WIBE

Ladders

Wibe Ladder is supplied by MITA and complements the other

cable support systems that we offer.

All galvanised ladders are supplied in 6m lengths and

pre-galvanised ladders in 4m or 6m lengths.

Wibe is one of Europe’s largest cable ladder brands and offers

the fastest installation system available.

Wibe Cable Ladders are based around a rapid fit system.

The unique coupling method avoids the need for flat fishplates

which require up to 32 nuts, bolts and washer sets per coupling.

Instead of the usual 10-15 minutes time taken per ladder, the

Wibe coupler comes with 2 captive bolts and a complete

connection can be made in around 30 seconds.

Additionally, the WIBE pre-galvanised ladder offers impressive

materials cost savings for any internal applications and is ideal

for use in commercial buildings, hospitals, distribution centres,

shopping and retail applications.

HDG = Hot Dip Galvanised

PG = Pre-Galvanised

SS = Stainless Steel

EG = Electro Galvanised

ALU = Aluminium

LDPE= Plastic

Finishes

CABLE JOINTS, CABLE TERMINATIONS, CABLE GLANDS, CABLE CLEATS

FEEDER PILLARS, FUSE LINKS, ARC FLASH, CABLE ROLLERS, CUT-OUTS

11KV 33KV CABLE JOINTS & CABLE TERMINATIONS

FURSE EARTHING

www.cablejoints.co.uk

Thorne and Derrick UK

Tel 0044 191 490 1547 Fax 0044 191 477 5371

Tel 0044 117 977 4647 Fax 0044 117 9775582

WIBE Ladders

KHZSP Ladder

Cable Ladder PG = Pre-Galvanised

▲

718572 200 KHZSP 200P PG 4m

718573 300 KHZSP 300P PG 4m

718574 400 KHZSP 400P PG 4m

718575 500 KHZSP 500P PG 4m

718576 600 KHZSP 600P PG 4m

781099 800 KHZPS 800P PG 6m

725356 1000 KHZPS 1000P PG 6m

Alt Code Type Mita Ref Finish Packed Price (£) per 4m

Alt Code Type Mita Ref Finish Packed Price (£) per 6m

*non stocked product

length

Flat Interior Bend

▲

723061 15/200 KAI 15200P PG 1

723062 15/300 KAI 15300P PG 1

723063 15/400 KAI 15400P PG 1

723064 15/500 KAI 15500P PG 1

723065 15/600 KAI 15600P PG 1

721961 15/800 KAI 15800G HDG 1

716073 15/1000 KAI 151000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Flat Exterior Bend*

▲

716180 15/200 KAE 15200G HDG 1

716182 15/300 KAE 15300G HDG 1

716183 15/400 KAE 15400G HDG 1

716184 15/500 KAE 15500G HDG 1

716185 15/600 KAE 15600G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Riser

▲

718177 18/200 KI 18200G HDG 1

718179 18/300 KI 18300G HDG 1

718180 18/400 KI 18400G HDG 1

718181 18/500 KI 18500G HDG 1

718182 18/600 KI 18600G HDG 1

721964 18800 KI 18800G HDG 1

718183 18/1000 KI 181000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

T Junction

▲

716194 16/200 KT 16200G HDG 1

716196 16/300 KT 16300G HDG 1

716197 16/400 KT 16400G HDG 1

716198 16/500 KT 16500G HDG 1

716199 16/600 KT 16600G HDG 1

721962 16/800 KT 16800G HDG 1

716200 16/1000 KT 161000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

X Junction

▲

716210 17/200 KX 17200G HDG 1

716212 17/300 KX 17300G HDG 1

716213 17/400 KX 17400G HDG 1

716214 17/500 KX 17500G HDG 1

716215 17/600 KX 17600G HDG 1

721963 17/800 KX 17800G HDG 1

716216 17/1000 KX 171000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Joint 19

▲

716048 Joint 19 KJC 19P PG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

718409 Coupling 22 KVHC 22G HDG 1

Universal Coupling

▲

725096 14 KJT 14G HDG 1

Junction Coupling

▲

732151 28P KPP 28P Grey 1 x 2m

Plastic

Profile Protection

▲

725363 41 KPC 41P PG 1

Profile Clamp

▲

709017 Fixed Take-off Hook 4 KTOH 4A ALU 1

709018 End Connection 10 KEC 10A ALU 1

Accessories

▲

768733 Angle Plate 33/1* KAP 331P PG 1

707748 Angle Plate 33/2 KAP 332G HDG 1

Corner Plates

▲

length

Accessories

Ordering Information KHZSP Ladder is ordered and priced in either 4m or 6m lengths

