Hello! Welcome to the C.B. RADIO SECRET ~ Master Tune Up Manual online sample
version. The following pages contain the the tuning adjustment locations and
microphone wiring charts for most C.B. and many Ham radios. We have also
included the complete set of 29 SECRET CB Manuals to help you with this great
hobby. I hope that this information is helpful to you. Please keep in mind that this is
only a fraction of the massive amount of information contained on the CD ROM
versions. The CD-ROMS contains Information for most of the newer radios including
such very useful information as....
Ads by Google
CB Radios for Sale Galaxy 99 CB Radio CB Mod CB Amplifier CB Store
menu
http://www.hardtimez99.com/CB%20RADIO%20SECRET/menu.html[3/12/2010 12:23:49 AM]
(Including Manuals) *
Ads by Google
CB Repair CB Store Base CB Amps Texas Ranger CB Galaxy CB
Ham Radio Online Courses
The easiest way to pass the ham radio
exams. Results guaranteed!
Barracuda Wiring Diagram
You can find it on Yahoo! Search for
Barracuda Wiring Diagram
All Rights Reserved C.B. RADIO SECRET © 2003 - 2008
~ MICROPHONE WIRING CHARTS ~
Click Here For Wiring Instructions
ALAN-COBRA COBRA-CRAIG CRAIG-GALAXY GALAXY-MAXON MIDLAND-RANGER RANGER-
REALISTIC ROBYN-SEARS SOMMERKAMP-TEABERRY TEABERRY-TRISTAR TRS-CHALLENGER-
UNIDEN/PRESIDENT UNIDEN-ZODIAC
~ CB RADIO Tune-Up Information ~
Click Here For Tune-Up Instructions
Just click the letters below to choose a radio brand that you want to tune.
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
~ CLICK HERE FOR ALL 29 VOLUMES OF SECRET CB RADIO ~
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/a.html[3/12/2010 12:31:16 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
ACTIONLINE RADIOS
Model Modulation AM Power SSB Power
WCB-10 RV1 N/A N/A
ALAN RADIOS
Model Modulation AM Power SSB Power
555 VR14 or Cut R249 or
Remove TR53 VR13 VR12
560 VR14 or Cut one end of
R291 VR15 Low Power VR13
High Power VR12
ALARON RADIOS
Model Modulation AM Power SSB Power
B-1025 VR7 or Cut D14 L11 L10 L9
B-1100 VR3 or Remove C72 L15 L16
B-1150 VR5 or Cut D11 & D12 L15 L16
B-4075 VR219 or Cut D201 &
D204 L307 L308 L309 L306
B-4085 RV202 or Remove C210 L306 L307 L308
B-4900 Remove C228 or Cut
D208 L401 L403 L406
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/a.html[3/12/2010 12:31:16 AM]
B-5050A
VR219 or Cut D201 or
D204 L307 L308 L309 L306
B-5200 VR4 L5 L8 L9
AMERICAN ELECTRONICS
Model Modulation AM Power SSB Power
76-501 VR4 or Cut D18 L8 L10
76-551 VR4 or Cut D7 L8 L9
76-601 VR4 or Cut D18 L8 L10
ARGO RADIOS
Model Modulation AM Power SSB Power
ARGO 300 VR4 or Remove C135 RV6 (AM) RV7 (FM)
ARGUS RADIOS
Model Modulation AM Power SSB Power
5000 RV12 RV11 RV6 RV3
AUDIOVOX RADIOS
Model Modulation AM Power SSB Power
100 Cut D12
MCB-500 R68 or Cut D16 L5
MCB-750 VR3 or Cut D16 T7 L3 L4
MCB-1000 VR5 or Cut D11 & D12 L16 L15 L14 VR10
MCB-2000 R145 or Cut D108 or
Remove C173 T114 T115
MCB-3000 VR5 or Remove C48 T8 T9
MCB-5000 R268 or Cut D207 or
D215 L202 L204
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/a.html[3/12/2010 12:31:16 AM]
MCB-6000
R279 or Cut D220 or
D215 L202
WINDSOR VR5 or Cut D11 & D12 L16 L15 L14 VR10
AUTOMATIC RADIOS
Model Modulation AM Power SSB Power
CBH-2265 R207 or Cut D201 L205
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Ham Radio Online Courses
Get your ham radio license. Morse Code no
longer required!
Connex CB Radio Sale
Reduced pricing on all CB Radios plus free
shipping over $200.
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET ~ Master Tune Up Manual
http://www.hardtimez99.com/CB%20RADIO%20SECRET/b.html[3/12/2010 12:33:05 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
BELTEK RADIOS
Model Modulation AM Power SSB Power
ENDURO 5 R142 C142 L115
ENDURO 23 R191 or Cut CR120 &
CR121 L115
BETA RADIOS
Model Modulation AM Power SSB Power
BETA 23 DELUXE Cut R78
BOMAN RADIOS
Model Modulation AM Power SSB Power
CB-515 RV5 or Cut D10 CV1
CB-555 VR481 or Cut D481 &
D482 L451 L463
CB-720B Cut CD12 L3
CB-725 VR481 or Cut D481 &
D482 L451 L463
CB-750 FVR3 or Cut D10 L23 L22
CB-770 VR206 or Cut D213 VC201 L301 VR205
CB-775 Cut D17 L7 L6
CB-910 RV2 or Remove C96 L7 L11 L12
CB-920 RV2 or Remove C96 L7 L11 L12
CB RADIO SECRET ~ Master Tune Up Manual
http://www.hardtimez99.com/CB%20RADIO%20SECRET/b.html[3/12/2010 12:33:05 AM]
CB-930 RV2 or Remove C96 L7 L11 L12
CB-950 RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
CBH-900 RV2 or Remove C96 L7 L11 L12
CBH-990 RV2 or Remove C96 L7 L11 L12
CBH-6100 Cut D221 L301 L314
CBR-9600 RV105 L111 L113
CBR-9900 VR902 L903 L905
CBR-9940 VR902 & VR 903 VR901
CBR9950 AM/FM/CB VR2 L4 L3 L1
BRISTOL RADIOS
Model Modulation AM Power SSB Power
CB-2271 Cut D481 & D482 L451 L463
BROWNING RADIOS
Model Modulation AM Power SSB Power
BARON R134 or Cut CD36 L5 L7 L3 R130
BROWNIE 23 Cut CD12 L3 L5
BROWNIE 40 Cut CD12 L3 L5
LTD R85 or Remove Q23 L2 L5 R96
MARK 4A R603 T303 C602 R318
SABRE Cut D11 & CD12 L5 L3
SST (early) Cut D19 & D20 A20 A21
SST (late) Cut D18 & D19 L2 L5
SST 2 Cut D11 & CD12 L5 L3
Want More? Check Out The CD! Over 400MB of VERY Useful Information
CB RADIO SECRET ~ Master Tune Up Manual
http://www.hardtimez99.com/CB%20RADIO%20SECRET/b.html[3/12/2010 12:33:05 AM]
Ham Radio 2010 Special
Entry-level license for $20 and 10 hours
study. No Morse code needed!
CB Radios & Equipment
Galaxy, Connex, Magnum Radios Sirio, CB,
Ham & Marine Antennas
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
C.P.I. RADIOS
Model Modulation AM Power SSB Power
CP 400 R699 or Cut Base Leg of
Q410 R205 R274
CALTRON RADIOS
Model Modulation AM Power SSB Power
CB-7500 VR6 or Cut D24 & D25 L18 L20 L21
CHANNEL MASTER RADIOS
Model Modulation AM Power SSB Power
CB-6830 VR7 or Cut D505 L906 L903
CB-6832 VR7 or Cut D505 L906 L903
CB-6834 VR6 or Cut D506 or D505 L903 L905
CB-6835 VR6 or Cut D506 or D505 L903 L905
CHEROKEE RADIOS
Model Modulation AM Power SSB Power
AH-100 RV14 RV4
CBS-1000 VR5 VR14 VR4
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
CM-10 VR103 VR502
CLARICON RADIOS
Model Modulation AM Power SSB Power
ACTIVATOR (30800) R152 or Cut CR107 L11 C162
PRIVATEER (30600) R152 or Cut CR107 L11 C162
RAIDER (30500) VR4 or Cut D13 L16 L14
INTRUDER (30200) R152 or Cut CR107 L11 C162
PIRATE (30400) R152 L10 C154
71200 R152 L111 L110
CLAIRION RADIOS
Model Modulation AM Power SSB Power
DMA-066 VR201 L201 L204
JC-201E Cut D201 L207
JC-202E VR201 L201 L204
JC-203E VR201 or Cut D205 L201 L204
PE-672E VR201 L201 L204
RCJ-003 VR201 L201 L204
TC-203C VR201 or Cut D205 L201 L204
COBRA RADIOS
Model Modulation AM Power SSB Power
7 PLUS VR4 or Cut D8 L11 L12 L13
10 PLUS VR4 or Cut D8 L11 L12 L13
18 LTD Cut D13 or Cut R84 L7 L6 L5
18 PLUS Cut D12 L7
18 RV RV501 or Cut D502 L304 L305 L306
19 Cut D11 L5 L8 L9
19 GTL VR6 or Cut D9 L15 L16 L17
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
19 LTD VR6 or Cut D9 L15 L16 L17
19 LTD CLASSIC VR4 or Cut D7 L7 L8
19 M Remove C73 L8 L5 L3
19 PLUS RV501 or Cut C511 L305 L306
19 PLUS (new) VR4 or Cut D8 L11 L12 L13
19XS Cut D105
20 (B&K) Cut CD20 & CD21 T11 T10 C60
20 LTD Cut D13
20 PLUS RV501 or Cut C511 L305 L306
20 PLUS (new) VR4 or Cut D8 L11 L12 L13
21 Remove C105 & C106 L12 L9
21A (old) Cut D24 L9 L8
21 GTL VR5 or Cut D9 L13 L10 L9 L8
21 LTD VR5 or Cut D9 L13 L10 L9 L8
21 LTD CLASSIC VR4 or Cut D7 L7 L8
21 PLUS Cut 1.5k resister next to
TR34 L12 L10
21X VR207 or Cut D212 L212 L214
21 XLR RT4 or Cut D13 L15 L12 L11
23 PLUS RV501 or Cut D502 L304 L306 L307
25 GTL VR5 or Cut D9 L13 L10 L9 L8
25 LTD VR5 or Cut D9 L13 L10 L9 L8
25 LTD CLASSIC VR5 or Cut D9 L10 L9 L8
25 PLUS Cut 1.5k resister next T34 L12 L10
26 Cut D24 L7 L8
28A Cut CD28 & CD29 T12 L2 L5
29A (old) Cut D24 L7 L8
29 XLR VR5 or Cut D14 L15 L12 L11
29 GTL VR4 or Cut D11 L14 L13 L12
29 LTD VR4 or Cut D11 L14 L13 L12
29 LTD CLASSIC VR4 or Cut D11 L14 L13 L12
29 LTD GOLD VR4 or Cut D11 L14 L13 L12
29 PLUS Cut D20 L12
31 PLUS Cut D19 L13 L12 L11
32 XLR Cut CD11 & CD12 L5 L3
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
33 PLUS VR4 Or Cut D17 L11 L9
33 LTD (sos) RV1
40 PLUS RV104 or Cut D203 L305 L306
