USER’S MANUAL
Revision 1.0
X10DBT
X10DBT-T
Manual Revision 1.0
Release Date: July 9, 2014
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2014 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
The information in this user’s manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
and makes no commitment to update or to keep current the information in this manual, or to notify
any person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE
USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between the manufacturer and the customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of Santa Clara
shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.
Preface
This manual is written for system integrators, IT professionals, and
knowledgeable end-users. It provides information for the installation and use of the
X10DBT/X10DBT-T motherboard.
About This Motherboard
The Super X10DBT(-T) motherboard supports dual Intel E7-2800v2/E7-4800*/
E7-8800* series processors that offer new Intel Microarchitecture 22nm Process
Technology, delivering the best balanced solution of performance, power efciency,
and features to address the diverse needs of next-generation data centers. With
the PCH C602 built in, the X10DBT(-T) motherboard supports Integrated Clock-
ing, Advanced Management Bus Infrastructure, MCTP Protocol, and Intel® Node
Manager 3.0. This motherboard is optimized for high-performance cloud-computing
platforms. Please refer to our website (http://www.supermicro.com) for CPU and
memory support updates.
(*E7-4800/E7-8800 CPU support is veried on some SKUs only. For CPU support
updates, please refer to our website.)
Manual Organization
Chapter 1 describes the features, specications and performance of the moth-
erboard. It also provides detailed information about the Intel PCH C602 chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory, and system setup stored in the CMOS.
Chapter 4 includes an introduction to the BIOS, and provides detailed information
on running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists Software Installation Instructions.
Appendix C contains UEFI BIOS Recovery instructions.
Preface
iii
iv
Conventions Used in the Manual
Pay special attention to the following symbols for proper system installation:
Warning: Important information given to ensure proper system installation or to prevent
damage to the components or injury to yourself;
Note: Additional information given to differentiate between models or
instructions provided for proper system setup.
X10DBT/X10DBT-T Motherboard User’s Manual
Preface
v
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: marketing@supermicro.com (General Information)
support@supermicro.com (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: sales@supermicro.nl (General Information)
support@supermicro.nl (Technical Support)
rma@supermicro.nl (Customer Support)
Web Site: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3992
Email: support@supermicro.com.tw
Web Site: www.supermicro.com.tw
vi
Table of Contents
Preface
Chapter 1 Overview
1-1 Overview ......................................................................................................... 1-1
1-2 Processor and Chipset Overview...................................................................1-11
1-3 Special Features ........................................................................................... 1-12
1-4 System health Monitoring ............................................................................. 1-12
1-5 ACPI Features ............................................................................................... 1-13
1-6 Power Supply ................................................................................................ 1-13
1-7 Advanced Power Management ..................................................................... 1-14
Intel® Intelligent Power Node Manager (NM) (Available when the "Supermicro
Power Manager (SPM)" is Installed) ............................................................. 1-14
Management Engine (ME) ............................................................................ 1-14
Chapter 2 Installation
2-1 Standardized Warning Statements ................................................................. 2-1
Battery Handling .............................................................................................. 2-1
Product Disposal ............................................................................................. 2-3
2-2 Static-Sensitive Devices .................................................................................. 2-4
Precautions ..................................................................................................... 2-4
Unpacking ....................................................................................................... 2-4
2-3 Processor and Heatsink Installation................................................................ 2-5
Installing the E7-2800/E7-4800*/E7-8800* Series Processor ....................... 2-5
Installing a Passive CPU Heatsink ................................................................. 2-9
Removing the Heatsink ................................................................................. 2-10
2-4 Installing and Removing the Memory Modules ..............................................2-11
Installing & Removing DIMMs ........................................................................2-11
Removing Memory Modules ..........................................................................2-11
2-5 Motherboard Installation ................................................................................ 2-14
Tools Needed ................................................................................................ 2-14
Location of Mounting Holes .......................................................................... 2-14
Installing the Motherboard ............................................................................ 2-15
2-6 Control Panel Connectors and I/O Ports ...................................................... 2-16
Back Panel Connectors and I/O Ports .......................................................... 2-16
Back Panel I/O Port Locations and Denitions ........................................... 2-16
Video Connection ..................................................................................... 2-17
Ethernet Ports .......................................................................................... 2-17
Universal Serial Bus (USB) ...................................................................... 2-18
Serial Port ................................................................................................. 2-18
X10DBT/X10DBT-T Motherboard User’s Manual
vii
Table of Contents
Unit Identier Switch/UID LED Indicator .................................................. 2-19
2-7 Connecting Cables ........................................................................................ 2-20
Power Output Connector ........................................................................ 2-20
Fan Headers ............................................................................................. 2-21
IPMB ......................................................................................................... 2-21
TPM/Port 80 Header ................................................................................ 2-22
SATA DOM Power Connectors ................................................................ 2-22
2-8 Jumper Settings ............................................................................................ 2-23
Explanation of Jumpers ................................................................................ 2-23
LAN Enable/Disable ................................................................................. 2-23
CMOS Clear ............................................................................................. 2-24
Watch Dog Enable/Disable ...................................................................... 2-24
VGA Enable .............................................................................................. 2-25
BMC Enable ............................................................................................ 2-25
I2C Bus to PCI-Exp. Slots ........................................................................ 2-26
Manufacturer Mode Select ....................................................................... 2-27
ME Recovery ........................................................................................... 2-27
2-9 Onboard LED Indicators ............................................................................... 2-28
LAN LEDs ................................................................................................. 2-28
IPMI Dedicated LAN LEDs ....................................................................... 2-28
Onboard Power LED ............................................................................... 2-29
BMC Heartbeat LED ................................................................................ 2-29
ME Power State Select ........................................................................... 2-30
2-10 SATA Connections ......................................................................................... 2-30
SATA 2.0/3.0 Ports ................................................................................... 2-30
Chapter 3 Troubleshooting
3-1 Troubleshooting Procedures ........................................................................... 3-1
Before Power On ............................................................................................ 3-1
No Power ........................................................................................................ 3-1
No Video ......................................................................................................... 3-2
System Boot Failure ..................................................................................... 3-2
Losing the System’s Setup Conguration ....................................................... 3-2
Memory Errors ............................................................................................... 3-3
When the System Becomes Unstable ............................................................ 3-3
3-2 Technical Support Procedures ........................................................................ 3-4
3-3 Battery Removal and Installation .................................................................... 3-6
Battery Removal .............................................................................................. 3-6
Proper Battery Disposal .................................................................................. 3-6
3-4 Frequently Asked Questions ........................................................................... 3-7
viii
3-5 Returning Merchandise for Service................................................................. 3-8
Chapter 4 BIOS
4-1 Introduction ...................................................................................................... 4-1
Starting BIOS Setup Utility .............................................................................. 4-1
How To Change the Conguration Data ......................................................... 4-2
Starting the Setup Utility ................................................................................. 4-2
4-2 Main Setup ...................................................................................................... 4-2
4-3 Advanced Setup Congurations...................................................................... 4-4
4-4 Event Logs ....................................................................................................4-45
4-5 IPMI ............................................................................................................... 4-47
4-6 Security .........................................................................................................4-49
4-7 Boot ............................................................................................................... 4-50
4-8 Save & Exit ...................................................................................................4-52
Appendix A
BIOS Error Beep Codes
A-1 BIOS Error Beep Codes .................................................................................A-1
Appendix B Software Installation Instructions
B-1 Installing Software Programs ..........................................................................B-1
B-2 Conguring SuperDoctor 5 .............................................................................B-2
Appendix C UEFI BIOS Recovery Instructions
C-1 An Overview to the UEFI BIOS ......................................................................C-1
C-2 How to Recover the UEFI BIOS Image (-the Main BIOS Block)....................C-1
C-3 To Recover the Main BIOS Block Using a USB-Attached Device..................C-1
X10DBT/X10DBT-T Motherboard User’s Manual
Chapter 1: Overview
1-1
Chapter 1
Overview
1-1 Overview
Checklist
Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance.
Note 1: The X10DBT(-T) motherboard was designed to be used with a
Supermicro-proprietary chassis as an integrated server platform. It is not
to be used as a stand-alone product and will not be shipped independently
in a retail box. No motherboard shipping package will be provided in your
shipment.
Note 2: For your system to work properly, please follow the links below
to download all necessary drivers/utilities and the user's manual for your
system.
•Supermicro product manuals: http://www.supermicro.com/support/manuals/
•Product Drivers and utilities: ftp://ftp.supermicro.com/
Note 3: For safety considerations, please refer to the complete list of safety
warnings posted on the Supermicro website at http://www.supermicro.com/
about/policies/safety_information.cfm
If you have any questions, please contact our support team at support@
supermicro.com.
1-2
X10DBT/X10DBT-T Motherboard User’s Manual
X10DBT(-T) Motherboard Image
Note: All graphics shown in this manual were based upon the latest PCB
revision available at the time of publishing of the manual. The motherboard
you've received may or may not look exactly the same as the graphics
shown in this manual.
Chapter 1: Overview
1-3
X10DBT(-T) Motherboard Layout
Note: For the latest CPU/memory updates, please refer to our website at
http://www.supermicro.com/products/motherboard/ for details.
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
1-4
X10DBT/X10DBT-T Motherboard User’s Manual
X10DBT(-T) Quick Reference
Notes:
•See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front
panel connections.
•" " indicates the location of "Pin 1".
•Jumpers/LED Indicators not indicated are for internal testing only.
•Use only the correct type of onboard CMOS battery as specied by the manufac-
turer. Do not install the onboard battery upside down to avoid possible explosion.
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
Chapter 1: Overview
1-5
X10DBT(-T) Jumpers
Jumper Description Default Setting
JBT1 Clear CMOS See Chapter 3
JI2C1/JI2C2 SMB to PCI-E slots Pins 2-3 (Disabled)
JPB1 BMC Enable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 GLAN1/GLAN2 Enable (X10DBT)
10_GLAN1/10G_LAN2 Enable (X10DBT-T)
Pins 1-2 (Enabled)
JPME1 Manufacture Mode (ME) Recovery Pins 1-2 (Normal)
JPME2 Manufacture Mode (ME) Select Pins 1-2 (Normal)
JWD1 Watch-Dog Timer Enable Pins 1-2 (Reset)
X10DBT(-T) Connectors
Connectors Description
Battery (BT2) Onboard Battery (See Chpt. 3 for used battery disposal)
COM1 Backplane COM port
FAN5, FAN6 CPU/System fan headers
I-SATA4/5 Intel SATA 3.0 connectors (4/5) from Intel PCH
JIPMB1 4-pin external BMC I2C header (for IPMI-card support)
JPW1 +12V Power Output connector header
JSD1/JSD2 SATA DOM (Device-On-Module) power connectors 1/2
JTPM1 TPM (Trusted Platform Module)/Port 80 header
LAN1/LAN2 G-bit Ethernet (GLAN) ports 1/2 (for X10DBT)
10 G-bit Ethernet (GLAN) ports 1/2 (for X10DBT-T)
(IPMI)_LAN IPMI_Dedicated LAN support by the BMC
NVMe8A/NVMe8B Solid-State Drive (SSD) slots for SMCI-proprietary Non-
Volatile Memory Express (NVMe) devices with Windows
8 support (Note: The part number for the add-on card to
be used with NVMe8A or NVMe8B is BPN-ADP-8PCIE3-
1UBR.)
SXB1A/1B/1C SMC-proprietary PCI-E 3.0 x16+x16 slot for riser card sup-
port (Left)
SXBP SMC-proprietary PCI-E 3.0x8 slot for storage add-on cards
with two SATA 3.0 and six SATA 2.0 connections supported
(Right) (Note: The part number for the add-on card to be
used for SXBP is BPN-ADP-8SATA3-1UBL-O-P or BPN-
ADP-SAS3-227HD-N2.)
SXB3 Micro-LP (Low-Prole) PCI-E 3.0 x8 slot
SXB4_2 Solid-State Drive (SSD) Slot B for Non-Volatile Memory Ex-
press (NVMe) drive with Windows 8 support
SW1 UID Switch
1-6
X10DBT/X10DBT-T Motherboard User’s Manual
(BP) USB 0/1 (2.0) Backpanel USB 2.0 Port 0/ Port 1
(FP) USB 2 (2.0) Front-accessible Type A USB 2.0 connection header
VGA Backpanel VGA port
X10DBT(-T) LED Indicators
LED Description State Status
LE1 Standby Power LED On Power On
LE3 BMC Heartbeat LED Green: Blinking BMC Normal
UID_LED1 Rear UID LED Blue: On Unit Identied
Chapter 1: Overview
1-7
Motherboard Features
CPU • Dual Intel® E7-2800/E7-4800*/E7-8800*) series
processors (Socket R1-LGA 2011); each processor
supports dual full-width Intel QuickPath Interconnect
(QPI) links (of up to 8.0 GT/s one direction per QPI)
(*E7-4800/E7-8800 CPU support is veried on some
SKUs only. For the latest CPU support updates, please
refer to our website at http://www.supermicro.com/prod-
ucts/motherboard.)
Memory • Integrated memory controller supports:
Up to 1 TB of Registered (RDIMM) or up to 2 TB of Load
Reduced (LRDIMM) DDR3 ECC 800/1066/1333/1600
MHz 240-pin memory modules in 32 slots (2 DIMMs
per channel).
Note: For the latest memory updates, please
refer to our website at http://www.supermicro.
com/products/motherboard.
DIMM sizes
• DIMM Up to 32GB ( RDIMM @ 1.25V, 1.5V,
LRDIMM @ 1.35V, 1.5V)
Chipset • Intel® PCH C602
Expansion • One (1) SMC-proprietary PCI-E 3.0 x16+x16 slot for
riser card support (Left) (SXB1A/1B/1C)
• One (1) PCI-E 3.0x8 slot to be used with an SMC-
proprietary storage add-on card with support of two
SATA 3.0 and six SATA 2.0 connections (Right)
(SXBP).
Note: The part number for the add-on card to be
used for SXBP is BPN-ADP-8SATA3-1UBL-O-P
or BPN-ADP-SAS3-227HD-N2.
• Micro-LP (Low-Prole) PCI-E 3.0 x8 slot (SXB3)
• Two (2) Solid-State Drive (SSD) slots for Non-Volatile
Memory Express (NVMe) drives w/Windows 8 sup-
port (NVMe8A/NVMe8B)
Note: The part number for the add-on card to be
used with NVMe8A or NVMe8B is BPN-ADP-
8PCIE3-1UBR.
Slots
Graphics • Graphics controller via the Aspeed AST2400 BMC
1-8
X10DBT/X10DBT-T Motherboard User’s Manual
Network • Intel i350 Gigabit (10/100/1000 Mb/s) Ethernet con-
troller for LAN 1/LAN 2 ports (X10DBT only),
• Intel X540 10_Gigabit Ethernet controller for LAN 1/
LAN 2 ports (X10DBT-T only)
• Aspeed 2400 Baseboard Controller (BMC) supports
IPMI_LAN 2.0
I/O Devices SATA Connections
• SATA Ports • Two (2) SATA 3.0 port head-
ers (I-SATA 4/5)
• Two (2) SATA 3.0 and six (6)
SATA 2.0 connections sup-
ported by SMC-proprietary
PCI-E 3.0x8 slot for storage
add-on cards (SXBP)
• RAID RAID 0, 1, 5, 10
IPMI 2.0
• IPMI 2.0 supported by Aspeed AST 2400
Serial (COM) Port
• One (1) Fast UART 16550 port
Peripheral
Devices
USB Devices
• Two (2) USB 2.0 ports on the rear I/O panel (USB 0/1)
• One (1) USB 2.0 Type A for front access support
(USB 2)
BIOS • 128Mb SPI AMI BIOS® SM Flash UEFI BIOS
• APM 1.2, ACPI 3.0/4.0, USB keyboard, Plug & Play
(PnP), BIOS rescue hotkey, riser card auto-detection,
RTC (Real-Time Clock) wake-up, Dual-Boot Block,
and SMBIOS 2.7 & later
Power • ACPI/ACPM power management
• S1, S4, S5 support
Management • Main switch override mechanism
• Power-on mode for AC power recovery
• Intel® Intelligent Power Node Manager 3.0 (Available
when the "Supermicro Power Manager (SPM)" is
installed and special power supply is used.)
• Management Engine (ME)
Chapter 1: Overview
1-9
System
health
System health/CPU Monitoring
Monitoring • Onboard voltage monitoring for +3.3V, 3.3V standby,
+5V, +5V standby, +/-12V, CPU core, memory, chip-
set, HT, and battery voltages
• CPU/System overheat LED and control
• 6 switch-phase voltage regulator
• CPU Thermal Trip support
• Status Monitor for speed control
• Status Monitor for On/Off control
Fan Control
• Fan status monitoring via IPMI connections
• Dual Cooling Zone
• Low noise fan speed control
• Pulse Width Modulation (PWM) fan control
System
Management
• PECI (Platform Environment Conguration Interface)
2.0/TSI support
• UID (Unit Identication)/Remote UID
• System resource alert via SuperDoctor 5
• SuperDoctor® 5, Watch Dog, NMI
• Chassis Intrusion header and detection
Dimensions • 19.33" (L) x 13.68" (W) (490.98 mm x 347.47 mm)
Note: For IPMI Conguration instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.
1-10
X10DBT/X10DBT-T Motherboard User’s Manual
System Block Diagram
Note: This is a general block diagram and may not represent the features
on your motherboard. See the "Motherboard Features" pages for the actual
specications of each motherboard.
