HP Color LaserJet CM6040/CM6030 User Guide – ENWW MFP CM6040 C01449477

User Manual: MFP CM6040

Open the PDF directly: View PDF PDF.
Page Count: 94

HP Color LaserJet CM6040/CM6030 MFP
Series
Analog Fax Accessory 300 Fax Guide
Copyright and License
© 2008 Copyright Hewlett-Packard
Development Company, L.P.
Reproduction, adaptation, or translation
without prior written permission is prohibited,
except as allowed under the copyright laws.
The information contained herein is subject
to change without notice.
The only warranties for HP products and
services are set forth in the express warranty
statements accompanying such products
and services. Nothing herein should be
construed as constituting an additional
warranty. HP shall not be liable for technical
or editorial errors or omissions contained
herein.
Edition 1, 04/2008
Part number: Q3701-91208
Trademark Credits
Microsoft® and Windows® are U.S.
registered trademarks of the Microsoft
Corporation.
All products mentioned herein may be
trademarks of their respective companies.
Local country/region laws may prohibit the
use of this product outside of the countries/
regions specified. It is strictly forbidden by
law in most countries/regions to connect
nonapproved telecommunications
equipment (fax machines) to public
telephone networks.
ENERGY STAR® and the ENERGY STAR®
logo are U.S. registered marks of the United
States Environmental Protection Agency.
Table of contents
1 Setup
Parts included with the fax accessory .................................................................................................. 2
Verifying fax operation .......................................................................................................................... 3
Required fax settings ............................................................................................................................ 4
Fax Configuration Wizard .................................................................................................... 4
Accessing fax settings menu ............................................................................................... 4
Set or verify the date and time ............................................................................................. 4
Set, verify, or change the MFP/fax accessory country/region ............................................. 5
Set the fax header ............................................................................................................... 5
2 Set fax settings
Remote fax configuration ..................................................................................................................... 8
Web browser ........................................................................................................................ 8
HP Web Jetadmin ................................................................................................................ 8
HP MFP Digital Sending Software Configuration Utility ....................................................... 9
Send fax settings ................................................................................................................................ 10
Set the dial tone detection ................................................................................................. 10
Set the overlay header (outgoing faxes) ............................................................................ 10
Set the dialing mode .......................................................................................................... 10
Set a dialing prefix ............................................................................................................. 11
Set the redial rules ............................................................................................................. 11
Set redial-on-busy ............................................................................................. 11
Set redial-on-no-answer .................................................................................... 12
Set redial interval .............................................................................................. 12
Set the outgoing fax resolution .......................................................................................... 13
Set billing codes ................................................................................................................. 13
Set the JBIG compression mode ....................................................................................... 14
Change the sharpness setting ........................................................................................... 14
Change the background setting ......................................................................................... 14
Change the light/dark setting ............................................................................................. 15
Activate Fax Number Confirmation .................................................................................... 15
Activate Fax Number Speed Dial Matching ....................................................................... 15
Receive fax settings ........................................................................................................................... 17
Set rings-to-answer ............................................................................................................ 17
ENWW iii
Stamp received faxes (incoming faxes) ............................................................................. 17
Set fit-to-page .................................................................................................................... 17
Set the paper tray .............................................................................................................. 18
Set the destination bin ....................................................................................................... 18
Blocking incoming faxes .................................................................................................... 18
Create a blocked-fax list .................................................................................... 19
Remove numbers from the blocked-fax list ....................................................... 19
Clear all numbers from the blocked-fax list ....................................................... 19
Initiate polling receive ........................................................................................................ 19
Changing notification settings ............................................................................................ 20
Set the error correction mode ............................................................................................................. 21
Set the modem volume ...................................................................................................................... 22
Set the ringer volume ......................................................................................................................... 23
3 Use Fax
Fax feature screen ............................................................................................................................. 26
Status message bar ........................................................................................................................... 28
Send a fax .......................................................................................................................................... 29
Send a fax - enter number(s) manually ............................................................................. 29
Send a fax using speed dial ............................................................................................... 30
Sending a fax using one touch speed dial ......................................................................... 31
Search a speed-dial list by name ....................................................................................... 32
Sending a fax using phone book numbers ........................................................................ 32
DSS fax phone book search .............................................................................................. 33
Canceling a fax ................................................................................................................................... 34
Cancel the current fax transmission .................................................................................. 34
Cancel all pending faxes .................................................................................................... 34
Receiving faxes .................................................................................................................................. 35
Creating and deleting speed dial lists ................................................................................................. 36
Create a speed dial list ...................................................................................................... 36
Delete a speed dial list ....................................................................................................... 36
Delete a single number from the speed dial list ................................................................. 36
Add a number to an existing speed dial list ....................................................................... 37
Assigning speed dial lists to one-touch keys ...................................................................................... 38
Clear or reassign speed dial lists to one-touch keys ......................................................... 38
Voice Calls and Retries ...................................................................................................................... 39
Fax Call Report .................................................................................................................. 39
Fax Activity Log ................................................................................................................. 39
T.30 Report ........................................................................................................................ 39
Secure settings ................................................................................................................................... 40
Change your PIN ............................................................................................................... 40
Set fax forwarding .............................................................................................................................. 41
Scheduling fax printing (memory lock) ............................................................................................... 42
iv ENWW
Fax-printing behavior ......................................................................................................... 42
Enable or disable the schedule for printing of faxes .......................................................... 42
Create a fax printing schedule ........................................................................................... 43
Using Fax over VoIP networks ........................................................................................................... 45
4 Solve fax problems
Is your fax set up correctly? ............................................................................................................... 48
What type of phone line are you using? ............................................................................ 48
Are you using a surge-protection device? ......................................................................... 48
Are you using a phone company voice-messaging service or an answering
machine? ........................................................................................................................... 48
Checking fax accessory status ........................................................................................................... 49
Fax feature is not operating ................................................................................................................ 50
General fax problems ......................................................................................................................... 51
Receiving fax problems ...................................................................................................................... 52
Sending fax problems ......................................................................................................................... 54
Error codes ......................................................................................................................................... 55
Fax error messages ........................................................................................................................... 56
Send-fax messages ........................................................................................................... 57
Receive-fax messages ...................................................................................................... 58
Fax logs and reports ........................................................................................................................... 59
Printing the fax call report (include thumbnail) ................................................................... 59
To schedule fax call report printing ................................................................... 60
Printing the fax activity log ................................................................................................. 60
Printing the billing code report ........................................................................................... 61
Clearing the fax activity log and billing code report ........................................................... 61
Printing the blocked fax list report ...................................................................................... 61
Printing the speed dial list report ....................................................................................... 62
Service settings .................................................................................................................................. 63
Firmware upgrades ............................................................................................................................ 65
Appendix A Service and support
Hewlett-Packard limited warranty statement ...................................................................................... 68
HP Customer Care ............................................................................................................................. 69
World Wide Web ................................................................................................................ 69
E-mail ................................................................................................................................. 69
Phone ................................................................................................................................ 69
Appendix B Specifications
Fax accessory product specifications ................................................................................................. 72
Replacement parts and accessories .................................................................................................. 73
Appendix C Regulatory Information
ENWW v
Environmental Product Stewardship Program ................................................................................... 76
Declaration of conformity .................................................................................................................... 77
US Federal Communications Commission ......................................................................................... 78
FCC Part 15 Compliance Statement ................................................................................. 78
FCC Part 68 Telecom ........................................................................................................ 78
Telephone Consumer Protection Act (US) ........................................................................ 79
Canadian Department of Communications ........................................................................................ 80
Canadian Limitations Notice .............................................................................................. 80
Other regulatory information ............................................................................................................... 81
Regulatory information for EU countries/regions ............................................................... 81
New Zealand Telecom Warning Notice ............................................................................. 81
South African Notice .......................................................................................................... 82
TAIWAN BSMI Class A Warning ....................................................................................... 82
Index ................................................................................................................................................................... 83
vi ENWW
1Setup
The HP LaserJet MFP Analog Fax Accessory 300 enables the HP multifunction product (MFP) to
function as a standalone analog fax machine.
This guide describes the fax functions of this product in the following sections:
●Parts included with the fax accessory
●Verifying fax operation
●Required fax settings
In addition, this guide provides information on product specifications and regulatory information.
NOTE: In addition to the analog fax feature, the MFP also supports LAN faxing. LAN faxing is managed
by the HP MFP Digital Sending Software Configuration Utility which is a separate product and is not
covered in this document. For information about LAN faxing, see the HP MFP Digital Sending Software
User Guide or the HP MFP Digital Sending Software Support Guide. If both the analog fax accessory
and the LAN fax are installed, only one fax can be enabled at a time.
You should save this guide so that you can refer back to instructions on specific fax features.
NOTE: If the MFP came with the fax accessory installed, you need to remove the fax connection cover,
connect the phone cord, and then perform the initial fax configuration that is also described in this
chapter. The fax connection cover is located on the phone connector on the formatter rear panel.
ENWW 1
Parts included with the fax accessory
The following components are included with the fax accessory:
●Fax guide (this document) (on CD)
●Send Fax Driver and Send Fax Driver Guide (on CD)
●Phone cord(s) (cords vary depending on the country/region)
NOTE: The Send Fax Driver allows a user to send a fax directly from their PC to a network connected
MFP. Installation of this driver is optional. (See Send Fax Driver Guide on the CD for further
instructions).
2 Chapter 1 Setup ENWW
Verifying fax operation
When the fax accessory is installed and operating correctly, the fax icon displays on the MFP control
panel. If the fax accessory has just been installed but has not been configured, the fax icon is grayed-
out and (depending on the MFP model) may have Not Configured written across it. If this occurs, the
fax accessory needs to be configured, see Required fax settings on page 4.
ENWW Verifying fax operation 3
Required fax settings
NOTE: A Fax Configuration Wizard is available to guide you through the steps to make the required
fax settings. For more information, see Fax Configuration Wizard on page 4.
After the fax accessory is installed, you must configure certain settings before you can use the
accessory. If these settings are not configured, the fax icon is grayed-out. These settings include:
●Date and time
●Location (country/region)
●Fax header (phone number and company name)
This information is used in the fax header, which is printed on all outgoing faxes.
NOTE: When first installed, the fax accessory might read some of these settings from the MFP;
therefore, a value may already be set. You should check the values to verify that they are set and correct.
NOTE: In the U.S. and many other countries/regions, setting the date, time, location, phone number,
and company name is a legal requirement for fax.
Fax Configuration Wizard
The Fax Configuration Wizard guides users through a step-by-step procedure to configure fax settings
that are required to use the fax feature. If the settings are not configured, the fax feature is disabled.
The following is a list of fax settings that are configured using the wizard:
●Location (country/region)
●Fax phone number
●Company name
This information is used in the fax header, which is printed on all outgoing faxes.
The wizard starts when the device is turned on. You can choose to use the wizard or exit the wizard to
configure the settings at a later date.
NOTE: The settings configured using the wizard on the control panel override any settings made in
the embedded Web server.
Accessing fax settings menu
The required fax settings are set by accessing the appropriate menu for your MFP.
NOTE: If the fax menu settings do not appear in the menu listing, LAN fax may be enabled. When
LAN fax is enabled, the analog fax accessory is disabled and the fax menu does not display. Only one
fax feature, either LAN fax or analog fax, can be enabled at a time. The fax icon displays for either fax
feature. If you wish to use analog fax when LAN fax is enabled, use the HP MFP Digital Sending Software
Configuration Utility to disable LAN fax.
Set or verify the date and time
The date and time setting for the fax accessory is the same value as the MFP date and time setting. If
this is the first time you are powering up the MFP, you will prompted for this information.
4 Chapter 1 Setup ENWW
To verify or change the date and time settings, complete the following steps.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup to display the setup settings menu and then touch Fax Setup.
3. Touch Required Settings.
4. Select the date format and then enter the date.
5. Select the time format and then enter the time.
6. Touch Save to accept the settings.
Set, verify, or change the MFP/fax accessory country/region
The location setting identifies the country/region where the MFP/fax accessory is located. This setting
also sets the date/time format and minimum/maximum rings-to-answer range for the country/region.
Because this setting is a legal requirement in some countries/regions, it must be set for the fax accessory
to operate. If this is the first time you are powering up the printer, you will be prompted for this information.
Set, verify, or change the MFP/fax country/region
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup to display the setup settings menu.
3. Touch Fax Setup to display the Fax Setup menu and touch Required Settings.
4. Touch Location to display the list of countries/regions.
5. Scroll through the list until your country/region is displayed, and then touch the country/region to
select it.
6. Touch Save to save the settings.
Set the fax header
The fax header setting is used to set a phone number and company name that are placed in the fax
header. This information is required and must be set.
If the fax icon is displayed on the control panel screen and does not have Not Configured written across
and/or is not grayed, you have completed all necessary setup. To send a fax, see Use Fax
on page 25 for information about sending faxes.
Set, verify, or change the fax header
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup to display the Initial Setup menu.
3. Touch Fax Setup to display the Fax Setup menu.
4. Touch Required Settings to display the Required Settings menu.
5. Touch Fax Header Information to display the header information.
6. Touch Phone Number to display the Phone Number screen.
ENWW Required fax settings 5
7. Touch the text box to display the keyboard.
8. Using the keyboard, type the phone number, and then touch OK.
9. Touch Save to save the header phone number.
10. Touch Company Name and repeat the process.
6 Chapter 1 Setup ENWW
2 Set fax settings
This chapter describes the configuration settings for the MFP fax accessory that you access through
the fax menu on the control panel. In addition to the control panel, you can access these settings through
remote configuration tools.
