ASUSPRO 7000 Test Report Rev.1.0 December 30th, 1997

Product ASUSPRO 7000 (P/I-P65UP8 mainboard )

ASUSTeK documents available from the web site are protected by the copyright laws.

You should not and may not reproduce, copy or redistribute web site document in

parts or all without written permission of ASUSTeK Computer Inc.

The information contained in this document is distributed AS IS. The use of this

information or the implementation of any of these techniques is a customer

responsibility and is subject to the customer's ability to evaluate and integrate

them into their operational environment. Customers attempting to adapt these

techniques to their own environments can do so at their own risk. ASUSTeK will not

accept any liabilities for consequences resulting from the use of this information.

This report is to be used solely for the purpose of installing and supporting the

product(s) discussed. This material must not be used for other purposes without the

written consent of ASUSTeK. The statistics resulted from the report is used mainly

for the demonstration purposes only. Different results may be shown when the

product(s) discussed are under different working environment.

The following terms are trademarks or registered trademarks of Microsoft

Corporation.

* Windows

* Windows 95

* Windows NT

More on third vendors' trademarks.....

ASUSPRO 7000

PART A. SPECIFICATION TEST

1. SYSTEM SPECIFIC TEST

2. SYSTEM BIOS TEST

3. SYSTEM UTILITY TEST

4. SYSTEM DIAGNOSTIC & CERTIFICATION TEST

5. FIELD (STRESS) TEST

PART B. OPERATING SYSTEM ENVIRONMENT TEST

1. DOS / WINDOWS OPERATING SYSTEM TEST

2. MICROSOFT WINDOWS 95 OPERATING SYSTEM TEST

3. MICROSOFT WINDOWS NT OPERATING SYSTEM TEST

4. IBM OS/2 OPERATING SYSTEM TEST

5. NOVELL NETWARE OPERATING SYSTEM TEST

6. SCO UNIX OPERATING SYSTEM TEST

7. SCO UNIXWARE OPERATING SYSTEM TEST

8. SUNSOFT SOLARIS OPERATING SYSTEM TEST

9. NEXT OPENSTEP OPERATING SYSTEM TEST

10. SLACKWARE LINUX OPERATING SYSTEM TEST

11. BANYAN VINES OPERATING SYSTEM TEST

PART C. RELIABILITY ENVIRONMENT TEST

1. POWER CONSUMPTION TEST

2. LINE VOLTAGE AND FREQUENCY TEST

3. DC MARGIN TEST

4. POWER LINE DISTURBANCE TEST

5. POWER SUPPLY INRUSH CURRENT TEST

6. TEMPERATURE / HUMIDITY

7. THERMAL MEASUREMENT

8. HUMIDITY CYCLE TEST

9. ALTITUDE TEST

10. VIBRATION TEST

11. ACOUSTIC NOISE TEST

12. SHOCK TEST

13. INCLINE IMPACT TEST

14. APPEARANCE CHECK

ASUSPRO 7000

PART A. SPECIFICATION TEST

1. System Specific Test

CPU Test

Vender Model Voltage Clock

Multiplier Bus Speed Remark/Special Setting

Intel Pentium Pro-180 3.3V 3.0X 60 MHz

Pentium Pro-200 3.3V 3.0X 66 MHz

Pentium II-233 2.8V 3.5X 66 MHz

Pentium II-266 2.8V 4.0X 66 MHz

Pentium II-300 2.8V 4.5X 66 MHz

Memory Test

Type SIZE Vendor Component Remark/Special Setting

72 Pin SIMM 8M Bytes Hitachi HM514400CLS7-7

Module Mitsubishi M5M44400BJ-7

NEC 424400-60

OKI M51440B-70SJ

Panasonic MN414400BSJ-7

Samsung KM416C1204AJ-6

Samsung KM416C1204AJ-7

TI TM348160DE-6

VIS VG2618165BJ 611-6

8M Bytes (EDO) Micron MT4C4007JDJ-6

Micron MT4C4007JDJ-7

16M Bytes Hitachi HM5117400AS6

Hitachi HM5117400AS7

NEC D424400GS-7

OKI K5117405A-6

Siemens HYB5117400BJ-60

TI Z417400G-6

32M Bytes Hitachi HM5117400AS6

NEC 4217400-60

Samsung KM44C4100J-7

TI TMS417400DJ-60

128M Bytes (EDO) Samsung KM44C16104AK-6

FDD Devices

Type Model O.S. Environment Status Remark/Special Setting

3Mode FDD Mitsumi D353T5 MS-DOS V6.20

Japanese (PCAT) Pass

1.44 MB FDD EPSON SMD-1300 Win95 V950B Pass

Panasonic

JU-257A606P OS/2 WARP Server

V4.0

OS/2 WARP V4.0

OpenStep R4.0

Pass

NEC FD1231H MS-DOS V6.22

Win95 V950B Pass

1.2 MB FDD NEC FD1157C MS-DOS V6.22

Win95 V950B Pass

720KB/1.44MB/

120MB FDD

Panasonic LKM-F434-1 Win95 V950B Pass

Mitsubishi

MF357G-111MA Win95 V950B Pass

Tape Colorado 250MB WFWG V3.11 Pass

Serial Port Devices

Type Model O.S. Environment Status Remark/Special Setting

Mouse Genius Serial Mouse Solaris V2.51

Solaris V2.6

SCO UNIX R5.0.4

Pass

ASUSPRO 7000

Serial Port Devices

Type Model O.S. Environment Status Remark/Special Setting

Mouse Genius Easy Scroll

Mouse Win95 V950B Pass

Logitech First Mouse

Super OS/2 WARP Connect

V3.0 Chinese

(Traditional)

OpenStep R4.0

Solaris V2.51

Pass

Logitech MouseMan OS/2 WARP Connect

V3.0

OS/2 WARP V4.0

OpenStep R4.0

Pass

Logitech TrackMan NT WKS V4.0 Pass

Microsoft Serial Mouse Win95 V950B

NT Server V4.0 Pass

PS2 Port Devices

Type Model O.S. Environment Status Remark/Special Setting

Mouse Digital PS/2 Mouse Solaris V2.51

Solaris V2.6 Pass

IBM PS/2 Mouse WFWG V3.11

Solaris V2.51 Pass

Genius PS/2 Mouse OS/2 WARP V4.0 Pass

Microsoft IntelliMouse WFWG V3.11

Win95 V950B

UnixWare V2.01

Pass

Parallel Port Devices

Type Model O.S. Environment Status Remark/Special Setting

ECP Direct Parallel

universal Cable (ECP) Win95 V950B Pass

EPP DataStor Commuter

Parallel Port Portable

SCSI Disk Case with

EPP function

MS-DOS V6.22 Pass

Up Select Commuter

Parallel Port Portable

IDE Disk Case with

EPP function

MS-DOS V6.22 Pass

Up Select Commuter

Parallel Port Portable

IDE CD-ROM Case

with EPP function

MS-DOS V6.22 Pass

M.O. Philips PDD230 Win95 V950B Pass

Printer HP LaserJet 5L Win95 V950B Pass

Tape Iomega IO3020 Win95 V950B Pass

Zip Iomega Z100P2 Win95 V950B Pass

USB Devices

Type Model O.S. Environment Status Remark/Special Setting

Camera Kodak DVC-300 Win95 V950B Pass

Keyboard Silitek SK-6000 MS-DOS V6.22

Win95 V950B Pass

Loop Back USB HPT Host

Production Tester MS-DOS V6.22 Pass

Mouse Anchor USB Mouse Win95 V950B Pass

Logitech USB Mouse Win95 V950B Pass

IR Devices

Type Model O.S. Environment Status Remark/Special Setting

IR Connector ASUSTeK Infrared

Device Win95 V950B Pass

ACTiSYS ACT-IR2000L Win95 V950B Pass

Vitex IRJet5000 Win95 V950B Pass

ASUSPRO 7000

IDE Devices

Type Model O.S. Environment Status Remark / Special Setting

M.O. Fujitsu M2541BE02 Win95 V950B Pass

Zip Iomega Z100ATAPI Win95 V950B Pass

Iomega Z100 iDE Win95 V950B Pass

SCSI Devices

Type Model O.S. Environment Status Remark / Special Setting

M.O. Fujitsu M2513S2B Win95 V950B Pass On-board Adaptec AIC-7880P

Mitsubishi MCA640 Win95 V950B Pass On-board Adaptec AIC-7880P

Removable HDD SyQuest SYJET1SI Win95 V950B Pass On-board Symbios 53C876

Zip Iomega Z100Si Win95 V950B Pass On-board Symbios 53C876

2. System BIOS Test

2.1 System CMOS Setup

System BIOS Test

Test Item Status Remark/Special Setting

CMOS Setup Utility Load BIOS Default Pass

Load Setup Default Pass

Supervisor Password Pass

User Password Pass

Save & Exit Setup Pass

Exit Without Saving Pass

Standard CMOS Setup Test Sign-On message and BIOS

Information Pass

POST error detection message test Pass

System Date and Time Pass Over 2000 years (BIOS/DOS/WIN95)

Diskette A: / B: Pass None / 1.2M / 1.44 MB / 3 Mode support

Hard Disk Drive Pass HDD Auto Detect / User Type / None

Video System Pass EGA / VGA, MONO

System Memory Pass

Extended Memory Pass

BIOS Features Setup Virus Warning Pass Enabled / Disabled

CPU Level 1 Cache Pass Enabled / Disabled

CPU Level 2 Cache Pass Enabled / Disabled

Quick Power On Self Test Pass Enabled / Disabled

System Security Option Pass System / Setup

PS/2 Mouse Function Control Pass Auto / Enabled

Boot Up NumLock status Pass On / Off

Chipset Features Setup Memory Hole At 15M-16M Pass Disabled / Enabled

Data Integrity (PARITY) Pass Disabled / Enabled

Onboard FDC Controller Pass Enabled / Disabled

Onboard FDC Swap A & B Pass No Swap / Swap AB

Onboard Serial Port 1 Pass Disabled, 3F8HIRQ4, 2F8HIRQ3, 3E8HIRQ4,

2E8HIRQ10

Onboard Serial Port 2 Pass Disabled, 3F8HIRQ4, 2F8HIRQ3, 3E8HIRQ4,

2E8HIRQ10

Onboard Parallel Port Pass Disabled, 378H/IRQ7, 278H/IRQ5, 3BCH/IRQ7

Parallel Port Mode Pass ECP+EPP, EPP, ECP, Normal

ECP DMA Select Pass 1, 3, Disabled

Onboard PCI IDE Enable Pass Both / Primary / Secondary / Disabled

PNP AND PCI SETUP Slot IRQ Pass Auto / NA / Manual

IRQ Used By ISA Pass No/ICU, Yes

DMA Used By ISA Pass No/ICU, Yes

Onboard AHA BIOS Pass Auto / Disabled

ASUSPRO 7000

2.2 Boot Sequence Test

SCSI / IDE HDD Sequence Test

O.S. Environment SCSI Device IDE Device Status Features Tested

Win95 V950B On-board Symbios

53C876

Iomega Z100Si

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from IDE device.

MS-DOS V6.22 On-board Adaptec

AIC-7880P

Quantum HN9100SW

On-board IDE

Iomega Z100ATAPI Pass Using IDE and SCSI device at the same time and boot

from IDE ZIP device.

Win95 V950B On-board Symbios

53C876

Iomega Z100Si

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from IDE device (with BusMaster driver).

MS-DOS V6.22 On-board Adaptec

AIC-7880P

Quantum HN9100SW

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from SCSI device.(Without ASPI8DOS.SYS)

MS-DOS V6.22 On-board Adaptec

AIC-7880P

Iomega Z100Si

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from SCSI ZIP device. (Without ASPI8DOS.SYS)

MS-DOS V6.22 On-board Adaptec

AIC-7880P

Quantum HN9100SW

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from SCSI device.(With ASPI8DOS.SYS)

MS-DOS V6.22 On-board Adaptec

AIC-7880P

Iomega Z100Si

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from SCSI ZIP device. (With ASPI8DOS.SYS)

MS-DOS V6.22 On-board Symbios

53C876

Micropolis 4345AV

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from SCSI device.(Without ASPI8XX.SYS)

MS-DOS V6.22 On-board Symbios

53C876

Micropolis 4345AV

On-board IDE

Fujitsu MPA3017AT Pass Using IDE and SCSI device at the same time and boot

from SCSI device.(With ASPI8XX.SYS)

Boot Sequence Test

Type O.S. Environment Peripheral Device Status Features Tested

A , C OS/2 WARP V4.0 Maxtor 82560D3 Pass

C , A OS/2 WARP V3.0 Micropolis 4540A Pass

A , CDROM , C NT WKS V4.0

Chinese (Traditional) Fujitsu MPA3017AT

Sony CDU511 Pass

CDROM , C , A NT WKS V4.0

Chinese (Traditional) Fujitsu MPA3017AT

Sony CDU511 Pass

D , A MS-DOS V6.22 Maxtor 82560D3

Micropolis 4525A Pass

E , A Win95 V950B Maxtor 82560D3

Micropolis 4525A

Fujitsu MPA3017AT

Pass

F , A NT Server V3.51 Maxtor 82560D3

Micropolis 4525A

Fujitsu MPA3017AT

Quantum TM2100AT

Pass

C Only Win95 V950B Fujitsu MPA3017AT Pass

LS/ZIP , C MS-DOS V6.22 Micropolis 4525A

Mitsubishi

MF357G-111MA

Pass

MS-DOS V6.22 Micropolis 4525A

Iomega Z100ATAPI Pass

2.3 Power Management Measurement

Power Management Test

Type Test Item Peripheral Device O.S. Environment Status Features Tested

Power

Management

Disable Fujitsu MPA3017AT Win95 V950B Pass

User Define Fujitsu MPA3017AT Win95 V950B Pass

Min Saving Fujitsu MPA3017AT Win95 V950B Pass

Max Saving Fujitsu MPA3017AT Win95 V950B Pass

PM Timers HDD Power Down Fujitsu MPA3017AT Win95 V950B Pass

Doze Mode Fujitsu MPA3017AT Win95 V950B Pass

ASUSPRO 7000

Power Management Test

Type Test Item Peripheral Device O.S. Environment Status Features Tested

PM Timers Standby Mode Fujitsu MPA3017AT Win95 V950B Pass

Suspend Mode Fujitsu MPA3017AT Win95 V950B Pass

PWR Button

< 4 Secs

Soft Off Micropolis 4525A MS-DOS V6.22 Pass

SMI Jumper Enabled Power

Management Fujitsu MPA3017AT Win95 V950B Pass

Disabled Power

Management Fujitsu MPA3017AT Win95 V950B Pass

3. System Utility Test

System Utility

Package Name Version Publisher O.S. Environment Status Remark/Special Setting

CBROM Utility V1.12 Award MS-DOS V6.22 Pass

PFLASH2 Utility V1.8 ASUSTeK MS-DOS V6.22 Pass

4. System Diagnostic & Certification Test

System Diagnostics

Package Name Version Publisher O.S. Environment Status Remark/Special Setting

Professional Qaplus V5.49 Diagsoft MS-DOS V6.22 Pass

Qaplus/FE V5.51 Diagsoft MS-DOS V6.22 Pass

Qaplus/win V7.1 Diagsoft WFWG V3.11

Win95 V950B Pass

System Certification

Package Name Version Publisher O.S. Environment Status Remark/Special Setting

Win95 HCT V7.2 Microsoft Win95 V950B Pass Execute all test item.

Windows NT HCT V7.2 Microsoft Windows NT 4.0 Pass Execute System Test.

OS/2 Warp CTK V4.0 IBM OS/2 Warp V4.0 Pass Run every test items.

Solaris HCT V2.06c Sunsoft Solaris V2.51 Pass Stress Tests: Keyboard, Mouse, Network, Disk, CD-

ROM, Floppy, Paging, Display.

5. Field (stress) Test

Test Type QAPlus/FE V5.51

Configuration Intel P6-200 + 64MB(32MB * 2) + 256KB(Internal) + On-board IDE + Fujitsu MPA3017AT

+ On-board S3 Trio64V2/DX + ASUS PCI-L101

Plug LoopBack

Test Procedure Running Qaplus Diagnostic Modules Test.

Test item including : System Board, Memory, Video, Floppy drive, Keyboard, Com

port, Parallel port.

Result Pass Duration 22 Hours

Test Type QAPlus/WIN 7.1

Configuration Intel Pentium II-266 + 16MB(4MB * 4) + 512KB(Internal) + On-board Adaptec AIC-7880P +

Micropolis 4345AV + On-board S3 Trio64V2/DX + IBM PS/2 Mouse

Plug LoopBack

Test Procedure Running System Board, Momery, Video , Hard drives , Floppy drive test item.

Result Pass Duration 24 Hours

ASUSPRO 7000

PART B. OPERATING SYSTEM ENVIRONMENT TEST

1. DOS / Windows Operating System Test

1.1 Software Compatibility Test

1.1.1 Operating System Compatibility

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

MS-DOS V6.22 Microsoft Pass

MS-DOS/V

Japanese (PCAT) V6.2 Microsoft Pass

Microsoft Windows

for Workgroup V3.11 Microsoft Pass

Microsoft Windows

Chinese (Traditional) V3.1 Microsoft Pass

Microsoft Windows

Chinese (Simplified) V3.2 Microsoft Pass

Microsoft Windows

Japanese (PCAT) V3.1 Microsoft Pass

PC-DOS V7.0 IBM Pass

PC-DOS

Japanese (PCAT) V6.1 IBM Pass

1.1.2 Application Software Compatibility

MS-DOS Utilities

Package Name Version Publisher O.S. Environment Status Features Tested

ET2000 for DOS V5.0 ETEN MS-DOS V6.22 Pass

ET2000 for Windows V1.0 ETEN Win V3.1

Chinese (Traditional) Pass

EMM386.EXE V6.22 Microsoft MS-DOS V6.22 Pass

HIMEM.SYS V6.22 Microsoft MS-DOS V6.22

WFWG V3.11 Pass

KEYB V6.22 Microsoft MS-DOS V6.22 Pass

MS-DOS Utilities V6.22 Microsoft MS-DOS V6.22 Pass

RAMDRIVE.SYS V3.07 Microsoft MS-DOS V6.22 Pass

Spreadsheet Applications

Package Name Version Publisher O.S. Environment Status Features Tested

Lotus-123 for Windows

Chinese (Traditional) R5 Lotus Win V3.1

Chinese (Traditional) Pass

Quattro Pro V6.0 Novell WFWG V3.11 Pass

Presentation Applications

Package Name Version Publisher O.S. Environment Status Features Tested

Lotus Freelance

Graphics for Windows

Chinese (Traditional)

V2.01 Lotus Win V3.1

Chinese (Traditional) Pass

Graphic Impact V2.0 Autodesk WFWG V3.11 Pass

Presentations V3.0 Novell WFWG V3.11 Pass

ASUSPRO 7000

Word Processing Applications

Package Name Version Publisher O.S. Environment Status Features Tested

Word Perfect for

Windows V6.1 Novell WFWG V3.11 Pass

Word Pro 96

Chinese (Traditional) V1.0 Lotus Win V3.1

Chinese (Traditional) Pass

Graphics / Image Processing / Multimedia Applications

Package Name Version Publisher O.S. Environment Status Features Tested

Adobe Photoshop V4.0 Adobe WFWG V3.11 Pass

Authorware V3.5 Macromedia WFWG V3.11 Pass

Image Pals V2.0 U-Lead WFWG V3.11 Pass

Mediamate

Chinese (Traditional) V2.1 Bestlink Win V3.1

Chinese (Traditional) Pass

Media Studio V2.0 U-Lead WFWG V3.11 Pass

Photostyler V2.0 Aldus WFWG V3.11 Pass

Database Applications

Package Name Version Publisher O.S. Environment Status Features Tested

Lotus Approach for

Windows

Chinese (Traditional)

