DS12007 Rev. 11 - 2 1 of 2 BAV99
www.diodes.com ã Diodes Incorporated
BAV99
DUAL SURFACE MOUNT SWITCHING DIODE
·Case: SOT-23, Molded Plastic
·Case material - UL Flammability Rating
Classification 94V-0
·Moisture sensitivity: Level 1 per J-STD-020A
·Terminals: Solderable per MIL-STD-202,
Method 208
·Also Available in Lead Free Plating
(Matte Tin Finish). Please See
Ordering Information, Note 4, on Page 2
·Polarity: See Diagram
·Marking: KJE (See Page 2)
·Weight: 0.008 grams (approx.)
·Ordering Information: See Page 2
Mechanical Data
A
E
JL
TOP VIEW
M
BC
H
G
D
D
K
Features
Characteristic Symbol Value Unit
Non-Repetitive Peak Reverse Voltage VRM 100 V
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
VRRM
VRWM
VR
75 V
RMS Reverse Voltage VR(RMS) 53 V
Forward Continuous Current (Note 1) IFM 300 mA
Non-Repetitive Peak Forward Surge Current @ t = 1.0ms
@ t = 1.0s IFSM 2.0
1.0 A
Power Dissipation (Note 1) Pd350 mW
Thermal Resistance Junction to Ambient Air (Note 1) RqJA 357 °C/W
Operating and Storage Temperature Range Tj,T
STG -65 to +150 °C
Maximum Ratings @ TA= 25°C unless otherwise specified
Notes: 1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website
at http://www.diodes.com/datasheets/ap02001.pdf.
2. Short duration test pulse used to minimize self-heating effect.
Characteristic Symbol Min Max Unit Test Condition
Reverse Breakdown Voltage (Note 2) V(BR)R 75 ¾VIR = 2.5mA
Forward Voltage (Note 2) VF¾
0.715
0.855
1.0
1.25
V
IF = 1.0mA
IF = 10mA
IF = 50mA
IF = 150mA
Reverse Current (Note 2) IR¾
2.5
50
30
25
mA
mA
mA
nA
VR = 75V
VR = 75V, Tj = 150°C
VR = 25V, Tj = 150°C
VR = 20V
Total Capacitance CT¾2.0 pF VR = 0, f = 1.0MHz
Reverse Recovery Time trr ¾4.0 ns IF = IR = 10mA,
Irr = 0.1 x IR,R
L = 100W
Electrical Characteristics @ TA= 25°C unless otherwise specified
·Fast Switching Speed
·Surface Mount Package Ideally Suited for
Automatic Insertion
·For General Purpose Switching Applications
·High Conductance
·Available in Lead Free Version
SOT-23
Dim Min Max
A0.37 0.51
B1.20 1.40
C2.30 2.50
D0.89 1.03
E0.45 0.60
G1.78 2.05
H2.80 3.00
J0.013 0.10
K0.903 1.10
L0.45 0.61
M0.085 0.180
a0°8°
All Dimensions in mm
SPICE MODEL: BAV99
DS12007 Rev. 11 - 2 2 of 2 BAV99
www.diodes.com
0.1
1
10
100
1000
10000
020 40 60 80 100
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
Fig. 2 Typical Reverse Characteristics
I , INSTANTANE
O
US REVERSE CURRENT (nA)
R
T = -40ºC
A
T = 25ºC
A
T = 75ºC
A
T = 125ºC
A
T = 150ºC
A
T = 0ºC
A
0.1
1
0.01
0.001
01.
5
1.0
0.5
I,INSTANTANE
O
US F
O
RWARD CURRENT (A)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
Fig. 1 Forward Characteristics
T = -40ºC
A
T = 150ºC
A
T = 75ºC
AT = 25ºC
A
T = 0ºC
A
0.0
0.2
0.4
0.6
0.8
1.8
1.6
1.4
1.2
1.0
2
.
0
010 20 40
30
C , TOTAL CAPACITANCE (pF)
T
V , REVERSE VOLTAGE (V)
R
Fi
g
.3 T
y
pical Capacitance vs. Reverse Volta
g
e
f= 1.0MHz
Month Jan Feb March Apr May Jun Jul Aug Sep Oct Nov Dec
Code 1234567
89 OND
Date Code Key
KJE = Product Type Marking Code
YM = Date Code Marking
Y = Year ex: N = 2002
M = Month ex: 9 = September
KJE
YM
Marking Information
Notes: 3. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
4. For lead free terminal plating part number, please add "-F" suffix to part number above. Example: BAV99-7-F.
Device Packaging Shipping
BAV99-7 SOT-23 3000/Tape & Reel
Ordering Information (Note 3 & 4)
0
50
100
150
200
250
25050
75 100 125 150
P , POWER DISSIPATION (mW)
d
T , AMBIENT TEMPERATURE (°C)
A
Fi
g
. 4 Power Deratin
g
Curve
300
3
5
0
Year 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009
Code LMN P R S T UV W