NOTE: For information about the following settings, see Setup on page 1. The following fax settings
are described in the first chapter and are not included here: Canceling faxes; Setting the date and time;
Setting the location; Setting the header.
ENWW 7
Remote fax configuration
In addition to using the MFP control panel, you can configure the fax accessory remotely by using various
software tools. Because the MFP contains an embedded Web server (EWS), you can configure the fax
accessory across the Web by using either a Web browser or HP Web Jetadmin (WJA). In addition, you
can configure the fax accessory across the network with a network-connected computer by using the
HP MFP Digital Sending Software Configuration Utility (DSS). These tools provide access to most of
the fax accessory configuration settings that available from the MFP fax menu, as described in this
document.
NOTE: The DSS configuration utility can disable or enable the analog-fax feature on the MFP. If the
DSS configuration utility disables the analog fax and then the MFP is detached from the configuration
utility, you will not see Send to Fax in the EWS or WJA Digital Sending menu. If this happens, enable
the analog fax for the MFP by using the DSS configuration utility.
Web browser
The MFP contains an embedded Web server (EWS). The EWS allows you to use a Web browser to
access and set the analog-fax settings, described in this chapter.
To use a Web browser to access the EWS fax setting screens, perform the following steps.
1. Type the IP address of the MFP in the browser URL address bar and press Enter to open the EWS
Configure MFP screen. To get the IP address of the MFP, print an MFP Configuration page.
NOTE: If DSS is being used, a message appears on EWS indicating that DSS is in control. The
only way to change settings is through DSS.
2. Click the Digital Sending tab.
3. Click the Send Fax tab to open the Fax configuration settings screen.
4. On the Fax Settings screen make any changes to the settings and click OK to accept the settings.
Select Advanced to open the Advanced MFP Modem Settings screen for additional fax settings.
For information about the settings, see the setting descriptions in this guide.
5. After you have made changes to the settings, click OK to accept the settings.
HP Web Jetadmin
To access the MFP analog-fax settings by using HP Web Jetadmin, perform the following steps. For
detailed information about HP Web Jetadmin, see the HP Web Jetadmin Reference Manual.
1. Start HP Web Jetadmin.
2. In the At a Glance text box, type the IP address of the MFP in the Quick Device Find text box,
and then click Go to see the device status in the right pane. Select Digital Sending and Fax from
the status drop-down menu in that pane.
3. Configure the options in the Fax Settings or the Advanced Fax Settings sections. For information
about a specific setting, select the context help next to the setting.
4. After you have made changes to the settings, click Apply to accept the settings.
In addition to configuring a single MFP, you can also perform multiple device configuration. Multiple
device mode configures several MFPs at once. For information about this feature, see the HP Web
Jetadmin Reference Manual.
8 Chapter 2 Set fax settings ENWW
HP MFP Digital Sending Software Configuration Utility
To access the analog MFP fax settings by using the DSS configuration utility, perform the following
steps.
1. 1. Start the utility (on the computer or server) to open the main screen.
2. Select the MFP and click the Configure MFP button on the main screen, and then click the Send
to Fax tab to open the Fax Settings screen.
3. To enable the fax capabilities on the MFP, select Enable Send to Fax. To access Analog-fax
settings, select directly from the MFP's internal modem in the Send Faxes drop-down list. On the
Fax Settings screen make any changes to the settings and click OK to accept the settings. Select
Advanced to open the Advanced MFP Modem Settings screen for additional fax settings.
For information about these settings, see the setting descriptions in this guide.
4. After you have made changes to the settings, click OK to accept the settings.
In addition to configuring a single MFP, you can also configure multiple devices. For more information
about the HP MFP Digital Sending Software Configuration Utility, see the HP MFP Digital Sending
Software User Guide or the HP MFP Digital Sending Software Support Guide.
NOTE: Depending on the capabilities and settings of your fax method, some of these options might
not be available or configurable.
ENWW Remote fax configuration 9
Send fax settings
Set the dial tone detection
The detect dial tone setting determines whether the fax checks for a dial tone before sending a fax.
Set the dial tone detection
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to touch Initial Setup to open the initial setup menu.
3. Touch Fax Setup to open the fax setup menu.
4. Touch Fax Send Settings and use the down arrow key to scroll to Detect Dial Tone.
5. Touch Enabled (default) to enable dial tone detection, or touch Disabled to disable dial tone
detection.
Set the overlay header (outgoing faxes)
The overlay header consists of the date, time, company name, phone number, and page number and
is printed at the top of the page on outgoing faxes. This setting determines whether the header is
appended to the top of the page or is printed as an overlay. If the header is appended to the top of a
page, it moves page data down which can result in data at the bottom of a page being pushed to another
page, possibly printing an additional page. If the header is printed as an overlay, it does not push any
page data, but might print over data at the top of the page.
NOTE: When fax forwarding is enabled, the overlay header is always appended to the top of the page,
even if overlay is enabled.
Set the overlay header for outgoing faxes
1. On the control panel, touch the Administration icon to open the Administration menu.
2. Scroll to and touch Default Job Options
3. Scroll to and touch Default Fax Options.
4. Scroll to and touch FAX SEND.
5. Touch Fax Header to see the header settings.
6. Touch Overlay to print the header as an overlay, or touch Prepend (default) to append the header
to the top of the page.
7. Touch Save.
Set the dialing mode
The dialing mode setting sets the type of dialing that is used: either tone (touch-tone phones) or pulse
(rotary-dial phones).
To set the dialing mode, perform the following steps.
10 Chapter 2 Set fax settings ENWW
Set the dialing mode
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to touch Initial Setup to open the initial setup menu.
3. Touch Fax Setup to open the fax setup menu.
4. Touch Fax Send Settings and use the down arrow key to scroll to Dialing Mode.
5. Touch Dialing Mode to see the dialing mode settings.
6. Touch Tone (default) to set the fax for tone dialing, or touch Pulse to set the fax for pulse dialing.
7. Touch Save.
Set a dialing prefix
The dialing prefix setting allows you to enter a prefix number (such as a "9" to access an outside line)
when dialing. This prefix number is automatically added to all phone numbers when dialed.
NOTE: You might need a pause between the prefix and the phone number. To insert a 2–second
pause, enter a comma (,). For more information on using a comma see Send a fax on page 29.
Set a dialing prefix
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to touch Initial Setup to open the initial setup menu.
3. Touch Fax Setup to open the fax setup menu.
4. Touch Fax Send Settings and use the down arrow key to scroll to Dialing Prefix to see the dialing
prefix settings.
5. Touch Custom to enter a dialing prefix number.
NOTE: If you want to disable the dialing prefix, touch OFF (default), touch Save, and then skip
the remaining steps.
6. Touch Save to open the Set Dialing Prefix screen.
7. Touch Dialing Prefix Number.
8. Touch the text box to display the keyboard.
9. Type the dialing prefix number and touch OK.
10. Touch Save.
Set the redial rules
Set redial-on-busy
The redial-on-busy setting selects the number of times (0 through 9) the fax accessory redials a number
when the number is busy. The interval between retries is set by the Redial Interval setting.
ENWW Send fax settings 11
Set the redial-on-busy setting
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to touch Initial Setup.
3. Scroll to touch Fax Setup.
4. Touch Fax Send Settings and use the down arrow key to scroll to Redial on Busy.
5. Touch the text box to display the keyboard.
6. Enter the value (0–9) and touch OK.
7. Touch Save.
Set redial-on-no-answer
The redial-on-no-answer setting selects the number of times the fax accessory redials if the number
dialed does not answer. The number of retries is either 0 to 1 (used in the U.S.) or 0 to 2, depending on
the country/region setting. The interval between retries is set by the redial interval setting.
Set the redial-on-busy setting
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to touch Initial Setup to open the initial setup menu.
3. Scroll to touch Fax Setup to open the fax setup menu.
4. Touch Fax Send Settings and use the down arrow key to scroll to Redial on No Answer.
5. Touch Never or Once.
6. Touch Save.
Set redial interval
The redial interval setting selects the number of minutes between retries if the number dialed is busy or
not answering.
NOTE: You might observe a redial message on the control panel when both the Redial-on-Busy and
Redial-on-No-Answer settings are set to off. This occurs when the fax accessory dials a number,
establishes a connection, and then loses the connection. As a result of this error condition, the fax
accessory performs two automatic redial attempts regardless of the redial settings (the first one at 26,400
bps and, if that fails, a second one at 14,400 bps). During this redial operation, a message appears on
the control panel to indicate that a redial is in progress.
Set the redial interval
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to touch Initial Setup to open the initial setup menu.
3. Touch Fax Setup to open the fax setup menu.
4. Touch Fax Send Settings and use the down arrow key to scroll to Redial Interval.
5. Touch the text box to display the keyboard.
12 Chapter 2 Set fax settings ENWW
6. Enter the value (1–5) and touch OK.
7. Touch Save.
Set the outgoing fax resolution
The outgoing fax resolution setting determines the maximum resolution supported by the receiving fax.
The fax accessory uses the highest possible resolution (as limited by this setting) and the maximum
resolution of the receiving fax.
NOTE: Faxes wider than 21.25 cm (8.5 inches) are automatically sent by using standard or fine
resolution, to reduce phone time.
NOTE: The default resolution setting is a lower dpi than previous MFP model default resolution
settings. For example, previous MFP models had a default resolution of FINE (200 x 200 dpi).
NOTE: The higher the resolution, the longer the transmission time required.
Set the resolution for outgoing faxes
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Default Job Options
3. Touch Default Fax Options
4. Scroll to and touch FAX SEND.
5. Touch Resolution to see the resolution settings.
6. Touch Standard (200 x 100 dpi, default), Fine (200 x 200 dpi), or Superfine (300 x 300 dpi) to select
the resolution.
7. Touch Save.
Set billing codes
The billing-code setting, when enabled, prompts the user to enter a number when sending a fax. This
number is placed in the billing-code report. To view the billing-code report, either print the report or query
it by using an application.
Set billing codes
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup and then Fax Setup to open the fax menu.
3. Touch Fax Send Settings to see the Fax Send settings.
4. Scroll to and touch Billing Codes to see the billing code settings.
5. Touch Custom to enable billing codes.
NOTE: If you want to disable billing codes, touch OFF, touch Save, and then skip the remaining
steps.
6. Touch Save to open the Billing Code screen.
7. Touch the text box to display the keyboard.
ENWW Send fax settings 13
8. Type the minimum number of digits you want in the billing code, and then touch OK.
9. Touch Save.
Set the JBIG compression mode
Enabling JBIG compression can reduce phone-call charges by reducing fax transmission time and is,
therefore, the preferred setting. However, JBIG might cause compatibility problems when
communicating with some older fax machines, in which case you might need to disable it.
NOTE: JBIG compression only works when both the sending and receiving machines have JBIG
compression.
To enable or disable JBIG compression, perform the following steps.
Set the JBIG compression mode
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup.
3. Scroll to and touch Fax Setup.
4. Scroll to and touch Fax Send Settings.
5. Touch JBIG Compression to see the settings.
6. Touch Enable (default) to enable JBIG compression, or touch Disabled to disable JBIG
compression.
Change the sharpness setting
The Sharpness setting specifies the sharpness that the scanner uses when the MFP scans your original.
Sharpness enhances the edges of the original so that faint or fine text and graphics are reproduced
more sharply. Increasing sharpness increases resolution which also increases transmission time.
Change the sharpness setting
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Scroll to and touch More Options.
3. Scroll to and touch Image Adjustment.
4. Scroll to and touch Sharpness.
5. Touch the left arrow to decrease the sharpness or touch the right arrow to increase the sharpness
of the image.
6. Touch OK to accept the setting.
Change the background setting
If you are faxing a document that is printed on colored paper, you can enhance your fax copy quality by
removing the background that might cause your fax copy to streak or blur.
14 Chapter 2 Set fax settings ENWW
Change the background setting
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Scroll to and touch More Options.
3. Scroll to and touch Image Adjustment.
4. Scroll to and touch Background Cleanup.
5. Touch the left arrow or touch the right arrow to change the background setting.
6. Touch OK to accept the setting.
Change the light/dark setting
The light/dark setting adjusts how light or dark the transmitted image appears on the recipient fax
machine.
Change the light/dark setting
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Scroll to and touch More Options.
3. Scroll to and touch Image Adjustment.
4. Scroll to and touch Darkness.
5. Touch the left arrow to make the image lighter and touch the right arrow to make the image darker.
6. Touch OK to accept the setting.
Activate Fax Number Confirmation
When fax number confirmation is enabled, the fax number must be entered twice to ensure that it was
entered correctly. The default setting for this feature is Disabled.
Activate Fax Number Confirmation
1. On the control panel, touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup and then Send Setup.
3. Scroll to and touch Fax Number Confirmation.
4. Touch Enable.
5. Touch Save.
Activate Fax Number Speed Dial Matching
If this feature is enabled, the MFP tries to match any fax number entered with existing entries in the
speed dial list. If a match is found, you can confirm the match and have the MFP complete the faxing
action automatically. The default setting for this feature is Disabled.
ENWW Send fax settings 15
Activate Fax Number Speed Dial Matching
1. On the control panel, touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup and then Send Setup.
3. Scroll to and touch Fax Number Speed Dial Matching.
4. Touch Enable.
5. Touch Save.
16 Chapter 2 Set fax settings ENWW
Receive fax settings
Set rings-to-answer
The rings-to-answer setting determines the number of times the phone rings before the call is answered
by the fax accessory.
NOTE: The default setting range for rings-to-answer is country/region-specific.
