Analysis Data Model (ADaM) Implementation Guide
Introduction
Fundamentals of the ADaM Standard
Standard ADaM Variables
- ADSL Variables
- ADaM Basic Data Structure (BDS) Variables
Implementation Issues, Standard Solutions, and Examples
Appendices
- Abbreviations and Acronyms
- Representations And Warranties; Limitations of Liability, And Disclaimers

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Analysis Data Model (ADaM)

Implementation Guide

Prepared by the

CDISC Analysis Data Model Team

Notes to Readers

This Implementation Guide is Version 1.0 (V1.0) and corresponds to Version 2.1 of the CDISC Analysis Data

Model.

Revision History

Date

Version

Summary of Changes

Dec. 17, 2009

1.0 Final

Released version reflecting all changes and corrections identified during comment

period.

May 30, 2008

1.0 Draft

Draft for Public Comment

Note: Please see Appendix B for Representations and Warranties; Limitations of Liability, and Disclaimers.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Contents

Analysis Data Model (ADaM) ....................................................................................................................................... 1

Implementation Guide ................................................................................................................................................... 1

Prepared by the .............................................................................................................................................................. 1

CDISC Analysis Data Model Team ............................................................................................................................... 1

Revision History ............................................................................................................................................................ 1

1 Introduction .......................................................................................................................................................... 4

1.1 Purpose ....................................................................................................................................................... 4

1.2 Background................................................................................................................................................. 4

1.3 What is Covered in the ADaMIG ............................................................................................................... 4

1.4 Organization of this Document ................................................................................................................... 5

1.5 Definitions .................................................................................................................................................. 5

1.5.1 General ADaM Definitions .................................................................................................................... 5

1.5.2 Basic Data Structure Definitions............................................................................................................ 6

2 Fundamentals of the ADaM Standard .................................................................................................................. 7

2.1 Fundamental Principles .............................................................................................................................. 7

2.2 Traceability ................................................................................................................................................. 7

2.3 The ADaM Data Structures ........................................................................................................................ 8

2.3.1 The ADaM Subject-Level Analysis Dataset ADSL ............................................................................... 8

2.3.2 The ADaM Basic Data Structure (BDS) ................................................................................................ 9

3 Standard ADaM Variables .................................................................................................................................. 10

3.1 ADSL Variables ........................................................................................................................................ 14

3.2 ADaM Basic Data Structure (BDS) Variables .......................................................................................... 20

3.2.1 Subject Identifier Variables for BDS Datasets ..................................................................................... 20

3.2.2 Treatment Variables for BDS Datasets................................................................................................. 21

3.2.3 Timing Variables for BDS Datasets ..................................................................................................... 22

3.2.4 Analysis Parameter Variables for BDS Datasets .................................................................................. 27

3.2.5 Analysis Descriptor Variables for BDS Datasets ................................................................................. 30

3.2.6 Indicator Variables for BDS Datasets .................................................................................................. 33

3.2.7 Differences Between SDTM and ADaM Population and Baseline Flags ............................................ 37

3.2.8 Other Variables .................................................................................................................................... 38

4 Implementation Issues, Standard Solutions, and Examples ............................................................................... 39

4.1 Examples of Treatment Variables for Common Trial Designs.................................................................. 40

4.2 Creation of Derived Columns Versus Creation of Derived Rows ............................................................. 42

4.2.1 Rules for the Creation of Rows and Columns ...................................................................................... 42

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.3 Inclusion of All Observed and Derived Records for a Parameter Versus the Subset of Records Used for

Analysis 56

4.3.1 ADaM Methodology and Examples .................................................................................................... 56

4.4 Inclusion of Input Data that are not Analyzed but that Support a Derivation in the Analysis Dataset ..... 60

4.4.1 ADaM Methodology and Examples .................................................................................................... 60

4.5 Identification of Rows Used for Analysis ................................................................................................. 65

4.5.1 Identification of Rows Used in a Timepoint Imputation Analysis ....................................................... 65

4.5.2 Identification of Baseline Rows ........................................................................................................... 67

4.5.3 Identification of Post-Baseline Conceptual Timepoint Rows .............................................................. 69

4.5.4 Identification of Rows Used for Analysis – General Case ................................................................... 71

4.6 Identification of Population-Specific Analyzed Rows .............................................................................. 74

4.6.1 ADaM Methodology and Examples .................................................................................................... 74

4.7 Identification of Rows Which Satisfy a Predefined Criterion for Analysis Purposes ............................... 76

4.7.1 ADaM Methodology and Examples .................................................................................................... 76

4.8 Other Issues to Consider ........................................................................................................................... 79

4.8.1 Adding Records to Create a Full Complement of Analysis Timepoints for Every Subject ................. 79

4.8.2 Creating Multiple Datasets to Support Analysis of the Same Type of Data......................................... 79

Appendices .................................................................................................................................................................. 80

Appendix A References and Abbreviations ......................................................................................................... 80

Appendix B Representations And Warranties; Limitations of Liability, And Disclaimers .................................. 81

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

1 Introduction

1.1 Purpose

This document comprises the Clinical Data Interchange Standards Consortium (CDISC) Version 1.0 Analysis Data

Model Implementation Guide (ADaMIG), which has been prepared by the Analysis Data Model (ADaM) team of

CDISC. The ADaMIG specifies ADaM standard dataset structures and variables, including naming conventions. It

also specifies standard solutions to implementation issues.

The ADaMIG must be used in close concert with the current version of the Analysis Data Model document (ADaM

document) which is available for download at http://www.cdisc.org/adam. The ADaM document explains the

purpose of the Analysis Data Model. It describes fundamental principles that apply to all analysis datasets, with the

driving principle being that the design of analysis datasets and associated metadata facilitate explicit communication

of the content of, input to, and purpose of submitted analysis datasets. The Analysis Data Model supports efficient

generation, replication, and review of analysis results.

1.2 Background

The user of the ADaMIG must be familiar with the CDISC Study Data Tabulation Model (SDTM) and the Study

Data Tabulation Model Implementation Guide (SDTMIG), both of which are available at http://www.cdisc.org/sdtm,

since SDTM is the source for ADaM data.

Both the SDTM and ADaM standards were designed to support submission by a sponsor to a regulatory agency such

as the United States Food and Drug Administration (FDA). Since inception, the CDISC ADaM team has been

encouraged and informed by FDA statistical and medical reviewers who participate in ADaM meetings as observers,

and who have participated in CDISC-FDA pilots. The origin of the fundamental principles of ADaM is the need for

transparency of communication with and scientifically valid review by regulatory agencies. The ADaM standard has

been developed to meet the needs of the FDA and industry. ADaM is applicable to a wide range of drug

development activities in addition to FDA regulatory submissions. It provides a standard for transferring datasets

between sponsors and contract research organizations (CROs), development partners, and independent data

monitoring committees. As adoption of the model becomes more widespread, in–licensing, out–licensing and

mergers are facilitated through the use of a common model for analysis data and metadata across sponsors.

1.3 What is Covered in the ADaMIG

This document describes two ADaM standard data structures: the subject-level analysis dataset (ADSL) and the

Basic Data Structure (BDS).

The ADSL dataset contains one record per subject. It contains variables such as subject-level population flags,

planned and actual treatment variables for each period, demographic information, stratification and subgrouping

variables, important dates, etc. ADSL contains required variables (as specified in this document) plus other subject-

level variables that are important in describing a subject’s experience in the trial. ADSL and its related metadata are

required in a CDISC-based submission of data from a clinical trial even if no other analysis datasets are submitted.

A BDS dataset contains one or more records per subject, per analysis parameter, per analysis timepoint. Analysis

timepoint is not required; it is dependent on the analysis. In situations where there is no analysis timepoint, the

structure is one or more records per subject per analysis parameter. This structure contains a central set of variables

that represent the actual data being analyzed. The BDS supports parametric and nonparametric analyses such as

analysis of variance (ANOVA), analysis of covariance (ANCOVA), categorical analysis, logistic regression,

Cochran-Mantel-Haenszel, Wilcoxon rank-sum, time-to-event analysis, etc.

Though the BDS supports most statistical analyses, it does not support all statistical analyses. For example, it does

not support simultaneous analysis of multiple dependent (response/outcome) variables or a correlation analysis

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

across a range of response variables. The BDS was not designed to support analysis of incidence of adverse events

or other occurrence data.

This version of the implementation guide does not fully cover dose escalation trials or integration of multiple

studies.

Future Developments

The ADaM team is working on several additional documents:

A specification document for an ADAE dataset supporting analysis of incidence of adverse events. ADAE may

be the first example of a more general structure supporting analysis of incidence data, such as concomitant

medications, medical history, etc.

A document that provides detailed specifications for and examples of applying the BDS to time-to-event

analysis.

A document that contains examples with data and metadata using the BDS for analyses such as analysis of

covariance.

A document that provides a detailed description of the ADaM metadata model and its implementation.

A document defining ADaM compliance.

It is expected that most or all of these documents will ultimately be incorporated into future releases of the ADaM

document and the ADaM Implementation Guide.

Integration of multiple studies will also be addressed in a future release of the documents.

1.4 Organization of this Document

This document is organized into the following sections:

Section 1 provides an overall introduction to the importance of the ADaM standards and how they relate to

other CDISC data standards.

Section 2 provides a review of the fundamental principles that apply to all ADaM datasets and introduces two

standard structures that are flexible enough to represent the great majority of analysis situations. Categories of

analysis variables are defined and criteria that are deemed important to users of analysis datasets are presented.

Section 3 defines standard variables for analysis variables that commonly will be used in the ADaM standard

data structures.

Section 4 presents standard solutions for BDS implementation issues, illustrated with examples.

1.5 Definitions

1.5.1 General ADaM Definitions

Analysis-enabling – Required for analysis. A column or row is analysis-enabling if it is required to perform the

analysis. Examples: the hypertension category column was added to the analysis dataset in order to enable

subgroup analysis, a covariate age was added in order to enable for the analysis to be age-adjusted, a

stratification factor for center was added in multicenter studies.

Traceability – The property that enables the understanding of the data’s lineage and/or the relationship between

an element and its predecessor(s). Traceability facilitates transparency, which is an essential component in

building confidence in a result or conclusion. Ultimately traceability in ADaM permits the understanding

of the relationship between the analysis results, the analysis datasets, and the SDTM domains. Traceability

is built by clearly establishing the path between an element and its immediate predecessor. The full path is

traced by going from one element to its predecessors, then on to their predecessors, and so on, back to the

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

SDTM domains, and ultimately to the data collection instrument. Note that the CDISC Clinical Data

Acquisition Standards Harmonization (CDASH) standard is harmonized with SDTM and therefore assists

in assuring end-to-end traceability.

Supportive – Enabling traceability. A column or row is supportive if it is not required in order to perform an

analysis but is included in order to facilitate traceability. Example: the LBSEQ and VISIT columns were

carried over from SDTM in order to promote understanding of how the analysis dataset rows related to the

study tabulation dataset.

Record – A row in a dataset.

Variable – A column in a dataset.

1.5.2 Basic Data Structure Definitions

Analysis parameter – A row identifier used to uniquely characterize a group of values that share a common

definition. Note that the ADaM analysis parameter contains all of the information needed to uniquely

identify a group of related analysis values. In contrast, the SDTM --TEST column may need to be

combined with qualifier columns such as --POS, --LOC, --SPEC, etc., in order to identify a group of related

values. Example: The primary efficacy analysis parameter is “3-Minute Sitting Systolic Blood Pressure

(mm Hg).” In this document the word “parameter” is used as a synonym for “analysis parameter.”

Analysis timepoint – A row identifier used to classify values within an analysis parameter into temporal or

conceptual groups used for analyses. These groupings may be observed, planned or derived. Example:

The primary efficacy analysis was performed at the Week 2, Week 6, and Endpoint analysis timepoints.

Analysis value – (1) The character (AVALC) or numeric (AVAL) value described by the analysis parameter.

The analysis value may be present in the input data, a categorization of an input data value, or derived.

Example: The analysis value of the parameter “Average Heart Rate (bpm)” was derived as the average of

the three heart rate values measured at each visit. (2) In addition, values of certain functions are considered

to be analysis values. Examples: baseline value (BASE), change from baseline (CHG).

Parameter-invariant – A derived column is parameter-invariant if, whenever it is populated within an analysis

dataset, it is always calculated the same way within the analysis dataset. For example, whenever CHG is

populated, it is always calculated as AVAL - BASE, regardless of the parameter. However CHG may be

left null where it does not apply, for example for a time-to-event parameter, or if CHG isn’t calculated for

pre-baseline rows. The property of parameter invariance applies only to analysis variables (columns) that

are functions of AVAL. The purpose of defining parameter invariance is to apply the concept in the rules in

Section 4.2 that help to define the BDS.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

2 Fundamentals of the ADaM

Standard

2.1 Fundamental Principles

Analysis datasets must adhere to certain fundamental principles as described in the Analysis Data Model document:

Analysis datasets and associated metadata must clearly and unambiguously communicate the content and source

of the datasets supporting the statistical analyses performed in a clinical study.

Analysis datasets and associated metadata must provide traceability to allow an understanding of where an

analysis value (whether an analysis result or an analysis variable) came from, i.e., the data’s lineage or

relationship between an analysis value and its predecessor(s). The metadata must also identify when analysis

data have been derived or imputed.

Analysis datasets must be readily usable with commonly available software tools.

Analysis datasets must be associated with metadata to facilitate clear and unambiguous communication. Ideally

the metadata are machine-readable.

Analysis datasets should have a structure and content that allow statistical analyses to be performed with

minimal programming. Such datasets are described as “analysis-ready.” Note that within the context of ADaM,

analysis datasets contain the data needed for the review and re-creation of specific statistical analyses. It is not

necessary to collate data into “analysis-ready” datasets solely to support data listings or other non-analytical

displays.

Refer to the ADaM document at www.cdisc.org for more details.

2.2 Traceability

To assist review, analysis datasets and metadata must clearly communicate how the analysis datasets were created.

This requirement implies that the user of the analysis dataset must have at hand the input data used to create the

analysis dataset in order to be able to verify derivations. A CDISC-compliant submission includes both SDTM and

ADaM datasets; therefore, it follows that the relationship between SDTM and ADaM must be clear. This highlights

the -importance of traceability between the input data (SDTM) and the analyzed data (ADaM).

Traceability is built by clearly establishing the path between an element and its immediate predecessor. The full

path is traced by going from one element to its predecessors, then on to their predecessors, and so on, back to the

SDTM domains, and ultimately to the data collection instrument. Note that the CDISC Clinical Data Acquisition

Standards Harmonization (CDASH) standard is harmonized with SDTM and therefore assists in assuring end-to-end

traceability. Traceability establishes across-dataset relationships as well as within-dataset relationships. For

example, the metadata for flags and other supportive variables within the analysis dataset enables the user to

understand how (and perhaps why) derived records were created.

There are two levels of traceability:

Metadata traceability enables the user to understand the relationship of the analysis variable to its source

dataset(s) and variable(s) and is required for ADaM compliance. This traceability is established by describing

(via metadata) the algorithm used or steps taken to derive or populate an analysis value from its immediate

predecessor. Metadata traceability is also used to establish the relationship between an analysis result and

analysis dataset(s).

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Data point traceability enables the user to go directly to the specific predecessor record(s) and should be

implemented if practically feasible. This level of traceability can be very helpful when a reviewer is trying to

trace a complex data manipulation path. This traceability is established by providing clear links in the data

(e.g., use of --SEQ variable) to the specific data values used as input for an analysis value.

It may not always be practical or feasible to provide data-point traceability via record-identifier variables from the

source dataset(s). However metadata traceability must always clearly explain how an analysis value was populated

regardless of whether data-point traceability is also provided.

Very complex derivations may require the creation of intermediate analysis datasets. In these situations, traceability

may be accomplished by submitting those intermediate analysis datasets along with their associated metadata.

Traceability would then involve several steps. The analysis results would be linked by appropriate metadata to the

data which supports the analytical procedure; those data would be linked to the intermediate analysis data; the

intermediate data would in turn be linked to the source SDTM data.

When traceability is successfully implemented, reviewers are able to identify:

information that exists in the submitted SDTM study tabulation data

information that is derived or imputed within the ADaM analysis dataset

the method used to create derived or imputed data

information used for analyses, in contrast to information that is not used for analyses yet is included to support

traceability or future analysis

2.3 The ADaM Data Structures

A fundamental principle of analysis datasets is clear communication. Given that analysis datasets contain both

source and derived data, a central issue becomes communicating how the variables and observations were derived

and how observations are used to produce analysis results. The user of an analysis dataset must be able to identify

clearly the data inputs and the algorithms used to create the derived information. If this information is

communicated in a predictable manner through the use of a standard data structure and metadata, the user of an

analysis dataset should be able to understand how to appropriately use the analysis dataset to replicate results or to

explore alternative analyses.

Many types of statistical analyses do not require a specialized structure. In other words, the structure of an analysis

dataset does not necessarily limit the type of analysis that can be done, nor should it limit the communication about

the dataset itself. Instead, if a predictable structure can be used for the majority of analysis datasets, communication

should be enhanced.

A predictable structure has other advantages in addition to supporting clear communication to the user of the

analysis dataset. First, a predictable structure eases the burden of the management of dataset metadata because there

is less variability in the types of observations and variables that are included. Second, software tools can be

developed to support metadata management and data review, including tools to restructure the data (e.g.,

transposing) based on known key variables. Finally, a predictable structure allows an analysis dataset to be checked

for conformance with ADaM standards, using a set of known conventions which can be verified.

As described in Section 1, the ADaMIG describes two ADaM standard data structures: the subject-level analysis

dataset (ADSL) and the Basic Data Structure (BDS). Standard ADaM variables are described in Section 3.

Implementation issues, solutions, and examples are presented in Section 4. Together, Sections 3 and 4 fully specify

the standard data structures.

2.3.1 The ADaM Subject-Level Analysis Dataset ADSL

ADSL contains one record per subject, regardless of the type of clinical trial design. ADSL is used to provide the

variables that describe attributes of a subject. This allows simple combining with any other dataset, including

SDTM domains and analysis datasets. ADSL is a source for subject-level variables used in other analysis datasets,

such as population flags and treatment variables. There is only one ADSL per study. ADSL and its related metadata

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

are required in a CDISC-based submission of data from a clinical trial even if no other analysis datasets are

submitted.

Although it would be technically feasible to take every single data value in a study and include them all as variables

in a subject-level dataset, such as ADSL, that is not the intent or the purpose of ADSL. The correct location for key

endpoints and data that vary over time during the course of a study is in a BDS dataset.

2.3.2 The ADaM Basic Data Structure (BDS)

A BDS dataset contains one or more records per subject, per analysis parameter, per analysis timepoint. Analysis

timepoint is conditionally required, depending on the analysis. In situations where there is no analysis timepoint, the

structure is one or more records per subject per analysis parameter. This structure contains a central set of variables

that represent the data being analyzed. These variables include the value being analyzed (e.g., AVAL) and the

description of the value being analyzed (e.g., PARAM). Other variables in the dataset provide more information

about the value being analyzed (e.g., the subject identification) or describe and trace the derivation of it (e.g.,

DTYPE) or support the analysis of it (e.g., treatment variables, covariates).

Readers are cautioned that ADaM dataset structures do not have counterparts in SDTM. Because the BDS tends

toward a vertical design, some might perceive it as similar to the SDTM findings class. However, BDS datasets may

be derived from findings, events, interventions and special-purpose SDTM domains, other ADaM datasets, or any

combination thereof. Furthermore, in contrast to SDTM findings class datasets, BDS datasets provide robust and

flexible support for the performance and review of most statistical analyses.

A record in an analysis dataset can represent an observed, derived, or imputed value required for analysis. For

example, it may be a time to an event, such as the time to when a score became greater than a threshold value or the

time to discontinuation, or it may be a highly derived quantity such as a surrogate for tumor growth rate derived by

fitting a regression model to laboratory data. A data value may be derived from any combination of SDTM and/or

ADaM datasets.

The BDS is flexible in that additional rows and columns can be added to support the analyses and provide

traceability, according to the rules described in Section 4.2. However, it should be stressed that in a study there is

often more than one analysis dataset that follows the BDS. The capability of adding rows and columns does not

mean that everything should be forced into a single analysis dataset. The optimum number of analysis datasets

should be designed for a study, as discussed in the ADaM document.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3 Standard ADaM Variables

This section defines the required characteristics of standard variables (columns) that are frequently needed in analysis datasets. The ADaM standard requires that

these variable names be used when a variable that contains the content defined in Section 3 is included in an analysis dataset.

Section 3.1 describes variables in ADSL. Section 3.2 describes variables in the BDS.

In this section, ADaM variables are described in tabular format. The two rightmost columns, “Core” and “CDISC Notes” provide information about the variables

to assist users in preparing their datasets. These columns are not meant to be metadata submitted in define.xml. The “Core” column describes whether a variable

is required, conditionally required, or permissible. The “CDISC Notes” column provides more information about the variable. In addition, the “Type” column is

being used to define whether the variable being described is character or numeric. More specific information will be provided in metadata (e.g., text, integer,

float).

Values of ADaM “Core” Attribute

Req = Required. The variable must be included in the dataset.

Cond = Conditionally required. The variable must be included in the dataset in certain circumstances.

Perm = Permissible. The variable may be included in the dataset, but is not required.

Unless otherwise specified, all ADaM variables are populated as appropriate, meaning nulls are allowed.

General Variable Naming Conventions

1. In a pair of corresponding variables (e.g., TRTP and TRTPN, AVAL and AVALC), the primary or most commonly used variable does not have the suffix or

extension (e.g., N for Numeric or C for Character).

2. The names of date imputation flag variables end in DTF, and the names of time imputation flag variables end in TMF.

3. The names of all other character flag (or indicator) variables end in FL, and the names of the corresponding numeric flag (or indicator) variables end in FN

If the flag is used, the character version (*FL) is required but the numeric version (*FN) can also be included.

4. Any ADaM variable whose name is the same as an SDTM variable must be a copy of the SDTM variable, and its label, meaning, and values must not be

modified. ADaM adheres to a principle of harmonization known as “same name, same meaning, same values.”

5. To ensure compliance with SAS Transport file and Oracle constraints, all ADaM variable names must be no more than 8 characters in length, start with a

letter (not underscore), and be comprised only of letters (A-Z), underscore (_), and numerals (0-9). All ADaM variable labels must be no more than 40

characters in length. All ADaM character variables must be no more than 200 characters in length.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

6. In Section 3, an asterisk (*) is sometimes used as a variable name prefix or suffix. The asterisk that appears in a variable name must be replaced by a

suitable character string, so that the actual variable name is meaningful and complies with the above restrictions.

7. The lower case letters “xx”, “y”, and “zz” that appear in a variable name or label must be replaced in the actual variable name or label using the

following conventions. The letters “xx” in a variable name (e.g., TRTxxP, APxxSDT) refer to a specific period where “xx” is replaced with a zero-padded

two-digit integer [01-99]. The lower case letter “y” in a variable name (e.g., SITEGRy) refers to a grouping or other categorization, an analysis criterion, or

an analysis range, and is replaced with a single digit [1-9]. The lower case letter “zz” in a variable name (i.e., ANLzzFL) is an index for the zzth record

selection algorithm where “zz” is replaced with a zero-padded two-digit integer [01-99].

8. Variables whose names end in GRy are grouping variables, where y refers to the grouping scheme or algorithm (not the category within the grouping). For

example, SITEGR3 is the name of a variable containing site group (pooled site) names, where the grouping has been done according to the third site

grouping algorithm; SITEGR3 does not mean the third group of sites.