1
D
C
B
P0
P0
P1
P1
PCI-E x8 GEN3
CPU1
CPU2
PE0 PE1 DMI
DDR3 DIMM
PCI-32bit
164E/164H
SPI FLASH
A
LPC
DDR3 DIMM
#2
PCIe Gen3 x8 (0-7)
PCIe Gen3 x8 (8-15)
SXB1
PCIe Gen3 x16
SXB4
TPM Header
USB
LAN
I350 /
X540
2 ports
RJ45RJ45
UM56
PCIe Gen3 x16
DMI Gen2 x4
PROCESSOR
PROCESSOR
QPI
U1
U3
U3G1
UMB1
PCIe Gen3 x16
SXB2
SSB
QPI
DMI
VGA BMC
VGA CONN
AST2400
DDR2
PHY1
LAN
RTL8211E
SPI
B
C
D
Left Socket
Right Socket
#1
PCIe Gen3 x16
MicroLP
PCIe Gen3 x8 (0-7)
PCIe Gen3 x8 (8-15)
PCI-E x16 Gen 3
DDR3 DIMM
DDR3 DIMM
#2
#1
DDR3 DIMM
DDR3 DIMM
DDR3 DIMM
#2
#1
DDR3 DIMM
#2 B
A
#1
DDR3 DIMM
DDR3 DIMM
DDR3 DIMM
#2 #1
DDR3 DIMM
#2
DDR3 DIMM
DDR3 DIMM
DDR3 DIMM
#2
#1
DDR3 DIMM
#2 A
B
#1
C
D
#1
PCI-E x16 Gen 3
DDR3 DIMM
#1
DDR3 DIMM
#2
DDR3 DIMM
#1
DDR3 DIMM
#2
DDR3 DIMM
#1
DDR3 DIMM
#2
DDR3 DIMM
#1
DDR3 DIMM
#2
DDR3 DIMM
#1
DDR3 DIMM
#2
DDR3 DIMM
#1
DDR3 DIMM
#2
P1M1CD
DDR3 DIMM
#1
DDR3 DIMM
#2
DDR3 DIMM
#1
DDR3 DIMM
#2
Combine with SATA/SAS interface
PCI-E x8 GEN3
PCI-E x8 GEN3
3/1.5 Gb/s
6 Gb/s for Port 0,1
3/1.5 Gb/s
SATA2 #4 DOM
SATA2 #5 DOM
SATA3 #0
SATA3 #1
SATA2 #3
SATA2 #0
SATA2 #1
SATA2 #3
SATA2 #2
SATA2 #2
USB 2.0
REAR
MicroLP
0,1 4,5
USB Type-A
D
C
A
B
D
C
SMI2
CH1
COM1
CONN
COM1
SXB3
2
NVMe8
SXBP
SCU
SATA
BIOS 16MB
CH0
SMI2 CH3
SMI2
CH2
SMI2
CH3
SMI2
CH2
SMI2
CH0
SMI2
CH1
SMI2
C102
P1M1AB P2M2CD P2M2AB
PE1 PE0 DMI
P1M2AB P1M2CD P2M1AB P2M1CD
Intel C102
Intel C102
Intel C102
Intel
C102
Intel
C102
Intel
C102
Intel
C102
Intel
Chapter 1: Overview
1-11
1-2 Processor and Chipset Overview
Built upon the functionality and capability of the Intel E7-2800 v2 processors
(Socket R1) and the Intel C602 PCH, the X10DBT(-T) motherboard provides
the best solution for High-Performance Computing (HPC) and Cloud-computing
server platforms.
With support of new Intel Microarchitecture 22nm Processing Technology and In-
tel® Silicon View Technology, the X10DBT(-T) dramatically increases performance
for a multitude of server applications.
The PCH C602 chip provides Enterprise SMbus and MCTP support with the fol-
lowing features included:
•DDR3 240-pin memory support on Socket R1
•Integrated Clocking capable of extending to most 2S platforms
•Support for MCTP protocol and ME
•Support of SMBus speeds of up to 1 MHz for BMC connectivity
•GSX capable of GPIO expansion
•Improved I/O capabilities to high-storage-capacity congurations
•Flexible Management Infrastructure focused on Run-Time with support for
MCTP Protocol/End Points, and Management trafc over DMI
•SPI Enhancements
•Intel® Node Manager 3.0 for advanced power monitoring, capping and man-
agement for BMC enhancement
•BMC supports remote management, virtualization, and the security package
for enterprise platforms
1-12
X10DBT/X10DBT-T Motherboard User’s Manual
1-3 Special Features
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will
respond when AC power is lost and then restored to the system. You can choose for
the system to remain powered off (in which case you must press the power switch
to turn it back on), or for it to automatically return to the power-on state. See the
Advanced BIOS Setup section for this setting. The default setting is Last State.
1-4 System health Monitoring
This section describes the features of system health monitoring of the motherboard.
This motherboard has an onboard BaseBoard Management Controller (BMC) chip
that monitors system health. An onboard voltage monitor will scan the following
onboard voltages continuously: +3.3V, 3.3V standby, +5V, +5V standby, +/-12V,
CPU core, memory, chipset, HT, and battery voltages. Once a voltage becomes
unstable, a warning is given, or an error message is sent to the screen. The user
can adjust the voltage thresholds to dene the sensitivity of the voltage monitor.
Fan Status Monitor with Firmware Control
The system health monitoring support provided by the BMC controller can check
the RPM status of a cooling fan. The onboard CPU and chassis fan speeds are
controlled by IPMI Thermal Management.
Environmental Temperature Control
A thermal control sensor monitors the CPU temperature in real time and will turn
on the thermal control fan whenever the CPU temperature exceeds a user-dened
threshold. The overheat circuitry runs independently from the CPU. Once it detects
that the CPU temperature is too high, it will automatically turn on the thermal fan
control to prevent the CPU from overheating. The onboard chassis thermal circuitry
can monitor the overall system temperature and alert the user when the chassis
temperature is too high.
Note: To avoid possible system overheating, please be sure to provide
adequate airow to your system.
System Resource Alert
This feature is available when used with SuperDoctor 5 in the Windows OS
environment or in Linux. SuperDoctor is used to notify the user of certain system
Chapter 1: Overview
1-13
events. For example, you can congure SuperDoctor to provide you with warnings
when the system temperature, CPU temperatures, voltages, and fan speeds go
beyond a predened range.
1-5 ACPI Features
ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-
tion denes a exible and abstract hardware interface that provides a standard
way to integrate power management features throughout a PC system, including
its hardware, operating system and application software. This enables the system
to automatically turn on and off peripherals such as CD-ROMs, network cards, hard
disk drives and printers.
In addition to operating system-directed power management, ACPI also provides
a generic system event mechanism for Plug and Play, and an operating system-
independent interface for conguration control. ACPI leverages the Plug and Play
BIOS data structures, while providing a processor architecture-independent imple-
mentation that is compatible with the latest Windows Operating Systems.
Slow Blinking LED for Suspend-State Indicator
When the CPU goes into a suspend state, the chassis power LED will start blinking
to indicate that the CPU is in suspend mode. When the user presses any key, the
CPU will "wake up" and the LED will automatically stop blinking and remain on.
1-6 Power Supply
As with all computer products, a stable power source is necessary for proper and
reliable operation. It is even more important for processors that have high CPU
clock rates.
The X10DBT(-T) motherboard accommodates Supermicro-proprietary power sup-
ply. For adequate cooling, be sure to use the power supply recommended for this
motherboard by Supermicro.
It is recommended that you also install a power surge protector to help avoid prob-
lems caused by power surges.
1-14
X10DBT/X10DBT-T Motherboard User’s Manual
1-7 Advanced Power Management
The following new advanced power management features are supported by this
motherboard:
Intel® Intelligent Power Node Manager (NM) (Available
when the "Supermicro Power Manager (SPM)" is Installed)
The Intel® Intelligent Power Node Manager 3.0 (IPNM) provides your system with
real-time thermal control and power management for maximum energy efciency.
Although IPNM Specication Version 1.5/2.0 is supported by the BMC (Baseboard
Management Controller), your system must also have IPNM-compatible Manage-
ment Engine (ME) rmware installed to use this feature.
Note: Support for IPNM Specication Version 1.5 or Vision 2.0 depends
on the power supply used in the system.
Management Engine (ME)
Management Engine, an ARC controller embedded in the PCH, provides Server
Platform Services (SPS) support to your system. The services provided by SPS are
different from those provided by the ME on client platforms.
Chapter 2: Installation
2-1
Chapter 2
Installation
2-1 Standardized Warning Statements
The following statements are industry-standard warnings, provided to warn the user
of situations which have the potential for bodily injury. Should you have questions or
experience difculty, contact Supermicro's Technical Support department for assis-
tance. Only certied technicians should attempt to install or congure components.
Read this section in its entirety before installing or conguring components in the
Supermicro chassis.
Battery Handling
Warnung
Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die
Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.
Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.
Warning!
There is a danger of explosion if the battery is replaced incorrectly. Replace the
battery only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions
電池の取り扱い
電池交換が正しく行われなかった場合、破裂の危険性があります。 交換する電池はメー
カーが推奨する型、または同等のものを使用下さい。 使用済電池は製造元の指示に従
って処分して下さい。
警告
电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更
换原有电池。请按制造商的说明处理废旧电池。
警告
電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有
電池。請按照製造商的說明指示處理廢棄舊電池。
2-2
X10DBT/X10DBT-T Motherboard User’s Manual
Attention
Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer
que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Jeter les piles usagées conformément aux instructions du fabricant.
¡Advertencia!
Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Re-
emplazar la batería exclusivamente con el mismo tipo o el equivalente recomen-
dado por el fabricante. Desechar las baterías gastadas según las instrucciones
del fabricante.
!הרהזא
תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי
גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.
תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל
경고!
배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일
하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다. 제조사
의 안내에 따라 사용된 배터리를 처리하여 주십시오.
Waarschuwing
Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de
batterij slechts met hetzelfde of een equivalent type die door de fabrikant aan-
bevolen wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften
afgevoerd te worden.
Chapter 2: Installation
2-3
Product Disposal
Warning!
Ultimate disposal of this product should be handled according to all national laws
and regulations.
製品の廃棄
この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が
ありま す。
警告
本产品的废弃处理应根据所有国家的法律和规章进行。
警告
本產品的廢棄處理應根據所有國家的法律和規章進行。
Warnung
Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen
des Landes erfolgen.
¡Advertencia!
Al deshacerse por completo de este producto debe seguir todas las leyes y regla-
mentos nacionales.
Attention
La mise au rebut ou le recyclage de ce produit sont généralement soumis à des
lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de
l'organisme compétent.
רצומה קוליס
!הרהזא
ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס.הנידמה יקוח
2-4
X10DBT/X10DBT-T Motherboard User’s Manual
2-2 Static-Sensitive Devices
Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam-
aging your system board, it is important to handle it very carefully. The following
measures are generally sufcient to protect your equipment from ESD.
Precautions
•Use a grounded wrist strap designed to prevent static discharge.
•Touch a grounded metal object before removing the board from the antistatic
bag.
•Handle the motherboard by its edges only; do not touch its components, periph-
eral chips, memory modules or gold contacts.
•When handling chips or modules, avoid touching their pins.
•Put the motherboard and peripherals back into their antistatic bags when not
in use.
•For grounding purposes, make sure that your system chassis provides excellent
conductivity between the power supply, the case, the mounting fasteners and
the motherboard.
Unpacking
The motherboard is shipped in antistatic packaging to avoid static damage.
When unpacking the motherboard, make sure that the person handling it is static
protected.
Waarschuwing
De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming
met alle nationale wetten en reglementen.
경고!
이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.
Chapter 2: Installation
2-5
2-3 Processor and Heatsink Installation
Warning: When handling the processor package, avoid placing direct pressure on
the label area.
Notes:
Always connect the power cord last, and always remove it before adding,
removing or changing any hardware components. Make sure that you in-
stall the processor into the CPU socket before you install the CPU heatsink.
If you buy a CPU separately, make sure that you use an Intel-certied
multi-directional heatsink only.
Make sure to install the motherboard into the chassis before you install
the CPU heatsink.
When receiving a motherboard without a processor pre-installed, make
sure that the plastic CPU socket cap is in place and none of the socket
pins are bent; otherwise, contact your retailer immediately.
Refer to the Supermicro website for updates on CPU support.
Press down
on
Load Lever
labeled 'Open 1st'.
Installing the E7-2800/E7-4800*/E7-8800* Series Processor
(*E7-4800/E7-8800 CPU support is veried on some SKUs only. Please refer to our
website for the latest CPU support updates.)
1. There are two load levers on the processor socket. To open the socket cover,
rst press and release the load lever labeled 'Open 1st'.
12
Note: All graphics, drawings and pictures shown in this manual are for il-
lustration only. The components that came with your machine may or may
not look exactly the same as those shown in this manual.
OPEN 1st
OPEN 1st
2-6
X10DBT/X10DBT-T Motherboard User’s Manual
OPEN 1st
Gently push
down to pop the
load plate open.
2. Press the second load lever labeled 'Close 1st' to release the load plate that
covers the CPU socket from its locking position.
3. With the lever labelled 'Close 1st' fully retracted, gently push down on the
lever labelled 'Open 1st' to open the load plate. Lift the load plate to open it
completely.
12
Press down on
Load
Lever 'Close 1st'
Pull lever away from
the socket
2
Note: All graphics, drawings and pictures shown in this manual are for il-
lustration only. The components that came with your machine may or may
not look exactly the same as those shown in this manual.
OPEN 1st
OPEN 1st
1
Chapter 2: Installation
2-7
1. Use your thumb and the index nger to loosen the lever and open the load
plate.
2. Using your thumb and index nger, hold the CPU on its edges. Align the CPU
keys, which are semi-circle cutouts, against the socket keys.
3. Once they are aligned, carefully lower the CPU straight down into the socket.
(Do not drop the CPU on the socket. Do not move the CPU horizontally or
vertically. Do not rub the CPU against the surface or against any pins of the
socket to avoid damaging the CPU or the socket.)
Socket Keys
CPU Keys
Warning: You can only install the CPU
inside the socket in one direction. Make
sure that it is properly inserted into the
CPU socket before closing the load
plate. If it doesn't close properly, do not
force it as it may damage your CPU.
Instead, open the load plate again to
make sure that the CPU is aligned
properly.
2-8
X10DBT/X10DBT-T Motherboard User’s Manual
OPEN 1st
4. With the CPU inside the socket, inspect the four corners of the CPU to make
sure that the CPU is properly installed.
Lever Lock
Lever Lock
Push down and
lock the lever
labelled 'Open
1st'.
Push down and lock the
lever labelled 'Close 1st'.
Gently close
the load plate.
1 2
34
OPEN 1st
OPEN 1st
5. Close the load plate with the CPU inside the socket. Lock the lever labelled
'Close 1st' rst, then lock the lever labelled 'Open 1st' second. Using your
thumb gently push the load levers down to the lever locks.
Chapter 2: Installation
2-9
OPEN 1st
Screw#1
Screw#2
Installing a Passive CPU Heatsink
1. Do not apply any thermal grease to the heatsink or the CPU die -- the re-
quired amount has already been applied.
2. Place the heatsink on top of the CPU so that the four mounting holes are
aligned with those on the Motherboard and the Heatsink Bracket underneath.
3. Screw in two diagonal screws (i.e., the #1 and the #2 screws) until just snug
(-do not over-tighten the screws to avoid possible damage to the CPU.)
4. Finish the installation by fully tightening all four screws.
Mounting Holes
2-10
X10DBT/X10DBT-T Motherboard User’s Manual
Removing the Heatsink
Warning: We do not recommend that the CPU or the heatsink be removed. However,
if you do need to uninstall the heatsink, please follow the instructions below to uninstall
the heatsink to prevent damage done to the CPU or the CPU socket.
1. Unscrew the heatsink screws from the motherboard in the sequence as
shown in the illustration below.
2. Gently wriggle the heatsink to loosen it from the CPU. (Do not use excessive
force when wriggling the heatsink!)
3. Once the CPU is loosened from the socket, remove the CPU from the CPU
socket.
4. Remove the used thermal grease and clean the surface of the CPU and the
heatsink, Reapply the proper amount of thermal grease on the surface before
reinstalling the CPU and the heatsink.
Loosen screws
in sequence as
shown.
Screw#2
Screw#1
Screw#3
Screw#4
Note: All graphics, drawings and pictures shown in this manual are for il-
lustration only. The components that came with your machine may or may
not look exactly the same as those shown in this manual.
Chapter 2: Installation
2-11
CLOSE 1st
OPEN 1st
CLOSE 1st
OPEN 1st
X10DBT-(T)
Rev. 1.01
Release Tabs
Notches
2-4 Installing and Removing the Memory Modules
Note: Check Supermicro's website for recommended memory modules.
CAUTION
Exercise extreme care when installing or removing DIMM
modules to prevent any possible damage.
Installing & Removing DIMMs
1. Insert the desired number of DIMMs into the memory slots, starting with
P1M1-DIMMA1. (For best performance, please use the memory modules of
the same type and speed in the same bank.)
2. Push the release tabs outwards on both ends of the DIMM slot to unlock it.
Removing Memory Modules
Press both notches on the ends of the DIMM module to unlock it. Once the DIMM
module is loosened, remove it from the memory slot.
3. Align the key of the DIMM module with the receptive point on the memory
slot.
4. Align the notches on both ends of the module against the receptive points on
the ends of the slot.
5. Use two thumbs together to press the notches on both ends of the module
straight down into the slot until the module snaps into place.
6. Press the release tabs to the locking positions to secure the DIMM module
into the slot.
Press both notches straight
down into the memory slot at
the same time.
P1M1_C1-D2
P1M1_A1-B2
P1M2_A1-B2
P1M2_C1-D2
P2M2_C1-D2
P2M2_A1-B2 P2M1_C1-D2
P2M1_A1-B2
2-12
X10DBT/X10DBT-T Motherboard User’s Manual
Memory Support for the X10DBT(-T) Motherboard
The X10DBT(-T) Motherboard supports Up to 1 TB of Registered (RDIMM) or up
to 2 TB of Load Reduced (LRDIMM) DDR3 ECC 800/1066/1333/1600 MHz 240-pin
memory modules in 32 slots (2 DIMMs per channel). For the latest memory updates,
please refer to our website a at http://www.supermicro.com/products/motherboard.
Processor & Memory Module Population Conguration
For memory to work properly, follow the tables below for memory installation.
Fully-Populated Conguration
Please follow the instructions below to populate all DIMM slots:
Processors and their Corresponding Memory Modules
CPU# Corresponding DIMM Modules for Full-Populated Conguration
CPU 1 P1M1-
DIMM
A1/B1
P1M1-
DIMM
C1/D1
P1M1-
DIMM
A2/B2
P1M1-
DIMM
C2/D2
P1M2-
DIMM
A1/B1
P1M2
DIMM
C1/D1
P1M2
DIMM
A2/B2
P1M2
DIMM
C2/D2
CPU2 P2M1-
DIMM
A1/B1
P2M1-
DIMM
C1/D1
P2M1-
DIMM
A2/B2
P2M1-
DIMM
C2/D2
P2M2-
DIMM
A1/B1
P2M2
DIMM
C1/D1
P2M2
DIMM
A2/B2
P2M2
DIMM
C2/D2
Half-Populated Conguration
Please follow the instructions below to populate half of the DIMM slots:
Processors and their Corresponding Memory Modules
CPU# Corresponding DIMM Modules for Half-Populated Conguration
CPU 1 P1M1-
DIMM A1/B1
P1M1-
DIMM C1/D1
P1M2-
DIMM A1/B1
P1M2
DIMM C1/D1
CPU2 P2M1-
DIMM A1/B1
P2M1-
DIMM C1/D1
P2M2-
DIMM A1/B1
P2M2
DIMM C1/D1
An Important Note:
•For the memory modules to work properly, please install DIMM modules of the
same type, same speed and same operating frequency in the motherboard.
Mixing of DIMMs of different types or different speeds is not allowed.