V3.0 Lotus Win V3.1

Chinese (Traditional) Pass

MS Fox Pro for

Windows V2.5b Microsoft WFWG V3.11 Pass

Visual dBASE V5.5 Borland WFWG V3.11 Pass

Utilities & Tools

Package Name Version Publisher O.S. Environment Status Features Tested

386 MAX V8.0 Qualitas MS-DOS V6.22 Pass

Corel SCSI ! Pro V2.2 Corel WFWG V3.11 Pass

EZ-SCSI V4.00E Adaptec WFWG V3.11 Pass

Norton Commander V5.0 Symantec MS-DOS V6.22 Pass

Norton Utility V8.0 Symantec MS-DOS V6.22 Pass

PC-Tools for DOS R9.0 Central Point MS-DOS V6.22 Pass

PC-Tools for Windows V2.0 Central Point WFWG V3.11 Pass

Sytos Plus for

Windows V2.0 Sytos WFWG V3.11 Pass

Xtree Gold V4.0 Central Point WFWG V3.11 Pass

Integrate Applications / Project Management

Package Name Version Publisher O.S. Environment Status Features Tested

Lotus Organizer

Chinese (Traditional) V1.1 Lotus Win V3.1

Chinese (Traditional) Pass

SideKick for Windows V1.0 Borland WFWG V3.11 Pass

Programming Language / Compiler

Package Name Version Publisher O.S. Environment Status Features Tested

Borland C++ V4.0 Borland WFWG V3.11 Pass

MASM V6.11 Microsoft MS-DOS V6.22 Pass

Turbo C V2.0 Borland MS-DOS V6.22 Pass

Turbo Pascal V7.0 Borland MS-DOS V6.22 Pass

ASUSPRO 7000

CAD & DTP / Mathematics & Statistics

Package Name Version Publisher O.S. Environment Status Features Tested

AutoCAD R13 C4a Autodesk MS-DOS V6.22 Pass

AutoCAD LT for

Windows

Chinese (Traditional)

1.0 Autodesk Win V3.1

Chinese (Traditional) Pass

MathCAD V6.0

Plus MathSoft Win V3.11 Pass

Mathematica V2.2

Enhance Wolfram

Research Win V3.11 Pass

MicroStation V5.0 Bentley

System Inc. MS-DOS V6.22 Pass

Communication / Remote Control / E-Mail

Package Name Version Publisher O.S. Environment Status Features Tested

Crosstalk V2.2 DCA WFWG V3.11 Pass

Ftp PC/TCP OnNet V2.0 Ftp WFWG V3.11 Pass

Procomm PLUS V2.01 Datastorm WFWG V3.11 Pass

Super TCP/NFS V4.00R2 Frontier WFWG V3.11 Pass

Telix for Windows V1.01d Delta Comm WFWG V3.11 Pass

1.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Fujitsu MPA3026AT (4) MPhilips PCA243CD (24X) MWFWG V3.11 Pass

IBM DAQA-32160 (4) MMitsumi CRMC-FX140S2 (14X) MWFWG V3.11 Pass

IBM DHEA-34330 (DMA33) MFujitsu MPA3026AT (4)

Sony CDU511 (16X) M

SWFWG V3.11 Pass

IBM DHEA-38451 (DMA33)

Teac CD-524E (24X) M

SNEC DSE2100A (4) MWin V3.1

Chinese (Traditional) Pass

Maxtor 83201A6 (4) MQuantum SR2550AT (4)

Wearnes CDD1620 (16X) M

SWin V3.1

Chinese (Traditional) Pass

Maxtor 83500A8 (4)

Philips PCA163CD (16X) M

SMicropolis 4550A (4) MWFWG V3.11 Pass

Maxtor 84000A6 (4)

WD AC32500 (4) M

SSony CDU571 (16X) MWin V3.2

Chinese (Simplified) Pass

Micropolis 4550A (4)

IBM DCAA-33610 (4) M

SDCS C706A (16X) MWFWG V3.11 Pass

Quantum CY4335AT (4) MWD WDAC33100 (4)

Funai E2950UA (16X) M

SWin V3.1

Chinese (Traditional) Pass

Quantum ST3240AT (DMA33) MSeagate ST52520A (4)

Funai E2950UA (16X) M

SWFWG V3.11 Pass

Quantum ST3240AT (DMA33) MFujitsu MPA3017AT (4)

NEC CDR-1800A (24X) M

SWFWG V3.11 Pass

Quantum TM2110AT (4) MMaxtor 84320D5 (DMA33)

BTC BCD16XA (16X) M

SWin V3.1

Chinese (Traditional) Pass

Quantum TM3840AT (4) MPioneer DRA24X (24X) MWFWG V3.11 Pass

Seagate ST32132A (4) MSeagate ST52520A (4)

Sony CDU511 (16X) M

SWFWG V3.11 Pass

Seagate ST33240A (4) MQuantum TM3840AT (4)

Vuego CD616A (16X) M

SWin V3.1

Chinese (Traditional) Pass

Seagate ST52520A (4)

Mitsumi CRMC-FX140S2 (14X) M

SQuantum TM3840AT (4) MWFWG V3.11 Pass

WD AC22500 (4)

Creative CD1220E (12X) M

SQuantum ST2160AT (DMA33) MWFWG V3.11 Pass

WD WDAC33100 (4) MIBM DHEA-34330 (DMA33)

Goldstar CRD8160B (16X) M

SWFWG V3.11 Pass

ASUSPRO 7000

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Seagate ST32155N NEC CDR-512 MS-DOS V6.22

WFWG V3.11 Pass

Adaptec AHA-1542CP

Rev.B (BIOS:V1.02) Quantum HN9100S Pioneer DR-U12X MS-DOS V6.22

WFWG V3.11 Pass

SCSI

(PCI)

ASUS PCI-DA2100

Rev.3A (BIOS:V1.13B) Quantum HN2275SW * 3 Teac CD-516S MS-DOS V6.22

WFWG V3.11 Pass

ASUS PCI-SC200

Rev.1.2 (BIOS:V4.03) Quantum HN4550S NEC CDR-512 MS-DOS V6.22

WFWG V3.11 Pass

ASUS PCI-SC860

Rev.1.2 (BIOS:V4.03) Seagate ST52160N Pioneer DR-U12X MS-DOS V6.22

WFWG V3.11 Pass

ASUS PCI-SC875

Rev.1.0 (BIOS:V4.03) IBM DCAS-32160W Toshiba XM-5701B MS-DOS V6.22

WFWG V3.11 Pass

Adaptec AHA-2940UW

Rev.C (BIOS:V1.24) Quantum HN2275SW Sony CDU415 MS-DOS V6.22

WFWG V3.11 Pass

Adaptec AHA-2940AU

Rev.C (BIOS:V1.21) Quantum TM3200S Teac CD-516S MS-DOS V6.22

WFWG V3.11 Pass

Adaptec AHA-3940UW

Rev.A (BIOS:V1.24) Seagate ST34371W Panasonic CR-506-B MS-DOS V6.22

WFWG V3.11 Pass

Adaptec AHA-3940W

Rev.D (BIOS:V1.12) WD WDE4360W NEC CDR-1410A MS-DOS V6.22

WFWG V3.11 Pass

Adaptec AHA-3985

Rev.A (BIOS:V1.5) WD WDE2170

Quantum HN9100S NEC CDR-1610A PC-DOS V6.1

Japanese (PCAT) Pass

AdvanSys ABP-940U

Rev. (BIOS:V) Seagate ST52160N Pioneer DR-U24X PC-DOS V7.0 Pass

AdvanSys ABP-930

Rev.2 (BIOS:V2.8C) Seagate ST32550N Plextor PX-20TSi MS-DOS V6.22

WFWG V3.11 Pass

Buslogic BT930

Rev.A (BIOS:V1.40e) Seagate ST31055N Pioneer DR-U24X MS-DOS V6.22

WFWG V3.11 Pass

Buslogic BT932

Rev.A (BIOS:V1.40e) Seagate ST32550N Sony CDU415 MS-DOS V6.22

WFWG V3.11 Pass

Buslogic BT948C

Rev.Ab (BIOS:4.95L) Seagate ST15150N NEC CDR-502 MS-DOS V6.22

WFWG V3.11 Pass

Buslogic BT950

Rev.A (BIOS:V4.94G) WD WDE2170W Panasonic CR-506-B MS-DOS V6.22

WFWG V3.11 Pass

DPT PM2144UW

(BIOS:V003.A0) Seagate ST32155W Toshiba XM-5701B MS-DOS V6.22

WFWG V3.11 Pass

DPT PM3334UW

(BIOS:V003.A0) WD WDE2170W

Fujitsu M2952QAU

Seagate ST32155W

NEC CDR-1410A MS-DOS V6.22

WFWG V3.11 Pass

On-board Adaptec AIC-

7880P

(BIOS:1.24)

IBM DCAS-32160W Toshiba XM-5701B MS-DOS V6.22

WFWG V3.11 Pass

On-board Symbios

53C876

(BIOS:4.03.00)

Micropolis 4345WAV Toshiba XM-5701B MS-DOS V6.22

WFWG V3.11 Pass

ProMISE SCSIULTRA

Rev. (BIOS:V.) Quantum HN9100SW Plextor PX-20TSi Win V3.1

Japanese(PCAT) Pass

WDC WD7197

Rev.B (BIOS:V172) Fujitsu M2952QAU Pioneer DR-U24X MS-DOS V6.22

WFWG V3.11 Pass

Graphic Adapters

Card Type Card Model Peripheral Device O.S. Environment Status Remark

VGA

(PCI)

On-board S3 Trio64V2/DX On-board IDE

IBM DAQA-32160 WFWG V3.11 Pass

Multimedia Kit

Card Type Card Model Peripheral Device O.S. Environment Status Remark

Sound

Card

ASUS I-A16C

Rev.1.2 On-board IDE

Quantum TM2110AT Win V3.1

Chinese (Traditional) Pass

Arvin Pro-Multimedia

Rev.2.1 On-board IDE

Quantum ST2160AT WFWG V3.11 Pass

Creative Sound Blaster

32 PnP On-board IDE

Seagate ST31277A Win V3.2

Chinese (Simplified) Pass

Creative Sound Blaster

AWE32 PnP On-board IDE

Micropolis 4540A Win V3.1

Chinese (Traditional) Pass

CinaAction 16 PnP On-board IDE

Maxtor 83201A6 Win V3.1

Chinese (Traditional) Pass

ASUSPRO 7000

Multimedia Kit

Card Type Card Model Peripheral Device O.S. Environment Status Remark

Sound

Card

FSO-PNP3D

Rev.1.1 On-board IDE

WD WDAC33100 WFWG V3.11 Pass

T.C. Star ATC931

Rev.A On-board IDE

IBM DCAA-34330 WFWG V3.11 Pass

Ultrasound Gravis PnP

Rev.1.0 On-board IDE

IBM DAQA-32160 WFWG V3.11 Pass

MPEG

Card

Acer DCS P531

MPEG Player On-board IDE

WD WDAC33100 WFWG V3.11 Pass

PRO-VIEWER On-board IDE

Quantum TM2110AT Win V3.1

Chinese (Traditional) Pass

W-2020 PCI MPEG On-board IDE

Quantum ST3240AT WFWG V3.11 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509B

(Plug and Play) 5 360 WFWG V3.11 Pass

Accton EN166X

Rev.02 (Plug and Play) 3 300 WFWG V3.11 Pass

Cnet 288PnP

Rev.A (Plug and Play) 3 300 WFWG V3.11 Pass

Cnet 888E

Rev.1.4 Auto Auto WFWG V3.11 Pass

Intel PCLA8205 5 340 WFWG V3.11 Pass

Novell NE2000Plus-3 5 300 WFWG V3.11 Pass

SMC 8013WC

Rev.A 10 300 WFWG V3.11 Pass

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev.B1 Auto Auto MS-DOS V6.22

WFWG V3.11 Pass

3COM 3C590C

Rev.14 Auto Auto MS-DOS V6.22

WFWG V3.11 Pass

3COM 3C900

Rev. Auto Auto WFWG V3.11 Pass

Accton EN1203

Rev.01C Auto Auto MS-DOS V6.22

WFWG V3.11 Pass

Accton EN1208

Rev.01A Auto Auto WFWG V3.11 Pass

Compaq NETFLEX-3/P

Rev.A Auto Auto WFWG V3.11 Pass

Cogent EM960 Auto Auto WFWG V3.11 Pass

Digital DE450AC

Rev.A01 Auto Auto WFWG V3.11 Pass

D-Link DE-530CT+

Rev.A1 Auto Auto WFWG V3.11 Pass

Intel PILA840X Auto Auto WFWG V3.11 Pass

Proteon P1670-EA Auto Auto WFWG V3.11 Pass

SMC 8432BT

Rev.A Auto Auto WFWG V3.11 Pass

Thomas-Conrad TC5048

Rev.A Auto Auto WFWG V3.11 Pass

100BaseTx ASUS PCI-DEC100TX+

Rev.01 Auto Auto WFWG V3.11 Pass

3Com 3C595TX

Rev.B Auto Auto WFWG V3.11 Pass

3Com 3C905TX

Rev.B Auto Auto WFWG V3.11 Pass

Accton EN1207

Rev.01 Auto Auto WFWG V3.11 Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

100BaseTx CNET CN100TX Auto Auto WFWG V3.11 Pass

Cogent EM110TX Auto Auto WFWG V3.11 Pass

Digital DE500XA Auto Auto WFWG V3.11 Pass

D-Link DFE-500TX

Rev.B4 Auto Auto WFWG V3.11 Pass

Intel PILA8465 Auto Auto WFWG V3.11 Pass

Intel PILA8465B Auto Auto WFWG V3.11 Pass

SMC 9332DST Auto Auto WFWG V3.11 Pass

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Token-

Ring

3COM 3C619C

Rev.A 5A20 WFWG V3.11 Pass

(ISA) D-Link DT-220P

Rev.B1 Auto Auto WFWG V3.11 Pass

IBM Auto 16/4 Adapter

(Plug and Play) Auto Auto WFWG V3.11 Pass

Intel PCLA815X

(Plug and Play) 5 340 WFWG V3.11 Pass

Olicom OC-3118

Rev.3 (Plug and Play) Auto Auto WFWG V3.11 Pass

Proteon P1392Plus

Rev.J (Plus and Play) 5A20 5WFWG V3.11 Pass

Thomas-Conrad

TC4145-C

Rev.A (Plug and Play)

Auto Auto WFWG V3.11 Pass

Token-

Ring

(PCI)

Proteon P1690 Auto Auto WFWG V3.11 Pass

Olicom OC-3870

Rev.4 Auto Auto WFWG V3.11 Pass

Thomas-Conrad

TC4048 Auto Auto WFWG V3.11 Pass

Modem Devices

Type Model O.S. Environment Application Status Remark / Special

Setting

Modems

(Internal)

Cardinal 28800 internal WFWG V3.11 Crosstalk V2.2 Pass 28,800 BPS

COM3

Modems

(External)

ADI CommuPack V336 Win V3.11

Chinese (Traditional) IE V3.0

Netscape V2.02 Pass 33,600 BPS

COM1

Hayes Optima 288 WFWG V3.11 Telix for Windows V1.01d Pass 28,800 BPS

COM2

USRoboties

Sportster Vi336 WFWG V3.11 Procomm PLUS V2.01 Pass 33,600 BPS

COM1

ZYXEL U336E Win V3.11

Chinese (Traditional) IE V3.0

Netscape V2.02 Pass 33,600 BPS

COM2

ISDN Devices

Type Model O.S. Environment Application Status Remark / Special

Setting

Terminal

Adapter

(External)

ZYXEL Omni TA128 Win V3.11

Chinese (Traditional) IE V3.0

Netscape V2.02 Pass 64,000 BPS

COM2

ASUSPRO 7000

Tape Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI Conner TSD4000H WFWG V3.11 Pass

Exabyte EXB2501 WFWG V3.11 Pass

Parallel iomega ditto 3200 WFWG V3.11 Pass

Colorado Trakker 700 WFWG V3.11 Pass

Floppy IOMEGA Tape 250 MS-DOS V6.22 Pass

Conner TSM420R WFWG V3.11 Pass

Colorado T1000 WFWG V3.11 Pass

ZIP Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI iomega jaz 1GB MS-DOS V6.22

WFWG V3.11 Pass

iomega Z100SCSI MS-DOS V6.22 Pass

IDE iomega ZIP 100 iDE MS-DOS V6.22

WFWG V3.11 Pass

Parallel iomega ZIP Tools 100 MS-DOS V6.22

WFWG V3.11 Pass

1.3 Field (stress) Test

Test Type Windows for Workgroup Integrate network access test

Configuration Intel P6-200 + 32MB(EDO 16MB * 2) + 256KB(Internal) + On-board IDE + Seagate ST52520A

Quantum TM3840AT + Mitsumi CRMC-FX140S CD-ROM + On-board S3 Trio64V2/DX +

3COM 3C905 + Microsoft IntelliMouse

2 * Peers(Windows for Workgroup V3.11)

Test Procedure Run Multitasking in this PC and access other workstation resource from network environment.

Result Pass Duration 15 Hours

Test Type Windows for Workgroup Integrate network access test

Configuration Intel P6-200 + 32MB(EDO 16MB * 2) + 256KB(Internal) + On-board Adaptec AIC-7880P +

IBM

DCAS-32160W + Toshiba XM-5701B CD-ROM + On-board S3 Trio64V2/DX + Intel

PILA8465B

+ Microsoft IntelliMouse

1 * Peer(Windows for Workgroup V3.11)

1 * Peer(Windows NT Server V4.0)

Test Procedure Run Multitasking in this PC and access other workstation resource from network environment.

Result Pass Duration 40 Hours

ASUSPRO 7000

2. Microsoft Windows 95 Operating System Test

2.1 Software Compatibility Test

2.1.1 Operating System Compatibility

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

Windows 95 V950B Microsoft Pass

Windows 95

Chinese (Simplified) V950B Microsoft Pass

Windows 95

Chinese (Traditional) V950B Microsoft Pass

Windows 95

German V950B Microsoft Pass

Windows 95

Japanese (PCAT) V950B Microsoft Pass

2.1.2 Application Software Compatibility

Graphics / Image Processing / Multimedia Applications

Package Name Version Publisher O.S. Environment Status Features Tested

ABC Graphics Suite V6.0 Micrografx Win95 V950B Pass

Astound V2.0 Gold Disk Win95 V950B Pass

Corel Draw for

windows V7.0 Corel Win95 V950B Pass

Video Director V2.5 Gold Disk Win95 V950B Pass

Visio for windows V4.0 VISIO Win95 V950B Pass

Photoshop V4.0 Adobe Win95 V950B Pass

MetaTools Kais

Power GOO V1.0 MetaTools Win95 V950B Pass

Database Applications

Package Name Version Publisher O.S. Environment Status Features Tested

Delphi Desktop V3.0 Borland Win95 V950B Pass

Visual Fox Pro V3.0 Microsoft Win95 V950B

Chinese (Traditional) Pass

Utilities & Tools

Package Name Version Publisher O.S. Environment Status Features Tested

ET2000 for Windows

95 V5.1 ETEN Win95 V950B

Chinese (Traditional) Pass

Norton Antivirus V1.0 Symantec Win95 V950B Pass

Norton Navigator V1.0 Symantec Win95 V950B Pass

Norton Utility for

Windows 95 V1.0 Symantec Win95 V950B

Chinese (Traditional) Pass

QEMM 97 V9.0 Quarterdeck Win95 V950B Pass

Integrate Applications / Project Management

Package Name Version Publisher O.S. Environment Status Features Tested

Lotus Smart Suite 96 V1.0 Lotus Win95 V950B Pass

Office 97 Profess-

ional

Edition

Microsoft Win95 V950B

Chinese (Traditional) Pass

ASUSPRO 7000

Integrate Applications / Project Management

Package Name Version Publisher O.S. Environment Status Features Tested

Office 95

Chinese (Traditional) Profess-

ional

Edition

Microsoft Win95 V950B

Chinese (Traditional) Pass

Project V4.1 Microsoft Win95 V950B Pass

Windows95 PLUS! V1.0 Microsoft Win95 V950B Pass

Windows95 PLUS!