Alt Code Type Mita Ref Finish Packed Price (£) each

800210 42S KPC 42SG HDG 1

Hold Down Clamp

▲

01745 586011

technical advice:

CONTACT

tel: 01745 586011 fax: 01745 586015 email: sales@mita.co.uk web site: www.mita.co.uk

Riser

▲

718176 18/150 KI 18150G HDG 1

718177 18/200 KI 18200G HDG 1

718179 18/300 KI 18300G HDG 1

718180 18/400 KI 18400G HDG 1

718181 18/500 KI 18500G HDG 1

718182 18/600 KI 18600G HDG 1

721964 18/800 KI 18800G HDG 1

718183 18/1000 KI 181000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

*non stocked product

length

Cable Ladder G = Galvanised

▲

718562 150 KHZP 150G HDG 6m

718563 200 KHZP 200G HDG 6m

718564 300 KHZP 300G HDG 6m

718565 400 KHZP 400G HDG 6m

718566 500 KHZP 500G HDG 6m

718567 600 KHZP 600G HDG 6m

721960 800 KHZP 800G HDG 6m

718568 1000 KHZP 1000G HDG 6m

Alt Code Type Mita Ref Finish Packed Price (£) per 6m

Flat Interior Bend

▲

716066 15/150 KAI 15150G HDG 1

716067 15/200 KAI 15200G HDG 1

716069 15/300 KAI 15300G HDG 1

716070 15/400 KAI 15400G HDG 1

716071 15/500 KAI 15500G HDG 1

716072 15/600 KAI 15600G HDG 1

721961 15/800 KAI 15800G HDG 1

716073 15/1000 KAI 151000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Flat Exterior Bend*

▲

716180 15/200 KAE 15200G HDG 1

716182 15/300 KAE 15300G HDG 1

716183 15/400 KAE 15400G HDG 1

716184 15/500 KAE 15500G HDG 1

716185 15/600 KAE 15600G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

T Junction

▲

716194 16/200 KT 16200G HDG 1

716196 16/300 KT 16300G HDG 1

716197 16/400 KT 16400G HDG 1

716198 16/500 KT 16500G HDG 1

716199 16/600 KT 16600G HDG 1

721962 16/800 KT 16800G HDG 1

716200 16/1000 KT 161000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

X Junction

▲

716210 17/200 KX 17200G HDG 1

716212 17/300 KX 17300G HDG 1

716213 17/400 KX 17400G HDG 1

716214 17/500 KX 17500G HDG 1

716215 17/600 KX 17600G HDG 1

721963 17/800 KX 17800G HDG 1

716216 17/1000 KX 171000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Joints

▲

705304 Joint 9 KJC 9G HDG 1

708740 Joint 21 KJC 21G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

718409 Coupling 22 KVHC 22G HDG 1

Universal Coupling

▲

709017 Fixed Take-off Hook 4 KTOH 4A ALU 1

709018 End Connection 10 KEC 10A ALU 1

Accessories

▲

768733 Angle Plate 33/1* KAP 331P PG 1

707748 Angle Plate 33/2 KAP 332G HDG 1

Corner Plates

▲

725096 14 KJT 14G HDG 1

Junction Coupling

▲

732151 28P KPP 28P Grey 1 x 2m

Plastic

Profile Protection

▲

720824 41 KPC 41G HDG 1

Profile Clamp

▲

Accessories

Alt Code Type Mita Ref Finish Packed Price (£) each

800210 42S KPC 42SG HDG 1

Hold Down Clamp

▲

KHZP Ladder

Ordering Information KHZP Ladder is ordered and priced in 6m lengths

WIBE Ladders

Cable Ladder HDG = Hot Dip Galvanised

▲

768001 150 KHZ 150G HDG 6m

768002 200 KHZ 200G HDG 6m

768004 300 KHZ 300G HDG 6m

768005 400 KHZ 400G HDG 6m

768006 500 KHZ 500G HDG 6m

768007 600 KHZ 600G HDG 6m

Alt Code Type Mita Ref Finish Packed Price (£) per 6m

*non stocked product

length

Flat Internal Bend

▲

720923 15/150 KAI 15150RG 1

720924 15/200 KAI 15200RG 1

720925 15/300 KAI 15300RG 1

720926 15/400 KAI 15400RG 1

720927 15/500 KAI 15500RG 1

720928 15/600 KAI 15600RG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Riser

