PRICE CATALOG
EFFECTIVE JANUARY 1, 2017
VENTLESS HOOD SYSTEMS BUILTINDROPIN WARMERS COLD & DUAL TEMP PANS
COOKING EQUIPMENT COUNTERTOP WARMERS WAFFLE BAKERS
PRODUCT INDEX
Model Page Model Page Model Page Model Page
2424G............................................ 59
2436G............................................ 59
3036G............................................ 59
3048G............................................ 59
B40 ................................................. 64
B406 .............................................. 65
B44 ................................................. 64
B446 .............................................. 65
B50 ................................................. 64
B506 .............................................. 65
BMW206RT .................................. 33
BMW206RTD ............................... 33
BMW206RTDAFU ........................ 33
BMW206RTDU ............................. 33
BMW206RTU ............................... 33
BMW206SDT ............................... 32
BMW206SDU ............................... 32
BMW206ST .................................. 32
BMW206STDL ............................. 32
BMW206STDU ............................ 32
BMW206STU ............................... 32
BWB1SE ........................................ 76
CICP-72 ......................................... 41
CICP-73 ......................................... 41
CICP-74 ......................................... 41
CICP-75 ......................................... 41
CP6-20 .......................................... 47
CP6-27 .......................................... 47
CP6-34 .......................................... 47
CRCP-72 ........................................ 41
CRCP-73 ........................................ 41
CRCP-74 ........................................ 41
CRCP-75 ........................................ 41
F15 ................................................. 52
F1725 ............................................ 52
F30 ................................................. 54
F556 ............................................... 53
F586 ............................................... 53
FT-1 ................................................ 47
FT-2 ................................................ 47
FT-2SL ........................................... 47
FT-3 ................................................ 47
FT-3SL ........................................... 47
FT-4 ................................................ 47
FT-4SL ........................................... 47
FT-5 ................................................ 47
FT-6 ................................................ 47
G13........................................... 58
G136 .............................................. 62
G19 ................................................. 58
G196 .............................................. 62
G23 ................................................. 58
G236 .............................................. 62
G24 ................................................. 58
G246 .............................................. 62
G60 ................................................. 58
G606 .............................................. 62
GF-15 ............................................. 51
GF-30 ............................................. 51
H115 .............................................. 66
H2412G ......................................... 68
H33 ................................................. 66
H336 .............................................. 67
H63 ................................................. 66
H636 .............................................. 67
H63CD ........................................... 66
H70 ................................................. 66
H706 .............................................. 67
HC100 ........................................... 66
HC1006 ......................................... 67
HC125 ........................................... 66
HC1256 ......................................... 67
HC225 ........................................... 66
HC2256 ......................................... 67
HDCB1230G ............................ 61
HDCB2430G ............................ 61
HDCB3630G ............................ 61
HDCB4830G ............................ 61
HDG2430G .............................. 60
HDG3630G .............................. 60
HDG4830G .............................. 60
HDG6030G ................................... 60
HDHP1230G ............................ 63
HDHP2430G ............................ 63
HDHP3630G ............................ 63
HDTG2430G............................. 60
HDTG3630G............................. 60
HDTG4830G............................. 60
HDTG6030G ................................. 60
HDW-2 ........................................... 69
HMP6 ............................................. 34
HMP6D .......................................... 34
HMP6T ........................................... 34
HMPDU .......................................... 34
HRCP-7500 .................................. 42
HRCP7100 .................................... 42
HRCP7100ST ............................... 43
HRCP7143 .................................... 43
HRCP7200 .................................... 42
HRCP7200SL ............................... 42
HRCP7200SLST .......................... 42
HRCP7200ST ............................... 43
HRCP7243 .................................... 43
HRCP7300 .................................... 42
HRCP7300SL ............................... 42
HRCP7300SLST .......................... 42
HRCP7300ST ............................... 43
HRCP7343 .................................... 43
HRCP7400 .................................... 42
HRCP7400SL ............................... 42
HRCP7400SLST .......................... 42
HRCP7400ST ............................... 43
HRCP7443 .................................... 43
HRCP7500ST ............................... 43
HRCP7543 .................................... 43
HRCP7600 .................................... 42
HRCP7600ST ............................... 43
HRCP7643 .................................... 43
HSW6 ............................................. 34
HSW6D .......................................... 34
HT200 ............................................ 37
HT200AF ....................................... 37
HT227 ............................................ 37
HT227AF ....................................... 37
HT300 ............................................ 37
HT300AF ....................................... 37
HT400 ............................................ 37
HT400AF ....................................... 37
HT500 ............................................ 37
HT500AF ....................................... 37
HW10 ............................................. 72
HW106D ....................................... 35
HWD-2G ........................................ 77
HWD-2G-120C............................. 77
HWD-5G-208V............................. 77
HWD-5G-240V............................. 77
HWSMP ......................................... 72
HWSMP6D .................................... 35
ICP100 ........................................... 46
ICP100ST ...................................... 46
ICP200 ........................................... 46
ICP200SL ...................................... 46
ICP200SLST ................................. 46
ICP200ST ...................................... 46
ICP300 ........................................... 46
ICP300SL ...................................... 46
ICP300SLST ................................. 46
ICP300ST ...................................... 46
ICP400 ........................................... 46
ICP400SL ...................................... 46
ICP400SLST ................................. 46
ICP400ST ...................................... 46
ICP500 ........................................... 46
ICP500ST ...................................... 46
ICP600 ........................................... 46
ICP600ST ...................................... 46
LLF14 ....................................... 73
LLSC11 .......................................... 73
LLSC11WA.................................... 73
LLSC7 ............................................ 73
LLSC7WA ...................................... 73
MOD100 ........................................ 19
MOD100D ..................................... 19
MOD100T...................................... 19
MOD100TD .............................. 19
MOD100TDAF .............................. 19
MOD127T...................................... 19
MOD127TD ................................... 19
MOD127TDAF .............................. 19
MOD200 ........................................ 20
MOD200D ..................................... 20
MOD200DM ................................. 20
MOD200T...................................... 20
MOD200TD ................................... 20
MOD200TDAF .............................. 20
MOD200TDM ........................... 20
MOD200TDMAF .......................... 20
MOD200TDMN ............................ 20
MOD200TDMNAF ....................... 20
MOD200TDN ................................ 20
MOD227TDM ............................... 20
MOD227TDMAF .......................... 20
MOD300 ........................................ 21
MOD300D ..................................... 21
MOD300DM ................................. 21
MOD300T...................................... 21
MOD300TD ................................... 21
MOD300TDAF .............................. 21
MOD300TDM ........................... 21
MOD300TDMAF .......................... 21
MOD300TDMN ............................ 21
MOD300TDMNAF ....................... 21
MOD300TDN ................................ 21
MOD327T...................................... 21
MOD327TD ................................... 21
MOD327TDM ............................... 21
MOD327TDMAF .......................... 21
MOD400 ........................................ 22
MOD400D ..................................... 22
MOD400DM ................................. 22
MOD400T...................................... 22
MOD400TD ................................... 22
MOD400TDAF .............................. 22
MOD400TDM ........................... 22
MOD400TDMAF .......................... 22
MOD400TDMAFS ........................ 22
MOD427TDM ............................... 22
MOD427TDMAF .......................... 22
MOD427TDMAF1 ........................ 22
MOD500 ........................................ 22
MOD500D ..................................... 23
MOD500DM ................................. 22
MOD500T...................................... 22
MOD500TD ................................... 22
MOD500TDAF .............................. 23
MOD500TDM ............................... 22
MOD500TDMAF .......................... 23
MOD500TDMAFS ........................ 23
MOD527TDM ............................... 23
MOD527TDMAF .......................... 23
MOD527TDMAFS ........................ 23
OC1................................................. 57
OC2................................................. 57
PW106........................................... 75
RCP-050 ........................................ 44
RCP-067 ........................................ 44
RCP-7050 ..................................... 45
RCP-7067 ..................................... 45
RCP100 ......................................... 44
RCP100ST .................................... 44
RCP143 ......................................... 44
RCP200 ......................................... 44
RCP200SL .................................... 44
RCP200SLST ................................ 44
RCP200ST .................................... 44
RCP243 ......................................... 44
RCP300 ......................................... 44
RCP300SL .................................... 44
RCP300SLST ................................ 44
RCP300ST .................................... 44
RCP343 ......................................... 44
RCP400 ......................................... 44
RCP400SL .................................... 44
RCP400SLST ................................ 44
RCP400ST .................................... 44
RCP443 ......................................... 44
RCP500 ......................................... 44
RCP500ST .................................... 44
RCP543 ......................................... 44
RCP600 ......................................... 44
RCP600ST .................................... 44
RCP643 ......................................... 44
RCP7100 ....................................... 45
RCP7100ST .................................. 45
RCP7143 ....................................... 45
RCP7200 ....................................... 45
RCP7200SL .................................. 45
RCP7200SLST ............................. 45
RCP7200ST .................................. 45
RCP7243 ....................................... 45
RCP7300 ....................................... 45
RCP7300SL .................................. 45
RCP7300SLST ............................. 45
RCP7300ST .................................. 45
RCP7343 ....................................... 45
RCP7400 ....................................... 45
RCP7400SL .................................. 45
RCP7400SLST ............................. 45
RCP7400ST .................................. 45
RCP7443 ....................................... 45
RCP7500 ....................................... 45
RCP7500ST .................................. 45
RCP7543 ....................................... 45
RCP7600 ....................................... 45
RCP7600ST .................................. 45
RCP7643 ....................................... 45
RCTS-4 ..................................... 49
RCTS-4-CVR ................................. 49
RW16HD ....................................... 71
RW1HD .................................... 70
RW26HD ....................................... 71
RW2HD .......................................... 70
RW36HD ....................................... 71
RW3HD .......................................... 70
RWN1 ............................................. 70
RWN16 .......................................... 71
RWN2 ............................................. 70
RWN26 .......................................... 71
RWN3 ............................................. 70
RWN36 .......................................... 71
SC6411 ......................................... 73
SC6411WA ................................... 73
SC6423 ......................................... 73
SC6423WA ................................... 73
SMPT........................................ 72
SMPT-D ......................................... 72
SMPT27......................................... 72
SS10D ........................................... 28
SS10T ............................................ 28
SS10TD ......................................... 28
SS10TDU ................................. 28
SS10TDUC .................................... 28
SS10TDUCI ................................... 28
SS10TDUCIA12 ........................... 29
SS10TDUCIAF .............................. 29
SS10TDUI ..................................... 28
SS10TDUIAF ................................ 29
SS10TDUIAF12 ........................... 29
SS10TU ......................................... 28
SS10TUC ...................................... 28
SS10TUCI ..................................... 28
SS10TUI ........................................ 28
SS206 ............................................ 31
SS206D ......................................... 31
SS206ER ....................................... 33
SS206ERD .................................... 33
SS206ET ....................................... 32
SS206ETD .................................... 32
SS206T ......................................... 31
SS206TD ....................................... 31
SS206TD6HI ................................ 32
SS206TDU ............................... 31
SS206TU ....................................... 31
SS276TDU .................................... 31
SS276TU ....................................... 31
SS4 ................................................. 26
SS4D .............................................. 26
SS4T............................................... 26
SS4TDU ......................................... 26
SS4TDUC ...................................... 26
SS4TU ............................................ 26
SS4TUC ......................................... 26
SS8 ................................................. 27
SS8D .............................................. 27
SS8EUT ......................................... 27
SS8EUTD ....................................... 27
SS8TD ............................................ 27
SS8TDU ......................................... 27
SS8TDUCIAF ................................ 29
SS8TDUCIAF12 ........................... 29
SS8TDUIAF ................................... 29
SS8TDUIAF120 ........................... 29
SS8TU ............................................ 27
SW10T-120 ............................. 72
TMPT .............................................. 72
WAOC1 .......................................... 55
WB1E-120V ................................. 76
WB2E-120V ............................. 76
WFAE55F ...................................... 51
WFAE55FC ................................... 51
WV2HG .......................................... 15
WV2HGRW ................................... 14
WV2HSG ....................................... 15
WV2HSGRW ................................. 14
WV4HF .......................................... 15
WV4HFRW .................................... 14
WV4HS .......................................... 15
WV4HSRW .................................... 14
WVAE55F ...................................... 16
WVAE55FC ................................... 16
WVC-46 ......................................... 12
WVC-46X ...................................... 12
WVF886 ........................................ 15
WVF886RW .................................. 14
WVFG ............................................. 15
WVFGRW....................................... 14
WVG136........................................ 15
WVG136RW ................................. 14
WVO2HSG .................................... 13
WVO4HF ........................................ 13
WVO4HS ....................................... 13
WVOG136 ..................................... 13
WVU-26 ......................................... 11
WVU-31CT .................................... 12
WVU-48 ......................................... 11
WVU-72 ......................................... 11
WVU-96 ......................................... 11
QUICK SHIP
MODELS IN RED!
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
i
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 1
QUICK-SHIP
Quick-Ship is the fastest way to ship our top selling cooking, food warming equip-
ment directly from our warehouse to your operation. The equipment will leave our
warehouse within 2 shipping days after you place your order.
Items in the price book highlighted in red are Quick-Ship items.
Quick-Ship products sent in 12:00 p.m. (Noon) Central Time will be shipped within
the next two days. (Received on Tuesday, will go out by Thursday or sooner)
STANDARD DOMESTIC MODELS ONLY, EXPORT MODELS EXCLUDED.
INDEX ..........................................................................i
TABLE OF CONTENTS ..............................................................1
VENTLESS COOKING SYSTEMS
Universal Ventless Hoods ............................................................ 11
Canopy & Counter Hoods ............................................................. 12
Convection Oven Base ................................................................. 13
Double Drawer Warmer Base ...................................................... 14
Double Door Cabinet Base ........................................................... 15
Open Auto-lift Fryers, Electric with Filter ................................ 16
Ventless Accessories ................................................................... 17
BUILT-IN/DROP-IN WARMERS
Warmers, Single Pan 12 x 20, Top Mount .............................. 19
Warmers, Single Pan 12 x 27, Top Mount .............................. 19
Warmers, Two Pan 12 x 20, Top Mount .................................. 20
Warmers, Two Pan 12 x 20, Narrow Top Mount .................... 20
Warmers, Two Pan 12 x 27, Top Mount .................................. 20
Warmers, Three Pan 12 x 20, Top Mount ............................... 21
Warmers, Three Pan 12 x 20, Narrow Top Mount ................. 21
Warmers, Three Pan 12 x 27, Top Mount ............................... 21
Warmers, Four Pan 12 x 20, Top Mount ................................. 22
Warmers, Four Pan 12 x 27, Top Mount ................................. 22
Warmers, Five Pan 12 x 20, Top Mount .................................. 23
Warmers, Five Pan 12 x 27, Top Mount .................................. 23
Warmers, Round Top Mount ..................................................24-29
Warmers, Single Pan, Top Mount ................................................ 31
Warmers, Single Pan, Bottom Mount, Square Corners ......... 32
Warmers, Single Pan, Bottom Mount, Round Corners ........... 33
Warmers, Fractional Size, Top Mount ........................................ 34
Cook’N Hold ..................................................................................... 35
Warmers, Bain Marie, Top Mount ................................................ 37
Warmer Accessories ............................................................... 38-39
REFRIGERATED & DUAL-TEMPERATURE HOT/COLD PANS
NEWCurved Self Contained Cold & Ice Pans ........................... 41
Dual Temperature Wells, 12 x 20 ............................................. 42
Dual Temperature Slim Lines & Slim Line Slope Top ............... 42
4-3rd Size Dual Temperature NSF-7 .......................................... 43
4-3rd Size Dual Temperature NSF-7, slope tops .................... 43
Refrigerated Wells, 12” x 20” ..................................................... 44
RCP Slim Lines & Slim Line Slope Top ........................................ 44
RCP Series 7 Slope Tops............................................................... 44
4-3rd Size Standard Deep Depth NSF-7 .................................. 44
Refrigerated Wells, 12” x 20” NSF-7 ......................................... 45
RCP Series 7 Slim Line & Slim Line Slope Top .......................... 45
RCP Series 7 Slope Tops............................................................... 45
4-3rd Size Standard Depth NSF-7 ............................................. 45
Ice-Cooled Wells 12” x 20” .......................................................... 46
Ice Pans, Slim Line ........................................................................ 46
Ice Pans, Slim Line Slope Tops .................................................... 46
Ice Pans, Slope Tops ...................................................................... 46
Frost Tops ........................................................................................ 47
Frost Tops, Slim Line ..................................................................... 47
NEW Fractional Sized Cold Pans ................................................ 47
Wells Remote System Info ......................................................... 48
Refrigerated Counter Top Server .............................................. 49
Cold Pan/Refrigeration Accessories ......................................... 49
COOKING PRODUCTS
Fryers, Open Auto-Lift, Electric ............................................50-51
NEW Single Pot, Countertop Gas Fryers .................................. 51
Fryers, Single Frypot, Electric & Gas ...................................52-53
Fryers, Dual Frypot, Electric ..................................................54-55
Oil Disposal Caddy ......................................................................... 55
Fryer Accessories .......................................................................... 56
Half Size Convection Oven .......................................................... 57
Griddles, Electric ...................................................................... 58-59
Teppan Griddle ................................................................................ 59
Griddles, Gas Countertop ............................................................ 60
Char Broilers, Gas ........................................................................... 61
Griddles, GasDrop-In ..................................................................... 62
Hotplates, Gas ................................................................................ 63
Char Broilers, Electric .............................................................64-65
Hotplates, Ceramic, Electric .................................................66-67
Hotplates, Spiral, Electric ......................................................66-67
Hotplate, French, Electric ......................................................66-67
Instant-On Hotplate ...................................................................... 68
Water Saver Disher Well .............................................................. 69
COUNTERTOP WARMING
Drawer Warmers, Free Standing................................................. 70
Drawer Warmers, Built-In ............................................................. 71
Countertop Warmers, Rectangular & Square .......................... 72
Cook’N Hold, Heavy-Duty ............................................................. 73
Deluxe Soup Cooker/Warmers ................................................... 73
Hydro Surge Pot Washer .............................................................. 74
Warmers Accessories .................................................................. 75
WAFFLE BAKERS, SYRUP DISPENSER &
HOT WATER HEATERS
Electronic Waffle Bakers ............................................................. 76
Heated Dispenser .......................................................................... 77
Hot Water Dispensers .................................................................. 77
NOTES PAGE
Organize Your Thoughts .........................................................78-79
PLACING ORDERS, RETURN POLICY
Orders & Return Policy .................................................................. 80
WARRANTY
Warranty & Service Policy ........................................................... 81
TABLE OF CONTENTS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
2
VENTLESS HOODS
Let’s Talk Ventless!
Wells-Bloomfield — 10 Sunnen Drive, St. Louis, MO 63143 U.S.A.
Phone: 314.678.6314 | Fax: 314.781.5445
www.wellsbloomfield.com © 2012 Wells Bloomfield | Printed in the U.S.A.
Wells Ventless Hoods are a great alternative to traditional Type-1 ventilation
for several reasons:
Why Ventless?
Historic buildings prohibit traditional ducted
hoods and/or roof top fans
Extensive duct-work for traditional hoods may be
cost prohibitive in high-rise buildings, stadiums
and arenas
Many building designs such as malls, food
courts, airports, etc., do not lend themselves to
traditional hood installations
Because Ventless Hoods are considered
equipment and may be depreciated quickly, they
provide a valuable tax benefit
Since Ventless Hoods are a
portable asset they are a perfect
solution for leased spaces
A Ventless kitchen can fit
into very small spaces
When no hood space is
available, they create added
capacity and/or make menu
expansion possible
Malls Bars
Stadiums & Arenas
Historic Buildings
Airports
Food Courts
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 3
Ventless Hoods
Ventless Hoods
VENTLESS HOODS
Let’s Talk Ventless!
Wells-Bloomfield — 10 Sunnen Drive, St. Louis, MO 63143 U.S.A.
Phone: 314.678.6314 | Fax: 314.781.5445
www.wellsbloomfield.com © 2012 Wells Bloomfield | Printed in the U.S.A.
Wells Ventless Hoods are a great alternative to traditional Type-1 ventilation
for several reasons:
Why Ventless?
Historic buildings prohibit traditional ducted
hoods and/or roof top fans
Extensive duct-work for traditional hoods may be
cost prohibitive in high-rise buildings, stadiums
and arenas
Many building designs such as malls, food
courts, airports, etc., do not lend themselves to
traditional hood installations
Because Ventless Hoods are considered
equipment and may be depreciated quickly, they
provide a valuable tax benefit
Since Ventless Hoods are a
portable asset they are a perfect
solution for leased spaces
A Ventless kitchen can fit
into very small spaces
When no hood space is
available, they create added
capacity and/or make menu
expansion possible
Malls Bars
Stadiums & Arenas
Historic Buildings
Airports
Food Courts
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
4
VENTLESS HOODS
Wells Universal Ventless Systems give you the option to use almost any commercial
electric cooking equipment such as ovens, deep-fat fryers, ranges, griddles, hot
plates, rethermalizers, woks, steamers, combi ovens, induction hot plates and more!
Horizontal Clean
Air Outlet
(customer’s choice)
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 5
VENTLESS HOODS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
6
Wells Ventless Cooking Systems (VCS) offer the opportunity to “set
up shop” in any well-ventilated room, with a wide variety of
equipment to match any menu.
Quick & Easy — because it’s all included in one complete package!
Venting SolutionsVent Anywhere Anytime
VCS with Convection Oven Base
VCS with Drawer Warmer Base
VCS with Cabinet Base
VCS 2000 Series
Wells-Bloomfield — 10 Sunnen Drive, St. Louis, MO 63143 U.S.A.
Phone: 314.678.6314 | Fax: 314.781.5445
www.wellsbloomfield.com © 2012 Wells Bloomfield | Printed in the U.S.A.
WVF-886
WVOC-2HFG
WVO2HFG
WV2HGRW
WV2HG
WVO2HSG
W2HSGRW
WV2HSG
WVO4HF
WVFGRW
WVFG
WVO4HS
WVG136RW
WVG136
WVOG136
WVF886RW
WVF886
WV4HFRW
WV2HF
WV4HSRW
WV2HS
WVG-136RW
Made in the U.S.A.
MADE IN THE U.S.A.
Cords & Plugs provided on 3Ø
Models
Available in various voltages and
phases
All-in-One — Integrated Ventless
hood and cooking equipment in one,
ready-to-use package
19 Models to choose from
First Stage:
Second Stage:
Third Stage:
Fourth Stage:
Stainless Steel Baffle Filter
Fire Rated Pre-Filter
High Efficiency Particulate Air (HEPA) Filter
Carbon / Charcoal Filter
4-Stage Filtration
1234
(3)
(4)
(2)
(1)
VENTLESS HOODS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 7
Wells Ventless Cooking Systems (VCS) offer the opportunity to “set
up shop” in any well-ventilated room, with a wide variety of
equipment to match any menu.
Quick & Easy — because it’s all included in one complete package!
Venting SolutionsVent Anywhere Anytime
VCS with Convection Oven Base
VCS with Drawer Warmer Base
VCS with Cabinet Base
VCS 2000 Series
Wells-Bloomfield — 10 Sunnen Drive, St. Louis, MO 63143 U.S.A.
Phone: 314.678.6314 | Fax: 314.781.5445
www.wellsbloomfield.com © 2012 Wells Bloomfield | Printed in the U.S.A.
WVF-886
WVOC-2HFG
WVO2HFG
WV2HGRW
WV2HG
WVO2HSG
W2HSGRW
WV2HSG
WVO4HF
WVFGRW
WVFG
WVO4HS
WVG136RW
WVG136
WVOG136
WVF886RW
WVF886
WV4HFRW
WV2HF
WV4HSRW
WV2HS
WVG-136RW
Made in the U.S.A.
MADE IN THE U.S.A.