40X RV201 or Cut D203 or
C215 L304 L305 L306
41 PLUS RV4 or Cut D21 L19 L20 L21
45 XLR VR105 or Cut D119 L113 L109
46 XLR VR105 or Cut D119 L113 L109
47 XLR VR105 or Cut D119 L113 L109
50 XLR VR5 or Cut D119 L109
55 XLR VR5 or Cut D119 L109
62 XLR VR3 or Remove C67 L16 L15 L12
66 GTL VR2 or Cut D4 L14 L15 L17
66 LTD Cut R54
67 LTD RV4 or Cut D212 L306 L307 L308
77X VR207 or Cut D212 L211 L212 L214
78X VR6 or Cut D9 L11 L12 L15
85 Remove Q17 from Circuit L3 T4
86 XLR L3 T4 L3
CAM 89 Add a 1k resister in series
with C110 L13 L12 L9
87 GTL VR6 or Cut D16 L17 L16 L13
89 GTL VR6 or Cut D16 L17 L16 L13
89 XLR VR5 or Cut D14 L15 L12 L11
90 LTD RV201 or Cut D203
132 (old) Cut Q25 from circuit T14 T15 L3 C116 R136
132A Cut CD39 & CD 40 R79 R87
132 XLR R134 or Cut R125 L3 R130
134 Cut D40 & D41 L8 L10 VR15
135 (old) Cut Cut Q25 from circuit T14 T15 L3 C116 R136
135 XLR R134 or Cut R125 L3 R130
138A (old) Cut D40 & D41 L8 L10 VR15
138 XLR VR7 & VR6 VR8 CT7
139 VR12 or Cut D63 L12 L10 VR15
139 XLR VR7 & VR6 VR8 CT7
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
140 GTL Cut R104 VR6 VR7
142 GTL Cut R104 VR6 VR7
146 GTL VR5 or Remove TR29 VR10 VR6
148 GTL Cut R131 VR10 VR11
148 GTL-DX (early) VR5 VR11 VR7
148 GTL-DX (late) VR14 or Remove TR32 VR13 VR12
148 GTL-B RV14 RV15 RV13
148 GTL-DX RV12 RV11 RV6 RV3
1000 GTL VR6 or Cut D16 L17 L16 L13
2000 GTL Cut R131 VR10 VR11
GTL 150 RV14 RV13 RV12 RV4
COLT RADIOS
Model Modulation AM Power SSB Power
SX33 RV2 or Remove C96 L7 L11 L12
190 R71
210 RV201 or Cut D203 L305 L306
222 RV201 or Cut D203 L305 L306
290 RV2 or Remove C96 L7 L11 L12
320DX RV14 RV13 RV12 RV4
320FM RV14 RV13 RV12 RV4
350 RV121 or Cut D19 & D20 L34 L37
355 RV201
357 (new) VR4 L11 L12 L13
357 (old) RV3 L5
390 RV2 or Remove C96 L7 L11 L12
444 Remove C99 L12 L15 L16 (HI PWR)
480 RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
485 RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
485DX RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
510 RV201 or Cut D203 L304 L305 L306
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
800 RV2 or Remove C96 L7 L11 L12
870 RV2 or Remove C96 L7 L11 L12
870 (export) RV2 or Remove C96 L7 L11 L12
1000 RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
1200 RV12 VR9 VR2
1200 DX RV14 RV13 RV12 RV4
1600 DX RV12 RV11 RV6 RV3
2000 DX RV12 RV11 RV6 RV3
2400 RV12 RV11 RV6 RV3
EXCAIBUR (EPT30010Z
Board) VR14 or Cut R249 VR13 VR12
EXCALIBUR
(PTBM121D4X Board) RV14 RV13 RV12 RV4
COMMANDO RADIOS
Model Modulation AM Power SSB Power
2310 Rv5 or Cut D10 CV1
2320 VR7 or Cut D14 L11 L10
2325 VR7 or Cut D14 L11 L10
2340 Cut R82 or Cut D11 L19 L18
COMMTRON RADIOS
Model Modulation AM Power SSB Power
VIII RV201 or Cut D203 L304 L305 L306
XII (export) RV201 or Cut D203 L304 L305 L306
CONNEX RADIOS
Model Modulation AM Power SSB Power
3300 Cut R249 & R246 VR13 (L PWR) L32 L33
(HI PWR)
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
CONVOY RADIOS
Model Modulation AM Power SSB Power
CON-400 R121 or Cut D19 & D20 L34 L37
CON-430 VR102 or Cut D112 L113 L116
CON-450 R85 L25
COURIER RADIOS
Model Modulation AM Power SSB Power
BLAZER 40D VR9 or Cut D12 T13 L9
CADET Cut D4 L14 L15
CARAVELLE II VR6 or Cut D6 L2
CARAVELLE 40D R504 orCut D503 L404 L403
CENTURIAN 23 VR14 or Cut D46 & D47 VR17 L12 L14 VR12 L15
CENTURIAN 40D RT601 RT14 RT14
CENTURIAN PLL40 RT9 or Cut D24 RT14 RT14
CLASSIC II R715 C934 L14 L15
CLASSIC III R523 or Cut D506
CLASSIC IV RV3 or Cut D9 L11 L13
CLASSIC PLL40 VR6 ot Remove C508 or
Cut D505 L903 L906
CONQUEROR II VR6 or Cut D6 L2
CONQUEROR 40D R504 or Cut D503 L404 L403
CRUISER Cut D17 or D18 L7 L8 L9
GALAXY VR11 or Cut R104 VR6 VR7
GALAXY IV RV3 RV7 RV8
GALAXY V RV14 or Cut R249 VR13 VR12
GALAXY VI RV14 or Cut R249 VR13 VR12
GLADIATOR VR14 VR17 VR15
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
NIGHTRIDER 40DR VR301 L120 L119
RANGLER 40D VR301 L120 L119
REBEL 23+ Cut D12 L13 L12 L9
REBEL 40A VR207 or Cut D212 L211 L212 L214
REBEL PLL VR207 or Cut D212 L214
REDBALL Cut D17 or D18 L7 L8 L9
RENEGADE 40 VR9 or Cut D12 T13 L9
ROGUE 40 VR5 or Cut D12 L9
SPARTAN SSB Cut D54 & D53 VR14 VR9
TRAVELLER II VR6 L16 L18 L20
CRAIG RADIOS
Model Modulation AM Power SSB Power
4101 VR4 or Cut D18 L6 T9 T10
4102 VR4 or Cut D18 L6 T9 T10
4103 R192 or Cut CR118 &
CR119 L111 L110
4104 R192 or Cut CR118 &
CR119 L111 L110
4201 R192 or Cut CR118 &
CR119 L111 L110
L-101 R226 or Cut R224 L305 L308 L309
L-102 R348 or Cut CR312 L311 L315
L-103 Cut D8 L16
L-104 VR5 or Cut D9 L10
L-131 R605 or Cut CR602 L109 L106 R130
L-132 Cut R104 VR6 VR7
L-150 Cut D4 L14 L15 L17
L-231 R605 or Cut CR602 L109 L106 R130
L-232 Cut R104 VR6 VR7
L-600 VR402 or Cut R461 T409 T410
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/c.html[3/12/2010 12:33:53 AM]
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Ham Radio 2010 Special
Entry-level license for $20 and 10 hours
study. No Morse code needed!
Stryker CB Radio Sale
Reduced pricing on all CB radios. Free
Shipping on orders over $200.
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/def.html[3/12/2010 12:34:50 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
DAK RADIOS
Model Modulation AM Power SSB Power
DAK IX (old) RV202 or Remove Q202 C714
DAK X REMOVE Q37 & Q38 RV201 RV2
MARK II Remove C226 L307 L308 L309
MARK V RV202 or Cut D202 L306 L307 L308
DIRLAND RADIOS
Model Modulation AM Power SSB Power
77-099 RV4 or Cut D8 L11 L12
SS-3900 VR14 or Remove TR53 VR13 VR12
SS-3900B VR14 or Remove TR53 VR13 VR12
EAGLE RADIOS
Model Modulation AM Power SSB Power
Eagle 2000 VR14 or Cut R249 VR13(HI PWR) VR16(LO
PWR) VR12
Eagle 5000 VR14 VR13(HI PWR) VR16(LO
PWR VR12
ECHO RADIOS
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/def.html[3/12/2010 12:34:50 AM]
Model Modulation AM Power SSB Power
Echo 49er VR5 or Cut D17 L9 L8 L7
Echo 99er R74 or Cut D4 T7 L14 L15
EMPEROR RADIO
Model Modulation AM Power SSB Power
TS-5010 VR110 or Cut R247 VR111 VR103
FALCON RADIO
Model Modulation AM Power SSB Power
FALCON 2000 RV12 RV11 RV6 RV3
FANON RADIOS
Model Modulation AM Power SSB Power
10-40 (AM/FM/CB) VR4 L5 L8 L9
FANFARE 100 Cut D12 L9 L12
FANFARE 100F1 VR207 or Cut D212 L211 L212 L214
FANFARE 120 VR5 or Cut D7 L8 L9
FANFARE 125F VR5 or Cut D12 T14 T13 L9
FANFARE 182F VR9 or Cut D12 T14 T13 L9
FANFARE 184DF VR9 or Cut D12 T14 T13 L9
FANFARE 185DF VR301 L118 L120 L119
FANFARE 185PLL VR301 L118 L120 L119
FANFARE 190DF VR301 L118 L120 L119
FANFARE 350F VR8 or Cut D33 VR6 VR7
FANFARE 700 R40 or Remove Q8 L3 C6
FANFARE 880 VR6 or Cut D6 L2
FANFARE 880DF R504 or Cut D503 L404 L403
FANON SFT-400 Cut D10 & D9 A10
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/def.html[3/12/2010 12:34:50 AM]
FANON SFT-500 Cut D10 & D9 A10
FANON SFT-900 VR403 or Cut D204 A16 A17
FANON T-600 R510 or Cut D503 L901 L902
FANON T-700 R510 or Cut D503 L901 L902
FANON T-800 R510 or Cut D503 L901 L902
FANON T1000C VR6 or Cut D505 L911
FIELDMASTER RADIO
Model Modulation AM Power SSB Power
MICRO-MINI 40 RV401 L13 L10
FORMAC RADIOS
Model Modulation AM Power SSB Power
88 AM/FM Export RV2 L7 L11 L12
FORMAC 40 VR2 or Remove C96 L7 L11 L12
FORMAC 240 VR3(LO MOD)
VR4(MED MOD) VR5
(HI PWR MOD)
LT3 LT2 (HI PWR) VR6
(MID PWR) VR7(LO
PWR)
FORMAC 700 VR3(LO MOD)
VR4(MED MOD) VR5(HI
PWR MOD)
LT6 LT5(HI PWR)
VR6(MID PWR) VR7(LO
PWR)
FOX RADIOS
Model Modulation AM Power SSB Power
CB-240 RV4 or Cut R65 or R61 L9 L11 L12
CB-340 RV201 L304 L305 L306
CB-440 RV4 L11 L12 L14
CB-911 RV1
FULCOMM RADIOS
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/def.html[3/12/2010 12:34:50 AM]
Model Modulation AM Power SSB Power
2303 VR206 or Cut D214 &
D214 L301 VC201 VR104 VR205
2330 VR481 or Cut D481 &
D482 L451 L463
FUZZBUSTER RADIOS
Model Modulation AM Power SSB Power
Z-40 RV201 or Remove C253 L205 L206 L207
Z-50 VR3 or Cut D7 LX18 LX19 LX20
Z-80 Cut D203 L305 L306 L304 L303
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Become a ham for $20
Entry-level ham license for $20 and 10
hours study. Success guaranteed!
Sony dash Internet Viewer
Display Over 1,500 Free Internet Apps At
the Touch of Your Finger.