▲

720935 18/150 KHZI 18150G 1

720936 18/200 KHZI 18200G 1

720937 18/300 KHZI 18300G 1

720938 18/400 KHZI 18400G 1

720939 18/500 KHZI 18500G 1

720940 18/600 KHZI 18600G 1

Alt Code Type Mita Ref Finish Packed Price (£) each

T Junction

▲

720929 16/150 KHZT 16150G 1

720930 16/200 KHZT 16200G 1

720931 16/300 KHZT 16300G 1

720932 16/400 KHZT 16400G 1

720933 16/500 KHZT 16500G 1

720934 16/600 KHZT 16600G 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Intermediate Connection Bolts

▲

705392 29/200 KICB 29200G HDG 1

705394 29/300 KICB 29300G HDG 1

705395 29/400 KICB 29400G HDG 1

705396 29/500 KICB 29500G HDG 1

705397 29/600 KICB 29600G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Joints

▲

705304 Joint 9 KJC 9G HDG 1

708740 Joint 21 KJC 21G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Alt Code External Mita Ref Finish Packed Price (£) each

Alt Code Plug Mita Ref Finish Packed Price (£) each

Alt Code Type Mita Ref Finish Packed Price (£) each

718409 Coupling 22 KVHC 22G HDG 1

Universal Coupling

▲

725096 14 KJT 14G HDG 1

Junction Coupling

▲

732151 28P KPP 28P Grey 1 x 2m

Plastic

Profile Protection

▲

720824 41 KPC 41G HDG 1

Profile Clamps

▲

726668 Plug 27 KCMP 27 Silver LDPE 1

617522 Rung Plug KRPK 71571LDPE Clear LDPE 1

Cross Member Plug

▲

709019 External 28 KEP 28 LDPE 1

731994 Internal 28i KEP 281FF LDPE 1

End Plugs

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

709017 Fixed Take-off Hook 4 KTOH 4A ALU 1

709018 End Connection 10 KEC 10A ALU 1

Accessories

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

768733 33/1 KAP 331P* PG 1

707748 33/2 KAP 332G HDG 1

Corner Plates

▲

length

Accessories

Alt Code Type Mita Ref Finish Packed Price (£) each

800210 42S KPC 42SG HDG 1

Hold Down Clamp

▲

KHZ Ladder

Ordering Information KHZ Ladder is ordered and priced in 6m lengths

01745 586011

technical advice:

CONTACT

tel: 01745 586011 fax: 01745 586015 email: sales@mita.co.uk web site: www.mita.co.uk

Cable Ladder HDG = Hot Dip Galvanised

▲

717982 200 KHZPV 200G HDG 6m

717983 300 KHZPV 300G HDG 6m

717984 400 KHZPV 400G HDG 6m

717985 500 KHZPV 500G HDG 6m

717986 600 KHZPV 600G HDG 6m

716400 1000 KHZPV 1000G HDG 6m

Alt Code Type Mita Ref Finish Packed Price (£) per 6m

*non stocked product

length

Flat Interior Bend

▲

716241 55/200 KHZVA 55200G HDG 1

716243 55/300 KHZVA 55300G HDG 1

716244 55/400 KHZVA 55400G HDG 1

716245 55/500 KHZVA 55500G HDG 1

716246 55/600 KHZVA 55600G HDG 1

716247 55/1000 KHZVA 551000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

T Junction

▲

716255 56/200 KHZVT 56200G HDG 1

716257 56/300 KHZVT 56300G HDG 1

716258 56/400 KHZVT 56400G HDG 1

716259 56/500 KHZVT 56500G HDG 1

716260 56/600 KHZVT 56600G HDG 1

716261 56/100 KHZVT 561000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Riser Coupling

▲

716389 49/200 KRC 49200G HDG 1

716390 49/300 KRC 49300G HDG 1

716391 49/400 KRC 49400G HDG 1

720517 49/500 KRC 49500G HDG 1

716392 49/600 KRC 49600G HDG 1

716393 49/1000 KRC 491000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Screw Set

(set of 4)

▲

706415 M12 KSSM 12G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

707609 45 KJ 45G HDG 1

(includes fixing and joining screw set)