Cords & Plugs provided on 3Ø
Models
Available in various voltages and
phases
All-in-One — Integrated Ventless
hood and cooking equipment in one,
ready-to-use package
19 Models to choose from
First Stage:
Second Stage:
Third Stage:
Fourth Stage:
Stainless Steel Baffle Filter
Fire Rated Pre-Filter
High Efficiency Particulate Air (HEPA) Filter
Carbon / Charcoal Filter
4-Stage Filtration
1234
(3)
(4)
(2)
(1)
VENTLESS HOODS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
8
VENTLESS HOODS
PLEASE SEE PAGE 55 FOR OIL CADDY DETAILS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 9
VENTLESS HOODS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
10
WVU-26
Shown with standard solid base.
Equipment sold separately
VENTLESS HOODS
UNIVERSAL VENTLESS HOODS
WVU-48
Shown with stan-
dard solid base
WVU-72
Shown with standard solid base.
Equipment sold separately
NEW
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 11
VENTLESS HOODS
WVU-96
Shown with standard solid base.
Equipment sold separately
Model
Number
Part
Number
Description/Hood Specs Overall Size
W x D x H (in)
Voltage Phase Amps Ship
Weight
Lbs.
Price
WVU-26 5N-WVU-26 Universal 26” opening for single appliance
Up to 26”+ cooking zone (660mm)
31 x 42.5 x 80 208/240 1 6 553 $19,600.00
WVU-48 5N-WVU-
48SS
Universal 50” opening for multiple appliances
Up to 50”+ cooking zone (1,220mm)
61.9 x 50.0 x
120.0
208/240 1 3.5 890 $31,520.00
WVU-48 5N-WVU-
48-50HZ
Universal 50” opening for multiple appliances
Up to 50”+ cooking zone (1,220mm)
61.9 x 50.0 x
120.0
208/240-
50HZ
1 3.5 890 $31,520.00
WVU-72 5N-WVU-72 Universal 72” opening for multiple appliances
Up to 72”+ cooking zone (1,829mm)
87.9 x 50.0 x
120.0
208/240 1 3.5 1,500 $41,200.00
WVU-96 5N-WVU-96 Universal 100” opening for multiple appli-
ances with stand
Up to 100”+ cooking zone (2,438mm)
113.9 x 50.0 x
120.0
208/240 1 8 2,004 $57,720.00
UNIVERSAL VENTLESS HOODS
NSF/ANSI 2 UL710B
UL710B CATEGORY YZCT RECIRCULATING
SYSTEM FILE NO. MH48408
NSF/ANSI 2 UL710B
UL710B CATEGORY YZCT RECIRCULATING
SYSTEM FILE NO. MH48408
NSF/ANSI 2 UL710B
UL710B CATEGORY YZCT RECIRCULATING
SYSTEM FILE NO. MH48408
NSF/ANSI 2 UL710B
UL710B CATEGORY YZCT RECIRCULATING
SYSTEM FILE NO. MH48408
NOTES:
• SPECIFY VOLTAGE, PHASE AND CYCLE ON ALL ORDERS
• SEE SPECIFICATION SHEET FOR APPLIANCE LIMITATIONS ELECTRIC APPLIANCES ONLY
ALL VENTLESS MODELS ARE NONRETURNABLE
SEE PAGE 17 FOR REPLACEMENT FILTERS & ACCESSORIES
All Universal Hoods NOW come with Vertical Discharge Standard
Part Number Hood Model Description List Price
WVU-48 Horizontal Discharge Kit - Converts Standard Vertical Discharge to Horizontal $350.00
SN-Z21080 WVU-72 Horizontal Discharge Kit - Converts Standard Vertical Discharge to Horizontal $350.00
WVU-96 Horizontal Discharge Kit - Converts Standard Vertical Discharge to Horizontal $700.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
12
Model
Number
Part
Number
Description/Hood Specs Overall Size
W x D x H (in)
Voltage Phase Amps Ship
Weight
Lbs.
Price
WVC-46 5N-WVC-46 Canopy Hood with on-board fire ANSUL
designed for all oven types 46.0 x 52.33 x
27.72 208/240 1 3.5 675 $22,600.00
WVC-46X 5N-WVC-46X Canopy Hood ANSUL ready (by others)
designed for all oven types 46.0 x 52.33 x
27.72 208/240 1 3.5 645 $19,650.00
WVU-31CT 5N-WVU-31CT Universal counter top hood for multi
appliances 31.2 x 34.4 x
57.0 208/240 1 3.5 445 $16,640.00
CANOPY & COUNTERTOP HOODS
Model WVU-31CT
VENTLESS HOODS
NOTES:
SPECIFY VOLTAGE, PHASE AND CYCLE ON ALL ORDERS
ALL VENTLESS MODELS ARE NONRETURNABLE
SEE PAGE 17 FOR REPLACEMENT FILTERS & ACCESSORIES
Model WVC-46 (oven not included)
DESIGNED TO ACCOMMODATE ELECTRIC CONVECTION,
COMBI, BAKERY AND COOK & HOLD OVENS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 13
Convection Oven Base – All 3Ø units ship with NEMA 15-60P, 60Hz Only
Model
Number
Part
Number
Description Voltage Phase KW Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
VGriddle with 2 French Top Hot Plates Cooking Platform
WVO2HFG 5M-WVO2HFG2081 Griddle with two French plates 208 1 12.8 42- x 34- x 80-9/16 754 82 $47,600.00
WVO2HFG 5M-WVO2HFG2083 Griddle with two French plates 208 3 12.8 42- x 34- x 80-9/16 754 82 $47,600.00
WVO2HFG 5M-WVO2HFG2401 Griddle with two French plates 240 1 12.8 42- x 34- x 80-9/16 754 82 $47,600.00
WVO2HFG 5M-WVO2HFG2403 Griddle with two French plates 240 3 12.8 42- x 34- x 80-9/16 754 82 $47,600.00
WVO2HFG 5M-OC2HFG-208GF Griddle with two French plates &
fully grooved griddle
208 3 12.8 42- x 34- x 80-9/16 754 82 $49,100.00
WVO2HFG 5M-WVO2HFG2401 Griddle with two French hot plates
& 6” grooved griddle, right side
208 3 12.8 42- x 34- x 80-9/16 754 82 $48.360.00
VGriddle with 2 Spiral Hot Plates Cooking Platform
WVO2HSG 5M-WVO2HSG2083 Griddle with two spiral hot plates 208 3 13.7 42- x 34- x 80-9/16 756 82 $47,600.00
WVO2HSG 5M-WVO2HSPG2083 Chrome plated griddle with two
spiral hot plates
208 3 13.7 42- x 34- x 80-9/16 756 82 $48,880.00
V4 French Top Hot Plates Cooking Platform
WVO4HF 5M-WVO4HF-2081 Four French plate cooktop 208 1 11.5 42- x 34- x 80-9/16 680 82 $46,280.00
WVO4HF 5M-WVO4HF-2083 Four French plate cooktop 208 3 11.5 42- x 34- x 80-9/16 680 82 $46,280.00
WVO4HF 5M-WVO4HF-2401 Four French plate cooktop 240 1 14.1 42- x 34- x 80-9/16 680 82 $46,280.00
WVO4HF 5M-WVO4HF-2403 Four French plate cooktop 240 3 14.1 42- x 34- x 80-9/16 680 82 $46,280.00
V4 Spiral Hot Plates Cooking Platform
WVO4HS 5M-WVO4HS-2083 Four spiral Cooktop 208 3 13.3 42- x 34- x 80-9/16 677 82 $46,280.00
VSingle Large Griddle Cooking Platform
WVOG136 5M-WVOG136-2081 Single, large griddle cooktop 208 1 12.2 42- x 34- x 80-9/16 793 82 $48,880.00
WVOG136 5M-WVOG136-2083 Single, large griddle cooktop 208 3 12.2 42- x 34- x 80-9/16 793 82 $48,880.00
WVOG136 5M-WVOG136-2401 Single, large griddle cooktop 240 1 15 42- x 34- x 80-9/16 793 82 $48,880.00
WVOG136 5M-WVOG136-2403 Single, large griddle cooktop 240 3 15 42- x 34- x 80-9/16 793 82 $48,880.00
WVOG136 5M-OCG136-208GF Single, large griddle cooktop,
fully grooved
280 3 12.2 42- x 34- x 80-9/16 793 82 $50,750.00
WVOG136 5M-OCG136R2-208 Single, large griddle cooktop,
12" grooved right section
280 3 12.2 42- x 34- x 80-9/16 793 82 $50,000.00
VCS 2000 SERIES
CONVECTION OVEN BASE
WVOC2HFG
VENTLESS HOODS
If Your Option for Grooving or Chrome is Not Defined above, add the
following to the base price:
Option Add Option Add
6” Grooving $785 24” Grooving $1,870
12” Grooving $1,155 Chrome Plate $1,340
18” Grooving $1,470
NOTES:
• SPECIFY VOLTAGE, PHASE AND CYCLE ON ALL ORDERS
ALL VENTLESS MODELS ARE NONRETURNABLE
SEE PAGE 17 FOR REPLACEMENT FILTERS & ACCESSORIES
GROOVING IS NOT AVAILABLE WITH CHROMEPLATED SURFACE.
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
14
VCS 2000 SERIES
DRAWER WARMER BASE
WVG136RW
VENTLESS HOODS
Drawer Warmer Base – All 3Ø units ship with NEMA 15-60P, 60Hz only
Model
Number
Part
Number
Description Voltage Phase KW Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
V Griddle with 2 French Top Hot Plates Cooking Platform
WV2HGRW 5M-WV2HGRW1 Griddle with 2-French hot plates 208/240 1 8.7 42- x 35- x 79- 775 82 $44,500.00
WV2HGRW 5M-WV2HGRW3 Griddle with 2-French hot plates 208/240 3 8.7 42- x 35- x 79- 775 82 $44,500.00
WV2HGRW 5M-2HFGRW-GF Griddle with 2-French hot plates with
fully grooved 18” griddle
208/240 3 8.7 42- x 35- x 79- 775 82 $46,000.00
V Griddle with 2 Spiral Hot Plates Cooking Platform
WV2HSGRW 5M-WV2HSGRW1 Griddle with 2-spiral hot plates 208/240 1 12 42- x 35- x 79- 770 82 $41,900.00
VGriddle with 15lb Fryer
WVFGRW 5M-WVFGRW-2081 Griddle with fryer 208 1 11.5 42- x 35- x 79- 738 82 $45,240.00
WVFGRW 5M-WVFGRW-208 Griddle with fryer 208 3 11.5 42- x 35- x 79- 738 82 $45,240.00
WVFGRW 5M-WVFGRW-240 Griddle with fryer 240 3 12.6 42- x 35- x 79- 738 82 $45,240.00
WVFGRW 5M-WVFGG1RRW208 Griddle with fryer & 6” grooved griddle,
right side
208 3 11.5 42- x 35- x 79- 738 82 $46,000.00
WVFGRW 5M-WVFGGRW-208V Fully grooved 18” griddle with fryer 208 3 11.5 42- x 35- x 79- 738 82 $46,800.00
V Single Large Griddle Cooking Platform
WVG136RW 5M-WVG136RW1 Griddle large cooktop 208/240 1 7.3/9.5 42- x 35- x 77-3/16 738 77 $41,900.00
WVG136RW 5M-WVG136RW Griddle large cooktop 208/240 3 7.3/9.5 42- x 35- x 77-3/16 738 77 $41,900.00
WVG136RW 5M-WVG136CRW Griddle large Chrome Plated 208/240 3 7.3/9.5 42- x 35- x 77-3/16 738 77 $43,260.00
WVG136RW 5M-WVG136RW6GL Griddle large with 6” grooved left side 208/240 1 7.3/9.5 42- x 35- x 77-3/16 738 77 $42,740.00
WVG136RW 5M-G136RW-GL Griddle large with 12” grooved left side 208/240 1 7.3/9.5 42- x 35- x 77-3/16 738 77 $43,150.00
WVG136RW 5M-G136RW-GR Griddle large with 12” grooved right side 208/240 3 7.3/9.5 42- x 35- x 77-3/16 738 77 $43,150.00
WVG136RW 5M-G136RW-GF Fully grooved griddle 208/240 3 7.3/9.5 42- x 35- x 77-3/16 738 77 $43,880.00
WVG136RW 5M-G136RW-GL Griddle large with 12” grooved left side 208/240 3 7.3/9.5 42- x 35- x 77-3/16 738 77 $43,160.00
V Twin Fryer Cooking Platform
WVF886RW 5M-WVF886RW2083 Twin fryer cooktop 208 3 12 42- x 35- x 77-3/16 696 77 $42,000.00
WVF886RW 5M-WVF886RW2401 Twin fryer cooktop 240 1 12 42- x 35- x 77-3/16 696 77 $42,000.00
WVF886RW 5M-WVF886RW2403 Twin fryer cooktop 240 3 12 42- x 35- x 77-3/16 696 77 $42,000.00
V4 French Top Hot Plate Cooking Platform
WV4HFRW 5M-WV4HFRW-1 4 French hot plate cooktop 208/240 1 7/9.1 42- x 35- x 77-¼ 655 77 $40,800.00
WV4HFRW 5M-WV4HFRW 4 French hot plate cooktop 208/240 3 7/9.1 42- x 35- x 77-¼ 655 77 $40,800.00
V4 Spiral Top Hot Plate Cooking Platform
WV4HSRW 5M-WV4HSRW-1 4 Spiral hot plate cooktop 208/240 1 8.7/11.5 42- x 35- x 77-¼ 650 77 $40,650.00
WV4HSRW 5M-WV4HSRW 4 Spiral hot plate cooktop 208/240 3 8.7/11.5 42- x 35- x 77-¼ 650 77 $40,650.00
If Your Option for Grooving or Chrome is Not Defined above, add the following to the base price:
Option Add Option Add
6” Grooving $785 24” Grooving $1,870
12” Grooving $1,155 Chrome Plate $1,340
18” Grooving $1,470
NOTES:
GROOVING IS NOT AVAILABLE WITH CHROMEPLATED SURFACE.
• SPECIFY VOLTAGE, PHASE AND CYCLE ON ALL ORDERS
ALL VENTLESS MODELS ARE NONRETURNABLE
SEE PAGE 17 FOR REPLACEMENT FILTERS & ACCESSORIES
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 15
VCS 2000 SERIES
DOUBLE DOOR CABINET BASE
F
F
WVF886
VENTLESS HOODS
F
NOTES:
GROOVING IS NOT AVAILABLE WITH CHROMEPLATED SURFACE.
• SPECIFY VOLTAGE, PHASE AND CYCLE ON ALL ORDERS
ALL VENTLESS MODELS ARE NONRETURNABLE
SEE PAGE 17 FOR REPLACEMENT FILTERS & ACCESSORIES
• SPECIFY VOLTAGE, PHASE AND CYCLE ON ALL ORDERS ALL VENTLESS MODELS ARE NONRETURNABLE SEE PAGE 17 FOR REPLACEMENT FILTERS & ACCESSORIES
Double Door Cabinet Base – All 3Ø units ship with NEMA 15-60P, 60 Hz only
Model
Number
Part
Number
Description Voltage Phase KW Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
VGriddle with 2 French Top Hot Plates Cooking Platform
WV2HG 5M-WV2HG-2081 Griddle with 2-French hot plates 208 1 8 42- x 35- x 79- 657 82 $37,200.00
WV2HG 5M-WV2HG-2083 Griddle with 2-French hot plates 208 3 8 42- x 35- x 79- 657 82 $37,200.00
WV2HG 5M-WV2HG-2401 Griddle with 2-French hot plates 240 1 9.9 42- x 35- x 79- 657 82 $37,200.00
WV2HG 5M-WV2HG-2403 Griddle with 2-French hot plates 240 3 9.9 42- x 35- x 79- 657 82 $37,200.00
WV2HG 5M-WV2HGGR2-208 Griddle with 2-French hot plates & 12” Grooved
Griddle Right Hand Side
208 3 8 42- x 35- x 79- 657 82 $38,370.00
V Griddle with 2 Spiral Hot Plates Cooking Platform
WV2HSG 5M-WV2HSG-208 Griddle with 2-spiral hot plate cooktop 208 3 8 42- x 35- x 79- 650 82 $39,500.00
WV2HSG 5M-WV2HSG-240 Griddle with 2-spiral hot plate cooktop 240 3 9.5 42- x 35- x 79- 650 82 $39,500.00
VGriddle with 15lb Fryer
WVFG 5M-WVFG-2081 Griddle with fryer cooktop 208 1 10.8 42- x 35- x 79- 656 82 $39,500.00
WVFG 5M-WVFG-2083 Griddle with fryer cooktop 208 3 10.8 42- x 35- x 79- 656 82 $39,500.00
WVFG 5M-WVFG-2401 Griddle with fryer cooktop 240 1 11.7 42- x 35- x 79- 656 82 $39,500.00
WVFG 5M-WVFG-240 Griddle with fryer cooktop 240 3 11.7 42- x 35- x 79- 656 82 $39,500.00
WVFG 5M-FG-208V-G6L Griddle with fryer grooved griddle 6” left hand side 208 3 10.8 42- x 35- x 79- 656 82 $39,500.00
WVFG 5M-FG-208V-G12L Griddle with fryer grooved griddle 12” left hand side 208 3 10.8 42- x 35- x 79- 656 82 $40,350.00
WVFG 5M-FG-208V-GF Griddle with fryer fully grooved griddle 208 3 10.8 42- x 35- x 79- 656 82 $41,000.00
V Single Large Griddle Cooking Platform
WVG136 5M-WVG1361 Large griddle cooktop fully grooved 208/240 1 7.9/9.5 42- x 35- x 77-3/16 664 77 $36,600.00
WVG136 5M-WVG1363 Large griddle cooktop, 12” grooved right side 208/240 3 7.9/9.5 42- x 35- x 77-3/16 664 77 $36,600.00
WVG136 5M-WVGG1361R2 Large griddle cooktop, 12” grooved right side 208/240 1 7.9/9.5 42- x 35- x 77-3/16 664 77 $37,750.00
WVG136 5M-WVG136-400 Large griddle cooktop with chrome plate 380/415
3NAC
3 WITH NEU-
TRAL AC 4
11 42- x 35- x 77-3/16 664 77 $37,750.00
WVG136 5M-WVG136C-2081 Large griddle cooktop with chrome plate 208/240 1 7.9/9.5 42- x 35- x 77-3/16 664 77 $37,960.00
WVG136 5M-WVG136C3 Large griddle cooktop grooved 6” left side 208/240 3 7.9/9.5 42- x 35- x 77-3/16 664 77 $37,440.00
WVG136 5M-G136-G6R Large griddle cooktop 12” grooved left side 208/240 3 7.9/9.5 42- x 35- x 77-3/16 664 77 $37,750.00
WVG136 5M-G136-GL Large griddle cooktop 12” grooved left side 208/240 3 7.9/9.5 42- x 35- x 77-3/16 664 77 $37,750.00
WVG136 5M-G136-GR Large griddle cooktop 12” grooved right side 208/240 3 7.9/9.5 42- x 35- x 77-3/16 664 77 $37,750.00
WVG136 5M-G136-GF Large griddle cooktop 208/240 3 7.9/9.5 42- x 35- x 77-3/16 664 77 $38,480.00
V Twin Fryer Cooking Platform
WVF886 5M-WVF886-2081 Twin fryers cooktop 208 1 12 42- x 35- x 77-3/16 606 77 $36,500.00
WVF886 5M-WVF886F-208 Twin fryers cooktop 208 3 12 42- x 35- x 77-3/16 606 77 $36,500.00
WVF886 5M-WVF886D-208 Twin Fryers VCS 208V 3PH with drain 208 3 12 42- x 35- x 77-3/16 606 77 $36,800.00
WVF886 5M-WVF886-240-1 Twin fryers cooktop 240 1 11.7 42- x 35- x 77-3/16 606 77 $36,500.00
WVF886 5M-WVF886-240 Twin fryers cooktop 240 3 11.7 42- x 35- x 77-3/16 606 77 $36,500.00
WVF886 5M-WVF886D-240 Twin Fryers VCS 240V 3PH with drain 240 3 11.7 42- x 35- x 77-3/16 606 77 $36,800.00
WVF886 5M-WVF886-400 Twin fryers cooktop 380/415
3 NAC
3 WITH NEU-
TRAL AC 4
12 42- x 35- x 77-3/16 606 77 $37,500.00
WVF886 5M-WVF886D-400 Twin Fryers VCS EU 400V 3N with drain 380/415
3 NAC
3 WITH NEU-
TRAL AC 4
12 42- x 35- x 77-3/16 606 77 $37,850.00
V4 French Top Hot Plate Cooking Platform
WV4HF 5M-WV4HF-2401 4 French hot plate cooktop 208/240 1 6.2/8.4 42- x 35- x 77-¼ 565 77 $36,000.00
WV4HF 5M-WV4HF 4 French hot plate cooktop 208/240 3 6.2/8.4 42- x 35- x 77-¼ 565 77 $36,000.00
V4 Spiral Top Hot Plate Cooking Platform
WV4HS 5M-WV4HS-2401 4 Spiral hot plate cooktop 208/240 1 8.1/10.8 42- x 35- x 77-¼ 556 77 $35,250.00
WV4HS 5M-WV4HS 4 Spiral hot plate cooktop 208/240 38.1/10.8 42- x 35- x 77-¼ 556 77 $35,250.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
16
VENTLESS HOODS
HIGH CAPACITY VENTLESS
OPEN AUTOLIFT FRYERS
Model
Number
Part
Number
Description Voltage Phase KW Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
V 55lb. Fryers with Auto Lift and Mechanical Timers
WVAE55F 5M-WVAE55F-208 50 lb fryer with mechanical
timer & filter
208V 3 17 15-13/16 x 43-
11/16 x 76-
556 60 $33,400.00
WVAE55F 5M-WVAE55F-240 50 lb fryer with mechanical
timer & filter
240V 3 17 15-13/16 x 43-
11/16 x 76-
556 60 $33,400.00
V 55lb. Fryers with Auto Lift and Solid State Computer Controls
WVAE55FC 5M-WVA55FC2081 50 lb fryer with solid state com-
puter controls
208V 1 11.3 15-13/16 x 43-
11/16 x 76-
525 60 $35,000.00
WVAE55FC 5M-WVAE55FC208 50 lb fryer with solid state com-
puter controls
208V 3 17 15-13/16 x 43-
11/16 x 76-
525 60 $35,000.00
WVAE55FC 5M-WVAE55FC2401 50 lb fryer with solid state com-
puter controls
240V 1 11.3 15-13/16 x 43-
11/16 x 76-
525 60 $35,000.00
WVAE55FC 5M-WVAE55FC2403 50 lb fryer with solid state com-
puter controls
240V 3 17 15-13/16 x 43-
11/16 x 76-
525 60 $35,000.00
Open Auto-Lift Fryer Accessories
Part
Number
Description Ship Weight Price
Ventless Fryers
22692 Rear leg kit, 2 rear legs to be used when remote fire pull station is field installed on WVPE & WVAE models 4 $260.00
22913 Full-size basket (WVAE55F/FS) - $970.00
22796 Half-size basket (WVAE55F/FS) 6 $400.00
21647 Heating element cleaning brush - $115.00
22516 Frypot cleaning brush - $58.00
22515 Chicken stirring paddle 2 $100.00
22402 High-Efficiency HEPA Filter 8 $555.00
22403 Charcoal Filter 2 $300.00
WVAE55F/FC
NOTES:
• SPECIFY VOLTAGE, PHASE AND CYCLE ON ALL ORDERS
ALL VENTLESS MODELS ARE NONRETURNABLE
SEE PAGE 17 FOR REPLACEMENT FILTERS & ACCESSORIES
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 17
Ventless Replacement Filters
Part
Number
Description Ship
Weight
Price
Universal Ventless Systems
WVU-26 (WVU-1) Requires one HEPA Charcoal filter pack only
WL0107 HEPA Charcoal filter pack $1,340.00
WVU-48 Requires two Pre filters and one HEPA Charcoal Filter Pack
22618 Pre-Filter $140.00
23312 HEPA Charcoal Filter pack $1,340.00
WVU-72 Requires two Pre filters and two HEPA Charcoal Filter Packs
22618 Pre-Filter $140.00
WL0711 HEPA Charcoal filter pack $1,300.00
WVU-96 Requires four Pre filters and two HEPA Charcoal Filter Pack
22618 Pre-Filter $140.00
23312 HEPA Charcoal Filter pack $1,340.00
VCS Systems
All Models Requires one Pre-Filter and one HEPA Charcoal Filter Pack
22618 Pre-Filter 3 $140.00
22619 HEPA Charcoal Filter Pack 11 $960.00
Canopy Style Hoods
WVC-46, WVC-46X Requires one Pre-Filter and one HEPA Charcoal Filter Pack
23324 Pre-Filter - $140.00
23325 HEPA Charcoal Filter Pack - $775.00
Countertop Ventless
WVU-31CT Requires one Pre-Filter and one HEPA Charcoal Filter Pack
302579 Pre-Filter - $140.00
WL0422 HEPA Charcoal Filter Pack - $1,300.00
Ventless Fryer Systems
WVAE55 Requires one HEPA and one Charcoal Filter
22402 HEPA Filter 5 $555.00
22403 Charcoal filter 6 $300.00
VENTLESS FILTERS & ACCESSORIES
Universal Ventless & VCS Accessories
Part
Number
Description Ship
Weight
Price
Universal Ventless Hood
5N-Z21648 Caster kit for WVU-26 6$355.00
WVU-LK Set of 4 each adjustable 10” to 12” legs with flanged feet for WVU-48, WVU-72 and WVU-96 12 $300.00
WV48-BPK Stainless steel back panel kit for WVU-48 -$780.00
WV72-BPK Stainless steel back panel kit for WVU-72 -$1,050.00
WV96-BPK Stainless steel back panel kit for WVU-96 -$1,310.00
VCS2000 Combination Ventless Cooking Systems
22649 Rear Leg Kit, 2 rear legs to be used when a remote fire pull station is field installed on all VCS-2000 Models 5 $265.00
22650 Caster Kit, 2 swivel casters with brakes to replace front legs where remote fire pull station is not required 6 $350.00
21376 Oven Rack for WVOC models 4 $84.00
Pre-Filter
Stainless Baffle
Filter
HEPA & Carbon-
Charcoal Filters
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
18
BUILT-IN / DROP-IN WARMERS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 19
SINGLE PAN
TOPMOUNT
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
V Single Pan 12” x 20”, Top-Mount
MOD100-120
MOD100
20459
20460
Infinite Control
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
CSA model available: 120V 10A, 208V 4.3A, 240V 5.0A
13-¾ x 21-¾ 24 4.15
$840.00
$840.00
$840.00
MOD100D-120
MOD100D
20530
20531
Infinite Control, with Drain
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
13-¾ x 21-¾ 24 4.15
$930.00
$930.00
MOD100T-120
MOD100T
MOD100T-230
21277
21015
22372
Thermostat control
120V, 1Ø, 1650W
208/240V, 1Ø, 1240/1650W
220-240V, 1Ø, 1650W
13-¾ x 21-¾ 24 4.15
$895.00
$895.00
$940.00
MOD100TD-120
MOD100TD
MOD100TD-230
21278
21017
22373
Thermostat control, with Drain
120V, 1Ø, 1650W
208/240V, 1Ø, 1240/1650W
220-240V, 1Ø, 1650W
13-¾ x 21-¾ 24 4.15
$975.00
$975.00
$1,025.00
MOD100TDAF 21920
Autofill, Thermostat control, with Drain
208/240V, 1Ø, 1240/1650W each
14-¾ x 23-½ 30 4.15
$1,695.00
N/A N/A 6 cord & plug for Thermostatic Control models only
(MOD100s in 120V)
$62.00
N/A N/A 6 cord & plug for Thermostatic Control models only
(MOD100s in 208/240V)
$62.00
V Single Pan 12” x 27”, Top-Mount
MOD127T 22940
Thermostat control
208/240V, 1Ø, 1240/1650W each
14-¾ x 30-½ 25 5.2
$1,210.00
MOD127TD 22939
Thermostat control, with Drain
208/240V, 1Ø, 1240/1650W each
14-¾ x 30-½ 25 5.2
$1,345.00
MOD127TDAF 22938
Autofill, Thermostat control, with Drain
208/240V, 1Ø, 1240/1650W each
14-¾ x 30-½ 30 5.2
$2,055.00
F
F
MOD100
BUILT-IN / DROP-IN WARMERS
Auto Fill Models Available
OPTIONAL CORDS AND PLUGS ARE AVAILABLE ON THERMOSTATIC CONTROL MODELS ONLY 120V & 208240V MODELS.