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/g.html[3/12/2010 12:35:32 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
GALAXY RADIOS
Model Modulation AM Power SSB Power
2100 VR14 or Cut R249 VR13 VR14
33 PLUS VR14 or Remove TR53 VR13(LOW) L32 L33
(HI)
DX 11B VR14 VR803..AM/FM Low
Power VR13...AM/FM
High Power VR12
DX 22B VR14 VR15...AM Low Power
VR13...High Power VR12
DX 2517 VR16 VR18...AM/FM Low
Power VR14...AM/FM
High Power VR17
DX 2527 VR14 VR15...AM Low Power
VR13...High Power VR16
DX33 HML Cut R249 VR13 (HI PWR)
DX33 HML (late) VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR)
DX 44V Cut R249 VR13 (HI PWR)
DX 55V VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR)
DX 66V VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR)
DX 77HML VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR) VR12
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/g.html[3/12/2010 12:35:32 AM]
DX 77V VR14 or Remove TR53
VR13(HI PWR)
VR16(LO PWR) VR12
DX 88HL VR14 or Cut R249 VR13 VR12
DX 949 VR16 VR18...AM Low Power
VR14...AM High Power VR13 VR17
DX 99V VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR) VR12
DX 959 VR16 VR18...AM Low Power
VR14...AM High Power VR13 VR17
Galaxy II VR14 or Cut R249 VR13 VR12
Jupiter VR14 or Cut R249 VR13 VR12
Mars Cut One End Of R104 &
D11 L14 L12 L11 L10 (HI
PWR)
Mirage 44 Cut R249 VR13 VR12
MIRAGE 44 (EPT
360014B Board) VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR)
MIRAGE 66 Cut R249 VR13 VR12
MIRAGE 88 Cut R249 VR13 VR12
PLUS VR14 or Cut R249 VR13 VR12
PLUTO VR14 or Cut R249 VR13 VR12
PLUTO (late) VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR) VR12
SATURN VR14 or Cut R249 VR13 VR12
SATURN II VR14 or Remove TR53 VR13(HI PWR) VR16(LO
PWR) VR12
SIRIUS VR4 or Cut R124 L18 L21 L25
SUPER GALAXY VR14 or Cut R249 VR13 VR12
GEMTRONICS
Model Modulation AM Power SSB Power
GR-11930 VR481 or Cut D481 &
D482 L451 L463
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/g.html[3/12/2010 12:35:32 AM]
GT-230
VR5 or Remove C56 or
Cut D14 L9 L10
GT-44 RV2 or Remove C96 L7 L11 L12
GT-55 RV2 or Remove C96 L7 L11 L12
GTX-23 VR481 or Cut D481 &
D482 L451 L463
GTX-230 VR5 or Remove C56 or
Cut D14 L9 L10
GTX-2325 VR103 or Cut D214 VC201 VR205
GTX-3000 R94 or Remove C82 or
Cut D16 L9 L10
GTX-3323 VR481 or Cut D481 &
D482 L451 L463
GTX-36 VR481 or Cut D481 &
D482 L451 L463
GTX-4040 VR481 or Cut D481 &
D482 L451 L463
GTX-5000 VR4 L702 (TOP)
GTX-66 RV2 or Remove C96 L7 L11 L12
GTX-77 RV12 or Remove Q37 &
Q38 VR4 VR2
GENERAL ELECTRIC RADIOS
Model Modulation AM Power SSB Power
3-5800A VR5 or Cut D507 or D508 L906
3-5801A VR7 or Cut D505 L905 L903
3-5804 RV5 or Cut D12 T4 T5 L3
3-5804A VR7 or Cut D505 L905 L903
3-5804B VR8 or Remove Q503 L905 L903
3-5804D RV2 or Remove C96 L7 L11 L12
3-5804F Cut D8 or Change R87 to
1.2k L9 L12 L16
3-5804G RV5 or Cut D12 T4 T5 L3
3-5805A Cut D13 L8 L9 L12
3-5805B RV201 L304 L305 L306
3-5806 Cut D9 L9 L11 L12
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/g.html[3/12/2010 12:35:32 AM]
3-5806A VR4 L11 L12
3-5810A VR7 Cut D505 or D504
3-5810B RV102 or Cut D111 L110 L109
3-5811B RV2 or Remove C96 L7 L11 L12
3-5813A RV2 or Remove C96 L7 L11 L12
3-5813B RV2 or Remove C96 L7 L11 L12
3-5814A RV2 or Cut D10 L10 L5 L9
3-5814B RV2 or Remove C96 L7 L11 L12
3-5814D Remove Q14
3-5815A VR504 or Cut D512 L903
3-5816A RV4 L5 L6 L7 L8
3-5817A RV2 or Cut D11 T3 T4 L3
3-5818A VR2 or Remove C98 L5 L9 L10
3-5819A RV2 or Remove C96 L7 L11 L12
3-5819B VR2 or Remove C98 L5 L9 L10
3-5821A VR10 or Cut R554 or Cut
D519 L903 L905
3-5821B VR10 or Cut R554 or Cut
D519 L903 L905
3-5825A RV12 or Remove Q37 &
Q38 VR5 RV2
3-5825B RV9 VR1 RV3 RV201
3-5826A RV6 RV7 RV5 RV2
3-5827A RV501 L305 L308
3-5830 VR2 L4 L1 L3
3-5869A RV2 or Cut D10 L5 L9 L10
3-5871A VR6 or Cut D504 & D505 L905
3-5871B VR11 or Cut D504 L905 L903
3-5875A (SUPERBASE) RV9 or Remove C71 VR10 RV20
3-5900A RV3 or Remove V71 VR10
GENERAL MOTORS RADIOS
Model Modulation AM POWER SSB Power
4120 Cut CR12 L6 L4
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/g.html[3/12/2010 12:35:32 AM]
4145 Cut CR12 L6 L4
4175 Cut CR14 T8
4230 CR12 L6 L4
70BFMCE Remove VR2 L12
80BCB1 RV2 or Remove C96 L7 L11 L12
80BCB2 Remove RV2 L4 L9
80BFTC1 RV2 or Remove C96 L7 L11 L12
86KFTC1 RV2 or Remove C96 L7 L11 L12
90BCB1 Remove RV2 L4 L9
90BFMC1 Cut D9 L44
90BFPC1 Cut D9 L44
90BFTC1 Remove RV2 L4 L9
91YFMC1 Cut D9 L44
9OECB1 Remove RV2 L4 L9
CBD-10 RV102 or Cut D111 L110 L109
CBD-12 Cut CR11 L6 L7
CBD-203 AM-FM-CB RV2 L4 L8 L9
CBD-20U (90BCB2) RV2 L4 L8 L9
GM123A Cut CR11 L6 L7
GM130 Cut CR11 L6 L7
GM23B Cut D9 L8
GM23C Cut D9 L8
GLOBE RADIOS
Model Modulation AM Power SSB Power
9000 VR7 or Cut D14 L9 L10 L11
9001 VR7 or Cut D14 L9 L10 L11
GRAN PRIX RADIOS
Model Modulation AM Power SSB Power
1125 VR7 or Cut D14 or D15 L18 L17
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/g.html[3/12/2010 12:35:32 AM]
D-1235RF
VR481 or Cut D481 &
D482 L451 L463
GRANADA RADIOS
Model Modulation AM Power SSB Power
CB-6 RV5 or Cut D17 & D18 L16 L14
CB-7 Remove C322 or Cut D11 L15
FCB-27 Remove C322 or Cut D11 L15
GREAT RADIOS
Model Modulation AM Power SSB Power
GT-818 VR8 L901 L903 L905
GT-838 Cut D17 T203 T204 T205
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Become a ham for $20
Entry-level ham license for $20 and 10
hours study. Success guaranteed!
CB Radios & Equipment
Galaxy, Connex, Magnum Radios Sirio, CB,
Ham & Marine Antennas
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/hi.html[3/12/2010 12:36:44 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
HAM INTERNATIONAL RADIOS
Model Modulation AM Power SSB Power
120-FM VR13(LO PWR MOD)
VR12(MED PWR MOD)
VR11(HI PWR MOD)
VR15(LO PWR)
VR14(MED PWR) L15
L16(HI PWR)
CONCORDE II RV14 RV13 RV12 RV4
CONCORDE III RV12 RV11 RV9 RV3
JUMBO III RV12 RV11 RV9 RV3
MAJOR 120 (EXPORT) RV2 or Remove C96 L7 L11 L12
MAJOR M-360 RV12 or Remove Q37 &
Q38 VR4 RV11 RV3
MULTIMODE III RV12 RV11 RV9 RV3
HANDIC RADIOS
Model Modulation AM Power SSB Power
199 VR2 or Cut D23 or D12 VR5
230 R85 or Cut D22 L25
2305 R51 or Remove C54 L8 L7
235 R54 or Cut D9 & D10 L6 L5
240 (AM-FM-CB) VR102 L113 L116
305 R54 or Cut D9 & D10 L6 L5
3605 R51 or Remove C54 VR6 or Cut D14 & D15
605 R54 or Cut D9 & D10 L6 L5
605 DL VR4 or Cut D6 L9 L8
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/hi.html[3/12/2010 12:36:44 AM]
HITACHI RADIOS
Model Modulation AM Power SSB Power
CM-2375H Cut D12 T15 T14
CM-2400C Cut D17 T17 T18
CM-2400H Cut D17 T17 T18
CM-2425H Cut D19 T13
CM-4800 C-H Cut D17 T17 T18
HUNTER RADIO
Model Modulation AM Power SSB Power
Hunter 120 RV3 or Cut D9 L11 L12 L13
HY-GAIN RADIOS
Model Modulation AM Power SSB Power
2679A RV102 or Cut D111 L110 L109
2680 RV102 or Cut D111 L110 L109
2681 RV102 or Cut D111 L110 L109
2682 RV102 or Cut D111 L110 L109
2683 RV102 or Cut D111 L110 L109
2701 RV102 or Cut D111 L110 L109
2702 RV2 or Remove C96 L7 L11 L12
2703 RV2 or Remove C96 L7 L11 L12
2705 Remove Q37 & Q38 VR4 RV2
2710X RV201 or Cut D111 L106 L109 L110
2720 RV201 or Cut D111 L106 L109 L110
2795 RV14 RV13 RV12 RV4
2795-DX RV14 RV13 RV12 RV4
3077 RV2 or Cut D10 L9 L8
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/hi.html[3/12/2010 12:36:44 AM]
670B RV2 or Cut D10 L7 L8 L9
670B-PR RV2 or Cut D10 L7 L8 L9
672B RV2 or Cut D10 L7 L8 L9
8795 (V) RV12 RV11 RV6 RV3
HYGAIN 16 (2716) RV2 or Remove C209 L109 L110
HYGAIN 9 (2679) RV102 or Cut D111 L110 L109
HYGAIN I RV102 or Cut D111 L110 L109
HYGAIN II RV102 or Cut D111 L110 L109
HYGAIN VII RV2 or Remove C96 L7 L11 L12
HYGAIN VIII (3078) RV7 or Cut D301 RV608 RV8 RV5
HY-RANGE I Cut D6 D10 D11
HY-RANGE IA RV102 or Cut D111 L110 L109
HY-RANGE II Cut D6 D10 D11
HY-RANGE IIA RV102 or Cut D111 L110 L109
HY-RANGE III RV103 L110 L111 VC2
INTEK RADIO
Model Modulation AM Power SSB Power
INTEK 2000FM RV14 RV13 RV12 RV4
ITT RADIOS
Model Modulation AM Power SSB Power
CB-4000FM R40 or Cut D10 L3 T13
4000 VR206 or Cut D209 L211 L210 L209
4400M VR206 or Cut D209 L211 L210 L209
Want More? Check Out The CD! Over 400MB of VERY Useful Information
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/hi.html[3/12/2010 12:36:44 AM]
HamTestOnline 2010 Promo
Tech license for $20 and 10 study hours.
Success guaranteed!
Cb Radio Manufacturers
Suppliers checked by D&B. Free info by HK
Trade Development Council.