Chinese (Traditional) V1.0 Microsoft Win95 V950B

Chinese (Traditional) Pass

WinHelp Office V1.0 Blue Sky Win95 V950B

Chinese (Traditional) Pass

Works V4.0 Microsoft Win95 V950B Pass

Works

Chinese (Traditional) V4.0 Microsoft Win95 V950B

Chinese (Traditional) Pass

Programming Language / Compiler

Package Name Version Publisher O.S. Environment Status Features Tested

Visual Basic V4.0 Microsoft Win95 V950B Pass

Visual C++ V4.0 Microsoft Win95 V950B Pass

Watcom C++ V10.5 Watcom Win95 V950B Pass

CAD & DTP / Mathematics & Statistics

Package Name Version Publisher O.S. Environment Status Features Tested

3D Studio MAX V1.2 Autodesk Win95 V950B Pass

AutoCAD for

Windows95

Chinese (Traditional)

R13C4a Autodesk Win95 V950B

Chinese (Traditional) Pass

Extreme 3D V1.0 Micromedia Win95 V950B Pass

Communication / Remote Control / E-Mail

Package Name Version Publisher O.S. Environment Status Features Tested

WinFax Pro for

Windows 95 V7.0 Delrina Win95 V950B Pass

Windows 95 Fax V950 Microsoft Win95 V950B Pass

2.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Fujitsu M1638TAU (4)

Pioneer DR-A12X (12X) M

SQuantum ST2160AT (DMA33) MWin95 V950B

Chinese (Traditional) Pass

Fujitsu MPA3017AT (4)

Sony CDU611 (24X) M

SMaxtor 84320D5 (DMA33)

Maxtor 83062A7 (4) M

SWin95 V950B Pass

IBM DJAA-31700 (4)

NEC CDR-1800A (24X) M

SSeagate ST32132A (4)

Quantum TM3840AT (4) M

SWin95 V950B Pass

IBM DAQA-32160 (4)

IBM DHEA-38451 (DMA33) M

SWearnes CDD1620 (16X)

IBM DCAA-34330 (4) M

SWin95 V950B Pass

IBM DAQA-33240 (4)

Philips PCA163CD (16X) M

SSeagate ST32531A (4)

Fujitsu MPA3026AT (4) M

SWin95 V950B Pass

IBM DCAA-33610 (4) MPioneer DR-A24X (24X) MWin95 V950B

Chinese (Traditional) Pass

IBM DHEA-34330 (DMA33)

NEC CDR-1600A (16X) M

SNone Win95 V950B Pass

ASUSPRO 7000

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Maxtor 72004AP (4)

Quantum TM2110AT (4) M

SQuantum TM3200AT (4)

Philips PCA243CD (24X) M

SWin95 V950B Pass

Maxtor 83500A8 (4) MPanasonic CR-584-B (12X) MWin95 V950B

German Pass

Maxtor 85120A8 (4)

NEC CDR-CC24 (24X) M

SSamsung WNR-31601A (4)

IBM DJAA-31700 (4) M

SWin95 V950B Pass

Maxtor 85250D6 (DMA33)

Hitachi CDR8130 (18X) M

SIBM DHEA-34330 (DMA33)

Quantum TM3840AT (4) M

SWin95 V950B Pass

Micropolis 4525A (4) MTeac CD-516E (16X) MWin95 V950B

Chinese (Traditional) Pass

Micropolis 4525A (4)

Philips PCA163CD (16X) M

SNone Win95 V950B

Chinese (Simplified) Pass

Micropolis 4540A (4) M

SSeagate ST32132A (4)

Acer CD616A (18X) M

SWin95 V950B Pass

NEC DSE2100A (4)

Aztech CDA1068-01I (10X) M

SNone Win95 V950B Pass

Quantum SR1700AT (4)

Goldstar CRD8160B (16X) M

SSeagate ST52520A (4)

Maxtor 82560A4 (4) M

SWin95 V950B

Chinese (Traditional) Pass

Quantum SR2550AT (4) MCyber 160D (16X) MWin95 V950B

Chinese (Traditional) Pass

Quantum TM3840AT (4) MDCS C706A (16X) MWin95 V950B Pass

Quantum BF2550AT (4)

Vuego CD616A (18X) M

SMaxtor 82560A4 (4) MWin95 V950B Pass

Quantum CY4335AT (4)

Quantum ST6480AT (DMA33) M

SBTC BCD24X (24X) MWin95 V950B

German Pass

Quantum ST2160AT (DMA33)

IBM DJAA-31700 (4) M

SPhilips PCA203CD (20X)

Quantum TM3840AT (4) M

SWin95 V950B

Japanese (PCAT) Pass

Quantum ST3240AT (DMA33)

Seagate ST32177A (4) M

SNEC CDR-CC24 (24X) MWin95 V950B

Japanese (PCAT) Pass

Quantum ST4320AT (DMA33)

Seagate ST31277A (4) M

SQuantum ST2160AT (DMA33)

DCS C637 (12X) M

SWin95 V950B

Chinese (Traditional) Pass

Samsung WNR-31601A (4) MFunai E2950UA (16X) MWin95 V950B

Seagate ST31277A (4) M

SSony CDU571 (16X)

Seagate ST32132A (4) M

SWin95 V950B

Japanese (PCAT) Pass

Seagate ST31720A (4)

Maxtor 83201A6 (4) MSeagate ST51270A (4)

NEC CDR-CC24 (24X) MWin95 V950B

Chinese (Traditional) Pass

Seagate ST32132A (4) MVuego CD624A (24x) MWin95 V950B

Chinese (Simplified) Pass

Seagate ST32531A (4) M

SPhilips PCA203CD (20X)

Micropolis 4550A (4) M

SWin95 V950B Pass

Seagate ST33240A (4) MMitsumi CRMC-FX140S2 (14X) MWin95 V950B Pass

WD WDAC31600 (4)

Fujitsu M1636TAU (4) M

STeac CD-524E (24X)

Maxtor 84000A6 (4) M

SWin95 V950B Pass

WD AC32500 (4)

Creative CD1220E (12X) M

SNone Win95 V950B Pass

WD WDAC33100 (4)

Mitsumi CRMC-FX120T (12X) M

SSeagate ST52520A (4) MWin95 V950B

German Pass

WD AC34000 (4) MPanasonic CR-585-B (24X) MWin95 V950B Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1530P

Rev.C (BIOS:V1.03) Micropolis 4345 Toshiba XM-5701B Win95 V950B Pass

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Quantum HN9100S On-board IDE

Vuedo PCA163CD Win95 V950B Pass

Adaptec AHA-1542CP

Rev.B (BIOS:V1.02) Quantum TM3200S Sony CDU415 Win95 V950B Pass

SCSI

(PCI)

On-board

Adaptec AIC-7880P

Rev.1.0 (BIOS:V1.24)

Quantum VK4550SW Plextor PX-20TSi Win95 V950B Pass

ASUS PCI-DA2100

Rev.3A (BIOS:V1.13B) Quantum VK4550SW

Quantum HN2275SW On-board IDE

Pioneer DR-A24X Win95 V950B Pass

ASUS PCI-SC200

Rev.1.2 (BIOS:V4.03) Seagate ST19171N Pioneer DR-U12X Win95 V950B Pass

ASUSPRO 7000

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(PCI)

ASUS PCI-SC860

Rev.1.2 (BIOS:V4.03) Micropolis 4345AV Teac CD-516S Win95 V950B Pass

Adaptec AHA-2940AU

Rev.C (BIOS:V1.21) Seagate ST19171N Pioneer DR-U12X Win95 V950B Pass

Adaptec AHA-2940UW

Rev.C (BIOS:V1.24) Quantum HN4550SW NEC CDR-512 Win95 V950B Pass

Adaptec AHA-3940

Rev.B (BIOS:V1.12) Micropolis 4345AV NEC CDR-1410A Win95 V950B Pass

AdvanSys ABP-940U

Rev.A (BIOS:V2.6L) Quantum TM3200S Plextor PX-20TSi Win95 V950B Pass

Buslogic BT948C

Rev.Ab (BIOS:4.95L) Quantum TM3200S NEC CDR-512 Win95 V950B Pass

Buslogic BT950

Rev.A (BIOS:V4.94G) Quantum HN2275SW NEC CDR-1610A Win95 V950B

Chinese (Traditional) Pass

Initio INI-9100U

Rev.D (BIOS:V1.02) Maxtor 9217SSN NEC CDR-1410A Win95 V950B Pass

Initio INI-9100UW

Rev.D (BIOS:V1.02) Seagate ST32171W NEC CDR-1610A Win95 V950B Pass

Promise SCSIMAX

Rev.B (BIOS:V3.07) Seagate ST19101SW Pioneer DR-U12X Win95 V950B Pass

Promise SCSIULTRA

Rev.B (BIOS:V4.03) Quantum HN4550SW On-board IDE

Sony CDU411 Win95 V950B

Chinese (Traditional) Pass

Graphic Adapters

Card Type Card Model Peripheral Device O.S. Environment Status Remark

VGA

(PCI)

On-board S3 Trio64V2/DX On-board AIC-7880P

Seagate ST34501W Win95 V950B Pass S3 Trio64V2/DX

Multimedia Kit

Card Type Card Model Peripheral Device O.S. Environment Status

Sound

Card

ASUS I-A16C

Rev.1.2 On-board Symbios 53C876

WD WDE4360W Win95 V950B Pass

Arvin AudioMagic - PnP

Rev.2.1 On-board Symbios 53C876

WD WDE4360W Win95 V950B Pass

Creative Sound Blaster

AWE32 PnP On-board IDE

Fujitsu M1636TAU Win95 V950B

Chinese (Traditional) Pass

Creative Sound Blaster

AWE64 PnP On-board IDE

Fujitsu M1636TAU Win95 V950B

Chinese (Traditional) Pass

FUNAI FSO-PNP3D

Sound Master On-board Symbios 53C876

WD WDE4360W Win95 V950B Pass

Turtle Beach Tropez

Plus On-board IDE

Fujitsu M1636TAU Win95 V950B Pass

Turtle Beach MultiSound

Pinnacle On-board AIC-7880P

Seagate ST34501W Win95 V950B Pass

T.C. Star ATC931 Sound

Adapter On-board AIC-7880P

Seagate ST34501W Win95 V950B Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509B-TP

(Plug and Play) 5 360 Win95 V950B

Chinese (Traditional) Pass

Accton EN166X

Rev.02 (Plug and Play) Auto Auto Win95 V950B

Chinese (Traditional) Pass

Cnet 288PnP

Rev.A (Plug and Play) Auto Auto Win95 V950B

Chinese (Traditional) Pass

Cnet 888E

Rev.1.4 5 300 Win95 V950B

Chinese (Traditional) Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

Digital DE205 Auto Auto Win95 V950B Pass

Intel PCLA8205 Auto Auto Win95 V950B

Chinese (Traditional) Pass

Novell NE2000Plus-3 5 300 Win95 V950B Pass

SMC 8013WC

Rev.A 10 300 Win95 V950B

Japanese (PCAT) Pass

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev.B1 Auto Auto Win95 V950B Pass

3COM 3C590C

Rev.14 Auto Auto Win95 V950B Pass

Accton EN1203

Rev.01C Auto Auto Win95 V950B

Chinese (Traditional) Pass

Accton EN1208

Rev.01A Auto Auto Win95 V950B

Chinese (Simplified) Pass

Cogent EM960 Auto Auto Win95 V950B

Chinese (Simplified) Pass

Digital DE450AC

Rev.A01 Auto Auto Win95 V950B Pass

Proteon P1670-EA Auto Auto Win95 V950B Pass

SMC 8432BT

Rev.A Auto Auto Win95 V950B Pass

Thomas-Conrad TC5048

Rev.A Auto Auto Win95 V950B Pass

100BaseTx ASUS PCI-DEC100TX+

Rev.01 Auto Auto Win95 V950B Pass

3Com 3C595TX

Rev.B Auto Auto Win95 V950B

Japanese (PCAT) Pass

3Com 3C905TX

Rev.B Auto Auto Win95 V950B

Japanese (PCAT) Pass

Accton EN1207

Rev.01 Auto Auto Win95 V950B

Chinese (Simplified) Pass

Cnet CN100TX Auto Auto Win95 V950B

Chinese (Traditional) Pass

Cogent EM110TX Auto Auto Win95 V950B

Chinese (Traditional) Pass

Digital DE500XA Auto Auto Win95 V950B

Chinese (Simplified) Pass

Intel PILA8465 Auto Auto Win95 V950B

Chinese (Simplified) Pass

SMC 9332DST Auto Auto Win95 V950B Pass

Intel PILA8465B Auto Auto Win95 V950B

German Pass

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Token-

Ring

3COM 3C619C

Rev.A 2A20 Win95 V950B Pass

(ISA) D-Link DT-220P

Rev.B1 Auto Auto Win95 V950B Pass

IBM Auto 16/4 Adapter

(Plug and Play) Auto Auto Win95 V950B Pass

Intel PCLA815X

(Plug and Play) Auto Auto Win95 V950B Pass

Olicom OC-3118

Rev.3 (Plug and Play) Auto Auto Win95 V950B Pass

ASUSPRO 7000

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Token-

Ring

Proteon P1392Plus

Rev.J (Plus and Play) 5A20 5Win95 V950B Pass

Token-

Ring

Olicom OC-3870

Rev.4 Auto Auto Win95 V950B Pass

(PCI) Thomas-Conrad TC4048

Rev.A Auto Auto Win95 V950B Pass

Proteon P1690

Rev.B Auto Auto Win95 V950B Pass

Modem Devices

Type Model O.S. Environment Application Status Remark / Special

Setting

Modems

(Internal)

Boca Office PnP internal Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 28,800 BPS

COM3

Cardinal 28800 internal Win95 V950B

Chinese (Traditional) Dial up Internet, Netscape

Upload / Download files Pass 28,800 BPS

COM2

Modems

(External)

ADI CommuPack

33600SVD Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 33,600 BPS

COM2

ADI CommuPack SVD56K Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 56,000 BPS

COM2

GVC SF1156V Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 56,000 BPS

COM2

Hayes Optima Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 28,800 BPS

COM2

Supra Express 288 PnP Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 28,800 BPS

COM2

USRobotics Sportster

Voice External 33.6 Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 33,600 BPS

COM2

ZyXEL U-336E Win95 V950B Dial up Internet, Netscape

Upload / Download files Pass 33,600 BPS

COM2

ISDN Devices

Type Model Peripheral Device Application Status Remark

Terminal

Adapter

(Internal)

ASUSCOM ISDN Internal

Adapter Win95 V950B Dial up Internet, Netscape

Upload / Download Files Pass

FritzCard Win95 V950B Dial up Internet, Netscape

Upload / Download Files Pass

Terminal

Adapter

(External)

ZyXEL Elite 2864I Win95 V950B Dial up Internet, Netscape

Upload / Download Files Pass

ZyXEL ISDN Terminal

Adapter Omni TA128 Win95 V950B Super Terminal, BBS

Upload / Download Files Pass

Tape Devices

Type Model O.S. Environment Status Remark / Special Setting

Parallel Iomega ditto 3200 Win95 V950B Pass

ZIP Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI Iomega Z100S2 Win95 V950B Pass

Iomega V1000S JAZ Win95 V950B Pass

Iomega V1000Si JAZ Win95 V950B Pass

IDE Iomega Z100 iDE Win95 V950B Pass

Iomega Z100ATAPI Win95 V950B Pass

Removable HDD Devices

Type Model Status Remark / Special Setting

SCSI Fujitsu Dyna MO640 Win95 V950B Pass

Mitsubishi MCA640 Win95 V950B Pass

Parallel Philips PEGASUS MO230 Win95 V950B Pass

ASUSPRO 7000

2.3 Field (stress) Test

Test Type Windows 95 network access test

Configuration Intel Pentium II-266 + 64MB(EDO 32MB * 2) + 512KB(Internal) + On-board IDE + Seagate

ST32132A + Vuego CD624A CD-ROM + On-board S3 Trio64V2/DX + Intel PILA8465 +

Logitech First Mouse Super

1 * Client (Windows 95)

1 * Server (SCO UNIX R5.0.4)

Test Procedure Client (Windows 95):Run multiple tasks.

Server (SCO UNIX):Run ping, telnet ....test.

Result Pass Duration 40 Hours

Test Type Windows 95 network access test

Configuration Intel Pentium II-266 + 128MB(EDO 32MB * 2 + EDO 16MB * 4) + 512KB(Internal) +

On-board IDE + WD AC32500 + Creative CD1220E CD-ROM + On-board S3 Trio64V2/DX +

3COM 3C905TX + Logitech First Mouse Super

1 * Client (Windows 95)

1 * Server (SCO UNIX R5.0.4)

Test Procedure Client (Windows 95):Run multiple tasks.

Server (SCO UNIX):Run ping, telnet ....test.

Result Pass Duration 15 Hours

ASUSPRO 7000

3. Microsoft Windows NT Operating System Test

3.1 Software Compatibility Test

3.1.1 Operating System Compatibility

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

Windows NT

Workstation V3.51 Microsoft Pass

Windows NT

Workstation

Chinese (Traditional)

V3.51 Microsoft Pass

Windows NT

Workstation

Japanese (PCAT)

V3.51 Microsoft Pass

Windows NT Server V3.51 Microsoft Pass

Windows NT Server

Chinese (Traditional) V3.51 Microsoft Pass

Windows NT

Workstation V4.0 Microsoft Pass

Windows NT

Workstation

Chinese (Traditional)

V4.0 Microsoft Pass

Windows NT

Workstation

Japanese (PCAT)

V4.0 Microsoft Pass

Windows NT Server V4.0 Microsoft Pass

Windows NT Server

Chinese (Traditional) V4.0 Microsoft Pass

Windows NT Server

Japanese (PCAT) V4.0 Microsoft Pass

3.1.2 Application Software Compatibility

Applications

Package Name Version Publisher O.S. Environment Status Features Tested

Exterme 3D V1.0 Micromedia NT WKS V4.0 Pass

Microsoft Office 95 Profess-

ional Microsoft NT WKS V4.0 Pass

Microsoft Office 97 Profess-

ional Microsoft NT WKS V4.0 Pass

Photoshop V4.0 Adobe NT WKS V4.0 Pass

Application Server

Package Name Version Publisher O.S. Environment Status Features Tested

Exchage Server V4.0 Microsoft NT Server V4.0 Pass

Internet Information

Server V2.0 Microsoft NT Server V4.0 Pass

Index Server V1.1 Microsoft NT Server V4.0 Pass

Proxy Server V1.0 Microsoft NT Server V4.0 Pass

SQL Server V6.5 Microsoft NT Server V4.0 Pass

SNA Server V3.0 Microsoft NT Server V4.0 Pass

Systems Management

Server V1.2 Microsoft NT Server V4.0 Pass

ASUSPRO 7000

HTML Editor

Package Name Version Publisher O.S. Environment Status Features Tested

FrontPage V2.02 Microsoft NT Server V4.0 Pass

3.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE(PCI) Fujitsu MPA3017AT (4)

IBM DJAA-31700 (4) M

SFujitsu M1636TAU (4)

ASUS S320 (32X) M

SNT WKS V4.0 Pass

Fujitsu MPA3026AT (4) MMaxtor 84320D5 (DMA33)

Aztech CDA1068-01I (10X) M

SNT WKS V3.51 Pass

IBM DAQA-32160 (4) MIBM DHEA-38451 (DMA33)

BTC BCD16XA (16X) M

SNT Server V4.0 Pass

IBM DAQA-33240 (4) MNEC CDR-CC24 (24X) MNT WKS V4.0 Pass

IBM DCAA-34330 (4) MDCS C637 (12X) MNT WKS V3.51

Chinese (Traditional) Pass

IBM DCAA-34330 (4) MFujitsu M2541BE02 (M.O.)