9. In general, if SDTM character variables are converted to numeric variables in ADaM datasets, then they should be named as they are in the SDTM with an

“N” suffix added. For example, the numeric version of the DM SEX variable is SEXN in an ADaM dataset, and a numeric version of RACE is RACEN. If

necessary to keep within the 8-character variable name length limit, the last character may be removed prior to appending the N. Note that this naming

scheme applies only to numeric variables whose values map one-to-one to the values of the equivalent character variables. Note also that this convention

does not apply to date/time variables.

10. If any combining of the SDTM character categories is done, the name of the derived ADaM character grouping variable should end in GRy and the name of

its numeric equivalent should end in GRyN where y is an integer from 1-9 representing a grouping scheme. For example, if a character analysis variable is

created to contain values of Caucasian and Non-Caucasian from the SDTM RACE variable that has 5 categories, then it should be named RACEGRy and its

numeric equivalent should be named RACEGRyN (e.g., RACEGR1, RACEGR1N). Truncation of the original variable name may be necessary when

appending suffix fragments GRy, or GRyN.

General Timing Variable Conventions

1. Numeric dates, times and datetimes should be formatted, so as to be human readable with no loss of precision. The anchor or reference day that all other

dates are numbered from should be clearly identified in the metadata.

2. Variables whose names end in DT are numeric dates.

3. Variables whose names end in DTM are numeric datetimes.

4. Variables whose names end in TM are numeric times.

5. If a *DTM and associated *TM variable exist, then the *TM variable must match the time part of the *DTM variable. If a *DTM and associated *DT

variable exist, then the *DT variable must match the date part of the *DTM variable.

6. Variables whose names end in DTF are date imputation flags. *DTF variables represent the level of imputation of the *DT variable based on the source

SDTM DTC variable. *DTF = Y if the entire date is imputed. *DTF = M if month and day are imputed. *DTF = D if only day is imputed. *DTF = null if

*DT equals the SDTM DTC variable date part equivalent. If a date was imputed, *DTF must be populated and is required. Both *DTF and *TMF may be

needed to describe the level of imputation in *DTM if imputation was done.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

7. Variables whose names end in TMF are time imputation flags. *TMF variables represent the level of imputation of the *TM (and *DTM) variable based on

the source SDTM DTC variable. *TMF = H if the entire time is imputed. *TMF = M if minutes and seconds are imputed. *TMF = S if only seconds are

imputed. *TMF = null if *TM equals the SDTM DTC variable time part equivalent. For a given SDTM DTC variable, if only hours and minutes are ever

collected, and seconds are imputed in *DTM as 00, then it is not necessary to set *TMF to “S”. However if seconds are generally collected but are missing

in a given value of the DTC variable and imputed as 00, or if a collected value of seconds is changed in the creation of *DTM, then the difference is

significant and should be qualified in *TMF. If a time was imputed *TMF must be populated and is required. Both *DTF and *TMF may be needed to

describe the level of imputation in *DTM if imputation was done.

8. Variables whose names end in DY are relative day variables. In ADaM as in the SDTM, there is no day 0. If there is a need to create a relative day variable

that includes day 0, then its name must not end in DY. ADaM relative day variables need not be anchored by SDTM RFSTDTC. When SDTM.RFSTDTC

is not the anchor date then the anchor date used must be stored in an ADaM dataset.

9. Names of timing start variables end with an S followed by the two characters indicating the type of timing (e.g., SDT, STM), unless otherwise specified

elsewhere in Section 3.

10. Names of timing end variables end with an E followed by the two characters indicating the type of timing (e.g., EDT, ETM), unless otherwise specified

elsewhere in Section 3.

11. The last section of Table 3.2.3.1 presents standard suffix naming conventions for user-defined supportive variables containing numeric dates, times,

datetimes, and relative days, as well as date and time imputation flags. These conventions are applicable to both ADSL and BDS datasets.

The reader is cautioned that the root or prefix (represented by *) of such user-specified supportive ADaM date/time variable names must be chosen with care,

to prevent unintended conflicts among other such names and standard numeric versions of possible SDTM variable names. In particular, potentially

problematic values for user-defined roots/prefixes (*) include:

One-letter prefixes.

For an example of the problem, if * is Q, then a date *DT would be QDT; however, a starting date *SDT would be QSDT, which would potentially be

confusing if the user intended QSDT to be something other than the numeric date version of the SDTM variable QSDTC.

Two-letter prefixes, except when intentionally chosen to refer explicitly to a specific SDTM domain and its --DTC, --STDTC, and/or --ENDTC

variables.

For an example of an appropriate intentional use of a two letter-prefix, if * is LB, then *DT is LBDT, the numeric date version of SDTM LBDTC.

For an example of the problem, if * is QQ, then a date *DT would be QQDT, which would potentially be confusing if the user intended QQDT to be

something other than the numeric date version of a potential SDTM variable QQDTC.

Three-letter prefixes ending in S or E.

For an example of the problem, if * is QQS, then a date *DT would be QQSDT, which would potentially be confusing if the user intended QQSDT to be

something other than the numeric date version of a potential SDTM variable QQSTDTC.

General Flag Variable Conventions

1. The terms “flag” and “indicator” are synonymous, and “flag variables” are sometimes referred to simply as “flags.”

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

2. Population flags must be included in a dataset if the dataset is analyzed by the given population. At least one population flag is required for datasets used for

analysis. All applicable subject-level population flags must be present in ADSL.

3. Character and numeric subject-level population flag names end in FL and FN, respectively. Similarly, parameter-level population flag names end in PFL

and PFN, and record-level population flag names end in RFL and RFN.

4. For subject-level character population flag variables: N = no (not included in the population), Y = yes (included). Null values are not allowed.

5. For subject-level numeric population flag variables: 0 = no (not included), 1 = yes (included). Null values are not allowed.

6. For parameter-level and record-level character population flag variables: Y = yes (included). Null values are allowed.

7. For parameter-level and record-level numeric population flag variables: 1 = yes (included). Null values are allowed.

8. In addition to the population flag variables defined in Section 3, other population flag variables may be added to ADaM datasets as needed, and must comply

with these conventions.

9. For character flags that are not population flags, a scheme of Y/N/null, or Y/null may be specified. As indicated in Table 3.2.6.1, some common character

flags use the scheme Y/null. Corresponding 1/0/null and 1/null schemes apply to numeric flags that are not population indicators.

10. Additional flags may be added if their names and values comply with these conventions.

Additional Information about Section 3

In general, the variable labels specified in the tables in Section 3 are required. There are only two exceptions to this rule:

(1) descriptive text is allowed at the end of the labels of variables whose names contain indexes “y” or “zz”; and

(2) asterisks (*) and ellipses (...) in specified variable labels should be replaced by the sponsor with appropriate text.

It is important to note that the standard variable labels by no means imply the use of standard derivation algorithms across studies and/or sponsors.

Controlled terminology has been developed for the values of certain ADaM variables. The most current CDISC terminology sets can be accessed via the CDISC

website (www.cdisc.org). In the tables in Section 3, the parenthesized external codelist name appears in the column labeled “Codelist / Controlled Terms” where

relevant. Where examples of controlled terms appear in this document, they should be considered examples only; the official source is the latest CDISC set

available through the website.

Note that CDISC external controlled terminology sets do not permit inclusion of null (absence of a value) in the list of valid terms. However, unless specified in

the definition for a specific variable below, null is allowed.

Additional variables not defined in Section 3 may be necessary to enable the analysis or to support traceability and may therefore be added to ADaM datasets,

providing that they adhere to the ADaM naming conventions and rules as defined in this document.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3.1 ADSL Variables

In the ADaM document, it is noted that one of the requirements of ADaM is that ADSL and its related metadata are required in a CDISC-based submission of

data from a clinical trial even if no other analysis datasets are submitted. The structure of ADSL is one record per subject, regardless of the type of clinical trial

design. ADSL is used to provide the variables that describe attributes of a subject.

This section lists the standard variables that are required to be in every ADSL. Other subject-level variables that are important in describing a subject’s

experience in the trial are also included in ADSL.

Although it would be technically feasible to take every single data value in a study and include them as variables in ADSL, that is not the intent or the purpose of

ADSL. The correct location for data that vary over time during the course of a study is in a BDS dataset. For example, one would not normally include key

endpoint values in ADSL.

Table 3.1.1 ADSL Variables

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

Study Identifiers

STUDYID

Study Identifier

Char

Req

Must be identical to the SDTM variables DM.STUDYID, DM.USUBJID, DM.SUBJID

and DM.SITEID.

USUBJID

Unique Subject

Identifier

Char

Req

SUBJID

Subject Identifier

for the Study

Char

Req

SITEID

Study Site

Identifier

Char

Req

SITEGRy

Pooled Site

Group y

Char

Perm

Character description of a grouping or pooling of clinical sites for analysis purposes. For

example, SITEGR3 is the name of a variable containing site group (pooled site) names,

where the grouping has been done according to the third site grouping algorithm, defined

in variable metadata; SITEGR3 does not mean the third group of sites.

SITEGRyN

Pooled Site

Group y (N)

Num

Perm

The numeric code for SITEGRy. One-to-one map to SITEGRy.

Subject Demographics

AGE

Age

Num

Req

The age of the subject is a required variable in ADSL. If the variable is not a copy of

DM.AGE, then an additional differently named variable must be added.

AGEU

Age Units

Char

(AGEU)

Req

The units for the subject’s age is a required variable in ADSL. If the variable is not a

copy of DM.AGEU, then an additional differently named variable must be added.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.1.1 ADSL Variables

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

SEX

Sex

Char

(SEX)

Req

The sex of the subject is a required variable in ADSL. If the variable is not a copy of

DM.SEX, then an additional differently named variable must be added.

RACE

Race

Char

(RACE)

Req

The race of the subject is a required variable in ADSL. If the variable is not a copy of

DM.RACE, then an additional differently named variable must be added.

RACEGRy

Pooled Race

Group y

Char

Perm

Character description of a grouping or pooling of subject race for analysis purposes.

RACEGRyN

Pooled Race

Group y (N)

Num

Perm

The numeric code for RACEGRy. Orders the grouping or pooling of subject race for

analysis and reporting. One-to-one map to RACEGRy.

Population Indicator(s)

FASFL

Full Analysis Set

Population Flag

Char

Y, N

Cond

A character indicator variable is required for every population that is defined in the

statistical analysis plan. A minimum of one subject-level population flag variable is

required for every clinical trial. Additional population flags may be added. The values

of subject-level population flags cannot be blank. If a flag is used, the corresponding

numeric version (*FN) can also be included.

SAFFL

Safety Population

Flag

Char

Y, N

Cond

ITTFL

Intent-To-Treat

Population Flag

Char

Y, N

Cond

PPROTFL

Per-Protocol

Population Flag

Char

Y, N

Cond

COMPLFL

Completers

Population Flag

Char

Y, N

Cond

RANDFL

Randomized

Population Flag

Char

Y, N

Cond

ENRLFL

Enrolled

Population Flag

Char

Y, N

Cond

Treatment Variables

ARM

Description of

Planned Arm

Char

Req

DM.ARM

TRTxxP

Planned

Treatment for

Period xx

Char

Req

Subject-level identifier that represents the planned treatment for period xx. In a one-

period randomized trial, TRT01P would be the treatment to which the subject was

randomized. TRTxxP might be derived from the SDTM DM variable ARM. At least

TRT01P is required.

TRTxxPN

Planned

Treatment for

Period xx (N)

Num

Perm

The numeric code variable for TRTxxP. One-to-one map to TRTxxP.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.1.1 ADSL Variables

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

TRTxxA

Actual Treatment

for Period xx

Char

Cond

Subject-level identifier that represents the actual treatment for the subject for period xx.

Required when actual treatment does not match planned and there is an analysis of the

data as treated.

TRTxxAN

Actual Treatment

for Period xx (N)

Num

Perm

The numeric code variable for TRTxxA. One-to-one map to TRTxxA.

TRTSEQP

Planned Sequence

of Treatments

Char

Cond

Required when there is a sequence of treatments that are analyzed, for example in a

crossover design. TRTSEQP is not necessarily equal to ARM, for example if ARM

contains elements that are not relevant to analysis of treatments or ARM is not fully

descriptive (e.g., “GROUP 1,” “GROUP 2”). Whenever applicable, TRTSEQP is

required even if identical to ARM.

TRTSEQPN

Planned Sequence

of Treatments (N)

Num

Perm

Numeric version of TRTSEQP. One-to-one map to TRTSEQP.

TRTSEQA

Actual Sequence

of Treatments

Char

Cond

TRTSEQA is required if a situation occurred in the conduct of the trial where a subject

received a sequence of treatments other than what was planned.

TRTSEQAN

Actual Sequence

of Treatments (N)

Num

Perm

Numeric version of TRTSEQA. One-to-one map to TRTSEQA.

TRxxPGy

Planned Pooled

Treatment y for

Period xx

Char

Perm

Planned pooled treatment y for period xx. Useful when planned treatments (TRTxxP) in

the specified period xx are pooled together for analysis according to pooling algorithm y.

For example when in period 2 the first pooling algorithm dictates that all doses of Drug

A (TR02PG1=“All doses of Drug A”) are pooled together for comparison to all doses of

Drug B (TR02PG1=“All doses of Drug B”). Each value of TRTxxP is pooled within at

most one value of TRxxPGy.

TRxxPGyN

Planned Pooled

Trt y for Period

xx (N)

Char

Perm

The numeric code for TRxxPGy. One-to-one map to TRxxPGy.

TRxxAGy

Actual Pooled

Treatment y for

Period xx

Char

Cond

Actual pooled treatment y for period xx. Required when TRxxPGy is present and

TRTxxA is present.

TRxxAGyN

Actual Pooled Trt

y for Period xx

(N)

Char

Perm

The numeric code for TRxxAGy. One-to-one map to TRxxAGy.

Trial Dates

RANDDT

Date of

Randomization

Num

Cond

Required in randomized trials

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.1.1 ADSL Variables

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

TRTSDT

Date of First

Exposure to

Treatment

Num

Cond

Date of first exposure to treatment for a subject in a study. TRTSDT and/or TRTSDTM

are required if there is an investigational product.

TRTSTM

Time of First

Exposure to

Treatment

Num

Perm

Time of first exposure to treatment for a subject in a study.

TRTSDTM

Datetime of First

Exposure to

Treatment

Num

Cond

Datetime of first exposure to treatment for a subject in a study. TRTSDT and/or

TRTSDTM are required if there is an investigational product.

TRTSDTF

Date of First

Exposure Imput.

Flag

Char

(DATEFL)

Cond

The level of imputation of date of first exposure to treatment. See General Timing

Variable Convention #6.

TRTSTMF

Time of First

Exposure Imput.

Flag

Char

(TIMEFL)

Cond

The level of imputation of time of first exposure to treatment. See General Timing

Variable Convention #7.

TRTEDT

Date of Last

Exposure to

Treatment

Num

Cond

Date of last exposure to treatment for a subject in a study. TRTEDT and/or TRTEDTM

are required if there is an investigational product.

TRTETM

Time of Last

Exposure to

Treatment

Num

Perm

Time of last exposure to treatment for a subject in a study.

TRTEDTM

Datetime of Last

Exposure to

Treatment

Num

Cond

Datetime of last exposure to treatment for a subject in a study. TRTEDT and/or

TRTEDTM are required if there is an investigational product.

TRTEDTF

Date of Last

Exposure Imput.

Flag

Char

(DATEFL)

Cond

The level of imputation of date of last exposure to treatment. See General Timing

Variable Convention #6.

TRTETMF

Time of Last

Exposure Imput.

Flag

Char

(TIMEFL)

Cond

The level of imputation of time of last exposure to treatment. See General Timing

Variable Convention #7.

TRxxSDT

Date of First

Exposure in

Period xx

Num

Cond

Date of first exposure to treatment in period xx. TRxxSDT and/or TRxxSDTM is

required in trial designs where multiple treatments are given to the same subject, such as

a crossover design. Also useful in designs where multiple periods exist for the same

treatment (i.e., multiple cycles of the same study treatment).

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.1.1 ADSL Variables

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

TRxxSTM

Time of First

Exposure in

Period xx

Num

Cond

The starting time of exposure in period xx. TRxxSTM and/or TRxxSDTM are required

in trial designs where multiple treatments are given to the same subject, such as a

crossover design, and time is important to the analysis.

TRxxSDTM

Datetime of First

Exposure in

Period xx

Num

Cond

Datetime of first exposure to treatment in period xx. TRxxSDT and/or TRxxSDTM are

required in trial designs where multiple treatments are given to the same subject, such as

a crossover design.

TRxxSDTF

Date 1st Exposure

Period xx Imput.

Flag

Char

(DATEFL)

Cond

The level of imputation of date of first exposure to treatment in period xx. See General

Timing Variable Convention #6.

TRxxSTMF

Time 1st

Exposure Period

xx Imput. Flag

Char

(TIMEFL)

Cond

The level of imputation of time of first exposure in period xx. See General Timing

Variable Convention #7.

TRxxEDT

Date of Last

Exposure in

Period xx

Num

Cond

Date of last exposure in period xx. TRxxEDT and/or TRxxEDTM are required in trial

designs where multiple treatments are given to the same subject, such as a crossover

design.

TRxxETM

Time of Last

Exposure in

Period xx

Num

Cond

The ending time of exposure in period xx. TRxxETM and/or TRxxEDTM are required

in trial designs where multiple treatments are given to the same subject, such as a

crossover design, and ending time is important to the analysis.

TRxxEDTM

Datetime of Last

Exposure in

Period xx

Num

Cond

The datetime of last exposure to treatment in period xx. TRxxEDT and/or TRxxEDTM

are required in trial designs where multiple treatments are given to the same subject, such

as a crossover design.

TRxxEDTF

Date Last

Exposure Period

xx Imput. Flag

Char

(DATEFL)

Cond

The level of imputation of date of last exposure in period xx. See General Timing

Variable Convention #6.

TRxxETMF

Time Last

Exposure Period

xx Imput. Flag

Char

(TIMEFL)

Cond

The level of imputation of time of last exposure in period xx. See General Timing

Variable Convention #7.

APxxSDT

Period xx Start

Date

Num

Perm

The starting date of period xx.

APxxSTM

Period xx Start

Time

Num

Perm

The starting time of period xx.

APxxSDTM

Period xx Start

Datetime

Num

Perm

The starting datetime of period xx.

APxxSDTF

Period xx Start

Date Imput. Flag

Char

(DATEFL)

Cond

The level of imputation of period xx start date. See General Timing Variable Convention

#6.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.1.1 ADSL Variables

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

APxxSTMF

Period xx Start

Time Imput. Flag

Char

(TIMEFL)

Cond

The level of imputation of period xx start time. See General Timing Variable Convention

#7.

APxxEDT

Period xx End

Date

Num

Perm

The ending date of period xx.

APxxETM

Period xx End

Time

Num

Perm

The ending time of period xx.

APxxEDTM

Period xx End

Date/Time

Num

Perm

The ending datetime of period xx.

APxxEDTF

Period xx End

Date Imput. Flag

Char

(DATEFL)

Cond

The level of imputation of period xx end date. See General Timing Variable Convention

#6.

APxxETMF

Period End Time

Imput. Flag

Char

(TIMEFL)

Cond

The level of imputation of period xx end time. See General Timing Variable Convention

#7.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3.2 ADaM Basic Data Structure (BDS) Variables

The ADaM document introduces the ADaM Basic Data Structure. A BDS dataset contains one or more records per subject, per analysis parameter, per analysis

timepoint. Analysis timepoint is conditionally required, depending on the analysis. In situations where there is no analysis timepoint, the structure is one or more

records per subject per analysis parameter. Typically there are several BDS datasets in a study. This section of the ADaMIG defines the standard variables used

in BDS datasets. See Section 3.1 for ADSL variables, any of which may be copied to basic structure datasets to support traceability or enable analysis.

3.2.1 Subject Identifier Variables for BDS Datasets

Table 3.2.1.1 Subject Identifier Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

STUDYID

Study Identifier

Char

Req

SDTM DM.STUDYID

USUBJID

Unique Subject

Identifier

Char

Req

SDTM DM.USUBJID

SUBJID

Subject Identifier

for the Study

Char

Perm

SDTM DM.SUBJID. SUBJID is required in ADSL, but permissible in other datasets.

SITEID

Study Site

Identifier

Char

Perm

SDTM DM.SITEID. SITEID is required in ADSL, but permissible in other datasets.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3.2.2 Treatment Variables for BDS Datasets

Table 3.2.2.1 Treatment Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

TRTP

Planned

Treatment

Char

Req

TRTP is a record-level identifier that represents the planned treatment attributed to a

record for analysis purposes. TRTP indicates how treatment varies by record within a

subject and enables analysis of crossover and other designs. TRTxxP (copied from

ADSL) may also be needed for some analysis purposes, and may be useful for

traceability and to provide context.

TRTPN

Planned

Treatment (N)

Num

Perm

The numeric code for TRTP. One-to-one map to TRTP.

TRTA

Actual Treatment

Char

Cond

TRTA is a record-level identifier that represents the actual treatment attributed to a

record for analysis purposes. TRTA indicates how treatment varies by record within a

subject and enables analysis of crossover and other multi-period designs. TRTxxA

(copied from ADSL) may also be needed for some analysis purposes, and may be useful

for traceability and to provide context. TRTA is required when there is an analysis of

data as treated and at least one subject has any data associated with a treatment other

than the planned treatment.

TRTAN

Actual Treatment

(N)

Num

Perm

The numeric code for TRTA. One-to-one map to TRTA.

TRTPGy

Planned Pooled

Treatment y

Char

Perm

Planned pooled treatment y. “y” represents an integer [1-9] corresponding to a

particular pooling scheme. Useful when planned treatments (TRTP) are pooled together

for analysis, for example when all doses of Drug A (TRTPG1=All doses of Drug A) are

compared to all doses of Drug B (TRTPG1=All doses of Drug B). Each value of TRTP

is pooled within at most one value of TRTPGy. May vary by record within a subject.

TRTPGyN

Planned Pooled

Treatment y (N)

Num

Perm

The numeric code for TRTPGy. One-to-one map to TRTPGy.

TRTAGy

Actual Pooled

Treatment y

Char

Cond

Actual pooled treatment y. “y” represents an integer [1-9] corresponding to a particular

pooling scheme. Required when TRTPGy is present and TRTA is present. May vary by

record within a subject.

TRTAGyN

Actual Pooled

Treatment y (N)

Num

Perm

The numeric code for TRTAGy. One-to-one map to TRTAGy.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3.2.3 Timing Variables for BDS Datasets

Any SDTM timing variables (including, but not limited to, EPOCH, --DTC, --DY, VISITNUM, VISIT, and VISITDY) may be copied into analysis datasets if

they would help to support data traceability and/or show how ADaM timing variables contrast with the SDTM data.

Table 3.2.3.1 defines analysis timing variables for BDS datasets. The timing variables whose names start with the letter “A” are the timing variables directly

associated with the AVAL and AVALC variables in the analysis dataset.

Timing variables (e.g., *DT) not directly characterizing AVAL should be prefixed by a character string instead of the placeholder asterisk shown in Table 3.2.3.1,

so that their actual names comply with the variable naming conventions described at the beginning of Section 3. In many cases, the prefix for these date and time

variables would match that of an SDTM --DTC, --STDTC or --ENDTC variable name. For example, if a numeric date variable were created from --STDTC,

then it would be named --SDT. However, if --DTC or --STDTC is the date that is associated with AVAL and AVALC, its numeric equivalent should be named

ADT. The General Timing Variable Conventions documented at the beginning of Section 3 apply here as well.

