • G.168 echo cancellation (25ms)
• 4/8 simultaneous low-bandwidth voice
or T.38 fax calls • Transparent ISDN data
• Silence suppression and comfort noise
• Adaptive and configurable dejitter
buffer • Configurable packet length
IP Quality of Service:Voice pri-
ority, DownStreamQoS • Traffic
Management, shaping policing • IEEE
802.1p, IEEE 802.1Q, 4096 VLANs (Tag
insertion/deletion),TOS, DiffServ Labeling
Connectivity: Two 10/100Base-T
Ethernet ports •Auto-MDIX • DHCP
Client • PPPoE Client (multi-session) •
IP Multi-Netting,VLAN, Secondary IP •
IPv4, RIPv2, ICMP • Dynamic and static
NAT and NAPT • ACL Firewall • DNS,
DynDNS • DHCP Server • SNTP Client •
Optional IPSec VPN (DES,3DES, AES)
Management: Web-based GUI •
Fully Documented CLI • Telnet and HTTP
access • TFTP configuration up- and
download • TFTP firmware upgrade •
SNMPv1 agent (MIB II and private MIB)
• Built-in diagnostic tools • Secure
Auto-Provisioning
Power & Packaging: Desktop
metal chassis • Dimension: 280/39/157
mm (W/H/D) • Weight: < 600g •
Power Consumption < 10W
Operating Environment:
Op. temp.: 32–104°F (0–40°C)
Op. humidity: up to 90% , non condensing
Compliance: FCC Part 15 Class A
(US EMC) • CE per RTTE 99/5/EC (EMC
and LVD) • Safety–EN60950 • TBR-3
(ISDN BRI/So)
FEATURES & BENEFITS
3/5 Ports Quality ISDN VoIP—3 or 5 ISDN BRI So ports, 4
or 8 low-bandwidth voice or T.38 fax calls. Advanced adap-
tive traffic management and shaping for maximum voice
quality. Voice prioritization and DownStreamQoS™
High Precision Unit—Supports wireless DECT PBX and
improves fax performance sd
Complete Access Routing—Two 10/100 Ethernet ports
with auto MDI-X. Access router with NAT, Firewall, PPPoE,
DHCP, DynDNS & VPN with IPsec*
Full VoIP protocol support—SIPv2, H.323v4, MGCP/IUA,
ISDN, DSS1, QSIG*, T.38, fax & modem bypass, DTMF relay.
Interoperable for voice & T.38 fax with leading SIP serv-
ice providers, soft-switch vendors, and Asterisk™IP-PBX.
*Requires optional license.
ORDERING INFORMATION
Multi-Port ISDN VoIP IAD with Dual Fast Ethernet Ports, H.323
and SIP, Passthrough Relay, and External Power Supply
SN4634/3BIS/EUI: 4 VoIP Call; 3 ISDN So Ports
SN4635/3BIS/EUI: 8 VoIP Call; 5 ISDN So Ports; High Precision
5ppm clock source
SN4638/5BIS/EUI: 8 VoIP Call; 5 ISDN So Ports
SN4639/3BIS/EUI: 8 VoIP Call; 5 ISDN So Ports; High Precision
5ppm clock source
SW Options
SNSW-VPN1: License Key for IPsec VPN (DES, 3DES,AES), IKE and
Voice-over-VPN
SNSW-QSIG1: License Key for QSIG
SNSW-DB1: Dial-Backup Feature License
NNoottee::Please indicate country specific power cord at time of ordering.
LAN Ethernet
PBX
WAN Ethernet, external
broadband access
Local breakout & life-line
Up to 8 VoIP calls
LAN to WAN QoS Routing and Security
Up to 5 BRI So for ISDN
terminals and/or PBX
ISDN Network
Internet Data
Voice
SmartNode 4638
Application—Network Integration
Whether used as a gateway or as an access router, the SmartNode 4630 provides excellent VoIP and IP QoS features for seam-
less network integration. All BRI ports are configurable to be TE or NT, you can thus connect your telco line(s) as well as a PBX
or ISDN terminals. Terminals are powered with the built-in power supply, eliminating the need for an external box. For business
class IP telephony at the tip of your fingers, the SmartNode 4630
is more than just talk!
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
16
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
VoIP
Product Guide
FXS/FXO VoIP IAD with WAN Access
SmartNode™4830 Series Analog Gateway Router
The SmartNode 4830 Series is the most cost-effective VoIP IAD with integrated WAN modem
in the industry. It lets you connect up to 8 phone lines with best-in-class voice quality and
QoS mechanisms for voice, fax and data.
Application—Remote Office/Branch Office Voice Extension and Access
FEATURES & BENEFITS
Integrated WAN Access—ADSL2+, G.SHDSL, T1/E1,
V.35/X.21 WAN access options. Two 10/100 Ethernet ports.
Access router with NAT, Firewall, PPPoE, DHCP, and DynDNS.
Full VoIP Protocol Support —SIPv2, H.323v4, T.38, fax &
modem bypass, G.723, G.729, G.726, G.711, echo cancel-
lation, silence compression, comfort noise, DTMF relay
FXS, FXO, or Combinations—Up to 8 FXS ports connect
to your standard telephone or PBX. 2 or 4 FXO ports
allow local PSTN connections. Programmable call routing
and switching.
Maximum Voice Quality —Advanced adaptive traffic
management for maximum voice quality. Voice prioritiza-
tion and DownStreamQoS™.
Management & Provisioning—Web-based management,
SNMP, command line interface, & auto-provisioning for
automated configuration & SW upgrades.