Set the number of rings-to-answer
1. On the control panel, touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup and then Fax Setup to open the fax menu.
3. Scroll to and touch Fax Receive Settings.
4. Touch Rings To Answer to open the rings-to-answer screen.
5. Use the up and down arrows to select the number of rings (the default is 2), and then touch OK.
6. Touch the text box to display the keyboard.
7. Type the number of rings (1–9), and then touch OK.
8. Touch Save.
Stamp received faxes (incoming faxes)
The stamp received faxes setting enables or disables stamping incoming faxes. The stamp prints the
date, time, phone number, and page number on each incoming page.
Stamp received faxes (incoming faxes)
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Default Job Options and then Default Fax Options.
3. Touch Fax Receive to see the Fax Receive setting.
4. Touch Stamp Received Faxes to see the settings.
5. Touch Disabled (default) to disable the stamp, or touch Enabled to enable the stamp.
6. Touch Save.
Set fit-to-page
When selecting a page size to print a fax, the MFP determines the closest page size that matches the
intended size from sizes available in the MFP. If the fit-to-page setting is enabled and the received image
is larger than that page size, the MFP attempts to scale the image to fit the page. If this setting is disabled,
an incoming image larger than the page splits across pages.
Set fit-to-page
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Default Job Options and then Default Fax Options.
ENWW Receive fax settings 17
3. Scroll to and touch Fax Receive to see the Fax Receive setting.
4. Touch Fit to Page to see the fit-to-page settings.
5. Touch Enabled (default) to enable fit-to-page, or touch Disabled to disable fit-to-page.
6. Touch Save.
Set the paper tray
The paper tray setting selects the MFP paper tray to pull paper from for printing faxes.
Set the paper tray
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Default Job Options.
3. Touch Default Fax Options.
4. Touch Fax Receive to display the Fax Receive menu.
5. Touch Fax Paper Tray to display the Fax Paper Tray menu.
6. Touch the text box to enter the desired paper tray value, 0 (default) - 2. (Other values may be
displayed depending on installed paper trays)
7. Touch Save to save the paper tray value.
Set the destination bin
The destination bin setting specifies the MFP output bin to receive the printed fax.
Set the output bin
NOTE: Some menu items (such as Output Bin) are not present if there is only a single selection
available.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Default Job Options to display the Default Job Options menu.
3. Touch Default Fax Options to display the Fax Receive menu.
4. Touch Output Bin to display the Output Bin menu.
5. Touch the text box to enter the desired paper tray value, 0 (default) - 2. (Other values may be
displayed depending on installed paper trays)
6. Touch Save.
Blocking incoming faxes
Use the fax block list setting to create a list of blocked phone numbers. When a fax is received from a
blocked phone number, the fax is not printed and is immediately deleted from memory.
NOTE: Only numbers can be used in the fax block list. Do not use dashes or spaces. If a fax is sent
from a blocked phone number and the sender uses a dash or a space in the number, the fax will not be
blocked.
18 Chapter 2 Set fax settings ENWW
Create a blocked-fax list
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup.
3. Touch Fax Setup.
4. Scroll to and touch Fax Receive Settings.
5. Scroll to and touch Blocked Fax List to open the blocked fax menu.
6. Touch Add Blocked Number to make the keyboard available.
7. Type a number and touch OK.
8. To add additional numbers, repeat steps 5 and 6.
Remove numbers from the blocked-fax list
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup.
3. Touch Fax Setup.
4. Scroll to and touch Fax Receive Settings.
5. Scroll to and touch Blocked Fax List to open the blocked fax menu.
6. Touch Remove Blocked Number to make the keyboard available.
7. Type a number and touch OK.
8. To add additional numbers, repeat steps 5 and 6.
Clear all numbers from the blocked-fax list
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup.
3. Touch Fax Setup.
4. Scroll to and touch Fax Receive Settings.
5. Scroll to and touch Blocked Fax Numbers to open the blocked fax menu.
6. Touch Clear all Blocked Numbers to make the keyboard available.
7. Touch Yes to clear all numbers from the list, or touch No to exit and retain the numbers.
Initiate polling receive
Some fax machines can hold a fax until another fax machine requests that the fax be sent. When an
MFP polls another fax machine that is holding a fax and requests that the held fax be sent to the MFP,
this is known as polling receive.
ENWW Receive fax settings 19
Initiate polling receive
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Touch More Options to display the options screen.
3. Scroll to page 3.
4. Touch Fax Polling to display the Fax Polling screen.
5. Touch the text box to display the keyboard.
6. Using the keypad, type a polling receive number, and then touch Start.
7. The number entered is dialed. If a stored fax is being held at the fax machine dialed, that fax is
transmitted to the mfp and printed. If no fax is held, a No Fax is Available message will be
displayed. If the fax machine does not support the polling feature, a Poll Invalid error message
will be shown.
Changing notification settings
Notification selects when and how you are notified of the status of an outgoing fax. This setting applies
to the current fax only. To change the setting permanently, change the default setting.
Change notification settings
1. On the control panel, touch the FAX icon to open the Fax screen.
2. Touch More Options.
3. Touch Notification.
4. Select a notification setting:
●Touch None to turn off notification.
●Touch This Job to enable notification for the current job.
●Touch On Error to enable error notification only for the current job.
5. Touch Print to receive a printed notification, or touch E-MAIL to receive an e-mail notification.
6. If you selected Print, touch OK to complete the notification setup.
-or-
If you selected E-MAIL, use the keyboard to type an e-mail address. Then touch OK to complete
the notification setup.
20 Chapter 2 Set fax settings ENWW
Set the error correction mode
Normally, the fax accessory monitors the signals on the telephone line while it is sending or receiving
a fax. If the fax accessory detects an error during the transmission and the error correction setting is on,
the fax accessory can request that the error portion of the fax be sent again.
You should turn off error correction only if you are having trouble sending or receiving a fax and if you
are willing to accept the errors in the transmission. Turning off the setting might be useful when you are
trying to send a fax overseas or receive one from overseas, or if you are using a satellite telephone
connection.
Set the error correction mode
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Initial Setup to open the setup settings menu and then touch Fax Setup.
3. Touch Fax Send Settings to see the settings.
4. Touch Error Correction Mode to see the settings.
5. Touch Enabled (default) to enable error correction mode, or touch Disabled to disable correction
mode.
ENWW Set the error correction mode 21
Set the modem volume
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup to display the Initial Setup menu.
3. Touch Fax Setup to display the Fax Setup menu.
4. Touch Fax Send Settings to display the Fax Send Settings menu.
5. Touch Fax Dial Volume to display the Fax Dial Volume menu.
6. Touch OFF; Low (default), or High to set the volume.
7. Touch Save to save the volume setting.
22 Chapter 2 Set fax settings ENWW
Set the ringer volume
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Initial Setup to display the Initial Setup menu.
3. Touch Fax Setup to display the Fax Setup menu.
4. Touch Fax Receive Settings to display the Fax Receive Settings menu.
5. Touch Ringer Volume to display the Ringer Volume menu.
6. Touch OFF; Low (default), or High to set the volume.
7. Touch Save to save the volume setting.
ENWW Set the ringer volume 23
24 Chapter 2 Set fax settings ENWW
3Use Fax
This chapter provides information about fax setup, sending faxes, and receiving faxes in the following
sections:
●Fax feature screen
●Status message bar
●Send a fax
●Canceling a fax
●Receiving faxes
●Creating and deleting speed dial lists
●Assigning speed dial lists to one-touch keys
●Voice Calls and Retries
●Secure settings
●Set fax forwarding
●Scheduling fax printing (memory lock)
●Using Fax over VoIP networks
ENWW 25
Fax feature screen
The Fax feature screen is used to send faxes. To access this screen, press the FAX icon displayed on
the control panel Home screen.
Figure 3-1 Fax feature screen
1Home Key - return to main screen
2Send Fax - press to send fax to recipients
3Enter Number into Recipient List
4Backspace/Delete Number
5Status Message Bar
6Access Phone Book
7Speed Dial Search by Number
8Alert Message - touch to display
9Help - touch to display help selections
10 Speed Dial - Edit Key
11 Speed Dial - Search by Name
12 Speed Dial List (scroll to display other entries)
13 Current Date and Time
14 Touch to access additional Fax Settings for current job
15 Press for Details of Selected Recipient
16 Press to Delete Selected Recipient from List
17 Recipient List
18 Recipient Number Entry Box - Touch for keyboard or enter
from control panel keypad1
26 Chapter 3 Use Fax ENWW
1
When the Recipient Number Entry Box is pressed, a pop up is displayed which includes the PIN button
for adding special character brackets ([ ]) to hide a PIN number, and a Pause button to insert a comma
for a two second pause. See the figure below:
Figure 3-2 Recipient number entry box
ENWW Fax feature screen 27
Status message bar
While sending and receiving faxes, status information will display in the status bar located at the top of
some touch screens. This status includes such information as: Ready, Receiving call, Page sent, and
others.
28 Chapter 3 Use Fax ENWW
Send a fax
To send a fax, you can use one of three basic methods to enter numbers:
●Enter number(s) manually.
●Enter number(s) using speed dial.
●Enter number(s) using the phone book (available only if HP MFP Digital Sending Software
Configuration Utility is installed and the phone book has been populated).
NOTE: For online information about sending a fax, touch ? on the screen to access the help menu,
and then touch Send a fax under the list of help topics.
When entering a phone number from the numeric keypad, include any pauses or other numbers, such
as area codes, access codes for numbers outside a PBX system (usually a 9 or 0), or a long-distance
prefix. A two second pause may be included by typing a comma (,). If the fax prefix setting has been
set to automatically include the dialing prefix, you will not need to enter it.
NOTE: When a fax is sent, it is first scanned and stored into memory. After the entire document is
stored, it is sent and then deleted from memory. Faxes that fail to send, because the number was busy
or did not answer, are deleted from memory. If Redial-On-Busy or Redial-On-No-Answer are set, the
fax will not be deleted until all retries fail or the fax is sent successfully.
Send a fax - enter number(s) manually
1. Place the document in the automatic document feeder (ADF) or on the scanner glass.
2. From the main screen, touch the FAX icon. You may be prompted to type a user name and
password.
3. Touch More Options. Verify that the Describe Original settings match those of your original. These
settings include:
●Original size (such as letter or A4)
●Original sides - 1–sided or 2–sided printing
●Optimize text/picture (text, mixed text and graphics, or graphics and photos) Sending
graphics and photos in text mode results in lower quality images.
●Content Orientation (portrait or landscape)
●Job Build combines multiple scans into a single job.
●Image adjustment
●Sharpness enhances text and graphic edges.
●Darkness
●Background removes a background that might be a result from copying color paper.
●Notification changes how you are notified of the status of the fax transmission (that is, if the
fax was sent or if an error occurred and the fax was not sent).
NOTE: Notification changes the notification setting for the current fax only.
4. When all settings are completed, touch OK to return to the Settings menu.
ENWW Send a fax 29
5. On the Settings screen, touch the Light or Dark arrow to adjust the lightness/darkness of the fax
you are sending.
6. When all settings are completed on the Settings screen, touch OK to return to the Fax screen.
7. Using the keyboard, enter a phone number. To enter additional numbers, touch Next Number and
continue entering numbers.
To remove a number from the list, use the arrow keys to highlight a number and then touch
Remove.
NOTE: If needed, enter a comma (,) to provide a two second pause after a prefix number (such
as a "9" or "0" ) to allow the internal phone system time to access an outside line before the
remainder of the number is dialed. To enter a comma, use the keypad on the control panel that
pops up when you touch the Recipient Number Entry Box
To enter a PIN as part of the recipient number, use the keypad on the control panel. Touch the
Recipient field, and then touch the PIN button. This inserts a left bracket ([). Type the PIN, and
then touch the PIN button again to insert the right (]) bracket. The number within the brackets is
not displayed in the fax number that appears on fax reports.
8. Touch Start to send the fax. You can either touch the Start icon on the touch screen or press the
green Start button on the control panel.
9. If the fax recipient number matches one or more saved speed dials, the matched speed dials are
displayed and you are asked if you want to continue sending the fax to the indicated recipient(s).
Touch Yes to confirm the number and send the fax, or touch No to cancel the fax. Note that this
step is not required if the Fax Number Speed Dial Matching feature is disabled.
If the fax recipient number does not match any saved speed dials, a number confirmation screen
appears and you must re-type the fax number. After re-typing the number, touch OK to send the
fax. Note that this step is not required if the Fax Number Confirmation feature is disabled.
NOTE: If you have made any changes to the settings on the Settings screen (such as changing
notification or 1-sided to 2-sided), a Processing Job screen displays asking "Would you like to keep your
current settings?". If you press Yes, the MFP returns you to the Fax screen and the settings you made
are retained. This allows you to send another fax using the same settings. If you press No, the settings
are cleared (returned to their default values) and the MFP home screen displays.
Send a fax using speed dial
NOTE: Prior to sending a fax using speed dial, you must create a speed dial. To create a speed dial,
see Creating and deleting speed dial lists on page 36.
1. Place the document in the automatic document feeder (ADF) or on the scanner glass.
2. On the control panel, touch the FAX icon to display the Fax screen.
3. Touch Speed Dials to display the Speed Dial screen.
4. Touch a Speed Dial number for the speed dial name you wish to use.
5. The speed dial name will appear in the Fax Recipients section of the Fax screen.
6. Touch the fax recipient name to highlight.
7. Touch Start to send the fax. You can either touch the Start button on the touch screen or press the
green Start button on the control panel.
