Package ‘causalLearning’
September 7, 2018
Title Methods for heterogeneous treatment effect estimation
Version 1.0.0
Description The main functions are cv.causalBoosting and bagged.causalMARS,
which build upon the simpler causalBoosting and causalMARS functions. All of
these functions have their own predict methods.
Depends R (>= 3.3.0)
Imports ranger
License GPL-2
LazyData true
RoxygenNote 6.0.1
NeedsCompilation yes
Author Scott Powers [aut, cre],
Junyang Qian [aut],
Trevor Hastie [aut],
Robert Tibshirani [aut]
Maintainer Scott Powers <saberpowers@gmail.com>
Rtopics documented:
bagged.causalMARS .................................... 2
causalBoosting ....................................... 3
causalMARS ........................................ 4
cv.causalBoosting...................................... 7
pollinated.ranger ...................................... 8
predict.bagged.causalMARS ................................ 9
predict.causalBoosting ................................... 9
predict.causalMARS .................................... 10
predict.causalTree...................................... 11
predict.cv.causalBoosting.................................. 11
predict.pollinated.ranger .................................. 12
predict.PTOforest...................................... 13
PTOforest.......................................... 13
stratify............................................ 14
Index 16
1
2bagged.causalMARS
bagged.causalMARS Fit a bag of causal MARS models
Description
Fit a bag of causal MARS models
Usage
bagged.causalMARS(x, tx, y, nbag = 20, maxterms = 11, nquant = 5,
degree = ncol(x), eps = 1, backstep = FALSE, propensity = FALSE,
stratum = rep(1, nrow(x)), minnum = 5, verbose = FALSE)
Arguments
xmatrix of covariates
tx vector of treatment indicators (0 or 1)
yvector of response values
nbag number of models to bag
maxterms maximum number of terms to include in the regression basis (e.g. maxterms = 11
means intercept + 5 pairs added)
nquant number of quantiles used in splitting
degree max number of different predictors that can interact in model
eps shrinkage factor for new term added
backstep logical: should out-of-bag samples be used to prune each model? otherwise full
regression basis is used for each model
propensity logical: should propensity score stratification be used?
stratum optional vector giving propensity score stratum for each observation (only used
if propensity = TRUE)
minnum minimum number of observations in each arm of each propensity score stratum
needed to estimate regression coefficients for basis (only used if propensity = TRUE)
verbose logical: should progress be printed to console?
Value
an object of class bagged.causalMARS, which is itself a list of causalMARS objects
Examples
# Randomized experiment example
n = 100 # number of training-set patients to simulate
p = 10 # number of features for each training-set patient
# Simulate data
x = matrix(rnorm(n * p), nrow = n, ncol = p) # simulate covariate matrix
tx_effect = x[, 1] + (x[, 2] > 0) # simple heterogeneous treatment effect
tx = rbinom(n, size = 1, p = 0.5) # random treatment assignment
causalBoosting 3
y = rowMeans(x) + tx * tx_effect + rnorm(n, sd = 0.001) # simulate response
# Estimate bagged causal MARS model
fit_bcm = causalLearning::bagged.causalMARS(x, tx, y, nbag = 10)
pred_bcm = predict(fit_bcm, newx = x)
# Visualize results
plot(tx_effect, pred_bcm, main = 'Bagged causal MARS',
xlab = 'True treatment effect', ylab = 'Estimated treatment effect')
abline(0, 1, lty = 2)
causalBoosting Fit a causal boosting model
Description
Fit a causal boosting model
Usage
causalBoosting(x, tx, y, num.trees = 500, maxleaves = 4, eps = 0.01,
splitSpread = 0.1, x.est = NULL, tx.est = NULL, y.est = NULL,
propensity = FALSE, stratum = NULL, stratum.est = NULL,
isConstVar = TRUE)
Arguments
xmatrix of covariates
tx vector of treatment indicators (0 or 1)
yvector of response values
num.trees number of shallow causal trees to build
maxleaves maximum number of leaves per causal tree
eps learning rate
splitSpread how far apart should the candidate splits be for the causal trees? (e.g. splitSpread = 0.1)
means we consider 10 quantile cutpoints as candidates for making split
x.est optional matrix of estimation-set covariates used for honest re-estimation (ig-
nored if tx.est = NULL or y.est = NULL)
tx.est optional vector of estimation-set treatment indicators (ignored if x.est = NULL
or y.est = NULL)
y.est optional vector of estimation-set response values (ignored if x.est = NULL or
y.est = NULL)
propensity logical: should propensity score stratification be used?