SPECIFICATIONS
Capacity: Up to 8 simultaneous VoIP
or T.38 fax calls (depending on the model)
Voice Signaling: H.323v4, SIPv2
(B2BUA capable, multi-instance, simulta-
neous support of multiple registrars and
direct IP dialing) • SIP call transfer, redi-
rect • DTMF in-band & out-of-band • All
tones programmable (dial, ringing, busy)
Voice Processing:CODEC G.711
a-law/mu-law, G.723, G.729ab, •
G.726, G.727. T.38 fax relay (9.6 k, 14.4
k) • G.711 transparent fax and bypass
Call Switching & Services:
Virtual interfaces • Regular expression
based call routing and number manipula-
tion • Number blocking • Short-dialing
• Digit collection, distribution and hunt
groups • Transparent line extension •
Fallback Routing: Soft fallback to alterna-
tive route(s)
FXS Connectivity: 2-wire Loopstart
on RJ-11/12 •short haul loop 1.1km
@3REN • EuroPOTS (ETSI EG201188) •
programmable AC impedance, feeding, ring
and on-hook voltage • Caller-ID FSK and
ITU V.23/Bell 202 generation
FXO Connectivity: 2-wire Loopstart
on RJ-11/12 • Programmable impedance,
ring detection, tone detection, disconnect
supervision • Caller ID detection
Data Services:Two 10/100 Ethernet
ports • Complete IP access router • DHCP
Client & server • Packet fragmentation •
Static firewall, NAT, NAPT RFC 1631
access control lists • DMZ port • IPSEC,
IKE,AES/DES/3DES Encryption (optional,
hardware accelerated)
Quality of Service:Voice priority •
DownStreamQoS™• Traffic management,
shaping and policing • IEEE 802.1p,TOS,
DiffServ labeling • IEEE 802.1Q,VLAN
tag insertion/deletion (simultaneous sup-
port of multiple VLANs)
Optional WAN interfaces:
X.21/V.35 Frame Relay (8 PVCs);
RFC1490, FRF.12 fragmentation; LMI,
Q.933D,ANSI 617D, Gang of Four; PPP,
PAP, CHAP, LCP, IPCP) • T1/E1 (ITU-T
G.703,ANSI T1.403; & AMI, B8ZS,
HDB3), PPP • ADSL2+ (Annex A, B, I, J,
I, M, U-R2) • G.SHDSL (G.991.2,Annex
A, B, F, G, Up to 5.7Mbps, 8 PVCs, QoS)
Management:Web/HTTP, CLI with
local console and remote Telnet access •
TFTP config & firmware loading • SNMP
MIB II and product MIB • Secure mass
provisioning for firmware & unit/sub-
scriber config • Built-in diagnostic tools
(trace, debug, call generator)
System: CPU Motorola MPC875 @
66MHz • Memory 32MB SDRAM/8MB
Flash • Power 100–240 VAC (50/60 Hz)
• Power dissipation 4–12W, model
dependent
Environment:Temp.: 0–40°C •
Humidity: 5–80% (non condensing)
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 60950 • CE compliance • FCC
Part 15 Class A • TBR21 (FXS) • RoHS
WAN
IPsec/AES
PPPoE
DHCP
QoS
NAT/NAPT
Firewall/ACL
VLAN
DHCP
LAN
Integrated ADSL2+,
X.21/V.35 or T1/E1
WAN uplink
10/100
LAN
1–8 Extensions (FXS)
1–4 Local Telco Extensions
Data Network
Model 4838
Local Calling VoIP Calling
End-to-End Packet Voice
ORDERING INFORMATION
SN4832/JSX*/EUI: 2 Port FXS with integrated WAN
SN4834/JSX*/EUI: 4 Port FXS with integrated WAN
SN4836/JSX*/EUI: 6 Port FXS with integrated WAN
SN4838/JSX*/EUI: 8 Port FXS with integrated WAN
SN4834/2JS2JOX*/EUI: 2 FXS, 2 FXO with integrated WAN
SN4836/ 4JS2JOX*/EUI: 4 FXS, 2 FXO with integrated WAN
SN4832/JOX*/EUI: 2 FXO with integrated WAN
SN4834/JOX*/EUI: 4 FXO with integrated WAN
SN4838/4JS4JOX*/EUI: 4 FXS, 4 FXO with integrated WAN
Sync Serial Cables
1205-25M/35M: DB-25 male to M/34 male, for V.35 port
1205-25M/35F: DB-25 male to M/34 female, for V.35 port
EMEM216006: DB-15 male to DB-15 male, for X.21 port
ADSL Splitters
5A-1: Single-ort ADSL Splitter
Options & Accessories
SNSW-VPN1: License key for IPsec VPN suppport (DES, 3DES, AES)
*
x
= Interface options:
C
=V.35 (DB-25F),
D
=X.21 (DB-15F),
K
=E1 (RJ-48C),
T
=T1 (RJ4-8C),
G
=G.SHDSL (RJ-11),
AA
= ADSL Annex A,
AB
= ADSL Annex B
WAN options with ADSL 2+ annexes
The SmartNode™ 4830 Series IADs let you deliver voice-
over-IP over virtually any WAN access link type. The series
offers models with combinations of 2 to 8 analog FXS
phone ports and 2 or 4 FXO ports. Each model has two
Ethernet ports and an integrated WAN access modem—
choose from X.21, V.35, T1, E1, G.SHDSL or ADSL2+ to
match the given access link with greatest flexibility. Quality
of Service (QoS) features include advanced voice prioritiza-
tion, traffic management, multiple VLANs and PVCs.
DownStreamQoS™ensures voice without interruptions even
over best-effort internet connections. Packet labeling accord-
ing to 802.1p, TOS and DiffServ enable integration into
managed QoS networks.
The SN4830 is the solution for service providers and network
integrators looking for the seamless integration of analog
phones and PBXs into converged VoIP-Data networks. It
ensures easy setup and continuous trouble-free operation and
cost effective deployment. The support of the leading VoIP
signaling protocols ensures interoperability with third-party
equipment and protects your investments for the future.
17
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
visit us online
www.patton.com FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
Product Guide
VoIP
Multi-Port ISDN VoIP IAD with Integrated WAN Access
SmartNode™4650 Series BRI So Gateway Router
The SmartNode 4650, with up to 5 BRI ports and 8 simultaneous voice channels, is the best
way to connect ISDN networks to the world of voice over IP. Featuring an integrated WAN
broadband modem, it delivers converged voice and data services that exceed ISDN standards.
The SmartNode™ 4650 Series are the multi-port ISDN BRI
models of the proven market leading SmartNode VoIP prod-
uct family. The available 3 and 5 BRI/So port configurations
fit the requirements of small and medium enterprises look-
ing for a cost-efficient way to network PBX systems on mul-
tiple sites or connect to a public Internet telephony service.
The integrated WAN access module enables you to connect
the SmartNode 4650 virtually anywhere! Connected to
your choice of ADSL2+, G.SHDSL, E1, T1 or V.35/X.21
broadband access, it offers complete access routing, IP secu-
rity features as well as industry leading Quality of Service
(QoS). The QoS features ensure a voice quality unmatched
by any IP-phone or gateway on the market, and together
with IGMP v2/v3, they make the SmartNode 4650 defi-
nitely ‘triple-play ready’—all in a single box.
The extra BRI port solves many VoIP network integration prob-
lems encountered in real-world installations. The port can syn-
chronize the gateway and provide error-free ISDN data and fax
transmissions, and it can be used as a fallback or local-break-
out port for optimized call-routing and risk-free operation. With
the life-line relay, the port even enables integration of an ISDN
emergency terminal powered from the public ISDN.
The SmartNode 4650 is the solution for service providers
and network integrators looking for a VoIP product that
matches up to ISDN standards in terms of features and qual-
ity. SmartNode products provide seamless network integra-
tion, continuous trouble-free operation and cost effective
deployment to protect your investments for the future.