30 Chapter 3 Use Fax ENWW
Sending a fax using one touch speed dial
NOTE: Prior to sending a fax using a one touch speed dial key, you must first create a speed dial, see
Creating and deleting speed dial lists on page 36. Then set up the one touch keys.
NOTE: If you have made any changes to the settings on the Settings screen (such as changing
notification or 1-sided to 2-sided ), a Processing Job screen displays asking "Would you like to keep
your current settings?". If you press Yes, the MFP returns you to the Fax screen and the settings you
made are retained which allows you to send another fax using the same settings. If you press No, the
settings are cleared (returned to their default values) and the MFP home screen is displayed.
1. Place the document in the automatic document feeder (ADF) or on the scanner glass.
2. From the main screen, touch the FAX icon. You may be prompted to type a user name and
password.
3. Touch Settings. Verify that the Describe Original settings match those of your original. These
settings include:
●Page size (such as letter or A4)
●1-sided or 2-sided printing
●Page content (text, mixed text and graphics, or graphics and photos) Sending graphics and
photos in text mode results in lower quality images.
●Orientation (portrait or landscape)
●Job Mode combines multiple scans into a single job.
If the settings do not match, complete the following steps.
a. Touch Describe Original to display the Original Setting screen.
b. Make any required changes to match your original.
c. When all settings are completed, touch OK to return to the Settings screen.
NOTE: All settings made on the Settings screen are temporary settings, enabled for the current
fax only.
4. On the Settings screen touch Fax Settings to make adjustments to the following settings:
●Sharpness--enhances text and graphic edges.
●Background Removal--removes a background that might be a result from copying color
paper.
5. When all settings are completed, touch OK to return to the Settings screen.
6. On the Settings screen, to adjust the lightness/darkness of the fax you are sending, touch the
Light or Dark arrows and touch OK to return to the Settings screen.
7. When all settings are completed on the Settings screen, touch OK to return to the Fax screen.
8. To change notification, touch NOTIFY. Make changes to notification settings and then touch OK
to return to the Settings screen.
NOTE: Notify/Notification changes the notification setting for the current fax only.
ENWW Send a fax 31
9. Touch the one touch speed dial key for the speed dial you want.
10. Touch Start to send the fax. You can either touch the Start button on the touch screen or press the
green Start button on the control panel.
Search a speed-dial list by name
Use this feature to search an existing speed dial by name.
NOTE: If you do not know the unique name of the speed dial, type a letter to select any portion of the
list. For example, to view speed-dial names that begin with the letter N, type the letter N. If no matching
entries exist, a message appears before the search shows the entry that is closest to the letter N.
1. On the control-panel main screen, touch the FAX icon to display the Fax screen.
2. Touch the Speed Dial Search button. This button looks like a magnifying glass and is located to
the right of the Speed Dial button.
3. Type the first letters of the name to search for. As matches are found, the list at the top of the search
screen is populated. If necessary, scroll to see all the entries, or type more letters to narrow the
search.
4. Select the appropriate name from the list and touch OK. The speed-dial list on the main fax screen
shows the selected entry at the top of the list.
5. Touch the selected entry to add it into the recipients list.
6. Select or search for additional names as needed.
Sending a fax using phone book numbers
The fax phone book feature is available when the MFP is configured to use the HP MFP Digital Sending
Configuration software. If the MFP has not been configured for use with this software, the Phone Book
button will not display. To configure the MFP for use with the HP MFP Digital Sending Configuration
software, see the HP MFP Digital Sending Software User Guide or the HP MFP Digital Sending
Software Support Guide.
Also, when Authentication is enabled from the HP MFP Digital Sending Configuration software, your
personal fax numbers from your Microsoft® Exchange contact list appear in the phone book.
NOTE: Fax numbers cannot be added or deleted from the phone book from this device. Fax numbers
can only be added or deleted using the Address Book Manager (ABM) running on the Digital Send
Server or by changing the entries in your contact list.
NOTE: If you have made any changes to the settings on the Settings screen (such as changing
notification or 1-sided to 2-sided), a Processing Job screen displays asking "Would you like to keep your
current settings?". If you press Yes, the MFP returns you to the Fax screen and the settings you made
are retained, which allows you to send another fax using the same settings. If you press No, the settings
are cleared (returned to their default values) and the MFP home screen is displayed.
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Touch Address Book icon to display the Address Book screen.
3. Select a phone book source from the drop down menu.
4. Touch the names to highlight and touch the Right Arrow icon to move the highlighted names to the
Fax Recipients section.
32 Chapter 3 Use Fax ENWW
5. Touch OK to return to the Fax screen.
6. Touch Start to send the fax. You can either touch the Start button on the touch screen or press the
green Start button on the control panel.
DSS fax phone book search
Use the fax phone book search feature to complete a name search of the fax phone book that is supplied
through the Digital Sending Service (DSS) and the Address Book Manager (ABM).
Check the HP Web site to determine if firmware updates are available for your MFP model.
NOTE: If you are not using DSS, the fax phone book does not appear on the MFP display. The DSS
phone book is not the same as the speed-dial list.
Use the fax phone book search feature
1. Touch the FAX icon on the display.
2. Touch the Phone Book icon (located to the right of the fax recipients box).
3. Select the phone book source or All in the pull-down menu at the top of the phone book screen.
4. Select the recipient name from the phone book list.
For long lists, a name search is available by pressing the Search icon (magnifying glass) at the
bottom of the phone book screen. In the search screen, type the first letter or letters of the name;
matching recipients appear as letters are typed. Type more letters to further refine the search.
Select from the name(s) found at the top of the screen, and then touch OK. The screen returns to
the Fax Phone Book.
5. Touch the right arrow to enter the selected name into the Fax Recipients list.
6. Touch OK to return to the Send Fax job screen.
NOTE: Use the Address Book Manager (part of DSS) to create/add content to the Fax Address Book.
NOTE: To import/export the local fax phone book to the EWS, refer to the EWS documentation.
ENWW Send a fax 33
Canceling a fax
Cancel the current fax transmission
The Cancel Current Transmission menu item only appears if an outgoing fax call is in progress.
NOTE: The cancel operation may require up to 30 seconds to complete.
1. On the control panel, press the red Stop button to display the Cancel Fax menu.
NOTE: All current and pending Fax jobs on the device will continue progress until the cancellation
is confirmed with OK
2. Touch Cancel current fax job to cancel the current fax job.
3. Touch OK to cancel the current fax transmission.
Cancel all pending faxes
This deletes all outgoing faxes stored in memory. However, if a fax is in the process of being transmitted,
that fax is not deleted and will be sent.
NOTE: If other outgoing faxes are waiting in memory, they will also be deleted.
1. On the control panel, press the red Stop button to display the Cancel Fax menu.
NOTE: All current and pending Fax jobs on the device will continue progress until the cancellation
is confirmed with OK.
2. Touch Cancel all fax jobs to cancel all current and pending fax jobs.
3. Touch OK to cancel all current and pending fax jobs.
34 Chapter 3 Use Fax ENWW
Receiving faxes
When the fax accessory receives incoming faxes, it stores them in memory before printing. After the
entire fax is stored, it is printed and then deleted from memory. Faxes print when received unless
Schedule Printing of Faxes is enabled. If Schedule Printing of Faxes is enabled, all incoming faxes are
stored in memory and not printed. When Schedule Printing of Faxes is disabled, all stored faxes print.
For more information, see Scheduling fax printing (memory lock) on page 42.
You can change the fax-receive default settings to modify the way a fax is received. These settings
include the following options:
●Selecting the number of rings-to-answer
●Printing date, time, and page number on faxes (stamp)
●Selecting input paper tray and destination bin
●Forwarding faxes to another number
●Blocking faxes from certain numbers
●Schedule the printing of faxes (memory lock)
For information about changing these menu settings, see Set fax settings on page 7.
NOTE: You cannot cancel incoming faxes.
ENWW Receiving faxes 35
Creating and deleting speed dial lists
Speed dial allows you to assign a speed dial name to a single number or a group of numbers and then
send a fax to that number or numbers by selecting the speed dial name.
Create a speed dial list
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Touch Speed Dials to display the Speed Dial screen.
3. Touch a Speed Dial number.
4. Touch the Speed Dial Name box to display the keyboard.
5. Type a name for the speed dial and touch OK to return to the Speed Dials screen.
6. Touch the Fax Numbers box to display the keyboard.
7. Type a fax number for the Speed Dial Name and touch OK to return to the Speed Dials screen.
8. Touch the Speed Dial number selected for the Speed Dial Name to save. The name and fax number
will appear next to the Speed Dial number.
9. Repeat steps 3-8 to enter all the numbers for the speed dial
10. When finished, press OK to return to the Fax screen
Delete a speed dial list
1. On the control panel main screen, touch the FAX icon to display the Fax screen.
2. Touch Speed Dial to display the Speed Dial screen.
3. Touch a Speed Dial number of the list to be deleted.
4. Touch Delete.
5. The next screen will ask to confirm the deletion.
6. Touch Yes to delete the speed dial list.
7. Touch Yes again to return to the Fax screen.
Delete a single number from the speed dial list
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Touch Speed Dials to display the Speed Dial screen.
3. Touch the Speed Dial number of the list to be edited.
4. Touch the Fax Numbers box to display the keyboard.
5. Scroll through the list of fax numbers and touch the screen to the right of last digit of the fax number
to be deleted. Use the backspace key to delete the fax number.
36 Chapter 3 Use Fax ENWW
6. Touch OK to return to the Speed Dials screen.
7. Touch OK to return to the Fax screen.
Add a number to an existing speed dial list
1. On the control panel, touch the FAX icon to display the Fax screen.
2. Touch Speed Dials to display the Speed Dial screen.
3. Touch the Speed Dial number of the list to be edited.
4. Touch the Fax Numbers box to display the keyboard.
5. Using the keyboard, type the fax number to add to the speed dial list.
NOTE: The cursor defaults to the next open space below the last entered fax number of the speed
dial list.
6. Touch OK to return to the Speed Dials screen.
7. Touch OK to return to the Fax screen.
ENWW Creating and deleting speed dial lists 37
Assigning speed dial lists to one-touch keys
The one-touch keypad allows you to send a fax to a speed dial list simply by touching a one-touch key.
However, before using the one-touch keys, you must create a speed dial list and assign the speed dial
name to a one-touch key.
Clear or reassign speed dial lists to one-touch keys
If you want to remove a speed dial list from a one-touch button, perform the following steps.
1. Touch Configure on the one-touch keypad to open the One-Touch Button Configuration screen.
2. Touch the number key with the speed dial name that you want to remove.
3. The Button is already configured screen opens. Touch Clear to remove the speed dial name from
the one-touch button, or touch Reassign to assign a different speed dial name to the key, or touch
Cancel to return to the One-Touch Button Configuration screen.
4. Touch OK to accept the settings.
38 Chapter 3 Use Fax ENWW
Voice Calls and Retries
Voice calls are not included in the Fax Activity log and do not generate a T.30 report. The following
sections provide information on retries of a fax job.
Fax Call Report
When all fax attempts have been exhausted, a Fax Call Report will be printed for a fax send. It shows
the fax job log ID. The result of the final attempt is printed on the Fax Call Report.
A Fax Call Report does not print for voice calls.
NOTE: A Fax Call Report only generates Job numbers for final attempts. If one of these reports is
printed manually from the menu and the last call was neither the final attempt nor a Voice call the Job
number will be zero.
Fax Activity Log
Voice Calls are not included in the Fax Activity Log by default. Only the final attempt will be displayed
in the Fax Activity Log.
T.30 Report
Voice Calls will not cause a T.30 report to print. All retry attempts will cause a T.30 report to print.
ENWW Voice Calls and Retries 39
Secure settings
Two settings, fax forwarding and fax printing, are secure features and require a PIN. The first time you
access either setting, you will be required to create a PIN. After you create that PIN, it is used to access
both features. That is, if a PIN that has been created for fax forwarding it is also used to access fax
printing, or if the PIN was first created for fax printing, it must be used to access fax forwarding. Only
one PIN can be created to access these secure settings.
If fax call report is enabled with thumbnails, a report prints with a thumbnail of the first page of the fax
when fax printing or fax forwarding is enabled. If you want secure fax printing, disable printing the
thumbnail on the fax call report.
Change your PIN
This procedure describes how to change your existing PIN.
CAUTION: Always save your PIN in a secure place. If you lose your PIN, you must contact HP Service
Support for information about how to reset the PIN. For more information, see HP Customer Care
on page 69.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Default Job Options to display the Default Job Options menu.
3. Touch Default Fax Options to display the Default Fax Options menu.
4. Touch Fax Receive to display the Fax Receive screen.
5. Touch Fax Forwarding to display the PIN screen.
6. Using the keypad, type the PIN (at least four digits), and then touch OK to display the Fax
Forwarding screen.
7. Touch Change PIN to display the PIN screen.
8. Using the keypad, type the new PIN (at least four digits), and then touch OK.
9. Using the keypad, confirm the new PIN, and then touch OK.
10. Touch OK again.
40 Chapter 3 Use Fax ENWW
Set fax forwarding
Use the forward fax setting to forward all received faxes to another fax number. When forward fax is
enabled, the receiving MFP prints the fax (if fax printing is disabled, the fax prints when the printing is
enabled), and also forwards the fax to the fax forward number.
NOTE: If the fax fails to forward to another phone number, the device will not attempt to forward the
fax again. All faxes are forwarded in fine or standard resolution.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Default Job Options to display the Default Job Options menu.
3. Touch Default Fax Options to display the Default Fax Options menu.
4. Touch Fax Receive to display the Fax Receive screen.
5. Touch Fax Forwarding to display the PIN screen.
6. Using the keypad, type the PIN (at least four digits), and then touch OK to display the Fax
Forwarding screen.
