{product.name} Administrator Guide

The {product.name} Team

Version 0.3.1

Table of Contents

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê2

Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê2

Install Java 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê2

Prepare database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê2

Setting up the application home folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê3

Running via embedded Tomcat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê4

Installing as a service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê4

Running the standalone behind HTTPD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê5

Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê7

Using HSQLDB in production . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê7

Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê8

Exporting/importing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê8

In-place update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê8

Backup your data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê8

Standalone service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê8

Separate Tomcat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê8

Version 3.2.x to 3.3.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê9

Version 2.3.1 to 3.0.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê9

System Properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê10

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê11

Configure database via environment variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê12

Custom header icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê13

Internal backups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê13

External pre-authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê14

System Requirements

Table 1. Requirements for users

Browser Chrome or Safari

Table 2. Requirements to run the standalone version

Java Runtime Environment version 8 or higher

Table 3. Requirements run the server version

Java Runtime Environment version 8 or higher

Apache Tomcat version 8.5 or higher (Servlet API 3.1.0)

MySQL Server version 5 or higher

Installation

Prerequisites

•This guide assumes Debian 9.1 (Stretch). It may also work on Ubuntu with some modifications,

but we do not test this. Instructions for other Linux distributions likely deviate significantly.

•It is further assumed that the user "www-data" already exists on the system and that it shall be

used to run the application.

•All commands assume that you are logged in as the root user.

If you cannot log in as root but have to use sudo to become root, then the

recommended way to do that is using the command sudo su -.

Install Java 8

You can install an Oracle Java 8 JDK using the following commands.

$ apt-get update

$ apt-get install dirmngr

$ echo "deb http://ppa.launchpad.net/webupd8team/java/ubuntu trusty main" | tee

/etc/apt/sources.list.d/webupd8team-java.list

$ echo "deb-src http://ppa.launchpad.net/webupd8team/java/ubuntu trusty main" | tee -a

/etc/apt/sources.list.d/webupd8team-java.list

$ apt-key adv --keyserver hkp://keyserver.ubuntu.com:80 --recv-keys EEA14886

$ apt-get update

$ apt-get install oracle-java8-installer

$ apt-get install oracle-java8-set-default

Prepare database

For production use, it is highly recommended to use a MySQL database. In this section, we briefly

describe how to install a MySQL server and how to prepare it for use with INCEpTION.

•Install MySQL

$ apt-get install mysql-server

•make sure your MySQL server is configured for UTF-8. Check the following line is present in

/etc/mysql/mariadb.conf.d/50-server.cnf (this is specific to Debian 9; on other systems the

relevant file may be /etc/mysql/my.cnf):

character-set-server = utf8

collation-server = utf8_bin

•also ensure the default settings for client connections to are UTF-8 in

/etc/mysql/mariadb.conf.d/50-server.cnf (again Debian 9; likely in /etc/mysql/my.cnf on other

systems)

default-character-set = utf8

•login to MySQL

$ mysql -u root -p

•create a database

mysql> CREATE DATABASE inception DEFAULT CHARACTER SET utf8 COLLATE utf8_bin ;

•create a database user called inception with the password t0t4llYSecreT which is later used by

the application to access the database (instructions for settings.properties file below).

mysql> CREATE USER 'inception'@'localhost' IDENTIFIED BY 't0t4llYSecreT';

mysql> GRANT ALL PRIVILEGES ON inception.* TO 'inception'@'localhost';

mysql> FLUSH PRIVILEGES;

For production use, make sure you choose a different, secret, and secure password.

Setting up the application home folder

The application home folder is the place where INCEpTION’s configuration file settings.properties

resides and where the data is stored. Mind that if you are using a MySQL database server

(recommended), then some data is also stored in the MySQL database. This is important when you

plan to perform a backup, as both the home folder and the database content need to be included in

the backup.

Now, let’s go through the steps of setting up the application home folder creating a configuration

file to access the previously created MySQL database.

