RESTORE
General Safety Information
IMPORTANT: Please read all the instructions
before operating your BRUNTON Portable
Power product.
This manual contains important information
about the BRUNTON Portable Power assembly,
use, and maintenance of the product, Keep this
manual for future reference. Be sure to read
this manual completely before using the
Restore to prevent misuse of the products anc
possible injury, fire, property damage or death.
Particular attention should be paid to the
information accompanied by the safely alert
words WARNING, IMPORTANT and CAUTION.
WARNING - ONLY use this product with the
supplied charging cables and accessories.
Use of an attachment not supplied by
BRUNTON may result in a risk of fire,
electric shock or injury and will void your
warranty on the product.
CAUTION - Do not submerge the unit in
water or use the unit after it has been
exposed to water!
CAUTION — Do not open the BRUNTON
Portable Power unit —there are no
serviceable parts inside.
Check all cables carefully before use —
cables exposed to extreme heat, sharp
edges, water or petroleum-based products
can become damaged. Do not use any cable
that has exposed wires! Contact BRUNTON
customer service at 1-800¬443-4871 for
replacement of any damaged product parts
before use or the warranty will be voided
on your unit.
CAUTION: Check for compatibility and fit of
adaptors before using the unit to charge
electronic devices — improperly seated
adaptors can be a shock ha2ard and may
damage the electronic device.
CAUTION: The USB output from this unit is
built for USB 2.0 compatible 5V units. Using
your BRUNTON Restore on older electronics
could cause damage to units and/or the
persons operating them.
WARNING – Explosion Hazard! DO NOT
incinerate any BRUNTON Portable Power
device.
WARNING – DO NOT use any BRUNTON
Portable Power device to power medical
equipment, life support or other critical
devices.
Your BRUNTON Portable Power product
should not be disposed of like ordinary
refuse. Please contact your local municipal
or civil authority for instructions on
correctly disposing of a Lithium Polymer
Battery.
IMPORTANT – only use a damp rag to clean
your BRUNTON Portable Power unit. Use of
chemicals can harm the unit and will void
the warranty.
Features and Locations
Product Specifications
Battery Type: Lithium Polymer
Solar Panel Type: (2) 100mA Polycrystalline
Output Voltage: 5V (USB 2.0 Compatible) with
auto shut-off feature.
Output Current: 1000 mA
Output Wattage: 5W
Battery Capacity: 8.1 Wh
Input Port: Standard USB 2.0 (Car Charge
adaptor provided with unit)
Output Port: Mini USB (Micro USB adaptor
provided with unit
Dimensions: 3”x 5.75” x 1.13”
Weight: 7.2 oz.
Use Temperature: Usable from -10°F to 120°F
Certification: CE, RoHS
Estimated Time to Charge:
Restore, via Car Charger - 2 hours
Restore, via USB 2.0 - 4 hours
Cell phone, via Restore 1-2 hours
MP3 player, via Restore 1-2 hours
GPS via Restore 1-2 hours
Camera, via Restore 1-2 hours
Note: Charge times are approximate and will
vary depending on specific device used and
solar conditions.
Determining the level of energy in your
Brunton Restore:
The BRUNTON Restore unit comes with easily
understood L.E.D. readout to show how much
energy your portable power item is holding.
Press the power button to turn on the unit.
When you do this, the blue L.E.D. display on the
surface of the unit will light up.
When your BRUNTON Restore is in use, a green
light on the unit will tell you that the unit is
charging. A red light from the power button
means that the unit is being used to power
another electronic device.
Traveling with your Portable Power Item
Please contact your airline prior to packing your
BRUNTON Portable Power device. There are
certain airlines that restrict the transport of
battery items on their planes or request that
certain safety precautions be made prior to
boarding the aircraft.
Charging the Unit
The BRUNTON Restore unit needs to be charged
before it is used. It can be charged via the
vehicle-adapter, the USB 2.0 connector or using
solar power.
Charging the unit via the male vehicle-adaptor:
1. Plug the vehicle-adaptor into the USB 2.0
connector from the BRUNTON Restore unit.
2. Connect the male vehicle-adaptor into the
vehicle cigarette lighter adaptor.
3. Leave the unit in place until fully charged.
4. Unplug the vehicle –adaptor and unplug the
USB cable from the adaptor.
5. Return the USB 2.0 plug on the charging
cable to its place on the unit.
Charging the unit via the USS 2.0 cable:
1. Unplug the USB 2.0 cable from the side of
the BRLJNTON Restore unit.
2. Make sure the Mini USB plug is firmly
connected to the BRUNTON Restore.
3. Plug the USB 2.0 into a USB jack on your
computer.
4. Leave the unit in place until fully charged.
5. Disconnect the unit from the computer.
Number of blue
LE.D.s lit
Amount of power
remaining
One
0.0% 24.9%
Two
25.0%-49.9%
Three
50.0% 74.9%
Four
75.0% to 100%
6. Return the USB 2.0 plug on the charging
cable to its place on the unit.
IMPORTANT — the power output provided by
USB Hubs will be determined by the model
Many are not independently powered and may
not provide enough power to charge in the time
estimates provided, if at all. We do not
recommend this use for our Portable Power
items. Plug your unit into a USB 2.0 outlet on
your computer whenever possible.
Usage Instructions
Charging with the BRUNTON Restore
cable:
1. Fully charge your BRUNTON
Restore unit.
2. Unplug the Mini USB connector
from the side of the unit.
3. Plug the Mini USB connector into
the electronic device needing
power. Micro USS adaptor provided
with the unit can be used if
needed.
4. Wait until the electronic device is
fully charged.
5. Unplug the Mini USB cable from
the electronic device and reseat it
in the BRUNTON Restore.
6. Recharge unit as necessary.
Charging with a USB cable that was
supplied with your 5V electronics
1. Fully charge your BRUNTON Restore
unit.
2. Unplug the Mini USO connector from
the side of the unit.
3. Plug the USB cable supplied with your
portable electronic device into the USB
port on the BRVNTON Restore. Plug
the other end of your cable into the
electronic device needing power.
4. Wait unit the electronic device is fully
charged.
5. Unplug the cable from the electronic
device and from the BRUNTON
Restore.
6. Reseat the mini USE connector into
the port on the BRUNTON Restore.
7. Recharge unit as necessary.
Note: if you need another adaptor to use
with your BRUNTON portable power
product, please visit our website at
www.brunton.com.
Brunton limited warranty
BRUNTON warrants this product to be free
of defects in materials and workmanship
for a period of one year. This warranty
extends to the original purchaser for one
year from the date of purchase.
This warranty is void and a charge for r
repair will be made if the product has
been damaged by negligence, accident or
mishandling, or has not been operated in
accordance with standard operating
procedures, or it the product was altered
or repaired by other than a BRUNTON
repair facility.
This warranty gives you specific legal
rights, and you also have rights which
vary from state to state. No other
warranty, expressed or implied applies to
this BRUNTON product. Nor is any person
or company authorized to assume any
other warranty for BRUNTON. BRUNTON
does not assume any responsibility for
any consequential damage occasioned by
this product. Should the product prove
defective, contact BRUNTON and you will
be provided with a Return Authorization
Number (RA#) Send a copy of your proof
of purchase, the RA#, a short description
of the problem and the product to
BRUNTON at the following address.
BRUNTON suggests insuring the product in
case of damage or loss in shipment.