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/jkhtml.html[3/12/2010 12:37:39 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
JC PENNY RADIOS
Model Modulation AM Power SSB Power
981-6203 Cut D7
981-6204 (981-7461) RV2 or Remove C96 L7 L11 L12
981-6212A Cut D10
981-6213 Cut D1 L5
981-6216 (981-3130) RV2 or Remove C98 or
Cut D10 L10
981-6218 RV2 or Remove C96 L7 L11 L12
981-6221 (981-8345) Cut D501 or D502 T704 T705
981-6225 R2 or Remove C2 L406
981-6235 Cut D15 & D14 L5 L8 L9
981-6237 (981-8352) Cut D7 or D12 T14 T15
981-6240 (981-3445) R212 L26 R316
981-6241 (981-8360) Cut D406 RT602 RT701
981-6246 Cut D313
981-6247 (981-3080 RV12 or Remove Q37 &
Q38 VR4 RV2
981-6248 Cut D302 RT301 RT402
981-6255 (981-7701) Cut D401 or D402 T704 T705
JIL RADIOS
Model Modulation AM Power SSB Power
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/jkhtml.html[3/12/2010 12:37:39 AM]
606CB Cut D208 L208 L209
615CB VR101 L203 L202 L201
825CB Cut D208 L208 L209
860CB VR101 L203 L202 L201
SSB-M6 RV12 or Remove Q37 &
Q38 VR4 RV1 RV2
JOHNSON RADIOS
Model Modulation AM Power SSB Power
110 Cut X6 A13 A14
120A Cut CR5 L3 L4
121A Cut CR5 L3 L4
123 Cut D7
123A Cut CR11 L6 L7
123B Cut CR11 L6 L7
123SJ Cut CR11 L6 L7
125 Cut D5
130 Cut CR11 L6 L7
132 Cut CR11 L6 L7
250 Cut CR11 L6 L7
320 Cut X11
323 Cut X11
323M Cut D17
MESSENGER 323A Remove C93 or Cut CR19 L10 L9
MESSENGER 351 VR7 or Cut D34 L7 L8
MESSENGER 40 VR49 or Cut CR62 L84 L85 L86
MESSENGER 4120 Cut CR12 L3 L4 L6
MESSENGER 4125 Cut CR12 L3 L4 L6
MESSENGER 4135 Cut CR12 L3 L4 L6
MESSENGER 4140 Cut CR12 L3 L4 L6
MESSENGER 4145 Cut CR12 L3 L4 L6
MESSENGER 4170 Cut CR12 L3 L4 L6
MESSENGER 4175 Cut CR12 L3 L4 L6
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/jkhtml.html[3/12/2010 12:37:39 AM]
MESSENGER 4190 Cut CR12 L3 L4 L6
MESSENGER 4230 Cut CR12 L3 L4 L6
MESSENGER 4250 Cut CR12 L3 L4 L6
MESSENGER 4730 R207 or Cut CR202 T704 T705 T706 R725
MESSENGER 50 VR49 or Cut CR62 L84 L85 L86
MESSENGER 80 VR49 or Cut CR62 L84 L85 L86
VIKING 200 Cut CR12 L3 L4 L6
VIKING 230 R49 or Cut CR64 T83 L84
VIKING 260 R49 or Cut CR64 T83 L84
VIKING 270 R49 or Cut CR64 T83 L84
VIKING 352 R216 or Cut CR203 T702 T703 R727
VIKING 430 R49 or Cut CR64 T83 L84
VIKING 4330 R227 or Cut CR12 T8
VIKING 4360 R227 or Cut CR12 T8
VIKING 4740 R216 or Cut CR203 T704 T705 T706 R726
K-40 RADIOS
Model Modulation AM Power SSB Power
K40 SSB Cut D301 L15 VR101
K40-1 T401 or Remove C417 TT004 TT005
K401 (AM) RT401 or Cut D9 L104 L107 L108
K40-2 RV201 or Remove C213 L304 L305 L306
K40-3 VR3 or Remove C94 T9 T10
K40-6 VR3 or Remove C94 T9 T10
K40-7 Cut D14 L6 L5 L4
Trucker Model VR5 or Cut D9 L10 L9 L8
KINGHOOD RADIO
Model Modulation AM Power SSB Power
K-195 VR7 or Cut D14
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/jkhtml.html[3/12/2010 12:37:39 AM]
K-MART RADIOS
Model Modulation AM Power SSB Power
D-40 VR202 or Cut D202 T302 L303
K-605 VR202
KRACO RADIOS
Model Modulation AM Power SSB Power
CCB-4007 RV3 or Cut D7 L6 L7
KB-2355 RV7 or Cut D301 RV607 RV8 RV5
KB-4045 RV2 or Remove C96 L7 L11 L12
KCB-1300 VR5 or Cut D7 L8 L9
KCB-1307 VR4 or Cut D9 L16
KCB-1401 VR7 or Cut D14 L11 L10 L9
KCB-2310A VR7 or Cut D14 L11 L10 L9
KCB-2320 RV2 L7 L8 L9
KCB-2320A RV102 or Cut D111 L110 L109
KCB-2320B RV102 or Cut D111 L110 L109
Kcb-2330B RV102 or Cut D111 L110 L109
KCB-2340 RV7 or Cut D206 RV605 RV8 RV5
KCB-2370 VR401 or Cut D402 L309
KCB-2390 Cut D208 L208 L209
KCB-4000 VR4 L6 L9
KCB-4001 VR202 or Cut D202 L303
KCB-4003 VR202 or Cut D205 L204 L205 L206
KCB-4004 R207 or Cut D201 L205 L202
KCB-4005 VR201 or Cut D201 L402 L403 L404 VR402
KCB-4006 RV1 or Remove C47 T3 T4 T6
KCB-4007 RV3 or Cut D7 L5 L4 L3
KCB-4009 RV1 or Remove C47 T3 T4 T6
KCB-4010 RV2 or Remove C96 L7 L11 L12
KCB-4020 RV2 or Remove C96 L7 L11 L12
KCB-4030 RV2 or Remove C96 L7 L11 L12
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/jkhtml.html[3/12/2010 12:37:39 AM]
KCB-4060 VR3 L9 L8
KCB-4070 VR402 or Cut D402 L317
KCB-4088 VR104 or Cut D115 L402
KCB-4090 VR401 or Cut D403 or
D405 L613
KCB-4095 VR401 or Cut D403 or
D405 L613
KCB-5001 RV2 or Remove C96 L7 L11 L12
KCB-5003 RV2 or Remove C96 L7 L11 L12
KRIS RADIOS
Model Modulation AM Power SSB Power
KRIS 99'ER R74 or Cut D4 L14 L15 T7
VEGA R74 or Cut D4 L14 L15 T7
VICTOR R51 or Cut CR11 L12 L13
VICTOR II R51 or Cut CR11 L12 L13
XL-23A VR6 or Cut D10 or D11 L12 L13
XL-25 VR6 or Cut D10 or D11 L12 L13
XL-45 VR201 or Cut D205 &
D206 L309 L308
XL-50 VR301 or Cut D305 &
D304 L13
XL-70 VR206 or Cut D214 &
D213 VC201 VR104
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Why Settle for CB?
Talk around the world with ham radio. No
Morse Code required!
CB Radios & Equipment
Galaxy, Connex, Magnum Radios Sirio, CB,
Ham & Marine Antennas
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
LAFAYETTE RADIOS
Model Modulation AM Power SSB Power
1800 RV12 RV11 RV6 RV3
2400-FM RV12 RV11 RV6 RV3
CBH-740 RV2 or Remove C96 L7 L11 L12
COM-PHONE-23 RV4 or Cut D11 L7 L8
COM-PHONE-23A RV102 or Cut D111 L110 L109
COM-PHONE-Mark II RV4 or Cut D16 L7 L8
COMSAT-35 RV4 L6 CV3
COMSAT-525 RV2 or Remove C96 or
Cut D11 L7 L11 L12
DYNA-COM 40 RV2 or Remove C96 or
Cut D11 L7 L11 L12
DYNA-COM 5A R4 or Cut X4 A9 A10
HB-4000 VR2 or Cut D8 L4 L3 L1
HB-525F RV4 L13 VC VR6
HB-550 Remove C217 or Cut
D201 L308 L307
HB-625A VR4 VC1 L12 L13
HB-640 RV2 or Remove C96 or
Cut D11 L7 L11 L12
HB-650 RV102 or Cut D111 L110 L109
HB-700 RV203 or Cut D211 L215 VC1
HB-740 RV2 or Remove C96 or
Cut D11 L7 L11 L12
HB-750 RV102 or Cut D111 L110 L109
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
HB-870 AFS RV14 RV13 RV12 RV4
HB-940 RV2 or Remove C96 or
Cut D11 L7 L11 L12
HB-950 RV102 or Cut D111 L110 L109
LM-100 RV2 or Cut d3 L7 L11 L12
LM-200 VR305 or Cut D312 L402 L405
LM-300 RV2 or Cut D3 L7 L11 L12
LM-400 VR201 or Cut D205 L201 L204
MB-740 Remove Q15
MICRO-223A RV102 or Cut D111 L110 L109
MICRO-66 RV102 or Cut Q118 L103 L102 C001
MICRO-723 Cut D107 L115
TELSAT SSB-100 RV7 or Cut D301 RV607 RV8 RV5
TELSAT SSB-140 RV12 VR4 RV11 RV2
TELSAT SSB-25A RV8 or Cut D22 L18 L19 TC18 RV9 RV7
TELSAT SSB-50A RV8 or Cut D22 L18 L19 TC18 RV9 RV7
TELSAT SSB-75 RV7 or Cut D206 RV304 RV8 RV5
TELSAT-1000 Cut D201 L308 L307
TELSAT-1023 RV103 L114 L115
TELSAT-1050 RV102 or Cut D111 L110 L109
TELSAT-1140 RV2 or Remove C96 or
Cut D11 L7 L11 L12
TELSAT-1240 VR305 orCut D312 &
D311 L402 L405 L406
TELSAT-925 VR6 or Cut D13 L8 VC
LAKE RADIOS
Model Modulation AM Power SSB Power
410 RV202 or Remove C209 L304 L305 L306
450 VR301 or Remove C313 LC202 LC203 LC204
5000 (SN-16) VR402 or Cut D402 L317 L319
5100 (SN-14) VR401 or Cut D401 L317 L310
600 VR2 or Remove C96 LC203 LC204
650 R218 or Cut CR205 & T301 T302 T303
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
CR204
750 R226 or Cut CR39 &
CR40 L308 L309
LINCOLN RADIO
Model Modulation AM Power SSB Power
1500 RV2 or Remove C96 L7 L11 L12
MEDALLION RADIOS
Model Modulation AM Power SSB Power
63-030 RV2 or Remove C96 L7 L11 L12
63-200 VR2 or Cut D8 L4 L3 L1
63-240 VR2 or Cut D8 L4 L3 L1
63-540 VR501 or Cut D502 L1 L2 L3
MARKO RADIO
Model Modulation AM Power SSB Power
CB-444 RV2 or Remove C96 L7 L11 L12
MAXON RADIOS
Model Modulation AM Power SSB Power
LP-27 RV202 L307
MCB-25 RV2 or Cur one end of
D403 L802 RFC705 RFC709
MCB-30 RV2 or Cur one end of
D403 L802 RFC705 RFC709
MCB-60 RV201 or Remove C215 L304 L305 L306
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
METROSOUND RADIO
Model Modulation AM Power SSB Power
CB-1 Cut D7 LX19 LX20 LX16
MIDLAND RADIOS
Model Modulation AM Power SSB Power
1001 RV201 or Cut D203 L304 L305 L306
100M RV201 or Cut D203 L304 L305 L306
101M RV201 or Cut D203 L304 L305 L306
102M RV201 or Cut D203 L304 L305 L306
103M RV201 or Cut D203 L304 L305 L306
104M VR4 L14 L13 L12
105M (77-150) RV201 or Cut D203 L304 L305 L306
13-700 VR4 L7 L8 L11
13-729 Cut D105 L101
13-779 Cut D8 L5
13-796 VR4 L5
13-830 RV102 or Cut D111 L110 L109
13-845 VR502 or CutD502 L6 L5
13-852 VR5 or Cut D703 or
D702 L914 VC1
13-853 VR5 or Cut D703 or
D702 L914 VC1
13-854 Cut D6 C4 L2
13-857 RV2 or Cut D10 L8 L9
13-857B RV102 or Cut D111 L110 L109
13-858 RV102 or Cut D111 L110 L109
13-862 R58 or Cut D8 T14 L3
13-862B R58 or Cut D8 T14 L3
13-863 RV103 or Cut D111 L113 L114 L115
13-863B RV2 or Cut D10 L8 L9
13-866 Cut D1 L5
13-867 Cut D14 L12 L13
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
13-870D VR3 or Cut D10 L3 L4
13-871 VR9 or Cut D14 L12 L13 L15
13-879 Remove C88 L15
13-879B R58 L3 C5
13-881 VR7 or Cut D26 L2 L21
13-882 Cut D6 L10 L11 L9
13-882B RV2 or Cut D10 L8 L9
13-882C Remove Q121 L109 L110
13-883 Cut D24 L11 L7 L8
13-883B VR213 or Cut D216 L212 L215
13-884 VR7 or Cut D506 or
D505 L909 L908
13-886 RV2 or Cut D10 L8 L9
13-887 RV103 or Cut D111 L113 L114 L115
13-888B RV102 or Cut D111 L110 L109
13-892 RV7 or Cut D206 RV305
13-893 VR12 or Cut D41 & D40 L8 VR15
13-894 VR9 or Cut D48 L13 L11 VR11
13-895 VR12 or Cut D41 & D40 L8 VR15
13-896 VR9 or Cut D48 L13 L11 VR11
13-898 RV301 or Cut D302 L1 TC1 RV302 RV106
13-898B RV302 or Cut D301 L113 L114 L112 L107 RV301
13-955 RV102 or Cut D111 L110 L109
13-976 RV7 or Cut D206 RV605 RV8 RV5
2001 RV201 or Cut D203 L304 L305 L306
200M (77-200) VR4 or Cut D11 L11 L14
3001 RV201 or Cut D203 L304 L305 L306
4001 RV201 or Cut D203 L304 L305 L306
5001 (77-005) RV2 or Cut D10 T4 L5 L10
52-100 (CARAVAN) RV2 L7 L12
6001 (79-006) RV9 VR1 RV8 RV10
6001 (79-012 ONLY) VR5 VR10 VR6
6001(7) VR5 VR10 VR6
63-445 VR5 or Cut D119 L112 L109
7001 RV9 VR1 RV8 RV10
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
7001(7) VR5 VR10 VR6
7001(8) RV12 RV11 RV6 RV3
76-300 (BASE AM) RV201or Cut D203 L304 L305 L306
76-858 RV2 or Remove C96 L7 L11 L12
76-860 VR6 or Cut D7 L3 L4 L5 L7
76-863 RV2 or Remove C96 L7 L11 L12
76-886 RV2 or Remove C96 L7 L11 L12
77-094 RV2 or Cut J27 L7 L6
77-099 RV4 or Cut D8 L10 L11 L13
77-101B RV201or Cut D203 L304 L305 L306
77-101C RV201or Cut D203 L304 L305 L306
77-104 RV4 L14 L13 L12
77-106 RV4 (Located Next To
C45) L11 L12 L13
77-112 RV4 or Remove C45 L11 L12
77-116 RV2 or Cut D7 L8 L9 L10