AUTOFILL MODELS REQUIRE A WATER CONNECTION. PLEASE REFER TO THE OPERATOR’S MANUAL AND INSTALLATION INSTRUCTIONS FOR DETAILS
ACCESSORIES PAGE 38 & 39 EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
20
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
V Two Pan 12” x 20”, Top-Mount
MOD200 20448
Infinite control
208/240V, 1Ø, 900/1200W each
CSA model available: 208V 8.7A, 240V 10A
29-½ x 23- 51 7.89
$2,090.00
MOD200D 20449
Infinite control, with Drain
208/240V, 1Ø, 900/1200W each
29-½ x 23- 51 7.89
$2,240.00
MOD200DM 22027
Infinite control, with Drain Manifold
208/240V, 1Ø, 900/1200W each
29-½ x 23- 51 7.89
$2,300.00
MOD200T 21016
Thermostat control
208/240V, 1Ø, 1240/1650W each
29-½ x 23- 51 7.89
$2,230.00
MOD200TD 21233
Thermostat control, with Drain
208/240V, 1Ø, 1240/1650W each
29-½ x 23- 53 7.89
$2,445.00
MOD200TDM 22028
Thermostat control, with Drain Manifold
208/240V, 1Ø, 1240/1650W
29-½ x 23- 51 7.89
$2,480.00
MOD200TDMAF 21921
Autofill, Thermostat control with Drain
Manifold,208/240V,
3Ø (1Ø), 1240/1650W each
29-½ x 23- 65 7.89
$3,265.00
MOD200TDAF N/A
Autofill, Thermostat control with Drain
NO Manifold,208/240V, 3Ø (1Ø), 1240/1650W each
29-½ x 23- 65 7.89
$3,220.00
V Two Pan 12” x 20” Slim Line, Narrow-Width, Top-Mount
MOD200TDN 23218
Thermostat control, with Drain
208/240V, 1Ø, 1240/1650W each
45- x 15-¾ 51 10.55
$2,660.00
MOD200TDMN 23211
Thermostat control, with Drain Manifold
208/240V, 1Ø, 1240/1650W each
45- x 15-¾ 60 10.55
$2,695.00
MOD200TDMNAF 23212
Autofill, Thermostat control with
Drain Manifold, 208/240V, 3Ø (1Ø), 1240/1650W each
45- x 15-¾ 65 10.55
$3,415.00
N/A N/A 6’ cord & plug for Thermostatic Control models only
(MOD200s in 208/240V)
- - -
$62.00
V Two Pan 12” x 27”, Top-Mount
MOD227TDM 22275
Thermostat control, with Drain Manifold
208/240V, 1Ø , 1240/1650W each
29-½ x 30-9/16 65 10.15
$3,090.00
MOD227TDMAF 22279
Autofill, Thermostat control, with
Drain Manifold, 208/240V, 3Ø (1Ø), 1240/1650W each
29-½ x 30-9/16 65 10.15
$3,860.00
TWO PAN
TOPMOUNT
MOD200TDM
BUILT-IN / DROP-IN WARMERS
OPTIONAL CORDS AND PLUGS ARE AVAILABLE ON THERMOSTATIC CONTROL MODELS ONLY 120V & 208240V MODELS.
AUTOFILL MODELS REQUIRE A WATER CONNECTION. PLEASE REFER TO THE OPERATOR’S MANUAL AND INSTALLATION INSTRUCTIONS
FOR DETAILS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 21
BUILT-IN / DROP-IN WARMERS
THREE PAN
TOPMOUNT
MOD300TDMN/AF
Slim Line
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
V Three Pan 12” x 20”, Top-Mount
MOD300 20363
Infinite control
208/240V, 3Ø (1Ø), 900/1200W each
CSA model available: 208V 13.5A, 240V 15A
43-½ x 23- 73 10.54
$2,720.00
MOD300D 20697
Infinite control, with Drain
208/240V, 3Ø (1Ø), 900/1200W each
43-½ x 23- 74 10.54
$3,045.00
MOD300DM 20366
Infinite control, with Drain Manifold
208/240V, 3Ø (1Ø), 900/1200W each
43-½ x 23- 78 10.54
$3,095.00
MOD300T 21892
Thermostat control
208/240V, 3Ø (1Ø), 1240/1650W each
43-½ x 23- 75 10.54
$2,955.00
MOD300TD 21891
Thermostat control, with Drain
208/240V, 3Ø (1Ø), 1240/1650W each
43-½ x 23- 75 10.54
$3,300.00
MOD300TDM 21890
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W
43-½ x 23- 78 10.54
$3,440.00
MOD300TDMAF 21922
Autofill, Thermostat control with Drain
Manifold,208/240V, 3Ø (1Ø), 1240/1650W each
43-½ x 23- 90 10.54
$4,210.00
MOD300TDAF -
Autofill, Thermostat control with Drain
NO Manifold,208/240V, 3Ø, 1240/1650W each
43-½ x 23- 90 10.54
$4,030.00
V Three Pan 12” x 20” Slim Line, Narrow-Width, Top-Mount
MOD300TDN 23219
Thermostat control, with Drain
208/240v, 3Ø, (1Ø) 1240/1650 W each
67-15/16 x 15-¾ 82 10.54
$3,495.00
MOD300TDMN 23213
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
67-15/16 x 15-¾ 85 10.54
$3,530.00
MOD300TDMNAF 23214
Autofill, Thermostat control with
Drain Manifold, 208/240V, 3Ø (1Ø),
1240/1650W each
67-15/16 x 15-¾ 78 10.54
$4,300.00
V Three Pan 12” x 27”, Top-Mount
MOD327T 22276
Thermostat control, NO Drain
208/240V, 3Ø, 1240/1650W each
43-½ x 30-9/16 90 12.45
$3,930.00
MOD327TD 22280
Thermostat control, with Drain
208/240V, 3Ø, 1240/1650W each
43-½ x 30-9/16 90 12.45
$4,245.00
MOD327TDM 22276
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
43-½ x 30-9/16 90 12.45
$4,280.00
MOD327TDMAF 22280
Autofill, Thermostat control, with
Drain Manifold, 208/240V, 3Ø (1Ø),
1240/1650W each
43-½ x 30-9/16 90 12.45
$5,050.00
ALL MOD300’S SHIP 3Ø AND ARE FIELD CONVERTIBLE TO 1Ø
AUTOFILL MODELS REQUIRE A WATER CONNECTION. PLEASE REFER TO THE OPERATOR’S MANUAL AND INSTALLATION INSTRUCTIONS FOR DETAILS
ACCESSORIES PAGE 38 & 39
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
22
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
V Four Pan 12” x 20”, Top-Mount
MOD400 20364
Infinite control
208/240V, 3Ø (1Ø), 900/1200W each
CSA model available: 208V 18.3A, 240V 20A
57-½ x 23- 95 13.56
$3,630.00
MOD400D 20698
Infinite control, with Drain
208/240V, 3Ø (1Ø), 900/1200W each
57-½ x 23- 95 13.56
$4,170.00
MOD400DM 20367
Infinite control, with Drain Manifold
208/240V, 3Ø (1Ø), 900/1200W each
57-½ x 23- 98 13.56
$4,510.00
MOD400T 21895
Thermostat control
208/240V, 3Ø (1Ø), 1240/1650W each
57-½ x 23- 98 13.56
$3,825.00
MOD400TD 21894
Thermostat control, with Drain
208/240V, 3Ø (1Ø), 1240/1650W each
57-½ x 23- 105 13.56
$4,400.00
MOD400TDM 21893
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W
57-½ x 23- 105 13.56
$4,660.00
MOD400TDAF -
Autofill, Thermostat control with Drain, NO Manifold
208/240V, 3Ø, 1240/1650W each
57-½ x 23- 112 13.56
$5,670.00
MOD400TDMAF 21923
Autofill, Thermostat control with Drain, Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
57-½ x 23- 112 13.56
$5,490.00
MOD400TDMAFS 22705
Autofill, Single control panel,
Thermostat control with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
57-½ x 23- 112 13.56
$5,490.00
V Four Pan 12” x 27”, Top-Mount
MOD427TDM 22277
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
57-½ x 30-9/16 112 15.85
$5,740.00
MOD427TDMAF 22281
Autofill, Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
57-½ x 30-9/16 112 19.15
$6,570.00
MOD427TDMAF1 22707
Autofill, Single control panel, Thermostat control,
with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
57-½ x 30-9/16 124 19.15
$6,570.00
FOUR PAN
TOPMOUNT
MOD400
MOD427TDM
BUILT-IN / DROP-IN WARMERS
ALL MOD300’S SHIP 3Ø AND ARE FIELD CONVERTIBLE TO 1Ø
AUTOFILL MODELS REQUIRE A WATER CONNECTION. PLEASE REFER TO THE OPERATOR’S MANUAL AND INSTALLATION
INSTRUCTIONS FOR DETAILS.
ACCESSORIES PAGE 38 & 39
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 23
BUILT-IN / DROP-IN WARMERS
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
V Five Pan 12” x 20”, Top-Mount
MOD500 20365
Infinite control
208/240V, 3Ø (1Ø), 900/1200W each
CSA model available: 208V 23A, 240V 25A
71-½ x 23- 105 16.57
$4,550.00
MOD500D 20669
Infinite control, with Drain
208/240V, 3Ø (1Ø), 900/1200W each
71-½ x 23- 116 16.57
$5,070.00
MOD500DM 20368
Infinite control, with Drain Manifold
208/240V, 3Ø (1Ø), 900/1200W each
71-½ x 23- 118 16.57
$5,560.00
MOD500T 21898
Thermostat control
208/240V, 3Ø (1Ø), 1240/1650W each
71-½ x 23- 116 16.57
$4,750.00
MOD500TD 21897
Thermostat control, with Drain
208/240V, 3Ø (1Ø), 1240/1650W each
71 ½ x 23 116 16.57
$5,500.00
MOD500TDM 21896
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W
71-½ x 23- 122 16.57
$5,710.00
MOD500TDAF -
Autofill, Thermostat control with Drain, NO Manifold
208/240V, 3Ø, 1240/1650W each
71-½ x 23- 136 16.57 $6,380.00
MOD500TDMAF 21924
Autofill, Thermostat control with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
71-½ x 23- 136 16.57 $6,590.00
MOD500TDMAFS 22706
Autofill, Single control panel,
Thermostat control with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
71-½ x 23- 126 16.57
$6,590.00
V Five Pan 12” x 27”, Top-Mount
MOD527TDM 22278
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
71-½ x 30-9/16 136 19.15
$7,030.00
MOD527TDMAF 22282
Autofill, Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
71-½ x 30-9/16 232 37.30
$8,020.00
MOD527TDMAFS 22708
Autofill, Single control panel,
Thermostat control, with Drain Manifold
208/240V, 3Ø (1Ø), 1240/1650W each
71-½ x 30-9/16 232 37.30
$8,020.00
FIVE PAN
TOPMOUNT
MOD500
ALL MOD500’S SHIP 3Ø AND ARE FIELD CONVERTIBLE TO 1Ø
AUTOFILL MODELS REQUIRE A WATER CONNECTION. PLEASE REFER TO THE OPERATOR’S MANUAL AND INSTALLATION INSTRUCTIONS FOR DETAILS
ACCESSORIES PAGE 38 & 39 EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
24
BUILT-IN / DROP-IN WARMERS
Choose between models that are fully insulated around the
sides and bottom or standard non-insulated models. Fully in-
sulated models SAVE ENERGY and may be
installed in nonmetal counters.
FULLY INSULATED
ROUND WARMERS
SAVE
GREEN!
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 25
BUILT-IN / DROP-IN WARMERS
LETTER OPTION
T THERMOSTAT CONTROLS
UUL APPROVED
C CORD & PLUG
I INSULATED
D DRAIN
AF Auto Fill
Auto Fill Models available
7-quart
SS10TDU
Q LISTED MODELS WITH INFINITE CONTROLS USE THESE CONTROLS
Q LISTED MODELS WITH THERMOSTATIC CONTROLS USE THESE CONTROLS
CONDUIT AND ENCLOSED BOX NOT SUPPLIED
V LISTED MODELS WITH THERMOSTATIC CONTROLS USE THESE CONTROLS
ONLY CULUS LISTED MODELS COME WITH CONDUIT AND ENCLOSED CONTROL BOX
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
26
BUILT-IN / DROP-IN WARMERS
ROUND WARMERS
TOPMOUNT
Approvals OLD
Model
Number
NEW
Model
Number
Part
Number
Description Dimensions
(in)
Ship
Weight
Cubic
Feet
Price
Round Warmers, Top-Mount, 4 Quart, Non-Insulated
Q NSS4 SS4 - 4 quart, Infinite control
208V, 1.62A, 338W, 240V, 1.87A, 450W
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $550.00
Q NSS4D-120 SS4D-120 21249 4 quart, Infinite control, with Drain
120V, 1Ø, 450W
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $660.00
V N SS4ULT-120 SS4TU-120 21553 4 quart, Thermostat control
120V, 1Ø, 825W
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $750.00
V N SS4ULT SS4TU 21554 4 quart, Thermostat control
208/240V, 1Ø, 620/825W
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $750.00
V N SS4ULTD-120 SS4TDU-120 21555 4 quart, Thermostat control with Drain
120V, 1Ø, 825W
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $790.00
V N SS4ULTD SS4TDU 21556 4 quart, Thermostat control with Drain
208/240V, 1Ø, 620/825W
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $790.00
V N SS4TUC-120 SS4TUC-120 - 4 quart, Thermostat control
120V, 1Ø, 825W. With cord and plug
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $810.00
V N SS4TUC SS4TUC - 4 quart, Thermostat control,
208/240V, 1Ø, 620/825W. With cord and plug
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $810.00
V N SS4TDUC-120 SS4TDUC-120 - 4 quart, Thermostat control with Drain
120V, 1Ø, 825W. With cord and plug
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $845.00
V N SS4TDUC SS4TDUC - 4 quart, Thermostat control with Drain
208/240V, 1Ø, 620/825W. With cord and plug
8-1/4” O.D. 6 lbs.
2.8 kg
0.82 $845.00
Round Warmers, Top-Mount, 4 Quart, Insulated
V N SS4TUI SS4TUI - 4 quart, Thermostat control
208/240V, 1Ø, 620/825W
8-1/4” O.D. 9.6 lbs.
4.4 kg 0.82 $885.00
V N SS4TDUI-120 SS4TDUI-120 - 4 quart, Thermostat control, with Drain
120V, 1Ø, 825W
8-1/4” O.D. 9.6 lbs.
4.4 kg 0.82 $945.00
V N SS4TDUI SS4TDUI - 4 quart, Thermostat control with Drain
208/240V, 1Ø, 620/825W
8-1/4” O.D. 9.6 lbs.
4.4 kg 0.82 $945.00
V N SS4TUCI-120 SS4TUCI-120 - 4 quart, Thermostat control,
120V, 1Ø, 825W
8-1/4” O.D. 9.6 lbs.
4.4 kg 0.82 $945.00
V N SS4TUCI SS4TUCI - 4 quart, Thermostat control
208/240V, 1Ø, 620/825W
8-1/4” O.D. 9.6 lbs.
4.4 kg 0.82 $945.00
V N SS4TDUCI-120 SS4TDUCI-120 - 4 quart, Thermostat control, with Drain
120V, 1Ø, 825W
8-1/4” O.D. 9.6 lbs.
4.4 kg 0.82 $1,005.00
V N SS4TDUCI SS4TDUCI - 4 quart, Thermostat control with Drain
208/240V, 1Ø, 620/825W
8-1/4” O.D. 9.6 lbs.
4.4 kg 0.82 $1,005.00
SS8
SS10TD
SS10TDU
ACCESSORIES PAGE 38 & 39
EXPORT MODELS CANNOT BE RETURNED
BUILT-IN / DROP-IN WARMERS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 27
BUILT-IN / DROP-IN WARMERS
ROUND WARMERS
TOPMOUNT
Approvals OLD
Model
Number
NEW
Model
Number
Part
Number Description Size Ship
Weight Cubic
Feet Price
Round Warmers, Top-Mount, 7 Quart, Non-Insulated
Q NSS8 SS8 20128 7 quart, Infinite control
208/240V, 1Ø, 338/450W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $475.00
Q NSS8D-120 SS8D-120 20127 7 quart, Infinite control, with Drain
120V, 1Ø, 450W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $545.00
Q N SS8D SS8D 20129 7 quart, Infinite control, with Drain
208/240V, 1Ø, 338/450W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $545.00
Q NSS8TD-120 SS8TD-120 21018 7 quart, Thermostat control, with Drain
120V, 1Ø, 825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $620.00
Q NSS8TD SS8TD 21019 7 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $620.00
V N SS8ULT-120 SS8TU-120 21560 7 quart, Thermostat control
120V, 1Ø, 825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $650.00
V N SS8ULT SS8TU 21561 7 quart, Thermostat control
208/240V, 1Ø, 620/825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $650.00
FSS8EUT-230 SS8EUT-230 22376 7 quart, Thermostat control
220-240V, 1Ø, 825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $680.00
V N SS8ULTD-120 SS8TDU-120 21562 7 quart, Thermostat control, with Drain
120V, 1Ø, 825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $730.00
V N SS8ULTD SS8TDU 21563 7 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $730.00
FSS8EUTD-230 SS8EUTD-230 22379 7 quart, Thermostat control, with Drain
220-240V, 1Ø, 825W
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $755.00
V N SS8TUC-120 SS8TUC-120 - 7 quart, Thermostat control
120V, 1Ø, 825W, With cord and plug
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $745.00
V N SS8TUC SS8TUC - 7 quart, Thermostat control
208/240V, 1Ø, 620/825W, With cord and plug
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $745.00
V N SS8TDUC-120 SS8TDUC-120 - 7 quart, Thermostat control with Drain
120V, 1Ø, 825W. With cord and plug
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $790.00
V N SS8TDUC SS8TDUC - 7 quart, Thermostat control with Drain
208/240V, 1Ø, 620/825W, With cord and plug
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $790.00
FSS8TDU-230 SS8TDU-230 - 7 quart, Thermostat control with Drain
220-240V, 1Ø, 825W, With cord and plug
10-1/16” O.D. 6 lbs.
2.8 kg
1.62 $790.00
Round Warmers, Top-Mount, 7 Quart, Insulated
V N SS8TUI-120 SS8TUI-120 -7 quart, Thermostat control
120V, 1Ø, 825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $790.00
V N SS8TUI SS8TUI -7 quart, Thermostat control
208/240V, 1Ø, 620/825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $790.00
V N SS8TDUI-120 SS8TDUI-120 -7 quart, Thermostat control with Drain
120V, 1Ø, 825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $870.00
V N SS8TDUI SS8TDUI -7 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $870.00
V N SS8TUCI-120 SS8TUCI-120 -7 quart, Thermostat control
120V, 1Ø, 825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $870.00
V N SS8TUCI SS8TUCI -7 quart, Thermostat control
208/240V, 1Ø, 620/825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $870.00
V N SS8TDUCI-120 SS8TDUCI-120 -7 quart, Thermostat control with Drain
120V, 1Ø, 825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $940.00
V N SS8TDUCI SS8TDUCI -7 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $940.00
ACCESSORIES PAGE 38 & 39
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
28
ROUND WARMERS
TOPMOUNT
Approvals OLD
Model
Number
NEW
Model
Number
Part
Number
Description Dimensions
(in)
Ship
Weight
Cubic
Feet
Price
Round Warmers, Top-Mount, 11 Quart, Non-Insulated
Q N SS10D-120 SS10D-120 20131 11 quart, Infinite control, with Drain
120V, 1Ø, 450W
12” O.D. 7 lbs.