stratum optional vector giving propensity score stratum for each observation (only used
if propensity = TRUE)
stratum.est optional vector giving propensity score stratum for each estimation-set observa-
tion (ignored if x.est = NULL or tx.est = NULL or y.est = NULL)
isConstVar logical: for the causal tree splitting criterion (T-statistc), should it be assumed
that the noise variance is the same in treatment and control arms?
4causalMARS
Details
This function exists primarily to be called by cv.causalBoosting because the num.trees parameter
generally needs to be tuned via cross-validation.
Value
an object of class causalBoosting with attributes:
• CBM: a list storing the intercept, the causal trees and eps
• tauhat: matrix of treatment effects for each patient for each step
• G1: estimated-treatment conditional mean for each patient
• G0: estimated-control conditional mean for each patient
• err.y: training error at each step, in predicting response
• num.trees: number of trees specified by function call
Examples
# Randomized experiment example
n = 100 # number of training-set patients to simulate
p = 10 # number of features for each training-set patient
# Simulate data
x = matrix(rnorm(n * p), nrow = n, ncol = p) # simulate covariate matrix
tx_effect = x[, 1] + (x[, 2] > 0) # simple heterogeneous treatment effect
tx = rbinom(n, size = 1, p = 0.5) # random treatment assignment
y = rowMeans(x) + tx * tx_effect + rnorm(n, sd = 0.001) # simulate response
# Estimate causal boosting model
fit_cb = causalBoosting(x, tx, y, num.trees = 500)
pred_cb = predict(fit_cb, newx = x, num.trees = 500)
# Visualize results
plot(tx_effect, pred_cb, main = 'Causal boosting',
xlab = 'True treatment effect', ylab = 'Estimated treatment effect')
abline(0, 1, lty = 2)
causalMARS Fit a causal MARS model
Description
Fit a causal MARS model
Usage
causalMARS(x, tx, y, maxterms = 11, nquant = 5, degree = ncol(x),
eps = 1, backstep = FALSE, x.val = NULL, tx.val = NULL,
y.val = NULL, propensity = FALSE, stratum = rep(1, nrow(x)),
stratum.val = NULL, minnum = 5)
causalMARS 5
Arguments
xmatrix of covariates
tx vector of treatment indicators (0 or 1)
yvector of response values
maxterms maximum number of terms to include in the regression basis (e.g. maxterms = 11
means intercept + 5 pairs added)
nquant number of quantiles used in splitting
degree max number of different predictors that can interact in model
eps shrinkage factor for new term added
backstep logical: after building out regression basis, should backward stepwise selection
be used to create a sequence of models, with the criterion evaluated on a valida-
tion set to choose among the sequence?
x.val optional matrix of validation-set covariates (only used if backstep = TRUE)
tx.val optional vector of validation-set treatment indicators (only used if backstep = TRUE)
y.val optional vector of validation-set response values (only used if backstep = TRUE)
propensity logical: should propensity score stratification be used?