7. Touch Fax Forwarding.
8. Touch Custom and touch save to display the Set Fax Forwarding screen.
9. Touch Forward to Number to display the Forward to Number screen.
10. Touch the text box to enter the fax forward phone number and touch OK.
ENWW Set fax forwarding 41
Scheduling fax printing (memory lock)
Use the fax printing feature to specify when faxes print. There are three fax printing modes that can be
selected. The selections are Store all received faxes, Print all received faxes, or Use fax printing
schedule.
If Store all received faxes is selected, then all incoming faxes will be stored in memory and not printed.
It is possible to access fax jobs stored in memory through the MFP Retrieve Job menu. Using this menu,
you can print or delete print jobs while they are stored in memory. For additional information about this
feature, see the Retrieve Job menu description in the MFP user guide.
NOTE: Retrieved stored faxes can be accessed by entering the Fax Printing menu and changing the
mode to Print all received faxes.
If Print all received faxes is selected, then all incoming faxes will be printed. Any faxes that are currently
stored in memory will also be printed.
If Use fax printing schedule is selected, then faxes will be only printed per the fax printing schedule. The
fax printing schedule can be set to lockout an entire day (24 hours) or lockout a time period during the
day. Only one lockout period can be set, but it can be applied to any number of days. The lockout period
is setup under the Fax Printing menu. For more information, see Create a fax printing schedule
on page 43.
NOTE: When the lockout time ends, any faxes that were received and stored during the lockout period
are printed automatically.
Fax-printing behavior
To increase fax security, the behavior of the Fax Printing feature changed with the release of the HP
LaserJet CM6040/CM6030 MFP Series. The key differences are how call reports, T.30 reports, report
menus, and the control panel status line are handled or displayed. The following table assumes that
Fax Printing is enabled.
Menu setting for call
report and/or T.30
Report
When fax is received,
how are call report/T.
30 report handled?
What happens when a
stored fax is printed?
What happens to
menus for fax reports
& T.30 report?
Does the control
panel show incoming
telephone number?
Never Not printed Fax prints Hidden Hidden
Every fax Not printed and stored
with fax
Fax prints, call report(s)
prints
Hidden Hidden
Enable or disable the schedule for printing of faxes
NOTE: Before enabling a fax-printing schedule, a schedule must be created. For more information,
see Create a fax printing schedule on page 43.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Time/Scheduling to display the Time/Scheduling screen.
3. Scroll to and touch Fax Printing to display the PIN menu.
4. Touch the text box to display the keyboard.
42 Chapter 3 Use Fax ENWW
5. Using the keypad, type the PIN (at least four digits), and then touch OK to display the Fax Printing
menu.
If you do not have a PIN, you will be prompted to create one.
NOTE: Always save your PIN in a secure place. If you loose your PIN, you must contact HP
Service Support for information on how to reset the PIN. For more information, see HP Customer
Care on page 69.
6. Scroll to and touch Fax Printing Mode.
7. Select a fax printing mode:
●Scroll to and touch Store all received faxes to disable printing of faxes and store all received
faxes to memory.
●Scroll to and touch Print all received faxes to allow all stored faxes to print and to print all faxes
as received.
●Scroll to and touch Use fax printing schedule to use the fax printing schedule to automatically
turn on and off the printing of faxes.
8. Scroll to and touch Save to exit.
NOTE: Fax printing and fax forwarding use the same PIN. If you have created a PIN for fax forwarding,
use that PIN here.
Create a fax printing schedule
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Time/Scheduling to display the Time/Scheduling screen.
3. Touch Fax Printing to display the PIN menu.
4. Touch the text box to display the keyboard.
5. Using the keypad, type the PIN (at least four digits), and then touch OK to display the Fax Printing
menu.
If you do not have a PIN, you will be prompted to create one.
6. Touch Fax Printing Mode, then touch Use fax printing schedule.
7. Touch Create Fax Printing Schedule to display the schedule settings. To edit the start/stop times,
select a day, select As Scheduled, then touch Save.
NOTE: The following menu allows you to edit the print start time or the print end time. To edit
both, touch Back after editing one to return to the previous menu and then select the other.
8. Touch Print Start Time to set the scheduled time when faxes will start printing (end the lockout
period when faxes are not stored to memory).
a. Touch the text box to display the keyboard.
b. Type a value for the hour, and then touch OK.
c. Touch Save to save the hour setting.
d. Touch the text box to display the keyboard.
ENWW Scheduling fax printing (memory lock) 43
e. Type a value (1–59) for the minutes, and then touch OK.
f. Touch Save to save the minutes setting.
g. Touch AM or PM.
h. A prompt appears asking to apply the changes to all scheduled days. Touch Yes, to apply the
changes to all scheduled days, or touch No to apply the changes only to the currently selected
scheduled date.
i. Touch Save.
9. Touch Print End Time to set the scheduled time when faxes will not print (begin the lockout period
when faxes store to memory).
a. Touch the text box to display the keyboard.
b. Type a value for the hour, and then touch OK.
c. Touch Save to save the hour setting.
d. Touch the text box to display the keyboard.
e. Type a value (1–59) for the minutes, and then touch OK.
f. Touch Save to save the minutes setting.
g. Touch AM or PM.
h. A prompt appears asking to apply the changes to all scheduled days. Touch Yes, to apply the
changes to all scheduled days, or touch No to apply the changes only to the currently selected
scheduled date.
i. Touch Save.
44 Chapter 3 Use Fax ENWW
Using Fax over VoIP networks
VoIP technology converts the analog phone signal into digital bits. These are then assembled into
packets which travel on the Internet. The packets are converted and transmitted back to analog signals
at or near the destination.
The transmission of the information on the Internet is done digitally instead of analog. Therefore, there
are different constraints on the fax transmission that may require different fax settings than the analog
Public Switched Telephone Network (PSTN). Fax is very dependent upon timing and signal quality, so
a fax transmission is more sensitive to a VoIP environment.
The following are suggested changes in settings for the Analog Fax Accessory 300 when it is connected
to a VoIP service:
●Start off with the fax set in V.34 mode and with Error Correction Mode (ECM) turned on. The V.34
protocol handles any changes in transmission speed needed to accommodate VoIP networks.
●If numerous errors or retries occur with the unit set to V.34, set V.34 Off and set Maximum Baud
Rate to 14,400 bps.
●If errors and retries persist, set a lower fax speed as some VoIP systems cannot handle the higher
signal rates associated with fax. Set the Maximum Baud Rate to 9,600 bps.
●In rare cases, if errors persist, turn off ECM on the product. The image quality might decrease.
Ensure that the image quality is acceptable with ECM off before using this setting.
●If the preceding setting changes have not improved the VoIP fax reliability, contact your VoIP
provider for help.
ENWW Using Fax over VoIP networks 45
46 Chapter 3 Use Fax ENWW
4 Solve fax problems
Use the information in this chapter to troubleshoot general fax issues.
Before you can use your fax accessory, you must complete the following tasks:
●Select a location
●Set the date, time, and fax header
When the fax accessory is installed for the first time, the settings must be entered manually by the
administrator through the menus, or the fax configuration wizard at initial power up.
NOTE: In the U.S. and many other countries/regions, setting the date, time, and other fax header
information is a legal requirement.
ENWW 47
Is your fax set up correctly?
Use the following checklist to help identify the cause of any fax related problems you are encountering:
●Are you using the phone cord supplied with the fax accessory? This fax accessory has been
tested with the supplied phone cord to meet RJ11 specifications. Do not substitute another phone
cord; the analog-fax accessory requires an analog phone cord. It also requires an analog phone
connection.
●Is the fax/phone line connector seated in the socket on the fax accessory? Make sure that
the phone jack is well seated in the socket. The connector should be inserted into the socket until
it "clicks."
●Is the phone wall jack working properly? Verify that a dial tone exists by attaching a phone to
the wall jack. Can you hear a dial tone, and can you make a phone call?
What type of phone line are you using?
●Dedicated line: A standard fax/phone number assigned to receive or send faxes.
NOTE: The phone line should be for mfp fax use only and not shared with other types of telephone
devices. Examples include alarm systems that use the phone line for notifications to a monitoring
companies.
●PBX system: A business-environment phone system. Standard home phones and the fax
accessory use an analog phone signal. Some PBX systems are digital and might not be compatible
with the fax accessory. You need to have access to a standard analog phone line to be able to
send and receive faxes.
●Roll-over lines: A phone system feature where a new call "rolls over" to the next available line
when the first incoming line is busy. Try attaching the fax accessory to the first incoming phone
line. The fax accessory will answer the phone after it rings the number of times set in the rings-to-
answer setting.
NOTE: Roll-over lines can cause problems with the fax accessory's ability to receive faxes. Using roll-
over lines with this product is not recommended.
Are you using a surge-protection device?
A surge-protection device can be used between the wall jack and the fax accessory to protect the fax
accessory against electrical power passed through the phone lines. These devices can cause some fax
communication problems by degrading the quality of the phone signal. If you are having problems
sending or receiving faxes and are using one of these devices, connect the fax accessory directly to the
phone jack on the wall to determine whether the problem is with the surge-protection device.
Are you using a phone company voice-messaging service or an answering
machine?
If the rings-to-answer setting for the messaging service is lower than the rings-to-answer setting for the
fax accessory, the messaging service answers the call, and the fax accessory is not able to receive
faxes. If the rings-to-answer setting for the fax accessory is lower than that of the messaging service,
the fax accessory answers all calls, and no calls are routed to the messaging service.
48 Chapter 4 Solve fax problems ENWW
Checking fax accessory status
If the analog-fax accessory does not appear to be functioning, print a Fax Accessory Page to check the
status.
Print the Fax Accessory Page
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Information.
3. Scroll to and touch Configuration/Status Pages.
4. Scroll to and touch Configuration Page to print the configuration pages.
On the Fax Accessory Page of the Information Page, under the HARDWARE INFORMATION heading,
check the MODEM STATUS. The following table identifies the status conditions and possible solutions.
OPERATIONAL / ENABLED
1
The analog-fax accessory is installed and ready.
OPERATIONAL / DISABLED
1
The fax accessory is installed and operational, however,
HP Digital Sending utility has either disabled the MFP fax
feature or has enabled LAN fax. When LAN fax is enabled, the
analog-fax feature is disabled. Only one fax feature, either LAN
fax or analog fax, can be enabled at a time.
NON-OPERATIONAL / ENABLED/DISABLED
1
A firmware failure has been identified. The firmware should be
updated, see Firmware upgrades on page 65.
DAMAGED / ENABLED/DISABLED
1
Fax accessory has failed; reseat the fax accessory card and
check for bent pins. If the status is still DAMAGED, replace the
analog-fax accessory card.
1ENABLED indicates that the analog fax accessory is enabled, turned on; DISABLED indicates that LAN fax is enabled (analog
fax is turned off).
ENWW Checking fax accessory status 49
Fax feature is not operating
Use the table in this section to identify and solve fax malfunctions.
The fax accessory is installed but the icon does not appear on the MFP main screen.
Cause Solution
HP MFP Digital Sending Software Configuration utility has
disabled the analog-fax feature.
Use the HP MFP Digital Sending Software Configuration utility
to enable the analog-fax feature.
The accessory is not operating correctly. Check the fax accessory status, see Checking fax accessory
status on page 49. If the status is
NON-OPERATIONAL, new firmware might need to be
installed.
If the status is DAMAGED and you just installed the card, try
reseating the card and check for bent pins.
If the status is DAMAGED and the card is installed correctly,
the card might need to be replaced.
Faulty formatter board. Contact your HP service representative for service, see
HP Customer Care on page 69.
The MFP is not displaying the fax menus.
Cause Solution
LAN fax is enabled. This is normal operation. When the HP Digital Sending
Software enables LAN fax, the analog fax is disabled and the
fax menu, which is used for the analog fax only, does not open.
50 Chapter 4 Solve fax problems ENWW
General fax problems
Use the table in this section to solve fax problems.
Problem Cause Solution
Fax failed to send. JBIG is enabled and receiving fax does
not have JBIG capability.
Set JBIG off.
An "Out of Memory" status message
appears on the status message bar.
The MFP storage disk is full. Delete some files from the disk, see the
MFP user guide for information about
managing the disk.
Print quality of a photo is poor or prints
as a gray box.
Wrong Page Content mode setting. Try setting the Page Content mode to
Graphics or Text and Graphics, see
Send a fax - enter number(s) manually
on page 29, or refer to Page Content
mode in the MFP user guide.
Pressed the Cancel button on the MFP
keyboard to cancel a fax transmission
and the fax was still sent.
Cancellation takes place after making a
selection in the cancellation menu
(displayed after pressing red Stop
button) and acknowledging with OK.
Cancel faxes using the fax menu, see
Canceling a fax on page 34.
No Phone Book button appears. The Phone Book feature has not been
enabled.
Use the HP MFP Digital Sending
Software Configuration utility to enable
the phone book feature.
Not able to locate the Fax settings in
HP Web Jetadmin.
Fax settings in HP Web Jetadmin are
located under the device's status page
drop-down menu.
Select Digital Sending and Fax from the
drop-down menu. For more information,
see HP Web Jetadmin on page 8.
The header is being appended to the top
of the page when I have overlay enabled.
The fax will append the overlay header to
the top of a page when overlay is set,
when the fax has been forwarded.
This is normal operation.
Have a mix of names and numbers in the
recipients box.
This is normal for both names and
numbers to appear, depending on where
they are from, the phone book lists
names, and all other databases list
numbers.
