The world’s
best-selling electric floor heating brand
™
The world’s
best-selling electric floor heating brand
TEMPO
SUBMITTAL SHEET WSC-1102
WARMUP INC.
USA: us@warmup.com
Tel.: 1-888-927-6333
www.warmup.com
CANADA: ca@warmup.com
Tel.: 1-888-592-7687
www.warmup.ca
PRODUCT CODE
TEMPO-CW-01
PRODUCT DESCRIPTION
Suitable with all Warmup underfloor heating systems, the
Tempo thermostat allows you to control the temperature of your
underfloor heating system, to bring comfort, warmth and luxury
to your home.
The Tempo was designed with simple features and accessible
interface. Not unlike the original iPods, you dial and click to select
the periods and temperature.
The Tempo provides all the efficient programming features you
require, at a very competitive price.
ADVANTAGES
• Easycontrolwithdialandsliders
• Compatibility: suitable with all Warmup electric underfloor
heating systems.
• Clearscreendisplayingprogramdetails: the Tempo’s
Proportional Adaptive Function learns the time it takes to
warm the room and activates the heating early so it is up to
the right temperature when needed.
• Simplicity: the Tempo enables you to choose the time as
easily as you would with a watch or clock and quickly set
heating programs .
• Stylishandcontemporarydesign
• ProportionalAdaptiveLearning
• AvailableinWhite
• 3-YearsWarranty
LIMITATIONS
The Tempo is not a transformer. It must be powered accordingly
to the load it will switch and operate.
INPUT VOLTAGE 120V / 240V
MAX LOAD 15A
DIMENSIONS (H/W/D) 90 x 113 x 23mm (from wall)
BATTERY BACKUP 3 months (CR2032 battery provided)
SENSORS Floor/ Air
SENSOR TYPE NTC10K 3m long (can be extended to 50m)
IP RATING IP20
INSTALLATION DEPTH 35mm back box
DISPLAY SIZE 45 X 50mm
COMPATIBILITY Ideal for electric underfloor heating systems
SPECIFICATIONS
™
The world’s
best-selling electric floor heating brand
™
The world’s
best-selling electric floor heating brand
TEMPO
SUBMITTAL SHEET WSC-1102
WARMUP INC.
USA: us@warmup.com
Tel.: 1-888-927-6333
www.warmup.com
CANADA: ca@warmup.com
Tel.: 1-888-592-7687
www.warmup.ca
TECHNICAL DATA
APPLICATIONS
INSTALLATION
SENSOR PROBE
Floor Heating
NADWM Floor Heating Mats
NADWS Floor Heating Cables
WODH In-slab Heating Cables
FOIL heating systems
NADCM-PRO Cable for uncoupling membranes
• Length: 3 meters or 10 feet
• Cable thickness: 3mm or 1/8"
• Probe dimensions: L x W = 20mm x 6mm or 5/8” x 1/4"
• Cable gauge: 24Ga 2-signal low voltage wire (extendable to 90ft)
™
The world’s
best-selling electric floor heating brand
WARMUP INC.
USA: us@warmup.com
Tel.: 1-888-927-6333
www.warmup.com
CANADA: ca@warmup.com
Tel.: 1-888-592-7687
www.warmup.ca
™
The world’s
best-selling electric floor heating brand
TEMPO
SUBMITTAL SHEET WSC-1102
PRODUCT LISTING
Code Description Amp(A)
TEMPO-CW-01 Digital Programmable Thermostat 15A
WARRANTY & MAINTENANCE
When installed according to the installation manual, the Tempo thermostats are covered with Warmup’s 3-Year manufacturer warranty.
The system requires no maintenance. All Warmup thermostats are protected by Warmup’s SafetyNET Guarantee.
TECHNICAL SUPPORT
Warmup is available 24/7/365 at (888) 927-6333.
For quotes, layouts and specific technical information, contact us at:
WarmupUSA
+1 (888) 927-6333
us@warmup.com
WarmupCANADA
+1 (888) 592-7687
ca@warmup.com
RELATED PRODUCTS
• NADCM-PRO - see WSC-0816
• NADWM - see WSC-0720
• NADWS - see WSC-0721
• FOIL - see WSC-0723
• WODH - see WSC-0724