3.2 kg
1.62 $555.00
Q N SS10D SS10D 20133 11 quart, Infinite control, with Drain
208/240V, 1Ø, 338/450W
12” O.D. 7 lbs.
3.2 kg
1.62 $555.00
Q N SS10T-120 SS10T-120 20966 11 quart, Thermostat control
120V, 1Ø, 825W
12” O.D. 7 lbs.
3.2 kg
1.62 $575.00
Q N SS10T-208 SS10T 20967 11 quart, Thermostat control
208/240V, 1Ø, 620/825W
12” O.D. 7 lbs.
3.2 kg
1.62 $575.00
FSS10T-230 SS10T-230 22371 11 quart, Thermostat control
220-240V, 1Ø, 825W
12” O.D. 7 lbs.
3.2 kg
1.62 $670.00
Q N SS10TD-120 SS10TD-120 21020 11 quart, Thermostat control, with Drain
120V, 1Ø, 825W
12” O.D. 7 lbs.
3.2 kg
1.62 $655.00
Q N SS10TD SS10TD 21021 11 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
12” O.D. 7 lbs.
3.2 kg
1.62 $655.00
FSS10TD-230 SS10TD-230 22371 11 quart, Thermostat control, with Drain
220-240V, 1Ø, 825W
12” O.D. 7 lbs.
3.2 kg
1.62 $745.00
V N SS10ULT-120 SS10TU-120 21567 11 quart, Thermostat control
120V, 1Ø, 825W
12” O.D. 7 lbs.
3.2 kg
1.62 $655.00
V N SS10ULT SS10TU 21568 11 quart, Thermostat control
208/240V, 1Ø, 620/825W
12” O.D. 7 lbs.
3.2 kg
1.62 $655.00
V N SS10ULTD-120 SS10TDU-120 21569 11 quart, Thermostat control, with Drain
120V, 1Ø, 825W
12” O.D. 7 lbs.
3.2 kg
1.62 $720.00
V N SS10ULTD SS10TDU 21570 11 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
12” O.D. 7 lbs.
3.2 kg
1.62 $720.00
V N SS10TUC-120 SS10TUC-120 - 11 quart, Thermostat control
120V, 1Ø, 825W, With cord and plug
12” O.D. 7 lbs.
3.2 kg
1.62 $710.00
V N SS10TUC SS10TUC - 11 quart, Thermostat control
208/240V, 1Ø, 620/825W, With cord and plug
10-1/16” O.D. 7 lbs.
3.2 kg
1.62 $710.00
V N SS10TDUC-120 SS10TDUC-120 - 11 quart, Thermostat control, with Drain
120V, 1Ø, 825W, With cord and plug
10-1/16” O.D. 7 lbs.
3.2 kg
1.62 $780.00
V N SS10TDUC SS10TDUC - 11 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W, With cord and plug
10-1/16” O.D. 7 lbs.
3.2 kg
1.62 $780.00
Round Warmers, Top-Mount, 11 Quart, Insulated
V N SS10TUI-120 SS10TUI-120 - 11 quart, Thermostat control
120V, 1Ø, 825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $785.00
V N SS10TUI SS10TUI - 11 quart, Thermostat control
208/240V, 1Ø, 620/825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $785.00
V N SS10TDUI-120 SS10TDUI-120 - 11 quart, Thermostat control, with Drain
120V, 1Ø, 825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $850.00
V N SS10TDUI SS10TDUI - 11 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $850.00
V N SS10TUCI-120 SS10TUCI-120 - 11 quart, Thermostat control
120V, 1Ø, 825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $850.00
V N SS10TUCI SS10TUCI - 11 quart, Thermostat control
208/240V, 1Ø, 620/825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $850.00
V N SS10TDUCI-120 SS10TDU-
CI-120 - 11 quart, Thermostat control, with Drain
120V, 1Ø, 825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $935.00
V N SS10TDUCI SS10TDUCI - 11 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $935.00
BUILT-IN / DROP-IN WARMERS
ACCESSORIES PAGE 38 & 39
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 29
BUILT-IN / DROP-IN WARMERS
ACCESSORIES PAGE 38 & 39 EXPORT MODELS CANNOT BE RETURNED
AUTOFILL MODELS REQUIRE A WATER SUPPLY CONNECTION. PLEASE REFER TO THE OPERATOR’S MANUAL AND INSTALLATION
INSTRUCTIONS FOR DETAILS.
WHEN MANIFOLDING AUTO FILL MODELS WITH NONAUTO FILL MODELS, USE ALL NEW WARMERS MANUFACTURED STARTING IN 2015.
Approvals Model
Number
Part
Number
Description Size Ship
Weight
Cubic
Feet
Price
Round Warmers, Top-Mount, 7 & 11 Quart, Fully Insulated with Auto Fill
N V SS8TDUIAF120 -7 quart, Thermostat control, with Drain
120V, 1Ø, 825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $1,445.00
N V SS8TDUIAF -7 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $1,515.00
N V SS8TDUCIAF12 -7 quart, Thermostat control, with Drain
120V, 1Ø, 825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $1,515.00
N V SS8TDUCIAF -7 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 10.3 lbs.
(4.7) kg
1.62 $1,515.00
V N SS10TDUIAF12 -11 quart, Thermostat control, with Drain
120V, 1Ø, 828W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $1,445.00
V N SS10TDUIAF -11 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W
10-1/16” O.D. 12.4 lbs.
(5.6) kg
1.62 $1,445.00
V N SS10TDUCIA12 -11 quart, Thermostat control, with Drain
120V, 1Ø, 828W 10-1/16” O.D. 12.4 lbs.
(5.6) kg 1.62 $1,515.00
V N SS10TDUCIAF -11 quart, Thermostat control, with Drain
208/240V, 1Ø, 620/825W 10-1/16” O.D. 12.4 lbs.
(5.6) kg 1.62 $1,515.00
ROUND WARMERS
FULLY INSULATED
WITH AUTO FILL
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
30
BUILT-IN / DROP-IN WARMERS
Q LISTED MODELS WITH INFINITE CONTROLS USE THESE CONTROLS
Q LISTED MODELS WITH THERMOSTATIC CONTROLS USE THESE CONTROLS
CONDUIT AND ENCLOSED BOX NOT SUPPLIED
V LISTED MODELS WITH THERMOSTATIC CONTROLS USE THESE CONTROLS
(Only cULus Listed models come with conduit and enclosed control box)
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 31
BUILT-IN / DROP-IN WARMERS
Approvals Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
Single Pan 12” x 20”, Top-Mount
QSS206-120
SS206
20120
20121
Infinite Control
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
CSA Models available 120V-10AMPS, 1200 W
208V-4.3AMPS, 900 W, 240V-5.0AMPS, 1200W
13-11/16 x 21-¾ 16 2.97
$600.00
$600.00
QSS206D-120
SS206D
20122
20123
Infinite Control, with Drain
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
13-11/16 x 21-¾ 16 2.97
$700.00
$700.00
SS206T-120
SS206T
SS206ET-230
21269
21270
22377
Thermostat Control
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
220-240V, 1Ø, 1200W
CSA Models available 120V-10AMPS, 1200 W
208V-4.3AMPS, 900 W, 240V-5.0AMPS, 1200 W
13-11/16 x 21-¾ 16 2.97
$670.00
$670.00
$835.00
VSS206TU-120
SS206TU
21575
21576
Thermostat Control
120V, 1Ø, 1650W
208/240V, 1Ø, 1240/1650W
13-11/16 x 21-¾ 20 4.15
$750.00
$750.00
QSS206TD-120
SS206TD
SS206TD-230
21271
21265
22378
Thermostat Control, with Drain
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
220-240V, 1Ø, 1200WV
13-11/16 x 21-¾ 15 2.97
$725.00
$725.00
$935.00
VSS206TDU-120
SS206TDU
21594
21577
Thermostat Control, with Drain
120V, 1Ø, 1650W
208/240V, 1Ø, 1240/1650W
13-11/16 x 21-¾ 21 4.15
$820.00
$820.00
Single Pan 12” x 27”, Top-Mount
VSS276TU-120
SS276TU
22101
22102
Thermostat Control
120V, 1Ø, 1650W
208/240V, 1Ø, 1240/1650W
CSA Models available 120V, 1Ø 1650W,
208/240 V, 1Ø, 1240/1650W
13-½ x 28-½ 22 3.85
$950.00
$950.00
VSS276TDU-120
SS276TDU
22103
22104
Thermostat Control, with Drain
120V, 1Ø, 1650W
208/240V, 1Ø, 1240/1650W
CSA Models available 120V, 1Ø 1650W,
208/240 V, 1Ø, 1240/1650W
13 -½ x 28-½ 22 3.85
$975.00
$975.00
SINGLE PAN
TOPMOUNT
SS206D SS206TDU SS276TDU
ACCESSORIES PAGE 38 & 39 EXPORT MODELS CANNOT BE RETURNED
F
F
Q
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
32
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
Single Pan 12” x 20”, Bottom-Mount, Square Corners
QSS206ET 21286
Thermostat Control
208/240V, 1Ø, 900/1200W
13-11/16 x 21-¾ 15 2.97
$690.00
QSS206ETD-120
SS206ETD
21272
21273
Thermostat Control, with Drain
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
13-11/16 x 21-¾ 15 2.97
$710.00
$710.00
QSS206TD6HI -
Thermostat Controls, with drains,
HIGHER WATTAGE, 6’ leads are standard
208/240V, 1Ø, 1365W
13-11/16 x 21-¾ 15 2.97
$710.00
QBMW206ST 21542
Thermostat Control
208/240V, 1Ø, 1240/1650W
13-11/16 x 21-
13/16
22 2.97
$655.00
VBMW206STU N/A
Thermostat Control
208/240V, 1Ø, 1240/1650W
13- x 21-15/16 24 2.97
$705.00
QBMW206SDU N/A
Infinite Control, with Drain
120V, 1Ø, 1000W
208/240V, 1Ø, 1000/1330W
13- x 21-15/16 24 2.97
$705.00
QBMW206SDT 21544
Thermostat Control, with Drain
208/240V, 1Ø, 1240/1650W
13-11/16 x 21-
13/16
22 2.97
$690.00
VBMW206STDU 22479
Thermostat Control, with Drain
208/240V, 1Ø, 1240/1650W
13- x 21-15/16 22 2.97
$765.00
QBMW206STDL120
BMW206STDL208
N/A Thermostat Control, with Drain, Low Wattage
120V, 1Ø, 1000W
208/240V, 1Ø, 1000/1330W
13- x 21-15/16 24 2.97
$735.00
$735.00
SINGLE PAN
BOTTOMMOUNT
WITH SQUARE CORNERS
BMW206STDU
SS206ET
BUILT-IN / DROP-IN WARMERS
ACCESSORIES PAGE 38 & 39
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 33
SINGLE PAN
BOTTOMMOUNT
WITH ROUND CORNERS
Approvals Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
Single Pan 12” x 20”, Bottom-Mount, Round Corners
QSS206ER-120
SS206ER
20788
20789
Infinite Control
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
13- x 21-15/16 14 2.97
$600.00
$600.00
QSS206ERD-120
SS206ERD
20790
20791
Infinite Control, with Drain
120V, 1Ø, 1200W
208/240V, 1Ø, 900/1200W
13- x 21-15/16 14 2.97
$700.00
$700.00
QBMW206RT -
21546
Thermostat Control
120V, 1Ø, 1200W
208/240V, 1Ø, 1240/1650W
13-11/16 x 21-
13/16
22 2.97
$670.00
QBMW206RTD120
BMW206RTD
21547
21548
Thermostat Control, with Drain
120V, 1Ø, 1200W
208/240V, 1Ø, 1240/1650W
13-11/16 x 21-
13/16
22 2.97
$670.00
$680.00
VBMW206RTU-
120V
-
Thermostat Control
120V, 1Ø, 1200W
13- x 21-15/16 22 2.97 $750.00
-
VBMW206RTDU 22482
Thermostat Control, with Drain
208/240V, 1Ø, 1240/1650W
13- x 21-15/16 22 2.97
$780.00
VBMW206RTDAFU 23052
Autofill, Thermostat Control, with Drain
208/240V, 1Ø, 1240/1650W
13- x 21-15/16 24 2.97
$1,450.00
SS206ERD
BUILT-IN / DROP-IN WARMERS
ACCESSORIES PAGE 38 & 39 EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
34
HALFSIZE PAN
TOPMOUNT
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
Single Pan Fractional Size Rectangular Warmers, Top-Mount, Thermostat Control
RHMP6-120 21050 Half Size Long, Holds a 6 x 20 pan
120V, 1Ø, 750W, without Wellslok™
6- x 20-¾ 11 2.54 $1,145.00
RHMP6D-120 21056 Half Size Long, Drain, Holds a 6 x 20 pan
120V, 1Ø, 750W, without Wellslok™
6- x 20-¾ 11 2.54 $1,170.00
UHMP6DU-120
HMPDU
HMP6T-230
21477
-
22367
Half Size Long, Drain, Holds a 6 x 20 pan
120V, 1Ø, 750W, without Wellslok™
208/240V without Wellslok, 1Ø, 620/825W
220-240V, 1Ø, 575W
6- x 20-¾ 14
2.54
2.54
2.54
$1,200.00
$1,200.00
$1,280.00
UHSW6-120 20986
Half Size, Holds a 12 x 10 pan
120V, 1Ø, 825W, with Wellslok™
11- x 13- 18
2.16 $1,280.00
UHSW6D-120
HSW6D
21232
22605
Half Size, Drain, Holds a 12 x 10 pan
120V, 1Ø, 450W, with Wellslok™
208/240V, 1Ø, 620/825W, with Wellslok™
11- x 13- 18 2.16
$1,285.00
$1,285.00
HMP6 HMP6DU
HSW6 & HSW6D
F
BUILT-IN / DROP-IN WARMERS
BUILT-IN / DROP-IN WARMERS
ACCESSORIES PAGE 38 & 39
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 35
BUILT-IN / DROP-IN WARMERS
COOK’N HOLD
HW106D Shown
with 54”” Wire Lead HWSMP6D
Model
Number
Part
Number
Description Size Ship
Weight
Cubic
Feet
Price
U Cook’N Hold, Thermostat Control, with Drain
HW106D-120
HW106D
20623
20656
11 quart Round
120V, 1Ø, 1650W
208/240V, 1Ø, 1240/1650W
CSA model available: 8.2A/7.1A, 50/60Hz, 208/240V, 1Ø
12 O.D. 12 1.60
$1,115.00
$1,115.00
HWSMP6D 21402
Hold one 12 x 20 pan 2 to 4 deep
208/240V, 1Ø, 1350/1800W
14-¾ W x
23-½D
26 3.85 $1,400.00
ACCESSORIES PAGE 38 & 39 EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
36
BUILT-IN / DROP-IN WARMERS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 37
BUILT-IN / DROP-IN WARMERS
*SELECT MODELS ARE FIELD CONVERTIBLE FROM 1Ø TO 3Ø
ACCESSORIES PAGE 38 & 39 EXPORT MODELS CANNOT BE RETURNED
BAIN MARIE
STYLE WARMERS
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
V Bain Marie Style Warmers, Top-Mount
HT200 22309 Opening 25 ¾ x 19
208/240V, 1Ø, 1800/2400W
29-½ x 23- 56 7.89 $2,140.00
HT300 22310 Opening 39 ¾ x 19
208/240V, 1Ø, 2700/3600W
43-½ x 23- 63 10.54 $2,540.00
HT400* 22311 Opening 53 ¾ x 19
208/240V, 1Ø (3Ø), 3600/4800W
57-½ x 23- 98 13.56 $3,015.00
HT500* 22312 Opening 67 ¾ x 19
208/240V, 1Ø (3Ø), 4500/6000W
71-½ x 23- 115 16.57 $3,420.00
V Bain Marie Style Warmers, Top-Mount, Large Capacity Opening
HT227 22606
Large Capacity, Opening 25 ¾ x 26
208/240V, 1Ø, 2480/3300W
29-½ x 30- 59 10.15 $2,680.00
V Bain Marie Style Warmers, Top-Mount, Autofill
HT200AF 22416
Autofill, Opening 25 ¾ x 19
208/240V, 1Ø, 1800/2400W
29-½ x 23- 57 7.89 $3,085.00
HT227AF 22610
Autofill, Large Capacity, Opening 25 ¾ x 26
208/240V, 1Ø, 2480/3300W
29-½ x 30- 65 10.15 $3,555.00
HT300AF 22313
Autofill, Opening 39 ¾ x 19
208/240V, 1Ø, 2700/3600W
43-½ x 23- 77 10.54 $3,460.00
HT400AF* 22314
Autofill, Opening 53 ¾ x 19
208/240V, 1Ø (3Ø), 3600/4800W
57-½ x 23- 98 13.56 $3,975.00
HT500AF* 22315
Autofill, Opening 67 ¾ x 19
208/240V, 1Ø (3Ø), 4500/6000W
71-½ x 23- 117 16.57 $4,700.00
HT300 HT200AF
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
38
BUILT-IN / DROP-IN WARMER ACCESSORIES
NEW Slope Top Adapters for
MOD, SMPT & TMPT Warmers
Standard 12” x 20”
Slim Line 12” x 20”
Use one adapter per well
One piece welded and pol-
ished HD stainless steel
Easily installs and remov-
able with out tools
Mix & match on multi-
Wells® warmers
Continuously welded and
polished corner seams
Raised NO-DRIP-LIP
on top
Adapts 12” x 20”
warmers @ 5°
SLOPE TOP ADAPTERS
Part
Number
Description Ship
Weight
Price
STA1220 Slope Top Adapter - Standard (one per well) 2 $330.00
STALS1220 Slope Top Adapter - Slim Line (one per well) 2 $330.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 39
BUILT-IN / DROP-IN WARMER ACCESSORIES
Part
Number
Description Ship
Weight
(lbs)
Price
ADAPTER TOPS FOR ROUND WARMERS
20177 Adapter Top, Converts 7 quart models to hold 4 quart inset 1 $66.00
20822 Adapter Top, Converts 11 quart models to hold 4 quart inset 2 $76.00
20175 Adapter Top, Converts 11 quart models to hold 7 quart inset 2 $76.00
ADAPTER TOPS FOR 12 x 20 ROUND CORNER WARMERS
23138 Adapter Top, Converts warmer to hold one 4 quart and one 11 quart inset 2 $66.00
23139 Adapter Top, Converts warmer to hold one 7 quart and one 11 quart inset 2 $66.00
23142 Adapter Top, Converts warmer to hold three 4 quart insets 2 $66.00
ADAPTER TOPS FOR 12 x 20 SQUARE CORNER WARMERS
20176 Adapter Top, Converts warmer to hold two 7 quart insets 2 $125.00
20434 Adapter Top, Converts warmer to hold two 4 quart and two 2 ½ quart insets 2 $135.00
21615 Adapter Top, Converts warmer to hold three 4 quart insets 2 $98.00
21621 Adapter Top, Converts warmer to hold one 7 quart and one 11 quart inset 2 $115.00
21624 Adapter Top, Converts warmer to hold four 2 ½ quart insets 2 $117.00
ADAPTER TOPS FOR 12 x 27 SQUARE CORNER WARMERS
22589 Adapter Top, Converts warmer to hold three 7 quart insets 1 $215.00
23115 Adapter Top, Converts warmer to hold two 11 quart insets 1 $200.00
INSETS WITH LIDS & LADLE
20774 4 quart Round Inset, Fits 6 ½ opening 2$120.00
20587 7 quart Round Inset, Fits 8 ½ opening 3$135.00
20908 11 quart Round Inset, Fits 10 ½ opening, with handles and slotted lid 4$250.00
21057 11 quart Round Inset, Fits 10 ½ opening, with hinged lid, NO handles 6$300.00
21860 8 ounce Soup Ladle 1 $56.00
BUILT-IN WARMER MISCELLANEOUS
21709 Drain Screen, Fits all models with drains, one per well required 1 $23.00
20385 Drain Valve Extension Kit, Extension from drain to counter front with remote handle, for use with “D”
models only, excluding “DM” models. Includes ½ brass drain valve
$235.00
22592 Wellslok™ Extension Kit*, For UL listed non-insulated circular warmers only to adapt to wood countertops
up to 1 ½ thick
1$98.00
22593 Wellslok™ Extension Kit*, For UL listed 12 x 20 warmers only to adapt to wood countertops up to 1 ½
thick
1$124.00
WL0330 Wellslok Extension kit for Fully Insulated Round Warmers only to adapt to wood countertops up to 1 ½”
thick
1$98.00
N/A • Optional 72 Wiring
• Thermostatically controlled warmers - one required per well
• Infinite Switch controlled models - one required per well
• Please contact factory for availability of optional wiring
$150.00
*Wellslok™ Extension Kits for UL listed units approved for installation in wood countertops.
One well unit requires one kit. Two to three well units require two kits. Four to five well units require three kits.
ADTBAR-HT Adapter bar for Bain Marie Style Warmers 1$45.00
ROUND & BUILTINDROPIN
WARMING ACCESSORIES
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
40
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 41
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
(lbs)
Cubic
Feet
Price
UVCurved Self-Contained Refrigerated Cold Pans, NSF Series 7
CRCP-72 N/A Two pan, R-134A Refrigerant, 115V, 1/4 HP, 5.5A, NEMA 5-15P 27 x 40- ½ 160 16.6 $8,590.00
CRCP-73 N/A Three pan, R-404A Refrigerant, 115V, 1/3 HP. 5.6A, NEMA 5-15P 29-¼ x 55-¾ 190 24.7 $9,075.00
CRCP-74 N/A Four pan, R-404A Refrigerant, 115V, 1/2 HP. 7.5A, NEMA 5-15P 30- x 74- 220 33.9 $9,850.00
CRCP-75 N/A Five pan, R-404A Refrigerant, 115V, 3/4 HP. 15.3 A, NEMA 5-15 32 x 90- 225 27.2 $12,600.00
NEW
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
(lbs)
Cubic
Feet
Price
N N Curved Iced (Non-Refrigerated) Cold Pans, NSF Series 2
CICP-72 N/A Two pan, R-134A Refrigerant, 115V, 1/4 HP, 5.5A, NEMA 5-15P 27 x 40- ½ 61 0.8 $2,299.00
CICP-73 N/A Three pan, R-404A Refrigerant, 115V, 1/3 HP. 5.6A, NEMA 5-15P 29-¼ x 55-¾ 65 10.8 $2,597.00
CICP-74 N/A Four pan, R-404A Refrigerant, 115V, 1/2 HP. 7.5A, NEMA 5-15P 30- x 74- 86 14.8 $2,830.00
CICP-75 N/A Five pan, R-404A Refrigerant, 115V, 3/4 HP. 15.3 A, NEMA 5-15P 32 x 90- 93 19.1 $3,150.00
COMPLIES
WITH
NSF-7
NEW CURVED SELF CONTAINED
COLD & ICE PANS
220V/230V/240V - 50HZ MODELS
All models of cold pans, dual temperature Pans and Frost Tops are available in 220V/230V/240V - 50HZ. Contact Factory for special pricing. Please
note that models with 1/4HP compressors use transformers while all other models use 220V/230V/240V - 50HZ compressor - condensing units.