SPECIFICATIONS
Capacity: 4 (SN4654 models) or 8
(SN4658 models) simultaneous VoIP or
T.38 fax calls
ISDN Connectivity: • 5 ports
Euro-ISDN BRI/So RJ-45 • All config-
urable TE or NT side • Built-in line
power • DSS-1, Q.921, Q.931 • Point-
point and point-multipoint • Lifeline
Bypass Relay • Optional QSIG support
VoIP Signaling:SIPv2 (B2BUA
capable, multi-instance, supports registrar
and direct IP dialing at the same time) •
H.323v4 • MGCP/IUA • SIP call trans-
fer, redirect • DTMF in-band & out-of-
band • All tones programmable (dial,
ringing, busy) • Overlap or en-bloc dial-
ing• Transparent AOC, ECT, CLIP, CLIR, etc
• speech, audio & data (Fax Gr 4, UDI
64, • RDI 64);
Voice Processing:CODEC G.711
a-law/mu-law, G.723, G.729ab, •
G.726, G.727. T.38 fax relay (9.6 k, 14.4
k) • G.711 transparent fax and bypass
Management:Web/HTTP, CLI with
local console and remote Telnet access •
TFTP configuration & firmware loading •
SNMP MIB II & product MIB • Secure
mass provisioning for both firmware and
unit/subscriber configuration • Built-in
diag tools (trace, debug, call generator)
Data Services:Two 10/100 Ethernet
ports • Complete IP access router • DHCP
Client & server • Packet fragmentation •
Static firewall, NAT, NAPT RFC 1631
access control lists • DMZ port • IPSEC,
IKE,AES/DES/3DES Encryption (optional,
hardware accelerated)
Quality of Service:Voice priority
• DownStreamQoS™• Traffic manage-
ment, shaping and policing • IEEE
802.1p,TOS, DiffServ labeling • IEEE
802.1Q,VLAN tag insertion/deletion
(simultaneous support of multiple VLANs
and PPPoE sessions)
Optional WAN interfaces:•
X.21/V.35 Frame Relay (8 PVCs);
RFC1490, FRF.12 fragmentation; LMI,
Q.933D,ANSI 617D, Gang of Four; PPP,
PAP, CHAP, LCP, IPCP) • T1/E1 (ITU-T
G.703,ANSI T1.403; & AMI, B8ZS,
HDB3), PPP • ADSL2+ (Annex A, B, I, J,
I, M, U-R2) • G.SHDSL (G.991.2,Annex
A, B, F, G, Up to 5.7Mbps, 8 PVCs, QoS)
System: CPU Motorola MPC870 @
66MHz • Memory 32MB SDRAM/8MB
Flash • Power 100–240 VAC (50/60 Hz)
• Power dissipation 4-12W, model
dependent
Environment:Temp.: 0–40°C •
Humidity: 5–80% (non condensing)
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 60950 • CE compliance • FCC
Part 15 Class A • TBR3 (ISDN) • RoHS
FEATURES & BENEFITS
Integrated WAN Access—ADSL2+, G.SHDSL.bis, T1/E1,
V.35/X.21 WAN access options. Two 10/100 Ethernet ports.
Access router with NAT, Firewall, PPPoE, DHCP, & DynDNS.
Outstanding Interoperability—Proven integration for
voice and T.38 fax with leading soft switch vendors; long
track record of ISDN interoperability in most countries.
Transparent Telephony Features—Preserves ISDN fea-
tures like caller ID and name (CLIP/CLIR), call transfer,
hold, waiting, AOC. Supports DID and MSN lines in
all major countries as well as complex numbering
plan manipulations.
Toll-Quality VoIP—Advanced traffic management and
shaping, combined with Patton’s patent-pending
DownStream QoS™ enforce uninterrupted toll-quality
voice over best-effort networks.
Management & Provisioning—Web-based management,
SNMP, command line interface. Automated provisioning
for easy large-scale deployments.
ClearConnect™dial-backup option for survivable voice and
data connectivity.—With the ClearConnect™dial-backup
option, adaptive network monitoring recognizes WAN
uplink failures and initiates an ISDN dial-up connection to
guarantee interrupt-free voice and data access at all times.
If the link goes down or becomes congested, the SN4650
will switch over to PSTN and guarantee your call each time.
ORDERING INFORMATION
SN4654/3BISx*/EUI: 3 BRI/So 4-call VoIP Router, Dual 10/100
Ethernet, Internal 90–250V power
SN4655/3BISx*/EUI: 3 BRI/So 4-call VoIP Router, Dual 10/100
Ethernet, Internal 90–250V power; High Precision Unit
SN4658/5BISx*/EUI: 5 BRI/So 8-call VoIP Router, Dual 10/100
Ethernet, Internal 90–250V power
SN4659/5BISx*/EUI: 5 BRI/So 8-call VoIP Router, Dual 10/100
Ethernet, Internal 90–250V power; High Precision Unit
Sync Serial Cables
1205-25M/35M: DB-25 male to M/34 male, for V.35 port
1205-25M/35F: DB-25 male to M/34 female, for V.35 port
EMEM216006: DB-15 male to DB-15 male, for X.21 port
ADSL Splitters
5A-1: Single-port ADSL Splitter
Software options (ordered separately)
SNSW-VPN1: License Key for IPsec VPN (DES, 3DES,AES), IKE and
Voice-over-VPN
SNSW-QSIG1: License Key for QSIG
SNSW-DB1: Dial-Backup Feature License
*
x
= Interface options:
C
=V.35 (DB-25F),
D
=X.21 (DB-15F),
K
=E1 (RJ-48C),
T
=T1
(RJ4-8C),
G
=G.SHDSL (RJ-11),
AA
= ADSL Annex A,
AB
= ADSL Annex B WAN options
Application diagram
Up to 5 BRI So for ISDN
terminals and/or PBX
PBX
Local breakout & life-line
LAN Ethernet SmartNode 4650
Up to 8 VoIP calls
LAN to WAN QoS Routing and Security
Integrated broadband access Internet
ISDN Network
Data
Voice
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
18
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
VoIP
Product Guide
LAN GigE
PBX
WAN GigE or T1/E1
broadband access
Local PSTN breakout
Up to 120 VoIP calls
LAN to WAN QoS Routing and Security
Up to 4X T1/E1/PRI
PSTN
Internet Data
Voice
SmartNode 4960
T1/E1/PRI
FEATURES & BENEFITS
Up to 120 simultaneous voice or T.38 fax calls with one
to four T1/E1/PRI ports and dual Gigabit Ethernet ports.
Use any CODEC or fax on any port, any time.
Universal SIP and T.38 support—Softswitch certified sig-
naling support between all T1 RBS CAS, ISDN PRI, Q.SIG,
SIP, H.323 and MGCP/IUA protocols.
Secure Toll-Quality VoIP—DownStreamQoS and Voice-over-
VPN with adaptive traffic management and shaping for
maximum voice quality and secure voice communication.
High Precision Unit—Supports wireless DECT PBX and
improves fax performance sd
Management & Provisioning—Web-based management,
SNMP, command line interface. Automated provisioning
for easy large-scale deployments.
ClearConnect™dial-backup option for survivable voice and
data connectivity.
Multi-Port T1/E1 VoIP Integrated Access Device
SmartNode™4960
The award-winning SmartNode 4960 integrates with legacy telephony gear to deliver VoIP
and data services with QoS and encrypted-voice VPNs. The SmartNode 4960 comes with
four T1/E1/PRI ports, two GigE ports, and supports up to 120 simultaneous VoIP calls, mak-
ing it the ideal choice for low-cost, secure, prioritized communications.
Providing a high-density seamless link between the circuit-
switched telephone network and voice-over-IP, the SN4960 is
ideal for PBX business trunking or corporate VoIP access.
Offering up to four software configurable T1/E1/PRI interfaces
the SN4960 connects to any switch, PBX and data network
with up to 120 simultaneous calls using SIP, T1, E1 or PRI sig-
naling. The dual gigabit Ethernet ports connect to the network
for the highest throughput with its integrated QoS router. With
its built-in CSU/DSU, any T1/E1 port can be selected as a
WAN port for a truly integrated voice and data access
Like every SmartNode, the SN4960 delivers toll-quality
voice with all industry standard CODECs including low-band-
width G.723/G.729. Business class services are supported
with T.38 fax, fax bypass and modem bypass features.