Normal, no action required.
My one page fax prints as two pages. The fax header is being appended to the
top of the fax, pushing text to a second
page.
If you want your one page fax to print on
one page, set the overlay header to
overlay mode.
Document stops feeding in the middle of
faxing.
There might be a jam in the ADF. If there is a jam, see the MFP user guide
for instructions on clearing jams.
The volume for sounds coming from the
fax accessory is too high or too low.
The volume setting needs to be adjusted. See Set the ringer volume on page 23 for
information about changing the sound
volume settings.
ENWW General fax problems 51
Receiving fax problems
Use the table in this section to solve problems that might occur when receiving faxes.
Incoming fax calls are not being answered by the fax accessory (no fax detected).
Cause Solution
The rings-to-answer setting might not be set correctly. Check the rings-to-answer setting.
The phone cord might not be connected properly, or the phone
cord is not working.
Check the installation. Make sure you are using the phone cord
that came with the fax accessory.
The phone line might not be working. Disconnect the fax accessory from the phone jack, and
connect a phone. Try to make a phone call to ensure the phone
line is working.
A voice-messaging service might be interfering with the fax
accessory's ability to answer calls.
Do one of the following:
●Discontinue the messaging service.
●Get a phone line dedicated to fax calls.
●Decrease the rings-to-answer for the fax accessory to a
number less than the rings-to-answer for the voice mail.
Faxes are transmitting or being received very slowly.
Cause Solution
You might be sending or receiving a very complex fax, such as
one with many graphics.
Complex faxes take longer to be sent or received.
The receiving fax machine might have a slow modem speed. The fax accessory only sends the fax at the fastest modem
speed the receiving fax machine can use.
Faxes are transmitting or being received very slowly (continued).
Cause Solution
The resolution at which the fax was sent or is being received
is very high. A higher resolution typically results in better
quality, but also requires a longer transmission time.
If you are receiving the fax, call and ask the sender to decrease
the resolution and resend the fax. If you are sending, decrease
the resolution and change the Page Content mode setting
described under Send a fax - enter number(s) manually
on page 29.
If there is a poor phone-line connection, the fax accessory and
the receiving fax machine slow down the transmission to adjust
for errors.
Cancel and resend the fax. Have the phone company check
the phone line.
Faxes are not printing on the MFP.
Cause Solution
There is no media in the media input tray. Load media. Any faxes received while the input tray is empty
are stored and will print after the tray has been refilled.
52 Chapter 4 Solve fax problems ENWW
Faxes are not printing on the MFP.
Cause Solution
Schedule Printing of Faxes is set. If Schedule Printing of Faxes is enabled, faxes will not print
until it is disabled. If you want to print your faxes, see Enable
or disable the schedule for printing of faxes on page 42.
The MFP is either low on toner or has run out of toner. The MFP stops printing as soon as it is low on toner or runs
out of toner. Any faxes received are stored in memory and print
after the toner has been replaced. For other MFP printing
problems, see the MFP user guide.
Incoming call may be a voice call. Incoming voice calls usually show up in the call report as a
Communication Error (17) As these are voice calls and not
a fax error, no action is needed to be taken. Ensure that those
calling you have a voice number that is different from the fax
number.
ENWW Receiving fax problems 53
Sending fax problems
Use the table in this section to solve problems that might occur when sending faxes.
Problem Cause Solution
Faxes quit during sending. The fax machine to which you are
sending might be malfunctioning.
Try sending to another fax machine.
Your phone line might not be working. Disconnect the fax accessory from the
phone jack, and connect a phone. Try to
make a phone call to ensure the phone
line is working.
Your phone line might be noisy or poor
quality
Try using a lower baud rate to improve
the reliability of transmission. See
maximum baud rate setting.
The fax accessory is receiving faxes
but is not sending them.
If the fax accessory is on a PBX system,
the PBX system might be generating a
dial tone the fax accessory cannot
detect.
Disable the detect dial tone setting.
There might be a poor phone connection. Try again later.
The fax machine to which you are
sending might be malfunctioning.
Try sending to another fax machine.
Your phone line might not be working. Disconnect the fax accessory from the
phone jack, and connect a phone. Try to
make a phone call to ensure the phone
line is working.
Outgoing fax calls keep dialing. The fax accessory automatically redials
a fax number if the Redial on Busy option
is set to on or if the Redial On No Answer
is set on.
This is normal operation. If you do not
want the fax to retry, set Redial on Busy
to 0 and set Redial On No Answer to 0.
Faxes you send are not arriving at the
receiving fax machine.
The receiving fax machine might be
turned off or might have an error
condition, such as being out of paper.
Call the recipient to make sure the fax
machine is turned on and ready to
receive faxes.
A fax might be in memory because it is
waiting to redial a busy number, or there
are other jobs ahead of it waiting to be
sent.
If a fax job is in memory for either of these
reasons, an entry for the job appears in
the fax log. Print the fax activity log, and
check the Result column for jobs with a
Pending designation.
54 Chapter 4 Solve fax problems ENWW
Error codes
If a fax problem occurs which prevents or interrupts sending or receiving of a fax, an error code is
generated that will help in determining the cause of the problem. Error codes show up in the fax activity
log, the fax call report, and the T.30 Protocol Trace (see Service settings on page 63). Print one of
these three reports to obtain the error code. A detailed description of the error codes and the appropriate
action can be found at http://www.hp.com by searching for the Q3701A or HP LaserJet MFP Analog
Fax Accessory 300.
ENWW Error codes 55
Fax error messages
When an analog fax is sent or received on a LaserJet MFP, any errors that occur during the fax process
will be displayed on the MFP control panel and entered into the fax reports. Fax errors can occur for
many reasons and often they are due to interruptions or noise on the telephone connection. Any error
that takes place during the fax process regardless of where it originates will be displayed by the MFP.
If the fax process is interrupted or an error occurs during a fax transmission or reception, a two part
status/error description is generated by the fax subsystem on the MFP. Normal or successful faxes also
generate messages indicating success. The message information consists of a text description and a
numeric code (a few messages don’t include numeric codes). Only the text part of the message will be
displayed on the MFP control panel; however, both the text message and numeric code will be listed in
the Fax Activity Report, Fax Call Report, and the Fax T.30 Trace (these fax reports can be printed out
individually from the MFP control panel – under the Administration > Information and
Administration > Troubleshooting menus). The numeric code is shown in parentheses after the text
part of the message in the reports. For example, if a communication error occurred, the control panel
display would show Fax Failed: Communication Error. The same error would be shown in the Result
field in the Fax Activity Report as Communication Error (17). For this example, the numeric code
associated with this communication error is ‘17’.
The numeric code is generated by the fax modem. Usually a numeric code of (0) indicates a normal
modem response. Some messages will always display a numeric code of (0), whereas other messages
can have a range of numeric codes depending on the circumstances, and a few messages will have no
numeric code. Usually a numeric code of (0) indicates an error was not associated with the fax modem,
but occurred in another part of the fax subsystem. Non-zero error codes give further detail into the
particular action or process that the modem is executing, and they don’t necessarily indicate that there
is a problem with the modem.
In the Send-fax messages on page 57 and Receive-fax messages on page 58 tables, the fax
messages with the most common number codes are given with recommended corrective action. Several
messages that are normal or indicate a normal event are also included in tables. For example, if a fax
was not able to be sent to a busy number, a Fail Busy message will be shown. Nothing is wrong with
the fax subsystem; the message indicates the fax was not completed due to a busy telephone number
at the receiving end. Further troubleshooting information is available in the HP MFP Analog Fax 300
User Guide (available at http://www.hp.com/go/mfpfaxaccessory300).
Persistent error messages with numeric codes different than those listed here require assistance of
customer support. A more detailed listing of the last fax call can be printed out before contacting
customer support to help identify the problem. The detailed fax listing is called a Fax T.30 Trace and
can be printed for the last fax, or it can be set to print whenever a fax error occurs. To print or configure
the Fax T.30 Trace, press Administration, Troubleshooting, and then Fax T.30 Trace. You can then
print the report for the last fax or configure when to print the T.30 trace.
56 Chapter 4 Solve fax problems ENWW
Send-fax messages
Table 4-1 Send-fax messages
Message Error No. Description Action(s)
Cancelled 0Fax was cancelled by user at
control panel of MFP.
None.
Success n/a Fax sent successfully. None.
Fail Busy 0The receiving fax machine is
busy.
The fax will be retired
automatically (if configured),
otherwise try resending fax
later.
No Answer 0The receiving fax machine is
not answering the call.
The receiving fax machine
may be disconnected or
turned off; contact the
receiver to check the
machine. Try resending.
Compression Error Any Fax may be corrupted or not
sent.
Try resending fax.
No Dial 0No dial tone is detected when
sending the fax.
Verify the phone line is active;
set the sending fax to "not" to
detect a dial tone.
Modem Fail Any Unexpected or bad response
from the internal fax modem
to MFP.
Try resending fax; if the error
persists, contact service.
Communication Error 17 or 36 Lost telephone connection
between sender and receiver.
Try resending the fax.
Communication Error Any besides 17 or 36 General communications
issue where the fax
transmission was interrupted
or did not proceed as
expected.
Try resending fax; if the error
persists, contact service.
Space Fail 0Unable to read or write the fax
image file to disk; could be
corrupt MFP disk or no space
available on the MFP's disk.
Try resending fax; if the error
persists, contact service.
Page Fail 0Incompatible page width, or
page had too many bad lines.
Try resending fax; if the error
persists, contact service.
Memory Error 0Out of RAM memory on MFP. If error persists, may need to
add RAM to MFP.
Job Fail Any Fax failure; the fax job did not
complete.
Try resending fax; if the error
persists, contact service.
Power Failure 0A power failure occurred
during the fax transmission on
the sending fax MFP.
Try resending the fax.
No Fax Detected 17 or 36 No fax machine was detected
at receiving end.
Verify fax number and have
receiver verify fax machine is
on and connected; then try
resending fax.
ENWW Fax error messages 57
Receive-fax messages
Table 4-2 Receive-fax messages
Message Error No. Description Action(s)
Success n/a Fax received ok. None.
Blocked n/a Fax reception was blocked by
receiving fax machine using
blocked number feature.
None.
Modem Fail Any Unexpected or bad response
from the internal modem to
the MFP - example is trying to
send a fax just as another fax
is arriving.
Have fax resent; if the error
persists, contact service.
Communication Error 17, 36 Lost telephone connection or
interruption between sender/
receiver.
Have the sender resend the
fax (if the sending machine
does not automatically retry).
Communication Error Any besides 17 or 36 General communications
issue where the fax
transmission was interrupted
or did not proceed as
expected.
Have fax resent; if the error
persists, contact service.
Space Fail 0Unable to read or write image
file to disk; could be corrupt
MFP disk or no space on disk.
Have fax resent; if the error
persists, contact service.
Page Fail 0Incompatible page width or
page had too many bad lines.
Have fax resent; if the error
persists, contact service.
Memory Error 0Out of RAM memory on MFP. If error persists, may need to
add additional RAM memory
to MFP.
Compression Error 0Corrupted fax - the received
image file cannot be decoded.
Have fax resent; enable ECM
(Error Correction Mode) if not
already.
Print Fail 0Corrupted fax - the received
image file cannot be decoded.
Have fax resent; enable ECM
(Error Correction Mode) if not
already.
Poll Invalid 0The fax polling feature
attempted to retrieve a fax
from another machine but no
fax was available.
Contact the administrator of
the fax machine being polled
and verify a fax is available,
and then retry.
Job Fail Any Fax failure; this includes all
non-specific failures.
Have fax resent; if the error
persists, contact service.
Power Failure 0A power failure occurred
during the fax reception.
Have the sender resend the
fax.
No Fax Detected 17, 36 A voice call was made to the
fax.
None
58 Chapter 4 Solve fax problems ENWW
Fax logs and reports
Printing the fax call report (include thumbnail)
The fax call report is a brief report that indicates the status of the last fax that was sent or received. If
you want a thumbnail (a 62 percent reduction of the first page) of the fax printed on this report, select
the Thumbnail on Report setting.
1. On the control panel, touch the Administration icon to open the Administration menu.
2. Touch Information to display the Information menu.
3. Touch Fax Reports to display the Fax Reports menu.
4. Touch Fax Call Report to display the Fax Call Report screen.
5. If you want a thumbnail of first page of the fax, touch THUMBNAIL ON REPORT, and then:
●Touch Yes to include a thumbnail of the first page.
●Touch No to disable printing a thumbnail on the report.
6. Touch Fax Call Report to print the fax call report.
7. Touch Auto Print to set when the printer prints the Fax Call Report.
●Touch Never auto print to never print a Fax Call Report.
NOTE: If you select Never auto print, you will have no printed indication other than the
touchscreen status bar message, that a fax failed to be transmitted, unless you print a fax
activity log.
●Touch Print after any fax job to print a Fax Call Report after a fax is sent or received.
●Touch Print after fax send jobs to print a Fax Call Report after a fax is sent.
●Touch Print after any fax error (default) to print a Fax Call Report after the device detects a
fax error.
●Touch Print after receive errors only to print a Fax Call Report after the device detects a fax
receive error.
ENWW Fax logs and reports 59
To schedule fax call report printing
Use the When To Print Report setting to specify under what conditions you want to print the fax call
report.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Touch Information then Fax Reports.
3. Touch Fax Call Report then To Print Report.
●Touch Never auto print to never print a Fax Call Report.
NOTE: If you select Never auto print, you will have no printed indication other than the
touchscreen status-bar message, that a fax failed to be transmitted unless you print a fax
activity log.