•Create the application home folder. This is the directory where the settings files and projects

(documents, annotations, etc.) are stored

$ mkdir /srv/inception

•Edit /srv/inception/settings.properties to define the database connection:

database.dialect=org.hibernate.dialect.MySQL5InnoDBDialect

database.driver=com.mysql.jdbc.Driver

database.url=jdbc:mysql://localhost:3306/inception?useSSL=false

database.username=inception

database.password=t0t4llYSecreT

•Fix permissions of the application home folder

$ chown -R www-data /srv/inception

Running via embedded Tomcat

The INCEpTION standalone JAR with an embedded Tomcat server and can be easily set up as a

UNIX service. This is the recommended way of running INCEpTION on a server.

Installing as a service

To set it up as a service, you can do the following steps. For the following example, I assume that

you install the application in /srv/inception:

•Copy the standalone JAR file inception-app-standalone-{revnumber}.jar to

/srv/inception/inception.jar. Note the change of the filename to inception.jar.

•Create the file /srv/inception/inception.conf with the following content

JAVA_OPTS="-Djava.awt.headless=true -inception.home=/srv/inception"

•In the previous step, you have already created the /srv/inception/settings.properties file. You

may optionally configure the Tomcat port using the following line

server.port=18080

If you need to do additional configurations of the embedded Tomcat, best refer to the

documentation of Spring Boot itself.

•Make sure that the file /srv/inception/inception.conf is owned by the root user. If this is not the

case, it will be ignored and any settings made there will not have any effect. If you start the

application and instead of using the MySQL database, it is using an embedded database, then

you should double-check that /srv/inception/inception.conf is owned by the root user.

$ chown root:root /srv/inception/inception.conf

•Change the owner/group of /srv/inception/inception.jar to www-data. When the service is

started, it will run with the privileges of the user that owns the JAR file, i.e. in this case the

application will run as under the www-data user.

$ chown www-data:www-data /srv/inception/inception.jar

•Create a symlink from /etc/init.d to the /srv/inception/inception.jar:

$ ln -s /srv/inception/inception.jar /etc/init.d/inception

•Start INCEpTION using

$ service inception start

•Stop INCEpTION using

$ service inception stop

Running the standalone behind HTTPD

These are optional instructions if you want to run the application behind an Apache web-server

instead of accessing it directly. This assumes that you already have the following packages installed:

•Apache Web Server

•mod_proxy

•mod_proxy_ajp

•Add the following lines to /srv/inception/settings.properties:

tomcat.ajp.port=18009

server.contextPath=/inception

server.use-forward-headers=true

•Edit /etc/apache2/conf.d/inception.local.conf

ProxyPreserveHost On

Ê Order Deny,Allow

Ê Deny from none

Ê Allow from all

</Proxy>

Ê ProxyPass ajp://localhost:18009/inception timeout=1200

Ê ProxyPassReverse http://localhost/inception

</Location>

•Restart Apache web server

$ service apache2 restart

Database

INCEpTION uses an SQL database to store project and user data.

We test MySQL using a MySQL server. INCEpTION uses by default an embedded HSQLDB database.

However, we recommend using the embedded database only for testing purposes. For production

use, we recommend using a MySQL server. The reason for this is, that:

•we do more testing on the MySQL server and

•in the past, we had cases where we described in-place upgrade procedures that required

performing SQL commands to change the data model as part of the upgrade. We promise to try

avoiding this in the future. However, in case we offer advice on fixing anything directly in the

database, this advice will refer to a MySQL database.

We try to keep the data model simple, so there should be no significant requirements to the

database being used. Theoretically, it should be possible to use any JDBC-compatible database after

adding a corresponding driver to the classpath and configuring INCEpTION to use the driver in the

settings.properties file.

If you plan to use UTF-8 encoding for project name and tagset/tag name, make sure either of the

following settings for MySQL databse a) in the settings.properties file, make sure that database.url

includes

useUnicode=true&characterEncoding=UTF-8

b) change the my.conf MySQL databse configuration file to include the following line

character-set-server = utf8

Using HSQLDB in production

INCEpTION displays a warning in the user interface when an embedded database is being used. In

case that you really want to run INCEpTION with an embedded database in production, you

probably want to disable this warning. To do so, please add the following entry to the

settings.properties file:

warnings.embeddedDatabase=false

Upgrade

Exporting/importing

•Log in to the application and export all the projects that you wish to migrate using the Export

pane in the project settings

•Move your INCEpTION home folder to a safe location and create a new home folder in the old

location

•Copy the settings.properties and formats.properties (if present) back from your moved folder

•Start the new INCEpTION version to initialize the database

•Recreate the users

◦If you are using MySQL

▪create a new database and update the settings.properties accordingly

▪use mysqldump to dump the tables users and authorities from the old database and load

it back into the new database

◦If you are not using MySQL, you have to recreate the users manually

•Restart INCEpTION and import the previously exported projects

In-place update

This method should work when updating only a bugfix version, e.g. from 2.0.9 to 2.0.10. When

performing a minor or major update, better use the exporting/importing method above.