Table 3.2.3.1 Timing Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

ADT

Analysis Date

Num

Perm

The date associated with AVAL and/or AVALC in numeric format.

ATM

Analysis Time

Num

Perm

The time associated with AVAL and/or AVALC in numeric format.

ADTM

Analysis

Date/Time

Num

Perm

The date/time associated with AVAL and/or AVALC in numeric format.

ADY

Analysis Relative

Day

Num

Perm

The relative day of AVAL and/or AVALC. The number of days from a reference date (not

necessarily DM.RFSTDTC) to ADT. The reference date should be indicated in the

variable-level metadata for ADY and the reference date should be included as a variable

in the given analysis dataset or alternatively in ADSL.

ADTF

Analysis Date

Imputation Flag

Char

(DATEFL)

Cond

The level of imputation of ADT based on the source SDTM DTC variable. See General

Timing Variable Convention #6.

ATMF

Analysis Time

Imputation Flag

Char

(TIMEFL)

Cond

The level of imputation of ATM based on the source SDTM DTC variable. See General

Timing Variable Convention #7.

ASTDT

Analysis Start

Date

Num

Perm

The start date associated with AVAL and/or AVALC. ASTDT and AENDT may be useful

for traceability when AVAL summarizes data collected over an interval of time, or when

AVAL is a duration.

ASTTM

Analysis Start

Time

Num

Perm

The start time associated with AVAL and/or AVALC. ASTTM and AENTM may be

useful for traceability when AVAL summarizes data collected over an interval of time, or

when AVAL is a duration.

ASTDTM

Analysis Start

Date/Time

Num

Perm

The start datetime associated with AVAL and/or AVALC. ASTDTM and AENDTM may

be useful for traceability when AVAL summarizes data collected over an interval of time,

or when AVAL is a duration.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.3.1 Timing Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

ASTDY

Analysis Start

Relative Day

Num

Perm

The number of days from a reference date (not necessarily DM.RFSTDTC) to ASTDT.

The reference date variable should be indicated in the variable-level metadata for

ASTDY and the reference date variable should be included as a variable in an analysis

dataset (typically, but not necessarily, ADSL).

ASTDTF

Analysis Start

Date Imputation

Flag

Char

(DATEFL)

Cond

The level of imputation of ASTDT based on the source SDTM DTC variable. See

General Timing Variable Convention #6.

ASTTMF

Analysis Start

Time Imputation

Flag

Char

(TIMEFL)

Cond

The level of imputation of ASTTM based on the source SDTM DTC variable. See

General Timing Variable Convention #7.

AENDT

Analysis End

Date

Num

Perm

The end date associated with AVAL and/or AVALC. See also ASTDT.

AENTM

Analysis End

Time

Num

Perm

The end time associated with AVAL and/or AVALC. See also ASTTM.

AENDTM

Analysis End

Date/Time

Num

Perm

The end datetime associated with AVAL and/or AVALC. See also ASTDTM.

AENDY

Analysis End

Relative Day

Num

Perm

The number of days from a reference date (not necessarily DM.RFSTDTC) to AENDT.

See also ASTDY.

AENDTF

Analysis End

Date Imputation

Flag

Char

(DATEFL)

Cond

The level of imputation of AENDT based on the source SDTM DTC variable. See

General Timing Variable Convention #6.

AENTMF

Analysis End

Time Imputation

Flag

Char

(TIMEFL)

Cond

The level of imputation of AENTM based on the source SDTM DTC variable. See

General Timing Variable Convention #7.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.3.1 Timing Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

AVISIT

Analysis Visit

Char

Cond

AVISIT may contain the visit names as observe d (i.e., from SDTM VISIT), derived visit

names, time window names, conceptual descriptions (such as Average, Endpoint, etc.), or

a combination of any of these. AVISIT is a derived field and does not have to map to

VISIT from the SDTM. AVISIT represents the analysis visit of the record, but it does not

mean that the record was analyzed. There are often multiple records for the same subject

and parameter that have the same value of AVISIT. ANLzzFL and other variables may

be needed to identify the records selected for any given analysis. See Section 3.2.6 for

metadata about flag variables. AVISIT should be unique for a given analysis visit

window. In the event that a record does not fall within any predefined analysis timepoint

window, AVISIT can be populated in any way that the sponsor chooses to indicate this

fact (i.e., blank or “Not Windowed”). The way that AVISIT is calculated, including the

variables used in its derivation, should be indicated in the variable metadata for AVISIT.

The values and the rules for deriving AVISIT may be different for different parameters

within the same dataset. Values of AVISIT are sponsor-defined, and are often directly

usable in Clinical Study Report displays.

AVISITN

Analysis Visit (N)

Num

Perm

A numeric representation of AVISIT. This may be a protocol visit number, a week or

cycle number, an analysis visit number, or any other number logically related to AVISIT

or useful for sorting that is needed for analysis. Within a parameter, there is a one-to-one

mapping between AVISITN and AVISIT so that AVISITN has the same value for each

distinct AVISIT. In the event that a record does not fall within any predefined analysis

timepoint window, AVISITN can be populated in any way that the sponsor chooses to

indicate this fact (e.g., may be null). Values of AVISITN are sponsor-defined.

ATPT

Analysis

Timepoint

Char

Perm

The analysis time point description which is required if analysis times are derived.

Timepoints are relative to ATPTREF.

ATPT can be within an analysis visit (e.g., blood pressure assessments at 10 min, 20 min,

and 30 min post-dose at AVISIT=Week 1) or can be unrelated to AVISIT (e.g., migraine

symptoms 30 min, 60 min, and 120 min post-dose for attack 1).

ATPTN

Analysis

Timepoint (N)

Num

Perm

ATPTN provides a numeric representation of ATPT. Within the same parameter, there is

a one-to-one mapping between ATPT and ATPTN.

ATPTREF

Analysis

Timepoint

Reference

Char

Perm

Description of the fixed reference point referred to by ATPT/ATPTN.

APERIOD

Period

Num

Perm

The numeric value characterizing the period to which the record belongs. The value of

APERIOD must be consistent with the xx value in TRTxxP, TRTxxA, and all variables

whose names begin with TRxx and APxx.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.3.1 Timing Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

APERIODC

Period (C)

Char

Perm

Text characterizing to which period the record belongs. One-to-one map to APERIOD.

APHASE

Phase

Char

Perm

Generally, a higher-level categorization of APERIOD. Does not replace APERIOD,

because APERIOD provides the indexing for the TRxx and APxx variables.

ARELTM

Analysis Relative

Time

Num

Perm

The time relative to an anchor time. When ARELTM is present, the anchor time variable

and ARELTMU must also be included in the dataset, and the anchor time variable must

be identified in the metadata for ARELTM.

ARELTMU

Analysis Relative

Time Unit

Char

Cond

The units of ARELTM. For example, “HOURS” or “MINUTES.” ARELTMU is

required if ARELTM is present.

APERSDT

Period Start Date

Num

Perm

The starting date for the period defined by APERIOD.

APERSTM

Period Start Time

Num

Perm

The starting time for the period defined by APERIOD.

APERSDTM

Period Start

Date/Time

Num

Perm

The starting datetime for the period defined by APERIOD.

APERSDTF

Period Start Date

Imput. Flag

Char

(DATEFL)

Cond

The level of imputation of APERSDT based on the source SDTM DTC variable. See

General Timing Variable Convention #6.

APERSTMF

Period Start Time

Imput. Flag

Char

(TIMEFL)

Cond

The level of imputation of APERSTM based on the source SDTM DTC variable. See

General Timing Variable Convention #7.

APEREDT

Period End Date

Num

Perm

The ending date for the period defined by APERIOD.

APERETM

Period End Time

Num

Perm

The ending time for the period defined by APERIOD.

APEREDTM

Period End

Date/Time

Num

Perm

The ending datetime for the period defined by APERIOD.

APEREDTF

Period End Date

Imput. Flag

Char

(DATEFL)

Cond

The level of imputation of APEREDT based on the source SDTM DTC variable. See

General Timing Variable Convention #6.

APERETMF

Period End Time

Imput. Flag

Char

(TIMEFL)

Cond

The level of imputation of APERETM based on the source SDTM DTC variable. See

General Timing Variable Convention #7.

The following timing variables are not directly descriptive of the analysis value (AVAL and/or AVALC) but may be included for support of review. There may

be a number of “sets” of these variables as indicated by the “*” prefix. See General Timing Variable Convention #11 for important cautions regarding the

“*” prefix.

*DT

Date of …

Num

Perm

Analysis date not directly characterizing AVAL and/or AVALC in numeric format.

*TM

Time of …

Num

Perm

Analysis time not directly characterizing AVAL and/or AVALC in numeric format.

*DTM

Date/Time of …

Num

Perm

Analysis date/time not directly characterizing AVAL and/or AVALC in numeric format.

*ADY

Relative Day of

…

Num

Perm

Analysis relative day not directly characterizing AVAL and/or AVALC.

*DTF

Date Imputation

Qual of …

Char

(DATEFL)

Cond

The level of imputation of *DT based on the source SDTM DTC variable. See General

Timing Variable Convention #6.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.3.1 Timing Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

*TMF

Time Imputation

Flag of …

Char

(TIMEFL)

Cond

The level of imputation of *TM based on the source SDTM DTC variable. See General

Timing Variable Convention #7.

*SDT

Start Date of …

Num

Perm

Starting analysis date not directly characterizing AVAL and/or AVALC in numeric

format.

*STM

Start Time of …

Num

Perm

Starting analysis time not directly characterizing AVAL and/or AVALC in numeric

format.

*SDTM

Start Date/Time

of …

Num

Perm

Starting analysis date/time not directly characterizing AVAL and/or AVALC in numeric

format.

*SDY

Relative Start Day

of …

Num

Perm

Starting analysis relative day not directly characterizing AVAL and/or AVALC.

*SDTF

Start Date

Imputation Flag

of …

Char

(DATEFL)

Cond

The level of imputation of *SDT based on the source SDTM DTC variable. See General

Timing Variable Convention #6.

*STMF

Start Time

Imputation Qual

of …

Char

(TIMEFL)

Cond

The level of imputation of *STM based on the source SDTM DTC variable. See General

Timing Variable Convention #7.

*EDT

End Date of …

Num

Perm

Ending analysis date not directly characterizing AVAL and/or AVALC in numeric format.

*ETM

End Time of …

Num

Perm

Ending analysis time not directly characterizing AVAL and/or AVALC in numeric format.

*EDTM

End Date/Time of

…

Num

Perm

Ending analysis date/time not directly characterizing AVAL and/or AVALC in numeric

format.

*EDY

Relative End Day

of …

Num

Perm

Ending analysis relative day not directly characterizing AVAL and/or AVALC.

*EDTF

End Date

Imputation Flag

of …

Char

(DATEFL)

Cond

The level of imputation of *EDT based on the source SDTM DTC variable. See General

Timing Variable Convention #6.

*ETMF

End Time

Imputation Flag

of …

Char

(TIMEFL)

Cond

The level of imputation of *ETM based on the source SDTM DTC variable. See General

Timing Variable Convention #7.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3.2.4 Analysis Parameter Variables for BDS Datasets

Table 3.2.4.1Analysis Parameter Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

PARAM

Parameter

Char

Req

The description of the analysis parameter. Examples include: “Supine Systolic Blood

Pressure (mm Hg)”, “Log10 (Weight (kg))”, “Time to First Hypertension Event (Days)”,

“Estimated Tumor Growth Rate”, etc. PARAM should be sufficient to describe

unambiguously the contents of AVAL and/or AVALC. PARAM must include test, units

(if appropriate), specimen type, location, position, and any other applicable qualifying

information needed, any additional information such as transformation function, and

indeed any text that is needed. PARAM may be longer than 40 characters in length.

PARAM is often directly usable in Clinical Study Report displays. Note that in the

ADaMIG, “parameter” is a synonym of “analysis parameter.”

PARAMCD

Parameter Code

Char

Req

The short name of the analysis parameter in PARAM. Values of PARAMCD should

follow SAS 5 variable naming conventions (8 characters or less; starts with a letter;

contains only letters and digits). There must be a one-to-one mapping with PARAM.

Examples: SYSBP, LWEIGHT, HYPEREVT.

PARAMN

Parameter (N)

Num

Perm

Useful for ordering and programmatic manipulation. There must be a one-to-one

mapping with PARAM. Must be an integer.

PARAMTYP

Parameter Type

Char

(PARAMTY

Perm

Indicator of whether the parameter is derived as a function of one or more other

parameters. This should not be confused with DTYPE which is relevant to derived

AVAL and/or AVALC values.

PARCATy

Parameter

Category y

Char

Perm

A categorization of PARAM. For example, value of PARCAT1 might group the

parameters having to do with a particular questionnaire, lab specimen type, or area of

investigation.

PARCATyN

Parameter

Category y (N)

Num

Perm

A numeric representation of PARCATy. This can be used for operations on PARCATy.

There should be a one to one relationship between PARCATy and PARCATyN.

AVAL

Analysis Value

Num

Req

(at

least

one)

Numeric analysis value described by PARAM.

AVALC

Analysis Value

(C)

Char

Character analysis value described by PARAM. AVALC can be a character string

mapping to AVAL, but if so there must be a one-to-one map between AVAL and AVALC

within a given PARAM. AVALC should not be used to categorize the values of AVAL.

AVALCATy

Analysis

Category y

Char

Perm

A categorical representation of AVAL and/or AVALC. Not necessarily a one-to-one

mapping to AVAL and/or AVALC. For example, if PARAM is “Headache Severity” and

AVAL has values 0, 1, 2, or 3, AVALCAT1 can categorize AVAL into “None or Mild”

(for AVAL 1 or 2) and “Moderate or Severe” (for AVAL 3 or 4)

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.4.1Analysis Parameter Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

BASE

Baseline Value

Num

Cond

Baseline analysis value. Required if dataset supports analysis or review of baseline

value or functions of baseline value. A baseline record may be derived (e.g., it may be an

average) in which case DTYPE must also be populated. If BASE is populated for a

parameter, and BASE is non-null for a subject for that parameter, then there must be a

record flagged by ABLFL for that subject and parameter.

BASEC

Baseline Value

(C)

Char

Perm

Baseline value of AVALC. May be needed when AVALC is of interest. There must be a

one-to-one map between BASE and BASEC within a given PARAM if both are

populated. The baseline record for AVALC must be the same as that for AVAL.

BASECATy

Baseline Category

Char

Perm

A categorical representation of BASE. Not necessarily a one-to-one map to BASE. For

example, if PARAM is “Headache Severity” and AVAL has values 0, 1, 2, or 3,

BASECAT1 can categorize BASE into “None or Mild” (for BASE 1 or 2) and

“Moderate or Severe” (for BASE 3 or 4)

BASETYPE

Baseline Type

Char

Cond

Sponsor-defined text describing the definition of baseline relevant to the value of BASE

on the current record. Required when there are multiple ways that baseline is defined. If

used for a given PARAM, should be populated for all records of that PARAM. Refer to

Section 4.2.1, Rule 6, for an example.

CHG

Change from

Baseline

Num

Perm

Change from baseline analysis value. Equal to AVAL-BASE. If used for a given

PARAM, should be populated for all post-baseline records of that PARAM. The

decision on how to populate pre-baseline and baseline values of CHG are left to sponsor

choice.

CHGCATy

Change from

Baseline Category

Char

Perm

A categorical representation of CHG. Not necessarily a one-to-one mapping to CHG.

The definition of CHGCATy may vary by PARAM. For example, CHGCAT1 may be

used to categorize CHG with respect to ranges of change in SYSBP; “-10 to -5 mm Hg”,

“-5 to 0 mm Hg” categories.

PCHG

Percent Change

from Baseline

Num

Perm

Percent change from baseline analysis value. Equal to ((AVAL-BASE)/BASE)*100. If

used for a given PARAM, should be populated (when calculable) for all records of that

PARAM. The decision on how to populate pre-baseline and baseline values of PCHG

are left to sponsor choice.

PCHGCATy

Percent Change

from Baseline y

Char

Perm

A categorical representation of PCHG. Not necessarily a one-to-one mapping to PCHG.

The definition of PCHGCATy may vary by PARAM. For example, PCHGCAT1 may be

used to categorize PCHG with respect to ranges of change in SYSBP; “>5%”, “>10%”

categories.

R2BASE

Ratio to Baseline

Num

Perm

AVAL / BASE

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.4.1Analysis Parameter Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

R2AyLO

Ratio to Analysis

Range y Lower

Limit

Num

Perm

AVAL / AyLO. AyLO must exist in the analysis dataset.

R2AyHI

Ratio to Analysis

Range y Upper

Limit

Num

Perm

AVAL / AyHI. AyHI must exist in the analysis dataset.

SHIFTy

Shift y

Char

Perm

A shift in values depending on the defined pairing for group “y”. SHIFTy can be based

on the change in value of any of the following pairs (BASECATy, AVALCATy),

(BNRIND, ANRIND), (BTOXGR, ATOXGR), (BASE, AVAL) or (BASEC, AVALC).

Useful for shift tables. For example, “NORMAL to HIGH”. The decision on how to

populate baseline and pre-baseline values of SHIFTy are left to sponsor choice.

SHIFTyN

Shift y (N)

Num

Perm

Numeric version of SHIFT. SHIFTN has a one-to-one mapping relationship with SHIFT.

The decision on how to populate baseline and pre-baseline values of SHIFTN are left to

sponsor choice.

CRITy

Analysis Criterion

Char

Perm

A text string identifying a pre-specified criterion, for example SYSBP > 90. In some

cases, the presence of the text string indicates that the criterion is satisfied on this record,

while a null value indicates that the criterion is not satisfied. In other cases, the text

string identifies the criterion being evaluated, but whether or not the criterion is satisfied

is indicated by the value of the variable CRITyFL. See CRITyFL and CRITyFN in

Section 3.2.6. Refer to Section 4.7 for additional discussion of CRITy, CRITyFL and

CRITyFN.

Note that additional variables may be added that are parameter-invariant functions of AVAL and BASE on the same row. Refer to Section 4.2 for the rules

governing when derivations are added as rows, and when they are added as columns.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3.2.5 Analysis Descriptor Variables for BDS Datasets

Table 3.2.5.1 Analysis Descriptor Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

DTYPE

Derivation Type

Char

(DTYPE)

Cond

Analysis value derivation method. DTYPE is used to denote, and is required to be

populated, when the value of AVAL or AVALC (and thus the entire record) has been

imputed, derived, or copied from other record(s). DTYPE is required to be populated

even if AVAL and AVALC are null on the derived record. DTYPE is not used to denote

that an analysis parameter is derived. PARAMTYP may be used to indicate that an entire

parameter is derived. For each value of DTYPE, the precise derivation algorithm must be

defined in analysis variable metadata, even for DTYPE values in the controlled

terminology. See Section 4 for examples of the use of DTYPE.

Examples of DTYPE values

LOCF = last observation carried forward.

WOCF = worst observation carried forward.

AVERAGE = average of values.

If analysis timepoints are defined by relative day or hour windows, then the variables in Table 3.2.5.2 may be used along with ADY or ARELTM to clarify how

the record representing each analysis timepoint was chosen from among the possible candidates. The record chosen is indicated by the analyzed record flag

ANLzzFL (see Table 3.2.6.1). Note that the variables in Table 3.2.5.2 may not be applicable in all situations and are presented as an option.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.5.2 Analysis Visit Windowing Variables for BDS Datasets

Variable

Name

Variable

Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

AWRANGE

Analysis Window

Valid Relative

Range

Char

Perm

The range of values that are valid for a given analysis timepoint (a given value of

AVISIT). For example, “5-9 DAYS”.

AWTARGET

Analysis Window

Target

Num

Perm

The target or most desired analysis relative day (ADY) value or analysis relative time

(ARELTM) value for a given value of AVISIT.

AWTDIFF

Analysis Window

Diff from Target

Num

Perm

Absolute difference between ADY or ARELTM and AWTARGET. It will be necessary to

adjust for the fact that there is no day 0 in the event that ADY and AWTARGET are not of

the same sign.

If the sign of the difference is important, then AWTDIFF might have to be used in

conjunction with ADY or ARELTM and possibly AWTARGET when choosing among

records.

AWLO

Analysis Window

Beginning

Timepoint

Num

Perm

The value of the beginning timepoint (inclusive) needs to be used in conjunction to

AWRANGE. For example, if AWRANGE is“5-9 DAYS”, then AWLO is “5”.

AWHI

Analysis Window

Ending Timepoint

Num

Perm

The value of the ending timepoint (inclusive) needs to be used in conjunction to

AWRANGE. For example, if AWRANGE is“5-9 DAYS”, then AWHI is “9”.

AWU

Analysis Window

Unit

Char

Perm

Unit used for AWLO and AWHI. Examples: DAYS, HOURS.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.5.3 Time to Event Variables for BDS Datasets

Variable

Name

Variable

Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

STARTDT

Time to Event

Origin Date for

Subject

Num

Perm

The original date of risk for the time-to-event analysis. This is generally the time at

which a subject is first at risk of the event of interest (as defined in the protocol or

Statistical Analysis Plan). For example, this may be the randomization date or the date

of first study therapy exposure.

CNSR

Censor

Num

Cond

Defines whether the event was censored (period of observation truncated prior to event

being observed). It is strongly recommended to use 0 as an event indicator and positive

integers as censoring indicators. It is also recommended that unique positive integers be

used to indicate coded descriptions of censoring reasons. CNSR is required for time-to-

event parameters.

EVNTDESC

Event or

Censoring

Description

Char

Perm

Description of the event of interest or censoring reason.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.5.4 Lab Related Analysis Variables for BDS Datasets

Variable

Name

Variable

Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

ATOXGR

Analysis Toxicity

Grade

Char

Perm

Toxicity grade for analysis; may be based on SDTM --TOXGR or an imputed or

assigned value.

BTOXGR

Baseline Toxicity

Grade

Char

Perm

ATOXGR of the baseline record identified by ABLFL.

ANRIND

Analysis

Reference Range

Indicator

Char

Perm

Normal range indicator for analysis; may be based on SDTM --NRIND or an imputed or

assigned value.

BNRIND

Baseline

Reference Range

Indicator

Char

Perm

ANRIND of the baseline record identified by ABLFL.

ANRLO

Analysis Normal

Range Lower

Limit

Char

Perm

Normal range lower limit for analysis; may be based on SDTM --NRLO or an imputed

or assigned value.

ANRHI

Analysis Normal

Range Upper

Limit

Char

Perm

Normal range upper limit for analysis; may be based on SDTM --NRHI or an imputed or

assigned value.

AyLO

Analysis Range y

Lower Limit

Char

Cond

AyLO and/or AyHI are used where there are multiple ranges used for analysis. AyLO

and/or AyHI are created to capture the different levels of cutoff values used to determine

whether an analysis is within a clinically acceptable value range or outside that value

range. AyLO and/or AyHI are usually but not necessarily constants, parameter-specific

constants, or subject-specific constants. AyLO must be included if R2AyLO is included

in the dataset.

AyHI

Analysis Range y

Upper Limit

Char

Cond

See AyLO.

For example, if ECG QTc values are summarized based on values 450, values >480, and

values >500, there is a need for 3 “hi value” range variables to calculate values against:

A1HI=450, A2HI=480, A3HI=500.