CRCP-72
CICP-72
COMPLIES
WITH
NSF-2
NEW
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
42
HOT AND COLD PANS
HRCP7200
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
UVDual Temperature Wells for 12” x 20” Pans NSF 7
HRCP7100 N/A One pan, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W,
9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 4.9A, 1Ø, 134A refrigerant
19-1/8 x
27-1/8
175 11.3 $10,230.00
HRCP7200 22840 Two pans, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W,
9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 4.9A, 1Ø, 134A refrigerant
32-¾ x 27- 220 18.3 $10,700.00
HRCP7300 22841 Three pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W,
14.4/16.7A, 1Ø
(COLD) 115V, 1/3HP, 5.6A, 1Ø, 404A refrigerant
46-½ x 27- 240 25.8 $11.190.00
HRCP7400 22842 Four pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W,
18.1/20.8A, 1Ø
(COLD) 115V, 1/2HP, 6.4A, 1Ø, 404A refrigerant
60-¼ x 27- 275 33.3 $12,420.00
HRCP-7500 22843 Five pans, (HOT) 404A Refrigerant, 208/240V, 6.0/8.0W,
28.9/33.3A, 1Ø
(COLD) 115V, 3/4HP, 15.2A, 1Ø, 404A refrigerant
74 x 27- 298 41.0 $13,750.00
HRCP7600 22844 Six pans, (HOT) 404A Refrigerant, 208/240V, 6.0/8.0W,
28.9/33.3A, 1Ø
(COLD) 115V, 3/4HP, 15.2A, 1Ø, 404A refrigerant
87-¾ x 27- 320 47.8 $13,980.00
UVDual Temperature Slim Lines 12” x 20” Pans NSF 7
HRCP7200SL N/A Two pans, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W,
9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 4.9A, 1Ø, 134A refrigerant
49 x 19-1/8 220 18.26 $11,830.00
HRCP7300SL N/A Three pans, (HOT) 404A Refrigerant, 208/240V, 3.0/4.0W,
14.4/16.7A, 1Ø
(COLD) 115V, 1/3HP, 5.5A, 1Ø, 404A refrigerant
70 x 19-1/8 240 25.78 $12,300.00
HRCP7400SL N/A Four pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W,
18.1/20.8A, 1Ø
(COLD) 115V, 1/2HP, 8.9A, 1Ø, 404A refrigerant
92 x 19-1/8 275 33.3 $13,940.00
UVDual Temperature Slim Line, Slope Top 12” x 20” Pans NSF 7
HRCP7200SLST N/A Two pans, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W,
9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 4.9A, 1Ø, 134A refrigerant
49 x 19-1/8 220 18.26 $12,390.00
HRCP7300SLST N/A Three pans, (HOT) 404A Refrigerant, 208/240V, 3.0/4.0W,
14.4/16.7A, 1Ø
(COLD) 115V, 1/3HP, 5.5A, 1Ø, 404A refrigerant
70 x 19-1/8 240 25.78 $12,890.00
HRCP7400SLST N/A Four pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W,
18.1/20.8A, 1Ø
(COLD) 115V, 1/2HP, 8.9A, 1Ø, 404A refrigerant
92 x 19-1/8 275 33.3 $14,600.00
EXPORT MODELS AVAILABLE, CONTACT FACTORY FOR DETAILS AND PRICING
ACCESSORIES PAGE 48
EXPORT MODELS CANNOT BE RETURNED
REMOTE SYSTEMS AVAILABLE SEE PAGE 48 FOR DETAILS
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
COMPLIES
WITH
NSF-7
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 43
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
UV4-3rd Size Pans - Dual Temperature NSF 7
HRCP7143 N/A One pan, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W, 9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 3.9A, 1Ø, 134A refrigerant
19-1/8 x
34-1/4
115 11.3
$11,650.00
HRCP7243 N/A Two pans, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W, 9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 3.9A, 1Ø, 134A refrigerant
32-3/4 x
34-1/4
140 18.3 $13,600.00
HRCP7343 N/A Three pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W, 14.4/16.7A, 1Ø
(COLD) 115V, 1/3HP, 6.2A, 1Ø, 404A refrigerant
46-1/2 x
34-1/4
175 25.8 $17,500.00
HRCP7443 N/A Four pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W, 18.1/20.8A, 1Ø
(COLD) 115V, 1/2HP, 7.0A, 1Ø, 404A refrigerant
60-3/4 x
34-1/4
210 33.3 $19,600.00
HRCP7543 N/A Five pans, (HOT) 404A Refrigerant, 208/240V, 6.0/8.0W, 28.9/33.3A, 1Ø
(COLD) 115V, 3/4HP, 15.8A, 1Ø, 404A refrigerant
74 x 34-
1/4
245 41.0 $24,100.00
HRCP7643 N/A Six pans, (HOT) 404A Refrigerant, 208/240V, 6.0/8.0W, 28.9/33.3A, 1Ø
(COLD) 115V, 3/4HP, 15.8A, 1Ø, 404A refrigerant
87-3/4 x
34-1/4
285 47.8 $26,000.00
UVDual Temperature 12” x 20” Pans, Slope Top, NSF 7
HRCP7100ST N/A One pan, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W, 9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 4.9A, 1Ø, 134A refrigerant
19-1/8 x
27-1/8
175 11.3 $12,150.00
HRCP7200ST N/A Two pans, (HOT) 134A Refrigerant, 208/240V, 1.9/2.5W, 9.0/10.4A, 1Ø
(COLD) 115V, 1/4HP, 4.9A, 1Ø, 134A refrigerant
32-3/4 x
27-1/8
220 18.3 $13,100.00
HRCP7300ST N/A Three pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W, 14.4/16.7A, 1Ø
(COLD) 115V, 1/3HP, 5.6A, 1Ø, 404A refrigerant
46-1/2 x
27-1/8
240 25.8 $13,640.00
HRCP7400ST N/A Four pans, (HOT) 404A Refrigerant, 208/240V, 3.8/5.0W, 18.1/20.8A, 1Ø
(COLD) 115V, 1/2HP, 6.4A, 1Ø, 404A refrigerant
60-1/4 x
27-1/8
275 33.3 $15,150.00
HRCP7500ST N/A Five pans, (HOT) 404A Refrigerant, 208/240V, 6.0/8.0W, 28.9/33.3A, 1Ø
(COLD) 115V, 3/4HP, 15.2A, 1Ø, 404A refrigerant
74 x 27-
1/8
298 41.0 $16,140.00
HRCP7600ST N/A Six pans, (HOT) 404A Refrigerant, 208/240V, 6.0/8.0W, 28.9/33.3A, 1Ø
(COLD) 115V, 3/4HP, 15.2A, 1Ø, 404A refrigerant
87-3/4 x
27-1/8
320 47.8 $16,830.00
HOT AND COLD PANS
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
EXPORT MODELS AVAILABLE, CONTACT FACTORY FOR DETAILS AND PRICING
ACCESSORIES PAGE 48
EXPORT MODELS CANNOT BE RETURNED
REMOTE SYSTEMS AVAILABLE SEE PAGE 48 FOR DETAILS
HRCP7300ST
COMPLIES
WITH
NSF-7
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
44
DROPIN REFRIGERATED
COLD PANS
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
UVNEW Refrigerated Wells for Fractional Size Pans, NSF Series 2
RCP-050 - One 1/2-size pan, R-134-A refrigerant, 115V, 1Ø, 1/6 HP, 2Amp, NEMA-
5-15P
17- x 15 76 0.68 $4,090.00
RCP-067 - One 2/3-size pan, R-134-A refrigerant, 115V, 1Ø, 1/6 HP, 2Amp, NEMA-
5-15P
17- x 18-½ 79 0.89 $4,100.00
UVRefrigerated Wells for 12” x 20” Pans, NSF Series 2
RCP100 22087 One pan, R-134-A refrigerant, 115V, 1Ø, 1/4 HP, 5.5A, NEMA-5-15P 17- x 25- 89 9.5 $4,200.00
RCP200 22088 Two pans, R-134-A refrigerant, 115V 1Ø, 1/4 HP, 5.5A, NEMA-5-15P 31 x 25- 182 16.0 $4,660.00
RCP300 22089 Three pans, R-404-A refrigerant, 115V, 1Ø, 1/4 HP, 5.5A, NEMA-5-15P 44-¾ x 25- 194 23.0 $4,930.00
RCP400 22090 Four pans, R-404-A refrigerant, 115V 1Ø, 1/3 HP, 6.5A, NEMA-5-15P 58-½ x 25- 258 30.0 $5,370.00
RCP500 22091 Five pans, R-404-A refrigerant, 115V 1Ø, 1/2 HP, 6.4A, NEMA-5-15P 72-¼ x 25- 278 36.5 $6,000.00
RCP600 22092 Six pans, R-404-A refrigerant, 115V, 1Ø, 1/2 HP, 6.4A, NEMA-5-15P 86 x 25- 290 43.5 $6,170.00
UVRCP Slim Lines, NSF Series 2
RCP200SL N/A Two pans, 134A refrigerant, 115V, 1/4 HP, 4.9A, 1Ø NEMA 5-15P 46-1/4 x 17-3/8 182 16 $5,650.00
RCP300SL N/A Three pans, 134A refrigerant, 115V, 1/3 HP, 5.6A, 1Ø NEMA 5-15P 67 x 17-3/8 194 23 $6,300.00
RCP400SL N/A Four pans , 404A refrigerant, 115V, 1/2 HP, 6.4A, 1Ø NEMA 5-15P 87-3/4 x 17-3/8 258 30 $6,480.00
UVRCP Slim Line, Slope Top, NSF Series 2
RCP200SLST N/A Two pans, 134A refrigerant, 115V, 1/4 HP, 4.9A, 1Ø NEMA 5-15P 46-1/4 x 17-3/8 182 16 $6,570.00
RCP300SLST N/A Three pans, 134A refrigerant, 115V, 1/3 HP, 5.6A, 1Ø NEMA 5-15P 67 x 17-3/8 194 23 $7,325.00
RCP400SLST N/A Four pans , 404A refrigerant, 115V, 1/2 HP, 6.4A, 1Ø NEMA 5-15P 87-3/4 x 17-3/8 258 30 $7,550.00
UVRCP Series Slope Tops, 12” x 20” Pans, NSF Series 2
RCP100ST N/A One pan, 134A refrigerant, 115V, 1/4HP, 5.5A, 1Ø, NEMA 5-15P 19-1/8 x 27 89 9.5 $5,380.00
RCP200ST N/A Two pans 134A refrigerant, 115V, 1/4HP, 5.5A, 1Ø, NEMA 5-15P 31-7/8 x 27 182 16.0 $6,240.00
RCP300ST N/A Three pans 134A refrigerant, 115V, 1/4HP, 5.5A, 1Ø, NEMA 5-15P 44-3/4 x 27 194 23.0 $6,900.00
RCP400ST N/A Four pans 404A refrigerant, 115V, 1/3HP, 5.6A, 1Ø, NEMA 5-15P 57-3/8 x 27 258 30.0 $7,140.00
RCP500ST N/A Five pans 404A refrigerant, 115V, 1/2HP, 6.4A, 1Ø, NEMA 5-15P 70-1/8 x 27 278 36.5 $7,820.00
RCP600ST N/A Six pans 404A refrigerant, 115V, 1/2HP, 6.4A, 1Ø, NEMA 5-15P 82-7/8 x 27 290 43.5 $8,300.00
UV4-3rd Size Standard Deep Depth Cold Pans, NSF Series 2
RCP143 N/A One pan, 134A refrigerant, 115V, 1/4HP, 4.9A, 1Ø, NEMA 5-15P 17-3/8 x 32-1/2 114 11.6 $6,700.00
RCP243 N/A Two pans 134A refrigerant, 115V, 1/4HP, 4.9A, 1Ø, NEMA 5-15P 31 x 32-1/2 232 20.2 $7,090.00
RCP343 N/A Three pans 404A refrigerant, 115V, 1/3HP, 5.6A, 1Ø, NEMA 5-15P 44-5/8 x 32-1/2 269 28.8 $9,240.00
RCP443 N/A Four pans 404A refrigerant, 115V, 1/2HP, 6.4A, 1Ø, NEMA 5-15P 58-1/4 x 32-1/2 358 37.4 $9,700.00
RCP543 N/A Five pans 404A refrigerant, 115V, 3/4HP, 7.2A, 1Ø, NEMA 5-15P 71-7/8 x 32-1/2 403 46.1 $11,440.00
RCP643 N/A Five pans 404A refrigerant, 115V, 3/4HP, 7.2A, 1Ø, NEMA 5-15P 85-1/2 x 32-1/2 440 54.7 $11,850.00
RCP300
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
EXPORT MODELS AVAILABLE, CONTACT FACTORY FOR DETAILS AND PRICING.
ACCESSORIES PAGE 48
EXPORT MODELS CANNOT BE RETURNED
REMOTE SYSTEMS AVAILABLE SEE PAGE 48 FOR DETAILS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 45
RCP7300
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
UVNEW Refrigerated Wells for Fractional Size Pans, NSF Series 7
RCP-7050 - One 1/2-size pan, R-134-A refrigerant, 115V, 1Ø, 1/6 HP, 2Amp, NEMA-
5-15P
19- x 16-¾ 84 0.89 $4,440.00
RCP-7067 - One 2/3-size pan, R-134-A refrigerant, 115V, 1Ø, 1/6 HP, 2Amp, NEMA-
5-15P
19- x 20-¼ 89 1.14 $4,450.00
UVRefrigerated Wells for 12” x 20” Pans - NSF 7
RCP7100 22449 One pan, 134A refrigerant, 115V, 4.9A, 1Ø, 1/4 HP, NEMA 5-15P 19- x 27- 115 11.3 $4,570.00
RCP7200 22450 Two pans, 134A refrigerant, 115V, 4.9A, 1Ø, 1/4 HP, NEMA 5-15P 32-¾ x 27- 140 18.3 $5,410.00
RCP7300 22451 Three pans, 404A refrigerant, 115V, 5.6A, 1Ø, 1/2 HP, NEMA 5-15P 46-½ x 27- 175 25.8 $5,540.00
RCP7400 22452 Four pans, 404-A refrigerant, 115V, 6.4A, 1Ø, 1/2 HP, NEMA 5-15P 60-¼ x 27- 210 33.3 $5,810.00
RCP7500 22453 Five pans, 404A refrigerant, 115V, 15.2A, 1Ø, 3/4 HP, NEMA 5-20P 74 x 27- 245 41.0 $6,340.00
RCP7600 22454 Six pans, 404A refrigerant, 115V, 15.2A, 1Ø, 3/4 HP, NEMA 5-20P 87-¾ x 27- 285 47.8 $7,090.00
UVRCP Slim Line, 12” x 20” Pans, NSF 7
RCP7200SL N/A Two pans, 404A refrigerant, 115V, 1/4 HP, 4.9A, 1Ø NEMA 5-15P 49 x 19- 220 18.26 $6,040.00
RCP7300SL N/A Three pans, 404A refrigerant, 115V, 1/3 HP, 5.6A, 1Ø NEMA 5-15P 70-1/2 x 19- 240 25.78 $6,650.00
RCP7400SL N/A Four pans , 404A refrigerant, 115V, 1/2 HP, 6.4A, 1Ø NEMA 5-15P 92 x 19- 275 33.3 $6,920.00
UVRCP Slim Line, Slope Top, 12” x 20” Pans, NSF 7
RCP7200SLST N/A Two pans, 404A refrigerant, 115V, 1/4 HP, 4.9A, 1Ø NEMA 5-15P 49 x 19- 220 18.26 $6,890.00
RCP7300SLST N/A Three pans, 404A refrigerant, 115V, 1/3 HP, 5.6A, 1Ø NEMA 5-15P 70-1/2 x 19- 240 25.78 $7,690.00
RCP7400SLST N/A Four pans , 404A refrigerant, 115V, 1/2 HP, 6.4A, 1Ø NEMA 5-15P 92 x 19- 275 33.3 $8,000.00
UVRCP Slope Tops, 12” x 20” Pans, NSF 7
RCP7100ST N/A One pan 134A refrigerant, 115V, 1/4HP, 5.5A, 1Ø, NEMA 5-15P 17-1/8 x 25-1/8 115 11.3 $5,850.00
RCP7200ST N/A Two pans 134A refrigerant, 115V, 1/4HP, 5.5A, 1Ø, NEMA 5-15P 29-7/8 x 25-1/8 140 18.3 $6,600.00
RCP7300ST N/A Three pans 404A refrigerant, 115V, 1/3HP, 6.5A, 1Ø, NEMA 5-15P 42-5/8 x 25-1/8 175 25.8 $7,250.00
RCP7400ST N/A Four pans 404A refrigerant, 115V, 1/2HP, 7.5A, 1Ø, NEMA 5-15P 55-3/8 x 25-1/8 210 33.3 $7,550.00
RCP7500ST N/A Five pans 404A refrigerant, 115V, 3/4HP, 15.8A, 1Ø, NEMA 5-20P 68-1/8 x 25-1/8 245 41.0 $8,180.00
RCP7600ST N/A Six pans 404A refrigerant, 115V, 3/4HP, 15.8A, 1Ø, NEMA 5-20P 80-7/8 x 25-1/8 285 47.8 $8,930.00
UV4-3rd Size Cold Pans NSF 7
RCP7143 N/A One pan 134A refrigerant, 115V, 1/4HP, 5.5A, 1Ø, NEMA 5-15P 19-1/8 x 34-1/4 115 11.3 $7,180.00
RCP7243 N/A Two pans 134A refrigerant, 115V, 1/4HP, 5.5A, 1Ø, NEMA 5-15P 32-3/4 x 34-1/4 140 18.3 $7,640.00
RCP7343 N/A Three pans 404A refrigerant, 115V, 1/2HP, 6.5A, 1Ø, NEMA 5-15P 46-1/2 x 34-1/4 175 25.8 $9,800.00
RCP7443 N/A Four pans 404A refrigerant, 115V, 1/2HP, 7.5A, 1Ø, NEMA 5-15P 60-1/4 x 34-1/4 210 33.3 $10,300.00
RCP7543 N/A Five pans 404A refrigerant, 115V, 3/4HP, 15.8A, 1Ø, NEMA 5-20P 74 x 34-1/4 245 41.0 $12,100.00
RCP7643 N/A Six pans 404A refrigerant, 115V, 3/4HP, 15.8A, 1Ø, NEMA 5-20P 87-3/4 x 34-1/4 285 47.8 $12,525.00
COMPLIES
WITH
NSF-7
DROPIN REFRIGERATED
COLD PANS
EXPORT MODELS AVAILABLE, CONTACT FACTORY FOR DETAILS AND PRICING. EXPORT MODELS CANNOT BE RETURNED
ACCESSORIES PAGE 48 REMOTE SYSTEMS AVAILABLE SEE PAGE 48 FOR DETAILS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
46
DROPIN ICECOOLED PANS
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
NIce-Cooled Wells for 12” x 20” Pans - NSF Series 2
ICP100 22093 One pan 17- x 25- 89 9.5 $1,440.00
ICP200 22094 Two pans 31 x 25- 182 16 $1,685.00
ICP300 22095 Three pans 44-¾ x 25- 194 23 $1,970.00
ICP400 22096 Four pans 58-½ x 25- 258 30 $2,310.00
ICP500 22097 Five pans 72-¼ x 25- 278 36.5 $2,570.00
ICP600 22098 Six pans 86 x 25- 290 43.5 $2,940.00
NIce Pans, Slim Lines - NSF Series 2
ICP200SL N/A Two pans, slim 46-1/4 x 17-3/8 182 9.2 $2,110.00
ICP300SL N/A Three pans, slim 67 x 17-3/8 194 13.3 $2,410.00
ICP400SL N/A Four pans, slim 87-3/4 x 17-3/8 258 17.4 $2,840.00
NIce Pans, Slim Line, Slope Top - NSF Series 2
ICP200SLST N/A Two pans, slim 46-1/4 x 17-3/8 182 9.2 $2,450.00
ICP300SLST N/A Three pans, slim 67 x 17-3/8 194 13.3 $2,800.00
ICP400SLST N/A Four pans, slim 87-3/4 x 17-3/8 258 17.4 $3,320.00
NIce Pans, Slope Tops - NSF Series 2
ICP100ST N/A One pan, slope top 17-3/8 x 25-3/8 89 9.5 $1,950.00
ICP200ST N/A Two pans, slope top 31 x 25-3/8 182 16.0 $2,310.00
ICP300ST N/A Three pans, slope top 44-3/4 x 25-3/8 194 23.0 $2,640.00
ICP400ST N/A Four pans, slope top 58-1/2 x 25-3/8 258 30.0 $3,150.00
ICP500ST N/A Five pans, slope top 72-1/4 x 25-3/8 278 36.5 $3,585.00
ICP600ST N/A Six pans, slope top 86 x 25-3/8 290 43.5 $3,890.00
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 47
FROST TOPS
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
V N Frost Tops
FT-1 N/A One pan, 115V, 1/4HP, 4.9A, 1Ø, NEMA 5-15P, 134A refrigerant 21-1/4 x 29-1/4 103 9.6 $6,190.00
FT-2 N/A Two pans, 115V, 1/4HP, 4.9A, 1Ø, NEMA 5-15P, 134A refrigerant 39-1/4 x 29-1/4 125 17.2 $6,595.00
FT-3 N/A Three pans, 115V, 1/3HP, 5.6A, 1Ø, NEMA 5-15P, 404A refrigerant 57-1/4 x 29-1/4 140 24.8 $7,580.00
FT-4 N/A Four pans, 115V, 1/2HP, 6.4A, 1Ø, NEMA 5-15P, 404A refrigerant 75-1/4 x 29-1/4 155 32.4 $9,150.00
FT-5 N/A Five pans, 115V, 3/4HP, 15.2A, 1Ø, NEMA 5-20P, 404A refrigerant 93-1/4 x 29-1/4 170 40 $10,715.00
FT-6 N/A Five pans, 115V, 3/4HP, 15.2A, 1Ø, NEMA 5-20P, 404A refrigerant 111-1/4 x 29-1/4 187 47.6 $11,235.00
V N Frost Tops, Slim Lines
FT-2SL N/A Two pans, 115V, 1/4HP, 4.9A, 1Ø, 134A refrigerant 55-1/4 x 21-1/4 105 19.2 $7,180.00
FT-3SL N/A Three pans, 115V, 1/3HP, 5.6A, 1Ø, 404A refrigerant 81-1/4 x 21-1/4 119 28 $8,740.00
FT-4SL N/A Four pans, 115V, 1/2HP, 6.4A, 1Ø, 404A refrigerant 107-1/4 x 21-1/4 142 36.8 $10,420.00
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
EXPORT MODELS AVAILABLE, CONTACT FACTORY FOR DETAILS AND PRICING
ACCESSORIES PAGE 48
REMOTE SYSTEMS AVAILABLE SEE PAGE 48 FOR DETAILS
Model
Number
Part
Number
Description Ship
Weight
Cubic
Feet
Price
NEW Fractional Sized Cold Pans to Accommodate a Row of 1/16th, 1/4th Size or 1/2 Size Pans - Remote Only
CP6-20 N/A Three Each 1/16th Size Pans, R-134-A Refrigerant, 115V, 1Ø, 1/4 HP, 5.5A, NEMA 5-15P 76 0.68 CONTACT
FACTORY
CP6-27 N/A Four Each 1/16th Size Pans, R-134-A Refrigerant, 115V, 1Ø, 1/4 HP, 5.5A, NEMA 5-15P 84 0.89 CONTACT
FACTORY
CP6-34 N/A Five Each 1/16th Size Pans, R-134-A Refrigerant, 115V, 1Ø, 1/4 HP, 5.5A, NEMA 5-15P 89 1.14 CONTACT
FACTORY
NEW
CP6-34
NEW FRACTIONAL SIZED
COLD PANS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
48
REMOTE SYSTEM DETAILS
WELLS REMOTE SYSTEMS REFRIGERATION SPECIFICATIONS
3 types of remote systems are available for any model. Choose any model RCP, HRCP or Frost Top from pages 42 through 47 then choose the
type of remote system that best meets your application. When ordering add RC or PCL or NC to the end of the standard model number. Each type
system has different pricing. Contact factory for prices.
RC Series-Remote Condenser/Compressor housing is included but is not connected to Unit.