stratum optional vector giving propensity score stratum for each observation (only used
if propensity = TRUE)
stratum.val optional vector giving propensity score stratum for each validation-set observa-
tion (only used if propensity = backstep = TRUE)
minnum minimum number of observations in each arm of each propensity score stratum
needed to estimate regression coefficients for basis (only used if propensity = TRUE)
Details
parallel arms mars with backward stepwise BOTH randomized case and propensity stratum. data
structures: model terms (nodes) are numbered 1, 2, ... with 1 representing the intercept. forward
stepwise: modmatrix contains basis functions as model is built up – two columns are added at each
step. Does not include a column of ones for tidiness, we always add two terms, even when term
added in linear (so that reflected version is just zero). backward stepwise: khat is the sequence
of terms deleted at each step, based on deltahat = relative change in rss. rsstesthat is rss over test
(validation) set achieved by each reduced model in sequence- used later for selecting a member of
the sequence. active2 contains indices of columns with nonzero norm
Value
an object of class causalMARS with attributes:
• parent: indices of nodes that are parents at each stage
• childvar: index of predictor chosen at each forward step
• childquant: quantile of cutoff chosen at each forward step
• quant: quantiles of the columns of x
• active: indices of columns with nonzero norm
• allvars: list of variables appearing in each term
• khat: the sequence of terms deleted at each step
• deltahat: relative change in rss
6causalMARS
• rsstesthat: validation-set rss achieved by each model in sequence
• setesthat: standard error for rsstesthat
• tim1: time elapsed during forward stepwise phase
• tim2: total time elapsed
• x
• tx
• y
• maxterms
• eps
• backstep
• propensity
• x.val
• tx.val
• y.val
• stratum
• stratum.val
• minnum
Examples
# Randomized experiment example
n = 100 # number of training-set patients to simulate
p = 10 # number of features for each training-set patient
# Simulate data
x = matrix(rnorm(n * p), nrow = n, ncol = p) # simulate covariate matrix
tx_effect = x[, 1] + (x[, 2] > 0) # simple heterogeneous treatment effect
tx = rbinom(n, size = 1, p = 0.5) # random treatment assignment
y = rowMeans(x) + tx * tx_effect + rnorm(n, sd = 0.001) # simulate response
# Estimate causal MARS model
fit_cm = causalLearning::causalMARS(x, tx, y)
pred_cm = predict(fit_cm, newx = x)
# Visualize results
plot(tx_effect, pred_cm, main = 'Causal MARS',
xlab = 'True treatment effect', ylab = 'Estimated treatment effect')
abline(0, 1, lty = 2)
cv.causalBoosting 7
cv.causalBoosting Fit a causal boosting model with cross validation
Description
Fit a causal boosting model with cross validation
Usage
cv.causalBoosting(x, tx, y, num.trees = 500, maxleaves = 4, eps = 0.01,
splitSpread = 0.1, type.measure = c("effect", "response"), nfolds = 5,
foldid = NULL, propensity = FALSE, stratum = NULL, isConstVar = TRUE)
Arguments
xmatrix of covariates
tx vector of treatment indicators (0 or 1)
yvector of response values
num.trees number of shallow causal trees to build
maxleaves maximum number of leaves per causal tree
eps learning rate
splitSpread how far apart should the candidate splits be for the causal trees? (e.g. splitSpread = 0.1)
means we consider 10 quantile cutpoints as candidates for making split
type.measure loss to use for cross validation: ’response’ returns mean-square error for predict-
ing response in each arm. ’effect’ returns MSE for treatment effect using honest
over-fit estimation.
nfolds number of cross validation folds
foldid vector of fold membership
propensity logical: should propensity score stratification be used?
stratum optional vector giving propensity score stratum for each observation (only used
if propensity = TRUE)
isConstVar logical: for the causal tree splitting criterion (T-statistc), should it be assumed
that the noise variance is the same in treatment and control arms?
Value
an object of class cv.causalBoosting which is an object of class causalBoosting with these
additional attributes:
• num.trees.min: number of trees with lowest CV error
• cvm: vector of mean CV error for each number of trees
• cvsd: vector of standard errors for mean CV errors
8pollinated.ranger
Examples
# Randomized experiment example
n = 100 # number of training-set patients to simulate
p = 10 # number of features for each training-set patient
# Simulate data
x = matrix(rnorm(n * p), nrow = n, ncol = p) # simulate covariate matrix
tx_effect = x[, 1] + (x[, 2] > 0) # simple heterogeneous treatment effect
tx = rbinom(n, size = 1, p = 0.5) # random treatment assignment
y = rowMeans(x) + tx * tx_effect + rnorm(n, sd = 0.001) # simulate response
# Estimate causal boosting model with cross-validation
fit_cv = causalLearning::cv.causalBoosting(x, tx, y)
fit_cv$num.trees.min.effect # number of trees chosen by cross-validation
pred_cv = predict(fit_cv, newx = x)
# Visualize results
plot(tx_effect, pred_cv, main = 'Causal boosting w/ CV',
xlab = 'True treatment effect', ylab = 'Estimated treatment effect')
abline(0, 1, lty = 2)
pollinated.ranger Pollinate a fitted ranger random forest model
Description
Pollinate a fitted ranger random forest model
Usage
pollinated.ranger(object, x, y)
Arguments
object a fitted ranger object
xmatrix of covariates
yvector of response values
Value
an object of class pollinated.ranger which is a ranger object that has been pollinated with the
data in (x, y)
predict.bagged.causalMARS 9
predict.bagged.causalMARS
Make predictions from a bag of fitted causal MARS models
Description
Make predictions from a bag of fitted causal MARS models
Usage
## S3 method for class 'bagged.causalMARS'
predict(object, newx, type = c("average", "all"),
...)