AyHI must be included if R2AyHI is included in the dataset.

3.2.6 Indicator Variables for BDS Datasets

See Section 3.2.7 for a discussion of the differences between ADaM population and baseline flags and the flags in SDTMIG 3.1.1 and 3.1.2.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.6.1 Flag Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

ABLFL

Baseline Record

Flag

Char

Cond

Character indicator to identify the baseline record for each parameter, or if there is more

than one baseline definition, for each parameter and baseline type (BASETYPE). See

BASETYPE in Table 3.2.4.1. ABLFL is required if BASE is present in the dataset.

A baseline record may be derived (e.g., it may be an average), in which case DTYPE

must also be populated. If BASE is populated for a parameter, and BASE is non-null for

a subject for that parameter, then there must be a record flagged by ABLFL for that

subject and parameter.

ABLFN

Baseline Record

Flag (N)

Num

Perm

Numeric indicator to identify the baseline record for each parameter, or if there is more

than one baseline definition, for each parameter and baseline type (BASETYPE).

ANLzzFL

Analysis Record

Flag zz

Char

Cond

ANLzzFL is a conditionally required flag to be used in addition to other selection

variables when the other selection variables in combination are insufficient to identify

the exact set of records used for one or more analyses. Often one ANLzzFL will serve to

support the accurate selection of records for more than one analysis.

When one is defining the set of records used in a particular analysis or family of

analyses, ANLzzFL is supplemental to, and is intended to be used in conjunction with,

other selection variables, such as subject-level, parameter-level and record-level

population flags, AVISIT, DTYPE, grouping variables such as SITEGRy, and others.

Every record selection algorithm “zz” (i.e., every algorithm for populating an ANLzzFL)

must be defined in variable metadata. When the set of records that the algorithm “zz”

operates on is pre-filtered by application of other criteria, such as a record-level

population flag, then the selection algorithm definition in the metadata must so specify.

Note that the ANLzzFL value of Y indicates that the record fulfilled the requirements of

the algorithm, but does not necessarily imply that the record was actually used in one or

more analyses, as whether or not a record is used also depends on the other selection

variables applied. The ANLzzFL flag is useful in many circumstances; an example is

when there is more than one record for an analysis timepoint within a subject and

parameter, as it can be used to identify the record chosen to represent the timepoint for an

analysis. “zz” is an index for a record selection algorithm, such as “record closest to

target relative day for the AVISIT, with ties broken by the latest record, for each AVISIT

within <list of AVISITS>.”

ANLzzFN

Analyzed Record

Flag zz (N)

Num

Perm

Numeric version of ANLzzFL.

ONTRTFL

On Treatment

Record Flag

Char

Perm

Character indicator of whether the observation occurred while the subject was on

treatment.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.6.1 Flag Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

ONTRTFN

On Treatment

Record Flag (N)

Num

Perm

Numeric indicator of whether the observation occurred while the subject was on

treatment.

LVOTFL

Last Value On

Treatment Record

Flag

Char

Perm

Character indicator of the last non-missing value on treatment for each parameter.

LVOTFN

Last Value On

Treatment Record

Flag (N)

Num

Perm

Numeric indicator of the last non-missing value on treatment for each parameter.

ITTRFL

Intent-To-Treat

Record-Level

Flag

Char

Cond

Character indicator of whether the subject was in the intent-to-treat analysis for the

specific record.

ITTRFN

Intent-To-Treat

Record-Level

Flag (N)

Num

Perm

Numeric indicator of whether the subject was in the intent-to-treat analysis for the

specific record.

ITTPFL

Intent-To-Treat

Parameter-Level

Flag

Char

Cond

Character indicator of whether the subject was in the intent-to-treat analysis for the

specific parameter.

ITTPFN

Intent-To-Treat

Param-Level Flag

(N)

Num

Perm

Numeric indicator of whether the subject was in the intent-to-treat analysis for the

specific parameter.

SAFRFL

Safety Analysis

Record-Level

Flag

Char

Cond

Character indicator of whether the subject was in the safety analysis for the specific

record.

SAFRFN

Safety Analysis

Record-Level

Flag (N)

Num

Perm

Numeric indicator of whether the subject was in the safety analysis for the specific

record.

SAFPFL

Safety Analysis

Parameter-Level

Flag

Char

Cond

Character indicator of whether the subject was in the safety analysis for the specific

parameter.

SAFPFN

Safety Analysis

Param-Level Flag

(N)

Num

Perm

Numeric indicator of whether the subject was in the safety analysis for the specific

parameter.

FASRFL

Full Analysis Set

Record-Level

Flag

Char

Cond

Character indicator of whether the subject was in the full analysis set analysis for the

specific record.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.6.1 Flag Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

FASRFN

Full Analysis Set

Record-Level

Flag (N)

Num

Perm

Numeric indicator of whether the subject was in the full analysis set analysis for the

specific record.

FASPFL

Full Analysis Set

Parameter-Level

Flag

Char

Cond

Character indicator of whether the subject was in the full analysis set analysis for the

specific parameter.

FASPFN

Full Analysis Set

Param-Level Flag

(N)

Num

Perm

Numeric indicator of whether the subject was in the full analysis set analysis for the

specific parameter.

PPROTRFL

Per-Protocol

Record-Level

Flag

Char

Cond

Character indicator of whether the subject was in the per-protocol analysis for the

specific record.

PPROTRFN

Per-Protocol

Record-Level

Flag (N)

Num

Perm

Numeric indicator of whether the subject was in the per-protocol analysis for the specific

record.

PPROTPFL

Per-Protocol

Parameter-Level

Flag

Char

Cond

Character indicator of whether the subject was in the per-protocol analysis for the

specific parameter.

PPROTPFN

Per-Protocol

Parameter-Level

Flag (N)

Num

Perm

Numeric indicator of whether the subject was in the per-protocol analysis for the specific

parameter.

COMPRFL

Completers

Record-Level

Flag

Char

Cond

Character indicator of whether the subject was in the completed subjects analysis for the

specific record.

COMPRFN

Completers

Record-Level

Flag (N)

Num

Perm

Numeric indicator of whether the subject was in the completed subjects analysis for the

specific record.

COMPPFL

Completers

Parameter-Level

Flag

Char

Cond

Character indicator of whether the subject was in the completed subjects analysis for the

specific parameter.

COMPPFN

Completers

Parameter-Level

Flag (N)

Num

Perm

Numeric indicator of whether the subject was in the completed subjects analysis for the

specific parameter.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 3.2.6.1 Flag Variables for BDS Datasets

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

CRITyFL

Criterion y

Evaluation Result

Flag

Char

Y, N

Cond

Character indicator of whether the criterion defined in CRITy was met. See also CRITy

in Section 3.2.4. Required if CRITy exists. Refer to Section 4.7 for additional

discussion.

CRITyFN

Criterion y

Evaluation Result

Flag (N)

Num

1, 0

Perm

Numeric indicator of whether the criterion defined in CRITy was met.

3.2.7 Differences Between SDTM and ADaM Population and Baseline Flags

The SDTM Implementation Guide includes controlled terminology for some Supplemental Qualifier values for subject-level population flags. The conceptual

mapping from those terms to ADaM indicator variables is presented in Table 3.2.7.1.

Table 3.2.7.1 ADaM Subject-Level Population Flags Corresponding to SDTM Supplemental Qualifiers

SDTM QNAM

SDTM QLABEL

ADaM Subject-Level Population Flags

COMPLT

Completers Population Flag

COMPFL

FULLSET

Full Analysis Set Flag

FASFL

ITT

Intent-to-Treat Population Flag

ITTFL

PPROT

Per Protocol Set Flag

PPROTFL

SAFETY

Safety Population Flag

SAFFL

It is possible that the ADaM subject-level population flags might not match their conceptual counterparts in the SDTM. For example, the SDTM ITT

supplemental qualifier may not match the ADaM ITTFL indicator variable for a given subject. These population indicators may not match because of operational

issues. It is entirely possible that a company could inherit a SDTM database that for various reasons cannot be changed. It is not incumbent on those creating

analysis datasets to go back and “fix” the SDTM population supplemental qualifiers and there may be good reason not to do so. The ADaM team agrees that it

would be best if the SDTM subject-level population supplemental qualifiers are in harmony with the ADaM population indicator variables, but it is important to

recognize that there may be situations where they differ. There are additional ADaM subject-level population flags that do not have counterparts in SDTM.

ADaM also supports parameter-level and record-level population flags, which do not exist in SDTM.

Similarly, a baseline record identified in SDTM may not be the record identified in an ADaM dataset and there are many reasons why this may occur. For

example it may be necessary to have a baseline for blood glucose and a different one for urine glucose. These would comprise two distinct parameters in an

ADaM dataset, each with its own baseline, whereas in SDTM there might be only one baseline for glucose. Additionally, there are ADaM parameters that are

highly derived and do not have simple counterparts in a findings domain. An ADaM parameter may be derived from SDTM data spanning multiple domains and

classes. Such a parameter would not exist in the SDTM and so its baseline could only exist in the ADaM dataset. Also, it may be necessary to have separate

baselines for different periods within the study, for example to support analyses of change from screening baseline, double-blind treatment baseline, and open

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

label extension baseline (see Section 4.2, Rule 6). When there is record-level population flagging, it may be necessary to have different baselines for two

different analysis populations. Lastly, it may be desired to conduct analyses for different definitions of baseline. The ADaM baseline flag ABLFL, coupled with

the BASE and BASETYPE columns, plus population flags, can handle all of these practical scenarios.

For analysis purposes, the values of population and baseline flags used for analysis are found in the analysis datasets. ADaM flags should be described in ADaM

metadata.

3.2.8 Other Variables

Analysis-Enabling Variables

There is a class of variables that enable one or more of the analyses that the dataset was designed to support. Often, these enabling variables would include the

indicator variables and analysis descriptor variables described above, which are often needed to make the analysis dataset one statistical procedure away from

analysis results. Enabling variables may also include stratification and subgrouping variables, model covariates and any other variables required to be present in

order to perform an analysis.

Data Point Traceability Variables

Variables to support data point traceability should be included whenever practical. The SDTM content that serves as primary candidates for data point

traceability are the SDTM DOMAIN variable value, the name of the SDTM source variable, and the relevant SDTM domain --SEQ value.

In the event that the value of AVAL or AVALC is taken from a supplemental qualifier in SDTM, the two-letter domain prefix of --SEQ in the ADaM dataset

would be the related domain abbreviation (the value of RDOMAIN in SUPP-- or SUPPQUAL), and the value of --SEQ would be the sequence number of the

relevant related domain record. If --SEQ was not the key linking variable to the SDTM source, --SEQ could still be used as the linking key back to the SDTM

since --SEQ would point to at least one valid SDTM record as the source of the ADaM data.

Table 3.2.8.1 defines additional variables useful in certain situations to facilitate data point traceability. Section 4.4 contains an example of how to use these

variables.

Table 3.2.8.1 Data Point Traceability Variables

Variable

Name

Variable Label

Type

Codelist /

Controlled

Terms

Core

CDISC Notes

SRCDOM

Source Domain

Char

Perm

The 2-character identifier of the SDTM domain that relates to AVAL or AVALC.

SRCVAR

Source Variable

Char

Perm

The name of the column (in the SDTM domain identified by SRCDOM) that relates to

AVAL or AVALC.

SRCSEQ

Source Sequence

Number

Num

Perm

The sequence number SEQ of the row (in the SDTM domain identified by SRCDOM)

that relates to AVAL or AVALC.

Variables used for data point traceability may also include any other variables that facilitate transparency and clarity of derivations and analysis for statistical

reviewers.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4 Implementation Issues, Standard

Solutions, and Examples

The ADaM standard variables (columns) are described in Section 3. However, there is more to ADaM compliance than adherence to Section 3. The purpose of

Section 4 is to provide additional guidance on how to implement ADaM standard datasets correctly, illustrated with examples.

Section 4.1 provides examples of treatment variables for common trial designs.

Sections 4.2-4.8 are concerned with the BDS. These sections provide standard solutions to BDS implementation issues, illustrated with examples. In contrast

with ADSL, there is usually more than one dataset that follows the BDS in a study. As discussed in the ADaM document, the number of analysis datasets should

be “optimal” to support analysis and review. The Class attribute of analysis dataset metadata indicates the structure that a dataset follows: ADSL, BDS, or Other.

For space reasons, the examples in Section 4 necessarily omit many required and permissible ADaM variables, and show only the variables needed to facilitate

understanding of the points being addressed.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.1 Examples of Treatment Variables for Common Trial Designs

The following examples illustrate the concepts around treatment variables in ADSL for several different trial designs, including a parallel design, a cross-over

design, and an open-label extension of a parallel design study. Note that only selected variables are illustrated; these examples are not intended to imply that

these are the only variables in ADSL.

In the first example (Table 4.1.1), the treatment variables for three subjects in a parallel design study are illustrated. Note that the third subject was randomized

to active treatment yet received placebo instead.

Table 4.1.1 Randomized Parallel Design

Row

USUBJID

ARM

TRT01P

TRT01A

TR01SDT

TR01EDT

1001

Drug X 5 mg

23OCT2007

17DEC2007

1002

Placebo

19JUL2006

20SEP2007

1003

Drug X 5 mg

Placebo

01NOV2007

20NOV2007

The second example (Table 4.1.2) illustrates the treatment variables for three subjects in a two-period cross-over design. It should be noted that TRTSDT and

TRTEDT are not displayed, but TRTSDT=TR01SDT and TRTEDT is the maximum of TR01EDT and TR02EDT as some subjects may have discontinued before

receiving TRT02P. Note that subjects 1002 and 1003 (in rows 2 and 3) were each exposed to placebo for both trial periods.

Table 4.1.2 Two Period Cross-Over Design

Row

USUBJID

TRTSEQP

TRT01P

TRT02P

TRTSEQA

TRT01A

TRT02A

TR01SDT

TR01EDT

TR02SDT

TR02EDT

1001

Placebo – Drug X

Placebo

Drug X

Placebo – Drug X

Placebo

Drug X

15FEB2006

03MAY2006

10MAY2006

15AUG2006

1002

Placebo – Drug X

Placebo

Drug X

Placebo – Placebo

Placebo

01MAR2006

12JUN2006

20JUN2006

23SEP2006

1003

Drug X – Placebo

Drug X

Placebo

Placebo – Placebo

Placebo

03FEB2006

25APR2006

01MAY2006

04AUG2006

The third example (Table 4.1.3) illustrates the treatment variables for three subjects in a three-period cross-over design. It should be noted that TRTSDT and

TRTEDT are not displayed, but TRTSDT=TR01SDT and TRTEDT is the maximum of TR01EDT, TR02EDT, and TR03EDT as some subjects may have

discontinued before receiving TRT03P. In this trial, all subjects received the planned treatment at each period so the TRTxxA variables are not needed.

Table 4.1.3 Three Period Cross-Over Design

Row

USUBJID

TRTSEQP

TRT01P

TRT02P

TRT03P

TR01SDT

TR01EDT

TR02SDT

TR02EDT

TR03SDT

TR03EDT

1001

Placebo – Drug X –

Drug Y

Placebo

Drug X

Drug Y

15FEB2006

03MAY2006

10MAY2006

15AUG2006

23AUG2006

14NOV2006

1002

Drug Y – Placebo –

Drug X

Drug Y

Placebo

Drug X

01MAR2006

12JUN2006

20JUN2006

23SEP2006

01OCT2006

05DEC2006

1003

Drug X – Drug Y –

Placebo

Drug X

Drug Y

Placebo

03FEB2006

25APR2006

01MAY2006

04AUG2006

12AUG2006

15OCT2006

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

The fourth example (Table 4.1.4) illustrates the treatment variables for two subjects in an open-label extension from a parallel design study. For open label

studies, the variable TRT01P is used for the treatment to which the subject was randomized in the double blinded trial. TRT02P is used for the open label

treatment.

Table 4.1.4 Open Label Extension of a Parallel Design

Row

USUBJID

TRTSEQP

TRT01P

TRT02P

TR01SDT

TR01EDT

TR02SDT

TR02EDT

1001

Drug X 5 mg - Drug X 5 mg

Drug X 5 mg

14AUG2007

20SEP2007

21SEP2007

15MAR2008

1002

Placebo - Drug X 5 mg

Placebo

Drug X 5 mg

05JUL2007

15AUG2007

17AUG2007

04FEB2008

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.2 Creation of Derived Columns Versus Creation of Derived Rows

In the ADaM BDS, subjects, analysis parameters, and analysis timepoints define rows and are identified in standard columns. Subject, parameter and timepoint

in combination may not be enough to serve as natural keys (unique record identifiers). There may be multiple rows within a given combination, depending on

the number of observations collected or derived, baseline definition, etc.

Standard columns exist for a variety of purposes, such as SDTM record identifiers for traceability, population and other record selection flags, analysis values,

and some standard functions of analysis values. Permissible columns are not limited to those whose variable names are specified in Section 3, and may include

study-specific analysis model covariates, subgrouping variables, variables supportive of traceability, and other variables needed for analysis or useful for review.

However, there are some constraints on when derived data may be added as columns. Specifically, the subject of Section 4.2 is to address when functions of

analysis values should be added as additional columns, and when they should be added as additional rows instead.

The precise sequence of steps involved in creating a BDS analysis dataset varies according to operational and study-specific needs. For the purposes of this

discussion, it is useful to think of two initial steps.

The first step is to create a set of rows and columns more or less directly derived from or loaded from input SDTM domains into their appropriate places. This

step may include creation of analysis parameters (PARAM etc.), analysis timepoint (AVISIT etc.) and analysis variables (AVAL and AVALC). It would also

include addition of identifiers (STUDYID, SITEID, USUBJID, SUBJID) and other SDTM variables for traceability (VISIT, --SEQ, etc.).

The second step consists of further derivation of additional rows and columns based on this precursor set of analysis dataset records and columns. It is this

second step that is addressed in Section 4.2.

To be specific, derived rows and columns are defined in Section 4.2 to be rows and columns that are created based on data already present in the analysis dataset,

as opposed to data that are (1) copied or derived directly from SDTM; or (2) copied or derived directly from other analysis datasets or metadata. This section

only addresses the creation of columns and rows to accommodate such internally-derived data.

This section discusses the ADaM rules that govern when such internal derivation of data should result in creation of columns, and when it should result in

creation of rows. These rules are an essential part of the definition of the BDS.

4.2.1 Rules for the Creation of Rows and Columns

To preserve the BDS, it is necessary to place constraints on when one is allowed to create derived columns. Rule 1 describes a situation in which one should

derive data in columns. Rules 2-6 describe situations in which one should derive data in new rows, whether in entire new parameters, or as additional rows in

existing parameters.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Rule 1. A parameter-invariant function of AVAL and BASE on the same row that does not involve a transform of BASE

should be added as a new column.

The three conditions of Rule 1 for when a function of AVAL and BASE should be added as a column are:

1. The function is of AVAL and, optionally, BASE, on the same row; and

2. The function is parameter-invariant; and

3. The function does not involve a transform of BASE.

The remainder of the discussion of this rule is devoted to explaining these conditions.

PARAM uniquely describes the contents of AVAL or AVALC. Often, AVAL itself is not the value that is needed for analysis. For example, in a change from

baseline analysis, it is the change from baseline CHG that is analyzed. The change from baseline column CHG should be created according to Rule 1 because it

satisfies the three conditions:

1. CHG is derived from AVAL and BASE on the same row;

2. The same calculation applies on all rows in the dataset on which CHG is populated (the function CHG=AVAL-BASE does not vary according to

PARAM).

This second condition is known as the property of “parameter invariance”; unless listed in Section 3, a function of AVAL (and optionally BASE) may not be

derived as a column if its purpose is to contain a collection of parameter-specific functions.

3. In the function CHG=AVAL-BASE, BASE is not transformed.

Table 4.2.1.1 illustrates the CHG column. Note that it is not required to populate CHG on all rows. If desired, CHG and other function columns allowed under

Rule 1 may be populated only on those rows and analysis parameters where it is appropriate or potentially useful for analysis and review of the study. The

baseline flag column ABLFL identifies the row that was used to populate the BASE column.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.1 Illustration of Rule 1: Creation of a Column Containing a Same-Row Parameter-Invariant Function of AVAL and BASE

Row

PARAM

PARAMCD

AVISIT

ABLFL

AVAL

BASE

CHG

Weight (kg)

WEIGHT

Screening

100

Weight (kg)

WEIGHT

Run-In

101

100

Weight (kg)

WEIGHT

Baseline

100

Weight (kg)

WEIGHT

Week 24

100

-6

Weight (kg)

WEIGHT

Week 48

100

-8

Weight (kg)

WEIGHT

Week 52

100

-5

Pulse Rate (bpm)

PULSE

Screening

Pulse Rate (bpm)

PULSE

Run-In

Pulse Rate (bpm)

PULSE

Baseline

Pulse Rate (bpm)

PULSE

Week 24

Pulse Rate (bpm)

PULSE

Week 48

Pulse Rate (bpm)

PULSE

Week 52

Now consider the potential function column LOG10 = Log10(AVAL). This function satisfies all three conditions of Rule 1 and as such is allowed as a function

column.

However, if it is desired to perform change from baseline analysis in LOG10, and columns for LOG10, baseline of LOG10 and change from baseline of LOG10

would also be needed for analysis and review, then the Log10 transformation should instead be created as a new parameter, so that the usual columns AVAL,

BASE and CHG can be used.

This is because columns for baseline of LOG10 and change from baseline of LOG10 would not satisfy the conditions of Rule 1. Baseline of LOG10 violates the

first condition, because it is not generally a function of AVAL on the same row (does not generally vary by AVAL), and instead is a function only of AVAL on the

baseline row. “Change from baseline of LOG10” =LOG10(AVAL) - LOG10(BASE) violates the third condition, because it contains the Log10 transform of

BASE.

The intent is to use the standard columns as much as possible, to keep the structure as standard as possible, and avoid undue horizontalization, while still

permitting efficient use of function columns.

Any function that satisfies the three conditions of Rule 1 is allowed as a column. If the function is listed in Section 3, then the ADaM standard column name

must be used just as CHG is used in Table 4.2.1.1.

Rule 2. A transformation of AVAL that does not meet the conditions of Rule 1 should be added as a new parameter, and AVAL

should contain the transformed value.

If the intention is to redefine AVAL, BASE, CHG, etc. in terms of a transform of AVAL, then a new parameter must be added, in which PARAM describes the

transform. The creation of a new parameter results by definition in the creation of a new set of rows.

For example, as described in the discussion of Rule 1, in a change from baseline analysis of the logarithm of weight, AVAL should contain the log of weight,

BASE should contain the baseline value of the log of weight, and CHG should contain the difference between the two. PARAM should contain a description of

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

the transformed data contained in AVAL, e.g., “Log10 (Weight (kg))”. In this way the ADaM standard accommodates an analysis of transformed data in the

standard columns without creating a multiplicity of new special-purpose columns.

In Table 4.2.1.2 we see that the sponsor has chosen values of AVISITN that correspond to week number and which serve well for sorting and for plotting.

VISITNUM is the SDTM visit number.

Note that when SDTM variables, such as USUBJID, SUBJID, SITEID, VISIT, VISITNUM and --SEQ, are included in an ADaM dataset with their original

SDTM variable names, their values must not be altered in any way.

For clarity, to indicate that PARAM Log10(Weight (kg)) is derived, permissible variable PARAMTYP has been populated. PARAMTYP is not required.