Cut End - Joint

▲

718643 Heavy Duty 200mm KLBHD 200 HDG 1

Lighting Bracket

▲

707511 43 KPC 43G HDG 1

Profile Clamp

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

708001 46 KPSP 46G HDG 1

Profile Support Piece

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

720815 44 KCC 44G HDG 1

731837 51 KJC 51G HDG 1

718901 48/30 Coupling Plate KCP 4830G HDG 1

718902 48/60 Coupling Plate KCP 4860G HDG 1

718411 48/45 Coupling Plate KCP 4845G HDG 1

(excludes joint screws)

Coupling

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

714353 47 KTH 47G HDG 1

Take Off Hook

▲

Accessories

KHZPV Ladder

Ordering Information KHZPV Ladder is ordered and priced in 6m lengths

WIBE Ladders

Covers Accessories

for Trunking Body*

▲

732216 W5-150 KCW 5150P PG 1

732217 W5-200 KCW 5200P PG 1

732218 W5-300 KCW 5300P PG 1

732219 W5-400 KCW 5400P PG 1

732220 W5-500 KCW 5500P PG 1

732221 W5-600 KCW 5600P PG 1

732222 W5-1000 KCW 51000P PG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

length

for Flat Interior Bend*

▲

732322 150 KCA 15150 PG 1

732323 200 KCA 15200 PG 1

732324 300 KCA 15300 PG 1

732325 400 KCA 15400 PG 1

732326 500 KCA 15500 PG 1

732327 600 KCA 15600 PG 1

732328 1000 KCA 151000 PG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

for T Junction*

▲

732345 150mm KTC 16150 PG 1

732346 200mm KTC 16200 PG 1

732347 300mm KTC 16300 PG 1

732348 400mm KTC 16400 PG 1

732349 500mm KTC 16500 PG 1

732350 600mm KTC 16600 PG 1

732351 1000mm KTC 161000 PG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Cover Joints

▲

712639 150 KCJ 150P PG 1

712640 200 KCJ 200P PG 1

712642 300 KCJ 300P PG 1

712643 400 KCJ 400P PG 1

712644 500 KCJ 500P PG 1

712645 600 KCJ 600P PG 1

(for 1000 use 2 x 500)

Alt Code Type Mita Ref Finish Packed Price (£) each

*non stocked product

Alt Code Type Mita Ref Finish Packed Price (£) each

729217 37 KPSP 37P PG 1

(Use with screw set W38)

Profile Support Piece

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

725065 36/50 KTC 3650P PG 1

725066 36/100 KTC 36100P PG 1

725067 36/200 KTC 36200P PG 1

Tele-Conduit 36*

With knockout holes

▲

728653 12/70 KC 1270G HDG 1

728654 12/120 KC 12120G HDG 1

Clamp 12*

▲

716824 Joint W39 KJW39 PG 1

Joint W39*

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

718618 35P KJBP 35P PG 1

711205 355 KJBP 355P PG 1

Junction Box Plate*

▲

Alt Code Type Mita Ref Finish Packed Price (£) each

716640 W79 KECW 49E EG 1

Earth Clamp W79*

▲

length

Alt Code Type Mita Ref Finish Packed Price (£) each

718835 39/24 KD 3924P PG 1

725785 39/55 KD 3955P PG 1

Dividing Strip 39*

▲

1.75m

length

01745 586011

technical advice:

CONTACT

tel: 01745 586011 fax: 01745 586015 email: sales@mita.co.uk web site: www.mita.co.uk

Cable Clamps Support Work

Cantilever Arm 50

▲

723432 50/100 KCA50 100G HDG 1

723433 50/150 KCA50 150G HDG 1

723434 50/200 KCA50 200G HDG 1

723435 50/250 KCA50 250G HDG 1

723436 50/300 KCA50 300G HDG 1

723437 50/400 KCA50 400G HDG 1

723438 50/500 KCA50 500G HDG 1

723439 50/600 KCA50 600G HDG 1

727128 50/1000* KCA50 1000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Vertical Piece 2