ASUS S320 (32X) M

SNT Server V4.0

Chinese (Traditional) Pass

IBM DHEA-34330 (DMA33) MFunai E2950UA (16X) MNT Server V4.0 Pass

IBM DHEA-34330 (DMA33) MO.R. Technology FD-3120A (LS120)

Funai E2950UA (16X) M

SNT Server V4.0 Pass

IBM DHEA-34330 (DMA33)

IBM DCAA-33610 (4) M

SFunai E2950UA (16X) MNT Server V4.0 Pass

Maxtor 82560A4 (4) MCyber 160D (16X) MNT WKS V3.51

Japanese (PCAT) Pass

Maxtor 82560A4 (4) MPanasonic CR-584-B (12X) MNT WKS V4.0 Pass

Maxtor 83201A6 (4) MMicropolis 4525A (4)

Philips PCA163CD (16X) M

SNT Server V3.51

Chinese (Traditional) Pass

Maxtor 83201A6 (4) MIomega Z100iDE ZIP

Philips PCA163CD (16X) M

SNT Server V3.51

Chinese (Traditional) Pass

Maxtor 83500A8 (4)

WD WDAC31600 (4) M

SFunai E2950UA (16X) MNT Server V3.51

Japanese (PCAT) Pass

Maxtor 84000A6 (4) MQuantum CY4335AT (4)

Teac CD-524E (24X) M

SNT Server V4.0 Pass

Maxtor 85120A8 (4)

WD AC22500 (4) M

SNEC CDR-1600A (16X) MNT WKS V3.51 Pass

Micropolis 4540A (4) MVuego CD616A (18X) MNT Server V3.51

Chinese (Traditional) Pass

Micropolis 4550A (4)

Seagate ST33240A (4) M

SQuantum ST6480AT (DMA33)

Wearnes CDD1620 (16X) M

SNT WKS V3.51 Pass

NEC DSE2100A (4) MVuego CD616A (18X) MNT WKS V4.0

Chinese (Traditional) Pass

NEC DSE2100A (4) MAcer CD616A (18X) MNT WKS V4.0

Chinese (Traditional) Pass

Quantum SR1700AT (4) MSony CDU511 (16X) MNT WKS V3.51 Pass

Quantum SR2550AT (4) MPioneer DR-A12X (12X) MNT Server V4.0

Chinese (Traditional) Pass

Quantum TM2110AT (4)

Quantum ST3240AT (DMA33) M

SBTC BCD16XA (16X) MNT WKS V4.0 Pass

Quantum TM3200AT (4) MTeac CD-516E (16X) MNT WKS V3.51 Pass

Quantum TM3840AT (4) MPhilips PCA203CD (20X) MNT Server V3.51 Pass

Quantum ST2160AT (DMA33)

Maxtor 83500A8 (4) M

SBTC BCD24X (24X) MNT WKS V4.0

Japanese (PCAT) Pass

Quantum ST4320AT (DMA33) MMaxtor 72004AP (4)

Creative CD1220E (12X) M

SNT WKS V4.0 Pass

Quantum ST4320AT (DMA33) MFujitsu M2541BE02 (M.O.)

Cyber 160D (16X) M

SNT WKS V4.0 Pass

Seagate ST31277A (4)

WD WDAC31600 (4) M

SPanasonic CR-585-B (24X) MNT Server V4.0

Chinese (Traditional) Pass

Seagate ST32132A (4) MMitsumi CRMC-FX120T (12X) MNT Server V3.51 Pass

Seagate ST32531A (4) MSony CDU571 (16X) MNT Server V4.0

Japanese (PCAT) Pass

ASUSPRO 7000

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

On-board

IDE(PCI) Seagate ST52520A (4) MMitsumi CRMC-FX140S2 (14X) MNT Server V4.0 Pass

Samsung WNR-31601A (4)

Maxtor 83062A7 (4) M

SMaxtor 83500D4 (DMA33)

Hitachi CDR8130 (18X) M

SNT Server V3.51

Chinese (Traditional) Pass

WD WDAC31600 (4) MWD WDAC33100 (4)

Vuego CD624A (24X) M

SNT WKS V4.0 Pass

WD AC32500 (4) MPioneer DR-A24X (24X) MNT WKS V3.51 Pass

WD WDAC33100 (4) MVuego CD624A (24X) MNT WKS V3.51

Chinese (Traditional) Pass

WD AC34000 (4) MDCS C706A (16X) MNT WKS V3.51

Chinese (Traditional) Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1530P

Rev.C (BIOS:V1.03) Seagate ST15150N NEC CDR-1610A NT Server V3.51 Pass

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Seagate ST32155N NEC CDR-1610A NT WKS V4.0 Pass

Adaptec AHA-1542CP

Rev.B (BIOS:V1.02) Quantum HN4550S NEC CDR-512 NT WKS V4.0 Pass

SCSI

(PCI)

ASUS PCI-AS300

Rev.1.0 (BIOS:V1.24) WD WDE2170W

Seagate ST32155W * 2 Plextor PX-20TSi NT Server V4.0 Pass

ASUS PCI-SC200

Rev.1.2 (BIOS:V4.03) Quantum HN9100S NEC CDR-512 NT Server V4.0

Japanese (PCAT) Pass

ASUS PCI-SC860

Rev.1.01 (BIOS:V4.03) Quantum TM3200S On-board Adaptec

AIC-7880P

Plextor PX-20TSi

NT Server V5.0

Beta 1 Pass

ASUS PCI-SC875

Rev.1.0 (BIOS:V4.03) Fujitsu M2954QAU NEC CDR-1410A NT Server V4.0 Pass

Adaptec AHA-2940AU

Rev.A (BIOS:V1.21) Seagate ST32550N Plextor PX-12TSi NT WKS V4.0 Pass

Adaptec AHA-2940UW

Rev.C (BIOS:V1.24) Seagate ST32155W NEC CDR-1410A NT Server V4.0 Pass

Adaptec AHA-3940

Rev.B (BIOS:V1.12) Seagate ST52160N Plextor PX-12TSi NT Server V3.51 Pass

Adaptec AHA-3940UW

Rev.A (BIOS:V1.24) Seagate ST32550W Plextor PX-12TSi NT Server V3.51 Pass

Adaptec AHA-3940W

Rev.D (BIOS:V1.12) Seagate ST15150W

Seagate ST32550W * 2 NEC CDR-1410A NT WKS V3.0

Chinese (Traditional) Pass

Adaptec AHA-3985

Rev.A (BIOS:V1.5) Seagate ST31055N Plextor PX-12TSi NT Server V3.51 Pass

Adaptec AHA-3985W

Rev.A (BIOS:V1.50) Seagate ST15150W Plextor PX-12TSi NT Server V3.51 Pass

AdvanSys ABP-930UA

Rev.1 (BIOS:V2.8C) Seagate ST32550N Plextor PX-20TSi NT Server V4.0 Pass

AdvanSys ABP-940UA

Rev.A (BIOS:V2.6L) Quantum TM3200S NEC CDR-502 NT Server V4.0

Chinese (Traditional) Pass

ATTO Vantage PCI

(BIOS:V1.50) Seagate ST34501W NEC CDR-1410A NT Server V4.0

NT Server V4.0

Chinese (Traditional)

Pass

Buslogic BT930

Rev.A (BIOS:V1.41d) NEC DSE2550S NEC CDR-1410A NT Server V3.51 Pass

Buslogic BT932

Rev.A (BIOS:V1.41d) Quantum HN4550S Plextor PX-12TSi NT WKS V4.0 Pass

Buslogic BT948C

Rev.Ab (BIOS:V4.96F) Micropolis 4341NS Plextor PX-20TSi NT WKS V3.51 Pass

Buslogic BT956C

Rev.A (BIOS:V4.96F) WD WDE4360 Plextor PX-20TSi NT WKS V4.0 Pass

DPT PM2144UW

(BIOS:V003.DS) IBM DCAS-34330W Panasonic CR-506-B NT Server V4.0 Pass

Initio INI-9100U

Rev.D (BIOS:V1.02) Fujitsu M2952SYU Panasonic CR-506-B NT WKS V4.0 Pass

Initio INI-9100UW

Rev.D (BIOS:V1.02) Quantum HN9100SW Plextor PX-12TSi NT WKS V3.51 Pass

ASUSPRO 7000

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(PCI)

Promise SCSIMAX

Rev.B (BIOS:V3.07) Seagate ST34501W Panasonic CR-506-B NT Server V5.0

Beta 1 Pass

Promise SCSIULTRA

Rev.B (BIOS:V4.03) Micropolis 4345WAV Plextor PX-12TSi NT Server V4.0

Chinese (Traditional) Pass

WDC WD7197

RevB (BIOS:V172) Quantum HN2275W Plextor PX-83CS NT Server V4.0 Pass

On-board Adaptec

AIC-7880P Seagate ST34371W Plextor PX-20TSi NT Server V4.0 Pass

Seagate ST51080N Plextor PX-20TSi NT Server V4.0 Pass

WD WDE9100W On-board IDE

Acer CD616A NT Server V4.0

Chinese (Traditional) Pass

RAID Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(PCI)

ASUS PCI-DA2100

Rev.3A (BIOS:V1.13B) Quantum HN2275SW * 3 On-board Adaptec

AIC-7880P

NEC CDR-502

NT Server V4.0 Pass

DPT PM3334UW

(BIOS:V003.DS) Seagate ST32155W * 2 Panasonic CR-506-B NT WKS V4.0

Japanese (PCAT) Pass

Graphic Adapters

Card Type Card Model Peripheral Device O.S. Environment Status Remark

VGA

(PCI)

On-board S3 Trio64V2/DX On-board AIC-7800P

WD WDE4360W NT WKS V4.0 Pass S3 Trio64V2/DX

Multimedia Kit

Card Type Card Model Peripheral Device O.S. Environment Status

Sound

Card

ASUS I-A16C

Rev.1.2 On-board IDE

Quantum TM2110AT NT WKS V4.0 Pass

Creative Sound Blaster

AWE32 PnP On-board AIC-7800P

WD WDE4360W NT WKS V4.0 Pass

Creative Sound Blaster

AWE642 PnP On-board Symbios 53C876

WD WDE4360W NT WKS V4.0 Pass

Creative Sound Blaster

ViBRA 16XV On-board IDE

Quantum TM2110AT NT WKS V4.0 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509BTP

(Plug and Play) 5 360 NT WKS V4.0 Pass

Accton EN166X

Rev.02 (Plug and Play) 3 300 NT WKS V3.51

Chinese (Traditional) Pass

Cnet 288PnP

Rev.A (Plug and Play) 3 300 NT Server V4.0

Chinese (Traditional) Pass

Cnet 650EPlus

Rev.A 5 300 NT WKS V4.0

Chinese (Traditional) Pass

Cnet 888E

Rev.1.4 5 300 NT Server V4.0 Pass

Digital DE204 5 300 NT Server V3.51

Chinese (Traditional) Pass

HP NC/16TP

Rev.D 5 300 7 NT WKS V4.0

Japanese (PCAT) Pass

Intel PCLA8205

(Plug and Play) 11 210 NT Server V3.51

Chinese (Traditional) Pass

Novell NE2000Plus-3 5 300 NT WKS V3.51

Chinese (Traditional) Pass

Ethernet

(PCI)

ASUS PCI-DEC10-TB

Rev.A1 Auto Auto NT WKS V4.0 Pass

ASUS PCI-DEC10-TB+

Rev.B1 Auto Auto NT WKS V4.0 Pass

3COM 3C590C

Rev.14 Auto Auto NT Server V4.0 Pass

3COM 3C900C

Rev.C Auto Auto NT WKS V3.51 Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(PCI)

Accton EN1203

Rev.01C Auto Auto NT Server V4.0 Pass

Accton EN1208

Rev.01A Auto Auto NT Server V4.0 Pass

Compaq NETFLEX-3/P

Rev.A Auto Auto NT WKS V4.0 Pass

Cogent EM960 Auto Auto NT Server V4.0

Japanese (PCAT) Pass

Cogent EM964 Auto Auto NT Server V5.0

Beta 1 Pass

D-Link DE530CT+

Rev.A1 Auto Auto NT WKS V4.0 Pass

Digital DE450AC

Rev.A01 Auto Auto NT Server V4.0

Chinese (Traditional) Pass

IBM PCI Ethernet

Rev.B2 Auto Auto NT Server V3.51 Pass

Intel PILA840X Auto Auto NT WKS V4.0 Pass

Proteon P1670-EA Auto Auto NT Server V4.0 Pass

SMC 8432BT

Rev.A Auto Auto NT Server V3.51 Pass

Thomas-Conrad TC5048

Rev.A Auto Auto NT WKS V4.0 Pass

Xpoint Quad PeerSwitch

Rev.2 Auto Auto NT WKS V4.0 Pass

100BaseTx ASUS PCI-DEC100TX

Rev.01 Auto Auto NT WKS V4.0 Pass

3COM 3C595TX

Rev.B Auto Auto NT WKS V3.51 Pass

3COM 3C905TX

Rev.B Auto Auto NT WKS V3.51 Pass

Accton EN1207

Rev.01 Auto Auto NT Server V4.0

Chinese (Traditional)

NT Server V4.0

Japanese (PCAT)

Pass

Cnet CN100TX Auto Auto NT Server V4.0

Chinese (Traditional) Pass

Cogent EM110TX Auto Auto NT Server V4.0 Pass

Cogent EM440TX Auto Auto NT Server V3.51

Chinese (Traditional) Pass

Digital DE500XA Auto Auto NT Server V4.0 Pass

Intel PILA8465 Auto Auto NT Server V3.51 Pass

Intel PILA8465B Auto Auto NT WKS V3.51 Pass

Intel PILA8485 Auto Auto NT Server V3.51

Chinese (Traditional) Pass

SMC 9332DST Auto Auto NT WKS V3.51

Chinese (Traditional) Pass

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Token-

Ring

Accton TR1615

Rev.C1 2A20 NT WKS V3.51 Pass

(ISA) D-Link DT-220P

Rev.B1 Auto Auto NT WKS V4.0 Pass

IBM Auto 16/4 Adapter

(Plug and Play) 2A20 NT WKS V4.0

Chinese (Traditional) Pass

ASUSPRO 7000

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Token-

Ring

Intel PCLA815X

(Plug and Play) Auto 210 NT Server V4.0 Pass

(ISA) Olicom OC-3118

Rev.3 (Plug and Play) Auto Auto NT Server V3.51 Pass

Proteon P1392Plus

Rev.J (Plus and Play) 5A20 5NT WKS V4.0 Pass

Token-

Ring

Olicom OC-3870

Rev.4 Auto Auto NT Server V3.51 Pass

(PCI) Proteon P1690

Rev.B Auto Auto NT Server V3.51 Pass

Thomas-Conrad TC4048

Rev.C Auto Auto NT Server V3.51 Pass

Modem Devices

Type Model Peripheral Device Application Status Remark

Modems

(Internal)

Cardinal 28800 internal NT WKS V4.0 Dial up Internet, Netscape

Upload / Download files Pass 28,800 BPS; COM1

Modems

(External)

ADi CommuPack 33600

SVD NT WKS V4.0 Dial up Internet, Netscape

Upload / Download files Pass 33,600 BPS; COM2

Hays OPTIMA 288 NT WKS V4.0 Dial up Internet, Explore,

Netscape, and

Upload / Download files

Pass 28,800 BPS; COM2

USRobotics Sportster

Voice 33.6 Faxmodem NT WKS V4.0 Dial up Internet, Netscape

Upload / Download files Pass 33,600 BPS; COM2

ZyXEL U-336E NT WKS V4.0 Dial up Internet, Netscape

Upload / Download files Pass 33,600 BPS; COM2

ISDN Devices

Type Model Peripheral Device Application Status Remark

Terminal

Adapter

(External)

ZyXEL Elite 2864I NT WKS V4.0 Dial up Internet, Netscape

Upload / Download Pass 64,000 BPS

ZyXEL ISDN Terminal

Adapter Omni TA128 NT WKS V4.0 Dial up Internet, Netscape

Upload / Download Pass 64,000 BPS

LS-120 Devices

Type Model O.S. Environment Status Remark / Special Setting

IDE O.R. Technology

FD-3120A NT Server V4.0 Pass

M.O. Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI Fujitsu Dyna M2513S2B NT WKS V4.0 Pass

Fujitsu TeraSys M2513A6 NT Server V5.0

Beta 1 Pass

Mitsubishi MCA640 NT WKS V4.0 Pass

IDE Fujitsu M2541BE02 NT WKS V4.0

NT Server V4.0

Chinese (Traditional)

Pass

Removable HDD Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI Iomega V1000Si JAZ NT Server V4.0

Chinese (Traditional) Pass

Iomega V1000S JAZ NT WKS V4.0 Pass

SyQuest SyJet

Internal 1.5G NT Server V5.0

Beta 1 Pass

SyQuest SyJet1SE 1.5G NT Server V5.0

Beta 1 Pass

ASUSPRO 7000

Tape Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI Archive Python 28388 NT WKS V4.0 Pass

Exabyte EXB2501 NT WKS V4.0 Pass

ZIP Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI Iomega Z100S2 NT Server V4.0

Chinese (Traditional) Pass

IDE Iomega Z100iDE NT Server V3.51

Chinese (Traditional) Pass

3.3 Field (stress) Test for Networking Environment

Test Type Windows NT Server V5.0 Beta 1 test

Configuration Intel P6-200 * 2 + 128MB(EDO 32MB * 2 + 32MB * 2) + 256KB(Internal) + Promise SCSIMAX

+ Seagate ST34501W + Panasonic CR-506-B CD-ROM + On-board S3 Trio64V2/DX +

Microsoft Serial Mouse

1 * Server (NT Server V5.0 Beta 1)

Test Procedure Server (NT Server V5.0 Beta 1): Run multitasking programs.

Result Pass Duration 17 Hours

Test Type Windows NT Workstation V4.0 test

Configuration Intel Pentium II-266 * 2 + 128MB(32MB * 4) + 512KB(Internal) + On-board IDE + WD

WDAC31600 + WD WDAC33100 + Vuego CD624A CD-ROM + On-board S3Trio64 V2/DX +

HP J3171 + Logitech Serial Mouse

1 * Workstation (NT WKS V4.0)

1 * Server (NT Server V4.0)

Test Procedure Workstation (NT WKS V4.0): Run multitasking programs, network I/O test.

Server (NT Server V4.0): Allows other user to log-on and connect.

Result Pass Duration 12 Hours

Test Type Windows NT Server V4.0 Soft RAID and Web Server test

Configuration Intel P6-200 * 2 + 64MB(EDO 32MB * 2) + 256KB(Internal) + On-board AIC-7880P + WD

WDE2170W + On-board Symbios 53C876 + WD WDE4360 + On-board IDE + Acer CD616A

CD-ROM + On-board S3 Trio64V2/DX + Intel PILA8465B + Logitech Serial Mouse

2 * Servers (NT Server V4.0)

Test Procedure Server (NT Server V4.0): Create NT Soft system volume MIRROR set, install internet

information Server(Web Server) to allow foreign connection. run

multitasking programs, network I/O test.

Server (NT Server V4.0): Allows other user to log-on and connect.

Result Pass Duration 21 Hours

Test Type Windows NT Server V4.0 Japanese (PCAT) test

Configuration Intel P6-200 * 2 + 64MB(EDO 32MB * 2) + 256KB(Internal) + On-board Symbios 53C876 +

WD WDE4360W + On-board Adaptec AIC-7880P + WD WDE2170W + On-board IDE + Acer

CD616A CD-ROM + On-board S3 Trio64V2/DX + Intel PILA8465B + Logitech PS/2 Mouse

Server (NT Server V4.0 Japanese (PCAT))

Server (NT Server V4.0)

Test Procedure Server (NT Server V4.0 Japanese (PCAT)): Create NT Soft data volumes VOLUME set, run

multitasking programs, network I/O test.

Server (NT Server V4.0): Allows other user to log-on and connect.

Result Pass Duration 135 Hours

ASUSPRO 7000

Test Type Windows NT Server V4.0 test

Configuration Intel P6-200 * 2 + 64MB(EDO 32MB * 2) + 256KB(Internal) + On-board Adaptec AIC-7880P +

Seagate ST34371W + Plextor PX-83CS CD-ROM + On-board S3 Trio64V2/DX + 3COM

3C590C + Microsoft Serial Mouse + Seagate ST34501W * 4

2 * Servers (NT Server V4.0)

Test Procedure Server (NT Server V4.0): Create I2O devices with NT soft data volume STRIPPING set with

parity, run multitasking programs, network I/O test.

Server (NT Server V4.0): Allows other user to log-on and connect.

Result Pass Duration 12 Hours

Test Type Windows NT Server V4.0 (Chinese Traditional) test

Configuration Intel P6-200 * 2 + 64MB(EDO 32MB * 2) + 256KB(Internal) + On-board Adaptec AIC-7880P +

WD WDE9100W + On-board Symbios 53C876 + WD WDE9100W + On-board S3

Trio64V2/DX + Intel PILA8465B + Microsoft Serial Mouse

1 * Server (NT Server V4.0 Chinese (Traditional))

1 * Server (NT Server V4.0)

Test Procedure Server (NT Server V4.0 Chinese (Traditional)): Create NT soft data volume STRIPPING set ,

run multitasking programs, network I/O test.

Server (NT Server V4.0): Allows other user to log-on and connect.