Table 4.2.1.2 Illustration of Rule 2: Creation of a New Parameter to Handle a Transformation

Row

PARAM

PARAMCD

AVISIT

AVISITN

VISITNUM

ABLFL

AVAL

BASE

CHG

PARAMTYP

Weight (kg)

WEIGHT

Screening

-4

100

Weight (kg)

WEIGHT

Run-In

-2

101

100

Weight (kg)

WEIGHT

Baseline

100

Weight (kg)

WEIGHT

Week 24

100

-6

Weight (kg)

WEIGHT

Week 48

100

-8

Weight (kg)

WEIGHT

Week 52

100

-5

Log10(Weight (kg))

L10WT

Screening

-4

1.9956

DERIVED

Log10(Weight (kg))

L10WT

Run-In

-2

2.0043

DERIVED

Log10(Weight (kg))

L10WT

Baseline

DERIVED

Log10(Weight (kg))

L10WT

Week 24

1.9731

-0.0269

DERIVED

Log10(Weight (kg))

L10WT

Week 48

1.9638

-0.0362

DERIVED

Log10(Weight (kg))

L10WT

Week 52

1.9777

-0.0223

DERIVED

A related application of Rule 2 is in the case where it is necessary to support analysis and reporting in two different systems of units. In SDTM findings domains

such as LB, QS, EG, etc., the --STRESN column is the only numeric result column, and is also the only standardized numeric result column. The --ORRES

column contains a character representation of the collected result, in the collected units specified in the --ORRESU column. The --ORRES column is not

standardized. So for example, if data are typically collected in conventional units, SDTM cannot accommodate standardized data in both conventional units and

the International System of Units (SI). In SDTM, for any given --TEST, a sponsor can standardize in one system of units but not two. If one wishes to be able to

analyze standardized results in both conventional units and in SI units, a transform in an analysis dataset is needed. In each such case, a new parameter must be

created in order to accommodate standardized data in the other system of units.

The description in the PARAM column must contain the units, as well as any other information such as location and specimen type that is needed to ensure that

PARAM uniquely describes what is in AVAL, and differentiates between parameters as needed. PARAM cannot be the same for different units.

Table 4.2.1.3 shows an example of data supporting analyses of low-density lipoprotein (LDL) cholesterol in both conventional units (mg/dL) and SI units

(mmol/L). In this study, SDTM cholesterol data were standardized in mg/dL. In the analysis dataset, two records, one for each system of units, were generated

from each original SDTM record.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.3 Illustration of Rule 2: Creation of a New Parameter to Handle a Second System of Units

Row

PARAM

PARAMCD

AVISIT

AVISITN

VISITNUM

LBSEQ

ABLFL

AVAL

BASE

CHG

PCHG

LDL Cholesterol (mg/dL)

LDL

Screening

-2

2829

206.3

213.4

LDL Cholesterol (mg/dL)

LDL

Run-In

-1

2830

202.1

213.4

LDL Cholesterol (mg/dL)

LDL

Week 0

2831

213.4

0.0

0.00

LDL Cholesterol (mg/dL)

LDL

Week 5

2832

107.4

213.4

-106.0

-49.67

LDL Cholesterol (mg/dL)

LDL

Week 11

2833

90.2

213.4

-123.2

-57.73

LDL Cholesterol (mg/dL)

LDL

Week 17

2834

96.8

213.4

-116.6

-54.64

LDL Cholesterol (mg/dL)

LDL

Week 23

2835

104.0

213.4

-109.4

-51.27

LDL Cholesterol (mmol/L)

LDLT

Screening

-2

2829

5.3349

5.5185

LDL Cholesterol (mmol/L)

LDLT

Run-In

-1

2830

5.2263

5.5185

LDL Cholesterol (mmol/L)

LDLT

Week 0

2831

5.5185

0.0000

0.00

LDL Cholesterol (mmol/L)

LDLT

Week 5

2832

2.7773

5.5185

-2.7412

-49.67

LDL Cholesterol (mmol/L)

LDLT

Week 11

2833

2.3326

5.5185

-3.1859

-57.73

LDL Cholesterol (mmol/L)

LDLT

Week 17

2834

2.5032

5.5185

-3.0153

-54.64

LDL Cholesterol (mmol/L)

LDLT

Week 23

2835

2.6894

5.5185

-2.8291

-51.27

Rule 3. A function of one or more rows within the same parameter for the purpose of creating an analysis timepoint should be

added as a new row for the same parameter.

For analysis purposes, there is often a need to impute missing data, or to create a derived conceptual timepoint. Such derivations should result in the creation of

new derived records within the same parameter.

As a general rule, when a record is derived from a single record in the dataset, retain on the derived record any variable values from the original record that do

not change and that make sense in the context of the new record (e.g., --SEQ, VISIT, VISITNUM, --TPT, covariates, etc.) When a record is derived from

multiple records, then retain on the derived record all variable values that are consistent across the original records, do not change, and that make sense in the

context of the new record. Note that there are situations in which retention of values from an original record or records would make no sense on the derived

record; in such cases, do not retain those values.

For example, suppose that the analysis endpoint value is defined as the average of last two available postbaseline values. In this case, a new row should be

added, with a corresponding description in AVISIT, and the DTYPE (derivation type) column should contain a description on that row such as “AVERAGE” to

indicate both that the row was derived, and also the derivation method. The metadata associated with AVISIT=Endpoint should adequately describe which

records are used in the definition of the average. Note that even though the set of records for the log transformation of weight are derived, DTYPE is not

populated for every row. DTYPE should be used to indicate rows that are derived within a given value of PARAM and is not to be used as an indication of

whether the record exists in SDTM. Permissible variable PARAMTYP may be used to indicate that an entire parameter is derived.

In Table 4.2.1.4, VISITNUM is not retained on the derived record because VISITNUM is not constant on the precursor records, and also makes no sense in the

derived analysis timepoint, which is an average that in most cases will span multiple VISITs. Similarly VSSEQ is not constant across multiple original records,

so VSSEQ is not populated on the derived record. PARAM and BASE should be retained because they are constant on the precursor records and make sense in

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

the context of the new record. For the new record, AVAL and change are recalculated, and AVISIT, AVISITN, and DTYPE are populated appropriately. Note

that the metadata will specify the algorithm used for the calculation (in this example, the rows being averaged).

AVISIT and AVISITN are defined by the sponsor. AVISIT and AVISITN are not necessarily defined the same for the individual parameters within a dataset. The

definition and derivation of the values of AVISIT, and any dependence on parameter, should be described in metadata. In this example, the sponsor decided to set

AVISITN to 9999 on the derived AVISIT=Endpoint records.

Table 4.2.1.4 Illustration of Rule 3: Creation of a New Row to Handle a Derived Analysis Timepoint

Row

PARAM

AVISIT

AVISITN

VISITNUM

VSSEQ

ABLFL

AVAL

BASE

CHG

PARAMTYP

DTYPE

Weight (kg)

Screening

-4

1164

100

Weight (kg)

Run-In

-2

1165

101

100

Weight (kg)

Baseline

1166

100

Weight (kg)

Week 24

1167

100

-6

Weight (kg)

Week 48

1168

100

-8

Weight (kg)

Week 52

1169

100

-5

Weight (kg)

Endpoint

9999

93.5

100

-6.5

AVERAGE

Log10(Weight (kg))

Screening

-4

1164

1.9956

DERIVED

Log10(Weight (kg))

Run-In

-2

1165

2.0043

DERIVED

Log10(Weight (kg))

Baseline

1166

DERIVED

Log10(Weight (kg))

Week 24

1167

1.9731

-0.0269

DERIVED

Log10(Weight (kg))

Week 48

1168

1.9638

-0.0362

DERIVED

Log10(Weight (kg))

Week 52

1169

1.9777

-0.0223

DERIVED

Log10(Weight (kg))

Endpoint

9999

1.9708

-0.0292

DERIVED

AVERAGE

An extension of rule 3 is necessary in the case where there is value-level (record-level) population flagging. For example, assume the Statistical Analysis Plan

states that if the subject is off drug for seven days prior to a visit, the measurement collected at that visit is not included in the per-protocol analysis. Then for

some subjects, the last two available values may be different for Intent-to-Treat and for Per-Protocol analyses, so that the calculated endpoint averages would be

different. For such subjects, two distinct derived endpoint rows would be needed, the appropriate row for each analysis indicated by the record-level population

flags ITTRFL and PPROTRFL.

In Table 4.2.1.5, the analyzed endpoint value varies according to the population. For example, for PARAM=Weight (kg), the last two available ITT values are 92

and 95, whose average is 93.5; whereas the last two Per-Protocol values are 94 and 92, whose average is 93. That is why two derived Endpoint rows are required

for this subject. For other subjects, the ITT and Per-Protocol data that are input to the Endpoint average may be the same; in that case, only one Endpoint record

would be needed, on which ITTRFL and PPROTRFL would both be set to Y. Values of AVISIT and AVISITN are sponsor-controlled. As in the example in Table

4.2.1.4, the sponsor decided to set AVISITN to 9999 on the derived AVISIT=Endpoint records. Note that the metadata will specify the algorithm used for the

calculation (in this example, the rows being averaged).

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.5 Illustration of Rule 3: Creation of New Rows to Handle a Derived Analysis Timepoint When There is Value-Level Population Flagging

Row

PARAM

AVISIT

AVISITN

VISITNUM

VSSEQ

ABLFL

AVAL

BASE

CHG

DTYPE

ITTRFL

PPROTRFL

Weight (kg)

Screening

-4

1164

100

Weight (kg)

Run-In

-2

1165

101

100

Weight (kg)

Baseline

1166

100

Weight (kg)

Week 24

1167

100

-6

Weight (kg)

Week 48

1168

100

-8

Weight (kg)

Week 52

1169

100

-5

Weight (kg)

Endpoint

9999

93.5

100

-6.5

AVERAGE

Weight (kg)

Endpoint

9999

100

-7

AVERAGE

Log10 (Weight (kg))

Screening

-4

1164

1.9956

Log10 (Weight (kg))

Run-In

-2

1165

2.0043

Log10 (Weight (kg))

Baseline

1166

Log10 (Weight (kg))

Week 24

1167

1.9731

-0.0269

Log10 (Weight (kg))

Week 48

1168

1.9638

-0.0362

Log10 (Weight (kg))

Week 52

1169

1.9777

-0.0223

Log10 (Weight (kg))

Endpoint

9999

1.9708

-0.0292

AVERAGE

Log10 (Weight (kg))

Endpoint

9999

1.9685

-0.0315

AVERAGE

In the example in Table 4.2.1.6, missing post-baseline values are imputed by last observation carried forward, and also by worst observation carried forward.

In this study, at Week 8, there is a scheduled visit (visit number 6). At that visit, blood pressure should be collected. However, for this subject, either there was

no visit 6, or there was a visit 6, but no data on blood pressure were collected. The SAP says that missing postbaseline data should be imputed (derived) by two

methods: LOCF (last observation carried forward), and WOCF (worst observation carried forward).

For LOCF analysis, the missing Week 8 (VISITNUM 6) result is imputed by carrying forward the most recent prior available postbaseline value, which is the

VISITNUM 5 value. That the Week 8 value is imputed is indicated by LOCF in the derivation type (DTYPE) column.

For WOCF analysis, even though the unscheduled VISITNUM 4.1 value was not chosen to represent the Week 2 analysis timepoint, it is used to impute the

missing Week 8 timepoint because it was the worst postbaseline result up to that point.

The exact algorithms employed in the record derivation methods (LOCF and WOCF in this case) must be indicated in the metadata for DTYPE.

Traceability is enhanced by the addition of the SDTM VISITNUM and --SEQ columns. The combination of USUBJID and VSSEQ provides a link to the exact

input record in the SDTM VS domain. On the derived LOCF and WOCF rows, VISITNUM and VSSEQ provide clarity about where the value came from.

There are several other concepts presented in this example. Analysis relative day (ADY) in this protocol is defined relative to date of first dose. In many but not

all protocols, ADY would equal the value of the SDTM --DY variable (or --STDY for some kinds of data). The data presented here illustrate that this particular

subject did not take drug until two days after randomization, so the value of ADY is -2 at the randomization visit, Visit 3 (VISITNUM 3). As is the case for

SDTM study day, there is no day 0 for ADY.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

In this protocol, if there are multiple data points within an analysis time window, the value that is observed closest to a pre-specified target planned relative day is

the value that is chosen to represent the analysis timepoint. For this study and parameter, AWTARGET = VISITDY (Planned Study Day) from SDTM, and

ADY=VSDY. AWTDIFF is the absolute value of ADY - AWTARGET, adjusted for the fact that there is no day 0 (so that if ADY and AWTARGET have

different signs, then AWTDIFF = |ADY - AWTARGET - 1| ).

For AVISIT=Week 2, there were two values observed, at study days 13 and 17 (rows 4 and 5). Day 13 is closer to the target, day 14. So the day 13 record (row

4) is chosen for analysis, as denoted by the analyzed record flag ANL01FL = Y. ANL01FL is used in conjunction with other selection variables in order to obtain

the exact set of records used for analysis.

AVISIT by itself functions as a description of an analysis time window. AVISIT, DTYPE, and ANL01FL are all needed to identify the records to be used in a

given analysis.

On the derived AVIST=Week 8 records, AWTARGET was set to the target for Week 8, and AWTDIFF was calculated accordingly. It did not make sense to retain

the values of AWTARGET and AWTDIFF from the original records.

Table 4.2.1.6 Illustration of Rule 3: Creation of New Rows to Handle Imputation of Missing Values by Last Observation Carried Forward and Worst

Observation Carried Forward

Row

PARAM

AVISIT

AVISITN

VISITNUM

VSSEQ

ABLFL

AVAL

BASE

CHG

DTYPE

ADY

AWTARGET

AWTDIFF

ANL01FL

Systolic BP (mm Hg)

Screening

-4

3821

120

114

-30

-28

Systolic BP (mm Hg)

Run-In

-2

3822

116

114

-16

-14

Systolic BP (mm Hg)

Week 0

3823

114

-2

Systolic BP (mm Hg)

Week 2

3824

118

114

Systolic BP (mm Hg)

Week 2

4.1

3825

126

114

Systolic BP (mm Hg)

Week 4

3826

122

114

Systolic BP (mm Hg)

Week 8

3826

122

114

LOCF

Systolic BP (mm Hg)

Week 8

4.1

3825

126

114

WOCF

Systolic BP (mm Hg)

Week 12

3827

134

114

Table 4.2.1.7 contains an example of data supporting change from baseline analyses of migraine pain. In this study, missing postbaseline data are imputed by the

methods of Baseline Observation Carried Forward (BOCF) and Last Observation Carried Forward (LOCF).

When a migraine headache occurs, subjects self-administer a single dose of blinded study treatment. Subjects assess migraine pain at planned timepoints Pre-

Dose, 30 Minutes Post Dose, 1 Hour Post-Dose, and 2 Hours Post-Dose. Collected data on migraine pain are tabulated in the SDTM Clinical Findings domain.

ATPT is the analysis timepoint description. ATPTN is the analysis timepoint number. CFTPTNUM is the collected timepoint number from SDTM. AVALC

contains the pain assessment, and AVAL contains the numeric coded value of the assessment. AVAL is a one-to-one map to AVALC.

Subject 000276 did not continue to provide data after 1 Hour Post-Dose. For this subject, the 2-Hours Post-Dose planned observation must be imputed.

Subject 001863 had complete data, so no imputation was necessary.

Subject 000276 is excluded from an observed case analysis of Migraine Pain at 2 Hours Post Dose.

The data for both subjects are included in the BOCF and LOCF analyses of Migraine Pain at 2 Hours Post-Dose.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.7 Illustration of Rule 3: Creation of New Rows to Handle Imputation of Missing Values by Baseline Observation Carried Forward and Last

Observation Carried Forward

Row

USUBJID

TRTP

PARAM

ATPT

ATPTN

FATPTNUM

FASEQ

ABLFL

AVAL

AVALC

BASE

CHG

DTYPE

000276

Placebo

Migraine Pain

Pre-Dose

Severe Pain

000276

Placebo

Migraine Pain

30 Minutes Post-Dose

0.5

Moderate Pain

-1

000276

Placebo

Migraine Pain

1 Hour Post-Dose

Mild Pain

-2

000276

Placebo

Migraine Pain

2 Hours Post-Dose

Severe Pain

BOCF

000276

Placebo

Migraine Pain

2 Hours Post-Dose

Mild Pain

-2

LOCF

001863

Soma 30 mg

Migraine Pain

Pre-Dose

638

Severe Pain

001863

Soma 30 mg

Migraine Pain

30 Minutes Post-Dose

0.5

639

Mild Pain

-2

001863

Soma 30 mg

Migraine Pain

1 Hour Post-Dose

640

Mild Pain

-2

001863

Soma 30 mg

Migraine Pain

2 Hours Post-Dose

641

Mild Pain

-2

Table 4.2.1.8 contains an example of some of the columns in a dataset supporting analysis of a 2-period crossover study.

In a crossover trial design, all subjects are planned to receive all of the study treatments. The sequence of treatments is randomized. If in a study there are two

treatments in a crossover design, two treatment periods are necessary.

In this example, the planned visits are 1 (Screening and beginning of placebo run-in period), 2 (Week -2, halfway through placebo run-in period), 3 (Week 0, end

of placebo run-in and randomization), 4 (Week 4, the end of the first treatment period), and 5 (Week 8, the end of the second treatment period). Baseline is

defined in the Statistical Analysis Plan as the average of the Week -2 (VISIT 2) and Week 0 (VISIT 3) measurements. This baseline is used for the analysis of

both the first and the second crossover periods. USUBJID 0987_4252 has no VISIT 2 measurement, so the average is just the Week 0 (VISIT 3) measurement.

Within any postbaseline week window, the last observation is used to characterize that week. For example, for USUBJID 0987_3984, the VISIT 5 (row 7) value is

used to characterize AVISIT=Week 8, as opposed to the earlier VISIT 4.1 value (row 6), which was also observed during the Week 8 time window. The variable

ANL01FL is used in this study to identify the record selected for analysis when there are multiple records for a given AVISIT, and must be used in conjunction

with other selection variables in order to identify the exact set of records used in a given analysis or summary.

APERIODC is the crossover period character description.

Note that in general, APERIODC is not the same as EPOCH. APERIOD/APERIODC would not be defined for periods of time such as prebaseline during which

there is no study treatment to be analyzed. Also, it is possible in some cases that boundaries of APERIODs would not align exactly with boundaries of EPOCHs.

A simple example is a post-discontinuation record that is associated with the most recent treatment period for analysis.

TRTSEQP, from ADSL, is the planned ordering of crossover treatments. TRTP is the analyzed planned treatment for the given period. The two endpoint records

are derived only for the subjects who have data for both periods.

The conventions used in AVISITN are sponsor-defined. In this example, the sponsor has decided that AVISITN contains -8888 for the derived baseline records,

9999 for the derived endpoint records, and week number otherwise.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.8 Illustration of Rule 3: Creation of Endpoint Rows to Facilitate Analysis of a Crossover Design

Row

USUBJID

PARAMCD

AVISIT

AVISITN

VISITNUM

DTYPE

ANL01FL

0987_3984

ALT

Screening

-4

0987_3984

ALT

Week -2

-2

0987_3984

ALT

Week 0

0987_3984

ALT

Baseline

-8888

AVERAGE

0987_3984

ALT

Week 4

0987_3984

ALT

Week 8

4.1

0987_3984

ALT

Week 8

0987_3984

ALT

Endpoint

9999

ENDPOINT

0987_3984

ALT

Endpoint

9999

ENDPOINT

0987_4252

ALT

Screening

-4

0987_4252

ALT

Week 0

0987_4252

ALT

Baseline

-8888

AVERAGE

0987_4252

ALT

Week 4

0987_4252

ALT

Week 8

0987_4252

ALT

Endpoint

9999

ENDPOINT

0987_4252

ALT

Endpoint

9999

ENDPOINT

Row

TRTP

APERIOD

APERIODC

TRTSEQP

AVAL

ABLFL

BASE

CHG

1 (cont)

Drug B, Drug A

2 (cont)

Drug B, Drug A

3 (cont)

Drug B, Drug A

4 (cont)

Drug B, Drug A

5 (cont)

Drug B

Period 1

Drug B, Drug A

-3

6 (cont)

Drug A

Period 2

Drug B, Drug A

-7

7 (cont)

Drug A

Period 2

Drug B, Drug A

-5

8 (cont)

Drug B

Period 1

Drug B, Drug A

-3

9 (cont)

Drug A

Period 2

Drug B, Drug A

-5

10 (cont)

Drug A, Drug B

11 (cont)

Drug A, Drug B

12 (cont)

Drug A, Drug B

13 (cont)

Drug A

Period 1

Drug A, Drug B

14 (cont)

Drug B

Period 2

Drug A, Drug B

15 (cont)

Drug A

Period 1

Drug A, Drug B

16 (cont)

Drug B

Period 2

Drug A, Drug B

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Rule 4. A function of multiple rows within a parameter should be added as a new parameter.

Rule 4 is a special case of Rule 2. The functions covered by this rule violate the second condition of Rule 1 (they are not same-row functions of AVAL), and may

also violate the first and third conditions.

For example, in a clinical trial of a Human Immunodeficiency Virus (HIV) vaccine, blood samples are drawn at each visit, and CD4 cell count is measured. To

assess efficacy, it is important to look at the cumulative effect over time on CD4 cell count during follow-up after administration.

Let AVAL(t) equal the value of CD4 cell count at postbaseline visit t, and let VISITDY(t) be the planned study day of visit t.

CD4AUC (cumulative daily CD4 count over follow-up) is calculated at any given postbaseline visit as follows:

CD4AUC at baseline visit is set to 0.

CD4AUC(t) = CD4AUC(t-1) + [ 0.5 * AVAL(t-1) + 0.5 * AVAL(t) ] * [ VISITDY(t) - VISITDY(t-1) ].

CD4AUC is not a simple same-row function of BASE and AVAL. It is calculated based on data from multiple observations (rows) of CD4 data, so it should be

added as a new parameter rather than as a new column. CD4AUC is not defined pre-baseline, which is why there is no Week -1 for this parameter.

CD4AUCMB (cumulative average change from baseline in daily CD4 count over follow-up) is calculated as

CD4AUCMB(t) = CD4AUC(t) / [ VISITDY(t) - 1 ] - baseline value of CD4 cell count.

CD4AUCMB is a function of both CD4AUC and the baseline value of CD4, so it also must be its own parameter (see Rule 5 below). CD4AUCMB is not

defined for pre-baseline and baseline records and therefore these records are not represented within this value of PARAM.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.9 Illustration of Rule 4: Creation of a New Parameter to Handle a Function of More Than One Row of a Parameter

Row

PARAM

PARAMCD

AVISIT

VISITDY

ABLFL

AVAL

BASE

CD4 (cells/mm3)

CD4

Week -1

-7

CD4 (cells/mm3)

CD4

Week 0

CD4 (cells/mm3)

CD4

Week 2

128

CD4 (cells/mm3)

CD4

Week 4

125

CD4 (cells/mm3)

CD4

Week 8

191

CD4 (cells/mm3)

CD4

Week 12

167

CD4 (cells/mm3)

CD4

Week 16

113

136

CD4 Cumulative AUC

CD4AUC

Week 0

CD4 Cumulative AUC

CD4AUC

Week 2

1428

CD4 Cumulative AUC

CD4AUC

Week 4

3199

CD4 Cumulative AUC

CD4AUC

Week 8

7623

CD4 Cumulative AUC

CD4AUC

Week 12

12635

CD4 Cumulative AUC

CD4AUC

Week 16

113

16877

CD4 Cumulative AUCMB

CD4AUCMB

Week 2

CD4 Cumulative AUCMB

CD4AUCMB

Week 4

38.25

CD4 Cumulative AUCMB

CD4AUCMB

Week 8

60.125

CD4 Cumulative AUCMB

CD4AUCMB

Week 12

74.4167

CD4 Cumulative AUCMB

CD4AUCMB

Week 16

113

74.6875

Rule 5. A function of more than one parameter should be added as a new parameter.