With the ClearConnect™dial-backup option, adaptive net-
work monitoring recognizes WAN uplink failures and initiates
an ISDN dial-up connection to guarantee interrupt-free voice
and data access at all times. If the VoIP link goes down or
becomes congested, the SN4960 will switch over to the
PSTN and guarantee your call each time.
The SmartNode 4960 is ready for SIP TLS and SRTP through
software upgrades. Exclusive DownStreamQoS™ and Voice-
over-VPN features give the clear advantage of uninterrupted
and secure voice communication for any call today.
ORDERING INFORMATION
SN4960/1E15V/UI: SmartNode Hi-Cap 1 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 15 VoIP Channels, upgradeable to 30 calls.
SN4960/1E24V/UI: SmartNode Hi-Cap 1 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 24 VoIP Channels, upgradeable to 30 calls.
SN4960/1E30V/UI: SmartNode Hi-Cap 1 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 30 VoIP Channels, non-upgradeable.
SN4960/4E15V/UI: SmartNode Hi-Cap 4 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 15 VoIP channels, field upgradeable to a max
of 60 channels.
SN4960/4E24V/UI: SmartNode Hi-Cap 4 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 24 VoIP channels, field upgradeable to a max
of 60 channels.
SN4960/4E30V/UI: SmartNode Hi-Cap 4 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 30 VoIP channels, field upgradeable to a max
of 60 channels.
SN4960/4E48V/UI: SmartNode Hi-Cap 4 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 48 VoIP channels, field upgradeable to a max
of 60 channels.
SN4960/4E60V/UI: SmartNode Hi-Cap 4 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 60 VoIP channels, non-upgradeable
SN4960/4E96V/UI: SmartNode Hi-Cap 4 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 96 VoIP channels, field upgradeable to a max
of 120 channels.
SN4960/4E120V/UI: SmartNode Hi-Cap 4 T1/E1/PRI VoIP IAD, 2x
GigEthernet, UI power, 120 VoIP channels.
Options & Accessories
SNSW-49V6: 6 channel Voice Upgrade Key for SN4960 VoIP IADs.
Software expansion for additional voice channels.
SNSW-VPN2: Software option for IPsec VPN, including DES/3DES
and AES encryption, IKE and Voice-Over-VPN.
SNSW-QSIG2: Support for ISDN Q.SIG.
SNSW-DB2: Dial-Backup Feature License
SPECIFICATIONS
Voice Connectivity:Up to four
software selectable T1/E1/PRI ports •
Signalling support (ISDN DSS-1, NI-2,
Q.SIG; CAS Robbed bit loop and ground
start, E&M, immediate, wink, double wink)
• SIPv2 & MGCP/IUA, H.323v4 • ISDN
AOC/ECT • ISDN speech, audio & data
(Fax Gr 4, UDI 64, • RDI 64); ISDN sup-
plementary services
Voice processing:Codec G.711 a-
law/mu-law, G.723, G.729ab, • G.726,
G.727.T.38 fax relay (9.6 k, 14.4 k) •
G.711 transparent fax and bypass
Call routing and services:
Regular expression matching and manipu-
lation; number blocking; short-dialing; digit
collection, distribution and hunt groups.
Data interfaces: Dual
10/100/1000 TX Ethernet Ports •
Autosensing • Auto-MDI • Full-duplex
IP Routing: Complete IP access router
• DHCP Client & server • Packet frag-
mentation • Static firewall, NAT, NAPT
RFC 1631 access control lists
IP Quality of Service: Voice pri-
ority, DownStreamQoS • traffic manage-
ment, shaping policing • IEEE 802.1p,
TOS, DiffServ labeling • IEEE 802.1Q,
VLAN tag insertion/deletion 4,096
Management: Web/HTTP, CLI with
local console & remote Telnet access •
TFTP configuration & firmware loading •
SNMP MIB II and product MIB • Secure
autoprovisioning for firmware & unit/sub-
scriber configuration • Built-in diagnostic
tools (trace, debug, call generator)
Environment: Temp: 32–104°F
(0–40°C); Humidity: Up to 90% (non
condensing)
Power: 100–240 VAC (50/60 Hz)
Power consumption:15W
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 60950 • CE compliance • FCC
Part 15 Class A; Part 68; CS-03
Remote Office/Branch Office Voice Extension and Access diagram
19
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
NETWORK ACCESS—VoIP TELEPHONY
BUSINESS CLASS VoIP ROUTERS
visit us online
www.patton.com FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
Product Guide
VoIP
ORDERING INFORMATION
SN4912/JS/RUI: IpChannel Bank 12 Port FXS
SN4916/JS/RUI: IpChannel Bank 16 Port FXS
SN4924/JS/RUI: IpChannel Bank 24 Port FXS
SN4932/JS/RUI: IpChannel Bank 32 Port FXS
SN4912/JSX*/RUI: IpChannel Bank 12 Port FXS WAN Uplink
SN4916/JSX*/RUI: IpChannel Bank 16 Port FXS WAN Uplink
SN4924/JSX*/RUI: IpChannel Bank 24 Port FXS WAN Uplink
SN4932/JSX*/RUI: IpChannel Bank 32 Port FXS WAN Uplink
Options & Accessories
SNSW-VPN1: License Key for IPSec VPN support (DES, 3DES, AES)
SN4912/JO/RUI: IpChannel Bank 12 Port FXO
SN4916/JO/RUI: IpChannel Bank 16 Port FXO
SN4924/JO/RUI: IpChannel Bank 24 Port FXO
SN4932/JO/RUI: IpChannel Bank 32 Port FXO
SN4912/JOX*/RUI: IpChannel Bank 12 Port FXO,WAN uplink
SN4916/JOX*/RUI: IpChannel Bank 16 Port FXO,WAN uplink
SN4924/JOX*/RUI: IpChannel Bank 24 Port FXO,WAN uplink
SN4932/JOX*/RUI: IpChannel Bank 32 Port FXO,WAN uplink
Note::48VDC or split 48VDC/UI power options available.