●Touch After any fax job to print a Fax Call Report after a fax is sent or received.
●Touch After fax send jobs to print a Fax Call Report after a fax is sent.
●Touch After any fax error (default) to print a Fax Call Report after the device detects a fax
error.
●Touch After send errors only to print a Fax Call Report after the device detects a fax send
error.
●Touch After receive errors only to print a Fax Call Report after the device detects a fax receive
error.
NOTE: If you select Never, you will have no printed indication other than the touchscreen status-bar
message, that a fax failed to be transmitted unless you print a fax activity log.
Printing the fax activity log
●Date and time of all faxes received, sent, or failed to send
●Identification (phone number, if available)
●Duration (off-hook time)
●Number of pages
●Result (successfully sent, pending, or failed to send which includes error type and code)
The database stores the most recent 500 fax entries (older faxes are deleted from the log). The database
fax entries include any fax session as an entry. For example, a fax session could be a sent fax, received
fax, or firmware upgrades. Depending on the activity, there might be fewer than 500 entries in the report
(unless you sent 500 faxes without receiving any faxes or other completing another activity).
If you want to use the log for record keeping purposes, you should print the log periodically (at least
every 500 faxes) and then clear it.
To print the fax activity log, complete the following steps.
60 Chapter 4 Solve fax problems ENWW
Print the fax activity log
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Information.
3. Scroll to and touch Fax Reports then Fax Activity Log. (Prints report)
Printing the billing code report
The billing code report is a list of the most recent 500 faxes that were successfully sent, listed by billing
code. The following information is provided in this report.
●Billing code number
●Date and time of all faxes that were successfully sent
●Identification number
●Duration (off hook time)
●Number of pages sent
●Result (success)
The database stores the most recent 500 faxes (older faxes are deleted from the database). If you want
to use the report for record keeping purposes, you should print the report periodically (at least every
500 faxes) and then clear it.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Information.
3. Scroll to and touch Fax Reports.
4. Scroll to and touch Billing Codes Report.
5. Touch Print to print the report.
Clearing the fax activity log and billing code report
The fax activity log and the billing code report use the same database. This setting clears the database
and therefore clears both the activity log and the billing report data.
To clear the fax database, complete the following steps.
1. On the control panel, touch the Administration icon to open the Fax menu.
2. Scroll to and touch Resets to open the menu.
3. Scroll to and touch Clear Fax Activity Log.
4. Touch Yes to clear all entries, or touch No to exit and retain the entries.
Printing the blocked fax list report
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Information.
ENWW Fax logs and reports 61
3. Scroll to and touch Fax Reports
4. Touch Blocked Fax List to print the report.
Printing the speed dial list report
A speed dial list report lists the fax numbers assigned to speed dial names.
1. On the control panel, scroll to and touch the Administration icon to open the Administration menu.
2. Scroll to and touch Information.
3. Scroll to and touch Fax Reports.
4. Touch Speed Dial List to print the report.
62 Chapter 4 Solve fax problems ENWW
Service settings
These selections can help with troubleshooting if the corrective action taken under the Error Codes
section is unsuccessful. They are intended to be used when an HP service representative is assisting
you.
These selections are located in one of three places: under Administration > Initial Setup > Fax Setup >
Fax Receive Settings; under Administration > Troubleshooting; or under Administration > Resets. Print
a menu map from the MFP Administration > Information menu to help locate the desired item.
T.30 Trace: The T.30 trace is a printed report which produces a record of all the communications
between the sending and receiving fax machines for the last Fax transmission or reception. The report
has many technical details which are usually beyond the scope of most users. However the report
contains detailed error codes and other information that might be useful in troubleshooting a particular
problem related to sending or receiving a FAX. The report contents might be requested by an HP service
representative when trying to determine the cause of a problem and will help to determine the
appropriate action. (For error code information, see Error codes on page 55.)
Restore Factory Telecom Settings or Restore Default Telecom Settings: This selection resets several
menu changes back to their default settings. This includes the maximum baud rate, ring-burst off time,
V.34, speaker mode, and transmit signal loss.
Transmit Signal Loss: This selection compensates for phone line signal loss. It is not recommended to
modify this setting unless requested to do so by an HP service representative as it might render the fax
inoperable.
V.34: This setting has two values (Normal and Off) that control the modem's baud rate. The Normal
setting allows the modem to select (negotiate with the other modem) any of the supported baud rates
up to 33,600 bps. The Off setting sets the baud rate to 14,400 bps. This setting remains set, until
changed.
Maximum baud rate: This setting is similar to V.34 but provides a list of baud rates to select for operation.
If the fax is having communication errors, use this setting to select slower baud rates to determine if the
communication error is caused by the phone line. Once this setting is set, it remains set until changed.
Speaker mode: This service setting has two modes, Normal and Diagnostic. In Normal mode, the
modem speaker is turned on during dialing through the initial connection and then shuts off. For
Diagnostic mode, the speaker is turned on and remains on for all fax communications until the setting
is returned to Normal.
Ring interval or Ring-burst off time: This setting is used to adjust for some PBX ring signals. Use this
setting when directed by an HP technical support agent.
Ring Frequency: This setting has a range between 1 to 200 Hz. It should be left at its default value of
68 Hz. Use this setting when directed by an HP technical support agent as adjustment procedures
associated with it is beyond the scope of this guide.
These selections are located in Administration > Initial Setup > Fax Setup > Fax Send Settings > Ring
Frequency. Select Custom to activate the menu selection for a specific value.
TCF T.30 Delay: This setting has a range between 60 to 255 ms. It should be left to its default value of
60 ms. Use this setting when directed by an HP technical support agent as adjustment procedures
associated with it is beyond the scope of this guide.
These selections are located under the Administration > Initial Setup > Fax Setup > Fax Send
Settings > TCF T.30 Delay Timer. Select Custom to activate the menu selection for a specific value.
ENWW Service settings 63
TCF T.30 Extend: This setting has a range between 0 to 2550 ms. It should be left to its default value
of 0 ms. Use this setting when directed by an HP technical support agent as adjustment procedures
associated with it is beyond the scope of this guide.
These selections are located under the Administration > Initial Setup > Fax Setup > Fax Send
Settings > TCF Extend. Select Custom to activate the menu selection for a specific value.
64 Chapter 4 Solve fax problems ENWW
Firmware upgrades
The firmware on the HP LaserJet MFP Analog Fax Accessory 300 can be updated. Fax firmware
updates will occur as part of an overall MFP firmware update. For additional information about MFP
firmware updates, refer to MFP service documentation.
NOTE: To update the fax firmware, go to the MFP Web site and download the MFP firmware. The fax
firmware updates are a part of the MFP firmware updates.
ENWW Firmware upgrades 65
66 Chapter 4 Solve fax problems ENWW
A Service and support
ENWW 67
Hewlett-Packard limited warranty statement
HP PRODUCT DURATION OF LIMITED WARRANTY
HP LaserJet MFP Analog Fax Accessory 300 1 year, Limited Warranty
HP warrants to you, the end-user customer, that HP hardware and accessories will be free from defects in materials
and workmanship after the date of purchase, for the period specified above. If HP receives notice of such defects
during the warranty period, HP will, at its option, either repair or replace products which prove to be defective.
Replacement products may be either new or equivalent in performance to new.
HP warrants to you that HP software will not fail to execute its programming instructions after the date of purchase,
for the period specified above, due to defects in material and workmanship when properly installed and used. If
HP receives notice of such defects during the warranty period, HP will replace software which does not execute
its programming instructions due to such defects.
HP does not warrant that the operation of HP products will be uninterrupted or error free. If HP is unable, within a
reasonable time, to repair or replace any product to a condition as warranted, you will be entitled to a refund of
the purchase price upon prompt return of the product.
HP products may contain remanufactured parts equivalent to new in performance or may have been subject to
incidental use.
Warranty does not apply to defects resulting from (a) improper or inadequate maintenance or calibration, (b)
software, interfacing, parts or supplies not supplied by HP, (c) unauthorized modification or misuse, (d) operation
outside of the published environmental specifications for the product, or (e) improper site preparation or
maintenance.
TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE WARRANTIES ARE EXCLUSIVE AND NO OTHER
WARRANTY OR CONDITION, WHETHER WRITTEN OR ORAL, IS EXPRESSED OR IMPLIED AND HP
SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY,
SATISFACTORY QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE. Some countries/regions, states or
provinces do not allow limitations on the duration of an implied warranty, so the above limitation or exclusion might
not apply to you. This warranty gives you specific legal rights and you might also have other rights that vary from
country/region to country/region, state to state, or province to province. HP's limited warranty is valid in any country/
region or locality where HP has a support presence for this product and where HP has marketed this product. The
level of warranty service you receive may vary according to local standards. HP will not alter form, fit or function
of the product to make it operate in a country/region for which it was never intended to function for legal or regulatory
reasons.
TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS WARRANTY STATEMENT ARE YOUR
SOLE AND EXCLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL HP OR ITS
SUPPLIERS BE LIABLE FOR LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL
(INCLUDING LOST PROFIT OR DATA), OR OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR
OTHERWISE. Some countries/regions, states or provinces do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
THE WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE EXTENT LAWFULLY
PERMITTED, DO NOT EXCLUDE, RESTRICT OR MODIFY AND ARE IN ADDITION TO THE MANDATORY
STATUTORY RIGHTS APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.
68 Appendix A Service and support ENWW
HP Customer Care
World Wide Web
Solutions to many fax accessory issues can be found at http://www.hp.com/go/mfpfaxaccessory300.
Go to the Support site and search for HP LaserJet MFP Analog Fax Accessory 300. This Web site
includes troubleshooting help, information about fax maintenance and use, manuals, FAQs, software
updates, and more.
NOTE: Check the HP Web site for additional information regarding updates or changes to the product
that might have been made after the printing of this document. Go to http://www.hp.com and search for
"Q3701A". Use the Product quick links to go to the product manuals and look if the Errata document
is present. The errata document identifies the most current changes to the product.
E-mail
For the quickest response, visit http://www.hp.com and click Contact HP. E-mail support is in English
only.
Phone
Search http://www.hp.com for HP LaserJet MFP Analog Fax Accessory 300, and look for a link to contact
support. You can find telephone contact information which can help with problem resolution.
ENWW HP Customer Care 69
70 Appendix A Service and support ENWW
B Specifications
This chapter contains specifications for the fax accessory. The sections described here include:
●Fax accessory product specifications
●Replacement parts and accessories
ENWW 71
Fax accessory product specifications
Environmental specifications
Operating environment ●Temperature: 10 to 32.5° C (50 to 91° F)
●Relative Humidity: 20 to 80 percent (no condensation)
Storage environment ●Temperature: -20° C to 40° C (-4° F to 104° F)
●Relative Humidity: Less than 95 percent (no
condensation)
Fax specifications
Fax compatibility ●CCIT/ITU-T Group 3, EIA/TIA Class 1, Class 2.1
Phone connector ●RJ11
Compression methods ●MH, MR, MMR, and JBIG
Transmission speeds and standards supported ●V.17 at 14,400, 12,000, 9,600, 7,200 bps
●V.33 at 14,400, 12,000 bps
●V.29 at 9,600, 7,200 bps
●V.27 at 4,800, 2,400 bps
●V.34 at 16,800, 19,200, 21,600, 24,000, 26,400, 28,800,
31,200, 33,600 bps
Modem speed ●Up to 33.6K bits per second (bps)
Speed dialing ●Yes
Fax resolution, (send and receive) ●Standard - 200 x 100 dots per inch (dpi)
●Fine - 200 x 200 dpi
●Superfine - 300 x 300 dpi
●Ultrafine - 200 x 400 (receive only)
●Ultrafine - 400 x 400 (receive only)
72 Appendix B Specifications ENWW
Replacement parts and accessories
You can obtain replacement parts for the fax accessory by contacting your sales representative or your
Hewlett-Packard dealer.
ENWW Replacement parts and accessories 73
74 Appendix B Specifications ENWW
C Regulatory Information
This section contains the following regulatory information:
●Environmental Product Stewardship Program
●Declaration of conformity
●US Federal Communications Commission
●Canadian Department of Communications
●Other regulatory information
ENWW 75
Environmental Product Stewardship Program
Protecting the environment
Hewlett-Packard Company is committed to providing quality products in an environmentally sound
manner. This product has been designed with several attributes to minimize impacts on our environment.
Plastics
Plastic parts over 25 grams are marked according to international standards that enhance the ability to
identify plastics for recycling purposes at the end of the product's life.
Material restrictions
This HP product does not contain added mercury.
This HP product contains lead in solder and might require special handling at end-of-life.
Disposal of Waste Equipment by Users in Private Households in the European Union
This symbol on the product or on its packaging indicates that this product must not be disposed of with
your other household waste. Instead, it is your responsibility to dispose of your waste equipment by
handing it over to a designated collection point for the recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and ensure that it is recycled in a manner that protects human health
and the environment. For more information about where you can drop off your waste equipment for
recycling, please contact your local city office, your household waste disposal service or the shop where
you purchased the product.