Chapter 2: Installation
2-13
Performance Mode (2:1) - DDR3 RDIMM + LRDIMM Configuration
Type
Ranks Per DIMM
and Data Width
(x8 is supported
for RDIMMs but
not listed)
Max DIMM
Capacity (GB)
Max Speed (GHz) ; Voltage (V);
Slot Per Channel (SPC) and DIMM Per Channel (DPC)
2 SPC 3 SPC
SR Single Rank
DR Dual Rank
QR Quad Rank
1DPC 2DPC 1DPC 2DPC 3DPC
2Gb 4Gb 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V
RDIMM SRx4 4GB 8GB 1333 1333 1333 1333 1333 1333 1333 1066 1066 N/A
RDIMM DRx4 8GB 16GB 1333 1333 1333 1333 1333 1333 1333 1066 1066 N/A
RDIMM QRx4 16GB 32GB 1066 1066 1066 1066 1066 1066 N/A N/A N/A N/A
N/A
LRDIMM QRx4 16GB 32GB 1333 1333 1333 1333 1333 1333 1333 1333 1333
N/A
LRDIMM (RM) 8Rx4 32GB 64GB 1066 N/A 1066 N/A 1066 N/A 1066 N/A 1066 N/A
INTEL CONFIDENTIAL
Intel and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Other names and brands may be
claimed as the property of others. All products, dates, and figures are preliminary and are subject to change without any notice. Copyright © 2013, Intel Corporation.
1
RDIMM/LRDIMM DDR3 ECC in Performance Mode (2:1)
RDIMM/LRDIMM DDR3 ECC in Lockstep Mode (1:1)
Lockstep Mode (1:1) - DDR3 RDIMM + LRDIMM Configuration
Type
Ranks Per
DIMM and Data
Width (x8 is
supported for
Max DIMM
Capacity (GB)
Max Speed (MT/s) ; Voltage (V);
Slot Per Channel (SPC) and DIMM Per Channel (DPC)
2 SPC 3 SPC
supported for
RDIMMs but
not listed)
1DPC 2DPC 1DPC 2DPC 3DPC
2Gb 4Gb 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V
RDIMM SRx4 4GB 8GB 1600 1333 1600 1333 1333 1333 1333
1066
1066 N
/
A
1066
/
RDIMM DRx4 8GB 16GB 1600 1333 1600 1333 1333 1333 1333 1066 1066 N/A
RDIMM QRx4 16GB 32GB 1066 1066 1066 1066 1066 1066 N/A N/A N/A N/A
LRDIMM QRx4 16GB 32GB 1600 1333 1600 1333 1600 1333 1600 1333 1333 N/A
LRDIMM (RM) 8Rx4 32GB 64GB 1066 N/A 1066 N/A 1066 N/A 1066 N/A 1066 N/A
INTEL CONFIDENTIAL
Intel and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Other names and brands may be
claimed as the property of others. All products, dates, and figures are preliminary and are subject to change without any notice. Copyright © 2013, Intel Corporation.
1
2-14
X10DBT/X10DBT-T Motherboard User’s Manual
BIOS
LICENSE
BAR CODE
X10DBT-(T)
Rev. 1.02
MEGERAC
LICENSE
2-5 Motherboard Installation
All motherboards have standard mounting holes to t different types of chassis.
Make sure that the locations of all the mounting holes for both motherboard and
chassis match. Although a chassis may have both plastic and metal mounting fas-
teners, metal ones are highly recommended because they ground the motherboard
to the chassis. Make sure that the metal standoffs click in or are screwed in tightly.
Then use a screwdriver to secure the motherboard onto the motherboard tray.
Tools Needed
•Phillips Screwdriver
•Pan head screws (15 pieces)
•Standoffs (15 pieces, if needed)
Location of Mounting Holes
There are fteen (15) mounting holes on this motherboard indicated by the arrows.
Caution: 1) To avoid damaging the motherboard and its components, please do
not use a force greater than 8 lb/inch on each mounting screw during motherboard
installation. 2) Some components are very close to the mounting holes. Please take
precautionary measures to prevent damage to these components when installing the
motherboard to the chassis.
Chapter 2: Installation
2-15
Installing the Motherboard
1. Install the I/O shield into the chassis.
2. Locate the mounting holes on the motherboard.
3. Locate the matching mounting holes on the chassis. Align the mounting holes
on the motherboard against the mounting holes on the chassis.
4. Install standoffs in the chassis as needed.
5. Install the motherboard into the chassis carefully to avoid damaging mother-
board components.
6. Using the Phillips screwdriver, insert a Pan head #6 screw into a mounting
hole on the motherboard and its matching mounting hole on the chassis.
7. Repeat Step 5 to insert #6 screws into all mounting holes.
8. Make sure that the motherboard is securely placed in the chassis.
Note: Images displayed are is for illustration only. Your chassis or compo-
nents might look different from those shown in this manual.
2-16
X10DBT/X10DBT-T Motherboard User’s Manual
BIOS
LICENSE
BAR CODE
X10DBT-(T)
Rev. 1.02
MEGERAC
LICENSE
2-6 Control Panel Connectors and I/O Ports
The I/O ports are color coded in conformance with the industry standards. See
the picture below for the colors and locations of the various I/O ports.
Back Panel Connectors and I/O Ports
Back Panel I/O Port Locations and Denitions
1. Gigabit_LAN 1 (X10DBT), 10G_LAN 1 (X10DBT-T)
2. Gigabit_LAN 2 (X10DBT), 10G_LAN 2 (X10DBT-T)
3. Back Panel USB 2.0 Port 0
4. Back Panel USB 2.0 Port 1
5. IPMI_Dedicated LAN
6. COM1
7. VGA (Blue)
8. UID Switch/UID LED (LED1)
1
2
3
4
5
6
7
8
Chapter 2: Installation
2-17
BIOS
LICENSE
BAR CODE
X10DBT-(T)
Rev. 1.02
MEGERAC
LICENSE
Video Connection
A Video (VGA) port is located next to
COM1 on the I/O backplane. Refer
to the motherboard layout below for
the location.
1. VGA
2. LAN1 (10G-LAN for X10DBT-T, GLAN
for X10DBT)
3. LAN2 (10G-LAN for X10DBT-T, GLAN
for X10DBT)
4. IPMI_LAN (GLAN for X10DBT(-T)
1
2
3
4
Ethernet Ports
Two Ethernet ports (LAN1, LAN2)
are located on the I/O backplane.
These Ethernet ports support 10G
LAN connections on the X10DBT-T,
and Gigabit LAN connections on the
X10DBT. In addition, an IPMI_Dedi-
cated LAN that supports Gigabit LAN
is located above USB 0/1 ports on the
backplane. All Ethernet ports accept
RJ45 type cables. Please refer to the
LED Indicator Section for LAN LED
information.
LAN Ports
Pin Denition
Pin# Denition
1 P2V5SB 10 SGND
2 TD0+ 11 Act LED
3 TD0- 12 P3V3SB
4 TD1+ 13 Link 100 LED
(Yellow, +3V3SB)
5 TD1- 14 Link 1000 LED
(Yellow, +3V3SB)
6 TD2+ 15 Ground
7 TD2- 16 Ground
8 TD3+ 17 Ground
9 TD3- 18 Ground
(NC: No Connection)
2-18
X10DBT/X10DBT-T Motherboard User’s Manual
BIOS
LICENSE
BAR CODE
X10DBT-(T)
Rev. 1.02
MEGERAC
LICENSE
1. Backpanel USB0 (USB2.0)
2. Backpanel USB1 (USB2.0)
3. Type A USB2 (USB 2.0)
4. COM1
Universal Serial Bus (USB)
Two USB2.0 ports (USB 0/1) are located
on the I/O backpanel. In addition, a Type A
USB header, located next to CPU Socket
1, also provides USB 2.0 connection (USB
2) for front panel support. (Cables are not
included). See the tables on the right and
below for pin denitions. Backplane
USB 2 (2.0)
Pin Denitions
Pin# Denition
1 +5V
2 PO-
3 PO+
4 Ground
5 NA
Back Panel USB 0/1 (2.0)
Pin Denitions
Pin# Denition Pin# Denition
1 +5V 5 +5V
2 USB_PN1 6 USB_PN0
3 USB_PP1 7 USB_PP0
4 Ground 8 Ground
1
2
3
4
Serial Port
A COM connection (COM1) is located next
to USB 0/1 on the I/O back panel. This port
provides serial port support. See the table on
the right for pin denitions.
Serial COM) Ports
Pin Denitions
Pin # Denition Pin # Denition
1 DCD 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 Ground 10 N/A
Chapter 2: Installation
2-19
BIOS
LICENSE
BAR CODE
X10DBT-(T)
Rev. 1.02
MEGERAC
LICENSE
Unit Identier Switch/UID LED Indicator
A Unit Identier (UID) switch (SW1) is lo-
cated on the I/O backplane, and a UID LED
indicator (UID_LED1) is located next to the
UID switch on the motherboard. When you
press the UID switch, the UID LED indica-
tors will be turned on. Press the UID switch
again to turn off the LED indicator. The UID
Indicator provide easy identication of a
system unit that may be in need of service.
Note: UID can also be triggered via
IPMI on the motherboard. For more
information on IPMI, please refer to
the IPMI User's Guide posted on
our website @http://www.super-
micro.com.
1. UID Switch
2. Rear UID LED
UID Switch
Pin# Denition
1 Ground
2 Ground
3 Button In
4 Ground
UID LED
Status
Color/State Status
Blue: On Unit Identied
1
1
2
2-20
X10DBT/X10DBT-T Motherboard User’s Manual
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
2-7 Connecting Cables
A. Power Output (JPW1_
A
Power Output Connector
This motherboard supports SMCI- \proprietary power supply. A 4-pin +12V power
output connector located at JPW1 on the motherboard. Be sure to use the power
supply recommended for this motherboard for adequate power supply to your sys-
tem. See the layout below for the power output connector location.
Chapter 2: Installation
2-21
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
C
A. Fan 5
B. Fan 6
C. IPMB
Fan Headers
This motherboard has two system/CPU fan head-
ers (Fan 5/Fan 6) on the motherboard. These
4-pin fan headers are backward compatible with
the traditional 3-pin fans. However, fan speed
control is available for 4-pin fans only. The fan
speeds are controlled by Thermal Management
via IPMI 2.0 interface. See the table on the right
for pin denitions.
Fan Header
Pin Denitions
Pin# Denition
1 Ground
2 +12V
3 Tachometer
4 PWR Modulation
A
B
IPMB
A System Management Bus header for IPMI 2.0
is located at JIPMB1. Connect the appropriate
cable here to use the IPMB I2C connection on
your system.
IPMB Header
Pin Denitions
Pin# Denition
1 Data
2 Ground
3 Clock
4 No Connection
2-22
X10DBT/X10DBT-T Motherboard User’s Manual
B
A
A. TPM/80 Port
B. JSD1
C. JSD2
TPM/Port 80 Header
A Trusted Platform Module/Port 80
header, located at JTPM1, provides
TPM support and Port 80 connection.
Use this header to enhance system
performance and data security. See
the table on the right for pin denitions.
TPM/Port 80 Header
Pin Denitions
Pin # Denition Pin # Denition
1 LCLK 2 GND
3 LFRAME# 4 <(KEY)>
5 LRESET# 6 +5V (X)
7 LAD 3 8 LAD 2
9 +3.3V 10 LAD1
11 LAD0 12 GND
13 SMB_CLK4 14 SMB_DAT4
15 +3V_DUAL 16 SERIRQ
17 GND 18 CLKRUN# (X)
19 LPCPD# 20 LDRQ# (X)
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
A
SATA DOM Power Connectors
Two power connectors for SATA DOM
(Disk_On_Module) devices are located
at JSD1/JSD2. Connect appropriate
cables here to provide power support
for your Serial Link DOM devices.
DOM PWR
Pin Denitions
Pin# Denition
1 +5V
2 Ground
3 Ground
B
C
Chapter 2: Installation
2-23
2-8 Jumper Settings
Explanation of Jumpers
To modify the operation of the mother-
board, jumpers can be used to choose
between optional settings. Jumpers create
shorts between two pins to change the
function of the connector. Pin 1 is identied
with a square solder pad on the printed
circuit board. See the motherboard layout
pages for jumper locations.
Note: On two pin jumpers,
"Closed" means the jumper is
on and "Open" means the jumper
is off the pins.
Connector
Pins
Jumper
Cap
Setting
Pin 1-2 short
3 2 1
3 2 1
LAN Enable/Disable
JPL1 enables or disables Gigabit_LAN
ports 1/2 on the X10DBT, and 10G_LAN
ports 1/2 on the X10DBT-T. See the table
on the right for jumper settings. The de-
fault setting is Enabled.
LAN Enable
Jumper Settings
Jumper Setting Denition
1-2 Enabled (default)
2-3 Disabled
A
A. GLAN1/2 Enable
(X10DBT)
A. 10G_LAN1/2 En-
able (X10DBT-T)
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
2-24
X10DBT/X10DBT-T Motherboard User’s Manual
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
CMOS Clear
JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads
to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such
as a small screwdriver to touch both pads at the same time to short the connection.
Note 1. For an ATX power supply, you must completely shut down the
system, and then short JBT1 to clear CMOS.
Note 2. Clearing CMOS will also clear all passwords.
A
B
A. Clear CMOS
B. Watch Dog Enable
Watch Dog Enable/Disable
Watch Dog (JWD1) is a system monitor that
will reboot the system when a software ap-
plication hangs. Close pins 1-2 to reset the
system if an application hangs. Close pins
2-3 to generate a non-maskable interrupt
signal for the application that hangs. See the
table on the right for jumper settings. Watch
Dog must also be enabled in the BIOS.
Watch Dog
Jumper Settings
Jumper Setting Denition
Pins 1-2 Reset (default)
Pins 2-3 NMI
Open Disabled
Chapter 2: Installation
2-25
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
A. VGA Enabled
B. BMC Enabled
A
B
VGA Enable
Jumper JPG1 allows the user to enable
the onboard VGA connector. The default
setting is on pins 1-2 to enable the con-
nection. See the table on the right for
jumper settings.
VGA Enable
Jumper Settings
Jumper Setting Denition
1-2 Enabled (Default)
2-3 Disabled
BMC Enable
Jumper JPB1 is used to enable or
disable the embedded AST2400 BMC
(Baseboard Management Controller)
that provides IPMI 2.0/KVM support on
the motherboard. See the table on the
right for jumper settings.
BMC Enable
Jumper Settings
Jumper Setting Denition
Pins 1-2 BMC Enable (Default)
Pins 2-3 Disabled
2-26
X10DBT/X10DBT-T Motherboard User’s Manual
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
I2C Bus to PCI-Exp. Slots
Use Jumpers JI2C1 and JI2C2 to connect
the System Management Bus (I2C) to
PCI-Express slots to improve PCI per-
formance. These two jumpers are to be
set at the same time. The default setting
is on pins 1-2 to disable the connection
for normal operations. See the table on
the right for jumper settings.
I2C for PCI-E slots
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 Enabled
A
A. JI2C1
B. JI2C2
B
Chapter 2: Installation
2-27
Manufacturer Mode Select
Close pin 2 and pin 3 of Jumper JPME2
to bypass SPI ash security and force the
system to operate in the Manufacturer
mode, which will allow the user to ash
the system rmware from a host server
for system setting modications. See the
table on the right for jumper settings.
ME Mode Select
Jumper Settings
Jumper Setting Denition
1-2 Normal (Default)
2-3 Manufacture Mode
ME Recovery
JPME1 is used for ME Firmware Re-
covery mode, which will limit system
resource for essential function use only
without putting restrictions on power
use. In the single operation mode, online
upgrade will be available via Recovery
mode. See the table on the right for pin
denitions.
ME Recovery
Jumper Settings
Jumper Setting Denition
Open Normal (Default)
Closed ME Recovery
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
A
A. JPME1
B. JPME2
B
2-28
X10DBT/X10DBT-T Motherboard User’s Manual
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
LAN Link Indicator
LED Settings
LED Color Denition
Off No Connection, 10 or 100 Mbps
Green 10 Gbps (X10DBT-T Only)
Amber 1 Gbps
2-9 Onboard LED Indicators
A. LAN1/2 LEDs
B. IPMI LAN LEDs
IPMI Dedicated LAN LEDs
In addition to LAN 1/LAN 2, an IPMI- dedi-
cated LAN is located on the I/O Backplane
of the motherboard. The amber LED on
the right indicates activity, while the green
LED on the left indicates the speed of the
connection. See the tables at right for more
information.
LAN 1/LAN 2
IPMI LAN
(X8ST3-F)
Link LED Activity LED
IPMI LAN
IPMI LAN Link LED (Left) &
Activity LED (Right)
Color/State Denition
Link (Left) Green: Solid 100 Mbps
Activity (Right) Amber: Blinking Active
A
B
A
B
LAN LEDs
The LAN ports are located on the IO Back-
plane on the motherboard. Each Ethernet
LAN port has two LEDs. The yellow LED in-
dicates activity. Link LED, located on the left
side of the LAN port, may be green, amber
or off indicating the speed of the connection.
See the tables at right for more information.
Activity LED
Link LED
GLAN Activity Indicator (Left)
LED Settings
Color Status Denition
Yellow Flashing Active
Rear View (when facing the
rear side of the chassis)
LAN 1/2
Chapter 2: Installation
2-29
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
Note: Refer to Page 2-19 for information on the UID LED (UID_LED1).
Onboard Power LED
An Onboard Power LED is located at LE1
on the motherboard. When this LED is on,
the system is on. Be sure to turn off the
system and unplug the power cord before
removing or installing components. See
the tables at right for more information.
Onboard PWR LED Indicator
LED States
LED Color Denition
Off System Off (PWR cable
not connected)
Green System On
Green:
Flashing
Quickly
ACPI S1 State
A. PWR LED
B. BMC LED
BMC Heartbeat LED
A BMC Heartbeat LED is located at LE3
on the motherboard. When LE3 is blink-
ing, BMC functions normally. See the
table at right for more information.
BMC Heartbeat LED
States
Color/State Denition
Green:
Blinking
BMC: Normal
A
B
2-30
X10DBT/X10DBT-T Motherboard User’s Manual
JPW1
SAN MAC
MEGERAC
LICENSE
BIOS
LICENSE
IPMI CODE MAC CODE
BAR CODE
JTPM1
SW1
JP2
JP4
JI2C2
1
JI2C1
JP1 JWD1
JPL1
JPME2 JPME1
JP5
JPG1
JPB1
FAN5
FAN6
BT2
UID_LED1
JBT1
LE3
LE1
JSD1
JSD2
JIPMB1
I-SATA5
I-SATA4
OUTPUT
PWR
NVMe8B
LAN1
IPMI_LAN
USB2
+12V PWR
VGA COM1
SXBP
NVMe8A
Micro-LP PCIE 3.0x8
SXB1C
SXB1B
SXB1A
P2M1-DIMMA2
P1M2-DIMMD1
USB0/1 LAN2
CLOSE 1st
OPEN 1st
CPU2
CLOSE 1st
OPEN 1st
CPU1
X10DBT-(T)
Rev. 1.02
PCH
LAN CTRL
BMC
JC1
JC1
JC1 JC1
JC1
JC1
JC1
JC1
P1M2-DIMMD2
P1M2-DIMMC1
P1M2-DIMMC2
P2M1-DIMMA1
P2M1-DIMMB2
P2M1-DIMMB1
P1M2-DIMMB1
P1M2-DIMMB2
P1M2-DIMMA1
P1M2-DIMMA2
P1M1-DIMMD2
P1M1-DIMMD1
P1M1-DIMMC2
P1M1-DIMMC1
P1M1-DIMMA1
P1M1-DIMMA2
P1M1-DIMMB1
P1M1-DIMMB2
P2M2-DIMMD2
P2M2-DIMMD1
P2M2-DIMMC2
P2M2-DIMMC1
P2M2-DIMMA1
P2M2-DIMMA2
P2M2-DIMMB1
P2M2-DIMMB2
P2M1-DIMMD2
P2M1-DIMMD1
P2M1-DIMMC2
P2M1-DIMMC1
SXB3
A. I-SATA4
A. I-SATA5
C. SXB2 (SXBP) Slot (for
storage add-on card with
support of two SATA 3.0 &
six SATA 2.0 connections)
SATA 2.0/3.0 Ports
Ten SATA 2.0/3.0 connections supported by Intel
PCH 602 are located on the motherboard. Two
SATA 3.0 ports are located at I-SATA 4/5. Two
SATA 3.0 connections and six SATA 2.0 connec-
tions are supported by SXB2 (SXBP), which is an
SMC-proprietary PCI-E 3.0x8 slot for a storage
add-on card with SATA support (Right). These
SATA ports provide serial-link signal connections,
which are faster than the connections of Parallel
ATA. See the table on the right for pin denitions.