Without: Quick Disconnects and Pre-charged Refrigeration Lines
Includes: Cold pan is shipped unattached to the compressor base assembly. The refrigeration lines protrude out the bottom, have a vacuum pulled
and are filled with nitrogen, crimped then soldered shut. Compressor housing that is normally shipped attached to the pan instead ships loose in
the crate and attached to a galvanized base. There is 10’ of refrigeration copper tubing provided and is connected to the compressor on one end,
have a vacuum pulled, and are filled with nitrogen, crimped and soldered shut. No refrigerant is provided. It would be up to the installer to mount
the base assembly within the 10’ line length to be able to connect to the pan. On/off switch and thermostat are mounted to the compressor base
along with sight glass and TXV valve. HRCP family pans in this series are shipped with the control panel temporarily attached to the bottom of the
pan on a 3’ lead.
PCL Series- Remote Condenser/Compressor housing included but is not connected to Unit.
INCLUDES Quick Disconnects and Pre-charged Refrigeration Lines.
Includes: Cold pan is shipped unattached to the compressor base assembly. The refrigeration lines protrude out the bottom and have a quick con-
nect attached to the ends, they have been pre-charged with the proper refrigerant. Compressor housing that is normally shipped attached to the
pan instead ships loose in the crate and attached to a galvanized base. There is 10’ of refrigeration copper tubing provided and is connected to the
compressor on one end, the other end has a quick connect and the lines have been pre-charged with refrigerant. It would be up to the installer to
mount the base assembly within the 10’ line length to be able to connect to the pan. On/off switch and thermostat are mounted to the compres-
sor base along with sight glass and TXV valve. HRCP family pans in this series are shipped with the control panel temporarily attached to the
bottom of the pan on a 3’ lead.
NC Series - No Condenser/Compressor”-No Condenser/Compressor housing, this unit is to “tie into” another Refrigeration system.
Unit comes with Refrigeration lines “stubbed” out the bottom of the Unit, vacuum is pulled, lines charged with nitrogen, crimped then soldered
shut. No refrigerant is provided. HRCP family pans in this series are shipped with the control panel temporarily attached to the bottom of the pan
on a 3’ lead.
Now includes: Solenoid, electronic thermostat control (TTC) and on/off switch. The expansion valve is available as an option/accessory for
$265 list. Contact factory for correct expansion valve. Wiring diagram from Thermostat to solenoid valve(s).
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 49
REFRIGERATED AND DUAL-TEMPERATURE HOT/COLD PANS
REFRIGERATED COUNTER
TOP SERVER
Model
Number
Description Size
W x D x H (in)
Ship
Weight
Price
Refrigerated Counter Top Server
RCTS-4 Refrigerated Server, 120V, 1/16HP, 2A, 1Ø, NEMA 5-15P, 134A refrigerant 15-1/8 x 25-7/8 x 10-1/2 70 $1,795.00
RCTS-4-CVR Night Cover $300.00
Cold Pan Accessories
Part Number Description Ship Weight Price
ADTBAR-RCP Adaptor Bar for RCPs & HRCPs 2 $113.00
ADTBAR-RCP43 Adaptor Bar for RCP-43 and HRCPs Extra Deep 2 $113.00
ADBAR-SL Adaptor Bar for RCP and HRCP Slim Lines 2 $113.00
22107 Perforated Bottom Strainer Plate, for RCP100 or ICP100 (1 piece) 5 $300.00
22108 Perforated Bottom Strainer Plates, 1” thick, for RCP200 or ICP200 (2 pieces) 11 $360.00
22109 Perforated Bottom Strainer Plates, 1” thick, for RCP300 or ICP300 (2 pieces) 14 $515.00
22110 Perforated Bottom Strainer Plates, 1” thick, for RCP400 or ICP-400 (2 pieces) 18 $610.00
22111 Perforated Bottom Strainer Plates, 1” thick, for RCP500 or ICP-500 (2 pieces) 26 $790.00
22112 Perforated Bottom Strainer Plates, 1” thick, for RCP600 or ICP600 (3 pieces) 24 $990.00
5O-WL0296 Perforated Bottom Strainer Plate, 3” thick, for HRCP7100 or RCP7100 (1 piece) 9 $200.00
23199 Perforated Bottom Strainer Plate, 3” thick, for HRCP7200 or RCP7200 (1 piece) 11 $555.00
23200 Perforated Bottom Strainer Plates, 3” thick, for HRCP7300 or RCP7300 (2 pieces) 14 $645.00
23201 Perforated Bottom Strainer Plates, 3” thick, for HRCP7400 or RCP7400 (2 pieces) 48 $790.00
23202 Perforated Bottom Strainer Plates, 3” thick, for HRCP7500 or RCP7500 (2 pieces) 60 $790.00
22696 Pan Rail, For RCP7100 3 $160.00
22697 Pan Rail, For RCP7200 6 $180.00
22698 Pan Rail, For RCP7300 9 $185.00
22699 Pan Rail, For RCP7400 12 $185.00
22700 Pan Rail, For RCP7500 15 $200.00
22701 Pan Rail, For RCP7600 18 $210.00
N/A 6’ extended lead for remote mounting of on/off switch RCPs only - $375.00
N/A 6’ extended lead for remote mounting of control panel for HRCPs only (3’ lead standard) - $485.00
WEL 1 EXTENDED WARRANTY/LABOR - 2nd Year Parts & Labor - NET Price - NO discounts, can only be
purchased at point of sale -$385.00
WEL 5 Extended Warranty - 5 year Compressor (4 additional years) - NET Price - NO discounts, can only be
purchased at point of sale -$180.00
Export Models Contact factory for details and pricing - Contact
Wells
Shown with night
cover. Sold separately
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
50
COOKING PRODUCTS
Standard paperless oil
filtration system
reduces labor while
cleaning oil more
Automatic temperature
controls ensure precise and
even temperatures
Automatic basket lifts
maximize handling safety
Repeat cycle timer activates using
a single push-button operation
Mechanical or Solid State
Programmable
Controls (Model F55FS)
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 51
GAS COUNTERTOP &
FLOOR FRYERS
HIGH PRODUCTION
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
VOpen Auto-Lift Fryer, Electric, Single Basket
WFAE55F-208
WFAE55F-240
22532
22533
(55 lb.) Mechanical timer, oil filter
208V, 3Ø, 17.0KW
240V, 3Ø, 17.0KW
15-11/16 x 37-5/16 x
45-11/16
263 35
$20,750.00
$20,750.00
WFAE55FC-208
WFAE55FC-240
WFAE55FC
22460
22461
22559
(55 lb.) Solid State control, oil filter
208V, 3Ø, 17.0KW
240V, 3Ø, 17.0KW
Open Auto-Lift Fryer, Single Basket with Filter
380-415V, 3Ø, 17100W
15-11/16 x 37-5/16 x
45-11/16
249 35
$21,850.00
$21,850.00
$22,940.00
WFAE55F/FC
F
COOKING PRODUCTS
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
USingle Pot Fryers - Gas
GF-15 N/A (15 lb.) Gas, Two Half-Size Baskets
30,000 BTUH, NG or LP
12x25-1/8x23-3/8” 75 6.5 $3,340.00
GF-30 N/A (30 lb.) Gas, Two full-size baskets
70,000 BTUH is NG or 65,000 BTUH in LP
24x25-1/8x23-3/8” 118 13.6 $4,100.00
NEW
GF-15 GF-30
• Snap action thermostat ranges
from 200°F to 375°F
• Automatic pilot light for quick
and easy ignition
• Units are compact requiring only
12” or 24” of counter space
*SELECT MODELS ARE FIELD CONVERTIBLE FROM 3Ø TO 1Ø
ACCESSORIES PAGES 56
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
52
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
USingle Pot Fryers - Electric
LLF14-120
LLF14
21498
21499
(14 lb.) Two half-size baskets, Cord set
120V, 1Ø, 1.8kW, TCS, NEMA 5-15P
208/240V, 1Ø, 3.4/4.5KW, TCS, NEMA 6-30P
11 x 21- x 13-” 34 4.95
$1,395.00
$1,395.00
F15 N/A
(15 lb.) Two half-size baskets, Cord set
208/240V, 4.32/5.75KW, TCS, NEMA 6-30P
12x24x16-¾” 47 4.5
$1,925.00
F1725-208
F1725-240
20832
20833
(40 lb.) Two half-size baskets
208V, 3Ø, 17.25KW, TCS
240V, 3Ø, 17.25KW, TCS
15 x 29-½ x 18” 79 7.29
$5,285.00
$5,285.00
COUNTERTOP FRYERS
SINGLE POT
F
F15
COOKING PRODUCTS
All stainless steel cabinet for
maintenance free operation.
High-limit safety thermostat,
on-off switch and two indicator
lights provide safe and easy
operation.
Two large nickel-plated steel
mesh side hanging baskets
(4”W x 4-3/4”D x 11”L) provide
continuous flow of product
during peak periods.
Snap-action thermostat
ranges from 200°F to 375°F
and provides quick response
to temperature change.
One-piece 15 lb. lift out
stainless steel kettle is
standard for easy strain-
ing of oils
Immersion-type tubular heating
elements provide even heat
distribution and precise tem-
perature control.
Accessory full basket (8-3/4”W x
5-1/4”D x 10”L) available
ACCESSORIES PAGES 56
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 53
BUILTIN FRYERS
SINGLE POT
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
RSingle Pot Built-in Fryers - Electric
F556-208
F556-240
21156
21157
(15 lb.) Two half-size baskets
208V, 1Ø, 5.75KW, TCS
240V, 1Ø, 5.75KW, TCS
14-¾ x 23-½ 36 4.51
$2,440.00
$2,440.00
F586-208
F586-240
21162
21163
(15 lb.) Auto-Lift, One full-size basket
208V, 1Ø, 5.75KW, 60 Hz, TCS
240V, 1Ø, 5.75KW, 60 Hz, TCS
14-¾ x 23-½ 45 4.51
$3,940.00
$3,940.00
F586
COOKING PRODUCTS
Wellslok™ standard for
easy installation
Flat-blade, low-watt density
Elements for quick heating
and longer oil life
Auto Lift models available
(F-586)
Terminal block provided for
connection to power supply
Manual reset safety
thermostats provide
added protection from
over-temperatures
A red signal light indicates
any over temperature
condition
ACCESSORIES PAGES 56
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
54
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
UDual Pot Fryer - Electric
F30 N/A
(30 lb.) Two full-size baskets
208/240V, 8.64/11KW
24 x 24 x 16-3/4” 81 9 $3,365.00
COUNTERTOP FRYERS
DUAL POT
F30
ACCESSORIES PAGES 56
COOKING PRODUCTS
Swing-up elements
for ease of cleaning
Heavy-duty, deep-drawn
stainless steel fry pots
Nickel-plated wire
baskets included
Signal light indicates
when heating elements
are energized
Elements have a spring-loaded
support to secure elements in a
raised position
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 55
BUILTIN FRYERS
DUAL POT
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
RDual Pot Fryer
F886-208
F886-240**
23244
23245
(30 lb.) Two full-size baskets
208V, 3Ø, 11.5KW
240V, 3Ø (1Ø), 11.5KW
24-13/16 x 23-9/16 89 8.85
$6,890.00
$6,890.00
F886
COOKING PRODUCTS
Wellslok™ standard for
easy installation
Flat-blade, low-watt density
elements for quick heating
and longer oil life
Terminal block provided
for connection to power
supply Manual reset safety thermostats
provide added protection from
over-temperatures
A red signal light indicates
any over temperature
condition
Model
Number
Part
Number
Description Ship
Weight
Price
Mobile Oil Disposal Floor Caddy
WAOC1 22470 With manual pump 78 $3,025.00
OIL DISPOSAL CADDY
WAOC1
Large Capacity -
Up to 100lb. oil capacity
Fast-
Move 50lbs. of oil
in less than
3 minutes
Flexible -
Great for counter top
or floor fryers Safe -
(4) Locking swivel casters
Easy-To-Use -
Geometrically designed
Dependable -
Cast iron valve-type
bidirectional pump
*SELECT MODELS ARE FIELD CONVERTIBLE FROM 3Ø TO 1Ø
ACCESSORIES PAGES 56
EXPORT MODELS CANNOT BE RETURNED
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
56
FRYER ACCESSORIES
Floor Fryer Accessories
Part Number Description Ship Weight Price
22913 Full-size basket (WFAE55F/FS) 12 $970.00
22796 Half-size basket (WFAE55F/FS) 6 $400.00
21647 Heating element cleaning brush - $115.00
22516 Frypot cleaning brush - $58.00
22515 Chicken stirring paddle 2 $100.00
22685 Round Basket (WFAE30F) N/A $610.00
Countertop Single Pot Fryer Accessories
Part Number Description Ship Weight Price
21506 Basket, half-size (2 per fry pot) (LLF14) 2 $93.00
22728 Cord set, 30 AMP, 1Ø, NEMA 6-50P (F55) 1 $500.00
20820 Basket, half-size (2 per fry pot) (F1725) 2 $105.00
20519 Fry Pot, replacement (F1725) 9 $1,045.00
20161 Basket, half-size (2 per fry pot) (LLF14/F49/55/58) 2 $83.00
20162 Basket, full-size (1 per fry pot) (F49/55/58) 2 $93.00
20690 Crumb cradle (1 per fry pot) (F49/55/58) 1 $165.00
20169 Fry pot, 15 lb. capacity (F49/55/58) 7 $180.00
E1-115714 Fry pot replacement, 15 lb. capacity (F15), 1 required N//A $300.00
21010 Fry pot cover (F49/55/58) 3 $165.00
20563 Legs, set of four, 4 adjustable (F49/55/58) 5$110.00
HSFB-LH 1/2 size basket (left hanging) - Fits the following models: F15, F30 & GF15 - $100.00
HSFB-RH 1/2 size basket (right hanging) - Fits the following models: F15, F30 & GF15 - $130.00
FSFB-LH Full size basket (left hanging) - Fits the following models: F15, F30 & GF30 - $95.00
FSFB-RH Full size basket (right hanging) - Fits the following models: F15, F30 & GF30 - $120.00
Built-In Single Pot Fryer Accessories
Part Number Description Ship Weight Price
20161 Basket, half-size (2 per fry pot) 2 $83.00
20162 Basket, full-size (1 per fry pot) 2 $93.00
20690 Crumb cradle (1 per fry pot) 1 $165.00
20169 Fry pot, 15 lb. capacity 7 $180.00
Countertop Dual Pot Accessories
Part Number Description Ship Weight Price
20161 Basket, half-size (each) (two per fry pot) 2 $83.00
20162 Basket, full-size (one per fry pot) 2 $93.00
20690 Crumb cradle (one per fry pot) 1 $165.00
20169 Fry pot, 15 lb. capacity 7 $180.00
20563 Legs, set of four, 4 adjustable (F1725) 5$110.00
E1-115714 Fry pot replacement, 15 lb. capacity (F30), 2 required ($300 per pot) N//A $300.00
HSFB-LH 1/2 size basket (left hanging) - Fits the following models: F15, F30 & GF15 - $100.00
HSFB-RH 1/2 size basket (right hanging) - Fits the following models: F15, F30 & GF15 - $130.00
FSFB-LH Full size basket (left hanging) - Fits the following models: F15, F30 & GF30 - $95.00
FSFB-RH Full size basket (right hanging) - Fits the following models: F15, F30 & GF30 - $120.00
Built-In Dual Pot Fryer Accessories
Part Number Description Ship Weight Price
20161 Basket, half-size (each) (2 per fry pot) (F49, F85) 2 $83.00
20162 Basket, full-size (1 per fry pot) 2 $93.00
20690 Crumb cradle (1 per fry pot) 1 $165.00
20169 Fry pot, 15 lb. capacity 7 $180.00
Celsius Knobs for Fryers
Part Number Description Ship Weight Price
Z17210 Celsius knobs in lieu of Fahrenheit knobs (1 each) (LLF14, F49, F55, F556) ($55.00 PER KNOB) 2 $55.00
Z17210 Celsius knobs in lieu of Fahrenheit knobs (2 each) (F67, F68, F676, F686) ($55.00 PER KNOB) 2 $110.00
Z21370 Celsius knobs in lieu of Fahrenheit knobs (1 each) F15 Fryer (2 each) F30 Fryer ($55.00 PER KNOB) 2 $110.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 57
COOKING PRODUCTS
HALF SIZE
CONVECTION OVEN
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Amps Price
N V Half Size Convection Oven
OC1 -
-
208V, 1Ø, 5,000 watts, NEMA 6-30P
240V, 1Ø, 5,600 watts, NEMA 6-30P
30-1/8 x 25-1/4 x 31
height includes 6" legs
253
(lbs)
24.0
24.0
$7,250.00
$7,250.00
INTERIOR DIMENSIONS
15-3/8 x 20-1/2 x 20
OC2 -
-
208V, 1Ø, 5,000 watts, NEMA 6-30P
240V, 1Ø, 5,600 watts, NEMA 6-30P
30-1/8 x 25-1/4 x 56
height includes 6" legs
506
(lbs)
24.0
24.0
$14,500.00
$14,500.00
Model OC2
Accessories
Part Number Description Ship Weight Price
21330 Caster set (set of four) 12 $210.00
21342 Stacking kit allows one oven to be stacked on top of another. If casters are used, they must be
installed on the lower oven
15 $160.00
21376 Oven rack, replacement 4 $84.00
23035 Venting kit for single oven - $54.00
21445 Oven prep top - turns the top of your oven into a work surface - $425.00
High wattage for rapid pre-
heat and quick recovery
Fully insulated for
maximum efficiency
and energy savings
Stainless steel exterior and
interior for durability, reliability
and ease of cleaning
Ergonomic, cool-touch
door handle
Easy-to-use, program-
mable controls
Two-speed fan is per-
fect for bakery items
Five fully adjustable racks for
13” x 18” pans
Heavy-duty power cord and
NEMA 6-30P plug is standard
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
58
Model
Number
Part
Number
Description Number of
Thermo-
stats
Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
UGriddles
G13**
G13-480**
G13-400
20052
90800*
21596
Cooking Surface 22”W x 18”D
208/240V, 3Ø (1Ø), 6.75/9.0KW
480V, 3Ø (1Ø), 9.0KW
380-415V, 3NAC, 3Ø, 10800W
*Optional Chrome-Plated Griddle Surface
CSA model available: 9kW, 60Hz,
208V or 240V, 1Ø or 3Ø
2 24-3/16 x
23-9/16 x 16
140 6.77
$3,430.00
$4,100.00
$3,935.00
Add $1,265.00
G19-208**
G19-240**
G19-480**
G19-400
20060
20062
90804*
21598
Cooking Surface 34”W x 18”D
208V, 3Ø (1Ø), 12.0KW
240V, 3Ø (1Ø), 12.0KW
480V, 3Ø (1Ø), 12.0KW
380-415V, 3NAC, 3Ø, 16100W
*Optional Chrome-Plated Griddle Surface
CSA model available: 12.0kW, 60Hz,
208V or 240V, 1Ø or 3Ø
2 36-½ x
23-9/16 x 16
190 9.70
$4,170.00
$4,170.00
$4,985.00
$4,985.00
Add $1,500.00
G23-208**
G23-240**
G23-480**
G23-400
20068
20070
90806*
22395
Cooking Surface 34”W x 24”D
208V, 3Ø (1Ø), 16.0KW
240V, 3Ø (1Ø), 16.0KW
480V, 3Ø (1Ø), 16.0KW
380-415V, 3NAC, 3Ø, 16000W
*Optional Chrome-Plated Griddle Surface
CSA model available: 16.0kW, 60Hz,
208V or 240V, 1Ø or 3Ø
4 36-½ x
29-9/16 x 16
260 14.52
$5,800.00
$5,800.00
$6,990.00
$6,285.00
Add $1,830.00
G24-208**
G24-240**
G24-480**
G24-400
20076
20078
90808*
22397
Cooking Surface 46”W x 24”D
208V, 3Ø (1Ø), 21.5KW
240V, 3Ø (1Ø), 21.5KW
480V, 3Ø (1Ø), 21.5KW
380-415V, 3NAC, 3Ø, 21000W
*Optional Chrome-Plated Griddle Surface
CSA model available: 21.0kW, 60Hz,
208V or 230V, 1Ø or 3Ø
4 49 x
29-9/16 x 16
326 19.47
$7,695.00
$7,695.00
$9,190.00
$8,240.00
Add $2,090.00
G60-208**
G60-240**
G60-480**
G60-400
90810*
90810*
90810*
N/A
Cooking Surface 67”W x 24”D
208V, 3Ø (1Ø), 32.0KW
240V, 3Ø (1Ø), 32.0KW
480V, 3Ø (1Ø), 32.0KW
380-415V, 3NAC, 3Ø, 32.0KW
*Optional Chrome-Plated Griddle Surface
CSA model available: 32.0kW, 60Hz,
208V or 240V, 1Ø or 3Ø
8 69 x
29-9/16 x 16
545 26.04
$9,690.00
$9,690.00
$11,700.00
$10,200.00
Add $2,340.00
Optional grooved Surface First 6”, must specify location*
Optional grooved Surface Each additional 6 incremental widths*
Add $800.00
Add $360.00
COUNTERTOP GRIDDLES ELECTRIC
F
F
F
F
G13
F
COOKING PRODUCTS
* BUILT TO BUYER’S SPECIFICATION. MAY NOT BE RETURNED. **SELECT MODELS ARE FIELD CONVERTIBLE FROM 3Ø TO 1Ø
VOLTAGE NEEDS TO BE SPECIFIED AT TIME OF ORDER. EXPORT MODELS CANNOT BE RETURNED.
GROOVING IS NOT AVAILABLE WITH CHROMEPLATED SURFACE.
Removable splash guard for
ease of cleaning
Four-quart capacity, remov-
able, front mounted grease
drawer (G-60 has two)
½” thick griddle plate
provides even heat
distribution
Front-mounted controls come with
ring guards to prevent accidental
temperature changes
A terminal block is provided
for field wiring to main power
source (G-60 has two)
4” adjustable legs standard
on countertop models
Grooved or chrome-plated
surfaces available
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 59
JAPANESE
TEPPAN GRIDDLE
JG246UL
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
VJapanese Teppan Griddle, No Grease Trough,
Plate Size 46 13/16” x 27 5/16”
JG246UL* 22227
Cooking Surface 24 x 20
208/240V, 3Ø (1Ø), 6.0/8.0KW 49-3/16 x 29-11/16 415 22.28 $6,885.00
*SELECT MODEL IS FIELD CONVERTIBLE FROM 3Ø TO 1Ø
COOKING PRODUCTS
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
oThermostatic Control
2424G 21457
Cooking Surface 23 13/16W x 20 ½D
Natural Gas, 50,000 BTU/hour, 2 burners
*Optional chrome-Plated Surface
23-13/13 x 25- x12- 210 11.30
$4,955.00
$6,325.00
2436G 21458
Cooking Surface 35 13/16W x 20 ½D
Natural Gas, 75,000 BTU/hour, 3 burners
*Optional chrome-Plated Surface
35-13/16 x 25- x
12-
291 17.32
$6,440.00
$8,080.00
3036G 21459
Cooking Surface 35 13/16W x 24D
Natural Gas, 75,000 BTU/hour, 3 burners
*Optional chrome-Plated Surface
35-13/16 x 30 x
12-
325 21.24
$8,010.00
$9,750.00
3048G 21460
Cooking Surface 47 13/16W x 24D
Natural Gas, 100,000 BTU/hour, 4 burners
*Optional chrome-Plated Surface
47-13/16 x 30 x
12-
423 26.71
$9,000.00
$11,230.00
Optional grooved surface First 6, must specify location*
Optional grooved surface Each additional 6 incremental widths*
Add $800.00
Add $360.00
Gas Griddles
2424G
Accessories
Part Number Description Ship Weight Price
20563 Legs, set of four, 4 adjustable 5$110.00
20651 Scraper, for grooved griddles 1 $130.00
3/4” thick griddle
plate provides even
heat distribution Snap-Action Thermostatic
Controls located every
12” for precise tempera-
tures
Stainless Steel, hinged front
panel protects control knobs
Full-width front-mounted grease
trough for ease of cleaning
Large capacity, removable
grease drawer for easy clean up
Natural or LP Gas
4” adjustable legs standard
Grooved or chrome-plated
surfaces available
GROOVING IS NOT AVAILABLE WITH CHROME PLATED SURFACE
* BUILT TO BUYER’S SPECIFICATION. MAY NOT BE RETURNED.