For more information
See http://www.hp.com/go/environment or http://www.hp.com/hpinfo/community/environment/ for more
information about HP's environmental programs, which include the following:
●Product environmental profile sheet for this and many related HP products
●HP's commitment to the environment
●HP's environmental management system
●HP's end-of-life product return and recycling program
●Material Safety Data Sheets
76 Appendix C Regulatory Information ENWW
Declaration of conformity
Declaration of Conformity
according to ISO/IEC 17050-1 and EN 17050-1
Manufacturer's Name: Hewlett-Packard Company
Manufacturer's Address: 11311 Chinden Boulevard,
Boise, Idaho 83714-1021, USA
declares, that the product
Product Name: HP LaserJet MFP Analog Fax Accessory
Regulatory Model Number:2) BOISB-0308-00
Product Numbers Q3701-60001, Q3701-60002, Q3701-60004, Q3701-60022
Product Options All
conforms to the following Product Specifications:
Safety: IEC 60950-1:2001 / EN60950-1: 2001 +A11
EMC: CISPR22:1997 / EN55022:1998 - Class A1)3)
EN 55024:1998 +A1:2002 +A2:2003
FCC Title 47 CFR, Part 15 Class A3) / ICES-003, Issue 4
GB9254-1998, GB17625.1-1998 / CNS13438
Telecom: FCC Rules Part 68
TBR-21:1998
Supplementary Information:
The product herewith complies with the requirements of the EMC Directive 89/336/EEC and the Low Voltage Directive 2006/95/EC, the R&TTE
Directive 1999/5/EC (Annex II) and carries the CE-Marking accordingly.
This Device complies with Part 15 of the FCC Rules. Operation is subject to the following two Conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
1) The product was tested in a typical configuration with Hewlett-Packard Personal Computer Systems.
Compliance testing of product to standard with exception of Clause 9.5, which is not yet in effect.
2) For regulatory purposes, this product is assigned a Regulatory model number. This number should not be confused with the product name
or the product number(s).
3) Warning: This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
Boise, Idaho 83714-1021, USA
October 24th, 2007
For Regulatory Topics only, contact:
European Contact: Your Local Hewlett-Packard Sales and Service Office or Hewlett-Packard Gmbh,Department HQ-TRE / Standards
Europe, Herrenberger Straße 140, D-71034 Böblingen, Germany, (FAX: +49-7031-14-3143)
USA Contact: Product Regulations Manager, Hewlett-Packard Company, PO Box 15, Mail Stop 160, Boise, Idaho 83707-0015, USA,
(Phone: 208-396-6000)
ENWW Declaration of conformity 77
US Federal Communications Commission
FCC Part 15 Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
WARNING! Any changes or modifications to the fax accessory that are not expressly approved by HP
could void the user's authority to operate this equipment.
NOTE: Use of a shielded interface cable is required to comply with the Class A limits of the FCC rules
FCC Part 68 Telecom
If requested, you must be prepared to provide the telephone company with the following information for
the SocketModem card included within this product:
Manufacturer: Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, MN 55112
USA
Trade Name: Modem Module
Model Number: MT5634SMI
FCC Registration No: AU7-USA-25814-M5-E
Ringer Equivalence: 0.3B
Modular Jack (USOC): RJ11C or RJ11W (single line)
Service Center in USA: U.S.A.
(763) 785-3500
(763) 785-9874 Fax
The equipment complies with FCC Rules, Part 68. The Socket Modem Module has a label that contains,
along with other information, the FCC registration number and ringer equivalence number (REN) for this
equipment. If requested, this information must be provided to the telephone company. The REN is used
to determine the quantity of devices which may be connected to the telephone line. Excessive RENS
on the telephone line may result in the devices not ringing in response to an incoming call. In most, but
not all areas, the sum of the RENS should not exceed five (5.0). To be certain of the number of devices
that may be connected to the line, as determined by the total RENS, contact the Telephone Company
to determine the maximum REN for the calling area.
This equipment uses the following USOC jacks: RJ11C or RJ11W (single line)
78 Appendix C Regulatory Information ENWW
An FCC compliant telephone cord and modular plug is provided with this equipment. This equipment is
designed to be connected to the telephone network or premises wiring using a compatible modular jack
with is Part 68 compliant. This equipment cannot be used on telephone company provided coin service.
Connection to Party Line Service is subject to state tariffs. If this equipment causes harm to the telephone
network, the telephone company will notify you in advance that temporary discontinuance of service
may be required. If advance notice isn't practical, the Telephone Company will notify the customer as
soon as possible. Also you will be advised of your right to file a complaint with the FCC if you believe it
is necessary. The telephone company may make changes in its facilities, equipment, operations, or
procedures that could affect the operation of the equipment. If this happens, the telephone company
will provide advance notice in order for you to make the necessary modifications in order to maintain
uninterrupted service. If trouble is experienced with this equipment, please contact HP customer service
by using the contact information provided in the Customer Support section of this manual for
troubleshooting, repair and (or) warranty information. If the trouble is causing harm to the telephone
network, the Telephone Company may request you remove the equipment from the network until the
problem is resolved. The following repairs can be done by the customer: Replace any original equipment
that came with the product and the telephone cord. It is also recommended that the customer install an
AC surge arrestor in the AC outlet of the host equipment to which the device is connected. This is to
avoid damage to the equipment caused by lightning strikes and other electrical surges.
Telephone Consumer Protection Act (US)
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer
or other electronic device, including fax machines, to send any message unless such message clearly
contains, in a margin at the top or bottom of each transmitted page or on the first page of the
transmission, the date and time it is sent and an identification of the business, other entity, or individual
sending the message and the telephone number of the sending machine or such business, or other
entity, or individual. (The telephone number provided cannot be a 900 number or any other number for
which charges exceed local or long distance transmission charges). In order to program this information
into your facsimile, please see Required fax settings on page 4 in Chapter 1.
ENWW US Federal Communications Commission 79
Canadian Department of Communications
This equipment complies with Canadian EMC Class A requirements.
<< Conforme á la classe A des normes canadiennes de compatibilité électromagnétiques (CEM). >>
Canadian Limitations Notice
Notice: The ringer equivalence number (REN) assigned to each terminal device provides an indication
of the maximum number of terminals allowed to be connected to a telephone interface. The termination
on an interface may consist of any combination of devices subject only to the requirement that the sum
of the ringer equivalence numbers of all the devices does not exceed 5.
Notice: The Industry Canada label identifies certified equipment. This certification means that the
equipment meets certain telecommunications network protective, operational, and safety requirements.
The Industry Canada label does not guarantee the equipment will operate to the user's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities
of the local telecommunications company. The equipment must also be installed using an acceptable
method of connection. The customer should be aware that compliance with the above conditions may
not prevent degradation of service in some situations. Repairs to certified equipment should be made
by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations
made by the user to this equipment or equipment malfunctions may give the telecommunications
company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility,
telephone lines and internal metallic water pipe system, if present, are connected together. This
precaution may be particularly important in rural areas.
CAUTION: Users should not attempt to make such connections themselves, but should contact the
appropriate electric inspection authority, or electrician, as appropriate.
Notice: The Ringer Equivalence Number (REN) assigned to each terminal device provides an
identification of the maximum number of terminals allowed to be connected to a telephone interface.
The termination of an interface may consist of any combination of devices subject only to the requirement
that this sum of Ringer Equivalence Number of all the devices does not exceed five (5.0). The standard
connecting arrangement code (telephone jack type) for equipment with direct connections to the
telephone network is CA11A.
80 Appendix C Regulatory Information ENWW
Other regulatory information
Regulatory information for EU countries/regions
This equipment has been designed to work in all countries/regions of the European Economic Area
(Public Switched Telephone Networks). Network compatibility is dependent on internal software
settings. Contact your equipment supplier if it is necessary to use the equipment on a different telephone
network. For further product support, contact Hewlett-Packard at the phone numbers provided in the
support flyer that came with the product.
New Zealand Telecom Warning Notice
1. The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has
accepted that the item complies with minimum conditions for connection to its network. It indicates
no endorsement of the product by Telecom, nor does it provide any sort of warranty. Above all, it
provides no assurance that any item will work correctly in all respects with another item of
Telepermitted equipment of a different make or model, nor does it imply that any product is
compatible with all of Telecom's network services.
This equipment is not capable under all operating conditions of correct operation at the higher
speed which it is designated. 33.6 kbps and 56 kbps connections are likely to be restricted to lower
bit rates when connected to some PSTN implementations. Telecom will accept no responsibility
should difficulties arise in such circumstances.
2. Immediately disconnect this equipment should it become physically damaged, and arrange for its
disposal or repair.
3. This modem shall not be used in any manner, which could constitute a nuisance to other Telecom
customers.
4. This device is equipped with pulse dialing, while the Telecom standard is DTMF tone dialing. There
is no guarantee that Telecom lines will always continue to support pulse dialing.
Use of pulse dialing, when this equipment is connected to the same line as other equipment, may
give rise to 'bell tinkle' or noise and may also cause a false answer condition. Should such problems
occur, the user should not contact the Telecom Faults Service.
The preferred method of dialing is to use DTMF tones, as this is faster than pulse (decadic) dialing
and is readily available on almost all New Zealand telephone exchanges.
5. Warning Notice: No '111' or other calls can be made from this device during a mains power failure.
6. This equipment may not provide for the effective hand-over of a call to another device connected
to the same line.
7. Some parameters required for compliance with Telecom's Telepermit requirements are dependent
on the equipment (PC) associated with this device. The associated equipment shall be set to
operate within the following limits for compliance with Telecom's Specifications:
For repeat calls to the same number:
●There shall be no more than 10 call attempts to the same number within any 30-minute period
for any single manual call initiation, and
●The equipment shall go on-hook for a period of not less than 30 seconds between the end of
one attempt and the beginning of the next attempt.
ENWW Other regulatory information 81
For automatic calls to different numbers:
●The equipment shall be set to ensure that automatic calls to different numbers are spaced
such that there is no less than 5 seconds between the end of one call attempt and the
beginning of another.
For automatically answered incoming calls:
●The equipment shall be set to ensure that calls are answered between 3 and 30 seconds of
receipt of ringing.
8. For correct operation, total of the RN's of all devices connected to a single line at any time should
not exceed 5.
South African Notice
This modem must be used in conjunction with an approved surge protection device.
TAIWAN BSMI Class A Warning
82 Appendix C Regulatory Information ENWW
Index
A
accessories 73
activity log 61
B
background setting
copying colored paper 15
removing from transmitted
faxes 15
billing code report
printing 61
billing codes 13
blocked fax list report
printing 61
browser, Web
remote configuration 8
C
call report 59, 60
canceling a fax 34
clearing log/report data 61
company name 5
configuration
remote 8
contacting HP 69
customer support 69
D
dark/light setting for transmitted
faxes 15
database 61
date/time setting 4
declaration of conformity 77
destination paper bin 18
dial tone detection, setting 10
dialing mode
setting 11
dialing prefix
setting 11
digital sending utility, remote
configuration 9
DSS. See digital sending utility
E
embedded Web server 8
environmental specifications 72
error
codes 55
error correction mode
settings 21
EWS. See embedded Web server
F
fax
canceling 34
configuration wizard 4
feeding problems 51
printing 42
receiving 35
required settings 4
resolution 72
send a fax using one touch
speed dial 31
sending 29
fax header 5
fax number confirmation 15
fax number speed dial
matching 16
feeding problems 51
firmware upgrades 65
fit-to-page 17
forwarding a fax 41
G
graphics, low quality 29
group dial. See speed dial
J
JBIG compression
setting 14
L
LAN fax 1, 4
light/dark setting for transmitted
faxes 15
location 5
locked fax printing 42
log/report
activity log 61
activity log, clearing 61
billing code report 61
billing report, clearing 61
blocked fax list report 61
fax call report 59, 60
speed dial list report 62
M
memory lock
disabling 42
enabling 42
PIN 40
memory, saving and deleting
faxes 29
menu, fax settings 4
MFP. See multifunction product
modem speed 52, 72
multifunction product 1
N
not configured 4
O
one touch speed dial 31
output paper bin. See destination
paper bin
overlay header
setting 10
ENWW Index 83
P
paper tray selection 18
parts 2
pause, when dialing 29
PBX systems troubleshooting 54
phone book 32
phone lines troubleshooting 54
phone number 5
phone support 69
photos, low quality 29
PIN
changing 40
creating 40
resetting 40
prefix
automatic dialing 11
printing locked faxes 42
pulse dialing
setting 11
R
receiving faxes 35
redial interval, setting 12
redial-on-busy
setting 12
regulatory statements
declaration of conformity 77
remote configuration
digital sending utility 9
Web browser 8
Web Jetadmin 8
replacement parts 73
required settings
country/region 4
resolution
setting 13
resolution, faxing 72
rings-to-answer 17
S
secure settings 40
sending a fax
delete multiple recipients 36
to multiple recipients 36
using phone book
numbers 32
service settings 63
settings
billing codes 13
change light/dark setting 15
destination paper bin 18
dial tone detection 10
dialing mode 11
dialing prefix 11
error correction mode 21
fax forwarding 41
fax number confirmation 15
fax number speed dial
matching 16
fit-to-page 17
JBIG compression 14
memory lock 42
menu 4
overlay header 10
paper tray selection 18
redial interval 12
redial-on-busy 12
required 4
resolution 13
rings-to-answer 17
stamp received faxes 17
settings menu does not appear 4
sharpness setting
for transmitted faxes 14
slow fax reception 52
slow fax transmission 54
specifications 72
speed dial
creating 36
delete 36
list report 62
stamp received faxes 17
status message bar 28
status, fax accessory page 49
storage, environment 72
support 69
T
T.30 Trace report 63
tone dialing
setting 11
troubleshooting
fax settings menu does not
appear 4
PBX systems 54
slow fax reception 52
slow fax transmission 54
V
voice calls and retries 39
VoIP 45
W
warranty
product 67, 68
Web Jetadmin, remote
configuration 8
wizard, fax configuration 4
84 Index ENWW

Navigation menu