C
2-10 SATA Connections
B
A
Note: For more information on SATA HostRAID conguration, please refer
to the Intel SATA HostRAID User's Guide posted on our website @ http://
www.supermicro.com..
SATA 3.0 (I-SATA 4/5)
Pin Denitions
Pin# Signal
1 Ground
2 SATA_TXP
3 SATA_TXN
4 Ground
5 SATA_RXN
6 SATA_RXP
7 Ground
ME Power State Select
Use Jumper JPME3 to select ME Power
State to maximize system performance
and power efciency. The default set-
ting is to close pins 1/2 to use Power
Standby Mode. See the table on the right
for jumper settings.
3-1
Chapter 3: Troubleshooting
Chapter 3
Troubleshooting
3-1 Troubleshooting Procedures
Use the following procedures to troubleshoot your system. If you have followed all
of the procedures below and still need assistance, refer to the "Technical Support
Procedures" and/or "Returning Merchandise for Service" section(s) in this chapter.
Note: Always disconnect the power cord before adding, changing or install-
ing any hardware components.
Before Power On
1. Make sure that there are no short circuits between the motherboard and
chassis.
2. Disconnect all ribbon/wire cables from the motherboard, including those for
the keyboard and mouse.
3. Remove all add-on cards.
4. Install CPU 1 rst (making sure it is fully seated) and connect the front panel
connectors to the motherboard.
No Power
1. Make sure that no short circuits between the motherboard and the chassis.
2. Make sure that the ATX power connectors are properly connected.
3. Check that the 115V/230V switch on the power supply is properly set, if avail-
able.
4. Turn the power switch on and off to test the system, if applicable.
5. The battery on your motherboard may be old. Check to verify that it still sup-
plies ~3VDC. If it does not, replace it with a new one.
3-2
X10DBT/X10DBT-T Motherboard User’s Manual
No Video
1. If the power is on, but you have no video, remove all the add-on cards and
cables.
2. Use the speaker to determine if any beep codes exist. Refer to Appendix A
for details on beep codes.
System Boot Failure
If the system does not display POST or does not respond after the power is turned
on, check the following:
1. Check for any error beep from the motherboard speaker.
•If there is no error beep, try to turn on the system without DIMM modules in-
stalled. If there is still no error beep, try to turn on the system again with only
one processor installed in CPU Socket#1. If there is still no error beep, replace
the motherboard.
•If there are error beeps, clear the CMOS settings by unplugging the power
cord and contracting both pads on the CMOS Clear Jumper (JBT1). (Refer to
Section 2-8 in Chapter 2.)
2. Remove all components from the motherboard, especially the DIMM modules.
Make sure that system power is on, and memory error beeps are activated.
3. Turn on the system with only one DIMM module installed. If the system
boots, check for bad DIMM modules or slots by following the Memory Errors
Troubleshooting procedure in this Chapter.
Losing the System’s Setup Conguration
1. Make sure that you are using a high quality power supply. A poor quality
power supply may cause the system to lose the CMOS setup information.
Refer to Section 1-7 for details on recommended power supplies.
2. The battery on your motherboard may be old. Check to verify that it still sup-
plies ~3VDC. If it does not, replace it with a new one.
3. If the above steps do not x the Setup Conguration problem, contact your
vendor for repairs.
3-3
Chapter 3: Troubleshooting
Memory Errors
When a No-Memory Beep Code is issued by the system, check the following:
1. Make sure that the memory modules are compatible with the system and that
the DIMM modules are properly and fully installed. (For memory compatibility,
refer to the Memory Compatibility Chart posted on our website @ http://www.
supermicro.com.)
2. Check if different speeds of DIMMs have been installed. It is strongly recom-
mended that you use the same RAM type and speed for all DIMMs in the
system.
3. Make sure that you are using the correct type of Registered (RDIMM)//Load
Reduced (LRDIMM) DDR3 ECC modules recommended by the manufacturer.
4. Check for bad DIMM modules or slots by swapping a single module among
all memory slots and check the results.
5. Make sure that all memory modules are fully seated in their slots. Follow the
instructions given in Section 2-4 in Chapter 2.
6. Please follow the instructions given in the DIMM Population Tables listed in
Section 2-4 to install your memory modules.
When the System Becomes Unstable
A. When the system becomes unstable during or after OS installation, check
the following:
1. CPU/BIOS support: Make sure that your CPU is supported, and you have the
latest BIOS installed in your system.
2. Memory support: Make sure that the memory modules are supported by test-
ing the modules using memtest86 or a similar utility.
Note: Refer to the product page on our website http:\\www.supermicro.
com for memory and CPU support and updates.
3. HDD support: Make sure that all hard disk drives (HDDs) work properly. Re-
place the bad HDDs with good ones.
4. System cooling: Check system cooling to make sure that all heatsink fans,
and CPU/system fans, etc., work properly. Check Hardware Monitoring set-
tings in the BIOS to make sure that the CPU and System temperatures are
3-4
X10DBT/X10DBT-T Motherboard User’s Manual
within the normal range. Also check the front panel Overheat LED, and make
sure that the Overheat LED is not on.
5. Adequate power supply: Make sure that the power supply provides adequate
power to the system. Make sure that all power connectors are connected.
Please refer to our website for more information on minimum power require-
ment.
6. Proper software support: Make sure that the correct drivers are used.
B. When the system becomes unstable before or during OS installation, check
the following:
1. Source of installation: Make sure that the devices used for installation are
working properly, including boot devices such as CD/DVD disc, CD/DVD-
ROM.
2. Cable connection: Check to make sure that all cables are connected and
working properly.
3. Using minimum conguration for troubleshooting: Remove all unnecessary
components (starting with add-on cards rst), and use minimum conguration
(with a CPU and a memory module installed) to identify the trouble areas.
Refer to the steps listed in Section A above for proper troubleshooting proce-
dures.
4. Identifying bad components by isolating them: If necessary, remove a compo-
nent in question from the chassis, and test it in isolation to make sure that it
works properly. Replace a bad component with a good one.
5. Check and change one component at a time instead of changing several
items at the same time. This will help isolate and identify the problem.
6. To nd out if a component is good, swap this component with a new one to
see if the system will work properly. If so, then the old component is bad.
You can also install the component in question in another system. If the new
system works, the component is good and the old system has problems.
3-2 Technical Support Procedures
Before contacting Technical Support, please take the following steps. Also, please
note that as a motherboard manufacturer, Supermicro also sells motherboards
through its channels, so it is best to rst check with your distributor or reseller for
3-5
Chapter 3: Troubleshooting
troubleshooting services. They should know of any possible problem(s) with the
specic system conguration that was sold to you.
1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked
Question' (FAQ) sections in this chapter or see the FAQs on our website
(http://www.supermicro.com/) before contacting Technical Support.
2. BIOS upgrades can be downloaded from our website (http://www.supermicro.
com).
3. If you still cannot resolve the problem, include the following information when
contacting Supermicro for technical support:
•Motherboard model and PCB revision number
•BIOS release date/version (This can be seen on the initial display when your
system rst boots up.)
•System conguration
4. An example of a Technical Support form is on our website at (http://www.
supermicro.com).
•Distributors: For immediate assistance, please have your account number ready
when placing a call to our technical support department. We can be reached by
e-mail at support@supermicro.com.
3-6
X10DBT/X10DBT-T Motherboard User’s Manual
Proper Battery Disposal
Warning! Please handle used batteries carefully. Do not damage the battery in any
way; a damaged battery may release hazardous materials into the environment. Do
not discard a used battery in the garbage or a public landll. Please comply with the
regulations set up by your local hazardous waste management agency to dispose of
your used battery properly.
3-3 Battery Removal and Installation
Battery Removal
To remove the onboard battery, follow the steps below:
1. Power off your system and unplug your power cable.
2. Locate the onboard battery as shown below.
3. Using a tool such as a pen or a small screwdriver, push the battery lock out-
wards to unlock it. Once unlocked, the battery will pop out from the holder.
4. Remove the battery.
OR
3-7
Chapter 3: Troubleshooting
3-4 Frequently Asked Questions
Question: What are the various types of memory that my motherboard can
support?
Answer: The motherboard supports Registered (RDIMM)//Load Reduced (LRDIMM)
ECC DDR3 of up to 1600 MHz DIMM modules. To enhance memory performance,
do not mix memory modules of different speeds and sizes. Please follow all memory
installation instructions given on Section 2-4 in Chapter 2.
Question: How do I update my BIOS?
It is recommended that you do not upgrade your BIOS if you are not experiencing
any problems with your system. Updated BIOS les are located on our website
at http://www.supermicro.com. Please check our BIOS warning message and the
information on how to update your BIOS on our website. Select your motherboard
model and download the BIOS le to your computer. Also, check the current BIOS
revision to make sure that it is newer than your BIOS before downloading. You can
choose from the zip le and the .exe le. If you choose the zip BIOS le, please
unzip the BIOS le onto a bootable USB device. Run the batch le using the format
AMI.bat lename.rom from your bootable USB device to ash the BIOS. Then, your
system will automatically reboot.
Warning: Do not shut down or reset the system while updating the BIOS to prevent
possible system boot failure!)
Note: The SPI BIOS chip used on this motherboard cannot be removed.
Send your motherboard back to our RMA Department at Supermicro for
repair. For BIOS Recovery instructions, please refer to the AMI BIOS
Recovery Instructions posted at http://www.supermicro.com.
Question: How do I handle the used battery?
Answer: Please handle used batteries carefully. Do not damage the battery in any
way; a damaged battery may release hazardous materials into the environment.
Do not discard a used battery in the garbage or a public landll. Please comply
with the regulations set up by your local hazardous waste management agency to
dispose of your used battery properly.
3-8
X10DBT/X10DBT-T Motherboard User’s Manual
3-5 Returning Merchandise for Service
A receipt or copy of your invoice marked with the date of purchase is required before
any warranty service will be rendered. You can obtain service by calling your ven-
dor for a Returned Merchandise Authorization (RMA) number. When returning the
motherboard to the manufacturer, the RMA number should be prominently displayed
on the outside of the shipping carton, and the shipping package is mailed prepaid
or hand-carried. Shipping and handling charges will be applied for all orders that
must be mailed when service is complete. For faster service, You can also request
a RMA authorization online (http://www.supermicro.com).
This warranty only covers normal consumer use and does not cover damages in-
curred in shipping or from failure due to the alternation, misuse, abuse or improper
maintenance of products.
During the warranty period, contact your distributor rst for any product problems.
Chapter 4: AMI BIOS
4-1
Chapter 4
BIOS
4-1 Introduction
This chapter describes the AMI BIOS setup utility for the X10DBT/X10DBT-T. It also
provides the instructions on how to navigate the AMI BIOS setup utility screens.
The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated.
Starting BIOS Setup Utility
To enter the AMI BIOS setup utility screens, press the <Del> key while the system
is booting up.
Note: In most cases, the <Del> key is used to invoke the AMI BIOS setup
screen. There are a few cases when other keys are used, such as <F3>,
<F4>, etc.
Each main BIOS menu option is described in this manual. The Main BIOS setup
menu screen has two main frames. The left frame displays all the options that can
be congured. Grayed-out options cannot be congured. Options in blue can be
congured by the user. The right frame displays the key legend. Above the key
legend is an area reserved for informational text. When an option is selected in
the left frame, it is highlighted in white. Often informational text will accompany it.
Note: The AMI BIOS has default informational messages built in. The
manufacturer retains the option to include, omit, or change any of these
informational messages.
The AMI BIOS setup utility uses a key-based navigation system called "hot keys."
Most of the AMI BIOS setup utility "hot keys" can be used at any time during setup
navigation. These keys include <F3>, <F4>, <Enter>, <ESC>, arrow keys, etc.
Note 1: Options printed in Bold are default settings.
Note 2: <F3> is used to load optimal default settings. <F4> is used to save
the settings and exit the setup utility.
4-2
X10DBT/X10DBT-T User’s Manual
How To Change the Conguration Data
The conguration data that determines the system parameters may be changed by
entering the AMI BIOS setup utility. This setup utility can be accessed by pressing
<Delete> at the appropriate time during system boot.
Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Recov-
ery User Guide posted @ http://www.supermicro.com/support/manuals/.
Starting the Setup Utility
Normally, the only visible Power-On Self-Test (POST) routine is the memory test.
As the memory is being tested, press the <Delete> key to enter the main menu of
the AMI BIOS setup utility. From the main menu, you can access the other setup
screens. An AMI BIOS identication string is displayed at the left bottom corner of
the screen below the copyright message.
Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue.
Flashing the wrong BIOS can cause irreparable damage to the system. In no event
shall the manufacturer be liable for direct, indirect, special, incidental, or consequential
damage arising from a BIOS update. If you have to update the BIOS, do not shut down
or reset the system while the BIOS is being updated to avoid possible boot failure.
4-2 Main Setup
When you rst enter the AMI BIOS setup utility, you will enter the Main setup screen.
You can always return to the Main setup screen by selecting the Main tab on the
top of the screen. The Main BIOS Setup screen is shown below.
Chapter 4: AMI BIOS
4-3
The AMI BIOS Main menu displays the following information:
System Date/System Time
Use this option to change the system date and time using the arrow keys. Enter
new values through the keyboard and press <Enter>. Press the <Tab> key to move
between elds. The date must be entered in Day MM/DD/YYYY format. The time is
entered in HH:MM:SS format. (Note: The time is in the 24-hour format. For example,
5:30 P.M. appears as 17:30:00.).
Supermicro X10DBT
Version
This item displays the SMC version of the BIOS ROM used in this system.
Build Date
This item displays the date that the BIOS setup utility was built.
Memory Information
Total Memory
This item displays the amount of memory that is available in the system.
4-4
X10DBT/X10DBT-T User’s Manual
4-3 Advanced Setup Congurations
Select the Advanced tab to access the following submenu items.
Boot Features
Boot Conguration
Quiet Boot
Use this item to select bootup screen display between POST messages and the
OEM logo. Select Disabled to display the POST messages. Select Enabled to
display the OEM logo instead of the normal POST messages. The options are
Enabled and Disabled.
CSM (Compatibility Support Module) Support
Select Enabled to enable CSM booting support to boot an UEFI-compatible device
from a legacy BIOS-based system. The options are Enabled and Disabled.
AddOn ROM Display Mode
Use this item to set the display mode for the Option ROM. Select Keep Current
to use the current AddOn ROM Display setting. Select Force BIOS to use the Op-
tion ROM display set by the system BIOS. The options are Force BIOS and Keep
Current.
Bootup Num-Lock
Use this item to set the power-on state for the Numlock key. The options are Off
and On.
Chapter 4: AMI BIOS
4-5
Wait For 'F1' If Error
Select Enabled to force the system to wait until the 'F1' key is pressed when an
error occurs. The options are Disabled and Enabled.
Interrupt 19 Capture
Interrupt 19 is the software interrupt that handles the boot disk function. When
this item is set to Immediate, the BIOS ROM of the host adaptors will immediately
capture Interrupt 19 at bootup and allow the drives that are attached to these host
adaptors to function as bootable disks. If this item is set to Postponed, the BIOS
ROM of the host adaptors will only capture Interrupt 19 during bootup from a legacy
device. The options are Immediate and Postponed.
Re-try Boot
Select Legacy Boot for the BIOS to continuously attempt to boot from the legacy
boot drive. Select EFI Boot for the BIOS to continuously attempt to boot from the
EFI boot drive. The options are Disabled, Legacy Boot, and EFI Boot.
Power Conguration
Watch Dog Function
If enabled, the Watch Dog timer will allow the system to automatically reboot when
a non-recoverable error that lasts for more than ve minutes occurs. The options
are Enabled and Disabled.
Power Button Function
If this feature is set to Instant Off, the system will power off immediately as soon
as the user presses the power button. If this feature is set to 4 Seconds Override,
the system will power off when the user presses the power button for 4 seconds or
longer. The options are Instant Off and 4 Seconds Override.
Restore on AC Power Loss
Use this item to set the power state after a power outage. Select Stay Off for the
system power to remain off after a power outage. Select Power On to turn on the
system power after a power outage. Select Last State to allow the system to resume
its last power state before a power outage. The options are Power On, Stay Off,
and Last State.
CPU Conguration
This submenu displays the following CPU information as detected by the BIOS. It
also allows the user to congure CPU settings.
4-6
X10DBT/X10DBT-T User’s Manual
Processor 0/Processor 1
This submenu displays the following information of the CPU installed a CPU socket
detected by the BIOS.
•Processor Socket
•Processor ID
•Processor Frequency
•Microcode Revision
•L1 Cache RAM
•L2 Cache RAM
•L3 Cache RAM
•Processor 0 Version
•Processor 1 Version
Clock Spread Spectrum
Select Enable to allow the BIOS to monitor and attempt to reduce the level of
Electromagnetic Interference caused by the components whenever needed. The
options are Disable and Enable.
Hyper-Threading [All]
Select Enable to support Intel's Hyper-threading Technology to enhance CPU per-
formance. The options are Enable and Disable.
Performance/Watt
Select Power Optimized to enable Intel® Turbo Boost Technology support when
the Power Performance State-P0 has lasted more than two seconds. The options
are Traditional and Power Optimized.
Clear MCA (Available if supported by the OS & the CPU)
Select Yes to enable Machine-Check Architecture (MCA) support for CPU error
logging. This feature is used in conjunction with the items below: "Execute Disable
Bit," "VMS," "Enable SMX," and "Lock Chipset" for Virtualization media support.
The default setting is No.
Chapter 4: AMI BIOS
4-7
Execute-Disable Bit (Available if supported by the OS & the CPU)
Select Enable to support Intel® Execute Disable Bit Technology, which will allow the
processor to designate areas in the system memory where an application code can
be executed and where it cannot, thus preventing a worm or a virus from ooding
illegal codes to overwhelm the processor or damage the system during an attack.