*X = Interface options: C=V.35, D=X.21, K=E1,T=T1, Fi=Fiber,AYx=ADSL, G=G.SHDSL
Typical applications SPECIFICATIONS
Capacity: 12, 16,24, 32 simultaneous
VoIP calls
Voice Signaling:SIPv2 H.323v4
(simultaneously with B2BUA capability) •
SIP call transfer, redirect • DTMF in-band
& out-of-band • All tones programmable
(dial, ringing, busy)
Voice Processing:CODEC G.711 a-
law/mu-law, G.723,G.729ab, • G.726,
G.727.T.38 fax relay (9.6 k, 14.4 k) •
G.711 transparent fax and bypass
Call Switching and
Services: Regular expression based
call routing and number manipulation •
Number blocking • Short-dialing • Digit
collection, distribution and hunt groups •
Transparent line extension
FXS Connectivity: 2-wire
Loopstart on 50pin (12 to 24 channels) or
64pin (32 channels) Telco connector
•short haul loop 1.1km @3REN •
EuroPOTS (ETSI EG201188) • program-
mable AC impedance,feeding, ring and
on-hook voltage • Caller-ID FSK and ITU
V.23/Bell 202 generation
FXO Connectivity: 2-wire
Loopstart on 50pin (12 to 24 channels) or
64pin (32 channels) Telco connector •
Programmable impedance, ring detection,
tone detection, disconnect supervision •
Caller ID detection
Data Services: Two 10/100 Ethernet
ports • Complete IP access router • DHCP
Client & server • Packet fragmentation •
Static firewall, NAT, NAPT RFC 1631
access control lists • DMZ port
Quality of Service: Voice priority •
DownStreamQoS™ • Traffic manage-
ment, shaping and policing • IEEE 802.1p,
TOS, DiffServ labeling • IEEE 802.1Q,
VLAN tag insertion/deletion 4,096
Optional WAN interfaces:
X.21/V.35 Frame Relay (8 PVCs);
RFC1490, FRF.12 fragmentation; LMI,
Q.933D,ANSI 617D, Gang of Four; PPP,
PAP, CHAP, LCP, IPCP) • T1/E1 (ITU-T
G.703,ANSI T1.403; & AMI, B8ZS, HDB3)
• ADSL2+ (Annex A, B, I, J, I, M, U-R2) •
G.SHDSL (G.991.2,Annex A, B, F, G, Up to
5.7Mbps, 8 PVCs, QoS)
Management: Web/HTTP, CLI with
local console and remote Telnet access
• TFTP configuration & firmware loading
• SNMP MIB II and product MIB •
Secure auto-provisioning for both
firmware and unit/subscriber configura-
tion • Built-in diagnostic tools (trace,
debug, call generator)
System: CPU Motorola MPC875 @
133 MHz • Memory 32MB
SDRAM/8MB Flash
Power: 100–240 VAC (50/60 Hz) •
Power dissipation:> 22W (60W max,
model SN4932/JS/RUI)
Environment: Temp.: 0–40°C •
Humidity: 5–80% (non condensing)
Compliance: EMC compliance:
EN55022 and EN55024 • Safety compli-
ance: EN 50950 • CE compliance • FCC
Part 15 Class A
FEATURES & BENEFITS
Optional Integrated WAN uplink—Choose from V.35,
X.21, T1/E1, ADSL and G.SHDSL data interfaces in addi-
tion to the two Ethernet ports.
Complete Access Routing—Two 10/100 Ethernet ports
with auto MDI-X. Access router with NAT, Firewall, PPPoE,
DHCP, DynDNS, multiple VLANs & VPN with IPSec*.
Secure Toll-Quality VoIP—DownStreamQoS and Voice-over-
VPN with adaptive traffic management and shaping for
maximum voice quality and secure voice communication.
12, 16, 24 or 32 FXS or FXO ports—Simultaneous voice
or fax calls on all ports. Advanced local call switching.
Full SIP and T.38 support—Supports the complete range
of industry standard VoIP: SIP, H.323, T.38 fax, fax and
modem bypass, DTMF relay. Codecs G.729, G.723 etc.
Outstanding Interoperability—Interoperable for voice
and T.38 fax with leading SIP service providers, soft-
switch vendors and Asterisk™IP-PBX.
Use FXS models for call center applications and FXO for
PSTN analog trunking.
Multi-Port FXS & FXO IAD
SmartNode™4900 Series
The SmartNode 4900 is the perfect VoIP gateway for applications requiring 12 to 32 concurrent
analog voice/fax calls within a single redundant solution.
The SmartNode 4900 is the ideal solution for service
providers and enterprises requiring high-density analog con-
nections for converged Internet-Telephony. Call centers,
multi-tenant-units and PBX/switch extensions can now
access the low-cost benefits of packet voice while WAN, data
and VPN features permit direct access the IP network with
full upstream and DownStream QoS™.
The SN4900 supports 12 to 32 simultaneous VoIP calls over
standard two-wire FXS connections. The analog ports are pre-
sented on a single Amphenol telco connector for convenient
wiring closet connection. Local LAN connectivity is presented
via dual 10/100 Ethernet ports. Traffic can be routed out
either port for load-balancing and redundancy. Dual-redun-
dant power supplies protect against equipment down-time.
Seamless and secure network integration with fixed IP, DHCP
or PPPoE. Complete access routing features include NAT/NAPT,
Firewall, DynDNS and the optional IPSec VPN feature license
offer secure data.
Optional WAN uplink modules, available in V.35/X.21,
T1/E1, and xDSL options, eliminate the need for extra net-
work termination devices and extra cost.
Quality of Service (QoS) features included advanced voice
prioritization and traffic management. DownStreamQoS™
ensures voice without interruptions even over best-effort inter-
net connections. Packet labeling according to 802.1p, TOS
and DiffServ enable integration into managed QoS networks.
Integrated GUI and Command Line, front panel status and
call load indicators and a full suite of management interfaces
ensure efficient setup, continuous trouble-free operation and
cost-effective deployment.
IP/VoIP
SIP server/Call Center software
FXS or
FXO
FXS or
FXO SN4900
SN4900
IP/VoIP
Bulk FXS or FXO Extension
Call Center/Analog Subscriber Integration
FEATURES & BENEFITS
IP Routing—RIP v1/v2, VRRP, Policy Based Routing,
Loopback Interface
VPN Tunnels—Standard IPsec with AH and ESP ensures
maximum protection when traversing unsecured networks.
Strong Encryption—DES, 3DES, and AES offer standards-
based encryption algorithms from 56 to 256 bits.
QoS/CoS Profiles—Configurable burst tolerance,
bandwidth guarantees plus reduce per flow traffic jit-
ter as required by the application
Configurable Security Profiles—Built-in IP address and
IP port filtering, ACLs and DoS attack detection creates
a comprehensive security environment.
Enhanced IP services—DNS resolver and relay, NAT/NAPT,
dynamic DNS, and DHCP server, ease integration.
10/100 Ethernet—1 10/100 WAN Ethernet port and 4
10/100 LAN Ethernet ports
Enterprise Session Border Router
SmartNode™5200
The SmartNode™5200 is the perfect Session Border Router for Enterprises requiring univer-
sal SIP trunking services for up to 32 SIP sessions.
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
Application diagram
ORDERING INFORMATION
SSNN55220000//3322BB//EEUUII: SmartNode Enterprise Session Border Router,
1x10;100Base-TX WAN, Integrated 4-port 10/100Base-TX LAN
Switch; 32 SIP-to-SIP Calls without Transcoding, External UI Power
SPECIFICATIONS
Capacity: 32 Simultaneous
SIP Sessions
Data Services: 1 10/100BaseT
WAN port, 4 10/100 LAN Ethernet Ports
• Complete IP Access Router • DHCP
Client & server • Packet Fragmentation
Static Firewall • NAT, NAPT RFC 1631
Access Control Lists • DMZ Port
Quality of Service: Voice priority
• DownStreamQoS™• Traffic manage-
ment, shaping and policing • IEEE 802.1p,
TOS, DiffServ labeling • IEEE 802.1Q,
VLAN tag insertion/deletion (4096 VLAN
IDs, multiple VLAN support
Voice Signaling: SIPv2 • SIP call
transfer, redirect • DTMF in-band & out-
of-band • All tones programmable (dial,
ringing, busy)
Management: Web/HTTP, CLI with
local console and remote Telnet access •
TFTP configuration & firmware loading •
SNMP MIB II and product MIB • Secure
autoprovisioning for both firmware
and unit/subscriber configuration •
Built-in diagnostic tools (trace, debug,
call generator)
Call Switching and
Services: Regular expression based
call routing and number manipulation •
Number blocking • Short-dialing • Digit
collection, distribution and hunt groups •
transparent line extension
Voice Processing: CODEC G.711
a-law/mu-law, G.723, G.729ab • G.726,
G.727.T.38 fax relay • G.711 transparent
fax and bypass
System: CPU Motorola MPC875 @
133 MHz • Memory 32MB SDRAM/8MB
Flash
Dimensions
7.3W x 1.6H x 6.1D in.