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
60
COOKING PRODUCTS
HD GAS GRIDDLES
Model
Number Part
Number Description Size
W x D x H (in) Ship
Weight Cubic
Feet Price
oManual Control - Natural Gas
HDG2430G 23143 Cooking Surface 23-¾W x 23-¾D
Natural Gas, 60,000 BTU/hour, 2 burners 24- x 33-¼ x 17 249 12.85 $1,965.00
HDG3630G 23144 Cooking Surface 35-¾W x 23-¾D
Natural Gas, 90,000 BTU/hour, 3 burners 36- x 33-¼ x 17 397 17.99 $2,645.00
HDG4830G 23145 Cooking Surface 47-¾W x 23-¾D
Natural Gas, 120,000 BTU/hour, 4 burners 48-1/8 x 33-¼ x 17 507 22.70 $3,335.00
HDG6030G N/A Cooking Surface 60-1/8W x 23-¾D
Natural Gas, 150,000 BTU/hour, 6 burners 60-1/8 x 33-¼ x 17 640 30.2 $4,340.00
oThermostatic Control - Natural Gas
HDTG2430G 23250 Cooking Surface 23-¾W x 23-¾D
Natural Gas, 60,000 BTU/hour, 2 burners 24- x 33-¼ x 17 249 12.85 $3,325.00
HDTG3630G 23251 Cooking Surface 35-¾W x 23-¾D
Natural Gas, 90,000 BTU/hour, 3 burners 36- x 33-¼ x 17 397 17.99 $4,210.00
HDTG4830G 23252 Cooking Surface 47-¾W x 23-¾D
Natural Gas, 120,000 BTU/hour, 4 burners 48-1/8 x 33-¼ x 17 507 22.70 $5,485.00
HDTG6030G N/A Cooking Surface 60-1/8W x 23-¾D
Natural Gas, 150,000 BTU/hour, 6 burners 60-1/8 x 33-¼ x 17 640 30.2 $7,315.00
HDG2430G
Accessories
Part Number Description Ship Weight Price
20563 Legs, set of four, 4 adjustable 5$110.00
NATURAL GAS MODELS ARE FIELD CONVERTIBLE TO LP GAS LP GAS REGULATORS AND ORIFICES INCLUDED.
3/4” thick griddle plate pro-
vides even heat distribution
Manual or thermostatic con-
trols located every 12” for
precise temperatures
Front-mounted grease trough
for ease of cleaning
Large capacity, stainless
steel, removable grease
drawer for easy clean up
Natural or LP Gas
4” adjustable legs standard
Stainless steel remov-
able front panel for ease
of access to components
Each burner has adjustable
air shutter control for opti-
mum combustion
COOKING PRODUCTS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 61
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
oRadiant - Natural Gas
HDCB1230G 23215
Cooking Surface 12W x 30D
Natural Gas, 40,000 BTU/hour, 2 burners
14 x 30-½ x 18- 139 5.19 $1,875.00
HDCB2430G 23191
Cooking Surface 24W x 30D
Natural Gas, 80,000 BTU/hour, 4 burners
24-1/8 x 30-½ x 18- 293 18.71 $2,450.00
HDCB3630G 23192
Cooking Surface 36W x 30D
Natural Gas, 120,000 BTU/hour, 6 burners
36-1/8 x 30-½ x 18- 401 19.70 $3,285.00
HDCB4830G 23193
Cooking Surface 48W x 30D
Natural Gas, 160,000 BTU/hour, 8 burners
48-1/8 x 30-½ x 18- 514 25.61 $4,510.00
HD GAS CHAR BROILERS
Accessories
Part Number Description Ship Weight Price
20563 Legs, set of four, 4 adjustable 5 $110.00
HDCB2430G
NATURAL GAS MODELS ARE FIELD CONVERTIBLE TO LP GAS LP GAS REGULATORS AND ORIFICES INCLUDED.
Cast iron top grates – adjustable
and reversible
Cast iron radiants for even
& consistent heat
Cast iron burners for higher
maximum temperatures &
consistency
Natural or LP Gas
Removable drip pan for
easy clean up
Easily removable front
panel for simple access to
components
Each burner has adjustable
air shutter control for opti-
mum combustion
Each burner has ON/OFF
control valves for infinite
heat adjustment
COOKING PRODUCTS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
62
Model
Number
Part
Number
Description Number of
Thermostats
Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
RGriddles
G136*
G136-480**
G136-400
20054
90801
21597
Cooking Surface 22W x 18D
208/240V, 3Ø (1Ø), 6.8/9.0KW
480V, 3Ø (1Ø), 9.0KW
380-415V, 3NAC, 3Ø, 10800W
*Optional Chrome-Plated Griddle Surface
2 24-3/16 x 23-9/16 120 5.84
$3,580.00
$4,340.00
$4,000.00
Add $1,265.00
G196-208**
G196-240**
G196-480**
G196-400
20064
20066
90805
21598
Cooking Surface 34W x 18D
208V, 3Ø (1Ø), 12.0KW
240V, 3Ø (1Ø), 12.0KW
480V, 3Ø (1Ø), 12.0KW
380-415V, 3NAC, 3Ø, 16100W
*Optional Chrome-Plated Griddle Surface
2 36-½ x 23-9/16 180 9.70
$4,240.00
$4,240.00
$5,145.00
$5,020.00
Add $1,500.00
G236-208**
G236-240**
G236-480**
G236-400
20072
90807
90807
22396
Cooking Surface 34W x 24D
208V, 3Ø (1Ø), 16.0KW
240V, 3Ø (1Ø), 16.0KW
480V, 3Ø (1Ø), 16.0KW
380-415V, 3NAC, 3Ø, 16000W
*Optional Chrome-Plated Griddle Surface
4 36-½ x 29-9/16 292 14.52
$6,045.00
$6,045.00
$7,125.00
$6,290.00
Add $1,830.00
G246-208**
G246-240**
G246-480**
G246-400
20080
90809
90809
22398
Cooking Surface 46W x 24D
208V, 3Ø (1Ø), 21.5KW
240V, 3Ø (1Ø), 21.5KW
480V, 3Ø (1Ø), 21.5KW
380-415V, 3NAC, 3Ø, 21000W
*Optional Chrome-Plated Griddle Surface
4 49 x 29-9/16 331 19.47
$7,960.00
$7,960.00
$9,525.00
$8,450.00
Add $2,090.00
G606-208**
G606-240**
G606-480**
90811
90811
90811
Cooking Surface 67W x 24D
208V, 3Ø (1Ø), 32.0KW
240V, 3Ø (1Ø), 32.0KW
480V, 3Ø (1Ø), 32.0KW
*Optional Chrome-Plated Griddle Surface
8 69 x 29-9/16 517 28.02
$10,845.00
$10,845.00
$12,941.00
Add $2,340.00
*Optional Grooved Surface First 6, must specify location
*Optional Grooved Surface Each additional 6 incremental widths
Add $800.00
Add $360.00
G236
F
F
F
F
GROOVING IS NOT AVAILABLE WITH CHROMEPLATED SURFACE EXPORT MODELS CANNOT BE RETURNED
*CUSTOM GROOVED SURFACES CANNOT BE RETURNED.
**SELECT MODELS ARE FIELD CONVERTIBLE FROM 3Ø TO 1Ø
COOKING PRODUCTS
Accessories - Countertop Electric Griddles
Part Number Description Ship Weight Price
20632 Splashguard G-13 & G136 3 $260.00
20634 Splashguard G-19 & G196 4 $270.00
20635 Splashguard G-23 & G236 4 $280.00
20636 Splashguard G-24 & G246 8 $335.00
20637 Splashguard G-60 & G606 10 $485.00
20651 Scraper, for grooved griddles 1 $130.00
Z17209 Celsius knobs in lieu of Fahrenheit knobs (2 each) G13, G19, G136, G196 ($50.00 PER KNOB) 1 $110.00
Z17209 Celsius knobs in lieu of Fahrenheit knobs (4 each) (G23, G24, G236, G246) ($50.00 PER KNOB) 2 $220.00
Z17209 Celsius knobs in lieu of Fahrenheit knobs (8each) (G60 & G606) ($50.00 PER KNOB) 3 $440.00
Wellslok™ standard for
easy installation
COOKING PRODUCTS
BUILTIN GRIDDLES ELECTRIC
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 63
HD GAS HOTPLATES
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
oStandard - Natural Gas
HDHP1230G 23146
Two Burners
Natural Gas, 53,000 BTU/hour
12 x 30- x 14-11/16 89 3.74 $1,105.00
HDHP2430G 23147
Four Burners
Natural Gas, 106,000 BTU/hour
23-¾ x 30- x 14-11/16 225 12.85 $1,665.00
HDHP3630G 23148
Six Burners
Natural Gas, 159,000 BTU/hour
35-½ x 30- x 14-11/16 304 17.99 $2,225.00
HDHP2430G
Accessories
Part Number Description Ship Weight Price
20563 Legs, set of four, 4 adjustable 5$110.00
COOKING PRODUCTS
Easily removable front
panel for simple access to
components
Durable cast iron burners provide con-
sistent high temperatures and gentle
low heat Heavy-duty, cast iron top
Grates are built to last
Removable drip pan for easy
clean up
Each burner has adjustable
air shutter control for opti-
mum combustion
Each burner has ON/OFF con-
trol valves for infinite heat
adjustment
Adjustable 4” legs standard
Natural or LP Gas
COOKING PRODUCTS
NATURAL GAS MODELS ARE FIELD CONVERTIBLE TO LP GAS LP GAS REGULATORS AND ORIFICES INCLUDED.
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
64
Model
Number
Part
Number
Description Number of
Controls
Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
UChar Broilers
B40-208**
B40-240**
B40-400
20002
20001*
21520
Cooking Surface 21 ½W x 14 ½D
208V, 3Ø (1Ø), 5.5KW
240V, 3Ø (1Ø), 5.5KW
380-415V, 3Ø, 5400W
2 24-¾ x 23-½ x
15-
80 7.81
$5,000.00
$5,000.00
$5,210.00
B44-208**
B44-240**
B44-400
20007
20005*
21603
Cooking Surface 16W x 20D
208V, 3Ø (1Ø), 5.5KW
240V, 3Ø (1Ø), 5.5KW
380-415V, 3Ø, 5400W
1 19-7/16 x
29-9/16 x
15-
85 8.02
$4,835.00
$4,835.00
$5,190.00
B50-208**
B50-240**
B50-400
20011
20010*
21824
Cooking Surface 32W x 20D
208V, 3Ø (1Ø), 11.0KW
240V, 3Ø (1Ø), 11.0KW
380-415V, 3Ø, 10800W
2 36-½ x 29-½ x
15-
159 14.46
$8,630.00
$8,630.00
$9,175.00
COUNTERTOP
CHAR BROILERS ELECTRIC
B50
F
F
F
* BUILT TO BUYER’S SPECIFICATION. MAY NOT BE RETURNED.
**SELECT MODELS ARE FIELD CONVERTIBLE FROM 3Ø TO 1Ø
EXPORT MODELS CANNOT BE RETURNED
COOKING PRODUCTS
Dual heating action
using both radiant and
conductive heat
Self-cleaning element(s)
are positioned between
broiler grate ribs to
protect from direct con-
tact with food and from
spatulas
Signal light illuminates
when element(s) are
energized
Front mounted control comes
with protective guard ring to
prevent accidental tempera-
ture adjustments
Lift-out drip-pan has handles
for easy clean up
Removable cast iron grates
makes clean up a breeze
Temperature is regulated
by infinite controls with
positive off position
Wellslok™ standard on Built-in
models for ease of installation
Element frame has a spring –load-
ed support to secure element(s)
when in a raised position
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 65
BUILTIN
CHAR BROILERS ELECTRIC
Accessories Countertop & Built-In Char Broilers
Part Number Description Ship Weight Price
21708 Wire Broiler Brush 3 $22.00
20141 Cord set, 30 AMP, 1Ø, NEMA 6-30P (B40 and B44) 1 $55.00
20202 Grease Pan, replacement (B40 & B406) 5 $305.00
20174 Grease Pan, replacement (B44, B50, B446 & B506) 4 $305.00
21707 Broiler Grate (B40 & B406) 20 $295.00
21706 Broiler Grate (B44, B50, B446 & B506) 25 $345.00
20563 Legs, set of four, 4 adjustable 25 $110.00
Model
Number
Part
Number
Description Number of
Controls
Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
RChar Broilers
B406-208
B406-240
B406-400
20004
20003*
Cooking Surface 21 ½W x 14 ½D
208V, 3Ø (1Ø), 5.5KW
240V, 3Ø (1Ø), 5.5KW
380-415V 3Ø (1Ø), 5.5KW
2 24-¾ x 23-½ 68 8.55
$5,010.00
$5,010.00
$5,240.00
B446-208
B446-240
B446-400
20009
20008*
Cooking Surface 16W x 20D
208V, 3Ø (1Ø), 5.5KW
240V, 3Ø (1Ø), 5.5KW
380-415V , 3Ø (1Ø), 5.5KW
1 19-7/16 x 29-9/16 80 8.02
$4,960.00
$4,960.00
$5,190.00
B506-208
B506-240
B506-400
20013
20012*
Cooking Surface 32W x 20D
208V, 3Ø, 11.0KW
240V, 3Ø (1Ø), 11.0KW
380-415V, 3Ø (1Ø), 11.0KW
2 36-½ x 29-½ 142 14.46
$8,750.00
$8,750.00
$9,290.00
B406
B446
* BUILT TO BUYER’S SPECIFICATION. MAY NOT BE RETURNED.
F
F
F
COOKING PRODUCTS
Wellslok™ standard
for easy installation
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
66
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
VCeramic Hotplates
HC100 22328
Single 7” element, 1” legs
120V, 1Ø, 1.4KW, NEMA 5-15P
12- x 12- x 6-¾ 14 1.63 $1,050.00
HC125
HC125-230V
22305
22418
Single 9” element, 1” legs
208/240V, 1Ø, 1.9/2.5KW, NEMA 6-15P
220-240V, 1Ø, 2500W
14-¾ x 14 x 6-¾ 15 3.00
$1,215.00
$1,215.00
HC225
HC225-230V
22307
22419
Dual 9” elements, 1” legs
208/240V, 1Ø, 3.8/5.0KW, NEMA 6-30P
220-240V, 1Ø, 5000W
14-¾ x 24- x 6-¾ 29 4.15
$1,910.00
$1,910.00
USpiral Hotplates
H33 20192
Single 6” element, 4” legs
120V, 1Ø, 1.5KW, NEMA 5-15P
12- x 12- x 10 12 1.62 $660.00
H115 20436
Dual 6” elements, 1” legs
120V, 1Ø, 1.65KW, NEMA 5-15P
14-¾ x 23-9/16 x 7 21 3.35 $1,090.00
H63*
H63CD*
20093
21622
Dual 8” elements, 4” legs
208/240V, 1Ø (3Ø), 3.9/5.2KW, No cord set
**CSA model available: 208V or 240V, 60Hz 1Ø or 3Ø
208/240V, 1Ø (3Ø), 3.9/5.2KW, NEMA 6-30P
14-¾ x 23-½ x 12- 28 4.51
$1,260.00
$1,385.00
UFrench Hotplates
H70*
H70-230V
20523
22384
Dual 9” elements, 4” legs
208/240V, 1Ø (3Ø), 3.0/4.0KW, No cord set
220-240V, 1Ø, 4000W
**CSA model available: 208V or 240V, 60Hz 1Ø or 3Ø
14-¾ x 23-½ x 12- 35 4.36 $1,355.00
$1,385.00
HC125
H63
H70
COUNTERTOP HOTPLATES
ELECTRIC
Accessories
Part Number Description Ship Weight Price
21109 Legs, set of four, 1” plastic for countertop electric hotplates 1 $50.00
20314 Legs, set of four, 4” adjustable plastic for all countertop electric hotplates 1 $45.00
20563 Legs, set of four, 4” adjustable nickel-plated alloy for all countertop electric hotplates 5 $110.00
21705 Drip Tray, model H63 5 $50.00
*SELECT MODELS ARE FIELD CONVERTIBLE FROM 1Ø TO 3Ø EXPORT MODELS CANNOT BE RETURNED
F
F
F
**Note: For 3 phase CSA models max line currents are as follows:
Volts L1 L2 L3
208 16.3 8.1 8.1
240 18.8 9.3 9.3
COOKING PRODUCTS
Heats five-times
faster than conven-
tion hot plates
Smooth easy-to-
clean surface works
with all types of
pans and skillets
Reduced cook
times saves energy
Larger surface area
provide even heat
distribution for larger
pots & pans
Solid surfaces are
easy to clean
Self cleaning elements
Drip trays are removable
for ease of cleaning
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 67
H706
BUILTIN HOTPLATES
ELECTRIC
Model
Number
Part
Number
Description Size
W x D (in)
Ship
Weight
Cubic
Feet
Price
UCeramic Hotplates
HC1006 22329
Single 7 element
120V, 1Ø, 1.4KW
12- x 12- 15 3.13
$1,145.00
HC1256
HC1256-230
22308
22420
Single 9 element
208/240V, 1Ø, 1.9/2.5KW
220-240V, 1Ø, 2500W
14-¾ x 14 19 3.50
$1,255.00
$1,285.00
HC2256
HC2256-230
22270
22421
Dual 9 elements
208/240V, 1Ø, 3.8/5.0KW
220-240V, 1Ø, 5000W
14-¾ x 24- 31 4.15
$2,090.00
$2,135.00
RSpiral Hotplates
H336 20092
Single 6 element
120/208V, 1Ø, 19.5/26.0KW
10 Diameter 6 0.74
$685.00
H636 20094
Dual 8 elements
208/240V, 1Ø (3Ø), 3.9/5.2KW
14-¾ x 23-½ 24 2.58
$1,365.00
RFrench Hotplates
H706
H706-230
20739
22385
Dual 9 elements
208/240V, 1Ø (3Ø), 3.0/4.0KW
220-240V, 1Ø, 4000W
14-¾ x 23-½ 29 2.58
$1,420.00
$1,485.00
HC1256
EXPORT MODELS CANNOT BE RETURNED
F
F
F
H336
COOKING PRODUCTS
Wellslok ™ standard on built-in
models for ease of installation
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
68
GAS HOTPLATES
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
oInstant-On Hotplate
H2412G 23185
Instant-On, Two Burners
Natural Gas, 24,000 BTU/hour
12- x 23-¾ x 13-½ 31 3.85 $2,155.00
Accessories
Part Number Description Ship Weight Price
20563 Legs, set of four, 4 adjustable 5$110.00
23179 Drip Tray 1$130.00
COOKING PRODUCTS
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 69
HEATED DISHER WELL
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Price
UWater-Saver Heated Disher Well
HDW-2 N/A 120V, 300W, 2.5 AMPS 5-15 Plug with 6 cord
208/240V, 300W, 1.4/1.3 AMPS 6-15 Plug with 6 cord
7.5 x 7.5 x 9.25 n/a $1,665.00
*PATENT PENDING*
HDW-2
WATER SAVER HEATED
DISHER WELL
It’s Easy to
SAVE GREEN
With the Water Saver Heated Disher Well
Saves Water
Saves Environmental Fees
Saves Energy
Food Safe- Protects Customers
Accessories
Part Number Description WxDxH
with optional faucet
Ship Weight Price
HDWF Heated Disher Well Faucet 7.5 x 7.77 x 10.4 - $140.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
70
RW2HD
HEAVYDUTY
DRAWER WARMERS
FREE STANDING
EXPORT MODELS CAN NOT BE RETURNED
ACCESSORIES PAGE 74
F
RW1HD
WARMERS
Individual thermostatic
controls per drawer for
maximum versatility
Choose between standard ther-
mostatic controls, electronic
thermometer with digital read-
outs or dial thermometers
Adjustable front vent allows
for humidity control for each
individual drawer
Large 12” x 20” x 6” deep
stainless steel pans accept
standard inset pans
Fully insulated for heat
retentions and energy
savings
Model
Number
Part
Number
Description Drawers Thermostat
Controls
Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
VHeavy-Duty Drawer Warmers
RW1HD-120
RW1HD
21470
21471
4” legs
120V, 1Ø, 450W, NEMA 5-15P
208/240V, 1Ø, 338/450W, NEMA 6-15P
1 1 29-¼ x 21-½ x
14-
77 7.93
$2,300.00
$2,300.00
RW2HD-120
RW2HD
RW2HD-230
21480
21481
22335
4” legs
120V, 1Ø, 900W, NEMA 5-15P
208/240V, 1Ø, 676/900W, NEMA 6-15P
220-240V, 1Ø, 900W
2 2 29-¼ x 21-½
x 25
126 13.80
$3,975.00
$3,975.00
$4,175.00
RW3HD-120
RW3HD
21482
21483
4” legs
120V, 1Ø, 1350W, NEMA 5-15P
208/240V, 1Ø, 1014/1350W, NEMA 6-15P
3 3 29-¼ x 21-½ x
31-
170 19.20
$5,595.00
$5,595.00
VHeavy-Duty Narrow-Width Drawer Warmers
RWN1-120
RWN1
22058
22059
4 legs
120V, 1Ø, 450W, NEMA 5-15P
208/240V, 1Ø, 338/450W, NEMA 6-15P
1 1 20-¼ x 26-5/16
x 14-
69 7.93
$2,445.00
$2,445.00
RWN2-120
RWN2
22060
22061
4 legs
120V, 1Ø, 900W, NEMA 5-15P
208/240V, 1Ø, 676/900W, NEMA 6-15P
2 2 20-¼ x 26-5/16
x 25
110 13.80
$4,110.00
$4,110.00
RWN3-120
RWN3
22062
22063
4 legs
120V, 1Ø, 1350W, NEMA 5-15P
208/240V, 1Ø, 1014/1350W, NEMA 6-15P
3 3 20-¼ x 26-5/16
x 31-
165 19.20
$5,635.00
$5,635.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 71
HEAVYDUTY
DRAWER WARMERS
BUILTIN
Model
Number
Part
Number
Description Drawers Thermostat
Controls
Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
VHeavy-Duty Drawer Warmers
RW16HD-120
RW16HD
RW16HD-230
21500
21501
22336
120V, 1Ø, 450W
208/240V, 1Ø, 338/450W
220-240V, 1Ø, 450W
CSA model available: 120V 3.75A, 208V
1.63A, 240V 1.87A
1 1 29-¼ x 21-½
x 10-
68 7.93 $2,370.00
$2,370.00
$2,520.00
RW26HD-120
RW26HD
RW26HD-230
21534
21535
22337
120V, 1Ø, 900W
208/240V, 1Ø, 676/900W
220-240V, 1Ø, 900W
CSA model available: 120V 7.50A, 208V
3.25A, 240V 3.75A
2 2 29-¼ x
21-½ x 21
115 13.80 $3,900.00
$3,900.00
$4,030.00
RW36HD-120
RW36HD
21536
21537
120V, 1Ø, 1350W
208/240V, 1Ø, 1014/1350W
CSA model available: 120V 11.25A, 208V
4.88A, 240V 5.62A
3 3 29-¼ x 21-½
x 31-
191 19.20 $5,430.00
$5,430.00
VHeavy-Duty Narrow-Width Drawer Warmers
RWN16-120
RWN16
22064
22065
120V, 1Ø, 450W
208/240V, 1Ø, 338/450W
1 1 20-¼ x 26-½ x
10-
63 7.93 $2,405.00
$2,405.00
RWN26-120
RWN26
22066
22067
120V, 1Ø, 900W
208/240V, 1Ø, 676/900W
2 2 20-¼ x 26-½
x 21
120 13.80 $4,015.00
$4,015.00
RWN36-120
RWN36
22068
22069
120V, 1Ø, 1350W
208/240V, 1Ø, 1014/1350W
3 3 20-¼ x 26-½ x
31-
191 19.20 $5,605.00
$5,605.00
F
F
WARMERS
EXAMPLE ONLY
RW16HD
DRAWER WARMER
RW16HD
Exclusive self-latching
mechanism provides
easy, one-touch and
secure closing
Durable and tough stainless
steel tracks and bearings pro-
vide smooth and trouble-free
operation
Drawers fully extend
for ease of loading and
unloading
Narrow width models save
space while accommodating
standard 12” x 20” pans
EXPORT MODELS CAN NOT BE RETURNED
ACCESSORIES PAGE 74
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
72
COUNTERTOP WARMERS
RECTANGULAR AND SQUARE
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
UHeavy-Duty Warmers - Thermostat Control
SW10T-120 20907
11 quart round, 1 leg
120V, 1Ø, 825W, NEMA 5-15P
12- x 12- x 9- 14 1.62
$680.00
SMPT-120
SMPT
SMPT-D
SMPT-230
20971
20936
22374
Holds one 12 x 20 pan, 4 legs
120V, 1Ø, 1650W, NEMA 5-15P
208/240V, 1Ø, 1240/1650W, NEMA 6-15P
With Drain
220-240V, 1Ø, 1650W
14-¾ x 23-½ x 12- 27 4.51
$1,015.00
$1,015.00
$1,175.00
$1,045.00
SMPT27-120
SMPT27
22322
22323
Holds four pans, 4 legs
120V, 1Ø, 1650W, NEMA 5-15P
208/240V, 1Ø, 1240/1650W, NEMA 6-15P
14-¾ x 30-½ x 12- 33 5.20
$1,215.00
$1,215.00
TMPT-120
TMPT
21360
21361
Holds two 12 x 20 pans, 4 legs
120V, 1Ø, 1800W, NEMA 5-20P
208/240V, 1Ø, 1800/2400W, NEMA 6-15P
29-9/16 x 23-½ x 12- 50 9.11
$1,770.00
$1,770.00
UHeavy-Duty Cook’N Hold
HW10-120
HW10
20574
20926
Square 11 quart round, 1 leg
120V, 1Ø, 1650W, NEMA 5-15P
208/240V, 1Ø, 1240/1650W, NEMA 6-15P
12- x 12- x 9- 14 1.60
$920.00
$920.00
HWSMP-120
HWSMP
20969
20970
Holds one 12 x 20 pan 2 or 4 deep, 4 legs
120V, 1Ø, 1800W, NEMA 5-15P
208/240V, 1Ø, 1350/1800W, NEMA 6-15P
14-¾ x 23-½ x 12- 25 4.51
$1,005.00
$1,005.00
F
SMPT
WARMERS
Tubular elements are positioned
under the warmer pan for quick
heating (standard models)