Result Pass Duration 37 Hours

ASUSPRO 7000

4. IBM OS/2 Operating System Test

4.1 Software Compatibility Test

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

IBM OS/2 WARP

Connect V3.0 IBM Pass

IBM OS/2 WARP

Connect

Chinese (Traditional)

V3.0 IBM Pass

IBM OS/2 WARP V4.0 IBM Pass

IBM OS/2 WARP

Chinese (Traditional) V4.0 IBM Pass

IBM OS/2 WARP

Server V4.0 IBM Pass

IBM OS/2 WARP

Server SMP V4.0 IBM Pass

4.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Fujitsu MPA1636TAU (4)

Mitsumi CRMC-FX140S2 (14X) M

SMaxtor 84000A6 (4) MOS/2 WARP Connect

V3.0

Chinese (Traditional)

Pass

Fujitsu MPA3017AT (4)

Funai E2950UA (16X) M

SQuantum SR1700AT (4)

Maxtor 83500A8 (4) M

SOS/2 WARP V4.0 Pass

IBM DAQA-32160 (4)

Mitsumi CRMC-FX140S2 (14X) M

SIBM DHEA-38451 (DMA33) MOS/2 WARP V4.0 Pass

IBM DHEA-34330 (DMA33)

IBM DJAA-31700 (4) M

SPhilips PCA203CD (20X) MOS/2 WARP V4.0 Pass

IBM DHEA-38451 (DMA33)

Maxtor 83500D4 (DMA33) M

STeac CD-516E (16X) MOS/2 WARP V4.0 Pass

Maxtor 72004AP (4) MNEC DSE2100A (4)

DCS C706A (16X) M

SOS/2 WARP Connect

V3.0 Pass

Maxtor 82560A4 (4)

WD AC22500 (4) M

SCyber 160D (16X) MOS/2 WARP V4.0 Pass

Maxtor 82560D3 (DMA33)

Maxtor 83500 D4 (DMA33) M

SIBM DHEA-38451 (DMA33)

Vuego CD624A (24X) M

SOS/2 WARP V4.0

Chinese (Traditional) Pass

Maxtor 83062A7 (4)

Sony CDU571 (16X) M

SIBM DHEA-38451 (DMA33)

Seagate ST32132A (4) MOS/2 WARP V4.0 Pass

Maxtor 83500A8 (4)

Fujitsu MPA3017AT (4) M

SQuantum SR1700AT (4)

Funai E2950UA (16X) M

SOS/2 WARP V4.0 Pass

Maxtor 84000A6 (4)

Panasonic CR-585-B (24X) M

SFujitsu MPA3017AT (4) MOS/2 WARP V4.0 Pass

Maxtor 85250D6 (DMA33)

Seagate ST32132 A (4) M

SNEC DSE2100A (4)

Teac CD-524E (24X) M

SOS/2 WARP V4.0 Pass

Micropolis 4540A (4)

IBM DJAA-31700 (4) M

SQuantum ST2160AT (DMA33)

NEC CDR-1800A (24X) M

SOS/2 WARP V4.0 Pass

NEC DSE2100A (4)

Maxtor 72004AP (4) M

SNEC CDR-CC24 (24X) MOS/2 WARP V4.0 Pass

Quantum BF2550AT (4)

Sony CDU511 (16X) M

SFujitsu MPA3017AT (4) MOS/2 WARP Connect

V3.0 Pass

Quantum CY4335AT (4)

Quantum SR2550AT (4) M

SPhilips PCA203CD (20X) MOS/2 WARP V4.0 Pass

Quantum SR1700AT (4)

Maxtor 83500A8 (4) M

SNEC CDR-1800A (24X)

Fujitsu MPA3017AT (4) M

SOS/2 WARP V4.0 Pass

ASUSPRO 7000

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Quantum SR2550AT (4)

Fujitsu MPA3017AT (4) M

SPhilips PCA203CD (20X) MOS/2 WARP V4.0 Pass

Quantum TM3200AT (4)

Acer CD616A (18X) M

SSeagate ST32531A (4) MOS/2 WARP V4.0 Pass

Quantum TM3840AT (4)

IBM DJAA-31700 (4) M

SNEC CDR-1600A (16X) MOS/2 WARP V4.0 Pass

Quantum ST2160AT (DMA33)

Maxtor 83500A8 (4) M

STeac CD-524E (24X)

Seagate ST31277A (4) M

SOS/2 WARP V4.0 Pass

Quantum ST6480A (DMA33)

IBM DJAA-31700 (4) M

SMicropolis 4540A (4)

NEC CDR-1800A (24X) M

SOS/2 WARP V4.0 Pass

Samsung WNR-31601A (4)

Fujitsu M1636TAU (4) M

SVuego CD624A (24X) MOS/2 WARP Connect

V3.0 Pass

Seagate ST31277A (4)

Maxtor 83500A8 (4) M

STeac CD-524E (24X) MOS/2 WARP Server

V4.0 Pass

Seagate ST32122A (DMA33)

Quantum TM3200AT (4) M

SQuantum CY4335AT (4)

Philips PCA243CD (24X) M

SOS/2 WARP V4.0 Pass

Seagate ST32531A (4)

Fujitsu MPA1636TAU (4) M

SMitsumi CRMC-FX140S2 (14X)

Maxtor 84000A6 (4) M

SOS/2 WARP Server

V4.0 Pass

Seagate ST52520A (4)

Seagate ST32132A (4) M

SPioneer DR-A12X (12X) MOS/2 WARP V4.0 Pass

WD WDAC22100 (4)

Quantum TM2110AT (4) M

SCyber 160D (16X) MOS/2 WARP V4.0 Pass

WD WDAC31600 (4)

Maxtor 83201A6 (4) M

SMaxtor 72004AP (4)

Sony CDU511 (16X) M

SOS/2 WARP V4.0 Pass

WD AC32500 (4)

Quantum TM3840AT (4) M

SNEC CDR-1800A (24X) MOS/2 WARP Connect

V3.0 Pass

WD WDAC33100 (4)

Maxtor 83201A6 (4) M

SMaxtor 72004AP (4)

Sony CDU511 (16X) M

SOS/2 WARP V4.0 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Quantum TM3200S Panasonic CR-506-B OS/2 WARP V4.0 Pass

Adaptec AHA-1542CP

Rev.B (BIOS:V1.02) Seagate ST32550N NEC CDR-1410A OS/2 WARP V4.0

Chinese (Traditional) Pass

SCSI

(PCI)

On-board Adaptec AIC-

7880P

(BIOS:V1.24)

Quantum HN2275SW Pioneer DR-U12X OS/2 WARP Server

SMP V4.0 Pass

On-board SC876

(BIOS:V4.03) Micropolis 4341NS NEC CDR-1410A OS/2 WARP Connect

V3.0 Pass

ASUS PCI-DA2100

Rev.3A (BIOS:V1.13B) IBM DCAS-32160W

Quantum HN2275SW * 2

Quantum VK4550SW

NEC CDR-1610A OS/2 WARP Connect

V3.0 Pass

ASUS PCI-SC200

Rev.1.2 (BIOS:V4.03) NEC DSE2550S NEC CDR-1610A OS/2 WARP Connect

V3.0 Pass

ASUS PCI-SC860

Rev.1.01 (BIOS:V4.03) Quantum TM2110S NEC CDR-1410A OS/2 WARP Connect

V3.0 Pass

ASUS PCI-SC875

Rev.1.0 (BIOS:V4.03) Seagate ST34371W Plextor PX-20TSi OS/2 WARP Server

V4.0 Pass

Adaptec AHA-2940AU

Rev.A (BIOS:V1.21) Seagate ST32550N NEC CDR-1410A OS/2 WARP V4.0 Pass

Adaptec AHA-2940UW

Rev.C (BIOS:V1.24) Seagate ST32550W Plextor PX-12TSi OS/2 WARP Server

V4.0 Pass

Adaptec AHA-3940UW

Rev.A (BIOS:V1.24) Quantum HN2275SW NEC CDR-1410A OS/2 WARP Server

SMP V4.0 Pass

AdvanSys ABP-930UA

Rev.1 (BIOS:V2.8C) IBM DCAS-34330 Panasonic CR-506-B OS/2 WARP Server

V4.0 Pass

AdvanSys ABP-940U

Rev.A (BIOS:V2.6L) Micropolis 4345AV NEC CDR-1410A OS/2 WARP V4.0 Pass

Buslogic BT930

Rev.A (BIOS:V1.40e) Seagate ST52160N Plextor PX-20TSi OS/2 WARP Connect

V3.0 Pass

Buslogic BT932

Rev.A (BIOS:V1.40e) WD WDE2170 Panasonic CR-506-B OS/2 WARP Connect

V3.0 Pass

Buslogic BT948C

Rev.Ab (BIOS:V4.95L) Seagate ST32155N NEC CDR-1610A OS/2 WARP V4.0

Chinese (Traditional) Pass

ASUSPRO 7000

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(PCI)

DPT PM2144UW

(BIOS:V003.DS) Quantum HN9100S Plextor PX-12TSi OS/2 WARP Connect

V3.0 Pass

DPT PM3334UW

(BIOS:V003.DS) Seagate ST32155W * 3 NEC CDR-1610A OS/2 WARP Server

V4.0 Pass

Initio INI-9100U

Rev.D (BIOS:V1.02) Seagate ST32155N Pioneer DR-U24X OS/2 WARP Server

SMP V4.0 Pass

Initio INI-9100UW

Rev.E (BIOS:V1.02) Micropolis 4345AV Pioneer DR-U12X OS/2 WARP V4.0 Pass

Promise SCSIMAX

Rev.B (BIOS:V3.07) NEC DSE2550S NEC CDR-1410A OS/2 WARP Connect

V3.0 Pass

Promise SCSIULTRA

Rev.B (BIOS:V4.03) Micropolis 4341NS NEC CDR-1610A OS/2 WARP Connect

V3.0 Pass

WDC WD7197

Rev.B (BIOS:V172) NEC DSE2550S Pioneer DR-U12X OS/2 WARP Connect

V3.0 Pass

Graphic Adapters

Card Type Card Model Peripheral Device O.S. Environment Status Remark

VGA

(PCI)

On-board S3-

Trio64V2/DX On-board IDE

Quantum CY4335AT OS/2 WARP V4.0 Pass S3 Trio64V2/DX

Multimedia Kit

Card Type Card Model Peripheral Device O.S. Environment Status Remark

Sound

Card

ASUS I-A16C

Rev.1.2 INI9100UW

Micropolis 4345AV OS/2 WARP V4.0 Pass

Creative Sound Blaster

32 PnP AHA-2940AU

Seagate ST32550N OS/2 WARP V4.0 Pass

Creative Sound Blaster

AWE32 PnP INI9100UW

Micropolis 4345AV OS/2 WARP V4.0 Pass

Arvin AudioMagic - PnP

Rev.2.1 DPT PM2144UW

Quantum HN9100S

Plextor PX-12TSi

OS/2 WARP Connect V3.0 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509B-TP

(Plug and Play) 5 360 OS/2 WARP Connect V3.0 Pass

Digital DE204 5 300 OS/2 WARP V4.0 Pass

Intel PCLA8205 Auto Auto OS/2 WARP V4.0 Pass

Novell NE2000Plus-3 5 300 OS/2 WARP V4.0 Pass

Ethernet

(PCI)

3COM 3C590C

Rev.14 Auto Auto OS/2 WARP V4.0 Pass

ASUS PCI-DEC10-TB+

Rev.B1 Auto Auto OS/2 WARP V4.0 Pass

Accton EN1203

Rev.01C Auto Auto OS/2 WARP V4.0 Pass

Accton EN1208

Rev.01A Auto Auto OS/2 WARP Server V4.0 Pass

Compaq NETFLEX-3/P

Rev.A Auto Auto OS/2 WARP V4.0 Pass

Cogent EM960 Auto Auto OS/2 WARP Server V4.0 Pass

Cogent EM964 Auto Auto OS/2 WARP Connect V3.0 Pass

Digital DE450AC

Rev.A01 Auto Auto OS/2 WARP V4.0 Pass

D-Link DE-530CT+

Rev.A1 Auto Auto OS/2 WARP Connect V3.0 Pass

IBM PCI Ethernet

Rev.B2 Auto Auto OS/2 WARP V4.0 Pass

Intel PILA840X Auto Auto OS/2 WARP Connect V3.0

Chinese (Traditional) Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(PCI)

Proteon P1670-EA Auto Auto OS/2 WARP V4.0 Pass

SMC 8432BT

Rev.A Auto Auto OS/2 WARP V4.0 Pass

Thomas-Conrad TC5048

Rev.A Auto Auto OS/2 WARP V4.0 Pass

100BaseTx 3COM 3C595TX

Rev.B Auto Auto OS/2 WARP Connect V3.0 Pass

3COM 3C905TX

Rev.B Auto Auto OS/2 WARP Server

SMP V4.0 Pass

ASUS PCI-DEC100TX

Rev.01 Auto Auto OS/2 WARP V4.0

Chinese (Traditional) Pass

Accton EN1207

Rev.01 Auto Auto OS/2 WARP Server

SMP V4.0 Pass

CNET CN100TX Auto Auto OS/2 WARP Connect V3.0 Pass

Cogent EM110TX Auto Auto OS/2 WARP Connect V3.0 Pass

Digital DE500XA Auto Auto OS/2 WARP V4.0 Pass

Intel PILA8465 Auto Auto OS/2 WARP Server

SMP V4.0 Pass

Intel PILA8465B Auto Auto OS/2 WARP Server

SMP V4.0 Pass

SMC 9332DST Auto Auto OS/2 WARP Server V4.0 Pass

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Token-

Ring

Accton TR1615

Rev.C1 2A20 OS/2 WARP Server

SMP V4.0 Pass

(ISA) D-Link DT-220P 2A20 OS/2 WARP Connect V3.0 Pass

IBM Auto 16/4 Adapter

(Plug and Play) Auto Auto OS/2 WARP Server

SMP V4.0 Pass

Intel PCLA815X

(Plug and Play) Auto Auto OS/2 WARP V4.0

Chinese (Traditional) Pass

Olicom OC-3118

Rev.3 (Plug and Play) Auto Auto OS/2 WARP Connect V3.0 Pass

Proteon P1392Plus

Rev.J (Plus and Play) 5A20 5OS/2 WARP Connect V3.0 Pass

Thomas-Conrad TC4145-

(Plug and Play) Rev.A

Auto Auto OS/2 WARP Connect V3.0 Pass

Token-

Ring

Olicom OC-3870

Rev.4 Auto Auto OS/2 WARP Connect V3.0 Pass

(PCI) Proteon P1690

Rev.B Auto Auto OS/2 WARP Connect V3.0 Pass

Thomas-Conrad TC4048

(Plug and Play) Rev.A Auto Auto OS/2 WARP V4.0 Pass

Modem Devices

Type Model O.S. Environment Application Status Remark

Modems

(Internal)

Cardinal 28800 internal OS/2 WARP V4.0 IBM Dial-Up for TCP/IP

FTP-PM Upload / Download Pass 28,800 BPS

COM1

Modems

(External)

ADI CommuPack

33600SVD OS/2 WARP V4.0 IBM Dial-Up for TCP/IP

FTP-PM Upload / Download Pass 33,600 BPS

COM2

Hayes OPTIMA 288 OS/2 WARP V4.0 IBM Dial-Up for TCP/IP

FTP-PM Upload / Download Pass 28,800 BPS

COM2

USRoboties

Sportster Vi OS/2 WARP V4.0 IBM Dial-Up for TCP/IP

FTP-PM Upload / Download Pass 33,600 BPS

COM2

ZYXEL U-336E OS/2 WARP V4.0 IBM Dial-Up for TCP/IP

FTP-PM Upload / Download Pass 33,600 BPS

COM2

ASUSPRO 7000

ZIP Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI Iomega Z100S2 OS/2 WARP V4.0 Pass

Iomega V1000S JAZ OS/2 WARP Server V4.0 Pass

Iomega V1000Si JAZ OS/2 WARP Server SMP V4.0 Pass

Parallel Iomega Z100P2 OS/2 WARP Server SMP V4.0 Pass

Removable HDD Devices

Type Model Status Remark / Special Setting

SCSI Fujitsu Dyna M2513S2B OS/2 WARP V4.0 Pass

Mitsubishi MCA640 OS/2 WARP V4.0 Pass

SyQuest SyJet

Internal 1.5G OS/2 WARP Connect V3.0 Pass

SyQuest SyJet1SE 1.5G OS/2 WARP Connect V3.0 Pass

4.3 Field (stress) Test For Networking Environment

Test Type IBM OS/2 WARP Server SMP V4.0 test

Configuration Intel Pentium II-300 * 2 + 48MB(EDO 16MB * 2 + 8MB * 2) + 512KB(Internal) + On-board

Adaptec AIC-7880P + Quantum HN2275SW + Pioneer DR-U12X CD-ROM + On-board S3

Trio64V2/DX + 3COM 3C905TX + Logitech MouseMan

1 * Server (OS/2 WARP Server V4.0)

1 * Client (OS/2 WARP V4.0)

Test Procedure Server : Run multitasking program and network I/O test.

Client : Run multitasking program and get data transfer between Server and client.

Result Pass Duration 18 Hours

Test Type IBM OS/2 WARP V4.0 test

Configuration Intel P6-180 + 96MB(32MB * 2 + 16MB * 2) + 256KB(Internal) + On-board IDE +

IBM DHEA-34330 + IBM DJAA-31700 + Philips PCA203CD CD-ROM + On-board S3

Trio64V2/DX + 3COM 3C590C

1 * Server (OS/2 WARP Server V4.0)

1 * Client (OS/2 WARP V4.0)

Test Procedure Run multitasking program on both peer side to add computer loading and do data

transfer between each of them.

Result Pass Duration 14 Hours

Test Type IBM OS/2 WARP V4.0 CTK test

Configuration Intel Pentium II-300 + 48MB(EDO 16MB * 2 + 8MB * 2) + 512KB(Internal) + On-board Adaptec

AIC-7880P + Seagate ST34501W + NEC CDR-1610A CD-ROM + On-board S3 Trio64V2/DX

+ Logitech MouseMan

1 * Peer (OS/2 WARP V4.0)

Test Procedure Run stress test items.