▲

717191 2/300 KVP 2300G HDG 1 7.53

717192 2/400 KVP 2400G HDG 1 8.46

717193 2/500 KVP 2500G HDG 1 8.99

717194 2/700 KVP 2700G HDG 1 9.80

717195 2/1000 KVP 21000G HDG 1 10.84

Alt Code Type Mita Ref Finish Packed Price (£) each

Vertical Piece 2F

▲

717196 2F/280 KVP2F 280G HDG 1 8.99

717197 2F/370 KVP2F 370G HDG 1 10.49

717198 2F/505 KVP2F 505G HDG 1 12.28

717199 2F/730 KVP2F 730G HDG 1 13.26

717200 2F/1000 KVP2F 1000G HDG 1 15.70

Vertical Piece 20

▲

715723 20/505 KVP20 505G HDG 1 31.80

715724 20/730 KVP20 730G HDG 1 36.70

715725 20/1000 KVP20 1000G HDG 1 38.99

715726 20/1500 KVP20 1500G HDG 1 49.34

715727 20/2000 KVP20 2000G HDG 1 62.08

715728 20/3000 KVP20 3000G HDG 1 87.86

Vertical Piece 20F & 20S

▲

718249 20F/1000 KVP20F 1000G HDG 1 68.95

718250 20F/1500 KVP20F 1500G HDG 1 94.59

718251 20F/2000 KVP20F 2000G HDG 1 117.48

709799 20F/3000 KVP20F 3000G HDG 1 128.95

718721 20FS/3000 KVP20FS 3000G HDG 1 263.49

Cantilever Arm 50F

▲

718624 50F/200 KCA50F 200G HDG 1

718625 50F/300 KCA50F 300G HDG 1

718626 50F/400 KCA50F 400G HDG 1

718627 50F/500 KCA50F 500G HDG 1

718628 50F/600 KCA50F 600G HDG 1

712465 50F/1000* KCA50F 1000G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Cantilever Arm 50L