There is often a need to derive for analysis a parameter that was not collected. Such parameters may be quite complex functions of data from multiple SDTM

domains and domain classes. Rule 5 addresses the case where a parameter is derived from other parameters already present in the dataset.

For example, a questionnaire total domain score is calculated as a function of more than one observed question. The total domain score should be added as a new

parameter, with its corresponding set of derived rows. For this derived parameter, the value of PARAM would be e.g., “Total Domain Score”, and the value of

the total domain score would be stored in the standard AVAL column, the baseline value would be stored in the standard BASE column, change from baseline

would be stored in CHG, as usual.

In the example in Table 4.2.1.10, blood samples are drawn at every visit, and laboratory test measurements of total cholesterol and high-density lipoprotein

cholesterol are found in the SDTM LB domain. The protocol calls for analysis of each individual lab analyte, and also for an analysis of the ratio of total

cholesterol (C) to high-density lipoprotein (HDL) cholesterol. The analysis dataset contains parameters for each of the two measured lab tests, as well as a new

set of derived rows where the description in PARAM is “Total Cholesterol:HDL-C ratio”, and AVAL contains the calculated ratio at each timepoint.

The analysis of percent change from baseline (PCHG) is of interest for all three parameters and is therefore populated on all records. In general, however, if

percent change is not analyzed for a particular value of PARAM, then it is not necessary to populate PCHG for those rows.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.10 Illustration of Rule 5: Creation of New Parameter to Handle a Function of More Than One Parameter

Row

PARAM

PARAMCD

AVISIT

AVISITN

VISITNUM

LBSEQ

ABLFL

AVAL

BASE

CHG

PCHG

Total Cholesterol (mg/dL)

CHOL

Screening

-2

39394

265

266

Total Cholesterol (mg/dL)

CHOL

Run-In

-1

25593

278

266

Total Cholesterol (mg/dL)

CHOL

Week 0

23213

266

0.000

Total Cholesterol (mg/dL)

CHOL

Week 2

32952

259

266

-7

-2.632

Total Cholesterol (mg/dL)

CHOL

Week 4

12768

235

266

-31

-11.654

Total Cholesterol (mg/dL)

CHOL

Week 8

18773

242

266

-24

-9.023

Total Cholesterol (mg/dL)

CHOL

Week 12

28829

217

266

-49

-18.421

High-Density Lipoprotein Chol (mg/dL)

HDL

Screening

-2

32437

High-Density Lipoprotein Chol (mg/dL)

HDL

Run-In

-1

26884

High-Density Lipoprotein Chol (mg/dL)

HDL

Week 0

52657

0.000

High-Density Lipoprotein Chol (mg/dL)

HDL

Week 2

38469

2.381

High-Density Lipoprotein Chol (mg/dL)

HDL

Week 4

12650

11.905

High-Density Lipoprotein Chol (mg/dL)

HDL

Week 8

24345

9.524

High-Density Lipoprotein Chol (mg/dL)

HDL

Week 12

23484

11.905

Total Cholesterol:HDL-C ratio

CHOLH

Screening

-2

6.023

6.333

Total Cholesterol:HDL-C ratio

CHOLH

Run-In

-1

6.950

6.333

Total Cholesterol:HDL-C ratio

CHOLH

Week 0

6.333

0.000

Total Cholesterol:HDL-C ratio

CHOLH

Week 2

6.023

6.333

-0.310

-4.896

Total Cholesterol:HDL-C ratio

CHOLH

Week 4

5.000

6.333

-1.333

-21.053

Total Cholesterol:HDL-C ratio

CHOLH

Week 8

5.261

6.333

-1.072

-16.934

Total Cholesterol:HDL-C ratio

CHOLH

Week 12

4.617

6.333

-1.716

-27.100

Rule 6. When there is more than one definition of baseline, each additional definition of baseline requires the creation of its

own set of rows.

In case there is more than one definition of baseline, new rows must be created for each additional alternative definition of baseline. There will therefore be

multiple sets of rows, where each set of rows corresponds to a particular definition of baseline. Whenever there is more than one definition of baseline, the

BASETYPE column is required. BASETYPE identifies the definition of baseline that corresponds to the value of BASE in each row. There is only one BASE

column, and only one column for each qualifying function of AVAL and BASE.

The example in Table 4.2.1.11 presents a dataset supporting shift analysis from three different baselines. Accordingly, it makes use of the BASETYPE variable

described above. The ANRIND, BNRIND, and SHIFTy variables are also illustrated.

For space reasons, the ANLzzFL variable is not shown, although it would be needed to identify which record is selected in cases of multiple observed records

within an analysis timepoint, as is the case for AVISIT=WEEK 12 (DB) for this subject and parameter.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.2.1.11 Illustration of Rule 6: Creation of New Rows to Handle Multiple Baseline Definitions

Row

BASETYPE

EPOCH

AVISIT

VISIT

AVAL

ANRLO

ANRHI

ANRIND

ABLFL

BASE

BNRIND

SHIFT1

RUN-IN

BASELINE (RUN-IN)

BASELINE

34.5

15.4

48.5

NORMAL

34.5

NORMAL

RUN-IN

WEEK 8 (RUN-IN)

DAY 57

11.6

15.4

48.5

LOW

34.5

NORMAL

NORMAL to LOW

RUN-IN

END POINT (RUN-IN)

DAY 57

11.6

15.4

48.5

LOW

34.5

NORMAL

NORMAL to LOW

RUN-IN

STABILIZATION

WEEK 14 (STAB.)

DAY 99

13.1

15.4

48.5

LOW

34.5

NORMAL

NORMAL to LOW

RUN-IN

STABILIZATION

END POINT (STAB.)

DAY 99

13.1

15.4

48.5

LOW

34.5

NORMAL

NORMAL to LOW

RUN-IN

DOUBLE BLIND

BASELINE (DB)

DAY 99

13.1

15.4

48.5

LOW

34.5

NORMAL

NORMAL to LOW

RUN-IN

DOUBLE BLIND

WEEK 12 (DB)

DAY 184

13.7

15.4

48.5

LOW

34.5

NORMAL

NORMAL to LOW

RUN-IN

DOUBLE BLIND

WEEK 12 (DB)

VISIT 98

19.7

15.4

48.5

NORMAL

34.5

NORMAL

NORMAL to NORMAL

RUN-IN

DOUBLE BLIND

END POINT (DB)

VISIT 98

19.7

15.4

48.5

NORMAL

34.5

NORMAL

NORMAL to NORMAL

RUN-IN

OPEN LABEL

BASE (OPEN)

VISIT 98

19.7

15.4

48.5

NORMAL

34.5

NORMAL

NORMAL to NORMAL

RUN-IN

OPEN LABEL

WEEK 24 (OPEN)

DAY 169

28.1

15.4

48.5

NORMAL

34.5

NORMAL

NORMAL to NORMAL

RUN-IN

OPEN LABEL

ENDPOINT (OPEN)

DAY 169

28.1

15.4

48.5

NORMAL

34.5

NORMAL

NORMAL to NORMAL

DOUBLE-BLIND

DOUBLE BLIND

BASELINE (DB)

DAY 99

13.1

15.4

48.5

LOW

13.1

LOW

DOUBLE-BLIND

DOUBLE BLIND

WEEK 12 (DB)

DAY 184

13.7

15.4

48.5

LOW

13.1

LOW

LOW to LOW

DOUBLE-BLIND

DOUBLE BLIND

WEEK 12 (DB)

VISIT 98

19.7

15.4

48.5

NORMAL

13.1

LOW

LOW to NORMAL

DOUBLE-BLIND

DOUBLE BLIND

END POINT (DB)

VISIT 98

19.7

15.4

48.5

NORMAL

13.1

LOW

LOW to NORMAL

DOUBLE-BLIND

OPEN LABEL

BASE (OPEN)

VISIT 98

19.7

15.4

48.5

NORMAL

13.1

LOW

LOW to NORMAL

DOUBLE-BLIND

OPEN LABEL

WEEK 24 (OPEN)

DAY 169

28.1

15.4

48.5

NORMAL

13.1

LOW

LOW to NORMAL

DOUBLE-BLIND

OPEN LABEL

END POINT (OPEN)

DAY 169

28.1

15.4

48.5

NORMAL

13.1

LOW

LOW to NORMAL

OPEN LABEL

BASE (OPEN)

VISIT 98

19.7

15.4

48.5

NORMAL

19.7

NORMAL

OPEN LABEL

WEEK 24 (OPEN)

DAY 169

28.1

15.4

48.5

NORMAL

19.7

NORMAL

NORMAL to NORMAL

OPEN LABEL

END POINT (OPEN)

DAY 169

28.1

15.4

48.5

NORMAL

19.7

NORMAL

NORMAL to NORMAL

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.3 Inclusion of All Observed and Derived Records for a Parameter Versus the Subset of

Records Used for Analysis

This section discusses whether the analysis dataset should include all rows of an analysis parameter, or only the subset of rows that are used for analysis. A value

of AVAL or AVALC for an analysis parameter at a specific time point may be observed (i.e., collected on the case report form or in an electronic diary at that time

point), it may be imputed because it was missing, or it may be derived from a combination of other values.

To illustrate the issue being presented, assume that the total scores for Questionnaire A (administered at Visits 1, 2, and 3) are in the SDTM QS domain as

illustrated below. Any missing total scores are imputed by carrying the last post-baseline (post-Visit 1) total score forward. The total score for visit 3 will be

analyzed.

In the SDTM QS domain data shown below, subject 0001 has data for visits 1, 2, and 3; subject 0002 will not be included in the analysis, as there are no post-

baseline data for the subject; subject 0003 has data for visits 1 and 2, but is missing data for visit 3.

Table 4.3.1 Illustration of Issue, Data as Found in SDTM QS Dataset

Row

DOMAIN

USUBJID

VISITNUM

QSSEQ

QSCAT

QSTESTCD

QSSTRESN

0001

101

QUES-A

TOTSCORE

0001

201

QUES-A

TOTSCORE

0001

555

QUES-A

TOTSCORE

0002

QUES-A

TOTSCORE

0003

156

QUES-A

TOTSCORE

0003

300

QUES-A

TOTSCORE

The questions that arise are whether or not the analysis dataset should contain data for subject 0002 even though the subject is not included in the analysis and if

the analysis dataset should contain totals for visits 1 and 2 even though the data being analyzed are from visit 3.

4.3.1 ADaM Methodology and Examples

The ADaM methodology is to include all observed and derived rows for a given analysis parameter. The inclusion of all the rows in the analysis dataset,

including those not used in the analysis, requires a way to identify the rows used in the specified analysis. This approach increases the size of the dataset, and

introduces a risk that users will not incorporate the appropriate selection criteria and thereby generate incorrect analysis results. The advantage is that the

inclusion of all rows makes it easier to verify that the selection and derived time-point processing was done correctly, thus providing useful traceability. In

addition, the data are also then available to enable other analyses, including sensitivity analyses.

Regulatory reviewers prefer that the path followed in creating and/or selecting analysis rows be clearly delineated and traceable all the way back to the

originating rows in the SDTM domain, if possible and within reason. Simply including the algorithm in the metadata is often not sufficient, as any complicated

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

data manipulations may not be clearly identified (e.g., how missing pieces of the input data were handled). Retaining in one dataset all of the observed and

derived rows for the analysis parameter provides the clearest traceability in the most flexible manner within the standard BDS. The resulting dataset also

provides the most flexibility for reviewers to test the robustness of an analysis (e.g., using a different imputation method).

Example 1

In the example discussed above (Table 4.3.1), the analysis dataset would contain the following rows (Table 4.3.1.1) for the total score parameter:

Table 4.3.1.1 Example 1: Analysis Dataset

Row

PARAMCD

USUBJID

VISITNUM

AVISITN

AVISIT

AVAL

DTYPE

TOTSCORE

0001

Visit 1

TOTSCORE

0001

Visit 2

TOTSCORE

0001

Visit 3

TOTSCORE

0002

Visit 1

TOTSCORE

0003

Visit 1

TOTSCORE

0003

Visit 2

TOTSCORE

0003

Visit 3

LOCF

For the analysis discussed above, the data to be analyzed are selected by specifying that AVISITN = 3 (or AVISIT=Visit 3).

It should be noted that this approach does not require the inclusion of all rows from the input dataset. For example, if the input dataset contains data for several

different questionnaires, the extraneous data (e.g., for questionnaires other than the one being addressed) do not have to be included in the analysis dataset.

Example 2

In the following example (Table 4.3.1.2 and Table 4.3.1.3), the Q01 assessment is scheduled to be performed at visits 1, 3, 5, and 7, and results are to be

summarized at those visits. Subject 1099 has data for the assessment at visits 1, 2, and 7. (Note that though the assessment was not scheduled to be performed at

Visit 2, the data show the assessment was performed at that time for that subject.) Subject 2001 is not in the Full Analysis Set. Subject 3023 has two assessments

at visit 5, and the study’s analysis plan specifies that only the first occurrence within a visit will be analyzed; however, as this subject does not have a visit 7 row

in the data, the later of the visit 5 rows is carried forward into visit 7. The SDTM domain that is the basis for the analysis dataset has the following rows:

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.3.1.2 Example 2: Data as Found in SDTM QS Dataset

Row

QSTESTCD

USUBJID

QSSEQ

VISITNUM

VISIT

QSSTRESN

QSDTC

Q01

1099

111

BASELINE

2005-04-04

Q01

1099

121

VISIT 2

2005-05-02

Q01

1099

132

VISIT 7

2005-08-22

Q01

2001

150

BASELINE

2005-02-05

Q01

3023

117

BASELINE

2005-06-30

Q01

3023

123

VISIT 3

2005-07-25

Q01

3023

134

VISIT 5

2005-08-20

Q01

3023

135

VISIT 5

2005-08-21

The analysis dataset contains rows corresponding to those found in SDTM as well as rows created by LOCF for the missing visit assessments, together with the

flags and other columns needed to identify the rows to be included in a given analysis:

Table 4.3.1.3 Example 2: Analysis Dataset

Row

USUBJID

VISITNUM

VISIT

AVISITN

AVISIT

AVAL

DTYPE

ANL01FL

FASFL

1099

BASELINE

1099

VISIT 2

1099

VISIT 2

VISIT 3

LOCF

1099

VISIT 2

VISIT 5

LOCF

1099

VISIT 7

2001

BASELINE

3023

BASELINE

3023

VISIT 3

3023

VISIT 5

3023

VISIT 5

3023

VISIT 7

LOCF

Selection criteria applicable to this example include:

DTYPE null identifies the data as found in the SDTM domain.

DTYPE=“LOCF” specifies the method used to derive the added rows, and indicates that those rows were derived.

FASFL=“Y” identifies the subjects who are members of the Full Analysis Set.

ANL01FL=“Y” identifies the rows chosen to represent each AVISIT. There were multiple observations for subject 3023 at AVISITN=5 and therefore in this

example, rows with ANL01FL=“Y” are the ones that have been chosen to represent their respective analysis timepoints.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

ANL01FL=null for subject 1099 for VISIT=“VISIT 2” (row 2) because visit 2 is an unscheduled visit for this questionnaire and Visit 2 will not be presented

in the analyses; AVISITN and AVISIT are also null because visit 2 will not be analyzed per the study’s analysis plan.

“(ANL01FL=“Y” and FASFL=“Y” and AVISITN=5)” identifies the rows used in a FAS analysis of Visit 5 data.

Approaches Considered and Not Adopted

The other approach considered was to include in the analysis dataset only the rows that are actually used in the analysis of the analysis parameter. In Example 1

above, only Visit 3 rows that were either observed or derived by LOCF would be included in the analysis dataset. The main advantage of this approach would be

to simplify the analysis, as no selection clause would need to be used to identify the appropriate rows for inclusion in the analysis. However, the primary

disadvantages would be the loss of traceability and the loss of flexibility for reviewers to test the robustness of the analysis. Because of these disadvantages, this

approach was not chosen.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.4 Inclusion of Input Data that are not Analyzed but that Support a Derivation in the Analysis

Dataset

Section 4.3 states that for a given analysis parameter, all observed and derived rows of that parameter should be included in the dataset, not just the rows that are

used in the analysis.

Section 4.3 is a simple case of a more general question addressed here in Section 4.4.

This section addresses the broader issue if whether an analysis dataset should contain the input data used in the derivation of the analysis data as well as the

actual data being analyzed. This includes:

Input data rows and columns to support traceability of the derivation of analyzed rows and columns, and

Raw or derived predecessor parameters that are not analyzed themselves but are used to derive an analyzed parameter.

The above input data rows and columns could come from one SDTM domain or multiple domains as necessary to derive the analysis data captured in the

analysis variable, as described by the analysis parameter.

4.4.1 ADaM Methodology and Examples

Analysis datasets are developed to facilitate intended analyses. SDTM is provided as source data; therefore, it is logical for reviewers to expect some level of

traceability between SDTM domain(s) and analysis dataset(s).

The ADaM methodology to achieve the expected traceability is to describe the derivation algorithms in the metadata and, if practical and feasible, to include

supportive rows as appropriate for traceability. To include the input data as rows in the analysis dataset, columns should be added where feasible to indicate the

source of the input data – domain, variable name, and sequence number. While this methodology increases both the size of the dataset and the complexity of

selecting the appropriate rows for analysis, it also provides input data in an immediately accessible manner. In addition, intermediate values can be retained if

appropriate flags are used to distinguish them.

In general, it is strongly recommended to include as much supporting data as is needed for traceability. However, there are situations in which it may not be

practical. For example, if an analyzed parameter is a summary derived from a very large number of raw e-diary input records, it may be neither useful nor

practical to include all of the raw e-diary records as rows in the analysis dataset.

The remainder of this section addresses cases where the analysis datasets contain not only the analysis data but also input data that are necessary to provide

clearer traceability of the algorithms used to derive the analysis data. In addition to the actual values used in the analysis, the dataset may include rows not used

in the analysis, rows containing input data, and rows containing intermediate values computed during the derivation of the analysis data. Flags or other columns

are used to distinguish the various data types as well as to provide a traceable path from the input data to the value used in the analysis. The analysis results

metadata specify how the appropriate rows are identified (by a specific selection clause). The identification of rows used in an analysis is addressed in Sections

4.5 and 4.6.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Unless the input data are already present as column(s) on the row (e.g., as covariate(s) or supportive variable(s)), the input data will be retained as rows in the

analysis dataset. The analysis value column (AVAL and/or AVALC) on the retained input data row will contain a value for the analysis parameter. Not all

columns from the input dataset are carried into the analysis dataset; instead additional variables will be included indicating the source of the input data – domain,

variable name, and sequence number. This approach will allow the inclusion of input data from multiple domains. If the input data are already included in

columns on the analysis parameter row (e.g., as covariates or supportive information), there is no need to include additional rows for those input data. The

decision on keeping the input data as rows or columns will therefore be dictated by the types of input data and whether they are used for other purposes in the

analysis dataset.

Retaining in one dataset all data used in the determination of the analysis parameter value will provide the clearest traceability in the most flexible manner within

the standard ADaM BDS. This large dataset also provides the most flexibility for the reviewers in testing the robustness of an analysis.

If it is determined that this large dataset is too cumbersome, the sponsor can choose to provide two datasets, one that contains all rows and another that is a subset

of the first, containing only the rows used in the specified analysis. To ensure traceability, the metadata for the subset analysis dataset will refer back to the full

analysis dataset as the immediate predecessor. Though this approach provides the needed traceability as well as providing a dataset that can be used in an

analysis without specifying a selection clause, the total file size is even larger. More importantly, the developer will need to ensure consistency is maintained

between the two datasets and validation will need to be done for both datasets. There is also potential confusion about which dataset supported an analysis, if

analysis results metadata is not provided for that analysis.

Example 1

An analysis dataset is created to support time-to-event analysis of a hypertension event. The analysis parameter is the study day of a hypertension event, defined

to be the earliest study day among those of the following events: hospital admission, diastolic blood pressure exceeded 90, and systolic blood pressure exceeded

140. If a subject does not experience any of these events, the subject will be analyzed as censored on the day he/she exited the study.

Table 4.4.1.1 Example 1: Data as Found in SDTM VS Dataset

Row

USUBJID

VISITNUM

VSSEQ

VSDTC

VSDY

VSTESTCD

VSSTRESN

2010

2004-08-05

SYSBP

115

2010

2004-08-05

DIABP

2010

101

2004-08-12

SYSBP

120

2010

102

2004-08-12

DIABP

2010

207

2004-08-19

SYSBP

135

2010

208

2004-08-19

DIABP

2010

238

2004-08-25

SYSBP

138

2010

239

2004-08-25

DIABP

3082

2004-09-08

SYSBP

120

3082

2004-09-08

DIABP

3082

119

2004-09-15

SYSBP

125

3082

120

2004-09-15

DIABP

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.4.1.2 Example 1: Data as Found in SDTM DS Dataset

Row

USUBJID

DSSEQ

DSSTDTC

DSSTDY

DSDECOD

DSTERM

2010

2004-08-05

RANDOM

Subject Randomized

2010

2004-08-13

HOSPSTRT

Subject Hospitalized

2010

140

2004-08-15

HOSPEND

Subject Discharged from Hospital

2010

199

2004-08-20

HOSPSTRT

Subject Hospitalized

2010

225

2004-08-22

HOSPEND

Subject Discharged from Hospital

2010

301

2004-08-26

COMPLETED

Subject Completed

3082

2004-09-08

RANDOM

Subject Randomized

3082

130

2004-09-17

COMPLETED

Subject Completed

The analysis dataset contains the sub-event data used to derive the analysis parameter “HYPEREVT”.

The ADaM methodology is illustrated in Table 4.4.1.3. Using this methodology, one would include all of the sub-events as analysis parameters (i.e., rows) and

create the input domain, input variable, and input sequence columns (SRC* columns) to identify where the input rows came from. AVAL for

PARAMCD=“HOSPADM” is the earliest relative day of hospitalization. AVAL for PARAMCD=“DBP” is the earliest relative day that diastolic blood pressure

exceeded 90. AVAL for PARAMCD=“SBP” is the earliest relative day that systolic blood pressure exceeded 140. If a subject did not experience a particular

sub-event, a row is still created for that sub-event indicating the subject was censored (CNSR=1) on the day the subject exited the study and the SRC* columns

reference the DS dataset. AVAL for PARAMCD=“HYPEREVT” is derived as the earliest event of the three: HOSPADM, DBP, and SBP (the minimum AVAL of

those three that have CNSR=0 will be the earliest relative day of the three types of events); a subject who meets one of these three conditions has CNSR=0 for

PARAMCD=“HYPEREVT” to indicate the subject had an event. If a subject does not meet one of the three conditions (i.e., all three records have CNSR=1),

then the subject is censored; that is, AVAL for PARAMCD=“HYPEREVT” is derived as the relative day that the subject exited the study and CNSR=1 is used to

indicate the subject is censored. The analysis will focus on HYPEREVT, but HOSPADM, DBP and SBP are included to support traceability, and also to enable

future analysis of the sub-events should it be desired.