Result Pass Duration 6 Hours

ASUSPRO 7000

5. Novell NetWare Operating System Test

5.1 Software Compatibility Test

5.1.1 Network Operating System Compatibility

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

Netware 386 V3.12 Novell Pass

Netware V4.1 Novell Pass

Netware V4.11 Novell Pass

Netware SFT3 V4.11 Novell Pass

5.1.2 Application Software Compatibility

Network Backup

Package Name Version Publisher O.S. Environment Status Features Tested

ARCServe for NetWare V6.1 Cheyenne NetWare V4.11 Pass

NFS Service

Package Name Version Publisher O.S. Environment Status Features Tested

NetWare NFS Service

(NW4 Edition) V2.1 Novell NetWare V4.1 Pass

Web Server

Package Name Version Publisher O.S. Environment Status Features Tested

NetWare Web Server V2.51 Novell NetWare V4.11 Pass

NetWare Web Server V3.0 Novell NetWare V4.11 Pass

Network Benchmark

Package Name Version Publisher O.S. Environment Status Features Tested

NetBench V5.01 Ziff-Davis NetWare V4.11 Pass

ServerBench for

NetWare V4.X V3.0 Ziff-Davis NetWare V4.11 Pass

5.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

IBM DHEA-34330 (DMA33)

Funai E2950UA (16X) M

SNone NetWare V4.11 Pass

Quantum ST2160AT (DMA33) MWearnes CDD1620 (16X) MNetWare V4.11 Pass

Micropolis 4550A (4) MPanasonic CR-585-B (24X) MNetWare V4.11 Pass

Quantum ST6480AT (DMA33) MSony CDU571 (16X) MNetWare V4.11 Pass

Samsung WNR-31601A (4) MTeac CD-524E (24X) MNetWare V4.11 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Maxtor MX9217SSN None NetWare V3.12 Pass

Adaptec AHA-1542CP

Rev.B (BIOS:V1.02) IBM DCAS-34330 Panasonic CR-506-B NetWare V4.1 Pass

SCSI

(PCI)

ASUS PCI-AS300

Rev.1.0 (BIOS:V1.24) Seagate ST34501N Toshiba XM-5701B NetWare V4.11 Pass

ASUS PCI-SC875

Rev.1.0 (BIOS:V4.03) Fujitsu M2952QAU None NetWare V3.12 Pass

ASUSPRO 7000

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(PCI)

Adaptec AHA-2940UW

Rev.F (BIOS:V1.23) WD WDE4360 Plextor PX-20TSi NetWare V4.11 Pass

Adaptec AHA-3940UW

Rev.B (BIOS:V1.23) Quantum HN4550SW

Quantum HN2275SW None NetWare V4.1 Pass

AdvanSys ABP-930UA

Rev.1 (BIOS:V2.8.0) IBM DCAS-34330 None NetWare V3.12 Pass

AdvanSys ABP-940U

Rev.2 (BIOS:V2.2.6) Quantum TM3200S None NetWare V3.12 Pass

Buslogic BT932

Rev.A (BIOS:V1.40e) Seagate ST19190N NEC CDR-1810A NetWare V4.11 Pass

Buslogic BT948C

Rev.Ab (BIOS:4.95L) IBM DCAS-34330 None NetWare V3.12 Pass

Buslogic BT950C

Rev.A (BIOS:V1.41d) Fujitsu M2952QAU None NetWare V3.12 Pass

DPT PM2144UW

(BIOS:V003.DS) Seagate ST19190W Teac CD-516S NetWare V4.11 Pass

Initio INI-9100UW

Rev.E (BIOS:1.02) WD WDE4360W Panasonic CR-506-B NetWare V4.11 Pass

On-board

Adaptec AIC-7880P

Rev.B (BIOS:V1.24)

WD WDE4360W

WD WDE9100W None NetWare V4.1

NetWare V4.11 Pass

On-board

Symbios 53C876

(BIOS:V4.03)

WD WDE4360W

WD WDE9100W

IBM DCAS-32160

None

Toshiba XM-5701B

NetWare V4.1

NetWare V4.11

Pass

RAID Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

RAID

Controller

Adaptec AAA-133

Rev.A (BIOS:V1.5) WD WDE4360W * 3 None NetWare V4.1

NetWare V4.11 Pass

ASUS PCI-DA2100

Rev.3A (BIOS:V1.13B) WD WDE2140W * 2

Seagate ST34501W None NetWare V4.1 Pass

DPT PM3224

(BIOS:V003.A0) WD WDE4360W * 3 Toshiba XM-5701B NetWare V4.11 Pass

Mylex DAC-960P WD WDE4360W * 3 On-board IDE

Teac CD-524E NetWare V4.11 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Driver Name

Server Client

Ethernet

(ISA)

3COM 3C509B-TP

(Plug and Play) 5 360 NetWare V4.11 Pass 3c5x9 3c5x9

Accton EN166X

Rev.02 (Plug and Play) Auto Auto NetWare V4.11 Pass acc6x

acc40 mpx2pnp

Cnet 288PnP

Rev.A (Plug and Play) Auto Auto NetWare V3.12 Pass e200p e200p

Cnet 888E

Rev.1.4 3 300 NetWare V3.12 Pass enet16a enet16a

D-Link DE220PCT

Rev.C1 (Plug and Play) Auto Auto NetWare V3.12 Pass de22x de22x

HP NC/16TP

Rev.D 5 300 7 NetWare V4.11 Pass am2100 am2100

Intel PCLA8200 5 360 NetWare V4.11 Pass epro eproodi

Intel PCLA8205 5 340 NetWare V3.12 Pass epro eproodi

Novell NE2000Plus-3 5 300 NetWare V3.12 Pass ne2000 ne2000

SMC 8013WC

Rev.A 3 280 NetWare V4.11 Pass smc8000 smc8000

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Driver Name

Server Client

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev.B1 Auto Auto NetWare V3.12

NetWare V4.11 Pass ethpci ethpci

3COM 3C590C

Rev.14 Auto Auto NetWare V3.12

NetWare V4.11 Pass 3c59x 3c59x

3COM 3C900C

Rev.14 Auto Auto NetWare V3.12

NetWare V4.11 Pass 3c90x 3c90x

Accton EN1203

Rev.01C Auto Auto NetWare V3.12

NetWare V4.11 Pass pci40 pcimlid

Accton EN1208

Rev.01A Auto Auto NetWare V4.11 Pass 1208odi 1208odi

Compaq NETFLEX-3/P

Rev.A Auto Auto NetWare V4.1

NetWare V4.11 Pass cpqnf3 cpqnf3

Cogent EM960 Auto Auto NetWare V4.11 Pass empci empci

Digital DE450AC

Rev.A01 Auto Auto NetWare V4.11 Pass de450 de450

D-Link DE-530CT+

Rev.A1 Auto Auto NetWare V3.12

NetWare V4.11 Pass dlkpci dlkpci

HP J2973A Auto Auto NetWare V3.12

NetWare V4.1 Pass hptxodim hptxodim

IBM PCI Ethernet

Rev.B2 Auto Auto NetWare V4.11 Pass ibmeanws ibmeanwc

Intel PILA840X Auto Auto NetWare V4.1

NetWare V4.11 Pass e10p e10podi

Proteon P1670-EA Auto Auto NetWare V3.12

NetWare V4.11 Pass pci40 pcimlid

SMC 8432BT

Rev.A Auto Auto NetWare V3.12

NetWare V4.11 Pass smcpwr smcpwr

Thomas-Conrad TC5048

Rev.A Auto Auto NetWare V4.11 Pass tce32pch tce32pcw

100BaseTx ASUS PCI-DEC100TX+

Rev.01 Auto Auto NetWare V3.12

NetWare V4.1 Pass ethpci ethpci

ASUS PCI-L101

Rev. 1.03 Auto Auto NetWare V3.12

NetWare V4.11 Pass e100b e100bodi

3COM 3C595TX

Rev.B Auto Auto NetWare V3.12

NetWare V4.11 Pass 3c59x 3c59x

3COM 3C905TX

Rev.B Auto Auto NetWare V3.12

NetWare V4.11 Pass 3c90x 3c90x

Accton EN1207

Rev.01 Auto Auto NetWare V3.12 Pass pci40 pcimlid

Cnet CN100TX Auto Auto NetWare V3.12 Pass dc21x4 dc21x4

Cogent EM110TX Auto Auto NetWare V4.11 Pass empci empci

Cogent EM440TX Auto Auto NetWare V4.11 Pass empci empci

Digital DE500XA Auto Auto NetWare V3.12

NetWare V4.11 Pass de500 de500

D-Link DFE-500TX

Rev.B4 Auto Auto NetWare V3.12

NetWare V4.11 Pass dlkpci dlkpci

HP J3171A Auto Auto NetWare V4.11 Pass hptx hptxodi

Intel PILA8465 Auto Auto NetWare V4.1

NetWare V4.11 Pass e100 e100odi

Intel PILA8465B Auto Auto NetWare V4.11 Pass e100b e100bodi

Intel PILA8485 Auto Auto NetWare V4.1

NetWare V4.11 Pass e100s N/A

SMC 9332DST Auto Auto NetWare V3.12

NetWare V4.11 Pass smcpwr smcpwr

ASUSPRO 7000

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Driver Name

Server Client

Token-

Ring

(ISA)

3COM 3C619B

Rev.C 5A20 NetWare V4.11 Pass 3ctoken 3ctoken

3COM 3C619C

Rev.A 5A20 NetWare V4.11 Pass 3ctoken 3ctoken

Accton TR1615

Rev.C1 2A20 NetWare V4.11 Pass token token

D-Link DT-220P 2A20 NetWare V4.11 Pass token token

IBM Auto 16/4 Adapter

(Plug and Play) Auto Auto NetWare V4.11 Pass token token

Intel PCLA815X

(Plug and Play) 5 340 NetWare V4.11 Pass tpro tproodi

Olicom OC-3118

Rev.3 (Plug and Play) Auto Auto NetWare V4.11 Pass octok161

octok162 octok16

Proteon P1392Plus

Rev.J 5A20 5NetWare V4.11 Pass 4nw39xr osh39xr

Thomas-Conrad

TC4145-C

Rev.A (Plug and Play)

Auto Auto NetWare V4.1 Pass tctokh tctoksh

Token-

Ring

Olicom OC-3870

Rev.4 Auto Auto NetWare V4.11 Pass octok162 octok16

(PCI) Proteon P1690

Rev.B Auto Auto NetWare V4.1 Pass ppnw4xx ppnw4xx

Thomas-Conrad TC4048

Rev.A Auto Auto NetWare V4.11 Pass tcpcih tc4048sh

Pocket LAN

Card Type Card Model Peripheral Device O.S. Environment Status Remark/Special Setting

Pocket

LAN

D-Link Packet LAN

DE-620CT (EPP function) On-board LPT port

(Use EPP mode) NetWare V3.12 Pass Test EPP mode

Xircom Pocket Ethernet

Adapter III

(EPP function)

On-board LPT port

(Use EPP mode) NetWare V3.12 Pass Test EPP mode

GVC Packet LAN

(EPP function) On-board LPT port

(Use EPP mode) NetWare V3.12 Pass Test EPP mode

Tape Devices

Type Model O.S. Environment Status Remark / Special Setting

SCSI HP JetStore 2000 NetWare V4.11 Pass

Exabyte EXB2501 NetWare V3.12 Pass

ZIP Devices

Type Model O.S. Environment Status Remark / Special Setting

IDE iomega Z100iDE NetWare V3.12 Pass

ASUSPRO 7000

5.3 Field (stress) Test for Networking Environment

Test Type Netware 3.12 Integrate Environment Test

Configuration Intel Pentium II 266 + 128MB(EDO 16MB * 4 + 16MB * 4) + 512KB(Internal) + Buslogic BT-

950 + Fujitsu M2952QAU + On-board S3 Trio64V2/DX + ASUS PCI-DEC10-TB+ + ASUS PCI-

DEC100TX+ + CNET CN888E

1 * Server (Netware 3.12)

3 * Clients (DOS/Windows Requester)

Test Procedure Server: Accepted network I/O from all clients, load DSK311 to add server load.

Clients: Run DTR (run all test) for actual I/O access between server and

clients under DOS environment.

Result Pass Duration 17 Hours

Test Type NetWare 4.1 Integrate Environment Test

Configuration Intel P6-200 + 64MB(EDO 16MB * 4) + 256KB(Internal) + On-board Adaptec AIC-7880P + WD

WDE4360W + On-board S3 Trio64V2/DX + SMC 9332DST + SMC 8432BT + Accton EN1208

1 * Server (NetWare 4.1)

3 * Clients (DOS/Windows Requester)

Test Procedure Server: Accept network request continuously from two clients, run DTS to add server load

itself.

Clients: Run DTR(all test) for actual access between server and clients.

Result Pass Duration 17 Hours

Test Type NetWare 4.1 NFS Service Test

Configuration Intel P6-200 + 64MB(EDO 16MB * 4) + 256KB(Internal) + On-board Adaptec AIC-7880P +

Seagate ST34501W + Toshiba XM-5701B + On-board S3 Trio64V2/DX + ASUS PCI-

DEC100TX+ * 2

1 * Server (NetWare 4.1)

2 * Clients (Slackware Linux V3.2.0)

Test Procedure Server: Run NetWare NFS Service V2.1, accept NFS request UNIX clients.

Clients: Run test program to generate rapid NFS request/respond between server and clients.

Result Pass Duration 24 Hours

Test Type NetWare 4.11 Integrate Environment Test

Configuration Intel Pentium II-233 * 2 + 128MB(16MB * 4 + 32MB * 2) + 512KB(Internal) + Adaptec AAA-133

+ WD WDE4360W * 3 + Panasonic CR-506-B CD-ROM + On-board S3 Trio64V2/DX + ASUS

PCI-DEC10-TB+ + Accton EN166X

1 * Server (NetWare 4.11)

2 * Clients (DOS/Windows Requester)

Test Procedure Server: ISA LAN adapter setup as plug and play mode, disks are associated to RAID5,

accept network request continuously from all clients, run DTS to add server load itself.

Clients: Run DTR(all test) for actual access between server and clients.

Result Pass Duration 240 Hours

Test Type NetWare 4.11 Web Server Test

Configuration Intel Pentium II-266 + 512MB(128MB * 4) + 512KB(Internal) + On-board Symbios 53C876 +

WD WDE9100W * 2 + Panasonic CR-506-B CD-ROM + On-board S3 Trio64V2/DX +

ASUS PCI-L101

1 * Server (NetWare 4.11)

1 * Controller (Windows NT Workstation V4.0)

2 * Clients (Windows 95)

Test Procedure Server: Disks are mirrored on both channel of on-board Symbios 53C876,

run WebBench server program.

Controller: Run WebBench 1.1 controller program and control the progress of all tests.

Clients: Act as WebBench Client site for access HTTP /CGI request/respond with web server .

Result Pass Duration 62 Hours

ASUSPRO 7000

Test Type NetWare SFT3 4.11 Redundant Test

Configuration Intel Pentium II-266 + 512MB(EDO 128MB * 4, with Parity check enabled) + 512KB(Internal) +

On-board Adaptec AIC-7880P + WD WDE4360 + Plextor PX-20TSi CD-ROM + On-board S3

Trio64V2/DX + Intel PILA8485 + ASUS PCI-DEC100TX+ + Cnet CN288PNP

2 * Servers (NetWare SFT3 4.11)

2 * Clients (DOS/Windows Requester)

Test Procedure Server: Each server have same DRAM size, HDD capacity, and same LAN adapters.

Setup servers to mirror together with NetWare SFT3 4.11 via MSL adapter

Accept network request continuously from all clients, run DTS to add server load

itself.

During testing, shutdown one of two mirrored server to observe the effort for another

server and connected clients, and the availability of server redundant function.

Clients: Run DTR(all test) for actual access between server and clients.

Result Pass Duration 72 Hours

ASUSPRO 7000

6. SCO UNIX Operating System Test

6.1 Software Compatibility Test

6.1.1 Network Operating System Compatibility

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

SCO Open Server R5.0.4 SCO Pass

6.1.2 Application Software Compatibility

Network Benchmark

Package Name Version Publisher O.S. Environment Status Features Tested

ServerBench for

SCO UNIX R5.0.4 V2.0 Ziff-Davis SCO UNIX R5.0.4 Pass

6.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Quantum SR1700AT (4)

Panasonic CR-584-B (12X) M

SNone SCO UNIX R5.0.2 Pass

WD WDAC22100 (4) MDCS C706A (16X) MSCO UNIX R5.0.2 Pass

NEC DSE2100A (4) MVuego CD624A (24X) MSCO UNIX R5.0.2 Pass

Maxtor 720004AP (4)

NEC CR-CC24 (24X) M

SNone SCO UNIX R5.0.2 Pass

Seagate ST31277A (4)

Creative CD2422E (24X) M

SNone SCO UNIX R5.0.4 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Seagate ST31055N NEC CDR-1410A SCO UNIX R5.0.4 Pass

Adaptec AHA-1542CP

Rev.B (BIOS:V1.02) Quantum TM3200S Plextor PX-20TSi SCO UNIX R5.0.4 Pass

SCSI

(PCI)

ASUS PCI-AS300

Rev.1.0 (BIOS:V1.24) Seagate ST19101W Plextor PX-12TSi SCO UNIX R5.0.2 Pass

ASUS PCI-SC200

Rev.1.2 (BIOS:V4.03) WD WDE2170 Teac CD-516S SCO UNIX R5.0.4 Pass

ASUS PCI-SC860

Rev.1.2 (BIOS:V4.03.02) Micropolis 4345NS Panasonic CR-506-B SCO UNIX R5.0.4 Pass

ASUS PCI-SC875

Rev.1.0 (BIOS:V4.03) Quantum HN4550SW NEC CDR-1410A SCO UNIX R5.0.4 Pass

Adaptec AHA-2940AU

Rev.A (BIOS:V1.21) Quantum HN4550S Toshiba XM-5701B SCO UNIX R5.0.4 Pass

Adaptec AHA-3940UW

Rev.B (BIOS:V1.12) Quantum VK4550SW Plextor PX-12TSi SCO UNIX R5.0.2 Pass

AdvanSys ABP-930UA

Rev.1 (BIOS:V2.8C) Seagate ST34501N Toshiba XM-5701B SCO UNIX R5.0.4 Pass

AdvanSys ABP-940U

Rev.A (BIOS:V2.6L) Quantum HN9100S NEC CDR-512 SCO UNIX R5.0.4 Pass

Buslogic BT930

Rev.A (BIOS:V1.41d) Seagate ST32155N NEC CDR-1610A SCO UNIX R5.0.2 Pass

Buslogic BT932

Rev.Ab (BIOS:V1.41d) Seagate ST52160N Sony CDU415 SCO UNIX R5.0.2 Pass

DPT PM2144UW

(BIOS:V003.DS) Micropolis 4341WS NEC CDR-512 SCO UNIX R5.0.4 Pass

ASUSPRO 7000

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(PCI)

Initio INI-9100UW

Rev.D (BIOS:1.02) Micropolis 4345WAV Pioneer DR-U12X SCO UNIX R5.0.4 Pass

On-board Symbios

53C876

(BIOS:V4.03.02)

Quantum HN4550S Sony CDU415 SCO UNIX R5.0.4 Pass

On-board Adaptec AIC-

7880P

(BIOS:V1.24)

WD WDE9100W * 2 Pioneer DR-U24X SCO UNIX R5.0.2 Pass

Promise SCSIMAX

Rev.B (BIOS:3.07) Quantum HN2275SW Teac CD-516S SCO UNIX R5.0.4 Pass

Promise SCSIUltra

Rev.B (BIOS:4.03) Seagate ST34371N NEC CDR-1610A SCO UNIX R5.0.2 Pass

RAID Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

RAID

Controller

ASUS PCI-DA2100

Rev.3A(BIOS:V1.13B) Seagate ST34371W * 3 Pioneer DR-U24X SCO UNIX R5.0.2 Pass

DPT PM3334UW

(BIOS:V003.DS) Quantum HN2275SW * 3 Plextor PX-20TSi SCO UNIX R5.0.4 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509B-TP

(Plug and Play) 5 360 SCO UNIX R5.0.4 Pass

HP NC/16TP

Rev.D 5 300 7 SCO UNIX R5.0.4 Pass

Novell NE2000Plus-3 5 300 SCO UNIX R5.0.2 Pass

SMC 8013WC

Rev.A 10 300 SCO UNIX R5.0.4 Pass

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev.B1 Auto Auto SCO UNIX R5.0.2 Pass

3COM 3C900

Rev.C Auto Auto SCO UNIX R5.0.4 Pass

Accton EN1203

Rev.01C Auto Auto SCO UNIX R5.0.2 Pass

Cogent EM960 Auto Auto SCO UNIX R5.0.2 Pass

Proteon P1670-EA

Rev.R01C Auto Auto SCO UNIX R5.0.4 Pass

SMC 8432BT

Rev.A Auto Auto SCO UNIX R5.0.2 Pass

Thomas-Conrad TC5048

Rev.A Auto Auto SCO UNIX R5.0.4 Pass

100BaseTx ASUS PCI-DEC100TX+

Rev.01 Auto Auto SCO UNIX R5.0.2 Pass

3COM 3C595-TX

Rev.B Auto Auto SCO UNIX R5.0.4 Pass

3COM 3C905TX

Rev.B Auto Auto SCO UNIX R5.0.4 Pass

Accton EN1207

Rev.01 Auto Auto SCO UNIX R5.0.2 Pass

Digital DE500XA Auto Auto SCO UNIX R5.0.4 Pass

Intel PILA8465 Auto Auto SCO UNIX R5.0.2 Pass

Intel PILA8465B Auto Auto SCO UNIX R5.0.4 Pass

SMC 9332DST Auto Auto SCO UNIX R5.0.2 Pass

ASUSPRO 7000

6.3 Field (stress) Test for Networking Environment

Test Type SCO UNIX OPEN SERVER R5.0.2

Configuration Intel Pentium II-300 * 2 + 32MB(EDO 8MB * 4) + 512KB(Internal) + Adaptec AHA-3940UW +

Quantum VK4550SW + Plextor PX-12TSi CD-ROM + On-board S3Trio64V2/DX + Intel

PILA8465 + Genius MouseOne

1 * Server (SCO UNIX R5.0.2)

1 * Server (Solaris V2.51)

Test Procedure Server (SCO UNIX R5.0.2):Run multiple tasks, including ping, telnet test.