(18.5H x 4.1W x 15.5D cm)
Weight: 24.4 oz./400g
Power: 100–240 VAC (50/60 Hz)
Temperature: 32–104°F (0–40°C)
Humidity: 5–80% (non condensing)
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
NETWORK ACCESS—VoIP TELEPHONY
T1/FT1 NETWORK SOLUTIONS
20 CATALOG
Network Access
Universal SIP trunking service lets businesses with PBXs use
VoIP and other real-time media communications over an
end-to-end IP connection. The SmartNode 5200 connects
the Enterprise’s LAN to an Internet telephony service
provider (ITSP), creating a single conduit for multimedia
components including voice, video and data.
The SN5200 includes SIP-aware NAT and access controlled
lists (ACLs) for maintaining secure communications when
SIP traffic crosses the Enterprise edge.
The SN5200 enables IP-based data routing for enterprises in
need of a single integrated access device to support their IP
data and voice connectivity needs. Routing capabilities
include RIP v1/v2, virtual router redundancy protocol
(VRRP), Loopback interfaces as well as advanced techniques
like policy based routing (PBR).
SN5200 provides advanced features like NAT/ NAPT in addi-
tion to ACLs and PBR for security and QoS that keep mali-
cious traffic from effecting bandwidth requirements of PBR-
marked essential traffic. Downstream QoS ensures impor-
tant voice and fax calls don’t get bogged down by such
resource hungry lower priority TCP traffic as FTP downloads.
SmartWare™is equipped with a link status based routing
function. This function, together with SIP registrar, enables
survivable telephony services to be deployed between intra-
office SIP clients in case there is a failure at the SIP provider.
Combined with a PSTN fall-back scheme, the SN5200 is
capable of routing calls over PSTN in the event of a SIP
trunking provider problem.
Provider
IP Network
IP handsets
DSL, T1/E1, fiber, Ethernet WAN access
Optional VPN IPsec encryption
IP
PBX
LAN
SmartNode 5200
The SN5200 enables Universal SIP Trunking and provides a single Integrated Access Device with
features like IP Routing, Redundancy, Security and a SIP registrar for survivability. The
Enterprise can use a single conduit for both its voice and data traffic thus making the most cost
efficient use of its resources. By using two SN5200 with VRRP enabled an Enterprise could con-
nect to two ITSP and provide for failover incase the primary SIP provider trunk has a problem.
Enterprise Session Border Router with Transcoding
SmartNode™5400
The SN5400 is the perfect Session Border Router for Enterprises requiring Integrated Access,
Universal SIP trunking and Transcoding services inside a single platform
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
Universal SIP trunking service lets businesses with PBXs use
VoIP and other real-time media communications over an
end-to-end IP connection. The SmartNode 5400 connects
the Enterprise’s LAN to an Internet telephony service
provider (ITSP), creating a single conduit for multimedia
components including voice, video and data.
The SN5400 includes SIP-aware NAT and access controlled
lists (ACLs) for maintaining secure communications when
SIP traffic crosses the Enterprise edge.
The SN5400 enables IP-based data routing for enterprises in
need of a single integrated access device to support their IP
data and voice connectivity needs. Routing capabilities
include RIP v1/v2, virtual router redundancy protocol
(VRRP), Loopback interfaces as well as advanced techniques
like policy based routing (PBR).
The SN5400 enables transcoding for up to 64 sessions. As
VoIP becomes more popular in Enterprise deployments,
more VoIP traffic within Enterprise LANs will be uncom-
pressed as a result of more available bandwidth whereas
that traffic on the WAN will be compressed to save band-
width. SN5400 transcoding between any VoIP codecs
enables this optimal utilization of transport network at both
sides of the Enterprise border.
The SN5400 provides advanced features like NAT/ NAPT in
addition to ACLs and PBR for security and QoS that keep mali-
cious traffic from effecting bandwidth requirements of PBR-
marked essential traffic. Downstream QoS ensures important
voice and fax calls don’t get bogged down by such resource
hungry lower priority TCP traffic as FTP downloads.
Whether you connect to your service provider using G.SHDSL
or via a PRI connection, the SN5400 provides a single inte-
grated platform for all your connectivity needs. You could
also use the Gigabit Ethernet port to connect to an all IP-
based service provider.
visit us online
www.patton.com
Application diagram
FEATURES & BENEFITS
Enterprise Session Border Router with Transcoding—
Enables up to 64 transcoding sessions between codecs
Secure Enterprise – Enable VPN, NAT/NAPT, Access
Control Lists with Downstream QoS to ensure the most
efficient use of your bandwidth
IP Routing—RIP v1/v2, VRRP, policy based routing,
loopback interface
Universal Interface support for WAN—Support for
G.SHDSL, PRI and Gigabit Ethernet interfaces for your
WAN needs
VPN Tunnels—Standard IPSec with AH and ESP ensures
maximum protection when traversing unsecured net-
works.
Configurable Security Profiles—Built-in IP address and IP
port filtering, ACLs and DoS attack detection creates a
comprehensive security environment.
ORDERING INFORMATION
SSNN55440000//3322PPGG//UUII: SmartNode Session Border Router, 2xGigabit
Ethernet, 32 SIP-SIP calls with generic Transcoding or 64 SIP-SIP
calls without Transcoding, 1 Pair G.SHDSL interface, Internal UI power
SSNN55440000//6644PPGG//UUII: SmartNode Session Border Router, 2xGigabit
Ethernet, 64 SIP-SIP calls with generic Transcoding or 128 SIP-SIP
calls without Transcoding, 1 Pair G.SHDSL interface, Internal UI power
SSNN55440000//3322PP22GGSS//EEUUII: SmartNode Session Border Router, 2xGigabit
Ethernet, 32 SIP-SIP calls with generic Transcoding or 64 SIP-SIP
calls without Transcoding, 2 Pair G.SHDSL interface, External UI power
SSNN55440000//6644PP22GGSS//EEUUII: SmartNode Session Border Router, 2xGigabit
Ethernet, 64 SIP-SIP calls with generic Transcoding or 128 SIP-SIP
calls without Transcoding, 2 Pair G.SHDSL interface, External UI power
SPECIFICATIONS
Capacity: 128 Simultaneous
Transcoding Sessions
Voice Connectivity: Signaling
support (ISDN DSS-1, NI-2, Q.SIG, 5ESS,
CAS Robbed bit loop and ground start,
E&M, immediate, wink, double wink) •
SIPv2, H.323v4 • ISDN AOC/ECT • ISDN
speech, audio & data (Fax Gr 4, UDI 64, •
RDI64) • ISDN supplementary Services
Voice processing: Codec G.711
a-law/mu-law, G.723, G.729ab, •
G.726, G.727. T.38 fax relay (9.6 k, 14.4
k) • G.711 transparent fax and bypass •
128 ms echo cancellation
IP Routing: Complete IP access
router • DHCP Client & server • Packet
fragmentation • Static firewall, NAT,
NAPT RFC 1631 access control lists
Quality of Service: Voice priority
• DownStreamQoS™• Traffic manage-
ment, shaping and policing • IEEE
802.1p,TOS, DiffServ labeling • IEEE
802.1Q,VLAN tag insertion/deletion
(4096 VLAN IDs, multiple VLAN support)
Management: Web/HTTP, CLI with
local console and remote Telnet access
• TFTP configuration & firmware loading
• SNMP MIB II and product MIB •
Secure autoprovisioning for both
firmware and unit/subscriber configura-
tion • Built-in diagnostic tools (trace,
debug, call generator)
Environment
Temp: 32–104°F (0–40°C)
Humidity: Up to 90% (non condensing)
Power: 100–240 VAC (50/60 Hz)
Power consumption:15W
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
21
NETWORK ACCESS—VoIP TELEPHONY
T1/FT1 NETWORK SOLUTIONS
CATALOG
Network Access
WAN
LAN
SmartNode 5400
The SN5400 enables Universal SIP Trunking and provides a
single Integrated Access Device with features like IP Routing,
Redundancy, Security and a SIP registrar for survivability.