77-118 RV501 or Cut D502 L304 L305 L306 L307
77-145A RV104 or Cut D111 L204 L206 L207 L208
77-149 Cut D206 L12 L11 L10
77-151 (77-151M RV201or Cut D203 L305 L306
77-155 VR4 or CutR42 or D16 LX12 LX13 LX14
77-202A (202M) VR201 or Cut D203 L305 L306
77-225A RV4 L13 L14 L15
77-250 RV201or Cut D203 L304 L305 L306 L307
77-808 RV2 or Cut D10 L5 L9 L10
77-821 RV2 or Cut D10 L5 L9 L10
77-824 RV201or Cut D203 L304 L305 L306
77-824B VR5 or Cur D20 & D19 L15 L16 L12
77-824C RV201or Cut D203 L304 L305 L306
77-825 Remove C38 or Cut D3 T4 T5 L3
77-830 RV2 or Remove C96 L7 L11 L12
77-838 RV2 or Remove C96 L7 L11 L12
77-849 RV2 or Remove C96 L7 L11 L12
77-853 VR7 L205 L903 L901
77-856 VR5 or Cut D9 L16 L15 L12
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
77-857 RV2 or Remove C96 L7 L11 L12
77-859 RV2 or Remove C98 or
Cut D10 L5 L9 L10
77-860 VR6 or Cut D7 L3 L4 L5 L7
77-861 Cut D2 L4 L5 L13
77-861B Remove C53 T2 T3 T4
MIDLAND RADIOS (cont)
Model Modulation AM Power SSB Power
77-865 VR5 or Cut D21 L16 L15 L12
77-882 VR2 or Cut C96 L7 L11 L12
77-883 VR401 L215
77-888 RV2 or Remove C96 L7 L11 L12
77-889 RV2 or Remove C96 L7 L11 L12
77-899 RV2 or Remove C96 L7 L11 L12
77-955 RV2 or Remove C96 L7 L11 L12
77-963 RV2 or Remove C96 L7 L11 L12
78-574 RV9 or Remove C71 or
Cut D22 VR1 RV3 RV201
78-976 RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
78-999 RV9 or Remove C71 VR2 RV3 RV201
79-012 (6001) VR5 VR10 VR6
79-265 RV3 RV7 RV8
79-891 RV9 or Remove C71 VR2 RV3 RV201
79-892 RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
79-893 RT601 VR6 VR7
79-900(4) VR6 or Cut R104 VR7 CT4
79-900(5) Cut R104 VR6 VR7
MONGOOSE RADIO
Model Modulation AM Power SSB Power
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
2000 RV12 RV11 RV3 RV7
MONTGOMERY WARDS RADIOS
Model Modulation AM Power SSB Power
GEN-680A VR3 or Cut D8 L6 L7 L9
GEN-696A VR3 or Cut D8 L6 L7 L9
GEN-702A VR6 or Cut D209 L208 L209 L210 L211
GEN-716A VR3 or Cut D8 L6 L7 L9
GEN-719A Cut R104 VR6 VR7
GEN-730A VR6 or Cut D209 L208 L209 L210 L211
GEN-774A VR7 or Cut D19 L6 L7 L10
GEN-775A VR6 or Cut D209 L208 L209 L210 L211
GEN-828A VR6 or Cut D209 L208 L209 L210 L211
MOPAR RADIOS
Model Modulation AM Power SSB Power
4094173 VR402 L319 L317
4094176 RV2 or Remove C96 L7 L11 L12
4094177 RV2 or Remove C96 L7 L11 L12
4094178 RV2 or Remove C96 L7 L11 L12
4094179 RV2 or Remove C96 L7 L11 L12
MORSE ELECTROPHONIC RADIOS
Model Modulation AM Power SSB Power
2001 VR202 or Cut D205 L205 L204
3005 RV2 or Remove C96 L7 L11 L12
CB-2000 R83 or Cut D10 & D9 L1 L2
CB-700 RV5 or Cut D10 CV1 L5
CB-800 VR481 or Cut D481 &
D482 L451 L463
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/lm.html[3/12/2010 12:38:36 AM]
MOTOROLA RADIOS
Model Modulation AM Power SSB Power
CB550 VR701 L310 L313 L316
CB555 VR701 L310 L313 L316
CF925AX Cut r27 & R33 or D8 L4 L3 L1
CM-540 VR701 L310 L313 L316 VR303
CM-550 VR701 L310 L313 L316 VR303
CM-555 VR701 L310 L313 L316 VR303
CT950AX VR501 L3 L1
T-4002A Cut CR206 & CR305
T-4005A Cut CR206 & CR305
T-4009A Cut CR206 & CR305
T-4010A Cut CR206 & CR305
T-4020A Cut CR206 & CR305
T-4025A Cut CR206 & CR305
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Ham Radio 2010 Special
Entry-level ham license for $20 and 10
study hours. Success guaranteed!
2-Way Radios
ICOM 2-Way Radios Check prices radios &
accessories
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
N.D.I. RADIOS
Model Modulation AM Power SSB Power
PC101 R203 or Cut CR304 T502 T503
PC102 R203 or Cut CR304 T502 T503
PC200 R217 or Cut CR206 R207 R721
PC201 R217 or Cut CR206 R207 R721
NATO RADIO
Model Modulation AM Power SSB Power
2000 RV12 RV11 RV3 RV7
NUVOX RADIOS
Model Modulation AM Power SSB Power
CB-7000 VR7 or Cut D14 L11 L9
TC-5020 R69 or Cut D16 L5 T14
OLSON RADIO
Model Modulation AM Power SSB Power
CB-409 VR5 or Cut D11 L16 L15
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
OMNIVOX RADIO
Model Modulation AM Power SSB Power
GB-1000 Remove C207 L7 L10
ORBITSONIC RADIO
Model Modulation AM Power SSB Power
ORBITSONIC 200 VR202 T205 T206
PACE RADIOS
Model Modulation AM Power SSB Power
1000 MC R521 or Cut CR508 L109 L107 R134
2300C R243 or Cut CR9 &
CR205 L10 L11 L12
2376B Cut CR9 L12
8003 VR201 or Remove C219
or Cut D201 L303 CT301 L304
8008 R218 or Cut CR18 or
CR19 L7
8010A R220 or Cut CR201 L308 L307
8014 R501 or Cut CR501 L602 L604 L605
8015A R220 or Cut CR201 L308 L307
8016 R168 or Remove C178 or
Cut CR115 L109 L106
8025 R207 or Remove C215 or
Cut CR21 L10 L4
8041 R302 or Remove C68 or
Cut CR15 L13 L14
8046 R302 or Remove C68 or
Cut CR15 L13 L14
8047 R302 or Remove C68 or
Cut CR15 L13 L14
8092 R307 or Cut CR46 L10 L13 C306
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
8093 VR7 or Cut R52 L12 VR11
8113 R220 or Cut CR201 L308 L307
8117 R220 or Cut CR201 L308 L307
8155 R310 or Remove C313 or
Cut CR302 L404 L408 C432
8193 VR7 or Cut R52 L12 VR11
8340 R104 L404 L402
C123A Cut D11 L9
CB-113 VR503 or Cut CR102 &
CR103 L10 L11 L9
CB-144 R92 or Cut CR15 & CR16 L9 L10
CB-145 R506 or Cut CR301 L103 L102
CB-161 R218 or Cut CR18 &
CR19 L8 L7
CB-162 R64 or Cut CR7 L5 L6
CB-166 R207 or Cut CR20 or
CR21 L14 L15
CB-166C R207 or Remove C215 or
Cut CR21 L10 L4
CB-185 R302 or Remove C68 or
Cut CR15 L13 L14
CB-76 Cut CR9 L11 L12 L13
CB-8001 RV3 L4 L5
CB-8001(1) RV3 LX20
CB-8002 RV4 or Cut D16 LX12 LX 13 LX14
CBST-23 (SIDETALK
23) VR8 or Cut D44 L7 VR7
SIDETALK 1000B R616 or Cut CR603 L106
SIDETALK 1000M R616 or Cut CR603 L106
SIDETALK CB-1023 VR7 L3 VR3
SIDETALK1000BC R521 or Cut CR508 L109 L107 R134
PACER RADIO
Model Modulation AM Power SSB Power
XLR 29 Cut D207 L407 (Spreadable Coil)
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
PACIFIC RADIO
Model Modulation AM Power SSB Power
160 RV12 RV11 RV3
PAL RADIOS
Model Modulation AM Power SSB Power
COYOTY 23 VR206 or Cut D204 VC201 VR104
ROADRUNNER 23 VR7 or Cut D14 L9 L10 L11
PALOMAR RADIOS
Model Modulation AM Power SSB Power
1200 (EXPORT) Remove C99 L15 L16 (HI PWR)
21 Remove C204 or Cut D30 L9
2400 RV12 RV11 RV6 RV3
2900 RV12 or Remove Q37 &
Q38 VR4 RV11 RV2
4100 RV2 or Remove C96 L7 L11 L12
49 Cut D207 & D208 L403 L406
5000 RV12 RV11 RV6 RV3
SSB-500 VR6 & VR7 VR8 CT7
PANASONIC RADIOS
Model Modulation AM Power SSB Power
CQ-B5919EU VR801 T901 L904
CR-B1717EU VR902 & VR903 L903 L905 VR901
CR-B4737EU VR902 & VR903 L903 L905 VR901
CR-B4747EU VR902 & VR903 L903 L905 VR901
RJ-3050 R117 L25 L16
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
RJ-3100 Cut D21 L17 L18
RJ-3150 R117 L25 L16
RJ-3200 R74 & Cut D14 L16 L17 L18
RJ-3250 R70 L6 FL1 L18
RJ-3450 R50 L7 FL1 FL2
RJ-3600 R94 L10 FL1 L11
RJ-3660 R94 L10 FL1 L11
RJ-3700 R129 R189 R192
PARADYNAMICS RADIOS
Model Modulation AM Power SSB Power
PDC-19 VR6 or Cut D10 L6 L7
PDC-25 VR6 or Cut D10 L6 L7
PDC-29 VR103 or Cut D203 L404 L408
PEARSE SIMPSON RADIOS
Model Modulation AM Power SSB Power
ALLYCAT 23 Cut D11 L5 L8
BEARCAT 23C Cut D16 L15 L16 L19
BENGAL SSB Cut R109 L9 VR17 VR16
BOBCAT 23B Cut D7 L8 L10
BOBCAT 23C Cut D9 L8 L10
BOBCAT 23D VR4 or Cut D18 or D19 L10
BOBCAT 23E Cut D9 L8 L10
CHEETAH SSB Cut D53 & D54 L13 L10 VR15 L12 VR17
COURGAR 23 (late) VR6 or Cut D15 L22
COURGAR 23B Cut D16 L15 L16 L19
JAGUAR 40B FVR3 or Cut D10 or D11 L26 L25
LEOPARD B VR903 or VR902 VR901
LION 40 RV2 or Cut C96 L7 L11 L12
LYNX 23 VR9 or Cut D14 L6 L5
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
MARK II RV102 or Cut D111 L106 L110 L109
PANTHER SSB Cut D53 & D54 VR4 VR9
PUMA 23B Remover C50 or Cut R58 L4 L5 L8
PUMA 23C Cut D9 L8 L10
PUSSYCAT 23 R152 or Cut CR107 C162 L111
SIMBA SSB (late) VR14 or Cut D47 & D48 L12 L14 VR17 VR12
SUPER LYNX Remove C103 or Cut D12 L8 L5
SUPER TIGER 40A VR13 or Cut D8 L12 L9 L6
TIGER 23B Cut D10 L4 L7
TIGER 23C Cut D12 L4 L5 L8
TIGER 23D Cut D10 L4 L7
TIGER 40 RV2 or Cut C96 L7 L11 L12
TIGER 40A RV102 or Cut D111 L106 L110 L109
TOMCAT 23B VR4 or Cut D18 L10 L8
TOMCAT23C Change CR56 to 800
OHMS L9
PIONEER RADIOS
Model Modulation AM Power SSB Power
GT-1100G VR2 or Cut D8 L4 L3 L1
GT-600 Cut D8
GT-6600 VR2 or Cut D8 L4 L3 L1
PRESIDENT RADIOS (Also see Uniden radios)
Model Modulation AM Power SSB Power
ADAMS VR7 & VR6 VR8 CT7
ANDREW JACKSON VR5 or Cut D9 L13 L10 L9 L8
AR-14 Cut D9 L15 L12 L11
AR-144 VR5 or Remove TR29 VR10 VR6
AR-44 VR5 or Cut D9 L13 L10 L9 L8
AR-7 Cut D8 or Change R87 to
1.2k L10 L12 L16
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
AR-711 VR5 or Cut D9 L13 L10 L9 L8
AX-11 VR3 or Cut R54 L12 L14
AX-14 Cut D9 L15 L12 L11
AX-144 VR5 or Remove TR29 VR10 VR6
AX-24 VR3 or Cut R54 L12 L14
AX-4 Cut D19 & D13
AX-43 Cut D12 L8 L9 L12
AX-44 VR5 or Cut D9 L13 L10 L9 L8
AX-52 Remove TR13 L9 L12
AX-55 Remove TR13 L9 L12
AX-7 Cut D13 L8 L9 L12
AX-711 VR5 or Cut D9 L13 L10 L9 L8
CONVOY II Cut D18 L11 L9 L8
DWIGHT D (858) VR5 or Cut D14 L15 L12 L11
GRANT (858) VR7 & VR6 VR8 CT7
GRANT-DX VR14 VR13 VR12
HONEST ABE (858) VR5 or Cut D14 L15 L12 L11
JACKSON VR12 or Remove TR26 VR11 VR8
JACKSON (new) VR12 VR11 VR8
JAMES K Cut D4 L15 L17
JFK Cut Brown Wire Next To
D8 L20 L15 L14 (HI PWR)
JOHN Q RT4 or Cut D13 L15 L12 L11
LINCOLN VR114 VR103 VR102
MADISON (858 VR7 & VR6 VR8 CT7
McKINLEY (101001) Cut R104 VR6 VR7
McKINLEY (EXPORT) VR5 VR11 VR11
OLD HICKORY VR5 or Cut R75 L11 L12
P-200 Cut D14 L6 L5 L4
P-210 Cut D14 L6 L5 L4
P-220 VR5 or Cut D9 L10 L9 L8
P-300 VR5 VR10 VR6
P-400 Cut R104 VR6 VR7
TEDDY R (858) VR5 or Cut D14 L15 L12 L11
THOMAS J (1013001) VR4 or Cut D11 L14 L13 L12
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/nop.html[3/12/2010 12:39:19 AM]
VEEP VR6 or Cut D9 L12 L15 L16
WASHINGTON (858) VR7 & VR6 VR8 CT7
ZACHARY T (858) VR5 or Cut D14 L15 L12 L11
PYRAMID RADIOS
Model Modulation AM Power SSB Power
1300 RV3 or Remove C94 T9 T10
CB-22 VR3 or Cut D9 L11 L12 L13
CB-22 (late) RV4 or Cut D7 L5 L4 L1
CB-24 VR3 or Cut D9 L11 L12 L13
CB-25 RV3 or Cut D12 L5 L4 L1
CB-26 RV7 or Cut D22 L14 L16 L17
CB-28 RV301 or Cut D302 L5 L4
CB-29 D11
GTL-148 RV7 or Remove C120 L16 L17
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Ham Radio 2010 Special
Entry-level ham license for $20 and 10 study hours. Success guaranteed!