This feature is used in conjunction with the items: "Clear MCA," "VMX," "Enable
SMX," and "Lock Chipset" for Virtualization media support. The default setting is
Enable. (Refer to Intel and Microsoft websites for more information.)
Intel TXT (Trusted Execution Technology) Support
Select Enable to support Intel Trusted Execution Technology to verify the authenticity
of a platform and its operating system (OS). This feature is used in conjunction with
the items below: "Clear MCA," "Enable SMX," and "Lock Chipset" for Virtualization
media support. The options are Enable and Disable.
VMX
Select Enable to support CPU-related Virtualization. This feature is used in conjunc-
tion with the items: "Clear MCA," "Enable SMX," and "Lock Chipset" for Virtualization
media support. The options are Enable and Disable.
Enable SMX
Select Enable to support Safer Mode Extensions (SMX) which will enhance data
security in the processor. This feature is used in conjunction with the items: "Clear
MCA," "VMX," and "Lock Chipset" for Virtualization media support. The options are
Enable and Disable.
Lock Chipset
Select Enable to lock chipset register tables and set the register tables to "read-only"
to prevent new data being written into the processor to ensure system security. This
feature is used in conjunction with the items: "Clear MCA," "VMX," and "Enable
SMX" for Virtualization media support. The options are Enable and Disable.
BIST Selection
Select Enable to congure Built-In_Self_Test (BIST) settings, which will allow the
system to perform BIST testing on the processors at bootup. The options are En-
able and Disable.
Hardware Prefetcher (Available when supported by the CPU)
If this item is set to Enable, the hardware prefetcher will prefetch streams of data and
instructions from the main memory to the L2 cache to improve CPU performance.
The options are Disable and Enable.
4-8
X10DBT/X10DBT-T User’s Manual
Adjacent Cache Prefetch (Available when supported by the CPU)
Select Enable for the CPU to prefetch both cache lines for 128 bytes as comprised.
Select Disable for the CPU to prefetch both cache lines for 64 bytes. The options
are Disable and Enable.
Note: Please reboot the system for changes on this setting to take effect.
Please refer to Intel’s web site for detailed information.
DCU (Data Cache Unit) Streamer Prefetcher (Available when supported by
the CPU)
If this item is set to Enable, the DCU Streamer Prefetcher will prefetch data streams
from the cache memory to the DCU (Data Cache Unit) to speed up data access-
ing and processing for CPU performance enhancement. The options are Disable
and Enable.
DCU IP Prefetcher
If this feature is set to Enable, the IP prefetcher in the DCU (Data Cache Unit) will
prefetch IP addresses to improve network connectivity and system performance.
The options are Enable and Disable.
DCU Mode
Use this feature to set the data-prefecting mode for the DCU (Data Cache Unit).
The options are 32KB 8Way Without ECC and 16KB 4Way With ECC.
Direct Cache Access (DCA)
Select Enable to use Intel DCA (Direct Cache Access) Technology to improve the
efciency of data transferring and accessing. The options are Enable and Disable.
DCA Prefetch Delay
A DCA Prefetcher is used with a TOE (TCP/IP Ofoad Engine) adapter to prefetch
data in order to shorten execution cycles and maximize data processing efciency.
Prefetching data too frequently can saturate the cache directory and delay neces-
sary cache access. This feature reduces or increases the frequency the system
prefetches data. The options are [8], [16], [32], [40], [48], [56], [64], [72], [80], [88],
[96], [104], [112], [120].
Extended APIC (Advanced Programmable Interrupt Controller)
Based on Intel's Hyper-Threading architecture, each logical processor (thread) is
assigned 256 APIC IDs (APIDs) in 8-bit bandwidth. When this feature is set to En-
able, the APIC ID will be expanded from 8 bits to 16 bits to provide 512 APIDs to
each thread to enhance CPU performance. The options are Disable and Enable.
Chapter 4: AMI BIOS
4-9
AES-NI (New Encryption Standard-New Instructions)
Select Enable to use the Intel Advanced Encryption Standard (AES) New Instruc-
tions (NI) to ensure data security. The options are Enable and Disable.
Down Stream PECI (Platform Environment Control Interface)
Select Enable to allow the client server to interact with the host server directly to
achieve better host-client communication in the PECI platform, which will result
in power saving and energy use efciency. The options are Disable and Enable.
SMM Save State (System Management Mode)
Select Enable for SMM (System Management Mode) Save state support which is
used for advanced power management and other operating-system-independent
functions. The options are Enable and Disable.
Cbox Pipe Serial Mode
Cbox is the caching agent that works as the external cache and system interface
unit within the Intel 7500 (or newer) series processors. Select Pipe Serial Mode
Enable to connect various serial ports used by different host/client virtual machines
together (pipe) for processor-interconnect and system-interface communications.
The options are Pipe Serial Mode Enable and Pipe Serial Mode Disable.
Advanced Power Management Conguration
Advanced Power Management Conguration
Power Technology
Select Energy Efcient to support power-saving mode, which might have an
impact on system performance. Select Custom to customize system power set-
tings. Select Max Performance to optimize system performance, which might
increase power consumption. Select Disabled to disable power-saving settings.
The options are Disabled, Energy Efcient, and Custom. If the option is set to
Custom, the following items will display:
CPU P State Control (Available when Power Technology
is set to Custom)
EIST (P-states)
EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically
adjust processor voltage and core frequency to reduce power consumption and
heat dissipation. The options are Disable and Enable.
4-10
X10DBT/X10DBT-T User’s Manual
Turbo Mode
Select Enabled to use the Turbo Mode to boost system performance. The options
are Enable and Disable.
P-state Coordination
This feature is used to change the P-state (Power-Performance State) coordi-
nation type. P-state is also known as "SpeedStep" for Intel processors. Select
HW_ALL to change the P-state coordination type for hardware components only.
Select SW_ALL to change the P-state coordination type for all software installed
in the system. Select SW_ANY to change the P-state coordination type for a soft-
ware program in the system. The options are HW_All, SW_ALL, and SW_ANY.
CPU C State Control (Available when Power Technology
is set to Custom)
C2C3TT (C2-to-C3 Transaction Timer)
This feature sets the transaction timer from C2 to C3. Enter 0 for Auto, which
will allow the BIOS to congure the transaction timer automatically. The Default
setting is 0 (Auto).
Package C State limit
Use this item to set the limit on the C-State package register. The options are
C0/1 state, C2 state, C6 (non-Retention) state, and C6 (Retention) state.
CPU C3 Report
Select Enable to allow the BIOS to report the CPU C3 State (ACPI C2) to the
operating system. During the CPU C3 State, the CPU clock generator is turned
off. The options are Enable and Disable.
CPU C6 Report (Available when Power Technology is set to Custom)
Select Enable to allow the BIOS to report the CPU C6 state (ACPI C3) to the
operating system. During the CPU C6 state, power to all cache is turned off.
The options are Enable and Disable.
Enhanced Halt State (C1E)
Select Enabled to use the "Enhanced Halt State" feature, which will signicantly
reduce CPU power consumption by reducing the CPU's clock cycle and voltage
during a "Halt State." The options are Disable and Enable.
Chapter 4: AMI BIOS
4-11
CPU T State Control
ACPI (Advanced Conguration Power Interface) T-States
Select Enable to support CPU throttling provided by the operating system to
reduce power consumption. The options are Enable and Disable.
CPU Advanced PM (Power Management) Tuning
Energy Perf (Performance) BIAS
Energy Performance Tuning
Select OS for the operating system to manage the settings of energy-perfor-
mance tuning. Select BIOS for the BIOS to manage the settings of energy-
performance tuning. The options are OS and BIOS.
Energy Performance Bias Setting
Use this feature to select an appropriate fan setting to achieve maximum system
performance (with maximum cooling) or maximum energy efciency with maxi-
mum power saving). The fan speeds are controlled by the rmware management
via IPMI 2.0. The options are Performance, Balanced Performance, Balanced
Power, and Power.
Workload Conguration
Use this feature to set the power management setting optimized for regular
workload condition. The options are Balanced and I/O sensitive.
Socket RAPL (Running Average Power Limit) Conguration
Turbo Pwr (Power) Limit Lock
Select Enable to set the power use limit for the machine when it is running in
the turbo mode. The options are Enable and Disable.
Long Pwr (Power) Limit Ovrd (Override)
Select Enable to support long-term power limit override. If this feature is set to
Disabled, BIOS will set the default value. The options are Enable and Disable.
Short Pwr (Power) Limit En (Enable)
Select Enable to support Short Duration Power Limit (Power Limit 2). The options
are Enable and Disable.
4-12
X10DBT/X10DBT-T User’s Manual
Chipset Conguration
North Bridge
This feature is used to congure Intel North Bridge settings.
Integrated IO Conguration
EV DFX (Device Function On-Hide) Features
When this feature is set to Enable, the EV_DFX Lock Bits that are located on a
processor will always remain clear during electric tuning. The options are Dis-
able and Enable.
IIO Conguration
Note: For /IIO1 Conguration/IIO2 Conguration/ IIO3 Conguration,
please refer to Page 4-16.
IIO0 Conguration
PCI-E Completion Timeout
Select Enable for PCI-E Completion Timeout support for electric tuning. The
options are Enable and Disable.
PCI-E Completion Timeout Value
Use this item to set the PCI-E Completion Time-out value for electric tuning.
Enter a value between 260ms to 900ms.
PCI Express Port 0 (DMI)
Note: For PCI Express Port 1A/Port 1B/Port 2A/Port 2B/Port 2C/Port 2D/
Port 3A/Port 3B/Port 3C/Port 3D, see the next section.
Use the items below to congure the PCI-E settings for a PCI-E port specied
by the user.
The following items will display:
•PCI-E Port Link Status
•PCI-E Port Link Max
•PCI-E Port Link Speed
Chapter 4: AMI BIOS
4-13
Link Speed
Use this item to select the PCI-E link speed for the PCI-E port specied by the
user. The options are GEN1 (2.5 GT/s), GEN2 (5 GT/s), and Auto.
Override Max Link Width
Use this feature to set the link speed for a selected PCI-E port to override the
maximum link-width which was previously set by PCI-Bifurcation. The options
are Auto, x1, x2, x4, x8, and x16.
PCI-E Port DeEmphasis
Use this item to select the De-Emphasis control setting for a PCI-E port specied
by the user. The options are -6.0 dB and -3.5 dB.
PCI-E ASPM Support
Select Enable to support the Active State Power Management (ASPM) level for
a PCI-E port specied by the user. Select Disabled to disable ASPM support.
The options are Disable and L1 Only.
Fatal Err (Error) Over
Select Enable to force the fatal error propogation to the II0 core-error-logic for
the port specied by the user. The options are Disable and Enable.
Non-Fatal Err (Error) Over
Select Enable to force non-fatal error propogation to the II0 core-error-logic for
the port specied by the user. The options are Disable and Enable.
Corr (Correctable) Err (Error) Over
Select Enable to force correctable error propogation to the II0 core-error-logic for
the port specied by the user. The options are Disable and Enable.
L0s Support
When this item is set to Disable, II0 will never put its transmitter in the L0s state.
The options are Disable and Enable.
PCI Express Port 1A/Port 1B/Port 2A/Port 2B/Port 2C/
Port 2D/Port 3A/Port 3B/Port 3C/Port 3D
Use the items below to congure the PCI-E settings for a PCI-E port specied
by the user.
The following items will display:
•PCI-E Port Link Status
4-14
X10DBT/X10DBT-T User’s Manual
•PCI-E Port Link Max
•PCI-E Port Link Speed
PCI-E Port
Select Enable to enable the PCI-E port specied by the user. The options are
Auto, Enable, and Disable.
PCI-E Port Link
Select Disable to disable the link that is not involved in PCI training, but its CFG
space is still active. The options are Enable and Disable.
Link Speed
Use this item to select the PCI-E link speed for the PCI-E port specied by the
user. The options are GEN1 (2.5 GT/s), GEN2 (5 GT/s), and Auto.
Override Max Link Width
This item allows the user to set the link speed for a selected PCI-E port to over-
ride the maximum link-width which was previously set by PCI-Bifurcation. The
options are Auto, x1, x2, x4, x8, and x16.
PCI-E Port DeEmphasis
Use this item to select the De-Emphasis control setting for a PCI-E port specied
by the user. The options are -6.0 dB and -3.5 dB.
PCI-E ASPM Support
Select Enable to support the Active State Power Management (ASPM) level for
a PCI-E port specied by the user. Select Disabled to disable ASPM support.
The options are Disable and L1 Only.
Fatal Err (Error) Over
Select Enable to force the fatal error propogation to the II0 core-error-logic for
the port specied by the user. The options are Disable and Enable.
Non-Fatal Err (Error) Over
Select Enable to force the non-fatal error propogation to the II0 core error logic
for the port specied by the user. The options are Disable and Enable.
Corr (Correctable) Err (Error) Over
Select Enable to force the correctable error propogation to the II0 core-error-logic
for the port specied by the user. The options are Disable and Enable.
Chapter 4: AMI BIOS
4-15
L0s Support
When this item is set to Disable, II0 will never put its transmitter in the L0s state.
The options are Disable and Enable.
PM ACPI Support
Select Enable to generate an _HPGPE message on a PM ACPI event. Select
Disable to generate an MSI message. The options are Disable and Enable.
Gen3 (Generation 3) Eq (Equalization) Mode
Use this item to set PCI-E Gen3 Adaptive Equalization mode. The options are
Auto, Enable Phase 0, 1, 2, 3; Disable Phase 0, 1, 2, 3; Enable Phase 1 Only,
Enable Phase 0, 1 Only, and Advanced.
Gen3 (Generation 3) Spec (Specics) Mode
Use this item to set the Specics mode for PCI-E Gen3 device. The options are
Auto, 0.70 July, 0.70 Sept and 071 Sept.
Gen3 (Generation 3) Phase2 Mode
Use this item to congure the Loop-count setting for PCI-E Gen3 Phase 2. The
options are Hardware Adaptive and Manual.
Gen3 (Generation 3) DN TX Preset
Use this item to set the Preset mode for PCI-E Gen3 downstream transactions
(from the master device to a slave device). The options are Auto, P0 (-6.0/0.0
dB), P1 (-3.5/0.0 dB), P2 (-4.5/0.0 dB), P3 (-2.5/0.0 dB), P4 (0.0/0.0 dB), P5
(0.0/2.0 dB), P6 (0.0/2.5 dB), P7 (-6.0 /3.5 dB), P8 (-3.5/3.5 dB), and P9 (0.0/3.5
dB).
Gen3 (Generation 3) DN RX Preset Hint
Use this item to set the Preset Hint mode for PCI-E Gen3 downstream Resets
(from the master device to a slave device). The options are Auto, P0 (-6.0 dB),
P1 (-7.0 dB), P2 (-8.0 dB), P3 (-9.0 dB), P4 (-10.0 dB) P5 (-11.0 dB), and P6
(-12.0 dB).
Gen3 (Generation 3) Up TX Preset
Use this item to set the Preset mode for PCI-E Gen3 upstream transactions (from
a slave device to the master device).The options are Auto, P0 (-6.0/0.0 dB),
P1 (-3.5/0.0 dB), P2 (-4.5/0.0 dB), P3 (-2.5/0.0 dB), P4 (0.0/0.0 dB), P5 (0.0/2.0
dB), P6 (0.0/2.5 dB), P7 (-6.0/3.5 dB), P8 (-3.5/3.5 dB), and P9 (0.0/3.5 dB).
Hide Port?
Select Yes to hide a selected PCI-E port from the OS. The options are No and
Yes.
4-16
X10DBT/X10DBT-T User’s Manual
IIO1 Conguration/IIO2 Conguration/IIO3 Conguration
IOU0 (II0 PCIE Port 2)
This item congures the PCI-E port Bifuraction settings for a PCI-E port specied
by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto.
IOU1 (II0 PCIE Port 3)
This item congures the PCI-E port Bifuraction settings for a PCI-E port specied
by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto.
PCI-E Completion Timeout
Select Enable to issue a "time-out" command when PCI-E electric tuning is
completed. The options are Enable and Disable.
PCI-E Completion Timeout Value
Use this item to set the PCI-E Completion Time-out value. Enter a value between
260ms to 900ms.
No PCI-E Port Active EC0
This is a workaround setting when there is no active PCI-E port detected. The
options are PCU Squelch exit ignore option, and Reset the SQ FLOP by
CSR optio.
PCI Express Port 0/Port 1A/Port 1B/Port 2A/Port 2B/Port
2C/Port 2D/Port 3A/Port 3B/Port 3C/Port 3D
Use the items below to congure the PCI-E settings for a PCI-E port specied
by the user.
The following items will display:
•PCI-E Port Link Status
•PCI-E Port Link Max
•PCI-E Port Link Speed
PCI-E Port
Select Enable to enable the PCI-E port specied by the user. The options are
Auto, Enable, and Disable.
PCI-E Port Link
Select Disable to disable the link that is not involved in training activities, but its
CFG is still active. The options are Enable and Disable.
Chapter 4: AMI BIOS
4-17
Link Speed
Use this item to select the link speed for the PCI-E port specied by the user.
The options are GEN1 (2.5 GT/s), GEN2 (5 GT/s), and Auto.
Override Max Link Width
Use this item to set the link speed for a selected PCI-E port to override the
maximum link width that was set by PCI-bifurcation. The options are Auto, x1,
x2, x4, x8, and x16.
PCI-E Port DeEmphasis
Use this item to select the De-Emphasis control setting for a PCI-E port specied
by the user. The options are -6.0 dB and -3.5 dB.
PCI-E ASPM Support
Select Enable to support the Active State Power Management (ASPM) level for
a PCI-E port specied by the user. Select Disabled to disable ASPM support.
The options are Disable and L1 Only.
Fatal Err (Error) Over
Select Enable to force the fatal error propogation to the II0 core-error-logic for
the port specied by the user. The options are Disable and Enable.
Non-Fatal Err (Error) Over
Select Enable to force the non-fatal error propogation to the II0 core-error-logic
for the port specied by the user. The options are Disable and Enable.
Corr (Correctable) Err (Error) Over
Select Enable to force the correctable error propogation to the II0 core-error-logic
for the port specied by the user. The options are Disable and Enable.
L0s Support
When this item is set to Disable, II0 will never put its transmitter in the L0s state.
The options are Disable and Enable.
PM ACPI Support
Select Enable to generate an _HPGPE message on a PM ACPI event. Select
Disable to generate an MSI message. The options are Disable and Enable.
Gen3 (Generation 3) Eq (Equalization) Mode
Use this item to set the "Adaptive Equalization" mode for PCI-E Generation 3
devices. The options are Auto, Enable Phase 0, 1, 2, 3; Disable Phase 0, 1, 2,
3; Enable Phase 1 Only, Enable Phase 0, 1 Only, and Advanced.