In addition, the SN5400 enables Transcoding between two
networks to most optimally support the bandwidth require-
ments. E.g. The internal of the network (LAN) could function
on G.711 and the WAN side could then be on G.729 enabled
by transcoding.
By using two SN5400 with VRRP enabled an Enterprise could
connect to two ITSP and provide for failover incase the primary
SIP provider trunk has a problem.
Provider
Softswitch
OSS/BSS
Backbone
FEATURES & BENEFITS
12, 16, 24 or 32 FXS—Simultaneous voice or fax calls
on all ports. Advanced local call switching.
Full SIP and T.38 support—Supports the complete range
of industry standard VoIP: SIP, H.323, T.38 fax, fax and
modem bypass, DTMF relay. Codecs G.729, G.723 etc.
Secure Toll-Quality VoIP—DownStreamQoS and Voice-over-
VPN with adaptive traffic management and shaping for
maximum voice quality and secure voice communication.
Complete Access Routing—Two 10/100 Ethernet ports
with auto MDI-X. Access router with NAT, Firewall, PPPoE,
DHCP, DynDNS, multiple VLANs & VPN with IPsec*
Outstanding Interoperability—Interoperable for voice
and T.38 fax with leading SIP service providers, soft-
switch vendors and Asterisk™IP-PBX
IpChannel Bank Multi-Port FXS Gateway
SmartNode™4400 Series
The IpChannel Bank is the perfect VoIP gateway for applications requiring 12 to 32 concur-
rent analog voice/fax calls within a single redundant solution.
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
The SmartNode 4400 Series IpChannel Bank is the perfect
business solution for applications requiring 12 to 32 concur-
rent analog voice/fax calls. The IpChannel Bank transforms
any PBX system, analog call-center application, or ISP MDU
service into a state-of-the-art packet-voice system without
requiring costly equipment replacement or upgrades.
There are several models in the SN4400 Series—ranging
from 12 to 32 FXS ports. The SN4400 Series supports key
industry-standard VoIP signaling protocols such as SIP,
H.323, and T.38 Fax Relay—plus fax-bypass and modem-
bypass. This ensures interoperability with the leading soft
switches and VoIP services.
Built-in Quality of Service (QoS) features include voice prior-
itization and traffic management via configurable service-
policy profiles. Patton’s advanced DownStreamQoS ensures
clear, uninterrupted voice--even over best-effort networks
such as the Internet. Packet classification using 802.1p,
TOS, and DiffServ makes integration with existing managed
QoS networks easy.
Create custom security profiles for a comprehensive security
environment. IPsec in the SmartNode 4400 Series delivers
data integrity, authentication, anti-replay and data confiden-
tiality. Firewall capabilities include access control lists (ACLs),
IP-address and port filtering, protection against denial of serv-
ice (DoS) attacks, and use of second Ethernet port as DMZ.
Offering easy setup, reliable operation, and third-party inter-
operability on a proven platform, the SN4400 Series
IpChannel Bank sits at the core of cost-effective business
solutions. The investment protection you need for the future
is here today.
visit us online
www.patton.com
ORDERING INFORMATION
SmartNode™High Density VoIP Gateway,
2x10/100bTX, H.323 and SIP
SSNN44441122//JJSS//UUII: High Density Gateway, 12 FXS, UI Power
SSNN44441166//JJSS//UUII: High Density Gateway, 16 FXS, UI power
SSNN44442244//JJSS//UUII: High Density Gateway, 24 FXS, UI Power
SSNN44443322//JJSS//UUII: High Density Gateway, 32 FXS, UI Power
SSNN44441122//JJSS//4488: High Density Gateway, 12 FXS, 48V DC power
SSNN44441166//JJSS//4488: High Density Gateway, 16 FXS, 48V DC Power
SSNN44442244//JJSS//4488: High Density Gateway, 24 FXS, 48V DC Power
SSNN44443322//JJSS//4488: High Density Gateway, 32 FXS, 48V DC Power
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
NETWORK ACCESS—VoIP TELEPHONY
IPCHANNEL BANK MULTI-PORT FXS GATEWAY
22 CATALOG
Network Access
SPECIFICATIONS
Capacity: 12, 16, 24, 32 simultaneous
VoIP calls
Data Services:Two 10/100 Ethernet
ports • Complete IP access router • DHCP
Client & server • Packet fragmentation •
Static firewall, NAT, NAPT RFC 1631
access control lists • DMZ port
Quality of Service: Voice priority
• DownStreamQoS™ • Traffic manage-
ment, shaping and policing • IEEE 802.1p,
TOS, DiffServ labeling • IEEE 802.1Q,
VLAN tag insertion/deletion (4096 VLAN
IDs, multiple VLAN support
Management: Web/HTTP, CLI with
local console and remote Telnet access •
TFTP configuration & firmware loading •
SNMP MIB II and product MIB • Secure
autoprovisioning for both firmware and
unit/subscriber configuration • Built-in
diagnostic tools (trace, debug, call generator)
FXS Connectivity: 2-wire
Loopstart on 50pin (12 to 24 channels) or
64pin (32 channels) Telco connector •
Short haul loop 1.1km @3REN •
EuroPOTS (ETSI EG201188) •
Programmable AC impedance, feeding,
ring and on-hook voltage • Caller-ID FSK
and ITU V.23/Bell 202 generation
Voice Signaling: SIPv2 H.323v4
(simultaneously with B2BUA capability) •
SIP call transfer, redirect • DTMF in-band
& out-of-band • All tones programmable
(dial, ringing,busy)
Call Switching and Services:
Regular expression based call routing and
number manipulation • Number blocking •
Short-dialing • Digit collection, distribution
and hunt groups • transparent line extension
System: CPU Motorola MPC875 @
133 MHz
Voice Processing:CODEC G.711
a-law/mu-law, G.723, G.729ab • G.726,
G.727.T.38 fax relay • G.711 transparent
fax and bypass
Dimensions: 19-in. rack-mount chas-
sis: 48.3W x 4.44H x 30.50D cm
Weight: 4.1 kg
Temperature: 32–104°F (0–40°C)
Humidity: 5–80% (non condensing)
Compliance: EMC compliance: EN
55022 and EN 55024 • Safety compli-
ance: EN 50950 • CE compliance • FCC
Part 15 Class A • RoHS
* Specifications subject to change without notice.
