1/2
C 140
Alcatel Vacuum Technology France - ASM 182 TD+ - ASM 192 T2D+ User’s Manual
Helium pollution prevention
Edition 02 - June 01
GB 00270 -
Purpose
Access
authorization
The helium pollution prevention function avoids the detector to
be polluted by helium when the part or installation to be tested
contains a lot of helium.
Leak detector in test mode, if the signal increases quickly above
depollution reject point, the cycle is automatically ended and
the leak detector stays in stand-by mode until the helium has
decreased.
Do you have access to this operation function? C 50
F1
F3
F2
F4
AUDIO :4
DIGITAL VOICE :4
F1
F3
F2
F4
SNIF. PROBE CLOGGED
REJECT POINT:1.0E-07
DEPOLLUTION: off
F1
F3
F2
F4
SNIF. PROBE CLOGGED
REJECT POINT:1.0E-07
DEPOLLUTION: on
REJECT POINT:1.0E-05
F1
F3
F2
F4
SNIF. PROBE CLOGGED
REJECT POINT:1.0E-07
DEPOLLUTION: on
REJECT POINT:1.0E-05
Activate the function
Reminder
Operating principle of the control panel
C 20
Press the key activated
SET POINTS
F3
+
F3
F4
x 2
NEXT
2/2
C 140
Alcatel Vacuum Technology France - ASM 182 TD+ - ASM 192 T2D+ User’s Manual
Helium pollution prevention
Edition 02 - June 01GB 00270 -
Depollution
reject point
Deactivate
the function
The procedure is the same as for activating the function but
instead of pressing , press .
F1
F3
F2
F4
SNIF. PROBE CLOGGED
REJECT POINT:1.0E-07
DEPOLLUTION: on
REJECT POINT:1.0E-06
F1
F3
F2
F4
SNIF. PROBE CLOGGED
REJECT POINT:1.0E-07
DEPOLLUTION: on
REJECT POINT:1.0E-06
F1
F3
F2
F4
READY FOR CYCLE
INLET ...
Adjustment of a value C 20
Adjust depollution reject
point.
F4
SET POINTS