www.hamtestonline.com
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
QUESTAR RADIO
Model Modulation AM Power SSB Power
Mark I Cut D201 L307 L308
RANGER RADIOS
Model Modulation AM Power SSB Power
HCA-818 Cut R60 T9 L4
RCI-2900 VR14 VR13 VR12
RCI-2950 VR14 VR13 VR12
RCI-2950DX VR17 VR15 VR12
Rci-2970 VR14 VR15 (LO PWR) VR13 (
HI PWR) VR12
RCI-2970DX VR17 VR15 VR12
RCI-2980 VR14 VR15 (LO PWR) VR13 (
HI PWR) VR12
RCI-2980DX VR17 VR15 VR12
RCI-2990 VR14 VR15 (LO PWR) VR13 (
HI PWR) VR12
RCI-6300 VR16 VR14
RCI-6900 VR17 VR15 VR14
ST-1000 Cut R60 T9 L4
RAY JEFFERSON RADIOS
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
Model Modulation AM Power SSB Power
CB-707 R68 or Cut D16 L5 T14
CB-740 VR1 L4
CB-845 VR2 or Cut C96 L7 L11 L12
CB-905 R53 or Cut D7 L6 L2
RCA RADIOS
Model Modulation AM Power SSB Power
14T100 VR481 or Cut D481 &
D482 L451 L463
14T200 VR481 or Cut D481 &
D482 L451 L463
14T260 RV2 or Remove C96 L7 L11 L12
14T270 RV2 or Remove C96 L7 L11 L12
14T275 RV2 or Remove C96 L7 L11 L12
14T300 RV201 or Cut D111 L110 L109
14T301 RV201 or Cut D111 L110 L109
14T302 RV12 or Remove Q37 &
Q38 VR4 RV2
14T303 RV2 or Remove C96 L7 L11 L12
14T304 RV2 or Remove C96 L7 L11 L12
14T305 RV2 or Remove C96 L7 L11 L12
14T400 VR903 VR902 L905 L903
14T405 VR903 VR902 L905 L903
14T410 VR903 VR902 L903 VR901
REALISTIC RADIOS
Model Modulation AM Power SSB Power
TRC-10A Cut D8 or D10 T10 T11
TRC-180 R48 L13 L12 L7
TRC-190 VR4 (LO) VR5 (HI) or
Cut D11 L6
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
TRC-200 Cut R43 or Remove C52
or Cut D11 T7 L4 L5
TRC-204 Cut R43 or Remove C52
or Cut D11 T7 L4 L5
TRC-205 Remove TR306 L302 L303 L100
TRC-206 Cut R53 or D9 L8 L10
TRC-208 VR3 or Cut R49
TRC-209 VR5 or Cut D7 L4 L7 L8
TRC-210 Cut R77 L12 L8
TRC-211 Cut R49 L6 L7 VR5
TRC-212 Remove C76 L11 L12 VR4
TRC-214 Cut R60
TRC-215 VR2 (LO PWR MOD)
VR3 (HI PWR MOD) VR4 L6 L7
TRC-216 VR2 (LO PWR MOD)
VR3 (HI PWR MOD) VR4 L6 L7
TRC-217 Cut R68 L12 L13
TRC-218 Cut R70 L4 L3 L6
TRC-23B Cut D6 T15 T14
TRC-23C Cut D11 T15 T16
TRC-24B VR8 or Cut D507 L910 L912 L913
TRC-24C VR8 or Cut D507 L910 L912 L913
TRC-29 Cut D10 L11 L17
TRC-30 VR8 or Cut D507 L910 L912 L913
TRC-30A VR8 or Cut D507 L910 L912 L913
TRC-35C R501 or Cut D503 or
D504 L902 L901
TRC-410 Remove Q12 L5 L4 L3
TRC-411 Cut R61 & R64 T10 L5 L8
TRC-412 Remove Q6
TRC-413 Cut R85 L3 L6
TRC-414 Cut D7 or Remove Q10 L3 L6 L7
TRC-415 RV4 or Cut R63 L10 L11
TRC-416 VR2 L21 L22
TRC-417 Cut D10 L10 L3 L1
TRC-418 Cut R73 or D10 L3 L10
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
Trc-419 VR202 L306 L305 L304
TRC-420 Cut D105 & D106 L104 L106
TRC-420-18 Cut D105 & D106 L104 L106
TRC-420A Cut D6 L5 L4 L3
TRC-421 Cut D16 L18 L9 L12
TRC-421A Cut D16 & D17 L3 L6
TRC-422 Cut D16 T18 L9 L12
TRC-422A Cut D16 & D17 L3 L6
TRC-423 Remove Q207 L305 L306 L304
TRC-424 VR9 or Cut D509 & D508 L909 L910
TRC-425 VR8 or Cut D508 L901 L902 L905
TRC-426 VR8 or Cut D507 L901 L903 L905
TRC-427 VR5 or Cut D19 L15 L12
TRC-428 R104 or Cut R90 L5 L8
TRC-429 VR2
TRC-431 VR7 or Cut D506 & D507 L905 L907 L910
TRC-432 Remove Q10 or Cut R56 L5 L4 L3
TRC-433 Remove Q15 L4 L3
TRC-434 Cut D11 L11 L12
TRC-435 VR4 L12 L19 L18 L17
TRC-440 Cut D107 or D108 L102 L104 L106
TRC-441 Cut D109 L107 L104
TRC-443 Cut X3
TRC-446 Cut D110 L106 L104 L102
TRC-448 VR5 or Cut D27 & D28 VR210 VR204
TRC-449 VR6 & VR7 VR8 CT7
TRC-450 Cut D42 VR6 VR7
TRC-451 VR5 VR10 VR6
TRC-452 VR207 or Cut D213 or
D212 L212 L214 L211
TRC-453 VR5 VR10 VR6
TRC-454 VR702B or Cut D704 L903 L907 L908
TRC-455 R504 or Cut D503 C430 L404 L403
TRC-456 VR8 or Cut D507 L903 L905
TRC-457 VR6 & VR7 VR8 CT7
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
TRC-458 VR6 & VR7 VR8 CT7
TRC-459 VR13 or Cur D54 & D55 VR14 VR4 VR5
TRC-46 R212 T15 T16 R316 R213
TRC-461 VR2 or Cut D11 VR5
TRC-462 VR2 or Remove C60 L15 VR3
TRC-466 Cut D110 L104 L106
TRC-467 Cut D110 L104 L106
TRC-468 Cut D116 T14 T15
TRC-469 VR5 or Cut D17 & D18 L13 L11
TRC-47 R46 or Cut D10 & D9 R55 R102
TRC-470 VR10 or Cut D513 L901 L903 L905
TRC-471 VR2 or Remove Q6 L4 L3 L1
TRC-472 VR204 L212 L210
TRC-473 VR3 or Remove C80 T11 T13 T14
TRC-473 (late) VR4 or Cut D16 L8 L11 L6
TRC-474 VR4 or Cut D19 L6 L8
TRC-474 (late) VR4 or Cut D21 L12 L11
TRC-477 Cut R216 L10 L11 L12 L13
TRC-48 R220 L305 R316
TRC-480 VR13 or Cur D54 & D55 VR14 VR4 VR5
TRC-49 Cut D18 T24 T25
Trc-490 Cut R104 VR6 VR7
TRC-50B Cut D6 or D7 T15 T16
TRC-52 VR8 or Cut D11 L4
TRC-55 Cut D15 & D16 L10 L9
TRC-56 VR7 or Cut D507 & D508 L909
TRC-57 VR12 or Cut D33 & D31 VR21 VR25
TRC-61 R68 or Cut D12 & D11 R104
TRC-67 Cut D7 L3 L1
TRC-68 Cut D7 T15 T14
REGENCY RADIOS
Model Modulation AM Power SSB Power
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
CB-1 (INFO-1) RV4 or Cut D9 L11 L12 L13
CB-2 (INFO 2) RV201 or Cut D203 L304 L305 L306
CB-501 Cut CR107 L102 L101
CB-701 Cut CR107 L102 L101
CR-123 Cut D54 & D53 VR14 VR9
CR-123B VR17 L10 L12 VR16
CR-142 Cut D14 L4
CR-185 Cut R73 L8
CR-186 Cut D9 L4 L5 L8
CR-202 Remove C73 or Cut D11 L8 L5
CR-230 Cut D16 L19 L21
CR-240 VR213 or Cut D218 &
D219 L217
SPRINT-23 VR4 or Cut D13 A15 A16
ROADMASTER RADIOS
Model Modulation AM Power SSB Power
RE-4000 RV4 L10 L11 L12
RE-6000 RV4 or Cut D14 L7 L9 L10
ROBERTS RADIO
Model Modulation AM Power SSB Power
ROBERTS 40CH VR202
ROBYN RADIOS
Model Modulation AM Power SSB Power
007-140 VR6 or Cut D15 & D14 L13 L12 L11 L10
440 RV202 or Remove C210 L306 L307
AM-500D VR5 or Cut D14 L15 L12
DG-130A VR6 or Cut D15 & D14 L13 L12 L11 L10
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
DG-30 VR4 & VR5 or Cut D17 L9 L10
GT-410D VR12 or Cut D16 L20 L21 L15
GT-V11B VR8 or Cut D14 & D15 L18
K-123 VR4 or Cut D13 A16
LB-120 VR6 or Cut D15 & D14 L13 L12 L11 L10
LB-23A VR4 L9 L14
SB-505D Cut R104 VR6 VR7
SB-510D VR7 VR8 CT7
SB-520D VR7 VR8 CT7
SB-540D VR311 VR531 VR312
SX-101 VR5 L20 L23
Sx-401 VR7 or Cut D18 & D19 L16 L17 L18
SX-402 VR12 & VR13 or Cut
D17 & D18 L15 L20 L21
T-240D VR4 + Replace 6BQ5
Audio Tube With A 7189
Tube
L702(TOP) VC901
VC902
TR-123C Cut D11
TR-123D Cut D12 L17 L18 L19
WV-110 VR6 or Cut D15 & D14 L13 L12 L11 L10
WV-23 VR6 L13 L17
WV-23A VR4 L9 L14
ROYCE RADIOS
Model Modulation AM Power SSB Power
603 VR201 or Cut D202 L204 CT 201
604 VR201 or Cut D202 L303 VC1
607 VR201 or Cut D202 L303 CT301
608 VR201 or Cut D202 L303 VC1
609 VR201 or Cut D202 L303 VC1
611 VR201 or Cut D202 L303 VC1
613 VR201 or Cut D202 L303 VC1
619 VR201 or Cut D202 L303 VC1
639 VR7 L2 L3 CT6
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
I-580 VR201 or Cut D201 T302 L303 CT301
I-582 VR201 or Cut D201 T302 L303 CT301
I-601 (PLL) VR201 or Cut D202 L204 L203
I-602 Cut D6
I-602A VR5 or Cut D5 & D6 L11 L15
I-605A VR5 or Cut D5 & D6 L11 L15
I-606 VR7 or Cut D16 & D17 L21 L16 L15
I-610 Cut D202 CT301
I-611 Remove Q205 VC1
I-612 VR5 or Cut D7 VR8
I-613 Cut D202 CT301
I-617 VR401 or Cut D401 L310
I-620 VR10 or Cut D43 & D44 L13 L12 VR13
I-621 VR3 VR4
I-624 VR201 or Cut D202 L204 L203
I-625 VR1602 T402
I-630 VR10 or Cut D43 & D44 L13 L12 VR13
I-631 VR10 L2 L4 VR12
I-632 VR7 L6 L4 L1 VR5
I-635 VR10 or Cut D43 & D44 L13 L12 VR13
I-639 VR7 or Remove Q16 L12 T8 T9 VR11
I-640 VR10 or Cut D43 & D44 L13 L12 VR13
I-641 VR7 L6 L1 VR8
I-642 VR7 or Remove Q16 L3 L2 VR11
I-648 VR3 VR4
I-650 Cut D301 T402
I-651 VR201 (HI PWR) VR203
(LO PWR C317 C319
I-653 Cut D301 T402
I-655 Cut D301 T402
I-658 Cut D301 T402
I-660 Cut D301 T402
I-662 Cut D301 T402
I-673 Cut D301 T402
I-675 Cut D301 T402
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/qr.html[3/12/2010 12:40:18 AM]
I-678 Cut D301 T402
I-680 Cut D301 T402
I-682 Cut D301 T402
RYSTAL RADIOS
Model Modulation AM Power SSB Power
CB-523 VR3 or Cut CR9 VC1 L3
CBR-1700 RV5 or Cut D10 CV1 L5 T5
CBR-1800 VR481 or Cut D481 &
D482 L451 L463
Want More? Check Out The CD! Over 400MB of VERY Useful Information
HamTestOnline 2010 Promo
Tech license for $20 and 10 study hours.