Server (Solaris V2.51): Run ping,telnet ....tests to communicate with SCO server

Result Pass Duration 87 Hours

Test Type SCO UNIX OPEN SERVER R5.04

Configuration Intel P6-200 * 2 + 64MB(EDO 16MB * 2 + 8MB * 4) + 256KB(Internal) + Adaptec AHA-2940AU

+ Quantum HN4550S + Toshiba XM-5701B CD-ROM + On-board S3Trio64V2/DX + Intel

PILA8465B + Genius MouseOne

1 * Server (SCO UNIX R5.0.4)

1 * Server (Solaris V2.51)

Test Procedure Server (SCO UNIX R5.0.4): Run multiple tasks, including ping, telnet test

Server (Solaris V2.51):Run ping,telnet ....tests to communicate with SCO server

Result Pass Duration 18 Hours

Test Type SCO UNIX OPEN SERVER R5.04

Configuration Intel P6-200 * 2 + 64MB(EDO 32MB * 2) + 256KB(Internal) + On-board AIC-7880P + WD

WDE9100W * 2 + Pioneer DR-U24X CD-ROM + On-board S3Trio64V2/DX + 3Com 3C595-TX

+ Genius MouseOne

1 * Server (SCO UNIX R5.0.4)

1 * Server (Solaris V2.51)

Test Procedure Server (SCO UNIX R5.0.4): Run multiple tasks, including ping, telnet test

Server (Solaris V2.51):Run ping,telnet ....tests to communicate with SCO server

Result Pass Duration 21 Hours

ASUSPRO 7000

7. SCO UnixWare Operating System Test

7.1 Software Compatibility Test

7.1.1 Network Operating System Compatibility

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

UnixWare V2.1 SCO Pass

7.1.2 Application Software Compatibility

Network Benchmark

Package Name Version Publisher O.S. Environment Status Features Tested

ServerBench for

UnixWare V2.X V2.0 Ziff-Davis UnixWare V2.1 Pass

7.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board Seagate ST31277A (4) MTeac CD-516S (16X) MUnixWare V2.1 Pass

IDE (PCI) Fujitsu MPA3026AT (4) MPhilips PCA203CD (20X) MUnixWare V2.1 Pass

Seagate ST52520A (4) MPanasonic CR-583-B (8X) MUnixWare V2.1 Pass

IBM DHEA-34330 (DMA33) MTeac CD-58E (8X) MUnixWare V2.1 Pass

Quantum ST3240AT (DMA33) MPanasonic CR-585-B (24X) MUnixWare V2.1 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Fujitsu M2954SYU NEC CDR-512 UnixWare V2.1 Pass

SCSI

(PCI)

ASUS PCI-AS300

Rev.1.0 (BIOS:V1.24) Quantum HN2275SW NEC CDR-512 UnixWare V2.1 Pass

ASUS PCI-SC200

Rev.1.2 (BIOS:V4.03) Seagate ST31255N NEC CDR-502 UnixWare V2.1 Pass

ASUS PCI-SC860

Rev.1.0 (BIOS:V4.03) Quantum HN9100S Sony CDU415 UnixWare V2.1 Pass

Adaptec AHA-2940AU

Rev.A (BIOS:V1.21) Quantum TM2110S Plextor PX-20TSi UnixWare V2.1 Pass

Adaptec AHA-3940

Rev.A (BIOS:V1.24) Quantum HN4550S Teac CD-516S UnixWare V2.1 Pass

DPT PM2144UW

(BIOS:V003.DS) Fujitsu M2952QAU Pioneer DR-U12X UnixWare V2.1 Pass

On-board Adaptec

AIC-7880P

(BIOS:1.24)

Seagate ST32155W Toshiba XM-5701B UnixWare V2.1 Pass

On-board Symbios

53C876

(BIOS:4.03)

Micropolis 4345WAV Toshiba XM-5701B UnixWare V2.1 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509B

(Plug and Play) 5 360 UnixWare V2.1 Pass

Intel PCLA8205 5 340 UnixWare V2.1 Pass

Novell NE2000Plus-3 5 300 UnixWare V2.1 Pass

SMC 8013WC

Rev. A 10 300 UnixWare V2.1 Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev. B1 Auto Auto UnixWare V2.1 Pass

3COM 3C590C

Rev. 14 Auto Auto UnixWare V2.1 Pass

Compaq NETFLEX-3/P

Rev. A Auto Auto UnixWare V2.1 Pass

Cogent EM960 Auto Auto UnixWare V2.1 Pass

SMC 8432BT

Rev. A Auto Auto UnixWare V2.1 Pass

100BaseTx 3COM 3C595TX

Rev. B Auto Auto UnixWare V2.1 Pass

Intel PILA8465 Auto Auto UnixWare V2.1 Pass

7.3 Field (stress) Test for Networking Environment

Test Type UnixWare V2.1 Test

Configuration Intel P6-200 * 2 + 64MB(EDO 32MB * 2) + 256KB(Internal) + On-board IDE + Seagate

ST31276A + Mitsumi CRMC-FX140S2 CD-ROM + On-board S3 Trio64 V2/DX + Compaq

NETFLEX-3/P + Microsoft Serial Mouse

1 * Server (UnixWare V2.1)

1 * Server (NT Server V4.0)

Test Procedure Server (UnixWare V2.1):Run multitasking programs.

Server (NT Server V4.0):Run ping, telnet ....tests.

Result Pass Duration 10 Hours

Test Type UnixWare V2.1 Test

Configuration Intel P6-200 * 2 + 48MB(EDO 8MB * 2 + 16MB * 2) + 256KB(Internal) + AHA-1542CF +

Fujitsu M2954SYU + NEC CDR-512 CD-ROM + On-board S3 Trio64 V2/DX + 3COM

3C595TX + Microsoft Serial Mouse

1 * Server (UnixWare V2.1)

1 * Server (NT Server V4.0)

Test Procedure Server (UnixWare V2.1):Create I2O devices with RAID 1 function, run multitasking programs.

Server (NT Server V4.0):Run ping, telnet ....tests.

Result Pass Duration 88 Hours

ASUSPRO 7000

8. Sunsoft Solaris Operating System Test

8.1 Software Compatibility Test

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

Solaris V2.51 Sunsoft Pass Buslogic BT-930 + WD WDE2170 + NEC CDR-512 CD-ROM +

On-board S3 Trio64V2/DX + Digital DE500XA + Genius MouseOne

Solaris

Chinese (Traditional) V2.51 Sunsoft Pass AHA-3940UW + Seagate ST19101W + Pioneer DR-U24X CD-ROM +

On-board S3 Trio64V2/DX + Conpaq NETFLEX-3/P + Genius MouseOne

Solaris V2.6 Sunsoft Pass DPT PM3334UW + Quantum HN2275SW * 3 + Plextor PX-20TSi CD-ROM +

On-board S3 Trio64V2/DX + ASUS PCI-DEC10-TB+ + Genius MouseOne

8.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Maxtor 84000A6 (4) MNEC CDR-CC24 (24X) MSolaris V2.51 Pass

WD WDAC22100 (4)

Panasonic CR-584-B (12X) M

SNone Solaris V2.51 Pass

Seagate ST32531A (4) MSeagate ST52520A (4)

Acer CD616A (16X) M

SSolaris V2.6 Pass

Micropolis 4540A (4)

Creative CD2422E (24X) M

SQuantum TM3200AT (4)

Quantum TM2110AT (4) M

SSolaris V2.6 Pass

Fujitsu MPA3026AT (4)

Hitachi CDR8130 (18X) M

SSamsung WNR-3160A (4) MSolaris V2.6 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Seagate ST52520N Teac CD-516S Solaris V2.6 Pass

SCSI

(PCI)

ASUS PCI-AS300

Rev.1.0 (BIOS:V1.24) Quantum HN455S Sony CDU415 Solaris V2.51 Pass

Adaptec AHA-2940AU

Rev.A (BIOS:V1.21) Quantum TM2110S Plextor PX-20TSi Solaris V2.6 Pass

Adaptec AHA-2940UW

Rev.B (BIOS:V1.23) IBM DCAS-34330W Plextor PX-12TSi Solaris V2.6 Pass

Adaptec AHA-3940UW

Rev.A (BIOS:V1.24) Seagate ST19101W Pioneer DR-U24X Solaris V2.51 Pass

AdvanSys ABP-940U

Rev.A (BIOS:V2.6L) Micropolis 4345NS NEC CDR-1410A Solaris V2.51 Pass

Buslogic BT930

Rev.A (BIOS:V1.41d) WD WDE2170 NEC CDR-512 Solaris V2.51 Pass

Buslogic BT932

Rev.AC (BIOS:V1.41d) Seagate ST34371N NEC CDR-1610A Solaris V2.51 Pass

DPT PM2144UW

(BIOS:V003.DS) Micropolis 4341WS Panasonic CR-506-B Solaris V2.51 Pass

On-board Adaptec AIC-

7880P

(BIOS:V1.24)

Seagate ST19101W Plextor PX-20TSi Solaris V2.51 Pass

RAID Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

RAID

Controller

DPT PM3334UW

(BIOS:V003.DS) Quantum HN2275SW * 3 Plextor PX-20TSi Solaris V2.6 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509B

(Plug and Play) Auto Auto Solaris V2.6 Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

Intel PCLA8200 5 360 Solaris V2.51 Pass

SMC 8013WC

Rev. A 10 300 Solaris V2.51 Pass

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev. B1 Auto Auto Solaris V2.51 Pass

3COM 3C900

Rev.C Auto Auto Solaris V2.51 Pass

Accton EN1203

Rev. 01C Auto Auto Solaris V2.51 Pass

Compaq NETFLEX-3/P

Rev.A Auto Auto Solaris V2.51 Pass

Cogent EM960 Auto Auto Solaris V2.6 Pass

Proteon P1670-EA Auto Auto Solaris V2.6 Pass

SMC 8432BT

Rev. A Auto Auto Solaris V2.51 Pass

Thomas-Conrad TC5048

Rev. A Auto Auto Solaris V2.6 Pass

100BaseTx ASUS PCI-DEC100TX+ Auto Auto Solaris V2.6 Pass

3COM 3C595TX

Rev.B Auto Auto Solaris V2.6 Pass

3COM 3C905TX

Rev.B Auto Auto Solaris V2.51 Pass

Accton EN1207

Rev.01 Auto Auto Solaris V2.51 Pass

Cogent EM110TX Auto Auto Solaris V2.51 Pass

Digital DE500XA Auto Auto Solaris V2.51 Pass

Intel PILA8465 Auto Auto Solaris V2.51 Pass

Intel PILA8465B Auto Auto Solaris V2.51 Pass

SMC 9332DST Auto Auto Solaris V2.6 Pass

Token-Ring Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Token-

Ring

(ISA)

IBM Auto 16/4 Adapter

(Plug and Play) Auto Auto Solaris V2.6 Pass

ASUSPRO 7000

8.3 Field (stress) Test for Networking Environment

Test Type Solaris V2.51 Test

Configuration Intel Pentium II-300 * 2 + 32MB(EDO 16MB * 2) + 512KB(Internal) + Buslogic BT-932 +

Seagate ST34371N + NEC CDR-1610A CD-ROM + On-board S3 Trio64V2/DX + Intel

PILA8465 + Genius MouseOne

1 * Server (Solaris V2.51)

Test Procedure Server (Solaris V2.51):Run Multi Tasks Test.

Server (Solaris V2.51):Run ping,telnet ....test.

Result Pass Duration 12 Hours

Test Type Solaris V2.6 Test

Configuration Intel P6-200 * 2 + 48MB(EDO 16MB * 2 + 8MB * 2) + 256KB(Internal) + AHA-2940AU +

Quantum TM2110S + Plextor PX-20TSi CD-ROM + On-board S3 Trio64V2/DX + Cogent

EM960 + Genius MouseOne

1 * Server (Solaris V2.6)

1 * Server (Solaris V2.51)

Test Procedure Server (Solaris V2.6):Run Multi Tasks Test.

Server (Solaris V2.51):Run ping,telnet ....test.

Result Pass Duration 15 Hours

Test Type Solaris V2.51 with HCT V2.06c

Configuration Intel Pentium II-300 * 2 + 96MB(32MB * 2 + 16MB * 2) + 512KB(Internal) + On-board Adaptec

AIC-7880P + Seagate ST19101W + Plextor PX-20TSi CD-ROM + On-board S3 Trio64V2/DX

+ 3Com 3C905TX + Logitech First Mouse Super

1 * Server (Solaris V2.51)

Test Procedure Server (Solaris V2.51 with HCT V2.06c):Run Certification Test: Keyboard, Mouse, Network,

Disk, CD-ROM, Floppy, Paging, Display.

Server(Solaris V2.51): Network test from Solaris.

Result Pass Duration 15 Hours

ASUSPRO 7000

9. Next OpenStep Operating System Test

9.1 Software Compatibility Test

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

OpenStep R4.0 Next Pass On-board IDE + Maxtor 85250D6 + Creative CD2422E CD-ROM +

On-board S3-Trio64V2/DX + 3Com 3C509B-TP + Logitech First Mouse Super

9.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

Maxtor 72004AP (4)

Aztech CDA1068-01I (10X) M

SNone OpenStep R4.0 Pass

Maxtor 83201A6 (4)

Funai E2950UA (16X) M

SNone OpenStep R4.0 Pass

Maxtor 83500D4 (DMA33)

Teac CD-516E (16X) M

SNone OpenStep R4.0 Pass

Maxtor 84000A6 (4)

DCS C706A (16X) M

SNone OpenStep R4.0 Pass

Maxtor 85250D6 (DMA33)

Creative CD2422E (24X) M

SNone OpenStep R4.0 Pass

NEC DSE2100A (4)

DCS C706A (16X) M

SNone OpenStep R4.0 Pass

Quantum ST6480AT (DMA33)

Acer CD616A (18X) M

SNone OpenStep R4.0 Pass

Quantum TM2110AT (4)

NEC CDR-CC24 (24X) M

SNone OpenStep R4.0 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) WD WDE2170 Panasonic CR-506-B OpenStep R4.0 Pass

SCSI

(PCI)

On-board Adaptec

AIC-7880P

Rev.1.0 (BIOS:V1.24)

IBM DCAS-34330 Panasonic CR-506-B OpenStep R4.0 Pass

Adaptec AHA-2940AU

Rev.A (BIOS:V1.21) Micropolis 4345AV Plextor PX-20TSi OpenStep R4.0 Pass

Adaptec AHA-2940UW

Rev.C (BIOS:V1.24) Seagate ST321550N Toshiba XM-5701B OpenStep R4.0 Pass

Adaptec AHA-3940UW

Rev.A (BIOS:V1.24) Seagate ST34371W NEC CDR-1410A OpenStep R4.0 Pass

Buslogic BT930

Rev.A (BIOS:V1.41d) Quantum TM3200S NEC CDR-1610A OpenStep R4.0 Pass

DPT PM2144UW

(BIOS:V003.DS) Seagate ST31055N NEC CDR-1410A OpenStep R4.0 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509B-TP

(Plug and Play) 5 360 OpenStep R4.0 Pass

SMC 8013WC

Rev.A 10 300 OpenStep R4.0 Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev.B1 Auto Auto OpenStep R4.0 Pass

Cogent EM960 Auto Auto OpenStep R4.0 Pass

Digital DE450AC

Rev.A01 Auto Auto OpenStep R4.0 Pass

Intel PILA840X Auto Auto OpenStep R4.0 Pass

Proteon P1670-EA Auto Auto OpenStep R4.0 Pass

Thomas-Conrad TC5048

Rev.A Auto Auto OpenStep R4.0 Pass

100BaseTx Cogent EM110TX Auto Auto OpenStep R4.0 Pass

Digital DE500XA Auto Auto OpenStep R4.0 Pass

Intel PILA8465 Auto Auto OpenStep R4.0 Pass

Intel PILA8465B Auto Auto OpenStep R4.0 Pass

SMC 9332DST Auto Auto OpenStep R4.0 Pass

9.3 Field (stress) Test for Networking Environment

Test Type OpenStep R4.0

Configuration Intel Pentium II-233 + 48MB(EDO 16MB * 2 + 8MB * 2) + 512KB(Internal) + DPT PM2144UW

+ Seagate ST31055N + NEC CDR-1410A CD-ROM + On-board S3-Trio64V2/DX + Intel

PILA8465 + Logitech MouseMan

1 * Server (OpenStep R4.0)

1 * Server (OS/2 WARP Server V4.0)

Test Procedure Server (OpenStep R4.0):Run multiple tasks.

Server (OS/2 WARP Server V4.0):Run ping, telnet ....test.

Result Pass Duration 15 Hours

Test Type OpenStep R4.0

Configuration Intel Pentium II-266 + 32MB(16MB * 2) + 512KB(Internal) + On-board IDE + Maxtor 72004AP

+ Aztech CDA1068-01I CD-ROM + On-board S3-Trio64V2/DX + Intel PILA840X + Logitech

First Mouse Super

1 * Server (OpenStep R4.0)

1 * Server (Linux 3.2)

Test Procedure Server (OpenStep R4.0):Run multiple tests.

Server (Linux 3.2):Run ping, telnet ....test.

Result Pass Duration 15 Hours

ASUSPRO 7000

10. Slackware Linux Operating System Test

10.1 Software Compatibility Test

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

Linux V3.2.0 Slackware Pass Adaptec AHA-1542CF + Maxtor MX9217SSN + Panasonic CR-506-B

CD-ROM + On-board S3 Trio64V2/DX + Accton EN1208

Linux V3.1.0 Slackware Pass On-board IDE + Quantum ST2170AT + Wearnes CDD-1620 CD-ROM +

On-board S3 Trio64V2/DX + Digital DE450AC

10.2 Hardware Compatibility Test

IDE Controller

Card Type Primary IDE Secondary IDE O.S. Environment Status

H.D.D./CD-ROM (Mode/Speed) M/S H.D.D./CD-ROM (Mode/Speed) M/S

On-board

IDE (PCI)

IBM DJAA-31700 (4) MNEC CDR-1800A (24X) MLinux V3.2.0 Pass

Maxtor 85250D6 (DMA33) MCreative CD2422E (24X) MLinux V3.1.0 Pass

Quantum CY4550AT (4)

Panasonic CR-585-B (24X) M

SNone Linux V3.2.0 Pass

Quantum ST2160AT (DMA33) MWearnes CDD-1620 (16X) MLinux V3.1.0 Pass

IBM DHEA-34330 (DMA33)

Funai M

SNone Linux V3.2.0 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev. C (BIOS: V2.02) Maxtor MX9217SSN Panasonic CR-506-B Linux V3.2.0 Pass

Adaptec AHA-1542CP

Rev. B (BIOS: V1.02) IBM DCAS-34330 Toshiba XM-5701B Linux V3.1.0 Pass

SCSI

(PCI)

On-board Adaptec

AIC-7880P

Rev.1.0 (BIOS:V1.24)

Fujitsu M2952QAU Toshiba XM-5701B Linux V3.2.0 Pass

ASUS PCI-AS300

Rev.1.2 (BIOS:V4.03) IBM DCAS-34330 Panasonic CR-506-B Linux V3.1.0 Pass

Adaptec AHA-2940

Rev.F (BIOS:V1.21) IBM DCAS-34330 Toshiba XM-5701B Linux V3.1.0 Pass

Adaptec AHA-2940UW

Rev.C (BIOS:V1.24) IBM DCAS-34330 Toshiba XM-5701B Linux V3.1.0 Pass

Adaptec AHA-3940UW

Rev.B (BIOS:V1.12) Fujitsu M2952QAU Panasonic CR-506-B Linux V3.2.0 Pass

AdvanSys ABP-930UA

Rev.E (BIOS:V2.6.0) IBM DCAS-34330 Panasonic CR-506-B Linux V3.2.0 Pass

Buslogic BT948C

Rev.Ab (BIOS:V4.95L) Maxtor MX9217SSN Panasonic CR-506-B Linux V3.1.0 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509BTP

(Plug and Play) 5 360 Linux V3.1.0 Pass

HP NC/16TP

Rev. D 5 300 7 Linux V3.1.0 Pass

Intel PCLA8200 5 360 Linux V3.2.0 Pass

Intel PCLA8205 10 340 Linux V3.1.0 Pass

Novell NE2000Plus-3 5 300 Linux V3.2.0 Pass

SMC 8013WC

Rev. A 10 300 Linux V3.1.0 Pass

ASUSPRO 7000

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(PCI)