The main advantage of this structure is that it can handle sub-event input rows from many domains in only 3 standard supportive columns. This approach is

preferred because it is standardized, scalable, and supports analysis of sub-events.

Table 4.4.1.3 Example 1: Analysis Dataset

Row

USUBJID

PARAM

PARAMCD

AVAL

CNSR

EVNTDESC

SRCDOM

SRCVAR

SRCSEQ

2010

Time to First Hospital Admission (day)

HOSPADM

FIRST HOSPITAL ADMISSION

DSSTDY

2010

Time to First DBP>90 (day)

DBP

FIRST DBP>90

VSDY

208

2010

Time to First SBP>140 (day)

SBP

COMPLETED THE STUDY

DSSTDY

301

2010

Time to Hypertension Event (day)

HYPEREVT

HYPERTEN. EVENT

DSSTDY

3082

Time to First Hospital Admission (day)

HOSPADM

COMPLETED THE STUDY

DSSTDY

130

3082

Time to First DBP>90 (day)

DBP

COMPLETED THE STUDY

DSSTDY

130

3082

Time to First SBP>140 (day)

SBP

COMPLETED THE STUDY

DSSTDY

130

3082

Time to Hypertension Event (day)

HYPEREVT

COMPLETED THE STUDY

DSSTDY

130

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Example 2

The analysis parameter is glomerular filtration rate (GFR) estimated from serum creatinine using the MDRD Equation (Modification of Diet in Renal Disease

Study Group). The equation1 uses plasma creatinine, BUN, and albumin values from the LB domain, as well as age, race, and sex.

Table 4.4.1.4 Example 2: Data as Found in SDTM LB Dataset

Row

USUBJID

VISITNUM

LBSEQ

LBTEST

LBTESTCD

LBSTRESN

LBSTRESU

3000

Creatinine

CREAT

78.2

micromol/L

3000

115

Blood Urea Nitrogen

BUN

9.1

mmol/L

3000

120

Albumin

ALB

g/L

Additional rows are not created for the input data age, race, and sex, as they are covariates in the analysis dataset. The analysis records are identified by

PARAMCD=MDRD_GFR, the parameter code for PARAM = Glomerular Filtration Rate (GFR) (ml/min/1.73m**2) (note that to due to space limitations, the

PARAM column is not presented in Table 4.4.1.5).

Table 4.4.1.5 Example 2: Analysis Dataset

Row

USUBJID

AGE

SEX

RACE

PARAMCD

VISITNUM

AVAL

SRCDOM

SRCVAR

SRCSEQ

3000

ASIAN

CREAT

78.2

LBSTRESN

3000

ASIAN

BUN

9.1

LBSTRESN

115

3000

ASIAN

ALB

LBSTRESN

120

3000

ASIAN

MDRD_GFR

76.77

Approaches Considered and Not Adopted

A second approach that was considered was to describe the derivation algorithms in metadata and include the input data as columns in the analysis dataset.

Pointer columns would be added to indicate the source of the input data – variable name and sequence number. This option would allow all pertinent input data

to be retained on the relevant analyzed row (i.e., all sub-events would be shown on the same row as a compound event), which might help simplify verification of

the calculation of the analysis parameter. However, this approach would clearly increase the number of columns in the analysis dataset and would require

naming the variables in a clear and concise manner. The approach also assumes that the only data to be retained are the original input values. Another drawback

of this approach is that if there were a need in the future to analyze the sub-events, sub-event parameters would have to be added to have an ADaM-compliant

structure supporting the analysis of sub-events. For these reasons, this approach was not chosen.

1 MDRD_GFR = 170 * power( PlasmaCr, -.999) * power(Age, -.176) * Sex (1 if male, 0.762 if female) * Race (1.18 if Black, 1 otherwise) * power(BUN, -.170)

* power(Albumin, .318). Reference: Levey AS, Bosch JP, Lewis JB, et. al., A more accurate method to estimate glomerular filtration rate from serum

creatinine: A new prediction equation, Ann Int Med, 1999; 130:461-470. Web-based calculator found at http://medcalc3000.com/GFREstimate.htm on 25 April,

2007.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

A third approach that was considered was to describe the derivation algorithms in metadata and include no input data or identification of the input data in the

analysis dataset. The advantage to this approach would be simplification of the analysis dataset. However, due to the simplified structure, there would be a loss

of traceability between the data collected in the study (i.e., SDTM domain) and the data analyzed (i.e., analysis dataset). Unless the derivation algorithms

described in the metadata are straightforward, verification of the analysis data computation could be very challenging or even impossible. This approach should

not be used.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.5 Identification of Rows Used for Analysis

This section addresses how to identify the rows of an analysis dataset that are used for analysis. The four specific issues addressed include: 1) identification of

the rows used in a last observation carried forward (LOCF) analysis ; 2) identification of the row containing the baseline value; 3) identification of post-baseline

conceptual timepoint rows, such as endpoint, minimum, maximum, or average ; and 4) identification of specific rows used in an analysis.

4.5.1 Identification of Rows Used in a Timepoint Imputation Analysis

This section considers the issue of how to identify rows used in a timepoint-related imputation analysis as well as how to represent data imputed for missing

timepoints in an analysis dataset. Last observation carried forward (LOCF) is one of the most commonly used timepoint-related imputation analyses, and is

therefore specifically mentioned. However, the methodology is general and is not restricted to LOCF analysis. Worst observation carried forward (WOCF)

analysis is also mentioned to emphasis the generalizability.

4.5.1.1 ADaM Methodology and Examples

When an analysis timepoint is missing, the ADaM methodology is to create a new row in the analysis dataset to represent the missing timepoint and identify

these imputed rows by populating the derivation type variable DTYPE.

For example, when an LOCF/WOCF analysis is being performed, create LOCF/WOCF rows when the LOCF/WOCF analysis timepoints are missing, and

identify these imputed rows by populating the derivation type variable DTYPE with values LOCF or WOCF. All of the original rows would have null values in

DTYPE. It would be very simple to select the appropriate rows for analysis by selecting DTYPE = null for Data as Observed (DAO) analysis, DTYPE = null or

LOCF for LOCF analysis, and DTYPE = null or WOCF for WOCF analysis. This approach would require understanding and communication that if the DTYPE

flag were not referenced correctly, the analysis would default to using all rows, including the DAO rows, plus the rows derived by LOCF and WOCF. To

perform a correct DAO analysis, one would need to explicitly select DTYPE = null.

Example 1: Identification of rows used in a LOCF analysis

In the example below (Table 4.5.1.1.1), some subjects have complete data and others have rows imputed by one method (LOCF). Subjects with no missing data

have the observed number of rows with all DTYPE values blank. Subject 1001 has complete data. DTYPE is blank for all rows indicating they are not imputed.

AVISIT matches VISIT (from SDTM) in this example. AVISIT does not always match VISIT from SDTM even in scenarios where there is no missing data.

Subject 1002 is missing the Week 2 assessment. Week 2 is imputed using the LOCF method. AVISIT=Week 2 but VISIT=Week 1 so one can see where the

imputed value came from in the original data. Subject 1003 is missing Week 2 and 3 data. A Data as Observed (DAO) analysis can be performed by selecting

only those rows where DTYPE is null. For a LOCF analysis, all rows (DTYPE=null or DTYPE=“LOCF”) should be used.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.5.1.1.1 Example 1: Analysis Dataset with Identification of Rows Used in a LOCF Analysis

Row

USUBJID

VISIT

AVISIT

ADY

PARAM

AVAL

DTYPE

1001

Baseline

-4

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

130

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1001

Week 3

SUPINE SYSBP (mm Hg)

125

1002

Baseline

-1

SUPINE SYSBP (mm Hg)

145

1002

Week 1

SUPINE SYSBP (mm Hg)

130

1002

Week 1

Week 2

SUPINE SYSBP (mm Hg)

130

LOCF

1002

Week 3

SUPINE SYSBP (mm Hg)

135

1003

Baseline

SUPINE SYSBP (mm Hg)

150

1003

Week 1

SUPINE SYSBP (mm Hg)

140

1003

Week 1

Week 2

SUPINE SYSBP (mm Hg)

140

LOCF

1003

Week 1

Week 3

SUPINE SYSBP (mm Hg)

140

LOCF

Example 2: Identification of rows used in both LOCF and WOCF analyses

This set of rows (Table 4.5.1.1.2) shows a situation where there is more than one imputation method used. In this case, additional rows are generated for each

type of imputation. A DAO analysis can be performed by selecting only those rows where DTYPE is null. For LOCF analysis, all rows with DTYPE=null or

DTYPE=“LOCF” should be used. For WOCF analysis, all rows with DTYPE=null or DTYPE=“WOCF” should be used.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.5.1.1.2 Example 2: Analysis Dataset with Identification of Rows Used in Both LOCF and WOCF Analyses

Row

USUBJID

VISIT

AVISIT

ADY

PARAM

AVAL

DTYPE

1002

Baseline

-4

SUPINE SYSBP (mm Hg)

145

1002

Week 1

SUPINE SYSBP (mm Hg)

130

1002

Week 2

SUPINE SYSBP (mm Hg)

138

1002

Week 3

SUPINE SYSBP (mm Hg)

135

1002

Week 3

Week 4

SUPINE SYSBP (mm Hg)

135

LOCF

1002

Week 2

Week 4

SUPINE SYSBP (mm Hg)

138

WOCF

1002

Week 5

SUPINE SYSBP (mm Hg)

130

1003

Baseline

-1

SUPINE SYSBP (mm Hg)

145

1003

Week 1

SUPINE SYSBP (mm Hg)

140

1003

Week 2

SUPINE SYSBP (mm Hg)

138

1003

Week 2

Week 3

SUPINE SYSBP (mm Hg)

138

LOCF

1003

Week 2

Week 4

SUPINE SYSBP (mm Hg)

138

LOCF

1003

Week 2

Week 5

SUPINE SYSBP (mm Hg)

138

LOCF

1003

Week 1

Week 3

SUPINE SYSBP (mm Hg)

140

WOCF

1003

Week 1

Week 4

SUPINE SYSBP (mm Hg)

140

WOCF

1003

Week 1

Week 5

SUPINE SYSBP (mm Hg)

140

WOCF

Approaches Considered and Not Adopted

Another approach considered is to create a complete separate set of rows for each analysis type (or a separate dataset), indicating the various analysis types by

assigning unique values of the analysis timepoint description AVISIT, e.g., “Week 4”, “Week 4 (LOCF)” and “Week 4 (WOCF)”. This approach would make it

more foolproof to perform the DAO, LOCF, and WOCF analysis in one step by referencing only AVISIT. However, because so many rows would be duplicated,

a very large dataset is one of the major disadvantages for this approach. In addition, this approach might be less tool-friendly, in that one might need to parse

AVISIT searching for a key substring, e.g., “(LOCF)”. This approach should not be used.

Create a flag (LOCFFL/LOCFFN) to indicate when a row is created by virtue of last observation carried forward; and similarly for WOCF. This is similar to the

specified ADaM methodology, except that a separate flag is created for each derivation type, rather than indicating row derivation type in one column DTYPE.

This approach might result in fewer rows than the recommended approach (for example if the WOCF row is the same as the LOCF row). In other respects, this

approach shares the advantages and disadvantages of the recommended approach. This approach of creating separate flags for each derivation type is not

recommended.

4.5.2 Identification of Baseline Rows

Many statistical analyses require the identification of a baseline value. This section describes how a record used as a baseline is identified.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.5.2.1 ADaM Methodology and Examples

The ADaM methodology is to create a baseline flag column to indicate the row used as baseline (the row whose value of AVAL is used to populate the BASE

variable). This method does not require duplication of rows in the event that the baseline row is not derived.

Though a baseline row flag variable ABLFL is created and used to identify the row that is the baseline row, this does not prohibit also providing a row with a

unique value of AVISIT, e.g., “Baseline”, designating the baseline row used for analysis, even if redundant with another row. For more complicated baseline

definitions (functions of multiple rows), a derived baseline row would have to be created in any case. This methodology requires that clear metadata be provided

for the baseline row variable so that the value can be reproduced accurately.

Example 1: Identification of baseline rows - using screening visit to impute a baseline row

This example (Table 4.5.2.1.1) illustrates the use of a baseline flag variable ABLFL. It also illustrates the inclusion of an additional row for a baseline analysis

timepoint (row 6). In this example, a unique value of AVISIT has been defined for the baseline record used for analysis. Subject 1001 had complete data. There

was no record that qualified as a baseline value for Subject 1002 in the source data. A derived baseline record (AVISIT=“Baseline”) is added with

DTYPE=“LVPD” (Last Value Prior to Dosing) to indicate that the record is imputed to be used as baseline.

Table 4.5.2.1.1 Example 1: Analysis Dataset with Identification of Baseline Rows When Imputation is Used

Row

USUBJID

VISIT

AVISIT

ADY

ABLFL

PARAM

AVAL

DTYPE

1001

Screening

-12

SUPINE SYSBP (mm Hg)

144

1001

Baseline

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

130

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1002

Screening

-14

SUPINE SYSBP (mm Hg)

144

1002

Screening

Baseline

-14

SUPINE SYSBP (mm Hg)

144

LVPD

1002

Week 1

SUPINE SYSBP (mm Hg)

130

1002

Week 2

SUPINE SYSBP (mm Hg)

133

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Example 2: Identification of baseline rows - using an average of multiple visits to derive a baseline row

This example (Table 4.5.2.1.2) illustrates the use of a baseline flag variable ABLFL to identify the record used as baseline for analysis in a scenario where the

baseline value is based on the average of the non-missing values collected prior to dosing. Row 3 is a derived “Baseline” record using the average of the values

of row 1 and row 2. DTYPE = “AVERAGE” to indicate that row 3 is derived. The Baseline flag (ABLFL=“Y”) indicates that AVAL from row 3 is used to

populate the BASE (Baseline) column. VISIT (from SDTM) is left blank on row 3 since AVAL on that record is not merely a copy of AVAL on another record.

Table 4.5.2.1.2 Example 2: Analysis Dataset with Identification of Baseline Rows When Baseline is an Average

Row

USUBJID

VISIT

AVISIT

ADY

ABLFL

PARAM

AVAL

BASE

DTYPE

1001

Screening

-12

SUPINE SYSBP (mm Hg)

144

144.5

1001

Baseline

SUPINE SYSBP (mm Hg)

145

144.5

1001

Baseline

SUPINE SYSBP (mm Hg)

144.5

AVERAGE

1001

Week 1

SUPINE SYSBP (mm Hg)

130

144.5

1001

Week 2

-14

SUPINE SYSBP (mm Hg)

133

144.5

Example 3: Identification of baseline rows - using an average of multiple visits to derive a baseline row

This example (Table 4.5.2.1.3) is the same as Example 2 except that the analysis timepoint description “Screening/Baseline Combination” helps differentiate the

derived average baseline record from an existing observed record whose timepoint description is “Baseline.” This was helpful in analysis and reporting because

it was desired to summarize all scheduled visits in addition to the average baseline visit. The analysis was straightforward using the distinct descriptions of

AVISIT. The choice of AVISIT values is up to the sponsor.

Table 4.5.2.1.3 Example 3: Analysis Dataset with Identification of Baseline Rows, Including Description in Analysis Timepoint Variable

Row

USUBJID

VISIT

AVISIT

ADY

ABLFL

PARAM

AVAL

BASE

DTYPE

1001

Screening

-12

SUPINE SYSBP (mm Hg)

144

144.5

1001

Baseline

SUPINE SYSBP (mm Hg)

145

144.5

1001

Screening/Baseline Combination

SUPINE SYSBP (mm Hg)

144.5

AVERAGE

1001

Week 1

SUPINE SYSBP (mm Hg)

130

144.5

1001

Week 2

-14

SUPINE SYSBP (mm Hg)

133

144.5

4.5.3 Identification of Post-Baseline Conceptual Timepoint Rows

When analysis involves cross-timepoint derivations such as endpoint, minimum, maximum and average post-baseline, questions such as “Should distinct rows

with unique value of AVISIT always be created even if redundant with an observed value record, or should these rows just be flagged?” should be considered.

There are two approaches presented in this section.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.5.3.1 ADaM Methodology and Examples

The ADaM methodology is to create a new row with a unique value of AVISIT in cases where analysis is based on AVISIT. The advantage of this approach is

that it is simple and analysis friendly. It is recognized that such new rows might be redundant with observed rows for some kinds of conceptual timepoint

definitions.

Always creating a row with a unique value of AVISIT designating the row used for analysis (e.g., “Endpoint”, “Post-Baseline Minimum”, “Post-Baseline

Maximum”) has the advantage that once the AVISIT values are understood, reviewers and software can rely on these values of AVISIT. This approach represents

the general case since any such cross-timepoint derivation can be represented in a new row with a unique AVISIT description. The disadvantage is that the

dataset would contain more rows, and conventions would have to be communicated and understood.

In cases where analysis is not based on AVISIT, then either solution is valid. It is recognized that in cases where the AVISIT values are not defined in the analysis

documentation, then adding a flag may be more appropriate. Which methodology is appropriate for situations where an “analysis visit” value is not defined can

be driven by how the analysis will be performed. In cases where only a subset of data is analyzed (i.e., only on-treatment minimum values), then flagging the

values that qualify for analysis might be a better choice than creating an additional row to contain the minimum value. However, where the subset of data is

analyzed within the context of a greater pool of data, then creating an additional row to contain the minimum value would help facilitate analysis-ready usage and

review.

Example 1: Identification of Endpoint rows

This example (Table 4.5.3.1.1) shows the creation of an added row with a unique value of AVISIT designating the Endpoint record used for analysis. Subject

1001 discontinued at Week 2, and a derived Endpoint record (AVISIT=“Endpoint”) is added using the Week 2 visit. DTYPE=“LOV” (Last Observed Value)

indicates how the AVISIT=“Endpoint” record is populated. Subject 1002 did not have any post-baseline visits, and therefore has no Endpoint record.

Table 4.5.3.1.1 Example 1: Analysis Dataset with Identification of Endpoint Rows

Row

USUBJID

VISIT

AVISIT

ADY

PARAM

AVAL

DTYPE

1001

Screening

-12

SUPINE SYSBP (mm Hg)

144

1001

Baseline

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

130

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1001

Week 2

Endpoint

SUPINE SYSBP (mm Hg)

133

LOV

1002

Screening

-14

SUPINE SYSBP (mm Hg)

144

1002

Baseline

-1

SUPINE SYSBP (mm Hg)

144

Example 2: Identification of Endpoint and Post-Baseline Minimum, Maximum, and Average rows

This example (Table 4.5.3.1.2) shows the creation of rows with unique values of AVISIT designating the Endpoint record, and the Post-Baseline Minimum,

Maximum, and Average rows. Subject 1001 had minimum post-baseline result at Week 1, maximum post-baseline result at Week 2, and the average post-

baseline result was based on the average of Week 1 and Week 2. This subject discontinued at Week 2. A derived Endpoint record (AVISIT=“Endpoint”) is added

using the Week 2 visit. DTYPE=“LOV” (last observed value) indicates that the AVISIT=“Endpoint” record is a derived record. Subject 1002 did not have any

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

post-baseline visit. Therefore, the Post-Baseline Minimum, Post-Baseline Maximum, Post-Baseline Average, and Endpoint rows could not be derived for that

subject.

Table 4.5.3.1.2 Example 2: Analysis Dataset with Identification of Endpoint and Post-Baseline Minimum, Maximum, and Average Rows

Row

USUBJID

VISIT

AVISIT

ADY

PARAM

AVAL

DTYPE

1001

Screening

-12

SUPINE SYSBP (mm Hg)

144

1001

Baseline

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

130

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1001

Week 1

Post-Baseline Minimum

SUPINE SYSBP (mm Hg)

130

MINIMUM

1001

Week 2

Post-Baseline Maximum

SUPINE SYSBP (mm Hg)

133

MAXIMUM

1001

Post-Baseline Average

SUPINE SYSBP (mm Hg)

131.5

AVERAGE

1001

Week 2

Endpoint

SUPINE SYSBP (mm Hg)

133

LOV

1002

Screening

-14

SUPINE SYSBP (mm Hg)

144

1002

Baseline

-1

SUPINE SYSBP (mm Hg)

144

Example 3: Identification of Post-Baseline Minimum and Maximum rows

This example (Table 4.5.3.1.3) shows the identification of the Post-Baseline Minimum and Maximum rows. Subject 1001 had minimum post-baseline result at

Week 1 (identified with ANL01FL=Y) and maximum post-baseline result at Week 2 (identified with ANL02FL=Y). Subject 1002 did not have any post-baseline

visit. Therefore, the Post-Baseline Minimum and Post-Baseline Maximum could not be identified for that subject.

Table 4.5.3.1.3 Example 3: Analysis Dataset with Identification of Post-Baseline Minimum and Maximum Rows

Row

USUBJID

VISIT

AVISIT

ADY

PARAM

AVAL

ANL01FL

ANL02FL

1001

Screening

-12

SUPINE SYSBP (mm Hg)

144

1001

Baseline

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

130

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1002

Screening

-14

SUPINE SYSBP (mm Hg)

144

1002

Baseline

-1

SUPINE SYSBP (mm Hg)

144

4.5.4 Identification of Rows Used for Analysis – General Case

It is important to identify the rows used in or excluded from analysis. Should rows used in the analysis be identified via flags or by unique values of analysis

timepoint window description AVISIT?

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.5.4.1 ADaM Methodology and Examples

The ADaM methodology is to use an analysis record flag (ANLzzFL) to indicate the rows that fulfill specific requirements for one or more analyses. For

example, ANLzzFL=Y indicates rows meeting the requirements for analysis and is blank (null) in other rows such as a duplicate row that was not the one

selected for analysis, or pre-specified post study timepoints not included in the analysis. This allows multiple rows within a parameter with the same value of

AVISIT. However, it also requires flags to be added to the dataset to be used in selecting appropriate rows for analysis. Understanding of the flags is required for

correct analysis results to be generated. In addition to ANLzzFL, additional flags might also be required, such as row-based population flags, e.g., ITTRFL and

PPROTRFL.

Please note that there can be multiple ANLzzFL variables. In this case it will be imperative to have clear and robust metadata to indicate the basis for creation

and populating of the ANLzzFL variable.

Example 1: Identification of rows used for analysis – multiple visits that fall within a visit window

This example (Table 4.5.4.1.1) illustrates the use of the analysis flag variable ANLzzFL to indicate the rows that were chosen for analysis from among the

multiple visits that fall within the analysis timepoint windows of “Baseline” and “Week 2”. Subject 1001 had two observed Baseline and Week 2 analysis

timepoints according to analysis window definitions. The one that is used in analysis is flagged with ANL01FL=Y. This approach is used because all original

visits (rows) are included in the dataset, and those selected for analysis must be identified. For traceability reasons, it is also recommended to add the AW*

columns (e.g., AWTARGET, etc.) presented in Section 3.2.5 if appropriate, in order to indicate more clearly how the analyzed rows were selected from among

the candidate rows within each analysis window. (Refer to Table 4.2.1.6 for an example of the use of these variables).

