wiring for its installation and operation. With the wall mount
option, the installer simply affixes the wall plate (included) onto
the wall and sits the keypad on the plate. Keypad programming is
simple and fast with DSC’s Quick Enroll feature. The keypad also
provides installer programming, so no dedicated keypad is needed
for installation.
Security without compromise
The signals between the WT5500 and Alexor are fully encrypted.
This prohibits unauthorized interruption or interception of the
communication between the keypad and Alexor. And even though
it is wire-free, if the WT5500 is ever tampered with or the power is
removed, its off-line status will immediately signal Alexor and the
system will instantly go into alarm, alerting authorities.
Small in Size but Loaded with Features
PANELS, KEYPADS & MODULES
Contact your DSC distributor
www.dsc.com
1-888-888-7838
Easy-to-Use Keypads Provide Secure
Interface to DSC's 2-Way
Wireless Security Suite
Greater Protection. Complete Security.
How would you like to offer your customers a security
system that provides complete security via a host of devices,
including keypads, sirens, detectors and wireless keys, and also
supports GSM and IP communications – all of it wirelessly?
DSC's 2-Way Wireless Security Suite delivers just that…
and so much more.
Protection is Always at Hand with the WT5500
Wire-free Keypad
The compact and sleek new WT5500 Wire-Free Keypad is
designed to work with the Alexor Wireless Panel. Since Alexor
is mounted in a secure location within the home – away from
main access areas – the WT5500 provides an easy-to-use and
convenient main interface to the system. And with handy wall
or free-standing desk stand mounting options and the ability
to connect up to four keypads per system, installers can offer
homeowners more choice in where keypads may be located
throughout the home. The WT5500 can be conveniently
located on the wall just inside the front door or on a desk-
stand in the kitchen or even near a bedside
Break Free from Wires & Lengthy Installs
The WT5500 is entirely wire-free. With batteries as its main
power source, it does not require any drilling or electrical
2-Way Wireless Wire-Free Keypad
WT5500
PANELS, KEYPADS & MODULES
PN 3000970 R002
For product information
www.dsc.com
Product specifications and availability subject to
change without notice. Certain product names
mentioned herein may be trade names and/or
registered trademarks of other companies.
©2009 2009-03
Although compact, the WT5500 still offers a host of the great
features you expect from DSC keypads. These include the multiple
door chimes feature which allows for pre-programmed chimes to
identify specific zones. Zones can include anything from front doors,
to patio doors to pool gates or specially protected cabinets. Audible
beeps provide notification of alarms, entry/exit delays or status
conditions and troubles. The WT5500 also features a large, easy-
to-read 2x16 display and contoured, programmable, illuminated
keys, as well as one-touch function keys and universally recognized
icons. The WT5500P, which mirrors all the features of the WT5500,
also offers proximity functionality. The prox tag*, the PT4, (a small
tag, easily attached to a key ring) allows a homeowner to arm and
disarm their system, without using a code.
Power no Problem with Battery Preservation
Function & AC Option
When the wire-free keypad is not in use, it moves into a battery
preservation mode while remaining entirely online. The keypad is
also equipped with a light sensor which determines the ambient
light in the area and automatically adjusts the display and key
backlighting. These features extend battery life. When the batteries
are low, an indication light alerts the end user to change them.
The user can easily remove the product from the wall mount, take
off the backing and make the replacement. The WT5500D, with
all the same functionality of the WT5500, also comes with a desk
mount kit and AC transformer. The WT5500D can be used with
AC as its primary source of power and with the battery feature
as backup – an option that is ideal for use beside a bed or on a
kitchen countertop. When the WT5500 is wirelessly connected to
the WT4911 outdoor siren (equipped with a temperature sensor),
the keypad also displays the outdoor temperature.
Product features
Compatibility
Alexor Wireless Panel
Specifications
Dimensions ......................................................6.7"× 4.9"× 1.42"
(170mm × 124mm × 36mm)
Weight (with backplate and battery) ........................1.0 lb (450 g)
Battery .....................................................................4 AA batteries
Battery Life .................................................3 years (typical usage)
Wireless Range .............................. 984ft/300m Nominal Open Air
Operating Environment ............................................... -4F to 129F
(-20C to 54C)
Relative Humidity ........................................................5% to 95%
*Disarm your System in one motion with the
PT4 Prox Tag from DSC
No more fumbling at the door with armfuls of packages or
worries about remembering security codes. With DSC’s new PT4
Prox Tag for the WT5500P Wire-Free keypad, the Alexor Wireless
Panel is armed or disarmed in one easy motion. Simply swipe the
tag across the front of the keypad and the system is either armed
or disarmed. It’s that easy.
Feature WT5500 WT5500P WT5500D
Large 2×16 Display Y Y Y
Intuitive Clock Programming Y Y Y
Multi-Language Support Y Y Y
Installer Programming Y Y Y
Tamper Switch Y Y Y
Multiple Door Chime Y Y Y
Ambient Light Sensor Y Y Y
Backlighting Y Y Y
Outdoor Temperature Display Y Y Y
AC status LED Y Y Y
Wall Mount Y Y Y
Desk Mount/AC Power Y* Y* Y
Proximity Arm/Disarm N Y N
Zone Support 34 34 34
Number of Function Keys 5 5 5
*Requires WT5500DMK (Desk Mount Kit)