Success guaranteed!
HP Desktop Computers
HP Official Store: Find Great Deals on the
Latest Models. Shop Now!
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
SAGA RADIO
Model Modulation AM Power SSB Power
2530 Cut D310 L15 VR101
SAM RADIO
Model Modulation AM Power SSB Power
SAM 2000 RV201 L304 L305 L306
SANKYO RADIO
Model Modulation AM Power SSB Power
SCS-555 R62 or Cut R63 or D14 T12 T13 T1
SANYO RADIOS
Model Modulation AM Power SSB Power
TA-2000 VR7 or Cut D504 & D505 L903 L905
TA-4000 VR7 or Cut D504 & D505 L903 L905
TA-6000 VR7 or Cut D504 & D505 L903 L905
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
SBE RADIOS
Model Modulation AM Power SSB Power
12CB VR7 L5 L6 L7 L8 VR1
14CB VR502 or Cut D502 L6 L5 VR504
16CB (Console II) VR7 L5 L6 L7 L8 VR1
21CB (Cortez) VR4 or Remove C87 or
Cut D14 L8 L10
22CB (Catalina II) R152 or Cut CR107 C162 L110 L111
23CB (Capri) VR1 L10
26CB (Formula D) VR9 or Cut D17 L8 L9
26CB-A (Formula 40) VR9 or Cut D17 L8 L9
27CB-A VR803 or Cut D801 L505 L502 VR302
29CB (Malibu) VR4 or Cut D18 L8 L10
30CB (Trinidad II) VR4 or Cut D18 T10 L6
32CB (Touchcom) VR9 or Cut D17 L8 L9
34CB (Brute) Cut D11 or Cut R82 L14 L18 L19
39CB (Sidebander V) VR803 or Cut D801 L505 L502 VR302
40CB VR803 or Cut D801 L505 L502 VR302
41CB (Aspen) VR203 or Cut D208 &
D209 L304 L306
42CB (Cortez) VR203 or Cut D208 &
D209 L304 L306
43CB (Touch-Com 40) R4 or Cut D17 L9 L8
44CB (Malibu 40) R226 or Cut CR33 &
CR32 L308 L309
45CB (Trinidad III) R226 or Cut CR33 &
CR32 L308 L309
47CB (Stowaway) VR4 or Cut D17 L14 L15 VR5
49CB (Tahoe) R121 or Cut D19 & D20 L34 L37
54CB (Key-Com 1000) RV1 L503 L505 L506
5CB (Cascade) R52 or Cut V2 L2 L5 L7
CONSOLE V Remove C804
CONSOLE VI VR601 VR603 L404 L407 VR404
LCB-8 VR6 or Cut D16 VR6 or Cut D16
Lcm-5 VR6 or Cut C49 or D9 L10 L11 L12 L15
LCM-8 RV2 or Cut D13 L7 L11 L12
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
LCM-8P R201 or Cut D201 L302 C310
LCMS VR7 VR11
TRINIDAD 23CH R152 L110 C154
SEARS RADIOS
Model Modulation AM Power SSB Power
242-38160700 VR201 L203
370-38050700 R218 or Cut CR204 T302 T303 C436
562-38200700 Cut D11 L5 L3 C301
663-38000900 Cut D8 L13 L16
663-38020800 VR6 or Cut D9 L11 L12 L15
663-38030050 Cut D7 L14 L15 L16
663-38070700 VR2 or Cut D14 L21 L11
663-3810500 VR5 VR10 VR6
7531 Cut D7 L7 L8
934-36710500 Cut D7 T15 T16
934-36740500 Cut D9 T17 T18
934-36741600 Cut D8
934-36770500 Cut D25 & D26 L14 R86 R281
934-36771500 Cut D25 & D27 R405 R281
934-36772600 Cut D25 & D27 R405 R281
934-38060700 Cut D7 or Cut D12 T14 T15
934-38061700 Cut D7 or Cut D12 T14 T15
934-38062700 Cut D7 or Cut D12 T14 T15
934-38080700 Cut D7 T14 T15
934-38081700 Cut D501 or D502 T704 T705
934-38110700 Cut D7 T14 T15
934-38120700 Cut D501 or D502 T704 T705
934-38260700 D303 RT301 RT402
934-38270700 Cut D405 or D406 RT602 RT701
934-38310700 D303 RT301 RT402
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
SHAKESPEARE RADIOS
Model Modulation AM Power SSB Power
GBS-1500 VR481 or Cut D481 &
D482 L451 L463
GBS-2000 VR5 or Cut D14 & D15 L13 L16 L18
Gbs-240 VR481 or Cut D481 &
D482 L451 L463
GBS-2500 VR481 or Cut D481 &
D482 L451 L463
SHARK RADIO
Model Modulation AM Power SSB Power
SHARK 23 VR201 L308 L307 L305
SHARP RADIOS
Model Modulation AM Power SSB Power
CB-2170 R110 or Cut D101 T304 L302 L301
CB-2260 R112 or Cut D101 L302 L303
CB-2460 R112 or Cut D101 L302 L303
CB-4370 R110 or Cut D101 T304 L302 L301
CB-4470 R110 or Cut D101 T304 L302 L301
CB-4670 R110 or Cut D101 T304 L302 L301
CB-500UB R74 or Cut D4 L15 L14
CB-5470 R541 C-31 R542
CB-700 R110 or Cut D101 T304 L302 L301
CB-750A R110 or Cut D101 T304 L302 L301
CB-800 R110 or Cut D101 T304 L302 L301
CB-800A R110 or Cut D101 T304 L302 L301
SILTRONIX RADIOS
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
Model Modulation AM Power SSB Power
APACHE (AM-1) VR7 or Cut D14 L9 L10 L11
CHEROKEE VR206 or Cut D214 &
D213 VC201 VR102 VR205
MOHAWK (AM-2) VR7 or Cut D14 L9 L10 L11
SSB-23 VR204 or Cut D207 &
D208 VC203 VR110 VR206
SSB-23A (Albatross) VR206 or Cut D214 &
D213 VC201 VR102 VR205
SOMMERKAMP RADIO
Model Modulation AM Power SSB Power
TS-2000DX VR14 or Cut one end of
R291 VR13 VR12
SOUND CREATION RADIO
Model Modulation AM Power SSB Power
SCB-500X Cut D115 L107 L108
SPARKOMATIC RADIOS
Model Modulation AM Power SSB Power
CB-1040 Cut D201 L202 L205
CB-1123 Cut D107 L5 L6
CB-1140 RV5 or Cut D15
CB-40 VR (next to D105)
RA-400 RV3 L4 L5
SBR-1CBM Cut D7
STAG RADIO
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
Model Modulation AM Power SSB Power
STAG-357 VR7 VR8 CT7
STANDARD COMUNICATIONS RADIOS
Model Modulation AM Power SSB Power
HORIZON 29-13 CH VR213 or Cut D218 &
D219 L217 L214
HORIZON 29A-40 CH VR213 or Cut D218 &
D219 L217 L214
STARFIRE RADIO
Model Modulation AM Power SSB Power
STARFIRE DX RV12 RV11 RV6 RV3
STEREOSONIC RADIOS
Model Modulation AM Power SSB Power
2300 VR481 or Cut D481 &
D482 L451 L463
2301 VR481 or Cut D481 &
D482 L451 L463
2302 VR481 or Cut D481 &
D482 L451 L463
2355 VR481 or Cut D481 &
D482 L451 L463
2360 VR481 or Cut D481 &
D482 L451 L463
SUPERSCOPE (AIR COMMAND) RADIOS
Model Modulation AM Power SSB Power
CB-140 R613 or Cut R612 or
D602 L407 L409 L410
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
CB-340 R613 or Cut R612 or
D602 L407 L409 L410
CB-640 R613 or Cut R612 or
D602 L407 L409 L410
CBB-1040 R508 or Cut Q517 &
Q516 L606 L607 L610
CBR-40 AM-FM-CB VR2 L3 L4
SUPERSTAR RADIOS
Model Modulation AM Power SSB Power
120 Remove C99 L15 L16 (HI PWR
1700 VR14 or Cut R249 VR13 VR12
1700 B RV12 L15 L16 (HI PWR)
1700 S RV12 L15 L16 (HI PWR)
2000 RV12 RV11 RV6 RV3
2200 RV12 RV11 RV6 RV3
360 Cut R104 VR6
3600 VR14 or Cut R249 VR13 VR12
360FM VR14 or Cut R301 VR13 VR7
3900 VR14 or Cut R249 VR13 VR12
95 Remove C99 L15 L16 (HI PWR
SURVEYOR RADIOS
Model Modulation AM Power SSB Power
1500 VT3 or Cut D6 L1 L19 (HI PWR) VR4
(LO PWR)
2100 VT3 or Cut D6 L15 L16
2300 Remove C54 or Cut D8 &
D9 L19 L20
2400 VR5 or Cut D12 L15 L16
2600 VR6 or Cut D12 L115 L116
2610 R207 or Cut D201 L202 L205
2620 RV401 L302 L306
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/s.html[3/12/2010 12:41:00 AM]
2630 VR104 or Cut D115 L404 L402
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Ham Radio 2010 Special
Entry-level ham license for $20 and 10 study
hours. Success guaranteed!
Cb Radio Manufacturers
Connect to suppliers & exporters from China
and Hong Kong.