Cook ‘n hold models have
elements inside the well
for rapid heat transfer (wet
operation only)
Protective ring guards pre-
vent accidental temperature
changes
Warming pans are deep-
drawn stainless steel for
strength & durability
Positive-off thermostats
provide adjustable and con-
sistent temperatures
Accepts standard 12” x 20” and
/ or fractional inset pans (SW-10
& HW-10 accepts 11-quart round
inset pans)
EXPORT MODELS CAN NOT BE RETURNED
ACCESSORIES PAGE 74
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 73
ROUND SOUP COOKERS
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
UHeavy-Duty Cook’N Hold
LLSC7-120
21830 Round Soup Cooker 7 quarts
120V, 1Ø, 850W, NEMA 5-15P
10 ¾ Diameter 8 1.62 $450.00
LLSC7WA-120 N/A Round Soup Cooker INCLUDES 7 QUART INSET, LID
AND LADLE
120V, 1Ø, 850W, NEMA 5-15P
10 ¾ Diameter 8 1.62 $470.00
LLSC11-120 21540 Round Soup Cooker 11 quarts
120V, 1Ø, 1100W, NEMA 5-15P
12 Diameter 10 1.62 $515.00
LLSC11WA-120 12006 Round Soup Cooker INCLUDES 11 QUART INSET,
HINGED LID AND 8 OZ. LADLE
120V, 1Ø, 1100W, NEMA 5-15P
12 Diameter 10 1.62 $550.00
UDeluxe Soup Cookers
SC6411 21732 Deluxe Round Soup Cooker/Warmer 11 qt round
120V, 1Ø, 1000W, NEMA 5-15P
10-½ x 10-½ 16 1.58 $930.00
SC6411WA 21794 Deluxe Package, Includes part number 21732
Deluxe Round Soup Cooker/Warmer, 11 quart inset,
hinged lid and 8 oz. ladle
120V, 1Ø, 1000W, NEMA 5-15P
10-½ x 10-½ 16 2.20 $995.00
SC6423 - Deluxe Round Soup Cooker/Warmer 11 qt round
230V, 4.3A 1Ø, 989W, Cord Included
10-½ x 10-½ 16 1.58 $975.00
SC6423WA - Deluxe Package, Includes part number 21732
Deluxe Round Soup Cooker/Warmer, 11 quart inset,
hinged lid and 8 oz. ladle
230V, 4.3A 1Ø, 989W Cord Included
10-½ x 10-½ 16 1.58 $1,040.00
LLSC11
WARMERS
SC6411WA
Handles for
easy moving
Stainless steel well
and outer housing for
strength and durability
Deluxe dual heating ele-
ments provide fast and
efficient operation
Band element that sur-
rounds the heat
well for quick preheat
Anodized aluminum well
Thermostatically controlled to
maintain precise holding tem-
peratures
High-wattage soup cookers
for rapid heating of refriger-
ated foods
Fully insulated for cooler outer
temperatures, maximum efficien-
cy and energy savings
DELUXE MODELS ONLY
F
F
ACCESSORIES PAGE 74
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
74
WARMER ACCESSORIES
WARMERS ACCESSORIES
Part
Number
Description Ship
Weight
Price
DRAWER WARMERS
20624 Humitrol Rack, 11/16” high, one per drawer 3 $120.00
21488 Replacement Pan, 12” x 20” (RW series) 10 $190.00
22228 Replacement Pan, 12” x 20” (RWN series) 10 $190.00
21607 Leg Kit, set of (4) 6” adjustable, stainless steel body, plastic foot 6 $190.00
20576 Leg Kit, set of (4) 6” stainless steel 6 $315.00
20563 Leg Kit for drawer warmers 6 $110.00
21034 Caster Kit, set of (4) 2 with front brakes, raises unit 10” nominal height (RW series)
Includes welded base frame for added support
16 $600.00
21947 Caster Kit, set of (4) 2 with front brakes, raises unit 3-½” nominal height (RW series) 19 $525.00
22025 Caster Kit, set of (4) 2 with front brakes, raises unit 2-¼” nominal height (RW series)
Includes welded base frame for added support
12 $600.00
22073 Caster Kit, set of (4) 2 with front brakes, raises unit 10” nominal height (RWN series)
Includes welded base frame for added support
10 $600.00
22201 Caster Kit, set of (4) 2 with front brakes, raises unit 3-½” nominal height (RWN series) 13 $400.00
22409 Caster Kit, set of (4) 2 with front brakes, raises unit 2-¼” nominal height (RWN series) 10 $505.00
COUNTERTOP WARMERS
21860 Soup Ladle, 8 oz.. 1 $56.00
20587 Round Inset, 7 qt with lid, fits 8-½ opening 3$135.00
20908 Round Inset, 11 qt with handles and slotted lid, fits 10-1/2 opening 4$250.00
20774 Round Inset, 4 qt with lid, fits 6-½ opening (SW10T, SMPT, & TMPT) 2$120.00
21057 Round Inset, 11 qt with hinged lid, no handles (SW10T, SMPT, & TMPT) 6 $300.00
20822 Adapter top, to convert 11 qt warmer to hold 4 qt inset (SW10T) 2 $76.00
20175 Adapter top, to convert 11 qt warmer to hold 7 qt inset (SW10T) 2 $76.00
20176 Adapter top, to convert 12 x 20 square corner warmer to hold (2) 7 quart insets (SMPT & TMPT) 2$125.00
20434 Adapter top, to convert 12 x 20 square corner warmer to hold (2) 4 qt & (2) 2-½ qt insets (SMPT & TMPT) 2$135.00
21615 Adapter top, to convert 12 x 20 square corner warmer to hold (3) 4 qt insets (SMPT & TMPT) 2$98.00
21621 Adapter top, to convert 12 x 20 square corner warmer to hold (1) 4 qt and (1) 7 qt inset (SMPT & TMPT) 2$110.00
21624 Adapter top, to convert 12 x 20 square corner warmer to hold (4) 2-½ qt insets (SMPT & TMPT) 2$117.00
22589 Adapter top, to convert 12 x 27 square corner warmer to hold (3) 7 qt insets (SMTP27) 1$215.00
23115 Adapter top, to convert 12 x 27 square corner warmer to hold (2) 11 qt insets (SMTP27) 1$200.00
20314 Leg Kit, set of (4) 4 adjustable plastic 1$45.00
20563 Leg Kit, set of (4) 4 adjustable nickel plated alloy 5$110.00
20605 Leg Kit, set of (4) 2 plastic 2$35.00
21109 Leg Kit, set of (4) 1 plastic 1$50.00
STA1220 SLOPE TOP ADAPTER FOR 12 X 20 WARMERS – ONE PER WELL - $320.00
STASL1220 SLOPE TOP ADAPTER FOR 12 X 20 SLIM LN WARMER – ONE PER WELL - $320.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 75
BUILT-IN PRODUCTS
PW106
HYDRO SURGE
POT WASHER
Model
Number
Part
Number
Description Size Ship
Weight
Cubic
Feet
Price
UHydro Surge Pot Washer
PW106
PW 106-EU50
PW 106-UK50
PW 106-UK60
20621 120V, 1Ø, 60 Hz, 1/3 HP, NEMA 5-15P
220/240V 50 1 with UKBS1363 plug
230V 50 1 with UKBS1363 plug
230V 60 1 with UKBS1363 plug
11-½w x 10-¼h36 1.77 $2,980.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
76
WAFFLE BAKERS
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
V Traditional Waffle bakers with Electronic Controls
WB1E-120V
WB1E-240V
WB1E--230V
-Single 7 Grid, 1/2 legs
120V, 1Ø, 900W, NEMA 5-15P
208/240V, 1Ø, 675/900W, NEMA 6-15P
220/240V, 1Ø, 750/900W, CEE7/7
10- x 13-½ x 8-¾ 15 1.60
$1,440.00
$1,440.00
$1,440.00
WB2E-120V
WB2E-240V
WB2E-230V
-Dual 7 Grids, 1/2 legs
120V, 1Ø, 1800W, NEMA 5-20P
208/240V, 1Ø, 1350/1800W, NEMA 6-15P
220/240V, 1Ø, 1500/1800W, CEE7/7
19-13/16 x 13-½
x 8-¾
28 3.00
$2,405.00
$2,405.00
$2,405.00
VBelgian Waffle Baker with Electronic Controls
BWB1SE-120
BWB1SE- 240V
BWB1SE- 230V
21216
Belgian Single 7 Grid, 1/2 legs
120V, 60Hz, 1Ø, 900W, NEMA 5-15P
208/240V, 60Hz, 1Ø, 9676/900, NEMA 6-15P
220/240V, 60Hz, 1Ø, 900W, CE VII 436U
10-3/16 x 14 x
10-9/16 (closed)
30.2 2.93
$3,080.00
$3,080.00
$3,080.00
Accessories
Part Number Description Ship
Weight
Price
21489 Replacement Drip Tray, for models WB1 and WB2 1 $72.00
21107 Replacement Drip Tray, for model BWB1S 1 $62.00
EXPORT MODELS CANNOT BE RETURNED
F
F
WAFFLE BAKERS
WB1E
Operator-controlled, program-
mable digital temperature-
controls allow the operator to
precisely establish the perfect
bake time & temperature
LED digital displays
illuminate time and
temperature settings
An audible electric
alarm beeps when the
baking cycle is com-
plete
7” diameter 1/4” deep
aluminum cast grids
Stainless steel exterior
for strength, durability
and ease of cleaning
Stainless steel, remov-
able drip trays for easy
clean up
BWB1SE
Operator-controlled, program-
mable digital temperature-
controls allow the operator to
precisely establish the perfect
bake time & temperature
LED digital displays illuminate
time and temperature settings
An audible electric
alarm beeps when the
baking cycle is com-
plete
7” diameter 5/8” deep
aluminum cast grids
Stainless steel exterior
for strength, durability
and ease of cleaning
Stainless steel, remov-
able drip trays for easy
clean up
F
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 77
SYRUP DISPENSER & HOT WATER DISPENSERS
Model
Number
Part
Number
Description Size
W x D x H (in)
Ship
Weight
Cubic
Feet
Price
UHeated Dispenser
HD8799 22873 2.5 gallons, 140°F, no legs
120V, 1Ø, 200W, 1.7 AMP, NEMA 5-15P
9 x 9 x 20-11/16 11 1.5 $960.00
T
HEATED SYRUP DISPENSER
HD8799
Durable stainless
steel body and lid for
durability and ease of
cleaning
Stainless steel han-
dles for easy transport
No-drip faucet and
drip tray keeps ser-
vice station clean
Temperature ready indicator
light illuminates when prod-
uct reaches temperature
140° F fixed tem-
perature thermostat
insures consistent
product
2 ½ gallon capacity for
high volume operations
Hot Water Dispensers
Accessories
Part Number Description Std
Pkg
List Price
Each
FMWB-2G Front mount wall bracket for 2 gallon hot water dispenser 1 $140.00
FMWB-5G Front mount wall bracket for 5 gallon hot water dispenser 1 $140.00
WMBDT Mount wall bracket drip tray 1 $44.00
HWD-2G
Model
Number
Approvals Description Voltage Watts Amps Dimensions
(in)
Ship
Weight
(lbs)
Std
Pkg
List Price
Each
HWD-2G
HWD-2G-120C
N U
C
2 Gallon Hot Water Dispenser, NEMA-5-15P 120V
120V
1800 15 10-1/2”D
7”W
23-5/8”H
25 1 $102100
$102100
HWD-5G-208V N U C 5 Gallon Hot Water Dispenser, NEMA-6-30P 208V 4000 19 14-1/2”D
7”W
27-1/4”H
38 1 $150100
HWD-5G-240V N U
C
5 Gallon Hot Water Dispenser, NEMA-6-30P 240V 4000 16.5 14-1/2”D
7”W
27-1/4”H
38 1 $1,513.00
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
78
NOTES
MODEL NUMBER PAGE NUMBER NOTES
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 79
NOTES
MODEL NUMBER PAGE NUMBER NOTES
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com
80
ORDERING INFO
PLACE AN ORDER
Customer Service or to Place an order:
Phone: 314-678-6314
Fax: 314-781-5445
International Sales
Phone: 314-781-2777
Fax: 314-781-4344
Email:
orders@wellsbloomfield.com (equipment)
eorders@wellsbloomfield.com (parts)
IF UNABLE TO MAIL OR FAX AN ORDER , please call a Wells Sales Representative or the factory. Wells Customer Service Department hours are
800 a.m. to 430 p.m. Central Time.
NOTE: If placing order by phone, please send confirming order to a Wells Sales Representative or the factory. Make sure to mark written order
“CONFIRMING” to avoid duplicate orders, and please send to the attention of the person with whom you placed the order.
NEW ACCOUNT MINIMUM ORDER POLICY Contact your local sales representative to fill out application. $4000 minimum first time order required. All
applications are subject to approval.
REQUIRED INFORMATION ON ORDERS
A. Purchase order number.
B. SHIP TO and BILL TO addresses.
C. Phone number and person to contact in case of questions.
D. Product numbers, descriptions and electrical specifications of all items ordered.
E. Note any special shipping instructions.
EXPLANATION OF PHASE SYMBOLS
1Ø: single phase.
3Ø: three phase.
3Ø (1Ø): three phase, field convertible to single phase.
1Ø (3Ø): single phase, field convertible to three phase.
INDEPENDENT LABORATORY CERTIFICATIONS
U : means product is LISTED by Underwriter’s Laboratories, Inc.
NOTE: Special voltage requests may impact UL certification.
R : means product is approved under the component recognition program of Underwriter’s Laboratories, Inc.
NOTE: Installation of Recognized Units requires additional evaluation to Underwriters Laboratories Standards.
o : means product design is certified by the CSA Gas Division, for use in USA and Canada.
C : means product design is certified by the CSA Gas Division, for use in USA only.
N : all catalog items are certified by the National Sanitation Foundation, unless otherwise noted.
: means product is listed by Intertek testing laboratories.
EXPORT ORDERS Please consult factory.
RETURN POLICY
1. DAMAGES AND SHORTAGES
A. Inspect your shipments immediately. The transportation company is responsible for the merchandise while it is in transit to you.
B. If there is a shortage or damage to your shipment, action must be taken by you to notify carrier within 48 hours of receipt of shipment to assure approval of
claim. It is the duty and responsibility of the delivering carrier to give you a written report of such shortage or damage following notification.
C. For visible shortage or damage do not accept delivery unless the condition is noted on your copy of the freight bill and signed by the driver.
If damaged and unacceptable, please advise the carrier of this and also notify Wells Manufacturing.
D. CONCEALED DAMAGE: If the damage is concealed, notify the carrier within 48 hours by phone and in writing, asking them to send their agent to complete an
inspection report. Retain all cartons and merchandise for their inspection report and claim approval.
E. It is critical that you file a written claim with the carrier within 48 hours of receipt of shipment for any shortage or concealed damage. Enclose with your claim:
1. Carrier’s Inspection Report
2. Paid freight bill
3. Original or Certified Copy of invoice
2. RETURNS Goods may not be returned without prior approval from Wells. In order for merchandise to be returned, it must be in the original carton and unopened.
Product must be less than six months old from date of invoice.
Special merchandise built to a buyer’s specifications may not be returned. Returned goods must be shipped to Wells prepaid and will be credited at
invoice less 30% restocking charge. The restocking charge will be reduced to 20% if a replacement unit is ordered.
ALL CARTONS RETURNED MUST BE MARKED WITH RETURN AUTHORIZATION NUMBER. A NUMBERED FORM WITH THE CARTON LABEL WILL BE MAILED
TO THE CUSTOMER FOR EACH REQUEST. MULTIPLE CARTONS MUST EACH BE MARKED WITH THE RETURN AUTHORIZATION NUMBER.
A return authorization request will only be issued for a minimum purchase of $200 list price.
3. ORDERS FOR NON-STOCK EQUIPMENT Orders for non-stock equipment built to a buyer’s specifications will be subject to a 50% charge to the dealer in the
event of cancellation.
4. PRICES Prices are subject to change without notice. All prices in U.S. dollars.
Parts & Service:
Phone: 314-678-6314
Fax: 314-781-2714
International Parts &Service
Phone: 314-781-2777
Fax: 314-781-4344
Mail Orders To:
WELLS MANUFACTURING
P.O. BOX 430129 | 10 SUNNEN DRIVE
ST. LOUIS, MO 63143-3800
PURCHASE PARTS ONLINE!
https://www.starholdingsparts.com/estar/
WELLS MANUFACTURING | Phone: 314-678-6314 | International Phone: 314-781-2777 | Fax: 314-781-5445 | www.wellsbloomfield.com 81
ALL EQUIPMENT MANUFACTURED BY WELLS IS WARRANTED AGAINST DEFECTS IN MATERIALS AND WORKMANSHIP FOR THE TIME
PERIODS LISTED IN THE CHART BELOW STARTING FROM THE DATE THE EQUIPMENT IS PLACED INTO SERVICE AND IS FOR THE BENEFIT
OF THE ORIGINAL PURCHASER.
THE FOREGOING OBLIGATION IS EXPRESSLY GIVEN IN LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH ARE HEREBY EXCLUDED.
WELLS SHALL NOT BE LIABLE FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES FROM ANY CAUSE WHATSOEVER.
This warranty is void if it is determined that upon inspection by an authorized service agency that the equipment has been modified,
misused, misplaced, improperly installed, or damaged in transit or by fire, flood or act of God. It also does not apply if the serial
nameplate has been removed or service is performed by unauthorized personnel. The price charged by Wells for its products are based
upon limitations in this warranty. Seller’s obligation under this warranty is limited to the repair of defects without charge to Wells’
factory authorized service agency or one of its sub-agencies. This service will be provided on customer’s premises for non-portable
models. Portable models (countertop models with a cord and plug) must be taken or shipped to the closest authorized service agency,
transportation charges prepaid for service. In addition to restrictions contained in this warranty, specific limitations are shown in the
Service Policy and Procedure Guide. Wells’ authorized service agencies are located in principal cities. Please visit our website to locate
an authorized service agent at www.wellsbloomfield.com. This warranty is valid in the United States and Canada and void elsewhere.
Please consult your classified telephone directory, your foodservice equipment dealer or for more information and other details
concerning warranty write to:
SERVICE PARTS DEPARTMENT
10 SUNNEN DR. ST. LOUIS, MO 63143
PHONE: 314 6786314 FAX: 314 7815445
PARTS@WELLSBLOOMFIELD.COM
WWW.WELLSBLOOMFIELD.COM
WELLS SERVICE POLICY AND PROCEDURE GUIDE ADDITIONAL WARRANTY EXCLUSIONS
1. Resetting the safety thermostats, circuit breakers, overload protector or fuse replacements.
2. All problems due to operation at voltages other than specified in equipment nameplates - conversion to correct voltage and phase
are the customer’s responsibility.
3. All problems due to electrical connections not made in accordance with the electrical code requirements and wiring diagrams
supplied with the equipment.
4. Calibration of heat controls- replacement of items subject to normal wear to include such items as:
Knobs, light bulbs, baskets & grids. Normal maintenance functions including lubrication, adjustments to airflow, thermostats,
door mechanisms, micro switches, burners and pilot burners and replacement of fuses and indicating lights are not covered by
warranty.
5. All fry pots welded in the field.
6. Damage caused by lack of proper cleaning and maintenance, abrasion, hard-water (high in mineral content) and chlorides or
caustic cleansers is not covered by warranty.
7. Travel mileage is limited to fifty (50) miles from an Authorized Service Agency or one of its sub-agencies.
8. All labor shall be performed during regular working hours. Overtime premium will be charged to the buyer.
9. All genuine Wells replacement parts are warranted for ninety (90) days from the date of purchase on non-warranty equipment.
This parts warranty is limited to replacement of the defective part. Any use of non-genuine Wells parts completely voids any
warranty.
10. Installation, labor and job checkouts are not considered warranty.
11. Charges incurred by delays, waiting time or operating restrictions that hinder the service technicians’ ability to perform service
are not covered by warranty. This includes institutional and correctional facilities.
12. The equipment is not properly installed, adjusted, operated and maintained in accordance with National and local codes, and in
accordance with the instructions provided with the product.
13. All removable parts in Gas Char-broilers, including but not limited to burners, grates, radiants, and valves, are covered for a period
of six months only.
WARRANTY INFO
LIMITED WARRANTIES
EQUIPMENT PARTS LABOR
UNIVERSAL VENTLESS HOODS 2 YEARS 1 YEAR
CANOPY HOODS 2 YEARS 1 YEAR
WATER SAVER HEATED DISHER WELL 2 YEARS 1 YEAR
COOK’N HOLD 2 YEARS 1 YEAR
ALL BUILT-IN WARMERS 2 YEARS 1 YEAR
HEAVY-DUTY DRAWER WARMERS - BUILT-IN 2 YEARS 1 YEAR
COUNTERTOP WARMERS 2 YEARS 1 YEAR
OIL CADDY 1 YEAR 1 YEAR
ALL OTHER 1 YEAR 1 YEAR
WWW.WELLSBLOOMFIELD.COM
10 SUNNEN DR. ST. LOUIS, MO 63143 P 314.678.6314 F 314.781.5445
EMAIL: CLIENTCARE@WELLSBLOOMFIELD.COM
VENTLESS HOOD SYSTEMS BUILTINDROPIN WARMERS COLD & DUAL TEMP PANS
COOKING EQUIPMENT COUNTERTOP WARMERS WAFFLE BAKERS