Nx 32 FXS E1/T1
SN4400 SN4960
IP
Multi-
Dwelling Unit
Sales: +1 301-975-1000
Fax: +1 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
Enterprise FXS concentration and extension over IP and T1/E1
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
23
NETWORK ACCESS—VoIP TELEPHONY
IPCHANNEL BANK MULTI-PORT FXS GATEWAY
CATALOG
Network Access
Legacy MTU/MDU migration to VoIP based networks
The SN4400 IPChannel Bank offers an ideal way for Service
Providers (SP) to migrate their existing networks to standards based
VoIP networks. By using the Telco Connector port, the existing clos-
et wiring in the MTU/MDU can be utilized and the customer’s analog
devices can now be connected to feature rich VOIP-based networks.
This protects the investments that have been made in analog equip-
ment and wiring by various MTU/MDU facilities and leverages it fur-
ther by connecting these facilities to the Service Provider’s
VoIPbased networks.
Above all, it allows simple and transparent migration process for
enterprise and residential customers in the MTU/MDU facilities.
The SN4400 Series IpChannel Bank can be used with a T1/E1
gateway to extend a T1 or E1 line over IP and split it into FXS
ports—providing operators and enterprise network administra-
tors with a simple and cost effective option to provide a large
number of FXS ports in a remote location.
PSTN
Sales: +1 301-975-1000
Fax: 301.869.9293 • E-mail: sales@patton.com
visit us online
www.patton.com
FAST Delivery From Your AUTHORIZED DISTRIBUTOR!
NETWORK ACCESS—VoIP TELEPHONY
LEASED-LINE EXTENDER OVER IP
24 CATALOG
Network Access
Application diagram
FEATURES & BENEFITS
Service Providers—Offer the same old analog leased
line service on the Internet with highly reduced capital
and operational expenditure even as you migrate away
from TDM
Enterprises—Enjoy the benefits of using leased lines
on Enterprise IP networks without the hassles of tele-
phone wires
Security—Connections are always on and securely
encrypted with IPsec and IKE
Quality of Service—Advanced traffic management
and shaping, combined with Patton’s DownStream
QOS™enforce uninterrupted toll-quality voice over
best-effort networks
Access Router Functions—Integrated access router
functions with NAT, firewall, ACL, PPPoE, DHCP, DynDNS
and VLAN
Easy to Monitor and Control—In-band (RS-232 console
port) and out-of-band management capabilities (Telnet
and HTTP)
Leased-Line Extender over IP
SmartNode™2290 Series
The SmartNode™2290 series saves on leased-line costs when extending up to four audio
lines between two locations using best-effort networks, even the Internet.
The 2290 Series Leased Line Extender is a SmartNode that
enables end users to deploy Leased-line applications like an
always-on connection even on the Internet. Using only one
Extender on each side, audio Leased-Lines can be transported
over a packet-based network. This means: Internet connection
in two different locations around the world is sufficient to estab-
lish up to four Leased-Lines between these two locations!
Many Service Providers are moving away from their TDM
backbone networks and their Analog leased lines offerings.
The 2290 series offers Service Providers a chance to offer
the same services like Always ON connections on Analog
leased lines over their IP based networks.
To Enterprises, it offers a chance to move to best effort net-
works like the Internet and enjoy the same benefits of using
Analog Leased Lines on the existing LAN network they have
already deployed. In addition, it allows them to use LANs to
provide Intra-Office Always ON lines instead of a dedicated
web of telephone wires.
After installation, the connection between two 2290
extenders can establish immediately. It also reestablishes
after any network disruption. The connection can also be
secured with Hardware-Accelerated 3DES or AES encryp-
tion end-to-end between the extenders , preventing wire-
tapping and making Patton the right choice for security
conscious enterprises.
ORDERING INFORMATION
2292/EUI: 2 VoIP leased line channels, External
Universal Input Power Supply
2294/EUI: 4 VoIP leased line channels, External
Universal Input Power Supply
SPECIFICATIONS
Capacity: 2 VoIP lines (2292) • 4
VoIP lines (2294)
Audio connectivity: 2-wire RJ-
11 • Bandwidth 4kHz • Impedance 600-
ohm • Narrow Band FXS style hybrid
transmit/receive
Data Services: Two 10/100
Ethernet ports • Complete IP access
router • DHCP Client & server • Packet
fragmentation • Static firewall, NAT,
NAPT RFC 1631 access control
lists • DMZ port • IPsec, IKE,
AES/DES/3DES Encryption
Quality of Service: Audio priority
• DownStreamQoS™ • Traffic manage-
ment, shaping and policing • IEEE 802.1p,
TOS, DiffServ labeling • IEEE 802.1Q,
VLAN tag insertion/deletion (simultaneous
support of multiple VLANs)
Voice Signaling: SIPv2 (B2BUA
capable, multi-instance, simultaneous
support of multiple registrars and direct IP
dialing) • SIP call transfer, redirect •
DTMF in-band & out-of-band
Voice Processing: CODEC G.711
a-law/mu-law, G.723, G.729ab, •
G.726, G.727.
Management: Web/HTTP, CLI with
local console and remote Telnet access •
TFTP configuration & firmware loading •
SNMP MIB II and product MIB • Secure
Mass provisioning for both firmware and
unit configuration • Built-in diagnostic
tools (trace, debug, call generator)
System: CPU Motorola MPC875
@66MHz • Memory 32MB
SDRAM/8MB Flash • Power 100–240
VAC (50/60Hz) • Power dissipation 4-
8W, model dependent
Temperature: 32–104°F (0–40°C)
Humidity: 5–80%, non-condensing
Compliance: CE Compliance
Corporate Headquarters
Patton Electronics Company
7622 Rickenbacker Drive
Gaithersburg, Maryland, 20879 USA
tel: +1 301 975 1000 • fax: +1 301 869 9293
web: www.patton.com • e-mail: sales@patton.com
EMEA
Patton-Inalp Networks AG
Meriedweg 7
CH-3172 Niederwangen, Switzerland
tel: +41 31 985 25 25 • Fax: +41 31 985 25 26
web: www.patton-inalp.com • e-mail: europe@patton.com
India Headquarters
PE-Inalp Networks Private Ltd
Old No. 14 and New No.6
Brahadambal Road, Nungambakkam High Road
Chennai: 600 034, India
tel: +91 44 45490395/6/7 • fax: +91 44 4549.0394
web: www.patton.co.in • e-mail: sales@patton-india.com
Regional Contacts
USA & Canada
tel: +1 301 975 1000
fax: +1 301 869 9293
e-mail: sales@patton.com
Australia/New Zealand
tel: +61 2 9620 8164
fax: +1 413 803 6235
e-mail: australia@patton.com
Western Europe
United Kingdom
tel: +41 31 985 25 25
fax: +41 31 985 25 26
e-mail: europe@patton.com
Central Europe/CIS
tel: +1 241 912 1218
eFax: +1 240 597 8442
e-mail: ce@patton.com
MENA
tel: +961 4 712 691 or 2
fax: +1 413 832 9194
e-mail: mena@patton.com
Asia/Pacific
tel: +84 9090 21213
fax: +1 208 728 1210
e-mail: asia@patton.com
Latin America/Caribbean
tel: +1 240 912 1219
fax: +1 301 869 9293
e-mail: americas@patton.com
07MVOIP-PG4