Arguments
object a fitted bagged.causalMARS object
newx matrix of new covariates for which estimated treatment effects are desired
type type of prediction required: ’average’ returns a vector of the averages of the
bootstrap estimates. ’all’ returns a matrix of all of the bootstrap estimates.
... ignored
Value
a vector of estimated personalized treatment effects corresponding to the rows of newx
predict.causalBoosting
Make predictions from a fitted causal boosting model
Description
Make predictions from a fitted causal boosting model
Usage
## S3 method for class 'causalBoosting'
predict(object, newx, newtx = NULL,
type = c("treatment.effect", "conditional.mean", "response"),
num.trees = 1:object$num.trees, honest = FALSE, naVal = 0, ...)
10 predict.causalMARS
Arguments
object a fitted causalBoosting object
newx matrix of new covariates for which estimated treatment effects are desired
newtx option vector of new treatment assignments (only used if type = 'response')
type type of prediction required: ’treatment.effect’ returns estimated treatment effect.
’conditional.mean’ returns two predictions, one for each arm. ’response’ returns
prediction for arm corresponding to newtx.
num.trees number(s) of shallow causal trees to use for prediction
honest logical: should honest re-estimates of leaf means be used for prediction? This
requires that x.est, tx.est, y.est were specified when the causal boosting
model was fit
naVal value with which to replace NA predictions
... ignored
Value
a vector or matrix of predictions corresponding to the rows of newx
predict.causalMARS Make predictions from a fitted causal MARS model
Description
Make predictions from a fitted causal MARS model
Usage
## S3 method for class 'causalMARS'
predict(object, newx, active, ...)
Arguments
object a fitted causalMARS object
newx matrix of new covariates for which estimated treatment effects are desired
active indices of columns with nonzero norm (defaults to model selected via backward
stepwise phase, or the full model if backstep = FALSE)
... ignored
Value
a vector of estimated personalized treatment effects corresponding to the rows of newx
predict.causalTree 11
predict.causalTree Make predictions from a fitted causal tree model
Description
Make predictions from a fitted causal tree model
Usage
## S3 method for class 'causalTree'
predict(object, newx, newtx = NULL,
type = c("treatment.effect", "conditional.mean", "response"),
honest = FALSE, naVal = 0, ...)
Arguments
object a fitted causalTree object
newx matrix of new covariates for which estimated treatment effects are desired
newtx option vector of new treatment assignments (only used if type = 'response')
type type of prediction required: ’treatment.effect’ returns estimated treatment effect.
’conditional.mean’ returns two predictions, one for each arm. ’response’ returns
prediction for arm corresponding to newtx.
honest logical: should honest re-estimates of leaf means be used for prediction? This
requires that x.est, tx.est, y.est were specified when the causal boosting
model was fit
naVal value with which to replace NA predictions
... ignored
Value
a vector or matrix of predictions corresponding to the rows of newx
predict.cv.causalBoosting
Make predictions from a fitted cross-validated causal boosting model
Description
Make predictions from a fitted cross-validated causal boosting model
Usage
## S3 method for class 'cv.causalBoosting'
predict(object, newx, newtx = NULL,
type = c("treatment.effect", "conditional.mean", "response"),
num.trees = object$num.trees.min.effect, naVal = 0, ...)