4-18
X10DBT/X10DBT-T User’s Manual
Gen3 (Generation 3) Spec (Specics) Mode
Use this item to set the Specics mode for PCI-E Generation 3 devices. The
options are Auto, 0.70 July, 0.70 Sept and 071 Sept.
Gen3 (Generation 3) Phase2 Mode
Use this item to set the PCI-E Generation 3 Phase 2 mode. The options are
Hardware Adaptive and Manual.
Gen3 (Generation 3) DN TX Preset
Use this item to set the Preset mode for PCI-E Gen3 downstream transactions
(from the master device to a slave device). The options are Auto, P0 (-6.0/0.0
dB), P1 (-3.5/0.0 dB), P2 (-4.5/0.0 dB), P3 (-2.5/0.0 dB), P4 (0.0/0.0 dB), P5
(0.0/2.0 dB), P6 (0.0/2.5 dB), P7 (-6.0 /3.5 dB), P8 (-3.5/3.5 dB), and P9 (0.0/3.5
dB).
Gen3 (Generation 3) DN TX Preset Hint
Use this item to set the Preset Hint mode for PCI-E Gen3 downstream transac-
tions (from the master device to a slave device). The options are Auto, P0 (-6.0
dB), P1 (-7.0 dB), P2 (-8.0 dB), P3 (-9.0 dB), P4 (-10.0 dB) P5 (-11.0 dB), and
P6 (-12.0 dB).
Gen3 (Generation 3) Up TX Preset
Use this item to set the Preset mode for PCI-E Gen3 upstream transactions (from
a slave device to the master device).The options are Auto, P0 (-6.0/0.0 dB),
P1 (-3.5/0.0 dB), P2 (-4.5/0.0 dB), P3 (-2.5/0.0 dB), P4 (0.0/0.0 dB), P5 (0.0/2.0
dB), P6 (0.0/2.5 dB), P7 (-6.0/3.5 dB), P8 (-3.5/3.5 dB), and P9 (0.0/3.5 dB).
Hide Port?
Select Yes to hide the PCI-E port specied from the OS. The options are No
and Yes.
Integrated IO Conguration
Enable I/OAT
Select Enable to enable Intel I/OAT (I/O Acceleration Technology), which signi-
cantly reduces CPU overhead by leveraging CPU architectural improvements
and freeing the system resource for other tasks. The options are Enable and
Disable.
No Snoop
Select Enable to support no-snoop mode for each CB device. The options are
Disable and Enable.
Chapter 4: AMI BIOS
4-19
Disable TPH
Select Enable to de-activate TLP Processing Hint support. The options are Dis-
able and Enable.
II0 Generation Conguration
The following information will display:
TXT DPR memory setting
Use this item to set TXT DPR settings. The options are 1M DPR, 3M DPR, 64M
DPR, 128M DPR, and 255M DPR.
Unhide QPI PMU Counter
Select Enable to use the PCI-Express counters. Select Disable to hide the PCI-
Express counters. The options are Disable and 255M Enable.
IIO0/IIO1/IIO2/IIO3
II0 IOAPCI
Select Enable to support IIO IOAPIC (I/O Advanced Power Interface Congura-
tion). The options are Enable and Disable.
Intel VT for Directed I/O (VT-d)
Intel VT for Direct I/O (VT-d)
Isoc
Select Enable to enable Isochronous support to meet QoS (Quality of Service)
requirements. This feature is especially important for Intel Virtualization technol-
ogy. The options are Enable and Disable.
Intel® VT for Directed I/O (VT-d)
Select Enable to enable Intel Virtualization Technology support for Direct I/O
VT-d by reporting the I/O device assignments to the VMM (Virtual Machine
Monitor) through the DMAR ACPI Tables. This feature offers fully-protected I/O
resource sharing across Intel platforms, providing greater reliability, security and
availability in networking and data-sharing. The options are Enable and Disable.
VTD (VT-d) BARLock Enable
Select Enable to enable Bar-lock support for the devices used in Intel
Virtualization Technology. The options are Enable and Disable.
4-20
X10DBT/X10DBT-T User’s Manual
Interrupt Remapping
Select Enable to support Interrupt Remapping to enhance system performance.
The options are Enable and Disable.
Pass Through DMA
Select Enable for the Non-Iscoh VT-d engine to pass through DMA (Direct Memo-
ry Access) to enhance system performance. The options are Enable and Disable.
ATS
Select Enable for the Non-Iscoh VT-d engine to pass through ATS to enhance
system performance. The options are Enable and Disable.
Super Pages
Select Enable for VT-d Super-Pages support to improve system performance.
The options are Enable and Disable.
Coherence Support
Select Enable for Non-Iscoh VT-d Engine Coherence support to improve system
performance. The options are Disable and Enable.
PCI Express Global Options
Gen3 (Generation 3) Phase3 Loop Count
Use this feature to set the Loop-Count value for PCI-E Gen3 Phase3 operations.
The options are 1, 4, 16, and 256.
Skip Halt On DMI Degradation
Select Enable to avoid the system being put on hold during DMI width/link deg-
radation. The options are Disable and Enable.
Power Down Unused Ports
Select Enable to disable the PCI-E ports that are not active. The options are
Disable, Enable, HSX Disable
QPI (Quick Path Interconnect) Conguration
QPI Status
The following information will display:
•Number of CPU
•Number of IIO
Chapter 4: AMI BIOS
4-21
•LInk Speed
•Current QPI Link Frequency
•QPI Global MMIO Low Base/Limit
•QPI Global MMIO High Base/Limit
•QPI PCI-E Conguration Base/Siz (Size)
Link Speed Mode
Use this feature to select the data transfer speed for QPI Link connections. The
options are Fast and Slow.
Link Frequency Select
Use this feature to select the desired frequency for QPI Link connections. The
options are 6.4GB/s, 7.2GB/s, 8.0GB/s, Auto, and Use Per LInk Setting.
Link L0p Enable
Select Enable for Link L0p support. The options are Enable and Disable.
Link L1 Enable
Select Enable for Link L1 support. The options are Enable and Disable.
Legacy VGA Socket
Enter the VGA socket number (from 0-7)t hat will used to support legacy VGA.
The default setting is 0.
MMIO P2P Disable
Select No to prevent MMIO (Memory-Mapped I/0) P2P (PCI-E device to PCI-E
device) signals from crossing the CPU socket. The options are No and Yes.
PPIN Opt-in
Select Yes to use the Protected-Processor Inventory Number (PPIN) in the
system. The options are No and Yes.
QPI Debut Print Level
Use this item to select the QPI Debug level that will be displayed in the monitor.
The options are Fatal, Warning, Summary, Detail, and All.
4-22
X10DBT/X10DBT-T User’s Manual
Resource Auto Adjust
Select Enable for the PCI resource-requests for each CPU socket to be auto-
matically adjusted on the need-base when the PCI resource allocator fails. The
options are Enable and Disable.
QPI Per Socket Conguration
CPU 0/CPU 1
Bus Resource Allocation Ratio
Use this feature to set the bus resource-allocation ratio (from 0-8). The default
setting is 1.
IO Resource Allocation Ratio
Use this feature to set the IO resource-allocation ratio (from 0-8). The default
setting is 1.
MMIOL Resource Allocation Ratio
Use this feature to set the Memory-Mapped IO resource-allocation ratio (from
0-8). The default setting is 1.
IIO UniPhy Disable
Select Yes to hide the entire UNIFY in L2 cache. The options are No, Yes, and
Yes w/Memory Hot Add.
Memory Conguration
This section displays the following Integrated Memory Controller (IMC) informa-
tion.
Promote Warnings
Select Enable to treat memory warnings as memory errors or memory faults for
system-level debugging. The options are Enable and Disable.
DDR Speed
Use this feature to force a DDR3 memory module to run at a frequency other
than what is specied in the specication. The options are Auto, 1067, 1333,
1600, 1867, and 2133.
Chapter 4: AMI BIOS
4-23
DDR Voltage Level
Select Auto for the BIOS to set the voltage settings for all DDR3 memory mod-
ules. Select Force to 1.50V to force all DDR3 memory modules to operate at
1.50V. The options are Auto and Force to 1.50V.
Advanced Clk (Clock) Training
Select Enable to support Advanced Clock Training, which will allow the memory
command line to be synchronized with the clock line to enhance memory per-
formance. The options are Enable and Disable.
Perbit (Per-bit) Deskew Training
Select Enable to support Perbit Deskew Training, which will allow the memory
controller to include various adjustable delay circuits in both Read and Write
paths on a per-bit base for effective memory interface to maximize memory
performance. The options are Disable and Enable.
0DT (On-Die Termination) Timing Mode
Use this feature to congure the timing mode setting for the ODT (On-Die Ter-
mination) where the termination resistor for impedance matching in transmission
lines is located inside a chip instead of on a printed circuit board. The options
are Aggressive Timing and Conservative Timing.
MxB Rank Sharing Mapping
Use this feature to select the address-mapping setting for memory-rank sharing
to enhance extended multimedia platform performance. The options are Maxi-
mum Performance and Maximum Margin.
DIMM Vref. (Voltage Reference) Circuit
This feature allows the user to decide how to congure the voltage reference
point (gate) for a DDR3 memory module. The options are Internal and External.
BIOS VMSE Reset
If this feature is set to Enable, BIOS settings pertaining to the Intel Scalable
Memory Interconnect 2 (Intel SMI 2) controller will be reset to improve system
performance. The options are Disable and Enable.
Save JCK Error Longs
Select Enable to save the JCK Error log at each system reset caused by system
rmware. The options are Enable and Disable.
4-24
X10DBT/X10DBT-T User’s Manual
Phase Shedding
Select Enabled to enable Static Phase-Shedding support for DDR3 memory
voltage regulators to improve memory performance. The options are Auto,
Disabled and Enabled.
Multi-Threaded MRC (Memory Reference Code)
Select Enabled for the system to execute multi-threaded memory codes to
improve memory performance. The options are Auto, Disabled and Enabled.
Rank Multiplication
Select Enabled to force the LRDIMM (Load-Reduced DIMM) memory modules to
operate at the Rank-Multiplication mode for memory performance enhancement.
The options are Auto and Enabled.
LRDIMM (Load-Reduction DIMM) Module Delay
When this item is set to Disabled, the MRC (Memory Regulator Controller) will
not use SPD bytes 90-95 for module delay on LRDIMM memory. The options
are Disabled and Auto.
Memory Type
Use this feature to select the memory type to be used in this system. The options
are RDIMMs only, UDIMMs only, and UDIMMs and RDIMMs.
Skip MemTest (Memory Test) on Fast Boot
Select Enable to skip memory routine testing at bootup if this machine is set to
Fast-boot mode. The options are Disable and Enable.
BDAT
Select Enabled for BDAT (Binary Data Advanced Technology) support to increase
system performance. The options are Disabled and Enabled.
Data Scrambling
Select Enabled to enable data scrambling to enhance system performance and
data integrity. The options are Disabled and Enabled.
Scrambling Speed Low
Use this feature to set the data scrambling speed to low-32 bits. Enter a value
between 0 and 32. The default setting is 0.
Scrambling Speed High
Use this feature to set the data scrambling speed to high-32 bits. Enter a value
between 0 and 32. The default setting is 0.
Chapter 4: AMI BIOS
4-25
Enable ADR
Select Enabled for ADR (Automatic Diagnostic Repository) support to enhance
memory performance. The options are Enabled and Disabled.
VMSE Lockstep Mode
Select Enabled to support the VMSE Lockstep mode, which will support Lock
step mode for the Intel Scalable Memory Interconnect 2 (Intel SMI 2) controller.
The options are 2:1 Mode.
NB Persistent Error
Select Enable to allow the system to properly handle the persistent errors oc-
curred in the North Bridge. The options are Enable and Disable.
SB Persistent Error
Select Enable to allow the system to properly handle the persistent errors oc-
curred in the South Bridge. The options are is Enable and Disable.
SB Error Threshold
Use this feature to set the threshold for South Bridge errors. When the number of
South Bridge errors reaches beyond the threshold, the system will automatically
take corrective actions. The default setting is 10.
Link Failure Threshold
Use this feature to set the link failure threshold. When the number reaches
beyond the threshold, the system will automatically take corrective actions. The
default setting is 7.
Refresh Options
Use this feature to set self-refresh mode The options are Acc Self Refresh
and 2x Refresh.
HA (Hash Mode) Early Write Post Mode
Select Enable to support memory hash-method-comparison mode when the
system is running at the early stage of POST (Power-On-Self-Test). The options
are is Enable and Disable.
MC Channel Hash Mode
Select Enabled to support the hash-method-comparison mode for the memory
controller to improve memory performance. The options are Enabled and Dis-
abled.
4-26
X10DBT/X10DBT-T User’s Manual
Unused Memory Channel Input
Select Enabled to allow input from unused memory channels. The options are
Enabled and Disabled.
Command 2 Data Tuning
Select Enabled to ne-tune electrical command paths from the host system to
the memory-extension buffer (MXB). The options are Enabled and Disabled.
JordonCreek Power Management
Select Enabled to activate power management features embedded in the Jordon
Creek chip for the Intel Scalable Memory Interconnect 2 (Intel SMI 2) controller.
The options are Enabled and Disabled.
MRC Debug Level
Use this feature to set the debugging level for memory reference codes, which
are used for memory multiple threads initialization. The options are L0, L1 and L2.
Halt on Memory Fatal Error
Select Enabled to put the system on hold when a memory fatal error occurs.
The options are Enabled and Disabled.
Promote MEM (Memory) Train Err (Error)
Select Enabled to promote warnings when a memory training-error occurs. The
options are Enabled and Disabled.
Promote MEM (Memory) RAS Warnings
Select Enabled to promote warnings pertaining to RAS (Reliability, Availability,
Serviceability) issues. The options are Enabled and Disabled.
Memory Test
When this feature is set to Enabled, memory tests will be performed in the sys-
tem. The options are Enabled and Disabled.
JCK (Jordon Creek) per DIMM Parity Error Enable
Select Enabled for the system to monitor and keep track of DIMM parity errors
occurred on each DIMM module. The options are Enabled and Disabled.
DRAM RAPL (Running Average Power Limit) Mode
Use this feature to set the run-time power-limit mode for DRAM modules. The
options are Disabled, VR Measured and Estimated.
Chapter 4: AMI BIOS
4-27
Closed Loop Thermal Throttling
Select Enabled to support Closed-Loop Thermal Throttling which will improve
reliability and reduces CPU power consumption via automatic voltage control
while the CPU are in idle states. The options are Disabled and Enabled.
Memory Hot Sense Thermal Throttling
Select Enabled to activate thermal-throttling when the hot-sensor reaches the
predened threshold via automatic voltage control when the CPU is in idle states.
The options are Enabled and Disabled.
Memory Hot Output Thermal Throttling
Select Enabled to provide thermal-throttling warnings when the hot-sensor
reaches the predene threshold via automatic voltage control when the CPU is
in idle states. The options are Enabled and Disabled.
MC ODT Mode
This feature sets the ODT (On-Die Termination) mode for the memory controller.
The options are Auto, 100 Ohms, and 50 Ohms.
MRC (Memory Reference Code) Promote Warnings
Select Enabled for the system to provide MRC warnings to improve memory
performance. The options are Enabled and Disabled.
Num (Number) of Sparing Transac (Transaction)
Use this feature to set the number of memory sparing transactions that will allow
data to be written from a failing component to another component to ensure data
security. The options are 4.
PSMI Support
Select Enabled for Power Supply Management Interface (PSMI) support. The
options are Enabled and Disabled.
VMSE Clock Stop
Select Enabled to de-activate the clock driver for the Intel Scalable Memory
Interconnect 2 (Intel SMI 2) controller. The options are Enabled and Disabled.
Safe MC (Micro Code) BGF (Buffer Generation First-in-First-Out) PSV
Select Enabled to use the Micro-Code Safe mode to allow the onboard power
control mechanism to supply power to the memory buffer on the on-demand basis
in an effort to save power consumption. The options are Enabled and Disabled.
4-28
X10DBT/X10DBT-T User’s Manual
Memory Topology
This item displays the status of each DIMM module as detected by the BIOS.
•Node
•Channel
•DIMM Frequency
Memory Thermal
Memory Power Savings Mode
Use this item to congure chipset-related memory power-saving features. The
options are Auto, Slow, Fast, Disabled, and User Dened.
Memory Power Savings Advanced Options
IBT (Intel Burn Test) Off
Select Enabled to turn off Intel Burn-in memory tests. The options are Dis-
abled, Auto, and Enabled.
CK in SR
This feature is used to congure PCH behaviors while in self-refreshing
cycles. The options are Auto, Driven, Tri-State, Pulled Low, and Pulled High.
MDLL Off
Select Enable to shut down MDLL (Multiple Delay-Locked Loop) operations
while system memory is synchronizing resources for power-saving. The op-
tions are Auto, Disabled, and Enabled.
Extreme Memory Prole
XMP Prole Support
Select Enabled for Extreme Memory support. The options are Disabled, Prole
1, and Prole 2.
XMP Prole
Use this item to select which type of Extreme Prole to use. The options are
Disabled and Manual.
Chapter 4: AMI BIOS
4-29
Memory Frequency
Use this item to set the frequency of system memory. The options are Auto, 1067
(MHz), 1333 (MHz), 1600 (MHz), 1867 (MHz), 2133 (MHz), and 2400 (MHz).
Memory RAS (Reliability_Availability_Serviceability)
Conguration
Use this submenu to congure the following Memory RAS settings.
Memory RAS Conguration Setup
Socket 0 Branch 0/Socket 0 Branch1/Socket 1 Branch 0/Socket 1 Branch1
Select Enable to enable the memory module installed on the socket specied by
the user. The default setting is Enable and Disable.
Migration Spare
Use this feature to set the bit-mask of the riser card that is designated as a spare
riser. The default setting is 0.
Current Memory Speed
This item displays the current memory speed.
Mirroring
This item indicates if memory mirroring is supported by the motherboard. Memory
mirroring creates a duplicate copy of the data stored in the memory to enhance
data security.
Sparing
This item indicates if memory sparing is supported by the motherboard. Memory
sparing enhances system performance.
Memory Rank Sparing
This item indicates if memory rank sparing is supported by the motherboard. Memory
rank sparing enhances system performance.
Spare Error/Memory Correctable Thr (Threshold)
Use this feature to set the correctable error threshold for spare memory modules.
The default setting is 10.
Leaky Bucket Low Bit
Use this feature to set the Low Bit value for the Leaky Bucket algorithm which
is used to check the data transmissions between CPU sockets and the memory
controller. The default setting is 40.
4-30
X10DBT/X10DBT-T User’s Manual
Leaky Bucket High Bit
Use this feature to set the High Bit value for the Leaky Bucket algorithm which
is used to check the data transmissions between CPU sockets and the memory
controller. The default setting is 41.
Publish SRAT (Static Resource Afnity Table)
Select Enable for the BIOS to report the ACPI SRAT table to the OS in order to
enhance CPU and memory performance when the NUMA (Non-Uniformed Memory
Access) is optimized. The options are Enable and Disable.