Backup your data

•Make a copy of your INCEpTION home folder

•If you are using MySQL, make a backup of your INCEpTION database, e.g. using the mysqldump

command.

Standalone service

•Stop the INCEpTION service

•Replace the inception.jar file with the new version

•Ensure that the file has the right owner/group (usually www-data)

•Start the INCEpTION service again

Separate Tomcat

•While Tomcat is running, delete the old WAR from your webapps folder

•Wait until Tomcat has automatically deleted the INCEpTION folder

•Stop Tomcat

•Place the new WAR file into your webapps folder

•Start Tomcat

Version 3.2.x to 3.3.0

•When upgrading from 3.2.x or earlier to 3.3.0 or later, Automation projects break.

Version 2.3.1 to 3.0.0

•The access permissions of the super admin have changed. Super admins can no longer access

annotation, curation, and monitoring pages for all projects. They can only access them if they

are annotators, admins, or curators in the respective projects. However, they still have full

access to the project settings of all projects and can simply give themselves the missing

permissions. After an upgrade to 3.0.0, all super admins who require project permissions

on existing projects should assign these permissions to themselves. This also applies when

importing old projects. For new projects, the creator of the project always starts with

annotator, curator, and project admin permissions. If these permissions are not required by the

project creator, they should be removed after project creation.

System Properties

Setting Description Default Example

inception.home INCEpTION home

folder

~/.inception /srv/inception

javamelody.disabled Disable JavaMelody true false

Settings

Setting Description Default Example

auth.mode Authentication mode database preauth

auth.preauth.header.pr

incipal

Principal header remote_user some other header

auth.preauth.newuser.r

oles

Default roles for new

users (comma

separated)

<none> ROLE_PROJECT_CREAT

auth.user.<username>.r

oles

Extra roles for user

(comma separated)

<none> ROLE_ADMIN

database.dialect Database dialect org.hibernate.dialect.H

SQLDialect

org.hibernate.dialect.M

ySQL5InnoDBDialect

database.driver Database driver org.hsqldb.jdbc.JDBCDr

iver

com.mysql.jdbc.Driver

database.url JDBC connection string location in the

application home folder

jdbc:mysql://localhost:3

306/inception?useUnico

de=true&characterEnco

ding=UTF-8

database.username Database username sa user

database.password Database password unset pass

database.initial-pool-

size

Initial database

connection pool size

database.min-pool-size Minimum database

connection pool size

database.max-pool-size Maximum database

connection pool size

backup.interval Time between backups

(seconds)

0 300 (60 * 5 = 5 minutes)

backup.keep.number Maximum number of

backups to keep

0 5

backup.keep.time Maximum age of

backups to keep

(seconds)

0 2592000 (60 * 60 * 24 *

30 = 30 days)

ui.brat.sentences.numb

The number of

sentences to display per

page

style.logo Logo image displayed

in the upper-right

corner

unset path to an image file

style.header.icon… Icons/links to display in

the page header. For

details, see below.

unset

Setting Description Default Example

warnings.embeddedDat

abase

Warn about using an

embedded database

true false

warnings.unsupported

Browser

Warn about

unsupported browser

true false

debug.showExceptionP

age

Show a page with a

stack trace instead of

an "Internal error"

page. Do not use in

production!

false true

appear on the login

page, such as project

web-site, annotation

guideline link, … The

message can be an

HTML content.

unset <span

style="color:red;

font-size: 200%;">Use

are your own

risk.</span>

user.profile.accessible Whether regular users

can access their own

profile to change their

password and other

profile information.