Table 4.5.4.1.1 Example 1: Analysis Dataset with Identification of Rows Used for Analysis When Multiple Visits Fall Within a Visit Window

Row

USUBJID

VISIT

AVISIT

ADY

PARAM

AVAL

DTYPE

ANL01FL

1001

Screening

Baseline

-5

SUPINE SYSBP (mm Hg)

144

1001

Baseline

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

130

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1001

Week 3

Week 2

SUPINE SYSBP (mm Hg)

125

1001

Week 4

SUPINE SYSBP (mm Hg)

128

Example 2: Identification of rows used for analysis – visit falls outside of a target window

In this example (Table 4.5.4.1.2), the Week 3 visit for subject 1001 was outside the day window of analysis Week 3, so “Post Study” was assigned to AVISIT.

This visit as well as the first baseline visit were excluded from the analysis. The “Worst Post Baseline” analysis timepoint (Row 6) was imputed by worst

observed case (DTYPE=WC). The “Endpoint” row was derived using the “Week 2” visit, since it was the last available eligible observation based on the

Statistical Analysis Plan. Both of the derived rows are flagged with ANL01FL=Y since they were rows selected for analysis.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Table 4.5.4.1.2 Example 2: Analysis Dataset with Identification of Rows Used for Analysis When Visit Falls Outside of a Target Window

Row

USUBJID

VISIT

AVISIT

ADY

VISITDY

PARAM

AVAL

DTYPE

ANL01FL

1001

Screening

Baseline

-5

SUPINE SYSBP (mm Hg)

144

1001

Baseline

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

150

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1001

Week 3

Post Study

SUPINE SYSBP (mm Hg)

140

1001

Week 1

Worst Post Baseline

SUPINE SYSBP (mm Hg)

150

1001

Week 2

Endpoint

SUPINE SYSBP (mm Hg)

133

ENDPOINT

Example 3: Identification of rows used for analysis – a visit not flagged for the analysis is used to create imputed LOCF rows

This example (Table 4.5.4.1.3) illustrates a scenario where two visits occur within a window (Week 2). The first record (on row 4) is analyzed as is (it is the

record chosen to represent analysis timepoint Week 2). The second Week 2 timepoint record (on row 5) is the basis for the LOCF derivation of analysis

timepoints Week 3, 4 and 5 (rows 6, 7, and 8). In the LOCF analysis, Week 2 is based on the observed data on row 4, and Weeks 3, 4, and 5 are imputed using

the last available observation on row 5.

Table 4.5.4.1.3 Example 3: Analysis Dataset with a Value that is Carried Forward But Not Included in the Analysis

Row

USUBJID

VISIT

AVISIT

ADY

PARAM

AVAL

DTYPE

ANL01FL

1001

Screening

Baseline

-5

SUPINE SYSBP (mm Hg)

144

1001

Baseline

SUPINE SYSBP (mm Hg)

145

1001

Week 1

SUPINE SYSBP (mm Hg)

130

1001

Week 2

SUPINE SYSBP (mm Hg)

133

1001

Week 3

Week 2

SUPINE SYSBP (mm Hg)

125

1001

Week 3

SUPINE SYSBP (mm Hg)

125

LOCF

1001

Week 3

Week 4

SUPINE SYSBP (mm Hg)

125

LOCF

1001

Week 3

Week 5

SUPINE SYSBP (mm Hg)

125

LOCF

Approaches Considered and Not Adopted

Another option considered was to create unique values of the timepoint window description AVISIT. For example, add an asterisk to the end of AVISIT such as

“Week 2 *” if not analyzed. This approach might be less confusing because the user would not need to be aware of a flag. The disadvantage is that one would

need to have a convention for AVISIT values, and tools would need to parse values of AVISIT for correct results to be generated. For these reasons, this

approach was not chosen.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.6 Identification of Population-Specific Analyzed Rows

It is not uncommon in the statistical analysis of clinical trials to repeat analyses based on multiple populations of interest. The population of interest can be

defined either at the subject level, the row (measurement) level or both. For example, when defining an analysis population, a subject may be included in one

analysis population such as Intent-to-Treat but may be excluded from another analysis population such as Per-Protocol. Analysis populations may also be

defined using characteristics of individual measurements. For example, a measurement that was assessed outside of a pre-specified time window for a particular

visit may not be included in a per-protocol visit-level population. In this section, it is assumed that the definition of a row-level analysis population is dependent

on the definition of the subject-level population. In other words, if a subject is excluded from the subject-level Per-Protocol population, then none of that

subject’s rows would be candidates for inclusion within the row-level Per-Protocol population. Given the variety of possible population definitions, the same row

in an analysis data set could be included in one analysis and excluded from another, depending on characteristics of the subject as a whole and the characteristics

of the individual measurement. Therefore, the issue becomes how best to select rows for each analysis.

4.6.1 ADaM Methodology and Examples

The ADaM methodology to this analysis issue is to have one analysis dataset that can be used to perform multiple analyses using population specific indicator

variables to identify rows that are used for each type of analysis. The advantage of this approach is that the one analysis dataset can be used for multiple analyses

and the use of flag variables obviates the need to replicate rows for each type of analysis. This promotes efficiency in the operational aspects of electronic

submissions, clarity of analyses, and ease for FDA reviewers to compare selected values for each population. This approach does, however, require that clear

metadata be provided for the indicator variable so that each specific analysis can be reproduced accurately. Below are several examples of the use of population

specific indicator variables to identify rows used for different analyses.

Example 1: Use of subject-level indicator variables (ITTFL and PPROTFL) and row (measurement) level indicator variables (ANL01FL, ITTRFL, and

PPROTRFL)

This analysis dataset (Table 4.6.1.1) can be used to repeat analyses based on multiple populations of interest either at subject level or at the row (measurement)

level.

ITTFL and PPROTFL are subject-level analysis population flags. If a subject is in the Intent-to-Treat population, then the column ITTFL will have the value of

“Y” (“N” if not). In Table 4.6.1.1, subjects 1001, 1002, and 1003 are in the Intent-to-Treat population. Similarly, if a subject is in the Per-Protocol population,

the column PPROTFL will have the value of “Y” (“N” if not). Subjects 1001 and 1003 in Table 4.6.1.1 are in the Per-Protocol population while subject 1002

with PPROTFL=N is excluded from any Per-Protocol analysis. These indicator variables are used to identify individual subjects that belong to each subject-level

population.

In contrast to the subject-level population flags, the columns ITTRFL and PPROTRFL are the analysis flags at the row level. If a row is eligible for the Intent-to-

Treat analysis, the variable ITTRFL is set to “Y”; it is null if the row is not a candidate for this analysis. In Table 4.6.1.1, all rows under the column ITTRFL are

all set to “Y”. Similarly, if a row is a candidate for the Per-Protocol analysis, the variable PPROTRFL is set to “Y”, it is null if the row does not fulfill the criteria

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

for this analysis. In Table 4.6.1.1, all three rows for subject 1002 and two of four rows for subject 1003 are not row-level Per-Protocol data and would not be

selected for a Per-Protocol analysis when we apply the subset condition: PPROTRFL=“Y”.

Not all rows in Table 4.6.1.1 are included for analysis purpose. In this example, the analyzed row flag ANL01FL is null for one row (USUBJID=1003,

VISIT=Week 1, AVISIT=Week 1, AVAL=999) because its value was replaced by the retest result in the next row (USUBJID=1003, VISIT=Retest, AVISIT=Week

1, AVAL=49). The analysis record flag for the Retest record is Y.

Table 4.6.1.1 Example 1: Analysis Dataset with Subject-Level and Row-Level Indicator Variables

Row

USUBJID

ITTFL

PPROTFL

VISIT

AVISIT

PARAMCD

AVAL

ANL01FL

ITTRFL

PPROTRFL

1001

Week 0

TEST1

500

1001

Week 1

TEST1

400

1001

Week 2

TEST1

600

1002

Week 0

TEST1

500

1002

Week 2

Week 1

TEST1

1002

Week 2

TEST1

1003

Week 0

TEST1

999

1003

Week 1

TEST1

999

1003

Retest

Week 1

TEST1

1003

Week 2

TEST1

499

Depending on the purpose of a statistical analysis, even if a subject is included in the Per-Protocol population, some or all data for that subject in a particular data

set may not be appropriate for a per-protocol analysis. Consider a situation in HIV studies where a Per-Protocol analysis excludes all data after permanent

discontinuation of study medication or addition of other antiretroviral therapy. The last dose for subject 1003 in the above example is at Week 1, so the data at

Retest and Week 2 will have a value of null under column PPROTRFL and will be excluded from any row-level Per-Protocol data analysis.

To identify rows used for an Intent-to-Treat analysis for parameter code “TEST1” at Week 1 requires the following selection specification:

AVISIT=“Week 1” & PARAMCD=“TEST1” & ANL01FL=“Y” & ITTRFL=“Y”;

Similarly, to identify rows used for a Per-Protocol analysis of values of TEST1 <=400 the selection specification becomes:

PPROTFL=“Y” & PARAMCD=“TEST1” &AVAL <=400 & ANL01FL=“Y” & PPROTRFL=“Y”;

Since an error in the specification of the selection for either of the above conditions will yield incorrect results, it is important that the metadata be clear for each

indicator variable. In addition, ADaM analysis results metadata will specify the selection criteria to provide clear documentation of how the indicator variables

were used to select analyzed rows for identified analyses.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.7 Identification of Rows Which Satisfy a Predefined Criterion for Analysis Purposes

For analysis purposes, criteria are often defined to group results based on the collected value’s relationship to one or more algorithmic conditions. For example,

subjects who had a result greater than five times the upper limit of the normal range or subjects who had a systolic blood pressure value > 160 mmHg with at

least a 25 point increase from the BASE value. In addition to creating subgroups of subjects, the categorization of the presence or absence of a criterion is often

used in listings, tabular displays or statistical modeling (as a covariate or a response variable).

4.7.1 ADaM Methodology and Examples

ADaM methodology requires the use of an analysis criterion variable, CRITy, along with a criterion evaluation result flag, CRITyFL, to identify whether a

criterion is met. These variables are defined in Sections 3.2.4 and 3.2.6, respectively.

CRITy is populated with a text description defining the conditions necessary to satisfy the presence of the criterion. The definition of CRITy can use any

variable(s) located on the row and the definition must stay constant across all rows within the same value of PARAM. A criterion can be complex, drawing from

multiple rows (see Example 3: Compound criteria) and involving AVAL, AVALC, CHG, PCHG., etc.

CRITyFL, “Criterion Evaluation Result Flag”, is the character indicator of whether the criterion described in CRITy was met. Variable CRITyFL must be present

on the dataset if variable CRITy is present. CRITyFN is permitted if a numeric result flag is needed.

ADaM methodology allows the option of only populating CRITy on a row if the CRITy criterion is met for that row (see Example 1). In that case, CRITyFL is

set to “Y” only if CRITy is populated and is null otherwise. If this option is not used and CRITy is populated on all rows within the parameter, then CRITyFL is

set to “Y” or “N” or null (see Example 2).

CRITy and CRITyFL facilitate subgroup analyses. ADaM methodology does not preclude the addition of rows (in contrast to the addition of multiple CRITy and

CRITyFL columns) to the BDS for the criterion CRITy. However, CRITy must be kept constant (if populated) across all rows within the same value of PARAM.

CRITy, CRITyFL and CRITyFN are not parameter-invariant.

Example 1: CRITy populated only when criterion met

Using this approach, when a criterion is defined for a PARAM but conditions are not met on a specific row, CRITy and CRITyFL are set to null. CRITy and

CRITyFL are also set to null if one or more missing data inputs to a criterion result in an unevaluable criterion (unevaluability is sponsor-defined, and is not

necessarily triggered by missing data inputs).

One purpose of this option is to facilitate subsetting within a parameter when the interest is in the subgroup of subjects who fulfilled the criterion. It is also

relevant when simple counts of criteria are desired. The following conditions must be true when this option is used:

1 Variables CRITy and CRITyFL are present on the dataset;

2 Analysis Variable Metadata defines CRITy relative to the specific parameter;

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

3 CRITy and CRITyFL are set to null for rows within the parameter where the criterion is not met or is unevaluable.

Table 4.7.1.1 illustrates ADaM methodology option “CRITy populated only when criterion met”. The presence of a value in CRIT1 indicates Subject 1001

satisfied the criterion. With this option, CRIT1 facilitates subsetting when the interest is in the subgroup of subjects who fulfilled the criterion. The null value in

CRIT1 is because Subject 1002 did not satisfy the criterion. The null value in CRIT1 is because the criterion is unevaluable due to missing inputs for Subject

1003.

Table 4.7.1.1 Example 1: Analysis Dataset with CRITy Populated Only When Criterion Met

Row

USUBJID

PARAM

AVAL

BASE

CHG

CRIT1

CRIT1FL

1001

Systolic Blood Pressure (mm Hg)

163

148

Systolic Pressure >160

1002

Systolic Blood Pressure (mm Hg)

140

148

-8

1003

Systolic Blood Pressure (mm Hg)

120

Example 2: CRITy populated on all rows within a parameter

Using this approach, CRITy is populated on all rows within the parameter and CRITyFL is set to “Y” or “N” or null. The purpose of this option is to facilitate

analyses where the criterion is used in tabular displays and/or statistical modeling for the parameter.

Table 4.7.1.2 illustrates ADaM methodology option “CRITy populated on all rows within a parameter”. Since this criterion is used for modeling or analysis in

this example, it is necessary to populate the rows which fail to satisfy the criterion. CRIT1FL indicates whether or not the subject meets the criterion. CRIT1FL

is set to null for Subject 1005 because the criterion is unevaluable due to missing input(s).

Table 4.7.1.2 Example 2: Analysis Dataset with CRITy Populated on All Rows Within a Parameter

Row

USUBJID

PARAM

AVAL

BASE

CHG

CRIT1

CRIT1FL

1001

Systolic Blood Pressure (mm Hg)

163

148

Systolic Pressure >160 and Change from Baseline in Systolic Pressure>10

1002

Systolic Blood Pressure (mm Hg)

140

148

-8

Systolic Pressure >160 and Change from Baseline in Systolic Pressure>10

1005

Systolic Blood Pressure (mm Hg)

120

Systolic Pressure >160 and Change from Baseline in Systolic Pressure>10

Example 3: Compound criteria

If the definition of a criterion uses values located on multiple rows (different parameters or multiple rows for a single parameter), then a new row must be added

with the value of PARAM being the textual description of the criterion and PARAMTYP set to “DERIVED” (see Section 4.2.1, Rule 5). The text of PARAM

(and CRITy) are sponsor-defined and can be as long or as short as needed to be meaningful, within the 200 character limitation for the columns.

For compound criterion rows, AVALC must always be populated with Y/N/null. If an analysis also requires a numeric indicator variable, either of the following

two options may be chosen:

1 CRITy may be set to the same criterion text as PARAM, CRITyFL set to the same Y/N/null value as AVALC, and CRITyFN set to 1/0/null.

2 AVAL may be set to a numeric 1/0/null indicator value.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

If an analysis requires only simple subsetting of the “hits” on a particular compound criterion, it is acceptable to add only the “compound criterion met”

(AVALC=“Y”) rows to the dataset. If this option is chosen, rows are not added where the assessment of a compound criterion in PARAM would result in

AVALC=“N” or null.

Note that if a compound criterion is defined, then its components do not have to exist on their own in the dataset unless these components are themselves used for

subsetting, display, or modeling purposes, or are needed for traceability.

Table 4.7.1.3 illustrates a compound criterion (row 3) included in the same dataset with noncompound criteria (rows 1 and 2).

Table 4.7.1.3 Example 3: Analysis Dataset with Both Compound and Noncompound Criteria

Row

USUBJID

PARAM

PARAMTYP

AVAL

AVALC

BASE

CHG

1001

Systolic Blood Pressure (mm Hg)

163

148

1001

Diastolic Blood Pressure (mm Hg)

1001

Systolic Pressure >160 and Diastolic Pressure > 95

DERIVED

Row

CRIT1

CRIT1FL

CRIT1FN

CRIT2

CRIT2FL

CRIT2FN

1 (cont)

Systolic Pressure > 160

Change from Baseline in Systolic Pressure > 10

2 (cont)

Diastolic Pressure > 95

3 (cont)

Note that criterion “Diastolic Pressure >95” (Row 2) can coexist in the same CRIT1 column with “Systolic Pressure >160” (Row 1). Each of these criteria is

specific to its own subset of PARAM rows.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

4.8 Other Issues to Consider

The issues presented in the previous sections represent analysis decisions that commonly occur when creating analysis datasets. However, the ADaM team

recognizes that those are not an exhaustive list. This section provides comment on some additional issues that may arise.

4.8.1 Adding Records to Create a Full Complement of Analysis Timepoints for Every Subject

It is not unusual for a given subject to have missing data for a specified analysis timepoint. For example, suppose an analysis is to be performed for the data

obtained at each of 4 visits and that no imputation is to be performed. For subjects who did not attend all 4 visits, it would be possible to create records in the

analysis dataset for these missed assessments, with AVAL and AVALC missing (null) and appropriate variable(s) set to indicate these added records. For

example, DTYPE could contain a sponsor-defined value such as “PHANTOM.” There are some advantages of having an analysis dataset contain the same

number of observations for each subject. For example, programming is facilitated by having the same data dimensions for all subjects, and by explicitly

representing missing data rather than implicitly representing it by the absence of a record. This also allows ADaM datasets to support listing creation, especially

for data that is not present in SDTM (e.g., added analysis parameters). For some categorical analyses, the denominators can be obtained directly from the

analysis dataset rather than from another input such as ADSL. The disadvantage of this approach is that it may require additional metadata to explain the use of

these derived blank records and would require in some cases that subsetting statements be used to exclude the rows on which AVAL is missing. The ADaM team

neither advocates nor discourages this practice.

4.8.2 Creating Multiple Datasets to Support Analysis of the Same Type of Data

The statistical analysis plan often specifies that an analysis will be performed using slightly different methodologies. For example, the primary efficacy analysis

may be performed using two different imputation algorithms for missing values. The sponsor must decide whether to include both sets of the imputed

observations in one analysis dataset or create two analysis datasets, each representing just one of the imputation algorithms. ADaM provides variables that can

be used to identify records that are used for different purposes. However, this does not imply that the sponsor should not or cannot submit multiple analysis

datasets of similar content, each designed for a specific analysis.

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Appendices

Appendix A Abbreviations and Acronyms

The following is a list of abbreviations and acronyms used multiple times in this document. Not included here are

explanations of the various SDTM domains (e.g., QS, DM). Also not included is a description of the variables

referenced.:

ADAE

ADaM Adverse Event Analysis Dataset

ADaM

CDISC Analysis Data Model

ADaM document

Analysis Data Model document

ADaMIG

Analysis Data Model Implementation Guide

ADSL

ADaM Subject-Level Analysis Dataset

BDS

ADaM Basic Data Structure

BOCF

Baseline Observation Carried Forward

CDASH

Clinical Data Acquisition Standards Harmonization

CDISC

Clinical Data Interchange Standards Consortium

DAO

Data as Observed

eCTD

electronic Common Technical Document

FDA

United States Food and Drug Administration

ITT

Intent-to-Treat

LOCF

Last Observation Carried Forward

LOV

Last Observed Value

LVPD

Last Value Prior to Dosing

SAP

Statistical Analysis Plan

SDS

Submission Data Standards

SDTM

Study Data Tabulation Model

SDTMIG

Study Data Tabulation Model Implementation Guide

Worst Observed Case

WOCF

Worst Observation Carried Forward

XML

Extensible Markup Language

CDISC ADaM Implementation Guide Version 1.0

FINAL December 17, 2009

Appendix B Representations And Warranties; Limitations of

Liability, And Disclaimers

CDISC Patent Disclaimers

It is possible that implementation of and compliance with this standard may require use of subject matter covered by

patent rights. By publication of this standard, no position is taken with respect to the existence or validity of any

claim or of any patent rights in connection therewith. CDISC, including the CDISC Board of Directors, shall not be

responsible for identifying patent claims for which a license may be required in order to implement this standard or

for conducting inquiries into the legal validity or scope of those patents or patent claims that are brought to its

attention.

Representations and Warranties

Each Participant in the development of this standard shall be deemed to represent, warrant, and covenant, at the time

of a Contribution by such Participant (or by its Representative), that to the best of its knowledge and ability: (a) it

holds or has the right to grant all relevant licenses to any of its Contributions in all jurisdictions or territories in

which it holds relevant intellectual property rights; (b) there are no limits to the Participant’s ability to make the

grants, acknowledgments, and agreements herein; and (c) the Contribution does not subject any Contribution, Draft

Standard, Final Standard, or implementations thereof, in whole or in part, to licensing obligations with additional

restrictions or requirements inconsistent with those set forth in this Policy, or that would require any such

Contribution, Final Standard, or implementation, in whole or in part, to be either: (i) disclosed or distributed in

source code form; (ii) licensed for the purpose of making derivative works (other than as set forth in Section 4.2 of

the CDISC Intellectual Property Policy (“the Policy”)); or (iii) distributed at no charge, except as set forth in

Sections 3, 5.1, and 4.2 of the Policy. If a Participant has knowledge that a Contribution made by any Participant or

any other party may subject any Contribution, Draft Standard, Final Standard, or implementation, in whole or in

part, to one or more of the licensing obligations listed in Section 9.3, such Participant shall give prompt notice of the

same to the CDISC President who shall promptly notify all Participants.

No Other Warranties/Disclaimers. ALL PARTICIPANTS ACKNOWLEDGE THAT, EXCEPT AS PROVIDED

UNDER SECTION 9.3 OF THE CDISC INTELLECTUAL PROPERTY POLICY, ALL DRAFT STANDARDS

AND FINAL STANDARDS, AND ALL CONTRIBUTIONS TO FINAL STANDARDS AND DRAFT

STANDARDS, ARE PROVIDED “AS IS” WITH NO WARRANTIES WHATSOEVER, WHETHER EXPRESS,

IMPLIED, STATUTORY, OR OTHERWISE, AND THE PARTICIPANTS, REPRESENTATIVES, THE CDISC

PRESIDENT, THE CDISC BOARD OF DIRECTORS, AND CDISC EXPRESSLY DISCLAIM ANY WARRANTY

OF MERCHANTABILITY, NONINFRINGEMENT, FITNESS FOR ANY PARTICULAR OR INTENDED

PURPOSE, OR ANY OTHER WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, FINAL

STANDARDS OR DRAFT STANDARDS, OR CONTRIBUTION.

Limitation of Liability

IN NO EVENT WILL CDISC OR ANY OF ITS CONSTITUENT PARTS (INCLUDING, BUT NOT LIMITED TO,

THE CDISC BOARD OF DIRECTORS, THE CDISC PRESIDENT, CDISC STAFF, AND CDISC MEMBERS) BE

LIABLE TO ANY OTHER PERSON OR ENTITY FOR ANY LOSS OF PROFITS, LOSS OF USE, DIRECT,

INDIRECT, INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER UNDER CONTRACT,

TORT, WARRANTY, OR OTHERWISE, ARISING IN ANY WAY OUT OF THIS POLICY OR ANY RELATED

AGREEMENT, WHETHER OR NOT SUCH PARTY HAD ADVANCE NOTICE OF THE POSSIBILITY OF

SUCH DAMAGES.

Note: The CDISC Intellectual Property Policy can be found at

http://www.cdisc.org/about/bylaws_pdfs/CDISCIPPolicy-FINAL.pdf.

ADaM Implementation Guide Version 1.0 V1.0

adam_implementation_guide_v1.0

Navigation menu

Versions of this User Manual:

Views

Navigation