▲

725107 50L/200 KCA50L 200G HDG 1 6.27

725109 50L/300 KCA50L 300G HDG 1 6.72

Alt Code Type Mita Ref Finish Packed Price (£) each

Accessories for Arms

▲

768738 Back Plate 40 KBP 40G HDG 1 4.19

717001 Mounting Rail KMR 40G HDG 1 4.98

Alt Code Type Mita Ref Finish Packed Price (£) each

Profile Clamps

▲

705611 42 KPC 42G HDG 1 1.73

800210 42S KPC 42SG HDG 1 1.74

707511 43 KPC 43G HDG 1 1.72

Alt Code Type Mita Ref Finish Packed Price (£) each

Cable Clamp Type A1 For 1 cable

▲

718507 A1-12 KCCA 112P PG 1

718508 A1-16 KCCA 116P PG 1

718509 A1-22 KCCA 122P PG 1

718510 A1-28 KCCA 128P PG 1

718511 A1-36 KCCA 136P PG 1

718512 A1-44 KCCA 144P PG 1

718513 A1-52 KCCA 152P PG 1

718514 A1-60 KCCA 160P PG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Cable Clamp Type R1 For 1 cable

▲

769000 R1-12 KCCR 112P PG 1 1.03

769001 R1-16 KCCR 116P PG 1 1.10

769002 R1-22 KCCR 122P PG 1 1.18

769003 R1-28 KCCR 128P PG 1 1.22

769004 R1-36 KCCR 136P PG 1 1.41

769005 R1-44 KCCR 144P PG 1 1.60

769006 R1-52 KCCR 152P PG 1 1.71

769007 R1-60 KCCR 160P PG 1 1.77

769008 R1-70 KCCR 170P PG 1 2.07

Alt Code Type Mita Ref Finish Packed Price (£) each

Cable Clamp Type R2 For 2 cables

▲

769009 R2-12 KCCR 212P PG 1 1.21

769010 R2-16 KCCR 216P PG 1 1.27

769011 R2-22 KCCR 222P PG 1 1.47

769012 R2-28 KCCR 228P PG 1 1.72

769013 R2-36 KCCR 236P PG 1 1.77

769014 R2-44 KCCR 244P PG 1 1.85

769015 R2-52 KCCR 252P PG 1 2.35

769016 R2-60 KCCR 260P PG 1 2.47

Alt Code Type Mita Ref Finish Packed Price (£) each

Insert Piece

▲

709050 EM-12 KIEM 12 PVC 1 0.35

709051 EM-16 KIEM 16 PVC 1 0.39

709052 EM-22 KIEM 22 PVC 1 0.47

709053 EM-28 KIEM 28 PVC 1 0.49

709054 EM-36 KIEM 36 PVC 1 0.54

709055 EM-44 KIEM 44 PVC 1 0.62

709056 EM-52 KIEM 52 PVC 1 0.66

709057 EM-60 KIEM 60 PVC 1 0.69

709058 EM-70 KIEM 70 PVC 1 0.72

Alt Code Type Mita Ref Finish Packed Price (£) each

Cable Roller

▲

718660 Type S KCRSG HDG 1 82.41

Alt Code Type Mita Ref Finish Packed Price (£) each

Cable Clamp Type A2 For 2 cables

▲

718516 A2-12 KCCA 212P PG 1

718517 A2-16 KCCA 216P PG 1

718518 A2-22 KCCA 222P PG 1

718519 A2-28 KCCA 228P PG 1

718520 A2-36 KCCA 236P PG 1

718521 A2-44 KCCA 244P PG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

*non stocked product

For KHZP & KHZPV Ladders

For KHZ Ladder

Inserts for all clamps

WIBE Ladders

Support Work

Screw Sets

▲

715735 2S KSS 2SG HDG 1

715736 20S KSS 20SG HDG 1

713694 22S KSS 22SG HDG 1

706415 M12 KSS M12G HDG 1

716407 24S KSS 24SG HDG 1

718632 Back Nut M8 KBN 8G HDG 1

718473 W34 KSSW 34E EG 1

715646 W36 KSSW 36E EG 1

716907 W38 KSSW 38G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Pendant/Fixing Rails

▲

715879 24/34 KPF 2434G HDG 1

705092 24/40 KPF 2440G HDG 1

705093 24/48 KPF 2448G HDG 1

709795 24/20 KPF 2420G HDG 1

709798 24/20F KPF 2420F HDG 1

718808 24/20F KPF 2420FL5940G HDG 1

709031 24/20FS KPF 2420FSL5940G HDG 1

768063 24/26x53 KFR 2426X53G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Pendant Joints

▲

713177 2J KP J2JG HDG 1

713178 2FJ KP J2JFG HDG 1

713173 2OJ KP J2OJG HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Ceiling Bracket 5

▲

718640 5 KCB 5G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Pendant Base Plate

▲

718253 5 KPBP 520G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Support Bracket 3

▲

720761 3/150 KSB 3150G HDG 1

720762 3/200 KSB 3200G HDG 1

720763 3/300 KSB 3300G HDG 1

720764 3/400 KSB 3400G HDG 1

720765 3/500 KSB 3500G HDG 1

720766 3/600 KSB 3600G HDG 1

Each bracket requires 2 x Clamp 42

Alt Code Type Mita Ref Finish Packed Price (£) each

Wall Brackets 11/25 & 11/75

▲

713204 11/25 KWB 1125G HDG 1

713203 11/75 KWB 1175G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

length

2.97m

length

5.94m

length

Beam Clamp

▲

715675 5BK-10 KBC5BK 10G HDG 1

718243 5BK-30 KBC5BK 30G HDG 1

713153 5TP KBC5TPG HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Bracket 60/40

▲

718904 60/40 KB 6040G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Wall Bracket

▲

723450 20 KWB 20 HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Angle Bracket 5L

▲

731791 5L KAB 5LG HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Angle Bracket 5LS

▲

709801 5L KAB 5LSG HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

End Bracket HT-11

▲

717618 HT-11 KEB HT11G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Clamp set M6

▲

720786 M6-25 KCM 625SS HDG 1 7.65

Alt Code Type Mita Ref Finish Packed Price (£) each

T-bolts

▲

716794 26/F30 KTB 26F30G HDG 1

716795 26/F40 KTB 26F40G HDG 1

716796 26/F50 KTB 26F50G HDG 1

714009 26 KTB 26G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Round Bar Fixing for floors

▲

718312 KRBF HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Ceiling Plate

▲

718849 20F KCP20FG HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

Pendant Bar 1

▲

717640 1/300 KPB 1300G HDG 1

717641 1/500 KPB 1500G HDG 1

717642 1/800 KPB 1800G HDG 1

718903 1/1500 KPB 11500G HDG 1

Alt Code Type Mita Ref Finish Packed Price (£) each

End Plugs

▲

709021 28E KEP 28E LDPE 1

709020 28D KEP 28D LDPE 1

Alt Code Type Mita Ref Finish Packed Price (£) each

726668 Wibe Cable Ladders

Navigation menu

Versions of this User Manual:

Views

Navigation