This setting has no

effect if the application

is running in pre-

authentication mode.

false true

Configure database via environment variables

The database connection details can also be configured via environment variables. When these

environment variables are present, they are preferred over the settings.properties file. The

following environment variables can be used:

Setting Description Default Example

INCEPTION_DB_DIALECT Database dialect org.hibernate.dialect.H

SQLDialect

org.hibernate.dialect.M

ySQL5InnoDBDialect

INCEPTION_DB_DRIVER Database driver org.hsqldb.jdbc.JDBCDr

iver

com.mysql.jdbc.Driver

INCEPTION_DB_URL JDBC connection string location in the

application home folder

jdbc:mysql://localhost:3

306/inception?useUnico

de=true&characterEnco

ding=UTF-8

INCEPTION_DB_USERNAME Database username sa user

INCEPTION_DB_PASSWORD Database password unset pass

Custom header icons

It is possible to add custom icons to the page header. You can declare such custom icons in the

application settings file as shown in the example below. Each declaration begins with the prefix

style.header.icon. followed by an identifier (here myOrganization and mySupport). The suffixes

.linkUrl and .imageUrl indicate the URL of the target page and of the icon image respectively.

Images are automatically resized via CSS. However, to keep loading times low, you should point to a

reasonably small image.

The order of the icons is controlled by the ID, not by the order in the configuration file!

Example: Custom header icon

style.header.icon.myOrganization.linkUrl=http://my.org

style.header.icon.myOrganization.imageUrl=http://my.org/logo.png

style.header.icon.mySupport.linkUrl=http://my.org/support

style.header.icon.mySupport.imageUrl=http://my.org/help.png

Internal backups

Annotations are internally stored as files. Whenever a user performs an action on a document, the

file is updated. It is possible to keep automatic internal backups of these files, e.g. to safeguard

against crashes or bugs.

The internal backups are controlled through three properties:

Setting Description Default

backup.interval Time between backups

(seconds)

0 (disabled)

backup.keep.number Maximum number of backups

to keep

0 (unlimited)

backup.keep.time Maximum age of backups to

keep (seconds)

0 (unlimited)

By default, backups are disabled (backup.interval is set to 0). Changing this properties to any

positive number enables internal backups. The interval controls the minimum time between

changes to a document that needs to have elapsed in order for a new backup to be created.

When backups are enabled, either or both of the properties backup.keep.number and

backup.keep.time should be changed as well, because their default values will cause the backups

to be stored indefinitely and they will eventually fill up the disk.

The properties backup.keep.number and backup.keep.time control how long backups are keep

and the maximal number of backups to keep. These settings are effective simultaneously.

Example: Make backups every 5 minutes and keep 10 backups irrespective of age

backup.interval = 300

backup.keep.number = 10

backup.keep.time = 0

Example: Make backups every 5 minutes and all not older than 7 days (60 * 60 * 24 * 7 seconds)

backup.interval = 300

backup.keep.number = 0

backup.keep.time = 604800

Example: Make backups every 5 minutes and keep at most 10 backups that are not older than 7 days

backup.interval = 300

backup.keep.number = 10

backup.keep.time = 604800

External pre-authentication

It is possible to use the application with header-based external per-authentication. In this mode, the

application looks for a special HTTP header (by default remote_user) and if that header exists, it is

taken for granted that this user has been authenticated. It will check its internal database if a user

by the given name exists, otherwise it will create the user.

Pre-authentication can be enabled by setting the property auth.mode to preauth. When enabling pre-

authentication mode, the default roles for new users can be controlled using the

auth.preauth.newuser.roles property. The ROLE_USER is always added, even if not specified explicitly.

Adding also the role ROLE_PROEJCT_CREATOR allows all auto-created users also to create their own

projects.

Since the default administrator user is not created in pre-authentication, it is useful to also declare

at least one user as an administrator. This is done through the property auth.user.<username>.roles

where <username> must be replaced with the name of the user. The example below shows how the

user Franz is given administrator permissions.

Example: Authenticate using the remote_user header, new users can create projects, user Franz is always

admin.

auth.mode = preauth

auth.preauth.header.principal = remote_user

auth.preauth.newuser.roles = ROLE_PROJECT_CREATOR

auth.user.Franz.roles = ROLE_ADMIN

The roles specified through auth.preauth.newuser.roles are saved in the database

when a user logs in for the first time and can be changed after creation through

the user interface.

The roles added through auth.user.<username>.roles properties are not saved in

the database and cannot be edited through the user interface.

{product.name} Administrator Guide Admin

Navigation menu

Versions of this User Manual:

Views

Navigation