12 predict.pollinated.ranger
Arguments
object a fitted cv.causalBoosting object
newx matrix of new covariates for which estimated treatment effects are desired
newtx option vector of new treatment assignments (only used if type = 'individual')
type type of prediction required: ’treatment.effect’ returns estimated treatment effect.
’conditional.mean’ returns two predictions, one for each arm. ’response’ returns
prediction for arm corresponding to newtx.
num.trees number of shallow causal trees to use for prediction
naVal value with which to replace NA predictions
... ignored
Value
a vector or matrix of predictions corresponding to the rows of newx
predict.pollinated.ranger
Make predictions from a pollinated ranger random forest model
Description
Make predictions from a pollinated ranger random forest model
Usage
## S3 method for class 'pollinated.ranger'
predict(object, newx, predict.all = FALSE,
na.treatment = c("omit", "replace", "NA"), ...)
Arguments
object a fitted pollinated.ranger object
newx matrix of new covariates for which predictions are desired
predict.all logical: should predictions from all trees be returned? Otherwise the average
across trees is returned
na.treatment how to treat NA predictions from individual trees: ’omit’ only uses trees for
which the prediction is not NA. ’replace’ replaces NA predictions with the over-
all mean response. ’NA’ returns NA if any tree prediction is NA.
... additional arguments passed on to predict.ranger
Value
a vector of predicted treatment effects corresponding to the rows of newx
predict.PTOforest 13
predict.PTOforest Make predictions from a fitted PTO forest model
Description
Make predictions from a fitted PTO forest model
Usage
## S3 method for class 'PTOforest'
predict(object, newx, ...)
Arguments
object a fitted PTOforest object
newx matrix of new covariates for which estimated treatment effects are desired
... ignored
Value
a vector of predictions corresponding to the rows of newx
PTOforest Fit a pollinated transformed outcome (PTO) forest model
Description
Fit a pollinated transformed outcome (PTO) forest model
Usage
PTOforest(x, tx, y, pscore = rep(0.5, nrow(x)), num.trees = 500,
mtry = ncol(x), min.node.size = max(25, nrow(x)/40), postprocess = TRUE,
verbose = FALSE)
Arguments
xmatrix of covariates
tx vector of treatment indicators (0 or 1)
yvector of response values
pscore vector of propensity scores
num.trees number of trees for transformed outcome forest
mtry number of variables to possibly split at in each node
min.node.size minimum node size for transformed outcome forest
postprocess logical: should optional post-processing random forest be fit at end?
verbose logical: should progress be printed to console?
14 stratify
Value
an object of class PTOforest with attributes:
• x: matrix of covariates supplied by function call
• pscore: vector of propensity score supplied by function call
• postprocess: logical supplied by function call
• TOfit: fitted random forest on transformed outcomes
• PTOfit1: TOfit pollinated with treatment-arm outcomes
• PTOfit0: TOfit pollinated with control-arm outcomes
• postfit: post-processing random forest summarizing results
Examples
# Randomized experiment example
n = 100 # number of training-set patients to simulate
p = 10 # number of features for each training-set patient
# Simulate data
x = matrix(rnorm(n * p), nrow = n, ncol = p) # simulate covariate matrix
tx_effect = x[, 1] + (x[, 2] > 0) # simple heterogeneous treatment effect
tx = rbinom(n, size = 1, p = 0.5) # random treatment assignment
y = rowMeans(x) + tx * tx_effect + rnorm(n, sd = 0.001) # simulate response
# Estimate PTO forest model
fit_pto = PTOforest(x, tx, y)
pred_pto = predict(fit_pto, newx = x)
# Visualize results
plot(tx_effect, pred_pto, main = 'PTO forest',
xlab = 'True treatment effect', ylab = 'Estimated treatment effect')
abline(0, 1, lty = 2)
stratify Get propensity strata from propensity scores
Description
Get propensity strata from propensity scores
Usage
stratify(pscore, tx, min.per.arm = 30)
Arguments
pscore vector of propensity scores
tx vector of treatment indicators
min.per.arm minimum number of observations for each arm within each stratum
stratify 15
Value
a vector of integers with length equal to the length of pscore, reporting the propensity stratum
corresponding to each propensity score