ASUS PCI-DEC10-TB+

Rev. B1 Auto Auto Linux V3.2.0 Pass

Accton EN1203

Rev. 01C Auto Auto Linux V3.1.0 Pass

Accton EN1208

Rev. 01A Auto Auto Linux V3.2.0 Pass

Cogent EM960 Auto Auto Linux V3.1.0 Pass

Digital DE450AC

Rev. A01 Auto Auto Linux V3.1.0 Pass

IBM PCI Ethernet

Rev. B2 Auto Auto Linux V3.2.0 Pass

Proteon P1670-EA Auto Auto Linux V3.2.0 Pass

SMC 8432BT

Rev. A Auto Auto Linux V3.2.0 Pass

Thomas-Conrad TC5048

Rev. A Auto Auto Linux V3.1.0 Pass

10.3 Field (stress) Test for Networking Environment

Test Type Linux V3.2.0

Configuration Intel P6-200 + 96MB(EDO 32MB * 2 + 16MB * 2) + 256KB(Internal) + Adaptec AHA-1542CF +

Maxtor MX9217SSN + Panasonic CR-506-B CD-ROM + On-board S3 Trio64V2/DX + Accton

EN1208

1 * Server(Linux V3.2.0)

1 * Server(Linux V3.1.0)

Test Procedure Server(Linux V3.2.0):Run multiple tasks, include NFS test for access via network

Server(Linux V3.1.0):Run multiple tasks, include NFS test for access via network

Result Pass Duration 10 Hours

Test Type Linux V3.1.0

Configuration Intel Pentium II-266 + 64MB(EDO 16MB * 4) + 512KB(Internal) + On-board IDE + Quantum

ST2160AT + Wearnes CDD-1620 CD-ROM + On-board S3 Trio64V2/DX + Digital DE450AC

1 * Server(Linux V3.1.0)

1 * Server(Linux V3.2.0)

Test Procedure Server(Linux V3.1.0):Run multiple tasks, include NFS test for access via network

Server(Linux V3.2.0):Run multiple tasks, include NFS test for access via network

Result Pass Duration 15 Hours

ASUSPRO 7000

11. Banyan Vines Operating System Test

11.1 Software Compatibility Test

O.S. Name Version Publisher Status Hardware Configuration / Hard Disk & Controller

Vines V7.0 Banyan Pass Adaptec AHA-1542CF + Quantum TM3200S + NEC CDR-512 CD-ROM +

On-board S3 Trio64V2/DX + Novell NE2000 Plus-3

11.2 Hardware Compatibility Test

IDE Controller

Card Type IDE H.D.D (Mode) M/S SCSI Controller & CR-ROM O.S. Environment Status

On-board

IDE (PCI)

Quantum TM3840AT (4) MASUS PCI-SC200

Plextor PX-20TSi Vines V7.0 Pass

NEC DSE2100A (4) MASUS PCI-SC200

Plextor PX-20TSi Vines V7.0 Pass

IBM DAQA-33240 (4) MDPT PM2144UW

Pioneer DR-U24X Vines V7.0 Pass

Maxtor 83201A6 (4) MPromise SCSIMAX

NEC CDR-1610A Vines V7.0 Pass

Seagate ST32531A (4) MPromise SCSIMAX

NEC CDR-1610A Vines V7.0 Pass

SCSI Disk Controllers

Card Type Card Model H.D.D. CD-ROM O.S. Environment Status

SCSI

(ISA)

Adaptec AHA-1542CF

Rev.C (BIOS:V2.02) Quantum TM3200S NEC CDR-512 Vines V7.0 Pass

SCSI

(PCI)

ASUS PCI-SC200

Rev.1.2 (BIOS:V4.03) Seagate ST32550N Plextor PX-20TSi Vines V7.0 Pass

DPT PM2124UW

(BIOS:V003.DS) NEC DSE2550S NEC CDR-1410A Vines V7.0 Pass

Promise SCSIMAX

Rev.B (BIOS:V3.07) Fujitsu M2954SYU NEC CDR-1610A Vines V7.0 Pass

Ethernet Adapters

Card Type Card Model Configurations:

IRQ Port Addr. DMA O.S. Environment Status Remark

Ethernet

(ISA)

3COM 3C509BTP

(Plug and Play) 5 360 Vines V7.0 Pass

Novell NE2000Plus-3 5 300 Vines V7.0 Pass

SMC 8013WC

Rev.A 10 300 Vines V7.0 Pass

11.3 Field (stress) Test for Networking Environment

Test Type Vines V7.0

Configuration Intel P6-200 + 64MB(32MB * 2) + 256KB(Internal) + DPT PM2144UW + NEC DSE2550S +

NEC CDR-1410A CD-ROM + On-board S3 Trio64V2/DX + SMC 8013WC

1 * Server (Vines V7.0)

1 * Client (MS-DOS 6.22)

Test Procedure Server (Vines V7.0):Run network monitoring.

Client (MS-DOS 6.22):Run copy file, compare file ....test.

Result Pass Duration 14 Hours

ASUSPRO 7000

PART C. RELIABILITY ENVIRONMENT TEST

1. Power Consumption Test

1.1 Configuration:

• P/I-P65UP8 with Intel Pentium II-233/266 MHz CPU with fan

• DRAM 288MB (64MB *4, 8MB*4), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST32122A 3.5 inch 2112 MB hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• ETASIS EPA-250B 250W ATX power supply

• Microsoft serial mouse

• TECO TE-9516S 14 inch green monitor

1.2 Test Environment

Temperature: 24 °C ~ 28°C

Relative Humidity: 45% ~ 55%

1.3 Test Location

ASUSTek QT Lab.

1.4 Test Result

ITEM

1. System Only Intel PentiumII-233 Intel PentiumII-266 UNIT

Full mode 99.2 96.2 Watts

Doze mode 65.4 64.6 Watts

Standby mode 61.5 60.6 Watts

Suspend mode 60.6 59.6 Watts

2. System & Monitor

Full mode 163.5 160.2 Watts

Doze mode 119.6 119.0 Watts

Standby mode 114.8 114.5 Watts

Suspend mode 113.9 113.3 Watts

ASUSPRO 7000

2. Line Voltage and Frequency Test

2.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 8), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch 4500 MB hard drive * 5

• Seagate ST34371W 3.5 inch 4300 MB hard drive

• Seagate ST32550W 3.5 inch 2500 MB hard drive

• IBM DCAS-32160 3.5 inch 2100 MB hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• EMACS RPD-5400F 400W ATX power supply

• CHENBRO Server case A9661/A9671

• Microsoft serial mouse

2.2 Test Software

MicroSoft Qaplus 5.51 Test Program

2.3 Test Specifications

Condition Voltage & Frequency Condition Voltage & Frequency

185V / 47Hz 9170V / 47Hz

285V / 53Hz 10 170V / 53Hz

385V / 57Hz 11 170V / 57Hz

485V / 63Hz 12 170V / 63Hz

5132V / 47Hz 13 264V / 47Hz

6132V / 53Hz 14 264V / 53Hz

7132V / 57Hz 15 264V / 57Hz

8132V / 63Hz 16 264V / 63Hz

Note : Each test condition combines a voltage limit with a frequency limit.

2.4 Test Result

Condition Voltage & Frequency Sample 1

185V / 47Hz Pass

285V / 53Hz Pass

385V / 57Hz Pass

485V / 63Hz Pass

5132V / 47Hz Pass

6132V / 53Hz Pass

7132V / 57Hz Pass

8132V / 63Hz Pass

9170V / 47Hz Pass

10 170V / 53Hz Pass

11 170V / 57Hz Pass

12 170V / 63Hz Pass

Condition Voltage & Frequency Sample 1

13 264V / 47Hz Pass

14 264V / 53Hz Pass

15 264V / 57Hz Pass

ASUSPRO 7000

16 264V / 63Hz Pass

3. DC Margin Test

3.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 288MB (64MB * 4 + 8MB * 4), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST32122A 3.5 inch 2112 MB hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• ETASIS EPA-250B 250W ATX power supply

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

3.2 Test Environment

Temperature: 24 °C ~ 28 ° C

Relative Humidity: 45% ~ 55%

3.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

3.4 Test Location

ASUSTeK QT Lab.

3.5 Testing Result

Item Test Condition Result

1+5 V + 5 % +12V + 5 % Pass

2+5 V + 5 % +12V - 4 % Pass

3+5 V - 4 % +12V + 5 % Pass

4+5 V - 4 % +12V - 4 % Pass

ASUSPRO 7000

4. Power Line Disturbance Test

4.1 Test Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 32MB (32MB * 1), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch 4500 MB hard drive * 5

• IBM DHEA-36480 3.5 inch 6400 MB hard drive

• Seagate ST32171W 3.5 inch 2100 MB hard drive

• Quantum LPS540S 3.5 inch 540 MB hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

4.2 Test Software

Micro Soft Qaplus 5.51 Test Program

4.3 Test Location

ASUSTek QT Lab

4.4 Test Specifications

1. Condition 1

a. An under voltage of 10% below any of the nominal input AC voltages applied for 2

seconds, repeated 10 times with a 10% duty cycle.

b. An under voltage of 100% during one half cycle repeated 10 times with a 1% duty cycle.

c. An over voltage of 15% above the any of the nominal AC voltage applied for one second,

repeated 10 times with a 10% duty cycle.

2. Condition 2

a. A complete AC line outage for 6 cycles.

b. A 65% under voltage lasting for 30 cycles.

c. A complete AC line outage for 30 cycles.

3. Surge Test

132 V to 150V for 0.5sec , back to 132 V at 60Hz

4. Sag Test

90 V to 88 V for 0.5sec , back to 90 V at 60Hz

Note:

a. For test condition 1,3,4 the EUT must operate normally.

b. For test condition 2, the EUT shall sustain no physical damage.

4.5 Test Result

Sample No. Qaplus 5.51

Condition 1 Condition 2 Surge Test Sag Test

No.1 Pass Pass Pass Pass

5. Power Supply inrush current Test

5.1 Test Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 8), Cache 512KB (Internal)

ASUSPRO 7000

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch 4500 MB hard drive * 5

• IBM DHEA-36480 3.5 inch 6400 MB hard drive

• Seagate ST32171W 3.5 inch 2100 MB hard drive

• Quantum LPS540S 3.5 inch 540 MB hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

5.2 Test Software

Micro Soft Dos 6.22 Test Program

5.3 Test Location

ASUSTek QT Lab

5.4 Test Specifications

The maximum inrush current is under cold start and warm start to measure the AC input

current, where the measured criteria is as below.

Warm start should not damage the power supply or cause the input fuse blow.

Cold start should not exceed to the rating of power supply.

5.5 Test Result

Test Inrush Current

Condition Cold Start Warm Start

115V 60Hz 230V 60Hz 115V 60Hz 230V 60Hz

Specification 50 Amp 100 Amp No Damage No Damage

Test Data 21.22 A 45.0 A 10.38 A 47.17 A

Test Result Pass Pass Pass Pass

6. Temperature / Humidity

6.1 Test Configuration:

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 8), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch 4500 MB hard drive * 5

• Seagate ST34371W 3.5 inch 4300 MB hard drive

• Seagate ST32550W 3.5 inch 2500 MB hard drive

ASUSPRO 7000

• IBM DCAS-32160 3.5 inch 2100 MB hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

6.2 Test Environment

Temperature: 10°C ~ 50°C

Relative Humidity: 20% ~ 85%

6.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

6.4 Test Period Result:

Step Temperature

(oC) Relative Humidity

(%) Time

(Hour:Minutes) Status

1 10 20 00:30 Pass

2 10 20 20:00 Pass

3 50 20 00:30 Pass

4 50 85 08:00 Pass

5 50 85 12:00 Pass

6 25 35 00:30 Pass

ASUSPRO 7000

7. Thermal Measurement

Please see Thermal Curve Figure1,Figure2 which shows all the thermal curves from different

measuring points, when the machine was warmed up and the temperature became stable, all

functions are working perfectly during the test.

7.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB *8), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch 4500 MB hard drive*5

• Seagate ST34371W 3.5 inch 4300 MB hard drive

• Seagate ST32550W 3.5 inch 2500 MB hard drive

• IBM DCAS-32160 3.5 inch 2100 MB hard drive

• Back Plane Board (DA-BP4 serial) *2 for 4 HDD In Each

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP0350-1 350W ATX power supply

• Elan Vital Server case S-50

• Microsoft serial mouse

• FRX FRX-256L 14 inch color monitor

• Place in KSON Tech. THS-D4L+ - 100 LabTester for different temperature and humidity

7.2 Test Environment

Temperature: 35 °C

Relative Humidity: 80 %

7.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

7.4 Testing Point

Channel No. Step Channel Temperature

CH1-1 (TP1) Ambient temperature 56.5°C

CH1-2 (TP2) FD3055(Q210) 65°C

CH1-3 (TP3) Adaptec AIC-7880P(U47) 66.1°C

CH1-4 (TP4) NEC K2941(Q5) 49.3°C

CH1-5 (TP5) FD3055(Q210A) 65.8°C

CH1-6 (TP6) Pentium II-266 CPU1 69.8°C

CH1-7 (TP7) Pentium II-266 CPU2 75.7°C

CH1-8 (TP8) Intel i960 74.2°C

CH1-9 (TP9) SYM BIOS Logic(U66) 62.1°C

CH1-10 (TP10) SEC KM44V16104AS-6 SDRAM 1 58.5°C

CH1-11 (TP11) SEC KM44V16104AS-6 SDRAM 2 60.8°C

CH1-12 (TP12) Intel SB82442FX(U6) 59.9°C

CH1-13 (TP13) Intel SB82441FX 70.1°C

CH1-14 (TP14) Winbond W83977TF-A(U23) 66.4°C

CH1-15 (TP15) S82093AA(U28) 61.9°C

CH1-16 (TP16) Intel SB82371SB(U29) 72.5°C

ASUSPRO 7000

Channel No. Step Channel Temperature

CH1-17 (TP17) S3 Trio64V2/DX(U7) 72.3°C

CH1-18 (TP18) Power 1 51.6°C

CH2-2 (TP2) Power 2 56°C

CH2-3 (TP3) SCSI HDD 1 52.5°C

CH2-4 (TP4) SCSI HDD 2 57.2°C

CH2-5 (TP5) SCSI HDD 3 66.1°C

CH2-6 (TP6) SCSI HDD 4 67.1°C

CH2-7 (TP7) SCSI HDD 5 67.1°C

CH2-8 (TP8) SCSI HDD 6 68.8°C

CH2-9 (TP9) SCSI HDD 7 70.1°C

CH2-10 (TP10) SCSI HDD 8 67.3°C

ASUSPRO 7000

8. Humidity Cycle Test

8.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 4 + 128MB * 2), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

8.2 Test Environment

Temperature: 35 °C

Relative Humidity: 90 %

8.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

8.4 Test Location

ERSO (Electronics Research & Service Organization)

8.5 Testing Result

Operating:

Step Temperature (oC) Relative Humidity

(%) Time

(Hour:Minutes) Status

1 35 20 1:30 Pass

2 35 20 2:00 Pass

3 35 80 3:00 Pass

4 35 80 4:00 Pass

5 40 50 1:30 Pass

6 40 50 4:00 Pass

7 40 85 2:00 Pass

8 40 85 12:00 Pass

9 25 50 2:00 Pass

Non-operating:

Step Temperature (oC) Relative Humidity

(%) Time

(Hour:Minutes) Status

1 60 20 1:30 Pass

2 60 20 2:00 Pass

3 60 80 3:00 Pass

4 60 80 4:00 Pass

5 60 50 1:30 Pass

6 60 50 4:00 Pass

7 60 90 2:00 Pass

8 60 90 12:00 Pass

9 25 50 2:00 Pass

ASUSPRO 7000

9. Altitude Test

9.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 4 + 128MB * 2), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

9.2 Test Environment

Temperature: 24°C ~ 28°C

Relative Humidity: 45% ~ 55%

9.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

9.4 Test Location

ERSO (Electronics Research & Service Organization)

9.5 Testing Result

Condition 10000 feet 15000 feet

Operation Pass -

Non-operation -Pass

10. Vibration Test

10.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 4 + 128MB * 2), Cache 512KB (Internal)

ASUSPRO 7000

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

10.2 Test Environment

Temperature: 24°C ~ 28°C

Relative Humidity: 25% ~ 55%

10.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

10.4 Test Location

ERSO (Electronics Research & Service Organization)

10.5 Testing Result

Operating (SINE Mode):

No. Condition Frequency Amplitude Duration Dwell Endurance

Unit Hertz Peak - Peak Minutes Minutes Cycle

1. Range 1 5 ~ 18 0.38mm 2 15 1 Cycle &

1 octv/min

2. Range 2 18 ~ 250 0.25 G 4 15

No. Condition (SINE Mode) Function Test Physical

1. X axis Pass Pass

2. Y axis Pass Pass

3. Z axis Pass Pass

ASUSPRO 7000

11. Acoustic Noise Test

11.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 4 +128MB * 2), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

11.2 Test Environment

Temperature: 24°C ~ 28°C, Relative Humidity: 25% ~ 55%

11.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

11.4 Test Location

ERSO (Electronics Research & Service Organization)

11.5 Test Location

Operation position: under 50 dB

Non-Operation position: under 50 dB

11.6 Testing Result

1. Operator Position: BACKGROUND NOISE LEVEL: 17.6 dB

Condition Noise Level (dB) LpA

60cm IDLE FDD WDD

IDE WDD

SCSI CD-ROM WIN95 Unit

Front 46.9 47.2 47.2 48.3 47.2 47.1 dB

Left 46.8 46.4 46.8 48.6 46.2 46.3 dB

Back 48.8 49.0 49.2 49.4 49.0 49.0 dB

Right 46.6 46.9 47.3 48.5 46.5 46.6 dB

Result Pass Pass Pass Pass Pass Pass -

2. Bystander Position: BACKGROUND NOISE LEVEL: 17.6 dB

Condition Noise Level (dB) LpA

100cm IDLE FDD WDD

IDE WDD

SCSI CD-ROM WIN95 Unit

Front 44.8 45.2 45.0 45.7 44.8 44.6 dB

Left 43.7 44.4 45.2 46.2 43.6 43.4 dB

Back 46.8 47.2 46.5 47.6 46.4 46.4 dB

Right 44.2 44.5 44.6 46.2 44.2 44.4 dB

Result Pass Pass Pass Pass Pass Pass -

ASUSPRO 7000

12. Shock Test

12.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 4 + 128MB * 2), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

12.2 Test Environment

Temperature: 24°C ~ 28°C

Relative Humidity: 25% ~ 55%

12.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

12.4 Test Location

ERSO (Electronics Research & Service Organization)

12.5 Testing Result

Operation Shock Test

Condition X axes Y axes Z axes

10 G 15 ms Half-sine Pass Pass Pass

Non-Operation Shock Test

Condition X axes Y axes Z axes

90 G 3 ms Half-sine Pass Pass Pass

ASUSPRO 7000

13. Incline Impact Test

13.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 4 + 128MB * 2), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

13.2 Test Environment

Temperature: 24°C ~ 28°C

Relative Humidity: 25% ~ 55%

13.3 Test Software

Running CMD multi-tasking test programs under Windows NT Server V4.0

13.4 Test Location

CETRA / (Packaging Research Laboratory)

13.5 Testing Gross Weight

Cross Weight: 50 KG

13.6 Testing Result

Incline Impact Test

Test Condition Front Rear Left Right Top Bottom

150 cm high 10 degree Pass Pass Pass Pass Pass Pass

ASUSPRO 7000

14. Appearance Check

14.1 Testing Configuration

• P/I-P65UP8 with Intel PentiumII-266 MHz CPU with fan

• DRAM 512MB (64MB * 4 + 128MB * 2), Cache 512KB (Internal)

• On-board IDE controller

• NEC FD-1231H 3.5 inch 1.44 MB floppy drive

• Seagate ST34501W 3.5 inch hard drive

• On-board S3 Trio64V2/DX PCI VGA with 1MB DRAM

• Elan Vital GP 0350-1 350W ATX power supply

• Elan Vital Aegis S-50 Super Server Case

• Microsoft serial mouse

• TECO TE9516S 14 inch green monitor

14.2 Test Environment

Temperature: 24°C - 28°C

Relative Humidity: 45% - 55%

14.3 Test Location

ASUSTek QT Lab

14.4 Test Result

Check Item Contain Result Remark

Gap Check panel gap, housing gap, device gap…Pass -

Scratch Check housing color, sharp edge …Pass -

Internal Assemble Check cable, device match, SPS match, …Pass -

External assemble Check Panel , cover, LED, panel vent, rubber

foot…Pass -

AP7000

Navigation menu

Versions of this User Manual:

Views

Navigation
