Wall Mounted Unit FTX JV(GV) RX
User Manual: Wall Mounted Unit - FTX-JV(GV) - RX-JV(GV)
Open the PDF directly: View PDF
.
Page Count: 2
Wall Mounted Unit
ENERGY LABEL:
CLASS
A
FTX-JV(GV) / RX-JV(GV)
Height 283mm
Width 770mm
Depth 198mm
Height 550mm
Width 658mm
Depth 275mm
FTX20JV
RX20JV
See tables overleaf for full list of dimensions
These popular indoor units can be mounted on virtually any type of wall,
leaving space free for furniture, decoration and fittings. Wall mounted units
are very quiet in operation.
• Inverter technology: reduces the power consumption by up to 30% compared to non inverter units.
• Comfort mode (class 20 to 35): guarantees draught free operation. When cooling, the flap is positioned horizontally to
prevent cold air flow directly onto the body. When heating, the flap turns vertically downwards to direct warm air to the
bottom of the room.
• Night set mode: prevents any sudden change in room temperature by gently raising/lowering the temperature before
the system stops, so you can sleep more comfortably.
• Powerful operation: activates the maximum air volume for 20 minutes to cool or warm the room quickly. After this,
the system automatically returns to its original setting.
• Titanium apatite photocatalytic air purifying filter: superior adsorption power. Besides mould and odours, it also effectively
adsorbs and decomposes bacteria and viruses for effective purification and deodorisation of the air inside the room.
• Energy saving during standby
(class 20 to 35)
: when the unit is in standby and no people are detected for more than
20 minutes, the system will automatically switch to the energy saving mode reducing current consumption by about 80%.
• ECONO mode
(class 20 to 35)
:
reduces power consumption so other appliances that need large power supply can be used.
• Dry programme: Daikin’s special dry programme reduces humidity in the rooms without variations in internal temperature.
• Quiet operation: lowers the indoor unit noise level by 3dB(A) by changing the fan speed.
• Self diagnosis digital display: in the unlikely event that an abnormality occurs, the LCD remote
controller displays the error code allowing prompt maintenance.
• Auto-restart function: after a power failure in the building, the system automatically
restarts to the setting in operation before the power failure.
Powerful operation and ECONO mode
your comfort. our world.
Wireless remote
control as standard
FTX20-35JV
FTXS50-71GV
UKEPLEN10-009 / 11.10 / DesignHQ. Copyright 2010 Daikin
The present publication supersedes UKEPLEN09-009
Printed in the UK on FSC certified paper from sustainable sources.
Indoor Units FTX20JV FTX25JV FTX35JV FTX50GV FTX60GV FTX71GV
Capacity Cooling capacity Minimum kW 1.3 1.7 2.3
Standard kW 2.0 2.5 3.3 5.0 6.0 7.1
Maximum kW 2.6 3.0 3.8 6.0 6.7 8.5
Heating capacity Minimum kW 1.3 1.7 2.3
Standard kW 2.5 2.8 3.4 5.8 7.0 8.2
Maximum kW 3.5 4.0 4.8 7.7 8.0 10.2
EER / COP Cooling / Heating 3.64 / 4.24 3.42 / 4.06 3.37 / 3.76 3.23 / 3.63 3.02 / 3.43 3.02 / 3.22
Annual energy consumption kWh 275 365 490 775 995 1,175
Energy Label cooling / heating A / A A / A B / B B / C
Dimensions (Height x Width x Depth) mm 283x770x198 290x1,050x238
Weight kg 7 12
Air Flow Rate Cooling H/M/L/SL m³/min 9.1 / 7.4 / 5.9 / 4.7 9.2 / 7.6 / 6.0 / 4.8 9.3 / 7.7 / 6.1 / 4.9 14.7 16.2 17.4
Heating H/M/L/SL m³/min 9.4 / 7.8 / 6.3 / 5.5 9.7 / 8.0 / 6.3 / 5.5 10.1 / 8.4 / 6.7 / 5.7 16.1 17.4 19.7
Sound Power Cooling High dBA 55 56 57 59 61 62
Heating High dBA 55 56 57 58 60 62
Sound Pressure Cooling H/M/L/SL dBA 39 / 33 / 25 / 22 40 / 33 / 26 / 22 41 / 34 / 27 / 23 43 / 39 / 34 / 31 45 / 41 / 36 / 33 46 / 42 / 37 / 34
Heating H/M/L/SL dBA 39 / 34 / 28 / 25 40 / 34 / 28 / 25 41 / 35 / 29 / 26 42 / 38 / 33 / 30 44 / 40 / 35 / 32 46 / 42 / 37 / 34
Refrigerant Type R-410A R-410A
Power Supply 1~/220-240V/50Hz 1~/220-240V/50Hz
Controller Wireless ARC433A87 ARC433B70
Outdoor Unit RX20JV RX25JV RX35JV RX50GV RX60GV RX71GV
Dimensions (Height x Width x Depth) mm 550x658x275 735x825x300 770x900x320
Weight kg 28 30 48 71
Operation Range Cooling Min~Max °CDB 10~46 10~46
Heating Min~Max °CWB -15~20 -15~20
Sound Power Cooling dBA 60 62 61 63 66
Sound Pressure (High) Cooling dBA 46 48 47 49 52
Heating dBA 47 48 48 49 52
Refrigerant Type R-410A R-410A
Power Supply 1~/220-240V/50Hz 1~/220-240V/50Hz
Piping connections Liquid (OD)/Gas/Drain mm 6.35 / 9.52 / 18 6.35 / 12.7 / 18.0 6.35 / 15.9 / 18.0
Piping Length (Maximum) m 15 30
Max Installation Height Difference m 12 20
HEAT PUMP INVERTER
Visit www.eca.gov.uk/etl and type ‘Daikin’ in the quick search box for details of the latest ECA qualifying Daikin units
Daikin Airconditioning UK Ltd The Heights, Brooklands, Weybridge, Surrey KT13 0NY Tel 0845 6419000 Fax 0845 6419009
www.daikin.co.uk
Daikin products are distributed by:
Daikin units comply with the European regulations that
guarantee the safety of the product.
Daikin Europe N.V. participates in the Eurovent Certification
Programme for Air Conditioners (AC), Liquid Chilling Packages
(LCP) and Fan Coil Units (FC); the certified data of certified
models are listed in the Eurovent Directory. Multi units are
Eurovent certified for combinations up to 2 indoor units.