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/t.html[3/12/2010 12:41:43 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
TEABERRY RADIOS
Model Modulation AM Power SSB Power
BIG T VR8
FIVE BY FIVE (early) RV5 or Cut X10 A17
FIVE BY FIVE (late Cut D10 L12 L9 L7
MIGHTY T VR5 or Cut D702 or
D703 VC1 L914
MODEL T VR6 or Cut D505 L905 L903
RACER T (23 CH) VR7 L906
RACER T (40 CH) VR6 or Cut D505 L905 L903
STALKER 3 Cut D13 L7 L10
STALKER I VR13 or Cut D52 VR17 VR16 VR12
STALKER II VR13 or Cut D28 & D29 VR17 VR6 VR12
STALKER III VR8 or Cut D504 L901 L903 L905
STALKER IV VR6 or Cut D9 L11 L12 L15
STALKER IX Cut R104 VR6 VR7
STALKER IX (export) VR5 VR11 VR7
STALKER V VR4 or Cut D11 L17 L16 L14
STALKER VIII Cut D9 L10 L11 L15
STALKER XII VR6 or Cut D16 L17 L16 L13
STALKER XV Cut R104 VR6 VR7
STALKER XX VR11 or Cut R104 VR6 VR7
STALKER XX (export) Cut R104 VR6 VR7
"T" RV4 (Change 6BQ5 to
7189) CV5
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/t.html[3/12/2010 12:41:43 AM]
T BEAR VR5 or Cut D14 L15 L12 L11
T CHARLIE (40 CH) VR7 or Cut D505 L905
T COMMAND VR5 or Cut D14 L15 L12 L11
T CONTROL VR5 or Cut D505 L914
T DISPATCH VR3 L13 L15
T SCOUT Remove C73 or Cut D11 L8 L5
TELE T VR7 or Cut D506 & D507 L909
TITAN T VR2 or Cut D14 L11 L12 L15
TEK RADIO
Model Modulation AM Power SSB Power
HR-3950 RV203 or Cut R270 RV300 RV304
TENNA RADIOS
Model Modulation AM Power SSB Power
10901 R54 or Cut D13 T10 T11 L3 L2 L1
10902 R71 or Cut D20 & D21 T15 T16 L4
11302 (AM-FM-CB) Cut D703 0r Cut D702 L609 L610
A0902 R77 or Cut D12 T11 L3
TEXAS RANGER RADIOS
Model Modulation AM Power SSB Power
TR-296DX VR7 VR10 VR11
TR-396F VR16 VR14
TR-696F VR16 VR14 VR13
TR-696F SSB Base VR16 VR14 VR13
TEXAS STAR RADIO
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/t.html[3/12/2010 12:41:43 AM]
Model Modulation AM Power SSB Power
2100 VR14 or Cut R249 VR13 VR12
THUNDER RADIO
Model Modulation AM Power SSB Power
THUNDER 2000 RV12 RV11 RV6 RV3
TRAM RADIOS
Model Modulation AM Power SSB Power
D-12 R61 or Cut CD12 L6 L3
D-201 R647 C711 C712 R719
D-300 Cut R104 VR6 VR7
D-42 R80 or Cut CD11 L5
D-64 R217 L704 L706 L709 R721
D-80 Cut R104 VR6 VR7
DIAMOND 40 Change R114 to a 10k L2 L5
DIAMOND 60 R98 L2 L5 R112
TITAN II Cut X9 A18 A19 A24 R112
TITAN IV R520 C718 C719
XL Cut CD12 L5 L3
XL-5 R616 or Remove C611 or
Cut CR603 L106 R130
TRI MAX RADIO
Model Modulation AM Power SSB Power
TRI MAX 220 RV3 or Cut D9 L11 L12 L13
TRISTAR RADIOS
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/t.html[3/12/2010 12:41:43 AM]
Model Modulation AM Power SSB Power
120 RV3 or Cut D9 L10 L11 L12 L13
240 (early) VR7 or Cut D22 L14 L16 L17
240 (late) RV2 or Cut D12 L7 L11-B LH10 L1
340 (early) RV7 or Cut D22 L14 L16 L17
340 (late) RV2 or Cut D12 L7 L11-B LH10 L1
727 Remove C99 L15 L16 (HI PWR)
747 RV14 RV13 RV12 RV4
777 RV12 RV11 RV6 RV3
797 RV12 RV11 RV6 RV3
848 RV12 RV11 RV6 RV3
TRS CHALLENGER RADIOS
Model Modulation AM Power SSB Power
1200 VR1 or Cut D201 or D202 VR6
1400 VR1 VR15 VR2 VR8
460 VR3 or Cut D8 & D9 L103 L106 l109
600 VR1 or Cut D2 VR210
730 VR1 or Cut D201 or
D202 VR6
850 VR1 VR15 VR2 VR8
TRUETONE RADIOS
Model Modulation AM Power SSB Power
CYJ4732A-77 RV102 or Cut D111 L110 L109
CYJ4832A-87 RV2 or Remove C96 L7 L11 L12
CYJ4834A-87 RV2 or Remove C96 L7 L11 L12
CYJ4837A-87 RV12 or Remove Q37 &
Q38 VR4 RV2
CYJ4862A-87 RV2 or Remove C96 L7 L11 L12
DC4530 Cut D6 L2 C4
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/t.html[3/12/2010 12:41:43 AM]
DC4672 RV2 or Cut D10 L7 L8 L9
MCC4370A-57 R58 or Cut D8 L3 C5
MCC4434A-57 Remove C39 or Cut D12 L11 L12 L14
MCC4434A-67 RV2 or Cut D10 L7 L8 L9
MCC4434B-67 RV102 or Cut d111 L110 L109
MCC4532A-47 R58 T14 C5
MCC4630A-67 Cut D7 T2 C4 L2
MCC4635A-67 Cut D24 L7 L8 L9
MCC4724A-77 VR4 or Cut D7 L5 L6
MCC4726A-67 Remove C45 or Cut D1 C29 L6 L9
MCC4760A-67 VR7 or Cut D507 & D507 L908 L909
MCC4770 RV2 or Cut D10 L7 L8 L9
MIC4350A-37 VR4 or Cut D6 L8 VR5
MIC4434A-67 RV2 or Cut D10 L7 L8 L9
MIC4622A-67 VR4 or Cut D6 L106
MIC4726A-67 Cut D1 C29 L6 T5
MIC4730A-67 RV2 or Cut D10 L7 L8 L9
MIC4731A-67 VR5 or Cut D703 or
D702 L914 VC1
MIC4733A-67 VR5 or Cut D703 or
D702 VC1
MIC4737A-67 RV7 or Cut D206 RV305 RV8 RV5
MIC4739A-67 RV2 or Cut D10 L7 L8 L9
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Ham Radio Online Courses
Don't just memorize the answers. Learn
about ham radio!
Motorola VL50 Radio
Small, easy-to-use, affordable Now only
$141.50 ea.
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/uvwxyz.html[3/12/2010 12:42:22 AM]
If You Find This Information Helpful Then Please Consider A Small Donation To Help Keep This Site Alive!
UNIC RADIOS
Model Modulation AM Power SSB Power
CB-40 RV4 or Cut R65 T9 T10 T11
CB-50 Cut D22 T9 T10
RV-40CB VR3 or Cut D9 L11 L12 L13
UNIDEN RADIOS (Also see President Radios)
Model Modulation AM Power SSB Power
DWIGHT D (1003002) VR6 or Cut D16 L13 L12 L11 T9 T10 T11
GRANT (1005002) Cut R131 VR10 VR11
HR-2510 VR114 VR103 VR104
MADISON Cut R131 VR10 VR11
PC-122 VR5 VR10 VR11
PC-22 VR3 or Cut R54 L12 L14
PC-244 VR5 or Remove TR29 VR10 VR6
PC-3 Cut D13 L7 L10
PC-33 Cut D13 L15 L12 L11
PC-33X Cut D14 L6 L5 L4
PC-43 Cut D12 L8 L9 L12
PC-55 Cut D13 L15 L12 L11
PC-55X Cut D14 L6 L5 L4
PC-66 VR5 or Cut D9 L13 L10 L9 L8
PC-66A VR5 or Cut D9 L13 L10 L9 L8
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/uvwxyz.html[3/12/2010 12:42:22 AM]
PC-77 Cut D15 L17 L16 L13
PC-9 (emergency radio) Cut D11
PRO-500D Cut D14 L6 L5
PRO-510e Cut D14 L6 L5 L4
PRO-510XL Cut D14 L6 L5
PRO-520e Cut D14 L6 L5 L4
PRO-520XL Cut D14 L6 L5
PRO-530e Cut D14 L11
PRO-540e Cut D22 L12 L10
PRO-640e VR5 or Remove TR29 VR10 VR6
PRO-710e Cut D11 L8 L7 L6
PRO-810e VR5 or Remove TR29 VR10 VR6
PTC-104 Cut D18 L11 L9 L8
WASHINGTON
(1002002) Cut R104 VR6 VR7
ZACHARY T (1002002) VR6 or Cut D16 L13 L12 L11
UNIMETRIC RADIOS
Model Modulation AM Power SSB Power
DOLPHONE VR4 or Cut D11 L7 L8
MAKO-1 VR6 or Cut D8 VC2 L14
MARLIN-1 VR6 or Cut D8 VC2 L13
PORPOIS-I VR6 L15 L16 VC2
SEA-HOURSE I RV203 or Cut D211 L214 VC1
STINGRAY-II RV7 RV304 RV8 RV5
USACO RADIO
Model Modulation AM Power SSB Power
U900CB VR3 or Remove C80 T11 T13 T14
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/uvwxyz.html[3/12/2010 12:42:22 AM]
UTAC RADIOS
Model Modulation AM Power SSB Power
MICRO-MINI 23 R69 or Cut D16 T14 L5
STUDIO 4000 R70 or Remove TR14 L21 L19
SUPER TINY 23 R69 or Cut D16 T14 L5
TR-18M R71 or Cut D10 L15 L17
TRX-2000 Cut D2 or D1 L5 T9 R41
TRX-30 R69 or Cut D10 or D16 L17
TRX-400 VR7 or Cut D10 L15 L17
TRX-500 VR7 or Cut D10 L15 L17
VECTOR RADIOS
Model Modulation AM Power SSB Power
770 FVR3 or Remove C35 or
Cut D14 L26 L25
790 FVR3 or Cut D10 L26 L25
VECTOR IV VR7 or Cut D14 L10 L11 L9
VECTOR IX VR9 or Cut D11 & D12 L12 L11
VECTOR VI VR7 or Cut D8 & D15 L12
VECTOR VII R71 or Cut D23 L22
VECTOR X VR260 or Cut D260 &
D261 L53 L55 L57
WELLS RADIO
Model Modulation AM Power SSB Power
W 705 R207 or Cut D9 L11 L12 L13
WESTPOINT RADIO
Model Modulation AM Power SSB Power
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/uvwxyz.html[3/12/2010 12:42:22 AM]
CB-9000 Cut D17 & D16 L14 L17
WHISTLER RADIO
Model Modulation AM Power SSB Power
900 RV301 or Cut R351 L410 L411 L412
XTAL RADIOS
Model Modulation AM Power SSB Power
XCB-11 Cut D13 & D14 L15 L13
XCB-12 Cut D13 & D14 L15 L13
XCB-23A Cut D9 or Remove C226 L25 TC7
XCB-28 Cut D24 or Remove C211 C228 L207
XCB-4 VR7 or Cut D7 L15 L13
XCB-5 Cut D11 or D14 L15 L13
XCB-6 RV5 or Cut D17 & D18 L16 L15
XCB-7 R75 or Cut D17 & D18 L16 L15
XCB-71 VR202 or Cut D202
XCB-88 TR4 or Cut D14 L22
XSSB-10 Cut D2 & D1 or Remove
C8 T8 T9 L5 R41
XSSB-4 Jumper Cathode side of
D2 to Ground
YOSAN RADIO
Model Modulation AM Power SSB Power
JC-2204 VR604 L204 L206
ZODIAC RADIOS
Model Modulation AM Power SSB Power
CB RADIO SECRET MASTER TUNE-UP MANUAL
http://www.hardtimez99.com/CB%20RADIO%20SECRET/uvwxyz.html[3/12/2010 12:42:22 AM]
M-5023 VR4 or Cut D14 & D13 L16 L14
M-5026 R89 & R35 or Cut D12 &
D11 L14 L15 L17
Want More? Check Out The CD! Over 400MB of VERY Useful Information
Become a ham for $20
Entry-level ham license for $20 and 10
hours study. Success guaranteed!
Not a Toy R/C Helicopter
Falcon 40-100% Built RC Helicopter Top
quality parts and electronics
All Rights Reserved C.B. RADIO SECRET © 2003,2004,2005,2006

Navigation menu