Memory Interleaving
Use this feature to set the DIMM memory interleaving mood. The options are NUMA
(1-way) Node Interleave, 2-way Node Interleave, 4-way Interleave, 8 Way Interleav-
ing, Inter-socket, and Auto.
Socket Interleave Below 4GB
Select Enabled for the memory above the 4G Address space to be split between
two sockets. The options are Enable and Disable.
Channel Interleaving
Use this feature to set the DIMM channel interleaving mood. The options are Auto,
1-Way Interleave, 2-Way Interleave, 3-Way Interleave, and 4-Way Interleave.
Rank Interleaving
Use this feature to select a rank memory interleaving method. The options are Auto,
1-Way, 2-Way, 4-Way, and 8-Way.
DRAM Maintenance
Select Auto for the BIOS to automatically congure DRAM Refreshing and Patrol
settings. The options are Manual and Auto.
pTRR (Pseudo Target Row Refresh) Support
Select Enabled for Pseudo TRR support which will allow the BIOS to assign an
invalid address to a questionable memory module to prevent this memory module
from being accessed by other components. The options are Enabled and Disabled.
Injection Probability
AMEI (Asynchroous MCA Error Injection) (AMEI) is a error-handling mechanism
that allows the BIOS to report the MCA errors to the CPU core or the CPU before
resuming normal operations. This item is used to set the threshold of the AMEI
events beyond which the BIOS will report the error events before resuming opera-
tions. The options are 512, 1024, 1365, 1638, 1820, 1928, 2048, 2731, 3277, 3641,
4096, 5461, 6554, 8192, 10923, 16384, 32768.
Chapter 4: AMI BIOS
4-31
Demand Scrub
Demand Scrubbing is a process that allows the CPU to correct correctable memory
errors found on a memory module. When the CPU or I/O issues a demand-read
command, and the read data from memory turns out to be a correctable error, the
error is corrected and sent to the requestor (the original source). Memory is updated
as well. Select Enable to use Demand Scrubbing for ECC memory correction. The
options are Enable and Disable.
Device Tagging
Select Enable to support device tagging. The options are Disable and Enable.
Memory Power Management
Select Enabled for memory power management support. The options are Disabled
and Enabled.
Memory Rank Mask
Select Enabled to support memory rank in the memory controller. The options are
Disabled and Enabled.
A7 Mode
Select Enabled to support A7 (Addressing) Mode to improve memory performance.
The options are Disable and Enable.
DDDC Support
Select Enabled to enable Double-Device Data Correction (DDDC) support for the
error-correction codes to correct memory errors caused by two failed DRAM devices.
The options are Disable and Enable.
DDDC Wirekill (Wire-Kill)
Select Enabled for Double-Device Data Correction (DDDC) Wire-kill support which
will disable the wire connection between two DRAM devices when they fail. The
options are Disable and Enable.
DDDC Wirekill (Wire-Kill) Threshold
Use this feature to set the DDDC Wirekill threshold. When the memory errors reach
the threshold,wire-connections between the failed DRAM modules will be discon-
nected. The default setting is 2.
Apply Memory RAS (Reliability-Availability-Serviceability Policy Globally
When this item is set to Enabled, the conguration settings for memory sparing,
Mirroring, DDDC, Device-Tagging will be applied to all nodes in the system. The
options are Disable and Enable.
4-32
X10DBT/X10DBT-T User’s Manual
Apply Memory RAS Policy Globally
Select Enable to apply Memory RAS policy to all related components and systems.
The options are Disable and Enable.
Memory Mirroring
Select Enable to enable memory-mirroring support which will create a duplicate
copy of the data stored in the memory to enhance data security. The options are
Disable and Enable.
South Bridge
This feature is used to congure Intel South Bridge settings.
USB Conguration
The following USB items will display.
•USB Module Version
•USB Devices
Legacy USB Support (Available when USB Functions is not Disabled)
Select Enabled to support legacy USB devices. Select Auto to disable legacy sup-
port if USB devices are not present. Select Disabled to have USB devices available
for EFI (Extensive Firmware Interface) applications only. The settings are Disabled,
Enabled and Auto.
USB 3.0 Support
Select Enabled for USB 3.0 support. The options are Disabled and Enabled.
XHCI Hand-Off
This feature is a work-around solution for operating systems that do not support
XHCI (Extensible Host Controller Interface) hand-off. The XHCI ownership change
should be claimed by the XHCI driver. The settings are Enabled and Disabled.
EHCI Hand-Off
This item is for operating systems that do not support Enhanced Host Controller
Interface (EHCI) hand-off. When this item is enabled, EHCI ownership change will
be claimed by the EHCI driver. The settings are Enabled and Disabled.
USB Mass Storage Driver Support
Select Enabled to use USB mass storage devices. The options are Disabled and
Enabled.
Chapter 4: AMI BIOS
4-33
Port 60/64 Emulation
Select Enabled for I/O port 60h/64h emulation support which will provide complete
USB keyboard legacy support for the operating system that does not support Legacy
USB devices. The options are Disabled and Enabled.
USB Hardware Delays and Time-outs
USB Transfer Time-out
Use this feature sets the USB Transfer Time-out values for control, bulk, and inter-
rupt transfers. The default setting is 20 sec (seconds).
Device Reset Time-out
Select Auto for the BIOS to automatically congure the delay maximum time setting
before a USB device properly reports itself to the system. The options are Auto
and Manual.
Device Power-up Delay
Use this feature sets the maximum time-out value for initialization of USB mass
storage devices. The options are Auto and Manual.
Mass Storage Devices:
Aten Virtual CDROM YS0J
Use this feature select the emulation type for the mass storage device. The options
are Auto, Floppy, Forced FDD, Hard Disk, and CD-ROM.
SATA Conguration
When this submenu is selected, the AMI BIOS automatically detects the presence
of the SATA devices that are supported by the Intel PCH chip and displays the
following items:
SATA Controller
This item enables or disables the onboard SATA controller supported by the Intel
PCH chip. The options are Enabled and Disabled.
Congure SATA as
Select IDE to congure a SATA drive specied by the user as an IDE drive. Select
AHCI to congure a SATA drive specied by the user as an AHCI drive. Select
RAID to congure a SATA drive specied by the user as a RAID drive. The options
are IDE, AHCI, and RAID.
*If the item above "Congure SATA as" is set to AHCI, the following items
will display:
4-34
X10DBT/X10DBT-T User’s Manual
Support Aggressive Link Power Management
When this item is set to Enabled, the SATA AHCI controller manages the power
usage of the SATA link. The controller will put the link in a low power mode during
extended periods of I/O inactivity, and will return the link to an active state when
I/O activity resumes. The options are Enabled and Disabled.
SATA Port 0~ Port 5
This item displays the information detected on the installed SATA drive on the
particular SATA port.
•Model number of drive and capacity
•Software Preserve Support
Port 0~ Port 5
Select Enabled to enable a SATA port specied by the user. The options are
Disabled and Enabled.
Port 0 ~ Port 5 Hot Plug
This feature designates the port specied for hot plugging. Set this item to En-
abled for hot-plugging support, which will allow the user to replace a SATA disk
drive without shutting down the system. The options are Enabled and Disabled.
Port 0 ~ Port 5 Spin Up Device
On an edge detect from 0 to 1, set this item to allow the PCH to initialize the
device. The options are Enabled and Disabled.
Port 0 ~ Port 5 SATA Device Type
Use this item to specify if the SATA port specied by the user should be con-
nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk
Drive and Solid State Drive.
*If the item above "Congure SATA as" is set to IDE, the following items
will display:
Serial ATA Port 0~ Port 5
This item indicates that a SATA port specied by the user is not installed or not
present.
Port 0 ~ Port 5 SATA Device Type (Available when a SATA port is
detected)
Use this item to specify if the SATA port specied by the user should be con-
nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk
Drive and Solid State Drive.
Chapter 4: AMI BIOS
4-35
*If the item above "Congure SATA as" is set to RAID, the following items
will display:
Support Aggressive Link Power Management
When this item is set to Enabled, the SATA AHCI controller manages the power
usage of the SATA link. The controller will put the link in a low power mode during
extended periods of I/O inactivity, and will return the link to an active state when
I/O activity resumes. The options are Enabled and Disabled.
SATA RAID Option ROM/UEFI Driver
Select EFI to load the EFI driver for system boot. Select Legacy to load a legacy
driver for system boot. The options are Disabled, EFI, and Legacy.
Serial ATA Port 0~ Port 5
This item displays the information detected on the installed SATA drives on the
particular SATA port.
•Model number of drive and capacity
•Software Preserve Support
Port 0~ Port 5
Select Enabled to enable a SATA port specied by the user. The options are
Disabled and Enabled.
Port 0 ~ Port 5 Hot Plug
This feature designates this port for hot plugging. Set this item to Enabled for
hot-plugging support, which will allow the user to replace a SATA drive without
shutting down the system. The options are Enabled and Disabled.
Port 0 ~ Port 5 Spin Up Device
On an edge detect from 0 to 1, set this item to allow the PCH to start a COMRE-
SET initialization to the device. The options are Enabled and Disabled.
Port 0 ~ Port 5 SATA Device Type
Use this item to specify if the SATA port specied by the user should be con-
nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk
Drive and Solid State Drive.
4-36
X10DBT/X10DBT-T User’s Manual
SCU (Storage Control Unit) Conguration
Storage Controller Unit
Select Enabled to enable PCH SCU storage devices. The options are Disable and
Enable.
Onchip SCU Option ROM
Select Disabled to boot the system from a SAS device. Select EFI to boot the system
from an EFI device. Select Legacy to boot the system from a Legacy SCU device.
The options are Disable, EFI, and Legacy.
Boot from SCU or SATA RAID
Use this feature to select device from which the system will boot. The options are
Boot from SCU, Boot from SATA RAID, Do not boot form SATA or SCU drives,
and No Legacy RAM Space Restrictions.
The AMI BIOS will display the status of an SCU port as detected:
•SCU Port 0
•SCU Port 1
•SCU Port 2
•SCU Port 3
PCIe/PCI/PnP Conguration
PCI Latency Timer
Use this feature to set the latency timer of each PCI device installed on a PCI bus.
Select 64 to set the PCI latency to 64 PCI clock cycles. The options are 32, 64, 96,
128, 160, 192, 224 and 248 (PCI Bus Clocks).
VGA Palette Snoop
Select Enabled to support VGA palette register snooping which will allow the
PCI cards that do not contain their own VGA color palette to examine the video
cards palette and mimic it for proper color display. The options are Disabled and
Enabled.
PERR# Generation
Select Enabled to allow a PCI/PCI-E device to generate a PCI/PCI-E Parity-Error
(PERR) number for a PCI Bus Signal Error Event. The options are Enabled and
Disabled.
Chapter 4: AMI BIOS
4-37
SERR# Generation
Select Enabled to allow a PCI/PCI-E device to generate a System-Error (SERR)
number for a PCI Bus Signal Error Event. The options are Enabled and Disabled.
PCI AER (Advanced Error-Reporting) Support
Select Enabled to support Advanced Error-Reporting for onboard PCI devices. The
options are Disabled and Enabled.
Above 4G Decoding (Available if the system supports 64-bit PCI decoding)
Select Enabled to decode a PCI device that supports 64-bit in the space above 4G
Address. The options are Enabled and Disabled.
42-bit Address AOC
Select Enabled to enable 42-bit Address Add-On card for Nvidia Tesla support. The
options are Enabled and Disabled.
SR-IOV Support (Available if the system supports Single-Root
Virtualization)
Select Enabled for Single-Root IO Virtualization support. The options are Enabled
and Disabled.
Maximum Payload
Select Auto to allow the system BIOS to automatically set the maximum payload
value for a PCI-E device to enhance system performance. The options are Auto,
128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.
PCI AER (Advanced Error-Reporting) Support
Select Enabled to support Advanced Error-Reporting for onboard PCI devices. The
options are Disabled and Enabled.
Maximum Read Request
Select Auto to allow the system BIOS to automatically set the maximum Read
Request size for a PCI-E device to enhance system performance. The options are
Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.
ASPM Support
This feature allows the user to set the Active State Power Management (ASPM)
level for a PCI-E device. Select Force L0s to force all PCI-E links to operate at L0s
state. Select Auto to allow the system BIOS to automatically set the ASPM level for
the system. Select Disabled to disable ASPM support. The options are Disabled,
Force L0s, and Auto.
Warning: Enabling ASPM support may cause some PCI-E devices to fail!
4-38
X10DBT/X10DBT-T User’s Manual
PCI Devices Option ROM Settiing
Slot1 x16 thru (through) SXB1 OPROM/Slot2 x16 thru (through) SXB1
OPROM/Slot SXB2 x8 thru (through) BPN-ADP-8SATA3-1 OPROM/Slot SXB3
x8 OPROM
Use this feature to select the type of device installed on a slot specied by the user
for the system to boot from. The options are EFI, Legacy and Disabled.
NVME thru (through) BPN-ADP-8SATA3-1 OPROM
Use this feature to select the type of NVME (Non-Volatile Memory Express) device
installed on the slot specied above for the system to boot from. The options are
EFI, Legacy and Disabled.
Onboard Video OPROM
This feature controls how the system executes UEFI (Unied Extensible Firmware
Interface), and legacy Option ROM. Select Legacy Only to boot the system using a
legacy video device. The options are Do not launch, UEFI Only and Legacy Only.
VGA Priority
This feature allows the user to select the graphics adapter to be used as the primary
boot device. The options are Onboard and Offboard.
Onboard LAN Option ROM Type
Use this item to select the device type for onboard LAN Option ROM for system
boot. The options are EFI and Legacy.
Onboard LAN 1 OpROM/Onboard LAN 2 OpROM
Select iSCSI to use the iSCSI Option ROM to boot the computer using a iSCSI
network device. Select PXE (Preboot Execution Environment) to use an PXE Op-
tion ROM to boot the computer using a PXE network device. The default option
for Onboard LAN 1 is PXE and for Onboard LAN 2 is Disabled.
ME (Management Engine) Subsystem
This feature displays the following ME Subsystem Conguration settings.
General ME Conguration
•Operational Firmware Version
•Recovery Firmware Version
•ME Firmware Features
Chapter 4: AMI BIOS
4-39
•ME Firmware Status #1
•ME Firmware Status #2
•Current State
•Error Code
Super IO Conguration
Super IO Chip: This item displays the Super IO chip used in the motherboard.
Serial Port 1 Conguration
Serial Port
Select Enabled to enable a serial port specied by the user. The options are En-
abled and Disabled.
Device Settings
This item displays the settings of Serial Port 1 (COM).
Change Settings
This option species the base I/O port address and the Interrupt Request address
of Serial Port 1 (COM). Select Disabled to prevent the serial port from accessing
any system resources. When this option is set to Disabled, the serial port becomes
unavailable. The options are Auto, IO=3F8h; IRQ=4; IO=3F8h; IRQ=3, 4, 5, 6, 7,
10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10,
11, 12; IO=2E8h; IRQ=IRQ=3, 4, 5, 6, 7, 10, 11, 12.
Device Mode
Use this feature to select the desired mode for a serial port specied. The options
are 24MHz/13 and 24MHz.
Serial Port 2 Conguration
Serial Port
Select Enabled to enable a serial port specied by the user. The options are En-
abled and Disabled.
Device Settings
This item displays the settings of Serial Port 2.
4-40
X10DBT/X10DBT-T User’s Manual
Change Settings
This option species the base I/O port address and the Interrupt Request address
of Serial Port 2 (SOL). Select Disabled to prevent the serial port from accessing
any system resources. When this option is set to Disabled, the serial port becomes
unavailable. The options are Auto, O=2F8h; IRQ=4; IO=3F8h; IRQ=3, 4, 5, 6, 7,
10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10,
11, 12; IO=2E8h; IRQ=IRQ=3, 4, 5, 6, 7, 10, 11, 12.
Device Mode
Use this feature to select the desired mode for a serial port specied. The options
are 24MHz/13 and 24MHz.
Serial Port 2 Attribute
Use this feature to select the attribute for this serial port. The options are SOL
(Serial Over LAN), and COM.
Serial Port Console Redirection
COM 1 Console Redirection
This submenu allows the user to congure the following Console Redirection set-
tings for this port.
Console Redirection
Select Enabled for Console Redirection support. The options are Enabled and
Disabled.
COM2/SOL Console Redirection
This submenu allows the user to congure the following Console Redirection set-
tings for the SOL Port specied by the user.
Console Redirection
Select Enabled to use the SOL Port for Console Redirection. The options are
Enabled and Disabled.
Console Redirection Settings
This feature allows the user to specify how the host computer will exchange data
with the client computer, which is the remote computer used by the user.
Terminal Type
This feature allows the user to select the target terminal emulation type for Con-
sole Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to
Chapter 4: AMI BIOS
4-41
add color and function key support. Select ANSI to use the Extended ASCII Char-
acter Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters
into one or more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.
Bits Per second
Use this feature to set the transmission speed for a serial port used in Console
Redirection. Make sure that the same speed is used in the host computer and the
client computer. A lower transmission speed may be required for long and busy
lines. The options are 9600, 19200, 38400, 57600 and 115200 (bits per second).
Data Bits
Use this feature to set the data transmission size for Console Redirection. The
options are 7 Bits and 8 Bits.
Parity
A parity bit can be sent along with regular data bits to detect data transmission
errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits
is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits
is odd. Select None if you do not want to send a parity bit with your data bits
in transmission. Select Mark to add a mark as a parity bit to be sent along with
the data bits. Select Space to add a Space as a parity bit to be sent with your
data bits. The options are None, Even, Odd, Mark and Space.
Stop Bits
A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard
serial data communication. Select 2 Stop Bits if slower devices are used. The
options are 1 and 2.
Flow Control
This feature allows the user to set the ow control for Console Redirection to
prevent data loss caused by buffer overow. Send a "Stop" signal to stop send-
ing data when the receiving buffer is full. Send a "Start" signal to start sending
data when the receiving buffer is empty. The options are None and Hardware
RTS/CTS.
VT-UTF8 Combo Key Support
Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100
terminals. The options are Enabled and Disabled.
Recorder Mode
Select Enabled to capture the data displayed on a terminal and send it as text
messages to a remote server. The options are Disabled and Enabled.
4-42
X10DBT/X10DBT-T User’s Manual
Resolution 100x31
Select Enabled for extended-terminal resolution support. The options are Dis-
abled and Enabled.
Legacy OS Redirection Resolution
Use this feature to select the number of rows and columns used in Console
Redirection for legacy OS support. The options are 80x24 and 80x25.
Putty KeyPad
This feature selects Function Keys and KeyPad settings for Putty, which is a
terminal emulator designed for the Windows OS. The options are VT100, LINUX,
XTERMR6, SCO, ESCN, and VT400.
Redirection After BIOS Post
Use this feature to enable or disable legacy console redirection after BIOS POST.
When set to Bootloader, legacy console redirection is disabled before booting
the OS. When set to Always Enable, legacy console redirection remains enabled
when booting the OS. The options are Always Enable and Bootloader.
