CI
-
150t
Portable Particle Counter
CLiMET’s CI-150t
Lightest and most user friendly !
CLiMET’s CI-150t is your best choice when Buying a
1CFM particle counter to monitor and validate a clean room
environment. The CI-150t is lightweight, portable
and intuitive. The CI-150t provides an ease of use
previously not available with particle counters.
It’s simplicity significantly reduces training time
for new operators.
CLiMET’s CI-150t will perform either Fed. Std. 209E, ISO 14644, or GMP calculations on acquired data
then provides a “pass/fail” report. With the color display, thermal printer and RS-232 connections, you
are able to receive visual, hard copy and digital verification of your clean room environment.
The CI-150t improves upon the Climet tradition of designing particle counters that test your clean room,
not your operators.
Please call, FAX, e-mail or visit our website to arrange for a free demonstration.
CLiMET Instruments Company 1320 West Colton Ave., Redlands, CA 92374 U.S.A.
T: (909) 793-2788 F: (909) 793-1738 E-mail: sales@climet.com Web site: www.climet.com
KEY FEATURES
• Longer Battery Life
• Bright and Beautiful TFT Display
• Stainless Steel and Lightweight
• External Horn with Volume Adjustment
TOUCHSCREEN INTERFACE
• Graphical User Interface
• Quick and Simple Setup
• Simple Adjustments
• Easier to input settings
• Simpler Navigation
COLOR DISPLAY
• Bright and Beautiful
• Easy to Read
• Reduces input Errors
STAINLESS STEEL
ENCLOSURE
• Rugged
• Stands up to Daily Cleaning
• Reduces chance of ESD
KEY BENEFITS
• Easy to Learn
• Easy to Use
• Easy to Carry
•
Samples Lon
g
er on a Sin
g
le Char
g
e
CLiMET Instruments Company
1320 W. Colton Ave., Redlands, CA 92374 U.S.A.
T: (909) 793-2788 F: (909) 793-1738
E-mail:sales@climet.com Web: www.climet.com
CLiMET is Particle Counting
MODEL CI-150t SPECIFICATIONS
SIZE SENSITIVITY: 0.30 μm
PARTICLE CHANNEL SIZES: Four sizes: 0.3, 0.5, 1.0, and 5.0 μm
SIZE RESOLUTION: 0.03 μm @ 0.33 μm (Ellipsoidal Mirror Collection System)
CONCENTRATION LIMIT: 106 Particles/ft³ @ 10%, 5x105 /ft³ @ 5%
SAMPLE FLOW RATE: 1.0 CFM (28.3 Liters per minute)
FLOW RATE CONTROL: Electronic, automatic closed loop. (Patented DC Blower System)
SAMPLE TUBE EXTENSION: 3/8” (9.525 mm) I.D., up to 20 ft. (6.1 meters) max. length
ZERO COUNT: < 1 count per 5 minutes, as per JIS 9971
BATTERY: Replaceable 9.6 Volts, 12.6 Amp hour Nickel Metal Hydride
Battery operation time: 5 to 6 hours of continuous operation
Time to charge battery: 3.0 to 3.5 hours
DISPLAY: Color TFT, ¼ VGA touch screen
PRINTER: Thermal Dot Matrix
MEMORY: 3,000 samples: Date, Time, 4 Particle Channels, Analog Channels,
Flow, ID, Sample Volume. Transferable to PC via RS-232 serial port.
UNIT ID User selectable
USER ID Up to 20 users with password authentication
SECURITY Four security levels with user authentication
LOCATION ID: Up to 100 per program; 16 characters long.
PROGRAM: Up to 30 user-defined and named, containing ID’s and settings.
REPORTS All data, Alarm data, Average data, FS-209E, ISO 14644, GMP
Reports include Unit and User ID’s
DATA INPUT/OUTPUT: RS-232
BEEP ON COUNT: 0.3 μm and greater.
AUDIBLE ALARM: Built-in
ALARM LIMITS: Programmable for all particle channels, Analog inputs, and flow.
DIMENSIONS: H-W-D: 8.65 X 8.5 X 9.5 inches (22 X 21.6 X 24.1 cm)
WEIGHT: 11.0 lb (4.99 Kg) without battery
14.25 lb (6.46 Kg) with battery
POWER: Auto switching: 85–260 VAC, 50/60 Hz
FUSES: two 5 X 20 mm, T 250C/1.0 Amp
OPERATING RANGE: 0–36º C, 10–90% RH, non-condensing
CALIBRATION: Factory Prime Calibration with monodisperse polystyrene latex spheres
traceable to NIST.
CALIBRATION FREQUENCY: Recommended every 12 months.
GAS COMPATIBILITY: Air, nitrogen; consult factory regarding other gases.
Note: Technical specifications and appearance are subject to change without notice.