Serial Port for Out-of-Band Management/Windows Emergency Management
Services (EMS)
The submenu allows the user to congure Console Redirection settings to support
Out-of-Band Serial Port management.
Console Redirection (for EMS)
Select Enabled to use a COM Port selected by the user for Console Redirection.
The options are Enabled and Disabled.
Console Redirection Settings (for EMS)
This feature allows the user to specify how the host computer will exchange
data with the client computer, which is the remote computer used by the user.
Out-of-Band Management Port
The feature selects a serial port used by the Microsoft Windows Emergency
Management Services (EMS) to communicate with a remote server. The options
are COM1 Console Redirection and COM2/SOL Console Redirection.
Terminal Type
This feature allows the user to select the target terminal emulation type for Con-
sole Redirection. Select VT100 to use the ASCII character set. Select VT100+
to add color and function key support. Select ANSI to use the extended ASCII
Chapter 4: AMI BIOS
4-43
character set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters
into one or more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.
Bits Per Second
This item sets the transmission speed for a serial port used in Console Redirec-
tion. Make sure that the same speed is used in the host computer and the client
computer. A lower transmission speed may be required for long and busy lines.
The options are 9600, 19200, 57600, and 115200 (bits per second).
Flow Control
This feature allows the user to set the ow control for Console Redirection to
prevent data loss caused by buffer overow. Send a "Stop" signal to stop send-
ing data when the receiving buffer is full. Send a "Start" signal to start sending
data when the receiving buffer is empty. The options are None, Hardware RTS/
CTS, and Software Xon/Xoff.
The setting for each these features is displayed:
Data Bits, Parity, Stop Bits
Trusted Computing (Available when a TPM device is detected
by the BIOS)
Conguration
Security Device Support
Select Enabled on this item and enable the TPM jumper on the motherboard to
enable onboard security devices to improve data integrity and network security.
The options are Enabled and Disabled.
TPM (Trusted-Platform Module) State
Select Enabled to enable TPM security settings to improve data integrity and
network security. The options are Disabled and Enabled.
Pending Operation
Use this item to schedule an operation for the security device. The options are None,
Enable Take Ownership, Disable Take Ownership, and TPM Clear.
Note: The computer will reboot in order to execute the pending commands
and change the state of the security device.
Current Status Information: This item displays the information regarding the
current TPM status.
4-44
X10DBT/X10DBT-T User’s Manual
TPM Enable Status
This item displays the status of TPM Support to indicate if TPM is currently
enabled or disabled.
TPM Active Status
This item displays the status of TPM Support to indicate if TPM is currently ac-
tive or deactivated.
TPM Owner Status
This item displays the status of TPM Ownership.
iSCSI Conguration
This item displays iSCSI conguration information:
iSCSI Initiator Name
This item displays the name of the iSCSI Initiator, which is a unique name used
in the world. The name must use IQN format. The following actions can also
be performed:
Add an Attempt
Delete Attempts
Change Attempt Order
Chapter 4: AMI BIOS
4-45
4-4 Event Logs
Select the Event Logs tab to access the following submenu items.
Change SMBIOS Event Log Settings
This feature allows the user to congure SMBIOS Event settings.
Runtime Error Logging Support
Select Enabled to enable runtime error logging upon system boot. The options are
Auto, Enabled, and Disabled.
Enabling/Disabling Options
SMBIOS Event Log
Select Enabled to enable SMBIOS (System Management BIOS) event logging dur-
ing system boot. The options are Enabled and Disabled.
Erasing Settings
Erase Event Log
Select Enabled to erase the SMBIOS (System Management BIOS) event log, which
is completed before a event logging is initialized upon system reboot. The options
are No, Yes, Next reset, and Yes, Every reset.
When Log is Full
Select Erase Immediately to immediately erase SMBIOS error event logs that ex-
ceed the limit when the SMBIOS event log is full. Select Do Nothing for the system
to do nothing when the SMBIOS event log is full. The options are Do Nothing and
Erase Immediately.
4-46
X10DBT/X10DBT-T User’s Manual
SMBIOS Event Log Standard Settings
Log System Boot Event
Select Enabled to log system boot events. The options are Disabled and Enabled.
MECI (Multiple Event Count Increment)
Enter the increment value for the multiple event counter. Enter a number from 1 to
255. The default setting is 1.
METW (Multiple Event Count Time Window)
This item allows the user to decide how long (in minutes) should the multiple event
counter wait before generating a new event log. Enter a number from 0 to 99. The
default setting is 60.
Custom Options
Log OEM Codes
Select Enabled to log the OEM's EFI Status codes that is not in Legacy format. The
options are Enabled and Disabled.
Convert OEM Codes
Select Enabled to convert the OEM's EFI Status codes to standard SMBIOS-
compatible codes. The options are Enabled and Disabled.
Note: Please reboot your system for your changes to take effect.
View SMBIOS Event Log
This item allows the user to view the event in the SMBIOS event log. Select this
item and press <Enter> to view the status of an event in the log. The following
categories are displayed:
Date/Time/Error Code/Severity
Chapter 4: AMI BIOS
4-47
4-5 IPMI
Select the IPMI (Intelligent Platform Management Interface) tab to access the fol-
lowing submenu items.
These items indicates your system IPMI rmware revision number and status.
•IPMI Firmware Revision
•IPMI Status
BMC Network Conguration
Update IPMI LAN Conguration
Select Yes for the AMI BIOS to congure the following IPMI LAN settings. The op-
tions are No and Yes. If the option is set to Yes, the following items will be available
for the user to congure IPMI network settings:
Conguration Address Source (Available when the item above is set to Yes)
This feature allows the user to select the source of the IP address for this computer.
If Static is selected, you will need to know the IP address of this computer and enter
it to the system manually in the eld. If DHCP is selected, the BIOS will search for
a DHCP (Dynamic Host Conguration Protocol) server in the network that is at-
tached to and request the next available IP address for this computer. The options
are DHCP, Unspecied, and Static.
The following items are assigned IP addresses automatically if DHCP is selected,
or can be congured manually if Static is selected.
4-48
X10DBT/X10DBT-T User’s Manual
Station IP Address (Available when the item above is set to Yes)
This item displays the Station IP address for this computer. This should be in decimal
and in dotted quad form (i.e., 192.168.10.253).
Subnet Mask (Available when the item above is set to Yes)
This item displays the sub-network that this computer belongs to. The value of each
three-digit number separated by dots should not exceed 255.
Station MAC Address (Available when the item above is set to Yes)
This item displays the Station MAC address for this computer. Mac addresses are
6 two-digit hexadecimal numbers.
Router IP Address (Available when the item above is set to Yes)
This item displays the Router IP address for this computer. This should be in decimal
and in dotted quad form (i.e., 192.168.10.253).
Router MAC Address
This item displays the Router MAC address for this computer.
Chapter 4: AMI BIOS
4-49
4-6 Security
This menu allows the user to congure the following security settings for the
system.
Administrator Password
Use this item to set the administrator password which is required to enter the
BIOS setup utility. The length of the password should be from 3 characters to 20
characters long.
User Password
Use this item to set a user password which is required to log into the system
and to enter the BIOS setup utility. The length of the password should be from 3
characters to 20 characters long.
Router MAC Address
This item displays the Router MAC address for this computer.
4-50
X10DBT/X10DBT-T User’s Manual
4-7 Boot
This submenu allows the user to congure the following boot settings for the
system.
Password Check
Use this feature to determine when a password entry is required. Select Setup to require the password only when entering setup. Select Always to require the password when entering setup and at each bootup.
The options are Setup and Always.
Boot Sector Virus Protection
When Enabled, the BIOS displays a warning when any program (or virus) issues a Disk Format command or attempts to write to the boot sector of the hard disk drive. The options are Enabled and Disabled.
Boot Mood Select
Use this item to congure boot mood select settings for the machine. The options
are Legacy, UEFI, and Dual.
Fixed Boot Order Priorities
This option prioritizes the order of bootable devices that the system to boot from.
Press [ENTER] on each entry from top to bottom to select devices.
•Boot Order #1 through #15
Delete Boot Option
Use this item to select a boot device to delete from the boot priority list.
Delete Boot Option
Select the target boot device to delete.
Delete Driver Option
Use this item to select a driver to delete from the boot priority list.
Delete Driver Option
Select the target driver to delete.
Chapter 4: AMI BIOS
4-51
Password Check
Use this feature to determine when a password entry is required. Select Setup to require the password only when entering setup. Select Always to require the password when entering setup and at each bootup.
The options are Setup and Always.
Boot Sector Virus Protection
When Enabled, the BIOS displays a warning when any program (or virus) issues a Disk Format command or attempts to write to the boot sector of the hard disk drive. The options are Enabled and Disabled.
Hard Disk Drive BBS Priorities (Available when a device is installed in
this drive)
This item sets the boot sequence of available hard disk drives.
•Boot Order #1
CD/DVD ROM Drive BBS Priorities (Available when a device is installed in
this drive)
•Boot Order #1
USB Hard Disk Drive BBS Priorities (Available when a device is installed
in this drive)
•Boot Order #1
Network Drive BBS Priorities (Available when a device is installed in this
drive)
•Boot Order #1
UEFI Application Boot Priorities (Available when a device is installed in
this drive)
•Boot Order #1
4-52
X10DBT/X10DBT-T User’s Manual
4-8 Save & Exit
This submenu allows the user to congure the Save and Exit settings for the
system.
Save Changes and Exit
When completing the system conguration changes, select this option to save the
changes and exit from the BIOS setup utility. When a dialog box appears, asking
you if you want to save conguration and exit, select Yes to save the changes and
exit from the BIOS setup utility.
Discard Changes and Exit
Select this option to quit the BIOS setup without making any changes to the system
conguration. Select Discard Changes and Exit, and press <Enter>. When the dialog
box appears, asking you if you want to exit the BIOS setup without saving, select
Yes to quit BIOS without saving the changes.
Save Changes and Reset
When completing the system conguration changes, select this option to save the
changes and reboot the computer so that the new system conguration settings
can take effect.
Discard Changes and Reset
When completing the system conguration changes, select this option to discard
the changes made the user and reboot the computer so that the new system con-
guration settings can take effect.
Chapter 4: AMI BIOS
4-53
Save Options
Save Changes
Select this option and press <Enter> to save all changes you've made so far and
return to the AMI BIOS utility. When the dialog box appears, asking you if you want
to save conguration, select Yes to save the changes, or select No to return to the
BIOS without making changes.
Discard Changes
Select this feature and press <Enter> to discard all the changes and return to the
BIOS setup. When the dialog box appears, asking you if you want to load previ-
ous values, select Yes to load the values previous saved, or select No to keep the
changes you've made so far.
Restore Defaults
Select this feature and press <Enter> to load the optimized default settings that
help optimize system performance. When the dialog box appears, asking you if you
want to load the factory defaults, select Yes to load the optimized default settings,
or select No to abandon optimized defaults.
Save as User Defaults
Select this feature and press <Enter> to save the current settings as the user's
defaults. When the dialog box appears, asking you if you want to save values as
user's defaults, select Yes to save the current values as user's default settings, or
select No to keep the defaults previously saved as the user's defaults.
Restore User Defaults
Select this feature and press <Enter> to load the user's defaults previously saved in
the system. When the dialog box appears, asking you if you want to restore user's
defaults, select Yes to restore the user's defaults previously saved in the system,
or select No to abandon the user's defaults that were previously saved.
Boot Override
This feature allows the user to override the Boot Option Priority sequence set in
the Boot menu, and boot the system with one of the listed devices instead. This is
a one-time override.
4-54
X10DBT/X10DBT-T User’s Manual
Notes
A-1
Appendix A: BIOS POST Error Codes
Appendix A
BIOS Error Beep Codes
During the POST (Power-On Self-Test) routines, which are performed at each
system boot, errors may occur.
Non-fatal errors are those which, in most cases, allow the system to continue to
boot. The error messages normally appear on the screen.
Fatal errors will not allow the system to continue with bootup procedure. If a fatal
error occurs, you should consult with your system manufacturer for possible repairs.
These fatal errors are usually communicated through a series of audible beeps.
The numbers on the fatal error list correspond to the number of beeps for the cor-
responding error.
A-1 BIOS Error Beep Codes
X9 Motherboard BIOS Error Beep Codes
Beep Code/LED Error Message Description
1 beep Refresh Ready to boot
5 short beeps + 1 long beep Memory error No memory detected in the system
5 beeps No Con-In or No Con-
Out devices
Con-In includes USB or PS/2 key-
board, PCI or Serial Console Redirec-
tion, IPMI KVM or SOL.
Con-Out includes Video Controller,
PCI or Serial Console Redirection,
IPMI SOL.
1 beep per device Refresh 1 beep or each USB device detected
X9 IPMI Error Codes
1 Continuous Beep System OH System Overheat
A-2
X10DBT/X10DBT-T Motherboard User’s Manual
Notes
Appendix B: Software Installation Instructions
B-1
Appendix B
Software Installation Instructions
B-1 Installing Software Programs
The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp.
supermicro.com. Some of these must be installed, such as the chipset driver.
After accessing the ftp site, go into the CDR_Images directory and locate the ISO
le for your motherboard. Download this le to create a CD/DVD of the drivers and
utilities it contains. (You may also use a utility to extract the ISO le if preferred.)
Another option is to go to the Supermicro Website at http://www.supermicro.com/
products/. Find the product page for your motherboard here, where you may down-
load individual drivers and utilities.
After creating a CD/DVD with the ISO les, insert the disk into the CD/DVD drive
on your system and the display shown below should appear.
Note 1: Click the icons showing a hand writing on paper to view the
readme les for each item. Click the computer icons to the right of these
items to install each item (from top to the bottom) one at a time. After
installing each item, you must re-boot the system before moving on
to the next item on the list. The bottom icon with a CD on it allows you
to view the entire contents.
Note 2: When making a storage driver diskette by booting into a Driver
CD, please set the SATA Conguration to "Compatible Mode" and congure
SATA as IDE in the BIOS Setup. After making the driver diskette, be sure
to change the SATA settings back to your original settings.
Driver/Tool Installation Display Screen
B-2
X10DBT/X10DBT-T Motherboard User’s Manual
B-2 Conguring SuperDoctor 5
The Supermicro SuperDoctor 5 is a hardware monitoring program that functions in
a command-line or web-based interface in Windows and Linux operating systems.
The program monitors system health information such as CPU temperature, system
voltages, system power consumption, fan speed, and provides alerts via email or
Simple Network Management Protocol (SNMP).
SuperDoctor 5 comes in local and remote management versions and can be used
with Nagios to maximize your system monitoring needs. With SuperDoctor 5 Man-
agement Server (SSM Server), you can remotely control power on/off and reset
chassis intrusion for multiple systems with SuperDoctor 5 or IPMI. SD5 Manage-
ment Server monitors HTTP, FTP, and SMTP services to optimize the efciency of
your operation.
Note: The default User Name and Password for SuperDoctor 5 is admin/
admin.
Note: The SuperDoctor 5 program and User’s Manual can be downloaded
from the Supermicro web site at http://www.supermicro.com/products/nfo/
sms_sd5.cfm. For Linux, we recommend that you use the SuperDoctor II
application instead.
Appendix C: UEFI BIOS Recovery
C-1
Appendix C
UEFI BIOS Recovery Instructions
Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue.
Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall
Supermicro be liable for direct, indirect, special, incidental, or consequential damages
arising from a BIOS update. If you need to update the BIOS, do not shut down or reset
the system while the BIOS is updating to avoid possible boot failure.
C-1 An Overview to the UEFI BIOS
The Unied Extensible Firmware Interface (UEFI) specication provides a software-
based interface between the operating system and the platform rmware in the
pre-boot environment. The UEFI specication supports an architecture-independent
mechanism for add-on card initialization to allow the UEFI OS loader, which is stored
in the add-on card, to boot up the system. UEFI offers a clean, hands-off control
to a computer system at bootup.
C-2 How to Recover the UEFI BIOS Image (-the Main
BIOS Block)
A UEF BIOS ash chip consists of a recovery BIOS block, comprised of two boot
blocks and a main BIOS block (a main BIOS image). The boot block contains critical
BIOS codes, including memory detection and recovery codes for the user to ash
a new BIOS image if the original main BIOS image is corrupted. When the system
power is on, the boot block codes execute rst. Once that is completed, the main
BIOS code will continue with system initialization and bootup.
Note: Follow the BIOS Recovery instructions below for BIOS recovery
when the main BIOS boot crashes. However, when the BIOS boot block
crashes, you will need to follow the procedures in Appendix D.
C-3 To Recover the Main BIOS Block Using a USB-
Attached Device
This feature allows the user to recover a BIOS image using a USB-attached device
without additional utilities used. A USB ash device such as a USB Flash Drive, or
a USB CD/DVD ROM/RW device can be used for this purpose. However, a USB
Hard Disk drive cannot be used for BIOS recovery at this time.
C-2
X10DBT/X10DBT-T Motherboard User’s Manual
5. When the screen as shown above displays, using the arrow key, select the
item- "Proceed with ash update" and press the <Enter> key. You will see the
progress of BIOS Recovery as shown in the screen below.
Note: Do not interrupt the process of BIOS ashing until it is com-
pleted.
To perform UEFI BIOS recovery using a USB-attached device, follow the instruc-
tions below.
1. Using a different machine, copy the "Super.ROM" binary image le into the
disc Root "\" Directory of a USB device or a writeable CD/DVD.
Note: If you cannot locate the "Super.ROM" le in your driver disk, visit
our website at www.supermicro.com to download the BIOS image into
a USB ash device and rename it "Super ROM" for BIOS recovery use.
2. Insert the USB device that contains the new BIOS image ("Super.ROM") into
your USB drive and power on the system
3. While powering on the system, keep pressing <Ctrl> and <Home> simultane-
ously on your keyboard until your hear two short beeps. This may take from a
few seconds to one minute.
4. After locating the new BIOS binary image, the system will enter the BIOS
Recovery menu as shown below.
Note: At this point, you may decide if you want to start with BIOS Recov-
ery. If you decide to proceed with BIOS Recovery, follow the procedures
below.
Appendix C: UEFI BIOS Recovery
C-3
6. After the process of BIOS Recovery is complete, press any key to reboot the
system.
7. Using a different system, extract the BIOS package into a bootable USB ash
drive.
8. When a DOS prompt appears, enter AMI.BAT BIOSname.### at the prompt.
Note: Do not interrupt this process until BIOS ashing is completed.
C-4
X10DBT/X10DBT-T Motherboard User’s Manual
9. After seeing the message that BIOS update is completed, unplug the AC pow-
er cable from the power supply to clear CMOS, and then plug the AC power
cable in the power supply again to power on the system.
10. Press <Del> continuously to enter the BIOS Setup utility.
11. Press <F3> to load default settings.
12. After loading default settings, press <F4> to save the settings and exit the
BIOS Setup utility.
(Disclaimer Continued)
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices,
aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products for use in such ultra-hazardous applications, it does so
entirely at its own risk. Furthermore, buyer agrees to fully indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
